Engineered
for Safety
Designed for Style
3M Occupational Health and Environmental Safety Division
Protective Eyewear Catalog
2
Protection all the way
We believe that health and safety are the priorities in any working
environment, and that greater comfort and modern styles improve
worker compliance with regulatory requirements for protective eyewear.
Therefore, we take care in adding comfort features where they are
needed most, such as heavy contact areas like nose bridges and temple
tips. The materials we choose to provide better comfort are designed to
be durable to last and soft to the touch. We are also continually working
on new coatings, new materials and new designs to bring the latest
technology, innovation and fashion into our protective eyewear line.
What contributes to eye injuries at work?
• Not wearing eye protection. According to the Bureau of Labor
Statistics, nearly three out of every ve workers injured are not
wearing eye protection at the time of the accident.
• Wearing the wrong kind of eye protection for the job. The
Bureau of Labor Statistics also reported that about 40% of the
injured workers were wearing some form of eye protection when the
accident occurred. However, these workers were most likely to be
wearing protective eyeglasses with no side shields.
What causes eye injuries?
• Flying particles. Per the Department of Labor Statistics, almost
70% of accidents resulted from ying or falling objects or sparks
striking the eye. Injured workers estimated that nearly three-
fths of the objects were smaller than a pinhead. Contact with
chemicals caused one-fth of the injuries.
Where do accidents occur most often?
• Craftwork. Potential eye hazards can be found in nearly
every industry, but according to the Bureau of Labor Statistics,
more than 40% of injuries occurred among craft workers, like
mechanics, repairers, carpenters and plumbers.
• Industrial equipment operation. The Bureau reported that over
a third of the injured workers were operators, such as assemblers,
sanders, and grinding machine operators. Almost half of these
injured workers were employed in manufacturing.
How can eye injuries be prevented?
• Always wear effective eye protection. OSHA standards require
that employers provide workers with suitable eye protection. To
be effective, the eyewear must be of the appropriate type for the
hazard encountered and properly tted.
• Better training and education. According to the Bureau of Labor
Statistics, most workers were hurt while doing their regular jobs.
Workers injured while not wearing protective eyewear most often said
they believed it was not required by the situation. Even though the vast
majority of employers furnished eye protection at no cost to employees,
about 40% of the workers received no information on where and what
kind of eyewear should be used.
• Maintenance. Eye protection devices must be properly
maintained. Scratched and dirty devices reduce vision, cause
glare and may contribute to accidents. Scratched or damaged
eyewear should be replaced immediately.
Source for All Statistical Claims: Bureau of Labor Statistics
Protective
Eyewear
injuries happen when you
Eyewear
least expect them.
Be prepared.
3
Protection
All 3M protective eyewear and goggles meet the High Impact
Requirements of ANSI Z87.1-2003 and provide reliable UV
protection—polycarbonate lenses absorb 99.9% UV. Additionally,
3M offers a variety of task-specic lens tints to help reduce glare,
eye stress and fatigue, as well as a range of lens coatings: hard coat,
anti-fog and our DX™ Coating, which is a combination anti-fog hard
coat that provides abrasion resistance and helps to prevent fogging.
DX provides fog resistance for up to four times longer than other
popular combination anti-fog/anti-scratch coatings while maintaining
a comparable abrasion resistance.*
Style
Style is a critical factor when it comes to raising the acceptance of the
user to wear personal protective equipment (PPE).
3M´s range of eyewear
offers a variety of modern and stylish products from which to choose.
Compatibility
Eye protection must not restrict vision or movement or interfere
with the function of other personal protective equipment. Protective
eyewear should t as closely to the face as possible. When it is
necessary to wear a safety spectacle with other protective equipment,
choose a frame with t adjustment features, such as an adjustable
nose bridge or temples that can be adjusted by changing the tilt or
length to maintain the proper position close to the face. When wearing
earmuffs, select protective eyewear with thin temples or straps that
t closely to the side of the head in order to reduce their effect on the
ability of cushions to seal around the ear.
Comfort
Many 3M products come with adjustable features and soft materials in
points of contact, which help improve t and comfort for different face
sizes and shapes.
* 3M R&D Lab, October 2010.
Protection
Eye Protection Information
Polycarbonate Lens Selection Guide 4
The Human Eye 5
Premium
Light Vision™ 6
Smart Lens™ 7
GlareX™ 7
Fuel™ 8
Moon Dawg™ 8
OCC™ 9
Value
Metaliks™ 10-11
Privo™ 11
Nitrous™ 12
Rene™ 13
Ana™ 13
Maxim™ 14-15
X.Sport™ 16
BX™ 16
QX™ 17
SX™ 17
Nassau™ 18
Malibu™ 19
EX™ 19
Nuvo™ 19
Lexa™ 20
Fectoids™ 20
Economy
Virtua™ 21-23
Zora™ 24
Economy
Seepro™ 24
KX™ 25
OX™ 25
Tour-Guard™ III 25
Readers
Light Vision™ 26
Lexa™ 26
BX™ 27
Nuvo™ 28
Virtua™ 28
Goggles
Maxim™ 30, 32
Fectoggles™ 31
Lexa™ GoggleGear™ 31
Modul-R™ 32
Centurion™ 33
332 & 334 33
Accessories & Displays
Displays for Merchandising 34
Super-Clear™ Lens Cleaning Products 34
Protective Eyewear Case 35
Breakaway Lanyard 35
Infrared Welding Flip-Up 35
Goggle Retainer Ring 35
Clear Slip-On Side Shields 35
Additional Information
Features Selection Guide 36-37
3M™ Protective Eyewear Products — Table of Contents
& Style
4
Lens Color/
Type
Color of Light
Reduced or
Blocked*
Lens Properties/Use
Percent of Visible
Light Passing
through the Lens
(approx.)
Suggested Applications/Environments
Clear None Maximum amount of light reaches
the eye for good vision and acuity. 85%+ General everyday eye protection.
Gray, Brown,
Bronze All Reduces brightness and glare
from the sun. 10%-25% Mainly for outdoor daytime use as in typical
sunglass use.
Mirror &
Colored Mirror All Reduces brightness and glare
from the sun. 10%-25% Mainly for outdoor daytime use as in typical
sunglass use.
Indoor/Outdoor All Reduces brightness and glare when
working both indoors and outdoors. 50%
For tasks requiring frequent movement indoor
to/from outdoor. Loading docks, forklift drivers,
construction or similiar jobs.
Photochromic All Reduces brightness and glare
from the sun and indoor lighting.
Varies from 20%
to 80%
Lens darkens when outside and lightens when
inside. Do not use for frequent indoor to/from
outdoor movement.
Polarized All Reduces brightness and glare
from the sun. 15% Exceptional for reducing reflective glare. Mainly
for outdoor use.
Yellow/Amber Purple and Blue
Increases contrast, reduces
haze from blue lighting, excellent
UV protection.
85%-92% Good for inspection tasks and hazy, overcast or
foggy days. Never use for night driving.
Pink/Vermillion Green Increases contrast, low level indoor
lighting glare reduction. 50% Good for inspection tasks. Some workers prefer
pink/vermillion over yellow/amber.
Blue Yellow Reduces brightness and glare
from indoor lighting. 35%-65% Very useful to reduce glare, eye stress and
fatigue in yellow light environments.
Filter Shades,
Green & Gray Red Reduces ultraviolet, visible and
infrared radiation.
Depends upon
shade number
Predominately used for gas welding, cutting,
brazing and soldering, metal making, furnace
work and open flames.
MinimIzeR™All Reduces ultraviolet, visible and
infrared radiation. 50%
Provides good visual sight and acuity while
absorbing UV and some IR. Excellent for wearing
with welding helmet.
This Polycarbonate Lens Selection Guide will help you understand the need for different color lenses and lens types for industrial applications. It
will also help you determine what type of lens is best for your application and environment. There are many lens options other than clear, gray and
mirror. When choosing a lens, the basic “rule of thumb” is to consider color opposites. Examples of these opposites are shown in the chart below in
columns one and two.
Clear
Polarized
Gray, Brown, Bronze
Yellow/Amber
Mirror & Colored Mirror
Pink/Vermillion
Indoor/Outdoor
Blue
Photochromic
Filter Shades Gray
and Green
Polycarbonate Lens
Selection Guide
* All polycarbonate safety lenses absorb 99.9% ultraviolet (UV) light.
5
Pupil
Cornea
Iris
Conjuntiva
Lens
Macula Lutea
Blood-vessel
Vitreous Humor
Superior
rectus muscle
Optic Canal
Optic Nerve
Sclera
Retina
Aqueous Humour
Superior
rectus muscle
ULTRAVIOLET SPECTRUM VISIBLE SPECTRUM INVISIBLE SPECTRUM - INFRA-RED
100NM
280NM
315NM
380NM
400NM
500NM
570NM
600NM
650NM
780NM
1400NM
2000NM
UV C UV B U.V.A VIOLET INDIGO BLUE GREEN YELLOW RED NEAR I.R. MIDDLE I.R.
CORNEA CONJUNCTIVITIS
PARTIAL BLINDNESS
LENS
RETINA
UV C
100 TO 280NM
CONJUNCTIVITIS
PARTIAL BLINDNESS
UV B
280 TO 315NM
UV A
315 TO 380NM
BLUE LIGHT
380 TO 480NM
VISIBLE LIGHT
380 TO 780NM
NEAR IR
780 TO 1.400NM
MIDDLE IR
1.400 TO 2.000NM
CONJUNCTIVITIS
PARTIAL BLINDNESS
CATARACT
PREMATURE AGING
CATARACT
PREMATURE AGING CATARACT CATARACT
PARTIAL BLINDNESS
RETINITIS
PIGMENTOSA BLINDNESS
VISION PROBLEMS
DISCONTINUOUS VISION
PARTIAL BLINDNESS
PHOTORETINITIS
The Human Eye
· The Cornea, in direct contact with external environment,
plays an essential part on the transmission of light rays. It is
the structure of the human body which has the highest
tactile sensibility.
· The Pupil (light controller), situated in the middle of the iris,
works like the diaphragm of a camera. Its diameter changes
in accordance with the luminosity.
· The Lens allows focusing (near vision, far vision) thanks to a
control muscle. With age this muscle loses power and impacts
near vision (presbyopia). The lens can lose its transparency due to
exposure to IR (infrared light) and UV (ultraviolet light), resulting in
loss of vision (cataract).
· The Retina, where all light beams converge, transmits all
information through the optic nerve to the brain in order to
create your vision. Burned retina cells are lost forever which
causes irreversible loss of vision.
Industrial hazards for the eyes:
· Mechanical hazards: dust, shock,
solid particles.
· Thermal hazards: hot liquid, molten
splash, flames.
· Chemical hazards: splashes of
acids, solvents.
· Radiation hazards: ultraviolet,
infrared, visible, light, laser.
· Electrical hazards: direct contact,
short-circuit electric arc.
Facts on eye damage:
Every day more than 600 workers worldwide suffer from eye
injury simply because they do not wear protective eyewear.*
* Source: Bureau of Labor Statistics
All 3M™ Protective Eyewear that meet the requirements of ANSI Z87.1-2003 provide 99.9% UV protection (UVA & UVB).
6
3M™ Protective
Light Vision™ OTG
Over-the-glass (OTG) design with hands-free lighting that ts over
most personal prescription eyewear
Light Vision™
Full-frame style, hands-free direct lighting
Light Vision™ 2
Half-frame style, hands-free direct lighting
Product Number Product Name UPC Number
11356-00000-10 3M™ Light Vision™ Protective Eyewear, Clear Anti-Fog Lens, Gray Frame, LED Lights 100 78371 62109 1
Product Number Product Name UPC Number
11476-00000-10 3M™ Light Vision™ 2 Protective Eyewear, Clear Anti-Fog Lens, Gray Frame, LED Lights 100 78371 62111 4
• Ultra-bright, adjustable LED lights
• Long-lasting batteries provide up to 50 hours of continuous use
• Cushioned brow, nose bridge and temple tips
• Soft nose bridge fits many faces
• Includes microfiber storage bag and lanyard
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
• Ultra-bright, adjustable LED lights
• Long-lasting batteries provide up to 50 hours of continuous use
• Adjustable length temples
• Soft nose bridge and temple tips
• Includes microfiber storage bag and lanyard
• Available in readers with three bifocal magnification strengths: +1.50,
+2.00, +2.50 (See page 26)
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
• Ultra-bright, adjustable LED lights
• Long-lasting batteries provide up to 50 hours of continuous use
• Secure-Grip temple tips
• Includes microfiber storage bag and lanyard
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
11489-00000-10 3M™ Light Vision™ OTG Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, LED Lights 100 78371 62203 6
Eyewear
7
Smart Lens™
Changing outdoor light conditions doesn’t require changing eyewear anymore
• Lightens and darkens with changing outdoor light conditions
- Light to dark in less than 20 seconds
- Dark to light in less than 3 minutes
• Soft, adjustable nose bridge
• Durable frame with nylon brow and magnesium alloy temples
• Spring-hinged temples for narrow or wide fit
• Includes microfiber storage bag and lanyard
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
13407-00000-5 3M™ Smart Lens™ Protective Eyewear, Photochromic Anti-Fog Lens, Black Frame 100 78371 62033 9
• Polarized lenses block reflective light
• Lightweight design for added comfort
• Includes microfiber storage bag and lanyard
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
12236-00000-20 3M™ GlareX™ Protective Eyewear, Gray Polarized Hard Coat Lens, Black Frame 100 78371 62376 7
GlareX™
The polarized choice
Safety directors should assess their particular workplace and make all people wearing Smart Lens™
photochromic eyewear aware of the time required for the lens transition. Special care should be taken
when moving from outdoors to indoors. Outdoor temperatures may affect the lens transmission time. Do
not store on vehicle dashboard. Prolonged exposure to intense heat can damage eyewear. Always store
Smart Lens in protective bag.
Light Reactive Lenses Adjust with
Changing Outdoor Light Conditions
8
3M™ Protective
Eyewear
Fuel™
Tired of running on empty? Pump up compliance levels with Fuel
• Sleek, wraparound design
• Three frame styles
• Flared accents
• Soft temple tips and nose bridge
• Adjustable nose bridge on Fuel™ X2 models
• Includes microfiber storage bag and lanyard
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 (Fuel™ 2 Only)
and the High Impact Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
11640-00000-10 3M™ Fuel™ Protective Eyewear, Red Mirror Lens, Metallic Sand Frame 100 78371 62147 3
11641-00000-10 3M™ Fuel™ Protective Eyewear, Blue Mirror Lens, Silver Frame 100 78371 62148 0
11642-00000-10 3M™ Fuel™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Blue Frame 100 78371 62149 7
11663-00000-10 3M™ Fuel™ Protective Eyewear, Brown Anti-Fog Lens, Burnt Copper Frame 100 78371 62158 9
11664-00000-10 3M™ Fuel™ Protective Eyewear, Blue Mirror Hard Coat Lens, Glacier White Frame 100 78371 62159 6
11650-00000-10 3M™ Fuel™ 2 Protective Eyewear, Red Mirror Lens, Metallic Sand Frame 100 78371 62153 4
11651-00000-10 3M™ Fuel™ 2 Protective Eyewear, Clear Anti-Fog Lens, Metallic Sand Frame 100 78371 62154 1
11652-00000-10 3M™ Fuel™ 2 Protective Eyewear, Blue Mirror Lens, Silver Frame 100 78371 62155 8
11653-00000-10 3M™ Fuel™ 2 Protective Eyewear, Clear Anti-Fog Lens, Silver Frame 100 78371 62156 5
11654-00000-10 3M™ Fuel™ 2 Protective Eyewear, Clear Anti-Fog Lens, Black Frame 100 78371 62157 2
11635-00000-10 3M™ Fuel™ X2 Protective Eyewear, Red Mirror Lens, Dark Copper Frame 100 78371 11635 1
11636-00000-10 3M™ Fuel™ X2 Protective Eyewear, Brown Anti-Fog Lens, Dark Copper Frame 100 78371 11636 8
11637-00000-10 3M™ Fuel™ X2 Protective Eyewear, Clear Anti-Fog Lens, Dark Copper Frame 100 78371 11637 5
Moon Dawg™
Surf-inspired styling
• Wide temples
• Rectangular shaped lens
• High fashion look
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
11213-00000-20 3M™ Moon Dawg™ Protective Eyewear, Gray Anti-Fog Lens, Tortoise Shell Frame 100 78371 62176 3
11214-00000-20 3M™ Moon Dawg™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Tortoise Shell Frame 100 78371 62177 0
11215-00000-20 3M™ Moon Dawg™ Protective Eyewear, Gray Anti-Fog Lens, Black Frame 100 78371 62178 7
11216-00000-20 3M™ Moon Dawg™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Black Frame 100 78371 62179 4
9
Product Number Product Name UPC Number
11440-00000-10 OCC™ 101 Protective Eyewear, Blue Mirror Lens, Silver Aluminum Frame 100 78371 62362 0
11441-00000-10 OCC™ 102 Protective Eyewear, Red Mirror Lens, Black Aluminum Frame 100 78371 62363 7
11444-00000-10 OCC™ 201 Protective Eyewear, Blue Mirror Lens, Silver Aluminum Frame 100 78371 62366 8
11445-00000-10 OCC™ 202 Protective Eyewear, Gray Polarized Hard Coat Lens, Silver Aluminum Frame 100 78371 62367 5
11446-00000-10 OCC™ 203 Protective Eyewear, Red Mirror Lens, Black Aluminum Frame 100 78371 62368 2
11447-00000-10 OCC™ 204 Protective Eyewear, Clear Anti-Fog Lens, Black Aluminum Frame 100 78371 62369 9
11448-00000-10 OCC™ 301 Protective Eyewear, Red Mirror Lens, Black Aluminum Frame 100 78371 62370 5
11449-00000-10 OCC™ 302 Protective Eyewear, Blue Mirror Lens, Silver Aluminum Frame 100 78371 62371 2
11451-00000-10 OCC™ 304 Protective Eyewear, Gray Polarized Hard Coat Lens, Silver Aluminum Frame 100 78371 62373 6
11716-00000-10 OCC™ 401 Protective Eyewear, Silver Mirror Lens, Black Aluminum Frame 100 78371 62030 8
11717-00000-10 OCC™ 402 Protective Eyewear, Gold Mirror Lens, Burgundy Aluminum Frame 100 78371 62031 5
11718-00000-10 OCC™ 403 Protective Eyewear, Red Mirror Lens, Silver/Gold Aluminum Frame 100 78371 62032 2
11732-00000-10 OCC™ 700 Protective Eyewear, Clear Anti-Fog Lens, Gray Frame 100 78371 62183 1
11733-00000-10 OCC™ 700 Protective Eyewear, Gray Anti-Fog Lens, Gray Frame 100 78371 62184 8
11734-00000-10 OCC™ 700 Protective Eyewear, Indoor/Outdoor Mirror Lens, Gray Frame 100 78371 62185 5
11727-00000-10 OCC™ 800 Protective Eyewear, Clear Anti-Fog Lens, Black/Silver Temple 100 78371 62198 5
11728-00000-10 OCC™ 800 Protective Eyewear, Gray Anti-Fog Lens, Black/Silver Temple 100 78371 62199 2
11729-00000-10 OCC™ 800 Protective Eyewear, Indoor/Outdoor Mirror Lens, Black/Silver Temple 100 78371 62200 5
11774-00000-10 OCC™ 1100 Protective Eyewear, Clear Anti-Fog Lens, Gun Metal Gray Frame 100 78371 11774 7
11775-00000-10
OCC
™
1100 Protective Eyewear, Gray Indoor/Outdoor Anti-Fog Lens, Gun Metal Gray Frame
100 78371 11775 4
11776-00000-10 OCC™ 1100 Protective Eyewear, Gray Anti-Fog Lens, Gun Metal Gray Frame 100 78371 11776 1
11777-00000-10 OCC™ 1100 Protective Eyewear, Blue Mirror Lens, Gun Metal Gray Frame 100 78371 11777 8
11778-00000-10 OCC™ 1200 Protective Eyewear, Clear Anti-Fog Lens, Gun Metal Gray Frame 100 78371 11778 5
11779-00000-10
OCC
™
1200 Protective Eyewear, Gray Indoor/Outdoor Anti-Fog Lens, Gun Metal Gray Frame
100 78371 11779 2
11780-00000-10 OCC™ 1200 Protective Eyewear, Gray Anti-Fog Lens, Gun Metal Gray Frame 100 78371 11780 8
11781-00000-10 OCC™ 1200 Protective Eyewear, Blue Mirror Lens, Gun Metal Gray Frame 100 78371 11781 5
• Eight OCC eyewear product lines
• High-quality, lightweight aluminum frames (100, 200, 300 Series)
• Spring hinge temples (100, 200, 300, 400 Series)
• Adjustable nose bridge on most models
• OCC logo on frame or lens
• Includes microfiber storage bag and lanyard
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Indicia of Orange County Choppers: ©2010 Orange County Choppers Design Properties LLC. Products, Packaging and all other indicia: ©2010 3M. All Rights Reserved. OCC products manufactured by 3M Company
under license from Orange County Choppers Merchandising LLC. Orange County Choppers, OCC, and the OCC LOGO and related indicia are trademarks of Orange County Choppers Design Properties, LLC used under
license. 3M and all other trademarks used herein or hereon are trademarks of 3M Company.
Rev up your eyewear protection
10
3M™ Protective
• Metal frame and temples
• Spring-hinge temples with soft rubber tips
• Soft, adjustable nose bridge
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Metaliks™ GT
Race-inspired metal frame
Product Number Product Name UPC Number
11554-00000-20 3M™ Metaliks™ GT Protective Eyewear, Clear Anti-Fog Lens, Bronze Frame 100 78371 11554 5
11555-00000-20 3M™ Metaliks™ GT Protective Eyewear, Bronze Anti-Fog Lens, Bronze Frame 100 78371 11555 2
11556-00000-20 3M™ Metaliks™ GT Protective Eyewear, Blue Mirror Lens, Bronze Frame 100 78371 11556 9
Product Number Product Name UPC Number
11343-10000-20 3M™ Metaliks™ Sport Protective Eyewear, Clear Anti-Fog Lens, Nickel Frame 100 78371 62355 2
11344-10000-20 3M™ Metaliks™ Sport Protective Eyewear, Gray Anti-Fog Lens, Nickel Frame 100 78371 62356 9
11345-10000-20 3M™ Metaliks™ Sport Protective Eyewear, Indoor/Outdoor Mirror Lens, Nickel Frame 100 78371 62357 6
11346-10000-20 3M™ Metaliks™ Sport Protective Eyewear, Amber Anti-Fog Lens, Nickel Frame 100 78371 62358 3
11540-10000-20 3M™ Metaliks™ Sport Protective Eyewear, Blue Mirror Lens, Nickel Frame 100 78371 62375 0
10151-00000-20 3M™ Metaliks™ Sport Protective Eyewear, Railway Signal Recognition Anti-Fog Lens*, Nickel Frame 100 78371 10151 7
• Metal temples with soft rubber tips
• Soft nose bridge
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Metaliks™ Sport
Brushed nickel frame and sport-styled lens
* Scientifically formulated lens material provides accurate red signal visibility. These RSR lenses are designed to provide railway personnel with glare, brightness, and
ultraviolet protection, as well as excellent signal light recognition. This type of lens is also used by U.S. and Canadian military personnel who need lens neutrality and red
signal visibility.
Eyewear
11
Privo™
Brings European-inspired styling to protective eyewear
• Soft nose bridge and temple tips for all-day comfort
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
12261-00000-20 3M™ Privo™ Protective Eyewear, Clear Anti-Fog Lens, Black Frame 100 78371 62087 2
12262-00000-20 3M™ Privo™ Protective Eyewear, Gray Anti-Fog Lens, Black Frame 100 78371 62088 9
12263-00000-20 3M™ Privo™ Protective Eyewear, Amber Anti-Fog Lens, Black Frame 100 78371 62089 6
12264-00000-20 3M™ Privo™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Black Frame 100 78371 62090 2
12265-00000-20 3M™ Privo™ Protective Eyewear, Clear Anti-Fog Lens, Silver Frame 100 78371 62091 9
12266-00000-20 3M™ Privo™ Protective Eyewear, Gray Anti-Fog Lens, Silver Frame 100 78371 62092 6
12267-00000-20 3M™ Privo™ Protective Eyewear, Amber Anti-Fog Lens, Silver Frame 100 78371 62093 3
12268-00000-20 3M™ Privo™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Silver Frame 100 78371 62094 0
Metaliks™
Stylish metal frames
Product Number Product Name UPC Number
11532-10000-20 3M™ Metaliks™ Protective Eyewear, Clear Anti-Fog Lens, Blue Metal Frame 100 78371 62374 3
15170-10000-20 3M™ Metaliks™ Protective Eyewear, Clear Anti-Fog Lens, Polished Metal Frame 100 78371 62380 4
15171-10000-20 3M™ Metaliks™ Protective Eyewear, Gray Anti-Fog Lens, Polished Metal Frame 100 78371 62381 1
15172-10000-20 3M™ Metaliks™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Metal Frame 100 78371 62382 8
10150-00000-20 3M™ Metaliks™ Protective Eyewear, Railway Signal Recognition Anti-Fog Lens*, Silver Frame 100 78371 10150 0
• Metal temples with soft rubber tips
• Soft, adjustable nose bridge
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
* Scientifically formulated lens material provides accurate red signal visibility. These RSR lenses are designed to provide railway personnel with glare, brightness, and
ultraviolet protection, as well as excellent signal light recognition. This type of lens is also used by U.S. and Canadian military personnel who need lens neutrality and red
signal visibility.
12
3M™ Protective
Nitrous™
Contemporary, street-wear styling
Nitrous™ CCS
Designed to offer workers convenient access to both eyewear and
hearing protection
Product Number Product Name UPC Number
11712-00000-20 3M™ Nitrous™ Protective Eyewear, Bronze Anti-Fog Lens, Silver Frame 100 78371 62160 2
11713-00000-20 3M™ Nitrous™ Protective Eyewear, Clear Anti-Fog Lens, Blue Frame 100 78371 62161 9
11715-00000-20 3M™ Nitrous™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Metallic Frame 100 78371 62163 3
Product Number Product Name UPC Number
11801-00000-20 3M™ Nitrous™ CCS Protective Eyewear, Clear Anti-Fog Lens, Black Frame 100 78371 11801 0
11802-00000-20 3M™ Nitrous™ CCS Protective Eyewear, Gray Anti-Fog Lens, Black Frame 100 78371 11802 7
11803-00000-20 3M™ Nitrous™ CCS Protective Eyewear, Indoor/Outdoor Mirror Lens, Black Frame 100 78371 11803 4
• Three brushed metallic frame colors with two-tone molding
• Soft nose bridge and temple tips
• Includes microfiber storage bag and lanyard
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
•
Designed to keep eyewear and earplugs attached, untangled and ready to use
• Can help reduce the expense of replacing lost earplugs and eyewear
•
Earplug cord can be worn around the neck to carry eyewear when neither
product is in use
• Comfortable, soft temple tips
• FREE earplugs included with purchase
• Compatible with a variety of vinyl-corded earplugs
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Corded earplug
Control System
(CCS)
Eyewear
13
Product Number Product Name UPC Number
11390-00000-20 3M™ Ana™ Protective Eyewear, Clear Anti-Fog Lens, Metal Temple 100 78371 62359 0
11391-00000-20 3M™ Ana™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Metal Temple 100 78371 62360 6
11399-00000-20 3M™ Ana™ Protective Eyewear, Gray Anti-Fog Lens, Metal Temple 100 78371 62361 3
Ana™
Smaller eyewear for smaller faces
• Sleek, unisex design for smaller faces
• Metal temples with soft rubber tips
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Rene™
Better t means better protection
Product Number Product Name UPC Number
11735-00000-20 3M™ Rene™ 201 Protective Eyewear, Clear Anti-Fog Lens, Teal Frame 100 78371 62186 2
11736-00000-20 3M™ Rene™ 202 Protective Eyewear, Gray Anti-Fog Lens, Teal Frame 100 78371 62187 9
11737-00000-20 3M™ Rene™ 203 Protective Eyewear, Indoor/Outdoor Mirror Lens, Teal Frame 100 78371 62188 6
11738-00000-20 3M™ Rene™ 101 Protective Eyewear, Clear Anti-Fog Lens, Mocha Frame 100 78371 62189 3
11739-00000-20 3M™ Rene™ 102 Protective Eyewear, Gray Anti-Fog Lens, Mocha Frame 100 78371 62190 9
11740-00000-20 3M™ Rene™ 103 Protective Eyewear, Indoor/Outdoor Mirror Lens, Mocha Frame 100 78371 62191 6
• Designed for smaller faces
• Padded, adjustable nose bridge available on 200 Series only
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
14
3M™ Protective
Eyewear
Maxim™ Sport
Contemporary, athletic styling
• Dual-injected, cushioned brow bar for comfort and protection
• Dual aspheric lens and wraparound coverage
• Soft, adjustable nose bridge
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
13274-10000-20 3M™ Maxim™ Sport Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Silver/Blue Frame 100 78371 62245 6
13280-10000-20 3M™ Maxim™ Sport Protective Eyewear, Indoor/Outdoor Mirror Lens, Silver/Blue Frame 100 78371 62249 4
Maxim™ GT
Sophistication, style and comfort in protective eyewear
• Dual-injected, cushioned brow bar for comfort and protection
• 3-position pantascopic lens angle adjustment
• Adjustable temple lengths
• Soft nose bridge and temple tips
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
14246-00000-20 3M™ Maxim™ GT Protective Eyewear, Clear Anti-Fog Lens, Metallic Gray and Black Frame 100 78371 62612 6
14247-00000-20 3M™ Maxim™ GT Protective Eyewear, Gray Anti-Fog Lens, Metallic Gray and Black Frame 100 78371 62613 3
14248-00000-20 3M™ Maxim™ GT, Indoor/Outdoor Mirror Lens, Metallic Gray and Black Frame 100 78371 62614 0
15
Maxim™
Style, comfort, t
• Dual-injected, cushioned brow bar for comfort and protection
• 3-position pantascopic lens angle adjustment
• Dual aspheric lens and wraparound coverage
• Adjustable temple lengths
• Prescription lens insert available
• Soft, adjustable nose bridge
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
• Meets U.S. Military VO Regimen for High Velocity Impact*
* Complies to MIL-PRF-31013 Using Test Method MIL STD 662F (V50 Ballistic Test for
Armor)-T37 Shaped (.15 Cal) Projectile @ 650 ft/sec = 440 mph.
Product Number Product Name UPC Number
12289-00000-20 3M™ Maxim™ Protective Eyewear, MinimIzeR™ Lens, Black Temple 100 78371 62232 6
12292-00000-20 3M™ Maxim™ Protective Eyewear, Shade 3.0 IR DX Anti-Fog Hard Coat Lens, Black Temple 100 78371 62233 3
13250-00000-20 3M™ Maxim™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple 100 78371 62235 7
13251-00000-20 3M™ Maxim™ Protective Eyewear, Bronze DX Anti-Fog Hard Coat Lens, Black Temple 100 78371 62236 4
13252-00000-20 3M™ Maxim™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Black Temple 100 78371 62237 1
13259-00000-20 3M™ Maxim™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Denim Temple 100 78371 62240 1
12295-00000-20 3M™ Maxim™ Replacement Lens, MinimIzeR™ Lens 100 78371 62234 0
13267-00000-20 3M™ Maxim™ Replacement Lens, Clear DX Anti-Fog Hard Coat Lens 100 78371 62241 8
12233-00000 3M™ Maxim™ Prescription Insert 100 78371 12233 8
Maxim™ Plus
Style, comfort, wide frame t
• Dual-injected, cushioned brow bar for comfort and protection
• 3-position pantascopic lens angle adjustment
• Dual aspheric lens and wraparound coverage
• Wider frame size to fit workers with larger size heads
• Adjustable temple lengths
• Soft, adjustable nose bridge
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
12282-00000-20 3M™ Maxim™ Plus Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Blue Frame 100 78371 62229 6
12283-00000-20 3M™ Maxim™ Plus Protective Eyewear, Gray DX Anti-Fog Hard Coat Lens, Blue Frame 100 78371 62230 2
12284-00000-20 3M™ Maxim™ Plus Protective Eyewear, Indoor/Outdoor Mirror Lens, Blue Frame 100 78371 62231 9
16
Product Number Product Name UPC Number
15176-00000-20 3M™ X.Sport™ Protective Eyewear, Clear Anti-Fog Lens, Black Frame 100 78371 62383 5
15177-00000-20 3M™ X.Sport™ Protective Eyewear, Gray Anti-Fog Lens, Black Frame 100 78371 62384 2
15178-00000-20 3M™ X.Sport™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Black Frame 100 78371 62385 9
15182-00000-20 3M™ X.Sport™ Protective Eyewear, Clear Anti-Fog Lens, Silver Frame 100 78371 62386 6
10152-00000-20 3M™ X.Sport™ Protective Eyewear, Railway Signal Recognition Anti-Fog Lens*, Black Frame 100 78371 10152 4
X.Sport™
Captures the sport styling of eyewear worn by professional athletes
• Sport-Grip temples
• Soft nose bridge
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
3M™ Protective
* Scientifically formulated lens material provides accurate red signal visibility. These RSR lenses are designed to provide railway personnel with glare, brightness
and ultraviolet protection, as well as excellent signal light recognition. This type of lens is also used by U.S. and Canadian military personnel who need lens
neutrality and red signal visibility as well.
BX™
Sleek, contoured and fully adjustable
• Adjustable length temple
• Lens angle adjustment
• Soft, adjustable nose bridge
• Available in readers with three bifocal magnification strengths:
+1.50, +2.00, +2.50 (See page 27)
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
11380-00000-20 3M™ BX™ Protective Eyewear, Clear Anti-Fog Lens, Silver/Black Frame 100 78371 62052 0
11381-00000-20 3M™ BX™ Protective Eyewear, Gray Anti-Fog Lens, Silver/Black Frame 100 78371 62053 7
11471-00000-20 3M™ BX™ Protective Eyewear, Clear Anti-Fog Lens, Ocean Blue Frame 100 78371 62065 0
11472-00000-20 3M™ BX™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Ocean Blue Frame 100 78371 62066 7
11523-00000-20 3M™ BX™ Protective Eyewear, Light Blue Anti-Fog Lens, Ocean Blue Frame 100 78371 62078 0
11524-00000-20 3M™ BX™ Protective Eyewear, Light Amber Anti-Fog Lens, Ocean Blue Frame 100 78371 62079 7
11525-00000-20 3M™ BX™ Protective Eyewear, Gray Indoor/Outdoor Anti-Fog Lens, Ocean Blue Frame 100 78371 62080 3
Eyewear
17
Product Number Product Name UPC Number
12135-00000-20 3M™ SX™ 1000 Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Half-Frame 100 78371 62217 3
12137-00000-20 3M™ SX™ 1000 Protective Eyewear, Gray DX Anti-Fog Hard Coat Lens, Black Half-Frame 100 78371 62218 0
12141-00000-20 3M™ SX™ 2000 Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Frameless 100 78371 62219 7
QX™
Takes protection higher than ever
• Two temple styles – sport grip and standard grip – to fit workers’ needs
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
• Meets U.S. Military VO Regimen for High Velocity Impact*
(QX 2000 and QX 3000)
* Complies to MIL-PRF-31013 Using Test Method MIL STD 662F (V50 Ballistic Test for
Armor)-T37 Shaped (.15 Cal) Projectile @ 650 ft/sec = 440 mph.
Product Number Product Name UPC Number
12100-10000-20 3M™ QX™ 1000 Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple 100 78371 62206 7
12101-10000-20 3M™ QX™ 1000 Protective Eyewear, Gray DX Anti-Fog Hard Coat Lens, Black Temple 100 78371 62207 4
12109-10000-20 3M™ QX™ 2000 Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple 100 78371 62209 8
12110-10000-20 3M™ QX™ 2000 Protective Eyewear, Gray DX Anti-Fog Hard Coat Lens, Black Temple, Soft Nose Bridge 100 78371 62210 4
12115-10000-20 3M™ QX™ 3000 Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Sport Grip Temple 100 78371 62211 1
12180-10000-20 3M™ QX™ 2000 Protective Eyewear, MinimIzeR™ Lens, Black Temple, Soft Nose Bridge 100 78371 62227 2
12128-10000-20 3M™ QX™ 1000 Replacement Lens, Clear DX Anti-Fog Hard Coat Lens 100 78371 62214 2
12222-10000-20 3M™ QX™ 2000 Replacement Lens, MinimIzeR™ Lens 100 78371 62228 9
12232-00000 3M™ Peltor™ QX™ Prescription Lens Insert 100 78371 12232 1
• Two distinct frame styles – half-frame and frameless
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
SX™
Provides protection and sports-inspired style with a sleek design
SX 1000
SX 2000
QX 3000
QX 1000
18
3M™ Protective
Nassau™ Rave
Adjustability and wraparound protection for a customized t
• Lightweight frame
• Adjustable length temples and lens angle
• Integrated sideshield provides wraparound protection
• Vertically vented brow guard helps minimize fogging
• Polycarbonate lenses absorb 99.9% of UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
14450-00000-20 3M™ Nassau™ Rave Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Frame 100 78371 62271 5
14451-00000-20 3M™ Nassau™ Rave Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Blue Frame 100 78371 62272 2
14459-00000-20 3M™ Nassau™ Rave Protective Eyewear, Shade 3.0 IR DX Anti-Fog Hard Coat Lens, Black Frame 100 78371 62274 6
14460-00000-20 3M™ Nassau™ Rave Protective Eyewear, Shade 5.0 IR DX Anti-Fog Hard Coat Lens, Black Frame 100 78371 62275 3
Nassau™ Vibrance
Contoured protection
• Lightweight frame
• Adjustable length temples
• Contoured, sculpted lens in a wraparound design allows for wide
viewing range
• Soft, form-fitting nose bridge
• Polycarbonate lenses absorb 99.9% of UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
16050-00000-20 3M™ Nassau™ Vibrance Protective Eyewear, Clear Hard Coat Lens, Black Frame 100 78371 62310 1
Nassau™ Plus
Strong, single-lens eyewear protection
Product Number Product Name UPC Number
14300-00000-20 3M™ Nassau™ Plus Protective Eyewear, Clear Anti-Fog Lens, Black Frame 100 78371 62262 3
14327-00000-20 3M™ Nassau™ Plus Protective Eyewear, Clear Anti-Fog Lens, Red/White/Blue Frame 100 78371 62268 5
14347-00000-100 3M™ Nassau™ Plus Replacement Lens, Clear Anti-Fog Lens, Black Frame 100 78371 62269 2
• Lightweight frame
• Adjustable length temples
• Integrated sideshield provides wraparound protection
• Single polycarbonate lens includes molded nose bridge
• Polycarbonate lenses absorb 99.9% of UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Eyewear
19
• Adjustable length temples
• Integral side shields and brow bar
• Soft, adjustable nose bridge
• Available in readers with three bifocal magnification strengths:
+1.50, +2.00, +2.50 (See page 28)
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
11411-00000-20 3M™ Nuvo™ Protective Eyewear, Clear Anti-Fog Lens, Gray Frame 100 78371 62059 9
11412-00000-20 3M™ Nuvo™ Protective Eyewear, Gray Anti-Fog Lens, Gray Frame 100 78371 62060 5
11518-00000-20 3M™ Nuvo™ Protective Eyewear, Clear Anti-Fog Lens, Tortoise Frame 100 78371 62073 5
11519-00000-20 3M™ Nuvo™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Tortoise Frame 100 78371 62074 2
Nuvo™
True “Retro” styling
Malibu™
Classic protection, wraparound style
Product Number Product Name UPC Number
13330-00000-20 3M™ Malibu™ Protective Eyewear, Clear Hard Coat Lens, Gold Frame 100 78371 62377 4
13333-00000-20 3M™ Malibu™ Protective Eyewear, Clear Hard Coat Lens, Black Frame 100 78371 62379 8
• Wraparound lens provides front and side protection
• Metal frame and temples
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
12235-00000-20 3M™ EX™ Protective Eyewear, Clear Anti-Fog Lens, Smoke Frame 100 78371 62045 2
• Secure-Grip temples help hold eyewear in place
• Hinged, vented sideshields for added protection and increased air flow
• Adjustable lens angle and temple length
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
EX™
Versatility for the workplace
20
3M™ Protective
• Adjustable length temples
• Lens angle adjustment
• Soft, adjustable nose bridge
• Available in Fectoids goggle – fully assembled (See page 31)
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Fectoids™
Frameless, wraparound protection
Product Number Product Name UPC Number
16100-00000-20 3M™ Fectoids™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Large 100 78371 62311 8
16200-00000-20 3M™ Fectoids™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Medium 100 78371 62316 3
Lexa™
Proprietary lens geometry and optical design provide full coverage and
a wide viewing range
Product Number Product Name UPC Number
15100-00000-20 3M™ Lexa™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Large 100 78371 62277 7
15200-00000-20 3M™ Lexa™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Medium 100 78371 62287 6
15201-00000-20 3M™ Lexa™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Blue Temple, Medium 100 78371 62288 3
15204-00000-20 3M™ Lexa™ Protective Eyewear, Gray DX Anti-Fog Hard Coat Lens, Black Temple, Medium 100 78371 62289 0
15250-00000-20 3M™ Lexa™ Protective Eyewear, MinimIzeR™ Lens, Black Temple, Medium 100 78371 62299 9
15150-00000-20 3M™ Lexa™ Protective Eyewear, MinimIzeR™ Lens, Black Temple, Large 100 78371 62281 4
15211-00000-20 3M™ Lexa™ Protective Eyewear, Shade 3.0 IR DX Anti-Fog Hard Coat Lens, Black Temple, Medium 100 78371 62292 0
15212-00000-20 3M™ Lexa™ Protective Eyewear, Shade 5.0 IR DX Anti-Fog Hard Coat Lens, Black Temple, Medium 100 78371 62293 7
15152-00000-100 3M™ Lexa™ Fighter Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Medium 100 78371 6222 1
15153-00000-100 3M™ Lexa™ Fighter Protective Eyewear, Gray DX Anti-Fog Hard Coat Lens, Black Temple, Medium 100 78371 62283 8
15154-00000-100 3M™ Lexa™ Fighter Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Large 100 78371 62284 5
15158-00000-100 3M™ Lexa™ Fighter Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Blue Temple, Large 100 78371 62285 2
15258-00000-100 3M™ Lexa™ Fighter Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Red/White/Blue Temple, Medium 100 78371 62301 9
15163-00000-100 3M™ Lexa™ Fighter Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Red/White/Blue Temple, Large 100 78371 62286 9
15245-00000-20 3M™ Lexa™ Replacement Lens, Clear DX Anti-Fog Hard Coat Lens, Medium 100 78371 62297 5
15246-00000-20 3M™ Lexa™ Replacement Lens, Clear DX Anti-Fog Hard Coat Lens, Large 100 78371 62298 2
• Adjustable length temples
• Lens angle adjustment
• Soft, adjustable nose bridge
• Available in readers with three bifocal magnification strengths:
+1.50, +2.00, +2.50 (See page 26)
• Available in Splash GoggleGear™ or Dust GoggleGear™ –
fully assembled (See page 29)
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Eyewear
21
Virtua™Sport
Unisex styling with excellent eye coverage and a comfortable t
• Sporty, high-wrap lens
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
11384-00000-20 3M™ Virtua™ Sport Protective Eyewear, Clear Anti-Fog Lens, Clear Temple 100 78371 62054 4
11385-00000-20 3M™ Virtua™ Sport Protective Eyewear, Clear Hard Coat Lens, Clear Temple 100 78371 62055 1
11386-00000-20 3M™ Virtua™ Sport Protective Eyewear, Gray Anti-Fog Lens, Gray Temple 100 78371 62056 8
11388-00000-20 3M™ Virtua™ Sport Protective Eyewear, Indoor/Outdoor Mirror Lens, Clear Temple 100 78371 62057 5
11542-00000-20 3M™ Virtua™ Sport Protective Eyewear, Light Blue Anti-Fog Lens, Blue Temple 100 78371 62081 0
11543-00000-20 3M™ Virtua™ Sport Protective Eyewear, Light Blue Hard Coat Lens, Blue Temple 100 78371 62082 7
11544-00000-20 3M™ Virtua™ Sport Protective Eyewea, Light Amber Anti-Fog Lens, Amber Temple 100 78371 62083 4
11545-00000-20 3M™ Virtua™ Sport Protective Eyewear, Light Amber Hard Coat Lens, Amber Temple 100 78371 62084 1
11742-00000-20 3M™ Virtua™ Sport Protective Eyewear, Gray Indoor/Outdoor Anti-Fog Lens, Gray Temple 100 78371 62085 8
11743-00000-20 3M™ Virtua™ Sport Protective Eyewear, Gray Indoor/Outdoor Hard Coat Lens, Gray Temple 100 78371 62086 5
Product Number Product Name UPC Number
11796-00000-20 3M™ Virtua™ Sport CCS Protective Eyewear, Clear Anti-Fog Lens 100 78371 11796 9
11797-00000-20 3M™ Virtua™ Sport CCS Protective Eyewear, Clear Hard Coat Lens 100 78371 11797 6
11798-00000-20 3M™ Virtua™ Sport CCS Protective Eyewear, Gray Anti-Fog Lens 100 78371 11798 3
11799-00000-20 3M™ Virtua™ Sport CCS Protective Eyewear, Gray Hard Coat Lens 100 78371 11799 0
Virtua™Sport CCS
Designed to offer workers convenient access to both eyewear and
hearing protection
• Designed to keep eyewear and earplugs attached, untangled and
ready to use
• Can help reduce the expense of replacing lost earplugs and eyewear
• Earplug cord can be worn around the neck to carry eyewear when
neither product is in use
• FREE earplugs included with purchase
• Compatible with a variety of vinyl-corded earplugs
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Corded earplug
Control System
(CCS)
22
3M™ Protective
Virtua™
Style, protection and affordability in lightweight unisex designs
• Weighs less than one ounce
• High wrap offers additional coverage
• Available in readers with three bifocal magnification strengths:
+1.50, +2.00, +2.50 (See page 28)
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
11228-00000-100 3M™ Virtua™ Protective Eyewear, Clear Uncoated Lens, Clear Temple 100 78371 11228 5
11326-00000-100 3M™ Virtua™ Protective Eyewear, Clear Hard Coat Lens, Clear Temple 100 78371 62098 8
11326-00000-20 3M™ Virtua™ Protective Eyewear, Clear Hard Coat Lens, Clear Temple 100 78371 62099 5
11327-00000-20 3M™ Virtua™ Protective Eyewear, Gray Hard Coat Lens, Gray Temple 100 78371 62102 2
11328-00000-20 3M™ Virtua™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Clear Temple 100 78371 62103 9
11329-00000-100 3M™ Virtua™ Protective Eyewear, Clear Anti-Fog Lens, Clear Temple 100 78371 62104 6
11329-00000-20 3M™ Virtua™ Protective Eyewear, Clear Anti-Fog Lens, Clear Temple 100 78371 62105 3
11330-00000-20 3M™ Virtua™ Protective Eyewear, Gray Anti-Fog Lens, Gray Temple 100 78371 62107 7
11331-00000-20 3M™ Virtua™ Protective Eyewear, Blue Mirror Lens, Blue Mirror Temple 100 78371 62108 4
11516-00000-20 3M™ Virtua™ Protective Eyewear, Gray Indoor/Outdoor Anti-Fog Lens 100 78371 62122 0
11517-00000-20 3M™ Virtua™ Protective Eyewear, Gray Indoor/Outdoor Hard Coat Lens 100 78371 62123 7
Virtua™ Slim — Designed specically for smaller facial proles
11754-00000-20 3M™ Virtua™ Slim Protective Eyewear, Clear Hard Coat Lens, Clear Temple 100 78371 62134 3
11755-00000-20 3M™ Virtua™ Slim Protective Eyewear, Clear Anti-Fog Lens, Clear Temple 100 78371 62135 0
11756-00000-20 3M™ Virtua™ Slim Protective Eyewear, Gray Hard Coat Lens, Gray Temple 100 78371 62136 7
Virtua™ Max — Large lens size for larger facial proles – CSA Z94.3
11509-00000-20 3M™ Virtua™ Max Protective Eyewear, Clear Hard Coat Lens, Clear Frame 100 78371 62115 2
11510-00000-20 3M™ Virtua™ Max Protective Eyewear, Clear Anti-Fog Lens, Clear Frame 100 78371 62116 9
11511-00000-20 3M™ Virtua™ Max Protective Eyewear, Gray Indoor/Outdoor Anti-Fog Lens 100 78371 62117 6
11512-00000-20 3M™ Virtua™ Max Protective Eyewear, Gray Indoor/Outdoor Hard Coat Lens 100 78371 62118 3
Virtua™ Plus — Cushioned brow provides added protection
11394-00000-20 3M™ Virtua™ Plus Protective Eyewear, Clear Anti-Fog Lens, Clear Temple 100 78371 62110 7
Eyewear
23
Product Number Product Name UPC Number
Virtua™ AP — Graceful, unisex styling with integral side-shields
11815-00000-20 3M™ Virtua™ AP Protective Eyewear, Gray Hard Coat Lens 100 78371 11815 7
11816-00000-20 3M™ Virtua™ AP Protective Eyewear, Light Blue Hard Coat Lens 100 78371 11816 4
11817-00000-20 3M™ Virtua™ AP Protective Eyewear, Amber Hard Coat Lens 100 78371 11817 1
11818-00000-20 3M™ Virtua™ AP Protective Eyewear, Clear Anti-Fog Lens 100 78371 11818 8
11819-00000-20 3M™ Virtua™ AP Protective Eyewear, Clear Hard Coat Lens 100 78371 11819 5
11847-00000-20 3M™ Virtua™ AP Protective Eyewear, Indoor/Outdoor Mirror Hard Coat Lens 100 78371 11847 8
Virtua™ V4 — Dual-injected temples and soft nose bridge
11670-00000-20 3M™ Virtua™ V4 Protective Eyewear, Clear Hard Coat Lens, Black/Gray Temple 100 78371 62034 6
11671-00000-20 3M™ Virtua™ V4 Protective Eyewear, Gray Hard Coat Lens, Black/Gray Temple 100 78371 62035 3
11672-00000-20 3M™ Virtua™ V4 Protective Eyewear, Clear Anti-Fog Lens, Black/Gray Temple 100 78371 62036 0
11673-00000-20 3M™ Virtua™ V4 Protective Eyewear, Gray Anti-Fog Lens, Black/Gray Temple 100 78371 62037 7
11674-00000-20 3M™ Virtua™ V4 Protective Eyewear, Indoor/Outdoor Mirror Lens, Black/Gray Temple 100 78371 62038 4
Virtua™ V5 — Soft nose bridge, adjustable temple lengths and lens angle
11675-00000-20 3M™ Virtua™ V5 Protective Eyewear, Clear Hard Coat Lens, Black Temple 100 78371 62124 4
Virtua™ V6 — Sporty look, soft temple tips and nose bridge
11680-00000-20 3M™ Virtua™ V6 Protective Eyewear, Clear Hard Coat Lens, Black Frame 100 78371 62142 8
11681-00000-20 3M™ Virtua™ V6 Protective Eyewear, Gray Hard Coat Lens, Black Frame 100 78371 62143 5
11682-00000-20 3M™ Virtua™ V6 Protective Eyewear, Clear Anti-Fog Lens, Black Frame 100 78371 62144 2
11683-00000-20 3M™ Virtua™ V6 Protective Eyewear, Gray Anti-Fog Lens, Black Frame 100 78371 62145 9
11684-00000-20 3M™ Virtua™ V6 Protective Eyewear, Indoor/Outdoor Mirror Lens, Black Frame 100 78371 62146 6
Virtua™ V7 — Frameless design with a soft nose bridge
11691-00000-20 3M™ Virtua™ V7 Protective Eyewear, Clear Hard Coat Lens, Clear Temple 100 78371 62039 1
11693-00000-20 3M™ Virtua™ V7 Protective Eyewear, Clear Anti-Fog Lens, Clear Temple 100 78371 62041 4
Virtua™ V8 — Adjustable temple lengths and lens angle
11702-00000-20 3M™ Virtua™ V8 Protective Eyewear, Clear Anti-Fog Lens, Black Temple 100 78371 62194 7
Virtua™ V10 — Sporty styling look with adjustable temple lengths and soft nose bridge
11722-00000-20 3M™ Virtua™ V10 Protective Eyewear, Clear Hard Coat Lens, Gray Frame 100 78371 62129 9
24
Eyewear
3M™ Protective
Product Number Product Name UPC Number
15902-00000-100 3M™ Seepro™ Fighter Protective Eyewear, Clear Anti-Fog Lens, Black Temple 100 78371 62302 6
Seepro™
Economical eyewear with wraparound design
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
11400-00000-20 3M™ Zora™ Protective Eyewear, Clear Hard Coat Lens 100 78371 62058 2
Zora™
Style, protection and affordability
• Weighs less than one ounce
• High wrap offers additional coverage
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
15950-00000-20 3M™ Seepro™ Plus Protective Eyewear, Clear Anti-Fog Lens, Black Temple 100 78371 62306 4
15957-00000-100 3M™ Seepro™ Plus Fighter Protective Eyewear, Clear Anti-Fog Lens, Black Temple 100 78371 62307 1
Seepro™ Plus
Economical eyewear with wraparound design and adjustable temples
• Adjustable temple lengths
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
25
Product Number Product Name UPC Number
41110-00000-100 3M™ Tour-Guard™ III Protective Eyewear, Clear Uncoated Lens, Dispenser Box, Regular 100 78371 62342 2
41120-00000-100 3M™ Tour-Guard™ III Protective Eyewear, Clear Uncoated Lens, Dispenser Box, Small 100 78371 62343 9
41200-00000-100 3M™ Tour-Guard™ III Protective Eyewear, Clear Uncoated Lens, Bulk Packaging, Regular 100 78371 62344 6
41210-00000-100 3M™ Tour-Guard™ III Protective Eyewear, Clear Uncoated Lens, Bulk Packaging, Small 100 78371 62345 3
Tour-Guard™ III
Economical visitor spec ts over most personal prescription eyewear
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
• Dispenser box includes five boxes of 20 each; bulk packaging contains
one box with 100 each
Product Number Product Name UPC Number
12150-00000-20 3M™ KX™ Protective Eyewear, Clear Uncoated Lens, Black Temple 100 78371 62222 7
12155-00000-20 3M™ KX™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temples 100 78371 62223 4
KX™
The value choice for visitor safety with high style
• Available with adjustable temple lengths
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
12159-00000-20 3M™ OX™ Protective Eyewear, Clear Uncoated Lens, Black Temple 100 78371 62224 1
12163-00000-20 3M™ OX™ 1000 Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple 100 78371 62225 8
12166-00000-20 3M™ OX™ 2000 Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Secure Grip Temple 100 78371 62226 5
OX™
Designed to t over most personal prescription eyewear
• Available with adjustable temple lengths
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
26
Light Vision™2
Half-frame style, hands-free direct lighting with molded-in magnifying
diopters on the lower lens
Lexa™
Proprietary lens shape designed with molded-in magnifying diopters
on the lower lens
3M™ Protective Eyewear
Product Number Product Name UPC Number
11477-00000-10 3M™ Light Vision™ 2 Protective Eyewear, Clear Anti-Fog Lens, Gray Frame, +1.5 Diopter 100 78371 62112 1
11478-00000-10 3M™ Light Vision™ 2 Protective Eyewear, Clear Anti-Fog Lens, Gray Frame, +2.0 Diopter 100 78371 62113 8
11479-00000-10 3M™ Light Vision™ 2 Protective Eyewear, Clear Anti-Fog Lens, Gray Frame, +2.5 Diopter 100 78371 62114 5
Product Number Product Name UPC Number
13353-00000-20 3M™ Lexa™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Medium, +1.5 Diopter 100 78371 62250 0
13354-00000-20 3M™ Lexa™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Medium, +2.0 Diopter 100 78371 62251 7
13355-00000-20 3M™ Lexa™ Protective Eyewear, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Medium, +2.5 Diopter 100 78371 62252 4
13415-00000-20 3M™ Lexa™ Protective Eyewear, MinimIzeR™ Lens, Black Temple, Medium, +1.5 Diopter 100 78371 13415 7
13416-00000-20 3M™ Lexa™ Protective Eyewear, MinimIzeR™ Lens, Black Temple, Medium, +2.0 Diopter 100 78371 13416 4
13417-00000-20 3M™ Lexa™ Protective Eyewear, MinimIzeR™ Lens, Black Temple, Medium, +2.5 Diopter 100 78371 13417 1
• Ultra-bright, adjustable LED lights
• Long-lasting batteries provide up to 50 hours of continuous use
• Adjustable length temples
• Soft nose bridge and temple tips
• Includes microfiber storage bag and lanyard
• Available without magnifying diopters (see page 6)
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
• Adjustable length temples
• Lens angle adjustment
• Available without magnifying diopters (See page 20)
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Did you know?
The term “presbyopia” means “old eye” and
is a vision condition involving the loss of the
eye’s ability to focus on close objects.
3M’s Protective Eyewear with Readers are ideal for anyone
who wears reading glasses, who is engaged in small detailed
work or has difculty reading small print.
?
with Readers
27
BX™
Sleek, contoured and fully adjustable with molded-in magnifying
diopters on the lower lens
• Adjustable length temples
• Lens angle adjustment
• Soft, adjustable nose bridge
• Available without magnifying diopters (See page 16)
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Product Number Product Name UPC Number
11374-00000-20 3M™ BX™ Protective Eyewear, Clear Anti-Fog Lens, Silver Frame, +1.5 Diopter 100 78371 62046 9
11375-00000-20 3M™ BX™ Protective Eyewear, Clear Lens, Silver Frame, +2.0 Diopter 100 78371 62047 6
11376-00000-20 3M™ BX™ Protective Eyewear, Clear Lens, Silver Frame, +2.5 Diopter 100 78371 62048 3
11377-00000-20 3M™ BX™ Protective Eyewear, Gray Lens, Silver Frame, +1.5 Diopter 100 78371 62049 0
11378-00000-20 3M™ BX™ Protective Eyewear, Gray Lens, Silver Frame, +2.0 Diopter 100 78371 62050 6
11379-00000-20 3M™ BX™ Protective Eyewear, Gray Lens, Silver Frame, +2.5 Diopter 100 78371 62051 3
11473-00000-20 3M™ BX™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Blue Frame, +1.5 Diopter 100 78371 62067 4
11474-00000-20 3M™ BX™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Blue Frame, +2.0 Diopter 100 78371 62068 1
11475-00000-20 3M™ BX™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Blue Frame, +2.5 Diopter 100 78371 62069 8
Product Number Product Name UPC Number
11457-00000-20 3M™ BX™ Protective Eyewear, Clear Anti-Fog Lens, Silver/Black Frame, +1.5 Top/Bottom Diopter 100 78371 11457 9
11458-00000-20 3M™ BX™ Protective Eyewear, Clear Anti-Fog Lens, Silver/Black Frame, +2.0 Top/Bottom Diopter 100 78371 11458 6
11459-00000-20 3M™ BX™ Protective Eyewear, Clear Anti-Fog Lens, Silver/Black Frame, +2.5 Top/Bottom Diopter 100 78371 11459 3
BX™ Dual
Sleek, contoured and fully adjustable with molded-in magnifying
diopters on the upper and lower lenses
• Adjustable length temples
• Lens angle adjustment
• Soft, adjustable nose bridge
• Available without magnifying diopters (See page 16)
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
28
3M™ Protective Eyewear
Nuvo™
“Retro” styling designed with molded-in magnifying diopters on the lower lens
Product Number Product Name UPC Number
11434-00000-20 3M™ Nuvo™ Protective Eyewear, Clear Anti-Fog Lens, Gray Frame, +1.5 Diopter 100 78371 62062 9
11435-00000-20 3M™ Nuvo™ Protective Eyewear, Clear Anti-Fog Lens, Gray Frame, +2.0 Diopter 100 78371 62063 6
11436-00000-20 3M™ Nuvo™ Protective Eyewear, Clear Anti-Fog Lens, Gray Frame, +2.5 Diopter 100 78371 62064 3
11500-00000-20 3M™ Nuvo™ Protective Eyewear, Gray Anti-Fog Lens, Gray Frame, +1.5 Diopter 100 7837162070 4
11501-00000-20 3M™ Nuvo™ Protective Eyewear, Gray Anti-Fog Lens, Gray Frame, +2.0 Diopter 100 78371 62071 1
11520-00000-20 3M™ Nuvo™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Tortoise Frame, +1.5 Diopter 100 78371 62075 9
11521-00000-20 3M™ Nuvo™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Tortoise Frame, +2.0 Diopter 100 78371 62076 6
11522-00000-20 3M™ Nuvo™ Protective Eyewear, Indoor/Outdoor Mirror Lens, Tortoise Frame, +2.5 Diopter 100 78371 62077 3
Virtua™
Lightweight unisex design with molded-in magnifying diopters on the
lower lens
Product Number Product Name UPC Number
11513-00000-20 3M™ Virtua™ Protective Eyewear, Clear Anti-Fog Lens, Clear Temple, +1.5 Diopter 100 78371 62119 0
11514-00000-20 3M™ Virtua™ Protective Eyewear, Clear Anti-Fog Lens, Clear Temple, +2.0 Diopter 100 78371 62120 6
11515-00000-20 3M™ Virtua™ Protective Eyewear, Clear Anti-Fog Lens, Clear Temple, +2.5 Diopter 100 78371 62121 3
• Adjustable length temples
• Integral side shields and brow bar
• Soft, adjustable nose bridge
• Available without magnifying diopters (see page 19)
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
• Weighs less than one ounce
• High wrap offers additional coverage
• Available without magnifying diopters (see page 22)
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
with Readers
29
safety gear
you need.
big or small,
Whether your
job site is
3M has the
3M™ OCC™ Protective
Eyewear, 200 Series
3M™ Maxim™
2X2 Air Seal Goggle
3M™ Hard Hat
3M™ Peltor™
Communication
Solutions
3M™ Peltor™
Communication
Solutions
3M™ Push-to-Fit
Earplugs
30
Maxim™ Plus Dust Goggle
Impact protection that helps seal out particulates
Product Number Product Name UPC Number
12305-00000-20 3M™ Maxim™ Plus Safety Dust Goggle, Clear DX Anti-Fog Hard Coat Lens, Elastic Strap 100 78371 12305 2
• Adjustable elastic headband
• Headband pivots for added adjustability
• Soft foam lens backing helps keep out particulates
• Ventilation channels heat away from the face
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Maxim™ 2x2 Air Seal Goggle
Advanced, dual lens design with a unique air bladder seal
Product Number Product Name UPC Number
40678-10000 3M™ Maxim™ 2x2 Safety Goggle Kit includes Case, Temples, Headband, Clear, Gray and Amber Anti-Fog Lenses 100 93045 92987 7
40683-00000 3M™ Maxim™ 2x2 Safety Goggle, Clear Anti-Fog Replacement Lens 100 78371 40683 4
40684-00000 3M™ Maxim™ 2x2 Safety Goggle, Gray Anti-Fog Replacement Lens 100 78371 40684 1
40685-00000 3M™ Maxim™ 2x2 Safety Goggle, Amber Anti-Fog Replacement Lens 100 78371 40685 8
40686-00000-10 3M™ Maxim™ 2x2 Safety Goggle, Clear Anti-Fog Lens, Black Frame, Elastic Strap 100 78371 62166 4
40687-00000-10 3M™ Maxim™ 2x2 Safety Goggle, Gray Anti-Fog Lens, Black Frame, Elastic Strap 100 78371 62167 1
40696-00000-10 3M™ Maxim™ 2x2 Goggle, Clear Anti-Fog Lens, Black Frame, Elastic Strap, Side Venting 100 78371 62169 5
40698-00000 3M™ Maxim™ 2x2 Air Flow Goggle, Clear Anti-Fog Lens, Elastic Strap 100 78371 40698 8
40699-00000 3M™ Maxim™ 2x2 Air Flow Goggle, Gray Anti-Fog Lens, Elastic Strap 100 78371 40699 5
40692-00000-10 3M™ Maxim™ 2x2 Goggle Prescription Frame, Black with Elastic Strap 100 78371 62168 8
• Air seal for comfort and impact absorption
• Excellent orbital eye coverage
• Polycarbonate lenses absorbs 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Goggles
3M™ Protective
31
Lexa™ Dust GoggleGear™
Impact protection that helps seal out particulates
Product Number Product Name UPC Number
16615-00000-10 3M™ Lexa™ Dust GoggleGear™ Safety Goggles, Clear DX Anti-Fog Hard Coat Lens, Black Frame, Medium 100 78371 62328 6
16616-00000-10 3M™ Lexa™ Dust GoggleGear™ Safety Goggles, Clear DX Anti-Fog Hard Coat Lens, Black Frame, Large 100 78371 62329 3
16617-00000-10 3M™ Lexa™ Dust GoggleGear™ Safety Goggles, Clear DX Anti-Fog Hard Coat Lens, Headband, Medium 100 78371 62330 9
16618-00000-10 3M™ Lexa™ Dust GoggleGear™ Safety Goggles, Clear DX Anti-Fog Hard Coat Lens, Headband, Large 100 78371 62331 6
• Available with adjustable temples or headband
• Soft foam lens backing helps keep out particulates
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Fectoggles™
Impact protection that helps seal out particulates
Product Number Product Name UPC Number
16400-00000-10 3M™ Fectoggles™ Safety Goggles, Clear DX Anti-Fog Hard Coat Lens, Elastic Strap, Medium 100 78371 62321 7
16408-00000-10 3M™ Fectoggles™ Safety Goggles, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Medium 100 78371 62322 4
16412-00000-10 3M™ Fectoggles™ Safety Goggles, Clear DX Anti-Fog Hard Coat Lens, Elastic Strap, Large 100 78371 62324 8
16420-00000-10 3M™ Fectoggles™ Safety Goggles, Clear DX Anti-Fog Hard Coat Lens, Black Temple, Large 100 78371 62325 5
• Adjustable elastic headband
• Soft foam lens backing helps keep out particulates
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Lexa™ Splash GoggleGear™
Lightweight, low-prole splash goggles
Product Number Product Name UPC Number
16644-00000-10 3M™ Lexa™ Splash GoggleGear™ Safety Goggle, Clear DX Anti-Fog Hard Coat Lens, Medium 100 78371 62336 1
16645-00000-10 3M™ Lexa™ Splash GoggleGear™ Safety Goggle, Clear DX Anti-Fog Hard Coat Lens, Large 100 78371 62337 8
• Adjustable elastic headband
• Lens angle adjustment
• Vent channels at the top and bottom help minimize fogging
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
32
Modul-R™ Goggle System
Splash goggle with optional impact visor
Product Number Product Name UPC Number
40657-00000-10 3M™ Modul-R™ Goggle, Clear Anti-Fog Lens 100 78371 62096 4
40658-00000-10 3M™ Modul-R™ Goggle, Clear Anti-Fog Lens with Chin Protector 100 78371 62097 1
• Low profile design for wide field of vision
• Headband pivots for added adjustability
• Adjustable, neoprene strap
• Translucent goggle shroud
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact requirements of ANSI Z87.1-2003
Visor features include:
• Splash shield • Flip-up, stand-by position
• Lightweight design • Open/close venting
Maxim™ Splash Goggle
Wide angle lens with optical clarity
Product Number Product Name UPC Number
40670-00000-10 3M™ Maxim™ Safety Splash Goggle, Clear DX Anti-Fog Hard Coat Lens 100 78371 62340 8
40671-00000-10 3M™ Maxim™ Safety Splash Goggle OTG, Clear Anti-Fog Lens 100 78371 62341 5
• Soft shroud for better comfort
• Adjustable, neoprene strap
• Indirect venting
• Available in low-profile or Over-the-Glass (OTG) model
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
Goggles
3M™ Protective
33
332 & 334
Economical exible mask goggle with direct vent ports for impact protection
and indirect vent ports for dust and splash protection
Product Number Product Name UPC Number
40650-00000-10 3M™ 332 Impact Goggle, Clear Uncoated Lens 100 78371 62137 4
40651-00000-10 3M™ 332AF Impact Goggle, Clear Anti-Fog Lens 100 78371 62138 1
40660-00000-10 3M™ 334 Splash Goggle, Clear Uncoated Lens 100 78371 62139 8
40661-00000-10 3M™ 334AF Splash Goggle, Clear Anti-Fog Lens 100 78371 62140 4
• Impact or splash protection
• Polycarbonate lenses absorb 99.9% UV
• Meets the High Impact Requirements of ANSI Z87.1-2003
Centurion™
Wide, wraparound lens provides exceptional peripheral vision
Product Number Product Name UPC Number
40300-00000-10 3M™ Centurion™ 452 Safety Impact Goggle, Clear Uncoated Lens 100 78371 62387 3
40301-00000-10 3M™ Centurion™ 452AF Safety Impact Goggle, Clear Anti-Fog Lens 100 78371 62388 0
40304-00000-10 3M™ Centurion™ 454 Safety Splash Goggle, Clear Uncoated Lens 100 78371 62389 7
40305-00000-10 3M™ Centurion™ 454AF Safety Splash Goggle, Clear Anti-Fog Lens 100 78371 62390 3
• Impact or splash protection
• Polycarbonate lenses absorb 99.9% UV
• Meets the requirements of CSA Z94.3-2007 and the High Impact
Requirements of ANSI Z87.1-2003
34
3M™ Accessories
Product Number Product Name UPC Number
13752-00000 3M™ Rotational Eyewear Display Rack (Empty), 36-Pair Capacity 100 78371 13752 3
13753-00000 3M™ Rotational Eyewear Display Rack (Empty), 12-Pair Capacity 100 78371 13753 0
11221-30000-40 3M™ Moon Dawg™ Display Rack (Empty), 40-Pair Capacity 100 78371 11221 6
10024-00000 3M™ Fuel™ Display (Empty), 32-Pair Capacity 100 78371 10024 4
Product Number Product Name UPC Number
83745-00000 3M™ Super-Clear™ Lens Cleaning Towlettes 100 78371 83745 4
83738-00000 3M™ Super-Clear™ Lens Cleaning Tissue Rell 100 78371 83738 6
83803-00000 3M™ Super-Clear™ Anti-Fog, Anti-Static Lens Cleaning Fluid 100 78371 83803 1
83735-00000 3M™ Super-Clear™ Disposable Lens Cleaning Station 100 78371 83735 5
36-pair
large countertop display
Displays
for merchandising
Lens Cleaning Solution
12-pair
countertop display
40-pair
floor display
(Display shown with product)
& Displays
35
Product Number Product Name UPC Number
40427-00000-10 3M™ Infrared Welding Flip-Up, Shade 3.0 IR 100 78371 62141 1
40192-00000-10 3M™ Goggle Retainer Ring 100 78371 62095 7
23451-00030-20 3M™ Clear Slip-On Side Shields (Does not meet the impact requirements of ANSI Z87.1-2003) 100 78371 62339 2
Product Number Product Name UPC Number
45940-00000-20 3M™ Protective Eyewear Case, Black 100 78371 62346 0
Product Number Product Name UPC Number
11248-00000 3M™ Breakaway Lanyard 100 78371 11248 3
Eyewear Case
with belt clip for safe storage
Breakaway Lanyard
Adjustable, slip-on soft cloth lanyard
Other Accessories
36
Features Selection Guide
Soft Nose
Bridge
Soft Temple
Tips
Temples Nose
Bridge
Lens
Angle
Clear Gray Bronze I/O Mirror Blue Mirror Red Mirror Light Blue Amber Polarized RSR MinimIzeR
Photochromic
Shade 3.0 Shade 5.0 Gray I/O Readers Uncoated Hard Coat Anti-Fog DX™ AF/HC
SAFETY EYEWEAR SAFETY EYEWEAR
Smart Lens™ •Smart Lens™• • •
OCC™• • • • • • OCC™• • • •
Fuel™•••••• Fuel™• • •
GlareX •GlareX •
Nitrous™ /Nitrous CCS ••••
Nitrous™ /Nitrous CCS
• • •
Moon Dawg™• • Moon Dawg™• •
Light Vision™•Light Vision™• • • • •
Metaliks™• • • • Metaliks™• • • •
Metaliks™ Sport • • • • • Metaliks™ Sport • • • • •
Metaliks™ GT • • • Metaliks™ GT • • • • • •
Rene™• • • Rene™• • • •
Maxim™• • • • Maxim™• • • • • •
Maxim™ Plus • • • Maxim™ Plus • • • • •
Maxim™ Sport • • Maxim™ Sport • • • • •
Maxim™ GT • • • Maxim™ GT • • • • • •
Lexa™• • • Lexa™• • • • • • • •
Fectoids™•Fectoids™• • • • •
QX™• • • QX™• • •
Privo™• • • • Privo™• • • •
Ana™• • • Ana™• • •
Malibu™•Malibu™
Nuvo™• • • Nuvo™• • • • • •
EX™•EX™• •
BX™• • • • • BX™• • • • • • • • •
SX™• • SX™•
X.Sport™• • • • X.Sport™• • •
Nassau™ Rave •Nassau™ Rave • • • • •
Nassau™ Plus •Nassau™ Plus • • •
Nassau™ Vibrance Nassau™ Vibrance •
Virtua™ V4 • • • Virtua™ V4 • • • •
Virtua™ V5 •Virtua™ V5 • • • •
Virtua™ V6 • • • Virtua™ V6 • • • •
Virtua™ V7 •Virtua™ V7 • • •
Virtua™ V8 •Virtua™ V8 • • •
Virtua™ V10 •Virtua™ V10 • • •
Virtua™ Plus •Virtua™ Plus • • •
Virtua™ Sport • • • • • Virtua™ Sport • • •
Virtua™ Slim • • Virtua™ Slim • •
Virtua™ Max • • Virtua™ Max • • •
Virtua™ AP • • • • • Virtua™ AP •••
Virtua™ • • • • Virtua™ •• •••
Seepro™•Seepro™•
Seepro™ Plus •Seepro™ Plus • •
KX™•KX™• • •
OX™•OX™• • •
Tour-Guard™•Tour-Guard™•
SAFETY GOGGLES SAFETY GOGGLES
Modul-R™•Modul-R™•
Maxim™ Splash •Maxim™ Splash • •
Maxim™ Plus •Maxim™ Plus •
Maxim™ 2x2 • • • Maxim™ 2x2 •
Lexa™ Dust GoggleGear™•
Lexa™ Dust GoggleGear™
• •
Centurion™•Centurion™• •
332 & 334 •332 & 334 • •
Lexa™ Splash GoggleGear™
•
Lexa™ Splash GoggleGear™
Fectoggles™•Fectoggles™•
Lens Tints
37
Soft Nose
Bridge
Soft Temple
Tips
Temples Nose
Bridge
Lens
Angle
Clear Gray Bronze I/O Mirror Blue Mirror Red Mirror Light Blue Amber Polarized RSR MinimIzeR
Photochromic
Shade 3.0 Shade 5.0 Gray I/O Readers Uncoated Hard Coat Anti-Fog DX™ AF/HC
SAFETY EYEWEAR SAFETY EYEWEAR
Smart Lens™ •Smart Lens™• • •
OCC™• • • • • • OCC™• • • •
Fuel™•••••• Fuel™• • •
GlareX •GlareX •
Nitrous™ /Nitrous CCS ••••
Nitrous™ /Nitrous CCS
• • •
Moon Dawg™• • Moon Dawg™• •
Light Vision™•Light Vision™• • • • •
Metaliks™• • • • Metaliks™• • • •
Metaliks™ Sport • • • • • Metaliks™ Sport • • • • •
Metaliks™ GT • • • Metaliks™ GT • • • • • •
Rene™• • • Rene™• • • •
Maxim™• • • • Maxim™• • • • • •
Maxim™ Plus • • • Maxim™ Plus • • • • •
Maxim™ Sport • • Maxim™ Sport • • • • •
Maxim™ GT • • • Maxim™ GT • • • • • •
Lexa™• • • Lexa™• • • • • • • •
Fectoids™•Fectoids™• • • • •
QX™• • • QX™• • •
Privo™• • • • Privo™• • • •
Ana™• • • Ana™• • •
Malibu™•Malibu™
Nuvo™• • • Nuvo™• • • • • •
EX™•EX™• •
BX™• • • • • BX™• • • • • • • • •
SX™• • SX™•
X.Sport™• • • • X.Sport™• • •
Nassau™ Rave •Nassau™ Rave • • • • •
Nassau™ Plus •Nassau™ Plus • • •
Nassau™ Vibrance Nassau™ Vibrance •
Virtua™ V4 • • • Virtua™ V4 • • • •
Virtua™ V5 •Virtua™ V5 • • • •
Virtua™ V6 • • • Virtua™ V6 • • • •
Virtua™ V7 •Virtua™ V7 • • •
Virtua™ V8 •Virtua™ V8 • • •
Virtua™ V10 •Virtua™ V10 • • •
Virtua™ Plus •Virtua™ Plus • • •
Virtua™ Sport • • • • • Virtua™ Sport • • •
Virtua™ Slim • • Virtua™ Slim • •
Virtua™ Max • • Virtua™ Max • • •
Virtua™ AP • • • • • Virtua™ AP •••
Virtua™ • • • • Virtua™ •• •••
Seepro™•Seepro™•
Seepro™ Plus •Seepro™ Plus • •
KX™•KX™• • •
OX™•OX™• • •
Tour-Guard™•Tour-Guard™•
SAFETY GOGGLES SAFETY GOGGLES
Modul-R™•Modul-R™•
Maxim™ Splash •Maxim™ Splash • •
Maxim™ Plus •Maxim™ Plus •
Maxim™ 2x2 • • • Maxim™ 2x2 •
Lexa™ Dust GoggleGear™•
Lexa™ Dust GoggleGear™
• •
Centurion™•Centurion™• •
332 & 334 •332 & 334 • •
Lexa™ Splash GoggleGear™
•
Lexa™ Splash GoggleGear™
Fectoggles™•Fectoggles™•
ComfortLens CoatingsLens Shades Adjustability
38
Notes
39
3M and all other trademarks used herein or hereon are trademarks of 3M Company.
Indicia of Orange County Choppers: ©2011 Orange County Choppers Design
Properties LLC. Products, Packaging and all other indicia: ©2011 3M. All Rights
Reserved. OCC products manufactured by 3M Company under license from Orange
County Choppers Merchandising LLC. Orange County Choppers, OCC, and the
OCC LOGO and related indicia are trademarks of Orange County Choppers Design
Properties, LLC used under license.
Please recycle. Printed in U.S.A.
© 3M 2011. All rights reserved.
70-0715-7455-5
Occupational Health
and Environmental
Safety Division
3M Center
Building 235-2W-70
St. Paul, MN 55144-1000
In Canada
Technical Assistance 1-800-267-4414
Customer Care Center 1-800-364-3577
Internet 3M.ca/safety
In U.S.
Technical Assistance 1-800-243-4630
Customer Care Center 1-800-328-1667
Internet 3M.com/OccSafety
These eye and face protection products help provide limited eye and face
protection. Misuse or failure to follow warnings and instructions may
result in serious potential injury, including blindness or death. For
proper use, selection, and applications against ying particles, optical
radiation and / or splash, see supervisor, read User Instructions and warnings
on the package, or call 3M OH&ESD Technical Service in the USA at
1-800-243-4630. In Canada, call 1-800-267-4414.
For more information about 3M Safety products or solutions please contact your 3M representative or:
