CONTROL & AUTOMATION
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
126
Lloyd’s Register
of Shipping
US
UL
C
P9 PUSH-BUTTON RANGE
P9 SerieS
Available made up: perfect for your storeroom.
COMMON PARTS
CHROME PLASTIC
Standards/Approvals: IEC/EN 60947-1, IEC/EN 60947-4-1, IEC/EN 60947-5-1,
EN 50003, UL 508, NEMA ICS-1, CSA C22.2/14, JIS C8325
IP66
CALL US TO
REQUEST YOUR
P9 STAND
CONTROL &
AUTOMATION
127
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
P9 SerieS
CHROME PLASTIC
DESCRIPTION COLOUR CONTACTS ORDER PRICE $ ORDER PRICE $
CODE excl. GST CODE excl. GST
Flush Push-button Black I N/O 153000 44.90 152000 41.90
Spring Return Red I N/C 153001 44.90 152001 41.90
Green I N/O 153002 44.90 152002 41.90
Yellow I N/O 153003 44.90 152003 41.90
Blue I N/O 153006 44.90 152006 41.90
IM Standard Push-buttons IP66
DESCRIPTION DIAMETER COLOUR CONTACTS ORDER PRICE $ ORDER PRICE $
CODE excl. GST CODE excl. GST
Push-Pull to Release 40mm Red 1 N/C 153161 91.10 152161 89.80
Push-Twist to Release 40mm Red 1 N/C 153170 112.00 152170 105.00
Push-Key to Release 40mm Red 1 N/C 153173 157.50 152173 148.30
IM Mushroom Head Push-buttons IP66
DESCRIPTION CONTACTS ORDER PRICE $ ORDER PRICE $
CODE excl. GST CODE excl. GST
2 Position Fixed Short Handle I N/O 153210 62.60 152210 58.80
3 Position Fixed Short Handle 2 N/O 153200 82.60 152200 79.60
4 Position Fixed Short Handle 3 N/O 153230 113.90 152230 108.10
IM Selector Switches (black) IP66
DESCRIPTION COLOUR CONTACTS ORDER PRICE $ ORDER PRICE $
CODE excl. GST CODE excl. GST
Flush Push-button Red I N/C 153591 81.40 152591 78.80
Diffused Lens Green I N/O 153592 81.40 152592 78.80
Spring Return Yellow I N/O 153593 81.40 152593 78.80
Orange I N/O 153595 81.40 152595 78.80
Blue I N/O 153596 81.40 152596 78.80
IM Illuminated Push-buttons (24V) IP66
Diffused Lens Red 153791 62.60 152791 55.70
Green 153792 62.60 152792 55.70
Yellow 153793 62.60 152793 55.70
Orange 153795 62.60 152795 55.70
Blue 153796 62.60 152796 55.70
IM Illuminated Pilot Light (24V) IP66
Diffused Lens Red 153691 81.40 152691 74.90
Green 153692 85.94 152692 74.90
Yellow 153693 81.40 152693 74.90
Orange 153695 81.40 152695 74.90
Blue 153696 81.40 152696 74.90
IM Illuminated Pilot Light (230V) IP66
Complete Push-button Range
(Flange, contact blocks and LED’s included, supplied in a blister pack)
IM Joysticks IP66
2 Position, Central Zero 1 NO/NC 153701 165.00
4 Position, Central Zero 2 NO/NC 153721 206.90
Without Interlock
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
128
IA Standard Push-buttons IP66
CHROME PLASTIC
DESCRIPTION COLOUR CAT ORDER PRICE $ CAT ORDER PRICE $
REF CODE excl. GST REF CODE excl. GST
Flush Push-button Black P9CPNNG 190000 28.10 P9XPNNG 185000 26.70
Spring Return Red P9CPNRG 190001 28.10 P9XPNRG 185001 26.70
Green P9CPNVG 190002 28.10 P9XPNVG 185002 26.70
Yellow P9CPNGG 190003 28.10 P9XPNGG 185003 26.70
Blue P9CPNLG 190006 28.10 P9XPNLG 185006 26.70
White P9CPNBG 190007 28.10 P9XPNBG 185007 26.70
Raised Push-button Black P9CPNNS 190010 34.90 P9XPNNS 185010 29.90
Spring Return Red P9CPNRS 190011 35.60 P9XPNRS 185011 29.90
Green P9CPNVS 190012 48.90 P9XPNVS 185012 29.90
Yellow P9CPNGS 190013 35.60 P9XPNGS 185013 29.90
Blue P9CPNLS 190016 34.90 P9XPNLS 185016 29.90
White P9CPNBS 190017 35.60 P9XPNBS 185017 29.90
IJ Rubber Protective Caps IP66
For flush standard Clear 080CPT 170198 7.80
push-buttons Black 080CPN 170190 7.80
Red 080CPR 170191 7.80
Green 080CPV 170192 7.90
Yellow 080CPG 170193 7.80
For raised standard push-buttons Clear P9ARCST 187490 8.70
IA Mushroom Head Push-Buttons IP66
CHROME PLASTIC
DESCRIPTION DIA- COLOUR CAT REF ORDER PRICE $ CAT REF ORDER PRICE $
METER CHROME CODE excl. GST PLASTIC CODE excl. GST
Spring Return 28mm Red P9CEM3RN 190031 52.20 P9XEM3RN 185031 46.10
40mm Black P9CEM4NN 190040 52.20 P9XEM4NN 185040 46.10
40mm Red P9CEM4RN 190041 52.20 P9XEM4RN 185041 46.10
40mm Green P9CEM4VN 190042 52.20 P9XEM4VN 185042 46.10
40mm Yellow P9CEM4GN 190043 52.20 P9XEM4GN 185043 46.10
60mm Red P9CEM6RN 190051 57.20 P9XEM6RN 185051 48.40
Push-Pull to Release 40mm Red P9CET4RN1 190061 76.40 P9XET4RN1 185061 70.60
Push-Twist 28mm Red P9CER3RN 190070 74.00 P9XER3RN 185070 70.60
to Release 40mm Red P9CER4RN 190071 70.40 P9XER4RN 185071 70.60
Push-Key to Release 40mm Red
P9CEC4RN95
190073 138.30 P9XEC4RN95 185074 126.80
P9 SerieS
Complete Unit Push-button Contact Block
CONTROL &
AUTOMATION
129
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
IB Selector Switches (Black) IP66
CHROME PLASTIC
DESCRIPTION CAT ORDER PRICE $ CAT ORDER PRICE $
REF CODE excl. GST REF CODE excl. GST
2 Position Selector Push-button
P9CPS22G 190691 75.10
Toggle Switch
P9CCD 190695 60.50 P9XCD 185695 56.20
Fixed Short Handle
P9CSMD0N 190110 50.20 P9XSMD0N 185110 42.50
Fixed Long Handle
P9CSVD0N 190370 56.20 P9XSVD0N 185370 44.90
Spring Return Right to Centre Short Handle
P9CSMI5N 190150 62.50 P9XSMI5N 185150 59.50
Spring Return Right to Centre Long Handle
P9CSVI5N 190374 66.80 P9XSVI5N 185374 58.30
Spring Return Left to Centre Short Handle
P9CSMH1N 190160 62.50 P9XSMH1N 185160 59.50
Spring Return Left to Centre Long Handle
P9CSVH1N 190375 66.80 P9XSVH1N 185375 58.30
3 Position Selector Push-button
P9CBS35G 190694 75.10
Fixed Short Handle
P9CSMZ0N 190200 51.80 P9XSMZ0N 185200 43.70
Fixed Long Handle
P9CSVZ0N 190379 51.60 P9XSVZ0N 185379 49.10
1 Spring Return Right to Centre Short Handle
P9CSMZ5N 190280 59.40 P9XSMZ5N 185280 57.00
1 Spring Return Right to Centre Long Handle
P9CSVZ5N 190387 58.30 P9XSVZ5N 185387 51.60
1 Spring Return Left to Centre Short Handle
P9CSMZ1N 190240 59.40 P9XSMZ1N 185240 57.00
1 Spring Return Left to Centre Long Handle
P9CSVZ1N 190383 58.30 P9XSVZ1N 185383 51.60
2 Spring Returns to Centre Short Handle
P9CSMZ3N 190320 56.20 P9XSMZ3N 185320 50.20
2 Spring Returns to Centre Long Handle
P9CSVZ3N 190391 59.80 P9XSVZ3N 185391 51.80
4 Position Fixed Short Handle
P9CSMX0N 190330 80.50 P9XSMX0N 185330 76.40
Fixed Long Handle
P9CSVX0N 190392 82.80 P9XSVX0N 185392 75.40
5 Position Fixed Short Handle
P9CSMY0N 190350 80.50 P9XSMY0N 185350 76.40
Fixed Long Handle
P9CSVY0N 190394 82.80 P9XSVY0N 185394 75.40
IB Key Selector Switches (Black) IP66
CHROME PLASTIC
DESCRIPTION KEY REMOVAL CAT REF ORDER PRICE $ CAT REF ORDER PRICE $
POSITION CODE excl. GST CODE excl. GST
2 Position Fixed I P9CSCD0A95 190400 123.80 P9XSCD0A95 185400 117.70
Fixed I+I P9CSCD0K95 190402 123.80 P9XSCD0K95 185402 117.70
Fixed 1 Spring Rtrn R-L I P9CSCD5A95 190409 139.50 P9XSCD5A95 185409 123.80
Fixed 1 Spring Rtrn R-C 0 P9CSCI5C95 190410 139.50 P9XSCI5C95 185410 123.80
3 Position Fixed 0 P9CSCZ0C95 190434 135.90 P9XSCZ0C95 185434 123.80
Fixed II P9CSCZ0E95 190435 135.90 P9XSCZ0E95 185435 123.80
Fixed I P9CSCZ0A95 190433 135.90 P9XSCZ0A95 185433 123.80
Fixed I+II P9CSCZ0K95 190437 135.90 P9XSCZ0K95 185437 123.80
Fixed I+0+II P9CSCZ0T95 190439 135.90 P9XSCZ0T95 185439 123.80
2 Spring Rtrn to Ctr 0 P9CSCZ3C95 190467 135.90 P9XSCZ3C95 185467 123.80
1 Spring Rtrn LH to Ctr II P9CSCZ1E95 190450 135.90 P9XSCZ1E95 185450 123.80
1 Spring Rtrn LH to Ctr O P9CSCZ1C95 190449 135.90 P9XSCZ1C95 185449 123.80
III
0
I
0
I
0
III
II IV
III
IV
I
II III
IV
III
III
O
I
0
III
0
III
III
0
III
0
III
0
III
0
III
=+
III
0
I
0
I
0
III
II IV
III
IV
I
II III
IV
III
III
O
I
0
III
0
III
III
0
III
0
III
0
III
0
III
III
0
I
0
I
0
III
II IV
III
IV
I
II III
IV
III
III
O
I
0
III
0
III
III
0
II
I
0
II
I
0
II
I
0
III
III
0
I
0
I
0
III
II IV
III
IV
I
II III
IV
II
I
II
I
O
I
0
II
I
0
II
I
III
0
III
0
III
0
III
0
III
P9 SerieS
Complete Unit Selector Switch Contact Block
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
130
IF Illuminated Push-buttons IP66
CHROME PLASTIC
DESCRIPTION COLOUR CAT ORDER PRICE $ CAT ORDER PRICE $
REF CODE excl. GST REF CODE excl. GST
Red P9CPLRGD 190491 48.60 P9XPLRGD 185491 32.20
Green P9CPLVGD 190492 48.60 P9XPLVGD 185492 32.20
Yellow P9CPLGGD 190493 48.60 P9XPLGGD 185493 32.20
Orange P9CPLAGD 190495 48.60 P9XPLAGD 185495 32.20
Blue P9CPLLGD 190496 48.60 P9XPLLGD 185496 32.20
White P9CPLBGD 190497 48.60 P9XPLBGD 185497 32.20
Clear P9CPLIGD 190498 48.60 P9XPLIGD 185498 32.20
Red P9CPLRSD 190501 48.60 P9XPLRSD 185501 32.20
Green P9CPLVSD 190502 48.60 P9XPLVSD 185502 32.20
Yellow P9CPLGSD 190503 48.60 P9XPLGSD 185503 32.20
Orange P9CPLASD 190505 48.60 P9XPLASD 185505 32.20
Blue P9CPLLSD 190506 48.60 P9XPLLSD 185506 32.20
White P9CPLBSD 190507 48.60 P9XPLBSD 185507 32.20
Clear P9CPLISD 190508 48.60 P9XPLISD 185508 32.20
Flush Push-button
Diffused Lens
Spring Return
Raised Push-button
Diffused Lens
Spring Return
IF Illuminated Emergency Stop Push-buttons IP66
Spring Return 40mm Red P9CEM4RL 190551 88.30 P9XEM4RL 185551 79.50
Push-Pull Release 40mm Red P9CET4RL1 190561 107.00 P9XET4RL1 185561 96.40
IF Illuminated Selector Switches IP66
Red P9CSLDOR 190591 67.40 P9XSLDOR 185591 57.00
Green P9CSLD0V 190592 67.40 P9XSLD0V 185592 57.00
Yellow P9CSLD0G 190593 67.40 P9XSLD0G 185593 57.00
Orange P9CSLD0A 190595 67.40 P9XSLD0A 185595 57.00
Blue P9CSLD0L 190596 67.40 P9XSLD0L 185596 57.00
White P9CSLD0B 190597 67.40 P9XSLD0B 185597 57.00
Clear P9CSLD0I 190598 67.40 P9XSLD0I 185598 57.00
Red P9CSLZOR 190601 67.40 P9XSLZOR 185601 57.00
Green P9CSLZ0V 190602 67.40 P9XSLZ0V 185602 57.00
Yellow P9CSLZ0G 190603 67.40 P9XSLZ0G 185603 57.00
Orange P9CSLZ0A 190605 67.40 P9XSLZ0A 185605 57.00
Blue P9CSLZ0L 190606 67.40 P9XSLZ0L 185606 57.00
White P9CSLZ0B 190607 67.40 P9XSLZ0B 185607 57.00
Clear P9CSLZ0I 190608 67.40 P9XSLZ0I 185608 57.00
2 Position Fixed
3 Position Fixed
=+ +
Complete Unit Illuminated Push-button LED Contact Block
P9 SerieS
CONTROL &
AUTOMATION
131
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
=+
IE Illuminated Pilot Light IP66
Diffused Lens Red P9CLRD 190791 24.90 P9XLRD 185791 17.60
for LEDs Green P9CLVD 190792 24.90 P9XLVD 185792 17.60
Yellow P9CLGD 190793 24.90 P9XLGD 185793 17.60
Orange P9CLAD 190795 24.90 P9XLAD 185795 17.60
Blue P9CLLD 190796 24.90 P9XLLD 185796 17.60
White P9CLBD 190797 24.90 P9XLBD 185797 17.60
Clear P9CLID 190798 24.90 P9XLID 185798 17.60
IE Unibloc Pilot Light (Complete) IP66
Diffused Lens Red P9XURDRN 185841 27.40
Green P9XUVDRN 185842 27.40
230V with resistor refracted lens. BA9110V 2W bulb included
IN Double Function Push-buttons (plastic) IP66
Flush Green
Indicator Light P9DPLVRGO1 186891 46.10
Flush Red
Flush Green
Indicator Light P9DPLVRSO1 186893 46.10
Raised Red
IJ Double Function Clear Cap IP66
Clear Cap (IEC 529) Flush/Raised P9ADCST 187796 17.00
Silicon Flush/Flush 080CPDT 173208 17.00
CHROME PLASTIC
DESCRIPTION COLOUR CAT ORDER PRICE $ CAT ORDER PRICE $
REF CODE excl. GST REF CODE excl. GST
Complete Unit Pilot Light Head LED
P9 SerieS
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
132
DESCRIPTION POSITION LAMP CAT REF ORDER PRICE $
ON FLANGE INCLUDED CODE excl.GST
2 3 1
X1
X2
X2
X1
X2
X5
X1
IG Integral LED (Panel Mount)
SUPPLY COLOUR CAT ORDER PRICE $
VOLTAGE REF CODE excl.GST
24V AC/DC Orange P9PLNVDA 197000 34.90
White P9PLNVDB 197001 34.90
Yellow P9PLNVDG 197002 34.90
Blue P9PLNVDL 197003 34.90
Red P9PLNVDR 197004 34.90
Green P9PLNVDV 197005 34.90
110-120V AC Orange P9PLNVJA 197006 35.80
White P9PLNVJB 197007 38.80
Yellow P9PLNVJG 197008 35.80
Blue P9PLNVJL 197009 35.80
Red P9PLNVJR 197010 35.80
Green P9PLNVJV 197011 35.80
220-240V AC Orange P9PLNVNA 197012 49.20
White P9PLNVNB 197013 49.20
Yellow P9PLNVNG 197014 49.20
Blue P9PLNVNL 197015 49.20
Red P9PLNVNR 197016 49.20
Green P9PLNVNV 197017 49.20
Lamp Comparison
Bulb Type Service
Life
Approx. Lifespan
(hours)
Shock & Vibration
Immunity
Operating
Te mperature
Power
Consumption
Brightness
LED
Incandescent(Ba9s)
Neon
100,000
2,000
20,000
( 11 yrs )
( 3 mths )
( 28 mths )
High 16g
Low
Medium
Low (-25 to +70oC)
High
Low
Low (20mA)
High
Low
High
Medium
Low
IG Power Supplies
Full Voltage - AC/DC
IEC: BA9S max 380V-2W NO P9PDNVO 187020 18.40
Resistor + Diode
220/240 V-AC
BA9S 130V-2W included YES P9PRDVN 187022 56.20
Test Full Voltage - AC/DC
IEC: BA9S max 380V-2W
not included NO P9PDTVO 187027 40.10
Suitable for all illuminated push-buttons and pilot lights
IG Integral LED (Base Mount)
24V AC/DC Orange P9PLNBDA 197036 34.90
White P9PLNBDB 197037 34.90
Yellow P9PLNBDG 197038 34.90
Blue P9PLNBDL 197039 34.90
Red P9PLNBDR 197040 34.90
Green P9PLNBDV 197041 34.90
120V AC Orange P9PLNBJA 197042 41.20
White P9PLNBJB 197043 41.20
Yellow P9PLNBJG 197044 41.20
Blue P9PLNBJL 197045 41.20
Red P9PLNBJR 197046 41.20
Green P9PLNBJV 197047 41.20
230V AC Orange P9PLNBNA 197048 65.90
White P9PLNBNB 197049 65.90
Yellow P9PLNBNG 197050 65.90
Blue P9PLNBNL 197051 65.90
Red P9PLNBNR 197052 65.90
Green P9PLNBNV 197053 65.90
P9 SerieS
CONTROL &
AUTOMATION
133
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
ID Panel Mounted Contact Blocks
DESCRIPTION COLOUR SPACES CAT ORDER PRICE $
TYPE USED REF CODE excl. GST
1 N/C 1 P9B01VN 187001 14.20
1 N/O 1 P9B10VN 187002 14.20
1 N/O + 1N/C 1 P9B11VN 187000 32.80
2 N/C 1 P9B02VN 187008 32.80
2 N/O 1 P9B20VN 187009 32.80
1 N/C 1 P9B01VR 187003 14.20
1 N/O 1 P9B10VA 187004 21.80
Fits both chrome and plastic buttons.
Standard
Opening
NC Late Opening
NO Early Closing
IJ Blank Insert Holder (with Black Legend Plate)
DESCRIPTION CAT ORDER PRICE $
REF CODE excl.GST
Standard 30 x 50mm P9ARTBS 188000 3.20
Extended 45 x 50mm P9ARTBM 188001 4.40
All extended legend plates are engraved to request
IJ Insert Holder (C/W Engraved Legend Plate 30x50mm)
TEXT ORDER PRICE $ TEXT ORDER PRICE $
CODE excl.GST CODE excl.GST
Stop 188201 6.00 Overload Tripped 188226 6.00
Start 188202 6.00 Stop Reset 188227 6.00
Down 188203 6.00 Emergency Stop 188229 6.00
Up 188204 6.00 For Rev 188231 6.00
Close 188205 6.00 Stop Start 188232 6.00
Open 188206 6.00 Off On 188233 6.00
Slow 188207 6.00 Open Close 188234 6.00
Fast 188208 6.00 For Off Rev 188239 6.00
Inch 188209 6.00 Power On 188240 6.00
Run 188211 6.00 Hand Auto 188243 6.00
On 188212 6.00 High Low 188244 6.00
Off 188213 6.00 Rev For 188250 6.00
Forward 188214 6.00 Start Stop 188255 6.00
Reverse 188215 6.00 Up Down 188256 6.00
Raise 188216 6.00 Auto Off Hand 188258 6.00
Lower 188217 6.00 For Stop Rev 188259 6.00
Fault 188218 6.00 Hand Off Auto 188261 13.80
Auto 188219 6.00 Man Off Auto 188269 13.80
Hand 188220 6.00 Reset 188291 6.00
Left 188222 6.00 Right 188224 6.00
Ask us for any engraving that is not listed
Round plates for emergency push-buttons (Black on Yellow background)
59mm Round Plate - Blank 080XTGR 179514 7.60
59mm “Emergency - Stop” 080XTGR02 179526 8.30
78mm “Emergency - Stop” 080XTG802 179536 8.40
P9 SerieS
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
134
IJ Engraved Caps for Push-buttons
TEXT SYMBOL COLOUR SUIT PUSH CAT ORDER PRICE $
BUTTON TYPE REF CODE excl.GST
Reset Blue Flush P9ARBGL 037 187143 6.70
Stop Red Flush P9ARBGR 201 187147 6.70
Raised P9ARBSR 201 187247 6.70
Start Green Flush P9ARBGV 201 187149 6.70
Raised P9ARBSV 201 187249 6.70
Caps can be removed with a knife or similar
R
START
STOP
R
START
STOP
R
START
STOP
IJ Accessories
DESCRIPTION CAT ORDER PRICE $
REF CODE excl.GST
Contact Flanges
With Three Positions (Centre Distances 30x50mm) P9ACFS3 187841 6.30
With Five Positions (Centre Distances 50x50mm) P9ACFS5 187842 9.00
Ring Reducers
Allows 22.5 Devices to be Mounted in 30mm Diameter Hole
Black P9ARAX32 188803 21.80
Chrome P9ARAM32 188801 21.80
Plugs
Use to fill an empty 22mm hole
Round P9ARHPR 187491 9.90
Square 30 x 30mm P9ASHP3 187792 10.30
Rectangular 30 x 50mm P9ASHP5 187793 10.30
Covers
Protection Cover Padlocked
for Standard Push-buttons/Selector Switches
Illuminated Push-buttons/Selector Switches P9ACRCL 187840 48.50
Protection Collar
Collar for Push-buttons ø 40mm P9ARRE4 187492 27.90
System to Convert Momentary to Maintained
Device for Standard Push-buttons and Illuminated Push-buttons
To be added only to single-pole contact blocks. P9ACDPP 187843 37.00
The NO-contacts must be early closing types. (P9B10VA) P9B10VA 187004 21.80
Other
Locking Ring Wrench P9ACWAF 187845 21.50
Spare Key (code 3095) 173095 18.60
Potentiometer Operator (potentiometer not included) P9XZ 185772 155.30
Buzzer 24V AC Frequency 85db at 1m P9XBD 185773 182.00
Buzzer 110-240V AC Frequency 85db at 1m P9XBM 185774 182.00
P9 SerieS
CONTROL &
AUTOMATION
135
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
With Interlock
4 Fixed Positions P9CMB4F 190740 156.50
4 Momentary Positions P9CMB4T 190741 156.50
* Contact block for use with joysticks 2 position = 1 x 187000, 4 position = 2 x 187000
II Mechanical Reset Buttons IP66
DESCRIPTION CAT REF ORDER PRICE $ CAT REF ORDER PRICE $
CHROME CODE excl. GST PLASTIC CODE excl. GST
Reset Push-button P9CRG 190771 60.70 P9XRG 185771 54.80
(White Symbol On Blue Background)
Extending Screw P9ACVLR 187844 24.90
(Setting Min 80mm. 170mm Max)
I0 Joysticks (Chrome) IP66
CAT ORDER PRICE $
REF CODE excl. GST
2 Positions + Central Zero Positions Without Interlock
2 Fixed Positions P9CMN2F 190700 148.10
2 Momentary Positions P9CMN2T 190701 148.10
1 Momentary - 1 Fixed P9CMN2A 190702 148.10
1 Fixed - 1 Momentary P9CMN2B 190703 148.10
1
3
0
4 Positions + Central Zero Positions Without Interlock
4 Fixed Positions P9CMN4F 190720 151.60
4 Momentary Positions P9CMN4T 190721 151.60
1
3
02
4
IK Control Stations (Thermoplastic) IP66
COLOUR OPERATORS CONTACT NAMEPLATE CAT ORDER PRICE $
REF CODE excl. GST
One Button
Green Flush Push-button 1 N/O 1 (Start) P9EPA01Y02 189010 89.50
Red Flush Push-button 1 N/C 0 (Stop) P9EPA01Y04 189012 89.50
Key Selector Switch 2 Position (Key code 3095) 1 NO/NC 0 (Stop) - 1 (Start) P9EPA01Y06 189014 137.90
Two Buttons (Start/Stop)
Green Flush Push-button 1 N/O 1 (Start) P9EPA02Y01 189016 137.90
Red Flush Push-button 1 N/C 0 (Stop)
Three Buttons (Start/Stop - Pilot Light)
Green Flush Push-button 1 N/O 1 (Start) P9EPA03Y01 189018 185.20
Red Flush Push-button 1 N/C 0 (Stop)
White Full Voltage Pilot Light Pilot Light Blank
BA9S max 380V-2W not incl.
IK Emergency Stop Control Station IP66
One Button
Red Emergency Push-button 1 N/C 0 (Stop) P9EPAG1Y08 189025 136.10
(with latch turn to release)
Red Emergency Push-button 1 N/C 0 (Stop) P9EPAG1Y95 192.90
with latch key to
release (Key code 3095)
Control station has yellow lid and a grey base
With Interlock
Without Interlock
P9 SerieS
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
136
IK Enclosures for Push-button Stations (Thermoplastic) IP66
DESCRIPTION No. OF HOLES DIMENSIONS CAT ORDER PRICE $
H W D REF CODE excl. GST
(mm) (mm) (mm)
Light Grey Coloured 1 72 72 57 P9EPE01 189001 45.90
Base and Lid 2 110 72 57 P9EPE02 189002 57.40
3 140 72 57 P9EPE03 189003 69.40
4 175 72 57 P9EPE04 189004 97.30
6 235 72 57 P9EPE06 189005 122.70
Grey Base Yellow Lid 1 72 72 57 P9EPEG1 189000 45.90
(Emergency Stop) Function
ID Contact Blocks (Base Mount)
DESCRIPTION CONTACT TYPE SPACES USED
Standard 1N/C 1 P9B01BN 187017 21.80
Opening 1N/O 1 P9B10BN 187018 17.60
IG Power Supplies (Base Mount)
DESCRIPTION POSITION 2 3 1 LAMP
ON FLANGE INCLUDED
Full Voltage-
IEC: BA9S max 380V-2W NO P9PDNB0 187070 19.50
Resistor=Diode
220/240V
BA9S 130V-2W included YES P9PRDBN 187072 58.30
Integral LED Base Mount Range Refer page 132
X1
X2
X2
X1
IK Legend Plates for Station (20 x 20mm)
DESCRIPTION CAT ORDER PRICE $ DESCRIPTION CAT ORDER PRICE $
REF CODE excl.GST REF CODE excl.GST
WITHOUT TEXT P9AELN 189030 3.90 P9AELN006 189041 3.90
START P9AELN202 189031 3.90 I P9AELN028 189042 3.90
STOP P9AELN201 189032 3.90 O P9AELN029 189043 3.90
FORWARD P9AELN214 189033 3.90 II P9AELN035 189044 3.90
REVERSE P9AELN215 189034 3.90 III P9AELN038 189045 3.90
CLOSE P9AELN205 189035 3.90 O-I P9AELN039 189046 3.90
OPEN P9AELN206 189036 3.90 I-O-II P9AELN042 189047 3.90
UP P9AELN204 189037 3.90
DOWN P9AELN203 189038 3.90
LEFT P9AELN222 189152 3.90
RIGHT P9AELN224 189154 3.90
Bilaminated, self-adhesive, black background, white engraving
P9 SerieS
CONTROL &
AUTOMATION
137
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
VERTICAL
ACTION
ELECTRONIC OVERLOAD RELAYS
>
>
>
>
>
>
>
>
>
>
>
MAIN CHARACTERISTICS
Standards/Approvals: IEC/EN 60947-1, IEC/EN 60947-4-1,
IEC/EN 60947-5-1, UL 508, NEMA ICS-1, CSA C22.2/14, JIS C8325
M SERIES MINI-CONTACTORS
Industrial range of mini-contactors
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
138
20A 2.2 3 6A 1 - MC0C310AT• 100156 114.50
20A 2.2 3 6A - 1 MC0C301AT• 100166 114.50
20A 4 5.5 9A 1 - MC1C310AT• 100216 118.05
20A 4 5.5 9A - 1 MC1C301AT• 100226 118.05
Low Consumption Coil 1.2W (PLC)
20A 4 5.5 9A 1 - MC1I310AT• 100572 118.05
20A 4 5.5 9A - 1 MC1I301AT• 100573 118.05
20A 5.5 7.3 12A 1 - MC2I310AT• 100559 196.65
20A 5.5 7.3 12A - 1 MC2I301AT• 100538 196.65
JA 3 Pole Contactors AC
20A 2.2 3 6A 1 - MC0A310AT• 102437 102439 100154 102435 90.85
20A 2.2 3 6A - 1 MC0A301AT• 102458 102471 100164 102456 90.85
20A 4 5.5 9A 1 - MC1A310AT• 102617 102619 100214 102615 110.40
20A 4 5.5 9A - 1 MC1A301AT• 102638 102640 100224 102636 110.40
20A 5.5 7.3 12A 1 - MC2A310AT• 103577 135701 103574 135704 114.20
20A 5.5 7.3 12A - 1 MC2A301AT• 103569 103358 103566 135705 114.20
COIL VOLTAGES
415V AUXILIARY CAT 24V 110V 230V 415V PRICE $
AC1 kW HP AC3 N/O N/C REF ORDER CODES excl. GST
JA 3 Pole Contactors DC
JE 4 Pole Contactors DC
20A 4 5.5 9A 4 - MC1C400AT• 100366 128.30
20A 4 5.5 9A 2 2 MC1CB00AT• 100376 133.15
Other coil voltages available on request
JB Thermal Overloads
SETTING RANGE CAT ORDER PRICE $
MIN. MAX. REF CODE excl. GST
0.11 0.17 MT03A 101000 135.80
0.17 0.26 MT03B 101001 135.80
0.26 0.43 MTO3C 101002 135.80
0.43 0.65 MT03D 101003 135.80
0.65 1 MT03E 101004 135.80
0.85 1.3 MT03F 101005 135.80
1.1 1.6 MT03G 101006 135.80
1.35 2 MT03H 101007 135.80
1.7 2.4 MT03I 101008 135.80
2.2 3.2 MT03J 101009 135.80
2.5 4 MT03R 101015 135.80
3 4.7 MT03K 101010 135.80
4 6.3 MT03L 101011 135.80
5.5 8 MT03M 101012 135.80
7.5 10.5 MT03N 101013 135.80
10 14 MT03P 101014 135.80
JD Replacement Coils
AC MB0A• 102407 102409 100454 102405 38.85
DC MB0C• 100466 48.20
M SerieS
JA 4 Pole Contactors AC
20A 4 5.5 9A 4 - MC1A400AT• 102986 102988 100364 102984 119.75
20A 4 5.5 9A - 4 MC1AA00AT• 103028 103030 100384 103026 123.50
20A 4 5.5 9A 2 2 MC1AB00AT• 103007 103009 100374 103005 123.50
20A 5.5 7.3 12A 4 - MC2A400AT• 101645 101646 116177 116193 137.40
COIL VOLTAGES
415V POWER CAT 24V 110V 230V 415V PRICE $
AC1 kW HP AC3 N/O N/C REF ORDER CODES excl. GST
CONTROL &
AUTOMATION
139
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
M SerieS
JC Auxiliary Contacts
MOUNTING CONTACTS CAT ORDER PRICE $
NO NC REF CODE excl.GST
Front 1 1 MACN211AT 100999 31.40
- 2 MACN202AT 100998 31.40
2 - MARN220AT 100994 31.40
2 2 MACN422AT 100996 45.80
1 3 MACN413AT 100995 45.80
3 1 MACN431AT 100997 45.80
4 - MARN440AT 100991 45.80
- 4 MARN404AT 100987 45.80
Side (Left or Right) - 1 MACL101AT 100561 25.45
1 - MACL110AT 100560 25.45
Minimum operational power -5mA 17V
JC Accessories for Thermal Overload Relays
DESCRIPTION CAT ORDER PRICE $
REF CODE excl.GST
Base for separate mounting of the Overload Relay on 35mm Din Rail MVB0T 101021 18.80
Input terminals for separate mounting MVE0T 101020 34.20
Auxiliary instantaneous contact block. Frontal fixing to the relay MATV10AT 101022 27.10
With trip indicator (0-1). One block per relay and only for manual reset
JC Voltage Suppressor Block
For suppression of disturbances in electronic circuits due to the coil transient voltage occurring on opening of the
contactor. Limits high voltage transients that may be produced when coil is de-energised.
SURGE CONTROL VOLTAGE CAT ORDER PRICE $
SUPPRESSOR TYPE REF CODE excl. GST
R/C AC 12...60V 50/60 Hz MP0AAE1 100544 39.95
AC 72...250V 50/60Hz MP0AAE2 100545 39.95
Diode DC 6...250V DC MP0CAE3 100546 39.95
Connection and (plug-in) fixing on to the contactor
Not suitable for low consumption coil contactors
JC Mechanical Interlock
Used for interlocking of two contactors, prevents the closing of one contactor (as long as the other remains closed).
Horizontal - Side Mounting MMHO 100547 13.20
JC Electronic Timer Blocks
CONTROL circ. FUNCTION TIME CAT ORDER PRICE $
REF CODE excl. GST
24-250V AC/DC Delay ON 0.5 - 60 s. MREBC10AC2 100541 167.90
24-250V AC/DC Delay ON 0.2 - 24 s. MREBC20AC2 100542 167.90
DIN rail adaptor for electronic timer block MVB0R 100543 14.80
Side or front mounting
Accessories for Mini Contactors
MOUNTING CAT ORDER PRICE $
REF CODE excl. GST
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
140
JH 4 Pole Contactors AC
25A 18 12A 4 - CL01A400T• 110600 110602 104314 109891 177.30
25A 5.5 12A 2 2 CL01AB00T• 110656 110658 104384 110066 177.30
32A 23 18A 4 - CL02A400T• 110608 110610 104324 109907 232.10
32A 7.5 18A 2 2 CL02AB00T• 110664 142231 104394 110082 232.10
45A 32 25A 4 - CL03A400M• 110616 110618 104334 109923 274.15
45A 12 25A 2 2 CL03AB00M• 110672 110674 104404 110098 274.15
60A 43 32A 4 - CL04A400M• 110624 110626 104344 109939 394.50
60A 16 32A 2 2 CL04AB00M• 110680 110682 104414 110114 394.50
90A 22 50A 4 - CL05A400M• 110632 110634 104354 109955 691.30
90A 22 50A 2 2 CL05AB00M• 110688 110690 104424 110129 797.00
110A 79 65A 4 - CL07A400M• 110762 110642 104364 109971 825.00
110A 37 65A 2 2 CL07AB00M• 110696 110698 104434 110145 875.00
110A 45 80A 2 2 CL08AB00M• 110704 110706 104444 110161 1136.60
140A 100 95A 4 - CL09A400M• 110648 110650 104374 109987 1203.40
COIL VOLTAGES
415V AUXILIARY CAT 24V 110V 230V 415V PRICE $
AC1 kW HP AC3 N/O N/C REF ORDER CODES excl. GST
JH 3 Pole Contactors AC
25A 4 5.5 9A 1 - CL00A310T• 109173 109175 104054 109169 133.75
25A 4 5.5 9A - 1 CL00A301T• 109197 109199 104064 109193 133.75
25A 5.5 7.5 12A 1 - CL01A310T• 109244 109246 104084 109240 142.50
25A 5.5 7.5 12A - 1 CL01A301T• 109268 109270 104094 109264 142.50
32A 7.5 10 18A 1 - CL02A310T• 109317 109319 104114 109313 198.00
32A 7.5 10 18A - 1 CL02A301T• 109341 109343 104124 109337 198.00
45A 11 15 25A - - CL25A300T• 110728 110730 110804 110724 262.85
45A 12 16 25A 1 - CL03A310M• 109389 109391 104144 109385 262.85
45A 12 16 25A - 1 CL03A301M• 109413 109415 104154 109409 262.85
60A 16 22 32A 1 - CL04A310M• 109461 109463 104174 109457 320.95
60A 16 22 32A - 1 CL04A301M• 109485 109487 104184 109481 320.95
60A 22 30 40A 1 1 CL45A311M• 112821 112823 112804 112817 383.85
90A 25 34 50A 1 1 CL06A311M• 109580 109582 104224 109576 611.10
110A 37 50 65A 1 1 CL07A311M• 109628 109630 104244 109624 664.55
110A 45 60 80A 1 1 CL08A311M• 109676 109678 104264 109672 910.55
140A 50 68 95A 1 1 CL09A311M• 109724 109726 104284 109720 1005.55
140A 55 75 105A 1 1 CL10A311M• 109772 109774 104304 109768 1141.90
4 FRAME SIZES
CL00
CL01
CL02
CL25
CL03
CL04
CL45
CL06
CL07
CL08
CL09
CL10
JM 3 Pole Contactors DC
25A 4 5.5 9A 1 - CL00D310T• 112006 237.25
25A 5.5 7.5 12A 1 - CL01D310T• 112026 204.80
32A 7.5 10 18A 1 - CL02D310T• 112046 292.05
45A 11 15 25A - - CL25D300T• 112066 309.90
45A 12 16 25A 1 - CL03D310M• 112076 362.15
60A 16 22 32A 1 - CL04D310M• 112096 370.75
60A 22 30 40A - - CL45D300M• 112116 618.95
90A 25 34 50A - - CL06E300M• 112126 798.50
110A 37 50 65A - - CL07E300M• 112136 1076.65
110A 45 60 80A - - CL08E300M• 112146 1273.65
140A 50 68 95A - - CL09E300M• 112156 1455.95
140A 55 75 105A - - CL10E300M• 112166 1586.25
COIL VOLTAGES
415V POWER CAT 24V 110V 230V 415V PRICE $
AC1 kW HP AC3 N/O N/C REF ORDER CODES excl. GST
CONTROL &
AUTOMATION
141
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
JM 4 Pole Contactors DC
25A 18 12A 4 - CL01A400T• 112176 285.30
25A 5.5 12A 2 2 CL01AB00T• 112246 285.30
32A 23 18A 4 - CL02A400T• 112186 327.30
32A 7.5 18A 2 2 CL02AB00T• 112256 327.30
45A 32 25A 4 - CL03A400M• 112196 388.45
45A 12 25A 2 2 CL03AB00M• 112276 652.00
60A 43 32A 4 - CL04A400M• 112201 652.00
60A 16 32A 2 2 CL04AB00M• 112276 652.00
90A 22 50A 4 - CL05A400M• 112216 861.80
90A 22 50A 2 2 CL05AB00M• 112286 958.70
110A 79 65A 4 - CL07A400M• 112226 1176.55
110A 37 65A 2 2 CL07AB00M• 112296 1295.10
110A 45 80A 2 2 CL08AB00M• 112306 1834.70
140A 100 95A 4 - CL09A400M• 112236 1666.50
Replacement Coils AC & DC
AC CL00...CL25 LB1A• 110416 110418 104634 110412 90.85
CL03...CL45 LB3A• 110449 110451 104644 110445 90.85
CL05...CL10 LB4A• 110482 110484 104654 110478 114.55
DC CL00...CL25 LB1D• 112316 110.15
CL03...CL45 LB3D• 112326 185.30
CL05...CL10 LB4E• 112336 320.95
JJ Auxiliary Contacts CL & CK Series
FRONT 1 - BCLF10 104700 18.60
- 1 BCLF01 104701 18.60
Make before Break - 1 BCLF01G 104703 20.25
Make before Break 1 - BCLF10G 104702 20.25
Side (Left or Right) 1 1 BCLL11 104707 61.45
2 - BCLL20 104706 61.45
Side, combinations of 1 1 BRLL11 104705 61.45
more than 2 blocks 2 - BRLL20 104704 61.45
MOUNTING CONTACTS CAT ORDER PRICE $
NO NC REF CODE excl.GST
JF Series RL Auxiliary Contactors (Control Relays) AC
For switching of resistive and AC2 type loads
10A - 4 RL4RA004T• 109088 109090 104034 109084 97.70
JJ Mechanical Interlock
MOUNTING TYPE FOR USE WITH
Horizontal Mechanical CL & RL BELA 104723 45.20
Horizontal Mech./Electrical CL00...CL45 BELA02 104724 57.90
MAXIMUM NUMBER OF AUXILIARY CONTACT BLOCKS PER EACH CONTACTOR
FOR USE WITH MAXIMUM NUMBER OF ARRANGEMENT OF AUX.
AUX. CONTACT BLOCKS CONTACT BLOCKS
5-15 HP Contactors (CL00, CL01, CL02, CL25) 4 4 Front-Mount, or 1 Side-Mount on each side
20-25 HP Contactors (CL03, CL04, CL45) 6 4 Front-Mount, plus 1 Side-Mount, or
2 Front-Mount plus 1 Side-Mount on each side
30-75 HP Contactors (CL05, CL06, CL07, CL08, 8 6 Front-Mount, plus 1 Side-Mount,
CL09, CL10) or 2 Side-Mount on each side
COIL VOLTAGES
415V POWER CAT 24V 110V 230V 415V PRICE $
AC1 kW HP AC3 N/O N/C REF ORDER CODES excl. GST
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
142
JI RT1 Thermal Overloads (for use with CL00 - CL45)
0.16 0.26 RT1B 113700 154.55
0.25 0.41 RT1C 113701 154.55
0.4 0.65 RT1D 113702 154.55
0.65 1.1 RT1F 113703 154.55
1 1.5 RT1G 113704 154.55
1.3 1.9 RT1H 113705 154.55
1.8 2.7 RT1J 113706 154.55
2.5 4 RT1K 113707 154.55
4 6.3 RT1L 113708 154.55
5.5 8.5 RT1M 113709 154.55
8 12 RT1N 113710 158.55
10 16 RT1P 113711 163.20
14.5 18 RT1S 113712 169.85
17.5 22 RT1T 113713 179.95
21 26 RT1U 113714 179.95
25 32 RT1V 113715 249.45
30 40 RT1W 113716 249.45
JP RT2 Thermal Overloads (for use with (CL05 - CL10)
11.5 15 RT2A 113717 435.80
14.5 19 RT2B 113718 435.80
18.5 25 RT2C 113719 435.80
24 32 RT2D 113720 435.80
30 43 RT2E 113721 435.80
42 55 RT2G 113722 470.80
54 65 RT2H 113723 470.80
64 82 RT2J 113724 522.20
78 97 RT2L 113725 568.80
90 110 RT2M 113726 568.80
JJ Accessories for Thermal Overload Relays
DESCRIPTION CAT ORDER PRICE $
REF CODE excl.GST
Base for separate mounting of the Overload Relay For use with RT1 RTXP 105170 41.85
on 35mm Din Rail For use with RT2 RT2XP 113764 80.75
Setting range cover protection For use with RT Range RTX3 113762 17.05
JY Remote Electrical Reset
RemoteElectricalResetAC/DC RTXRR• 113662 113664113665 113666 316.50
For use with RT RANGE
SETTING RANGE CAT ORDER PRICE $
MIN MAX REF CODE excl. GST
DESCRIPTION CAT ORDER CODES - COIL VOLTAGES PRICE $
REF 24V 110V 230V 415V excl. GST
JK Electronic Overloads
0.1 0.5A 101866 245.00
0.4 2A 101867 245.00
1 5A 101868 245.00
1.6 8A 101869 245.00
6.4 32A 101870 245.00
9 45A 101871 345.00
15 75A 101872 485.00
22 110A 101873 525.00
30 150A 101874 1995.00
CONTROL &
AUTOMATION
143
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
JJ Push-button with Flexible Cable IP66
Beldon Cable Length 500mm RTXS 113855 237.80
Beldon Cable Length 1 Metre RTXSL 113856 356.30
JJ Transient Voltage Suppressor Block
For suppression of disturbances in electronic circuits due to the coil transient voltage occurring on opening of the
contactor. Limits high voltage transients that may be produced when coil is de-energised.
SURGE CONTROL VOLTAGE FOR USE WITH CAT ORDER PRICE $
SUPPRESSOR TYPE REF CODE excl. GST
R/C AC 24V...48V CL00...CL45 BSLR2G 104713 44.65
50V...127V RL4RA... BSLR2K 104714 44.65
Diode 130V...240V BSLR2R 104715 44.65
R/C AC 24V...48V CL05A...CL10A BSLR3G 104716 81.35
50V...127V BSLR3K 104717 81.35
130V...240V BSLR3R 104718 81.35
Diode DC 12V...600V CL...D...RL4RC BSLDZ 104719 65.00
Varistor AC/DC 24V...48V CL00...CL10 BSLV3G 104720 81.35
50V...127V RL4RA... BSLV3K 104721 81.35
130V...240V BSLV3R 104722 81.35
277V...500V RL4RC... BSLV3U 110836 81.35
Directly connected parallel to the coil terminals A1-A2
JJ Interface Module
Interface between the DC control signal (PLC) and the AC operating mechanism of the contactor.
Directly connected in parallel to the coil terminals A1-A2 without cables, giving the facility of being used
together with front and/or side mounted auxiliary contact blocks.
Relay 24V 24-250V AC IMRD 113606 143.55
Relay + Forced Operation 24V 24-250V AC IMRFD 113608 227.40
Solid State 24V 24-250V AC IMSSD 113610 279.55
24-250V DC
Auto/Manual/Off control 24-250V AC/DC IMAMS 113611 242.40
For use with all CL & RL contactors
Electronic Timer Blocks
CONTROL circ. FUNCTION TIME CAT ORDER PRICE $
REF CODE excl. GST
24-250 V AC/DC Delay ON 0.1 - 2 s. BETL02C 113602 221.50
Delay ON 1.5 - 45 s. BETL45C 113603 221.50
Delay OFF 0.1 - 2 s. BETL02D 113604 221.50
Delay OFF 1.5 - 45 s. BETL45D 113605 221.50
Directly Connected Parallel to the Coil Terminals A1-A2
For use with all CL contactors
JJ Pneumatic Timer Blocks
MOUNTING FUNCTION TIME CONTACTS CAT ORDER PRICE $
REF CODE excl. GST
Front delay ON 0.1...30 s. 1 1 BTLF30C 104709 173.20
delay ON 1.0...60 s. 1 1 BTLF60C 104710 173.20
Front delay OFF 0.1...30 s. 1 1 BTLF30D 104711 205.95
delay OFF 1.0...60 s. 1 1 BTLF60D 104712 205.95
Sealing Cover Protection for Pneumatic Timer BTLFX 113001 27.10
For use with all CL & RL contactors
Pneumatic timers are adjustable time-delayed auxiliary contacts. They come equipped with two time-delayed con-
tacts: 1 NO and 1 NC, electrically separated. To mount a pneumatic timer, simply clip it on front face of contactor.
TYPE Ue (DC) CONTROL CIRC. CAT ORDER PRICE $
REF CODE excl. GST
DESCRIPTION CAT ORDER PRICE $
REF CODE excl. GST
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
144
JO 3 Pole Contactors AC & DC
AC 250A 80 108 150A 1 1 CK75CA311• 113101 113103 133188 113120 1675.60
AC/DC 250A 80 108 150A 1 1 CK75CE311• 113106 113108 113109 113125 2311.10
AC 250A 100 135 185A 1 1 CK08CA311• 113131 113133 133187 113147 2292.70
AC/DC 250A 100 135 185A 1 1 CK08CE311• 113136 113138 113139 113152 2796.80
AC 325A 125 170 205A 1 1 CK85BA311• 104471 104473 104474 110276 2640.00
AC/DC 315A 125 170 205A 1 1 CK85BE311• 104476 104478 104479 110281 3264.10
AC/DC 315A 132 180 250A 1 1 CK09BE311• 104486 104488 104489 110299 3264.10
AC/DC 450A 160 218 309A 1 1 CK95BE311• 104616 104618 104614 104611 4276.00
AC/DC 600A 230 312 420A 1 1 CK10CE311• 133783 133784 133286 133785 5493.40
AC/DC 700A 315 425 550A 1 1 CK11CE311• 133789 133790 133288 133791 6380.90
AC/DC 1000A 400 540 700A 1 1 CK12BE311• 104516 104518 104519 110305 9030.50
AC 1250A 450 610 825A 1 1 CK13BA311• - 104523 104524 104525 15046.90
415V COIL VOLTAGES
CONTROL AUXILIARY CAT 24V 110V 230V 415V PRICE $
CIRCUIT AC1 kW HP AC3 N/O N/C REF ORDER CODES excl. GST
JO 4 Pole Contactors AC & DC
AC 200A 143 - - 1 1 CK07BA411• 104531 104533 104534 104535 1854.10
AC/DC 200A 143 - - 1 1 CK07BE411• 104536 104538 104539 110340 2098.60
AC 325A 233 - - 1 1 CK08BA411• 104541 104543 104544 110353 2725.10
AC/DC 325A 233 - - 1 1 CK08BE411• 104546 104548 104549 110358 3690.20
AC/DC 400A 287 - - 1 1 CK09BE411• 104556 104558 104559 110376 5357.70
AC/DC 500A 359 - - 1 1 CK95BE411• 104560 104568 104569 110378 6362.10
AC/DC 600A 431 - - 1 1 CK10BE411• 133786 133787 133287 133788 6540.10
AC/DC 700A 503 - - 1 1 CK11BE411• 133972 133793 133289 133794 8662.90
AC/DC 1000A 719 - - 1 1 CK12BE411• 104596 104598 104599 110384 11780.70
AC 898 - - 1 1 CK13BA411• - 104603 104604 104605 18949.30
JR Replacement Coils & Electronic Modules AC & DC
CKCOIL CK75CE3...CK08CE3... KB4E• 104950 104957 104958 104959 304.10
CK85BE3...CK09BE3...CK95BE3...
CK07BE4... KB5E• 104850 104857 104858 104859 338.00
CK12BE3...CK09BE4...CK08BE4...
CK95BE4...CK12BE4... KB6E• 104860 104867 104868 104869 914.10
CK10CE3...CK11CE3...
CK10CE4...CK11CE4... KB7E• 113675 113673 113672 113671 914.10
CKELECTRONIC CK75CE3...CK08CE3... KM4E• 104960 104967 104968 104969 1418.80
MODULE CK85BE3...CK09BE3...CK95BE3...
CK07BE4... KM5E• 104870 104877 104878 104879 1713.50
CK12BE3...CK09BE4...CK08BE4...
CK95BE4...CK12BE4... KM6E• 104880 104887 104888 104889 1713.50
CK10CE3...CK11CE3...
CK10CE4...CK11CE4... KM7E• 113427 113429 113430 113431 1713.50
Replacement Coils AC
CK75CA3...CK08CA3... C12168• 104895 104893 104894 105313 331.90
NOELECTRONIC CK85BA3...CK07BA4... C04255• 104811 104813 104814 110511 281.10
MODULE CK08BA4... C04787• 104821 104823 104824 110527 752.30
CK13BA3...CK13BA4... C08998• 104572 104833 104834 104835 840.70
CONTROL &
AUTOMATION
145
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
FOR USE WITH SETTING RANGE CAT ORDER PRICE $
MIN MAX REF CODE excl. GST
JQ Single Pole Protection Covers IPXXB
DESCRIPTION QTY CAT REF
for CK75C - CK08C Set = 2 PTPCK75 103747 103.15
for CK85 - CK95 Set = 6 PTPCK95 103748 346.05
for CK10C - CK12C Set = 2 PTPCK11 103749 126.55
JP RT3 Thermal Overloads (for use with CK75 & CK08)
CK75 55 80 RT3B 113727 835.40
CK08 63 90 RT3C 113728 843.30
Direct 90 120 RT3D 113729 843.30
Mounting 110 140 RT3E 113730 963.70
140 190 RT3F 113731 963.70
JP RT4 Thermal Overloads (for use with CK85, 09, 95)
CK85 120 190 RT4N 113732 949.90
CK09 175 280 RT4P 113733 1225.60
CK95 200 310 RT4R 113734 1225.60
JP RT5 Thermal Overloads (for use with CK10, 11, 12)
CK10 120 190 RT5A 113750 1237.80
CK11 175 280 RT5B 113751 1237.80
CK12 250 400 RT5C 113752 1237.80
315 500 RT5D 113753 2026.00
430 700 RT5E 113754 2026.00
JP RT6 Thermal Overloads (for use with CK13)
CK13 500 850 RT6A 113760 2279.40
JJ Auxiliary Contacts CL & CK Series
FRONT 1 - BCLF10 104700 18.60
- 1 BCLF01 104701 18.60
Make before Break - 1 BCLF01G 104703 20.25
Make before Break 1 - BCLF10G 104702 20.25
Side (Left or Right) 1 1 BCLL11 104707 61.45
2 - BCLL20 104706 61.45
Side, combinations of 1 1 BRLL11 104705 61.45
more than 2 blocks 2 - BRLL20 104704 61.45
MAXIMUM NUMBER OF AUXILIARY CONTACT BLOCKS PER EACH CONTACTOR
FOR USE WITH MAXIMUM NUMBER OF ARRANGEMENT OF AUX.
AUX. CONTACT BLOCKS CONTACT BLOCKS
100-500 HP Contactors (CK75, CK08, CK09, 8 2 Side-Mount on each side
CK95, CK10, CK11, CK12)
MOUNTING CONTACTS CAT ORDER PRICE $
NO NC REF CODE excl.GST
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
146
JS Contactors For Capacitor Switching AC
7.5 13 1 1 CSCN12A311• 110907 110909 265.00
10 17 1 1 CSCN16A311• 110922 110924 306.90
12.5 21 1 - CSCN20A310• 110932 110934 348.50
15 26 1 - CSCN25A310• 110952 110954 378.20
20 31 1 - CSCN30A310• 247247 247270 611.20
25 47 1 - CSCN45A310• 247244 247272 938.00
35 57 1 - CSCN55A310• 247239 247209 1190.60
45 73 1 - CSCN70A310• 247234 247276 1370.20
VOLTAGE SELECTION
DESCRIPTION CAT 24V 110V 230V 415V PRICE $
REF ORDER CODES excl. GST
JY Thermister Relay
ThermisterRelayAC RS01N• 124373 212776 124375 382.50
JY Star Delta Starter Timer Relay (110 / 230 / 440V AC)
6 - 60sec (1 changeover contact) 24-230V NMETV 124908 316.10
1 - 60sec (1 changeover contact) 380-440V NMETV t 124911 434.30
Common Accessories
JJ Transient Voltage Suppressor Block
For suppression of disturbances in electronic circuits due to the coil transient voltage occurring on opening of the
contactor. Limits high voltage transients that may be produced when coil is de-energised.
CONTROL VOLTAGE FOR USE WITH CAT ORDER PRICE $
REF CODE excl. GST
AC 24V...48V AC CK75...CL08 BSLR3G 104716 81.35
50V...127V AC BSLR3K 104717 81.35
130V...240V AC BSLR3R 104718 81.35
AC 24V AC CK85...CK13 K/RC-24 104760 66.70
260V AC K/RC-48/260 104761 65.00
415V AC K/RC-380/415 104762 65.00
Directly connected parallel to the coil terminals A1-A2
JQ Mechanical Interlock
MOUNTING FOR USE WITH
Horizontal CK07B...CK12... BEKH 104763 194.55
Vertical CK07B...CK95... BEKVS 133907 703.80
CK10C...CK12B... BEKVA 104784 592.20
CK13... BEKV 104764 1055.00
DESCRIPTION CAT ORDER PRICE $
REF CODE excl. GST
kVAR AUXILIARY CAT ORDER CODE PRICE $
230V 415V N/O N/C REF 230V 415V excl. GST
CONTROL &
AUTOMATION
147
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
CA GPS1BS - Standard Breaking Capacity Rocker
RATED POWER THERMAL INSTANTANEOUS RATED ULTIMATE CAT ORDER PRICE $
3 PHASE MOTORS CURRENT SHORT-CIRCUIT SHORT-CIRCUIT REF CODE excl. GST
AT 400VAC PN SETTING RANGE RELEASE BREAKING
CAPACITY AT 400V
kW AMPS AMPS Icu kA
0.02 0.1 - 0.16 2.1 100 GPS1BSAA 101211 205.95
0.06 0.16 - 0.25 3.3 100 GPS1BSAB 101212 205.95
0.09 0.25 - 0.4 5.2 100 GPS1BSAC 101213 205.95
0.12/0.18 0.4 - 0.63 8.2 100 GPS1BSAD 101214 214.00
0.25 0.63 - 1 13 100 GPS1BSAE 101215 214.00
0.37/0.55 1 - 1.6 20.8 100 GPS1BSAF 101216 214.00
0.75 1.6 - 2.5 32.5 100 GPS1BSAG 101217 214.00
1.5 2.5 - 4 52 100 GPS1BSAH 101218 214.00
2.2 4 - 6.3 81.9 100 GPS1BSAJ 101219 214.00
3.0/4.0 6.3 - 10 130 100 GPS1BSAK 101220 256.20
5.5 9 - 13 169 50 GPS1BSAL 101221 262.85
7.5 11-16 208 25 GPS1BSAM 101222 272.85
10 14 - 20 260 25 GPS1BSAN 101223 330.35
11 19 - 25 325 25 GPS1BSAP 101224 346.35
15 24 - 32 416 25 GPS1BSAR 101225 374.40
Din rail mounting
CA GPS1BH - High Breaking Capacity Rotary
0.02 0.1 - 0.16 2.1 100 GPS1BHAA 101234 242.80
0.06 0.16 - 0.25 3.3 100 GPS1BHAB 101235 238.75
0.09 0.25 - 0.4 5.2 100 GPS1BHAC 101236 238.75
0.12/0.18 0.4 - 0.63 8.2 100 GPS1BHAD 101237 249.45
0.25 0.63 - 1 13 100 GPSB1HAE 101238 249.45
0.37/0.55 1 - 1.6 20.8 100 GPS1BHAF 101239 249.45
0.75 1.6 - 2.5 32.5 100 GPS1BHAG 101240 249.45
1.5 2.5 - 4 52 100 GPS1BHAH 101241 249.45
2.2 4 - 6.3 81.9 100 GPS1BHAJ 101242 249.45
3.0/4.0 6.3 - 10 130 100 GPS1BHAK 101243 290.20
5.5 9 - 13 169 100 GPS1BHAL 101244 298.25
7.5 11-16 208 50 GPS1BHAM 101245 304.95
10 14 - 20 260 50 GPS1BHAN 101246 369.10
11 19 - 25 325 50 GPS1BHAP 101247 397.20
15 24 - 32 416 50 GPS1BHAR 101248 397.20
Din rail mounting
CC GPS2BH - High Breaking Capacity Rotary
3.0/4.0 6.3 - 10 130 100 GPS2BHAK 101249 481.40
5.5 9 - 13 169 50 GPS2BHAL 107120 481.40
7.5 11 -16 208 50 GPS2BHAM 101250 481.40
10 14 - 20 260 50 GPS2BHAN 101251 481.40
11 19 - 25 325 50 GPS2BHAP 101252 481.40
15 24 - 32 416 50 GPS2BHAR 101253 580.35
18.5 28 - 40 520 50 GPS2BHAS 101254 645.90
22 35 - 50 650 50 GPS2BHAT 101255 748.80
30 45 - 63 819 50 GPS2BHAU 101256 879.85
Din rail or direct screw mounting
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
148
CI Auxiliary Contact Blocks GPS1 & GPS2
The N/C contact opens in the ON position and closes in the OFF or TRIPPED position.
The N/O contact closes in the ON position and opens in the OFF or TRIPPED position.
DESCRIPTION TYPE CODE No ORDER PRICE $
CODE excl. GST
Front Mount 1NO GPAC10FBA 101303 31.60
(Maximum 2 auxiliary contact blocks 1NC GPAC01FBA 101304 31.60
per manual motor starter)
Side Mount Left 1NO+1NC GPAC11LLA 101305 36.45
Two contacts 2NO GPAC20LLA 101306 36.45
2NC GPAC02LLA 101307 36.45
Side Mount Right 1NO+1NC GPAC11LRA 101308 36.45
Two contacts 2NO GPAC20LRA 101309 36.45
2NC GPAC02LRA 101310 36.45
CI Alarm Contact Block GPS1 & GPS2
The N/C contact is closed in the ON and OFF position and opens in the TRIPPED position.
The N/O contact is open in the ON and OFF position and closes in the TRIPPED position.
Front Mount 1NO GPAL10FRA 101311 33.05
Single contact 1NC GPAL01FRA 101312 33.05
CI Auxiliary/Alarm Contact Block GPS1 & GPS2
Side Mount left 1NO (Alarm)+1NO (Aux.) GPAD1010LLA 101313 54.50
(front alarm contact block can 1NO (Alarm)+1NC (Aux.) GPAD1001LLA 101314 54.50
be used at the same time) 1NC (Alarm)+1NO (Aux.) GPAD0110LLA 101315 54.50
Two contacts 1NC (Alarm)+1NC (Aux.) GPAD0101LLA 101316 54.50
CI Short-circuit Alarm Contact Block GPS1 & GPS2
Side Mount Left 1NO+1NC GPAE11LLA 101317 68.85
Two contacts
(Mechanical indication marking)
CONTROL &
AUTOMATION
149
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
CI Shunt Trip Device GPS1 & GPS2
DESCRIPTION COIL VOLTAGE CAT ORDER PRICE $
REF CODE excl. GST
Side Mount Right 24V 50/60Hz GPASLRAA1 101318 109.70
(Can not be used together with 110/127V 50Hz / 120V 60Hz GPASLRAAJ 101321 109.70
the undervoltage trip device) 230V 50Hz / 240V 60Hz GPASLRAAN 101323 109.70
415/440V 50Hz / 460/480V 60Hz GPASLRAAW 101326 109.70
24 to 60VDC GPASLRADD 101328 109.70
110 to 240VDC GPASLRADJ 101329 109.70
CI Under Voltage Trip Device GPS1 & GPS2
Side Mount Right 24V 50Hz GPAULRAAD 101330 97.60
(Can not be used together with 110/127V 50Hz / 120V 60Hz GPAULRAAJ 101334 97.60
the shunt trip device) 230V 50Hz / 240V 60Hz GPAULRAAN 101336 97.60
415/440V 50Hz / 460/480V 60Hz GPAULRAAW 101339 97.60
CI Under Voltage Trip Device (Rotary Type Only) GPS1*H & GPS2
Side Mount Right 24V 50Hz GPAU20LCAAD 101352 189.80
(Can not be used together with 110/127V 50Hz / 120V 60Hz GPAU20LCAAJ 101356 189.80
the shunt trip device) 230V 50Hz / 240V 60Hz GPAU20LCAAN 101358 189.80
415/440V 50Hz / 460/480V 60Hz GPAU20LCAAW 101361 189.80
CI Under Voltage Trip Device (Rocker Type Only) GPS1*S
Side Mount Right 24V 50Hz GPAU20LTAAD 101341 160.50
With 2NO Early Make 110/127V 50Hz / 120V 60Hz GPAU20LTAAJ 101345 160.50
Auxiliary Contacts 230V 50Hz / 240V 60Hz GPAU20LTAAN 101347 160.50
(Can not be used together with 415/440V 50Hz / 460/480V 60Hz GPAU20LTAAW 101350 160.50
the shunt trip device)
CK Terminal Protector GPS2
Protection against accidental For use with GPS2 *H GPAPTP2A 107182 15.10
finger touch (IP20)
CK External Handle Operator (Rotary Type Only)
DESCRIPTION FOR USE WITH TYPE
CK Enclosures for (Rocker Type Only) GPS 1*S
Surface Mounting IP55 GPES55A 101366 55.80
Flush Mounting IP55 GPEF55A 101368 55.80
Padlocking Device
For three padlocks with max. 8mm shackle diameter GPEPA 101370 31.80
(Not to be used with emergency stop handle)
Emergency Mushroom Push-button
With impulse functions GPEPMA 101372 55.55
Self latching, unlatching by turning GPEPLA 101373 65.15
Self latching, unlatching with a key GPEPKA 101374 151.55
Used for distance mounting GPS1*H... Standard (Black) GPA1HAB 101363 152.25
on a panel GPS1*H... Emergency (Red/Yellow) GPA1HAR 101364 152.25
GPS2*H... Standard (Black) GPA2HAB 101502 152.25
GPS2*H... Emergency (Red/Yellow) GPA2HAR 101503 152.25
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
150
CM Busbar System
DESCRIPTION FOR USE WITH CONNECTION CAT ORDER PRICE $
TYPE AUX REF CODE excl. GST
3-Phase Feed-in Terminals
Main Feeding Terminal GPS1 Terminal Capacity: 25mm2 GPB1FA 107186 87.20
Upper Connection GPS2 Terminal Capacity: 50mm2 GPB2FA 107187 87.20
Main Busbar for 2 GPS1 Front Pin GPB1B02A 101390 43.75
Modular Spacing 45mm for 3 GPS1 Front Pin GPB1B03A 101391 59.50
for 4 GPS1 Front Pin GPB1B04A 101392 70.65
for 5 GPS1 Front Pin GPB1B05A 101393 75.40
Modular Spacing 54mm for 2 GPS1 9mm Side Pin GPB1B12A 101394 64.65
for 3 GPS1 9mm Side Pin GPB1B13A 101395 74.75
for 4 GPS1 9mm Side Pin GPB1B14A 101396 89.35
for 5 GPS1 9mm Side Pin GPB1B15A 101397 106.15
Modular Spacing 63mm for 2 GPS1 18mm Side Fork GPB1B22A 101398 72.25
or 2 x 9mm Side
for 4 GPS1 18mm Side Fork GPB1B24A 101399 81.55
or 2 x 9mm Side
Modular Spacing 55mm for 2 GPS2 Front Pin GPB2BO2A 101400 65.05
for 3 GPS2 Front Pin GPB2BO3A 101401 73.95
for 4 GPS2 Front Pin GPB2BO4A 101402 86.05
Modular Spacing 64mm for 2 GPS2 9mm Side Pin GPB2B12A 101403 97.85
for 3 GPS2 9mm Side Pin GPB2B13A 101404 96.65
for 4 GPS2 9mm Side Pin GPB2B14A 101405 100.25
Modular Spacing 73mm for 2 GPS2 18mm Side Pin GPB2B22A 101406 70.15
or 2 x 9mm Side
for 4 GPS2 18mm Side Pin GPB2B24A 101407 94.25
or 2 x 9mm Side
Busbar Cover GPS1 - GPB1GA 101408 18.75
Touch guard for non used space
GPS2 - GPB2GA 101409 12.35
CONTROL &
AUTOMATION
151
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
=+ +
Contactor link module base platefuseless starter
CM Link Modules
For mechanical and electrical connection between contactors and manual motor starters
FOR USE WITH AC/DC FRAME CAT ORDER PRICE $
SIZE REF CODE excl. GST
MC0...MC1/MC2 AC/DC GPS1 GPF1LMCBA 101410 17.75
CL00A..., CL01A..., CL02A AC GPS1 GPF1L02AA 101411 20.15
CL25A.. AC GPS1 GPF1L25AA 101413 20.15
CL03A..., CL04A AC GPS1 GPF1L04AA 107165 20.15
CL00D..., CL01D..., CL02D DC GPS1 GPF1L02DA 101412 22.45
CL25D.. DC GPS1 GPF1L25DA 101414 19.55
CL03D.., CL04D DC GPS1 GPF1L04DA 107166 21.95
CL03A.., CL04A.. AC GPS2 GPF2L04AA 107190 23.45
CL45A.. AC GPS2 GPF2L45AA 101415 38.15
CL06A.., CL07A.. AC GPS2 GPF2L07AA 101417 42.85
CL03D.., CL04D.. DC GPS2 GPF2L04DA 107191 47.35
CL45D DC GPS2 GPF2L45DA 101416 43.05
CO Base Plates
Base Plates CL00..., CL01..., CL02.. CL25 AC/DC GPS1 GPF1B1A 101418 41.45
Plastic plates for mounting the
CL03..., CL04 AC/DC GPS1 GPF1B4A 107163 41.45
fuseless starter in panels or on
CL03.., CL04... and CL 45 AC/DC GPS2 GPF2B2A 101419 60.85
35mm DIN rail CL06.., CL07... AC/DC GPS2 GPF2B3A 101420 63.45
Link Connector
For two base plates for reversing applications GPF1CBA 101427 15.15
fuseless starter contactor link module base plate
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
152
CS Contactor Cover
Clips on the front of contactor to allow a clear identification of the terminal numbering (as contactor is upside down)
FOR USE WITH
CL00.., CL01.. and CL02 with Built-in 1NO Auxiliary Contact GPF10C02 107099 5.45
CL00.., CL01.. and CL02 with Built-in 1NC Auxiliary Contact GPF01C02 107100 5.45
CL25 GPF00C25 107101 5.75
CL03.., CL04 with Built-in 1NO Auxiliary Contact GPF10C04 107103 7.15
CL03.., CL04 with Built-in 1NC Auxiliary Contact GPF01C04 107105 6.65
CL45.. GPF00C45 107106 7.75
CL06.., CL07.. GPF00C08 107107 8.65
Rotary Switch 415V
CURRENT MOTOR LINK CONTACTOR kW OPTIONAL OPTIONAL
RANGE STARTER MODULE 1 N/O BASE BASE PLATE BUSBAR PLATE
1.0 - 1.6A 101239 101411 109169 0.37 / 0.55 101418 107152
1.6 - 2.5A 101240 101411 109169 0.75 101418 107152
2.5 - 4.0A 101241 101411 109169 1.5 101418 107152
4.0 - 6.3A 101242 101411 109169 2.2 101418 107152
6.3 - 10A 101243 101411 109240 3.0 / 4.0 101418 107152
9 - 13A 101244 101411 109313 5.5 101418 107152
11 - 16A 101245 101411 109313 7.5 101418 107152
14 - 20A 101246 107165 109385 10 107163 107153
19 - 25A 101247 107165 109385 11 107163 107153
24 - 32A 101248 107165 109457 15 107163 107153
Rotary Switch 230V
1.0 - 1.6A 101239 101411 104054 0.37 / 0.55 101418 107152
1.6 - 2.5A 101240 101411 104054 0.75 101418 107152
2.5 - 4.0A 101241 101411 104054 1.5 101418 107152
4.0 - 6.3A 101242 101411 104054 2.2 101418 107152
6.3 - 10A 101243 101411 104084 3.0 / 4.0 101418 107152
9 - 13A 101244 101411 104114 5.5 101418 107152
11 - 16A 101245 101411 104114 7.5 101418 107152
14 - 20A 101246 107165 104144 10 107163 107153
19 - 25A 101247 107165 101144 11 107163 107153
24 - 32A 101248 107165 104174 15 107163 107153
Fuseless Starters - Reference Chart
CQ Busbar Adaptor Plates
DESCRIPTION WIDTH/LENGTH RATING FRAME CONTACTOR CAT ORDER PRICE $
(mm) (A) SIZE REF CODE excl. GST
For Manual Motor 45/182 32 GPS1 - PBF23ECBA 107142 103.25
Starter Mounted Alone 54/182 32 GPS2 - PBF23FCBA 107143 127.15
60mm Centre Line Spacing 54/182 63 GPS2 - PBF23FDBA 107145 104.75
For Fuseless Starter 45/182 32 GPS1 MC0/MC1/MC2 PBF23EBCA 107151 111.15
Applications 45/182 32 GPS1 CL00/01/02/25 PBF23EBDA 107152 120.65
60mm Centre Line 55/182+60* 32 GPS1 CL03/04 PBF23ECDA 107153 167.25
Spacing 55/182+60* 63 GPS2 CL04/45 PBF23FDEA 107155 130.95
63/182 63 GPS2 CL06/07 PBF23GDFA 107156 168.75
For Reversing Applications 45/182 - GPS1 MC0/MC1/MC2/CL00 PBF2AEAHA 107157 116.35
60mm Centre Line Spacing CL01/CL02/CL25
Base Without Contacts 55/182 - GPS2 CL03/CL04/CL45 PBF2AFAHA 107158 121.95
63/182 - GPS2 CL06/CL07 PBF2AGAHA 107159 127.45
*Using 60mm Extension Base
CONTROL &
AUTOMATION
153
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
UF Busbar Supports
DESCRIPTION CAT ORDER PRICE $
REF CODE excl. GST
Busbar Supports Set=2 (Left & Right) FBB3S 433458 57.80
Endplate Covers Set=2 FBB3E 433455 31.00
UF Connection Set
Connection Set 3 pole for conductors 1.5 to 70mm2 FBTF3L12 433456 87.00
1 pole for lateral bar, flexible bar or cable connection FBTS1L12 433468 72.80
Cu/Al 35-240mm for busbar section 5mm (Each)
1 pole for lateral bar, flexible bar or cable connection FBTS10L12 433474 101.60
Cu/Al 35-300mm for busbar section 10mm (Each)
UF Accessories
Adjustable Busbar Cover 3P FBC13 433377 115.40
Filler for cover plate cut out of 64mm l = 1.2m FBF6 883970 27.00
Fuseless Starter
1 Busbar support
2 Busbars (not part of offering)
3 Connection set
5 Endplate cover
8 Busbar covers
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
154
JT 3 Pole DOL Starter (Start - Stop) IP65
3 PHASE OVERLOAD RANGE OVERLOAD STARTER
415V-AC3 MIN MAX CAT ORDER PRICE $ ORDER ORDER PRICE $
kW HP AMPS AMPS REF CODE excl. GST CODE CODE excl. GST
230V 415V
0.55 0.75 9 1.3 1.9 RT1H 113705 154.55 LG0006P1BN LG0006P1BW 229.00
0.75 1 9 1.8 2.7 RT1J 113706 154.55 LG0006P1BN LG0006P1BW 229.00
1.5 2 9 2.5 4 RT1K 113707 154.55 LG0006P1BN LG0006P1BW 229.00
2.2 3 9 4 6.3 RT1L 113708 154.55 LG0006P1BN LG0006P1BW 229.00
4 5.5 9 8 12 RT1N 113710 158.55 LG0006P1BN LG0006P1BW 229.00
5.5 7.5 12 10 16 RT1P 113711 163.20 LG0106P1BN LG0106P1BW 255.00
7.5 10 18 14.5 18 RT1S 113712 169.85 LG0206P1BN LG0206P1BW 304.90
11 15 25 21 26 RT1U 113714 179.95 LG2506P1BN LG2506P1BW 426.50
15 20 32 25 32 RT1V 113715 249.45 LG0406P1BN LG0406P1BW 529.50
Direct-on-Line Starters Start-Stop in larger enclosures are available on request
JT 3 Pole DOL Starter (Reset Only) IP65
0.55 0.75 9 1.3 1.9 RT1H 113705 154.55 LG0006R1BN LG0006R1BW 229.00
0.75 1 9 1.8 2.7 RT1J 113706 154.55 LG0006R1BN LG0006R1BW 229.00
1.5 2 9 2.5 4 RT1K 113707 154.55 LG0006R1BN LG0006R1BW 229.00
2.2 3 9 4 6.3 RT1L 113708 154.55 LG0006R1BN LG0006R1BW 229.00
4 5.5 9 8 12 RT1N 113710 158.55 LG0006R1BN LG0006R1BW 229.00
5.5 7.5 12 10 16 RT1P 113711 163.20 LG0106R1BN LG0106R1BW 255.00
7.5 10 18 14.5 18 RT1S 113712 169.85 LG0206R1BN LG0206R1BW 304.90
11 15 25 21 26 RT1U 113714 179.95 LG2506R1BN LG2506R1BW 400.80
15 20 32 25 32 RT1V 113715 249.45 LG0406R1BN LG0406R1BW 462.10
Direct-on-Line Starters Start-Stop in larger enclosures are available on request
JT Empty Boxes (Polycarbonate)
FOR USE WITH PUSH-BUTTONS IP RATING CAT ORDER PRICE $
REF CODE excl. GST
DOL up to 7.5 kW Start/Stop + Reset IP65 LG0006P1B0 200004 136.50
DOL up to 11 kW Start/Stop + Reset IP65 LG2506P1B0 101095 100.30
DOL up to 15 kW Start/Stop + Reset IP65 LG0406P1B0 116656 140.90
DOL up to 7.5 kW Reset Only IP65 LG0006R1B0 116652 114.10
DOL up to 11 kW Reset Only IP65 LG2506R1B0 133611 86.40
DOL up to 15 kW Reset Only IP65 LG0406R1B0 133265 82.30
DOL Start Contact Terminal - BMLF 104800 30.60
JK 3 Pole Economy DOL Starter (Complete with Overload) IP65
3 PHASE OVERLOAD ORDER ORDER PRICE $
415V-AC3 RANGE CODE CODE excl. GST
kW HP 230V 415V
4 5.5 1.25-2.0A 101932 101933 229.00
4 5.5 1.6-2.5A 101934 101935 229.00
4 5.5 2.5-4.0 101936 101937 229.00
4 5.5 4.0-6.0 101938 101939 229.00
4 5.5 5.5-8.0A 101940 101941 229.00
4 5.5 7-10 101952 101953 229.00
5.5 7.5 9-13 101954 101955 229.00
7.5 10 12-18 101956 101957 229.00
11 15 17-25 101958 101959 995.00
CONTROL &
AUTOMATION
155
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
JX Enclosed Reversing Starters IP66
3 PHASE OVERLOAD RANGE OVERLOAD STARTER
415V-AC3 MIN MAX CAT ORDER PRICE $ ORDER ORDER PRICE $
kW HP AMPS AMPS REF CODE excl. GST CODE CODE excl. GST
230V 415V
0.37 0.5 1 1.5 RT1G 113704 154.55 CLREV4EN CLREV4EW 985.00
0.55 0.75 1.3 1.9 RT1H 113705 154.55 CLREV4EN CLREV4EW 985.00
0.75 1 1.8 2.7 RT1J 113706 154.55 CLREV4EN CLREV4EW 985.00
1.1 1.5 2.4 4 RT1K 113707 154.55 CLREV4EN CLREV4EW 985.00
1.5 2 2.4 4 RT1K 113707 154.55 CLREV4EN CLREV4EW 985.00
2.2 3 4 6.3 RT1L 113708 154.55 CLREV4EN CLREV4EW 985.00
4 5.5 8 12 RT1N 113710 158.55 CLREV4EN CLREV4EW 985.00
0.37 - 18.5kW enclosure size 300 x 185 x 175
22 - 45kW enclosure size 300 x 300 x 175
MC0...MC1/MC2 AC/DC WKMIU 101421 20.45
CL00.., CL01.., CL02.. AC/DC WKLI02P 101422 33.15
CL25.. AC/DC WKLI25P 101423 34.45
CL03.., CL04... AC/DC WKLI04P 101424 155.95
CL45.. AC/DC WKLI45P 101425 163.65
CL06A.., CL07A.. AC WKLI07P 101426 79.05
CO Wiring Kits For Reversing Starters
JX Enclosed Star Delta Starters IP66
5.5 7.5 11 5.5 8.5 RT1M 113709 154.55 SD5.5kWEN SD5.5kWEW 1621.20
7.5 10 14 8 12 RT1N 113710 158.55 SD7.5kWEN SD7.5kWEW 1670.00
11 15 21 10 16 RT1P 113711 163.20 SD11kWEN SD11kWEW 1710.00
15 20 28 14.5 18 RT1S 113712 169.85 SD15kWEN SD15kWEW 1825.00
18.5 25 35 17.5 22 RT1T 113713 179.95 SD18.5kWEN SD18.5kWEW 1825.00
22 30 40 21 26 RT1U 113714 179.95 SD22kWEN SD22kWEW 1990.00
30 40 55 30 40 RT1W 113716 249.45 SD30kWEN SD30kWEW 2275.00
Order Thermal Overloads Separately (set at 0.58 x the Motor Current)
5.5 - 30kW Enclosure size 300 x 185 x 175
37* - 75kW Enclosure size 465 x 350 x 200
* other sizes available on request. Sizes 37kW to 75kW
JX Open Type Star Delta Starters
5.5 7.5 11 5.5 8.5 RT1M 113709 154.55 SD5.5kWON SD5.5kWOW 1026.90
7.5 10 14 8 12 RT1N 113710 158.55 SD7.5kWON SD7.5kWOW 1070.30
11 15 21 10 16 RT1P 113711 163.20 SD11kWON SD11kWOW 1110.00
15 20 28 14.5 18 RT1S 113712 169.85 SD15kWON SD15kWOW 1230.00
18.5 25 35 17.5 22 RT1T 113713 179.95 SD18.5kWON SD18.5kWOW 1230.00
22 30 40 21 26 RT1U 113714 179.95 SD22kWON SD22kWOW 1430.00
30 40 55 30 40 RT1W 113716 249.45 SD30kWON SD30kWOW 1665.00
Order Thermal Overloads Separately (set at 0.58 x the Motor Current)
Star deltas up to 30kW fit RT1 Overload Only
* other sizes available on request. Sizes 37kW to 75kW
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
156
OW Digital Temperature Controllers (PID or on/off) IP66
Temperature Controllers use PID (proportional + intergral + derivatives) to create tighter temperature control achieving a more
constant temperature.
CASE SIZE VOLTAGE SENSOR INPUT (PV) PROGRAMMABLE ORDER PRICE $
OUTPUTS & ALARMS CODE excl. GST
24 x 48mm 100-240V AC Selectable TC & PT100 SSd+Relay 320.000 897.50
100-240V AC Selectable TC & PT100 SSd+Relay 330.000.000 705.80
12-24V AC/DC Selectable TC & PT100 SSd+Relay 330.000.030 705.80
100-240V AC Selectable TC & PT100 Relay x 2 331.100.000 783.60
100-240V AC Selectable TC & PT100 SSd x2 332.200.000 845.20
48 x 48mm 100-240V AC Selectable TC & PT100 SSd+Relay 940.000.000 845.20
Comms cards optional
ow Digital Temperature Controllers (PID or on/off) IP66
•Ramp-soak-rampstemperatureuptoapre-definedtemperatureandholdsitforaperiodoftime.
•Profiling-allowstemperaturerampinganddeclining.
•Heating/cooling-whenbothheatingandcoolingisrequiredatthesametime.
SIZE VOLTAGE SENSOR INPUT (PV) PROGRAMMABLE ORDER PRICE $
OUTPUTS & ALARMS CODE excl. GST
48 x 48mm 100-240V AC Selectable TC & PT100 SSd & Relay (x2) 9500.1PA.000 1151.30
100-240V AC 4-20mA 4-20mA+SSd+Relay 95B2.1PB.000 1405.70
Comms cards optional
OX Digital Thermostats (on-off) IP65
TEMP RANGE VOLTAGE SENSOR TYPE OUTPUTS ORDER PRICE $
CODE excl. GST
DEFROST FUNCTION
-50° to 110° C 12V AC/DC NTC Thermistor 1 x 8A Relay EDT1411-NTC-12 215.00
24V AC/DC NTC Thermistor 1 x 8A Relay EDT1411-NTC-24 215.00
230V AC NTC Thermistor 1 x 8A Relay EDT1411-NTC-230 215.00
STANDARD FUNCTION
-100° to 600° C 9-30V DC PT100 Relay (8A) ETC1311-R-SM 275.00
230V AC PT100 Relay (8A) ETC1311-R-230 238.00
9-30V DC PT100 Relay (16A) ETC1311-R-SM-P 295.00
230V AC PT100 Relay (16A) ETC1311-R-230-P 255.00
Thermister & Thermocouple types also available
Thermostats do not have PID and control within a temperature range, by switching on and off to heat/cool
OY Optional Accessories
TYPE ACCESSORY COMPATIBLE ORDER PRICE $
CODE excl. GST
RS232 Plug-in communications board All PID controllers 3C0.000.200 284.70
RS485* Plug-in communications board All PID controllers 3C0.000.400 284.70
CALgrafix process monitoring & setup software 100.3GB.000 1337.80
RS485 is required when there is more than 1 controller
Thermostats do not have PID and control within a temperature range, by switching on and off to heat/cool
CONTROL &
AUTOMATION
157
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
OY Digital / Temperature Indicators (Display Output) IP65
These units are for display only. They have no other controlling function
TEMP RANGE VOLTAGE INPUT TYPES ORDER PRICE $
CODE excl. GST
-1999° to 4000° C 230V AC Analogue (V) or (mA) EI141-230 316.60
9-30VDC Analogue (V) or (mA) EI141-SM 370.60
-50° to 110° C 12V AC/DC NTCH Thermistor EI1410-NTCH-12 174.30
24V AC/DC NTCH Thermistor EI1410-NTCH-24 174.30
230V AC NTCH Thermistor EI1410-NTCH-230 174.30
OY Timers (8A Relay Output) IP65
Timers count down or up and activate a relay
INPUT MODES VOLTAGE OUTPUT MODES ORDER PRICE $
CODE excl. GST
Start / Stop Extremal 12V AC/DC Delay & Pulse ETM1411-12 284.70
24V AC/DC Delay & Pulse ETM1411-24 284.70
230V AC Delay & Pulse ETM1411-230 284.70
OY Thermisters (Silicon Cable Type)
CASING SENSOR TYPE ENVIRONMENT ORDER PRICE $
CODE excl. GST
Stainless shell NTC AIR E-NTC-APS-1.5S 69.80
NTC LIQUID E-NTC-LPS-1.5S 69.80
NTCH AIR E-NTCH-APS-1.5S 69.80
NTCH LIQUID E-NTCH-LPS-1.5S 69.80
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
158
The only partner you need for plant and machine control
GE INTELLIGENT PLATFORMS
CONTROL &
AUTOMATION
159
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
OUA Starter Kits (Includes Programming Software and Cable)
DESCRIPTION POWER INPUT OUTPUT KEYPAD/LCD ORDER PRICE $
CODE excl. GST
DESCRIPTION POWER INPUT OUTPUT BUS ORDER PRICE $
CODE excl. GST
Durus Controller Starter Kit, 10 Point 85-264VAC 6 4 YES IC210TBX010 427.50
Durus Controller Starter Kit, 10 Point 24VDC 6* 4 YES IC210TBX012 415.80
Durus Controller Starter Kit, 20 Point 85-264VAC 12 8 YES IC210TBX020 544.60
*2 Analog inputs can be configured as DC Discrete inputs
Mixed I/O 24VDC 16 8 IC200MDD845 485.00
Output Module 8 IC200MDL930 220.00
Output Module 16 IC200MDL940 465.00
Remote I/O Slave Profibus-DP IC200PBI001 945.00
Power Supply 120/240VAC IC200PWR102 165.00
Micro14 PLC 120/240VAC 8 6 IC200UDR001 495.00
Micro28 PLC 24VDC 16 12 IC200UDR010 835.00
Analog Exp Module 24VDC 4 IC200UEX624 485.00
Other models available, please enquire
OUA Durus Controllers
Durus Controller 85-264VAC 6 4 YES IC210DAR010 497.80
Durus Controller 85-264VAC 12 8 YES IC210DAR020 682.20
Durus Controller 24VDC 6 4 YES IC210DDR012 442.50
Durus Controller 24VDC 12 8 YES IC210DDR024 626.90
Durus Controller 85-264VAC 12 8 YES IC210NAR020 442.50
Other models available, please enquire
OUA Durus Accessories
OUA Durus Expansion Modules
Programming Cable, PC to Durus Controller IC210CBL001 110.70
Durus Memory Pack Portable Flash Device IC210TMP001 55.40
Durus Controller Programming Software IC646DUR001 99.60
Other models available, please enquire
Analogue Expansion Unit 12/24VDC 4 IC210EA1004 474.10
Discrete Expansion Unit 24VDC 4 4 IC210EDR008 298.50
Discrete Expansion Unit 85-264VDC 4 4 IC210EAR008 351.20
Versamax Battery for Micro 23 and 28 IC200ACC403 $43.50
Versamax Micro RS232 Programming Cable IC200CBL500 $55.00
Versamax Series I/O Carrier Box Style IC200CHS002 $159.00
Other models available, please enquire
OUB Versamax Controllers
OUB Versamax Accessories
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
160
OUC 90-30 Controllers
OUE Rx3i Controllers
OUE Rx3i Accessories
OUC 90-30 Accessories
DESCRIPTION POWER INPUT OUTPUT BUS ORDER PRICE $
CODE excl. GST
Baseplate 10 slot IC693CHS391 $484.00
Baseplate Expansion 10 slot IC693CHS392 $572.20
Power Supply 120/240 VAC OR 125VDC 24VDC IC693PWR321 $442.90
Power Supply 120/240 VAC OR 125VDC 24VDC HI-CAPACITY IC693PWR330 $630.60
CPU 240KB Memory IC693CPU360 $2,437.00
CPU 240KB Memory ETHERNET + WEB IC693CPU374 $5,449.00
Analog Input 4 IC693ALG221 $992.50
Analog Input 16 IC693ALG223 $1,898.00
Analog Output 8 IC693ALG392 $1,898.00
Digital Input 16 IC693MDL645 $406.50
Digital Output 16 IC693MDL340 $689.50
Digital Output 16 IC693MDL940 $499.50
Ethernet Module TCP/IP IC693CMM321 $2,167.00
High Speed Counter 4 IC693APU300 $1,169.00
Temperature Control 8 T/C I/P 8 24VDC O/P IC693TCM302 $3,797.00
Mini-Converter Kit & Cable (R-S232/RS-485) IC690ACC901 $443.40
Rack Expansion Cable IC693CBL300 $184.50
Blank Filler Module IC693ACC310 $77.70
Chassis 12 Slot IC695CHS012 $971.25
Chassis 16 Slot IC695CHS016 $1,128.00
Power Supply 230VAC 3.3 5&24VDC IC695PSA040 $925.00
Power Supply 100-240VAC OR 125VDC IC695PSA140 $1,046.00
Power Supply 24VDC 3.3, 5&24VDC IC695PSD040 $624.80
Power Supply 24VDC 24VDC IC695PSD140 $735.00
Power Supply 24VDC 24VDC IC694PWR331 $429.50
CPU Ethernet, Serial & USB Port IC695CPE305 $5,175.00
CPU 20MB Memory IC695CPU315 $7,610.00
Analog Input 12 IC695ALG112 $4,356.00
Analog Input 16 IC695ALG626 $2,852.00
Analog Output 8 IC695ALG728 $2,655.00
Analog Output 8 IC694ALG392 $1,839.00
Digital Input 16 IC694MDL645 $402.00
Digital Input 32 IC694MDL660 $588.00
Digital Output 16 IC694MDL741 $436.00
Digital Output 32 IC694MDL754 $832.00
Ethernet Switch TCP/IP IC695ETM001 $2,270.00
Local Expansion Module IC695LRE001 $165.90
NIU Supports 2 Serial Comms Ports IC695NIU001 $2,447.00
Profibus Master PROFIBUS IC695PBM300 $1,959.00
External High Capacity Battery Pack IC693ACC302 $290.00
Blank Filler Module IC694ACC310 $78.75
Box Style High Density Terminal Block IC694TBB032 $88.50
Box Style High Density Terminal Block Extended Depth IC694TBB132 $95.90
Energy Pack IC695ACC400 $232.90
CPU Lithium Battery and Spare Door IC698ACC701 $120.75
Other models available, please enquire
CONTROL &
AUTOMATION
161
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
APM Motion Controller 1-Axis IC693APU301 $6961.50
APM Control Cable 1 Metre Long Sl Terminal Block To APM Motion Control IC800SLCAPM010 $602.00
Interface Cable 1 Metre Long Sl Series Amplifier To Terminal Block IC800SLCIV010 $918.00
Amplifier Terminal Block Sl Series IC800SLT001 $465.00
I/O Cable for DSM314 IC693CBL324 $225.00
Motion Controller 1-2 Axis Digital Servo Or 1-4 Axis Analog Servo IC694DSM314 $3,540.00
OUG QuickPanel View HMI
OUL Motion Controllers
OUK Procy Machine Edition Software
OUM Training Modules
DESCRIPTION POWER SIZE COLOUR FEATURES ORDER PRICE $
CODE excl. GST
QuickPanel View 24VDC 6” MONO BASIC IC754VSB06MTD 1618.20
QuickPanel View 24VDC 8” TFT INTERMEDIATE IC754VBI08CTD 4498.00
QuickPanel View 24VDC 12” TFT INTERMEDIATE IC754VSI12CTD 6906.00
Development Suite - Lite with USB Hardware License Key IC647MBL001 POA
Development Suite - Standard with USB Hardware License Key IC647MBS001 POA
Development Suite - Professional with USB Hardware License Key IC647MBP001 POA
PLC Maintenance with Proficy Logic Developer ME (Duration 3 Days) CBS-338 POA
Proficy Logic Developer PLC Machine Edition (Duration 4 Days) CBS-347 POA
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
162
OP U Series Standard Screw Terminal Block
OP Ground Earth Terminal Blocks
OP Terminal Block Fuse Single Level
OP U Series End Plates
OP Partition Plates
OP Separator Plates
WIRE SIZE ORDER PRICE $
(mm2) CODE excl. GST
WIRE SIZE ORDER PRICE $
(mm2) CODE excl. GST
USED ORDER PRICE $
WITH CODE excl. GST
2.5 CTS2.5UN 2.10
4 CTS4UN 2.40
6 CTS6U 2.60
10 CTS10U 3.30
16 CTS16U 5.80
25 CTS25U 6.10
25 CTS25UN 8.60
35 CTS35U 9.70
35 CTS35UN 11.40
50 CTS50U 36.00
95 CTS95U 60.00
Colour: grey
4 CGT4N 11.20
4 CGT4U 12.40
6 CGT6N 15.20
10 CGT10U 15.30
16 CGT16N 17.80
35 CGT35U 33.40
Colour: green/yellow
4 CSFL4U 10.40
4 (without fuse) CSFL4U/WF 10.60
Colour: grey
Other models available - please enquire
CTS2.5UN/2.5UE/4UN EP2.5/4UN 9.60
CTS6U/10U EP6/10U 10.80
CTS25U EP25U 1.90
CTS35U EP35U 2.40
Colour: grey
CTS2.5UN/2.5UE/4UN PP2.5/4UN 1.80
CTS6U/10U PP6/10U 2.30
CTS25U PP25U 2.90
CTS35U PP35U 3.20
Colour: grey
CTS2.5UN/2.5UE/4UN SP2.5/4UN 7.20
CTS6U/10U/16U SP16U 6.20
Colour: grey
CONTROL &
AUTOMATION
163
Order Codes in Bold: Stocked Items
Order Codes in Light: Subject to Availability
OP Terminal Blocks Disconnect & Test
OP End Plates for Disconnect & Test
OP End Clamps
OP Shorting Link Pre-assembled (10 Way)
OP Marking Tag (10 Way)
WIRE SIZE TYPE ORDER PRICE $
(mm2) CODE excl. GST
DESCRIPTION ORDER PRICE $
CODE excl. GST
4 Lever action CKT4U 8.70
6 Slide action CDTTU 15.20
6 Slide action/shorting link CDTTUSH 27.70
Colour: grey
4 EPCSFL4U 1.50
6 EPCDTTU 2.00
Colour: grey
End Clamp for Fixing Busbar CA202 4.30
End Clamp for Din 32/35 Rail CA702 2.10
2.5mm spacing CA721/10 8.00
4mm spacing CA722/10 8.00
K5 10 Blanks CA509/K5 7.20
K6 Vertical Print 1 to 10 CA509/K6V 8.40
Other models available - please enquire
