2calbrite.com
Food and Beverage
Our stainless steel conduit, fittings, and applicable
accessories are ideal for food and beverage
processing applications due to stainless steel’s ability
to stand up to the often acidic content of wash-down
chemicals commonly used in these environments.
Cleaning agents and chemical disinfectants can
quickly corrode other equipment, promoting bacterial
growth and enabling food contamination. Stainless
steel is a safer, more hygienic choice in these
applications as it provides resistance to pitting and
stress corrosion cracking, and is easily sterilized to
prevent bacteria growth.
• There are typically three constants and
requirements when working with food or beverage
processing work stations and equipment:
extremely easy to clean, corrosion and damage
resistance, and easy to sanitize. Cleanliness and
hygiene are critical in these environments, and
stainless steel has proven to have a wide range
of preferred qualities in comparison to traditional
conduit systems used, such as galvanized,
aluminum and PVC Coated.
• The smooth, polished surface of Calbrite’s
stainless conduit and fittings not only promote
cleanliness, but also greatly reduce the risk of
corrosion.
Headquartered in Hammond, IN, Calbrite™
is the leading name in stainless steel conduit
systems for harsh and corrosive environments.
We provide the largest stainless steel conduit
systems offering in the industry, with over 2,800
SKUs manufactured to strict guidelines set forth
by UL and NEMA. Many of our products are
ARRA-compliant.
Calbrite supports its customers throughout the
U.S. and Canada from three manufacturing
and distribution centers in the U.S. Calbrite is
committed to providing quality products with
the shortest lead times, combined with friendly,
personal, and reliable service. If you have a
need for a unique product, or need a product
converted to stainless steel, we can work with
you to develop custom products quickly and at a
competitive price.
Our quality assurance program complies with
industry standards established by Underwriters
Laboratories (UL), ANSI, and NEMA.
UL listings:
• Approval file number for stainless rigid
conduit, nipples, elbows and couplings is
E230584 (ANSI / UL 6A & CUL 6A)
• Approval file number for stainless conduit
bodies and device boxes is E307133
(ANSI / UL 514A & CUL 514A)
• Approval file number for stainless steel
locknuts is E308159 (ANSI / UL 514B &
CUL 514B)
Many of our products are produced to NEMA
4X standards, which ensures protection against
corrosion, wind-blown dust and rain, splashing
water, hose-directed water and damage from
external ice formation in outdoor or indoor
environments.
The Leader in Stainless Steel Conduit
Broadest Selection.
Better Response.
Best Performance.
The durability, cost-effectiveness, and design
flexibility makes Calbrite's stainless steel the
preferred choice for a range of applications and
industries.
Stainless steel resists corrosion in aqueous, gaseous
and high-temperature environments, maintains its
mechanical properties in all temperatures and its
long-term value attribute allows for substantial cost
savings. In these applications, use of acidic, toxic
and flammable chemical combinations can rapidly
deteriorate traditional conduit systems.
Stainless steel’s corrosion-resistance, weld ability,
strength, ductility, fabrication versatility and
composition stability can significantly guard against
product contamination. It is also important that
the surfaces of the conduit and fittings are smooth,
easy to maintain and clean, to minimize microbial
contamination, reduce corrosion and prevent the
adherence of particulates to the surfaces of the
equipment and product.
Pharmaceutical,
Petrochemical, and
Chemical Industries
3
800-536-2248
Pulp & Paper
In pulp and paper applications, stainless steel is
used extensively because of its good mechanical
properties and its resistance to liquor used in the
process. These benefits will become even more of
a priority as pulp mills move into the realm of bio-
refineries.
Stainless steel’s properties prevent contamination
of the end product and are resistant to process
corrosion. Although the process is mostly standard
at all mills, there can be small mill-to-mill differences
that may affect levels of corrosion. Stainless steel
is able to withstand these differences in a stable,
uniform manner that makes it the most reliable
choice for these applications.
Some of the more common applications for stainless
steel conduit in the pulp and paper industry include:
• Batch and continuous digesters
• Brown stock washers
• Black liquor equipment and tanks and recovery
circuits
• Bleach plant
• Lime kiln (for high temperature properties)
• Air and water pollution control equipment
• Waste paper recycling
• Stock preparation equipment
• Paper machines including suction rolls
Water and Waste Water
In recent years, the use of stainless steel in water
and wastewater treatment plants (WWTP) has
grown significantly, as type 304 and 316 grades
are increasingly utilized as standard materials of
construction due to superior performance and cost-
saving factors. A WWTP is a complex, sophisticated
system with a high-level of standards for the entire
plant, including technical installations. The materials
needed to construct a WWTP must be able to
withstand the wide range of corrosive conditions.
For a clean, environmentally safe and cost-effective
plant, there is no better material than stainless
steel. Stainless steel will improve efficiency, reduce
maintenance, and in many cases, provide the most
cost-effective solution.
Systems for Harsh Environments
Power Plants, Energy
& Power Generation
Whether the form of energy production is nuclear,
fossil or renewable, safety, long-term value and effi-
ciency are the utmost concerns for energy and power
generation companies with the nuclear power indus-
try requiring absolute reliability. These characteristics
are provided by high quality stainless steel.
Stainless steel is now extensively used in the power
generation industry to combat corrosion, particularly
at elevated temperatures. In particular, type 304 &
316 stainless are used for high temperature, strength
and oxidation resistance in fossil fuelled power
plants.
The nuclear power industry also uses large quantities
of stainless, often specified for both power gen-
eration and radiation containment. Steam and gas
turbines also use stainless because of its corrosion-
resistant and heat-resistant qualities.
Architecture, Building
& Construction
Stainless steel is the foremost material choice in
building projects primarily for its aesthetic and
performance reasons. While the non-corrosive
material provides an impressive looking finish that
requires no maintenance as well as design flexibility,
the durability provides strength and is resistant to fire
and water damage, making it a practical choice for
public and industrial structures.
Benefits to this industry include:
• Corrosion resistance to a wide range of waters,
chemicals, such as Hydrogen Sulphide (H2S)
• A protective layer forms naturally on all stainless
steels because of the inclusion of chromium.
Even if damaged and oxygen is present, the
invisible passive layer self-heals and protects the
steel from corrosion, ensuring a long life
• Stainless steel is not harmful to people during its
production or use, recycling and ultimate disposal
• Good strength and ductility
• Ease of fabrication
• Lightweight and easy to transport
• Availability in a wide range of product forms
• Durability
• Fully recyclable
4
Stainless Steel in Harsh Environments
Non-corrosive. Durable. UL-approved.
Stainless steel is the highest quality, most durable, easiest
to install, UL-approved conduit material available. Corrosion
damages equipment, which results in downtime and
expensive maintenance and repairs. That’s why stainless
steel conduit systems, designed for harsh environments,
are the material of choice for a wide range of industries.
• Corrosion-resistance. Both 304 and 316 stainless
steel alloys provide excellent resistance to corrosives,
at extreme temperatures and in most industrial
environments. When scratched, stainless steel’s
exposed metal “self-heals”, oxidizing over the abrasion
to protect against further corrosion.
• Longevity. The durability of a stainless steel conduit
system, frequently in excess of 50 years, reduces the
need for costly maintenance or replacement needs,
providing long-term protection for your facility and
optimizing your equipment investment.
• Lowest total cost of ownership. For many applications,
stainless steel has the lowest maintenance cost and
the lowest total lifecycle cost of any other UL-approved
conduit material. This is due to the durability of stainless
steel. It will outlast other materials, require little, if any,
maintenance, and is easy to install (contractors only
need their standard tools).
• Environmentally-friendly. Stainless steel retains
structural and anti-corrosive properties in temperatures
ranging from cryogenic to hundreds of degrees
and does not burn and emit dangerous smoke and
carcinogens. Additionally, stainless steel is recyclable.
• Easy to install. Calbrite stainless steel conduit and
fittings do not require installers to use special tools or
labor-intensive procedures for installation, and stainless
is in full NEC compliance for all facilities.
The Calbrite Difference
Known for our custom machining and fabrication
capabilities and developing products that meet specific
customer requirements, we take pride in being able to
listen and understand our customers’ special requests
and quickly respond with solutions designed to meet
their needs. With manufacturing and distribution centers
in Indiana, California and Florida, we have established
a customer-centric product development process that
enables us to react and respond to custom requirements
with the shortest lead times in the industry.
If you don’t find the exact part you are looking for in our
product catalog, call us (800-536-2248) and we’ll develop a
special solution for you…fast.
calbrite.com
5
STAINLESS STEEL CONDUIT, ELBOWS AND NIPPLES
Rigid Conduit....................................6
Nipples ........................................6
IMC ...........................................7
EMT Conduit ....................................7
Rigid Elbows ....................................8
EMT Elbows.....................................8
STAINLESS STEEL CONDUIT FITTINGS
Compression Fittings..............................9
EMT Compression Fittings .........................9
EMT Set Screw Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Flex Conduit ...................................10
Flexible Connectors ..............................10
3-Piece Couplings ...............................11
Couplings .....................................11
Grounding Hubs.................................11
Line Terminator Hubs.............................11
Conduit Bodies – Form 8 Style......................12
C & X Conduit Bodies - Form 8 Style .................13
CALSTRUT™ STAINLESS STEEL STRUT
Slotted Strut ...................................13
Solid Strut .....................................13
Back-to-Back Strut ..............................13
Post Base for Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Food Grade Channel .............................13
STAINLESS STEEL STRUT ACCESSORIES
4-Hole Flat Angle Plate .......................... 14
4-Hole Splice Plate ..............................14
3-Hole Flat Angle Plate ...........................14
Cross Plate ....................................14
Tee Plate .....................................14
4-Hole Angle Bracket ............................14
2-Hole Angle Bracket ............................14
Saddle Washers ................................14
Channel Nuts with Spring .........................14
U-Fitting ......................................14
Wall Spacers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
L-Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Hanger Rod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
STAINLESS STEEL CORD GRIP CONNECTORS
Cord Grip Connectors.............................15
Cord Grip Connectors with Mesh ....................16
STAINLESS STEEL DEVICE BOXES
FS Single Gang Box ..............................17
FDC Single Gang Box.............................17
FDCC & FSCC Single Gang Boxes....................17
FSCT & FDCT Single Gang Boxes....................17
FD Single Gang Box..............................17
FDC Double Gang Box ............................17
FDX & FSX Single Gang Boxes ......................17
In-Use Boxes ...................................17
Device Box Covers...............................17
Device Box Plates ...............................17
STAINLESS STEEL ACCESSORIES
Locknuts ......................................18
Standard Washers ...............................18
Lock Washers ..................................18
Fender Washers.................................18
Grounding Locknuts..............................18
Hex Nuts ......................................18
Square Washers ................................18
Threaded Rod ..................................18
Hex Head Cap Screws ............................18
Slotted Machine Screws ..........................18
Split Ring Clamps ...............................19
Split Ring Extensions .............................19
Split Ring Mounting Plates.........................19
Clamp Back Spacers .............................19
Right Angle Clamps ..............................19
Beam Clamps ..................................19
Parallel Clamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Clamp Backs ...................................19
Right Angle Beam Clamps .........................19
Strut Clamps ...................................19
2-Hole Straps ..................................20
1-Hole Straps ..................................20
Conduit Hangers ................................20
MISCELLANEOUS
Counter Sunk Hex Plugs ..........................20
Box Connectors .................................20
Threaded Conduit Caps ...........................21
Face Bushings..................................21
Pulling Elbows..................................21
Rod Couplings ..................................21
Wedge Anchors .................................21
Conduit Body Cover, Gasket & Screw Sets .............21
Drop-In Anchors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
U-Bolts .......................................21
Cut Sheet Sample ...............................22
Notes ........................................23
Table Of Contents
800-536-2248
6
STAINLESS STEEL RIGID CONDUIT
Diameters 10’ Length w/ Coupling 5’ Length w/ Coupling
Trade Size Metric Size OD ID Wt./Ft. Type 304 Type 316 Type 304 Type 316
½" 16 0.840” 0.622” 0.82 S40510CT00 S60510CT00 S40505CT00 S60505CT00
¾" 21 1.050” 0.824” 1.09 S40710CT00 S60710CT00 S40705CT00 S60705CT00
1" 27 1.315” 1.049” 1.61 S41010CT00 S61010CT00 S41005CT00 S61005CT00
1-¼" 35 1.660” 1.380” 2.18 S41210CT00 S61210CT00 S41205CT00 S61205CT00
1-½" 41 1.900” 1.610” 2.63 S41510CT00 S61510CT00 S41505CT00 S61505CT00
2" 53 2.375” 2.067” 3.50 S42010CT00 S62010CT00 S42005CT00 S62005CT00
2-½" 63 2.875” 2.469” 5.59 S42510CT00 S62510CT00 S42505CT00 S62505CT00
3" 78 3.500” 3.068” 7.27 S43010CT00 S63010CT00 S43005CT00 S63005CT00
4” 103 4.500” 4.026” 10.08 S44010CT00 S64010CT00 S44005CT00 S64005CT00
5” 129 5.563" 5.073" 14.61 S45010CT00 S65010CT00 S45005CT00 S65005CT00
6” 155 6.625 6.093" 18.97 S46010CT00 S66010CT00 S46005CT00 S66005CT00
STAINLESS STEEL RIGID NIPPLES Custom lengths available upon request
Type 304 SS
Trade Size Close 1-½” 2” 2-½” 3” 3-½” 4” 5” 6”
½” S405CLCN00 S40515CN00 S40520CN00 S40525CN00 S40530CN00 S40535CN00 S40540CN00 S40550CN00 S40560CN00
¾” S407CLCN00 S40715CN00 S40720CN00 S40725CN00 S40730CN00 S40735CN00 S40740CN00 S40750CN00 S40760CN00
1” S410CLCN00 S41020CN00 S41025CN00 S41030CN00 S41035CN00 S41040CN00 S41050CN00 S41060CN00
1-¼” S412CLCN00 S41220CN00 S41225CN00 S41230CN00 S41235CN00 S41240CN00 S41250CN00 S41260CN00
1-½” S415CLCN00 S41520CN00 S41525CN00 S41530CN00 S41535CN00 S41540CN00 S41550CN00 S41560CN00
2” S420CLCN00 S42035CN00 S42040CN00 S42050CN00 S42060CN00
2-½” S425CLCN00 S42550CN00 S42560CN00
3” S430CLCN00 S43050CN00 S43060CN00
4” S440CLCN00 S44050CN00 S44060CN00
Type 316 SS
Trade Size Close 1-½” 2” 2-½” 3” 3-½” 4” 5” 6”
½” S605CLCN00 S60515CN00 S60520CN00 S60525CN00 S60530CN00 S60535CN00 S60540CN00 S60550CN00 S60560CN00
¾” S607CLCN00 S60715CN00 S60720CN00 S60725CN00 S60730CN00 S60735CN00 S60740CN00 S60750CN00 S60760CN00
1” S610CLCN00 S61020CN00 S61025CN00 S61030CN00 S61035CN00 S61040CN00 S61050CN00 S61060CN00
1-¼” S612CLCN00 S61220CN00 S61225CN00 S61230CN00 S61235CN00 S61240CN00 S61250CN00 S61260CN00
1-½” S615CLCN00 S61520CN00 S61525CN00 S61530CN00 S61535CN00 S61540CN00 S61550CN00 S61560CN00
2” S620CLCN00 S62030CN00 S62035CN00 S62040CN00 S62050CN00 S62060CN00
2-½” S625CLCN00 S62550CN00 S62560CN00
3” S630CLCN00 S63050CN00 S63060CN00
4” S640CLCN00 S64050CN00 S64060CN00
“OD”
Outside Diameter
ID”
Inside Diameter
LENGTH
CalbriteTM stainless steel rigid conduit is manufactured in type 304 & 316 stainless to meet stringent sanitary requirements and withstand harsh corrosive environments. The conduit is polished to
a bright, easily maintainable finish that allows for minimal cleaning, enhances the appearance, and improves the surface’s resistance to pitting & bacterial corrosion in CIP (clean-in-place) and SIP
(sterilize-in-place) systems.
Calbrite stainless steel rigid conduit is highly resistant to damage from impact. Easy to cut, form and join, stainless steel conduit avoids the labor-intensive procedures that come with PVC-coated
installation. No special tools or complicated maintenance and repair procedures are required. In addition to the ease of installation and maintenance, stainless steel is 100% recyclable. Standard rigid
conduit threads allow for trouble-free installations.
* Trade sizes ½” to 6”
* Includes one coupling with each length purchased
* Custom lengths and diameters are available
* Conduit is domestically manufactured in our U.S. manufacturing facilities
Compliances: Underwriter Laboratories Listed for
US and Canada standard UL6A File # E230584
American National Standards Institute (ANSI) specification C80.1
STAINLESS STEEL CONDUIT & NIPPLES
* Consult factory for 5" & 6" Conduit Nipple info.
7
STAINLESS STEEL IMC
Threaded IMC
Trade Size Metric Size Outside Dia. Inside Dia. Wt./Ft. Type 304 Type 316
½" 16 0.815" 0.660" 0.62 S50510CTWT S70510CTWT
¾" 21 1.029" 0.864" 0.84 S50710CTWT S70710CTWT
1" 27 1.290" 1.120" 1.19 S51010CTWT S71010CTWT
1-½" 41 1.883" 1.703" 1.94 S51510CTWT S71510CTWT
2" 53 2.360" 2.170" 2.56 S52010CTWT S72010CTWT
Stainless steel IMC is often specified in corrosive environments where it's subject to harsh chemical treatments or wash-downs
due to its lighter weight, precise tolerances, and ease of installation.
Stainless IMC is more impact resistant compared to stainless EMT, and is 100% recyclable.
Calbrite's IMC is manufactured with or without threads. The non-threaded conduit is joined together by utilzing compression
fittings, and the threaded conduit can be used with standard threaded couplings, allowing for lowered costs and simplified
installations.
* Custom lengths available
* Trade sizes ½”, ¾”, 1”, 1-½", 2”
Compliances: Manufactured to the highest standards of the
American National Standards Institute (ANSI) and Underwriters Laboratories (UL).
“OD”
Outside Diameter
ID”
Inside Diameter
LENGTH
STAINLESS STEEL EMT CONDUIT
EMT Conduit
Diameters 10’ Length 5’ Length
Trade Size O.D. I.D. Wt./Ft. Type 304 Type 316 Type 304 Type 316
½" 0.706” 0.622” 0.30 S10510CT00 S20510CT00 S10505CT00 S20505CT00
¾" 0.922” 0.824” 0.46 S10710CT00 S20710CT00 S10705CT00 S20705CT00
1" 1.163” 1.050” 0.67 S11010CT00 S21010CT00 S11005CT00 S21005CT00
1-¼" 1.510” 1.380” 1.01 S11210CT00 S21210CT00 S11205CT00 S21205CT00
1-½" 1.740” 1.610” 1.16 S11510CT00 S21510CT00 S11505CT00 S21505CT00
2" 2.200” 2.067” 1.48 S12010CT00 S22010CT00 S12005CT00 S22005CT00
Calbrite's stainless steel EMT conduit and fittings combine strength with ductility, resulting in a lightweight and easy-to-handle conduit assembly.
EMT can be installed indoors and outdoors in accordance with NEC®, providing it will not be subject to severe physical damage during and after
installation.
Calbrite's stainless steel EMT provides superior performance in applications subject to corrosive environments, harsh chemical treatments, and
required wash-downs. In addition to the ease of installation and maintenance, stainless steel is 100% recyclable. Calbrite EMT enhances the ap-
pearance and the surface’s resistance to pitting & bacterial corrosion in CIP (clean-in-place) and SIP (sterilize-in-place) systems.
* Trade sizes ½” – 2”
* Conduit is domestically manufactured in our U.S. manufacturing facilities
* Calbrite stainless steel EMT is manufactured to UL797 standards and meets ANSI C80.3
“OD”
Outside Diameter
ID”
Inside Diameter
LENGTH
STAINLESS STEEL IMC & EMT CONDUIT
Non-Threaded IMC
Trade Size Metric Size Outside Dia. Inside Dia. Wt./Ft. Type 304 Type 316
1/2" 16 0.815" 0.660" 0.62 S50510CT00 S70510CT00
3/4" 21 1.029" 0.864" 0.84 S50710CT00 S70710CT00
1" 27 1.290" 1.120" 1.19 S51010CT00 S71010CT00
1-1/2" 41 1.883" 1.703" 1.94 S51510CT00 S71510CT00
2" 53 2.360" 2.170" 2.56 S52010CT00 S72010CT00
8
*Large radius rigid stainless elbows are available upon request in 24”, 36”, 48” and 60”
*Consult factory for 5” & 6” Conduit Elbow info.
*IMC elbows are also available upon request
*Contact factory for 1-1/4" - 2" EMT Elbow info.
STAINLESS STEEL ELBOWS
STAINLESS STEEL RIGID ELBOWS (Type 304 & 316)
Standard Radius Elbows 90º
Part # Part #
Trade Size Metric Size Outside Dia. Inside Dia. ABType 304
Part Number
Type 316
Part Number
½" 16 0.840" 0.622” 3.79" 4.00" S40590EL00 S60590EL00
¾" 21 1.050" 0.824” 3.94" 4.50" S40790EL00 S60790EL00
1" 27 1.315" 1.049” 5.05" 5.75" S41090EL00 S61090EL00
1-¼" 35 1.660" 1.380” 6.38" 7.25" S41290EL00 S61290EL00
1-½" 41 1.900" 1.610” 7.26" 8.25" S41590EL00 S61590EL00
2" 53 2.375" 2.067” 8.27" 9.50" S42090EL00 S62090EL00
2-½" 63 2.875" 2.469” 9.02" 10.50" S42590EL00 S62590EL00
3" 78 3.500" 3.068” 11.21" 13.00" S43090EL00 S63090EL00
4" 103 4.500" 4.026” 13.71" 16.00" S44090EL00 S64090EL00
STAINLESS STEEL EMT ELBOWS
Standard Radius Elbows 90º
Trade Size Outside Dia. Inside Dia. Min. Radius Straight Leg Each End Type 304
Part Number
Type 316
Part Number
½" 0.706” 0.622" 4" 2" S10590EL00 S20590EL00
¾" 0.922” 0.824" 4½" 2" S10790EL00 S20790EL00
1" 1.163” 1.050" 5¾" 2" S11090EL00 S21090EL00
Standard Radius Elbows 45º
Trade Size Outside Dia. Inside Dia. Min. Radius Straight Leg Each End Type 304
Part Number
Type 316
Part Number
½" 0.706” 0.622" 4" 2" S10545EL00 S20545EL00
¾" 0.922” 0.824" 4½" 2" S10745EL00 S20745EL00
1" 1.163” 1.050" 5¾" 2" S11045EL00 S21045EL00
Standard Radius Elbows 45º
Trade Size Metric Size Outside Dia. Inside Dia. ABType 304
Part Number
Type 316
Part Number
½" 16 0.840" 0.622” 3.79" 4.00" S40545EL00 S60545EL00
¾" 21 1.050" 0.824” 3.94" 4.50" S40745EL00 S60745EL00
1" 27 1.315" 1.049” 5.05" 5.75" S41045EL00 S61045EL00
1-¼" 35 1.660" 1.380” 6.38" 7.25" S41245EL00 S61245EL00
1-½" 41 1.900" 1.610” 7.26" 8.25" S41545EL00 S61545EL00
2" 53 2.375" 2.067” 8.27" 9.50" S42045EL00 S62045EL00
2-½" 63 2.875" 2.469” 9.02" 10.50" S42545EL00 S62545EL00
3" 78 3.500" 3.068” 11.21" 13.00" S43045EL00 S63045EL00
4" 103 4.500" 4.026” 13.71" 16.00" S44045EL00 S64045EL00
STRAIGHT LEG
ID
OD
9
STAINLESS STEEL EMT COMPRESSION FITTINGS (Type 316SS)
EMT Male Compression Fittings NEMA4X
Trade Size Metric Size Wt. (lbs) ABPart Number
½” 16 0.18 1.620” 1.050” S20500MC00
¾” 21 0.28 1.700” 1.250” S20700MC00
1" 27 0.43 1.840” 1.580” S21000MC00
1-¼" 35 0.60 1.850” 1.980” S21200MC00
1-½" 41 0.73 2.050” 2.250” S21500MC00
2" 53 1.22 2.140” 2.750” S22000MC00
EMT Compression Unions NEMA4X
Trade Size Metric Size Wt. (lbs) ABPart Number
½" 16 0.16 2.130" 1.050” S20500CC00
¾" 21 0.21 2.050" 1.250” S20700CC00
1" 27 0.31 2.200" 1.580” S21000CC00
1-¼" 35 0.47 2.560" 1.980” S21200CC00
1-½" 41 0.63 2.700" 2.250” S21500CC00
2" 53 0.83 2.880" 2.750” S22000CC00
STAINLESS STEEL COMPRESSION FITTINGS (Type 316SS)
Male Compression Connectors NEMA4X
Trade Size Metric Size Wt. (lbs) A B Part Number
½" 16 0.11 1.725" 1.200" S60500MC00
¾" 21 0.16 1.860" 1.450" S60700MC00
1" 27 0.23 2.000" 1.750" S61000MC00
1-½" 41 0.33 2.380" 2.390" S61500MC00
2" 53 0.45 2.530" 2.920" S62000MC00
Compression Unions NEMA4X
Trade Size Metric Size Wt. (lbs) A B Part Number
½" 16 0.28 2.310" 1.200" S60500CC00
¾" 21 0.42 2.220" 1.450" S60700CC00
1" 27 0.67 2.400" 1.750" S61000CC00
1-½" 41 1.11 3.000" 2.390" S61500CC00
2" 53 1.75 3.000" 2.920" S62000CC00
STAINLESS STEEL COMPRESSION FITTINGS
* Compatible for use with stainless steel IMC and rigid conduit
* Compatible for use with stainless steel EMT conduit
EMT Set Screw Male Connectors
Trade Size Metric Size Part Number Type 316S
½" 16 S20500MCSS
¾" 21 S20700MCSS
1" 27 S21000MCSS
1-¼" 35 S21200MCSS
1-½" 41 S21500MCSS
2" 53 S22000MCSS
EMT Set Screw Couplings
Trade Size Metric Size Part Number Type 316S
½" 16 S20500CCSS
¾" 21 S20700CCSS
1" 27 S21000CCSS
1-¼" 35 S21200CCSS
1-½" 41 S21500CCSS
2" 53 S22000CCSS
* Not suitable for damp locations
10
Bare Flex Conduit 25’ Length
Trade Size Metric Size Outside Dia. Inside Dia. Bend Wt. 25’ Coil (lbs) Part Number
½" 16 0.744” 0.610” 4” 4.50 S60500CTFX
¾" 21 0.960” 0.790” 4-½” 5.50 S60700CTFX
1" 27 1.160” 1.010” 6” 7.00 S61000CTFX
1-¼” 35 1.500” 1.330" 7-½” 8.50 S61200CTFX
1-½" 41 1.750” 1.520” 9” 10.00 S61500CTFX
2" 53 2.125" 2.020" 10" 13.00 S62000CTFX
“OD”
Outside Diameter
ID”
Inside Diameter
LENGTH
Clear Coated Flex Conduit 25’ Length NEMA4X
Suitable for damp locations
Trade Size Metric Size Outside Dia. Inside Dia. Bend Wt. 25’ Coil (lbs) Part Number
½” 16 0.840” 0.610” 4-½” 5.50 S40500CTCC
¾” 21 1.050” 0.790” 6” 7.00 S40700CTCC
1” 27 1.315” 1.010” 10” 9.00 S41000CTCC
1-½” 41 1.900” 1.520” 12” 12.00 S41500CTCC
STAINLESS STEEL FLEXIBLE CONNECTORS (Type 316SS)
Flex Connector Male 90º Elbow NEMA4X
Suitable for damp locations
Trade Size Metric Size Wt. (lbs) A B C Part Number
½” 16 0.29 1.900” 1.150” 1.380” S60500FC90
¾” 21 0.50 2.250” 1.400” 1.710” S60700FC90
1” 27 0.75 2.800” 1.780” 2.140” S61000FC90
1-¼" 35 1.00 3.290” 2.250” 2.500” S61200FC90
1-½" 41 1.38 3.750” 2.500” 2.960” S61500FC90
2" 53 1.55 4.450" 2.830" 4.420" S62000FC90
Flex Connector Male Straight NEMA4X
Suitable for damp locations
Trade Size Metric Size Wt. (lbs) A B Part Number
½” 16 0.15 1.530” 1.200” S60500FCS0
¾” 21 0.22 1.675” 1.500” S60700FCS0
1” 27 0.33 1.800” 1.650” S61000FCS0
1-¼" 35 0.70 2.000” 2.250” S61200FCS0
1-½" 41 0.83 2.000” 2.480” S61500FCS0
2" 53 1.00 2.190" 2.830" S62000FCS0
C
B
A
STAINLESS STEEL FLEXIBLE CONDUIT & CONNECTORS
STAINLESS STEEL FLEXIBLE CONDUIT
Coated Flex Conduit 25’ Length NEMA4X
Suitable for damp locations
Trade Size Metric Size Outside Dia. Inside Dia. Bend Wt. 25’ Coil (lbs) Part Number
½” 16 0.840” 0.610” 4-½” 5.50 S40500CTFC
¾” 21 1.050” 0.790” 6” 7.00 S40700CTFC
1” 27 1.315” 1.010” 10” 9.00 S41000CTFC
1-¼” 35 1.660" 1.330" 11" 11.00 S41200CTCC
1-½” 41 1.900” 1.520” 12” 12.00 S41500CTFC
B
A
*45º Flex Connectors available in ½” and ¾”.
11
3-PIECE STAINLESS STEEL COUPLINGS (Union) (Type 316SS)
3-Piece Couplings
Trade Size Metric Size Wt. (lbs) Part Number
½" 16 0.44 S605003U00
¾" 21 0.58 S607003U00
1" 27 0.94 S610003U00
1-¼" 35 1.25 S612003U00
1-½" 41 1.47 S615003U00
2" 53 2.27 S620003U00
2-½" 63 2.38 S625003U00
3" 78 2.50 S630003U00
4" 103 4.00 S640003U00
STAINLESS STEEL LINE TERMINATOR HUBS (Type 316SS)
LT Hubs
Trade Size Metric Wt. (lbs) A B a T1 T2 Part Number
½” 16 0.19 1.580” 1.625” 0.625" 1.040” 0.770" S60500LT00
¾” 21 0.25 1.525” 1.875” 0.625” 1.280” 0.980” S60700LT00
1" 27 0.45 1.830” 2.125” 0.650” 1.600” 1.240” S61000LT00
1-¼" 35 0.67 2.050” 2.500” 0.850” 1.970” 1.580” S61200LT00
1-½” 41 0.72 2.070” 2.625” 0.870” 2.210” 1.820” S61500LT00
2” 53 1.08 2.100” 3.125” 0.800” 2.750” 2.300” S62000LT00
2-½” 63 1.91 2.250” 3.625” 0.850” 3.310” 2.730” S62500LT00
3” 78 2.43 2.880” 4.375” 0.930” 3.880” 3.350” S63000LT00
4” 103 4.09 3.180” 5.500” 1.060” 5.000” 4.340” S64000LT00
A
a
B
T1
T2
STAINLESS STEEL COUPLINGS & HUBS
STAINLESS STEEL COUPLINGS (Type 316SS)
Standard Couplings
Trade Size Metric Size Wt. (lbs) APart Number
½" 16 0.17 1.570" S60500CP00
¾" 21 0.29 1.630" S60700CP00
1" 27 0.34 2.000" S61000CP00
1-¼" 35 0.51 2.050" S61200CP00
1-½" 41 0.61 2.063" S61500CP00
2" 53 0.90 2.125" S62000CP00
2-½" 63 1.87 3.190" S62500CP00
3" 78 1.93 3.250" S63000CP00
4" 103 3.97 3.540" S64000CP00
5" 129 5.96 3.970" S65000CP00
6" 155 9.94 4.270" S66000CP00
A
STAINLESS STEEL GROUNDING HUBS (Type 316SS)
Grounding Hubs
Trade Size Part Number
½" S60500LTV2
¾" S60700LTV2
1" S61000LTV2
1-¼" S61200LTV2
1-½" S61500LTV2
2" S62000LTV2
2-½" S62500LTV2
3" S63000LTV2
4" S64000LTV2
12
STAINLESS STEEL CONDUIT BODIES - FORM 8 STYLE (Type 316SS)
Trade Size Wt. (lbs) Cubic In. A B C a Part Number
½” 0.98 4” 4.970” 1.330” 2.330” 4.320” S60500LB00
¾” 1.25 7” 5.570” 1.570” 2.750” 4.950” S60700LB00
1" 1.90 11” 6.500” 1.750” 3.050” 5.650” S61000LB00
1-¼" 2.90 20” 7.500” 2.150” 3.630” 6.530” S61200LB00
1-½” 4.30 35” 8.850” 2.560” 4.030” 7.810” S61500LB00
2” 8.00 71” 11.360” 3.480” 4.460” 10.000” S62000LB00
2-½” 13.25 157” 13.430” 4.650” 5.750” 12.000” S62500LB00
3” 13.94 177” 13.560” 4.650” 5.800” 12.000” S63000LB00
4” 29.50 380” 16.330” 5.850” 7.375” 14.630” S64000LB00
LB Body
Trade Size Wt. (lbs) Cubic In. A B C a Part Number
½” 1.26 5” 5.620” 2.000” 2.030” 4.320” S60500TE00
¾” 1.86 9” 6.200” 2.330” 2.320” 4.950” S60700TE00
1" 2.50 13” 7.300” 2.650” 2.330” 5.650” S61000TE00
1-¼" 3.50 24” 8.520” 3.190” 2.900” 6.530” S61200TE00
1-½” 5.00 35” 9.810” 3.580” 3.000” 7.810” S61500TE00
2” 9.82 77” 12.300” 4.700” 3.880” 10.000” S62000TE00
2-½” 14.32 160” 15.290” 6.200” 4.550” 12.000” S62500TE00
3” 15.00 177” 15.330” 6.280” 4.520” 12.000” S63000TE00
4” 30.00 382” 18.340” 7.610” 5.930” 14.630” S64000TE00
TEE Body
LB Body
A
a
B
C
TEE Body
A
aB
C
Trade Size Wt. (lbs) Cubic In. A B C a Part Number
½” 1.04 4” 4.950” 2.150” 1.690” 4.320” S60500LL00
¾” 1.34 7” 5.590” 2.320” 1.950” 4.950” S60700LL00
1" 1.91 11” 6.480” 2.670” 2.250” 5.650” S61000LL00
1-½” 4.45 35” 8.940” 3.650” 3.040” 7.810” S61500LL00
2” 9.02 71” 11.170” 4.710” 3.860” 10.000” S62000LL00
LL Body
LL Body
A
aB
C
Trade Size Wt. (lbs) Cubic In. A B C a Part Number
½” 1.04 4” 4.950” 2.150” 1.690” 4.320” S60500LR00
¾” 1.34 7” 5.590” 2.320” 1.950” 4.950” S60700LR00
1" 1.91 11” 6.480” 2.670” 2.250” 5.650” S61000LR00
1-½” 4.45 35” 8.940” 3.650” 3.040” 7.810” S61500LR00
2” 9.02 71” 11.170” 4.710” 3.860” 10.000” S62000LR00
LR Body
LR Body
A
aB
C
Trade Size Wt. (lbs) Cubic In. A B C a Part Number
½” 1.08 5” 5.690” 1.350” 2.500” 4.320” S60500TB00
¾” 1.50 9” 6.270” 1.600” 2.720” 4.950” S60700TB00
1" 2.28 13” 7.320” 1.770” 3.100” 5.650” S61000TB00
1-½” 4.90 35” 10.400” 2.560” 4.290” 7.810” S61500TB00
2” 9.32 77” 12.300” 3.500” 4.640” 10.000” S62000TB00
TB Body
TB Body
A
a
B
C
STAINLESS STEEL CONDUIT BODIES
*Cover, gasket and screws
included with all models
* Conduit bodies continued on page 13.
13
CALSTRUT™ STAINLESS STEEL STRUT Available in other sizes, styles and gauges upon request. Available in 10’ lengths.
Slotted Strut
Trade Size Gauge Type Part Number
1-5
/8
” x 1-5
/8
”12 ga SS304 S45810ST58
1-5
/8
” x 7
/8
”14 ga SS304 S45810ST78
1-5
/8
" x 1-5
/8
”12 ga SS316 S65810ST58
1-5
/8
” x 7
/8
”14 ga SS316 S65810ST78
Post Base for Channel
Trade Size Type Part Number
Fits 1-5
/8
” channel holes - ¾” dia. SS304 S45800PB00
SS316 S65800PB00
Back-To-Back Strut
Trade Size Gauge Type Part Number
1-5
/8
” x 1-5
/8
”12 ga SS304 S45810SB58
1-5
/8
” x 7
/8
”14 ga SS304 S45810SB78
1-5
/8
” x 1-5
/8
”12 ga SS316 S65810SB58
1-5
/8
” x 7
/8
”14 ga SS316 S65810SB78
Solid Strut
Trade Size Gauge Type Part Number
1-5
/8
” x 1-5
/8
”12 ga SS304 S45810SL58
1-5
/8
” x 7
/8
”14 ga SS304 S45810SL78
1-5
/8
” x 1-5
/8
”12 ga SS316 S65810SL58
1-5
/8
” x 7
/8
”14 ga SS316 S65810SL78
CALSTRUT™ STAINLESS STEEL STRUT & FOOD GRADE CHANNEL
C Body
Trade Size Wt. (lbs) Cubic In. A B C a Part Number
½” 1.15 5” 5.690” 1.330” 1.720” 4.320” S60500CE00
¾” 1.64 9” 6.280” 1.560” 2.020” 4.950” S60700CE00
1” 2.19 13” 7.330” 1.740” 2.020” 5.630” S61000CE00
1-¼” 3.19 24” 8.520” 2.120” 2.630” 6.530” S61200CE00
1-½” 4.63 35” 10.500” 2.530” 2.740” 7.810” S61500CE00
2” 8.66 77” 12.300” 3.480” 3.550” 10.000” S62000CE00
X Body
Trade Size Wt. (lbs) Cubic In. A B C a Part Number
½" 1.26 5" 5.690" 2.210" 2.030" 4.320" S60500XB00
¾" 1.86 9" 6.280" 2.930" 2.300" 4.950" S60700XB00
1" 1.90 13" 7.330" 2.680" 2.570" 5.650" S61000XB00
1-½" 4.30 35" 10.500" 3.660" 3.000" 7.810" S61500XB00
2" 8.00 77" 12.300" 4.660" 3.800" 10.000" S62000XB00
C Body
A
a
B
C
A B
C
a
X Body
STAINLESS STEEL FOOD GRADE CHANNEL Wall and Trapeze Mount Channel is
manufactured in both type 304 and 316 12-gauge stainless steel. Available in 12", 24" & 120" lengths.
Wall Mount Food Grade Channel
12" Length Type 304
Part Number
24" Length Type 304
Part Number
120" Length Type 304
Part Number
12" Length Type 316
Part Number
24" Length Type 316
Part Number
120" Length Type 316
Part Number
S4FG12STWM S4FG24STWM S4FG10STWM S6FG12STWM S6FG24STWM S6FG10STWM
Trapeze Mount Food Grade Channel
12" Length Type 304
304 Part Number
24" Length Type 304
Part Number
120" Length Type 304
Part Number
12" Length Type 316
Part Number
24" Length Type 316
Part Number
120" Length Type 316
Part Number
S4FG12STTR S4FG24STTR S4FG10STTR S6FG12STTR S6FG24STTR S6FG10STTR
14
STAINLESS STEEL STRUT & FOOD GRADE CHANNEL ACCESSORIES (Type 316SS)
4-Hole Flat Angle Plate
Hole Diameter Part Number
9
/16
”S600004BF0
4-Hole Splice Plate
Hole Diameter Part Number
9
/16
”S60000PL4S
3-Hole Flat Angle Plate
Hole Diameter Part Number
9
/16
”S600003BF0
Cross Plate
Hole Diameter Part Number
9
/16
”S60000PLCR
Tee Plate
Hole Diameter Part Number
9
/16
”S60000PLTE
4-Hole Angle Bracket
Hole Diameter Part Number
9
/16
”S600004B00
U-Fitting
Hole Diameter Part Number
Fits 1-5
/8
” channel
holes - 9
/16
” dia.
S60000UF00
Channel Nuts with Spring
Hole Diameter Part Number
¼”-20” S60000CN11
3
/8
”-16” S60000CN31
½”-13” S60000CN41
5
/8
”-11” S60000CN51
¾”-10” S60000CN61
Saddle Washers
Hole Diameter Part Number
3
/8
”S60300STSW
½” S60500STSW
5
/8
”S60600STSW
2-Hole Angle Bracket
Hole Diameter Part Number
9
/16
”S600002B00
STAINLESS STEEL STRUT & FOOD GRADE CHANNEL ACCESSORIES
Wall Spacers
Type Part Number
Standard S60000WS00
Heavy Duty S60000WSHD
L-Bracket
Part Number
S60000BRL0
Hanger Rod
Part Number
S60000HR00
15
STAINLESS STEEL CORD GRIP CONNECTORS
(Type 304SS)
Cord Grip Connectors
Trade Size Cable Range Part Number
½" 0.125" - 0.188" S40501GR00
½" 0.188" - 0.250" S40502GR00
½" 0.250" - 0.312" S40503GR00
½" 0.312" - 0.375" S40504GR00
½" 0.375" - 0.438" S40505GR00
½" 0.438" - 0.500" S40506GR00
½" 0.500" - 0.562" S40507GR00
½" 0.562" - 0.625" S40508GR00
¾" 0.438" - 0.500" S40701GR00
¾" 0.500" - 0.562" S40702GR00
¾" 0.500" - 0.625" S40703GR00
¾" 0.562" - 0.688" S40704GR00
¾" 0.625" - 0.750" S40705GR00
¾" 0.688" - 0.812" S40706GR00
1" 0.438" - 0.562" S41001GR00
1" 0.500" - 0.562" S41002GR00
1" 0.500" - 0.625" S41003GR00
1" 0.562" - 0.688" S41004GR00
1" 0.625" - 0.750" S41005GR00
1" 0.688" - 0.812" S41006GR00
1" 0.750" - 0.875" S41007GR00
1" 0.812" - 0.938" S41008GR00
1" 0.875" - 1.000" S41009GR00
1-¼" 0.562" - 0.688" S41201GR00
1-¼" 0.688" - 0.812" S41202GR00
1-¼" 0.750" - 0.875" S41203GR00
1-¼" 0.875" - 1.000" S41204GR00
1-¼" 1.000" - 1.125" S41205GR00
1-¼" 1.125" - 1.250" S41206GR00
1-¼" 1.250" - 1.375" S41207GR00
1-½" 0.562" - 0.688" S41501GR00
1-½" 0.688" - 0.812" S41502GR00
1-½" 0.750" - 0.875" S41503GR00
1-½" 0.875" - 1.000" S41504GR00
1-½" 1.000" - 1.125" S41505GR00
1-½" 1.125" - 1.250" S41506GR00
1-½" 1.250" - 1.375" S41507GR00
2" 1.250" - 1.375" S42001GR00
2" 1.438" - 1.562" S42002GR00
2" 1.562" - 1.688" S42003GR00
2" 1.688" - 1.812" S42004GR00
2" 1.812" - 1.938" S42005GR00
2" 1.938" - 2.062" S42006GR00
2" 2.062" - 2.188" S42007GR00
2" 2.188" - 2.312" S42008GR00
2" 2.312" - 2.438" S42009GR00
STAINLESS STEEL CORD GRIP CONNECTORS
16
STAINLESS STEEL CORD GRIP CONNECTORS WITH MESH
(Type 304SS)
Cord Grip Connectors with Mesh
Trade Size Cable Range Part Number
½" .188" - .250" S40502GRWM
½" .250" - .312" S40503GRWM
½" .312" - .375" S40504GRWM
½" .375" - .438" S40505GRWM
½" .438" - .500" S40506GRWM
½" .500" - .562" S40507GRWM
½" .562" - .625" S40508GRWM
¾" .438" - .500" S40701GRWM
¾" .500" - .562" S40702GRWM
¾" .500" - .625" S40703GRWM
¾" .562" - .688" S40704GRWM
¾" .625" - .750" S40705GRWM
¾" .688" - .812" S40706GRWM
1" .438" - .562" S41001GRWM
1" .500" - .562" S41002GRWM
1" .500" - .625" S41003GRWM
1" .562" - .688" S41004GRWM
1" .625" - .750" S41005GRWM
1" .688" - .812" S41006GRWM
1" .750" - .875" S41007GRWM
1" .812" - .938" S41008GRWM
1" .875" - 1.000" S41009GRWM
1-¼" .562" - .688" S41201GRWM
1-¼" .688" - .812" S41202GRWM
1-¼" .750" - .875" S41203GRWM
1-¼" .875" - 1.000" S41204GRWM
1-¼" 1.000" - 1.125" S41205GRWM
1-¼" 1.125" - 1.250" S41206GRWM
1-¼" 1.250" - 1.375" S41207GRWM
1-½" .562" - .688" S41501GRWM
1-½" .688" - .812" S41502GRWM
1-½" .750" - .875" S41503GRWM
1-½" .875" - 1.000" S41504GRWM
1-½" 1.000" - 1.125" S41505GRWM
1-½" 1.125" - 1.250" S41506GRWM
1-½" 1.250" - 1.375" S41507GRWM
2" 1.250" - 1.375" S42001GRWM
2" 1.438" - 1.562" S42002GRWM
2" 1.562" - 1.688" S42003GRWM
2" 1.688" - 1.812" S42004GRWM
2" 1.812" - 1.938" S42005GRWM
2" 1.938" - 2.062" S42006GRWM
2" 2.062" - 2.188" S42007GRWM
2" 2.188" - 2.312" S42008GRWM
2" 2.312" - 2.438" S42009GRWM
STAINLESS STEEL CORD GRIP CONNECTORS WITH MESH
17
STAINLESS STEEL DEVICE BOXES, COVERS & PLATES
STAINLESS STEEL DEVICE BOXES
FS Single Gang Box
Size Wt. (lbs) Cubic In. Part Number
¾”
2.05 18" S60700FS00
FDC Single Gang Box
Size Wt. (lbs) Cubic In. Part Number
¾”
2.61 25" S60700FDCS
1" 3.20 25" S61000FDCS
FD Single Gang Box
Size Wt. (lbs) Cubic In. Part Number
¾”
2.53 25" S60700FD00
FDC Double Gang Box
Size Wt. (lbs) Cubic In. Part Number
¾" 3.52 45" S60700FDCD
1" 4.02 45" S61000FDCD
FDCC & FSCC Single Gang Boxes
Model Size Wt. (lbs) Cubic In. Part Number
FDCC ¾" 2.50 25" S60700FDCC
FSCC ¾" 2.06 18" S60700FSCC
FSCT & FDCT Gang Boxes
Model Size Wt. (lbs) Cubic In. Part Number
FDCT ¾" 2.53 25" S60700FDCT
FSCT ¾" 2.15 18" S60700FSCT
FDX & FSX Single Gang Boxes
Model Size Wt. (lbs) Cubic In. Part Number
FDX ¾" 2.60 25" S60700FDX0
FSX ¾" 2.22 18" S60700FSX0
STAINLESS STEEL DEVICE BOX COVERS STAINLESS STEEL DEVICE BOX PLATES
Duplex
Receptacle
(Horizontal)
#S607HDCVRS
GFCI Receptacle
(Vertical)
#S607VGCVRS
Toggle Switch
(Vertical)
#S6071TCVRS
Toggle Switch
(Horizontal) #S6071TCVLS
Single Gang Blank
(1 Gang) #S607BLPLTS
Two Toggle Switch
(Vertical) #S6072TCVRD
Two Toggle
Switch
(2 Gang)
#S6072TPLTD
Two Toggle
Receptacle
(2 Gang) #S6072DPLTD
One Duplex
Receptacle
(1 Gang)
#S6072DPLTS
One Toggle Switch
(1 Gang)
#S6071TPLTS
Two GFCI
Receptacle
(2 Gang) #S6072GPLTD
One GFCI
Receptacle
(1 Gang)
#S6071GPLTS
One Toggle Switch &
One GFCI Receptacle
(2 Gang)
#S607TGPLTD
One Toggle Switch
& One Duplex Receptacle
(2 Gang) #S607TDPLTD
Duplex Receptacle
(Vertical)
#S607VDCVRS
Duplex Receptacle
(Horizontal)
#S607HDCVLS
GFCI Receptacle
(Vertical)
#S607VGCVLS
Two Gang Blank
(2 Gang)
#S607BLPLTD
In-Use Boxes
Wt. (lbs) Part Number
2.65 S60000FVCS
3.61 S60000FVCD
NEMA4X
(Suitable for Damp Environments)
(Type 316SS) S = Shallow, D = Deep
18
STAINLESS STEEL WASHERS, NUTS & SCREWS (Type 316SS)
Locknuts
Trade Size Part Number
½” S60500LN00
¾” S60700LN00
1” S61000LN00
1-¼” S61200LN00
1-½” S61500LN00
2” S62000LN00
2-½” S62500LN00
3” S63000LN00
4” S64000LN00
Standard Washers
Trade Size Part Number
¼” S60200WA00
3
/8
”S60300WA00
½” S60500WA00
5
/8
”S60600WA00
Hex Nuts
Trade Size Part Number
¼” S60200HN00
3
/8
”S60300HN00
½” S60500HN00
5
/8
”S60600HN00
Grounding Locknuts
Trade Size Part Number
½" S60500LNWG
¾" S60700LNWG
1" S61000LNWG
1-¼" S61200LNWG
1-½" S61500LNWG
2" S62000LNWG
2-½" S62500LNWG
3" S63000LNWG
4" S64000LNWG
Lock Washers
Trade Size Part Number
¼” S60200LW00
3
/8
”S60300LW00
½” S60500LW00
5
/8
”S60600LW00
Square Washers
Trade Size Part Number
¼” S60200SW00
3
/8
”S60300SW00
½” S60500SW00
5
/8
”S60600SW00
Fender Washers
Trade Size Part Number
¼” x 1" S60200FW10
¼” x 1-¼” S60200FW12
3
/8
” x 1-¼” S60300FW12
Threaded Rod
Trade Size Type 304 Part Number Type 316 Part Number
¼” S40212TR00 S60212TR00
3
/8
”S40312TR00 S60312TR00
½” S40512TR00 S60512TR00
STAINLESS STEEL WASHERS, NUTS & SCREWS
Slotted Machine Screws 316SS
Trade Size Part Number
Various S60000MS00
Hex Head Cap Screws
Trade Size Part Number
Various S60000HC00
STAINLESS STEEL RODS & SCREWS
* Sold in 12’ Lengths
STAINLESS STEEL CLAMPS
19
STAINLESS STEEL CLAMPS (Type 316SS)
Split Ring Clamps
Trade Size Part Number
½” S60500SP00
¾” S60700SP00
1” S61000SP00
1-¼" S61200SP00
1-½” S61500SP00
2” S62000SP00
2-½” S62500SP00
3” S63000SP00
4” S64000SP00
Split Ring Mounting Plates
Trade Size Description Part Number
3
/8
”For Clamps - ½” - 2” S60300SPMP
½” For Clamps - 2-½” - 4” S60500SPMP
Right Angle Clamps
Trade Size Part Number
½” S60500RA00
¾” S60700RA00
1” S61000RA00
1-¼” S61500RA00
1-½” S61200RA00
2” S62000RA00
2-½” S62500RA00
3” S63000RA00
4” S64000RA00
Parallel Clamps
Trade Size Part Number
¾” S60700PC00
1” S61000PC00
Clamp Backs
Trade Size Part Number
½” S60500CB00
¾” S60700CB00
1" S61000CB00
Clamp Back Spacers
Trade Size Description Part Number
½” - 1" Universal Clamp Back Spacer S60510CBSP
Beam Clamps
Trade Size Part Number
¼” - 20” S60200BC00
3
/8
” - 16” S60300BC00
½” - 13” S60500BC00
STAINLESS STEEL CLAMPS
Strut Clamps
Trade Size Part Number
½” S60500SC00
¾” S60700SC00
1” S61000SC00
1-¼” S61500SC00
1-½” S61200SC00
2” S62000SC00
2-½” S62500SC00
3” S63000SC00
4” S64000SC00
(Also available in SS EMT)
Right Angle Beam Clamp
Trade Size Part Number
1-5
/8
” x 1-5
/8
”S60000RB00
Split Ring Extensions
Trade Size Description Part Number
3
/8
” x 2” For Clamps 2-½”- 4" S60302SPX0
3
/8
” x 4” For Clamps 2-½”- 4" S60304SPX0
3
/8
” x 6” For Clamps 2-½”- 4" S60306SPX0
½” x 2” For Clamps 2-½”- 4" S60502SPX0
½” x 4” For Clamps 2-½”- 4" S60504SPX0
½” x 6” For Clamps 2-½”- 4" S60506SPX0
20
STAINLESS STEEL STRAPS AND HANGERS
2-Hole Straps
(Also Available in SS EMT)
Trade Size ABCBolt Hole Part Number
½" 2.427" 0.627" 0.840" ¼" S605002S00
¾" 2.925" 0.750" 1.050" ¼" S607002S00
1" 3.370" 0.750" 1.300" ¼" S610002S00
1-¼" 4.440" 0.875" 1.660" ¼" S612002S00
1-½" 4.440" 1.240" 1.900" ¼" S615002S00
2" 5.290" 1.245" 2.370" ¼" S620002S00
2-½" 6.119" 1.250" 2.874" ¼" S625002S00
3" 6.727" 1.250" 3.500" ¼" S630002S00
4" 8.947' 1.250" 4.500" ¼" S640002S00
1-Hole Straps
(Also available in SS EMT)
Trade Size ABCBolt Hole Part Number
½" 0.625" 0.075" 0.840" ¼" S605001S00
¾" 0.750" 0.090" 1.050" ¼" S607001S00
1" 0.875" 0.090" 1.300" ¼" S610001S00
1-¼" 0.875" 0.100" 1.660" ½" S612001S00
1-½" 1.000" 0.125" 1.900" ½" S615001S00
2" 1.125" 0.125" 2.370" 9
/16
"S620001S00
2-½" 1.250" 0.150" 2.874" 9
/16
"S625001S00
3" 1.250" 0.150" 3.500" 9
/16
"S630001S00
4" 1.250" 0.180" 4.500" 9
/16
"S640001S00
A
BDC
STRAPS, HANGERS, MISCELLANEOUS
Conduit Hangers
Trade Size Part Number
½” S60500MH00
¾” S60700MH00
1” S61000MH00
1-¼” S61200MH00
1-½” S61500MH00
2” S62000MH00
2-½” S62500MH00
3” S63000MH00
4” S64000MH00
(Also available in SS EMT)
MISCELLANEOUS
Counter-Sunk Hex Plugs
Trade Size aPart Number
½" 0.375" S60500CSHP
¾" 0.563" S60700CSHP
1" 0.625" S61000CSHP
1-¼" 0.750" S61200CSHP
1-½" 1.000" S61500CSHP
2" 1.000" S62000CSHP
2-½" 1.000" S62500CSHP
3" 1.000" S63000CSHP
4" 1.000" S64000CSHP
5" 1.000" S65000CSHP
6" 1.000" S66000CSHP
Box Connectors
Trade Size Part Number
½" S60500CH00
¾" S60700CH00
1" S61000CH00
1-¼" S61200CH00
1-½" S61500CH00
2" S62000CH00
2-½" S62500CH00
3" S63000CH00
4" S64000CH00
C
C
B
A
(Type 316SS)
21
Standard U-Bolts
(Figure 137 Style)
Trade Size A B C D E F Weight/100 (lbs) Part Number
½” ¼” 15
/16
”1-3/
16”2-¾”` 2-1
/8
”2-5
/16
”23 S60500UB00
¾” ¼” 1-1
/8
”1-3
/8
”2-¾” 2-1
/8
”2-7
/32
”” 24 S60700UB00
1" ¼” 1-3
/8
”1-5
/8
”2-¾” 2-1
/8
”2-3
/32
”26 S61000UB00
1-¼" 3
/8
”1-11
/16
”2-1
/16
”2-7
/8
”2-1
/8
”2-1
/32
”28 S61200UB00
1-½" 3
/8
”2” 2-3
/8
”3” 2-½" 2-1
/16
”29 S61500UB00
2” 3
/8
”2-7
/16
”2-13
/16
”3-¼” 2-½" 2-1
/16
”32 S62000UB00
2-½" ½” 2-15
/16
”3-7
/16
”3-¾” 3” 2-¼” 68 S62500UB00
3” ½” 3-9
/16
”4-1
/16
”4” 3” 2-¼” 77 S63000UB00
3-½" ½” 4-1
/16
”4-9
/16
”4-¼” 3” 2-¼” 82 S63500UB00
4” ½” 4-9
/16
”5-1
/16
”4-½” 3” 2-¼” 88 S64000UB00
Conduit Body Cover, Gasket
& Screw Sets
Trade Size Part Number
½" S60500CG00
¾” S60700CG00
1” S61000CG00
1-½” S61500CG00
2” S62000CG00
Threaded Conduit Caps
Trade Size Part Number
½” S60500CA00
¾” S60700CA00
1” S61000CA00
1-¼” S61200CA00
1-½” S61500CA00
2” S62000CA00
2-½” S62500CA00
3” S63000CA00
4” S64000CA00
Rod Couplings
Trade Size Part Number
¼" S60200RC00
3
/8
”S60300RC00
½" S60500RC00
¾" S60700RC00
Pulling Elbows
Trade Size Wt. (lbs) Part Number
¾" 0.31 S60700P900
1" 0.64 S61000P900
Face / Reducing Bushings
Trade Size Part Number
¾" x ½" S60700FB05
1" x ½" S61000FB05
1" x ¾" S61000FB07
1-¼" x ½" S61200FB05
1-¼" x ¾" S61200FB07
1-¼" x 1" S61200FB10
1-½" x ½" S61500FB05
1-½" x ¾" S61500FB07
1-½" x 1" S61500FB10
1-½" x 1-¼" S61500FB12
2" x ½" S62000FB05
2" x ¾" S62000FB07
2" x 1" S62000FB10
2" x 1-¼" S62000FB12
2" x 1-½" S62000FB15
2-½" x ½" S62500FB05
2-½" x ¾" S62500FB07
2-½" x 1" S62500FB10
* 5" & 6" Bushings available upon request
* SS Hex Bushings also available
Wedge Anchors
Trade Size Part Number
Various S60000WR00
MISCELLANEOUS CONTINUED
Face / Reducing Bushings
Trade Size Part Number
2-½" x 1-¼" S62500FB12
2-½" x 1-½" S62500FB15
2-½" x 2" S62500FB20
3" x ½" S63000FB05
3" x ¾" S63000FB07
3" x 1" S63000FB10
3" x 1-¼" S63000FB12
3" x 1-½" S63000FB15
3" x 2" S63000FB20
3" x 2-½" S63000FB25
4" x ½" S64000FB05
4" x ¾" S64000FB07
4" x 1" S64000FB10
4" x 1-¼" S64000FB12
4" x 1-½" S64000FB15
4" x 2" S64000FB20
4" x 2-½" S64000FB25
4" x 3" S64000FB30
Drop-In Anchors
Trade Size Part Number
¼" S60200DR00
3
/8
”S60300DR00
½" S60500DR00
5
/8
"S60600DR00
¾" S60700DR00
22
The Stainless Steel Resource Center
Check out our resource section on Calbrite.com for
product cut sheets, a custom Conduit Lifecycle Calculator
and a database of valuable papers on stainless steel and
its benefits.
Each Calbrite cut sheet includes a product image, feature
and benefit summary, certifications and compliances met,
common applications, industry recommendations and part
number specs. Each is formatted to be easily printed and
kept as a reference.
Cut sheet sample
Calbrite ♦ 2207 165th St. Hammond, IN 46320 ♦ Ph: 219-844-6800 ♦ www.calbrite.com
Stainless Steel Rigid Conduit
Features:
Manufactured in type 304 & 316 stainless to meet any stringent sanitary condition
Polished to a bright, easily maintainable finish that is modern, attractive, easy to
clean, and that also enhances the surface's resistance to pitting & bacterial corrosion
Calbrite stainless steel rigid conduit functions in exactly the same way as any other
metallic conduit. There are none of the labor-intensive procedures that come with
PVC-coated installations, nor the complicated maintenance and repair procedures
Standard NPT threads allow for trouble-free installations
Includes one coupling with each length purchased
Certifications and Compliances:
Calbrite stainless steel rigid conduit is UL / CUL listed and manufactured in accordance to
UL6A & ANSI C80.1 standards.
UL file number – E230584
Full NEC code compliance
Meets ASTM A-321/SA-312 standards
Manufactured in the US
Along with other corrosive environments
Applications:
Stainless conduit is often recommended when corrosive applications exceed the limitations of aluminum, rigid, & PVC Coated
conduit. Calbrite's type 304 & 316 UL-listed stainless steel conduit meets & exceeds current requirements for wash down, is food
-safe/potable water-safe and satisfies the strictest mandates for plant cleanliness by HACCP, FDA, various state agencies, and
hundreds of common regulatory requirements.
Industries Commonly Served:
Food & Beverage Production & Distribution
Chemical Plants
Water & Wastewater Treatment
Pharmaceuticals & Cosmetics
Refining & Extraction Sites
Petrochemical Operations
Marine & Coastal Facilities
Trade Size Type 304
Part Number
Type 316
Part Number
Outer
Diameter
Inner
Diameter
Threads
Per Inch
Length w/o
Coupling
Weight per
ft. (lbs.)
1/2" S40510CT00 S60510CT00 0.840” 0.632” 14 9’ 11-1/4” 0.82
3/4" S40710CT00 S60710CT00 1.050” 0.836” 14 9’ 11-1/4” 1.09
1" S41010CT00 S61010CT00 1.315” 1.063” 11.5 9’ 11” 1.61
1-1/4" S41210CT00 S41510CT00 1.660” 1.394” 11.5 9’ 11” 2.18
1-1/2" S41510CT00 S61510CT00 1.900” 1.624” 11.5 9’ 11” 2.63
2" S42010CT00 S62010CT00 2.375” 2.083” 11.5 9’ 11” 3.50
2-1/2" S42510CT00 S62510CT00 2.875” 2.489” 8 9’ 10-1/2” 5.59
3" S43010CT00 S63010CT00 3.500” 3.090” 8 9’ 10-1/2” 7.27
4” S44010CT00 S64010CT00 4.500” 4.050” 8 9’ 10-1/4” 10.08
All dimensions are for informational purposes only *Tolerances +/- 5%
calbrite.com
23
NOTES & CONTACTS
800-536-2248
INDUSTRIES SERVED
Food, Dairy & Beverage Industries
Water & Wastewater Treatment Facilities
Mining
Marine & Coastal Facilities
Chemical Plants
Petrochemical
Steel Mills
Offshore Platforms
Breweries
Cooling Towers
Transportation
Pharmaceuticals & Cosmetics
Architectural & Structural Design
Power Plants
Solar Farms
Pulp and Paper Mills
Fertilizer Plants
and other corrosive & harsh environments
UL 6A & CUL 6A, UL 514A & CUL 514A , UL 514B & CUL 514B, NEMA 4X, ANSI
3 U.S. Manufacturing Locations
Keep America Working
MIDWEST (Sales Office)
2207 165th Street
Hammond, IN 46320
(219) 844-6800
(800) 536-2248
(219) 844-6884 fax
CORPORATE
HEADQUARTERS
12021 Woodruff Avenue
Downey, CA 90241
SOUTHEAST
301 Mears Blvd.,Suite A
Oldsmar, FL 34677
(219) 844-6800
(800) 536-2248
(219) 844-6884 fax
A division of
