Juno Lighting Group | Juno Residential Recessed Lighting | Offering 1
Juno Recessed
Lighting
Welcome to the world of Juno Recessed Lighting. A brilliant world
where lighting is effective and efficient … blending seamlessly with
every décor … perfectly illuminating every room of the house.
Juno offers the largest selection of high-quality recessed fixtures,
incorporating industry leading performance, features and efficiency.
Flat or sloped ceilings; ambient, task or accent lighting; niches or
open spaces; Juno has a solution for every conceivable application.
Juno recessed fixtures are the favorite of contractors, architects, and
lighting designers because they offer feature-rich installation, integrate
quietly into ceilings, and present artwork, textures and architectural
features at their dramatic best. They set the mood, expand space, and
create stunning effects … all the while allowing you to navigate easily
throughout the interior of your home.
So whether you want your lighting to make a bold statement,
provide practical illumination, or both, you need to look no further
than Juno’s superb line of recessed lighting products.
Advanced illumination for the discerning homeowner
2 Juno Lighting Group | Juno Residential Recessed Lighting | Offering
The best and the brightest
Every Juno recessed fixture is designed and engineered in the United States to exacting quality
standards, employing only the finest materials and manufacturing processes. A full range of trims,
optics, and light sources ensures that you will be able to create the exact lighting effect you desire
with the economy and efficiency you demand.
In addition to its exceptional recessed fixtures, Juno offers an extensive range of track systems,
decorative pendants, and linear lighting solutions. By taking advantage of this diverse fixture
collection, you can employ layers of light to create any mood or suit any illumination requirement
throughout your home.
Since 1976, we have been providing the lighting industry with innovative products and unsurpassed
service and support. When you choose Juno fixtures for your home, rest assured you are choosing
the best and brightest.
Juno Lighting Group | Juno Residential Recessed Lighting | Offering 3
Juno Downlights are a complete line of LED, compact fluorescent, low-voltage, and incandescent
recessed luminaires for both flat and sloped ceilings. They provide high-quality illumination for all
your applications, including general, task, accent, wall-wash, and step lighting. New construction
and remodel housings are available in 2", 3", 4", 5", and 6" sizes for insulated and non-insulated
ceilings.
Housing Offering
* Based on 10 cents per KWH
Juno Air-Loc IC
w/Air-Loc Trim
or Gasket
< .1 sq. inch
0
$7.34 per fixture
Juno
Air-Loc IC
Standard
IC
Areas of Leak Path
Air Leakage
Energy Loss
Annual Energy Savings
(VS. STANDARD IC)
0
2.8 sq. inches
5 cu. ft./min.
2.6 million cu.
ft./year
.86 million
BTUs/year
2.46 sq. inches
2.6 cu. ft./min.
1.4 million cu.
ft./year
.45 million
BTUs/year
$3.53 per
fixture
Real Nail 3® Bar Hanger
The Juno originated, Real Nail bar hanger has set
the industry standard for ease of installation for
over 35 years. This 3rd generation design features
an improved range of benefits:
• Proprietary bugle-head, ring shank nail for
positive installation and simple claw hammer
removal when repositioning housings
• Integral T-bar clip for secure installation in
suspended ceilings
• Patented break-away bars for tight joist
spacings
• Curved foot facilitates alignment with joist
bottom
Air-Loc®
Juno IC housings are Air-Loc rated and designed to minimize air leak paths. Air-Loc rated
housings are tested in accordance with ASTM E283 and certified by an independent
laboratory to be in compliance with the minimum air-leakage standards as set in the
International Energy Conservation Code, as well as several state energy codes, including
Washington State. Significant cost savings are realized as summarized in the chart below:
Regulatory Listings & Standards -
Catalog Icons
• ENERGY STAR® Qualified products
• Juno's sealed recessed IC housings meet
IECC Air-Loc® Code requirements per ASTM
E283 for minimum leakage with IC housing
• Juno Downlights meet the high efficacy
requirements of California Title 24-2008
• UL and C-UL Listed for Wet Location when
used with outdoor rated lamps or when used
with lensed trims
• Many Juno Step Lights are ADA Compliant
• LED fixtures are RoHS Compliant
4 Juno Lighting Group | Juno Residential Recessed Lighting | Offering
Aesthetically Superior Trims
Juno's downlight trim offering is unparallel in the industry; choose from 3", 4", 5" and 6" baffle, cone,
wall wash, and lensed trims in an array of finishes and styles.
Clear Cone
Specular finish produces a
neutral appearance
with exceptionally
low brightness.
Haze Cone
Uniform satin finish has a
soft luminous appearance
and hides dust and fingerprints.
Blends with white ceilings and
coordinates well with cooler
interior finishes, light hard-
woods and metallic accents
such as satin nickel and
stainless steel.
Wheat Haze Cone
Offers a rich trim appearance,
and adds subtle warmth to
an interior. Coordinates well
with warmer tone interior
finishes, hardwoods and
metallic accents such as
satin brass and oil-rubbed
bronze.
Gold Cone
Specular finish with a pale
gold tint slightly warms
lamp color temperature
and provides decorative
aperture appearance.
Black Cone
Specular black finish
produces lowest possible
brightness and maximum
source concealment.
Black Baffle
Sharply defined concentric
ridges reduce trim brightness
and create a pleasing
architectural appearance.
White Baffle
Brighter appearance when
illuminated, but blends
with white ceiling when off.
Baffle
Styles
Cone Adjustable Wall Wash
Decorative Lensed
Trim Ring Finishes
ABZ - Classic Aged Bronze
BL - Black
GP - Graphite
PW - Plastic White (Polycarbonate material shower trim)
SC - Satin Chrome
SL - Silver
WH - White
Juno Lighting Group | Juno Residential Recessed Lighting | Offering 5
