63-2691-01

Cross Reference

Modutrol IV™ Motor Cross Reference

For Honeywell and Competitive Motors

1

CROSS REFERENCE

Modutrol IV™ Motor Cross Reference

FOR HONEYWELL AND COMPETITIVE MOTORS

HOW TO USE THIS MANUAL

This cross reference is intended to aid in selection of new and

replacement Modutrol IV Motors. Since publication of the

previous edition, several changes in the Modutrol IV Motor

product line have occurred. Many specialty models formerly

available are replaceable with TRADELINE® models only.

To select a Modutrol IV Motor, open to the section for the motor

under consideration. Find the motor in the left-most column and

read across the page to find appropriate replacement Modutrol

IV Motors. For column format explanations, refer to the page

preceding the table. Once you have selected a replacement

Modutrol IV Motor, turn to the Modutrol IV to Modutrol IV Motor

of this manual and compare the data for the selected motor to

the data for the original motor as well as to the application. This

will ensure proper Modutrol IV Motor selection.

Not all cross referenced motors match exactly. The comments

describe differences and indicate necessary actions when

replacing the original motor.

IMPORTANT

1. The final choice of a replacement motor is the sole decision of the purchaser. There are often several

approaches to replacing a Modutrol® Motor. Double-check each cross reference and comments to ensure

the correct motor for the application has been chosen.

2. Ensure that settings and recommendations for accessories match the application requirements.

3. Consider all discrepancies between the original motor and the selected replacement motor when deter-

mining whether the selected motor will operate as desired.

4. Report any discrepancies you find in the data to your local Honeywell Sales Representative.

Contents

Modutrol IV Cross Reference Application Notes ........ 2

Competitive Motors to Modutrol IV Motors ................. 5

Other Honeywell Motors to Modutrol IV Motors ......... 13

Modutrol I, II and III Motors to Modutrol IV Motors ..... 17

Modutrol IV Motors to Modutrol IV Motors ................. 48

Modutrol IV Accessories ............................................ 65

Modutrol IV Motor Order Number Guide

MODUTROL IV™ MOTOR CROSS REFERENCE

263-2691—01

MODUTROL IV CROSS REFERENCE APPLICATION NOTES

This section contains the application of Modutrol IV Motors in replacement situations. In

each subsection, additional data is provided about notations listed in the tables. The

notations are listed in alphabetical order with the comment in bold type. Unless

specifically noted, the data refers to any section where the comment appears.

Add Q181 for Slaved Motor Applications

Certain Modutrol II Motors included a second feedback potentiometer, which was used to

drive a second Series 90 Motor. They were the last Modutrol Motors to have this feature.

The applications that used this feature now require a Q181 mounted on the auxiliary end

of the motor to provide control of the second motor. If the master motor uses Series 90

control, (i.e., the controller is T915, L91, T921, etc.) the motors can be run in parallel by

using resistor kit 4074BYK or resistor board 221508A.

NOTE: Slaving a second motor to the master motor causes the second motor to lag the

first in operation. Depending on the Q181 and stroke adjustment, it may not

achieve full stroke. Running two Series 90 Modutrol IV Motors in parallel with

the resistor kit will synchronize operation of the two Modutrol IV Motors.

Adjustable Zero and Span

In 4 to 20 mA signal Series 70 applications, a narrower control range is required to

provide motor sequencing across the input signal. M744Y and M745Y Modutrol III

Motors and M7284Q and M7285Q Modutrol IV Motors were designed for this application.

This feature can also be obtained using the Q7230A1006 Interface Module with a Series

91 Motor. The adjustable zero feature allows you to set the point on the input signal

where the motor leaves closed and the adjustable span feature allows you to select the

change in input signal that causes the motor to run from fully open to fully closed. Refer

to Interface Module literature for details.

Auxiliary Switch Settings

When specified, the auxiliary switch setting indicates the factory set switching action. If

no setting is listed, the switches were not set at the factory and can be set at any motor

stroke position. It is the responsibility of the installer to ensure correct operation of the

auxiliary switches when the replacement Modutrol IV Motor is installed.

Check Voltage

When a comment regarding checking the original application and replacement motor

voltage supplies appears, the cross referenced motor may not have the correct voltage,

and some adjustment needs to be made. If possible, change motor voltage requirements

to agree with the application. If necessary, an internal or external transformer can be

added to the motor. If the replacement motor has a transformer where 24 Vac operation

is required, the transformer can be removed. For additional information, refer to the cross

reference listing and literature for the motor selected.

CAUTION

Equipment Damage Hazard.

Removal of an isolation transformer can result in motor damage.

Leave 24 Vac to 24 Vac isolation-type transformers in the replacement motor.

Change Control Circuit to 24 Vac

Certain Modutrol I and Modutrol II Motors were designed with line voltage submotors.

Accordingly, the controllers for these motors switched line voltage to the motor to drive

the motor open or closed. This application is similar to the external balance relay

application (see the No Internal Balance Circuit section). Modutrol III and Modutrol IV

Motors were designed with 24 Vac submotors. Motors listed as replacements for line

voltage versions list a transformer to match the original input voltage. To complete the

circuit, the switching must be changed to provide dry contact closures capable of 24 Vac

operation. A difficulty arising from this change is the requirement of supplying line voltage

to the Modutrol IV Motor. In most cases, this involves running one or two new wires to the

motor. However, if you modify the controller to supply 24 Vac to the motor coils,

additional wiring can be avoided. In this alternative, place the transformer in the circuit

ahead of both the controller and the motor and original wiring will operate.

Control Signal

This section described the various input signals listed in the signal columns:

Digital: Specifically, M7405 Economizer Motor which will operate only with T7400/

W7400 systems.

Series 40 (41): Line voltage, single pole, single throw (spst) switching. Motor runs full

stroke on contact closure, and spring-returns when contact opens.

Series 60 (61): Three-wire, single pole, double throw (spdt) switching. Responds to

either spst (three-wire) contacts or three-wire floating control (drive open, off, drive

closed). Series 60 (61) motors may be either line or low voltage. Modutrol III and

Modutrol IV Motors require low voltage switch contacts.

Series 62: similar to Series 60 (61), but includes feedback potentiometer. Responds to

either spst (three-wire) contacts or three-wire floating control (drive open, off, drive

closed). The three-wire feedback potentiometer provides a position indication to the

controller. See No Internal Balance Circuit (Series 62 Modutrol IV) section.

Series 70 (71,72,73,74,76,79): Voltage, current and specialty inputs. Appropriate input

signal is listed for each motor.

Series 80 (81): Low voltage, spst (spst) switching. Motor runs full stroke on contact

closure, and spring-returns when contact opens.

MODUTROL IV™ MOTOR CROSS REFERENCE

363-2691—01

Series 90 (91, 94) 135 Ohm: Three-wire potentiometer input. Based on 135 ohm

potentiometers found in controls such as L91, Q181, Q209, S963B, T915, T991, and

T921. The Modutrol III and Modutrol IV Motors operate with electronic Series 90 outputs

such as those found in T775E, T775F, T775G, W973B, W7100D, and W7100E. Modutrol

I and Modutrol II Motors will not operate with electronic inputs, while Modutrol III and

Modutrol IV Motors will operate with either electronic or potentiometer inputs.

SPST: See Series 40 and 80.

Thermistor: Motor works with a specific thermistor input. Consult specification for

original motor for details.

W936 (W945): The W936 are control systems utilizing a voltage output to position a

damper or valve motor. Voltage range is approximately 0.7 (fully-closed) to 1.9 Vdc (fully-

open).

Customer Names

Specific customer names in the comments column indicate the motor was originally built

around specific OEM customer application requirements. Some of the requirements

allow the original to be cross referenced to a Modutrol IV Motor. If no replacement is

listed, please contact the OEM or their local agent for assistance in replacing the original

motor.

Motor Not Crossed To Modutrol IV

If no Modutrol IV Motor cross reference is listed because of specifications, some critical

feature included in the original is not duplicated in functional replacements or

TRADELINE motors. In these cases, the original motor will cross reference to itself,

rather than to a Modutrol IV Motor and no TRADELINE model will be listed. For further

information on these motors, contact your local Honeywell sales representative.

NOTE: Consider all Modutrol I, II and III Motors obsolete.

No Internal Balance Circuit (Series 62 Modutrol IV)

When Modutrol Motors included a mechanical balance relay (Modutrol I and II), they

were susceptible to vibration. To solve this issue, a Series 90 Modutrol Motor was

designed which allowed the balance relay to be remote-mounted in a location with less

or no vibration. The motors were the M944E,B,G,S, M945B,C,G. The balance relay was

the R927. The motor-relay combination acted the same as a Series 90 Modutrol Motor.

These motors were also used with other controllers over the years and, as a result, the

Series 90 designation is confusing. With the introduction of Modutrol IV Motors, these

motors were designated Series 62. The motor acts on inputs exactly the same as Series

61. It also includes a feedback potentiometer. To use Series 62 Modutrol IV Motors in

R927 applications, a Q181 feedback potentiometer is required to provide the feedback

signal to the R927. The higher current of the R927 burns out the Series 62 Modutrol IV

Motor internal feedback potentiometer. A low current source does not. This allows it to be

used in applications requiring position feedback to a control system.

NOTE: When replacing a motor that was connected to a balancing relay, Honeywell

recommends performing a retrofit to remove the relay and the old motor.

Replace both with one Series 90 Modutrol IV motor (that is, do not replace the

relay).

Normally Open (N.O.) / Normally Closed (N.C.)

This indicates how the motor rotates, usually in reference to the spring return action. It

also indicates electrical response to input signals. Most motors are normally closed, so

unless normally open is indicated, the motor is normally closed. When referencing

electrical operation, this indicates response to the input signal. Viewed from the power

end of motor, an increase in signal causes the shaft to rotate clockwise for a normally

closed motor. A normally open motor rotates counterclockwise on the same signal

increase. When the signal is removed, all motors (except for Series 60 and 62) return to

normal position, closed for normally closed, or open for normally open.

Set To... (Voltage, Current, or Rotation)

A note specifying a signal range or rotation choice indicates a setting on the interface

module listed under Accessories. Please refer to the literature shipped with the interface

module for details.

Ship Position (90 Or 160 Degrees)

Indicates factory stroke setting of adjustable stroke motors. TRADELINE models are

shipped in the 160 degree position. To adjust the stroke setting, refer to the literature

shipped with the Modutrol IV Motor.

Tapped Auxiliary Shaft

These motors include a tapping in the auxiliary shaft end as well as in the power shaft.

Some OEM customers use this tapping to mount specific accessories to the motor when

used in their equipment. The tapping is 8-32 UNC-2B x 0.56 in. deep.

MODUTROL IV™ MOTOR CROSS REFERENCE

463-2691—01

TRADELINE

Indicates the original motor is a TRADELINE model. Modutrol IV TRADELINE Motors

have the following features: 24 Vac, cams installed for addition of auxiliary switches,

adjustable stroke (except for M6285A1005 and M6285A1013), and the auxiliary end

shaft can accept a Q5001 Valve Linkage. There are several Modutrol IV TRADELINE

Motors that cover the entire range of input signals. Each motor can be configured to

replace multiple other models.

25 Hz

Motors marked 25 Hz were designed to operate at a line or low voltage with 25 Hz rather

than 50/60 Hz. Motors not specifically indicated are 50/60 Hz.

Unidirectional Drive

Specifically, some competitive motors and Modutrol I M204 motors are listed as

unidirectional drive. This indicates a SPDT, low-voltage control circuit. On the initial call,

the motor rotates clockwise through 180 degrees. On the second call, the motor rotates

clockwise another 180 degrees to return to normal position.

Weather Kit Installed

This indicates the appropriate weatherproofing kit is installed at the factory. Modutrol IV

Motors are rated at NEMA 3 when mounted in an upright position. Addition of a

weatherproofing kit extends this rating to side and upside down mounting arrangements.

IMPORTANT

In all applications, the motor must be mounted with the shaft horizontal to main-

tain normal motor life.

NOTE: Motors previous to Modutrol IV are not NEMA rated and therefore required a

weatherproofing kit that requires a NEMA 3 rating, regardless of mounting ori-

entation.

MODUTROL IV™ MOTOR CROSS REFERENCE

563-2691—01

COMPETITIVE MOTORS TO MODUTROL IV MOTORS

This section cross references motors produced by Barber-Colman, Johnson, and White

Rodgers to Modutrol IV Motors. Please refer to the Application Notes section for specific

comments.

Cross Reference Format

Information contained in individual rows refer to the motor listed in the OS # to be

Replaced column unless otherwise noted in the Comments column. Following is an

example of the format used in this section and explanations of each column.

1. Lists the original motor to be replaced.

2. Lists the Modutrol IV TRADELINE Replacement Motor. This TRADELINE motor

may require configuration with the accessories listed in columns 3 through 7 and

15.

3. Specifies which internal mount transformer, if any, is required to match the original

motor voltage. The transformer choices are:

a. 198162AA – 120/208/240 Vac, 50/60 Hz (multi-tap).

b. 198162EA – 120 Vac, 50/60 Hz.

c. 198162GA – 220 Vac, 50/60 Hz.

d. 198162JA – 24 Vac, 50/60 Hz (isolation).

4. Specifies which field-addable auxiliary switch, if any, is required to match the

original motor. The switch kit choices are:

a. 220736A – one spdt switch and mounting bracket.

b. 220736B – two spdt switches and mounting bracket.

5. Specifies which accessory parts or devices, if any, are required to complete the

replacement. Items include Weatherproofing Kits, Minimum Position

Potentiometers, and linkages. Check the original application to ensure that you

account for all modifications of the original motor.

6. Specified stroke setting of the Modutrol IV TRADELINE Motor. 12 of the 14

TRADELINE models have adjustable stroke. The remaining two (M6285A) are

fixed stroke. “ADJ” listed here indicates the original motor also had adjustable

stroke. Check the application to duplicate the original stroke requirements.

7. Lists the voltage of the original motor.

8. Lists the torque rating of the original motor.

9. Lists the full stroke rotation of the original motor (closed to open) in angular

degrees. Two values with a “-” indicate a range of adjustment available in the field.

10. Lists the timing of the original motor. If two or adjustable stroke is listed in

column 10, the time refers to a 160 degree stroke.

11. Lists the number of auxiliary switches, if any in the original motor.

12. Lists the control signal of the motor. The listing can specify either an actual value of

signal input, or a “Series” designation. Please refer to the Application Notes

section in this manual.

13. Lists the functional Modutrol IV Motor replacement. In some cases, the replace-

ment will have additional features not found in the original motor. This column can

also specify “+” and an accessory. This indicates a minor addition to the functional

replacement will provide the functionality required in the application.

14. Comments listed in this column provide additional information to consider when

replacing the original motor. Consider differences carefully prior to installation of

the Modutrol IV TRADELINE Motor.

IMPORTANT

When replacing competitive motors, check the valve or damper linkage. In

some cases, both the motor and the linkage will require replacement due to

physical size incompatibility between the Modutrol IV Motors and some

competitive motors.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement Comments

Model

Number Required

Transformer Required

Aux. Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

1 2 3 4 5 6 7 8 9 10 11 12 13 14

MODUTROL IV™ MOTOR CROSS REFERENCE

663-2691—01

Table 1. Competitive Modutrol Motor Cross Reference.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

BARBER COLMAN - TAC

MA-12313 None 24 25 75-180° 28 spst M8415A1004 90 sec, 1 aux switch

MA-12323 None 24 25 75-180° 28 2 spst M8415A1004

MA-305 None 24 16 180° 20 spst M836A1042 75° stroke, 30 sec, 32-125°F

MA-305-500 None 24 16 180° 20 1 spst M836A1042

MA-318 M8185D1006 160° 24 60 180° 20 spst M8185D1006 160° stroke, 60 sec

MA-318-500 M8185D1006 220736A 160° 24 60 180° 20 1 spst None

MA-405 None 120 16 180° 20 spst M436A1116 75° stroke, 30 sec, 32-125°F

MA-405-500 None 120 16 180° 20 1 spst M436A1116

MA-406 None 208 16 180° 20 spst M836A1042 Requires 208 Vac transformer

MA-406-500 None 208 16 180° 20 1 spst M836A1042

MA-407 None 240 16 180° 20 spst M436A1124 75° stroke, 30 sec, 32-125°F

MA-407-500 None 240 16 180° 20 1 spst M436A1124

MA-416 M8185D1006 50017460-001 160° 208 60 180° 20 spst M4185B1058 160° stroke, 60 sec

M8185D: 60 sec

MA-416-500 M8185D1006 50017460-001 220736A 160° 208 60 180° 20 1 spst M4185B1058

MA-418 M8185D1006 50017460-003 160° 120 60 180° 20 spst M4185A1001

MA-418-500 M8185D1006 50017460-003 220736A 160° 120 60 180° 20 1 spst M4185B1009

MA-419 M8185D1006 50017460-001 160° 240 60 180° 20 spst M4185B1058 160° stroke, 60 sec

TRADELINE is 60 sec

MA-419-500 M8185D1006 50017460-001 220736A 160° 240 60 180° 20 1 spst M4185B1058

MA-5330 None 120 20 2 spst None MA-5330: Damper DCA

MA-5333 None 24 20 2 spst None MA-5333: Damper DCA

MA5-419 M8185D1006 50017460-001 160° 240 60 170° 20 spst M4185B1058 MA5 includes special

MA5-419-500 M8185D1006 50017460-001 220736A 160° 240 60 170° 20 1 spst M4185B1058

MC-351 M6194D1017 220736A 160° 24 220 180° 70 1 spdt None Original: unidirectional operation

TRADELINE is 240 sec

MC-421 M6184D1035 50017460-003 220736A 160° 120 175 180° 20 1 spdt None Original: unidirectional operation

TRADELINE is 60 sec

MC-431 M6194D1017 50017460-001 220736A 160° 120 220 180° 30 1 spdt None Original: unidirectional operation

TRADELINE is 240 sec

MODUTROL IV™ MOTOR CROSS REFERENCE

763-2691—01

MC-4311 M6194D1017 50017460-001 220736A 160° 240 220 180° 30 1 spdt None

MC5-4311 M6194D1017 50017460-001 220736B ES-650 160° 120 220 180° 36 1 spdt None Original: unidirectional operation

TRADELINE is 240 sec; ES-650 is

explosion proof housing (see

Accessories)

MC-9610 None 120 1100 180° 65 1 spdt None Original: unidirectional operation

MC-9810 None 120 1300 180° 115 1 spdt None

ME-12313 None 24 25 110° 28

(90°) 3-position M8405A1006 Original: economizer

ME-12313-102 None 24 25 110° 28

(90°) 2 3 position M8405A1006

MP-2110 None 120 50 180° 25 1 CP-8000 None

MP-2113-500 M6184D1035 220736A 160° 24 50 180° 25 1 spdt M6184D1001 + Q607A 75 lb-in, 60 sec

TRADELINE is 60 sec, 150 lb-in

MP-2130-500 M6184D1035 50017460-003 220736A 90° 120 50 90° 13 1 spdt M6184D1001 + Q607A

MP-2150-500 M6184D1035 50017460-003 220736A 160° 120 50 180° 25 1 spdt M6184A1023 + Q607A

MP-2151-500 M6184D1035 50017460-001 220736A 160° 240 50 180° 30 1 spdt None TRADELINE is 60 sec, 150 lb-in

MP-371 M6294D1008-S 220736A 160° 24 50 180° 90 1 spdt None TRADELINE is 160°, 240 sec

MP-381 M6194D1017 220736A 160° 24 220 180° 130 1 spdt None Replacement is 160°, 240 sec

TRADELINE is 160°, 240 sec

MP-481 M9194D1003 50017460-003 220736A Q7230A 160° 120 220 180° 130 1 2-15 Vdc None Set signal range

MP-483-600 M6294D1008-S 50017460-003 220736A 90° 120 220 90° 65 1 spdt M6294D1008-S Check timing and stroke

MP-485 M6194D1017 50017460-003 220736A 160° 120 220 180° 130 1 spdt None

MP-4851 M6294D1008-S 50017460-001 220736A 160° 240 220 180° 130 1 CP-8000 None

MP-486 M6294D1008-S 50017460-003 220736A 160° 120 220 180° 130-

1300 1 spdt None

MP-9710 None 120 800 180° 135 1 Proportional None

MU-12313 None 24 25 90° 28 Economizer M7415A1006

PENN JOHNSON

M110AAB-1 M8185D1006 50017460-003 220736A ADJ 120 25 45-270° 60 1 None

M110AGA-1 M8185D1006 ADJ 24 25 45-270° 60 None

M110AGB-1 M8185D1006 220736A ADJ 24 25 45-270° 60 1 None

Table 1. Competitive Modutrol Motor Cross Reference.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

863-2691—01

M110GGA-1 M9185D1004 220738A Q7230A None

M110JGA-1 M9185D1004 ADJ 24 25 65-270° 60 M9184D1004 + 220738A Replacement is 90°-160° stroke

M110JGB-1 M9185D1004 220736A ADJ 24 25 65-270° 60 M9184D1004 + 220738A

M110QGA-1 None None

M120AAA-1 M6184D1035 50017460-003 ADJ None

M120AAB-1 M8185D1006 50017460-003 220736A ADJ None

M120AAC-1 M6184D1035 50017460-003 220736B ADJ None

M120AGA-1 M6184D1035 ADJ None

M120GGA-1 M9164D1009 Q7230A ADJ None Select signal range

M120JAA-1 M9164D1009 50017460-003 ADJ 120 35 65-270° 60 M9164D1009 Replacement is 90°-160° stroke

M120JAC-1 M9164D1009 220736B ADJ 24 35 65-270° 60 2 M9164C1068

M120JGA-1 M9164D1009 ADJ 24 35 65-270° 60 M9164A1005 M9164A1005: wire to 24 Vac

M120QGA-1 None None

M130AGA-1 M8185D1006 ADJ 24 50 45-270° 60 None Replacement is 90°-160° stroke

M130AGB-1 M8185D1006 220736A ADJ 24 50 45-270° 60 1 None

M130GGA-1 M9185D1004 ADJ 24 50 65-270° 60 M7285Q1008 Replacement is 90°-160° stroke

M130JGA-1 M9185D1004 ADJ 24 50 65-270° 60 M9185A1018

M130JGB-1 M9185D1004 220736A ADJ 24 50 65-270° 60 1 M9185E1019 Replacement is 90°-160° stroke

M130QGA-1 None None

M140AAA-1 M6184D1035 ADJ None

M140AGA-1 M6184D1035 ADJ None

M140GGA-1 M9174D1007 Q7230A ADJ None Select signal range

M140JAA-1 M9174D1007 50017460-003 ADJ 120 70 65-270° 60 M9174D1007 Replacement is 90°-160° stroke

M140JGA-1 M9174D1007 ADJ 24 70 65-270° 60 M9174D1007

M150AGA-1 M6184D1035 ADJ 24 150 65-270° 60 M6184D1035

M150AGB-1 M6184D1035 220736A ADJ 24 150 65-270° 60 1 None

M150GGA-1 M9184D1021 220738A Q7230A ADJ None Select signal range

M150JGA-1 M9184D1021 ADJ 24 150 65-270° 60 M9184A1019

M150JGB-1 M9184D1021 220736A ADJ 24 150 65-270° 60 1 M9184F1034 Replacement is 90°-160° stroke

M150JGC-1 M9184D1021 220736B ADJ 24 150 65-270° 60 2 M9184F1034

Table 1. Competitive Modutrol Motor Cross Reference.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

963-2691—01

M150QGA-1 None 24 150 65-270° 60 M7284Q1009

M40AAA-1 M9164D1009 50017460-003 90° 120 35 90° 34 M9164A1005

M40AAC-1 M9164D1009 50017460-003 220736B 90° 120 35 90° 34 2 M9164C1068

M40AGA-1 M6184D1035 90° 24 35 90° 34 M6184A1015

M40AGC-1 M9164D1009 220736B 90° 24 35 90° 34 2 None

M80AAA-3 M6284D1000-S M6284F1013-S Check voltage & stroke of motor

M80AAB-1 M6284D1000-S 220736B M6284F1013-S

M80ACA-1 M6285A1005-S M6285A1005-S Check voltage & stroke of motor

M80ADA-1 M6285A1005-S M6285A1005-S

M80BAA-1 M9184D1021 M9184A1019

M80BAA-4 None M9184D1005

M80BCA-1 M9185D1004 M9185D1004

M80BDA-1 M9185D1004 M9185D1004

M80BEA-1 M9185D1004 M9185A1018 replacemement is Nornally Closed

M80FAA-2 M9184D1021 M9184A1019 Check voltage & stroke of motor

M80FCA-2 M9185D1004 M9185D1004

M80FDA-1 M9185D1004 M9185D1004

M80FEA-1 M9185D1004 M9185A1018 Replacement is Normally Closed

M80FFA-1 M9185D1004 M9185A1018 Check voltage & stroke of motor

M80HAB-1 M9184D1021 M9184F1034

M80HAC-1 M9184D1021 M9184F1034

M80JAA–2 M9184D1021 ADJ 24 150 65-240° 60 M9184A1019 Replacement is 90°-160° stroke

M80JAB–1 M9184D1021 220736A ADJ 24 150 65-240° 60 1 M9184F1034

M80JAC–1 None 24 150 65-240° 60 2 M9484E1017

M80JCA–2 M9185D1004 ADJ 24 50 65-180° 60 M9185A1018

M80JCB–1 M9185D1004 220736A ADJ 24 50 65-180° 60 1 M9185E1019

M80JDA-1 None None

M80JFA-1 None None

M81AAA–12 M6184D1035 ADJ 24 150 65-270° 60 M6184F1014 Replacement is 90°-160° stroke

M81AAA–13 M6184D1035 ADJ 24 80 65-270° 30 M6184D1001

Table 1. Competitive Modutrol Motor Cross Reference.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

10 63-2691—01

M81AAB–5 M6184D1035 220736A ADJ 24 150 65-270° 60 1 M6184F1014

M81AAC-1 M6184D1035 M6184F1014

M81ACA-3 M8185D1006 160° 24 50 160° 60 M8185D1006

M81ACB-1 M8185D1006 220736A 160° 24 50 160° 60 1 None

M81ADA-2 M8185D1006 50017460-001 160° MULTI 75 160° 60 M4185B1058

M81AEA-2 M8185D1006 50017460-001 160° MULTI 75 160° 60 M4185B1009

M81AFA-2 M8185D1006 160° 24 50 160° 60 None Use aux shaft

M81AFB-1 M8185D1006 50017460-001 M4185B1058 Check stroke and aux switch

WHITE RODGERS

3402–7 None 24 25 110° M8415A1004 90 sec, 90°

3402A–7 None 120 25 110° None

3403–4 None 24 25 110° M8405A1006 90 sec, 90°

3405–2 None 24 20 90° M836A1042 30 sec, 75°

3405–3 None 24 25 90° M836A1042

3405A–2 None 120 25 90° M436A1116

3405–11 None 24 25 90° 1 M836A1042 30 sec, 75°

3405A–11 None 120 25 90° 1 M436A1116

3405–14 None 24 25 90° 1 M836A1042

3420–4 M9185D1004 220738A 24 25 90° M9185D1004 W/220738A 30 sec

3420A–4 M9185D1004 50017460-003 220738A 120 25 90° M9185D1004 W/220738A

3430–7 None 24 25 90° M7415A1006 30 sec

3430-18 None 24 25 90° 25 None

3430-21 None 24 25 90° 25 None

3440–4 M9184D1021 24 100 160° 30 M9184A1019 150 lb-in, 60 sec

SIEMENS

SQM50.261R1G3 110 90 8 4-20mA M7284C1000 Q607 to add more switches

SQM50.261R1Z3 110 90 8 all M9184C1031+

Q7230A1005+50017460-

003

Q607 to add more switches

SQM50.264R1G 110 90 8 4-20mA M7284C1000 Q607 to add more switches

SQM50.264R1G4 110 90 8 4-20mA M7284C1000 Q607 to add more switches

Table 1. Competitive Modutrol Motor Cross Reference.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

11 63-2691—01

SQM50.264R1Z3 110 90 8 all M9184C1031+

Q7230A1005+50017460-

003

Q607 to add more switches

SQM50.361R1G 110 140 12 4-20mA M7284C1000 Q607 to add more switches

SQM60.361r1z3 110 140 12 all M9184C1031+

Q7230A1005+50017460-

003

Q607 to add more switches

SQM50.364R1G 110 140 12 4-20mA M7284C1000 Q607 to add more switches

SQM50.364R1Z3 110 140 12 all M9184C1031+

Q7230A1005+50017460-

003

Q607 to add more switches

SQM50.461R1G3 110 140 25 4-20mA M7284C1000 Q607 to add more switches

SQM50.461R1H3 110 140 25 135 ohm M9184C1031+50017460-

003 Q607 to add more switches

SQM50.461R1Z 110 140 25 all M9184C1031+

Q7230A1005+50017460-

003

Q607 to add more switches

SQM50.464R8G 24 140 25 4-20mA M7284C1000+50017460-

001 Q607 to add more switches

SQM50.464R1G 110 140 25 4-20mA M7284C1000 Q607 to add more switches

SQM50.464R1H3 110 140 25 135 ohm M9184C1031+50017460-

003 Q607 to add more switches

SQM50.464R8H3 24 140 25 135 ohm M9184C1031 Q607 to add more switches

SQM50.464R1Z3 110 140 25 all M9184C1031+

Q7230A1005+50017460-

003

Q607 to add more switches

SQM50.464R2Z3 220 140 25 all M9184C1031+

Q7230A1005+50017460-

001

Q607 to add more switches

SQM50.464R8Z3 24 140 25 all M9184C1031+

Q7230A1005 Q607 to add more switches

SQM53.461R1Z3 110 200 25 all M9194D1003+220736+

Q7230A1005+50017460-

003

Q607 to add more switches

SQM53.464R1G 110 200 25 4-20mA M7294A1010+220736B Q607 to add more switches

Table 1. Competitive Modutrol Motor Cross Reference.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

12 63-2691—01

SQM53.464R1Z3 110 200 25 all M9194D1003+220736B+

Q7230A1005+50017460-

003

Q607 to add more switches

SQM53.464R2Z3 220 200 25 all M9194D1003+220736B+

Q7230A1005+50017460-

001

Q607 to add more switches

SQM56.564R1G 110 310 37 4-20mA M7294A1010+220736B Q607 to add more switches

SQM56.564R1H4 110 310 37 135 ohm M9194D1003+220736B+5

0017460-003 Q607 to add more switches

SQM56.564R1Z3 110 310 37 all M9194D1003+220736B+

Q7230A1005+50017460-

003

Q607 to add more switches

SQM56.664R1G3 110 400 50 4-20mA M7294A1010+220736B Q607 to add more switches

SQM56.664R2G3R 220 400 50 4-20mA M7294A1010+220736B+5

0017460-001 Q607 to add more switches

SQM56.664R1H3 110 400 50 135 ohm M9194D1003+220736B+5

0017460-003 Q607 to add more switches

SQM56.664R1Z3 110 400 50 all M9194D1003+220736B+

Q7230A1005+50017460-

001

Q607 to add more switches

SQM56.667R1G 110 400 50 4-20mA M7294A1010+220736B Q607 to add more switches

SQM56.667R1Z3 110 400 50 all M9194D1003+220736B+

Q7230A1005+50017460-

001

Q607 to add more switches

Table 1. Competitive Modutrol Motor Cross Reference.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

13 63-2691—01

OTHER HONEYWELL MOTORS TO MODUTROL IV MOTORS

This section cross references motors produced by Honeywell (which are not Modutrol

Motors) to Modutrol IV Motors where appropriate. Please refer to the Application Notes

section for specific comments.

Cross Reference Format

Information contained in individual rows refer to the motor listed in the OS # to be

Replaced column unless otherwise noted in the Comments column. Following is an

example of the format used in this section and explanations of each column.

1. Lists the original motor to be replaced.

2. Lists the Modutrol IV TRADELINE Replacement Motor. This TRADELINE motor

may require configuration with the accessories listed in columns 2 through 7 and

15.

3. Specifies which internal mount transformer, if any, is required to match the

original motor voltage. The transformer choices are:

a. 198162AA – 120/208/240 Vac, 50/60 Hz (multi-tap).

b. 198162EA – 120 Vac, 50/60 Hz.

c. 198162GA – 220 Vac, 50/60 Hz.

d. 198162JA – 24 Vac, 50/60 Hz (isolation).

4. Specifies which field-addable auxiliary switch, if any, is required to match the origi-

nal motor. The switch kit choices are:

a. 220736A – one spdt switch and mounting bracket.

b. 220736B – two spdt switches and mounting bracket.

5. Specifies which accessory parts or devices, if any, are required to complete the

replacement. Items include Weatherproofing Kits, Minimum Position

Potentiometers, and linkages. Check the original application to ensure that you

account for all modifications of the original motor.

6. Specified stroke setting of the Modutrol IV TRADELINE Motor. 12 of the 14

TRADELINE models have adjustable stroke. The remaining two (M6285A) are

fixed stroke. “ADJ” listed here indicates the original motor also had adjustable

stroke. Check the application to duplicate the original stroke requirements.

7. Lists the voltage of the original motor.

8. Lists the torque rating of the original motor.

9. Lists the full stroke rotation of the original motor (closed to open) in angular

degrees. Two values with a “-” indicate a range of adjustment available in the field.

10. Lists the timing of the original motor. If two or adjustable stroke is listed in

column 10, the time refers to a 160 degree stroke.

11. Lists the number of auxiliary switches, if any in the original motor.

12. Lists the control signal of the motor. The listing can specify either an actual value of

signal input, or a “Series” designation. Please refer to the Application Notes sec-

tion in this manual.

13. Lists the functional motor replacement. In some cases, the replacement will have

additional features not found in the original motor. This column may also

specify “+” and an accessory. This indicates a minor addition to the functional

replacement will provide the functionality required in the application.

14. Comments listed in this column provide additional information to consider when

replacing the original motor. Consider differences carefully prior to motor

installation.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement Comments

Model

Number Transformer Aux.

Switch Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(seconds) Aux.

Sw Control

Signal

1 2 3 4 5 678 9 101112 13 14

MODUTROL IV™ MOTOR CROSS REFERENCE

14 63-2691—01

Table 2. Other Honeywell Motors to Modutrol IV Motors.

OS # to be

Replaced

Original Motor Specifications

Functional Replacement Comments

Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees)

Timing

(secon

ds) Aux.

Sw Control

Signal

M436A1009 120 20 75° 30 1 Series 40 M436A1116

M436A1017 120 20 75° 30 1 Series 40 M436A1116

M436A1025 240 20 75° 30 1 Series 40 M436A1124

M436A1033 240 20 75° 30 1 Series 40 M436A1124

M436A1041 120 20 75° 30 1 Series 40 M436A1116

M436A1058 240 20 75° 30 1 Series 40 M436A1124

M436A1066 240 20 75° 50 1 Series 40 M436A1124 M436A1124 has 30 sec timing

M436A1074 220 20 75° 50 1 Series 40 M436A1140 M436A1140 has 50 sec timing

M436A1082 120 20 75° 30 1 Series 40 M436A1116

M436A1090 120 20 75° 30 1 Series 40 N/A

M436A1108 240 20 75° 30 1 Series 40 M436A1124

M436A1116 120 20 75° 30 1 Series 40 N/A

M436A1124 240 20 75° 30 1 Series 40 N/A

M436A1132 240 20 75° 50 1 Series 40 M436A1140 M436A1124 has 30 sec timing

M436A1140 220 20 75° 50 1 Series 40 N/A

M436A1157 120 20 75° 30 1 Series 40 M436A1116

M436A1165 120 20 75° 30 1 Series 40 M436A1090 Ray Special

M436A1173 240 20 75° 40 1 Series 40 M436A1124 M436A1124 has 30 sec timing

M6414A1009 24 25 90° 90 1 spdt floating None

M6415A1008 24 25 90° 90 1 spdt floating None Trane Special, CCW Open

M6415A1016 24 25 90° 90 1 spdt floating N/A CCW to Open

M6415B1006 24 25 90° 90 spdt floating None Trane Special, CCW Open

M6415B1014 24 25 90° 90 spdt floating N/A CW to Open

M7405A1008 24 25 90° 90 Digital None

M7405A1016 24 25 90° 90 Digital none

M7415A1006 24 25 90° 90 Thermistor M7415A1006

M7415A1014 24 25 90° 90 Thermistor M7415A1006 York Special

M7415A1022 24 25 90° 90 Thermistor M7415A1006

M7415A1048 24 25 90° 90 Thermistor M7415A1006

M7415B1004 24 25 90° 90 Thermistor N/A Opens CW, spring return CCW

MODUTROL IV™ MOTOR CROSS REFERENCE

15 63-2691—01

M828A ALL 120/240 25 None None Series 80 M836A1042

M828B ALL 120/240 25 None None Series 80 M836A1042

M828C ALL 24 40 None None Series 80 M836A1042

M828D ALL 24 40 None None Series 80 M836A1042

M828X ALL 120/208 25 None None Series 80 M836A1042

M829A ALL 24 3 75° None 1 Series 80 None Rewire & replace control system with M835

M833A1007 24 6 90° 15M Series 80 None

M833A1015 24 6 90° 15M Series 80 none

M833A1023 24 6 90° 15M Series 80 None G.E. Special, special rotation, Lennox

M833A1031 24 6 90° 15M Series 80 None Trane Special, special rotation

M835A1002 24 4 80° 80 Series 80 M835A1051

M835A1010 24 4 80° 80 1 Series 80 M835A1051 Reset heat anticipator setting

M835A1028 24 4 80° 80 1 Series 80 M835A1051

M835A1036 24 4 80° 80 1 Series 80 M835A1051

M835A1044 24 4 80° 80 1 Series 80 M835A1051 Reset heat anticipator setting

M835A1051 24 4 80° 80 1 Series 80 N/A Tradeline

M835A1069 24 4 80° 80 1 Series 80 M835A1051

M836A1000 24 20 80° 30 1 Series 80 M836A1042

M836A1018 24 20 75° 30 1 Series 80 M836A1042

M836A1026 24 20 75° 50 1 Series 80 M836A1042 International

M836A1034 24 20 75° 30 1 Series 80 M836A1042

M836A1042 24 20 75° 30 1 Series 80 N/A Tradeline

M836A1059 24 20 75° 50 1 Series 80 M836A1042 International

M836A1067 24 20 75° 30 1 Series 80 M836A1042

M836A1075 24 20 75° 30 1 Series 80 M836A1042 Coleman Special

M836B1009 24 15 75° 25 1 Series 80 M836B1033

M836B1017 24 15 75° 25 1 Series 80 M836B1033

M836B1025 24 15 75° 25 1 Series 80 M836B1033

M836B1033 24 15 75° 25 1 Series 80 N/A Tradeline

M836B1041 24 15 75° 25 1 Series 80 M836B1033 Carrier Special

Table 2. Other Honeywell Motors to Modutrol IV Motors.

OS # to be

Replaced

Original Motor Specifications

Functional Replacement Comments

Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees)

Timing

(secon

ds) Aux.

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

16 63-2691—01

M8405A1006 24 25 90° 90 spst N/A

M8405A1014 24 25 90° 90 spst M8405A1006 York Special

M8405B1004 24 25 90° 90 spst None Carrier Special

M8414A1005 24 25 90° 90 1 spst None Non spring return

M8415A1004 24 25 90° 90 1 spst N/A

M842A1008 24 6 90° 18M Series 80 N/A

M847A1008 24 2 45° 20 Series 80 M847A1080

M847A1023 24 2 45° 20 Series 80 M847A1072

M847A1031 24 2 45° 20 Series 80 M847A1080 Canada only, with 38 in. chain linkage & extended mount bracket

M847A1049 24 2 45° 20 Series 80 M847A1072 Canada Special with disengaging actuator arm

M847A1056 24 2 45° 20 Series 80 M847A1072 Arm not mounted

M847A1064 24 2 45° 20 Series 80 M847A1072

M847A1072 24 2 45° 20 Series 80 N/A With disengaging actuator arm

M847A1080 24 2 45° 20 Series 80 N/A With 38 in. chain linkage, with extended mount bracket

M847A1098 24 2 45° 20 Series 80 M847A1098 Canada Special, with disengaging actuator arm, extended

mounting bracket included

M984B1015 24 45 90° 18 1 135 ohm None Canada Versa Drive

M986A1011 24 45 90° 18 135 ohm None

M986B1002 24 45 90° 18 1 135 ohm None

ML984A1030 24 160 lb 0.75 in. 60 135 ohm None Canada Special

ML984B1004 24 80 lb 0.75 in. 75 135 ohm None Liebert Special, no balance relay, with feedback potentiometer

Table 2. Other Honeywell Motors to Modutrol IV Motors.

OS # to be

Replaced

Original Motor Specifications

Functional Replacement Comments

Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees)

Timing

(secon

ds) Aux.

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

17 63-2691—01

MODUTROL I, II AND III MOTORS TO MODUTROL IV MOTORS

This section cross references Honeywell motors (produced from 1936 to 1991) to

Modutrol IV Motors. Please refer to the Application Notes section for specific comments.

Cross Reference Format

Information contained in individual rows refer to the motor listed in the OS # to be

Replaced column unless otherwise noted in the Comments column. Following is an

example of the format used in this section and explanations of each column.

1. Lists the original motor to be replaced.

2. Lists the Modutrol IV TRADELINE Replacement Motor. This TRADELINE motor

can require configuration with the accessories listed in columns 3 through 6 and 15.

3. Specifies which internal mount transformer, if any, is required to match the original

motor voltage. The transformer choices are:

a. 198162AA – 120/208/240 Vac, 50/60 Hz (multi-tap).

b. 198162EA – 120 Vac, 50/60 Hz.

c. 198162GA – 220 Vac, 50/60 Hz.

d. 198162JA – 24 Vac, 50/60 Hz (isolation).

4. Specifies which field-addable auxiliary switch, if any, is required to match the

original motor. The switch kit choices are:

a. 220736A – one spdt switch and mounting bracket.

b. 220736B – two spdt switches and mounting bracket.

5. Specifies which accessory parts or devices, if any, are required to complete the

replacement. Items include Weatherproofing Kits, Minimum Position

Potentiometers, and linkages. Check the original application to ensure that you

account for all modifications of the original motor.

6. Specified stroke setting of the Modutrol IV TRADELINE Motor. 12 of the 14

TRADELINE models have adjustable stroke. The remaining two (M6285A) are

fixed stroke. “ADJ” listed here indicates the original motor also had adjustable

stroke. Check the application to duplicate the original stroke requirements.

7. Lists the voltage of the original motor.

8. Lists the torque rating of the original motor.

9. Lists the full stroke rotation of the original motor (closed to open) in angular

degrees. Two values with a “-” indicate a range of adjustment available in the field.

10. Lists the timing of the original motor. If two or adjustable stroke is listed in column

10, the time refers to a 160 degree stroke.

11. Lists the number of auxiliary switches, if any in the original motor.

12. Lists the control signal of the motor. The listing can specify either an actual value of

signal input, or a “Series” designation. Please refer to the Application Notes

section in this manual.

13. Lists the functional Modutrol IV Motor replacement. In some cases, the replace-

ment will have additional features not found in the original motor. This column may

also specify “+” and an accessory. This indicates a minor addition to the functional

replacement will provide the functionality required in the application.

14. Comments listed in this column provide additional information to consider when

replacing the original motor. Consider differences carefully prior to installation of

the Modutrol IV TRADELINE Motor.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement Comments

Model

Number Required

Transformer Required

Aux. Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

1 2 3 4 5 6 7 8 9 10 11 12 13 14

MODUTROL IV™ MOTOR CROSS REFERENCE

18 63-2691—01

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

M204A1001 None 24 37 180 15 Series 20 M6184D1001 Unidirectional stroke; Replacement is 160°,

30 sec timing

M204A1019 M6184D1035 160° 24 54 180 30 Series 20 M6184D1001 Unidirectional stroke

M204A1027 None 24 54 30 54 Series 20 None Unidirectional stroke; For use with 25 Hz

M204A1035 M6184D1035 160° 24 108 180 60 Series 20 M6184D1035 Unidirectional stroke; Replacement is 160°

M204A1043 None 24 108 180 60 Series 20 None Unidirectional stroke; 25 Hz

M204A1050 M6184D1035 160° 24 108 180 240 Series 20 M6194D1017 Unidirectional stroke; Replacement is 160°,

300 lb-in.

M204A1068 M6184D1035 160° 24 108 180 60 Series 20 M6184D1035 Unidirectional stroke; Replacement is 160°

M204B1000 M6184D1035 160° 24 108 180 60 Series 20 M6184D1035

M405A1004 None 120 94 60 25 Series 40 None Special timing and stroke

M405A1020 None 240 94 60 25 Series 40 None

M405B1003 M8185D1006 50017460-

003 160° 120 50 160 60 Series 40 M4185B1009

M405B1011 M8185D1006 50017460-

001 160° 208 50 160 60 Series 40 M4185B1058

M405B1029 M8185D1006 50017460-

001 160° 240 50 160 60 Series 40 M4185B1058

M405B1037 M8185D1006 50017460-

003 160° 120 50 160 60 Series 40 M4185A1001

M405B1045 M8185D1006 50017460-

001 160° 220 50 160 60 Series 40 None

M405B1052 M8185D1006 50017460-

003 90° 120 50 60 60 Series 40 M4185B1058 Replaced Motor is 60°

Replacement is 160°, 60 sec timing

M405B1086 M8185D1006 50017460-

001 90° 220 50 60 60 Series 40 None

M405B1094 M8185D1006 50017460-

003 160° 120 50 160 60 Series 40 M4185A1001

M405B1102 M8185D1006 50017460-

003 160° 120 50 160 60 Series 40 M4185A1001

M405C1002 M8185D1006 50017460-

003 160° 120 50 160 60 Series 40 M4185A1001

MODUTROL IV™ MOTOR CROSS REFERENCE

19 63-2691—01

M405C1010 M8185D1006 50017460-

001 160° 208 50 160 60 Series 40 M4185B1058

M405C1028 M8185D1006 50017460-

001 160° 220 50 160 60 Series 40 None

M405C1036 M8185D1006 50017460-

003 90° 120 50 90 30 Series 40 M4185B1058

M405C1044 M8185D1006 50017460-

001 90° 208 50 90 30 Series 40 M4185B1058

M405C1051 M8185D1006 50017460-

001 90° 240 50 90 30 Series 40 M4185B1058

M405C1069 M8185D1006 50017460-

001 160° 240 50 160 60 Series 40 M4185B1058

M405D1001 M8185D1006 50017460-

003 160° 120 50 160 60 Series 40 M4185B1009 Use aux. end; N.O.

M405D1019 M8185D1006 50017460-

001 160° 208 50 160 60 Series 40 None Use aux. end; N.O.

M405D1027 M8185D1006 50017460-

001 160° 240 50 160 60 Series 40 None

M405D1035 M8185D1006 50017460-

001 160° 220 27 160 60 Series 40 None

M445A1000 M8185D1006 50017460-

003 220736A 160° 120 50 160 60 1 Series 40 M4185B1009

M445A1018 M8185D1006 50017460-

003 220736A 160° 120 50 160 60 1 Series 40 M4185B1009

M445A1026 M8185D1006 50017460-

001 220736A 160° 208 50 160 60 1 Series 40 M4185B1058

M445A1034 M8185D1006 50017460-

001 220736A 160° 208 50 160 60 1 Series 40 M4185B1058

M445A1042 M8185D1006 50017460-

001 220736A 160° 208/240 50 160 60 1 Series 40 M4185B1058

M445A1059 M8185D1006 50017460-

001 220736A 160° 240 50 160 60 1 Series 40 M4185B1058

M445A1067 M8185D1006 50017460-

001 220736A 160° 220 50 160 60 1 Series 40 None

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

20 63-2691—01

M445A1075 M8185D1006 50017460-

003 220736A 90° 120 50 60 25 1 Series 40 M4185B1058 30 sec timing & 90° stroke

M445A1091 M8185D1006 50017460-

003 220736A 160° 120 50 160 60 1 Series 40 M4185B1009

M445A1109 M8185D1006 50017460-

003 220736A 160° 120 50 160 60 1 Series 40 M4185B1009

M445A1117 M8185D1006 50017460-

003 220736A 90° 120 50 90 30 1 Series 40 M4185B1058

M445A1125 M8185D1006 50017460-

003 220736A 90° 120 50 90 15 1 Series 40 M4185B1058

M445A4004 M8185D1006 50017460-

003 220736A ADJ 120 50 90/160 30/60 1 Series 40 None Canada Special, aux. switch set at 120°

M445C1008 M8185D1006 50017460-

003 220736A 160° 120 50 160 60 1 Series 40 M4185B1009

M445C1016 M8185D1006 50017460-

003 220736A 160° 120 50 160 60 1 Series 40 M4185B1009 Aux. switch set at 155°

M445C1024 M8185D1006 50017460-

003 220736A 160° 120 50 160 60 1 Series 40 M4185B1009

M445D1007 M8185D1006 50017460-

003 160° 120 50 160 60 Series 40 M4185A1001

M445D1015 M8185D1006 50017460-

003 90° 120 50 90 30 Series 40 M4185B1058

M445D1023 M8185D1006 50017460-

001 160° 220 50 160 60 Series 40 None

M445D1031 M8185D1006 50017460-

001 160° 240 50 160 60 Series 40 M4185B1058

M445D1049 M8185D1006 50017460-

003 160° 120 50 180 67 Series 40 M4185A1001 60 sec timing & 160° stroke

M445D1056 M8185D1006 50017460-

003 160° 120 50 160 60 Series 40 M4185A1001 M445D was moisture fungus treated

M465A1008 M8185D1006 50017460-

003 160° 120 25 160 40 Series 40 M4185B1009 60 sec timing

M465B1007 M8185D1006 50017460-

003 220736B 160° 120 50 160 60 2 Series 40 M4185A1001

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

21 63-2691—01

M604A1002 M6184D1035 50017460-

003 120 75 360 30 Series 61 M6184A1023 TRADELINE is 90°/160°

M604A1028 M6184D1035 50017460-

001 240 40 360 60 Series 61 None TRADELINE is 90°/160°

M604A1036 M6184D1035 50017460-

001 208 54 360 30 Series 61 None

M604A1051 None 240 40 180 15 Series 61 None Special shaft length

M604A1069 M6184D1035 50017460-

003 120 40 360 60 Series 61 None Bahnson Special; TRADELINE is 90°/160°

M604A1077 M6184D1035 50017460-

003 120 75 360 15 Series 61 None TRADELINE is 90°/160°

M604B1001 M6184D1035 50017460-

003 160° 120 37 180 15 Series 61 M6184A1023 Change control circuit to 24 Vac

M604B1019 M6184D1035 50017460-

001 160° 240 37 180 30 Series 61 None

M604B1027 M6184D1035 50017460-

003 160° 120 75 180 30 Series 61 M6184A1023

M604B1035 M6184D1035 50017460-

001 160° 208 54 180 30 Series 61 None

M604B1043 M6184D1035 50017460-

001 160° 240 75 180 30 Series 61 None

M604B1050 None 120 54 180 30 Series 61 None Designed for use with 25 Hz

M604B1068 M6184D1035 50017460-

003 160° 120 54 180 30 Series 61 M6184A1023 Change control circuit to 24 Vac

M604B1076 M6184D1035 50017460-

001 160° 220 54 180 30 Series 61 None

M604C1059 None 24 108 160 60 Series 61 None Micronik System

M604C1083 None 24 150 160 120 Series 61 None

M604D1009 M6184D1035 50017460-

001 160° 220 85 180 60 Series 61 None

M604D1017 M6184D1035 50017460-

001 160° 220 85 180 60 Series 61 None

M604E1008 M6184D1035 220736A ADJ 24 150 90/160 30/60 1 Series 61 M6184F1014 Replacement is 90°/160° stroke

M604E1016 M6184D1035 220736A ADJ 24 150 90/160 30/60 1 Series 61 M6184F1014

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

22 63-2691—01

M604E1024 M6184D1035 220736A ADJ 24 150 90/160 30/60 1 Series 61 M6184F1014

M634A1009 M6184D1035 160° 24 35 160 60 Series 61 M6184D1035 Replacement is150 lb-in. torque

M634B1008 M6184D1035 50017460-

003 160° 120 35 160 60 Series 61 None Change control circuit to 24 Vac

M634B1016 M6184D1035 50017460-

001 160° 240 35 160 60 Series 61 None

M634C1007 M6184D1035 220736B 160° 24 35 160 60 2 Series 61 M6184F1014 Check torque

M634C1015 M6184D1035 50017460-

003 220736B 160° 120 35 160 60 2 Series 61 M6184F1014 150 lb-in. torque; Replacement: requires

50017460-001

M634C1023 M6184D1035 50017460-

001 220736B 160° 240 35 160 60 2 Series 61 M6184F1014

M634C1031 M6184D1035 50017460-

001 220736B 160° 220 35 160 60 2 Series 61 M6184F1014 150 lb-in. torque; Replacement: requires

50017460-001

M634C1049 M6184D1035 50017460-

003 220736B 160° 120 35 160 60 2 Series 61 M6184F1014 150 lb-in. torque; Replacement: requires

50017460-003

M634C1056 M6184D1035 220736B 160° 24 35 160 60 2 Series 61 M6184F1014 Check torque

M634C1064 M6184D1035 50017460-

001 220736B 160° 220 35 160 60 2 Series 61 M6184F1014 150 lb-in. torque; Replacement: requires

50017460-001

M634C1072 M6184D1035 50017460-

003 220736B 160° 120 35 160 60 2 Series 61 M6184F1014 150 lb-in. torque; Replacement: requires

50017460-003

M634C1080 M6184D1035 50017460-

001 220736B 160° 220 35 160 60 2 Series 61 M6184F1014 150 lb-in. torque; Replacement: requires

50017460-001

M634C1098 M6184D1035 50017460-

001 220736B 160° 220 35 160 60 2 Series 61 M6184F1014

M644A1008 M6184D1035 160° 24 150 160 60 Series 61 M6184D1035

M644A1016 M6184D1035 160° 24 150 160 60 Series 61 M6184D1035

M644A1024 M6184D1035 90° 24 150 90 30 Series 61 M6184A1015

M644A1032 None 24 37 160 15 Series 61 None

M644A1107 None 24 37 335 15 Series 61 None

M644A1115 None 24 37 335 30 Series 61 None

M644A1149 M6184D1035 50017460-

001 160° 220 150 160 60 Series 61 None

M644A1180 M6184D1035 160° 24 150 160 60 Series 61 M6184D1035 Carrier Special

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

23 63-2691—01

M644B1007 M6184D1035 50017460-

003 160° 120 75 160 30 Series 61 None Change control circuit to 24 Vac

M644B1015 None 120 37 160 15 Series 61 None

M644B1031 M6184D1035 50017460-

003 90° 120 150 90 120 Series 61 None Change control circuit to 24 Vac

M644B1049 M6184D1035 50017460-

003 160° 120 75 160 30 Series 61 M6184A1023 TRADELINE is 30/60 sec timing;

Replacement is 150 lb-in.

M644B1056 M6194D1017 50017460-

003 90° 120 150 90 120 Series 61 None

M644C1006 M6184D1035 ADJ 24 75 90/160 15/30 Series 61 M6184D1001 TRADELINE is 30/60 sec timing

M644C1014 M6194D1017 ADJ 24 150 90/160 120/

240 Series 61 M6194D1017

M644C1022 M6184D1035 50017460-

003 ADJ 120 150 90/160 120/

240 Series 61 None

M644C1030 M6194D1017 ADJ 24 150 90/160 120/

240 Series 61 M6194D1017

M644C1055 M6194D1017 ADJ 24 300 90/160 120/

240 Series 61 M6194D1017 Lennox Special

M644C1063 M6184D1035 50017460-

003 ADJ 120 150 90/160 120/

240 Series 61 None

M644C1071 M6194D1017 ADJ 24 300 90/160 120/

240 Series 61 None York Special

M644C4000 M6194D1017 ADJ 24 150 90/160 120/

240 Series 61 M6194D1017 Canada Special

M644D1005 M6184D1035 220736B ADJ 24 150 90/160 30/60 2 Series 61 M6184F1014

M644D1013 M6184D1035 220736B ADJ 24 150 90/160 30/60 2 Series 61 M6184F1014

M644D1021 M6184D1035 220736B ADJ 24 150 90/160 30/60 2 Series 61 M6184F1014

M644D1039 M6184D1035 220736B ADJ 24 150 90/160 30/60 2 Series 61 M6184F1014

M644D1047 M6194D1017 220736B ADJ 24 300 90/160 120/

240 2 Series 61 None Lennox Special

M644E1004 M6184D1035 220736A ADJ 24 150 90/160 30/60 1 Series 61 M6184F1014 Aux. switch set at 4°

M644E1012 M6194D1017 220736A 90° 24 150 90 60 1 Series 61 M6194B1011 TRADELINE: 30/60 sec timing

M644E1020 M6184D1035 50017460-

003 220736A ADJ 120 75 90/160 15/30 1 Series 61 None Aux. switch set at 4°

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

24 63-2691—01

M644E1038 M6184D1035 220736A ADJ 24 75 90/160 15/30 1 Series 61 M6184D1001 Requires Q607A1050; Set aux. switch at

40°

M644E1053 M6194D1017 220736A ADJ 24 300 90/160 120/

240 1 Series 61 M6194E1006

M644F1003 M6184D1035 50017460-

003 160° 120 75 180 30 Series 61 M6184D1001 Trane Special; Requires 50017460-001 &

24 Vac control circuit

M644L1006 M6194D1017 50017460-

003 220736A 90° 120 150 90 120 1 Series 61 None

M644L1014 M6184D1035 50017460-

003 220736A 90° 120 150 90 30 1 Series 61 M6184F1014 Requires 50017460-001

M644L1022 M6194D1017 50017460-

003 220736A 90° 120 150 90 120 1 Series 61 None

M644L1030 M6194D1017 50017460-

003 220736A 90° 120 150 90 120 1 Series 61 None Trane Special, aux. switch set at 7°

M734A1007 None 120 35 90 30 W936 None Special circuit

M734A1015 None 120 35 90 30 W936 None

M734A1023 None 120 35 90 30 W936 None Nesbitt Special; Special circuit

M734B1006 None 120 35 90 28 W936 None Special circuit; Check transformer

M734B1014 None 240 35 90 28 W936 None

M734B1022 None 24 35 90 28 W936 None Nesbitt Special; Special circuit

M734B1030 None 240 35 160 50 W936 None Special circuit

Check transformer

M734B1048 None 120 35 160 50 W936 None

M734C1005 None 120 35 90 28 W936 None Special circuit

M734C1013 None 120 35 90 28 W936 None Nesbitt Special; Special circuit

M734C1021 None 120 35 90 28 W936 None

M734D1004 M9164D1009 50017460-

003 Q7330A1004 160° 120 35 160 50 W936 None

M734D1012 M9164D1009 50017460-

003 Q7330A1004 90° 120 35 90 28 W936 None

M734D1020 M9164D1009 50017460-

001 Q7330A1004 160° 240 35 160 50 W936 None

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

25 63-2691—01

M734D1038 M9164D1009 Q7330A1004 160° 24 35 160 50 W936 None

M734D1046 M9164D1009 220736A Q7330A1004 90° 24 35 90 28 1 W936 None

M734D1053 M9164D1009 220736A Q7330A1004 160° 24 35 160 50 1 W936 None

M734E ALL M9164D1009 Q7330A1004 35 W936 None Use aux end of N.C. motor; N.O.

M734F ALL M9164D1009 Q7330A1004 75 W936 None

M734G ALL M9164D1009 Q7330A1004 75 W936 None

M734H1000 M9164D1009 50017460-

003 Q7130A1006 90° 120 35 90 28 10.5-13.5

Vdc M7164G1030 Adjust for 10.5-13.5 Vdc, select CCW

rotation; Elec. N.O.

M734H1018 M9164D1009 50017460-

003 Q7130A1006 90° 120 35 90 28 4 - 7 Vdc None Adjust for 4-7 Vdc, Select CCW; Electrically

N.O.

M734H1026 M9164D1009 Q7130A1006 160° 24 35 160 50 4 - 7 Vdc None

M734H1034 M9164D1009 Q7130A1006 90° 24 35 90 30 10.5-13.5

Vdc M7164G1030 Adjust for 10.5-13.5 Vdc, select CCW

rotation; Elec. N.O.

M734J1007 M9164D1009 50017460-

003 Q7130A1006 160° 120 35 160 50 6 - 9 Vdc None Adjust for 6-9 Vdc

M734J1015 M9164D1009 Q7130A1006 160° 24 35 160 50 4 - 7 Vdc None Adjust for 4-7 Vdc

M734J1023 M9164D1009 Q7130A1006 90° 24 35 90 30 10.5-13.5

Vdc M7164A1017 Lennox Special; Adjust for 10.5-13.5 Vdc

M734J1031 M9164D1009 50017460-

003 Q7130A1006 90° 120 35 90 30 10.5-13.5

Vdc None York Special; Adjust for 10.5-13.5 Vdc

M734J1049 M9164D1009 Q7130A1006 160° 24 35 160 50 10.5-13.5

Vdc None Lennox Special; Adjust for 10.5-13.5 Vdc

M734J1056 M9164D1009 Q7130A1006 90° 24 35 90 30 10.5-13.5

Vdc M7164A1017 Adjust for 10.5-13.5 Vdc

M734J1064 M9164D1009 50017460-

003 Q7130A1006 90° 120 35 90 30 6 - 9 Vdc None Adjust for 6-9 Vdc

M734J1072 M9164D1009 50017460-

003 220736A Q7130A1006 160° 120 35 160 50 1 4 - 7 Vdc None Adjust for 4-7 Vdc

M734K1006 None 120 35 160 50 4 - 7 Vdc,

3W, 11 Vdc

out

None 3 wire output

Micronik system

M734K1014 None 24 35 160 50

M741B1001 None 24 150 90 30 BRCS None Cleaver Brooks BRCS

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

26 63-2691—01

M741B1019 None 24 150 90 30 BRCS M7484A1010 BRCS

M744A1006 M9184D1021 Q7330A1004 160° 24 150 160 60 W936 None

M744A1014 M9184D1021 Q7330A1004 90° 24 150 90 30 W936 None

M744A1022 M9184D1021 50017460-

003 Q7330A1004 90° 120 150 90 30 W936 None Westinghouse Special

M744B ALL None 24 150 W936 None

M744D1003 M9184D1021 Q7130A1006 160° 24 150 160 60 4 - 7 Vdc None Adjust for 4-7 Vdc

For use with W7080 systems

M744D1011 M9184D1021 Q7130A1006 160° 24 150 160 60 4 - 7 Vdc None

M744D1029 None 24 150 90 30 0.8 - 3.3 Vdc None

M744D1037 None 24 150 90 120 0.8 - 3.3 Vdc None Despatch Industries

M744D1045 None 120 150 90 30 0.8 - 3.3 Vdc None

M744E1002 None 24 50 160 60 2 - 10 Vdc None Micronik, with external overdrive

M744F1001 M9184D1021 Q7330A1004 160° 24 150 160 60 W936 None Includes internal heater

M744G1000 None 24 150 160 60 4 - 7 Vdc,

3W, 11 Vdc

out

None 3 wire output

M744J1006 None 24 150 90 30 0 - 2.5 Vdc None With zero adjustment

M744S1005 M9184D1021 50017460-

003 Q7230A1005 90° 120 150 90 30 4 - 20 mA M7284A1004 Adjust for 4-20 mA

Micronik system

M744S1013 M9184D1021 50017460-

003 Q7230A1005 160° 120 150 160 60 4 - 20 mA M7284A1012

M744T1004 M9184D1021 50017460-

003 220736B Q7230A1005 90° 120 150 90 30 2 4 - 20 mA M7284C1000

M744T1012 M9184D1021 50017460-

003 220736B Q7230A1005 160° 120 150 160 60 2 4 - 20 mA M7284C1000

M744Y1009 M9184D1021 50017460-

003 220736B Q7230A1005 90° 120 150 90 30 2 4 - 20 mA M7284Q1009 Adjust for desired range

Adjustable zero span

M744Y1017 M9184D1021 50017460-

003 220736B Q7230A1005 160° 120 150 160 60 2 4 - 20 mA M7284Q1009

M745A1003 M9185D1004 Q7330A1004 90° 24 50 90 30 W936 None

M745A1011 M9185D1004 Q7330A1004 160° 24 50 160 60 W936 None

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

27 63-2691—01

M745A1029 M9185D1004 50017460-

003 Q7330A1004 160° 120 50 160 60 W936 None

M745B1002 M9185D1004 Q7330A1004 160° 24 50 160 60 W936 None Use aux end of N.C. motor; N.O. mech. and

elec.

M745C1001 M9185D1004 Q7330A1004 160° 24 50 160 60 W936 None Used with W936 & W945 systems

M745D ALL None 24 50 160 60 None N.O.

M745E1009 None 24 50 160 60 W936 M9185D1004

+Q7330A1006 N.O. mechanically, N.C. electrically

M745F1008 None 24 50 160 60 None N.C. mechanically, N.O. electrically

M745G1007 M9185D1004 Q7130A1006 160° 24 50 160 60 4 - 7 Vdc M9185D1004 +

Q7130A1006 Adjust for 4-7 Vdc, Select CCW, use aux

shaft; N.O. mech. and elec.

M745H1006 M9185D1004 Q7630A1001 160° 24 50 160 60 14 - 17 Vdc None

M745J1003 None 24 50 160 60 4 - 7 Vdc,

3W, 11 Vdc

out

None 3 wire output, Micronik System, electrically

N.O.

M745K1002 M9185D1004 Q7630A1001 90° 24 50 90 35 14 - 17 Vdc None Lennox Special, select CCW rotation,

electrically N.O.

M745L1001 M9185D1004 Q7630A1001 90° 24 50 90 35 14 - 17 Vdc None Lennox Special

M745L1019 M9185D1004 50017460-

003 Q7630A1001 160° 120 50 160 60 14 - 17 Vdc None York Special

M745L1027 M9185D1004 Q7630A1001 160° 24 50 160 60 14 - 17 Vdc None

M745L1035 M9185D1004 Q7630A1001 90° 24 50 90 35 14 - 17 Vdc None Lennox Special

M745L1043 M9185D1004 Q7630A1001 90° 24 50 90 35 14 - 17 Vdc None

M745M1000 M9185D1004 Q7130A1006 160° 24 50 160 60 6 - 9 Vdc None Adjust for 6-9 Vdc, use aux. end;

Mechanically N.O.

M745M1018 M9185D1004 Q7130A1006 90° 24 50 90 35 10.5-13.5

Vdc None Lennox Special; Adjust for 10.5-13.5 Vdc,

use aux. end

M745M1026 M9185D1004 Q7130A1006 160° 24 50 160 60 4 - 7 Vdc None Adjust for 4-7 Vdc, use aux. end;

Mechanically N.O.

M745M1034 M9185D1004 Q7130A1006 160° 24 50 160 60 4 - 7 Vdc None Lennox Special, Adjust for 4-7 Vdc, use aux.

end, mech. N.O.

M745M1042 M9185D1004 Q7130A1006 160° 24 50 160 60 4 - 7 Vdc None Adjust for 4-7 Vdc, use aux. end;

Mechanically N.O.

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

28 63-2691—01

M745N1009 M9185D1004 Q7130A1006 90° 24 50 90 35 10.5-13.5

Vdc None Lennox Special; Adjust for 10.5-13.5 Vdc,

select CCW rotation

M745N1017 M9185D1004 Q7130A1006 160° 24 50 160 60 10.5-13.5

Vdc None Mammoth Special, Adjust for 10.5-13.5 Vdc,

select CCW rotation; elect. N.O.

M745N1025 M9185D1004 Q7130A1006 160° 24 50 160 60 6 - 9 Vdc None Adjust for 4-7 Vdc, Select CCW; Electrically

N.O.

M745P1007 M9185D1004 Q7130A1006 160° 24 50 160 60 4 - 7 Vdc M9185D1004 +

Q7130A1006 Adjust for 4-7 Vdc

M745P1015 M9185D1004 Q7130A1006 90° 24 50 90 35 10.5-13.5

Vdc None Lennox Special; Adjust for 10.5-13.5 Vdc

M745Q1006 None 24 50 90 35 None

M745S1002 M9185D1004 50017460-

003 Q7230A1005 90° 120 50 90 30 4 - 20 mA M7285A1003 Adjust for 4-20 mA

M745S1010 M9185D1004 50017460-

003 Q7230A1005 160° 120 50 160 60 4 - 20 mA M7285A1003

M745T1001 M9185D1004 50017460-

003 220736B Q7230A1005 90° 120 50 90 30 2 4 - 20 mA M7285C1009

M745T1019 M9185D1004 50017460-

003 220736B Q7230A1005 160° 120 50 160 60 2 4 - 20 mA M7285C1009

M745Y1006 M9185D1004 50017460-

003 220736B Q7230A1005 90° 120 50 90 30 2 4 - 20 mA M7285Q1008 Adjustable zero span, Adjust for desired

range

M745Y1014 M9185D1004 50017460-

003 220736B Q7230A1005 160° 120 50 160 60 2 4 - 20 mA M7285Q1008

M765A1001 M9185D1004 Q7330A1004 160° 24 25 160 40 W936 None

M765A1019 M9185D1004 Q7330A1004 90° 24 25 90 25 W936 None

M765K1000 M9185D1004 Q7630A1001 90° 24 25 90 25 14 - 17 Vdc None Select CCW rotation; Use with W7080

system, elec. N.O.

M765L1009 M9185D1004 Q7630A1001 160° 24 25 160 40 14 - 17 Vdc None For use with W7080 system

M765L1017 M9185D1004 Q7630A1001 90° 24 25 90 25 14 - 17 Vdc None

M765L1025 M9185D1004 50017460-

003 Q7630A1001 90° 120 25 90 25 14 - 17 Vdc None Trane Special; use with W7080 system

M765N1007 M9185D1004 Q7130A1006 90° 24 25 90 25 10.5-13.5

Vdc None Lennox Special; Adjust for 10.5-13.5 Vdc,

select CCW rotation, elect. N.O.

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

29 63-2691—01

M765N1015 M9185D1004 Q7130A1006 160° 24 25 160 40 10.5-13.5

Vdc None

M765P1005 None 24 25 90 25 3.5 - 6.5 Vdc None McDonald’s Special; 3 wire output

M765P1013 None 24 25 90 25 3.5 - 6.5 Vdc None York Special; 3 wire output

M765Q1004 None 24 25 90 25 0 - 1 mA None Nesbitt Special

M805B1004 M8185D1006 160° 24 50 160 60 Series 80 M8185D1006

M805B1012 None 24 27 160 120 Series 80 None Designed for use with 25 hz

M805B1020 M8185D1006 160° 24 50 160 60 Series 80 M8185D1006

M805B1038 M8185D1006 220736A 160° 24 50 160 60 1 Series 80 None

M805C1003 M8185D1006 160° 24 50 160 60 Series 80 M8185D1006

M805D1002 M8185D1006 160° 24 50 160 60 Series 80 M4185B1009 Use aux. motor end; N.O.

M845A1001 M8185D1006 220736A 160° 24 50 160 60 1 Series 80 None

M845A1027 M8185D1006 50017460-

001 220736A 160° MULTI 50 160 60 1 Series 80 M4185B1058

M845A1035 M8185D1006 50017460-

001 220736A 90° MULTI 50 90 30 1 Series 80 M4185B1058 Requires 50017460-001

M845A1050 None 24 50 160 60 1 Series 80 None

M845A1068 None 24 50 160 60 1 Series 80 None

M845A4005 M8185D1006 50017460-

001 220736A ADJ MULTI 50 90/160 30/60 1 Series 80 None Canada Special, Aux. switch set at 120°

M845B1000 M8185D1006 220736A 160° 24 50 160 60 1 Series 80 None

M845B1018 M8185D1006 50017460-

003 220736A 160° 120 50 160 60 1 Series 80 M4185B1058

M845B1026 M8185D1006 50017460-

001 220736A 160° 220 50 160 60 1 Series 80 None

M845C1009 M8185D1006 160° 24 50 160 60 Series 80 M8185D1006

M845D1008 M8185D1006 160° 24 50 160 60 Series 80 None Univac Special

M845D1016 M8185D1006 50017460-

003 160° 120 50 160 60 Series 80 M4185B1058 G.E. Special

M845D1024 M8185D1006 160° 24 50 160 60 Series 80 None Braden Special

M845E1007 M8185D1006 50017460-

003 220736A 160° 120 50 160 60 1 Series 80 M4185B1009 Use aux. motor end; N.O.

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

30 63-2691—01

M845E4001 M8185D1006 50017460-

003 220736A ADJ 24/120 50 90/160 30/60 1 Series 80 M4185B1009 Canada Special; Use aux. motor end

M865A1009 M8185D1006 160° 24 25 160 40 Series 80 None

M865B1008 M8185D1006 220736A 160° 24 25 160 40 1 Series 80 None

M904A1006 M9184D1021 160° 24 108 160 60 135 ohm M9184A1019

M904E1002 M9184D1021 160° 24 108 160 60 135 ohm M9184A1019

M904E1010 None 24 108 160 60 135 ohm None 25 Hz

M904E1028 None 24 108 160 60 135 ohm None 40 Hz

M904E1036 M9184D1021 Q181A1004 160° 24 108 180 60 135 ohm M9184A1019 Add Q181 for slaved motor applications

M904E1051 M9184D1021 90 24 108 90 30 135 ohm None

M904E1085 M9184D1021 90 24 108 90 30 135 ohm None Special cam for few positions

M904E1119 M9194D1003 160 24 108 240 90 135 ohm None TRADELINE is 90/160 degrees

M904E1150 M9184D1021 Q181A1004 160° 24 108 160 240 135 ohm M9194D1003 Add Q181 for slaved motor applications

M904E1176 M9184D1021 Q181A1004 160° 24 108 180 240 135 ohm M9194D1003

M904E1218 None 24 108 160 240 135 ohm None

M904E1226 None 24 14 160 7.5 135 ohm None Ariel Davis Mfg., special cam

M904E1234 None 24 38 180 15 135 ohm None Special timing; For 30 sec 160° motor,

Select M9184D1021

M904E1242 None 24 38 180 15 135 ohm None

M904E1267 M9184D1021 Q181A1004 160° 24 54 160 30 135 ohm M9184D1005 Add Q181 for slaved motor applications

M904E1358 M9184D1021 Q181A1004 160° 24 150 180 60 135 ohm M9184A1019

M904E1366 M9184D1021 90 24 150 90 30 135 ohm M9184D1021 Univac Special

M904E1374 None 24 150 160 60 135 ohm None Fungus treated

M904F1001 None 24 37 160 15 Series 62 None

M904F1019 None 24 75 160 30 Series 62 None

M904F1027 M6284D1000-S 160° 24 150 160 60 Series 62 M6284D1000-S No internal balance circuit, requires Q181

when using R927

M904F1035 M6284D1000-S 160° 24 150 160 60 Series 62 M6284D1000-S

M904F1043 M6284D1000-S 90° 24 150 90 30 Series 62 M6284F1013-S

M904F1050 M6284D1000-S 160° 24 150 160 240 Series 62 None

M904G1000 M6284D1000-S 160° 24 150 160 60 Series 62 M6284D1000-S

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

31 63-2691—01

M905E1009 M9185D1004 Q181A1004 160° 24 50 160 60 135 ohm M9185A1018 Add Q181 for slaved motor applications

M905E1025 M9185D1004 Q181A1004 160° 24 50 160 60 135 ohm M9185A1018

M905E1058 M9185D1004 Q181A1004 160° 24 50 160 60 135 ohm M9185A1018

M905E1066 M9185D1004 Q181A1004 90° 24 50 90 30 135 ohm M9185A1018

M905E1074 M9185D1004 Q181A1004 160° 24 50 160 60 135 ohm M9185A1018

M905E1082 M9185D1004 Q181A1004 160° 24 50 160 60 135 ohm M9185A1018

M905E1108 M9185D1004 Q181A1004 160° 24 50 160 60 135 ohm M9185A1018

M905E1116 M9185D1004 Q181A1004 160° 24 50 160 60 135 ohm M9185A1018

M905E1124 M9185D1004 Q181A1004 160° 24 50 160 60 135 ohm M9185A1018

M905F1008 M9185D1004 160° 24 56 160 60 135 ohm M9185A1018

M905F1016 None 24 27 160 120 135 ohm None M905F1016 designed for 25 Hz

M905F1024 M9185D1004 160° 24 27 160 60 135 ohm M9185A1018 Add Q181 for slaved motor applications

M905F1032 M9185D1004 160° 24 56 160 60 135 ohm M9185A1018

M905G1007 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018 Use aux. motor end

N.O. - replacement is normally closed

M905G1015 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018

M905G1023 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018 Use aux. end; Add Q181 for slaved motor

applications

M905H1006 M6285A1005-S 160° 24 27 160 60 Series 62 M6285A1005-S +

Q209/S963 No internal balance circuit, requires Q181

when using R927

M905H1014 M6285A1005-S 160° 24 50 160 60 Series 62

M905J1003 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S

M905K1002 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S

M905K1010 None 24 27 160 120 Series 62 None M905K1010 designed for 25 Hz

M905L1001 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S Use aux. motor end, No internal balance

circuit; N.O.

M905L1019 None 24 27 160 120 Series 62 None M905L1019 designed for 25 Hz

M905N1009 M9185D1004 160° 24 50 160 60 135 ohm M9185C1006

M905N1017 M6285A1005-S 160° 24 50 160 60 135 ohm M9185C1006 For use with W841

M905N1025 M6285A1005-S 160° 24 50 160 60 135 ohm M9185C1006 Replacement is less power supply cord, for

use with W841, no internal balance circuit

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

32 63-2691—01

M905P1007 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S For use with W841 No internal balance

circuit

M905P1015 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S Replacement is less power supply cord, for

use with W841, no internal balance circuit

M931A1009 None 24 108 90 30 135 ohm M9484D1010

M931A1017 None 24 108 90 60 135 ohm None

M931A1025 None 24 150 160 60 135 ohm M9484D1010

M931A1033 None 24 37 160 15 135 ohm None

M931A1041 None 24 54 90 15 135 ohm M9484D1010

M931A1058 None 24 75 160 30 135 ohm M9484D1010

M931A1066 None 24 108 90 30 135 ohm M9484D1010

M931A1074 None 24 108 160 60 135 ohm M9484D1010

M931A1082 None 24 108 90 60 135 ohm None

M931A1090 None 24 150 160 240 135 ohm None

M931A1108 None 24 150 90 60 135 ohm None

M931A1116 None 24 150 90 30 135 ohm M9484D1010

M931A1124 None 24 108 90/160 30/60 135 ohm M9494D1000

M931A1132 None 24 108 90/160 60/120 135 ohm M9484D1010

M931A1140 None 24 150 90/160 30/60 135 ohm M9484D1010

M931A1157 None 24 37 90/160 7.5/15 135 ohm None Special timing

M931A1165 None 24 76 90/160 15/30 135 ohm M9484D1010

M931A1173 None 24 108 90/160 30/60 135 ohm M9484D1010

M931A1181 None 24 108 90/160 120/

240 135 ohm None

M931A1199 None 24 54 90/160 30/60 135 ohm M9484D1010

M931A1207 None 24 150 160 60 135 ohm M9484D1010

M931A1215 None 24 108 90/160 30/60 1 135 ohm M9484E1017

M931A1223 None 24 108 90/160 60/120 1 135 ohm None

M931A1231 None 24 108 90/160 30/60 1 135 ohm M9484E1017

M931A1249 None 24 27 90/160 7.5/15 1 135 ohm None Special timing

M931A1256 None 24 54 90/160 15/30 1 135 ohm M9484E1009

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

33 63-2691—01

M931A1264 None 24 108 90/160 30/60 1 135 ohm M9484E1017

M931A1272 None 24 108 90/160 120/

240 1 135 ohm None

M931A1280 None 24 150 90/160 30/60 1 135 ohm M9484E1033

M931A1298 None 24 150 90 60 135 ohm None

M931A1306 None 24 108 90/160 30/60 135 ohm M9484D1010

M931A1314 None 24 108 90/160 60/120 135 ohm M9494D1000

M931A1322 None 24 108 90/160 30/60 135 ohm M9484D1010

M931A1330 None 24 150 160 60 135 ohm None

M931B1008 None 24 108 90 30 Series 62 M6284F1013-S No internal balance circuit, requires Q181

when using R927

M931B1016 None 24 150 90/160 30/60 Series 62 M6284F1013-S

M931B1024 None 24 150 160 60 Series 62 M6284D1000-S

M931B1032 None 24 150 160 30 Series 62 None

M931B1040 None 24 150 160 60 Series 62 M6284D1000-S No internal balance circuit, requires Q181

when using R927

M931B1057 None 24 150 90 60 Series 62 None

M931C1007 None 24 108 90/160 30/60 1 135 ohm M9484E1017

M931C1015 None 24 150 90/160 60/120 1 135 ohm None

M931C1023 None 24 150 90/160 30/60 1 135 ohm M9484E1017

M931C1031 None 24 37 90/160 7.5/15 1 135 ohm None International special timing

M931C1049 None 24 75 90/160 15/30 1 135 ohm M9484E1009

M931C1056 None 24 150 90/160 120/

240 1 135 ohm None

M931C1064 None 24 150 90/160 30/60 1 135 ohm M9484E1017 International

M931C1072 None 24 150 90/160 30/60 1 135 ohm M9484E1033 Switch set in 90° position

M931D1006 None 24 150 160 60 1 135 ohm M6284F1013-S No internal balance circuit

M931D1014 None 24 150 90 30 1 135 ohm M6284F1013-S

M934A1003 M9164D1009 50017460-

001 160° 240 35 160 60 135 ohm None

M934A1011 M9164D1009 50017460-

003 160° 120 35 160 60 135 ohm None

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

34 63-2691—01

M934A1029 M9164D1009 160° 24 35 160 60 135 ohm M9164A1005 Wire M9164A1005 to 24 Vac

M934A1037 M9164D1009 50017460-

001 160° 220 35 160 60 135 ohm M9164A1088

M934A1045 M9164D1009 220736B 160° 24 35 160 60 2 135 ohm M9164C1068 Wire M9164C1068 to 24 Vac

M934A1052 M9164D1009 50017460-

003 220736B 160° 120 35 160 60 2 135 ohm M9164C1068

M934A1060 M9164D1009 50017460-

001 220736B 160° 240 35 160 60 2 135 ohm None

M934A1078 M9164D1009 50017460-

001 220736B 160° 220 35 160 60 2 135 ohm None

M934A1086 M9164D1009 50017460-

003 160° 120 35 160 60 135 ohm M9164A1005

M934A1094 M9164D1009 50017460-

003 220736B 160° 120 35 160 60 2 135 ohm M9164C1068

M934A1102 M9164D1009 50017460-

001 90° 240 35 90 35 135 ohm None York Special

M934A1128 M9164D1009 50017460-

003 220736B 90° 120 35 90 35 2 135 ohm M9164C1068

M934A1136 M9164D1009 50017460-

003 90° 120 35 90 35 135 ohm M9164A1005

M934A1144 M9164D1009 90° 24 35 90 35 135 ohm None

M934A1169 M9164D1009 160° 24 35 160 60 135 ohm M9164A1005 Wire M9164A1005 to 24 Vac

M934A1193 M9164D1009 220736B 160° 24 35 160 60 2 135 ohm M9164C1068 Wire M9164C1068 to 24 Vac

M934A1201 M9164D1009 50017460-

001 160° 240 35 160 60 135 ohm M9164A1013

M934A1219 M9164D1009 50017460-

003 160° 120 35 160 60 135 ohm M9164A1005

M934A1227 M9164D1009 160° 24 35 160 60 135 ohm M9164D1009

M934A1235 M9164D1009 50017460-

001 160° 220 35 160 60 135 ohm M9164A1088

M934A1243 M9164D1009 220736B 160° 24 35 160 60 2 135 ohm M9164C1068 Wire M9164C1068 to 24 Vac

M934A1250 M9164D1009 50017460-

003 220736B 160° 120 35 160 60 2 135 ohm M9164C1068

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

35 63-2691—01

M934A1268 M9164D1009 50017460-

001 220736B 160° 240 35 160 60 2 135 ohm None

M934A1276 M9164D1009 50017460-

001 220736B 160° 220 35 160 60 2 135 ohm None

M934A1284 M9164D1009 50017460-

003 160° 120 35 160 60 135 ohm M9164A1005

M934A1292 M9164D1009 50017460-

003 220736B 160° 120 35 160 60 2 135 ohm M9164C1068

M934A1300 M9164D1009 50017460-

001 90° 240 35 90 30 135 ohm None York Special

M934A1318 M9164D1009 50017460-

003 220736B 90° 120 35 90 30 2 135 ohm M9164C1068

M934A1326 M9164D1009 50017460-

003 90° 120 35 90 30 135 ohm M9164A1005 Carrier Special

M934A1334 M9164D1009 90° 24 35 90 30 135 ohm None

M934A1342 M9164D1009 160° 24 35 160 60 135 ohm M9164A1005 Wire M9164A1005 to 24 Vac

M934A1359 M9164D1009 220736B 160° 24 35 160 60 2 135 ohm M9164C1068 Wire M9164C1068 to 24 Vac

M934A1367 M9164D1009 50017460-

003 Q209E 160° 120 35 160 60 135 ohm None Carrier Special

M934A1375 M9164D1009 50017460-

001 160° 240 35 160 60 135 ohm None

M934A1383 M9164D1009 50017460-

001 160° 240 35 160 60 135 ohm M9164A1013 For use with W899A systems

M934A1391 M9164D1009 50017460-

003 90° 120 35 90 35 135 ohm M9164A1005

M934A1409 M9164D1009 90° 24 35 90 35 135 ohm None

M934A1425 M9164D1009 160° 24 35 160 60 135 ohm M9164A1005 Use with W899A,E,F systems; Wire

M9164A1005 to 24 Vac

M934A1433 M9164D1009 50017460-

001 220736B 160° 240 35 160 60 2 135 ohm None For use with W899A systems

M934A1441 M9164D1009 50017460-

003 160° 120 35 160 60 135 ohm M9164A1005

M934A1458 M9164D1009 90° 24 35 90 35 135 ohm None

M934A1466 M9164D1009 90° 24 35 90 35 135 ohm None

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

36 63-2691—01

M934A1474 M9164D1009 220736B 160° 24 35 160 60 2 135 ohm M9164C1068 Wire M9164C1068 to 24 Vac

M934A1482 M9164D1009 50017460-

003 220736B 160° 120 35 160 60 2 135 ohm M9164C1068

M934A1490 M9164D1009 Q209E 160° 24 35 160 60 135 ohm None Carrier Special

M934A1508 M9164D1009 50017460-

001 160° 240 35 160 60 135 ohm None Use with W899A systems

M934A1516 M9164D1009 50017460-

003 220736A 90° 120 35 90 35 1 135 ohm M9164C1068

M934A1524 M9164D1009 160° 24 35 160 60 135 ohm M9164A1005 Wire M9164A1005 to 24 Vac

M934A1532 M9164D1009 50017460-

001 90° 240 35 90 35 135 ohm None

M934A1540 M9164D1009 50017460-

003 90° 120 35 90 35 135 ohm M9164A1005 York Special

M934A1557 M9164D1009 50017460-

001 160° 208/240 35 160 60 135 ohm None G.E. Special

M934A1565 M9164D1009 50017460-

003 220736A 90° 120 35 90 35 1 135 ohm M9164C1068 Reset aux. switch

M934A1573 M9164D1009 50017460-

003 160° 120 35 160 60 135 ohm M9164A1005 Carrier Special

M934A1599 M9164D1009 Q209E 160° 24 35 160 60 135 ohm None

M934B1036 M6284D1000-S 90° 24 35 90 35 Series 62 M6284F1013-S No internal balance circuit, requires Q181

when using R927

M934C1001 M9164D1009 50017460-

003 Q181A1004 90° 120 35 90 35 135 ohm M9164A1005

+Q181A1004 Nesbitt Special; Q181 for Nesbitt Relay

Driver

M934D1000 M9174D1007 50017460-

003 220736A 160° 120 75 160 60 1 135 ohm M9174B1043

M934D1018 M9174D1007 50017460-

003 220736B 160° 120 75 160 60 2 135 ohm M9174C1033

M934D1026 M9174D1007 50017460-

003 220736A 90° 120 75 90 35 1 135 ohm M9174B1027 +

220738A

M934D1034 M9174D1007 50017460-

003 220736B 90° 120 75 90 35 2 135 ohm M9174C1025

M934D1042 M9174D1007 50017460-

003 220736B 90° 120 75 90 35 2 135 ohm None Cleaver Brooks Special

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

37 63-2691—01

M934D1059 M9174D1007 50017460-

003 220736A 90° 120 75 90 35 1 135 ohm None

M934E1009 M9174D1007 160° 24 75 160 60 135 ohm M9174B1043 Remove transformer

M934E1017 M9174D1007 50017460-

003 160° 120 75 160 60 135 ohm M9174B1043

M934E1025 M9174D1007 50017460-

003 90° 120 75 90 35 135 ohm M9174B1043

M941A1008 None 24 75 90/160 15/30 135 ohm M9484D1010 Shipped in 160° position

M941A1016 None 24 150 90/160 30/60 135 ohm M9484D1010 Tapped aux shaft, Shipped in 160° position

M941A1024 None 24 150 90/160 60/120 135 ohm M9484D1010 Shipped in 160° position

M941A1032 None 24 150 90/160 30/60 135 ohm M9484D1010 Tapped aux shaft; Shipped in 90° position

M941A1040 None 24 37 90/160 7.5/15 135 ohm None Special timing

M941A1057 None 24 75 90/160 15/30 135 ohm M9484D1010 Shipped in 90° position

M941A1065 None 24 75 90/160 15/30 135 ohm M9484D1010 International Shipped in 160° position

M941A1073 None 24 150 90/160 30/60 135 ohm M9484D1010 Tapped aux shaft; International Shipped in

90° position

M941A1081 None 24 150 90/160 30/60 135 ohm M9484D1010 Tapped aux shaft; International Shipped in

160° position

M941A1099 None 24 150 90/160 60/120 135 ohm M9494D1000 International Shipped in 90° position

M941A1107 None 24 37 90/160 7.5/15 135 ohm None Special timing shipped in 90° position

M941A4002 None 24 150 90/160 30/60 135 ohm M9484D1010 Canada Special; Tapped aux shaft

M941B1007 None 24 150 90/160 30/60 Series 62 M6284F1013-S No internal balance circuit

M941B1015 M6284D1000-S 24 50 90/160 30/60 Series 62 None

M941C1006 None 24 75 90/160 15/30 1 135 ohm M9484E1009 Shipped in 160° position

M941C1014 None 24 150 90/160 30/60 1 135 ohm M9484E1017 Tapped aux shaft; Shipped in 160° position

M941C1022 None 24 150 90/160 30/60 1 135 ohm M9484E1033 Shipped in 90° position

M941C1030 None 24 150 90/160 30/60 1 135 ohm M9484E1033 Tapped aux shaft, aux switch set to 7°;

Shipped in 90° position, switch set at 4°,

with crankarm

M941C1048 None 24 150 90/160 30/60 1 135 ohm M9484E1033 Aux. switch set at 4°, with crankarm;

Shipped in 90° position.

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

38 63-2691—01

M941C1055 None 24 150 90/160 30/60 1 135 ohm M9484E1033 Tapped aux shaft, aux. switches set to 4°;

International, shipped in 90° position, with

tapped shaft

M941C1063 None 24 150 90/160 30/60 1 135 ohm M9484E1033 Tapped aux shaft, replaced model includes

crank arm; Tapped shaft

M941C1089 None 24 150 90/160 30/60 1 135 ohm None Cleaver Brooks Special, Tapped aux shaft

M941C4000 None 24 150 90/160 30/60 1 135 ohm M9484E1017 +

220741A Canada Special, Tapped aux shaft, aux

switch set at 5°, tapped shaft

M941C4018 None 24 150 90/160 30/60 1 135 ohm M9484E1017 +

220741A Canada Special, Tapped aux shaft, aux

switch set at 30°, tapped shaft

M941D1005 None 24 150 90/160 30/60 2 135 ohm M9484F1007 Aux switched set to 7°/57°; Shipped in 90°

position, switches set at 5°/54°, no tapped

shaft

M941D1013 None 24 150 90/160 30/60 2 135 ohm M9484F1007 Tapped aux shaft, aux. switch set to 7°/57°;

Shipped in 90° position, Switches set at 5°/

54°, crankarm, no tapped shaft

M941D1021 None 24 75 90/160 15/30 2 135 ohm M9484F1023 Tapped aux shaft, shipped in 160° position

M941D1039 None 24 150 90/160 30/60 2 135 ohm M9484F1031 Tapped aux shaft, aux switches set to 5°/

54°; tapped shaft, shipped in 90° position

M941D1047 None 24 150 90/160 30/60 2 135 ohm M9484F1049 Tapped aux shaft, aux switches set to 35°/

120°

M941D1054 None 24 150 90/160 30/60 2 135 ohm M9484F1031 Tapped aux shaft, aux switches set to 5°/

54°; International, Shipped in 90° position

M941D1062 None 24 150 90/160 30/60 2 135 ohm M9484F1031 Tapped aux shaft, aux switches set to 90°/

107°; International

M941D1070 None 24 150 90/160 30/60 2 135 ohm M9484F1007 Cleaver Brooks Special; Tapped aux shaft,

aux switches set to 5°/54°

M941D1112 None 120 300 90/160 60/120 2 135 ohm None Aux. switches to 7°/57°

M941D4009 None 24 150 90/160 30/60 2 135 ohm M9484F4001 Canada Special, requires 220741A, switch

preset at 5°/54°; Tapped aux shaft, aux.

shaft set to 5°/54°

M941D4017 None 24 75 90/160 15/30 2 135 ohm M9484F4019

M941E1012 None 24 75 160 30 135 ohm M9484D1010 International

M941E1038 None 24 150 160 60 135 ohm M9484D1010

M941E1046 None 24 150 160 60 135 ohm M9484D1010

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

39 63-2691—01

M941E1053 None 24 150 90 60 135 ohm None

M941E1061 None 24 75 90 60 135 ohm None

M943A1004 None 24 40 240 90 2 135 ohm None Singer Special, 240° stroke

M944A1002 M9184D1021 160° 24 150 160 60 135 ohm M9184A1019

M944A1010 M9184D1021 160° 24 150 160 60 135 ohm M9184A1019

M944A1028 M9184D1021 90° 24 150 90 30 135 ohm M9184D1021

M944A1036 None 24 37 160 15 135 ohm None

M944A1044 None 24 37 310 15 135 ohm None

M944A1051 M9184D1021 90° 24 75 90 30 135 ohm m9184F1034 Univac Special

M944A1069 M9184D1021 50017460-

003 90° 120 75 90 30 135 ohm m9184F1034 Requires 50017460-001

M944A1119 None 24 37 335 15 135 ohm None No 335° stroke motors

M944A1127 None 24 75 335 30 135 ohm None

M944A1150 M9184D1021 160° 24 150 160 120 135 ohm M9194D1003 Chrysler Special, check timing

M944A1168 M9184D1021 160° 24 150 160 60 135 ohm M9184A1019

M944A1176 M9184D1021 160° 24 150 160 60 135 ohm M9184A1019

M944A1192 M9184D1021 90° 24 75 90 30 135 ohm m9184F1034 Nesbitt Special

M944B1001 M6284D1000-S 160° 24 150 160 60 Series 62 M6284D1000-S No internal balance circuit, requires Q181

when using R927

M944B1019 M6284D1000-S 160° 24 150 160 60 Series 62 M6284D1000-S

M944B1027 None 24 37 160 15 Series 62 None

M944B1035 M6284D1000-S 160° 24 150 160 240 Series 62 None

M944B1043 M6284D1000-S 90° 24 75 90 30 Series 62 M6284A1055-S No internal balance circuit, check timing and

stroke, requires Q181 when using R927

M944B1167 M6284D1000-S 160° 24 150 160 60 Series 62 M6284D1000-S

M944B1175 M6284D1000-S 160° 24 150 160 60 Series 62 M6284D1000-S

M944B1183 M6284D1000-S 160° 24 37 160 15 Series 62 M6284D1000-S

M944B1191 M6294D1008-S 160° 24 300 160 240 Series 62 None No internal balance circuit, requires Q181

when using R927

M944B1209 M6284D1000-S 160° 24 150 160 60 Series 62 M6284D1000-S

M944B1241 M6294D1008-S 220736A 160° 24 150 160 240 1 Series 62 None

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

40 63-2691—01

M944B4005 M6284D1000-S ADJ 24 75 90/160 15/30 Series 62 M6284D1000-S Canada Special, no internal balance circuit,

requires Q181 when using R927

M944C1000 M9184D1021 ADJ 24 75 90/160 15/30 135 ohm M9184D1005 M9184D is 30/60 sec timing

M944C1018 M9194D1003 ADJ 24 300 90/160 120/

240 135 ohm M9194D1003

M944C1042 M9184D1021 ADJ 24 150 90/160 30/60 135 ohm M9184D1021

M944C1059 M9194D1003 220736A ADJ 24 300 90/160 120/

240 1 135 ohm M9194E1000

M944C4004 M9184D1021 ADJ 24 150 90/160 30/60 135 ohm M9184D1021 Canada Special

M944C4012 M9184D1021 ADJ 24 150 90/160 120/

240 135 ohm M9194D1003

M944D1009 M9184D1021 220736B ADJ 24 150 90/160 30/60 2 135 ohm m9184F1034

M944D1017 M9184D1021 220736B ADJ 24 150 90/160 30/60 2 135 ohm m9184F1034

M944E1008 M6284D1000-S 220736B ADJ 24 75 90/160 15/30 2 Series 62 None M6284 is 30/60 sec timing, No internal

balance circuit

M944E1016 M6284D1000-S 220736B ADJ 24 150 90/160 30/60 2 Series 62 M6284F1013-S No internal balance circuit

M944E1024 M6284D1000-S 220736B ADJ 24 150 90/160 30/60 2 Series 62 M6284F1013-S Set aux switches at 4°/54°, no internal

balance circuit

M944E1032 M6284D1000-S 220736B ADJ 24 75 90/160 15/30 2 Series 62 None Replaced motor is 2X faster, No internal

balance circuit

M944E1040 M6284D1000-S 220736B ADJ 24 150 90/160 30/60 2 Series 62 M6284F1013-S No internal balance circuit

M944E1057 M6284D1000-S 220736B ADJ 24 150 90/160 30/60 2 Series 62 M6284F1013-S Set aux switches at 4°/54°, no internal

balance circuit

M944E1081 M6284D1000-S 220736B 90° 24 75 90 30 2 Series 62 M6284F1013-S Set aux switches at 42°/48°, no internal

balance circuit

M944E1099 M6284D1000-S 220736B 90° 24 150 90 30 2 Series 62 M6284F1013-S No internal balance circuit

M944F1007 M9184D1021 160° 24 150 160 60 135 ohm M9184A1019 Use Q181 for slaved motor applications

M944G1006 M9184D1021 220736B 160° 24 150 160 60 2 Series 62 m9184F1034

M944G1014 M9184D1021 220736B 160° 24 150 160 60 2 Series 62 m9184F1034

M944G1022 M6284D1000-S 50017460-

003 160° 120 150 160 60 Series 62 M6284A1055-S No internal balance circuit, change control

circuit to 24 Vac

M944G1030 M6284D1000-S 50017460-

003 90° 120 150 90 30 Series 62 M6284A1055-S

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

41 63-2691—01

M944G1048 M6284D1000-S 50017460-

003 160° 120 150 160 60 Series 62 M6284A1055-S

M944G1055 M6284D1000-S 50017460-

003 160° 120 150 160 240 Series 62 None No internal balance circuit

M944G1063 M6284D1000-S 50017460-

003 160° 120 150 160 60 Series 62 M6284A1055-S No internal balance circuit, change control

circuit to 24 Vac

M944G1071 M6284D1000-S 50017460-

003 90° 120 150 90 30 Series 62 M6284A1055-S

M944G1089 M6284D1000-S 50017460-

003 160° 120 150 160 60 Series 62 M6284A1055-S

M944G1097 M6284D1000-S 50017460-

003 90° 120 150 90 30 Series 62 M6284A1055-S

M944G1105 M6294D1008-S 50017460-

003 160° 120 300 160 240 Series 62 None No internal balance circuit

M944G1121 M6294D1008-S 50017460-

003 220736A 160° 120 300 160 240 1 Series 62 None

M944H1013 M6284D1000-S 50017460-

003 220736A 160° 120 150 160 60 1 Series 62 M6284F1013-S No internal balance circuit, change control

circuit to 24 Vac; Requires 50017460-003

M944H1021 M6284D1000-S 50017460-

003 220736A 160° 120 150 160 60 1 Series 62 M6284F1013-S

M944H1039 M6284D1000-S 50017460-

003 220736A 160° 120 150 160 60 1 Series 62 M6284F1013-S +

50017460-003 York Special, no internal balance circuit,

change control circuit to 24 V

M944H1047 M6284D1000-S 50017460-

003 220736A 160° 120 150 160 60 1 Series 62 M6284F1013-S +

50017460-003 No internal balance circuit; Change control

circuit to 24V

M944H1062 M6294D1008-S 50017460-

003 220736A 160° 120 150 160 240 1 Series 62 None Trane Special, no internal balance circuit

M944J1002 M6284D1000-S 160° 24 150 160 60 Series 62 M6284D1000-S No internal balance circuit, requires Q181

for aux. pot and when using R927

M944J1051 M6284D1000-S 160° 24 150 160 60 Series 62 M6284D1000-S

M944K1001 M6284D1000-S 50017460-

003 220736B 160° 120 150 160 60 2 Series 62 M6284F1013-S No internal balance circuit, change control

circuit to 24 Vac; Requires 50017460-003

M944K1019 M6284D1000-S 50017460-

003 220736B 160° 120 150 160 60 2 Series 62 M6284F1013-S

M944L1018 M9184D1021 50017460-

003 ADJ 120 150 90/160 120/

240 135 ohm None

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

42 63-2691—01

M944N1024 M9184D1021 220736A 160° 24 75 160 30 1 135 ohm M6184D1001

+Q607A1050 Tapped shaft

M944N1032 M9184D1021 220736A 90° 24 150 90 30 1 135 ohm M9184F1034

M944N1040 M9184D1021 220736A 90° 24 150 90 30 1 135 ohm M9184F1034

M944N1057 M9184D1021 220736A 160° 24 150 160 60 1 135 ohm M9184F1034

M944N1065 M9184D1021 220736A 160° 24 75 160 30 1 135 ohm M6184D1001 M9184D is 60 sec at 160° stroke; Tapped

shaft; Requires Q607A1050

M944N1073 M9184D1021 220736A 90° 24 150 90 30 1 135 ohm M9184F1034 Tapped shaft

M944N1081 M9184D1021 220736A 90° 24 150 90 30 1 135 ohm M9184F1034

M944P1014 M9184D1021 220736B 90° 24 150 90 30 2 135 ohm M9184F1034

M944P1022 M9184D1021 220736B 90° 24 150 90 30 2 135 ohm M9184F1034

M944P1030 M9184D1021 220736B 90° 24 150 90 30 2 135 ohm M9184F1034

M944P1048 M9184D1021 220736B 90° 24 150 90 30 2 135 ohm M9184F1034

M944R1012 M6294D1008-S 50017460-

003 220736A 160° 120 150 160 120 1 Series 62 None Carrier Special; Check timing and stroke,

requires Q181 when using R927

M944R1020 M6294D1008-S 50017460-

003 220736B 160° 120 150 160 120 2 Series 62 None

M944S1001 M6284D1000-S 50017460-

003 220736B ADJ 120 75 90/160 15/30 2 Series 62 None M6284 is 30/60 sec timing, No internal

balance circuit

M944S1019 M6284D1000-S 50017460-

003 220736B ADJ 120 150 90/160 30/60 2 Series 62 M6284F1013-S No internal balance circuit; Requires

50017460-003

M944S1027 M6284D1000-S 50017460-

003 220736B ADJ 120 150 90/160 30/60 2 Series 62 M6284F1013-S

M945A1009 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018

M945A1017 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018

M945A1025 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018 Less power supply cord

M945A1033 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018

M945A1066 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018 For use with W899B systems

M945A1074 M9185D1004 90° 24 50 90 35 135 ohm M9185A1018

M945A1082 M9185D1004 90° 24 50 90 35 135 ohm M9185A1018

M945A1090 M9185D1004 160° 24 50 160 60 135 ohm M9185D1004

M945A1108 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018 York Special

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

43 63-2691—01

M945A1116 M9185D1004 90° 24 50 90 35 135 ohm M9185A1018

M945A1124 M9185D1004 90° 24 50 90 35 135 ohm M9185A1018 Nesbitt Special

M945A1157 M9185D1004 ADJ 24 50 90/160 30/60 135 ohm M9185D1004

M945A4003 M9185D1004 ADJ 24 50 90/160 30/60 135 ohm M9185D1004 Canada Special

M945AA1007 M9185D1004 220736B 90° 24 50 90 60 2 None Nesbitt Special, N.O. mech.; M9185D is 30

sec., 90° stroke, use aux. end

M945AB1005 M9185D1004 220736A 90° 24 50 90 60 1 None Nesbitt Special; M9185 is 30 sec at 90°

stroke

M945AB1013 M9185D1004 220736A 90° 24 50 90 60 1 None

M945AD1001 M6285A1005-S 90° 24 25 90 60 Series 62 None Trane Special, No internal balance circuit

M945B1057 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S No internal balance circuit, requires Q181

when using R927

M945B1065 M6285A1005-S 90° 24 50 90 30 Series 62 M6285A1005-S

M945B1073 None 24 50 90 30 Series 62 None Nesbitt Special, includes 1.0K ohm

feedback pot

M945B1081 None 24 50 160 60 Series 62 None

M945B1115 M6285A1005-S 50017460-

003 90° 120 50 90 30 Series 62 None Trane Special, no internal balance circuit

M945B4002 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S Canada Special, no internal balance circuit,

requires Q181 when using R927

M945C1007 M6285A1005-S 220736B 160° 24 50 160 60 2 Series 62 M6285C1001-S No internal balance circuit, requires Q181

when using R927

M945C1015 M6285A1005-S 220736B 160° 24 50 160 60 2 Series 62 M6285C1001-S

M945C1031 M6285A1005-S 220736A 90° 24 50 90 30 1 Series 62 None

M945D1006 M9185D1004 220736B 160° 24 50 160 60 2 135 ohm M9185C1006

M945D1030 None 24 50 160 60 2 135 ohm None

M945D1048 None 24 50 160 60 2 135 ohm None

M945E1005 M9185D1004 Q181A1004 160° 24 50 160 60 135 ohm M9185A1018 Q181: slaved motor application

M945E1013 M9185D1004 Q181A1004 160° 24 50 160 60 135 ohm M9185A1018 Add Q181 for slaved motor applications

M945F1004 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018 Use aux. motor end; N.O. - replacement is

normally closed

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

44 63-2691—01

M945F1038 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018 Use aux. motor end; For use with W899M

systems, N.O. - replacement is normally

closed

M945F1046 M9185D1004 50017460-

001 160° 208 50 160 60 135 ohm None Use aux. motor end; N.O.

M945F1053 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018 York Special, N.O.; Use aux. motor end -

replacement is normally closed

M945F4008 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018 Canada Special, N.O.; Use aux. motor end -

replacement is normally closed

M945G1003 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S Use aux. motor end; No internal balance

circuit, requires Q181 when using R927

M945G1037 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S

M945G1045 None 24 50 160 60 Series 62 None Includes 1.8K ohm feedback pot

M945G1052 None 220 50 160 60 Series 62 None IBM Special, N.O., 100K-ohm pot.

M945H1002 M9185D1004 220736B 160° 24 50 160 60 2 135 ohm M9185C1006 M945H includes internal heater

M945H1010 M9185D1004 220736B 160° 24 50 160 60 2 135 ohm M9185C1006

M945J1009 M9185D1004 220736A 160° 24 50 160 60 1 135 ohm M9185C1006

M945J1017 M9185D1004 220736A 160° 24 50 160 60 1 135 ohm M9185C1006 Less power supply cord

M945J1025 M9185D1004 220736B 160° 24 50 160 60 2 135 ohm M9185C1006

M945J1033 M9185D1004 50017460-

003 220736B 160° 120 50 160 60 2 135 ohm None

M945K1008 M6285A1005-S 220736B 160° 24 50 160 60 2 Series 62 M6285C1001-S No internal balance circuit

M945K1016 M6285A1005-S 220736B 160° 24 50 160 60 2 Series 62 M6285C1001-S

M945L1007 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S No internal balance circuit, requires Q181

when using R927

M945L1015 M6285A1005-S 160° 24 50 160 60 Series 62 M6285A1005-S

M945M1006 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018

M945M1022 M9185D1004 50017460-

001 160° 208/240 50 160 60 135 ohm None G.E. Special

M945M1030 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018 Use with W899C systems

M945M1048 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018

M945Y1002 M6285A1005-S Q181A1004 160° 24 50 160 60 Series 62 M6285A1005-S Add Q181 for slaved motor applications

M945Y1010 None 24 50 90 60 135 ohm None Nesbitt Special

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

45 63-2691—01

M945Z1001 M9185D1004 220736B 160° 24 50 160 60 2 135 ohm M9185A1018 N.O.; Requires Q607B1067 - replacement is

normally closed

M945Z1019 M9185D1004 50017460-

001 160° 208/240 50 160 60 135 ohm None N.O.

M954A1001 M9184D1021 ADJ 24 150 90/160 30/60 135 ohm M9184D1021

M954A1019 M9184D1021 ADJ 24 150 90/160 30/60 135 ohm M9184D1021

M954A1027 M9184D1021 ADJ 24 150 90/160 30/60 135 ohm M9184D1021

M954A1035 M9184D1021 ADJ 24 150 90/160 30/60 135 ohm M9184D1021

M954B1000 M9184D1021 220736B 160° 24 150 160 60 2 135 ohm M9184F1034

M954B1018 M9184D1021 220736B 90° 24 150 90 30 2 135 ohm M9184C1031

M954B1026 M9184D1021 220736B 90° 24 150 90 30 2 135 ohm M9184C1031

M954B1034 M9184D1021 220736B 90° 24 150 90 30 2 135 ohm M9184C1031

M954B1042 M9184D1021 220736B 90° 24 150 90 30 2 135 ohm M9184C1031

M954B1059 M9184D1021 50017460-

003 220736B 160° 120 75 160 30 2 135 ohm M9184D1005 Requires 50017460-001

M954B1067 M9184D1021 220736B 160° 24 150 160 60 2 135 ohm M9184F1034

M954B1075 M9184D1021 220736B 90° 24 150 90 30 2 135 ohm None Cleaver Brooks Special

M954C1009 M9184D1021 220736A 160° 24 75 160 30 1 135 ohm M9184D1005

M954C1017 M9184D1021 220736A 90° 24 150 90 30 1 135 ohm M9184F1034

M954C1025 M9184D1021 220736A 90° 24 150 90 30 1 135 ohm M9184F1034

M954C1033 M9184D1021 220736A 160° 24 150 160 60 1 135 ohm M9184F1034

M954C1041 M9184D1021 220736A 160° 24 75 160 30 1 135 ohm M9184D1005

M954C1058 M9184D1021 220736A 90° 24 150 90 30 1 135 ohm M9184F1034

M954C1066 M9184D1021 220736A 90° 24 150 90 30 1 135 ohm M9184F1034

M954C1074 M9184D1021 220736A 160° 24 150 160 60 1 135 ohm M9184F1034

M954C1082 M9184D1021 220736A 90° 24 75 90 30 1 135 ohm M9184F1034 Cleaver Brooks Special

M954C4003 M9184D1021 220736A ADJ 24 150 90/160 30/60 1 135 ohm None Canada Special, aux. switch set at 120°

M954D1008 M9184D1021 220736B ADJ 24 150 90/160 30/60 2 135 ohm M9184F1034

M954D1016 M9184D1021 220736B ADJ 24 150 90/160 30/60 2 135 ohm M9184F1034

M954G1052 None 220 50 160 60 Series 62 None IBM Special, N.O., 100K-ohm pot.

M955A1008 M9185D1004 ADJ 24 50 90/160 30/60 135 ohm M9185D1004

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

46 63-2691—01

M955A1016 M9185D1004 ADJ 24 50 90/160 30/60 135 ohm M9185D1004

M955A1024 M9185D1004 ADJ 24 50 90/160 30/60 135 ohm M9185D1004

M955A1032 M9185D1004 ADJ 24 50 90/160 30/60 135 ohm M9185D1004

M955B1007 M9185D1004 220736B ADJ 24 50 90/160 30/60 2 135 ohm M9185E1019

+Q607A1050

M955C1006 M9185D1004 220736A ADJ 24 50 90/160 30/60 1 135 ohm M9185E1019

M955C1014 M9185D1004 220736A ADJ 24 50 90/160 30/60 1 135 ohm M9185E1019

M955C4000 M9185D1004 220736A ADJ 24 50 90/160 30/60 1 135 ohm M9185E1019 Canada Special, Tapped shaft; TRADELINE

shaft not tapped

M955D1005 M9185D1004 160° 24 50 160 60 135 ohm M9185A1018

M955D1013 M9185D1004 90° 24 50 90 30 135 ohm M9185A1018

M955D1039 M9185D1004 50017460-

003 90° 120 50 90 30 135 ohm None

M955D1047 M9185D1004 90° 24 50 90 30 135 ohm M9185A1018 Lennox Special

M955D1054 M9185D1004 90° 24 50 90 30 135 ohm M9184D1021 York Special

M955E1004 M9185D1004 50017460-

003 220736A 90° 120 50 90 30 1 135 ohm None

M955E1012 M9185D1014 50017460-

003 220736A Q209E 90° 120 50 90 30 1 135 ohm None Trane Special, includes Q209C

M965A1007 M9185D1004 160° 24 25 160 40 135 ohm M9185D1004

M965A1015 M9185D1004 160° 24 25 160 40 135 ohm M9185D1004 For use with W963B systems

M965A1023 M9185D1004 50017460-

003 160° 120 25 160 40 135 ohm None

M965A1031 M9185D1004 50017460-

003 90° 120 25 90 23 135 ohm None York Special

M965A1049 M9185D1004 50017460-

003 90° 120 25 90 23 135 ohm M9185D1004 Requires 50017460-003

M965A1064 M9185D1004 90° 24 25 90 23 135 ohm M9185D1004 No balance relay

M965A1072 M9185D1004 90° 24 25 90 23 135 ohm M9185D1004 Trane Special

M965B1006 M9185D1004 220736B 160° 24 25 160 40 2 135 ohm None

M965B1014 M9185D1004 50017460-

001 220736B 90° 240 25 90 23 2 135 ohm None

M965B1022 M9185D1004 220736A 90° 24 25 90 23 1 135 ohm None

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

47 63-2691—01

M965B1030 M9185D1004 220736B 160° 24 25 160 40 2 135 ohm None Reznor Special

M975A1006 M9185D1004 160° 24 25 160 40 135 ohm M9185D1004

M975A1014 M9185D1004 90° 24 25 90 23 135 ohm M9185D1004

M975A1022 M9185D1004 50017460-

003 160° 120 25 160 40 135 ohm M9185D1004 Requires 50017460-003

M975A1030 M9185D1004 50017460-

003 Q209E 90° 120 25 90 23 135 ohm None Trane Special

M975A1055 M9185D1004 50017460-

003 Q209E 160° 120 25 160 40 135 ohm None Carrier Special

M975A1071 M9185D1004 160° 24 25 160 40 135 ohm M9185D1004

M975A1089 M9185D1004 160° 24 25 160 40 135 ohm M9185D1004

M975A1097 M9185D1004 50017460-

003 160° 120 25 160 40 135 ohm M9185D1004 Requires 50017460-003

M975B1005 M9185D1004 220736B 160° 24 25 160 40 2 135 ohm None

M975B1013 M9185D1004 50017460-

001 220736B 160° 240 25 160 40 2 135 ohm None

M975B1021 M9185D1004 50017460-

003 220736A Q209E 90° 120 25 90 23 1 135 ohm None Trane Special

M975B1039 M9185D1004 50017460-

003 220736B Q209E 160° 120 25 160 40 2 135 ohm None Carrier Special

M975B1047 M9185D1004 50017460-

003 220736B 90° 120 25 90 23 2 135 ohm None Trane Special, aux. switches set at 35°

M975B1062 M9185D1004 50017460-

003 220736B 90° 120 25 90 23 2 135 ohm None Reznor Special, aux. switches set at 35°

Table 3. Modutrol I, II, III Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Stroke

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Control

Signal

MODUTROL IV™ MOTOR CROSS REFERENCE

48 63-2691—01

MODUTROL IV MOTORS TO MODUTROL IV MOTORS

This section cross references Modutrol IV Motors to Modutrol IV Motors. Please refer to

the Application Notes section for specific comments.

Cross Reference Format

Information contained in individual rows refer to the motor listed in the OS # to be

Replaced column unless otherwise noted in the Comments column. Following is an

example of the format used in this section and explanations of each column.

1. Lists the original motor to be replaced.

2. Lists the Modutrol IV TRADELINE Replacement Motor. This TRADELINE motor

may require configuration with the accessories listed in columns 3 through 8.

3. Specifies which internal mount transformer, if any, is required to match the original

motor voltage. The transformer choices are:

a. 198162AA – 120/208/240 Vac, 50/60 Hz (multi-tap).

b. 198162EA – 120 Vac, 50/60 Hz.

c. 198162GA – 220 Vac, 50/60 Hz.

d. 198162JA – 24 Vac, 50/60 Hz (isolation).

4. Specifies which field-addable auxiliary switch, if any, is required to match the

original motor. The switch kit choices are:

a. 220736A – one spdt switch and mounting bracket.

b. 220736B – two spdt switches and mounting bracket.

5. Specifies which accessory parts or devices, if any, are required to complete the

replacement. Items include Weatherproofing Kits, Minimum Position

Potentiometers, and linkages. Check the original application to ensure that you

account for all modifications of the original motor.

6. Specified stroke setting of the Modutrol IV TRADELINE Motor. 12 of the 14

TRADELINE models have adjustable stroke. The remaining two (M6285A) are

fixed stroke. “ADJ” listed here indicates the original motor also had adjustable

stroke. Check the application to duplicate the original stroke requirements.

7. Specifies the original motor auxiliary switch setting that was factory set. Check the

application to make sure that the original factory stroke setting was not changed in

the field. Motors shipped with specific stroke settings have adjustable auxiliary

switches, and there is possibility that the original setting was changed.

8. Lists the voltage of the original motor.

9. Lists the torque rating of the original motor.

10. Lists the full stroke rotation of the original motor (closed to open) in angular

degrees. Two values with a “-” indicate a range of adjustment available in the field.

11. Lists the timing of the original motor. If two or adjustable stroke is listed in

column 10, the time refers to a 160 degree stroke.

12. Lists the number of auxiliary switches, if any in the original motor.

13. Lists number of motor shafts on the original motor. Choices are 1 or 2. All motors

have the power end shaft, when listed as 1, the auxiliary end shaft of the original

motor is not present.

14. Indicates that a 220738A Adapter Bracket is shipped with the Modutrol IV Motor.

Reflects presence as of 1999 date codes. If the original motor used the adapter

bracket, it may be reused with the replacement motor. If required for replacement

of Modutrol I, II, III or competitive Motors, it must be ordered separately.

15. Lists the control signal of the motor. The listing can specify either an actual value of

signal input, or a “Series” designation. Please refer to the Application Notes

section in this manual.

16. Lists the functional Modutrol IV Motor replacement. In some cases, the replace-

ment will have additional features not found in the original motor. This column may

also specify “+” and an accessory. This indicates a minor addition to the functional

replacement will provide the functionality required in the application.

17. Comments listed in this column provide additional information to consider when

replacing the original motor. Consider differences carefully prior to installation of

the Modutrol IV TRADELINE Motor.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications Original Motor Specifications

Functional

Replacement TRADELINE

Comments

Model

Number Required

Transformer Required

Aux. Switch Required

Accessories Stroke

Setting

Aux.

Switch

Setting Voltage

(Vac) Torque

(lb-in.) Stroke

(degrees) Timing

(sec) Aux

Sw Motor

Shafts Adapt

Brack Control

Signal

12345678910111213141516 17

MODUTROL IV™ MOTOR CROSS REFERENCE

49 63-2691—01

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

M4172A1006 M8185D1006 50017460-003 60 M4185A1001

M4172B1004 M4185B1058 60 1 M4185B1009

M4175D1015 M4185B1058 30/60 None

M4175E1012 M8185D1006 50017460-003 220736A 30/60 1 None

M4182A1004 M8185D1006 50017460-003 60 M4185A1001

M4182B1002 M8185D1006 50017460-003 220736A 60 1 M4185B1009

M4182B1010 M8185D1006 50017460-001 220736A 60 1 M4185B1017

M4182B1028 M8185D1006 50017460-001 220736A 60 1 None

M4182B1036 M4185B1009 30 1 M4185B1058

M4182B1044 M8185D1006 50017460-001 220736A 30 1 M4185B1058

M4182B1051 M8185D1006 50017460-003 220736A 4074ERU 30 1 M4185B1058 With weatherproof kit; Requires 4074ERU

M4182B1069 M8185D1006 50017460-003 220736A 4074ERU 60 1 M4185B1009

M4185A1001 N/A 60 N/A

M4185A1019 M8185D1006 50017460-003 67 None

M4185A1027 M8185D1006 50017460-003 60 M4185A1001

M4185B1009 N/A 60 1 N/A

M4185B1017 M4185B1058 60 1 M4185B1017

M4185B1025 M8185D1006 50017460-001 220736A 60 1 None

M4185B1033 M8185D1006 50017460-003 220736A 60 1 M4185B1009

M4185B1041 M8185D1006 50017460-001 220736A 60 1 M4185B1017

M4185B1058 N/A 30 1 N/A

M4185B1066 M8185D1006 50017460-003 220736A 30 1 M4185B1058

M4185B1074 M8185D1006 50017460-001 220736A 60 1 None

M4185C1007 N/A 30 2 None

M4185D1013 M8185D1006 50017460-003 30 None

M4185E1010 M8185D1006 50017460-003 220736A 30 1 None

M4185E4006 N/A 30/60 1 None Canada TRADELINE

M4185E4014 N/A 30/60 1 None Canada TRADELINE

M4186H1005 M8185D1006 50017460-003 220736A 60 1 M4185B1009 Use auxiliary shaft

MODUTROL IV™ MOTOR CROSS REFERENCE

50 63-2691—01

M4186H4009 M8185D1006 50017460-003 220736A 60 1 None Canada, use auxiliary shaft

M4186L4000 M8185D1006 50017460-003 220736A 30/60 1 None

M6161A1004 M6184A1023 30 M6184A1015

M6161B1002 M6184D1035 50017460-003 220736A 30 1 None

M6174A1009 M6184D1035 60 None Includes aux. switch cams

M6174D1003 M6184D1035 50017460-003 30/60 M6184D1035

M6181A1000 M6184D1035 60 None Less junction box

M6181A1018 M6184A1015 60 None

M6181A1026 M6184D1035 30 M6184A1015

M6181A1034 M6184A1023 30 M6184A1023

M6181A1042 M6184D1035 50017460-003 60 None

M6181A1059 M6184D1035 60 None Carrier

M6181D1004 M6184D1035 15/30 M6184D1001

M6181F1009 M6184D1035 220736B 30/60 2 M6184F1014

M6181F1017 M6184D1035 50017460-001 220736B 30/60 2 M6184F1014 Replacement requires 50017460-001

M6182D1003 None 15/60 None Carrier

M6182D1011 None Select None

M6182F1008 None 15/60 2 None

M6182F1016 M6285A1005-S 30/60 2 None With weatherproof kit

M6184A1007 M6184D1035 60 None

M6184A1015 N/A 30 N/A

M6184A1023 N/A 30 N/A

M6184A1031 M6184D1035 60 None Carrier

M6184A1049 M6184D1035 50017460-003 30 M6184A1023

M6184A1056 M6184D1035 30 None Trane

M6184B1005 M6184D1035 50017460-003 220736A 120 1 None

M6184B1013 N/A 120 1 None Trane

M6184B1021 M6184D1035 220736A 60 1 M6184F1014

M6184D1001 N/A 15/30 N/A

M6184D1035 N/A 30/60 N/A TRADELINE

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

51 63-2691—01

M6184D1050 M6184D1035 15/30 M6184D1001

M6184D1068 N/A 120/240 N/A

M6184D1076 M6184D1035 30/60 None Trane

M6184F1006 M6184D1035 220736B 30/60 2 M6184F1014

M6184F1014 N/A 30/60 2 N/A

M6185D1000 M6285A1005-S 30/60 None

M6191A1008 M6194D1017 50017460-003 120 None

M6191B1006 M6194D1017 220736A 60 1 M6194B1011

M6191D1002 M6284D1008-S 120/240 M6194D1017

M6191D1010 M6194D1017 50017460-003 120/240 None York

M6194A1005 N/A 120 None OEM

M6194A1021 M6194D1017 120 None With aux. switch cams

M6194B1003 M6194D1017 220736A 60 1 M6194B1011

M6194B1011 N/A 220736A 60 1 N/A

M6194B1029 N/A 120 1 N/A Requires 50017460-003 - Trane

M6194B1037 M6194D1017 50017460-003 220736A 120 1 None Trane

M6194B1045 M6194D1017 50017460-003 220736A 120 1 M6194E1006 Requires 50017460-003

M6194D1017 N/A 120/240 N/A TRADELINE

M6194D1025 M6194D1017 120/240 None Lennox

M6194D1033 M6194D1017 120/240 None York

M6194D1041 M6194D1017 220741A2-61 120/240 None Japan, includes 220741A

M6194D4003 N/A 120/240 N/A Canada TRADELINE

M6194E1006 N/A 220736A 120/240 1 N/A

M6194E1014 M6194D1017 220736A 4074ERU 120/240 1 M6194E1006 + 4074ERU Includes weatherproof kit

M6194F1004 M6194D1017 220736B 120/240 2 None

M6281A1009 M6284D1000-S 60 M6284A1055-S

M6281F1008 M6284D1000-S 220736B 30/60 2 M6284F1013-S

M6281F1016 M6284F1062-S 50017460-003 220736B 30/60 2 M6284F1013-S Requires 50017460-003

M6282A1008 M6285A1005-S 60 M6285A1005-S

M6282A1016 M6285A1005-S 50017460-003 30 None Trane

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

52 63-2691—01

M6282A1024 M6285A1005-S 60 None

M6282A1032 M6285A1005-S 50017460-003 60 None

M6282B1006 M6285A1005-S 220736A 30 1 None

M6282E1009 M6282A1009-F 15/60 1 None Carrier

M6284A1006 M6284D1000-S 60 M6284A1055-S

M6284A1014 M6284D1000-S 50017460-003 60 M6284A1055-S

M6284A1022 M6284D1000-S 50017460-003 30 M6284A1055

M6284A1030 M6284A1030-S 60 None Japan, includes 220741A

M6284A1048 M6284A1055-S 60 M6284A1055-S

M6284A1055 M6284A1055-S 30 M6284A1055-S

M6284A1063 M6284D1000-S 50017460-003 220741A2-62 60 M6284A1055-S + 4074ERU Includes 220741A

M6284A1071 M6284A1071-S 30 M6284A1071-S

M6284A1089 M6284A1089-S 15 M6284A1089-S

M6284A1097 M6284A1097-S 30 M6284A1097-S

M6284B1004 M6284B1004-S 240 1 None Trane

M6284C1002 M6284D1000-S 220736B 30 2 M6284F1013-S

M6284C1010 M6284C1010-S 30 2 None Includes 220741A

M6284C1028 M6284C1028-S 30 2 None Japan, includes 220741A

M6284C1036 M6284D1000-S 50017460-003 220736B 4074ERU 60 2 None Includes weatherproof kit

M6284C1044 M6284C1044-S 30 2 None

M6284D1000 M6284D1000-S 30/60 M6284D1000-S TRADELINE

M6284D1026 M6284D1026-S 30/60 None Includes 220741A

M6284D4004 M6284D4004-S 30/60 N/A Canada TRADELINE

M6284F1005 M6284D1000-S 220736B 30/60 2 M6284F1013-S

M6284F1013 M6284F1013-S 220736B 30/60 2 N/A

M6284F1021 M6284D1000-S 50017460-003 220736B 30/60 2 M6284F1013-S Requires 50017460-003

M6284F1039 M6284F1039-S 30/60 2 N/A Japan, includes 220741A

M6284F1047 M6284D1000-S 50017460-003 220736B 30/60 2 M6284F1013-S Requires 50017460-003

M6284F1054 M6284F1062-S 30/60 2 None

M6285A1005 M6285A1005-S 60 N/A TRADELINE

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

53 63-2691—01

M6285A1013 M6285A1005-S 30 N/A

M6285A1021 M6285A1005-S 50017460-003 30 None

M6285A1039 M6285A1039-S 60 None Trane

M6285A1047 M6285A1047-S 60 None Japan, includes 220741A

M6285A1054 M6285A1054-S 60 None Snyder General

M6285A4009 M6285A4009-S 60 M6285A4009-S Canada TRADELINE

M6285B1003 M6285A1005-S 220736A 30 1 None

M6285C1001 M6285C1001-S 60 2 M6285C1001-S

M6286G1001 M6285A1005-S 60 M6285A1005-S Use auxiliary shaft

M6286G1019 M6285A1005-S 50017460-001 60 None

M6286G1027 M6285A1005-S 220741A2-62 60 M6285A1005-S + 4074ERU Japan, includes 220741A, use auxiliary shaft

M6294A1004 M6294D1008-S 50017460-003 240 None

M6294B1002 M6294D1008-S 220736A 240 1 None

M6294B1010 M6294D1008-S 50017460-003 220736A 240 1 None

M6294B1028 M6294D1008-S 50017460-003 220736A 240 1 None Trane

M6294B1036 M6294B1036-S 120 1 None

M6294C1000 M6294D1008-S 50017460-003 220736B 220741A 60 2 None Includes 220741A

M6294D1008 M6294D1008-S 120/240 M6294D1008-S

M7161A1002 M9164D1009 50017460-003 Q7130A1006 30 None

M7161B1000 M9164D1009 50017460-003 220736A Q7130A1006 60 1 None

M7161B1018 M9164D1009 50017460-003 220736A Q7130A1006 60 1 None Trane

M7161G1009 M9164D1009 50017460-003 Q7130A1006 30 M7164G1030

M7161G1017 M9164D1021 50017460-003 Q7130A1006 30 None

M7161G1025 M9164D1009 Q7130A1006 60 None

M7164A1009 M9164D1009 Q7130A1006 60 None

M7164A1017 N/A 30 N/A

M7164A1025 M9164D1009 Q7130A1006 30 None Lennox

M7164A1033 M9164D1009 Q7130A1006 60 None

M7164A1041 M9164D1009 Q7130A1006 60 None

M7164A1058 M9164D1009 50017460-001 Q7130A1006 30 M7164A1017

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

54 63-2691—01

M7164B1007 M9164D1009 50017460-003 220736A Q7130A1006 60 1 None

M7164G1006 M9164D1009 50017460-003 Q7130A1006 30 M7164G1030

M7164G1014 M9164D1009 50017460-003 Q7130A1006 30 None

M7164G1022 M9164D1009 Q7130A1006 60 None

M7164G1030 N/A 30 N/A

M7183G1003 M9185D1004 Q7130A1006 60 N/A Use auxiliary shaft

M7184A1005 M9184D1021 Q7130A1006 60 None

M7184A1013 None 30 None

M7184A1021 None 30 None

M7185A1004 M9185D1004 Q7130A1006 60 N/A

M7186G1000 M9185D1004 Q7130A1006 60 N/A Use auxiliary shaft

M7261A1001 N/A 60 N/A Trane

M7272A1008 M9185D1004 50017460-003 Q7230A1005 30 None

M7274A1006 M9174D1007 Q7230A1005 60 N/A

M7274G1003 M9174D1007 Q7230A1005 60 N/A

M7281A1007 M7284A1004 30 M7284A1004 Includes 220741A

M7281C1003 M9184D1021 50017460-003 220736B Q7230A1005 30 2 M7284C1000

M7281C1011 M9184D1021 50017460-003 220736B Q7230A1005 60 2 M7284C1018

M7281Q1002 M7284Q1009 30 2 M7284Q1009 Includes 203709D

M7282A1006 M9185D1004 50017460-003 Q7230A1005 30 M7285A1003 Includes 220741A

M7282A1014 N/A 30 N/A Trane

M7282A1022 N/A 30 N/A Trane, with wiring harness

M7282B1004 M9185D1004 50017460-003 220736A Q7230A1005 30 1 None Trane

M7282B1012 N/A 30 1 N/A

M7282C1002 M9185D1004 50017460-003 220736B Q7230A1005 30 2 None

M7282D1000 N/A 15/60 N/A Carrier, with 205118A

M7282D1018 M7282D1000 50017460-001 15/60 None Carrier

M7282F1005 M7282D1000 220736B 15/60 2 None Carrier, 205118A and crank arm

M7284A1004 N/A 30 N/A Includes 220741A

M7284A1012 N/A 60 N/A

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

55 63-2691—01

M7284A1020 M9184D1021 50017460-003 Q7230A1005 60 M7284A1012

M7284A1038 N/A 15 N/A

M7284A1046 M7284A1004 30 M7284A1004

M7284A1053 N/A 30 N/A Trane

M7284A1061 M9184D1021 50017460-003 Q7230A1005 60 None

M7284A1079 N/A 60 N/A

M7284A1087 N/A 30 N/A Trane

M7284C1000 N/A 30 2 N/A Includes 220741A2-72

M7284C1018 M7284C1000 60 2 N/A

M7284C1026 M9184D1021 50017460-003 220736B Q7230A1005 30 2 M7284C1000 includes 220741A2-72

M7284C1034 M9184D1021 50017460-003 220736B Q7230A1005 60 2 M7284C1018 includes 220741A2-72

M7284C1042 M9184D1021 220736B Q7230A1005 30 2 None International, incl.220741A

M7284C1059 M7284C1083 30 2 None Enhanced

M7284C1067 M7284C1091 30 2 None

M7284G1001 M9184D1021 Q7230A1005 60 M7284A1079

M7284Q1009 N/A 30 2 N/A Includes 203709D

M7284Q1017 M7284Q1009 60 2 None

M7284Q1025 M7284Q1009 30 None International, incl.203709D

M7284Q1033 M7284Q1082 30 2 None Enhanced

M7284Q1041 M7284Q1090 60 2 None

M7285A1003 N/A 30 N/A Includes 220741A

M7285A1011 M7285A1003 60 None

M7285A1029 M9185D1004 Q7230A1005 60 None

M7285A1037 M9185D1004 Q7230A1005 60 None

M7285A1045 N/A 60 N/A

M7285A1052 M9185D1004 Q7230A1005 30 None

M7285B1001 M9185D1004 220736A Q7230A1005 30 1 None Trane

M7285C1009 N/A 30 2 N/A Includes 220741A

M7285C1017 M7284C1009 60 2 None

M7285C1025 M9185D1004 220736B Q7230A1005 60 2 None

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

56 63-2691—01

M7285C1033 M9185D1004 220736B Q7230A1005 60 2 None

M7285Q1008 N/A 30 2 N/A Includes 203709D

M7285Q1016 M7285Q1008 60 2 N/A

M7286G1009 N/A 60 N/A

M7294A1002 M9194D1003 50017460-003 Q7230A1005 60 M7294Q1007 Includes 220741A

M7294A1010 N/A 120 N/A

M7294G1009 M7294A1010 120 None

M7294Q1007 N/A 60 2 N/A Includes 203709D

M7361A1000 M9164D1009 50017460-003 Q7330A1004 30 None

M7361A1018 None 60 None Liebert, with 203709B

M7364A1007 M9164D1009 50017460-003 Q7330A1004 60 None

M7364A1015 M9164D1009 50017460-003 Q7330A1004 30 None

M7364A1023 M9164D1009 Q7330A1004 60 None

M7364A1031 M9164A1070 50017460-001 Q7330A1004 60 None Liebert

M7381A1006 None 60 None Liebert, with 203709B board

M7382A1005 None 60 None Liebert

M7384A1003 M9184D1021 Q7330A1004 60 None

M7384A1011 M9184D1021 Q7330A1004 30 None

M7384A1029 None 60 None Liebert

M7385A1002 M9185D1004 Q7330A1004 30 None

M7385A1010 M9185D1004 50017460-003 Q7330A1004 60 None Includes isolation transformer

M7385A1028 M9185D1004 50017460-003 Q7330A1004 60 None

M7385A1036 M9185D1004 Q7330A1004 60 None

M7385A1044 M9185A1018 50017460-001 Q7330A1004 60 None Liebert

M7484A1002 None 30 None Cleaver Brooks

M7484A1010 None 30 None

M7675A1001 M9185D1004 Q7630A1001 60 None

M7675A1019 M9185D1004 50017460-003 Q7630A1001 30 None Trane

M7675G1008 M9185D1004 Q7630A1001 60 None

M7682A1010 M9185D1004 Q7630A1001 60 None Includes Q209F1001

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

57 63-2691—01

M7685A1009 M9185D1004 Q7630A1001 60 None

M7685A1017 M9185D1004 Q7630A1001 30 None

M7685A1025 M9185D1004 Q7630A1001 30 None

M7685A1033 M9185D1004 50017460-003 Q7630A1001 60 None York

M7685A1041 M9185D1004 Q7630A1001 30 None Lennox

M7685G1006 M9185D1004 Q7630A1001 30 None

M7964A1001 None 30 None

M7964B1009 None 30 None Nesbitt ITT

M7964B1017 None 60 None

M7964C1007 None 30 None

M7964C1015 None 30 None

M7964D1005 None 60 None

M7964D1013 None 60 None

M7975E1009 None 30 None

M7975E1017 None 30 None

M7983G1005 None 60 None IBM

M7984D1001 None 60 None Includes 220741A

M7984N1008 None 30 None

M7985D1000 None 60 None

M8175B1002 M8185D1006 220736A 60 1 None

M8182A1005 M8185D1006 60 M8185A1002

M8182B1003 M8185D1006 220736A 60 1 None

M8182B1011 M8185D1006 220736A 4074ERU 60 1 None Includes weatherproof kit

M8185A1002 M8185D1006 60 M8185A1002

M8185A1010 M8185D1006 60 M8185D1006

M8185A1028 None 60 None

M8185B1000 M8185D1006 220736A 60 1 None

M8185B1018 M8185D1006 60 1 M8185D1006

M8185B1026 None 60 1 None

M8185B1034 M8185D1006 220736A 60 1 None

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

58 63-2691—01

M8185D1006 N/A 30/60 N/A TRADELINE

M8186G1008 M8185D1006 60 None Includes aux. switch cams, use aux. shaft

M9161A1008 M9164D1009 50017460-003 60 M9164A1005

M9161A1016 M9164D1009 60 M9164A1005 Wire to 24 Vac

M9161A1024 M9164A1005 30 None

M9161A1032 M9164A1005 60 None Carrier

M9161A1040 M9164D1009 50017460-003 4074ERU 30 M9164A1005 + 4074ERU Includes weatherproof kit

M9161C1004 M9164C1001 220736B 60 2 M9164C1068 Wire to 24 Vac

M9161C1012 M9164C1068 30 2 None

M9161V1009 N/A 60 N/A Carrier

M9164A1005 N/A 30 N/A

M9164A1013 N/A 60 N/A

M9164A1021 M9164A1005 60 M9164A1005

M9164A1039 M9164D1009 50017460-003 60 M9164A1005

M9164A1047 M9164D1009 50017460-001 60 M9164A1013

M9164A1054 M9164D1009 50017460-003 30 M9164A1005

M9164A1062 M9164D1009 30 M9164A1005 Wire to 24 Vac

M9164A1070 N/A 60 N/A

M9164A1088 M9164A1013 60 None

M9164A1096 M9164D1009 50017460-003 60 M9164A1005

M9164A1104 M9164D1009 50017460-003 60 None Carrier

M9164A1112 M9164D1009 50017460-001 30 None York

M9164A1120 M9164D1009 30 M9164A1005 Wire to 24 Vac

M9164A1138 M9164D1009 50017460-003 60 None Carrier

M9164B1003 M9164D1009 50017460-003 220736A 30 1 M9164C1068

M9164C1001 N/A 60 2 N/A Wire to 24 Vac

M9164C1019 M9164D1009 50017460-003 220736B 60 2 M9164C1068

M9164C1027 M9164D1009 50017460-001 220736B 60 2 None

M9164C1035 M9164D1009 50017460-003 220736B 30 2 M9164C1068

M9164C1043 M9164D1009 50017460-003 220736B 60 2 M9164C1068

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

59 63-2691—01

M9164C1050 M9164C1068 60 2

M9164C1068 N/A 30 2 N/A

M9164D1009 N/A 30/60 N/A TRADELINE

M9164V1006 N/A 60 N/A Carrier

M9164V1014 M9164D1009 60 None

M9164V1022 M9164D1009 Q209E1010 60 None Carrier, with Q209E, crank arm

M9171A1006 M9174B1027 50017460-003 60 M9174B1027

M9171B1004 M9184D1021 50017460-003 220736A 60 1 M9174B1027

M9171B1012 M9174D1007 50017460-003 220736A 30 1 M9174B1027

M9171B1020 None 30 1 None Cleaver Brooks

M9171C1002 M9174C1025 22036B 30 2 M9174C1025

M9171C1010 M9174D1007 50017460-003 220736B 30 2 9174C1041 Cleaver Brooks

M9172A1005 M9185D1004 60 None

M9172A1013 M9185D1004 60 None

M9172A1021 M9185D1004 60 None Carrier

M9172C1001 M9185D1004 220736B 60 2 None Reznor

M9172W1004 M9185D1004 50017460-003 220736A Q209E1010 30 1 None Trane, with Q209E1010

M9172W1012 N/A 60 1 N/A Carrier

M9174B1001 M9174D1007 50017460-003 220736A 60 1 M9174B1027

M9174B1019 M9174D1007 50017460-003 220736A 30 1 M9174B1027 Requires 220738A

M9174B1027 N/A 30 1 N/A

M9174B1035 M9184D1021 50017460-003 220736A 30 1 None Cleaver Brooks

M9174B1043 M9174B1027 60 1 M9174B1027

M9174C1009 M9174D1007 50017460-003 220736B 60 2 M9174C1033

M9174C1017 M9174D1007 50017460-003 220736B 30 2 M9174C1025

M9174C1025 N/A 30 2 N/A

M9174C1033 N/A 60 2 N/A

M9174C1041 N/A 30 2 None Cleaver Brooks

M9174D1007 N/A 30/60 N/A TRADELINE

M9175A1002 M9185D1004 60 None

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

60 63-2691—01

M9175A1010 M9185A1018 221455A 30 None Includes crank arm

M9175A1028 M9185D1004 60 None

M9175A1036 M9185D1004 50017460-003 30 None York

M9175A1044 M9185D1004 50017460-003 30 None

M9175A1051 M9185A1018 30 None

M9175A1069 M9185D1004 60 None Carrier

M9175A1077 M9185D1004 30 None Trane

M9175B1000 N/A 30 1 N/A

M9175C1008 M9185D1004 50017460-003 220736A 30 2 None Reznor

M9175D1006 M9185A1018 50017460-003 30/60 M9185D1004 Requires 50017460-003

M9175D1014 M9185D1004 30/60 M9185D1004 TRADELINE

M9175V1003 M9185D1004 50017460-003 30 None Trane

M9175V1011 None 60 None Carrier, leadwires

M9175W1001 M9185D1004 50017460-003 220736A 60 1 None Carrier

M9175W1019 M9185D1004 50017460-003 220736A 30 1 None Trane

M9175Y1007 M9185D1004 50017460-003 220736B 30 2 None

M9181A1004 M9184D1021 60 M9184A1019

M9181A1012 M9184A1019 60 None

M9181A1020 M9184D1021 60 M9184A1019

M9181A1038 M9184D1021 30 M9184A1035

M9181B1002 M9184D1021 220736A 30 1 M9184C1031

M9181B1010 M9184D1021 220736A 60 1 None

M9181B1028 None 30 1 None Cleaver Brooks

M9181C1000 None 30 2 None

M9181D1008 M9184D1021 15/30 M9184D1005

M9181D1016 N/A 120/240 N/A Trane

M9181D1024 None 60/120/

240 None Special Timing

M9182A1003 M9185D1004 60 M9185A1018 Less junction box

M9182A1011 N/A 60 N/A

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

61 63-2691—01

M9182A1029 M9185A1018 30 None

M9182A1037 M9185D1004 50017460-003 30 None Trane

M9182A1045 M9185D1004 60 M9185A1018

M9182A1052 M9185D1004 4074ERU 60 M9185A1018 + 4074ERU Includes weatherproof kit

M9182A1060 M9185D1004 50017460-003 30 None York

M9182C1009 M9185C1006 60 2 None

M9182C1017 M9185D1004 220736B 30 2 None

M9182D1007 M9185D1004 30/60 M9185D1004 Less junction box

M9182D1015 M9185D1004 30/60 M9185D1004

M9182D1023 N/A 60/120/

240 N/A Special Timing

M9182D1031 M9185D1004 50017460-001 Q209E1010 30/60 None Includes Q209E

M9182D4001 M9185D4008 30/60 M9185D1004 Canada

M9182W1002 M9185D1004 50017460-003 220736A Q209E1010 30 1 None Trane, includes Q209E

M9183G1009 M9185D1004 60 M9185A1018 Use auxiliary shaft

M9184A1001 M9184D1021 60 M9184A1019

M9184A1019 N/A 60 N/A

M9184A1027 M9184D1021 30 M9184A1035

M9184A1035 M9184D1021 30 M9184A1019

M9184A1043 M9184D1021 220741A2-90 60 M9184A1019 Japan; replacement requires 220741A

M9184B1009 N/A 30 1 N/A Cleaver Brooks

M9184B1017 N/A 30 1 N/A

M9184B1025 N/A 30 1 N/A Cleaver Brooks

M9184B1033 M9184D1021 220736A 60 1 M9184F1034 With tapped shaft

M9184B1041 M9184D1021 220736A 4074ERU 30 1 M9184C1031 Includes weatherproof kit

M9184C1007 M9184D1021 220736B 30 2 M9184C1031 With tapped shaft

M9184C1015 M9184D1021 220736B 60 2 None

M9184C1023 N/A 30 2 N/A Cleaver Brooks

M9184C1031 N/A 30 2 N/A With tapped shaft

M9184C1049 N/A 30 2 N/A Cleaver Brooks

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

62 63-2691—01

M9184D1005 N/A 15/30 N/A

M9184D1013 M9184D1021 30/60 none TRADELINE

M9184D1021 N/A 30/60 N/A TRADELINE, with tapped shaft

M9184D1039 M9184D1021 220741A2-90 15/30 M9184D1005 Japan; replacement requires 220741A

M9184D1047 M9184D1021 15/30 M9184D1005

M9184D1054 M9194D1003 120/240 None

M9184D1062 M9184D1021 30/60 M9184D1021

M9184D4009 N/A 30/60 N/A Canada, TRADELINE

M9184E4006 N/A 220736A 30/60 1 None Canada, TRADELINE, tapped shaft

M9184F1000 M9184F1034 30/60 2 None

M9184F1018 M9184D1021 220736B 30/60 2 M9184F1034 With tapped shaft

M9184F1026 M9184D1021 220736B 220741A2-90 30/60 2 M9184F1034 Requires 220741A

M9184F1034 N/A 220736B 30/60 2 N/A With tapped shaft

M9185A1000 M9185D1004 60 M9185A1018

M9185A1018 N/A 60 N/A

M9185A1026 M9185A1018 30 None

M9185A1034 M9185D1004 60 M9185A1018

M9185A1042 M9185D1004 50017460-003 30 M9185A1026 Requires 50017460-003

M9185A1059 M9185D1004 30 None Lennox

M9185A1067 M9185D1004 30 None York

M9185A1075 N/A 220741A 60 N/A Requires 220741A

M9185A1083 M9185D1004 60 M9185A1018

M9185A1091 M9185D1004 30 M9185A1018 Less junction box

M9185B1008 M9185D1004 50017460-003 220736A 30 1 None

M9185C1006 N/A 220736B 60 2 N/A

M9185C1014 M9185D1004 220736B 60 2 None

M9185C1022 M9185D1004 220736B 60 2 None

M9185D1004 N/A 30/60 N/A TRADELINE

M9185D1012 M9185D1004 30/60 M9185D1004

M9185D4008 N/A 30/60 N/A Canada, TRADELINE

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

63 63-2691—01

M9185E1001 M9185D1004 220736A 30/60 1 M9185E1019

M9185E1019 N/A 30/60 1 N/A

M9185E4005 N/A 220736A 30/60 1 N/A Canada, TRADELINE, tapped shaft

M9185F1009 None 30/60 2 None Carrier (W957G1006)

M9185W1017 M9185D1004 50017460-003 220736A Q209E1010 30 1 None Trane, with Q209E

M9186G1006 M9185A1018 60 None Use auxiliary shaft

M9186G1014 M9185D1004 220741A2-90 60 M9185A1018 Japan, use auxiliary shaft

M9186G4000 M9185E4005 60 None Canada, use auxiliary shaft

M9191D1006 M9194D1003 120/240 M9194D1003

M9191F1001 N/A 220736B 120/240 2 N/A

M9194C1005 N/A 60 2 N/A

M9194D1003 N/A 120/240 N/A TRADELINE

M9194D4007 M9194D1003 120/240 None Canada, TRADELINE

M9194E1000 N/A 120/240 1 N/A

M9481D1005 M9484F1007 30/60 M9484D1010

M9481E1002 M9484F1007 30/60 1 M9484E1017

M9481F1000 M9484F1007 30/60 2 None

M9484D1002 None 15/30 M9484D1010

M9484D1010 N/A 30/60 N/A With tapped shaft

M9484D1028 none 30/60 M9484D1010

M9484D1036 None 15/30 M9484E1009

M9484D1044 None 30/60 M9484D1010 With tapped shaft

M9484D1051 None 30/60 M9484D1010

M9484D4006 N/A 30/60 N/A Canada, tapped shaft, 220741A

M9484E1009 N/A 15/30 1 N/A With tapped shaft

M9484E1017 N/A 30/60 1 N/A

M9484E1025 None 30/60 1 M9484E1033

M9484E1033 N/A 30/60 1 N/A

M9484E1041 None 30/60 1 M9484E1033 With 221455A

M9484E1058 None 30/60 1 M9484E1033

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

64 63-2691—01

M9484E1066 None 30/60 1 M9484E1033

M9484E1074 None 30/60 1 M9484E1033

M9484E1082 None 30/60 1 M9484E1017 With tapped shaft

M9484E1090 None 30/60 1 M9484E1017

M9484E1116 None 15/30 1 M9484E1009

M9484E4003 N/A 30/60 1 N/A Canada, tapped shaft, 220741A

M9484F1007 N/A 30/60 2 N/A

M9484F1015 None 30/60 2 M9484F1007

M9484F1023 N/A 15/30 2 N/A With tapped shaft

M9484F1031 N/A 30/60 2 N/A

M9484F1049 N/A 30/60 2 N/A

M9484F1056 None 15/30 2 M9484F1023 With tapped shaft

M9484F1064 None 30/60 2 M9484F1031

M9484F1072 None 30/60 2 M9484F1007

M9484F4001 N/A 30/60 2 N/A Canada, tapped shaft, 220741A

M9484F4019 N/A 15/30 2 N/A

M9491D1003 None 60/120 M9494D1000

M9494D1000 N/A 60/120 N/A

Table 4. Modutrol IV Cross Reference to Modutrol IV.

OS # to be

Replaced

Modutrol IV TRADELINE Replacement Specifications

Functional Replacement TRADELINE CommentsModel Number Required

Transformer

Required

Aux.

Switch Required

Accessories Timing

(sec) Aux Sw

MODUTROL IV™ MOTOR CROSS REFERENCE

65 63-2691—01

MODUTROL IV ACCESSORIES

This section cross-references accessory parts for all Modutrol Motors. It provides

detailed data about accessories. See the Application Notes section for details.

Cross Reference Format

Information contained in individual rows refers to the motor listed in the Accessory Part

Number column unless otherwise noted. Following is an example of the format used in

this section and explanations of each column.

1. The part number of the accessory to be replaced.

2. Accessory name and basic function.

3. Original use of or applications for the device.

4. Whether or not the original accessory works with a Modutrol III Motor.

5. Whether or not the original accessory works with a Modutrol IV Motor.

6. The Modutrol IV equivalent for use with Mod IV Motors.

NOTE: Not all Modutrol IV equivalents work with pre-Modutrol IV Motors. Cross-

check the selected part to ensure proper operation in your application.

7. Additional information to consider when replacing an accessory. This column

indicates special handling that is required. Consider differences carefully.

Accessory

Part

Number For Use With Description

Works

with Mod Mod IV

Equivalent CommentsIII IV

12 34567

Table 5. Modutrol Motor Accessory Cross Reference.

Accessory Part Number Description Mod IV Equivalent Comments

27518 Ball Joint N/A

101662A Bracket, external damper mount 101662A

104643A Crank Arm Adapter 104643A Requires 220738A for Mod III to Mod IV

112894FB Remote Manual Potentiometer, 270 ohm 112894FA

112894FD Remote Manual Potentiometer, 135 ohm 112894FD

112894FE Remote Manual Potentiometer, 270 ohm, with wallplate 112894FE

112894GB Remote Manual Potentiometer, 72 ohm 112894FE

198162AA Internal Transformer, 120/208/240 Vac, 50/60 Hz 50017460-001

198162EA Internal Transformer, 120 Vac, 50/60 Hz 50017460-003

198162GA Internal Transformer, 220 Vac, 50/60 Hz 50017460-001

198162JA Internal Transformer, 24 Vac, 50/60 Hz, Isolation 50017460-001

220736A Auxiliary Switch Kit, 1 Switch 220736A

220736B Auxiliary Switch Kit, 2 Switches 220736B

203977A Economizer Adapter Kit 203977A

220738A Adapter Bracket 220738A

MODUTROL IV™ MOTOR CROSS REFERENCE

66 63-2691—01

220741A Screw Terminal Adapter 220741A2-XX order by Mod Motor series number

221455A Infinitely Adjustable Crank Arm 221455A

221508A Resistor Board 221508A2

34343A Connecting Rod Q5001D1000

4074BYK Resistor Kit - Series 90 221508A2

4074EAU Resistor Kit - W973 221508A2

4074EDC Resistor Kit - 4 to 20 mA 221508A2

4074EED Resistor Kit - 4 to 20 mA 221508A2

4074ELR Heavy Duty Crank Arm 4074ELR Requires 220738A for Mod IV

4074ELY Infinitely Adjustable Crank Arm 221455A

4074ERU Weatherproof Kit 4074ERU

4074EQE Heavy Duty Crank Arm 4074EQE

None Economizer Weatherproof Kit None

7616BR Adjustable Crank Arm 7617ADW Requires 220738A for Mod IV

7617ADW Adjustable Crank Arm 7617ADW

7617DM Coupling 7617DM

None Bracket, DR/ZR valve to Mod Motor None

ES-650-117 Explosion Proof Housing EGS Enclosures ES-650-117 Requires 220738A for Mod IV

ES-650-118 Explosion Proof Housing EGS Enclosures ES-650-118

None Valve Linkage None

Q100A1015 Valve Linkage Q100A1015

Q100A1023 Valve Linkage Q100A1023

Q181A1007 Auxiliary Potentiometer (1 Potentiometer) Q181A1007

Q181A1015 Auxiliary Potentiometer (2 Potentiometer) Q181A1015

Q181A1064 Auxiliary Potentiometer (3 Potentiometer) Q181A1064

Q181A1072 Auxiliary Potentiometer (4 Potentiometer) Q181A1072

Q209E1002 Cover Mounted Minimum Position Pot 135 ohm Q209E1002

Q209E1010 Cover Mounted Minimum Position Pot 270 ohm Q209E1010

Q209F1001 Internal Minimum Position Pot 135 ohm Q209F1001

Q209F1019 Internal Minimum Position Pot 270 ohm Q209F1019

Q5001A1006 V5011, V5013 Valves Q5001A1006

Q5001A1014 V5011, V5013 Valves Q5001A1014

Table 5. Modutrol Motor Accessory Cross Reference.

Accessory Part Number Description Mod IV Equivalent Comments

MODUTROL IV™ MOTOR CROSS REFERENCE

67 63-2691—01

None V5011, V5013 Valves None

None V5011, V5013 Valves None

None V5011, V5013 Valves non

Q5001D1000 V5011, V5013 Valves Q5001D1000

Q5001D1018 V5011, V5013 Valves Q5001D1018

Q5001D1026 V5011, V5013 Valves Q5001D1026

None Series 90 Motors None

None Series 90 Motors None

None Series 90 Motors None

Q7130A1006 Series 90 Motors Q7130A1006

Q7230A1005 Series 90 Motors Q7230A1005

Q7330A1004 Series 90 Motors Q7330A1004

Q7630A1001 Series 90 Motors Q7630A1001

S443A1007 Remote mount Series 90 motor manual control S443A1007

S963B1128 Series 90 Motors S963B1128

S963B1136 Series 90 Motors S963B1136

W859 Series 90 Mod III W859 Requires 220738A for Mod IV

W859 Series 90 Mod IV W859

Table 5. Modutrol Motor Accessory Cross Reference.

Accessory Part Number Description Mod IV Equivalent Comments

MODUTROL IV™ MOTOR CROSS REFERENCE

68 63-2691—01

63-2691—01

Automation and Control Solutions

Honeywell International Inc. Honeywell Limited-Honeywell Limitée

1985 Douglas Drive North 35 Dynamic Drive

Golden Valley, MN 55422 Toronto, Ontario M1V 4Z9

customer.honeywell.com

® U.S. Registered Trademark

© 2009 Honeywell International Inc.

63-2691—01 M.S. 07-09

%\XVLQJWKLV+RQH\ZHOOOLWHUDWXUH\RXDJUHHWKDW+RQH\ZHOOZLOOKDYHQROLDELOLW\IRUDQ\GDPDJHVDULVLQJRXWRI\RXUXVHRUPRGLILFDWLRQ

WRWKHOLWHUDWXUH<RXZLOOGHIHQGDQGLQGHPQLI\+RQH\ZHOOLWVDIILOLDWHVDQGVXEVLGLDULHVIURPDQGDJDLQVWDQ\OLDELOLW\FRVWRUGDPDJHV

LQFOXGLQJDWWRUQH\V¶IHHVDULVLQJRXWRIRUUHVXOWLQJIURPDQ\PRGLILFDWLRQWRWKHOLWHUDWXUHE\\RX
