Russellstoll® Pin and Sleeve Power Connectors
MaxGard ® Interconnection Systems
WW
POLE WIRE
CONDUCTOR
PLACEMENT
VOLTAGE
60 HZ
CAT. NO.
STANDARD
BUSHING
I.D. †
CAT. NO.
STANDARD
BUSHING
I.D. †
23 277 DF1104FPØØØ 111⁄16"DS1104MPØØØ 111⁄16"
125 DF1107FPØØØ DS1107MPØØØ
23
480 DF1204FPØØØ
111⁄16"
DS1204MPØØØ
111⁄16"
250 DF1207FPØØØ DS1207MPØØØ
600 DF1214FPØØØ DS1214MPØØØ
208 DF1216FPØØØ DS1216MPØØØ
34
277/480 DF1304FPØØØ
113⁄16"
DS1304MPØØØ
113⁄16"125/250 DF1307FPØØØ DS1307MPØØØ
120/208 DF1316FPØØØ DS1316MPØØØ
34
3Ø 480 DF1404FPØØØ
113⁄16"
DS1404MPØØØ
113⁄16"
3Ø 250 DF1407FPØØØ DS1407MPØØØ
3Ø 600 DF1414FPØØØ DS1414MPØØØ
3Ø 208 DF1416FPØØØ DS1416MPØØØ
3Ø 440 DF1421FPØØØ DS1421MPØØØ
45
3ØY 277/480 DF1504FPØØØ
2"
DS1504MPØØØ
2"
3ØY 347/600 DF1514FPØØØ DS1514MPØØØ
3ØY 110/208 DF1516FPØØØ DS1516MPØØØ
3ØY 250/440 DF1521FPØØØ DS1521MPØØØ
100 Amp Reverse Service
111⁄8"
53⁄8"
** If receptacle is desired with a Straight Adapter instead of standard
Angle Adapter, substitute “S” for the “A” in the catalog number
of the Receptacle with Angle Adapter or Adapter and Box.
† Standard cable bushings shown; see page 34 for other sizes
available at no extra cost if specified on order.
†† Always furnished with screw collar. We recommend cup cap
with male plug; order catalog number DS1CC.
Maximum lug wire 0 AWG 19-strand or 1 AWG flexible,
cable entrance .386" diameter.
Receptacles furnished with flap cap also have screw thread
to accept male collar on plug.
Catalog numbers shown are for flap cap receptacles;
change “DF” to “DS” for ordering screw cap.
Boldface figures are for voltage assignment.
For different ratings, see page 40.
Outlet furnished at location “B” unless otherwise
specified. 2" NPT.
61⁄2"
10 1⁄8"
G
N
1
G
1
2
G
N
1
2
G
1
23
G
N
1
23
WControl contacts for plug/receptacles:
Use “K” where noted. Ex: DS1104MR00K
For Adapters, Junction Boxes and Accessories,
see pages 34–37.
Device Ratings and Polarizations
Maximum 600VAC or 250VDC
(For full polarization, see page 40)
Male Plug
††
Female Connector
B
D
A C
United States
Tel: 901.252.8000
800.816.7809
Fax: 901.252.1354
Technical Services
Tel: 888.862.3289
www.tnb.com
25
Russellstoll® Pin and Sleeve Power Connectors
MaxGard ® Interconnection Systems
33⁄8"
51⁄2"
21⁄2"
67⁄8"
10 1⁄8"
4"
111⁄2"
73⁄8"
101⁄8"
33⁄4"
10 5⁄8"
WW W W
CAT. NO. CAT. NO. CAT. NO. CAT. NO.
DS1104MRØEØ DS1104MRABØ DS1104MRAØØ DS1104MRØØØ
DS1107MRØEØ DS1107MRABØ DS1107MRAØØ DS1107MRØØØ
DS1204MRØEØ DS1204MRABØ DS1204MRAØØ DS1204MRØØØ
DS1207MRØEØ DS1207MRABØ DS1207MRAØØ DS1207MRØØØ
DS1214MRØEØ DS1214MRABØ DS1214MRAØØ DS1214MRØØØ
DS1216MRØEØ DS1216MRABØ DS1216MRAØØ DS1216MRØØØ
DS1304MRØEØ DS1304MRABØ DS1304MRAØØ DS1304MRØØØ
DS1307MRØEØ DS1307MRABØ DS1307MRAØØ DS1307MRØØØ
DS1316MRØEØ DS1316MRABØ DS1316MRAØØ DS1316MRØØØ
DS1404MRØEØ DS1404MRABØ DS1404MRAØØ DS1404MRØØØ
DS1407MRØEØ DS1407MRABØ DS1407MRAØØ DS1407MRØØØ
DS1414MRØEØ DS1414MRABØ DS1414MRAØØ DS1414MRØØØ
DS1416MRØEØ DS1416MRABØ DS1416MRAØØ DS1416MRØØØ
DS1421MRØEØ DS1421MRABØ DS1421MRAØØ DS1421MRØØØ
DS1504MRØEØ DS1504MRABØ DS1504MRAØØ DS1504MRØØØ
DS1514MRØEØ DS1514MRABØ DS1514MRAØØ DS1514MRØØØ
DS1516MRØEØ DS1516MRABØ DS1516MRAØØ DS1516MRØØØ
DS1521MRØEØ DS1521MRABØ DS1521MRAØØ DS1521MRØØØ
Male Inlet
††
Male Inlet with
Angle Enclosure
Male Inlet with
Angle Adapter** and
DJB3 Junction Box
Male Inlet with
Angle Adapter**
