Wrenches
Heavy-Duty Pipe Wrenches ..................2-3
Aluminum Pipe Wrenches.....................3-4
Chain Wrenches ....................................4
Strap Wrenches ....................................5
Hex Wrenches .......................................5
Spud Wrench.........................................5
Internal Wrench ....................................6
Basin Wrench ........................................6
One Stop Wrench ..................................6
Faucet and Sink Installer.......................7
Wrench Parts.........................................7
Pipe Vises & Stands
Pipe Vises ..............................................8
Pipe Stands ...........................................9
Pipe/Tube Cutting &
Preparation
Pipe Cutters ...........................................10
Soil Pipe Cutters....................................11
Pipe Cutter Replacement Wheels .........12
Inner/Outer Cleaning Brush ..................12
Reamers, Extractors and Taps ...............13
Power Pipe Cutter .................................14
Copper Cutting Prep Machine ...............15
Tubing Cutters .......................................16-17
Tubing Cutter Replacement Wheels .....17
Plastic Pipe Cutters ...............................18
Threading
Manual Threaders .................................19-20
Cutting Oil .............................................21
Oiler .......................................................21
Hand-Held Power Drives .......................22-24
Mounted Power Drive ...........................25
Threading Machines .............................26-32
Product CatalogProduct Catalog
1
Roll Groovers
Manual Roll Groover .............................33
Combination Manual or
Powered Roll Groover ...........................34
Powered Roll Groover ...........................35
Pipe/Tube Fabrication &
Maintenance
Benders .................................................36-37
Tube Expander .......................................37
Swaging Tools .......................................37
Flaring Tools ..........................................38
Pressure Test Pump ...............................38
Soldering Gun........................................39
Vises ......................................................39
Pipe Freezer ...........................................40
Pipe Thawer ..........................................40
Press Tools
Compact Battery-Powered Press Tool ...41
Battery-Powered Press Tool ..................42
Corded Press Tool ..................................43
Press Rings ............................................43
Inspection and Locating
Utility Line Locator ................................44-45
Hand-Held Inspection Cameras ............46-48
Video Pipe Inspection Systems .............49-52
Pipe Locators .........................................53-54
Transmitters ..........................................55
Drain Cleaning
Toilet Augers .........................................56
Hand Spinners .......................................56
Sink Machines.......................................57-58
Drum Machines .....................................59-67
Sectional Machines ..............................68-72
Water Jetters ........................................73-75
Heavy-Duty Pipe Wrenches
RapidGrip®
• Quick one-handed operation makes your jobs move faster.
• The spring-loaded jaw design provides rapid ratcheting action.
• Unique combination heel/hook jaw design aggressively bites the
work piece and ensures a secure grip.
Catalog No. Model
No.
Nom. Size Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
1XDY9 31000 6 6 150 3⁄420 1⁄2 0.2 6
4A497 31005 8 8 200 1 25 3⁄40.3 6
4A498 31010 10 10 250 11⁄240 13⁄40.8 6
4CW42 31015 12 12 300 2 50 2 3⁄41.2 6
4A499 31020 14 14 350 2 50 31⁄21.6 6
4A500 31025 18 18 450 21⁄265 53⁄42.6 6
4A501 31030 24 24 600 3 80 93⁄44.4 6
4A502 31035 36 36 900 5 125 19 8.7 1
4NV21 31040 48 48 1200 6 150 341⁄415.6 1
1XDY8 31045 60 60 1500 8 200 511⁄423.3 1
Catalog No. Model
No.
Nom. Size Pipe Capacity Fittings
Cap. Weight Std.
Pack
Grainger RIDGID in. mm in. mm in. mm lb. kg
1EZ12 10348 10 10 250 11⁄237.5 1 25 1.6 0.7 6
3AY50 10358 14 14 350 2 50 1½ 37.5 3.1 1.4 6
Catalog No. Model
No.
Nom. Size Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
4CW42 31070 E-14 14 350 2 50 31⁄21.6 6
4CW44 31075 E-18 18 450 21⁄265 53⁄42.6 6
Straight Pipe Wrench
• Sturdy, cast-iron housing and I-beam handle with full floating forged
hook jaw, featuring self-cleaning threads with replaceable hook and
heel jaws.
• Heavy-duty pipe wrenches comply with federal specifications
GGG-W65IE, Type II, Class A.
End Pipe Wrench
• Assures a fast and easy grip for pipe working in restricted spaces
or close to a wall.
• Provides a faster, easier way to get a grip and long handle swing.
• Ideal for pipe work close to a wall, in tight quarters or in closely-spaced
parallel lines.
Raprench®
• A deeper and broader hook jaw housing provides a smooth, flat surface that
is ideal for occasional use as a hammer.
• Offers all of the same outstanding qualities found in all RIDGID heavy-duty
wrenches.
Catalog No. Model
No.
Nom. Size Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
5FY90 31395 10 10 250 11⁄240 2 0.9 6
Aluminum Straight Pipe Wrench
• Professional strength in lightweight aluminum.
• Offers the same durability and ease-of-use found in
all RIDGID heavy-duty wrenches.
Catalog No. Model
No.
Nom. Size Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
6A650 31090 810 10 250 11⁄240 1 0.4 6
6YJ41 47057 812 12 300 2 50 21⁄21.1 6
6A651 31095 814 14 350 2 50 21⁄21.1 6
6A652 31100 818 18 450 21⁄265 33⁄41.7 6
6A653 31105 824 24 600 3 80 6 2.7 6
6A654 31110 836 36 900 5 125 11 5.0 1
4NV22 31115 848 48 1200 6 150 181⁄28.4 1
Catalog No. Model
No.
Nom. Size Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
1EZ15 31120 14 14 350 2 50 2 0.9 6
4CW45 31125 18 18 450 21⁄265 31⁄21.6 6
1EZ16 31130 24 24 600 3 80 6 2.7 6
Aluminum Offset Pipe Wrench
• Features a jaw opening parallel to the handle and a
narrower hook jaw head.
• Provides easy entry into tight spots.
Aluminum Pipe Wrenches
• Nearly 40% lighter than comparable cast-iron wrenches.
• Jaws and all other parts identical to RIDGID Heavy-Duty Wrenches.
WrenchesWrenches
32
Aluminum RapidGrip
• All the great benefits of the heavy-duty RapidGrip.
• 35% lighter than heavy-duty models.
• Ideal for overhead applications.
Catalog No. Model
No.
Nom. Size Pipe Capacity Fittings
Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm in. mm lb. kg
4MY87 12693 14 14 350 2 50 11⁄237.5 2.1 0.9 6
4MY88 12698 18 18 450 3 75 21⁄262.5 4.3 1.9 6
Aluminum End Wrench
• Ideal for jobs in close quarters and over-
head applications.
• Designed for easy access in close parallel lines.
• 40% lighter than heavy-duty wrenches.
Catalog No. Model
No. Description Nom. Size Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
6YJ46 90117 E-914 Aluminum End 14 350 2 50 2 0.9 6
6YJ47 90122 E-918 Aluminum End 18 450 21⁄265 3 1.4 6
• A double jaw gives fast, ratchet-like action
in either direction.
• The heavy-duty model has replaceable
alloy steel jaws.
• The light-duty model has a one-piece
forged alloy steel handle and jaw. Ideal
for use in close quarters.
Catalog No. Model
No. Description
Rated Pipe
Capacity
Actual O.D.
Capacity Chain Length Weight Std.
Pack
Grainger RIDGID in. mm in. mm in. mm lb. kg
4CW47 31315 C-14 Heavy-Duty Chain 2 50 5 125 181⁄2460 23⁄41.2 1
4CW48 31320 C-18 Heavy-Duty Chain 21⁄260 5 125 201⁄4500 6 2.7 1
1EZ14 31325 C-24 Heavy-Duty Chain 3 75 5 125 201⁄4500 81⁄43.7 1
1XDY7 31330 C-36 Heavy-Duty Chain 41⁄2110 71⁄2185 29 725 153⁄47.1 1
Chain Wrenches
• Best for any polished pipe.
• Strong, woven nylon strap gives tight grip.
• Two models available for plastic pipe.
• Polyurethane-coated strap.
Catalog No. Model
No.
Handle
Length
Strap
Length Strap Width Pipe
Capacity
O.D. Tube
Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm in. mm in. mm in. mm lb. kg
4A505 31340 2 113⁄4300 17 425 11⁄830 2 50 31⁄290 13⁄40.8 1
4CW49 31360 5 18 450 291⁄4750 13⁄445 5 125 7 175 2 0.9 1
Strap Wrenches
• Hex jaw design gives multi-sided, secure grip on all hex nuts,
square nuts, unions and valve packing nuts.
• The extra-wide opening offset model is ideal for securing
drain nuts on sinks and tubs.
• Thin, smooth jaws slip into the tightest places.
Catalog No. Model
No. Description Nom. Size Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
4A504 31305 E-110 Offset Hex 9½ 240 11⁄8-25⁄829-67 11⁄20.6 6
• 12” Spud Wrench features narrow jaws to fit into
tight places.
• Smooth, toothless jaws ideal for square or
rectangular stock.
Catalog No. Model
No. Description Nom. Size Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
5FY89 31400 – Spud Wrench 12 300 3⁄8-25⁄810-67 21⁄21.1 1
Hex Wrenches
Spud Wrench
WrenchesWrenches
54
• Spring-loaded jaws of forged alloy steel provide fast,
one-hand ratcheting.
• Tension plug holds head in any position up to 90° angle.
• Telescopic shanks on Models 1017 and 1019 quickly
adjust for lengths from 10" to 17".
Catalog No. Model
No. Description Nom. Size Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
1XDZ1 31170 1010 Basin 10 250 3⁄8 - 11⁄410-30 13⁄40.8 1
4A503 31175 1017 Telescoping Basin 10-17 250-425 3⁄8 - 11⁄410-30 2 0.9 1
1XDZ2 31180 1019 Telescoping Basin 10-17 250-425 11⁄4-21⁄230-60 2 0.9 1
• Holds closet spuds and bath, basin and sink strainers
through 2". Use to install or extract 1" through 2" nipples.
• Jaws expand by eccentric action and are reversible for
various sizes.
Catalog No. Model
No. Description Nom. Size Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
1VUV1 31405 342 Internal 41⁄2113 1-2 25-50 15⁄80.7 1
Internal Wrench
Basin Wrenches
• The One Stop Wrench is two wrenches in one.
• It provides the exact size wrench you need to
install angle stops and compression couplings.
Catalog No. Model
No. Description Nom. Size Weight Master
Pack
Grainger RIDGID in. mm lb. kg
3MA14 97452 2002 One Stop – – .73 0.3 12
One Stop Wrench
Catalog No. Model
No. Description Nom. Size Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
1XDX8 66807 2006 Faucet & Sink Installer 101⁄4260.35 0.77 0.35 6
Faucet & Sink Installer
• Extra long to turn hard to reach mounting nuts on faucets, sprayers
and ball cocks.
• Notched ends engage 2, 3, 4, and 6 tab basin nuts.
• Open slot allows easy access over existing supply lines.
• Shutoff valve attachment turns hard to reach angle stops without
marring chrome.
• Strainer basket attachment holds drain unit in place while
tightening strainer nut.
• Works with 7⁄8" & 1" metal or plastic hex nuts.
• Light-weight, high strength plastic construction with durable
aluminum inserts.
Wrench Parts: Always Insist On
Genuine RIDGID Parts
Wrench
Size Pipe
Cap.
Nut Heel Jaw &
Pin Assembly
Coil & Flat
Spring Assembly Hook Jaw
Str. End Catalog No. Catalog No. Catalog No. Catalog No.
Grainger RIDGID Grainger RIDGID Grainger RIDGID Grainger RIDGID
10 E-10 11⁄21VTN1 31615 1VTL9 31610 1VTN2 31620 1VTL8 31605
12 E-12 2 1VTN6 31645 1VTN4 31635 1VTN5 31640 1VTN3 31630
14 E-14 2 1VTN9 31665 1VTN4 31635 1VTN8 31660 1VTN7 31655
18 E-18 21⁄21VTP4 31685 1VTP2 31675 1VTP3 31680 1VTP1 31670
24 E-24 3 1VTP8 31710 1VTP6 31700 1VTP7 31705 1VTP5 31695
36 E-36 5 1VTR3 31735 1VTR1 31725 1VTR2 31730 1VTP9 31720
48 – 6 1VTR7 31760 1VTR5 31750 1VTR6 31755 1VTR4 31745
60 – 8 1VTT2 31785 1VTR9 31775* 1VTT1 31780 1VTR8 31770
WrenchesWrenches
76
Portable TRISTAND® Vises
• Models 460 and 40-A include integral legs and tray fold in for easy carrying and setup. Large
vise base overhangs front legs for clear tool swing.
• Models 460 and 40-A include slots for hanging tools, pipe rest, three-pipe benders, and ceiling
brace screw.
• Model 460 features a larger work surface, 6" diameter, rear support and receding ceiling
brace screw.
• Model 425 features “quick grab”, self-locking latch and carrying handle for ease of transport.
Catalog No. Model
No. Description Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
1VUV5 40130 40-A Portable TRISTAND Yoke Vise 1⁄8-21⁄23-60 481⁄222.0 1
4ZA21 16703 425 Portable TRISTAND Chain Vise 1⁄8-21⁄23-60 32 14.5 1
4VX15 72037 460 Portable TRISTAND Chain Vise** 1⁄8-6 3-150 47 21.0 1
**Jaw for Plastic Pipe, Catalog No. 41280 available; order separately.
460 Portable TRISTAND
Chain Vise
Pipe Vises
425 Portable TRISTAND
Chain Vise
40-A Portable TRISTAND
Yoke Vise
Catalog No. Model
No. Description Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
1VUV7 40185 BC210 Top Screw Bench Chain Vise 1⁄8-21⁄23-60 7¾ 11.7 1
1VUV9 40195 BC410 Top Screw Bench Chain Vise 1⁄8-4 3-100 14¾ 3.5 1
1VUW2 40210 BC610 Top Screw Bench Chain Vise ¼-6 6-150 24½ 6.8 1
1VUW4 40215 BC810 Top Screw Bench Chain Vise ½-8 15-200 37¼ 11.1 1
Bench Chain Vises
• Crank handle is anchored to base.
• Rugged cast-iron base has handy pipe rest and bender. Capacities of 1⁄8" through 8".
• Two models available for plastic pipe. Toothless jaws are neoprene-coated to prevent
scoring of pipe.
Top Screw Bench
Chain Vise
Bench Yoke Vises
• Yoke and base made of strong, dependable iron. Hardened alloy steel jaws and convenient pipe
rest and bender.
Catalog No. Model
No. Description Pipe Capacity Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
1ED98 40080 21 Bench Yoke Vise 1⁄8-2 3-50 8¾ 4.0 1
4NV31 40100 25 Bench Yoke Vise 1⁄8-4 3-100 27¾ 12.6 1
Bench Yoke Vise
Pipe Stands
Catalog No. Model
No. Description
Height Adjustment
Low-High
Max. Pipe
Capacity
Max. Weight
Capacity Weight
Grainger RIDGID in. cm in. mm lb. kg lb. kg
4CX07 56662 VJ-99 V Head High Pipe Stand 28-53 71-132 12 300 2500 1134 23 10.4
Catalog No. Model
No. Description
Height Adjustment
Low-High
Max. Pipe
Capacity
Max. Weight
Capacity Weight
Grainger RIDGID in. cm in. mm lb. kg lb. kg
3FE65 56672 RJ-99 Roller Head
High Pipe Stand 32-55 82-140 12 300 1000 454 27 12.3
A full range of heavy-duty adjustable pipe stands are available in varying configurations with capacity from 1⁄8"-36" (3mm-900 mm); suitable for use with
threading machines, roll groovers, etc.
V Head Pipe Stands
Roller Head Pipe Stands
Catalog No. Model
No. Description Height Max. Pipe
Capacity
Max. Weight
Capacity Weight
Grainger RIDGID in. cm in. mm lb. kg lb. kg
1VXG9 64642 AR99 Adj. Roller Stand
w/Steel Wheels 34 86 36 900 2500 1134 30 13.6
Adjustable Stand with Steel Rollers
Pipe Vises & StandsPipe Vises & Stands
98
Heavy-Duty Pipe Cutters
• Fast, clean pipe cutting by hand or power.
• Extra-long shank protects adjustment threads, while an extra-large handle is provided for
quick, easy adjustment.
• Can be converted to 3-wheel cutter by replacing rollers with cutter wheel, or the 2A and 4S
can be ordered as 3-wheel model for use in areas where a complete turn is not possible.
• Second handle on 3-S AND 4-S makes two-man leverage possible on
large pipe sizes.
Pipe Cutters
Nos. 3-S & 4-S
No. 2-A
Catalog No. Model
No.
Pipe Cutter
Description
Pipe Capacity
Nominal Size Weight
Grainger RIDGID in. mm lb. kg
4A506 32820 2-A Heavy-Duty 1⁄8-2 3-50 7 3.2
4CW50 32830 3-S Heavy-Duty 1-3 25-75 15 6.9
4CW51 32840 4-S Heavy-Duty 2-4 50-100 18 8.2
4-Wheel Pipe Cutters
• Designed for work in areas where a complete turn is impossible.
• No. 42-A has a short handle for use in confined areas.
• Second handle on No. 44-S makes two-man leverage possible for large pipe sizes.
• Both equipped with four heavy-duty wheels.
No. 44-S
No. 42-A
Catalog No. Model
No.
Pipe Cutter
Description
Pipe Capacity
Nominal Size Weight
Grainger RIDGID in. mm lb. kg
4CW52 32870 42-A Heavy-Duty 4-Wheel 3⁄4-2 20-50 63⁄43.1
4CW53 32880 44-S Heavy-Duty 4-Wheel 21⁄2-4 60-100 20 9.1
No. 226 In-Place Soil Pipe Cutter
• The RIDGID 226 In-Place Soil Pipe Cutter is a compact, lightweight tool
designed to cut hub and no-hub soil pipe in tight quarters.
• Only 17" long, the Model 226 is perfect for cutting cast iron, concrete and
clay pipe where space is limited.
• The Model 226 is especially suited for against-the-wall and other tight
quarter applications.
• From the Model 226’s compact design to its unique chain latching
mechanism, every feature has been engineered for maximum productivity.
No. 246 Soil Pipe Cutter
• Cuts 1½"-6" clay, cast-iron or cement pipe and 4" class 22 water main.
• Ratchet-action handle parallel to pipe allows for application in minimum width trenches.
• Complete with hand guard to protect operator’s knuckles when cutting.
No. 276 Soil Pipe Cutter
• Provides one stroke cutting of 11/2"-6" service weight, No Hub soil pipe, clay and concrete
pipe. Makes repeated cuts quickly.
• Expand capacity up to 8" service weight soil pipe by ordering Catalog No. 33665 Chain
Extension Assembly.
Catalog No. Model
No. Description
Capacity Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
1VXH1 69982 226 In-Place Soil Pipe Cutter 11⁄2-6 50-150 18 8.2 1
6YJ36 32900 246 Soil Pipe Cutter 11⁄2-6 50-150 25 11.3 1
1VXH2 74207 276 Soil Pipe Cutter 11⁄2-6 50-150 233⁄411.7 1
Ordering Information
Soil Pipe Cutters
No. 902 Torque Wrench
• Preset to eliminate guesswork in No Hub soil pipe installations.
• Assures proper coupling tightness for strong, leak-free joints.
• The 5⁄16" drive tightens with a fast ratchet action until the wrench clicks for accurate
60 inch-pounds torque.
No. 904 Torque Wrench
• The 3⁄8" drive tightens with a fast ratchet action until the wrench clicks for accurate
80 inch-pounds torque.
Catalog No. Model
No. Description Torque Weight Std.
Pack
Grainger RIDGID in. lb. NM lb. kg
1XDZ7 31410 902 Torque Wrench for No Hub
Cast-Iron Soil Pipe Couplings 60 6.8 1⁄20.2 1
1XDZ8 14988 904 Torque Wrench for No Hub
Cast-Iron Soil Pipe Couplings 80 9.0 1⁄20.2 1
Pipe/Tubing Cutter
& Preparation
Pipe/Tubing Cutter
& Preparation
1110
Pipe Cutter Replacement Wheels
Pipe Cutters
(Original Product)
Model
Catalog No.
32810
32820
32830
32840
32870
32880
32895
42370
74685
83080
83085
74700
83145
83150
74710
83165
83170
42390/34617
58657
26212
Model No.
1A
2A
3S
4S
42A
44S
202
360
466C
466S
466HWS
468C
468S
468HWS
472C
472S
472HWS
820/364
732
764
Cutter Wheels
Catalog
No
Catalog
No.
Model
No.
Standard
Pack
Blade
Exp. Application/Material
4CW85 44185 E-1032 6 .450 ▲• • • Steel Pipe & Ductile Iron
4CW86 44190 E-1032S 6 .450 ▲ ▲ ▲ ▲ S.S. Pipe
4CW59 33105 F-3 12 .312 ▲ ▲ •▲ ▲ ▲ ▲ Steel & Ductile Iron
4CW60 33110 F-3S 6 .312 ▲ ▲ ▲ ▲ ▲ ▲ ▲ S.S. Pipe
4CW62 33125 F-229 6 .411 ▲ ▲ •▲•▲ ▲ •▲ ▲ •▲•Steel & Ductile Iron
4NV23 33130 F-229S 6 .411 ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ S.S. Pipe
4CW58 33100 F-514 12 .312 • • ▲•▲ ▲ ▲ Steel & Ductile Iron
4CW61 33120 F-515 6 .411 • •▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ Steel & Ductile Iron
• Denotes Cutter Wheels furnished with original product. ▲ Denotes alternate Cutter Wheel.
Always use genuine RIDGID Cutter Wheels. These wheels are precision-machined from high-grade
steel and are engineered for long life and maximum cutting accuracy.
Pipe Reamers
• No. 2-S Spiral Ratchet Reamer – Self-feeding spiral design for extra-fast and easy hand
reaming. Model 2-S Reamer is not suitable for power reaming.
Reamers, Extractors & Taps
Pipe Extractors
• RIDGID pipe extractors make easy work of removing broken threaded ends of pipe, pipe
plugs and fittings.
• Each is plainly marked showing drill size used when solid ends of plugs and fittings must be
drilled to receive extractor.
Catalog No. Model
No.
Capacity/Pipe Size Set
includes
Weight Std.
Pack
Grainger RIDGID in. mm oz. g
1VUV3 35685 883 1⁄8 - 1 3-25 Nos. 80 to
85 Inclusive 28 794 1
Pipe Extractor Sets
No. 2-S
No. 254 No. 2&3
Catalog No. Model
No. Description Capacity Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
4A512 34955 2-S Spiral Reamer 1⁄4 - 2 6-50 71⁄43.3 1
Note: All reamers include handle.
• Combines tube O.D. cleaning and fitting I.D. brush into one hand tool.
• High carbon steel brushes quickly clean ½" or ¾" nominal tube and fittings in preparation
for soldering or brazing.
• Durable plastic construction designed for easy brush replacement.
Catalog No. Model
No. Description Weight Std.
Pack
Grainger RIDGID oz. g
1VTT4 34142 4100 I-O Copper Cleaning Brush 31⁄490.7 10
Inner-Outer Copper
Cleaning Brush
Hardened Steel Construction Inner-Outer Reamer
• 46 cutting edges on interior cone allow for fast, clean, inner reaming and outer deburring/
beveling of 1⁄2"-2" (12mm-54mm) copper and stainless steel tubing.
• Hardened steel construction.
Catalog No. Model
No. Description Weight Std.
Pack
Grainger RIDGID lb. g
3ARC6 29983 223S 1⁄4" (5 mm) through 11⁄4" (36 mm)
Copper and Stainless Tubing 3⁄4340 1
3ARC7 29993 227S 1⁄2" (12 mm) through 2" (54 mm)
Copper and Stainless Tubing 11⁄4560 1
Pipe/Tubing Cutter
& Preparation
Pipe/Tubing Cutter
& Preparation
1312
227S Inner-Outer Reamer
223S Inner-Outer Reamer
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
2RPC4 50767 258 21⁄2"-8" Pipe Cutter 105 48
Note: 700 Power Drive not included. For information on 700 Power Drive see page 23.
Transport Cart
Model No. 258XL
Model 258 for 8” to 12” Diameter Pipe
The RIDGID 258 offers 2½"-8" diameter pipe cutting capacity. Utilizing displacement type
cutter wheel technology, the patented design enables larger diameter pipe to be cut to length.
The 258 also uses the RIDGID 700 Power Drive to rotate the heavy-duty cutter wheel. Now
one person can easily square cut 8" schedule 40 pipe in minutes.
Specifications
• Cutting Capacity: Model 258: 2½"-8" schedule 10*/40 steel pipe.
• Model 700 Power Drive (not included) RPM: 26-30 (no load).
• Weight: 140 lbs. (excludes No. 700 Power Drive).
Standard Equipment
• One RIDGID 774 Square Drive Adapter.
• One 81/2" H-D Cutter Wheel Assembly.
• One Hydraulic Ram and Foot Pump.
• Two Ball Transfer Pipe Support Tools.
*Use the thin cutting wheel for best results.
Note: For optimum wheel life properly support the work piece with standard ball transfer pipe
supports (see below).
Copper Cutting Prep Machine
Model 122
Model 122 Capacity
• Copper Tube: 1⁄2" - 2" (12mm - 60mm).
• Copper Fittings: 1⁄2" - 2" (12mm - 60mm).
Designed to cut, clean, ream, and debur copper tubing and fittings quickly and professionally.
Weighing only 50 pounds, and possessing a conveniently located carrying handle, the Model
122 is ideal for transport directly to the job site. Rugged cast aluminum housing and powerful
1⁄3 HP induction motor assure long life.
Features
• Powerful, 1⁄3 HP induction motor drives rollers at 450 RPM.
• Rugged O.D. Cleaning Brush cleans tubing quickly with minimal effort.
• Core Reamer easily removes turbulence-causing burrs.
• Cutting Handle adjusts to accommodate different tubing sizes.
• Cutter Wheel tested to over 10,000 cuts.
• Guide Rollers ensure a straight cut with no tracking.
• Large Carrying Handle for easy transport to the job site.
• Built-in 1⁄2"-Incremental Scale for quick, easy measuring.
• Fitting Brush Kit includes six brushes, storage rack and collet.
• Approved by CSA to CSA and UL standards (115 V only).
Technical Specifications
• Motor: 1⁄3 HP, 115V, 60Hz Induction Motor.
• Switch: Toggle On/Off.
• Reamer: Single Flute Cone, RH, 1⁄2" to 2".
• Cutter Wheel: Model 2191 HD Wheel.
Standard Equipment
• One O.D. Cleaning Brush.
• One Core Reamer.
• One Fitting Brush Storage Kit.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
3FE66 93492 122 115V Copper Cutting/Prep Machine 1⁄2"–2" 50 22.68
The heavy-duty O.D. Cleaning
Brush cleans the outside diameter
of 1⁄2" or 2" copper tubing quickly
and easily.
The Inner Reamer removes
turbulence-causing burrs quickly
and effortlessly.
The optional fitting brush attachments
can be used to clean fittings fast.
The optional Debur Disk is used
to grind the O.D. edge to help
with tight fittings.
Power Pipe Cutter
Pipe/Tubing Cutter
& Preparation
Pipe/Tubing Cutter
& Preparation
1514
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
2RPC6 50812 E-258 8½" H-D Cutter Wheel only 2 1
2RPC5 54397 – Transport Cart 24 11
Accessories
Close Quarters Tubing Cutters
• Specifically designed for use in restricted spaces on small diameter, hard and soft copper, aluminum, brass
and plastic tubing; rollers include grooves for close-to-flare cuts.
• Strong, lightweight slide and wheel housing, large knurled feed screw knob gives easy control of cutting
pressure for clean cuts.
• Model 118 includes a self-feeding cutter wheel that automatically cuts after tightening the knob only once.
No. 118
Catalog No. Model
No. Description Std.
Wheel
Capacity Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
1ATH7 40617 101 Close Quarters Cutter* E-3469 1⁄4-11⁄86-28 1⁄2.23 6
1ATH6 32975 103 Close Quarters Cutter E-3469 1⁄8-5⁄83-16 1⁄3.15 6
4A513 32985 104 Close Quarters Cutter E-3469 3⁄16-15⁄16 5-24 1⁄3.15 6
6XW70 86127 118 Close Quarters Quick-Feed Cutter* E-3469 1⁄4-11⁄86-28 5⁄8.26 6
* Models 101 and 118 include spare cutter wheel in knob
Model 150
Spare wheel
included in knob.
X-CEL™ Knob = quicker cut.
X-CEL™ Pin =
quicker wheel change.
Catalog No. Model
No. Description Std.
Wheel
Capacity Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
1ATH8 31622 150 Constant Swing Cutter E-3469 1⁄8-11⁄83-28 1 0.44 6
Quick-Acting Tubing Cutters with New X-CEL Features
• Models 151-156 feature a quick-acting design, I-beam construction, hardened wear surfaces
and thrust bearing slide assemblies for smooth operation.
• All Models now include an X-CEL Knob and X-CEL Pin for quicker cutting
and wheel replacement.
• These cutters are available in models for plastic pipe or metallic tubing.
Spare wheel
included in knob.
X-CEL™ Knob = quicker cut.
X-CEL™ Pin =
quicker wheel change.
Spare wheel
included in knob.
X-CEL™ Knob = quicker cut.
Catalog No. Model
No. Description Std.
Wheel
Capacity Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
4CW54 32910 10 Tubing and Conduit Cutter F-158 1⁄8-1 3-25 7⁄80.40 6
5A193 32920 15 Tubing and Conduit Cutter F-158 3⁄16-11⁄85-28 1⁄20.68 6
4CW55 32930 20 Tubing and Conduit Cutter F-158 5⁄8-21⁄816-54 13⁄40.79 1
4CW56 32940 30 Tubing and Conduit Cutter E-2558 1-31⁄825-79 31⁄21.6 1
1VTU2 97212 15-SI Tubing and Conduit Cutter E-1525 3⁄16-11⁄85-28 11⁄20.68 1
Tubing Cutters
(Original Product)
Catalog No.
Grainger
4CW54
5A193
4CW55
4CW56
1ATH7
1ATH6
4A513
6XW70
1VTU2
4A514
4A515
1XDY6
4A516
1XDY4
4CW57
RIDGID
32910
32920
32930
32940
40617
32975
32985
86127
97212
31632
31642
36597
31652
31662
33055
Model
No.
10
15
20
30
101
103
104
118
15-SI
151
152
153
154
156
205
Cutter Wheels
Catalog No. Model
No.
Std.
Pack
Blade
Exp. Application/Material
Grainger RIDGID
4CW64 33165 E-1240 12 .162 ▲▲▲ Stainless Steel
4CW65 33185 E-3469 12 .149 • • • • • • • • Aluminum & Copper
4CW66 33190 E-4546 6 .162 ▲ ▲ ▲ Stainless Steel
4CW63 33160 F-158 12 .149 ••• Aluminum & Copper
1VTU3 96397 E-1525 1 .120 •Stainless Steel
6YJ37 33170 E-2558 6 .220 • • • Aluminum & Copper
• Denotes Cutter Wheels furnished with original product. ▲ Denotes alternate Cutter Wheel.
Always use genuine RIDGID Cutter Wheels. These wheels are precision-machined from high-grade
steel and are engineered for long life and maximum cutting accuracy.
Tubing Cutter Replacement Wheels
Tubing Cutters
Constant Swing Cutters with New X-CEL Features
• Telescoping feed screw design keeps the cutter at the same length regardless of tubing
diameter – good for tight spaces.
• Features an enclosed feed screw to eliminate clogging and jamming, grooved rollers for
close-to-flare cuts, and a fold-away reamer.
• Now includes X-CEL Knob and X-CEL Pin for quicker cutting and wheel replacement.
• Made from high-strength zinc alloy.
• Spare cutter wheel included in the knob.
• Cuts copper, brass, and aluminum tubing and thin-wall conduit.
Tubing & Conduit Cutters with New X-CEL Features
• Clean, square cuts are easily made on copper, brass, aluminum and thin-wall conduit.
• Now includes X-CEL Knob for quicker cutting.
• Nos. 10, 15 and 20 feature a convenient fold-away reamer.
• No. 30 is rated for larger diameter steel and stainless steel tubing.
• No. 15-SI is especially designed for stainless steel tubing. Includes special roller bearings
and cutter wheel to make stainless cutting easier.
RIDGID Quick-Acting plastic cutter models are equipped to easily convert to cut copper or other metallic tubing.
Catalog No. Model
No. Description Std.
Wheel
Capacity Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
4CW57 33055 205 Ratcheting Encl. Feed Cutter E-3469 1⁄4-23⁄86-60 2 .91 1
4A514 31632 151 Quick-Acting Cutter E-3469 1/4-15/86-42 11/40.56 6
1XDY1 31637 151-P Above w/Wheel for Plastic* E-2155 1/8-11/4** 10-40** 11/4.056 6
4A515 31642 152 Quick-Acting Cutter E-3469 1/4-25/86-66 2 0.92 1
1XDY2 31647 152-P Above w/Wheel for Plastic* E-2155 1/4-2** 10-63** 2 0.92 1
1XDY4 36597 153 Quick-Acting Cutter E-3469 11/4-31/232-90 2 0.92 1
1XDY3 36592 153-P Above w/Wheel for Plastic* E-2155 1-3** 25-75** 2 0.92 1
4A516 31652 154 Quick-Acting Cutter E-2558 17/8-41/248-116 37/81.72 1
1XDY5 31657 154-P Above w/Wheel for Plastic* E-2156 11/2-4** 50-110** 37/81.72 1
1XDY6 31662 156 Quick-Acting Cutter E-2558 4-6 5/8100-170 5 2.23 1
*Plastic models do not include a spare cutting wheel
**Nominal Plastic Pipe Size
X-CEL™ Means Speed
Many of our most popular tubing cutters now include several X-CEL features to make your job quicker and easier.
• X-CEL Knob – cut tubing more quickly and easily with our larger, more ergonomic designs.
• X-CEL Wheel Pin – change your cutter wheel quickly using our new ball detent design…no tool needed…no lost clips!
• Spare cutter wheels included for maximum uptime.
Pipe/Tubing Cutter
& Preparation
Pipe/Tubing Cutter
& Preparation
1716
1.) Remove spare copper cutting wheel from knob.
2.) Reverse knob position so that the “Cu” notation is visible inside the knob.
3.) Screw knob back on to handle.
4.) Using the X-CEL Wheel Pin, you can quickly replace the existing plastic
cutting wheel with the copper cutting wheel. You’re now ready to cut
copper, aluminum, and brass tubing.
5.) When you wish to revert to plastic cutting, follow the same instructions
but make sure to reposition knob so that “PE” and “PVC” notations are
visible inside knob.
Single Stroke Cutter
• Patent pending, X-CEL blade for fast single stroke cutting. No ratcheting or twisting required.
• Extra large 1.375" O.D. capacity.
• Ergonomic grips on bottom handle are spaced at 1⁄2" increments to
act as a quick pipe measuring scale.
• Replaceable, hardened steel cutting blade.
• Spring-loaded handles provide instant adjustment to any pipe size.
• “Burr-less” cutting operation provides a square cut.
Catalog No. Model
No. Description Capacity (O.D.) Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
1XDX7 23493 PC-1375 Single Stroke Plastic Pipe
and Tubing Cutter
1⁄8" – 13⁄8" 12-42 3⁄41.36 6
Plastic Pipe Cutters
Model PC-1375
Model RC-1625
Catalog No. Model
No. Description Capacity (O.D.) Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
2CVH7 23488 PC-1250 Scissor-Style Plastic Pipe
& Tubing Cutter 1⁄8-15⁄812-42 1⁄20.20 6
Scissor-Style Cutter
• X-CEL blade – Quick change, reversible blade provides two times blade life.
• Spring loaded handles for faster positioning.
Ratchet Cutter with Ergonomic Grips
• Ergonomic grips on bottom handle are spaced at 1⁄2" increments to act as a quick pipe measuring scale.
• X-CEL quick-change blade.
• “Burr-less” cutting operation provides a square cut.
Catalog No. Model
No. Description
Capacity
(O.D.) Weight Std.
Pack
Grainger RIDGID in. mm lb. kg
2DPH3 23498 RC-1625 Ratchet Action Plastic Pipe & Tubing Cutter 1⁄2-15⁄812-42 13⁄16 0.52 6
2DPH4 27858 RCB-1625 RC-1625 Replacement Blade – – 1⁄80.03 1
3ARC4 30088 RC-2375 Ratchet Action Pipe & Tubing Cutter 1⁄2-23⁄83-63 17⁄80.90 6
3ARC5 30093 RCB-2375 RC-2375 Replacement Blade – – 1⁄40.10 1
Model PC-1250
Manual Ratchet Threaders
All matched Threader/Sets include Die Heads, Ratchet Assembly, Ratchet Handle and Alloy Dies. All Threader Sets use same 12-R Dies in Die Head.
Exposed Ratchet Threader Set
• No. 12-R: Capacity 1⁄8"-2" with carrying case.
Catalog No. Model No. NPT Capacity Weight
Grainger RIDGID in. mm lb. kg
4A508 36475 12-R ½-2 12-50 34¾ 15.8
Ratchet & Handle Only
Ratchet knob indicates forward and reverse. Die heads snap in from both
sides and lock in place.
Catalog No. Model
No. Description
Grainger RIDGID
3AFP4 38555 12-R Ratchet & Handle Only
Catalog No. Model No. Description Nominal Pipe
Size (in.)
Grainger RIDGID
4NV24 37390 12-R NPT 1⁄2
4NV25 37395 12-R NPT 3⁄4
4NV26 37400 12-R NPT 1
4NV27 37405 12-R NPT 11⁄4
4NV28 37410 12-R NPT 11⁄2
4NV29 37415 12-R NPT 2
Die Heads
For Ratchet Threaders – 12-R NPT
Catalog No. Description Nominal Pipe Size
Threads Per Inch
Grainger RIDGID
4A509 37825 Alloy RH 1⁄2-14
4A510 37830 Alloy RH 3⁄4-14
4A511 37835 Alloy RH 1-111⁄2
4CW67 37840 Alloy RH 11⁄4-111⁄2
4CW68 37845 Alloy RH 11⁄2-111⁄2
4CW69 37850 Alloy RH 2-111⁄2
4CW71 37870 High-Speed RH 1⁄2-14
4CW72 37875 High-Speed RH 3⁄4-14
4CW73 37880 High-Speed RH 1-111⁄2
4CW74 37885 High-Speed RH 11⁄4-111⁄2
4CW75 37890 High-Speed RH 11⁄2-111⁄2
4CW76 37895 High-Speed RH 2-111⁄2
4CW77 37915 High-Speed for Stainless Steel RH 1⁄2-14
4CW78 37920 High-Speed for Stainless Steel RH 3⁄4-14
4CW79 37925 High-Speed for Stainless Steel RH 1-111⁄2
4CW80 37930 High-Speed for Stainless Steel RH 11⁄4-111⁄2
4CW81 37935 High-Speed for Stainless Steel RH 11⁄2-111⁄2
4CW82 37940 High-Speed for Stainless Steel RH 2-111⁄2
Pipe Dies
For Ratchet Threaders
Pipe/Tubing Cutter
& Preparation Threading
1918
Manual Receding Threaders
No. 65R-C
• Threads 1"-2" pipe.
• Jam-proof drive pawl.
• Cam workholder sets
instantly.
• Right-hand only.
Catalog No. Model
No. Description
Capacity
Nominal
Pipe Size
Weight
Grainger RIDGID in. mm lb. kg
1XDZ5 96720 – Metal Carrying Case for 65R Series Threaders – – 8 3.7
1XDZ4 36565 65R-C NPT with 1 Set High-Speed Dies 1-2 25-50 25 11.4
Receding Geared Threaders
Catalog No. Model
No. Description
Capacity
Nominal Pipe
Size
Weight
Grainger RIDGID in. mm lb. kg
6YJ38 36620 141 NPT with 1 Set High-Speed Dies 21/2-4 62-100 93 42.3
Geared Threader Accessories
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
6YJ35 19366 758 Loop (141 with 300 Power Drive) 1¼ 0.6
6YJ40 42405 844 Drive Bar (300, 535M & old style) 5¾ 2.6
No. 758 Loop
No. 844 Drive Bar
Pipe Dies for 141
Geared Pipe Threaders
Catalog No. Description NPT Size
Thread Per Inc
Grainger RIDGID
1VTV1 38120 High-Speed RH 21⁄2-4-8
No. 418 Oiler
The Model 418 hand-held oiler is sturdier than ever before. The 418's pump assembly and
heavy-duty reservoir are designed to increase productivity.
Pump Assembly
• 50% more oil per stroke than other hand-held oilers for longer die life.
• An ergonomic 2-finger trigger design that reduces user fatigue.
• Die cast, heavy-duty body with swivel nozzle with no exposed parts for longer life.
Heavy Duty Reservoir
• The 418 oiler features a patent pending fastenerless twist and lock drip
pan that easily locks in place.
• The material withstands abrasion, is lighter than metal and does not rust.
• The reservoir will not crack or leak.
• Material is so strong that under normal use, no dents will form on impact
or shape changes will occur over time. As a result, the drip pan will fit squarely
on the reservoir time after time.
• Integral molded body eliminates leaks at the hose-reservoir connection.
• Convenient anti-slip grip design with integral hook for easy hanging.
Cutting Oil
Oiler
Thread Cutting Oil
• Cools threads and pipe during operation.
• Speeds metal removal.
• Improves thread quality.
• Reduces threading torque.
RIDGID thread cutting oils are free of chlorine and other halogens, PCBs and heavy metals.
Complete material safety data sheet available.
Dark Oil – Traditional mineral oil with low odor and anti-mist formulation.
Nu-Clear® Oil – Clear mineral oil with low odor and anti-mist formulation.
Special low temperature properties maintain workable viscosity to -20°F.
Extreme Peformance Oil – High performance mineral oil formulated to produce superior
quality threads on stainless steel and black pipe.
Catalog No.
Description
Container Size Containers
Per Case
Weight
U.S. Metric
Grainger RIDGID lb. kg
6YJ44 70835 Nu-Clear 1 Gal. 3.78 L 6 50 22.7
6YJ43 70830 Dark 1 Gal. 3.78 L 6 50 22.7
2RPA9 74012 Extreme Performance 1 Gal. 3.78 L 6 50 22.7
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1ED22 10883 418 Hand operated oiler complete. Includes 1 gallon thread cutting oil,
reservoir with removeable chip tray, and 54" hose. 201⁄29.4
1VUT2 72332 #4 Hand-operated oiler only. 11⁄40.5
1VUR9 72327 #4 Hand-operated oiler with 54" hose and hose fittings. 21⁄41.0
Nos. 141
• 141 threads 2½", 3", 3½",
4" pipe with one set of dies.
• Jaw clutch prevents
jamming.
• Simple adjustment for tapered or
straight threads.
• Cam-type workholder sets instantly.
• Fully enclosed gearing.
• Right-hand only.
ThreadingThreading
2120
Model 600 Power Drive
• A hand-held, powerful, portable power drive.
• Features a reversible 115V universal motor.
• Capacity 1⁄8"-1¼" (3mm-32mm) pipe. Designed for RIDGID 11-R die heads.
• Ideal for on-site applications such as gas line pipe installation.
• Approved by CSA to CSA and UL standards (115V only).
Technical Specifications
• Motor: 1⁄2 HP Universal 115V, 50/60 Hz.
• Switch: Heavy-duty paddle-type switch with safety lock off switch.
Separate FORWARD/REVERSE switch.
• Gear Housing: Aluminum.
• Body & Handle: Durable heavy-duty fiberglass reinforced plastic.
• Spindle Speed: 32 RPM (No load).
• Capacity: 1⁄8"-1¼" (3mm-32mm) pipe.
• Die Heads Included: ½, ¾, 1, 1¼ (Type 11-R).
• Includes No. 601 support arm.
• Length: 20 in. (51 cm).
Hand-Held Power Drives
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
5A189 36912 600 115V ½"-1¼" NPT w/Case and Support Arm 36 16.4
Model 690 Power Drive
The 690 Power Drive is a new lightweight and powerful hand-held power drive. It is
designed for threading 1⁄8" - 2" pipe with the use of 11-R Die Heads. The 690 comes
equipped with a full set of 11-R Die Heads, ½" - 2", the 691 Support Arm and a durable
Carrying Case. The 690 Power Drive is the perfect lightweight and portable power drive
for maintenance and repair workers, as well as service plumbers requiring 2" pipe
capacity.
• Capacity: 1⁄8" - 2" (3 - 51 mm) pipe.
• Length: 24 in. (61 cm).
• Motor: Universal 1020 Watt, 115Volt, 50/60 Hz.
• Approved by CSA to CSA and UL standards (115V only).
• Switch: Heavy-duty paddle switch with safety lock-off device (automatically locks off
when released). Separate FORWARD/RELEASE switch.
• Gear Head: Spur gear reduction/face gear drive. All shafts, ball and needle bearing
mounted. Permanently lubricated gear housing.
• Gear Housing: Die cast aluminum.
• Body & Handle: Durable, heavy-duty, fiberglass-reinforced, industrial plastic.
• Spindle Speed: 32 RPM.
• Die Heads: ½", ¾", 1”, 11⁄4", 1½", 2" (type 11-R).
• Includes Support Arm: No. 691.
• Die Head Adapter: Used with 1⁄8” through 1¼" die heads.
• Carrying Case.
No. 690 with Support Arm,
Die Heads and Carrying Case
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1VUT7 16013 690 115V ½"-2" 25-60 NPT with Case & Support Arm 521⁄224
ThreadingThreading
2322
Model 700 Power Drive
• Heavy-duty hand-held power drive.
• Capacity 1⁄8"-2" (3mm-50mm) pipe, 1⁄4"-1" bolt with OO-RB die heads. Designed for
RIDGID No. 12-R die heads. Other RIDGID die heads (OO-R, OO-RB, 11-R) using adapters,
threading 2½" through 6" (62mm-150mm) with 141/161 geared threaders. Also used with
258/258XL pipe cutters.
• Approved by CSA to CSA and UL standards (115V only).
Technical Specifications
Motor: Universal, ½ HP, 115V 50/60 Hz.
Switch: Double-throw reversible.
Gear Head: Spur gear reduction face gear drive. Spring-loaded adapter pawls.
Hardened steel spindle gear.
Body: Cast aluminum.
Spindle Speed: 26-30 RPM (no load).
Capacity: 1⁄8"-2" Pipe (30mm-50mm).
¼"-1" (6mm-25mm) Bolt (using OO-RB).
Weight: 25 lbs. (11 kg) Power Drive only.
Length: 28¼" (71.7 cm).
Optional Carrying Case
Catalog No. Model
No. Description
Pipe Threading
Capacity
Rod Threading
Capacity
Max. Geared
Threader
Capacity
Weight
Grainger RIDGID in. mm in. mm in. mm lb. kg
1AC02 41935 700 115V 50/60 Hz
Only 1⁄8-2 3-50 ¼-1 6-25 6 150 31 14
Catalog No. Model
No. Accessories Description Weight
Grainger RIDGID lb. kg
1XDZ6 42620 774 Square Drive Adapter - 15⁄16" 5¼ 2
1VUR1 42625 775 Support Arm for No. 700 11 5
4NV34 42950 B-171-X Metal Carrying Case 29 13
Threading using a pipe wrench
as a support arm.
Mounted Power Drive
Model 300 Power Drive Only
• RIDGID speed chuck.
• Reversible ½ HP universal motor.
• Capacity: 1⁄8"-2" (3mm-50mm) pipe, 2¼"-4" with 141, and 4"-6" with 161 Geared Threaders; ¼"-2" (6mm-50mm) rod.
• Recessed On/Off/Reverse switch.
• Ideal for use with RIDGID roll groovers.
• 115V, 38 RPM approved by CSA to CSA and UL standards.
Technical Specifications
• Motor: ½ HP, universal, reversible motor, single-phase, 50/60 Hz, 115V (230V available).
• Switch: Heavy-duty FOR/OFF/REV and Integral Foot Switch.
• Chuck: RIDGID speed chuck with replaceable rocker-action jaws.
• Spindle Speed: 38 RPM.
• Rear Centering Device: Cam-action turns with chuck.
• Support Bar: Heavy-duty (2).
Catalog No. Model
No. Description
Spindle
Speed
RPM
Pipe Threading
Capacity
Rod Threading
Capacity
Max. Geared
Threader Capacity Weight
Grainger RIDGID in. mm in. mm in. mm lb. kg
1VXG8 41855 300 Only 115V, 50/60 Hz 38 1⁄8-2 3-50 ¼-2 6-50 6 150 94 43.0
Hand-Held Power Drives
ThreadingThreading
2524
Model 300 Power Drive Complete
for Portable Threading
Standard Equipment
• Die heads and dies for use with 300 Power Drive with 311 carriage.
• No. 360 Cutter: Capacity: 1⁄8"-2" (3mm-50mm) pipe, ¼"-7⁄8"
(6mm-2mm) rod with F-3 wheel, 5⁄16"-1" (8mm-25mm) with E-1032
cutter wheel.
• No. 341 Reamer: Positive-locking, 5-flute cone, right-hand 1⁄8"-2"
(3mm-50mm). Special E863 RH/LH combination reamer cone available.
• No. 311 Carriage with lever.
• No. 1206 Stand.
• No. 1452 Clip-on tool tray.
• No. 418 Oiler with 1 gallon of Nu-Clear thread cutting oil.
• No. 32 Transporter.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1VTV2 42360 1206 Stand for 300 Power Drive 31 14.1
1VTV3 42365 341 Reamer for No. 311 Carriage with Lever 7 3.2
1VUP6 42370 360 Cutter for No. 311 Carriage 8½ 3.9
4Z974 97065 811A Universal Q.O. Die Head Only, Right-Hand Only 12½ 5.7
5A195 97075 815A Self-Opening Die Head Only, Right-Hand Only 13½ 6.1
1VUR3 44505 – On/Off/Rev Switch 3⁄40.3
1VUR5 44715 – Jaw Inserts 1⁄40.1
1VUR7 51005 819 Nipple Chuck Complete, 1⁄2"-2" (12mm-50mm) 101½ 4.8
1VUR9 36642 – Footswitch 8 3.6
1VUT4 97365 – Jaw Inserts for Coated Pipe 1⁄40.1
No. 32 Transporter
Die Heads
and Dies No. 360
Cutter
No. 311
Carriage
with lever
No. 341
Reamer
No. 1206
Stand
No. 1452 Clip-On
Tool Tray
No. 418 Oiler
Catalog No. Model
No. Description
Spindle
Speed
RPM
Pipe Threading
Capacity
Rod Threading
Capacity
Max. Geared
Threader Capacity Weight
Grainger RIDGID in. mm in. mm in. mm lb. kg
3Z987 15682 300 Complete 115V, 50/60 Hz (NPT) 38 1⁄8-2 3-50 ¼-2 6-50 6 150 212 96.2
Model 535 Threading Machine
Capacities
• Pipe: 1⁄8"-2" (3mm-50mm) 21⁄2"-4" (62mm-100mm),
4"-6" (100mm-150mm) with 141 and 161 geared threaders.
• Bolt: 1⁄4"-2" (6mm-50mm).
The Model 535 maintains the ruggedness of the industry workhorse
while adding the features that makes the threading operation more
productive.
Features
• Large 1.75 gallon oil tray.
• 100% larger chip tray.
• Generous top cover for keeping tools and fittings handy.
• High clearance carriage.
• Speed chuck with rocker-action jaws centers and grips work
piece instantly.
• Can be used with geared threaders Models 141 and 161.
• Uses Model 815A self-opening or Model 811A quick-opening
die heads.
• Length gauge for quick, accurate cut-off.
• Approved by CSA to CSA and UL standards (115V only).
Technical Specifications
• Motor: 1⁄2 HP, single-phase, 115V, 50/60 Hz, 15 amp reversible
universal motor (36 RPM).
• Switches: FOR/OFF/REV and Integral safety foot switch.
• Chuck: Speed Chuck™ with replaceable rocker-action jaw
inserts (3).
• Rear Centering Device: Cam-action, turns with chuck.
• Cutters: Self-centering, full-floating. No. 820 Wheel-Type Cutter,
pipe capacity 1⁄8"-2" (3mm-50mm), bolt capacity 1⁄4"-1"
(6mm-25mm).
• Spindle Speed: 36 RPM standard (no load), 54 RPM model also
available.
• Reamer: 5-flute cone, RH, 1⁄8"-2" (3mm-50mm).
• Oil Pump: Self-priming gerotor oil pump.
• RH/LH combination reamer available.
Standard Equipment
Model No. 535 threading machine with foot switch:
• One No. 811A universal quick opening die head.
• One No. 341 reamer.
• OneNo. 820 cutter.
• One set 1⁄2" - 3⁄4" universal alloy dies.
• One set 1" - 2" universal alloy dies.
• One gallon premium oil.
• Four hex wrenches.
• One spare E-1032 cutter wheel.
Model 535
Catalog No. Model
No.
Description
115V 50/60 Hz
Cutter
Model RPM Volt Weight
Grainger RIDGID lb. kg
3RY43 93287 535 1⁄2"-2" NPT 820 36 115V 260 117.9
Threading Machines
Accessories
Accessories
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1VUP8 42390 820 Wheel-Type Cutter 81⁄23.9
ThreadingThreading
2726
Model 1215 Threading Machine
Capacities
• Pipe: 1⁄4"-11⁄2" (6mm-37mm).
• Bolt: 5⁄16"-1" (6mm-25mm).
Features
• Compact, lightweight design.
• One-piece aluminum housing.
• Two easy-to-use carrying handles.
• Integral foot switch hanger.
• Powerful motor and transmission.
• Through die head oiling.
• Adjustable oil flow control.
• Approved by CSA to CSA and UL standards (115V only).
Technical Specifications
• Motor: 1⁄2 HP universal motor 50/60 Hz.
• Motor Control: ON/OFF heavy duty switch and integral foot switch.
• Spindle Speed: 44 RPM right hand operation.
• Front Chuck: Hammer type with replaceable rocker action jaw inserts.
• Rear Centering Device: Cam action.
• Cutter: Model 732.
• Reamer: Model 344, 1⁄4"-11⁄2".
• Oiling: Through die head adjustable.
• Pump: Self-priming constant flow, gerotor type.
Standard Equipment
• One No. 811A Quick Opening Die Head.
• One Set 1⁄2"-3⁄4" Universal Alloy NPT Dies.
• One Set 1"-11⁄2" Universal Alloy NPT Dies.
• One No. 344 Five Fluted Reamer 1⁄4"-11⁄2".
• One No. 732 Cutter with Cutter Wheel.
• One Gallon Nu-Clear Oil.
Machine Accessories
Model 1215
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1XDZ9 61142 1215 1⁄2"-11⁄2" NPT, 115V, 60Hz 69 30
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1XEA1 61187 1203 Tripod Stand 15 6.8
Threading Machines
Model 300 Compact Threading Machine
Capacity
• Pipe: 1⁄8" - 2" (3mm-50mm).
• Bolt: 1⁄4" - 2" (6mm-50mm).
Features
• Heavy-duty proven performance.
• Lightweight, portable design.
• Fast transport and set-up.
• Self-Contained Oil System with adjustable flow control.
• Versatility for threading and grooving.
• Quiet operation.
• Approved by CSA to CSA and UL standards (115V only).
Technical Specifications
• Motor: 1⁄2 HP, 115V universal 50/60 Hz.
• Motor Control: Heavy duty rotary FOR/OFF/REV with integral foot switch.
• Spindle Speed: 38 RPM (52 RPM available).
• Chuck: Hammer-type with replaceable, rocker-action jaw inserts.
• Oiling System: Through-the-head, with integral oil reservoir. Self-priming,
constant-flow, gerotor pump.
• Cutter: Model 360, roll-type cutoff, self-centering, full-floating.
• Reamer: Model 344, 1⁄8"-2", five flute cone, right hand only.
Standard Equipment
Model 300 Compact Threading Machine:
• One No. 811A Quick-opening die head.
• One No. 344 Reamer.
• One No. 360 Cutter with E-1032 Cutter Wheel.
• One Set 1⁄2" - 3⁄4" Alloy Universal Dies.
• One Set 1"- 2" Alloy Universal Dies.
• One Gallon Nu-Clear Threading Cutting Oil.
• Model 1250 Folding Wheel Stand.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
3FE64 67182 300 Compact Kit 1⁄2" - 2" NPT, 115V, 50/60 Hz
– includes Model 250 Folding Wheel Stand
160 72.7
ThreadingThreading
2928
Model 1822-I Threading Machine
Capacities
• Pipe: 1⁄8"-2" (3mm-50mm) 21⁄2"-4" (62mm-100mm)
with No. 141 geared threader.
• Bolt: 1⁄4"-2" (6mm-50mm).
Features
• Heavy Duty Automatic Chucking. Threads a wide range of material including
black and galvanized pipe, stainless steel, IMC, PVC and heavy-wall conduit.
• Induction motor (81 db) delivers constant 45 or 16 RPM as required.
• Constant and proper lubrication of dies and workpiece with through-head oiling.
• Triple filtration provides for longer oil pump life and clean threads.
• Special jaw inserts allow for quick, easy replacement.
Technical Specifications
• Motor: 11⁄2 HP, single-phase, 60 Hz.
• Motor Control: Open/Off/Close, heavy-duty rotary type switch and integral
safety foot switch.
• Spindle Speed: 45 and 16 RPM, right-hand, can be adapted to
left-hand operation.
• Transmission: Two-speed (45 RPM for up to 11⁄4" pipe and 1" bolt, 16 RPM for
low voltage and higher torque applications).
• Front Chuck: Automatic gripping/centering.
• Rear Centering Device: Automatic, centering only.
• Cutter: Model 364, 1⁄8"-2" full-floating, self-centering with E-1032 Cutter Wheel.
• Reamer: Model 344, 1⁄8"-2" right-hand only.
• Clutch: Shiftable cone type.
• Oil Pump: Self-priming gerotor.
Standard Equipment
Model No. 1822-I threading machine with foot switch.
• One No. 815A universal self-opening die head.
• One No. 344 reamer.
• One No. 364 cutter with E-1032 cutter wheel.
• One set 1⁄2"- 3⁄4" universal alloy dies.
• One set 1"- 2" universal high speed dies.
• One gallon Nu-Clear oil.
Machines
Model 1822-I
Shown on optional
stand – see page 31
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
5A191 20000 1822-I 1/2"-2" NPT 120V 60 Hz 240 109.1
Stands
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1EZ17 92462 150A Universal Wheel & Tray Stand 103 46.7
2ZB62 92467 200A Universal Wheel & Cabinet Stand 104 74.5
Threading Machines
Model 1224 Threading Machine
Capacities
• Pipe: 1⁄4"-4" (6mm-100mm) 4"-6" (100mm-150mm) with
161 Geared Threader.
• Bolt: 1⁄4"-2" (6mm-50mm).
Features
• Threads 1⁄4"-2" pipe at 36 RPM and 21⁄2"-4" at 12 RPM.
• The 1224 threads a wide range of pipe including black, galvanized
and plastic-coated pipe, together with stainless steel, IMC and
heavy-wall conduit, as well as rod up to 30 Rockwell C.
• An induction motor insures sound levels well within the limits
set by the regulating authorities.
• A special capacitor-start / capacitor-run motor allows the 1224 to
thread a full range of material where voltage drop is experienced.
• 1⁄4"-2" Universal Die Head; 21⁄2"-4" receding die head allows cutting
of tapered or straight NPT/NPSM or BSPT/BSPP threads.
• Constant and proper lubrication of dies and workpiece with
through-head oiling.
• Approved by CSA (115V only).
Technical Specifications
• Motor: 11⁄2 HP, single-phase, 60 Hz or 50 Hz, induction type.
• Motor Control: Reverse/Off/Forward, heavy-duty rotary-type and
integral foot switch.
• Spindle Speed: 36/12 RPM.
• Gear Box: Two-speed gear box 3:1 ratio.
• Chuck: Hammer-type with replaceable rocker-action jaw inserts.
• Rear Centering Device: Cam action.
• Cutter: Model 764 full-floating, self-centering 1⁄4"-4" with
F-229 cutter wheel.
• Reamer: Model 744, 1⁄4"-4" blade-type.
• Oiling: Through die head.
• Pump: Self-priming, gerotor-type, automatic-reversing, constant-flow.
Model 1224
Shown on optional
stand – see page 31
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
4CW39 26092 1224 1⁄2-4 NPT 120V 60 Hz 509 231.0
Stands
1EZ17 92462 150A Universal Wheel & Tray Stand 103 46.7
2ZB62 92467 200A Universal Wheel & Cabinet Stand 164 74.5
Pipe Dies 21⁄2"-4"
4CW41 26192 – 1224 H.S. Dies NPT 21⁄41.0
Die Heads
4CW40 26132 711 Universal Self-Opening R.H., NPT 121⁄25.6
Accessories
1VTU6 34577 – 1⁄4"-4" Reamer Blade 1⁄20.2
Standard Equipment
Model No. 1224 threading machine with foot switch.
• One No. 714 (914) 21⁄2"- 4" receding self-opening die head.
• One No. 711 (911) 1⁄4"- 2" universal self-opening die head.
• One set 1⁄2"- 3⁄4" universal alloy dies.
• One set 1" - 2" universal alloy dies.
• One set 21⁄2"- 4" 1224 high-speed dies.
• One gallon Nu-Clear oil.*
• Three (3) hex keys.
• One spare F-229 cutter wheel.
• One 3⁄4" combination wrench.
• One tool box.
• One No. 744 reamer.
• One No. 764 cutter.
ThreadingThreading
3130
Catalog No. Description Nominal Pipe Size
Threads Per Inch
Grainger RIDGID
4Z975 47735 Alloy RH 1⁄8-27
4Z976 47740 Alloy RH 1⁄4-3⁄8-18
4Z977 47745 Alloy RH 1⁄2-3⁄4-14
4Z978 47750 Alloy RH 1-2-111⁄2
4CW92 47760 High-Speed RH 1⁄4-3⁄8-18
4CW93 47765 High-Speed RH 1⁄2-3⁄4-14
5A196 47770 High-Speed RH 1-2-111⁄2
4CW94 47780 High-Speed for Stainless Steel RH 1⁄4-3⁄8-18
4CW95 47785 High-Speed for Stainless Steel RH 1⁄2-3⁄4-14
4CW96 47790 High-Speed for Stainless Steel RH 1-2-111⁄2
NPT Pipe Dies for
Machine Die Heads
Pipe Dies for use in Universal Die Heads
(Nos. 504A, 711, 713, 811A, 815A, 816, 817 and 842)
Machine Stands
No. 150A
Steel Cabinet Features
• 17-gauge steel walls and welded construction.
• Two internal and one external storage shelves.
• Oversized bi-fold door with steel clasp.
• Cut-outs for power cord and foot switch storage.
• Two drain plugs for easy cleaning.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1EZ17 92462 150A Universal Wheel & Tray Stand 103 46.7
2ZB62 92467 200A Universal Wheel & Cabinet Stand 104 74.5
No. 200A with Steel Cabinet
Manual Roll Groover
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1ED99 88232 915 915 Roll Groover with 2" - 6" Sch. 10 (2" - 31⁄2" Sch. 40) Roll Set 23 10.4
1EZ10 93497 – 915 Tool Box 211⁄29.7
915 Manual Roll Groover
The new RIDGID 915 Roll Groover is a manual roll groover for in-place field applications. The
915 requires only 3½" of clearance to travel around a pipe and a minimum of 2¾" of exposed
pipe for grooving. With the appropriate roll sets, the 915 can groove from 1¼" to 12" pipe, the
widest range in its class! The 915’s cast-in handle allows for easy transport or chaining the
groover down to prevent theft. The 915 is a must for service work crews.
Features
• Lightweight design – only 23 pounds.
• Easy roll set change out – up to 12" pipe capacity in one unit for service versatility.
• Cast-in carrying handle – easy to transport or lock up to prevent theft.
• Included ratchet – 90 degree bend-in handle makes grooving easier.
• Available customized tool box – holds 915 groover and all available roll sets.
• Easy to use depth setting gauge – helps make accurate grooves.
Specifications
Capacity:
– 2"- 6" Sch. 10 Steel Pipe.
– 2"- 3½" Sch. 40 Steel Pipe.
• Operation: Feed screw with 1⁄2" ratchet wrench (included).
Standard Equipment
• 915 Roll Groover with 2"- 6" Sch. 10 (2"- 31⁄2" Sch. 40).
• Roll Set Ratchet Wrench.
Model 915
Accessories
Roll GroovingThreading
3332
Model 975 Combo Roll Groover
The Model 975 Combo Roll Groover is two tools in one. Like other RIDGID roll groovers, the
975 mounts on the RIDGID® 300 Power Drive for machine-powered roll grooving jobs, but it is
also designed to manually roll groove in-place pipe.
Auto Tracking & Depth Setting Gauge Means Easier Use
The 975 Combo Groover includes new, patented auto tracking technology for significantly
easier grooving. Whether you’re doing machine-powered or manual grooving, the AutoTrack
gauge keeps the pipe automatically engaged to the groover throughout the grooving process.
The 975 also includes a permanently-fixed depth setting gauge for quicker, repeatable set-up.
Less Hand-Force Required
When manually roll grooving, the 975’s 55% higher gear reduction means less hand-force is
required versus competitive manual roll groovers. This is especially helpful for over-head roll
grooving.
Durability And Portability
A tough, ductile iron construction means the 975 can absorb job site abuse and provide ac-
curate grooves time after time. A cast-in handle makes the 975 easily portable to and from the
job site.
Specifications
• Pipe Capacity:
– 11⁄4"- 6” Schedule 5, 10 and Schedule 40 Steel, Aluminum and PVC Pipe.
– 11⁄4"- 6” Schedule 5, 10 and 11⁄4"- 2" Schedule 40 Stainless Steel Pipe.
• Depth Adjustment: Adjusting screw and integral, index depth gauge.
• Actuation: Feed screw with 1⁄2" ratchet wrench (included) or any 15⁄16" hex wrench.
• Power Drive Mounting: RIDGID 300 Power Drive 38/57 RPM
(Reverse Direction Only).
Ordering Information
Model 975
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
3ARC8 25638 975 975 Combo Roll Groover 26.1 11.9
Combination Manual or
Powered Roll Groover
Power-Driven 916 Roll Groover
The RIDGID Model 916 Roll Groover is the most durable and efficient lightweight portable unit
available. Built with a solid, durable cast-iron housing, it withstands heavy usage, yet is light
enough for easy transportation. The 916 features a patented single stroke feed mechanism
that allows for accurate operation quickly and effortlessly.
Features
• Specifically designed for field service roll grooving applications.
• Quick and easy mount to RIDGID Nos. 300 Power Drive, 535 or 1822 Threading Machines.
• Cam-type feed actuation – translates into minimum operator effort to form roll grooves.
• Durable cast-iron housing withstands extensive field use.
• Depth adjustment screw separate from feed mechanism allows for consistent groove depth.
• Lightweight, only 33 lbs., allows for easy transport and storage.
• Integral feed handle is part of overall unit. No extra tools required.
• Easy serviceability – drive and groove rolls are easy to change.
Standard Equipment
• One 1¼"- 6" Roll Groove Set for steel. (1¼"- 6" schedule 10, 1¼"- 3" schedule 40).
Ordering Information
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
2RPC2 45007 916 Roll Groover for 300 Power Drive 33 15
Note: A Roll Set consists of a Groove Roll and a Drive Roll.
Model 916
Roll GroovingRoll Grooving
Powered Roll Groover
3534
400 Series Instrument Benders
• Combine accuracy with easy operation.
• Offset cushion grip handles for comfort when forming 180° bends. A 90° start angle
and unique oil-absorbing shoe minimize bending effort while forming accurate bends
in copper, steel and stainless steel tubing.
Catalog No. Model
No. Description
Capacity Weight
Tube Size
(actual O.D.) Bend Radius lb. kg
Grainger RIDGID
4A520 36122 404 Lever Bender ¼" 5⁄8" 11⁄20.68
4A521 36097 406 Lever Bender 3⁄8"15⁄16" 23⁄41.18
4A522 36132 408 Lever Bender 1⁄2" 11⁄2" 51⁄22.45
Benders
Model 456 Tri-Bender
• Designed to easily bend three different sizes of soft tubing:
1⁄4", 5⁄16" and 3⁄8" with the same tool. Ideal for plumbing and HVAC applications.
• A 90° start angle minimizes effort required to form a bend. Handy reference marks
indicate the angle for quick bends through 90°.
500 Series Heavy-Duty Instrument Benders
• Specially designed for bending stainless steel, titanium and other types of hard tubing.
• A unique two-stage handle design and rollers in the bending handle combine to produce high
quality bends with significantly less effort than with conventional benders.
Catalog No. Model
No. Capacity Weight
Grainger RIDGID lb. kg
1ATH9 44852 456 1⁄4", 5⁄16", 3⁄8" 14 0.4
Catalog No. Model
No. Description Capacity Bend Radius Weight
Grainger RIDGID lb. kg
4CX01 51912 506 Lever Bender 3⁄8"15⁄16" 31⁄21.45
4CX02 51917 508 Lever Bender 1⁄2" 11⁄2" 61⁄22.95
Geared Ratchet Tube Benders
• High geared mechanical ratios, bend heavy-wall steel tube (up to 1⁄8" wall thickness),
stainless steel tube (up to 3⁄32" wall thickness) and hard copper water tube (types K and L).
• Benders produce uniform bends up to 180°, with no need to anneal tubing or use
special temper grade tubing.
• Reduce bending effort to a minimum.
Catalog No. Model
No.
Radius to Center
of Tube Tube O.D. Weight Std.
Pack
Grainger RIDGID in. mm in. mm lb. kg
1VTT6 35170 358 3 76 5⁄816 71⁄23.25 1
1VTT7 35175 368 33⁄495 3⁄419 131⁄26.25 1
1VTT8 35180 378 33⁄495 7⁄822 131⁄26.25 1
• RIDGID Swaging Tools are quality-made and zinc-plated for accuracy and durability.
• Set of four tools is packaged in handy vinyl pouch.
• Designed for copper, aluminum or brass.
Tube Expander
Swaging Tools
Catalog No. Model
No. Description O.D. Capacity Weight Std.
Pack
Grainger RIDGID in. mm oz. g
4A523 52420 570 Kit-4 Tools 1⁄4, 3⁄8,1⁄2, 5⁄86, 9, 12, 16 16 454 1
• This single-stage expander is designed to expand tubing for fast, accurate
joints in soft copper, aluminum, and soft steel tube without using fittings.
The mechanism is free-floating and self-centering.
Note: Kit Head sizes are given by Tube O. D.
Catalog No. Model
No. Description Tube Capacity Weight/Pk.
Grainger RIDGID O.D. nominal lb. kg
4A524 34152 8 Kit with 3⁄8", 1⁄2", 3⁄4", 1" Heads
and Case – – 61⁄2.03
Pipe/Tube Fabrication
& Maintenance
Pipe/Tube Fabrication
& Maintenance
3736
Catalog No. Model
No. Description Sizes (in.) Weight Std.
Pack
Grainger RIDGID lb. kg
4A519 83037 458R 45° SAE Flares 1⁄8, 3⁄16, 1⁄4, 5⁄16, 3⁄8, 1⁄2, 5⁄8, ¾ 31⁄21.6 1
No. 458R Ratchet Flaring Tool
• This precision tool provides smooth, uniform flares with minimum effort.
• The new ratcheting feed screw handle turns easily and requires less motion and effort
than a standard handle.
• Hardened steel flaring cone, eccentrically mounted in needle bearings, produces rolling
action for even metal flow, giving uniform flare walls without galling.
Flaring Tools
Catalog No. Model
No. Description Sizes (in.) Weight Std.
Pack
Grainger RIDGID lb. kg
1ATK0 23332 345 45° SAE Flares 3⁄16", 1⁄4", 5⁄16", 3⁄8", 7⁄16", 1⁄2", 5⁄8" 2¾ 1.2 1
4A518 33927 345/150DL 45° SAE Flares No. 345/DL w/No. 150 Tubing Cutter and Case Kit 3½ 1.6 1
All flaring tools listed are recommended for soft materials such as aluminum and soft
copper. No. 458R will flare steel, stainless steel, hard copper, and brass thru wall thickness
of .035 inches.
No. 345 Flaring Tool
• Model 345 is a precision designed tool for producing 45° flares in soft copper, brass,
aluminum and mild steel (JIC and Bundy) tubing.
• A hardened, smooth cone provides fast, 45° flares either single or double lap.
• A single clamp screw provides for easy clamping and removal of tubing.
Pressure Test Pump
No. 1450 Pressure Test Pump
• Tests hydraulically for leaks in installations which are required to be leak proof.
Will test systems up to 725 PSI.
• Especially for use in heating, compressed air, refrigeration systems, oil
installations, sprinkler systems and other small bore pipe installations.
No. 1450 Pressure Test Pump
Catalog No. Model
No. Description Max.
Pressure Connections Weight
Grainger RIDGID lb. kg
1XDZ3 50557 1450 Pressure Test Pump 725 PSI 1⁄2" NPT 14 6.5
Soldering Gun Professional Electric Soldering Gun
RT-100
• Designed for soft soldering (50/50, 95/5 Alloys) 1⁄4" - 11⁄2" Copper Tube.
• Flameless soldering – easy-to-use.
• Six feet of cable.
• Built-in handle and cord wrap.
• Specially designed for repair and renovation jobs.
• Approved by CSA to CSA and UL standards (115 V only).
RT-175
• Soft solders 1⁄4" - 3" tube.
• Flameless soldering – easy-to-use.
• Twelve feet of cable.
• Fully contained in metal carrying case.
• Approved by CSA to CSA and UL standards (115 V only).
RT-100
RT-175
Catalog No. Model No. Description Weight
Grainger RIDGID lb. kg
5LC06 69762 RT-100 115V Mini-Pro Soldering Gun 21 9.5
4NV35 62862 RT-175 115V Professional Solder Gun 33 15.0
Vises F-Series Vise Features
• All steel, drop-forged construction with fixed pipe jaws.
• Steel handle with rubber anti-pinch rings.
• Large, hardened anvil.
• Forged steel swivel base with dual draw-down bolts.
XF-Series Quick-Acting Vise Features
• Quick-Action Trigger for fast work piece positioning.
• Forged steel construction for superior durability and strength.
• Patented jaw alignment system for precise clamping and long service life.
• 360˚ swivel base for flexibility.
• Oversized jaws and anvil for maximum work areas.
Vise Ordering Information
Infinitely adjustable
swivel base allows vise
to lock securely in any
position.
Large capacity pipe jaws
for secure clamping Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg.
4WN27 66987 F-45 41⁄2" Forged Vise 26 11.9
4WN28 66992 F-50 5" Forged Vise 48 21.6
4WN29 66997 F-60 6" Forged Vise 63 28.6
3AFP5 26648 XF-45 41⁄2" Quick-Action Grip Forged Vise 26 11.7
3AFP6 27848 XF-50 5" Quick-Action Grip Forged Vise 48 28.6
Pipe/Tube Fabrication
& Maintenance
Pipe/Tube Fabrication
& Maintenance
3938
F-Series Vise
XF-Series Vise
XF-Series Vise –
360˚ swivel base for flexibility.
Model KT-200
For fast thawing of frozen metal pipes
1⁄2" through 11⁄2" (12-36mm).
The KT-200 Pipe Thawing Unit provides continuous heating to quickly thaw 1⁄2" to 11⁄2" frozen
metal pipes. With this lightweight, versatile unit, there is no need to dig or tear apart walls.
Simply attach the clamps to the metal pipe on each side of the frozen section and the pipe is
thawed within minutes.
• Approved by CSA to CSA and UL standards (115 V only).
• Continuous Operation: The KT-200 will operate continuously without requiring any “cool-
down” periods. There is no tripping of the unit or need to turn the unit off during the
thawing process. Simply attach the cables to the pipe, turn the unit on and let it do its job
– continuously from start to finish.
• Lightweight: Weighing under 30 lbs., each unit can be easily transported to the most dif-
ficult locations such as attics.
• Versatile: With 4 output levels, the KT-200 can be used on 4' to 150' lengths of pipe. The
KT-200’s amp meter allows the user to select the proper output level for maximum current
draw and minimum thawing time.
• Powerful: The KT-200 operates on a standard 115V, 15 amp outlet. It produces 250-400 amps
of thawing power.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1XEA2 62747 KT-200 Pipe Thawer w/2 - 25' #1/0 Cables 55 2
Pipe Thawer
KT-190 Pipe Thawer
100-B Kit
Compact Battery-Powered Press Tool
1⁄2" to 11⁄4" Capacity for Copper and Stainless Steel
Model 100-B Compact
The Model 100-B is the most compact, lightweight, and yet, powerful
press tool developed by Ridge Tool. It delivers just the right capacity
needed for small diameter copper and stainless steel tubing. The 100-B’s
compact size, and barrel that swivels 90º, allows access to the tightest
spots.
Specifications
• Capacity: ½" to 11⁄4" for copper and stainless.
• Uses Compact Series Press Jaws.
• 90˚ barrel/jaw swivel.
• Battery: 14.4V 2.6 Ah Ni-MH.
• Battery Charger: 115V.
• Hydraulic Ram Output: 5,400 lbs. (24 kN).
• Weight: 7.5 lbs. with battery.
• Operating Temperature Range: 32ºF - 122ºF.
• Approximate Cycle Time: 4 seconds.
• Standard Kit Includes: 100-B Press Tool, 2 Batteries, Battery Charger
and Carrying Case.
Catalog No. Model
No. Description Weight
lb.
Std.
Pack
Grainger RIDGID
2TE25 16953 100-B
½", ¾", 1" Jaw Sets for
ProPress (copper &
stainless)
25 1
SuperFreeze® Pipe Freezing Tool Avoids the Cost and
Inconvenience of a System Shutdown and Purge.
The SuperFreeze Pipe Freezer is an easy-to-use pipe freezing unit that allows the contractor to
keep water systems operating while making repairs. The RIDGID SF-2500 is a mini-refrigera-
tion unit that circulates self-contained refrigerant to its aluminum freeze heads. This forms an
ice plug in as little as 6 minutes in 1⁄2" copper tube and can be used with up to 21⁄2" tube or 2"
pipe. Once the pipe is plugged, repairs can be made while the ice plug is maintained by the
unit. Now includes a bottle of specially formulated freeze gel to speed freezing. Apply the gel
to freeze heads before placing on pipe.
• Approved by UL to CSA and UL standards (115 V only).
Catalog No. Model No. Description Weight
Grainger RIDGID lb. kg
6YJ42 68967 SF-2500
Pipe Freezing Kit - 115V
1⁄2"-2" Steel Pipe
1⁄2"-21⁄2" Copper Tube
55 24.8
Pipe Freezer
SF-2500
SF-2500
Capacity: Copper Tube: 1⁄2" - 21⁄2".
Steel Pipe: 1⁄2" - 2".
Compressor: 115V, 60 Hz, 4.3A or 230V, 50 Hz, 2.4 A.
Refrigerant: R-507 (14.2 oz. charge).
Weight: 55 lbs.
Hose Length: 8.5 ft. (17 ft. span).
Dimensions: L = 21" W = 10.5" H = 13".
Standard Equipment
• SuperFeeze Unit.
• Two Velcro® straps.
• Water bottle.
• Clamp.
• Freezegel.
Pipe/Tube Fabrication
& Maintenance Press Tools
4140
Battery-Powered Press Tool
1⁄2" to 2" Capacity Model RP 330-B Battery-Powered Press Tool
For convenience and portability, the RP 330-B is the logical choice. Featuring a barrel that
rotates 270 degrees and a longer service interval, the RP330-B is designed to handle your
toughest construction projects. Powered by a 18V Lithium-Ion Battery, the RP 330-B offers 50%
more presses per battery charge than Ni-MH battery powered tools.
Specifications
• Capacity: 1⁄2" – 2".
• 270° Barrel/Jaw Swivel.
• Battery: 18V 2.2 Ah Lithium-Ion .
• Battery Charger: 115V.
• Hydraulic Ram Output: 7,200 lbs. (32kN).
• Weight: 9.8 lbs. with Battery.
• Operating Temperature Range: 15°F to 122°F.
• Approximate Cycle Time: 5 seconds.
• Standard Kit includes: RP 330-B Press Tool, 2 Batteries, Battery Charger and Carrying Case.
• Compatible with all RIDGID Standard Series Pressing Attachments.
• For use with Copper, Stainless Steel and PEX Tubing.
• Approved by UL to UL and CSA Standards.
RP 330-B with Jaw Sets for ProPress Copper
Catalog
No. Model
No. Description Weight lb. Std.
Pack
Grainger RIDGID
2GME4 27923 RP 330-B 1⁄2"-2" Jaw Sets for ProPress
(copper & stainless steel) 54 1
Accessories
Catalog No. Model
No. Description Weight lb. Std.
Pack
Grainger RIDGID
2GME6 27968 RP 330-B Battery, 18V 2.2 Ah Lithium Ion 11⁄21
2GME7 27958 RP 330-B 115V Charger 11⁄41
RP 330-B Kit
Corded Press Tool
1⁄2" to 2" Capacity
Catalog No. Model
No. Description Weight
lb.
Std.
Pack
Grainger RIDGID
2GME5 27948 RP 330-C ½" to 2" Jaw Sets for ProPress
(copper & stainless steel) 52 1
RP 330-C with Jaw Sets for ProPress (copper)
Model RP 330-C Corded Press Tool
For the piece of mind a corded tool offers, choose the RP 330-C press tool.
With all of the same features, functionality and durability of the battery-
powered version, the RP 330-C press tool is the workhorse of the job site.
At nearly one-half the weight of the previous CT400 unit, this is our lightest
corded press tool.
Specifications:
• Capacity: 1⁄2" – 4".
• 270° Barrel/Jaw Swivel.
• Hydraulic Ram Output: 7,200 lbs. (32kN).
• Weight: 9 lbs.
• Operating Temperature Range: 15°F to 122°F.
• Approximate Cycle Time: 5 seconds.
• Standard Kit includes: RP 330-C Press Tool and Carrying Case.
• Compatible with all RIDGID Standard Series Pressing Attachments.
• For use with Copper, Stainless Steel and PEX Tubing.
• Approved by UL to UL and CSA Standards.
Standard Series XL-C/S Press Rings
For Use with ProPress XL-C/S (Copper & Stainless Steel Fittings)
The patented XL-C/S Press Rings and V2 Actuator provide increased flexibility in tight
spaces. The ball-tip V2 Actuator swivels nearly 180° with the XL-C/S Press Rings, allow-
ing increased accessibility when making 2½" to 4" connections on ProPress XL-C/S fittings.
These rings work with all RIDGID Standard Series Pressing Tools to make connections on
2½"-4" tube (320-E, RP 330-B, RP 330-C & CT400).
Catalog No. Model
No. Description Weight lb. Std.
Pack
Grainger RIDGID
2TE27 20483 XL-C/S 2½" to 4” Rings, Actuator and
Case Complete 401⁄41
Press Rings
Catalog No. Model
No. Description Weight lb. Std.
Pack
Grainger RIDGID
2GME8 27423 V1 V1 Kit, 1⁄2", 3⁄4", 1", 11⁄4" Ring 103⁄41
2GME9 27428 V2 V2 Kit, 1⁄2", 3⁄4", 1", 11⁄4", 11⁄2", 2" Ring 135⁄81
2GMF1 28043 C1 C1 Kit, 1⁄2", 3⁄4", 1", 11⁄4" Ring 81⁄81
Standard Series Press Rings for ProPress
Copper and Stainless Fittings
Standard Series Press Rings for ProPress fittings permit access
in tighter spaces and serve as an excellent complement to your
RIDGID jaw sets. The swivel actuator allows a press tool to be
placed +/-90 degrees to the tube being pressed!
Features
• V1 and V2 Kits are designed for use with RIDGID 320-E,
RP 330-B, RP 330-C & CT400 Press Tools.
• C1 Compact Kits are designed for RIDGID 100-B Press Tools.
• ProPress Rings are available in 1⁄2" – 2" capacity.
• Standard Kit includes: Press Rings, Actuator and Carrying Case.
Compatible With:
• ProPress System (copper & stainless steel 1⁄2" - 2").
Specifications
• Capacity: 1⁄2" to 2".
Kits
Press Rings
Press ToolsPress Tools
4342
Inspection & LocatingInspection & Locating
4544
Utility Line Locator
SeekTech® Utility Line Locators
The large displays on SeekTech Receivers give you the information you need when you need it to locate
more with greater certainty.
SR-20
Comparison of Features
SR-20 Conventional
Simultrace™
(Simultaneous Sonde & Line Trace) No No
User Defined Frequencies
(Competitor Frequencies) Yes up to 35 K Limited or No
Omni-Seek®
(Simultaneous Multiple Line Trace) Yes – All Passive Bands at Once No
Depth Continual Push Button or Triangulation
Current Measurement Continual Push Button & Average
Distortion Indication On One Screen Yes No
Stereo Guidance (Using Headphones) No No
Performance
The Mapping Display confirms a good locate signal and identifies distortion in congested areas using:
• Target Line – Guides the operator down the line and shows changes in direction.
• Left-Right Guidance Arrows – Points the operator to the target utility.
• Proximity Signal and Signal Strength – Helps the operator center the locator closer to the target
for more confident locates.
Other features include:
• Continual Depth – Increases productivity by showing depth changes in real time.
• Omni-Seek® – Increases accuracy and efficiency when searching in passive mode. Continuously
searches passive power and radio bands to locate and avoid unknown metallic lines.
• User-Defined Frequencies – RIDGID SeekTech SR-20 Receivers can be configured with up to 30 user
defined frequencies between 10 Hz and 35,000 Hz.
Current Strength/
Signal Angle
Signal Strength
Left/Right Guidance Arrows
Depth/Distance
Target Line
Proximity Signal
Catalog No. Description Weight
Grainger RIDGID lb. kg
1DPH2 21893 SeekTech SR-20 Line Locator 4.0 1.8
2YCA5 22163 SeekTech SR-60 Line Locator 6 2.7
1DPH3 21898 SeekTech ST-305 Transmitter (5 watts) 21⁄41.1
1DPH4 21903 SeekTech ST-510 Transmitter (10 watts) 9.0 4.0
2YCA4 26168 SeekTech ST-33Q Transmitter (+5 watts*) 121⁄45.5
1DPH5 20973 SeekTech 4" Inductive Signal Clamp 17⁄80.8
SR-20 Specifications
Active Line Trace Frequencies* ...128 Hz, 1 kHz, 8 kHz, 33 kHz.
Passive Power Trace ....................50 Hz, 60 Hz, <4 kHz Broadband.
Passive Radio Trace .....................4 kHz-15 kHz, 15 kHz-36 kHz.
Sonde Frequencies .......................16 Hz. 512 Hz, 640 Hz, 850 Hz,
8 kHz, 16 kHz, 33 kHz.
Power Source ...............................4 C-Cell Batteries.
Battery Life ...................................Approximately 16 Hours.
Weight ..........................................4 lbs. (2.0 kg).
Meets FCC Class A and EN 55022 Class A requirements.
* 30 user definable frequencies can be set from 10 Hz to 35,000 Hz
SR-60 Specifications
Active Line Trace Frequencies** .. 128 Hz, 1 kHz, 33 kHz 93 kHz, 262 kHz.
Passive Power Trace ..................... 50 Hz, 60 Hz, <4 kHz Broadband.
Passive Radio Trace ...................... 4 kHz-15 kHz, 15 kHz-36 kHz.
Sonde Frequencies** .................... 16 Hz. 512 Hz, 640 Hz, 850 Hz,
8k, Hz16, kHz, 33 kHz.
Power Source ................................4 C-Cell Batteries.
Battery Life .................................... Approximately 16 Hours.
Weight ........................................... 6 lbs. (2.7 kg).
Meets FCC Class A and EN 55022 Class A requirements.
** 30 user definable frequencies can be set from 10 Hz to 490,000 Hz
SR-20:
For users wanting a lightweight yet rugged
receiver that provides all the information needed for
faster, more accurate locates:
• Target line and guidance arrows quickly
identify distortion.
• Proximity signal and signal strength help
work through difficult locates.
Choose the SR-20 and learn to locate with more
confidence.
SR-60:
For users wanting the fastest, easiest, most versatile receiver available:
• Can trace any frequency from 10 Hz to
490,000 Hz.
• Can trace energized lines and sondes (active beacons)
simultaneously.
• Has all the ease of use and accuracy of the SR-20
but with ALL locatable frequencies.
Choose the SR-60 for fast confident locates even under
tough locate conditions (poor conductors, poor soil condi-
tions, poor grounding, etc.)
RIDGID Line Transmitters
Accuracy & Confidence: RIDGID Transmitters deliver the power and performance you expect from RIDGID Locating Equipment. Combine your experience with
the information provided by RIDGID Locating Equipment and you have tools that allow you to work through difficult traces with confidence.
ST-305 ST-510 ST-33Q
Direct Connect Frequencies 4 5 All
Inductive Frequencies 3 3 2
Simultaneous Transmit 2 Line Frequencies Y N N
Automatic Impedance Matching Y Y Y
Digital Output Level Display N Y Y
Max Power Output 5W 10W +5W*
Variable Power Setting Low, Medium, High Fully Adjustable Low, Medium, High
Competitors’ Frequencies No Factory Set User Defined Frequencies
Battery Check At Start-up Continuous Continuous
Weight 21⁄2 lb. / 1.1 kg 41⁄2 lb. / 2.0 kg 121⁄4 lb. / 5.5 kg
FCC & EN 55022 Requirement Class A Class B Class A
*When external power source is connected to the ST-33Q, or rechargeable batteries are used up to 10 Watts nominal
output power can be generated in direct connect mode.
Inspection & LocatingInspection & Locating
4746
SeeSnake® micro™ Inspection Camera
See It.
Into, Under and Around Tight Spaces
The SeeSnake micro Inspection Camera detects and diagnoses the unreachable. Standard
3' cable (expandable to 30' with optional cable extensions), snakes into the tightest spots. A
2.4" high visibility color LCD display shows in detail what can’t be seen.
Mirror to see around corners Hook to retrieve objects Magnet to pick up
ferrous metal objects
FInd It.
Locate and Discover
The SeeSnake micro Inspection Camera includes a fully adjustable LED lit camera head to
help see no matter how bright or dark the conditions are. The camera head is just 0.7" (17
mm) in diameter to fit in tight spots. A smaller, 0.37" (9.5 mm) diameter, camera head is
available for detailed inspections in confined spaces.
Solve It.™
Grab It, Hook It and Diagnose It
Three attachments that twist and lock on the camera head are included with every
SeeSnake micro inspection camera to help solve tough problems.
0.7'' (17 mm) diameter
imager head
0.37'' (9.5 mm) diameter
imager head
3' and 6' cable extensions
3' or 6' Cable Extension Accessories
Can be combined to see objects up to 30' away.
0.37'' (9.5 mm) Diameter Imager Head Accessory
• Nearly one-half the size of the standard camera head.
• Enables detailed inspections in very confined spaces.
• Bright LED lighting provides clear images.
• Sleek aluminum construction withstands demanding applications.
• Easily perform visual inspections in hard to reach and confined areas.
• Lightweight, hand-held design – can be carried anywhere.
• Onboard accessories aid repairs and maintenance.
Specifications
• Display ............................2.4" Color LCD (160 x 234 resolution).
• Camera Diameter............0.7" (17 mm).
• Lighting ...........................2 Adjustable LEDs.
• Cable Reach .................... 3' (expandable to 30' w/optional extensions).
• Waterproof ..................... Camera & Cable to 10' (when properly assembled).
• Power Source.................. 4 AA Batteries (3 hrs. of continuous run-time).
• Attachments ................... Mirror, Hook & Magnet.
• Weight ............................ 1.2 lbs (0.5 kg).
Catalog No.
Description Weight
Grainger RIDGID lb. kg
2VYZ8 31128 3' Cable Extension 3⁄40.3
2RPA6 31133 6' Cable Extension 13⁄80.6
1XJY6 26663 Replacement Imager Head for micro 3⁄40.3
1XJY7 26668 Accessory Pack (Mirror, Hook, Magnet) 1⁄80.01
2RPA7 30068 0.37'' (9.5 mm) Diameter Camera Head 3⁄40.3
Hand-Held Inspection Cameras
Carrying case
SeeSnake micro Camera Heads
Catalog No.
Description Weight
Grainger RIDGID lb. kg
3CZJ7 31118 SeeSnake micro Inspection Camera with
17 mm Camera Head 11⁄40.5
3CZJ8 31123 SeeSnake micro Inspection Camera with
9.5 mm Camera Head 3⁄40.3
Cameras
Accessories
Inspection & LocatingInspection & Locating
4948
Hand-Held Inspection Cameras
microEXPLORER™
Digital Inspection Camera
• Perform and record visual inspections in hard-to-reach areas.
• Download still images and video to a computer via USB or SD card.
• Digital self-leveling for conistent upright image.
Features
• Still and video image capture.
• Image is always up – self-leveling.
• SD card and mini USB port.
• Pan and zoom.
• Rugged aluminum camera head.
Specifications
Display ......................3.5” Color LCD (320 x 240 resolution)
Image Capture..........JPG Images (1280 x 1024) AVI Video (320 x 240)
Recording Medium ...Internal Memory or SD Card
Image Controls .........Pan, Zoom, Self-Leveling, Low-Light Vision
Lighting.....................4 Fully-Adjustable LEDs
Camera Diameter.....0.7” (17 mm)
Cable Reach ............3’ (expandable to 30’ w/optional extensions)
Waterproof................Camera & Cable to 10’ (when properly assembled)
Power Source ..........Rechargeable Lithium Ion Battery (4 Hours of Continuous Run Time)
Standard Equipment
• Hard plastic carrying case.
• Operator's manual.
• One lithium ion battery.
• Battery charger.
• USB cable.
• Hook, magnet and mirror.
Accessories
• Car charger cord.
• 3' and 6' extension cables.
Catalog No. Description Weight
Grainger RIDGID lb. kg
2RPA5 30063 microEXPLORER Digital Inspection Camera 17⁄80.83
SeeSnake® Pipe
Inspection… Builds
Business and Profits
• Sell additional services. • Reduce service time.
• Increase customer satisfaction. • Increase profits.
More than 95% of SeeSnake System owners report increasing sales and
profits soon after purchasing their system. It’s easy to see why. Establish
credibility with your customers as you show them the condition of the line.
Sell more services such as water jetting, root cutting or excavation and
repair. SeeSnake not only reduces call backs, but helps you satisfy your
customer – and that adds up to more profits.
RIDGID Rugged
The SeeSnake line of pipe inspection equipment is designed and manufac-
tured to endure the roughest conditions. You wouldn’t expect anything less
from a RIDGID tool. And, of course, they are approved by UL to CSA and UL
standards.
Pushable Length
11⁄4" 11⁄2" 2" 4" 6" 12" Pipe Diameter
100’
200’
325’
RIDGID Has a SeeSnake System to Meet Your Needs
SeeSnake –
See the Difference
Push Cables
This durable push cable, along with RIDGID's small camera heads, allows
you to reach areas other camera systems cannot.
• Fiberglass inner core.
• Polypropylene coating.
• Integrated push cable with power/video signal.
Reels
• All SeeSnake drums are enclosed to avoid dirt getting on floors.
• Rust-free, dent-resistant drums.
• Mercury-free slip rings.
• Distance counter included.
• All connectors are sturdy 3-pin waterproof universal connectors for
added reliability.
Camera Head
The best performing camera is built tougher for unmatched durability,
reliability and performance.
• Scratch-resistant, debris-shedding sapphire crystal lens.
• 100% stainless steel housing.
• High power adjustable LEDs behind a thick polymer plastic window.
• 410,000 CCD pixel resolution.
• Small camera diameter size (25 mm-35 mm).
• Pipe view (wide angle) technology to be able to clearly see the
pipe wall.
• Self-leveling option.
• Tested water tight to 330'.
Mini SeeSnake Plus
– 11⁄4" 90˚ Bends
– 2" P-Traps
Compact
SeeSnake Plus
Self-Leveling SeeSnake Plus
– 2" 90˚ Bends
– 3" P-Traps
Catalog No. Description Weight
Grainger RIDGID
2VYZ8 31128 3' Cable Extension 3⁄40.3
2RPA6 31133 6' Cable Extension 13⁄80.6
2RPA7 30068 0.37'' (9.5 mm) Diameter Camera Head 3⁄40.3
Accessories
Inspection & LocatingInspection & Locating
5150
Video Pipe Inspection Systems
SeeSnake Plus Video Inspection System
2'' to 12'' Lines up to 325'
For the most reliable and rugged pipe inspection camera …
SeeSnake Plus, built tougher for unmatched durability,
reliability and performance, including:
• 100% hardened stainless steel camera head spring assembly for increased durability.
• Inspects 2" lines and larger:
– 2" 90s.
– 3" P-Traps.
• Rugged, high-intensity lights for improved reliability.
• Flexible transmitter makes locating easier and is fully compatible with RIDGID NaviTrack II
and NaviTrack Scout locators.
• Also available in an always upright, self-leveling option.
• Compatible with any SeeSnake monitor.
• The best choice if you plan on purchasing only one camera.
• Operates on 115 VAC.
SeeSnake Plus Selection
Catalog No. Description
Grainger RIDGID
4GB16 14038 200' B&W Reel
4GB14 14053 200' Color Reel
1VUT5 13988 200' Self-Leveling Reel
4GB17 69697 B&W Monitor
1XDX6 23668 Color LCD Monitor + DVD
4GB15 73172 Color LCD Monitor + VCR
For monitors, see page 46.
Monitors
Color LCD
Monitor + VCR
• 10.4" high resolution, color LCD.
• DVD recorder with wireless remote.
• Hands-free audio recording.
• Video and audio in/out connection.
• 10.4" high resolution color LCD or 9" black & white monitor
with sunshield.
• Commercial grade VCR.
• Hands-free audio recording.
• Video & audio In/Out connection.
Mini SeeSnake Plus Selection
Catalog No. Description
Grainger RIDGID
1XDX6 23668 Color LCD Monitor + DVD
4GB15 73172 Color LCD Monitor + VCR
4GB17 69697 B&W Monitor + VCR
Color LCD Monitor + DVD
Pipe Inspection
Mini-SeeSnake Plus Video Inspection System
11⁄4'' to 6'' Lines up to 200'
At 25 pounds, the Mini-SeeSnake combines portability with a rugged camera used to
inspect lines up to 200 feet. It is built tougher for unmatched durability, reliability and
performance including:
• 100% hardened stainless steel camera head for increased durability.
• Improved push cable and smaller camera head to push farther through tighter spots.
• Inspects 1¼"-6" lines:
– 1¼" 90s (black and white only).
– 2" P-Traps.
• Rugged, high-intensity lights for improved visibility.
• Flexible transmitter makes locating easier and is fully compatible with RIDGID
NaviTrack II and NaviTrack Scout.
• Choose Mini-SeeSnake when portability and maneuverability are crucial (multi-story
buildings, roof tops, confined areas, etc.).
Mini SeeSnake Plus Selection
Catalog No. Description
Grainger RIDGID
1VUT6 14063 200' Color Mini Reel
Inspection & LocatingInspection & Locating
5352
Pipe Locators
Catalog No.
Description Weight
Grainger RIDGID lb. kg
4GB18 96967 NaviTrack II Locator 5 2.3
NaviTrack® II Locator
The NaviTrack II locator navigates you to the location of underground pipes quickly and easily.
It tracks energized lines with ease.
NaviTrack II Locates
• SeeSnake In-Line Transmitters.
• Remote Transmitters (Sondes).
• Energized Metallic Lines.
Performance
• Approach the transmitter from any direction for faster, more accurate locates.
• Maximize the signal and the locate is complete.
• Verify the locate using the large mapping display.
• Depth measurement is continuous.
• Depths of greater than 15' can be read.
NaviTrack II locators provide unprecedented ease of use. Due to NaviTrack II’s advanced
technology, training time is greatly reduced. You can learn to locate
with a NaviTrack II unit in minutes.
Specifications
• Weight ..................................... 5 lbs.
• Power Source........................... 4 C-Cell batteries.
• Battery Life .............................. Approximately 16 hours.
Standard Frequencies
• Sonde ....................................... 512 Hz.
• Active Line Trace ..................... 128 Hz, 1 kHZ, 8 kHz, 33 kHz, 262 kHz.
• Passive AC Line Trace .............. 60 Hz, 50 Hz.
Additional Frequencies
• Sonde ....................................... 16 Hz, 640 Hz, 850 Hz, 8 kHz, 16 kHz, 33 kHz.
• Active Line Trace ..................... 65 kHz, 200 kHz.
Standard Equipment
• Hard Plastic Carrying Case.
• Surface Markers and Clip.
• Instructional DVD.
• Operator’s Manual.
• 4 C-Cell batteries.
For users that locate both remote transmitters and energized lines on a regular basis,
NaviTrack II is the fastest, easiest, most versatile locator.
Kit shown without optional
accessories.
Meets FCC Class A and EN 55022 Class A requirements.
Catalog No. Description Weight
Grainger RIDGID lb. kg
2RPA8 95542 Color Compact System w/ 2 Batteries & Charger 24 11.0
Color Compact Systems
SeeSnake Compact
SeeSnake Compact
Video Inspection System
11⁄4'' to 4'' Lines up to 100'
At 20 pounds, this system offers fast setup for quick inspections. Their ultra portability makes
these cameras excellent complements to your SeeSnake Plus.
Standard Equipment
Power Source:
• Battery port for use with optional 14.4V battery.
• AC/DC operation.
Monitor System:
• High-resolution monitor.
• Power on/off button with step function dimming.
• Splash-resistant case with built in sunshade.
• Video In/Out jack.
• Power indicator light.
Camera System:
• Scratch-resistant, debris-shedding, flush-mounted sapphire lens.
• Integrated transmitter.
• Durable stainless steel camera head assembly and tapered
spring assembly.
Reel:
• 100' of push cable.
• Debris-capturing, rotating drum with mercury-free slip ring.
• Counter to display distance on monitor in feet and inches.
Frame:
• Rust-resistant roll-cage frame.
• Skid-resistant feet for stability.
Inspection & LocatingInspection & Locating
5554
NaviTrack Transmitters
RIDGID offers a range of transmitters for different applications.
NaviTrack Transmitters generate a signal onto the buried cable one of three ways:
• Direct connection using connection cords.
• Induction with the optional inductive signal clamp.
• Induction from the transmitter.
Catalog No. Description Weight
Grainger RIDGID lb. kg
4GB19 14818 NaviTrack Line Transmitter 9 4.0
4GB20 20503 Inductive Signal Clamp 2 0.9
NaviTrack Line Transmitter – 10 Watt
• For tracing buried cable, TV lines, phone lines and other metallic lines which can carry
an electromagnetic signal.
• Fully variable 10 Watts of power output.
• Two 25' coil connectors.
• Conductive ground rod.
• Inductive signal clamp (optional accessory).
Specifications
• 128 Hz, 1 kHz, 8 kHz, 33 kHz – 10 Watt output power.
• 200 kHz, 262 kHz – 1 Watt output power.
• Power Source: 8 D-Cell Batteries.
• Battery Life: Greater than 120 hours.
• Meets FCC Class B and EN 55022 Class B requirements.
Floating Transmitter
• Ideal for locating septic tanks.
• 512 Hz signal.
• Flashing LED indicates that sonde is transmitting.
• Flushable.
• Battery-powered.
• Meets FCC Class B and EN 55022 Class B requirements.
Catalog No. Description
Grainger RIDGID
4GB21 16728 Remote Transmitter, 512 – AAA
Remote Transmitter
• Can be attached to a drain cleaning cable or a water jet hose to locate the Remote
Transmitter in a line.
• Flashing LED indicates that sonde is transmitting.
• Meets FCC Class B and EN 55022 Class B requirements.
Catalog No. Description
Grainger RIDGID
2RPC3 19793 Float Sondes (2), Plus Extra Battery
NaviTrack Scout® Locator
The NaviTrack Scout locator is designed to solve the most demanding remote
transmitter (sonde) locates using the same multi-directional locating technology
as the full-featured NaviTrack II.
Easier Locates
The NaviTrack Scout multi-directional antenna technology sees the entire signal all
of the time. Simply maximize the signal strength and you have found the target. No
nulls or false peaks to complicate the locate.
Accuracy
This locator verifies the locate position using a micro-mapping display to mark
distinctive poles in front of and behind the target, insuring an accurate locate.
Automatic Depth
Depth is automatically calculated and displayed when over the target.
Specifications
• Weight ...................3 lbs.
• Power Source.........4 C-Cell batteries.
• Battery Life ............Approximately 24 hours.
Standard Frequencies
• Sonde ..............................16 Hz, 512 Hz, 640 Hz, 874 Hz and 33 kHz.
• Line Trace ........................128 Hz, 1 kHz, 8 kHz and 33 kHz.
• Passive AC Line Trace .....60 Hz, 50 Hz.
Standard Equipment
• Hard Plastic Carrying Case.
• Surface Markers and Clip.
• Instructional DVD.
• Operator's Manual.
• 4 C-Cell Batteries.
The NaviTrack Scout is ideal for users locating SeeSnake cameras and other sondes
who occasionally need to locate energized lines.
Catalog No. Description Weight
Grainger RIDGID lb. kg
1VUT8 19238 NaviTrack Scout Locator 3 1.4
Meets FCC Class B and EN 55022 Class B requirements.
K-3/K-6 Toilet Augers
High quality tools in 3' and 6' lengths provide fast and safe clearing of toilet obstructions.
Features include:
• Vinyl guard to protect porcelain.
• New durable, kink-resistant, 1⁄2" compression-wrapped Inner Core Cable.
• Large, ergonomically designed handles.
• Negotiate water-conserving toilets.
• Available in either drop head or bulb head models.
Catalog No. Model
No. Description Weight Standard
Pack
Grainger RIDGID lb. kg
4CX10 59787 K-3 3' Toilet Auger w/Bulb Head 41⁄21.9 6
4CX11 59797 K-6 6' Toilet Auger w/Bulb Head 41⁄21.9 6
K-26 Hand Spinner
Ideal for users seeking excellent performance and value. Features include:
• Slip-resistant collet chuck that grips/releases cable with the flick-of-the-wrist.
• 5⁄16" x 25' hollow core cable with bulb head auger.
• Rotary molded plastic drum that won’t rust or dent – cleans easily.
• Open drum design that permits access to cable and allows
application of Cable Rust Inhibitor.
Catalog No. Model
No. Description
Diameter x
Length mm x m Weight
Grainger RIDGID in. x ft. lb. kg
4CX13 59812 K-26 Hand Spinner w/C1
Bulb Head Cable 5⁄16" x 25' 8 x 7.6 6 2.7
K-39AF quickly opens clogged tub lines.
Advance and retrieve cable without
reversing motor.
The 3⁄8" cable in the K-39AF-7 extends
machine’s capacity to 2 ½" drain lines.
K-39 Sink Machines for 3⁄4" to 21⁄2" (19-64 mm) Lines
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
2ZB61 21888 K-39AF Machine with:
– C-1IC, 5⁄16" x 25' Inner Core Cable w/Inner Drum 11 5.0
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
4Z661 68057 K-39 Machine with:
– C-1IC, 5⁄16" x 25' Inner Core Cable w/Inner Drum 11 5.0
2RPC1 68072 K-39-7
Machine with:
– C-1IC, 5⁄16" x 25' Inner Core Cable w/Inner Drum
– C-6, 3⁄8" x 35' Cable w/Inner Drum
– C-21, 5⁄16" x 50' Cable w/Inner Drum
– T-250, Five-Piece Tool Set for 3/8" Cable
– C-6429 Carrying Case
42 19.1
Inner Core Cables
• Vinyl-wrapped inner core to prevent core from rusting to
spring – enhances cable life.
• Compression wound for strength.
• Resists kinking; negotiates tough bends and traps.
• Provides good flexibility and cleaning power to
the cable end.
The drum front and inner drum makes
changing cables quick and easy.
• Excellent for small line cleaning. Opens clogged
lavatory, sink lines, urinals, and tub/shower drains.
– 5⁄16" cables best for ¾" to 1½" lines.
– 3⁄8" cables best for 1¼" to 2½" lines.
• Available in 2 styles: Manual & AUTOFEED.
– Both have slide action chuck for quick locking/
releasing of cable.
– Advanced two-way AUTOFEED keeps hands and
work area clean – advances & retrieves cable
with push of a lever.
• Lightweight, easy-to-use, no set-up required.
• Variable speed power unit rotates cable 0-450
RPM’s.
• Two piece twist lock canister with interchangeable
inner drum.
– Makes cable changeout simple; easy to match
the right cable to the job.
– Inner drum prevents water leaks and
greatly reduces cable flip-over inside the drum.
– Drums won’t rust or dent – ever.
• Drum Capacity: 50' of 5⁄16" (15m/8mm) or 35'
of 3⁄8" (11m/10mm).
• Approved by CSA to CSA and UL Standards
(115V only).
• Includes RIDGID drain cleaning gloves and
operator’s manual.
Drain CleaningDrain Cleaning
Toilet Augers
Hand Spinners
Sink Machines
5756
Power Spin™
• Light-duty product for drains to 11⁄2" .
• Comfortable hand grip eases effort.
• 1⁄4" x 25' hollow core cable
• Power Spin automatically advances and retrieves cable.
• Power Spin operates by hand or by adding any variable speed drill.
Catalog No. Model
No. Description
Diameter x
Length mm x m Weight
Grainger RIDGID in. x ft. lb. kg
3FE62 88387 – Power Spin 1⁄4" x 25' 8 x 7.6 41⁄22.3
Cables
Catalog No. Model
No. Description lb. kg
Grainger RIDGID
5⁄16"- 8 mm
Bulb Auger
1VUX3
4CX08
5KZ97
1VUY7
62225
56782
56792
89400
C-1
C1-IC
C13IC
C-21
25' (7.6m) w/Bulb Auger
25' (7.6m) Inner Core w/Bulb Auger
35' (10.7m) with Bulb Auger
50' (15.2m) w/Bulb Auger
31⁄2
4
51⁄2
7
1.6
1.8
2.5
3.2
Drop Head
1VUX4
1VUW8
1VUW9
1VUY9
62235
56787
56797
89405
C-2
C2-IC
C23-IC
C-22
25' (7.6m) w/Drop Head Auger
25' (7.6m) Inner Core w/Drop Head Auger
35' (10.7m) with Drop Head Auger
50' (15.2m) w/Drop Head Auger
31⁄2
4
51⁄2
7
1.6
1.8
2.5
3.2
3⁄8"- 10
6X907
1VUX5
1VUX6
62245
62250
62260
C-4
C-5
C-6
25' (7.6m) w/Male Coupling
35' (10.7m) w/Bulb Auger
35' (10.7m) w/Male Coupling
41⁄2
81⁄4
81⁄4
2.0
3.8
3.8
K-40 Sink Machine
For 3⁄4" to 21⁄2" (19-64 mm) Drain Lines
The K-40 Sink Machine is ideal for cleaning small secondary drain lines from 3⁄4" to 21⁄2". The
K-40 sits flat on the floor or countertop and also tips onto its back for easy access to sink
drains and bathtubs full of water. The K-40AF practically eliminates job site clean-up thanks
to the patented Guide Hose two-way AUTOFEED accessory. It completely contains the rotating
cable and eliminates any waste water splashing or spraying.
• 1⁄8 HP, 115 V, induction motor quietly delivers enough torque to clear even the toughest
blockages.
• Premium-quality, compression-wound inner core cable combines strength and flexibility to
resist kinking.
• Two-piece “twist lock” drum housing will not dent or corrode and allows easy access to
the inner drum and cable.
• Special inner drum design virtually eliminates cable flip-over inside the drum and drum
leakage.
• Two-way AUTOFEED advances and retrieves the drain cleaning cable with a simple push of
a lever keeping you and the work area clean.
• Approved by CSA to CSA and UL Standards (115V only).
• Includes RIDGID drain cleaning gloves and operator’s manual.
Machine Options
Model K-40AF
Model K-40AF in vertical position
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
5LC09 71722 K-40AF
Machine with:
– AUTOFEED
– Guide Hose
– Mounting Bracket
– C-13IC-SB, 5⁄16" x 35' Speed Bump
CabIe w/Inner Drum
33 15
IW (Integral Wound) Solid Core Cables
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
2AER4 24853 K-400
w/C-32 IW
K-400 Machine w/RIDGID Drain Cleaning Gloves & Std. Equipment
– C-32 IW 3⁄8" x 75' Solid Core (Integral Wound) Cable
– T-260 Tool Set
68 31
2AER5 26998 K-400
w/C-45 IW
K-400 Machine w/RIDGID Drain Cleaning Gloves & Std. Equipment
– C-45 IW 1⁄2" x 75' Solid Core (Integral Wound) Cable
– T-260 Tool Set
81 37
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
6NZ28 87597 C-45IW 1⁄2" x 75' (23m) IW Cable 39 17.7
6NZ27 87582 C-32IW 3⁄8" x 75' (23m) IW Cable 26 11.8
K-400 Drum Machine
For 11⁄2" to 4" (32-100 mm) Drain Lines
The K-400 offers several unique, user-friendly features to make the toughest drain cleaning jobs
easier and hassle-free. Designed with a sleek profile, the K-400 is a great fit for drain cleaners,
service plumbers, facility and institutional maintenance departments and property management
companies.
• Integrated Transport Cart – allows for easy movement to and from the job site. Heavy-duty,
large wheels easily navigate over bumps and up stairs.
• Integrated Telescoping Handle – provides high-handle height during transport. Handle
locks in low position during drain cleaning operation or during transport to minimize
space requirements.
• Cable Control System – causes the drum to stop spinning when the blade becomes
lodged in a blockage, limits potential for cable to flip-over in the drum and helps to
indicate to operator when blockages are encountered.
• “Solid Core” Cable – uses tough 3⁄8" or 1⁄2" Integral Wound (IW) solid core cable that is
rugged and kink resistant. Each size comes in several lengths and utilizes a variety of the
RIDGID quick-connect cutters.
• AUTOFEED® – offered as an accessory, this patented, automatic cable feed powers cable
in and out of the drain. Reverse the direction of the AUTOFEED® and the cable feeds back
into the drum.
Specifications
• Drum Capacity .................100' of 3⁄8" Diameter Cable or 75’ of 1⁄2" Diameter Cable.
• Motor ...............................115V/60 Hz, Reversible, Split Phase, 1⁄3 HP @ 1725 RPM, 6.7 Amps.
• Weight (Machine Only) ....45 lbs. (20.4) kg.
• Dimensions ......................Length 21" (24" with AUTOFEED), Height 23", Width 17".
Approved by CSA to CSA and UL Standards (115V only). All K-400 machines are supplied with
RIDGID drain cleaning gloves, operator’s manual and instructional video.
K-400 with AUTOFEED®
K-400 Machine Only
Catalog No. Model No. Description Weight
Grainger RIDGID lb. kg
2AER6 26773 – K-400 AUTOFEED Assembly 2 0.9
2AER7 26778 – Guide Hose 2 0.9
Accessories
Drain CleaningDrain Cleaning
Sink Machines Drum Machines
5958
Cables
Catalog No. Model
No. Description lb. kg
Grainger RIDGID
5⁄16"- 8 mm
Bulb Auger
1VUX3
4CX08
5KZ97
1VUY7
62225
56782
56792
89400
C-1
C1-IC
C13IC
C-21
25' (7.6m) w/Bulb Auger
25' (7.6m) Inner Core w/Bulb Auger
35' (10.7m) with Bulb Auger
50' (15.2m) w/Bulb Auger
31⁄2
7
1.6
3.2
Drop Head
1VUX4
1VUW8
1VUW9
1VUY9
62235
56787
56797
89405
C-2
C2-IC
C23-IC
C-22
25' (7.6m) w/Drop Head Auger
25' (7.6m) Inner Core w/Drop Head Auger
35' (10.7m) with Drop Head Auger
50' (15.2m) w/Drop Head Auger
31⁄2
7
1.6
3.2
3⁄8"- 10
6X907
1VUX5
1VUX6
62245
62250
62260
C-4
C-5
C-6
25' (7.6m) w/Male Coupling
35' (10.7m) w/Bulb Auger
35' (10.7m) w/Male Coupling
41⁄2
81⁄4
81⁄4
2.0
3.8
3.8
Tools Fit 3⁄8" IC, 3⁄8" IW and 1⁄2" IW Cables
C-31,C-32,C-33,C-31IW,C-32IW,C-33IW,C-44IW and C-45IW
Catalog No. Model
No. Description
Grainger RIDGID
1VXC4 62990 T-201 Straight Auger, 5" Long
1VXC6 62995 T-202 Bulb Auger, 11⁄8" O.D.
1VXC8 63000 T-203 Bulb Auger 7⁄8" O.D.
1VXD7 63065 T-217 Drop Head, 4" Long
1VXD1 63005 T-205 “C” Cutter, 13⁄8"
1VXD3 63010 T-206 Funnel Auger, 3" Long
1VXD5 63035 T-211 Grease Cutter, 13⁄8"
4CW97 49002 T-260
Tool Set: T-202 Bulb
Auger, T-205 “C” Cutter,
T-211 Spade Cutter, A-13
Pin Key
1VXB9 48482 T-250 Tool Set includes: T-203,
T-205, T-210, T217, A-13
Tools Fit 1⁄2" Cables
C-44, C-45 and C-46
Catalog No. Model
No. Description
Grainger RIDGID
4CX04 54992 T-270 Tool Set: T-102 Funnel Auger, T-142 Knife – Blade Cutter, T-107 Spade Cutter,
A-12 Pin Key
Model K-3800
K-3800 Drum Machine
For 3⁄4" to 4" (19-100 mm) Drain Lines
• A powerful, easy to transport, versatile machine for cleaning indoor drains. Requires mini-
mal set-up to clean sink lines, floor drains and roof vents.
• Rugged, corrosion-resistant molded cable drum won’t dent or rust. The drum tilt adjusts for
proper cable feed angle. Inner-drum guards against cable flip-over inside the drum.
• Cable drum’s quick-release and built-in hand-holds allow easy cable change and transport.
• Standard drum capacity is 100' of 3⁄8" or 90' of 1⁄2" (30m/10mm or 27m/12mm) continuous
length cable:
– 3⁄8" cable best for 11⁄2" to 3" lines up to 100'.
– 1⁄2" cable best for 2" to 4" lines up to 90'.
• Powerful 1⁄
1
2 HP, 115 V, Universal Motor spins cable at 240 RPM. When cable hits blockage,
motor gears down automatically to deliver more power and enhance operator control.
• Tools connect to cable in seconds.
• Approved by CSA to CSA and UL Standards (115V only).
• IW (Integral Wound) cables available. IW cables are slightly stiffer and more kink resistant.
All IW cables use 3⁄8" T-200 series cutters.
• Includes RIDGID PVC drain cleaning gloves and operator’s manual.
Catalog No. Model
No. Description Weight
RIDGID
115 V 115 V lb. kg
4CX03 53117 K-3800
w/C-32
K-3800 Machine w/Std. Equip
– C-32, 3/8" x 75' Cable
– T-202 Bulb Auger
– T-205 “C” Cutter
– T-211 Spade Cutter
– A-13 Pin Key
– RIDGID PVC Drain Cleaning Gloves
71 32.2
Inner Core (IC) Cables –
Good flexibility and more cleaning power to the cable end.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
3⁄8" - 10 mm
1VXH3 37842 C-31 50' (15m) IC Cable 18 8.2
6A649 37847 C-32 75' (23m) IC Cable 26 11.8
1VXH4 37852 C-33 100' (30m) IC Cable 34 15.4
1⁄2"- 12 mm 1VXH5 37857 C-44 50' (15m) IC Cable 27 12.2
4CW70 37862 C-45 75' (23m) IC Cable 39 17.7
Integral Wound (IW) Cables –
Wound tighter on the inner core creating a solid assembly.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
3⁄8" - 10 mm 6NZ27 87582 C-32IW 75' (23m) IW Cable 26 11.8
1⁄2"- 12 mm 6NZ28 87597 C-45IW 75' (23m) IW Cable 26 11.8
Accessories
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1VXB7 60087 A3800 PF. AUTOFEED® Assembly 73⁄83.3
Tools Fit 3⁄8" IC, 3⁄8" IW and 1⁄2" IW Cables
C-31,C-32,C-33,C-31IW,C-32IW,C-33IW,C-44IW and C-45IW
Catalog No. Model
No. Description
Grainger RIDGID
1VXC4 62990 T-201 Straight Auger, 5" Long
1VXC6 62995 T-202 Bulb Auger, 11⁄8" O.D.
1VXC8 63000 T-203 Bulb Auger 7⁄8" O.D.
1VXD7 63065 T-217 Drop Head, 4" Long
1VXD1 63005 T-205 “C” Cutter, 13⁄8"
1VXD3 63010 T-206 Funnel Auger, 3" Long
1VXD5 63035 T-211 Grease Cutter, 13⁄8"
4CW97 49002 T-260 Tool Set: T-202 Bulb Auger, T-205 “C” Cutter, T-211 Spade
Cutter, A-13 Pin Key
1VXB9 48482 T-250 Tool Set includes: T-203, T-205, T-210, T217, A-13
Tools Fit 1⁄2" Cables
C-44, C-45 and C-46
Catalog No. Model
No. Description
Grainger RIDGID
4CX04 54992 T-270 Tool Set: T-102 Funnel Auger, T-142 Knife – Blade Cutter, T-107 Spade
Cutter, A-12 Pin Key
Drain CleaningDrain Cleaning
Drum Machines
6160
K-6200 Drum Machine
For 3" to 6" (75-150mm) Drain/Sewer Lines
Superior maneuverability and a small footprint allow easy access to tight work areas. The
K-6200 comes equipped with either IC (Inner Core) cable or IW (Integral Wound) cable.
Recommend 5⁄8" cable for 3" to 6" drain lines up to 200'.
• Patented Cable Control System – Causes the drum to slow down when the blade
becomes lodged in a blockage. Limits potential for cable flip-over inside the drum.
•
Direct Drive Design – 4⁄10 HP universal motor and gearbox bear down as torque builds.
Motor sound lets the operator know when blockage is encountered. Drum requires no
adjustments to stay aligned and tight on drive shaft.
• Easy Maintenance Construction – Separate drum and machine in seconds.
Inner drum and guide tube remove easily to maintain or replace cable.
•
Designed Durable and Stable – Low center of gravity frame design and custom
kickstand keep machine firmly anchored during operation. Rugged, corrosion-resistant
polyethylene drum is rust and dent proof. Double tubular frame is lightweight and designed
for extra strength.
• AUTOFEED and Standard Accessories – Powerful feed mechanism is built to last and is
easily maintained. AUTOFEED, toolbox and selection of cutters included in all models.
• Approved by CSA to CSA and UL Standards (115V only).
• Includes RIDGID PVC drain cleaning gloves and operator’s manual.
Specifications
Line Capacity ....................................... 3"- 6" Lines, Up to 200 feet.
Drum Capacity ..................................... 100' of 5⁄8" Cable.
Motor:
Type ..................................................... 115V/60 Hz, Reversible, Universal AC Motor.
Rating ..................................................
4⁄10 HP, 285 RPM.
Amps ................................................... 5.6.
Weight (Machine & 100 ft. of Cable) ... 180 lbs.
Length ................................................... 291⁄2".
Height.................................................... 431⁄2" (Max).
Width..................................................... 183⁄4".
Model K-6200
Catalog No. Model No. Description Weight
Grainger RIDGID lb. kg
3FE63 93557 K-6200
w/C-24-IW
Machine, Standard Accessories and
5⁄8" x 100' IW Solid Core Cable 180 81.81
Cables and Flexible Leaders
• Inner Core (IC) cables provide good flexibility and more cleaning power to the cable end.
• Integral Wound (IW) cables are wound tighter on the inner core creating a solid assembly.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
5⁄8" - 16 mm (IC)
1VUZ2
1VUZ4
1VUZ5
92460
92465
92470
C-25
C-26
C-27
25' IC Cable (7.6m)
50' IC Cable (15.2m)
75' IC Cable (22.9m)
24
43
63
10.9
19.5
28.6
(IW)
1VUZ6 95747 C-24IW 100' IW Cable
(30.5m) 84 38.1
Catalog No. Model
No. Description
Grainger RIDGID
1VXE6 92485 T-403 P-Trap Cutter, 3"
1VXE7 92495 T-406 Spear Blade
1VXE8 92500 T-407 Retrieving Auger
1VXE9 92505 T-408 Sawtooth Cutter
1VXC1 51762 T-409 H-D Bulb Auger
1VXF1
1VXF2
1VXF4
92510
92520
92525
T-411
T-413
T-414
Double Cutter, 2"
Double Cutter, 3"
Double Cutter, 4"
1VXF6
1VXF8
92535
92540
T-432
T-433
3-Blade Cutter, 2"
3-Blade Cutter, 3"
Tools and Replacement Blades – Fits 5⁄8" IC and IW Cables
C-24, C-25, C-26, C-27, C-24IW, C-25IW, C-26 IW, C-27 IW, C-24HC, C-27HC
Drain CleaningDrain Cleaning
Drum Machines
6362
K-750 Drum Machine
For 3" to 8" (75-200mm) Drain/Sewer Lines
• Powerful, self-contained machine ideal for lateral lines. Easy to transport, minimal
set-up – attach a tool and go.
• AUTOFEED advances, retrieves cable with a push of a lever, up to 20' per minute.
• Versatile AUTOFEED adjusts for either 5⁄8" or 3⁄4" cable with a twist of a screwdriver.
– Recommend 5⁄8" cable for 3" to 6" drain lines up to 150' (75-150mm, 48m).
– Recommend 3⁄4" cable for 4" to 8" drain lines up to 200' (100-250mm, 62m).
• Cable spins at 200 RPM.
• Tough, corrosion-resistant cable drum withstands harsh treatment and abuse. It will not
dent or corrode and cleans easily.
• Drum holds 100 feet of 3⁄4" (30m, 19mm) or 125 feet of 5⁄8" (35m, 16mm) cable and is
designed for quick, easy removal.
• Well-balanced design gives machine a lightweight “feel.” Transport wheels ease loading
into service truck/van.
• Equipped with 1⁄2 HP induction motor.
• Approved by CSA to CSA and UL Standards (115V only).
• Includes RIDGID PVC drain cleaning gloves and operator’s manual.
Standard 3⁄4" Tool Set Includes:
• T-406 Spear Blade Cutter. • T-413 3" Cutter.
• T-407 Retrieving Auger. • T-414 4" Cutter.
• T-411 2" Cutter.
Model K-750
Cable advance Cable retractK-750 with C-100 shown above
Catalog No.
Model No. Description Weight
Grainger RIDGID lb. kg
1ATH5 42007 K-750
Machine with RIDGID Drain Cleaning Gloves,
w/C-100 AUTOFEED, Standard 3⁄4" Tool Set,
and: C-75, 75' x 3⁄4" Cable
234 106.3
Inner Core (IC) Cables
Good flexibility and more cleaning power to the cable end.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
5⁄8" - 16 mm 1VXH7 43647 C-24 100' IC Cable (30.5m) 84 38.1
3⁄4" - 20 mm 1VXH6
4CW83
41212
41697
C-75
C-100
75' IC Cable (22.9m)
100' IC Cable (30.5m)
93
122
42.5
55.3
Hollow Core Cables
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
5⁄8" - 16 mm 1VUX1 58192 C-24 100' HC Cable (30.5m) 701⁄232.1
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1VXG2 92560 T-468 3⁄4" x 2' Leader 23⁄41.25
Leaders
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1VUZ7 43642 A-75 AUTOFEED Assembly 83.5
Accessories
Tools and Replacement Blades – Fit 5⁄8" and 3⁄4" Cables
C-24, C-25, C-26, C-27, C-28, C-29, C-75, C-100, C-27HC, C-24HC, C-75HC and C-100HC
Drain CleaningDrain Cleaning
Drum Machines
6564
Catalog No. Model
No. Description
Grainger RIDGID
1VXE6 92485 T-403 P-Trap Cutter, 3"
1VXE7 92495 T-406 Spear Blade
1VXE8 92500 T-407 Retrieving Auger
1VXE9 92505 T-408 Sawtooth Cutter
1VXC1 51762 T-409 H-D Bulb Auger
1VXF1
1VXF2
1VXF4
92510
92520
92525
T-411
T-413
T-414
Double Cutter, 2"
Double Cutter, 3"
Double Cutter, 4"
1VXF6
1VXF8
92535
92540
T-432
T-433
3-Blade Cutter, 2"
3-Blade Cutter, 3"
K-7500 Drum Machine
For 3" to 10" (75-250mm) Lines
• The performance, cable control, durability, and maneuverability demanded by professional
users. Ideal for any tough job, such as roots – up to 250'.
– Recommend 5⁄8" cable for 3" to 6" drain lines up to 250' (75-150mm, 76m).
– Recommend 3⁄4" cable for 4" to 10" drain lines up to 250' (100-250mm, 76m).
• Cable spins at 200 RPM.
• Powerful, yet quiet, 4⁄10 HP universal motor and gearbox bear down as cutter engages tough
obstructions.
– Provides audible and visual signals to operator.
• Inner-drum and ball bearing distributor arm work with motor/gearbox system to reduce
chance of cable flip-over inside the drum.
• Main and inner drums won’t rust, split or dent – ever, and clean easily for professional
appearance. Main drum holds up to 100' of 3⁄4" cable.
• Powerful AUTOFEED mechanism has grease fittings and an open design for easy
maintenance; advances and retrieves cable up to 22' per minute.
• Patented two position stair climber eases transport and loading – eliminates extra cost for
loading wheels.
• Narrow profile allows machine to fit through bathroom doors.
• Handles adjust to desired height to ensure balanced transport.
• Approved by CSA to CSA and UL Standards (115V only).
• Includes RIDGID PVC drain cleaning gloves and operator’s manual.
Standard Accessories
T-406 Spear Blade.
T-407 Retrieving Auger.
T-411 2" Double Cutter.
T-413 3" Double Cutter.
T-414B 4" Double Cutter - (Blade only).
T-416B 6" Double Cutter - (Blade only).
T-408 Sawtooth Cutter.
T-403 3" P-Trap Cutter.
T-468 3⁄4" Flexible Leader.
Tool Box, Hex Key, RIDGID Drain Cleaning Gloves.
For 5⁄8" machine packages (Catalog Nos. 61102 and 61112), the T-468 Leader
is replaced with the T-458 Leader and the 6" Double Cutter Blade is eliminated.
Model K-7500
Catalog No.
Model No. Description Weight
Grainger RIDGID lb. kg
4CX14 60052 K-7500 C-100 Machine, Standard Accessories,
and 3⁄4" x 100' Inner Core Cable. 244 110.9
Drain CleaningDrain Cleaning
Drum Machines
6766
Catalog No. Model
No. Description
Grainger RIDGID
1VXE6 92485 T-403 P-Trap Cutter, 3"
1VXE7 92495 T-406 Spear Blade
1VXE8 92500 T-407 Retrieving Auger
1VXE9 92505 T-408 Sawtooth Cutter
1VXC1 51762 T-409 H-D Bulb Auger
1VXF1
1VXF2
1VXF4
92510
92520
92525
T-411
T-413
T-414
Double Cutter, 2"
Double Cutter, 3"
Double Cutter, 4"
1VXF6
1VXF8
92535
92540
T-432
T-433
3-Blade Cutter, 2"
3-Blade Cutter, 3"
Tools and Replacement Blades – Fits 5⁄8" IC and IW Cables
C-24, C-25, C-26, C-27, C-24IW, C-25IW, C-26 IW, C-27 IW, C-24HC, C-27HC
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1VXG2 92560 T-468 3⁄4" x 2' Leader 23⁄41.25
Leaders
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
2RPC7 58920 K-50 Machine with A-1 RIDGID drain
cleaning mitt 37 16.8
4Z249 59000 K-50-8
Machine, with:
– A-17-A Adapter
– A-17-B Adapter
– A-30 Cable Kit
77 34.9
K-50 Sectional Machine
For 3⁄4" to 4" (19-100 mm) Drain Lines
• Compact, versatile, professional’s machine. Capable of running three different size cables:
5⁄16", 3⁄8", and 5⁄8". The perfect, all-around sink, shower and floor drain machine. Weighs less
than 40 lbs.
• Unique, easy-to-use, instant-acting cable clutch maximizes operator control:
– Pull handle down and cable spins at 400 RPM.
– Release handle, cable stops instantly.
• Uses sections of 5⁄8" cable, cleans 11⁄4" to 4" lines up to 100 feet.
– C-8 best for 11⁄4 -3" drains.
– C-9 best for 2 - 4" drains.
• Equipped with an A-17 adapter, runs up to 50 feet of 5⁄16" (15m/8mm) or 35 feet of 3⁄8"
(11m/10mm) continuous length cable.
– 5⁄16" best for 3⁄4" to 11⁄2" lines.
– 3⁄8" best for 11⁄4" to 2" lines.
• Equipped with 1⁄6 HP motor; 115V Models.
• Includes A-1 RIDGID drain cleaning mitt and operator’s manual.
• Approved by CSA to CSA and UL Standards (115V only).
A-30 Cable Kit, includes:
– Six Sections C-8, 71⁄2' x 5⁄8" Cable (45 feet).
– A-10 Cable Carrier.
– T-201 Straight Auger.
– T-202 Bulb Auger.
– T-205 “C” Cutter.
– T-211 Spade Cutter.
– A-13 Coupling Pin Key.
– A-14-6 Rear Guide Hose.
– A-1 Left-Hand RIDGID Drain Cleaning Mitt.
K-50-8 shown below includes:
• K-50 Machine.
• A-17-A, Adapter includes:
– 25' x 5⁄16", C-1 Bulb Auger Cable.
• A-17-B, Adapter includes:
– 35' x 3⁄8", C-5 Bulb Auger Cable.
• A-1 RIDGID Drain Cleaning Mitt.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1VUZ8
1VXB3
59205
59295
A-1
A-2
Left-Hand RIDGID Drain
Cleaning Mitt
Right-Hand RIDGID Drain
Cleaning Mitt
1⁄2
1⁄2
0.2
0.2
1VUZ9 59230 A-13 Pin Key For 5⁄8" Cable 1⁄80.1
1VXB5 59450 A-3179 K-50 Jaw Set 11⁄20.7
Accessories
Cable Kits
Catalog No. Model
No. Cable Tools & Accessories Weight
Grainger RIDGID lb. kg
1VUX2 59365 A-30
Six
Sections:
C-8,
5⁄8"x71⁄2'
(45',
13.7m)
T-201 Straight Auger
T-202 Bulb Auger
T-205 “C” Cutter
T-211 Spade Cutter
A-13 Coupling Pin Key
A-10 Cable Carrier
A-14-6 Rear Guide Hose
A-1 Left-Hand RIDGID
Drain Cleaning Mitt
20 9.1
Adapters
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1VXA1 59250 A-17-A Adapter With 25' x 5⁄16"
Cable w/Bulb Auger 8 3.6
1VXB1 59255 A-17-B Adapter With 35' x 3⁄8"
Cable w/Bulb Auger 13 5.9
Cables
Tools – Fits 5⁄16", 3⁄8" and 5⁄8" Cables
C-4, C-6, C-7, C-8 and C-9
Catalog No. Model
No. Description lb. kg
Grainger RIDGID
5⁄16"- 8 mm
Bulb Auger
1VUX3
4CX08
5KZ97
1VUY7
62225
56782
56792
89400
C-1
C1-IC
C13IC
C-21
25' (7.6m) w/Bulb Auger
25' (7.6m) Inner Core w/Bulb Auger
35' (10.7m) with Bulb Auger
50' (15.2m) w/Bulb Auger
31⁄2
4
51⁄2
7
1.6
1.8
2.5
3.2
Drop Head
1VUX4
1VUW8
1VUW9
1VUY9
62235
56787
56797
89405
C-2
C2-IC
C23-IC
C-22
25' (7.6m) w/Drop Head Auger
25' (7.6m) Inner Core w/Drop Head Auger
35' (10.7m) with Drop Head Auger
50' (15.2m) w/Drop Head Auger
31⁄2
4
51⁄2
7
1.6
1.8
2.5
3.2
3⁄8"- 10 mm
6X907
1VUX5
1VUX6
62245
62250
62260
C-4
C-5
C-6
25' (7.6m) w/Male Coupling
35' (10.7m) w/Bulb Auger
35' (10.7m) w/Male Coupling
41⁄2
81⁄4
81⁄4
2.0
3.8
3.8
5⁄8"- 16 mm
1VUX7
6X908
1VXH8
62265
62270
51317
C-7
C-8
C-9
71⁄2' (2.3m) Tight Wind
71⁄2' (2.3m) All-Purpose Wind
10' (3.1m) Tight Wind
4
3
43⁄4
1.8
1.4
2.1
Drain CleaningDrain Cleaning
Sectional Machines
6968
Catalog No. Model
No. Description
Grainger RIDGID
1VXC4 62990 T-201 Straight Auger, 5" Long
1VXC6 62995 T-202 Bulb Auger, 11⁄8" O.D.
1VXC8 63000 T-203 Bulb Auger 7⁄8" O.D.
1VXD7 63065 T-217 Drop Head, 4" Long
1VXD1 63005 T-205 “C” Cutter, 13⁄8"
1VXD3 63010 T-206 Funnel Auger, 3" Long
1VXD5 63035 T-211 Grease Cutter, 13⁄8"
4CW97 49002 T-260 Tool Set: T-202 Bulb Auger, T-205 “C” Cutter, T-211
Spade Cutter, A-13 Pin Key
1VXB9 48482 T-250 Tool Set includes: T-203, T-205, T-210, T217, A-13
K-60 Sectional Machine
For 11⁄4" to 4" (32-100 mm) Drain Lines
• A compact machine for institutional, commercial or residential cleaning. Also ideal for
septic tank vacuum truck operators. Small enough to fit into cramped spaces, yet powerful
enough to clear tough blockages.
• Ideal for rooftop vent stacks. Rear handle allows for easy transporting up
ladders and onto rooftops.
• Unique, easy-to-use, instant-acting cable clutch maximizes operator control.
– Push handle down, cable spins at 600 RPM.
– Release handle, cable stops instantly.
• Simple adjustment knob allows unit to spin both 7⁄8" (22 mm) and 5⁄8" (16mm) diameter
cable. Adjusts in seconds.
– 7⁄8" cable (C-10) cleans 2" to 4" lines through 150 feet.
–
5⁄8" cable (C-7, C-8, C-9) cleans 11⁄4" to 4" lines through 125 feet.
• Remove only two bolts to access jaw set for cleaning or replacement.
Removal of same bolts provides access to belt drive.
• Equipped with 1⁄2 HP motor.
• Includes A-1 RIDGID drain cleaning mitt and operator’s manual.
• Approved by CSA to CSA and UL Standards (115V only).
K-60SP-SE includes:
• K-60SP Machine.
• A-1 RIDGID Drain Cleaning
Mitt.
• A-60-12 Rear Guide Hose.
• A-62 Cable Kit, includes:
– A-8 Cable Carrier.
– Five Sections Of C-10,
7⁄8" Cable, Total 75 Feet.
• A-61 Tool Kit, includes:
– T-101 Straight Auger.
– T-102 Funnel Auger.
– T-107 Spade Cutter.
– T-125 Retrieving Auger.
– T-150-1 Sharktooth Cutter.
– A-3 Tool Box.
– A-12 Pin Key.
Model K-60SP
Catalog No. Model No. Description Weight
Grainger RIDGID lb. kg
1XDX9 66497 K-60SP-SE
Machine with RIDGID Drain Cleaning
Mitt, A-12 Pin Key, and A-60-12 Rear
Guide Hose, plus: A-61 Tool Kit A-62
Cable Kit
92 41.7
Cables
Cable Type Catalog No. Model
No. Description lb. kg
Grainger RIDGID
7⁄8"Sectional 1VUX8 62275 C-10 15' All-Purpose Wind (4.6m) 91⁄24.3
5⁄8"Sectional 6X908 62270 C-8 71⁄2' All-Purpose Wind (2.3m) 3 1.4
K-1500 B W/C-11 shown above includes:
• K-1500 B Machine with A-1 RIDGID Drain Cleaning Mitt,
A-12 Pin Key and A-34-12 Rear Guide Hose.
• Seven Sections of 11⁄4" (C-11) Cable, Total 105 Feet.
• Two A-8 Cable Carriers.
• Nine-Piece Tool Set includes:
– T-1 Straight Auger. – T-50-1 Sharktooth Cutter.
– T-3 Funnel Auger. – A-2864 Hex Key.
– T-6 Retrieving Auger. – T-8 Grease Cutter.
– A-3516 Hex Key. – A-3 Tool Box.
– T-13 Sawtooth Cutter.
K-1500 Sectional Machine For 2" to 8"
(50-200 mm) Drain and Sewer Lines
• The finest all-around sewer and drain cleaning machine. One man can easily clean the
heaviest blockages – indoors or out. High-speed cleaning gets the job done faster...better.
• Unique, easy-to-use, instant-acting cable clutch maximizes operator control:
– Pull handle down, cable spins at constant 710 RPM.
– Release handle, cable stops instantly.
• Wheels to the job site – sets up fast, cleans up fast.
• Low-profile “B” frame design will fit most crawl spaces, loads and unloads from truck
easily. Upright “A” frame features cable carrier storage during transport, ideal for in-
house applications.
• Equipped to run, easy to handle, 15-foot sections of 11⁄4" cable to clean 3" to 8" (32m-
200mm) lines to 200 feet (61m).
• Easy clutch jaw change-out adapts K-1500 to run 15-foot sections of 7⁄8" (4.6/22mm) cable
through 2" to 4" lines up to 175 feet (50-100mm, 53m).
• Equipped with 3⁄4 HP motor; 115V Models.
• Includes RIDGID drain cleaning mitt and operator’s manual.
• Approved by CSA to CSA and UL Standards (115V only).
Model K-1500B
(B- Frame)
Model K-1500A
(A-Frame)
A Frame
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
3Z748 23717 K-1500B Machine with A-1 RIDIGD Drain
Cleaning Mitt, A-12 Pin Key, and
A-34-12 Rear Guide Hose, Plus:
– Seven Sections 11⁄4" (C-11)
Cable, Total 105 Feet
– Two A-8 Cable Carriers
– Nine-Piece 11⁄4" Tool Set
256 116.1
B Frame
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1EZ18 23712 K-1500A Machine with A-1 RIDIGD Drain
Cleaning Mitt, A-12 Pin Key, and
A-34-12 Rear Guide Hose, Plus:
– Seven Sections 11⁄4" (C-11)
Cable, Total 105 Feet
– Two A-8 Cable Carriers
– Nine-Piece 11⁄4" Tool Set
256 116.1
Drain CleaningDrain Cleaning
Sectional Machines
7170
For cables, leaders, cable, kits, accessories and tools, see page 72.
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
11⁄4" - 32mm
Sectional
2W354 62280 C-11 15' Standard All-Purpose Wind. 3⁄8"
Pitch. Good for 4" Traps,
3"- 8" Lines.
16 7.3
To adapt K-1500 to run 7⁄8" cable requires A-368X Jawset and 7⁄8" Cable Kit.
Engage clutch, cable spins. Release handle, cable stops instantly.
Instant-Acting Clutch
Cables, Leaders and Cable Kits
Catalog No. Model
No. Description Weight
Grainger RIDGID lb. kg
1VXB4 59320 A-369X 11⁄4" Replacement Jawset 3⁄4 0.3
Accessories
Catalog No. Model
No. Description
Grainger RIDGID
1VXC3 62840 T-1 Straight Auger
1VXD9 63105
61790
T-3
T-4
Funnel Auger
Heavy-Duty Funnel Auger
1VXE2 63195 T-6 Funnel Retrieving Auger
(Run Machine In Reverse)
1VXE4 63205 T-8 Grease Cutter, 21⁄2"
1VXC2 61970 T-13 Sawtooth Cutter, 21⁄2"
1VXG4
1VXG6
98035
98040
T-50-1
T-50-2
Sharktooth Cutter, 3"
Sharktooth Cutter, 4"
Tools – Fits 11⁄4" Sectional Cable (C-11, C-12, C-14 and C-15)
KJ-1750 for 11⁄4" to 4" (32-100mm) Drain Lines
• Powerful: Actual working pressure of 1750 psi and flow of 1.4 GPM for fast, effective
cleaning of lines.
•
Pulse Action: Two levels of pulse are standard. Activate the KJ-1750’s pulse action to
easily negotiate difficult bends and traps.
•
Portable: The optional H-30 Cart rolls the jetter and hose to the job site. The jetter is
easily removed from the cart in seconds for hard to reach drain or for remote storage.
Optional adapter allows the KJ-1750 to be mounted on the compact H-10 Cart.
•
Electrical Requirement: The 2.0 HP motor draws a maximum of 17 Amps which requires
a 20 Amp, 115 Volt circuit.
Model KJ-1750-C
on H-30 Cart
Catalog No. Model No. Description Wt.
Grainger RIDGID
4CX15 62697 KJ-1750-C KJ-1750 230V Jetter with Dual Pulse
– H-41, H-42, and H-44 1⁄8" NPT Nozzles
– 50' x 1⁄8" Sink Trap Hose
– Nylon Storage Bag
– Nozzle Cleaning Tool
– H-30 Cart
– 110' x 1⁄2" Jet Hose
155 lb.
(70.3 kg)
Jetter Nozzles and Hoses
Catalog No. Model
No. Description Hose
I.D.
Hose
O.D.
Grainger RIDGID
4CW87 64742 H-41 KJ-1750 Propulsion Nozzle 1⁄8" NPT
4CW88 64747 H-42 KJ-1750 Penetrating Nozzle Fits 1⁄8" & – –
4CW99 64752 H-44 KJ-1750 Drop Head Nozzle 1⁄4" Hose
4CW89 64757 H-51 KJ-1750 Propulsion Nozzle 1⁄4" NPT – –
4CW90 64762 H-52 KJ-1750 Penetrating Nozzle Fits 1⁄2" Hose
4GL58 53037 H-1850 1⁄8" x 50' Sink Trap Hose 1⁄8"3/16"
4CW91 47597 H-1435 1⁄4" x 35' 3⁄16"1⁄4"
4CW98 51587 H-1211 1⁄2" x 110' 1⁄2" Jet Hose 1⁄4"1⁄2"
Drain CleaningDrain Cleaning
Water Jetters
7372
K-1500 Sectional Machine
For 2" to 8" (50-200 mm) Drain and Sewer Lines
KJ-2200 Water Jetter
Jets 11⁄4" to 6" (32-150mm) Drain Lines
This jetter propels a highly flexible hose through 11⁄4" to 6" lines – blasting
through sludge, soap and grease blockages. As you pull the hose back, it
power scrubs the line flushing debris away, restoring drain lines to their full,
free-flowing capacity.
•
Powerful: Actual working pressure of 2200 psi and flow of 2.4 GPM for fast, effective
cleaning of lines.
•
Easy to Use: Thrust propels the hose down the line. You simply guide the hose into the
drain.
•
Pulse Action: Activate the KJ-2200’s pulse action to easily negotiate difficult bends and
traps.
•
Portable: The optional H-30 cart rolls the jetter and hose to the job site. The jetter is easily
removed from the cart in seconds for hard to reach drains, indoor applications or remote
storage.
•
Convenient: Standard equipment includes FV-1 foot valve. It makes remote or indoor
operation simple and safe. You control the jetting action at the drain while leaving the jetter
outdoors.
•
Quality & Dependability: Triplex pump with corrosion-resistant, forged brass head.
Reduced number of fittings, hoses and parts minimizes leaks and down time – keeping you
on the job.
•
Versatile: Optional power washer package cleans cables, tools and other
heavily soiled equipment.
• New and improved 6.5 HP Recoil start gasoline engine starts easily. Features: ON/OFF
switch; choke and throttle controls; easy access oil fill
and dip stick.
Model KJ-2200-C
Catalog No. Model No. Description Wt.
Grainger RIDGID
2RPC8 63882 KJ-2200-C
KJ-2200 Jetter with Pulse
– H-61, H-62, and H-64 1⁄8" NPT Nozzles
– H-71 and H-72 1⁄4" NPT Nozzles
– 75' x 1⁄4" Trap Hose
– FV-1 Foot Valve
– Nozzle Cleaning Tool
– H-10 Cart
– 110' x 1⁄4" Trap Hose
145 lb.
(65.8kg)
KJ-3000 Water Jetter
Jets 2" to 8" (50-200mm) Drain Lines
The RIDGID KJ-3000 portable water jetter gives you 3000 psi actual working pressure to
handle large commercial and industrial applications. This jetter propels a highly flexible and
lightweight hose through 2" to 8" lines – blasting through sludge, soap, grease, and sediment
blockages. As you pull the hose back, it power scrubs the line flushing debris away and restor-
ing drain lines to their full, free-flowing capacity – all without the use of harmful chemicals.
•
Powerful: Actual working pressure of 3000 psi and flow of 4.0 GPM for fast, effective
cleaning of lines.
•
Lightweight Hose: Hose with nylon braid provides significant weight reduction and
increased flexibility – all without reducing strength. Allows the thrust to propel the hose
further down the line.
•
Complete: With the KJ-3000’s removable hose reel, there is no need to purchase expensive
portable hose reels. Standard packages come equipped to handle indoor and remote appli-
cations.
•
Convenient: Completely remove the hose reel to ease loading onto service trucks. Simply
rotate the hose reel forward to gain full access to the engine’s gas tank and air filter.
•
Maneuverable: In the heavy-duty 3000 psi jetter category, the RIDGID
KJ-3000 is one of the most maneuverable jetters on the market. The unit, on its unique two-
wheeled cart, easily fits through standard size doors and can
negotiate tight turns with the greatest of ease.
•
Pulse Action: Activate the KJ-3000’s pulse action to easily negotiate difficult bends and
traps.
•
Quality & Dependability: Triplex pump with corrosion-resistant, forged brass head. Gear
reducer allows pump to run at slower (optimal) speed. Reduced number of fittings, hoses
and parts minimizes leaks and downtime – keeping you on the job.
•
Versatile: Power wash package and chemical injector system cleans cables, tools, and
other heavily soiled equipment.
• 13 HP Recoil start gasoline engine starts easily. Features: ON/OFF switch; choke and throt-
tle controls; easy access oil fill and dip stick.
Model KJ-3000
Root Ranger root cutting jetter
nozzle included with KJ-3000.
KJ-3000 with hose reel removed Catalog No. Model
No. Description Wt.
Grainger RIDGID
4NV37 64882 KJ-3000 KJ-3000 Jetter with Pulse
– H-91 and H-92 1⁄4" NPT Nozzles
– RR3000 Root Cutting Nozzle
– H-38 Hose Reel with
200' x 3⁄8" ID Jet Hose
– 50' x 3⁄8" ID Jet/Wash Hose
– Pressure Wash Package
– FV-1 Foot Valve
– Nozzle Cleaning Tool
215 lb. (97.5 kg)
160 lb. (72.6 kg) w/o
Hose Reel
Drain CleaningDrain Cleaning
Water Jetters
7574
The Emerson logo is a trademark and service mark of Emerson Electric Co. ©2008, RIDGID, Inc.
DIAGNOSTICS PRESSING PIPE & TUBE TOOLS DRAIN MAINTENANCE POWER TOOLS
ALL DAY TOUGH
RIDGID.com
RID-238 AllDayToughAd-SHTimes.indd 1 4/28/08 2:26:30 PM
Drop Head Auger
For cleaning back to back mounted
fixtures e.g., sinks where cable needs to
be led into down pipe.
Straight Auger
For use in exploring and breaking
up stoppages or returning sample to
surface to determine correct tool.
Hook Auger
For heavy and dense root stoppages
in pipes that require hooking and
breaking up.
Retrieving Auger
For searching for cable which is broken
or lost in line.
Spade Cutter
For following up after augers have been
used and to open up floor drains.
Four Blade Saw Tooth Cutter
For blockages caused by hardened,
glazed material such as chemical
deposits.
Grease Cutter
For lines which have become badly
greased with detergents and have
to be opened.
Spiral Saw Tooth Cutter
For clearing any stoppage, roots, rags,
sticks, etc.
Spiral Bar Cutter
For main sewers blocked by roots,
leaf debris, sticks, sawdust, cloth, and
sacking.
Grease “C” Cutter
For grease blockage in lines leading from
garbage disposal unit or waste pipe.
Expanding Finish Cutters
For final removal of material adhering to
walls and certain roots of fibrous nature.
Chain Knocker
For use when vigorous action is required
for cleaning of scale in pipes and boiler
tubes.
Flue Brush
For use for finish cleaning required of
boiler tubes and heat exchangers.
Always start with a straight auger to try and determine what you are
trying to clean. Then chose the correct cutter to clear the drain.
Funnel Auger
For use as second tool in line. Breaks
up remains of stoppage left by straight
auger.
Saw Tooth Cutter
For cleaning lines blocked heavily with
roots. Unique design permits cutter to
be removed from damaged pipe without
locking.
Sharktooth Cutter
For use in cleaning pipes of general
material clinging to pipe walls.
Drain Cleaning
76
