R900, R1800 series relays and optocouplers
Transitioning into obsolete phase
Low Voltage Products lifecycle announcement
Overview
The R900 and R1800 series relays including optocouplers have now reached the end of their active sales status and are transitioning
into the obsolete phase effective January 1, 2014. These products are replaced by the R600 series which offers enhanced features
and functionality.
Products concerned
Obsolete P/N Description Type Family Replacemet P/N
Description
Family Comments
1SNA630001R0000 RB121-12VDC Relay R900 1SNA645037R2600 RB121 12VDC / 1mA TO 6A-250V R600
1SNA630002R0100 RB121A-24V AC/DC Relay R900 1SNA645005R0700 RB121A 24V / 1mA TO 6A-250V R600
1SNA630003R0200 RB121A-48VAC/DC Relay R900 1SNA645006R0000 RB121A 48-60V / 1mA TO 6A-250V R600
1SNA630004R0300 RB121B 110VAC/50HZ Relay R900 1SNA645007R0100 RB121A 115V / 1mA TO 6A-250V R600
1SNA630005R0400 RB121B 115VAC/60HZ Relay R900 1SNA645007R0100 RB121A 115V / 1mA TO 6A-250V R600
1SNA630006R0500 RB121B 230VAC/50HZ Relay R900 1SNA645008R1200 RB121A 230V / 1mA TO 6A-250V R600
1SNA630007R0600 RB121AI-24VAC-DC Relay R900 1SNA645037R2600 RB121 12VDC / 1mA TO 6A-250V R600
1SNA630011R2100 RB122A 24VAC/DC Relay R900 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA630019R0100 RB122 24VDC Relay R900 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600
1SNA630021R2300 RB122B 110VAC 50HZ Relay R900 1SNA645041R0200 RB122A 115V / 1mA TO 6A-250V R600
1SNA630022R2400 RB122B 115VAC 60HZ Relay R900 1SNA645041R0200 RB122A 115V / 1mA TO 6A-250V R600
1SNA008010R0500 RB111V-24VDC Relay R900 no replacement
1SNA008004R0400 OBC 0100 S125VDC Optocoupler R900 1SNA645022R2700 OBIC0100 115-230VACDC / 100mA- R600
1SNA008048R1700 OBC0100-110VAC/125VDC Optocoupler R900 1SNA645022R2700 OBIC0100 115-230VACDC / 100mA- R600
1SNA008049R1000 OBC0100-125VDC Optocoupler R900 1SNA645022R2700 OBIC0100 115-230VACDC / 100mA- R600
1SNA008076R0300 OBC 00100R-110VAC Optocoupler R900 1SNA645022R2700 OBIC0100 115-230VACDC / 100mA- R600
1SNA008077R0400 OBC 0100R-230VAC Optocoupler R900 1SNA645022R2700 OBIC0100 115-230VACDC / 100mA- R600
1SNA008079R1600 OBC 0300 24VDC/125VDC Optocoupler R900 no replacement
1SNA030040R0400 OBC 0050-125VDC/24VDC Optocoupler R900 no replacement
1SNA608014R2200 OBC1000-5VDC Optocoupler R900 1SNA645050R1700 OBOC1000 5-12VDC / 2A-58VDC R600 rated contact voltage 5-58VDC
1SNA608015R0400 OBA 1000 5VDC Optocoupler R900 no replacement
1SNA608017R0600 OBC0100-24VDC Optocoupler R900 1SNA645021R2600 OBIC0100 24VDC / 100mA-58VDC R600 rated contact voltage 5-58VDC
1SNA608018R1700 OBC1000-24VDC Optocoupler R900 1SNA645051R0400 OBOC1000 24VDC / 2A-58VDC R600 rated contact voltage 5-58VDC
1SNA608019R1000 OBA 1000 24VDC Optocoupler R900 1SNA645029R0600 OBOA2000 24VDC / 2A-10 TO 230V R600 rated contact voltage 10-230VAC
1SNA608021R0200 OBC0100-48VDC Optocoupler R900 1SNA645049R1200 OBIC0100 48-60V / 100MA-58VDC R600 rated contact voltage 5-58VDC
1SNA608022R0300 OBC1000-48VDC Optocoupler R900 1SNA645053R0600 OBOC1000 48-60VACDC / 2A- 58VD R600 rated contact voltage 5-58VDC
1SNA608023R0400 OBA 1000 48VDC Optocoupler R900 1SNA645061R0600 OBOA1000 48-60VACDC / 1A-24 TO R600
1SNA608024R0500 OBC0100-110VAC Optocoupler R900 1SNA645022R2700 OBIC0100 115-230VACDC / 100mA- R600 rated contact voltage 5-58VDC
1SNA608025R0600 OBC1000-110VAC Optocoupler R900 1SNA645054R0700 OBOC1000 115VACDC / 2A-58VDC R600 rated contact voltage 5-58VDC
1SNA608026R0700 OBA 1000 110VAC Optocoupler R900 1SNA645062R0700 OBOA1000 115VACDC / 1A-24 TO 4 R600
1SNA608027R0000 OBC0100-230VAC Optocoupler R900 1SNA645022R2700 OBIC0100 115-230VACDC / 100mA- R600 rated contact voltage 5-58VDC
1SNA608028R1100 OBC1000-220VAC Optocoupler R900 1SNA645026R2300 OBOC1000 230VACDC / 2A-58VDC R600
1SNA608068R2100 ORC111-24VDC Optocoupler R900 no replacement
1SNA608069R2200 ORA111-24VDC SORTIE 135VAC MAX Optocoupler R900 no replacement
1SNA010014R1200 RB211-24VDC Relay R1800 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600 no CSA approval, min contact current 1mA
1SNA010055R2300 RB131-24VDC Relay R1800 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA010063R2300 RB310-24VDC Relay R1800 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA010064R2400 RB310-48VDC Relay R1800 1SNA645040R1500 RB122A 48-60V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA010126R1700 RB114A-24VAC-DC Relay R1800 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600 2 x pieces,min contact current 1mA
1SNA010127R1000 RB114A-48VAC-DC Relay R1800 1SNA645040R1500 RB122A 48-60V / 1mA TO 6A-250V R600 2 x pieces,min contact current 1mA
1SNA010151R2000 RB131CV 24VDC Relay R1800 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA010152R2100 RB131CV 48VDC Relay R1800 1SNA645040R1500 RB122A 48-60V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA010153R2200 RB131BCVR 110VAC Relay R1800 1SNA645541R0400 RBR122A 115V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA010154R2300 RB121CV 24VDC Relay R1800 1SNA645005R0700 RB121A 24V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA010155R2400 RB121CV 48VDC Relay R1800 1SNA645006R0000 RB121A 48-60V / 1mA TO 6A-250V R600 min contact voltage 1mA
ABB Inc.
Low Voltage Products
16250 W. Glendale Drive
New Berlin, WI 53151
Technical Support & Customer Service
Phone: 888-385-1221, Option 4
Email: lvps.support@us.abb.com
Web: www.abb.us/lowvoltage
1SXUX117001L0201, December 2013
Obsolete P/N Description Type Family Replacemet P/N
Description
Family Comments
1SNA010156R2500 RB121BCVR 110VAC Relay R1800 1SNA645007R0100 RB121A 115V / 1mA TO 6A-250V R600 min contact voltage 1mA
1SNA010158R0700 RB121A-115VAC-DC RC Relay R1800 1SNA645041R0200 RB122A 115V / 1mA TO 6A-250V R600 rated contact voltage250V
1SNA010168R0100 RB121A 115VAC DC Relay R1800 1SNA645041R0200 RB122A 115V / 1mA TO 6A-250V R600 rated contact voltage250V
1SNA010174R2700 RB122 12VDC Relay R1800 no replacement
1SNA010181R1700 RB131CV 24VDC Relay R1800 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600
1SNA010182R1000 RB131CV 48VDC Relay R1800 1SNA645040R1500 RB122A 48-60V / 1mA TO 6A-250V R600
1SNA010183R1100 RB131BCVR 110VAC Relay R1800 1SNA645041R0200 RB122A 115V / 1mA TO 6A-250V R600
1SNA010184R1200 RB121CV 24VDC Relay R1800 1SNA645005R0700 RB121A 24V / 1mA TO 6A-250V R600
1SNA010185R1300 RB121CV 48VDC Relay R1800 1SNA645006R0000 RB121A 48-60V / 1mA TO 6A-250V R600
1SNA010186R1400 RB121BCVR 110VAC Relay R1800 1SNA645007R0100 RB121A 115V / 1mA TO 6A-250V R600
1SNA010226R2300 RB121A 110/135VAC DC Relay R1800 1SNA645041R0200 RB122A 115V / 1mA TO 6A-250V R600 rated supply / coil voltage 115VAC/DC
1SNA010228R0500 RB122A-135VAC-DC Relay R1800 no replacement with
135VAC/DC 2c/o
1SNA010570R0000 RB 122 S - 230V Relay R1800 no replacement
1SNA610004R0700 RB121A-24VAC-DC Relay R1800 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600 rated contact voltage 250V
1SNA610006R0100 RB121A-48VAC-DC Relay R1800 1SNA645040R1500 RB122A 48-60V / 1mA TO 6A-250V R600
1SNA610011R2500 RB122AR-110VAC-DC Relay R1800 1SNA645041R0200 RB122A 115V / 1mA TO 6A-250V R600
1SNA610059R1500 RB122-24VDC Relay R1800 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA610060R1200 RB122-48VDC Relay R1800 1SNA645040R1500 RB122A 48-60V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA610089R0400 RB122BR-220VAC Relay R1800 1SNA645013R2600 RB122A 230V / 1mA TO 6A-250V R600
1SNA610115R2200 RB122BR-110VAC Relay R1800 1SNA645041R0200 RB122A 115V / 1mA TO 6A-250V R600 min contact current 1mA
1SNA610121R2000 RB122AV-24VAC-DC Relay R1800 1SNA645012R2500 RB122A 24V / 1mA TO 6A-250V R600
1SNA610122R2100 RB122AV-48VAC-DC Relay R1800 1SNA645040R1500 RB122A 48-60V / 1mA TO 6A-250V R600
1SNA610123R2200 RB122A-220VAC-DC Relay R1800 1SNA645013R2600 RB122A 230V / 1mA TO 6A-250V R600
1SNA610125R2400 RB121A 12V Relay R1800 no replacement
1SNA610132R2300 RB121A-110-220VAC-DC Relay R1800 1SNA645041R0200 RB122A 115V / 1mA TO 6A-250V R600 rated supply / coil voltage 115VAC/DC
1SNA011093R0700 ROB 121 24VDC Relay R1800
1SNA010031R1300 EB IDC5 Optocoupler R1800 1SNA645047R0000 OBIC0100 5-12VDC / 100mA-58VDC R600
1SNA010033R1500 EB IDC24 Optocoupler R1800 1SNA645021R2600 OBIC0100 24VDC / 100mA-58VDC R600
1SNA010034R1600 EB OAC5 Optocoupler R1800 no replacement
1SNA010036R1000 EB OAC24 Optocoupler R1800 1SNA645027R2400 OBOA1000 24VDC / 1A-24 TO 400 R600
1SNA010037R1100 EB ODC5 Optocoupler R1800 1SNA645050R1700 OBOC1000 5-12VDC / 2A-58VDC R600 rated contact voltage 5-58VDC
1SNA010039R2300 EB ODC24 Optocoupler R1800 1SNA645051R0400 OBOC1000 24VDC / 2A-58VDC R600 rated contact voltage 5-58VDC
1SNA010048R0400 EBO1-48VAC-DC Optocoupler R1800 1SNA645049R1200 OBIC0100 48-60V / 100MA-58VDC R600
1SNA010131R1400 EB01R 5VDC Optocoupler R1800 no replacement
1SNA610022R2000 EB01-24VAC-DC Optocoupler R1800 1SNA645025R2200 OBOC1500 24VACDC / 2A-58VDC R600 rated contact voltage 5-58VDC
1SNA610023R2100 EB01-220VAC-DC Optocoupler R1800 1SNA645022R2700 OBIC0100 115-230VACDC / 100mA- R600 rated contact voltage 5-58VDC
1SNA610108R1400 EBO1-127VAC-DC Optocoupler R1800 1SNA645022R2700 OBIC0100 115-230VACDC / 100mA- R600 rated contact voltage 5-58VDC
1SNA610230R1100 EB03-DC Optocoupler R1800 1SNA645049R1200 OBIC0100 48-60V / 100MA-58VDC R600
1SNA011119R1500 EBO2MOS-EMERAUDE Optocoupler R1800 no replacement
Important dates
Once a product enters the obsolete phase, it is no longer pro-
moted and will be removed from the product catalog. Therefore,
long-term requirements and last buy decisions should be based
on the following:
• Last time to order: Dec. 31, 2013 or until stock is depleted
• Obsolete phase: Jan. 1, 2014
Support and availability
• Product is no longer manufactured nor supported by development
•
Product availability may continue, but is not guaranteed
• Service support (field service, phone support, etc.) continues,
but may diminish over time with decreasing installed base.
• Spare parts are available while stock lasts
Obsolete phase
A product is transferred to the obsolete phase when it is no lon-
ger possible to provide services at reasonable cost, or when ABB
can no longer support the product technically, or the old technol-
ogy is not available.
