PG-BB-0307
ConneCtors
Compression Connectors
Automatic Connectors
Wedge Clamps
Mechanical Connectors
Grounding Connectors
Installation Dies and Tools
Product Selection Guide
ConneCtors
THOMAS & BETTS...
A recognized world leader in the
design and manufacture of innovative
products for the electrical industry.
For over 100 years, Thomas & Betts has successfully
applied innovative design and manufacturing techniques
to meet the changing needs of the marketplace. Today,
we offer more than 100,000 electrical items, components
and systems to terminate, connect, fasten, protect and
identify wires, components and conduits. Many well-
known brands, like Blackburn, complement the vast
assortment of products and services that makes T&B
one of the largest and best sources of electrical compo-
nents in North America.
Maintaining the technical excellence of existing products
along with new product innovation is central to the way
we do business. That’s why we invest considerably more
in research and development than the industry average.
Our commitment to lean manufacturing and Six-Sigma
initiatives is to provide you with innovative, cost-effec-
tive products and systems that are supported by our
quality processes. This ensures that we remain sensitive
to your needs and focused on providing you with quality
products, and superior service to enhance your abilities
to be a reliable electric power provider.
Thomas & Betts maintains a nationwide network of
stocking electrical utility distributors
. Our customer
service capability is unmatched in the industry. Our heavy
investment into world class manufacturing, order process-
ing systems, and warehousing was designed to meet our
customer service needs promptly and efficiently. We also
maintain a substantial inventory of critical, storm related
items essential for the quick restoration of electric power.
With quality product design and superior product
performance, backed with outstanding customer service,
Thomas & Betts delivers the solutions that allow you
to build a reliable electric system of the future.
2
Introduction
ConneCtors
Contents
continued
Product Overview Pg. 37
Split Bolt Connectors 38-39
Mechanical Service Entrance Connectors 40
Parallel Groove Connectors 41-43
Two-Bolt Connectors 44-45
Cross Tap Clamps 46
Dead-End Clamps 46
Hot Line Clamps 47
Multi-Bolt Connectors 48
Product Overview Pg. 29
Automatic Splices for Aluminum 30
Automatic Deadends for Aluminum 31-32
Guystrand Deadends 33
Guystrand Splices 34
Service Wedge Clamps 35
Product Overview Pg. 5
Compression H-Tap Connectors 6-14
Service Entrance Connectors 14-18
Distribution Compression Connectors (Splices and Terminals) 19-25
Compression Stirrup Connectors 26-28
Compression Connectors
Mechanical Connectors
Automatic Connectors & Wedge Clamps
Grounding Connectors & Accessories
Product Overview Pg. 49
Ground Rod Clamps and Accessories 50-52
Ground Plates 53
Mechanical Grounding Connectors 54
3
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
ConneCtors
Contents
4
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference Pg. 64-76
Tool Cross Reference 77
Conductor Cross Reference 78-86
Product Overview Pg. 55
Ground Clamp Adapter 56
Manual Compression Tools 56
Manual Hydraulic Tools 57
Battery-Operated Hydraulic Tools 58-59
Service and Warranty Information 60
Tool Die Selection Chart 61-62
Chemicals, Sealant and Lubricants 63
Index Pg. 87-89
Installation Dies & Tools
Alphanumeric Index
Reference Tables
Compression
Connectors
ConneCtors
5
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Product Overview
Type WR
Wide Range
Compression
Connectors
Pages 6-12
Type KL
Large Compression
Service Entrance Sleeves
Page 15
Type ICS
5/8” Insulated Service
Entrance Sleeves
Page 16
Type TR
Triplex Neutral Splices
Page 18
Type RS
Non-Tension
Aluminum Splices
Page 18
Type ACJ, RCJ
Aluminum Jumper
Sleeves
Pages 19, 20
Type AC, RC
Full Tension
Aluminum Splices
Pages 21,22
Type CTS
Copper Full Tension
Splices
Page 23
Type PCS, PKL, PRS
Pigtail Compression
Sleeves
Page 23
Type AL
Aluminum
Compression
Terminal Lugs
Page 24
Type LP
Line Protector
Sleeves
Page 28
Type CF
Copper Compression
Tap Connectors
Page 13
Type C
Compression Tap
Covers
Page 14
Type CS, CSC
5/8” Service Entrance
Sleeves With Cover
Page 14
Type IKL
Insulated Large
Service Entrance
Sleeves
Page 17
Type ALS
Aluminum
Compression
Terminal Lugs
Page 25
Type WRQ, WRS,
SC, QC, CCS
Compression Stirrups
Pages 26-28
Compression
Connectors
ConneCtors
6
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Compression H-Tap Connectors
TYPE WR
Type WR – Wide Range Aluminum Tap
Connectors
• For combinations of aluminum-aluminum and
aluminum-copper conductors
• Pass the requirements of ANSI C119.4
• Standard compression tools and dies install
all sizes
• Seven Connector Program provides superior
connector performance, lower connection
costs and simplified installation procedures
• Fold-in tabs provide positive tab interlock as
tool closes
• Field-proven ribbed design provides excellent
connector/conductor contact, without
distorting the conductor’s shape
• Made of 1350 aluminum alloy
• Pre-filled with an oxide inhibitor which is held
captive in the rib/connection area
• RUS Listed
• For copper to copper combinations, use CF
type shown on page 13.
Main Tap Main Tap Main Tap
Standard Conductor
Compact Conductor Diameter (in.) No. Indents
ACSR Str. Sol. ACSR Str. Sol. ACSR Str. ACSR Str. max. min. max. min.
Conductor Range Installation
Information
WR159 1 .332 .162 .332 .162 17⁄16” O 4 2
WR289 3
WR379 5
WR419 7
WR399 6
WR279 4
WR189 2
.470 .398 .332 .162 113⁄16” D 5 2
.563 .475 .332 .162 113⁄16” D 5 2
.419 .266 .332 .162 111⁄16” O 5 2
.470 .336 .470 .336 113⁄16” D 5 2
.563 .461 .447 .338 23⁄16” D 6 2
.563 .461 .563 .461 27⁄16” D 7 3
Mech. Hyd.
Tool Tool
Cat.
No.
Con-
nector
No.
Con-
nector
Length
L
Con-
nector
Die
2
4
6
1
2
3
4
6
2
4
6
2
4
6
2
4
6
1
2
3
4
6
1
2
3
4
6
1
2
3
4
6
1
2
4
6
1
2
4
6
1/0
1
2
2/0
1/0
1
2
3/0
2/0
1/0
1
2
4
6
1
2
3
4
6
1/0
1
2
4
6
2/0
1/0
1
2
2/0
1/0
1
2
1
2
4
6
1
2
3
4
6
2/0
1/0
3/0
2/0
4/0
3/0
2
4
6
1
2
3
4
6
1/0
1
2
4
6
2/0
1/0
1
2
2/0
1/0
1
2
1
2
4
6
1
2
3
4
6
2/0
1/0
1
3/0
2/0
1/0
—
—
—
3/0
2/0
1/0
3/0
2/0
1/0
3/0
2/0
1/0
3/0
2/0
1/0
4/0
3/0 4/0 —
1/0
1
2
4
6
2
4
6
1
2
3
4
6
26618⁄1
250
4/0
266
250
4/0
1
2
4
6
1
2
3
4
6
4/0
3/0
4/0
3/0 —
2/0
1/0
1
2/0
1/0
3/0
2/0
26618⁄1
4/0
3/0
266
250
4/0
2/0
1/0
3/0
2/0
1/0
4/0
3/0
4/0
3/0 —4/0
3/0
4/0
3/0 —
26618⁄1
4/0
3/0
266
250
4/0
26618⁄1
4/0
3/0
266
250
4/0
TYPE WR – “O” AND “D” DIE SEVEN CONNECTOR PROGRAM
2/0
1/0
1
3/0
2/0
1/0
—
—
—
Compression
Connectors
ConneCtors
7
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Compression H-Tap Connectors
TYPE WR
Tap
Main
WR219
WR299
WR239
WR229
WR269
Standard Conductor Compact Conductor Diameter (in.) No. Indents
Main Tap Main Tap Main Tap
ACSR Str. Sol. ACSR Str. Sol. ACSR Str. ACSR Str. max. min. max. min.
Conductor Range Installation
Information
WR149 .266 .162 .266 .162 11⁄2” O 5 2
WR199
WR259
WR1010
WR179
.419 .232 .419 .232 13⁄4” O 4 2
.398 .324 .398 .316 17⁄8” D 5 2
.398 .266 .332 .232 13⁄4” O 5 2
.419 .326 .412 .292 17⁄8” D 5 2
.447 .365 .332 .236 17⁄8” D 5 2
.470 .410 .398 .316 17⁄8” D 5 2
Mech. Hyd.
Tool Tool
Con-
nector
Length
L
Con-
nector
Die
.398 .266 .266 .162 13⁄4” O 5 2
.470 .398 .266 .162 11⁄2” D 4 2
.447 .410 .447 .336 17⁄8” D 5 2
4
6
3
4
6
2
3
4
6
4
6
4
6
3
4
6
2
3
4
6
3
4
6
2
3
4
6
2
3
4
6
1/0
1
2
3
1/0
1
2
14
6
3
4
6
2
3
4
6
1/0
1
2
2/0
1/0
1
2
1
2
3
4
1
2
1/0
1
2
3
1/0
1
2
1
2
3
4
1
2
3
4
1
2
1/0
1
2
2/0
1/0
1
2
4
6
2
3
4
6
2/0
1/0
1
2
3
4
1/0
1
2
3
4
1/0
1
2
1/0
1
2
3
4
2/0
1/0
1
2
3
4
1/0
1
2
2/0
1/0
1
2
3
4
2/0
1/0
1
2
2/0
1/0
1
2
3
4
2/0
1/0
1
2
1/0
1
2/0
1/0 —1/0
1
2/0
1/0 —2/0
1/0
2/0
1/0
2/0
1/0
2/0
1/0
1/0
1
2/0
1/0
3/0
2/0 —3/0
2/0
4
6
3
4
6
2
3
4
6
4
6
2
3
4
6
3/0
1/0
1—
1/0
1
2
1/0
1— 1/0 2/0
1/0 1/0 2/0
1/0
2/0
1/0
2/0
1/0 —
2
3
4
1
2
3
1
2
2/0
1/0
1
2
3
4
1
2
4/0
3/0
2/0
2/0 2/0
3/0
2/0 —
—
—
—
1/0
1
2
1/0
1
2/0
1/0
2/0
1/0
3/0
2/0 3/0
2/0 3/0
1/0
1
2/0
1/0
2/0
1/0
3/0
2/0
1/0
Cat.
No.
TYPE WR – SUPPLEMENTAL “O” AND “D” DIE CONNECTORS
Compression
Connectors
ConneCtors
8
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Compression H-Tap Connectors
TYPE WR
Tap
Main
Main Tap Main Tap Main Tap
WR389**
WR389
Standard Conductor* Compact Conductor Diameter (in.) No. Indents
ACSR Str. Sol. ACSR Str. Sol. ACSR Str. ACSR Str. max. min. max. min.
WR319 .502 .461 .332 .229 17⁄8” D 5 2
WR359
WR369**
WR369
WR339
.563 .461 .374 .266 17⁄8” D 4 2
.563 .423 .470 .336 23⁄16” D 6 2
.563 .461 .266 .162 17⁄8” D 4 2
.563 .423 .373 .232 17⁄8” D 5 2
Mech. Hyd.
Tool Tool
Cat. No.
Con-
nector
Length
L
Con-
nector
Die
.502 .461 .447 .336 21⁄8” D 6 2
.563 .461 .470 .376 23⁄16” D 6 2
*Will accept conductors of these same wire sizes with a 3% reduction of diameter (compressed).
**This range possible only when crimped with hydraulic tool.
4/0
3/0
2/0
3/0
3/0
4/0
3/0
4/0
3/0
4/0
3/0
4/0
3/0
2/0
4/0
3/0 —4
6
3
4
6
2
3
4
6
266
4/0
3/0
266
250
4/0
1/0
1
2
1/0
1
2
3/0 —
2
3
4
1
2
3
4
1
23/0 4/0
1
2
3
4
1
2
3/0 —
2/0
1/0
1
2/0
1/0 — 3/0 4/0 2/0
1/0
3/0
2/0
1/0
4/0
3/0 —
1
2
3
4
1/0
1
2
3
1
266
4/0
3/0
266
250
4/0
1/0
1
2
1/0
1
2
4/0
3/0 —
1/0
1
2
3
4
266
4/0
3/0
1/0
1
2
3
4
1/0
1
2
266
250
4/0
3/0
1/0
1
2
3
4
1/0
1
2
4/0
3/0 —2/0
1/0
3/0
2/0 —
266
4/0
3/0
266
250
4/0
3/0
2/0
3/0
2/0
4/0
3/0 —
2/0
1/0
1
3/0
2/0
1/0
—
266
4/0
3/0
266
250
4/0
3/0
2/0
1/0
3/0
2/0
1/0
Conductor Range Installation
Information
TYPE WR – SUPPLEMENTAL“O” AND “D” DIE CONNECTORS
Compression
Connectors
ConneCtors
9
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Compression H-Tap Connectors
TYPE WR
500
400
397
350
336
300
266
250
4/0
500
400
397
350
336
300
266
250
4/0
WR885
WR715 .753 .520 .447 .162 2” 2
WR815
WR875**
WR835
WR775
.858 .520 .563 .368 2” 2
.858 .520 .447 .162 2” 2
.858 .520 .684 .520 3” 3
.743 .520 .743 .520 3” 3
.814 .520 .814 .520 3” 3
400
397
350
336
300
266
250
400
397
350
336
300
266
250
4/0
400
397
350
336
300
266
250
4/0
500
477
397
350
336
300
266
250
500
477
397
336
300
266
250
39718⁄1
336
266
39718⁄1
336
266
4/0
556
477
397
336
266
250
2/0
1/0
1
2
3
4
6
3/0
2/0
1/0
1
2
3
4
6
477
397
336
2/0
1/0
1
2
3
4
6
2/0
1/0
1
2
3
4
6
3/0
2/0
1/0
1
2
3
4
6
500
477
397
350
39718⁄1
336
266
4/0
—
477
397
336
266
477
397
336
266
3/0
2/0
1/0
1
2
3
4
6
2/0
1/0
1
2
3
4
6
3/0
2/0
1/0
1
2
3
4
6
2/0
1/0
1
2
3
4
6
2/0
1/0
1
2
3
4
6
556
477
397
336
266
400
397
350
336
300
266
250
266
4/0
3/0
2/0
556
477
397
350
336
300
266
250
250
4/0
3/0
556
477
397
350
336
300
266
250
556
477
397
336
266 397
336
266
4/0
3/0
2/0
4/0
3/0
2/0
1/0
4/0
3/0
2/0
1/0
397
336
350
336
300
266
250
33618⁄1
266
556
477
397
350
336
300
266
250
—
556
477
397
336
266
556
477
397
336
266
47718⁄1
397
336
266
4/0
47718⁄1
397
336
266
4/0
JB12A,
JB12B,
12A
and
Y-35
tools
* Will accept conductors of these same wire sizes with a 3% reduction of diameter (compressed).
**Figure 2
Standard Conductor*
Compact Conductor Diameter (in.)
Main Tap Main Tap Main Tap
ACSR
Str.
ACSR
Str. Sol.
ACSR
Str.
ACSR
Str. max. min. max. min. For Use No. of
With Tool Indents
Cat. No.
Con-
nector
Length
L
Conductor Range
Installation
Information
TYPE WR – WIDE RANGE “N” DIE TAP CONNECTORS FOR HYDRAULIC TOOLS, 12-TON AND GREATER
556
500
400
397
350
336
300
266
250
47718⁄1
397
336
266
4/0
Fig. 2
Main
Tap
Main
Tap
Fig. 1
Compression
Connectors
ConneCtors
10
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Fig. 2
Main
Tap
Compression H-Tap Connectors
TYPE WR
.814 .666 3” 3
WR819
WR699
WR739
WR719
.563 .477 2” 2
.684 .593 3” 3
477
397
336
266
250
4/0
4
6
2
3
4
6
4
6
2
3
4
6
39718⁄1
336
266
4/0
47718⁄1
266
266
4/0
3/0
4
6
477
397
397
350
336
2/0
1/0
1
2
556
477
397
350
3/0
2/0
1/0
1
397
336
500
400
397
350
336
3/0
2/0
1/0
1
4/0
3/0
2/0
397
33618⁄1
266
556
477
397
350
556
477
397
336
556
477
397
336
47718⁄1
397
336
47718⁄1
397
336
4/0
3/0
2/0
2/0
1/0
1
2
WR779
WR799
400
397
350
336
266
250
3
4
6
2/0
1/0
1
2
WR839
4/0
3/0
WR879**
WR889
350
336
300
266
500
400
397
350
336
3
4
6
2/0
1/0
1
2
3
4/0
3/0
2/0
1/0
2/0
1/0
1
2
3
3/0
2/0
1/0
1
2
3
4
6
500
250
2/0
1/0
1
2
3/0
2/0
1/0
1
477
397
336
3
4
6
2
3
4
6
266
4/0
3/0
266
250
4/0
.477 .289 2” 2
.270 .160 2” 2
.743 .570 3” 3
.563 .398 2” 2
.447 .289 2” 2
.266 .162 2” 2
.814 .575
.666.814
500
250
556
500
477
450
400
397
350
336
47718⁄1
266
47718⁄1
397
336
556
477
397
556
477
397
.858 .659
.570
.743
400
397
350
336
300
266
250
39718⁄1
336
266
477
397
336
477
397
350
336
300
Standard Conductor*
Compact Conductor Diameter (in.)
Main Tap Main Tap Main Tap
ACSR Str. ACSR Str. Sol. ACSR Str. ACSR Str. max. min. max. min.
Conductor Range
Installation
Information
For Use No. of
With Tool Indents
Cat. No.
Con-
nector
Length
L
—
4/0
JB12A,
JB12B,
WH2,
PH2, 12A
and
Y-35
tools
*Will accept conductors of these same wire sizes with a 3% reduction of diameter (compressed).
**Figure 2
TYPE WR – WIDE RANGE “N” DIE TAP CONNECTORS FOR HYDRAULIC TOOLS, 10-TON AND GREATER
Main
Tap
Fig. 1
Compression
Connectors
ConneCtors
11
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Compression H-Tap Connectors
TYPE WR
Tap
Main
WR999
WR949
WR989
WR969
Conductor Range
Installation
Information
WR909
954
900
874
1000
900
Standard Conductor Compact Conductor Diameter (in.)
Main Tap Main Tap Main Tap
ACSR Str. ACSR Str. ACSR Str. ACSR Str. max. min. max. min.
.684 .398 43⁄4 R 4
WR929
Cat. No.
Con-
nector
Length
L
900
874
800
795
750
715
700
636
600
350
336
266
250
4/0
3/0
2/0
79526⁄7
715
666
636
605
556
477 30⁄7
954
874
795
636
556
477
397
1000
954
874
795
750
700
636
556
477
450
900
874
800
795
750
715
700
636
600
55618⁄1
477
397
336
300
1000
954
874
795
750
55618⁄1
477
397
336
300
JB60A,
JB60B,
Y60,
60A
and
PH-3
tools
For Use Connector No. of
With Tool Die Indents
600
556
550
500
400
477
450
400
397
350
336
397
350
336
300
266
250
4/0
3/0
3971⁄2
336
266
4/0
3/0
2/0
33618⁄1
266
4/0
3/0
2/0
1/0
55618⁄1
477
397
336
300
636
556
477
397
700
636
556
500
477
450
600
556
550
500
477
450
400
397
350
336
636
556
477
397
700
636
556
477
450
397
350
336
300
266
250
4/0
3/0
.893 .666 43⁄4 R 4
.666.893
600
556
550
500
477
450
400
397
350
336
39718⁄1
336
266
4/0
3/0
2/0
350
336
266
250
4/0
3/0
2/0
79526⁄7
715
666
636
605
556
477 30⁄7
33618⁄1
266
4/0
3/0
2/0
1/0
954
874
795
.8831.108
954 45⁄7
900
874
795
715
666
1033
1000
900
800
795
750
954 45⁄7
900
874
795
715
666
1033
1000
900
800
795
750
954
900
1000
900 1.172 .997
.684 .398 43⁄4 R 4
1.108 .883 43⁄4 R 4
.893 .666 43⁄4 R 4
1.172 .997 43⁄4 R 4
TYPE WR – WIDE RANGE “R” DIE TAP CONNECTORS
Compression
Connectors
ConneCtors
12
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
.563 .461 .162 .100 .092 .064 11⁄2” D 4 —
.292 .184 .146 .064 — — 13⁄16” 3 —
WR9
WR502**
WR139
Compression H-Tap Connectors
Fig. 2
Main
Tap A
Tap A
Fig. 1
Main
Tap B
Main Tap A Tap B Main Tap A Tap B
ACSR Str. Sol. Str. Sol. Str. Sol. max. min. max. min. max. min.
Conductor Range Installation
Information
WR502
Mech. Hyd.
Tool Tool
Cat. No.
Con-
nector
Length
L
Con-
nector
Die
* Will accept conductors of these same wire sizes with a 3% reduction of diameter (compressed).
** This range possible only when crimped with hydraulic tool.
2
—
3
4
6
2
3
4
6
1
2
3
4
4/0
3/0
2/0
1/0
1/0
1
2
3
4
4/0
3/0
Figure
No.
1
1
1
2
4/0
3/0
2/0
1/0
1
2
3
4/0
3/0
2/0
1/0
—
8
10
8
10
12
14
8
10
8
10
8
10
12
14
6
8
10
6
8
10
6
8
10
— —
12
14
12
14
12
14
12
14
12
14
12
14
.419 .250 .162 .100 .092 .064 11⁄2” O 4 2
.563 .365 .162 .100 .092 .064 11⁄2” D — 2
5⁄8
BG
TYPE WR
TYPE WR – STREET LIGHTING COMPRESSION CONNECTORS
1
Standard Conductor* Diameter (in.) No. Indents
Compression
Connectors
ConneCtors
13
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
.528 .414 .528 .414 2.252 1.483 — — — D** D** D** D**
B,T B,T W-KB BKT B BKT BKT
5⁄8 5⁄8 W-BG U-BG U-BG
K K W-KK — — — BKT
— — — O O O O
— — — K-C C K-C K-C
— — — D** D** D** D**
CF44-1
CF22-1
CF102-1
CF202-1
CF402-1
CF4040-1
Dimensional
Information
CFS44-1
Compression H-Tap Connectors
• For tapping copper conductors to unbroken
main copper conductors
• Extruded pure electrolytic copper
• Full length tab for easy installation
• Efficient design for lower crimping force
• Standard compression tools and dies
• Single and double tab designs
• RUS listed
Cat. No.
1
Figure
No.
Standard Conductor* Diameter (in.)*
Mechanical Tools***
Hydraulic Tools***
Main Tap Main Tap
Sol. Str. Sol. Str. max. min. max. min.
Conductor Range Installation Information
“H” “H”
Connector
Type MD JB12A H
TBM15/
(min.) 1 Length
OD 58
O Series JB12B Series Y-35
Y45/Y46
4
66
4
6
8
6 .204 .162 .204 .128 .971 .729
24
66
4
6
8
8 .204 .162 .204 .128 .864 .743
4
12
4
2
44 .258 .204 .258 .204 1.162 .813
CFS22-1 4
22
4
2
66 .258 .204 .258 .162 1.017 .842
1—
1/0
1
2
2
4
6
4 .373 .292 .258 .162 1.540
1.100
CF1010-1 1—
1/0
1
2
—
1/0
1
2
.373 .292 .373 .292 1.610
1.050
1—2/0
1/0 —
2/0
1/0
1
2
.419 .368 .258 .204 1.670
1.269
1
CF2020-1 —2/0
1/0 —
2/0
1/0
1
2
.419 .368 .414 .292 1.740
1.220
1—
4/0
3/0
2/0
2
44 .528 .414 .258 .204 1.983
1.423
CF4010-1 1 —
4/0
3/0
2/0
—
1/0
1
2
.528 .414 .373 .292 1.992
1.423
1—
4/0
3/0
2/0
—
4/0
3/0
2/0
13⁄16”
B,T B,T W-KB BKT BKT BKT BKT
5⁄8 5⁄8 W-BG U-BG U-BG
K K W-KK W-KK BKT BKT BKT
— — — O O O O
— — — K-C C K-C K-C
*Decimal dimensions are for conventional conductor, not Copperweld or Alumoweld.
**Blackburn “D” dies.
***Three indents with mechanical tools and one indent with hydraulic tools. 15 ton/head use appropriate die adapters.
13⁄16”
27⁄32”
7⁄8”
11⁄8”
A
B
«H» 1 «H»
(MIN)
A
B
«H» 1 «H»
(MIN)
TYPE CF
— — — D** D** D** D**
Fig. 1
TYPE CF – COPPER COMPRESSION TAP CONNECTORS
Fig. 2
.528 .414 .528 .414 2.252
1.483
Compression
Connectors
ConneCtors
14
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Cat. Dimension
No. Capacity* Height Length Width
C2BB All5⁄8”O.D.,sleeves2”longorless 1.1 4 1.05
C5BB All“O”Dietaps,13⁄4”longorless 1.6 3.75 1.25
C7 All“D”Dietaps,21⁄2”longorless 1.8 5 1.45
C9 All “N” and “D” die taps, up to 2” long 2.75 4.25 2
C9L All “N” and “D” die taps, up to 5” long 2.75 7.25 2
CS61‡ CSC61 — 8 str. Green — 8 str. .162 .146 Green
6 sol. 6 sol.
CS62‡ CSC62 66⁄1 6 str. Blue 1 10 str. .128 .116 Brown
4 sol. 8 sol.
CS63‡ CSC63 66⁄1 6 str. Blue — 8 str. .162 .146 Green
4 sol. 6 sol.
CS64‡ CSC64 66⁄1 6 str. Blue 66⁄1 6 str. .204 .184 Blue
4 sol. 4 sol.
CS65‡ CSC65 46⁄1, 7⁄1 3-4 str. Orange — 10 str. .128 .116 Brown
2 sol. 8 sol.
CS66‡ CSC66 46⁄1, 7⁄1 3-4 str. Orange — 8 str. .162 .146 Green
2 sol. 6 sol.
CS67‡ CSC67 46⁄1, 7⁄1 3-4 str. Orange 66⁄1 6 str. .204 .184 Blue
2 sol. 4 sol.
CS68‡ CSC68 46⁄1, 7⁄1 3-4 str. Orange 46⁄1, 7⁄1 3-4 str. .258 .232 Orange
2 sol. 2 sol.
CS69‡ CSC69 26⁄1, 7⁄1 1-2 str. Red — 10 str. .128 .116 Brown
8 sol.
CS70‡ CSC70 26⁄1, 7⁄1 1-2 str. Red — 8 str. .162 .146 Green
6 sol.
CS71‡ CSC71 26⁄1, 7⁄1 1-2 str. Red 66⁄1 6 str. .204 .184 Blue
4 sol.
CS72‡ CSC72 26⁄1, 7⁄1 1-2 str. Red 46⁄1, 7⁄1 3-4 str. .258 .232 Orange
2 sol.
CS73‡ CSC73 26⁄1, 7⁄1 1-2 str. Red 26⁄1, 7⁄1 1-2 str. .328 .292 Red
CS74‡ CSC74 1/0 1/0 str. Yellow — 8 str. .162 .146 Green
6 sol.
CS75‡ CSC75 1/0 1/0 str. Yellow 66⁄1 6 str. .204 .184 Blue
4 sol.
CS76‡ CSC76 1/0 1/0 str. Yellow 46⁄1, 7⁄1 3-4 str. .258 .232 Orange
2 sol.
CS77‡ CSC77 1/0 1/0 str. Yellow 26⁄1, 7⁄1 1-2 str. .328 .292 Red
CS78‡ CSC78 1/0 1/0 str. Yellow 1/0 1/0 str. .398 .368 Yellow
CS84‡ CSC84 — 2/0 str. Grey 1/0 1/0 str. .398 .368 Yellow
CS85‡ CSC85 — 2/0 str. Grey — 2/0 str. .414 .414 Grey
.162 .146
Cat. No.
Color
Code
Bare
Sleeve ASCR AWG max. min. ASCR AWG max. min.
Conductor Range
Diameter (in.)
Conductor Range
Diameter (in.)
Sleeve
With
Cover
Compression H-Tap & Service Entrance Connectors
.204 .184
.258 .232
.398 .368
.414 .414
.328 .292
End “A” End “B”
Color
Code
‡ RUS Listed.
• Hinged polyethylene cover
• Installs easily, quickly and is less expensive
than taping
• Positive snap-locks fasten securely
• Drain ports prevent accumulation of
corrosion-causing moisture
• Ultra-violet stabilized
• For combinations of alumi-
num-aluminum and alumi-
num-copper conductors
• Pass the requirements of
ANSI C119.4
• Sleeves are made of highly
conductive aluminum
• Quick identification with
color-coded foil caps
• Install with standard
compression dies
TYPE C
TYPE C – COMPRESSION CONNECTOR COVERS
TYPE CS & CSC – SERVICE ENTRANCE SLEEVES 5/8 DIE
TYPE CS & CSC
*Before compression.
INSTALLATION INFORMATION
Cat. No. Mech. Hyd.
All 5⁄8 (OD58 Tool) Peach, U-BG
BG, G, TU B58CS, 52
Installation Dies
Compression
Connectors
ConneCtors
15
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
KL20-1 6 str. .184 .167 Blue 6 str. .184 .167 Blue
6 str. compact 6 str. compact
KL22-1 4 str. .232 .211 Orange 4 str. .232 .167 Orange
4 str. compact 4 str. compact
2 str. 2 str.
KL25-1 2 str. compact .292 .266 Red 2 str. compact .292 .266 Red
1/0 sol. Al, 1 str. 1/0 sol. Al, 1 str.
KL31-1 2 ACSR, .336 .316 Red 1 str. compact .336 .316 Red
1/0 str. comp 2 ACSR
1/0 ACSR 1/0 ACSR
KL36-1 1/0 str. .398 .368 Yellow 1/0 str. .398 .368 Yellow
2/0 str. compact 2/0 str. compact
KL45-1 2 ACSR, 1–2 str. .328 .292 Red
1 str. compact
KL46-1 1/0 ACSR, 1/0 str. .398 .368 Yellow
2/0 str. compact
KL47-1 2/0 ACSR, 2/0 str. .448 .414 Gray
3/0 str. compact
KL54-1 4 ACSR, 3– 4 str. .258 .232 Orange
2 sol.
KL55-1 2 ACSR, 1–2 str. .328 .268 Red
1 str. compact
KL56-1 1/0 ACSR, 1/0 str. .398 .368 Yellow
2/0 str. compact
KL57-1 2/0 ACSR, 2/0 str. .448 .414 Gray
3/0 str. compact
KL58-1 3/0 ACSR, 3/0 str. .502 .464 Black
4/0 str. compact
KL64-1 4 ACSR, 3– 4 str. .258 .232 Orange
2 sol.
KL65-1 2 ACSR, 1–2 str. .328 .268 Red
1 str. compact
KL66-1 1/0 ACSR, 1/0 str. .398 .368 Yellow
2/0 str. compact
KL67-1 2/0 ACSR, 2/0 str. .448 .414 Gray
3/0 str. compact
KL68-1 3/0 ACSR, 3/0 str. .502 .464 Black
4/0 str. compact
KL69-1 4/0 ACSR, 4/0 str. .563 .522 Pink
Service Entrance Connectors
• For combinations of aluminum-aluminum
and aluminum-copper conductors
• Pass the requirements of ANSI C119.4
• Splices large conductors required for
commercial service; use as low cost
reducing sleeve
• All sizes can be installed with popular
mechanical and hydraulic tools
• Center stop assures proper conductor
positioning
• Quick identification with color-coded foil
caps
max. min. max. min.
Conductor Range
Diameter (in.)
Conductor Range
Diameter (in.)
Cat. No.
End “A” End “B”
Color
Code
Color
Code
2/0 ASCR
2/0 str. .448 .414 Gray
3/0 str. compact
3/0 ASCR
3/0 str. .502 .464 Black
4/0 str. compact
4/0 ASCR
4/0 str. .563 .522 Pink
INSTALLATION INFORMATION
Cat. No. Mech. Hyd.
All 840, W-K840 840, U-K840
EEI-11A, TX U-249, B49EA
Installation Dies
TYPE KL – LARGE COMPRESSION SERVICE ENTRANCE SLEEVES, 840 DIE
TYPE KL
Compression
Connectors
ConneCtors
16
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
ICS61-1 — 8 str. .162 .144 Green
6 sol.
ICS62-1 — 10 str. .128 .114 Brown
8 sol.
ICS63-1 — 8 str. .162 .144 Green
6 sol.
ICS64-1 6 6 str. .204 .184 Blue
4 sol.
ICS65-1 — 10 str. .128 .114 Brown
8 sol.
ICS66-1 — 8 str. .162 .144 Green
6 sol.
ICS67-1 6 6 str. .204 .184 Blue
4 sol.-
ICS68-1 4 3-4 str. .258 .213 Orange
2 sol.
ICS70-1 — 8 str. .162 .144 Green
6 sol.
ICS71-1 6 6 str. .204 .184 Blue
4 sol.
ICS72-1 4 3-4 str. .258 .213 Orange
2 sol.
ICS73-1 2 1-2 str. .328 .268 Red
ICS74-1 — 8 str. .162 .146 Green
6 sol.
ICS75-1 6 6 st .204 .184 Blue
4 sol.
ICS76-1 4 3-4 str. .258 .213 Orange
2 sol.
ICS77-1 2 1-2 str. .328 .268 Red
ICS78-1 — 1/0 str. .398 .368 Yellow
— 8 str. .162 .144 Green
6 sol.
Service Entrance Connectors
ASCR AWR max. min. ASCR AWR max. min.
Conductor Range
Diameter (in.)
Conductor Range
Diameter (in.)
Cat. No.
End “A” End “B”
Color
Code
Color
Code
6 6 str. .204 .184 Blue
4 sol.
4 3-4 str. .258 .213 Orange
2 sol.
2 1-2 str. .328 .268 Red
1/0 1/0 .398 .368 Yellow
• Pre-insulated for fast, easy installation with
standard tools
• For combinations of aluminum and
aluminum-copper conductors
• Pass the requirements of ANSI C119.4
• Overall length 2-3/4”
TYPE ICS
INSTALLATION INFORMATION
Cat. No. Mech. Hyd.
All 5⁄8(OD58Tool)Peach, U-BG
BG, W-BG, G, TU B58CS
Installation Dies
All are RUS Listed.
TYPE ICS – SERVICE ENTRANCE SLEEVES 5/8 DIE
2-3/4”
Compression
Connectors
ConneCtors
17
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
IKL34 4 ACSR .258 .213 Orange
3–4 str., 2 sol.
IKL35 2 ACSR .328 .268 Red
1– 2 str.
1/0 ACSR
IKL36 1/0 str. .398 .365 Yellow
2/0 str. comp
IKL44 4 ACSR .258 .213 Orange
3–4 str., 2 sol.
IKL45 2 ACSR .328 .268 Red
1–2 str.
1/0 ACSR
IKL46 1/0 str. .398 .365 Yellow
2/0 str. comp
2/0 ACSR
IKL47 2/0 str. .448 .414 Grey
3/0 str. comp
IKL54 4 ACSR .258 .213 Orange
3–4 str., 2 sol.
IKL55 2 ACSR .328 .268 Red
1– 2 str.
1/0 ACSR
IKL56 1/0 str. .398 .365 Yellow
2/0 str. comp
2/0 ACSR
IKL57 2/0 str. .448 .414 Grey
3/0 str. comp
3/0 ACSR
IKL58 3/0 str. .502 .464 Black
4/0 str. comp
IKL64 4 ACSR .258 .213 Orange
3–4 str., 2 sol.
IKL65 2 ACSR .328 .268 Red
1– 2 str.
IKL66 1/0 ACSR .398 .365 Yellow
1/0 str.
2/0 ACSR
IKL67 2/0 str. .448 .414 Grey
3/0 str. comp
3/0 ACSR
IKL68 3/0 str. .502 .464 Black
4/0 str. comp
IKL69 4/0 ACSR .564 .522 Pink
4/0 str.
Service Entrance Connector
• For combinations of aluminum-aluminum
and aluminum-copper conductors
• Pass the requirements of ANSI C119.4
• Use as a low tension reducing sleeve for
insulated conductor
• Pre-insulated for fast, easy installation of
large home or commercial service entrances
• Concave polyethylene end caps seal out
dirt, but are easily pierced when inserting
conductor
max. min. max. min.
Conductor Range
Diameter (in.)
Conductor Range
Diameter (in.)
Cat. No.
End “A” End “B”
Color
Code
Color
Code
1/0 ASCR
2/0 str. .398 .365 Yellow
1/0 str.
(compact)
2/0 ASCR
2/0 str. .448 .414 Grey
3/0 str.
(compact)
3/0 ASCR
3/0 str. .502 .464 Black
4/0 str.
(compact)
4/0 ACSR .564 .522 Pink
4/0 str.
INSTALLATION INFORMATION
Cat. No. Mech. Hyd.
All BY37, 840 B49EA, 840
W-K840, TX U-K840, U-249
Installation Dies
All are RUS Listed.
TYPE IKL – INSULATED SERVICE ENTRANCE SLEEVES 840 DIE
TYPE IKL
Compression
Connectors
ConneCtors
18
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
RS253 300-250 MCM .630-.574 4/0 .528
RS2525 300-250 MCM .630-.574 300-250 MCM .630-.574
RS403 400-336 MCM .726-.666 4/0 .528
RS4040 400-336 MCM .726-.666 400-336 MCM .726-.666
RS4525 500-450 MCM .813-.770 300-250 MCM .630-.574
RS4545 500-450 MCM .813-.770 500-450 MCM .813-.770
RS8080 800-750 MCM 1.029-.997 800-750 MCM 1.029-.997
Conductor Range
Conductor Diameter* Cap
Cat. No. ACSR AWG max. min. Color Length
TR61 6 6 str. .204 .184 Blue 41⁄4”
4 sol.
TR63 4 4 str. .258 .232 Orange 41⁄4”
2 sol.
TR64 2 2 str. .316 .292 Red 41⁄4”
TR65 1 1/0 str. .373 .355 Yellow 6”
TR66 1/0 — .398 .373 Yellow 6”
Service Entrance Connector
• Non tension splice frequently used for
service entrance on commercial-industrial
loads
• For end-to-end splicing of aluminum to cop-
per conductor, #4/0 str. through 1000 MCM
• Prefilled with oxide inhibitor
• Passes the requirements of ANSI C119.4
*Decimal dimensions are for conventional conductor, not Copperweld or Alumoweld.
max.-min. max.-min. max.-min. max.-min.
Conductor Range
Diameter (in.)
Conductor Range
Diameter (in.)
Cat. No. End “A” End “B”
Installation
Dies
Hydraulic
Tool
Length
6”
8”
B20AH
318
15⁄16
6030AH
352
TYPE TR
TYPE TR – TRIPLEX NEUTRAL SPLICE, SEMI-TENSION, 5/8 DIE
TYPE RS
TYPE RS – ALUMINUM COMPRESSION SPLICE
Cat. No. Installation Dies
All 5⁄8,Peach,G,TU
INSTALLATION INFORMATION
71⁄2”
Compression
Connectors
ConneCtors
19
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Distribution Compression Connectors
• Meets the 40% partial tension
requirement of ANSI C119.4
TYPE ACJ
Mechanical Tools Hydraulic Tools
OD58* MD Series O-52 JB12B Y Series WH Series
Crimps Crimps Crimps Dies Crimps Crimps Crimps EEI
Conductor per Die per per Cat. per Die per Die per Classi-
Cat. No. (Stranding) Lgth. Dies End Index End Dies End Nos. End Index End Index End fication
ACJ20 2/0(7,19) 4-3⁄4” BY33 8 C-167 8 737 8 B39EA 2 247 2 737 4 10A
W-247 4 747 4
ACJ205 2/0(7,19) 4-3⁄4” BY41 4 W-245 4 635 4 B30EA 2 245 2 5⁄8–1 4 9A
635 2
ACJ40 4/0(7,19) 4-3⁄4” BY37 8 W-249 4 840 8 B49EA 2 249 2 840 4 11A
ACJ266 266.8(7,19) 5-3⁄8” — — — — — — B75AH 3 251 3 11⁄2 3 —
ACJ336 336.4(19,37) 5-3⁄8” — — — — — — B80EA 3 321 3 1-1⁄8–1 3 13A
ACJ350 350(19) 6-3⁄4” — — — — — — B80EA 5 490 5 1-1⁄8–1 5 13A
547
ACJ397 397.5(19) 6-3⁄4” — — — — — — B80EA 4 468 4 1-1⁄8–1 4 13A
ACJ477 477, 500 9-1⁄2” — — — — — — B80EA 6 317 6 1-1⁄8–1 6 13A
(19, 37) 426
ACJ556 556.5(19,37) 9-9⁄16” — — — — — — B76AH 8 318 9 1-1⁄8–1 11 —
*OD58 dies are interchangeable with those listed for 0-52.
TYPE ACJ – ALUMINUM JUMPER SLEEVES FOR ALL ALUMINUM CONDUCTOR
Compression
Connectors
ConneCtors
20
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Mechanical Tools Hydraulic Tools
OD58* MD Series O-52 JB12B Y Series WH Series
Crimps Crimps Crimps Dies Crimps Crimps Crimps EEI
Conductor per Die per per Cat. per Die per Die per
Classi-
Cat. No. (Stranding) Lgth. Dies End Index End Dies End Nos. End Index End Index End
fication
1/0 ACSR(6⁄1)
737 12 W-C 12 737 12
167 6 737 6
1/0 AAAC(7) 61⁄2”
747 6 W-702 4 747 6
B39EA 3
247 3 747 3
10A
RCJ10‡ 1/0 5005(7)
1/0 AAC(7)
2/0 ACSR(6⁄1)
RCJ20‡ 2/0 AAAC(7) 63⁄4” 781 13 — — 781 13 B74AH 3 659 3 3⁄4 3 —
2/0 5005(7)
2/0 AAC(7)
3/0 ACSR(6⁄1)
RCJ30‡ 3/0 AAAC(7) 61⁄4” — — — — — — B49EA 3 658 3 29⁄32 3 11A
3/0 5005(7)
3/0 AAC(7)
4/0 ACSR(6⁄1)
4/0 AAAC(7) 63⁄4” — — — — — — B61EA 3 654 3 1.00 3 12A
RCJ40BB‡ 4/0 5005(7)
4/0 AAC(7)
RCJ266‡ 266.8 ACSR(18⁄1) 7” — — — — — — B80EA 3 655 3 11⁄8–1 3 13A
RCJ336‡ 336.4 ACSR(18⁄1) 7” — — — — — — B80EA 3 655 3 11⁄8–1 3 13A
397.5 ACSR(18⁄1)
RCJ397 336.4(26-7) 71⁄4” — — — — — — B20AH 4 327 4 11⁄8–1 4 14A
336.4(30-7)
RCJ477 477 ACSR(18⁄1) 8 3⁄4” — — — — — — B20AH 5 318 5 15⁄16 5 14A
RCJ477M 477 ACSR(26⁄7) 9” — — — — — — B76AH 5 318 8 11⁄8 6 —
* OD58 dies are interchangeable with those listed for O-52.
‡ RUS Listed.
Distribution Compression Connectors
• Meets the 40% partial tension requirement of
ANSI C119.4
TYPE RCJ
TYPE RCJ – ALUMINUM JUMPER SLEEVES FOR ACSR, AAAC, 5005, AAC CONDUCTOR
Compression
Connectors
ConneCtors
21
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Mechanical Tools Hydraulic Tools
OD58* MD Series O-52 JB12B Y Series WH Series
Crimps Crimps Crimps Dies Crimps Crimps Crimps EEI
Conductor per Die per per Cat. per Die per Die per
Classi-
Cat. No. (Stranding) Lgth. Dies End Index End Dies End Nos. End Index End Index End
fication
AC6-TB 6(7) 3” BY19 4 W-161 2 5⁄16 4 B73SH 1 161 1 5⁄16 3 —
AC4-BB 4(7) 3” BY21 4 W-162 4 3⁄8 4 B71AH 1 162 1 3⁄8 3 —
AC2-TB 2(7) 41⁄8” BY23 6 W-163 6 1⁄2 6 B17EA 2 163 2 1⁄2 4 6A
510 3
1/0 BG 12 5⁄8–1 6
AC10-TB
(7, 19) 71⁄4” BY31 12 W-243 12
5⁄8–1 12 B24EA 3 243 3 635 3 8A
W-687 6
AC20 2/0 91⁄4” BY33 16 C-167 16 737 16 B39EA 4 247 4 737 8 10A
(7, 19) W-247 8 747 4
AC205 2/0 91⁄4” BY41 8 W-245 8 635 8 B30EA 4 245 4 635 4 9A
(7, 19)
AC30 3/0 8” BY35 16 W-247 8 781 16 B74AH 4 247 4 781 8 —
(7, 19)
AC40 4/0 91⁄2” BY37 12 W-249 12 840 12 B49EA 6 249 6 840 12 11A
(7, 19)
AC266 266.8 85⁄8” — — — — — — B75AH 7 251 7 1.00 7 —
(7, 19)
AC336 336.4 10” — — — — — — B80EA 8 321 8 11⁄8–1 8 13A
(19, 37)
AC350 350 11” — — — — — — B80EA 9 490 9 11⁄8–1 9 13A
(19) 547 9
AC397 397.5 121⁄8” — — — — — — B80EA 8 468 8 11⁄8–1 8 13A
(19)
AC477 477 131⁄2” — — — — — — B80EA 9 317 9 11⁄8–1 9 13A
(19, 37) 426 9
AC556 556 131⁄2” — — — — — — B76AH 9 318 13 15⁄16 16 —
(19, 37)
* OD58 dies are interchangeable with those listed for O-52.
TYPE AC
Distribution Compression Connectors
• Center stop assures proper conductor
positioning
• External end taper provides conductor
stress relief, ease of stringing and corona
protection
• Internal end chamfer allows easy conductor
insertion and prevents sharp edge contact
with conductor
• Fully tested to meet electrical and
mechanical requirements of ANSI C119.4;
will withstand 95% of conductor rated
breaking strength
TYPE AC – SINGLE SLEEVE, FULL TENSION SPLICE FOR ALL ALUMINUM CONDUCTOR
Compression
Connectors
ConneCtors
22
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Distribution Compression Connectors
• Center stop assures proper conductor
positioning
• Replaces two-piece splices
• External end taper provides conductor stress
relief, ease of stringing and corona
protection
• Internal end chamfer allows easy conductor
insertion and prevents sharp edge contact
with conductor
• Tested to meet electrical and mechanical
requirements of ANSI C119.4; will withstand
95% of conductor rated breaking strength
TYPE RC
TYPE RC – SINGLE SLEEVE, FULL TENSION SPLICE, FOR ACSR, AAAC, 5005, AAC CONDUCTOR
Mechanical Tools Hydraulic Tools
OD58* MD Series O-52 JB12B Y Series WH Series
Crimps Crimps Crimps Dies Crimps Crimps Crimps EEI
Conductor per Die per per Cat. per Die per Die per
Classi-
Cat. No. (Stranding) Lgth. Dies End Index End Dies End Nos. End Index End Index End
fication
4ACSR(6⁄1,7⁄1)
4AAAC(7) 12” 1⁄2 24 W-163 24 1⁄2 24 B72AH 6 163 6 1⁄2 12 —
RC4BB‡
4 5005(7) 510 6
4AAC(7)
4ACSR(6⁄1,7⁄1) BG 24
RC45‡ 4AAAC(7) 12” 5⁄8–1 24 W-BG 24 5⁄8–1 24 B24EA 6 243 6 5⁄8–1 12 8A
4 5005(7) 635 12 W-243 12 635 12 687 6 635 6
4AAC(7)
2ACSR(6⁄1,7⁄1)
2AAAC(7) 13 5⁄8” 5⁄8–1 28 BG 28 5⁄8–1 28 B24EA 7 245 7 5⁄8–1 14 9A
RC2BB‡
2 5005(7) 635 14 W-245 14 635 14 B30EA 687 7 635 7
2AAC(7)
2ACSR(6⁄1,7⁄1) W-C 28 167 14
RC25‡ 2AAAC(7) 13 5⁄8” 737 28 W-247 28 737 28 B39EA 7 247 14 737 14 10A
2 5005(7) 747 14 W-702 14 747 14 702 7 747 7
2AAC(7)
1/0 ACSR(6⁄1) 167 8
RC10‡ 1/0 AAAC(7) 151⁄4” 737 32 W-C 32 737 32 B39EA 8 247 8 737 16 10A
1/0 5005(7) 747 16 W-702 16 747 16 702 8
1/0 AAC(7)
RC205‡ 2/0 ACSR (6⁄1) 17” 737 36 W-702 18 737 36 B39EA 9 247 9 — — 10A
747 18 747 18
2/0 ACSR(6⁄1)
RC20‡ 2/0 AAAC(7) 16” 781 32 — — 781 32 B74AH Overlap 659 Overlap 3⁄4 Overlap —
2/0 5005(7)
2/0 AAC(7)
3/0 ACSR(6⁄1)
RC30‡ 3/0 AAAC(7) 17” — — — — — — B49EA Overlap 658 Overlap 29⁄32 Overlap 11A
3/0 5005(7)
3/0 AAC(7)
4/0 ACSR(6⁄1)
RC40‡ 4/0 AAAC(7) 181⁄2” — — — — — — B61EA Overlap 654 Overlap 1.00 12A
4/0 5005(7) 1–2 Overlap
4/0 AAC(7)
RC336 336.4 ACSR(18⁄1) 191⁄4” — — — — — — B80EA Overlap 655 Overlap 11⁄8–1 Overlap 13A
11⁄8–2
RC397 397.5 ACSR(18⁄1) 211⁄2” — — — — — — B20AH Overlap 327 Overlap 11⁄8–1 Overlap 14A
11⁄8–2
RC477 477 ACSR(18⁄1) 24” — — — — — — B78AH Overlap 788 Overlap 15⁄16 Overlap —
‡ RUS Listed
*OD58 dies are interchangeable with those listed for O-52.
Compression
Connectors
ConneCtors
23
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Range Installation Dies
Aluminum Copper Pigtail Mechanical Hydraulic
Cat. No. ACSR Str. Compact Solid Diameter Length Tool Tool
PCS64 6 6 4
PCS67 4 4 2
PCS71 2 1–2
PCS76
PKL36-1
PKL46-1 2/0 2/0
PKL56-1 3/0 3/0
PKL66-1 4/0 4/0 .365
PKL31-1 1 1, 1/0 1/0 .325
PKL365-1 1/0 1/0, 2/0 2/0
PKL46S-1 2/0 3/0
PKL58-1 3/0 4/0
PKL68-1 4/0 250 KCMIL
PRS25N 266 26⁄7
250-300 MCM
PRS30N
26626⁄7, 36618⁄1
300-350 MCM
33630⁄7,26⁄7,18⁄1,
PRS35N 397 18⁄1
336-400 MCM
PRS40N
39718⁄1, 47718⁄1
450-500 MCM
Mechanical Tools Hydraulic Tools
OD58 MD Series O-52 JB12B Y Series WH Series
Crimps Crimps Crimps Dies Crimps Crimps Crimps
Conductor per Die per per Cat. per Die per Die per
Cat. No. (Stranding) Lgth. Dies End Index End Dies End Nos. End Index End Index End
CTS8 8 sol. 2 J 3 J 3 161 3 — — — — — —
5⁄16 4 5⁄16 4
CTS6 6 sol. 21⁄2 J 4 J 4 161 4 — — — — — —
5⁄16 5 5⁄16 5
CTS4 4 sol. 23⁄4 P 5 P 5 162 5 — — — — — —
CTS27 2–7 str. 31⁄4 1⁄2 6 1⁄2 6 163 5 — — — — — —
CTS407 4/0 str. 71⁄4 — — — — — — — — 168 9 840 9
CTS6ACW* 6 ACW 51⁄2 P 10 P 10 162 10 — — — — — —
* For Copperweld conductor applications only
Distribution Compression Connectors
• Designed for use in joining
aluminum secondaries and
services to copper transformer
bushings
• Sleeves are highly conductive
aluminum
• Pigtails are solid copper, tin
plated
• Installed with standard tools
and dies
• Prefilled with oxide inhibitor
—
—
—
—
1/0 1/0
—
.204
.258
.325
.366
.500
.625
21⁄2
6
61⁄4
41⁄2
8
Peach
5⁄8
BG
TU
U-BG
52
840
K840
TX
—
—
840
B48EA
EEI 11A
K840,
U249
76
B80EA,
CSA 26,
96H,
EEI 13A
655, 11⁄8
B20AH,
CSA28,
EEI 14A,
318, 1064,
15⁄16
• Meets the full tension requirements of
ANSI C119.4
TYPE CTS
TYPE PCS
TYPES PCS, PKL AND PRS – PIGTAIL COMPRESSION SLEEVES
TYPE CTS – COPPER FULL TENSION SPLICE FOR SOLID, STRANDED AND COPPERWELD CONDUCTOR
Compression
Connectors
ConneCtors
24
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Cat. No. Conductor Range Installation Dies Dimensions
Diameter (in.)
2 Hole 1 Hole Mech. Hyd. T (Pad
(Fig. 1) (Fig. 2) Tool Tool W L Thickness)
AL4 2 1–2 — .316 .332 57⁄8 5⁄16
AL5 47⁄8
AL6 65⁄8
AL7 47⁄8
AL8 65⁄8
AL9 47⁄8
AL10 65⁄8-
AL11 47⁄8
AL12 65⁄8
AL16 26626⁄7, 6⁄7, 18⁄1 250–300 — .574 .679 11⁄2 7⁄16
AL18 266 26⁄7, 6⁄7, 18⁄1 300–350 450
KCMIL
.609 .772 19⁄16 13⁄32
33618⁄1
AL20 33630⁄7, 26⁄7, 18⁄1 336– 400 500
KCMIL
.666 .813 19⁄16 3⁄8
39718⁄1
AL24 397 30⁄7, 26⁄7, 18⁄1 450–500 600
KCMIL
.770 .893
47718⁄1
AL28 477 30⁄7, 26⁄7, 24⁄7 550 & 556 — .846 .964
55618⁄1
AL32 556 26⁄7, 24⁄7 600 & 636 750
KCMIL
.891 .990
63618⁄1
AL44 63626⁄7, 71554⁄7 750–800 — .990 1.031
66624⁄7
AL60* 90054⁄7 1000–1033 — 1.151 1.165
95445⁄7
AWG
ACSR (Stranded) Compact min. max.
1/0 1/0 2/0 .368 .398
2/0 2/0 3/0 .414 .447
3/0 3/0 4/0 .464 .502
4/0 4/0 — .522 .563
840
K840
845
TX
840
B49EA
EEI, 11A
K840
249
76
CSA 24
—
B80EA
EEI 13A
655
11⁄8
96H
CSA 26
106H
CSA 28
B20AH
EEI 14A
318
15⁄16
11⁄2
6024AH
125H
301
CSA 30
—
—
11⁄4
15⁄16
15⁄8
75⁄8
81⁄8
91⁄8
13⁄32
11⁄32
5⁄16
9⁄32
1⁄2
* For aluminum conductor only.
Distribution Compression Connectors
• Extended barrel for additional crimping area
or weatherseal for outdoor terminators
• For aluminum and copper conductor
• NEMA Standard mounting holes
• Prefilled with oxide inhibitor
• Complete die and crimp information clearly
indented on each lug
• Installed with standard tools and dies
• Use 1/2” mounting hardware for all sizes
• Available tin plated; add suffix P to
catalog number
TYPE AL
TYPE AL – ALUMINUM COMPRESSION TERMINAL LUGS
Fig. 1 Fig. 2
Compression
Connectors
ConneCtors
25
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Fig. 1 Fig. 2
Cat. No. Conductor Range Installation Dies Dimensions
Diameter (in.)
T (Pad
2 Hole 1 Hole Mech. Hyd.
Thick-
(Fig. 1) (Fig. 2) Tool Tool W L
ness)
AL581 2 37⁄64
AL582 4 37⁄64
AL583 2 37⁄64
AL584 4 37⁄64
AL585 2 37⁄64
AL586 4 37⁄64
ALS1 29⁄32 31⁄4
ALS2 11⁄4 5 3⁄4
ALS3 29⁄32 31⁄4
ALS4 11⁄4 5 3⁄4
ALS5 29⁄32 31⁄4
ALS6 11⁄4 5 3⁄4
ALS7 29⁄32 31⁄4
ALS8 11⁄4 5 3⁄4
ALS9 29⁄32 31⁄4
ALS10 11⁄4 5 3⁄4
ALS11 29⁄32 31⁄4
ALS12 11⁄4 5 3⁄4
ALS13 45⁄8
ALS14 6
ALS15 45⁄8
ALS16 6
ALS17 45⁄8
ALS18 6
ALS19 45⁄8
ALS20 6
ALS23 59⁄16
ALS24
ALS28 47730⁄7, 26⁄7, 24⁄7 550–556 650–700 .883 .846
55618⁄1
ALS32 55626⁄7, 26⁄7 600–636 750 .940 .891
63618⁄1
ALS44 63626⁄7, 71554⁄7 750–800 900 1.031 .990
66626⁄7, 54⁄7
ALS60* 900 54⁄7 1000–1033 1033 1.172 1.151
954 45⁄7
Distribution Compression Connectors
AWG
ACSR (Stranded) Compact min. max.
4 4 — .277 .213
2 2 — .344 .290
1/0 1/0 2/0 .422 .381
4 4 4 .258 .232
2 Solid
5⁄8
Peach
BG
WBG
G
TU
B58CS
U-BG
840
K840
845
TX
840
B49EA
EEI 11A
K840
249
76
CSA24
B80EA
EEI 13A
655
11⁄8
321
96H
CSA 26
11⁄2
6024
125H
CSA 30
—
—
29⁄32
11⁄4
67⁄8
15⁄8
13⁄8
71⁄4
1⁄4
5⁄8
3⁄8
• For aluminum and copper conductor.
• NEMA Standard mounting holes
• Prefilled with oxide inhibitor
• Complete die and crimp information clearly
indented on each lug
• Installed with standard tools and dies
• Use 1/2” mounting hardware for all sizes
• Available tin plated; add suffix P to
catalog number
* For aluminum conductor only.
2 1–2 1–2 .332 .316
1/0 1/0 2/0 .398 .368
2/0 2/0 3/0 .447 .414
3/0 3/0 4/0 .502 .464
4/0 4/0 — .563 .522
3/0, 4/0 3/0, 4/0 250 .575 .464
250
KCMIL
300
KCMIL
26626⁄7, 6⁄7, 18⁄1 250–300 350 .633 .574
KCMIL
26626⁄7, 6⁄7, 18⁄1 300–350 350–400 .684 .609
33618⁄1
336 30⁄7, 26⁄7, 18⁄1 336–400 450–500 .743 .666
39718⁄1
397 30⁄7, 26⁄7, 18⁄1 450–500 550–600 .814 .743
47718⁄1
—
B20AH
EEI 14A
318
15⁄16
CSA 28
106H
TYPE ALS
TYPE ALS – ALUMINUM COMPRESSION TERMINAL LUGS
9⁄16
Compression
Connectors
ConneCtors
26
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Cat. No. Conductor Range Dimensions
Diameter (in.)* Copper Installation Dies Type WRS
Figure 1 Figure 2 ACSR AWG max. min. Bail Mech. Hyd. L H1
WRQ154 WRS154 4 sol.
WRQ152 WRS152 2 sol.
WRQ172 WRS172 1/0–3 1/0 str.–1 sol. .398 .281 2 sol.
WRQ232 WRS232 2/0–1/0 2/0 str.–1/0 str. .447 .368 2 sol.
WRQ352 WRS352 4/0–3/0 4/0 str.–3/0 str. .563 .460 2 sol.
— WRS719 39718⁄1-266 400 str.–250 str. .743 .600 2/0 sol.
— WRS819 47726⁄7-336 500 str.–336 str. .858 .666 2/0 sol.
WRQ698 — 47726⁄7-266 500 str.–250 str. .858 .574 2 sol.
2–6 1 str.–6 sol. .332 .162
10” 215⁄16
121⁄4”33⁄16”
* Decimal dimensions are for conventional conductor, not Copperweld or Alumoweld.
Compression Stirrup Connectors
• For protection of main conductors from
arcing damage when hot line taps are
installed
• Utilizes standard WR connectors and plated
copper bails
Fig. 2
Fig. 1
TYPES WRQ & WRS
—
N
DD
OO
TYPES WRQ AND WRS – WIDE RANGE COMPRESSION STIRRUPS
Compression
Connectors
ConneCtors
27
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Range Bail
Cat. No. Diameter (Tin Plated) Installation Dies
Dimensions (in.)
Fig. 1 Fig. 2 ACSR AWG Alum. (in.) mm Size Diameter (mm) Mech. Hyd. L H
QCO 02 SCO 02 2-6 2 str.–6 sol. .325-.162 8.25-.412 #2 solid 6.35 O O 8 3⁄4 31⁄8
QCO 21 SCO 21 2/0-2 2/0 str.–2 str. .414-.292 10.51-7.41 #2 solid 6.35 O O 83⁄4 31⁄8
QCD 41 SCD 41 4/0-3/0 4/0 str.–3/0 str. .563-.464 14.29-10.51 #2 solid 6.35 D — 83⁄4 31⁄8
QCN 50 SCN 50 47718⁄1-4/0 500–4/0 str. .814-.528 20.66-13.40 1/0 solid 6.22 — N 11 311⁄16
Cat. No. Ball Wire Size Mech. Hyd.
7019 #2solidcopper 10” 2-15⁄16”
7020 2/0solidcopper 12-1⁄4” 3-3⁄16”
7030 #2solidcopper 4-1⁄2” 3-3⁄4”
7030C #2solidcopper 4-1⁄2” 3-3⁄4”
Compression Stirrup Connectors
• Aluminum connector elements are designed
to be pre-loaded for faster installation into
popular “hot stick” tools and compressed
using standard “O,” “D” and “N” dies
• Connectors are prefilled with inhibitor
compound
• Wide range–only 4 sizes cover #6 solid to
500 KCMIL stranded
• Tin plated bail for lower contact
resistance
• Knurled to resist rotation
Fig. 2
Fig. 1
• Tin plated for lower contact resistance
• Knurled to resist rotation
7019
7020
7030
7030C
TYPE SC & QC
PLATED COPPER BAIL
Dimensions
TYPES SC AND QC – WIDE RANGE COMPRESSION STIRRUPS
PLATED COPPER BAIL
Compression
Connectors
ConneCtors
28
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
TYPE LP
Compression Stirrup Connectors
• Covers and protects conductor from arcing
when line clamp is attached or disconnected
• Single-piece stirrup for large conductor
• Use U or 6024 Installation Die
Conductor Range
Diameter Copper Bail
Cat. No. max.-min. max.-min. (Tin Plated)
CCS44 800—636 str. 1.032—.918 2/0 sol.
TYPE CCS
TYPE CCS – COMPRESSION STIRRUP
Conductor Range
Diameter Dimensions Installation
Cat.No. ACSR AWG max. min. L Dies
LP4 4 4 .257 .232
LP2 2 2 .316 .292
LP10 1/0 1/0 .398 .373 0
8”
5⁄8, Peach
BG, G
TYPE LP – COMPRESSION LINE PROTECTOR SLEEVE
13-3/4”
4”
5”
L”
4”
11/16”
Hot line clamp bearing surface: 11/16” dia. x 4” length
ConneCtors
29
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Automatic Connectors
and Wedge Clamps
Type ATS
Automatic Splices
Page 30
Type ATD-ZB
Stainless Steel Bail
Page 31
Type ATD-CB
Clevis Bracket
Page 32
Type ATD-FB
Flexible Bail
Page 32
Type W
Wedge Clamp
Page 35
Guystrand
ATDG
Page 33
Guystrand
ATSG
Page 34
Product Overview
Automatic Connectors
and Wedge Clamps
ConneCtors
30
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Automatic Splices for Aluminum
• Color-coded end pieces provide
instant visual identification of maxi-
mum conductor size. A separate,
color-coded tape identifies the mini-
mum conductor size of wide range
connectors to further eliminate errors
and save installation time.
• The funnel-shaped end piece swiftly
guides conductor into position for
insertion.
• A pilot cup envelopes strands and
guides the conductor past the ser-
rated jaws and into the center of the
splice.
• Die-cast precision made jaw provides
optimum contact area for a greater
range of conductor sizes. No other
jaw design forms point-to-point con-
tact with such tenacity to give you a
better fit over a range of conductor
diameters which reduces your inven-
tory stocking requirements.
• Compression spring positions the
unique jaw for positive conductor
acceptance.
• Tubular center stop automatically
determines proper insertion length of
both conductors.
• High strength, aluminum alloy tubing
covers the connection for superior
corrosion protection and lasting ser-
vice life.
• Packaged in plastic bags to repel dirt
and debris. Instructions, printed on
each bag, save time and further elimi-
nate the potential for errors during
installation.
Blackburn automatic connectors make fast
and dependable overhead tension splices that
take a bite out of installation time.
Conductor simply slips into the color-
coded, funnel-shaped end piece and automati-
cally enters the pilot cup with a gentle push.
The pilot cup guides the conductor past the
unique serrated jaws and into the center of
the connector.
When the conductor meets the center stop,
the pull-back locks it into position as the jaws
firmly clamp down…the more pull, the more
bite…to provide an instant, positive and auto-
matic connection.
TYPE ATS
Conductor Range Decimal Overall
Cat. No. ACSR AAAC AAC Range Color Code Length
ATS4-S 46⁄1, 7⁄1 4 4 .232 -.260 4 - Orange 11.50”
ATS4 46⁄1, 7⁄1 4 4 .232 -.260 4 - Orange 13.75”
ATS42 46⁄1, 7⁄1 4–2 4–2 .232 -.332 4 - Orange 13.75”
26⁄1, 7⁄1 2 - Red
ATS2 26⁄1, 7⁄1 2 2 .292 -.332 2 - Red 13.75”
ATS10 1/06⁄1 1/0 1/0 .368 -.410 1/0 - Yellow 16.25”
ATS1020 1/06⁄1 1/0–2/0 1/0–2/0 .368 -.461 1/0 - Yellow 16.25”
2/07⁄1 2/0 - Grey
ATS20 2/0, 7⁄1 2/0 2/0 .414 -.461 2/0 - Grey 16.25”
ATS30 3/0, 6⁄1 3/0 3/0 .461 -.522 3/0 - Black 16.25”
ATS3040 3/06⁄1 3/0–4/0 3/0–4/0 .461 -.575 3/0 - Black 23.50”
4/06⁄1 4/0 - Pink
ATS40 4/06⁄1 4/0 4/0 .475 -.575 4/0 - Pink 23.50”
26618⁄1
ATS266336 26626⁄7*
312.8* 266–336 .586 -.684 Green 23.50”
33618⁄1
33626⁄7*
ATS397477 39718⁄1
394.5* 397–477 .720 -.858 Blue 23.50”
39726⁄7*
47718⁄1*
*Application limited to maximum 10,000 pounds tensile.
TYPE ATS – AUTOSET™ AUTOMATIC SPLICES
Automatic Connectors
and Wedge Clamps
ConneCtors
31
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Range Decimal
Approximate Dimensions (in.)
Cat. No. ACSR AAAC AAC Range Color Code A B C
ATD42ZB 46⁄1, 7⁄1 4 4 .232 -.332 4 - Orange 1213⁄16 73⁄16 51⁄16
26⁄1, 7⁄1 2 2 2 - Red
ATD1020ZB 1/06⁄1 1/0 1/0 .368 -.461 1/0 - Yellow 141⁄2 9 415⁄16
2/06⁄1 2/0 2/0 2/0 - Grey
ATD3040ZB 3/06⁄1 3/0 3/0 .461 -.575 3/0 - Black 203⁄4 113⁄4 81⁄2
4/06⁄1 4/0 4/0 4/0 - Pink
ATD266336ZB 26618⁄1 266 266 .586 -.684 Green 203⁄4 113⁄4 81⁄2
33618⁄1 336 336
ATD397477ZB 39718⁄1 397 397 .720 -.858 Blue 203⁄4 113⁄4 81⁄2
47718⁄1 477 477
Automatic Deadends for Aluminum
Blackburn’s automatic deadend features the
same innovative jaw design as the field-proven
Blackburn Type ATS automatic tension splice.
The Type ATD automatic tension deadend
accepts ACSR, AAC, and AAAC conductors. It’s
range-taking capability helps take a bite out
of inventory costs because the five ATD sizes
replace eight sizes of other brands. Installation
of the new deadend is fast and easy, thus reduc-
ing maintenance costs as well as reducing
inventory.
• Color-coded end pieces provide instant visual
identification of maximum conductor size.
A separate, color-coded tape identifies the
minimum conductor size of the wide range
connectors to further eliminate errors and
save installation time.
• The funnel-shaped end piece swiftly guides
conductor into position for insertion.
• A pilot cup envelopes strands and guides the
conductor past the serrated jaws.
• Die-cast precision-made jaws provide opti-
mum contact area for a greater range of con-
ductor sizes.
• The jaws and the I.D. of the tube are coated
with a special microcrystalline based inhibi-
tor/lubricant which seals the connection and
provides a high pressure lubricant for long
term continuous performance.
• The deadends are provided with factory
installed dust covers.
• Compression spring positions the unique jaw
for positive conductor acceptance.
A
B C
TYPE ATD-ZB
TYPE ATD-ZB – STAINLESS STEEL BAIL
• Used for deadending ACSR, AAC,
and AAAC conductors
• Complete with galvanized steel
clevis pin and stainless steel cotter
pin for use with standard deadend
suspension insulators
• Breaking strength exceeds 95% of
rated strength of conductor up to
10,000 lb. maximum.
TYPE ZB
TYPE CB
TYPE FB
Automatic Connectors
and Wedge Clamps
ConneCtors
32
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Range Decimal
Approximate Dimensions (in.)
Cat. No. ACSR AAAC AAC Range Color Code A B
ATD42FB 46⁄1, 7⁄1 4 4 .232 -.332 4 - Orange 143⁄16 73⁄16
26⁄1, 7⁄1 2 2 2 - Red
ATD1020FB 1/06⁄1 1/0 1/0 .368 -.461 1/0 - Yellow 187⁄8 9
2/06⁄1 2/0 2/0 2/0 - Grey
Conductor Range Decimal
Approximate Dimensions (in.)
Cat. No. ACSR AAAC AAC Range Color Code A B C
ATD42CB 46⁄1, 7⁄1 4 4 .232 -.332 4 - Orange 12 9⁄16 7 3⁄16 51⁄16
26⁄1, 7⁄1 2 2 2 - Red
ATD1020CB 1/06⁄1 1/0 1/0 .368 -.461 1/0 - Yellow 151⁄4 9 53⁄8
2/06⁄1 2/0 2/0 2/0 - Grey
ATD3040CB 3/06⁄1 3/0 3/0 .461 -.575 3/0 - Black 203⁄4 113⁄4 61⁄2
4/06⁄1 4/0 4/0 4/0 - Pink
ATD266336CB 26618⁄1 266 266 .586 -.684 Green 19 3⁄16 113⁄4 61⁄2
33618⁄1 336 336
ATD397477CB 39718⁄1 397 397 .720 -.858 Blue 19 3⁄16 113⁄4 61⁄2
47718⁄1 477 477
Automatic Deadends for Aluminum
• Used for deadending ACSR, AAC, and AAAC
conductors
• Complete with galvanized steel clevis pin and
stainless steel cotter pin for use with stan-
dard deadend suspension insulators
• Slots provided for use with standard pulling
hooks
• Breaking strength exceeds 95% of rated
strength of conductor up to 10,000 lb.
maximum
• Used for deadending ACSR, AAC, and AAAC
conductors
• Flexible Bail for use with spool and other
type insulators where flexibility is a
requirement
• Breaking strength exceeds 95% of rated
strength of conductor
A
B C
A
B
TYPE ATD-CB
TYPE ATD-FB
TYPE ATD-CB – CLEVIS BRACKET
TYPE ATD-FB – FLEXIBLE BAIL
Automatic Connectors
and Wedge Clamps
ConneCtors
33
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Strand Nominal Strand** Dimensions in. (mm) Std.
Cat. No. Type Diameter in. (mm) Size RBS lbs. (kN) A B C Pack
ATDG14 Std. Bail 1/4 (6.35) 1/4 (6.6M) 6,650 (29.58) 9.2 (233.7) 1.7 (43.2) 4.0 (101.6) 12
ATDG516 Std. Bail 5/16 (7.94) 5/16 (6M) 11,200 (49.82) 9.5 (241.3) 1.8 (45.7) 4.5 (114.3) 12
ATDG38 Std. Bail 3/8 (9.52) 3/8 (10M) 15,400 (68.50) 11.5 (292.1) 2.3 (58.4) 5.0 (127) 12
ATDG716 Std. Bail 7/16 (11.11) 7/16 (18M) 20,800 (92.52) 14 (355.6) 2.8 (71.1) 6.8 (172.7) 12
ATDG14-L Long Bail 1/4 (6.35) 1/4 (6.6M) 6,650 (29.58) 13.4 (340.4) 1.7 (43.2) 4.0 (101.6) 12
ATDG516-L Long Bail 5/16 (7.94) 5/16 (6M) 11,200 (49.82) 15.1 (383.5) 1.8 (45.7) 4.5 (114.3) 12
ATDG38-L Long Bail 3/8 (9.52) 3/8 (10M) 15,400 (68.50) 17.0 (431.8) 2.3 (58.4) 5.0 (127) 12
ATDG716-L Long Bail 7/16 (11.11) 7/16 (18M) 20,800 (92.52) 22 (558.8) 2.8 (71.1) 6.8 (172.7) 12
Automatic Guystrand Connector System
Features:
The new family of steel strand automatic
deadends is designed and recommended for
use on:
• Common Grade
• Siemens-Martin
• High Strength Utility Grade
• EHS*
• Galvanized
• Bethalume
• Aluminized steel strand
(Per ASTM A 474, A 475)
• The connectors are designed and capable
of handling tensile loads in excess of 90%
of the rated strength of the recommended
strand.
• Made from high strength aluminum tapered
cartridge and hardened zinc plated steel
jaws
• Aluminum cartridge and internal compo-
nents (jaws, spring, washers) are factory
lubricated
Benefits:
• No tools required – quick and easy
installation
• Variable / flexible on demand strand
compression
• Exceeds 90% of the strand rated breaking
strength (RBS)* *
• Pilot cup/jaw system eliminates accidental
misapplication.
• Slotted access window permits jaw adjust-
ment to allow repositioning, removal or
retensioning of strand (deadends)
• Corrosion resistant (aluminum tube, zinc-
dichromate plated jaws, lubricated internal
components)
TYPE ATDG
*Items for 3/8” and 7/16” steel strand are not EHS rated.
**RBS rating listed is for 7 wire EHS strand.
TYPE ATDG GUYSTRAND CONNECTORS FOR STEEL STRAND APPLICATIONS
Automatic Connectors
and Wedge Clamps
ConneCtors
34
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Strand Nominal Strand** Dimensions in. (mm) Std.
Cat. No. Diameter in. (mm) Rating RBS lbs. (kN) A B Pack
ATSG14 1/4 (6.35) 1/4 (6.6M) 6,650 (29.58) 6.4 (162.6) .9 (22.8) 12
ATSG516 5/16 (7.94) 5/16 (6M) 11,200 (49.82) 7.2 (182.9) 1.1 (27.9) 12
ATSG38 3/8 (9.52) 3/8 (10M) 15,400 (68.50) 7.8 (198.1) 1.3 (33.0) 12
ATSG716 7/16 (11.11) 7/16 (18M) 20,800 (92.52) 12.5 (317.5) 1.6 (40.6) 12
*Items for 3/8” and 7/16” steel strand are not EHS rated.
**RBS rating listed is for 7 wire EHS strand.
Automatic Guystrand Connector System
TYPE ATSG
Features:
The new family of steel strand automatic
splices is designed and recommended for use on:
• Common Grade
• Siemens-Martin
• High Strength Utility Grade
• EHS*
• Galvanized
• Bethalume
• Aluminized steel strand
(Per ASTM A 474, A 475)
• The connectors are designed and capable
of handling tensile loads in excess of 90%
of the rated strength of the recommended
strand.
• Made from high strength aluminum tapered
cartridge and hardened zinc plated steel
jaws
• Aluminum cartridge and internal compo-
nents (jaws, spring, washers) are factory
lubricated
Benefits:
• No tools required – quick and easy
installation
• Variable / flexible on demand strand
compression
• Exceeds 90% of the strand rated breaking
strength (RBS)* *
• Pilot cup/jaw system eliminates accidental
misapplication.
• Corrosion resistant (aluminum tube, zinc-
dichromate plated jaws, lubricated internal
components)
TYPE ATSG SPLICES
Automatic Connectors
and Wedge Clamps
ConneCtors
35
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Range Dimensions Typical Tensile Values
Cat. No. Description ACSR AL AAAC D L Conductor Value (lb.) Color Code
W62-1 W-1 Series 2—6 1 str.— 2—6 23⁄8 12 2 6/1 ACSR 1200 Orange
W62-1FC Aluminum 6 sol. flex. 171⁄2
W20-1 Wedge 1/0—4 2/0 str.— 1/0—4 23⁄8 121⁄2 1/0 6/1 ACSR 1800 Blue
W20-1FC and 2 sol. flex. 181⁄2
W40-1* Slider 4/0—2/0 4/0 str.— 4/0—2/0 23⁄8 123⁄4 4/0 6/1 ACSR 1900 Red
W40-1FC* 2/0 sol. flex. 181⁄2
W62-1B W-1B Series 2—6 1 str.— 2—6 23⁄8 12 2 6/1 ACSR 1200 Orange
W62-1BFC For extremely 6 sol. flex. 171⁄2
W20-1B corrosive areas. 1/0—4 2/0 str.— 1/0—4 23⁄8 121⁄2 1/0 6/1 ACSR 1800 Blue
W20-1BFC Iridited Aluminum 2 sol. flex. 181⁄2
W40-1B* Wedge 4/0—2/0 4/0 str.— 4/0—2/0 23⁄8 123⁄4 4/0 6/1 ACSR 1900 Red
W40-1BFC* and Slider 2/0 sol. flex. 181⁄2
* W40 series clamps rated 850 lb. ultimate tension for 1/0 ACSR, AL, or AAAC.
Conductor Range Dimensions Typical Tensile Values
Cat. No. Stranded Solid D L Conductor Value (lb.) Color Code
W62D 2—6 1—6 23⁄8 12 2—7str.AAC 1300 Orange
• For dead-ending self-supporting drop wire
• Saves conductor – drop wire may be cut to
exact length
• Can be attached to bare neutral at any point
in the span
• Adjustments in drop wire sag are easily made
• Grips ACSR, AAAC, or AAC conductors
D
L
• For use on copper neutral
• Stainless steel wedge and slider
“FC” Flexible Bail
(Bail Length - 11-1/2”)
Rigid Stainless Steel Bail
(Bail Length - 6-1/2”)
TYPE W
TYPE W – ALUMINUM SERVICE WEDGE CLAMPS FOR USE WITH ACSR, ALUMINUM, AAAC CONDUCTOR
Service Wedge Clamps
TYPE W – STAINLESS STEEL WEDGE CLAMPS
Automatic Connectors
and Wedge Clamps
ConneCtors
36
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Mechanical
Connectors
ConneCtors
37
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Product Overvew
Type H, HPS, HPW
Copper Split Bolt
Connectors
Pages 38, 39
Type PAA, PAC, PAE, PC, K
Parallel Groove
Connectors
Pages 41-43
Type 2B, 2BX, 2BW,
2BPW
Two-Bolt Connectors
Pages 44, 45
Type XT
Cross Tap Clamp
Page 46
Type DLC
Dead-End Clamps
Page 46
Type HLC, PGH
Hot Line Clamps
Page 47
Type 4B, 6B
Multi-Bolt Connectors
Page 48
Type N, NPW
Service Entrance Connectors
Page 40
Type MS
Neutral Span Clamp
Page 40
Mechanical
Connectors
ConneCtors
38
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Split Bolt Connectors
• For copper to copper connections
• Bolt and nut of high strength corrosion-resis-
tant bronze alloy
• Pressure bar is copper through 40H; copper
alloy is used for 350 KCMIL and above
• Bolt and nut of hex design up to 350 KCMIL
• Tested and Listed to U.L. 486A requirements
®
®
TYPE H-—-HIGH STRENGTH SPLIT BOLT CONNECTORS
Conductor Range (AWG or KCMIL)
Range for Min. Tap
Equal Main with One Dimensions (in.)
Cat. No. and Tap Max. Main A B C D
9H 10 str.—12 sol. 14 sol. 3⁄8 .146 1⁄2 25⁄32
8H 8 str.—10 sol. 14 sol. 3⁄8 .146 1⁄2 25⁄32
8H3* 8 str.—12 sol. 16 str. 3⁄8 .146 1⁄2 29⁄32
6H 6 sol.—8 sol. 14 sol. 15⁄32 .170 21⁄32 31⁄32
6H3* 6 sol.—10 sol. 16 str. 15⁄32 .170 21⁄32 11⁄8
4H 4 sol.—8 sol. 14 sol. 17⁄32 .235 23⁄32 11⁄16
4H3* 4 sol.—8 sol. 16 str. 17⁄32 .235 23⁄32 19⁄32
3H 3 sol.—8 sol. 16 str. 17⁄32 .235 23⁄32 11⁄16
3H3* 4 str.—8 sol. 16 str. 17⁄32 .235 23⁄32 19⁄32
2H 2 sol.—6 sol. 14 sol. 19⁄32 .271 25⁄32 11⁄4
2H3* 2 sol.—6 sol. 14 sol. 19⁄32 .271 25⁄32 115⁄32
1H 2 str.—6 sol. 14 sol. 11⁄16 .330 7⁄8 111⁄32
1H3** 2 str.—6 sol. 14 sol. 11⁄16 .330 7⁄8 15⁄8
10H 1/0 str.—4 sol. 14 sol. 3⁄4 .385 15⁄16 119⁄32
20H 2/0 str.—2 sol. 14 sol. 7⁄8 .443 11⁄16 113⁄16
30H 4/0 str.—2 sol. 6 sol. 1 .580 15⁄16 25⁄32
40H 250 KCMIL—1 str. 8 sol. 1 .580 15⁄16 25⁄32
350M 350 KCMIL-250 KCMIL
1/0 str. 15⁄16 .717 121⁄32 211⁄16
500M 500 KCMIL-400 KCMIL
2/0 str. 11⁄2 .842 17⁄8 31⁄32
750M 750 KCMIL-600 KCMIL
4/0 str. 115⁄16 1.029 21⁄4 321⁄32
1000M 1000 KCMIL-800 KCMIL
4/0 str. 21⁄4 1.185 217⁄32 41⁄32
* Will accommodate 3 wires of maximum size
** Will accommodate 3 #2 str. wires
The H3 bolts are not U.L. Listed or CSA Certified.
U.L. recognizes solid and stranded conductor configurations for sizes #8 and
smaller and stranded configurations only for sizes #6 and larger.
TYPE H
TYPE H – HIGH STRENGTH SPLIT BOLT CONNECTORS
Mechanical
Connectors
ConneCtors
39
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Range (AWG or
KCMIL
)
Range for Range for Min. Tap
Equal Main Equal Main with One
and Tap and Tap Max. Main Dimensions (in.)
Cat.No. ACSR Copper or Aluminum A B C D
6HPW 8 6 sol.—12 sol. 12 sol. 15⁄32 .170 21⁄32 11⁄8
4HPW 6—8 4 sol.—12 sol. 12 sol. 17⁄32 .235 23⁄32 19⁄32
2HPW 4—8 2 sol.—8 sol. 8 sol. 19⁄32 .271 25⁄32 115⁄32
1HPW 2—8 1 str.—8 sol. 8 sol. 11⁄16 .330 7⁄8 15⁄8
10HPW 1—6 1/0 str.—6 sol. 6 sol. 3⁄4 .385 15⁄16 113⁄16
20HPW 1/0—6 2/0 str.—6 sol. 6 sol. 7⁄8 .443 11⁄16 21⁄16
40HPW 4/0—4 4/0 str.—4 sol. 4 sol. 1 .580 15⁄16 215⁄32
Split Bolt Connectors
®
®
A
A
D
• For use on combinations of copper, aluminum and ACSR
conductors
• Bolt and pressure bar of high strength copper alloy com-
pletely tin plated; spacer and washer of electrolytic copper
up through 4/0; bronze alloy 350 and above, all tin plated
• Contoured spacer and bell mouth washer distributes pres-
sure over large area of
conductor
• Large contoured spacer provides wide separation between
copper and aluminum conductors
• Blackburn Contax recommended when used with alumi-
num conductor
TYPE HPS – PLATED SPLIT-BOLT CONNECTORS WITH SPACER
TYPE HPS
TYPE HPW
• For use on copper, aluminum and ACSR conductors
• Most connectors are U.L. Listed and CSA Certified for
copper conductor only
• Bolt and pressure bar of copper alloy completely tin plated
• Contoured spacer of electrolytic copper up through 4/0;
bronze alloy 350 and above, all tin plated
• Blackburn Contax recommended when used on aluminum
conductor
TYPE HPW – PLATED SPLIT-BOLT CONNECTORS W/SPACER & WASHER
Conductor Range (AWG or KCMIL)
Range for Range for Min. Tap
Equal Main Equal Main with One
and Tap and Tap Max. Main Dimensions (in.)
Cat. No. ACSR Copper or Aluminum A B C D
9HPS – 10 str.–12 sol. 12 sol. 3⁄8 .146 1⁄2 29⁄32
8HPS – 8 str.–12 sol. 12 sol. 3⁄8 .146 1⁄2 29⁄32
6HPS 8 6 sol.–12 sol. 12 sol. 15⁄32 .170 21⁄32 11⁄8
4HPS 6–8 4 sol.–12 sol. 12 sol. 17⁄32 .235 23⁄32 19⁄32
2HPS 4–8 2 sol.–8 sol. 8 sol. 19⁄32 .271 25⁄32 115⁄32
1HPS 2–8 1 str.–8 sol. 8 sol. 11⁄16 .330 7⁄8 15⁄8
10HPS 1–6 1/0 str.–6 sol. 6 sol. 3⁄4 .385 15⁄16 113⁄16
20HPS 1/0–6 2/0 str.–6 str. 6 sol. 7⁄8 .443 11⁄16 21⁄16
40HPS 4/0–4 4/0 str.–4 sol. 4 sol. 1 .580 15⁄16 215⁄32
350HPS 266.8–1/0 350
KCMIL
–1/0 str. 2 sol. 15⁄16 .717 121⁄32 211⁄1
500HPS* 397.5–1/0 500
KCMIL
–1/0 str. 1/0 str. 11⁄2 .842 17⁄8 31⁄32
750HPS* 666.6–4/0 750
KCMIL
–4/0 str. 2/0 str. 115⁄16 1.029 21⁄4 321⁄32
1000HPS*
900–477
1000 KCMIL–500 KCMIL
4/0 str. 21⁄4 1.185 217⁄32 41⁄32
* Not CSA Certified. U.L. 486A
Washer
Spacer
Pressure
Bar
Mechanical
Connectors
ConneCtors
40
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Mechanical Service Entrance Connectors
• A combination aerial cable neutral parallel
groove connector and dead-ending clamp that
accommodates up to four service drops
• Used in situations where house is not
adjacent to pole
• Taps may be installed later independent of
existing connections
• Castings are of high strength aluminum alloy;
hardware is galvanized steel; one piece con-
struction
• Service entrance connectors with bodies and
screws of high-strength copper alloy; NPW is
tin plated
• Type NPW has phosphor bronze washer, tin
plated to protect conductor and distribute
pressure
• Type NPW can be used on ACSR conductor
• Slotted hex head screw
Type N Type NPW
Washer on
Type NPW only
AA
Conductor Range (AWG)
ACSR Copper Dimensions (in.)
Cat. No. max. min. max. min. A B C H Bolt Head
10N 10NPW — — 10 str. 14 sol. 3⁄8 .337 .156 .562 9⁄32
6N 6NPW 8 8 6 str. 10 sol. 7⁄16 .415 .191 .656 5⁄16
4N 4NPW 6 8 4 str. 6 sol. 1⁄2 .515 .243 .775 3⁄8
— 2NPW 4 8 2 str. 6 sol. 21⁄32 .643 .304 .970 1⁄8
Conductor Range
ACSR AWG
Cat. No. Main Tap Main Tap
MS4 4/0—4 1/0—6 4/0 str.—2 sol. 1/0 str.—6 sol.
5”
21⁄8”
27⁄16”
3⁄8”
9⁄16”
TYPE MS
TYPES N, NPW
TYPE MS – NEUTRAL SPAN CLAMP
TYPES N & NPW – SERVICE ENTRANCE CONNECTORS
Mechanical
Connectors
ConneCtors
41
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Parallel Groove Connectors
• Aluminum body cast around pronged copper
liner effectively seals out moisture
• Corrosion resistant; copper conductor is in
contact with copper aluminum conductor sur-
rounded by aluminum; clamp provides wide
physical separation of conductors reducing
possibility of galvanic corrosion; aluminum
bodies are pressure cast of corrosion resistant
alloy; steel bolt and lockwasher are galva-
nized, and the nut is nickel plated
• One piece construction; no loose parts to
assemble during installation; copper inserts
always face each other; carriage bolts
Furnished standard
• For hex head bolt add suffix 3
Conductor Range
Cat. No. Main Tap Conductor Diameter Dimensions (in.)
Standard Prefilled ACSR AL Copper Main Tap H W L
PAC345# PAC3459
1/0—8
1/0 str.—8 sol.
1/0 str.—8 sol. .398-.128 .373-.128 27⁄32 117⁄32 11⁄4
PAC7‡ PAC79
336.4—1/0 400—2/0 str. 1/0 str.—8 sol. .741-.398 .373-.128 215⁄32 15⁄8 17⁄8
1/0—6 AR 1/0—6 AR
‡ RUS Listed.
• For use on copper, aluminum and ACSR conductors
• Order pre-filled with oxide inhibitor for use
on copper to aluminum
• Clamps are high-strength, heat treated cast
aluminum alloy
• Galvanized steel carriage bolt, nut and
lockwasher are standard; for hex head bolts
add suffix 3
TYPE PAC
TYPE PAA
Cast PAA PAA339
TYPE PAA – ONE & TWO-BOLT ALUMINUM PARALLEL GROOVE CLAMPS
TYPE PAC – ALUMINUM PARALLEL GROOVE CLAMPS WITH COPPER LINER
Conductor Range Conductor Diameter
Cat. No. Main Tap Main Tap Dimensions (in.) Bolt
Standard Prefilled ACSR AL/CU ACSR AL/CU max. min. max. min. F H L W Size
PAA29
2—6 2 str.—6 sol. 2—6 2 str.—6 sol. .316 .162 .316 .162 9⁄16 113⁄16 113⁄32 13⁄8 5⁄16
PAA339 1/0—6 1/0 str.—6 sol. 1/0—6 1/0 str.—6 sol. .398 .162 .398 .162 9⁄16 19⁄16 11⁄4 11⁄2 3⁄8
PAA4 PAA49
1/0—6 1/0 str.—6 sol. 1/0—6 1/0 str.—6 sol. .398 .162 .398 .162 9⁄16 27⁄32 13⁄16 11⁄2 3⁄8
PAA5 PAA59
1/0—8 1/0 str.—8 sol. 1/0—8 1/0 str.—8 sol. .398 .128 .398 .128 9⁄16 27⁄32 111⁄32 11⁄2 3⁄8
PAA6 PAA69
1/0—8 2/0 str.—8 sol. 1/0—8 2/0 str.—8 sol. .414 .128 .414 .128 9⁄16 27⁄32 13⁄8 15⁄8 3⁄8
PAA10‡ PAA109
336.4—1/0 400—1/0 str. 1/0—8 1/0 str.—8 sol. .741 .368 .398 .128 9⁄16 215⁄32 2 13⁄4 3⁄8
1/0—6 AR 1/0—6 AR
PAA12 PAA129
4/0—2 4/0 str.—2 sol. 4/0—2 4/0 str.—2 sol. .563 .258 .563 .258 3⁄4 21⁄4 2 2 1⁄2
PAA400* PAA4009*
336.4—1/0 400—1/0 str. 336.4—1/0 400—1/0 str. .741 .368 .741 .368 3⁄4 31⁄4 33⁄4 21⁄2 1⁄2
1/0—6 AR 1/0—6 AR
* PAA 400 and 4009 are two bolt clamps.
AR = Over armor rod
‡ RUS Listed.
Mechanical
Connectors
ConneCtors
42
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Diameter (in.) Galvanized Aluminum
Conductor Range Main Tap Dimensions (in.) Steel Bolt Bolt
Cat. No. Main Tap max. min. max. min. Fig. H W L F B A Thd. Size. Thd. Size
PAE-335-79 1/0 str.—6 sol. 1/0 str.—6 sol. .398 .162 .398 .162 1 19⁄16 11⁄2 11⁄4 9⁄16 — — 3⁄8—16 UNC 3⁄8—16 UNC
PAE-2121-9‡ 2/0 ACSR—6 sol. 6 AR 2/0 ACSR—6 sol. 6 AR .447 .162 .447 .162 1 2 15⁄8 13⁄8 9⁄16 7⁄8 — 3⁄8—16 UNC 3⁄8—16 UNC
PAE-2121X-79 2/0 ACSR—6 sol. 6 AR 2/0 ACSR—6 sol. 6 AR .447 .162 .447 .162 1 2 15⁄8 13⁄8 9⁄16 7⁄8 — — 3⁄8—16 UNC
PAE-4141-9‡ 4/0 ACSR—2 sol. 4-6 AR 4/0 ACSR—2 sol. 4-6 AR .563 .258 .563 .258 1 2 2 13⁄8 9⁄16 7⁄8 — 3⁄8—16 UNC 3⁄8—16 UNC
397.5 ACSR—3/0 str. 2/0 str.—6 sol. .
PAE-3921-9-2 2/0—6 AR 6 AR .743 .464 .414 .162 2 29⁄16 21⁄4 15⁄8 3⁄4 11⁄8 — 1⁄2—13 UNC 1⁄2—13 UNC
1000 KCMIL-397.5 4/0 ACSR—2 sol.
PAE-9941-9 ACSR 336.4—2/0 AR 4-6 AR 1.152 .743 .563 .258 3 213⁄16 259⁄64 21⁄4 3⁄4 — — 1⁄2—13 UNC 1⁄2—13 UNC
397.5 ACSR—3/0 str. 3/0 ACSR—2 str.
PAE-3931-9-2 2/0—6 AR 6 AR .743 .464 .502 .292 4 29⁄16 25⁄16 33⁄8 3⁄4 — 13⁄4 1⁄2—13 UNC 1⁄2—13 UNC
397.5 ACSR—3/0 str. 397.5 ACSR—3/0 str.
PAE-3939-9-2 2/0—6 AR 2/0—6 AR .743 .464 .743 .464 5 29⁄16 29⁄16 35⁄8 3⁄4 — 17⁄8 1⁄2—13 UNC 5⁄8—11 UNC
1000 KCMIL—397.5 2/0 str.—6 sol.
PAE-9921-9 ACSR 336.4—2/0 AR 6 AR 1.152 .743 .414 .162 3 213⁄16 23⁄16 21⁄4 3⁄4 — — 1⁄2—13 UNC 5⁄8—11 UNC
1000 KCMIL—397.5 397.5 ACSR—3/0 str.
PAE-9939-9 ACSR 336.4—2/0 AR 2/0—6 AR 1.152 .743 .743 .464 4 23⁄16 37⁄64 31⁄2 3⁄4 — 11⁄2 1⁄2—13 UNC 5⁄8—11 UNC
1000 KCMIL—397.5 1000 KCMIL—397.5
PAE-9999-9 ACSR 336.4—2/ AR ACSR 336.4—2/0 AR 1.152 .743 1.152 .743 6 213⁄16 31⁄2 6 3⁄4 — 2 1⁄2—13 UNC 5⁄8—11 UNC
‡ RUS Listed.
Parallel Groove Connectors
• Extruded parallel groove clamps for use on
aluminum to aluminum or aluminum to
copper connections with oxide inhibitor
• Tin plating (-P) or wax dip (-6) must be speci-
fied for non-oxide inhibitor filled connectors
• Standard PAE clamp is supplied with contax
(-9) and galvanized steel hardware
• All connectors can be installed with live line
tools
• Options:
-7 Aluminum hardware
-P Tin plating
-6 Wax dip for oxide protection
Example: Cat. Number for PAE 2121 with
Contax and aluminum hardware is PAE-2121-79
Fig. 1
Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6
TYPE PAE
TYPE PAE – PARALLEL GROOVE CLAMPS, EXTRUDED TYPE
Mechanical
Connectors
ConneCtors
43
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
TYPE PC
Parallel Groove Connectors
2”
1-3/4”
23/32”
2-5/16”
5/8”
3/8”
Plated Groove Copper Groove
Cat. No. Max. Min. Max. Min.
1/0 ASCR 2/0 str. 8 solid
2 SCG 6 ACSR copper copper
K1 amerductor 12SCG 7⁄16 9-12D
7⁄16 galv. amerductor Copperweld* Copperweld*
strand 8 solid iron 2A etc.
Copperweld*
Plated with plating removed from one groove. For use with aluminum, amerductor, or
galvanized steel strand to copper or copper bonded steel wires.
Both Grooves Plated
Cat. No. Max. Min.
1/0 ACSR 6 ACSR
K2 2 SCG amerductor 12 SCG
7⁄16 galvanized amerductor
steel strand 8 solid iron
Clamp is plated. For use with amerductor, aluminum, or galvanized steel stranding.
Both Grooves Unplated
Cat. No. Max. Min.
2/0 str. copper 8 solid copper
K3 7⁄16 copperweld* 91⁄2D
2A copperweld* copperweld*
etc.
Clamp is not plated. For copper to copper connections.
* Trademark of Copperweld.
TYPE K
Conductor Range Conductor Diameter
AWG or
KCMIL
(in.)
Main Tap A B
Cat. No. max. min. max. min. max. min. max. min.
PC250 250 str. 4 sol. 250 str. 4 sol. .575 .204 .575 .204
• A copper alloy parallel groove clamp;
hex head bolts with square shank of silicon bronze, spring
washers also of silicon bronze
• Square shank bolts prevent turning while tightening
• Contour of casting permits use of socket wrench if desired
• Large contact area increases conductance
• No special tools required
• Not recommended for aluminum conductor
• Cast of high strength copper alloy
• Furnished with silicon bronze hex washer head bolt
• Parallel groove design; no need to remove bolt for installation
• Only one size for all requirements from
No. 8 solid copper to 1/0 ACSR or 2/0 copper
• Available plated, unplated or with plating in one groove
TYPE PC – TWO-BOLT PARALLEL GROOVE CLAMP
TYPE K – JUMPER CLAMPS
Mechanical
Connectors
ConneCtors
44
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Two-Bolt Connectors
®
®
• Castings and bolts of high-strength copper
alloy
• One piece construction
• Free bolt is held in place with neoprene wash-
er during installation
• One extra length bolt allows top casting to
swing free over two conductors of maximum
range
• U.L. 486A Listed for copper conductor only
• Castings and bolts of high-strength copper
alloy
• Cap is removable; neoprene washers
capture each bolt in bottom casting, aiding
installation
• U.L. 486A Listed for copper conductor only
Conductor Range (AWG or KCMIL) Conductor
Main Tap Diameter (B) Bolt
Dimensions (in.)
Cat. No. max. min. max. min. max. min. Head L H D
2B10 1/0 str. 2 str. 1/0 str. 10 sol. .746 .394 1⁄2 15⁄16 13⁄4 5⁄16
2B20BB
2/0 str. 2 str. 2/0 str. 8 sol. .838 .420 1⁄2 15⁄16 11⁄4 5⁄16
2B40 4/0 str. 1/0 str. 4/0 str. 6 sol. 1.056 .530 9⁄16 123⁄32 13⁄4 3⁄8
2B350 350 KCMIL 4/0 str. 350 KCMIL 4 sol. 1.362 .726 3⁄4 21⁄8 2 1⁄2
2B500 500 KCMIL 350 KCMIL 500 KCMIL 4 sol. 1.626 .883 3⁄4 21⁄4 21⁄2 1⁄2
2B800 800 KCMIL 600 KCMIL 800 KCMIL 2 sol. 2.062 1.149 3⁄4 21⁄2 21⁄2 1⁄2
2B1000 1000 KCMIL 750 KCMIL 1000 KCMIL 2 sol. 2.304 1.255 15⁄16 231⁄32 23⁄4 5⁄8
U.L. 486A
Conductor Range (AWG or KCMIL) Conductor
Main Tap Diameter (B) Bolt
Dimensions (in.)
Cat. No. max. min. max. min. max. min. Head L H D
2B10X 1/0 str. 2 str. 1/0 str. 10 sol. .746 .394 1⁄2 15⁄16 11⁄2 5⁄16
2B20X 2/0 str. 2 str. 2/0 str. 8 sol. .838 .420 1⁄2 15⁄16 11⁄2 5⁄16
2B40X 4/0 str. 1/0 str. 4/0 str. 6 sol. 1.056 .530 9⁄16 123⁄32 17⁄8 3⁄8
2B350X 350 KCMIL 4/0 str. 350 KCMIL 4 sol. 1.362 .726 3⁄4 21⁄8 21⁄4 1⁄2
2B500X 500 KCMIL 350 KCMIL 500 KCMIL 4 sol. 1.626 .883 3⁄4 21⁄4 21⁄2 1⁄2
2B800X 800 KCMIL 600 KCMIL 800 KCMIL 2 sol. 2.062 1.149 3⁄4 21⁄2 23⁄4 1⁄2
2B1000X
1000 KCMIL 750 KCMIL 1000 KCMIL 2 sol. 2.304 1.255 15⁄16 231⁄32 31⁄4 5⁄8
U.L. 486A
®
®
TYPE 2BX – ONE-PIECE TWO-BOLT CONNECTOR WITHOUT SPACER
TYPE 2BX
TYPE 2B
TYPE 2B – TWO-BOLT CONNECTOR WITHOUT SPACER
Mechanical
Connectors
ConneCtors
45
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Two-Bolt Connectors
®
®
• U.L. 486A Listed for copper conductor only
• For use on copper, aluminum and ACSR
conductors
• Tin Plated
• U.L. 486A Listed for copper conductor only
• For use on copper conductors only
• Castings and bolts of high-strength copper
alloy; spacer of ductile, high-conductivity
copper alloy
• One-piece construction; contoured spacer is
ringed and swings easily over the conductor
Conductor Range (AWG or KCMIL) Conductor Diameter
Main Tap A B Bolt Dimensions
Cat. No. max. min. max. min. max. min. max. min. Head L H E
2B10W 1/0 str. 2 str. 1/0 str. 10 sol. .373 .292 .373 .102 1⁄2 15⁄16 15⁄8 5⁄16
2B20W 2/0 str. 2 str. 2/0 str. 8 sol. .419 .292 .419 .128 1⁄2 15⁄16 15⁄8 5⁄16
2B40W 4/0 str. 1/0 str. 4/0 str. 6 sol. .528 .368 .528 .162 9⁄16 123⁄32 21⁄8 3⁄8
2B350W 350 KCMIL 4/0 str. 350 KCMIL 4 sol. .681 .522 .681 .204 3⁄4 21⁄8 21⁄2 1⁄2
2B500W 500 KCMIL 350 KCMIL 500 KCMIL 4 sol. .813 .679 .813 .204 3⁄4 21⁄4 23⁄4 1⁄2
2B800W 800 KCMIL 600 KCMIL 800 KCMIL 2 sol. 1.031 .891 1.031 .258 3⁄4 21⁄2 31⁄4 1⁄2
2B1000W
1000 KCMIL 750 KCMIL 1000 KCMIL 2 sol. 1.152 .997 1.152 .258 15⁄16 231⁄32 33⁄4 5⁄8
TYPE 2BW – ONE PIECE TWO-BOLT CONNECTOR WITH SPACER
TYPE 2BPW
TYPE 2BW
Conductor Range (AWG or KCMIL) Conductor Dia.
Main Tap A B Bolt Dimensions
Cat. No. max. min. max. min. max. min. max. min. Head L H E
2B10PW 1/0-2 1/0-6 1/0 str. 10 sol. 0.398 0.292 0.398 0.102 1/2 15/16 15/8 1/16
2B20PW 2/0-2 2/0-6 2/0 str. 8 sol. 0.447 0.292 0.447 0.128 1/2 15/16 15/8 5/16
2B40PW 4/0-1/0 4/0-6 4/0 str. 6 sol. 0.563 0.368 0.563 0.162 9/16 123/32 21/8 3/8
2B350PW 350-4/0 350-4 350 4 sol. 0.680 0.522 0.680 0.204 3/4 21/8 21/2 1/2
2B500PW 500 KCMIL 350 KCMIL 500 4 sol. 0.813 0.679 0.813 0.204 3/4 21/4 23/4 1/2
2B800PW 800 KCMIL 600 KCMIL 800 2 sol. 1.031 0.891 1.031 0.258 3/4 21/2 31/4 1/2
2B1000PW
1000 KCMIL 750 KCMIL 1000 2 sol. 1.162 0.997 1.162 0.258 15/16 231/32 33/4 5/8
®
®
TYPE 2BPW – ONE PIECE TWO-BOLT CONNECTOR WITH SPACER
Mechanical
Connectors
ConneCtors
46
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
TYPE XT
Cross Tap Clamps / Dead-End Clamp
• A multi-purpose connector; castings of
copper alloy; bolts of silicon bronze
• Design allows for free wrench rotation which
speeds installation
• For tin-plated style add suffix P to Cat.
Number – e.g. XT12P
A
B
Conductor Range (AWG or KCMIL) Conductor Diameter
Main Tap A B Dim. (in.)
Bolt
Cat. No.
max. min. max. min. max. min. max. min. L H W
Size
XT12 4/0 str. 1 str. 2 str. 6 sol. .528 .328 .292 .162 11⁄2 113⁄16 11⁄2 5⁄16
XT13 4/0 str. 1 str. 4/0 str. 1 str. .528 .328 .528 .328 17⁄8 2 17⁄8 3⁄8
XT21 500 KCMIL 250 KCMIL 2 str. 6 sol. .813 .574 .292 .162 21⁄16 23⁄16 15⁄8 3⁄8
XT22 500 KCMIL 250 KCMIL 4/0 str. 1 str. .813 .574 .528 .328 21⁄8 23⁄16 27⁄8 3⁄8
XT23* 500 KCMIL 250 KCMIL 500 KCMIL 250 KCMIL .813 .574 .813 .574 21⁄8 23⁄16 21⁄26 3⁄8
XT33*
1000 KCMIL
500 KCMIL 500 KCMIL 250 KCMIL 1.152 .811 .813 .574 21⁄4 3 215⁄16 3⁄8
XT34*
1000 KCMIL
500 KCMIL 1000 KCMIL 500 KCMIL 1.152 .811 1.152 .811 211⁄16 31⁄8 211⁄16 7⁄16
* 4 bolt clamps
• Top and bottom pressure pads cast of high
strength, heat treated, aluminum silicon alloy
• Extra long separating spacer of highly
conductive aluminum; spacer interlocks with
U bolt – will not drop out
• Spring action counteracts cold flow
• No special tools required for installation
• Suitable for deadend loop connections
• Hardware of high-strength galvanized steel
• For use on copper, aluminum and ACSR
conductors
• Order pre-filled with oxide inhibitor (suffix 9)
for use on aluminum to copper
Conductor Range Conductor Diameter
ACSR AWG or KCMIL A B Dimensions (in.)
Cat. No. Main Tap Main Tap max. min. max. min. W L H F E
DLC2106‡ 2/0—6 2/0—6 2/0 str.—6 sol. 2/0 str.—6 sol. .447 .162 .447 .162 17⁄8 11⁄2 31⁄4 9⁄16 3⁄8
4/0—1 4/0—1/0 266.8—1/0 str. 266.8—1/0 str. .563 .368 .609 .368 23⁄8 27⁄8 4 3⁄4 1⁄2
DLC23‡
2—6 AR
336.4—1/0 336.4—1/0
DLC25 1/0—6 AR 1/0—6 AR 397.5—1/0 str. 397.5—1/0 str. .684 .368 .743 .368 23⁄8 33⁄16 4 3⁄4 1⁄2
‡ RUS listed
TYPE DLC
TYPE DLC – SINGLE U BOLT ALUMINUM FITTINGS
TYPE XT – CLAMP FOR TEE TAP, CROSS, PARALLEL & END-TO-END CONNECTORS
Mechanical
Connectors
ConneCtors
47
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Fig. 1 Fig. 2 Fig. 3
Hot Line Clamps
®
®
• Eye-bolt coated with high temperature grease, assuring easy
turning in all weather conditions
• Available prefilled with oxide-inhibiting Contax and individu-
ally packaged; add suffix 9 to Cat. Number
• HLC2108 Series is for 2/0 – 8 main line conductor
• HLC3974 Series is for 400 KCMIL – 6 main line conductor
Conductor Range
For Wire Main Tap
Cat. No. Combination ACSR
AWG or KCMIL
ACSR AWG
Bronze Body Copper to
HLC2108‡ Copper — 2/0—8 — 2/0
Plated Bronze General
Body Purpose 2/0—6 2/0—8 2/0—6 2/0—8
HLC2108P
Plated Aluminum
Body General
2/0—6 2/0—8 2/0—6 2/0—8
HLC2108AP9 Purpose
Bronze Body Copper to — 400—6 sol. — 4/0—6 sol.
HLC3974 Copper
Plated Bronze
Body General
— 400—6 sol. 3/0—6 4/0—6 sol.
HLC3974P Purpose
Plated Aluminum General
Body Purpose 397.5—6 400—6 sol. 3/0—6 4/0—6 sol.
HLC3974AP
‡ RUS Listed.
• I ncorporates the superior design features of parallel groove
clamps, time-proven for their reliable performance
• Protected threads; wide temperature range lubricant prevents
seizing
• Tap wire positively secured to clamp during installation and
removal by hex head bolt and pressure pad; main and tap
clamped securely as clamp is tightened
• Available prefilled with Contax, add suffix 9
• Copper clamps are for use on copper conductors only
Conductor Range Conductor Diameter Center Dimensions
Cat. No. Main Tap Main Tap Bolts (in.)
Std. Pre-filled ACSR AWG ACSR AWG max. min. max. min. No. Dia. Fig. W H L
Aluminum Clamps
PGH29 2/0—8
2/0 str.—8 sol.
1/0—8 1/0 str.—8 sol. .447 .128 .398 .128 1 1⁄2 1 23⁄8 53⁄4 23⁄8
PGH4 PGH49 397.5—6 450—4 sol. 3/0—6 4/0 str.—6 sol. .781 .198 .528 .162 1 1⁄2 1 35⁄16 65⁄16 27⁄16
2/0—6 AR
874—4/0
PGH69
397.518⁄1—2 AR
1000—4/0 str. 266—6 300—6 sol. 1.152 .522 .657 .162 2 1⁄2 2 4 63⁄4 41⁄4
PGH6129* 874—4/0 1000—4/0 str. 266—6 300—6 sol. 1.152 .522 .657 .162 1 1⁄2 3 35⁄8 63⁄4 31⁄16
397.518⁄1—2 AR
Copper Clamps
PGH3 PGH39 —
2/0 str.—8 sol.
— 2/0 str.—8 sol. .419 .419 .128 .128 1 7⁄16 1 23⁄8 51⁄4 11⁄4
* PGH6129 has two hex head bolt and pressure pad tap conductor retainers. AR-with Armor Rod.
TYPE PGH
TYPE HLC
TYPE HLC – HOT LINE CLAMPS (PROTECTED THREAD)
TYPE PGH – CENTER BOLT PARALLEL GROOVE HOT TAP CLAMPS
Mechanical
Connectors
ConneCtors
48
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Range Conductor Diameter No.
ACSR AWG or KCMIL A B Dimensions (in.) of
Cat. No. Main Tap Main Tap max. min. max. min. W F H T L E Bolts
4B29 4/0—4 4/0—4 250—2 str. 250—2 sol. .575 .250 .575 .250 25⁄16 5⁄8 39⁄16 11⁄32 31⁄4 7⁄16 4
4B49 397.5—1/0 397.5—1/0 477—1/0 str. 477—1/0 str. .795 .368 .795 .368 23⁄4 3⁄4 45⁄16 13⁄32 43⁄4 1⁄2 4
6B89 795—300 795—300 800—350 800—336.4 1.108 .679 1.108 .679 31⁄2 15⁄16 59⁄64 7⁄16 63⁄4 5⁄8 6
Multi-Bolt Connectors
• Cap and pressure plate of cast aluminum
alloy; spacer of high conductivity aluminum
• High strength aluminum alloy bolts and lock
washers prevent seizing
• One piece construction eliminates loose parts
during installation
• For use on copper, aluminum and ACSR
conductors
• Factory filled with Contax oxide inhibitor
TYPES 4B, 6B
TYPES 4B, 6B – ONE PIECE MULTI-BOLT CONNECTORS
Grounding Connectors
and Accessories
ConneCtors
49
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Product Overview
Type JAB, G,
GG, GGH
Ground Rod Clamps
Pages 50, 51
Type DGC
Drive-on Ground
Clamps
Page 51
Type K
Parallel Connector
Page 54
Type TTC
Transformer Tank
Grounding
Connector
Page 54
Ground Plates
Page 53
Type C
Sectional Ground
Rod Couplings
Page 52
Threadless
Couplings and
Driving Caps
Page 52
Type DS
Driving Stud
Page 52
Metallic Gradient
Control Mat
Page 54
Grounding Connectors
and Accessories
ConneCtors
50
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Ground Rod Clamps and Accessories
• Cast of high strength corrosion resistant
copper alloy
• Both hex head and socket set screws
available
• Long bearing surface of clamp on ground wire
secures ground connection
• U.L. Listed for direct burial
• A dependable ground connection offered at a
substantial saving
• Cast of high strength corrosion-resistant cop-
per alloy
• Hex head bolts
• Simplified compact design will make a last-
ing, trouble-free connection
• U.L. Listed for direct burial
®
®
Dimensions (in.)
Cat. No. A A Screw
Socket Hex Nominal Wire Range (max.) (max.) Thread
Set Head Rod Dia. max. min. Socket Hex Size
Screw Bolt (in.) (mm) max. min. (mm
2
) (mm
2
) Screw Bolt UNC-2A B C D
JAB12* JAB12H
1⁄2 12.7 2 str. 10 sol. 33.6 5.2 119⁄32 23⁄32 7⁄16-14 27⁄32 7⁄8 19⁄32
JAB58 JAB58H
5⁄8 15.8 1/0 str. 8 sol. 53.4 8.3 127⁄32 213⁄64 7⁄16-14 29⁄32 1 11⁄16
JAB34 JAB34H
3⁄4 19.0 1/0 str. 8 sol. 53.4 8.3 2 211⁄32 7⁄16-14 11⁄16 1 51⁄64
-
JAB34C
3⁄4 +-5⁄8 15.8 1/0 str. 8 sol. 95.0 8.3
-
211⁄32 7⁄16-14 11⁄8 11⁄32 13⁄16
to 19.0
JAB1 JAB1H
1 25.0 4/0 str. 8 sol. 107.1 8.3 21⁄4 3 7⁄16-14 111⁄32 11⁄16 1
* Not CSA listed
Add suffix P to Cat. No. for tin plated clamp.
E
D
TYPE G
Dimensions (in.)
Screw
Nominal Wire Range A Thread
Rod Dia. max. min. (max.) Size
Cat. No. (in.) (mm.) max. min. (mm2) (mm2) Bolt UNC-2A B C D E
G3* 3⁄8 9.5 4 str. 10 sol. 21.1 5.2 13⁄8 5⁄16–18 11⁄16 1⁄2 27⁄64 3⁄8
G4 1⁄2 12.7 2 str. 10 sol. 33.6 5.2 – 3⁄8–16 27⁄32 3⁄8 37⁄64 1⁄2
G5‡ 5⁄8 15.8 2 str. 10 sol. 33.6 5.2 – 3⁄8–16 29⁄32 3⁄8 43⁄64 1⁄2
G6 3⁄4 19.0 2 str. 10 sol. 33.6 5.2 – 3⁄8–16 11⁄16 3⁄8 13⁄16 1⁄2
* Not U.L. Listed
‡ RUS Listed
Add suffix P to Cat. No. for tin plated clamp.
TYPE JAB
TYPE JAB – GROUND ROD CLAMPS
TYPE G – BUDGET LINE GROUND CLAMPS
Grounding Connectors
and Accessories
ConneCtors
51
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Ground Rod Clamps and Accessories
Dimensions (in.)
Cat. No.* A A Screw
Socket Hex Nominal Wire Range (max.) (max.) Thread
Set Head Rod Dia. max. min. Socket Hex Size
Screw Bolt (in.) (mm) max. min. (mm
2
) (mm
2
) Screw Bolt UNC-2A B C
GG12 GG12H 1⁄2 12.7 2 str. 8 sol. 33.6 8.3 113⁄64 113⁄16 7⁄16–14 27⁄32 15⁄16
GG58 GG58H 5⁄8 15.8 2 str. 8 sol. 53.6 8.3 151⁄64 27⁄32 7⁄16–14 61⁄64 15⁄16
-
GG34H 3⁄4 19.0 4/0 str. 8 sol. 120.6 8.3
-
3 1⁄2–14 13⁄8 11⁄4
* Add suffix P to catalog number for tin plated clamp.
GG34H has no pressure bar or axial groove.
• Cast of high strength corrosion-resistant
copper alloy; two types of screws available;
type GG has a socket set screw; type GGH has
a hex head bolt
• Floating pressure bar distributes pressure
evenly over a large area of the ground wire
• Axial groove keeps wire and rod in perfect
alignment
®
• Drive-on design provides easy tool free
installation, high reliability compression fit
connection, and room for one or two ground
leads
• High strength copper alloy provides
increased tensile strength and long term cor-
rosion resistance for direct burial applica-
tions
• U.L. 486A and U.L. 467 Listed
• RUS Listed
TYPES GG AND GGH
Cat. No. Ground Rod Size Ground Wire Size
DGC58-44‡ 5⁄8 (.555–.565) 1 or 2–#4 sol.
DGC58-66‡ 5⁄8 (.555–.565) 1 or 2–#6 sol.
DGC58-46 5⁄8 (.555–.565) 1–#4 sol.
1–#6 sol.
‡ RUS Listed
Width Across
Flats = 1⁄2”
Type GG
Socket Size
= .219
Type GGH
TYPE DGC
TYPE DGC – DRIVE-ON GROUND CLAMPS
TYPE GG AND GGH – HEAVY DUTY GROUND ROD CLAMPS
Grounding Connectors
and Accessories
ConneCtors
52
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Ground Rod Clamps and Accessories
Dimensions (in.)
Cat. No. Description Length Diameter
50LCNT* 1⁄2” L Threadless Coupling 3.0 .78
60CNT2* 5⁄8” Threadless Coupling 2.5 .69
70CNT* 3⁄4” Threadless Coupling 3.0 .97
60DSNT 5⁄8” Threadless Driving Cap 4.0 .88
*U.L. Listed.
• Threaded couplings are of high strength,
corrosion-resistant alloy; streamlined design
reduces driving friction; couplings are tapped
so that they may be used on all standard
threaded sectional rods
®
®
®
®
• Driving Studs of high strength steel may be
used with all standard threaded couplings
Threadless Coupling (Fig. 1)
• For joining non-threaded, sectional, copper
bonded, steel ground rods
• Coupling is manufactured of a high strength,
corrosion resistant, copper alloy
Threadless Driving Cap (Fig. 2)
• Prevents “mushrooming” of ground rod while
driving to insure proper fit of coupling
• Driving cap is manufactured of high strength,
hardened steel
TYPE C
TYPE DS
THREADLESS COUPLINGS
Size Thread
Cat. No. (Nominal Diameter) Size
50C 1⁄2” 1⁄2”–13 UNS
50LC*† 1⁄2” L 9⁄16”–12 UNS
60C*‡ 5⁄8” 5⁄8”–11 UNS
70C* 3⁄4” 3⁄4”–10 UNS
80C* 1” 1”–8 UNS
*U.L. Listed 467 (425H).
† CSA lists rods 1⁄2” and larger, 10’ and longer.
‡ RUS Listed.
Size Thread
Cat. No. (Nominal Diameter) Size
50DS 1⁄2” 1⁄2”–13 UNS
50LDS*† 1⁄2” L 9⁄16”–12 UNS
60DS*‡ 5⁄8” 5⁄8”–11 UNS
70DS* 3⁄4” 3⁄4”–10 UNS
80DS* 1” 1”–8 UNS
*U.L. Listed 467 (425H).
†CSA lists rods 1⁄2” and larger, 10’ and longer.
‡REA Listed.
Fig. 2
Fig. 1
TYPE DS – DRIVING STUDS
TYPE C – SECTIONAL GROUND ROD COUPLINGS
THREADLESS COUPLINGS AND DRIVING CAP
®
Grounding Connectors
and Accessories
ConneCtors
53
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Ground Plates
• More efficient than butt wrapping poles
• Made of electrolytic sheet copper
• Built-in high pressure connector for ground
lead, or supplied with #6 AWG copper
pigtail pre-attached
• Plates are grooved for trapping moisture
Pigtail Wire Range
min. max. Diameter of Plate
Cat. No. min. max. (mm2) (mm2) (in.) (mm)
GP100 71⁄2 191
GP110 8 2 sol. 6.3 25.6 10 254
GP114 14 356
GP1003 #6 AWG solid CU Pigtail
with 12” conductor — — 71⁄2 191
GP1008 #6 AWG solid CU Pigtail
with 96” conductor — — 71⁄2 191
GP1108 #6 AWG solid CU Pigtail
with 96” conductor — — 10 254
®
• 1/4” thick, hot-dipped galvanized
• Can be as efficient as two ground rods
• Must be buried at least 600mm (24")
below finish grade level according to
CEC Rule 10-702
GALVANIZED GROUND PLATES
Cat. No. Description Conductor Range
1016TB Galvanized ground plates 8 sol. to 1/0 str.
1016BTB Galvanized ground plates with JAB58H connector 8 sol. to 1/0 str.
‡ RUS Listed.
Wire Range Surface Area
Cat. No. max. min. Finished Size sq. in.
PBGW 2/0 str. 10 sol. 7 x 75⁄8 56
PBH‡ 4 str. 14 sol. 7 x 73⁄8 56
‡ RUS Listed.
• Installed on butt end of utility poles to pro-
vide an economical, low resistance neutral
ground.
• Installed cost considerably less than butt-
wrapped poles. Plate portion fabricated of
.025” pure copper.
• PBGW connector is eye-bolt type, cast of
corrosion resistant aluminum bronze alloy,
with silicon bronze nut and lock washer.
Riveted all copper terminal lug is an integral
part of the PBH, and provides the means of
connection to the grounding conductor.
TYPE GP
TYPE PB
TYPE PB – COPPER POLE GROUND PLATES
GALVANIZED GROUND PLATES
TYPE GP – COPPER POLE BOTTOM GROUND PLATES FOR
MULTIGROUNDED NEUTRAL CONSTRUCTION
Grounding Connectors
and Accessories
ConneCtors
54
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
1Q
1a
Mechanical Grounding Connectors
• For all combinations of aluminum, copper and
steel conductors
• Cast of high strength bronze alloy
•
Furnished with silicon bronze bolt and lockwasher
– lockwasher minimized loosening of installed clamp
• Parallel groove design; no need to remove bolt for
installation
• Only one size for all requirements from No. 8 solid
copper to 1/0 ACSR or 2/0 copper
Max. Min. Max. Min.
Plated Plated Unplated Unplated
Cat. No. Groove Groove Groove Groove
K1
1/0 ACSR 2 SCG 6 ACSR 12 SCG 2/0 str. copper 8 solid copper
amerductor amerductor 7⁄16 Copperweld* 91⁄2 D
7⁄16 galv. strand 8 solid iron 2A Copperweld* Copperweld* etc.
* Trademark of Copperweld Steel Co. Plated with plating removed from one groove.
For use with alumum, amerductor, or galvanized steel strand to copper or copper bonded
steel wires.
1s
TYPE K
BRONZE JUMPER CLAMPS
• Transformer Grounding Connectors are cast of
high conductivity bronze; 1⁄2”–13 stud fits all
standard EEI-NEMA distribution transformers
• Eye bolt on TTC2 rotates to accommodate
cable in either vertical or horizontal direction
• One size connector to handle full range of
grounding conductors from #8 through 2/0 str.
• No special tools required
TTC2 TTC4 TTC3
Conductor Range Stud Thread
max. min. Size Dimensions (in.)
Cat. No. max. min. (mm2) (mm2) UNC-2A A B C
TTC2 2/0 str. 8 sol. 67.4 8.3 1⁄2”–13 151⁄64 19⁄64 121⁄32
TTC3 1 str. 10 sol. 42.4 5.2 1⁄2”–13 13⁄8 13⁄64 19⁄16
TTC4‡ 1 str. 10 sol. 42.4 5.2 1⁄2”–13 11⁄4 7⁄8 13⁄8
TTC2P‡ 2/0 str. 8 sol. 67.4 8.3 1⁄2”–13 151⁄64 19⁄64 121⁄32
TTC3P* 1 str. 10 sol. 42.4 5.2 1⁄2”–13 13⁄8 13⁄64 19⁄16
TTC4P* 1 str. 10 sol. 42.4 5.2 1⁄2”–13 11⁄4 7⁄8 13⁄8
‡ RUS Listed.
* Tin Plated.
TYPE TTC
TYPE TTC – TRANSFORMER TANK GROUND CONNECTORS
Wt/100 Standard
Cat. No. Description lb kg package
64663 Mat with connectors 3000 1363 1
64660 Mat without connectors 2900 1318 1
4 ft. x 6 ft. hot dip galvanized mat is made from 6”x6” welded mesh, 1/4” diameter. Silicone
bronze connector, bolt, nut and lockwasher.
• To reduce risk and prevent build up of
dangerous potential differences between high
voltage equipment or structures and the user
standing on the ground surface.
CEC Rule 36-308
TYPE DS
METALLIC GRADIENT CONTROL MAT
Installation Dies
and Tools
ConneCtors
55
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Product Overview
Type EC-S8C
Oxide Inhibitor
Page 63
Silicone Lubricant
Page 63
Manual
Compression Tools
Page 56
Battery-Operated
Hydraulic Tools
Page 58-59
Type WW
Wire Bristle Brush
Page 63
Tool Service &
Warranty Information
Page 60
Type GCA
Ground Clamp Adapters
Page 56
Manual
Hydraulic Tools
Page 57
Tool Die
Selection Chart
Pages 61-62
Installation Dies
and Tools
ConneCtors
56
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
GCA / Manual Compression Tools
Handle
Length Weight
Cat. No. Description (in.) (lb)
Mechanical tool with 5⁄8” nose die and insert
OD58 die cavity – straight wooden handles 6.5
Mechanical tool with 5⁄8” nose die
OD581 and insert die cavity – fiberglass handles 6.0
Mechanical tool with 5⁄8” nose die and
OD583 insert die cavity – curved wooden handles 6.5
ODF Mechanical tool with fixed O & D dies 6.5
– straight wooden handles
ODF1 Mechanical tool with fixed O & D dies 6.0
– fiberglass handles
ODF3 Mechanical tool with fixed O & D dies 6.5
– curved wooden handles
Mechanical tool with fixed “O” and
ODB “D” dies. “D” die cavity accepts MD6 6.5
tool insert dies – straight wooden handles
Mechanical tool with fixed “O” and
ODB1 “D” dies. “D” die cavity accepts MD6 6.0
tool insert dies – fiberglass handles
Mechanical tool with fixed “O” and
ODB3 “D” dies. “D” die cavity accepts MD6 6.5
tool insert dies – curved wooden handles
Mechanical tool with 5⁄8” nose die and insert 10.5
OD58L72 die cavity – hot stick handles – 1.5” x 72”
Mechanical tool with fixed “O” and
ODBL72 “D” dies “D” die cavity accepts MD6 tool 10.5
insert dies – hotstick handles – 1.5” x 72”
ODH1 Insulating head cover 0.40
For Hand Tool with insulated head, add suffix 5 to cat. number; e.g. OD585.
21
72
TYPE OD
TYPE OD – MECHANICAL COMPRESSION TOOLS
• Patented, integral self-gaging system in tool head assures proper
adjustment before each crimp
• Improved design reduces force to crimp by as much as 20%
• Teflon over bronze bearings greatly reduce wear a linkage and
pins; far superior to steel bearing surfaces
• All standard insert dies available for OD58 tool: “O” and “D”, 840,
etc., 5⁄8” fixed die in nose
• ODF tool has fixed “O” and “D” dies
TYPE GCA
The Ground Clamp Adapter (GCA) allows tem-
porary ground installation without the use of
bucket trucks or the need for climbing poles.
This new method makes temporary grounding
and jumpering safer, easier than ever, and is a
useful alternative when unusual circumstances
exist for which the other two methods are not
possible or feasible.
Features and Benefits:
• Eliminates problems with unsafe pole
conditions (unstable, leaning, wet or icy,
cracked or broken, weathered poles)
• Eliminates pole “cut-outs”
• Eliminates additional equipment
associated training requirements
• Decreases installation cost
• Optimizes crew utilization and provides
faster system restoration
GCA-3
Top mount, twisted
for duckbill clamp
2.80”H x 4.40”L
GCA-2
Side mount for
duckbill clamp
2.80”H x 4.45”L
GCA-1
With wire guide for
standard C-clamp
2.43”H x 8.20”L
Length
Height
• ODB tool has fixed “O” and “D” dies;
accepts standard insert dies designed
for MD6 tool
• Distribution of weight over tool
length gives better balance, results in
easier handling and positioning
• Optional fiberglass handles for
greater strength, lighter weight,
better insulating properties and
lower moisture absorption rate
• OD58, ODF and ODB tools with
insulated heads available as option
• Lever action tool with hot stick
handles
of Glastrux Fiberglass, rated and
tested
for 100 kv/ft/5 minutes
• Lever action results in minimum force
to crimp
Installation Dies
and Tools
ConneCtors
57
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Catalog No. Description Weight lbs.
(Tool Only)
JB12B Hand operated 12-ton Tools
with Carrying Case
13
Catalog No.
Max
Cutting O.D.
in.
Dimensions Weight
lbs.
Length Width
TBM10HC up to 1 15.53 5.1 7.7
Note: Neoprene head cover for hand operated tools available.
TYPES JB12B
TYPES JB12B – SELF CONTAINED
HYDRAULIC COMPRESSION TOOLS
• Hand operated hydraulic wire cutter
• Cuts aluminum, copper and ACSR conductors
up to 1.” Cuts steel strand up to 7/8” includ-
ing EHS. Cuts ground rods up to 5/8”
• Compact Design – only 15.5” long – Just over
5” wide
• Very short stroke – only 8” – Perfect for con-
fined areas or small enclosures
• Weighs less than 8 lbs.
• 1 inch jaw opening
• Double speed ram action
• Head rotates 180 degrees
• Canvas storage bag included
• Pressure release lever can be used to relieve
pressure at any stage of the cutting process
*Not intended for use on fine strand rope wire
TYPE TBM10HC
TYPE TBM10HC – HYDRAULIC CUTTING TOOL
• For installing compression connectors to
copper, aluminum and ACSR conductors
• Tools accept all U-Type dies now used for Alcoa,
Burndy, T&B and previous Blackburn tools of
equivalent tonnage
• JB12B crimps conductor sizes from #8 – 750
KCMIL copper and #8 – 500 KCMIL aluminum
• Replaceable “Drop-Out” Bypass Valve cartridge
resolves chronic problems typical with other
pump designs; facilitates easy shop repair
• 180° head rotation
• Fiberglass handles
• Two stage pump for rapid advance
Manual Hydraulic Tools
Installation Dies
and Tools
ConneCtors
58
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
TYPE BPLT14BSCR
Battery-Powered 14-Ton Hydraulic
Crimping Tool
• Crimps connectors to 750 kcmil Cu and 600
kcmil Al
• Lightweight and balanced for single-handed
operation
• 1.65” jaw opening accommodates large com-
pression terminals and joints
• Dual-speed action pump offers fast advancing
speed for approach of die to connector and
slower, more powerful speed for crimping
• Head rotates 180° for operator convenience
and comfort
• Quiet, low-vibration operation
• Automatically displays residual battery capac-
ity after each crimp cycle
• Uses standard Blackburn, T&B and Burndy
U-Dies (sold separately)
• Provides 14 tons of crimping force
• Comes with 14.4 Ni-MH battery, spare battery,
battery charger, shoulder strap, and carrying
case
• 18.1”L x 10”H x 3.9”W, 18.1 lbs. (including
battery)
Battery-Operated Hydraulic Tools
TYPE BPLT6BSCR
Battery-Powered 6-Ton Hydraulic
Crimping Tool
• Open head design
• Wire range up to 500mcm
• Lightweight - just 11 pounds with battery
• 14.4 volt 3.0 Ah Ni-MH battery for extra
power and speed
• 6 tons of crimping force
• Uses “OD” style Blackburn and Kearney dies
and Burndy “W” dies with use of DBL die “D”
as an adapter
• Dual-speed ram action for rapid advance to
meet connector then slower for a tight crimp
• Head rotates 180 degrees
• Battery condition monitor
• Balanced ergonomically designed handle
offers easy operation and reduces carpal
tunnel strain
• Includes charger, spare battery, wrist and
shoulder strap
• Impact resistant case
Installation Dies
and Tools
ConneCtors
59
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
TYPE BPLT14BSCRI
Battery-Powered 14-Ton Hydraulic
Crimping Tool with Insulated Head
• Fully insulated tool, head, case, oil, and bat-
tery safeguard operator from accidental acti-
vation of tool
• Crimps connectors to 750 kcmil Cu and 600
kcmil AI
• Lightweight and balanced for single-handed
operation
• 1.65” jaw opening accommodates large com-
pression terminals and joints
• Dual-speed action pump offers fast advancing
speed for approach of die to connector and
slower, more powerful speed for crimping
• Head rotates 180° for operator convenience
and comfort
• Quiet, low-vibration operation
• Automatically displays residual battery capac-
ity after each crimp cycle
• Uses standard Blackburn, T&B and Burndy
U-Dies (sold separately)
• Provides 14 tons of crimping force
• Comes with 14.4 Ni-MH battery, spare battery,
battery charger, shoulder strap, and carrying
case
• 18.1”L x 10”H x 3.9”W, 18.1 lbs. (including
battery)
Battery-Operated Hydraulic Tools
BPLT15BSCR-B
Battery-Powered 15-Ton Hydraulic
Crimping Tool
• Conductor range up to 1500 Kcmil
• Weighs approximately 23 pounds
• Integrated controls for single hand operation
• Dual-speed ram action for rapid advance to
meet connector then slower for a tight crimp
• Head rotates 180 degrees
• Automatic cut off when crimp is complete
• Single-hand trigger operation
• Swing-open head for easy access
• Powered by 14.4v 3.0ah Ni-MH battery pack
• Optional connection point for use with 12VDC
power source
• Battery condition display
• Steel case for easy transport and storage
• Includes charger, spare battery and shoulder
strap
• Accepts standard Burndy P Dies (no adapter
needed)
• Will also accept Blackburn, T&B and Burndy
U-Dies with the use of a DA15-U die adapter
(sold separately)
• Accessories:
BCA12V cable for use with 12 VDC battery
DA15-U
Installation Dies
and Tools
ConneCtors
60
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
1 YEAR
• CABLE CUTTERS, DIES
5 YEARS
• MECHANICAL HAND TOOLS
(without Shure Stake® Mechanism)
• HYDRAULIC TOOLS
(self-contained)
Thomas & Betts Tool Service has a staff of highly trained,
experienced and dedicated technicians and application spe-
cialists to support our customers in every aspect of their tool-
ing needs.
The Tool Service Department is capable of repairing all
Thomas & Betts tools, from small tools to large hydraulic
pumps and crimping heads. The department is also respon-
sible for warranty repairs and will supply a loaner tool when
necessary.
For customers capable of repairing their own tools, Tool
Service also sells the component parts. In addition, they can
provide the technical data and information required.
The Application Tool Specialist also supports the field sales
organization in tool demos, customer training and tool instal-
lations. Arrangements are made with the local sales represen-
tative.
Limited Warranty
Thomas & Betts manufactures these tools to be free of defects in material and workmanship for the time specified above.
Should any defect occur during the specified time period, Thomas & Betts will repair or replace the tool at its option.
Limitations and Exclusions
THIS WARRANTY IS IN LIEU OF ALL OTHER REPRESENTATIONS AND EXPRESSED AND IMPLIED WARRANTIES (INCLUDING
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE) AND UNDER NO CIRCUMSTANCES SHALL
THOMAS & BETTS BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL PROPERTY DAMAGES OR LOSSES.
THIS WARRANTY IS NONTRANSFERABLE AND REPLACEMENT OF DEFECTIVE PARTS MUST BE MADE AT A FACILITY DESIGNATED BY THE
MANUFACTURER.
THOMAS & BETTS TOOL SERVICE TOOLS
2 YEARS
• BATTERY-OPERATED TOOLS
Tool Service and Warranty Information
Installation Dies
and Tools
ConneCtors
61
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Tool Die Selection Chart
INSERT DIES
Catalog No. Description or Color Code
OJB O
DBL D
BY39 510 Hex (non-bow)
BY41 635 Hex (non-bow)
BY43 747 Hex (non-bow)
BY45 T
BY47 K
BY49 B
BY51 J
BY53 P
BY13 3/16
BY15* 7/32 (EEI—1 index 236)
BY17 1/4
BY19 5/16 (index 161.242)
BY21 3/8
BY23 1/2 (index 163)
BY25 9/16
BY27 11/16
BY29 19/32
BY31 5/8—1 (index 165)
BY33 737
BY35 781
BY37 840 (EEI 11A)
BY55 Wire Cutter (2/0 max.)
BY63 Orange (Nicopress)
BY65 Plum
BY15C* 7/32 Red
BY17C* 1/4 Blue
BY19C* 5/16 Grey
BY21C* 3/8 Brown
BY23C* 1/2 Pink
BY24C* 1/2—1 Gold
BY25C* 9/16 Tan/Orange
BY27C* 11/16 Yellow
BY31C* 5/8—1 Olive/Purple
BY32C* Ruby
BY35C* 781 White
BY37C* 840 Red
BY28C* 17/32 Black
BY53C* P Green
ODH1 Insulating Head Cover
✻Can also be used with OD58 tool.
INSERT DIES FOR BPLT6BSCR HYDRAULIC HEAD & TYPE OD TOOLS
Installation Dies
and Tools
ConneCtors
62
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Catalog No. Description or Color Code
B58CS 5/8 Die Set
HO “O” Die Set
HD “D” Die Set
HN “N” Die Set
HU “U” Die Set
HBKC BKC
HBKT BKT
B24EA EEI 8A
B30EA EEI 9A
B39EA EEI 10A
B49EA EEI 11A (840)
B61EA EEI 12A
B80EA EEI 13A
B20AH EEI 14A
B71AH
B72AH
B73AH
B74AH
B75AH
B76AH
B76SH
B06CHI Pink/Gold
B08CH Tan/Orange
B09CH Olive/Purple
B11CH Red/Blue
B10SH
B05CH Green
B26CH Ruby/Yellow
B71CH Red
B72CH Black
B73CH Blue
B74CH Grey
B75CH Brown
B76CH Pink
B10CHI White
B12CHI Brown
Tool Die Selection Chart
INSERT DIES
INSERT U-TYPE DIES FOR HYDRAULIC HEADS*
FOR JB12B, BPLT14BSCR AND BPLT15BSCR-B
*Adapter 15500TB required with T&B 15-ton tools.
Installation Dies
and Tools
ConneCtors
63
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Sealants and Lubricants
• Seals electrical connections from oxygen and
moisture
• Non-water soluble, non-petroleum based
polymer grease
• Nontoxic, will not irritate the skin
• Service temperature to 460°F can be applied
in 0°F weather
• Clear in color, 8 oz. squeezable bottle
• Prevents formation of surface oxides (espe-
cially for aluminum) that interfere with the
current transfer between electrical compo-
nents
• For a more effective electrical connection
all conductors need to be wire brushed right
before or with the application of the electri-
cal compound. Wire brushing is not recom-
mended on tin plated components
• Applications for use on aluminum to alumi-
num, aluminum to copper or copper to copper
• Required on all cable connections, on flat to
flat surfaces or threaded assemblies
• Does not affect rubber or cable insulation
• Does not contain grit
• Does not stain
• For removing oxides from conductor surfaces
• Easy grip handle with glove guard to prevent
rubber glove puncture
• Long life brushes can be rotated and are
replaceable
• Handle and guard coated with durable non-
conductive plastic
EC-S8C
TYPE WW
Cat. No. Description
WWB1 Complete Brush with Handle
WRB1 Wire Element Only, Pair
TYPE WW – WIRE BRISTLE BRUSH
SILICONE LUBRICANT
Cat. No. Size Std. Pkg.
SL5 5 oz./142 grams 12 tubes
SILICONE LUBRICANT FOR HIGH VOLTAGE ELECTRICAL WORK
Chemicals, Sealant and Lubricants
Reference
Tables
ConneCtors
64
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
Split Bolts
Type H High Strength Split-Bolt Connectors
Blackburn Penn Union Burndy Ilsco/Utilco Anderson Josyln Dossert Eritech
9H S-10 KS90 IK-10 C-10 J3657 DS-09F ESB10
8H S-8 KS15 IK-8 C-8 J3608 DS-1F ESB8
8H3 SEL-8 SEL8S C-8-L
6H S-6 KS17 IK-6 C-6 J3606 DS-2F ESB6
6H3 SEL-6 KS17-3 SEL6S C-6-L J3608 DS-2-3
4H S-4 KS20 IK-4 C-4 J3604 DS-3F ESB4
4H3 SEL-4 KS20-3 SEL4S C-4-L J3604 DS-3-3
3H ESB3
3H3
2H S-3 KS22 IK-3 C-2 J3602 DS-5F ESB2
2H3 SEL-3 KS22-3 C-2-L J3602 DS-5-3
1H S-2 KS23 IK-2 C-1 DS-6F
1H3 SEL-2 SEL-2S C-1-L DS-6-3
10H S-1/0 KS25 IK-1/0 C-1/0 J3610 DS-10F ESB1/0
20H S-2/0 KS26 IK-2/0 C-2/0 DS-13F ESB2/0
30H S-3/0 KL27 IK-3/0 C-3/0 DS-17 ESB4/0
40H S-4/0-250 KS29 IK-250 C-4/0 J3640 DS-25C ESB250
350M S-350 KS31 IK-350 C-350 J3635 DS-35 ESB350
500M S-500 KS34 IK-500 C-500 J2650 DS-50 ESB500
750M S-750 KS39 IK-750 C-750 J3675 DS-75 ESB750
1000M S-1000 KS44 IK-1000 C-1000 J3679 DS-100
Type HPS Plated Split-Bolt Connectors
Blackburn Penn Union Burndy Ilsco/ Utilco Dossert Eritech
9HPS SW-1
8HPS SW-2 ESBP8
6HPS SW-3 KSU17 SK-6 DSNS2 ESBP9
4HPS SW-4 KSU20 SK-4 DSNS3F ESBP6
2HPS SW-5 KSU22 SK-3 DSNS5F ESBP2
1HPS SW-6 KSO23 SK-2 DSNS6F
10HPS SW-7 KSU25 SK-1/0 DSNS10F ESBP1/0
20HPS SW-8 KSU26 SK-2/0 DSNS13F ESBP2/0
40HPS SW-9A KSU27 SK-3/0 DSNS25C ESBP4/0
350HPS SW-11 KSU31 SK-350 DSNS35 ESBP350
500HPS SW-12 KSU34 SK-500 DSNS50 ESBP500
750HPS SW-13 DSNS75
1000HPS SW-14 DSNS100
MECHANICAL CONNECTORS
Reference
Tables
ConneCtors
65
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
Mechanical Service Entrance Connectors
Type N and NPW Service Entrance Connectors
Blackburn Penn Union Burndy Ilsco Dossert
10N SX-10-8 SX-10-8 ES1V
6N SX-6 KP6C SX-6 ES2
4N SX-4 KP4C SX-4 ES4
10NPW
6NPW SAX-6 ESSN2
4NPW SAX-4 ESSN4
MECHANICAL CONNECTORS
Parallel Groove Connectors
Type PAA One and Two-Bolt Aluminum Parallel Groove Clamps
Blackburn Penn Union Burndy Anderson Dossert
PAA4 PCAA-10 UC25R2R LC51A AC100
PAA5 LC51C AC101
PAA6 LC52A
PAA10 UC32R LC81A AC103
PAA12 PCAA-17 LC53A AC102
PAA400 LC66A
PAA29 PCAA-10-BF
PAA339 PCAA-10-BF
PAA49 PCAA-10-BF LC51A-XB
PAA59 UC25RS LC51C-XB
PAA69 LC52A-XB
PAA109 UC28RS
PAA129 PCAA-17-BF
PAA4009
Type K Jumper Clamps
Blackburn Penn Union Sherman
K1 JC-1-AC R-12
K2 JC-2-AA R-22
K3 JC-3-CC R-23
Type PAC Aluminum Parallel Groove Clamps with Cast Copper Liner
Blackburn Anderson
PAC 345 LCS11, LCS22A
PAC7 LC811A
PAC3459
PAC79
Type PAE Parallel Groove Clamps Extruded Type
Blackburn Alcoa
PAE2121-9 396.6
PAE4141-9 481.1
PAE3921-9-2 392.6
PAE9941-9
PAE3931-9-2 392.6
PAE3939-9-2 482.2
PAE9921-9 393.6
PAE9939-9 483.2
PAE9999-9 483.3
Reference
Tables
ConneCtors
66
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
MECHANICAL CONNECTORS
Two-Bolt Connectors
Type 2B Two-Bolt Connector without Spacer
Blackburn Penn Union Burndy Ilsco Kearney Anderson Chance Dossert
2B10 VT-0 17280 K-1 DSU10
2B20BB VT-1 KVS26 16369 K-2 00UC DSU13
2B40 VT-2 KVS28 IKB-4/0 K-3 DSU21
2B350 VT-3 KVS31 IKB-350 16371 K-4 35UC DSU35
2B500 VT-4 KVS34 IKB-500 16372 K-5 50UC DSU50
2B800 VT-5 KVS40 IKB-800 K-6 75UC DSU80
2B1000 VT-6 KVS44 IKB-1000 16374 K-7 100UC DSU100
Type 2BX One-Piece Two-Bolt Connector without Spacer
Blackburn Penn Union
2B10X VT-0L
2B20X VT-1L
2B40X VT-2L
2B350X VT-3L
2B500X VT-4L
2B800X VT-5L
2B1000X VT-6L
Type 2BPW Plated Two-Bolt Connector with Spacer
Blackburn Penn Union Burndy Ilsco Anderson Dossert
2B10PW VTA-0 KR-1TP DSUN10
2B20PW VTA-1 KVSU26 KR-2TP DSUN13
2B40PW VTA-2 KVSU28 IKS-4/0 KR-3TP DSUN21
2B350PW VTA-3 KVSU31 IKS-350 KR-4TP DSUN35
2B500PW VTA-4 KVSU34 IKS-500 KR-5TP DSUN50
2B800PW VTA-5 KVSU40 IKS-800 KR-6TP DSUN80
2B1000PW VTA-6 KVSU44 IKS-1000 KR-7TP DSUN100
Type 2BW One-Piece Two-Bolt Connector with Spacer
Blackburn Penn Union Burndy Anderson Dossert
2B10W VTW-0 KR-1 DSUS10
2B20W VTW-1 KVSW26 KR-2 DSUS13
2B40W VTW-2 KVSW28 KR-3 DSUS21
2B350W VTW-3 KVSW31 KR-4 DSUS35
2B500W VTW-4 KVSW34 KR-5 DSUS50
2B800W VTW-5 KVSW40 KR-6 DSUS80
2B1000W VTW-6 KVSW44 KR-7 DSUS100
Reference
Tables
ConneCtors
67
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
MECHANICAL CONNECTORS
Cross Tap Clamp
Type XT Clamp for Tee Tap, Cross, Parallel and End-to-End Connectors
Blackburn Penn Union Burndy Anderson Chance Dossert
XT12 VX-3 QPX282C XP-024018 GTX-216
XT13 VX-3 QPX2828 XP-024024 0000-MT GTX21-21
XT21 VX-4 QPX342C XP-050018 GTX50-6
XT22 VX-6 QPX3428 XP-050024 GTX50-21
XT23 VX-6 QPX3434 XP-050050 50-MT GTX50-50
XT33 VX-10 QPX4434 XP-100050 GTX100-50
XT34 VX-10 QPX4444 XP-100100 100-MT GTX100-100
Deadend Clamps
Type DLC Single U-Bolt Aluminum Fittings
Blackburn Penn Union Burndy Anderson Fargo Chance Dossert Bethea Alcoa
DLC2106 ADC10, ADC9, UW2R, LC71B, GA-144, S610AA AR7, AR11 ALD-1-U, 2412, 411,
ADC11 UW25R
LC70B, LC72B
GA145 ALD-23-U 412, 413
DLC23 LC74-4 GA145 S640AA AR22 ALD-3636-U
DLC25 LC74B S650AA ALD-67-U
Multi-Bolt Connectors
Type 4B and 6B One-Piece Multi-Bolt Connectors
Blackburn Anderson Chance Dossert Alcoa
4B29 A740AA
4B49 LCU-13 ACA450 582.2
6B89 LCU-16 582.3
Hot Line Clamps
Type HLC Hot Line Clamps, Protected Thread
Blackburn Anderson Fargo Chance Kearney Utilco
HLC2108 BH-00, BH-1 GH100 S-1520-CC 3532 BHLC-1
HLC2108P BH-1-FTP GH100P S-1520-GP 3532-4
HLC2108AP9 S-1520-AGP
HLC3974 BH-4 GH101 S-1530-CC 3537 BHLC-2
HLC3974AP
HLC3974P BH-4-FTP GH101P S-1530-GP 3537-4
Reference
Tables
ConneCtors
68
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Type WR “O” and “D” Die Seven Connector Program
Blackburn Penn Union Burndy Homac Kearney
WR159 KO-R06 YHO100, YHO1 OB44 506-82
WR189 KO-R08 YHO150, YHO2 OB101 508-82
WR289 KD-R02 YHD200,YHD3 DB202 502-82
WR279 KD-R04 YHD300, YHD4 DB2020 504-82
WR379 KD-R03 YHD250, YHD5 DB404 503-82
WR399 KD-R05 YHD350, YHD6 DB4020 505-82
WR419 KD-R28 YHD400, YHD7 DB4040 507-82
Type WR Supplemental “O” and “D” Die Connectors
Blackburn Penn Union Burndy Kearney Anderson Homac
WR149 KO-R33 YNO125 333-81 VCP44
WR179 KO-R08 YC25A2 325-81
WR199 KO-R08 YP26AU2 (ALT) 329-81
WR1010 YHO2-ONE OB1010D
WR259 KD-R04 YC25A25
WR299 KD-R02 YHD200
WR219 KD-R26 326-81
WR239
WR229 KD-R30
WR269 KD-R27
WR319
WR339 KD-R96
WR359 KD-R49 349-81
WR369 KD-R94 394-81
WR389 KD-R95 395-8
Type WR Wide Range “N” Die Tap Connector for Hydraulic Tools, 12-Ton and Greater
Blackburn Penn Union Burndy Homac
WR715 KN-1 NB50040
WR775 YHN450
WR815 YHN500
WR835 KN-R2
WR875
WR885 YHN525 NB500
Type WR Wide Range “N” Die Tap Connector for Hydraulic Tools, 10-Ton and Greater
Blackburn Penn Union Burndy Kearney Homac
WR699 KN-0 480
WR719 481
WR739 KN-R2 YHN550 482-81
WR779 KN-4 YHN600 483
WR799 KN-R5 485-81
WR819 KN-R6 YC33R26 486-81 NB60020
WR839 KN-R7 487-81
WR879 KN-8 488
WR889
Type WR Wide Range “R” Die Tap Connectors
Blackburn Penn Union Burndy Homac Kearney
WR909 KR-R03 YHR700 603-82
WR929 KR-R04 YHR750 ZB-954 604-82
WR949 KR-R05 YHR800 605-82
WR969 KR-R06 YHR850 ZB-954 606-82
WR989 KR-R07 YHR900 ZB954 607-82
WR999
Competitive Cross Reference
COMPRESSION H-TAP CONNECTORS
Reference
Tables
ConneCtors
69
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
Type WR Street Lighting Compression Connectors
Blackburn Penn Union Burndy Kearney
WR9 KO-R22 YP2A9U 421-8
WR139 KO-R24 YPC26R8U
WR502
Type CF Copper Compression Taps
Blackburn Penn Union Kearney
CF44-1 CDT-399-8 399-8
CFS44-1 CDT-301
CF22-1 CDT-398-8 398-8
CFS22-1 CDT-302
CF102-1 CDT-304-8 304-8
CF1010-1 CDT-303-8 303-8
CF202-1
CF2020-1 CDT-305-8 305-8
CF402-1 CDT-309-8 309-8
CF4010-1 CDT-308-8 308-8
CF4040-1 CDT-307-8 307-8
Type C Compression Connector Covers
Blackburn Burndy Homac Kearney Anderson
C2BB CO20B 48480 SEC-4
C5-BB CCO CO20B 601O PTC-1
C7 CCD CD40B 601D PTC-2
C9 CCN CN600B
C9L CCNL CN600B
Type CS Service Entrance Sleeves, 5/8 Die
Blackburn Penn Union Burndy Homac Kearney
CS61 PSK-66 YSU6W6W U1B88 26427
CS62 PSK-48 YSU4W8W U1B61 26527
CS63 PSK-46 YSU4W6W U1B68 26393
CS64 PSK-44 YSU4W4W U1B66 20693
CS65 PSK-28 YSU2W8W U1B41 26412
CS66 PSK-26 YSU2W6W U1B48 26467
CS67 PSK-24 YSU2W4W U1B46 20692
CS68 PSK-22 YSU2W2W U1B44 20691
CS69 PSK-18 YSU2R8W U1B21 26526
CS70 PSK-16 YSU2R6W U1B28 26525
CS71 PSK-14 YSU2R4W U1B26 20690
CS72 PSK-12 YSU2R2W U1B24 20689
CS73 PSK-11 YSU2R2R U1B22 20688
CS74 PSK-06 YSU25R6W U1B108 30933
CS75 PSK-04 YSU25R4W U1B106 30163
CS76 PSK-02 YSU25R2W U1B104 26485
CS77 PSK-01 YSU25R2R U1B102 26484
CS78 PSK-00 YSU25R25R U1B1010 30198
CS84 U1B2010
CS85 U1B3030
COMPRESSION CONNECTORS
SERVICE ENTRANCE CONNECTORS
Reference
Tables
ConneCtors
70
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
Type ICS Insulated Service Entrance Sleeves, 5/8 Die
Blackburn Penn Union Burndy Homac Kearney
ICS61-1 PIK-66 ES6W6W U1N61 58-GG
ICS62-1 PIK-48 ES4W8W U1N68 58-BLBR
ICS63-1 PIK-46 ES4W6W U1N66 58-BLG
ICS64-1 PIK-44 ES4W4W U1N41 58-BLBL
ICS65-1 PIK-28 ES2W8W U1N48 58-OBR
ICS66-1 PIK-26 ES2W6W U1N46 58-OG
ICS67-1 PIK-24 ES2W4W U1N44 58-OBL
ICS68-1 PIK-22 ES2W2W U1N28 58-OO
ICS70-1 PIK-16 ES2R6W U1N26 58-RG
ICS71-1 PIK-14 ES2R4W U1N24 58-RBL
ICS72-1 PIK-12 ES2R2W U1N22 58-RO
ICS73-1 PIK-11 ES2R2R U1N22 58-RR
ICS74-1 PIK-08 ES25R6W U1N106 58-YBL
ICS75-1 PIK-04 ES25R4W U1N104 58-YO
ICS76-1 PIK-02 ES25R2W U1N102 58-YR
ICS77-1 PIK-01 ES25R2R U1N1010 58-YY
ICS78-1 PIK-00 ES25R25R U1N1010 58YY
Type KL Large Compression Service Entrance Sleeves, 840 Die
Blackburn Penn Union Burndy Homac Kearney
KL22-1 X1U44
KL25-1 X1U22 36718
KL31-1 PS-00
KL36-1 PS-00 X1U1010 36715
KL45-1 PS-201 YSD26R2R X1U202 36713
KL46-1 PS-200 YSD26R25R X1U2010 36712
KL47-1 PS-2020 YSD26R26R X1U2020 36711
KL54-1 PS-302 YSD27R2W X1U304 36710
KL55-1 PS-301 YSD27R2R X1U302 36709
KL56-1 PS-300 YSD27R25R X1U3010 36708
KL57-1 PS-3020 YSD27R26R X1U3020 36707
KL58-1 PS-3030 YSD27R27R X1U3030 36706
KL64-1 PS-402 YSD28R2W X1U404 36705
KL65-1 PS-401 YSD28R2R X1U402 36704
KL66-1 PS-400 YSD28R25R X1U4010 36703
KL67-1 PS-4020 YSD28R26R X1U4020 36702
KL68-1 PS-4030 YSD28R27R X1U4030 36701
KL69-1 PS-4040 YSD28R28R X1U4040 36700
COMPRESSION CONNECTORS
Reference
Tables
ConneCtors
71
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
COMPRESSION CONNECTORS
Type IKL Insulated Service Entrance Sleeves, 840 Die
Blackburn Penn Union Homac
IKL34
IKL35 PIK-01R
IKL36 PIK-00R
IKL43 PIK-204
IKL44 PIK-202
IKL45 PIK-201
IKL46 PIK-200 XIN2010
IKL47 PIK-2020 XIN2020
IKL54 PIK-302
IKL55 PIK-301
IKL56 PIK-300 XIN3010
IKL57 PIK-3020 XIN3020
IKL58 PIK-3030 XIN3030
IKL64 PIK-402
IKL65 PIK-401
IKL66 PIK-400 XIN4010
IKL67 PIK-4020 XIN4020
IKL68 PIK-4030 XIN4030
IKL69 PIK-4040 XIN4040
Type TR Triplex Neutral Splice, Semi-Tension, 5/8 Die
Blackburn Penn Union Burndy Homac Kearney Anderson
TR61 PNK-44 YSS6RG2 SNG66 30008 DCN-6R6R
TR63 PNK-22 YSS4R SNG44 30009 DCN4R4R
TR64 PNK-11 YSS2R SNG22 30010 DCN2R2R
TR65 PNK-00 YDS25AT SNG00 30013 DCN-0W0W
TR66 SNG00 30715
Reference
Tables
ConneCtors
72
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
Type AC Single Sleeve, Full Tension Splice for All Aluminum Conductor
Blackburn Burndy Homac Kearney
AC6-TB YDS6CA
AC4-BB YDS4CA L2A5 OHR-4-7AL
AC2-TB YDS2CA Q247 OHR-2-7AL
AC10-TB YDS25AT U2A9 OHR-1/0-7AL
AC20 Z2A10 OHR-2/0-7AL
AC205 YDS26AT
AC30 YDS27AT 2169 OHR-3/0-7AL
AC40 YDS28AT 2170 OHR-4/0-7AL
AC266 YDS291AT 2174 HR-266-7AL
AC336 YDS301AT 2176 HR-336-7AL
AC350 YDS31AT
AC397 YDS311AT 2178 2178
AC477 TDS331AT 2182 2182
AC556
Type RC Single Sleeve, Full Tension Splice for ACSR, AAAC, 5005, AAC Conductor
Blackburn Penn Union Burndy Homac Kearney
RC4BB KFAS-4-61-71 BS46 BS467 OH4-61-71AS
RC45
RC2BB KFAS-2-61-71 YDS2RL DS26 DS267 OH2-61-71AS
RC25 YDS021RL DS26 DS267
RC10 KFAS-1/0-61 YDS25RL WS10 RS10 OH-1/0-61AS
RC205
RC20 KFAS-2/0-61 YDS26RL MS20 H-2/0-61AS
RC30 KFAS-3/0-61 YDS27RL 16100 H-3/0-61AS
RC40 KFAS-4/0-61 YDS28RL 16101 H-4/0-61AS
RC336 KFAS-336-181 YDS321RL 16104 H-336-181AS
RC397 YDS341RL 16106 H-397-181AS
RC477
Type CTS Copper Full Tension Splice for Solid, Stranded and Copperweld Conductor
Blackburn Penn Union Burndy Kearney Nicopress
CTS8 YDS8WGI OH8C 1-128J
CTS6 BFW-6 YDS6W OH6C 1-162J
CTS4 BFW-4 YDS4W OH4C 1-204P
CTS27 YDS2C OH2-7C 1-258/7X
CTS407 YDS28 H4/0-7C 1-460/7H5
CTS6ACW YDS6KT OHR6ACW 1-6A-P
DISTRIBUTION COMPRESSION CONNECTORS
Reference
Tables
ConneCtors
73
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
Type PCS, PKL, and PRS Pigtail Compression Sleeves
Blackburn Penn Union Burndy Homac Kearney
PCS64 PSKS-44-2 1/4 YE6R-25 U5U6 103908-1
PCS67 PSKS-24-2 1/4 YE4R-25 U5U4 103909
PCS71 PSKS-14-2 1/4 YE2R-25 U5U2 103910
PCS76 PSKS-02-3 1/4 YE25R25 U5U10 103911
PKL36-1 PSS-01-6 1/2 X5U10 40668
PKL46-1 PSS-201-6 1/2 YE26R-60 X5U20
PKL56-1 PSS-301-6 1/2 YE27R-60 X5U30 36875, 40628,
40019
PKL66-1 PSS-401-6 1/2 YE28R-60 X5U40 40549,26485-12,
30579-12
PRS25N PSS-261-5 1/2 YE30R-60 PTB300
PRS30N PSS-3330-5 1/2 YE32R-60 PTB350 36691-1
PRS35N PTB400 49603-1, 49603
PRS40N YE361R-60 PTM500
Type AL Aluminum Compression Terminal Lugs
Blackburn Penn Union Burndy Homac
AL4 KSL-R2D YCA2R-2N SAK2-N
AL5 YCAK25AG1 SAK1/0-48
AL6 KSL-1/0D YCA25R-2N SAK1/0-N
AL7 YCAK26AG1 SAK2/0-48
AL8 KSL-2/0D YCA26R-2N SAK2/0-N
AL9 YCAK27AG1 SAK3/0-48
AL10 KSL-3/0D YCA27R-2N SAK3/0-N
AL11 YCAK28AG1 SAK4/0-48
AL12 KSL-4/0D YCA28R-2N SAK4/0-N
AL16 KSL-026D YCA30R-2N SAB300-N
AL18 KSL-035D YCA321R-2N SAB350-N
AL20 YCA33R-2N SAB400-N
AL24 KSL-050D YCA35R-2N AL500NTN
AL28 YCA37R-2N AL600NTN
AL32 YCA39R-2N SAM636-N
AL44 YCA391A-2N SAL750-N
AL60 SAL1033-N
Type ALS Aluminum Compression Terminal Lugs
Blackburn Penn Union Burndy Homac Kearney Anderson
AL581 FKLA-W2-S YRA4CU SA4-48
AL582 SA4-N 40155
AL583 FKLA-C2-S SA2-48
AL584 SA2-N 36918
AL585 FKLA-010-S YRA25A SA1/0-48
AL586 YCA25R-2N SA1/0-N
ALS1 FSLA-W2-S YRAL4CU 104761-1
ALS2
ALS3 FSLA—C2-S YA2CA2 104761-2
ALS4 CCL-316-B
ALS5 FSLA-010-S YRA25U 104761-3
ALS6 36233 CCL-372-B
CCL-398-B
ALS7 FSLA-013-S YRA26U SA2/0-48 104761-4
ALS8 YCA26R-2N SA2/0-N 36234 CCL-418-B
CCL-447-B
ALS9 FSLA-017-S YRA27U SA3/0-48 104761-5
ALS10 YCA27R-2N SA3/0-N 48212 CCL-470-B
CCL-527-B
COMPRESSION CONNECTORS
Reference
Tables
ConneCtors
74
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
Type ALS Aluminum Compression Terminal Lugs
Blackburn Penn Union Burndy Homac Kearney Anderson
ALS11 FSLA-025-S YRA28U SA4/0-48 104761-6
ALS12 YCA28R-2N SA4/0-N 48160 CCL-593-B
ALS13 FULA-025-S SA250-48
ALS14 FULA-025-D SA250-N 36236
ALS15 FULA-030-S SA300-48 104761-7
ALS16 FULA-030-D YCA30R-2N SA300-N 36237
ALS17 FULA-035-S YCAK31AG1 SA350-48 104761-8
ALS18 FULA-035-D YCA321R-2N SA350-N 36238
ALS19 FULA-R033-S SA400-48 104761-9
ALS20 FULA-R033-D YCA33R-2N SA400-N 36239
ALS23 FULA-045-S SA500-48
ALS24 FULA-045-D YCA35R-2N SA500-N 36950
ALS28 YCA37R-2N
ALS32 YCA39R-2N
ALS44 YCA43R-2N
ALS60 YCA48R-2N
Type WRQ and WRS Wide Range Compression Stirrups
Blackburn Penn Union Burndy Kearney
WRQ154
WRQ152 YCB4U1 101400
WRQ172 KBO-1/0-2 YCB1U1 101400-01
WRQ232 KBD-2/0-2 YCB28U26 101400-02
WRQ352 KBD-4/0 YCB28U26 101400-03
WRQ698 YCB38R26U 101400-04
WRS154
WRS152
WRS172 KKBO-1/0-2 YCB25R
WRS232 KKBO-2/0-2
WRS352 KKBO-4/0-2
WRS719
WRS819
Type SC Wide Range Compression Stirrups
Blackburn Penn Union Kearney
SCO02 KKBO-R2-2 40894
SCO21 KKBO-1/0-2 36104
SCD41 KKBO-4/0-2 104307
COMPRESSION CONNECTORS
COMPRESSION STIRRUP CONNECTORS
Reference
Tables
ConneCtors
75
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
Type ATS Automatic Splices
Blackburn Fargo Reliable
ATS4-S GL402 7651
ATS42 GL402; GL404 7651, 7652
ATS2 GL404 7652
ATS10 GL406 7653
ATS1020 GL406, GL407 7653, 7654
ATS3040 GL408, GL409 7655, 7656
ATS40 GL409 7656
ATS266336 GL1315A 7657, 7658
ATS397477 GL1325A 7659
Type ATD-ZB Stainless Steel Bail
Blackburn Fargo Reliable
ATD42ZB GD402Z, GD404Z 7651SDS, 7652SDS
ATD1020ZB GD406Z, GD407Z 7653SDS, 7654SDS
ATD3040ZB GD408Z, GD409Z 7655SDS, 7656SDS
ATD266336ZB GD1205AZ, GD1315AZ 7657SDS, 7658SDS
ATD397477ZB GD1325AZ 7659SDS
Type ATD-CB Clevis Bracket
Blackburn Fargo Reliable
ATD42CB GD442, GD444 7651LD, 7651LD
ATD1020CB GD446, GD447 7653LD, 7654LD
ATD3040CB GD448, GD449 7655LD, 7656LD
ATD266336CB GD5315A 7657LD, 7658LD
ATD397477CB GD5325A 7659LD
Type ATD-FB Flexible Bail
Blackburn Fargo Reliable
ATD42FB GD402, GD404 7651FD, 7652FD
ATD1020FB GD406, GD407 7653FD, 7654FD
AUTOMATIC CONNECTORS
WEDGE CLAMPS
Type W Aluminum Service Wedge Clamps- ACSR, Aluminum, AAAC Conductor
Blackburn Reliable
W62-1 7195
W62-1FC 7195F
W20-1 7187
W20-1FC 7187F
W40-1 7197
W40-1FC 7187F
W62-1B 7195I
W62-1BFC 7195FI
W20-1B 7187I
W20-1BFC 7187FI
W40-1B 7187I
W40-1BFC 7187FI
Type ATDG Guystrand Connectors
Blackburn Strand Size Fargo Reliable
ATDG14 1/4” GDE-5100 5100
ATDG516 5/16” GDE-5101 5101
ATDG38 3/8” GDE-5102 5102
ATDG716 7/16” – 5203
ATDG14L 1/4” 5000 5000-L
ATDG516L 5/16” 5001 5001-L
ATDG38L 3/8” 5002 5002-L
ATDG716L 7/16” – –
Type ATSG Guystrand Splices
Blackburn Strand Size Fargo Reliable
ATSG14 1/4” – 5000
ATSG516 5/16” – 5001
ATSG38 3/8” – 5002
ATSG716 7/16” – –
Reference
Tables
ConneCtors
76
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Competitive Cross Reference
Type JAB Ground Rod Clamps
Blackburn Penn Union Burndy Ilsco Eritech Anderson Josyln Dossert
JAB12 CAB-1 GRC12 CGRC48 HDC12 J8391AB GNA50
JAB58 CAB-2 GRC58 CGRC58 J8392AB GNA62
JAB34 CAB-3 HDC34 J8393AB GNA75
JAB34C GRC3426 CGRC68
JAB1
JAB12H CAB-1 HDC12 GC-103-01 J8491AB GN-50
JAB58H CAB-2 HDC58R GC-103-02 A8393AB GN-62
JAB34H CAB-3 HDC34 GC-103-03 J8493AB GN-75
JAB1H
Type G Budget Line Ground Rod Clamps
Blackburn Penn Union Burndy Ilsco Eritech Anderson Dossert
G3 CAB-1 GRC38 CP38
G4 CEB-1 GRC-12 GRC-48 CP12 GC-4 GNL50
G5 CEB-2 GRC-58 GRC-58 CP58 GC-5 GNL62
G6 CEB-3 GRC34 GRC-68 CP34 GC-6 GNL75
GROUND CONNECTORS
Type TTC Transformer Tank Ground Connectors
Blackburn Penn Union Burndy Anderson Dossert Eritech
TTC2 HGSE-020 EQC632C GTCL-34A TGC210
TTC3 HGSE-C1 GTCL-23A TGC8-50
TTC4
TTC2P
TTC3P GSE-C1TN GTC23A-TP TGC8-50SN
TTC4P
Reference
Tables
ConneCtors
77
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Tool Cross Reference
Blackburn/T&B
Mechanical Hydraulic
OD58 Series & TBM6H
Die Hydraulic Head JB12B, TBM14M Burndy Alcoa/
Designation (Except as Noted) 13100A, TBM15 Mechanical Hydraulic Other EEI
BY31
5/8 13474/13477* B58CS W-BG U-BG G, TU, Peach
(Orange/Tan Nest)
BY37 B49EA W-K840 U-K840
840 13474/13477* 15512 U-249 TX
(Red/Blue Nest)
O OJB HO W-O U-O B11AH
13470* 15501-A
D DBL HD U-D BD
13471* 15502
N HN U-N BN
15612**
R 15620** U-R
B, T, BKT BY45, BY49 HBKT W-KB
W-BG
K BY47 HBKT W-KK
C BY33 HBKC W-C U-C
KC B39EA W-247 U-247
U-167
J, 5/16 BY19 B73AH W161 U-161 TP
BY51 W-242 U-242
P, 3/8 BY21 B71AH W-162 U-162 TK
BY53 15513 TL, TN, TB
B17EA
1/2, 510, 500 BY23 15526 W-163 U-163 B06AH 6A
B72AH TQ, TS
W-BG U-BG, U-165 B08AH 8A
5/8-1, 620 BY31 B24EA W-165
W-243 U-243 TU
635 BY41 B30EA W-245 U-245 TWTY 9A
W-687 B09AH
W-C
737 B39EA W-247 U-247 B10AH
W-167 U-167
747 BY33 15534 W-694 U-694 TV 10A
W-702
781 BY35 B74AH W-247 U-247
U-659
B49EA U-249 TX 11A
840, 845 BY37 15514 W-249 U-658
15512 U-168 B11AH
B75AH U-251 TH
1 15506
B61EA U654 B12AH 12A
B80EA U-321
1 1/8-1 B20AH U-490, U-317 B13AH 13A
15536 U468, U426
15505 U547, U-655 14A
B76AH U-318, U-327
1 5/16 B78AH U-261 B14AH 14A
B20AH
15515 U-788
All Blackburn and Alcoa “B” Series Dies and Burndy “U” Dies fit the T&B/Blackburn Hydraulic Tools listed.
Adapter 15500TB required with TBM15.
* Fit TBM6, 6S, and TBM60RS. (Same as Homac UT5 and “H” series Dies)
** Fit TBM15 only
For reference only. Connectors may require a specific die for proper application.
DIE CROSS REFERENCE
Reference
Tables
ConneCtors
78
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Cross Reference
Compacted Copper or
Conductor ACSR or Rated Aluminum Rated ACSR or Rated Rated Copperweld Rated
Diameter All Breaking Alloy Breaking All Breaking Breaking Copper Breaking
(in.) Aluminum Strength (5005-6201) Strength Aluminum Strength AWAC Strength Composite Strength
.162 #6, Solid 474.0 #6, Solid 1,280
.169 #6, 7W 528
.174 91⁄2D 1,743
.179 8C 1,362
.182 #5, Solid 597.7 #6, 6/1 1,170 #5, Solid 1,591
.184 #6, 7W 560 #6, 7W 1,228
.198 #6, 6/1 1,170 #6, 7W 555
.199 8A 2,233
.201 #6, 3W 915
.202 #6, 3W 1,204
.204 #4, Solid 753.9 #4, Solid 1,970
.206 #5, 7W 1,542
.213 #4, 7W 826
.219 8D 3,256
.223 #5, 6/1 1,460 7A 2,754
.225 6C 2,143
.226 #5, 3W 1,516
.229 #3, Solid 929.9 #4, 6/1 1,830 #3, Solid 2,439
.230 6A 2,585
.232 #4, 7W 915 #4, 7W 1,938
.236 #4, 7/1 2,288
.245 #4, 6/1 1,783
.246 7D 4,022
.250 #4, 6/1 1,830 #4, 7W 875
.257 #4, 7/1 2,290
.258 #2, Solid 1,172.6 #3, 6/1 2,250 #2, Solid; 5A 3,003; 3,193
.260 #3, 7W 1,100 #3, 7W 2,433
.261 #4, 5/2 2,830
.268 #2, 7W 1,266
.276 6D 4,942
.281 #3, 6/1 2,250 #4, 4/3 4,305
.286 #3, 3W 2,359
.289 #1, Solid 3,688
.290 #2, 6/1 2,790 4A 3,938
.292 #2, 7W 1,340 #2, 7W 3,045
.298 #2, 7/1 3,525
.301 #1, 7W 1,537
.307 #4, 3/4 6,325
.308 2F 4,233
.309 #2, 6/1 2,760
.310 5D 6,035
.316 #2, 6/1 2,790 #2, 7W 2,195
.320 #2, 3W 2,913
.325 #2, 7/1 3,525 1/0, Solid 4,517
.326 #1, 6/1 3,480 5P 9,311
.327 2G 5,626
.328 #1, 7W 1,620 #1, 7W; 4N 3,804; 8,460
.330 #2, 5/2 4,436
.332 #1, 19W 1,685 #1, 19W 3,899
.338 1/0, 7W 1,865
.340 1/0, 19W 2,090 #4, 2/5 9,314
.346 1F 5,266
BARE CONDUCTOR INFORMATION AWG OR KCMIL
Reference
Tables
ConneCtors
79
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Cross Reference
BARE CONDUCTOR INFORMATION AWG OR KCMIL (continued)
Compacted Copper or
Conductor ACSR or Rated Aluminum Rated ACSR or Rated Rated Copperweld Rated
Diameter All Breaking Alloy Breaking All Breaking Breaking Copper Breaking
(in.) Aluminum Strength (5005-6201) Strength Aluminum Strength AWAC Strength Composite Strength
.348 4D 7,340
.349 2J 7,322
.355 #1, 6/1 3,480 #2, 4/3 6,785
.360 #1, 3W 3,620
.365 1/0, 6/1 4,280 2/0, Solid 5,519
.366 2A; 4P 5,876; 11,420
.367 80, 8/1 5,200 1G 6,956
.368 1/0, 7W 1,970 1/0, 7W; 3N 4,750; 10,390
.372 1/0, 19W 4,901
.373 1/0, 19W 2,090
.377 2K 9,730
.381 2/0, 7W 2,350
.382 2/0, 19W 2,586
.386 #2, 3/4 9,793
.388 1/0F 6,536
.390 1/0, 6/1 4,246 1/0, 12W 4,841
.392 1J 9,000
.398 1/0, 6/1 4,280 1/0, 7W 3,405
.410 2/0, 6/1 5,345
.411 3P 13,910
.412 1/0G 8,563
.413 2N 12,680
.414 2/0, 7W 2,485 2/0, 7W 5,927
.416 1/0, 5/2 6,712
.419 2/0, 19W 2,586 2/0, 19W 6,152
.423 1K 11,900
.426 3/0, 7W 2,845
.428 3/0, 19W 3,200
.429 #2, 2/5 14,060
.436 2/0F 8,094
.438 2/0, 6/1 5,135 2/0, 12W 6,048
.440 1/0J 10,970
.447 2/0, 6/1 5,345 2/0, 7W 4,230 1/0, 4/3 10,020
.461 101.8, 12/7 9,860 3/0, 6/1 6,675
.462 2P 16,870
.463 2/0G 10,510
.464 3/0, 7W 3,005 3/0, 7W; IN 7,366; 15,410
.467 2/0, 5/2 8,040
.470 3/0, 19W 3,200 3/0, 19W 7,698
.475 1/0K 14,490
.480 4/0, 7W 3,590
.481 110.8, 12/7 10,730 4/0, 19W 3,890
.487 1/0, 3/4 14,006
.492 3/0, 12W 7,556
.494 2/0J 13,430
.502 3/0, 6/1 6,675 3/0, 7W 4,965 2/0, 4/3 12,000
.517 4/0, 6/1 8,420
.522 4/0, 7W 3,590 4/0, 7W 9,154
.523 250, 19W 4,506
.528 4/0, 19W 3,980 4/0, 19W 9,617
.530 134.6, 12/7 12,920
.534 2/0K 17,600
.537 266.8, 7W 4,775
.540 266.8, 19W 4,800
.541 1/0, 2/5 20,030
.550 4/0F 12,290
Reference
Tables
ConneCtors
80
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Cross Reference
BARE CONDUCTOR INFORMATION AWG OR KCMIL (continued)
Compacted Copper or
Conductor ACSR or Rated Aluminum Rated ACSR or Rated Rated Copperweld Rated
Diameter All Breaking Alloy Breaking All Breaking Breaking Copper Breaking
(in.) Aluminum Strength (5005-6201) Strength Aluminum Strength AWAC Strength Composite Strength
.552 4/0, 6/1 7,685 4/0, 12W 9,483
.559 266.8, 18/1 7,100
.563 4/0, 6/1 8,420 4/0, 7W 6,265
.571 4/0EK 15,370
.573 300, 19W 5,301
.574 250, 19W 250, 19W 11,360
.575 250, 37W 4,860 4/0, 15/4 10,870 250, 37W 11,560
.576 159, 12/7 15,200
.583 4/0G 15,640
.586 266.8, 7W 4,780
.593 266.8, 19W 4,810 300, 18/1 7,990
.594 266.8, 37W
.600 250, 12W 11,130
.603 336.4, 7W 5,885
.607 176.9, 12/7 16,440 336.4, 19W 5,940
.609 266.8, 18/1 7,100
.613 4/0E 20,730
.618 350, 19W 6,185
.621 250EK 17,840
.628 300, 19W 5,890 336.4, 18/1 8,950 300, 19W 13,510
.630 300, 37W 5,830 300, 37W 13,870
.631 190.8, 12/7 17,730
.633 266.8, 6/7 9,645
.642 266.8, 26/7 11,250 266.8, 19W 8,180
.657 300, 12W 13,170
.660 397.5, 19W 6,880
.664 211.3, 12/7 19,640
.666 336.4, 19W 5,945 250E 23,920
.678 350, 19W 15,590
.679 350, 19W 6,180 336.4, 18/1 8,650
.680 300, 26/7 12,650 300EK 20,960
.681 350, 37W 6,680 350, 37W 16,060
.682 397.5, 18/1 10,040
.684 336.4, 18/1 8,950
.700 300, 30/7 15,430
.710 350, 12W 15,140
.714 203.2, 16/19 27,500
.721 336.4, 26/7 14,050
.722 477, 19W 8,090
.724 397.5, 19W 6,885
.726 400, 19W 17,560
.728 400, 37W 7,350 400, 37W 18,320
.729 300E 27,770
.735 350EK 23,850
.739 500, 19W 8,480
.741 336.4, 30/7 17,040
.742 477, 18/1 11,870
.743 397.5, 18/1 10,400
.770 450, 19W 19,750
.772 450, 37W 8,110 450, 37W 20,450
.780 556, 19W 9,440
.782 397.5, 19W 11,840
.783 397.5, 26/7 16,190
.788 350E 32,420
.793 477, 19W 8,090
.795 477, 37W 8,600
Reference
Tables
ConneCtors
81
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Cross Reference
Compacted Copper or
Conductor ACSR or Rated Aluminum Rated ACSR or Rated Rated Copperweld Rated
Diameter All Breaking Alloy Breaking All Breaking Breaking Copper Breaking
(in.) Aluminum Strength (5005-6201) Strength Aluminum Strength AWAC Strength Composite Strength
.801 556.5, 18/1 13,850
.806 397.5, 30/7 19,980
.811 500, 19W 9,425 500, 19W 21,950
.813 500, 37W 9,010 500, 37W 22,510
.814 477, 18/1 12,300
.834 636, 19W 10,790
.846 477, 24/7 17,200
.853 550, 37W 24,760
.855 500, 61W 10,490 550, 61W 25,230
.856 556, 19W 9,440
.858 477, 26/7 19,430 477, 19W 13,450
556.5, 37W 9,835
.862 636, 18/1 15,830
.879 556.5, 18/1 14,300
.883 477, 30/7 23,300
.891 600, 37W 27,020
.893 600, 61W 11,450 600, 61W 27,530
.904 500, 30/7 24,450
.914 556.5, 24/7 9,925
.918 636, 37W 11,240
.927 556.5, 26/7 19,850 556.5, 19W 15,680
.928 650, 37W 29,130
.929 650, 61W 11,940 650, 61W 29,770
.932 795, 19W 16,540
.940 636, 18/1 16,400
.953 556.5, 30/7 27,200
.953 605, 24/7 21,500
.953 605, 54/7 22,500
.962 700, 37W 31,170
.964 700, 61W 12,860 700, 61W 31,820
.966 605, 26/7 24,100
.974 715.5, 37W 12,640
.975 715.5, 61W 13,150
.977 636, 24/7 22,600
.977 636, 54/7 23,600
.981 874.5, 37W 14,830
.990 636, 26/7 25,000 636, 37W 19,110
.994 605, 30/19 30,000 874.5, 36/1 17,900
.997 750, 37W 14,430 750, 37W 33,400
.998 750, 61W 13,510 750, 61W 34,090
1.000 666.6, 24/7 23,700
1.000 666.6, 54/7 24,500
1.019 636, 30/19 30,500
1.024 954, 37W 16,180
1.026 795, 37W 13,770
1.028 795, 61W 14,330
1.029 800, 37W 35,120
1.031 800, 61W 14,410 800, 61W 36,360
1.039 954, 36/1 19,520
1.040 795, 36/1 10,000
1.051 715.5, 26/7 28,100
1.061 850, 37W 37,310
1.062 850, 61W 38,270
1.063 795, 45/7 22,900
1.077 874.5, 37W 14,840
1.078 874.5, 61W 15,760
BARE CONDUCTOR INFORMATION AWG OR KCMIL (continued)
Reference
Tables
ConneCtors
82
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Cross Reference
BARE CONDUCTOR INFORMATION AWG OR KCMIL (continued)
Compacted Copper or
Conductor ACSR or Rated Aluminum Rated ACSR or Rated Rated Copperweld Rated
Diameter All Breaking Alloy Breaking All Breaking Breaking Copper Breaking
(in.) Aluminum Strength (5005-6201) Strength Aluminum Strength AWAC Strength Composite Strength
1.081 715.5, 30/19 34,600
1.092 900, 37W 39,510
1.093 795, 54/7 28,500
1.094 900, 61W 15,900 900, 61W 40,520
1.108 795, 26/7 31,200 795, 37W 23,590
1.124 954, 37W 16,180
1.126 954, 61W 16,860
1.140 795, 30/19 38,400
1.146 874.5, 54/7 31,400
1.151 1,000, 37W 1,000, 37W 43,830
1.152 1,000, 61W 17,670 1,000, 61W 45,030
1.162 900, 54/7 32,300
1.165 954, 45/7 26,900
1.170 1,033.5, 37W 17,530
1.172 1,033.5, 61W 18,260
1.196 954, 54/7 34,200
1.213 1,033.5, 45/7 28,900
1.216 1,113, 61W 19,670
1.246 1,033.5, 54/7 37,100
1.258 1,192.5, 61W 21,070
1.259 1,113, 45/7 30,900
1.288 1,468 36/1 30,000
1.293 1,113, 54/19 40,200
1.300 1,272, 61W 22,030
1.302 1,192.5, 45/7 33,200
1.333 1,192.5, 54/19 43,100
1.340 1,351.5, 61W 23,400
1.345 1,272, 45/7 35,400
1.379 1,431, 61W 23,400
1.382 1,272, 54/19 44,800
1.417 1,510.5, 61W 25,630
1.424 1,351.5, 54/19 47,600
1.427 1,431, 45/7 39,800
1.443 1,431, 54/19, 50,400
1,590, 61W 26,970
1.454 1,590, 91W 28,100
1.465 1,431, 54/19 50,400
1.504 1,590, 45/7 43,800
1.506 1,510.5, 54/19 53,300
1.545 1,590, 54/19 56,000
1.602 1,780, 84/19 53,600
1.630 2,000, 91W 34,640
1.823 2,500, 91W 42,410
1.996 3,000, 127W 50,890
2.158 3,500, 127W 59,380
Reference
Tables
ConneCtors
83
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Stranding/Wire Approximate
Metric Wire Diameter Overall
Circ. Mils AWG Size Equivalent per Strand Diameter
Typical Size mm2 Circ. Mils in. mm in. mm
0.50 987 1/.032 1/.813 .032 0.81
1020 20 7/.0121 7/.307 .036 0.91
0.75 1480 1/.039 1/.991 .039 0.99
1620 18 1/.0403 1/1.02 .040 1.02
1620 18 7/.0152 7/.386 .046 1.16
1.0 1974 1/.045 1/1.14 .045 1.14
1.0 1974 7/.017 7/.432 .051 1.30
2580 16 1/.0508 1/1.29 .051 1.29
2580 16 7/.0192 7/.488 .058 1.46
1.5 2960 1/.055 1/1.40 .055 1.40
1.5 2960 7/.021 7/5.33 .063 1.60
4110 14 1/.0641 1/1.63 .064 1.63
4110 14 7/.0242 7/.615 .073 1.84
2.5 4934 1/.071 1/1.80 .071 1.80
2.5 4934 7/.027 7/.686 .081 2.06
6530 12 1/.0808 1/2.05 .081 2.05
6530 12 7/.0305 7/.775 .092 2.32
4 7894 1/.089 1/2.26 .089 2.26
4 7894 7/.034 7/.864 .102 2.59
10380 10 1/.1019 1/2.59 .102 2.59
10380 10 7/.0385 7/.978 .116 2.93
6 11840 1/.109 1/2.77 .109 2.77
6 11840 7/.042 7/.107 .126 3.21
13090 9 1/.1144 1/2.91 .1144 2.91
13090 9 7/.0432 7/1.10 .130 3.30
16510 8 1/.1285 1/3.26 .128 3.26
16510 8 7/.0486 7/1.23 .146 3.70
10 19740 1/.141 1/3.58 .141 3.58
10 19740 7/.054 7/1.37 .162 4.12
20820 7 1/.1443 1/3.67 .144 3.67
20820 7 7/.0545 7/1.38 .164 4.15
26240 6 1/.162 1/4.11 .162 4.11
26240 6 7/.0612 7/1.55 .184 4.66
16 31580 7/.068 7/1.73 .204 5.18
33090 5 7/.0688 7/1.75 .206 5.24
41740 4 7/.0772 7/1.96 .232 5.88
25 49340 7/.085 7/2.16 .255 6.48
25 49340 19/.052 19/1.32 .260 6.60
52620 3 7/.0867 7/2.20 .260 6.61
66360 2 7/.0974 7/2.47 .292 7.42
35 69070 7/.100 7/2.54 .300 7.62
35 69070 19/.061 19/1.55 .305 7.75
Conductor Cross Reference
AWG / KCMIL VS. METRIC WIRE SIZES – OPTION 1
Reference
Tables
ConneCtors
84
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Conductor Cross Reference
Stranding/Wire Approximate
Metric Wire Diameter Overall
Circ. Mils AWG Size Equivalent per Strand Diameter
Typical Size mm2 Circ. Mils in. mm in. mm
83690 1 19/.0664 19/1.69 .332 8.43
50 98680 19/.073 19/1.85 .365 9.27
105600 1/0 19/.0745 19/1.89 .373 9.46
133100 2/0 19/.0837 19/2.13 .419 10.6
70 138100 19/.086 19/2.18 .430 10.9
167800 3/0 19/.094 19/2.39 .470 11.9
167800 3/0 37/.0673 37/1.71 .471 12.0
95 187500 19/.101 19/2.57 .505 12.8
95 187500 37/.072 37/1.83 .504 12.8
211600 4/0 19/.1055 19/2.68 .528 13.4
120 237.8 KCMIL 37/.081 37/2.06 .567 14.4
250 KCMIL 37/.0822 37/2.09 .575 14.6
300 KCMIL 150 37/.090 37/2.29 .630 16.0
350 KCMIL 37/.0973 37/2.47 .681 17.3
185 365.1 KCMIL 37/.100 37/2.54 .700 17.8
400 KCMIL 37/.104 37/2.64 .728 18.5
240 473.6 KCMIL 37/.114 37/2.90 .798 20.3
240 473.6 KCMIL 61/.089 61/2.26 .801 20.3
500 KCMIL 37/.1162 37/2.95 .813 20.7
500 KCMIL 61/.0905 61/2.30 .814 20.7
300 592.1 KCMIL 61/.099 61/2.51 .891 22.6
600 KCMIL 61/.0992 61/2.52 .893 22.7
700 KCMIL 61/.1071 61/2.72 .964 24.5
750 KCMIL 61/.1109 61/2.82 .998 25.4
750 KCMIL 91/.0908 91/2.31 .999 25.4
400 789.4 KCMIL 61/.114 61/2.90 1.026 26.1
800 KCMIL 61/.1145 61/2.91 1.031 26.2
800 KCMIL 91/.0938 91/2.38 1.032 26.2
1000 KCMIL 500 986.8 KCMIL 61/.1280 61/3.25 1.152 29.3
1000 KCMIL 91/.1048 91/2.66 1.153 29.3
625 1233.7 KCMIL 91/.117 91/2.97 1.287 32.7
1250 KCMIL 91/.1172 91/2.98 1.289 32.7
1250 KCMIL 127/.0992 127/2.52 1.290 32.8
1500 KCMIL 91/.1284 91/3.26 1.412 35.9
1500 KCMIL 127/.1087 127/2.76 1.413 35.9
800 1578.8 KCMIL 91/.132 91/3.35 1.452 36.9
1000 1973.5 KCMIL 91/.147 91/3.73 1.617 41.1
2000 KCMIL 127/.1255 127/3.19 1.632 41.5
2000 KCMIL 169/.1088 169/2.76 1.632 41.5
AWG / KCMIL VS. METRIC WIRE SIZES – OPTION 1 (continued)
Reference
Tables
ConneCtors
85
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Stranding/ Wire
Approximate Overall Metric Wire Diameter
Diameter Circ. AWG Size Equivalent per Strand
in. mm Mils Size mm2 Circ. Mils in. mm
.032 0.81 0.50 987 1/.032 1/.813
.036 0.91 1020 20 7/.0121 7/.307
.039 0.99 0.75 1480 1/.039 1/.991
.040 1.02 1620 18 1/.0403 1/1.02
.046 1.16 1620 18 7/.0152 7/.386
.045 1.14 1.0 1974 1/.045 1/1.14
.051 1.30 1.0 1974 7/.017 7/.432
.051 1.29 2580 16 1/.0508 1/1.29
.058 1.46 2580 16 7/.0192 7/.488
.055 1.40 1.5 2960 1/.055 1/1.40
.063 1.60 1.5 2960 7/.021 7/5.33
.064 1.63 4110 14 1/.0641 1/1.63
.073 1.84 4110 14 7/.0242 7/.615
.071 1.80 2.5 4934 1/.071 1/1.80
.081 2.06 2.5 4934 7/.027 7/.686
.081 2.05 6530 12 1/.0808 1/2.05
.092 2.32 6530 12 7/.0305 7/.775
.089 2.26 4 7894 1/.089 1/2.26
.102 2.59 4 7894 7/.034 7/.864
.102 2.59 10380 10 1/.1019 1/2.59
.116 2.93 10380 10 7/.0385 7/.978
.109 2.77 6 11840 1/.109 1/2.77
.126 3.21 6 11840 7/.042 7/.107
.1144 2.91 13090 9 1/.1144 1/2.91
.130 3.30 13090 9 7/.0432 7/1.10
.128 3.26 16510 8 1/.1285 1/3.26
.146 3.70 16510 8 7/.0486 7/1.23
.141 3.58 10 19740 1/.141 1/3.58
.162 4.12 10 19740 7/.054 7/1.37
.144 3.67 20820 7 1/.1443 1/3.67
.164 4.15 20820 7 7/.0545 7/1.38
.162 4.11 26240 6 1/.162 1/4.11
.184 4.66 26240 6 7/.0612 7/1.55
.204 5.18 16 31580 7/.068 7/1.73
.206 5.24 33090 5 7/.0688 7/1.75
.232 5.88 41740 4 7/.0772 7/1.96
.255 6.48 25 49340 7/.085 7/2.16
.260 6.60 25 49340 19/.052 19/1.32
.260 6.61 52620 3 7/.0867 7/2.20
.292 7.42 66360 2 7/.0974 7/2.47
.300 7.62 35 69070 7/.100 7/2.54
.305 7.75 35 69070 19/.061 19/1.55
AWG / KCMIL VS. METRIC WIRE SIZES – OPTION 2
Conductor Cross Reference
Reference
Tables
ConneCtors
86
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Stranding/ Wire
Approximate Overall Metric Wire Diameter
Diameter Circ. AWG Size Equivalent per Strand
in. mm Mils Size mm2 Circ. Mils in. mm
.332 8.43 83690 1 19/.0664 19/1.69
.365 9.27 50 98680 19/.073 19/1.85
.373 9.46 105600 1/0 19/.0745 19/1.89
.419 10.6 133100 2/0 19/.0837 19/2.13
.430 10.9 70 138100 19/.086 19/2.18
.470 11.9 167800 3/0 19/.094 19/2.39
.471 12.0 167800 3/0 37/.0673 37/1.71
.505 12.8 95 187500 19/.101 19/2.57
.504 12.8 95 187500 37/.072 37/1.83
.528 13.4 211600 4/0 19/.1055 19/2.68
.567 14.4 120 237.8 KCMIL 37/.081 37/2.06
.575 14.6 250 KCMIL 37/.0822 37/2.09
.630 16.0 300 KCMIL 150 37/.090 37/2.29
.681 17.3 350 KCMIL 37/.0973 37/2.47
.700 17.8 185 365.1 KCMIL 37/.100 37/2.54
.728 18.5 400 KCMIL 37/.104 37/2.64
.798 20.3 240 473.6 KCMIL 37/.114 37/2.90
.801 20.3 240 473.6 KCMIL 61/.089 61/2.26
.813 20.7 500 KCMIL 37/.1162 37/2.95
.814 20.7 500 KCMIL 61/.0905 61/2.30
.891 22.6 300 592.1 KCMIL 61/.099 61/2.51
.893 22.7 600 KCMIL 61/.0992 61/2.52
.964 24.5 700 KCMIL 61/.1071 61/2.72
.998 25.4 750 KCMIL 61/.1109 61/2.82
.999 25.4 750 KCMIL 91/.0908 91/2.31
1.026 26.1 400 789.4 KCMIL 61/.114 61/2.90
1.031 26.2 800 KCMIL 61/.1145 61/2.91
1.032 26.2 800 KCMIL 91/.0938 91/2.38
1.152 29.3 1000 KCMIL 500 986.8 KCMIL 61/.1280 61/3.25
1.153 29.3 1000 KCMIL 91/.1048 91/2.66
1.287 32.7 625 1233.7 KCMIL 91/.117 91/2.97
1.289 32.7 1250 KCMIL 91/.1172 91/2.98
1.290 32.8 1250 KCMIL 127/.0992 127/2.52
1.412 35.9 1500 KCMIL 91/.1284 91/3.26
1.413 35.9 1500 KCMIL 127/.1087 127/2.76
1.452 36.9 800 1578.8 KCMIL 91/.132 91/3.35
1.617 41.1 1000 1973.5 KCMIL 91/.147 91/3.73
1.632 41.5 2000 KCMIL 127/.1255 127/3.19
1.632 41.5 2000 KCMIL 169/.1088 169/2.76
AWG / KCMIL VS. METRIC WIRE SIZES – OPTION 2 (continued)
Conductor Cross Reference
Index
ConneCtors
87
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
AC10-TB ........................21
AC2-TB .........................21
AC20 ...........................21
AC205 ..........................21
AC266 ..........................21
AC30 ...........................21
AC336 ..........................21
AC350 ..........................21
AC397 ..........................21
AC4-BB .........................21
AC40 ...........................21
AC477 ..........................21
AC556 ..........................21
AC6-TB .........................21
ACJ20 ..........................19
ACJ205 .........................19
ACJ266 .........................19
ACJ336 .........................19
ACJ350 .........................19
ACJ397 .........................19
ACJ40 ..........................19
ACJ477 .........................19
ACJ556 .........................19
AL10 ...........................24
AL11 ...........................24
AL12 ...........................24
AL16 ...........................24
AL18 ...........................24
AL20 ...........................24
AL24 ...........................24
AL28 ...........................24
AL32 ...........................24
AL4 ............................24
AL44 ...........................24
AL5 ............................24
AL581 ..........................25
AL582 ..........................25
AL583 ..........................25
AL584 ..........................25
AL585 ..........................25
AL586 ..........................25
AL6 ............................24
AL60 ...........................24
AL7 ............................24
AL8 ............................24
AL9 ............................24
ALS1 ...........................25
ALS10 ..........................25
ALS11 ..........................25
ALS12 ..........................25
ALS13 ..........................25
ALS14 ..........................25
ALS15 ..........................25
ALS16 ..........................25
ALS17 ..........................25
ALS18 ..........................25
ALS19 ..........................25
ALS2 ...........................25
ALS20 ..........................25
ALS23 ..........................25
ALS24 ..........................25
ALS28 ..........................25
ALS3 ...........................25
ALS32 ..........................25
ALS4 ...........................25
ALS44 ..........................25
ALS5 ...........................25
ALS6 ...........................25
ALS60 ..........................25
ALS7 ...........................25
ALS8 ...........................25
ALS9 ...........................25
ATD1020CB .....................32
ATD1020FB ......................32
ATD1020ZB ......................31
ATD266336CB ...................32
ATD266336ZB ....................31
ATD3040CB .....................32
ATD3040ZB ......................31
ATD397477CB ...................32
ATD397477ZB ....................31
ATD42CB .......................32
ATD42FB ........................32
ATD42ZB ........................31
ATDG14. . . . . . . . . . . . . . . . . . . . . . . . . 33
ATDG38. . . . . . . . . . . . . . . . . . . . . . . . . 33
ATDG516. . . . . . . . . . . . . . . . . . . . . . . . 33
ATDG716. . . . . . . . . . . . . . . . . . . . . . . . 33
ATDG14-L .......................33
ATDG38-L .......................33
ATDG516-L ......................33
ATDG716-L ......................33
ATS10 ..........................30
ATS1020 ........................30
ATS2 ...........................30
ATS20 ..........................30
ATS266336 ......................30
ATS30 ..........................30
ATS3040 ........................30
ATS397477 ......................30
ATS4 ...........................30
ATS40 ..........................30
ATS42 ..........................30
ATS4-S .........................30
ATSG14 .........................34
ATSG516 ........................34
ATSG38 .........................34
ATSG716 ........................34
BPLT6BSCR .....................58
BPLT14BSCR ....................58
BPLT14BSCRI. . . . . . . . . . . . . . . . . . . . 59
BPLT15BSCR-B . . . . . . . . . . . . . . . . . . 59
C2BB ...........................14
C5BB ...........................14
C7 .............................14
C9 .............................14
C9L ............................14
CCS44 ..........................28
CF1010-1 .......................13
CF102-1 ........................13
CF2020-1 .......................13
CF202-1 ........................13
CF22-1 .........................13
CF4010-1 .......................13
CF402-1 ........................13
CF4040-1 .......................13
CF44-1 .........................13
CFS22-1 ........................13
CFS44-1 ........................13
CS61 ...........................14
CS62 ...........................14
CS63 ...........................14
CS64 ...........................14
CS65 ...........................14
CS66 ...........................14
CS67 ...........................14
CS68 ...........................14
CS69 ...........................14
CS70 ...........................14
CS71 ...........................14
CS72 ...........................14
CS73 ...........................14
CS74 ...........................14
CS75 ...........................14
CS76 ...........................14
CS77 ...........................14
CS78 ...........................14
CS84 ...........................14
CS85 ...........................14
CSC61 ..........................14
CSC62 ..........................14
CSC63 ..........................14
CSC64 ..........................14
CSC65 ..........................14
CSC66 ..........................14
CSC67 ..........................14
CSC68 ..........................14
CSC69 ..........................14
CSC70 ..........................14
CSC71 ..........................14
CSC72 ..........................14
CSC73 ..........................14
CSC74 ..........................14
CSC75 ..........................14
CSC76 ..........................14
CSC77 ..........................14
CSC78 ..........................14
CSC84 ..........................14
CSC85 ..........................14
CTS27 ..........................23
CTS4 ...........................23
CTS407 .........................23
CTS6 ...........................23
CTS6ACW .......................23
CTS8 ...........................23
DA15-U .........................59
DGC58-44 .......................51
DGC58-46 .......................51
DGC58-66 .......................51
DLC2106 ........................46
DLC23 ..........................46
DLC25 ..........................46
EC-S8C .........................63
G3 .............................50
G4 .............................50
G5 .............................50
G6 .............................50
GCA-1 ..........................56
GCA-2 ..........................56
GCA-3 ..........................56
GG12 ...........................51
GG12H .........................51
GG34H .........................51
GG58 ...........................51
GG58H .........................51
GP100 ..........................53
GP1003 .........................53
GP1008 .........................53
GP110 ..........................53
GP1108 .........................53
GP114 ..........................53
HLC2108 ........................47
HLC2108AP9 ....................47
HLC2108P .......................47
HLC3974 ........................47
HLC3974AP .....................47
HLC3974P .......................47
ICS61-1 .........................16
ICS62-1 .........................16
ICS63-1 .........................16
ICS64-1 .........................16
ICS65-1 .........................16
ICS66-1 .........................16
ICS67-1 .........................16
ICS68-1 .........................16
ICS70-1 .........................16
ICS71-1 .........................16
ICS72-1 .........................16
ICS73-1 .........................16
ICS74-1 .........................16
ICS75-1 .........................16
ICS76-1 .........................16
ICS77-1 .........................16
ICS78-1 .........................16
IKL34 ...........................17
IKL35 ...........................17
IKL36 ...........................17
IKL44 ...........................17
IKL45 ...........................17
IKL46 ...........................17
IKL47 ...........................17
IKL54 ...........................17
IKL55 ...........................17
IKL56 ...........................17
IKL57 ...........................17
IKL58 ...........................17
Index
Catalog Page
Number Number
Catalog Page
Number Number
Catalog Page
Number Number
Catalog Page
Number Number
Index
ConneCtors
88
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
IKL64 ...........................17
IKL65 ...........................17
IKL66 ...........................17
IKL67 ...........................17
IKL68 ...........................17
IKL69 ...........................17
JAB1 ...........................50
JAB12 ..........................50
JAB12H .........................50
JAB1H ..........................50
JAB34 ..........................50
JAB34C .........................50
JAB34H .........................50
JAB58 ..........................50
JAB58H .........................50
JB12B ..........................57
K1 ..........................43, 54
K2 .............................43
K3 .............................43
KL20-1 ..........................15
KL22-1 ..........................15
KL25-1 ..........................15
KL31-1 ..........................15
KL36-1 ..........................15
KL45-1 ..........................15
KL46-1 ..........................15
KL47-1 ..........................15
KL54-1 ..........................15
KL55-1 ..........................15
KL56-1 ..........................15
KL57-1 ..........................15
KL58-1 ..........................15
KL64-1 ..........................15
KL65-1 ..........................15
KL66-1 ..........................15
KL67-1 ..........................15
KL68-1 ..........................15
KL69-1 ..........................15
LP10 ...........................28
LP2 ............................28
LP4 ............................28
MS4 ............................40
OD58 ...........................56
OD581 ..........................56
OD583 ..........................56
OD58L72 ........................56
ODB ...........................56
ODB1 ..........................56
ODB3 ..........................56
ODBL72 ........................56
ODF ............................56
ODF1 ...........................56
ODF3 ...........................56
ODH1 ..........................56
PAA10 ..........................41
PAA109 .........................41
PAA12 ..........................41
PAA129 .........................41
PAA29 ..........................41
PAA339 .........................41
PAA4 ...........................41
PAA400 .........................41
PAA4009 ........................41
PAA49 ..........................41
PAA5 ...........................41
PAA59 ..........................41
PAA6 ...........................41
PAA69 ..........................41
PAC345# ........................41
PAC3459 ........................41
PAC7 ...........................41
PAC79 ..........................41
PAE-2121-9 ......................42
PAE-2121X-79. . . . . . . . . . . . . . . . . . . . 42
PAE-3921-9-2 ....................42
PAE-3931-9-2 ....................42
PAE-3939-9-2 ....................42
PAE-4141-9 ......................42
PAE-9921-9 ......................42
PAE-9939-9 ......................42
PAE-9941-9 ......................42
PAE-9999-9 ......................42
PBGW ..........................53
PBH ............................53
PC250 ..........................43
PCS64 ..........................23
PCS67 ..........................23
PCS71 ..........................23
PCS76 ..........................23
PGH29 .........................47
PGH3 ..........................47
PGH39 .........................47
PGH4 ..........................47
PGH49 .........................47
PGH6129 .......................47
PGH69 .........................47
PKL31-1 ........................23
PKL36-1 ........................23
PKL365-1 .......................23
PKL46-1 ........................23
PKL46S-1 .......................23
PKL56-1 ........................23
PKL58-1 ........................23
PKL66-1 ........................23
PKL68-1 ........................23
PRS25N ........................23
PRS30N ........................23
PRS35N ........................23
PRS40N ........................23
QCD 41 .........................27
QCN 50 .........................27
QCO 02 .........................27
QCO 21 .........................27
RC10 ...........................22
RC20 ...........................22
RC205 ..........................22
RC25 ...........................22
RC2BB .........................22
RC30 ...........................22
RC336 ..........................22
RC397 ..........................22
RC40 ...........................22
RC45 ...........................22
RC477 ..........................22
RC4BB .........................22
RCJ10 ..........................20
RCJ20 ..........................20
RCJ266 .........................20
RCJ30 ..........................20
RCJ336 .........................20
RCJ397 .........................20
RCJ40BB .......................20
RCJ477 .........................20
RCJ477M .......................20
RS2525 .........................18
RS253 ..........................18
RS403 ..........................18
RS4040 .........................18
RS4525 .........................18
RS4545 .........................18
RS8080 .........................18
SCD 41 .........................27
SCN 50 .........................27
SCO 02 .........................27
SCO 21 .........................27
SL5 ............................63
TBM10HC .......................57
TR61 ...........................18
TR63 ...........................18
TR64 ...........................18
TR65 ...........................18
TR66 ...........................18
TTC2 ...........................54
TTC2P ..........................54
TTC3 ...........................54
TTC3P ..........................54
TTC4 ...........................54
TTC4P ..........................54
W20-1 ..........................35
W20-1B .........................35
W20-1BFC ......................35
W20-1FC ........................35
W40-1 ..........................35
W40-1B .........................35
W40-1BFC ......................35
W40-1FC ........................35
W62-1 ..........................35
W62-1B .........................35
W62-1BFC ......................35
W62-1FC ........................35
W62D ..........................35
WR1010 .........................7
WR139 .........................12
WR149 ..........................7
WR159 ..........................6
WR179 ..........................7
WR189 ..........................6
WR199 ..........................7
WR219 ..........................7
WR229 ..........................7
WR239 ..........................7
WR259 ..........................7
WR269 ..........................7
WR279 ..........................6
WR289 ..........................6
WR299 ..........................7
WR319 ..........................8
WR339 ..........................8
WR359 ..........................8
WR369 ..........................8
WR379 ..........................6
WR389 ..........................8
WR399 ..........................6
WR419 ..........................6
WR502 .........................12
WR699 .........................10
WR715 ..........................9
WR719 .........................10
WR739 .........................10
WR775 ..........................9
WR779 .........................10
WR799 .........................10
WR815 ..........................9
WR819 .........................10
WR835 ..........................9
WR839 .........................10
WR875 ..........................9
WR879 .........................10
WR885 ..........................9
WR889 .........................10
WR9 ...........................12
WR909 .........................11
WR929 .........................11
WR949 .........................11
WR969 .........................11
WR989 .........................11
WR999 .........................11
WRB1 ..........................63
WRQ152 ........................26
WRQ154 ........................26
WRQ172 ........................26
WRQ232 ........................26
WRQ352 ........................26
WRQ698 ........................26
WRS152 ........................26
WRS154 ........................26
WRS172 ........................26
WRS232 ........................26
WRS352 ........................26
WRS719 ........................26
WRS819 ........................26
WWB1 ..........................63
XT12 ...........................46
XT13 ...........................46
XT21 ...........................46
XT22 ...........................46
Index
Catalog Page
Number Number
Catalog Page
Number Number
Catalog Page
Number Number
Catalog Page
Number Number
Index
ConneCtors
89
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
XT23 ...........................46
XT33 ...........................46
XT34 ...........................46
1000HPS ........................39
1000M ..........................38
1016BTB ........................53
1016TB .........................53
10H ............................38
10HPS ..........................39
10HPW .........................39
10N ............................40
10NPW .........................40
1H .............................38
1H3 ............................38
1HPS ...........................39
1HPW ..........................39
20H ............................38
20HPS ..........................39
20HPW .........................39
2B10 ...........................44
2B1000 .........................44
2B1000PW ......................45
2B1000W .......................45
2B1000X ........................44
2B10PW ........................45
2B10W .........................45
2B10X ..........................44
2B20BB .........................44
2B20PW ........................45
2B20W .........................45
2B20X ..........................44
2B350 ..........................44
2B350PW .......................45
2B350W ........................45
2B350X .........................44
2B40 ...........................44
2B40PW ........................45
2B40W .........................45
2B40X ..........................44
2B500 ..........................44
2B500PW .......................45
2B500W ........................45
2B500X .........................44
2B800 ..........................44
2B800PW .......................45
2B800W ........................45
2B800X .........................44
2H .............................38
2H3 ............................38
2HPS ...........................39
2HPW ..........................39
2NPW ..........................40
30H ............................38
350HPS .........................39
350M ...........................38
3H .............................38
3H3 ............................38
40H ............................38
40HPS ..........................39
40HPW .........................39
4B29 ...........................48
4B49 ...........................48
4H .............................38
4H3 ............................38
4HPS ...........................39
4HPW ..........................39
4N .............................40
4NPW ..........................40
500HPS .........................39
500M ...........................38
50C ............................52
50DS ...........................52
50LC ...........................52
50LCNT .........................52
50LDS ..........................52
60C ............................52
60CNT2 .........................52
60DS ...........................52
60DSNT. . . . . . . . . . . . . . . . . . . . . . . . . 52
64660 ..........................54
64663 ..........................54
6B89 ...........................48
6H .............................38
6H3 ............................38
6HPS ...........................39
6HPW ..........................39
6N .............................40
6NPW ..........................40
7019 ...........................27
7020 ...........................27
7030 ...........................27
7030C ..........................27
70C ............................52
70CNT ..........................52
70DS ...........................52
750HPS .........................39
750M ...........................38
80C ............................52
80DS ...........................52
8H .............................38
8H3 ............................38
8HPS ...........................39
9H .............................38
9HPS ...........................39
Index
Catalog Page
Number Number
Catalog Page
Number Number
Notes
ConneCtors
90
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Notes
Notes
ConneCtors
91
Thomas & Betts Corporation 8155 T&B Boulevard Memphis TN 38125 800.888.0211 www.tnb.com
PG-BB-0307
Notes
Thomas & Betts Corporation
8155 T&B Blvd.
Memphis, TN 38125
Tel: (800) 888-0211
Fax: (800) 888-0690
www.tnb.com/utility
PG-BB-0307
©2007 Thomas & Betts
