Downlighting – Professional
BPhilips Lightolier For complete specification information visit www.lightolier.com
Downlighting
Professional – Downlighting
CComprehensive lighting catalog 7th Edition
Section 1
Downlighting – Professional
DPhilips Lightolier For complete specification information visit www.lightolier.com
Professional – Downlighting
1.1Comprehensive lighting catalog 7th Edition
LED lighting (light emitting diode) > 1.2
CFL lighting (CFL lighting) > 1.16
HID lighting (High intensity discharge) > 1.44
Low & line voltage lighting lighting > 1.86
ProSpec Linear > 1.140
Accessories & options > 1.144
Philips Lightolier continues to set
new standards in design, efficiency and
flexibility with its Calculite, specification
grade, architectural downlights.
Contents
Downlighting – Professional
1.2 Philips Lightolier For complete specification information visit www.lightolier.com
LED lighting
Professional – Downlighting
1.3Comprehensive lighting catalog 7th Edition
Contents
1.75" Round > 1.4
1.75" Square > 1.5
4", 6" & 7" Round > 1.6
4" & 6" Square > 1.12
4" & 6" Cylinders > 1.14
Remote phosphor technology > 1.15
1.4 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
Calculite LED 1¾" aperture
Round downlight
Trim/frame compatibility
Aperture
Light engine
/Frame-in kit Description
Ceiling
cutout Type
Input
voltage Technology Wattage Length Width Height
1.75"
Flanged
C2L04DL30K12R1
C2L04DL30K17R1
C2L04DL30K25R1
C2L04DL30K38R1
400 Lumen downlight, 3000K, 12 Degree beam
400 Lumen downlight, 3000K, 17 Degree beam
400 Lumen downlight, 3000K, 25 Degree beam
400 Lumen downlight, 3000K, 38 Degree beam
2 1/8"
2 1/8"
2 1/8"
2 1/8"
Non-IC
Non-IC
Non-IC
Non-IC
120V
120V
120V
120V
White Light LED
White Light LED
White Light LED
White Light LED
See
specification
sheet
10.25"
10.25"
10.25"
10.25"
4.25"
4.25"
4.25"
4.25"
5.25"
5.25"
5.25"
5.25"
* For flangeless, add “FT". Example: C2L04DLFT30K12R1. CA2FMR flangeless accessory ring recommended for gypsum installations.
How to specify
Light engine/Frame-in kit CCT Beam spread Installation/input voltage Reflector
C2L04DL 30K 12 R1 C2LDLWHW (Downlight)
C2LLWWHW (Wall washer)
1125
2250
4500
3375
30°
60°
750
1500
3000
2250
30°
60°
400
800
1600
1200
30°
60°
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
4711
2969
534
320
253
100
26
15
9
6
4
2
1
0
186
93
51
10
5
2
0
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
3123
2589
1213
476
261
125
31
11
5
2
1
0
0
0
200
147
57
8
2
0
0
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
1517
1366
972
564
291
114
37
18
10
5
2
1
0
0
118
155
57
12
4
1
0
1 ¾", 400 Lumen, round, 1
Reflector trim: C2L04DL30K11R1/C2LDLCCDW
Output lumens: 347
Center beam candlepower: 4711
Correlated color temp: 3000K
1 ¾", 400 Lumen, round, 17°
Reflector trim:C2L04DL30K17R1/C2LDLCCDW
Output lumens: 414
Center beam candlepower: 3123
Correlated color temp: 3000K
1 ¾", 400 Lumen, round, 25°
Reflector trim:C2L04DL30K25R17R1/C2LDLCCDW
Output lumens: 348
Center beam candlepower: 1517
Correlated color temp: 3000K
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
Beam spread
options Reflector finish options Ordering guide: installation accessories
Beam
spread Code
Reflector
finish
Aperture -
matching flange Flangeless Accessories-installation Lumen package (nominal)
12 Degree
17 Degree
25 Degree
38 Degree
12
17
25
38
Comfort clear diffuse
White
Champagne bronze
Black
CCDP
WHW
CCZP
BKP
CCDFT
WHFT
CCZFT
BKFT
CA2FMR
CA2X2FMR
C2LIC
C2LMP
Round aperture flush-mount mud-in ring*
Square aperture flush-mount mud-in ring*
IC frame (new construction)*
New construction mounting pan*
* Recommended for specific applications
1.5Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
Trim/frame compatibility
Aperture
Light engine
/Frame-in kit Description
Ceiling
cutout Type
Input
voltage Technology Wattage Length Width Height
1.75"
Flanged
C2L04DL30K12R1
C2L04DL30K17R1
C2L04DL30K25R1
C2L04DL30K38R1
400 Lumen downlight, 3000K, 12 Degree beam
400 Lumen downlight, 3000K, 17 Degree beam
400 Lumen downlight, 3000K, 25 Degree beam
400 Lumen downlight, 3000K, 38 Degree beam
2 1/8"
2 1/8"
2 1/8"
2 1/8"
Non-IC
Non-IC
Non-IC
Non-IC
120V
120V
120V
120V
White Light LED
White Light LED
White Light LED
White Light LED
See
specification
sheet
10.25"
10.25"
10.25"
10.25"
4.25"
4.25"
4.25"
4.25"
5.25"
5.25"
5.25"
5.25"
* For flangeless, add “FT". Example: C2L04DLFT30K12R1. CA2X2FMR flangeless accessory ring recommended for gypsum installations.
Calculite LED 1¾" aperture
Square downlight
How to specify
Light engine/Frame-in kit CCT Beam spread Installation/input voltage Reflector
C2L04DL 30K 12 R1 C2X2LDLWHW (Downlight)
C2X2LLWWHW (Wall washer)
Beam spread
options Reflector finish options Ordering guide: installation accessories
Beam
spread Code
Reflector
finish
Aperture -
matching flange Flangeless Accessories-Installation Lumen Package (nominal)
12 Degree
17 Degree
25 Degree
38 Degree
12
17
25
38
Comfort clear diffuse
White
Champagne bronze
Black
CCDP
WHW
CCZP
BKP
CCDFT
WHFT
CCZFT
BKFT
CA2FMR
CA2X2FMR
C2LIC
C2LMP
Round aperture flush-mount mud-in ring*
Square aperture flush-mount mud-in ring*
IC frame (new construction)*
New construction mounting pan*
* Recommended for specific applications
200
400
800
600
30°
60°
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
787
797
747
569
350
164
66
31
17
8
2
1
0
0
76
152
79
21
6
1
0
1 ¾", 400 Lumen, round, 3 Optional installation accessories
The standard C2L product offering is Non-IC, wet location listed* with no additional
frame-in kit” required. Listed below are additional frame options.
Reflector trim: C2L04DL30K38R1/C2LDLCCDW
Output lumens: 335
Center beam candlepower: 787
Correlated color temp: 3000K
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
Square aper ture photometric data not yet available at time of printing.
Please see product specification sheet for updated, accurate performance data.
C2LIC
C2LMP
CA2FMR
CA2X2FMR
IC frame (new construction).
New construction mounting pan provides ability to prelocate.
wiring for easy below-ceiling access. Includes bar hangers with
preset screws which accommodate 12"-24" joist spacing. Bars also
attach to T-bar ceilings. Width: 5.5", Length (min): 13.12"
Round aperture flush-mount mud-in ring. Recommended for
gypsum applications. Perforated flange allows installation only
1.4"from vertical structure, including corners.
Square aperture flush-mount mud-in ring. Recommended for
gypsum applications. Perforated flange allows installation only
1.4"from vertical structure, including corners. Square plate
secures magnetically to mud-in ring. Tether included.
2"
2"
2"
13 "
2"
2"
8"
4"
4"
3"
2"
2"
2"
2"
"
2"
C2LIC
C2LMP
C2LMP
CA2X2FMR
1.6 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
Calculite LED 6" & 7" aperture
Downlight medium beam (0.9 S.C.)
Trim/frame compatibility
Aperture Trim kit
Light engine
description Frame-in kit*
Ceiling
cutout Type
Input
voltage Technology Wattage** Width Height
6"
7"
C6L1520DL_ _ _M
C7L1520DL_ _ _M
1500/2000 Lumen
downlight
1500/2000 Lumen
downlight
C6L15N1 (1500 Lumen)
C6L15N2 (1500 Lumen)
C6L20N1 (2000 Lumen)
C6L20N2 (2000 Lumen)
C7L15N1 (1500 Lumen)
C7L15N2 (1500 Lumen)
C7L20N1 (2000 Lumen)
C7L20N2 (2000 Lumen)
6 9/16"
6 9/16"
6 9/16"
6 9/16"
8"
8"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
120V
277V
120V
277V
120V
277V
120V
277V
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
See
specification
sheet
10 1/8"
10 1/8"
10 1/8"
10 1/8"
11 13/16"
11 13/16"
11 13/16"
11 13/16"
7 1/4"
7 1/4"
7 1/4"
7 1/4"
8 1/8"
8 1/8"
8 1/8"
8 1/8"
*Remodeler & retrofit frames also available. See specification sheet for details
How to specify
Trim kit CCT
Beam
(6" & 7" only)
Finish/
flange
Frame-in
kit
C6L1520DL 27K MCLW C6L15N1
Color
temperature options Reflector finish options
Color
temperature Code
Reflector
finish
White
flange
Aperture -
matching flange Flangeless
2700K
3000K
3500K
4000K
27K
30K
35K
40K
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A
CLFT
CCLFT
CCDFT
CCZFT
WHFT
500
1000
2000
1500
30°
60°
500
1000
1500
2000
2500 30°
60°
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
1672
1625
1551
1477
1405
1182
612
313
139
32
3
1
1
0
0
0
0
0
0
153
417
501
205
35
1
0
0
0
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
2298
2233
2130
2028
1931
1630
843
431
191
44
4
2
1
1
0
0
0
0
0
210
573
690
282
48
2
1
0
0
6", 1500 Lumen
Reflector trim: C6L1520DL30KMCLW
Output lumens: 1312
Correlated color temp: 3000K
6", 2000 Lumen
Reflector trim: C6L1520DL30KMCLW
Output lumens: 1805
Correlated color temp: 3000K
C6L1520DL30KWCLW
C6L1520DL30KWCLW
500
1000
2000
1500
30°
60°
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
1692
1664
1634
1594
1518
1300
768
351
147
35
3
1
10
0
0
0
0
0
0
158
449
562
238
37
1
0
0
0
7", 2000 Lumen
Reflector trim: C7L1520DL30KMCLW
Output lumens: 1998
Correlated color temp: 3000K
C6L1520DL30KWCLW
Length (bars) is 20" -30"
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
1.7Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
Trim/frame compatibility
Aperture Trim kit
Light engine
description Frame-in kit*
Ceiling
cutout Type
Input
voltage Technology Wattage** Width Height
4"
4"
6"
7"
C4L05DL
C4L10DL
C6L1520DL_ _ _W
C7L1520DL_ _ _W
500 Lumen downlight
1000 Lumen
downlight
1500/2000 Lumen
downlight
1500/2000 Lumen
downlight
C4L05N1
C4L05N2
C4L10N1
C4L10N2
C6L15N1 (1500 Lumen)
C6L15N2 (1500 Lumen)
C6L20N1 (2000 Lumen)
C6L20N2 (2000 Lumen)
C7L15N1 (1500 Lumen)
C7L15N2 (1500 Lumen)
C7L20N1 (2000 Lumen)
C7L20N2 (2000 Lumen)
5 1/8"
5 1/8"
5 1/8"
5 1/8"
6 9/16"
6 9/16"
6 9/16"
6 9/16"
8"
8"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
120V
277V
120V
277V
120V
277V
120V
277V
120V
277V
120V
277V
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
See
specification
sheet
9 3/16"
9 3/16"
9 3/16"
9 3/16"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
11 13/16"
11 13/16"
11 13/16"
11 13/16"
6 1/8"
6 1/8"
6 1/8"
6 1/8"
7 1/4"
7 1/4"
7 1/4"
7 1/4"
8 1/8"
8 1/8"
8 1/8"
8 1/8"
*Remodeler & retrofit frames also available. See specification sheet for details.
How to specify
Trim kit CCT
Beam
(6" & 7" only)
Finish/
flange
Frame-in
kit
C6L1520DL 27K WCLW C6L15N1
Color
temperature options Reflector finish options
Color
temperature Code
Reflector
finish
White
flange
Aperture -
matching flange Flangeless
2700K
3000K
3500K
4000K
27K
30K
35K
40K
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A"
CLFT
CCLFT
CCDFT
CCZFT
WHFT
Calculite LED 4", 6" & 7" aperture
Downlight wide beam (1.2 S.C.)
500
1000
2000
1500
30°
60°
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
1000
1001
1010
1056
1049
1003
911
742
475
108
10
5
3
2
1
1
0
0
0
96
297
459
451
116
5
2
1
0
6", 1500 Lumen
Reflector trim: C6L1520DL30KWCLW
Output lumens: 1426
Correlated color temp: 3000K
C6L1520DL30KWCLW
500
1000
2000
1500
30°
60°
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
1369
1371
1382
1445
1436
1374
1249
1017
653
149
14
7
4
2
1
1
0
0
0
131
407
629
619
160
6
2
1
0
6", 2000 Lumen
Reflector trim: C6L1520DL30KWCLW
Output lumens: 1954
Correlated color temp: 3000K
C6L1520DL30KWCLW
60°
200
400
600
30°
800
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
577
595
647
693
692
665
611
529
405
188
15
4
2
1
1
0
0
0
0
153
417
501
205
35
1
0
0
0
4", 1000 Lumen
Reflector trim: C4L10DL30 KCLW
Output lumens: 1034
Correlated color temp: 3000K
C4L10DL30KCLW
Length (bars) is 20" -30"
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
1.8 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
250
500
750
1000 30°
60°
Wall
Wash
Side
Downlight
Side
150
300
450
600 30°
60°
Wall
Wash
Side
Downlight
Side
250
500
750
1000 30°
60°
Wall
Wash
Side
Downlight
Side
Calculite LED 4", 6" & 7" aperture
Lensed wall washers
Trim/frame compatibility
Aperture Trim kit Light engine description
Frame-In
Kit*
Ceiling
cutout Type
Input
voltage Technology Wattage** Width Height
4"
4"
6"
7"
C4L05LW
C4L10LW
C6L1520LW
C7L1520 LW
500 Lumen lensed wall washer
1000 Lumen lensed wall washer
1500/2000 Lumen lensed wall washer
1500/2000 Lumen lensed wall washer
C4L05N1
C4L05N2
C4L10N1
C4L10N2
C6L15N1 (1500 Lumen)
C6L15N2 (1500 Lumen)
C6L20N1 (2000 Lumen)
C6L20N2 (2000 Lumen)
C7L15N1 (1500 Lumen)
C7L15N2 (1500 Lumen)
C7L20N1 (2000 Lumen)
C7L20N2 (2000 Lumen)
5 1/8"
5 1/8"
5 1/8"
5 1/8"
6 9/16"
6 9/16"
6 9/16"
6 9/16"
8"
8"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
120V
277V
120V
277V
120V
277V
120V
277V
120V
277V
120V
277V
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
See
specification
sheet
9 3/16"
9 3/16"
9 3/16"
9 3/16"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
5 3/8"
5 3/8"
5 3/8"
5 3/8"
6 5/8"
6 5/8"
6 5/8"
6 5/8"
7 3/8"
7 3/8"
7 3/8"
7 3/8"
*Remodeler & retrofit frames also available. See specification sheet for details
How to specify
Trim kit CCT Finish/flange Frame-in kit
C6L1520DL 27K CLW C6L15N1
Color
temperature options Reflector finish options
Color
temperature Code
Reflector
finish
White
flange
Aperture -
matching flange Flangeless
2700K
3000K
3500K
4000K
27K
30K
35K
40K
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A
N/A
N/A
N/A
N/A
N/A
4", 1000 Lumen 6", 1500 Lumen 6", 2000 Lumen
Trim: C4L10LW30KCLW
Reflector finish:
Specular clear
Correlated
color temp: 3000K
Trim: C6L1520LW30KCLW
Reflector finish:
Specular clear
Correlated
color temp: 3000K
Trim: C6L1520LW30KCLW
Reflector finish:
Specular clear
Correlated
color temp: 3000K
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
3'
1' 545
2' 14 12 14
3' 19 18 19
4' 18 17 18
5' 15 15 15
6' 13 12 13
7' 10 10 10
8' 999
9' 878
10' 777
12' 555
14 ' 444
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
3'
1' 868
2' 21 18 21
3' 26 25 26
4' 24 24 24
5' 21 21 21
6' 17 17 17
7' 14 14 14
8' 12 12 12
9' 10 10 10
10' 989
12' 777
14 ' 666
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
3'
1' 989
2' 24 22 24
3' 32 30 32
4' 32 31 32
5' 27 27 27
6' 23 23 23
7' 19 19 19
8' 16 16 16
9' 14 13 14
10' 12 12 12
12' 999
14 ' 888
Length (bars) is 20" -30"
C6L1520LW30KCLW
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
1.9Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
Wall
Wash
Side
Downlight
Side
60°
30°
200
400
600
800
Wall
Wash
Side
Downlight
Side
60°
30°
250
500
750
1000
Wall
Wash
Side
Downlight
Side
60°
30°
250
500
750
1000
Trim/frame compatibility
Aperture Trim kit Light engine description Frame-in kit*
Ceiling
cutout Type
Input
voltage Technology Wattage** Width Height
4"
4"
6"
7"
C4L05WW
C4L10WW
C6L1520W W
C7L1520W W
500 Lumen open wall washer
1000 Lumen open wall washer
1500/2000 Lumen open wall washer
1500/2000 Lumen open wall washer
C4L05N1
C4L05N2
C4L10N1
C4L10N2
C6L15N1 (1500 Lumen)
C6L15N2 (1500 Lumen)
C6L20N1 (2000 Lumen)
C6L20N2 (2000 Lumen)
C7L15N1 (1500 Lumen)
C7L15N2 (1500 Lumen)
C7L20N1 (2000 Lumen)
C7L20N2 (2000 Lumen)
5 1/8"
5 1/8"
5 1/8"
5 1/8"
6 9/16"
6 9/16"
6 9/16"
6 9/16"
8"
8"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
120V
277V
120V
277V
120V
277V
120V
277V
120V
277V
120V
277V
Remote Phosphor
Remote Phosphor
Remote Phosphor
Remote Phosphor
Remote Phosphor
Remote Phosphor
Remote Phosphor
Remote Phosphor
Remote Phosphor
Remote Phosphor
Remote Phosphor
Remote Phosphor
See
specification
sheet
9 3/16"
9 3/16"
9 3/16"
9 3/16"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
6 1/8"
6 1/8"
6 1/8"
6 1/8"
7 1/4"
7 1/4"
7 1/4"
7 1/4"
7 5/8"
7 5/8"
7 5/8"
7 5/8"
*Remodeler & retrofit frames also available. See specification sheet for details
How to specify
Trim kit CCT Finish/flange Frame-in kit
C6L1520WW 27K CLW C6L15N1
Color
temperature options Reflector finish options
Color
temperature Code
Reflector
finish
White
flange
Aperture -
matching flange Flangeless
2700K
3000K
3500K
4000K
27K
30K
35K
40K
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A"
CLFT
CCLFT
CCDFT
CCZFT
WHFT
Calculite LED 4", 6" & 7" aperture
Open wall washers
4", 1000 Lumen 6", 1500 Lumen 6", 2000 Lumen
Reflector trim:
C4L10WW30KCLW
Reflector finish:
Specular clear
Correlated
color temp: 3000K
Reflector trim:
C6L1520WW30KCLW
Reflector finish:
Specular clear
Correlated
color temp: 3000K
Reflector trim:
C6L1520WW30KCLW
Reflector finish:
Specular clear
Correlated color
temp: 3000K
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
3'
1' 777
712 12 12
3' 17 17 17
4' 16 16 16
5' 14 14 14
6' 12 12 12
7' 12 12 12
8' 10 10 10
9' 999
10' 888
12' 777
14 ' 666
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
3'
1' 10 910
725 25 25
3' 25 24 25
4' 21 22 21
5' 19 19 19
6' 17 17 17
7' 15 15 15
8' 13 13 13
9' 11 11 11
10' 10 10 10
12' 999
14 ' 888
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
3'
1' 14 13 14
735 32 35
3' 35 34 35
4' 29 30 29
5' 27 26 27
6' 23 23 23
7' 20 20 20
8' 18 18 18
9' 16 16 16
10' 14 14 14
12' 12 12 12
14 ' 10 10 10
C4L10WW30KCLW
C4L10WW30KCLW
C4L10WW30KCLW
Length (bars) is 20" -30"
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
1.10 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
Trim/frame compatibility
Aperture Trim kit Light engine description Frame-in kit*
Ceiling
cutout Type
Input
voltage Technology Wattage** Width Height
4"
4"
6"
7"
C4L05DW
C4L10DW
C4L10DW
C6L1520DW
C7L1520 DW
500 Lumen double wall washer
1000 Lumen double wall washer
1000 Lumen double wall washer
1500/2000 Lumen double wall washer
1500/2000 Lumen double wall washer
C4L05N1DW
C4L05N2DW
C4L10N1DW
C4L10N2DW
C6L15N1 (1500 Lumen)
C6L15N2 (1500 Lumen)
C6L20N1 (2000 Lumen)
C6L20N2 (2000 Lumen)
C7L15N1 (1500 Lumen)
C7L15N2 (1500 Lumen)
C7L20N1 (2000 Lumen)
C7L20N2 (2000 Lumen)
5 1/8"
5 1/8"
5 1/8"
5 1/8"
6 9/16"
6 9/16"
6 9/16"
6 9/16"
8"
8"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
120V
277V
120V
277V
120V
277V
120V
277V
120V
277V
120V
277V
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
See
specification
sheet
9 3/16"
9 3/16"
9 3/16"
9 3/16"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
5 1/3"
5 1/3"
5 1/3"
5 1/3"
7 1/4"
7 1/4"
7 1/4"
7 1/4"
8 1/8"
8 1/8"
8 1/8"
8 1/8"
*Remodeler & retrofit frames also available. See specification sheet for details
Color
temperature options Reflector finish options
Color
temperature Code
Reflector
finish
White
flange
Aperture -
matching flange Flangeless
2700K
3000K
3500K
4000K
27K
30K
35K
40K
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A
CLFT
CCLFT
CCDFT
CCZFT
WHFT
4", 1000 Lumen 6", 1500 Lumen 6", 2000 Lumen
Multiple unitsFootcandles on wall
Distance from ceiling in feet
6' from hallway - 3' on center
3'
1' 12 12 12
2' 18 17 18
3' 24 24 24
4' 25 26 25
5' 24 23 24
6' 21 21 21
7' 18 18 18
8' 16 16 16
9' 14 14 14
10' 13 13 13
12' 11 11 11
14 ' 9 9 9
Multiple unitsFootcandles on wall
Distance from ceiling in feet
6' from hallway - 3' on center
3'
1' 21 21 21
2' 40 38 40
3' 40 39 40
4' 36 37 36
5' 33 32 33
6' 29 29 29
7' 26 25 26
8' 23 23 23
9' 20 20 20
10' 18 18 18
12' 15 15 15
14 ' 13 13 13
Multiple unitsFootcandles on wall
Distance from ceiling in feet
6' from hallway - 3' on center
3'
1' 29 29 29
2' 55 53 55
3' 55 54 55
4' 49 51 49
5' 45 45 45
6' 39 40 39
7' 35 35 35
8' 31 31 31
9' 28 28 28
10' 25 25 25
12' 20 21 20
14 ' 17 17 17
Length (bars) is 20" -30"
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
Trim:
C4L10DW30KCLW
Reflector finish:
Specular clear
Correlated
color temp: 3000K
150
300
450
600 30°
60°
Wall
Wash
Side
Downlight
Side
C4L10DW30KCLW
Trim:
C6L1520DW30KCLW
Reflector finish:
Specular clear
Correlated
color temp: 3000K
600
400
200
30°
60°
Wall
Wash
Side
Downlight
Side
C4L10DW30KCLW
250
500
750
1000
30°
60°
Wall
Wash
Side
Downlight
Side
Trim:
C6L1520DW30KCLW
Reflector finish:
Specular clear
Correlated
color temp: 3000K
C4L10DW30KCLW
How to specify
Trim kit CCT Finish/flange Frame-in kit
C6L1520DW 27K CLW C6L15N1
Calculite LED 4", 6" & 7" aperture
Double wall washers
1.11Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
200
400
600
800
30°
60°
Wall
Wash
Side
Downlight
Side
Wall
Wash
Side
Downlight
Side
250
500
750
1000
30°
60°
Trim/frame compatibility
Aperture Trim kit Light engine description Frame-in kit*
Ceiling
cutout Type
Input
voltage Technology Wattage** Width Height
6"
7"
C6L1520CW
C7L1520CW
1500/2000 Lumen corner wall washer
1500/2000 Lumen corner wall washer
C6L15N1 (1500 Lumen)
C6L15N2 (1500 Lumen)
C6L20N1 (2000 Lumen)
C6L20N2 (2000 Lumen)
C7L15N1 (1500 Lumen)
C7L15N2 (1500 Lumen)
C7L20N1 (2000 Lumen)
C7L20N2 (2000 Lumen)
6 9/16"
6 9/16"
6 9/16"
6 9/16"
8"
8"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
120V
277V
120V
277V
120V
277V
120V
277V
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
See
specification
sheet
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
10 1/8"
7 1/4"
7 1/4"
7 1/4"
7 1/4"
8 1/8"
8 1/8"
8 1/8"
8 1/8"
*Remodeler & retrofit frames also available. See specification sheet for details
Color
temperature options Reflector finish options
Color
temperature Code
Reflector
finish
White
flange
Aperture -
matching flange Flangeless
2700K
3000K
3500K
4000K
27K
30K
35K
40K
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A"
CLFT
CCLFT
CCDFT
CCZFT
WHFT
Calculite LED 6" & 7" aperture
Corner wall washers
6", 1500 Lumen 6", 2000 Lumen
Trim:
C6L1520CW30KCLW
Reflector finish:
Specular clear
Correlated color
temp: 3000K
Trim:
C6L1520CW30KCLW
Reflector finish:
Specular clear
Correlated color
temp: 3000K
Length (bars) is 20" -30"
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
C4L10WW30KCLW
C4L10WW30KCLW
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
1.5' 3' 4.5
1' 911 9
2' 16 20 18
3' 18 21 21
4' 17 22 25
5' 16 20 23
6' 15 19 22
7' 15 18 20
8' 15 17 18
9' 14 16 17
10' 13 15 16
12' 12 13 14
14 ' 11 11 12
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
1.5' 3' 4.5'
1' 13 16 15
2' 24 30 30
3' 28 34 35
4' 26 32 36
5' 23 28 32
6' 22 26 29
7' 21 25 27
8' 20 23 25
9' 19 22 23
10' 18 20 22
12' 17 18 19
14 ' 15 16 17
How to specify
Trim kit CCT Finish/flange Frame-in kit
C6L1520CW 27K CLW C6L15N1
1.12 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
Calculite LED 4" & 6" squares
Downlight wide beam (1.2 S.C.)
Trim/frame compatibility
Aperture Trim kit Light engine description Frame-in kit* Type
Input
voltage Technology Wattage** Width Height
4 " x 4"
4" x 4"
6" x 6"
C4X4L05DL
C4X4L10DL
C6X6L1520 DL
500 Lumen downlight
1000 Lumen downlight
1500/2000 Lumen downlight
C4X4L05N1
C4X4L05N2
C4X4L10N1
C4X4L10N2
C6X6L15N1 (1500 Lumen)
C6X6L15N2 (1500 Lumen)
C6X6L20N1 (2000 Lumen)
C6X6L20N2 (2000 Lumen)
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
120V
277V
120V
277V
120V
277V
120V
277V
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
See specification
sheet
10 3/4"
10 3/4"
10 3/4"
10 3/4"
12 1/2"
12 1/2"
12 1/2"
12 1/2"
6 1/4"
6 1/4"
6 1/4"
6 1/4"
7 1/4"
7 1/4"
7 1/4"
7 1/4"
Color
temperature options Reflector finish options
Color
temperature Code
Reflector
finish
White
flange
Aperture -
matching flange Flangeless*
2700K
3000K
3500K
4000K
27K
30K
35K
40K
Specular clear
Comfort clear
Comfort clear diffuse
White
CLW
CCLW
CCDW
WHW
CLP
CCLP
CCDP
N/A
CLFT
CCLFT
CCDFT
WHFT
* Available
in 6"x6" only
30°
60°
200
400
600
800
400
800
1600
1200
30°
60°
400
800
1600
1200
30°
60°
Angle 0
Degree
45
Degree
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
727
722
727
735
724
696
624
499
285
80
12
2
1
0
0
0
0
0
0
727
728
733
746
756
743
693
571
385
189
55
8
0
0
0
0
0
0
0
70
210
329
323
111
6
0
0
0
Angle 0
Degree
45
Degree
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
1143
1138
1139
1129
1088
999
839
596
392
204
49
5
2
1
0
0
0
0
0
1143
1141
1144
1132
1093
1019
882
669
440
220
61
8
4
2
1
0
0
0
0
111
318
463
415
184
20
1
0
0
Angle 0
Degree
45
Degree
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
1571
1565
1566
1552
1495
1375
1156
822
542
282
69
7
3
1
1
0
0
0
0
1571
1568
1572
1555
1522
1428
1272
1017
687
382
165
41
4
2
1
0
0
0
0
152
437
637
571
254
27
2
0
0
4"x4", 1000 Lumen 6"x6", 1500 Lumen 6"x6", 2000 Lumen
Reflector trim: C4X4L10DL30KCLW
Output lumens: 1048
Correlated color temp: 3000K
Reflector trim: C6X6L1520DL30KCLW
Output lumens: 1512
Correlated color temp: 3000K
Reflector trim: C6X6L1520DL30KCLW
Output lumens: 2081
Correlated color temp: 3000K
C4X4L10DL30KCLW
C4X4L10DL30KCLW
C4X4L10DL30KCLW
How to specify
Trim kit CCT Finish/flange Frame-in kit
C6X6L1520DL 27K CLW C6L15N1
Length (bars) is 20" -30"
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
1.13Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
Trim/frame compatibility
Aperture Trim kit Light engine description Frame-in kit* Type
Input
voltage Technology Wattage** Width Height
4" x 4"
4" x 4"
6" x 6"
C4X4L05WW
C4X4L10WW
C6X6L1520W W
500 Lumen lensed wall washer
1000 Lumen lensed wall washer
1500/2000 Lumen lensed wall washer
C4X4L05N1
C4X4L05N2
C4X4L10N1
C4X4L10N2
C6X6L15N1 (1500 Lumen)
C6X6L15N2 (1500 Lumen)
C6X6L20N1 (2000 Lumen)
C6X6L20N2 (2000 Lumen)
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
120V
277V
120V
277V
120V
277V
120V
277V
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
See
specification
sheet
10 3/4"
10 3/4"
10 3/4"
10 3/4"
12 1/2"
12 1/2"
12 1/2"
12 1/2"
5 1/2"
5 1/2"
5 1/2"
5 1/2"
6 1/4"
6 1/4"
6 1/4"
6 1/4"
How to specify
Trim kit CCT
Finish/
flange Frame-in kit
C6X6L1520WW 27K CLW C6X6L15N1
Color
temperature options Reflector finish options
Color
temperature Code
Reflector
finish
White
flange
Aperture -
matching flange Flangeless
2700K
3000K
3500K
4000K
27K
30K
35K
40K
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A
CLFT
CCLFT
CCDFT
WHFT
*Available in
6"x6" only
150
300
450
600 30°
60°
Wall
Wash
Side
Downlight
Side
750
1000
500
250
30°
60°
Wall
Wash
Side
Downlight
Side
750
1000
500
250
30°
60°
Wall
Wash
Side
Downlight
Side
4"x4", 1000 Lumen
Reflector trim:
C4X4L10WW30KCLW
Correlated
color temp: 3000K
6"x6", 1500 Lumen 6"x6", 2000 Lumen
Reflector trim:
C6X6L1520WW30KCLW
Reflector finish:
Specular clear
Correlated color
temp: 3000K
Reflector trim:
C6X6L1520WW30KCLW
Reflector finish:
Specular clear
Correlated color
temp: 3000K
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
3'
1' 12 11 12
2' 21 19 21
3' 24 24 24
4' 21 21 21
5' 18 18 18
6' 14 14 14
7' 12 12 12
8' 10 10 10
9' 888
10' 777
12' 555
14 ' 555
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
3'
1' 17 14 17
2' 29 26 29
3' 33 32 33
4' 30 30 30
5' 25 24 25
6' 20 20 20
7' 16 16 16
8' 14 13 14
9' 11 11 11
10' 10 10 10
12' 888
14' 777
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 3' on center
3'
1' 123 19 23
2' 240 35 40
3' 346 45 46
4' 441 41 41
5' 534 34 34
6' 6 27 27 27
7' 722 22 22
8' 819 19 19
9' 916 16 16
10 10 14 14 14
12 12 11 11 11
14 14 9 9 9
C4X4L10WW30KCLW
C6X6L1520WW30KCLW
C6X6L1520WW30KCLW
Length (bars) is 20" -30"
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
Calculite LED 4" & 6" squares
Lensed wall washers
1.14 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
Trim/frame compatibility
Aperture Cylinder
Beam
(7" only) Description Input voltage Technology Wattage** Width Height
4"
4"
7"
7"
7"
7"
C4L05CW
C4L10CW
C7L15CW_ _ _
C7L20CW_ _ _
C7L15CW_ _ _
C7L20CW_ _ _
M
M
W
W
500 Lumen Surface Cylinder
1000 Lumen Surface Cylinder
1500 Lumen Surface Cylinder-Medium Beam
2000 Lumen Surface Cylinder-Medium Beam
1500 Lumen Surface Cylinder-Wide Beam
2000 Lumen Surface Cylinder-Wide Beam
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
Remote phosphor
See specification
sheet
5"
5"
8 1/2"
8 1/2"
8 1/2"
8 1/2"
6 7/8"
6 7/8"
9 7/8"
9 7/8"
9 7/8"
9 7/8"
How to specify
Trim kit CCT
Beam
(7" only)
Finish/Input
voltage
C7L15CW
(also available
in Black)
27K MCCLU
Color
temperature options Reflector finish options
Color
temperature Code
Reflector
finish White flange Voltage
2700K
3000K
3500K
4000K
27K
30K
35K
40K
Comfort clear CCL U
60°
200
400
600
30°
800
60°
500
1000
1500
30°
2000
60°
30°
500
1000
1500
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
577
595
647
693
692
665
611
529
405
188
15
4
2
1
1
0
0
0
0
153
417
501
205
35
1
0
0
0
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
2238
2298
2257
2201
2095
1792
1068
487
205
49
4
2
1
0
0
0
0
0
0
218
619
776
330
52
2
1
0
0
Angle Mean
CP
Lumens
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
1117
1146
1239
1358
1470
1476
1357
1084
607
136
11
5
3
2
1
0
0
0
0
113
388
670
647
153
5
2
0
0
4", 1000 Lumen
Reflector trim: C4L10CW30KCCLW
Output lumens: 1034
Correlated color temp: 3000K
7", 2000 Lumen medium beam
Reflector trim: C7L20CW30KMCCLW
Output lumens: 1998
Correlated color temp: 3000K
7", 2000 Lumen wide beam
Reflector trim: C7L20CW30KWCCLW
Output lumens: 1978
Correlated color temp: 3000K
Length (bars) is 20" -30"
** As Calculite LED fixture efficiency is continuously improving, please see product specification sheet for updated, accurate performance data.
Calculite LED 4" & 7"
Cylinders
1.15Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
warranty
5 year
Finishes
CL specular
clear
CCL comfort
clear
CCD comfort
clear diffuse
CCZ champagne
bronze
WH White
Flanges
W White
P Polished
FT Flangeless*
*available in
round only
Depreciating more
consistently over time as
compared to CFL, Calculite’s
LED downlight will provide at
least 50,000 hours rated life
at 70% lumen maintenance.
Philips Lightolier is emphasizing
confidence in our product
and a commitment to our
specifiers with an industry-
best 5year warranty covering
all components. Conventional
equipment typically offers
separate warranties for the
lamp and the ballast.
LED
0
70%
80%
90%
100%
10,000 hours
CFL
Electronic low voltage (5%),
O-10V (10%) and Lutron dimming
options available depending on
luminaire selected. See LED-DIM
specification sheet for details.
Both Integral (EM suffix) and
low-wattage inverter (see LED-
DIM specification sheet) options
available for emergency backup.
Calculite round aperture
downlights are compatible with
Vetro architectural decorative
accessories. A flangeless “FT
trim is required.
Dimming/emergency capability Decorative accessories
Lumen maintenance
Industry best warranty
Designed as a direct replacement
for CFL, Calculite Solid-State
offers medium and wide beam
spread options where possible.
Medium is an alternative to
vertically-oriented CFL (0.9
s.c.), wide is an alternative to
horizontal orientations (1.2 s.c.).
Designed specifically
around the LEDsource
Calculite Solid-State
delivers true 50°
physical and reflected
cutoff for reduced
aperture brightness and
an unobtrusive ceiling
presence.
50°50°
Comfort optics Beam distributions
0.9 s.c. 1.2 s.c.
M W
After the frame-in kit is installed, the
flangeless ring is inserted into the ceiling
opening and the flange is plastered
over, feathered, sanded and finished.
A flangeless “FT” trim is required.
Accessory ring CA_FMRLED
recommended for gypsum applications.
Flangeless option Flangeless option
Up to 60% of light that contacts phosphor, whether
it’s remote-mounted or applied directly to the chip, is
back-reflected.
With Philips’ remote-mounted phosphor system this
back-reflected light can be utilized. Philips Lightolier
developed an optimized, highly reflective mixing
chamber which redirects this light, resulting in a 20%
increase in systemefficiency.
Variation in color across products has historically been a
challenge for lighting products utilizing LED technology.
This is in large part due to the process variability in
applying phosphor directly to the LED diode.
Remote phosphor technology provides superior
color consistency across products, as the phosphor
is manufactured in large sheets, cut to shape, and
laminated to diffusion film. This process results in color
consistency ± 100k across products.
Calculite’s remote phosphor technology ensures that the
LED performance that’s been specified willbe available
at construction rollout.
The phosphor itself is developed and manufactured
exclusivey from the LED chip and can therefore be
modified as required to deliver the fixture performance
expected when the lighting specification is written. This
allows the product to change with technology gains,
yet provide the same below-ceiling performance as
specified.
Maximum efficiency Color consistency As-specified performance
Key benefits
Product features
Calculite LED
Remote phosphor technology: features & benefits
Downlighting – Professional
1.16 Philips Lightolier For complete specification information visit www.lightolier.com
CFL lighting
Calculite compact fluorescent downlights
provide a broad assortment of light
distributions in coordinated apertures,
nominally 4" x 4", 4" x 9", 9" x 9", 4", 6", 7"
and 8". Most use triple tube lamps, from
18W to 42W, for soft-edged, Energy Smart
illumination.
Professional – Downlighting
1.17Comprehensive lighting catalog 7th Edition
Contents
Rectilinear downlights > 1.20
Rectilinear wall washers > 1.26
Round downlights > 1.28
Round wall washers > 1.37
Cylinders > 1.42
1.18 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
9 x 9
4 x 4
4 x 9
4 x 9 rectangles provide
perimeter illumination or wall
washing. 9 x 9 squares produce
the general ambient illumination.
4 x 4 squares are used in the
corners to visually complete the
pattern.
Pathways and circulation areas
can also be emphasized by the
orientation of 4 x 9 rectangular
apertures. 4 x 4 squares are
used at intersections. 9 x 9
squares accommodate areas
requiring higher light levels.
Matrix
Matrix provides complete design flexibility with a palette of symmetrical elements in three sizes, each with a
specific purpose and appearance.
The apertures are developed from a base module that is a 4 1/2" square with 55° visual and reflected cutoff. The 4 1/2" by 9" rectangle is
derived from 2 equal cells and the 9" by 9" square is a combination of 4 cells. Open downlights deliver high efficiency, excellent glare control
and wide spacing. Lensed downlights offer reduced lamp image and are UL listed for installation in wet locations. Lensed wall washers
provide smooth, even vertical illumination.
The combination of different aperture sizes and shapes can be used to accentuate interior architecture or create interesting patterns.
The two square sizes complement the rectangular aperture and provide solutions for inside or outside corners and the ending of rows.
The matrix system offers exciting new options for creating expressive, yet functional lighting plans. Matrix provides the lighting tools to
accentuate feature areas, differentiate circulation areas or light entire spaces.
1.19Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
Smaller is better
Compact lamps and efficient fixtures provide options for achieving high light levels while reducing the size of the ceiling opening. You no
longer need to go to a 2' x 2' fluorescent product to provide adequate illumination and wide spacing. Matrix 9" x 9" square luminaires with
two 42W triple tube compact fluorescent lamps are comparable in output to traditional recessed 2' x 2' troffers. Triple tube lamps have the
added benefit of amalgam technology, which maintains lumen output over a wider range of operating temperatures.
24" x 24"
Two 40W
Twin tube
75 Watts
3680 Lumens
9" x 9"
Two 42W
Triple tube
93 Watts
3980 Lumens
VS.
Matrix 4" x 9" open downlights, 4' on center 6" round downlights, 4' on center
Hallways and corridors
Matrix rectangular apertures are ideal for
lighting long narrow spaces such as hallways and
corridors. When installed parallel to the wall,
these luminaires provide wide spacing and a clean,
even beam pattern devoid of distracting scallops
produced by round aperture downlights.
1.20 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
4 ½" x 4 ½" aperture
Open downlight
4 ½" x 4 ½" 26W Triple tube
Reflector trim: 4X4 CLW
Report: 1763FR
Lamp: 26W Triple
Initial lumens: 1,800
Efficiency: 54.5%
Spacing: 1.1 X 1.4
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
42
30
17
11
7
1.12
0.78
0.44
0.28
0.19
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
175
350
525
700
4 ½" x 4 ½" 32W Triple tube
Reflector trim: 4X4 CLW
Report: 1710FR
Lamp: 32W Triple
Initial lumens: 2,400
Efficiency: 54.7%
Spacing: 1.1 X 1.5
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
57
39
22
14
10
1.44
1.00
0.56
0.36
0.25
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
125
250
375
900
Ceiling cutout:: 5 ⅛" x 5 ⅛"
Ceiling thickness: 1 ¼" Max.
How to specify
Trim kit Frame-in kit
4X4 CLW 4X4132HU
Trim/frame compatibility
Frame-in kits Type Ballast Input voltage Lamp Wattage-lamp Length Width Height
4X4132HU
4X4132HUEM4E
Non-IC
Non-IC
Electronic
Emergency
120V/277V
120V/277V
TRT
TRT
26/32W
26/32W
10"
10"
9 1/2"
11"
5 3/4"
5 3/4"
Standard dimming options* Reflector finish options
4X4132H (add suffix in box)
Suffix Ballast Input voltage
Reflector
finish
White
flange
Aperture -
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
White
CLW
CCLW
CCDW
WHW
CLP
CCLP
CCDP
N/A
N/A
N/A
N/A
N/A
* Some dimming options not available on all products.
See product specification sheet for details.
1.21Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
4 ½" x 4 ½" aperture
Lensed downlight
Trim/frame compatibility
Frame-in kits Type Ballast Input voltage Lamp Wattage-lamp Length Width Height
4X4132HU Non-IC Electronic 120V/277V TRT 26/32W 10" 9 1/2" 5 3/4"
Ceiling cutout:: 5 ⅛" x 5 ⅛"
Ceiling thickness: 1 ¼" Max.
Standard dimming options* Reflector finish options
4X4132H (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish
White
flange
Aperture -
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
White
CLW
CCLW
CCDW
WHW
CLP
CCLP
CCDP
N/A
N/A
N/A
N/A
N/A
* Some dimming options not available on all products.
See product specification sheet for details.
How to specify
Trim kit Frame-in kit
4X4PL (prismatic) CLW 4X4132HU
4X4LFL (light frost) CLW 4X4132HU
4 ½" x 4 ½" 26W Triple tube
Reflector trim: 4X4PL CLW
Report: 1764FR
Lamp: 26W Triple
Initial lumens: 1,800
Efficiency: 47.4%
Spacing: 1.0 X 1.2
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
37
26
15
9
7
1.12
0.78
0.44
0.28
0.19
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
125
250
375
900
4 ½" x 4 ½" 32W Triple tube
Reflector trim: 4X4PL CLW
Report: 1909FR
Lamp: 32W Triple
Initial lumens: 2,400
Efficiency: 44.0%
Spacing: 1.0 X 1.2
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
46
32
18
12
8
1.44
1.00
0.56
0.36
0.25
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
200
400
600
800
1.22 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
4 ½" x 9" aperture
Open downlight
Ceiling cutout:: 5 ⅛" x 9 ⅝"
Ceiling thickness: 1 ¼" Max.
How to specify
Trim kit Frame-in kit
4X9 CLW 4X9142HU
Standard dimming options* Reflector finish options
4X9142H (add suffix in box)
Suffix Ballast Input voltage
Reflector
finish White flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
White
CLW
CCLW
CCDW
WHW
CLP
CCLP
CCDP
N/A
N/A
N/A
N/A
N/A
* Some dimming options not available on all products.
See product specification sheet for details.
Trim/frame compatibility
Frame-in kits Type Ballast Input voltage Lamp Wattage-lamp Length Width Height
4X9142HU
4X9142HUEM
Non-IC
Non-IC
Electronic
Emergency
120V/277V
120V/277V
QT/TRT
QT/TRT
QT: 26W TRT: 32/42W
QT: 26W TRT: 32/42W
12 1/2"
12 1/2"
9 1/2"
11"
5 3/4"
5 3/4"
4 ½" x 9" 26W quad
Reflector trim: 4X9 CLW
Report: 1762FR
Lamp: 26W Quad
Initial lumens: 1,800
Efficiency: 55.5%
Spacing: 1.5 X 1.3
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
43
30
17
11
8
1.12
0.78
0.44
0.28
0.19
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
125
250
375
500
4 ½" x 9" 32W Triple tube
Reflector trim: 4X9 CLW
Report: 1761FR
Lamp: 32W Triple
Initial lumens: 2,400
Efficiency: 69.3%
Spacing: 1.7 X 1.5
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
72
50
28
18
13
1.44
1.00
0.56
0.36
0.25
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
200
400
600
800
4 ½" x 9" 42W Triple tube
Reflector trim: 4X9 CLW
Report: 1760FR
Lamp: 42W Triple
Initial lumens: 3,200
Efficiency: 66.1%
Spacing: 1.6 X 1.5
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
92
64
36
23
16
1.80
1.25
0.70
0.45
0.31
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
250
500
750
1000
1.23Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
4 ½" x 9" 26W quad
Reflector trim: 4X9PL CLW
Report: 1624FR
Lamp: 26W Quad
Initial lumens: 1,800
Efficiency: 43.4%
Spacing: 1.2 X 1.1
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
34
24
13
8
6
1.12
0.78
0.44
0.28
0.19
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
125
250
375
500
4 ½" x 9" 32W Triple tube
Reflector trim: 4X9PL CLW
Report: 1617FR
Lamp: 32W Triple
Initial lumens: 2,400
Efficiency: 62.2%
Spacing: 1.3 X 1.1
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
65
49
26
14
11
1.44
1.08
0.58
0.31
0.23
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
200
400
600
800
4 ½" x 9" 42W Triple tube
Reflector trim: 4X9PL CLW
Report: 1610FR
Lamp: 42W Triple
Initial lumens: 3,200
Efficiency: 61.1%
Spacing: 1.2 X 1.1
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
85
64
34
19
14
1.96
1.47
0.78
0.43
0.31
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
250
500
750
1000
4 ½" x 9" aperture
Lensed downlight
Trim/frame compatibility
Frame-in kits Type Ballast Input voltage Lamp Wattage-lamp Length Width Height
4X9142HU
4X9142HUEM
Non-IC
Non-IC
Electronic
Emergency
120V/277V
120V/277V
QT/TRT
QT/TRT
QT: 26W TRT: 32/42W
QT: 26W TRT: 32/42W
12 1/2"
12 1/2"
9 1/2"
11"
5 3/4"
5 3/4"
Ceiling cutout:: 5 ⅛" x 9 ⅝"
Ceiling thickness: 1 ¼" Max.
Standard dimming options* Reflector finish options
4X9142H (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish
White
Flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
White
CLW
CCLW
CCDW
WHW
CLP
CCLP
CCDP
N/A
N/A
N/A
N/A
N/A
* Some dimming options not available on all products.
See product specification sheet for details.
How to specify
Trim kit Frame-in kit
4X9PL (prismatic) CLW 4X9142HU
4X9LFL (light frost) CLW
1.24 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
9" x 9" aperture
Open downlight
Ceiling cutout:: 9 ⅝" x 9 ⅝"
Ceiling thickness: 1 ¼" Max.
How to specify
Trim kit Frame-in kit
9X9 CLW 9X9242HU
Standard dimming options* Reflector finish options
9X9242H (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish
White
flange
Aperture
Matching Flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
White
CLW
CCLW
CCDW
WHW
CLP
CCLP
CCDP
N/A
N/A
N/A
N/A
N/A
* Some dimming options not available on all products.
See product specification sheet for details.
Trim/frame compatibility
Frame-in kits Type Ballast Input voltage Lamp Wattage-lamp Length Width Height
9X9242HU
9X9242HUEM
Non-IC
Non-IC
Electronic
Emergency
120V/277V
120V/277V
QT/TRT
QT/TRT
(2) 32/42W
(2) 32/42W
12 1/2"
12 1/2"
14"
15 3/4"
5 3/4"
5 3/4"
9" x 9" 42W Triple tube
Reflector trim: 9X9 CLW
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
166
116
65
42
29
3.64
2.53
1.42
0.91
0.63
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
Report no.: 1777FR
Lamp: 42W Triple
Initial lumens: 6,400
Efficiency: 60.1%
Spacing: 1.6 X 1.4 1000
2000
30°
60°
500
1500
9" x 9" 32W Triple tube
Reflector trim: 9X9 CLW
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
131
91
51
33
23
2.76
1.92
1.08
0.69
0.48
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
Report no.: 1776FR
Lamp: 32W Triple
Initial lumens: 4,800
Efficiency: 63.0%
Spacing: 1.6 X 1.4 750
1500 30°
60°
375
1125
9" x 9" 26W quad
Reflector trim: 9X9 CLW
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
76
53
30
19
13
2.24
1.56
0.88
0.56
0.39
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
Report no.: 1775FR
Lamp: 26W Quad
Initial lumens: 3,600
Efficiency: 48.6%
Spacing: 1.4 X 1.3 500
1000 30°
60°
250
750
1.25Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
9" x 9" 42W Triple tube
Reflector trim: 9X9PL CLW
Report no.: 1953FR
Lamp: 42W Triple
Initial lumens: 6,400
Efficiency: 68.7%
Spacing: 1.3 X 1.3
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
189
132
74
47
33
3.64
2.53
1.42
0.91
0.63
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
1000
2000
30°
60°
500
1500
9" x 9" 32W Triple tube
Reflector trim: 9X9PL CLW
Report no.: 1956FR
Lamp: 32W Triple
Initial lumens: 4,800
Efficiency: 72.1%
Spacing: 1.3 X 1.3
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
150
104
59
37
26
2.76
1.92
1.08
0.69
0.48
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
900
1800 30°
60°
450
1350
9" x 9" 26W quad
Reflector trim: 9X9PL CLW
Report no.: 1657FR
Lamp: 26W Quad
Initial lumens: 3,600
Efficiency: 47.1%
Spacing: 1.1 X 1.0
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
73
51
29
18
13
2.24
1.56
0.88
0.56
0.39
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
500
1000
30°
60°
250
750
9" x 9" aperture
Lensed downlight
Trim/frame compatibility
Frame-in kits Type Ballast Input voltage Lamp Wattage-lamp Length Width Height
9X9242HU
9X9242HUEM
Non-IC
Non-IC
Electronic
Emergency
120V/277V
120V/277V
QT/TRT
QT/TRT
(2) 26/32/42W
(2) 26/32/42W
12 1/2"
12 1/2"
14"
15 3/4"
5 3/4"
5 3/4"
Ceiling cutout:: 9 ⅝" x 9 ⅝"
Ceiling thickness: 1 ¼" Max.
Standard dimming options* Reflector finish options
9X9242H (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish
White
Flange
Aperture
Matching Flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear
diffuse White
CLW
CCLW
CCDW
WHW
CLP
CCLP
CCDP
N/A
N/A
N/A
N/A
N/A
* Some dimming options not available on all products.
See product specification sheet for details.
How to specify
Trim kit Frame-in kit
9X9PL (prismatic) C LW 9X9242HU
9X9LFL (light frost) CLW
1.26 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
4 ½" x 4 ½" 32W Triple tube
Reflector trim: 4X4LW CLW
Report: 1981FR
Lamp: 32W Triple
Initial lumens: 2,400
Efficiency: 42.9%
200
400
600
800
30°
Wall
Wash Side
Downlight
Side
60°
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 4' on center
4'
110 610
216 12 16
318 14 18
417 15 17
515 14 15
612 12 12
710 10 10
8 9 8 9
9 7 7 7
10 666
150
300
450
600
30°
60°
Wall
Wash Side
Downlight
Side
4 ½" x 4 ½" 26W Triple tube
Reflector trim: 4X4LW CLW
Report: 1765FR
Lamp: 26W Triple
Initial lumens: 1,800
Efficiency: 40.8%
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 4' on center
4'
1 7 4 7
211 811
313 10 13
412 11 12
511 10 11
6 9 9 9
7 7 7 7
8 6 6 6
9 5 5 5
10 545
Ceiling cutout:: 5 ⅛" x 5 ⅛"
Ceiling thickness: 1 ¼" Max.
How to specify
Trim kit Frame-in kit
4X4LW CLW 4X4132HU
Standard dimming options* Reflector finish options
4X4132H (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish White flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
White
CLW
CCLW
CCDW
WHW
CLP
CCLP
CCDP
N/A
N/A
N/A
N/A
N/A
* Some dimming options not available on all products.
See product specification sheet for details.
Trim/frame compatibility
Frame-in kits Type Ballast Input voltage Lamp Wattage-lamp Length Width Height
4X4132HU Non-IC Electronic 120V/277V TRT 26/32W 10" 9 1/2" 5 3/4"
4 ½" x 4 ½" aperture
Lensed wall washer
1.27Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
4 ½" x 9" aperture
Lensed wall washer
Ceiling cutout:: 5 ⅛" x 9 ⅝"
Ceiling thickness: 1 ¼" Max.
How to specify
Trim kit Frame-in kit
4X9LW CLW 4X9142HU
Standard dimming options* Reflector finish options
4X9142H (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish White flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
White
CLW
CCLW
CCDW
WHW
CLP
CCLP
CCDP
N/A
N/A
N/A
N/A
N/A
* Some dimming options not available on all products.
See product specification sheet for details.
Trim/frame compatibility
Frame-in kits Type Ballast Input voltage Lamp Wattage-lamp Length Width Height
4X9142HU
4X9142HUEM
Non-IC
Non-IC
Electronic
Emergency
120V/277V
120V/277V
QT/TRT
QT/TRT
QT: 26W TRT: 32/42W
QT: 26W TRT: 32/42W
12 1/2"
12 1/2"
9 1/2"
11"
5 3/4"
5 3/4"
4 ½" x 9" 42W Triple tube
Reflector trim: 4X9LW CLW
Report no.: 1876FR
Lamp: 42W Triple
Initial lumens: 3,200
Efficiency: 50.3%
250
500
750
1000
60°
30°
Wall Wash
Side
Downlight
Side
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 4' on center
4'
114 10 14
222 19 22
3 27 25 27
426 26 26
523 23 23
619 19 19
716 16 16
813 13 13
911 11 11
10 10 10 10
4 ½" x 9" 32W Triple tube
Reflector trim: 4X9LW CLW
Report no.: 1891FR
Lamp: 32W Triple
Initial lumens: 2,400
Efficiency: 57.2%
450
900
60°
225
675
30°
Wall Wash
Side
Downlight
Side
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 4' on center
4'
112 912
219 17 19
323 21 23
422 22 22
519 19 19
616 16 16
714 13 14
811 11 11
910 10 10
10 888
1.28 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
Trim/frame compatibility
Aperture Trim kit
Frame-in
kits
Ceiling
cutout Type Ballast Input voltage Lamp Wattage Length Width Height
4"
6"
6"
7"
7"
7"
7"
7 "
8"
8"
8011
8011
8021
8021...E
8022
8022…E
8022
8022…E
8023
8023
4118VU
4118VUEM
S6132BU
S6132BUEM
S7132BU
S7132BUEM
S7142BU
S7142BUEM
S8142BU
S8142BUEM
5 1/16"
5 1/16"
6 9/16"
6 9/16"
8"
8"
8"
8"
9 1/4"
9 1/4"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Electronic
Emergency
Electronic
Emergency-integral switch
Electronic
Emergency-integral switch
Electronic
Emergency-integral switch
Electronic
Emergency
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
TRT
TRT
TRT
TRT
TRT
TRT
TRT
TRT
TRT
TRT
18W
18W
26/32W
26/32W
26/32W
26/32W
26/32/42W
26/32/42W
26/32/42W
26/32/42W
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
8 1/16"
9 5/8"
10"
11 1/16"
11 3/4"
13 5/16"
11 3/4"
13 5/16"
12 1/2"
14 1/16"
8 1/8"
8 1/8"
9 7/8"
9 7/8"
11 1/8 "
11 1/8 "
11 1/8 "
11 1/8 "
11 3/4"
11 3/4"
How to specify
Trim kit Frame-in kit
8021 C LW S6132BU
Standard dimming options* Reflector finish options
S6132B (add suffix in
box)
Suffix Ballast
Input
voltage
Reflector
finish
White
flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A
CL
CCL
CCD
CCZ
WH
* Some dimming options not available on all products. See product specification sheet for details.
4 ½" 18W Triple tube
Reflector trim: 8011 CCLW
Lamp lumens: 1200
Efficiency: 42%
Luminaire lumens: 507
Spacing ratio: 1.2
Cut-off: 50°
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
7'
8'
9'
23
16
12
9
7
0.76
0.53
0.39
0.29
0.23
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
ICON8010.AI-pg.6A
200
400
30°
60°
100
300
6" 32W Triple tube
Reflector trim: 8021 CCLW
Lamp lumens: 2400
Efficiency: 52.7%
Luminaire lumens: 1265
Spacing ratio: 1.1
Cut-off: 50°
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
7'
8'
9'
57
39
22
17
14
1.40
0.97
0.55
0.43
0.35
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
Pg. 6 B
600
1200 30°
60°
300
900
8" 42W Triple tube
Reflector trim: 8023 CCLW
Lamp lumens: 3200
Efficiency: 63%
Luminaire lumens: 2019
Spacing ratio: 0.9
Cut-off: 50°
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
9'
10'
65
45
26
20
16
1.40
1.00
0.55
0.43
0.35
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
Pg. 6C
Pg. 6 C
600
1500 30°
60°
300
1200
4", 6", 7" & 8" aperture
Vertical open downlight
1.29Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
600
1200 30°
60°
300
900
7" 42W Triple tube
Reflector trim: 8037
CLW
Report No. LRL798-1F
Lamp lumens: 3200
Efficiency: 65%
Luminaire lumens: 2092
Spacing ratio: 1.4
Cut-off: 55°
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
88
61
35
22
15
1.68
1.17
0.66
0.42
0.29
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
pg 08 C
pg 08 C
6" & 7" aperture
Horizontal open downlight (1 lamp)
How to specify
Trim kit Frame-in kit
8031 CLW S6132BU
Trim/frame compatibility
Aperture Trim kit
Frame-In
Kits
Ceiling
cutout Type Ballast Input voltage Lamp Wattage Length Width Height
6"
6"
7"
7"
7"
7"
8031
8031…E
8037
8 03 7… E
8037
8 03 7… E
S6132BU
S6132BUEM
S7132BU
S7132BUEM
S7142BU
S7142BUEM
6 9/16"
6 9/16"
8"
8"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Electronic
Emergency-integral
Electronic
Emergency-integral
Electronic
Emergency-integral
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
TRT
TRT
TRT
TRT
TRT
TRT
26/32W
26/32W
26/32W
26/32W
26/32/42W
26/32/42W
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
10"
11 9/16"
11 3/8"
12 15/16"
11 3/8"
12 15/16"
6 7/8"
6 7/8"
7 3/4"
7 3/4"
7 3/4"
7 3/4"
Standard dimming options* Reflector finish options
S6132BU (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish
White
flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A
CL
CCL
CCD
CCZ
WH
* Some dimming options not available on all products. See product specification sheet for details.
6" 26W Triple tube
Reflector trim: 8031 CLW
Report no.: LRL796-1A
Lamp lumens: 1800
Efficiency: 62%
Luminaire lumens: 1109
Spacing ratio: 1.4
Cut-off: 55°
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
46
33
18
12
8
1.24
0.86
0.48
0.31
0.21
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
8031CLW-26W
200
400 30°
60°
100
300
6" 32W Triple tube
Reflector trim: 8031 CLW
Report no.: LRL796-1B
Lamp lumens: 2400
Efficiency: 62%
Luminaire lumens: 1493
Spacing ratio: 1.4
Cut-off: 55°
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
63
44
24
16
11
0.76
0.53
0.39
0.29
0.23
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
8031CLW-26W
400
800 30°
60°
200
600
1.30 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
Trim/frame compatibility
Aperture Trim kit
Frame-In
Kits
Ceiling
cutout Type Ballast Input voltage Lamp Wattage Length Width Height
8"
8"
8"
8"
8038 (55° cutoff)
8038…E
8039 (50° cutoff )
8039…E
S8242BU
S8242BUEM
S8242BU
S8242BUEM
9 1/4"
9 1/4"
9 1/4"
9 1/4"
Non-IC
Non-IC
Non-IC
Non-IC
Electronic
Emergency-integral
Electronic
Emergency-integral
120/277V
120/277V
120/277V
120/277V
TRT
TRT
TRT
TRT
(2) 26/32/42W
(2) 26/32/42W
(2) 26/32/42W
(2) 26/32/42W
20"- 30"
20"- 30"
20"- 30"
20"- 30"
12 3/4"
14 5/16"
12 3/4"
14 5/16"
8"
8"
9"
9"
8" aperture
Horizontal open downlight (2 lamp)
Standard dimming options* Reflector finish options
S8242HU (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish
White
Flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec
HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A
CL
CCL
CCD
CCZ
WH
* Some dimming options not available on all products. See product specification sheet for details.
How to specify
Trim kit Frame-in kit
8038 C LW S8242HU
ICON8038.Al-Apg.10A
8" 32W Triple tube
Reflector trim: 8038 C LW
Report no.: ITL 44462
Lamp lumens: 4800
Efficiency: 72%
Luminaire lumens: 3479
Spacing ratio: 1.4 x 1.6
Cut-off: 55°
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
6'
7'
8'
10'
12'
106
77
59
38
27
1.77
1.31
1.00
0.64
0.44
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
700
1400
2800
30°
60°
700
2100
ICON8038.Al-Apg.10A
8" 42W Triple tube
Reflector trim: 8038 C LW
Report no.: ITL 44463
Lamp lumens: 6400
Efficiency: 67%
Luminaire lumens: 4320
Spacing ratio: 1.4 x 1.7
Cut-off: 55°
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
6'
7'
8'
10'
12'
131
97
74
48
32
2.64
1.94
1.48
0.95
0.66
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
700
1400
2800 30°
60°
700
2100
ICON8038.Al-Apg.10A
8" 42W Triple tube
Reflector trim: 8039 CLW
Report no.: 0172FR
Lamp lumens: 6400
Efficiency: 54%
Luminaire lumens: 3470
Spacing ratio: 1.4 x 1.6
Cut-off: 50°
Multiple unit data(RCR 1)
Spacing
on center
Initial
footcandles
Watts
per sq ft
6'
7'
8'
10'
12'
107
78
60
38
27
2.64
1.94
1.48
0.95
0.66
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
700
1400
2800
30°
60°
700
2100
1.31Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
6" & 7" aperture
Horizontal open downlight (2 lamp)
How to specify
Trim kit Frame-in kit
8052 CLW 6213HU
Trim/frame compatibility
Aperture Trim kit
Frame-In
Kits
Ceiling
cutout Type Ballast Input voltage Lamp Wattage Length Width Height
6"
6"
6"
6"
7"
7"
7"
7"
8052
8052
8051
8051
8056
8056…E
8056
8056…E
6213HU
6213HUEM
6218HU
6218HUEM
7218HU
7218HUEM
S7226HU
S7226HUEM
6 9/16"
6 9/16"
6 9/16"
6 9/16"
8"
8"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Electronic
Emergency
Electronic
Emergency
Electronic
Emergency-integral
Electronic
Emergency-integral
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
QT
QT
QT
QT
QT
QT
QT
QT
(2) 13W
(2) 13W
(2) 18W
(2) 18W
(2) 18W
(2) 18W
(2) 26W
(2) 26W
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
10"
10"
10"
10"
11 3/8"
12 15/16"
11 3/8"
12 15/16"
6"
6"
6"
6"
6 7/8"
6 7/8"
6 7/8"
6 7/8"
Standard dimming options* Reflector finish options
6213H (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish White flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A
CL
CCL
CCD
CCZ
WH
* Some dimming options not available on all products.
See product specification sheet for details.
6" Aperture (2) 13W quad
Reflector trim: 8052 C LW
Report No. LSI 9474
Lamp lumens: 1800
Efficiency: 54%
Luminaire lumens: 930
Spacing ratio: 1.6
Cut-off: 55°
Multiple unit data
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
37
26
15
9
6
1.28
0.89
0.50
0.32
0.22
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
400
800 30°
60°
200
600
6" Aperture (2) 18W quad tube
Reflector trim: 8051 CLW
Report No. 0053 FR
Lamp lumens: 2500
Efficiency: 50%
Luminaire lumens: 1253
Spacing ratio: 1.3 x 1.6
Cut-off: 55°
8051clw/6218/cs
Multiple unit data
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
50
35
20
15
13
1.56
1.08
0.61
0.48
0.39
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
500
1000 30°
60°
250
750
7" Aperture (2) 26W quad tube
Reflector trim: 8056 CLW
Report No. ITL 40604
Lamp lumens: 3600
Efficiency: 56%
Luminaire lumens: 2018
Spacing ratio: 1.6 x 1.7
Cut-off: 55°
8056clw/7218/cs
Multiple unit data
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
89
61
34
22
15
2.20
1.53
0.86
0.55
0.38
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
800
1600
30°
60°
400
1200
1.32 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
6" & 7" aperture
Horizontal lensed downlight
Trim/frame compatibility
Aperture Trim kit
Frame-In
Kits
Ceiling
cutout Type Ballast Input voltage Lamp Wattage Length Width Height
6"
7"
7"
7"
8091
8097
8096
8096
S6132BU
S6132BUEM
S7142BU
S7142BUEM
S7218HU
S7226HU
S7226HUEM
6 9/16"
6 9/16"
8"
8"
8"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Electronic
Electronic
Electronic
Electronic
Electronic
Electronic
Electronic
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
TRT
TRT
TRT
TRT
TRT
TRT
TRT
26/32W
26/32W
26/32/42W
26/32/42W
(2) 18W
(2) 26W
(2) 26W
20"- 30"
20"-30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
10"
11 9/16"
11 3/8"
12 15/16"
11 3/8"
11 3/8"
12 15/16"
6"
6"
6 1/2"
6 1/2"
5 3/4"
5 3/4"
5 3/4"
Standard dimming options* Reflector finish options
S6132B (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish
White
Flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Fresnel Lens, Clear Cone
Fresnel Lens, White Cone
Clear Lens, Clear Cone
Clear Lens, White Cone
Opal Lens, Clear Cone
Opal Lens, White Cone
Prismatic Lens, Clear Cone
Prismatic Lens, White Cone
FCLW
FWHW
CCLW
CWHW
DCLW
DWHW
PCLW
PWHW
FCLP
N/A
CCLP
N/A
DCLP
N/A
PCLP
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
* Some dimming options not available on all products.
See product specification sheet for details.
How to specify
Trim kit Frame-in kit
8091F CLW S6132BU
Multiple unit data(42W )
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
66
46
26
21
17
1.68
1.17
0.65
0.52
0.42
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
7" Aperture 42W Triple tube
Reflector trim: 8097 FCLW
Report No.
Lamp lumens: 3200
Efficiency: 47%
Luminaire lumens: 953
Spacing ratio: 0.8
30°
60°
350
700
1050
1400
Multiple unit data
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
7'
8'
9'
60
42
24
19
15
2.20
1.53
0.86
0.68
0.55
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
pg 14 B
7" Aperture (2) 26W Triple tube
Reflector trim: 8096 CCLW
Report No.
Lamp lumens: 3600
Efficiency: 38%
Luminaire lumens: 1376
Spacing ratio: 1.3
30°
60°
300
600
900
1200
30°
60°
250
500
750
1000
Multiple unit data(32W)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10'
12'
54
37
21
15
13
1.40
0.97
0.56
0.43
0.31
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
6" Aperture 32W Triple tube
Reflector trim: 8091 FCLW
Report No. 0075FR
Lamp lumens: 2400
Efficiency: 56%
Luminaire lumens: 1229
Spacing ratio: 1.2
1.33Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
8 ¾" aperture
Vandal resistant lensed downlights
Trim/frame compatibility
Aperture Trim kit
Frame-In
Kits
Ceiling
cutout Type Ballast Input voltage Lamp Wattage Length Width Height
8" 8098VWH 8242HUV 10" Non-IC Electronic 120/277V TRT 26/32/42W 20"- 30" 14" 5 1/8"
Standard dimming options* Reflector finish options
No dimming options currently available
Lens
Reflector finish White Flange
Aperture
matching flange Flangeless
Flush Opal Lens,
White Cone
VWH N/A N/A
* Some dimming options not available on all products.
How to specify
Trim kit Frame-in kit
8098V WH 8242HUV
400
800
30°
60°
200
600
8 ¾" Aperture (2) 32W Triple tube
Reflector trim: 8098VWH CLW
Lamp lumens: 2400
Efficiency: 43%
Luminaire lumens: 2066
Spacing ratio: 1.3
Multiple unit data
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
10
10'
85
60
35
22
11
2.47
1.74
1.01
.64
0.39
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
1.34 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
6" & 7" aperture
Cross blade louver downlight
How to specify
Trim kit Frame-in kit
8091CB WS6132BU
Standard dimming options* Reflector finish options
S6132B (add suffix in box)
Suffix Ballast
Input
voltage
Lens
Reflector finish White flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Clear Cone
Aluminum Cone
CBW
CBA
N/A
N/A
N/A
N/A
* Some dimming options not available on all products. See product specification sheet for details.
6" Aperture 32W Triple tube
Reflector trim: 8091CB CLW
30°
60°
200
400
600
800
Report No.0194 FR
Lamp lumens: 2400
Efficiency: 33%
Luminaire lumens: 804
Spacing ratio: 1.1
Cut-off: 50°
Multiple unit data (42W)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
9'
10'
31
21
12
9
8
1.40
0.97
0.56
0.43
0.35
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
pg 14 B
30°
60°
250
500
750
1000
7" Aperture 42W Triple tube
Reflector trim: 8097CB CLW
Report No.LSI12581
Lamp lumens: 3200
Efficiency: 30%
Luminaire lumens: 953
Spacing ratio: 0.8
Cut-off: 50°
Multiple unit data (42W)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
7'
8'
9'
41
28
21
16
13
1.68
1.17
0.67
0.52
0.42
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
Trim/frame compatibility
Aperture Trim kit
Frame-In
Kits
Ceiling
Cutout Type Ballast Input voltage Lamp Wattage Length Width Height
6"
7"
7"
8091CB
8097CB
8096CB
S6132BU
S6132BUEM
S7132BU
S7132BUEM
S7142BU
S7142BUEM
7218HU
S7226HU
6 9/16"
6 9/16"
8"
8"
8"
8"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Electronic
Emergency-integral
Electronic
Emergency-integral
Electronic
Emergency-integral
Electronic
Electronic
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
120/277V
TRT
TRT
TRT
TRT
TRT
TRT
DTT
DTT
26/32W
26/32W
26/32W
26/32W
26/32/42W
26/32/42W
(2) 18W
(2) 26W
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
10"
11 9/16"
11 3/8"
12 15/16"
11 3/8"
12 15/16
11 3/8"
11 3/8"
6"
6"
6 1/2"
6 1/2"
6 1/2"
6 1/2"
6 7/8"
6 7/8"
1.35Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
Trim/frame compatibility
Aperture Trim kit
Frame-In
Kits
Ceiling
cutout Type Ballast Input voltage Lamp Wattage Length Width Height
7"
7"
7"
7"
8"
8056TB
8056TB
8056TB
8037TB
8038TB
S7218HU
S7126HU
S7226HU
S7142BU
S8242HU
8"
8"
8"
8"
9 1/4"
Non-IC
Non-IC
Non-IC
Non-IC
Non-IC
Electronic
Electronic
Electronic
Electronic
Electronic
120/277V
120/277V
120/277V
120/277V
120/277V
DTT
DTT
DTT
TTT
TTT
(2) 18W
26W
(2) 26W
26/32/42W
(2) 26/32/42W
20"- 30"
20"- 30"
20"- 30"
20"- 30"
20"- 30"
11 3/8"
11 3/8"
11 3/8"
11 3/8"
11 3/8"
6 7/8"
6 7/8"
6 7/8"
7 3/4"
8"
7" & 8" aperture
Parabolic louver downlight
Standard dimming options* Reflector finish options
7218H (add suffix in box)
Suffix Ballast
Input
voltage
Lens
Reflector finish
White
Flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Turbo Louver,
White Cone
TBW N/A N/A
* Some dimming options not available on all products. See product specification sheet for details.
How to specify
Trim kit Frame-in kit
8056TB W7218HU
7" Aperture (2) 18W quad
Reflector trim: 8056TB W
Report No. LSC 6701
Lamp lumens: 2500
Efficiency: 40%
Luminaire lumens: 1007
Spacing ratio: 1.4
Cut-off: 50°
Multiple unit data
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
9'
10'
45
31
18
14
11
1.56
1.08
0.61
0.48
0.39
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
500
1000 30°
60°
250
750
7" Aperture (2) 26W quad tube
Reflector trim: 8056TB W
Report No. LSG 6477
Lamp lumens: 3600
Efficiency: 37%
Luminaire lumens: 1317
Spacing ratio: 1.4
Cut-off: 50°
Multiple unit data
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
8'
9'
10'
59
41
23
18
15
2.20
1.53
0.86
0.68
0.55
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
500
1000 30°
60°
250
750
1.36 Philips Lightolier For complete specification information visit www.lightolier.com
Downlighting – Professional – Calculite
7" & 8" aperture
Low profile parabolic louver downlight
How to specify
Trim kit Frame-in kit
8067 CLW 7213LPM120
Trim/frame compatibility
Aperture Trim kit
Frame-In
Kits
Ceiling
cutout Type Ballast Input voltage Lamp Wattage Length Width Height
7"
7"
8"
8"
8067
8067
8068
8068
7213LPM120
7213LPM277
8218LPU
8226LPU
8"
8"
9 1/4"
9 1/4"
Non-IC
Non-IC
Non-IC
Non-IC
Electronic
Electronic
Electronic
Electronic
120/277V
120/277V
120/277V
120/277V
DTT
DTT
DTT
DTT
(2) 13W
(2) 18W
(2) 18W
(2) 26W
20"- 30"
20"- 30"
20"- 30"
20"- 30"
10"
10"
11 3/8"
11 3/8"
6"
6"
6 7/8"
6 7/8"
Standard dimming options* Reflector finish options
No dimming options currently available
Lens Reflector
finish White flange
Aperture
matching flange Flangeless
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A
CL
CCL
CCD
CCZ
WH
* Some dimming options not available on all
products. See product specification sheet for details.
Report No. 1162FH
Lamp lumens: 1,600
Efficiency: 46.4%
Spacing ratio: 1.2
Cut-off: 50°
7" Aperture (2) 13W Twin tube
Reflector trim: 8067
Multiple unit data
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
7'
8'
9'
33
23
17
13
10
1.28
0.89
0.65
0.50
0.40
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
8" Aperture (2) 18W quad tube
Reflector trim: 8068
Lamp lumens: 2,320
Efficiency: 44.5%
Spacing ratio: 1.1
Cut-off: 50° 500
1000 30°
60°
250
750
Multiple unit data (18W)
Spacing
on center
Initial
footcandles
Watts
per sq ft
5'
6'
7'
8'
9'
46
32
18
14
12
1.56
1.08
0.61
0.48
0.39
75' x 75' x 10' room, workplane 2 ½'
above floor, 80/50/20% reflectances.
30°
60°
7 3/8"
4 1/8"
8 3/4"
5 1/8"
1.37Comprehensive lighting catalog 7th Edition
Calculite – Professional – Downlighting
Trim/frame compatibility
Aperture Trim kit
Frame-in
kits
Ceiling
cutout Type Ballast Input voltage Lamp Wattage Length Width Height
4"
6"
7"
7"
8011W W
8021WW*
8022WW
8022WW*
4118VU
S6132BU
S7132BU
S7142BU
5 1/16"
6 9/16"
8"
8"
Non-IC
Non-IC
Non-IC
Non-IC
Electronic
Electronic
Electronic
Electronic
120/277V
120/277V
120/277V
120/277V
TRT
TRT
TRT
TRT
18W
26/32W
26/32W
26/32/42W
20"- 30"
20"- 30"
20"- 30"
20"- 30"
8 1/16"
10"
11 3/8"
11 3/8"
8"
9 3/4"
11 ¼"
11 ¼"
*Corner (CW) and Double (DW) wall washers also available
Standard dimming options* Reflector finish options
S6132B (add suffix in box)
Suffix Ballast
Input
voltage
Reflector
finish White Flange
Aperture
matching flange Flangeless
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
PowerSpec HDF
Lutron 3%
Lutron 3%
Mark 7
Mark 10
Mark 10
120/277V
120V
277V
120/277V
120V
277V
Specular clear
Comfort clear
Comfort clear diffuse
Champagne bronze
White
CLW
CCLW
CCDW
CCZW
WHW
CLP
CCLP
CCDP
CCZP
N/A
CL
CCL
CCD
CCZ
WH
* Some dimming options not available on all products. See product specification sheet for details.
How to specify
Trim kit Frame-in kit
8021WW C LW S6132BU
6" 32W Triple tube
Reflector trim: 8021 CCLW
Lamp lumens: 2400
Cut-off: 50° 225
450
675
900
30°
60°
Wall
Wash Side
Downlight
Side
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 4' on center
4'
111 11 11
218 18 18
320 20 20
422 19 21
520 18 20
617 16 17
715 13 14
812 11 12
911 10 10
4 ½" 18W Triple tube
Reflector trim: 8011 CCLW
Lamp lumens: 1200
Cut-off: 50°
Multiple unitsFootcandles on wall
Distance from ceiling in feet
3' from wall - 4' on center
4'
112 712
213 10 13
313 14 13
411 11 11
5 9 8 9
6 7 7 7
7 5 5 5
8 4 4 4
9 3 4 3
100
