Commercial/Industrial
EN/IEC 60309
Industrial Plugs & Sockets
International Configurations
®
The products and support to get the job done.
Everywhere.
Leviton is the smart choice, providing the most comprehensive range of solutions to meet the needs of today’s residential,
commercial and industrial buildings. Leveraging more than a century of experience, Leviton helps customers create
sustainable, intelligent environments through its electrical wiring devices, network and data center connectivity solutions,
lighting energy management systems, and security and automation applications. From switches and receptacles, and
daylight harvesting controls to networking systems, intelligent safety controls, and equipment for charging electric vehicles,
Leviton solutions help customers achieve savings in energy, time and cost, all while enhancing safety.
Through investment in research and development, manufacturing, distribution, human capital and training, Leviton is well
positioned to respond to the needs of a changing marketplace. Leviton’s heritage provides a strong foundation for meeting
and exceeding market expectations by bringing continuous innovation to the industry.
Over time, Leviton has expanded its business into global markets, building engineering, manufacturing, and distribution
facilities worldwide, ensuring access to quality products and world-class customer service.
Leviton Global Companies
Canada
China
Colombia
India
Korea
Mexico
Middle East
South Africa
United Kingdom
Global Network of Programs & Support
Sales Offices
Manufacturing Plants
Distribution Centers
Leviton products are available in
more than 80 countries
Distributed in over 17,000
locations worldwide
14
13
8
The smart choice for commercial and industrial applications.
With over 100 years experience and a reputation for industry-leading reliability, innovation
and value, we’re the brand standard for dozens of applications. Working closely with key
industry specifiers, we’ve created smart solutions for all manner of environments and
workplaces — from processing plants to entertainment venues to offices and tasting rooms.
Our state-of-the-art weather-resistant wiring devices, high speed data connections, and
energy-saving lighting controls contribute to safer, more efficient production environments
while improving energy conservation.
Today, we’re the market share leader in GFCIs as well as other electrical safety devices for
private and public facilities. Leviton has a comprehensive product line of electrical, lighting,
energy management and data networking devices — over 26,000 products in all — many
engineered specifically for the needs of niche industries. We’re also the undisputed leader
in meeting today’s energy codes: nine out of 10 U.S. buildings use our low-voltage products.
Supported by over 600 patents and a fully integrated service approach, Leviton is the go-to
resource for many of the world’s top industries.
www.leviton.com/ENIEC60309
4
EN/IEC 60309 Industrial Plug & Socket Line Overview
Technical Characteristics
Rated current: 16A, 32A, 63A, 125A
Rated voltage: 100-690V~
Frequency: 50Hz-60Hz
Insulating voltage: 500/690V~
Protection degree: IP44-IP66/IP67
Operating temperature: -25°C +40°C
Max operating temperature: 60°C
Glow Wire test: 650°C/850°C
Material: Engineering plastic
IK degree at 20°C: IK08
Cable inlets: Cable gland
Halogen free: Yes
Terminals: Screw
Standards and Certifications: NOM, IEC/EN 60309-1, 60309-2, RETIE, CE
Behavior With Chemical And Atmospheric Agents
Saline
Solution
Acids Bases Solvents Mineral Oil UV Rays
Concentrated
Diluted
Concentrated
Diluted Hexane Benzol Acetone Alcohol
Resistant Limited
Resistance Resistant Resistant Resistant Not
Resistant
Not
Resistant
Not
Resistant
Limited
Resistance Resistant Limited
Resistance
Wiring And Installation
Ampere
Rating
Plugs and Connectors Receptacles and Inlets
FROM TO Cord Grip Range
(External Diameter) FROM TO
AWG
TYPE mm2AWG
TYPE mm2(in) (mm) AWG
TYPE mm2AWG
TYPE mm2
16 16 1 14 2.5 .315 - .590 8 - 15 16 1.5 12 4
32 14 2.5 10 6 .453 - .827 11.5 - 21 14 2.5 8 10
63 10 6 6 16 .669 - 1.22 17 - 31 10 6 4 25
125 6 16 1 50 1.024 - 1.90 26 - 48 4 25 2/0 70
Connectors Panel Mounting
Inlets
Panel Mounting
Socket Outlets
Plugs Surface Mounting
Socket Outlet
5
www.leviton.com/ENIEC60309
EN/IEC 60309 Industrial Plug & Socket Line Overview
Clockface Position
Viewing the socket from the front, the clockface (h) position can be established by observing the hour position of the earthing contact
compared to the socket keyway, which always faces 6 o’clock.
Different voltages are identified by conventional color codes.
The clock diagram for rated operating voltages > 50V (LV) shows, in compliance with EN 60309, the hour position (h) of the earthing contact
of industrial plugs and sockets compared to the socket keyway, for any specific rating (number of poles, operating voltages, frequencies and
AC or DC supply).
Industrial Plugs And Sockets For Rated Operating Voltages > 50V
12
1
210
9
*
*
*
*
*
250/440V -
265/460V
60Hz
440V - 460V
60Hz
16 - 32A
>50V
100 - 300Hz
16 - 32A
>50V
100 - 300Hz 16 -
32A
>50V 100 -
300Hz
120/208V -
144/250V
380V 50Hz
440V 60Hz
220/380V
50Hz
250/440V
60Hz
380 - 415V
200 - 250V 50 - 250V
>250V
1000V
480 - 500V
480 -
500V 200 -
250V
100 -
130V
100 - 130V
57/100V -
75/130V
277/480V -
288/500V
347/600V -
400/690V
200/346V -
240/415V
600 - 690V
380 - 415V
>50V
300 -
500Hz
>50V
300 - 500Hz
>50V
300 - 500Hz
*
3
8 4
7 5
11
6
2P +
3P +
3P + N +
Industrial Plug And Socket Characteristics
In Compliance With EN 60309 Standard For
Rated Operating Voltages > 50V (LV)
SOCKET FRONT VIEW
(*) Keyway
L1
L2 L3
N
(*)
3P+N+E
L1
L2
L3
(*)
3P+E
L/+
2P+E
(*)
www.leviton.com/ENIEC60309
6
EN/IEC 60309 Industrial Plug & Socket Overview
Splashproof (IP44) Devices
Positive
locking grip
provides
excellent
strain relief
Constructed of
halogen-free
engineering
polymer for extra
durability and
environmental
safety
Rubber gland
provides
watertight
seal at
cable
entrance
Spring clip
connection
speeds
assembly of
plugs and
connectors
(16A and 32A
models only)
Product Detail
IP44 Connectors
and Socket Outlets
feature a specially
designed cap that
facilitates easy,
single-handed
opening
Easy access wire chambers
enable faster wiring
Terminal screws are oriented in
a single direction and feature
combination drive heads for
fast and secure wiring
7
www.leviton.com/ENIEC60309
EN/IEC 60309 Industrial Plug & Socket Ordering Information
Plug Connector Panel Mounting
Socket Outlet
Surface Mounting
Socket Outlet
Panel Mounting
Inlet
Back Box
Splashproof (IP44) Devices
Amps Poles Hz Volts
Connector/
Outlet
Config.
and Clock
Position
Plug/Inlet
Config. Plug Connector
Panel
Mounting
Socket
Outlet
Surface
Mounting
Socket
Outlet
Panel
Mounting
Inlet
Back
Box
16
2P+E
(2P,3W)
50/60Hz 100V-130V 4 S216-P4 S216-C4 S216-R4 S216-S4 S216-B4 BB16-A
50/60Hz 200V-250V 6 S216-P6 S216-C6 S216-R6 S216-S6 S216-B6 BB16-A
50/60Hz 380V-415V 9 S216-P9 S216-C9 S216-R9 S216-S9 S216-B9 BB16-A
3P+E
(3P,4W)
50/60Hz 200V-250V 9 S316-P9 S316-C9 S316-R9 S316-S9 S316-B9 BB16-A
50/60Hz 380V-415V 6 S316-P6 S316-C6 S316-R6 S316-S6 S316-B6 BB16-A
60Hz 440V-460V 11 S316-P11 S316-C11 S316-R11 S316-S11 S316-B11 BB16-A
3P+N+E
(4P,5W)
50/60Hz 208V-250V 9 S416-P9 S416-C9 S416-R9 S416-S9 S416-B9 BB16-A
50/60Hz 346V-415V 6 S416-P6 S416-C6 S416-R6 S416-S6 S416-B6 BB16-A
60Hz 440V-460V 11 S416-P11 S416-C11 S416-R11 S416-S11 S416-B11 BB16-A
32
2P+E
(2P,3W)
50/60Hz 100V-130V 4 S232-P4 S232-C4 S232-R4 S232-S4 S232-B4 BB32-A
50/60Hz 200V-250V 6 S232-P6 S232-C6 S232-R6 S232-S6 S232-B6 BB32-A
50/60Hz 380V-415V 9 S232-P9 S232-C9 S232-R9 S232-S9 S232-B9 BB32-A
3P+E
(3P,4W)
50/60Hz 200V-250V 9 S332-P9 S332-C9 S332-R9 S332-S9 S332-B9 BB32-A
50/60Hz 380V-415V 6 S332-P6 S332-C6 S332-R6 S332-S6 S332-B6 BB32-A
60Hz 440V-460V 11 S332-P11 S332-C11 S332-R11 S332-S11 S332-B11 BB32-A
3P+N+E
(4P,5W)
50/60Hz 208V-250V 9 S432-P9 S432-C9 S432-R9 S432-S9 S432-B9 BB32-A
50/60Hz 346V-415V 6 S432-P6 S432-C6 S432-R6 S432-S6 S432-B6 BB32-A
60Hz 440V-460V 11 S432-P11 S432-C11 S432-R11 S432-S11 S432-B11 BB32-A
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
www.leviton.com/ENIEC60309
8
EN/IEC 60309 Industrial Plug & Socket Dimensions
Amps Poles A mm(in) B Min mm(in) Ø C Min mm(in) Ø D mm(in)
16A
2P+E (2P,3W) 30(1.2) 128(5.0) 6(.2) 56(2.2)
3P+E (3P,4W) 34(1.3) 135(5.3) 6(.2) 60(2.4)
3P+N+E (4P,5W) 38(1.5) 153(6.0) 9(.3) 65(2.6)
32A
2P+E (2P,3W) 40(1.6) 162(6.4) 9(.3) 65(2.6)
3P+E (3P,4W) 40(1.6) 162(6.4) 9(.3) 65(2.6)
3P+N+E (4P,5W) 45(1.8) 176(6.9) 13(.5) 73(2.9)
Plugs — Splashproof (IP44)
A
30
34
38
40
40
45
IP44
16A
32A
Ø D
56
60
65
65
65
73
B Min
128
135
153
162
162
176
Ø C Min
6
6
9
9
9
13
2P+E
3P+E
3P+N+E
2P+E
3P+E
3P+N+E
PLUGS- Splashproof IP44
A
B MIN
Ø C MIN
Ø D
Panel Mounting Inlet — Splashproof (IP44)
Amps Poles A mm(in) B mm(in) C mm(in) D mm(in) Ø E mm(in)
16A
2P+E(2P,3W)
2(0.1) 65(2.6) 75(2.9) 60(2.4) 60(2.4)3P+E(3P,4W)
3P+N+E(4P,5W)
32A
2P+E(2P,3W)
19(0.7) 73(2.9) 75(2.9) 60(2.4) 60(2.4)3P+E(3P,4W)
3P+N+E(4P,5W)
(Dimension in mm)
2P+E
3P+E
3P+N+E
2P+E
3P+E
3P+N+E
A
2
2
2
19
19
19
IP44
16A
32A
B C
65 75
D
60
E
60
65
65
73
73
73
44PI - STELNI ECNAILPPA
Ø E
D
D
A BC
C
9
www.leviton.com/ENIEC60309
EN/IEC 60309 Industrial Plug & Socket Dimensions
Amps Poles A mm(in) B Min mm(in) Ø C Min mm(in) Ø D mm(in)
16A
2P+E (2P,3W) 46(1.8) 138(5.4) 6(.2) 56(2.2)
3P+E (3P,4W) 49(1.9) 145(5.7) 6(.2) 60(2.4)
3P+N+E (4P,5W) 54(2.1) 165(6.5) 9(.3) 65(2.6)
32A
2P+E (2P,3W) 54(2.1) 175(6.9) 9(.3) 65(2.6)
3P+E (3P,4W) 54(2.1) 175(6.9) 9(.3) 65(2.6)
3P+N+E (4P,5W) 59(2.3) 190(7.5) 13(.5) 73(2.9)
Connectors — Splashproof (IP44)
CONNECTORS - Splashproof IP44
A
46
49
54
54
54
59
Ø D
56
60
65
65
65
73
B Min
138
145
165
175
175
190
Ø C Min
6
6
9
9
9
13
IP44
16A
32A
2P+E
3P+E
3P+N+E
2P+E
3P+E
3P+N+E
Ø D
Ø C MIN
A
B MIN
Panel Mounting Socket Outlets — Splashproof (IP44)
Amps Poles A mm(in) B mm(in) C mm(in) D mm(in) Ø E mm(in) F mm(in) G mm(in) H mm(in) I mm(in)
16A
2P+E(2P,3W) 70(2.7) 87(3.4) 56(2.2) 70(2.7) 6(.2) 73(2.9) 65(2.6) 45(1.8) 40(1.6)
3P+E(3P,4W) 70(2.7) 87(3.4) 56(2.2) 70(2.7) 6(.2) 73(2.9) 65(2.6) 46(1.8) 40(1.6)
3P+N+E(4P,5W) 70(2.7) 87(3.4) 56(2.2) 70(2.7) 6(.2) 73(2.9) 65(2.6) 48(1.9) 41(1.6)
32A
2P+E(2P,3W) 90(3.5) 106(4.2) 68(2.7) 84(3.3) 6(.2) 87(3.4) 76(3.0) 52(2.1) 60(2.4)
3P+E(3P,4W) 90(3.5) 106(4.2) 68(2.7) 84(3.3) 6(.2) 87(3.4) 76(3.0) 52(2.1) 60(2.4)
3P+N+E(4P,5W) 90(3.5) 106(4.2) 68(2.7) 84(3.3) 6(.2) 87(3.4) 76(3.0) 54(2.1) 61(2.4)
Ø E
E = .220
5,6 MM
A
C
G
H I
D
B
F
DIMENSIONS: INCH / MM
Catalog Number SCAME CODE VOLTAGE COLOR Dimension A Dimension B Dimension C Dimension D Dimension F Dimension G Dimension H Dimension I CLOCK (Hr)
0S216-0R4 413.1660
100-130V YELLOW
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.56" / 65 MM 1.77" / 45 MM 1.57" / 40 MM
0S232-0R4 413.3260 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.43" / 87 MM 2.99" / 76 MM 2.05" / 52 MM 2.36" / 60 MM
0S216-0R6 413.1663
200-250V BLUE
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.56" / 65 MM 1.77" / 45 MM 1.57" / 40 MM
0S232-0R6 413.3263 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.43" / 87 MM 2.99" / 76 MM 2.05" / 52 MM 2.36" / 60 MM
0S316-0R9 413.1664
200-250V BLUE
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.56" / 65 MM 1.81" / 46 MM 1.57" / 40 MM
0S332-0R9 413.3264 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.43" / 87 MM 2.99" / 76 MM 2.05" / 52 MM 2.36" / 60 MM
0S416-0R9 413.1665
208-250V BLUE
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.56" / 65 MM 1.89" / 48 MM 1.61" / 41 MM
0S432-0R9 413.3265 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.43" / 87 MM 2.99" / 76 MM 2.13" / 54 MM 2.40" / 61 MM
0S316-0R6 413.1666
380-415V RED
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.56" / 65 MM 1.81" / 46 MM 1.57" / 40 MM
0S332-0R6 413.3266 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.43" / 87 MM 2.99" / 76 MM 2.05" / 52 MM 2.36" / 60 MM
0S316-R11 413.16665
440-460V RED
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.56" / 65 MM 1.81" / 46 MM 1.57" / 40 MM
0S332-R11 413.32665 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.43" / 87 MM 2.99" / 76 MM 2.05" / 52 MM 2.36" / 60 MM
0S416-0R6 413.1667
346-415V RED
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.56" / 65 MM 1.89" / 48 MM 1.61" / 41 MM
0S432-0R6 413.3267 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.43" / 87 MM 2.99" / 76 MM 2.13" / 54 MM 2.40" / 61 MM
0S216-0R9 413.1668
380-415V RED
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.56" / 65 MM 1.77" / 45 MM 1.57" / 40 MM
0S232-0R9 413.3268 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.43" / 87 MM 2.99" / 76 MM 2.05" / 52 MM 2.36" / 60 MM
0S416-R11 413.16675
440-460V RED
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.56" / 65 MM 1.89" / 48 MM 1.61" / 41 MM
0S432-R11 413.32675 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.43" / 87 MM 2.99" / 76 MM 2.13" / 54 MM 2.40" / 61 MM
4 13
4 3 2 1
B
A
SHEET 1 OF 1
PROJECT NO.
TITLE:
ALL PRINTED COPIES
ARE UNCONTROLLED
DWG NO.
REVSIZE
C
UNLESS OTHERWISE SPECIFIED:
DO NOT SCALE DRAWING.
ALL DIMENSIONS ARE IN INCHES.
ALL ANGLES ARE IN DEGREES.
The information in this document is
the exclusive PROPRIETARY
property of LEVITON MFG. CO.,
INC. It is disclosed with the
understanding that acceptance or
review by the recipient constitutes
an undertaking by the recipient:
(1) to hold this information in strict
confidence.
(2) not to disclose, duplicate, copy,
or use the information, in whole or in
part, for any purpose other than that
for which disclosed.
DWN BY
CHK BY
TOLERANCES
THIRD ANGLE PROJECTION
SCALE:1:1
MFG
ENGRG
REV. DATE ECO NUMBER APVDCHGD
1/2°
.XX
.XXX
±
±
INCH
.01
.005
ANGLES: ±
.X
.XX
METRIC
.2 mm
.1 mm
±
±
Copyright 2010. Unpublished.
All Rights Reserved.
2
C
D
B
A
C
D
-
---
-
---
-
-
---
-- --
-
A - PRA KNJ
09/19/2013
09/19/2013KNJ
KNJ 09/19/2013
IP44 16A/32A ASSEMBLY
FLUSH MTG RECEPTACLE
KNJ 09/19/2013
05/30/2013PRA
A
ORA7005-D01
PROJ-02986
-
-
18°
www.leviton.com/ENIEC60309
10
EN/IEC 60309 Industrial Plug & Socket Dimensions
Surface Mounting Socket Outlets — Splashproof (IP44)
Amps Poles A mm(in) B mm(in) C mm(in) D mm(in) E mm(in) F mm(in) G mm(in) H mm(in) I mm(in)
16A
2P+E(2P,3W) 65(2.6) 52(2.0) 5(0.2) 112(4.4) 7.5(0.3) 127(5.0) 8(0.3) 99(3.9) 128(5.0)
3P+E(3P,4W) 65(2.6) 52(2.0) 5(0.2) 112(4.4) 7.5(0.3) 127(5.0) 8(0.3) 102(4.0) 131(5.2)
3P+N+E(4P,5W) 65(2.6) 52(2.0) 5(0.2) 112(4.4) 7.5(0.3) 127(5.0) 8(0.3) 107(4.2) 133(5.2)
32A
2P+E(2P,3W) 80(3.1) 66(2.6) 5(0.2) 121(4.8) 7.5(0.3) 137(5.4) 8(0.3) 116(4.6) 141 (5.5)
3P+E(3P,4W) 80(3.1) 66(2.6) 5(0.2) 121(4.8) 7.5(0.3) 137(5.4) 8(0.3) 116(4.6) 141(5.5)
3P+N+E(4P,5W) 80(3.1) 66(2.6) 5(0.2) 121(4.8) 7.5(0.3) 137(5.4) 8(0.3) 120(4.7) 143(5.6)
A
I
E C
C G
B
F
H
D
DIMENSION: INCH / MM
Catalog Number SCAME CODE VOLTAGE COLOR Dimension A Dimension B Dimension D Dimension F Dimension H Dimension L CLOCK (Hr)
0S216-0S6 512.1653
200 -250V BLUE
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 3.90" / 99 MM 5.04" / 128 MM
0S232-0S6 512.3253 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 4.57" / 116 MM 5.55" / 141 MM
0S316-0S9 512.1654
200 -250V BLUE
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 4.02" / 102 MM 5.16" / 131 MM
0S332-0S9 512.3254 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 4.57" / 116 MM 5.55" / 141 MM
0S416-0S9 512.1655
208 -250V BLUE
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 4.21" / 107 MM 5.24" / 133 MM
0S432-0S9 512.3255 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 4.72" / 120 MM 5.63" / 143 MM
0S316-0S6 512.1656
380 - 415V RED
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 4.02" / 102 MM 5.16" / 131 MM
0S332-0S6 512.3256 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 4.57" / 116 MM 5.55" / 141 MM
0S316-S11 512.16565
440 - 460V RED
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 4.02" / 102 MM 5.16" / 131 MM
0S332-S11 512.32565 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 4.57" / 116 MM 5.55" / 141 MM
0S416-0S6 512.1657
346 - 415V RED
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 4.21" / 107 MM 5.24" / 133 MM
0S432-0S6 512.3257 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 4.72" / 120 MM 5.63" / 143 MM
0S416-S11 512.16575
440 - 460V RED
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 4.21" / 107 MM 5.24" / 133 MM
0S432-S11 512.32575 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 4.72" / 120 MM 5.63" / 143 MM
0S216-0S9 512.1658
380 - 415V RED
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 3.90" / 99 MM 5.04" / 128 MM
0S232-0S9 512.3258 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 4.57" / 116 MM 5.55" / 141 MM
0S216-0S4 512.1650
100 - 130V YELLOW
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 3.90" / 99 MM 5.04" / 128 MM
0S232-0S4 512.3250 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 4.57" / 116 MM
C = .197” / 5 MM
E = .295” / 7.5 MM
G = .315” / 8 MM
5.55" / 141 MM
4 13
4 3 2 1
B
A
SHEET 1 OF 1
PROJECT NO.
TITLE:
ALL PRINTED COPIES
ARE UNCONTROLLED
STATUS:
DWG NO.
REVSIZE
C
UNLESS OTHERWISE SPECIFIED:
DO NOT SCALE DRAWING.
ALL DIMENSIONS ARE IN INCHES.
ALL ANGLES ARE IN DEGREES.
The information in this document is
the exclusive PROPRIETARY
property of LEVITON MFG. CO.,
INC. It is disclosed with the
understanding that acceptance or
review by the recipient constitutes
an undertaking by the recipient:
(1) to hold this information in strict
confidence.
(2) not to disclose, duplicate, copy,
or use the information, in whole or in
part, for any purpose other than that
for which disclosed.
DWN BY
CHK BY
TOLERANCES
THIRD ANGLE PROJECTION
SCALE:1:1
MFG
ENGRG
REV. DATE ECO NUMBER APVDCHGD
1/2°
.XX
.XXX
±
±
INCH
.01
.005
ANGLES: ±
.X
.XX
METRIC
.2 mm
.1 mm
±
±
Copyright 2010. Unpublished.
All Rights Reserved.
2
C
D
B
A
C
D
-
---
-
---
-
-
---
-- --
-
A - PRA KNJ
09/19/2013
09/19/2013KNJ
KNJ 09/19/2013
IP44 16A/32A ASSEMBLY
SURFACE MTG RECEPTACLE
KNJ 09/19/2013
05/30/2013PRA
A
Production Release
ORA7008-D01
PROJ-02986
-
-
11
www.leviton.com/ENIEC60309
EN/IEC 60309 Industrial Plug & Socket Overview
Positive
locking grip
provides
excellent
strain relief
Rubber gland
provides
watertight
seal at
cable
entrance
Product Detail
Nickel-plated brass contact pins
provide excellent electrical
conductivity and are corrosion
and abrasion resistant
IP66/67 devices feature
molded-on gaskets for a
consistent watertight seal
Watertight (IP66/67) Devices
www.leviton.com/ENIEC60309
12
EN/IEC 60309 Industrial Plug & Socket Ordering Information
Plug Connector Panel Mounting
Socket Outlet
Surface Mounting
Socket Outlet
Panel Mounting
Inlet
Back Box
Amps Poles Hz Volts
Connector/
Outlet
Config.
and Clock
Position
Plug/Inlet
Config. Plug Connector
Panel
Mounting
Socket
Outlet
Surface
Mounting
Socket
Outlet
Panel
Mounting
Inlet
Back
Box
16
2P+E
(2P,3W)
50/60Hz 100V-130V 4
W216-P4 W216-C4 W216-R4 W216-S4 W216-B4 BB16-A
50/60Hz 200V-250V 6
W216-P6 W216-C6 W216-R6 W216-S6 W216-B6 BB16-A
50/60Hz 380V-415V 9
W216-P9 W216-C9 W216-R9 W216-S9 W216-B9 BB16-A
3P+E
(3P,4W)
50/60Hz 200V-250V 9
W316-P9 W316-C9 W316-R9 W316-S9 W316-B9 BB16-A
50/60Hz 380V-415V 6
W316-P6 W316-C6 W316-R6 W316-S6 W316-B6 BB16-A
60Hz 440V-460V 11
W316-P11 W316-C11 W316-R11 W316-S11 W316-B11 BB16-A
3P+N+E
(4P,5W)
50/60Hz 208V-250V 9
W416-P9 W416-C9 W416-R9 W416-S9 W416-B9 BB16-A
50/60Hz 346V-415V 6
W416-P6 W416-C6 W416-R6 W416-S6 W416-B6 BB16-A
60Hz 440V-460V 11
W416-P11 W416-C11 W416-R11 W416-S11 W416-B11 BB16-A
32
2P+E
(2P,3W)
50/60Hz 100V-130V 4
W232-P4 W232-C4 W232-R4 W232-S4 W232-B4 BB32-A
50/60Hz 200V-250V 6
W232-P6 W232-C6 W232-R6 W232-S6 W232-B6 BB32-A
50/60Hz 380V-415V 9
W232-P9 W232-C9 W232-R9 W232-S9 W232-B9 BB32-A
3P+E
(3P,4W)
50/60Hz 200V-250V 9
W332-P9 W332-C9 W332-R9 W332-S9 W332-B9 BB32-A
50/60Hz 380V-415V 6
W332-P6 W332-C6 W332-R6 W332-S6 W332-B6 BB32-A
60Hz 440V-460V 11
W332-P11 W332-C11 W332-R11 W332-S11 W332-B11 BB32-A
3P+N+E
(4P,5W)
50/60Hz 208V-250V 9
W432-P9 W432-C9 W432-R9 W432-S9 W432-B9 BB32-A
50/60Hz 346V-415V 6
W432-P6 W432-C6 W432-R6 W432-S6 W432-B6 BB32-A
60Hz 440V-460V 11
W432-P11 W432-C11 W432-R11 W432-S11 W432-B11 BB32-A
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
Watertight (IP66/67) Devices
13
www.leviton.com/ENIEC60309
EN/IEC 60309 Industrial Plug & Socket Ordering Information
Plug Connector Panel Mounting
Socket Outlet
Surface Mounting
Socket Outlet
Panel Mounting
Inlet
Back Box
Amps Poles Hz Volts
Connector/
Outlet
Config.
and Clock
Position
Plug/Inlet
Config. Plug Connector
Panel
Mounting
Socket
Outlet
Surface
Mounting
Socket
Outlet
Panel
Mounting
Inlet
Back
Box
63
2P+E
(2P,3W) 50/60Hz 200V-250V 6 W263-P6 W263-C6 W263-R6 W263-S6 W263-B6 BB63-A
3P+E
(3P,4W)
50/60Hz 200V-250V 9 W363-P9 W363-C9 W363-R9 W363-S9 W363-B9 BB63-A
50/60Hz 380V-415V 6 W363-P6 W363-C6 W363-R6 W363-S6 W363-B6 BB63-A
60Hz 440V-460V 11 W363-P11 W363-C11 W363-R11 W363-S11 W363-B11 BB63-A
3P+N+E
(4P,5W)
50/60Hz 208V-250V 9 W463-P9 W463-C9 W463-R9 W463-S9 W463-B9 BB63-A
50/60Hz 346V-415V 6 W463-P6 W463-C6 W463-R6 W463-S6 W463-B6 BB63-A
60Hz 440V-460V 11 W463-P11 W463-C11 W463-R11 W463-S11 W463-B11 BB63-A
125
2P+E
(2P,3W) 50/60Hz 200V-250V 6 W2125-P6 W2125-C6 W2125-R6 W2125-S6 W2125-B6 BB125-A
3P+E
(3P,4W)
50/60Hz 200V-250V 9 W3125-P9 W3125-C9 W3125-R9 W3125-S9 W3125-B9 BB125-A
50/60Hz 380V-415V 6 W3125-P6 W3125-C6 W3125-R6 W3125-S6 W3125-B6 BB125-A
60Hz 440V-460V 11
W3125-P11 W3125-C11 W3125-R11 W3125-S11 W3125-B11
BB125-A
3P+N+E
(4P,5W)
50/60Hz 208V-250V 9 W4125-P9 W4125-C9 W4125-R9 W4125-S9 W4125-B9 BB125-A
50/60Hz 346V-415V 6 W4125-P6 W4125-C6 W4125-R6 W4125-S6 W4125-B6 BB125-A
60Hz 440V-460V 11
W4125-P11 W4125-C11 W4125-R11 W4125-S11 W4125-B11
BB125-A
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
2P3W_4_C&P
2P3W_6_C&P
2P3W_9_C&P
3P4W_3_C&P
3P4W_6_C&P
3P4W_9_C&P
3P4W_11_C&P
4P5W_6_C&P
4P5W_9_C&P
4P5W_11_C&P
Watertight (IP66/67) Devices
www.leviton.com/ENIEC60309
14
EN/IEC 60309 Industrial Plug & Socket Dimensions
A
C = 2.95” / 75 MM
D = 2.36” / 60 MM
BC
C
D
DØ E
DIMENSION: INCH / MM
Catalog Number SCAME CODE VOLTAGE COLOR CLOCK (Hr)
0W216-0B6 248.1693
200-250V BLUE
0W232-0B6 248.3293
0W316-0B9 248.1694
200-250V BLUE
0W332-0B9 248.3294
0W416-0B9 248.1695
208-250V BLUE
0W432-0B9 248.3295
0W316-0B6 248.1696
380-415V RED
0W332-0B6 248.3296
0W316-B11 248.16965
440-460V RED
0W332-B11 248.32965
0W416-0B6 248.1697
346-415V RED
0W432-0B6 248.3297
0W416-B11 248.16975
440-460V RED
0W432-B11 248.32975
0W216-0B9 248.1698
380-415V RED
0W232-0B9 248.3298
0W216-0B4 248.1690
100-130V YELLOW
0W232-0B4 248.3290 AMP DIMENSION A DIMENSION B
16A 0.08" / 2 MM 2.56" / 65 MM
32A 0.75" / 19 MM 2.87" / 73 MM
4 13
4 3 2 1
B
A
SHEET 1 OF 1
PROJECT NO.
TITLE:
ALL PRINTED COPIES
ARE UNCONTROLLED
STATUS:
DWG NO.
REVSIZE
C
UNLESS OTHERWISE SPECIFIED:
DO NOT SCALE DRAWING.
ALL DIMENSIONS ARE IN INCHES.
ALL ANGLES ARE IN DEGREES.
The information in this document is
the exclusive PROPRIETARY
property of LEVITON MFG. CO.,
INC. It is disclosed with the
understanding that acceptance or
review by the recipient constitutes
an undertaking by the recipient:
(1) to hold this information in strict
confidence.
(2) not to disclose, duplicate, copy,
or use the information, in whole or in
part, for any purpose other than that
for which disclosed.
DWN BY
CHK BY
TOLERANCES
THIRD ANGLE PROJECTION
SCALE:1:1
MFG
ENGRG
REV. DATE ECO NUMBER APVDCHGD
1/2°
.XX
.XXX
±
±
INCH
.01
.005
ANGLES: ±
.X
.XX
METRIC
.2 mm
.1 mm
±
±
Copyright 2010. Unpublished.
All Rights Reserved.
2
C
D
B
A
C
D
-
---
-
---
-
-
---
-- --
-
A - PRA KNJ
09/04/2013
09/04/2013KNJ
KNJ 09/04/2013
16A/32A ASSEMBLY
IP67 INLET CATALOG
KNJ 09/04/2013
05/30/2013PRA
A
Production Release
ORA7012-D01
PROJ-02986
-
-
Panel Mounting Inlet — Watertight (IP66/67)
Amps Poles A mm(in) B mm(in) C mm(in) D mm(in) Ø E mm(in)
16A
2P+E(2P,3W)
2(0.1) 65(2.6) 75(2.9) 60(2.4) 60(2.4)3P+E(3P,4W)
3P+N+E(4P,5W)
32A
2P+E(2P,3W)
19(0.7) 73(2.9) 75(2.9) 60(2.4) 60(2.4)3P+E(3P,4W)
3P+N+E (4P,5W)
Amps Poles A mm(in) B Min mm(in) Ø C Min mm(in) Ø D mm(in)
16A
2P+E (2P,3W) 103(4.0) 128(5.0) 6(.2) 73(2.9)
3P+E (3P,4W) 110(4.3) 135(5.3) 6(.2) 81(3.2)
3P+N+E (4P,5W) 129(5.1) 153(6.0) 9(.3) 88(3.5)
32A
2P+E (2P,3W) 131(5.2) 162(6.4) 9(.3) 93(3.7)
3P+E (3P,4W) 131(5.2) 162(6.4) 9(.3) 93(3.7)
3P+N+E (4P,5W) 145(5.7) 176(6.9) 13(.5) 101(4.0)
63A All 160(6.3) 220(8.7) 17(.7) 112(4.4)
125A All 202(7.9) 272(10.7) 26(1.0) 128(5.0)
Plugs — Watertight (IP66/67)
A
103
110
129
131
131
145
160
202
IP66/IP67
16A
32A
63A
125A
Ø D
73
81
88
93
93
101
112
128
B Min
128
135
153
162
162
176
220
272
Ø C Min
6
6
9
9
9
13
17
26
2P+E
3P+E
3P+N+E
2P+E
3P+E
3P+N+E
B MIN A
Ø C MIN
Ø D
15
www.leviton.com/ENIEC60309
EN/IEC 60309 Industrial Plug & Socket Dimensions
Amps Poles A mm(in) B Min mm(in) Ø C Min mm(in) Ø D mm(in)
16A
2P+E (2P,3W) 39(1.5) 141(5.5) 6(.2) 73(2.9)
3P+E (3P,4W) 43(1.7) 148(5.8) 6(.2) 81(3.2)
3P+N+E (4P,5W) 51(2.0) 168(6.6) 9(.3) 88(3.5)
32A
2P+E (2P,3W) 56(2.2) 178(7.0) 9(.3) 93(3.7)
3P+E (3P,4W) 56(2.2) 178(7.0) 9(.3) 93(3.7)
3P+N+E (4P,5W) 52(2.0) 195(7.7) 13(.5) 101(4.0)
63A All 57,5(2.26) 230(9.0) 17(.7) 112(4.4)
125A All 64,25(2.53) 288(11.3) 26(1.0) 128(5.0)
Connectors — Watertight (IP66/IP67)
A
39
43
51
56
56
52
57,5
64,25
IP66/IP67
16A
32A
63A
125A
Ø D
73
81
88
93
93
101
112
128
B Min
141
148
168
178
178
195
230
288
Ø C Min
6
6
9
9
9
13
17
26
2P+E
3P+E
3P+N+E
2P+E
3P+E
3P+N+E
B MIN
A
Ø D
Ø C MIN
42.5 MM
85 MM
80 MM
85 MM
6.5 MM
80 MM
100 MM
85 MM
110 MM
112 MM
101 MM
12 MM
63A
NOTE:
UPPER DIMENSION: INCH
LOWER DIMENSION: MM
REV B
REV B
125A
C
C
ØF
D
A
B
ØGD
ØE
Panel Mounting Inlet — Watertight (IP66/67)
Amps Poles A mm(in) B mm(in) C mm(in) D mm(in) Ø E mm(in) Ø F mm(in) Ø G mm(in)
63A
2P+E(2P,3W)
12(.47) 101(3.9) 100(3.9) 80(3.1) 85(3.3) 6.5(.2) 112(4.4)3P+E(3P,4W)
3P+N+E(4P,5W)
125A
2P+E(2P,3W)
13(.5) 113.5(4.4) 114(4.4) 100(3.9) 95(3.7) 6.5(.2) 128.5(5.0)3P+E(3P,4W)
3P+N+E (4P,5W)
www.leviton.com/ENIEC60309
16
EN/IEC 60309 Industrial Plug & Socket Dimensions
Amps Poles A mm(in) B mm(in) C mm(in) D mm(in) Ø E mm(in) F mm(in) G mm(in) H mm(in) I mm(in)
16A
2P+E(2P,3W) 70(2.7) 87(3.4) 56(2.2) 70(2.7) 73(2.9) 73(2.9) 65(2.6) 52(2.0) 40(1.6)
3P+E(3P,4W) 70(2.7) 87(3.4) 56(2.2) 70(2.7) 81(3.2) 73(2.9) 65(2.6) 54(2.1) 40(1.6)
3P+N+E (4P,5W) 70(2.7) 87(3.4) 56(2.2) 70(2.7) 88(3.5) 73(2.9) 65(2.6) 55(2.2) 41(1.6)
32A
2P+E(2P,3W) 90(3.5) 106(4.2) 68(2.7) 84(3.3) 93 (3.7) 87(3.4) 76(3.0) 61(2.4) 60(2.4)
3P+E(3P,4W) 90(3.5) 106(4.2) 68(2.7) 84(3.3) 93 (3.7) 87(3.4) 76(3.0) 61(2.4) 60(2.4)
3P+N+E (4P,5W) 90(3.5) 106(4.2) 68(2.7) 84(3.3) 101(4.0) 87(3.4) 76(3.0) 63(2.5) 61(2.4)
Panel Mounting Socket Outlets — Watertight (IP66/IP67)
CØ 5,6 MM
.22"
G
A
F
18°
I
H
D
Ø E
B
DIMENSION: INCH / MM
Catalog Number SCAME CODE VOLTAGE COLOR Dimension A Dimension B Dimension C Dimension D Dimension E Dimension F Dimension G Dimension H Dimension I CLOCK (Hr)
0W316-0R9 418.1664
200-250V BLUE
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 3.19" / 81 MM 2.87" / 73 MM 2.56" / 65 MM 2.13" / 54 MM 1.57" / 40 MM
0W332-0R9 418.3264 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.66" / 93 MM 3.43" / 87 MM 2.99" / 76 MM 2.40" / 61 MM 2.36" / 60 MM
0W316-0R6 418.1666
380-415V RED
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 3.19" / 81 MM 2.87" / 73 MM 2.56" / 65 MM 2.13" / 54 MM 1.57" / 40 MM
0W332-0R6 418.3266 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.66" / 93 MM 3.43" / 87 MM 2.99" / 76 MM 2.40" / 61 MM 2.36" / 60 MM
0W316-R11 418.16665
440-460V RED
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 3.19" / 81 MM 2.87" / 73 MM 2.56" / 65 MM 2.13" / 54 MM 1.57" / 40 MM
0W332-R11 418.32665 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.66" / 93 MM 3.43" / 87 MM 2.99" / 76 MM 2.40" / 61 MM 2.36" / 60 MM
0W216-0R6 418.1663
200-250V BLUE
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.87" / 73 MM 2.56" / 65 MM 2.05" / 52 MM 1.57" / 40 MM
0W232-0R6 418.3263 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.66" / 93 MM 3.43" / 87 MM 2.99" / 76 MM 2.40" / 61 MM 2.36" / 60 MM
0W416-0R9 418.1665
208-250V BLUE
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 3.46" / 88 MM 2.87" / 73 MM 2.56" / 65 MM 2.17" / 55 MM 1.61" / 41 MM
0W432-0R9 418.3265 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.98" / 101 MM 3.43" / 87 MM 2.99" / 76 MM 2.48" / 63 MM 2.40" / 61 MM
0W416-0R6 418.1667
346-415V RED
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 3.46" / 88 MM 2.87" / 73 MM 2.56" / 65 MM 2.17" / 55 MM 1.61" / 41 MM
0W432-0R6 418.3267 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.98" / 101 MM 3.43" / 87 MM 2.99" / 76 MM 2.48" / 63 MM 2.40" / 61 MM
0W416-R11 418.16675
440-460V RED
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 3.46" / 88 MM 2.87" / 73 MM 2.56" / 65 MM 2.17" / 55 MM 1.61" / 41 MM
0W432-R11 418.32675 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.98" / 101 MM 3.43" / 87 MM 2.99" / 76 MM 2.48" / 63 MM 2.40" / 61 MM
0W216-0R4 418.1660
100-130V YELLOW
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.87" / 73 MM 2.56" / 65 MM 2.05" / 52 MM 1.57" / 40 MM
0W232-0R4 418.3260 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.66" / 93 MM 3.43" / 87 MM 2.99" / 76 MM 2.40" / 61 MM 2.36" / 60 MM
0W216-0R9 418.1668
380-415V RED
2.76" / 70 MM 3.43" / 87 MM 2.20" / 56 MM 2.76" / 70 MM 2.87" / 73 MM 2.87" / 73 MM 2.56" / 65 MM 2.05" / 52 MM 1.57" / 40 MM
0W232-0R9 418.3268 3.54" / 90 MM 4.17" / 106 MM 2.68" / 68 MM 3.31" / 84 MM 3.66" / 93 MM 3.43" / 87 MM 2.99" / 76 MM 2.40" / 61 MM 2.36" / 60 MM
4 13
4 3 2 1
B
A
SHEET 1 OF 1
PROJECT NO.
TITLE:
ALL PRINTED COPIES
ARE UNCONTROLLED
DWG NO.
REVSIZE
C
UNLESS OTHERWISE SPECIFIED:
DO NOT SCALE DRAWING.
ALL DIMENSIONS ARE IN INCHES.
ALL ANGLES ARE IN DEGREES.
The information in this document is
the exclusive PROPRIETARY
property of LEVITON MFG. CO.,
INC. It is disclosed with the
understanding that acceptance or
review by the recipient constitutes
an undertaking by the recipient:
(1) to hold this information in strict
confidence.
(2) not to disclose, duplicate, copy,
or use the information, in whole or in
part, for any purpose other than that
for which disclosed.
DWN BY
CHK BY
TOLERANCES
THIRD ANGLE PROJECTION
SCALE:1:1
MFG
ENGRG
REV. DATE ECO NUMBER APVDCHGD
1/2°
.XX
.XXX
±
±
INCH
.01
.005
ANGLES: ±
.X
.XX
METRIC
.2 mm
.1 mm
±
±
Copyright 2010. Unpublished.
All Rights Reserved.
2
C
D
B
A
C
D
-
---
-
---
-
-
---
-- --
-
A - PRA KNJ
09/04/2013
09/04/2013KNJ
KNJ 09/04/2013
IP67 16A/32A ASSEMBLY
FLUSH MTG RECEPTACLE
KNJ 09/04/2013
05/30/2013PRA
A
ORA7006-D01
PROJ-02986
-
-
Panel Mounting Socket Outlets — Watertight (IP66/IP67)
Amps Poles A mm(in) B mm(in) C mm(in) D mm(in) Ø E mm(in) F mm(in) G mm(in) H mm(in) I mm(in) Ø J mm(in)
63A
2P+E(2P,3W)
85(3.3) 110(4.3) 80(3.1) 100(3.9) 6.5(0.2) 92(3.6) 80(3.1) 71.2(2.8) 65(2.5) 112(4.4)3P+E(3P,4W)
3P+N+E (4P,5W)
125A
2P+E(2P,3W)
90(3.5) 114.5(4.5) 90(3.5) 114(4.4) 6.5(0.2) 104(4.0) 92(3.6) 85.7(3.3) 75.4(2.97) 128.5(5.0)3P+E(3P,4W)
3P+N+E (4P,5W)
NOTE:
63A
125A
G
C
ØE
AF B
ØJ
D
I
H
17
www.leviton.com/ENIEC60309
EN/IEC 60309 Industrial Plug & Socket Dimensions
Amps Poles A mm(in) B mm(in) C mm(in) D mm(in) E mm(in) F mm(in) G mm(in) H mm(in) K mm(in) L mm(in) PG/M Ø N mm(in)
63A
2P+E (2P,3W)
115(4.5) 96(3.8) 6(0.2) 10(0.4) 235(9.2) 205(8.1) 80(3.1) 125(4.9) 15(0.6) 267(10.5) 29/32 112(4.4)3P+E (3P,4W)
3P+N+E(4P,5W)
125A
2P+E (2P,3W)
135(5.3) 120(4.72) 6(0.2) 13(0.5) 300(11.8) 270(10.6) 100(3.9) 157(6.2) 17(0.7) 346(13.6) 48/63 128(5.0)3P+E (3P,4W)
3P+N+E (4P,5W)
Surface Mounting Socket Outlet — Watertight (IP66/IP67)
D
FK
G
A
B
Ø C
Ø N
E
H
PG/M
L
UPPER VALUE = INCH
LOWER VALUE = MM
AMP DIM A DIM B DIM C DIM D DIM E DIM F DIM G DIM H DIM K DIM L PG/M N
63 4.53"
115 MM 3.78"
96 MM 0.24"
6 MM 0.39"
10 MM 9.25"
235 MM 8.07"
205 MM 3.15"
80 MM 4.92"
125 MM 0.59"
15 MM 10.51"
267 MM 29/32 4.41"
112 MM
125 5.31"
135 MM
4.72"
120 MM
0.24"
6 MM
0.51"
13 MM
11.81"
300 MM
10.63"
270 MM
3.94"
100 MM
6.18"
157 MM
0.67"
17 MM
13.62"
346 MM 48/63 5.04"
128 MM
Catalog Number SCAME CODE VOLTAGE COLOR CLOCK (Hr)
0W263-0S6 515.6353
200-250V BLUE
W2125-0S6 515.12553
0W363-0S9 515.6354
200-250V BLUE
W3125-0S9 515.12554
0W463-0S9 515.6355
208-250V BLUE
W4125-0S9 515.12555
0W363-0S6 515.6356
380-415V RED
W3125-0S6 515.12556
0W363-S11 515.63565
440-460V RED
W3125-S11 515.125565
0W463-0S6 515.6357
346-415V RED
W4125-0S6 515.12557
0W463-S11 515.63575
440-460V RED
W4125-S11 515.125575
4 13
4 3 2 1
B
A
SHEET 1 OF 1
PROJECT NO.
TITLE:
ALL PRINTED COPIES
ARE UNCONTROLLED
STATUS:
DWG NO.
REVSIZE
C
UNLESS OTHERWISE SPECIFIED:
DO NOT SCALE DRAWING.
ALL DIMENSIONS ARE IN INCHES.
ALL ANGLES ARE IN DEGREES.
The information in this document is
the exclusive PROPRIETARY
property of LEVITON MFG. CO.,
INC. It is disclosed with the
understanding that acceptance or
review by the recipient constitutes
an undertaking by the recipient:
(1) to hold this information in strict
confidence.
(2) not to disclose, duplicate, copy,
or use the information, in whole or in
part, for any purpose other than that
for which disclosed.
DWN BY
CHK BY
TOLERANCES
THIRD ANGLE PROJECTION
SCALE:1:1
MFG
ENGRG
REV. DATE ECO NUMBER APVDCHGD
1/2°
.XX
.XXX
±
±
INCH
.01
.005
ANGLES: ±
.X
.XX
METRIC
.2 mm
.1 mm
±
±
Copyright 2010. Unpublished.
All Rights Reserved.
2
C
D
B
A
C
D
-
---
-
---
-
-
---
-- --
-
A - PRA KNJ
09/19/2013
09/19/2013KNJ
KNJ 09/19/2013
IP67 63A/125A ASSEMBLY
SURFACE MTG RECEPTACLE
KNJ 09/19/2013
05/30/2013PRA
A
Production Release
ORA7010-D01
PROJ-02986
-
-
Surface Mounting Socket Outlets — Watertight (IP66/IP67)
Amps Poles A mm(in) B mm(in) C mm(in) D mm(in) E mm(in) F mm(in) G mm(in) H mm(in) I mm(in) J mm(in)
16A
2P+E(2P,3W) 65(2.6) 52(2.0) 5(0.2) 112(4.4) 7.5(0.3) 127(5.0) 73 (2.9) 91(3.6) 134(5.3) 8(0.3)
3P+E(3P,4W) 65(2.6) 52(2.0) 5(0.2) 112(4.4) 7.5(0.3) 127(5.0) 81(3.2) 95(3.7) 135(5.3) 8(0.3)
3P+N+E(4P,5W) 65(2.6) 52(2.0) 5(0.2) 112(4.4) 7.5(0.3) 127(5.0) 88(3.5) 98(3.9) 136(5.3) 8(0.3)
32A
2P+E(2P,3W) 80(3.1) 66(2.6) 5(0.2) 121(4.8) 7.5(0.3) 137(5.4) 93(3.7) 112(4.4) 147(5.8) 8(0.3)
3P+E(3P,4W) 80(3.1) 66(2.6) 5(0.2) 121(4.8) 7.5(0.3) 137(5.4) 93(3.7) 112(4.4) 147(5.8) 8(0.3)
3P+N+E 4P,5W) 80(3.1) 66(2.6) 5(0.2) 121(4.8) 7.5(0.3) 137(5.4) 101(4.0) 113(4.4) 149(5.9) 8(0.3)
C
C = 0.197” / 5 MM
E = 0.295” / 7.5 MM
J = 0.315” / 8 MM
E
F
I
H
B
D
G
A
J
C
DIMENSIONS: INCH / MM
Catalog Number SCAME CODE VOLTAGE COLOR Dimension A Dimension B Dimension D Dimension F Dimension G Dimension H Dimension L CLOCK (Hr)
0W216-0S6 517.1653
200 - 250V BLUE
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 2.87" / 73 MM 3.58" / 91 MM 5.28" / 134 MM
0W232-0S6 517.3253 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 3.66" / 93 MM 4.41" / 112 MM 5.79" / 147 MM
0W316-0S9 517.1654
200 - 250V BLUE
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 3.19" / 81 MM 3.74" / 95 MM 5.31" / 135 MM
0W332-0S9 517.3254 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 3.66" / 93 MM 4.41" / 112 MM 5.79" / 147 MM
0W416-0S9 517.1655
208 - 250V BLUE
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 3.46" / 88 MM 3.86" / 98 MM 5.35" / 136 MM
0W432-0S9 517.3255 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 3.98" / 101 MM 4.45" / 113 MM 5.87" / 149 MM
0W316-0S6 517.1656
380 - 415V RED
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 3.19" / 81 MM 3.74" / 95 MM 5.31" / 135 MM
0W332-0S6 517.3256 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 3.66" / 93 MM 4.41" / 112 MM 5.79" / 147 MM
0W316-S11 517.16565
440 - 460V RED
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 3.19" / 81 MM 3.74" / 95 MM 5.31" / 135 MM
0W332-S11 517.32565 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 3.66" / 93 MM 4.41" / 112 MM 5.79" / 147 MM
0W416-0S6 517.1657
346 - 415V RED
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 3.46" / 88 MM 3.86" / 98 MM 5.35" / 136 MM
0W432-0S6 517.3257 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 3.98" / 101 MM 4.45" / 113 MM 5.87" / 149 MM
0W416-S11 517.16575
440 - 460V RED
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 3.46" / 88 MM 3.86" / 98 MM 5.35" / 136 MM
0W432-S11 517.32575 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 3.98" / 101 MM 4.45" / 113 MM 5.87" / 149 MM
0W216-0S9 517.1658
380 - 415V RED
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 2.87" / 73 MM 3.58" / 91 MM 5.28" / 134 MM
0W232-0S9 517.3258 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 3.66" / 93 MM 4.41" / 112 MM 5.79" / 147 MM
0W216-0S4 517.1650
100-130V YELLOW
2.56" / 65 MM 2.05" / 52 MM 4.41" / 112 MM 5.00" / 127 MM 2.87" / 73 MM 3.58" / 91 MM 5.28" / 134 MM
0W232-0S4 517.3250 3.15" / 80 MM 2.60" / 66 MM 4.76" / 121 MM 5.39" / 137 MM 3.66" / 93 MM 4.41" / 112 MM 5.79" / 147 MM
4 13
4 3 2 1
B
A
SHEET 1 OF 1
PROJECT NO.
TITLE:
ALL PRINTED COPIES
ARE UNCONTROLLED
STATUS:
DWG NO.
REVSIZE
C
UNLESS OTHERWISE SPECIFIED:
DO NOT SCALE DRAWING.
ALL DIMENSIONS ARE IN INCHES.
ALL ANGLES ARE IN DEGREES.
The information in this document is
the exclusive PROPRIETARY
property of LEVITON MFG. CO.,
INC. It is disclosed with the
understanding that acceptance or
review by the recipient constitutes
an undertaking by the recipient:
(1) to hold this information in strict
confidence.
(2) not to disclose, duplicate, copy,
or use the information, in whole or in
part, for any purpose other than that
for which disclosed.
DWN BY
CHK BY
TOLERANCES
THIRD ANGLE PROJECTION
SCALE:1:1
MFG
ENGRG
REV. DATE ECO NUMBER APVDCHGD
1/2°
.XX
.XXX
±
±
INCH
.01
.005
ANGLES: ±
.X
.XX
METRIC
.2 mm
.1 mm
±
±
Copyright 2010. Unpublished.
All Rights Reserved.
2
C
D
B
A
C
D
-
---
-
---
-
-
---
-- --
-
A - PRA KNJ
09/19/2013
09/19/2013KNJ
KNJ 09/19/2013
IP67 16A/32A ASSEMBLY
SURFACE MTG RECEPTACLE
KNJ 09/19/2013
05/30/2013PRA
A
Production Release
ORA7009-D01
PROJ-02986
-
-
www.leviton.com/ENIEC60309
18
EN/IEC 60309 Industrial Plug & Socket Dimensions
Amps A mm(in) B mm(in) C mm(in) D mm(in) E mm(in) F mm(in) G mm(in)
63A 235(9.2) 115(4.5) 117(4.6) 96(3.8) 6(0.2) 207(8.1) 80(3.1)
125A 300(11.8) 135 (5.3) 136(5.3) 120(4.7) 6(0.2) 270(10.6) 100(3.9)
Back Boxes — Watertight (IP66/IP67)
B
A
C
E
E= .197
5 MM
D
C G
B
D
F
A
E
.236
6 MM
E=
F
16A & 32A VIEW 63A & 125A VIEW
DIMENSION: INCH / MM
DIMENSION: INCH / MM
IP67IP44/IP67
AMP Cat No. Scame Code Dimension A Dimension B Dimension C Dimension D Dimension F
16A 0BB16-00A 570.0116 5.00 " / 127 MM 2.87" / 73 MM 3.27" / 83 MM 2.05" / 52 MM 4.41" / 112 MM
32A 0BB32-00A 570.0132 5.39" / 137 MM 3.43" / 87 MM 3.90" / 99 MM 2.60" / 66 MM 4.80" / 122 MM
AMP Cat No. Scame Code Dimension A Dimension B Dimension C Dimension D Dimension F Dimension G
63A 0BB63-00A 570.0163 9.25" / 235 MM 4.53" / 115 MM 4.61" / 117 MM 3.78" / 96 MM 8.15" / 207 MM 3.15" / 80 MM
125A BB125-00A 570.0125 11.81" / 300 MM 5.31" / 135 MM 5.35" / 136 MM 4.72" / 120 MM 10.63" / 270 MM 3.94" / 100 MM
4 13
4 3 2 1
B
A
SHEET 1 OF 1
PROJECT NO.
TITLE:
ALL PRINTED COPIES
ARE UNCONTROLLED
STATUS:
DWG NO.
REVSIZE
C
UNLESS OTHERWISE SPECIFIED:
DO NOT SCALE DRAWING.
ALL DIMENSIONS ARE IN INCHES.
ALL ANGLES ARE IN DEGREES.
The information in this document is
the exclusive PROPRIETARY
property of LEVITON MFG. CO.,
INC. It is disclosed with the
understanding that acceptance or
review by the recipient constitutes
an undertaking by the recipient:
(1) to hold this information in strict
confidence.
(2) not to disclose, duplicate, copy,
or use the information, in whole or in
part, for any purpose other than that
for which disclosed.
DWN BY
CHK BY
TOLERANCES
THIRD ANGLE PROJECTION
SCALE:1:1
MFG
ENGRG
REV. DATE ECO NUMBER APVDCHGD
1/2°
.XX
.XXX
±
±
INCH
.01
.005
ANGLES: ±
.X
.XX
METRIC
.2 mm
.1 mm
±
±
Copyright 2013. Unpublished.
All Rights Reserved.
2
C
D
B
A
C
D
-
---
-
---
-
-
---
-- --
-
A - PRA KNJ
09/19/2013
09/19/2013KNJ
KNJ 09/19/2013
16A/32A/63A/125A
BACK BOX ACCESSORY
KNJ 09/19/2013
05/30/2013PRA
A
Production Release
ORA7014-D01
PROJ-02986
-
-
Back Boxes — Splashproof (IP44) and Watertight (IP66/IP67)
Amps A mm(in) B mm(in) C mm(in) D mm(in) E mm(in) F mm(in)
16A 127(5.00) 73(2.9) 83(3.3) 52(2.0) 5(0.2) 112 (4.4)
32A 137(5.39) 87(3.4) 99(3.9) 66(2.6) 5(0.2) 122 (4.8)
B
A
C
E
E= .197
5 MM
D
C
G
B
D
F
A
E
.236
6 MM
E=
F
16A & 32A VIEW 63A & 125A VIEW
DIMENSION: INCH / MM
DIMENSION: INCH / MM
IP67IP44/IP67
AMP Cat No. Scame Code Dimension A Dimension B Dimension C Dimension D Dimension F
16A 0BB16-00A 570.0116 5.00 " / 127 MM 2.87" / 73 MM 3.27" / 83 MM 2.05" / 52 MM 4.41" / 112 MM
32A 0BB32-00A 570.0132 5.39" / 137 MM 3.43" / 87 MM 3.90" / 99 MM 2.60" / 66 MM 4.80" / 122 MM
AMP Cat No. Scame Code Dimension A Dimension B Dimension C Dimension D Dimension F Dimension G
63A 0BB63-00A 570.0163 9.25" / 235 MM 4.53" / 115 MM 4.61" / 117 MM 3.78" / 96 MM 8.15" / 207 MM 3.15" / 80 MM
125A BB125-00A 570.0125 11.81" / 300 MM 5.31" / 135 MM 5.35" / 136 MM 4.72" / 120 MM 10.63" / 270 MM 3.94" / 100 MM
4 13
4 3 2 1
B
A
SHEET 1 OF 1
PROJECT NO.
TITLE:
ALL PRINTED COPIES
ARE UNCONTROLLED
STATUS:
DWG NO.
REVSIZE
C
UNLESS OTHERWISE SPECIFIED:
DO NOT SCALE DRAWING.
ALL DIMENSIONS ARE IN INCHES.
ALL ANGLES ARE IN DEGREES.
The information in this document is
the exclusive PROPRIETARY
property of LEVITON MFG. CO.,
INC. It is disclosed with the
understanding that acceptance or
review by the recipient constitutes
an undertaking by the recipient:
(1) to hold this information in strict
confidence.
(2) not to disclose, duplicate, copy,
or use the information, in whole or in
part, for any purpose other than that
for which disclosed.
DWN BY
CHK BY
TOLERANCES
THIRD ANGLE PROJECTION
SCALE:1:1
MFG
ENGRG
REV. DATE ECO NUMBER APVDCHGD
1/2°
.XX
.XXX
±
±
INCH
.01
.005
ANGLES: ±
.X
.XX
METRIC
.2 mm
.1 mm
±
±
Copyright 2013. Unpublished.
All Rights Reserved.
2
C
D
B
A
C
D
-
---
-
---
-
-
---
-- --
-
A - PRA KNJ
09/19/2013
09/19/2013KNJ
KNJ 09/19/2013
16A/32A/63A/125A
BACK BOX ACCESSORY
KNJ 09/19/2013
05/30/2013PRA
A
Production Release
ORA7014-D01
PROJ-02986
-
-
19
www.leviton.com/ENIEC60309
Additional Industrial Products and Accessories
V-0-MAX® Locking Receptacles
Locking Receptacles
n 15, 20 & 30 Amp
n 125V thru 600V
n NEMA and Non-NEMA Configurations
n UL/Fed.Spec./CSA/NOM
n UL V-O Flammability Rating
n Color-Coding Indicates Voltage Ratings
Wire Management
Wire Mesh Grips
n Pulling, Support, & Strain Relief
n Single & Double Eyes
n Flexible, Offset & Rotating Eyes
n Closed, Split Lace,or Split Rod Mesh
n Liquid Tight, Wide Range, Deluxe Grips
Portable Outlet Boxes
Industrial Grade Portable Outlet Boxes
n Made from a High-Performance, UL Listed
TPV for durability and safety
n Pendant and feed-thru
styles; in single- and
two-gang configurations
Cover Plates
n Durable polycarbonate
construction provides
exceptional impact
resistance and service life
n Many configurations
available for a variety
of wiring device
combinations
n Weather-resistant
flip-lid versions provide
NEMA 3R protection
while not in use
Wetguard® Watertight Devices
Watertight Devices
n 15, 20 and 30 Amp
n 125V thru 600V
n NEMA and Non-NEMA Configurations
n UL/Fed. Spec./CSA/NOM
n Full complement of device types: plugs,
connectors, single and duplex outlets
and single inlets
n IEC IP66, IP67, NEMA 4, 4X, 6, 6P
Wetguard FD Box System
n Available in one-, two- and three-gang configurations
n Rigid PVC construction
n Accepts direct connection
of 1", 3/4" and 1/2" PVC
conduit
n Patented design
allows for combining
single gang devices
in multi-gang
configurations
n IEC IP66, NEMA 4, 4X, 12 Power Distribution Boxes
The Box™
n Reinforced metal housing
and legs withstand
heavy abuse
n Weatherproof device
covers prevent moisture
from entering contacts
n Available with standard
or high-current GFCI protection
Portable GFCI
Automatic & Manual
Reset Cord Sets
n Rainproof, Outdoor rated
n Fully Complies with
NEC and OSHA regulations
for construction sites
n 15A and 20A, 120V
versions available;
in a variety of cord lengths
Black & White® Plugs & Connectors
Plugs & Connectors
n 15, 20 & 30 Amp
n 125V thru 600V
n NEMA and Non-NEMA Configurations
n UL/Fed.Spec./CSA/NOM
North American Configurations
IEC 60309 Pin & Sleeve
n 20 to 100 Amp, IP67 Watertight
- Plugs & Connectors
- Receptacles & Inlets
n Back Boxes
n Replacement Components
n UL/CSA
Leviton Manufacturing Co., Inc.
201 North Service Road, Melville, NY 11747
Phone: 1-800-323-8920 • FAX: 1-800-832-9538
Tech Line (8:30AM-7:00PM E.S.T. Mon-Fri): 1-800-824-3005
Leviton Manufacturing of Canada, Ltd.
165 Hymus Blvd, Pointe-Claire, QC H9R 1E9
Telephone: 1-800-469-7890 • FAX: 1-800-563-1853
Leviton S. de R.L. de C.V.
Lago Tana 43, Col. Huichapan, Miguel Hidalgo, CP 11290 México DF
Tel. (+52) 55-5082-1040 • Fax: (+52) 55-5386-1797 • www.leviton.com.mx
Visit us on the web at: www.leviton.com/industrial • email: industrial@leviton.com
Copyright 2014 Leviton Manufacturing Co., Inc. All rights reserved. Note: Features and specifications subject to change. Q-876
052914
Industrial Grade Switches
Heavy Duty AC Control
with Toggle Actuator
n 15, 20 & 30 Amp
n 120/277V AC
n SP, DP 3-Way, 4-Way
n UL/Fed. Spec./CSA
n Back or Side Wired
Grounding Terminal
Motor Starter Switches - AC Control
for Single-Phase or Three-Phase Motor Loads
n 30, 40 & 60 AMP
n Suitable as Motor
Disconnect (30A & 40A)
n 120V AC thru 600V AC
n Max HP Rating:
20HP 600V AC
n Available with Type 1,
3R or 4X enclosures
n cUL/NOM
Safety Disconnect Switches-
AC Control for Horsepower
Rated Motor Loads
n 30, 60 & 100 Amp
n Heavy Duty 600V AC
n Max HP Rating: 50HP 600V AC
n Fused and Non-Fused
n Dust-tight and Watertight
n IP67, IP65, NEMA 3R, 4X, 12K
Surge Protective Devices
Surge Panels (Type 2)
n Available for both Delta and
WYE Transformers
n NEMA-rated enclosures
n Limited Lifetime Product
Warranty
Communication Modules
3803 Series (Type 4)
n Surface Mount
n UL Listed
n 2 Options for Ground Connection
n For Use on Allen Bradley PH-485,
“Blue Hose” Networks,
and Modbus Networks
n Protects Programmable Logic
Devices from Surges in Harsh
Industrial and High EMI Environments
Wallplates
Stainless Steel Wallplates
n Type 302 Stainless Steel for optimum
strength and corrosion resistance
n Expansive selection of single- and
multi-gang configurations
n Also available in Type 430
Stainless Steel, Aluminum,
Chrome and Brass
Single Pole Devices
17 Series-Taper Nose and
19 Series Ball Nose
n Up to 690 Amp, 600V
n Insulators Molded from
Impact-Resistant TPV or
vulcanized neoprene
n Slit and Cam Male Contact Design
- Compensates for Wear
n Color-Coded Insulators
for Easy Phase Identification
16 Series Taper Nose and
18 Series Ball Nose
n Up to 400 Amp, 600 V
n Insulators Molded from Impact-Resistant
TPV or vulcanized neoprene
n Slit and Cam Male Contact Design
- Compensates for Wear
n Color-Coded
Insulators for Easy
Phase Identification
n UL Listed and CSA Certified
High-Amperage Connectivity
Rhino-Hide® 49 Series
Connectors and Receptacles
n For Oil/Gas Rig and Power
Distribution Applications
n Up to 1135 Amp, 1000V AC or DC
n Accepts cable range 313 to 777 MCM
n Insulators Molded from
Impact-Resistant
Santoprene™ TPV
n 10 Colors available for easy
phase identification
n Grounding Contact Available
