MAY 2015
CALL US TOLL FREE AT 888.243.9445
HOURS 6AM-7PM CENTRAL
FAX 262.504.5409
PARA ESPAÑOL 888.243.9339
FREE SHIPPING
ON ORDERS OVER $500
LED CANOPY LIGHTS
STARTING AT $69.99
BACK IN STOCK!
PAGES 16 - 17 PAGE 18 PAGES 18 - 19 PAGES 18 - 19
New for May
LED 5" & 6" Surface Mount
Downlight
See page 32
LED 4" Surface Mount
Downlight
See page 32
LED Tube
See page 37
LED Linear High Bay
See page 37
Cut Your
Energy Cost In Half
with LED!
NEW LED
BOLLARD
MORE LIGHT,
LOWER PRICE
PAGE 20
Only
$349.99!
2Free Shipping on Orders Over $500
Heat-dissipating fins keep LEDs
running cool
High-output arrays
provide and estimated 50,000
hours of maintenance-free
operation
The glass is thermal, shock and
impact resistant, keeping the LEDs
and optics safe
Put light where you need it with the
included adjustable fitter
40° Flood
Perfect for general
illumination applications
like parking lots and signs.
20° Spot
Use when you need a precise,
focused beam of light like
accenting architecture.
Die-Cast Aluminum Housing
LED Arrays
Tempered Glass Lens
Maximum Adjustability
Premium LED Floodlight – Large
Cool White, 5700K, 40° Flood
Up To 60%
Brighter!
Choose from two high-quality optics
LED FLOODLIGHTS
3
www.e-conolight.com 888.243.9445
COLOR TEMP Cool White (5000K) Neutral White (4000K)
WATTAGE 72W LED 72W LED
LUMENS 6150 6150
CRI 70 70
COMPARABLE TO 150W PSMH 150W PSMH
CAT.# 40
°
FLOOD E-HL5F06C2Z E-HL5F06N2Z
CAT.# 20
°
SPOT E-HL5S06C2Z E-HL5S06N2Z
PRICE $149.90 $149.90
COLOR TEMP Cool White (5000K) Neutral White (4000K)
WATTAGE 144W LED 144W LED
LUMENS 11,500 11,500
CRI 70 70
COMPARABLE TO 400W MH 400W MH
CAT.# 40
°
FLOOD E-HL6F11CSZ E-HL6F11NSZ
CAT.# 20
°
SPOT E-HL6S11CSZ E-HL6S11NSZ
PRICE $289.90 $289.90
Premium LED
Floodlight
Applications: Building facades, displays, uplighting and
signs - also effective as security lighting,
for storage areas and commercial sites
Typical Mounting Height: 8 to 20 feet (Small)
12 to 25 feet (Large)
Dimensions: 17"H x 15-7/8"W x 6-3/4"D
(Height dimension includes fitter)
Weight: 19.5 lbs.
Dimensions: 12-1/4"H x 10-3/4"W x 6"D
(Height dimension includes fitter)
Weight: 8.4 lbs.
Large
Small
COLOR TEMP Cool White (5700K) Neutral White (4100K)
WATTAGE 152W LED 152W LED
LUMENS 7600 7000
CRI 73 82
COMPARABLE TO 250W MH 250W MH
CAT.# 40
°
FLOOD E-HL4F11CSZ E-HL4F11NSZ
WAS $264.90 $264.90
PRICE $189.99 $189.99
Features:
• Estimated 50,000 hours of maintenance-free
operation to L70 at 25° C
• Non-dimmable
• Low-copper, die-cast aluminum housing and
lens frame
• Dark bronze polyester powder-coat finish
• Tempered glass lens, thermal, shock and
impact resistant
• Minimum starting temperature: -30°C (-22°F)
• Small Floodlight includes 1/2" adjustable
NPS fitter
• Large Floodlight includes 2"
adjustable fitter
• Universal voltage (120V through 277V)
• UL Listed for wet locations
• Cree® LEDs inside
• 5-year limited warranty
CAT.# E-ACP1 (120 volts)
$690
CAT.# E-ACP2 (208/240/277 volts)
$690
Photocell is field installed,
for use 2" adjustable
slip fitter only
Accessories: (For Large only)
LED FLOODLIGHTS
Price Drop!
While
Supplies
Last
4Free Shipping on Orders Over $500
LED Small Floodlight
LED Compact Floodlight
Applications: Security, building facades, displays, signs
and other residential uses
Typical Mounting Height: 8 to 15 feet
Applications: Security, building facades, displays, signs
and other residential uses
Typical Mounting Height: 8 to 15 feet
Dimensions: 6"H x 7-3/4"W x 4-3/4"D
Weight: 3.0 lbs.
Dimensions: 4"H x 4"W x 4-5/8"D
Weight: 0.8 lbs.
Finish: Textured black or smooth white polyester powder-coat
Dimensions: 4-3/4"H x 6-1/8"W x 4-3/4"D
Weight: 2.0 lbs.
Finish: Dark Bronze or White polyester powder-coat
COLOR TEMP Neutral White (4000K) Neutral White (4000K)
WATTAGE 9W LED 9W LED
LUMENS 700 700
CRI 80 80
COMPARABLE TO 50W Halogen 50W Halogen
CAT.# E-GL3L09N2K
(Black)
E-GL3L09N2W
(White)
PRICE $34.99 $34.99
COLOR TEMP Neutral White (4000K) Neutral White (4000K)
WATTAGE 21W LED 21W LED
LUMENS 1600 1600
CRI 80 80
COMPARABLE TO 50W PSMH 50W PSMH
CAT.# E-CF2L21N2Z
(Dark Bronze)
E-CF2L21N2W
(White)
PRICE $64.99 $64.99
COLOR TEMP Cool White (5000K) Neutral White (4000K)
WATTAGE 30W LED 30W LED
LUMENS 3000 3000
CRI 70 70
COMPARABLE TO 100W PSMH 100W PSMH
CAT.# Dk. Bronze E-CF3L03C2Z E-CF3L03N2Z
CAT.# White E-CF3L03C2W E-CF3L03N2W
PRICE $99.99 $99.99
Features:
• Estimated 50,000 hours of maintenance-free
operation
• Non-dimmable
• Low-copper, die-cast aluminum housing and
lens frame
• Tempered glass lens, thermal shock and
impact resistant
• 1/2" NPS aluminum die-cast swivel fitter
attaches to standard J-box
• Universal voltage (120V through 277V)
• Minimum starting temperature: -30°C (-22°F)
• UL Listed for wet locations
• Cree® LEDs inside
• 5-year limited warranty
Features:
• Estimated 76,000+ hours of maintenance-
free operation to L70 at 25°C
• Non-dimmable
• Durable die-cast aluminum housing
• Polyester powder coat white or dark-bronze
finish for extra corrosion protection
• Tempered glass lens, thermal shock and
impact resistant
• Minimum starting temperature: -40°F
• Universal voltage (120V-277V)
• 1/2-inch NPS die-cast swivel fitter included
• UL Listed for wet locations
• Cree® LEDs inside
• 5-year limited warranty
LED FLOODLIGHTS
5
www.e-conolight.com 888.243.9445
Features:
• Estimated 50,000 hours of maintenance-
free operation to L70 at 25°C
• Non-dimmable
• Low-copper, die-cast aluminum housing
and lens frame
• Polyester powder-coat finish
(textured black or smooth white)
• Tempered glass lens, thermal, shock and
impact resistant
• Minimum starting temperature: -30°C
(-22°F)
• 1/2" NPS adjustable fitter included
• Universal voltage (120V through 277V)
• Cree® LEDs inside
• UL Listed for wet locations
• 5-year limited warranty
Premium LED
Directional Floodlight
Applications: For accenting architecture or lighting
landscape areas
Typical Mounting Height: 8 to 15 feet
Dimensions: 8-1/2"H x 6-1/4"W x 7-3/4"D
(Height dimension includes fitter)
Weight: 5.8 lbs.
COLOR TEMP Cool White (5000K) Neutral White (4000K)
WATTAGE 36W LED 36W LED
LUMENS 2800 2800
CRI 70 70
COMPARABLE TO 100W PSMH 100W PSMH
CAT.# 40
°
FLOOD E-GL4F03C2K (Black) E-GL4F03N2K (Black)
CAT.# 40
°
FLOOD E-GL4F03C2W (White) E-GL4F03N2W (White)
CAT.# 20
°
SPOT E-GL4S03C2K (Black) E-GL4S03N2K (Black)
CAT.# 20
°
SPOT E-GL4S03C2W (White) E-GL4S03N2W (White)
PRICE $99.90 $99.90
Premium LED Directional Floodlight
Cool White, 5000K, 40° Flood
LED FLOODLIGHTS
6Free Shipping on Orders Over $500
LED AREA LIGHT
The time to upgrade parking &
roadway lighting is now
There has never been a better time to upgrade parking lot and roadway
lighting to LED now that e-conolight offers a true LED area light. This fixture
delivers over 10,000 lumens but uses only 155 watts and is designed to last for
up to 76,000 hours of virtually maintenance-free operation. Available in either
neutral or cool white color temperatures, the LED area light is comparable to
250-watt PSMH but uses about half of the energy. A 6-inch direct mount arm,
2-inch adjustable slip fitter or an adjustable U-bracket provides flexible
mounting options.
COLOR TEMP Cool White (5000K) Neutral White (4000K)
WATTAGE 155W LED 155W LED
LUMENS 11,872 10,881
CRI ≥ 70 ≥ 70
COMPARABLE TO 250W PSMH 250W PSMH
CAT.# E-AL1L315CZ E-AL1L315NZ
PRICE $224.99 $224.99
Features:
• Estimated 76,000 hours of maintenance-free
operation to L70
• Non-dimmable
• Low-copper, durable die-cast aluminum
housing
• Dark bronze polyester powder-coat finish for
extra corrosion protection
• Fixed cutoff glare shield reduces light
pollution
• Tempered glass lens, thermal shock,
and impact resistant
• Custom-made lens design delivers
IES Type III distribution
• Minimum starting temperature: -30°C (-22°F)
• Universal voltage (120V through 277V)
• UL listed for wet locations at 0° tilt only
• For use in 0° orientation (downlight position)
only
• Cree® LEDs inside
• 5-year limited warranty
Mounting Options:
Use only when mounting E-AL (shown above)
CAT.# E-ACE
6" mounting arm,
for pole mounting
$1190
CAT.# E-ACU
Adjustable U-bracket
for wall mounting
2-1/2"H x5-1/2"W x 6"L
$690
CAT.# E-ACS
2" slip fitter for pole
or wall mounting
$1190
CAT.# E-ACP1 (120 volts)
$690
CAT.# E-ACP2 (208/240/277 volts)
$690
Photocell is field installed,
for use 2" adjustable
slip fitter only
Accessories:
For use in 0°
orientation
(downlight position)
only
LED Area Light
Applications: Parking lots, roadways, walkways & general
area lighting - also effective as a
wall-mounted security and perimeter light
Typical Mounting Height: 15 to 25 feet
Typical Spacing: 3 to 5 times the mounting height
Dimensions: 4-7/8"H x13-7/8"W x 17-1/4"L
Weight: 16.0 lbs.
*Fixture comes without mounting, ordered separately
Now DLC
Listed!
7
www.e-conolight.com 888.243.9445
LED DUSK TO DAWN
LED Dusk to Dawn - Large
Cool White, 6650 Lumens
"Anybody that was on the fence about switching
to LED, this is the light for you."
– E-conolight customer Mark Maurer
LED Dusk To Dawn
Applications: Ideal for general security lighting for yards,
parking lots, service roads and building
perimeters
Typical Mounting Height: 12 to 30 feet
Dimensions: 15-1/2"H x 9"W x 23"L
(Dimensions include mounting arm)
Weight: 6.4 lbs.
Dimensions: 13"H x 7-1/2"W x 20"L
(Dimensions include mounting arm)
Weight: 4.5 lbs.
Large
Small
Now available in two sizes!
You now have greater flexibility when choosing the right security light.
Replace your up to 175 watt mercury vapor fixtures with brighter light and
bigger energy cost savings with the new, large LED dusk to dawn security
light fixture. Experience superior light output, over 70,000 hours of virtually
maintenance-free and hands-free operation with the twist-lock photocell and
the comfort of a 5-year limited warranty.
Small Large
COLOR TEMP Cool White (5000K) Cool White (5000K)
WATTAGE 36W LED 68W LED
LUMENS 3550 6650
CRI ≥ 70 ≥ 70
COMPARABLE TO 100W PSMH 150W PSMH / 175MV
CAT.# E-DD1L36C1 E-DD1L68C1
PRICE $109.90 $169.99
Features:
• Estimated 76,000 hours of maintenance-free
operation to L70 at 25°C
• Non-dimmable
• Durable die-cast aluminum housing
• Grey polyester powder-coat finish for extra
corrosion protection
• Mount directly or with included
mounting arm
• Mounting arm diameter: 1-11/16"
• 120V Operation
• Twist-lock photocell included
• Minimum starting temperature: -30°C (-22°F)
• Cree® LEDs inside
• UL Listed for wet locations
• 5-year limited warranty
8Free Shipping on Orders Over $500
LED Slim Wall Pack/
Flood
Applications: As a wall pack, use for security, pathway,
and perimeter lighting: ideal for entryways,
walkways, and other applications where
control of spill light is important. With
adjustable mounting accessories, use
as a flood for building facades, displays,
up-lighting, and signs. Also effective for
storage areas and commercial sites.
Typical Mounting Height: 8 to 20 feet (Small)
8 to 25 feet (Large)
Typical Spacing: 1 to 2 times the mounting height
COLOR TEMP Cool White
(5000K) Neutral White
(4000K) Cool White
(5000K) Neutral White
(4000K)
WATTAGE 40W LED 40W LED 60W LED 60W LED
LUMENS 3917 3917 5135 5135
CRI ≥ 70 ≥ 70 ≥ 70 ≥ 70
COMPARABLE TO 100W PSMH 100W PSMH 175W MH 175W MH
CAT.# E-WF1L04CZ E-WF1L04NZ E-WF1L06CZ E-WF1L06NZ
PRICE $139.99 $139.99 $219.99 $219.99
COLOR TEMP Cool White
(5000K) Neutral White
(4000K) Cool White
(5000K) Neutral White
(4000K)
WATTAGE 80W LED 80W LED 150W LED 150W LED
LUMENS 8110 8110 15,790 15,790
CRI ≥ 70 ≥ 70 ≥ 70 ≥ 70
COMPARABLE TO 250W MH 250W MH 400W MH 400W MH
CAT.# E-WF2L08CZ E-WF2L08NZ E-WF2L15CZ E-WF2L15NZ
PRICE $249.99 $249.99 $349.99 $349.99
A Versatile Wall Pack & Floodlight
Architectural uniformity across diverse applications is now a reality with
E-conolight’s new series of Wall Packs that can also be utilized as flood lights.
The six mounting accessories (sold separately) convert these wall packs to
flood lights enabling highly versatile installations and applications.
Features:
• Estimated 133,000 (40W,60W and 150W)
hours, 50,000 (80W) hours to L70 at 25°C
(77°F)
• -40°C (-40°F) minimum starting temperature
• Non-dimmable electronic driver
• 120V-277V operation
• Solid construction, die-cast aluminum
housing
• Dark bronze polyester powder-coat finish for
extra corrosion protection and long-lasting
color
• Tempered glass lens: thermal, shock and
impact resistant
• Included mounting plate mounts over 4"
square or 4" octagonal junction box
• Cree® LEDs inside
• UL Listed for wet locations
• 5-year limited warranty
LED WALL PACKS
Small (40/60-Watt)
Large (80/150-Watt)
Dimensions: 2.8"L x 7.5"W x 8.0"H
Weight: 3.6 lbs.
Dimensions: 4.9"L x 14.2"W x 12.8"H
Weight: 11.2 lbs. (80-Watt)
12.2 lbs. (150-Watt)
CAT.# E-ACSBWFZ
Surface Mounting Box
(Large & Small) - For use where there
is no existing junction box or for
easy through-wiring
$1199
CAT.# E-ACSWF1Z
2" Adjustable Slip Fitter (Small) -
Fits over 2-3/8" O.D. pipe
$2499
CAT.# E-ACSWF2Z
2" Adjustable Slip Fitter (Large) -
Fits over 2-3/8" O.D. pipe
$2999
CAT.# E-ACUWF2Z
Adjustable U-Bracket (Large) -
Comes with 24" cord
$1999
CAT.# E-ACUWF1Z
Adjustable U-Bracket (Small) -
Comes with 24" cord
$1499
CAT.# E-ACWF1/2Z
1/2" NPS Swivel Fitter (Small)
$1999
Accessories Use only when mounting E-WF1L & E-WF2L (shown above)
NEW!
9
www.e-conolight.com 888.243.9445
LED Traditional Style
Wall Pack
Applications: Security, pathway and perimeter lighting -
also ideal for entryways and walkways
Typical Mounting Height: 8 to 18 feet (Small)
12 to 20 feet (Large)
Typical Spacing: 2 to 3 times the mounting height
Small
Dimensions: 9-3/4"H x 18"W x 9-3/8"D
Weight: 15.8 lbs.
Dimensions: 9-1/4"H x 14-1/8"W x 7-1/2"D
Weight: 8.6 lbs.
COLOR TEMP Cool White (5000K) Neutral White (4000K)
WATTAGE 96W LED 96W LED
LUMENS 6300 5600
CRI 70+ 70+
COMPARABLE TO 175W MH 175W MH
CAT.# E-WP9L09CZ E-WP9L09NZ
PRICE $184.99 $184.99
COLOR TEMP Cool White (5000K) Neutral White (4000K)
WATTAGE 47W LED 47W LED
LUMENS 3200 2900
CRI 70+ 70+
COMPARABLE TO 100W PSMH 100W PSMH
CAT.# E-WP8L05CZ E-WP8L05NZ
PRICE $99.99 $99.99
The look you want now in LED
Now is the time to replace your HID wall pack with LED.
We’ve combined traditional design and familiar installation
with advanced LED technology to deliver this new wall pack.
This LED wall pack is comparable up to a 175W metal halide
fixture but only uses 45 percent of the energy.
Large
Features:
• Non-dimmable
• Estimated 76,000 hours of maintenance-
free operation to L70 at 25°C
• Universal voltage (120V through 277V)
• Heavy duty, die-cast aluminum housing
with hinged door frame
• Dark-bronze polyester powder-coat finish
• Heat- & shock-resistant borosilicate glass
prismatic lens
• Minimum starting temperature:
-30°C (-22°F)
• For E-WP8 (Small): 1/2" NPT tapped
knockouts for conduit entrances
(one on top, one on each side, one on back)
• For E-WP9 (Large): 1/2" NPT tapped
knockouts for conduit entrances
(one on top, one on each side, two on back)
• Optional photocell available
• RoHS compliant
• UL listed for wet locations
• Cree® LEDs inside
• 5-year limited warranty
CAT.# E-ACP1 (120 volts)
$690
CAT.# E-ACP2 (208/240/277 volts)
$690
Photocell is field installed.
Drilling of the back box in the
field is required.
Accessories:
LED WALL PACKS
NEW!
10 Free Shipping on Orders Over $500
Premium LED Wall Pack – Small
Neutral White
LED WALL PACKS
Features:
• Estimated 50,000 hours of maintenance-
free operation to L70 at 25°C
• Non-dimmable
• Low-copper, die-cast aluminum housing
and lens frame
• Dark bronze polyester powder-coat finish
• Fixed cutoff glare shield to reduce light
pollution
• Tempered glass lens, thermal, shock and
impact resistant
• Minimum starting temperature: -30°C
(-22°F)
• Patented lens design delivers true IES Type
III distribution
• Mounts over recessed Junction box or with
conduit
• Die-cast detachable back box for easy
mounting
• 75°C minimum supply wire required
• Universal voltage (120V through 277V)
• Cree® LEDs inside
• UL Listed for wet locations–downlight only
• 5-year limited warranty
CAT.# E-ACP1 (120 volts)
$690
CAT.# E-ACP2 (208/240/277 volts)
$690
Photocell is field installed.
Drilling of the back box in the
field is required.
Accessories:
COLOR TEMP Cool White (5700K) Cool White (5000K) Neutral White (4000K)
WATTAGE 76W LED 72W LED 72W LED
LUMENS 3800 6000 6000
CRI 73 70 82
COMPARABLE TO 100W PSMH 175W MH 175W MH
CAT.# E-WP4L06CZ E-WP7L06CZ E-WP7L06NZ
WAS $194.90 – –
PRICE $129.99 $199.90 $199.90
Premium LED
Wall Pack
Applications: Security, pathway and perimeter lighting;
ideal for entryways, walkways and other
applications where control of spill light is
important
Typical Mounting Height: 8 to 20 feet
Typical Spacing: 1 to 2 times the mounting height
Large
Dimensions: 5-3/4"H x 13"W x 11-3/4"D
Weight: 13.6 lbs.
Price Drop!
While Supplies
Last
"We have installed these lights for 2
customers and they are very pleased with
the light output and lower electric bills."
– E-conolight customer
11
www.e-conolight.com 888.243.9445
COLOR TEMP Cool White (5000K) Neutral White (4000K)
WATTAGE 36W LED 36W LED
LUMENS 3350 3350
CRI 70 70
COMPARABLE TO 100W PSMH 100W PSMH
CAT.# E-WP6L03CZ E-WP6L03NZ
PRICE $119.90 $119.90
LED WALL PACKS
Features:
• Estimated 50,000 hours of maintenance-
free operation to L70 at 25°C
• Non-dimmable
• Low-copper, die-cast aluminum housing
and lens frame
• Dark bronze polyester powder-coat finish
• Fixed cutoff glare shield to reduce light
pollution
• Tempered glass lens, thermal, shock and
impact resistant
• Minimum starting temperature: -30°C
(-22°F)
• Patented lens design delivers true IES Type
III distribution
• Mounts over recessed Junction box or with
conduit
• Die-cast detachable back box for easy
mounting
• 75°C minimum supply wire required
• Universal voltage (120V through 277V)
• Cree® LEDs inside
• UL Listed for wet locations–downlight only
• 5-year limited warranty
CAT.# E-ACP1 (120 volts)
$690
CAT.# E-ACP2 (208/240/277 volts)
$690
Photocell is field installed.
Drilling of the back box in the
field is required.
Accessories:
COLOR TEMP Neutral White (4000K)
WATTAGE 27W LED
LUMENS 1300
CRI 80
COMPARABLE TO 100W Incandescent
CAT.# E-WP1X031Z7
PRICE $64.90
• Estimated 25,000 hours of maintenance-free
operation
• 120-volt operation
• Non-dimmable
• Sturdy die-cast aluminum housing and lens
frame, with dark-bronze polyester powder-coat
finish
• Minimum starting temperature: -40°C (-40°F)
• UV stabilized prismatic polycarbonate refractor
• One-piece anodized aluminum reflector
• 1/2-inch NPT tapped back and two sides for
conduit entrances
• Optional photocell available
• Cree® LEDs inside
• UL Listed for wet locations
• 5-year limited warranty
Features:
LED Wall Pack
Applications: Security, pathway and perimeter lighting;
ideal for entryways, walkways and parking
facilities
Typical Mounting Height: 8 to 15 feet
Typical Spacing: 1-2 times the mounting height
Dimensions: 7-1/4"H x 8-1/2"W x 7-1/4"D
Weight: 3.0 lbs.
CAT.# E-ACP1 (120 volts)
$690
Photocell is field installed.
Drilling of the housing in the
field is required.
Accessories:
Dimensions: 4-1/2"H x 8-3/4"W x 9-1/2"D
Weight: 7.0 lbs.
Small
Premium LED
Wall Pack
Applications: Security, pathway and perimeter lighting;
ideal for entryways, walkways and other
applications where control of spill light is
important
Typical Mounting Height: 8 to 15 feet
Typical Spacing: 1 to 2 times the mounting height
Free Shipping on Orders Over $500
12 Free Shipping on Orders Over $500
LED WALL MOUNTS
LED Wall Mount
Applications: Security, entryways, stairways, storage and
perimeter areas, as well as residential
exteriors
Typical Mounting Height: 8 to 18 feet
Typical Spacing: 1.5 to 2 times the mounting height
Dimensions: 9"H x 5-3/4"W x 4"D
Weight: 2.0 lbs.
COLOR TEMP Neutral White
(4000K) Neutral White
(4000K)
WATTAGE 14W LED 22W LED
LUMENS 1000 1200
CRI 70+ 70+
COMPARABLE TO 100W Incandescent 120W Incandescent
CAT.# BRONZE E-WW1L11NMP E-WW1L21NMP
PRICE $59.99 $64.99
CAT.# WHITE E-WW1L11NWP E-WW1L21NWP
PRICE $59.99 $64.99
Applications: Security, entryways, stairways, storage and
perimeter areas, as well as residential
exteriors
Typical Mounting Height: 8 to 18 feet
Typical Spacing: 1.5 to 2 times the mounting height
Dimensions: 5.9"H x 5.4"W x 7.3"L
Weight: 2.3 lbs.
LED Architectural
Wall Mount
COLOR TEMP Cool White (5000K)
WATTAGE 14W LED
LUMENS 1100
CRI ≥ 70
COMPARABLE TO 100W Incandescent
CAT.# E-WA1L11CMP
PRICE $79.99
Long-lasting, durable & stylish
The new LED architectural wall mount delivers long-lasting bright light in a
durable housing that is both sleek and stylish. Light output is an impressive
1100 lumens at just 14 watts. The expected lifetime of 154,000 hours of
virtually maintenance-free operation means this fixture is built for big energy
cost savings that continue to add up over time. Installation is also a snap with
a mounting plate that fits over a 4" square or octagonal junction box.
• Estimated 154,000 hours of maintenance-free
operation to L70
• Non-dimmable
• Durable die-cast aluminum housing
• Medium bronze polyester powder-coat finish for
extra corrosion protection
• Anti-glare, heavy-duty frosted polycarbonate lens
• 120V operation with built-in photocell
• Mounts directly to recessed junction
box with included mounting plate
• Minimum starting temperature: -30°C
(-22°F)
• UL listed for wet locations
• Cree® LEDs inside
• 3-year limited warranty
Features:
• Estimated 50,000 hours of maintenance-free
operation to L70 at 25°C
• 120V operation with built-in photocell
• Non-dimmable
• Polycarbonate housing in medium bronze or white
with heavy-duty aluminum mounting plate
• 1/2" NPT tapped back and bottom for conduit
entrances
• Minimum starting temperature: -40°C (-40°F)
• UV-stabilized polycarbonate prismatic
refractor
• RoHS compliant
• UL listed for wet locations
• Cree® LEDs inside
• 5-year limited warranty
Features:
NEW!
www.e-conolight.com 888.243.9445 13
www.e-conolight.com 888.243.9445
LED WALL MOUNTS
• 120V operation
• Non-dimmable
• Designed to last 50,000 hours to L70 at 25°C
(77°F)
• -40°C (-40°F) minimum starting temperature
• Die-cast aluminum housing
• Polyester powder-coat finish for extra corrosion
protection and long-lasting color
• Available in dark bronze or white finishes
• Screw-in polycarbonate lens
• Bracket with threaded nipple mounts to
standard 3" or 4" octagonal j-box
• Built in photocell allows for fixture automation
• Cree® LEDs inside
• UL Listed
• Suitable for wet locations
• 5-year limited warranty
Features:
LED Globe and
Cylinder
Applications: Security, entryway, walkways, sheds,
stairways, storage and perimeter lighting for
both residential and commercial locations
Typical Mounting Height: 8 to 12 feet
Typical Spacing: 12 feet
Dimensions: 5.8"L x 4.4"W x 9.8"H
Weight: 2.22 lbs.
Dimensions: 6.5"L x 4.7"W x 9.3"H
Weight: 2.12 lbs.
Globe
Cylinder
COLOR TEMP Neutral White (4000K)
WATTAGE 22W LED
LUMENS 595
CRI 85
COMPARABLE TO 60W Incandescent
CAT.# Dk. Bronze E-WC1L21NZP
CAT.# White E-WC1L21NWP
PRICE $39.99
COLOR TEMP Neutral White (4000K)
WATTAGE 22W LED
LUMENS 828
CRI 81
COMPARABLE TO 75W Incandescent
CAT.# Dk. Bronze E-WG1L21NZP
CAT.# White E-WG1L21NWP
PRICE $42.99
Also available in
White Finish
Also available in
White Finish
Securely Light the Way
The new LED residential security globe & cylinder fixtures provide excellent
performance while reducing energy use and maintenance costs. These fixtures
maintain a traditional design, but offer long-lasting LED technology making
them a smart upgrade choice.
NEW!
14 Free Shipping on Orders Over $500
Features:
• Estimated 100,000+ hours of maintenance-
free operation to L70
• E-S1 Series: Use in an uplight or downlight
orientation
• E-S2 Series: Provides uplight and downlight
distribution
• Dimmable with most 0-10V dimmers
• Die-cast aluminum mounting box with
extruded aluminum housing-mounting box
measures 5" square (5-3/8" square w/gasket)
• 25° beam spread
• Supplied with back mounting plate to
mount over a 4" square or 4" octagonal
junction box
• Silicone gasket provides a water tight seal
• Polyester powder-coat black or white finish
• Tempered glass lens, thermal shock and
impact resistant
• Universal voltage (120V through 277V)
• Cree® LEDs inside
• ETL Listed for wet locations
• 3-year limited warranty
LED Decorative
Wall Sconce
Applications: Ideal for illumination along steps, walkways
and entryways
Typical Mounting Height: 8 to 15 feet
Typical Spacing: 1 to 2 times the mounting height
Dimensions: 5-3/16"H x 4-1/16"D x 2-3/4"Dia (Small)
5-3/16"H x 6-3/16"D x 4-7/8"Dia (Medium)
5-3/16"H x 7-1/4"D x 6"Dia (Large)
Weight: 1.9 lbs. (Small)
3.2 lbs. (Medium)
4.5 lbs. (Large)
Dimensions: 7-3/16"H x 4-1/16"D x 2-3/4"Dia (Small)
7-3/16"H x 6-3/16"D x 4-7/8"Dia (Medium)
7-3/16"H x 7-1/4"D x 6"Dia (Large)
Weight: 2.4 lbs. (Small)
4.2 lbs. (Medium)
6.2 lbs. (Large)
Up or Down
Up and Down
Also available in
White Finish
Also available in
White Finish
(*) Specify finish color: K=Black, W=White
WATTAGE 10W LED 16W LED 30W LED
LUMENS 650 950 1950
CRI 80 80 80
COMPARABLE TO 60W Incandescent 100W Incandescent 70W PSMH
CAT.# - 3000K E-S11L013U(*) E-S12L013U(*) E-S13L033U(*)
CAT.# - 4000K E-S11L014U(*) E-S12L014U(*) E-S13L034U(*)
PRICE $59.99 $69.99 $79.99
Small Medium Large
(*) Specify finish color: K=Black, W=White
WATTAGE 14W LED (total) 30W LED (total) 34W LED (total)
LUMENS 1000 (total) 1850 (total) 2500 (total)
CRI 80 80 80
COMPARABLE TO 100W Incandescent 50W PSMH 70W PSMH
CAT.# - 3000K E-S21L013U(*) E-S22L033U(*) E-S23L033U(*)
CAT.# - 4000K E-S21L014U(*) E-S22L034U(*) E-S23L034U(*)
PRICE $69.99 $89.99 $99.99
Small Medium Large
34W Large Up and Down
LED Wall sconce - Black Finish
LED WALL SCONCES
15
www.e-conolight.com 888.243.9445
LED Vapor Tights
Applications: Non-hazardous industrial uses, including
environments with dust or high-moisture,
such as cold storage, harbors, railway depots,
tunnels, foundries, bridges, manufacturing,
retail and residential sites.
Typical Mounting Height: 8 to 12 feet
Typical Spacing: 12 feet
Dimensions: 4.5"L x 4.5"W x 9.3"H (Small)
5.7"L x 5.7"W x 11.6"H (Large)
Weight: 2.7 lbs. (Small)
4.4 lbs. (Large)
Dimensions: 4.5"L x 4.5"W x 10.0"H (Small)
5.7"L x 5.7"W x 12.4"H (Large)
Weight: 2.4 lbs. (Small)
4.1 lbs. (Large)
Dimensions: 5.8"L x 4.4"W x 9.8"H (Small)
8.9"L x 5.7"W x 12.2"H (Large)
Weight: 3.3 lbs. (Small)
5.2 lbs. (Large)
Ceiling Mount
Pendant Mount
Wall Mount
Rugged Design & Durability
The new LED vapor tight fixtures come in multiple mounting options- ceiling,
wall & pendant- making it extremely versatile for a variety of applications. The
heavy duty die-cast aluminum housing and lamp guard protect a frosted glass
globe that houses state-of-the-art LEDs, so you don't have to worry about
changing bulbs. Enjoy the same look you've become accustomed to, but with
a clean, uniform light thanks to LED technology.
• Designed to last 172,000 hours to L70 at 25°C
(77°F) (small fixtures)
• Designed to last 118,000 hours to L70 at 25°C
(77°F) (large fixtures)
• -40°C (-40°F) minimum starting temperature
• 120V operation
• Non-dimmable
• Die-cast aluminum housing and lamp guard
• Grey polyester powder-coat finish for extra
corrosion protection and long-lasting color
• Screw-in, frosted glass globe provides
uniform light distribution
• Die-cast aluminum 4" junction box
(Ceiling & Wall Mount)
• 5 threaded and plugged 3/4" conduit entry
points (Ceiling & Wall Mount)
• Threaded for conduit entry: 1/2" Small,
3/4" Large (Pendant Mount)
• Cree® LEDs inside
• UL Listed for wet locations
• 5-year limited warranty
Features:
CAT.# E-MTAC01S (Small)
15" aluminum shroud with powder-coat
finish (grey outer surface, white interior)
Not for use with wall mount
$2299
CAT.# E-MTAC01L (Large)
15" aluminum shroud with powder-coat
finish (grey outer surface, white interior)
Not for use with wall mount
$2499
Accessories:
Small
Small
Small
Large
Large
Large
COLOR TEMP Neutral White (4000K) Neutral White (4000K) Neutral White (4000K)
WATTAGE 14W LED 14W LED 14W LED
LUMENS 931 927 928
CRI 71 71 71
COMPARABLE TO 100W Incandescent 100W Incandescent 100W Incandescent
CAT.# E-VT1L141NG E-VT2L141NG E-VT3L141NG
PRICE $79.99 $79.99 $89.99
Ceiling Pendant Wall
SMALL
COLOR TEMP Neutral White (4000K) Neutral White (4000K) Neutral White (4000K)
WATTAGE 22W LED 22W LED 22W LED
LUMENS 1215 1247 1212
CRI 75 75 75
COMPARABLE TO 120W Incandescent 120W Incandescent 120W Incandescent
CAT.# E-VT4L221NG E-VT5L221NG E-VT6L221NG
PRICE $99.99 $99.99 $99.99
Ceiling Pendant Wall
LARGE
NEW!
LED VAPOR TIGHTS
16 Free Shipping on Orders Over $500
LED Canopy Light - Wide Distribution
Cool White
Heat-dissipating fins keep LEDs
running cool
Die-Cast Aluminum Housing
UV-stabilized acrylic lens built for
maximum durability
Prismatic Refractor
1/2" conduit on two sides plus 3/4"
entry on top for pendant mounting
Conduit Entries
High-output array
provides an estimated 50,000
hours of maintenance-free
operation
LED Array
*All fixtures are shown with a mounting height of 12 feet and 0° tilt
E-CP2L04CS Fixture
(42W LED)
PAGE 19
E-CP2L03CW Fixture
(30W LED)
PAGE 19
36ft
36ft
2
1
.5
38ft
38ft
2
1
.5
E-CP2L07CW Fixture
(72W LED)
PAGE 18
60ft
60ft
2
1
.5
56ft
56ft
2
1
.5
40ft
40ft
2
1
.5
.2
E-CP2L04CW & E-RC2L04CW
Fixtures (42W LED)
PAGE 18
E-CC5L03
Fixtures (36W LED)
PAGE 17
Four distributions to fit your installation
"Easy to retrofit into current setup, light weight
and ridiculously bright."
– E-conolight customer Jason
LED CANOPY
17
www.e-conolight.com 888.243.9445
Applications: Security, entryway and perimeter lighting -
also recommended for parking garages,
shopping area walkways & exterior canopies
Typical Mounting Height: 8 to 15 feet
Typical Spacing: 1 to 2 times the mounting height
Dimensions: 3-15/16"H x 9-7/8"W x 9-7/8"D
Weight: 5.0 lbs.
LED Canopy Light -
Wide Distribution
• Estimated 50,000 hours of maintenance-free
operation to L70 at 25°C
• Non-dimmable
• Low-copper, die-cast aluminum housing
• Polyester powder-coat finish for extra corrosion
protection and long-lasting color - dark bronze or
white finishes available
• Minimum starting temperature: -40°C (-40°F)
• UV-stabilized acrylic prismatic refractor with self-
retaining screws
• 75°C minimum supply wire required
• 3/4" conduit entry on top for pendant
mounting
• 1/2" conduit entries on two sides
• Universal voltage (120V through 277V)
• Cree® LEDs inside
• UL Listed for wet locations
• 5-year limited warranty
Features:
COLOR TEMP Neutral White (4100K)
WATTAGE 38W LED
LUMENS 2000
CRI 77
COMPARABLE TO 70W PSMH
CAT.# White E-CC3L03NW
WAS $74.90
PRICE $69.99
COLOR TEMP Cool White (5000K) Neutral White (4000K)
WATTAGE 36W LED 36W LED
LUMENS 3618 3662
CRI ≥ 70 ≥ 70
COMPARABLE TO 100W PSMH 100W PSMH
CAT.# Dark Bronze E-CC5L03CZ E-CC5L03NZ
CAT.# White E-CC5L03CW E-CC5L03NW
PRICE $119.99 $119.99
E-CC3
E-CC5
LED CANOPY
Now DLC
Listed!
Price Drop!
While
Supplies
Last
BACK IN
STOCK!
18 Free Shipping on Orders Over $500
Features:
• Estimated 50,000 hours of maintenance-
free operation to L70 at 25°C
• 0-10V dimmable driver
• Rugged and durable aluminum housing
• White polyester powder-coat finish
• Minimum starting temperature: -30°F
(-22°F)
• UV-stabilized acrylic lens with molded
precision optics
• 1/2" conduit entry on top for pendant
mounting or on one side for NPT threaded
pipe
• Slots provided on top for mounting over a
4" square or octagonal J-box
• Universal voltage (120V through 277V)
• Cree® LEDs inside
• ETL Listed for wet locations
• 5-year limited warranty
LED PATTERN
COLOR TEMP Cool White (5000K) Cool White (5000K)
WATTAGE 72W LED 42W LED
LUMENS 7300 4100
CRI ≤ 75 ≤ 75
COMPARABLE TO 250W PSMH 100W PSMH
CAT.# White E-CP2L07CW E-CP2L04CW
PRICE $289.99 $239.99
Low-Profile LED
Canopy Light -
Wide Distribution
Applications: Security, entryway and perimeter lighting -
also recommended for parking garages,
shopping area walkways & exterior canopies
Typical Mounting Height: 8 to 20 feet
Typical Spacing: 1 to 2 times the mounting height
Dimensions: 2-3/8"H x 12"W x 12"D
Weight: 7.5 lbs.
72W Delivers
Over 7000
Lumens!
Applications: Security, entryway and perimeter lighting -
also recommended for walkways and
exterior canopies
Typical Mounting Height: 8 to 15 feet
Typical Spacing: 1 to 2 times the mounting height
Dimensions: 2-3/4"H x 16"W x 16"D
Weight: 6.2 lbs.
LED Recessed
Canopy Light -
Wide Distribution
• 0-10V dimmable driver
• Estimated 50,000 hours of maintenance-free
operation to L70 at 25°C
• Rugged and durable aluminum housing
• White polyester powder-coat finish
• Minimum starting temperature: -30°F (-22°F)
• UV-stabilized acrylic lens with molded precision
optics
• 1/2" conduit entry on top
• Hanging cable supports fixture while wiring
connections are made
• Secures to mounting surface with four
screws (provided by others)
• RoHS compliant
• Universal voltage (120V through 277V)
• Cree® LEDs inside
• ETL listed for wet locations
• 5-year limited warranty
Features:
LED PATTERN
COLOR TEMP Cool White (5000K)
WATTAGE 42W LED
LUMENS 4100
CRI 75
COMPARABLE TO 100W PSMH
CAT.# White E-RC2L04CW
PRICE $249.99
LED CANOPY
BACK IN
STOCK!
BACK IN
STOCK!
19
www.e-conolight.com 888.243.9445
LED PATTERN
COLOR TEMP Cool White (5000K) Cool White (5000K)
WATTAGE 30W LED 42W LED
LUMENS 2800 4100
CRI ≤ 70 ≤ 70
COMPARABLE TO 70W PSMH 100W PSMH
CAT.# E-CP2L03CW (White) E-CP2L04CS (Silver)
PRICE $219.99 $239.99
Features:
• Estimated 50,000 hours of maintenance-
free operation to L70 at 25°C
• 0-10V dimmable driver
• Rugged and durable aluminum housing
• White or Silver polyester powder-coat finish
• Minimum starting temperature: -30°F
(-22°F)
• UV-stabilized acrylic lens with molded
precision optics
• 1/2" conduit entry on top for pendant
mounting or on one side for NPT
threaded pipe
• Slots provided on top for mounting over a
4" square or octagonal J-box
• Universal voltage (120V through 277V)
• Cree® LEDs inside
• ETL Listed for wet locations
• 5-year limited warranty
Features:
• Estimated 50,000 hours of maintenance-
free operation to L70 at 15°C
• 0-10V dimmable driver for Low-Profile
Canopy.
Parking Garage Light is non-dimmable.
• Rugged and durable housing with polyester
powder-coat finish
• Minimum starting temperature: -30°F
(-22°F)
• Parking Garage Light has polycarbonate
refractor lens.
• Parking Garage Light mounts flush to
standard J-box, surface mount conduit,
or 1/2" conduit entry on top for pendant
mounting using NPT threaded pipe
• 1/2" conduit entry on top for pendant
mounting
• Slots provided on top of both fixtures for
mounting over a 4" square or octagonal
J-box.
• Universal voltage (120V through 277V)
• Cree® LEDs inside
• ETL Listed for wet locations
• 5-year limited warranty
Low-Profile LED
Canopy Light -
Medium Distribution
LED Parking Garage
Light
Applications: Security, entryway and perimeter lighting -
also recommended for parking garages,
shopping area walkways & exterior canopies
Typical Mounting Height: 8 to 15 feet
Typical Spacing: 1 to 2 times the mounting height
Dimensions: 2-3/8"H x 12"W x 12"D
Weight: 7.5 lbs.
Applications: Security, entryway and perimeter lighting -
also recommended for parking garage
Typical Mounting Height: 8 to 15 feet
Typical Spacing: 1 to 2 times the mounting height
Dimensions: 11-3/8"H x 13"W x 13"D
Weight: 10.25 lbs.
COLOR TEMP Cool White (5000K)
WATTAGE 75W LED
LUMENS 5900
CRI 75
COMPARABLE TO 175W MH
CAT.# Silver E-PG1L08CS
PRICE $298.90
LED CANOPY & PARKING
BACK IN
STOCK!
BACK IN
STOCK!
20 Free Shipping on Orders Over $500
COLOR TEMP Neutral White (4000K) Cool White (5000K)
WATTAGE 27W LED 27W LED
LUMENS 1675 1253
CRI 72 72
COMPARABLE TO 50W MH 50W MH
CAT.# E-BR3L27U4K E-BR3L27U5K
PRICE $349.99 $349.99
Features:
• Estimated 57,500 hours of maintenance-free
operation to L70 at 25°C (77°F)
• Durable aluminum housing
• Metallic black powder coat
• Polycarbonate lens
• Mounts to the included anchor bolts
• Non-dimmable
• ETL Listed for wet locations
• Cree® LEDs inside
• 5-year limited warranty
New LED Bollard - More Light,
Lower Price
E-conolight’s new LED Bollard is brighter, more efficient and lasts longer
than our previous model. Choose either neutral white (4000K) or cool white
(5000k) to create a safe and bright walkway without annoying glare.
LED BOLLARD
LED Bollard
Applications: Security, entryway, walkway and perimeter
lighting
Dimensions: 36.06"H x 7.87"Dia
Weight: 15.2 lbs.
NEW!
21
www.e-conolight.com 888.243.9445
LED GOOSENECK
Applications: Business storefronts, restaurants, & building
perimeters that need an architectural touch
of style
Typical Mounting Height: 8 to 15 feet
LED gooseneck lighting combines the best of simple, traditional elegance
with the advanced LED technology, making it the perfect replacement for
HID fixtures. LED gooseneck lights are one of the best choices to make when
choosing fixtures for accent illumination in an architectural design. This
fixture is ideal for business storefronts, restaurants, and building perimeters.
COLOR TEMP Warm White (3000K) Warm White (3000K)
WATTAGE 15W LED 15W LED
LUMENS 1100 1260
CRI ≥ 70 ≥ 70
COMPARABLE TO 100W Incandescent 100W Incandescent
SHROUD Angled Straight
CAT.# E-DG1L13UAK E-DG1L13USK
PRICE $179.99 $179.99
• Non-dimmable
• Estimated 150,000+ hours of maintenance-free
operation to L70
• Universal voltage (120V through 277V)
• Die-cast aluminum mounting box and housing
• Supplied with back mounting plate to mount
over a 3" or 4" octagonal J-box
• Black polyester powder-coat finish for extra
corrosion protection and long-lasting color
• Minimum starting temperature: -30°C (-22°F)
• Tempered glass lens, thermal, shock and
impact resistant
• ETL Listed for wet locations
• Cree® LEDs inside
• 5-year limited warrnaty
Features:
Dimensions: 31.5"L x 15.3"W x 18.8"H
(Mounting canopy diameter is 4.8")
Weight: 5.0 lbs.
Dimensions: 35"L x 15.3"W x 25.8"H
(Mounting canopy diameter is 4.8")
Weight: 5.0 lbs.
Straight Shroud
Angled Shroud
LED Gooseneck
Angled Shroud, 3000K
LED Gooseneck
Enjoy high architectural style with
maximum energy savings
22 Free Shipping on Orders Over $500
Heat-dissipating fins keep LEDs
running cool
High-efficiency, spun aluminum
reflector provides maximum amount
of downlight
Polycarbonate prismatic reflector with
high-efficiency white coating provides
soft, diffuse uplight, making spaces
appear larger
Mounts directly over J-box or with
3/4" pendant. Six 1/2" and two 3/4"
knockouts provided on the sides.
Die-Cast Aluminum Housing
16" Aluminum Reflector
16" Prismatic Reflector (pictured)
Versatile Splice Box
High-output arrays
provide an estimated 76,000 hours
of instant-on virtually maintenance-
free operation
LED Arrays
LED HIGH BAY
23
www.e-conolight.com 888.243.9445
LED High Bay
Applications: Warehouses, industrial and retail sites
Typical Mounting Height: 15 to 30 feet
Dimensions: 16"L x 16"W x 12.9"H (113W)
16"L x 16"W x 15.5"H (225W)
Weight: 13.0 lbs. (113W)
17.0 lbs. (225W)
Dimensions: 16"L x 16"W x 19.5"H (113W)
16"L x 16"W x 22.3"H (225W)
Weight: 14.6 lbs. (113W)
18.8 lbs. (225W)
Aluminum Reflector
Prismatic Reflector
• Estimated 76,000 hours of maintenance-free
operation to L70
• Non-dimmable
• Durable die-cast aluminum heat sink & housing
• White polyester powder-coat finish
• LEDs protected against dust and dirt with
tempered glass lens
• 16" spun aluminum reflector or 16" diffuse
polycarbonate prismatic reflector
• Minimum starting temperature: -30°C (-22°F)
• Universal voltage (120V through 277V)
• UL listed for damp locations for locations not
exceeding 40°C (104°F) ambient temps
• Included slide splice box mounts directly over
junction box or with 3/4" pendant (provided by
others). Splice box has six 1/2" and two 3/4"
knockouts on the sides.
• 75°C minimum supply wire required
• Cree® LEDs inside
• 5-year limited warranty
Features:
LED upgrade made easy
The new LED high bay from e-conolight has been designed as a direct one-for-
one replacement of 250W and 400W traditional HID fixtures. Enjoy incredible
energy savings and a familiar installation with this LED fixture. This LED high
bay is ideal for industrial, retail and warehouse sites.
CAT.# E-1CP61S (120V)
6-foot cord with straight blade plug.
Strain relief included.
$390
CAT.# E-1CP61 (120V), CAT.# E-1CP62 (277V)
CAT.# E-1CP64 (208V/240V)
6-foot cord with 3-blade twist-lock plug. Strain relief included.
$490
CAT.# E-LHSB/H
Slide splice box with hook
$799
CAT.# E-LENSLA/PB
16" flat diffusor lens
$4999
CAT.# E-ACRCPT31 (120V, 3-Wire, NEMA L5-15R)
CAT.# E-ACRCPT32 (277V, 3-Wire, NEMA L7-15R)
CAT.# E-ACRCPT34 (208/240V, 3-Wire, NEMA L6-15R)
Locking-Type Receptacle (3-blade twist-lock)
$490
Accessories (available with fixture purchase only):
Aluminum Reflector
Prismatic Reflector
COLOR TEMP Neutral White (4000K) Neutral White (4000K)
WATTAGE 110W LED 220W LED
LUMENS 11,263 20,736
CRI ≥ 70 ≥ 70
COMPARABLE TO 250W MH 400W MH
CAT.# E-AB1L11NU E-AB1L22NU
PRICE $229.99 $329.99
COLOR TEMP Neutral White (4000K) Neutral White (4000K)
WATTAGE 110W LED 220W LED
LUMENS 11,215 20,503
CRI ≥ 70 ≥ 70
COMPARABLE TO 250W MH 400W MH
CAT.# E-PB1L11NU E-PB1L22NU
PRICE $249.99 $349.99
LED HIGH BAY
Now DLC
Listed!
Now DLC
Listed!
24 Free Shipping on Orders Over $500
2'x2' LED Troer
2'x4' LED Troer
LED Lay-In Troffers
Applications: For use in office, educational, retail,
commercial and institutional applications.
Dimensions: 4-3/4"H x 11-3/4"W x 47-3/4"D
(Height includes driver)
1'x4'
LED LAY-IN TROFFERS
• Up to 3700 Lumens
• Up to 97 LPW
• Dimmable
Features (apply to all sizes of troffers):
• Estimated 50,000 hours of maintenance-free
operation to L70 at 25°C
• Dimmable down to 10% with most 0-10V
dimmers
• Universal voltage (120V through 277V)
• Sealed, maintenance-free fixture design
• Integrated trim with white, glossy finish
• Prismatic polystyrene lens
• Durable steel housing construction (Body is
20 gauge steel; lens frame is 18 gauge steel)
• LED backlit design provides uniform light
distribution
• Minimum starting temperature: -30°C
(-22°F)
• IC-rated and can be in direct contact with
insulation
• UL Listed for damp locations
• Cree® LEDs inside
• 5-year limited warranty
COLOR TEMP Warm White (3500K) Neutral White (4000K)
WATTAGE 38W LED 38W LED
LUMENS 3500 3700
CRI 80 80
COMPARABLE TO 1x4 Fluorescent Troffer
(2x 32W T8) 1x4 Fluorescent Troffer
(2x 32W T8)
CAT.# E-TR14L383U E-TR14L384U
PRICE (1-14) $139.90 $139.90
PRICE (15-29) $129.90 $129.90
PRICE (30-59) $122.90 $122.90
PRICE (60+) $114.90 $114.90
25
www.e-conolight.com 888.243.9445
LED LAY-IN TROFFERS
COLOR TEMP Warm White (3500K) Neutral White (4000K)
WATTAGE 39W LED 39W LED
LUMENS 3400 3700
CRI 80 80
COMPARABLE TO 2x2 Fluorescent Troffer
(2x 31W U6) 2x2 Fluorescent Troffer
(2x 31W U6)
CAT.# E-TR22L393U E-TR22L394U
PRICE (1-14) $124.90 $124.90
PRICE (15-29) $119.90 $119.90
PRICE (30-59) $108.90 $108.90
PRICE (60+) $99.90 $99.90
Dimensions: 4-3/4"H x 23-3/4"W x 23-3/4"D
(Height includes driver)
Dimensions: 4-3/4"H x 23-3/4"W x 47-3/4"D
(Height includes driver)
2'x2'
2'x4'
Don't spend more!
Upgrade to LED for brighter light, bigger energy cost savings and easy 1-for-1
replacement in existing T-bar ceiling grids.
• Up to 3700 Lumens
• Up to 95 LPW
• Dimmable
• Up to 5000 Lumens
• Up to 100 LPW
• Dimmable
COLOR TEMP Warm White (3500K) Neutral White (4000K)
WATTAGE 50W LED 50W LED
LUMENS 4500 5000
CRI 80 80
COMPARABLE TO 2x4 Fluorescent Troffer
(3x 32W T8) 2x4 Fluorescent Troffer
(3x 32W T8)
CAT.# E-TR24L503U E-TR24L504U
WAS $194.90 $194.90
PRICE $169.90 $169.90
Battery backup option
The LED troffer you appreciate is now available with a battery backup for
greater flexibility with the same 1-for-1 lay-in replacement and installation.
Battery backup provides up to 90 minutes of illumination for peace of mind
in case of a power outage.
LUMENS 700 750 1000
CRI 80 80 80
WATTAGE 38W LED 39W LED 50W LED
CAT.# - 3500K E-TR14L383E E-TR22L393E E-TR24L503E
CAT.# - 4000K E-TR14L384E E-TR22L394E E-TR24L504E
WAS $439.99 $429.99 $499.99
PRICE $389.99 $379.99 $449.99
1'x4'2'x2'2'x4'
Price Drop!
26 Free Shipping on Orders Over $500
Lots of Lumens in A Small
Track Fixture
Size Comparison
Stylishly unobtrusive, the E-KXF is perfect for accenting architecture or providing
general illumination. With its introduction, the E-KXF rounds out E-conolight’s track
family while setting a standard for energy savings, color consistency and
flexible options.
COLOR TEMP Soft White (2700K) Warm White (3000K) Neutral White (4000K)
WATTAGE 8W LED 8W LED 8W LED
LUMENS 500 500 530
CRI 80 80 80
CAT.# E-KXF108F1(*) E-KXF108F3(*) E-KXF108F7(*)
PRICE $44.99 $44.99 $44.99
(*) Specify finish color: K=Black, W=White
Mini LED Flat Back
Track Head
Applications: General purpose track lighting
perfect for indoor residential, commercial,
retail or industrial applications
Dimensions: 3.44"H x 1.875"W x 5.125"D
Weight: 0.77 lbs.
Also available in
Black Finish
NEW!
E-KXF Series E-KXC Series E-KXD Series
Pivot mount allows rotation of 350° horizontally and
90° vertically in both directions for maximum aiming
adjustability. 36° beam angle.
Features:
• Estimated lifetime of 30,000 hours to L70
at 25°C
• -10°C minimum starting temperature
• Non-dimmable
• 120V operation
• Pivot mount allows rotation of 350°
horizontally and 90° vertically in both
directions for maximum aiming adjustability.
• Compatible with 1- or 2- circuit track from
E-conolight, Ruud Lighting and certain track
systems from Juno (via included adaptor)
and Con-Tech.
• 36° beam angle
• Polycarbonate adapter with copper
conductor
• Die-cast aluminum
• White and black powder-coat finish
• Polycarbonate reflector and lens
• Cree® LEDs inside
• ETL Listed for dry locations
• 3-year limited warranty
LED TRACK LIGHTING
27
www.e-conolight.com 888.243.9445
Features:
• Estimated 35,000 hours of maintenance-
free operation
• 120V operation
• Die-cast aluminum housing for driver and
optics
• White or black polyester powder-coat finish
• Polycarbonate adapter with copper
conductor
• Spring latch secures light fixture to track
• Integral On/Off switch
• Pivot mount allows rotations up to 315°
horizontally and 0-90° vertically in both
directions for maximum aiming adjustability
• Compatible with 1- or 2-circuit track from
E-conolight, Ruud Lighting, and certain track
systems from Juno, Prescolite, and Con-Tech
• Dimmable to 10% (Visit us online for spec
sheet with compatible dimmers)
• ETL Listed for dry locations
• Cree® LEDs inside
• 3-year limited warranty
LED Beveled Cylinder
Track Light
LED Flat Back
Track Light
Applications: General purpose track lighting that's a
perfect fit for commercial, retail or
industrial applications
Dimensions: 6.5"H x 3.6"W x 5.0"D
Weight: 0.9 lbs.
Applications: High-output LED track ideal for commercial
applications like retail, restaurant and
hospitality
Dimensions: 7.3"H x 6.0"W x 4.5"D
Weight: 2.7 lbs.
The Light That Can Do It All
Great for Presentation
Experience up to 80% energy savings, three color temperatures and 35,000 hours of
maintenance-free operation with the new beveled cylinder LED track light. The E-KXC
is comparable to a 75W PAR30 halogen lamp and is available as a residential warm
light (2700K); soft, warm light (3000K); or crisp, neutral white light (4000K).
Maintenance of lamps and fixtures is a thing of the past with the new LED Flat Back
Track Light. Appropriate for retail, restaurant and hospitality applications where color
and tone are critical, the E-KXD delivers soft, warm light (3000K) or crisp, neutral
white light (4000K) at 2500 lumens over a lifetime of 35,000 hours. The E-KXD is
available in either durable black or white, polyester powder-coat finish to match any
décor. Internal reflectors provide spot, display and floodlighting for maximum effect.
COLOR TEMP Soft White (2700K) Warm White (3000K) Neutral White (4000K)
WATTAGE 15W LED 15W LED 15W LED
LUMENS 980 980 980
CRI 80 80 80
CAT.# E-KXC215U1(*) E-KXC215U3(*) E-KXC215U7(*)
PRICE $59.99 $59.99 $59.99
(*) Specify finish color: K=Black, W=White
COLOR TEMP Warm White (3000K) Neutral White (4000K)
WATTAGE 36W LED 36W LED
LUMENS 2500 2500
CRI 80 80
CAT.# E-KXD235U3(*) E-KXD235U7(*)
PRICE $99.99 $99.99
(*) Specify finish color: K=Black, W=White
Supplied with 20˚ spot reflector and additional 40˚ diffuse
lens for easy beam angle interchangeability. Diffuse lens
changes lumen output to 950 lumens.
see pages 28-29 for full
range of track connectors
Supplied with 20° spot, 30° narrow flood, and 40° flood
reflectors for easy beam angle interchangeability
LED TRACK LIGHTING
28 Free Shipping on Orders Over $500
1- and 2- Circuit Track
E-conolight track and fixtures are UL Listed for use with existing Ruud Lighting
T1 & T2 and Juno® T & TU systems (not affiliated with e-conolight).
The track features an extruded aluminum body, Lexan® fittings, a Noryl®
insert and No. 12 AWG solid copper conductors. Each track section includes
two end caps and mounting hardware.
Available in 4-, 6- and 8-foot lengths and a black or white finish.
UL Listed for dry locations.
1 - CIRCUIT
TRACK
4' TRACK
(actual length 3'8" or 44.1")
6' TRACK
(actual length 5'8" or 68.1")
8' TRACK
(actual length 7'8" or 92.1")
CAT.# Black E-K1T4K E-K1T6K E-K1T8K
CAT.# White E-K1T4W E-K1T6W E-K1T8W
PRICE $14.99 $22.99 $25.99
2 - CIRCUIT
TRACK
4' TRACK
(actual length 3'8" or 44.1")
6' TRACK
(actual length 5'8" or 68.1")
8' TRACK
(actual length 7'8" or 92.1")
CAT.# Black E-K2T4K E-K2T6K E-K2T8K
CAT.# White E-K2T4W E-K2T6W E-K2T8W
PRICE $14.99 $24.40 $29.90
1.425"
.688"
.825"
1.425"
1.425"
.688"
.825"
1.425"
Cord & Plug Feed
CAT.# E-KC211K (Black)
CAT.# E-KC211W (White)
15' cord, 3-pring plug, 6-amp capacity
Not UL Listed. 3.25' Long.
$390
T-Bar Attachment Clips (Drop Tiles)
Fastens track to 1" or 9/16" inverted tee
with drop tiles. One required for each 2'
of track. 4 per package.
CAT.# E-KC124 (1")
CAT.# E-KC127 (9/16")
$399
Outlet Box Cover
CAT.# E-KC31K (Black)
CAT.# E-KC31W (White)
Use with either single to 2-circuit adjustable,
"T" or "X" connectors when feeding at oublet
box. 4.062" square.
$240
T-Bar Attachment Clips (Flush Tiles)
Fastens track to 1" or 9/16" inverted tee with
flush tiles. One required for each 2' of track.
4 per package.
CAT.# E-KC123 (1")
CAT.# E-KC126 (9/16")
$340
Monopoint Mounting
CAT.# E-KC100K (Black)
CAT.# E-KC100W (White)
Mounts directly to any outlet box. Not for use
with low voltage fixtures with external power
supplies. 4.3-/4" diameter.
$390
Pendant Adaptor
To support chain-hung fixtures up to 10 lbs.
3/8" wiring hole. 5A max, 600 watts. Not UL
Listed. 1.425" Square x 3.3" High.
CAT.# E-KC122K (Black)
CAT.# E-KC122W (White)
$399
Accessories:
NOTE: 2-circuit 40 amp track
consists of two 20 amp feeds on
different phases sharing a common neutral feed line.
If both circuits are on the same phase, the total load
between two circuits is limited to 20 amps.
ADVANTAGES OF 2-CIRCUIT TRACK
• Double the load capacity (compared to 1-circuit track)
• Additional design flexibility
• Each circuit can be switched separately
• Create three different schemes on one section of the track:
1. First circuit on only
2. Second circuit on only
3. Both circuits on together
TRACK LIGHTING
29
www.e-conolight.com 888.243.9445
STYLE DESCRIPTION 1-CIRCUIT CAT.# PRICE 2-CIRCUIT CAT.# PRICE
End Feed
Allows feed from above with Romex,
Greenfield, or conduit.
3.28" Long
(Black)
(White)
E-KC381K
E-KC381W $340 (Black)
(White)
E-KC382K
E-KC382W $599
Floating Feed
Mounts to outlet box to provide power feed
at any point on track. Includes mounting
hardware.
4.6" Square, 1.6" High
(Black)
(White)
E-KC261K
E-KC261W $340 (Black)
(White)
E-KC262K
E-KC262W $590
Conduit Feed
Accepts male-threaded 1/2" conduit fitter for
surface wiring.
3" Long
(Black)
(White)
E-KC271K
E-KC271W $340 (Black)
(White)
E-KC272K
E-KC272W $590
Outlet Box Feed
End feed with outlet box cover and mounting
strap.
4.25" Square
(Black)
(White)
E-KC291K
E-KC291W $340 (Black)
(White)
E-KC292K
E-KC292W $590
T-Bar End Feed
End feed for T-Bar-mounted track. Three 1/2"
knockouts.
4.2" Square
(Black)
(White)
E-KC361K
E-KC361W $590 (Black)
(White)
E-KC362K
E-KC362W $890
Mini Straight Connector
Connects two track sections together.
0.3125" Long (1-Circuit)
0.4375" Long (2-Circuit)
(Black)
(White)
E-KC221K
E-KC221W $140 (Black)
(White)
E-KC222K
E-KC222W $290
Adjustable Connector/Feed†
Connects two track sections at 90° angle or
straight run. 1/2" knockout allows feed from
above.
2.8" x 2.8" (90°), 4.2 Long (Straight)
(Black)
(White)
E-KC231K
E-KC231W $490 (Black)
(White)
E-KC232K
E-KC232W $690
"T" Connector/Feed†
Joins three track sections.
4.2" Long x 2.8" Wide
(Black)
(White)
E-KC241K
E-KC241W $490 (Black)
(White)
E-KC242K
E-KC242W $790
"X" Connector/Feed†
Joins four track sections.
4.2" Square
(Black)
(White)
E-KC251K
E-KC251W $590 (Black)
(White)
E-KC252K
E-KC252W $1090
T-Bar Adjustable Connector/Feed
Connects two T-Bar-mounted track sections
at 90° angle or straight run. Three 1/2"
knockouts.
4.2" Square
(Black)
(White)
E-KC351K
E-KC351W $790 (Black)
(White)
E-KC352K
E-KC352W $1190
† NOTE: If fed from an outlet box, use the E-KC31(*) outlet box cover when using connector as feed. See page 28.
Track Feeds &
Connectors
TRACK LIGHTING
30 Free Shipping on Orders Over $500
Features:
• Estimated 96,000 hours of maintenance-free
operation to L70 at 25°C (77°F)
• 120V operation
• Triac dimming compatible with most dimmers
(See spec sheet online for list of
recommended dimmers)
• Aluminum housing with On/Off rocker switch
• Housing also features a 3/8" conduit
knockout
• 1 Romex connector included with each
fixture (models can be daisy chained
together with through wiring of Romex)
• White powder coat finish
• Polystyrene diffuser with glass cover
• Surface mount
• Custom low-profile driver, Non-Isolated,
Dimmable Driver, 120VAC 60Hz
• 75°C minimum supply wire required
• Cree® LEDs inside
• UL Listed for dry locations
• 5-year limited warranty
LED STEP LIGHT/LED SURFACE LIGHTING
LED Under-cabinet
Light
COLOR TEMP Soft White
(2700K) Soft White
(2700K) Soft White
(2700K) Soft White
(2700K) Soft White
(2700K)
SIZE 8"12.5"21.5"30"40"
WATTAGE 3W LED 6W LED 9W LED 11W LED 15W LED
LUMENS 202 332 484 690 917
CRI 90 90 90 90 90
COMPARABLE TO 6W T5 Lamp 8W T5 Lamp 8W T5 Lamp 13W T5 Lamp 13W T5 Lamp
CAT.# E-UN08L0321 E-UN13L0621 E-UN22L0921 E-UN30L1121 E-UN40L1521
PRICE $44.99 $54.99 $69.99 $84.99 $99.99
NEW!
LED Step Light
Applications: For use in single gang box to illuminate
stairs, steps and hallways
Dimensions: 4.72"H x 2.99"W x 1.73"D (with faceplate)
Weight: 0.44 lbs.
COLOR TEMP Warm White (3000K) Warm White (3000K)
PHOTOCELL No Yes
WATTAGE 0.5W LED 0.6W
LUMENS 12 10
CAT.# White E-SL2L131W E-SL2L131WP
PRICE $24.99 $29.99
Features:
• Designed to last 50,000 hours
• Comparable to 7W Incandescent
• Comes with both vertical and horizontal,
white painted steel faceplate and bracket
• Mounts in a single gang-box
• UL Listed for damp locations
• 2-year limited warranty
Step into the future with LED
E-conolight is introducing a new LED step light that boasts even better quality
than the previous model, and with a new lower cost. With more lumens and a
built-in photocell option, this new step light outperforms the old.
Photocell
NEW!
Applications: Kitchens and pantries, also recommended
for workshops, retail and display, back bars
and entertainment centers
Dimensions: 1.0"H x 3.5"W x
8.0", 12.5", 21.5", 30.0" or 40.0" L
Weight: 8.0" - 1.03 lbs.,
12.5" - 1.4 lbs.
21.5" - 2.2 lbs.,
30.0" - 3.04 lbs.
40.0" - 3.9 lbs.
31
www.e-conolight.com 888.243.9445
The Ideal Task Light
The LED surface mount wrap is the perfect energy-saving replacement for less
efficient fluorescent wrap fixtures. This fixture delivers higher lumens in a smaller
housing and is designed to mount directly to a 4/0 junction box. It is cheaper to
operate than incandescent and fluorescent lights, and with a 36,000+ hour average
LED life, you won’t have to worry about changing bulbs. Ideal applications include
task lighting for garages, closets, laundry rooms, hallways, entryways, and kitchens
and lunch rooms.
The Traditional Look You’re Used to
Now in LED
Replace that existing fluorescent wrap once and for all with E-conolight’s new AC
LED Wrap Fixture. High efficacy and long lifetime are achieved while maintaining the
familiar form factor.
COLOR TEMP Warm White (3000K) Neutral White (4000K)
WATTAGE 37.5W LED 37.5W LED
LUMENS 2760 2760
CRI 80 80
CAT.# E-WR1L383U E-WR1L384U
PRICE $109.99 $109.99
LAMPS Neutral White (4000K) Neutral White (4000K)
WATTAGE 36W LED (2-Lamp) 71W LED (4-Lamp)
LUMENS 2590 (2-Lamp) 4911 (4-Lamp)
COMPARABLE TO (2) 17W T8 Lamps (2-Lamp) (2) 32W T8 Lamps (4-Lamp)
CRI > 85 > 85
CAT.# E-WR2L3641 E-WR4L7141
PRICE $89.99 $149.99
Features:
• Triac dimming compatible with most dimmers
(See spec sheet online for list of
recommended dimmers)
• Estimated 36,300+ hours of maintenance-free
operation
• Universal voltage (120V through 277V)
• 80 CRI
• Easy installation into most 4/0 junction boxes
• Durable steel construction
• Microprismatic diffuser
• Mounting hardware included
• UL listed for damp locations
• Cree® LEDs inside
• 5-year limited warranty
Features:
• Estimated lifetime of 60,000 hours to L70 at
25°C (77°F)
• -18°C (-0.4°F) minimum starting temperature
• 120V operation
• Non-dimmable
• Constructed of durable 20-gauge steel
• White powder coat finish
• Clear prismatic acrylic lens
• Surface mount
• UL Listed for dry locations
• 5-year limited warranty
LED SURFACE LIGHTING
LED Surface Mount
Wrap
Applications: Residential and commercial surface mount
perfect for task lighting for garages,
closets, laundry rooms, hallways,
entryways, kitchens and lunch rooms
Typical Mounting Height: 8 to 10 feet
Typical Spacing: 1.2 times the mounting height
Dimensions: 19.82"L x 6.36"W x 2.2"H
Weight: 5.0 lbs.
Traditional-style LED
Surface Mount Wrap
Applications: Storage, laundry rooms, utility lighting,
work space
Dimensions: 49.0"L x 8.5"W x 2.5"H (2-Lamp)
49.0"L x 11.0"W x 2.5"H (4-Lamp)
Weight: 8.75 lbs. (2-Lamp)
12.0 lbs. (4-Lamp)
NEW!
32 Free Shipping on Orders Over $500
Next Generation LED
Surface Mount
Downlight
†
Applications: For use in 4/0 junction boxes and a variety
of existing 4", 5" and 6" recessed housings
COLOR TEMP Warm White (3000K) Warm White (3000K)
WATTAGE 15W LED 10W LED
LUMENS 1025 671
CRI 95 95
COMPARABLE TO 100W Incandescent 65W Incandescent
CAT.# E-T6D2153WW E-T4D2103WW
PRICE $34.99 $29.99
Features:
• Estimated 76,000 hours of maintenance-free
operation to L70 at 25°C (77°F)
• -18°C (-32°F) minimum starting temperature
• 95 CRI with an R9 of 64
• 120V operation
• Suitable for use in IC-rated housings
• Die-cast aluminum housing and trim
• White powder coat finish
• White polycarbonate diffuser eliminates hot
spots for uniform light distribution
• Surface mounts to 4/0 junction box and
retrofits into most 4", 5" & 6" housings
• Edison-style socket adaptor included
for easy installation
• Dimmable to 10% (see spec sheet online
for list of recommended dimmers)
• ETL Listed for wet locations
• 5-year limited warranty
More Light, Better Color, Lower Price
The Next Generation LED Surface Mount Downlight features vibrant color quality and
LED brightness and efficiency. Installation over a 4/0 junction box is a breeze using
the included snap-in mounting bracket. You can also easily install in a recessed can
using the provided hardware.
LED RECESSED
Dimensions: 2.0"H x 7.25" Trim Width
Weight: 0.85 lbs.
Dimensions: 2.0"H x 5.0" Trim Width
Weight: 0.45 lbs.
4" (10-Watt)
5" & 6" (15-Watt)
NEW!
† Recessed housing not included
5" & 6"4"
CAT.# E-T6C-GU24 (For E-T6D & E-T4D)
$199
Title 24 Compliant with
GU24 socket adaptor.
Can also be
installed in
most 4" cans
Very nice kit! Works in a junction box or can!
This is a great light fixture that I have used several times
now and love! It gives excellent light, looks good, is energy
efficient and is rated for wet locations such as a shower.
-E-conolight customer
"
"
33
www.e-conolight.com 888.243.9445
† Recessed housing not included
The LED Retrofit Kit
now also available in 4"!
The smaller diameter allows this LED retrofit kit to go into 4" recessed housings.
Plus, it offers over 600 lumens, 90+ CRI and uses 9 watts.
COLOR TEMP Soft White (2700K) Warm White (3000K)
WATTAGE 9W LED 9W LED
LUMENS 600 630
CRI 91 91
COMPARABLE TO 50W Incandescent 50W Incandescent
CAT.# E-T4C1092WW E-T4C1093WW
PRICE $26.99 $26.99
Features:
• 120V operation
• Edison-style socket adaptor included
• Durable construction with integrated trim
• Compatible with most 4" (E-T4C)
incandescent recessed housings with
included adjustable torsion springs
• Durable construction with diffused
convex lens
• Suitable for use in IC-rated recessed
housings
• Dimmable to 10% with most standard
dimmers (visit us online for spec sheet with
list of recommended dimmers)
• UL Listed for wet locations
• 5-year limited warranty
LED 5" & 6"
Recessed Retrofit Kit
†
Applications: For use in a variety of existing 5" & 6"
(E-T6C) recessed housings
Dimensions: 2.75"H x 7.5"Trim Width
Weight: 0.7 lbs.
COLOR TEMP Soft White
(2700K) Warm White
(3000K) Soft White
(2700K) Warm White
(3000K)
WATTAGE 13W LED 13W LED 17W LED 17W LED
LUMENS 966 966 1273 1273
CRI 93 93 93 93
COMPARABLE TO 75W Incandescent 75W Incandescent 100W Incandescent 100W Incandescent
CAT.# E-T6C2132WW E-T6C2133WW E-T6C2172WW E-T6C2173WW
PRICE $29.99 $29.99 $34.99 $34.99
Features:
• Estimated 60,000 hours of maintenance-
free operation to L70 at 25°C (77°F)
• -10°C (-50°F) minimum starting temperature
• Trim: Spun aluminum
Housing: ABS plastic
• White powder-coat finish for extra corrosion
protection and long-lasting color
• Polycarbonate lens
• Adjustable torsion spring clips allow for easy
installation into most 5" and 6" recessed
housings
• Edison-style socket adaptor included
• UL Listed for wet locations
• 5-year limited warranty
† Recessed housing not included
Versatile and more efficient
The new 6" LED Recessed Retrofit Kit is even more efficient than previous models.
It delivers more lumens; 966 lumens using only 13 watts, and 1273 lumens using
only 17 watts. It boasts an impressive 93 CRI with an R9 value of at least 58, thus
rendering red colors with superior quality. It installs in most 5" and 6" recessed
housings, making it one of the most versatile retrofit kits available.
NEW!
LED RECESSED
• Estimated 60,000 hours of
maintenance-free operation
• Easy installation with push-in
retention clips
Dimensions: 2.8"H x 4.9" Trim Width
Weight: 0.4 lbs.
4"
LED Recessed
Retrofit Kits
†
Applications: For use in a variety of existing 4" (E-T4C)
recessed housings
34 Free Shipping on Orders Over $500
LED RECESSED
• Estimated 35,000 hours of
maintenance-free operation
• Easy installation with adjustable
torsion springs
Features:
• 120V operation
• Edison-style socket adaptor included
• Durable construction with integrated trim
• Compatible with most 6" incandescent
recessed housings with included adjustable
torsion springs
• Durable construction with diffused
convex lens
• Suitable for use in IC-rated recessed
housings
• Dimmable to 10% with most standard
dimmers (visit us online for spec sheet with
list of recommended dimmers)
• UL Listed for wet locations
• Cree® LEDs inside
• 5-year limited warranty
† Recessed housing not included
COLOR TEMP Soft White (2700K)
WATTAGE 14W LED
LUMENS 703
CRI 91
COMPARABLE TO 75W Incandescent
CAT.# E-T6C1142WW
WAS $29.99
PRICE $24.99
CAT.# E-T6C-GU24 (For E-T6C & E-T4C)
$199
Title 24 Compliant with
GU24 socket adaptor.
While Supplies
Last
Bringing LED Lighting TO The Masses
Developed with Cree TrueWhite® Technology, the Cree 6-inch downlight provides efficacy
that is up to twice that of compact fluorescents, while achieving better color quality with a
CRI of 90+. This fixture is designed to easily install into existing IC or non-IC six-inch and some
five-inch housings and is dimmable down to 5% with widely available traditional dimmers.
Features:
• Cree TrueWhite™ Technology
(90 CRI model)
• Up to 66 lumens per watt
• Fits for most 6" and some 5" recessed
housings
• Replaces 65 watt incandescent
• CRI: 90
• Dimmable to 5%, with most standard
dimmers
• Designed to last up to 50,000 hours
• Energy Star® Qualified
• Damp Rated
• Compatible with IC and Non-IC rated
housings
• Warranty: Cree offers industry-leading
limited product warranties. Please visit
www.cree.com/Lighting/Products/Warranty
for more information on this product
COLOR TEMP Soft White (2700K)
WATTAGE 9.5W LED
LUMENS 625
CRI 90
COMPARABLE TO 65W Incandescent
CAT.# E-T6E1102WW
WAS $39.99
PRICE $27.99
Cree® 6" Downlight
Applications: New construction or upgrade for
residential and commercial lighting
Dimensions: 6.3"H x 7.5" Trim Width
LED 5" & 6"
Recessed Retrofit Kit
†
Applications: For use in a variety of existing 5" & 6"
(E-T6C) recessed housings
Dimensions: 2.75"H x 7.5"Trim Width
Weight: 0.7 lbs.
35
www.e-conolight.com 888.243.9445
6" LED Recessed
Retrofit Kit
†
Applications: For use in a variety of existing 6" recessed
housings, comparable up to 65W BR30
or 50W PAR20/PAR30
Dimensions: 4-1/2"H x 5-1/2"Diameter
Trim Ring 7-1/2" O.D.
Weight: 1.0 lbs.
CRI:80
†Recessed housing not included
1. After shutting off power
& removing old trim and
lamp, install the included
Edison-style socket
adaptor into the existing
medium base socket
2. Attach ground wire to
existing housing with
supplied screws
3. Plug the connector
from the LED Recessed
Retrofit Kit into the
connector on the Edison-
style socket adaptor
4. Squeeze torsion springs
together and mount into
brackets of the existing
recessed housing
5. Carefully route wires
up into the housing and
push up trim flush to the
ceiling - turn power back
on to the fixture
Easy 5-step
Installation!
Replace your incandescent.
Save Energy and Money.
Using only 14 watts, the Cree® LEDs provide up to 625 lumens of soft, uniform white
light at a color temperature of 3000K and 80 CRI.
With an estimated life rating of 25,000 hours, you can virtually eliminate the
maintenance and replacement costs associated with incandescent lamps.
Features:
• 25,000 hours of maintenance-free operation
• Non-dimmable
• 120V operation
• Extruded aluminum heat sink
• High-power factor greater than 90%
• Color temperature: 3000K
• Greater than 80 CRI
• Edison-style socket adaptor included
• ETL Certified per 1598C for use with most 6"
incandescent recessed white can housings.
See online spec sheet for list of qualified
manufacturers.
• ETL Certified for use in damp locations
• 3-year limited warranty
LUMENS 625
COMPARABLE TO 65W Incandescent
CAT.# E-T6B1143WC
PRICE $24.90
LUMENS 500
COMPARABLE TO 50W Incandescent
CAT.# E-T6B1143WK
PRICE $24.90
LUMENS 475
COMPARABLE TO 50W Incandescent
CAT.# E-T6B1143WL
PRICE $24.90
LUMENS 575
COMPARABLE TO 50W Incandescent
CAT.# E-T6B1143WW
PRICE $24.90
LUMENS 400
COMPARABLE TO 50W Incandescent
CAT.# E-T6B1143EB
PRICE $24.90
Specular Clear Reflector
White Molded Trim Ring
O.D. 7-1/2"
Grooved Baffle, Black Metal
White Molded Trim Ring
O.D. 7-1/2"
Patterned Lens
White Molded Trim Ring
O.D. 8"
Grooved Baffle, White Metal
While Molded Trim Ring
O.D. 7-1/2"
Eyeball
O.D. 7-3/4"
CAT.# E-T6B-GU24
$199
Title 24 Compliant with
GU24 socket adaptor.
Trims:
LED RECESSED
Free Shipping on Orders Over $500
36
LED RECESSED
6" LED Architectural
Downlight -
Type Non-IC
Applications: For use in new construction applications
with non-insulated ceilings or where
insulation can be kept 3" from housing
Dimensions: 6-1/2"(Ceiling Cutout)
12"W x 13-1/2" L (Plaster Frame)
New Construction
12.6"
(320 mm)
6.0"
(152 mm)
1.3"
(33 mm)
5.4"
(137 mm)
12.0"
(305 mm)
12.6"
(320 mm)
6.0"
(152 mm)
1.3"
(33 mm)
5.4"
(137 mm)
12.0"
(305 mm)
COLOR TEMP Warm White (3500K)
WATTAGE 21W LED
LUMENS 1000
CRI 80
COMPARABLE TO 75W Incandescent
CAT.# E-A6NL21-1T
PRICE $49.90
OPEN TRIM
Clear Reflector
White Molded Trim Ring (8" O.D.)
CAT.# E-AT6L110CL
$990
More trims
available at
www.e-conolight.com/
trims
Features:
• Heavy-gauge formed steel housing
• Non-dimmable
• Thermally protected in accordance with
Article 410 of NEC and UL 1598
• Mounting brackets are adjustable from
above or below the ceiling and have a 5"
vertical adjustment
• Listed for eight #12AWG (4 in - 4 out) 90°C
feed through branch circuit conductors
• Ten 1/2" and four 3/4" knockouts with
pry-outs
• Eight knockouts with Romex cable clamp
• ETL Listed for damp locations and where
insulation can be kept 3" away from housing
• 120V operation
• Cree® LEDs inside
• 3-year limited warranty
CAT.# E-RABH30C
30" C-Channel Hanger Bars (2)
$440
CAT.# E-RARC7
T-Bar Clips (4)
$299
CAT.# E-RABH27
27" Flat Bar Hangers (2)
$190
Accessories:
www.e-conolight.com 888.243.9445
COLOR TEMP Neutral White (4000K) Neutral White (4000K) Neutral White (4000K)
LUMENS 13,794 13,794 13,794
WATTAGE 110W LED 110W LED 110W LED
LUMENS/WATT 125 125 125
CRI 81 81 81
COMPARABLE TO 6 Lamp T8 Fluorescent 6 Lamp T8 Fluorescent 6 Lamp T8 Fluorescent
CAT.# E-LL6L1WUN4 E-LL6L1WUK4
(with motion sensor) E-LL6L1WUW4
(with wire guard)
PRICE $149.99 $209.99 $209.99
COLOR TEMP Cool White (5000K) Cool White (5000K) Cool White (5000K)
LUMENS 13,905 13,905 13,905
WATTAGE 110W LED 110W LED 110W LED
LUMENS/WATT 126 126 126
CRI 81 81 81
COMPARABLE TO 6 Lamp T8 Fluorescent 6 Lamp T8 Fluorescent 6 Lamp T8 Fluorescent
CAT.# E-LL6L1WUN5 E-LL6L1WUK5
(with motion sensor) E-LL6L1WUW5
(with wire guard)
PRICE $149.99 $209.99 $209.99
Switch to an LED High Bay and
Cut Your Energy Cost In Half
The Best Value in an LED Tube
Powered by our new T8 LED Tube, the LED Linear High Bay shines with almost 14,000 lumens
at over 125 lumens per Watt. They install quickly and easily using supplied V-hangers and have
a rated lifetime of 50,000 hours.
COLOR TEMP Neutral White (4000K) Cool White (5000K)
LUMENS 2384 2410
WATTAGE 18W LED 18W LED
LUMENS/WATT 132 134
CRI 81 81
COMPARABLE TO 32W Fluorescent T8 32W Fluorescent T8
CAT.# ~LT8118840 ~LT8118850
PRICE $19.99 $19.99
OPEN TRIM
Clear Reflector
White Molded Trim Ring (8" O.D.)
CAT.# E-AT6L110CL
$990
Features:
• Estimated 50,000 hours of maintenance-free
operation to L70 at 25°C (77°F)
• -20°C (-4°F) minimum starting temperature
• 120V-277V operation
• Bodies of fixtures constructed of durable
rolled steel
• Reflectors constructed of stamped aluminum
• Fixtures are painted white; reflectors are
painted with hi-gloss reflective white paint
• V-hangers come standard with each fixture
for ease of installation with customer
supplied cable or chains
• Do not install in environments that contain
airborne corrosive agents such as chemical
solvents or cutting fluids as they can cause
sockets to deteriorate
• Direct AC wiring
• Non-dimmable
• UL Listed for damp locations
• 5-year limited warranty
Features:
• Estimated 50,000 hours of maintenance-free
operation to L70 at 25°C (77°F)
• -20°C (-4°F) minimum starting temperature
• 100V-277V operation
• Aluminum heat-sink and back cover
• Plastic frosted lens
• Non-dimmable internal driver
• UL Listed for damp locations
• 5-year limited warranty
*Works with most electronic T8 ballasts
including rapid start, instant start and
programmed start ballasts. Also works
without a ballast. Not compatible with
most magnetic ballasts.
LED LINEAR HIGH BAY/ LED TUBE
6-Lamp LED
Linear High Bay
Applications: Warehouses, industrial and retail sites
Dimensions: 48"H x 19"W x 4.5"L
Weight: 14.8 lbs.
15.3 lbs. (with sensor)
19.1 lbs. (with wire guard)
LED T8 Tube
Applications: 4' fluorescent T8 lamp retrofit
Dimensions: 47.16"L x 1.16"W x 1.32"H
Weight: 1.014 lbs.
NEW!
NEW!
37
• Over 2300 Lumens
• Over 130 LPW
• Works with or without a ballast
on both single and dual end
powered fixtures*
• Over 13,700 Lumens
• Over 125 LPW
• Quick and Easy Installation
• Available with Motion Sensor
• Available with Wire Guard
• Can only be used with LED T8 Tube
(shown below)
Includes 6 LED
T8 Tubes and
starts at only
$149.99!
See page 48 for accessories
38 Free Shipping on Orders Over $500
Cree®
MR16
Cree®
BR30
Cree® T8
Cree® A19
LED LAMPS
LED Lamps
NEW!
WARNINGS & CAUTIONS
• Turn off power before changing lamp
Risk of electric shock
• Do not use in outdoor fixtures
• Suitable for use in damp locations
• For MR16 lamps, remove cover glass in track or recessed fixtures
CAT.# DESCRIPTION WATTS BEAM
ANGLE
APPROX
LUMENS
RATED
LIFE
COLOR
TEMP CRI MOL WARRANTY PRICE
HOURS KELVIN INCHES
CREE® MR16 DIMMABLE (12V AC/DC 50/60 Hz - Replaces up to 35W Quartz Halogen) /Bulb
~LM207CS3 CREE® MR16 7W GU5.3 (17) 30K 7W 17°464 25,000 3000K 83 1.9 3-Year Limited $29.00
~LM207CF3 CREE® MR16 7W GU5.3 (25) 30K 7W 25°464 25,000 3000K 83 1.9 3-Year Limited $29.00
CREE® PREMIUM MR16 DIMMABLE (12V AC/DC 50/60 Hz - Replaces up to 50W Quartz Halogen) /Bulb
~LM209CS3 CREE® MR16 9W GU5.3 (17) 30K 9W 17°620 25,000 3000K 83 1.9 3-Year Limited $30.00
~LM209CF3 CREE® MR16 9W GU5.3 (25) 30K 9W 25°620 25,000 3000K 83 1.9 3-Year Limited $30.00
CREE® A19 DIMMABLE (Replaces up to 60W) /6-pack
~LA209C1/6 CREE® 9.5-Watt A19 Warm White 9.5W OMNI 800 25,000 2700K 80 4.4 3-Year Limited $59.99
~LA209C9/6 CREE® 9.5-Watt A19 Cool White 9.5W OMNI 800 25,000 5000K 80 4.4 3-Year Limited $65.99
CREE® A19 DIMMABLE (Replaces up to 75W) /6-pack
~LA213C1/6 CREE® 13.5-Watt A19 Warm White 13.5W OMNI 1100 25,000 2700K 80 4.4 3-Year Limited $95.99
~LA213C9/6 CREE® 13.5-Watt A19 Cool White 13.5W OMNI 1100 25,000 5000K 80 4.4 3-Year Limited $101.99
CREE® BR30 DIMMABLE (Replaces up to 65W) /4-pack
~LB309C1/4 CREE® 9.5-Watt BR30 Warm White 9.5W FLOOD 650 25,000 2700K 80 5.0 3-Year Limited $79.99
~LB309C9/4 CREE® 9.5-Watt BR30 Cool White 9.5W FLOOD 650 25,000 5000K 80 5.0 3-Year Limited $79.99
CREE® T8 /Bulb
~LT821935 T8 21-Watt Warm White 21W
varies by
ballast N/A 2100 50,000 3500K 90+ 48.0 5-Year Limited $34.99
$23.99
~LT820935 T8 20-Watt Warm White 20W
varies by
ballast N/A 1700 50,000 3500K 90+ 48.0 5-Year Limited $18.49
~LT820940 T8 20-Watt Neutral White 20W
varies by
ballast N/A 1700 50,000 4000K 90+ 48.0 5-Year Limited $18.99
~LT820950 T8 20-Watt Cool White 20W
varies by
ballast N/A 1700 50,000 5000K 90+ 48.0 5-Year Limited $18.99
39
www.e-conolight.com 888.243.9445
LED LAMPS
MR16 PAR30L PAR38PAR20
CAT.# DESCRIPTION WATTS BEAM
ANGLE
APPROX
LUMENS
RATED
LIFE
COLOR
TEMP CRI MOL PRICE
HOURS KELVIN INCHES
LUMA® MR16 DIMMABLE (12V AC/DC 50/60 Hz - Replaces up to 40W Quartz Halogen Incandescent)
~LM207AW3 MR16 6.5W GU5.3 (54) 30K 7W 54°400 35,000 3000K 80 2.0 $22.40
LUMA® PAR20 DIMMABLE (110-120V 50/60 Hz - Replaces 50W Quartz Halogen Incandescent)
~LP208AF3 PAR20 8W E26 (35) 30K 8W 35°400 35,000 3000K 80 3.7 $27.99
LUMA® PAR30L DIMMABLE (110-120V 50/60 Hz - Replaces 60W Quartz Halogen Incandescent)
~LL312AF3 PAR30L 12W E26 (25) 30K 12W 25°700 35,000 3000K 80 4.5 $39.99
$27.99
~LL312AW3 PAR30L 12W E26 (40) 30K 12W 40°700 35,000 3000K 80 4.5 $39.99
$27.99
LUMA® PAR38 DIMMABLE (110-120V 50/60 Hz - Replaces 90W Quartz Halogen Incandescent)
~LP420AF3 PAR38 18.5W E26 (22) 30K 18.5W 22°1200 35,000 3000K 80 5.0 $34.99
$29.99
(excludes linear fluorescent lamps and Cree
®
LED Lamps on p.38)
Volume discounts available
for purchases of 100+ lamps
LED Lamps
WARNINGS & CAUTIONS
• Turn off power before changing lamp
Risk of electric shock
• Do not use in enclosed fixtures or fixtures without air flow
• Do not use in outdoor fixtures
• Suitable for use in damp locations
• For MR16 lamps, remove cover glass in track or recessed fixtures
While Supplies
Last
Free Shipping on Orders Over $500
40
LED FLEXIBLE STRIP LIGHTING
3500K SOFT OUTPUT 3500K HIGH OUTPUT 6500K HIGH OUTPUT
LED Cable is ideal for creating the perfect mood
in places where you need just a little bit of
light such as cabinets or coves. The warm color
temperature creates an elegant look at
an affordable price.
When you need just a little more light, choose
the 3500K High Output Cable. It's more than 2
times brighter than our Soft Output LED Cable,
while the warm light lets you add vibrant accent
lighting anywhere.
This is our brightest LED Cable yet, designed
to satisfy those who need the most light
output. The cool color temperature makes it a
sparkling choice for many retail and commercial
applications.
The easiest way to add task & accent lighting to any application
Get started with these
easy-to-use kits!
Save big with pre-packaged kits instead of purchasing parts separately!
LED Kit w/15W Driver
CAT.# E-CLK15W
$9290
LED Kit w/15W Driver & Dimmer
CAT.# E-CLK15DW
$10290
LED Kit w/30W Driver
CAT.# E-CLK30W
$18999
LED Kit w/30W Driver & Dimmer
CAT.# E-CLK30DW
$19990
(1) 12' LED Flexible Cable Lighting Strip
(3500K Soft Output)
(1) 15W LED Power Supply/Driver
(1) Inline On/Off Dimmer (E-CLK15DW only)
(1) 6" Power Supply Link
(1) 4" Jumper Cable
(1) 12" Jumper Cable
(1) End Cap
(10) Cable Brackets
(10) Edge Brackets
(1) Quick Start Installation Guide
Included:
(1) 24.5' LED Flexible Cable Lighting Strip
(3500K Soft Output)
(1) 308W LED Power Supply/Driver
(1) Inline On/Off Dimmer (E-CLK30DW only)
(4) 6" Power Supply Link
(1) 4-way Power Splitter
(1) 6" Jumper Cable
(2) 24" Jumper Cables
(1) L-connector (1) U-connector
(1) T-connector
(2) Channeling Strips
(10) End Caps
(20) Cable Brackets
(10) Edge Brackets
(1) Quick Start Installation Guide
Included:
LED Flexible Cable
Strip Kits
UL Listed for
wet locations
15W Driver
30W Driver
www.e-conolight.com 888.243.9445
LED Flexible Cable Strip
24-volt and UL Listed for wet locations
LENGTH CCT OUTPUT CRI LUMENS CAT. # PRICE
7.5'3500K Soft Output 80 68/foot E-CLC07WWS $39.90
12'3500K Soft Output 80 68/foot E-CLC12WWS $74.90
24.5'3500K Soft Output 80 68/foot E-CLC24WWS $1 1 9.90
49.5'3500K Soft Output 80 68/foot E-CLC49WWS $249.90
82'3500K Soft Output 80 68/foot E-CLC82WWS $399.90
32'3500K High Output 80 177/foot E-CLC32WWH $228.90
32'6500K High Output 72 191/foot E-CLC32CWH $228.90
41
3. POWER SUPPLY LINK & END CAPS
One Power Supply Link is required for every run of LED
cable and connects it to the power supply.
End caps are necessary to protect the end of LED cable
that is not connected to a connector.
Power Supply/Driver–UL Listed
Wet listed, 6.5' power cord, 39" power supply cord, available in three wattages.
LED FLEXIBLE STRIP LIGHTING
W
E
T
L
I
S
T
E
D
W
E
T
L
I
S
T
E
D
Required for every new installation
1. POWER SUPPLY
Select the power supply that has the capacity for all
of the cable in your installation. More than one power
supply may be needed.
2. LED FLEXIBLE CABLE
Choose the length of cable that is needed for your
installation. LED Flexible Cable can be cut
every 7 inches!
WATTAGE
MAX.
CABLE SOFT
OUTPUT
MAX. CABLE
HIGH OUTPUT CASE DIMENSIONS CAT. # PRICE
15W 12 feet 5.5 feet 4-3/4"L x 1-1/4"W x 1"H E-CLD15W $17.90
30W 25 feet 11.5 feet 6"L x 1-3/4"W x 1-3/8"H E-CLD30W $36.90
60W 50 feet 23 feet 7-3/8"L x 2-1/8"W x 1-5/8"H E-CLD60W $59.90
96W 82 feet 32 feet 8-3/8"L x 2-1/8"W x 1-5/8"H E-CLD96W $69.90
CAT.# E-CL/PS06W
Power Supply (PS)
Length: 6"
$190
CAT.# E-CL/ECW1
End Caps
$0.90 ea.
CAT.# E-CL/ECW
End Caps
$9.99 bag (10 per bag)
Our LED Flexible Cable Strip lighting is sold as a system and not recommended for use with other manufacturers' systems.
Field modification of product may lead to fixture malfunction or failure and could void the 3-year product warranty.
42 Free Shipping on Orders Over $500
LED FLEXIBLE STRIP LIGHTING
Connectors
Optional Accessories: Mounting Hardware:
Inline On/Off Dimmer
Provides on/off functionality
and the ability to dim LED
Cable system.
(Dims up to 96W)
Length: 16-1/4"
Housing: 2"W x 3"H x 7/8"D
CAT. # E-CL/IDSMW
PRICE: $13.90
Jumper Cable
Connects two LED Cable
strips together with a
flexible cable.
4" E-CL/JC04W
6" E-CL/JC06W
12" E-CL/JC12W
24" E-CL/JC24W
PRICE: $1.90
I-Connector
Connects two LED Cable
strips together in a
straight line or extends a
length of LED Cable.
Length: 1"
CAT. # E-CL/ICW
PRICE: $1.90
L-Connector
Connects two LED Cable
strips together at a right
angle.
Size: 1-1/4" square
CAT. # E-CL/LCW
PRICE: $1.90
U-Connector
Connects two LED Cable
strips parallel together
for twice the brightness.
Size: 1-3/8" x 5/8"
CAT. # E-CL/UCW
PRICE: $1.90
T-Connector
Connects three LED
Cable strips in a flexible
"T" shape.
Size: 4-5/8" x 2-5/8"
CAT. # E-CL/TCW
PRICE: $3.90
X-Connector
Connects four LED Cable
strips in a flexible "X"
shape.
Size: 4-5/8" square
CAT. # E-CL/XCW
PRICE: $3.90
4-way Power Splitter
Connects four LED Cable
strips to one power supply.
Requires four PS Links.
Length: 6-5/8"
CAT. # E-CL/PS4W
PRICE: $4.90
Cable Brackets
Installs with one screw
(by others). Barely visible
after LED Cable snaps in.
10 per bag.
CAT. # E-CL/CBC
PRICE: $3.90/bag
Edge Brackets
Installs with one screw
(by others). Use for flush
mount installations.
10 per bag.
CAT. # E-CL/EBC
PRICE: $3.90/bag
Channeling Strips
Installs with screws
(by others). LED Cable snaps
securely into place.
2 per box.
5/8"W x 39"L x 7/16"D each
CAT. # E-CLT03W
PRICE: $6.90
From power
supply Power
Supply Link LED
Cable
Female-
to-Male
Extension
Power
Supply Link Power
Supply Link LED
Cable
LED
Cable
Male-
to-Male
Extension
Take Your LED Cable Installations Even Farther!
FEMALE-TO-MALE-EXTENSION
These extensions let you start your run of LED Cable longer
than the Power Supply's 39-inch cord allows.
Each run of LED Cable supports a maximum of 15 feet of
extension.
CAT.# E-CL/FMX05W
5 feet
$390
CAT.# E-CL/FMX15W
15 feet
$590
MALE-TO-MALE-EXTENSION
These extensions let you have breaks in your LED Cable run
longer than the Jumper Cables allow.
Each run of LED Cable supports a maximum of 15 feet of
extension.
CAT.# E-CL/MMX05W
5 feet
$390
CAT.# E-CL/MMX15W
15 feet
$590
43
www.e-conolight.com 888.243.9445
LED EXIT & EMERGENCY
LED Exit Sign/
Emergency Light with
Battery Backup
LED Exit Sign with
Battery Backup
Applications: For general purpose exit identification and
emergency lighting in indoor commercial,
retail, or industrial applications
Dimensions: 9.0"H x 26.0"W x 4.0"D (Width includes heads
fully extended, Depth includes mounting plate)
Weight: 4.1 lbs., 4.2 lbs. (with Battery Backup)
Input Voltage: 120V or 277V
Ambient Temperature Rating: 32°F-104°F
Applications: For general purpose exit identification
in indoor commercial, retail, or industrial
applications
Dimensions: 7.125"H x 11.625"W x 1.625"D
Weight: 2.4 lbs.
Input Voltage: 120V or 277V
Ambient Temperature Rating: 32°F-104°F
* Remote unit will run up to 3 single LED remote heads
DESCRIPTION CAT.# ENERGY
CONSUMPTION PRICE
Red Letters
Single/Double Face E-XCL2RW 3.7W at 120V
3.8W at 277V $29.99
Green Letters
Single/Double Face E-XCL2GW 3.7W at 120V
3.8W at 277V $29.99
Red Letters with
Remote Capability*
Single/Double Face E-XCL2RRCW 3.4W at 120V
3.6W at 277V $35.99
Green Letters with
Remote Capability*
Single/Double Face E-XCL2GRCW 3.0W at 120V
3.2W at 277V $35.99
DESCRIPTION CAT.# ENERGY
CONSUMPTION PRICE
Red Letters
Single/Double Face E-XPL2RBW 0.8W $13.99
Green Letters
Single/Double Face E-XPL2GBW 0.8W $13.99
Features:
• Includes 2 adjustable 1W LED lighting heads
• Letters on sign are 6" tall
• Easy-snap mounting canopy included for top
or end mounting
• Universal knockout pattern on back plate for
wall mount
• Mounting hardware included
• Sealed, 9.6V maintenance-free nickel
cadmium battery backup (90 min.)
• Battery recharges within 24 hours via
internal solid-state, two-rate charger
• Charge/Power on indicator LED
• Push-to-test switch
• Easy to remove and replace chevrons
• Injection-molded, 5VA flame retardant
thermoplastic housing
• Remote-capable unit can accommodate
3 watts
• UL Listed for damp locations
• Meets UL924, NFPA 101 Life Safety Code,
NEC, OSHA codes
• 5-year limited warranty on all Exit &
Emergency fixtures with nickel cadmium
batteries
Features:
• Letters on sign are 6" tall
• Easy-snap mounting canopy included for top
or end mounting
• Universal knockout pattern on back plate
for wall mount
• Mounting hardware included
• Sealed, 1.2V maintenance-free nickel
cadmium battery backup (90 min.)
• Battery recharges within 24 hours via
internal solid-state, two-rate charger
• Charge/Power on indicator LED
• Push-to-test switch
• Easy to remove and replace chevrons
• Injection-molded, 5VA flame retardant
thermoplastic housing
• UL Listed for Damp Locations
• Meets UL924, NFPA 101 Life Safety Code,
NEC, OSHA codes
• 5-year limited warranty on all Exit &
Emergency fixtures with nickel cadmium
batteries
44 Free Shipping on Orders Over $500
Visit us online
for our complete
Exit & Emergency line
DESCRIPTION CAT.# ENERGY
CONSUMPTION PRICE
Red Letters
Single Face E-XEL1RBCA 3.6W at 120V
4W at 277V $34.99
Green Letters
Single Face E-XEL1GBCA 3.6W at 120V
4W at 277V $34.99
Red Letters
Double Face E-XEL2RBMA 3.6W at 120V
4W at 277V $44.99
Green Letters
Double Face E-XEL2GBMA 3.6W at 120V
4W at 277V $44.99
DESCRIPTION CAT.# ENERGY
CONSUMPTION PRICE
Red Letters
Single Face E-XELR1RBCA 3.6W at 120V
4W at 277V $52.99
Green Letters
Single Face E-XELR1GBCA 3.6W at 120V
4W at 277V $52.99
Red Letters
Double Face E-XELR2RBMA 3.6W at 120V
4W at 277V $62.99
Green Letters
Double Face E-XELR2GBMA 3.6W at 120V
4W at 277V $62.99
Features:
• Letters on sign are 6" tall
• Easy-snap mounting canopy included for top
or end mounting
• Mounting hardware included
• Clear, acrylic single face or acrylic double
face with
factory installed silver insert
• Sealed, 4.8V maintenance-free nickel
cadmium battery backup (90 min.)
• Battery recharges within 24 hours via
internal solid-state, two-rate charger
• Charge/Power on indicator LED
• Push-to-test switch
• Injection-molded, 5VA flame retardant
thermoplastic silver housing
• Self-adhesive chevrons and guide template
included
• Bi-color LED indicator alerts occupant to
battery status
• (green-normal, red-check battery)
• UL Listed for damp locations
• Meets UL924, NFPA 101 Life Safety Code,
NEC, OSHA codes
• 5-year limited warranty on all Exit &
Emergency fixtures with nickel cadmium
batteries
Features:
• Letters on sign are 6" tall
• Mounting hardware included
• Compatible with drywall or drop ceilings (bar
hangers included)
• Housing constructed with durable aluminum
• Clear acrylic single face or acrylic double
face with factory installed silver insert
• Sealed, 4.8V maintenance-free nickel
cadmium battery backup (90 min.)
• Battery recharges within 24 hours via
internal solid-state, two-rate charger
• Charge/Power on indicator LED
• Push-to-test switch
• Self-adhesive chevrons and guide template
included
• Trim assembly is detachable from below to
easily allow for servicing
or maintenance
• UL Listed for damp locations
• Meets UL924, NFPA 101 Life Safety Code,
NEC, OSHA codes
• 5-year limited warranty on all Exit &
Emergency fixtures with nickel cadmium
batteries
LED Edgelit Exit Sign
with Battery Backup
LED Recessed
Edgelit Exit Sign with
Battery Backup
Applications: For general purpose exit identification in
indoor commercial, retail, or industrial
applications
Dimensions: 10.875"H x 13.875"W x 1.75"D
Weight: 3.75 lbs.
Input Voltage: 120V or 277V
Ambient Temperature Rating: 32°F-122°F
Applications: For general purpose exit identification in
indoor commercial, retail, or industrial
applications
Dimensions: 7.6875"H x 12.625"W (Sign Face)
4.125"H x 15.75"W (Trim Plate)
3.25"H x 14.5625"W x 3.125"D (Housing)
Weight: 7.35 lbs. (Single Face)
7.5 lbs. (Double Face)
Input Voltage: 120V or 277V
Ambient Temperature Rating: 32°F-122°F
LED EXIT & EMERGENCY
45
www.e-conolight.com 888.243.9445
LED Standard
Emergency Light &
Remote Capable Unit
LED Low-Profile
Emergency Light
LED Wet-Listed
Emergency Light
Applications: For general purpose emergency lighting in
indoor commercial, retail, or industrial
applications - available also with the flexibility
of additional remote locations
Dimensions: 4.25"H x 14.625"W x 3.75"D
5.0"H x 15.2"W x 3.25"D (Remote Capable)
Weight: 1.7 lbs.
2.0 lbs. (Remote Capable)
Input Voltage: 120V or 277V
Ambient Temperature Rating: 32°F-122°F
Applications: For general purpose emergency lighting in
indoor commercial, retail, or industrial
applications
Dimensions: 2.25"H x 9.5"W x 4.625"D
Weight: 1.4 lbs.
Input Voltage: 120V or 277V
Ambient Temperature Rating: 32°F-122°F
Applications: For general purpose emergency lighting in
indoor commercial, retail, or industrial
applications
Dimensions: 10.5"H x 6.125"W x 3.625"D
Weight: 4.65 lbs.
Input Voltage: 120V or 277V
Ambient Temperature Rating : 32°F-122°F
-40°F-122°F (Cold Location)
Also available in
White Finish
DESCRIPTION CAT.# ENERGY
CONSUMPTION PRICE
Standard Emergency
Light w/2 adjustable
heads E-XML1W 1.8W at 120V and 277V $15.99
2.1W Emergency Light
3.6V Remote
Capable*
E-XML1RCW 2.1W at 120V and 277V $21.99
DESCRIPTION CAT.# ENERGY
CONSUMPTION PRICE
Adjustable Low-Profile
Emergency Light E-XML2W 2.1W at 120V and 277V $12.99
DESCRIPTION CAT.# ENERGY
CONSUMPTION PRICE
Wet-Listed
Emergency Light E-XML4WZ
(Dk. Bronze)
2.7W at 120V, 2.8W at 277V
CL: 2.9W at 120V, 3W at 277V $68.99
Wet-Listed
Emergency Light E-XML4WW
(White)
2.7W at 120V, 2.8W at 277V
CL: 2.9W at 120V, 3W at 277V $68.99
Wet-Listed Cold Location
Emergency Light E-XML4CWZ
(Dk. Bronze)
2.7W at 120V, 2.8W at 277V
CL: 2.9W at 120V, 3W at 277V $84.99
Wet-Listed Cold Location
Emergency Light E-XML4CWW
(White)
2.7W at 120V, 2.8W at 277V
CL: 2.9W at 120V, 3W at 277V $84.99
Features:
• 3-watt, 3.6V remote capability
• (E-XML1RCW only)
• Sealed, 3.6V maintenance-free nickel
cadmium battery backup (90 min.)
• Quick-connect back plate makes surface
mounting to standard J-box easy; also snaps
into place making electrical connections
• Can be wall or ceiling mounted
• Top knockout for conduit applications
• Injection-molded, 5VA flame retardant
thermoplastic housing
• UL Listed for damp locations
• Meets UL924, NFPA 101 Life Safety Code,
NEC, OSHA codes
• 5-year limited warranty on all Exit &
Emergency fixtures with nickel cadmium
batteries
Features:
• Sealed, 3.6V maintenance-free nickel
cadmium battery backup (90 min.)
• Quick-Connect back plate makes surface
mounting to standard J-box easy; also snaps
into place making electrical connections
• Can be wall or ceiling mounted
• Top knockout for conduit applications
• Injection-molded, 5VA flame retardant
thermoplastic housing
• UL Listed for damp locations
• Meets UL924, NFPA 101 Life Safety Code,
NEC, OSHA codes
• 5-year limited warranty on all Exit &
Emergency fixtures with nickel cadmium
batteries
Features:
• Die-cast aluminum housing with durable
powder-coated finish
• Sealed, 4.8V maintenance-free nickel
cadmium battery provides 90 minutes of
emergency operation
• Includes back plate for wall mount -
universal knockout pattern on back plate
provdes for easy installation over most
standard junction boxes
• Fully gasketed
• UL Listed for wet locations
• 5-year limited warranty on all Exit &
Emergency fixtures with nickel cadmium
batteries
* Remote unit will run up to 3 single LED remote heads
LED EXIT & EMERGENCY
46 Free Shipping on Orders Over $500
LED Recessed
Emergency Light
Applications: For general purpose emergency lighting
in indoor commercial, retail, or industril
applications
Dimensions: 9.25"H x 13.25"W x 10.0"D (Width includes
mounting clips, Depth is only faceplate)
Weight: 4.0 lbs. Input Voltage: 120V or 277V
Ambient Temperature Rating: 77°F
Features:
• Sealed, 6V maintenance-free lead-acid battery backup (90 min.)
• Compatible with drywall or drop ceilings (bar hangers included)
• Trim plate constructed of rugged 20-gauge steel
• UL Listed for dry locations
• 5-year limited warranty on all housing and electronics for Exit & Emergency fixtures with lead acid
batteries (5-year pro-rated warranty on lead acid batteries)
Features:
• Housing constructed of durable 20-gauge
steel
• Neutral white finish
• 20W, 6V remote capability
• Runs up to 8 hours without remote heads
• Sealed, 6V maintenance-free lead acid
battery backup (90 min.)
• Knockouts on back for wall mount
• Top and side knockouts for conduit
applications
• UL Listed for damp locations
• 5-year limited warranty on all housing and
electronics for Exit & Emergency fixtures
with lead acid batteries (5-year pro-rated
warranty on lead acid batteries)
DESCRIPTION CAT.# ENERGY
CONSUMPTION PRICE
27W Emergency Light
6V Remote Capable*E-X1ML1006 11W at 120V and 277V $69.99
DESCRIPTION CAT.# PRICE
1W Single Remote Head E-XHL1DW $7.99
1W Double Remote Head
(2W Total) E-XHL2DW $17.99
DESCRIPTION CAT.# PRICE
1W Single Remote Head
(Wet-Listed) E-XHL1WG $11.99
1W Double Remote Head
(Wet-Listed, 2W Total) E-XHL2WG $19.99
DESCRIPTION CAT.# ENERGY
CONSUMPTION PRICE
Recessed Emergency
Light E-XML3W 5W at 120V and 277V $47.99
27W Emergency Light,
6V Remote-Capable
Applications: For general purpose emergency lighting
in indoor commercial, retail, or industrial
applications with the flexibility of
additional remote locations
Dimensions: 12.375"H x 11.375"W x 2.5"D
Weight: 10.05 lbs. Input Voltage: 120V or 277V
Ambient Temperature Rating: 68°F-122°F
Dimensions:
4.875"H x 5.875"W x 4.5"D
Weight: 0.7 lbs.
Color: White
Dimensions:
5"H x 8.5"W x 4.5"D
Weight: 1.0 lbs.
Color: White
Dimensions:
6.625"H x 4.5"W x 4.5"D
Weight: 1.3 lbs.
Color: Grey
Dimensions:
7.0"H x 10.375"W x 4.5"D
Weight: 2.3 lbs.
Color: Grey
Features:
• Voltage-regulated design allows for heads to
be used with 3.6V, 6V & 9V DC sources
• Suitable for wall or ceiling mount
• Universal mounting base mounts to single-
gang switch box
• Meets UL924, NFPA 101 Life Safety Code, NEC,
OSHA codes
• 5-year limited warranty on all Exit &
Emergency fixtures with nickel cadmium
batteries
• Indoor units are injection-molded, 5VA
flame retardant thermoplastic, sealed
and gasketed in white finish
• Outdoor units are die-cast aluminum,
sealed and gasketed in grey finish
Remote Heads - Multi Volt
* Remote unit will run up to 20 single LED remote heads, or 10 double LED remote heads
LED EXIT & EMERGENCY
47
www.e-conolight.com 888.243.9445
LINEAR FLUORESCENT
For pricing &
availability of other
configurations,
please call Customer
Service at
888.243.9445
Linear Fluorescent
Applications: Warehouses, industrial and retail sites
Note: Fixtures must be mounted a minimum of 7.5" below
ceiling
Emergency Ballasts: Field-installable Plug-N-Go
emergency ballast option available
for 120V or 277V fixtures only
• Easy field installation & maintenance
of emergency ballasts
• For use with E-conolight Linear Fluorescent
fixtures only
• Will operate one lamp for 90 minutes
• Fixture must be purchased with "E" option,
ballast required
• Factory pre-wired for easy Plug-N-Go field
installation
• UL Listed 384 emergency ballast
CAT.# E-LNACLEB08D
T5HO & T8
800 initial lumens
$9990
CAT.# E-LNACLEB14D
T5HO
1150 initial lumens
(Not for use on T8)
$12990
CAT.# E-LNACLEB30D
T5HO & T8
2700 initial lumens
$33990
4-Lamp Decorative (page 49)
All linear lamp types
CAT.# E-LNACRCPT31 (120V, 3-Wire, NEMA L5-15R)
CAT.# E-LNACRCPT32 (277V, 3-Wire, NEMA L7-15R)
CAT.# E-LNACRCPT34 (208/240V, 3-Wire, NEMA L6-15R)
Locking-Type Receptacle (3-blade twist-lock)
$490
Locking-Type Receptacle (4-blade twist-lock)
CAT.# E-LNACRCPT2 (277V, 4-wire, emergency units only, NEMA L16-20R)
$1190
CAT.# E-LNACRCPT1 (120V, 4-wire, emergency units only, NEMA L14-20R)
$1090
CAT.# E-LPWG4
Steel wire guard (white)
Mounting hardware included
Grid pattern of wires is 2"x2.5"
$2290
CAT.# E-LNWG6
Steel wire guard (white)
Retention clips secure wire guard to fixture
Hardware included
Grid pattern of wires is 2.375"x2.375"
$2290
CAT.# E-LNACSC5
Mounting/Safety cable
Cable Length: 5-feet, field adjustable
Note: Requires 2 per fixture if used for mounting
$490
CAT.# E-LPLENS4
Flat clear acrylic lens with
white painted steel end covers
$5990
Accessories (Available with fixture purchase only):
6-Lamp (page 50-52) & 8-Lamp (page 53)
Common Features:
• High efficiency (95% Total Reflectance)
MIRO 4™ specular reflector provides
medium distribution
• High reflectance (94% Total Reflectance)
white painted reflectors provide wide light
distribution
• T5HO = 120V-277V programmed start
electronic universal voltage ballast
• T8/P8 = 120V-277V instant start GE®
UltraMax® HIgh Efficiency Ballast
• Includes 2 wire-form hangers for mounting
• Access over 3/4" conduit and wire entry for
hard wiring
• 54W T5HO Luma® Lamps installed available
• 32W Standard (T8) or Premium (P8) GE®
Lamps available installed
• Do not install in environments that contain
airborne corrosive agents such as chemical
solvents or cutting fluids as they can cause
sockets to deteriorate
• With motion sensor: Switch Selectable Low
Mode ("All Off" or "Partial Off" = 2 lamps off)
• 5-year limited warranty on fixture and
electrical components
48 Free Shipping on Orders Over $500
LINEAR FLUORESCENT
Factory installed ballast
disconnect to met 2008 NEC
article 410.130(G). Standard
on all hardwire fixtures
without emergency ballast.
4-Lamp T5HO
Compact Linear
Fluorescent
Applications: Warehouses, industrial and retail sites
Note: Fixtures must be mounted a minimum of 7.5"
below ceiling
Dimensions: 48.6"L x 18"W
Comparable to: 250W MH Low Bay
Features:
• Supplied with white reflector
• Quality die-formed galvanized steel ballast
housing and cover
• 120-277V electronic universal voltage
ballasts
• Includes two wire-form hangers for mounting
• Access cover for 3/4" conduit and wire entry
for hard wiring
• Minimum starting temperature, 0˚F
• Optimum starting temperature, 40˚F+
• 18" wide design is suitable for use in
applications with sprinkler systems installed
in accordance with NFPA 13 and Factory Mutual
codes
• Do not install in environments that contain
airborne corrosive agents such as chemical
solvents or cutting fluids as they can cause
sockets to deteriorate.
• UL Listed for damp locations
• 5-year fixture warranty
Compact design with folding
arms for ease of transportation
and on the job storage.
Folding arms lock in place,
no tools required.
CAT.# E-ACSC5 Mounting Safety Cable (compatible with E-LL6 Series, p.37)
Cable Length: 5', field adjustable.
Note: Requires 2 per fixture if used for mounting
$490
CAT.# E-LFK3S
Motion Sensor Kit with Hi-Lo Selector Switch
Converts E-LF34X54U to provide 360 Motion Sensing
Switch Selectable Low Mode ("All Off" or "Partial Off" = 2 Lamps)
Prewired harness for ease of installations - simple Plug-N-Go
Adjustable Low Mode Time Delay
$5990
CAT.# E-1CP61S (120V) (compatible with E-LL6 Series, p.37)
6-foot cord with straightblade plug
Strain relief included
$390
CAT.# E-1CP61 (120V) (compatible with E-LL6 Series, p.37)
CAT.# E-1CP62 (277V) (compatible with E-LL6 Series, p.37)
CAT.# E-1CP64 (208V/240V) (compatible with E-LL6 Series, p.37)
6-foot cord with 3 blade twist-lock plug
Strain relief included
$490
CAT.# E-2CP61 (120V)
CAT.# E-2CP62 (277V)
6-foot cord with 4 blade twist-lock plug for emergency ballast
Strain relief included
$1890
Accessories (Available with fixture purchase only):
CAT.# E-ACLBP08D
800 inital lumens
$8990
CAT.# E-ACLBP14D
1400 inital lumens
$12990
Emergency Ballasts:
DESCRIPTION CAT.# PRICE
4-Lamp T5HO E-LF34X54U $79.90
4-Lamp T5HO - Skid Pack
(30 Fixtures at $74.90 ea.)
*$150 total savings or $5
per fixture*
E-LF34X54U30 $2247.00
Lamps ordered
separately,
see page 101.
49
www.e-conolight.com 888.243.9445
LINEAR FLUORESCENT
CAT.# E-ACSC5 Mounting Safety Cable (compatible with E-LL6 Series, p.37)
Cable Length: 5', field adjustable.
Note: Requires 2 per fixture if used for mounting
$490
See page 47 for accessories
4-Lamp Decorative
Linear Fluorescent
Applications: Warehouses, industrial and retail sites
Note: Fixtures must be mounted a minimum of 7.5"
below ceiling
Dimensions: 49.3"L x 21"W x 3.5"H
All T5HO lamps are TCLP compliant
Additional Features:
• Durable injection molded thermoplastic end caps
• 21" wide design is suitable for use in applications with sprinkler systems installed in accordance
with NFPA 13 and Factory Mutual codes
• With motion sensor: Switch Selectable Low Mode
("All Off" or "Partial Off" = 2 lamps off)
Typical Mounting Height: 15 to 30 feet
Comparable to: 250W Probe Start MH High Bay
T5HO High Bay Specular Reflector
Typical Mounting Height: 12 to 25 feet
Comparable to: 250W Probe Start MH Low Bay
T5HO Low Bay White Reflector
CAT.# REFLECTOR VOLTAGE MOTION
SENSOR
EMERGENCY
BALLAST LAMPS*1 - 9*10 - 19 20 - 29 30 - 59 60 +
PER UNIT PRICE
E-LP4T5S2KN0 Specular 3-Wire 277V √– – $157.90 $137.90 $125.90 $118.90 $112.90
E-LP4T5S2NN4 Specular 3-Wire 277V – – 4100K $123.90 $105.90 $94.90 $88.90 $84.90
E-LP4T5S2NN5 Specular 3-Wire 277V – – 5000K $123.90 $105.90 $94.90 $88.90 $84.90
E-LP4T5SSKN0 Specular 3-Wire 120V Straight Blade √– – $157.90 $137.90 $125.90 $118.90 $112.90
E-LP4T5SSNN4 Specular 3-Wire 120V Straight Blade – – 4100K $123.90 $105.90 $94.90 $88.90 $84.90
E-LP4T5SSNN5 Specular 3-Wire 120V Straight Blade – – 5000K $123.90 $105.90 $94.90 $88.90 $84.90
E-LP4T5SUKN0 Specular Universal √– – $152.90 $132.90 $120.90 $113.90 $107.90
E-LP4T5SUNN4 Specular Universal – – 4100K $118.90 $100.90 $89.90 $83.90 $79.90
E-LP4T5SUNN5 Specular Universal – – 5000K $118.90 $100.90 $89.90 $83.90 $79.90
E-LP4T5W2KN0 White 3-Wire 277V √– – $147.90 $127.90 $115.90 $108.90 $102.90
E-LP4T5W2NN4 White 3-Wire 277V – – 4100K $113.90 $95.90 $84.90 $78.90 $74.90
E-LP4T5W2NN5 White 3-Wire 277V – – 5000K $113.90 $95.90 $84.90 $78.90 $74.90
E-LP4T5WSKN0 White 3-Wire 120V Straight Blade √– – $147.90 $127.90 $115.90 $108.90 $102.90
E-LP4T5WSNN4 White 3-Wire 120V Straight Blade – – 4100K $113.90 $95.90 $84.90 $78.90 $74.90
E-LP4T5WSNN5 White 3-Wire 120V Straight Blade – – 5000K $113.90 $95.90 $84.90 $78.90 $74.90
E-LP4T5WUKN0 White Universal √– – $142.90 $122.90 $110.90 $103.90 $97.90
E-LP4T5WUNN4 White Universal – – 4100K $108.90 $90.90 $79.90 $73.90 $69.90
E-LP4T5WUNN5 White Universal – – 5000K $108.90 $90.90 $79.90 $73.90 $69.90
* Fixtures without lamps included, see page 101 to order lamps separately
* Quantities less than 4 are shipped Parcel
50 Free Shipping on Orders Over $500
LINEAR FLUORESCENT
Applications: Warehouses, industrial and retail sites
Note: Fixtures must be mounted a minimum of 7.5"
below ceiling
Dimensions: 48.8"L x 24"W x 3.3"H
6-Lamp Linear
Fluorescent
All T5HO lamps are TCLP compliant
Additional Features:
• 24" wide design is suitable for use in applications with sprinkler systems installed in accordance
with NFPA 13 and Factory Mutual codes
• With motion sensor: Switch Selectable Low Mode
("All Off" or "Partial Off" = 2 lamps off)
Typical Mounting Height: 25 to 45 feet
Comparable to: 400W Probe Start Metal Halide High Bay
T5HO High Bay Specular Reflector
CAT.# REFLECTOR VOLTAGE MOTION
SENSOR
EMERGENCY
BALLAST*LAMPS*1 - 11*12 - 23 24 - 35 36 - 107 108 +
PER UNIT PRICE
E-LN6T5S2KN0 Specular 3-Wire 277V √– – $174.90 $150.90 $136.90 $129.90 $122.90
E-LN6T5S2NE0 Specular 3-Wire 277V –√–$140.90 $121.90 $108.90 $102.90 $97.90
E-LN6T5S2NN0 Specular 3-Wire 277V – – – $122.90 $105.90 $93.90 $87.90 $83.90
E-LN6T5S2NN4 Specular 3-Wire 277V – – 4100K $140.90 $121.90 $108.90 $102.90 $97.90
E-LN6T5S2NN5 Specular 3-Wire 277V – – 5000K $140.90 $121.90 $108.90 $102.90 $97.90
E-LN6T5S9NE0 Specular 4-Wire 277V –√–$122.90 $105.90 $93.90 $87.90 $83.90
E-LN6T5SDNE0 Specular Dual Voltage (120/277V) –√–$117.90 $100.90 $88.90 $82.90 $78.90
E-LN6T5SSKN0 Specular 3-Wire 120V Straight Blade √– – $174.90 $150.90 $136.90 $129.90 $122.90
E-LN6T5SSNN0 Specular 3-Wire 120V Straight Blade – – –$122.90 $105.90 $93.90 $87.90 $83.90
E-LN6T5SSNN4 Specular 3-Wire 120V Straight Blade – – 4100K $140.90 $121.90 $108.90 $102.90 $97.90
E-LN6T5SSNN5 Specular 3-Wire 120V Straight Blade – – 5000K $140.90 $121.90 $108.90 $102.90 $97.90
E-LN6T5SUKN0 Specular Universal √––$169.90 $145.90 $131.90 $124.90 $117.90
E-LN6T5SUNN0 Specular Universal – – –$117.90 $100.90 $88.90 $82.90 $78.90
E-LN6T5SUNN4 Specular Universal – – 4100K $135.90 $116.90 $103.90 $97.90 $92.90
E-LN6T5SUNN5 Specular Universal – – 5000K $135.90 $116.90 $103.90 $97.90 $92.90
* Emergency ballast available for certain configurations. Cost of ballast not included, see page 47.
* Fixtures without lamps included, see page 101 to order lamps separately
* Quantities less than 4 are shipped Parcel
Shown with
motion sensor
See page 47 for accessories
51
www.e-conolight.com 888.243.9445
LINEAR FLUORESCENT
All T5HO lamps are TCLP compliant
Additional Features:
• 24" wide design is suitable for use in applications with sprinkler systems installed in accordance
with NFPA 13 and Factory Mutual codes
• With motion sensor: Switch Selectable Low Mode
("All Off" or "Partial Off" = 2 lamps off)
Shown with
motion sensor
Typical Mounting Height: 20 to 35 feet
Comparable to: 400W Probe Start Metal Halide Low Bay
T5HO Low Bay White Reflector
CAT.# REFLECTOR VOLTAGE MOTION
SENSOR
EMERGENCY
BALLAST*LAMPS*1 - 11*12 - 23 24 - 35 36 - 107 108 +
PER UNIT PRICE
E-LN6T5W2KN0 White 3-Wire 277V √– – $164.90 $140.90 $126.90 $119.90 $112.90
E-LN6T5W2NN0 White 3-Wire 277V – – – $112.90 $95.90 $83.90 $77.90 $73.90
E-LN6T5W2NN4 White 3-Wire 277V – – 4100K $130.90 $111.90 $98.90 $92.90 $87.90
E-LN6T5W2NN5 White 3-Wire 277V – – 5000K $130.90 $111.90 $98.90 $92.90 $87.90
E-LN6T5W9NE0 White 4-Wire 277V –√–$112.90 $95.90 $83.90 $77.90 $73.90
E-LN6T5WDNE0 White Dual Voltage (120/277V) –√–$107.90 $90.90 $78.90 $72.90 $68.90
E-LN6T5WSKN0 White 3-Wire 120V Straight Blade √– – $164.90 $140.90 $126.90 $119.90 $112.90
E-LN6T5WSNN0 White 3-Wire 120V Straight Blade – – –$112.90 $95.90 $83.90 $77.90 $73.90
E-LN6T5WSNN4 White 3-Wire 120V Straight Blade – – 4100K $130.90 $111.90 $98.90 $92.90 $87.90
E-LN6T5WSNN5 White 3-Wire 120V Straight Blade – – 5000K $130.90 $111.90 $98.90 $92.90 $87.90
E-LN6T5WUKN0 White Universal √––$159.90 $135.90 $121.90 $114.90 $107.90
E-LN6T5WUNN0 White Universal – – –$107.90 $90.90 $78.90 $72.90 $68.90
E-LN6T5WUNN4 White Universal – – 4100K $125.90 $106.90 $93.90 $87.90 $82.90
E-LN6T5WUNN5 White Universal – – 5000K $125.90 $106.90 $93.90 $87.90 $82.90
6-Lamp Linear
Fluorescent
Applications: Warehouses, industrial and retail sites
Note: Fixtures must be mounted a minimum of 7.5"
below ceiling
Dimensions: 48.8"L x 24"W x 3.3"H
* Emergency ballast available for certain configurations. Cost of ballast not included, see page 47.
* Fixtures without lamps included, see page 101 to order lamps separately
* Quantities less than 4 are shipped Parcel
See page 47 for accessories
52 Free Shipping on Orders Over $500
LINEAR FLUORESCENT
6-Lamp Linear
Fluorescent
Applications: Warehouses, industrial and retail sites
Note: Fixtures must be mounted a minimum of 7.5"
below ceiling
Dimensions: 48.8"L x 24"W x 3.3"H
All T8 lamps are TCLP compliant
Additional Features:
• 24" wide design is suitable for use in applications with sprinkler systems installed in accordance
with NFPA 13 and Factory Mutual codes
• With motion sensor: Switch Selectable Low Mode
("All Off" or "Partial Off" = 2 lamps off)
Typical Mounting Height: 20 to 35 feet
Comparable to: 250W to 400W Probe Start MH High Bay
T8 High Bay Specular Reflector
Typical Mounting Height: 15 to 30 feet
Comparable to: 250W to 400W Probe Start MH Low Bay
T8 Low Bay White Reflector
CAT.# REFLECTOR VOLTAGE MOTION
SENSOR
EMERGENCY
BALLAST LAMPS*1 - 11*12 - 23 24 - 35 36 - 107 108 +
PER UNIT PRICE
E-LN6T8S2KN0 Specular 3-Wire 277V √– – $179.90 $156.90 $142.90 $135.90 $129.90
E-LN6T8S2NN4 Specular 3-Wire 277V – – 4100K $114.90 $98.90 $87.90 $82.90 $79.90
E-LN6T8S2NN5 Specular 3-Wire 277V – – 5000K $114.90 $98.90 $87.90 $82.90 $79.90
E-LN6T8SSKN0 Specular 3-Wire 120V Straight Blade √– – $179.90 $156.90 $142.90 $135.90 $129.90
E-LN6T8SSNN4 Specular 3-Wire 120V Straight Blade – – 4100K $114.90 $98.90 $87.90 $82.90 $79.90
E-LN6T8SSNN5 Specular 3-Wire 120V Straight Blade – – 5000K $114.90 $98.90 $87.90 $82.90 $79.90
E-LN6T8SUKN0 Specular Universal √– – $174.90 $151.90 $137.90 $130.90 $124.90
E-LN6T8SUNN4 Specular Universal – – 4100K $109.90 $93.90 $82.90 $77.90 $74.90
E-LN6T8SUNN5 Specular Universal – – 5000K $109.90 $93.90 $82.90 $77.90 $74.90
E-LN6T8W2KN0 White 3-Wire 277V √– – $169.90 $146.90 $132.90 $125.90 $119.90
E-LN6T8W2NN4 White 3-Wire 277V – – 4100K $104.90 $88.90 $77.90 $72.90 $69.90
E-LN6T8W2NN5 White 3-Wire 277V – – 5000K $104.90 $88.90 $77.90 $72.90 $69.90
E-LN6T8WSKN0 White 3-Wire 120V Straight Blade √– – $169.90 $146.90 $132.90 $125.90 $119.90
E-LN6T8WSNN4 White 3-Wire 120V Straight Blade – – 4100K $104.90 $88.90 $77.90 $72.90 $69.90
E-LN6T8WSNN5 White 3-Wire 120V Straight Blade – – 5000K $104.90 $88.90 $77.90 $72.90 $69.90
E-LN6T8WUKN0 White Universal √– – $164.90 $141.90 $127.90 $120.90 $114.90
E-LN6T8WUNN4 White Universal – – 4100K $99.90 $83.90 $72.90 $67.90 $64.90
E-LN6T8WUNN5 White Universal – – 5000K $99.90 $83.90 $72.90 $67.90 $64.90
See page 47 for accessories
* Fixtures without lamps included, see page 101 to order lamps separately
* Quantities less than 4 are shipped Parcel LED AVAILABLE
See page 37
NEW!
53
www.e-conolight.com 888.243.9445
LINEAR FLUORESCENT
8-Lamp Linear
Fluorescent
Applications: Warehouses, industrial and retail sites
Note: Fixtures must be mounted a minimum of 7.5"
below ceiling
Dimensions: 48.8"L x 24"W x 3.3"H
Additional Features:
• 24" wide design is suitable for use in applications with sprinkler systems installed in accordance
with NFPA 13 and Factory Mutual codes
• With motion sensor: Switch Selectable Low Mode
("All Off" or "Partial Off" = 6 lamps off)
All T5H0 lamps are TCLP compliant
Typical Mounting Height: 30 to 45 feet
Comparable to: 400 Probe Start MH High Bay
T5H0 White Reflector
Typical Mounting Height: 35 to 45 feet
Comparable to: 400W Probe Start MH High Bay
T5H0 Specular Reflector
CAT.# REFLECTOR VOLTAGE MOTION
SENSOR
EMERGENCY
BALLAST LAMPS*1 - 11*12 - 23 24 - 35 36 - 107 108 +
PER UNIT PRICE
E-LN8T5S2KN0 Specular 3-Wire 277V √– – $204.90 $174.90 $157.90 $149.90 $141.90
E-LN8T5S2NN4 Specular 3-Wire 277V – – 4100K $170.90 $146.90 $130.90 $123.90 $117.90
E-LN8T5S2NN5 Specular 3-Wire 277V – – 5000K $170.90 $146.90 $130.90 $123.90 $117.90
E-LN8T5SSNN4 Specular 3-Wire 120V Straight Blade – – 4100K $170.90 $146.90 $130.90 $123.90 $117.90
E-LN8T5SSNN5 Specular 3-Wire 120V Straight Blade – – 5000K $170.90 $146.90 $130.90 $123.90 $117.90
E-LN8T5SUKN0 Specular Universal √– – $199.90 $169.90 $152.90 $144.90 $136.90
E-LN8T5SUNN4 Specular Universal – – 4100K $165.90 $141.90 $125.90 $118.90 $112.90
E-LN8T5SUNN5 Specular Universal – – 5000K $165.90 $141.90 $125.90 $118.90 $112.90
E-LN8T5W2KN0 White 3-Wire 277V √– – $194.90 $164.90 $147.90 $139.90 $131.90
E-LN8T5W2NN4 White 3-Wire 277V – – 4100K $160.90 $136.90 $120.90 $113.90 $107.90
E-LN8T5W2NN5 White 3-Wire 277V – – 5000K $160.90 $136.90 $120.90 $113.90 $107.90
E-LN8T5WSNN4 White 3-Wire 120V Straight Blade – – 4100K $160.90 $136.90 $120.90 $113.90 $107.90
E-LN8T5WSNN5 White 3-Wire 120V Straight Blade – – 5000K $160.90 $136.90 $120.90 $113.90 $107.90
E-LN8T5WUKN0 White Universal √– – $189.90 $159.90 $142.90 $134.90 $126.90
E-LN8T5WUNN4 White Universal – – 4100K $155.90 $131.90 $115.90 $108.90 $102.90
E-LN8T5WUNN5 White Universal – – 5000K $155.90 $131.90 $115.90 $108.90 $102.90
See page 47 for accessories
* Fixtures without lamps included, see page 101 to order lamps separately
* Quantities less than 4 are shipped Parcel
54 Free Shipping on Orders Over $500
22–24"H x 16"W x 16"D
Weight: 19-23 lbs.
Accessories: (Available with fixture purchase only)
16-inch High Bay Aluminum Reflector
Applications – Warehouses, industrial and retail sites. Typical Mounting Height: 18 to 40 feet
One mogul base lamp included;
(Quartz option) Both lamps included
PSMH 320-watt
Pulse-Start Metal Halide
CAT.# E-HB2P32Q
With Quartz option
CAT.# E-HB2P32QQ
Replacement lamp
CAT.# ~PS320BUO
$11999
$14999
$12.90
400-watt
Pulse-Start Metal Halide
CAT.# E-HB2P40Q
With Quartz option
CAT.# E-HB2P40QQ
Replacement lamp
CAT.# ~PS400BUO
$9999
$14999
$12.90
Quartz replacement lamp
CAT.# ~QZ100DC
$1.65
• 120/208/240/277-volt CWA ballast HPF
• Sturdy die-cast aluminum housing
• Adjustable lamp position
• Rugged 4kv porcelain open-rated socket
• Wiring compartment with adjustable leveling feature
• 16-inch spun aluminum reflector
• Mount using threaded 3/4" conduit (by others) or with hook & cord
accessory kit (see below)
• Maximum Ambient Temperature 35˚ C
• UL Listed for damp locations
• 1-year warranty
Note: Meets 2005 NEC code.
Note: Pulse start metal halide products supplied with open-rated lamp and
open-rated socket.
Note: Quartz standby option (delay-relay) includes 100W Quartz lamp.
Features:
Clear, gasketed tempered lens,
retention clips secure lens to
fixture. Hardware included.
Cannot be used with E-WG-A.
CAT.# E-LENSHB
$2990
Steel wire guard, retention clips
secure wire guard to fixture.
Hardware included.
Cannot be used with E-LENSHB.
CAT.# E-WG-A
$1290
6-foot Cord and Plug
with 3/4" Hook
(straight blade plug)
CAT.# E-2HCP61S
(120-volt)
$590
Locking-Type Receptacle (3 blade twist lock)
(120V, 3-wire,
NEMA L5-15R)
CAT.# E-ACRCPT31
(120-volt)
$490
(277V, 3-wire,
NEMA L7-15R)
CAT.# E-ACRCPT32
(277-volt)
$490
(208/240V, 3-wire,
NEMA L6-15R)
CAT.# E-ACRCPT34
(208/240-volt)
$490
Mounting/Safety cable
Cable Length: 5-feet,
field adjustable
CAT.# E-ACSC5
$490
6-foot Cord and Plug
with 3/4" Hook
(locking type plug)
CAT.# E-2HCP61
(120-volt)
CAT.# E-2HCP62
(277-volt)
CAT.# E-2HCP64
(208- or 240-volt)
$790
6-foot Cord -NO PLUG
with 3/4" Hook
CAT.# E-2HC6
$599
3/4" Hook only
CAT.# E-2HOOK
$290
LED
AVAILABLE
See pages
22-23
HIGH BAYS & LOW BAYS
NEW!
55
www.e-conolight.com 888.243.9445
HIGH BAYS & LOW BAYS
LED
AVAILABLE
See pages
22-23
16-inch High Bay Acrylic Prismatic Reflector
Applications – Warehouses, industrial and retail sites. Typical Mounting Height: 18 to 35
feet
22–24"H x 16"W x 16"D
Weight: 19-24 lbs.
• 120/208/240/277-volt CWA ballast HPF
• Sturdy die-cast aluminum housing
• Adjustable lamp position
• Rugged 4kv porcelain open-rated socket
• Wiring compartment with adjustable leveling feature
• 16-inch acrylic prismatic reflector
• Mount using threaded 3/4" conduit (by others) or with hook & cord
accessory kit (see below)
• Maximum Ambient Temperature 35˚ C
• UL Listed for damp locations
• 1-year warranty
• Do not install in environments that contain airborne corrosive agents
such as chemical solvents or cutting fluids as they can cause relfector to
deteriorate.
Note: Meets 2005 NEC code.
Note: Pulse start metal halide products supplied with open-rated lamp and
open-rated socket. (Fixture cannot be enclosed.)
Note: Quartz standby option (delay-relay) includes 100W Quartz lamp.
Features:
PSMH 250-watt
Pulse-Start Metal Halide
CAT.# E-PB2P25Q
With Quartz option
CAT.# E-PB2P25QQ
Replacement lamp
CAT.# ~PS250BUCO
$11999
$16999
$12.40
320-watt
Pulse-Start Metal Halide
CAT.# E-PB2P32Q
With Quartz option
CAT.# E-PB2P32QQ
Replacement lamp
CAT.# ~PS320BUCO
$12999
$17999
$12.90
400-watt
Pulse-Start Metal Halide
CAT.# E-PB2P40Q
With Quartz option
CAT.# E-PB2P40QQ
Replacement lamp
CAT.# ~PS400BUCO
$12999
$17999
$12.90
Quartz replacement lamp
CAT.# ~QZ100DC
$1.65
Accessories: (Available with fixture purchase only)
6-foot Cord and Plug
with 3/4" Hook
(straight blade plug)
CAT.# E-2HCP61S
(120-volt)
$590
Locking-Type Receptacle (3 blade twist lock)
(120V, 3-wire,
NEMA L5-15R)
CAT.# E-ACRCPT31
(120-volt)
$490
(277V, 3-wire,
NEMA L7-15R)
CAT.# E-ACRCPT32
(277-volt)
$490
(208/240V, 3-wire,
NEMA L6-15R)
CAT.# E-ACRCPT34
(208/240-volt)
$490
Steel wire guard, secured to
fixture with v-band.
Hardware included.
CAT.# E-WG-AP
$1690
One mogul base lamp included;
(Quartz option) Both lamps included
Mounting/Safety cable
Cable Length: 5-feet,
field adjustable
CAT.# E-ACSC5
$490
6-foot Cord and Plug
with 3/4" Hook
(locking type plug)
CAT.# E-2HCP61
(120-volt)
CAT.# E-2HCP62
(277-volt)
CAT.# E-2HCP64
(208- or 240-volt)
$790
6-foot Cord -NO PLUG
with 3/4" Hook
CAT.# E-2HC6
$599
3/4" Hook only
CAT.# E-2HOOK
$290
WHILE SUPPLIES LAST
NEW!
56 Free Shipping on Orders Over $500
20-1/2"H x 9"W x 9"D
Weight: 20 lbs.
Acrylic Prismatic Compact Fluorescent High Bay
Applications – Warehouses, industrial and retail sites. Typical Mounting Height: 10 to 18 feet
400-watt Construction Light
Applications – Work sites or any area needing temporary lighting. Typical Mounting Height: greater than 10 feet
17-3/8"H x 14"W x 14"D
Weight: 6 lbs.
One open rated mogul base
coated lamp included
*some state restrictions may apply
• 120/208/240/277-volt CWA ballast HPF
• Sturdy die-cast aluminum housing
• Rugged 4kv porcelain open rated socket
• Adjustable fixture leveling bracket
• Chrome-plated, steel wire guard
• Mount using threaded 3/4" conduit (by others) or with hook & cord
accessory kit
• UL Listed for damp locations
• 1-year warranty
Features:
• 120 through 277-volt Universal Electronic Ballast
• 14-inch acrylic prismatic reflector
• Heavy duty four-pin GX24q-5 socket accepts 57-watt
lamp (~CF57T4/41) or 70-watt lamp (by others)
• Mount using threaded 1/2" conduit (by others) or with
hook & cord accessory kit
• Sturdy die-cast aluminum housing
• Minimum starting temperature, -13˚F
• Optimum starting temperature, 50˚F+
• 1-year warranty
• UL Listed for damp locations
Features:
Accessories: (Available with fixture purchase only)
6-foot Cord and Plug
with 1/2" Hook
(straight blade plug)
CAT.# E-1HCP61S
(120-volt)
$590
6-foot Cord and Plug
with 1/2" Hook
(locking type plug)
CAT.# E-1HCP61
(120-volt)
CAT.# E-1HCP62
(277-volt)
CAT.# E-1HCP64
(208- or 240-volt)
$790
6-foot Cord -NO PLUG
with 1/2" Hook
CAT.# E-1HC6
$599
1/2" Hook Only
CAT.# E-1HOOK
$190
For Locking-Type Receptacle see pg 57
Accessories: (Available with fixture purchase only) For Locking-Type Receptacle see pg 57
6-foot Cord and Plug
with 3/4" Hook
(straight blade plug)
CAT.# E-2HCP61S
(120-volt)
$590
PSMH 400-watt
Pulse-Start Metal Halide
CAT.# E-HB5P40Q
Replacement lamp
CAT.# ~PS400BUCO
$9490
$12.90
One lamp included
CFL 57-watt Compact
Fluorescent
CAT.# E-PB1F57U
Replacement lamp
CAT.# ~CF57T4/41
$6390
$3.90
6-foot Cord and Plug
with 3/4" Hook
(locking type plug)
CAT.# E-2HCP61
(120-volt)
CAT.# E-2HCP62
(277-volt)
CAT.# E-2HCP64
(208- or 240-volt)
$790
6-foot Cord -NO PLUG
with 3/4" Hook
CAT.# E-2HC6
$599
3/4" Hook only
CAT.# E-2HOOK
$290
HIGH BAYS & LOW BAYS
LED AVAILABLE
See pages 22-23
NEW!
57
www.e-conolight.com 888.243.9445
HIGH BAYS & LOW BAYS
22–1/2"H x 16"W x 16"D
Weight: 21-24 lbs.
16-inch Low Bay
• 120/208/240/277-volt CWA ballast HPF
• Sturdy die-cast aluminum housing
• Rugged 4kv porcelain open-rated socket
• Wiring compartment with adjustable leveling feature
• 16-inch spun white aluminum reflector
• Includes drop acrylic lens
• Mount using threaded 3/4" conduit (by others) or with hook & cord
accessory kit (see below)
• Maximum Ambient Temperature 35˚ C
• UL Listed for damp locations
• 1-year warranty
Note: Meets 2005 NEC code.
Note: Quartz standby option (delay-relay) includes 100 Quartz lamp.
Applications – Warehouses, industrial and retail sites. Typical Mounting Height: 15 to 25 feet
PSMH 250-watt
Pulse-Start Metal Halide
CAT.# E-LB2P25Q
With Quartz option
CAT.# E-LB2P25QQ
Replacement lamp
CAT.# ~PS250BUO
$11999
$14490
$12.40
320-watt
Pulse-Start Metal Halide
CAT.# E-LB2P32Q
With Quartz option
CAT.# E-LB2P32QQ
Replacement lamp
CAT.# ~PS320BUO
$8999
$15490
$12.90
400-watt
Pulse-Start Metal Halide
CAT.# E-LB2P40Q
With Quartz option
CAT.# E-LB2P40QQ
Replacement lamp
CAT.# ~PS400BUO
$11999
$15490
$12.90
Quartz replacement lamp
CAT.# ~QZ100DC
$1.65
6-foot Cord and Plug
with 3/4" Hook
(straight blade plug)
CAT.# E-2HCP61S
(120-volt)
$590
Locking-Type Receptacle (3 blade twist lock)
(120V, 3-wire,
NEMA L5-15R)
CAT.# E-ACRCPT31
(120-volt)
$490
(277V, 3-wire,
NEMA L7-15R)
CAT.# E-ACRCPT32
(277-volt)
$490
(208/240V, 3-wire,
NEMA L6-15R)
CAT.# E-ACRCPT34
(208/240-volt)
$490
Accessories: (Available with fixture purchase only)
Features:
One mogul base lamp included;
(Quartz option) Both lamps included
Mounting/Safety cable
Cable Length: 5-feet,field
adjustable
CAT.# E-ACSC5
$490
6-foot Cord and Plug
with 3/4" Hook
(locking type plug)
CAT.# E-2HCP61
(120-volt)
CAT.# E-2HCP62
(277-volt)
CAT.# E-2HCP64
(208- or 240-volt)
$790
6-foot Cord -NO PLUG
with 3/4" Hook
CAT.# E-2HC6
$599
3/4" Hook only
CAT.# E-2HOOK
$290
58 Free Shipping on Orders Over $500
New Construction
Applications – For use in non-insulated ceilings or where insulation can be kept 3" from housing.
4" Low Voltage – Type Non-IC
• Ceiling cutout: 4-3/8"
• New Construction Plaster Frame: 7-5/8"W X 12-1/4"L
(magnetic transformer); 5-3/4"W x 8"L (electronic
transformer)
• Listed for eight (4 in-4 out) #12AWG (90˚C) through-
branch circuit conductors
• New Construction has five 1/2", one 3/4" and four
Romex® knockouts. Remodel has eight 1/2" and four
Romex® knockouts.
• Hanger bars allow housing to be positioned within 24"
joist span and designed to fit onto T-Bar spine.
• New Construction adjusts for ceilings up to 1-3/8"
thick. Remodel adjusts for ceilings from 3/8" to 5/8"
thick.
• For electronic transformers: 10W minimum lamp
wattage required for standard operation; 20W minimum
lamp wattage required for dimmed operation.
• UL listed for use in damp locations
• 2-year warranty
B
5-3/16"
(147.3mm)
1/2"
(12.7mm)
4-5/16"
(109mm)
10-38"
(263mm)
7-1/16"
(180mm)
A
CAT.# A B
E-RHN45E1TP 6-1/2" 4-5/16"
E-RHN4501TP 5-1/2" 4-5/16"
A
B
C
CAT.#
E-RHR45E1TP
E-RHR4501TP
A B C
14-5/16" 6-1/2" 4-5/16"
14-3/8" 5-5/8" 4-1/8"
Remodel
1 When dimming fixture, use dimmer rated for use with electronic transformer.
2 When dimming fixture, use dimmer rated for use with magnetic transformer.
3 LED MR16 lamps: remove cover glass in recessed fixtures.
12V MR16 Lamp (50W Max)
120V Dimmable Electronic Transformer1
CAT.# E-RHN45E1TP
$1790
12V MR16 Lamp (50W Max)
120V Dimmable Magnetic Transformer2
CAT.# E-RHN4501TP
$1640
12V MR16 Lamp (50W Max)
120V Dimmable Electronic Transformer1
CAT.# E-RHR45E1TP
$2240
12V MR16 Lamp (50W Max)
120V Dimmable Magnetic Transformer2
CAT.# E-RHR4501TP
$1890
Features:Trims:
Metal Baffle
White Metal Trim Ring
O.D. 4-7/8"
CAT.# E-T4316WH
$390
Gimbal
White Metal Trim Ring
O.D. 4-7/8"
CAT.# E-T4616WH
$390
Clear Reflector
White Metal Trim Ring
O.D. 4-7/8"
CAT.# E-T4216CL
$440
Pin Hole w/Black Baffle
White Metal Trim Ring
O.D. 4-7/8"
CAT.# E-T4100WH
$390
A
B
C
CAT.#
E-RHR45E1TP
E-RHR4501TP
A B C
14-5/16" 6-1/2" 4-5/16"
14-3/8" 5-5/8" 4-1/8"
B
5-3/16"
(147.3mm)
1/2"
(12.7mm)
4-5/16"
(109mm)
10-38"
(263mm)
7-1/16"
(180mm)
A
CAT.# A B
E-RHN45E1TP 6-1/2" 4-5/16"
E-RHN4501TP 5-1/2" 4-5/16"
LAMPS ORDERED SEPARATELY
LED LAMPS3, SEE PAGE 38
HALOGEN LAMPS, SEE PAGE 104
RECESSED
59
www.e-conolight.com 888.243.9445
RECESSED
5" Vertical Lamp Incandescent – Type IC
Applications – For use in insulated ceilings and can be in direct contact with insulation.
New Construction
• Ceiling cutout: 5-3/4"
• New Construction Plaster Frame: 7-1/16"W x 10-3/4"L
• Listed for eight (4 in-4 out) #12AWG (90˚C) through-
branch circuit conductors
• New Construction has five 1/2", one 3/4" and four
Romex® knockouts. Remodel has eight 1/2" and four
Romex® knockouts.
• Hanger bars allow housing to be positioned within 24"
joist span and designed to fit onto T-Bar spine.
• New Construction adjusts for ceilings up to 1-3/8"
thick. Remodel adjusts for ceilings from 3/8" to 5/8"
thick.
• Sealed and gasketed construction limits air exchange
between ceiling plenum and heated/air conditioned
areas.Performance tested to ASTM-E283
(Washington State)
• Meets State of California Title 24 requirements
• UL listed for use in damp locations (Listed for wet
locations with select trims)
• 2-year warranty
* When dimming fixtures with magnetic transformers, you must use a
dimmer rated for use with magnetic transformer.
3 LED MR16 lamps: remove cover glass in recessed fixtures.
Remodel
LAMPS ORDERED SEPARATELY
LED LAMPS3, SEE PAGE 38, HALOGEN LAMPS, SEE PAGE 105
One Lamp: 75W Max
CAT.# E-RIN5AT $790
One Lamp: 75W Max
CAT.# E-RIR5AT $760
Features:Trims:
Metal Baffle
PAR30L (50W Max)
White Self-Flanged Trim
Ring
O.D. 6-9/16"
CAT.# E-T5313WH
$490
Full Reflector, Clear
A19 (40W Max)
White Plastic Trim Ring
O.D. 6-9/16"
CAT.# E-T5200CL
$590
R-lamp Reflector, Clear
PAR30/R30 (75W Max)
White Plastic Trim Ring
O.D. 6-9/16"
CAT.# E-T5230CL
$590
Opal Glass Lens/w Refl.
A19 (40W Max)
Wet Location Listed
O.D. 6-9/16"
CAT.# E-T5506WH
$
1290
5-5/8"
(143mm)
7-3/4"
(196mm)
12-1/4"
(312mm)
7-1/2"
(191mm)
5-7/16"
(138mm)
60
More trims available at www.e-conolight.com/trims
6" Vertical Lamp CFL – Type Non-IC
New Construction
Remodel
(1) 26W/32W Double or Triple Tube CFL
CAT.# E-RFN632UTP $3999
(1) 26W/32W Double or Triple Tube CFL
CAT.# E-RFR632UTP $3999
• Ceiling cutout: 6-3/8"
• New Construction Plaster Frame: 7-1/8"W x 10-3/8"L
• Universal voltage, HPF electronic ballast with end of life
protection
• Minimum starting temperature 0˚F (-18˚C)
• Listed for eight (4 in-4 out) #12AWG (90˚C) through-
branch circuit conductors
• New Construction has five 1/2", one 3/4" and four
Romex® knockouts. Remodel has eight 1/2" and four
Romex® knockouts.
• Hanger bars allow housing to be positioned within 24"
joist span and designed to fit onto T-Bar spine.
• New Construction adjusts for ceilings up to 1-3/8"
thick. Remodel adjusts for ceilings from 3/8" to 5/8"
thick.
• 7-1/2" height allows for use in 2"x8" joist construction
• Adjustable socket bracket allows use of different lamp
types and sizes
• UL listed for use in damp locations (Listed for wet
locations with select trims)
• 2-year warranty
Features:
Trims:
Self-Flanged, Full Cone
White Metal Baffle
O.D. 7-9/16"
CAT.# E-T6300WH
$490
Albalite Glass Lens
White Metal Trim Ring
Wet Location Listed
O.D. 7-3/4"
CAT.# E-T6552WH
$390
Reflector, Clear
White Plastic Trim Ring
O.D. 7-9/16"
CAT.# E-T6200CL
$490
Fresnel Glass Lens
White Metal Trim Ring
Wet Location Listed
O.D. 7-3/4"
CAT.# E-T6550WH
$390
Applications – For use in non-insulated ceilings or where insulation can be kept 3" from housing.
7.5"
(191mm)
6.313"
(160mm)
7.5"
(191mm)
6.188"
(157mm)
12.75"
(324mm)
LAMPS ORDERED SEPARATELY
SEE PAGE 101
RECESSED
61
More trims available at www.e-conolight.com/trims
(1) 26W Double or Triple Tube CFL
CAT.# E-RFN626UAT $3390
ICF-1206A-E-JN-SN
6-5/16"
(160mm)
12"
(305mm)
7-5/8"
(194mm)
7-3/4"
(196mm)
6" Vertical Lamp CFL – Type IC
Applications – For use in insulated ceilings and can be installed in direct contact with insulation.
E-RFN6261ES/UAT
E-RFN6131ES/UAT /
ICF-106-E-JN
6-5/16"
(160mm)
7-5/8"
(193.6mm)
12"
(305mm)
8-1/16"
(204mm)
LAMPS ORDERED SEPARATELY
SEE PAGE 101
New Construction
(1) 26W/32W Double or Triple Tube CFL
CAT.# E-RFN632UAT $3990
Features:
• E-RFN632UAT ceiling cutout: 6-1/2"
E-RFN626UAT ceiling cutout: 6-3/8"
• E-RFN632UAT plaster frame: 7-5/8"W x 12"L
E-RFN626UAT plaster frame: 7-5/8"W x 12-1/2"L
• Universal voltage, HPF electronic ballast with end of life
protection
• Listed for eight (4 in-4 out) #12AWG (90˚C) through-
branch circuit conductors
• New Construction has five 1/2", one 3/4" and four
Romex® knockouts. Remodel has eight 1/2" and four
Romex® knockouts.
• Hanger bars allow housing to be positioned within 24"
joist span and designed to fit onto T-Bar spine.
• New Construction adjusts for ceilings up to 1-3/8"
thick.
• Sealed and gasketed construction limits air exchange
between ceiling plenum and heated/air conditioned
areas.Performance tested to ASTM-E283 (Washington
State)
• Meets State of California Title 24 requirements
• UL listed for use in damp locations (Listed for wet
locations with select trims)
• 2-year warranty
Trims:
Self-Flanged, Full Cone
White Metal Baffle
O.D. 7-9/16"
CAT.# E-T6300WH
Only for E-RFN626UAT
$490
Full Reflector, Clear
White Plastic Trim Ring
O.D. 8"
CAT.# E-T6202CL
$
1090
Black Metal Baffle with
Reflector, Clear
White Plastic Trim Ring
O.D. 8"
CAT.# E-T6402BK
$
1390
White Metal Baffle with
Reflector, Clear
White Plastic Trim Ring
O.D. 8"
CAT.# E-T6402WH
$
1390
RECESSED
62
More trims available at www.e-conolight.com/trims
6" Horizontal Lamp CFL – Type Non-IC
Applications – For use in non-insulated ceilings or where insulation can be kept 3" from housing.
New Construction
Remodel
• Ceiling cutout: 6-3/8"
• New Construction Plaster Frame: 7-5/8"W x 12-1/2"L
• Universal voltage, HPF electronic ballast with end of life
protection
• Minimum starting temperature 0˚F (-18˚C)
• Listed for eight (4 in-4 out) #12AWG (90˚C) through-
branch circuit conductors
• New Construction has five 1/2", one 3/4" and four
Romex® knockouts. Remodel has eight 1/2" and four
Romex® knockouts.
• Hanger bars allow housing to be positioned within 24"
joist span and designed to fit onto T-Bar spine.
• New Construction adjusts for ceilings up to 1-3/8"
thick. Remodel adjusts for ceilings from 3/8" to 5/8"
thick.
• Shallow profile height allows for use in 2"x6" joist
construction
• UL listed for use in damp locations (Listed for wet
locations with select trims)
• 2-year warranty
Features:
Trims:
Reflector, Clear
White Plastic Trim Ring
O.D. 7-9/16"
CAT.# E-T6250CL
$
1190
Albalite Glass Lens
White Metal Trim Ring
Wet Location Listed
O.D. 7-3/4"
CAT.# E-T6552WH
$390
Fresnel Glass Lens
White Metal Trim Ring
Wet Location Listed
O.D. 7-3/4"
CAT.# E-T6550WH
$390
White Metal Baffle with
Reflector, Clear
White Plastic Trim Tring
O.D. 7-9/16"
CAT.# E-T6450WH
$ 999
(2) 13W Double Tube CFL
CAT.# E-RZN627UTP $3890
(2) 26W Double Tube CFL
CAT.# E-RZN652UTP $3890
(2) 13W Double Tube CFL
CAT.# E-RZR627UTP $2999
(2) 26W Double Tube CFL
CAT.# E-RZR652UTP $3890
5.063"
(128mm)
6.313"
(160mm)
13.688"
(348mm)
4.875"
(124mm)
6.188"
(157mm)
LAMPS ORDERED SEPARATELY
SEE PAGE 101
RECESSED
63
More trims available at www.e-conolight.com/trims
6" Sloped Ceiling Incandescent – Type IC
Applications – For use in insulated ceilings and can be in direct contact with insulation.
New Construction
• Ceiling cutout: 7-1/16" x 6-7/8" oval
• New Construction Plaster Frame: 7-5/8"W X 12"L
• Designed for sloped ceilings from 2/12 to 6/12 pitch.
Socket swivels to align lamp direction.
• Listed for eight (4 in-4 out) #12AWG (90˚C) through-
branch circuit conductors
• New Construction has five 1/2", one 3/4" and four
Romex® knockouts. Remodel has eight 1/2" and four
Romex® knockouts.
• Hanger bars allow housing to be positioned within 24"
joist span and designed to fit onto T-Bar spine.
• New Construction adjusts for ceilings up to 1-3/8"
thick. Remodel adjusts for ceilings from 3/8" to 5/8"
thick.
• 7-1/2" height allows use in 2" X 8" joist construction
• New Construction has sealed and gasketed
construction to limit air exchange between ceiling
plenum and heated/air conditioned areas. Performance
tested to ASTM-E283 (Washington State)
• UL listed for use in damp locations (Listed for wet
locations with select trims)
• 2-year warranty
Remodel
One Lamp: 90W Max
CAT.# E-RSN6SAT $1940
Features:Trims:
White Metal Baffle
(90W New, 75W Remodel)
White Plastic Trim Ring
O.D. 7-7/8"
CAT.# E-T6380WH
$890
Eyeball
75W PAR30L/65W BR30
White Metal Trim Ring
O.D. 7-3/4"
CAT.# E-T6730WH
$740
Fresnel Glass Lens with
Reflector, Clear
A19 (40W Max)
Wet Location Listed, O.D. 8"
CAT.# E-T6540WH
$690
Albalite Glass Lens with
Reflector, Clear
A19 (40W Max)
Wet Location Listed, O.D. 8"
CAT.# E-T6541WH
$690
One Lamp: 75W Max
CAT.# E-RSR6SIC $1360
LAMPS ORDERED SEPARATELY
LED LAMPS3, SEE PAGE 38
HALOGEN LAMPS, SEE PAGE 105
7-3/4"
(197mm)
7-3/4"
(197mm)
6-1/2"
(165.6mm)
14-1/6"
(159mm)
7-1/4"
(184mm)
6-1/2"
(165mm)
7-7/16"
(189mm)
RECESSED
Free Shipping on Orders Over $500
64
6" Vertical Lamp Incandescent – Type IC
Applications – For use in insulated ceilings and can be installed in direct contact with insulation.
New Construction
• E-RIN6AT ceiling cutout: 6-1/2"
E-RIR6AT ceiling cutout: 6-3/8"
• New Construction Plaster Frame: 7-1/6"W X 10-3/4"L
• Listed for eight (4 in-4 out) #12AWG (90˚C) through-
branch circuit conductors
• New Construction has five 1/2", one 3/4" and four
Romex® knockouts. Remodel has eight 1/2" and four
Romex® knockouts.
• Hanger bars allow housing to be positioned within 24"
joist span and designed to fit onto T-Bar spine.
• New Construction adjusts for ceilings up to 1-3/8"
thick. Remodel adjusts for ceilings from 3/8" to 5/8"
thick.
• 7-1/2" height allows use in 2" X 8" joist construction
• New Construction has sealed and gasketed
construction to limit air exchange between ceiling
plenum and heated/air conditioned areas. Performance
tested to ASTM-E283 (Washington State)
• Meets State of California Title 24 requirements
• UL listed for use in damp locations (Listed for wet
locations with select trims)
• 2-year warranty
Remodel
One Lamp: 75W Max
CAT.# E-RIN6AT $740
Features:
One Lamp: 75W Max
CAT.# E-RIR6AT $740
LED AVAILABLE
See page 33
LAMPS ORDERED SEPARATELY
LED LAMPS3, SEE PAGE 38
HALOGEN LAMPS, SEE PAGE 105
7.5"
(191mm)
6.313"
(160mm)
12.75"
(324mm)
7.5"
(191mm)
6.125"
(157mm)
RECESSED
NEW!
www.e-conolight.com 888.243.9445 65
6" Vertical Lamp Incandescent Trims
Open
75W PAR30L, 65W BR30
White Metal Trim Ring
O.D. 8"
CAT.# E-T6131WH
$390
Full Reflector, Clear
60W A19
White Plastic Trim Ring
O.D. 8"
CAT.# E-T6201CL
$540
R-lamp Reflector, Clear
75W PAR30, 65W BR30
White Plastic Trim Ring
O.D. 7-9/16"
CAT.# E-T6230CL
$440
Full Cone Metal Baffle
75W PAR30, 65W BR30
White Self-Flanged Baffle
O.D. 7-9/16"
CAT.# E-T6300WH
$490
White Metal Baffle
75W PAR30, 65W BR30
White Self-Flanged Baffle
O.D. 7-9/16"
CAT.# E-T6313WH
$290
Black Metal Baffle
75W PAR30, 65W BR30
White Plastic Trim Ring
O.D. 7-9/16"
CAT.# E-T6314BK
$190
Black Micro Groove Baffle
75W PAR30, 65W BR30
White Plastic Trim Ring
O.D. 7-9/16"
CAT.# E-T6330BK
$290
White Micro Groove Baffle
75W PAR30, 65W BR30
White Plastic Trim Ring
O.D. 7-9/16"
CAT.# E-T6330WH
$340
Black Metal Baffle with
Reflector, Clear
60W A19
O.D. 7-9/16"
CAT.# E-T6400BK
$699
White Metal Baffle with
Reflector, Clear
60W A19
O.D. 7-9/16"
CAT.# E-T6400WH
$699
Fresnel Glass Lens with
Reflector, Clear
40W A19
Wet Location Listed, O.D. 8"
CAT.# E-T6540WH
$690
Albalite Glass Lens with
Reflector, Clear
40W A19
Wet Location Listed, O.D. 8"
CAT.# E-T6541WH
$690
Drop Opal Glass Lens with
Reflector, Clear
40W A19
Wet Location Listed, O.D. 8"
CAT.# E-T6543WH
$899
Fresnel Glass Lens
40W A19
Wet Location Listed
O.D. 7-3/4"
CAT.# E-T6550WH
$390
Albalite Glass Lens
40W A19
Wet Location Listed
O.D. 7-3/4"
CAT.# E-T6552WH
$390
Drop Opal Glass Lens
40W A19
Wet Location Listed
O.D. 7-3/4"
CAT.# E-T6556WH
$440
Eyeball
75W PAR30L, 65W BR30
White Metal Trim Ring
O.D. 7-3/4"
CAT.# E-T6730WH
$740
RECESSED
66 Free Shipping on Orders Over $500
HID Dusk to Dawn
CAT.# LAMP MOUNTING PRICE
E-DD0H071 70W HPS Direct $43.90
E-DD1M101 100W PSMH Mounting Arm $54.99
E-DD1H151 150W HPS Mounting Arm $56.90
E-DD1P151 150W PSMH Mounting Arm $67.90
• 120V reactor ballast NPF (HPS)
• 120V HX ballast NPF (PSMH)
• Die-cast aluminum housing
• Polyester powder coat grey finish for extra corrosion protection
• 120V twist-lock photocell included
• Open acrylic refractor: 10" dia. (Direct Mount) or 12" dia.
(Mounting Arm)
• One medium-base lamp included
• UL Listed for wet locations
• 1-year warranty
Features:
With Mounting Arm
Direct Mount
Fluorescent Under Cabinet
CAT.# LENGTH LAMP PRICE
E-UC12F081S 12-1/4" (1) 8W T5 $15.90
E-UC21F131S 21-1/4" (1) 13W T5 $20.90
E-UC24F161S 24-1/2" (2) 8W T5 $24.90
E-UC33F211S 33-1/2" (1) 8W & (1) 13W T5 $26.90
E-UC42F261S 42-1/2" (2) 13W T5 $28.90
• Heavy gauge steel construction with flush ends
• Baked-on white enamel finish
• White translucent plastic lens
• 1/4" conduit knockouts (0.575" dia.) provided on top, sides, and back
• Fixtures are 3-1/2 wide by 1" high
• Knock-out hole provided for receptacle (Call Factory or Shop Online)
• On/Off Rocker Switch (installed)
• Fixture comes standard with a Hot, Common, and Ground wire
• 90˚C supply wire required for fixture
• Ballast compartment cover with concealed fixture mounting screws
• Individual or continuous row mounting
• Includes Romex connector
• 4100K (Neutral White) lamp(s) included
• UL listed for dry locations (not for use above stoves)
• 1-year warranty
Features:
One lamp included
LED AVAILABLE
See page 7
LED AVAILABLE
See page 30
Lamp(s) included
SPECIALTY
NEW!
67
www.e-conolight.com 888.243.9445
Wall Mount
(Shown with Fluorescent)
Applications – Non-hazardous uses only. Typical Mounting Height: 8 to 18 feet
Shroud accessory:
Pendant Mount
(Shown with HID)
Ceiling Mount
(Shown with HID)
FIXTURE SIZE BALLAST CAT.# PRICE
Fluorescent
(42-watt)
Heavy-duty four-pin
GX24q-4 socket
Ceiling Mount 14-3/4"H x 7-1/4"W x 7-1/4"D120-volt electronic ballast E-MT5F421G $49.99
Metal Halide
(70-watt)
4kv medium-base
porcelain socket
Ceiling Mount 14-3/4"H x 7-1/4"W x 7-1/4"D120/277-volt HX ballast NPF E-MT5M07DG $61.90
Pendant mount 13-1/4"H x 7-1/4"W x 7-1/4"D120/277-volt HX ballast NPF E-MT6M07DG $59.90
Ceiling Mount Wall Mount
150/300-watt Incandescent Vapor Tight
Applications – Non-hazardous uses only. Typical Mounting Height: 8 to 15 feet
Pendant Mount
FIXTURE SIZE WEIGHT CAT.# PRICE
150-watt
Medium-base
porcelain socket
Wall Mount 9-1/2"H x 4-1/2"W x 7-1/4"D4 lbs E-MT4A101G $15.90
Ceiling Mount 9-5/8"H x 5-1/2"W x 4-1/8"D3 lbs E-MT1A101G $13.90
Pendant mount 9-1/2"H x 4-1/2"W x 4-1/2"D3 lbs E-MT3A101G $12.90
300-watt
Medium-base
porcelain socket
Wall Mount 12"H x 5-1/2"W x 9"D4.7 lbs E-MT7A301G $26.90
Ceiling Mount 11-1/4"H x 5-1/2"W x 5-1/2"D4.4 lbs E-MT5A301G
For non-combustible surfaces only $24.90
Pendant mount 12-1/4"H x 5-1/2"W x 5-1/2"D4 lbs E-MT6A301G $22.90
Use a "Type A"
Incandescent Lamp
Max 150W Type A21
Max 300W Type A25
(lamps ordered separately,
provided by others)
• Heavy-duty die-cast aluminum housing and adapter, with grey
polyester powder-coat finish
• Easy-install, screw-in, clear glass jar
• Die-cast aluminum 4-inch Junction box (Wall and Ceiling Mount only)
• 5 threaded and plugged 3/4" conduit entry points
(Wall and Ceiling Mount only)
• Threaded for 1/2" conduit entry (Fluorescent and HID Pendant Mount)
• Threaded for 3/4" conduit entry (Incandescent Pendant Mount)
• CFL minimum starting temperature, 0˚F
CFL optimum starting temperature, 40˚F+
• UL Listed for wet locations
• 1-year warranty
Features:
Replacement lamp
Fluorescent :
CAT.# ~CF42T4/41 $3.70
Metal Halide:
CAT.# ~MH070ME $10.90
Replacement lamp
Fluorescent :
CAT.# ~CF42T4/41 $3.70
Metal Halide:
CAT.# ~MH070ME $10.90
Replacement lamp
Fluorescent :
CAT.# ~CF42T4/41 $3.70
Metal Halide:
CAT.# ~MH070ME $10.90
150W Incandescent
• 15-inch aluminum shroud
with powder-coat finish (grey
outer surface, white interior
(not for use with wall mount)
CAT.# E-MTAC01S $2299
300W Incandescent,
42-watt Fluorescent &
70W HID
• 15-inch aluminum shroud
with powder-coat finish (grey
outer surface, white interior
(not for use with wall mount)
CAT.# E-MTAC01L $2499
One lamp includedOne lamp included One lamp included
42-watt Fluorescent & 70-watt HID Vapor Tight
Use a "Type A"
Incandescent Lamp
Max 150W Type A21
Max 300W Type A25
(lamps ordered separately,
provided by others)
Use a "Type A"
Incandescent Lamp
Max 150W Type A21
Max 300W Type A25
(lamps ordered separately,
provided by others)
VAPOR TIGHTS
LED AVAILABLE
See page 15
While
Supplies
Last
NEW!
68 Free Shipping on Orders Over $500
PAR20 SHROUD
(Black)
(White)
E-KAU2K
E-KAU2W
$340
PAR30 (SHORT NECK) SHROUD
(Black)
(White)
E-KAU3K
E-KAU3W
$390
PAR38 SHROUD
(Black)
(White)
E-KAU4K
E-KAU4W
$540
PAR20, PAR30L, PAR38 COLLAR
(Black)
(White)
E-KAUCK
E-KAUCW
$299
STYLE DESCRIPTION DIMENSIONS CATALOG # PRICE
Rear-Loading
Gimbal Ring
PAR20, 50W Max
3" Diameter
4.1" Long
180° Tilt Range
(Black)
(White)
E-KGR2RK
E-KGR2RW $890
Rear-Loading
Gimbal Ring
PAR30, 75W Max
4" Diameter
4" Long
180° Tilt Range
(Black)
(White)
E-KGR3RK
E-KGR3RW $990
Rear-Loading
Gimbal Ring
PAR38, 150W Max
5" Diameter
6" Long
180° Tilt Range
(Black)
(White)
E-KGR4RK
E-KGR4RW $1240
Front-Loading
Gimbal Ring
PAR30, 75W Max
4.4" Diameter
5" Long
90° Tilt Range
(Black) E-KRG3RK $1899
Front-Loading
Gimbal Ring
PAR38, 150W Max
5.3" Diameter
6.5" Long
90° Tilt Range
(Black)
(White)
E-KRG4RK
E-KRG4RW $1999
(Black)
(White)
E-KLPU4RK
E-KLPU4RW $990
PAR Track Lighting – Line Voltage
Applications – For general purpose track lighting in indoor commercial, retail or industrial applications.
Features:
• Injection-molded, high-strength polymer housing
(Low-Profile Lamp Holder)
• Deep-drawn steel housing (Rear-Loading Gimbal Ring)
• Die-cast aluminum housing
(Front-Loading Gimbal Ring)
• Polyester powder coated finish available in black or
white (Gimbal Rings)
• Rotation: 358˚
• Compatible with 1- or 2-circuit track
• UL listed for dry locations
• 1-year warranty
Dimensions without lamp
2.3" Diameter x 2.8" Long
90° Tilt Range
Our Best-Selling Track Fixture!
Low-Profile Lamp Holder
PAR20 50W Max, PAR30 75W Max, PAR38 100W Max
shown with
optional shroud
Low-Profile Accessories:
LAMPS ORDERED SEPARATELY
LED LAMPS3, SEE PAGE 39
HALOGEN LAMPS, SEE PAGE 101
(Philips brand par 30 lamps are not compatible TRG3R and E-KRG3R series track fixtures)
TRACK LIGHTING
SEE PAGES 28 & 29 FOR FULL RANGE OF
TRACK CONNECTORS
69
www.e-conolight.com 888.243.9445
STYLE DESCRIPTION DIMENSIONS CATALOG # PRICE
Round Back
R20, PAR20
50W Max
3.5" Diameter
6" Long
100° Tilt Range
(Black)
(White)
E-KRB2RK
E-KRB2RW $740
Round Back
PAR30L, BR30
75W Max
4.5" Diameter
7" Long
100° Tilt Range
(Black)
(White)
E-KRB3RK
E-KRB3RW $790
Round Back
PAR30 (short neck)
75W Max
4.5" Diameter
6" Long
100° Tilt Range
(Black)
(White)
E-KRB3RSK
E-KRB3RSW $790
Round Back
PAR38, BR40
150W Max
5.75" Diameter
8" Long
100° Tilt Range
(Black)
(White)
E-KRB4RK
E-KRB4RW $1140
Flat Back
R20, PAR20
50W Max
3.5" Diameter
6" Long
100° Tilt Range
(Black)
(White)
E-KFB2RK
E-KFB2RW $690
Flat Back
PAR30L, BR30
75W Max
4.5" Diameter
7" Long
100° Tilt Range
(Black)
(White)
E-KFB3RK
E-KFB3RW $740
Flat Back
PAR30 (short neck)
75W Max
4.5" Diameter
6" Long
100° Tilt Range
(Black) E-KFB3RSK $740
Flat Back
PAR38, BR40
150W Max
5.6" Diameter
8" Long
100° Tilt Range
(White) E-KFB4RW $899
PAR Track Lighting – Line Voltage
Applications – For general purpose track lighting in indoor commercial, retail or industrial applications.
Features:
• Deep-drawn steel housing
• Polyester powder coated finish available in black or
white
• Standard with an internal baffle in black finish
• U-shaped double yoke with single-locking knob to
secure aiming angle
• Rotation: 358˚
• Compatible with 1- or 2-circuit track
• UL listed for dry locations
• 1-year warranty
LAMPS ORDERED SEPARATELY
LED LAMPS3, SEE PAGE 39
HALOGEN LAMPS, SEE PAGE 101
LED AVAILABLE
See page 27
TRACK LIGHTING
70 Free Shipping on Orders Over $500
STYLE DESCRIPTION DIMENSIONS CATALOG # PRICE
Notch Back
External Electronic Transformer
MR16, 50W Max
2.5" Diameter
2.5" Long
180° Tilt Range
(Black)
(White)
E-KNB1EK
E-KNB1EW $2790
Round Back
External Electronic Transformer
MR16, 50W Max
2.5" Diameter
4.25" Long
90° Tilt Range
(Black)
(White)
E-KRB1EK
E-KRB1EW $2540
Round Back
Internal Magnetic Transformer
MR16, 50W Max
3.5" Diameter
6.5" Long
90° Tilt Range
(Black)
(White)
E-KRB2LK
E-KRB2LW $2990
Flat Back
External Electronic Transformer
MR16, 50W Max
2.5" Diameter
4.25" Long
90° Tilt Range
(Black)
(White)
E-KFB1EK
E-KFB1EW
$1999
$2999
Flat Back
Internal Magnetic Transformer
MR16, 50W Max
3.5" Diameter
6" Long
90° Tilt Range
(Black)
(White)
E-KFB2LK
E-KFB2LW
$1999
$2940
MR16 Track Lighting – Low Voltage
Applications – For general purpose track lighting in indoor commercial, retail or industrial applications.
• Die-cast aluminum housing (Notch Back)
• Deep drawn steel housing (Flat Back and Round Back)
• Polyester powder coat finish available in black or white
• Includes clear glass lens
• Rotation: 358˚
• Compatible with 1 or 2 circuit track
• 10W minimum lamp wattage required for electronic
transformers only.
• 20W minimum lamp wattage required for dimmed operation.
• UL Listed for dry locations
• 1-year warranty
Features:
NOTE: Dimming fixtures with magnetic transformers require
dimmers rated for inductive loads. Dimming fixtures with electronic
transformers require a dimmer rated for use with an
electronic transformer.
LAMPS ORDERED SEPARATELY
HALOGEN LAMPS, SEE PAGE 104
TRACK LIGHTING
LED AVAILABLE
See page 26
While Supplies
Last
While Supplies
Last
71
www.e-conolight.com 888.243.9445
Premium Floodlights
Wire Guard
CAT.# E-ACHJWG
$1199
Deep Baffle
CAT.# E-ACHJDB
$4399
Glare Shield
(Not for use w/HJC)
CAT.# E-ACHJGS
$5399
Accessories: (No combination of Wire Guard, Deep Baffle, or Glare Shield can be used.)
• 120/208/240/277V CWA ballast HPF; HX ballast HPF for 150W PSMH
• Sturdy low copper, die-cast aluminum housing and lens frame
• E-coat epoxy primer with five layers of protection
• Super durable dark-bronze powder topcoat
• Tempered-glass lens, thermal-shock and impact resistant
• Suitable for ground mounting, uplight & downlighting
• Precision reflector delivers premium optical patterns
(wide, cutoff and roadway)
• 2" adjustable fitter or adjustable u-bracket comes pre-installed on fixture
• High-performance H75 lamp included; universal burn lamp for 150W
PSMH
• Foam-in-place gaskets provide superior seal
• Durable, stainless steel captive fasteners
• UL Listed for wet locations (IP54)
• 5-year finish warranty
• 3-year fixture warranty
• 1-year lamp warranty
• Assembled in the USA
CAT.# E-ACP1
(120 volts)
$690
Photocell, field installed, use with adjustable slip fitter only
CAT.# E-ACP2
(208/240/277 volts)
$690
Features:
Adjustable U-Bracket
Premium Wide Floodlight
Wattage Adjustable U-Bracket Price 2" Adjustable Fitter Price
150W PSMH E-HJWP15YQZ $137.99 E-HJWP15SQZ $145.99
250W PSMH E-HJWP25YQZ $152.99 E-HJWP25SQZ $160.99
320W PSMH E-HJWP32YQZ $153.99 E-HJWP32SQZ $162.99
400W PSMH E-HJWP40YQZ $157.99 E-HJWP40SQZ $165.99
Premium Cutoff Floodlight
Wattage Adjustable U-Bracket Price 2" Adjustable Fitter Price
150W PSMH E-HJCP15YQZ $137.99 E-HJCP15SQZ $145.99
250W PSMH E-HJCP25YQZ $163.99 E-HJCP25SQZ $160.99
320W PSMH E-HJCP32YQZ $165.99 E-HJCP32SQZ $162.99
400W PSMH E-HJCP40YQZ $157.99 E-HJCP40SQZ $165.99
Premium Roadway Floodlight
Wattage Adjustable U-Bracket Price 2" Adjustable Fitter Price
150W PSMH E-HJRP15YQZ $137.99 E-HJRP15SQZ $145.99
250W PSMH E-HJRP25YQZ $152.99 E-HJRP25SQZ $160.99
320W PSMH E-HJRP32YQZ $165.99 E-HJRP32SQZ $162.99
400W PSMH E-HJRP40YQZ $157.99 E-HJRP40SQZ $165.99
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
Replacement Lamps
150W Universal Burn PSMH: CAT.# ~PS150E, $10.90
250W H75 PSMH: CAT.# ~PS250H75, $29.90
320W H75 PSMH: CAT.# ~PS320PH75, $30.90
400W H75 PSMH: CAT.# ~PS400PH75, $35.90
14"H x 14"W x 6-3/8"D
Weight: 29-30 lbs.
Universal burn lamp for 150W PSMH
One mogul base H75 Venture
lamp included
1.25"
Version to be used only
when "Uniform" is 1.25"
or smaller in size.
example:
Preferred Master
Four Color
Black and White
LED AVAILABLE
See pages 2-5
FLOODLIGHTS & POLES
72 Free Shipping on Orders Over $500
HID Parking / Roadway
Applications – Parking lots, roadways, walkways and general area lighting. Also effective as a wall mounted security / perimeter light for storage
areas and commercial sites. Not for use as uplight. Typical Mounting Height: 15 to 30 feet Typical Spacing: 3 to 5 times the mounting height
• 120/208/240/277V CWA ballast HPF
• Sturdy die-cast aluminum housing and lens frame with dark-bronze
polyester powder-coat finish
• Tempered-glass lens, thermal-shock and impact resistant
• Fixture comes without mounting. (Order E-ACE 6-inch mounting arm,
E-ACU U-bracket, or E-ACS slip fitter)
• UL Listed for wet locations
• 1-year warranty
Mounting Options:
16-1/2"H x 16-1/2"W x 7"D
Weight: 29-33 lbs.
Accessories:
Internal Backlight Shield
Adjustable shield clips inside of glass lens
CAT.# E-ACBLS16
$390
PSMH 250-watt
Pulse-Start Metal Halide
CAT.# E-HS4P25QZ
H75 Replacement Lamp
CAT.# ~PS250H75
$14990
$29.90
320-watt
Pulse-Start Metal Halide
CAT.# E-HS4P32QZ
H75 Replacement Lamp
CAT.# ~PS320PH75
$14990
$30.90
400-watt
Pulse-Start Metal Halide
CAT.# E-HS4P40QZ
H75 Replacement Lamp
CAT.# ~PS400H75
$14990
$31.90
HPS 250-watt
High-Pressure Sodium
CAT.# E-HS4H25QZ
Replacement lamp
CAT.# ~HP250
$12690
$6.00
400-watt High-Pressure
Sodium
CAT.# E-HS4H40QZ
Replacement lamp
CAT.# ~HP400
$10299
$6.25
6-inch mounting arm,
attaches
to 1, 2, 3, 5 & 6 pole drill
configuration or wall
mount plate (see pg. 76)
CAT.# E-ACE
$1190
Adjustable U-bracket, with 30"
cord.
2-1/2"H x 5-1/2"W x 6"D
CAT.# E-ACU
$690
Adjustable slip fitter.
Fits over 2-3/8" O.D. pipe
CAT.# E-ACS
$1190
CAT.# E-ACP1
(120 volts)
$690
Photocell, field installed, use with adjustable slip fitter only
CAT.# E-ACP2
(208/240/277 volts)
$690
Features:
One mogul base H75 Venture
lamp included for PSMH
1.25"
Version to be used only
when "Uniform" is 1.25"
or smaller in size.
example:
Preferred Master
Four Color
Black and White
Universal burn lamp included for HPS
*Use only with mounting E-HS4 (shown above)
FLOODLIGHTS & POLES
73
www.e-conolight.com 888.243.9445
23-3/4"H x 23-3/4"W x 10-1/4"D
Weight: 62.60 lbs.
Applications – General purpose floodlighting, parking lot lighting and building facade lighting.
Typical Mounting Height: 25 to 50 feet Typical Spacing: 3 to 5 times the mounting height
• 120/208/240/277 CWA ballast HPF
• Sturdy die-cast aluminum housing and lens frame, with dark-bronze
polyester powder-coat finish
• Tempered-glass lens, thermal-shock and impact resistant
• Adjustable slip fitter model fits over 2-3/8" O.D. pipe
• Adjustable U-bracket model comes with 30" cord
• UL listed for wet locations
• 1-year warranty
Accessories:
CAT.# E-ACP1EXT
(120 volts, external style)
$1990
Adjustable Slip Fitter
Adjustable U-bracket
1000-watt HID Floodlight
1000-watt Metal Halide (MH)
w/ Adjustable Slip Fitter
CAT.# E-HR5M99SQZ
Replacement lamp
CAT.# ~MH999UE
$34990
$19.90
Photocell, field installed, use with adjustable slip fitter only
CAT.# E-ACP2
(208/240/277 volts, button style)
$690
Photocell, field installed, use with adjustable slip fitter only
Features:
One mogul base
lamp included
23-3/4"H x 23-3/4"W x 10-1/4"D
Weight: 64.20 lbs.
NOT FOR USE AS AN UPLIGHT
One mogul base
lamp included
1000-watt Metal Halide (MH)
w/ Adjustable U-bracket
CAT.# E-HR5M99YQZ
Replacement lamp
CAT.# ~MH999UE
$33990
$19.90
NOT FOR USE WITH 1000W 120V
Adjustable Slip Fitter
Adjustable U-Bracket
FLOODLIGHTS & POLES
74
16-1/2"H x 16-1/2"W x 7"D
Weight: 29-33 lbs.
13-3/8"H x 13-3/8"W x 6-7/8"D
Weight: 21.5 lbs.
Applications – Building facades, displays, uplighting and signs. Also effective as security lighting, for storage areas and commercial sites.
Typical Mounting Height: 15 to 25 feet Typical Spacing: 2 to 4 times the mounting height
• 120/208/240/277V HX ballast HPF (E-HR3P15QZ)
• 120/208/240/277V CWA ballast HPF
• Sturdy die-cast aluminum housing and lens frame, with dark-bronze
polyester powder-coat finish
• Tempered-glass lens, thermal-shock and impact resistant
• Fixture comes without mounting.
• (Order E-ACS slip fitter or E-ACU U-bracket)
• UL Listed for wet locations
• 1-year warranty
Applications – Building facades and displays. Also effective as security lighting, for storage areas and commercial sites.
Typical Mounting Height: 15 to 30 feet Typical Spacing: (250W) 2 to 3 times the mounting height (320/400W) 2 to 4 times the mounting height
150/250-watt HID Floodlight
250/320/400-watt HID Floodlight
Features:
Accessories:
Mounting Options:
PSMH 250-watt
Pulse-Start Metal Halide
CAT.# E-HR4P25QZ
H75 Replacement Lamp
CAT.# ~PS250H75
$12990
$29.90
320-watt
Pulse-Start Metal Halide
CAT.# E-HR4P32QZ
H75 Replacement Lamp
CAT.# ~PS320PH75
$12990
$30.90
400-watt
Pulse-Start Metal Halide
CAT.# E-HR4P40QZ
H75 Replacement Lamp
CAT.# ~PS400H75
$12990
$31.90
HPS 250-watt
High-Pressure Sodium
CAT.# E-HR4H25QZ
Replacement lamp
CAT.# ~HP250
$11190
$6.00
400-watt
High-Pressure Sodium
CAT.# E-HR4H40QZ
Replacement lamp
CAT.# ~HP400
$12190
$6.25
PSMH 150-watt
Pulse-Start Metal Halide
CAT.# E-HR3P15QZ
Replacement lamp
CAT.# ~PS150E
$5899
$10.90
250-watt
Pulse-Start Metal Halide
CAT.# E-HR3P25QZ
H75 Replacement Lamp
CAT.# ~PS250H75
$10999
$29.90
CAT.# E-ACP1
(120 volts)
$690
Photocell, field installed, use with adjustable slip fitter only
CAT.# E-ACP2
(208/240/277 volts)
$690
Adjustable U-bracket, with 30" cord.
2-1/2"H x 5-1/2"W x 6"D
CAT.# E-ACU
$690
Adjustable slip fitter.
Fits over 2-3/8" O.D. pipe
CAT.# E-ACS
$1190
One mogul base H75 Venture
lamp included for 250W PSMH
1.25"
Version to be used only
when "Uniform" is 1.25"
or smaller in size.
example:
Preferred Master
Four Color
Black and White
Universal burn lamp included for 150W PSMH
One mogul base H75 Venture
lamp included for PSMH
1.25"
Version to be used only
when "Uniform" is 1.25"
or smaller in size.
example:
Preferred Master
Four Color
Black and White
Universal burn lamp included for HPS
NOT FOR USE AS AN UPLIGHT
LED AVAILABLE
See pages 2-5
*Use only with mounting E-HR3 & E-HR4 (shown above)
Full assortment of floodlights & poles available at www.e-conolight.com
FLOODLIGHTS & POLES
75
Applications – Building facades, displays, uplighting and signs. Also effective as security lighting, for storage areas and commercial sites.
Typical Mounting Height: 15 to 25 feet
70W–150W HID Floodlight
Spot
Standard
6-1/4"H x 9-1/8"W x 6-1/8"D
Weight: 6-8 lbs.
70W–150W HID Floodlight
• Sturdy die-cast aluminum housing and lens frame, with dark-bronze
polyester powder-coat finish
• Tempered-glass lens, thermal-shock and impact resistant
• 1/2-inch NPS die-cast swivel fitter
• Anodized aluminum reflector
• Hydroformed, anodized aluminum reflector (spot only)
• UL Listed for wet locations
• 1-year warranty
Applications – Building facades, displays, uplighting and signs. Also effective as security lighting, for storage areas and commercial sites.
Typical Mounting Height: 8 to 20 feet
PSMH 70-watt
Pulse-Start Metal Halide
• 120-volt HX ballast NPF
CAT.# E-HC1M071Z
Replacement lamp
CAT.# ~MH070ME
$5490
$10.90
100-watt
Pulse-Start Metal Halide
• 120-volt HX ballast NPF
CAT.# E-HC1M101Z
Replacement lamp
CAT.# ~MH100ME
$5590
$10.40
HPS 70-watt
High-Pressure Sodium
• 120-volt Reactor ballast NPF
CAT.# E-HC1H071Z
Replacement lamp
CAT.# ~HP070M
$4290
$5.25
100-watt
High-Pressure Sodium
• 120-volt Reactor ballast NPF
CAT.# E-HC1H101Z
Replacement lamp
CAT.# ~HP100M
$4390
$5.25
150-watt
High-Pressure Sodium
• 120-volt Reactor ballast NPF
CAT.# E-HC1H151Z
Replacement lamp
CAT.# ~HP150M
$4590
$5.25
PSMH 70-watt
Pulse Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-HP2M07QZ
Replacement lamp
CAT.# ~MH070ME
$5399
$10.90
100-watt
Pulse Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-HP2M10QZ
Replacement lamp
CAT.# ~MH100ME
$5599
$10.40
Features:
One medium base
lamp included
9-1/4"H x 9-1/4"W x 7-1/8"D
Weight: 15 lbs.
One medium base
lamp included 9-1/4"H x 9-1/4"W x 7-1/8"D
Weight: 12-14 lbs.
One medium base
lamp included
PSMH
100-watt
Pulse-Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-HC2M10QZ
Replacement lamp
CAT.# ~MH100ME
$7390
$10.40
150-watt Pulse-Start
Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-HC2P15QZ
Replacement lamp
CAT.# ~PS150ME
$6999
$9.90
HPS
150-watt
High-Pressure Sodium
• 120-volt Reactor ballast HPF
CAT.# E-HC2H151Z
Replacement lamp
CAT.# ~HP150M
$6490
$5.25
Full assortment of floodlights & poles available at www.e-conolight.com
FLOODLIGHTS & POLES
76 Free Shipping on Orders Over $500
Flood
Flood
Spot
9"H x 11"W x 10-1/2"D
Weight: 18-21 lbs.
9"H x 11"W x 10-1/2"D
Weight: 16 lbs.
Applications – Building facades, displays, uplighting and signs. Also effective as security lighting, for storage areas and commercial sites.
Typical Mounting Height: 8 to 25 feet
HID Roundback Flood & Spot Light
One medium base lamp included
7-1/2"H x 9"W x 8-3/4"D
Weight: 10 lbs.
7-1/2"H x 9"W x 8-3/4"D
Weight: 8.5 lbs.
SMALL
SMALL
2" Adjustable Fitter – Flood
Wattage Housing Ballast Replacement Lamp Lamp Price Fixture CAT.# Price
70W PSMH 120/277V HX ballast HPF ~MH070ME $10.90 E-HU1M07DZ $66.99
70W PSMH 120V reactor ballast NPF ~MH070ME $10.90 E-HU3M071Z $55.99
100W PSMH 120/277V HX ballast HPF ~MH100ME $10.40 E-HU1M10DZ $91.90
150W PSMH 120/208/240/277V HX ballast HPF ~PS150ME $9.90 E-HU1P15QZ $102.90
150W HPS 120/208/240/277V HX ballast HPF ~HP150M $5.25 E-HU1H15QZ $67.99
1/2" Adjustable Fitter – Flood
Wattage Housing Ballast Replacement Lamp Lamp Price Fixture CAT.# Price
70W PSMH 120/277V HX ballast HPF ~MH070ME $10.90 E-HU2M07DZ $62.99
70W PSMH 120V reactor ballast NPF ~MH070ME $10.90 E-HU4M071Z $51.99
100W PSMH 120/277V HX ballast HPF ~MH100ME $10.40 E-HU2M10DZ $63.99
9"H x 11"W x 10-1/2"D
Weight: 21 lbs.
2" Adjustable Fitter – Spot
Wattage Housing Ballast Replacement Lamp Lamp Price Fixture CAT.# Price
150W PSMH 120/208/240/277V HX ballast HPF ~PS150ME $9.90 E-HUSP15QZ $104.90
CAT.# E-ACP2
(208/240/277 volts)
$690
• Sturdy die-cast aluminum housing and lens frame with dark-bronze
polyester powder-coat finish
• Tempered-glass lens, thermal-shock and impact resistant
• Anodized aluminum reflector
• Glare shield
• 2" adjustable fitter models fit over 2-3/8" O.D. pipe
• 1/2" adjustable fitter models are 1/2" NPS
• UL Listed for wet locations
• 1-year warranty
Accessories:
CAT.# E-ACP1
(120 volts)
$690
Photocell, field installed, use 2" adjustable slip fitter only
Features:
LARGE LARGE
LARGE
LARGE
LARGE
LARGE
LARGE
LARGE
LARGE
LARGE
SMALL
SMALL
LED AVAILABLE
See pages 2-5
FLOODLIGHTS & POLES
77
www.e-conolight.com 888.243.9445
4-7/8"H x 8-1/2"W x 5-3/4"D
6-1/4"H x 9"W x 4"D4-3/8"H x 5"W x 4"D
150/300-watt Quartz Halogen Floodlight
• 150-watt Quartz Halogen
• Lamp Output: 2000 lumens
• Lamp Color Rendition: 100 CRI
• Weight: 1.5 lbs
• Silicone gasketing and tempered-glass lens
• 1/2-inch NPS die-cast swivel fitter
• Sturdy die-cast aluminum housing and lens frame, with dark-bronze
polyester powder-coat finish
• UL Listed for wet locations
• 1-year warranty on fixture; 90-days on lamp
Applications – Security, signage, displays, uplighting, landscaping and other residential uses.
13-watt x 2 Fluorescent Floodlight
Applications – Security, signage, displays, uplighting, landscaping and other residential uses.
• 300-watt Quartz Halogen
• Lamp Output: 4800 lumens
• Lamp Color Rendition: 100 CRI
• Weight: 2.5 lbs.
• Silicone gasketing and tempered-glass lens
• 1/2-inch NPS die-cast swivel fitter
• Sturdy die-cast aluminum housing and lens frame, with dark-bronze
polyester powder-coat finish
• Housing has integral ribs for heat dissipation
• UL Listed for wet locations
• 1-year warranty on fixture; 90-days on lamp
• Total 26-watts
• 120-volt Magnetic ballast NPF
• Lamp Output: 820 lumens per lamp, total 1640 lumens
• Lamp Color Rendition: 82 CRI
• Weight: 5 lbs.
• Silicone gasketing and tempered-glass lens
• 1/2-inch NPS die-cast swivel fitter
• Sturdy die-cast aluminum housing and lens frame, with dark-bronze
polyester powder-coat finish
• Specular aluminum reflector
• Eyebrow-style hinge frame to reduce spill light
• Minimum starting temperature, 0˚F
• Optimum starting temperature, 40˚F+
• UL Listed for wet locations
• 1-year warranty
Features:
• Total 26-watts
• 120V Electronic Ballast NPF
• Lamp Output: 890 lumens per lamp, total 1780 lumens
• Lamp Color Rendition: 82 CRI
• Weight: 3.5 lbs.
• Silicone gasketing
• 1/2-inch NPS die-cast swivel fitter
• Corrosion resistant polycarbonate housing in dark-bronze finish
• Specular aluminum reflector
• UV-stabilized polycarbonate prismatic refractor
• Minimum starting temperature, 0˚F
• Optimum starting temperature, 40˚F+
• UL Listed for wet locations
• 1-year warranty
Features:
7"H x 9"W x 3-3/8"D
One lamp included
CAT.# E-CF3Q301Z
Replacement lamp 300-watt
CAT.# ~QZ300T3
$940
$0.50
CAT.# E-CF4F261Z
Replacement lamp
CAT.# ~CF13SA/27
$2790
$1.70
Features: Features:
Two lamps included
One lamp included
Two lamps included
CAT.# E-CF7F261Z
Replacement lamp
CAT.# ~CF13D4/41
$2640
$2.20
CAT.# E-CF1Q151Z
Replacement lamp 150-watt
CAT.# ~QZ150T3
$590
$0.50
Typical Mounting Height: 8 to 20 feet
Typical Mounting Height: 8 to 15 feet
Typical Mounting Height: 15 to 25 feet
Typical Mounting Height: 8 to 15 feet
FLOODLIGHTS & POLES
78 Free Shipping on Orders Over $500
Seattle
Spokane
Portland
Pendleton
Roseburg Burns
Eureka
Sacramento
San Francisco
Fresno
Los Angeles
San Diego
Phoenix
Las Vegas
To nopah
Reno
Winnemucca
Pocatello
Boise
Missoula
Havre
Great Falls
Billings
Lander
Cheyenne
Salt Lake City
Milford
Denver
Grand
Junction
Albuquerque Amarillo
El Paso
Del Rio
Brownsville
San Antonio
Houston
Fort Worth
Abilene
Oklahoma City
Dodge City
Lincoln
North
Platte
Rapid City Huron
Williston
Bismarck
Fargo
International
Falls
Duluth
Minneapolis Green Bay
Dubuque
Des Moines
Kansas
City
St. Louis
Little Rock
Shreveport
Jackson
Birmingham
Atlanta
Pensacola
Jacksonville
Tampa
Charleston
Columbia
Memphis
Nashville
Knoxville
Raleigh
Wilmington
Cape Hatteras
Lexington
Charleston Norfolk
Richmond
Washington
Philadelphia
Harrisburg
Pittsburgh
Columbus
Indianapolis
Springfield
Chicago
Buffalo
New Yo rk
Albany
Hartford
Burlington
Caribou
150 (67)
150 (67)
150 (67)
140 (63)
130 (58)
130 (58)
120 (54)
120 (54)
130 (58)
110 (49)
100 (45)
90 (40)
110 (49)
100 (45)
90 (40)
90 (40)
90 (40)
140 (63)
140 (63)
140 (63)
140 (63)
Lake
Superior
Lake
Huron
Lake Erie
Lake
Ontario
Sault Ste. Marie
Racine Detroit
Lansing
Lake Michigan
Miami
Special Wind Region
Population Center
Legend
Portland
Concord
Boston
New Orleans
Approximate maximum wind zones
Max. Wind Speed miles/hour
(meters/second)
E-conolight® Steel Square Poles (Dark Bronze)
The maximum wind zone chart is included only for reference. Soil conditions can vary substantially within an area.
Installers are advised to work with an engineering firm to determine suitable poles and EPA loadings for every installation.
Steel Bullhorns & Square Poles* Round-Tapered Steel Pole* Round-Tapered Aluminum Poles*
Quantity Quantity Quantity
1 - 25 Approximately 10 business days to
ship
26 - 99 3 weeks
100 + (Consult Factory)
1 - 50 4 weeks
51 - 99 6 weeks
100 + (Consult Factory)
1 - 30 4 weeks
31 - 75 5 weeks
76 - 99 6 weeks
100 + (Consult Factory)
*Approximate manufacturing lead times: (allow additional time for transit) - business days do not include weekends or holidays
Single Tenon
Mount
For 1 fixture
or
bullhorns
Side Mount
For 1 or 2 Fixtures
(Drilled on
2 sides @ 180˚)
Side Mount
For 2, 3 or
4 Fixtures
(Drilled on
4 sides)
Single Tenon Mount
For 1 fixture or bullhorns
Side Mount
For 1 or 2 Fixtures
(Drilled on 2 sides @ 180˚)
Side Mount
For 2, 3 or 4 Fixtures
(Drilled on 4 sides)
Single Tenon Mount
for 1 fixture or bullhorn
Ordering
E-conolight poles can be ordered through our Customer Service department by
calling 888-243-9445 or on-line at www.e-conolight.com. Because poles are
custom manufactured upon your order, your credit card will be charged
immediately, regardless of lead-time. Please carefully select your poles based
upon proper mounting configuration and wind loading in your area.
Pole and Bullhorn Shipping
Freight charges are included in the price of all e-conolight poles and bullhorns. A
complete shipping address must be provided at the time of order (No PO Boxes).
Expedited orders can not be accepted. Because poles and fixtures ship from
different locations, e-conolight can not guarantee arrival of fixtures and poles on the
same day. Anchor bolts shipping in advance will incur additional freight charges.
Shipping to the continental US only.
Returns / Restocking and Order Changes
Because all poles and bullhorns are custom manufactured specifically for your
order, returns, restocking or cancellations are not possible.
Anchor Bolts
Partially galvanized anchor bolts and hardware are furnished with each pole. The
bolts are made from carbon steel bar conforming to AASHTO and ASTM Grade-55
requirements. Anchor bolts shipping in advance will incur additional freight charges
and must ship to the same address as the pole shipment.
Pole Base
Base is supplied with slotted anchor bolt openings so that a range of bolt circles
can be utilized. The base plate telescopes the pole shaft and is circumferentially
welded top and bottom. Template can be found on our Website under installation
instructions. Paper template provided with pole.
Handhole
A rectangular shaped handhole is furnished and includes a steel cover and
attachment bar with machine screw. The handhole is located 18-inches above the
pole base.
Electrical Ground
A ground lug is provided near the handhole and includes a hex-head bolt and nut.
Base Cover
A standard, full base cover is included with each steel pole and is made from ABS
plastic. Its two-piece construction is secured together with two plastic, hand push
rivets. Round Tapered Aluminum poles are supplied with nut covers.
Pole Caps
A removable pole cap is included with each pole configured for fixture side
mounting or no drill. Poles with tenon top configuration do not include a pole cap.
Paint Finish
All e-conolight poles are mechanically cleaned and coated with an electrostatically
applied, baked-on powder topcoat to provide years of worry-free service in the
field. All e-conolight poles and bullhorns are painted in dark-bronze to closely
match fixtures and mounting options.
Warranty
E-conolight warrants its poles to be free from defects in materials and workmanship
for a period one year from the date of delivery. E-conolight will, at its discretion,
repair or replace without charge any returned defective part (FOB factory). The
warranty specifically excludes fatigue failure, or similar phenomena, resulting from
induced vibration, harmonic oscillation or resonance associated with movement of
air currents around the pole.
The above warranties are given in lieu of all other warranties expressed or implied,
including and without limitation, the warranty of merchantability and the warranty of
suitability for a particular purpose. It is expressly stated that e-conolight assumes
no liability for consequential or liquidated damages arising out of a breach of the
sale, including any warranties arising therefrom and buyer's remedy shall be limited
to repair or replacement of defective parts as described above.
NOTE: EPA ratings for e-conolight poles are rated for use with e-conolight fixtures
only. It is the sole responsibility of the customer to carefully select poles based
upon the proper mounting configuration and the wind loading of the area where the
installation will occur.
Additional Information
Seattle
Spokane
Portland
Pendleton
Roseburg Burns
Eureka
Sacramento
San Francisco
Fresno
Los Angeles
San Diego
Phoenix
Las Vegas
To nopah
Reno
Winnemucca
Pocatello
Boise
Missoula
Havre
Great Falls
Billings
Lander
Cheyenne
Salt Lake City
Milford
Denver
Grand
Junction
Albuquerque Amarillo
El Paso
Del Rio
Brownsville
San Antonio
Houston
Fort Worth
Abilene
Oklahoma City
Dodge City
Lincoln
North
Platte
Rapid City Huron
Williston
Bismarck
Fargo
International
Falls
Duluth
Minneapolis Green Bay
Dubuque
Des Moines
Kansas
City
St. Louis
Little Rock
Shreveport
Jackson
Birmingham
Atlanta
Pensacola
Jacksonville
Tampa
Charleston
Columbia
Memphis
Nashville
Knoxville
Raleigh
Wilmington
Cape Hatteras
Lexington
Charleston Norfolk
Richmond
Washington
Philadelphia
Harrisburg
Pittsburgh
Columbus
Indianapolis
Springfield
Chicago
Buffalo
New Yo rk
Albany
Hartford
Burlington
Caribou
150 (67)
150 (67)
150 (67)
140 (63)
130 (58)
130 (58)
120 (54)
120 (54)
130 (58)
110 (49)
100 (45)
90 (40)
110 (49)
100 (45)
90 (40)
90 (40)
90 (40)
140 (63)
140 (63)
140 (63)
140 (63)
Lake
Superior
Lake
Huron
Lake Erie
Lake
Ontario
Sault Ste. Marie
Racine Detroit
Lansing
Lake Michigan
Miami
Special Wind Region
Population Center
Legend
Portland
Concord
Boston
New Orleans
FLOODLIGHTS & POLES
79
www.e-conolight.com 888.243.9445
E-conolight® Steel Square Poles (Dark Bronze)
Mounting Guide for e-conolight Square Steel Poles when Bullhorn Tenons are used
(For side mounting of 400-watt and below fixtures, all poles can accept up to four fixtures with wind speeds up to 100 mph)*
Poles using Bullhorn Tenons must be "T" Configuration
* (30' x 5") and (35' x 6") poles can only accommodate (3) 400-watt and below e-conolight fixtures at 100 MPH wind speeds.
Mounting Guide for e-conolight Square Steel Poles when Bullhorn Tenons are used
Poles using Bullhorn Tenons must be "T" Configuration
1000-watt Fixtures
Height x
Width x
Wall Thickness
Bolt Circle
Range
Structural
Weight of
Pole (lbs.)
Anchor
Bolt Size
80 MPH 90 MPH 100 MPH
Catalog # Price
Max
EPA
Max
Fixture
Weight
Max
EPA
Max
Fixture
Weight
Max
EPA
Max
Fixture
Weight
4-Inch Poles
15' x 4" x 0.120" 8" - 9" 108 3/4" 14.1 353 10.6 265 8.1 203 %E-PS4E15C*DB $349.90
17' x 4" x 0.120" 8" - 9" 120 3/4" 11.4 285 8.4 210 6.2 155 %E-PS4E17C*DB $379.90
20' x 4" x 0.120" 8" - 9" 140 3/4" 8.1 203 5.6 140 3.7 93 %E-PS4E20C*DB $379.90
20' x 4" x 0.180" 8" - 9" 200 3/4" 14.4 360 10.8 270 8.2 205 %E-PS4E20S*DB $499.90
22' x 4" x 0.180" 8" - 9" 220 3/4" 12.2 305 9.1 228 6.8 170 %E-PS4E22S*DB $499.90
25' x 4" x 0.180" 8" - 9" 245 3/4" 9.6 240 6.7 168 4.8 120 %E-PS4E25S*DB $499.90
5-Inch Poles
17' x 5" x 0.120" 10" - 12" 160 3/4" 19.5 488 14.7 368 11.1 278 %E-PS5E17C*DB $524.90
20' x 5" x 0.120" 10" - 12" 185 3/4" 14.0 373 10.9 273 8.0 200 %E-PS5E20C*DB $524.90
22' x 5" x 0.180" 10" - 12" 305 3/4" 19.5 488 14.6 365 11.0 275 %E-PS5E22S*DB $659.90
25' x 5" x 0.180" 10" - 12" 330 3/4" 15.6 390 11.3 283 8.1 203 %E-PS5E25S*DB $659.90
27' x 5" x 0.180" 10" - 12" 350 3/4" 13.1 328 9.2 230 6.3 158 %E-PS5E27S*DB $799.90
30' x 5" x 0.180" 10" - 12" 380 3/4" 9.9 248 6.4 160 3.6 90 %E-PS5E30S*DB $799.90
6-inch Poles
27' x 6" x 0.180" 11" - 13" 508 1" 21.6 540 15.8 395 11.5 288 %E-PS6E27S*DB $839.90
30' x 6" x 0.180" 11" - 13" 520 1" 17.6 440 12.2 305 8.3 208 %E-PS6E30S*DB $899.90
35' x 6" x 0.180" 11" - 13" 540 1" 11.9 298 7.8 183 4.0 100 %E-PS6E35S*DB $999.90
* Select Drill Configuration Note: Tenon measures (2.38" O.D. x 4.0" L)
For mounting other manufacturers' fixtures, please reference
EPA and maximum fixture weight information above.
0 1 2 3 5 6 Tdf
No Drill Tenon
Maximum Number of Fixtures @ 90˚ Tilt
Maximum Wind Speed
80 MPH 90 MPH 100 MPH
15' X 4" X 0.120" 4 4 3
17' X 4" X 0.120" 4 3 2
17' X 5" X 0.120" 4 4 4
20' X 4" X 0.120" 3 2 1
20' X 4" X 0.180" 4 4 3
20' X 5" X 0.120" 4 4 3
22' X 4" X 0.180" 4 3 2
22' X 5" X 0.180" 4 4 4
25' X 4" X 0.180" 3 2 1
25' X 5" X 0.180" 4 4 3
27' X 5" X 0.180" 4 3 2
27' X 6" X 0.180" 4 4 4
30' X 5" X 0.180" 3 2 1
30' X 6" X 0.180" 4 4 3
35' X 6" X 0.180" 4 3 1
Maximum Number of Fixtures @ 45˚ Tilt
Maximum Wind Speed
80 MPH 90 MPH 100 MPH
15' X 4" X 0.120" 4 4 3
17' X 4" X 0.120" 4 3 3
17' X 5" X 0.120" 4 4 4
20' X 4" X 0.120" 3 2 1
20' X 4" X 0.180" 4 4 3
20' X 5" X 0.120" 4 4 3
22' X 4" X 0.180" 4 4 3
22' X 5" X 0.180" 4 4 4
25' X 4" X 0.180" 4 3 2
25' X 5" X 0.180" 4 4 3
27' X 5" X 0.180" 4 4 3
27' X 6" X 0.180" 4 4 4
30' X 5" X 0.180" 4 3 1
30' X 6" X 0.180" 4 4 3
35' X 6" X 0.180" 4 3 1
Maximum Number of Fixtures @ 0˚ Tilt
Maximum Wind Speed
80 MPH 90 MPH 100 MPH
15' X 4" X 0.120" 4 4 4
17' X 4" X 0.120" 4 4 3
17' X 5" X 0.120" 4 4 4
20' X 4" X 0.120" 4 3 2
20' X 4" X 0.180" 4 4 4
20' X 5" X 0.120" 4 4 4
22' X 4" X 0.180" 4 4 3
22' X 5" X 0.180" 4 4 4
25' X 4" X 0.180" 4 3 2
25' X 5" X 0.180" 4 4 4
27' X 5" X 0.180" 4 4 3
27' X 6" X 0.180" 4 4 4
30' X 5" X 0.180" 4 3 2
30' X 6" X 0.180" 4 4 4
35' X 6" X 0.180" 4 4 2
Maximum Number of Fixtures @ 90˚ Tilt
Maximum Wind Speed
80 MPH 90 MPH 100 MPH
15' X 4" X 0.120" 2 2 1
17' X 4" X 0.120" 2 1 1
17' X 5" X 0.120" 4 3 2
20' X 4" X 0.120" 1 1 0
20' X 4" X 0.180" 3 2 1
20' X 5" X 0.120" 2 2 1
22' X 4" X 0.180" 2 1 1
22' X 5" X 0.180" 4 3 2
25' X 4" X 0.180" 2 1 1
25' X 5" X 0.180" 3 2 1
27' X 5" X 0.180" 2 1 1
27' X 6" X 0.180" 4 3 2
30' X 5" X 0.180" 2 1 0
30' X 6" X 0.180" 3 2 1
35' X 6" X 0.180" 2 1 0
Maximum Number of Fixtures @ 45˚ Tilt
Maximum Wind Speed
80 MPH 90 MPH 100 MPH
15' X 4" X 0.120" 3 2 2
17' X 4" X 0.120" 3 2 1
17' X 5" X 0.120" 4 3 3
20' X 4" X 0.120" 2 1 1
20' X 4" X 0.180" 3 2 2
20' X 5" X 0.120" 3 2 2
22' X 4" X 0.180" 3 2 1
22' X 5" X 0.180" 4 3 2
25' X 4" X 0.180" 2 1 1
25' X 5" X 0.180" 4 3 2
27' X 5" X 0.180" 3 2 1
27' X 6" X 0.180" 4 4 3
30' X 5" X 0.180" 2 1 1
30' X 6" X 0.180" 4 3 2
35' X 6" X 0.180" 3 2 1
Maximum Number of Fixtures @ 0˚ Tilt
Maximum Wind Speed
80 MPH 90 MPH 100 MPH
15' X 4" X 0.120" 4 3 2
17' X 4" X 0.120" 3 2 2
17' X 5" X 0.120" 4 4 3
20' X 4" X 0.120" 2 1 1
20' X 4" X 0.180" 4 3 2
20' X 5" X 0.120" 4 3 2
22' X 4" X 0.180" 4 3 2
22' X 5" X 0.180" 4 4 3
25' X 4" X 0.180" 3 2 1
25' X 5" X 0.180" 4 3 2
27' X 5" X 0.180" 4 3 2
27' X 6" X 0.180" 4 4 3
30' X 5" X 0.180" 3 2 1
30' X 6" X 0.180" 4 4 2
35' X 6" X 0.180" 4 2 1
Bolt
Circle
PRICE
INCLUDES
SHIPPING
400-watt Fixtures and Below
FLOODLIGHTS & POLES
80 Free Shipping on Orders Over $500
Mounting Options
Mounting hardware not included.
120˚ (TYP)
90˚ (TYP) 2' – 0" RAD.
2' – 0" RAD.
2'–10"
1'– 0"
3'–5"
1'– 0"
2'– 6" 2'– 6" 2'– 6"
1'– 0"
1'– 0"
2'– 6" 2'– 6"
3'– 0"
120˚ (TYP)
90˚ (TYP) 2' – 0" RAD.
2' – 0" RAD.
2'–10"
1'– 0"
3'–5"
1'– 0"
2'– 6" 2'– 6" 2'– 6"
1'– 0"
1'– 0"
2'– 6" 2'– 6"
3'– 0"
Bullhorns
Double @ 180˚
CAT.# %E-PT2E180DB
$17090
Triple @ 180˚
CAT.# %E-PT3E180DB
$20490
120˚ (TYP)
90˚ (TYP) 2' – 0" RAD.
2' – 0" RAD.
2'–10"
1'– 0"
3'–5"
1'– 0"
2'– 6" 2'– 6" 2'– 6"
1'– 0" 1'– 0"
2'– 6" 2'– 6"
3'– 0"
120˚ (TYP)
90˚ (TYP) 2' – 0" RAD.
2' – 0" RAD.
2'–10"
1'– 0"
3'–5"
1'– 0"
2'– 6" 2'– 6" 2'– 6"
1'– 0" 1'– 0"
2'– 6" 2'– 6"
3'– 0"
(All Steel Bullhorn tenons measure 2-3/8" O.D. and accommodate an e-conolight adjustable slip fitter.)
120˚ (TYP)
90˚ (TYP) 2' – 0" RAD.
2' – 0" RAD.
2'–10"
1'– 0"
3'–5"
1'– 0"
2'– 6" 2'– 6" 2'– 6"
1'– 0" 1'– 0"
2'– 6" 2'– 6"
3'– 0"
120˚ (TYP)
90˚ (TYP) 2' – 0" RAD.
2' – 0" RAD.
2'–10"
1'– 0"
3'–5"
1'– 0"
2'– 6" 2'– 6" 2'– 6"
1'– 0" 1'– 0"
2'– 6" 2'– 6"
3'– 0"
WALL MOUNT
BOX WITH 2-3/8"
O.D. TENON
CAT.#
E-ACWM1DB
$2990
WALL MOUNT
BRACKET WITH
2-3/8" O.D.
TENON
CAT.#
E-ACWM2DB
$1890
90° WALL
MOUNT
BRACKET WITH
2-3/8" O.D.
TENON
CAT.#
E-ACWM4DB
$3499
WALL MOUNT PLATE
Requires E-ACE see page 68
CAT.# E-ACWM3DB
$1399
4" SQUARE POLE MOUNT
WITH 2-3/8" O.D. TENON
For mounting one fixture on
existing pole. O.D. 3.5" square.
CAT.# E-ACPB1A4Z
$3199
3.5"
(89 mm)
4" sq.
(102 mm)
3"
(76 mm)
Back
Front
4.8" sq.
(122 mm)
3.8"
(97 mm)
4" sq.
(102 mm)
2.38"
(60 mm)
8"
(203 mm)
6"
(152
mm)
4" sq.
(102 mm)
2.38"
(60 mm)
PRICE
INCLUDES
SHIPPING
Quad @ 180˚
CAT.# %E-PT4E180DB
$25590
GROUND MOUNT POST
Use with 2" adjustable fitter.
Wiring or conduit feeds through post base.
Overall: 24"
Tube: 18"H x 2.4"D
Base: 4.9"W x 6.3"L
CAT.# E-ACGM1DB
$3390
CONDUIT SLIP FITTER
Cast aluminum hub provides a threaded
entry for the 1/2" adjustable fitter and slips
over a 2-3/8" O.D. pipe or tenon.
CAT.# E-ACMNH2DB
$1190
120˚ (TYP)
90˚ (TYP) 2' – 0" RAD.
2' – 0" RAD.
2'–10"
1'– 0"
3'–5"
1'– 0"
2'– 6" 2'– 6" 2'– 6"
1'– 0" 1'– 0"
2'– 6" 2'– 6"
3'– 0"
Triple @ 120˚
CAT.# %E-PT3E120DB
$19990
Quad @ 90˚
CAT.# %E-PT4E090DB
$24090
FLOODLIGHTS & POLES
81
www.e-conolight.com 888.243.9445
Premium
Compact Floodlight
PSMH 70-watt Pulse-Start Metal Halide
• 120/277V HX ballast NPF
CAT.# E-CF9M07D(*)
Replacement lamp
CAT.# ~MH070ME
$9099
$10.90
HPS 70-watt High-Pressure Sodium
• 120V Reactor ballast NPF
CAT.# E-CF9H071(*)
Replacement lamp
CAT.# ~HP070M
$7299
$5.25
150-watt High-Pressure Sodium
• 120V Reactor ballast NPF
CAT.# E-CF9H151(*)
Replacement lamp
CAT.# ~HP150M
$7299
$5.25
CFL 26/32/42-watt Compact
Fluorescent
• 120-277V Electronic universal ballast
CAT.# E-CF9F42U(*)
Triple Tube Replacement lamp
Ordered separately. See page 109.
$5699
• Seamless die-cast aluminum housing
• Die-cast aluminum lens frame with silicone gasket, provide complete
seal
• Clear, double-strength heat-tempered glass lens
• Included adjustable fitter allows for directional aiming in 5° increments.
Threaded lower fitter mounts to 1/2"-14 NPSM knockout.
• E-coat epoxy primer with five layers of protection
• Super durable dark- or medium-bronze powder topcoat
• UL Listed for wet locations
• 5-year finish warranty
• 3-year fixture warranty
• 1-year lamp warranty
• Assembled in the USA
Features:
Applications – Building facades, displays, uplighting and signs. Also effective as security lighting, for storage areas and commercial sites.
Typical Mounting Height: 8 to 20 feet
Accessories: (No combination of Wire Guard, Deep Baffle, or Glare Shield can be used.)
(*) Specify finish color: Z=Dark Bronze, M=Medium Bronze
Wire Guard
CAT.# E-CF9/WG
(Black)
$999
Deep Baffle
CAT.# E-CF9/DBM
(Medium Bronze)
CAT.# E-CF9/DBZ
(Dark Bronze)
$1799
CAT.# E-CF9/GSM
(Medium Bronze)
CAT.# E-CF9/GSZ
(Dark Bronze)
$2099
Glare Shield
Mounting Box w/Stake, Cord, & PlugMounting Box
CAT.# E-GAMNB2M
(Medium Bronze)
CAT.# E-GAMNB2DB
(Dark Bronze)
$3790
CAT.# E-GAMNB1M
(Medium Bronze)
CAT.# E-GAMNB1DB
(Dark Bronze)
$2190
CAT.# E-ACMNH2M
(Medium Bronze)
CAT.# E-ACMNH2DB
(Dark Bronze)
$1190
Conduit Slipfitter
Ground Mount Post
CAT.# E-ACGM1M
(Medium Bronze)
CAT.# E-ACGM1DB
(Dark Bronze)
$3390
One lamp included
Fluorescent lamp ordered separately.
See page 101.
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
Same as the NS Series
from Ruud Lighting Direct
A Cree Company
6-1/4"H x 9-3/4"W x 4-3/4"D
Weight: 5-10 lbs.
26%
SAVE
UP TO
FLOODLIGHTS & POLES
82 Free Shipping on Orders Over $500
7-1/2"H x 9"W x 9"D
Weight: 7-9 lbs.
8-3/4"H x 12-3/8"W x 12-3/8"D
Weight: 12-17 lbs.
9-inch Canopy Light
Applications – Security, entryway and perimeter lighting. Also recommended for parking garages, shopping area walkways and exterior canopies.
Typical Mounting Height: 10 to 20 feet Typical Spacing: 1 to 1.5 times the mounting height
Applications – Security, entryway and perimeter lighting. Also recommended for parking garages, shopping area walkways and exterior canopies.
Typical Mounting Height: 8 to 18 feet Typical Spacing: 1 to 1.5 times the mounting height
Lamp(s) included
Lamp included
PSMH
(White)
(Bronze)
70-watt Pulse-Start
Metal Halide
• 120-volt HX ballast NPF
CAT.# E-CC1M071W
CAT.# E-CC1M071Z
Replacement lamp
CAT.# ~MH070MO
$10.90
CFL
(White)
(Bronze)
42-watt Compact
Fluorescent
• 120-volt Electronic ballast
CAT.# E-CC1F421W
CAT.# E-CC1F421Z
Replacement lamp
CAT.# ~CF42T4/41
$3099
$3.70
HPS
(White)
(Bronze)
70-watt
High-Pressure Sodium
• 120-volt Reactor ballast NPF
CAT.# E-CC1H071W
CAT.# E-CC1H071Z
Replacement lamp
CAT.# ~HP070M
$4790
$5.25
PSMH
(White)
(Bronze)
100-watt
Pulse-Start Metal Halide
• 120/277-volt HX ballast HPF
CAT.# E-CC2M10DW
CAT.# E-CC2M10DZ
Replacement lamp
CAT.# ~MH100MO
$8690
$10.90
(White)
(Bronze)
150-watt
Pulse-Start Metal Halide
• 120/208/240/277V HX ballast
HPF
CAT.# E-CC2P15QW
CAT.# E-CC2P15QZ
Replacement lamp
CAT.# ~PS150MO
$9890
$9.90
CFL
(White)
Two 42-watt
Compact Fluorescent
• 120-277V Electronic universal
ballast
CAT.# E-CC2F84UW
Replacement lamp
CAT.# CF42T4/41
$6290
$3.70
12-inch Canopy Light
• Heavy-duty die-cast aluminum housing, with white or dark bronze
polyester powder-coat finish
• UV-stabilized polycarbonate prismatic refractor
• 1/2-inch NPS tapped for conduit, two on sides, one on top (9" only)
• 1/2-inch NPS tapped for conduit, three sides, one on top (12" only)
• CFL minimum starting temperature: 0˚F.
CFL optimum starting temperature: 40˚F+
• UL Listed for wet locations
• 1-year warranty
Features:
LED AVAILABLE
See pages 16-19
$4599
$5990
CANOPY
83
www.e-conolight.com 888.243.9445
• Durable and seamless die-cast
aluminum housing
• Rough-in 12.3" square hole
required for fixture installation
• Includes four adjustable steel
“L” brackets for mounting to
various ceiling thicknesses
• Large wiring compartment with
access from above or below
the ceiling line, for ease of field
wiring
• Four (2 in – 2 out) #12AWG
(90°C) through-branch circuit
conductors
• Specular aluminum reflector
• Lens assembly consists of rigid
aluminum frame with white
ultra-durable powder topcoat
and high-impact, #P73 crystal
tempered glass
• HID fixtures are provided
with an insulation detector,
which will deactivate fixture
if inadvertently covered with
insulation
• UL Listed for wet locations
• 5-year finish warranty, 3-year
fixture warranty, 1-year lamp
warranty
• Assembled in the USA
Features:
Accessory:
CAT.#
E-RC3/LP12
$4299
2x2 Lay-in Panel
Field-installed Lay-in Panel
supports the fixture while replacing
a standard 24" square recessed
ceiling tile. Steel panel finished with
a white durable powder coat paint.
Applications – Security, entryway and perimeter lighting. Also recommended for parking garages, shopping area walkways and exterior cano-
pies. Typical Mounting Height: 8 to 18 feet Typical Spacing: 1 to 1.5 times the mounting height
5"H x 12"W x 12"D
(Trim frame 13.3" square)
Weight: 13-21 lbs.
PSMH 70-watt Pulse-Start
Metal Halide
• 120V HX ballast HPF
CAT.# E-RC3M071W
Replacement lamp
CAT.# ~MH070ME
$17399
$10.90
100-watt Pulse-Start
Metal Halide
• 120V HX ballast HPF
CAT.# E-RC3M101W
Replacement lamp
CAT.# ~MH100ME
$17399
$10.40
150-watt Pulse-Start
Metal Halide
• 120V HX ballast HPF
CAT.# E-RC3P151W
Replacement lamp
CAT.# ~PS150ME
$18099
$9.90
CFL 26/32/42-watt Compact
Fluorescent
• 120-277V Electronic universal bal-
last
CAT.# E-RC3F42UW
Triple Tube Replacement lamp
Ordered separately. See page 109.
$13899
Premium Canopy Lights
One lamp included
Fluorescent lamp ordered separately.
See page 109.
Premium Recessed
Canopy Light
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
Same as the RC0 Series
from Ruud Lighting
A Cree Company
LED AVAILABLE
See page 18
7%
SAVE
UP TO
CANOPY
84
CAT.# E-CS3/WG
$699
CAT.# E-CS4/WG
$990
Applications – Security, entryway and perimeter lighting. Also recommended for parking garages, shopping area walkways and exterior canopies.
Typical Mounting Height: 8 to 25 feet Typical Spacing: 1 to 1.5 times the mounting height
PSMH 70-watt Pulse-Start
Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-CS3M07QW
Replacement lamp
CAT.# ~MH070ME
$14399
$10.90
100-watt Pulse-Start
Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-CS3M10QW
Replacement lamp
CAT.# ~MH100ME
$14399
$10.40
150-watt Pulse-Start
Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-CS3P15QW1
Replacement lamp
CAT.# ~PS150ME
$15199
$9.90
250-watt Pulse-Start
Metal Halide
• 120/208/240/277V CWA ballast HPF
CAT.# E-CS4P25QW2
H75 Replacement Lamp
CAT.# ~PS250H75
$22399
$25.99
HPS 250-watt
High-Pressure Sodium
• 120/208/240/277V CWA ballast HPF
CAT.# E-CS4H25QW2
Replacement lamp
CAT.# ~HP250
$21599
$6.00
CFL 26/32/42-watt Compact
Fluorescent
• 120-277V Electronic universal bal-
last
CAT.# E-CS3F42UW
Triple Tube Replacement lamp
Ordered separately. See page 109.
$10999
SMALL
SMALL
SMALL
SMALL
SMALL
LARGE
LARGE
• Durable and seamless die-cast aluminum housing with super durable
white powder topcoat
• Fixture is designed for direct mount over a recessed junction box
• Two 1/2" conduit openings provided for wire supply
• Surface Box is required for 150W PSMH when mounting to
comubustible surface such as plaster or drywall
• Surface Box comes standard for 250W PSMH and HPS
• Lens assembly consists of rigid aluminum frame and high-impact, #P73
crystal tempered glass
• Specular aluminum reflector
• E-coat epoxy primer with five layers of protection
• UL Listed for wet locations
• 5-year finish warranty
• 3-year fixture warranty
• 1-year lamp warranty
• Assembled in the USA
Features:
Accessories:
Wire Guard
CAT.#
E-CS3&4/SMBK
$1999
Surface Box
For use where surface wiring
is required. Five threaded and
closed 1/2" conduit entries for
surface wiring.
LARGE
1 Surface Box required for 150W PSMH if mounting to combustible surface
2 Surface Box comes standard with 250 PSMH and HPS fixtures
SMALL
LARGE
"A" "B"
12.0" Square 5.0"
16.0" Square 6.5"
Weight: 19-21 lbs. (small)
29 lbs. (large)
A
B
One lamp included
Fluorescent lamps ordered separately.
See page 101.
LED AVAILABLE
See pages 16-19
Premium
Canopy Light
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
Same as the CL0 Series
from Ruud Lighting
A Cree Company
Full assortment of canopy & parking available at www.e-conolight.com
7%
SAVE
UP TO
CANOPY
85
Applications – Security, pathway and perimeter lighting; ideal for entry ways, walkways and corridors.
Typical Mounting Height: 8 to 20 feet Typical Spacing: 2 to 3 times the mounting height
One lamp included
Applications – Security, pathway and perimeter lighting; ideal for entry ways, walkways and corridors.
Typical Mounting Height: 8 to 20 feet Typical Spacing: 2 to 3 times the mounting height
Premium Square Low-Profile Canopy Light
LAMP
WATTAGE
HOUSING
SIZE
WITHOUT
PHOTOCELL
PRICE 120V
PHOTOCELL
PRICE 277V
PHOTOCELL
PRICE
CFL 21W CFL E-CS1F211W (120V)
E-CS1F212W (277V) $59.99 E-CS1F211WP $67.99 E-CS1F212WP $67.99
28W CFL E-CS2F28UW $60.99 E-CS2F281WP $69.99 E-CS2F282WP $69.99
38W CFL E-CS2F38UW $60.99 E-CS2F381WP $69.99 E-CS2F382WP $69.99
SMALL
SMALL
• Meets Americans with Disability Act Accessibility Guidelines (ADAAG)
• Translucent polycarbonate lens
• Knockouts are provided for 1/2" conduit entry, mounting over single
gang J-box, 4" square or 4" octagonal J-boxes
• 120-277V universal electronic ballast (E-CS2F only)
• UL Listed for wet locations
• 5-year finish warranty, 3-year fixture warranty, 1-year lamp warranty
• Assembled in the USA
Features:
LARGE
LARGE
LARGE
Premium Rectangular Soffit Light
Weight: 5-11 lbs.
LAMP
WATTAGE
CATALOG #
MEDIUM BRONZE
CATALOG #
DARK BRONZE
PRICE
PSMH 70W PSMH E-SR1M07QM E-SR1M07QZ $90.99
HPS 70W HPS E-SR1H07QM E-SR1H07QZ $56.99
CFL 26/32/42W
CFL E-SR1F42UM E-SR1F42UZ $56.99
• Durable die-cast aluminum housing
• Neoprene gasket on back of housing provides a watertight
mounting seal
• Silicone rubber seal between housing and lens ensures a watertight seal
• Steel fixture mounting bar and threaded nipple provide direct mounting
to recessed J-box
• White polycarbonate lens is fastened to housing with phillips-head
captive stainless-steel screws
• 120/208/240/277V HX ballast HPF (70W PSMH & HPS)
• 120-277V universal electronic ballast HPF (42W CFL)
• E-coat epoxy primer with five layers of protection
• Super durable medium- or dark-bronze powder topcoat
• UL Listed for wet locations
• 5-year finish warranty, 3-year fixture warranty, 1-year lamp warranty
• Assembled in the USA
Features:
2.3"
4.2"
10" 6"
8.5"
6.5"
Surface Mounting Box Accessories available. See page 84 for more information.
8"Square x 3"D
10"Square x 3-7/8"D
Weight: 3.5 lbs. (small)
5.5 lbs. (large)
SPACING RATIO =
DISTANCE ALONG
SPACING RATIO =
DISTANCE ACROSS
MOUNTING HEIGHT
SPACING RATIO =
DISTANCE ALONG
SPACING RATIO =
DISTANCE ACROSS
MOUNTING HEIGHT
DISTRIBUTION PATTERN
Bird's Eye View
Ceiling Mounted
60W Incandescent version available online! CAT#. E-SR1I061, $28.99
Find replacement lamps at
www.e-conolight.com
One lamp included
Fluorescent lamps ordered separately.
See page 101.
Find replacement lamps at
www.e-conolight.com
A Cree Company
A Cree Company
Full assortment of canopy & parking available at www.e-conolight.com
CANOPY
86 Free Shipping on Orders Over $500
• Extruded aluminum housing supplied internally
with a formed and channeled 16 gauge steel
frame
• Two silicone lens seals prevent moisture from
entering the lens
• Clear, super-durable polycarbonate lens with
specular reflector
• 120/208/240/277V HX ballast NPF (PSMH & HPS)
• 120-277V universal electronic ballast NPF
(42W CFL)
• Template and anchor bolts included
• E-coat epoxy primer with five layers of protection
• Super durable medium-bronze powder topcoat
• UL Listed for wet locations
• 5-year finish warranty,
3-year fixture warranty,
1-year lamp warranty
• Assembled in the USA
Features: Accessory:
LAMP
WATTAGE LENS TYPE
CATALOG #
FLAT TOP
CATALOG #
DOME TOP
CATALOG #
EXTENDED TOP
PRICE
PSMH 70W PSMH Clear Lens E-BR1M07QM E-BR2M07QM E-BR3M07QM $244.99
70W PSMH 180° Shielded Lens E-BR1M07QMA E-BR2M07QMA E-BR3M07QMA $258.99
100W PSMH Clear Lens E-BR1M10QM E-BR2M10QM E-BR3M10QM $244.99
100W PSMH 180° Shielded Lens E-BR1M10QMA E-BR2M10QMA E-BR3M10QMA $258.99
HPS 70W HPS Clear Lens E-BR1H07QM E-BR2H07QM E-BR3H07QM $244.99
70W HPS 180° Shielded Lens E-BR1H07QMA E-BR2H07QMA E-BR3H07QMA $258.99
CFL 26/32/42W CFL Clear Lens E-BR1F42UM E-BR2F42UM E-BR3F42UM $204.99
26/32/42W CFL 180° Shielded Lens E-BR1F42UMA E-BR2F42UMA E-BR3F42UMA $218.99
CAT.# E-BR/LVRK
(Black)
$5399
Internal Louver
Diameter: 8-7/8"
Height: 36" (Flat Top), 40-1/2" (Dome Top),
39-1/2" (Extended Flat Top)
Weight: 26-34 lbs. One lamp included for
PSMH & HPS fixtures
Fluorescent lamp
ordered
separately for
CFL fixtures.
See page 101.
Premium HID
Round Bollard
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
In-Ground & Surface Mount
Applications – For accenting architecture or lighting landscape
areas
In-Ground Mount
PAR20 35W CMH
Flat Prole
Size: 5.4"L x 6.5"H x 3.3" dia
CAT. # E-GLGC03FDK
$18490
Surface Mount
PAR20 35W CMH
Flat Prole
Size: 5.4"L x 6.5"H x 3.3" dia
CAT. # E-GLSC03FDK
$15490
In-Ground Mount
PAR30L 70W CMH
Flat Prole
Size: 6.5"L x 7.3"H x 4.4" dia
CAT. # E-GLGC07FQK
$17990
Surface Mount
PAR30L 70W CMH
Flat Prole
Size: 6.5"L x 7.3"H x 4.4" dia
CAT. # E-GLSC07FQK
$14490
In-Ground Mount
PAR38 100W CMH
Flat Prole
Size: 7.0"L x 7.5"H x 5.5" dia
CAT. # E-GLGC10FDK
$21999
Surface Mount
PAR38 100W CMH
Flat Prole
Size: 7.0"L x 7.5"H x 5.5" dia
CAT. # E-GLSC10FDK
$18999
CMH FLOOD LAMP
In-Ground Mount
PAR20 35W CMH
Shrouded Prole
Size: 7.8"L x 6.5"H x 3.3" dia
CAT. # E-GLGC03SDK
$19490
Surface Mount
PAR20 35W CMH
Shrouded Prole
Size: 7.8"L x 6.5"H x 3.3" dia
CAT. # E-GLSC03SDK
$16490
In-Ground Mount
PAR30L 70W CMH
Shrouded Prole
Size: 9.7"L x 7.3"H x 4.4" dia
CAT. # E-GLGC07SQK
$13699
Surface Mount
PAR30L 70W CMH
Shrouded Prole
Size: 9.7"L x 7.3"H x 4.4" dia
CAT. # E-GLSC07SQK
$15490
In-Ground Mount
PAR38 100W CMH
Shrouded Prole
Size: 10.9"L x 7.5"H x 5.5" dia
CAT. # E-GLGC10SDK
$22999
Surface Mount
PAR38 100W CMH
Shrouded Prole
Size: 10.9"L x 7.5"H x 5.5" dia
CAT. # E-GLSC10SDK
$19999
CMH SPOT LAMP
• Die-cast copper-free aluminum housing
• PAR20 and PAR30 lens is tempered glass
• PAR38 lens is borosilicate glass
• Die-cast copper-free aluminum lens frame
• Mounting is accomplished with a watertight in-ground
ballast compartment
• Two 1/2" threaded hubs are included for conduit entry
• Fixture is completely sealed and includes a silicone
O-ring sealing system
• Fixture head rotates 358°
• Fixture head has a tilt range of 125° on the
adjust able fitter and locks into position
• Swivel is die-cast copper-free aluminum with
threaded end 1/2"-14 NPSM
• E-coat epoxy primer with textured ultra-durable
powder topcoat
• Flat profile fixtures include lamp with flood beam spread
• Shrouded profile fixtures include lamp with
spot beam spread
• UL and cUL Listed for wet locations
• 1-year warranty
Features:
Ceramic Metal
Halide fixtures
include lamps &
ballasts from
A Cree Company
LINE VOLTAGE LANDSCAPE & PATHWAY
87
www.e-conolight.com 888.243.9445
Incandescent Surface Mount
PAR20 thru 50W
Flat Prole
Size: 5.4"L x 6.5"H x 3.3" dia
CAT. # E-GLSP20F1K
$3790
PAR20 thru 50W
Shrouded Prole
Size: 7.8"L x 6.5"H x 3.3" dia
CAT. # E-GLSP20S1K
$4390
PAR30 thru 75W
Flat Prole
Size: 6.5"L x 7.3"H x 4.4" dia
CAT. # E-GLSP30F1K
$3990
PAR30 thru 75W
Shrouded Prole
Size: 9.7"L x 7.3"H x 4.4" dia
CAT. # E-GLSP30S1K
$4790
PAR38 thru 150W
Flat Prole
Size: 7.0"L x 7.5"H x 5.5" dia
CAT. # E-GLSP38F1K
$4890
PAR38 thru 150W
Shrouded Prole
Size: 10.9"L x 7.5"H x 5.5" dia
CAT. # E-GLSP38S1K
$5490
Accessories: For use with incandescent surface mount fixtures only
Ground Mount Post
Wiring or conduit feeds
through base of Ground
Mount Post. Use with 2"
Conduit Slipfitter.
Overall: 24"
Tube: 18"H x 2.4"D
Base: 4.9"W x 6.3"L
CAT. # E-ACGM1K
$3390
Mounting Box with
Stake, Cord & Plug
Cast aluminum box provides
enclosed wiring chamber.
Supplied cover gasket ensures
watertight seal. Includes four ½"
conduit entries: top, back and
sides.
Stake: 6.5"
Cord: 10' gasketed cord with
120V straight blade plug
CAT. # E-GAMNB2K
$3790
Dual Mount
Junction Box Cover
For use with octagonal and
single gang junction boxes.
Includes adapter plate with
½" knockout(s) for mounting
two 120V xtures. Photocell
knockout provided.
1.5" H x 4.4" dia.
CAT. # E-GAJB2K
$1499
2" Conduit Sliptter
Cast aluminum hub provides
a threaded entry for the 1/2"
adjustable fitter and slips
over a 2-3/8" O.D. pipe or
tenon.
CAT. # E-ACMNH2K
$1190
Single Mount
Junction Box Cover
For use with octagonal and
single gang junction boxes.
Includes adapter plate with
½" knockout for mounting
one 120V xture. Photocell
knockout provided.
1.5" H x 4.4" dia.
CAT. # E-GAJB1K
$1499
Photocell (120V)
Photocell, eld installed for
use with single or dual mount
junction box covers.
CAT. # E-ACP1
$690
• Die-cast copper-free aluminum
housing and lens frame
• Fixture is completely sealed and
includes a silicone O-ring sealing
system
• Fixture head rotates 358°
• Fixture head has tilt range of 125°
on the adjust able fitter and locks
into position
• Swivel is die-cast copper-free
aluminum with threaded end 1/2"-
14 NPSM
• Junction box cover not included
• 120V incandescent fixtures, order
lamps separately.
• E-coat epoxy primer with textured
ultra-durable powder topcoat
• UL and cUL Listed for wet
locations
• 1-year warranty
Features:
Applications – For accenting architecture or lighting landscape areas
Lamps ordered separately. See page 105.
LED AVAILABLE
See page 5
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
LINE VOLTAGE LANDSCAPE & PATHWAY
88 Free Shipping on Orders Over $500
Sealed Well Light
0.4"
(10 mm)
17.6"
(446 mm)
16.6"
(423 mm)
0.4"
(10 mm)
2.4"
(61 mm
)
9.7" (245 mm)
6.3" (160 mm)
0.4"
(10 mm)
0.5"
(13 mm)
0.4"
(10 mm)
9.5"
(241 mm)
8.6"
(217 mm)
0.4"
(10 mm)
2.4"
(61 mm)
9.7" (245 mm)
6.3" (160 mm)
0.4"
(10 mm)
0.5"
(13 mm)
Accessories:
External Glare
Shield
Easily attaches to top cover
of xture with four black
stainless steel screws
(included). Not for use with
E-GALG.
CAT. # E-GAGS
$1590
External Linear
Grate
Provides cuto and glare
control and protects lens
from falling objects. Easily
attaches to top cover of
xture with four black
stainless steel screws
(included). Not for use with
E-GAGS.
CAT. # E-GALG
$1690
MR16 Thru 75W Max
120V
CAT.# E-GLWM161K $11490
PAR20/30/38 Fixture accommo-
dates PAR20, PAR30
or PAR38 lamps up to
150W max
120V
CAT.# E-GLWP381K $7490
CMH 35W, PAR30L Flood
30˚ Flood lamp included
120/277V HPF-HX
CAT.# E-GLWC03FDK $19490
35W, PAR30L Spot
10˚ Spot Lamp Included
120/277V HPF-HX
CAT.# E-GLWC03SDK $19490
70W, PAR30L Flood
40˚ Flood Lamp Included
120/208/240/277V HPF-HX
CAT.# E-GLWC07FQK $18490
70W, PAR30L Spot
10˚ Spot Lamp Included
120/208/240/277V HPF-HX
CAT.# E-GLWC07SQK $18490
100W, PAR38
Narrow Flood
25˚ Flood Lamp Included
120/277V HPF-HX
CAT.# E-GLWC10FDK $18790
100W, PAR38 Spot
15˚ Spot Lamp Included
120/277V HPF-HX
CAT.# E-GLWC10SDK $18790
MR16 Incandescent
PAR20/30/38 Series
Lamps ordered separately. See page 104.
Ceramic Metal Halide (CMH)
Lamp Included
Applications – For accenting architecture or lighting landscape areas
• Copper-free aluminum extrusion housing with rounded corners
• Die-cast copper-free aluminum lens frame
• Silicone sponge rubber gasket for watertight seal
• Convex lens is borosilicate glass
• Silicone compound between wiring compartment and housing
• Fully gasketed die-cast copper-free aluminum external wiring
compartment
• Lamp bracket rotates 360˚ degrees
• Adjustable internal lamp provides easy aiming
• UL Listed for wet locations
• 1-year warranty
• Lamp tilt range of:
MR16 = +/- 45˚
PAR20/30/38 = +/- 22˚
CMH PAR30L/PAR38 base = +/- 20˚
Features:
Fixtures include Philips
Ceramic Metal Halide
Lamps/Philips Advance Ballasts
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
LINE VOLTAGE LANDSCAPE & PATHWAY
89
www.e-conolight.com 888.243.9445
Transformer (300W & 600W)
Transformer
(manual control) 300W
8.2"L x 4.5"W x 4.8"D
CAT. # E-GX300
$11490
Transformer with Photocell/Time
Clock 300W
12.6"L x 4.5"W x 4.8"D
CAT. # E-GX302
$14990
Transformer
(manual control) 600W
15.6"L x 4.5"W x 4.8"D
CAT. # E-GX600
$17490
Transformer with Photocell/Time
Clock 600W
20.3"L x 4.5"W x 4.8"D
CAT. # E-GX602
$20990
10/3 12V Cable
12/2 12V Cable
Flexible Cable
E-conolight oers self-
sealing, #10 gauge, 3-wire
cable to allow longer runs
without typical voltage
drop.
The patented connector
allows quick and easy
connections without cutting
or splicing cable.
Features of 12V Cable:
•
UV-stabilized
•
Flame retardant
•
Self sealing
•
UL listed for wet
locations
10/3 Cable (black)
CAT. # E-GC103K
$199
/ foot
10/3 Cable (white)
CAT. # E-GC103W
$199
/ foot
10/3 Cable (black)
•
500' spool
CAT. # E-GC103KS
$49990
Maximum Cable Run
PVC Spine for 12/2 Cable
Adapts 2-wire cable to a 3-wire
connector system. Use one per
xture for secure connection. 20 per
package.
Not for use with
Aluminum Track.
CAT. # E-GT1P122K
$240
Accessories:
0
50
100
150
200
250
300
350
400
450
500
550
600
650
100 200 300 400 500 600
Wattage Total (on transformer)
Distance In Feet
10/3 Cable
10/2
Cable
12/2
Cable
Use the chart below to compare our 10/3 cable to typical 12/2 cable and
see the advantage in distance and total wattage load. Figure total wattage
(both circuits combined) for the xtures used by referring to bottom of
chart. Follow the line up until you reach the RED "10/3 Cable" line. Read
across the chart to "Distance in Feet". This is the maximum recommended
length of cable for your system.
To achieve optimum performance, e-conolight landscape products
should be used with e-conolight transformers and cable. Field
modification of product may lead to fixture malfunction or failure and
void the product warranty.
LOW VOLTAGE LANDSCAPE
AND PATHWAY FIXTURES
AVAILABLE ON PAGES 90-91
12/2 Cable (black)
•
250' length spool
•
Includes 20 PVC Spines
(E-GT1P122K) for
12/2 conversion
CAT. # E-GC122K
$9990
With landscape transformer or fixture purchase only.
Our 12-volt dual-circuit magnetic
transformers are available in 300-
and 600-watt. Rocker-type ON/
OFF switches, with built-in circuit
breakers provided for each 12-volt
circuit. Breaker switches are thermally
insensitive and allow each circuit to be
switched independently.
Heavy-duty terminal lugs are provided
for the 12-volt cable connectors.
Terminals are provided for each
circuit, making it easy to split branch
circuits and loop systems. The 6-foot
power cord plugs into a 120-volt GFI
receptacle; unit may be permanently
wired.
Photocell/Time Clock
The Photocell-ON/Time clock-OFF option means no daily manual control
is necessary. Controlled by a photocell, the lighting will click on at dusk
regardless of the season. The xtures operate during a period of time
determined by the user, then the time clock automatically turns the system o.
L
W
D
(shown with cover removed &
optional photocell time clock)
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
LOW VOLTAGE LANDSCAPE & PATHWAY
90 Free Shipping on Orders Over $500
Path Lighting
• Stake & 18W lamp
included
CAT. # E-GP09K
$3590
• Stake & 18W lamp
included
CAT. # E-GP44K
$3990
• Stake & 18W lamp
included
CAT. # E-GP19K
$2190
• Stake & 18W lamp
included
CAT. # E-GP45K
$3590
• Stake & 18W lamp
included
CAT. # E-GP41K
$5799
• Stake & 18W lamp
included
CAT. # E-GP47K
$3990
• Stake & 18W lamp
included
CAT. # E-GP48K
$3990
• Stake & 18W lamp
included
CAT. # E-GP49K
$4999
14" H (18W lamp included)
Dual directional bollard.
Available in black nish.
E-GA19 friction-t stake
included.
CAT. # E-GP62K
$4490
4.8"
(121 mm)
18.3"
(463 mm)
1.6"
(41 mm)
Ø 0.75"
(19 mm)
E-GP09K
17.5"
(445 mm)
8"
(203 mm)
Ø 1"
(25 mm)
3.9"
(100 mm)
E-GP44K
6"
(152 mm)
5"
(127 mm)
ø 0.5"
(13 mm)
17"
(432 mm)
Stake
E-GP19K
4.5"
(114 mm)
12.3"
(311 mm)
Ø 1"
(25 mm)
3.4"
(86 mm)
E-GP45K
7.3"
(108 mm)
22.3"
(565 mm)
ø 0.397"
(10 mm)
E-GP41K
4.5"
(114 mm)
1.4"
(36 mm)
20"
(508 mm)
ø 1"
(24 mm)
E-GP47K
20"
(508 mm
)
ø 0.75"
(19 mm)
5.4"
(137 mm)
3.6"
(92 mm)
E-GP48K
8"
(203 mm)
2.6"
(66 mm)
21.5"
(546 mm)
Ø 1"
(25 mm)
E-GP49K
ø 2.5"
(64 mm)
14"
(356 mm)
E-GP60K
ø 2.5"
(64 mm)
14"
(356 mm)
E-GP62K
14" H (18W lamp included)
Single directional bollard.
Available in black nish.
E-GA19 friction-t stake
included.
CAT. # E-GP60K
$4490
• Cast aluminum shade
• Extruded aluminum tube
stanchion
• Black stainless-steel hardware
• Fixture includes 12V, 18W
(#1141) lamp. 26W maximum
(#1156).
• Solid, die-formed nickel-plated
brass socket with stainless-
steel spring
• 5' Patented pigtail connector
is molded polycarbonate, with
nickel plated beryllium copper
contact pins
• E-coat epoxy primer with black
textured ultra-durable powder
topcoat
• UL Listed for wet locations
• 1-year warranty
Features:
Applications – For accenting architecture or lighting landscape areas.
Cable Connector
Allows for splicing of
10/3 cable or cable runs
o of main cable. 150W
max through dual cable
connector. PVC spine
(E-GT1P122K) is required
when using 12/2 cable
(see pg. 97)
CAT. # E-GA13W
(White)
$1390
CAT. # E-GA13K
(Black)
$1190
Pigtail & Connector
18/2 SPT is 5' long, molded
black polycarbonate with
nickel plated beryllium
copper contact pins.
For converting other
manufacturers' product
to work on 10/3 cable;
to extend length of
connectors. PVC spine
(E-GT1P122K) is required
when using 12/2 cable
(see pg. 89)
CAT. # E-GA08
$590
Accessories:
Consult factory for replacement stakes
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
LOW VOLTAGE LANDSCAPE & PATHWAY
91
www.e-conolight.com 888.243.9445
• Trims are heavy gauge
die-formed
aluminum with reverse louver
• Black stainless-steel hardware
• Louver extends 3/8" from surface
of wall.
Trim overlaps box 1/2" on all
sides
• Solid, die-formed nickel-plated
brass socket with stainless-steel
spring
• 5' pigtail connector is molded
polycarbonate,
with nickel plated beryllium
copper contact pins
• E-coat epoxy primer with textured
ultra-durable powder topcoat
• UL Listed for wet locations
• 1-year warranty
Directional / Step / Well Lighting
MR16 bi-pin 50W max
E-GA07 friction-t stake
included.
CAT. # E-GD80K
$1999
PAR36 75W max
E-GA07 friction-t stake
included.
CAT. # E-GD81K
$5490
MR16 bi-pin 20W max
Stake included
CAT. # E-GD20K
$2999
6.5"
(165 mm)
2.9"
(73 mm)
3.9"
(98 mm)
2.6"
(65 mm)
Threaded End
1/2"-14 NPSM
0.75" (19 mm)
E-GD80K
2.4"
(60 mm)
3.4"
(86 mm)
1.9"
(48 mm)
9.4"
(238 mm)
GL20
E-GD20K
10.9"
(276 mm)
5.5"
(140 mm)
2"
(51 mm)
2.6"
(65 mm)
Threaded End
1/2"-14 NPSM
0.75" (19 mm)
E-GD81K
Rough-in opening:
2.25" x 4.125"
(57 mm x 105 mm)
Top View
5"
(127 mm)
1.9"
(48 mm)
0.375"
(10 mm)
3.3"
(83 mm)
E-GS50K
2.3"
(57 mm)
3.3"
(83 mm)
9.5"
(241 mm)
Rough-in opening:
2.375" x 8.125"
(60 mm x 206 mm)
Top View
0.375"
(10 mm)
E-GS51K
0.5"
(13 mm)
0.40
(10
mm
0.40"
(10 mm)
6.2"
(157 mm)
5.3"
(133 mm)
6.3" (160 mm)
E-GW70/71K
5.3"
(133 mm)
8"
(203 mm)
4.8"
(121 mm)
2.5"
(64 mm)
5.6"
(143 mm)
E-GW23K
1"
(25 mm)
7"
(178 mm)
5.6"
(143 mm)
E-GW23SK
13W #93 lamp included
CAT. # E-GS50K
$2999
(2) 13W #93 lamps
included
CAT. # E-GS51K
$3999
PAR36 25-50W max
Directional well light
moves up and down tube
CAT. # E-GW23K
$2590
PAR36 25-50W max
Directional well light (does
not move up and down tube)
CAT. # E-GW23SK
$1890
PAR36 50W max
CAT. # E-GW71K
$6999
MR16 bi-pin 75W max
CAT. # E-GW70K
$6190
• Die-cast copper-free aluminum
housing
• Tempered glass lens
• Fixture is completely sealed and
includes a silicone O-ring sealing
system
• Fixture head rotates 360° and tilt
range of 125° on the adjustable
fitter
• 5' pigtail connector is molded
polycarbonate, with nickel-plated
beryllium copper contact pins
• E-coat epoxy primer with textured
ultra-durable powder topcoat
• Die-cast copper-free aluminum
lens frame with a shrouded profile
(E-GD80K and E-GD81K only)
• Swivel is die-cast copper-free
aluminum with threaded end 1/2"-
14 NPSM. (E-GD80K and E-GD81K
only)
• UL Listed for wet locations
• 1-year warranty
Directional Features: MR16 lamps ordered separately. Provided by others.
Step Features:
• Extruded plastic housing
• 5' patented pigtail
connector included
• Outdoor use only
• UL listed for wet
locations
• 1-year warranty
Well Features: Outdoor use only. Consult factory for PAR36 lamps. MR16 lamps ordered separately. Provided by others.
Applications – For accenting architecture or lighting landscape areas.
• Copper-free aluminum extrusion
• Die-cast copper-free aluminum
lens frame
• Covers feature silicone sponge
rubber gasket for watertight seal
• Maximum internal lamp aiming
angle for MR16 ±45˚; PAR36 ±20˚
• Convex lens is borosilicate glass
• 5' pigtail connector is molded
polycarbonate, with nickel plated
beryllium copper contact pins
• E-coat epoxy primer with
textured ultra-durable powder
topcoat
• For outdoor use only
• UL Listed for wet locations
• 1-year warranty
See below for accessories
External Linear
Grate
Provides cuto and glare
control and protects lens
from falling objects. Easily
attaches to top cover of
xture with four black
stainless steel screws
(included). Not for use with
E-GAGS.
CAT. # E-GALG
$1690
External Glare
Shield
Easily attaches to top
cover of xture with
four black stainless
steel screws (included).
Not for use with E-
GALG.
CAT. # E-GAGS
$1590
Accessories: (for E-GW70K and E-GW71K)
Linear Grate
6.2" dia. Black cast aluminum
For E-GW23SK only.
CAT. # E-GALG23SK
$1090
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
STEP LIGHTS NOT SUITABLE
FOR INSTALLATION IN
POURED CONCRETE
LED AVAILABLE
See page 30
LOW VOLTAGE LANDSCAPE & PATHWAY
NEW!
92 Free Shipping on Orders Over $500
9-1/2"H x 9-1/8"W x 9-1/2"D
Weight: 9-10 lbs.
9-1/4"H x 14-1/8"W x 7-1/2"D
Weight: 11-17 lbs.
Applications – Security, pathway and perimeter lighting; ideal for entry ways, walkways and parking facilities.
Typical Mounting Height: 8 to 18 feet Typical Spacing: 2 to 3 times the mounting height
Applications – Security, pathway and perimeter lighting; ideal for entry ways, walkways and parking facilities.
Typical Mounting Height: 12 to 20 feet Typical Spacing: 2 to 3 times the mounting height
70/100-watt HID Wall Pack
100/150-watt HID Wall Pack
Accessory:
70-watt
Pulse-Start Metal Halide
• 120V HX ballast NPF
CAT.# E-WP2M071Z
Replacement lamp
CAT.# ~MH070ME
$6790
$10.90
100-watt
Pulse-Start Metal Halide
• 120/277V HX ballast HPF
CAT.# E-WP2M10DZ
Replacement lamp
CAT.# ~MH100ME
$7490
$10.40
HPS 70-watt High-Pressure
Sodium
• 120V Reactor ballast NPF
CAT.# E-WP2H071Z
Replacement lamp
CAT.# ~HP070M
$5590
$5.25
CAT.# E-ACP1
(120 volts)
$690
Photocell, field installed
CAT.# E-ACP2
(208/240/277 volts)
$690
• Heavy-duty, die-cast aluminum housing and door-hinge frame, with dark-
bronze polyester powder-coat finish
• Prismatic lens refractor, made of heat and shock resistant borosilicate
glass
• One-piece anodized aluminum reflector
• 1/2-inch NPT tapped back and two sides for conduit entrances
(70/100W only)
• 1/2-inch NPT tapped top and two side, rear knockouts for 1/2-inch
conduit or Junction box (150W only)
• Optional photocell available
• UL Listed for wet locations
• 1-year warranty
Features:
One medium base
lamp included
One medium base
lamp included
PSMH 100-watt
Pulse-Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-WP3M10QZ
Replacement lamp
CAT.# ~MH100ME
$7490
$10.40
150-watt
Pulse-Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-WP3P15QZ
Replacement lamp
CAT.# ~PS150ME
$9790
$9.90
HPS 150-watt
High-Pressure Sodium
• 120V Reactor ballast NPF
CAT.# E-WP3H151Z
Replacement lamp
CAT.# ~HP150M
$6990
$5.25
WALL PACKS
93
www.e-conolight.com 888.243.9445
9-3/4"H x 18"W x 9-3/8"D
Weight: 24-26 lbs.
9-3/4"H x 18"W x 13"D
Weight: 28-29 lbs.
Applications – Security, pathway and perimeter lighting; ideal for entry ways, walkways and parking facilities.
Typical Mounting Height: 15 to 25 feet Typical Spacing: 2 to 3 times the mounting height
Applications – Security, pathway and perimeter lighting; ideal for entry ways, walkways and parking facilities.
Typical Mounting Height: 20 to 30 feet Typical Spacing: 2 to 3 times the mounting height
250-watt HID Wall Pack
400-watt HID Wall Pack
Accessory:
PSMH 250-watt
Pulse-Start Metal Halide
CAT.# E-WP4P25QZ
H75 Replacement Lamp
CAT.# ~PS250H75
$14990
$29.90
PSMH 400-watt
Pulse-Start Metal Halide
CAT.# E-WP5P40QZ
H75 Replacement Lamp
CAT.# ~PS400H75
$15790
$31.90
CAT.# E-ACP1
(120 volts)
$690
Photocell, field installed
CAT.# E-ACP2
(208/240/277 volts)
$690
• 120/208/240/277V CWA ballast HPF
• Heavy-duty, die-cast aluminum housing and door-hinge frame, with dark-
bronze polyester powder-coat finish
• Prismatic lens refractor, made of heat-and-shock-resistant borosilicate
glass
• One-piece anodized aluminum reflector
• 1/2-inch NPS tapped two back, top and two sides for conduit entrances
(320/400W only)
• 1/2-inch NPT tapped top and two side, rear knockouts for 1/2-inch
conduit or Junction box (250W only)
• Optional photocell available
• UL Listed for wet locations
• 1-year warranty
Features:
One mogul base H75 Venture
lamp included for PSMH
1.25"
Version to be used only
when "Uniform" is 1.25"
or smaller in size.
example:
Preferred Master
Four Color
Black and White
Universal burn lamp included for HPS
One mogul base H75 Venture
lamp included for PSMH
1.25"
Version to be used only
when "Uniform" is 1.25"
or smaller in size.
example:
Preferred Master
Four Color
Black and White
Universal burn lamp included for HPS
WALL PACKS
94
250/400-watt Cutoff Wall Pack
Applications – Security, pathway and perimeter lighting; ideal for entry ways, walkways and other applications where control of spill light is
important. Typical Mounting Height: 250W–15 to 25 feet; 400W–20 to 30 feet Typical Spacing: 2 to 3 times the mounting height
9-1/4"H x 18-1/8"W x 17-1/4"D
Weight: 32-35 lbs.
PSMH 250-watt
Pulse-Start Metal Halide
• 120/208/240/277V CWA ballast HPF
CAT.# E-WPDP25QZ
H75 Replacement Lamp
CAT.# ~PS250H75
$13790
$29.90
HPS 250-watt High-Pressure
Sodium
• 120/208/240/277V CWA ballast HPF
CAT.# E-WPDH25QZ
Replacement lamp
CAT.# ~HP250
$9099
$6.00
400-watt
High-Pressure Sodium
• 120/208/240/277V CWA ballast HPF
CAT.# E-WPDH40QZ
Replacement lamp
CAT.# ~HP400
$9799
$6.25
Accessory:
CAT.# E-ACP1
(120 volts)
$690
Photocell, field installed
CAT.# E-ACP2
(208/240/277 volts)
$690
• Sturdy die-cast aluminum housing and lens frame, with dark-bronze polyester powder-coat finish
• Fixed cutoff glare shield to reduce light pollution
• Tempered-glass lens, thermal shock and impact resistant
• 1/2-inch NPT tapped and plugged holes located on top and two sides for easy wiring access (70/100/150-watt only)
• 1/2-inch NPT tapped and plugged holes located two on the back, one on the top and two sides for easy wiring access (250/400-watt only)
• Hinged door frame for easy relamping
• Optional photocell available
• UL listed for wet locations
• 1-year warranty
Features:
One mogul base H75 Venture
lamp included for PSMH
1.25"
Version to be used only
when "Uniform" is 1.25"
or smaller in size.
example:
Preferred Master
Four Color
Black and White
Universal burn lamp included for HPS
NOT FOR USE AS AN UPLIGHT
LED AVAILABLE
See pages 8-11
Full assortment of wall packs available at www.e-conolight.com
WALL PACKS
95
• Sturdy die-cast aluminum housing and lens frame, with dark-bronze
polyester powder-coat finish
• Adjustable cutoff glare shield
• Tempered glass lens, thermal shock and impact resistant
• One piece anodized aluminum reflector
• 1/2-inch NPT tapped back and two sides for conduit entrances
(70-100-watts only)
• 1/2-inch NPT tapped top and two sides for conduit entrances
(150-watts only)
• Optional photocell available
• UL Listed for wet locations
• 1-year warranty
Features:
42-watt Fluorescent Wall Pack
Applications – Security, pathway and perimeter lighting; ideal for entry ways, walkways and parking facilities.
Typical Mounting Height: 8 to 18 feet Typical Spacing: 2 to 3 times the mounting height
8-1/2"H x 8-3/8"W x 9"D
Weight: 3.6 lbs.
Adjustable Cutoff Wall Pack
Applications – Security, pathway and perimeter lighting; ideal for entry ways and walkways, espe-
cially where glare can be an issue Typical Mounting Height: 8 to 18 feet
Typical Spacing: 2 to 3 times the mounting height
8-3/8"H x 8-3/8"W x 11-7/8"D
Weight: 9-10 lbs.
25˚ of adjustability
9"H x 14-1/4"W x 11"D
Weight: 11-16 lbs.
25˚ of adjustability
One medium base
lamp included
PSMH 70-watt (SMALL)
Pulse-Start Metal Halide
• 120V HX ballast NPF
CAT.# E-WPAM071Z
Replacement lamp
CAT.# ~MH070ME
$7690
$10.90
150-watt (LARGE)
Pulse-Start Metal Halide
• 120/208/240/277V HX ballast HPF
• For non-combustible surfaces only
CAT.# E-WPAP15QZ
Replacement lamp
CAT.# ~PS150ME
$9390
$9.90
HPS 70-watt (SMALL)
High-Pressure Sodium
• 120V Reactor ballast NPF
CAT.# E-WPAH071Z
Replacement lamp
CAT.# ~HP070M
$4799
$5.25
150-watt (LARGE)
High-Pressure Sodium
• 120V Reactor ballast NPF
• For non-combustible surfaces only
CAT.# E-WPAH151Z
Replacement lamp
CAT.# ~HP150M
$6690
$5.25
• 120-volt Electronic ballast
• Sturdy die-cast aluminum housing and lens frame, with dark-bronze
polyester powder-coat finish
• UV stabilized prismatic polycarbonate refractor
• Heavy duty four-pin GX24q-4 socket
• One-piece anodized aluminum reflector
• 1/2-inch NPT tapped back and two sides for conduit entrances
• Optional photocell available
• Minimum starting temperature, 0˚F
• Optimum starting temperature, 40˚F+
• UL Listed for wet locations
• 1-year warranty
Features:
Accessory:
CAT.# E-ACP1
(120 volts)
$690
Photocell, field installed
CAT.# E-ACP2
(208/240/277 volts)
$690
One medium base
lamp included
One lamp included
CFL 42-watt Compact
Fluorescent
• Lamp Output: 3190 lumens
• Lamp Color Temperature: 4100K
• Weight: 3.6 lbs.
CAT.# E-WP1F421Z
Replacement lamp
CAT.# ~CF42T4/41
$3790
$3.70
SMALL
LARGE
SMALL
SMALL
LARGE
LARGE
LED AVAILABLE
See page 11
Full assortment of wall packs available at www.e-conolight.com
WALL PACKS
WHILE SUPPLIES LAST
96 Free Shipping on Orders Over $500
PSMH 70-watt Pulse-Start Metal Halide
• 120/208/240/277V HS ballast HPF
CAT.# E-WPC1M07Q(*)
Replacement lamp
CAT.# ~MH070ME
$12399
$10.90
100-watt Pulse-Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-WPC1M10Q(*)
Replacement lamp
CAT.# ~MH100ME
$12399
$10.40
150-watt Pulse-Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-WPC1P15Q(*)
Replacement lamp
CAT.# ~PS150ME
$13299
$9.90
150-watt Pulse-Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-WPC2P15Q(*)
Replacement lamp
CAT.# ~PS150E
$17899
$10.90
250-watt Pulse-Start Metal Halide
• 120/208/240/277V CWA ballast HPF
CAT.# E-WPC2P25Q(*)
Replacement lamp
CAT.# ~PS250BUE
$19299
$12.40
400-watt Pulse-Start Metal Halide
• 120/208/240/277V CWA ballast HPF
CAT.# E-WPC2P40Q(*)
Replacement lamp
CAT.# ~PS400PBUE
$19899
$12.90
HPS 100-watt High-Pressure Sodium
• 120/208/240/277V HX ballast HPF
CAT.# E-WPC1H10Q(*)
Replacement lamp
CAT.# ~HP100M
$12099
$5.25
CFL 57-watt Compact Fluorescent
• 120V-277V universal electronic ballast
CAT.# E-WPC2F57U(*)
Replacement lamp
CAT.# ~CF57T4/35
$15299
$1.99
70-watt Compact Fluorescent
• 120V-277V universal electronic ballast
CAT.# E-WPC2F70U(*)
Replacement lamp
PROVIDED BY OTHERS
$15299
$XX.90
One lamp included
Weight: 18-20 lbs. (small)
24-35 lbs. (large)
• Seamless copper-free die-cast aluminum housing
• Copper-free die-cast aluminum lens assembly and frame is hinged,
allowing for easy serviceability
• Clear, borosilicate glass lens
• Foam-in-place gasketing around lens and mounting provide watertight
seal
• Precision specular aluminum reflector provides forward throw with
wide distribution
• Fixture design provides cutoff light distribution without glare
• Supplied with lightweight mounting box designed for installation over
standard 4-inch square or octagonal and single-gang J-boxes
• Conduit entry from top, sides and rear for easy through-wiring
• E-coat epoxy primer with five layers of protection
• Super durable dark-bronze powder topcoat
• UL Listed for wet locations
• 5-year finish warranty
• 3-year fixture warranty
• 1-year lamp warranty
• Assembled in the USA
Features:
SMALL
SMALL
SMALL
SMALL
LARGE
LARGE
LARGE
LARGE
Applications – Security, pathway and perimeter lighting; ideal for entry ways, walkways and parking facilities.
Typical Mounting Height: 8 to 30 feet Typical Spacing: 2 to 3 times the mounting height
LARGE
Accessories:
A
B
C
SMALL
LARGE
"A" "B" "C"
12.0" 11.6" 8.2"
16.3" 16.8" 10.1"
Photocell
CAT.# E-ACP1
(120 volts)
$690
Field installed
CAT.# E-ACP2
(208/240/277
volts)
$690
CAT.# E-WP/USMP
$1099
Uneven Surface Mounting Plate
Used to prevent water
entry into fixture through
back box due to uneven
gasket sealing when
mounting to brick, stucco
and corrugated metal.
(*) Specify finish color: Z=Dark Bronze, M=Medium Bronze
Same as the GWC Series
from Ruud Lighting
Premium HID
Cutoff Wall Pack
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
A Cree Company
32%
SAVE
UP TO
WALL PACKS
97
www.e-conolight.com 888.243.9445
CAT.# E-WPG/WG2
$1999
CAT.# E-WPG/WG1
$1599
CAT.# E-WP/USMP
$1099
PSMH 70-watt Pulse-Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-WPG1M07Q(*)
Replacement lamp
CAT.# ~MH070ME
$12699
$10.90
100-watt Pulse-Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-WPG1M10Q(*)
Replacement lamp
CAT.# ~MH100ME
$12699
$10.40
150-watt Pulse-Start Metal Halide
• 120/208/240/277V HX ballast HPF
CAT.# E-WPG1P15Q(*)
Replacement lamp
CAT.# ~PS150ME
$13499
$9.90
250-watt Pulse-Start Metal Halide
• 120/208/240/277V CWA ballast HPF
CAT.# E-WPG2P25Q(*)
Replacement lamp
CAT.# ~PS250BUE
$18899
$12.40
320-watt Pulse-Start Metal Halide
• 120/208/240/277V CWA ballast HPF
CAT.# E-WPG2P32Q(*)
Replacement lamp
CAT.# ~PS320PBUE
$19099
$12.90
400-watt Pulse-Start Metal Halide
• 120/208/240/277V CWA ballast HPF
CAT.# E-WPG2P40Q(*)
Replacement lamp
CAT.# ~PS400PBUE
$19399
$12.90
HPS 100-watt High-Pressure Sodium
• 120/208/240/277V HX ballast HPF
CAT.# E-WPG1H10Q(*)
Replacement lamp
CAT.# ~HP100M
$12699
$5.25
250-watt High-Pressure Sodium
• 120/208/240/277V CWA ballast HPF
CAT.# E-WPG2H25Q(*)
Replacement lamp
CAT.# ~HP250
$17999
$6.00
Weight: 18-21 lbs. (small)
45-46 lbs. (large)
One lamp included
• Seamless copper-free die-cast aluminum housing
• Copper-free die-cast aluminum lens assembly and frame is hinged,
allowing for easy serviceability
• Clear, borosilicate refractor glass lens
• Foam-in-place gasketing around lens and mounting provide watertight
seal
• Precision specular aluminum reflector provides forward throw with
wide distribution
• Supplied with lightweight mounting box designed for installation over
standard 4-inch square or octagonal and single-gang J boxes
• Conduit entry from top, sides and rear for easy through-wiring
• E-coat epoxy primer with five layers of protection
• Super durable dark- or medium-bronze powder topcoat
• UL Listed for wet locations
• 5-year finish warranty
• 3-year fixture warranty
• 1-year lamp warranty
• Assembled in the USA
Features:
SMALL
SMALL
SMALL
SMALL
SMALL
LARGE
LARGE
LARGE
LARGE
LARGE
Applications – Security, pathway and perimeter lighting; ideal for entry ways, walkways and parking facilities.
Typical Mounting Height: 8 to 30 feet Typical Spacing: 2 to 3 times the mounting height
Wire Guard
Uneven Surface Mounting Plate
Accessories:
A
B
C
E
D
SMALL
LARGE
"A" "B" "C" "D" "E"
12.0" 11.6" 12.3" 5.5" 3.3"
16.3" 16.9" 17.6" 7.2" 5.0"
Photocell
CAT.# E-ACP1
(120 volts)
$690
Field installed
CAT.# E-ACP2
(208/240/277
volts)
$690
Used to prevent water
entry into fixture through
back box due to uneven
gasket sealing when
mounting to brick, stucco
and corrugated metal.
(*) Specify finish color: Z=Dark Bronze, M=Medium Bronze
Premium HID
Glass Refractor Wall Pack
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
Same as the GWP Series
from Ruud Lighting
A Cree Company
9%
SAVE
UP TO
WALL PACKS
98 Free Shipping on Orders Over $500
Premium Square
Up/Down Wall Pack
Weight: 8-11 lbs. (small)
9-17 lbs. (large)
DISTRIBUTION PATTERN
Bird's Eye View, Wall Mounted
(Pattern shines up and down the wall)
• Durable die-cast aluminum housing
• Knockouts provided on back of housing for 1/2" conduit entry, mounting
over a 4" square or octagonal and single gang J-boxes
• 1/2" NPT threaded hubs on three sides for conduit entry-Small Housing
• 1/2" NPT threaded hubs on four sides for conduit entry-Large Housing
• Neoprene gasket on back of housing provides a watertight mounting seal
• Sponge cord gasket between housing and lens ensures a watertight seal
• Clear polycarbonate lens held in place with hidden spring clip assembly
• 120/208/240/277V HX ballast NPF (50W-70W PSMH & HPS)
• 120/208/240/277V HX ballast HPF (100W-150W PSMH & HPS)
• 120V reactor ballast HPF (70W-150W HPS w/120V photocell)
• 120-277V universal electronic ballast HPF (26/32/42W CFL)
• E-coat epoxy primer with five layers of protection
• Super durable medium-bronze powder topcoat
• UL Listed for wet locations
• 5-year finish warranty, 3-year fixture warranty, 1-year lamp warranty
• Assembled in the USA
Features:
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
Applications – Security, pathway and perimeter lighting; ideal for entry ways and walkways.
Typical Mounting Height: 8 to 20 feet Typical Spacing: 2 to 3 times the mounting height
3.10"
0.25"
A
B
SMALL
LARGE
"A" "B"
8" Sq. 4.1"
12" Sq. 5.0"
LAMP
WATTAGE
HOUSING
SIZE
WITHOUT
PHOTOCELL
PRICE 120V
PHOTOCELL
PRICE 208/240/277V
PHOTOCELL
PRICE
PSMH 50W PSMH E-SS5M05QM $126.99 E-SS5M051MP $135.99 E-SS5M052MP $135.99
70W PSMH E-SS5M07QM $126.99 E-SS5M071MP $135.99 E-SS5M072MP $135.99
100W PSMH E-SS5M10QM $143.99 E-SS5M101MP $99.99 E-SS5M102MP $152.99
150W PSMH E-SS5P15QM $151.99 E-SS5P151MP $159.99 E-SS5P152MP $159.99
HPS 70W HPS E-SS5H07QM $126.99 E-SS5H071MP $74.99 E-SS5H072MP $135.99
150W HPS E-SS5H15QM $88.99 E-SS5H151MP $103.99 E-SS5H152MP $152.99
CFL 26/32/42W CFL E-SS5F42UM $67.99 E-SS5F421MP $74.99 E-SS5F422MP $111.99
SMALL
SMALL
SMALL
LARGE
LARGE
LARGE
LARGE
Find replacement lamps at
www.e-conolight.com
One lamp included
FOR PSMH & HPS
Fluorescent lamp
ordered separately.
See page 101.
A Cree Company
43%
SAVE
UP TO
WALL PACKS
99
www.e-conolight.com 888.243.9445
Premium Square
Up/Down Wall Pack
Premium Rectangular
Perimeter Wall Pack
Weight: 11 lbs.
Weight: 5-11 lbs.
PRODUCTS THAT MEET BUY AMERICAN
REQUIREMENTS WITHIN ARRA
ARE DESIGNATED BY THIS SYMBOL.
Applications – Security, pathway and perimeter lighting; ideal for entry ways and walkways.
Typical Mounting Height: 8 to 20 feet Typical Spacing: 2 to 3 times the mounting height
8.5"
10.0"
4.2" 6.5"
2.3"
6.0"
8.5"
10.0"
4.2" 6.5"
2.3"
6.0"
LAMP
WATTAGE
CATALOG #
MEDIUM BZ
CATALOG #
DARK BZ
PRICE
PSMH 70W PSMH E-SR3M07QM E-SR3M07QZ $90.99
HPS 70W HPS E-SR3H07QM E-SR3H07QZ $90.99
LAMP
WATTAGE
CATALOG #
MEDIUM BZ
CATALOG #
DARK BZ
PRICE
PSMH 70W PSMH E-SR4M07QM E-SR4M07QZ $90.99
HPS 70W HPS E-SR4H07QM E-SR4H07QZ $90.99
CFL 26/32/42W
CFL E-SR4F42UM E-SR4F42UZ $56.99
• Durable die-cast aluminum housing
• Neoprene gasket on back of housing provides a watertight mounting seal
• Silicone rubber seal between housing and lens ensures a watertight seal
• Steel fixture mounting bar and threaded nipple provide direct mounting
to recessed J-box
• Clear polycarbonate lens is fastened to housing with phillips-head
captive stainless-steel screws
• Polished aluminum shroud and semi-specular reflector
• 120/208/240/277V HX ballast HPF (70W PSMH & HPS)
• 120-277V universal electronic ballast HPF (42W CFL)
• E-coat epoxy primer with five layers of protection
• Super durable medium- or dark-bronze powder topcoat
• UL Listed for wet locations
• 5-year finish warranty, 3-year fixture warranty, 1-year lamp warranty
• Assembled in the USA
Features:
60W Incandescent version available online! CAT#. E-SR4I061, $27.90
Applications – Security, pathway and perimeter lighting; ideal for entry ways and walkways.
Typical Mounting Height: 8 to 20 feet Typical Spacing: 2 to 3 times the mounting height
Premium Rectangular Projection Wall Pack
SPACING RATIO =
DISTANCE ALONG
MOUNTING HEIGHT
SPACING RATIO =
DISTANCE ACROSS
MOUNTING HEIGHT
SPACING RATIO =
DISTANCE ALONG
MOUNTING HEIGHT
SPACING RATIO =
DISTANCE ACROSS
MOUNTING HEIGHT
SPACING RATIO =
DISTANCE ACROSS
MOUNTING HEIGHT
SPACING RATIO =
DISTANCE ACROSS
MOUNTING HEIGHT
SPACING RATIO =
DISTANCE ACROSS
MOUNTING HEIGHT
SPACING RATIO =
DISTANCE ACROSS
MOUNTING HEIGHT
DISTRIBUTION PATTERN
Bird's Eye View, Wall Mounted
DISTRIBUTION PATTERN
Bird's Eye View, Wall Mounted
Find replacement lamps at
www.e-conolight.com
Find replacement lamps at
www.e-conolight.com
Fluorescent lamp ordered separately.
See page 101.
Accessories:
Surface Mounting Box with Photocell
CAT.# E-SR/SMBM
(Medium Bronze)
CAT.# E-SR/SMBZ
(Dark Bronze)
$1499
Surface Mounting Box
Die-cast aluminum in medium
or dark bronze finish. For
use where surface wiring is
required. Five tapped and
plugged knockouts to feed 1/2"
conduit. 10" x 6" x 1.25".
CAT.# E-SR/SMB1MP
(Medium Bronze, 120V)
CAT.# E-SR/SMB2MP
(Medium Bronze,
208V-277V)
$2199
CAT.# E-SR/SMB1ZP
(Dark Bronze, 120V)
CAT.# E-SR/SMB2ZP
(Dark Bronze, 208V-277V)
$2199
A Cree Company
One lamp included
FOR PSMH & HPS
One lamp included
FOR PSMH & HPS
A Cree Company
38%
SAVE
UP TO
WALL PACKS
100 Free Shipping on Orders Over $500
10-7/8"H x 6-3/4"W x 5-1/2"D
Built-in
Photocell
Built-in Photocell
Built-in Photocell
42-watt Fluorescent Wall Mount
Applications – Security, entry ways, stairways, storage and perimeter areas, as well as residential exteriors.
Typical Mounting Height: 8 to 18 feet Typical Spacing: 1.5 to 2 times the mounting height
10-7/8"H x 6-3/4"W x 5-1/2"D
Built-in
Photocell
Built-in Photocell
Built-in Photocell
70-watt HID Wall Mount
Applications – Security, entry ways, stairways, storage and perimeter areas, as well as residential exteriors.
Typical Mounting Height: 8 to 18 feet Typical Spacing: 1.5 to 2 times the mounting height
13-watt x 2 Fluorescent Wall Mount
Applications – Security, entry ways, stairways, storage and perimeter areas, as well as residential exteriors.
Typical Mounting Height: 8 to 18 feet Typical Spacing: 1.5 to 2 times the mounting height
10-7/8"H x 6-3/4"W x 5-1/2"D
Built-in
Photocell
Built-in Photocell
Built-in Photocell
• Built-in photocell
• Heavy duty four-pin GX24q-4 socket (42W CFL only)
• Polycarbonate housing in bronze or white with heavy-duty aluminum
mounting plate
• UV-stabilized polycarbonate prismatic refractor
• CFL minimum starting temperature, 0˚F
CFL optimum starting temperature, 40˚F+
• UL Listed for wet locations
• 1-year warranty
Features:
One medium base
lamp included
One lamp included
Two lamps included
HPS
(Bronze)
High-Pressure Sodium
(HPS)
• 120-volt Reactor ballast NPF
• Lamp Output: 6000 lumens
• Lamp Color Rendition: 22
CRI
• Weight: 5.5 lbs.
CAT.#E-WW2H071ZP
Replacement lamp
CAT.# ~HP070M
CFL
(White)
(Bronze)
13-Watt Compact Fluorescent
• Two 13-watt Fluorescent,
total 26-watts
• 120-volt Electronic ballast NPF
• Lamp Output: 890 lumens total
1780 lumens
• Lamp Color Rendition: 82 CRI
• Weight: 4 lbs.
CAT.# E-WW3F261WP
CAT.# E-WW3F261ZP
Replacement lamp
CAT.# ~CF13D4/41
CFL
(White)
(Bronze)
42-Watt Compact Fluorescent
• 120-volt Electronic ballast
• Lamp Output: 3190 lumens
• Lamp Color Rendition: 82 CRI
• Weight: 4.1 lbs.
CAT.# E-WW1F421WP
CAT.# E-WW1F421ZP
Replacement lamp
CAT.# ~CF42T4/41
LED AVAILABLE
See page 12
$4499
$2699
$5.25
$2.20
$3.70
$3099
$3490
$4790
$3490
WAS
$4490
WAS
WALL MOUNTS
NEW!
101
www.e-conolight.com 888.243.9445
Initial/Mean Average CCT*
Catalog # Description Pins Base Lumens Rated Life (K) CRI Price ea.
13W
~CF13SA/27 CFT13W/GX23/827 2 GX23 820 / 700 10000 2700 82 $1.70
13W
~CF13DA/27 CFQ13W/GX23/827 2 GX23-2 800 / 685 10000 2700 82 $2.40
13W
~CF13D4/27 CFQ13W/G24q/827 4 G24q-1 890 / 750 12000 2700 82 $2.20
~CF13D4/35 CFQ13W/G24q/835 4 G24q-1 890 / 750 12000 3500 82 $2.20
~CF13D4/41 CFQ13W/G24q/841 4 G24q-1 890 / 750 12000 4100 82 $2.20
18W
~CF18D4/27 CFQ18W/G24q/827 4 G24q-2 1190 / 960 12000 2700 82 $1.99
~CF18D4/35 CFQ18W/G24q/835 4 G24q-2 1190 / 960 12000 3500 82 $1.99
~CF18D4/41 CFQ18W/G24q/841 4 G24q-2 1190 / 960 12000 4100 82 $2.50
26W
~CF26D4/27 CFQ26W/G24q/827 4 G24q-3 1700 / 1435 12000 2700 82 $1.99
~CF26D4/35 CFQ26W/G24q/835 4 G24q-3 1700 / 1435 12000 3500 82 $2.70
~CF26D4/41 CFQ26W/G24q/841 4 G24q-3 1700 / 1435 12000 4100 82 $2.70
26W
~CF26T4/27 CFTR26W/GX24q/827 4 GX24q-3 1700 / 1435 12000 2700 82 $1.99
~CF26T4/35 CFTR26W/GX24q/835 4 GX24q-3 1700 / 1435 12000 3500 82 $1.99
~CF26T4/41 CFTR26W/GX24q/841 4 GX24q-3 1700 / 1435 12000 4100 82 $3.20
32W
~CF32T4/27 CFTR32W/GX24q/827 4 GX24q-3 2180 / 1845 12000 2700 82 $1.99
~CF32T4/35 CFTR32W/GX24q/835 4 GX24q-3 2180 / 1845 12000 3500 82 $3.50
~CF32T4/41 CFTR32W/GX24q/841 4 GX24q-3 2180 / 1845 12000 4100 82 $3.50
42W
~CF42T4/27 CFTR42W/GX24q/827 4 GX24q-4 3190 / 2680 12000 2700 82 $2.20
~CF42T4/35 CFTR42W/GX24q/835 4 GX24q-4 3190 / 2680 12000 3500 82 $2.99
~CF42T4/41 CFTR42W/GX24q/841 4 GX24q-4 3190 / 2680 12000 4100 82 $3.70
57W
~CF57T4/27 CFTR57W/GX24q/827 4 GX24q-5 4300 / 3700 12000 2700 82 $2.40
~CF57T4/35 CFTR57W/GX24q/835 4 GX24q-5 4300 / 3700 12000 3500 82 $2.70
~CF57T4/41 CFTR57W/GX24q/841 4 GX24q-5 4300 / 3700 12000 4100 82 $3.90
21W
~CF212D/35 CF21W/2D/GR10q/835 4 GR10q-4 1350 / 1130 10000 3500 82 $1.99
28W
~CF282D/35 CF28W/2D/GR10q/835 4 GR10q-4 2045 / 1715 10000 3500 82 $2.99
38W
~CF382D/35 CF38W/2D/GR10q/835 4 GR10q-4 2845 / 2390 10000 3500 82 $2.99
* Correlated Color Temperature (Kelvin)
CFL
Double
Tube–2-pin
CFL
Single
Tube–2-pin
CFL
Double
Tube–4-pin
Compact Fluorescent Lamps
CFL
2D–4-pin
CFL
Triple
Tube–4-pin
Initial/Mean Average CCT*
Catalog # Description Pins Base Lumens Rated Life (K) CRI
32W
~LF32T8835 F32W/T8/835 n/a G13 2775 / 2600 20000 3500 82
~LF32T8841 F32W/T8/841 n/a G13 2775 / 2600 20000 4100 82
~LF32T8850 F32W/T8/850 n/a G13 2775 / 2600 20000 5000 82
Case Qty Price ea. Total 1/2 Skid Qty Price ea. Total Skid Qty Price ea. Total
~LF32T8835-C 25 $3.04 ($76.00) ~LF32T8835-HS 625 $2.76 ($1,725.00) ~LF32T8835-FS 1250 $2.56 ($3,200.00)
~LF32T8841-C 25 $3.04 ($76.00) ~LF32T8841-HS 625 $2.76 ($1,725.00) ~LF32T8841-FS 1250 $2.56 ($3,200.00)
~LF32T8850-C 25 $3.04 ($76.00) ~LF32T8850-HS 625 $2.76 ($1,725.00) ~LF32T8850-FS 1250 $2.56 ($3,200.00)
54W
~LF54T5835 F54W/T5/835 n/a G5 4950 / 4675 20000 3500 82
~LF54T5841 F54W/T5/841 n/a G5 4950 / 4675 20000 4100 82
~LF54T5850 F54W/T5/850 n/a G5 4950 / 4675 20000 5000 82
Case Qty Price ea. Total 1/2 Skid Qty Price ea. Total Skid Qty Price ea. Total
~LF54T5835-C 40 $2.75 ($110.00) ~LF54T5835-HS 600 $2.54 ($1,524.00) ~LF54T5835-FS 1200 $2.33 ($2,796.00)
~LF54T5841-C 40 $2.75 ($110.00) ~LF54T5841-HS 600 $2.54 ($1,524.00) ~LF54T5841-FS 1200 $2.33 ($2,796.00)
~LF54T5850-C 40 $2.75 ($110.00) ~LF54T5850-HS 600 $2.54 ($1,524.00) ~LF54T5850-FS 1200 $2.33 ($2,796.00)
T8 Linear
Fluorescent
T5HO Linear
Fluorescent
TCLP
Compliant
TCLP
Compliant
Linear Fluorescent Lamps
E-conolight carries a wide selection of fluorescent lamps from Luma Lamps in a variety of wattages and
lamp types. Choose from Single Tube, Double Tube-2 pin, Double Tube-4 pin, Triple Tube, 2D and Linear
Fluorescent lamps – all 100% satisfaction guaranteed.
Volume discounts available
for purchases of 250+ lamps
(excludes linear uorescent lamps and Cree® LED Lamps on p.38)
REPLACEMENT LAMPS
102
Fixture Bulb Operating Initial/Mean Average CCT*
Catalog # Description Type Type Position Base Lumens Rated Life (K) CRI Price ea.
70W (ANSI–M98)
~MH070G12 MH70/G12/UVS/4K Clear Encl T23 U G12 5600 / 3600 10000 4200 70 $8.90
100W (ANSI–M90)
~MH100G12 MH100/G12/UVS/4K Clear Encl T23 U G12 9000 / 5900 10000 4200 70 $8.90
150W (ANSI–M102
~MH150G12 MH150/G12/UVS/4K Clear Encl T23 U G12 14000 / 10500 10000 4200 70 $8.90
50W (ANSI–M110) Pulse Start
~MH050MCE MH50/MED/U/C/E Coated Encl ED17 U E26 3200 / 2100 10000 3700 70 $10.40
~MH050MCO MH50/MED/U/C/O Coated Open EDX17 U E26 3000 / 2000 10000 3700 70 $10.40
~MH050ME MH50/MED/U/E Clear Encl ED17 U E26 3400 / 2200 10000 4000 65 $10.40
~MH050MO MH50/MED/U/O Clear Open EDX17 U E26 3200 / 2100 10000 3200 65 $10.40
70W (ANSI–M98) Pulse Start
~MH070MCE MH70/MED/U/C/E Coated Encl ED17 U E26 5300 / 3400 15000 3700 70 $10.90
~MH070MCO MH70/MED/U/C/O Coated Open EDX17 U E26 5000 / 3300 15000 3700 70 $10.90
~MH070ME MH70/MED/U/E Clear Encl ED17 U E26 5600 / 3600 15000 4000 65 $10.90
~MH070MO MH70/MED/U/O Clear Open EDX17 U E26 5300 / 3400 15000 4000 65 $10.90
100W (ANSI–M90) Pulse Start
~MH100MCE MH100/MED/U/C/E Coated Encl ED17 U E26 8500 / 5500 15000 3700 70 $10.40
~MH100MCO MH100/MED/U/C/O Coated Open EDX17 U E26 8100 / 5300 15000 3700 70 $10.40
~MH100ME MH100/MED/U/E Clear Encl ED17 U E26 9000 / 5900 15000 4000 65 $10.40
~MH100MO MH100/MED/U/O Clear Open EDX17 U E26 8500 / 5500 15000 3200 65 $10.40
150W (ANSI–M102) Pulse Start
~PS150MCE PS150/MED/U/C/E Coated Encl ED17 U E26 13300 / 10000 15000 3700 70 $9.90
~PS150MCO PS150/MED/U/C/O Coated Open EDX17 U E26 12600 / 9500 15000 3700 70 $9.90
~PS150ME PS150/MED/U/E Clear Encl ED17 U E26 14000 / 10500 15000 4000 68 $9.90
~PS150MO PS150/MED/U/O Clear Open EDX17 U E26 13300 / 10000 15000 4000 68 $9.90
175W (ANSI–M57) Probe Start
~MH175MCE MH175/MED/U/C/E Coated Encl ED17 U E26 13300 / 8600 10000 3700 70 $9.90
~MH175ME MH175/MED/U/E Clear Encl ED17 U E26 14000 / 10000 10000 4000 65 $9.90
175W (ANSI–M57)
~MH175CE MH175/U/C/E Coated Encl ED28 U E39 13300 / 8600 10000 3700 70 $7.99
~MH175E MH175/U/E Clear Encl ED28 U E39 14000 / 9100 10000 4000 65 $9.90
250W (ANSI–M58)
~MH250CE MH250/U/C/E Coated Encl ED28 U E39 20000 / 13000 10000 3700 70 $9.90
~MH250E MH250/U/E Clear Encl ED28 U E39 21000 / 13700 10000 4000 65 $9.90
400W (ANSI–M59)
~MH400UCE MH400/U/C/E Coated Encl ED37 U E39 34000 / 22000 20000 3700 70 $9.90
~MH400UE MH400/U/E Clear Encl ED37 U E39 36000 / 23000 20000 4000 65 $9.90
~MH400UPCE MH400/28/U/C/E Coated Encl ED28 U E39 34000 / 22000 20000 3700 70 $6.99
~MH400UPE MH400/28/U/E Clear Encl ED28 U E39 36000 / 23000 20000 4000 65 $9.90
~MH400BUCO MH400/VBU/C/O Coated Open ED37 BU EX39 38000 / 25000 20000 3700 70 $9.90
~MH400BUO MH400/VBU/O Clear Open ED37 BU EX39 40000 / 26000 20000 4000 65 $9.90
1000W (ANSI–M47)
~MH999UCE MH1000/U/C/E Coated Encl BT56 U E39 104000 / 79500 15000 4000 70 $19.90
~MH999UE MH1000/U/E Clear Encl BT56 U E39 106000 / 85500 15000 4200 65 $19.90
~MH999UPE MH1000/37/U/E Clear Encl BT37 U E39 110000 / 71000 12000 4000 65 $19.90
150W (ANSI–M102)
~PS150E PS150/MOG/U/E Clear Encl ED28 U E39 14000 / 11200 15000 4000 68 $10.90
250W (ANSI–M138/M153)
~PS250BUCE PS250/VBU/C/E Coated Encl ED28 BU E39 23800 / 19000 15000 3700 70 $8.99
~PS250BUCO PS250/VBU/C/O Coated Open ED28 BU EX39 22600 / 18000 15000 3700 70 $12.40
~PS250BUE PS250/VBU/E Clear Encl ED28 BU E39 25000 / 20000 15000 4000 68 $12.40
~PS250BUO PS250/VBU/O Clear Open ED28 BU EX39 23800 / 19000 15000 4000 68 $12.40
320W (ANSI–M132/M154)
~PS320BUCO PS320/VBU/C/O Coated Open ED37 BU EX39 29000 / 23000 20000+ 3700 70 $12.90
~PS320BUO PS320/VBU/O Clear Open ED37 BU EX39 31000 / 25000 20000+ 4000 68 $12.90
~PS320PBCE PS320/28/VBU/C/E Coated Encl ED28 BU E39 31000 / 25000 20000+ 3700 70 $12.90
~PS320PBCO PS320/28/VBU/C/O Coated Open ED28 BU EX39 29000 / 23000 20000+ 3700 70 $12.90
~PS320PBUE PS320/28/VBU/E Clear Encl ED28 BU E39 33000 / 26000 20000+ 4000 68 $12.90
~PS320PBUO PS320/28/VBU/O Clear Open ED28 BU EX39 31000 / 25000 20000+ 4000 68 $12.90
400W (ANSI–M135/M155)
~PS400BUCE PS400/VBU/C/E Coated Encl ED37 BU E39 42000 / 33000 20000+ 3700 70 $12.90
~PS400BUCO PS400/VBU/C/O Coated Open ED37 BU EX39 39000 / 31000 20000+ 3700 70 $12.90
~PS400BUE PS400/VBU/E Clear Encl ED37 BU E39 44000 / 35000 20000+ 4000 68 $12.90
~PS400BUO PS400/VBU/O Clear Open ED37 BU EX39 41000 / 33000 20000+ 4000 68 $12.90
~PS400PBCE PS400/28/VBU/C/E Coated Encl ED28 BU E39 42000 / 33000 20000+ 3700 70 $12.90
~PS400PBCO PS400/28/VBU/C/O Coated Open ED28 BU EX39 39000 / 31000 20000+ 3700 70 $8.99
~PS400PBUE PS400/28/VBU/E Clear Encl ED28 BU E39 44000 / 35000 20000+ 4000 68 $12.90
~PS400PBUO PS400/28/VBU/O Clear Open ED28 BU EX39 41000 / 33000 20000+ 4000 68 $12.90
* Correlated Color Temperature (Kelvin)
Metal Halide
G12 Base
Metal Halide
Medium Base
Metal Halide
Mogul Base
Probe Start
Metal Halide
Mogul Base
Pulse Start
HID Lamps
E-conolight carries a wide selection of HID lamps from Luma Lamps in a variety of wattages and lamp types.
Choose from Probe-Start Metal Halide, Pulse-Start Metal Halide and High-Pressure Sodium lamps
– all 100% satisfaction guaranteed.
Volume discounts available for purchase of 250+ lamps
(excludes linear uorescent lamps and Cree® LED Lamps on p.38)
REPLACEMENT LAMPS
www.e-conolight.com 888.243.9445 103
0° Aiming Angle 60° Aiming Angle
Beam Beam Spread Beam Spread Approx. Average
Catalog # Description Angle per Ft. per Ft. from Wall Lumens Rated Life Notes Price ea.
100W
~QZ100DC Q100DC n/a – – 1200 2000 1,2 $1.65
150W
~QZ150DC Q150DC n/a – – 2100 2000 1,2 $1.20
100W
~QZ100T3 Q100T3 n/a – – 1200 2000 1,2 $0.50
~QZ100T3L Q100T3/Long n/a – – 1300 2000 1,2 $0.45
150W
~QZ150T3 Q150T3 n/a – – 2000 2000 1,2 $0.50
250W
~QZ250T3 Q250T3 n/a – – 4250 2000 1,2 $0.50
300W
~QZ300T3 Q300T3 n/a – – 4800 2000 1,2 $0.50
500W
~QZ500T4 Q500T4 n/a – – 8500 2000 1,2 $0.50
1) Use only in an enclosed fixture. Do not touch quartz bulb with bare hands. 2) Keep combustible materials away from lamp. Do not use if lamp is
scratched or broken. Use in fixtures rated for this product.
Incandescent Lamps (Line Voltage)
Quartz
DC Bayonet
Base
T23 T3ET25BT56ED37ED28ET23.5ED18ED17
DC
Quartz
Double
Ended Base
HID Lamps
E-conolight carries a wide selection of HID lamps from Luma Lamps in a variety of wattages and lamp types.
Choose from Probe-Start Metal Halide, Pulse Start Metal Halide and High-Pressure Sodium lamps
– all 100% satisfaction guaranteed.
Catalog # Description Fixture
Type
Bulb
Type
Operating
Position Base Initial/Mean
Lumens
Average
Rated Life
CCT*
(K) CRI Price
Metal Halide
Mogul Base
Pulse Start (H75)
250W (ANSI-M138/M153)
~PS250H75 MS 250W/H75/PS/740 Enclosed ED28 H ± 75° E39 22,000/17,600 20,000 4000 68 $29.90
320W (ANSI-M132/M154)
~PS320PH75 MS 320W/H75/ED28/PS/740 Enclosed ED28 H ± 75° E39 30,000/24,000 26,000 4000 68 $30.90
400W (ANSI-M135/M155)
~PS400H75 MS 400W/H75/PS/740 Enclosed ED37 H ± 75° E39 40,000/32,000 26,000 4000 68 $31.90
~PS400PH75 MS 400W/H75/ED28/PS/740 Enclosed ED28 H ± 75° E39 40,000/32,000 26,000 4000 68 $32.99
High-Pressure
Sodium
Medium Base
35W (ANSI-S76)
~HP035M HPS35/MED/U Clear Open ED17 U E26 2250/1700 16000 2100 22 $5.25
50W (ANSI-S68)
~HP050M HPS50/MED/U Clear Open ED17 U E26 4000/3600 24000+ 2100 22 $5.25
70W (ANSI-S62)
~HP070M HPS70/MED/U Clear Open ED17 U E26 6000/4500 24000+ 2100 22 $5.25
100W (ANSI-S54)
~HP100M HPS100/MED/U Clear Open ED17 U E26 9000/6750 24000+ 2100 22 $5.25
150W (ANSI-S55)
~HP150M HPS150/MED/U Clear Open ED17 U E26 15000/11250 24000+ 2100 22 $5.25
High-Pressure
Sodium
Mogul Base
50W (ANSI-S68)
~HP050 HPS50/U Clear Open ED23.5 U E39 4000/3600 24000+ 2100 22 $5.50
70W (ANSI-S62)
~HP070 HPS70/U Clear Open ED23.5 U E39 6000/4500 24000+ 2100 22 $5.50
100W (ANSI-S54)
~HP100 HPS100/U Clear Open ED23.5 U E39 9000/6750 24000+ 2100 22 $5.50
150W (ANSI-S55)
~HP150 HPS150/U Clear Open ED23.5 U E39 15000/11250 24000+ 2100 22 $5.50
250W (ANSI-S50)
~HP250 HPS250/U Clear Open ED18 U E39 26000/19550 24000+ 2100 22 $6.00
400W (ANSI-S51)
~HP400 HPS400/U Clear Open ED18 U E39 48000/36000 24000+ 2100 22 $6.25
1000W (ANSI-S52)
~HP999 HPS1000/U Clear Open ET25 U E39 13000/124000 24000+ 2100 22 $28.50
Volume discounts available for purchases of 250+ lamps
(excludeslinearuroscentlamps)
REPLACEMENT LAMPS
Free Shipping on Orders Over $500 www.e-conolight.com
104
Catalog # Description Philips
SKU
Watts Volts Beam
Angle
Approx.
Lumens
Rated Life
(Hrs.)
Approx.
MBCP
MOL
(Inches)
Price
MR16
~20M16ESP 20MR16/SP10 ESX 37802-6 20W 12V Spot 10˚ 240 3000 3400 1.875 $2.99
~20M16EFL 20MR16/FL36 BAB 37803-4 20W 12V Flood 36˚ 240 3000 550 1.875 $2.99
~35M16EFL 35MR16/FL36 14056-6 35W 12V Flood 36˚ 540 3000 1000 1.875 $2.99
~50M16ESP 50MR16/SP10 EXT 37804-2 50W 12V Spot 10˚ 790 3000 8800 1.875 $2.99
~50M16ENF 50MR16/MFL24 EXZ 37807-5 50W 12V N. Flood 24˚ 800 3000 2500 1.875 $2.99
~50M16EFL 50MR16/FL36 EXN 37805-9 50W 12V Flood 36˚ 850 3000 1600 1.875 $2.99
MR16 LONG LIFE
~20M16PSP 20MRC16/SP10 ESX 37814-1 20W 12V Spot 10˚ 310 6000 5000 1.875 $5.49
~20M16PFL 20MRC16/FL36 BAB 37815-8 20W 12V Flood 36˚ 320 6000 780 1.875 $5.49
~35M16PSP 35MR16/SP10 14054-1 35W 12V Spot 10˚ 680 6000 8000 1.875 $5.49
~35M16PNF 35MR16/NFL24 14052-5 35W 12V N. Flood 24˚ 690 6000 3100 1.875 $5.49
~35M16PFL 35MR16/FL36 14053-3 35W 12V Flood 36˚ 710 6000 1500 1.875 $3.99
~50M16PNF 50MRC16/NFL24 EXZ 37817-4 50W 12V N. Flood 24˚ 960 6000 4400 1.875 $5.49
~50M16PFL 50MRC16/FL36 EXN 37814-2 50W 12V Flood 36˚ 960 6000 2200 1.875 $5.49
~75M16PSP 75MR16/SP10 EYF 37808-3 75W 12V Spot 10˚ 1320 6000 14,000 1.875 $5.49
~75M16PFL 75MR16/FL36 EYC 37809-1 75W 12V Flood 36˚ 1410 6000 2500 1.875 $2.99
Halogen Lamps – MR16
Which Do I Choose?
Philips halogen lamps provide bright, crisp
light that is perfect for retail and hospitality
applications. Since they deliver more lumens
per watt, have perfect color rendering,
consume less energy and last longer than
standard halogen lamps, they are the ideal,
cost-efficient choice. LIGHTING LEGISLATION EXPLAINED
Section 321 of the Energy Independence and Security Act
(EISA) of 2007 set maximum wattages and minimum rated
average lifetimes for general service incandescent lamps.
It directed the Department of Energy (DOE) to undertake
new standards for Incandescent Reflector Lamps.
Depending on the type of lamp, these standards are
phased in from January 1, 2012 through January 1, 2014.
Lamp Type Phase-Out Wattage Replace With
R20 75W 40W
BR30 65W 40W
85W 50W
BR40 65W 40W
120W 70W
PAR20 50W 39W
20W
PAR30S 50W 40W
39W
PAR30L
50W 39W
75W 53W
50W
PAR38
45W 39W
60W 39W
75W 53W
90W 72W
70W
Premium replacement option.
See page 105.
EcoVantage PRO Energy Advantage IRC Energy Advantage IRC+
• Deliver excellent light
quality at a low initial
cost
• EISA and DOE
Rulemaking compliant
• 1,100 hour average
rated life
• Provide excellent light
quality and long life,
ideal for retail
applications.
• EISA and DOE
Rulemaking compliant
• 3,000 hour average
rated life
• Best Total Cost of
Ownership, Efficacy
and Energy Savings
• EISA and DOE
Rulemaking compliant
• 4,400 hour average
rated life
Put People and Merchandise in the Best Light
REPLACEMENT LAMPS
105
Catalog # Description Philips
SKU
Watts Volts Beam
Angle
Approx.
Lumens
Rated Life
(Hrs.)
Approx.
MBCP
CRI Color
Temp (K)
MOL
(Inches)
Price
R & BR – ECOVANTAGE HALOGEN PRO
~40R20EFL 40R20/EV/FL 42117-2 40W 120V Flood 570 2750 — — 2700 3.9375 $5.90
~40BR3EFL 40BR30/EV/FL 42106-5 40W 120V Flood 590 2750 — — 2710 5.375 $6.90
~40BR4EFL 40BR40/EV/FL 42116-4 40W 120V Flood 605 2750 — — 2730 6.5 $6.99
~70BR4EFL 70BR40/EV/FL 42119-8 70W 120V Flood 1225 2750 — — 2900 6.5 $8.90
R & BR – HALOGEN ENERGY ADVANTAGE
~40R20PFL 40R20/HEA/FL 22236-4 40W 120V Flood 65˚ 570 3000 — 100 2800 3.9 $7.90
~40BR3PFL 40BR30/HEA/FL 21359-5 40W 120V Flood 65˚ 600 3000 — 100 2800 5.4 $8.90
~40BR4PFL 40BR40/HEA/FL 22238-0 40W 120V Flood 65˚ 630 3000 — 100 2800 6.5 $9.40
~70BR4PFL 70BR40/HEA/FL 22997-1 70W 120V Flood 65˚ 1280 3000 — 100 2900 6.5 $9.90
PAR20 – ECOVANTAGE HALOGEN PRO
~39P20ESP 39PAR20/EVP/SP10 42512-4 39W 120V Spot 10˚ 500 1100 3800 100 3000 3.4 $4.40
~39P20EFL 39PAR20/EVP/FL25 42520-7 39W 120V Flood 25˚ 500 1100 850 100 3000 3.4 $4.40
PAR20 – ELECTRONIC HALOGEN
~20P20PSP 20PAR20E/HAL/SP10 40494-7 20W 120V Spot 10˚ 220 5000 6600 100 2900 3.4 $18.90
~20P20PFL 20PAR20E/HAL/FL25 15216-5 20W 120V Flood 25˚ 220 5000 1200 100 2900 3.4 $18.90
PAR30 SHORT NECK – ECOVANTAGE HALOGEN PRO
~39P30ESP 39PAR30S/EVP/SP10 42891-2 39W 120V Spot 10˚ 530 1100 6300 100 2900 3.6 $5.49
~39P30EFL 39PAR30S/EVP/FL25 42896-0 39W 120V Flood 25˚ 530 1100 2000 100 2900 3.6 $5.49
~53P30ESP 53PAR30S/EVP/SP10 42888-8 53W 120V Spot 10˚ 920 1100 10,000 100 2900 3.6 $6.99
~53P30EFL 53PAR30S/EVP/FL25 42890-4 53W 120V Flood 25˚ 920 1100 3500 100 2900 3.6 $6.99
~53P30EWF 53PAR30S/EVP/WFL40 42898-6 53W 120V W. Flood 40˚ 920 1100 1400 100 2900 3.6 $6.99
PAR30 SHORT NECK – ENERGY ADVANTAGE IRC+
~39P30PSP 39PAR30S/IRC+/SP10 23853-5 39W 120V Spot 10˚ 650 4400 11,000 100 2700 3.6 $11.90
~39P30PFL 39PAR30S/IRC+/FL25 23854-3 39W 120V Flood 25˚ 650 4400 2200 100 2700 3.6 $8.99
~50P30PSP 50PAR30S/IRC+/SP10 14499-7 50W 120V Spot 10˚ 940 4400 12,000 100 2740 3.6 $10.40
~50P30PFL 50PAR30S/IRC+/FL25 14500-3 50W 120V Flood 25˚ 940 4400 3850 100 2740 3.6 $10.40
~50P30PWF 50PAR30S/IRC+/WFL40 14501-1 50W 120V W. Flood 40˚ 940 4400 1420 100 2740 3.6 $10.40
PAR30 LONG NECK – ECOVANTAGE HALOGEN PRO
~39P3LEFL 39PAR30L/EVP/FL25 42887-0 39W 120V Flood 25˚ 520 1100 2000 100 2900 4.5 $5.49
~53P3LEFL 53PAR30L/EVP/FL25 42892-0 53W 120V Flood 25˚ 920 1100 3500 100 2900 4.5 $6.99
~53P3LEWF 53PAR30L/EVP/WFL40 42895-2 53W 120V W. Flood 40˚ 920 1100 1400 100 2900 4.5 $6.99
PAR30 LONG NECK – ENERGY ADVANTAGE IRC
~50P3LPSP 50PAR30L/IRC/SP10 23799-0 50W 120V Spot 10˚ 1000 4400 12,000 100 2750 4.5 $11.90
~50P3LPFL 50PAR30L/IRC/FL25 23429-4 50W 120V Flood 25˚ 1000 4400 3500 100 2750 4.5 $11.90
~50P3LPWF 50PAR30L/IRC/WFL40 23800-6 50W 120V W. Flood 40˚ 1000 4400 1600 100 2750 4.5 $11.90
PAR38 – ECOVANTAGE HALOGEN PRO
~39P38ESP 39PAR38/EVP/SP10 42886-2 39W 120V Spot 10˚ 570 1100 7000 100 2900 5.3 $5.49
~39P38EFL 39PAR38/EVP/FL25 42884-7 39W 120V Flood 25˚ 570 1100 2100 100 2900 5.3 $5.49
~53P38ESP 53PAR38/EVP/SP10 42889-6 53W 120V Spot 10˚ 920 1100 11,000 100 2900 5.3 $4.99
~53P38EFL 53PAR38/EVP/FL25 42885-4 53W 120V Flood 25˚ 920 1100 3250 100 2900 5.3 $4.99
~72P38ESP 72PAR38/EVP/SP10 42894-6 72W 120V Spot 10˚ 1350 1100 16,000 100 2900 5.3 $7.99
~72P38EFL 72PAR38/EVP/FL25 42893-8 72W 120V Flood 25˚ 1350 1100 4700 100 2900 5.3 $7.99
PAR38 – ENERGY ADVANTAGE IRC & IRC+
~39P38PSP 39PAR38/IRC+/SP10 23844-4 39W 120V Spot 10˚ 720 4400 11,000 100 2700 5.3 $11.90
~39P38PFL 39PAR38/IRC+/FL25 23845-1 39W 120V Flood 25˚ 720 4400 2500 100 2700 5.3 $8.99
~50P38PSP 50PAR38/IRC+/SP10 14505-2 50W 120V Spot 10˚ 950 4400 15,500 100 2760 5.3 $10.40
~50P38PFL 50PAR38/IRC+/FL25 14506-0 50W 120V Flood 25˚ 950 4400 4000 100 2760 5.3 $10.40
~70P38PSP 70PAR38/IRC/SP10 13861-0 70W 120V Spot 10˚ 1500 4400 17,800 100 2750 5.3 $11.40
~70P38PFL 70PAR38/IRC/FL25 13862-8 70W 120V Flood 25˚ 1500 4400 6170 100 2750 5.3 $8.99
~70P38PWF 70PAR38/IRC/WFL40 13863-6 70W 120V W. Flood 40˚ 1500 4400 2320 100 2750 5.3 $11.40
~83P38PSP 83PAR38/IRC+/SP10 23850-1 83W 120V Spot 10˚ 1750 4400 25,000 100 2750 5.3 $11.40
~83P38PFL 83PAR38/IRC+/FL25 23851-9 83W 120V Flood 25˚ 1750 4400 7000 100 2750 5.3 $8.99
~83P38PWF 83PAR38/IRC+/WFL40 23852-7 83W 120V W. Flood 40˚ 1750 4400 3000 100 2750 5.3 $11.40
~100P38PSP 100PAR38/IRC/SP10 13876-8 100W 120V Spot 10˚ 2150 4400 26,400 100 2750 5.3 $11.40
~100P38PFL 100PAR38/IRC/FL25 13877-6 100W 120V Flood 25˚ 2150 4400 8500 100 2750 5.3 $11.40
~100P38PWF 100PAR38/IRC/WFL40 13878-4 100W 120V W. Flood 40˚ 2150 4400 3500 100 2750 5.3 $11.40
Halogen Lamps – R, BR, & PAR
Volume discounts available for purchase of 250+ lamps
(excludes linear uorescent lamps and Cree® LED Lamps on p.38)
REPLACEMENT LAMPS
Free Shipping on Orders Over $500
About e-conolight
E-conolight sells quality, low-cost lighting fixtures and
accessories that cover a wide range of security and utility
needs in residential, commercial, professional and industrial
settings. Our products give you efficient lighting for less
money. Our ordering and shipping systems help you to
obtain your products easily and quickly.
How to Order
You can buy e-conolight products from our web site,
www.e-conolight.com, or by calling toll-free, (888) 243-9445.
Our Customer Service Department is available Monday
through Friday 6 a.m. to 7 p.m. CT to take your order.
Please double check the lamp type, size and wattage before
ordering replacement lamps and verify the voltage for your
specific application before ordering lighting fixtures.
—Para Español (888) 243-9339 —Fax (262) 504-5409
Payment and Pricing
Prepayment is required for all products. We accept Visa,
MasterCard, Discover Card, American Express and ACH
Debit. All product prices are subject to change and exclude
shipping and handling costs and state sales tax. Visit us at
www.e-conolight.com/credit to inquire about invoice terms.
Volume discounts available on Linear Fluorescent and LED
Troffers only.
Shipping and Handling
• Poles/Bullhorns - Free shipping except Ruud Poles
(Expedited Not Available)
• All orders that exceed $500 - Free shipping
• All orders less than $500 - $20 shipping and handling
• Orders from Alaska or Hawaii - Call to place order.
Additional shipping & handling charges will apply.
• Expedited service orders - Call to place order. Additional
shipping and handling charges will apply.
• We do not ship internationally. We can ship to a U.S.
freight forwarder but shipping responsibility passes to you
when your order leaves our factory.
• All shipments are F.O.B. origin; product ownership and risk
of loss passes to you when it leaves our factory.
• Additional charges will be assessed when changing a
shipment's destination.
• The customer is responsible for unloading goods. Please
have the necessary unloading equipment readily available
at the shipment destination.
• Orders must ship to one location using the carrier of our
choice to qualify for the free shipping.
Shipping Lead Times
(excluding poles and bullhorns–see page 78)
Orders received before noon CT during
normal business hours, on in-stock items,
are generally shipped from the Midwest
on the same day. You can expect delivery
within 3-7 business days depending on
your location. Most orders ship via FedEx Ground. Larger
orders may ship via common carrier and require you to be
responsible for unloading.
State Sales Tax
State sales taxes are levied on all orders. Orders that are tax-
exempt for resale or exempt organizations will be accepted
but not processed until a valid tax certificate is received. Fax,
e-mail, or mail the valid certificate to:
E-conolight
Attn: Accounting
1501 96th St.
Sturtevant, WI 53177-1882
e-mail: sales@e-conolight.com Fax: (262) 504-5408
Order Acknowledgements
An e-mailed order acknowledgement is provided to all
customers that provide a valid e-mail address. If a valid
e-mail address is not provided, an order acknowledgment
will be sent via postal mail or fax if supplied.
Customer Service and Technical Support
For answers to questions concerning technical issues,
warranty returns, replacement parts or to report products
damaged in shipping, please call us at (888) 243-9445,
Monday through Friday, 6:00 a.m. to 7:00 p.m. CT.
Limited Product Warranties
(excluding poles and bullhorns - see page 78)
E-conolight's limited warranty for its products and the limited
warranty applicable to non e-conolight third party branded
products, if any, are set forth at
www.e-conolight.com/product-warranties
Sales Terms and Conditions
All sales of e-conolight products are subject to, and
expressly conditioned upon your acceptance of,
e-conolight's sales terms and conditions, as then in effect
and set forth at
www.e-conolight.com/terms
Specification Sheets
Available online at www.e-conolight.com
Installation
Instruction manuals are included with each fixture and are
also available online at www.e-conolight.com
Buy American Requirements
E-conolight products that meet Buy American Requirements,
meet Section 1605 of the American Recovery Reinvestment
Act (ARRA).
Environmental
Fluorescent and HID lamps contain mercury.
Dispose of these lamps according to local, state or
federal laws. For further information on local state
or other requirements for disposal of mercury-
containing lamps, see www.lamprecycle.org.
©2015 E-Conolight, LLC. All Rights Reserved.
e-conolight®, LUMA® and After-Sunset® are registered trademarks of E-Conolight, LLC, and e-conolight.com™, the e-conolight logo and the Luma logo
are trademarks of E-Conolight, LLC. CREE®, the CREE LEDs logo, Crown-Weld®, RUUD® and RUUD LIGHTING® are registered trademarks of Cree, Inc.
BUYING FROM E-CONOLIGHT
Go to our homepage & sign up for our emails today!
Be the first to know about
• Promotions
• New Products
• Private Sales
• Bestsellers
And More!
DON'T MISS OUT
VISIT US AT
TO FIND MORE OF YOUR FAVORITE PRODUCTS, INCLUDING:
www.e-conolight.com
CANOPY AND
PARKING
WALL PACKS
Go to our homepage & sign up for our emails today!
Be the first to know about
• Promotions
• New Products
• Private Sales
• Bestsellers
And More!
Visit us online at
www.e-conolight.com
for our full line of products
LED FLOODLIGHTS
PAGES 2 - 5
LED AREA LIGHT
PAGE 6
LED DUSK TO
DAWN
PAGE 7
LED WALL
PACKS
PAGES 8 - 11
LED WALL
MOUNTS
PAGES 12 - 13
LED WALL
SCONCES
PAGE 14
LED VAPOR
TIGHTS
PAGE 15
LED CANOPY
& PARKING
PAGES 16- 19
LED BOLLARD
PAGE 20
LED GOOSENECK
PAGE 21
LED HIGH BAY
PAGES 22 - 23
LED LAY-IN
TROFFER
PAGES 24 - 25
LED TRACK
LIGHTING
PAGES 26 - 29
LED STEP LIGHT
PAGE 30
LED SURFACE
LIGHTING
PAGES 30 - 31
LED RECESSED
PAGES 32 - 36
LED LINEAR
PAGE 37
LED LAMPS
PAGES 38 - 39
LED FLEXIBLE
CABLE
PAGES 40 - 42
LED EXIT &
EMERGENCY
PAGES 43 - 46
LINEAR
FLUORESCENT
PAGES 47 - 53
HIGH BAYS &
LOW BAYS
PAGES 54 - 57
RECESSED
PAGES 58 - 65
SPECIALTY
PAGE 66
VAPOR TIGHTS
PAGE 67
TRACK
LIGHTING
PAGES 68- 70
FLOODLIGHTS
& POLES
PAGES 71- 81
CANOPY
PAGES 82- 85
LANDSCAPE &
PATHWAY
PAGES 86 -91
WALL PACKS
PAGES 92 -99
WALL MOUNTS
PAGE 100
REPLACEMENT
LAMPS
PAGES 101 -105
PRSRT STD
US POSTAGE
PAID
HARRISBURG, PA
PERMIT NO. 366
1501 96th Street
Sturtevant, Wisconsin 53177-1882
©2015 e-conolight, LLC. All rights reserved.
• FG# CAT/EL-0515
• Printed in U.S.A.
E-conolight, a Wisconsin-based company, sells popular, low-cost lighting fixtures and accessories that cover
a wide range of residential, commercial, professional and industrial applications. e-conolight.com
Mailing ID
Customer Number
Key Code
