LADDER MODEL TYPE PAGE
STEPLADDERS
FIBERGLASS
• Rhino™ 375 Stepladder FS1100HD IAA 10
• Stepladder FS1300HD IAA 10
• Brute™ 375 Stepladder FS1400HD IAA 11
• Stepladder FS1500 IA 12
• Stepladder L-3016 IA 12
• Stepladder FS2000 I13
• Stepladder FS4000 II 13
ALUMINUM
• Stepladder AS1100HD IAA 25
• Stepladder AS1000 IA 25
• Stepladder AS3000 IA 26
• Stepladder AS2100 I26
• Stepladder AS4000 II 27
TWIN FRONT LADDERS
FIBERGLASS
• Rhino™ 375 Twin Front Ladder FM1100HD IAA 14
• Brute™ 375 Twin Front Ladder FM1400HD IAA 14
• Twin Front Ladder FM1500 IA 15
• Twin Front Ladder FM2000 I15
ALUMINUM
• Twin Front Ladder AM1100HD IAA 27
• Twin Front Ladder AM1000 IA 28
PLATFORM LADDERS
FIBERGLASS
• Rhino™ 375 Platform Ladder FP1100HD IAA 16
• Brute™ 375 Platform Ladder FP1400HD IAA 16
• Platform Ladder FP1500 IA 17
ALUMINUM
• Rhino™ 375 Platform Ladder AP1100HD IAA 28
• Platform Ladder AP1000 IA 29
• Mobile Platform Ladder AP5000 IA 29
SPECIALTY LADDERS
FIBERGLASS
• Step-To-Straight FC1200 IAA 17
• Tripod Ladder FT1000 IA 18
• Ultimate Articulated Ladder L-3092 IA 18
• Shelf Ladder FH1000 IA 20
• Manhole Ladder FE8800 IA 21
ALUMINUM
• Sawhorse Ladder L-2032 IA 30
• Ultimate Articulated Ladder L-2091 IA 30
• Aircraft Mechanic Ladder AM8000 IA 32
• Shelf Ladder AH1000 IA 33
• Multi Purpose Ladder L-2094 IA 33
STEP STOOLS
FIBERGLASS
• Step Stand FY8000 IA 19
ALUMINUM
• Step Stand AY8000 IA 31
• Euro Platform Ladder L-2346 III 39
• Platform Ladder AP8000 III 39
STEEL
• Qwik Step® Step Stool L-4362 III 40
• Qwik Step® Step Stool L-4340 III 40
LADDER MODEL TYPE PAGE
TRESTLE LADDERS
FIBERGLASS
• Extension Trestle FX1100 IA 20
ALUMINUM
• Extension Trestle AX1000 IA 32
EXTENSION LADDERS
FIBERGLASS
• Rhino™ 375 Extension Ladder FE4000HD IAA 21
• Extension Ladder FE3200 IA 22
• Extension Ladder L-3022-PT (ProTop™) IA 22
• Plate Connect Extension & Single FE7000 IA 23
• Extension Ladder FE1700 I24
• Extension Ladder FE0600 II 24
ALUMINUM
• Rhino™ 375 Extension Ladder AE1200HD IAA 34
• Stacked Extension Ladder AE2800 IA 34
• Extension Ladder AE2000 IA 35
• Extension Ladder – 3 Section AE1660 I36
• Extension Ladder AE3200 I36
• Extension Ladder (Select models NEW w/ ProGrip™)AE4000 II 37
• Extension Ladder L-2324 III 38
• Extension Ladder L-2321 III 38
ATTIC LADDERS
ALUMINUM
• Elite Series -
350 lbs.
41
• Everest Series -
350 lbs.
41
WOOD
• Big Boy Series -
350 lbs.
42
• Champion Series -
300 lbs.
42
• Premium Series -
250 lbs.
43
WORK & WAREHOUSE PLATFORMS
FIBERGLASS
• Mini Working Platform L-3041 IA 19
• Mobile Maintenance Platform FW SERIES IA 43
ALUMINUM
• Mini Working Platform L-2241 II 31
STEEL
• Rolling Warehouse Ladders GSW SERIES
450 lbs.
44
• HD Rolling Warehouse Ladders GSX2400 SERIES
450 lbs.
45
• HD Rolling Warehouse Ladders GSX1600 SERIES
450 lbs.
45
• NEW Rolling Tower Scaffolds ST SERIES
1,000 lbs.
46
• Mini Fortruss® Mobile Work Stand SM SERIES
500 lbs.
47
STAGES
• Scaf-A-Deck PD9000 SERIES -48
• Scaf-A-Deck PD8000 SERIES -48
• Telescoping Plank LP-2921 -48
• Scaffold Planks & Stages P1 / P2 / P3 -48-49
• NEW Modular Guardrail Systems - - 50
OTHER
Louisville Ladder History - - 3
Ladder Safety Standards - - 4-5
When To Use... - - 6-7
Ladder Features - - 8-9
Merchandiser - SRA9 Ladder Rack - - 51
LogoLock™ System - - 51
Extension Ladder Accessories - - 52-53
NEW C.L.I.M.B. Academy® Program - - 54
Warehouse Locations - - 55
TABLE OF CONTENTS
PRODUCTS MAY DIFFER FROM CATALOG PICTURE WITHOUT PRIOR NOTICE.
2
THE INDUSTRY’S LEADER
IN PRODUCT INNOVATION
MORE INNOVATION JUST AROUND THE CORNER!
Twin platform ladder coming soon...
• Louisville Ladder created the rst aluminum step and
extension ladder.
• Revolutionary aluminum step and extension
ladder construction, with steps using a channel that
had the steps riveted directly to the rail
ange; and with extensions using a patented
rung-to-rail connection.
• Knocked-down steel rolling warehouse ladder.
• First line of berglass ladders, including an extension
ladder using the patented rung-to-rail connection
with aluminum washers on both sides of the rail.
• First structural foam-molded stepladder top.
• First powder-coat paint on the steel product line.
• Patented steel rolling tower that could be set up by
one person.
• Patented QuickLatch® on runglocks (Patent
#5429207).
• The only berglass mobile work platform.
• Full Metal Boot™ wrap-around shoe assembly
for stepladders.
• Rhino™ 375 Series, the rst ladder with a 375 lb.
weight capacity.
• Da Boot™ is a polypropylene copolymer upper boot
that provides strength, durability and berglass rail
surface protection (Patent #7,000,731 B2).
• ProTops™ are multifunctional tops on extension
ladders (Patent #7,753,170) and stepladders (Patent
#D597,685 & patents pending) designed with
innovative features to improve the user’s performance
when working electrical, utility, heavy construction
and residential jobs.
• Fiberglass Mini Working Platform, a 3’ lightweight
non-conductive, all-around performance platform.
• ProGrip™ is an integrated slip-resistant ladder cap
that protect the support surface from damage while
including easy-carry hand grips.
• SHOX™ are a side rail impact absorption system that
reduces damage to the rst step, thus prolonging the
life of the ladder.
Founded in 1946, Louisville Ladder, Inc. is one of the largest manufacturers of ladders in North America. The
company’s headquarters is located in Louisville, KY, and it has a network of warehouses in various cities
throughout the United States and Canada. Since its beginning, Louisville Ladder has been an industry leader in
product innovation.
www.louisvilleladder.com 3
LADDER SAFETY STANDARDS
WE MAKE SAFE LADDERS... All Louisville Ladder products have been designed and built to meet or exceed the application standards
and requirements of the American National Standards Institute (ANSI), Occupational Safety and Health
Administration (OSHA), and Canadian Standards Association (CSA).
ProPer Selection
Select ladder of proper duty rating to support combined weight of user and
materials. Ladders are available with duty ratings of 200, 225, 250, 300 and 375
lbs. Select ladder of proper length to safely reach desired height.
inSPection Before each USe
• Inspect thoroughly for missing or damaged components. Never use a damaged
ladder and never make temporary repairs.
• Inspect thoroughly for loose fasteners. Make sure all working parts are in
good working order (lubricate if necessary).
• Clean ladder of all foreign material (wet paint, mud, snow, grease, oil, etc).
• Destroy ladder if damaged, worn, or exposed to re or chemicals.
conSider Before each USe
• Metal ladders conduct electricity. Keep away from electrical circuits.
• Consult manufacturer for use in chemical or other corrosive environments.
• Use ladder only as outlined in instructions. Ladders are designed for one
person only. Do not overload.
• Do not use in high winds or during storm.
• Do not use if in poor health, if taking any drugs or alcoholic beverages, or if
physically handicapped.
• Keep shoes clean. Leather soles should not be worn.
• Never leave ladder set up and unattended.
• Pay close attention to what you are doing.
StePladderS
ProPer SetUP and USe
• Use help in setting up ladder, if possible.
• Make sure ladder is fully open and spreaders locked.
• Set all feet on rm, level surface. Do not place on unstable, loose or slippery
surfaces. Place ladder where access is not obstructed. Do not place in front of
unlocked doors. Ladders are not intended to be used on scaffolds.
OCCUPATIONAL SAFETY AND
HEALTH ADMINISTRATION
OSHA sets minimum national requirements with respect to the use of ladders in business and industry. However, many states have enacted their own
regulations under the Occupational Safety & Health Act that establish more severe requirements. The more demanding state codes will supersede OSHA
standards within their respective states. Therefore, users should check with their own state OSHA representatives.
TYPE IAA: Extra heavy
duty industrial capable of
supporting 375 lbs.
TYPE IA: Extra heavy
duty industrial capable of
supporting 300 lbs.
TYPE I: Heavy duty industrial
capable of supporting 250 lbs.
TYPE II: Medium duty
commercial capable of
supporting 225 lbs.
TYPE III: Light duty
household capable of
supporting 200 lbs.
There are a variety of ANSl safety codes depending on material and type of ladder. The applicable ANSI codes are as follows:
In addition, ANSI codes have established a Duty Rating which identies the use for which a portable ladder is intended and the conditions under which the
ladder can be used safely. The following table describes the various types of ladders:
AMERICAN NATIONAL
STANDARDS INSTITUTE
The adequacy of ladders and the work practices followed by employees using them are regulated by OSHA in ve sections: Portable Wood (1910.25), Portable
Metal (1910.26), Fixed Ladders (1910.27), Mobile Ladder Stands and Scaffolds (1910.29) and ladders used in Construction Industry (1926.1053). These
sections specify the standards to which all portable ladders must be manufactured, care and placement of ladders in the workplace and the safe use of ladders
on the job. Louisville Ladder, Inc. manufactures products in compliance with the applicable safety codes of the American National Standards Institute (ANSI).
An extensive series of tests and design requirements determines which Duty Rating label a particular ladder may receive. The total load supported includes the
combined weight of the user, clothing, tools and any materials on the ladder. However, ladders must be used properly in order to support the intended load.
...but you MAKE LADDERS SAFE. Even a rigidly constructed ladder can be involved in an accident if the proper cautions are
not taken in its use. Critical factors in safe use include reading all instructions and labels
accompanying the ladder.
DANGER
Metal ladders conduct electricity; do not use where
contact may be made with live electrical circuits. Failure
to read and follow instructions on the use of this product
could result in serious personal injury or death.
CANADIAN STANDARDS
ASSOCIATION
Product meets or exceeds Canadian Standards Association testing requirements.
WOOD LADDER: ANSI A14.1 STEEL LADDER: ANSI A14.7 ROLLING SCAFFOLD: ANSI A10.8
METAL LADDER: ANSI A14.2FIBERGLASS LADDER: ANSI A14.5 STAGE PLATFORM: ANSI A10.8
ATTIC LADDER: ANSI A14.9
4
• Secure ladder, where possible, from excessive movement
• Make sure spreaders are locked and ladder is stable before climbing.
• Climb only front side of ladder. Face ladder when climbing up or down.
Maintain a rm grip. Use both hands in climbing.
• Keep body centered between side rails. Do not overreach. Get down and
move ladder as needed.
• Do not climb, stand, or sit above second step from top. Do not climb, stand,
or sit on spreader braces, ladder top, or pail shelf.
• Do not straddle front and back. Do not climb from one ladder onto another.
• Avoid pushing or pulling off to side of ladder. Do not “walk” or “shift”
ladder while on it.
FOR ADDITIONAL INFORMATION SEE ANSI A14.1-WOOD:
A14.2-ALUMINUM: A14.5-FIBERGLASS.
Mechanic ladders and extension trestle ladders may be climbed
from either side.
SinGle & eXtenSion ladderS
ProPer SetUP and USe
• Use help in setting up ladder, if possible.
• Set base of ladder on rm, level surface. Ladder leveling devices are
available for use on uneven ground. Place ladder where access is not
obstructed.
• Do not place on unstable, loose, or slippery surfaces. Do not place in front of
unlocked doors. Ladders are not intended to be used on scaffolds.
• Secure base section before raising ladder to upright position. Do not raise or
lower with y section extended.
• Extend y section and engage runglocks. Make sure rope does not create a
tripping hazard or interfere with activity near ladder.
• Recommend tying bottom y rung to adjacent base rung.
• Extend and retract y section only from ground and when no one is on ladder.
• Do not overextend. A minimum overlap of sections is required as follows:
• — ladder size up to and including 32’–3’ overlap
• — over 32’ up to and including 36’–4’ overlap
• — over 36’ up to and including 48’–5’ overlap
• — sizes over 48’–6’ overlap
• Position ladder against upper support surface. Make sure ladder does not lean to
side. Ladder must make a 75 1/2° angle with the ground.
• To establish if ladder is at proper angle – Determine the distance along the
rail between the top and bottom support points of the ladder. Divide this
distance by 4. The result will be the horizontal distance between the top and
bottom support points.
• When using ladder for access to roof, extend top 3 feet above roof edge. Tie
or secure top from movement.
• Make sure top and bottom ends of ladder are rmly supported.
• Check that top and bottom of ladder are properly supported. Make sure
runglocks are engaged before climbing.
• Face ladder when climbing up or down. Maintain a rm grip.
• Use both hands in climbing.
• Keep body centered between side rails. Do not overreach. Get down and
move ladder as needed.
• Do not climb above top support point. Do not climb from one ladder to another.
• Do not straddle or sit on rungs.
• Avoid pushing or pulling off to side of ladder. Do not “walk” or “shift”
ladder while on it.
ProPer care and StoraGe
• Hang ladder on racks at intervals of 6’ for support.
• Never store materials on ladder.
• Never drop or apply an impact load to ladder.
• Securely support ladder in transit.
• Never paint a wood ladder. Treat with wood preservative.
• Protect wood ladder from exposure to the elements, but allow good
ventilation. Keep away from heat and moisture.
USE THESE CHARTS TO DETERMINE THE RIGHT
LADDER LENGTH FOR YOUR JOB:
WHAT MAKES LOUISVILLE LADDERS UNIQUE...
Activated caster technology by
Bodyweight™. 4 swivel casters,
mounted on a front cam
mechanism and rear springs,
make it easy to use in material
handling applications.
Rhino™ 375 Series – the
rst ladder with a 375 lb.
duty rating. A Louisville
Ladder exclusive!
Wraparound shoe assembly is
an exclusive design by Louisville
Ladder. For full description, see
ladder features on pages 8-9.
Da Boot™ is a patented
design by Louisville Ladder.
For full description, see
ladder features on pages
8-9. Patent #7,000,731 B2
These ladders have a 375 lb. duty
rating, combining top of the line
components for all demanding
industrial applications.
TOP SUPPORT
POINT
TOP SUPPORT
POINT
ACCESSIBLE
ROOF HEIGHT
3
FEET
STEPLADDER HEIGHT SELECTION GUIDE
STEPLADDER SIZE
APPROX. HIGHEST
STANDING LEVEL
4’ 1’ 11”
5’ 2’ 10”
6’ 3’ 9”
7’ 4’ 9”
8’ 5’ 8”
10’ 7’ 7”
12’ 9’ 6”
14’ 11’ 5”
16’ 13’ 4”
18’ 15’ 3”
20’ 17’ 2”
EXTENSION LADDER LENGTH SELECTION GUIDE
LADDER SIZE MAXIMUM
EXTENDED LENGTH
*WORKING RANGE TO TOP
SUPPORT
*MAXIMUM ACCESSIBLE
ROOF HEIGHT RANGE
16’ 13’ 7 ½’ – 12 ½’ 4 ½’–9 ½’
20’ 17’ 9 ½’ – 16 ½’ 6 ½’–13 ½’
24’ 21’ 11 ½’ – 20’ 8 ½’–17’
28’ 25’ 13 ½’ – 24’ 10 ½’–21’
32’ 29’ 15 ½’– 28’ 12 ½’–25’
36’ 32’ 17 ½’ – 31’ 14’–28’
40’ 35’ 19’ – 33 ½’ 16’–30 ½’
44’ 39’ 21’ – 37 ½’ 18’–34 ½’
48’ 43’ 23’ – 41 ½’ 20’–38 ½’
60’(1) 48’ 23’ – 46 ½’ 20’–43 ½’
*When set up at the proper 75 ½° angle (1)Three-section extension
5
WHEN TO USE...
StEPLADDERS
EXtENSIoN LADDERS
PLAtFoRM LADDERS
Excellent for low and medium-height jobs, with adequate space for
working. Manufactured with berglass or aluminum rails, and equipped
with multifunctional tops for holding tools, paint, and hardware.
These ladders are great for diverse professional and household tasks.
Extension ladders are
designed for extended
height tasks. Available in
aluminum or berglass,
and with adjustable
lengths, these ladders are
versatile and can be used
for most jobs.
Excellent for any task
that require extended
periods of standing at an
elevation/height. Our new
and improved platform
ladders feature a full
platform and slimmer
prole for better storage.
Great option for painters,
decorators and electricians.
iMProVed
PlatforM
deSiGn!
Gapless and slimmer
for improved storage.
6
tWIN StEPLADDERS
tRIPoD LADDERS
Great for jobs that require two people on
the ladder simultaneously. Manufactured
with steps on both sides, it can be
climbed from either side. The ladder will
hold its Duty Rating simultaneously on
each side of the ladder.
MuLtI PuRPoSE LADDERS
Multi purpose ladders are efcient four ladders in one.
Can be opened into a twin stepladder or stairway ladder;
also can be fully extended to become an extension
ladder or separated for scaffolding planks or platforms.
Tripod ladders are great
for irregular surfaces and
reduced areas. The back
rail ts easily into tight
angles and other conned
spaces like between 2x4’s.
STRAIGHT / EXTENSION
PLANK SUPPORT
TWIN STEPLADDER
STAIRWAY
7
LADDER FEATURES Feature images depicted on these pages may vary according to ladder model.
StEPLADDER
HEAVY GAUGE METAL TOP
Metal tool tray top attached to front rails with four rivets and a
shoulder bolt and nut on top hinge.
INSIDE SPREADER BRACES
Spreader braces inside berglass rails help protect braces from
getting hooked or abused in transit.
DA BOOT™
Polypropylene copolymer upper boot provides strength, durability
and berglass rail surface protection. Thick non-marring
thermoplastic elastomer tread is bonded and mechanically
fastened to the upper boot and provides a slip-resistant footing.
Inside, Da Boot™ has a unique open design that allows for quick
and easy visual inspection of berglass rail. Patent #7,000,731 B2
PROTOP™ - VERSATILE AND DURABLE
ProTop™ is a multifunctional top featuring a magnet tray,
hardware tray, curved ergonomic front, drill and tool slots, paint
bucket holder, and a pipe or 2x4 holder to increase productivity.
Patent #D597,685 & patents pending
WIDE BACK BRACES
Vertically mounted U-shaped back braces spaced at one foot
intervals provide maximum stiffness and discourage unsafe
climbing. Heavy duty bottom back brace provides additional
strength to the bottom of the ladder.
DOUBLE-RIVET STEP CONSTRUCTION
Each step secured with six, large-headed, solid rivets for maximum
strength. 30% greater shear strength than solid aluminum rivets.
SLIP-RESISTANT RUBBER FEET
Aluminum angle feet with thick rubber tread on all four legs to
provide sure footing.
MOLDED TOP WITH RECESSED
TRAY / HANDYMAN’S TOOL SLOTS
Non-conductive structural molded top provides greater impact
resistance and durability than aluminum tops. Large parts tray
recessed ¼” deep with tool slots.
REINFORCEMENT PLATES
Reinforcement plates wrap around the rail at spreader brace for
unsurpassed durability.
OPTIONAL MOLDED PAIL SHELF
Features many tools slots, a drill slot, and can securely hold a
paint tray as well as round or square paint buckets.
CENTER-PULL SPREADER BRACE
Unique center-pull spreader brace designed for one-hand
operation. Brace is plated steel for extra durability.
HEAVY DUTY GUSSET BRACING
All gussets are heavy duty steel. Added to angle back braces and
steps for extra support.
PINCH-RESISTANT SPREADER BRACES
Heavy duty plated steel spreader braces with double rivet hinge to
protect user from pinched ngers.
SHOX™ - SUPERIOR IMPACT ABSORPTION
Side rail impact absorption system that reduces damage to the
rst step, thus prolonging the life of the ladder.
FULL METAL BOOT
See following page.
8
EXtENSIoN LADDER
FULL I-BEAM
Slide rails are extra heavy duty 3” I-beam extrusions for maximum
strength.
ALUMINUM CAST RAIL END CAPS
Extra heavy duty cast aluminum caps on all rail ends for rail
protection, longer life and durability.
DOUBLE ROPE & PULLEY
All aluminum double pulley system comes with a rot-resistant
manila rope for all weather performance.
FULL METAL BOOT™
Extra heavy duty cast aluminum shoes with thick rubber tread.
Exclusive Louisville Ladder design. Reinforcement plates wrap
around the rail for unsurpassed durability.
MAR-RESISTANT RAIL END CAPS
Impact-resistant caps on all rail ends provide rail protection for
longer life and protect work surfaces from marring.
MODIFIED I-BEAM
Side rails are full 3” extrusions shaped into a modied I-beam
for strength and light weight. Interlocking rails keep y and base
sections from coming apart.
OUTSIDE SLIDE GUIDES
Two extra heavy duty outside slide guides secured to top of base
section with four rivets per guide for maximum strength. Over
extending stop on y section.
PROTOP™
A multifunctional top designed to increase productivity.
Patent #7,753,170
QUICKLATCH® EQUIPPED RUNGLOCK
Provides easier method of securing y and base sections when
extended. One-nger operation. Patent #5429207
STACKED ALUMINUM I-BEAM RAIL
Extra heavy duty outside slide guides secured to top of base
section with four rivets per guide.
SWIVEL SAFETY SHOES
Heavy duty plated steel shoes with thick rubber tread. Shoe can be
used with tread down or in spike position.
D-SHAPED RUNGS
Flat top, D-shape provides greater standing area than round rungs.
Fully serrated for slip-resistant surface.
ALUMINUM PLATE CONNECTION RUNGS
Tempered aluminum rungs are hydraulically double-crimped to
aluminum plate. Each plate is fastened to side rails with four solid
aluminum rivets.
ROUND RUNGS
Tempered round aluminum rungs are fully serrated for
slip-resistant surface. Each rung end is hydraulically double
crimped to side rail.
RUBBER FLY SECTION SHOES
Fly section is equipped with solid rubber end cap shoes enabling
the y section to be used separately as a straight ladder.
PROGRIP™
Integrated slip-resistant ladder caps that protect the support
surface from damage while including easy-carry hand grips.
9
STEPLADDERS
FIBERGLASS
StEPLADDER FS1100HD SERIES
Molded top with
recessed tray
Double-rivet step
construction w/ heavy
duty gusset bracing
Heavy duty
reinforcement plates
Full Metal
Boot™
Extra heavy
duty inside
spreader braces
SHOX™ - superior
impact absorption
FIBERGLASS
StEPLADDERFS1300HD SERIES
Heavy gauge
metal top
Double-rivet
step construction
Inside spreader
braces
Heavy duty
gusset bracing
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FS1304HD 4’ 3” 18 ⁄” 29” 15 4‘
FS1305HD 5’ 3” 20 ⁄” 35” 18 5.4‘
FS1306HD 6’ 3” 21 ⁄” 41” 22 6.8‘
FS1308HD 8’ 3” 24 ⁄” 54” 28 10.3‘
FS1310HD 10’ 3” 27 ⁄” 64 ⁄” 40 14.2‘
FS1312HD 12’ 3” 30 ⁄” 78” 41 18.4‘
ANSI A14.5
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FS1104HD 4’ 3” 20 ⁄” 29” 19 4.2’
FS1106HD 6’ 3” 24 ⁄” 40 ⁄” 27 7.2’
FS1108HD 8’ 3” 27 ⁄” 52 ⁄” 36 11.1’
FS1110HD 10’ 3” 31 ⁄” 64 ⁄” 45 15.5’
FS1112HD 12’ 3” 34 ⁄” 76 ¼” 56 20.4’
FS1306HD
FS1106HD
ANSI A14.5
Aluminum angle
slip-resistant
rubber feet
10
STEPLADDERS
FIBERGLASS
StEPLADDER FS1400HD SERIES
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT.
(LBS)
APPROX.
CUBES
FS1404HD 4’ 3” 19 ⁄” 28 ⁄” 15 3.7‘
FS1405HD 5’ 3” 21 ⁄” 34 ⁄” 17 4.8‘
FS1406HD 6’ 3” 22 ⁄” 40 ⁄” 21 6.1‘
FS1407HD 7’ 3” 24 ⁄” 46 ⁄” 25 7.5‘
FS1408HD 8’ 3” 25 ⁄” 52 ¾” 28 8.7‘
FS1410HD 10’ 3” 28 ⁄” 64 ⁄” 34 12.6‘
FS1412HD 12’ 3” 31 ⁄” 76 ⁄” 51 16.7‘
ANSI A14.5
SHOX™ - superior
impact absorption
ProTop™ - versatile
and durable
Inside spreader
braces
Wide back braces
Riveted step
construction
with gussets
Da Boot™
Patent #7,000,731 B2
FS1406HD
A multifunctional top designed to increase productivity.
• HARDWARE TRAY
Recessed tray provides area to secure hardware from falling off the top.
• PAINT BUCKET HOLDER
Convenient recessed tray holds quarter/half/full gallon paint buckets.
• DRILL SLOTS
Two separate drill slots make for a variety of convenient options especially
when also using the paint bucket holder.
• SCREWDRIVERS/PLIERS
Featuring plenty of slots, ProTop™ will hold all the tools needed.
• CURVED FRONT
Curved surface on front of top helps provide leg comfort.
• PIPE & 2X4 HOLDER
Groove across top keeps pipes and 2x4’s from getting away from you.
• MAGNET TRAY
Easily secures metallic hardware and tools. Not available on type II ladders.
Patent #D597,685 & patents pending
• ENHANCED IMPACT ABSORPTION
• BETTER PROTECTION AGAINST DAMAGE
• ALSO AVAILABLE WITH THE SUPERIOR DA BOOT™
The cutting edge of impact absorption!
11
STEPLADDERS
FIBERGLASS
StEPLADDER FS1500 SERIES
SHOX™ - superior
impact absorption
Double-rivet
step construction
Wide back braces
Inside spreader
braces
Da Boot™
Patent #7,000,731 B2
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FS1502* 2’ 3” 17” 18 ¼” 8 1.8‘
FS1503 3’ 3” 18 ⁄” 23 12 2.6‘
FS1504 4’ 3” 19 ⁄” 28 ⁄” 14 3.6‘
FS1505 5’ 3” 21 ⁄” 34 ⁄” 17 4.9‘
FS1506 6’ 3” 22 ⁄” 40 ⁄” 20 5.7‘
FS1507 7’ 3” 24 ⁄” 46 ⁄” 22 7.9‘
FS1508 8’ 3” 25 ⁄” 52 ¾” 26 8.7‘
FS1510 10’ 3” 28 ⁄” 64 ⁄” 34 10.9‘
FS1512 12’ 3” 31 ⁄” 76 ⁄” 47 15.8‘
*FS1502 is a folding step stand & is not equipped with Da Boot™, ProTop™, or SHOX™.
ANSI A14.5
ProTop™ - versatile
and durable
FS1506
FIBERGLASS
StEPLADDER L-3016 SERIES
Molded top
with handyman’s
tool slots
Aluminum angle
slip-resistant
rubber feet
Heavy duty
gusset bracing
Pinch-resistant
spreader braces
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
L-3016-04 4’ 3” 18 ⁄” 28 ⁄” 14 3.6‘
L-3016-06 6’ 3” 21 ⁄” 40 ⁄” 20 5.7‘
L-3016-08 8’ 3” 24 ⁄” 51 ⁄” 26 8.7‘
L-3016-10 10’ 3” 27 ⁄” 64 ⁄” 34 10‘
L-3016-12 12’ 3” 30 ⁄” 75 ⁄” 47 15.8‘
ANSI A14.5
L-3016-06
12
STEPLADDERS
FIBERGLASS
StEPLADDERFS2000 SERIES
ProTop™ - versatile
and durable
Double-rivet
step construction
Pinch-resistant
spreader braces
Optional molded
pail shelf
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FS2004 4’ 3” 18 ⁄” 28 ⁄” 12 3.4‘
FS2005 5’ 3” 20 ⁄” 34 ⁄” 15 4.6‘
FS2006 6’ 3” 21 ⁄” 40 ⁄” 17 5.9‘
FS2007 7’ 3” 23 ⁄” 46” 20 7.2‘
FS2008 8’ 3” 24 ⁄” 51 ⁄” 22 8.9‘
ANSI A14.5
FS2006
Aluminum angle
slip-resistant
rubber feet
FIBERGLASS
StEPLADDER FS4000 SERIES
*ProTop™ - versatile
and durable
Pinch-resistant
spreader braces
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FS4004 4’ 3’ 18 ⁄” 28 ⁄” 11 3.4‘
FS4006 6’ 3’ 21 ⁄” 40 ⁄” 16 5.9‘
FS4007 7’ 3’ 23 ⁄” 46” 18 7.2‘
FS4008 8’ 3’ 24 ⁄” 51 ⁄” 21 8.9‘
*ProTop™ does not include magnet on FS4000 series.
ANSI A14.5
Optional molded
pail shelf
FS4006
Slip-resistant
rubber feet
13
TWIN FRONT LADDERS
FIBERGLASS
tWIN FRoNt LADDER FM1100HD SERIES
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FM1104HD 4’ 3” 20 ½” 36” 28 5.2‘
FM1106HD 6’ 3” 24” 52” 32 9‘
FM1108HD 8’ 3” 27 ½” 67” 48 13.7‘
FM1110HD 10’ 3” 31” 83” 64 19.2‘
FM1112HD 12’ 3” 34 ½” 98” 78 25.5‘
BOTH SIDES of twin front ladders can be used simultaneously by one person plus materials.
Therefore the duty rating for this ladder is PER SIDE.
FM1106HD
ANSI A14.5
Double-rivet step
construction w/ heavy
duty gusset bracing
Reinforcement
plates
SHOX™ - superior
impact absorption
Inside spreader
braces
Full Metal
Boot™
Heavy gauge
steel hinges
FIBERGLASS
tWIN FRoNt LADDER FM1400HD SERIES
Inside spreader
braces
Heavy gauge
steel hinges
Heavy duty
gusset bracing
Riveted step
construction
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FM1404HD 4’ 3” 19 ⁄” 37 ½” 21 4.7‘
FM1405HD 5’ 3” 21 ⁄” 44 ⁄” 24 6.5‘
FM1406HD 6’ 3” 22 ⁄” 52 ⁄” 27 8.3‘
FM1407HD 7’ 3” 24 ⁄” 59 ⁄” 32 10.2‘
FM1408HD 8’ 3” 25 ⁄” 67 ⁄” 36 12.4‘
FM1410HD 10’ 3” 28 ⁄” 81 ⁄” 55 17.5‘
FM1412HD 12’ 3” 31 ⁄” 96 ¾” 68 23.2‘
FM1414HD* 14’ 3” 34 ⁄” 111 ½” 84 27.5‘
FM1416HD* 16’ 3” 37 ⁄” 126 ⁄” 100 33.5‘
*Special duty: manufacturer tested to 375 lbs.
BOTH SIDES of twin front ladders can be used simultaneously by one person plus materials.
Therefore the duty rating for this ladder is PER SIDE.
ANSI A14.5
SHOX™ - superior
impact absorption
Da Boot™
Patent #7,000,731 B2
FM1406HD
14
TWIN FRONT LADDERS
FIBERGLASS
tWIN FRoNt LADDER FM1500 SERIES
Double-rivet step
construction
Heavy gauge
steel hinges
Inside spreader
braces
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FM1503 3’ 3” 18 ⁄” 30 ⁄” 16 3.4‘
FM1504 4’ 3” 19 ⁄” 37 ½” 19 4.9‘
FM1505 5’ 3” 21 ⁄” 44 ⁄” 22 6.5‘
FM1506 6’ 3” 22 ⁄” 52 ⁄” 27 8.4‘
FM1507 7’ 3” 24 ⁄” 59 ⁄” 30 10.2‘
FM1508 8’ 3” 25 ⁄” 67 ⁄” 34 12.3‘
FM1510 10’ 3” 28 ⁄” 81 ⁄” 44 17.3‘
FM1512 12’ 3” 31 ⁄” 96 ¾” 62 23.1‘
BOTH SIDES of twin front ladders can be used simultaneously by one person plus materials.
Therefore the duty rating for this ladder is PER SIDE.
ANSI A14.5
SHOX™ - superior
impact absorption
Da Boot™
Patent #7,000,731 B2
FM1506
FIBERGLASS
tWIN FRoNt LADDERFM2000 SERIES
Double-rivet
step construction
Pinch-resistant
spreader braces
Heavy gauge
steel hinges
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FM2004 4’ 3” 18 ¾” 37 ¼” 17 4.6‘
FM2006 6’ 3” 21 ¾” 52” 24 8.1‘
FM2008 8’ 3” 24 ¾” 66 ⁄” 34 12‘
FM2010 10’ 3” 27 ¾” 81 ⁄” 45 16.8‘
FM2012 12’ 3” 30 ¾” 96 ⁄” 55 22.1‘
BOTH SIDES of twin front ladders can be used simultaneously by one person plus materials.
Therefore the duty rating for this ladder is PER SIDE.
ANSI A14.5
FM2006
Aluminum angle
slip-resistant
rubber feet
15
PLATFORM LADDERS
Gapless
slip-resistant
platform
Double-rivet step
construction
Heavy duty
gusset bracing
Top rail
guard
SHOX™ - superior
impact absorption
Full Metal
Boot™
MODEL
HT. TO
PLATFORM
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FP1104HD 3’ 9” 3” 24 ⁄” 45 ⁄” 25 5.4‘
FP1106HD 5’ 8” 3” 27 ⁄” 52 ⁄” 36 7.8‘
FP1108HD 7’ 7” 3” 30 ¼” 65” 49 10.4‘
FP1110HD* 9’ 6” 3” 33 ⁄” 75 ½” 61 13‘
FP1112HD* 11’ 5” 3” 36 ¼” 87 ½” 73 15.6‘
*Special duty: manufacturer tested to 375 lbs.
FIBERGLASS
PLAtFoRM LADDER FP1100HD SERIES
FP1104HD
ANSI A14.5
iMProVed
PlatforM
deSiGn! iMProVed
PlatforM
deSiGn!
Gapless and slimmer
for improved storage.
Gapless and slimmer
for improved storage.
FIBERGLASS
PLAtFoRM LADDER FP1400HD SERIES
Gapless
slip-resistant
platform
MODEL
HT. TO
PLATFORM
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT.
(LBS)
APPROX.
CUBES
FP1403HD 2’ 10” 3” 23 ⁄” 34 ¼” 20 3.9‘
FP1404HD 3’ 9” 3” 24 ⁄” 39 ⁄” 22 5.2‘
FP1405HD 4’ 9” 3” 26 ⁄” 45 ¾” 25 6.5‘
FP1406HD 5’ 8” 3” 27 ¾” 52” 28 7.6‘
FP1408HD 7’ 7” 3” 30 ⁄” 63 ¾” 42 10.2‘
FP1410HD* 9’ 6” 3” 33 ⁄” 75 ⁄” 58 12.7‘
FP1412HD* 11’ 5” 3” 36 ⁄” 86 ⁄” 69 15.3‘
*Special duty: manufacturer tested to 375 lbs.
ANSI A14.5
SHOX™ - superior
impact absorption
Da Boot™
Patent #7,000,731 B2
Heavy duty
gusset bracing
Riveted step
construction
FP1404HD
Top rail
guard
16
PLATFORM / SPECIALTY LADDERS
FIBERGLASS
PLAtFoRM LADDER FP1500 SERIES
Top rail
guard
Double-rivet step
construction
Gapless
slip-resistant
platform
MODEL
HT. TO
PLATFORM
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FP1503 2’ 10” 3” 23 ⁄” 34 ¼” 19 3.9‘
FP1504 3’ 9” 3” 24 ⁄” 39 ⁄” 23 5.2‘
FP1505 4’ 9” 3” 26 ⁄” 45 ¾” 25 6.5‘
FP1506 5’ 8” 3” 27 ¾” 52” 28 7.6‘
FP1508 7’ 7” 3” 30 ⁄” 63 ¾” 41 10‘
FP1510 9’ 6” 3” 33 ⁄” 75 ⁄” 57 12.9‘
FP1512 11’ 5” 3” 36 ⁄” 86 ⁄” 68 15.4‘
ANSI A14.5
SHOX™ - superior
impact absorption
Da Boot™
Patent #7,000,731 B2
FP1504
FIBERGLASS
StEP-to-StRAIGHt LADDER FC1200 SERIES
Hinging
mechanism
Runglock
Utility-style
safety shoes
Double-rivet
step construction
Standard
pole grip
MODEL
LADDER
SIZE
MAX.
EXT.
LENGTH
FLARED
SECTION
MIN. O.D.
FLARED
SECTION
MAX. O.D.
FC1206 6’ 9’ 17 ⁄” 23 ⁄”
FC1207 7’ 11’ 17 ⁄” 24 ⁄”
FC1208 8’ 13’ 17 ⁄” 25 ⁄”
Table
continued
below...
MODEL
PARALLEL
SECTION O.D.
APPROX.
WT. (LBS)
APPROX.
CUBES
FC1206 14 ⁄” 33 6.8‘
FC1207 14 ⁄” 36 8.4‘
FC1208 14 ⁄” 41 9.8‘
O.D. denotes outside dimension
FC1206
iMProVed
PlatforM
deSiGn!
Gapless and slimmer
for improved storage.
17
SPECIALTY LADDERS
FIBERGLASS
tRIPoD LADDERFT1000 SERIES
FIBERGLASS
uLtIMAtE ARtICuLAtED LADDERL-3092 SERIES
Outrigger rail
brackets
Heavy duty
gusset bracing
Center-pull
spreader brace
Double-rivet step
construction
Steel reinforced
outrigger
Full Metal
Boot™
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FT1004 4’ 3” 28 ¾” 29” 17 6.1‘
FT1005 5’ 3” 30 ⁄” 35” 20 7.2‘
FT1006 6’ 3” 35 ⁄” 41” 24 10.5‘
FT1007 7’ 3” 37” 48” 27 14.2‘
FT1008 8’ 3” 41 ¾” 54” 31 15.5‘
FT1010 10’ 3” 44 ½” 66” 44 22.5‘
FT1012 12’ 3” 53 ½” 78” 53 32.9‘
MODEL
LADDER
SIZE
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
L-3092-13 13’ 13’ 46 5.15‘
L-3092-15 15’ 15’ 49 7.5‘
ANSI A14.5
FT1006
*2” x 12” plank needed for these positions
Stepladder
Supported
span scaffold
(*with plank)
Short span
scaffold
(*with plank)
Stairwell
scaffold
(*with plank)
Worktable or
multi-shelf
Stand-off ladder Stand-off ladder
Don’t
stand
or sit
Don’t
stand
or sit
Double (short)
stepladder
Fully
extended
straight
ladder
¾ length
straight
ladder
Self-supporting
scaffold
(*with plank)
Short
self-supporting
scaffold
(*with plank)
Built-In
Stabilizer
Comfortable
wide side rails
EasyHinge™
18
SPECIALTY LADDERS
FIBERGLASS
MINI WoRKING PLAtFoRM L-3041 SERIES
Easy to
use hinge
Durable
non-conductive
fiberglass rails
Slip-resistant
rubber feet
12” wide
slip-resistant
standing surface
FIBERGLASS
INDuStRIAL StEP StAND FY8000 SERIES
Large
aluminum steps
Large
molded top
MODEL
HT. TO
TOP STEP
TOP SIZE
(W x D)
FY8001* 13” 14” x 9 ¼”
FY8002 23” 14” x 9 ¼”
FY8003 34 ⁄” 14” x 9 ¼”
FY8004 45 ¾” 14” x 9 ¼”
MODEL
WORK
AREA
BASE
WIDTH
APPROX.
SPREAD
APPROX.
WT.
(LBS)
APPROX.
CUBES
HT. TO
PLATFORM
L-3041-03 12” x 37 ¼” 16 ¼” 46 ⁄” 13 2.1 21”
MODEL STEP SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
FY8001* 6” 15” 15 ⁄” 8 2.6‘
FY8002 6” 17 ¾” 20 ⁄” 15 2.7‘
FY8003 6” 19 ¾” 26 ½” 20 4.1‘
FY8004 6” 21 ¾” 32 ⁄” 25 5.8‘
*Casters and handle option not available on this model.
Heavy duty
gusset bracing
Double-rivet step
construction
Table
continued
below...
FY8002
19
SPECIALTY LADDERS
Slide guides &
spreader braces
Heavy trestle
top hinge
Locking
bail
FIBERGLASS
EXtENSIoN tREStLE LADDERFX1100 SERIES
MODEL
LADDER
SIZE
MAX. EXT.
LENGTH
STEP
SIZE
BOTTOM
WIDTH
FX1108 8’ 12’ 6” 3” 33”
FX1110 10’ 15’ 6” 3” 39”
FX1112 12’ 19’ 6” 3” 45”
MODEL
APPROX.
SPREAD
INSIDE
WIDTH
FLY
OUTSIDE
WIDTH
FLY
APPROX.
WT. (LBS)
APPROX.
CUBES
FX1108 70 ¼” 15 ½” 18 ¼” 65 19.1‘
FX1110 82 ⁄” 15 ½” 18 ¼” 90 22.7‘
FX1112 93 ⁄” 15 ½” 18 ¼” 115 30.4‘
Table
continued
below...
Heavy duty
gusset bracing
FIBERGLASS
SHELF LADDERFH1000 SERIES
Serrated
aluminum steps
Heavy duty
gusset bracing
Angled
steps
Double-rivet step
construction
Rubber
bumper
MODEL LADDER SIZE STEP SIZE WIDTH
APPROX.
WT. (LBS)
APPROX.
CUBES
FH1004 4’ 3” 15 ¼” 8 1.5‘
FH1005 5’ 3” 15 ¼” 10 1.9‘
FH1006 6’ 3” 15 ¼” 11 2.4‘
FH1007 7’ 3” 15 ¼” 12 2.7‘
FH1008 8’ 3” 15 ¼” 14 3‘
FH1010 10’ 3” 15 ¼” 20 3.6‘
FH1012 12’ 3” 15 ¼” 24 4.5‘
FH1014 14’ 3” 15 ¼” 28 5.2‘
FH1016 16’ 3” 15 ¼” 32 6.1‘
FX1108
FH1006
ANSI A14.5
Aluminum angle
slip-resistant
rubber feet
Aluminum angle
slip-resistant
rubber feet
20
EXTENSION LADDERS
Outside
slide guides
D-shaped or
round rungs
Mar-resistant
rail end caps
Aluminum plate
connection rungs
QuickLatch®
Patent #5429207
Aluminum swivel
safety shoe with
Full Metal Boot™
FIBERGLASS
EXtENSIoN LADDER FE4000HD SERIES
MODEL
TOTAL
LENGTH
LENGTH EA.
SECTION
MAX.
EXT. LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
FE4216HD* 16’ 8’ 13’ 41 6.4‘
FE4220HD 20’ 10’ 17’ 50 9.5‘
FE4224HD 24’ 12’ 21’ 58 10.4‘
FE4228HD 28’ 14’ 25’ 67 12.5‘
*Does not include rope and pulley.
D-RUNG
INSIDE WIDTH OUTSIDE WIDTH
SIZES RAIL DEPTH STACK HEIGHT BASE FLY BASE FLY
16’–28’ 3 ¼” 6” 15 ⁄” 13 ⁄” 17 ¾” 16 ⁄”
ANSI A14.5
FE4620HD 20’ 10’ 17’ 48 9.5‘
FE4624HD 24’ 12’ 21’ 56 10.4‘
FE4628HD 28’ 14’ 25’ 64 12.5‘
Special order item.
ROUND RUNG
Convenient 14”
width design
Rail
protectors
Round
rungs
Utility-style
safety shoes
FIBERGLASS
MANHoLE LADDERFE8800 SERIES
SIZES RAIL DEPTH OUTSIDE WIDTH INSIDE WIDTH
8’-20’ 3 ¼” 14” 11 ⁄”
SINGLE LADDERS
MODEL TOTAL LENGTH APPROX. WT. (LBS) APPROX. CUBES
FE8808 8’ 19 2.5‘
FE8810 10’ 23 3.2‘
FE8812 12’ 25 3.8‘
FE8814 14’ 30 4.4‘
FE8816 16’ 36 5‘
FE8818 18’ 41 5.7‘
FE8820 20’ 45 6.3‘
FE8810 FE4220HD
21
EXTENSION LADDERS
Mar-resistant
rail end caps
Outside
slide guides
D-shaped
rungs
ALSO AVAILABLE WITH...
FIBERGLASS
EXtENSIoN LADDER FE3200 SERIES
MODEL
TOTAL
LENGTH
LENGTH
EACH
SECTION
MAX. EX.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
FE3216* 16’ 8’ 13’ 30 6.5‘
FE3220 20’ 10’ 17’ 42 8.6‘
FE3224 24’ 12’ 21’ 52 10.2‘
FE3228 28’ 14’ 25’ 58 11.9‘
FE3232 32’ 16’ 29’ 70 12.6‘
FE3236** 36’ 18’ 32’ 79 15.8‘
FE3240** 40’ 20’ 35’ 93 17.5‘
*Does not include rope and pulley.
** 250 lb. Type I rated.
SIZES RAIL DEPTH OUTSIDE WIDTH INSIDE WIDTH
8’–14’ 3 ¼” 17 ⁄” 14 ⁄”
16’–20’ 3 ⁄” 17 ⁄” 15 ⁄”
INSIDE WIDTH OUTSIDE WIDTH
SIZES
RAIL
DEPTH
STACK
HEIGHT BASE F LY BASE FLY
16’–28’ 3 ¼” 6 ¼” 14 ⁄” 13 ⁄” 17 ⁄” 16 ⁄”
32’–40’ 3 ⁄” 6 ¼” 15 ⁄” 14 ⁄” 17 ⁄” 16 ⁄”
ANSI A14.5
A multifunctional top designed to increase productivity.
• CORNER GRIP
The V-shape design provides greater stability on corners.
• POLE GRIP
The V-shape design with rubber tread makes it ideal for working
against poles or trees. The tool slots provide the option for lashing the
ladder to the pole or tree.
• INTEGRATED BUMPER
Soft non-marking/non-marring rubber tread protects the work surface.
• WIDER DESIGN
Wider design provides greater stability and 700% more contact area
on at surfaces.
• WORK TRAY
Non-conductive molded work-tray with convenient handyman’s tool slots.
SINGLE LADDERS - FE3100
MODEL TOTAL LENGTH APPROX. WT. (LBS) APPROX. CUBES
FE3108 8’ 16 3’
FE3110 10’ 21 5.3’
FE3112 12’ 25 4.8’
FE3114 14’ 28 5.6’
FE3116 16’ 36 6.7’
FE3118 18’ 41 7.5’
FE3120 20’ 45 11.4’
Special order item.
L-3022-PT SERIES
Patent #7,753,170
EXTENSION LADDERS WITH PROTOP™
MODEL
TOTAL
LENGTH
LENGTH
EACH
SECTION
MAX. EX.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
L-3022-20PT 20’ 10’ 17’ 42 8.6‘
L-3022-24PT 24’ 12’ 21’ 52 10.2‘
L-3022-28PT 28’ 14’ 25’ 58 10.6‘
L-3022-32PT 32’ 16’ 29’ 70 12‘
Steel swivel safety
shoe w/ metal shield
QuickLatch®
Patent # 5429207
FE3220
22
EXTENSION LADDERS
FIBERGLASS
PLAtE CoNNECt EXtENSIoN LADDERFE7000 SERIES
Mar-resistant
rail end caps
Aluminum plate
connection rungs
D-shaped or
round rungs
Outside
slide guides
D-RUNG
MODEL
TOTAL
LENGTH
LENGTH
EACH
SECTION
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
FE7216* 16’ 8’ 13’ 34 6.7‘
FE7220 20’ 10’ 17’ 45 8.8‘
FE7224 24’ 12’ 21’ 53 10.7‘
FE7228 28’ 14’ 25’ 62 12.5‘
FE7232 32’ 16’ 29’ 72 14.1‘
FE7236 36’ 18’ 32’ 110 19.1‘
FE7240 40’ 20’ 35’ 117 21.1‘
*Does not include rope and pulley.
INSIDE WIDTH OUTSIDE WIDTH
SIZES
RAIL
DEPTH
STACK
HEIGHT BASE FLY BASE FLY
16’–28’ 3 ¼” 6 ¼” 15” 13 ⁄” 17 ⁄” 16 ⁄”
32’–40’ 4” 6 ⁄” 15” 13 ⁄” 18 ½” 17 ¼”
ANSI A14.5
SINGLE LADDERS
MODEL TOTAL LENGTH APPROX. WT. (LBS) APPROX. CUBES
FE7512 12’ 27 4.8‘
FE7514 14’ 31 5.6‘
FE7516 16’ 36 7.0‘
FE7518 18’ 50 11.3‘
FE7520 20’ 54 15.3‘
Special order item.
ROUND-RUNG
MODEL
TOTAL
LENGTH
LENGTH
EACH
SECTION
MAX.
EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
FE7616* 16’ 8’ 13’ 34 6.7‘
FE7620 20’ 10’ 17’ 44 8.8‘
FE7624 24’ 12’ 21’ 52 10.7‘
FE7628 28’ 14’ 25’ 60 12.5‘
FE7632 32’ 16’ 29’ 73 14.1‘
FE7636 36’ 18’ 32’ 100 19.1‘
FE7640 40’ 20’ 35’ 108 21.1‘
Special order item.
*Does not include rope and pulley.
ROUND-RUNG
Aluminum swivel
safety shoe with
Full Metal Boot™
SINGLE LADDERS
MODEL TOTAL LENGTH APPROX. WT. (LBS) APPROX. CUBES
FE7108 8’ 16 4.7‘
FE7110 10’ 22 6.9‘
FE7112 12’ 26 7.3‘
FE7114 14’ 32 8.3‘
FE7116 16’ 37 9.5‘
FE7118 18’ 53 10.6‘
FE7120 20’ 61 12.8‘
D-RUNG
QuickLatch®
Patent # 5429207
FE7220
23
EXTENSION LADDERS
FIBERGLASS
EXtENSIoN LADDERFE1700 SERIES
Mar-resistant
rail end caps
D-shaped
rungs
Outside
slide guides
D-shaped
rungs
Mar-resistant
rail end caps
FIBERGLASS
EXtENSIoN LADDER FE0600 SERIES
MODEL
TOTAL
LENGTH
LENGTH
EACH
SECTION
MAX.
EXTENDED
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
FE1716* 16’ 8’ 13’ 30 6.9‘
FE1720 20’ 10’ 17’ 44 8.6‘
FE1724 24’ 12’ 21’ 52 10.2‘
FE1728 28’ 14’ 25’ 60 11.8‘
*Does not include rope and pulley.
OUTSIDE WIDTHINSIDE WIDTH
SIZES
RAIL
DEPTH
STACK
HEIGHT BASE FLY BASE FLY
16’–20’ 3 ¼” 6 ¼” 14 ⁄” 13 ⁄” 17 ⁄” 16 ⁄”
24’–28’ 3 ⁄” 6 ¼” 15 ⁄” 14 ⁄” 17 ⁄” 16 ⁄”
ANSI A14.5
OUTSIDE WIDTHINSIDE WIDTH
SIZES
RAIL
DEPTH
STACK
HEIGHT BASE FLY BASE FLY
16’–28’ 3 ¼” 6 ¼” 14 ⁄” 13 ⁄” 17 ⁄” 16 ⁄”
ANSI A14.5
MODEL
TOTAL
LENGTH
LENGTH
EA.
SECTION
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
FE0616* 16’ 8’ 13’ 28 6.9
FE0620 20’ 10’ 17’ 39 8.6
FE0624 24’ 12’ 21’ 48 10.2
FE0628 28’ 14’ 25’ 53 11.8
*Does not include rope and pulley.
Special order item.
Steel swivel safety
shoe w/ metal shield
Steel swivel safety
shoe w/ metal shield
QuickLatch®
Patent # 5429207
QuickLatch®
Patent # 5429207
FE1720 FE0620
24
STEPLADDERS
Heavy duty
gusset bracing
Inside spreader
braces
Double-rivet step
construction
**Molded top with
recessed tray
ALUMINUM
StEPLADDERAS1000 SERIES
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AS1003 3’ 3” 18 ⁄” 23 ¼” 12 2.9‘
AS1004 4’ 3” 19 ⁄” 29 ⁄” 14 3.7‘
AS1006 6’ 3” 22 ⁄” 41” 20 7.1‘
AS1008 8’ 3” 25 ⁄” 52 ⁄” 24 9.2‘
AS1010 10’ 3” 28 ⁄” 64 ⁄” 30 14.2‘
AS1012 12’ 3” 31 ⁄” 76 ⁄” 38 19‘
AS1014* 14’ 3 ⁄” 34 ¾” 90” 60 33.4‘
AS1016* 16’ 3 ⁄” 37 ¾” 102” 70 34.2‘
AS1018* 18’ 3 ⁄” 40 ¾” 114” 81 50.2‘
AS1020* 20’ 3 ⁄” 43 ¾” 126” 93 61‘
**Molded top only on 3’-12’ models, otherwise aluminum top.
*Pail shelf not available on these models.
ANSI A14.2
ALUMINUM
StEPLADDERAS1100HD SERIES
Molded top with
recessed tray
Pinch-resistant
spreader braces
Double-rivet
step construction
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AS1106HD 6’ 3” 22 ¾” 40” 25 6.9’
AS1108HD 8’ 3” 25 ¾” 52 ⁄” 30 9.7’
AS1110HD 10’ 3” 28 ¾” 64 ⁄” 37 12.9’
AS1112HD 12’ 3” 31 ¾” 76 ½” 44 15.4’
ANSI A14.2
AS1106HD AS1006
Full set of
back braces
Full set of heavy
duty double
gusset bracing
Aluminum angle
slip-resistant
rubber feet
Aluminum angle
slip-resistant
rubber feet
25
STEPLADDERS
ProTop™ - versatile
and durable
Pinch-resistant
spreader braces
ALUMINUM
StEPLADDERAS2100 SERIES
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AS2104 4’ 3” 18 ⁄” 28 ⁄” 11 3.1‘
AS2106 6’ 3” 21 ⁄” 39 ⁄” 15 5.7‘
AS2108 8’ 3” 24 ⁄” 51 ⁄” 22 7.2‘
AS2110 10’ 3” 27 ⁄” 63 ⁄” 28 9.7‘
ANSI A14.2
ProTop™ - versatile
and durable
**Center-pull
spreader braces
ALUMINUM
StEPLADDERAS3000 SERIES
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AS3002* 2’ 3” 16 ⁄” 18 ⁄” 6 1.5‘
AS3003 3’ 3” 17 ⁄” 22 ⁄” 10 2.1‘
AS3004 4’ 3” 18 ⁄” 28 ⁄” 13 3.1‘
AS3005 5’ 3” 20 ⁄” 33 ⁄” 15 4.5‘
AS3006 6’ 3” 21 ⁄” 39 ⁄” 17 5.7‘
AS3008 8’ 3” 24 ⁄” 51 ⁄” 23 8.6‘
AS3010 10’ 3” 27 ⁄” 63 ⁄” 28 12.5‘
*AS3002 is a folding step stand and is not equipped with the ProTop™.
**Center-pull spreader brace only available on 3’-6’ models.
ANSI A14.2
AS3006 AS2106
Heavy duty
gusset bracing
Molded
pail shelf
Molded
pail shelf
Aluminum angle
slip-resistant
rubber feet
Aluminum angle
slip-resistant
rubber feet
Our new molded pail shelf is durable
and multifunctional designed to increase
productivity just like our ProTop™.
It features grooves for securing a paint
tray, quart and gallon paint bucket
holder, hardware tray, drill and tool slots.
26
STEPLADDERS / TWIN FRONT LADDERS
ALUMINUM
tWIN FRoNt LADDERAM1100HD SERIES
ALUMINUM
StEPLADDERAS4000 SERIES
Molded
pail shelf
Pinch-resistant
spreader braces
Slip-resistant
rubber feet
Heavy duty
gusset bracing
Double-rivet step
construction
Heavy gauge
steel hinges
Inside spreader
braces
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AS4003 3’ 3” 16 ⁄” 21 ⁄” 8 2.1‘
AS4004 4’ 3” 17 ⁄” 27 ⁄” 9 2.3‘
AS4005 5’ 3” 19 ¼” 33 ⁄” 11 3.3‘
AS4006 6’ 3” 20 ⁄” 39 ⁄” 13 4.6‘
AS4008 8’ 3” 23 ⁄” 51 ¼” 18 7.1‘
ANSI A14.2
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AM1104HD 4’ 3” 21 ⁄” 37 ⁄” 24 4.8‘
AM1106HD 6’ 3” 24 ⁄” 52 ⁄” 34 8.4‘
AM1108HD 8’ 3” 27 ⁄” 66 ⁄” 42 12.4‘
AM1110HD 10’ 3” 30 ⁄” 81 ⁄” 57 17.4‘
AM1112HD 12’ 3” 33 ⁄” 96 ½” 68 23.1‘
Special order item.
BOTH SIDES of twin front ladders can be used simultaneously by one person plus materials.
Therefore the duty rating for this ladder is PER SIDE.
ANSI A14.2
AS4006
AM1106HD
Molded top
with handyman’s
tool slots
Aluminum angle
slip-resistant
rubber feet
27
TWIN FRONT / PLATFORM LADDERS
ALUMINUM
tWIN FRoNt LADDERAM1000 SERIES
Double-rivet step
construction
Heavy gauge
steel hinges
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AM1003 3’ 3” 18 ½” 30 ⁄” 16 3.4‘
AM1004 4’ 3” 20” 37 ⁄” 18 4.8‘
AM1005 5’ 3” 21 ½” 45” 22 7‘
AM1006 6’ 3” 23” 52 ⁄” 24 8.2‘
AM1008 8’ 3” 26” 67 ⁄” 32 12.4‘
AM1010 10’ 3” 29” 82” 42 17.4‘
AM1012 12’ 3” 31” 96 ⁄” 51 23.1‘
AM1014 14’ 3 ⁄” 35” 111 ⁄” 79 29.5‘
AM1016 16’ 3 ⁄” 38” 126 ⁄” 101 36.5‘
AM1020 20’ 3 ⁄” 41” 156” 114 52.5‘
BOTH SIDES of twin front ladders can be used simultaneously by one person plus materials.
Therefore the duty rating for this ladder is PER SIDE.
ANSI A14.2
ALUMINUM
PLAtFoRM StEPLADDER AP1100HD SERIES
Gapless
slip-resistant
platform
Top rail
guard
Double-rivet step
construction
Heavy duty
gusset bracing
MODEL
HT. TO
PLATFORM
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT.
(LBS)
APPROX.
CUBES
AP1104HD 3’ 9” 3” 24 ½” 43 ⁄” 23 12.4‘
AP1106HD 5’ 8” 3” 27 ½” 55 ⁄” 30 16.2‘
AP1108HD 7’ 7” 3” 30 ½” 67 ⁄” 40 22.1‘
ANSI A14.2
AM1006
AP1104HD
Aluminum angle
slip-resistant
rubber feet
Aluminum angle
slip-resistant
rubber feet
iMProVed
PlatforM
deSiGn!
Gapless and slimmer
for improved storage.
28
PLATFORM / SPECIALTY LADDERS
ALUMINUM
MobILE PLAtFoRM LADDERAP5000 SERIES
Bodyweight™
activated caster
technology
Heavy duty
gusset bracing
Handrails
Slip-resistant
platform
Double-rivet step
construction
MODEL
HT. TO
PLATFORM
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
CASTER
SIZE
APPROX.
WT.
(LBS)
APPROX.
CUBES
AP5004 3’ 9” 3” 24 ¼” 44 ¾” 3” 42 13.9‘
AP5006 5’ 8” 3” 27 ¼” 54 ¾” 3” 56 18.7‘
AP5008 7’ 8” 3” 30 ¼” 65 ¾” 3” 68 27.1‘
AP5010 9’ 6” 3” 33 ¼” 76 ¾” 3” 82 38.1‘
ANSI A14.2
Top rail
guard
ALUMINUM
PLAtFoRM StEPLADDERAP1000 SERIES
Gapless
slip-resistant
platform
Double-rivet step
construction
Heavy duty
gusset bracing
Top rail
guard
MODE
HT. TO
PLATFORM
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AP1003 2’ 10” 3” 23” 38” 20 8.5‘
AP1004 3’ 9” 3” 24 ½” 43 ⁄” 22 10.2‘
AP1005 4’ 9” 3” 26” 49 ⁄” 24 13.2‘
AP1006 5’ 8” 3” 27 ½” 55 ⁄” 28 15.8‘
AP1008 7’ 7” 3” 30 ½” 67 ⁄” 36 21.7‘
AP1010 9’ 6” 3” 33 ½” 79 ½” 42 23.4‘
AP1012 11’ 5” 3 ¼” 36 ½” 91 ⁄” 64 37‘
AP1014 13’ 4” 3 ¼” 39 ½” 103 ¼” 75 40‘
AP1016 15’ 3” 3 ¼” 42 ½” 115 ⁄” 85 44.2‘
ANSI A14.2
AP1004
AP5006
Aluminum angle
slip-resistant
rubber feet
iMProVed
PlatforM
deSiGn!
Gapless and slimmer
for improved storage.
29
SPECIALTY LADDERS
ALUMINUM
SAWHoRSE LADDERL-2032 SERIES
ALUMINUM
uLtIMAtE ARtICuLAtED LADDERL-2091 SERIES
Pinch-resistant
spreader braces
Heavy duty
gusset bracing
Extra wide
work surface
Double-rivet step
construction
Heavy gauge
steel hinges
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
L-2032-02 2’ 3” 33 ¼” 22 ½” 14 3.7‘
L-2032-03 3’ 3” 34 ¾” 30 ¼” 20 6.6‘
L-2032-04 4’ 3” 36 ¼” 37 ¾” 24 9.2‘
L-2032-03 L-2091-13
Aluminum angle
slip-resistant
rubber feet
Built-In
Stabilizer
Comfortable
wide side rails
EasyHinge™
MODEL
LADDER
SIZE
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
L-2091-13 13’ 13’ 36 5.15‘
L-2091-17 15’ 17’ 43 7.5‘
ANSI A14.2
*2” x 12” plank needed for these positions
Stepladder
Supported
span scaffold
(*with plank)
Short span
scaffold
(*with plank)
Stairwell
scaffold
(*with plank)
Worktable or
multi-shelf
Stand-off ladder Stand-off ladder
Don’t
stand
or sit
Don’t
stand
or sit
Double (short)
stepladder
Fully
extended
straight
ladder
¾ length
straight
ladder
Self-supporting
scaffold
(*with plank)
Short
self-supporting
scaffold
(*with plank)
30
SPECIALTY LADDERS
Slip-resistant
standing surface
Slip-resistant
rubber feet
Easy to
use hinge
ALUMINUM
MINI WoRKING PLAtFoRML-2241 SERIES
MODEL
WORK
AREA
APPROX.
BASE
WIDTH
APPROX.
SPREAD
APPROX.
WT.
(LBS)
APPROX.
CUBES
HT. TO
PLATFORM
L-2241-03 12” x 37 ¼” 16 ¼” 47 ⁄” 11 2.4 21”
ALUMINUM
INDuStRIAL StEP StAND AY8000 SERIES
Large
aluminum steps
Large
molded top
Heavy duty
gusset bracing
Double-rivet step
construction
Table
continued
below...
MODEL
HT. TO
TOP STEP
TOP SIZE
(W x D)
AY8001* 13” 14” x 9 ¼”
AY8002 23” 14” x 9 ¼”
AY8003 34 ⁄” 14” x 9 ¼”
AY8004 45 ¾” 14” x 9 ¼”
MODEL STEP SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AY8001* 6” 15” 15 ⁄” 8 2.5‘
AY8002 6” 17 ¾” 20 ⁄” 14 2.8‘
AY8003 6” 19 ¾” 26 ½” 19 3.6‘
AY8004 6” 21 ¾” 32 ⁄” 24 6.6‘
*Casters and handle option not available on this model
AY8002
31
SPECIALTY LADDERS
Heavy duty
trestle top hinge
Double-rivet step
construction
Locking
bail
Slide guides &
spreader braces
ALUMINUM
EXtENSIoN tREStLE LADDERAX1000 SERIES
MODEL
HT. TO
PLATFORM
MAX. EXT.
LENGTH
STEP SIZE
BOTTOM
WIDTH
AX1008 8’
12’ 6”
3” 33”
AX1010 10’
15’ 6”
3” 39”
AX1012 12’
19’ 6”
3” 45”
MODEL
APPROX.
SPREAD
INSIDE
WIDTH FLY
OUTSIDE
WIDTH FLY
APPROX.
WT. (LBS)
APPROX.
CUBES
AX1008 69” 15 ⁄” 17 ⁄” 58 20.3‘
AX1010 84” 15 ⁄” 17 ⁄” 74 29.3‘
AX1012 99” 15 ⁄” 17 ⁄” 90 41.2‘
Table
continued
below...
AX1008
ANSI A14.2
Aluminum angle
slip-resistant
rubber feet
Durable
design
Tilt
and roll
Double-rivet step
construction
Slip-resistant
rubber feet
Extra large
top platform
Premium
construction
ALUMINUM
AIRCRAFt MECHANIC LADDERAM8000 SERIES
MODEL
LADDER
SIZE
STEP
SIZE
BOTTOM
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AM8003 3’ 3 ⁄” 24 ⁄” 43 ⁄” 44 7.6‘
AM8004 4’ 3 ⁄” 25 ⁄” 51 ¼” 55 10.8‘
AM8006 6’ 3 ⁄” 28 ⁄” 66 ⁄” 69 18‘
AM8008 8’ 3 ⁄” 31 ⁄” 80 ⁄” 84 25.1‘
AM8010 10’ 3 ⁄” 34 ⁄” 95 ⁄” 100 36.7‘
AM8012 12’ 3 ⁄” 37 ⁄” 110 ⁄” 115 47.7‘
AM8014 14’ 3 ⁄” 40 ⁄” 125 ¼” 134 60‘
Optional handrail available, part #PR091023
AM8006
32
SPECIALTY LADDERS
ALUMINUM
MuLtI PuRPoSE LADDERL-2094 SERIES
Heavy duty
locking pins
Quick activating
snap-lock hinge
MODEL
LADDER
SIZE
APPROX.
WT. (LBS)
APPROX.
CUBES
L-2094-13 13’ 35 4.0
L-2094-17 17’ 42 5.2
L-2094-22 22’ 50 6.4
MODEL
ADJUSTABLE
STEPLADDER STAIRWAY
SCAFFOLDING
EXTENSION
L-2094-13 3’ - 5’ 3’ - 5’ 1’ - 2’ 7’ - 11’
L-2094-17 4’ - 7’ 4’ - 7’ 1’ - 4’ 9’ - 15’
L-2094-22 5’ - 9’ 5’ - 9’ 1’ - 5’ 11’ - 19’
ANSI A14.2
Table
continued
below...
See congurations on pg. 7
Slip-resistant
rubber feet
Double rivet
step construction
L-2094-17
Rubber
bumper
Angled
steps
Double-rivet step
construction
Heavy duty
gusset bracing
ALUMINUM
SHELF LADDER AH1000 SERIES
MODEL LADDER SIZE STEP SIZE WIDTH
APPROX.
WT. (LBS)
APPROX.
CUBES
AH1004 4’ 3” 15 ¼” 6 1.6‘
AH1005 5’ 3” 15 ¼” 8 2‘
AH1006 6’ 3” 15 ¼” 10 2.3‘
AH1007 7’ 3” 15 ¼” 11 2.7‘
AH1008 8’ 3” 15 ¼” 12 3.1‘
AH1010 10’ 3” 15 ¼” 16 3.5‘
AH1012 12’ 3” 15 ¼” 20 3.9‘
AH1014 14’ 3” 15 ¼” 23 4.3‘
AH1016 16’ 3” 15 ¼” 26 4.6‘
AH1006
Aluminum angle
slip-resistant
rubber feet
4
4
LADDERS IN ONE!
LADDERS IN ONE!
33
EXTENSION LADDERS
ALUMINUM
EXtENSIoN LADDER AE1200HD SERIES
Mar-resistant
rail end caps
Outside
slide guides
D-shaped
rungs
Full
I-beam
Swivel
safety shoes
Mar-resistant
rail end caps
Rubber fly
section shoes
D-shaped
rungs
Stacked aluminum
I-beam rail
Swivel
safety shoes
ALUMINUM
EXtENSIoN LADDER AE2800 SERIES
MODEL
TOTAL
LENGTH
LENGTH EA.
SECTION
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
AE2816* 16’ 8’ 13’ 32 6.3‘
AE2820 20’ 10’ 17’ 39 9.5‘
AE2824 24’ 12’ 21’ 46 11.4‘
AE2828 28’ 14’ 25’ 59 13‘
AE2832 32’ 16’ 29’ 66 15.2‘
AE2836 36’ 18’ 32’ 80 16‘
AE2840 40’ 20’ 35’ 89 16.8‘
*Does not include rope & pulley.
INSIDE WIDTH OUTSIDE WIDTH
SIZES RAIL DEPTH STACK HT BASE FLY BASE FLY
16’–40’ 3” 6” 15 ¾” 15 ¾” 18” 18”
ANSI A14.2
MODEL
TOTAL
LENGTH
LENGTH EA.
SECTION
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
AE1216HD* 16’ 8’ 13’ 38 7.3‘
AE1220HD 20’ 10’ 17’ 42.79 9.1‘
AE1224HD 24’ 12’ 21’ 52.03 10.7‘
AE1228HD 28’ 14’ 25’ 59.26 13.4‘
AE1232HD 32’ 16’ 29’ 73.19 15.3‘
AE1236** 36’ 18’ 32’ 81.57 17.1‘
AE1240** 40’ 20’ 35’ 90.26 19.6‘
AE1248*** 48’ 24’ 43’ 122 29.1‘
*Does not include rope & pulley **300 lb. Type IA rated standard ladder.
***250 lb. Type I rated standard ladder.
INSIDE WIDTH OUTSIDE WIDTH
SIZES RAIL DEPTH STACK HT. BASE FLY BASE FLY
16’–40’ 3” 5 ¼” 16 ⁄” 14 ⁄” 19 ⁄” 16 ⁄”
44’–48’ 4” 6 ⁄” 18” 15 ⁄” 20 ⁄” 18 ⁄”
ANSI A14.2
QuickLatch®
Patent # 5429207
QuickLatch®
Patent # 5429207
AE1220HD AE2820
34
EXTENSION LADDERS
MODEL
TOTAL
LENGTH
LENGTH EA.
SECTION
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
AE2216* 16’ 8’ 13’ 30 7.3‘
AE2220 20’ 10’ 17’ 37 8.8‘
AE2224 24’ 12’ 21’ 44 9‘
AE2228 28’ 14’ 25’ 56 11.8‘
AE2232 32’ 16’ 29’ 62 14.1‘
AE2236 36’ 18’ 32’ 76 16.5‘
AE2240 40’ 20’ 35’ 84 18.5‘
*Does not include rope & pulley.
SINGLE LADDERS
MODEL TOTAL LENGTH APPROX. WT. (LBS) APPROX. CUBES
AE2108 8’ 15 4.3‘
AE2110 10’ 18 5.9‘
AE2112 12’ 22 6.7‘
AE2114 14’ 28 7.7‘
AE2116 16’ 30 9.1‘
AE2118 18’ 38 9.4‘
AE2120 20’ 42 10.1‘
Mar-resistant
rail end caps
Outside
slide guides
D-shaped
rungs
Full
I-beam
Swivel
safety shoes
ALUMINUM
EXtENSIoN LADDER AE2000 SERIES
INSIDE WIDTH OUTSIDE WIDTH
SIZES
RAIL
DEPTH
STACK
HEIGHT BASE FLY BASE FLY
16’–24’ 3” 5 ¼” 15 ⁄” 13 ⁄” 17 ⁄” 15 ⁄”
28’–40’ 3” 5 ¼” 15 ⁄” 13 ¼” 18” 15 ⁄”
ANSI A14.2
QuickLatch®
Patent # 5429207
AE2220
35
EXTENSION LADDERS
Swivel
safety shoes
Double rope
& pulley
Aluminum cast
rail end caps
Full
I-beam
Round
rungs
ALUMINUM
3-SECtIoN EXtENSIoN LADDER AE1660 SERIES
Mar-resistant
end caps
Modified
I-beam
Swivel
safety shoes
ALUMINUM
EXtENSIoN LADDERAE3200 SERIES
MODEL
TOTAL
LENGTH
MAX. EXTENDED
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
AE1660 60’ 48’ 169 30.4‘
TOTAL
LENGTH RAIL DEPTH
STACK
HEIGHT
SECTION
LENGTH
INSIDE
WIDTH
OUTSIDE
WIDTH
60’ 4” 8 ¼”
Base Section 22’ 18” 21 ½”
Center Section 20’ 15 ⁄” 18 ⁄”
Fly Section 18’ 12 ⁄” 16 ⁄”
ANSI A14.2
MODEL
TOTAL
LENGTH
LENGTH EA.
SECTION
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
AE3216* 16’ 8’ 13’ 27 6.5‘
AE3220 20’ 10’ 17’ 32 7‘
AE3224 24’ 12’ 21’ 38 8.3‘
AE3228 28’ 14’ 25’ 53 11.3‘
AE3232 32’ 16’ 29’ 60 13.2‘
AE3236 36’ 18’ 32’ 72 14.7‘
AE3240 40’ 20’ 35’ 80 15.7‘
*Does not include rope & pulley.
INSIDE WIDTH OUTSIDE WIDTH
SIZES
RAIL
DEPTH
STACK
HEIGHT BASE FLY BASE FLY
16–40’ 3” 5 ¼” 15 ¼” 13 ⁄” 17 ½” 16 ⁄”
ANSI A14.2
QuickLatch®
Patent # 5429207
D-shaped
rungs
AE1660 AE3220
36
EXTENSION LADDERS
QuickLatch®
Patent # 5429207
ALUMINUM
EXtENSIoN LADDERAE4000 SERIES
MODEL
TOTAL
LENGTH
LENGTH EA.
SECTION
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
AE4216PG** 16’ 8’ 13’ 27 6.4‘
AE4220PG 20’ 10’ 17’ 32 8.2‘
AE4224PG 24’ 12’ 21’ 38 9.6‘
AE4228PG 28’ 14’ 25’ 48 11.3‘
AE4232PG 32’ 16’ 29’ 58 12.9‘
AE4236PG 36’ 18’ 32’ 71 14.5‘
AE4240PG 40’ 20’ 35’ 80 16.3‘
**Does not include rope & pulley.
INSIDE WIDTH OUTSIDE WIDTH
SIZES
RAIL
DEPTH STACK HT. BASE FLY BASE FLY
16’-40’ 3” 5 ¼” 15 ¼” 14 ⁄” 17 ⁄” 16 ⁄”
ANSI A14.2
SINGLE LADDERS*
MODEL TOTAL LENGTH APPROX. WT. (LBS) APPROX. CUBES
AE4110 10’ 17 5.1‘
AE4112 12’ 20 5.9‘
AE4114 14’ 23 7.5‘
AE4116 16’ 29 8.5‘
AE4118 18’ 31 8.7‘
AE4120 20’ 36 10.1‘
*Does not include ProGrip™.
ProGrip™ - Get a
grip on your task!
Swivel
safety shoes
D-shaped
rungs
Modified
I-beam
AE4220PG
• NON-MARRING
• SLIP-RESISTANT
• HAND GRIP
•
NO MORE WRAPPING
YOUR LADDER IN TOWELS
neW!
37
EXTENSION LADDERS
D-shaped
rungs
Mar-resistant
end caps
D-shaped
rungs
Slip-resistant
rubber feet
Mar-resistant
rail end caps
MODEL
TOTAL
LENGTH
LENGTH EA.
SECTION
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
L-2321-16 16’ 8’ 13’ 18 5.5‘
Does not include rope & pulley.
ALUMINUM
EXtENSIoN LADDERL-2321 SERIES
ALUMINUM
EXtENSIoN LADDERL-2324 SERIES
ANSI A14.2
MODEL
TOTAL
LENGTH
LENGTH EA.
SECTION
MAX. EXT.
LENGTH
APPROX.
WT. (LBS)
APPROX.
CUBES
L-2324-16* 16’ 8’ 13’ 21 5.6
L-2324-20 20’ 10’ 17’ 26 7
L-2324-24 24’ 12’ 21’ 39 8.4
L-2324-28 28’ 14’ 25’ 41 9.9
*Does not include rope & pulley.
ANSI A14.2
Fixed
runglock
Slip-resistant
feet
Aluminum
runglock
L-2324-20 L-2321-16
38
STEP STOOLS
Slip-resistant
platform
Slip-resistant
platform
Slip-resistant
rubber feet
Top rail
guard
Top rail
guard
Double-rivet step
construction
Heavy duty
gusset bracing
Heavy duty
gusset bracing
ALUMINUM
EuRo PLAtFoRM LADDERL-2346 SERIES
ALUMINUM
PLAtFoRM LADDERAP8000 SERIES
MODEL
HT. TO
PLATFORM
APPROX.
BASE WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
L-2346-02 2’ 17 ⁄” 23 ¾” 8 2
L-2346-03 3’ 18 ⁄” 31” 9 2.7
L-2346-04 4’ 19 ⁄” 38 ¼” 11 3.5
MODEL
HT. TO
PLATFORM
APPROX.
BASE WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
AP8004 2’ 19 ⁄” 26 ⁄” 9 2.4
AP8005 3’ 20 ½” 33 ¾” 10 3.2
Slip-resistant
rubber feet
L-2346-04
AP8005
39
STEP STOOLS
L-4341-02
L-4342-02
STEEL
QWIK StEP® StEP StooLL-4340 SERIES
STEEL
QWIK StEP® StEP StooLL-4362 SERIES
Slip-resistant
steps
Slip-resistant
steps
Non-marring
rubber feet
Non-marring
rubber feet
Folds flat for
easy storage
Folds flat for
easy storage
MODEL
HT. TO
PLATFORM
APPROX.
BASE WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
L-4362-02 1’ 11” 16” 18” 10 2.6
L-4362-03 2’ 10” 17” 24 ¼” 12 3.5
MODEL COLOR
HT. TO
PLATFORM
APPROX.
BASE
WIDTH
APPROX.
SPREAD
APPROX.
WT. (LBS)
APPROX.
CUBES
L-4341-02 Almond 2’ 16 ⁄” 19 ½” 9.2 1
L-4342-02 Black 2’ 16 ⁄” 19 ½” 9.2 1
L-4345-02 White 2’ 16 ⁄” 19 ½” 9.2 1
L-4362-03
L-4345-02
40
ATTIC LADDERS
Advanced
cylinder design
Adjustable
shoes
ALUMINUM
AttIC LADDERELITE SERIES
MODEL
DIMENSIONS
ROUGH
OPEN
CEILING
(A)
FITS CEILING
HEIGHTS
MIN. MAX
.
(B)
APPROX.
LANDING
SPACE
(C)
APPROX.
PROJECT
WIDTH
APPROX.
WT.
(LBS)
APPROX.
CUBES
AA229GS 22 ½” x 54” 7 ’ 9 ” 10’ 72” 76” 55 8.5‘
AA259GS 25 ½” x 54” 7’9” 10’ 72” 76” 58 9.5‘
ANSI A14.9
Heavy
duty hinges
Insulated
door
EZ-hang
strap
Heavy duty
hinges
3 ¼”deep
steps
Adjustable
shoes
EZ-hang
strap
Angle
bracing
Insulated
door
MODEL
DIMENSIONS
ROUGH OPEN
CEILING
(A)
FITS CEILING
HEIGHTS
MIN. MAX.
(B)
APPROX.
LANDING
SPACE
(C)
APPROX.
PROJECT
WIDTH
APPROX.
WT.
(LBS)
APPROX.
CUBES
AL258P 25 ½” x 63” 10’ 12’ 85” 87” 67 11.9‘
ANSI A14.9
ALUMINUM
AttIC LADDEREVEREST SERIES
EASY OPENING
& CLOSING
WIDER CLEARANCE
FULLY ASSEMBLED
READY TO INSTALL
3 ¼” deep
steps
NOW WITH ADVANCED
CYLINDER DESIGN!
Rail size - 3 ⁄” Rail size - 3 ⁄”
41
ATTIC LADDERS
Adjustable
EZ-hang
strap
Corner
bracing
Metal
hinges
5 ½” deep
steps
Reinforced
steps
WOOD
AttIC LADDERBIG BOY SERIES
MODEL
DIMENSIONS
ROUGH
OPEN
CEILING
(A)
FITS CEILING
HT
MIN. MAX
.
(B)
APPROX.
LANDING
SPACE
(C)
APPROX.
PROJECT
WIDTH
APPROX.
WT.
(LBS)
APPROX.
CUBES
S305P 30” x 60” 7 ’ 8’9” 63” 66” 75 15’
L305P 30” x 60” 8’9” 10’ 71” 75” 82 15’
ANSI A14.9
WOOD
AttIC LADDER CHAMPION SERIES
Adjustable
EZ-hang
strap
Reinforced
steps
5 ½” deep
steps
MODEL
DIMENSIONS
ROUGH
OPEN
CEILING
(A)
FITS CEILING
HEIGHTS
MIN. MAX
.
(B)
APPROX.
LANDING
SPACE
(C)
APPROX.
PROJECT
WIDTH
APPROX.
WT.
(LBS)
APPROX.
CUBES
CS224P 22 ½” x 54” 7’ 8’9” 63” 66” 64 8.5‘
CL224P 22 ½” x 54” 8’9” 10’ 71” 75” 70 8.5‘
CS254P 25 ½” x 54” 7’ 8’9” 63” 66” 65 9.5‘
CL254P 25 ½” x 54” 8’9” 10’ 71” 75” 71 9.5‘
CS224I 22 ½” x 54” 7 ’ 8’9” 63” 66” 64 8.5‘
CL224I 22 ½” x 54” 8’9” 10’ 71” 75” 70 8.5‘
CS254I 25 ½” x 54” 7’ 8’9” 63” 66” 65 9.5‘
CL254I 25 ½” x 54” 8’9” 10’ 71” 75” 71 9.5‘
P = standard option without insulation / I = insulated door.
ANSI A14.9
Rail size - ¾” x 4 ⁄” Rail size - ¾” x 4 ⁄”
42
ATTIC / WAREHOUSE LADDERS
WOOD
AttIC LADDERPREMIUM SERIES
Adjustable
EZ-hang
strap
Reinforced
steps
3 ½” deep
steps
MODEL
DIMENSIONS
ROUGH
OPEN
CEILING
(A)
FITS CEILING
HEIGHTS
MIN. MAX
.
(B)
APPROX.
LANDING
SPACE
(C)
APPROX.
PROJECT
WIDTH
APPROX.
WT.
(LBS)
APPROX.
CUBES
S224P 22 ½” x 54” 7 ’ 8’9” 63” 66” 53 8.5‘
L224P 22 ½” x 54” 8’9” 10’ 71” 75” 57 8.5‘
S254P 25 ½” x 54” 7’ 8’9” 63” 66” 56 9.5‘
L254P 25 ½” x 54” 8’9” 10’ 71” 75” 58 9.5‘
ANSI A14.9
Reinforced back
assembly
Step-lock
safety feature
Non-conductive
platform assembly
Heavy duty base
assembly
Forward-descent
design
Heavy duty,
slip-resistant,
step assembly
FIBERGLASS
SAFEGuARD™ MobILE
MAINtENANCE PLAtFoRMFW SERIES
STANDARD
EASY-TURN
DESIGN ON
7-15 STEP
LADDERS!
FW2400 Series 24” x 17” Platform 300 lb. Capacity 1-Person
MODEL
LADDER
SIZE
HT. TO
TOP
STEP
MAX.
LENGTH
MAX.
WIDTH
MAX.
HT. w/
RAILS
SHIP.
WT.
(LBS)
APPROX.
CUBES
FW2404 4’ 3’ 2 ½” 54 ¾” 32 ⁄” 6’ 8 ½” 159 18‘
FW2406 6’ 4’ 9 ½” 71 ⁄” 32 ⁄” 8’ 3 ½” 189 21‘
FW2408 8’ 6’ 4 ½” 89” 32 ⁄”9’ 10 ½” 258 28‘
FW2410 10’ 7’ 11 ½” 106 ⁄” 32 ⁄”11’ 5 ½” 404 60‘
FW2412 12’ 9’ 6 ½” 123 ¼” 36 ⁄”13’ ½” 440 71‘
FW2414 14’ 11’ 1 ½” 140 ⁄” 39 ½”14’ 7 ½” 530 83‘
FW2415 15’ 11’ 11” 148 ⁄” 39 ½” 15’ 5” 545 89‘
An optional outrigger is also available for compliance with local code.
6-15 step (328000B)
ANSI A14.7
FW2408
Rail size - ¾” x 3 ⁄”
43
WAREHOUSE LADDERS
GSW2410
*Spring
loaded casters
No forward
descent
Premium
powder paint
**Toeboard
(12’+ models only)
Locking
device
GSW1601A-W04
ACCESSORIES & OPTIONS
EXTRA DEEP TOP
*SPRING LOADED CASTERS
HANDRAIL & GUARDRAIL
ACCESSORY #W03
HANDRAIL & OUTRIGGER
MODEL STEPS
STEP
WIDTH
HT. TO
PLATFORM
OVERALL
HEIGHT
OVERALL
DEPTH
OVERALL
WIDTH
APPROX.
CUBES
APPROX.
WT. (LBS)
NO HANDRAILS
GSW1601A-W04 1 16” 12” 12” 17” 19” 1.9 16
GSW1602 2 16” 20” 20” 19” 20” 3.4 25
GSW2402 2 24” 20” 20” 19” 28” 8.1 30
GSW2403 3 24” 30” 30” 27” 28” 8.1 41
GSW1604 4 16” 40” 40” 35” 23” 8.3 47
GSW2404 4 24” 40” 40” 35” 31” 10.4 55
HANDRAILS
GSW1603A-W03 3 16” 30” 66” 27” 20” 5 46
GSW2403-W03 3 24” 30” 66” 27” 28” 8.1 56
GSW1604-W03 4 16” 40” 76” 35” 23” 8.3 58
GSW2404-W03 4 24” 40” 76” 35” 31” 10.4 66
GSW1605 5 16” 50” 86” 42” 23” 10.1 67
GSW2405 5 24” 50” 86” 42” 31” 12.6 79
GSW2406 6 24” 60” 96” 50” 34” 14.9 109
GSW2407 7 24” 70” 106” 57” 34” 17.2 121
GSW2408 8 24” 80” 116” 63” 34” 19.4 151
GSW2409 9 24” 90” 126” 70” 34” 21.7 170
GSW2410 10 24” 100” 136” 77” 34” 23.9 198
GSW2411 11 24” 110” 146” 83” 34” 26.2 214
GSW2412 12 24” 120” 156” 90” 34” 28.5 228
GSW2413 13 24” 130” 166” 97” 39” 30.7 289
GSW2414 14 24” 140” 176” 104” 39” 33 298
GSW2415 15 24” 150” 186” 110” 39” 35.2 311
ANSI A14.7
*Spring loaded casters available for 1-5 step models only.
**Toeboard only available on models GSW2412 and up.
5 Step (16” Wide Only)
5-9 Step
10-12 Step
13-15 Step
GRCAL05EC-B
GRCAL0509-B
GRCAL1012-B
GRCAL1315-B
HANDRAIL & OUTRIGGER (ACCESSORY)
Mandatory when local codes
require 3:1 height to base ratio
CONSULT LEAD TIMES WITH A
CUSTOMER SERVICE REPRESENTATIVE
FOR THE PRODUCTS ON THIS PAGE
STEEL
RoLLING WAREHouSE LADDER GSW SERIES
44
WAREHOUSE LADDERS
Forward
descent
Bottom
landing step
Non marring/marking
casters
Wide
steps
Handrail &
guardrail
Tubular
construction
Forward
descent
Bottom
landing step
Non marring/marking
casters
Tubular
construction
HANDRAIL & OUTRIGGER (ACCESSORY)
Mandatory when local codes require 3:1 height to base ratio
MODEL STEPS
STEP
WIDTH
HT. TO
PLATFORM
OVER
ALL
HEIGHT
OVER
ALL
DEPTH
OVER
ALL
WIDTH
APPROX.
CUBES
APPROX.
WT.
(LBS)
GSX1603 3 16” 30” 66” 41” 23” 9.6’ 75
GSX1604 4 16” 40” 76” 49” 23” 11.7’ 91
GSX1605 5 16” 50” 86” 58” 23” 13.8’ 104
GSX1606 6 16” 60” 96” 66” 27” 15.8’ 118
GSX1607 7 16” 70” 106” 74” 27” 17.9’ 132
ANSI A14.7
MODEL
STEPS
STEP
WIDTH
HT. TO
PLATFORM
OVER
ALL
HEIGHT
OVER
ALL
DEPTH
OVER
ALL
WIDTH
APPROX.
CUBES
APPROX.
WT.
(LBS)
GSX2404 4 24” 40” 76” 49” 28” 14.6 113
GSX2405 5 24” 50” 86” 58” 28” 17.2 126
GSX2406 6 24” 60” 96” 66” 34” 19.8 146
GSX2407 7 24” 70” 106” 74” 34” 22.4 159
GSX2408 8 24” 80” 116” 82” 34” 25 200
GSX2409 9 24” 90” 126” 91” 34” 27.6 232
GSX2410 10 24” 100” 136” 99” 34” 30.2 248
GSX2411 11 24” 110” 146” 107” 34” 32.8 264
GSX2412 12 24” 120” 156” 116” 34” 35.4 280
GSX2413 13 24” 130” 166” 124” 39” 38 356
GSX2414 14 24” 140” 176” 133” 39” 40.6 369
GSX2415 15 24” 150” 186” 141” 39” 43.3 392
ANSI A14.7
SHOWN WITH
EASY-TURN
DESIGN!
(option #X09)
3-7 Step (16” wide only)
4-9 Step
10-12 Step
13-15 Step
GRCAL05EC-O
GECAL0509-O
GRCAL1012-O
GRCAL1315-O
This super heavy duty ladder is constructed for the most demanding
requirements, yet it is only 16" wide—the number one choice for
narrow spaced industrial applications.
GSX1603
CONSULT LEAD TIMES WITH A CUSTOMER SERVICE
REPRESENTATIVE FOR THE PRODUCTS ON THIS PAGE
HEAVY DUTY STEEL
WAREHouSE LADDER
GSX2400 SERIES (Knocked Down)
HEAVY DUTY STEEL
WAREHouSE LADDER
GSX1600 SERIES (Knocked Down)
45
WAREHOUSE LADDERS
One-persOn assembly!
STEEL
RoLLING toWER SCAFFoLDSST SERIES
TO MAKE THE 12’ TOWER, YOU NEED:
(2) ST0606A - 6‘ Scaffold
(1) PK735A - Outriggers (4/box)*
(1) PK736A - Handrail (1/box)*
*Outriggers and handrail sold separately.
Do not stack higher than 2 units high totaling 12’. Each set of end frames requires
1 pair of trusses & platform.
ST0606A
MODEL SIZE (HxL) APPROX. WT. (LBS) APPROX. CUBES
ST0306A* 3’ x 6’ 115 7.3’
ST0606A 6’ x 6’ 132 7.3’
*Does not include casters.
ANSI A10.8
12’ TOWER
END-FRAMES:
Full height unit 29” wide x 69” high (without casters)
Half unit 29” wide x 42” high (without casters)
WIDTH (ASSEMBLED):
29 ½” with casters
66 ¾” with outriggers & casters
PLATFORM:
Exterior grade, edge protected
⁄” thick plywood
6’ unit – 28.75” wide x 67” long
PLATFORM HEIGHT (MAX):
with casters
6’ unit – 6’ 1”
12’ unit – 11’
HEIGHT OF HANDRAIL: 39”
neW!
Locking pins
prevent accidental
unlocking
Deck pin secures
platform
Fits through 30”
door frame
1,000 LBS. LOAD CAPACITY!
46
WAREHOUSE LADDERS
Folds flat for
easy storage
Sturdy
workbench
Individual platform
can be used at
different levels
Great for painting and
decorating projects
MINI FORTRUSS®
MobILE WoRK StANDSM SERIES
ADJUSTABLE HEIGHT:
The working height can be adjusted to 12”, 24”, 36”, & 48.”
AMPLE WORK CAPACITY:
Provides a large 17”x 43” work surface, along with 500 lbs.
distributed load work capacity.
END FRAME STOPS:
Exclusive non-pinching stops limit rotation of end frame to 90°.
Patent #5,555,954
MODEL CASTERS
APPROX. WT.
(LBS)
OVERALL LENGTH
w/CASTERS
OVERALL HT.
w/CASTERS
OVERALL
WIDTH
FOLDED UNIT
WIDTH PLANK WIDTH
PLANK
LENGTH
LOAD
RATING
SM1404A 4 68 47 ½” 50 ¾” 22 ½” 6 ¾” 8.5 (2), 17 overall 46 ⁄” 500 lbs.
47
STAGES
Nail
lock
Heavy
duty
Edge-guard
SCAF-A-DECK PD8000 SERIES
MEDIUM-DUTY
TELESCOPING PLANK LP-2921 SERIES
MODEL
PLANK
LENGTH WIDTH RAIL SIZE
CAPACITY
(LBS/SQ.FT.)
APPROX.
WT. (LBS)
PD8007 7’ 19” 3” 75 27
PD8008 8’ 19” 3” 75 32
PD8010 10’ 19” 3” 50 35
MODEL
PLANK
LENGTH
STANDARD
EXTENSION WIDTH
APPROX.
WT. (LBS)
LP-2921-09A 9’ 6’0” - 9’0” 12” 30
LP-2921-13A 13’ 8’0” - 13’0” 12” 39
LP-2921-16A 16’ 10’0” - 16’0” 12” 50
SCAFFOLD PLANKS &
STAGE PLATFORMS P SERIES
Molded ergonomic
handles
Optional modular
handrail systems
Reinforcing
web braces
Slip-resistant
decking
Easy grip
rungs
P1, P2 AND P3 SERIES AVAILABLE. SEE THE FOLLOWING PAGE FOR DETAILS.
ANSI A10.8
The LadderPro™ medium-duty telescoping plank is available in 9’, 13’,
and 16’ sizes (fully extended). The plank is manufactured with heavy
wall aluminum tubing to prevent the twisting and exing common to
most other planks. The built-in, skid-resistant surface reduces slips. It
stores and transports in approximately half of its fully extended length.
The telescoping plank has the strength to do the job safely, and the
compactness to store easily after the work is done. 250 lb. rated.
Safety
latch
Solid bolt
construction
SCAF-A-DECK PD9000 SERIES
MODEL
PLANK
LENGTH WIDTH RAIL SIZE
CAPACITY
(LBS/SQ.FT.)
APPROX.
WT. (LBS)
PD9007 7’ 18 ¾” 2” 75 33
PD9008 8’ 18 ¾” 2” 75 36
PD9010 10’ 18 ¾” 2” 50 42
CONSULT LEAD TIMES WITH A CUSTOMER SERVICE REPRESENTATIVE FOR THE PRODUCTS ON THIS PAGE
neW
handleS!
• Increased impact absorption
• Doubled resistance
• Supreme polymer technology
48
STAGES
CONSULT LEAD TIMES WITH A CUSTOMER SERVICE REPRESENTATIVE FOR THE PRODUCTS ON THIS PAGE
1-PERSON DECORATOR PLANK250 Lb. WoRKING LoAD P1 SERIES
2-PERSON SCAFFOLD PLANK & STAGE 500 Lb. WoRKING LoADP2 SERIES
lb.
250
lb.
250
VV
12" 12"
CENTER
18" 18"
VV
lb.
250
12" 12"
CENTER
14” WIDE
MODEL
APPROX.
WT. (LBS)
- -
- -
P21412 45
- -
P21416 65
P21420 103
P21424 118
P21428 149
- -
P21432 167
24” WIDE
MODEL
APPROX.
WT. (LBS)
- -
- -
P22412 57
- -
P22416 81
P22420 124
P22424 142
P22428 176
- -
P22432 197
28” WIDE
MODEL
APPROX.
WT. (LBS)
P22805 26
P22806 31
P22812 60
P22814 76
P22816 85
P22820 129
P22824 151
P22828 185
P22830 199
P22832 213
20” WIDE
MODEL
APPROX.
WT. LBS)
- -
- -
P22012 52
- -
P22016 69
P22020 115
P22024 133
P22028 166
- -
P22032 181
SIZE
SIDE RAIL
DEPTH
5’ 4”
6’ 4”
12’ 4”
14’ 5”
16’ 5”
20’ 6”
24’ 6”
28’ 6”
30’ 6”
32’ 6”
12” WIDE
MODEL
APPROX.
WT. (LBS)
- -
P21206 15
P21212 41
- -
P21216 60
P21220 97
P21224 112
P21228 142
- -
P21232 160
3-PERSON STAGE PLATFORM 750 Lb. WoRKING LoAD P3 SERIES
lb.
250
lb.
250
lb.
250
VV
12" 12"
CENTER
18" 18"
20” WIDE
MODEL
APPROX.
WT. (LBS)
P32016 87
P32020 119
P32024 135
P32028 217
- -
- -
24” WIDE
MODEL
APPROX.
WT. (LBS)
P32416 101
P32420 133
P32424 149
P32428 225
P32432 252
- -
28” WIDE
MODEL
APPROX.
WT. (LBS)
P32816 111
P32820 139
P32824 163
P32828 239
P32832 275
P32840 367
SIZE
SIDE RAIL
DEPTH
16’ 6”
20’ 6”
24’ 6”
28’ 7”
32’ 7”
40’ 7”
14” WIDE
MODEL
APPROX.
WT. (LBS)
P11408 29
P11416 53
P11420 78
P11424 90
20” WIDE
MODEL
APPROX.
WT. (LBS)
P12008 36
P12016 62
P12020 88
P12024 100
12” WIDE
MODEL
APPROX.
WT. (LBS)
P11208 27
P11216 51
P11220 76
P11224 88
SIZE
SIDE RAIL
DEPTH
8’* 4”
16’ 4”
20’ 5”
24’ 5”
*Full length decking.
49
CONSULT LEAD TIMES WITH A CUSTOMER SERVICE
REPRESENTATIVE FOR THE PRODUCTS ON THIS PAGE
MODULAR
GUARDRAIL SYSTEMS
FoR PLANKS & StAGES
RAIL END CAPS MODEL
APPROX.
WT. (LBS)
Caps for 7” Rail PR064226 0.8 Ea.
RAIL END CAPS MODEL APPROX. WT. (LBS)
Caps for 4” Rail PK740A 0.65 Ea.
Caps for 5” Rail PK740B 0.80 Ea.
Caps for 6” Rail PK740C 1.07 Ea.
(2 end caps & hardware per kit)
SINGLE SIDED SYSTEM*
STAGE
LENGTH
GUARDRAIL
POST
ASSEMBLY
9’
GUARDRAIL
LENGTH
13’
GUARDRAIL
LENGTH
9’
TOEBOARD
LENGTH
13’
TOEBOARD
LENGTH
WEB
BRACE
ASSEMBLY**
MPT-01 MGR-09 MGR-13 MTB-09 MTB-13 MRF-01
5’ 2 2 0 1 0 2
6’ 2 2 0 1 0 2
8’ 2 2 0 1 0 2
10’ 2 0 2 0 1 2
12’ 3 0 2 0 1 3
14’ 3 0 2 0 1 3
16’ 3 4 0 2 0 3
18’ 3 0 4 0 2 3
20’ 4 6 0 3 0 4
24’ 4 6 0 3 0 4
28’ 5 4 2 2 1 0
30’ 5 8 0 4 0 0
32’ 5 4 4 2 2 0
36’ 6 10 0 5 0 0
40’ 6 6 4 3 2 0
*Double all quantities, except for web brace assembly, for two-sided systems.
PRODUCT WEIGHTS
ITEM
APPROX.
WT. (LBS)
MPT-01 0.56
MGR-09 2.31
MGR-13 3.33
MTB-09 2.38
MTB-13 3.44
MRF-01 1.13
MER-01 2.00
MER-02 2.84
THREE SIDED SYSTEM
STAGE
LENGTH
GUARDRAIL
POST
ASSEMBLY
9’
GUARDRAIL
LENGTH
13’
GUARDRAIL
LENGTH
9’
TOEBOARD
LENGTH
13’
TOEBOARD
LENGTH
WEB
BRACE
ASSEMBLY**
ENDRAIL
ASSEMBLY
MPT-01 MGR-09 MGR-13 MTB-09 MTB-13 MRF-01
MER-01+/
MER-02+
5’ 4 2 0 1 0 2 2
6’ 4 2 0 1 0 2 2
8’ 4 2 0 1 0 2 2
10’ 4 0 2 0 1 2 2
12’ 5 0 2 0 1 3 2
14’ 5 0 2 0 1 3 2
16’ 5 4 0 2 0 3 2
18’ 5 0 4 0 2 3 2
20’ 6 6 0 3 0 4 2
24’ 6 6 0 3 0 4 2
28’ 7 4 2 2 1 0 2
30’ 7 8 0 4 0 0 2
32’ 7 4 4 2 2 0 2
36’ 8 10 0 5 0 0 2
40’ 8 6 4 3 2 0 2
FOUR SIDED SYSTEM
STAGE
LENGTH
GUARDRAIL
POST
ASSEMBLY
9’
GUARDRAIL
LENGTH
13’
GUARDRAIL
LENGTH
9’
TOEBOARD
LENGTH
13’
TOEBOARD
LENGTH
WEB
BRACE
ASSEMBLY**
ENDRAIL
ASSEMBLY
MPT-01 MGR-09 MGR-13 MTB-09 MTB-13 MRF-01
MER-01+/
MER-02+
5’ 4 4 0 2 0 2 2
6’ 4 4 0 2 0 2 2
8’ 4 4 0 2 0 2 2
10’ 4 0 4 0 2 2 2
12’ 6 0 2 0 2 3 2
14’ 6 0 4 0 2 3 2
16’ 6 8 0 4 0 3 2
18’ 6 0 8 0 4 3 2
20’ 8 12 0 6 0 4 2
24’ 8 12 0 6 0 4 2
28’ 10 8 4 4 2 0 2
30’ 10 16 0 8 0 0 2
32’ 10 8 8 4 4 0 2
36’ 12 20 0 10 0 0 2
40’ 12 12 8 6 4 0 2
+MER-01 required on 12” and 14” wide planks. MER-02 required on 20”, 24” and 28” wide planks.
**Required on planks with side rails LESS than 6” tall
ANSI A10.8
neW!
50
MERCHANDISER
SRA9 LADDER RACK
LOGO LOCK SYSTEM
FoR FIbERGLASS LADDERS
LOUISVILLE LADDER’S SRA9 LADDER RACK
MERCHANDISER DESIGNED SPECIFICALLY
TO INCREASE LADDER SALES.
DETAILS
Each ladder will have one custom logo applied to each side rail
(Dimension of logo should be a maximum of 7 ⁄” x 2 ⁄”)
One time setup fee for each logo
Artwork must be provided in either “.jpg” or “.tif” format with a
minimum 300 dpi (dots per inch) resolution
CONTACT YOUR LOUISVILLE LADDER SALES
REPRESENTATIVE FOR MORE INFORMATION!
Please visit our website and click
“Online Store” from the top menu.
replaCemenT parTs
aVaIlable OnlIne
WWW.loUiSVilleladder.coM
Holds 7 ladders
Accessory tray
Easy to assemble
3.83’ x 2.16’ footprint
Ladders and accessories not included.
Promote your customer’s name with the LogoLock™ system
Deter theft by displaying your logo
Customize the image of your ladders
Long-lasting image embedded into the berglass rail
LogoLock™ Patent #7,095,428
YOUR COMPANY
LOGO HERE!
51
EXTENSION LADDER ACCESSORIES
For availability, please contact Customer Service. Please specify ladder size and ladder model. To order factory-mount accessories, add the
3-digit accessory number and size. (EXAMPLE: FE3220-E05, 20’ Fiberglass Extension with Web Pole Grip)
acceSSorY #e03
COMBINATION POLE
GRIP & CABLE HOOK
acceSSorY #e04
RIGID POLE GRIP
acceSSorY #e05
WEB POLE GRIP
acceSSorY #e11
LADDER LASH
acceSSorY #e30
WHEEL SPURS
acceSSorY #e34
AUTO. ADJUSTING
LEVELER
(FACTORY MOUNT)
acceSSorY #091006c
AUTO. ADJUSTING
LEVELER
(FIELD MOUNT)
acceSSorY #e38
COMBINATION
SPUR & SHOE
acceSSorY #e55
FRONT-MOUNTED
PULLEY
Model #fe979
PROGRIP™ ACCESSORY
Model #lP-2200-00
LADDER
STABILIZER
Model #lP-2210-00
ADJUSTABLE
STABILIZER
Model #lP-5510-00
PRO-GUARDS™
Model #lP-2100-23
LADDER JACK
SHORT BODY
Model #lP-2100-13
LADDER JACK
LONG BODY
Model #lP-2300-00
LADDER LEVELER
Model #lP-2220-01
KEYLOK
®
QUICK
CONNECT
SYSTEM
fe3200
fe7000
fe1700
fe0600
fe4000hd
ae1200hd
ae2800
ae2000
ae1660
ae3200
ae4000
neW!
neW deSiGn!
52
eXTeNsioN ladders FIBERGLASS & ALUMINUM
PAIL SHELF (CERTAIN MODELS)
MODEL #LP-2400-00 (UNIVERSAL) (APPROX. WT. 1.5 LBS)
FITS ALL LOUISVILLE / DAVIDSON BRAND STEPLADDERS.
DETAILED INSTRUCTIONS AND SUPPLIED HARDWARE
MAKE INSTALLATION EASY.
STEPLADDER
ACCESSORY
WEB POLE GRIP (FIBERGLASS ONLY, 16‘-40‘)
FACTORY: E05
FIELD: PK-E05R (APPROX. WT. 0.7 LBS)
Made of exible high strength nylon webbing with a
5” section of corrugated rubber tread. Helps to hold top of ladder
against poles, pipes or corners.
LADDER LASH (FIBERGLASS ONLY, 16‘-40‘)
FACTORY: E11
FIELD: PK-E11R (APPROX. WT. 1.1 LBS)
Lash for wrapping around objects up to 17” in diameter.
Made of 2” Dacron webbing with forged steel snaps and a
quick adjustment with clip.
WHEEL SPURS (FIBERGLASS ONLY, 16‘-28‘)
FACTORY: E30
FIELD: PK-E30A (APPROX. WT. 0.9 LBS)
Wheel spurs are available as an alternative to our
standard cast swivel safety shoe.
AUTOMATIC-ADJUSTING LEVELER
FACTORY: E34
FIELD: PR091006C (APPROX. WT. 6.3 LBS)
Leveler keeps ladder stabilized in perpendicular position
on uneven terrain. Adjustable up to a 9” height differential.
COMBINATION SPUR & SHOE (FIBERGLASS ONLY)
FACTORY ONLY: E38
This accessory allows the use of either a spur or a shoe
with thick rubber tread.
FRONT-MOUNTED PULLEY (FIBERGLASS ONLY)
FACTORY ONLY: E55
Large diameter pulley sheave assembly mounted
between slide guides allows y section to be extended
and lowered from front side of ladder.
LADDER STABILIZER
MODEL #LP-2200-00 (APPROX. WT. 6 LBS)
Fits extension and single ladders with rail up to 4” x
1 ¾”. Holds ladder 12” from wall and spans 48” to
clear most windows. Stabilizers attach with 2 U-bolts and feature
replaceable extra heavy duty rubber tips.
ADJUSTABLE STABILIZER
MODEL #LP-2210-00 (APPROX. WT. 6 LBS)
Fits extension and single ladders with rail up to 4” x 1
¾”. Aluminum bracket with vertical adjustments hold
ladder from 13” to 25” from wall and spans 48” to clear most
windows. Stabilizers attach with 2 U-bolts and feature replaceable
extra heavy duty rubber tips.
LADDER JACK (SHORT BODY)
MODEL #LP-2100-23 (APPROX. WT. 14 LBS)
Short body ladder jacks (1 pair) span 2 extension
ladder rungs. Holds stages and planks up to 20”
wide, features six pitch adjustments and folds for easy storage.
Manufactured for use with Type IAA, IA, and I berglass and
aluminum extension ladders.
LADDER JACK (LONG BODY)
MODEL #LP-2100-13 (APPROX. WT. 16 LBS)
Long body ladder jacks (1 pair) span 3 extension
ladder rungs. Holds stages and planks up to 20”
wide, features six pitch adjustments and folds for easy storage.
Manufactured for use with Type IAA, IA, and I berglass and
aluminum extension ladders.
LADDER LEVELER
MODEL #LP-2300-00 (APPROX. WT. 8 LBS)
Ideal for using on extension or straight ladders on
uneven surfaces. Attaches easily to Type IAA, IA, I, and II
berglass and aluminum extension or single ladders. Features plated
steel construction and a safety guard to protect from accidental
release. The ladder leveler has a maximum differential of 15”.
KEYLOK® QUICK CONNECT SYSTEM
LOUISVILLE LADDER LEVELER BY LEVELOK®
MODEL #LP-2220-01 (APPROX. WT. 8 LBS)
The LeveLok® is one of the easiest to use ladder levelers
in the market. It can be installed on almost any berglass or
aluminum extension ladder, and can be operated using only your
foot - freeing your hands to hold the ladder.
RIGID POLE GRIP (FIBERGLASS ONLY)
FACTORY: E04
FIELD: PK-E04A (16‘-28‘) (APPROX. WT. 1.9 LBS)
3/16” x 1” plated steel bar formed into a “V” shape and covered
with heavy rubber tread makes an ideal pole grip and can be added
to ladders already in service.
PK-E04B (32‘-40‘) (APPROX. WT. 1.7 LBS)
COMBINATION POLE GRIP &
CABLE HOOK (FIBERGLASS ONLY)
FACTORY: E03
FIELD: PK-E03A (16‘-28‘) (APPROX. WT. 3 LBS)
A rigid plated steel V-shaped pole grip covered with rubber tread,
combined with cable hook assembly.
PK-E03B (32‘-40‘) (APPROX. WT. 3 LBS)
PRO-GUARDS™
MODEL #LP-5510-00 (APPROX. WT. 1.4 LBS)
Pro-Guards™ t most berglass and aluminum
extension and single ladders. Protect your work
surface with Pro-Guards™. Patent #6,499,563 B1
PROGRIP™ ACCESSORY
FIELD ONLY: FE979 (1 pair)
Slip-resistant design that easily replace your ladder’s
current endcaps. They protect the support surface from
damage while including easy-carry hand grips.
neW!
53
53
THE C.L.I.M.B. ACADEMY® SAFETY TRAINING
PROGRAM FROM LOUISVILLE LADDER, INC.
Order kits or replacement handbooks online at WWW.LOUISVILLELADDER.COM
Train online at WWW.CLIMBACADEMY.COM
The C.L.I.M.B. Academy® includes a video, C.L.I.M.B. teaches you to CHOOSE the right equipment,
LOOK for damage or missing parts, INSURE a safe setup, and MOVE safely always using 3 points of
contact. We encourage everyone to BE a climbing equipment safety expert, not a statistic!
Louisville’s NEW C.L.I.M.B. Academy® teaches fundamental principles when using:
Step and Extension Ladders • Rolling Warehouse Ladders • Rolling Tower Scaffolding
C.L.I.M.B. ACADEMY®
Louisville Ladder, Inc. is herein referred to as the “Seller” and the customer or person or entity purchasing goods (“Goods”)
from Seller is referred to as the “Buyer”. These Terms and Conditions, any quotation or acknowledgment from Seller relevant
to the sale of the Goods and all documents incorporated by specic reference therein, constitute the complete and exclusive
statement of the terms of the agreement governing the sale of Goods by Seller to Buyer. Any other language proposed by
Buyer, including Buyer’s Purchase Order language shall not control over these Terms. Buyer’s acceptance of the Goods will
manifest Buyer’s assent to these Terms and Conditions.
1. PriceS: All prices are exclusive of taxes, transportation and insurance, which are to be borne by Buyer.
2. taXeS: Any tax or governmental charge affecting Seller’s costs of production, sale, or delivery shall be for Buyer’s
account and shall be added to the price.
3. terMS of PaYMent: Unless otherwise specied by Seller, terms are 1% ten (10), net thirty (30) days from date of
Seller’s invoice in U.S. currency. Seller shall have the right, among other remedies, either to terminate this agreement or to
suspend further performance under this and/or other agreements with Buyer in the event Buyer fails to make any payment
when due. Buyer shall be liable for all expenses, including attorneys’ fees, relating to the collection of past due amounts.
Should Buyer’s nancial responsibility become unsatisfactory to Seller, cash payments or security satisfactory to Seller may
be required by Seller for future deliveries and for the Goods theretofore delivered.
4. freiGht PolicY: Freight prepaid on shipments to one destination within the continental U.S. that total 1000 pounds
or more of berglass and/or aluminum products or 1000 pounds of any combination including wood and steel.
5. ShiPMent and deliVerY: Deliveries are made F.O.B. Seller’s shipping point. Risk of loss or damage and responsibility
shall pass from Seller to Buyer upon delivery. Any claims for shortages or damages suffered in transit shall be submitted
by the Buyer directly to the carrier. While Seller will use all reasonable commercial efforts to maintain the delivery date(s)
acknowledged or quoted by Seller, all shipping dates are approximate and not guaranteed. Seller reserves the right to make
partial shipments. Seller, at its option, shall not be bound to tender delivery of any Goods for which Buyer has not provided
shipping instructions. If the shipment of the Goods is postponed or delayed by Buyer for any reason, Buyer agrees to
reimburse Seller for any and all storage costs and other additional expenses resulting therefrom.
6. liMited WarrantY: Subject to the limitations of Section 7, Seller warrants that the Goods manufactured by Seller
will be free from defects in material and under normal use and regular service and maintenance for a period of one year
from the date of shipment of the Goods by Seller, unless otherwise specied by Seller in writing. THIS IS THE SOLE AND
EXCLUSIVE WARRANTY GIVEN BY SELLER WITH RESPECT TO THE GOODS AND IS IN LIEU OF AND EXCLUDES ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, ARISING BY OPERATION OF LAW OR OTHERWISE, INCLUDING WITHOUT LIMITATION,
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE WHETHER OR NOT THE PURPOSE OR USE HAS BEEN
DISCLOSED TO SELLER IN SPECIFICATIONS, DRAWINGS OR OTHERWISE, AND WHETHER OR NOT SELLER’S PRODUCTS ARE
SPECIFICALLY DESIGNED AND/OR MANUFACTURED BY SELLER FOR BUYER’S USE OR PURPOSE. This warranty does not extend
to any losses or damages due to misuse, accident, abuse, neglect, normal wear and tear, Buyer’s negligence, unauthorized
modication or alteration, use beyond rated capacity, or improper installation, maintenance or application. To the extent that
Seller has relied upon any specications, information, representation of operating conditions or other data supplied by Buyer
or its agents to Seller in the selection or design of the Goods and the preparation of Seller’s quotation, and in the event that
actual operating conditions or other conditions differ from those represented by Buyer and relied upon by Seller, any warranties
or other provisions contained herein which are affected by such conditions shall be null and void. If within thirty (30) days after
Buyer’s discovery of any warranty defects within the warranty period, Buyer noties Seller thereof in writing, Seller shall, at its
option, repair, correct or replace F.O.B. point of manufacture, that portion of the Goods found by Seller to be defective. Failure by
Buyer to give such written notice within the applicable time period shall be deemed an absolute and unconditional waiver of
Buyer’s claim for such defects. Goods repaired or replaced during the warranty period shall be covered by the foregoing warranty
for the remainder of the original warranty period or ninety (90) days, whichever is longer. Buyer assumes all other responsibility
for any loss, damage, or injury to persons or property arising out of, connected with, or resulting from the use of Goods, either
alone or in combination with other products/components.
terMS and conditionS of Sale
7. liMitation of reMedY and liaBilitY: THE SOLE AND EXCLUSIVE REMEDY FOR BREACH OF ANY WARRANTY
HEREUNDER (OTHER THAN THE WARRANTY PROVIDED UNDER SECTION 7) SHALL BE LIMITED, AT SELLER’S OPTION, TO
REPAIR, CORRECTION OR REPLACEMENT UNDER SECTION 5. SELLER SHALL NOT BE LIABLE FOR DAMAGES CAUSED BY
DELAY IN PERFORMANCE AND IN NO EVENT, REGARDLESS OF THE FORM OF THE CLAIM OR CAUSE OF ACTION (WHETHER
BASED IN CONTRACT, INFRINGEMENT, NEGLIGENCE, STRICT LIABILITY, OTHER TORT OR OTHERWISE), SHALL SELLER’S
LIABILITY TO BUYER AND/OR ITS CUSTOMERS EXCEED THE PRICE PAID BY BUYER FOR THE SPECIFIC GOODS PROVIDED BY
SELLER GIVING RISE TO THE CLAIM OR CAUSE OF ACTION. BUYER AGREES THAT IN NO EVENT SHALL SELLER’S LIABILITY
TO BUYER AND/OR ITS CUSTOMERS EXTEND TO INCLUDE INCIDENTAL, CONSEQUENTIAL OR PUNITIVE DAMAGES. The term
“consequential damages” shall include, but not be limited to, loss of anticipated prots, business interruption, loss of use
or revenue, cost of capital or loss or damage to property or equipment. It is expressly understood that any technical advice
furnished by Seller with respect to the use of the Goods is given without charge, and Seller assumes no obligation or liability
for the advice given, or results obtained, all such advice being given and accepted at Buyer’s risk.
8. PatentS and coPYriGhtS: Subject to the limitations of the second paragraph of Section 6, Seller warrants that the
Goods sold, except as are made specically for Buyer according to Buyer’s specications, do not infringe any valid U.S. patent
or copyright in existence as of the date of shipment. This warranty is given upon the condition that Buyer promptly notify
Seller of any claim or suit involving Buyer in which such infringement is alleged, and, that Buyer cooperate fully with Seller
and permit Seller to control completely the defense, settlement or compromise of any such allegation of infringement. Seller’s
warranty as to use only applies to infringements arising solely out of the inherent operation of such Goods. In the event such
Goods are held to infringe such a U.S. patent or copyright in such suit, and the use of such Goods is enjoined, or in the case
of a compromise or settlement by Seller, Seller shall have the right, at its option and expense, to procure for Buyer the right to
continue using such Goods, or replace them with non-infringing Goods, or modify same to become non-infringing, or grant
Buyer a credit for the depreciated value of such Goods and accept return of them.
9. eXcUSe of PerforMance: Seller shall not be liable for delays in performance or for non-performance due to acts
of God; acts of Buyer; war; re; ood; weather; sabotage; strikes, or labor or civil disturbances; governmental requests,
restrictions, laws, regulations, orders or actions; unavailability of or delays in transportation; default of suppliers; or unforeseen
circumstances or any events or causes beyond Seller’s reasonable control. Deliveries or other performance may be suspended
for an appropriate period of time or canceled by Seller upon notice to Buyer in the event of any of the foregoing, but the balance
of the agreement shall otherwise remain unaffected as a result of the foregoing. If Seller determines that its ability to supply the
total demand for the Goods, or to obtain material used directly or indirectly in the manufacture of the Goods, is hindered, limited
or made impracticable due to causes set forth in the preceding paragraph, Seller may allocate its available supply of the Goods
or such material (without obligation to acquire other supplies of any such Goods or material) among its purchasers on such basis
as Seller determines to be equitable without liability for any failure of performance which may result therefrom. Seller reserves
the right to change designs and specications for the Goods without prior notice to Buyer, except with respect to Goods being
made-to-order for Buyer.
10. aSSiGnMent: Buyer shall not assign its rights or delegate its duties hereunder or any interest therein or any rights
hereunder without the prior written consent of the Seller, and any such assignment, without such consent, shall be void.
11. General ProViSionS: These terms and conditions supersede all other communications, negotiations and prior
oral or written statements regarding the subject matter of these terms and conditions. No change, modication, rescission,
discharge, abandonment, or waiver of these terms and conditions shall be binding upon the Seller unless made in writing
and signed on its behalf by a duly authorized representative of the Seller. No conditions, usage or trade, course of dealing
or performance, understanding or agreement purporting to modify, vary, explain, or supplement these terms and conditions
shall be binding unless hereafter made in writing and signed by the party to be bound, and no modication shall be
affected by the Seller’s receipt, acknowledgment, or acceptance of purchase orders, shipping instruction forms, or other
documentation containing terms at variance with or in addition to those set forth herein. No waiver by either party with
respect to any breach or default or of any right or remedy and no course of dealing, shall be deemed to constitute a
continuing waiver of any other breach or default or of any other right or remedy, unless such waiver be expressed in writing
and signed by the party to be bound. All typographical or clerical errors made by Seller in any quotation, acknowledgment
or publication are subject to correction. The validity, performance, and all other matters relating to the interpretation and
effect of this agreement shall be governed by the law of the state of Kentucky. Buyer and Seller agree that the proper venue
for all actions arising in connection herewith shall be only in the State where the Goods involved in such actions were
manufactured and the parties agree to submit to such jurisdiction.
C.L.I.M.B. ACADEMY® SAFETY TRAINING PROGRAM includes
• Combined Facilitator & Student Handbook
• DVD
• Editable C.L.I.M.B. Certicate PDF
• Other bonus materials accessible via PC/MAC
neW VerSion!
NOW ONLINE!
54
WAREHOUSE LOCATIONS
COMPANY HEADQUARTERS
& WAREHOUSE
7765 National Turnpike, Unit 190
Louisville, KY 40214
Tel: (502)-636-2811
(800)-666-2811
U.S. & CAN
Fax: (800)-274-4566
ATLANTA
REGIONAL WAREHOUSE
2689A Mountain Industrial Blvd.
Tucker, GA 30084
Tel: (770)-491-1515
(800)-241-9051
Fax: (770)-723-7681
BENSENVILLE
REGIONAL WAREHOUSE
644 Supreme Drive
Bensenville, IL 60106
Tel: (630) 238 2005
Fax: (630) 238 2006
DALLAS
REGIONAL WAREHOUSE
801 Heinz Way
Grand Prairie, TX 75051
Tel: (972)-602-4400
(800)-625-5742
Fax: (972)-602-4410
DENVER
REGIONAL WAREHOUSE
5160 Fox Street
Denver, CO 80216
Tel: (303)-455-8175
Fax: (303)-477-6504
LOS ANGELES
REGIONAL WAREHOUSE
10013 E. 8th Street Suite R
Rancho Cucamonga, CA 91730
Tel: (909) 941 0623
(800)-625-1408
Fax: (909) 941 0967
PEORIA
REGIONAL WAREHOUSE
7921 N. Hale Ave.
Peoria, IL 61615
Tel: (309)-692-1895
Fax: (309)-692-2161
PHILADELPHIA
REGIONAL WAREHOUSE
855 Dunks Ferry Road
Bensalem, PA 19020
Tel: (215)-638-8904
(800)-447-4785
Fax: (215)-638-2581
(800)-283-2388
PHOENIX
REGIONAL WAREHOUSE
2920 E. Elwood Street
Phoenix, AZ 85040
Tel: (602)-268-7008
Fax: (602)-268-7125
SALT LAKE CITY
REGIONAL WAREHOUSE
1355 South 700 West
Salt Lake City, Utah 84104
Tel: (801)-972-7056
Fax: (801)-972-3560
SAN FRANCISCO
REGIONAL WAREHOUSE
41652 Boscell Road
Fremont, CA 94538
Tel: (510)-344-4231
SEATTLE
REGIONAL WAREHOUSE
920 S. Doris Street
Seattle, WA 98108
Tel: (206)-762-4888
Fax: (206)-767-4386
VALDOSTA
REGIONAL WAREHOUSE
1617 James P. Rodgers Drive
Valdosta, GA 31601
Tel: (229)-245-0669
Fax: (229)-245-0659
VANCOUVER
REGIONAL WAREHOUSE
7509 North East 47th Ave.
Vancouver, WA 98661
Tel: (360)-816-0434
Fax: (360)-816-0437
NH
MA
RI
CT
NJ
DE
MD
WA
OR
CA
UT
AZ
NM
TX
CO
WY
MT
ID
NV
ND
NE
KS
OK
MN
IA
MO
AR
LA
MS AL
TN
GA
FL
SC
NC
VA
OH
IN
IL
WI
PA
NY
VT
ME
WV
SD
KY
55
Louisville Ladder Inc.
7765 National Turnpike, Unit 190 | Louisville, KY 40214
1-(800)-666-2811 (U.S. & CANADA) | 1-(502)-636-2811 | FAX: 1-(800)-274-4566
www.louisvilleladder.com Revised - October 2011 ©2011 Louisville Ladder Printed in U.S.A. 11/11
