Cable to Cable–TACS7S7
ERICO CADWELD graphite molds are designed and engineered for thousands of connection styles and conductor combinations.
• Forms a permanent, low resistance connection
• Provides a molecular bond
• ERICO CADWELD Exothermic Connections are rated with the same current capacity as the conductor
• Portable installation equipment with no external source of power required
• Installers can be easily trained to make ERICO CADWELD Exothermic Connections
• Connections can be visually inspected
Part Number TACS7S7
Mold Family TA
Conductor 1 4/0 Composite
Conductor 1 Outer Diameter, Nominal 16.7 mm
Conductor 2 4/0 Composite
Conductor 2 Outer Diameter, Nominal 16.7 mm
Split Crucible No
Wear Plates No
Mold Only No
Welding Material 200 or 200PLUSF20, Sold Separately
Handle Clamp L160, Sold Separately
Price Key C
Ease of Use Preferred
Certifications cULus
Standard Packaging Quantity 1 pc
UPC 78285679833
For applications such as computer room, tunnel or other low-ventilation areas, specify a smokeless ERICO CADWELD EXOLON mold. Add an XL prefix to the standard mold part
number when ordering (for example, a TAC2Q2Q becomes XLTAC2Q2Q). Similarly, ERICO CADWELD EXOLON welding material is also designated by the XL prefix (for example, 150
becomes XL150).
A gap between conductors may be required. See mold tag for more information.
UL, UR, cUL, cUR, cULus and cURus are registered certification marks of UL LLC.
WARNING
Pentair products shall be installed and used only as indicated in Pentair’s product instruction sheets and training materials. Instruction sheets are available at erico.pentair.com and
from your Pentair customer service representative. Improper installation, misuse, misapplication or other failure to completely follow Pentair’s instructions and warnings may cause
product malfunction, property damage, serious bodily injury and death and/or void your warranty.
© 2016PentairAll rights reserved
Pentair, CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH and LENTON are owned by Pentair or its global affiliates.
All other trademarks are the property of their respective owners. Pentair reserves the right to change specifications without prior notice.
