Packing List Envelopes

F1, FED1, NP1, NP2, NP3, NP4, NP5, NP6, NP9, NPZ

T1, T1-INV, T1-PL, T2, T3, T4, and Custom-Printed PLEs

Product Description 3M™ Packing List Envelopes are an oil-resistant and water-resistant polyethylene

envelope for packing slips, invoices, cards, and other shipping documents. This

packet has pre-sealed edges, is loaded from the back, and has a synthetic rubber

adhesive on the back that is covered by an easily removed paper liner. These

envelopes work well in situations where the shipping orders are generated in an

office area and later applied to the proper package in the shipping area.

Typical Physical

Properties

Technical Data November, 2006

Note: The following technical information and data should be considered representative

or typical only, and should not be used for specification purposes.

ASTM Test Method

Thickness:

Top Sheet: 2 mil D-3652

Total: 5 mil D-3652

Liner: 42#

Construction Backing Adhesive Liner Colors Standard Print

Polyethylene film Synthetic White or natural Clear Black letters on

rubber resin Kraft paper red background

Features • Back slit opening in standard offering.

• F – fully printed front, “PACKING LIST/

INVOICE ENCLOSED”.

• FED – no print, perforated.

• NP – no print.

• T – top printed, “PACKING LIST/

INVOICE ENCLOSED”.

• T1-INV – top printed, “INVOICE

ENCLOSED”.

• T1-PL – top printed, “PACKING LIST

ENCLOSED”.

• Z – zipper.

• Portable.

• Immediate adhesion.

• Consistent dimensions.

• Custom printing available.

• Holds papers securely to package.

• Protects papers from water and

oil splashes.

• Easy to apply to packages.

• No need for dispenser.

• Eliminates need to stock separate

inventories.

• Can serve as interim holder for

papers to be attached to shipping

container.

3M™Packing List Envelopes

F1, FED1, NP1 NP2, NP3, NP4, NP5, NP6, NP9, NPZ

T1, T1-INV, T1-PL, T2, T3, T4, and Custom-Printed PLEs

Temperature Range These envelopes will function well between -20°F (-29°C) and 140°F (60°C).

The application temperature should be 35°F (2°C) and above.

3M™ Packing List Envelopes F1, NP1, T1, T1-INV, T1-PL 41/2x 51/2in. 114 x 140 mm

3M™ Packing List Envelopes NP2, T2 41/2x 6 in. 114 x 152 mm

3M™ Packing List Envelopes NP3, T3 7 x 51/2in. 178 x 140 mm

3M™ Packing List Envelopes NP4, T4 51/2x 10 in. 140 x 254 mm

3M™ Packing List Envelope NP5 7 x 10 in. 178 x 254 mm

3M™ Packing List Envelope NP6 91/2x 12 in. 241 x 305 mm

3M™ Packing List Envelope NP9 7 x 6 in. 178 x 152 mm

3M™ Packing List Envelope FED1 (Perforated) 63/4x 103/4in. 172 x 273 mm

3M™ Packing List Envelope NPZ-L 81/2x 111/2in. 216 x 292 mm

3M™ Packing List Envelope NPZ-XL 10 x 121/2in. 254 x 316 mm

Custom printing available in all standard sizes.

Available Sizes

3M is a trademark of 3M Company.

Printed in U.S.A.

©3M 2006 70-0710-0238-3 (11/06)

Recycled Paper

40% pre-consumer

10% post-consumer

Storage Conditions Store in a cool, dry area, preferably at 65-75°F (18-24°C) and 30-50% relative

humidity in original carton. Avoid pressure from stacking.

Shelf Life Apply within one year after purchase.

Except where prohibited by law, 3M and seller will not be liable for any loss or damage arising from the

3M product, whether direct, indirect, special, incidental or consequential, regardless of the legal theory

asserted, including warranty, contract, negligence or strict liability.

Limitation of Liability

All statements, technical information and recommendations contained in this document are based upon

tests or experience that 3M believes are reliable. However, many factors beyond 3M’s control can affect

the use and performance of a 3M product in a particular application, including the conditions under

which the product is used and the time and environmental conditions in which the product is expected to

perform. Since these factors are uniquely within the user’s knowledge and control, it is essential that the

user evaluate the 3M product to determine whether it is fit for a particular purpose and suitable for the

user’s method of application.

Product Use

Unless stated otherwise in 3M’s product literature, packaging inserts or product packaging for individual

products, 3M warrants that each 3M product meets the applicable specifications at the time 3M ships the

product. Individual products may have additional or different warranties as stated on product literature,

package inserts or product packages. 3M MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED,

INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE OR ANY IMPLIED WARRANTY ARISING OUT OF A COURSE OF

DEALING, CUSTOM OR USAGE OF TRADE. User is responsible for determining whether the 3M product

is fit for a particular purpose and suitable for user’s application. If the 3M product is defective within the

warranty period, your exclusive remedy and 3M’s and seller’s sole obligation will be, at 3M’s option, to

replace the product or refund the purchase price.

Warranty and

Limited Remedy

3
