Test Tools Catalog

Digital Multimeters

Clamp Meters

Electrical Testers

Insulation Testers

Earth Ground Testers

Installation Testers

Portable Appliance Testers

Digital Thermometers

Thermal Imagers

Distance Meters

Indoor Air Quality Tools

ScopeMeter® Test Tools

Power Quality Tools

Field Calibrators

Vibration Tester

Radiation Tester

EX Test Tools

Accessories

Fluke web and electronic newsletter .................................................... 1

New from Fluke........................................................................................ 2-3

Fluke Combo Kits ..................................................................................... 4-5

Application/background articles ...................................................... 6

Fluke After Sales Service .................................................................. 7

Fluke where safety is built in .......................................................... 8-9

Fluke web/campaign ......................................................................... 10

Digital Multimeters ............................................................................ 11

DMM Selection Guide ....................................................................... 12

280 Series Digital Multimeters ....................................................... 13

233 Remote Display Multimeter ...................................................... 14

80 Series V Digital Multimeters ....................................................... 15

170 Series Digital Multimeters ........................................................ 16

110 Series II Digital Multimeters .....................................................17

27 II / 28 II Rugged Industrial Multimeters ....................................18

77 IV Digital Multimeter ...................................................................19

88V Automotive Meter ...................................................................... 20

8845A/8846A 6.5 Digit Precision Multimeters ............................... 21

8808A 5.5 Digit Multimeter .............................................................. 22

Thermal Imagers ............................................................................... 58

Ti Series Thermal Imagers ...............................................................59

Ti32/Ti29/Ti27 Industrial Thermal Imagers ...................................60-61

TiR32/TiR29/TiR27 Industrial Thermal Imagers

for Building Diagnostics ................................................................... 62-63

Ti125/Ti110/Ti100 Industrial / Commercial Thermal Imagers ....64-65

TiR125/TiR110/Ti100 Building Diagnostic Thermal Imagers ....... 66-67

Ti9/Ti10/Ti25 Thermal Imagers ....................................................... 68-69

TiS/TiR/TiRx/TiR1 Thermal for Building Inspection ..................... 70-71

Hawk IR CRange IRWindows ........................................................... 72

Digital Thermometers ....................................................................... 49

Infrared Thermometer Selection Guide ......................................... 50

570 Series Precision Infrared Thermometers ................................ 51

60 Series Infrared Thermometers ...................................................52

566/568 Multipurpose Thermometers ............................................ 53

561 Multipurpose Thermometer ..................................................... 54

50 Series II Thermometers ............................................................... 55

1523/1524 Reference Thermometers .............................................. 56

1551A/1552A Ex “Stik” Thermometers ........................................... 57

Installation Testers/Portable Appliance Testers .............................. 43

1650 Series Multifunction Installation Testers.............................. 44-45

6000 Series Portable Appliance Testers .......................................... 46-47

1650/6000 Series Accessories ........................................................... 48

Insulation Testers/Earth Ground Testers .........................................35

Insulation Tester Selection Guide ................................................... 36

1577/1587 Insulation Multimeters ..................................................37

1503/1507 Insulation Testers ...........................................................38

1555/1550C Insulation Resistance Testers ....................................39

1620 Series Earth Ground Testers ................................................... 40

1621 Earth Ground Tester ................................................................. 41

1630 Ground Loop Tester .................................................................. 42

Clamp Meters and Electrical Testers ................................................23

Clamp Meter selection guide ........................................................... 24

381/365 Clamp Meters ...................................................................... 25

370 Series Clamp Meters .................................................................. 26

320 Series / 902 Clamp Meters ......................................................... 27

353/355 AC/DC Clamp Meters .......................................................... 28

360 Current Leakage Clamp Meter ................................................. 29

T100 Series Voltage/Continuity Testers ..........................................30

T5/T5-H5-1AC Kit Electrical Testers ................................................ 31

2AC/1AC-II/LVD1/LVD2 Voltage Detectors ...................................... 32

9040/9062 Phase Rotation Indicators .............................................. 33

2042 Cable Locator ............................................................................34

Indoor Air Quality Tools .................................................................... 75

975 Air Meter ...................................................................................... 76

922 Airflow Meter .............................................................................. 77

971 Temperature Humidity Meter ................................................... 78

983 Particle Counter .......................................................................... 79

Field Calibrators ................................................................................. 101

Field Calibrator Selection Guide ...................................................... 102

750 Series Documenting Process Calibrators ................................ 103

726/725/725Ex Multifunction Process Calibrators ........................ 104

724 Temperature Calibrator ............................................................. 105

712/714 Temperature Calibrators .................................................... 106

914X/418X Drywells/IR Calibrators ................................................. 107

717/718/718Ex/719 Pressure Calibrators ......................................... 108

705/707/707Ex/715 Loop Calibrators ............................................... 109

771/772/773 mA Clamp Meters ........................................................ 110

787/789 ProcessMeters......................................................................111

Field Calibrator Accessories ............................................................. 112

Power Quality Tools ........................................................................... 87

Power Quality Selection Guide ........................................................ 88

345 Power Quality Clamp Meter ...................................................... 89

43B Single-phase Power Quality Analyzer ..................................... 90

1710 Single-Phase Voltage Quality Recorder ................................. 91

430 II Series Three-phase Power Quality Analyzers ..................... 92-93

1735 Power Logger ............................................................................. 94

1740 Series Power Quality Loggers.................................................. 95

1750 Power Recorder ......................................................................... 96

1760 Power Quality Recorder ........................................................... 97

Power Quality Current Clamp Accessories .................................... 98

Norma 4000/5000 Series ................................................................... 99-100

ScopeMeter® Test Tools ...................................................................... 80

ScopeMeter 190 Series II .................................................................. 81-83

ScopeMeter 120 Series ..................................................................... 84

ScopeMeter 225C/S and general specifications ............................ 85

ScopeMeter Accessories ................................................................... 86

Fluke. Keeping your world up and running

Contents

Laser Distance Meters ....................................................................... 73

421D/416D/411D Laser Distance Meters ........................................ 74

General Accessories ........................................................................... 120

Electronic Test Leads, Probes & Clips ............................................. 121

Industrial Test Leads, Probes & Clips .............................................. 122-123-124

Automotive Accessories ................................................................... 125

Current Clamps ................................................................................. 126-127

Temperature Accessories .................................................................128-129

Cases and Holsters ............................................................................ 130-131

Software and Other Accessories ..................................................... 132

Other Accessories .............................................................................. 133

Fuse and Warranty Information......................................................134

ATEX Certified Test Tools .................................................................. 117

A brief look at ATEX .......................................................................... 118

Fluke intrinsically safe tools ............................................................ 119

Vibration Tester .................................................................................. 113

810 Vibration Tester .......................................................................... 114

Radation Meter ...................................................................................115

481 Radation Meter ........................................................................... 116

riešenia na presné meranie

http://www.elso.sk

Fluke Web and

Electronic Newsletter

E-Test-it! is Fluke’s regular news

publication for professional test tool

users. It is electronically available 6

times per year. You will be the first to

hear about:

• New Fluke products

• The latest actions and promotions from Fluke

• How to get more out of Fluke tools

• How to use Fluke tools better in your

application

• Exclusive offers, promotions and discounts on

Fluke Merchandizing

• Exclusive offers on Fluke ex-demo equipment

E-Test-it! is free of charge. If at any point in time

you do not want to receive E-Test-it! anymore,

you can unsubscribe with a simple mouse click.

E-Test-it! is small in size (on average about 12

KB) and does not ll up your mailbox or take

long to download.

Try it now and sign-up for your FREE

e-Test-it! subscription.

Go to the Fluke web site and fill in the

on-line subscription form.

Fluke web

Electronic Newsletter

Fluke web sites are available in all countries around the world and in 18 different languages.

Complete information

The most complete and in-depth resource for

information on Fluke’s products and services

including:

• Product information

• Solution Centers

• Interactive selection guides

• Virtual product demonstrations

• Extended specications

• Application notes

• Product manuals

• Service information

• Promotions

• Prices

• Where to buy

• Distributor and sales ofce locations

Find information fast

To quickly nd more information on Fluke

products, use the “Search by model” box in the

top left corner of our web pages. All you have to

do is type in the model number.

UK: www.fluke.sk

IE: www.fluke.sk

Worldwide: www.fluke.sk

riešenia na presné meranie

http://www.elso.sk

New from Fluke

For the rst time, plant maintenance engineers and technicians can

take a high-performance four-channel scope into the harsh world of

industrial electronics.

See page 81-83.

The new 1654B Installation Tester builds upon the rugged reputation of the earlier

1650 Series, only it’s re-designed to meet your need for more

productive test tools.

See page 44 and 45.

Fluke 750 series process calibrators can help you get the job done faster. It does so

many different tasks, so quickly and so well, it’s the only process calibrator you need

to carry.

See page 103.

The new Fluke 381 does everything you would expect from a clamp meter, and then

lets you remove the display for even more exibility.

See page 25.

Fluke 190 Series II Scopemeter

Fluke 1654B Multifunction Installation Tester

Fluke 750 series Documenting Process Calibrators

Fluke 381 Remote Display True-rms AC/DC ClampMeter with iFlex

Fluke proudly introduces an entry level thermal imager for quick, easy, and

accurate problem identication and troubleshooting designed specically for

the building inspection professional.

See page 70 and 71.

The Fluke 365 is a new, innovative Fluke clamp meter, offering a thin,

small jaw design that makes it easy to get around tightly packed wires.

See page 25.

With this new family of clamp meters, Fluke provides a range of state of-the-art

capabilities to meet users’ most demanding requirements for exibility, safety and

performance.

See page 26.

Fluke TiS Thermal Imaging Scanner

Fluke 365 Detachable Jaw True-rms AC/DC Clamp Meter

Fluke 370 series Clamp Meters

riešenia na presné meranie

http://www.elso.sk

New from Fluke

Designed for industrial and commercial environments, the Fluke P3 series of thermal

imagers deliver superior image quality, versatility, and affordability without compromise.

See page 60-63.

The new Fluke 434, 435 and 437 Series II models help locate, predict,

prevent, and troubleshoot power quality problems in three-phase

and single-phase power distribution systems.

See page 92-93.

The new 1555 and redesigned Fluke 1550C insulation resistance testers offer digital

insulation testing up to 10kV, making them ideal for testing a wide range of high

voltage equipment including switchgear, motors, generators and cables.

See page 39.

Fluke Ti27/Ti29 Thermal Imagers

Fluke 430 Series II

Three-Phase Power Quality and Energy Analyzers

Fluke 1555/1550C Insulation Resistance Testers

Fluke proudly introduces ve new thermal imagers specically designed to help you do

more in less time, while being at home in the harshest of environments. A project that

might normally take an hour can now be done in minutes. Our newest imagers are the

lightest, most rugged, easiest-to-use professional imagers you can buy.

See page 64-67.

Accurate and repeatable to ± 0.05 °C over its full range, the 1551A/1552A “Stik”

Thermometer is the new “gold standard” of industrial temperature calibration.

See page 57.

The new Fluke TL175 TwistGuard™ Test Leads are the innovative test leads with adjustable

length test tips for use in different measurement environments.

See page 124.

Ti125/Ti110/Ti100/TiR125/TiR110 Thermal Imagers

1551A Ex and 1552A Ex “Stik” Thermometer

TL175 Twistguard™ Test Leads

riešenia na presné meranie

http://www.elso.sk

Fluke Combo Kits

Fluke 179/TPAK

179/ToolPak Combo Kit

• Fluke 179 True RMS

Multimeter

• TPAK ToolPak Meter Hanging

Kit

Fluke 87V/E2

Industrial Electrician

Combo Kit

• Fluke 87V True RMS

Multimeter

• TL224 SureGrip™ Silicone Test

Lead Set

• TP38 Slim Reach Test Probe

Set (insulated)

• AC220 SureGrip™ Alligator

Clip Set

• TPAK Magnetic Hanger

• 80BK-A Integrated DMM

Temperature Probe

• C35 Soft Meter Case

Fluke 179/EDA2 Kit

Electronics Combo Kit

• Fluke 179 True RMS

Multimeter

• TL224 SureGrip™ Silicone Test

Lead Set

• TL910 Electronic Test Probe

Set

• AC280 SureGrip™ Hook Clip

Set

• TPAK Magnetic Hanger

• 80BK-A Integrated DMM

Temperature Probe

• C35 Soft Meter Case

Fluke 179/61 Kit

Multimeter and Infrared

Thermometer Combo Kit

• Fluke 179 True RMS

Multimeter

• Fluke 61 Infrared

Thermometer

• C550 Hard Meter and

Accessory Case

Fluke 179/MAG2 Kit

Industrial Combo Kit

• Fluke 179 True RMS

Multimeter

• TL224 SureGrip™ Silicone Test

Lead Set

• AC220 SureGrip™ Alligator

Clip Set

• TP74 lantern tip test probe set

• TPAK Magnetic Hanger

• 80BK-A Integrated DMM

Temperature Probe

• C35 Soft Meter Case

• + Maglite ashlight

Fluke 117/322 Kit

Electrician’s Combo Kit

• Fluke 117 True RMS

Multimeter

• Fluke 322 Clamp Meter

• Silicon test lead set

• TPAK Magnetic Hanger

• C115 Deluxe carrying case

with shoulder strap

Fluke 87V/i410

Combo Kit for Industrial

Applications

• 87V Industrial Multimeter

• TL75 Test Leads

• AC172 Alligator Clips

• i410 400A AC/DC Current

Clamp

• 80BK-A Temperature Probe

• C115 Soft Carrying Case

(Not available in all countries)

Buy a Combo Kit and save

Ordering Information

Fluke 117/322 Kit

Fluke 179/TPAK

Fluke 179/61 Kit

Fluke 179/MAG2 Kit

Fluke 179/EDA2 Kit

Fluke 87V/E2

Fluke 87V/i410

riešenia na presné meranie

http://www.elso.sk

Fluke Combo Kits

Fluke T5-600/62/IAC-E Kit

• Fluke T5-600 Electrical Tester

• Fluke 62 Mini IR Thermometer

• Fluke 1AC-II Volt Alert

• C115 Soft Meter Case

Fluke T5-H5-1AC Kit

• Fluke T5-1000 Electrical Tester

• H5 Holster

• 1AC-II Volt Alert

Fluke 1587/ET Advanced

Electrical Troubleshooting Kit

• Fluke 1587 Insulation Multimeter

• Fluke 62 Mini Infrared

Thermometer

• I400 Current Clamp

Fluke 1587/MDT

Advanced Motor & Drive

Troubleshooting Kit

• Fluke 1587 Insulation

Multimeter

• Fluke 9040 Phase Rotation

Indicator

• I400 Current Clamp

Fluke 62/322/1AC Kit

• Fluke 62 Mini IR Thermometer

• Fluke 322 Clamp Meter

• Fluke 1AC-II Volt Alert

Fluke 411D/62 Kit

• Fluke 411D Laser Distance

Meter

• Fluke 62 Mini IR Thermometer

• Soft case for each model

Fluke 289/FVF Industrial

Logging Multimeter and

Software Combo Kit

• Fluke 289 True-RMS

Multimeter

• FVF-SC2 FlukeView Forms

Software and cable

• Silicon Test Lead Set

• AC172 Alligator Clips

• 80BK-A Integrated DMM

Temperature Probe

• TPAK Magnetic Meter Hanger

for hands-free operation

• C280 Soft Case for meter

protection and accessory

storage

Buy a Combo Kit and save

Ordering Information

Fluke 287/FVF

Fluke 289/FVF

Fluke 1587/ET

Fluke 1587/MDT

Fluke T5-H5-1AC Kit

Fluke T5-600/62/IAC-E Kit

Fluke 62/322/1AC Kit

Fluke 411D/62 Kit

Fluke 287/FVF FlukeView

Forms Combo Kit

• Fluke 287 True RMS Electronic

Logging Multimeter with

TrendCapture

• FVF-SC2 FlukeView Forms

Software and cable

• 80BK-A Thermocouple Probe

• CAT III 1000 V 10 A Modular

Test Leads (red, black)

• CAT II 300 V 5 A Alligator Clips

(red, black)

• C280 Soft Case for meter

protection and accessory

storage

Fluke 1587/MDT

riešenia na presné meranie

http://www.elso.sk

Application/

background articles

As part of our commitment to supporting you in your work we do

more than just design and manufacture rugged and versatile test tools:

we also provide application notes which all can be downloaded from

our web site. Furthermore check out our “total solutions” campaigns

on the website. In addition to inspection tips and helpful application

information, these campaigns also offer advice on picking the right tool

for the job.

riešenia na presné meranie

http://www.elso.sk

So why should you use Fluke service?

• Original manufacturers’ parts used

• All instruments reviewed for latest updates

• Repair warranty that covers whole unit

• In depth product knowledge

• Accredited calibrations available

• Traceable calibrations available on all

products

• Full check of unit during verication cycle

• Full safety test on mains powered units

What other instruments can we help

you with?

We also offer a range of calibrations and

repairs on other manufacturer’s equipment

upon request. Manufacturers such as:

• Tektronix

• Agilent

• Bruel & Kjaer

• Philips

• Megger

• Seaward

• Kewtech

• Lecroy

• Hioki

• Yokogawa

• Druck

• Iwatzu

• plus many more ...

Did you know that the Fluke after sales

service team can offer you much more

than just repairing and calibrating your

instrument when it is needed? Across

our whole Fluke European service

organization we have a vast range of

capabilities, which can be utilized via

your local service centre. Behind the

scenes Fluke draws on the expertise of

over 150 service staff that are focused

on offering only the best and most

comprehensive after sales service.

What other value added services do

we offer?

• Gold Support for Fluke Networks

• Gold CarePlans for calibration products

• A full range of maintenance contracts

• Extended warranty programs

• Instrument upgrades

• Option retrots

• Asset management

• Calibration reminders

What services do we offer you?

• 5 day repairs on all current products

• 5 days or less on all calibrations (excl.

repairs)

• 3 days for all Gold CarePlan calibrations

• 1-2 days on all Networks Gold calibration

• Pick up services where available

Let Fluke After Sales Service

help you further

Eindhoven Norwich Cologne

Telephone +31 (0)40 267 5300 +44 (0)1603 256620 +49 (0)69 2222 20210

Telefax +31 (0)40 267 5321 +44 (0)1603 256688 +49 (0)69 2222 20211

Email servicedesk@fluke.nl ukservicedesk@fluke.com servicedeskgermany@fluke.com

Address Science Park 5108

Eindhoven

5692 EC Son

Netherlands

52 Hurricane Way

Norwich

Norfolk

NR6 6JB

United Kingdom

Heinrich-Pesch-Str. 9-11

50739 Köln

Germany

Contact Information

Fluke Brands Instrument Types

Fluke Digital Multimeters

Hart Scientific Electrical Standards

Fluke Networks Biomedical Equipment

Fluke Biomedical Data Loggers

Raytek Thermal Imagers

Reliable Power Meters Thermometers

Robin Pressure

LEM Instruments Function Generators

BEHA Oscilloscopes

Norma Installation Testers

Wavetek/Datron PAT Testers

Metron Clamp Meters

DHI Power Analyzers

Comark EX meters

Plus many more

Fluke service centres handle a wide range

of equipment.

As part of Fluke’s continuing focus on improving

our service to our customer we now offer a

comprehensive range of repairs and calibrations

on a vast range of equipment.

Fluke manufactures equipments such as:

On-Line booking in system

Why not use our On-Line booking in system

where you can book your unit in, get pricing

and receive a RMA number for a smooth

return.

www.uke.com/servicerma

riešenia na presné meranie

http://www.elso.sk

Table 1

Figure 1. Understanding categories: location

Overvoltage installation categories. IEC 61010-1 applies to low-voltage (< 1000V) test equipment

Fluke: Where safety is built in

Overvoltage category In brief Examples

CAT IV Three-phase at utility connection,

any outdoor conductors • Refers to the “origin of installation”; i.e., where low-voltage connection is made to utility power.

• Electricity meters, primary overcurrent protection equipment.

• Outside and service entrance, service drop from pole to building, run between meter and panel.

• Overhead line to d etached building, underground line to well pump.

CAT III Three-phase distribution, including

single-phase commercial lighting • Equipment in xed installations, such as switchgear and polyphase motors.

• Bus and feeder in industrial plants.

• Feeders and short branch circuits, distribution panel devices.

• Lighting systems in larger buildings.

• Appliance outlets with short connections to service entrance.

CAT II Single-phase receptable

connected loads • Appliance, portable tools, and other household and similar loads.

• Outlet and long branch circuits.

• Outlets at more than 10 meters (30 feet) from CAT III source.

• Outlets at more than 20 meters (60 feet) from CAT IV source.

CAT I Electronic • Protected electronic equipment.

• Equipment connected to (source) circuits in which measures are taken to limit transient overvoltages

to an appropriately low level.

• Any high-voltage, low-energy source derived from a high-winding resistance transformer, such as the

high-voltage section of a copier.

As distribution systems and loads

become more complex, the possibilities

of transient overvoltages increase.

Motors, capacitors and power conversion

equipment such as variable speed drives

can be prime generators of spikes.

Lightning strikes on outdoor transmission

lines also cause extremely hazardous

high-energy transients. If you’re taking

measurements on electrical systems,

these transients are “invisible” and

largely unavoidable hazards. They occur

regularly on low-voltage power circuits,

and can reach peak values in the many

thousands of volts. To protect you against

transients, safety must be built into the

test equipment.

Who Develops Safety Standards?

The IEC (International Electrotechnical

Commission) develops international general

standards for safety of electrical equipment

for measurement, control and laboratory

use. IEC61010-1 is used as the basis for the

following national standards:

• US ANSI/ISA-S82.01-94

• Canada CAN C22.2 No.1010.1-92

• Europe EN61010-1:2001

Overvoltage Installation Categories

IEC61010-1 species categories of

overvoltage based on the distance the piece

of equipment is from the power source

(see Fig. 1 and Table 1) and the natural

damping of transient energy that occurs

in an electrical distribution system. Higher

categories are closer to the power source and

require more protection.

Within each installation category there are

voltage classications. It is the combination of

installation category and voltage classication

which determines the maximum transient

withstand capability of the instrument.

IEC 61010 test procedures take into account

three main criteria: steady-state voltage,

peak impulse transient voltage and source

impedance. These three criteria together will

tell you a multimeter’s true voltage withstand

value.

Within a category, a higher working voltage”

(steadystate voltage) is associated with a

higher transient, as would be expected. For

example, a CAT III 600 V meter is tested

with 6000 V transients while a CAT III 1000 V

meter is tested with 8000 V transients.

So far, so good. What is not as obvious is the

difference between the 6000 V transient for

CAT III 600 V and the 6000 V transient for

CAT II 1000 V. They are not the same. This is

where the source impedance comes in. Ohm’s

Law (Amps = Volts/Ohms) tells us that the 2 

test source for CAT III has six times the current

of the 12  test source for CAT II. The CAT III

600 V meter clearly offers superior transient

protection compared to the CAT II 1000 V

meter, even though its so-called “voltage

rating” could be perceived as being lower. See

Table 2.

Independent testing is the key to safety

compliance

How can you tell if you’re getting a genuine

CAT III or CAT II meter? Unfortunately it’s

not always that easy. It is possible for a

manufacturer to self-certify that its meter

is CAT II or CAT III without any independent

verication. The IEC (International

Electrotechnical Commission) develops and

proposes standards, but it is not responsible

for enforcing the standards. Look for the

symbol and listing number of an independent

testing lab such as UL, CSA, VDE, TÜV or other

recognized approval agency.

These symbols can only be used if the product

successfully completed testing to the agency’s

standard, which is based on national and

international standards. UL 3111, for example,

is based on EN61010-1. In an imperfect world,

this is the closest you can come to ensuring

that the meter you choose was actually tested

for safety.

riešenia na presné meranie

http://www.elso.sk

Select the right test tool:

• Choose a test tool rated to the highest

category and voltage for which it could

possibly be used (most often 600 or 1000

volt CAT III and/or 600 volt CAT IV).

• Look for the category and voltage marking

near the recessed input connectors of your

test tool and a “double insulated” symbol

on the back.

• Verify your test tool has been tested and

certied by two or more independent

testing laboratories, such as UL in the

United States and VDE or TüV in Europe by

looking for the symbols of these agencies

on (the back of) your test tool.

• Make sure that the test tool is made of

a high-quality, durable non-conductive

material.

• Check the manual to verify that the

ohms, continuity and capacitance circuits

are protected to the same level as the

voltage test circuit, to reduce hazards

when the test tool is used incorrectly in

ohms, continuity or capacitance mode (if

applicable).

• Verify that the test tool has internal

protection to prevent instrument damage

when voltage is incorrectly applied to

an amperage measurement function (if

applicable).

• Make sure that the amperage and

voltage of your test tool’s fuses meets

specications. Fuse voltage must be as high

or higher than the test tool’s voltage rating.

• Be sure to use test leads that have:

- Shrouded connectors

- Finger guards and a non-slip surface

- Category ratings that equal or exceed

those of the test tool

- Double insulation (look for the symbol)

- A minimum of exposed metal on the

probe tips

Safety is everyone’s responsibility but

ultimately it is in your hands.

No tool by itself can guarantee your safety

when working with electricity. It’s the

combination of the right tools and safe

work practices that gives you maximum

protection. Here are a few tips to help you

in your work:

Make sure you always comply with (local)

regulations.

Work on de-energized circuits whenever

possible.

Use proper lock-out/tag-out procedures. If these

procedures are not in place or enforced, assume

that the circuit is live.

Use protective gear when working on live

circuits:

• Use insulated tools

• Wear safety glasses or a face shield

• Wear insulated gloves, remove watches or

jewelry

• Stand on an insulated mat

• Wear ame resistant clothing, not ordinary

work clothes

Inspect and test your test tool:

• Check for a broken case, worn test leads or

a faded display.

• Make sure the batteries still deliver

sufcient power to get reliable readings.

Many test tools have a low battery indicator

on the display.

• Check the test leads resistance for internal

breaks while moving the leads around

(good leads measure 0.1-0.3 Ohm).

• Use the meter’s own test capability to

ensure that the fuses are in place and

working right (see manual for details).

Apply the appropriate working

practices when measuring on live

circuits:

• Hook on the ground clip rst, then make

contact with the hot lead. Remove the hot

lead rst, the ground lead last.

• Use the three-point test method, especially

when checking to see if a circuit is dead.

First test a known live circuit. Second,

test the target circuit. Third, test the live

circuit again. This veries that your test

tool worked properly before and after the

measurement.

• Hang or rest the test tool if possible.

Try to avoid holding it in your hands, to

minimize personal exposure to the effects

of transients.

• Use the old electrician’s trick of keeping

one hand in your pocket. This lessens the

change of a closed circuit across your chest

and through your heart.

Fluke: Where safety is built in

Overvoltage

Installation

See also page 48 for more details

Speciﬁcations

BDST3 Snap Tags

Cable Tie PASS

Appliance 560R

Pass Labels

SP-SCAN-15

Barcode scanner

(6500 Fluke only)

SP1000-02

Mini printer

Fluke PowerPat Plus

software

riešenia na presné meranie

http://www.elso.sk

ES165X Earth Spike Test Kit

(Fluke 1653B and 1654B)

Earth Spike Test kit contents:

• Auxiliary earth probes

• Test connection leads and crocodile clips

• Purpose-made carry case

1650 Series/6000 Series

Accessories

FVF-SC2 Fluke ViewForms Software

(Fluke 1653B)

To address the increasing demands for

reporting and documentation, Fluke presents

FlukeView Forms documenting software.

Download the data from the Fluke 1653B and

create an easy report. The Fluke ViewForms

Software also supports other Fluke tools.

See page 132.

TLK 290 Test Probe Kit

• Kit includes three exible socket probes and

a large alligator clip

• To be used on three phase sockets

• Probes have exible width test points that t

securely in 4 to 8 mm sockets

• CAT III 1000 V, 8 A

Mains Test Cord for 1650B series

MTC1363 UK plug

MTC77 Schuko plug

PASS560R Appliance Pass Labels

Quantity 500

APP1000/APP2000 Bar Code Appliance

Number Labels

APP1000: Labels numbered 0001-1000

APP2000: Labels numbers 1001-2000

Label number >2000 on request

BDST3/BDST4 Snap Tags

BDST3: Cable Tie

BDST4: Clip On

Quantity 20. Without labels.

EXTL100 Extension Lead Test Adaptor

Adaptor for testing extension leads. Allows

the earth test lead to be connected to the

extension leads to perform insulation and

earth bond tests.

SPScan15 Barcode Scanner

Easy to use, low current, intelligent barcode

reader. SPScan15 can be used to scan barcodes

attached to curved surfaces or where actual

contact with the barcode surface is difcult.

SP1000 Mini Printer

Without using any additional software the

SP1000 can be used to directly printout stored

test records on to thermal paper. The printer

is compact and easily transported and is ideal

for test professionals who need to issue an

immediate written account of work carried

out. The printer is powered by a rechargeable

battery and comes complete with mains

charger and RS232 Printer Lead.

SP1000 Paper

Replacement thermal paper for the SP1000

Mini Printer

Fluke DMS software for

1650/6000 Series

The Fluke DMS (Data Management Software)

is an efcient program for administration and

reporting of installation tests in compliance

with EN 60364, DIN VDE 0100/0105, BS7671

17th edition wiring resulation and appliance

tests in compliance with DIN VDE 0701/0702,

ÖVE E 8701.

DMS 0100/INST Software for Installation

Tester Fluke 1653B and 1654B

Supporting reports for Austria, Germany, UK,

Switzerland, Netherlands

DMS 0702/PAT Software for Portable

Appliance Tester Fluke 6500

Supporting reports for Austria, Germany, UK,

Netherlands

DMS COMPL PROF Software for the Fluke

1654B, 1653B and Fluke 6500

Supporting reports for Austria, Germany, UK,

Switzerland, Netherlands

EXTL100-02 (Schuko plug)EXTL100-02 (UK plug)

MTC77MTC1363

Accessories for Fluke 1650

Series Installation Testers

Accessories for Fluke 6500 Series

Portable Appliance Testers

riešenia na presné meranie

http://www.elso.sk

For troubleshooting systems where temperature is a critical symptom,

our digital thermometers provide you with laboratory accuracy wherever

you need it. We offer a choice of non-contact, laser-guided infrared

thermometers for safely getting at hard-to-reach, electrically live or

particularly hot targets, and contact thermometers with a full range of

thermocouple probes.

Digital Thermometers

riešenia na presné meranie

http://www.elso.sk

Infrared Thermometer

Selection Guide

Infrared Thermometer

Selection Guide

Fluke 60 Series Fluke 560 Series Fluke 570 Series

Fluke 61 Fluke 62 Fluke 63 Fluke 561 Fluke 566 Fluke 568 Fluke 572 Fluke 574

Temperature range -18 to 275 ºC -30 to 500 ºC - 32 to 535 ºC - 40 to 550 ºC - 40 to 650 ºC - 40 to 800 ºC - 30 to 900 ºC - 30 to 900 ºC

Accuracy 2% 1.5% 1% 1% 1% 1% 0.75% 0.75%

Response time < 500 mSec < 500 mSec < 500 mSec < 500 mSec < 500 mSec < 500 mSec < 250 mSec < 250 mSec

Optical resolution 8:1 10:1 12:1 12:1 30:1 50:1 60:1 (50:1

with close

focus)

60:1 (50:1

with close

focus)

Close focus model

available

Recommended distance

to spot Up to 2 m Up to 2 m Up to 2.5 m Up to 2.5 m Up to 4.5 m Up to 7.5 m 300 mm

(with close

focus) up to 10.5 m

300 mm

(with close

focus) up to 10.5 m

Laser sighting single-point

laser single-point

laser single-poimt

laser single-point

laser 3-point

laser

Adjustable emissivity

OOOOO

MIN/MAX readings -/

OOOOOO

AVG readings

OO O

DIF readings

OOO O

Backlit LCD

OOOOOOOO

Bar graph display

Audible Hi/Lo alarm

Visible Hi/Lo alarm

Includes contact probe

OOO O

Probe input (types) Type K Thermocouple Type K Thermocouple Type K Thermocouple Type K Thermocouple

Data logging

(number of

measurements) 20 points 99 points 100 points

PC interface USB RS232

Compatible with

FlukeView Forms

software

See catalog page 52 52 52 54 53 53 51 51

Recommended Applications

Safety and protection

Fire localization

Hazardous materials

Faulty ballasts

Search and rescue

Smoldering embers

Equipment maintenance

Manufacturing processes

Molding temperature measurement

Printing, paper and converting

Thermoforming plastics

Electronics

Paint curing/drying

Food

Chemical and pharmaceutical

Heating/ventilation/air conditioning/

refrigeration

Leaky ductwork

Thermostats

Temperature balancing

Steam distribution systems

Compressor lines

Plant/facilities maintenance

Preventive and predictive maintenance

Energy audits

Vehicle and fleet maintenance

programs

Faulty electrical/circuit connections

Petrochemical/hazardous locations

Motors, pumps and bearings

Contact thermometers

For our complete range of contact

thermometers, see page 55.

riešenia na presné meranie

http://www.elso.sk

570 Series

Precision Infrared Thermometers

572 574

Temperature range -30 to 900ºC

Optical resolution Standard: 60:1

Close focus: 50:1

3 dot laser beam for accurate targeting

Adjustable emissivity

Bar graph display

Backlit LCD display

Use selectable ºC or ºF

Audible and visible Hi/Lo Alarm

MIN/MAX

AVG/DIF readings

Datalogging (number of measurements) 100

PC interface RS232

572 574

Temperature range -30 to 900°C

Response time 250ms (95 % of reading)

Resolution 0.1°C of reading up to 900°C

Repeatability ±0.5% of reading or ±1°C*

Accuracy: (assumes ambient operating temperature of 23 ºC to 25 ºC ) ±0.75% of reading, ±0.75°C *

Typical distance to target 10,5 m

Emissivity Digitally adjustable from 0.10 to 1.0

by 0.01

*whichever is greater.

Features

Included Accessories

Fluke 572: Hard case, 2 batteries

Fluke 574: Hard case, 2 batteries, Thermocouple

K probe, 220V power supply, IRGraph software,

RS232 cable

Ordering Information

Fluke 572 Precision Infrared Thermometer

Fluke 574 Precision Infrared Thermometer

Fluke 572CF Precision Infrared Thermometer

with close focus option

Fluke 574CF Precision Infrared Thermometer

with close focus option

The Fluke 570 series are the most

advanced IR non-contact thermometers,

and are ideal for predictive and

preventative maintenance applications.

Offering a broad temperature range

and a true dimension laser sighting

system for precise targeting resulting

in more accurate measurements. When

requiring analysis and documentation

use the 100-point data logging and

software for graphing and analysis.

From close-up electrical connections, to

far-distance room balancing checks, the

Fluke 570 series can take IR temperature

measurements with ease and precision.

• Enhanced optics allows measurements

of smaller objects from farther away

• True Dimension™ three-dot laser

sighting system highlights the true

diameter of measurement spots at all

distances

• Adjustable emissivity setting and 30

pre-set common material values for

more accurate measurements

• 100 data point memory for storage of

measurements (Fluke 574).

Speciﬁcations

Battery Life: 10 hours typical

Weight: 0.480 kg

Size (HxWxD): 200 mm x 170 mm x 55 mm

Two years warranty

AN5

Analog data cable

Recommended Accessories

Measure temperature with ease and

precision

Fluke 572

Fluke 574

riešenia na presné meranie

http://www.elso.sk

61 62 63

Range - 18 to 275ºC - 30 to 500 ºC - 32 to 535 ºC

Response time < 500ms < 500ms

(95 % of reading) ≤ 0.5 second

Resolution 0.2 ºC 0.2 ºC 0.2 ºC

Repeatability

(% of reading) ± 2%

or ± 2 ºC* ± 0.5%

or < ± 1 ºC* ± 0.5%

or ≤ ± 1 ºC*

Accuracy:

(assumes ambient operating temperature of 23ºC) For targets at:

-18 to -1ºC: ± 3ºC

-1 to 275ºC: ± 2% of

reading or ± 2ºC

For targets at:

10 °C to 30 °C: ±1 °C

± 1.5% of reading

or ± 1.5°C whichever

is greater over

the balance of the

range

For targets at:

-32 to -26°C: ± 3°C

-26 to -18°C: ± 2.5°C

-18 to 23°C: ± 2°C

23°C -510°C: ± 1%

of reading or ± 1°C*

For targets

above 510°C:

± 1.5% of reading

Typical distance to target Up to 1m Up to 1.5 m Up to 2 m

Emissivity Fixed at 0.95 Pre-set to 0.95 Fixed at 0.95

61 62 63

Form factor Flat grip Pistol grip Pistol grip

Temperature range -18 to 275°C -30 to 500 °C -32 to 535°C

Optical resolution 8:1 10:1 12:1

Laser beam for accurate targeting

OOO

Backlit LCD display

OOO

Use selectable °C or °F

OOO

Min/max/avg/dif readings Max Max

60 Series

Infrared Thermometers

Battery Life:

Fluke 63: 10 hours with laser and backlight on

Fluke 62: 12 hours with laser and backlight on

Fluke 61: 12 hours with laser and backlight on

Size (HxWxD):

Fluke 63: 200 mm x 160 mm x 55 mm

Fluke 62: 152 mm x 101 mm x 38 mm

Fluke 61: 184 mm x 45 mm x 38 mm

Weight:

Fluke 63: 0.320 kg

Fluke 62: 0.200 kg

Fluke 61: 0.227 kg

Fluke 62: 2 years warranty

Other models: one year warranty

* whichever is greater

Included Accessories

Fluke 61: 9V Battery

Fluke 62: 9V Battery, storage holster

Fluke 63: Hard carrying case, 9V batteries

Ordering information

Fluke 61 Infrared Thermometer

Fluke 62 Mini Infrared Thermometer

Fluke 63 Infrared Thermometer

Fluke 62/322/1AC-E (see page 5)

Fluke T5-600/62/1AC (see page 5)

Fluke FP FoodProTM Food Safety

Thermometer

Fluke FP Plus FoodProTM Plus

Food Safety Thermometer

The Fluke 60 Series non-contact

thermometers are the ideal professional

diagnostic tools for quick and accurate

temperature measurements.

These handheld tools are ideal for

measuring surface temperatures of

rotating, hard-to-reach, electricity live

or dangerously hot targets like electrical

motors and – panels, and heating and

ventilation systems.

The laser sighting system guides

measurements to the right target and in

less than a second, the large temperature

display provides a readout of the surface

temperature.

The 60 Series IR thermometers

feature:

• Laser guided sighting system for easy

targeting with 1% accuracy

• Up to 12:1 optical resolution

• Backlit display for easy reading in the

dark

• Temperatures up to 535°C

The Fluke FoodPro™ thermometer

series provide advanced

temperature measurement solutions

for the foodservice industry. Check

the Fluke web for more information.

Features

Specifications

See page 131

Recommended Accessories

C23

See page 130

Fluke 62/322 kit T5-600/62/1AC-E

Point, press and read temperature

Kits

Fluke 63

Fluke 62

Fluke 61

riešenia na presné meranie

http://www.elso.sk

566 and 568

Multipurpose Thermometers

Fluke 566

Fluke 568

The Fluke 566 and included accessories

Specifications

Power: 2 AA/LR6 Batteries (566); 2 AA/LR6

Batteries and USB for use with a PC (568)

Battery life: Used continuously; laser and

backlight on: 12 hours; laser and backlight off:

100 hours

Weight: 0.965 kg (566); 1.026 kg (568)

Size (HxLxW): 25.4 cm x 19.1 cm x 6.9 cm

Operating temperature: 0 °C to 50 °C

Storage temperature: -20 °C to 60 °C

Two years warranty

Included accessories

FlukeView® Forms software (568 only), USB

cable (568 only), K-type thermocouple bead

probe, 2 AA batteries, hard carrying case,

quick start guide, and users manual.

Ordering information

Fluke 566 Infrared thermometer

Fluke 568 Infrared thermometer

With a straight-forward, menu-driven

user interface and graphical display,

the Fluke 566 and 568 multipurpose

thermometers make even complex

temperature measurements easy. Quickly

navigate and adjust emissivity, start data

logging, or turn on and off alarms, with

just a few pushes of a button. For added

convenience, both rugged handheld

thermometers combine contact and

non-contact temperature measurement

capability, providing a total temperature

measurement solution for any service

and maintenance program.

• Easily access advanced features with

the soft-key buttons and graphical

display

• Measure smaller targets from farther

away using the IR thermometer

• Adjustable emissivity and built-in table

of common materials for higher IR

accuracy

• Quickly identify problems with the MIN,

MAX, AVG, and DIF functions

• 2-color ashing alarm alerts you

visually when measurements exceed

limits

• Includes Type K thermocouple bead

probe

• Compatible with all standard mini-

connector K-type thermocouples

• Data logging with a date/time stamp

• Soft rubber boot for increased

ruggedness

• User interface available in 6 languages

Choose your language Select the measurement surface See complete measurement details

in seconds

(Check the Fluke web for detailed specifications)

The Fluke 568 and included accessories

566 568

Infrared temperature range -40 °C to 650 °C -40 °C to 800 °C

Infrared accuracy < 0 °C : ± (1.0 °C + 0.1°/1 °C);

> 0 °C : ± 1 % or ± 1.0 °C, whichever is greater

Display resolution 0.1 °C

Infrared spectral response 8 µm to 14 µm

Infrared response time < 500 msec

Input temperature range -270 °C to 1372 °C

Input accuracy -270 °C to -40 °C: ± (1 °C + 0.2 °/1 °C)

-40 °C to 1372 °C: ± 1 % or 1 °C, whichever is greater

D:S (Distance to measurement spot size) 30:1 50:1

Laser sighting Single-point laser < 1 mw output Class 2 (II) operation, 630 nm to 670 nm

Minimum spot size 19 mm

Emissivity adjustment By built-in table of common materials or digitally adjustable

from 0.10 to 1.00 by 0.01

Data logging with Date/Time stamp 20 points 99 points

PC interface and cable None USB 2.0 with FlukeView®

Forms software

Hi/Low alarms Audible and two-color visual

Min/Max/Avg/Dif Yes

Display Dot matrix 98 x 96 pixels with function menus

Backlight Two levels, normal and extra bright for darker environments

Trigger Lock Yes

Switchable between Celsius and Fahrenheit Yes

80PK-26

See page 128

Recommended Accessories

80PK-25

See page 128

80PK-11

See page 128

80PK-9

See page 128

80PK-8

See page 128

See page 131

The two-in-one infrared and contact thermo-

meter with an innovative graphical display

riešenia na presné meranie

http://www.elso.sk

561

Multipurpose Thermometer

Fluke 561

The Fluke 561 includes everything you need for

immediate inspections.

Specifications

Temperature range -40° to 550°C

Display resolution 0.1° of reading

D:S (Distance to spot size) 12:1

Easy emissivity selector Adjustable with three settings: low (0.3), medium (0.7), high (0.95)

Display accuracy (Assumes ambient operating

temperature of 23° to 25°C) ± 1.0% of reading or ± 1°C, whichever is greater; below 0°C, ± 1°C, ± 1°/1°

Response time 500 mSec (95% or reading)

Repeatability ± 0.5% of reading or ± 1°C, whichever is greater

Spectral focus 8 µm to 14 µm

Laser sighting Single-point laser

Laser shutoff Laser turns off above ambient temperature of 40°C

Laser power Class 2 (II) operation; output ‹ 1 mW, wavelength 630 nm to 670 nm

Relative humidity 10% to 90% RH non-condensing, at < 30°C

Power 2 AA batteries (alkaline or NiCD)

Display hold 7 seconds

Backlit display Yes, LCD with dual temperatures (current and MAX/MIN/DIF/KTC), low battery,

F/C indicator, and Scan/Hold options

Operating temperature 0° to 50°C

Storage temperature -20 to 65°C

MAX, MIN, DIF temperatures Yes

Thermocouple type K mini-adapter input Yes, compatible with industry standard type K probes with mini-connector

Thermocouple type K Velcro pipe probe Yes, with a temperature range of 0° to 100°C and accuracy of ± 2.2°C

Measurement guide Yes

Battery Life (alkaline): 12 hours

Size (HxLxW): 176,9 mm x 163,6 mm x 51,8 mm Weight: 340 grams

Two years warranty

Included accessories

Thermocouple K-type Velcro pipe probe,

hand carrying case, 2 AA batteries and user

manual with measurement guide.

Ordering information

Fluke 561 HVACPro Thermometer

The Fluke 561 combines the temperature

measurement functions that industrial,

electrical, and HVAC/R professionals

need, all in one tool. It measures both

IR and contact temperature, replacing

several other test tools. It’s fast, efcient,

and easy to use, saving you valuable time

and effort. With the Fluke 561, you can

take contact and ambient temperatures

in the way that’s best for you. Use the IR

thermometer to measure hot, moving,

electrically energized, and hard-to-

reach objects instantly. Check motors,

insulation, breakers, radiant heating,

pipes, corroded connections, and wires.

Plus, scan ducts, and other hard-to-reach

objects from the oor—leave your ladder

in the truck. You can use the Fluke 561’s

handy Velcro® pipe probe or, plug in any

industry standard, K-type mini-connector

thermocouple probe you already own.

• IR thermometer for quick

measurements up close or at a distance

• Single-point laser sighting

• Easy emissivity adjustment for

measuring pipes and ducts more

accurately

• Includes a Velcro pipe probe for super-

heat and sub-cooling as well as other

surface contact measurements

• Also compatible with all standard mini-

connector K-type thermocouples

• MIN, MAX and DIF temperature

readings

• Lightweight (only 340 grams) and

portable

• Includes measurement guide

80PK-8

See page 128 80PK-25

See page 128

Recommended Accessories

80-PK-1

See page 128

Se page 131

Combined Infrared and Contact Thermometer

riešenia na presné meranie

http://www.elso.sk

50 Series II Thermometers

FVF-SC 2

See page 132 TPAK

See page 132

Recommended Accessories

Fluke 54 II B

Fluke 51 II

Features

80PK-25

See page 128

Battery life: 1000 hours typical, AA

Size (HxWxD): 173 x 86 x 38 mm Weight: 0.4 kg

Three Year Warranty

Included Accessories

Impact absorbing holster

Two bead probe thermocouples 80PK-1 (54+52)

One bead probe thermocouple 80PK-1 (51+53)

Ordering Information

Fluke 51 II Thermometer

Fluke 52 II Thermometer

Fluke 53 II B Thermometer

Fluke 54 II B Thermometer

FVF-SC2 FlukeView Forms Software

including USB interface cable

The Fluke 50 Series II contact

thermometers offer fast response and

laboratory accuracy (0.05% + 0.3°C) in

a rugged handheld test tool.

• Large backlit dual display shows any

combination of T1, T2 (52 and 54 only),

T1-T2 (52 and 54 only) plus MIN, MAX,

or AVG

• Relative time clock on MIN, MAX, and

AVG provides a time reference for major

events

• Electronic Offset function allows

compensation of thermocouple errors

to maximize overall accuracy

• Readout in °C, °F, or Kelvin (K)

• Sleep mode increases battery life

• Battery door allows easy battery

replacement without breaking the

calibration seal

Additional features for the 53 and

54 Series II:

• Data Logging up to 500 points of data

with user adjustable recording interval

• Real time clock captures the exact time

of day when events occur

• Recall function allows logged data to be

easily reviewed on the meter display

• IR communication port allows data to

be exported to optional FlukeView®

PC software

51 II 52 II 53 II B 54 II B

Thermocouple types J,K,T,E J,K,T,E J,K,T,E,N,R,S J,K,T,E,N,R,S

Number of inputs Single Dual Single Dual

Time stamp Relative Time Relative Time Time of Day Time of Day

Splash/Dust resistant

OOOO

Dual display with backlight

OOOO

Min/Max/Avg recording

OOOO

(T1-T2) True differential

Data logging up to 500 points

IR data port for interface

to PC

Compatible with optional

FlukeView Software

80PK-26

See page 128

Fluke 52 II Fluke 53 II B

Specifications

C25

See page 130

**Only the Fluke Models 53 and 54 Series II thermometers are capable of measuring N, R, and S-type

Temperature range:

J-type Thermocouples -210°C to 1200°C

K-type Thermocouples -200°C to 1372°C

T-type Thermocouples -250°C to 400°C

E-type Thermocouples -150°C to 1000°C

N-type** Thermocouples -200°C to 1300°C

R** and S-type** Thermocouples 0°C to 1767°C

Temperature accuracy

Above –100°C (-148°F):

J, K, T, E, and N-type** ± [ 0.05% + 0.3°C ]

R** and S-type** ± [ 0.05% + 0.4°C ]

Below –100°C (-148°F):

J, K, E, and N-types ± [ 0.20% + 0.3°C ]

T-type ± [ 0.50% + 0.3°C ]

Laboratory accuracy. Wherever you go.

riešenia na presné meranie

http://www.elso.sk

1523 and 1524

Reference Thermometers

2384P and 2384T

Spare INFO-CON Adapters 2373-LTC

Universal TC adapter

Recommended Accessories

Fluke 1524

Features

FLK80P3

(80PK-3A with universal

thermocouple adapter)

Battery life (alkaline): 20 hours

Power supply: Universal 12 Vdc

Size (HxWxD): 200 x 96 x 47 mm

Weight: 0.65 kg

Warranty: 1 year

Measure, graph and record three

sensor types with one tool. The Fluke

1523/24 Reference Thermometer deliver

high accuracy, wide measurement

range, logging, and trending, all in a

handheld tool you can take anywhere.

For top accuracy, a memory chip inside

the probe connector feeds probe

calibration information to the readout.

In addition, any thermocouple with

a mini-thermocouple connector can

be read using the optional universal

thermocouple adapter. Choose the 1523

for single channel or the 1524 for dual

channel measurement.

Three sensor types

• PRTs: –200 °C to 1000 °C

• Thermocouples –200 °C to 2315 °C

• Precision thermistors: –50 °C to 150 °C

High accuracy

• PRTs: ±0.011 °C

• Thermocouples: ±0.24 °C for J,K,L,M

• Precision thermistors: ±0.002 °C

Fast measurement

• PRTs: up to 0.45 seconds/sample

• Thermocouples: up to 0.3 seconds/

sample

• Precision thermistors: up to 0.3

seconds/sample

Two models

• 1523: Single channel standard model;

memory for 25 readings & statistics

• 1524: Two channels; memory for 25

readings and statistics plus logging

15,000 measurements; real-time clock

for time and date stamps

1523 1524

Sensor Types PRT & RTD, Thermistor, and Thermocouple

Thermocouple Types B,C,E,J,K,L,M,N,R,S,T,U

Number of inputs Single Dual

Data trending (graphing)

Graphical display with backlight

Min/Max/Avg/Standard deviation recording

High speed measurement

RS-232 PC communications

T1-T2 True differential

Data logging up to 15,000 points

Time and date stamp

O

FLK80P1

(80PK1 with universal

thermocouple adapter)

Fluke 1523

Speciﬁcations

TPAK

Temperature range

Thermocouple –200 °C to 2315 °C

PRT & RTD –200 °C to 1000 °C

Thermistor –50 °C to 150 °C

Resolution and best accuracy

Thermocouple 0.01 °, ±0.24 °C

PRT & RTD 0.001 °, ±0.011 °C

Thermistor 0.001 °, ±0.002 °C

Operating temperature –10 °C to 60 °C

Storage temperature –20 °C to 70 °C

A new standard in

accuracy and versatility.

Included Accessories

NIST traceable certicate of calibration, users

guide, CD-ROM (contains technical manual),

12 V dc universal power supply, RS-232 cable,

9940 I/O ToolKit software

Ordering Information

Fluke 1523* Reference Thermometer

Fluke 1524* Reference Thermometer

Fluke 1523-P1 Reference Thermometer,

PRT(–200 °C to 420 °C, 6.35

mm x 298 mm), Universal

Thermocouple Adapter, TPAK,

and Case

Fluke 1524-P1 Reference Thermometer,

PRT(–200 °C to 420 °C, 6.35

mm x 298 mm), Universal

Thermocouple Adapter, TPAK,

and Case

* Requires an optional probe

Optional Accessories

2384-P INFO-CON Connector, PRT

(Gray Cap), Spare

2384-T INFO-CON Connector,

Thermocouple (Blue Cap),

Spare

2373-LPRT RTD Adapter, Lemo to

Mini Grabbers (4-wire)

Optional probes:

5616-12-P PRT, 6.35 mm x 298 mm,

–200 °C to 420 °C

5615-9-P PRT, 4.76 mm x 229 mm,

–200 °C to 420 °C

5610-9-P Thermistor, 3.2 mm x 229 mm,

0 °C to 100 °C

(Check the Fluke web for detailed speciﬁcations)

Note: The 1523/24 are pictured with probes connected which may

be purchased seperately.

riešenia na presné meranie

http://www.elso.sk

1551A Ex 1552A Ex

Temperature range –50 °C to 160 °C –80 °C to 300 °C

Accuracy (1 year) ±0.05 °C

Display units °C, °F

Sensor type 100  thin film RTD 100  wire-wound PRT

Probe temperature coefficient 0.00385 //°C nominal

Sensor length ≤ 10 mm ≤ 30 mm

Sensor position (from sheath tip) 3 mm

Minimum immersion depth170 mm 120 mm

Probe sheath material SST

Response time 4.8 mm diameter probe (3/16 in): 14 seconds

6.35 mm diameter probe (1/4 in): 21 seconds

Probe hysteresis ±0.01 °C

Temperature resolution Selectable: 0.1, 0.01, 0.001 (default 0.01)

Sample rate Selectable: 0.5, 1, 2, seconds (default 1)

Operating temperature range of readout –10 to 50 °C

Storage temperature –20 °C to 60 °C , 0 to 95% RH, non-condensing

Optional data logging2 Up to 10k time-stamped readings stored to internal memory

Logging intervals2 2, 5, 10, 30, or 60 seconds; 2, 5, 10, 30, or 60 minutes

Averaging Moving average of most recent 2 to 10 readings, user selectable

(ON/OFF, 2,5,10)

Communications RS-232 stereo jack (access calibration parameters only)

EMC compliance EN61326:2006 Annex C; CISPR II, Edition 5.0-2009; Class “B”

Enclosure rating IP50

Calibration NVLAP accredited, NIST Traceable System Calibration

Characterization CVD ITS-90

1 Per ASTM E 644

2 See ordering information for optional data logging configurations

1551A Ex / 1552A Ex Intrinsically

Safe “Stik” Thermometers

Included Accessories

NVLAP –accredited report of calibration, user’s

guide on CD-ROM, 3 AAA batteries

Ordering Information

1551A-9 “Stik” Thermometer

1551A-12 “Stik” Thermometer

1551A-20 “Stik” Thermometer

1551A-9-DL “Stik” Thermometer with

datalogging

1551A-12-DL “Stik” Thermometer with

datalogging

1551A-20-DL “Stik” Thermometer with

datalogging

1552A-12 “Stik” Thermometer

1552A-12-DL “Stik” Thermometer with

datalogging

Note: Model number appended with a -9, -12, -20

indicates probe sheath length in inches. All probe

diameters are 6.35 mm with the exception of the

1551A-9, which is 4.8 mm diameter

Finally, a digital substitute for your

mercury-in-glass thermometers! Highly

accurate and durable, the Fluke 1551A

Ex/1552A Ex “Stik” Thermometer is soon

to become the new “gold standard” of

industrial temperature calibration.

Whether working outdoors in

environments where potentially

explosive gases may be present or on

the oor of a processing plant, the

intrinsically safe, battery-operated,

portable reference thermometer is

designed to go where you work.

The RTD sensor of the “Stik” Thermometer

is housed in a rugged stainless steel

sheath—you no longer have to worry

about breaking a mercury-in-glass

thermometer and the subsequent

cleanup. The probe and digital readout

are xed together, calibrated as a system,

and accurate to ± 0.05 °C over the full

temperature range. The large backlit

LCD display rotates 90° making it easy

to read from any position. Minimize

measurement errors with the user-

congurable temperature trend/stability

indicator which tells you when your

temperature source is stable or if your

temperature is trending up or down.

• ± 0.05 °C accuracy over full range

• Intrinsically safe (ATEX compliant)

• Display temperature in °C or °F

• Optional data logging to internal

memory

• Temperature trend indicator

• User selectable resolution (0.1, 0.01,

0.001)

• 300 hour battery life

• Percent battery-life and low battery

indicator

• NVLAP accredited calibration

(NIST traceable)

Battery Life: 300 hours typical without LCD, 3 AAA

Size (HxWxD): 114 x 57 x 25 mm

Weight: 196 grams

Warranty: 1 year

Speciﬁcations

The new “gold standard” of industrial

temperature calibration

1552A Ex

1551A Ex

1551-CASE

Carrying case 1551-CBL

RS-232 cable

Recommended Accessories

New

riešenia na presné meranie

http://www.elso.sk

5858

Temperature changes can indicate problems in many everyday

applications and a thermal imager makes it quick and easy to visually

check surface temperatures. Often problems can be discovered before

contact measurements even need to be made. Fluke offers a complete

range of handheld thermal imagers for both industrial and building

diagnostic applications. Models are available for any budget.

Thermal Imagers

riešenia na presné meranie

http://www.elso.sk

Ti Series Thermal Imagers

Overheating bearing cap

See things both ways - Infrared and

visual (visible light) images fused

together communicating critical

information faster and easier –

traditional infrared images are no longer

enough. Patented IR-Fusion® Technology,

only available from Fluke, simultaneously

captures a digital photo and the infrared

image and fuses them together taking

the mystery out of IR image analysis.

Three-phase switch-gear

load imbalance

Overheated motor Cool corner in a building

SmartView® Software

Fluke SmartView® software is included with each Fluke

Thermal Imager. This powerful software is a modular

suite of tools that annotates, views, edits and analyzes

IR images.

It also generates fully customizable and professional-

looking reports in a few easy steps. The IR-Fusion

technology is fully supported.

FREE webinars/webcasts on

Thermal Imaging

Keep up-to-date on the latest troubleshooting

techniques. Attend a FREE Fluke webinar (web-based

seminar) about thermal imaging applications.

Go to the Fluke website for more information.

Picture-in-Picture Alpha BlendingFull IR

Full Visible Light

Find it, ﬁx it, fast!

Temperature changes can indicate problems

in many areas you see everyday, some

include:

• Inside electrical distribution and service

(Switch gear, panels, controls,

fuses,transformers, receptacles, lighting,

conductors, bus bars, motor control

centers)

• Motors, pumps and mechanical (Electric

motors and generators, pumps,

compressors, evaporators, bearings,

couplings, gearboxes, gaskets/seals, belts,

rollers, disconnects)

• Process (Tanks and vessels, pipes, valves

and traps, reactors, process insulation)

• HVAC/R (air conditioning, heating, air

handlers, refrigeration)

• Outside electrical distribution - utilities

(Transformers, bushings, insulators,

transmission lines, other exterior

conductors, service connections,

disconnects, capacitor banks)

IR/Visible Alarm

IR-Fusion® Technology: Infrared and

visual images fused together in one image

riešenia na presné meranie

http://www.elso.sk

Ti32/Ti29/Ti27 Industrial/

Commercial Thermal Imagers

Designed for industrial and commercial environments, the Fluke P3 Series of

thermal imagers deliver superior image quality, versatility, and affordability without

compromise. They also boast superior infrared resolution, industry leading spatial

resolution, and a high denition display creating the sharpest images in their price

classes. Finding a potential problem before it becomes a costly disaster shows you

just how much a Fluke thermal imager can save you in time, money and even lifes.

The New P3 Series from Fluke

• Delivers the clear, crisp images needed to nd problems fast with up to 320 x 240

sensor.

• Identify even the smallest temperature differences that could indicate problems

with industry-leading thermal sensitivity (NETD), down to 45 mK.

• Automatic alignment (parallax correction) of visual and infrared images with Fluke

patented IR-Fusion®.

• Optional telephoto and wide angle lenses available for added versatility and special

applications (easily installable in the eld).

Superior image quality

• Field replaceable batteries give you maximum exibility no matter where your work

takes you.

• Intuitive, three-button menu is easy to use—simply navigate with the push of a

thumb.

• No need to carry pen and paper—record ndings by speaking into the imager. Voice

annotations can be recorded with every image you take. Voice comments are saved

along with individual images for future reference.

• One-handed focus capability, emissivity correction, reected background

temperature compensation, and transmission correction increase the accuracy of

measurements in most situations.

• Adjustable hand strap for left-or right-handed use.

• Everything needed to get started is included.

Easy to use

• Optimized for eld use in challenging work environments.

• Engineered and tested to withstand a 2 m drop for the ultimate peace of mind.

• Withstands dust and water—tested to an IP54 rating.

• With their rugged design, integrated lens cover, protected display and 2 meter drop

test, they are designed to handle the harshest environments.

Rugged

New

Fluke Ti32

Fluke Ti29

Fluke Ti27

riešenia na presné meranie

http://www.elso.sk

Ti32/Ti29/Ti27 Industrial/

Commercial Thermal Imagers

Specifications

Water and dust resistant: IP54

Size (HxWxD): 277 x 122 x 170 mm

Weight: 1.05 kg

Two Years Warranty

Fluke Ti27 Fluke Ti29 Fluke Ti32

Thermal imaging performance

Detector type 240 x 180 Focal Plane Array,

uncooled microbolometer 280 x 210 Focal Plane Array,

uncooled microbolometer 320 x 240 Focal Plane Array,

uncooled microbolometer

Field of view (FOV) 23 º horizontal x 17 º vertical

Spatial resolution (IFOV) 1.67 mRad 1.49 mRad 1.25 mRad

Min focus distance 15 cm

Thermal sensitivity (NETD) ≤0.05 °C at 30 °C (50 mK) ≤0.045 °C at 30 °C (45 mK)

Minimum span (auto/manual) 2.5 °C / 5 °C

Focus Manual

Optional telephot infrared lens type

Field of view (FOV) 11.5” x 8.7”

Minimum focus distance 45 cm

Optional wide-angle infrared lens type

Field of view (FOV) 46” x 34”

Minimum focus distance 7.5 cm

Visual imaging performance

Minimum focus distance 46 cm

On camera operating modes Picture-in-Picture and full screen IR plus Blending

Color Alarm High temperature alarm

Visible light camera 2.0 MegaPixel

Temperature measurement

Temperature range -20 °C to 600 °C

Accuracy

±2 °C or 2%

Measurement modes

Center point and hot and cold markers

Image presentation

Digital display 9.1 cm (3.7”) landscape color VGA (640x480) LCD

LCD backlight Selectable bright or auto

Palettes

Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale,

Grayscale Inverted

Ultra Contrast Palettes

Voice Annotation

Voice annotation

Image and data storage

Storage medium 2GB SD Card (3000 .bmp IR images/1200 .IS2 images)

File formats supported JPG, JPEG, JPE, JFIF, BMP, GIF, DIB, PNG, TIF, and TIFF

Controls and adjustments

Set-up controls Date/time, Cº/ºF, language

On screen emissivity correction

On-screen reflected background temperature compensation

On-screen transmission correction

Language selection Eng, ger, fre, spa, por, ita, swe, fin, rus, cze, pol, tur

Image controls Smooth auto scaling and manual scaling

Power

Battery type Two replaceable rechargeable battery packs (Lithium ion)

Battery operating time 4+ hours per battery pack

FLK-LENS/TELE1

Telephoto Infrared Lens FLK/LENS/WIDE

Wide-angle Infrared Lens

FLK-TI-SPB3

Extra battery FLK-TI-SBC3

Charging base

Ti-Car Charger

Car charger

Recommended Accessories

Included Accessories

SmartView® software

2 GB SD card

SD card reader

Rugged hard carrying case

Soft carrying case

Hand strap

Rechargeable battery (extra)

AC charger/power supply

User manual

Ordering Information

Fluke Ti27 Thermal Imager

Fluke Ti29 Thermal Imager

Fluke Ti32 Thermal Imager

Complete package

riešenia na presné meranie

http://www.elso.sk

TiR32/TiR29/TiR27 Building

Diagnostic Thermal Imagers

Designed specically for the building inspection professional, the Fluke P3 Series

of thermal imagers deliver the perfect balance between performance and price.

They also boast superior infrared resolution, spatial resolution, and high denition

displays. The P3 Series delivers crisp images and impressive reports with the

included professional SmartView® software. Whether you’re searching for energy

waste, leaky roofs or moisture problems, Fluke P3 thermal imagers offer tested and

proven technology that takes the guesswork out of nding problems and provides

solutions.

The New P3 Series from Fluke

• Delivers the clear, crisp images needed to nd problems fast

• Identify even the smallest temperature differences that could indicate problems

with industry-leading thermal sensitivity (NETD), down to 40 mK.

• Automatic alignment (parallax correction) of visual and infrared images with Fluke

patented IR-Fusion®

• Optional telephoto and wide angle lenses available for added versatility and special

applications (easily installable in the eld).

Superior image quality

• Field replaceable batteries give you maximum exibility no matter where your work

takes you.

• Intuitive, three-button menu is easy to use—simply navigate with the push of a

thumb.

• No need to carry pen and paper—record ndings by speaking into the imager. Voice

annotations can be recorded with every image you take. Voice comments are saved

along with individual images for future reference.

• One-handed focus capability, emissivity correction, reected background

temperature compensation, and transmission correction increase the accuracy of

measurements in most situations.

• Adjustable hand strap for left-or right-handed use.

• Everything needed to get started is included.

Easy to use

• Optimized for eld use in challenging work environments.

• Engineered and tested to withstand a 2 m drop for the ultimate peace of mind.

• Withstands dust and water—tested to an IP54 rating.

• With their rugged body, integrated lens cover, protected display and 2 meter drop

test, they are designed to handle the harshest environments.

Rugged

Fluke TiR32

Fluke TiR29

Fluke TiR27

New

riešenia na presné meranie

http://www.elso.sk

TiR32/TiR29/TiR27 Building

Diagnostic Thermal Imagers

Recommended Accessories

FLK-TI-SPB3

Extra battery FLK-TI-SBC3

Charging base

Ti-Car Charger

Car charger

Included Accessories

SmartView® software

2 GB SD card

SD card reader

Rugged hard carrying case

Soft carrying case

Hand strap

Rechargeable battery (extra)

AC charger/power supply

User manual

Ordering Information

Fluke TiR27 Thermal Imager for

Building Diagnostics

Fluke TiR29 Thermal Imager for

Building Diagnostics

Fluke TiR32 Thermal Imager for

Building Diagnostics

Water and dust resistant: IP54

Size (HxWxD): 277 x 122 x 170 mm

Weight: 1.05 kg

Two Years Warranty

Complete package

Specifications

Fluke TiR27 Fluke TiR29 Fluke TiR32

Thermal imaging performance

Detector type 240 x 180 Focal Plane Array,

uncooled microbolometer 280 x 210 Focal Plane Array,

uncooled microbolometer 320 x 240 Focal Plane Array,

uncooled microbolometer

Field of view (FOV) 23 º horizontal x 17 º vertical

Spatial resolution (IFOV) 1.67 mRad 1.49 mRad 1.25 mRad

Min focus distance 15 cm

Thermal sensitivity (NETD) ≤0.045 °C at 30 °C (50 mK) ≤0.040 °C at 30 °C (40 mK)

Minimum span (auto/manual) 2.5 °C / 5 °C

Focus Manual

Optional telephot infrared lens type

Field of view (FOV) 11.5” x 8.7”

Minimum focus distance 45 cm

Optional wide-angle infrared lens type

Field of view (FOV) 46” x 34”

Minimum focus distance 7.5 cm

Visual imaging performance

Minimum focus distance 46 cm

On camera operating modes Picture-in-Picture and full screen IR plus Blending

Color Alarm Dewpoint alarm

Visible light camera 2.0 MegaPixel

Temperature measurement

Temperature range -20 °C to 150 °C

Accuracy

±2 °C or 2%

Measurement modes

Center point and hot and cold markers

Image presentation

Digital display 9.1 cm (3.7”) landscape color VGA (640x480) LCD

LCD backlight Selectable bright or auto

Palettes

Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale,

Grayscale Inverted

Ultra Contrast Palettes

Voice Annotation

Voice annotation

Image and data storage

Storage medium 2GB SD Card (3000 .bmp IR images/1200 .IS2 images)

File formats supported JPG, JPEG, JPE, JFIF, BMP, GIF, DIB, PNG, TIF, and TIFF

Controls and adjustments

Set-up controls Date/time, Cº/ºF, language

On screen emissivity correction

On-screen reflected background temperature compensation

On-screen transmission correction

Language selection Eng, ger, fre, spa, por, ita, swe, fin, rus, cze, pol, tur

Image controls Smooth auto scaling and manual scaling

Power

Battery type Two replaceable rechargeable battery packs (Lithium ion)

Battery operating time 4+ hours per battery pack

FLK-LENS/TELE1

Telephoto Infrared Lens FLK/LENS/WIDE

Wide-angle Infrared Lens

riešenia na presné meranie

http://www.elso.sk

Ti125/Ti110/Ti100 Industrial /

Commercial Thermal Imagers

Ti125

Ti110

Ti100

New Industrial and commercial maintenance

made easy

Technology isn’t working for you if it’s slowing you down. Fluke proudly introduces

ve new thermal imagers specically designed to help you do more in less time,

while being at home in the harshest of environments. A project that might normally

take an hour can now be done in minutes. Our newest imagers are the lightest, most

rugged, easiest-to-use professional imagers you can buy.

IR-OptiFlex™ focus system

Discover issues signicantly faster with Fluke’s revolutionary, ultra-rugged focus

system. The IR-OptiFlex focus system gives you optimum focus by combining

focus-free ease-of-use with the exibility of manual focus on the same camera!

IR-Fusion® technology

Enjoy the industry’s best point-and-shoot IR-Fusion camera. Fluke patented

technology blends digital and infrared images into a single image to precisely

document problem areas.

Rugged one-hand operation

Experience the most rugged and reliable, lightweight professional camera around.

One-touch focus, laser pointer, and torch. Point-and-shoot simplicity. No one builds

more rugged, ergonomic tools than Fluke.

Multi-mode video recording

Troubleshoot with the industry’s only thermal imager that records focus-free video in

visible light and infrared with full IR-Fusion capabilities. Monitor processes over time,

easily create infrared video reports, and troubleshoot.

IR-PhotoNotes™ annotation system

Get an exact reference to your problem area by capturing up to three digital photos

per le. Add images of equipment, motor nameplates, workroom doors or any other

useful or critical information.

Electronic compass

Make sure you and others know the location of the problem. Compass readings easily

appear in images and reports.

riešenia na presné meranie

http://www.elso.sk

Ti125/Ti110/Ti100 Industrial /

Commercial Thermal Imagers

Recommended Accessories

Included Accessories

SmartView® software

AC power adapter

Lithium ion smart battery

USB cable

2 GB SD memory card

Hard carrying case

Soft transport bag

Adjustable hand strap

User manual

Two-bag charging base and multi-format USB

memory card reader (Ti125 only)

Ordering Information

Fluke Ti125 Industrial-Commercial

Thermal Imager

Fluke Ti110 Industrial-Commercial

Thermal Imager

Fluke Ti100 General Use Thermal

Imager

Water and dust resistant: IP54

Size (HxWxD): 284 x 86 x 135 mm

Weight: 0.726 kg

Two Years Warranty

Specifications

Fluke Ti125 Fluke Ti110 Fluke Ti100

Industrial-Commercial General

Thermal imaging performance

IR resolution (FPA size) 160 x 120 FPA Uncooled Microbolometer

Field of view (FOV) 22.5 °H x 31 °V

Spatial resolution (IFOV) 3.39 mRad

Thermal sensitivity (NETD) ≤ 0.10 °C at 30 °C target temp (100 mK)

Minimum span in auto mode 5 °C

Minimum span in manual mode 2.5 °C

Minimum IR focus distance 15.25 cm (6 in) 1.2 m (4 ft)

Focus mechanism IR-OptiFlex™ focus system Focus-free 1.2 m and

beyond

IR-Fusion® technology PIP, FULL IR, FULL VISIBLE,

AutoBlend PIP, FULL IR, FULL VISIBLE No, full IR only

Color alarms High temperature,

low temperature, isotherm High temperature -

Visual imaging performance

Visible camera 2 megapixel industrial-grade n/a

LCD display 3.5 inch diagonal (portrait format)

Hot/Cold markers Yes -

User definable spot markers Three on camera and in SmartView®in SmartView® only

Centerbox (MIN/AVG/MAX) Yes -

Level and span control Manual and auto

IR-PhotoNotes™ annotation system Yes (3 images) -

Laser pointer Yes

Torch Yes -

Electronic (cardinal) compass Yes -

Emissivity correction Yes

Transmission correction Yes -

Video

Multi-mode video output Streaming USB video output -

Multi-mode video recording

(standard AVI with MPEG encoding) Yes (AVI with MPEG encoding) -

Multi-mode video recording

(radiometric .IS3) Yes, radiometric .is3 for

approx.. 2.5 to 5 minutes

depending upon thermal

scene

Temperature measurement

Temperature measurement range

(not calibrated below -10° C) -20 °C to +350 °C -20 °C to +250 °C

Accuracy ± 2 °C or 2 % (at 25 °C nominal, whichever is greater)

Image presentation

Standard palettes Blue-Red, Grayscale, Inverted Grayscale, High-contrast,

Hot Metal, Ironbow, Amber, Inverted Amber Blue-Red, Ironbow,

Grayscale, Amber

Ultra Contrast™ palettes Blue-Red, Grayscale,

Inverted Grayscale,

High-contrast, Hot Metal,

Ironbow, Amber,

Inverted Amber

Blue-Red, Grayscale,

Ironbow -

Voice Annotation

Voice annotation Yes (60 seconds) per image -

Image and data storage

Memory storage 2 GB SD memory card

Power

Battery

(field-replaceable, rechargeable) Two One

Battery life 4+ hours (each) (assumes 50% brightness of LCD)

FLK-TI-SPB3

Extra battery FLK-TI-SBC3

Charging base

Ti-Car Charger

Car charger

riešenia na presné meranie

http://www.elso.sk

TiR125/TiR110/Ti100 Building

Diagnostic Thermal Imagers

New Building diagnostics made easy

Technology isn’t working for you if it’s slowing you down. Fluke proudly introduces

ve new thermal imagers specically designed to help you do more in less time,

while being at home in the harshest of environments. A project that might normally

take an hour can now be done in minutes. Our newest imagers are the lightest, most

rugged, easiest-to-use professional imagers you can buy.

IR-OptiFlex™ focus system

Discover issues signicantly faster with Fluke’s revolutionary, ultra-rugged focus

system. The IR-OptiFlex focus system gives you optimum focus by combining

focus-free ease-of-use with the exibility of manual focus on the same camera!

IR-Fusion® technology

Enjoy the industry’s best point-and-shoot IR-Fusion camera. Fluke patented

technology blends digital and infrared images into a single image to precisely

document problem areas.

Rugged one-hand operation

Experience the most rugged and reliable, lightweight professional camera around.

One-touch focus, laser pointer, and torch. Point-and-shoot simplicity. No one builds

more rugged, ergonomic tools than Fluke.

Multi-mode video recording

Troubleshoot with the industry’s only thermal imager that records focus-free video in

visible light and infrared with full IR-Fusion capabilities. Monitor processes over time,

easily create infrared video reports, and troubleshoot.

IR-PhotoNotes™ annotation system

Always have references handy – IR-PhotoNotes™ annotation system – quickly

identify and keep track of inspection locations by adding digital images of important

information and surrounding areas (TiR110 and TiR125).

Electronic compass

Make sure you and others know the location of the problem. Compass readings easily

appear in images and reports.

TiR125

TiR110

Ti100

riešenia na presné meranie

http://www.elso.sk

Recommended Accessories

Water and dust resistant: IP54

Size (HxWxD): 284 x 86 x 135 mm

Weight: 0.726 kg

Two Years Warranty

Specifications

FLK-TI-SPB3

Extra battery FLK-TI-SBC3

Charging base

Ti-Car Charger

Car charger

TiR125/TiR110/Ti100 Building

Diagnostic Thermal Imagers

Fluke TiR125 Fluke TiR110 Fluke Ti100

Building diagnostics General

Thermal imaging performance

IR resolution (FPA size) 160 x 120 FPA Uncooled Microbolometer

Field of view (FOV) 22.5 °H x 31 °V

Spatial resolution (IFOV) 3.39 mRad

Thermal sensitivity (NETD) ≤ 0.08 °C at 30 °C target temp (80 mK) ≤ 0.10 °C at 30 °C target

temp (100 mK)

Minimum span in auto mode 2.5 °C 5 °C

Minimum span in manual mode 2.0 °C 2.5 °C

Minimum IR focus distance 15.25 cm (6 in) 1.2 m (4 ft)

Focus mechanism IR-OptiFlex™ focus system Focus-free 1.2 m and

beyond

IR-Fusion® technology PIP, FULL IR, FULL VISIBLE,

AutoBlend PIP, FULL IR, FULL VISIBLE No, full IR only

Color alarms High temperature,

low temperature (dewpoint),

and isotherm

Low temperature

(dewpoint) -

Visual imaging performance

Visible camera 2 megapixel industrial-grade n/a

LCD display 3.5 inch diagonal (portrait format)

Hot/Cold markers Yes -

User definable spot markers Three on camera and in SmartView®in SmartView® only

Centerbox (MIN/AVG/MAX) Yes -

Level and span control Manual and auto

IR-PhotoNotes™ annotation system Yes (3 images) -

Laser pointer Yes

Torch Yes -

Electronic (cardinal) compass Yes -

Emissivity correction Yes

Transmission correction Yes -

Video

Multi-mode video output Streaming USB video output -

Multi-mode video recording

(standard AVI with MPEG encoding) Yes (AVI with MPEG encoding) -

Multi-mode video recording

(radiometric .IS3) Yes, radiometric .is3 for

approx.. 2.5 to 5 minutes

depending upon thermal

scene

Temperature measurement

Temperature measurement range

(not calibrated below -10° C) -20 °C to +150 °C -20 °C to +250 °C

Accuracy ± 2 °C or 2 % (at 25 °C nominal, whichever is greater)

Image presentation

Standard palettes Blue-Red, Grayscale, Inverted Grayscale, High-contrast,

Hot Metal, Ironbow, Amber, Inverted Amber Blue-Red, Ironbow,

Grayscale, Amber

Ultra Contrast™ palettes Blue-Red, Grayscale,

Inverted Grayscale,

High-contrast, Hot Metal,

Ironbow, Amber,

Inverted Amber

Blue-Red, Grayscale,

Ironbow -

Voice Annotation

Voice annotation Yes (60 seconds) per image -

Image and data storage

Memory storage 2 GB SD memory card

Power

Battery

(field-replaceable, rechargeable) Two One

Battery life 4+ hours (each) (assumes 50% brightness of LCD)

Included Accessories

SmartView® software

AC power adapter

Lithium ion smart battery

USB cable

2 GB SD memory card

Hard carrying case

Soft transport bag

Adjustable hand strap

User manual

Two-bag charging base and multi-format USB

memory card reader (Ti125 only)

Ordering Information

Fluke TiR125 Building Diagnostics

Thermal Imager

Fluke TiR110 Building Diagnostics

Thermal Imager

Fluke Ti100 General Use Thermal Imager

riešenia na presné meranie

http://www.elso.sk

Ti9/Ti10/Ti25 Thermal Imagers

Get the full picture instantly with the Fluke Ti9/Ti10/Ti25 thermal imagers. Built for

tough work environments, these fully radiometric imagers are ideal for detecting

problems in a wide range of equipment including switchgear, motor control centers

and lighting systems.

• Delivers the clear images to nd problems fast with its 160x120 sensor

• Even the smallest details become visible with the large, widescreen full color

LCD display

• Optimized for eld use in harsh work environments

- Engineered and tested to withstand a 2 meter drop

- Withstands dust and water – tested to an IP54 rating

- Innovative protective lens cover protects the lens when not in use

• Enhanced problem detection and analysis capabilities with patent pending

IR-Fusion® Technology (Ti10 and Ti25)

• Intuitive, three-button menu is easy to use ... simply navigate with the push

of a thumb

• Store more than 3.000 screen images (.bmp format) or 1.200 fully radiometric

images (.IS2 format) on included 2 GB SD memory card

See things both ways—infrared and visual (visible light) images fused together

communicating critical information faster and easier—traditional infrared images

are no longer enough. IR-Fusion, a patent-pending technology that simultaneously

captures a digital photo in addition to the infrared image and fuses it together taking

the mystery out of IR image analysis. IR-Fusion is standard on Ti10 and Ti25 models.

The Fluke Ti9 can be upgraded to a full Fluke Ti10 with IR-Fusion at a later time.

Fluke Ti10

Fluke Ti9

The rugged and affordable tools for

electricians and technicians

IR-Fusion® Technology

Fluke Ti25

riešenia na presné meranie

http://www.elso.sk

Ti9/Ti10/Ti25 Thermal Imagers

Included Accessories

SmartView® software

2 GB SD card

SD card reader

Rugged hard carrying case

Soft carrying case

Hand strap

Rechargeable battery

AC charger/power supply

User manual

Ordering Information

Fluke Ti9 Electrical Thermal Imager

Fluke Ti10 Electrical Thermal Imager

Fluke Ti25 Industrial Thermal Imager

Ti-Visor

Sun Visor

(for complete Ti Series)

Ti-Car Charger

Car charger

Recommended Accessories

Water and dust resistant: IP54

Size (HxWxD): Ti9/Ti10/Ti25: 267 x 127 x 152 mm

Weight: Ti9/Ti10/Ti25: 1.2 kg

Two Years Warranty

Complete package

Specifications

Fluke Ti9 Fluke Ti10 Fluke Ti25

Thermal imaging performance

Detector type 160 x 120 Focal Plane Array, uncooled microbolometer

Field of view (FOV) 23 º horizontal x 17 º vertical

Spatial resolution (IFOV) 2.5 mRad

Min focus distance 15 cm

Thermal sensitivity (NETD) ≤0.2 °C at 30 °C (200 mK) ≤0.13 °C at 30 °C (130 mK) ≤0.09 °C at 30 °C (90 mK)

Minimum span (auto/manual) 10 ˚C / 5 ˚C 10 ˚C / 5 ˚C 2.5 °C / 5 °C

Focus Manual

Visual imaging performance

Minimum focus distance 46 cm 46 cm

On camera operating modes Picture-in-Picture and full

screen IR plus Picture-in-Picture and full

screen IR plus Blending

Visible light camera 1.3 MegaPixel 1.3 MegaPixel

Temperature measurement

Temperature range -20 ˚C to 250 ˚C -20 ˚C to 250 ˚C -20 ˚C to 350 ˚C

Accuracy ± 5 °C or 5% ± 2 °C or 2% ± 2 °C or 2%

Measurement modes

Center point Center point Center point and hot and

cold markers

Image presentation

Digital display 9.1 cm (3.6”) landscape color VGA (640x480) LCD

LCD backlight Selectable bright or auto

Palettes

Ironbow, blue-red, high contrast, grey Ironbow, blue-red, high

contrast, grey, amber and

hot metal

Image and data storage

Storage medium 2GB SD Card (3000 .bmp IR images/1200 .IS2 images)

File formats supported JPG, JPEG, JPE, JFIF, BMP, GIF, DIB, PNG, TIF, and TIFF

Controls and adjustments

Set-up controls Date/time, Cº/ºF, language Date/time, Cº/ºF, language

On screen emissivity

correction On-screen

reflected background

temperature compensation

Language selection Eng, ger, fre, spa, por, ita, swe, fin, rus, cze, pol, tur

Image controls Smooth auto scaling and manual scaling

Power

Battery type Internal rechargeable battery NiMh (included)

Battery operating time 3 to 4 hours continuous operation

riešenia na presné meranie

http://www.elso.sk

TiS/TiR/TiRx/TiR1

Thermal Imagers

for Building Diagnostics

The affordable rugged Fluke TiRx and TiR Thermal Imagers are workhorse tools

for the demands of building envelope, restoration and remediation, inspection

and roong applications. Whether to perform energy audits, locate the origins of

construction problem or to nd roof leaks, the TiRx and TiR offer an economical

solution for complete detection, analysis and documentation.

• Delivers the clear images to nd problems fast with its 160x120 sensor

• Enhanced problem detection and analysis capabilities with patent pending

IR-Fusion® Technology (TiR)

• The Fluke TiRx can be upgraded to a full Fluke TiR with IR-Fusion at a later time.

• NETD 90 mK

The TiR1 Thermal Imager is the professional’s choice for building diagnostics. The

Fluke TiR1 has all the features of the Fluke TiR, but with an NETD of 0.07ºC for the

TiR1 to identify even small temperature differences that could indicate problems.

• IR-Fusion®, full option (combines visible image with IR image in full screen or

picture-in-picture views)

• Voice recording; record ndings by speaking into the camera. Voice annotations

can be recorded with every image you take. Voice comments are saved along with

individual images for future reference

• NETD 70 mK

Fluke TiR

Fluke TiRx

Optimized for energy audits, restoration and

remediation

The professional’s choice

Fluke’s entry level thermal imager for quick, easy, and accurate problem identication

and troubleshooting designed specically for the building inspection professional.

Whether you are a building inspector, plumber, roofer, electrician, energy auditor,

HVAC, insulator, or windows installer the Fluke Thermal Imaging Scanner is the

perfect tool to help you identify hidden building construction issues, nd moisture

intrusion, detect energy loss/missing insulation, and many basic electrical connection

and load problems. Now Fluke quality, durability, and performance are available in a

thermal imager engineered for the valueconscious building professional. The Fluke

TiS Thermal Imaging Scanner is the top-performing imager in its price class.

• Highest resolution (120x120) in price class

• Only imager in price class with versatile, manual focus

• Largest display size (3.7”) in price class.

• Long battery life lasts ~4 hours

• Rugged body engineered to withstand 2 m drop test

• Easy to use—the TiS Thermal Imaging Scanner provides you with a basic,

reliable solution for the building professional

• NETD 100 mK

Entry-level Thermal Imager

Fluke TiR1

Fluke TiS

New

riešenia na presné meranie

http://www.elso.sk

TiS/TiR/TiRx/TiR1

Thermal Imagers

for Building Diagnostics

Included Accessories

SmartView® software

2 GB SD card

SD card reader

Rugged hard carrying case

Soft carrying case

Hand strap

Rechargeable battery

AC charger/power supply

User manual

Ordering Information

Fluke TiS Thermal Imaging Scanner

Fluke TiRx Inspector Thermal Imager

Fluke TiR Thermal Imager for Building

Diagnostics

Fluike TiR1 Thermal Imager for Building

Diagnostics

Water and dust resistant: IP54

Size (HxWxD): 267 x 127 x 152 mm

Weight: 1.2 kg

Two Years Warranty

Complete package

Ti-Visor

Sun Visor

(for complete Ti Series)

Ti-Car Charger

Car charger

Recommended Accessories

Fluke TiS Fluke TiRx Fluke TiR Fluke TiR1

Thermal imaging performance

Detector type 120 x 120 Focal Plane

Array, uncooled

microbolometer

160 x 120 Focal Plane Array, uncooled microbolometer

Field of view (FOV) 17 º horizontal x 17 º

vertical 23 º horizontal x 17 º vertical

Spatial resolution (IFOV) 2.5 mRad

Min focus distance 15 cm

Thermal sensitivity (NETD) ≤0.1 °C at 30 °C

(100 mK) ≤0.09 °C at 30 °C

(90 mK) ≤0.07 °C at 30 °C

(70 mK)

Minimum span 5 ˚C (in auto mode) 2.5 ˚C / 5 ˚C (Auto/Manual)

Focus Manual

Visual imaging performance

Minimum focus distance - 46 cm

On camera operating modes - Picture-in-Picture and full screen IR Picture-in-Picture and

full screen IR plus

Blending

Visible light camera 1.3 MegaPixel

Temperature measurement

Temperature range -20 ˚C to 100 ˚C -20 ˚C to 150 ˚C

Accuracy ± 5 °C or 5% ± 2 °C or 2%

Measurement modes

Center point Center point and hot

and cold markers

Image presentation

Digital display 9.1 cm (3.6”) landscape color VGA (640x480) LCD

LCD backlight Selectable bright or auto

Palettes

Ironbow, blue-red,

greyscale Ironbow, blue-red, high contrast, grey Ironbow, blue-red, high

contrast, grey, amber

and hot metal

Image and data storage

Storage medium 2GB SD Card (3000 .bmp IR images/1200 .IS2 images)

File formats supported JPG, JPEG, JPE, JFIF, BMP, GIF, DIB, PNG, TIF, and TIFF

Controls and adjustments

Set-up controls Date/time, Cº/ºF, language Date/time, Cº/ºF, language

On screen emissivity

correction On-screen

reflected background

Language selection Eng, ger, fre, spa, por, ita, swe, fin, rus, cze, pol, tur

Image controls Smooth auto-scaling

and lock of level and

span

Smooth auto scaling and manual scaling

Power

Battery type Internal rechargeable battery NiMh (included)

Battery operating time 3 to 4 hours continuous operation

Specifications

FLK-TI-SBC3

Charging base (Ti32)

riešenia na presné meranie

http://www.elso.sk

CRange IRWindows

Included Accessories

Installation CD, self-adhesive drilling

template, security access key, warranty

statement.

Ordering Information

FLK-075-CLKT 75mm C-Range IR Window,

Kwik Twist

FLK-100-CLKT 100mm C-Range IR Window,

Kwik Twist

IP-200-UK Window Installation Kit

220/240V

Infrared windows mount into panel doors

and covers for switchgear, transformers,

bus bars and other live electrical

equipment, allowing Infrared, Ultraviolet,

Visual and IRfusion technologies to be

used without exposing personnel to live

equipment.

All infrared windows from Fluke use

the unique Quadraband™ multispectral

optic, allowing inspection with any

camera for total exibility both now and

in the future.

• Reduce the arc ash risk associated

with electrical thermography

• Increase efciency as thermographer

can work alone without being

accompanied by an electrician to isolate

and open panels

• Stay safety compliant with NFPA70E

and other safety protocols and leave the

panels closed

• Extend the life of your equipment with

more frequent IR scans

• Easy to install

• Durable enough to withstand extreme

outdoor conditions yet practical for

indoor applications as well.

Specifications

(Check the Fluke web for detailed specifications)

Increase the safety and speed of electrical

thermography

FLK-075-CLKT FLK-100-CLKT

Optic Data

Crystal Insert Diameter 75 mm 100 mm

Viewing Aperture Diameter 68 mm 89 mm

Viewing Aperture Area 3632 mm2 6322 mm2

Thickness 2 mm 4 mm

CLIRVU Coating

Shortwave IR Capable

Midwave IR Capable

Longwave IR Capable

Ultraviolet (UV) Capable

Visual Capable

Fusion Capable

General

Maximum Temperature

Gaskets 250º C

Body 659 º C

Optic 1400º C

Gaskets Low Smoke & Fume (LSF) compliant silicone

IP rating IP65

NEMA rating Typo 3/12 (UL & CSA Third Party Certified)

Vibration rating IEC60068-2-6

Humidity rating IEC60068-2-3

Pull out strength Up to 630 kg

Warranty: Lifetime replacement against manufacturing defects

riešenia na presné meranie

http://www.elso.sk

The Fluke Laser Distance Meters bring you the most advanced

measuring technology. Unlike ultrasonic distance meters with laser

pointers, these meters use a precision narrow laser beam that can

avoid the common errors caused by extraneous objects near

measurement targets.

Laser Distance Meters

riešenia na presné meranie

http://www.elso.sk

6574

421D, 416D, 411D

Laser Distance Meters

Included Accessories

Two AAA batteries, Users manual on CD,

Quick start guide, Nylon carrying case,

Wrist wrap (421D)

Ordering Information

Fluke 411D Laser Distance Meter

Fluke 416D Laser Distance Meter

Fluke 421D Laser Distance Meter

Professional-grade laser distance

measuring tools that are fast, easy to use,

and ﬁt in your pocket.

The Fluke laser distance meters bring you

the most advanced measuring technology.

These meters are fast, accurate, durable,

and easy to use — just point and shoot.

Their straightforward design and easy,

one-button operation mean you spend less

time measuring. Unlike ultrasonic distance

meters with laser pointers, the Fluke 421D,

416D and 411D use a precision narrow

laser beam that can avoid the common

errors caused by extraneous objects near

measurement targets.

These compact and handy Fluke distance

meters are designed for indoor, and limited

outdoor applications. Addition, subtraction,

area, and volume calculations could not

be simpler. The extra bright laser is clearly

visible so you can see your targeting point

even if an object is hard-to-reach or distant.

The Fluke 421D, 416D and 411D have a large

LCD screen and buttons positioned for one-

handed measurements.

Features

Operating temperature: 0°C to 40°C

Storage temperature: -25°C to 70°C

Operating altitude: up to 3500 m

Battery Life: 411D: up to 3000 readings

416D, 421D: up to 5000 readings

Size (HxWxD):

411D: 123 mm x 50 mm x 26 mm

416D: 135 mm x 46 mm x 31 mm

421D: 127 mm x 52 mm x 25 mm

Weight: 411D: 0.150 kg

416D: 0.110 kg

421D: 0.125 kg

Warranty: 2 years

Fluke 416DFluke 411D

411D 416D 421D

Reduction of estimation errors, saving both time and money OOO

Instant measurement with one-button operation OOO

Easy targeting with bright laser OOO

Quick calculation of area (square footage) and volume OOO

Easy addition and subtraction of measurements OOO

Improved battery life from automatic shut-off feature OOO

Pythagoras calculation for determining distance indirectly from two

other measurements

OOO

Pouch OOO

Ability to view more with large, 3-line display with backlight OO

Ability to measure up to 30 m 60 m 100 m

Storage capacity of measurements for quick recall of distance - 10 20

MIN/MAX function OO

Enhanced Pythagoras calculation for determining distance indi-

rectly from three other measurements

Audible feedback of on and off modes OO

Strong environment protection with IP54 (water spray & dust proof)

sealing

Audible feedback for taking room angle and incremental measurements

± 45° Tilt sensor for taking indirect measurements in hard to reach areas

Tripod mode allows you to mount to a tripod for measuring long

distances

Built in light sensor for activating the backlight saving battery life O

Corner angle feature, allows you to determine the angle of a corner O

Fluke 411D Fluke 416D Fluke 421D

Range (for extended distances, use a target plate) 30 m 60 m 100 m

Accuracy ± 3 mm ± 1.5 mm ± 1.5 mm

Measurement units 00.000 m 00.000 m 00.000 m

Measurement storage 10 locations 20 locations

Backlight OO

Automatic power off After 180 seconds After 180 seconds After 360 seconds

Speciﬁcations

(Check the Fluke web for detailed speciﬁcations)

411D/62 Kit

Combo kit includes:

- Fluke 62 Mini IR Thermometer

- Fluke 411D Laser Distance Meter

- Soft pouch for each model

Fluke 421D

riešenia na presné meranie

http://www.elso.sk

In response to the growing importance of air quality in buildings,

workplaces and homes, Fluke offers you a range of tools that monitor

temperature, humidity, air velocity, particulate, and carbon monoxide

levels. These tools help you to quickly and easily troubleshoot and

maintain indoor air quality, as well as to verify the efcient operation of

heating, ventilation and air conditioning systems.

Indoor Air Quality Tools

riešenia na presné meranie

http://www.elso.sk

975 AirMeter

Operating temperature

(CO and CO2 sensors): -20 °C to 50 °C

Operating temperature

(all other functions): -20 °C to 60 °C

Storage temperature: -20 °C to 60 °C

Humidity: 10% to 90%

Altitude: Up to 2000 m

975VP

AirMeter Velocity Probe

Recommended Accessories

Shock and vibration: MIL-PRF-28800F, Class 2

Battery: Rechargeable Li-Ion (primary), three-

AA (backup)

Weight: 0.544 kg

Size (HxWxD): 28.7 cm x 11.43 cm x 5.08 cm

Data logging: 25,000 records (continuous),

99 records (discrete)

Multilanguage interface: English, French,

Spanish, Portuguese and German

Two-year warranty

The Fluke 975 AirMeter combines ve air

monitoring tools into one, rugged and

easy-to-use handheld tool. Use the Fluke

975 to verify the efcient operation of

heating, ventilation and air conditioning

systems, and test for dangerous carbon

monoxide leaks in all types of buildings.

• Simultaneously measures, logs, and

displays temperature, humidity, CO2,

and CO on a bright, backlit LCD display

• One-touch air ow and velocity

measurements with available probe

• Min/Max/Average on all measured and

calculated readings

• Audible and visual threshold alarms

• Multi-language user interface

• Extensive discrete or continuous data

logging capacity, down-loadable to PC

via USB interface

Specifications

(Check the Fluke web for detailed specifications)

Fluke 975

Included Accessories

A4 alkaline batteries (3), Users Manual,

Calibration Cap, FlukeView Forms Software,

Power Adapter, International Power Plugs,

Air Velocity Probe (Fluke 975V only)

Ordering Information

Fluke 975 AirMeter

Fluke 975V AirMeter with Velocity

975R Regulator

975VP Air Velocity Probe

Feature Range Display resolution Accuracy

Measured specifications

Temperature -20 °C to 60 °C 0.1 °C ± 0.9 °C from 40 °C to 60 °C

± 0.5 °C from 5 °C to 40 °C

± 1.1 °C from -20 °C to 5 °C

Relative humidity 10 % to 90 % RH non-

condensing 1 % ± 2 % RH (10 % RH

to 90 % RH)

Air velocity 50 fpm to 3000 fpm

0.25 m/sec to 15 m/sec 1 fpm

0.005m/sec 4 % or 4 fpm*

3 % or 0.015 m/sec*

whichever is greater

*Accuracy specification only valid

for velocity readings above 50 fpm.

CO20 to 5000 ppm 1 ppm Warm up time 1 min

(5 minutes for full specification)

2.75 % + 75 ppm

CO 0 to 500 ppm 1 ppm ± 5 % or ± 3 ppm,

whichever is greater,

@ 20 °C and 50 % RH

Calculated specifications

Dew point temperature -44 °C to 57 °C 0.1 °C ± 1 °C when temp: -20 °C to 60 °C

RH: 40 % to 90 %

± 2 °C when temp: -20 °C to 60 °C

RH: 20 % to 40 %

± 4 °C when RH: 10 % to 20 %

Wet bulb temperature -16 °C to 57 °C 0.1 °C ± 1.2 °C when RH: 20 % to 90 %

temp: -20 °C to 60 °C

± 2.1 °C when RH: 10 % to 20 %

Volume flow rate (in a duct) 0 to 3,965 M3/m 0 to

140,000 cfm) 0.001 M3/min (1 cfm) N/A: The volume flow

calculation will be a simple average

of the data points times the

duct area

% outside air (based on temperature) 0 to 100 % 0.1 % N/A

% outside air (based on CO2) 0 to 100 % 0.1 % N/A

Combined inspection tool for complete air

quality inspections

riešenia na presné meranie

http://www.elso.sk

922 Airflow Meter

Data Storage: 99 readings

Size (HxWxD): 175 x 775 x 419 mm

Weight: 0.64 kg

Battery: Four AA batteries

Battery Life: 375 hours without backlight,

80 hours with backlight

Two Year Warranty

TPAK

Toolpak

See page 132

Recommended Accessories

Specifications

(Check the Fluke web for detailed specifications)

Fluke 922

Included Accessories

Fluke 922: Two Rubber Hoses, Wrist Strap, Four

AA Batteries 1.5 V Alkaline, Users Manual and

Soft Carrying Case

Fluke 922 Kit Includes: Fluke 922 Airflow Meter,

30.48 cm Pitot tube, ToolPak, Two Rubber

Hoses, Wrist Strap, Four AA Batteries 1.5 V

Alkaline, Users Manual and Hard Carrying

Case

Ordering Information

Fluke 922 Air Flow Meter

Fluke 922/Kit Airflow Meter with

30.48 cm Pitot Tube

General Specifications

Feature Range Resolution Accuracy

Operating Specifications

Air Pressure ± 4000 Pascals

± 16 in H2O

± 400 mm H2O

± 40 mbar

± 0.6 PSI

1 Pascal

0.001 in H2O

0.1 mm H2O

0.01 mbar

0.0001 PSI

± 1% +1 Pascal

± 1% + 0.01 in H2O

± 1% + 0.1 mm H2O

± 1% +0.01 mbar

± 1% + 0.0001 PSI

Air Velocity 250 to 16,000 fpm

1 to 80 m/s 1 fpm

0.001 m/s ± 2.5 % of reading at 10 m/s

(2000 p/min)

Air Flow (Volume) 0 to 99,999 cfm

0 to 99,999 m3/hr

0 to 99,999 l/s

1 cfm

1 m3/hr

1 l/s

Accuracy is a function of

velocity and duct size

Temperature 0 °C to 50 °C 0.1°C ± 1 % + 2 °C

General specifications

Operating Temperature 0 ºC to +50 ºC

Storage Temperature -40 ºC to +60 ºC

Operating Relative Humidity Non condensing (<10 ºC)

90% RH (10 ºC to 30 ºC)

75% RH (30 ºC to 40 ºC)

45% RH (40 ºC to 50 ºC) Without Condensation

IP Rating IP40

Operating Altitude 2000 m

Storage Altitude 12000 m

EMI, RFI, EMC Meets requirements for EN61326-1

Vibration MIL-PREF-28800F, Class 3

Max Pressure at Each Port 10 PSI

Fluke 922/Kit

PT12

Pitot Tube, 30.48 cm

Measures pressure, air flow and velocity for

maintaining balanced and comfortable

ventilation

The Fluke 922 makes airow

measurements easy by combining

pressure, air ow, and velocity into a

single, rugged meter. Compatible with

most Pitot tubes, the Fluke 922 allows

technicians to conveniently enter

their duct shape and dimensions for

maximum measurement accuracy.

Use the Fluke 922 to: Ensure proper air

ow balance and maintain a comfortable

environment; measure pressure drops

across lters and coils; match ventilation

to occupant loads; monitor indoor vs.

outdoor pressure relationships and

manage the building envelope; and

perform duct traversals for accurate

airow readings.

• Provides differential and static pressure,

air velocity and ow readings

• Convenient colored hoses help you

properly diagnose pressure readings

• Bright, backlit display for clear viewing

in all environments

• Min/Max/Average/Hold functions for

easy data analysis

• Auto power off saves battery life

riešenia na presné meranie

http://www.elso.sk

971 Temperature Humidity Meter

Carbon Monoxide Meters

Fluke 561

Combined Contact

and Non-contact

Thermometer

See page 54.

Included Accessories

Fluke CO-220: C50 soft carrying case and

battery

Ordering Information

Fluke 971 Temperature Humidity

Meter

Fluke CO-220 Carbon Monoxide Meter

CO-205 Aspirator Kit

Quickly take accurate humidity and

temperature readings in the air.

Temperature and humidity are two

important factors in maintaining

optimal comfort levels and good indoor

air quality. The Fluke 971 is invaluable

for facility maintenance and utility

technicians, HVAC-service contractors,

and specialists who assess indoor air

quality (IAQ). Lightweight, rugged, and

easy to hold, the Fluke 971 is the perfect

tool for monitoring problem areas.

• Simultaneously measures humidity and

temperature

• Measures dew point and wet bulb

• 99 record storage capacity

• Min/Max/Avg Data Hold

• Ergonomic design with built-in belt clip

and protective holster

• Backlit, dual readings display

• Twist-open protective cap

• Low battery indicator

Specifications

Temperature range -20 ºC to 60 ºC

Temperature accuracy

0 ºC to 45 ºC

-20 ºC to 0 ºC and 45 ºC to 60 ºC ± 0.5 0C

± 1.0 ºC

Resolution 0.1 ºC

Response time (temperature) 500 ms

Temperature sensor type NTC

Relative humidity range 5% to 95% R.H.

Relative humidity accuracy

10% to 90% R.H. @ 23 ºC

<10%, >90% R.H. @ 23 ºC ± 2.5 % R.H.

± 5.0 % R.H.

Humidity sensor Electronic capacitance polymer film sensor

Data storage 99 points

Response time (humidity) For 90% of total range - 60 sec with 1 m/s air movement

Operating temperature:

Temperature: -20 °C to 60 °C

Humidity: 0 °C to 60 °C

Storage temperature: : -20 °C to 55 °C

Battery life: 4 AAA alkaline, 200 hours

Safety: Complies with EN61326-1

Weight: 0.188 kg

Size (HxWxD): 194 mm x 60 mm x 34 mm

One Year Warranty

Carbon Monoxide Meters

CO-220 Carbon Monoxide Meter

The CO-220 Carbon Monoxide Meter makes it easy to take quick

and accurate measurements of CO levels. A large, backlit LCD

display shows CO levels from 0 to 1000 PPM. The MAX Hold

function stores and displays the maximum CO level.

1 year warranty.

Fluke 416D

Laser Distance Meter

See page 74 .

Fluke CO-220

Fluke 971

Temperature Humidity Meter

Fluke 971

Other useful tools

CO-205 Aspirator Kit

Allows flue gas samples up to 371°C to be drawn with the

CO-220 for carbon monoxide measurement.

1 year warranty.

Fluke CO-205

riešenia na presné meranie

http://www.elso.sk

983 Particle Counter /

RLD2 Leak Detector Flashlight

6 size channels 0.3, 0.5, 1.0, 2.0, 5.0, 10.0 µm

Flow rate 0.1 cfm (2.83 L/min) controlled by internal pump

Count modes Concentration, totalize, audio

Counting efficiency 50 % @ 0.3 µm; 100 % for particles > 0.45 µm (per JIS B9921:1997)

Zero count 1 count/5 minute (per JIS B9921:1997)

Coincidence loss 5 % at 56,000 particles per m3

Relative humidity ± 7 %, 20 % to 90 %, non-condensing

Temperature ± 3 °C, 10 °C to 40 °C

Data storage 5000 sample records (rotating buffer) of date, time, counts, relative humidity,

temperature, sample volumes, alarms, label

Alarms Counts, low battery, sensor fail

Delay time 0 to 24 hours

Sample inlet Isokinetic probe

Interface RS-232 and RS-485 via RJ-45

Calibration PSL particles in air (NIST traceable)

Included Accessories

Fluke 983:

Certificate of Calibration (NIST)

Isokinetic probe

Zero count filter

Windows-compatible software download

utility

DB9 to RS-232 adapter and cable

High purity tubing

1/8 in. hose barb adapter

Power supply

Operation manual

Hard molded carrying case

Fluke RLD2: Key chain carabiner and batteries.

Ordering Information

Fluke 983 Particle Counter

Fluke RLD2 Leak Detector Flashlight

Specifications

RLD2 Leak Detector Flashlight

Operating temperature: 10 °C to 40 °C, 20 % to

90 % relative humidity, non-condensing

Storage temperature: -10 °C to 50 °C, up to

90 % relative humidity, non-condensing

Power: AC adapter, 90 to 250 V AC, 50 to 60 Hz

Battery life/recharge time: 8 hours/2 hours

Rechargeable battery: NiMH, 4.8V at 4.5 Ah;

replaceable

Size (HxWxD): 209 mm x 114 mm x 57 mm

Weight: 1 kg

Warranty: 1 year

Fluke 983

The Fluke 983 Particle Counter

simultaneously measures and displays

six channels of particle size distribution,

temperature and humidity. This compact,

lightweight, self-contained tool allows

for one-handed operation. As the Fluke

983 doesn’t require level holding, it can

make accurate measurements in any

position. The 8 hour rechargeable battery

together with a large 5000 sample record

allows for complete air quality surveys in

one go. The Fluke 983 is the ideal tool for

determining size distribution of airborne

particles or tracking down a particle

source.

• Simultaneously measure and display 6

channels of particle sizes, temperature

and humidity

• Measure particle size down to 0.3 µm

• Selectable sample time, count data,

programmable delay

• Store 5000 records of date, time, counts,

relative humidity, temperature, sample

volumes, alarms and location label

• Upload stored data to a PC with

included software

• Compact, self-contained package allows

for one-handed operation

• Intuitive, easy-to-use user interface

• Always ready to run, with no uids to

rell

• Backlit LCD for use in any lighting

condition

Easy to use tool for troubleshooting and

maintaining indoor air quality

RLD2 Leak Detector Flashlight.

Leak detection made easy. The compact RLD2

uncovers refrigerant leaks instantly. Use the UV

light to nd the leakage area, then, use the laser

pointer to pinpoint the exact leak location.

• Six UV LEDs detect leak detection dyes

• Laser pointer clearly locates center of the UV

eld for accuracy

• Three LED ashlight with 100,000 hour LED life

• Operating temperature 0ºC to 50ºC

• Four operating modes: ashlight, UV light, laser

light, UV/laser light combination

• One year warranty

riešenia na presné meranie

http://www.elso.sk

8080

ScopeMeter portable oscilloscopes take you into territory standard

bench scopes can’t go: where it’s harsh, hazardous and dirty – without

sacricing any capabilities. They provide you with unmatched speed,

performance and analysis power while working on site.

ScopeMeter® Test Tools

riešenia na presné meranie

http://www.elso.sk

ScopeMeter 190 Series II

Combining rugged portability with the

performance of a bench scope, the Fluke 190

Series can take you from troubleshooting

microelectronics all the way into power

electronic applications. See more, x more

and go where you’ve never gone with a scope

before.

The first high-performance two and

four Channel scopes built for harsh

industrial environments.

Introducing the rst high-performance portable

oscilloscopes with 2 or 4 independently

insulated input channels, an IP51 dust- and

drip waterproof rating and a CAT III 1000 V /

CAT IV 600 V safety rating. Choose from 500 MHz,

200 MHz, 100 MHz or 60 MHz bandwidth

models.

Now plant maintenance engineers can take

a four-channel scope into the harsh world

of industrial electronics. Safely troubleshoot

three-phase systems like variable speed drives,

UPS or back-up generators. Measure input,

output and feedback signals simultaneously to

diagnose industrial electronics.

• 4 independent isolated input channels enable

3-axis industrial testing, simultaneous testing

of input signals, output signals and feedback

loops or safety interlocks

• 190-XX4 model with four independent

isolated inputs

• 190-XX2 models with two independenet

isolated scope inputs and DMM input

• Fast sample rate: up to 5 GS/s with up to

200 ps resolution

• Single shot, pulse width and video triggering

• Deep memory: 10,000 points per trace

waveform capture

• CAT III 1000 V / CAT IV 600 V, safety rated

• Up to seven hours of operation with high

performance Li-ion batteries, that extend

usage time plus optional external charger

• Battery door for conveniently swapping out

• Two isolated USB ports, for memory devices

and PC connectivity

• Security slot to lock down instrument using

standard Kensington® lock

• Connect & View™ triggering for intelligent,

automatic triggering on fast, slow and even

complex signals

• Frequency Spectrum using FFT analysis

• Automatic capture and REPLAY of 100 screens

• ScopeRecord™ mode gives 30000 points or

more per input channel for low frequency

signal analysis

• TrendPlot™ paperless recorder mode with

deep memory for long-term automatic

measurements

What could you do with four

channels?

Take multiple measurements simultaneously

to track down the root cause of your most

complex troubleshooting challenges.

• Easily diagnose timing-related issues with

multiple signals

• Real-time inspection of multiple signals

simultaneously

• Meaure a combination of input and output

signals and system safety interlocks and

feedback loops

Fluke 190-502 brings wide

bandwidth test applications in the

palm of your hand!

With the new 500 MHz model, the verication

of telecommunication equipment, high

frequency and wide bandwidth systems such

as radar equipment has become truly portable.

Conveniently verify the systems performance

right ‘on the spot’, fully safely without carrying

bulky lab equipment around. Battery powered

and fully oating – up to 600V CAT III, for each

channel and in between channel references.

Find problems in industrial

systems including:

• Circuit voltage/current overloading

• Attenuation/input impedance mismatch

• Signal uctuation/drift

• Conditioning circuits signal integrity

• Test point verication for critical signals

• Input/output/feedback timing issues

• Induced noise and disturbances

• Random shutdowns/reset

Diagnose VSDs* or power inverters

and converters

• Harmonics, transients and loads in three

phase power input

• Troubleshoot dc to ac converters for faulty

control circuits or output IGBT gate stages

• Cable interface - test PWM output for

reections and transients

• Vpwm measurement to measure the effective

voltage on drive outputs

The toughest portable scopes ever built

Application driven

Technologies Electrical Electromechanical Process Controls Automation Medical Imaging Avionics A/V & Security

Systems

Equipment Switch Gear,

Interlocks,

Motors,

Pumps,

Fans,

Furnaces,

Presses,

Mixers,

Refrigeration

Actuators,

VFD Drives,

Linear Motors,

Pressure-Level-

Flow-Position

Sensors,

Packaging

Equipment

Transducers,

Sensors,

Loop Controllers,

Calibrated Gauges

PLC´s,

Sensors,

Transducers,

Motion

Controllers,

Rotory

Encoders,

Scanners,

Readers,

Printers

XRay,

MRI,

Ultrasound

Imaging

equipment

Flight Line

Navigation

Systems,

Communication

systems,

Radar,

On board

aircraft control

systems

Retail security

devices,

Surveillance and

monitoring

equipment,

RFID

New

riešenia na presné meranie

http://www.elso.sk

ScopeMeter 190 Series II

New

Fluke 190-204

Fluke 190-202

Multiply your diagnostic powers with the new

Fluke 190 Series II portable oscilloscopes

Optional Accessories

C290 Hard shell protective carrying case for

190 Series II

HH290 Hanging Hook for 190 Series II

instruments

SCC290 FlukeView Software (full version) and

C290 Carrying Case kit

VPS410-R Voltage Probe set, 10:1, 300 MHz,

one set red

VPS410-G Voltage Probe set, 10:1, 300 MHz,

one set grey

VPS410-B Voltage Probe set, 10:1, 300 MHz,

one set blue

VPS410-V Voltage Probe set, 10:1, 300 MHz,

one set green

VPS420-R High working voltage probe set 150 MHz,

100:1, CAT III 2000 V (1000 V to earth)

BC190 Mains adapter/battery charger

EBC290 External battery charger for BP290

and BP291

TL175 TwistGuard™ safety designed Test

Leads set (1 red, 1 black)

BP290 Li-Ion battery pack, 2400 mAh

BP291 Li-Ion battery pack, 4800 mAh

SW90W FlukeView® ScopeMeter Software for

Windows®

VPS510-X Wide bandwidth probe set, 10:1,

500 MHz, 600V CAT III

ScopeMeter test tools are rugged solutions built for industrial troubleshooting. The

new Fluke 190 Series II are double-insulated oating oscilloscopes safety rated for

measurements up to CAT III 1000 V/CAT IV 600 V environments. The new 500 MHz

model is rated all the way up to 600 V CAT III.

Rated all the way to CAT IV

Measure from mV to kV safely

Independently isolated inputs allow you to make measurements in mixed circuits

having different ground references reducing the risk of accidental short circuits.

Conventional bench oscilloscopes without special differential probes and isolation

transformers can only reference measurements to line power earth ground. With

standard probes that cover a wide application range from mV to kV, you are ready for

anything from micro-electronics to heavy-duty higher voltage electrical applications.

IP-51 rated for harsh environments

Rugged and shock-proof, ScopeMeter portable oscilloscopes are built for dirty,

hazardous environments. With its sealed case, it can endure dust, drips, humidity and

airborne pollutants. Every time you reach for ScopeMeter you can be condent it will

work reliably wherever your work takes you.

USB connectivity makes it

easy to capture and share

waveforms

The new Fluke 190 Series II offers two USB ports,

electrically isolated from measurement input circuits.

Easily transfer data to a PC. Archive and share

waveforms with OEMs, colleagues and support staff.

Store waveforms, screen captures and instrument

setups onto USB memory devices.

FlukeView ScopeMeter software for

documenting, archiving and analysis

Get more out of your ScopeMeter with FlukeView® ScopeMeter® SW90W Software for

Windows.

• Documentation—transfer waveforms, screens and data to your PC for printing or

importing data into a report

• Add text to ScopeMeter settings—give operators guidance when recalling settings

• Archive—create a library of waveforms for easy reference, waveform comparison, or

pass/fail testing

• Analysis—use cursors, perform spectrum analysis or export data to another

analysis program

True RMS

riešenia na presné meranie

http://www.elso.sk

Figure 1. G703 - E1 template

Application Note

From the Fluke Digital Library @ www.fluke.com/library

The G.703 standard

G.703 is a standard origi-

nally introduced for voice and

data transmission over digital

networks. It is an ITU recom-

mendation (formerly CCITT)

that’s associated with the PCM

standard. Analog-voice to digital-

data conversion according to

PCM requires a bandwidth of

64 kb/s (±100 ppm), resulting in

the basic unit for G.703. Through

multiplexing this results in a T1

of 1.544 Mb/s and E1 of

2.048 Mb/s.

The electrical characteristics

of the network interfaces are

described in recommendation

G.703. The signal limits for a

2.048 Mb/s signal are shown in

Figure 1.

Multiple-channel

testing using two

different masks

A balun is used between the

patch panel and a coaxial

transmission line to match the

impedance of the 120 Ω sym-

metrical line to a 75 Ω coaxial

line. The input and output of the

balun each has its specific mask.

The ScopeMeter 190 Series II

portable oscilloscopes can simul-

taneously perform a pass/fail test

at the input and output of the

balun with different masks.

The floating and isolated

inputs of the Fluke ScopeMeter

190 Series II test tools make

these measurements pos-

sible without the risk of making

unwanted groundings. Moreover,

the high impedance probes allow

for direct measurements without

loading the line and without the

need for an external differential

probe.

Testing telecommunication

equipment using Pass/Fail

mask testing with a Fluke

ScopeMeter

190 Series II

Editing the pass/fail

templates

With FlukeView we can export

a waveform into a spreadsheet

and a custom template can be

created by editing a waveform

using Excel.

A reference template for

pass/fail testing can be cre-

ated by saving waveforms from

FlukeView in .csv format and

editing the waveform using, for

Figure 2. ISDN30 network

ISDN 30

Patch

Panel

Balun SDH

Distr.

2 Mb/s

120 Ω 2 Mb/s

75 Ω

Telephone

Exchange

Nowadays digital communication systems such as Synchronous

Digital Hierarchy (SDH) in Europe and the Synchronous Optical

Network (SONET) in North America require standard test methods.

The electrical signals are tested against the standard ITU pulse

masks. The Fluke ScopeMeter 190 Series II portable oscilloscope

offers a standard pass/fail function that can be used to perform

these tests. The instrument is capable of storing up to 100 “fails”

for further analysis.

Application Note

Demystifying

drive anomalies

using the Fluke 190 Series II 2-Channel

ScopeMeter® portable oscilloscope

From the Fluke Digital Library @ www.fluke.com/library

Vogel, an HVAC technician,

becomes energized when dis-

cussing the return on investment

in his handheld ScopeMeter

Test Tool. “Out at one large site,

where we monitor and trouble-

shoot variable frequency drives

(VFDs), component-level repair

can often mean the difference

between a $20 repair part and

a $100,000 repair bill. I know

firsthand, because we recently

documented that very scenario.”

On large VFDs, Vogel uses his

ScopeMeter portable oscilloscope

to uncover capacitance problems,

transistor firing mishaps, and

even bleed-throughs on a gate.

“Of course, a transistor is basi-

cally a lightning-fast switch,”

he says. “It switches back and

forth between open and closed,

and it can sometimes start to

break down. When that happens,

motors will start doing weird

things. For example, at load

stage we’ll actually see

the motor banging back and

forth as if it is not sure which

way to turn.”

Seeing is believing? More aptly, seeing is

understanding.

If anyone can wring every last ounce of functionality out

of a piece of electronic test equipment, it’s Chris Vogel.

At Siemens Building Technologies, Vogel has his work cut

out for him keeping HVAC systems running for the com-

pany’s large commercial customers in Florida’s tropical

weather, which is marked by seemingly nonstop 90 °F

temperatures and 95 % humidity levels. And that’s just

one of the challenges faced by technicians at Siemens

Building Technologies, which plays a more sweeping role

in its customers’ success: ensuring energy efficiency,

comfort, protection against unauthorized access, and

fire safety year-round for every building or office tower

entrusted to it by customers.

Storing a slice of time

It’s important, says Vogel,

that the technician be able to

characterize VFD problems by

capturing a waveform from the

offending drive. His premise: A

signal is much more telling when

presented in a waveform view

than in a single, static volt-

age reading. The signal has a

shape and value that may look

right at a glance, but could just

as easily have a distortion or

rough “edge,” or a momentary

spike almost too short to be

seen. Either problem, or a host

of other signal anomalies, would

be indistinguishable with just a

numeric reading of the signal.

“The scope allows me to

record information, and from a

number of sources—sine waves

on the inputs and outputs of

VFDs, current and voltage—and,

for that matter, make compari-

sons of current and voltage so

that I can derive a power factor

for the circuit.”

Operator: Chris Vogel, HVAC

Technician for Siemens Building

Technologies

Testing

Functions

Case

Study

Measuring tools: 190 Series II

2-Channel ScopeMeter

Test Tool

Measurements: Current and voltage

waveform analysis, power factor

Connect the ScopeMeter

test tool and view the

result: the start of every

measurement

It frequently happens t hat service

engineers have to spend a lot of

time adjusting thei r measuring

device such as a portable oscil-

loscope for an optimal s etting.

Valuable time is spent completi ng

this set up, and ideally, this could

be done automatically.

With the introduction of the

new ScopeMeter 190 Series II,

Fluke has revamped it s unique

feature, Connect and Vie w.

Scope users know how d if-

ficult trigger ing can be. Wrong

settings show unstable and

sometimes wrong resu lts. Fluke’s

unique Connect a nd View

recognizes signal patterns, and

automatically sets up cor rect

triggering, attenu ator and time

base settings. S witching on the

ScopeMeter portable oscilloscope

to display correct sig nal patterns

only takes a couple of second s,

and this is exact ly what an

operator wants.

Settings regarding

 amplitude,

 timebase,

 triggering,

 etc.

are automatically detec ted and

adjusted, followed by display-

ing the signal in t he correct ratio

with respect to t he horizontal

and vertical ax is. At least 1.5

to 4 periods of the signal a re

measured before the pattern is

shown.

Connect and View prov ides

a stable, reliable and repeat-

able display of virtually any

signal, includi ng motor drive and

control signals, w ithout touch-

ing a button. Signal cha nges are

instantly recog nized and settings

adjusted for, once again, a stable

display. This is all done auto -

matically, but manual overruling

is still possible. If manual over-

ruling is needed, t he ScopeMeter

190 Series will switch from auto-

matic to 1/2 automatic, which is

visible on the dis play.

Figure 1 gives a n example of

the different ty pes of waveforms

which can de detected by

Connect & View. If requir ed the

criteria for best set tings can be

optimized by sw itching on one or

all of the followi ng options:

 Automatic trigger

Application Note

From the Fluke Digital Library @ www.fluke.com/library

Figure 1.

 AC/DC coupling

 Glitch detect

Figure 2 shows the d ifferent

settings.

ScopeMeter 190 Series II

AS400

Recommended Accessories

EBC290VPS420-R

SCC290SW90W

If you’ve used other scopes, you know how tricky

triggering can be. If settings are incorrect, results

can be unstable or incorrect. Connect-and-

View™ automatically sets up correct triggering

by recognizing signal patterns. Without touching

a button, you get a stable, reliable and repeatable

display of virtually any signal including motor

drive and control signals. It’s especially fast and

convenient when you’re measuring a number of

test points in rapid succession.

190 Series II models with isolated dual input

scope and dedicated digital multimeter.

Conveniently switch from waveform analysis

to precise multimeter measurements using

the built in 5000 count digital multimeter.

Measurement functions include Vdc, Vac,

Vac+dc, resistance, continuity and diode test.

Measure current and temperature using suitable

shunt, probe or adapter with wide range of

scaling factors.

Scope users know how frustrating it is to see a one-

time anomaly ash by, never to be seen again. Not

with the ScopeMeter 190-series! Now you can look

back in time with the touch of a button. In normal

use, the instrument continuously memorizes the

most recent 100 screens. At any moment in time, you

can ‘freeze’ these latest screens and scroll through

them picture-by-picture or replay them as a ‘live’

animation. Cursors and zoom can be used for further analysis. You can even use

the advanced trigger capabilities to capture up to 100 specic events. Two sets of 100

screens with individual time stamps can be stored for later recall or download to a PC.

See dynamic signal behavior instantly

The digital Persistence mode helps to nd anomalies and to analyze complex

dynamic signals by showing the waveforms amplitude distribution over time using

multiple intensity levels and user selectable decay time – it’s as if you’re looking at

the display of an analog, real time oscilloscope! A fast display update rate reveals

signal changes instantaneously, useful for instance when making adjustments to a

system under test.

Connect-and-View™ captures even the

most complex motor drive signals.

The built in multimeter provides

convenient precision measurements.

Connect-and-View™ triggering for an instant,

stable display

Built-in digital multimeter (2 channel models)

Automatic capture and replay op 100 screens

A range of application notes is available.

See the Fluke website.

Included Accessories

Fluke 190 Series II 4-channel instruments include a set

of four probes, hanging strap, handstrap, USB cable with

mini-B connector, double capacity Li-ion battery BP291,

battery charger/power adapter BC190, a FlukeView demo

package and users manuals on CD-ROM. The /S-versions

also include the C290 hard-shell carrying case and the

FlukeView software package. The 2-channel models come

with two probes plus a set of TL175 test leads and a single

capacity battery BP290. The 190-502 also includes two

pieces TRM50 coaxial feedthrough terminator.

The SCC290 kit includes: C290 hardshell carrying case and

FlukeView

for Windows

software (full version).

Ordering Information

Fluke-190-502/S Color ScopeMeter (500 MHz,

2 channel), with SCC290-kit

Fluke-190-204/S Color ScopeMeter (200 MHz,

4 channel), with SCC290-kit

Fluke-190-204 Color ScopeMeter (200 MHz, 4 channel)

Fluke-190-202/S Color ScopeMeter (200 MHz,

2 channel), with SCC290-kit

Fluke-190-202 Color ScopeMeter (200 MHz, 2 channel)

Fluke-190-104/S Color ScopeMeter (100 MHz,

4 channel), with SCC290-kit

Fluke-190-104 Color ScopeMeter (100 MHz, 4 channel)

Fluke-190-062/S Color ScopeMeter (60 MHz,

2 channel), with SCC290-kit

Fluke-190-062 Color ScopeMeter (60 MHz, 2 channel)

AS400 Probe Accessory Extension set for

VPS400 Series probes

BP291 Double capacity Li-Ion battery

(4800 mAh) pack for 190C Series II

BP290 Single capacity Li-ion battery

(2400 mAh) pack for 190-series II

C195 Soft padded carrying case for

ScopeMeter and accessories

C290 Protective Carrying Case for Fluke

190-series II

EBC290 External Battery Charger for charging

BP290 or BC291 outside the instrument

HH290 Hanging Hook

RS400 Probe Accessory Replacement set

for VPS400 series probes

RS500 Probe Accessory Replacement set

for VPS510 series probes

SCC290 Software and Case kit for Fluke 190

Series 190 Series II. Includes SW90W

and C290.

SW90W FlukeView

ScopeMeter Software for

Windows

(full version)

TRM50 Coaxial 50  feedthrough terminator

VPS410-x Probe-set, 10:1, 1000V CAT III / 600V

CAT IV (colors: blue, green, red, grey)

VPS420-R Probe-set, bicolor (r/b), 100:1, 150 MHz,

1000V CAT III / 600V CAT IV, working

voltage (voltage between probe tip and

reference lead): 2000V CAT III / 1200V

CAT IV.

VPS510-x Wide bandwidth probeset, 500 MHz,

10:1, 600V CAT III

riešenia na presné meranie

http://www.elso.sk

ScopeMeter® 120 Series

SCC128

See page 125

Recommended Accessories

Fluke 125

Included Accessories

PM 8907 line adapter/charger, STL120-III

shielded test leads set (1 red, 1 grey) including

hook clips, BB120 shielded BNC adapter,

BP120MH NiMH battery pack, VPS40-III wide

bandwidth Voltage Probe (Fluke 124/125),

TL175 Safe-guard testlead, i400s current

clamp (Fluke 125), Getting Started booklet,

user’s manual (cd-rom)

Ordering Information

Fluke 123 Industrial ScopeMeter® (20MHz)

Fluke 123/S Industrial ScopeMeter® (20MHz)

+ SCC120 kit

Fluke 124 Industrial ScopeMeter® (40MHz)

Fluke 124/S Industrial ScopeMeter® (40MHz)

+ SCC120 kit

Fluke 125 Industrial ScopeMeter (40 MHz)

Fluke 125/S Industrial ScopeMeter (40 MHz) +

SCC120 kit

SCC120 FlukeView® Software + OC4USB

Cable + Carrying Case

OC4USB USB Interface Cable

PM9080 RS-232 Interface Cable

DP120 Differential Voltage Probe

ITP120 Isolated Trigger Probe

SW90W FlukeView Software

BHT190 Set of 3 break-out adapters

(Fluke 125)

OC4USB

See page 86

The compact ScopeMeter 120 Series

is the rugged solution for industrial

troubleshooting and installation

applications. It’s a truly integrated test

tool, with oscilloscope, multimeter and

“paperless” recorder in one affordable,

easy-to-use instrument. Find answers to

problems in machinery, instrumentation,

control and power systems quickly and

easily.

• Dual-input 40 MHz or 20 MHz digital

oscilloscope

• Two 5,000 counts true-RMS digital

multimeters

• A dual-input TrendPlot™ recorder

• Bus Health Test for industrial bus

systems (Fluke 125)

• Connect-and-View™ trigger simplicity

for hands-off operation

• Power Measurements and Harmonics

measurement (Fluke 125)

• Shielded test leads for oscilloscope,

resistance and continuity

measurements

• Up to 7 hours battery operation

• 600 V CAT III safety certied

• Optically isolated interface for PC and

Printer connection (optional)

• Rugged, compact case

Connect-and-View™ triggering for

an instant, stable display

Scope users know how difcult triggering

can be. Wrong settings show unstable

and sometimes wrong results. Fluke’s

unique Connect-and-View recognizes

signal patterns, and automatically

sets up correct triggering. It provides a

stable, reliable and repeatable display

of virtually any signal - including

motordrive and control signals - without

touching a button. Signal changes

are instantly recognized and settings

adjusted for - once again - a stable

display.

Use TrendPlot™ to help find

intermittents fast

The toughest faults to nd are those

that happen only once in a while:

intermittents. They can be caused by

bad connections, dust, dirt, corrosion

or simply broken wiring or connectors.

You may not be around to see it – your

Fluke ScopeMeter will. In this “paperless

recorder” mode, you can plot the

minimum and maximum peak values

and average over time – up to 22 days

(Fluke 190 Series) or 16 days (Fluke 120

Series).

Bus Health mode (Fluke 125)

Bus Health mode gives a clear “Good/

Bad” indication for the electrical signals

on industrial buses and networks, such

as CAN-bus, Pro-bus, RS-232 and many

more. The Fluke 125 validates the quality

of the electrical signals as soon as any

electrical signals are passed along the

network.

Fluke 124

Fluke 123

True RMS

DP120

See page 86

C125

See page 124

SCC120

Connect-and-View captures even the most

complex motor drive signals.

Bus Health mode allows for an analysis of the

signal quality on an industrial network.

See page 85 for specifications.

Three-in-one simplicity

riešenia na presné meranie

http://www.elso.sk

ScopeMeterTest Tools

General ScopeMeter

Specifications

Fluke 225C/S Industrial Networks

and Bus Health Test

Built on the Fluke 190C-series, the 225C/S makes Bus Health

Test analysis on the electrical signals on an industrial bus

or network, giving a clear “Good”, “Weak” or “Bad” validation

of the relevant parameters, presented next to the actual

measurement value. The Fluke 225C/S can make the signal

quality validation as soon as electrical signals are passed

along the network, without looking at the data content. It nds

errors like improper cable connections, bad contacts, incorrect

grounding and missing or superuous terminators.

Included Accessories

BHT190 Set of three break-out adapters for

industrial networks

BC190 Mains adapter/Battery charger

BP190 NiMH battery pack (installed)

VPS210 Voltage probe sets (1 red, 1 grey)

TL175 SafeGuard(r) Testlead set

C190 Hard shell protective carrying case

OC4USB Optically insulated USB interface

cable for PC connectivity

SW90W FlukeView software package

(full version)

Ordering Information

225C/S Color ScopeMeter (200 MHz,

2.5 GS/s) with Bus Health Test

capabilities and SCC-kit.

Model: 190-502 190-204 190-202 190-104 190-102 190-062 225C/S 125 124 123

Oscilloscope Specifications

Bandwidth 500 MHz 200 MHz 100 MHz 60 MHz 200 MHz 40 MHz 20 MHz

Max. real time sample rate 5 GS/s 2.5 GS/s 1.25 GS/s 625 MS/s 2.5 GS/s 25 MS/s

Input sensitivity 2 mV/div. 5 mV/div.

Max. timebase speed 1 ns/div. 2 ns/div. 4 ns/div. 10 ns/div. 5 ns/div. 10 ns/div. 20 ns/div.

Inputs and digitizers 2 + Ext.Tr. 4 2 + Ext.Tr. 4 2 + Ext.Tr. 2 + Ext.Tr. 2 + Ext.Tr. 2 (+ Ext.Trig. Optional)

Independently floating isolated inputs 600 V

CAT III 1000 V CAT III,

600 V CAT IV 600 V

CAT III -

Max.record length

…. In Scope mode

…. In ScopeRecord mode 10 000 samples per trace

30 000 min/max pairs 3000

27500 512 min/max pairs per input

Glitch capture 8 ns peak detect at full timebase range 50 ns 40 ns

True RMS multimeter built-in (5000 counts) yes - yes - yes dual 5000 counts DMM

Dedicated test capabilities V/Hz ratio - V/Hz ratio - V/Hz ratio Bus health test -

General Specifications

Mains adapter/battery charger incl. (type) BC 190 PM8907

Battery installed BP291 BP291 BP290 BP291 BP290 BP290 BP190 BP120MH

Size 265 x 190 x70 mm ** 232 x 115 x 50 mm

Weight 2.1 kg 2.2 kg 2.1 kg 2.2 kg 2.1 kg 2 kg 1.2 kg

Safety certified 1000 V CAT III / 600 V CAT IV 600 V CAT III

Typical status overview of a bushealth measurement.

riešenia na presné meranie

http://www.elso.sk

VPS410-X

PM9091/9092

RS400

VPS420-R

PM9081

AS400

VPS510-x

PM9082

BP291

STL120-III

PM9093

OC4USB

VPS40-III

DP120

EBC290

ScopeMeter® Accessories

ScopeMeter series 190-series II 120-series

VPS410-x VPS420-R VPS510-x STL120-III VPS40-III DP120

Description Voltage probe High working voltage

probe* Wide bandwidth

voltage probe Shielded Test leads Voltage probe Differential Voltage

Probe

Colors available red, grey, blue, green bicolor (red & black) red, grey, blue, green red + grey (1 set) black red + grey (1 set)

Attenuation 10:1 100:1 10:1

1:1

10:1 200:1 / 20:1

Bandwidth 300 MHz 150 MHz 500 MHz 12.5 MHz 40 MHz 20 MHz

Length 1.2 m 1.2 m 1.2 m 1.2 m 1.2 m 1.5 m (2x)

Safety Rating CAT II -- -- -- 1000 V 1000 V 1000 V

Safety Rating CAT III 1000 V 1000 V* 300 V

600 V

600 V 600 V

Safety Rating CAT IV 600 V 600 V* -- -- -- --

PM9091 PM9092 PM9081 PM9082 PM9093

Description Safety designed 50  BNC Cable set

(1 red, 1 black, 1 grey) Dual banana plug

(m) to female BNC Dual banana jack

(f) to BNC plug (m) BNC (m) to dual

BNC (f) ‘T-piece’

Length 1.5 m each 0.5 m each -- -- --

Safety Rating CAT III 300 V 600 V 600 V

600 V

10:1

* High Working Voltage Probe is specied for working voltages (between probe tip and reference lead) up to 2000V in CAT III or 1200V in CAT IV environments. Reference lead

voltage (between reference lead and earth ground): 1000V in CAT III, 600V in CAT IV. These specication applies only when used with Fluke 190-series II Test Tool.

RS400 Probe Accessory Replacement set for VPS200 and VPS400 series probes

AS400 Accessory Extension set for VPS200 and VPS400 series probes

PM9080 RS232 interface cable for 120-series

OC4USB Optocoupler to USB interface cable for 120 series

BP120MH Ni-MH battery pack for Fluke 120-series and Fluke 43B

BP290 Single capacity Li-ion battery pack for 190-series II

BP291 Double capacity Li-ion battery pack for 190-series II

EBC290 External battery charger for BP290 and BP291

TRM50 Coaxial 50  feedthrough terminator

RS500 Probe Accessory Replacement set for VPS510 series probes

C437-II Hard shell protective carrying case with rollers for 190-II and 430-II

RF-AM90 RF Detector and Demodulation probe

riešenia na presné meranie

http://www.elso.sk

We offer an extensive range of power quality test tools for

troubleshooting, predictive maintenance and long-term recording in

industrial and utility applications. For the development and test of

electrical equipment, our high-precision power analyzers enable easy

and reliable use in the eld or as a bench unit in test laboratories.

Additionally, the Fluke-patented energy loss algorithm, Unied Power

Measurement, measures and quanties energy losses due to harmonics

and unbalance issues, allowing the user to pinpoint the origin of energy

waste within a system.

Power Quality Tools and Power

Analyzers

riešenia na presné meranie

http://www.elso.sk

Power Quality Selection Guide

Power quality tools help pinpoint problems fast

Basic measurements Application use

Single phase Three phase

VR1710 345 43B 430 II 1735 1740 1750 1760

RMS voltage Detailed RMS trending shows how connected loads

behave.

OOOOOOOO

RMS Current

OOOOOOO

Energy studies

Measure V, I, kW, Cos/DPF, kWhr Get detailed power and energy consumption

profiles during energy audits and pinpoint savings

opportunities.

OOOOOOO

Measure MIN/MAX and AVG values

OOOOOOO

10 day logging

OOOOOOO

Energy aggregation

OOOOOOO

Utility meter pulse input

Energy Loss (Eff. kW, Reactive kVAR, Unbalance kVAR,

Distortion kVAR, Neutral kVAR)

OOOOOOO

Energy loss calculator

Basic harmonics study

THD measurement (V & I) Discover the source of distortion in your installation, so

that you can filter those loads or move them to separate

circuits.

OOOOOOOO

Harmonics 1 to 25 for V & I

OOOOOO



(not 1743)

Tabular values

OOOOO

Neutral current measurement

OOOOO

Crest factor

OOO OOO

Advanced harmonics study

Full harmonic spectrum If distorting loads are causing problems in your

installation, you need comprehensive data to intentify

the source and create a solution.

OOOOOOO

Power harmonics

OOO OO

Harmonics 1 to 50 and dc

OOO O

(no DC)

(not 1743)

k-factor

OOO OO

%Fundamental and %RMS

OOO OOO

Basic Industrial PQ Troubleshooting

Oscilloscope function When troubleshooting in the field, graphical data

enables you to trace the source of the problem at hand.

OOOO OO

Voltage dips and swells

O OOOOOO

Phasor diagram

OOO

Trend recording

OOOO OO

Inrush current

OOO OO

Advanced industrial PQ troubleshooting

Comprehensive logging capability Complex installations often require a deeper dive into

measurement data. Multiple loads may be interacting

randomly to cause a single problem.

OOOOOOO

Transient capture

OOO OO

Flicker

O O OOO

EN50160 analysis

O OOO

Complex System interaction event capture (manual

threshold setting)

Random/variable system event capture (Adaptive

threshold setting)

400 Hz

O

(only 437-II)

Utility PQ benchmarking

Phase sequence components Before you install sensitive loads, make sure you

understand the existing quality of power delivered by

your utility. Comparing benchmarks over time can help

pinpoint potential areas of concern.

OOO

Interharmonics

O OOO

Mains signaling

O OOO

IEC61000-4-30 Class A

Software

Power Log To make use of the power data you collect, you need

software that can help analyze your findings and share

them with equipment providers and plant management.

OO OO

PQ Log

Power Analyze

PQ Analyze

FlukeView Forms

FSD card (max 32 GB) 8 GB 8 GB

riešenia na presné meranie

http://www.elso.sk

345

Power Quality Clamp Meter

Fluke 345

Included Accessories

Soft carrying case, Power Log software,

Test probes, Test leads, Alligator clips,

International ac adapter / battery eliminator,

Printed English User manual, Multi-language

manual on CD

Ordering Information

Fluke 345 Power Quality Clamp Meter

View waveforms for equipment

checking and setup

Log parameters over time

to track down intermittent faults

Recommended Accessories

C550

See page 130

TP1-1

See page 123

AC220

See page 124

TP220-1

See page 123

TLK291

See page 123

The Fluke 345 measures a wide range of

electrical parameters for troubleshooting

power disturbances in single- and

three-phase electrical loads. With a

bright color display to see waveforms

and trends, a low-pass lter to remove

high frequency noise, and a high EMC

immunity design, the Fluke 345 is ideal

for measurements on switching loads

such as variable speed drives, electronic

lighting and UPS systems.

• High safety rating: 600V CAT IV / 1000V

CAT III rated for use at the service

entrance

• ac/dc current measurements: Clamp-

on measurement of ac peak and dc

current up to 2000 A without breaking

the circuit

• Harmonic analysis: Analyze, display

and log harmonics up to the 30th

harmonic (40th harmonic for 15 Hz to

22 Hz)

• Verify batteries: Direct measurement

of dc ripple (%) for battery and dc

systems

Specifications

(Check the Fluke web for detailed specifications)

Power supply: 1.5 V Alkaline AA MN 1500 or IEC LR6

x 6 Battery

Battery life (typical): >10 hours (backlight on full);

>12 hours (backlight reduced)

Safety: IEC 61010-1 600 V CAT IV, 1000V CAT III

(maximum input phase-phase 825V rms) double or

reinforced insulation, pollution degree 2

Protection: IP40; EN60529

Operating temperature: 0 °C to 50 °C

Display: Color transmissive LCD 320 x 240 pixels

(70 mm diagonal) with 2 level backlight

Digital output: USB interface to a PC

Size (HxWxD): 300 mm x 98 mm x 52 mm

Jaw opening: 60 mm

Jaw capacity: 58 mm diameter

Weight (including batteries): 0.82 kg

Two Year Warranty

Current measurement

DC, DC rms, AC rms All measurements DC and 15 Hz to 1 kHz.

Maximum overload 10,000 A or RMS x frequency < 400,000. Amps rms is a true rms

measurement (AC + DC).

Measuring range 0 – 2000 A dc or 1400 AC rms

Harmonics All measurements up to 30th harmonic (40th harmonic for 15 Hz to 22 Hz); Frequency

range F0 : 15 Hz to 22 Hz and 45 Hz to 65 Hz; Iacrms > 10A

Voltage measurement

DC, DC rms, AC rms All measurements DC and 15 Hz to 1 kHz. Maximum overload 1,000 V rms. Volts rms is a

true-rms measurement (AC + DC).

Measuring range 0 – 825 V DC or AC rms

Harmonics All measurements up to 30th harmonic; Frequency range F0 : 15 Hz to 22 Hz and 45 Hz

to 65 Hz; Vacrms > 1V

Watts measurement (single- and three-phase) DC, DC rms, AC rms

Measuring range 0 – 1650 kW DC or 1200 kW ac

VA measurement (single- and three-phase) DC, DC rms, AC rms

Measuring range 0 -1650 kVA DC or 1200 kVA ac

VAR measurement (single- and three-phase)

Measuring range 0 – 1250 kVAR

Power factor (single- and three-phase)

Measuring range 0.3 cap…1.0… 0.3 ind (72.5° cap…0°… 72.5° ind)

Displacement power factor

Measuring range 0.3 cap … 1.0 … 0.3 ind (72.5° cap ... 0° ... 72.5° ind)

Kilowatt Hour (kWHr)

Measuring range 40,000 kWHr

Scope function

Time base 2.5 ms, 5 ms, 10 ms, 25 ms, 50 ms/div

Current management:

Ranges 10 A/20 A/40 A/100 A; 200 A/400 A/1000 A/2000 A

Voltage measurement:

Ranges 4 V/10 V/20 V/40 V/100 V; 200 V/400 V/1000 V

Inrush current function All measurements dc and 15 Hz to 1 kHz

Ranges 40, 400 and 2000 A

Memory Up to 50 screen shots and over 150,000 individual measurement values

The ideal troubleshooting tool for modern

electrical loads

riešenia na presné meranie

http://www.elso.sk

43B Single-phase Power

Quality Analyzer

The Fluke 43B is the choice for

diagnosing and troubleshooting power

quality and general equipment failures.

Ease to use thanks to menu selection of

the power modes, it combines the

capabilities of a power quality analyzer, a

20 MHz oscilloscope, a multimeter and a

data recorder in a single instrument.

Specifications

(Check the Fluke web for detailed specifications)

Battery life: Rechargeable Ni-MH pack (charger included), 6 hrs typical (continuous)

Shock & Vibration: Mil 28800E, Type 3, Class III, Style B.

Operating temperature: 0°C to 50°C; Case: IP51 (dust, drip, waterproof)

Size (HxWxD): 232 mm x 115 mm x 50 mm; Weight: 1.1 kg

Three Years Warranty

Included Accessories

TL224 test lead set, AC220 alligator clip set,

TP4 test probe set, BP120MH rechargeable

battery pack, BB120 shielded BNC adapter,

PM8907 line adapter/charger, i400s AC current

clamp, AB200 alligator clip set,

TP1-1 test probe set, C120 hand carrying case,

OC4USB interface cable, SW43W FlukeView

software, VPS 40 voltage probe, Fluke 61 IR

thermometer, user and application manual.

Ordening information

Fluke 43B Power Quality Analyzer

(single-phase)

Recommended Accessories

80TK

See page 128

i1000s

See page 126

i2000flex

See page 126

Fluke 43B

On all inputs

True RMS

Menu items Measurements Ranges Accuracy

Volts/Amps/Hz Volts

Amps

Mains frequency

CF Crest Factor

5.000 V - 1250 V

50.00A - 50.00 kA

40.0 - 70.0 Hz

1,0 à 10,0

±(1%+10)

±(0.5%+2)

±(5%+1)

Power Watts, VAR, VA

PF, DPF, COS ƴ 250 W - 1.56 GW

0.25 W-0.9

0.90-1.00

±(4%+4)

±0.04

±0.03

Harmonics Volts

Amps

Watts

K-factor

1 st to 51 st harmonic

1 st to 51 st

1.0 to 30.0

±(3%+2) to ±(15%+5)

±(3%+8) to ±(15%+5)

±(5%+2) to ±(30%+5)

±10%

Sags & Swells Voltage and Current 4 min-16 days selectable ±(2%+10)

Transient Capture 40 ns pulse width

Up to 40 transients Select 20/50/100/200%

above or below line voltage ± 5% of full scale

Inrush Current 1 sec. to 5 min selectable 1 A to 1000 A ± 5% of full scale

Ohms/Continuity/

Capacitance Ohms

Capacitance 500.0  to 30.00 M

50.00 nF to 500.0 µF ± (0.6%+5)

± (2%+10)

Temperature

(with accessory) ºC

ºF -100.0ºC to 400.0ºC

-200.0ºF to 800.0ºF ± (0.5%+5)

Scope DC, AC, AC+DC, peak,

peak-peak, Hz, duty cycle,

phase, pulse width,

crest factor

Sampling rate:

Bandwidth:

Voltage BW (Channel 1)

Current BW (Channel 2)

25 MS/sec

20 MHz

15 kHz

Screen saves All functions 20 screens

Recording V/A/Hz, Power, Harmonics,

Ω/Cap, Temperature, Scope 4 min - 16 days selectable Select any two parameters

display mode in each

The perfect tool for tracking down

single-phase power-related problems

• Voltage, current, and

power harmonics

• Up to 51st harmonic

• Total harmonic distortion

(THD)

• Phase angle of individual

harmonics

• Watts, power factor,

COS

ƴ, VA and VAR

• Voltage and current

waveforms

• Continuously measure

volts and amps on a

cycle-by-cycle basis for up

to 16 days

• Use cursors to read time

and date of sags and

swells

• Connect-and-View™

scope for quick waveform

display

• View voltage and current

channels simultaneously

riešenia na presné meranie

http://www.elso.sk

VR1710 Single-Phase Voltage

Quality Recorder

The Fluke VR1710 is a single-phase, plug-

in voltage quality recorder that provides

fast and easy recording of voltage trends,

dropouts, harmonics and general power

quality including dips and surges to help

maintenance and facilities management

personnel easily pinpoint the root cause

of voltage problems. Voltage quality

parameters including RMS average,

transients, icker, and harmonics up to

the 32nd are recorded using a user-

selected average period from

1 second to 20 minutes.

• Clear graphical summary of data and

quick overview of key power quality

parameters

• Get the complete picture with Min, Max,

Average RMS values (1/4 cycle) with

time stamps

• See the detailed with actual transient

display (> 100 µs) with time stamp

• Comprehensive analysis of Individual

harmonic and THD values with trends

Specifications

(Check the Fluke web for detailed specifications)

Display: LED

Size (HxWxD): 23 x 19.75 x 22.2 cm

Included Accessories

Plug-in Fluke VR1710, USB cable, PowerLog

software CD, universal power cord adapters.

Ordering Information

Fluke VR1710 Voltage Quality Recorder

Fluke VR1710

Includes PowerLog software

Fluke VR1710 and included accessories

PowerLog Setup – Simple set up of

internal clock, logging periods, and

intervals with default values for

quick results.

PowerLog View – Data presentation

showing RMS voltage and harmonic

trends, actual transients, summary

information and statistics in

accordance with EN50160.

Actual transient display

(> 100 μs) with time stamp–

Quickly identify issues with included

graphical software.

Statistical analysis of voltage event

– reduces analysis time by tracking

event quantities and magnitudes.

Applications

• Voltage recording – Monitors and

records supply voltage; measures RMS

average, minimum and maximum

values, and checks whether the socket

outlet is providing voltage within

tolerance.

• Distortion measurement – Measure

frequency and harmonics; check

whether the distorting loads (UPS

systems, drives, etc.) are affecting your

other equipment.

• Flicker measurement – Quantify the

affects of switching loads on lighting

systems.

• Voltage transients – Capture those

intermittent, momentary events that

may be affecting your equipment; the

full waveform is captured with date,

timestamp, and duration.

Weight: 0.8 kg

Two years warranty

Operating voltage 70 V to 300 V

Min/Max/Avg RMS value Resolution 0.125 V

Number of events 175,000

Dips/Interruptions Yes

Time resolution 5 ms

Voltage resolution) 0.125 V

Over-voltages Yes

Frequency Yes

Harmonics measurement EN 61000-4-7 (up to 32nd)

Flicker measurement EN 61000-4-15

Number of recording channels 1 Phase to Neutral

2 Phase/Neutral to Ground

Recording time 1 day to 339 days depending on average time from 1 second to 20 minutes

Transients Yes (> 100µs)

Frequency range 50 Hz ± 1 Hz and 60 Hz ± 1 Hz

Safety category rating CAT II 300 V

Easy-to-use solution for detecting and

recording voltage quality problems

riešenia na presné meranie

http://www.elso.sk

Compliant

Fluke

435 II / 437 II

430 Series II Three-Phase Power

Quality and Energy Analyzers

More detailed power quality analysis capability,

and a Fluke-patented energy monetization function

The new Fluke 434, 435 and 437 Series II models

help locate, predict, prevent, and troubleshoot

power quality problems in three-phase and single-

phase power distribution systems. Additionally,

the Fluke-patented energy loss algorithm, Unied

Power Measurement, measures and quanties

energy losses due to harmonics and unbalance

issues, allowing the user to pinpoint the origin of

energy waste within a system.

• Energy loss calculator: Classic active and reactive

power measurements, unbalance and harmonic

power, are quantied to pinpoint true system

energy losses in dollars.

• Power inverter efciency: Simultaneously

measure AC output power and DC input power

for power electronics systems using optional DC

clamp.

• PowerWave data capture: 435 and 437 Series II

analyzers capture fast RMS data, show half-cycle

and waveforms to characterize electrical system

dynamics (generator start-ups, UPS switching

etc.).

• Waveform capture: 435 and 437 Series II models

capture 100/120 cycles (50/60Hz) of each event

that is detected in all modes, without set-up.

• Automatic Transient Mode: 435 and 437 Series II

analyzers capture 200 kHz waveform data on all

phases simultaneously up to 6 kV.

• Fully Class-A compliant: 435 and 437 Series II

analyzer conduct tests according to the stringent

international IEC 61000-4-30 Class-A standard

with 435 and 437 Series II analyzers.

• 400 Hz measurement: 437 Series II analyzer

captures power quality measurements for avionic

and military power systems.

• Troubleshoot real-time: Analyze the trends using

the cursors and zoom tools.

• Highest safety rating in the industry: 600 V CAT IV/

1000 V CAT III rated for use at the service

entrance.

• Automatic Trending: Every measurement is

always automatically recorded, without any

set-up.

• System-Monitor: Ten power quality parameters

on one screen according to EN50160 power

quality standard

• Logger function: Congure for any test condition

with memory for up to 600 parameters at user

dened intervals.

Unified Power Measurement

Fluke’s patented Unied Power Measurement

system (UPM) provides the most comprehensive

view of power available, measuring:

• Parameters of Classical Power (Steinmetz 1897)

and IEEE 1459-2000 Power

• Detailed Loss Analysis

• Unbalance Analysis

• These UPM calculations are used to quantify in

dollars the cost of energy loss caused by power

quality issues.

Energy savings

The cost of power quality could only be

quantied in terms of downtime caused by lost

production and damage to electrical equipment.

The Unied Power Measurement (UPM) method

now goes beyond this to achieve energy savings

by discovering the energy waste caused by

power quality issues. Using the Unied Power

Measurement, Fluke’s Energy Loss Calculator will

determine how much money as facility is losing

due to waste energy.

Unbalance

UPM gives a more comprehensive breakdown of

the energy consumed in the plant. In addition

to measuring reactive power (caused by poor

power factor), UPM also measures the energy

waste caused by unbalance; the effect of unevenly

loading each phase in three-phase systems.

Harmonics

UPM also provides details of the energy wasted

in your facility due to the presence of harmonics.

The presence of harmonics in your facility can

lead to:

• Overheating transformers and conductors

• Nuisance tripping of circuit breakers

• Early failures of electrical equipment

Fluke 437-II

Fluke 435-II Fluke 434-II

True RMS

On all inputs

New

Track harmonics up to the 50th, and measure and record

THD in accordance with IEC61000-4-7 requirements.

The System-Monitor overview gives instant insight into

whether the voltage, harmonics, flicker, frequency and

the number of dips and swells fall outside the set limits.

A detailed list is given of all events falling outside the

set limits.

Phasor diagram.

riešenia na presné meranie

http://www.elso.sk

430 Series II Three-Phase Power

Quality and Energy Analyzers

Logging provides instantaneous analysis of user

selectable parameters.

Fluke 437 II with all standard accessories.

Included Accessories

TL430 test lead and alligator clip set,

i430ex-TF, 61 cm, 4 clamps,

BC430 power adapter,

BP290 single capacity Li-ion battery,

International plug adapter set,

WC100 color coding clips and regional decals,

8 GB SD card,

PowerLog on CD

USB cable A-Bmini

C1740 softcase (434-II, 435-II),

C437 hard case (437-II)

Ordering information

Fluke 434-II Three-Phase Energy Analyzer

Fluke 435-II Three-Phase Power Quality

and Energy Analyzer

Fluke 437-II Three-Phase Power Quality

and Energy Analyzer

Battery life: 7 hours operating time per charge on Li-ion battery pack

Safety: EN61010-1 (2nd edition) pollution degree 2; 1000 V CAT III / 600 V CAT IV

Case: Rugged, shock proof with integrated protective holster, IP51 (drip and dust proof)

Shock: 30 g; Vibration: 3g according to MIL-PRF-28800F Class 2

Operating temperature: 0°C to +50°C

Size (HxWxD): 265 mm x 190 mm x 70 mm; Weight: 2.1 kg

Three Years Warranty

BP291

See page 86

Recommended Accessories

i5sPQ3

See page 98

i430-FLEXI-TF-4PK

See page 98

See page 98 for power quality current clamps

Voltage inputs

Number of inputs 4 (3 phase + neutral) dc-coupled

Maximum input voltage 1000 Vrms

Nominal voltage range Selectable 1 V to 1000 V

Max. peak measurement voltage 6 kV (transient mode only)

Input impedance 4 M//5 pF

Bandwidth > 10 kHz, up to 100 kHz for transient mode

Scaling 1:1, 10:1, 100:1, 1,000:1 10,000:1 and variable

Current inputs

Number of inputs 4 (3 phase + neutral) dc- or ac-coupled

Type Clamp or current transformer with mV output or i430flex-TF

Range 0.5 Arms to 600 Arms with included i430flex-TF (with sensitivity 10x)

5 Arms to 6000 Arms with included i430flex-TF (with sensitivity 1x)

0.1 mV/A to 1 V/A and custom for use with optional ac or dc clamps

Input impedance 1 M

Bandwidth > 10 kHz

Scaling 1:1, 10:1, 100:1, 1,000:1 10,000:1 and variable

Measurement modes

Scope 4 voltage waveforms, 4 current waveforms, Vrms, Vfund. Arms, A fund, V @ cursor,

A @ cursor, phase angles

Volts/amps/hertz

Vrms phase to phase, Vrms phase to neutral, Vpeak, V Crest Factor, Arms Apeak, A Crest Factor, Hz

Dips and swells Vrms½, Arms½, Pinst with programmable threshold levels for event detection

Harmonics dc, 1 to 50, up to 9th harmonic

for 400 Hz

Harmonics Volts, THD, Harmonic Amps, K factor Amps, Harmonic Watts, THd Watts, K factor

Watts, Interharmonic Volts, Interharmonic Amps, Vrms, Arms (relative to fundamental or to

total rms)

Power and energy Vrms, Arms, Wfull, Wfund., VAfull, VAfund., VAharmonics, VAunbalance, var, PF, DPF, CosQ,

Efficiency factor, Wforward, Wreverse

Energy loss calculator Wfund, VAharmonics, VAunbalance, var, A, Loss Active, Loss Reactive, Loss Harmonics, Loss

Unbalance, Loss Neutral, Loss Cost (based upon user defined cost / kWh)

Inverter efficiency

(requires optional dc current clamp)

Wfull, Wfund, Wdc, Efficiency, Vdc, Adc, Vrms, Arms, Hz

Unbalance Vneg%, Vzero%, Aneg%, Azero%, Vfund, Afund, V phase angles, A phase angles

Inrush Inrush current, Inrush duration, Arms½, Vrms½

Monitor Vrms, Arms, harmonic Volts, THD Volts, PLT, Vrms½, Arms½, Hz, dips, swells, interruptions, rapid

voltage changes, unbalance and mains signalling. All parameters are measured simultaneously

in accordance with EN50160 Flagging is applied according to IEC61000-4-30 to indicate unreliable

readings due to dips or swells

Flicker (435-II and 437-II only) Pst(1min), Pst, Plt, Pinst, Vrms ½, Arms ½, Hz

Transients (435-II and 437-II only) Transient waveforms 4x Voltage 4x Amps, triggers: Vrms ½, Arms ½, Pinst

Mains Signaling

(435-II and 437-II only)

Relative signaling voltage and absolute signaling voltage averaged over three seconds for up to two

selectable signaling frequencies

UPower Wave

(435-II and 437-II only)

Vrms½, Arms½ W, Hz and scope waveforms for voltage amps and watts

Logger Custom selection of up to 150 PQ parameters measured simultaneously on 4 phases

Input characteristics

Energy Loss Calculator

Useful kilowatts (power) available

Kilowatts made unusable by harmonics

Kilowatts made unusable by unbalance issues

Total billable kilowatt hours wasted

Total cost of wasted kilowatt hours

riešenia na presné meranie

http://www.elso.sk

1735 Power Logger

Included Accessories

FS17X5-TF 4-phase flexible current clamp

set, VL1735/1745 voltage lead set, Power Log

software, color localization set, PC interface

cable, international ac adapter, BC1735 battery

charger, soft carrying case, printed English

manual and multi-language manual on CD.

Ordering Information

Fluke 1735 Power Logger

FS17X5-TF 4-phase thin flexi current

clamp set, 3000 A

3000/6000A-TF-4 4-phase thin flexi current

clamp set, 6000 A

The Fluke 1735 Power Logger is the ideal

tool for electricians and maintenance

technicians for conducting energy

studies and basic power quality logging.

The 1735 is easy to set up with its color

display and four included new thinner

exible current probes.

The 1735 logs most electrical power

parameters, harmonics and captures

voltage events. View graphs and generate

reports with the included Fluke Power

Log software.

• Record power and associated

parameters for up to 45 days

• Monitor maximum power demand over

user-dened averaging periods

• Prove the benet of efciency

improvements with energy

consumption tests

• Measure harmonic distortion caused by

electronic loads

• Improve reliability by capturing voltage

dips and swells from load switching

• Conrm instrument setup easily with

color display of waveforms and trends

Specifications

Display: VGA Graphic Color transmissive displays

320 x 240 pixels with additional background lighting

and adjustable contrast, text and graphics in color

Interface: USB with Mini USB B socket. Firmware

updates are possible with the USB interface

Housing: IP65; EN60529 (refers only to the main

housing without the battery compartment)

Power supply: NiMH battery-pack, with AC adapter

(15 V to 20 V/0.8 A)

Battery Life: Typical > 16 hours without backlight and

> 6 hours with backlight high

Operating temperature: 0°C to +40°C

Size (HxWxD): 240 mm x 180 mm x 110 mm

Weight: 1.7 kg, including battery

Two Year Warranty

(Check the Fluke web for detailed specifications)

Recommended Accessories

See page 98 for power quality current clamps

Volts rms V-rms wye measurement ranges:

57 V/66 V/110 V/120 V/127 V/220 V/230 V/240 V/260 V/277 V/347 V/380 V/

400 V/417 V/480 V AC

V-rms delta measurement ranges:

100 V/115 V/190 V/208 V/220 V/380 V/400 V/415 V/450 V/480 V/600 V/660 V/

690 V/720 V/830 V AC

Amps rms Flexi set measurement range: 15 A/150 A/3000 A rms (at sine)

Current clamp measurement range: 1 A/10 A

Frequency Measurement range: 46 Hz to 54 Hz and 56 Hz to 64 Hz

Harmonics and THD To 50th harmonic (< 50 % of nom)

Power measurement

(P - Active, S - Apparent, Q - Reactive, D - Distorting) Measuring range: see V-rms and A-rms measurement ranges

Energy Measurement (kWh, KVAh, kVARh) Measuring range: see V-rms and A-rms measurement rangeso

PF (Power factor) 0.000 to 1.000

Events Detection of voltage dips, voltage swells and voltage interruptions with a

10 ms resolution and measuring error of the half period sine wave of rms.

General

Memory 4 MB Flash memory, 3.5 MB for measuring data

Sample rate 10.24 kHz

Line frequency 50 Hz or 60 Hz, user-selectable, with automatic synchronization

Customize the report generator to easily

generate professional looking reports.

Performs electrical load studies, energy

consumption testing, and general power

quality logging

Conduct load studies

for up to 45 days and

view saved data

on-screen or on a

computer.

Quantify energy

consumption quickly

on-screen or log to

memory for extended

periods.

Access voltage and

current harmonics

up to the 50th.

Capture voltage events

using user-defined

thresholds.

Fluke 1735

View recorded data in simple graphs and

tables with Fluke Power Log software.

riešenia na presné meranie

http://www.elso.sk

1740 Series Three-Phase

Power Quality Loggers Memobox

Included Accessories

Fluke 1743/1744/1745: FS17XX IP65-TF thin

exible current clamp set (1743 & 1744),

FS17X5-TF thin exible current clamp set

(1745), VL1735/1745 voltage lead set (1745

only), Power Log software, RS232 interface

cable and RS232-USB adapter, 4 black dolphin

clips, WC17XX color localization set, carrying

bag, test certicate with measurement values,

printed English manual and multi-language

manual on CD.

Basic models: Excl. current clamps FS17XX-TF

Ordering Information

Fluke 1743 Basic Power Quality Logger

Memobox

Fluke 1743 Power Quality Logger

Memobox

Fluke 1744 Basic Power Quality Logger

Memobox

Fluke 1744 Power Quality Logger

Memobox

Fluke 1745 Power Quality Logger

Memobox

FS17x5-TF 4-phase thin exi current

clamp set, 3000 A

3000/6000A-TF-4 4-phase thin exi current

clamp set, 6000 A

Compact, rugged and reliable, the Fluke

1740 Series three-phase power quality

loggers are everyday instruments for

technicians who troubleshoot and

analyze power distribution systems.

Capable of simultaneously logging up

to 500 parameters for up to 85 days and

capturing events, the Fluke 1740 Series

helps uncover intermittent and hard-to-

nd power quality issues. There are three

models to choose from to meet your

basic or advanced power logging needs.

Fluke 1743: IP65 waterproof monitor

for logging the most common power

parameters including V, A, W, VA, VAR, PF,

energy, icker, voltage events and THD.

Fluke 1744: Includes the same features

as the Fluke 1743. In addition to common

power parameters, the Fluke 1744 also

measures voltage and current harmonics,

interharmonics, mains signaling,

unbalance, and frequency.

Fluke 1745: Advanced IP50 power quality

logger with the same measurement

capability as the 1744, plus real-time LCD,

ve hour UPS.

• Plug and play: Set up in minutes with

automatic current probe detection and

powering

• Installs inside the cabinet: Compact,

fully-insulated housing and accessories

t easily in tight spaces next to live

power

• Monitors power for the long-term:

Data can be downloaded during

recording without interruption

• Measure voltage with premium

accuracy: IEC61000-4-30 Class-A

compliant voltage accuracy (0.1%)

• Quickly validate quality of power:

Assess power quality according to

EN50160 power quality standard with

statistical overview

Speciﬁcations

Fluke 1743

1745 1744 1743

Measurement of common power parameters: V, A, W,

VA, VAR, PF, energy, flicker, voltage events (dips, swells,

interruptions), and THD

OOO

Measurement of voltage and current harmonics to the

50th, unbalance, frequency and mains signaling

Dust/water resistance IP 50 IP 65 waterproof

Display LED + LCD LED LED

Memory 8 MB 8 MB 8 MB

UPS ride-through > 5 hrs 3s 3s

EN 50160

OOO

(Check the Fluke web for detailed speciﬁcations)

See page 98 for power quality current clamps

Fluke 1745

The included PQ Log software helps you

to quickly identify the root cause of a

disturbance.

Power supply: 88 V … 660 V AC

Safety: IEC/EN 61010-1 600 V CAT III, 300 V

CAT IV, pollution degree 2, double insulation

Housing: Fully insulated housing and accessories

Operating temperature: 0 °C to 35°C

Interface: RS 232, 9600 ... 115 000 Baud, automatic

Baud rate selection, 3-wire communication

Size: Fluke 1745: 282 mm x 216 mm x 74 mm;

Fluke 1743/44: 170 mm x 125 mm x 55 mm

Weight: Fluke 1745 – approx. 3 kg;

Fluke 1743/44: approx. 2 kg

Two Year Warranty

Fluke 1744

Assess power quality and conduct long-term

studies with ease

riešenia na presné meranie

http://www.elso.sk

1750 Three-Phase Power

Recorder

Included Accessories

PDA and charger power plug adapters,

4 current probes, 5 test leads and clips, SD

memory card., Fluke Power View and Fluke

Power Analyze software, power cord with

international plug set, Ethernet cable, color

localization set, soft carrying case, Printed

Getting Started manual, CD with software and

users manual PDF

Basic model: excl. 4 current probes

Ordering Information

Fluke 1750/B Three-Phase Basic Power

Recorder

Fluke 1750

Three-Phase Power Recorder

With its exclusive threshold-free

measurement system, the Fluke

1750 Power Recorder captures every

measurement, every event, on every cycle,

all the time. Outstanding accuracy and

resolution provide complete visibility into

your installation or distribution system.

• Power quality that meets the standard:

All measurements comply with

IEC61000-4-30 standards for correct

evaluation of all measured values

including voltage, current, power,

harmonics, icker etc.

• Quick and reliable conguration: PDA

wireless “front panel interface” provides

the ability to verify setup without a

laptop along with a window into what

the instrument is recording, even in

awkward test locations.

• Threshold-free setup: Apply thresholds

after data is collected with Fluke Power

Analyzer Software so there is no need to

worry about missed information due to

incorrect set-up.

• Captures everything: Cross-channel

and current triggering capture every

measurement, on every channel, every

time.

• Intuitive PC software: Easily analyze

data and generate reports. Automated

EN50160 reporting and compliance.

• Plug and play: Set up in minutes with

seldentifying current probes and

single-lead voltage connections.

• No need to reconnect wires: Swap

channels internally with the wireless

PDA or PC when connections are not

correct.

• Measure every parameter: Voltage and

current on three phases, neutral, and

ground.

• 5 MHz, 8000 Vpk waveform capture:

Get a detailed picture of even the

shortest events.

• Quickly retrieve data: With included SD

memory card or via the 100BaseT high-

speed Ethernetv connection

Specifications

(Check the Fluke web for detailed specifications)

View measurements real time with wireless PDA interface

Safety: EN 61010-1 2nd Edition; 2000

Weight: 6.3 kg

Size (H x W x D): 215 x 310 x 35 mm

One Year Warranty

Power quality measurement standards

Conformance IEC 61999-1-4 Class 1, IEC 61000-4-30, IEEE519, IEEE1159, IEEE1459 and EN50160

Clock/calendar Leap years, 24-hour clock

Real-time clock accuracy Not more than ± 1 s/day

Internal memory capacity for data At least 1 GB

Maximum recording period At least 31 days

Measurement time control Automatic

Maximum number of events Limited only by the size of the internal memory

Power requirements 100 to 240 V rms ± 10 %, 47-63 Hz, 40 W

Operating time during interruptions (internal UPS operation) 5 minutes per interruption, 60 minutes total operating time without recharging

Recommended Accessories

Model Description

3210-PR-TF 1000A Thin flexible current transformer 61 cm (24") (20 A - 1000 A)

3310-PR-TF 5000A Thin flexible current transformer 61 cm (24") (100 A - 5000 A)

3312-PR-TF 5000A Thin flexible current transformer 122 cm (48") (100 A - 5000 A)

3140-PR Clamp-on current transformer (2 A - 400 A)

i40S-PR Clamp-on current transformer (0,1 A - 40 A)

i4S-PR Clamp-on current transformer (0,01 A - 5 A)

FLUKE-1750/SEAT-L Fluke Power Analyze – Additional SEAT LICENSE

FLUKE-1750/SITE-L Fluke Power Analyze – Additional SITE LICENSE

FLUKE-1750/CASE Hard Case

CS1750 Soft Case

HP IPAQ 2490 Additional Wireless Interface PDA

FLUKE-1750/MC Additional 512 MB SD Memory Card

Never miss capturing a disturbance

On all inputs

riešenia na presné meranie

http://www.elso.sk

1760 Three-Phase Power

Quality Recorder Topas

Included Accessories

4 x TPS Flex 24-TF flexible current probe, 4 x TPS

VoltProbe 600V, 2 GB internal flash memory, ST1760

standard Ethernet cable, RS232 interface cable and

RS232-USB adapter, CS1760 crossover Ethernet cable,

1 mains cable, PC software on CD-ROM, WC17xx

color localization set, GPS-time sync (1760TR only)

CS 1750/1760 carrying bag, hardware and software

manual

Basic models: Excl. current clamps TPS Flex 24-TF

Ordering Information

Fluke 1760 Basic Power Quality Recorder Topas

Fluke 1760TR Basic Power Quality Recorder Topas

Fluke 1760 Power Quality Recorder Topas

Fluke 1760TR Power Quality Recorder Topas

The Fluke 1760 Three-Phase Power

Quality Recorder is fully compliant to

IEC 61000-4-30 Class-A, for advanced

power quality analysis and consistent

compliance testing. Designed for analysis

of utility and industrial power distribution

systems, in medium and low-voltage

networks, the Fluke 1760 provides the

exibility to customize thresholds,

algorithms, and measurement selections.

It has 8 input channels (4 currents/4

voltages or 8 voltages), and captures the

most comprehensive details on user

selectable parameters.

• GPS time synchronization: Correlate

data with events or datasets from other

instruments with precision

• Uninterrupted power supply

(40 minutes): Never miss important

events - even record the beginning and

end of interruptions and outages

• 10 MHz, 6000 Vpk waveform capture:

Get a detailed picture of even the

shortest event

• 2 GB data memory: Enables detailed,

simultaneous recording of numerous

power parameters for long periods of

time

• Includes Comprehensive software:

Provides trend diagrams for root cause

analysis, statistical summaries, report

writing and real-time data monitoring

in the online mode

Features

Fluke 1760

(Check the Fluke web for detailed specifications)

The included PQ Analyze software

provides a detailed overview of several

power quality parameters on one

dashboard according to the EN50160

power quality standard. Power supply: 83 V to 264 V, 45 to 65 Hz

Battery pack: NIMH, 7.2 V, 2.7 Ah (up to 40 minutes

back-up power supply)

Safety: 600V CAT IV/1000V CAT III

(Rated for use at the service entrance)

Housing: Fully insulated robust plastic housing

Operating temperature: 0 °C to 35°C

Interfaces: Ethernet (100 MB/s), RS-232, external

modem via RS-232

Size (HxWxD): 325 mm x 300 mm x 65 mm

Weight: Approxiamtely 4.9 kg

Two Year Warranty

1760 Basic 1760TR Basic 1760 1760TR

Power quality statistics according to EN50160

OOOO

Voltage event list (dips, swells and interruptions)

OOOO

Continuous recording of:

Voltage

OOOO

Current

OOOO

Power P, Q, S

OOOO

Power factor

OOOO

kWh

OOOO

Flicker

OOOO

Unbalance

OOOO

Frequency

OOOO

Voltage and current harmonics to the 50th/

Interharmonics

OOOO

THD

OOOO

Mains signaling

OOOO

Triggered recordings

OOOO

Online mode (Oscilloscope, transients and events)

OOOO

Fast transient analysis up to 10 MHz

4 voltage probes

4 dual-range flexible current probes (1000 A / 200 A ac)

GPS time sync receiver

Memory 2 GB Flash memory

Recommended Accessories

(Check the Fluke web for complete accessory list)

Model Description

• TPS VOLTPROBE 10 V 10 V Voltage Probes (Range: 0.1 V to 17 V)

• TPS VOLTPROBE 100 V 100 V Voltage Probes (Range: 1 V to 170 V)

• TPS VOLTPROBE 400 V 400 V Voltage Probes (Range: 4 V to 680 V)

• TPS VOLTPROBE 600 V 600 V Voltage Probes (Range: 10 V to 1000 V)

• TPS VOLTPROBE 1 KV 1000 V Voltage Probes (Range: 10 V to 1700 V)

• TPS FLEX 18-TF Flexible Current Probe (Range: 1 A to 100 A / 5 A to 500 A)

• TPS FLEX 24-TF Flexible Current Probe (Range: 2 A to 200 A / 10 A to 1000 A)

• TPS FLEX 36-TF Flexible Current Probe (Range: 30 A to 3000 A / 60 A to 6000 A)

• TPS CLAMP 10 A / 1 A Clip-on Current Transformer (Range: 0.01 A to 1 A / 0.1 A to 10 A)

• TPS CLAMP 50 A / 5A Clip-on Current Transformer (Range: 0.05 A to 5 A / 0.5 A to 50 A)

• TPS CLAMP 200 A / 20 A Clip-on Current Transformer (Range: 0.2 A to 20 A / 2 A to 200 A)

• TPS SHUNT 20 MA 20 mA ac/dc Shunt (Range: 0 to 55 mA)

• TPS SHUNT 5 A 5 A ac/dc Shunt (Range: 0 to 10 A)

Class-A compliance for the most demanding

power quality tests

riešenia na presné meranie

http://www.elso.sk

i3000 flex-4PK

(4x i3000s flex24)

i400s i430-FLEXI-TF-4PK i5sPQ3

Power Quality Current Clamps

Fluke model number i1A/10A

CLAMP PQ3

i1A/10A

CLAMP PQ4

i5A/50A

CLAMP PQ3

i5A/50A

CLAMP PQ4

i20A/200A

CLAMP PQ3

i20A/200A

CLAMP PQ4

3000/6000A-TF-4 FS17X5-TF FS17xx IP65-TF i3000 flex ... 4PK i400s

i430-FLEXI-TF-4PK

i5sPQ3

Description 3 ... phase

1A/10A Mini

current

clamp set

4 ... phase

1A/10A Mini

current

clamp set

3 ... phase

5A/50A Mini

current

clamp set

4 ... phase

5A/50A Mini

current

clamp set

3 ... phase

20A/200A

Mini current

clamp set

4 ... phase

20A/2000A

Mini current

clamp set

4 Phase

flexiset 4 Phase

flexiset,

IP41

4 Phase

flexiset,

IP65

4 ... phase

3000A

Flexible

current

clamp set

Single phase

400A current

clamp

(4 required)

4 ... phase

3000A

Flexible

current

clamp set

3 ... phase 5A

Current

clamp

set

Old Fluke model # CURRENT

CLAMPS 1A

(EPO450A)

MBX CLAMP

1A/10A+N

(EPO451A)

MBX CLAMP

5A/50A

(EPO452A)

MBX CLAMP

5A/50A+N

(EPO453A)

MBX CLAMP

20A/200A

(EPO455A)

MBX CLAMP

20/2000A+N

(EPO456A)

MBX

Lem Flex

(15/150/3000)

(EP0404A)

MBX

Lem Flex

(15/150/3000)

(EP0404A)

Fluke 1735

OOOOOOOOO

Fluke 174X

OOOOOOOOO

Fluke 43X

OOOO

Nominal current range(s) 1 A

10 A AC 1 A

10 A AC 5 A

50 A AC 5 A

50 A AC 20 A

200 A AC 20 A

200 A AC 30A 300A

3000A 6000A

15A 150A

1500A 3000A

15A 150A

1500A 3000A

30 A

300 A

3000 A

40 A

400 A 3000 A 5 A

Cont. AC current range 10 mA ... 1 A

100 mA ...

10 A

10 mA ... 1 A

100 mA ...

10 A

50 mA ... 5 A

500 mA ...

50 A

50 mA ... 5A

500 mA ...

50 A

200 mA ...

20 A

2 A ... 200 A

200 mA ...

20 A

2 A ... 200 A

0.8 ... 6.000 A

AC 450mA …

15A 600mA…

150A 6A…

1500A 12A…

3000A

450mA …

15A 600mA…

150A 6A…

1500A 12A…

3000A

1 A ... 30 A

1 A ... 300 A

1 A ... 2400 A

0.5 A ... 40 A

5 A ... 400 A 30 A ...

3000 A 0.01 A ... 6 A

Highest current 20 A 20 A 100 A 100 A 300 A 300 A 0.8 A 3300 A 3300 A 4000 A 1000 A 100 kA 70 A

Lowest measurable current 10 mA 10 mA 50 mA 50 mA 200 mA 200 mA 450 mA 450 mA 1 A 0.5 A 30 A 10 mA

Basic accuracy (48 ... 65 Hz) 1) 0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 2%+2% position

influence 2%+2% position

influence 2% + 2 A 2% + 0.15 A 1% 1%

Usable frequency 40 Hz ... 10

kHz 40 Hz ... 10

kHz 40Hz …5kHz 40Hz …5kHz 10 Hz ... 100

kHz 45 Hz ... 3

kHz 10 Hz ... 7

kHz 40 Hz ... 5

kHz

Requires battery

Flex head length 92 cm 61 cm 61 cm Clamp

opening:

32 mm

61 cm Clamp

opening:

15 mm

Output level(s) 75 mV/A 75 mV/A 15 mV/A 15 mV/A 3.75 mV/A 3.75 mV/A 0.1 mV/A 0.1 mV/A 10 mV/A

1 mV/A

0.1 mV/A

10 mV/A

1 mV/A 0.085 mV/A

@50 Hz 400 mV/A

Output cable (m) 2 222224222.12.52.52.5

Safety rating CAT III 600 V CAT III 600 V CAT III 600 V CAT III 600 V CAT III 600 V CAT III 600 V CAT III 1000 V

CAT IV 600V CAT III 1000 V

CAT IV 600V CAT III 600 V CAT III 1000 V

CAT IV 600 V CAT III 1000 V

CAT IV 600 V CAT III 600 V

Connection One

connector One

connector 4 x BNC 4 x BNC 4 x BNC 3 x BNC

BNC to banana adapters included n/a n/a n/a n/a n/a n/a n/a n/a n/a

1 Basic accuracy: % reading plus floorspec.

n/a = not applicable

riešenia na presné meranie

http://www.elso.sk

Norma 4000/5000

Power Analyzers

The compact Fluke Norma Series

Power Analyzers provide the latest

measurement technology to assist

engineers with the development and

testing of motors, inverters, lighting,

power supplies, transformers and

automotive components.

Based on a patented, high-bandwidth

architecture, the instruments deliver

high-precision measurements of single

or three-phase current and voltage,

harmonics analysis, Fast Fourier

Transformation (FFT) analysis, as well as

calculations of power and other derived

values.

A unique user-congurable system

design with plug-in power phases and

other optional modules provides the

exibility to meet a variety of application

measurement requirements. Recorded

data and waveforms can be viewed

clearly in the large color display and

easily downloaded to a PC for analysis

and report writing.

The Series consists of the Fluke Norma

4000 Three-Phase Power Analyzer and

the Fluke Norma 5000 Six-Phase Power

Analyzer. These rugged analyzers provide

unmatched price performance for easy

and reliable use in the eld, or as a bench

unit in laboratories and on test benches.

• Simple user interface ensures easy,

intuitive operation

• Unique user-congurable modular

design

• Simultaneous parallel acquisition of all

phases

• Voltage, current and power harmonics

up to the 40th

• Includes FFT analysis, vector diagram

display, recorder function, and Digital

Oscilloscope (DSO) mode

• User selectable average time – from

15ms to 3600s

• Expandable on-board memory for

storage of measured values

Specifications

(Check the Fluke web for detailed specifications)

Operating temperature:

+ 5 °C to 35 °C

Storage temperature:

- 20 °C to 50 °C

Climatic class: KYG DIN 40040, maximum

85% relative humidity, non-condensing.

Included Accessories

Power Supply Cable, RS232 Interface and USB

adaptor for Data Download, Fluke NormaView

PC Software, User’s Manual, Test Certificate,

and Calibration Values.

Ordering Information

Fluke Norma 4000 Three-Phase High

Precision Power Analyzer

Fluke Norma 5000 Six-Phase High Precision

Power Analyzer

Fluke Norma Series Power Analyzers

Fast Fourier

Transformation (FFT)

analysis

Fluke Norma 4000

Housing: Solid metal case

Safety: EN 61010-1 / 2nd Edition, 1000 V CAT II

(600 V CAT III)

Two Year Warranty

Fluke Norma 4000 Fluke Norma 5000

Number of Phases 1 or 3 3, 4 or 6

Weight Approx. 5 kg Approx. 7 kg

Size (HxWxD) 15 cm x 23.7 cm x 31.5 cm 15 cm x 44.7 cm x 31.5 cm

On-board Printer No Yes (optional)

Display Color, 5.7“ / 144 mm - 320 x 240 pixel

Bandwidth dc to 3 MHz or dc to 10MHz depending on input module

Basic Accuracy 0.2%, 0.1% or 0.03% depending on input modules

Sampling Rate 0.33 MHz or 1 MHz depending on input modules

Voltage Input Range 0.3 V to 1000 V

Current Input Range (direct, not via shunt) 0.03 mA – 20 A depending on input module

Memory for Configurations 4 MB, expandable to 128 MB

Memory for Settings 0.5 MB

Fast Fourier Transformation (FFT) To the 40th harmonic

RS232 Interface Standard

PI1 Process Interface (8 analog/impulse inputs and

4 analog outputs) Optional

IEEE 488.2 /GPIB Interface (1 MBit/s Ethernet /

10 MBit/s or 100 Mbit/s) Optional

Fluke NormaView PC Software (for data download,

analysis & report writing) Standard

Fluke Norma 5000

Digital Oscilloscop

(DSO) mode

Vector Display Recorder function

Reliable, highly accurate measurements for

the test & development of power electronics

riešenia na presné meranie

http://www.elso.sk

100

Norma 4000/5000

Power Analyzer Accessories

Fluke Norma 4000 (rear view)

Fluke Norma 5000 (rear view)

3024770 3024812 3024820 3024835

Channel PP42 PP50 PP54 PP64

Accuracy 0.2%

(0.1% rd + 0.1% rg) 0.1%

0.05% rd + 0.05% rg 0.03%

(0.02% rg + 0.01% rg)

Current range 20 A 10 A 10 A 10 A

Sampling rate 341 kHz 1 MHz 341 kHz 341 kHz

Bandwidth 3 MHz 10 MHz 3 MHz 3 MHz

Shunts

The input modules can take up to 10 A

or 20 A directly or measure current via

wideband precision shunts. The available

range of shunts enables measurements up

to 1500 A and can be used in conjunction

with all of the available input modules.

Cables & Adaptors

Printer Accessories

3024677 32 A Planar Shunt

3024689 Cables for 32 A Planar Shunt

3024886 10 A Triaxial Shunt with Cables

(0.333 ., 0 to 0.5 MHz)

3024899 30 A Triaxial Shunt with Cables

(0.010 ., 0 to 0.5 MHz)

3024847 100 A Shunt with Cables (0.001 Ω, 0 to 0.5 MHz)

3024858 150 A Shunt with Cables (0.5 mΩ, 0 to 0.5 MHz)

3024864 300 A Shunt with Cables (0.1 mΩ, 0 to 1 MHz)

3024873 500 A Shunt with Cables (0.1 mΩ, 0 to 0.2 MHz)

3024692 LG Shunt Cables for High Current Shunts

3024661 Measurement Cable Set (for one power phase)

3024704 Fluke Norma WYE Adaptor (external accessory

box)

3024650 Printer Cable for Fluke Norma 5000

(RS232-Centronics)

All accessories have a

two-year warranty.

Optional shunts for Fluke Norma Series Power

Analyzers

32 A Planar Shunt

Power Phases

The Fluke Norma 4000 Power Analyzer

can be equipped with up to three power

phases and the Fluke Norma 5000 Power

Analyzer can be equipped with up to six

power phases. Users can select the power

phase best suited for their application.

Specications vary depending on the model

of the power phase.

Each plug-in power phase consists of

a voltage and a current measurement

channel. Each measuring channel is

available for each basic unit.

Power Phase Overview

riešenia na presné meranie

http://www.elso.sk

101

Fluke process calibration tools include a full range of calibrators and

troubleshooting tools for instrument technicians working in the process

industries. The range of process calibrators include: Documenting

Process Calibrators, Multifunction Process Calibrators, single function

and multifunction temperature calibrators, a variety of mA loop

calibrators and a range of intrinsically safe products.

Field Calibrators

riešenia na presné meranie

http://www.elso.sk

102

Field Calibrator

Selection Guide

1 Fluke 700 pressure modules required

2 Ranges for the internal sensor.

Ranges for use of Fluke 700 pressure modules, see page 108.

Documenting Process

Calibators

Multifunction Process

Calibrator Temperature Calibrators Pressure Calibrators Loop Calibrators ProcessMeters

Model 754 753 725/725Ex 726 724 714 712 718/718Ex 717 719 715 707/707Ex 771 772 773 705 789 787

Measure

Voltage DC 300 V 300 V 30 V 30V 30 V 75 mV 10 V 28 V 30 V 28 V 1000 V 1000 V

Voltage AC (true RMS) 300 V 300 V 1000 V 1000 V

Resistance 10 kΩ 10 kΩ 3200 Ω 4000 Ω 3200 Ω 3200 Ω 40 MΩ 40 M

Current DC 110 mA 110 mA 24 mA 24 mA 24 mA 24 mA 24 mA 24 mA 24 mA 24 mA 100 mA 100 mA 100 mA 24 mA 30 mA,

1 A 30 mA, 1A

Current AC

O O

Frequency 50 kHz 50 kHz 10 kHz 15 kHz 20 kHz 20 kHz

Pressure

168,9 mbar

to 20 bar /

2 to 7 bar2

68,9 mbar

to 345 bar2

2 bar to

7 bar2

Temperature: RTD types 88787 7

Temperature: TC types 13 13 12 12 12 9

Source/Simulate

Voltage DC 15 V 15 V 10 V 20 V 10 V 75 mV 10 V 10 V

Resistance 10 kΩ 10 kΩ 3200 Ω 4000 Ω 3200 Ω 3200 Ω

mA DC/% scale 22 mA 22 mA 24 mA 24 mA

24 mA 24 mA 24 mA 24 mA 24 mA 24 mA 24 mA

mA source; auto step, auto ramp

OOOO OO OOOOO

Frequency 50 kHz 50 kHz 10 kHz 15 kHz

Temperature: RTD types 88787 7

Temperature: TC types 13 13 10 10 10 9

Record

Min/Max

OOO OO

Hold

OOO OOO OO

As Found/As Left results

Log data

Upload data to PC

OO O

Remote operation

Features

Loop supply 26 V 26 V 24 V/12 V 24 V 24 V 24 V/- 24 V 24 V 24 V 24 V 24 V 24 V 24 V 24 V

Hart communication

Integrated hand pressure pump

Electric Pump

Intrinsically safe (ATEX) 725Ex 718Ex 707Ex

NIST traceable certification

OOOOOOOOOOOO O

Warranty in years 333333333333333333

See catalog page 103 103 104 104 105 106 106 108 108 108 109 109 110 110 110 109 111 111

riešenia na presné meranie

http://www.elso.sk

103

750 Series Documenting

Process Calibrators

700P27

See page 112

Recommended Accessories

Included Accessories

Stackable test leads (3 sets), TP220 test probes

(3 sets) with extended tooth” alligator clips

(3 sets), AC280 hook clips (2 sets), BP7240

Li-ion battery pack, BC7240 battery charger,

C799 field soft case, USB communication

cable, getting started guide, instruction

manual on CDROM, NIST traceable certificate

of calibration, DPCTrack™ 2 sample

software that enables upload and printing

of calibration

records. HART communication

cable (754 only).

Ordering Information

Fluke 753 Documenting Process Calibrator

Fluke 754 Documenting Process Calibrator

700 TLK Process test lead kit

BP7240 753/754 Spare battery

750 SW DPC/Track2

BC7240 753/754 Battery charger/eliminator

754HCC 754 HART communication cable

80PK-25

See page 128

80PK-8

See page 128

TL220-1

See page 122

C799

See page 130

Function Measure Sourcing

Voltage DC 0.02% + 0.005 mV 0.01% + 0.005 mV

Current DC 0.01% + 5 µA 0.01% + 0.003 mA

Resistance 0.05% reading + 50 m 0.01% output + 10 m

Frequency 0.05 Hz 0.01 Hz

Thermocouples 0.3ºC 0.2ºC

RTDs 0.07 ºC 0.06 ºC

Pressure To 0.05% of full scale. See Pressure Module specifications.

Specifications

(Check the Fluke web for detailed specifications)

Operating temperature: -10º C to 50º C

Storage temperature: -20º C to 60º C

Safety: CAT II 300V

Battery Life: Typically over eight hours

Internal Battery Pack: li-ion, 7.2V, 4400 mAh,

30 Wh

Fluke 754

Fluke 753

Battery Replacement: Via snap-shut door wit-

hout opening calibrator; no tools required

Weight: 1.2 kg

Size (HxWxD): 245 mm x 136 mm x 63 mm

Three Year Warranty

Whether you’re calibrating instruments,

troubleshooting a problem or running

routine maintenance, Fluke 750 series

process calibrators can help you get the

job done faster. It does so many different

tasks, so quickly and so well, it’s the only

process calibrator you need to carry.

• Measure volts, mA, RTDs,

thermocouples, frequency, and ohms

to test sensors, transmitters and other

instruments

• Source/simulate volts, mA,

thermocouples , RTDs, frequency, ohms,

and pressure to calibrate transmitters

• Power transmitters during test using

loop supply with simultaneous mA

measurement

• Measure/source pressure using any of

29 Fluke pressure modules

• Measure and source simultaneously

with one compact, rugged, reliable tool

• Create and run automated as-found/

as-left procedures to satisfy quality

programs or regulations. Record and

document results

• Advanced features like autostep,

custom units, user entered values

during test, one-point and two-point

switch testing, square root DP ow

testing, programmable measurement

delay and more

• Control the temperature of selected

Hart Scientic Dry Blocks

• Handle fast pulsed RTD transmitters

and PLCs in RTD source mode with

1 ms response time

• English, French, German, Italian, and

Spanish languages

• Three-year warranty

753: A complete documenting

calibrator

The 753 Documenting Process Calibrator

automates calibration procedures and

captures your data. Use the PC interface

for downloading procedures, lists, and

instructions to the 753 and for uploading

data for printing, archiving and analysis.

754: Get HART-ability

The 754 offers all of the capabilities

of the 753, plus integrated HART

communication capability. This rugged,

reliable tool is ideal for calibrating,

maintaining, and troubleshooting HART

and other instrumentation.

Instrumentation Management

Software

The Fluke 753 and 754 are compatible

with Fluke 700SW DPC/TRACK software

and with software from Cornerstone,

Fisher-Rosemont, Honeywell, Yokogawa,

Prime Technologies and On Time Support.

Work smarter. Work faster

New

riešenia na presné meranie

http://www.elso.sk

104

725/725Ex/726 Multifunction

Process Calibrators

700P27

See page 112

(Not for hazardous zones)

Specifications

725/725Ex/726 Multifunction

Process Calibrators

• Two separate channels; measure, source

and view process signals simultaneously

• Measure volts, mA, RTDs,

thermocouples, frequency, and

resistance to test sensors and

transmitters

• Source/simulate volts, mA,

thermocouples, RTDs, frequency, and

pressure to calibrate transmitters

• Measure or *source pressure using any

of 29 Fluke 700Pxx Pressure Modules

• Source mA with simultaneous pressure

measurement to conduct valve and I/P

tests

• Perform fast linearity tests with auto

step and auto ramp features

• Power transmitters during test using

24 V loop supply and simultaneous mA

measurement

• Store frequently-used test setups for

later use

• For 725Ex version see also page 118 and

119

726 Precision Multifunction

Process Calibrator

Additional features:

• More precise measurement and

calibration source performance,

accuracies of 0.01%

• Transmitter error% calculation

• Memory storage for up to 8 calibration

results

• Frequency totalizer and frequency

pulse train source mode for enhanced

owmeter testing

• HART mode inserts 250 ohm

resistor in mA measure and source

for compatibility with HART

instrumentation

• Integrated pressure switch test allows

you to capture the set, reset and

deadband of a switch

• Custom RTD curves, add calibration

constants for certied RTD probes for

enhanced temperature measurement

Maximum voltage: 30V

Operating temperature: 10°C to 55°C

Safety: CSA C22.2 No. 1010.1:1992

EMC: EN50082-1:1992 and EN55022:

1994 Class B

Fluke 725

Size (HxWxD): 200 mm x 96 mm x 47 mm

Weight: 0.65 kg

Battery: Four AA alkaline batteries.

Battery life: 25 hours typical; battery door

Warranty: Three years

Included Accessories

Test Leads, AC172 Test Clips, one pair of

stackable test leads, user’s Manuals on

CD-ROM (725Ex also includes CCD control

drawing, Statement of Quality Assurance

Practices, NIST Traceable calibration

certificate)

Ordering Information

Fluke 725 Multifunction Process Calibrator

Fluke 725Ex Intrinsically Safe Multifunction

Process Calibrator

Fluke 726 Precision Multifunction Process

Calibrator

Simultaneous Function

Capability

Channel A Channel B

24.000 mA DC M M or S

24.000 mA DC with

24 V loop supply M M or S

100.00 mV DC M or S

30.000V DC measure M M or S

20.000V DC Measure

10.000V DC Source

20.000V DC Source

M or S

15 to 3200 Ohms

5 to 4000 Ohms

M or S

Thermocouple J, K, T, E, R, S, B, M,

L, U, N, XK, BP M or S

RTD Cu 10, Ni120; Pt100 (392);

Pt100 (JIS); Pt100, 200, 500, 1000

(385)

M or S

Pressure (requires Fluke 700 PXX

Modules) M M used as S

Frequency; 10 kHz; (15 kHz) M or S

Function

Measure or Source

Range or Type Resolution Accuracy Notes

Voltage 0 to 100 mV

725: 0 to 10V (source)

0 to 20V (source)

725/726: 0 to 30V (measure)

0.01 mV

0.001 V

0.01%

0.02% Rdg + 2 LSD Max load, 1 mA

mA 0 to 24 0.001 mA 0.01%; 0.02% Rdg

+2 LSD Max load,

725/726: 1000

725Ex: 250

(TC terminals) -10.00 mV to +75.00 mV 0.01 mV 0.01%

0.02% of range +

1 LSD

Ohms 15 to 3200

5 to 4000

0.01 to 0.1 0.10 to 1.0

0.015%

Hz - CPM 2.0 to 1000 CPM

1 to 1100 Hz

1.0 to 10.0 kHz

10.0 to 15.0 kHz

0.1 CPM

1 Hz

0.1 kHz

±0.05%

±0.25%

±0.05%

Source;

5V p-p

1V - 20 V p-p

squarewave,

-0.1 V offset

Loop Supply 725/726: 24 V DC

725Ex: 12 V DC N/A 10%

T/C J, K, T, E, L, N, U, XK 0.1 ºC, 0.1 ºF to 0.7 ºC

to 0.2 ºC

T/C B, R, S, BP 1 ºC, 1 ºF to 1.7 ºC

to 1.2 ºC

RTDs Cu (10), Ni 120 (672)

Pt 100, 200, 500, 1000 (385)

Pt 100 (3916),

Pt 100 (3926)

0.01 ºC

0.01 ºF

0.1 ºC, 0.1 ºF

to 0.15 ºC

to 0.2 ºC

Fluke 725Ex

Fluke 726

Features

M = Measure S = Source/Simulate

Unique 726 features are in bold

725Ex: ATEX cerfified

(Ex ATEX II IG EEX 1a IIB 171°C)

Recommended Accessories

TPAK

See page 132

80PK-27

See page 128

TL220-1

See page 122

C125

See page 130

More calibration power!

*Pressure pump required

Unique 726 features are in bold

riešenia na presné meranie

http://www.elso.sk

105

724 Temperature Calibrator

80PK-3A

See page 128

Features

The Fluke 724 Temperature Calibrator is

a powerful yet easy-to-use calibrator. Use

the measure and source functions to test

and calibrate almost any temperature

instrument.

• Easy to read dual display lets you view

input and output simultaneously

• Measure RTDs, thermocouples,

ohms, and volts to test sensors and

transmitters

• Source/simulate thermocouples, RTDs,

volts, and ohms to calibrate transmitters

• Perform fast linearity tests with 25% and

100% steps

• Execute remote tests with auto step and

auto ramp

• Power transmitters during test using

loop power supply with simultaneous

mA measurement

• Store frequently-used test setups for

later use

Fluke 724

Included Accessories

Test Leads, AC172 Test Clips, one pair of

stackable test leads.

Ordering Information

Fluke 724 Temperature Calibrator Recommended Accessories

80PK-25

See page 128

TL81A

See page 121

TL220-1

See page 122

C25

See page 130

Maximum voltage: 30V

Operating temperature: -10°C to 55°C

Safety: CSA C22.2 No. 1010.1:1992

EMC: EN50082-1:1992 and EN55022:

1994 Class B

Size (HxWxD): 200 mm x 96 mm x 47 mm

Weight: 0.65 kg

Battery: Four AA alkaline batteries

Battery life: 25 hours typical; battery door

Three Year Warranty

Function

Measure or Source

Range Resolution Accuracy Notes

Voltage 0 to 100 mV

0 to 10V (source)

0 to 30V (measure)

0.01 mV

0.01 V

0.001 V

0.02% Rdg + 2 LSD Max load, 1 mA

mA (measure) 0 to 24 mA 0.001 mA 0.02% Rdg +2 LSD Max load,

1000

mV -10.00 mV to +75.00 mV 0.01 mV 0.025% of range +

1 LSD

Resistance 0 to 3200 (measure)

15 to 3200 (source) 0.01 to 0.1 0.10 to 1.0

Loop Supply 24V DC N/A 10%

Thermocouples J, K, T, E, L, N, U 0.1 ºC to 0.7 ºC

Thermocouples B, R, S 1 ºC to 1.4 ºC

RTDs Ni120 (672)

Pt 100, 200, 500, 1000 (385)

Pt 100 (3916)

Pt 100 (3926)

0.1 ºC to 0.2 ºC

Simultaneous Function

Capability

Channel A Channel B

24.000 mA DC M

24.000 mA DC with 24V loop

supply M

100.00 mV DC M or S

30.000V DC Measure M

20.000V DC Measure 10.000V

DC Source M or S

0 to 3200 Ohms M or S

Thermocouple J, K, T, E, R, S, B,

L, U, N M or S

RTD Ni120; Pt100 (3926); Pt100

(JIS); Pt100, 200, 500, 1000 (385) M or S

Specifications

M = Measure S = Source/Simulate

The temperature solution

riešenia na presné meranie

http://www.elso.sk

106

712/714 Temperature Calibrators

80PK-24 (714)

See page 128

The Fluke 710 Series Process Calibrators

offer clear new choices in single-function

calibrators. Whatever you want to

measure - temperature, pressure or basic

electrical parameters - you’ll nd one of

these easy-to-carry handheld tools gives

you exactly the functions you need. They

combine the rugged, ready-for-action

package of the proven Fluke 80 Series

DMMs with the easy-to-use pushbutton

operation of the multifunction Fluke 740

Series Documenting Process Calibrators.

These calibrators are EMI tolerant,

dust and splash resistant, and have a

removable battery door for quick battery

changes.

712 RTD Calibrator

• Measure temperature from RTD output

• Simulate RTD output

• Rosemount pulsed RTD transmitter

compatible

• Operates with seven types of RTDs

• Measure additional RTDs using Ohms

measurement function

• Simulate additional RTDs using Ohms

source function

• °F or °C selectable

• Four shrouded banana jacks

714 Thermocouple Calibrator

• Measure temperature from TC output

• Simulate TC output

• Operable with nine types of

thermocouples

• Calibrate linear TC transmitter with

mV source function

• Selectable °F or °C

• Thermocouple mini-jack termination

• Available as accessories; Fluke 700 TC1

and TC2 Thermocouple Mini-plug Kits

Fluke 714

Included Accessories

Yellow Holster (H80M excl. TPAK), Test Leads

and AC172 Alligator Clips (excluding model

714), single 9V alkaline battery and Instruction

Sheet (14 languages)

Ordering Information

Fluke 712 RTD Calibrator

Fluke 714 Thermocouple Calibrator

Recommended Accessories

TL220-1 (714)

See page 122

TL970

See page 121

C550

See page 130

C25

See page 130

Maximum voltage: 30 V

Operating temperature: -10°C to 55°C

Safety: CSA C22.2 No. 1010.1:1992

EMC: EN50082-1:1992 and EN55022:

1994 Class B

Size (HxWxD): 201mm x 98 mm x 52 mm

Weight: 0.6kg

Battery: 9V alkaline

Battery Life: 4 to 20 hours, typical, depending

on functions used

Three Year Warranty

Model Function Range Resolution Accuracy Notes

Fluke 712 Measure/

simulate RTD -200 to 800ºC

(Pt 100) 0.1ºC, 0.1ºF 0.33ºC, 0.6ºF

(Pt 100) Pt; 100, 200, 500,

1000 (385);

Pt 100 (3926);

Pt 100 (3916) JIS;

Ni 120 (672)

Measure/

simulate

Resistance

15  to 3200  0.1  0.1  to 1 

Fluke 714 Measure/

simulate

Thermocouple

-200 to 1800ºC,

depending on

type (K, -200 to

1370ºC)

0.1–C or ºF

(1ºC or ºF; BRS) 0.3ºC to 10 µV 9 TC types:

J K T E R S B per NIST

175 and ITS-90, L U per

DIN 43710 and IPTS-68

Measure/

simulate mV -10 to 75 mv 0.01 mV 0.025% +

1 count

Speciﬁcations

Fluke 712

The clear choice

riešenia na presné meranie

http://www.elso.sk

107

9140 Series Field Metrology Wells

4180 Series Infrared Calibrators

9142, 9143, 9144

Field temperature calibration with

precision and speed

The Fluke 9140 series Field Metrology

Wells extend high performance portable

temperature calibration to the industrial

process environment by maximizing

portability, speed, and functionality

with little compromise to metrology

performance.

Offering a broad temperature covered by

three models you can easily cover varied

contact temperature probe workloads

between -25 ºC to 660 ºC.

They are quick to reach temperature set

points, yet they are stable, uniform, and

accurate. These industrial temperature

calibrators are perfect for performing

transmitter loop calibrations, comparison

calibrations, or simple checks of

thermocouple sensors.

Adding the process option means there is

no need to carry additional tools into the

eld. The optional built-in two-channel

readout measures resistance, voltage, and

4–20 mA current with 24V loop power.

• Lightweight, portable, and fast

• Cool to –25 °C in 15 minutes and heat to

660 °C in 15 minutes

• Built-in two-channel readout for PRT,

RTD, thermocouple, 4-20 mA current

• On-board automation and

documentation

• Metrology performance in accuracy,

stability, uniformity, and loading

4180/4181 IR Calibrators

True metrology solution for infrared

Calibration

Now it’s easy to increase your IR

temperature measurement accuracy in

the lab or the eld with the new 4180/81

Precision Infrared Calibrators from Fluke’s

Hart Scientic division.

Their accredited calibrations from Hart’s

IR laboratory help to ensure traceable,

consistent measurements accurate to

+0.25 ºC. Select from eight precongured

Fluke thermometer settings or set up your

own.

The large 152 mm (6 inch) target helps

eliminate errors. So whether you’re

measuring from -15 ºC to 120 ºC (4180)

or from 35 ºC to 500 ºC (4181) you’ll get

a 4:1 TUR.

• High performance, designed for

industrial use

• Guaranteed accuracy specications

• Excellent stability and uniformity

• Large 152 mm targets capture peripheral

vision of IR thermometer

• Portability and speed for eld use -

including convenient bail handle

• Simulates individual IR thermometer

emissivity settings

• No difcult infrared calculations

• Fluke and Raytek thermometer

calibration points can be loaded directly

into the calibrator for convenience

• Calibrated in accredited infrared

laboratory by Hart Scientic, the experts

in temperature calibration

• At least 4 times more accurate than

most IR thermometers

• Calibration includes uncertainties from

surface heat loss and emissivity

Fluke 9142/9143/9144

Included Accessories

914x: 9930 Interface-it Software, Report of

Calibration, Test leads (P Version Only),

6-pin DIN Connector for Reference Probe

(P Version Only)

Ordering Information

Fluke 4180 Precision Infrared

Calibrator, –15 °C to 120 °C

Fluke 4181 Precision Infrared

Calibrator, 35 °C to 500 °C

Fluke 4180-CASE Carrying Case, 4180, 4181

Fluke 4180-DCAS Carrying Case with wheels,

4180, 4181

Fluke 9142-X Field Metrology Well,

Low Temp

Fluke 9143-X Field Metrology Well,

Mid Temp

Fluke 9144-X Field Metrology Well,

High Temp

Add -P to order optional Process option

(914X-X-P). X represents insert type,

A, B, C, D, E or F

9142/9143/9144:

Size (HxWxD): 290 x 185 x 295 mm

Weight: 9142: 8.2 kg, 9143: 7.3 kg, 9144: 7.7 kg

One Year Warranty

4180/4181

Size (HxWxD): 241 x 356 x 241 mm

Weight: 4180: 9.1 kg, 4181: 9.5 kg

One Year Warranty

9142 9143 9144 4180 4181

Temp Range –25 °C to 150 °C 33 °C to 350 °C 50 °C to 660 °C –15 °C to 120 °C 35 °C to 500 °C

Stability ±0.01 °C Full Range ±0.02 °C at 33 °C

±0.02 °C at 200 °C

±0.03 °C at 350 °C

±0.03 °C at 50 °C

±0.04 °C at 420 °C

±0.05 °C at 660 °C

±0.05 °C at 0 °C ±0.2 °C at 250 °C

Uniformity ±0.01 °C Full Range ±0.01 °C at 33 °C

±0.015 °C at 200 °C

±0.02 °C at 350 °C

±0.02 °C at 50 °C

±0.05 °C at 420 °C

±0.15 °C at 660 °C

±0.1 °C at 0 °C ±0.1 °C at 35 °C

Target Size

diameter N/A N/A N/A 152.4 mm

diameter 152.4 mm

Emissivity

Range N/A N/A N/A Preset to 0.95 Preset to 0.95

NIST

Accredited

Calibration

YES YES YES YES YES

Specifications

Fluke 4180/4181

Field Metrology Wells and infrared

calibration targets

For the complete line of Fluke heat sources

check the Fluke website

riešenia na presné meranie

http://www.elso.sk

108

717/718/718Ex/719

Pressure Calibrators

700 LTP-1

See page 112

717 Pressure Calibrators

• Measure pressure, 0.025% of full scale

with internal sensor

- 1/8 NPT pressure tting

- Compatible with non-corrosive gasses

and liquids

• Pressure measurement to 690 bar

• Wide range of selectable measurement

units for pressure

• Current measurement with 0.015%

accuracy and 0.001mA resolution

• Simultaneous pressure and current

measurement for easy P/I testing

• 24 volt loop power supply

• Zero, Min-Max, Hold and Damping

functions

• Pressure switch test captures set, reset

and deadband values

718 Pressure Calibrators

Same features as Fluke 717 plus:

• Newly designed built-in pressure/

vacuum hand pump with vernier and

bleed valve helps protect the pump from

damage and is easier to clean

For 718Ex Intrinsically Safe Pressure

Calibrator see chapter on Ex products in

this catalog.

719 Electric Pressure Calibrator

Same features as Fluke 717 plus:

• Electric pump for one handed operation

• mA source for calibrating I/P devices

and 4-20 mA I/O

• Best in class pressure measurement

accuracy of 0.025%

• Programmable pump limit settings can

eliminate overpressurization - set ‘pump

to’ pressure values

Included Accessories

Fluke 717, 718, 718Ex and 719:

Yellow Holster (718Ex red holster), Test leads,

AC172 Alligator Clips, Single 9V alkaline

battery (two 9V batteries in 718 and 719), User

manual on CD ROM.

719 also includes: Push t connectors,

Translucent test hose.

Ordering Information

Fluke 719 30G Electric Pressure Calibrator

Fluke 719 100G Electric Pressure Calibrator

Fluke 718 1G Pressure Calibrator

Fluke 718 30G Pressure Calibrator

Fluke 718 100G Pressure Calibrator

Fluke 718 300G Pressure Calibrator

Fluke 718Ex 30G Intrinsically Safe Pressure

Calibrator

Fluke 718Ex 100G Intrinsically Safe Pressure

Calibrator

Fluke 717 1G Pressure Calibrator

Fluke 717 15G Pressure Calibrator

Fluke 717 30G Pressure Calibrator

Fluke 717 100G Pressure Calibrator

Fluke 717 300G Pressure Calibrator

Fluke 717 500G Pressure Calibrator

Fluke 717 1000G Pressure Calibrator

Fluke 717 1500G Pressure Calibrator

Fluke 717 3000G Pressure Calibrator

Fluke 717 5000G Pressure Calibrator

Fluke 717 10000G Pressure Calibrator

Recommended Accessories

700P27

See page 112

TL220-1

See page 122

C125 (717)

See page 130

C43 (718)

See page 130

717

Size (HxWxD): 201 mm x 98 mm x 52 mm

Weight: 0.6 kg

Three years Warranty

718/718Ex

Size (HxWxD): 216 mm x 94 mm x 66 mm

Weight: 0.992 kg

Warranty: Three years (Pump one year)

719

Size (HxWxD): 210 mm x 87 mm x 60 mm

Weight: 0.912 kg

Three Year Warranty (Pump one year)

Speciﬁcations

Pump up the pressure

For Fluke 717/718/719 models: Supported Pressure Units; psi, in. H2O(4°C), in. H2O(20°C), cm

H2O(4°C), cm H2O(20°C), bar mBar, kPa, inHg, mmHg, kg/cm2

Functions: Zero, Min, Max, Hold, Damp functions

Max. Voltage: 30 V

Operating temperature: -10°C to 55°C

Safety: CSA C22.2 No. 1010.1:1992

EMC: EN50082-1:1992 and EN55022:1994 Class B

Fluke 717: For use with non corrosive gasses and liquids

Fluke 718/719: For use with Dry Air only

(Not for hazardous zones)

Fluke 718

Fluke 719 Fluke 717

Fluke 718Ex

Model Range Resolution Over Pressure

719 30G -850 mbar to 2 bar 0.1 mbar Over pressure 2xFS

719 100G -850 mbar to 7 bar 1 mbar Over Pressure 2xFS

718 1G -68.9 mbar to 68.9 mbar 0.001 mbar Over Pressure 5xFS

718 30G -850 mbar to 2 bar 0.1 mbar Over Pressure 2xFS

718 100G -850 mbar to 7 bar 0.1 mbar Over Pressure 2xFS

718 300G -850 mbar to 20 bar 1 mbar Over Pressure 375 PSI, 25 bar

717 1G -68.9 mbar to 68.9 mbar 0.001 mbar Over Pressure 5xFS

717 15G -830 mbar to 1 bar 0.01 mbar Over Pressure 2xFS

717 30G -850 mbar to 2 bar 0.1 mbar Over Pressure 2xFS

717 100G -850 mbar to 7 bar 0.1 mbar Over Pressure 2xFS

717 300G -850 mbar to 20 bar 1 mbar Over Pressure 375 PSI, 25 bar

717 500G 0 mbar to 34.5 bar 1 mbar Over Pressure 2xFS

717 1000G 0 mbar to 69 bar 1 mbar Over Pressure 2xFS

717 1500G 0 bar to 103.4 bar 0.01 bar Over Pressure 2xFS

717 3000G 0 bar to 207 bar 0.01 bar Over Pressure 2xFS

717 5000G 0 bar to 345 bar 0.01 bar Over Pressure 2xFS

717 10000G 0 bar to 690 bar 0.01 bar Over Pressure 2xFS

riešenia na presné meranie

http://www.elso.sk

109

705/707/707Ex/715

Loop Calibrators

T PAK (715)

See page 132

Fluke 705

TP920

See page 121

TL220-1

See page 122

C25 (715)

See page 130

C12A (705/707)

See page 130

Functions

Voltage measurement

705/707/707 Ex 715

Range 0-28 V DC 0-200 mV, 0-20 V

Resolution 1 mV 10 µV 1 mV

Accuracy 705: 0.025% Rdg + 2 LSD

707/707Ex: 0.015% Rdg + 2 LSD 0.01% Rdg + 2 LSD

Speciﬁcations

Fluke 705, 707, 707Ex

Maximum voltage: 30 V (28 V - 707Ex)

Operating temperature: -10 to 55°C

Safety: CSA C22.2 No. 1010.1: 1992

EMC: EN50082-1:1992 and EN55022: 1994 Class B

Size (HxWxD): 164 mm x 75 mm x 47 mm;

Weight: 0.35 kg

Battery: One 9 V alkaline

Battery life: 18 hours typical, at 12 mA

Three Year Warranty

Fluke 715

715

Size (HxWxD): 201 mm x 98 mm x 52 mm

Weight: 0.6 kg

Battery: One 9V alkaline

Battery life: 4 to 20 hours

Three Year Warranty

705 Loop Calibrator

• Simultaneous mA and %

• mA accuracy of 0.02%

• Measure, source and simulate mA

• Push button 25% steps for fast, easy

linearity checks

• “Span Check” for fast conrmation of

zero and span

• Selectable slow ramp, fast ramp, and

step function

• 24 volt internal loop supply

• 0 - 20 mA or 4 - 20 mA default start up

modes

707 Loop Calibrator

• Features of the Fluke 705

• “Quick Click” detented rotary knob for

one handed operation

• Higher accuracy: 0.015%

• Mains Voltage Input protection

• 250 Ohm loop resistance for with Hart

instrumentation

715 Volt/mA Calibrator

• Measure loop current (0-20 mA,

4-20 mA) signals with 0.015% accuracy

and 0.001 mA resolution

• Measure voltage output process signals

from PLCs, transmitters

• Source or simulate 24 mA loop current

• Source voltage to 100 mV or 10 V

• 24 V loop supply with simultaneous

current measurement

707Ex Intrinsically Safe Loop

Calibrator

• Same features as Fluke 707

• For use in explosion endangered areas

• ATEX certied ( II 2 G Eex ia IIC T4)

4-20 mA, source, measure, simulate

Fluke 707

Fluke 707Ex

Current sourcing

Range 0-20 mA or 4-20 mA10-20 mA or 4-20 mA1

Accuracy 705: 0.025% Rdg + 2 LSD

707/707Ex: 0.015% Rdg + 2 LSD 0.015% + 2 LSD

Drive capability 705: 1000  @ 24 mA

707: 1200  @ 24 mA

707Ex: 700  20 mA

1000  @ 24 mA

Loop power while measuring mA 24 V 24 V

Voltage sourcing N/A 0-100 mV or 0-10 V

Display current and % of span Yes mA or %

Auto step, auto ramp Yes Yes

Span Check Yes Yes

Current measurement

Range 0-24 mA 0-24 mA

Resolution 0.001 mA 0.001 mA

Accuracy 705: 0.025% Rdg + 2 LSD

707/707Ex: 0.015% Rdg + 2 LSD 0.015%

Included Accessories

Fluke 705/707: C10 Yellow Holster, Test Leads,

AC172 Alligator Clips, Single 9V alkaline

battery, Instruction Sheet

Fluke 707Ex: Red Ex-holster, Test Leads, AC172

Alligator Clips, Single 9V alkaline battery,

Instruction Sheet

Fluke 715: Yellow Holster (H80M excl. TPAK),

Test Leads and AC172 Alligator Clips, Single 9V

alkaline battery, Instruction Sheet

Ordering Information

Fluke 705 Loop Calibrator

Fluke 707 Loop Calibrator

Fluke 707Ex Intrinsically Safe Loop Calibrator

Fluke 715 Volt/mA Calibrator

1 will over-range to 24 mA

riešenia na presné meranie

http://www.elso.sk

110

771, 772 and 773

mA Process Clamp Meters

Fluke 773

Fluke 771

Included Accessories

Fluke 771: soft carrying case and user’s manual

Fluke 771 + 772: plus test leads, AC172 alligator

clip set and TL940 mini-hook test lead set

Ordering Information

Fluke 771 Milliamp Process Clamp Meter

Fluke 772 Milliamp Process Clamp Meter

Fluke 773 Milliamp Process Clamp Meter

Specifications

Features

Size (HxWxD):

771: 212 mm x 59 mm x 38 mm

772 + 773: 248 mm x 76 mm x 41 mm

Weight: 771: 0.26 kg

772 + 773: 0.42 kg

Battery: 771: 2x 1.5V Alkaline, IEC LR6

772 + 773: 4x 1.5V Alkaline, IEC LR6

Battery Life: 771: 20 hours typical

772 + 773: 12 hours @ 12 mA source into

500 ohms

IP Rating: IP 40

Warranty: 3 years, 1 year on mA clamp

accessory and cable

Fluke 771, 772 and 773

• Measure 4 to 20 mA signals without

”breaking the Loop,” save time and

money troubleshooting 4 to 20 mA

signals

Fluke 772 and 773

• Source 4 to 20 mA signals for testing

control system I/O or I/Ps

• Simulate 4 to 20 mA signals for testing

control system I/O

• Measure 4 to 20 mA signals with in-

circuit measurement

• Power a transmitter with the 24 V loop

power supply

• Automatically ramp and step change

the 4 to 20 mA output for remote

testing

Fluke 773

• DC voltage measurement to verify 24 V

power supplies or voltage I/O signals

• Source dc voltage to test voltage input

devices

• Scaled mA output signal enables a

logging DMM (289) to record 4 to 20 mA

signal without breaking the loop

• mA in/out: simultaneously source a mA

signal while measuring a mA signal

with the clamp

mA measurements without breaking the loop.

Save time. Save money.

Function Resolution and range Accuracy Notes

771, 772, 773 mA measurement 0 to 20.99 mA 0.2 % + 5 counts Measured by clamp

21.0 mA to 100.0 mA 1 % + 5 counts

772 and 773 mA measurement 0 to 24.00 mA 0.2 % + 2 counts Measured in series

with test jacks

772 and 773 mA source 0 to 24.00 mA 0.2 % + 2 counts Maximum mA drive:

24 mA into 1,000 ohms

772 and 773 mA simulate 0 to 24.00 mA 0.2 % + 2 counts Maximum voltage

50 V dc

773 Voltage source 0 to 10.00 V dc 0.2 % + 2 counts 2 mA maximum

drive current

773 Voltage measure 0 to 30.00 V dc 0.2 % + 2 counts

771 772 773

mA measure w/jaw OOO

mA measure In circuit OO

mA source OO

mA sim OO

Loop power 24 V OO

DCV source 0-10 V O

DCV measure 0-30 V O

Scaled mA output to mA input O

mA in/out O

Fluke 772

riešenia na presné meranie

http://www.elso.sk

111

787/789 ProcessMeters

Fluke 787

Included Accessories

787: Yellow Holster (H80M excl. TPAK), Hard

Point Test Lead Set plus AC172 Alligator Clips,

one 9V battery, user manual

789: Test Lead Set plus AC172 Alligator Clips,

four 9V AA alkaline batteries, user manual

and quick reference guide.

Ordering Information

Fluke 787 ProcessMeter

Fluke 789 ProcessMeter

FVF-SC2 FlukeView Forms Software

including interface cable

Features

Maximum voltage: 1000 V

Operating temperature: -20 to 55ºC

787

Size (HxWxD): 201 mm x 98 mm x 52 mm

Weight: 0.642 kg

Battery: One 9 V alkaline

Battery life: 12 to 50 hours typical

Three Year Warranty

789

Size (HxWxD): 203 mm x 100 mm x 50 mm

Weight: 0.6 kg

Battery: Four AA alkaline batteries

Battery life: 14 to 140 hours typical

Three Year Warranty

The Fluke 787 and 789 ProcessMeters

combine a Digital Multimeter and a Loop

Calibrator in one rugged handheld tool,

giving process technicians double the

power.

The Fluke 789 has a built-in 24 V loop

supply which reduces the need for

taking a separate power supply when

doing ofine transmitter testing. The

IR communication port of the Fluke

789 allows data to be logged to optional

FlukeView Software for graphical analysis

and reporting.

Double your power

Recommended Accessories

C125

See page 130 TL220-1

See page 122 80T-150U

See page 128 i400

See page 126 i410

See page 127

Specifications

Fluke 789

True RMS

787 789

DMM and Loop Calibrator in one tool

Precision 1000 V, 440 mA True RMS Digital Multimeter

DC current source and Loop Calibrator

24 V Loop power supply

Min/Max / Average / Hold / Relative Modes

Diode Test and Continuity Beeper

Manual Step (100%, 25%, Coarse, Fine) plus Auto Step and Auto Ramp

Simultaneous mA and % of scale read-out

Externally accessible battery / fuses

HART mode setting with loop power and a built-in 250  resistor

0% and 100% buttons to toggle between 4 and 20 mA sourcing for a quick span check

Infrared I/O serial port

787 789

Voltage measurements

Range 0-1000 V AC or DC 0-1000 V AC or DC

Resolution 0.1 mV to 1.0 V 0.1 mV to 1.0 V

Accuracy 0.1% Rdg+1 LSD (V DC) 0.1% Rdg+1 LSD (V DC)

Other specifications

Max drive capability 500  1200 

Loop power N/A 24 V

Resistance measurement To 40 M, 0.2%+1 LSD To 40 M, 0.2%+1 LSD

Frequency To 19.999 kHz, 0.005%+1 LSD To 19.999 kHz, 0.005%+ LSD

Continuity Beeps for resistance < 100  Beeps for resistance < 100 

Span Check No Yes

Current measurement

Range 0-1 A 0-30 mA 0-1 A 0-30 mA

Resolution 1 mA 0.001 mA 1 mA 0.001 mA

Accuracy 0.2%+2 LSD 0.05%+2 LSD 0.2%+2 LSD 0.05%+2 LSD

Current Sourcing

Range 0-20 mA or 4-24 mA 0-20 mA or 4-24 mA

Accuracy 0.05% of span 0.05% of span

riešenia na presné meranie

http://www.elso.sk

112

Field Calibrator Accessories

Model Range (approx.) Resolution

uncertainty

(23 ± 3°C) (FS)

Reference High side media Low side media Fitting material Max

overpressure2)

Differential

700P00 2.5 mbar 0.001 mbar 0.3 % Dry 1) Dry 1) 316 SS 30x

700P01/700P01Ex 25 mbar 0.01 mbar 0.2 % Dry Dry 316 SS 3x

700P02 70 mbar 0.007 mbar 0.15 % Dry Dry 316 SS 3x

700P22 70 mbar 0.007 mbar 0.1 % 316 SS Dry 316 SS 3x

700P03 340 mbar 0.01 mbar 0.05 % Dry Dry 316 SS 3x

700P23 340 mbar 0.01 mbar 0.025 % 316 SS Dry 316 SS 3x

700P04 1000 mbar 0.1 mbar 0.025 % Dry Dry 316 SS 3x

700P24/700P24Ex 1001 mbar 0.1 mbar 0.025 % 316 SS Dry 316 SS 3x

Gage

700P05/700P05Ex 2 bar 0.1 mbar 0.025 % 316 SS N/A 316 SS 3x

700P06/700P06Ex 7 bar 0.7 mbar 0.025 % 316 SS N/A 316 SS 3x

700P27/700P27Ex 20 bar 1 mbar 0.025 % 316 SS N/A 316 SS 3x

700P07 34 bar 1 mbar 0.025 % 316 SS N/A 316 SS 3x

700P08 70 bar 7 mbar 0.025 % 316 SS N/A 316 SS 3x

700P09/700P09Ex 100 bar 10 mbar 0.025 % 316 SS N/A 316 SS 2x

Absolute

700PA3 340 mbar 0.01 mbar 0.05 % 316 SS N/A 316 SS 3x

700PA4/700PA4Ex 1000 mbar 0.1 mbar 0.05 % 316 SS N/A 316 SS 3x

700PA5 2 bar 0.1 mbar 0.05 % 316 SS N/A 316 SS 3x

700PA6 7 bar 0.7 mbar 0.05 % 316 SS N/A 316 SS 3x

Vacuum

700PV3 -340 mbar 0.01 mbar 0.04 % 316 SS Dry 316 SS 3x

700PV4 -1000 mbar 0.1 mbar 0.04 % 316 SS Dry 316 SS 3x

Dual

700PD2 ± 70 mbar 0.007 mbar 0.15 % 316 SS Dry 316 SS 3x

700PD3 ± 340 mbar 0.01 mbar 0.04 % 316 SS Dry 316 SS 3x

700PD4 ±1000 mbar 0.1 mbar 0.025 % 316 SS Dry 316 SS 3x

700PD5 -1000/+2000 mbar 0.1 mbar 0.025 % 316 SS N/A 316 SS 3x

700PD6 -1000 mbar/+6.9 bar 1 mbar 0.025 % 316 SS N/A 316 SS 3x

700PD7 -1000 mbar/+13.8 bar 1 mbar 0.04 % 316 SS N/A 316 SS 3x

High

700P29/700P29Ex 200 bar 0.01 bar 0.05 % C276 N/A C276 2x

700P30 340 bar 0.01 bar 0.05 % C276 N/A C276 2x

700P31 700 bar 0.07 bar 0.05 % C276 N/A C276 1.5x

• Ranges from 2.5 mbar to 700 bar.

• Gage, differential, dual (compound), absolute

and vacuum modules

• Very high accuracy: up to 0.025% FS

• Features internal temperature compensation

from 0°C to 50°C for full-accuracy

performance

• Pressure readings update twice per second,

and may be displayed in any of 11 different

units

700LTP-1 Low-pressure Test Pump

• For low pressure applications

• Vacuum to -13 psi / -.90 bar

• Pressure to 100 psi / 6.9 bar

• With ne-control, adjustable relief valve

and slow bleed capability

700PTP-1 Pneumatic Test Pump-1

• Handheld pressure pump

• Pressures up to 600 psi, 40 bar

700HTP-2 Hydraulic Test Pump

• Pressures up to 10,000 psi/690 bar.

• Compatible with Fluke 717, 718, 725 and 75x

series.

• Rugged cases protect the modules from

harsh environments

• All modules include NIST traceable

certicate and test data

• ATEX certied Ex versions available

( II 1 Eex ia IIB T4)

700PRV-1 Pressure Relief Valve

• Pressure relief valve for 700HTP-1

• Adjustable from 725 to 5800 PSI

(50 to 200 bar)

700HTH-1 Hydraulic Test Hose

• Hydraulic test hose is a 10,000 psi, 690 bar

700ILF In-Line Filter for the

Fluke 718

700PCK Pressure Module

Calibration Kit

BE9005 Battery Eliminator

Fluke 700 Series Pressure Modules

Other accessories

1)“Dry” indicates dry air or non-corrosive gas as compatible media. “316 S S” indicates media compatible with Type 316 Stainless Steel. “C276” indicates media compatible with Hastelloy C276.

2)Maximum overpressure specification includes common mode pressure.

Fluke 700LTP-1Fluke 700HTP-2 Fluke 700PTP-1

riešenia na presné meranie

http://www.elso.sk

113

With the Fluke 810 Vibration Tester you will be able to control unplanned

downtime, prevent recurring problems, set repair priorities and manage

your resources with an entirely new approach to vibration testing. In three

quick, easy steps, the new Fluke 810 helps you locate and diagnose com-

mon mechanical problems and prioritize their repair actions. The combi-

nation of powerful algorithms and a database of real-world measurement

experience make the Fluke 810 the most advanced troubleshooting tool

for mechanical maintenance teams who need an answer now.

Vibration Tester

riešenia na presné meranie

http://www.elso.sk

114

810 Vibration Tester

Included Accessories

Tri-axial TEDS accelerometer, accelerometer

magnet mount, accelerometer mounting

pad kit with adhesive, accelerometer quick

disconnect cable, laser tachometer and

storage pouch, smart battery pack with cable

and adapters, shoulder strap, adjustable

hand strap, Viewer PC application software,

mini-USB to USB cable, getting started guide,

illustrated quick reference guide, users

manual CD-ROM, instructional training CD-

ROM, hard carrying case.

Ordering Information

Fluke 810 Vibration Tester

Diagnostic specifications

Standard faults Unbalance, looseness, misalignment and bearing failures

Analysis for Motors, fans, blowers, belts and chain drives, gearboxes, couplings, centrifugal pumps,

piston pumps, sliding vane pumps, propeller pumps, screw pumps, rotary thread/gear/

lobe pumps, piston compressors, centrifugal compressors, screw compressors, closed

coupled machines, spindles

Machine rotational

speed range 200 rpm to 12000 rpm

Diagnosis details Plain-text diagnosis, fault severity (slight, moderate, serious, extreme), repair details,

cited peaks, spectra

Electrical specifications

Ranging Automatic

A/D converter 4 channel, 24 bit

Usable bandwith 2 Hz to 20 kHz

Sampling 51.2 kHz

Digital signal

processing functions Automatically configured anti-alias filter, high-pass filter, decimation, overlapping,

windowing, FFT, and averaging

Sampling rate 2.5 kHz to 50 kHz

Dynamic range 128 dB

Amplitude accuracy ±0.1 dBV

FFT resolution 800 lines

Spectral windows Hanning

Frequency units Hz, orders, cpm

Amplitude units in/sec, mm/sec, VdB (US), VdB (Europe)

Non-volatile nemory SD micro memory card, 2 GB internal + user accessible slot for additional storage

Specifications

(Check the Fluke web for detailed specifications)

Battery type: Lithium-ion, 14.8 V 2.55 Ah

Size (HxWxD): 186 x 267 x 70

Weight: 1.9 kg

Fluke 810

Language support:

eng, ger, fre, ita, spa, por

Warranty: Three years on tester

One year on sensor and tachometer

The Fluke 810 Vibration Tester is the

most advanced troubleshooting tool

for mechanical maintenance teams

who need an answer now. The unique

diagnostic technology helps you quickly

identify and prioritize mechanical

problems, putting the expertise of a

vibration analyst in your hands.

Use the vibration tester to:

• Troubleshoot problem equipment and

understand the root cause of failure

• Survey equipment before and after

planned maintenance and conrm the

repair

• Commission new equipment and

ensure proper installation

• Provide quantiable proof of equipment

condition and drive investment in

repair or replacement

• Prioritize and plan repair activities and

operate more efciently

• Anticipate equipment failures before

they happen and take control of spare

parts inventories

• Train new or less-experienced

technicians and build condence and

skill across the team

Features and benefits

• On-board identication and location of

the most common mechanical faults

(bearings, misalignment, unbalance,

looseness) focus maintenance efforts

on root cause, reducing unplanned

downtime

• Fault severity scale with four severity

levels help you prioritize maintenance

work

• Repair recommendations advise

technicians on corrective action

• On-board context sensitive help provide

real-time tips and guidance to new

users

• 2 GB expandable on-board memory

provide enough space for your

machinery’s data

• Self-test functions ensure optimal

performance and more time on the job

• Laser tachometer for accurate machine

running speed promotes condent

diagnoses

• Tri-axial accelerometer reduces

measurement time by 2/3 over single

axis accelerometers

• Viewer PC Software expands data

storage and tracking capacity

• Color LCD display and intuitive

multilingual, icon-based user interface

promote use right out of the box

Motor diagnosis and repair in three simple steps

Set-up

Measure

Diagnose

riešenia na presné meranie

http://www.elso.sk

115

Radiation safety quality assurance is top of mind for hospitals, nuclear

power facilities, nuclear medicine laboratories, x-ray manufacturers,

government agencies, state inspectors, emergency response and

HAZMAT (hazardous materials) teams, and police and fire departments

around the world.

With the 481 Fluke offers these professionals the versatility they need to

get the job done and the quality they trust in a radiation-safety device.

481 Radiation Detection Meter

riešenia na presné meranie

http://www.elso.sk

116

481 Radiation Detection Meter

Fluke 481

Ordering Information

Fluke 481 Ion Chamber Survey Meter

Fluke 481-DESI DESI Ion Chamber Survey Meter,

dose equivalent SI

190HPS Single Unit Carrying Case

The Fluke 481 Radiation Detection Meter

is a portable and practical means for

discovering irradiated goods, and for

helping remediate contaminant and

safety issues while minimally affecting

performances. Ideal for detecting

irradiated goods, equipment, surfaces

or environments in industrial settings,

the 481 Radiation Meter helps ascertain

worker safety and compliance to national

regulations.

Use of the Fluke 481 assures employees

that radiation dangers are known,

monitored and calculated for their

security. Whenever radiation is found,

a clear and quantiable result provides

handlers to comply with national

guidelines while avoiding unnecessary

steps that could stop procedures, impact

productivity or lead to missed revenue.

• Detects skin-dose (beta particle)

and deep-dose (gamma) and X-ray

radioactivity

• Requires no adjustments; simple two

button process

• Provides promptly read, correct value

through autoranging capability

• Easily visible inside truck trailers

and other low-light situations with

automated backlight

• Works dependably inside or outside

thanks to sealed case

• 30 % more precise than other available

meters

• Delivers more than one week of

uninterrupted functioning with two

9-volt alkaline batteries

• Proven in use by state and local

governmental emergency response

professionals, state inspectors,

HAZMAT teams and nuclear power

workers

• Measures both dose and dose-rate

• Valuable for contamination-detection,

general radiation area metering,

radiation-level monitoring, and

hazardous materials assessment

• Rugged Fluke design

Fluke 481 Radiation Detection Meter

General specifications Fluke 481 Fluke 481-DESI

Radiation detected Beta > 100 keV

Gamma > 7 keV

Operating ranges 0 mR/h to 5 mR/h (8 sec)

0 mR/h to 50 mR/h (2.5 sec)

0 mR/h to 500 mR/h (2 sec)

0 R/h to 5 R/h (2 sec)

0 R/h to 50 R/h (2 sec)

0 µSv/h to 50 µSv/h (8 sec)

0 µSv/h to 500 µSv/h (2,5 sec)

0 mSv/h to 5 mSv/h (2 sec)

0 mSv/h to 50 mSv/h (2 sec)

0 mSv/h to 500 mSv/h (2 sec)

Accuracy Within 10 % of readings between 10 % and 100 % of full scale indication on any

range, exclusive of energy response

Detector Chamber (cc volume air ionization) 349 cc

Chamber wall (phenolic) 246 mg/cm2

Chamber window (mylar) 6.6 mg/cm2

Beta slide 440 mg/cm2

Automatic features Auto-zeroing, auto-ranging, and auto-backlight

Power requirements Two 9 V alkaline, 200 hours operation

Warm-up time One minute

Battery life Four+ hours continuous use per battery pack

(assumes 50 % brightness of LCD)

Dimensions (W x D x H) 10 cm x 20 cm x 15 cm

Weight 1.11 kg

Display LCD analog/digital with backlight

Analog 100 element bar graph 6.4 cm long. Bar graph is divided into 5 major segments,

each labeled with the appropriate value for the range of the instrument

Digital 2.5 digit display is followed by a significant zero digit depending on the

operating range of the instrument. The units of measurement are indicated

on the display at all times. Digits are 6.4 mm high. Low battery and freeze

indicators are also provided on the display

Modes

Integrate mode Operates continuously 30 seconds after the instrument has been turned on.

Integration is performed even if the instrument is displaying in mR/h or R/h

Freeze mode Will place a tick mark on the bar graph display to hold on the peak displayed

value. The unit will continue to read and display current radiation values

Environmental

Temperature range -20 °C to 50 °C

Relative humidity 0 % to 100 % (at 50 °C)

Geotropism < 1 %

Speciﬁcations

riešenia na presné meranie

http://www.elso.sk

117

The Fluke line of intrinsically safe tools is designed to meet the needs of

technicians working in and around hazardous areas. The tools are ideal

for environments in chemical plants, petro-chemical plants, oil plat-

forms, refineries and other locations where risk of explosion exists. The

products are easily recognizable from standard Fluke products by their

lighter grey colour and red holster.

ATEX Certified Test Tools

riešenia na presné meranie

http://www.elso.sk

118

What is “Intrinsically Safe”?

Intrinsically safe standards apply to all

equipment that can create one or more

of a range of dened potential explosion

sources:

• Electrical sparks

• Electrical arcs

• Flames

• Hot surfaces

• Static electricity

• Electromagnetic radiation

• Chemical reactions

• Mechanical impact

• Mechanical friction

• Compression ignition

• Acoustic energy

• Ionizing radiation

What industries are intrinsically

safe products designed for?

• Petro-chemical

• Oil platforms and reneries

• Pharmaceutical

• Bulk materials (e.g. grain)

• Mining

• Pipelines

• Any environment where explosive gases

are present

What is ATEX?

The primary intrinsically safe standard has

been set in the European Union with the

9/94/EC Directive, commonly called ATEX

(“Atmosphères Explosibles,” French for

explosive atmospheres). The stated goal of

the guidelines is to “help ensure the free

movement of products in the European

Union” by “minimizing the number of

safeguard clause applications, at least those

originating from divergent interpretations

The ATEX rules have been in place as a

voluntary standard since 1 March 1996.

The rules are mandatory on electrical

and electronic equipment for use in

environments subject to explosion hazard

sold in the EU starting 1 July 2003. From

this date onwards, all products sold for

use in explosive atmospheres must have

ATEX certication and carry the distinctive

symbol:

The Fluke Ex (IS) product line

Fluke is among the rst manufacturers to

produce handheld test tools according to

the latest ATEX standards. The Fluke line of

intrinsically safe tools is designed to meet

the needs of technicians working in and

around hazardous areas:

• Install, maintain and troubleshoot

equipment by using the new Fluke 87V Ex

Digital Multimeter

• Maintain and calibrate sensors,

transmitters and control loops with the

line of Ex eld calibrators

The tools are ideal for environments

in petro-chemical plants, oil platforms,

reneries and other locations subject to risk

of explosion.

Apart from having the ATEX markings, the

visual difference between a standard Fluke

tool and the corresponding Ex version is

the different grey body colour and a red,

conductive holster designed specically

to eliminate the potential for electrical

discharge.

Inside, the Fluke Ex tools have been

reengineered to reduce energy avoiding

generation of heat and electrical sparks.

They are premium products designed for

ultimate safety.

Making sense of ATEX certication

Fluke 707Ex is ATEX-compliant and is

certied II 2 G EEx ia IIC T4— but what

exactly does that mean?

Intrinsic safety is a protection standard

employed in potentially explosive

atmospheres. Devices that are certified

as “intrinsically safe” are designed to be

unable to release sufficient energy, by

either thermal or electrical means, to cause

ignition of flammable material (gas, dust/

particulates).

Here a brief explanation of the ATEX

certification designations.

A brief look at ATEX

The ATEX examination mark. This sign is required on all devices used in European hazardous

areas.

II 2 G

The classification of zones.

“II” designates the tool is approved for all non-mining areas.

“2” represents the category of the device, in this case the device is rated for the second most

hazardous areas.

“G” designates atmosphere, in this case gas, vapors and mist.

EEx Explosion protection based on European Ex-regulations.

ia The type of protection from explosion, in this case the energy in a device or connector has

been reduced to a safe value.

IIC Gas Group. “IIC” indicates compatibility with the most dangerous gas group.

T4 Temperature class gives the user the maximum temperature of a surface that may be in

contact to the Ex atmosphere under fault conditions. T4 is rated at 135°C.

ATEX certification 707Ex

A brief look at ATEX

riešenia na presné meranie

http://www.elso.sk

119

Fluke 87V Ex Intrinsically safe

version of the world’s most popular

multimeter

With its high performance, accuracy and

motor drive compatibility, the Fluke 87V

is the most popular industrial multimeter

around. Now Fluke has introduced a new

intrinsically safe version – the 87V Ex – for

measurements in and around hazardous

areas.

The Fluke 87V Ex has all the measurement

and troubleshooting functions of the proven

Fluke 87V. Unlike other ATEX-certified tools,

it can be used both inside and outside the

hazardous zone (ATEX Zones 1 & 2) without

compromising performance or compliance.

So there’s no need to carry different tools

for use in specific zones. It also has a built-

in thermometer with TC probe, further

reducing technicians’ tool counts.

• ATEX safety rating II 2G EEx ia IIC T4

• EN61010-1 CAT III 1000V/CAT IV 600V

electrical safety rating

Product Detail Manual

243809-Catalog 243809-Catalog 243809-Catalog 095969 Batch5 unilog cesco-content

Navigation menu

Versions of this User Manual:

Views

Navigation
