Important Notice:

This catalog contains data accumulated up to the last update. Additional in-

formation is constantly being uncovered through research and testing, which

may modify the data given herein. This is particularly true of newer lamps. Ac-

cordingly, SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.

The data and suggested applications contained in this catalog, as well as any

additional information our representatives may be able to furnish, are for gen-

eral information only and are not intended and should not be taken as repre-

sentations or warranties as to the suitability of a lamp for any particular applica-

tion or use in any particular equipment, nor are our representatives authorized

to make any such representations or give any such warranties. Applications

and conditions of use are many and varied, and beyond our control. We can-

not have the same degree of knowledge that the purchaser has with respect

to the design of his equipment and the conditions of its use. Therefore, it is up

to the purchaser to determine the suitability of a lamp for his intended applica-

tion or use and to assume the responsibility for that determination.

EiKO Global, LLC. desires to supply the best possible products at all times. For

this reason, EiKO reserves the right to make changes in its products and to

introduce new products or discontinue existing products without notice.

The specications and information in this catalog are believed to be accurate.

However, no warranty is made or implied as to the accuracy of this informa-

tion. EiKO Global, LLC does not accept or assume responsibility of liability for

errors, changes, omissions, or for harm resulting therefrom.

In order to insure that you have the latest information and

product specications, please visit us on the web at:

eiko.com

Lighting Information

Index/Additional Info

4 Cross-Referencing 6 Common Base Types

100 Index 112 Terms & Conditions 113 Limited Warranty

8 LitespanLED® Fixtures 20 LitespanLED® Replacement Lamps

28 Compact Fluorescent 24 Linear Fluorescent 40 PowerMaster® Ballasts

42 ColorMaster PRO™ Ceramic Metal Halide 43 Metal Halide 46 HPS 47 Mercury Vapor

48 EiKON™ Energy Efﬁcient 49 MR 52 Single & Double Ended 54 Bi-Pin 55 SoLux®

56 A-Shaped 57 C-Shaped 57 R & BR 57 S-Shaped 58 T-Shaped

60 Forward Lighting 66 HID-OE 67 Mo/Sno 67 Sealed Beam 71 Miniature

88 ArcMaster™ SSTV 88 ColorMaster™ Digital Imaging 89 SSTV 91 Healthcare 95 ANSI

LED

Fluorescent

HID

Halogen

Incandescent

Automotive & Miniature

Specialty

Contents

100

Visit our website for the most current specs: eiko.com

Lighting Information

Cross Referencing

for General Lighting & Automotive/Miniature

Cross referencing a lamp can be done in two ways:

• By matching the known part number of your lamp to a part number of another manufacturer

known to have the same speciﬁcations.

• By matching the speciﬁcations of your lamp to the speciﬁcations of a known part number.

Step 1: What is the lamp family and sub-family? (For General Lighting lamps)

Use the chart opposite to determine to which family and sub-family your lamp belongs.

Step 2: What is the bulb shape?

“Bulb” refers to the glass portion of the

lamp. Refer to the diagram to the right for

common bulb shapes.

Step 3: What is the base type?

The base supports the lamp in the socket and conducts electricity to the ﬁlament. Refer to the

charts on pages 6-7 for common General Lighting and Automotive Miniature base types.

Step 4: What is the voltage and wattage?

This information can usually be found stamped on the base of the bulb. If only given amps, re-

member this conversion: Amps x Volts = Watts.

Step 4: What is the color temperature? (For General Lighting lamps)

Color temperature is usually represented in one of three ways:

• Descriptive

“Warm White” (WW), “Cool White” (CW), “Daylight” (D), etc.

• Degrees Kelvin (by hundreds)

27, 41, 65, etc. (27=2700° Kelvin)

• Color Rendering Index (CRI) + Degrees Kelvin

735, 841, etc. (735 = a CRI of approx. 75% and a color temp of 3500° Kelvin)

Step 5: What is the beam spread (light pattern)? (For PAR and MR Type lamps)

Narrow Spot (NSP) = 10° Spot (SP) = 17°

Narrow Flood (NFL) = 24° Medium Flood (MFL) = 26°

Flood (FL) = 36° Wide Flood (WFL) = 55°

B G

P RP S T TL

Note: The number after the letter designation of a bulb means “eighths of an inch.”

Example: T-2 is a T-shaped bulb that is approximately 2/8” in diameter; each eighth is 0.125”, so a T-2 would be approximately 0.250” in diameter.

Finding EiKO’s Part Number

Visit us at eiko.com and hover over “Search” on the quick link bar at the top of the page,

then select “Advanced Search” from the dropdown menu. Enter as much information as

you have and click “Search.”

If you have another manufacturer’s part number, select “Basic Search,” enter the part num-

ber and check “Cross Reference Part Number.” If a match is not returned, look up the part

number in the manufacturer’s catalog and find the specifications. Then cross the lamp to an

EiKO part number using the “Advanced Search” option.

Visit our website for the most current specs: eiko.com 5

Lighting Information

General Lighting

IncandescentHalogenHIDFluorescentLED

A-Line Linear Metal Halide PAR A-Line

R & BR CFL

High Pressure Sodium

MR Types R & BR

PAR CFLi Mercury Vapor JC, JCD

QuartzMR Types

Linear

Automotive

Capsules Miniatures Sealed Beams

Visit our website for the most current specs: eiko.com

Lighting Information

General Lighting > Common Base Types

E10

Miniature Screw

G24d-1

2-Pin

GX24q-3

4-Pin

E17

Intermediate Screw

G24q-1

4-Pin

2G11

4-Pin, Twin Tube

GZ4

Bi-Pin

Sub-Mini 2-Pin

GU5.3

Bi-Pin

Miniature Bi-Pin

G9.5

Bi-Pin Cap

GX5.3

Bi-Pin

Circular

E11

Mini. Candelabra Screw

G24d-2

2-Pin

GX24q-4

4-Pin

E26

Medium Screw

G24q-2

4-Pin

W2.1x9.5d

Miniature Wedge

GZ6.35

Bi-Pin

Bi-Pin Cap

GU10

Bi-Pin

Medium Bi-Pin

G12

12mm Bi-Pin

GX23

Bi-Pin Cap

BA15d

DC Bayonet

E12

Candelabra Screw

G24d-3

2-Pin

SV8.5mm

Festoon

E39/E40

Mogul Screw

G24q-3

4-Pin

W2x4.6d

Sub-Miniature Wedge

GY5.3

Bi-Pin

EX39

Mogul Screw w/

Long Prong

GU4

Bi-Pin

Rx7s

Recessed Single

Contact

GY9.5

Bi-Pin

G6.35

Bi-Pin Base

GU24

Bi-Pin

T12

Medium Bi-Pin

G13

½” Bi-Pin

GX23-2

Bi-Pin

BAY15d

DC Index Bayonet

G23

Bi-Pin Cap

GX24q-2

4-Pin

BA15s

SC Bayonet

TS5

Slide Base #5

Wedge

Glass Wedge T5

RGLP

Rigid Loop

Visit our website for the most current specs: eiko.com 7

Lighting Information

Automotive & Miniature > Common Base Types

E10

Miniature Screw

W2.1x9.5d

Miniature Wedge

W2x4.6d

Sub-Miniature Wedge

BA7s

European Bayonet

P40s

Single Contact Mogul

Prefocus Flanged

Mini Cap

Miniature Cap

B10d

Printed Circuit Socket

BA15s

SC Bayonet

PK22s

Prefocus Flanged, H3

PGJ13

Right Angle Prefocus

SV8.5mm

Festoon

2 Contact

Lugs 3 Contact

Lugs 2 Right

Angle Lugs Right Angle,

Plastic

P22d

Axial Prefocus

P45t

Axial Prefocus

BA9s

Miniature Bayonet

P43t

Axial Prefocus

Wire Leads

TS5

Slide Base #5

BAU15s

SC Bayonet Offset

PK32d-2

P29t

Axial Prefocus

R7s

Recessed Single

Contact

P14.5s

H1 Type

P28s

Medium Prefocus

Flanged Single Contact

PK32d-3

2 Lugs

BA15d

DC Bayonet

PGJ19

Right Angle Prefocus

PG13

Axial Prefocus

W2.5x16d

Plastic Wedge

Single Filament

W2.5x16q

Plastic Wedge

Double Filament

BAY15d

DC Index Bayonet

PX26d

Axial Prefocus

2ST

2 Screw Terminals

Wedge

Glass Wedge T5

BAZ15d

DC Index Bayonet

Offset

PY20d

Right Angle Prefocus

Slip-On

Slip-On Terminals

Sub-Midget Flanged

P20d

Axial Prefocus

P32d-2

X511

H2 Prefocus Type

W3x16d

Maxi Wedge Single

Filament

P32d-3

RGLP

Rigid Loop

W3x16q

Maxi Wedge Double

Filament

Visit our website for the most current specs: eiko.com

LED

LitespanLED® 2x2 Direct Panel

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

LS-DP22-46W-35K-L1-W-N-U 08069 Max 46 120-277 VAC 3000 3500 Satin White Poly. White None

LS-DP22-46W-41K-L1-W-N-U 08070 Max 46 120-277 VAC 3500 4100 Satin White Poly. White None

LS-DP22-46W-50K-L1-W-N-U 08071 Max 46 120-277 VAC 3500 5000 Satin White Poly. White None

LitespanLED® 2x2 Slim Panel

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

LS-SP22-45W-35K-L1-W-N-U 08072 45 120-277 3000 3500 Satin White White None

LS-SP22-45W-41K-L1-W-N-U 08073 45 120-277 3500 4100 Satin White White None

LS-SP22-45W-50K-L1-W-N-U 08074 45 120-277 3500 5000 Satin White White None

LitespanLED® Area Street Light - 2-3/8” Aimable Slipﬁtter

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-CR-240W-50K-N18-W-N-U 08262 240 120-277 VAC 5000K Type V (Wide) White None

LED Based Fixtures

Our LitespanLED® line offers the most efﬁcient LED ﬁxtures on the market at 95-105 LPW. The individual LED heatsink

provides unrivaled thermal control, and the innovative modular design allows for scalability. Precision optics target light to

the task. Our ﬁxtures are IP65 rated for weather protection, and DesignLights Consortium™ (DLC) qualiﬁed for high quality

and energy efﬁciency.

Advantages include directional light emission, superior optical controls, instant-on capabilities, rapid on/off cycling, cold

temperature operation, extended lifetime, and superior lumen-per-watt efﬁcacy.

Direct Panel Slim Panel Area Street Light

Visit our website for the most current specs: eiko.com 9

LED

LitespanLED® Area Street Light - 2-3/8” Aimable Slipﬁtter Vertical Orientation

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-BR-50W-50K-N18-BR-N-N 08063 50 120-277 VAC 5000 Type V (Wide) Bronze None

C0820-BR-50W-50K-N31-BR-N-U 08121 50 120-277 VAC 5000 Type II (Short) Bronze None

C0820-BR-70W-50K-N27-W-N-U 08085 70 120-277 VAC 5000 Type III White None

C0820-BR-90W-50K-N18-BR-N-N 08014 90 120-277 VAC 5000 Type V (Wide) Bronze None

C0820-BR-90W-50K-N18-W-N-U 08066 90 120-277 VAC 5000 Type V (Wide) White None

C0820-BR-90W-50K-N27-BR-P-U 08197 90 120-277 VAC 5000 Type III Bronze Button Type Photocell

C0820-BR-90W-50K-N31-BR-N-N 08013 90 120-277 VAC 5000 Type II (Short) Bronze None

C0820-BR-90W-50K-N31-W-N-N 08012 90 120-277 VAC 5000 Type II (Short) White None

C0820-BR-120W-40K-N18-BR-N-U 08297 120 120-277 VAC 5000 Type V (Wide) Bronze None

C0820-BR-120W-50K-N18-BR-N-U 08093 120 120-277 VAC 5000 Type V (Wide) Bronze None

C0820-BR-120W-50K-N27-BR-N-U 08150 120 120-277 VAC 5000 Type III Bronze None

C0820-BR-120W-50K-N27-BR-P-U 08198 120 120-277 VAC 5000 Type III Bronze Button Type Photocell

C0820-BR-120W-50K-N27-BR-TL-U 08294 120 120-277 VAC 5000 Type III Bronze Twist Lock Photocell

C0820-BR-120W-50K-N31-BR-N-U 08122 120 120-277 VAC 5000 Type II (Short) Bronze None

C0820-BR-120W-50K-N34-BR-N-U 08225 120 120-277 VAC 5000 Type II (Medium) Bronze None

C0820-BR-120W-50K-N34-BR-P-U 08199 120 120-277 VAC 5000 Type II (Medium) Bronze Button Type Photocell

C0820-BR-160W-50K-N18-BR-N-U 08257 160 120-277 VAC 5000 Type V (Wide) Bronze None

C0820-BR-160W-50K-N18-BR-TL-U 08239 160 120-277 VAC 5000 Type V (Wide) Bronze Twist Lock Photocell

C0820-BR-160W-50K-N27-W-N-U 08194 160 120-277 VAC 5000 Type III White None

C0820-BR-160W-50K-N34-BR-P-U 08200 160 120-277 VAC 5000 Type II (Medium) Bronze Button Type Photocell

C0820-BR-200W-50K-N27-BR-TL-U 08285 200 120-277 VAC 5000 Type III Bronze Twist Lock Photocell

C0820-BR-240W-50K-N18-BR-N-U 08258 240 120-277 VAC 5000 Type V (Wide) Bronze None

C0820-BR-240W-50K-N18-S-N-U 08111 240 120-277 VAC 5000 Type V (Wide) White None

C0820-BR-240W-50K-N18-W-N-U 08259 240 120-277 VAC 5000 Type V (Wide) White None

C0820-BR-240W-50K-N27-BR-N-U 08196 240 120-277 VAC 5000 Type III Bronze None

C0820-BR-240W-50K-N27-W-N-N 08030 240 120-277 VAC 5000 Type III White None

C0820-BR-240W-50K-N31-BR-N-U 08123 240 120-277 VAC 5000 Type II (Short) Bronze None

C0820-BR-240W-50K-N31-W-N-U 08129 240 120-277 VAC 5000 Type II (Short) White None

C0820-BR-240W-50K-N34-BL-N-U 08177 240 120-277 VAC 5000 Type II (Medium) White None

LitespanLED® Area Street Light - Arm Mount for Square or Round Pole

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-DR-F-50W-50K-N18-BR-N-N 08016 50 120-277 VAC 5000 5000 Type V (Wide) Bronze None

C0820-DR-F-90W-50K-N18-BR-N-N 08017 90 120-277 VAC 9000 5000 Type V (Wide) Bronze None

C0820-DR-120W-50K-N18-BR-N-U 08241 120 120-277 VAC 5000 Type V (Wide) Bronze None

C0820-DR-160W-50K-N27-BR-N-U 08260 160 120-277 VAC 5000 Type III Bronze None

C0820-DR-160W-50K-N27-BR-TL-U 08283 160 120-277 VAC 5000 Type III Bronze Twist Lock Photocell

C0820-DR-160W-50K-N27-W-N-U 08261 160 120-277 VAC 5000 Type III White None

C0820-DR-F-240W-40K-N27-W-N-N 08015 240 120-277 VAC 4000 Type III White None

LitespanLED® Area Street Light - Spider Mount Bracket

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-SPIDER MOUNT BRACKET 08040

Area Street Light

Visit our website for the most current specs: eiko.com

LED

LitespanLED® Canopy Light - Scottsdale Design

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-HC-80W-40K-N38-W-N-N 93205 80 120-277 VAC 7083 4000 White None

C0820-HC-80W-40K-N39-W-N-N 93206 80 120-277 VAC 7085 4000 Type V (Wide) White None

C0820-HC-80W-50K-N38-W-N-N 93207 80 120-277 VAC 7870 5000 White None

C0820-HC-80W-50K-N39-W-N-N 93208 80 120-277 VAC 7872 5000 Type V (Wide) White None

C0820-HC-100W-40K-N39-W-N-N 93201 100 120-277 VAC 8856 4000 Type V (Wide) White None

C0820-HC-100W-50K-N39-W-N-N 93202 100 120-277 VAC 9840 5000 Type V (Wide) White None

C0820-HC-120W-40K-N39-W-N-N 93203 120 120-277 VAC 10628 4000 Type V (Wide) White None

C0820-HC-120W-50K-N39-W-N-N 93204 120 120-277 VAC 11808 5000 Type V (Wide) White None

LitespanLED® Canopy Light - Richmond Design

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-KC-80W-40K-N39-W-N-N 93213 80 120-277 VAC 7085 4000 Type V (Wide) White None

C0820-KC-80W-50K-N38-W-N-N 93214 80 120-277 VAC 7870 5000 White None

C0820-KC-80W-50K-N39-W-N-N 93215 80 120-277 VAC 7872 5000 Type V (Wide) White None

C0820-KC-100W-40K-N39-W-N-N 93209 100 120-277 VAC 8856 4000 Type V (Wide) White None

C0820-KC-100W-50K-N39-W-N-N 93210 100 120-277 VAC 9840 5000 Type V (Wide) White None

C0820-KC-120W-40K-N39-W-N-N 93211 120 120-277 VAC 10628 4000 Type V (Wide) White None

C0820-KC-120W-50K-N39-W-N-N 93212 120 120-277 VAC 11808 5000 Type V (Wide) White None

LitespanLED® Canopy Light - Slim Design

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-RF-80W-40K-N39-W-N-N 93255 80 120-277 VAC 7085 4000 Type V (Wide) White None

C0820-RF-80W-50K-N39-W-N-N 93256 80 120-277 VAC 7872 5000 Type V (Wide) White None

C0820-RF-100W-40K-N39-W-N-N 93251 100 120-277 VAC 8856 4000 Type V (Wide) White None

C0820-RF-100W-50K-N39-W-N-N 93252 100 120-277 VAC 9840 5000 Type V (Wide) White None

C0820-RF-120W-40K-N39-W-N-N 93253 120 120-277 VAC 10628 4000 Type V (Wide) White None

C0820-RF-120W-50K-N39-W-N-N 93254 120 120-277 VAC 11808 5000 Type V (Wide) White None

LitespanLED® 4” Downlight Kit

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

LED-DK6-12W827K-DIM-G4 90015 11 120 650 2700

LED-DK6-12W830K-DIM-G4 90014 11 120 650 3000

LED-DK6-12W840K-DIM-G4 90013 11 120 650 4000

LED-DK6-16W927K-DIM-G4 90012 12 120 600 2700

LED-DK6-16W930K-DIM-G4 90011 12 120 600 3000

LED-DK6-19W827K-DIM-G4 90010 15 120 850 2700

LED-DK6-19W830K-DIM-G4 90009 15 120 850 3000

LED-DK6-19W840K-DIM-G4 90008 15 120 850 4000

LitespanLED® 6” Downlight Kit

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

LED-DK6-12W827K-DIM-G4 90007 12 120 750 2700

LED-DK6-12W830K-DIM-G4 90006 12 120 750 3000

LED-DK6-12W840K-DIM-G4 90005 12 120 750 4000

LED-DK6-16W927K-DIM-G4 90004 16 120 800 2700

>>Continued on page 11

6” Downlight Kit4” Downlight KitCanopy Light

Visit our website for the most current specs: eiko.com 11

LED

LitespanLED® 6” Downlight Kit

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

LED-DK6-16W930K-DIM-G4 90003 16 120 800 3000

LED-DK6-19W827K-DIM-G4 90002 19 120 1200 2700

LED-DK6-19W830K-DIM-G4 90001 19 120 1200 3000

LED-DK6-19W840K-DIM-G4 90000 19 120 1200 4000

LitespanLED® 30W Flood Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-FL-30W-40K-N31-BL-N-N 93081 30 120-277 VAC 2970 4000 Type II Black None

C0820-FL-30W-40K-N31-BL-P-N 93082 30 120-277 VAC 2970 4000 Type II Black Photo Censor

C0820-FL-30W-40K-N31-BR-N-N 93083 30 120-277 VAC 2970 4000 Type II Bronze None

C0820-FL-30W-40K-N31-BR-P-N 93084 30 120-277 VAC 2970 4000 Type II Bronze Photo Censor

C0820-FL-30W-40K-N31-S-N-N 93085 30 120-277 VAC 2970 4000 Type II Silver None

C0820-FL-30W-40K-N31-S-P-N 93086 30 120-277 VAC 2970 4000 Type II Silver Photo Censor

C0820-FL-30W-40K-N31-W-N-N 93087 30 120-277 VAC 2970 4000 Type II White None

C0820-FL-30W-40K-N31-W-P-N 93088 30 120-277 VAC 2970 4000 Type II White Photo Censor

C0820-FL-30W-50K-N31-BL-N-N 93089 30 120-277 VAC 3150 5000 Type II Black None

C0820-FL-30W-50K-N31-BL-P-N 93090 30 120-277 VAC 3150 5000 Type II Black Photo Censor

C0820-FL-30W-50K-N31-BR-N-N 93091 30 120-277 VAC 3150 5000 Type II Bronze None

C0820-FL-30W-50K-N31-BR-P-N 93092 30 120-277 VAC 3150 5000 Type II Bronze Photo Censor

C0820-FL-30W-50K-N31-S-N-N 93093 30 120-277 VAC 3150 5000 Type II Silver None

C0820-FL-30W-50K-N31-S-P-N 93094 30 120-277 VAC 3150 5000 Type II Silver Photo Censor

C0820-FL-30W-50K-N31-W-N-N 93095 30 120-277 VAC 3150 5000 Type II White None

C0820-FL-30W-50K-N31-W-P-N 93096 30 120-277 VAC 3150 5000 Type II White Photo Censor

LitespanLED® 50W Flood Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-FL-50W-40K-N31-BL-N-N 93097 50 120-277 VAC 4950 4000 Type II Black None

C0820-FL-50W-40K-N31-BL-P-N 93098 50 120-277 VAC 4950 4000 Type II Black Photo Censor

C0820-FL-50W-40K-N31-BR-N-N 93099 50 120-277 VAC 4950 4000 Type II Bronze None

C0820-FL-50W-40K-N31-BR-P-N 93100 50 120-277 VAC 4950 4000 Type II Bronze Photo Censor

C0820-FL-50W-40K-N31-S-N-N 93101 50 120-277 VAC 4950 4000 Type II Silver None

C0820-FL-50W-40K-N31-S-P-N 93102 50 120-277 VAC 4950 4000 Type II Silver Photo Censor

C0820-FL-50W-40K-N31-W-N-N 93103 50 120-277 VAC 4950 4000 Type II White None

C0820-FL-50W-40K-N31-W-P-N 93104 50 120-277 VAC 4950 4000 Type II White Photo Censor

C0820-FL-50W-50K-N31-BL-N-N 93105 50 120-277 VAC 5250 5000 Type II Black None

C0820-FL-50W-50K-N31-BL-P-N 93106 50 120-277 VAC 5250 5000 Type II Black Photo Censor

C0820-FL-50W-50K-N31-BR-N-N 93107 50 120-277 VAC 5250 5000 Type II Bronze None

C0820-FL-50W-50K-N31-BR-P-N 93108 50 120-277 VAC 5250 5000 Type II Bronze Photo Censor

C0820-FL-50W-50K-N31-S-N-N 93109 50 120-277 VAC 5250 5000 Type II Silver None

C0820-FL-50W-50K-N31-S-P-N 93110 50 120-277 VAC 5250 5000 Type II Silver Photo Censor

C0820-FL-50W-50K-N31-W-N-N 93111 50 120-277 VAC 5250 5000 Type II White None

C0820-FL-50W-50K-N31-W-P-N 93112 50 120-277 VAC 5250 5000 Type II White Photo Censor

Flood Light

Visit our website for the most current specs: eiko.com

LED

LitespanLED® 80W Flood Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-FL-80W-40K-N31-BL-N-N 93113 80 120-277 VAC 7920 4000 Type II Black None

C0820-FL-80W-40K-N31-BL-P-N 93114 80 120-277 VAC 7920 4000 Type II Black Photo Censor

C0820-FL-80W-40K-N31-BR-N-N 93115 80 120-277 VAC 7920 4000 Type II Bronze None

C0820-FL-80W-40K-N31-BR-P-N 93116 80 120-277 VAC 7920 4000 Type II Bronze Photo Censor

C0820-FL-80W-40K-N31-S-N-N 93117 80 120-277 VAC 7920 4000 Type II Silver None

C0820-FL-80W-40K-N31-S-P-N 93118 80 120-277 VAC 7920 4000 Type II Silver Photo Censor

C0820-FL-80W-40K-N31-W-N-N 93119 80 120-277 VAC 7920 4000 Type II White None

C0820-FL-80W-40K-N31-W-P-N 93120 80 120-277 VAC 7920 4000 Type II White Photo Censor

C0820-FL-80W-50K-N31-BL-N-N 93121 80 120-277 VAC 8400 5000 Type II Black None

C0820-FL-80W-50K-N31-BL-P-N 93122 80 120-277 VAC 8400 5000 Type II Black Photo Censor

C0820-FL-80W-50K-N31-BR-N-N 93123 80 120-277 VAC 8400 5000 Type II Bronze None

C0820-FL-80W-50K-N31-BR-P-N 93124 80 120-277 VAC 8400 5000 Type II Bronze Photo Censor

C0820-FL-80W-50K-N31-S-N-N 93125 80 120-277 VAC 8400 5000 Type II Silver None

C0820-FL-80W-50K-N31-S-P-N 93126 80 120-277 VAC 8400 5000 Type II Silver Photo Censor

C0820-FL-80W-50K-N31-W-N-N 93127 80 120-277 VAC 8400 5000 Type II White None

C0820-FL-80W-50K-N31-W-P-N 93128 80 120-277 VAC 8400 5000 Type II White Photo Censor

LitespanLED® 100W Flood Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-FL-100W-40K-N31-BL-N-N 93001 100 120-277 VAC 9900 4000 Type II Black None

C0820-FL-100W-40K-N31-BL-P-N 93002 100 120-277 VAC 9900 4000 Type II Black Photo Censor

C0820-FL-100W-40K-N31-BR-N-N 93003 100 120-277 VAC 9900 4000 Type II Bronze None

C0820-FL-100W-40K-N31-BR-P-N 93004 100 120-277 VAC 9900 4000 Type II Bronze Photo Censor

C0820-FL-100W-40K-N31-S-N-N 93005 100 120-277 VAC 9900 4000 Type II Silver None

C0820-FL-100W-40K-N31-S-P-N 93006 100 120-277 VAC 9900 4000 Type II Silver Photo Censor

C0820-FL-100W-40K-N31-W-N-N 93007 100 120-277 VAC 9900 4000 Type II White None

C0820-FL-100W-40K-N31-W-P-N 93008 100 120-277 VAC 9900 4000 Type II White Photo Censor

C0820-FL-100W-50K-N31-BL-N-N 93009 100 120-277 VAC 10500 5000 Type II Black None

C0820-FL-100W-50K-N31-BL-P-N 93010 100 120-277 VAC 10500 5000 Type II Black Photo Censor

C0820-FL-100W-50K-N31-BR-N-N 93011 100 120-277 VAC 10500 5000 Type II Bronze None

C0820-FL-100W-50K-N31-BR-P-N 93012 100 120-277 VAC 10500 5000 Type II Bronze Photo Censor

C0820-FL-100W-50K-N31-S-N-N 93013 100 120-277 VAC 10500 5000 Type II Silver None

C0820-FL-100W-50K-N31-S-P-N 93014 100 120-277 VAC 10500 5000 Type II Silver Photo Censor

C0820-FL-100W-50K-N31-W-N-N 93015 100 120-277 VAC 10500 5000 Type II White None

C0820-FL-100W-50K-N31-W-P-N 93016 100 120-277 VAC 10500 5000 Type II White Photo Censor

LitespanLED® 120W Flood Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-FL-120W-40K-N31-BL-N-N 93017 120 120-277 VAC 11340 4000 Type II Black None

C0820-FL-120W-40K-N31-BL-P-N 93018 120 120-277 VAC 11340 4000 Type II Black Photo Censor

C0820-FL-120W-40K-N31-BR-N-N 93019 120 120-277 VAC 11340 4000 Type II Bronze None

C0820-FL-120W-40K-N31-BR-P-N 93020 120 120-277 VAC 11340 4000 Type II Bronze Photo Censor

C0820-FL-120W-40K-N31-S-N-N 93021 120 120-277 VAC 11340 4000 Type II Silver None

C0820-FL-120W-40K-N31-S-P-N 93022 120 120-277 VAC 11340 4000 Type II Silver Photo Censor

C0820-FL-120W-40K-N31-W-N-N 93023 120 120-277 VAC 11340 4000 Type II White None

>>Continued on page 13

Flood Light

Visit our website for the most current specs: eiko.com 13

LED

LitespanLED® 120W Flood Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-FL-120W-40K-N31-W-P-N 93024 120 120-277 VAC 11340 4000 Type II White Photo Censor

C0820-FL-120W-50K-N31-BL-N-N 93025 120 120-277 VAC 12600 5000 Type II Black None

C0820-FL-120W-50K-N31-BL-P-N 93026 120 120-277 VAC 12600 5000 Type II Black Photo Censor

C0820-FL-120W-50K-N31-BR-N-N 93027 120 120-277 VAC 12600 5000 Type II Bronze None

C0820-FL-120W-50K-N31-BR-P-N 93028 120 120-277 VAC 12600 5000 Type II Bronze Photo Censor

C0820-FL-120W-50K-N31-S-N-N 93029 120 120-277 VAC 12600 5000 Type II Silver None

C0820-FL-120W-50K-N31-S-P-N 93030 120 120-277 VAC 12600 5000 Type II Silver Photo Censor

C0820-FL-120W-50K-N31-W-N-N 93031 120 120-277 VAC 12600 5000 Type II White None

C0820-FL-120W-50K-N31-W-P-N 93032 120 120-277 VAC 12600 5000 Type II White Photo Censor

LitespanLED® 160W Flood Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-FL-160W-40K-N31-BL-N-N 93033 160 120-277 VAC 15840 4000 Type II Black None

C0820-FL-160W-40K-N31-BL-P-N 93034 160 120-277 VAC 15840 4000 Type II Black Photo Censor

C0820-FL-160W-40K-N31-BR-N-N 93035 160 120-277 VAC 15840 4000 Type II Bronze None

C0820-FL-160W-40K-N31-BR-P-N 93036 160 120-277 VAC 15840 4000 Type II Bronze Photo Censor

C0820-FL-160W-40K-N31-S-N-N 93037 160 120-277 VAC 15840 4000 Type II Silver None

C0820-FL-160W-40K-N31-S-P-N 93038 160 120-277 VAC 15840 4000 Type II Silver Photo Censor

C0820-FL-160W-40K-N31-W-N-N 93039 160 120-277 VAC 15840 4000 Type II White None

C0820-FL-160W-40K-N31-W-P-N 93040 160 120-277 VAC 15840 4000 Type II White Photo Censor

C0820-FL-160W-50K-N31-BL-N-N 93041 160 120-277 VAC 16800 5000 Type II Black None

C0820-FL-160W-50K-N31-BL-P-N 93042 160 120-277 VAC 16800 5000 Type II Black Photo Censor

C0820-FL-160W-50K-N31-BR-N-N 93043 160 120-277 VAC 16800 5000 Type II Bronze None

C0820-FL-160W-50K-N31-BR-P-N 93044 160 120-277 VAC 16800 5000 Type II Bronze Photo Censor

C0820-FL-160W-50K-N31-S-N-N 93045 160 120-277 VAC 16800 5000 Type II Silver None

C0820-FL-160W-50K-N31-S-P-N 93046 160 120-277 VAC 16800 5000 Type II Silver Photo Censor

C0820-FL-160W-50K-N31-W-N-N 93047 160 120-277 VAC 16800 5000 Type II White None

C0820-FL-160W-50K-N31-W-P-N 93048 160 120-277 VAC 16800 5000 Type II White Photo Censor

LitespanLED® 200W Flood Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-FL-200W-40K-N31-BL-N-N 93049 200 120-277 VAC 16193 4000 Type II Black None

C0820-FL-200W-40K-N31-BL-P-N 93050 200 120-277 VAC 16193 4000 Type II Black Photo Censor

C0820-FL-200W-40K-N31-BR-N-N 93051 200 120-277 VAC 16193 4000 Type II Bronze None

C0820-FL-200W-40K-N31-BR-P-N 93052 200 120-277 VAC 16193 4000 Type II Bronze Photo Censor

C0820-FL-200W-40K-N31-S-N-N 93053 200 120-277 VAC 16193 4000 Type II Silver None

C0820-FL-200W-40K-N31-S-P-N 93054 200 120-277 VAC 16193 4000 Type II Silver Photo Censor

C0820-FL-200W-40K-N31-W-N-N 93055 200 120-277 VAC 16193 4000 Type II White None

C0820-FL-200W-40K-N31-W-P-N 93056 200 120-277 VAC 16193 4000 Type II White Photo Censor

C0820-FL-200W-50K-N31-BL-N-N 93057 200 120-277 VAC 21000 5000 Type II Black None

C0820-FL-200W-50K-N31-BL-P-N 93058 200 120-277 VAC 21000 5000 Type II Black Photo Censor

C0820-FL-200W-50K-N31-BR-N-N 93059 200 120-277 VAC 21000 5000 Type II Bronze None

C0820-FL-200W-50K-N31-BR-P-N 93060 200 120-277 VAC 21000 5000 Type II Bronze Photo Censor

C0820-FL-200W-50K-N31-S-N-N 93061 200 120-277 VAC 21000 5000 Type II Silver None

C0820-FL-200W-50K-N31-S-P-N 93062 200 120-277 VAC 21000 5000 Type II Silver Photo Censor

>>Continued on page 14

Flood Light

Visit our website for the most current specs: eiko.com

LED

LitespanLED® 200W Flood Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-FL-200W-50K-N31-W-N-N 93063 200 120-277 VAC 21000 5000 Type II White None

C0820-FL-200W-50K-N31-W-P-N 93064 200 120-277 VAC 21000 5000 Type II White Photo Censor

LitespanLED® 240W Flood Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-FL-240W-40K-N31-BL-N-N 93065 240 120-277 VAC 22680 4000 Type II Black None

C0820-FL-240W-40K-N31-BL-P-N 93066 240 120-277 VAC 22680 4000 Type II Black Photo Censor

C0820-FL-240W-40K-N31-BR-N-N 93067 240 120-277 VAC 22680 4000 Type II Bronze None

C0820-FL-240W-40K-N31-BR-P-N 93068 240 120-277 VAC 22680 4000 Type II Bronze Photo Censor

C0820-FL-240W-40K-N31-S-N-N 93069 240 120-277 VAC 22680 4000 Type II Silver None

C0820-FL-240W-40K-N31-S-P-N 93070 240 120-277 VAC 22680 4000 Type II Silver Photo Censor

C0820-FL-240W-40K-N31-W-N-N 93071 240 120-277 VAC 22680 4000 Type II White None

C0820-FL-240W-40K-N31-W-P-N 93072 240 120-277 VAC 22680 4000 Type II White Photo Censor

C0820-FL-240W-50K-N31-BL-N-N 93073 240 120-277 VAC 25200 5000 Type II Black None

C0820-FL-240W-50K-N31-BL-P-N 93074 240 120-277 VAC 25200 5000 Type II Black Photo Censor

C0820-FL-240W-50K-N31-BR-N-N 93075 240 120-277 VAC 25200 5000 Type II Bronze None

C0820-FL-240W-50K-N31-BR-P-N 93076 240 120-277 VAC 25200 5000 Type II Bronze Photo Censor

C0820-FL-240W-50K-N31-S-N-N 93077 240 120-277 VAC 25200 5000 Type II Silver None

C0820-FL-240W-50K-N31-S-P-N 93078 240 120-277 VAC 25200 5000 Type II Silver Photo Censor

C0820-FL-240W-50K-N31-W-N-N 93079 240 120-277 VAC 25200 5000 Type II White None

C0820-FL-240W-50K-N31-W-P-N 93080 240 120-277 VAC 25200 5000 Type II White Photo Censor

LitespanLED® 90W High Bay

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-HB-90W-40K-N39-BR-N-N 93189 90 120-277 VAC 7882 4000 Type V (Wide) Bronze None

C0820-HB-90W-40K-N39-S-N-N 93190 90 120-277 VAC 7882 4000 Type V (Wide) Silver None

C0820-HB-90W-40K-N39-W-N-N 93191 90 120-277 VAC 7882 4000 Type V (Wide) White None

C0820-HB-90W-40K-N40-BR-N-N 93192 90 120-277 VAC 7872 4000 Type V (Narrow) Bronze None

C0820-HB-90W-40K-N40-S-N-N 93193 90 120-277 VAC 7872 4000 Type V (Narrow) Silver None

C0820-HB-90W-40K-N40-W-N-N 93194 90 120-277 VAC 7872 4000 Type V (Narrow) White None

C0820-HB-90W-50K-N39-BR-N-N 93195 90 120-277 VAC 8475 5000 Type V (Wide) Bronze None

C0820-HB-90W-50K-N39-S-N-N 93196 90 120-277 VAC 8475 5000 Type V (Wide) Silver None

C0820-HB-90W-50K-N39-W-N-N 93197 90 120-277 VAC 8475 5000 Type V (Wide) White None

C0820-HB-90W-50K-N40-BR-N-N 93198 90 120-277 VAC 8464 5000 Type V (Narrow) Bronze None

C0820-HB-90W-50K-N40-S-N-N 93199 90 120-277 VAC 8464 5000 Type V (Narrow) Silver None

C0820-HB-90W-50K-N40-W-N-N 93200 90 120-277 VAC 8464 5000 Type V (Narrow) White None

LitespanLED® 120W High Bay

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-HB-120W-40K-N39-BR-N-N 93129 120 120-277 VAC 10170 4000 Type V (Wide) Bronze None

C0820-HB-120W-40K-N39-S-N-N 93130 120 120-277 VAC 10170 4000 Type V (Wide) Silver None

C0820-HB-120W-40K-N39-W-N-N 93131 120 120-277 VAC 10170 4000 Type V (Wide) White None

C0820-HB-120W-40K-N40-BR-N-N 93132 120 120-277 VAC 10162 4000 Type V (Narrow) Bronze None

C0820-HB-120W-40K-N40-S-N-N 93133 120 120-277 VAC 10162 4000 Type V (Narrow) Silver None

C0820-HB-120W-40K-N40-W-N-N 93134 120 120-277 VAC 10162 4000 Type V (Narrow) White None

>>Continued on page 15

Flood Light High Bay

Visit our website for the most current specs: eiko.com 15

LED

LitespanLED® 120W High Bay

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-HB-120W-50K-N39-BR-N-N 93135 120 120-277 VAC 10936 5000 Type V (Wide) Bronze None

C0820-HB-120W-50K-N39-S-N-N 93136 120 120-277 VAC 10936 5000 Type V (Wide) Silver None

C0820-HB-120W-50K-N39-W-N-N 93137 120 120-277 VAC 10936 5000 Type V (Wide) White None

C0820-HB-120W-50K-N40-BR-N-N 93138 120 120-277 VAC 10927 5000 Type V (Narrow) Bronze None

C0820-HB-120W-50K-N40-S-N-N 93139 120 120-277 VAC 10927 5000 Type V (Narrow) Silver None

C0820-HB-120W-50K-N40-W-N-N 93140 120 120-277 VAC 10927 5000 Type V (Narrow) White None

LitespanLED® 130W High Bay

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-HB-130W-40K-N39-BR-N-N 93141 130 120-277 VAC 12870 4000 Type V (Wide) Bronze None

C0820-HB-130W-40K-N39-S-N-N 93142 130 120-277 VAC 12870 4000 Type V (Wide) Silver None

C0820-HB-130W-40K-N39-W-N-N 93143 130 120-277 VAC 12870 4000 Type V (Wide) White None

C0820-HB-130W-40K-N40-BR-N-N 93144 130 120-277 VAC 12870 4000 Type V (Narrow) Bronze None

C0820-HB-130W-40K-N40-S-N-N 93145 130 120-277 VAC 12870 4000 Type V (Narrow) Silver None

C0820-HB-130W-40K-N40-W-N-N 93146 130 120-277 VAC 12870 4000 Type V (Narrow) White None

C0820-HB-130W-50K-N39-BR-N-N 93147 130 120-277 VAC 13650 5000 Type V (Wide) Bronze None

C0820-HB-130W-50K-N39-S-N-N 93148 130 120-277 VAC 13650 5000 Type V (Wide) Silver None

C0820-HB-130W-50K-N39-W-N-N 93149 130 120-277 VAC 13650 5000 Type V (Wide) White None

C0820-HB-130W-50K-N40-BR-N-N 93150 130 120-277 VAC 13650 5000 Type V (Narrow) Bronze None

C0820-HB-130W-50K-N40-S-N-N 93151 130 120-277 VAC 13650 5000 Type V (Narrow) Silver None

C0820-HB-130W-50K-N40-W-N-N 93152 130 120-277 VAC 13650 5000 Type V (Narrow) White None

LitespanLED® 150W High Bay

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-HB-150W-27K-N39-BL-D-U 08277 150 120-277 VAC 2700 Type V (Wide) Black 0-10V Dimming

C0820-HB-150W-50K-N31-W-N-U 08216 150 120-277 VAC 5000 Type V (Narrow) White None

LitespanLED® 160W High Bay

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-HB-160W-27K-N39-BL-D-U 08281 160 120-277 VAC 2700 Type V (Wide) Black 0-10V Dimming

C0820-HB-160W-27K-N39-BL-DMX-U 08278 160 120-277 VAC 2700 Type V (Wide) Black

C0820-HB-160W-40K-N39-BR-N-N 93153 160 120-277 VAC 13484 4000 Type V (Wide) Bronze None

C0820-HB-160W-40K-N39-S-N-N 93154 160 120-277 VAC 13484 4000 Type V (Wide) Silver None

C0820-HB-160W-40K-N39-W-N-N 93155 160 120-277 VAC 13484 4000 Type V (Wide) White None

C0820-HB-160W-40K-N40-BR-N-N 93156 160 120-277 VAC 13474 4000 Type V (Narrow) Bronze None

C0820-HB-160W-40K-N40-S-N-N 93157 160 120-277 VAC 13474 4000 Type V (Narrow) Silver None

C0820-HB-160W-40K-N40-W-N-N 93158 160 120-277 VAC 13474 4000 Type V (Narrow) White None

C0820-HB-160W-50K-N39-BR-N-N 93159 160 120-277 VAC 14499 5000 Type V (Wide) Bronze None

C0820-HB-160W-50K-N39-S-N-N 93160 160 120-277 VAC 14499 5000 Type V (Wide) Silver None

C0820-HB-160W-50K-N39-W-N-N 93161 160 120-277 VAC 14499 5000 Type V (Wide) White None

C0820-HB-160W-50K-N40-BR-N-N 93162 160 120-277 VAC 14488 5000 Type V (Narrow) Bronze None

C0820-HB-160W-50K-N40-S-N-N 93163 160 120-277 VAC 14488 5000 Type V (Narrow) Silver None

C0820-HB-160W-50K-N40-W-N-N 93164 160 120-277 VAC 14488 5000 Type V (Narrow) White None

High Bay

Visit our website for the most current specs: eiko.com

LED

LitespanLED® 180W High Bay

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-HB-180W-40K-N39-BR-N-N 93165 180 120-277 VAC 15887 4000 Type V (Wide) Bronze None

C0820-HB-180W-40K-N39-S-N-N 93166 180 120-277 VAC 15887 4000 Type V (Wide) Silver None

C0820-HB-180W-40K-N39-W-N-N 93167 180 120-277 VAC 15887 4000 Type V (Wide) White None

C0820-HB-180W-40K-N40-BR-N-N 93168 180 120-277 VAC 15865 4000 Type V (Narrow) Bronze None

C0820-HB-180W-40K-N40-S-N-N 93169 180 120-277 VAC 15865 4000 Type V (Narrow) Silver None

C0820-HB-180W-40K-N40-W-N-N 93170 180 120-277 VAC 15865 4000 Type V (Narrow) White None

C0820-HB-180W-50K-N39-BR-N-N 93171 180 120-277 VAC 17083 5000 Type V (Wide) Bronze None

C0820-HB-180W-50K-N39-S-N-N 93172 180 120-277 VAC 17083 5000 Type V (Wide) Silver None

C0820-HB-180W-50K-N39-W-N-N 93173 180 120-277 VAC 17083 5000 Type V (Wide) White None

C0820-HB-180W-50K-N40-BR-N-N 93174 180 120-277 VAC 17060 5000 Type V (Narrow) Bronze None

C0820-HB-180W-50K-N40-S-N-N 93175 180 120-277 VAC 17060 5000 Type V (Narrow) Silver None

C0820-HB-180W-50K-N40-W-N-N 93176 180 120-277 VAC 17060 5000 Type V (Narrow) White None

LitespanLED® 240W High Bay

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-HB-240W-40K-N39-BR-N-N 93177 240 120-277 VAC 20400 4000 Type V (Wide) Bronze None

C0820-HB-240W-40K-N39-S-N-N 93178 240 120-277 VAC 20400 4000 Type V (Wide) Silver None

C0820-HB-240W-40K-N39-W-N-N 93179 240 120-277 VAC 20400 4000 Type V (Wide) White None

C0820-HB-240W-40K-N40-BR-N-N 93180 240 120-277 VAC 20376 4000 Type V (Narrow) Bronze None

C0820-HB-240W-40K-N40-S-N-N 93181 240 120-277 VAC 20376 4000 Type V (Narrow) Silver None

C0820-HB-240W-40K-N40-W-N-N 93182 240 120-277 VAC 20376 4000 Type V (Narrow) White None

C0820-HB-240W-50K-N39-BR-N-N 93183 240 120-277 VAC 21935 5000 Type V (Wide) Bronze None

C0820-HB-240W-50K-N39-S-N-N 93184 240 120-277 VAC 21935 5000 Type V (Wide) Silver None

C0820-HB-240W-50K-N39-W-N-N 93185 240 120-277 VAC 21935 5000 Type V (Wide) White None

C0820-HB-240W-50K-N40-BR-N-N 93186 240 120-277 VAC 21910 5000 Type V (Narrow) Bronze None

C0820-HB-240W-50K-N40-S-N-N 93187 240 120-277 VAC 21910 5000 Type V (Narrow) Silver None

C0820-HB-240W-50K-N40-W-N-N 93188 240 120-277 VAC 21910 5000 Type V (Narrow) White None

LitespanLED® 40W Parkade Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-PK-40W-27K-N18-BR-N-N 93216 40 120-277 VAC 3640 2700 Type V (Square) Bronze None

C0820-PK-40W-27K-N18-S-N-N 93217 40 120-277 VAC 3640 2700 Type V (Square) Silver None

C0820-PK-40W-27K-N18-W-N-N 93218 40 120-277 VAC 3640 2700 Type V (Square) White None

C0820-PK-40W-40K-N18-BR-N-N 93219 40 120-277 VAC 3960 4000 Type V (Square) Bronze None

C0820-PK-40W-40K-N18-S-N-N 93220 40 120-277 VAC 3960 4000 Type V (Square) Silver None

C0820-PK-40W-40K-N18-W-N-N 93221 40 120-277 VAC 3960 4000 Type V (Square) White None

C0820-PK-40W-50K-N18-BR-N-N 93222 40 120-277 VAC 4200 5000 Type V (Square) Bronze None

C0820-PK-40W-50K-N18-S-N-N 93223 40 120-277 VAC 4200 5000 Type V (Square) Silver None

C0820-PK-40W-50K-N18-W-N-N 93224 40 120-277 VAC 4200 5000 Type V (Square) White None

LitespanLED® 50W Parkade Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-PK-50W-27K-N18-BR-N-N 93225 50 120-277 VAC 4550 2700 Type V (Square) Bronze None

C0820-PK-50W-27K-N18-S-N-N 93226 50 120-277 VAC 4550 2700 Type V (Square) Silver None

C0820-PK-50W-27K-N18-W-N-N 93227 50 120-277 VAC 4550 2700 Type V (Square) White None

>>Continued on page 17

High Bay Parkade Light

Visit our website for the most current specs: eiko.com 17

LED

LitespanLED® 50W Parkade Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-PK-50W-40K-N18-BR-N-N 93228 50 120-277 VAC 4428 4000 Type V (Square) Bronze None

C0820-PK-50W-40K-N18-S-N-N 93229 50 120-277 VAC 4428 4000 Type V (Square) Silver None

C0820-PK-50W-40K-N18-W-N-N 93230 50 120-277 VAC 4428 4000 Type V (Square) White None

C0820-PK-50W-50K-N18-BR-N-N 93231 50 120-277 VAC 5250 5000 Type V (Square) Bronze None

C0820-PK-50W-50K-N18-S-N-N 93232 50 120-277 VAC 5250 5000 Type V (Square) Silver None

C0820-PK-50W-50K-N18-W-N-N 93233 50 120-277 VAC 5250 5000 Type V (Square) White None

LitespanLED® 80W Parkade Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-PK-80W-27K-N18-BR-N-N 93234 80 120-277 VAC 7820 2700 Type V (Square) Bronze None

C0820-PK-80W-27K-N18-S-N-N 93235 80 120-277 VAC 7820 2700 Type V (Square) Silver None

C0820-PK-80W-27K-N18-W-N-N 93236 80 120-277 VAC 7820 2700 Type V (Square) White None

C0820-PK-80W-40K-N18-BR-N-N 93237 80 120-277 VAC 7085 4000 Type V (Square) Bronze None

C0820-PK-80W-40K-N18-S-N-N 93238 80 120-277 VAC 7085 4000 Type V (Square) Silver None

C0820-PK-80W-40K-N18-W-N-N 93239 80 120-277 VAC 7085 4000 Type V (Square) White None

C0820-PK-80W-50K-N18-BR-N-N 93240 80 120-277 VAC 8400 5000 Type V (Square) Bronze None

C0820-PK-80W-50K-N18-S-N-N 93241 80 120-277 VAC 8400 5000 Type V (Square) Silver None

C0820-PK-80W-50K-N18-W-N-N 93242 80 120-277 VAC 8400 5000 Type V (Square) White None

LitespanLED® Plate Downlight

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-LP1-50W-27K-N40-W-D-U 08079 50 120-277 VAC 2700 Type V (Narrow) White 0-10V Dimming

C0820-LP1-50W-35K-N40-W-D-U 08078 50 120-277 VAC 3500 Type V (Narrow) White 0-10V Dimming

C0820-LP1-50W-40K-N39-W-N-U 08184 50 120-277 VAC 4000 Type V White None

C0820-LP1-50W-40K-N40-W-D-U 08077 50 120-277 VAC 4000 Type V (Narrow) White 0-10V Dimming

C0820-LP1-50W-50K-N40-W-D-U 08076 50 120-277 VAC 5000 Type V (Narrow) White 0-10V Dimming

C0820-LP3-100W-50K-N39-W-N-U 08120 100 120-277 VAC 5000 Type V White None

C0820-LP3-120W-40K-N39-W-N-U 08188 120 120-277 VAC 4000 Type V White None

C0820-LP3-120W-40K-N40-W-D-U 08087 120 120-277 VAC 4000 Type V (Narrow) White 0-10V Dimming

C0820-LP3-120W-50K-N18-W-N-U 08098 120 120-277 VAC 5000 Type V (Wide) White None

C0820-LP3-120W-50K-N39-W-N-U 08103 120 120-277 VAC 5000 Type V White None

C0820-LP3-120W-50K-N40-W-N-U 08104 120 120-277 VAC 5000 Type V (Narrow) White None

LitespanLED® 30W Post-Top LED Replacement Lamp

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-PT-30W-27K-W 93243 30 120-277 VAC 2730 2700 Cone White

C0820-PT-30W-30K-W 93244 30 120-277 VAC 2775 3000 Cone White

C0820-PT-30W-40K-W 93245 30 120-277 VAC 2970 4000 Cone White

C0820-PT-30W-50K-W 93246 30 120-277 VAC 3150 5000 Cone White

LitespanLED® 45W Post-Top LED Replacement Lamp

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-PT-45W-27K-W 93247 45 120-277 VAC 4095 2700 Cone White

C0820-PT-45W-30K-W 93248 45 120-277 VAC 4275 3000 Cone White

C0820-PT-45W-40K-W 93249 45 120-277 VAC 4455 4000 Cone White

C0820-PT-45W-50K-W 93250 45 120-277 VAC 4725 5000 Cone White

Post-TopPlate Downlight Wallpack Light

Visit our website for the most current specs: eiko.com

LED

LitespanLED® 20W Wallpack Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-WP-20W-40K-N19-BL-N-N 93257 20 120-277 VAC 1980 4000 Asymmetric Black None

C0820-WP-20W-40K-N19-BL-P-N 93258 20 120-277 VAC 1980 4000 Asymmetric Black Photo Censor

C0820-WP-20W-40K-N19-BR-N-N 93259 20 120-277 VAC 1980 4000 Asymmetric Bronze None

C0820-WP-20W-40K-N19-BR-P-N 93260 20 120-277 VAC 1980 4000 Asymmetric Bronze Photo Censor

C0820-WP-20W-40K-N19-S-N-N 93261 20 120-277 VAC 1980 4000 Asymmetric Silver None

C0820-WP-20W-40K-N19-S-P-N 93262 20 120-277 VAC 1980 4000 Asymmetric Silver Photo Censor

C0820-WP-20W-40K-N19-W-N-N 93263 20 120-277 VAC 1980 4000 Asymmetric White None

C0820-WP-20W-40K-N19-W-P-N 93264 20 120-277 VAC 1980 4000 Asymmetric White Photo Censor

C0820-WP-20W-50K-N19-BL-N-N 93265 20 120-277 VAC 2100 5000 Asymmetric Black None

C0820-WP-20W-50K-N19-BL-P-N 93266 20 120-277 VAC 2100 5000 Asymmetric Black Photo Censor

C0820-WP-20W-50K-N19-BR-N-N 93267 20 120-277 VAC 2100 5000 Asymmetric Bronze None

C0820-WP-20W-50K-N19-BR-P-N 93268 20 120-277 VAC 2100 5000 Asymmetric Bronze Photo Censor

C0820-WP-20W-50K-N19-S-N-N 93269 20 120-277 VAC 2100 5000 Asymmetric Silver None

C0820-WP-20W-50K-N19-S-P-N 93270 20 120-277 VAC 2100 5000 Asymmetric Silver Photo Censor

C0820-WP-20W-50K-N19-W-N-N 93271 20 120-277 VAC 2100 5000 Asymmetric White None

C0820-WP-20W-50K-N19-W-P-N 93272 20 120-277 VAC 2100 5000 Asymmetric White Photo Censor

LitespanLED® 30W Wallpack Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-WP-30W-40K-N19-BL-N-N 93273 30 120-277 VAC 2657 4000 Asymmetric Black None

C0820-WP-30W-40K-N19-BL-P-N 93274 30 120-277 VAC 2657 4000 Asymmetric Black Photo Censor

C0820-WP-30W-40K-N19-BR-N-N 93275 30 120-277 VAC 2657 4000 Asymmetric Bronze None

C0820-WP-30W-40K-N19-BR-P-N 93276 30 120-277 VAC 2657 4000 Asymmetric Bronze Photo Censor

C0820-WP-30W-40K-N19-S-N-N 93277 30 120-277 VAC 2657 4000 Asymmetric Silver None

C0820-WP-30W-40K-N19-S-P-N 93278 30 120-277 VAC 2657 4000 Asymmetric Silver Photo Censor

C0820-WP-30W-40K-N19-W-N-N 93279 30 120-277 VAC 2657 4000 Asymmetric White None

C0820-WP-30W-40K-N19-W-P-N 93280 30 120-277 VAC 2657 4000 Asymmetric White Photo Censor

C0820-WP-30W-50K-N19-BL-N-N 93281 30 120-277 VAC 2952 5000 Asymmetric Black None

C0820-WP-30W-50K-N19-BL-P-N 93282 30 120-277 VAC 2952 5000 Asymmetric Black Photo Censor

C0820-WP-30W-50K-N19-BR-N-N 93283 30 120-277 VAC 2952 5000 Asymmetric Bronze None

C0820-WP-30W-50K-N19-BR-P-N 93284 30 120-277 VAC 2952 5000 Asymmetric Bronze Photo Censor

C0820-WP-30W-50K-N19-S-N-N 93285 30 120-277 VAC 2952 5000 Asymmetric Silver None

C0820-WP-30W-50K-N19-S-P-N 93286 30 120-277 VAC 2952 5000 Asymmetric Silver Photo Censor

C0820-WP-30W-50K-N19-W-N-N 93287 30 120-277 VAC 2952 5000 Asymmetric White None

C0820-WP-30W-50K-N19-W-P-N 93288 30 120-277 VAC 2952 5000 Asymmetric White Photo Censor

LitespanLED® 40W Wallpack Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-WP-40W-40K-N19-BL-N-N 93289 40 120-277 VAC 3283 4000 Asymmetric Black None

C0820-WP-40W-40K-N19-BL-P-N 93290 40 120-277 VAC 3283 4000 Asymmetric Black Photo Censor

C0820-WP-40W-40K-N19-BR-N-N 93291 40 120-277 VAC 3283 4000 Asymmetric Bronze None

C0820-WP-40W-40K-N19-BR-P-N 93292 40 120-277 VAC 3283 4000 Asymmetric Bronze Photo Censor

C0820-WP-40W-40K-N19-S-N-N 93293 40 120-277 VAC 3283 4000 Asymmetric Silver None

C0820-WP-40W-40K-N19-S-P-N 93294 40 120-277 VAC 3283 4000 Asymmetric Silver Photo Censor

C0820-WP-40W-40K-N19-W-N-N 93295 40 120-277 VAC 3283 4000 Asymmetric White None

>>Continued on page 19

Wallpack Light

Visit our website for the most current specs: eiko.com 19

LED

LitespanLED® 40W Wallpack Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-WP-40W-40K-N19-W-P-N 93296 40 120-277 VAC 3283 4000 Asymmetric White Photo Censor

C0820-WP-40W-50K-N19-BL-N-N 93297 40 120-277 VAC 3936 5000 Asymmetric Black None

C0820-WP-40W-50K-N19-BL-P-N 93298 40 120-277 VAC 3936 5000 Asymmetric Black Photo Censor

C0820-WP-40W-50K-N19-BR-N-N 93299 40 120-277 VAC 3936 5000 Asymmetric Bronze None

C0820-WP-40W-50K-N19-BR-P-N 93300 40 120-277 VAC 3936 5000 Asymmetric Bronze Photo Censor

C0820-WP-40W-50K-N19-S-N-N 93301 40 120-277 VAC 3936 5000 Asymmetric Silver None

C0820-WP-40W-50K-N19-S-P-N 93302 40 120-277 VAC 3936 5000 Asymmetric Silver Photo Censor

C0820-WP-40W-50K-N19-W-N-N 93303 40 120-277 VAC 3936 5000 Asymmetric White None

C0820-WP-40W-50K-N19-W-P-N 93304 40 120-277 VAC 3936 5000 Asymmetric White Photo Censor

LitespanLED® 48W Wallpack Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-WP-48W-40K-N19-BL-N-N 93305 48 120-277 VAC 4250 4000 Asymmetric Black None

C0820-WP-48W-40K-N19-BL-P-N 93306 48 120-277 VAC 4250 4000 Asymmetric Black Photo Censor

C0820-WP-48W-40K-N19-BR-N-N 93307 48 120-277 VAC 4250 4000 Asymmetric Bronze None

C0820-WP-48W-40K-N19-BR-P-N 93308 48 120-277 VAC 4250 4000 Asymmetric Bronze Photo Censor

C0820-WP-48W-40K-N19-S-N-N 93309 48 120-277 VAC 4250 4000 Asymmetric Silver None

C0820-WP-48W-40K-N19-S-P-N 93310 48 120-277 VAC 4250 4000 Asymmetric Silver Photo Censor

C0820-WP-48W-40K-N19-W-N-N 93311 48 120-277 VAC 4250 4000 Asymmetric White None

C0820-WP-48W-40K-N19-W-P-N 93312 48 120-277 VAC 4250 4000 Asymmetric White Photo Censor

C0820-WP-48W-50K-N19-BL-N-N 93313 48 120-277 VAC 4723 5000 Asymmetric Black None

C0820-WP-48W-50K-N19-BL-P-N 93314 48 120-277 VAC 4723 5000 Asymmetric Black Photo Censor

C0820-WP-48W-50K-N19-BR-N-N 93315 48 120-277 VAC 4723 5000 Asymmetric Bronze None

C0820-WP-48W-50K-N19-BR-P-N 93316 48 120-277 VAC 4723 5000 Asymmetric Bronze Photo Censor

C0820-WP-48W-50K-N19-S-N-N 93317 48 120-277 VAC 4723 5000 Asymmetric Silver None

C0820-WP-48W-50K-N19-S-P-N 93318 48 120-277 VAC 4723 5000 Asymmetric Silver Photo Censor

C0820-WP-48W-50K-N19-W-N-N 93319 48 120-277 VAC 4723 5000 Asymmetric White None

C0820-WP-48W-50K-N19-W-P-N 93320 48 120-277 VAC 4723 5000 Asymmetric White Photo Censor

LitespanLED® 60W Wallpack Light

Ordering Code Barcode Watts Volts Lumens CT°K Lens Finish Options

C0820-WP-60W-40K-N19-BL-N-N 93321 60 120-277 VAC 5224 4000 Asymmetric Black None

C0820-WP-60W-40K-N19-BL-P-N 93322 60 120-277 VAC 5224 4000 Asymmetric Black Photo Censor

C0820-WP-60W-40K-N19-BR-N-N 93323 60 120-277 VAC 5224 4000 Asymmetric Bronze None

C0820-WP-60W-40K-N19-BR-P-N 93324 60 120-277 VAC 5224 4000 Asymmetric Bronze Photo Censor

C0820-WP-60W-40K-N19-S-N-N 93325 60 120-277 VAC 5224 4000 Asymmetric Silver None

C0820-WP-60W-40K-N19-S-P-N 93326 60 120-277 VAC 5224 4000 Asymmetric Silver Photo Censor

C0820-WP-60W-40K-N19-W-N-N 93327 60 120-277 VAC 5224 4000 Asymmetric White None

C0820-WP-60W-40K-N19-W-P-N 93328 60 120-277 VAC 5224 4000 Asymmetric White Photo Censor

C0820-WP-60W-50K-N19-BL-N-N 93329 60 120-277 VAC 5804 5000 Asymmetric Black None

C0820-WP-60W-50K-N19-BL-P-N 93330 60 120-277 VAC 5804 5000 Asymmetric Black Photo Censor

C0820-WP-60W-50K-N19-BR-N-N 93331 60 120-277 VAC 5804 5000 Asymmetric Bronze None

C0820-WP-60W-50K-N19-BR-P-N 93332 60 120-277 VAC 5804 5000 Asymmetric Bronze Photo Censor

C0820-WP-60W-50K-N19-S-N-N 93333 60 120-277 VAC 5804 5000 Asymmetric Silver None

C0820-WP-60W-50K-N19-S-P-N 93334 60 120-277 VAC 5804 5000 Asymmetric Silver Photo Censor

C0820-WP-60W-50K-N19-W-N-N 93335 60 120-277 VAC 5804 5000 Asymmetric White None

C0820-WP-60W-50K-N19-W-P-N 93336 60 120-277 VAC 5804 5000 Asymmetric White Photo Censor

Visit our website for the most current specs: eiko.com

LED

LitespanLED® GEN 4 A19 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED10WA19/300/840K-GU24-DIM-G4 90086 10 120 A19 GU24 800

LED10WA19/300/840K-DIM-G4 90087 10 120 A19 E26 800

LED10WA19/300/830K-GU24-DIM-G4 90088 10 120 A19 GU24 800

LED10WA19/300/830K-DIM-G4 90089 10 120 A19 E26 800

LED10WA19/300/827K-GU24-DIM-G4 90090 10 120 A19 GU24 800

LED10WA19/300/827K-DIM-G4 90091 10 120 A19 E26 800

LED12WA19/300/827K-DIM-G4 90082 12 120 A19 E26 1100 25,000

LED12WA19/300/827K-GU24-DIM-G4 90081 12 120 A19 GU24 1100

LED12WA19/300/830K-DIM-G4 90080 12 120 A19 E26 1100

LED12WA19/300/830K-GU24-DIM-G4 90079 12 120 A19 GU24 1100

LED12WA19/300/840K-DIM-G4 90078 12 120 A19 E26 1100

LED12WA19/300/840K-GU24-DIM-G4 90077 12 120 A19 GU24 1100

LED12WA19/300/927K-DIM-G4 90076 12 120 A19 E26 800

LED12WA19/300/927K-GU24-DIM-G4 90075 12 120 A19 GU24 800

LED12WA19/300/930K-DIM-G4 90074 12 120 A19 E26 800

LED12WA19/300/930K-GU24-DIM-G4 90073 12 120 A19 GU24 800

LED Replacement Lamps

EiKO’s extended line of LitespanLED® Linear and Replacement Lamps truly represents the next generation in lighting,

saving you time, money, and energy through the use of quality Cree chips for long life and superior lumen and color main-

tenance. Our lamps also feature instant, ﬂicker-free start-up and no off-state power draw.

LitespanLED® GEN4 A19 Advantage™ GEN4 A19 Dimmable Advantage™ GEN4 A19 Non-Dimmable

Visit our website for the most current specs: eiko.com 21

LED

GEN4 BR30 GEN4 BR40

Advantage™ GEN 4 A19 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED7WA19/240/827K-DIM-G4A 90035 7 120 A19 E26 400

LED7WA19/240/827K-G4A 90034 7 120 A19 E26 400

LED7WA19/240/830K-DIM-G4A 90033 7 120 A19 E26 420 25,000

LED7WA19/240/830K-G4A 90032 7 120 A19 E26 420

LED7WA19/240/840K-DIM-G4A 90031 7 120 A19 E26 420

LED7WA19/240/840K-G4A 90030 7 120 A19 E26 420

LED7WA19/240/850K-DIM-G4A 90029 7 120 A19 E26 420

LED10WA19/240/827K-DIM-G4A 10 120 A19 E26 700

LED10WA19/240/830K-DIM-G4A 10 120 A19 E26 750

LED10WA19/240/840K-DIM-G4A 10 120 A19 E26 750

LED10WA19/240/850K-DIM-G4A 90092 10 120 A19 E26 750

LED10WA19/240/827K-G4A 10 120 A19 E26 750

LED10WA19/240/830K-G4A 10 120 A19 E26 750

LED10WA19/240/840K-G4A 10 120 A19 E26 750

LitespanLED® GEN 4 A21 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED17WA21/300/827K-DIM-G4 90053 17 120 A21 E26 1600 25,000

LED17WA21/300/827K-GU24-DIM-G4 90052 17 120 A21 GU24 1600

LED17WA21/300/830K-DIM-G4 90051 17 120 A21 E26 1600

LED17WA21/300/830K-GU24-DIM-G4 90050 17 120 A21 GU24 1600

LED17WA21/300/840K-DIM-G4 90049 17 120 A21 E26 1600

LED17WA21/300/840K-GU24-DIM-G4 90048 17 120 A21 GU24 1600

LitespanLED® GEN 4 BR30 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED11WBR30/827K-DIM-G4 90085 11 120 BR-30 E26 800 25,000

LED11WBR30/830K-DIM-G4 90084 11 120 BR-30 E26 800

LED11WBR30/840K-DIM-G4 90083 11 120 BR-30 E26 800

LED14WBR30/927K-DIM-G4 90063 14 120 BR-30 E26 800

LED14WBR30/930K-DIM-G4 90062 14 120 BR-30 E26 800

LitespanLED® GEN 4 BR40 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED13WBR40/827K-DIM-G4 90066 13 120 BR-40 E26 1000 25,000

LED13WBR40/830K-DIM-G4 90065 13 120 BR-40 E26 1000

LED13WBR40/840K-DIM-G4 90064 13 120 BR-40 E26 1000

LED16WBR40/927K-DIM-G4 90055 16 120 BR-40 E26 1000

LED16WBR40/930K-DIM-G4 90054 16 120 BR-40 E26 1000

LED17WBR40/827K-DIM-G4 90047 17 120 BR-40 E26 1400 25,000

LED17WBR40/830K-DIM-G4 90046 17 120 BR-40 E26 1400

LED17WBR40/840K-DIM-G4 90045 17 120 BR-40 E26 1400

Visit our website for the most current specs: eiko.com

LED

LitespanLED® GEN 4 G25 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED6WG25/827K-DIM-G4 90038 60 120 G25 E26 450 15,000

LED6WG25/830K-DIM-G4 90037 60 120 G25 E26 450

LED6WG25/840K-DIM-G4 90036 60 120 G25 E26 450

LitespanLED® GEN 4 MR-16 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED7WMR16/20/830-DIM-G4 90026 7 12VAC/DC MR-16 GU5.3 450

LED7WMR16/40/830-DIM-G4 90025 7 12VAC/DC MR-16 GU5.3 450

LED7WGU10/20/830-DIM-G4 90028 7 120 MR-16 GU10 450

LED7WGU10/40/830-DIM-G4 90027 7 120 MR-16 GU10 450

LitespanLED® GEN 4 PAR20 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED7WPAR20/FL/827K-DIM-G4A 90024 7 120 PAR20 E26 500

LED7WPAR20/FL/830K-DIM-G4A 90023 7 120 PAR20 E26 500

LED7WPAR20/FL/840K-DIM-G4A 90022 7 120 PAR20 E26 500

Advantage™ GEN 4 PAR20 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED7WPAR20/NFL/827K-DIM-G4A 90021 7 120 PAR20 E26 500

LED7WPAR20/NFL/830K-DIM-G4A 90020 7 120 PAR20 E26 500

LED7WPAR20/NFL/840K-DIM-G4A 90019 7 120 PAR20 E26 500

Advantage™ GEN 4 PAR30 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED12WPAR30/FL/827K-DIM-G4A 90072 12 120 PAR30 E26 800

LED12WPAR30/FL/830K-DIM-G4A 90071 12 120 PAR30 E26 800

LED12WPAR30/FL/840K-DIM-G4A 90070 12 120 PAR30 E26 800

LED12WPAR30/NFL/827K-DIM-G4A 90069 12 120 PAR30 E26 800 25,000

LED12WPAR30/NFL/830K-DIM-G4A 90068 12 120 PAR30 E26 800

LED12WPAR30/NFL/840K-DIM-G4A 90067 12 120 PAR30 E26 800

Advantage™ GEN 4 PAR30SN Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED12WPAR30S/FL/827-DIM-G4A 08553 12 120 PAR30SN E26 800

LED12WPAR30S/FL/830-DIM-G4A 08554 12 120 PAR30SN E26 800

LED12WPAR30S/FL/840-DIM-G4A 08555 12 120 PAR30SN E26 800

LED12WPAR30S/NFL/827-DIM-G4A 08556 12 120 PAR30SN E26 800

LED12WPAR30S/NFL/830-DIM-G4A 08557 12 120 PAR30SN E26 800

LED12WPAR30S/NFL/840-DIM-G4A 08558 12 120 PAR30SN E26 800

GEN4 G25 GEN4 MR16 GEN4 PAR20 GEN4 PAR30

Visit our website for the most current specs: eiko.com 23

LED

GEN4 PAR30SN GEN4 PAR38 GEN4 T8 Linear

Advantage™ GEN 4 PAR38 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED14WPAR38/FL/827K-DIM-G4A 90061 14 120 PAR38 E26 900

LED14WPAR38/FL/830K-DIM-G4A 90060 14 120 PAR38 E26 900

LED14WPAR38/FL/840K-DIM-G4A 90059 14 120 PAR38 E26 900

LED14WPAR38/NFL/827K-DIM-G4A 90058 14 120 PAR38 E26 900 25,000

LED14WPAR38/NFL/830K-DIM-G4A 90057 14 120 PAR38 E26 900

LED14WPAR38/NFL/840K-DIM-G4A 90056 14 120 PAR38 E26 900

LED17WPAR38/FL/827K-DIM-G4A 90044 17 120 PAR38 E26 1300

LED17WPAR38/FL/830K-DIM-G4A 90043 17 120 PAR38 E26 1300

LED17WPAR38/FL/840K-DIM-G4A 90042 17 120 PAR38 E26 1300

LED17WPAR38/NFL/827K-DIM-G4A 90041 17 120 PAR38 E26 1300

LED17WPAR38/NFL/830K-DIM-G4A 90040 17 120 PAR38 E26 1300

LED17WPAR38/NFL/840K-DIM-G4A 90039 17 120 PAR38 E26 1300

LitespanLED® GEN 4 T8 Linear Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED9WT8F/24/835K-G4D 08529 9 120 T8 G13 900 50,000

LED9WT8F/24/840K-G4D 08530 9 120 T8 G13 900 50,000

LED9WT8F/24/850K-G4D 08531 9 120 T8 G13 900 50,000

LED18WT8F/48/835K-G4D 08526 18 120 T8 G13 1800 50,000

LED18WT8F/48/840K-G4D 08527 18 120 T8 G13 1800 50,000

LED18WT8F/48/850K-G4D 08528 18 120 T8 G13 1800 50,000

Advantage™ GEN 4 T8 Linear Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LED9WT8F/24/835K-G4A 08535 9 120 T8 G13 800 25,000

LED9WT8F/24/840K-G4A 08536 9 120 T8 G13 800 25,000

LED9WT8F/24/850K-G4A 08537 9 120 T8 G13 800 25,000

LED18WT8F/48/835K-G4A 08532 18 120 T8 G13 1600 25,000

LED18WT8F/48/840K-G4A 08533 18 120 T8 G13 1600 25,000

LED18WT8F/48/850K-G4A 08534 18 120 T8 G13 1600 25,000

LitespanLED® GEN 3 A19 Replacement Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-8WA19/827-DIM3 07964 8 120 A-19 E26 435 4.25/108 2.28/58 25,000

LEDP-8WA19/830-DIM3 07965 8 120 A-19 E26 450 4.25/108 2.28/58 25,000

LEDP-8WA19/841-DIM3 07966 8 120 A-19 E26 470 4.25/108 2.28/58 25,000

LEDP-8WA19/850-DIM3 08174 8 120 A-19 E26 510 4.25/108 2.28/58 25,000

LEDP-10WA19/827-DIM3 07988 10 120 A-19 E26 800 4.41/112 2.36/60 25,000

LEDP-10WA19/830-DIM3 07989 10 120 A-19 E26 830 4.41/112 2.36/60 25,000

LEDP-10WA19/841-DIM3 07990 10 120 A-19 E26 860 4.41/112 2.36/60 25,000

LEDP-12WA19/827-DIM 07917 12 120 A-19 E26 800 4.409/112 2.36/60 25,000

LEDP-12WA19/830-DIM 07918 12 120 A-19 E26 830 4.409/112 2.36/60 25,000

LEDP-12WA19/841-DIM 08128 12 120 A-19 E26 860 4.409/112 2.36/60 25,000

Visit our website for the most current specs: eiko.com

LED

LitespanLED® GEN3 R20 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-8WR20/827-DIM3 07991 8 120 R-20 E26 500 3.94/100 2.48/63 25,000

LEDP-8WR20/830-DIM3 07992 8 120 R-20 E26 520 3.94/100 2.48/63 35,000

LEDP-8WR20/841-DIM3 07993 8 120 R-20 E26 540 3.94/100 2.48/63 35,000

LitespanLED® GEN 3 R30 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-11WR30/827-DIM 07948 11 120 R-30 E26 750 5.12/130 3.74/95 35,000

LEDP-11WR30/830-DIM 07949 11 120 R-30 E26 750 5.12/130 3.74/95 35,000

LEDP-11WR30/GU24/827-DIM 07950 11 120 R-30 GU24 730 4.49/114 3.74/95 35,000

LEDP-11WR30/GU24/830-DIM 07951 11 120 R-30 GU24 750 4.49/114 3.74/95 35,000

LitespanLED® GEN 3 R40 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-13WR40/827-DIM3 07794 13 120 R-40 E26 850 6.46/164 5.00/127 25,000

LEDP-13WR40/830-DIM3 07983 13 120 R-40 E26 880 6.46/164 5.00/127 35,000

LEDP-13WR40/841-DIM3 07984 13 120 R-40 E26 920 6.46/164 5.00/127 35,000

LEDP-18WR40/827-DIM3 07985 18 120 R-40 E26 1200 6.46/164 5.00/127 25,000

LEDP-18WR40/830-DIM3 07986 18 120 R-40 E26 1230 6.46/164 5.00/127 35,000

LEDP-18WR40/841-DIM3 07987 18 120 R-40 E26 1280 6.46/164 5.00/127 35,000

LitespanLED® GEN 3 B11 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-3WB11/827-DIM 08254 3 120 B-11 E12 160 3.78/96 1.374/34.9 25,000

LEDP-3WB11/830-DIM 08255 3 120 B-11 E12 165 3.78/96 1.374/34.9 25,000

LEDP-5WB11/827-DIM 07925 5 120 B-11 E12 300 4.21/107 1.38/35 25,000

LitespanLED® GEN 3 G25 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-8WG25/827-DIM 07929 8 120 G-25 E26 450 4.25/108 3.15/80 35,000

LEDP-8WG25/830-DIM 07894 8 120 G-25 E26 450 4.25/108 3.15/80 35,000

LitespanLED® GEN 3 T-8 Linear Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-9T8/24/41K 07895 9 120-277VAC T- 8 G13 850 23.81/605 1.10/28 50,000

LEDP-9T8/24/50K 07896 9 120-277VAC T- 8 G13 850 23.81/605 1.10/28 50,000

LEDP-14T8/36/41K 07897 14 120-277VAC T- 8 G13 1100 35.74/908 1.10/28 50,000

LEDP-14T8/36/50K 07898 14 120-277VAC T- 8 G13 1100 35.74/908 1.10/28 50,000

LEDP-18T8/48/30K 07899 18 120-277VAC T- 8 G13 1800 47.75/1213 1.10/28 50,000

LEDP-18T8/48/41K 07900 18 120-277VAC T- 8 G13 1800 47.75/1213 1.10/28 50,000

LEDP-18T8/48/50K 07901 18 120-277VAC T- 8 G13 1800 47.75/1213 1.10/28 50,000

LEDP-22T8/60/41K 07902 22 120-277VAC T- 8 G13 2100 59.55/1513 1.10/28 50,000

LEDP-22T8/60/50K 07903 22 120-277VAC T- 8 G13 2100 59.55/1513 1.10/28 50,000

LEDP-24T8/72/41K 07904 24 120-277VAC T- 8 G13 2300 71.37/1813 1.10/28 50,000

LEDP-24T8/72/50K 07905 24 120-277VAC T- 8 G13 2300 71.37/1813 1.10/28 50,000

GEN3 A19 GEN3 R30 GEN3 R40 GEN3 B11 GEN3 G25GEN3 R20

Visit our website for the most current specs: eiko.com 25

LED

LitespanLED® GEN 3 T-8 U-Bend Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-18T8U6/41K 07906 18 120-277VAC T- 8 G13 1800 22.00/560 1.10/28 50,000

LEDP-18T8U6/50K 07907 18 120-277VAC T- 8 G13 1800 22.00/560 1.10/28 50,000

LitespanLED® GEN 3 MR16 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-6WGU10/830-DIM 07926 6 120 MR16 GU10 370 3.11/79 1.97/50 35,000

LEDP-6WGU10/841-DIM 08178 6 120 MR16 GU10 385 3.11/79 1.97/50 35,000

LEDP-6WMR16/827-DIM 07943 6 12V AC/DC MR16 GU5.3 340 2.40/61 1.97/50 35,000

LEDP-6WMR16/830-DIM 07927 6 12V AC/DC MR16 GU5.3 350 2.40/61 1.97/50 35,000

LEDP-6WMR16/841-DIM 08179 6 12V AC/DC MR16 GU5.3 365 2.40/61 1.97/50 35,000

LitespanLED® GEN 3 PAR16 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-6WPAR16/FL/830-DIM 07908 6 120 PAR 16 E26 370 3.27/83 1.97/50 35,000

LEDP-6WPAR16/FL/841-DIM 07909 6 120 PAR 16 E26 385 3.27/83 1.97/50 35,000

LitespanLED® GEN 3 PAR20 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-7WPAR20/FL/841-DIM 07911 7 120 PAR 20 E26 400 3.34/85 2.48/63 40,000

LEDP-7WPAR20/NFL/827-DIM 07912 7 120 PAR 20 E26 320 3.34/85 2.48/63 40,000

LEDP-7WPAR20/NFL/841-DIM 07913 7 120 PAR 20 E26 350 3.34/85 2.48/63 40,000

LEDP-8WPAR20/FL/827-DIM 07952 8 120 PAR 20 E26 365 3.42/87 2.48/63 35,000

LEDP-8WPAR20/FL/830-DIM 07953 8 120 PAR 20 E26 380 3.42/87 2.48/63 35,000

LEDP-8WPAR20/FL/841-DIM 07954 8 120 PAR 20 E26 395 3.42/87 2.48/63 35,000

LEDP-8WPAR20/NFL/827-DIM 07955 8 120 PAR 20 E26 365 3.42/87 2.48/63 35,000

LEDP-8WPAR20/NFL/830-DIM 07956 8 120 PAR 20 E26 380 3.42/87 2.48/63 35,000

LEDP-8WPAR20/NFL/841-DIM 07957 8 120 PAR 20 E26 395 3.42/87 2.48/63 35,000

LitespanLED® GEN 3 PAR30 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-13WPAR30/FL/827-DIM 07958 13 120 PAR 30 E26 680 4.45/113 3.74/95 35,000

LEDP-13WPAR30/FL/830-DIM 07959 13 120 PAR 30 E26 700 4.45/113 3.74/95 25,000

LEDP-13WPAR30/FL/841-DIM 07960 13 120 PAR 30 E26 730 4.45/113 3.74/95 35,000

LEDP-13WPAR30/NFL/827-DIM 07961 13 120 PAR 30 E26 680 4.45/113 3.74/95 35,000

LEDP-13WPAR30/NFL/830-DIM 07962 13 120 PAR 30 E26 700 4.45/113 3.74/95 35,000

LEDP-13WPAR30/NFL/841-DIM 07963 13 120 PAR 30 E26 730 4.45/113 3.74/95 35,000

LEDP-15WPAR30/NFL/827-DIM 07914 15 120 PAR 30 E26 730 4.65/118 3.74/95 25,000

LEDP-15WPAR30/NFL/830-DIM 07888 15 120 PAR 30 E26 750 4.65/118 3.74/95 25,000

LEDP-15WPAR30SN/FL/830-DIM 08081 15 120 PAR 30 E26 800 3.74/95 3.74/95 25,000

LEDP-15WPAR30SN/FL/841-DIM 08075 15 120 PAR 30 E26 750 3.74/95 3.74/95 40,000

LEDP-15WPAR30SN/NFL/830-DIM 08083 15 120 PAR 30 E26 750 3.74/95 3.74/95 25,000

LEDP-15WPAR30SN/NFL/841-DIM 08084 15 120 PAR 30 E26 750 3.74/95 3.74/95 40,000

GEN3 T8 Linear GEN3 MR16 GEN3 PAR16 GEN3 PAR20 GEN3 PAR30GEN3 T8 U-Bend

Visit our website for the most current specs: eiko.com

LED

LitespanLED® GEN 3 PAR38 Lamps

Ordering Code Barcode Watts Volts Shape Base Lumens MOL in/mm

MOD in/mm

Life

LEDP-20WPAR38/FL/827-DIM 07921 20 120 PAR 38 E26 1150 5.00/127 4.76/121 35,000

LEDP-20WPAR38/FL/830-DIM 07891 20 120 PAR 38 E26 1200 5.00/127 4.76/121 25,000

LEDP-20WPAR38/FL/841-DIM 07922 20 120 PAR 38 E26 1250 5.00/127 4.76/121 35,000

LEDP-20WPAR38/NFL/827-DIM 07923 20 120 PAR 38 E26 1150 5.00/127 4.76/121 35,000

LEDP-20WPAR38/NFL/830-DIM 07890 20 120 PAR 38 E26 1200 5.00/127 4.76/121 35,000

LEDP-20WPAR38/NFL/841-DIM 07924 20 120 PAR 38 E26 1250 5.00/127 4.76/121 35,000

GEN3 PAR30 GEN3 PAR38

Visit our website for the most current specs: eiko.com 27

LED

LED Replacement Lamps > Base Types

E26

Medium Screw

GU5.3

Bi-Pin

E12

Candelabra Screw

GU10

Bi-Pin

G13

Bi-Pin

GU24

Bi-Pin

Visit our website for the most current specs: eiko.com

LED

Miniature Replacement LED Lamps

Ordering Code Barcode Shape Base Emitted Color Life Replaces

LED-12-DCBAY-R 05378 S-8 BAY15d Red 10,000 DC Index Bayonet Base 12V S8 Lamps

LED-12-DCBAY-W 05379 S-8 BAY15d White 10,000 DC Index Bayonet Base 12V S8 Lamps

LED-12-FESTOON-W 05385 Festoon

10mm SV8.5mm White 30,000 10 x 44 Xenon Festoons

LED-12-SCBAY-R 05391 S-8 BA15s Red 10,000 SC Bayonet Base 12V S8 Lamps

LED-12-SCBAY-W 05394 S-8 BA15s White 10,000 SC Bayonet Base 12V S8 Lamps

LED-120-MB-G 02678 T-3 1/4 BA9s Green 30,000 120MB, 120MB-6, 130MB, 8-3995, 949, 967

LED-120-MB-R 02679 T-3 1/4 BA9s Red 30,000 120MB, 120MB-6, 130MB, 8-3995, 949, 967

LED-120-MB-W 02681 T-3 1/4 BA9s White 30,000 120MB, 120MB-6, 130MB, 8-3995, 949, 967

LED-120-MB-Y 02682 T-3 1/4 BA9s Yellow 30,000 120MB, 120MB-6, 130MB, 8-3995, 949, 967

LED-120-PSB-G 02683 T-2 TS5 Green 30,000 120PSB5, 120PSB-Neon

LED-120-PSB-R 02684 T-2 TS5 Red 30,000 120PSB5, 120PSB-Neon

LED-120-PSB-W 02685 T-2 TS5 White 30,000 120PSB5, 120PSB-Neon

LED-120-PSB-Y 02686 T-2 TS5 Yellow 30,000 120PSB5, 120PSB-Neon

LED-14-BA9S-G 02687 T-3 1/4 BA9s Green 30,000 756, 1813, 1815, 1816, 1889, 1891, 1892, 1893

LED-14-BA9S-R 02688 T-3 1/4 BA9s Red 30,000 756, 1813, 1815, 1816, 1889, 1891, 1892, 1893

LED-14-BA9S-W 02689 T-3 1/4 BA9s White 30,000 756, 1813, 1815, 1816, 1889, 1891, 1892, 1893

LED-14-T1.75 WEDGE-W 02691 T-1 3/4

W2.1x4.6d

White 30,000 18, 37, 70, 73, 74

LED-194-R 00346 T-3 1/4

W2.1x9.5d

Red 30,000 T3-1/4 Min Wedge Based Lamps 12/14V

LED-194-W 00345 T-3 1/4

W2.1x9.5d

White 30,000 T3-1/4 Min Wedge Based Lamps 12/14V

LED-24-BA9S-G 02693 T-3 1/4 BA9s Green 30,000 24MB, 28MB, 313, 757, 1818, 1819, 1820, 1829, 1843,

1864, 1873

LED-24-BA9S-R 02694 T-3 1/4 BA9s Red 30,000 24MB, 28MB, 313, 757, 1818, 1819, 1820, 1829, 1843,

1864, 1873

LED-24-BA9S-W 02695 T-3 1/4 BA9s White 30,000 24MB, 28MB, 313, 757, 1818, 1819, 1820, 1843, 1829,

1864, 1873

LED-24-BA9S-Y 02696 T-3 1/4 BA9s Yellow 30,000 24MB, 28MB, 313, 757, 1818, 1819, 1820, 1843, 1829,

1864, 1873

LED-24-FESTOON-W 05377 Festoon

10mm SV8.5mm White 30,000 10 x 44 Xenon Festoons

LED-24-MF-R 02697 T-1 3/4 SX6s Red 30,000 327, 376, 385, 387, 7341

LED-24-MF-W 02698 T-1 3/4 SX6s White 30,000 327, 376, 385, 387, 7341

LED-24-MF-Y 02699 T-1 3/4 SX6s Yellow 30,000 327, 376, 385, 387, 7341

LED-24-MG-R 02701 T-1 3/4 S5.7s Red 30,000 276, 334, 388

LED-24-MG-W 02702 T-1 3/4 S5.7s White 30,000 276, 334, 388

LED-24-MG-Y 02703 T-1 3/4 S5.7s Yellow 30,000 276, 334, 388

LED-24-PSB-G 02704 T-2 TS5 Green 30,000 24PSB5, 28PSB5

LED-24-PSB-R 02705 T-2 TS5 Red 30,000 24PSB5, 28PSB5

LED-24-PSB-W 02706 T-2 TS5 White 30,000 24PSB5, 28PSB5

LED-24-PSB-Y 02707 T-2 TS5 Yellow 30,000 24PSB5, 28PSB5

LED-24-T1.75 WEDGE-G 02708 T-1 3/4

W2.1x4.6d

Green 30,000 17, 85

LED-24-T1.75 WEDGE-R 02709 T-1 3/4

W2.1x4.6d

Red 30,000 17, 85

LED-24-T1.75 WEDGE-W 02711 T-1 3/4

W2.1x4.6d

White 30,000 17, 85

LED-24-T1.75 WEDGE-Y 02712 T-1 3/4

W2.1x4.6d

Yellow 30,000 17, 85

LED-6-BA9S-W 05742 T-3 1/4 BA9s White 30,000 6MB, 44, 47, 238, 755, 1810, 1847, 1866

LED-6-T1.75 WEDGE-W 02715 T-1 3/4

W2.1x4.6d

White 30,000 56, 79, 84, 86

LED-6-T1.75 WEDGE-Y 02716 T-1 3/4

W2.1x4.6d

Yellow 30,000 56, 79, 84, 86

LEDP-1383/30K 07797 MR11 BA15s Warm White 30,000

LEDP-1383/41K 07798 MR11 BA15s Cool White 30,000

T1¾ Midget GrooveT1¾ Midget FlangeDC BayonetSC Bayonet Festoon 10mm

Visit our website for the most current specs: eiko.com 29

LED

T3¼ Mini Bayonet T2 Slide Base T3¼ Mini Wedge T1¾ Sub-Mini Wedge

Miniature LED Lamps > Base Types

BA9s

Miniature Bayonet

BA15s

SC Bayonet

W2.1x4.6d

Sub-Miniature Wedge

BAY15d

DC Index Bayonet

W2.1x9.5d

Miniature Wedge

TS5

Slide Base #5

SV8.5mm

Festoon

Visit our website for the most current specs: eiko.com

Fluorescent

A Shaped Decorative CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP9A19/27K 06445 9 120 E26 470 80 2700 4.213/107 1.6 10,000

SP9A19/41K 06446 9 120 E26 470 80 4100 4.213/107 1.6 10,000

SP11A/27K-GU24 07732 11 120 GU24 600 >80 2700 3.82/97 1.6 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP13A19/27K 06447 13 120 E26 800 >80 2700 4.84/123 3 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP15A/27K-GU24 07710 13 120 GU24 800 >80 2700 4.45/113 1.6 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP13A19/41K 06448 14 120 E26 750 >80 4100 4.88/123 3 10,000 UL/CUL, TCLP Compliant

B10 Decorative CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP5B10/E12/27K 06435 5 120 E12 220 80 2700 4.331/110 1.6 10,000

SP5B10/E12/41K 06437 5 E12 220 80 4100 4.331/110 1.6 10,000

SP7B10/E12/27K 06442 7 E12 320 80 2700 4.685/119 1.6 10,000

SP7B10/E12/41K 06449 7 E12 320 80 4100 4.685/119 1.6 10,000

Compact Fluorescent Lamps

EiKO’s selection of compact ﬂuorescent (CFL) and self-ballasted compact ﬂuorescent (CFLi) lamps features long life, high

quality tri-phosphor blends, and many options with environmentally-friendly ratings such as TCLP, CEE, and ENERGY

STAR. Our selection includes duo tube, triple tube, quad tube, FML, spiral, PAR, R and decorative shapes in various

wattages and color temperatures.

A Shaped B10 B13 G25

Visit our website for the most current specs: eiko.com 31

Fluorescent

B13 Decorative CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP5B13/E26/27K 06452 5 E26 220 80 2700 4.449/113 1.6 10,000

SP5B13/E26/41K 06453 5 E26 220 80 4100

4.449/1113

1.6 10,000

G25 Decorative CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP9G25/27K 06550 9 E26 500 80 2700 4.331/110 1.6 10,000

SP9G25/41K 06551 9 E26 500 80 4100 4.331/110 1.6 10,000

SP15G25/27K 07870 15 120 E26 820 80 2700 4.724/120 1.6 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP15G25/27K-GU24 07734 15 120 GU24 740 >80 2700 4.45/113 1.6 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP15G25/41K 07871 15 120 E26 820 80 4100 4.724/120 1.6 10,000 UL/CSA, TCLP Compliant

High Watt CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP65/41/MED 05293 65 120 E26 4300 >80 4100 9.45/240 4.8 10,000 UL/CSA, TCLP Compliant

SP65/50/MED 06659 65 120 E26 4000 >80 5000 9.45/240 4.8 10,000 UL/CSA, TCLP Compliant

SP85/41/MED 81183 85 120 E26 5700 >80 4100 9.96/253 4.8 10,000 UL/CSA, TCLP Compliant

SP85/50/MED 81181 85 120 E26 5350 >80 5000 9.96/253 4.8 10,000 UL/CSA, TCLP Compliant

SP105/41/MED 81184 105 120 E26 7000 >80 4100 10.75/273 4.8 10,000 UL/CSA, TCLP Compliant

SP105/41/MOG 81185 105 120 E39 7000 >80 4100 11.26/286 4.8 10,000 UL/CSA, TCLP Compliant

SP105/41/MOG-277V 04412 105 277 E39 7000 >80 4100 11.26/286 4.8 10,000 UL/CSA, TCLP Compliant

SP105/50/MED 81180 105 120 E26 6600 >80 5000 10.75/273 4.8 10,000 UL/CSA, TCLP Compliant

SP180/41/MOG 07822 180 120 E39 11,100 80 4100 14.3/364 9.2 10,000 UL/CSA, TCLP Compliant

SP180/50/MOG 07823 180 120 E39 10,400 80 5000 14.3/364 9.2 10,000 UL/CSA, TCLP Compliant

PAR CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

PAR20/9/30K 06281 9 120 E26 280 >80 3000 3.82/97 1.35 8,000 UL/CSA, Energy Star, TCLP

Compliant

PAR20/9/35K 01519 9 120 E26 272 >80 3500 3.82/97 1.35 8,000 UL/CSA, TCLP Compliant

PAR20/9/41K 06282 9 120 E26 270 >80 4100 3.82/97 1.35 8,000 UL/CSA, Energy Star, TCLP

Compliant

PAR20/9/50K 01521 9 120 E26 258 >80 5000 3.82/97 1.35 8,000 UL/CSA, TCLP Compliant

PAR30LN/15/30K 06279 15 120 E26 750 >80 3000 5.12/130 1.93 8,000 UL/CSA, TCLP Compliant

PAR30LN/15/35K 01522 15 120 E26 728 >80 3500 5.12/130 1.93 8,000 UL/CSA, TCLP Compliant

PAR30LN/15/41K 06280 15 120 E26 725 >80 4100 5.12/130 1.93 8,000 UL/CSA, Energy Star, TCLP

Compliant

PAR30LN/15/50K 01523 15 120 E26 745 >80 5000 5.12/130 1.93 8,000 UL/CSA, Energy Star, TCLP

Compliant

PAR38/23/27K 01046 23 120 E26 1250 >80 2700 5.51/140 2.31 8,000 UL/CSA, TCLP Compliant

PAR38/23/30 06277 23 120 E26 1200 >80 3000 5.51/140 2.31 8,000 UL/CSA, Energy Star, TCLP

Compliant

PAR38/23/30K 06277 23 120 E26 1200 >80 3000 5.51/140 2.5 8,000 UL/CSA, TCLP Compliant

>>Continued on page 32

High Watt Spiral PAR20 PAR30LN PAR38

Visit our website for the most current specs: eiko.com

Fluorescent

PAR CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

PAR38/23/41K 06278 23 120 E26 1210 >80 4100 5.51/140 2.31 8,000 UL/CSA, Energy Star, TCLP

Compliant

PAR38/23/50K 01531 23 120 E26 1200 >80 5000 5.51/140 2.31 8,000 UL/CSA , TCLP Compliant

R-Shaped CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP14/R20/27K 06390 14 120 E26 500 82 2700 4.88/124 3 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP14/R20/41K 06391 14 120 E26 450 82 4100 4.88/124 3 8,000 UL/CSA, TCLP Compliant

SP15/R30/27K 49365 15 E26 700 80 2700 5.394/137 1.6 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP15/R30/27K-DIM 07879 15 120 E26 680 2700 6.102/155 1.6 10,000 UL/CSA, TCLP Compliant

SP15/R30/27K-GU24 07733 15 120 GU24 690 >80 2700 4.45/113 1.6 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP15/R30/41K 49366 15 E26 700 80 4100 5.394/137 1.6 10,000

SP15/R30/41K-DIM 07880 15 120 E26 680 4100 6.102/155 1.6 10,000 UL/CSA, TCLP Compliant

SP15/R30/50K-DIM 07881 15 120 E26 680 5000 6.102/155 1.6 10,000 UL/CSA, TCLP Compliant

SP15/R30/65K 49367 15 E26 650 80 6500 5.394/137 1.6 10,000

SP15/R30/65K-DIM 07882 15 120 E26 640 6500 6.102/155 1.6 10,000 UL/CSA, TCLP Compliant

SP23/R40/27K 49371 23 120 E26 1090 80 2700 6.496/165 1.6 10,000 UL/CSA, TCLP Compliant

SP23/R40/27K-DIM 07704 23 120 E26 1090 2700 7.01/178 1.6 10,000 UL/CSA, TCLP Compliant

SP23/R40/41K 49372 23 120 E26 1090 80 4100 6.496/165 1.6 10,000 UL/CSA, TCLP Compliant

SP23/R40/41K-DIM 07705 23 120 E26 1090 4100 7.01/178 1.6 10,000 UL/CSA, TCLP Compliant

SP23/R40/50K-DIM 07706 23 120 E26 1050 5000 7.01/178 1.6 10,000 UL/CSA, TCLP Compliant

SP23/R40/65K 49373 23 120 E26 1000 80 6500 6.496/165 1.6 10,000 UL/CSA, TCLP Compliant

Dimmable Spiral CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP13/27K-DIM 06392 13 120 E26 900 80 2700 4.92/125 2 8,000 UL/CSA, TCLP Compliant

SP13/41K-DIM 06393 13 120 E26 850 80 4100 4.92/125 2 8,000 UL/CSA, TCLP Compliant

SP15/R30/27K-DIM 07879 15 120 E26 680 2700 6.102/155 1.6 10,000 UL/CSA, TCLP Compliant

SP15/R30/41K-DIM 07880 15 120 E26 680 4100 6.102/155 1.6 10,000 UL/CSA, TCLP Compliant

SP15/R30/50K-DIM 07881 15 120 E26 680 5000 6.102/155 1.6 10,000 UL/CSA, TCLP Compliant

SP15/R30/65K-DIM 07882 15 120 E26 640 6500 6.102/155 1.6 10,000 UL/CSA, TCLP Compliant

SP19/27K-DIM 06394 18 120 E26 1350 80 2700 5.12/130 2 8,000 UL/CSA, TCLP Compliant

SP19/41K-DIM 06395 20 120 E26 1300 80 4100 5.12/130 2 8,000 UL/CSA, TCLP Compliant

SP23/27K-DIM 06396 23 120 E26 1550 80 2700 5.47/139 2 8,000 UL/CSA, TCLP Compliant

SP23/41K-DIM 06397 23 120 E26 1500 80 4100 5.47/139 2 8,000 UL/CSA, TCLP Compliant

GU24 Based Spiral CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP13/27-GU24 05255 13 120 GU24 800 80 2700 3.622/92 1.6 10,000 Energy Star

SP13/27K-GU24-DIM 07701 13 120 GU24 800 82 2700 3.94/100 1.6 10,000 UL/CSA, Energy Star, TCLP

Compliant

>>Continued on page 33

GU24 Based SpiralDimmable SpiralR30R20 R40

Visit our website for the most current specs: eiko.com 33

Fluorescent

GU24 Based Spiral CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP13/41-GU24 07749 13 120 GU24 900 82 4100 3.74/95 1.6 10,000 UL/CSA, TCLP Compliant

SP18/27-GU24 05256 18 GU24 1200 80 2700 4.055/103 1.6 10,000 Energy Star

SP18/27K-GU24-DIM 07702 18 120 GU24 1200 82 2700 4.37/111 1.6 10,000 UL/CSA, TCLP Compliant

SP18/41-GU24 07750 18 120 GU24 1100 82 4100 4.33/110 1.6 10,000 UL/CSA, TCLP Compliant

SP23/27-GU24 07751 23 120 GU24 1600 80 2700 4.409/112 1.6 10,000 Energy Star

SP23/27K-GU24-DIM 07703 23 120 GU24 1600 82 2700 4.84/123 1.6 10,000 UL/CSA, TCLP Compliant

SP23/41-GU24 07752 23 120 GU24 1600 80 4100 4.409/112 1.6 10,000 UL/CSA, TCLP Compliant

SP26/27-GU24 05258 27 120 GU24 1900 82 2700 4.73/123 3 10,000 UL/CSA, Energy Star, TCLP

Compliant

Medium Based Spiral CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP13/27K 00031 13 120 E26 900 82 2700 4.50/114 2 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP13/35K 00032 13 120 E26 800 82 3500 4.10/104 2 8,000 UL/CSA, TCLP Compliant

SP13/41K 00033 13 120 E26 900 82 4100 4.10/104 2 10,000 UL/CSA, TCLP Compliant, RoHS

SP13/50K 05667 13 120 E26 800 82 5000 4.10/104 2 10,000 UL/CSA, TCLP Compliant

SP13/65K 06131 13 120 E26 900 82 6500 4.10/104 2 10,000 UL/CSA, TCLP Compliant

SP19/27K 00034 18 120 E26 1200 80 2700 4.528/115 1.6 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP19/35K 00035 18 120 E26 1200 80 3500 4.528/115 1.6 10,000 UL/cUL, TCLP Compliant, RoHS

SP19/41K 00036 18 120 E26 1200 80 4100 4.528/115 1.6 10,000 UL/cUL, TCLP Compliant, RoHS

SP19/50K 05668 18 120 E26 1200 80 5000 4.528/115 1.6 10,000 UL/cUL, TCLP Compliant, RoHS

SP19/65K 49324 18 120 E26 1100 80 6500 4.528/115 1.6 10,000 UL/cUL, TCLP Compliant, RoHS

SP23/27K 49325 23 120 E26 1600 80 2700 4.882/124 1.6 10,000 UL/CSA, Energy Star, TCLP

Compliant

SP23/35K 81171 23 120 E26 1600 80 3500 4.882/124 1.6 10,000 UL/CSA, TCLP Compliant

SP23/41K 49326 23 120 E26 1600 80 4100 4.882/124 1.6 10,000 UL/CSA, TCLP Compliant

SP23/50K 81172 23 120 E26 1600 80 5000 4.882/124 1.6 10,000 UL/CSA, TCLP Compliant

SP23/65K 49327 23 120 E26 1600 80 6500 4.882/124 1.6 10,000 UL/CSA, TCLP Compliant

SP27/27K 05412 26 E26 1700 80 2700 5.079/129 1.6 10,000 Energy Star

SP27/35K 05413 26 120 E26 1700 80 3500 5.08/129 1.6 10,000 UL/CSA, TCLP Compliant

SP27/41K 05414 26 E26 1700 80 4100 5.079/129 1.6 10,000

SP27/50K 05415 26 E26 1700 80 5000 5.079/129 1.6 10,000

SP32/27K 05416 32 E26 2000 80 2700 5.711/145 3.2 10,000

SP32/35K 05417 32 120 E26 2050 80 3500 5.63/143 3.2 8,000 UL/CSA, TCLP Compliant

SP32/41K 05418 32 120 E26 2050 80 4100 5.63/143 3.2 8,000 UL/CSA, TCLP Compliant

SP32/50K 05419 32 120 E26 2000 80 5000 5.71/145 3.2 10,000 UL/CSA, TCLP Compliant

SP42/27K 05420 40 E26 2600 80 2700 7.283/185 3.2 10,000 UL/CSA, TCLP Compliant

SP42/35K 05421 40 E26 2600 80 3500 7.283/185 3.2 10,000

SP42/41K 05422 40 E26 2600 80 4100 7.13/181 3.2 10,000

SP42/50K 05423 40 E26 2600 80 5000 7.283/185 3.2 10,000

SP65/41/MED 05293 65 120 E26 4300 >80 4100 9.45/240 4.8 10,000 UL/CSA, TCLP Compliant

SP65/50/MED 06659 65 120 E26 4000 >80 5000 9.45/240 4.8 10,000 UL/CSA, TCLP Compliant

SP85/41/MED 81183 85 120 E26 5700 >80 4100 9.96/253 4.8 10,000 UL/CSA, TCLP Compliant

>>Continued on page 34

Medium Based Spiral

Visit our website for the most current specs: eiko.com

Fluorescent

Medium Based Spiral CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP85/50/MED 81181 85 120 E26 5350 >80 5000 9.96/253 4.8 10,000 UL/CSA, TCLP Compliant

SP105/41/MED 81184 105 120 E26 7000 >80 4100 10.75/273 4.8 10,000 UL/CSA, TCLP Compliant

SP105/50/MED 81180 105 120 E26 6600 >80 5000 10.75/273 4.8 10,000 UL/CSA, TCLP Compliant

Mogul Based Spiral CFLi Lamps

Ordering Code Barcode Watts Volts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg

Hg Life Approvals

SP105/41/MOG 81185 105 120 E39 7000 >80 4100 11.26/286 4.8 10,000 UL/CSA, TCLP Compliant

SP105/41/MOG-277V 04412 105 277 E39 7000 >80 4100 11.26/286 4.8 10,000 UL/CSA, TCLP Compliant

SP180/41/MOG 07822 180 120 E39 11,100 80 4100 14.3/364 9.2 10,000 UL/CSA, TCLP Compliant

SP180/50/MOG 07823 180 120 E39 10,400 80 5000 14.3/364 9.2 10,000 UL/CSA, TCLP Compliant

4-Pin Based Spiral CFL Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg Hg Life

SP13/27-4P 05251 13 G24q-1 900 80 2700 3.74/95 2.5 10,000

SP18/27-4P 05250 18 GX24q-2 1100 82 2700 4.41/112 2.5 10,000

SP26/27-4P 05252 26 GX24q-3 1800 82 2700 4.72/120 2.5 10,000

Duo-Tube CFL Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg Hg Life

DT5/27 15554 5 G23 250 82 2700 4.2/107 2.2 10,000

DT5/35 49204 5 G23 250 82 3500 4.2/107 2.2 10,000

DT5/41 49205 5 G23 250 82 4100 4.2/107 2.2 10,000

DT5/50 49206 5 G23 250 82 5000 4.2/107 2.2 10,000

DT5/65 49207 5 G23 250 82 6500 4.2/107 2.2 10,000

DT7/27 15556 7 G23 400 82 2700 5.3/135 2.2 10,000

DT7/35 49208 7 G23 400 82 3500 5.3/135 2.2 10,000

DT7/41 49209 7 G23 400 82 4100 5.3/135 2.2 10,000

DT7/50 49210 7 G23 400 82 5000 5.3/135 2.2 10,000

DT7/65 49211 7 G23 400 82 6500 5.3/135 2.2 10,000

DT9/27 15558 9 G23 600 82 2700 6.6/168 2.2 10,000

DT9/35 49212 9 G23 600 82 3500 6.6/168 2.2 10,000

DT9/41 49213 9 G23 600 82 4100 6.6/168 2.2 10,000

DT9/50 49214 9 G23 600 82 5000 6.6/168 2.2 10,000

DT9/65 49215 9 G23 600 82 6500 6.6/168 2.2 10,000

DT13/27 15560 13 GX23 825 82 2700 7.3/185 2.2 10,000

DT13/30 49216 13 GX23 825 82 3000 7.3/185 2.2 10,000

DT13/35 15575 13 GX23 825 82 3500 7.3/185 2.2 10,000

DT13/41 49217 13 GX23 825 82 4100 7.3/185 2.2 10,000

DT13/50 49218 13 GX23 825 82 5000 7.3/185 2.2 10,000

DT13/65 49219 13 GX23 825 82 6500 7.3/185 2.2 10,000

DT18/30/RS 49283 18 2G11 1250 82 3000 9.0/229 2.2 20,000

DT18/35/RS 49284 18 2G11 1250 82 3500 9.0/229 2.2 20,000

>>Continued on page 35

Mogul Based Spiral 4-Pin Based Spiral Duo-Tube

Visit our website for the most current specs: eiko.com 35

Fluorescent

Duo-Tube CFL Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg Hg Life

DT18/41/RS 49285 18 2G11 1250 82 4100 9.0/229 2.2 20,000

DT18/50/RS 49286 18 2G11 1250 82 5000 9.0/229 2.2 20,000

DT24/30/RS 49288 24 2G11 1800 82 3000 12.9/328 2.2 20,000

DT24/35/RS 49289 24 2G11 1800 82 3500 12.9/328 2.2 20,000

DT24/41/RS 49290 24 2G11 1800 82 4100 12.9/328 2.2 20,000

DT24/50/RS 49291 24 2G11 1800 82 5000 12.9/328 2.2 20,000

DT24/65/RS 49292 24 2G11 1800 82 6500 12.9/328 2.2 20,000

DT36/30/RS 49293 36 2G11 2900 82 3000 16.6/422 2.2 20,000

DT36/35/RS 49294 36 2G11 2900 82 3500 16.6/422 2.2 20,000

DT36/41/RS 49295 36 2G11 2900 82 4100 16.6/422 2.2 20,000

DT36/50/RS 49296 36 2G11 2900 82 5000 16.6/422 2.2 20,000

DT36/65/RS 49297 36 2G11 2900 82 6500 16.6/422 2.2 20,000

DT40/30/RS 49298 40 2G11 3300 82 3000 22.5/572 2.2 20,000

DT40/35/RS 49299 40 2G11 3300 82 3500 22.5/572 2.2 20,000

DT40/41/RS 49300 40 2G11 3300 82 4100 22.5/572 2.2 20,000

DT40/50/RS 49301 40 2G11 3300 82 5000 22.5/572 2.2 20,000

DT40/65/RS 49302 40 2G11 3300 82 6500 22.5/572 2.2 20,000

DT50/30/RS 49303 50 2G11 4300 82 3000 22.5/572 2.2 18,000

DT50/35/RS 49304 50 2G11 4300 82 3500 22.5/572 2.2 18,000

DT50/41/RS 49305 50 2G11 4300 82 4100 22.5/572 2.2 18,000

DT50/50/RS 49306 50 2G11 4300 82 5000 22.5/572 2.2 18,000

DT50/65/RS 49307 50 2G11 4300 82 6500 22.5/572 2.2 18,000

DT55/30/RS 49308 55 2G11 4800 82 3000 21.5/546 2.2 18,000

DT55/35/RS 49309 55 2G11 4800 82 3500 21.5/546 2.2 18,000

DT55/41/RS 49310 55 2G11 4800 82 4100 21.5/546 2.2 18,000

DT55/50/RS 49311 55 2G11 4800 82 5000 21.5/546 2.2 18,000

DT55/65/RS 49312 55 2G11 4800 82 6500 21.5/546 2.2 18,000

Triple-Tube CFL Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg Hg Life

TT18/27 49259 18 GX24q-2 1200 82 2700 4.8/122 2.2 10,000

TT18/30 49260 18 GX24q-2 1200 82 3000 4.8/122 2.2 10,000

TT18/35 49261 18 GX24q-2 1200 82 3500 4.8/122 2.2 10,000

TT18/41 49262 18 GX24q-2 1200 82 4100 4.8/122 2.2 10,000

TT18/65 49264 18 GX24q-2 1200 82 6500 4.8/122 2.2 10,000

TT26/27 49265 26 GX24q-3 1800 82 2700 5.2/132 2.2 10,000

TT26/30 49266 26 GX24q-3 1800 82 3000 5.2/132 2.2 10,000

TT26/35 49267 26 GX24q-3 1800 82 3500 5.2/132 2.2 10,000

TT26/41 49268 26 GX24q-3 1800 82 4100 5.2/132 2.2 10,000

TT26/50 49269 26 GX24q-3 1800 82 5000 5.2/132 2.2 10,000

TT26/65 49270 26 GX24q-3 1800 82 6500 5.2/132 2.2 10,000

TT32/27 49271 32 GX24q-3 2200 82 2700 5.8/147 2.2 10,000

TT32/30 49272 32 GX24q-3 2200 82 3000 5.8/147 2.2 10,000

TT32/35 49273 32 GX24q-3 2200 82 3500 5.8/147 2.2 10,000

>>Continued on page 36

Triple-Tube

Visit our website for the most current specs: eiko.com

Fluorescent

Triple-Tube CFL Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg Hg Life

TT32/41 49274 32 GX24q-3 2200 82 4100 5.8/147 2.2 10,000

TT32/50 49275 32 GX24q-3 2200 82 5000 5.8/147 2.2 10,000

TT32/65 49276 32 GX24q-3 2200 82 6500 5.8/147 2.2 10,000

TT42/27 49277 42 GX24q-4 3200 82 2700 6.4/163 2.2 10,000

TT42/30 49278 42 GX24q-4 3200 82 3000 6.4/163 2.2 10,000

TT42/35 49279 42 GX24q-4 3200 82 3500 6.4/163 2.2 10,000

TT42/41 49280 42 GX24q-4 3200 82 4100 6.4/163 2.2 10,000

TT42/50 49281 42 GX24q-4 3200 82 5000 6.4/163 2.2 10,000

TT42/65 49282 42 GX24q-4 3200 82 6500 6.4/163 2.2 10,000

Quad-Tube CFL Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg Hg Life

QT9/27 15562 9 G23-2 550 82 2700 4.3/109 2.2 10,000

QT9/35 49221 9 G23-2 550 82 3500 4.3/109 2.2 10,000

QT9/41 49558 9 G23-2 550 82 4100 4.3/109 2.2 10,000

QT13/27 15564 13 GX23-2 810 82 2700 4.6/117 2.2 10,000

QT13/27-4P 49241 13 G24q-1 900 82 2700 5/127 2.2 10,000

QT13/30 49222 13 GX23-2 810 82 3000 4.6/117 2.2 10,000

QT13/30-4P 49242 13 G24q-1 900 82 3000 5/127 2.2 10,000

QT13/35 15576 13 GX23-2 810 82 3500 4.6/117 2.2 10,000

QT13/35-4P 49243 13 G24q-1 900 82 3500 5/127 2.2 10,000

QT13/41 49084 13 GX23-2 810 82 4100 4.6/117 2.2 10,000

QT13/41-4P 49244 13 G24q-1 900 82 4100 5/127 2.2 10,000

QT13/50 49223 13 GX23-2 810 82 5000 4.6/117 2.2 10,000

QT13/50-4P 49245 13 G24q-1 900 82 5000 5/127 2.2 10,000

QT13/65 49224 13 GX23-2 810 82 6500 4.6/117 2.2 10,000

QT13/65-4P 49246 13 G24q-1 900 82 6500 5/127 2.2 10,000

QT13/G24D1/30 49226 13 G24d-1 900 82 3000 5.5/140 2.5 10,000

QT13/G24D1/35 49227 13 G24d-1 900 82 3500 5.5/140 2.5 10,000

QT13/G24D1/50 49229 13 G24d-1 900 82 5000 5.5/140 2.5 10,000

QT13/G24D1/65 49230 13 G24d-1 900 82 6500 5.5/140 2.5 10,000

QT18/27 15566 18 G24d-2 1150 82 2700 5.9/150 2.2 10,000

QT18/27-4P 49247 18 G24q-2 1150 82 2700 5.8/147 2.2 10,000

QT18/30 49231 18 G24d-2 1150 82 3000 5.9/150 2.2 10,000

QT18/30-4P 49248 18 G24q-2 1150 82 3000 5.8/147 2.2 10,000

QT18/35 49232 18 G24d-2 1150 82 3500 5.9/150 2.2 10,000

QT18/35-4P 49249 18 G24q-2 1150 82 3500 5.8/147 2.2 10,000

QT18/41 49233 18 G24d-2 1150 82 4100 5.9/150 2.2 10,000

QT18/41-4P 49250 18 G24q-2 1150 82 4100 5.8/147 2.2 10,000

QT18/50 49234 18 G24d-2 1150 82 5000 5.9/150 2.2 10,000

QT18/50-4P 49251 18 G24q-2 1150 82 5000 5.8/147 2.2 10,000

QT26/27 15568 26 G24d-3 1710 82 2700 6.7/170 2.2 10,000

QT26/27-4P 49253 26 G24q-3 1710 82 2700 6.4/163 2.2 10,000

QT26/30 49236 26 G24d-3 1710 82 3000 6.7/170 2.2 10,000

>>Continued on page 37

FMLQuad-Tube

Visit our website for the most current specs: eiko.com 37

Fluorescent

Quad-Tube CFL Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg Hg Life

QT26/30-4P 49254 26 G24q-3 1710 82 3000 6.4/163 2.2 10,000

QT26/35 49237 26 G24d-3 1710 82 3500 6.7/170 2.2 10,000

QT26/35-4P 49255 26 G24q-3 1710 82 3500 6.4/163 2.2 10,000

QT26/41 49238 26 G24d-3 1710 82 4100 6.7/170 2.2 10,000

QT26/41-4P 49256 26 G24q-3 1710 82 4100 6.4/163 2.2 10,000

QT26/50 49239 26 G24d-3 1710 82 5000 6.7/170 2.2 10,000

QT26/50-4P 49257 26 G24q-3 1710 82 5000 6.4/163 2.2 10,000

QT26/65 49240 26 G24d-3 1710 82 6500 6.7/170 2.2 10,000

QT26/65-4P 49258 26 G24q-3 1710 82 6500 6.4/163 2.2 10,000

FML CFL Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens CRI CT° K MOL in/mm mg Hg Life

FML18/65 05148 18 GX10q-4 1080 82 6500 5.1/129 2.5 10,000

FML27/27 49313 27 GX10q-4 1400 82 2700 5.7/145 2.5 10,000

FML27/41 49314 27 GX10q-4 1400 82 4100 5.7/145 2.5 10,000

FML27/65 49315 27 GX10q-4 1400 82 6500 5.7/145 2.5 10,000

CFL & CFLi Lamps > Base Types

G24d-1

2-Pin

GX24q-3

4-Pin

G24q-1

4-Pin

2G11

4-Pin, Twin Tube

G24d-2

2-Pin

GX24q-4

4-Pin

E26

Medium Screw

GX23

Bi-Pin Cap

E12

Candelabra Screw

G24d-3

2-Pin

E39/E40

Mogul Screw

GU24

Bi-Pin

GX23-2

Bi-Pin

G23

Bi-Pin Cap

GX24q-2

4-Pin

Visit our website for the most current specs: eiko.com

Fluorescent

Programmed Start T5 Linear Fluorescent Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens

Approx Mean

Lumens CRI CT° K MOL in/

mm mg Hg Life 3hr

Start

Life 12hr

Start

F14T5/835 81147 14 G5 1350 1256 85 3500 22/559 2.7 25,000 35,000

F14T5/841 81148 14 G5 1200 85 4000 22/559 2.7 25,000 35,000

F14T5/865 07151 14 G5 1300 1210 85 6500 22/559 4.25 25,000 35,000

F21T5/835 81149 21 G5 2100 1953 85 3500 34/864 2.7 25,000 35,000

F21T5/841 81150 21 G5 1900 85 4000 34/864 2.7 25,000 35,000

F24T5/HO/835 81154 24 G5 1750 1625 85 3500 22/559 4.25 25,000 35,000

F24T5/HO/841 81155 24 G5 1750 1625 85 4100 22/559 4.25 25,000 35,000

F28T5/835 81151 28 G5 2600 85 3000 46/1169 2.7 25,000 35,000

F28T5/841 81152 28 G5 2600 85 4000 46/1169 2.7 25,000 35,000

F28T5/850 81153 28 G5 2400 85 5000 46/1169 2.7 25,000 35,000

F28T5/865 07150 28 G5 2850 2650 85 6500 46/1169 2.7 25,000 35,000

F35T5/830 04727 35 G5 3300 85 3000 57/1463 2.7 25,000 35,000

F39T5/HO/835 81156 39 G5 3200 2975 85 3500 34/864 4.25 25,000 35,000

F39T5/HO/841 81157 39 G5 3200 2975 85 4100 34/864 4.25 25,000 35,000

F49T5/HO/835 00973 49 G5 4900 4750 85 3500 46/1169 2.7 25,000 35,000

F49T5/HO/841 00976 49 G5 4900 4750 85 4000 46/1169 2.7 25,000 35,000

F49T5/HO/850 00981 49 G5 4800 4625 85 5000 46/1169 2.7 25,000 35,000

F49T5/HO/865 00982 49 G5 4800 4625 85 6500 46/1169 2.7 25,000 35,000

F54T5/HO/830 07376 54 G5 5000 4650 85 3000 46/1169 2.7 25,000 35,000

F54T5/HO/835 81158 54 G5 5000 4650 85 3500 46/1169 2.7 25,000 35,000

F54T5/HO/841 81159 54 G5 5000 4650 85 4100 46/1169 2.7 25,000 35,000

>>Continued on page 39

Linear Fluorescent Lamps

EiKO’s entire line of linear ﬂuorescent lamps features long life, high quality tri-phosphor blends and a variety of environ-

mentally-friendly TCLP and CEE ratings. Our selection includes linear, circuline and u-bend ﬂuorescents in various sizes,

wattages and color temperatures.

T5 Linear

Visit our website for the most current specs: eiko.com 39

Fluorescent

Programmed Start T5 Linear Fluorescent Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens

Approx Mean

Lumens CRI CT° K MOL in/

mm mg Hg Life 3hr

Start

Life 12hr

Start

F54T5/HO/850 81160 54 G5 4850 4500 85 5000 46/1169 2.7 25,000 35,000

F54T5/HO/865 06854 54 G5 4850 4500 85 6500 46/1169 2.7 25,000 35,000

Preheat T5 Linear Fluorescent Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens

Approx Mean

Lumens CRI CT° K MOL in/mm mg Hg Life

F4T5/CW 15500 4 G5 135 100 60 4100 6.0/152 2.72 6,000

F4T5/D 15501 4 G5 115 92 75 6500 6.0/152 2.75 6,000

F6T5/CW 15505 6 G5 295 235 60 4100 9.0/229 2.75 7,500

F6T5/D 15506 6 G5 230 185 75 6500 9.0/229 2.75 7,500

F6T5/WW 15507 6 G5 275 220 52 3000 9.0/229 2.75 7,500

F8T5/CW 15510 8 G5 400 320 60 4100 12.0/305 2.75 7,500

F8T5/D 15511 8 G5 330 265 75 6500 12.0/305 2.75 7,500

F8T5/W 15513 8 G5 400 320 55 3500 12.0/305 2.75 7,500

F8T5/WW 15512 8 G5 410 330 52 3000 12.0/305 2.75 7,500

F13T5/CW 15517 13 G5 850 705 60 4100 21.0/533 2.75 7,500

F13T5/D 15531 13 G5 700 460 75 6500 21.0/533 2.75 7,500

F13T5/WW 15518 13 G5 870 720 60 3000 21.0/533 2.75 7,500

Blacklight T5 Linear Fluorescent Lamps

Ordering Code Barcode Watts Base MOL in/mm MOD in/mm mg Hg Life

F4T5/BL 15503 4 G5 6.0/152 0.63/16 2.75 6,000

F4T5/BLB 15504 4 G5 6.0/152 0.63/16 2.75 6,000

F6T5/BL 15528 6 G5 9.0/229 0.63/16 2.75 7,500

F6T5/BLB 15509 6 G5 9.0/229 0.63/16 2.75 7,500

F8T5/BL 15515 8 G5 12.0/305 0.63/16 2.75 7,500

F8T5/BLB 15516 8 G5 12.0/305 0.63/16 2.75 7,500

T8 Linear Fluorescent Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens

Approx Mean

Lumens CRI CT° K MOL in/

mm mg Hg Life 3hr

Start

Life 12hr

Start

F17T8/730K 49572 17 G13 1325 1200 73 3000 24.0/610 3 20,000 25,000

F17T8/735K 49573 17 G13 1325 1200 73 3500 24.0/610 3 20,000 25,000

F17T8/741K 49574 17 G13 1325 1200 73 4100 24.0/610 3 20,000 25,000

F17T8/830K 49575 17 G13 1400 1300 85 3000 24.0/610 3 20,000 25,000

F17T8/835K 49576 17 G13 1400 1300 85 3500 24.0/610 3 20,000 25,000

F17T8/841K 49577 17 G13 1400 1300 85 4100 24.0/610 3 20,000 25,000

F17T8/850K 48055 17 G13 1400 1300 85 5000 24.0/610 3 20,000 25,000

F25T8/830K 49581 25 G13 2225 2050 85 3000 36.0/915 3 20,000 25,000

F25T8/835K 49582 25 G13 2225 2050 85 3500 36.0/915 3 20,000 25,000

F25T8/841K 49583 25 G13 2225 2050 85 4100 36.0/915 3 20,000 25,000

F32T8/735K 49585 32 G13 2850 2705 75 3500 48.0/1219 3 20,000 25,000

F32T8/741K 49586 32 G13 2850 2705 75 4100 48.0/1219 3 20,000 25,000

F32T8/830K 49587 32 G13 2950 2800 85 3000 48.0/1219 3 20,000 25,000

F32T8/835K 49588 32 G13 2950 2800 85 3500 48.0/1219 3 20,000 25,000

>>Continued on page 40

T8 LinearBlacklight T5 Linear

Visit our website for the most current specs: eiko.com

Fluorescent

T8 Linear Fluorescent Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens

Approx Mean

Lumens CRI CT° K MOL in/

mm mg Hg Life 3hr

Start

Life 12hr

Start

F32T8/841K 49589 32 G13 2950 2800 85 4100 48.0/1219 3 20,000 25,000

F32T8/850K 81174 32 G13 2950 2773 85 5000 48.0/1219 3 24000 24000

F32T8/865K 07147 32 G13 2900 2725 85 6500 48.0/1219 3 20,000 25,000

CEE Speciﬁed T8 Linear Fluorescent Lamps

Ordering Code Barcode Watts Base Approx Initial

Lumens

Approx Mean

Lumens CRI CT° K MOL in/

mm mg Hg Life 3hr

Start

Life 12hr

Start

F32T8/830/ES/25W 06748 25 G13 2400 2260 85 3000 48.0/1219 3 24,000 30,000

F32T8/835/ES/25W 06749 25 G13 2400 2260 85 3500 48.0/1219 3 24,000 30,000

F32T8/841/ES/25W 06750 25 G13 2400 2260 85 4100 48.0/1219 3 24,000 30,000

F32T8/850/ES/25W 06751 25 G13 2350 2200 85 5000 48.0/1219 3 24,000 30,000

F32T8/865/ES/25W 07149 25 G13 2350 2200 85 6500 48.0/1219 3 24,000 30,000

F28T8/830/ES 06603 28 G13 2800 2635 85 3000 48.0/1219 3 24,000 30,000

F28T8/835/ES 06604 28 G13 2800 2635 85 3500 48.0/1219 3 24,000 30,000

F28T8/841/ES 06605 28 G13 2800 2635 85 4100 48.0/1219 3 24,000 30,000

F28T8/850/ES 06606 28 G13 2800 2635 85 5000 48.0/1219 3 24,000 30,000

F28T8/865/ES 07146 28 G13 2750 2585 85 6500 48.0/1219 3 24,000 30,000

F32T8/830K/HL 06568 32 G13 3100 2915 85 3000 48.0/1219 3 24,000 30,000

F32T8/835K/HL 06569 32 G13 3100 2915 85 3500 48.0/1219 3 24,000 30,000

F32T8/841K/HL 06570 32 G13 3100 2915 85 4100 48.0/1219 3 24,000 30,000

F32T8/850K 81174 32 G13 2950 2773 85 5000 48.0/1219 3 24000 24000

F32T8/850K/HL 06571 32 G13 3000 2820 85 5000 48.0/1219 3 24,000 30,000

F32T8/850K/XL 07476 32 G13 2950 2810 85 5000 48.0/1219 3.5 44,000 55,000

F32T8/865K/HL 07148 32 G13 3000 2820 85 6500 48.0/1219 3 24,000 30,000

Energy Saving T8 Linear Fluorescent Lamps
