OVERVIEW
With a design life of 20+ years and superior in-rush current and surge-protection features, the DLL Elite
support the extended life and low maintenance benefits associated with LED fixtures.
FEATURES
APPLICATIONS
• LED lighting fixtures that require dusk to dawn control
• High inrush current fixtures
• Designed to last as long as your LED lighting system, 20 + years
• LED inrush protection with triac assisted relay
• Extreme surge protection of 1280J/40kA utility or 2120J/40kA UL listed
• Double thick enclosure and lens with additional UV inhibitor
• High temp base plastic tested to 140°C
• Long life capacitors
• Full wave rectified power supply
• Dual zener diodes for long life
• Solid brass contact blades
• Double sided, thru hole plated .062” FR4 circuit board
• Conformal coated printed circuit board
• Sealed packaging for extended storage
DLL Elite
Electronic Locking Type Photocontrol
ORDERING INFORMATION
DLL PHOTOCONTROL Example: DLL127 1.5 J50
Series & Voltage Failure Mode Turn-On Level (fc) Filter Certification Cover Color Pkg. Qty.
DLL127 120-277V
DLL347 340V
DLL480 480V
[blank] Fail On
F Fail Off
1.5 ANSI Std. [blank] Std. Operation
IR IR Filtered Silicon
[blank] Std.
CUL CULus
[blank] Std.¹
BK Black²
BR Brown²
GR Green²
GY Gray²
BL Blue²
YL Yellow²
JU 1 Unit
J12 12 Units
J50 50 Units
SPECIFICATIONS
Catalog Number: Date: Project:
REGULATORY LISTINGS
• ANSI C136.10
• ROHS compliant
• UL listed to U.S. and Canadian safety standards
• Surge rated in excess of ANSI C136.10 to 20kV/10kA
OPERATING CHARACTERISTICS
• Voltage 120 to 480 VAC, 60Hz
• Load rating: 1000 watts, 1800 VA ballast
• Average power consumption: <0.5 watts @ 120V DLL STANDARD COLORS
Non-UL UL
120-277V Green Blue
347V Green Green
480V Yellow Yellow
DIMENSIONS
Warranty
Ten-year limited warranty. Complete warranty terms located at:
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
Note: Actual performance may differ as a result of end-user environment and application.
Specifications subject to change without notice.
DTL-DLL
NOTES
1. No color substitutions for UL models.
2. Non-standard custom colors are non-stock items. Available in J12 and J50 only. Consult customer service.
2.55”
3.25”
2 of 2
Acuity Brands | One Lithonia Way Conyers, GA 30012 Phone: 800.535.2465 www.acuitycontrols.com © 2014-2015 Acuity Brands Lighting, Inc. All rights reserved. 08/19/15
STOCKED MODEL NUMBERS
Model # Description Pkg. Qty.
DLL127 1.5 120-277V Fail- On (non-UL) JU, J12, J50
DLL127F 1.5 120-277V Fail- Off (non-UL) JU, J12, J50
DLL127F 1.5 CUL 120-277V Fail- Off JU, J12, J50
DLL127 1.5 CUL 120-277V Fail- On JU, J12, J50
DLL347F 1.5 CUL 347V Fail- Off JU, J12, J50
DLL347 1.5 CUL 347V Fail- On JU, J12, J50
DLL480F 1.5 CUL 480V Fail- Off JU, J12, J50
DLL480 1.5 CUL 480V Fail- On JU, J12, J50
Models not listed above are subject to the standard 60 day lead-time.
