Features and Benefits
Quick-cure epoxy
No lamps or ovens needed
Minimal tools and no index-matching gel
Low installation cost
Hand polished for minimum insertion loss
Reliability and optical performance
Standards
Intermateability Compliant with TIA/EIA
604-2 (ST® Compatible
Connectors), 604-3 (SC),
604-4 (FC) and 604-10 (LC)
Corning anaerobic-cure connectors offer optical perfor-
mance in a fast, easy field-termination solution designed
for fiber-to-the-workstation applications for single-mode
and multimode connections. This connector combines
the quick-cure convenience of anaerobic adhesive with
the performance of epoxy-and-polish connectors. Ideal
for enterprise networks and any installations requiring
field-installed connectors, the anaerobic-cure technology
enables fiber optic networks to be installed cost effec-
tively with minimal tools. Installation of the connector can
be accomplished in minutes with the anaerobic adhesive
two-part epoxy process. The adhesive is first injected
into the connector ferrule, then the fiber is dipped into the
primer and inserted into the connector. Curing takes only
one minute without the use of lamps or ovens. With the
hand-polish process, an average insertion loss of 0.2 dB
is achieved.
Anaerobic-Cure Multimode Connectors
| Photo CRR1243
TKT-ANAEROBIC2 Installation Tool Kit
| Photo LAN3164
Anaerobic-Cure Connectors
Family Spec Sheet 0251_NAFTA_AEN
Page 1 | Revision date 2014-05-14
Anaerobic-Cure Single-mode Connectors
| Photo CRR1244
Specifications
Boot Color
Boot Color
50 µm Black
Laser-optimized multimode
fiber
Aqua
62.5 µm Beige
Single-mode Blue
All SC, FC and ST Compatible connectors come with 3 mm, 2 mm and 900 µm boots. LC connectors come with 3 mm, 900 µm and combination 2 mm/1.6 mm
boots.
Optical Characteristics
Insertion Loss Reflectance Temperature Cycling
typical max. change, -40° Celsius to +75° Celsius, 21 cycles
Multimode Connectors 0.2 dB 0.75 dB ≤ -26 dB ≤ 0.3 dB
Single-Mode Connectors 0.2 dB 0.75 dB ≤ -40 dB ≤ 0.3 dB
Anaerobic-Cure Connectors
Family Spec Sheet 0251_NAFTA_AEN
Page 2 | Revision date 2014-05-14
Multimode Connectors
Ordering Information
Multimode
Part Number Description Units per Delivery
95-051-52-SP ST Compatible Connector, 50 µm multimode, ceramic
ferrule, metal hardware; single pack
1/1
95-051-52-SP-X ST Compatible Connector, 50 µm multimode (OM3/
OM4/OM4 extended 10G distance), ceramic ferrule,
metal hardware; single pack
1/1
95-101-52-SP ST Compatible Connector, 62.5 µm multimode, cera-
mic ferrule, metal hardware; single pack
1/1
95-051-41-SP SC Connector, 50 µm multimode, ceramic ferrule;
single pack
1/1
95-051-41-SP-X SC Connector, 50 µm multimode (OM3/OM4/OM4 ex-
tended 10G distance), ceramic ferrule; single pack
1/1
95-101-41-SP SC Connector, 62.5 µm multimode, ceramic ferrule;
single pack
1/1
95-051-61-SP FC Connector, 50 µm multimode, ceramic ferrule;
single pack
1/1
95-051-61-SP-X FC Connector, 50 µm multimode (OM3/OM4/OM4 ex-
tended 10G distance), ceramic ferrule; single pack
1/1
95-101-61-SP FC Connector, 62.5 µm multimode, ceramic ferrule;
single pack
1/1
95-051-98-SP LC Connector, 50 µm multimode, ceramic ferrule;
single pack
1/1
95-051-98-SP-X LC Connector, 50 µm multimode (OM3/OM4/OM4 ex-
tended 10G distance), ceramic ferrule; single pack
1/1
95-101-98-SP LC Connector, 62.5 µm multimode, ceramic ferrule;
single pack
1/1
Single-mode Connectors
Ordering Information
Single-Mode
Part Number Description Units per Delivery
95-201-52-SP ST Compatible Connector, single-mode (OS2), cera-
mic ferrule, metal hardware; single pack
1/1
95-201-41-SP SC Connector, single-mode (OS2), ceramic ferrule,
composite hardware; single pack
1/1
Anaerobic-Cure Connectors
Family Spec Sheet 0251_NAFTA_AEN
Page 3 | Revision date 2014-05-14
Ordering Information
Single-Mode
Part Number Description Units per Delivery
95-201-61-SP FC Connector, single-mode (OS2), ceramic ferrule,
composite hardware; single pack
1/1
95-201-98-SP LC Connector, single-mode (OS2), ceramic ferrule,
composite hardware; single pack
1/1
Accessories
Part Number Product Description Units per
Delivery
TKT-ANAEROBIC2 Installation Kit for Anaerobic and Anaerobic Glass-Insert
Connectors (GIC)
1/1
TKT-ANAEROBIC2-C Installation Kit for Anaerobic and Anaerobic Glass-insert
Connectors (GIC), includes consumables for up to 500 con-
nectors
1/1
3201031-01 Crimp Tool, FC/SC/ST® Compatible, 1.6 mm / 2.0 mm / 3.0
mm
1/1
3201032-01 Crimp Tool, LC, 3.0 mm 1/1
2104459-01 Polishing Fixture LC 1/1
2104020-01 Universal Polishing Puck 1/1
1101045-01 Anaerobic Adhesive, Primer and Syringe Tips for 500 con-
nectors
1/1
CLEANER-UNIV-CASS Universal Connector Cleaning Cassette, offers more than
500 cleanings
1/1
Anaerobic-Cure Connectors
Family Spec Sheet 0251_NAFTA_AEN
Page 4 | Revision date 2014-05-14
Accessories
Part Number Product Description Units per
Delivery
TRIGGER-BP-D Connector Trigger, LC, bulk pack, duplex, white 50/1
95-400-03-BP Connector Trigger, SC, bulk pack, duplex 50/1
Anaerobic-Cure Connectors
Family Spec Sheet 0251_NAFTA_AEN
Page 5 | Revision date 2014-05-14
Corning Optical Communications LLC • PO Box 489 • Hickory, NC 28603-0489 USA
800-743-2675 • FAX: 828-325-5060 • International: +1-828-901-5000 • www.corning.com/opcomm
A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks.
Corning Optical Communications is ISO 9001 certified. © 2014 Corning Optical Communications. All rights reserved.
