•Electricalcabinets
•Generaltasklighting
•Sprayandwashdownareas
•Vaultsandinspectionareas
HANDLAMPS
Tasklightinginindustrialenvironmentscanbeachallengeforanyprocess.Woodheadhand
lampsfeaturethemostrugged,longest-lastingenclosuresforuseinallharsh environments:
wetlocation,industrialduty,commercialdutyandgeneralduty.
WOODHEAD® OFFERS THE MOST EXTENSIVE LINE OF PORTABLE HAND
LAMPS FOR USE IN WET, INDUSTRIAL AND COMMERCIAL ENVIRONMENTS
Widevariety Fixturescanbeselectedbasedontheactual
oflightsources typeandamountoflightneededfortheapplication
Widevarietyof Fixturescanbeselectedbasedontheapplication
enclosureratings requirementsformaterial,moisture,ruggedness
Themostruggedhigh- Productscanbeusedforextendedperiodsinthe
performanceenclosures mostharshenvironments
FEATURES AND
BENEFITS
APPLICATIONS
www.woodhead.com
A-14
A
Portable Lighting
Handlamps
Super-Safeway™
Industrial Duty
Incandescent
100W Max.
Features and Benefits
• The Super-Safeway line of handlamps offer heavy-
duty construction and long operating life in the most
demanding operating applications
• Rubber handles and 8-gauge Steel guards provide
maximum protection for bulbs and electrical components
• Ergonomically designed fencer’s flange handle helps
protect users from accidentally touching a hot guard
• Available with or without a switch, outlet, reflector or
insulated guard ensuring the correct configuration for
the application
Reference Information
CSA File No.: LR85374
Electrical
NEMA Configuration,
Product with Plug or Outlet: NEMA 5-15
Voltage: 240V max.
Physical
Bulb Size: A21
Handle Construction: Rubber
Guard Material: 8-gauge Zinc-plated Steel
Guard Style: Open end, 75–100W
Outlet Switch Reflector Insulated Guard Cord Type Cord Length Woodhead No. Order No.
None
No
16/3 SOOW
110 130102-0138
Yes 114 130102-0167
Yes 7.62m (25.00') 114A163 130102-0168
Yes 15.24m (50.00') 114B163 130102-0169
Side
110U 130102-0140
7.62m (25.00') 110UA163 130102-0141
15.24m (50.00') 110UB163 130102-0142
Yes 114U 130102-0171
Yes 7.62m (25.00') 114UA163 130102-0172
Yes 15.24m (50.00') 114UB163 130102-0173
Yes Yes 114UI 130102-0176
Yes
110US 130102-0143
Yes 114US 130102-0177
Yes 7.62m (25.00') 114USA163 130102-0178
Yes Yes 7.62m (25.00') 114USIA163 130102-0183
Yes 15.24m (50.00') 114USB163 130102-0180
Yes Yes 15.24m (50.00') 114USIB163 130102-0184
Handlamps
Super-Safeway™
Industrial Duty
Incandescent
100W Max.
Features and Benefits
• The Super-Safeway line of handlamps offer heavy-
duty construction and long operating life in the most
demanding operating applications
• Unique quick-open nylon guard runs cooler than standard
metal guards
• Available with or without switch or outlet ensuring the
correct configuration for the application
Reference Information
CSA File No.: LR85374
Electrical
NEMA Configuration,
Product with Plug or Outlet: NEMA 5-15
Voltage: 240V max.
Physical
Bulb Size: A21
Handle Construction: Rubber
Guard Material: Nylon
Guard Style: Closed end, 75–100W, quick open
Outlet Switch Cord Type Cord Length Woodhead No. Order No.
None
No
16/3 SOOW
118 130102-0212
7.62m (25.00') 118A163 130102-0213
15.24m (50.00') 118B163 130102-0214
Yes
118S 130102-0215
7.62m (25.00') 118SA163 130102-0216
15.24m (50.00') 118SB163 130102-0217
Side
No 15.24m (50.00') 118UB163 130102-0221
Yes
118US 130102-0222
7.62m (25.00') 118USA163 130102-0223
15.24m (50.00') 118USB163 130102-0224
