![](asset-1.png)
Machined
Aluminum
Machined
Zinc-Plated Steel
WIRE MANAGEMENT
E1
Straight Male
N.P.T. Cord Dia. Machined
Hub Inches Form Colour Machined Zinc-Plated Stainless Nylon Nylon
Size (mm) Size Code Aluminum Steel Steel Gray Black
IP66*
SUITABILITY
UL Listed to Type 4, 4X, 12
and Type 13
STRAIGHT MALE CORD CONNECTORS
.06"-.13" Green — — — SHC1001CR —
(1.6-3.2)
.13"-.19" Orange SHC1002 — — SHC1002CR —
(3.2-4.7)
1/4 .19"-.25" F1 Red SHC1003 — SHC1003SS SHC1003CR —
(4.7-6.3)
.25"-.31" Black SHC1004 — SHC1004SS SHC1004CR —
(6.3-7.9)
.31"-.38" White SHC1005** — — SHC1005CR SHC2005CR
(7.9-9.5)
.38"-.44" Blue — — — SHC1006CR —
(9.5-11)
.06"-.13" Green SHC1007 — — — —
(1.6-3.2)
.13"-.19" Orange SHC1008 SHC1008ZP — SHC1008CR SHC2008CR
(3.2-4.7)
3/8 .19"-.25" F1 Red SHC1009 — SHC1009SS SHC1009CR —
(4.7-6.3)
.25"-.31" Black SHC1010 SHC1010ZP — SHC1010CR SHC2010CR
(6.3-7.9)
.31"-.38" White SHC1011 — SHC1011SS SHC1011CR SHC2011CR
(7.9-9.5)
.38"-.44" Blue SHC1012 SHC1012ZP SHC1012SS SHC1012CR SHC2012CR
(9.5-11.0)
.19"-.25" Red SHC1015 — — — —
(4.7-6.3)
1/2 .25"-.31" F1 Black SHC1016 — — — —
(6.3-7.9)
.31"-.38" White SHC1017 — — — —
(7.9-9.5)
.38"-.44" Blue SHC1018 — — — —
(9.5-11.0)
.06"-.13" Green SHC1019 — — SHC1019CR —
(1.6-3.2)
.13"-.19" Orange SHC1020 SHC1020ZP SHC1020SS SHC1020CR —
(3.2-.4.7)
1/2 .19"-.25" F2 Red SHC1021 SHC1021ZP SHC1021SS SHC1021CR SHC2021CR
(4.7-6.3)
.25"-.38" White SHC1022 SHC1022ZP SHC1022SS SHC1022CR SHC2022CR
(6.3-.9.7)
.38"-.50" Blue SHC1023 SHC1023ZP SHC1023SS SHC1023CR SHC2023CR
(9.7-12.7)
.50"-.63" Brown SHC1024 SHC1024ZP SHC1024SS SHC1024CR** SHC2024CR**
(12.7-15.9
)
.38"-.50" Blue SHC1025 — — — —
(9.7-12.7)
.50"-.63" Brown SHC1026 — — — —
(12.7-15.9
)
1/2 .63"-.75" F3 Yellow SHC1027** SHC1027ZP** — — —
(15.9-19.0
)
.75"-.88" Orchid SHC1028** SHC1028ZP** — — —
(19.0-22.2
)
Note:
* IP66 Suitability when used with optional metal clad O-ring.
** Cable jacket may have to be stripped to pass through connector body.
![](asset-2.png)
Stainless
Steel
Gray Nylon
Black Nylon
WIRE MANAGEMENT
E2
Straight Male
N.P.T. Cord Dia. Machined
Hub Inches Form Colour Machined Zinc-Plated Stainless Nylon Nylon
Size (mm) Size Code Aluminum Steel Steel Gray Black
UL Listed to Type 4,
4X, 12 and Type 13
STRAIGHT MALE CORD CONNECTORS
IP66*
SUITABILITY
.06"-.13" Green SHC1029 — — — —
(1.6-3.2)
.13"-.19" Orange SHC1030 SHC1030ZP — — —
(3.2-4.7)
3/4 .19"-.25" F2 Red SHC1031 SHC1031ZP — — —
(4.7-6.3)
.25"-.38" White SHC1032 SHC1032ZP — — —
(6.3-9.7)
.38"-.50" Blue SHC1033 SHC1033ZP — — —
(9.7-12.7)
.50"-.63" Brown SHC1034 SHC1034ZP — — —
(12.7-15.9
)
.38"-.50" Blue — SHC1035ZP SHC1035SS SHC1035CR SHC2035CR
(9.5-12.7)
3/4 50"-.63" F3 Brown SHC1036 — SHC1036SS SHC1036CR SHC2036CR
(12.7-15.9
)
.63"-.75" Yellow SHC1037 SHC1037ZP SHC1037SS SHC1037CR SHC2037CR
(15.9-19.0
)
.75"-.88" Orchid SHC1038** SHC1038ZP** SHC1038SS** SHC1038CR** SHC2038CR**
(19.0-22.2
)
1 .50"-.63" F3 Brown — SHC1097ZP — — —
(12.7-15.9
)
.63"-.75" Yellow — SHC1098ZP — — —
(15.9-19.0
)
.75"-.88" Orchid — SHC1099ZP — — —
(19.0-22.2
)
.38"-.50" Blue SHC1039 — — SHC1039CR —
(9.7-12.7)
.50"-.63" Brown SHC1040 — — SHC1040CR SHC2040CR
(12.7-15.9
)
1 .63"-.75" F4 Yellow SHC1041 — SHC1041SS SHC1041CR SHC2041CR
(15.9-19.0
)
.75"-.88" Orchid SHC1042 — SHC1042SS SHC1042CR SHC2042CR
(19.0-22.2
)
.88"-1.00" Gray SHC1043 SHC1043ZP — SHC1043CR SHC2043CR
(22.2-25.4
)
1.00"-1.13
"
Pink SHC1044** — SHC1044SS** SHC1044CR** SHC2044CR**
(25.4-28.6
)
Note:
* IP66 Suitability when used with optional metal clad O-ring.
** Cable jacket may have to be stripped to pass through connector body.
Form 4 aluminum and plated steel nuts are machined, bodies are cast aluminum.
![](asset-3.png)
Cast Aluminum
Cast Aluminum
Malleable Iron
WIRE MANAGEMENT
E3
Straight Male
N.P.T. Cord Diameter Form
Hub Size Inches (mm) Size Cast Aluminum Malleable Iron
UL Listed to Type 4,
4X, 12 and Type 13
STRAIGHT MALE CORD CONNECTORS
IP66*
SUITABILITY
.88"-1.00" (22.2-25.4
)
SHC1046 —
1 1.00"-1.13
"
(25.4-28.6
)
F5 SHC1047** —
1.13"-1.25
"
(28.6-31.7
)
SHC1048** —
1.25"-1.38
"
(31.7-34.9
)
SHC1049** —
.75"-.88" (19.0-22.2
)
SHC1050 —
.88"-1.00" (22.2-25.4
)
SHC1051 —
1-1/4 1.00"-1.13
"
(25.4-28.6
)
F5 SHC1052 SHC1052ZP
1.13"-1.25
"
(28.6-31.7
)
SHC1053 SHC1053ZP
1.25"-1.38
"
(31.7-34.9
)
SHC1054** SHC1054ZP
.75"-.88" (19.0-22.2
)
SHC1055 —
.88"-1.00" (22.2-25.4
)
SHC1056 —
1-1/2 1.00"-1.13
"
(25.4-28.6
)
F5 SHC1057 SHC1057ZP
1.13"-1.25
"
(28.6-31.7
)
SHC1058 SHC1058ZP
1.25"-1.38
"
(31.7-34.9
)
SHC1059 SHC1059ZP
1.38"-1.50
"
(34.9-38.1
)
SHC1061 —
1-1/2 1.50"-1.63
"
(38.1-41.3
)
F6 SHC1062** —
1.63"-1.75
"
(41.3-44.4
)
SHC1063** —
1.75"-1.88
"
(44.4-47.6
)
SHC1064** —
1.25"-1.38
"
(31.7-34.9
)
SHC1065 —
1.38"-1.50
"
(34.9-38.1
)
SHC1066 —
2 1.50"-1.63
"
(38.1-41.3
)
F6 SHC1067 —
1.63"-1.75
"
(41.3-44.4
)
SHC1068 —
1.75"-1.88
"
(44.4-47.6
)
SHC1069 —
1.69"-1.81
"
(42.9-46.0
)
SHC1070 —
1.81"-1.94
"
(46.0-49.2
)
SHC1071 —
2 1.94"-2.06
"
(49.2-52.4
)
F7 SHC1072** —
2.06"-2.19
"
(52.4-55.6
)
SHC1073** —
2.19"-2.31
"
(55.6-58.7
)
SHC1074** —
1.69"-1.81
"
(42.9-46.0
)
SHC1076 —
1.81"-1.94
"
(46.0-49.2
)
SHC1077 —
2-1/2 1.94"-2.06
"
(49.2-52.4
)
F7 SHC1078 —
2.06"-2.19
"
(52.4-55.6
)
SHC1079 —
2.19"-2.31
"
(55.6-58.7
)
SHC1080 —
2.31"-2.44
"
(58.7-61.9
)
SHC1081** —
1.69"-1.81
"
(42.9-46.0
)
SHC1086 —
1.94"-2.06
"
(49.2-52.4
)
F7 SHC1088 —
3 2.06"-2.19
"
(52.4-55.6
)
SHC1089 —
2.19"-2.31
"
(55.6-58.7
)
SHC1090 —
2.31"-2.44
"
(58.7-61.9
)
SHC1091 —
2.44"-2.63
"
(61.9-66.7
)
SHC1092 —
2.63"-2.81
"
(66.7-71.4
)
SHC1093 —
3 2.81"-3.00
"
(71.4-76.2
)
F8 SHC1094 —
3.00"-3.25
"
(76.2-82.5
)
SHC1095** —
Note:
* IP66 Suitability when used with optional metal clad O-ring.
** Cable jacket may have to be stripped to pass through connector body.
Form 4 aluminum and plated steel nuts are machined, bodies are cast aluminum.
F5 and larger will not be colour coded.
![](asset-4.png)
Machined
Aluminum †
Machined
Zinc-Plated Steel '
Cast Aluminum
WIRE MANAGEMENT
E4
45° Male
N.P.T. Machined
Hub Cord Diameter Form Colour Machined Zinc-Plated Cast
Size Inches (mm) Size Code Aluminum† Steel' Aluminum
45° MALE CORD CONNECTORS
UL Listed to Type 4,
4X, 12 and Type 13
IP66*
SUITABILITY
.19"-.25" (4.7-6.3) Red VHC1021 — —
1/2 .25"-.38" (6.3-9.7) F2 White VHC1022 VHC1022ZP —
.38"-.50" (9.7-12.7) Blue VHC1023 VHC1023ZP —
.50"-.63" (12.7-15.9
)
Brown VHC1024** VHC1024ZP** —
.38"-.50" (9.7-12.7) Blue VHC1035 — —
3/4 .50"-.63" (12.7-15.9
)
F3 Brown VHC1036 — —
.63"-.75" (15.9-19.0
)
Yellow VHC1037** — —
1 .63"-.75" (15.9-19.0
)
F4 Yellow VHC1041 — —
.75"-.88" (19.0-22.2
)
Orchid VHC1042 — —
1-1/4 1.00"-1.13
"
(25.4-28.6
)
F5 — — VHC1052
1.13"-1.25
"
(28.6-31.7
)
— — VHC1053**
Note:
* IP66 Suitability when used with optional metal clad O-ring.
** Cable jacket may have to be stripped to pass through connector body.
Form 4 aluminum and plated steel nuts are machined, bodies are cast aluminum.
† Nuts are machined aluminum and bodies are cast aluminum.
' Nuts are machined zinc-plated steel and bodies are malleable iron, cadmium plated.
![](asset-5.png)
Machined
Aluminum†
Machined
Zinc-Plated Steel'
Cast AluminumGray Nylon Black Nylon
WIRE MANAGEMENT
E5
90° Male
N.P.T. Machined
Hub Cord Diameter Form Colour Machined Zinc-Plated Nylon Nylon Cast
Size Inches (mm) Size Code Aluminum† Steel' Gray Black Aluminum
90° MALE CORD CONNECTORS
UL Listed to Type 4,
4X, 12 and Type 13
IP66*
SUITABILITY
.25"-.31" (6.3-7.9) Black NHC1010 — — — —
3/8 .31"-.38" (7.9-9.5) F1 White NHC1011 — — — —
.38"-.44" (9.5-11.0) Blue NHC1012 — — — —
.06"-.13" (1.6-3.2) Green — — — — —
.13"-.19" (3.2-4.7) Orange NHC1020 — NHC1020CR — —
1/2 .19"-.25" (4.7-6.3) F2 Red NHC1021 NHC1021ZP NHC1021CR — —
.25"-.38" (6.3-9.7) White NHC1022 NHC1022ZP NHC1022CR NHC2022CR —
.38"-.50" (9.7-12.7) Blue NHC1023 NHC1023ZP NHC1023CR NHC2023CR —
.50"-.63" (12.7-15.9
)
Brown NHC1024** NHC1024ZP** NHC1024CR** NHC2024CR** —
.38"-.50" (9.7-12.7) Blue NHC1035 NHC1035ZP NHC1035CR — —
3/4 .50"-.63" (12.7-15.9
)
F3 Brown NHC1036 NHC1036ZP NHC1036CR — —
.63"-.75" (15.9-19.0
)
Yellow NHC1037 NHC1037ZP NHC1037CR — —
.75"-.88" (19.0-22.2
)
Orchid NHC1038 NHC1038ZP NHC1038CR — —
.50"-.63" (12.7-15.9
)
Brown NHC1040 — — — —
.63"-.75" (15.9-19.0
)
Yellow NHC1041 NHC1041ZP NHC1041CR NHC2041CR —
1 .75"-.88" (19.0-22.2
)
F4 Orchid NHC1042 — NHC1042CR NHC2042CR** —
.88"-1.00" (22.2-25.4
)
Gray NHC1043** — NHC1043CR NHC2043CR** —
1.00"-1.13
"
(25.4-28.7
)
Pink NHC1044** — — — —
.88"-1.00" (22.2-25.4
)
— — — — — NHC1051
1-1/4 1.00"-1.13
"
(25.4-28.6
)
F5 — — — — — NHC1052
1.13"-1.25
"
(28.6-31.7
)
— — — — — NHC1053**
1.25"-1.38
"
(31.7-34.9
)
— — — — — NHC1054**
1.00"-1.13
"
(25.4-28.6
)
— — — — — NHC1057
1-1/2 1.13"-1.25
"
(28.6-31.7
)
F5 — — — — — —
1.25"-1.38
"
(31.7-34.9
)
— — — — — NHC1059
2 1.38"-1.50
"
(34.9-38.1
)
F6 — — — — — NHC1066
Note: * IP66 Suitability when used with optional metal clad O-ring.
** Cable jacket may have to be stripped to pass through connector body.
† Nuts are machined aluminum and bodies are cast aluminum.
' Compression nuts are machined zinc-plated steel and bodies are zinc-plated malleable iron.
![](asset-6.png)
Machined
Aluminum
Gray Nylon
Machined
Zinc-Plated Steel
Machined
Aluminum
Machined
Aluminum
WIRE MANAGEMENT
E6
Straight Female
N.P.T.
Hub Cord Diameter Form Colour Machined
Size Inches (mm) Size Code Aluminum
Note: * Cable jacket may have to be stripped to pass through connector body.
† Nuts are machined aluminum and bodies are cast aluminum.
Underground Feeder Connectors
N.P.T. UF** Machined
Hub Diameter Wire Machined Zinc-Plated Nylon Nylon
Size Inches (mm) Size Aluminum Steel Gray Black
Metric Aluminum Cord Connectors
Hub Cord Diameter Form
Size Inches (mm) Size Catalog Number
IP66*
SUITABILITY
UL Listed to Type 4,
4X, 12 and Type 13
STRAIGHT FEMALE, UNDERGROUND
FEEDER AND METRIC CONNECTORS
1/2 .25"-.38" (6.3-9.7) F2 White FHC1022
.38"-.50" (9.7-12.7) Blue FHC1023
3/4 .38"-.50" (9.7-12.7) F2 Blue FHC1033
.50"-.63" (12.7-15.9
)
Brown FHC1034
1 .75"-.88" (19.0-22.2
)
F4 Orchid FHC1042†
.88"-1.00" (22.2-25.4
)
Gray FHC1043†
1/2 .2"x.4" mi
n
(5.1 x 10.
2)
2 # 14,
.25"-.55"
max
(6.3 x 14.
0)
2 # 12, UFC0001 UFC0001ZP UFC0001CR UFC2001CR
2 # 10.
3/4 .2"x.4" mi
n
(5.1x10.2) 2 # 14,
.25"-.55"
max
(6.3x14.0) 2 # 12, UFC0002 — — —
2 # 10.
3/4 .2"x.6" mi
n
(5.1x15.2) 3 # 14,
.26"x.78"
max
(6.6x19.8) 3 # 12, UFC0003 — UFC0003CR UFC2003CR
3 # 10.
Note: * IP
66 Suitability when used with optional metal clad O-ring.
** Wire si
zes vary among manufacturers.
M16 .31"-.38" (7.9-9.7) F1 SHCM161011
M20 .31"-.38" (7.9-9.7) F1 SHCM201017
.25"-.38" (6.3-9.7) SHCM201022
M20 .38"-.50" (9.7-12.7) F2 SHCM201023
.50"-.62" (12.7-15.8
)
SHCM201024
M25 .38"-.50" (9.7-12.7) F2 SHCM251033
.50"-.62" (12.7-15.8
)
SHCM251034
M30 .63"-75" (15.9-19.0
)
F3 SHCM301037
Note: † When used with metal clad O-ring.
Non-metallic Locknuts sold separately.
![](asset-7.png)
SEC100BA
SECP29GA
LNP29BPK25
WIRE MANAGEMENT
E7
Low Profile N.P.T. Cord Connectors
N.P.T. Cord Diameter Catalog Non-metallic
Hub Size Inches (mm) Colour Number Locknuts
Low Profile PG' Cord Connectors
Cord Diameter Catalog Non-metallic
Hub Size Inches (mm) Colour Number Locknuts
Low Profile Metric Cord Connectors
Cord Diameter Catalog Non-metallic
Hub Size Inches (mm) Colour Number Locknuts
LOW PROFILE N.P.T., PG
AND METRIC THREAD CONNECTORS
IP66*
SUITABILITY
3/8 .18"-.31" (4.6-7.9) Gray SEC38GA* 31622002LPK50
3/8 .18"-.31" (4.6-7.9) Black SEC38BA* 31622002LPK50
1/2 .17"-.45" (4.3-11.4) Gray SEC50GA 31622003LPK50
1/2 .17"-.45" (4.3-11.4) Black SEC50BA 31622003LPK50
3/4 .45"-.71" (11.4-18.0
)
Gray SEC75GA 31622007LPK50
3/4 .45"-.71" (11.4-18.0
)
Black SEC75BA 31622007LPK50
1 .59"-1.00" (15-25.4) Gray SEC100GA 31622008LPK50
1 .59"-1.00" (15-25.4) Black SEC100BA 31622008LPK50
Note: Cata
log numbers with “PK50” suffix are bulk packed 50 pieces.
PG7 .11"-.25" (2.9-6.4) Gray SECP7GA* LNP7BPK100
PG7 .11"-.25" (2.9-6.4) Black SECP7BA* LNP7BPK100
PG9 .18"-.31" (4.6-7.9) Gray SECP9GA* LNP9BPK100
PG9 .18"-.31" (4.6-7.9) Black SECP9BA* LNP9BPK100
PG11 .23"-.40" (5.8-10.0) Gray SECP11GA* LNP11BPK100
PG11 .23"-.40" (5.8-10.0) Black SECP11BA* LNP11BPK100
PG13.5 .17"-.47" (4.3-11.9) Gray SECP13GA LNP13BPK100
PG13.5 .17"-.47" (4.3-11.9) Black SECP13BA LNP13BPK100
PG16 .23"-.53" (5.8-13.5) Gray SECP16GA LNP16BPK100
PG16 .23"-.53" (5.8-13.5) Black SECP16BA LNP16BPK100
PG21 .45"-.71" (11.4-17.9
)
Gray SECP21GA LNP21BPK100
PG21 .45"-.71" (11.4-17.9
)
Black SECP21BA LNP21BPK100
PG29 .59"-.99" (15-25.2) Gray SECP29GA LNP29BPK25
PG29 .59"-.99" (15-25.2) Black SECP29BA LNP29BPK25
PG36 .88"-1.30" (22.2-32.0
)
Gray SECP36GA LNP36BPK25
PG36 .88"-1.30" (22.2-32.0
)
Black SECP36BA LNP36BPK25
M12 .12"-.25" (2.9-6.4) Gray SECM12G LNM12BPK100
M12 .12"-.25" (2.9-6.4) Black SECM12B LNM12BPK100
M16 .11"-.31" (2.7-7.9) Gray SECM16G LNM16BPK100
M16 .11"-.31" (2.7-7.9) Black SECM16B LNM16BPK100
M20 .17"-.45" (4.3-11.4) Gray SECM20G* LNM20BPK100
M20 .17"-.45" (4.3-11.4) Black SECM20B* LNM20BPK100
M25 .49"-.71" (12.3-18.0
)
Gray SECM25G* LNM25BPK100
M25 .49"-.71" (12.3-18.0
)
Black SECM25B* LNM25BPK100
M32 .59"-1.00" (15.0-25.4
)
Gray SECM32G* LNM32BPK100
M32 .59"-1.00" (15.0-25.4
)
Black SECM32B* LNM32BPK100
M40 .87"-1.30" (22.0-32.0
)
Gray SECM40G LNM40BPK100
M40 .87"-1.30" (22.0-32.0
)
Black SECM40B LNM40BPK100
Note: Cata
log numbers above with “PK100” suffix, i.e. LNP7BPK100, are bulk packed 100 per carton.
Catalog nu
mbers above with “PK25” suffix, i.e. LNP29BPK25, are bulk packed 25 per carton.
* Items in
dicated are UL recognized components.
' Panzerge
winde.
![](asset-8.png)
Metal Clad
Sealing O-Rings
Non-Metallic Locknuts
WIRE MANAGEMENT
E8
Locknuts — Non-Metallic
N.P.T.
Hub Size Catalog Number
Metal Clad Sealing O-Rings
N.P.T.
Hub Size Catalog Number
ACCESSORIES
1/4 31622001LPK50
3/8 31622002LPK50
1/2 31622003LPK50
3/4 31622007LPK50
131622008LPK50
1-1/4 —
1-1/2 —
Note: Catalog numbers above with “PK50” suffix are bulk packed 50 per carton.
See page T-101 for additional technical data and dimensional drawings.
1/2 20509001
3/4 20509002
120509003
1-1/4 20509004
1-1/2 20509005
220509006
2-1/2 20509007
320509008
![](asset-9.png)
WIRE MANAGEMENT
E9
Gray Cord Connector
Black Cord Connector
Gray Cord Connector with
Spiral
Black Cord Connector with
Spiral
Gray Snap-In
Cord Connector
Black Snap-In
Cord Connector
Miniature Nylon Cord Connector
N.P.T. Cord Diameter Range
Hub Size Inches (mm) Gray Black
Miniature Nylon Cord Connector with Spiral
N.P.T. Cord Diameter Range
Hub Size Inches (mm) Gray Black
Miniature Nylon Snap-In Cord Connector with Spiral
Cord Diameter Range For Chassis
Inches (mm) Thickness Gray Black
HUBBELL JUNIORS® MINIATURE
NYLON CORD CONNECTORS
.08"-.14" (1.9-3.4) HJ1001GPK25 HJ1001BPK25
1/4 .14"-.20" (3.4-5.1) HJ1002GPK25 HJ1002BPK25
.20"-.27" (5.1-6.7) HJ1003GPK25 HJ1003BPK25
.15"-.21" (3.7-5.3) HJ1004GPK25 HJ1004BPK25
3/8 .21"-.28" (5.3-7.0) HJ1005GPK25 HJ1005BPK25
.28"-.34" (7.0-8.6) HJ1006GPK25 HJ1006BPK25
.06"-.13" (1.6-3.2) HJ1055GPK25 HJ1055BPK25
.13"-.19" (3.2-4.7) HJ1056GPK25 HJ1056BPK25
1/2 .19"-.25" (4.7-6.3) HJ1057GPK25 HJ1057BPK25
.25"-.31" (6.3-7.9) HJ1058GPK25 HJ1058BPK25
.31"-.38" (7.9-9.5) HJ1059GPK25 HJ1059BPK25
.38"-.44" (9.5-11.1) HJ1060GPK25 HJ1060BPK25
.08"-.14" (1.9-3.4) HJ1010GPK25 HJ1010BPK25
1/4 .14"-.20" (3.4-5.1) HJ1011GPK25 HJ1011BPK25
.20"-.27" (5.1-6.7) HJ1012GPK25 HJ1012BPK25
.15"-.21" (3.7-5.3) HJ1013GPK25 HJ1013BPK25
3/8 .21"-.28" (5.3-7.0) HJ1014GPK25 HJ1014BPK25
.28"-.34" (7.0-8.6) HJ1015GPK25 HJ1015BPK25
.13"-.19" (3.2-4.7) HJ1038GPK25 HJ1038BPK25
.19"-.25" (4.7-6.3) HJ1039GPK25 HJ1039BPK25
1/2 .25"-.31" (6.3-7.9) HJ1040GPK25 HJ1040BPK25
.31"-.38" (7.9-9.5) HJ1041GPK25 HJ1041BPK25
.38"-.44" (9.5-11.1) HJ1042GPK25 HJ1042BPK25
3/4 .25"-.49" (6.4-12.3) HJ1043GPK25* HJ1043BPK25*
.45"-.71" (11.4-18.0
)
HJ1044GPK25* HJ1044BPK25*
.22"-.27" (5.6-6.9) .10" (2.5)
Max
HS1001GPK25 HS1001BPK25
.28"-.32" (7.1-8.1) .10" (2.5)
Max
HS1002GPK25 HS1002BPK25
.30"-.36" (7.6-9.1) .13" (3.2)
Max
HS1003GPK25 HS1003BPK25
.32"-.43" (8.1-10.9) .13" (3.2)
Max
HS1004GPK25 HS1004BPK25
Note: Cata
log numbers above with “PK25” suffix, i.e. HJ1001GPK25, are bulk packed 25 per carton.
![](asset-a.png)
Rigid PVC core bonded to Üexible PVC jacket
All nonmetallic construction ends metal fatigue and
separation problems
UL Listed and CSA CertiÛed
Cuts cleanly with a knife or PVC cutter so there
are no jagged metal edges
WIRE MANAGEMENT
E10
PolyTuff® I Conduit
Trade Size (metric designator) Feet (m) Catalog Number
PolyTuff
®
I Conduit–Gray
IP66
SUITABILITY
POLYTUFF® I NON-METALLIC
LIQUIDTIGHT CONDUIT
³⁄₈ (12) 100 (30.5)
G1038
½ (16) 100 (30.5)
G1050
¾ (21) 100 (30.5)
G1075
1 (27) 100 (30.5)
G1100
1¼ (35) 100 (30.5)
G1125
1½ (41) 50 (15.2) G1150
2 (53) 50 (15.2) G1200
![](asset-b.png)
PVC core with corrugated walls bonded to PVC jacket
Handles twists, turns, bends, switchbacks and straightaways with ease
All nonmetallic construction ends fatigue and
separation problems
Can be cut with a knife or PVC cutters
UL Recognized and CSA CertiÛed
WIRE MANAGEMENT
E11
PolyTuff® II Tubing
Trade Size (metric designator) Feet (m) Catalog Number
PolyTuff
®
II Tubing–Black
IP66
SUITABILITY
POLYTUFF® II NON-METALLIC
LIQUIDTIGHT TUBING
¼ (10) 100 (30.5)
B2025
³⁄₈ (12) 100 (30.5)
B2038
½ (16) 100 (30.5)
B2050
¾ (21) 100 (30.5)
B2075
1 (27) 100 (30.5)
B2100
1¼ (35) 100 (30.5)
B2125
1½ (41) 50 (15.2) B2150
2 (53) 50 (15.2) B2200
![](asset-c.png)
PS05GYKIT
P1259NGY
P125NGY
P075NGYA
PS0509NGY - SwivelLok®
WIRE MANAGEMENT
E12
Straight with Male Non-Metallic Liquidtight Fittings
Trade Black Gray
Size (metric designator) Catalog Number Catalog Number
SwivelLok® Multi-Position with Male Non-Metallic Liquidtight Fittings
Trade Black Gray
Size (metric designator) Catalog Number Catalog Number
Fixed 90° Fittings for Non-Metallic Conduit
Trade Black Gray
Size (metric designator) Catalog Number Catalog Number
SwivelLok® Flexible Conduit Kit
Trade Size (metric designator) Fitting and Conduit Catalog Number
POLYTUFF® II NON-METALLIC
LIQUIDTIGHT FITTINGS
UL Listed to Type 4,
4X, 12 and Type 13
¼ (6) F2025 —
³⁄₈
(9) P038NBKA P038NGYA
½ (13) P050NBKA P050NGYA
¾ (19) P075NBKA P075NGYA
1 (25) P100NBKA P100NGYA
1¼ (32) P125NBK P125NGY
1½ (38) P150NBK P150NGY
2 (51) P200NBK P200NGY
Note: Fitt
ings are to be used with PolyTuff I and PolyTuff II.
³⁄₈ Liq
uidtight conduit fitting have ½ N.P.T. male threads.
³⁄₈ (9) PS0389NBK PS0389NGY
½ (13) PS0509NBK PS0509NGY
¾ (19) PS0759NBK PS0759NGY
1 (25) PS1009NBK PS1009NGY
Note: Fitt
ings are to be used with PolyTuff I and PolyTuff II.
³⁄₈6S[_S
dtight conduit fitting have ½ N.P.T. male threads.
¼ (6) F20259 —
³⁄₈ (9) P0389NBK P0389NGY
½ (13) P0509NBK P0509NGY
¾ (19) P0759NBK P0759NGY
1 (25) P1009NBK P1009NGY
1¼ (32) P1259NBK P1259NGY
Note: Fitt
ings are to be used with PolyTuff I and PolyTuff II.
³⁄₈6S[
uidtight conduit fitting have ½ N.P.T. male threads.
½ (13) 2 PS0509NG
Y, 6' G1050
PS05GYKIT
¾ (19) 2 PS0759NG
Y, 6' G1075
PS07GYKIT
