Pricing Guide

AC Drives And Soft Starts

Pricing Guide

8800PL9701R06/09

2009

Class 8800

Altivar 21

S-Flex

Altivar 61

PowerGard

E-Flex

Altistart 01

Altistart 48

Altivar 11 Enclosed 48

Altivar 71

CONTENTS

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page

AC Drives and Soft Starts

AC Drive Products for Centrifugal Pumps and Fans

(for Variable Torque Applications)

Altivar® 21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Altivar® 61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

S-Flex™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

E-Flex™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

M-Flex™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

PowerGard™ Series C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

AC Drive Products for Applications Such As: Conveyors, Mixers, Extruders

and Material Handling (for Constant Torque Applications)

Altivar® 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Altivar® 31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Altivar® 71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

M-Flex™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

AC Soft Start Products for Reduced Voltage Control

(for use in Variable Torque or Constant Torque Applications)

Altstart® 01 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Altstart® 48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Enclosed 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Line Reactors and Motor Protection Output Filters. . . . . . . . . . . . . . . . . . 56

Renewal Parts List

Altivar® 61-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Altivar® 58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Altistart® 48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Auxiliary Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Prices subject to change without notice.

06/2009

Pricing Guide AC Drives and Soft Starts

Altivar® 21

aThese horsepower, wattage and continuous ampere ratings apply to default switching frequency and maximum 40°C ambient. Refer to the installation

manual for derating curves as a function of switching frequency, ambient temperature, and mounting conditions.

bOpen type Altivar 21 Drives can be installed as UL Type 1 with an optional conduit box when following instruction in the Installation Manual.

cFor ATV21 with Class B EMC filter, add the letter “C” to the end of the standard catalog number and multiply $ Price by 1.3.

aAltivar 21 PC Soft can be downloaded free of charge from www.schneider-electric.com.

Table 1: Altivar® 21 Selection and Pricing (for Variable Torque applications only)

Input Line

Voltage

Three Phase Motor PoweraOpen DrivesbIP54/UL Type 12 Enclosed

HP kW AaCatalog Number $ Price Catalog Number Class A EMC

$ Pricec

208/240 Vac

Three Phase

1 0.75 4.6 ATV21H075M3X 309.00 ——

2 1.5 7.5 ATV21HU15M3X 400.00 ——

3 2.2 10.6 ATV21HU22M3X 454.00 ——

— 3 13.7 ATV21HU30M3X 555.00 ——

5 4 16.7 ATV21HU40M3X 618.00 ——

7.5 5.5 24.2 ATV21HU55M3X 799.00 ——

10 7.5 32 ATV21HU75M3X 963.00 ——

15 11 46.2 ATV21HD11M3X 1225.00 ——

20 15 61 ATV21HD15M3X 1532.00 ——

25 18.5 74.8 ATV21HD18M3X 1795.00 ——

30 22 88 ATV21HD22M3X 2188.00 ——

40 30 117 ATV21HD30M3X 2806.00 ——

400/480 Vac

Three

Phase

1 0.75 2.2 ATV21H075N4 400.00 ATV21W075N4 500.00

2 1.5 3.7 ATV21HU15N4 472.00 ATV21WU15N4 590.00

3 2.2 5.1 ATV21HU22N4 545.00 ATV21WU22N4 681.00

— 3 7.2 ATV21HU30N4 618.00 ATV21WU30N4 772.00

5 4 8.2 ATV21HU40N4 654.00 ATV21WU40N4 817.00

7.5 5.5 12 ATV21HU55N4 798.00 ATV21WU55N4 998.00

10 7.5 16 ATV21HU75N4 946.00 ATV21WU75N4 1183.00

15 11 22.5 ATV21HD11N4 1145.00 ATV21WD11N4 1489.00

20 15 30.5 ATV21HD15N4 1425.00 ATV21WD15N4 1853.00

25 18.5 37 ATV21HD18N4 1705.00 ATV21WD18N4 2131.00

30 22 43.5 ATV21HD22N4 1856.00 ATV21WD22N4 2412.00

40 30 58.5 ATV21HD30N4 2284.00 ATV21WD30N4 2855.00

50 37 79 ATV21HD37N4 2686.00 ATV21WD37N4 3358.00

60 45 94 ATV21HD45N4 3372.00 ATV21WD45N4 4215.00

75 55 116 ATV21HD55N4 3883.00 ATV21WD55N4 4853.00

100 75 160 ATV21HD75N4 4433.00 ATV21WD75N4 5541.00

Table 2: Altivar 21 Options

Description For Use on Drives Catalog Number $ Price

User Interface Kits

Remote Keypad

Display Mounting Kit Includes remote, keypad, remote mounting hardware and 3 meter cable. ATV21 all ranges VW3A21101 200.00

PCSoft

Software OptionsaCable connection kit for PC ATV21 VW3A8106 75.00

Communication Card Kits

LONWORKS This card is equipped with a removable 3-way screw terminal block. ATV21 all ranges VW3A21312 375.00

METASYS N2 This card is equipped with a removable 4-way screw terminal block. ATV21 all ranges VW3A21313 185.00

APOGEE FLN P1 This card is equipped with a removable 4-way screw terminal block. ATV21 all ranges VW3A21314 185.00

BACnet This card is equipped with a remote 4-way screw terminal block. ATV21 all ranges VW3A21315 185.00

Table 3: Conduit Entrance Kits for ATV 21

Description For use With Altivar 21 Catalog Number $ Price

Multiple knockout sizes

Installation of conduit entrance kit and retention of vent cover on top of

drive controller provides the ATV21with UL Type 1 rating

ATV21H075M3X, ATV21HU15M3X, ATV21HU22M3X,

ATV21H075N4, ATV21HU15N4, ATV21HU22N4 VW3A31814 45.00

ATV21HU30M3X, ATV21HU40M3X, ATV21HU30N4,

ATV21HU40N4, ATV21HU55N4 VW3A31815 45.00

ATV21HU55M3X, ATV21HU75M3X, ATV21HU75N4,

ATV21HD11N4 VW3A31816 45.00

ATV21HD11M3X, ATV21HD15M3X, ATV21HD18M3X,

ATV21HD15N4, ATV21HD18N4 VW3A31817 45.00

ATV21HD22M3X, ATV21HD22N4, ATV21HD30N4 VW3A9206 65.00

ATV21HD37N4, ATV21HD45N4 VW3A9207 65.00

ATV21HD30M3X, ATV21HD55N4, ATV21HD75N4 VW3A9208 135.00

ATV21H

Open Type Drive

ATV21W

IP54 / UL Type 12

CP4B Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drives and Soft Starts

Altivar® 61 – Class 8800

aOption to have product treated for increased protection for dusty and corrosive environments. This product is not stocked. Add “S337” to the end of the

catalog number and multiply the listed price by 1.2 to obtain new price. With this option, exposed copper is tinned, circuit boards are conformal coated

in critical areas and plastics are treated to better withstand the corrosive nature of certain oils. This option is standard on 55 kW/75 hp @ 230 Vac and

higher and

90 kW/125 hp @ 460 Vac and higher.

bThese products require a user supplied 3% line reactor when used with single-phase input.

cProduct does not contain an EMC filter.

dProduct ships with a DC choke that must be field mounted. A 5% line reactor may be purchased and installed in place of the DC choke. Add “D” to the

end of the catalog number to receive just the AC drive and multiply the listed price by .96 to obtain new price.

eThese products can be ordered with Lonworks® or BACnet communication option card shipped as one line item. Field installation required. Add “LW” to

the end of the part number to receive a Lonworks® option card. Add $550 to the list price. Add “BN” to the end of the part number to receive a BACnet

option card. Add $225 to the list price.

fThese products do not contain a dynamic braking transistor. A separate transistor must be added for applications requiring dynamic braking.

gWhen ordering replacements for Square D E-Flex, MCC and M-Flex containing the Altivar 61 drive, identify the replacement catalog number by referring

to the applicable instruction manual, the side nameplate on power converter, or using the graphic keypad (menu 1.11 identification).

hOption to have product treated for increased protection for dusty and corrosive environments. This product is not stocked. Add “337” to the end of the

catalog number and multiply the listed price by 1.2 to obtain new price. With this option, exposed copper is tinned, circuit boards are conformal coated

in critical

areas and plastics are treated to better withstand the corrosive nature of certain oils. This option is standard on 55 kW/75 hp @ 230 Vac and higher and

90 kW/125 hp @ 460 Vac and higher.

Table 4: Altivar® 61 Selection and Pricing

Input

Line

Voltage

Variable Torque

Catalog Number

with LCD Keypad

(Stocked)

$ Price

Catalog Numer

to have ATV61 and Type 1

conduit \entry kit shipped

as one line item.

Field installation required

(Packaged as kit at

warehouse).

$ Price

Catalog Number

with LED

Keypad

(Non-stocked)

$ Price

Three-Phase

Motor Power

Continuous

Output

Current

hp kW A

208/240 Vac

Single

Phase

0.5 0.37 3 ATV61H075M3aeg 639. ATV61H075M3T1e684. ATV61H075M3Z 544.

1 0.75 4.8 ATV61HU15M3aeg 663. ATV61HU15M3T1e708. ATV61HU15M3Z 568.

21.5 8 ATV61HU22M3aeg 764. ATV61HU22M3T1e809. ATV61HU22M3Z 669.

3 2.2 11 ATV61HU30M3aeg 925. ATV61HU30M3T1e970. ATV61HU30M3Z 830.

4 3 13.7 ATV61HU40M3abeg 1035. ATV61HU40M3T1be 1080. ATV61HU40M3Zb940.

5 4 17.5 ATV61HU55M3abeg 1292. ATV61HU55M3T1be 1337. ATV61HU55M3Zb1197.

7.5 5.5 27.5 ATV61HU75M3abeg 1586. ATV61HU75M3T1be 1631. ATV61HU75M3Zb1491.

208/240 Vac

Three

Phase

1 0.75 4.8 ATV61H075M3aeg 639. ATV61H075M3T1e684. ATV61H075M3Z 544.

21.5 8 ATV61HU15M3aeg 663. ATV61HU15M3T1e708. ATV61HU15M3Z 568.

3 2.2 11 ATV61HU22M3aeg 764. ATV61HU22M3T1e809. ATV61HU22M3Z 669.

4 3 13.7 ATV61HU30M3aeg 925. ATV61HU30M3T1e970. ATV61HU30M3Z 830.

5 4 17.5 ATV61HU40M3aeg 1035. ATV61HU40M3T1e1080. ATV61HU40M3Z 940.

7.5 5.5 27.5 ATV61HU55M3aeg 1292. ATV61HU55M3T1e1337. ATV61HU55M3Z 1197.

10 7.5 33 ATV61HU75M3aeg 1586. ATV61HU75M3T1e1631. ATV61HU75M3Z 1491.

15 11 54 ATV61HD11M3Xcegh 2011. ATV61HD11M3XT1ce 2056. ATV61HD11M3XZc1916.

20 15 66 ATV61HD15M3Xcegh 2525. ATV61HD15M3XT1ce 2570. ATV61HD15M3XZc2430.

25 18 75 ATV61HD18M3Xcegh 2943. ATV61HD18M3XT1ce 3008. ——

30 22 88 ATV61HD22M3Xcegh 3586. ATV61HD22M3XT1ce 3651. ——

40 30 120 ATV61HD30M3Xcegh 4599. ATV61HD30M3XT1ce 4684. ——

50 37 144 ATV61HD37M3Xcegh 5342. ATV61HD37M3XT1ce 5427. ——

60 45 176 ATV61HD45M3Xcegh 6326. ATV61HD45M3XT1ce 6411. ——

75 55 221 ATV61HD55M3Xcdegh 7806. ATV61HD55M3XT1ce 8266. ——

100 75 285 ATV61HD75M3Xcdegh 9379. ATV61HD75M3XT1ce 9839. ——

125 90 359 ATV61HD90M3Xcdegh 11954. ATV61HD90M3XT1ce 12507. ——

400/480 Vac

Three

Phase

1 0.75 2.3 ATV61H075N4aeg 754. ATV61H075N4T1e799. ATV61H075N4Z 659.

2 1.5 4.1 ATV61HU15N4aeg 857. ATV61HU15N4T1e902. ATV61HU15N4Z 762.

3 2.2 5.8 ATV61HU22N4aeg 999. ATV61HU22N4T1e1044. ATV61HU22N4Z 904.

4 3 7.8 ATV61HU30N4aeg 1125. ATV61HU30N4T1e1170. ATV61HU30N4Z 1030.

5 4 10.5 ATV61HU40N4aeg 1158. ATV61HU40N4T1e1203. ATV61HU40N4Z 1063.

7.5 5.5 14.3 ATV61HU55N4aeg 1299. ATV61HU55N4T1e1344. ATV61HU55N4Z 1204.

10 7.5 17.6 ATV61HU75N4aeg 1578. ATV61HU75N4T1e1623. ATV61HU75N4Z 1483.

15 11 27.7 ATV61HD11N4aeg 1868. ATV61HD11N4T1e1913. ATV61HD11N4Z 1773.

20 15 33 ATV61HD15N4aeg 2322. ATV61HD15N4T1e2367. ATV61HD15N4Z 2227.

25 18 41 ATV61HD18N4aeg 2795. ATV61HD18N4T1e2840. ATV61HD18N4Z 2700.

30 22 48 ATV61HD22N4aeg 3042. ATV61HD22N4T1e3107. ATV61HD22N4Z 2947.

40 30 66 ATV61HD30N4aeg 3744. ATV61HD30N4T1e3809. ATV61HD30N4Z 3649.

50 37 79 ATV61HD37N4aeg 4403. ATV61HD37N4T1e4468. ATV61HD37N4Z 4308.

60 45 94 ATV61HD45N4aeg 5528. ATV61HD45N4T1e5563. ATV61HD45N4Z 5433.

75 55 116 ATV61HD55N4aeg 6365. ATV61HD55N4T1e6500. ATV61HD55N4Z 6270.

100 75 160 ATV61HD75N4aeg 7267. ATV61HD75N4T1e7402. ATV61HD75N4Z 7172.

125 90 179 ATV61HD90N4deg 7988. ATV61HD90N4T1e8448. ——

150 110 215 ATV61HC11N4deg 9022. ATV61HC11N4T1e9575. ——

200 130 259 ATV61HC13N4deg 10366. ATV61HC13N4T1e10939. ——

250 160 314 ATV61HC16N4deg 11711. ATV61HC16N4T1e12299. ——

350 220 427 ATV61HC22N4deg 13993. ATV61HC22N4T1e14581. ——

400 250 481 ATV61HC25N4defg 16475. ATV61HC25N4T1e17079. ——

500 315 616 ATV61HC31N4defg 23734. ATV61HC31N4TI 24338. ——

600 400 759 ATV61HC40N4defg 31783. ————

700 500 941 ATV61HC50N4defg 44235. ————

900 630 1188 ATV61HC63N4defg 63935. ————

CP4B Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drives and Soft Starts

Altivar® 61 – Class 8800

aConformal coating is standard.

bAn AC 5% line reactor is mandatory.

cThese products do not contain a dynamic braking transistor. A separate transistor must be added for applications requiring dynamic braking.

Altivar® 61 Selection and Pricing (continued)

Input Line Voltage

Variable Torque

Catalog Number with LCD Keypad

(Stocked)

$ Price

Three-Phase Motor Power Continuous Output Current

hp kW A

575/690 Vac

Three-Phase

3 3 3.9 ATV61HU30Ya1889.00

4 4 5.8 ATV61HU40Ya1990.00

5 5.5 6.1 ATV61HU55Ya2099.00

7.5 7.5 9 ATV61HU75Ya2380.00

10 11 11 ATV61HD11Ya2799.00

15 15 17 ATV61HD15Ya3380.00

20 18.5 22 ATV61HD18Ya3979.00

25 22 27 ATV61HD22Ya4790.00

30 30 32 ATV61HD30Ya5780.00

40 37 41 ATV61HD37Ya6999.00

50 45 52 ATV61HD45Ya8579.00

60 55 62 ATV61HD55Ya10379.00

75 75 77 ATV61HD75Ya12199.00

100 90 99 ATV61HD90Ya14399.00

125 110 125 ATV61HC11Yab 16899.00

150 132 150 ATV61HC13Yab 19179.00

— 160 180 ATV61HC16Yab 20795.00

200 200 220 ATV61HC20Yab 24290.00

250 250 290 ATV61HC25Yabc 28950.00

350 315 355 ATV61HC31Yabc 35950.00

450 400 420 ATV61HC40Yabc 46750.00

550 500 543 ATV61HC50Yabc 59590.00

700 630 675 ATV61HC63Yabc 78490.00

800 800 840 ATV61HC80Yabc 103390.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drives and Soft Starts

Altivar® 61 and Altivar 71

Table 5: Options—Field Installed

Description For Use on Drives Catalog No. $ Price

Operator

Interface

LCD graphic keypad: IP54 rating

any ATV61

any ATV71

VW3A1101 115.00

Remote mounting kit: includes bezel and mounting hardware VW3A1102 55.00

Door for use with remote mount kit for IP65 rating VW3A1103 45.00

Cable for remote mounting LCD graphic

keypad

RJ-45 connector on each end

1 meter VW3A1104R10 35.00

3 meters VW3A1104R30 35.00

5 meter VW3A1104R50 35.00

10 meters VW3A1104R100 45.00

RJ-45 female—female adaptor to connect LCD keypad and cable. Not

required if using VW3A1102. VW3A1105 35.00

PowerSuite™

Software Options

PowerSuite™ software on CD for PC Altivar AC drives

Altistart 48

Tesys U–line

VW3A8104 150.00

Cable connection kit for PC VW3A8106 75.00

For Wireless

Connection Modbus® to Bluetooth® Gateway and RS-485 converter any ATV61

any ATV71 VW3A8114 125.00

I/O Adaptor 115 Vac logic input adaptor adapts 7 logic inputs for use with

user supplied 115 Vac signals

any ATV61

any ATV71 VW3A3101 195.00

I/O Extension

Option Cards

Basic I/O option card—4 logic inputs, 2 logic outputs, 1 Form C relay

output, an input for PTC motor probes, a 24 Vdc output, a—10 Vdc output any ATV61

any ATV71

VW3A3201 165.00

Extended I/O option card—contains all the I/O on the Basic I/O option

card plus 2 analog inputs, 2 analog outputs, 1 pulse input VW3A3202 195.00

CANopen

Adapter

This adaptor connects to the RJ-45 port and provides a 9–pin male SUB–

D connector conforming to the CANopen standard

(CIA DRP 303–1)

any ATV61

any ATV71 VW3CANA71 45.00

CANopen

Connector

9-pin female SUB–D with line terminator (can be disabled). 180º cable

outlet CAN–H, CAN–L, CAN–GND connection

any ATV61

any ATV71 VW3CANKCDF180T 45.00

Incremental

Encoder

Interface

Option Cards

with RS-422 outputs, 5 Vdc

any ATV71

VW3A3401 85.00

with RS-422 outputs, 15 Vdc VW3A3402 85.00

with open collector outputs, 12 Vdc VW3A3403 85.00

with open collector outputs, 15 Vdc VW3A3404 85.00

with push–pull outputs, 12 Vdc VW3A3405 85.00

with push–pull outputs, 15 Vdc VW3A3406 85.00

with push–pull outputs, 24 Vdc VW3A3407 85.00

Resolver VW3A3408 85.00

Universal with SinCos, SinCos Hiperface®, SinCos EnDat® or SSI output VW3A3409 85.00

incremental with RS422 outputs and encoder emulation VW3A3411 85.00

Communication

Option Cards

Modbus® Plus card

any ATV61

any ATV71

VW3A3302 550.00

Modbus® / Unitelway card VW3A3303 225.00

Modbus® TCP/IP Daisy Chain VW3A3310D 275.00

Interbus® S card VW3A3304 550.00

Profibus DP card VW3A3307 550.00

Profibus DPv1 card VW3A3307S371 550.00

DeviceNet™ card VW3A3309 225.00

Ethernet/IP card VW3A3316 275.00

Fipio® card VW3A3311 550.00

Lonworks® card

any ATV61

VW3A3312 550.00

MetaSYS® N2 card VW3A3313 225.00

APOGEE FLN P1 card VW3A3314 225.00

BACnet card VW3A3315 225.00

Controller Inside

Option Card

Programmable option card, conforms with IEC61131–3 programming

standard.

any ATV61

any ATV71 VW3A3501 550.00

Water Solutions

Control Card

This option card contains a variety of pre-programmed functions and

features to manage multi–pump installations.

any ATV61

any ATV71 VW3A3503 650.00

Simple Loader Using RJ45 port connections, the configurations of a drive can be

downloaded then uploaded to compatible drive. ATV31,ATV61 and ATV71 VW3A8120 175.00

The drive cannot support the VW3A3503 water solutions card and the VW3A3501 controller inside option card simultaneously.

For use with the ATV71H...383 drive ONLY.

LCD Keypad

Mounting Kits

Option Card Assembly

I/O Option Card

Communication

Option Card

Incremental

Encoder Interface

Option Card

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drives and Soft Starts

Altivar® 61 and Altivar 71

Options—Field Installed (continued)

Description For Use on Drives Catalog No. $ Price

Fan Kit

Installation of kit enables the drive to operate in higher ambient

temperatures. Fan mounts on drive. Consult the product catalog for

more information.

ATV61/71HD18M3X...HD22M3X,

ATV61/71HD22N4 VW3A9404 135.00

ATV61/71HD30N4...HD37N4 VW3A9405 145.00

ATV61/71HD30M3X...HD45M3X VW3A9406 165.00

ATV61/71HD45N4...HD75N4 VW3A9407 195.00

Description

ATV61: Options and Accessories — Variable Torque Applications

ATV58 Drive Replaced by Reference Mounting

Plate $ Price

Mounting

Plate Kit

Kit includes: Mechanical adaptors required

for mounting and Altivar 61/71 drive in the

place of an Altivar 58 or Altivar 58F drive

using same holes.

Single-phase supply voltage: 200…240V 50/60 Hz

ATV58HU09M2ZU ATV61H075M3 VW3A9301 83.00

ATV58HU18M2ZU ATV61HU15M3 VW3A9301 83.00

ATV58HU29M2ZU ATV61HU22M3 VW3A9303 83.00

ATV58HU41M2ZU ATV61HU30M3 VW3A9303 83.00

ATV58HU72M2ZU ATV61HU40M3 VW3A9304 93.00

ATV58HU90M2ZU ATV61HU55M3 VW3A9306 133.00

ATV58HD12M2ZU ATV61HU75M3 VW3A9307 133.00

Three-phase supply voltage 200…240 V 50/60 hz

ATV58HU29M2ZU ATV61HU15M3 VW3A9302 83.00

ATV58HU41M2ZU ATV61HU22M3 VW3A9303 83.00

ATV58HU54M2ZU ATV61HU30M3 VW3A9304 93.00

ATV58HU72M2ZU ATV61HU40M3 VW3A9304 93.00

ATV58HU90M2ZU ATV61HU55M3 VW3A9306 133.00

ATV58HD12M2ZU ATV61HU75M3 VW3A9307 133.00

ATV58HD16M2XZU ATV61HD11M3X VW3A9309 170.00

ATV58HD16M2XZU ATV61HD15M3X VW3A9309 170.00

ATV58HD23M2XZU ATV61HD18M3X VW3A9310 170.00

ATV58HD28M2XZU ATV61HD22M3X VW3A9312 337.00

ATV58HD33M2XZU ATV61HD30M3X VW3A9312 337.00

ATV58HD46M2XZU ATV61HD37M3X VW3A9312 337.00

Three-phase supply voltage: 380…480V 50/60 Hz

ATV58HU18N4ZU ATV61H075N4 VW3A9302 83.00

ATV58HU29N4ZU ATV61HU15N4 VW3A9302 83.00

ATV58HU41N4ZU ATV61HU22N4 VW3A9302 83.00

ATV58HU54N4XZU ATV61HU40N4 VW3A9304 93.00

ATV58HU72N4XZU ATV61HU55N4 VW3A9305 93.00

ATV58HU90N4XZU ATV61HU75N4 VW3A9305 93.00

ATV58HD12N4XZU ATV61HD11N4 VW3A9307 133.00

ATV58HD16N4XZU ATV61HD15N4 not available —

ATV58HD23N4XZU ATV61HD18N4 VW3A9308 138.00

ATV58HD28N4XZU ATV61HD22N4 VW3A9310 170.00

ATV58HD33N4XZU ATV61HD30N4 VW3A9310 170.00

ATV58HD46N4XZU ATV61HD37N4 VW3A9310 170.00

ATV58HD54N4XZU ATV61HD45N4 VW3A9312 337.00

ATV58HD64N4XZU ATV61HD55N4 VW3A9312 337.00

ATV58HD79N4XZU ATV61HD75N4 VW3A9312 337.00

ATV71: Options and Accessories – Constant Torque Applications

ATV58 Drive Replaced by Reference Mounting

Plate $ Price

Single-phase supply voltage: 200…240V 50/60 Hz

ATV58HU09M2ZU ATV71H075M3 VW3A9301 83.00

ATV58HU18M2ZU ATV71HU15M3 VW3A9301 83.00

ATV58HU29M2ZU ATV71HU22M3 VW3A9303 83.00

ATV58HU41M2ZU ATV71HU30M3 VW3A9303 83.00

ATV58HU72M2ZU ATV71HU40M3 VW3A9304 93.00

ATV58HU90M2ZU ATV71HU55M3 VW3A9306 133.00

ATV58HD12M2ZU ATV71HU75M3 VW3A9307 133.00

Three-phase supply voltage: 200…240V 50/60 Hz

ATV58HU29M2ZU ATV71HU15M3 VW3A9302 83.00

ATV58HU41M2ZU ATV71HU22M3 VW3A9303 83.00

ATV58HU54M2ZU ATV71HU30M3 VW3A9304 93.00

ATV58HU72M2ZU ATV71HU40M3 VW3A9304 93.00

ATV58HU90M2ZU ATV71HU55M3 VW3A9306 133.00

ATV58HD12M2ZU ATV71HU75M3 VW3A9307 133.00

ATV58HD16M2XZU ATV71HD11M3X VW3A9309 170.00

ATV58HD23M2XZU ATV71HD15M3X VW3A9309 170.00

ATV58HD28M2XZU ATV71HD18M3X VW3A9312 337.00

ATV58HD33M2XZU ATV71HD22M3X VW3A9312 337.00

ATV58HD46M2XZU ATV71HD30M3X VW3A9312 337.00

Three-phase supply voltage 380…480 V 50/60 HZ

ATV58HU18N4ZU ATV71H075N4 VW3A9302 83.00

ATV58HU29N4ZU ATV71HU15N4 VW3A9302 83.00

ATV58HU41N4ZU ATV71HU22N4 VW3A9302 83.00

ATV58HU54N4ZU ATV71HU30N4 VW3A9304 93.00

ATV58HU72N4ZU ATV71HU40N4 VW3A9304 93.00

ATV58HU90N4ZU ATV71HU55N4 VW3A9305 93.00

ATV58HD12N4ZU ATV71HU75N4 VW3A9306 133.00

ATV58HD16N4ZU ATV71HD11N4 VW3A9307 133.00

ATV58HD23N4ZU ATV71HD15N4 VW3A9308 138.00

ATV58HD28N4ZU ATV71HD18N4 VW3A9309 170.00

ATV58HD33N4ZU ATV71HD22N4 VW3A9310 170.00

ATV58HD46N4ZU ATV71HD30N4 VW3A9310 170.00

ATV58HD54N4ZU ATV71HD37N4 VW3A9312 337.00

ATV58HD64N4ZU ATV71HD45N4 VW3A9312 337.00

ATV58HD79N4ZU ATV71HD55N4 VW3A9312 337.00

Verify motor/drive ratings and application for proper replacement selections.

Catalog number may or may not contain an “X” in this position.

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drives and Soft Starts

Altivar® 61 and Altivar 71

aThe symbol “•” indicates the part of the number that varies with controller size or rating.

Options—Field Installed (continued)

Description For Use on Drives Catalog No. $ Price

Flange Kit

Kit includes:

a metal frame, seals, mounting hardware, and

bracket to mount fan kit so fan can be accessed

from the front of the drive template.

Kit used to mount the heatsink of the drive

outside of an enclosure.

ATV61/71H037M3...HU15M3 VW3A9501 255.00

ATV61/71H075N4...HU22N4

ATV61/71HU22M3...HU40M3 VW3A9502 279.00

ATV61/71HU30N4...HU40N4

ATV61/71HU55M3 VW3A9503 325.00

ATV61/71HU55N4, HU75N4

ATV61/71HU75M3 VW3A9504 358.00

ATV61/71HD11N4

ATV61/71HD11M3X..HD15M3X VW3A9505 419.00

ATV61/71HD15N4, HD18N4

ATV61/71HD18M3X..HD22M3X VW3A9506 438.00

ATV61/71HD22N4, ATV61/71HU30Y...HD30Y

ATV61/71HD30N4, HD37N4 VW3A9507 469.00

ATV61/71HD30M3X..HD45M3X VW3A9508 469.00

ATV61/71HD45N4...HD75N4, ATV61/71HD37Y...HD90Y VW3A9509 477.00

ATV61HD55M3X...HD75M3X

ATV61HD90N4...HC11N4 VW3A9510 500.00

ATV71HD55M3X, ATV71HD90N4

ATV61HD90M3X, ATV61HC13N4 VW3A9511 667.00

ATV71HD75M3X, ATV71HC11N4

ATV61HC16N4, ATV61HC20Y, ATV61/71HC11Y...HC16Y,

ATV71HC13N4 VW3A9512 1053.00

ATV61HC22N4, ATV71HC16N4 VW3A9513 1053.00

ATV61HC25N4…HC31N4

ATV61HC40Y

ATV61/71HC25Y, HC31Y

ATV71HC20N4...HC28N4

ATV71HC20Y

VW3A9514 1053.00

ATV61HC25N4…HC31N4 with VW3A7101 braking transistor

ATV61HC40Y

ATV61/71HC25Y, HC31Y

ATV71HC20N4...HC28N4 with VW3A7101 braking transistor

ATV71HC20Y

VW3A9515 1062.00

Type 1

Condiut Kit

Kit includes:

a metal box, with conduit knockouts

Kit provides conduit landing when wall mounting

the drive

ATV61/71H037M3...HU15M3 VW3A9201 45.00

ATV61/71H075N4...HU22N4

ATV61/71HU22M3...HU40M3 VW3A9202 45.00

ATV61/71HU30N4...HU40N4

ATV61/71HU55M3 VW3A9203 45.00

ATV61/71HU55N4, HU75N4

ATV61/71HU75M3 VW3A9204 45.00

ATV61/71HD11N4

ATV61/71HD11M3X..HD15M3X VW3A9205 45.00

ATV61/71HD15N4, HD18N4

ATV61/71HD18M3X..HD22M3X

VW3A9206 65.00ATV61/71HD22N4

ATV61/71HU30Y...HD30Y

ATV61/71HD30N4, HD37N4 VW3A9207 65.00

ATV61/71HD30M3X..HD45M3X VW3A9217 85.00

ATV61/71HD45N4..HD75N4 VW3A9208 135.00

ATV61/71HD37Y...HD90Y

ATV61HD55M3X...HD75M3X

ATV61HD90N4...HC11N4 VW3A9209 460.00

ATV71HD55M3X, ATV71HD90N4, ATV61HC11N4

ATV61HD90M3X, ATV61HC13N4 VW3A9210 553.00

ATV71HD75M3X, ATV71HC11N4

ATV61HC16N4, ATV71HC13N4

VW3A9211 573.00ATV61/71HC11Y...HC16Y

ATV61HC20Y

ATV61HC22N4, ATV71HC16N4 VW3A9212 588.00

ATV61HC25N4...ATV61HC31N4

ATV71HC20N4...HC28N4

VW3A9213 604.00

ATV71HC20Y

ATV61/71HC25Y, HC31Y

ATV61HC40Y

ATV61HC25N4...HC31N4 with VW3A7101 braking transistor

ATV71HC20N4...HC28N4 with VW3A7101 braking transistor

VW3A9214 604.00

ATV71HC20Y

ATV61/71HC25Y, HC31Y

ATV61HC40Y

Profibus

Option Card

Cover

Type 1 cover for Profibus Option Card

230V Drive controllers 480V Drive controllers

ATV61H••••aATV71H•••• ATV61H•••• ATV71H••••

075M3 037M3 075N4 075N4

VW3A9201PF 101.00U15M3 075M3 U15N4 U15N4

— U15M3 U22N4 U22N4

U22M3 U22M3 U30N4 U30N4

VW3A9292PF 102.00U30M3 U30M3 U40N4 U40N4

U40M3 U40M3 — —

U55M3 U55M3 U55N4 U55N4 VW3A9203PF 104.00

— — U75N4 U75N4

U75M3 U75M3 D11N4 D11N4 VW3A9204PF 107.00

D11M3X D11M3X D15N4 D15N4 VW3A9205PF 112.00

D15M3X D15M3X D18N4 D18N4

Flange Kit VW3A9506

CP4B Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drives and Soft Starts

S-Flex™ 21

Variable Torque AC Drive —208 V, and 460 V Ratings

aWhen ordering a Non-Bypass unit insert a "W" in place of the "Y" in the Catalog Number.

bOptions A07 Disconnect Switch and B07 Line Contactor are available only when a full voltage bypass standard "Y" product is selected. Options A07 and

B07 are mutually exclusive.

aMiscellaneous Options A06, B06, C06, and D06 are mutually

exclusive. Add Misc. Option number to S-Flex™ 21 Catalog Number

when ordering communications card factory installed.

bCan be downloaded from the internet at www.Schneider-Electric.com

AFC

S-Flex™ 21 Enclosed

Drive Controller Type 1

Rated +14 to +140°F

(-10 to +40°C)

Power Circuit Y

Bypass Package

Table 6: S-Flex™ 21 Enclosed Drive Selection and Pricing

Input Line

Vol tage hp kW

Output Current

Catalog

Number

Standard

Product List

$ Price

Options

Non-Bypass Disc Switch Line

Contactor

AMOD W

Price $a

MOD A07

Price $b

MOD B07

Price $b

208 Vac

Three-phase

1 0.75 4.8 SFD21CG2Y 1402.00 1048.00 1584.00 1480.00

2 1.5 7.8 SFD21DG2Y 1501.00 1123.00 1689.00 1585.00

3 2.2 11 SFD21EG2Y 1593.00 1193.00 1784.00 1682.00

5 4 17.5 SFD21FG2Y 1789.00 1342.00 1992.00 1889.00

7.5 5.5 25.3 SFD21GG2Y 1957.00 1468.00 2177.00 2066.00

10 7.5 32.2 SFD21HG2Y 2253.00 1700.00 2478.00 2378.00

15 11 48.3 SFD21JG2Y 2758.00 2089.00 3023.00 2886.00

20 15 62.1 SFD21KG2Y 3169.00 2389.00 3476.00 3316.00

25 18.5 78.2 SFD21LG2Y 3865.00 2910.00 4240.00 4044.00

30 22 92 SFD21MG2Y 4705.00 3542.00 5171.00 4950.00

40 30 120 SFD21NG2Y 5920.00 4911.00 6370.00 6294.00

230 Vac

Three-phase

1 0.75 4.2 SFD21CG3Y 1402.00 1048.00 1584.00 1480.00

2 1.5 6.8 SFD21DG3Y 1501.00 1123.00 1689.00 1585.00

3 2.2 9.6 SFD21EG3Y 1593.00 1193.00 1784.00 1682.00

5 4 15.2 SFD21FG3Y 1789.00 1342.00 1992.00 1889.00

7.5 5.5 22 SFD21GG3Y 1957.00 1468.00 2177.00 2066.00

10 7.5 28 SFD21HG3Y 2253.00 1700.00 2478.00 2378.00

15 11 42 SFD21JG3Y 2758.00 2089.00 3023.00 2886.00

20 15 54 SFD21KG3Y 3169.00 2389.00 3476.00 3316.00

25 18.5 68 SFD21LG3Y 3865.00 2910.00 4240.00 4044.00

30 22 80 SFD21MG3Y 4705.00 3542.00 5171.00 4950.00

40 30 104 SFD21NG3Y 5920.00 4911.00 6370.00 6294.00

460 Vac

Three-phase

1 0.75 2.1 SFD21CG4Y 1250.00 880.00 1314.00 1289.00

2 1.5 3.4 SFD21DG4Y 1317.00 928.00 1384.00 1358.00

3 2.2 4.8 SFD21EG4Y 1419.00 1000.00 1491.00 1463.00

5 4 7.6 SFD21FG4Y 1554.00 1095.00 1633.00 1602.00

7.5 5.5 11 SFD21GG4Y 1690.00 1190.00 1776.00 1742.00

10 7.5 14 SFD21HG4Y 1892.00 1333.00 1988.00 1950.00

15 11 21 SFD21JG4Y 2227.00 1624.00 2361.00 2296.00

20 15 27 SFD21KG4Y 2709.00 2060.00 2909.00 2864.00

25 18.5 34 SFD21LG4Y 3229.00 2455.00 3467.00 3409.00

30 22 40 SFD21MG4Y 3749.00 3037.00 3956.00 3903.00

40 30 52 SFD21NG4Y 4359.00 3641.00 4600.00 4538.00

50 37 65 SFD21PG4Y 5347.00 4545.00 5643.00 5567.00

60 45 77 SFD21QG4Y 6257.00 5444.00 6603.00 6514.00

75 55 96 SFD21RG4Y 7102.00 6392.00 7527.00 7379.00

100 75 124 SFD21SG4Y 8097.00 7293.00 8581.00 8413.00

Table 7: Miscellaneous Optionsa

Description Option Number $ Price

BACnet Communication Card A06 185.00

LonWorks N2 Communication Card B06 375.00

Metasys N2 Communications Card C06 185.00

Apogee FLN P1 Communications Card D06 185.00

Modbus Monitoring N06 N/C

Seismic Qualification S07 215.00

Table 8: Accessories

Description Catalog

Number $ Price

Altivar 21 PCSoft software

PC Soft Test and Commissioning Software.

For use with Microsoft Windows 95, 98, NT, XP,

and Vista operating systems for PC’s only. (Cable

not included)

VW3A2104bN/C

PC Cable for Test and Comissioning

Software Includes 3-meter (9.8 ft.) cable,

RS-485/RS-232C adaptor and connectors

VW3A8106 75.00

EZ-M Mounting Channel, 72" length EZM72MC 42.00

CP4C Discount

Schedule

All S-Flex™ 21 Enclosed Drives are supplied with:

•Altivar® 21 power converter

•Square D® circuit breaker disconnect (Power Fuses for 460 V

version only)

•UL508C coordinated short circuit rating for 100,000 A

•Adjustable Frequency Controller-Off-Bypass selector switch

•Local/Remote configurable on controller

•Power On red LED

•Bypass Run green LED

•Fire/Freezestat interlock for Adjustable Frequency Drive and

Bypass mode

•Form C Adjustable Frequency Controller fault auxiliary contact

•Modbus RJ-45 communication port

•Smoke Purge Function

•Bypass Run Auxiliary Contact

•Drive Run Auxiliary Contact

•Full Voltage Bypass Power Circuit with overload relay

•120 Vac fused control power transformer

Prices subject to change without notice.

06/2009

Pricing Guide AC Drives and Soft Starts

E-Flex™ AC Drives – Class 8839

Variable Torque AC Drive—208, 230 V and 460 V Ratings

Note: Standard packages are rated 100 k AIC

aControl Option C07 (Start–Stop, Speed Potentiometer)

is not compatible with Power Circuit Y Bypass or Light

Option A08 or B08.

bLight Options A08, B08 and C08 cannot be selected

together. Select only one.

cLight Option B08 (Power On, Run, Fault, Bypass) is not

compatible with Power Circuit W Without Bypass.

dMisc. Option B09 Line Contactor is not compatible with

Power Circuit W (Without Bypass).

eMisc. Option E09 Smoke Purge (Fireman’s Override)

permits motor to run at full speed.

fHand–Off—Auto switch must be placed in off position

for AFC fault reset.

gWhen Power Circuit Y Bypass selected, AFC–Off–

Bypass switch and Test–Normal switch is supplied.

hWhen communication options are selected, Control

Option D07 or E07 must be selected for control.

iMisc. Option C09 3–15 PSI Transducer is not

compatible with Control Options C07, D07 or E07, J09

0–10 Vdc Auto Speed Reference Option, H09 I/O

Extension Card, F09, L09, M09, O09, P09, Q09, R09

Serial Communication Cards

jMisc. Option H09 I/O Extension Card is not compatible

with

C09 3–15 PSI Transducer or Serial Comunications

Cards F09, L09, M09, O09, P09, Q09, or R09.

kMisc. Option J09 input programmed for 0–10 Vdc is not

compatible with Control Options C07, D07 or E07

Control Options or Misc. Option C09 3–15 PSI

Transducer.

lOmit the Keypad Option D09 from Enclosure Door. User

must buy a separate device to program the controller

inside.

mSerial Communication Options F09, L09, M09, O09,

P09, Q09, R09 cannot be selected together. Select only

one. Serial Communications and Misc. Option H09 are

not compatible. Control Option D07 or E07 must be

selected for monitoring and control with Serial

Communication Options.

nLight Option A08 is compatible with Control Options

A07, B07, D07 and E07.

oMisc. Option S09 End Damper Control is not compatible

with Control Options D07 Hand–Off–Comm, Speed Pot.

Or E07 Hand–Off–Comm, Start–Stop, Speed Pot.

pMisc. Option B09 Line Contactor is not compatible with

H03 Type 3R Enclosure.

qOption T09 service entrance rating and K09 (cUL) are

mutually exclusive.

NOTE: Order part numbers by using the

Product Selectors.

E-Flex devices are supplied with:

•Circuit breaker as the overcurrent protective

device (OCPD) and have a corrdinated short

circuit current rating of 100,000 A symmetrical.

•Equivalent 3% DC choke is standard. Option A09

replaces DC choke with 5% line reactor.

•Fire/Freezestats interlock locations wired to

customer terminal strip

•One Form C AFC run mode conrtact

•One Form C AFC Fault contact

•Circuit Breaker Disconnect

•Analog Output terminals on terminal strip (A01

and COM)

•Modbus and CANopen communications built into

Drive. Modbus Unitelway card option provides

Modbus ASCII and 4 wire RS485 functions.

•Speed Potentiometer as part of keypad or

separately mounted on the enclosure door

hp Output Amperes

208 V 230 V 460 V

1 4.6 4.2 2.1

2 7.5 6.8 3.4

3 10.6 9.6 4.8

516.715.27.6

7.5 24.2 22 11

10 30.8 28 14

15 46.2 42 21

20 59.4 54 27

25 74.8 68 34

30 88 80 40

40 114 104 52

50 143 130 65

60 — — 77

75 — — 96

100 — — 124

Type 1

Drive Controller

Rated -10 to 40°C

Type 3R

Drive Controller

Rated -10 to 50°C

AFC

Power

Circuit Y

AFC

Power

Circuit W

Class Type Modifications

Control Lights Misc

8839 EFD V A07

1 23456 7 8 9

Table 9: E-Flex™ Selection and Pricing

Code

3 Enclosure Type

Vol tage

Code

Aplication

Type

(Applied

Rating

Code)

6 Device Type 9 Miscellaneous Options

208/230 V 460 V W—Without

Bypass Package

Y—Bypass

Packageg

Mod X09

3% Line Reactor

Mod A09

5% Line Reactor

Mod B09

Line Contactor

Type 1

Type

12K

Type 3R G=

Type 1

Type

12K

Type 3R 208/230 V 460 V 208/230 V 460 V 208/230 V 460 V 208/230 V 460 V 208/230 V 460 V

$ Price $ Price $ Price $ Price $ Price $ Price $ Price

C = 1

Included

155.00 1500.00

Included

155.00 1500.00

2 = 208 V

3 = 230 V

4 = 460 V

V=Variable

To r q u e

1561.00 1530.00 1773.00 1739.00 173.00 173.00 216.00 216.00 50.00 50.00

D = 2 155.00 1500.00 155.00 1500.00 1561.00 1653.00 1773.00 1878.00 188.00 188.00 235.00 235.00 50.00 50.00

E = 3 155.00 1500.00 155.00 1500.00 1561.00 1791.00 1773.00 2036.00 188.00 188.00 235.00 235.00 60.00 50.00

F = 5 155.00 1500.00 155.00 1500.00 1766.00 1928.00 2007.00 2191.00 202.00 202.00 253.00 253.00 70.00 50.00

G = 7.5 155.00 1700.00 155.00 1500.00 1887.00 2044.00 2144.00 2323.00 238.00 238.00 298.00 298.00 70.00 60.00

H = 10 155.00 1700.00 155.00 1700.00 2183.00 2226.00 2480.00 2578.00 306.00 306.00 382.00 382.00 90.00 70.00

J = 15 362.00 2625.00 155.00 1700.00 2838.00 2479.00 3225.00 2817.00 315.00 315.00 394.00 394.00 120.00 78.00

K = 20 362.00 2625.00 155.00 1700.00 3621.00 2892.00 4115.00 3286.00 382.00 382.00 478.00 478.00 168.00 90.00

L = 25 362.00 2625.00 155.00 1700.00 3694.00 3083.00 4198.00 3503.00 382.00 382.00 478.00 478.00 195.00 120.00

M = 30 362.00 3750.00 362.00 2625.00 4635.00 3686.00 5267.00 4189.00 398.00 398.00 497.00 497.00 195.00 120.00

N = 40 362.00 3750.00 362.00 2625.00 5850.00 4424.00 6647.00 4800.00 448.00 448.00 560.00 560.00 252.00 168.00

P = 50 362.00 3750.00 516.00 2625.00 7316.00 5222.00 8314.00 5934.00 583.00 583.00 729.00 729.00 364.00 195.00

Q = 60 — — 516.00 3750.00 —6604.00 —7505.00 —583.00 —729.00 —195.00

R = 75 — — 516.00 3750.00 —7372.00 —8378.00 —649.00 —811.00 —252.00

S = 100 — — 516.00 3750.00 —8908.00 —10122.00 —777.00 —971.00 —364.00

7 Control Options

A07fn Hand-Off—Auto, Speed Pot. Included

B07fHand-Off—Auto, Start-Stop, Speed Pot. 100.00

C07aStart-Stop, Speed Pot. 75.00

D07fh Hand-Off-Comm, Speed Pot. N/C

E07fh Hand-Off-Comm, Start-Stop, Speed Pot. 100.00

N07 No operators; wired for remote operation -100.00

8 Light Options

A08bn Power On, Run, Fault, Auto Lights 80.00

B08bc Power On, Run, Fault, Bypass Lights 80.00

C08bPower On, Run, Fault Lights 65.00

9 Miscellaneous Options

A09 5% Line Reactor option See Above

B09dp Line Contactor See Above

C09i3–15 PSI Transducer 180.00

D09lOmit Keypad -40.00

E09eSmoke Purge (Fireman’s Override) 80.00

F09mProfibus DP 400.00

H09jI/O Extension Card, 0–20 mA Output 150.00

J09kInput programmed for 0–10 Vdc N/C

K09 cUL Listing Certification 140.00

L09mLonWorks Card 400.00

M09mModbus / Unitelway Card 165.00

O09mApogee P1 Card 165.00

P09mMetasys N2 Card 165.00

Q09mEthernet TCP/IP 165.00

R09mBACnet Card 165.00

S09oEnd Damper Control 115.00

T09qService entrance rating 185.00

U09 Seismic Qualification 215.00

V09 DeviceNet Option Card 225.00

X09 3% Line Reactor option See Above

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

General Information

M-Flex enclosed adjustable frequency (AC) drive controllers are designed for industrial, commercial and municipal

process applications, where high functionality of features is required. Each M-Flex enclosed drive offers a platform of

standard, engineered and special features to meet the most demanding application and specification requirements.

M-Flex enclosed drive controllers are low voltage products in the following ratings:

Constant torque (Heavy duty ratings – 150% current limit)

•Altivar® 71 power converter

•1 to 450 hp, 460 V

•1 to 40 hp, 208/230 V

Variable torque (Light duty ratings – 110% current limit)

•Altivar® 61 power converter

•1 to 500 hp, 460 V

•1 to 50 hp, 208/230 V

Application Data

The table below outlines typical application characteristics with load requirements and should be used as a guideline

only. This information should be confirmed by the responsible system designer for a designated installation.

aPotential impact load.

b> 150% torque.

c100 to 150% torque.

d< 100% torque.

Application Speed-Torque

Relationship Breakaway Torque

Agitators

Liquid Variable TorqueaModeratec

Slurry Variable TorqueaModeratec

Blowers

Centrifugal Variable Torque Lowd

Positive Displacement Constant Torque Low (Unloaded)d

Calendars Constant Torque Lowd

Card Machines Constant Torque Moderatec

Centrifuges Constant Torque Moderatec

Chippers Constant TorqueaHighb

Compressors

Axial-Centrifugal Variable Torque Lowd

Reciprocating Constant TorqueaModeratec

Rotary Constant Torque Moderatec

Conveyors

Belt Constant Torque Moderatec

Screw Constant TorqueaHighb

Shaker Constant TorqueaModeratec

Cranes

Bridge Constant Torque Moderatec

Trolley Constant Torque Moderatec

Hoist Constant Torque Moderatec

Crushers Constant TorqueaHighb

Drill Presses Constant Horsepower Moderatec

Elevators Constant Torque Moderatec

Extruders Constant Torque Moderatec

Fans-Centrifugal Variable Torque Lowd

Frames-Spinning Constant Horsepower Lowd

Grinders Constant Horsepower Moderatec

Kiln Constant Torque Highb

Looms Constant Torque Moderatec

Lathes Constant HorsepoweraModeratec

Application Speed-Torque

Relationship Breakaway Torque

Machines

Boring Constant Torque Moderatec

Bottling Constant Torque Moderatec

Milling Constant HorsepoweraModeratec

Mills

Rolling Constant TorqueaModeratec

Rubber Constant TorqueaModeratec

Mixers

Chemical Constant Torque Highb

Dough Constant Torque Highb

Slurry Constant Torque Highb

Planers Constant Torque Moderatec

Plows-Conveyor Constant Torque Moderatec

Presses

Printing Constant Torque Moderatec

Punch Constant TorqueaModeratec

Pullers-Car Constant Torque Moderatec

Pumps

Centrifugal Variable Torque Lowd

Positive Displacement Constant Torque Moderatec

Slurry Constant Torque Highb

Roll Benders Constant Torque Moderatec

Sanders Constant Torque Lowd

Saws Constant TorqueaModeratec

Shakers Constant TorqueaHighb

Shears Constant TorqueaLowd

Tension Drives Constant Horsepower Moderatec

Tool Machines Constant Horsepower Moderatec

Walkways Constant Torque Lowd

Winches Constant Torque Moderatec

Winders Constant Horsepower Moderatec

Washers Constant Torque Moderatec

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

Product Selection

To select a M-Flex enclosed drive controller, identify the basic drive and optional devices by Class, Type, Modifications

(MODS, E-MODS) and Special Features as required to create the catalog number shown below. In all cases,

Q2C/Product Selectors are preferred to price enclosed drives.

Contact Seneca TAG for pricing assistance with special features if required. Features highlighted in gray within this

selection are ENGINEERED and require special handling by factory personnel in lieu of system supported features.

NOTE: Type 12/12K pending UL approval of new UL508C Section 9.6 testing requirements for insulation materials

and is subject to availability and Q2C/Product Selector support.

•Type 12/12K dust/drip proof enclosure ratings

Standard M-Flex™ Features

•Circuit Breaker Disconnect

•3% AC line reactor

•UL listed to UL508C Power Conversion Equipment

•100,000 A symmetrical short circuit rating

•Heavy duty industrial disconnect handle with lockout/tag-out

provisions

•Hand-Off-Auto selector switch and manual speed

potentiometer

•0–10 Vdc and 4-20 mAdc speed reference input

•0–10 Vdc or x-y mAdc programmable output

•Door mounted graphic display terminal

•Auto Start Relay (120 Vac control)

•One Form ‘C’ AFC Run mode contact

•One Form ‘C’ AFC Fault contact

•Remote fault condition reset in AUTO mode with transition of

auto start contact

•Manual fault condition reset in OFF position of H-O-A selector

switch

•Safety interlock/Run permissive wired to customer terminal

strip

•Permanent wire markings

•White component mounting plate

•Conduit knockouts on top and bottom for wall mounted

enclosures

•Removable conduit entry plates on top and bottom for floor

mount enclosures

•ANSI #49 gray enclosure

•Class 10 electronic overload protection

•Custom wiring diagrams

Isolation/Bypass Standard Features

•Class 20 overload protection with door mounted reset

•AFC-Off-Bypass selector switch

•Test-Normal selector switch

•AC3 duty rated isolation and bypass contactors

(with mechanical and electrical interlocking)

•Bypass and isolation contactor sequencing provides true motor

isolation

•Remote automatic bypass operation using Auto Start Relay

•Custom wiring diagrams

CLASS 8839 TYPE MFD N G 4 V W MODS A07, H10, E301, SPL SERIES A

Series Designation

A = Altivar® 61/71

Power converter platform

Combination Device

8839 = Circuit Breaker Type

Product Code (Prefix)

MFD = M-Flex™ Controller

Modifications (120+ Options)

A07 = Hand-Off-Auto selector switch

with manual speed potentiometer

H10 = Seismic qualified

E301 = ANSI #61 enclosure paint

SPL = Special features (specified)

Horsepower Rating

C = 1 hp Q = 60 hp

D = 2 hp R = 75 hp

E = 3 hp S = 100 hp

F = 5 hp T = 125 hp

G = 7.5 hp U = 150 hp

H = 10 hp W = 200 hp

J = 15 hp X = 250 hp

K = 20 hp Y = 300 hp

L = 25 hp Z = 350 hp

M = 30 hp 4 = 400 hp

N = 40 hp 5 = 450 hp

P = 50 hp 6 = 500 hp

Power Circuit Type

R = Barriered Bypass – RVAT

S = Barriered Bypass – Soft Start

T = Isolation & transfer

W = Combination device (Drive only)

Y = Integrated bypass (IEC)

Z = Barriered bypass – Full Voltage

Application Type

C = Constant torque

(Heavy duty – 150% current limit)

V = Variable torque

(Light duty – 110% current limit)

Enclosure Environmental Rating

G = Type 1 general purpose

A = Type 12/12K dust/drip proof

B = Type 1 with gasket/fan filter

Voltage Code

2 = 208 V, 60 Hz

3 = 230/240 V, 60 Hz

4 = 460/480 V, 60 Hz

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

aFactory engineered products – dimensions subject to design modifications.

Table 10: Pricing – Constant Torque

Reference

Code

Ratings

Controller

Output

Current

Enclosure

Frame Size

List Price – Power Circuits (Type 1 General Purpose Enclosures)

Constant Torque – Heavy Duty Rating (150% Current Limit)

Power

Circuit W:

Combination

DIsconnect

(Drive Only)

$ Price

Power

Circuit Y:

IEC Integrated

Isolation/

Bypass

$ Price

Power

Circuit S:

Soft Start

Isolation/

Bypassa

$ Price

Power

Circuit Z:

Full Voltage

Barriered

Isolation/Bypass

$ Price

Power

Circuit T:

Separate

Starter

Isolation/Transfera

$ Price

Power

Circuit R:

RVAT

Isolation/Bypassa

$ Price

208/230 V

C 1 hp 4.6 A

4163.00 4730.00 N/A 5760.00 4730.00 N/A

D 2 hp 7.5 A 4189.00 4760.00 N/A 5790.00 4760.00 N/A

E 3 hp 10.6 A 4498.00 5111.00 N/A 6141.00 5111.00 N/A

F 5 hp 16.7 A 4891.00 5218.00 N/A 6248.00 5218.00 N/A

G 7.5 hp 24.2 A D5598.00 6247.00 N/A 7277.00 6247.00 N/A

H 10 hp 30.8 A 6078.00 6906.00 N/A 7936.00 6906.00 N/A

J 15 hp 46.2 A

6799.00 7725.00 N/A 8965.00 7725.00 N/A

K 20 hp 59.4 A 8270.00 10175.00 N/A 11415.00 10175.00 N/A

L 25 hp 74.8 A 9342.00 12932.00 N/A 14682.00 12932.00 N/A

M 30 hp 88 A F11129.00 14895.00 N/A 16645.00 14895.00 N/A

N 40 hp 114 A 14379.00 16339.00 N/A 18799.00 16339.00 N/A

460 V

C 1 hp 2.1 A

3753.00 4909.00 N/A 5939.00 4909.00 N/A

D 2 hp 3.4 A 3985.00 5120.00 N/A 6150.00 5120.00 N/A

E 3 hp 4.8 A 4343.00 5557.00 N/A 6587.00 5557.00 N/A

F 5 hp 7.6 A 4829.00 6037.00 N/A 7067.00 6037.00 N/A

G 7.5 hp 11 A 5778.00 6767.00 N/A 7797.00 6767.00 N/A

H 10 hp 14A 6465.00 7333.00 N/A 8363.00 7333.00 N/A

J 15 hp 21 A 7053.00 8416.00 N/A 9656.00 8416.00 N/A

K 20 hp 27 A 8140.00 9250.00 N/A 10490.00 9250.00 N/A

L 25 hp 34 A 9594.00 11441.00 N/A 13191.00 11441.00 N/A

M 30 hp 40 A

11228.00 13351.00 N/A 15101.00 13351.00 N/A

N 40 hp 52 A 13071.00 14854.00 20594.00 17314.00 14854.00 21194.00

P 50 hp 65 A 15326.00 17416.00 24566.00 22086.00 17416.00 25656.00

Q 60 hp 77 A

17344.00 19709.00 27659.00 24379.00 19709.00 32009.00

R 75 hp 96 A 20130.00 22875.00 31325.00 27545.00 22875.00 35175.00

S 100 hp 124 A 24200.00 31540.00 40540.00 34180.00 31540.00 43840.00

T 125 hp 156 A H 28400.00 36050.00 46500.00 38740.00 36050.00 56250.00

U 150 hp 180 A

34000.00 41990.00 53790.00 44740.00 41990.00 62190.00

W 200 hp 240 A 39200.00 53590.00 66740.00 56430.00 53590.00 73790.00

X 250 hp 302 A 46000.00 N/A 76130.00 64190.00 61230.00 81430.00

Y 300 hp 361 A

52000.00 N/A 83800.00 71560.00 68450.00 106150.00

Z 350 hp 414 A 59200.00 N/A 94920.00 80480.00 77170.00 114870.00

4 400 hp 477 A 67600.00 N/A 108130.00 91710.00 88030.00 125730.00

5 450 hp 515 A 76390.00 N/A 121880.00 102010.00 98080.00 135780.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

aFactory engineered products – dimensions subject to design modifications.

Table 11: Pricing – Variable Torque

Reference

Code

Ratings

Controller

Output

Current

Enclosure

Frame

Size

List Price – Power Circuits (Type 1 General Purpose Enclosures)

Variable Torque – Light Duty Ratings (110% Current Limit)

Power

Circuit W:

Combination

DIsconnect

(Drive Only)

$ Price

Power

Circuit Y:

IEC Integrated

Isolation/

Bypass

$ Price

Power

Circuit S:

Soft Start

Isolation/

Bypassa

$ Price

Power

Circuit Z:

Full Voltage

Barriered

Isolation/Bypass

$ Price

Power

Circuit T:

Separate

Starter

Isolation/Transfera

$ Price

Power

Circuit R:

RVAT

Isolation/Bypassa

$ Price

208/230 V

C 1 hp 4.6 A

4068.00 4623.00 N/A 5653.00 4623.00 N/A

D 2 hp 7.5 A 4163.00 4730.00 N/A 5760.00 4730.00 N/A

E 3 hp 10.6 A 4189.00 4760.00 N/A 5790.00 4760.00 N/A

F 5 hp 16.7 A 4498.00 5111.00 N/A 6141.00 5111.00 N/A

G 7.5 hp 24.2 A D4891.00 5218.00 N/A 6248.00 5218.00 N/A

H 10 hp 30.8 A 5598.00 6247.00 N/A 7277.00 6247.00 N/A

J 15 hp 46.2 A

6078.00 6906.00 N/A 7936.00 6906.00 N/A

K 20 hp 59.4 A 6799.00 7725.00 N/A 8965.00 7725.00 N/A

L 25 hp 74.8 A 8270.00 10175.00 N/A 11415.00 10175.00 N/A

M 30 hp 88 A F9342.00 12932.00 N/A 14682.00 12932.00 N/A

N 40 hp 114 A 11129.00 14895.00 N/A 16645.00 14895.00 N/A

460V

C 1 hp 2.1 A

3528.00 4646.00 N/A 5676.00 4646.00 N/A

D 2 hp 3.4 A 3753.00 4909.00 N/A 5939.00 4909.00 N/A

E 3 hp 4.8 A 3985.00 5120.00 N/A 6150.00 5120.00 N/A

F 5 hp 7.6 A 4343.00 5557.00 N/A 6587.00 5557.00 N/A

G 7.5 hp 11 A 4829.00 6037.00 N/A 7067.00 6037.00 N/A

H 10 hp 14 A 5778.00 6767.00 N/A 7797.00 6767.00 N/A

J 15 hp 21 A 6465.00 7333.00 N/A 8363.00 7333.00 N/A

K 20 hp 27 A 7053.00 8416.00 N/A 9656.00 8416.00 N/A

L 25 hp 34 A 8140.00 9250.00 N/A 10490.00 9250.00 N/A

M 30 hp 40 A

9594.00 11441.00 N/A 13191.00 11441.00 N/A

N 40 hp 52 A 11228.00 13351.00 19091.00 15101.00 13351.00 19781.00

P 50 hp 65 A 13071.00 14854.00 22004. 00 17314.00 14854.00 23094.00

Q 60 hp 77 A

15326.00 17416.00 25366. 00 22086.00 17416.00 29716.00

R 75 hp 96 A 17344.00 19709.00 28159.00 24379.00 19709.00 32009.00

S 100 hp 124 A 20130.00 22875.00 31875.00 27545.00 22875.00 35175.00

T 125 hp 156 A H 24200.00 31540.00 41990.00 34180.00 31540.00 51740.00

U 150 hp 180 A

28400.00 36050.00 47850.00 38740.00 36050.00 56250.00

W 200 hp 240 A 34000.00 41990.00 55140.00 44740.00 41990.00 62190.00

X 250 hp 302 A 39200.00 N/A 68490.00 56430.00 53590.00 91290.00

Y 300 hp 361 A

46000.00 N/A 76580.00 64190.00 61230.00 98930.00

Z 350 hp 414 A 52000.00 N/A 86200.00 71560.00 68450.00 106150.00

4 400 hp 477 A 59200.00 N/A 97270.00 80480.00 77170.00 114870.00

5 450 hp 515 A 67600.00 N/A 111830.00 91710.00 88030.00 125730.00

6 500 hp 590 A 76390.00 N/A 121880.00 102010.00 98080.00 162580.00

Table 12: Type 12 & 1G Environment Adders

Constant Torque Variable Torque

A = Type 12

(Dust/Drip)

$ Price

B = Type 1 G

(Gasket)

$ Price

HP @ 208/230 V

1–10 hp 1–10 hp 349.00 N/A

15–40 hp 15–50 hp 749.00 N/A

HP @ 460 V

1–20 hp 1–25 hp 349.00 N/A

25–40 hp 30–50 hp 749.00 N/A

50–75 hp 60–100 hp 949.00 N/A

100–450 hp 125–500 hp N/A 557.00

Table 12: Type 12 & 1G Environment Adders

Constant Torque Variable Torque

A = Type 12

(Dust/Drip)

$ Price

B = Type 1 G

(Gasket)

$ Price

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

aIntegrated bypass for 125 hp offered in 20" wide section adder (45" total width). Barriered bypass offered in 25" wide section adder (50" total width) –

standard product configuration

bIntegrated bypass for 150-200 hp offered in 20" wide section adder (50" total width). Barriered bypass offered in 25" wide section adder (55" total width)

– standard configuration

cIntegrated bypass for 250 hp offered in 20" wide section adder (50" total width). Barriered bypass offered in 30" wide section adder (60" total width) –

factory engineered configuration

dIntegrated bypass for 300-400 hp not available. Barriered bypass offered in 30" wide section adder (65" total width) – factory engineered configuration

eIntegrated bypass for 450-500 hp not available. Barriered bypass offered in 35" wide section adder (70" total width) – factory engineered configuration

Operator Control Device Options

Door mounted operator controls provide dedicated control for commanding operation of the power converter functions.

Select only one.

aControl option defined by default.

bAvailable only with Power Circuit W.

cProvides control and monitoring capabilities when supplied with any communication card.

Table 13: Dimensions

M-Flex™ Enclosed AC Drives Class 8839 Type MFD – With or Without Options Dimensions Weights Construction Data

HP/Voltage (VT) HP/Voltage (CT) Power Circuit

Configuration

Enclosure

Size

Height

(In)

Width

(In)

Depth

(In) lbs.

Wall or

Floor

Mount

Environment

Rating

Operating

Handle

1–25 hp @ 460 V 1–20 hp @ 460 V

Power Circuit W

Combination

Device or Power

Circuit &

Integrated Bypass

C 49.00 20 14.81 175 Wall

Type 1 or Type

12/12K

3" Metal

Rotary

1–5 hp @ 208/230 V 1–5 hp @ 208/230 V

7.5–10 hp @ 208/230 V 7.5–10 hp @ 208/230 V D 63.00 25 14.81 243 Wall

30–50 hp @ 460 V 25–40 hp @ 460 V E 93.87 20 20.38 170.5

Floor

Mount

6" Metal

Rotary

15–25 hp @ 208/230 V 15-20 hp @ 208/230 V

60–100 hp @460 V 50–75 hp @460 V F 93.87 25 20.38 249.1

30–50 hp @ 208/230 V 25–40 hp @ 208/230 V

1–25 hp @ 460 V 1–20 hp @ 460 V

Power Circuits

Z, S, T or R

Barriered Designs

with 2

Disconnects

Barriered C/D 93.87 20 20.38 379 3" Metal

Rotary

1–10 hp @ 208/230 V 1–10 hp @ 208/230 V

30–50 hp @ 460 V 25–40 hp @ 460 V Barriered E 93.87 25 20.38 512

6" Metal

Rotary

15–25 hp @ 208/230 V 15–20 hp @ 208/230 V

60–100 hp @ 460 V 50–75 hp @ 460 V Barriered F 93.87 30 20.38 684

30–50 hp @ 208/230 V 25–40 hp @ 208/230 V

125 hp @ 460V 100 hp @ 460 V Power Circuit Wa25" Wide

Relay Section 94.58 25 20 489

Type 1 or Type

1G Filtered Flange150–250 hp @ 460 V 125–200 hp @ 460 V Power Circuit

Wbc

30" Wide

Relay Section 94.58 30 20 657

300–500 hp @ 460 V 250–450 hp @ 460 V Power Circuit

Wde

35" Wide

Relay Section 94.58 35 20 969

MOD Description $ Price

Hand-Off-Auto selector switch with manual speed potentiometera

A07

Provides a three position selector switch and manual speed potentiometer door mounted. The Hand-Off-Auto selector switch is used to select

between the AI1 and AI2 analog inputs. In the Auto position the motor may be started and stopped by a user supplied remote contact. The

speed may be adjusted by a 4-20 mAdc signal to analog input reference AI2 or the door mounted manual speed

potentiometer. The Off position will stop the motor. The Off position is also used to reset drive controller faults.

—

Hand-Off-Auto selector switch, Start/Stop push-buttons with manual speed potentiometer

B07

Provides a three-position selector switch and manual speed potentiometer door mounted. The Hand-Off-Auto selector switch is used to select

between the AI1 and AI2 analog inputs. In the Auto position the motor may be started and stopped by a user supplied remote contact. The

speed may be adjusted by a 4-20 mAdc signal to analog input reference AI2 or the door mounted manual speed

potentiometer. In the Hand position, Start/Stop push-buttons are use to start and stop the motor using a “three-wire” control strategy. The Off

position will also stop the motor. The Off position is also used to reset drive controller faults

100.00

Start/Stop push-buttons with manual speed potentiometerb

C07 Provides Start/Stop pushbuttons to start and stop the motor using a “three-wire” control strategy. The speed is adjusted by a door mounted

manual speed potentiometer. The drive disconnect is used to reset drive controller faults unless “Fault Reset” (P10) is ordered. 75.00

Start/Stop push-buttons, Forward-Reverse selector switch with manual speed potentiometerb

D07

Provides Start/Stop push-buttons to start and stop the motor using a “three-wire” control strategy. The speed is adjusted by a door mounted

manual speed potentiometer. Motor direction is controlled with a forward –reverse selector switch. The drive disconnect is used to reset drive

controller faults unless “Fault Reset” (P10) is ordered.

200.00

Hand-Off-Auto selector, Local-Remote selector switch with manual speed potentiometer

E07

Provides a three-position selector switch and manual speed potentiometer door mounted. The Hand-Off-Auto selector switch is used to select

between the AI1 and AI2 analog inputs. In the Auto position the motor may be started and stopped by a user supplied remote contact. The

speed may be adjusted by a 4-20 mAdc signal to analog input reference AI2 or the door mounted manual speed

potentiometer. The Off position will stop the motor. The Off position is also used to reset drive controller faults.

100.00

Communication-Hand-Off-Auto selector switch with manual speed potentiometerc

F07

Provides a four-position selector switch and manual speed potentiometer door mounted. The Communication-Hand-Off-Auto selector switch

is used to select between the AI1 and AI2 analog inputs. In the Auto position the motor may be started and stopped by a user supplied remote

contact. The speed may be adjusted by a 4-20 mAdc signal to analog input reference AI2 or the door mounted manual speed potentiometer.

The Off position will stop the motor. The Off position is also used to reset drive controller faults.

250.00

No Door Mounted Operators (wired for remote operation)

N07 No operators are provided on the enclosure door. The customer must provide remote mounted operator controls. Drive controllers are factory

programmed and configured for remote mounted Hand-Off-Auto operation.

Deduct

100.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

Pilot Light Combination Options

Pilot lights are ordered in light groups and door mounted. Pilot light groups are selected with compatible control

options. Pilot lights are all 22 mm long life LED type. Select only one.

aNot available with C07 or D07.

bNot available with Power Circuit W.

cAvailable only with D07 or N07.

dAvailable only with Power Circuit W.

eAvailable only with A07, B07, E07 or N07.

fSupplied with AMR relay.

gAvailable only with F07 or N07.

MOD Description $ Price

Power On, Fault, AFC Run, Auto pilot lightsa

A08 Provides a combination of (4) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow), AFC run

(green) and auto (yellow). 245.00

Power On, Fault, AFC Run, Bypass pilot lightsb

B08 Provides a combination of (4) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow), AFC run

(green) and bypass (yellow). 245.00

Power On, Fault, AFC Run pilot lights

C08 Provides a combination of (3) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow) and AFC

run (green). 185.00

Power On, Fault, AFC Forward, AFC Reverse pilot lightscd

D08 Provides a combination of (4) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow), forward

(green) and reverse (green). 245.00

Power On, Fault, AFC Run, Hand, Auto pilot lightsef

E08 Provides a combination of (5) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow), AFC run

(green), hand (blue) and auto (yellow). 305.00

Power On, Fault, AFC Run, Communication pilot lightsg

F08 Provides a combination of (4) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow), AFC run

(green) and communication (yellow). 245.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

Option Cards

All communication cards are provided without factory programming. Select only one.

MOD Description $ Price

Modbus Plus communication card

A09 Provides a factory installed plug-in Modbus Plus card, VW3A3302. This interface device connects to a Modbus Plus tap. 795.00

Modbus/Unitelway communication card

B09 Provides a factory installed plug-in Modbus/Unitelway card, VW3A3303. 476.00

Johnson Controls MetaSYS N2 communication card

C09 Provides a factory installed plug-in Johnson Controls MetaSYS N2 card, VW3A3313. 476.00

Ethernet TCP/IP communication card

D09 Provides a factory installed plug-in Ethernet TCP/IP card, VW3A3310, with user termination to RJ45 plug-in interface connector. 476.00

LonWorks communication card

E09 Provides a factory installed LonWorks card, VW3A3312. 795.00

DeviceNet communication card

F09 Provides a factory installed DeviceNet card, VW3A3309. 476.00

Profibus DP communication card

G09 Provides a factory installed Profibus DP card, VW3A3307. 795.00

I/O Extension card

H09 Provides a factory installed I/O Extension card, VW3A3202. Adds (2) analog outputs, 4 logic inputs, 2 logic outputs and 1 differential analog

input. 275.00

Siemens APOGEE FLN / P1 communication card

J09 Provides a factory installed Siemens Building Automation Apogee FLN / P1 card, VW3A3314. 476.00

BACnet communication card

K09 Provides a factory installed BACnet card, VW3A3315. 476.00

Interbus S communication card

L09 Provides a factory installed Interbus S card, VW3A3304. 795.00

FIPIO communication card

M09 Provides a factory installed FIPIO card, VW3A3311. 795.00

R09 Ethernet IP Option Card, Provides a factory installed Ethernet/ip Card VW3A3316 476.00

D09 Ethernet TCP/IP Daisy Chain Card, Provides a factory installed Ethernet TCP/IP Daisy Chain Card VW3A3310D 476.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

Miscellaneous Options

Additional system supported features to provide miscellaneous product modifications.

aAll M-Flex™ enclosed drive controllers include a 3% AC line reactor as standard. The selection of A10 substitutes a 5% line reactor in place of the 3%

AC line reactor.

bAvailable only with Power Circuit Y, unless factory engineered.

cFactory engineered for 125–500 hp ratings.

MOD Description

$ Price

208/230 V 460 V

5% AC line reactora

A10 Provides an integrally mounted, 5% AC line reactor factory-installed and wired between the circuit breaker

disconnect means and the power converter for harmonic mitigation.

1–3 hp 823.00 823.00

5–7.5 hp 949.00 949.00

10–15 hp 1054.00 1000.00

20 hp 1481.00 1000.00

25 hp 1481.00 1518.00

30–40 hp 1761.00 1518.00

50 hp 1938.00 1714.00

60 hp — 1714.00

75 hp — 1839.00

100 hp — 2000.00

125 hp — 2078.00

150 hp — 2291.00

200 hp — 3303.00

250 hp — 3697.00

300 hp — 3806.00

350–400 hp — 4988.00

450–500 hp — 5261.00

Line contactorbc

B10

A line contactor is added between the circuit breaker disconnect (or line reactor or harmonic filter when

provided) and the power converter for bypass configured Power Circuits. With the line contactor, the AFC

Fault light illuminates when the AFC-Off-Bypass selector switch is in the Off or Bypass position to indicate that

the power converter is not running. When the line contactor is open, serial communication is disabled.

1–5 hp 120.00 120.00

7.5–10 hp 197.00 157.00

15 hp 287.00 187.00

20 hp 402.00 213.00

25–30 hp 466.00 287.00

40 hp 601.00 402.00

50 hp 868.00 466.00

60 hp — 466.00

75 hp — 601.00

100 hp — 868.00

125 hp — 1065.00

150 hp — 1275.00

200 hp — 1750.00

250 hp — 2150.00

300 hp — 2750.00

350 hp — 3250.00

400 hp — 3680.00

450 hp — 4185.00

500 hp — 4695.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

Miscellaneous Options (continued)

aNot available with C07 or D07.

bMutually exclusive with J09.

cFactory engineered for 125–500 hp ratings.

dPermanent wire marking is provided as standard.

eNot available with C07, D07 or C10.

fAvailable only with Power Circuits Y, S, Z, R and T.

gAvailable only with Power Circuit W.

hNot available on Fault pilot light if P10 is selected.

iNot available with B07, C07 or D07.

jMutually exclusive with V10 unless F10 is also selected.

kFor 125–500 hp, select E217.

lExclusive with U10 unless F10 is also selected.

MOD Description $ Price

3-15 PSI transducerabc

C10 Allows the controller to follow a user supplied 3-15 PSI input. 450.00

Omit door mounted graphic display terminal

D10 The graphic display terminal is not supplied. To alter the programming of the power converter, the user must buy a graphic display terminal

or PowerSuite software to program the drive controller.

Deduct

100.00

Smoke purge relay

E10

Provides a smoke purge operating mode controlled by a user-supplied 120 Vac signal wired to terminal block TB1. Smoke purge operation

is full speed bypass (when provided) or High Speed in the drive controller. This operation is designed run the motor from any operator control

setting except emergency stop or open safety interlocks

225.00

Additional control power VAc

F10

Provides additional control power VA using a larger control transformer (120 Vac) connected to terminal block TB1for customer use.

1–50 hp @ 208/230 V / 1–100 hp @ 460 V – 50 VA 290.00

125–500 hp @ 460 V – 50 VA 380.00

CSA / cUL certification

G10 Provides a Canadian cUL (or CSA) certification when required by local code requirements. 335.00

Seismic qualified

H10 Supplies a certification label and hardware qualified to seismic rating ICC ES AC156 acceptance criteria test protocol with an importance

factor of 1.5. 425.00

Permanent wire markers (sleeve type)d

I10 Provides permanent wire sleeve type markers on control wiring. 1750.00

0-10 Vdc Auto speed reference (programming)e

J10 Provides a controller interface for 0-10 Vdc user supplied auto speed reference signal to the AI2 input, on terminal block TB2.

The 0–10 V analog input is not isolated, but it does contain noise suppression circuitry and a programmable electronic filter. N/C

1 Additional N.O. auxiliary drive run contactc

K10 Provides 1 additional N.O. contact for drive run indication wired to TB1. 185.00

1 Additional N.C. auxiliary drive fault contactd

L10 Provides 1 additional N.C. contact for drive fault indication wired to TB1. 185.00

1 N.O. Auxiliary bypass run contactcf

M10 Provides 1 additional N.O. contact for bypass run indication wired to TB1. 185.00

1 N.O. Auxiliary auto mode contactac

O10 Provides 1 additional N.O. contact for auto mode indication wired to TB1. 185.00

AFC Fault reset push-button acg

P10 Provides factory installed door-mounted push button to fault reset LI4 on the power converter at terminal TB2 when Hand-Off-Auto is not

supplied. 100.00

Push-to-Test pilot lightsh

Q10 Provides push-to-test function on all pilot lights except Power On. 210.00

Auto transfer to bypassfi

R10

Provides an automatic transfer (time adjustable 0.1–10 s) to bypass in the event that the drive controller faults. A selector switch is provided

inside the enclosure to enable or disable this function. Longer transfer time requirements are available by replacing the plug-in adjustable

timer.

270.00

Motor elapsed time meterc

S10 Provides a dedicated non-resettable elapsed time meter to record the motor run time. Runs whenever the motor is running. 270.00

Emergency stop mushroom head push-button ac

T10 Provides door mounted maintained off emergency stop red mushroom pushbutton with turn-to-reset feature. 127.00

Motor space heater sequencing circuit (light duty)jk

U10 Provides 50 VA/120V to terminal block TB1 for motor space heater whenever the motor is not running. 400.00

Seal water solenoidcl

V10 Provides 50 VA/120V to terminal block TB1 for seal water solenoid whenever the motor is running. 400.00

Check valve sequencing circuit (gravity type)c

W10

Provides an automatic shutdown of the drive controller when the user supplied N.C. contact from the check valve limit switch does not open

within 5 seconds after the motor starts. The user limit switch contact connects to terminal block TB1. Circuit provides reset function with an

illuminated (blue) push-button.

520.00

ID engraved nameplates

X10 Provides an engraved laminated nameplate attached to the front door of the enclosure (engraved per user request at time of order). 100.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

Miscellaneous Options (continued)

aNot available with 1–3 hp controllers.

bMutually exclusive with A10

cFactory engineered for 125–500 hp

MOD Description $ Price

Harmonic filter provisionsabc

Y10

Provides fused output terminals with return terminals for connection of an externally mounted harmonic filter

(provided separately). Class J fuses are provided. 208/230V 460V

For 125–500 hp VT units, the standard 3% line reactor is removed due to the line impedance of the

harmonic filter.

CT VT

5–10 hp 5–10 hp 740.00 740.00

15–20 hp 15–25 hp 850.00 850.00

25–40 hp 30–50 hp 960.00 960.00

50–200 hp 60–250 hp N/A 1070.00

250–450 hp 300–500 hp N/A 1515.00

MOD Description $ Price

24 Vdc power supply

Z10 Provides a 24 Vdc, 300 mA power supply at terminal block TB2. 370.00

RFI/EMI suppressor

410 Provides radio frequency interference suppression with ferrite cores which are factory supplied on the power wires ahead of the power

converter. 250.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

Engineered Features

Factory orders with engineered features (E-MOD, SPL, etc.) are subject to review by factory personnel and have

longer lead-time availability. Standard M-Flex™ enclosure dimensions may no longer apply to orders containing any

combination of engineered features. In addition, factory orders containing engineered features may carry a UL508A

(Industrial Control Equipment) label in lieu of a UL508C (Power Conversion Equipment) label depending on

configuration.

Control Options

The E200 series features cover control circuit option configurations for M-Flex™ enclosed drive controllers.

E-MOD Description $ Price

Door mounted meters (dedicated displays)ab

Provides a dedicated door mounted meter display, analog or digital

E201 Analog percent speed meter scaled 0 to 120% base speed. 540.00

E202 Analog percent current scaled 0 to 100% of rated output current. 540.00

E203 Digital ammeter (amperes) scaled 0 to 2 times rated output amperes. 630.00

E204 Digital speed meter (frequency) scaled 0 to 72 Hz output frequency. 630.00

E205 Digital percent speed meter scaled 0 to 120% base speed. 630.00

E206 Digital percent current scaled 0 to 100% of rated output current. 630.00

Door mounted RJ45 port

E211 Provides (1) Sixnet RJ45 door mounted 30 mm bulk head connector and internal CAT5 cabling for access via PC with PowerSuite software.

The RJ45 (Modbus/CANopen) drive port provides customer access through the enclosure door. 325.00

Auxiliary drive run contactscde

E212 Provides (3) Form ‘C’ contacts rated 5A @ 120 Vac wired to terminal blocks for customer use. 310.00

Auxiliary bypass run contactsfgh

E213 Provides (3) Form ‘C’ contacts rated 5A @ 120 Vac wired to terminal blocks for customer use. 310.00

Auxiliary drive fault contactsci

E214 Provides (3) Form ‘C’ contacts rated 5A @ 120 Vac wired to terminal blocks for customer use. 310.00

Auxiliary auto mode contactsjk

E215 Provides (3) Form ‘C’ contacts rated 5A @ 120 Vac wired to terminal blocks for customer use. 310.00

Adjustable restart delay timer

E216 Provides an adjustable On Time Delay Relay for power up restart function, mounted and wired for AFC mode (hand or auto) mode

and/or in the bypass mode (hand/auto). 240.00

Motor space heater (heavy duty)

E217 Provides control circuit contacts, 120 Vac, 500VA supply and fusing wired to terminals for customer use. 1000.00

Signal loss follower alarm relayl

E218

Provides (1) Form ‘C’ contact rated 5A @ 120 Vac wired to terminal blocks for customer use. Intended for 4-20mAdc control loop

applications where upon the loss of input signal it is desired to retain the output signal at the last input signal level. The relay provides an

alarm relay contact for signal loss alert.

360.00

Inhibit/shutdown sequence (timed operation)

E219 Provides a relay circuit operating in the fail safe mode where a remote initiating contact opens the relay, de-energizes and after a specified

time shuts the drive controller down in the AFC mode (hand or auto) and/or in the bypass mode (hand or auto). 580.00

Check valve sequence (motorized type)

E220

Provides relay circuitry sequenced from a check valve limit switch. A valve closed position limit switch will energize relays that will initiate a

remote valve operating solenoid limited to 50VA and give a run permissive to the drive controller in the AFC mode (hand or auto) and/or in

the bypass mode (hand or auto). A valve closed position limit switch will de-energize a timer relay such that if this relay is not de-energized

within a specified time period, the drive controller will shut down in the AFC mode (hand or auto) and/or in the bypass mode (hand or auto).

710.00

Seal water solenoid - with pressure switch feedback

E221

Provides relay, which will energize a remote seal water solenoid limited to 50VA during drive controller operation. Additionally, the remote

initiating contact will open the relay, de-energizing and after a specified time shuts the drive controller down in the AFC mode (hand or auto)

and/or in the bypass mode (hand or auto).

1220.00

Moisture detection relay circuit (without relay)m

E222 Provides 24 V or 120 V control power to a customer supplied moisture detection relay device, either electronic or electro-mechanical.

Factory provides pre-wired socket or mounting space only. 350.00

Moisture detection relay circuit (with relay options)n

E223A Relay option: Provides 24 V or 120 V control power to a moisture detection relay device, either electronic or electro-mechanical.

The moisture detection relay is mounted and wired by the factory. 1220.00

E223B

Relay and Pilot Light indication option: Provides 24 V or 120 V control power to a customer supplied moisture detection relay device, either

electronic or electro-mechanical. Includes a pilot light for discrete input(s). The customer supplied moisture detection relay is mounted and

wired by the factory.

1395.00

aLimited to one meter selection unless H09 is selected.

bIf H09 is selected, (1) additional meter can be selected.

cOne (1) Form ‘C’ contact for drive run indication is supplied as standard.

dAvailable only if K10 is selected.

eAvailable without K10 for 125–500 hp.

fOne (1) N.O. contact for bypass run indication is supplied as standard when bypass is provided.

gAvailable only if M10 is selected.

hAvailable without M10 for 125–500 hp.

iAvailable only if L10 is selected.

jOne (1) N.O. contact for auto mode indication is supplied as standard when auto mod operation is provided.

kAvailable only if O10 is selected.

lRequires use of logic output LO1.

mCustomer supplies relay. Details concerning type must also be provided at time of order entry in “Engineering Notes” within Q2C.

nDetails concerning type must be provided at time of order entry in “Engineering Notes” within Q2C.

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

E-MOD Description $ Price

Substitute Type K operators

E224 Provides Class 9001 Type K 30 mm heavy duty multi-function operators in lieu of standard 22 mm pilot devices. 410.00

Spare control relays (for customer use)

E225 Provides control relays mounted and unwired for customer use. Up to (3) are available. 150.00

each

Substitute pilot light lens color(s)a

E226 Provides the flexibility to configure lens cap colors to contract equipment designations. —

Blown fuse indicators on control fuses

E227 Provides blown circuit fuse indicators on control circuit fuses in lieu of standard fuses. 750.00

Motor over temperature logic input

E228 Provides dedicated terminals using an external motor over temperature input (N.C. contact) factory wired and programmed. 186.00

RTD inputs (motor protection alarm)b

E229 Provides capability for accepting RTD inputs using an RTD limit alarm, factory mounted and wired. Limited to three (3) RTD inputs. 4122.00

Motor management relay optionc

Provides motor protection and metering functions using a selection of motor management relays. This relay provides protection for motor and load conditions:

overload, differential, stator temperature, high inertia loads, undercurrent, under power, jam and bearing over temperature. The motor management relay is factory

mounted and wired. Includes PT’s and CT’s.

E230A Schneider Electric Sepam Series 20 motor protective relay. 2850.00

E230B Schneider Electric Sepam Series 41 motor protective relay. 3975.00

E230C GE Multilin 269+ motor management relay. 13995.00

E230D GE Multilin 469 motor management relay. 14750.00

PowerLogic® power meter display option

Provides a Class 3020 PM800 series power module true rms meter display with basic instrumentation, demand, THD, date/time stamping, neutral current,

min/max, alarms, event and data storage factory mounted and wired.

E231A PM820 power module. 1400.00

E231B PM850 power module. 1550.00

E231C PM870 power module. 1995.00

PowerLogic circuit monitor option

Provides a Class 3020 CM3000 or CM4000 series circuit monitor display with instrumentation, 0.2% accuracy, data logging and waveform capture, factory mounted

and wired. Includes PT’s and CT’s.

E232A CM3250 circuit monitor. 2415.00

E232B CM3350 circuit monitor. 2415.00

E232C CM4000T circuit monitor. 4275.00

E232D CM4250 circuit monitor. 4275.00

Spare terminal blocks (unwired)

E234 Provides (10) spare terminal blocks 'unwired' for customer use using the Class 9080 Type G series terminals. 120.00

End damper control circuit

E235 Provides a damper control circuit to coordinate starting of the drive controller or the bypass with the position of the damper. Requires

connection to customer damper limit switch. 240.00

Emergency power off push-button

E236

Provides a shunt trip modified molded case switch or circuit breaker where a push-pull maintained mushroom head push-button energizes

the shunt trip coil and instantaneously opens to shut down power supplied to the drive controller in the AFC mode and/or bypass mode,

coasting to an uncontrolled stop.

540.00

Audible alarm horn with silencer

E238 Provides an audible alarm horn, timer to annunciate a user defined conditions with a silencer push-button, factory assembled and wired for

customer use. 625.00

Three phase ammeter with selector switch

Provides 3 CT's with 3-position selector switch to indicate Phase A, B or C connected on the motor leads to monitor full load amps.

E239A Monitor input full load amps. 1575.00

E239B Monitor output full load amps. 1575.00

Basin high level alarm indication option

E240A Alarm with pilot light: Provides relay circuit and pilot light indicator alarm for high level alarm limit switch via contact closure. Includes master

reset push-button and (1) Form 'C' contact for customer use. 795.00

E240B

Command to run and alarm with pilot light indication: Provides relay circuit, timer and pilot light indicator sequenced for high level alarm

limit switch via contact closure, energizing the drive controller and/or bypass to run full speed. Includes master reset push-button and (1)

Form 'C' contact for customer use

895.00

aSpecify lens cap colors desired at time of order in “Engineering Notes” field within Q2C.

bSpecify RTD values at time of order entry in “Engineering Notes” within Q2C.

cAvailable for 125–500 hp only.

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

aMutually exclusive to E221.

bMutually exclusive to E228.

cAvailable with Power Circuits Y, Z, S, T or R only.

dMust also select E224.

Enclosure & Miscellaneous Modifications

The E300 series features cover enclosure and miscellaneous option configurations for the M-Flex™ enclosed drive

controller.

aAvailable on configurations 1–20 hp CT or 1–25 hp VT only.

bAvailable on configurations 1–50 hp CT or 1–60 hp VT only.

cAvailable on configurations 1–75 hp CT or 1–100 hp VT only.

E-MOD Description $ Price

Basin low level stop with pilot light indication

E241 Provides relay circuit and pilot light indicator sequenced for low level alarm limit switch via N.O./N.C.contact closure, causing the drive

controller to stop. Includes master reset push-button and (1) Form 'C' contact for customer use. 795.00

Enclosure ventilation fan shutdown

E242 Provides interlocking and timer functions of enclosure ventilation fans to shutdown during drive controller idle conditions. 795.00

High discharge pressure with pilot light indication

E243 Provides relay circuitry with pilot light indicator sequenced from a pressure switch input, causing the drive controller to stop. Includes master

reset push-button and (1) Form 'C' contact for customer use. 795.00

Low discharge pressure with pilot light indication

E244 Provides relay circuit, timer with pilot light sequenced from a pressure switch input when low discharge condition. Includes master reset

push-button and (1) Form 'C' contact for customer use. 795.00

Low seal water shutdown with pilot light indicationa

E245 Provides relay circuitry, timer with pilot light sequenced from a pressure switch input when not enough seal water is supplied. Includes

master reset push-button and (1) Form 'C' contact for customer use. 795.00

Motor over temperature shutdown with pilot lightb

E246 Provides dedicated terminals using an external motor over temperature input (Form 'C' contact) and a pilot light indicator factory wired and

programmed. 380.00

Phase failure relayc

E247 Provides a phase failure relay (Tele RM4T series) mounted and wired to indicate phase reversal, phase loss and imbalance operating

conditions. 725.00

Single test pilot light push-buttond

E248 Provides a dedicated 30 mm push-to-test button for indication of operable pilot lights. 130.00

Substitute TeSys 600 V relay(s)

E249 Substitutes TeSys Type NEMA rated relays rated 600 V, 10A. 985.00

E-MOD Description $ Price

ANSI #61 enclosure paint

E301 Provides option to configure enclosure paint to industry standard ANSI #61 light gray paint in lieu of ANSI #49 gray. 526.

Free standing enclosurea

E302 Converts all standard wall mounted enclosure configurations to a floor mounted 90” high enclosure. 925.

Enclosure expansionb

E303 Converts all standard wall and floor mounted enclosures up one enclosure size. 925.

Barriered enclosure expansionc

E304 Uses Barriered enclosure for non-bypass drives controllers. Bypass space is configured with circuit breaker disconnect and handle only. 1450.

Enclosure space heater option

E305A Space heater only: Provides a Hoffman type enclosure strip heater and thermostat to maintain internal low temperature ambient ratings. 1500.

E305B Space heater with storage operation provision: Provides a Hoffman type enclosure strip heater and thermostat to maintain internal low

temperature ambient ratings. Includes 120 V remote source input terminals for operation during storage conditions. 1800.

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

Power Options

The E400 series features cover engineered power option configurations for M-Flex™ enclosed drive controllers.

aAvailable for Barriered design configurations only; requires selection of Power Circuit S, Z, T or R.

E-MOD Description 208/230V

Rating $ Price 460V

Rating $ Price

Dynamic braking resistors

E401

Provides dynamic braking resistor top mounted on the enclosure. Resistors are 10% duty cycle

constant torque (CT) applications. Overload protection for externally mounted dynamic braking

resistor is mounted inside the drive controller enclosure.

1 hp 1035.00 1–3 hp 1415.00

2–5 hp 1245.00 5 hp 1595.00

7.5 hp 1595.00 7.5 hp 1775.00

10–15 hp 2015.00 10–20 hp 2545.00

20–25 hp 2525.00 25–40 hp 2725.00

30–40 hp 3515.00 50 hp 4015.00

— — 60–75 hp 5335.00

Motor protection filter

E402 Provides a factory mounted and wired dV/dt filter on the drive output for long motor lead lengths considerations in excess of

published guidelines.

1 hp 1120.00

2 hp 1120.00

3 hp 1145.00

5 hp 1165.00

7.5 hp 1215.00

10 hp 1222.00

15 hp 1530.00

20 hp 1695.00

25 hp 1770.00

30 hp 1840.00

40 hp 1895.00

50–60 hp 2675.00

75 hp 3145.00

100 hp 3675.00

125 hp 5025.00

150 hp 5230.00

200 hp 5330.00

250 hp 5365.00

300 hp 5645.00

350 hp 6540.00

400 hp 6980.00

450–500 hp 7310.00

NEMA rated contactorsa

E403 Provides NEMA rated contactors for isolation and bypass configuration in lieu of the IEC rated

contactors.

1–3 hp 1725.00 1–3 hp 1152.00

5–7.5 hp 2013.00 5–10 hp 1259.00

10–15 hp 2415.00 15–20 hp 2013.00

20–25 hp 2875.00 25–30 hp 2415.00

30 hp 3450.00 40–50 hp 2875.00

40–50 hp 4830.00 60 hp 3450.00

— — 75–100 hp 4830.00

— — 125 hp 5290.00

— — 150 hp 6240.00

— — 200 hp 7610.00

— — 250 hp 8870.00

— — 300 hp 8980.00

— — 350 hp 9450.00

— — 400 hp 11280.00

— — 450 hp 12260.00

— — 500 hp 12580.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

M-Flex™ Enclosed AC Drives

aThe sum of the total connected motors must not exceed the drive controller FLA rating. Specify motor FLA values at time of order entry in “Engineering

Notes” within Q2C.

bSpecify mode of operation via “Motor A-Off-Motor B” selector switch, remote contact closure or rotation timer scheme at time of order entry in

“Engineering Notes” within Q2C.

cAvailable for 460/480 V rated devices only.

E-MOD Description $ Price

Transient voltage surge supperssor

E405 Provides supplementary surge protection using a Class 1310 TVSS XWF Series Transient Voltage Surge Suppressor

hard-wired and factory mounted. 100,000 peak volts of surge protection. 1885.00 E405

Note: Service connection type (Delta or Wye) must be specified in “Engineering Notes” within Q2C.

Dual motor overloads and branch short circuit protectiona

E406 Provides short circuit and overload protection for (2) motors connected to the output of the drive controller. Includes

thermal overload modules for each motor.

1–10 hp 720.00

15–25 hp 790.00

30–50 hp 880.00

60–100 hp 1250.00

125–200 hp 3650.00

Motor A or B contactor alternation schemeb

E407 Provides a contactor interlocked for the selection of one motor for load share via a selector switch or rotation timer

scheme.

1–10 hp 1310.00

15–25 hp 1950.00

30–50 hp 2450.00

60–100 hp 5520.00

125–200 hp 11450.00

250–500 hp 24950.00

SEMI F47 compliance

E408

Provides modified drive controller settings and hardware configuration for ride-through capability to comply with SEMI F47-0200 standards, 50% voltage

sag, 200ms sustained without interruption. Drive must be configured for 2-wire control and the start signal must maintain during sag

conditions.

Power Circuit W 1169.00

Power Circuits Y, S, Z, T or R 1675.00

Line contactor (without bypass)

E409 Provides a line contactor between the circuit breaker disconnect (or line reactor or harmonic filter where provided) and

the power converter. When the line contactor is open, serial communications is disabled.

1–10 hp 1169.00

15–25 hp 1675.00

30–50 hp 2176.00

60–100 hp 4891.00

125–200 hp 10862.00

Secondary surge arrestor

E413 Provides a secondary surge arrester Class 6671 SDSA3650 mounted and wired. 485.00

3% output reactorc

E414 Provides a 3% rated output reactor to address long lead considerations, mounted and wired.

1–5 hp 750.00

7.5–25 hp 850.00

30–40 hp 1450.00

50–60 hp 1650.00

75–100 hp 1750.00

125 hp 1850.00

150 hp 2050.00

200 hp 3150.00

250 hp 3450.00

300–350 hp 4350.00

400–450 hp CT /

400–500 hp VT 4850.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Enclosed AC Drives

PowerGard™ Series C — Class 8839

PowerGard Series C—18-Pulse Drives

Class 8839 Type CPD family of drive controllers now features the Altivar® 61/71 platform in an integrated 18-Pulse AC

drive solution designed for the construction and industrial markets. A patented 18-Pulse converter design provides near

linear load performance for adjustable frequency controllers rated 40 hp and above. This product is strategically

designed to help the user comply with IEEE 519 guidelines.

Each PowerGard 18-Pulse enclosed drive offers a feature rich platform of standard, engineered and user configurable

options to meet the most demanding application and specification requirements with availability in the following ratings:

Constant torque (Heavy duty ratings – 150% current limit)

•Altivar 71 power converter platform

•40 to 450 hp, 460 V

Variable torque (Normal duty ratings – 110% current limit)

•Altivar 61 power converter platform

•50 to 500 hp, 460 V

Selection

To select a PowerGard 18-Pulse enclosed drive controller, identify the basic drive and optional devices by Class, Type,

Options (MODS, E-MODS,) and Special Features (if required) to create the catalog number as shown below. This

catalog number is used to identify the features of the product. In all cases, Q2C/Product Selectors must be used to price

enclosed drives.

Standard PowerGard Features

•Circuit Breaker Disconnect

•UL listed to UL508

•100,000 A symmetrical short circuit rating

•Heavy duty industrial disconnect handle with lockout/tag-out

provisions

•18-Pulse transformer/reactor assembly

•18-Pulse bridge rectifier assembly

•Altivar® 61/71 power converter

•120 V fused control transformer

•Hand-Off-Auto selector switch and manual speed

potentiometer

•Door mounted graphic display terminal

•Auto Start Relay (120 V control)

•One Form “C” AFC Run mode contact

•One Form “C” AFC Fault contact

•Remote fault condition reset in AUTO mode with transition of

auto start contact

•Manual fault condition reset in OFF position of H-O-A selector

switch

•Safety interlock (e.g., run permissive) wired to user terminal

block TB1

•Permanent wire markings

•White component mounting plate

•Top and bottom conduit access

•ANSI #49 gray enclosure

•Class 10 electronic overload protection

•Optional equipment as specified

•Customized wiring diagrams

Typical Isolation/Bypass Features

(when provided)

•Class 20 overload protection with door mounted reset

•120 V fused control transformer

•AFC-Off-Bypass selector switch

•Test-Normal selector switch

•AC3 duty rated isolation and bypass contactors (with

mechanical and electrical interlocking)

•Bypass and isolation contactor sequencing provides true motor

isolation

•Overload relay reset push button

•Customized wiring diagrams

CLASS 8839 TYPE CPD T G 4 V W MODS A07, etc. SERIES C

Series Designation

C = Altivar® 61/71

Power converter platform

Combination Device

8839 = Circuit Breaker

Disconnect

Design

CPD = PowerGard™

18-Pulse Controller

Modifications

(120+ Options are available)

A07 = Hand-Off-Auto selector switch with

manual speed potentiometer

Horsepower Rating

N = 40 hpW = 200 hp

P = 50 hpX = 250 hp

Q = 60 hpY = 300 hp

R = 75 hpZ = 350 hp

S = 100 hp4 = 400 hp

T = 125 hp5 = 450 hp

U = 150 hp6 = 500 hp

Power Circuit Type

R = Barriered Bypass – RVAT

S = Barriered Bypass – Soft Start

T = Isolation & transfer

W = Combination device (Drive only)

Y = Integrated bypass (IEC)

Z = Barriered bypass – Full Voltage

Application Type

C = Constant torque (150% current limit)

V = Variable torque (110% current limit)

Enclosure Environmental

Rating

G = Type 1 general purpose

B = Type 1 with gasket/fan filter

Voltage Code

4 = 460/480 V, 60 Hz

Prices subject to change without notice.

06/2009

Pricing Guide Enclosed AC Drives

PowerGard™ Series — Class 8839

Notes:

For Type 1B enclosures with fan filter option, add $550.

The listings define the available factory modifications. Modifications in gray shaded areas require order engineering support. All modifications follow specific

interoperability rules for selection and configuration. Modification selection can be validated at the time of quotation or order entry by the Q2C/Product Selector

process. Contact your nearest Square D/Schneider Electric sales office for details.

When options with an “E” and/or “SPL” prefix appear on thenameplate, engineered-to-order options are provided.

Note:

All enclosures are 94.65” height and 24” depth standard switchboard enclosures.

Table 14: Selection and Pricing

Horsepower

HP @ 460 V Hp Code

Output

Current

(A)

Power Circuit Configurations (Type 1 General Purpose Enclosures)

Combination

Drive Only

$ Price

Integrated Bypass

Full Voltage

$ Price

Barriered Bypass

FUll Voltage

$ Price

Barriered Bypass

Soft Start

$ Price

Isolation & Transfer

Separate Starter

$ Price

Barriered Bypass

RVAT

$ Price

Constant Torque - Heavy Duty Ratings (150% Current Limit)

40 N 52 53059.00 57486.00 57935.00 65709.00 57141.00 66817.00

50 P 65 54032.00 60035.00 61806.00 69177.00 59690.00 73835.00

60 Q 77 54347.00 61224.00 62443.00 70941.00 60879.00 75024.00

75 R 96 55685.00 63057.00 64218.00 73407.00 62712.00 76857.00

100 S 124 65632.00 74924.00 77960.00 86941.00 74579.00 97809.00

125 T 156 70980.00 83078.00 86172.00 96648.00 82848.00 106078.00

150 U 180 75730.00 91439.00 94601.00 106561.00 91094.00 114324.00

200 W 240 79874.00 96423.00 99689.00 113558.00 94928.00 127933.00

250 X 302 98342.00 115857.00 119261.00 133509.00 115512.00 154267.00

300 Y 361 120928.00 139846.00 143422.00 160258.00 139501.00 182856.00

350 Z 414 129253.00 149919.00 153725.00 173034.00 149574.00 195229.00

400 4 477 136845.00 160340.00 164572.00 187710.00 159995.00 212550.00

450 5 515 138523.00 163467.00 167986.00 190837.00 163122.00 237297.00

Variable Torque - Light Duty Ratings (110% Current Limit)

50 P 65 53059.00 57486.00 57935.00 65709.00 57141.00 66617.00

60 Q 77 54032.00 60035.00 61806.00 69177.00 59690.00 73835.00

75 R 96 54347.00 61224.00 62443.00 70941.00 60879.00 75024.00

100 S 124 55685.00 63057.00 64218.00 73407.00 62712.00 76857.00

125 T 156 65632.00 74924.00 77960.00 86941.00 74579.00 97809.00

150 U 180 70980.00 83078.00 86172.00 96648.00 82848.00 106078.00

200 W 240 75730.00 91439.00 94601.00 106561.00 91094.00 114324.00

250 X 302 79874.00 96423.00 99689.00 113558.00 94928.00 127933.00

300 Y 361 98342.00 115857.00 119261.00 133509.00 115512.00 154267.00

350 Z 414 120928.00 139846.00 143422.00 160258.00 139501.00 182856.00

400 4 477 129253.00 149919.00 153725.00 173034.00 149574.00 195229.00

450 5 515 136845.00 160340.00 164572.00 187710.00 159995.00 212550.00

500 6 590 138523.00 163467.00 167986.00 190837.00 163122.00 237297.00

Table 15: Dimensions

Hp @ 480 V

PowerGard™ Series C enclosure width dimensions

Combination

Drive only

Integrated Bypass

Full Voltage

Barriered Bypass

Full Voltage / Separate Starter

Z or T

Barriered Bypass

Soft Start

Barriered Bypass

RVAT

Total Extender Total Extender Total Extender Total Extender Total

50 to 75 36” — 36” 20” 56” 20” 56” 42” 78”

100 36” — 36” 20” 56” 36” 72” 42” 78”

125 36” 20” 56” 20” 56” 36” 72” 42” 78”

150 42” 20” 62” 20” 62” 36” 78” 48” 90”

200 42” 20” 62” 20” 62” 36” 78” 48” 90”

250 42” 20” 62” 20” 62” 42” 84” 54” 90”

300 48” 25” 73” 25” 73” 42” 90” 54” 102”

350 48” 25” 73” 25” 73” 42” 90” 54” 102”

400 48” 25” 73” 25” 73” 42” 90” 54” 102”

450 48” or 54” 36” 84” 36” 84” 48” 96” 54” 102”

500 48” or 54” 36” 84” 36” 84” 48” 96” 54” 102”

Table 16: Weights and Heat Loss Data

PowerGard Series C - Power Circuit W

HP @ CT rating Weight

lbs.

Estimated Heat Loss

HP @ VT rating Weight

Estimated Heat Loss

Watts Loss BTU/Hour Watts Loss BTU/Hour

40 1603 2478 8457 — — — —

50 1603 2674 9126 50 1603 2674 9126

60 1603 2838 9686 60 1603 2838 9686

75 1603 3027 10331 75 1603 3027 10331

100 1703 4776 16300 100 1703 3756 12819

125 2070 6333 21615 125 1703 4843 16529

150 2070 6637 22652 150 2070 6637 22652

200 2086 7074 24144 200 2086 7074 24144

250 2682 9582 32703 250 2086 9582 32703

300 2682 11216 38280 300 1682 11216 38280

350 2682 11684 39877 350 2682 11684 39877

400 2682 12894 44007 400 2682 12894 44007

450 3148 13793 47076 450 3148 13793 47076

— — — — 500 3148 14691 50140

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Enclosed AC Drives

PowerGard™ Series — Class 8839

Operator Control Device Options

Door mounted operator controls provide dedicated control for commanding power converter speed and start/stop

functions. Select only one.

Pilot Light Options

Pilot lights are ordered in light groups and door mounted. Pilot light groups are selected with compatible control

options. Pilot lights are all 22mm, long life LED type. Select only one.

MOD Description $ Price

Hand-Off-Auto selector switch with manual speed potentiometer

A07

Provides a three position selector switch and manual speed potentiometer door mounted. The Hand-Off-Auto selector switch is used to select

between the AI1 and AI2 analog inputs. In the Auto position the motor may be started and stopped by a user supplied remote contact. The speed

may be adjusted by a 4-20 mAdc signal to analog input reference AI2 or the door mounted manual speed potentiometer. The Off position will stop

the motor. The Off position is also used to reset drive controller faults.

—

Rules: Control option defined by default.

Hand-Off-Auto selector switch, Start/Stop push-buttons with manual speed potentiometer

B07

Provides a three-position selector switch and manual speed potentiometer door mounted. The Hand-Off-Auto selector switch is used to select

between the AI1 and AI2 analog inputs. In the Auto position the motor may be started and stopped by a user supplied remote contact. The speed

may be adjusted by a 4-20 mAdc signal to analog input reference AI2 or the door mounted manual speed potentiometer. In the Hand position,

Start/Stop push-buttons are use to start and stop the motor using a “three-wire” control strategy. The Off position will also stop the motor. The Off

position is also used to reset drive controller faults.

100.00

Start/Stop push-buttons with manual speed potentiometer

C07 Provides Start/Stop pushbuttons to start and stop the motor using a “three-wire” control strategy. The speed is adjusted by a door mounted manual

speed potentiometer. The drive disconnect is used to reset drive controller faults unless “Fault Reset” (MOD P10) is ordered. 75.00

Rules: Available only with Power Circuit W.

Start/Stop push-buttons, Forward-Reverse selector switch with manual speed potentiometer

D07

Provides Start/Stop push-buttons to start and stop the motor using a “three-wire” control strategy. The speed is adjusted by a door mounted

manual speed potentiometer. Motor direction is controlled with a forward -reverse selector switch. The drive disconnect is used to reset drive

controller faults unless “Fault Reset” (Option P10) is ordered.

200.00

Rules: Available only with Power Circuit W.

Hand-Off-Auto selector, Local-Remote selector switch with manual speed potentiometer

E07

Provides a three-position selector switch and manual speed potentiometer door mounted. The Hand-Off-Auto selector switch is used to select

between the AI1 and AI2 analog inputs. In the Auto position the motor may be started and stopped by a user supplied remote contact. The speed

may be adjusted by a 4-20 mAdc signal to analog input reference AI2 or the door mounted manual speed potentiometer. The Off position will stop

the motor. The Off position is also used to reset drive controller faults. The Local-Remote switch selects whether speed control is sent by a signal

into terminal AI1 (local) or AI2 (remote) on terminal block TB2, when the Hand-Off-Auto switch is in Auto mode.

100.00

Communication-Hand-Off-Auto selector switch with manual speed potentiometer

F07

Provides a four-position selector switch and manual speed potentiometer door mounted. The Communication-Hand-Off-Auto selector switch is

used to select between the AI1 and AI2 analog inputs. The communication position is for communication option card control of the drive controller.

In the Auto position the motor may be started and stopped by a user supplied remote contact. The speed may be adjusted by a

4-20 mAdc signal to analog input reference AI2 or the door mounted manual speed potentiometer. The Off position will stop the motor. The Off

position is also used to reset drive controller faults.

250.00

Rules: Provides control and monitoring capabilities when supplied with any communication card.

No Door Mounted Operators (wired for remote operation)

N07 No operators are provided on the enclosure door. The customer must provide remote mounted operator controls. Drive controllers are factory

programmed and configured for remote mounted Hand-Off-Auto operation.

Deduct

$100.00

MOD Description $ Price

Power On, Fault, AFC Run, Auto pilot lights

A08 Provides a combination of (4) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow), AFC run (green)

and auto (yellow). 245.00

Rules: Not available with C07 or D07.

Power On, Fault, AFC Run, Bypass pilot lights

B08 Provides a combination of (4) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow), AFC run (green)

and bypass (yellow). 245.00

Rules: Not available with Power Circuit W.

Power On, Fault, AFC Run pilot lights

C08 Provides a combination of (3) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow) and AFC run

(green). 185.00

Power On, Fault, AFC Forward, AFC Reverse pilot lights

D08 Provides a combination of (4) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow), forward (green)

and reverse (green). 245.00

Rules: 1. Available only with D07 or N07.

2. Available only with Power Circuit W.

Power On, Fault, AFC Run, Hand, Auto pilot lights

E08 Provides a combination of (5) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow), AFC run

(green), hand (blue) and auto (yellow). 305.00

Rules: 1. Available only with A07, B07, E07 or N07.

2. Supplied with AMR relay.

Power On, Fault, AFC Run, Communication pilot lights

F08 Provides a combination of (4) pilot lights for visual indication of protective functions and circuit status; power on (red), fault (yellow), AFC run (green)

and communication (yellow). 245.00

Rules: Available only with F07 or N07.

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Enclosed AC Drives

PowerGard™ Series — Class 8839

Option Cards

All communication cards are provided without factory programming. Select only one.

MOD Description $ Price

Modbus Plus communication card

A09 Provides a factory installed plug-in Modbus Plus card, VW3A3302. This interface device connects to a Modbus Plus tap. 795.00

Modbus/Unitelway communication card

B09 Provides a factory installed plug-in Modbus/Unitelway card, VW3A3303. 476.00

Johnson Controls MetaSYS N2 communication card

C09 Provides a factory installed plug-in MetaSYS N2 card, VW3A3313. 476.00

Ethernet TCP/IP communication carD

D09 Provides a factory installed plug-in Ethernet TCP/IP card, VW3A3310, with user termination to RJ45 plug-in interface connector. 476.00

LonWorks communication card

E09 Provides a factory installed LonWorks card, VW3A3312. 795.00

DeviceNet communication card

F09 Provides a factory installed DeviceNet card, VW3A3309. 476.00

Profibus DP communication card

G09 Provides a factory installed Profibus DP card, VW3A3307. 795.00

I/O Extension card

H09 Provides a factory installed I/O extension card, VW3A3202. Adds (2) analog outputs, 4 logic inputs, 2 logic outputs and 1 differential analog input. 275.00

Siemens APOGEE FLN / P1 communication card

J09 Provides a factory installed Apogee P1 card, VW3A3314. 476.00

BACnet communication card

K09 Provides a factory installed BACnet card, VW3A3315. 476.00

Interbus S communication card

L09 Provides a factory installed Interbus card, VW3A3304. 795.00

FIPIO communication card

M09 Provides a factory installed Fipio card, VW3A3311. 795.00

Bluetooth Modbus

P09 Provides a Bluetooth Modbus adapter, VW3A8114. 125.00

FIPIO communication card

R09 Ethernet IP Option Card, Provides a factory installed Ethernet/ip Card VW3A3316 476.00

D09 Ethernet TCP/IP Daisy Chain Card, Provides a factory installed Ethernet TCP/IP Daisy Chain Card VW3A3310D 476.00

Trademarks used herein are properties of their respective owners.

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Enclosed AC Drives

PowerGard™ Series — Class 8839

Miscellaneous Options

Pre-engineered and system supported options to provide miscellaneous product modifications.

MOD Description $ Price

3-15 PSI Transducer

C10 Allows the controller to follow a user supplied 3-15 PSI input. 450.00

Rules: 1. Not available with C07 or D07.

2. Mutually exclusive with J09.

Omit Door mounted graphic display terminal

D10 The graphic display terminal is not supplied. To alter the programming of the power converter, the user must buy a graphic display terminal or

PowerSuite software to program the drive controller.

Deduct

100.00

Smoke Purge Relay

E10

Provides a smoke purge operating mode controlled by a user-supplied 120 VAC signal wired to terminal block TB1. Smoke purge operation is full

speed bypass (when provided) or High Speed in the drive controller. This operation is designed run the motor from any operator control setting

except emergency stop or open safety interlocks.

225.00

Additional 200 VA Control Power

F10 Provides additional control power 200 VA using a larger 120 V control transformer connected to terminal block TB1 for customer use. 380.00

cUL Certification

G10 Provides a Canadian cUL certification when required by local code requirements. 335.00

Seismic Qualified

H10 Supplies a certification label and hardware qualified to seismic rating ICC ES AC156 acceptance criteria test protocol with an importance

factor of 1.5. 425.00

Permanent Wire Marker (Sleeve Type)

I10 Provides permanent wire sleeve type markers on control wiring. 1750.00

Note: Permanent wire markings are provided as standard.

Input programmed for 0 - 10 Vdc AI2 input

J10

Provides programming for 0-10 Vdc user supplied auto speed reference signal to the AI2 input, on terminal block TB2. The 0-10 Vdc analog input

is not isolated, but it does contain noise suppression circuitry and a programmable electronic filter. using a 0-10V/4-20mA converter

(P/n# 31158-297-50). Source impedance: Z=40k .

—

Rules: Not available with C07, D07 or C10.

1 Additional N.O. Auxiliary Drive Run Contact

K10 Provides 1 additional N.O. contact for drive run indication wired to TB1. 185.00

1 Additional N.C. Auxiliary Drive Fault Contact

L10 Provides 1 additional N.C. contact for drive fault indication wired to TB1. 185.00

1 N.O. Auxiliary Bypass Run Contact

M10 Provides 1 additional N.O. contact for bypass run indication wired to TB1. 185.00

Rules: Available only with Power Circuits Y, S, Z, R and T.

1 N.O. Auxiliary Auto Mode Contact

O10 Provides 1 additional N.O. contact for auto mode indication wired to TB1. 185.00

Rules: Not available with C07 or D07.

AFC Fault Reset Push-button

P10 Provides factory installed door-mounted push button to fault reset LI4 on the power converter at terminal TB1 when Hand-Off-Auto is not supplied. 100.00

Rules: 1. Available only with C07 or D07.

2. Available only with Power Circuit W.

Push-to-Test Pilot Lights

Q10 Provides push-to-test function on all pilot lights except Power On pilot light. 210.00

Rules: Not available on Fault pilot light if P10 is selected.

Auto Transfer to Bypass

R10 Provides an automatic transfer (time adjustable 0.1-10 s) to bypass in the event that the drive controller faults. A selector switch is provided inside

the enclosure to enable or disable this function. Longer transfer time requirements are available by replacing the plug-in adjustable timer. 270.00

Rules: 1. Available only with Power Circuits Y, S, Z, T or R.

2. Not available with B07, C07 or D07.

Motor Elapsed Time Meter

S10 Provides a dedicated elapsed time meter to record the motor run time. Runs whenever the motor is running. The motor elapsed time meter is

non-resettable. 270.00

Emergency Stop Mushroom Head Push-button

T10 Provides door mounted maintained off emergency stop red mushroom pushbutton with turn-to-reset feature. 127.00

Rules: Not available with C07 or D07.

Motor Space Heater Sequencing Circuit - Light Duty

U10 Provides 50 VA/120 V to terminal block TB1 for motor space heater whenever the motor is not running. 400.00

Rules: Mutually exclusive with V10 unless F10 is also selected.

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Enclosed AC Drives

PowerGard™ Series — Class 8839

Engineered Features

Factory orders with engineered features (E-MOD, SPL, etc.) are subject to review by factory personnel and have

longer lead-time availability. Standard PowerGard™ enclosure dimensions may no longer apply to orders containing

any combination of engineered features. In addition, factory orders containing engineered features may carry a

UL508A (Industrial Control Equipment) label in lieu of a UL508C (Power Conversion Equipment) label depending on

configuration.

Control Options

The E200 series features cover control circuit option configurations for PowerGard™ enclosed drive controllers.

MOD Description $ Price

Seal Water Solenoid

V10 Provides 50 VA/120 V to terminal block TB1 for seal water solenoid whenever the motor is running. 400.00

Rules: Exclusive with U10 unless F10 is also selected.

Check Valve Sequencing Circuit (Gravity Type)

W10

Provides an automatic shutdown of the drive controller when the user supplied N.C. contact from the check valve limit switch does not open within

5 seconds after the motor starts. The user limit switch contact connects to terminal block TB1. Circuit provides reset function with an illuminated

(blue) push-button.

520.00

54 inch wide enclosure

Y10 Provides a 54 inch wide switchboard enclosure for bottom conduit entry space provisions. 275.00

Rules: Available for 450-500 hp ratings only.

24 VDC Power Supply

Z10 Provides a 24 Vdc, 300 mA power supply at terminal block TB1. 370.00

ID Engraved Nameplates

610 Provides an engraved laminated nameplate attached to the front door of the enclosure (engraved per user request at time of order). 100.00

E-MOD Description $ Price

Door mounted meters (dedicated displays)

Provides a dedicated door mounted meter display, analog or digital.

E201 Analog percent speed meter scaled 0 to 120% base speed. 540.00

E202 Analog percent current scaled 0 to 100% of rated output current. 540.00

E203 Digital ammeter (amperes) scaled 0 to 2 times rated output amperes. 630.00

E204 Digital speed meter (frequency) scaled 0 to 72 Hz output frequency. 630.00

E205 Digital percent speed meter scaled 0 to 120% base speed. 630.00

E206 Digital percent current scaled 0 to 100% of rated output current. 630.00

Rules: 1. Limited to one meter selection unless H09 is selected.

2. If H09 is selected, (1) additional meter can be selected.

Door mounted RJ45 port

E211 Provides (1) Sixnet RJ45 door mounted 30 mm bulk head connector and internal CAT5 cabling for access via PC with PowerSuite software. The

RJ45 (Modbus/CANopen) drive port provides customer access through the enclosure door. 325.00

Auxiliary drive run contacts

E212 Provides (3) Form 'C' contacts rated 5 A @ 120 V wired to terminal blocks for customer use. 310.00

Note: One (1) Form 'C' contact for drive run indication is supplied as standard.

Rules: 1. Available only if K10 is selected.

2. Available without K10 for 100-450 hp CT /125-500 hp VT.

Auxiliary bypass run contacts

E213 Provides (3) Form 'C' contacts rated 5 A @ 120 V wired to terminal blocks for customer use. 310.00

Note: One (1) N.O. contact for bypass run indication is supplied as standard when bypass is provided.

Rules: 1. Available only if M10 is selected.

2. Available without M10 for 100-450 hp CT / 125-500 hp VT.

Auxiliary drive fault contacts

E214 Provides (3) Form 'C' contacts rated 5 A @ 120 V wired to terminal blocks for customer use. 310.00

Note: One (1) Form 'C' contact for drive fault indication is supplied as standard.

Rules: Available only if L10 is selected.

Auxiliary auto mode contacts

E215 Provides (3) Form 'C' contacts rated 5 A @ 120 V wired to terminal blocks for customer use. 310.00

Note: One (1) N.O. contact for auto mode indication is supplied as standard when auto mod operation is provided.

Rules: Available only if O10 is selected.

Adjustable restart delay timer

E216 Provides an adjustable On Time Delay Relay for power up restart function, mounted and wired for AFC mode (hand or auto) mode and/or in the

bypass mode (hand/auto). 240.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Enclosed AC Drives

PowerGard™ Series — Class 8839

E-MOD Description $ Price

Motor space heater (heavy duty)

E217 Provides control circuit contacts, 120 V, 500 VA supply and fusing wired to terminals for customer use. 1000.00

Signal loss follower alarm relay

E218

Provides (1) Form 'C' contact rated 5 A @ 120 V wired to terminal blocks for customer use. Intended for 4-20 mAdc control loop applications

where upon the loss of input signal it is desired to retain the output signal at the last input signal level. The relay provides an alarm relay contact

for signal loss alert.

360.00

Note: Requires use of logic output LO1.

Inhibit/shutdown sequence (timed operation)

E219 Provides a relay circuit operating in the fail safe mode where a remote initiating contact opens the relay, de-energizes and after a specified time

shuts the drive controller down in the AFC mode (hand or auto) and/or in the bypass mode (hand or auto). 580.00

Check valve sequence (motorized type)

E220

Provides relay circuitry sequenced from a check valve limit switch. A valve closed position limit switch will energize relays that will initiate a remote

valve operating solenoid limited to 50 VA and give a run permissive to the drive controller in the AFC mode (hand or auto) and/or in the bypass

mode (hand or auto). A valve closed position limit switch will de-energize a timer relay such that if this relay is not de-energized within a specified

time period, the drive controller will shut down in the AFC mode (hand or auto) and/or in the bypass mode (hand or auto).

710.00

Seal water solenoid - with pressure switch feedback

E221

Provides relay, which will energize a remote seal water solenoid limited to 50 VA during drive controller operation. Additionally, the remote initiating

contact will open the relay, de-energizing and after a specified time shuts the drive controller down in the AFC mode (hand or auto) and/or in the

bypass mode (hand or auto).

1220.00

Moisture detection relay circuit (without relay)

E222 Provides 24 V or 120 V control power to a customer supplied moisture detection relay device, either electronic or electro-mechanical. Factory

provides pre-wired socket or mounting space only. 350.00

Note: Customer supplies relay. Details concerning type must also be provided at time of order entry in “Engineering Notes” within Q2C.

Moisture detection relay circuit (with relay options)

E223A Relay option: Provides 24 V or 120 V control power to a moisture detection relay device, either electronic or electro-mechanical. The moisture

detection relay is mounted and wired by the factory. 1220.00

E223B

Relay and Pilot Light indication option: Provides 24 V or 120 V control power to a customer supplied moisture detection relay device, either

electronic or electro-mechanical. Includes a pilot light for discrete input(s). The customer supplied moisture detection relay is mounted and wired

by the factory.

1395.00

Note: Details concerning type must be provided at time of order entry in “Engineering Notes” within Q2C.

Substitute Type K operators

E224 Provides Class 9001 Type K 30mm heavy duty multi-function operators in lieu of standard 22mm pilot devices. 410.00

Spare control relays (for customer use)

E225 Provides control relays mounted and unwired for customer use. Up to (3) are available. 150.00

each

Substitute pilot light lens color(s)

E226 Provides the flexibility to configure lens cap colors to contract equipment designations. —

Notes: Specify lens cap colors desired at time of order entry in “Engineering Notes” field within Q2C.

Blown fuse indicators on control fuses

E227 Provides blown circuit fuse indicators on control circuit fuses in lieu of standard fuses. 750.00

Motor over temperature logic input

E228 Provides dedicated terminals using an external motor over temperature input (N.C. contact) factory wired and programmed. 186.00

RTD inputs (motor protection alarm)

E229 Provides capability for accepting RTD inputs using an RTD limit alarm, factory mounted and wired. Limited to three (3) RTD inputs. 4122.00

Note: Specify RTD values at time of order entry in 'Engineering Notes' within Q2C.

Motor management relay option

Provides motor protection and metering functions using a selection of motor management relays. This relay provides protection for motor and load conditions:

overload, differential, stator temperature, high inertia loads, undercurrent, under power, jam and bearing over temperature. The motor management relay is factory

mounted and wired. Includes PT's and CT's.

E230A Schneider Electric Sepam® Series 20 motor protective relay. 2850.00

E230B Schneider Electric Sepam® Series 41 motor protective relay. 3975.00

E230C GE Multilin® 269+ motor management relay. 13995.00

E230D GE Multilin® 469 motor management relay. 14750.00

PowerLogic® power meter display option

Provides a Class 3020 PM800 series power module true rms meter display with basic instrumentation, demand, THD, date/time stamping, neutral current, min/max,

alarms, event and data storage factory mounted and wired.

E231A PM820 power module. 1400.00

E231B PM850 power module. 1550.00

E231C PM870 power module. 1995.00

Trademarks used herein are properties of their respective owners.

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Enclosed AC Drives

PowerGard™ Series — Class 8839

E-MOD Description $ Price

PowerLogic circuit monitor option

Provides a Class 3020 CM3000/CM4000 series circuit monitor display with instrumentation, 0.2% accuracy, data logging and waveform capture, factory mounted

and wired. Includes PT's and CT's.

E232A CM3250 circuit monitor. 2415.00

E232B CM3350 circuit monitor. 2415.00

E232C CM4000T circuit monitor. 4275.00

E232D CM4250 circuit monitor. 4275.00

Spare terminal blocks (unwired)

E234 Provides (10) spare terminal blocks 'unwired' for customer use using the Class 9080 Type G series terminals. 120.00

End damper control circuit

E235 Provides a damper control circuit to coordinate starting of the drive controller or the bypass with the position of the damper. Requires

connection to customer damper limit switch. 240.00

Emergency power off push-button

E236

Provides a shunt trip modified molded case switch or circuit breaker where a push-pull maintained mushroom head push-button energizes the

shunt trip coil and instantaneously opens to shut down power supplied to the drive controller in the AFC mode and/or bypass mode, coasting to

an uncontrolled stop.

540.00

Audible alarm horn with silence

E238 Provides an audible alarm horn, timer to annunciate a user defined conditions with a silencer push-button, factory assembled and wired for

customer use. 625.00

Three phase ammeter with selector switch

Provides 3 CT's with 3-position selector switch to indicate Phase A, B or C connected on the motor leads to monitor full load amps.

E239A Monitor input full load amps. 1575.00

E239B Monitor output full load amps. 1575.00

Basin high level alarm indication option

E240A Alarm with pilot light: Provides relay circuit and pilot light indicator alarm for high level alarm limit switch via contact closure. Includes master reset

push-button and (1) Form 'C' contact for customer use. 795.00

E240B

Command to run and alarm with pilot light indication: Provides relay circuit, timer and pilot light indicator sequenced for high level alarm limit switch

via contact closure, energizing the drive controller and/or bypass to run full speed. Includes master reset push-button and (1) Form 'C' contact for

customer use.

895.00

Basin low level stop with pilot light indication

E241 Provides relay circuit and pilot light indicator sequenced for low level alarm limit switch via N.O./N.C. contact closure, causing the drive controller

to stop. Includes master reset push-button and (1) Form 'C' contact for customer use. 795.00

Enclosure ventilation fan shutdown

E242 Provides interlocking and timer functions of enclosure ventilation fans to shutdown during drive controller idle conditions. 795.00

High discharge pressure with pilot light indication

E243 Provides relay circuitry with pilot light indicator sequenced from a pressure switch input, causing the drive controller to stop. Includes master reset

push-button and (1) Form 'C' contact for customer use. 795.00

Low discharge pressure with pilot light indication

E244 Provides relay circuit, timer with pilot light sequenced from a pressure switch input when low discharge condition. Includes master reset

push-button and (1) Form 'C' contact for customer use. 795.00

Low seal water shutdown with pilot light indication

E245 Provides relay circuitry, timer with pilot light sequenced from a pressure switch input when not enough seal water is supplied. Includes master

reset push-button and (1) Form 'C' contact for customer use. 795.00

Rules: Mutually exclusive to E221.

Motor over temperature shutdown with pilot light

E246 Provides dedicated terminals using an external motor over temperature input (Form 'C' contact) and a pilot light indicator factory wired and

programmed. 380.00

Rules: Mutually exclusive to E228.

Phase failure relay

E247 Provides a phase failure relay (Tele RM4T series) mounted and wired to indicate phase reversal, phase loss and imbalance operating

conditions. 725.00

Rules: Available with Power Circuits Y, Z, S, T or R only.

Single test pilot light push-button

E248 Provides a dedicated 30mm push-to-test button for indication of operable pilot lights. 130.00

Rules: Must also select E224.

Substitute TeSys® 600V relay(s)

E249 Substitutes TeSys® Type NEMA rated relays rated 600 V, 10 A. 985.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Enclosed AC Drives

PowerGard™ Series — Class 8839

Enclosure & Miscellaneous Modifications

The E300 series features cover enclosure and miscellaneous option configurations for the PowerGard™ enclosed

drive controller.

Power Options

The E400 series features cover engineered power option configurations for PowerGard™ enclosed drive controllers.

E-MOD Description $ Price

ANSI #61 enclosure paint

E301 Provides option to configure enclosure paint to industry standard ANSI #61 light gray paint in lieu of ANSI #49 gray. 526.00

Enclosure space heater option

E305A Space heater only: Provides a Hoffman type enclosure strip heater and thermostat to maintain internal low temperature ambient ratings. 1500.00

E305B Space heater with storage operation provision: Provides a Hoffman type enclosure strip heater and thermostat to maintain internal low

temperature ambient ratings. Includes 120 V remote source input terminals for operation during storage conditions. 1800.00

E-MOD Description $ Price

Motor protection filter

Provides a factory mounted and wired dV/dt filter on the drive output for long motor lead lengths considerations in excess of our published guidelines, up to 1000 feet.

E402

40 hp CT 1895.00

50-60 hp 2675.00

75 hp 3145.00

100 hp 3675.00

125 hp 5025.00

150 hp 5230.00

200 hp 5330.00

250 hp 5365.00

300 hp 5645.00

350 hp 6540.00

400hp 6980.00

450-500 hp 7310.00

Transient voltage surge suppressor

E405 Provides supplementary surge protection using a Class 1310 TVSS XWF Series Transient Voltage Surge Suppressor hard-wired and factory

mounted. 100,000 peak volts of surge protection. 1885.00

Note: Service connection type (Delta or Wye) must be specified in “Engineering Notes” within Q2C.

SEMI F47 compliance

Provides modified drive controller settings and hardware configuration for ride-through capability to comply with SEMI F47-0200 standards, 50% voltage sag, 200ms

sustained without interruption. Drive must be configured for 2-wire control and the start signal must maintain during sag conditions.

E408 Power Circuit W 1169.

Power Circuits Y, S, Z, T or R 1675.

Secondary surge arrestor

E413 Provides a secondary surge arrester Class 6671 SDSA3650 mounted and wired. 485.

3% output reactor

Provides a 3% rated output reactor to address long lead considerations, mounted and wired.

E414

40 hp CT 1450.

50-60 hp 1650.

75-100 hp 1750.

125 hp 1850.

150 hp 2050.

200 hp 3150.

250 hp 3450.

300-350 hp 4350.

400-450 hp CT / 400-500 hp VT 4850.

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

Altivar® 11

Adjustable Frequency AC Drives

The ALTIVAR 11 is an adjustable speed drive that incorporates sensorless flux vector control technology in a

compact, nano drive design. This cost-effective solution improves low-speed torque, speed regulation and starting

torque over traditional per hertz drives, while offering excellent performance and reliability.

aPower ratings are for a switching frequency of 4 kHz in continuous operation.

bATV11P... units have baseplates for mounting on steel or aluminum frames.

cResistor Not Supplied.

dIntended for use with PowerSuite cable kits pruchased before December 2002. The adapter will be included in kits VW3A9106 and VW3A8111 in

December 2002.

Table 17: Selection and Pricing

Voltage + 10% -15% 50/60 Hz MotoraNominal

Current Rating

Catalog

Numberb$ Price

Input Output kW Horsepower

115 V

single phase

230 V

three phase

0.18 0.25 1.6 ATV11HU05F1U 181.00

0.37 0.5 2.4 ATV11HU09F1U 188.00

0.75 1 4.6 ATV11HU18F1U 220.00

0.37 0.5 2.4 ATV11PU09F1U 188.00

230 V

single phase

230 V

three phase

0.18 0.25 1.6 ATV11HU05M2U 181.00

0.37 0.5 2.4 ATV11HU09M2U 188.00

0.75 1 4.6 ATV11HU18M2U 220.00

1.5 2 7.5 ATV11HU29M2U 285.00

2.2 3 10.6 ATV11HU41M2U 342.00

0.37 0.5 2.4 ATV11PU09M2U 188.00

0.75 1 4.6 ATV11PU18M2U 220.00

230 V

three phase

230 V

three phase

0.18 0.25 1.6 ATV11HU05M3U 166.00

0.37 0.5 2.4 ATV11HU09M3U 173.00

0.75 1 4.6 ATV11HU18M3U 202.00

1.5 2 7.5 ATV11HU29M3U 262.00

2.2 3 10.6 ATV11HU41M3U 314.00

0.37 0.5 2.4 ATV11PU09M3U 173.00

0.75 1 4.6 ATV11PU18M3U 202.00

Table 18: Options

Description Catalog Number $ Price

EMC Filters .25 to 1 hp—Single Phase VW3A11401 105.00

EMC Filters 2 to 3 hp—Single Phase VW3A11402 160.00

EMC Filters .25 to 1 hp—Three Phase VM3A11403 120.00

EMC Filters 2 to 3 hp—Three Phase VM3A11404 180.00

Adapter Kit VW3A11811 25.00

DIN Rail Kit .25 to 1 hp VW3A11851 25.00

DIN Rail Kit 2 to 3 hp VW3A11852 25.00

Braking ModulecVW3A11701 105.00

ECM Mounting Plate VW3A11831 25.00

Replacement Fan Kit 1 to 3 hp VW3A11821 50.00

PowerSuite Commissioning Software V1.4 VW3A8104 150.00

PowerSuite upgrade CD — provides upgrade to most recent version VW3A8105 98.00

PowerSuite cable adapterdVW3A11301 45.00

Cable kit for use with PowerSUite commissioning software on PC VW3A8106 75.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

Altivar® 31

Selection and Pricing

aThese horsepower, wattage, and continuous ampere ratings apply to 4 kHz switching frequency and maximum 50°C ambient. Refer to the installation

manual for derating curves as a function of switching frequency, ambient temperature, and mounting conditions.

bOpen type Altivar 31 Drives can be installed as UL Type 1 with optional conduit box when following instructions in the installation manual.

cAdd the letter “A” to the end of the standard open type catalog number for a drive controller with a reference potentiometer and RUN/STOP buttons.

This does not apply to the IP54 / UL Type 12 products.

dA minimum 3% line reactor is required on all 575 V drive installations.

Table 19: Altivar® 31 Selection and Pricing

Input Line

Vol tage

Three Phase Motor PoweraOpen DrivesbIP54 / UL Type 12 Enclosed

kW HP AaCatalog Number Standard

$ Price

Local Control

$ PricecCatalog Number Standard

$ Price

208/230 Vac

Single Phase

0.18 0.25 1.5 ATV31H018M2 268.00 308.00 ATV31C018M2 362.00

0.37 0.5 3.3 ATV31H037M2 287.00 330.00 ATV31C037M2 387.00

0.55 0.75 3.7 ATV31H055M2 306.00 352.00 ATV31C055M2 413.00

0.75 1 4.6 ATV31H075M2 335.00 385.00 ATV31C075M2 452.00

1.1 1.5 6.9 ATV31HU11M2 363.00 418.00 ATV31CU11M2 490.00

1.5 2 8 ATV31HU15M2 402.00 462.00 ATV31CU15M2 543.00

2.2 3 11 ATV31HU22M2 468.00 539.00 ATV31CU22M2 632.00

208/230 Vac

Three Phase

0.18 0.25 1.5 ATV31H018M3X 258.00 297.00 — —

0.37 0.5 3.3 ATV31H037M3X 287.00 330.00 — —

0.55 0.75 3.7 ATV31H055M3X 306.00 352.00 — —

0.75 1 4.8 ATV31H075M3X 325.00 374.00 — —

1.1 1.5 6.9 ATV31HU11M3X 363.00 418.00 — —

1.5 2 8 ATV31HU15M3X 421.00 484.00 — —

2.2 3 11 ATV31HU22M3X 478.00 550.00 — —

3 4 13.7 ATV31HU30M3X 554.00 638.00 — —

— 5 17.5 ATV31HU40M3X 650.00 748.00 — —

5.5 7.5 27.5 ATV31HU55M3X 841.00 967.00 — —

7.5 10 33 ATV31HU75M3X 1013.00 1165.00 — —

11 15 54 ATV31HD11M3X 1338.00 1539.00 — —

15 20 66 ATV31HD15M3X 1721.00 1979.00 — —

400/480 Vac

Three Phase

0.37 0.5 1.5 ATV31H037N4 363.00 418.00 ATV31C037N4 490.00

0.55 0.75 1.9 ATV31H055N4 392.00 451.00 ATV31C055N4 529.00

0.75 1 2.3 ATV31H075N4 421.00 484.00 ATV31C075N4 568.00

1.1 1.5 3 ATV31HU11N4 449.00 517.00 AT V 3 1 C U 1 1 N 4 606.00

1.5 2 4.1 ATV31HU15N4 497.00 572.00 AT V 3 1 C U 1 5 N 4 671.00

2.2 3 5.5 ATV31HU22N4 574.00 660.00 AT V 3 1 C U 2 2 N 4 774.00

3 4 7.1 ATV31HU30N4 650.00 748.00 AT V 3 1 C U 3 0 N 4 878.00

— 5 9.5 ATV31HU40N4 688.00 792.00 AT V 3 1 C U 4 0 N 4 929.00

5.5 7.5 14.3 ATV31HU55N4 860.00 989.00 AT V 3 1 C U 5 5 N 4 1162.00

7.5 10 17 ATV31HU75N4 1052.00 1209.00 AT V 3 1 C U 7 5 N 4 1420.00

11 15 27.7 ATV31HD11N4 1386.00 1594.00 AT V 3 1 C D 1 1 N 4 1733.00

15 20 33 ATV31HD15N4 1721.00 1979.00 AT V 3 1 C D 1 5 N 4 2151.00

575/600 Vac

Three Phased

0.75 1 1.7 ATV31H075S6X 484.00 —— —

1.5 2 2.7 ATV31HU15S6X 572.00 —— —

2.2 3 3.9 ATV31HU22S6X 660.00 —— —

3.7/4.0 5 6.1 ATV31HU40S6X 792.00 —— —

5.5 7.5 9 ATV31HU55S6X 989.00 —— —

7.5 10 11 ATV31HU75S6X 1209.00 —— —

11 15 17 ATV31HD11S6X 1594.00 —— —

15 20 22 ATV31HD15S6X 1979.00 —— —

ATV31H

Open Type Drive

ATV31C

IP54 / UL Type 12

ATV31H037M2A

Open Drive with Local Operator

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

Altivar® 31

NOTE: Reference Catalog #8800CT0401 for communication cables.

Table 20: Altivar 31 Options

Description For Use on Drives Catalog Number $ Price

Simple Loader Using RJ45 port connections, the configurations of a drive can be downloadedthen

uploaded to compatible drive.

ATV31, ATV61

and ATV71 VW3A8120 175.00

User Interface Kits

Powersuite

(SoMove) Test and

Cimmissioning

Software Kit

Software on CD-ROM. For use with Microsoft Windows 95, 98, NT, and XP

operating systems for PCs ATV31 all ranges VW3A8104 150.00

PC Cable

for Test and

Commissioning

Software

Includes a 3 meter (9.8 ft) cable, an RS-485/RS-232C adapter, and connectors All Altivar Drives VW3A8106 75.00

Table 21: Options—Field Installed Kits

Description For Use on Drives Catalog Number $ Price

DIN Rail

Mount Kit DIN Rail Mounting Plate for 35 mm wide DIN rail

ATV31H018M2, ATV31H037M2,

ATV31H055M2, ATV31H075M2,

ATV31H018M3X, ATV31H037M3X,

ATVH055M3X, ATV31H075M3X

VW3A11851 25.00

ATV31HU11M2, ATV31HU15M2,

ATV31HU11M3X, ATV31HU15M3X,

ATV31HU22M3X, ATV31H037N4,

ATV31H055N4, ATV31H075N4,

ATV31HU11N4, ATV31HU15N4,

ATV31H075S6X, ATV31HU15S6X

VW3A31852 25.00

Conduit

Entrance Kit

Multiple knockout sizes

Installation of conduit entrance kit and retention of vent cover on

top of drive controller provides the ATV31 with UL Type 1 rating.

ATV31H018M2, ATV31H037M2,

ATV31H055M2, ATV31H075M2 VW3A31812 45.00

ATV31H018M3X, ATV31H037M3X,

ATV31H055M3X, ATV31H075M3X VW3A31811 45.00

ATV31HU11M3X, ATV31HU15M3X VW3A31813 45.00

ATV31HU11M2, ATV31HU15M2,

ATV31HU22M3X, ATV31H037N4,

ATV31H055N4, ATV31H075N4,

ATV31HU11N4, ATV31HU15N4,

ATV31H075S6X, ATV31HU15S6X

VW3A31814 45.00

ATV31HU22M2, ATV31HU30M3X,

ATV31HU40M3X, ATV31HU22N4,

ATV31HU30N4, ATV31HU40N4,

ATV31HU22S6X, ATV31HU40S6X

VW3A31815 45.00

ATV31HU55M3X, ATV31HU75M3X,

ATV31HU55N4, ATV31HU75N4,

ATV31HU55S6X, ATV31HU75S6X

VW3A31816 45.00

ATV31HD11M3X, ATV31HD15M3X,

ATV31HD11N4, ATV31HD15N4,

ATV31HD11S6X, ATV31HD15S6X

VW3A31817 45.00

AT V 2 8

Replacement

Kit

This kit contains brackets that adapt the spacing of the ATV31

mounting holes to be equivalent to that of an ATV28 with the

same rating. This will permit the ATV31 to be secured to the

panel holes and mounting hardware already in place for the

AT V 28 .

ATV31H018M2, ATV31H037M2,

ATV31H055M2, ATV31H075M2

ATV31H018M3X, ATV31H037M3X,

ATV31H055M3X, ATV31H075M3X

VW3A31821 25.00

ATV31HU11M2, ATV31HU15M2,

ATV31HU11M3X, ATV31HU15M3X,

ATV31HU22M3X, ATV31H075S6X,

ATV31HU15S6X

VW3A31822 25.00

ATV31HU55N4, ATV31HU75N4,

ATV31HU55M3X, ATV31HU75M3X,

ATV31HU55S6X, ATV31HU75S6X

VW3A31823 25.00

Dynamic

Braking

Resistor Kit

DB resistors are provided in a Type 1 enclosure and are

thermally protected.

ATV31H018M2–037M2

VW3A66711 422.00ATV31H018M3X–037M3X

ATV31H037N4–U40N4

ATV31H055M2–U22M2

VW3A66712 633.00ATV31H055M3X–U22M3X

ATV31HU55N4–U75N4

ATV31HU30M3X–U40M3X VW3A66713 950.00

ATV31HD11N4–D15N4

ATV31HU55M3X–U75M3X VW3A66714 1266.00

ATV31HD11M3X–D15M3X VW3A66715 1846.00

CP4B Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

Altivar® 31

Options—Field Installed Kits (Continued)

Description For Use on Drives Catalog Number $ Price

Line Reactors

230/460 V See page 56 of this Price Guide.

575 V

Open Style

ATV31H075S6X RL00202 158.00

ATV31HU15S6X RL00403 163.00

ATV31HU22S6X

ATV31HU40S6X RL00803 245.00

ATV31HU55S6X RL00802 179.00

ATV31HU75S6X RL01202 200.00

ATV31HD11S6X RL01802 253.00

ATV31HD15S6X RL02502 291.00

Enclosed (Type 1)

ATV31H075S6X RL00212 289.00

ATV31HU15S6X RL00413 294.00

ATV31HU22S6X

ATV31HU40S6X RL00813 379.00

ATV31HU55S6X RL00812 310.00

ATV31HU75S6X RL01212 332.00

ATV31HD11S6X RL01812 388.00

ATV31HD15S6X RL02512 507.00

RFI Input Filter

For compliance with European

(CE) conducted emissions

standard 55022 Class B

(Class A filter built into

230/460 V ATV31 drives)

Single phase

supply voltage:

200–240 V 50/60 Hz

ATV31H037M2 ATV31H055M2

ATV31H075M2 VW3A31401 58.00

ATV31HU11M2 ATV31HU15M2 VW3A31403 79.00

ATV31HU22M2 VW3A31405 108.00

3-phase supply

voltage: 200–240 V

50/60 Hz

ATV31H018M3X ATV31H037M3X

ATV31H055M3X ATV31H075M3X VW3A31402 72.00

ATV31HU11M3X ATV31HU15M3X

ATV31HU22M3X VW3A31404 90.00

ATV31HU30M3X ATV31HU40M3X VW3A31406 133.00

ATV31HU55M3X ATV31HU75M3X VW3A31407 189.00

ATV31HD11M3X ATV31HD15M3X VW3A31408 297.00

ATV31HD11N4 ATV31HD15N4 VW3A31409 243.00

3-phase supply

voltage: 380–500 V

50/60 Hz

ATV31H037N4 ATV31H055N4

ATV31H075N4 ATV31HU11N4

ATV31HU15N4

VW3A31404 90.00

ATV31HU22N4 ATV31HU30N4

ATV31HU40N4 VW3A31406 133.00

ATV31HU55N4 ATV31HU75N4 VW3A31407 189.00

ATV31HD11N4 ATV31HD15N4 VW3A31409 243.00

CP4B Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

Altivar® 71 — Class 8800

aOption to have product treated for increased protection for dusty and corrosive environments. This product is not stocked. Add “S337” to the end of

the catalog number and multiply the listed price by 1.2 to obtain new price. With this option, exposed copper is tinned, circuit boards are conformal

coated in critical areas and plastics are treated to better withstand the corrosive nature of certain oils. This option is standard on 55 kW/75 hp @ 230

Vac and higher & 90 kW/125 hp @ 460 Vac and higher.

bThese products require a user supplied 3% line reactor when used with single-phase input.

cProduct does not contain an EMC filter.

dProduct ships with a DC choke that must be field mounted. A 5% line reactor may be purchased and installed in place of the DC choke. Add “D” to

the end of the catalog number to receive just the AC drive and multiply the listed price by .96 to obtain new price.

eAlso possible for use with a synchronous motor. Add “383” to the end of the catalog number and multiply the listed price by 1.2 to obtain new price.

fOption to have product treated for increased protection for dusty and corrosive environments. This product is not stocked. Add “337” to the end of the

catalog number and multiply the listed price by 1.2 to obtain new price. With this option, exposed copper is tinned, circuit boards are conformal coated

in ciritical areas and plastics are treated to better withstand the corrosive nature of certain oils. This option is standard on 55 kW/7 hp @ 230 Vac and

higher and 90 kW/125 hp @ 460 Vac and higher.

gConformal coating is standard.

hAn AC 5% line reactor is mandatory.

Table 22: Altivar® 71 Selection and Pricing

Input

Line

Voltage

Constant Torque

$ Price

Catalog Numer

ATV71 drive and Type

conduit entry kit

$ Price

Catalog Number

with LED Keypad

(Non-stocked)

$ Price

Three-Phase

Motor Power

Continuous

Output

Current

hp kW A

208/240 Vac

Single

Phase

0.5 0.37 3 ATV71H075M3ae 652.00 ATV71H075M3T1 697.00 ATV71H075M3Z 557.00

10.75 4.8 ATV71HU15M3ae 684.00 ATV71HU15M3T1 729.00 ATV71HU15M3Z 589.00

21.5 8 ATV71HU22M3ae 796.00 ATV71HU22M3T1 841.00 ATV71HU22M3Z 701.00

3 2.2 11 ATV71HU30M3ae 984.00 ATV71HU30M3T1 1029.00 ATV71HU30M3Z 889.00

4 3 13.7 ATV71HU40M3abc 1150.00 ATV71HU40M3T1bc 1195.00 ATV71HU40M3Zbc 1055.00

5 4 17.5 ATV71HU55M3abce 1458.00 ATV71HU55M3T1bc 1503.00 ATV71HU55M3Zbc 1363.00

7.5 5.5 27.5 ATV71HU75M3abce 1790.00 ATV71HU75M3T1bc 1835.00 ATV71HU75M3Zbc 1695.00

208/240 Vac

Three

Phase

0.5 0.37 3 ATV71H037M3ae 616.00 ATV71H037M3T1 661.00 ATV71H037M3Z 521.00

1 0.75 4.8 ATV71H075M3ae 652.00 ATV71H075M3T1 697.00 ATV71H075M3Z 557.00

21.5 8 ATV71HU15M3ae 684.00 ATV71HU15M3T1 729.00 ATV71HU15M3Z 589.00

3 2.2 11 ATV71HU22M3ae 796.00 ATV71HU22M3T1 841.00 ATV71HU22M3Z 701.00

4 3 13.7 ATV71HU30M3ae 984.00 ATV71HU30M3T1 1029.00 ATV71HU30M3Z 889.00

5 4 17.5 ATV71HU40M3ae 1150.00 ATV71HU40M3T1 1195.00 ATV71HU40M3Z 1055.00

7.5 5.5 27.5 ATV71HU55M3ae 1458.00 ATV71HU55M3T1 1503.00 ATV71HU55M3Z 1363.00

10 7.5 33 ATV71HU75M3ae 1790.00 ATV71HU75M3T1 1835.00 ATV71HU75M3Z 1695.00

15 11 54 ATV71HD11M3Xcef 2270.00 ATV71HD11M3XT1c2315.00 ATV71HD11M3XZc2175.00

20 15 66 ATV71HD15M3Xcef 2850.00 ATV71HD15M3XT1c2895.00 ATV71HD15M3XZc2755.00

25 18 75 ATV71HD18M3Xcef 3422.00 ATV71HD18M3XT1c3487.00 ——

30 22 88 ATV71HD22M3Xcef 4170.00 ATV71HD22M3XT1c4235.00 ——

40 30 120 ATV71HD30M3Xcef 5348.00 ATV71HD30M3XT1c5433.00 ——

50 7 144 ATV71HD37M3Xcef 6212.00 ATV71HD37M3XT1c6297.00 ——

60 45 176 ATV71HD45M3Xcef 7356.00 ATV71HD45M3XT1c7491.00 ——

75 55 221 ATV71HD55M3Xcdeg 8870.00 ATV71HD55M3XT1c9330.00 ——

100 75 285 ATV71HD75M3Xcdeg 10658.00 ATV71HD75M3XT1c11211.00 ——

LCD Keypad

LED Keypad

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

Altivar® 71 — Class 8800

aOption to have product treated for increased protection for dusty and corrosive environments. This product is not stocked. Add “S337” to the end of

the catalog number and multiply the listed price by 1.2 to obtain new price. With this option, exposed copper is tinned, circuit boards are conformal

coated in critical areas and plastics are treated to better withstand the corrosive nature of certain oils. This option is standard on 55 kW/75 hp @ 230

Vac and higher & 90 kW/125 hp @ 460 Vac and higher.

bThese products require a user supplied 3% line reactor when used with single-phase input.

cProduct does not contain an EMC filter.

dProduct ships with a DC choke that must be field mounted. A 5% line reactor may be purchased and installed in place of the DC choke. Add “D” to

the end of the catalog number to receive just the AC drive and multiply the listed price by .96 to obtain new price.

eAlso possible for use with a synchronous motor. Add “383” to the end of the catalog number and multiply the listed price by 1.2 to obtain new price.

fOption to have product treated for increased protection for dusty and corrosive environments. This product is not stocked. Add “337” to the end of the

catalog number and multiply the listed price by 1.2 to obtain new price. With this option, exposed copper is tinned, circuit boards are conformal coated

in ciritical areas and plastics are treated to better withstand the corrosive nature of certain oils. This option is standard on 55 kW/7 hp @ 230 Vac and

higher and 90 kW/125 hp @ 460 Vac and higher.

gConformal coating is standard.

hAn AC 5% line reactor is mandatory.

iThese products do not contain a dynamic braking transistor. A separate transistor must be added for applications requiring dynamic braking.

Altivar® 71 Selection and Pricing (continued)

Input

Line

Voltage

Constant Torque

Catalog Numer

with LCD Keypad

(Stocked)

$ Price

Catalog Numer

to have ATV71 drive and

Type 1 conduit entry kit

shipped as one line item.

Field installation required

(Packaged as kit at

warehouse).

$ Price

Catalog Number

with LED Keypad

(Non-stocked)

$ Price

Three-Phase

Motor Power

Continuous

Output

Current

hp kW A

400/480 Vac

Three

Phase

1 0.75 2.3 ATV71H075N4ae 794.00 ATV71H075N4T1 839.00 ATV71H075N4Z 699.00

2 1.5 4.1 ATV71HU15N4ae 912.00 ATV71HU15N4T1 957.00 ATV71HU15N4Z 817.00

3 2.2 5.8 ATV71HU22N4ae 1110.00 ATV71HU22N4T1 1155.00 ATV71HU22N4Z 1015.00

4 3 7.8 ATV71HU30N4ae 1250.00 ATV71HU30N4T1 1295.00 ATV71HU30N4Z 1155.00

5 4 10.5 ATV71HU40N4ae 1316.00 ATV71HU40N4T1 1361.00 ATV71HU40N4Z 1221.00

7.5 5.5 14.3 ATV71HU55N4ae 1584.00 ATV71HU55N4T1 1629.00 ATV71HU55N4Z 1489.00

10 7.5 17.6 ATV71HU75N4ae 1924.00 ATV71HU75N4T1 1969.00 ATV71HU75N4Z 1829.00

15 11 27.7 ATV71HD11N4ae 2278.00 ATV71HD11N4T1 2323.00 ATV71HD11N4Z 2183.00

20 15 33 ATV71HD15N4ae 2832.00 ATV71HD15N4T1 2877.00 ATV71HD15N4Z 2737.00

25 18 41 ATV71HD18N4ae 3408.00 ATV71HD18N4T1 3453.00 ATV71HD18N4Z 3313.00

30 22 48 ATV71HD22N4ae 3710.00 ATV71HD22N4T1 3775.00 ATV71HD22N4Z 3615.00

40 30 66 ATV71HD30N4ae 4566.00 ATV71HD30N4T1 4631.00 ATV71HD30N4Z 4471.00

50 37 79 ATV71HD37N4ae 5370.00 ATV71HD37N4T1 5435.00 ATV71HD37N4Z 5275.00

60 45 94 ATV71HD45N4ae 6742.00 ATV71HD45N4T1 6877.00 ATV71HD45N4Z 6647.00

75 55 116 ATV71HD55N4ae 7762.00 ATV71HD55N4T1 7897.00 ATV71HD55N4Z 7667.00

100 75 160 ATV71HD75N4ae 8862.00 ATV71HD71N4T1 8997.00 ATV71HD75N4Z 8767.00

125 90 179 ATV71HD90N4de 9742.00 ATV71HD90N4T1 10202.00 ——

150 110 215 ATV71HC11N4de 11002.00 ATV71HC11N4T1 11555.00 ——

200 130 259 ATV71HC13N4de 12642.00 ATV71HC13N4T1 13215.00 ——

250 160 314 ATV71HC16N4de 14282.00 ATV71HC16N4T1 14870.00 ——

300 200 387 ATV71HC20N4dei 16462.00 ATV71HC20N4T1 17066.00 ——

400 250 481 ATV71HC25N4dei 19382.00 ATV71HC25N4T1 19986.00 ——

450 280 550 ATV71HC28N4dei 23002.00 ATV71HC28N4T1 23606.00 ——

500 310 616 ATV71HC31N4dei 27922.00 ————

600 400 759 ATV71HC40N4dei 37392.00 ————

700 500 941 ATV71HC50N4dei 52041.00 ————

575/690 Vac

Three

Phase

2 2.2 2.7 ATV71HU22Yg1889.00 ————

3 3 3.9 ATV71HU30Yg1990.00 ————

4 4 5.8 ATV71HU40Yg2009.00 ————

5 5.5 6.1 ATV71HU55Yg2380.00 ————

7.5 7.5 9 ATV71HU75Yg2799.00 ————

10 11 11 ATV71HD11Yg3380.00 ————

15 15 17 ATV71HD15Yg3979.00 ————

20 18.5 22 ATV71HD18Yg4790.00 ————

25 22 27 ATV71HD22Yg5780.00 ————

30 30 32 ATV71HD30Yg6999.00 ————

40 37 41 ATV71HD37Yg8579.00 ————

50 45 52 ATV71HD45Yg10379.00 ————

60 55 62 ATV71HD55Yg12199.00 ————

75 75 77 ATV71HD75Yg14399.00 ————

100 90 99 ATV71HD90Yg16899.00 ————

125 110 125 ATV71HC11Yg19179.00 ————

150 132 150 ATV71HC13Ygh 23795.00 ————

175 160 180 ATV71HC16Ygh 24290.00 ————

200 200 220 ATV71HC20Yghi 28950.00 ————

250 250 290 ATV71HC25Yghi 35950.00 ————

350 315 355 ATV71HC31Yghi 46750.00 ————

450 400 420 ATV71HC40Yghi 59590.00 ————

550 500 543 ATV71HC50Yghi 78490.00 ————

700 630 675 ATV71HC63Yghi 103390.00 ————

ATV71HC28N4

ATV71HC31Y

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

Altivar® 61 and Altivar 71

Table 23: Options—Field Installed

Description For Use on Drives Catalog No. $ Price

Operator

Interface

LCD graphic keypad: IP54 rating

any ATV61

any ATV71

VW3A1101 115.00

Remote mounting kit: includes bezel and mounting hardware VW3A1102 55.00

Door for use with remote mount kit for IP65 rating VW3A1103 45.00

Cable for remote mounting LCD graphic

keypad

RJ-45 connector on each end

1 meter VW3A1104R10 35.00

3 meters VW3A1104R30 35.00

5 meter VW3A1104R50 35.00

10 meters VW3A1104R100 45.00

RJ-45 female—female adaptor to connect LCD keypad and cable. Not

required if using VW3A1102. VW3A1105 35.00

PowerSuite™

Software

Options

PowerSuite™ software on CD for PC Altivar AC drives

Altistart 48

Tesys U–line

VW3A8104 150.00

Cable connection kit for PC VW3A8106 75.00

For Wireless

Connection Modbus® to Bluetooth® Gateway and RS-485 converter any ATV61

any ATV71 VW3A8114 125.00

I/O Adaptor 115 Vac logic input adaptor adapts 7 logic inputs for use with

user supplied 115 Vac signals

any ATV61

any ATV71 VW3A3101 195.00

I/O Extension

Option Cards

Basic I/O option card—4 logic inputs, 2 logic outputs, 1 Form C relay

output, an input for PTC motor probes, a 24 Vdc output, a—10 Vdc

output any ATV61

any ATV71

VW3A3201 165.00

Extended I/O option card—contains all the I/O on the Basic I/O option

card plus 2 analog inputs, 2 analog outputs, 1 pulse input VW3A3202 195.00

CANopen

Adapter

This adaptor connects to the RJ-45 port and provides a 9–pin male

SUB–D connector conforming to the CANopen standard

(CIA DRP 303–1)

any ATV61

any ATV71 VW3CANA71 45.00

CANopen

Connector

9-pin female SUB–D with line terminator (can be disabled). 180º cable

outlet CAN–H, CAN–L, CAN–GND connection

any ATV61

any ATV71 VW3CANKCDF180T 45.00

Incremental

Encoder

Interface

Option Cards

with RS-422 outputs, 5 Vdc

any ATV71

VW3A3401 85.00

with RS-422 outputs, 15 Vdc VW3A3402 85.00

with open collector outputs, 12 Vdc VW3A3403 85.00

with open collector outputs, 15 Vdc VW3A3404 85.00

with push–pull outputs, 12 Vdc VW3A3405 85.00

with push–pull outputs, 15 Vdc VW3A3406 85.00

with push–pull outputs, 24 Vdc VW3A3407 85.00

Resolver VW3A3408 85.00

Universal with SinCos, SinCos Hiperface®, SinCos EnDat® or SSI output VW3A3409 85.00

incremental with RS422 outputs and encoder emulation VW3A3411 85.00

Communicati

Option Cards

Modbus® Plus card

any ATV61

any ATV71

VW3A3302 550.00

Modbus® / Unitelway card VW3A3303 225.00

Modbus® TCP/IP Daisy Chain VW3A3310D 275.00

Interbus® S card VW3A3304 550.00

Profibus DP card VW3A3307 550.00

Profibus DPv1 card VW3A3307S371 550.00

DeviceNet™ card VW3A3309 225.00

Ethernet/IP card VW3A3316 275.00

Fipio® card VW3A3311 550.00

Lonworks® card

any ATV61

VW3A3312 550.00

MetaSYS® N2 card VW3A3313 225.00

APOGEE FLN P1 card VW3A3314 225.00

BACnet card VW3A3315 225.00

Controller

Inside

Option Card

Programmable option card, conforms with IEC61131–3 programming

standard.

any ATV61

any ATV71 VW3A3501 550.00

Water

Solutions

Control Card

This option card contains a variety of pre-programmed functions and

features to manage multi–pump installations.

any ATV61

any ATV71 VW3A3503 650.00

Simple

Loader

Using RJ45 port connections, the configurations of a drive can be

downloaded then uploaded to compatible drive. ATV31, ATV61 and ATV71 VW3A8120 175.00

The drive cannot support the VW3A3503 water solutions card and the VW3A3501 controller inside option card simultaneously.

For use with the ATV71H...383 drive ONLY.

LCD Keypad

Mounting Kits

Option Card Assembly

I/O Option Card

Communication

Option Card

Incremental

Encoder Interface

Option Card

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

Altivar® 61 and Altivar 71

Options—Field Installed (continued)

Description For Use on Drives Catalog No. $ Price

Fan Kit

Installation of kit enables the drive to operate in higher ambient

temperatures. Fan mounts on drive. Consult the product catalog for

more information.

ATV61/71HD18M3X...HD22M3X,

ATV61/71HD22N4 VW3A9404 135.00

ATV61/71HD30N4...HD37N4 VW3A9405 145.00

ATV61/71HD30M3X...HD45M3X VW3A9406 165.00

ATV61/71HD45N4...HD75N4 VW3A9407 195.00

Description

ATV61: Options and Accessories — Variable Torque Applications

ATV58 Drive Replaced by Reference Mounting

Plate $ Price

Mounting

Plate Kit

Kit includes: Mechanical adaptors required

for mounting and Altivar 61/71 drive in the

place of an Altivar 58 or Altivar 58F drive

using same holes.

Single-phase supply voltage: 200…240V 50/60 Hz

ATV58HU09M2ZU ATV61H075M3 VW3A9301 83.00

ATV58HU18M2ZU ATV61HU15M3 VW3A9301 83.00

ATV58HU29M2ZU ATV61HU22M3 VW3A9303 83.00

ATV58HU41M2ZU ATV61HU30M3 VW3A9303 83.00

ATV58HU72M2ZU ATV61HU40M3 VW3A9304 93.00

ATV58HU90M2ZU ATV61HU55M3 VW3A9306 133.00

ATV58HD12M2ZU ATV61HU75M3 VW3A9307 133.00

Three-phase supply voltage 200…240 V 50/60 hz

ATV58HU29M2ZU ATV61HU15M3 VW3A9302 83.00

ATV58HU41M2ZU ATV61HU22M3 VW3A9303 83.00

ATV58HU54M2ZU ATV61HU30M3 VW3A9304 93.00

ATV58HU72M2ZU ATV61HU40M3 VW3A9304 93.00

ATV58HU90M2ZU ATV61HU55M3 VW3A9306 133.00

ATV58HD12M2ZU ATV61HU75M3 VW3A9307 133.00

ATV58HD16M2XZU ATV61HD11M3X VW3A9309 170.00

ATV58HD16M2XZU ATV61HD15M3X VW3A9309 170.00

ATV58HD23M2XZU ATV61HD18M3X VW3A9310 170.00

ATV58HD28M2XZU ATV61HD22M3X VW3A9312 337.00

ATV58HD33M2XZU ATV61HD30M3X VW3A9312 337.00

ATV58HD46M2XZU ATV61HD37M3X VW3A9312 337.00

Three-phase supply voltage: 380…480V 50/60 Hz

ATV58HU18N4ZU ATV61H075N4 VW3A9302 83.00

ATV58HU29N4ZU ATV61HU15N4 VW3A9302 83.00

ATV58HU41N4ZU ATV61HU22N4 VW3A9302 83.00

ATV58HU54N4XZU ATV61HU40N4 VW3A9304 93.00

ATV58HU72N4XZU ATV61HU55N4 VW3A9305 93.00

ATV58HU90N4XZU ATV61HU75N4 VW3A9305 93.00

ATV58HD12N4XZU ATV61HD11N4 VW3A9307 133.00

ATV58HD16N4XZU ATV61HD15N4 not available —

ATV58HD23N4XZU ATV61HD18N4 VW3A9308 138.00

ATV58HD28N4XZU ATV61HD22N4 VW3A9310 170.00

ATV58HD33N4XZU ATV61HD30N4 VW3A9310 170.00

ATV58HD46N4XZU ATV61HD37N4 VW3A9310 170.00

ATV58HD54N4XZU ATV61HD45N4 VW3A9312 337.00

ATV58HD64N4XZU ATV61HD55N4 VW3A9312 337.00

ATV58HD79N4XZU ATV61HD75N4 VW3A9312 337.00

ATV71: Options and Accessories – Constant Torque Applications

ATV58 Drive Replaced by Reference Mounting

Plate $ Price

Single-phase supply voltage: 200…240V 50/60 Hz

ATV58HU09M2ZU ATV71H075M3 VW3A9301 83.00

ATV58HU18M2ZU ATV71HU15M3 VW3A9301 83.00

ATV58HU29M2ZU ATV71HU22M3 VW3A9303 83.00

ATV58HU41M2ZU ATV71HU30M3 VW3A9303 83.00

ATV58HU72M2ZU ATV71HU40M3 VW3A9304 93.00

ATV58HU90M2ZU ATV71HU55M3 VW3A9306 133.00

ATV58HD12M2ZU ATV71HU75M3 VW3A9307 133.00

Three-phase supply voltage: 200…240V 50/60 Hz

ATV58HU29M2ZU ATV71HU15M3 VW3A9302 83.00

ATV58HU41M2ZU ATV71HU22M3 VW3A9303 83.00

ATV58HU54M2ZU ATV71HU30M3 VW3A9304 93.00

ATV58HU72M2ZU ATV71HU40M3 VW3A9304 93.00

ATV58HU90M2ZU ATV71HU55M3 VW3A9306 133.00

ATV58HD12M2ZU ATV71HU75M3 VW3A9307 133.00

ATV58HD16M2XZU ATV71HD11M3X VW3A9309 170.00

ATV58HD23M2XZU ATV71HD15M3X VW3A9309 170.00

ATV58HD28M2XZU ATV71HD18M3X VW3A9312 337.00

ATV58HD33M2XZU ATV71HD22M3X VW3A9312 337.00

ATV58HD46M2XZU ATV71HD30M3X VW3A9312 337.00

Three-phase supply voltage 380…480 V 50/60 HZ

ATV58HU18N4ZU ATV71H075N4 VW3A9302 83.00

ATV58HU29N4ZU ATV71HU15N4 VW3A9302 83.00

ATV58HU41N4ZU ATV71HU22N4 VW3A9302 83.00

ATV58HU54N4ZU ATV71HU30N4 VW3A9304 93.00

ATV58HU72N4ZU ATV71HU40N4 VW3A9304 93.00

ATV58HU90N4ZU ATV71HU55N4 VW3A9305 93.00

ATV58HD12N4ZU ATV71HU75N4 VW3A9306 133.00

ATV58HD16N4ZU ATV71HD11N4 VW3A9307 133.00

ATV58HD23N4ZU ATV71HD15N4 VW3A9308 138.00

ATV58HD28N4ZU ATV71HD18N4 VW3A9309 170.00

ATV58HD33N4ZU ATV71HD22N4 VW3A9310 170.00

ATV58HD46N4ZU ATV71HD30N4 VW3A9310 170.00

ATV58HD54N4ZU ATV71HD37N4 VW3A9312 337.00

ATV58HD64N4ZU ATV71HD45N4 VW3A9312 337.00

ATV58HD79N4ZU ATV71HD55N4 VW3A9312 337.00

aVerify motor/drive ratings and application for proper replacement selections.

bCatalog number may or may not contain an “X” in this position.

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Drive Products

Altivar® 61 and Altivar 71

aThe symbol “•” indicates the part of the number that varies with controller size or rating.

Options—Field Installed (continued)

Description For Use on Drives Catalog No. $ Price

Flange Kit

Kit includes:

a metal frame, seals, mounting hardware, and

bracket to mount fan kit so fan can be accessed

from the front of the drive template.

Kit used to mount the heatsink of the drive outside

of an enclosure.

ATV61/71H037M3...HU15M3 VW3A9501 255.00

ATV61/71H075N4...HU22N4

ATV61/71HU22M3...HU40M3 VW3A9502 279.00

ATV61/71HU30N4...HU40N4

ATV61/71HU55M3 VW3A9503 325.00

ATV61/71HU55N4, HU75N4

ATV61/71HU75M3 VW3A9504 358.00

ATV61/71HD11N4

ATV61/71HD11M3X..HD15M3X VW3A9505 419.00

ATV61/71HD15N4, HD18N4

ATV61/71HD18M3X..HD22M3X VW3A9506 438.00

ATV61/71HD22N4, ATV61/71HU30Y...HD30Y

ATV61/71HD30N4, HD37N4 VW3A9507 469.00

ATV61/71HD30M3X..HD45M3X VW3A9508 469.00

ATV61/71HD45N4...HD75N4, ATV61/71HD37Y...HD90Y VW3A9509 477.00

ATV61HD55M3X...HD75M3X

ATV61HD90N4...HC11N4 VW3A9510 500.00

ATV71HD55M3X, ATV71HD90N4

ATV61HD90M3X, ATV61HC13N4 VW3A9511 667.00

ATV71HD75M3X, ATV71HC11N4

ATV61HC16N4, ATV61HC20Y, ATV61/71HC11Y...HC16Y,

ATV71HC13N4 VW3A9512 1053.00

ATV61HC22N4, ATV71HC16N4 VW3A9513 1053.00

ATV61HC25N4…HC31N4

ATV61HC40Y

ATV61/71HC25Y, HC31Y

ATV71HC20N4...HC28N4

ATV71HC20Y

VW3A9514 1053.00

ATV61HC25N4…HC31N4 with VW3A7101 braking transistor

ATV61HC40Y

ATV61/71HC25Y, HC31Y

ATV71HC20N4...HC28N4 with VW3A7101 braking transistor

ATV71HC20Y

VW3A9515 1062.00

Type 1

Condiut Kit

Kit includes:

a metal box, with conduit knockouts

Kit provides conduit landing when wall mounting

the drive

ATV61/71H037M3...HU15M3 VW3A9201 45.00

ATV61/71H075N4...HU22N4

ATV61/71HU22M3...HU40M3 VW3A9202 45.00

ATV61/71HU30N4...HU40N4

ATV61/71HU55M3 VW3A9203 45.00

ATV61/71HU55N4, HU75N4

ATV61/71HU75M3 VW3A9204 45.00

ATV61/71HD11N4

ATV61/71HD11M3X..HD15M3X VW3A9205 45.00

ATV61/71HD15N4, HD18N4

ATV61/71HD18M3X..HD22M3X

VW3A9206 65.00ATV61/71HD22N4

ATV61/71HU30Y...HD30Y

ATV61/71HD30N4, HD37N4 VW3A9207 65.00

ATV61/71HD30M3X..HD45M3X VW3A9217 85.00

ATV61/71HD45N4..HD75N4 VW3A9208 135.00

ATV61/71HD37Y...HD90Y

ATV61HD55M3X...HD75M3X

ATV61HD90N4...HC11N4 VW3A9209 460.00

ATV71HD55M3X, ATV71HD90N4, ATV61HC11N4

ATV61HD90M3X, ATV61HC13N4 VW3A9210 553.00

ATV71HD75M3X, ATV71HC11N4

ATV61HC16N4, ATV71HC13N4

VW3A9211 573.00ATV61/71HC11Y...HC16Y

ATV61HC20Y

ATV61HC22N4, ATV71HC16N4 VW3A9212 588.00

ATV61HC25N4...ATV61HC31N4

ATV71HC20N4...HC28N4

VW3A9213 604.00

ATV71HC20Y

ATV61/71HC25Y, HC31Y

ATV61HC40Y

ATV61HC25N4...HC31N4 with VW3A7101 braking transistor

ATV71HC20N4...HC28N4 with VW3A7101 braking transistor

VW3A9214 604.00

ATV71HC20Y

ATV61/71HC25Y, HC31Y

ATV61HC40Y

Profibus

Option Card

Cover

Type 1 cover for Profibus Option Card

230V Drive controllers 480V Drive controllers

ATV61H••••aATV71H•••• ATV61H•••• ATV71H••••

075M3 037M3 075N4 075N4

VW3A9201PF 101.00U15M3 075M3 U15N4 U15N4

— U15M3 U22N4 U22N4

U22M3 U22M3 U30N4 U30N4

VW3A9292PF 102.00U30M3 U30M3 U40N4 U40N4

U40M3 U40M3 — —

U55M3 U55M3 U55N4 U55N4 VW3A9203PF 104.00

——U75N4U75N4

U75M3 U75M3 D11N4 D11N4 VW3A9204PF 107.00

D11M3X D11M3X D15N4 D15N4 VW3A9205PF 112.00

D15M3X D15M3X D18N4 D18N4

Flange Kit VW3A9506

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Altistart® 01

ATS•01N2 Soft Starts

Three-phase motors rated for 6 to 32 A at 230, 400, and 460 volts.

NOTE: The ATSU01N2 soft start must be externally supplied with 24 Vdc control power. If this is not available,

select from the ATS01N2 table below.

The ATSU01N2 soft start is shipped with a custom ATSU01N2 to TeSys U-line power connector.

aNo separate control voltage is needed.

TeSys U-line compatible Full motor control solution

Soft start and soft stop 1–10 second ramp

Motor voltage 230, 400, 460

Three-phase motor 1 to 20 hp, 0.75–15 kW

Internal shorting contactor Cool, reliable operation

Application Derate for high duty cycle, temperature > 40°C, altitude > 1000 m

(see ATS01 Catalog 8637CT0401 for more detail)

Adjustments Start and stop times (1–10 s) and initial (starting) voltage (30–80%)

Voltage boost (Kickstart) Activated by BOOST logic input—full voltage for first 12 cycles of motor starting (200

mS)

LED display Two: "Power ON" and "Full Voltage" (up to speed)

Control inputs and outputs 2 or 3 wire control, fault relay (also for isolation contactor control), "up to speed" logic

output

Plug-in control terminals Ease of wiring

Table 24: ATSU01N2 Family Selection and Pricing

For use with TeSys® U-line motor starter (24 Vdc control power)

A Catalog Number

Three-Phase Motor Power

$ Price

230 V 400 V 460 V

6 ATSU01N206LT 0.75–1.1 kW 1–1.5 hp 1.5–2.2 kW 2–3 hp 133.00

9 ATSU01N209LT 1.5 kW 2 hp 3–4 kW 5 hp 152.00

12 ATSU01N212LT 2.2–3 kW 3 hp 5.5 kW 7.5 hp 175.00

22 ATSU01N222LT 4–5.5 kW 5–7.5 hp 7.5–11 kW 10–15 hp 219.00

32 ATSU01N232LT 7.5 kW 10 hp 15 kW 20 hp 300.00

Table 25: ATS01N2 Family Selection and Pricing

For use with TeSys® U-linea, GV2, GV3, and other motor starters

A Catalog Number

Three-Phase Motor Power

$ Price

230 V 400 V 460 V

6 ATS01N206LU 0.75 / 1.1 kW 1 / 1.5 hp — — 133.00

9 ATS01N209LU 1.5 kW 2 hp — — 152.00

12 ATS01N212LU 2.2 / 3 kW 3 hp — — 175.00

22 ATS01N222LU 4 / 5.5 kW 5 / 7.5 hp — — 219.00

32 ATS01N232LU 7.5 kW 10 hp — — 300.00

6 ATS01N206QN — — 1.5 / 2.2 kW — 133.00

9 ATS01N209QN — — 3 / 4 kW — 152.00

12 ATS01N212QN — — 5.5 kW — 175.00

22 ATS01N222QN — — 7.5 / 11 kW — 219.00

32 ATS01N232QN — — 15 kW — 300.00

6 ATS01N206RT — — — 2 / 3 hp 133.00

9 ATS01N209RT — — — 5 hp 152.00

12 ATS01N212RT — — — 7.5 hp 175.00

22 ATS01N222RT — — — 10 / 15 hp 219.00

32 ATS01N232RT — — — 20 hp 300.00

Table 26: Accessory

Description Catalog No. $ Price

Custom power connector (between ATS01N2 and TeSys U-line motor starter) VW3G4104 10.00

CP1G Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Altistart® 01

ATS01N1 Soft Starts

Single or three-phase motors rated for 3 to 12 A at 110, 208, 230, 400 and 460 volts

aDiscount Schedule I.

ATS01 Higher Horsepower Soft Starts

Three-phase motors rated for 32 to 85 A at 230, 400, 460, 575, and 690 volts.

aDiscount Schedule I12.

Soft start (no soft stop) 1–5 second ramp

Motor voltage 110, 208, 230, 400, 460

Three-phase motor 1/2 to 7.5 hp

Single-phase motor 1/4 to 2 hp

External control power 24 Vac/dc or 110–230 Vac

Internal shorting contactor 9 and 12 A models—cool, reliable operation

Application Derate for temperature > 40°C, altitude > 1000 m

(

see ATS01 Catalog 8637CT0401 for more detail

)

Adjustments Start time (1–5 s) and initial (starting) voltage (30–80%)

LED display Two: "Power ON" and "Full Voltage" (up to speed)

Plug-in control terminals 9 and 12 A models—ease of wiring

Table 27: ATS01N1 Selection and Pricing

A Catalog Number

Motor Power

$ PriceSingle-Phase Three-Phase

110 V 208 V 230 V 230 V 400 V 460 V

3 ATS01N103FT — 1/4 hp 0.37 kW 1/4 hp 0.37–0.55 kW 1/2 hp 1.1 kW 1–1.5 hp 100.00

6 ATS01N106FT 1/4 hp 1/2 hp 0.75 kW 1/2 hp 0.75–1.1 kW 1–1.5 hp 2.2 kW 2–3 hp 115.00

9 ATS01N109FT 1/3 hp 1 hp 1.1 kW 1 hp 1.5 kW 2 hp 4 kW 5 hp 130. 00

12 ATS01N112FT 1/2 hp 1.5 hp 1.5 kW 2 hp 2.2 kW 3 hp 5.5 kW 7.5 hp 145. 00

Table 28: Accessory

Description Catalog No. $ Price

DZ5 MB DIN rail ( ) adaptor for 3 and 6 A models (sold only in packages of 10) RHZ66a3.60

Soft start and soft stop 1–25 second ramp

Motor voltage 230, 400, 460, 575, 690

Three-phase motor 10 to 75 hp, 7.5–85 kW

External control power 110 Vac

Internal shorting contactor Cool, reliable operation

Application Derate for high duty cycle and altitude > 2000 m.

(

see ATS01 Catalog 8637CT0401 for more detail

). Maximum temperature = 55°C

Adjustments Start and stop times (1–25 s) and initial (starting) voltage (30–80%)

LED display "Power ON" and "Full Voltage" (up to speed)

Control inputs and outputs 2 or 3 wire control, fault relay (also for isolation contactor control),

"Up to Speed" auxiliary relay (accessory: LAD8N11)

Table 29: ATS01N2 Selection and Pricing

A Catalog Number

Three-Phase Motor Power

$ Price

230 V 400 V 460 V 575 V 690 V

32 ATS01N230LY 7.5 kW 10 hp 15 Kw 20 hp 30 hp 30 kW 613.00

44 ATS01N244LY 11 kW 15 hp 22 kW 30 hp 40 hp 37 kW 799.00

72 ATS01N272LY 18.5 kW 25 hp 37 kW 50 hp 60 hp 55 kW 1013.00

85 ATS01N285LY 22 kW 30 hp 45 kW 60 hp 75 hp 85 kW 1227.00

Table 30: Accessories

Description Catalog No. $ Price

"Up to Speed" auxiliary relay contact (attaches to side of ATS01) LAD8N11a20.70

DIN rail adaptor (32 and 44 A models) VY1H4101 25.00

I11 CP1G Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Altistart® 48

Altistart® 48 Soft Starts

The Altistart 48 soft start combines ease of selection with simple installation and high motor control performance. With

its exclusive and patented motor Torque Control System, the Altistart 48 helps eliminate uncontrolled motor

acceleration and deceleration, a problem inherent with standard voltage—ramp soft starts. The Altistart 48 includes

features to help with motor and machine protection and is available for motors ranging from 208 to 575 volts. In

addition to a built–in display and programming terminal, a remote keypad option and programming software is

available to ease integration and commissioning. The Altistart 48 has a built–in Modbus port and is offered with serial

communication gateways to such popular networks as Ethernet and DeviceNet.

Open Style Soft Starts 50–60 Hz, Three-Phase, 690 V Maximum—AC3 Duty

The Altistart 48 soft start must be selected using the table below, based on nameplate full load ampere rating of the

motor. The horsepower ratings shown in table are for reference only.

aMotor full load amperage (FLA) must not exceed the ampere rating of the soft start.

bLow Inertia—Connected motor load inertia equal or less than 10 times motor rotor inertia.

High Inertia—Connected motor load inertia greater than 10 times motor rotor inertia.

NOTE: For severe duty or high inertia loads, derate by 1 hp size.

cFor more information, see Data Bulletin 8806DB0001.

dUse discount schedule I12

eUse discount schedule PC41

fdiscount schedule I11

gdiscount schedule CP4C

For additional information on Altistart 48, reference Catalog #8636CT0201.

Table 31: Altistart® 48 Selection and Pricinga

Standard Duty (Low Inertia Loads)b Maximum Horsepower Altistart® Soft Starts

208 V230 V400 V460 V575 V Rated

Catalog

Number $ Price

3 5 5.5 10 15 17 ATS48D17Y 780.00

5 7.5 7.5 15 20 22 ATS48D22Y 810.00

7.510112025 32ATS48D32Y840.00

10 — 15 25 30 38 ATS48D38Y 900.00

— 15 18.5 30 40 47 ATS48D47Y 950.00

15 20 22 40 50 62 ATS48D62Y 1200.00

20 25 30 50 60 75 ATS48D75Y 1280.00

25 30 37 60 75 88 ATS48D88Y 1500.00

30 40 45 75 100 110 ATS48C11Y 1700.00

40 50 55 100 125 140 ATS48C14Y 2100.00

50 60 75 125 150 170 ATS48C17Y 2300.00

60 75 90 150 200 210 ATS48C21Y 2600.00

75 100 110 200 250 250 ATS48C25Y 2900.00

100 125 132 250 300 320 ATS48C32Y 3300.00

125 150 160 300 350 410 ATS48C41Y 3900.00

150 — 220 350 400 480 ATS48C48Y 4700.00

— 200 250 400 500 590 ATS48C59Y 5400.00

200 250 315 500 600 660 ATS48C66Y 6200.00

250 300 355 600 800 790 ATS48C79Y 7200.00

350 350 400 800 1000 1000 ATS48M10Y 8600.00

400 450 500 1000 1200 1200 ATS48M12Y 10600.00

Table 32: Altistart® 48 Options

Description Catalog Number $ Price

Remote Keypad Display Mounting Kit, including:

Keypad with 3–character 7–segment display

IP65 cover and seal, mounting screws, and 3 meter cable to connect keypad display to Altistart 48

VW3G48101 165.00

Cover for power terminals—Set of 6 for ATS48C14Y and ATS48C17Y LA9F702d61.00

Cover for power terminals—Set of 6 for ATS48C21Y, ATS48C25Y, and ATS48C32Y LA9F703d82.00

Ethernet Bridge 174CEV30020e1027.00

DeviceNet Gateway LUFP9f495.00

Profibus DP Gateway LUFP7f495.00

FIPIO Gateway LUFP1f495.00

1/3 meter connection cable (RJ–45 to RJ–45) VW3A8306R03 20.00

1 meter connection cable (RJ–45 to RJ–45) VW3A8306R10 25.00

3 meter connection cable (RJ–45 to RJ–45) VW3A8306R30 30.00

1/3 meter splitter cable (For RJ—45 daisy chain connection) VW3A8306TF03 75.00

1 meter splitter cable (For RJ–45 daisy chain connection) VW3A8306TF10 85.00

RJ45 terminator (2 per package) VW3A8306RC 6.00

Modbus hub (Eight RJ–45 ports) LU9GC3f208.00

Powersuite commissioning software on CDcVW3A8104g150.00

PowerSuite upgrade CD from most recent to new versioncVW3A8105g98.00

PC connection kit. To connect PC to Altistart 48 soft startcVW3A8106g75.00

Pocket PC connection kit. To connect JORNADA® or iPAQ® PPC to Altistart soft startcVW3A8111g95.00

Size M10 Bolt Kit W808780210111 8.00

Size M12 Bolt Kit W808780220111 10.00

CP1G I12 PC41 I11 CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Enclosed 48

General Information

Enclosed Altistart 48 Soft Starts (Enclosed 48) are

available from 11 to 604 amperes in Type 1, 12 and 3R

enclosures. The Enclosed 48 soft start can provide soft

starting (reduced voltage) and stopping with deceleration

control with machine and motor protection of standard

NEMA Design B squirrel cage asynchronous motors in the

following ranges:

•3–200 hp, 208 V

•5–250 hp, 230 V

•10–500 hp, 460 V

•15–600 hp, 575 V

Selection

The Enclosed 48 controller must be selected based on

three main criteria:

•AC mains voltage supply (distribution voltage):

Three-phase AC voltage: 208, 240, 480 or 600 V.

•The power and the nominal motor current (FLA) indicated on

the motor nameplate.

•The type of application and the operating cycle. To simplify

selection, applications are categorized as either standard duty

or severe duty applications. Standard or severe duty

applications define the limiting values of the current and the

duty cycle ratings. If severe duty is required, select the

next higher horsepower device.

Depending on the type of machine, the applications are

categorized as standard or severe duty based on the

starting characteristics, which are given by example are

illustrated within the table below.

Type of Machine Application Functions performed by the ATS48

Starting

Current

(% In)

Starting

Time

(secs)

Centrifugal pump Standard Deceleration (reduction in pressure surges)

Protection against underloads or inversion of the phase rotation direction 300 5 to 15

Piston pump Standard Control of running dry and direction of rotation of the pump 350 5 to 10

Fan Standard

Severe if > 30s

Detection of overloads caused by clogging or underloads (motor fan transmission

broken) Braking torque on stopping 300 10 to 40

Cold compressor Standard Protection, even for special motors 300 5 to 10

Screw compressor Standard Protection against inversion of direction of phase rotation Contact for automatic

draining on stopping 300 3 to 20

Centrifugal compressor Standard

Severe if > 30s

Protection against inversion of direction of phase rotation Contact for automatic

emptying on stopping 350 10 to 40

Piston compressor Standard Protection against inversion of direction of phase rotation Contact for automatic

emptying on stopping 350 5 to 10

Conveyor, transporter Standard Overload control for detecting faults or underload control for detecting breaks 300 3 to 10

Lifting screw Standard Overload control for detecting hard spots or underload control for detecting breaks 300 3 to 10

Drag lift Standard Overload control for detecting jamming or underload control for detecting breaks 400 2 to 10

Lift Standard Overload control for detecting jamming or underload control for detecting breaks

Constant starting with variable load 350 5 to 10

Circular saw, band saw Standard

Severe if > 30s Braking for fast stop 300 10 to 60

Pulper, butchery knife Severe Torque control on starting 400 3 to 10

Agitator Standard The current display indicates the density of the product 350 5 to 20

Mixer Standard The current display indicates the density of the product 350 5 to 10

Grinder Severe Braking to limit vibrations during stopping, overload control to detect jamming 450 5 to 60

Crusher Severe Braking to limit vibrations during stopping, overload control to detect jamming 400 10 to 40

Refiner Standard Torque control on starting and stopping 300 5 to 30

Press Severe Braking to increase the number of cycles 400 20 to 60

CP1G Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Enclosed 48

Special Applications

Contact Seneca Enclosed Drives TAG for additional

application information and pricing for those applications

requiring:

•Two-speed or delta-wye motors. The ATS48 can operate with

a 2-speed motor. A motor demagnetizing period must elapse

before changing from low speed to high speed in order to avoid

anti-phase between the line supply and the motor, which would

generate very high currents.

•Motors other than NEMA Design B.

•High efficiency motors.

•Low slip motors.

•Power factor correction capacitors. Do not connect power

factor correction capacitors to the terminals of a motor

controlled by an ATS48 soft start. The power factor capacitors

must be controlled and connected to a line side contactor

sequenced by the ATS48 at end of starting.

•Controller oversizing of more than 50%.

•Non-standard trip characteristics.

•Modifications not listed in this pricing guide.

•Horsepower greater than those listed in this pricing guide.

•Long motor cable lengths. Very long motor cables cause

voltage drops due to the resistance of the cable. If the voltage

drop is significant, it could affect the current consumption and

the torque available. This criterion must be taken into account

when selecting the motor and the starter.

•Miscellaneous application precautions. Do not use the ATS48

controller upstream of loads other than motors (i.e.,

transformers and resistance type loads)

Pricing And Special Feature Assistance

Square D/Schneider Electric personnel are to use the Q2C

computer-based pricing system to determine Enclosed 48

controller pricing. For pricing and delivery assistance on

equipment and options not listed in Q2C or this pricing

guide, contact the Seneca Enclosed Drives Technical

Applications Group (TAG) located in the Seneca plant for

further assistance.

Enclosed 48 Catalog Number Identification

Class Type Modifications

8639 48U K A 4 N C06, A07

Combination Device

8638 = Fusible Disconnect

8639 = Circuit Breaker

Factory Modifications (MODS)

C06 =Hand-Off-Auto selector switch

A07 =Run (Red) and Off (Green) lights

Soft Start Device

48U = Enclosed Altistart 48 Soft Start

Power Circuit Type

N=Non-reversing with isolation contactor

R=Reversing with isolation contactor

S=Shunt trip coil

Horsepower Rating

A=3 hpJ=40 hpS=250 hp

B=5 hpK=50 hpT=300 hp

C=7.5 hpL=60 hpU=350 hp

D=10 hpM=75 hpW=400 hp

E=15 hpN=100 hpX=500 hp

F=20 hpP=125 hpZ=600 hp

G=25 hpQ=150 hp

H=30 hpR=200 hp

Voltage Code (utilization)

2=208 V, 60 Hz

3=230 V, 60 Hz

4=460 V, 60 Hz

5=575 V, 60 Hz

Enclosure Environment Rating

G=Type 1

A=Type 12

H=Type 3R

CP1G Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Enclosed 48

aNot available in 575 V ratings.

Table 33: Combination Controller—Enclosed 48 Soft Starts (Fusible Disconnect)

60Hz, Three Phase, 208/230/460/575 Volts—AC3 Duty

Class 8638 Enclosed 48—FUSIBLE Disconnect 8638 Power Circuit Type (Type 1 Enclosure)

(See page 50 for description)

Enclosure Type

Adders

Size ATS48_YU 208 V 230 V 460 V 575 V

Power Circuit

$ Price

Power Circuit

$ Price

Power Circuit

$ Price

Type 12

$ Price

Type 3R

$ Price

D17 3 5 10 15 2944.00 3327.00 2576.00 200.00 750.00

D22 5 7.5 15 20 3128.00 3535.00 2668.00 200.00 750.00

D32 7.5 10 20 25 3404.00 3847.00 2944.00 200.00 750.00

D38 10 — 25 30 3662.00 4138.00 3128.00 200.00 750.00

D47 — 15 30 40 3662.00 4138.00 3128.00 200.00 750.00

D62 15204050 4180.00 4723.00 3608.00 300.00 1200.00

D75 20255060 5315.00 6006.00 4752.00 300.00 1200.00

D88 25306075 5940.00 6712.00 5368.00 300.00 1200.00

C11 30 40 75 100 6442.00 7279.00 5808.00 300.00 1200.00

CC14 40 50 100 125 6800.00 7684.00 6205.00 450.00 1750.00

C17 50 60 125 150 7990.00 9029.00 7310.00 450.00 1750.00

C21 60 75 150 200 9070.00 10249.00 8415.00 600.00 2200.00

C25 75 100 200 250 10200.00 11526.00 9520.00 600.00 2200.00

C32 100 125 250 300 11645.00 13159.00 10600.00 600.00 2200.00

C41 125 150 300 350 11880.00 13424.00 10925.00 825.00 2900.00

C48 150 — 350 400 13864.00 15666.00 12240.00 825.00 2900.00

C59 — 200 400 500 15840.00 17899.00 13840.00 825.00 2900.00

C66 200 250 500 600 18920.00 21380.00 16480.00 825.00 2900.00

Table 34: Combination Controller—Enclosed 48 Soft Starts (Circuit Breaker Disconnect)

60Hz, Three Phase, 208/230/460 Volts—AC3 Duty

Class 8639 Enclosed 48—CIRCUIT BREAKER Disconnect 8639 Power Circuit Type (Type 1 Enclosure)

(See page 50 for description)

Enclosure Type

Adders

Size ATS48_YU 208 V 230 V 460 V 575 V

Power Circuit

$ Price

Power Circuit

$ Price

Power Circuit

$ Price

Type 12

$ Price

Type 3R

$ Price

D17 3 5 10

2856.00 3227.00 2499.00 200.00 750.00

D22 5 7.5 15 3034.00 3429.00 2588.00 200.00 750.00

D32 7.5 10 20 3302.00 3731.00 2856.00 200.00 750.00

D38 10 — 25 3552.00 4013.00 3034.00 200.00 750.00

D47 — 15 30 3552.00 4013.00 3034.00 200.00 750.00

D62 15 20 40 4055.00 4582.00 3500.00 300.00 1200.00

D75 20 25 50 5156.00 5826.00 4609.00 300.00 1200.00

D88 25 30 60 5762.00 6511.00 5207.00 300.00 1200.00

C11 30 40 75 6248.00 7061.00 5634.00 300.00 1200.00

CC14 40 50 100 6596.00 7453.00 6019.00 450.00 1750.00

C17 50 60 125 7750.00 8758.00 7091.00 450.00 1750.00

C21 60 75 150 8797.00 9941.00 8163.00 600.00 2200.00

C25 75 100 200 9894.00 11180.00 9234.00 600.00 2200.00

C32 100 125 250 11296.00 12764.00 10282.00 600.00 2200.00

C41 125 150 300 11524.00 13022.00 10597.00 825.00 2900.00

C48 150 — 350 13448.00 15196.00 11873.00 825.00 2900.00

C59 — 200 400 15365.00 17362.00 13425.00 825.00 2900.00

C66 200 250 500 18352.00 20738.00 15986.00 825.00 2900.00

CP1G Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Enclosed 48

Configuration & Factory Modifications

The Enclosed 48 combination controllers can be

configured with pre-engineered features and functions

identified below. Factory modifications (MODS) identified

by “custom engineered option” has extended lead times

and will be handled by a factory order engineer for

processing.

Enclosed 48 Features

•Class 8638 fusible disconnect version with provisions for Class

J or L fuses are provided. Fuses are not installed at the factory.

•Class 8639 circuit breaker version provided with MAG-GARD

or thermal-magnetic circuit breaker as OCPD.

•Three power circuit configurations—shunt trip, non-reversing

and reversing options.

•Industrial rated flange disconnect operating handle and

mechanism.

•Shorting contactors (AC1 duty) provided on all Enclosed 48

soft starts.

•Input isolation contactor option.

•Full voltage bypass (AC3 duty) option.

•Transient suppression modules on all contactors.

•Agency listing to UL508 Industrial Control Equipment. cUL

and/or CSA label available as an option.

•Coordinated short circuit ratings:

•Type 1, 12 or 3R enclosure environmental ratings.

•22 mm LED long life pilot light clusters with option for push-to-

test configurations.

•120 Vac control power transformers, with or without an

additional 150 VA for customer use.

•Top and bottom conduit knockouts on wall-mounted

enclosures

•Removable conduit entry plates on floor mounted enclosures.

•Cabinet component identification.

•ANSI #49 gray enclosure paint.

•Door mounted keypad on Type 1 and 12 units.

•Wire marking identification.

•Factory specific drawings.

Altistart 48 Soft Start Device Features

TCS™ Torque Control System

The Atlistart 48 soft start uses TCS ramping to accelerate

the motor to full voltage. Basing the acceleration ramp on

the motor torque rather than current or voltage, as used in

traditional soft starts, provides a linear speed ramp

independent of the motor loading without tachometer

feedback. The TCS ramp is also used for improved control

of deceleration independent of motor loading. When used

in pumping applications, TCS ramping can eliminate water

hammer problems and provide an alternative to expensive

motorized control values.

Starting and Stopping

Four types of starting are available:

•TCS soft start—adjustable from 1 to 60 seconds

•TCS with “boost”—adjustable 50 to 100% of mains voltage

•Current limit—adjustable from 150 to 500% of controller rating

•Voltage ramping

Modes of stopping

•Freewheel or coast to stop

•TCS soft stop—adjustable from 1 to 60 seconds

Device Protective Features

•Solid State motor thermal overload protection—programmable

from Class 10 through 30

•Soft start thermal protection

•Motor phase loss protection

•Line supply failure

•Overcurrent fault

•Locked rotor fault

•Line frequency outside limits ±5% or ±20%—EGSA

compliance with Class 3 application (droop operation)

generators.

•Selectable protection, including:

— Phase reversal

— Stall and jam

— Thermal overload pre-alarm

— Current threshold alarm

— Underload fault

Enclosure

Size

Horsepower Rating 8638

Fusible

Disconnect

8639

Circuit

Breaker@ 208 V @ 230 V @ 460 V @ 575 V

A–C 3–50 5–60 10–125 15–150 100k 25k

D 60–100 75–125 150–250 200–300 100k 30k

E 125–200 150–250 300–500 350–600 65k 30k

CP1G Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Enclosed 48

Device Monitoring and Indication

Door mounted keypad:

•Displays setup parameters and fault codes.

•Factory presets for most common adjustments.

•Security to avoid accidental controller modifications is

provided by dipswitches on the back of the keypad, which

must be adjusted to provide access to three programming

levels.

Real time indication via the digital keypad of:

•Motor current

•Load Torque

•Motor thermal state

•Power factor

•Fault status

Two logic outputs:

•Motor thermal overload or indication of motor current present

•Current threshold alarm

•Motor underload alarm

One analog output for 4 to 20 or 0 to 20 mA indication of

motor current, torque, thermal state, active power or

power factor.

Two logic inputs, which are configurable for force to

freewheel, thermal overload reset or indication of external

fault.

Refer to the Altistart 48 product catalog (8636CT0201) for

additional information.

Power Circuit Descriptions (pick one)

Power Circuit N—

Non-Reversing with Isolation Contactor

A contactor ahead of the soft start is coordinated to

automatically disconnect the motor from the ac line in the

conditions of a fault. In addition, the isolation contactor is

coordinated to open when the motor is running. This

provides protection from voltage transients when the

electronics are most susceptible to damage. The isolation

contactor operation shall be coordinated via the R1 relay

in isolation contactor control mode. The control scheme

and contactor sequencing shall maintain the control power

and remove the main power to the soft start after a fault or

normal stop. Not available with shunt trip option, and is

required with full voltage bypass option.

Power Circuit R—

Reversing with Isolation Contactor

The reversing combination starter is configured for

forward and reverse operation through a reversing

contactor and appropriate logic control. The reversing

contactor also provides isolation for the motor from the

line supply power following a stop command (and

deceleration period, if selected) or in the condition of a

fault. Control of the forward and reverse contactors shall

use time delay relays (time set for 2 seconds) and the R1

fault relay in fault configuration. Not available with NEMA

contactors or full voltage bypass.

Power Circuit S—

Shunt Trip Coil

If a fault is detected, a shunt trip coil on the disconnect

means removes all power on the load side of the

disconnect. The disconnect must be reset before

restarting is permitted after all fault conditions. The shunt

trip function shall be coordinated via a time delay relay

(time set for 2 seconds) signaled from the R1 relay in fault

configuration. Shunt trip coils shall be standard for MCC &

option S for enclosed, and available on both circuit

breaker & molded case switch versions. Not available with

input isolation contactor option (Power Circuit N).

CP1G Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Enclosed 48

Control Options (pick one)

Rules:Not available on Power Circuit R (Reversing).

Rules:Available for Power Circuit R (Reversing) configurations only.

Rules:Not available on Power Circuit R (Reversing).

Pilot Light Cluster Options (pick one)

Rules: Not available with Power Circuit S (Shunt Trip).

Rules:Not available on Power Circuit S (Shunt Trip).

Meter Display Options (pick one)

Rules:Not available on Type 3R Enclosed.

Communications/Gateway Options

(pick one)

Factory installed communication features shall be available

as a custom engineered option utilizing the RJ45

communications port for control and annunciation of the

soft start in “link” mode.

Mod

A06

Start/Stop push buttons $ Price

Provides black start and red stop push buttons

(3 wire control scheme). 132.00

Mod

B06

Forward-Off-Reverse selector switch $ Price

Provides three-position selector switch to select between

forward, off and reverse. Uses 2-wire control. 240.00

Mod

C06

Hand-Off-Auto selector switch $ Price

Provides a three-position selector switch, 2-wire control

scheme. 132.00

Mod

D06

Stop-Run selector switch $ Price

Provides a two-position selector switch. 132.00

Mod

E06

Hand-Auto selector switch and Start/Stop push buttons $ Price

Provides a two-position selector switch and start/stop push

buttons (3-wire control). 264.00

Mod

A07

Pilot Light Cluster #1 $ Price

Consists of red “RUN” and green “OFF” pilot lights. Provides

standard red “RUN (ON)” and green “OFF” pilot lights for status

annunciation.

180.00

Mod

B07

Pilot Light Cluster #2 $ Price

Consists of red “RUN” (push-to-test) and green “OFF” (push-to-

test) pilot lights. Provides push-to-test type red “RUN (ON)” and

standard green “OFF” pilot lights for status annunciation.

360.00

Mod

C07

Pilot Light Cluster #3 $ Price

Consists of red “RUN”, green “OFF” and yellow “FAULT”

pilot lights. Provides standard red “RUN (ON)”, green “OFF”,

and yellow “FAULT” pilot lights for status annunciation.

270.

Mod

D07

Pilot Light Cluster #4 $ Price

Consists of red “RUN (ON)” (push-to-test), green “OFF” (push-

to-test) and yellow “FAULT” (push-to-reset) pilot lights. Provides

push-to-test type red “RUN (ON)”, standard green “OFF”, and

push-to-reset type yellow “FAULT” for status annunciation.

540.00

Mod

A08

Ammeter $ Price

Provides a single-phase ammeter fed from the ATS48 analog

output. Dial is in percent of device rated current. 1188.00

Mod

B08

Elapsed Time Meter $ Price

Provides a seven-digit analog, non-resettable elapsed run time

meter. 348.00

Mod

A09

Modbus®$ Price

Provides Modbus communications (native protocol) 850.00

Mod

B09

Modbus Plus $ Price

Provides Modbus communications. 950.00

Mod

C09

Ethernet $ Price

Provides Ethernet gateway communications protocol. 950.00

Mod

D09

Devicenet $ Price

Provides Devicenet gateway communications protocol. 950.00

CP1G Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Enclosed 48

Miscellaneous Options (multiple compatible options may be selected)

Rules:Only available for Power Circuit N (Non-Reversing). Not available with

Power Circuit S (Shunt Trip) SCR fault isolation scheme.

Rules:Only available on 2-wire control circuits.

Rules:Requires Power Circuit S (Shunt Trip).

Rules:MOD A10 (Full Voltage Bypass) must be selected. Must use Power Circuit

N or R (line isolation contactor combination). Not compatible with Power

Circuit S (Shunt Trip).

Rules:MOD C06 (Hand-Off-Auto selector switch) or E06 (Hand-Auto selector

switch) must be specified.

Rules:Available on Class 8639 circuit breaker disconnect configurations only.

Rules: Only for Type 3R size D and E enclosures.

Rules:Not available with Power Circuit R (Reversing) or MOD A10 (Full voltage

bypass.

Rules:Standard on Type 3R enclosures.

Rules:Not available for Enclosure Sizes A–C (wall mounted enclosures).

Mod

A10

Full voltage bypass $ Price

Provides an AC3 duty rated bypass/shorting contactor,

normal/bypass selector switch, Class 20 bi-metal motor OL

relay, door mounted OL reset push-button for across the line

starting capability.

Enclosure Size A adder: 500.00

Enclosure Size B adder: 600.00

Enclosure Size C adder: 700.00

Enclosure Size D adder: 750.00

Enclosure Size E adder: 900.00

Mod

B10

150 VA additional control power capacity $ Price

Provides 150 VA additional control VA capacity for customer

use. 150.00

Mod

C10

Power Up ON delay (start relay) $ Price

Provides an electronic time delay relay adjustable from 0.1 to

60 seconds. Relay is pre-wired to inhibit start for users set

delay time upon power-up of control power circuit.

150.00

Mod

D10

Emergency Stop push button $ Price

Provides a push-button for immediate removal of all power. 140.00

Mod

E10

“cUL” Label $ Price

Provides a Canadian Underwriters Laboratories label when

required by local code requirements. 200.00

Mod

F10

Auxiliary contacts for run mode $ Price

Provides 1 Form 'C' contact rated 5 A @ 120 Vac

(8501 Type R relay or equivalent) wired to terminal blocks for

customer use. Contacts change state when soft start is

sending current to the motor. Controlled by the R3 relay

programmed for “rnl”.

550.00

Mod

G10

Auxiliary contacts for full voltage bypass run mode $ Price

Provides 1 Form 'C' contact rated 5 A @ 120 Vac

(8501 Type R relay or equivalent) wired to terminal blocks for

customer use. Contacts change state when motor is operated

across the line with full voltage bypass starter.

550.00

Mod

H10

Auxiliary contacts for auto mode $ Price

Provides an auxiliary starter mode (auto) contact that

will energize a relay with 1 Form 'C' contact rated 5 A @ 120

Vac (8501 Type R relay or equivalent) wired to terminal blocks

for customer use.

550.00

Mod

J10

Auxiliary contacts for fault mode $ Price

Provides an auxiliary starter mode (auto) contact that

will energize a relay with 1 Form 'C' contact rated 5 A @ 120

Vac (8501 Type R relay or equivalent) wired to terminal blocks

for customer use.

650.00

Mod

K10

Motor space heater provisions

(custom engineered option) $ Price

Provides control circuit contacts, 120 V, 150–500 kW supply

and fusing, wired to terminals (9080 GM6) for customer use. 640.00

Mod

L10

ID engraved nameplates $ Price

Provides a lamacoid nameplate, engraved with equipment

designation. 50.00

Mod

M10

Spare terminal blocks $ Price

Provides up to (10) spare terminal blocks 'unwired' for

customer use. Since Phoenix style terminal blocks will be

used, extra terminal points will be provided as standard.

20 terminal points are available as standard for all control

wiring (including any additional customer spare terminal

points).

340.00

Mod

P10

Permanent wire markers $ Price

Provides permanent sleeve type wire markers on control

wiring assemblies. 1400.00

Mod

Q10

ANSI #61 painted enclosure

(custom engineered option) $ Price

Provides the option to configure the enclosure paint scheme to

standard ANSI #61 paint instead of ANSI #49 paint. 375.00

Mod

R10

MOV / Surge arrestor (custom engineered option) $ Price

Provides supplementary MOV protection using a

Class 6671 SDSA3650 Surgebreaker® Secondary Surge

Arrester hard-wired and factory mounted.

450.00

Mod

S10

Dual motor overloads and branch circuit protection

(custom engineered option) $ Price

Provides dual rated motor OLs rated equally, one-half

the hp of the selected starter. Motor branch short circuit

protection is provided per NEC. Maximum total current rating

of the combined motors not to exceed the continuous current

rating of the starter package.

Enclosure Size A adder: 820.00

Enclosure Size B adder: 1874.00

Enclosure Size C adder: 2645.00

Enclosure Size D adder: 3160.00

Enclosure Size E adder: 6570.00

Mod

U10

Omit door mounted keypad display $ Price

Removes the keypad display from outside the enclosure door.

The keypad on the ATS48 soft start can be used for

programming and commissioning.

(50.00)

Mod

W10

NEMA style contactors (custom engineered option) $ Price

Provides horsepower rated NEMA rated contactors instead

of AC3 rated IEC TeSys or F-line contactors.

Enclosure Size A adder: 400.00

Enclosure Size B adder: 600.00

Enclosure Size C adder: 700.00

Enclosure Size D adder: 2000.00

Enclosure Size E adder: 4500.00

Mod

X10

50 Degrees C operation $ Price

Provides extended range high ambient equipment rating

above 40°C (104°F) to a maximum of 50°C (122°F) without

de-rating.

125.00

Mod

Y10

Seismic Qualification label $ Price

Provides a self-certified identification label with compliance to

2000 IBC, NFPA 5000, 2001 CBC, 1997 UBC, 1999 NBC,

1999SBC, ASCE-7 02 seismic qualification/certification. The

label criteria will be uniform for all enclosed products.

Enclosures shall contain additional bracing as defined by the

seismic qualification/certification criteria.

450.00

Mod

Z10

Service Entrance Rating $ Price

Provides a UL869A approved insulated ground neutral lug

assembly,mounting bracket with bonded enclosure ground

wire suitable for use as service entrance equipment.

185.00

CP1G Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Enclosed 48 — Class 8636, 8638, and 8639

aThese Type 1 and 12 units are not shipped with a shorting contactor installed.

Table 35: Renewal Parts

Description Line

Vol tage

Class 8636 Controllers Class 8638/8639 Combination Controllers

Catalog Number $ Price

Type 1

No Shorting

Type

1 and 12

W/Shorting

Standard

Duty

Heavy

Duty

Standard

W/Bypass

Heavy

W/Bypass

Control Power

Primary Fuse

FU8

Standard VA

460 V 10–20 hp a10–20 hp 7.5–15 hp 2543020020 11.00

208 V 3–7.5 hp a3–7.5 hp 2–5 hp

2543020050 11.00230 V 5–10 hp a5–10 hp 3–7.5 hp

460 V 30–60 hp 30–75 hp 30–75 hp 20–60 hp

230 V 15–30 hp 15–40 hp 15–40 hp 10–30 hp 2543020100 11.00

460 V 75–100 hp 100–125 hp 100–125 hp 75–100 hp 75 hp

208 V 10–25 hp 10–30 hp 10–30 hp 7.5–25 hp 2543020112 11.00

460 V 125 hp 150 hp 150 hp 125 hp 2543020125 14.76

460 V 250– 400 hp 300–500 hp 300–500 hp 150–400 hp 2543020150 11.00

460 V 150–200 hp 200–250 hp 200–250 hp 150–200 hp 150 hp 125 hp 2543020180 11.00

230 V 40–50 hp 50–60 hp 50– 60 hp 40–50 hp 40 hp 2543020200 11.00

208 V 30–40 hp 40–50 hp 40–50 hp 30–40 hp 30 hp 2543020250 13.68

230 V 60 hp 75 hp 75 hp 60 hp

208 V 50 hp 60 hp 60 hp 50 hp 2543020300 11.00

230 V 125–200 hp 150–250 hp 150–250 hp 125– 200 hp

208 V 100–150 hp 125–200 hp 125–200 hp 100–150 hp 2543020350 11.00

230 V 75–100 hp 100–125 hp 100–125 hp 75–100 hp 75 hp 60 hp

208 V 60–75 hp 75–100 hp 75–100 hp 60–75 hp 60 hp 50 hp 2543020400 11.00

Control Power

Primary Fuse

FU8

Form T41

100 Additional VA

460 V 10–20 hp a10–20 hp 7.5–15 hp 2543020060 11.00

460 V 30–60 hp 30–75 hp 30–75 hp 20–60 hp 2543020100 11.00

230 V 5–10 hp a5–10 hp 3–7.5 hp 2543020150 11.00

460 V 75–100 hp 100–125 hp 100–125 hp 75–100 hp 75 hp

208 V 3–7.5 hp a3 –7.5 hp 2 –5 hp 2543020160 14.76

460 V 125 hp 150 hp 150 hp 125 hp 2543020180 11.00

230 V 15–30 hp 15–40 hp 15–40 hp 10–30 hp 2543020200 11.00

208 V 10–25 hp 10–30 hp 10 –30 hp 7.5–25 hp 2543020250 13.68

460 V 150–400 hp 200–500 hp 200–500 hp 150–400 hp 150 hp 125 hp

230 V 40–50 hp 50–60 hp 50–60 hp 40–50 hp 40 hp 2543020300 11.00

230 V 75–200 hp 100–250 hp 100–250 hp 75–200 hp 75 hp 60 hp 2543020320 11.00

208 V 30–40 hp 40–50 hp 40–50 hp 30– 40 hp 30 hp 2543020350 11.00

230 V 60 hp 75 hp 75 hp 60 hp

208 V 50–150 hp 60–200 hp 60–200 hp 50–150 hp 60 hp 50 hp 2543020400 11.00

Control Power

Primary Fuse

FU8

Form T42

200 Additional VA

460 V 10–20 hp a10–20 hp 7.5–15 hp 2543020125 14.67

460 V 30–60 hp 30–75 hp 30–75 hp 20–60 hp 2543020150 11.00

230 V 5–10 hp a5–10 hp 3–7.5 hp

2543020250 13.68460 V 75–125 hp 100–150 hp 100–150 hp 75–125 hp 75 hp

460 V 250–400 hp 300–500 hp 300–500 hp 250–400 hp

208 V 3–7.5 hp a3–7.5 hp 2–5 hp 2543020300 11.00

230 V 15–30 hp 15–40 hp 15–40 hp 10–30 hp

230 V 40–60 hp 50–75 hp 50–75 hp 40–60 hp 40 hp 2543020320 11.00

230 V 125–200 hp 150–250 hp 150–250 hp 125–200 hp

208 V 10–25 hp 10–30 hp 10–30 hp 7.5–25 hp 2543020350 11.00

460 V 150–200 hp 200–250 hp 200–250 hp 150–200 hp 150 hp 125 hp

208 V 30–50 hp 40–60 hp 40– 60 hp 30–50 hp 30 hp 2543020400 11.00

208 V 100–150 hp 125–200 hp 125–200 hp 100–150 hp

230 V 75–100 hp 100–125 hp 100–125 hp 75–100 hp 75 hp 60 hp 2543020500 11.00

208 V 60–75 hp 75–100 hp 75–100 hp 60–75 hp 60 hp 50 hp 2543020600 11.00

CP4C PE4 Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Enclosed 48 — Class 8636, 8638, and 8639

aThese Type 1 & 12 units are not shipped with a shorting contactor installed.

Table 36: Renewal Parts

Description Line

Vol tage

Class 8636 Controllers Class 8638/8639 Combination Controllers

Catalog Number $ Price

Type 1

No Shorting

Type

1 & 12

W/Shorting

Standard

Duty

Heavy

Duty

Standard

W/Bypass

Heavy

W/Bypass

Control Power

Secondary Fuse

FU6 & 7

Standard VA

208 V 3–7.5 hp a3–7.5 hp 2–5 hp

2543020060 11.00230 V 5–10 hp a5–10 hp 3–7.5 hp

460 V 10–20 hpa10–20 hp 7.5 –15 hp

208 V 10–25 hp 10–30 hp 10–30 hp 7.5–25 hp

2543020125 14.76q230 V 15–30 hp 15– 40 hp 15–40 hp 10–30 hp

460 V 30–60 hp 30–75 hp 30–75 hp 20–60 hp

208 V 30–40 hp 40–50 hp 40–50 hp 30–40 hp 30 hp

2543020250 13.68q230 V 40–50 hp 50–60 hp 50–60 hp 40–50 hp 40 hp

460 V 75–100 hp 100–125 hp 100–125 hp 75–100 hp 75 hp

208 V 50 hp 60 hp 60 hp 50 hp

2543020300 11.00230 V 60 hp 75 hp 75 hp 60 hp

460 V 125 hp 150 hp 150 hp 125 hp

208 V 100–150 hp 125–200 hp 125–200 hp 100–150 hp

2543020400 11.00230 V 125–200 hp 150–250 hp 150–250 hp 125–200 hp

460 V 250–400 hp 300–500 hp 300–500 hp 250–400 hp

208 V 60–75 hp 75–100 hp 75–100 hp 60–75 hp 60 hp 50 hp

2543020500 11.00230 V 75–100 hp 100–125 hp 100–125 hp 75–100 hp 75 hp 60 hp

460 V 150–200 hp 200–250 hp 200–250 hp 150–200 hp 150 hp 125 hp

Control Power

Secondary Fuse

FU6 & 7

Form T41

100 Additional VA

208 V 3–7.5 hp a3–7.5 hp 2–5 hp

2543020200 11.00230 V 5–10 hp a5–10 hp 3–7.5 hp

460 V 10–20 hp a10–20 hp 7.5–15 hp

208 V 10–25 hp 10–30 hp 10–30 hp 7.5–25 hp

2543020250 13.68q230 V 15–30 hp 15– 40 hp 15–40 hp 10–30 hp

460 V 30–60 hp 30–75 hp 30–75 hp 20–60 hp

208 V 30–40 hp 40–50 hp 40–50 hp 30–40 hp 30 hp

2543020400 11.00230 V 40–50 hp 50–60 hp 50–60 hp 40–50 hp 40 hp

460 V 75–100 hp 100–125 hp 100–125 hp 75–100 hp 75 hp

208 V 50 hp 60 hp 60 hp 50 hp

2543020500 11.00230 V 60 hp 75 hp 75 hp 60 hp

460 V 125 hp 150 hp 150 hp 125 hp

208 V 60–150 hp 75–200 hp 75–200 hp 60–150 hp 60 hp 50 hp

2543020700 11.00230 V 75–200 hp 100–250 hp 100–250 hp 75–200 hp 75 hp 60 hp

460 V 150–400 hp 200–500 hp 200–500 hp 150–400 hp 150 hp 125 hp

Control Power

Secondary Fuse

FU6 & 7

Form T42

200 Additional VA

208 V 3–7.5 hp a3–7.5 hp 2–5 hp

2543020300 11.00230 V 5–10 hp a5–10 hp 3–7.5 hp

460 V 10–20 hp a10–20 hp 7.5–15 hp

208 V 10–25 hp 10–30 hp 10–30 hp 7.5–25 hp

2543020400 11.00230 V 15–30 hp 15–40 hp 15–40 hp 10–30 hp

460 V 30–60 hp 30–75 hp 30–75 hp 20–60 hp

208 V 30–50 hp 40–60 hp 40–60 hp 30–50 hp 30 hp

2543020700 11.00

208 V 100–150 hp 125–200 hp 125–200 hp 100–150 hp

230 V 40–60 hp 50–75 hp 50–75 hp 40–60 hp 40 hp

230 V 125–200 hp 150–250 hp 150–250 hp 125–200 hp

460 V 75–125 hp 100–150 hp 100–150 hp 75–125 hp 75 hp

460 V 250–400 hp 300–500 hp 300–500 hp 250–400 hp

208 V 60–75 hp 75–100 hp 75–100 hp 60–75 hp 60 hp 50 hp

2543021000 11.00230 V 75–100 hp 100–125 hp 100–125 hp 75–100 hp 75 hp 60 hp

460 V 150–200 hp 200–250 hp 200–250 hp 150–200 hp 150 hp 125 hp

CP4C PE4qDiscount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide AC Softstart Products

Enclosed 48 — Class 8636, 8638, and 8639

aUnits with the following hp ratings are not shipped with shorting contactors: 3–7.5 hp (208 V), 5–10 hp (230 V) and 10–20 hp (460 V)

Description Line

Vol tage

Class 8636 Controllers 8638/8639 Combination Controllers

Catalog Number $ PriceType 1 Type 1 & 12 Standard Heavy

No Shorting W/Shorting Duty Duty

Altistart

CL1-CL2

Control Power Fuse

FU4 & 5

208 V 3–7.5 hp 3–10 hp a3–10 hp 2–7.5 hp

2543020025 11.00230 V 5–10 hp 5–15 hp a5–15 hp 3–10 hp

460 V 10–75 hp 10–100 hp a10–100 hp 7.5–75 hp

208 V 10–30 hp 15–40 hp 15–40 hp 10–30 hp

2543020050 11.00

230 V 15–40 hp 20–50 hp 20–50 hp 15–40 hp

460 V 100–200 hp 125–250 hp 125–250 hp 100–200 hp 2543020080 11.00

460 V 250–400 hp 300–500 hp 300–500 hp 250–400 hp 2543020100 11.00

208 V 40–75 hp 50–100 hp 50–100 hp 40–75 hp

2543020160 14.76q

230 V 50–100 hp 60–125 hp 60–125 hp 50–100 hp

208 V 100–150 hp 125–200 hp 125–200 hp 100–150 hp

2543020200 11.00

230 V 125–200 hp 150–250 hp 150–250 hp 125–200 hp

Auxiliary CPT

Primary Fuses

FU9 & 10

208 V 10–150 hp 10–200 hp 10–200 hp 7.5–150 hp

2543021500 11.00230 V 15–200 hp 15–250 hp 15–250 hp 10–200 hp

460 V 30–400 hp 30–500 hp 30–500 hp 20–500 hp

1.2VA / 6V Bulb

for Pilot Lights

208 V ALL ALL ALL ALL

DL1CB006 5.30c230 V ALL ALL ALL ALL

460 V ALL ALL ALL ALL

CP4C PE4qDiscount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Line Reactors and Motor Protection Output Filters

Options

Options—Field Installed

aSuitable for use with ATV 31, 575 V. See Altivar 31 Options for selection.

NOTE: Line reactors and filters are intended for separate mounting and wiring by the user. Based on NEC (NFPA

70)

430-150 current ratings. If drive has higher FLA rating, use the “amperes” rating to select the appropriate

filter.

Table 37: Line Reactors—480 V Rated Three Phase

460 V Drive Rating Open Style

Part Number $ Price

Enclosed

Part Number

(Type 1)

Approx.

Wt.

(Lbs.)

Enclosure

Dimensions

HxWxD (In.)

$ Price

Horsepower kW

1 — RL00202a169.00 RL00212a11 8x8x6 310.00

2–3 — RL00403a174.00 RL00413a12 8x8x6 315.00

5 — RL00803a262.00 RL00813a18 15x13x13 405.00

7.5 — RL01203 308.00 RL01213 25 15x13x13 455.00

10 — RL01803 357.00 RL01813 49 15x13x13 590.00

15 — RL02503 368.00 RL02513 49 15x13x13 602.00

20–25 — RL03503 487.00 RL03513 61 15x13x13 727.00

30 — RL04503 571.00 RL04513 70 15x13x13 816.00

40 — RL05503 578.00 RL05513 72 15x13x13 822.00

50–60 — RL08003 939.00 RL08013 86 15x13x13 1200.00

75 — RL10003 1096.00 RL10013 105 15x13x13 1366.00

100 — RL13003 1120.00 RL13013 105 15x13x13 1392.00

125 — RL16003 1260.00 RL16013 105 15x13x13 1539.00

150 — RL20003 1539.00 RL20013 131 15x13x13 1831.00

200 — RL25003 2727.00 RL25013 185 24x17x17 3447.00

250 — RL32003 2915.00 RL32013 235 24x17x17 3646.00

300 — RL40003 3576.00 RL40013 245 24x17x17 4338.00

350–400 — RL50003 4150.00 RL50013 335 24x17x17 5761.00

450–500 — RL60003 5740.00 RL60013 335 24x17x17 7431.00

Table 38: Line Reactors—208/230 V Rated Three Phase

208 V Drive Rating 230 V Drive Rating Open Style

Part Number $ Price

Enclosed

Part Number

(Type 1)

Approx.

Wt.

(Lbs.)

Enclosure

Dimensions

HxWxD (In.)

$ Price

Horsepower kW Horsepower kW

1— 1—RL00402168.00 RL00412 11 8x8x6 308.00

1.5–2 — 1.5–2 — RL00802a192.00 RL00812a15 8x8x6 332.00

3— 3—RL01202a214.00 RL01212a17 8x8x6 356.00

5— 5—RL01802a270.00 RL01812a19 8x8x6 416.00

7.5 — 7.5 — RL02502a311.00 RL02512a45 15x13x13 542.00

10 — 10 — RL03502 327.00 RL03512 47 15x13x13 559.00

15 — 15 — RL04502 431.00 RL04512 59 15x13x13 669.00

20 — 20 — RL05502 455.00 RL05512 59 15x13x13 693.00

25 — 25–30 — RL08002 534.00 RL08012 82 15x13x13 776.00

30 — 40 — RL10002 746.00 RL10012 82 15x13x13 999.00

40 — 50 — RL13002 848.00 RL13012 88 15x13x13 1106.00

50 — — — RL16002 1048.00 RL16012 88 15x13x13 1317.00

Table 39: Line Reactors—208/230 V Rated Single Phase

208 V Drive Rating 230 V Drive Rating Open Style

Part Number $ Price

Enclosed

Part Number

(Type 1)

Approx.

Wt.

(Lbs.)

Enclosure

Dimensions

HxWxD (In.)

$ Price

Horsepower kW Horsepower kW

.5 — .5–1 — RL00801 171.00 RL00811 15 8x8x6 311.00

1 — 2 — RL01201 202.00 RL01211 17 8x8x6 344.00

2 — 3 — RL01801 263.00 RL01811 19 8x8x6 407.00

3 — — — RL02501 275.00 RL02511 45 15x13x13 504.00

— 3 — 3 RL01801 246.00 RL01811 47 15x13x13 380.00

5 — 5 — RL03501 311.00 RL03511 59 15x13x13 542.00

7.5 — 7.5 — RL04501 410.00 RL04511 82 15x13x13 646.00

Table 40: Motor Protecting Output Filters—480 V Rated Type 1 Enclosed Motor Protection Output Filters

(UL508A)

Horsepower

Amperes KLCUL Filter Enclosed

Part Number $ Price Approximate

Weight (lbs)

Enclosure Dimensions

Drive 460 V Rating

HWD

IN mm IN mm IN mm

1–2 4 KLCUL4A1 1126.00 15 12.25 311 12.50 318 6.75 171

36KLCUL6A11148.00 15 12.25 311 12.50 318 6.75 171

58KLCUL8A11171.00 15 12.25 311 12.50 318 6.75 171

7.5 12 KLCUL12A1 1224.00 15 12.25 311 12.50 318 6.75 171

10 16 KLCUL16A1 1249.00 17 12.25 311 12.50 318 6.75 171

15 25 KLCUL25A1 1355.00 20 12.25 311 12.50 318 6.75 171

20–25 35 KLCUL35A1 1485.00 20 12.25 311 12.50 318 6.75 171

30 45 KLCUL45A1 1535.00 20 12.25 311 12.50 318 6.75 171

40 55 KLCUL55A1 1672.00 20 12.25 311 12.50 318 6.75 171

50–60 80 KLCUL80A2 2178.00 56 19.13 486 15.50 394 15.50 394

75 110 KLCUL110A2 3005.00 60 19.13 486 15.50 394 15.50 394

100 130 KLCUL130A2 3368.00 66 19.13 486 15.50 394 15.50 394

125 160 KLCUL160A2 3617.00 80 19.13 486 15.50 394 15.50 394

150 200 KLCUL200A3 3766.00 102 22.13 562 20.50 521 24.37 619

200 250 KLCUL250A3 3841.00 110 22.13 562 20.50 521 24.37 619

250 300 KLCUL300A3 3863.00 115 22.13 562 20.50 521 24.37 619

300 360 KLCUL360A3 4300.00 125 22.13 562 20.50 521 24.37 619

350 420 KLCUL420A3 4659.00 145 22.13 562 20.50 521 24.37 619

400 480 KLCUL480A3 5221.00 150 22.13 562 20.50 521 24.37 619

450–500 600 KLCUL600A3 5393.00 167 22.13 562 20.50 521 24.37 619

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Renewal Parts

Altivar® 61/71 AC Drives

Description For Use on Drives Catalog Number $ Price

Replacement

Parts

Arm of IGBT Inverter ATV61HD30M3X, ATV71HD30M3X VZ3IM2201M1271 487.00

Arm of IGBT Inverter ATV61HD37M3X, ATV71HD37M3X VZ3IM2301M1271 625.00

Arm of IGBT Inverter ATV61HD45M3X, ATV71HD45M3X VZ3IM2401M1271 798.00

Arm of the Rectifier ATV61HD45M3X, ATV71HD45M3X VZ3TD1162M1671 309.00

Control Terminal Board Kit All ATV61 & ATV71 VX4A1104 142.00

Fan Kits ATV61HD75M3X, ATV61HD90N4, ATV61HD55M3X, ATV61HC11N4, ATV71HD90N4,

ATV71HD55M3X VZ3V1215 199.00

Braking IGBT ATV61HD30N4, ATV61HD37N4, ATV71HD30N4, ATV71HD37N4 VZ3IM1145M1271 160.00

Braking IGBT ATV61HD30M3X, ATV71HD30M3X VZ3IM1195M0671 154.00

Braking IGBT ATV61HD37M3X, ATV61HD45M3X, ATV71HD37M3X, ATV71HD45M3X VZ3IM1300M0671 211.00

Braking IGBT ATV61HD45N4, ATV61HD55N4, ATV61HD75N4, ATV71HD45N4, ATV71HD55N4,

ATV71HD75N4 VZ3IM1300M1271 212.00

Braking Module ATV61HC13N4, ATV61HD90N4, ATV61HC11N4,ATV71HC11N4,ATV71HD90N4 VZ3TM1400M1271 407.00

Braking Module IGBT ATV61HD75M3X, ATV61HD55M3X, ATV71HD55M3X VZ3TM1400M0671 370.00

Braking Unit Kit ATV61HC16N4, ATV61HC22N4, ATV71HC13N4, ATV71HC16N4 VZ3F1110 1030.00

Capacitor Kit ATV61HD90N4, ATV61HC11N4, ATV71HD90N4 VY1ADC1110 628.00

Capacitor Kit ATV61HC13N4, ATV71HC11N4 VY1ADC1111 910.00

Capacitor Kit ATV61HC16N4, ATV61HC31N4, ATV61HC50N4, ATV61HC63N4, ATV71HC13N4,

ATV71HC25N4, ATV71HC28N4, ATV71HC40N4, ATV71HC50N4 VY1ADC1112 1088.00

Capacitor Kit ATV61HC22N4, ATV71HC16N4 VY1ADC1113 1441.00

Capacitor Kit ATV61HC25N4, ATV61HC40N4, ATV71HC20N4, ATV71HC31N4 VY1ADC1114 794.00

Capacitor Kit ATV61HD75M3X, ATV61HD55M3X, ATV71HD55M3X VY1ADC1115 693.00

Capacitor Kit ATV61HD90M3X, ATV71HD75M3X VY1ADC1116 453.00

Control Board Kit ATV61..075M3 to ATV61..D45M3X, ATV61..075N4 to ATV61..D75N4 VX4A61100Y 325.00

Control Board Kit ATV61..D55M3X to ATV61..D90M3X, ATV61..D90N4 to ATV61..C63N4 VX4A61101Y 375.00

Control Board Kit ATV71..037M3 to ATV71..D45M3X, ATV71..075N4 to ATV71..D75N4 VX4A71100Y 325.00

Control Board Kit ATV71..D55M3X to ATV71..D75M3X, ATV71..D90N4 to ATV71..C50N4 VX4A71101Y 375.00

Control Front Cover with

4x7 Segments All ATV61 & ATV71 VX4A1103 144.00

Control Module Cover

Assembly W/2 LEDS All ATV61 & ATV71 VX4A1102 423.00

Fan Control Board

ATV61HC16N4, ATV61HC22N4, ATV61HC25N4, ATV61HC31N4, ATV61HC13N4,

ATV61HC40N4, ATV61HC50N4, ATV61HC63N4, ATV61HD90M3X, ATV71HC13N4,

ATV71HC16N4, ATV71HC20N4, ATV71HC25N4, ATV71HC28N4, ATV71HC11N4,

ATV71HC31N4, ATV71HC40N4, ATV71HC50N4, ATV71HD75M3X

VX5A1400 160.00

Fan Kits

ATV61H075M3, ATV61HU15M3, ATV61H075N4, ATV61HU15N4, ATV61HU22N4,

ATV71H075M3, ATV71HU15M3, ATV71H037M3, ATV71H075N4, ATV71HU15N4,

ATV71HU22N4

VZ3V1203 44.00

Fan Kits ATV61HU55M3, ATV61HU55N4, ATV61HU75N4, ATV71HU55M3, ATV71HU55N4,

ATV71HU75N4 VZ3V1204 61.00

Fan Kits ATV61HD11M3X, ATV61HD15M3X, ATV61HD15N4,ATV61HD18N4, ATV71HD11M3X,

ATV71HD15M3X, ATV71HD15N4,ATV71HD18N4 VZ3V1205 98.00

Fan Kits ATV61HD30N4, ATV61HD37N4, ATV71HD30N4, ATV71HD37N4 VZ3V1206 104.00

Fan Kits ATV61HD30M3X, ATV61HD37M3X, ATV61HD45M3X, ATV71HD30M3X,

ATV71HD37M3X, ATV71HD45M3X VZ3V1207 137.00

Fan Kits ATV61HD45N4, ATV61HD55N4, ATV61HD75N4, ATV71HD45N4, ATV71HD55N4,

ATV71HD75N4 VZ3V1208 137.00

Fan Kits ATV61HU22M3, ATV61HU30M3, ATV61HU40M3, ATV61HU30N4, ATV61HU40N4,

ATV71HU22M3, ATV71HU30M3, ATV71HU40M3, ATV71HU30N4, ATV71HU40N4 VZ3V1209 55.00

Fan Kits ATV61HU75M3, ATV61HD11N4, ATV71HU75M3, ATV71HD11N4 VZ3V1210 78.00

Fan Kits ATV61HD18M3X, ATV61HD22M3X, ATV61HD22N4, ATV71HD18M3X,

ATV71HD22M3X, ATV71HD22N4 VZ3V1211 104.00

Heat Sink Fan

ATV61HC16N4, ATV61HC22N4, ATV61HC25N4, ATV61HC31N4, ATV61HC13N4,

ATV61HC40N4, ATV61HC50N4, ATV61HC63N4, ATV71HC13N4, ATV71HC16N4,

ATV71HC20N4, ATV71HC25N4, ATV71HC28N4, ATV71HC11N4, ATV71HC31N4,

ATV71HC40N4, ATV71HC50N4

VZ3V1212 578.00

Fan Power Electronic ATV61HD90M3X,ATV71HD75M3X VZ3V1216 1278.00

Filter Board ATV61HD18M3X, ATV61HD22M3X, ATV71HD18M3X, ATV71HD22M3X VX4A1106 46.00

Filter Board ATV61HD22N4, ATV71HD22N4 VX4A1107 260.00

Filter Board ATV61HD30N4, ATV61HD37N4, ATV71HD30N4, ATV71HD37N4 VX4A1108 149.00

Filter Board ATV61HD30M3X, ATV61HD37M3X, ATV61HD45M3X, ATV71HD30M3X,

ATV71HD37M3X, ATV71HD45M3X VX4A1109 84.00

Filter Board ATV61HD45N4, ATV61HD55N4, ATV61HD75N4, ATV71HD45N4, ATV71HD55N4,

ATV71HD75N4 VX4A1110 130.00

Filter Board ATV61HC16N4, ATV71HC13N4 VX4A1113 294.00

Filter Board ATV61HC22N4, ATV71HC16N4 VX4A1114 382.00

Filter Board ATV61HC25N4, ATV61HC31N4,ATV71HC20N4,ATV71HC25N4,ATV71HC28N4 VX4A1115 412.00

Filter Board ATV61HD75M3X, ATV61HC13N4, ATV61HD90N4, ATV61HD55M3X, ATV61HD90M3X,

ATV61HC11N4,ATV71HC11N4,ATV71HD90N4, ATV71HD55M3X, ATV71HD75M3X VX4A1116 151.00

Filter Board ATV61HC50N4, ATV61HC63N4,ATV71HC40N4,ATV71HC50N4 VX4A1117 244.00

CP4B Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Renewal Parts

Altivar® 61/71 AC Drives

Description For Use on Drives Catalog Number $ Price

Replacement

Parts

Filter Board ATV61HC40N4,ATV71HC31N4 VX4A1118 333.00

Front Cover Incl.I/O

Terminal Cover

ATV61HD75M3X, ATV61HD90N4, ATV61HD55M3X, ATV61HC11N4, ATV71HD90N4,

ATV71HD55M3X Common Part? VY1A1210 283.00

Front Cover Incl.I/O

Terminal Cover ATV61HC13N4, ATV61HD90M3X,ATV71HC11N4,ATV71HD75M3X Common part? VY1A1211 283.00

Front Cover Incl.I/O

Terminal Cover ATV61HC16N4,ATV71HC13N4 (Common part?) VY1A1212 441.00

Front Cover Incl.I/O

Terminal Cover ATV61HC22N4,ATV71HC16N4 (Check common part?) VY1A1213 500.00

Front Cover Incl.I/O

Terminal Cover

ATV61HC25N4, ATV61HC31N4, ATV71HC20N4,ATV71HC25N4,ATV71HC28N4

Common Part? VY1A1214 529.00

Front Cover Incl.I/O

Terminal Cover ATV61HC40N4, ATV61HC50N4, ATV71HC31N4, ATV71HC40N4 common part? VY1A1216 813.00

Front Cover Incl.I/O

Terminal Cover ATV61HC63N4,ATV71HC50N4 VY1A1217 1111.00

Gate Drive Board IGBT ATV61HC16N4, ATV71HC13N4 VX5A1200 1294.00

Gate Drive Board IGBT ATV61HC22N4, ATV61HC25N4, ATV71HC16N4, ATV71HC20N4 VX5A1201 647.00

Gate Drive Board IGBT ATV61HC31N4, ATV71HC25N4, ATV71HC28N4 VX5A1202 647.00

Gate Drive Board IGBT ATV61HC40N4, ATV61HC50N4, ATV71HC31N4, ATV71HC40N4 VX5A1203 1084.00

Gate Drive Board IGBT ATV61HC63N4, ATV71HC50N4 VX5A1204 1220.00

Internal Fan

ATV61HC16N4, ATV61HC22N4, ATV61HC25N4 , ATV61HC31N4, ATV61HC40N4,

ATV61HC50N4, ATV61HC63N4, ATV71HC13N4, ATV71HC16N4, ATV71HC20N4,

ATV71HC25N4, ATV71HC28N4, ATV71HC31N4, ATV71HC40N4, ATV71HC50N4

VZ3V1213 47.00

Internal Fan ATV61HD75M3X, ATV61HC13N4, ATV61HD90N4, ATV61HD55M3X, ATV61HD90M3X,

ATV61HC11N4, ATV71HC11N4, ATV71HD90N4, ATV71HD55M3X, ATV71HD75M3X VZ3V1214 42.00

Motor Current Sensor ATV61HD75M3X, ATV61HC13N4, ATV61HD90N4, ATV61HD55M3X, ATV61HD90M3X,

ATV61HC11N4, ATV71HC11N4, ATV71HD90N4, ATV71HD55M3X, ATV71HD75M3X VY1A1105 106.00

Motor Current Sensor ATV61HC16N4, ATV71HC13N4 VY1A1107 118.00

Motor Current Sensor ATV61HC22N4, ATV61HC25N4, ATV61HC31N4, ATV71HC16N4, ATV71HC20N4,

ATV71HC25N4, ATV71HC28N4 VY1A1108 176.00

Motor Current Sensor ATV61HC40N4, ATV61HC50N4, ATV61HC63N4, ATV71HC31N4, ATV71HC40N4,

AT V 7 1 H C 5 0 N 4 VY1A1109 190.00

Plastic Kit

ATV61H075M3, ATV61HU15M3, ATV61H075N4, ATV61HU15N4, ATV61HU22N4,

ATV71H075M3, ATV71HU15M3, ATV71H037M3, ATV71H075N4, ATV71HU15N4,

AT V 7 1 H U 2 2 N 4

VY1A1202 33.00

Plastic Kit ATV61HU22M3, ATV61HU30M3, ATV61HU40M3, ATV61HU30N4, ATV61HU40N4,

ATV71HU22M3, ATV71HU30M3, ATV71HU40M3, ATV71HU30N4, ATV71HU40N4 VY1A1203 33.00

Plastic Kit ATV61HU55M3, ATV61HU55N4, ATV61HU75N4, ATV71HU55M3, ATV71HU55N4,

AT V 7 1 H U 7 5 N 4 VY1A1204 52.00

Plastic Kit ATV61HD11M3X, ATV61HD15M3X, ATV61HD15N4,ATV61HD18N4, ATV71HD11M3X,

ATV71HD15M3X, ATV71HD15N4, ATV71HD18N4 VY1A1205 56.00

Plastic Kit ATV61HU75M3, ATV61HD11N4, ATV71HU75M3, ATV71HD11N4 VY1A1215 58.00

Plastic Kit ATV61HC16N4, ATV71HC13N4 VY1A1401 882.00

Plastic Kit ATV61HC22N4, ATV71HC16N4 VY1A1402 618.00

Plastic Kit ATV61HC25N4, ATV61HC31N4, ATV71HC20N4, ATV71HC25N4, ATV71HC28N4 VY1A1403 706.00

Plastic Kit ATV61HC40N4, ATV61HC50N4, ATV71HC31N4, ATV71HC40N4 VY1A1406 1111.00

Plastic Kit ATV61HC63N4, ATV71HC50N4 VY1A1407 1274.00

Plastic Kit ATV61HD75M3X, ATV61HD90N4, ATV61HD55M3X, ATV61HC11N4, ATV71HD90N4,

ATV71HD55M3X VY1A1404 131.00

Plastic Kit ATV61HC13N4, ATV61HD90M3X, ATV71HC11N4, ATV71HD75M3X VY1A1405 134.00

Power Board ATV61HC13N4, ATV71HC11N4 VX5A1HC1113 737.00

Power Board ATV61HC16N4, ATV71HC13N4 VX5A1HC1316 1235.00

Power Board ATV61HC22N4, ATV71HC16N4 VX5A1HC1622 1824.00

Power Board ATV61HC25N4, ATV71HC20N4 VX5A1HC2025 1824.00

Power Board ATV71HC25N4, ATV61HC31N4 VX5A1HC2531 1824.00

Power Board ATV61HC40N4, ATV71HC31N4 VX5A1HC3140 2792.00

Power Board ATV61HC50N4, ATV71HC40N4 VX5A1HC4050 2846.00

Power Board ATV61HC63N4, ATV71HC50N4 VX5A1HC5063 2846.00

Power Board ATV61HD18M3X, ATV71HD18M3X VX5A1HD18M3X 486.00

Power Board ATV61HD37N4, ATV71HD37N4 VX5A1HD37N4 446.00

Power Board ATV61HD45M3X, ATV71HD45M3X VX5A1HD45M3X 459.00

Power Board ATV61HD75M3X, ATV61HD55M3X, ATV71HD55M3X VX5A1HD5575 956.00

Power Board ATV61HD90M3X, ATV71HD75M3X VX5A1HD7590 956.00

Power Board ATV61HD90N4, ATV61HC11N4, ATV71HD90N4 VX5A1HD9011 737.00

Power Board ATV71HC28N4 VX5A71HC28N4 1904.00

Power Board ATV61HD22M3X, ATV71HD22M3X VX5A1HD22M3X 486.00

Power Board ATV61HD22N4, ATV71HD22N4 VX5A1HD22N4 475.00

Power Board ATV61HD30M3X, ATV71HD30M3X VX5A1HD30M3X 459.00

CP4B Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Renewal Parts

Altivar® 61/71 AC Drives

Description For Use on Drives Catalog Number $ Price

Replacement

Parts

Power Board ATV61HD37M3X, ATV71HD37M3X VX5A1HD37M3X 459.00

Power Board / IGBT

Modules ATV61HD30N4, ATV71HD30N4 VX5IM2145M1271 1139.00

Power Board / IGBT

Modules ATV61HD45N4, ATV71HD45N4 VX5IM2200M1271 1379.00

Power Board / IGBT

Modules ATV61HD55N4, ATV71HD55N4 VX5IM2300M1271 1252.00

Power Board / IGBT

Modules ATV61HD75N4, ATV71HD75N4 VX5IM2400M1271 992.00

Power IGBT Module ATV61HC13N4, ATV61HD90N4, ATV61HC11N4, ATV71HC11N4, ATV71HD90N4 VZ3IM1400M1271 606.00

Power IGBT Module ATV61HC22N4, ATV61HC25N4, ATV71HC16N4, ATV71HC20N4 VZ3IM1402M1271 794.00

Power IGBT Module ATV61HD75M3X, ATV61HD55M3X, ATV61HD90M3X, ATV71HD55M3X,

ATV71HD75M3X VZ3IM1600M0671 461.00

Power IGBT Module ATV61HC16N4, ATV71HC13N4 VZ3IM1600M1271 529.00

Power IGBT Module ATV61HC31N4, ATV71HC25N4, ATV71HC28N4 VZ3IM1602M1271 1059.00

Power IGBT Module ATV61HC40N4, ATV61HC50N4, ATV71HC31N4, ATV71HC40N4 VZ3IM1603M1271 1491.00

Power IGBT Module ATV61HC63N4, ATV71HC50N4 VZ3IM1604M1271 1952.00

Power IGBT Module ATV61HD37N4, ATV71HD37N4 VZ3IM2195M1271 223.00

Power Rectifier Module ATV61HD90N4, ATV61HC11N4, ATV71HD90N4 VZ3TD1250M1671 310.00

Power Rectifier Module ATV61HC16N4, ATV61HC13N4, ATV71HC13N4, ATV71HC11N4 VZ3TD1285M1671 353.00

Power Terminal Block ATV61HD11M3X, ATV61HD15M3X, ATV61HD15N4, ATV61HD18N4,

ATV71HD11M3X, ATV71HD15M3X, ATV71HD15N4, ATV71HD18N4 VZ3N1205 65.00

Power Terminals Block ATV61HD18M3X, ATV61HD22M3X, ATV61HD22N4, ATV71HD18M3X,

ATV71HD22M3X, ATV71HD22N4 VZ3N1206 229.00

Power Terminals Block ATV61HD30N4, ATV61HD37N4, ATV71HD30N4, ATV71HD37N4 VZ3N1207 229.00

Rectfier Module

Thyristor/Diode

ATV61HC22N4, ATV61HD75M3X, ATV61HD55M3X, ATV61HD90M3X,

ATV71HC16N4, ATV71HD55M3X, ATV71HD75M3X VZ3TD1330M1601 412.00

Rectifier Module Diode

ATV61HC25N4, ATV61HC31N4, ATV61HC40N4, ATV61HC50N4, ATV61HC63N4

,ATV71HC20N4, ATV71HC25N4, ATV71HC28N4, ATV71HC31N4, ATV71HC40N4,

ATV71HC50N4

VZ3DM1600M1671 412.00

Rectifier Module Thyristor ATV61HC25N4, ATV61HC50N4, ATV71HC20N4, ATV71HC40N4 VZ3TM1425M1671 382.00

Rectifier Module Thyristor ATV61HC31N4, ATV61HC40N4, ATV61HC63N4, ATV71HC25N4, ATV71HC28N4,

ATV71HC31N4, ATV71HC50N4 VZ3TM1600M1671 407.00

Rectifier Snubber Circuit

ATV61HC16N4, ATV61HC22N4, ATV61HC25N4, ATV61HC31N4, ATV61HC40N4,

ATV61HC50N4, ATV61HC63N4, ATV71HC13N4, ATV71HC16N4, ATV71HC20N4,

ATV71HC25N4, ATV71HC28N4, ATV71HC31N4, ATV71HC40N4, ATV71HC50N4

VX4A1200 294.00

SCR Modules ATV61HD30N4, ATV71HD30N4 VZ3TD1057M1671 44.00

SCR Modules ATV61HD37N4, ATV61HD45N4, ATV71HD37N4, ATV71HD45N4 VZ3TD1072M1671 156.00

SCR Modules ATV61HD30M3X, ATV61HD55N4, ATV71HD30M3X, ATV71HD55N4 VZ3TD1092M1671 155.00

SCR Modules ATV61HD37M3X, ATV61HD75N4, ATV71HD37M3X, ATV71HD75N4 VZ3TD1132M1671 290.00

Screw Kit ATV61HD75M3X, ATV61HD90N4, ATV61HD55M3X, ATV61HC11N4, ATV71HD90N4,

ATV71HD55M3X VY1ADV1105 107.00

Screw Kit ATV61HC22N4, ATV71HC16N4, ATV71HC20N4 VY1ADV1108 76.00

Screw Kit ATV61HC25N4, ATV61HC31N4, ATV71HC20N4, ATV71HC25N4, ATV71HC28N4 VY1ADV1109 76.00

Screw Kit ATV61HC40N4, ATV61HC50N4, ATV71HC31N4, ATV71HC40N4 VY1ADV1110 70.00

Screw Kit ATV61HC63N4, ATV71HC50N4 VY1ADV1111 70.00

Screw Kit ATV61HC13N4, ATV61HD90M3X, ATV71HC11N4, ATV71HD75M3X VY1ADV1106 109.00

Screw Kit ATV61HC16N4, ATV71HC13N4 VY1ADV1107 76.00

Snubber Capacitor Kit ATV61HD90N4, ATV61HC11N4, ATV71HD90N4 VZ3S1910 407.00

Snubber Capacitor Kit ATV61HD75M3X, ATV61HD55M3X, ATV61HD90M3X, ATV71HD55M3X,

ATV71HD75M3X VZ3S1911 68.00

Snubber Capacitor Kit ATV61HC13N4, ATV71HC11N4 VZ3S1912

Soft Charge Board

ATV61HC16N4, ATV61HC22N4, ATV61HD75M3X, ATV61HC25N4, ATV61HC31N4,

ATV61HC13N4, ATV61HD90N4, ATV61HC40N4, ATV61HC50N4, ATV61HC63N4,

ATV61HD55M3X, ATV61HD90M3X, ATV61HC11N4, ATV71HC13N4, ATV71HC16N4,

ATV71HC20N4, ATV71HC25N4, ATV71HC28N4, ATV71HC11N4, ATV71

VX5A1300 126.00

Thermal Sensor

ATV61HD75M3X, ATV61HC13N4, ATV61HD90N4, ATV61HD55M3X,

ATV61HD90M3X, ATV61HC11N4, ATV71HC11N4, ATV71HD90N4, ATV71HD55M3X,

ATV71HD75M3X

VZ3G1102 41.00

Thermal Sensor

ATV61HC16N4, ATV61HC22N4, ATV61HC25N4, ATV61HC31N4, ATV61HC40N4,

ATV61HC50N4, ATV61HC63N4, ATV71HC13N4, ATV71HC16N4, ATV71HC20N4,

ATV71HC25N4, ATV71HC28N4, ATV71HC31N4, ATV71HC40N4, ATV71HC50N4

VZ3G1104 71.00

Wire Kit ATV61HC16N4, ATV71HC13N4 VZ3N1316 382.00

Wire Kit ATV61HC22N4, ATV71HC16N4 VZ3N1317 471.00

Wire Kit ATV61HC31N4, ATV61HC25N4, ATV71HC25N4, ATV71HC28N4, ATV71HC20N4 VZ3N1318 2765.00

Wire Kit ATV61HC40N4, ATV61HC50N4, ATV71HC31N4, ATV71HC40N4 VZ3N1333 1135.00

Wire Kit ATV61HC63N4, ATV71HC50N4 VZ3N1334 894.00

Wire Kit ATV61HD75M3X, ATV61HD90N4, ATV61HD55M3X, ATV61HC11N4, ATV71HD90N4,

ATV71HD55M3X VZ3N1323 244.00

Wire Kit ATV61HC13N4, ATV61HD90M3X, ATV71HC11N4, ATV71HD75M3X VZ3N1324 242.00

Note: Spare Parts not listed are not yet available for Commercial sale. For installation contact your local Square D Services location or call 1-888-788-2733

(option Technical Support then option for Field Services) for scheduling assistance.

CP4B Discount

Schedule

Prices subject to change without notice.

06/2009

REDUCED

AVAILABILTY

Pricing Guide Renewal Parts List

Altivar® 58 TRX AC Drives

aThis kit can be used on ATV58..U41M2 product with a date code of 0126 or later. ATV58..U41M2 product manufactured prior to this date had the fan

leads soldered to the power board and should be sent to the factory for repair or exchange.

Note: We anticipate offering renewal parts for 5 years through 2012. The ATV61 and ATV71 AC drive should be used in new applications.

Description For Use on Drives Catalog Number $ Price

Replacement

Parts

ATV58 TRX Control Board Kit ATV58 Type E, F, H and N VX4A581U 625.00

ATV58 Flux Vector Control Board FVC only VX4A58F1 1195.00

Removable ATV58 Control Board Terminal Strips

(Includes relay terminal strip and both 9 pin and

10 pin terminal strips)

ATV58 Type E, F, H and N VZ3N581U 25.00

Internal Fan Kit for ATV58 Frame 2 and Frame 3 (2

Fans)

ATV58..U29M2, U41M2a, U54M2, U72M2 and

ATV58..U18N4, U29N4, U41N4, U54N4,

U72N4, U90N4

VZ3V58223U 125.00

Internal Fan Kit for ATV58 Frame 4 and Frame 5 (3

Fans)

ATV58..U90M2, D12M2 and

ATV58..D12N4, D16N4, D23N4 VZ3V58245U 158.00

Internal Fan Kit for ATV58 Frame 6 (4 Fans) ATV58..D16M2, D23M2 and

ATV58..D28N4, D33N4, D46N4 VZ3V58260U 198.00

Internal Fan Kit for ATV58 Frame 7 (4 Fans) ATV58..D28M2, D33M2, D46M2 and

ATV58..D54N4, D64N4, D79N4 VZ3V58270U 235.00

Power Terminal Block for ATV58 Frame 6 ATV58..D16M2 and

ATV58..D28N4, D33N4 VZ3N58160U 155.00

Power Terminal Block for ATV58 Frame 6 ATV58..D23M2 and

AT V 5 8 . .D 4 6 N 4 VZ3N58165U 165.00

Power Terminal Block for ATV58 Frame 7 ATV58..D28M2, D33M2, D46M2 and

ATV58..D54N4, D64N4, D79N4 VZ3N58170U 175.00

Internal EMC Filter Kit

ATV58 ..D28N4 VX4A58861U 325.00

ATV58 ..D33N4 VX4A58862U 475.00

ATV58 ..D46N4 VX4A58863U 485.00

ATV58 ..D54N4 VX4A58871U 547.00

ATV58 ..D64N4 VX4A58872U 634.00

ATV58 ..D79N4 VX4A58873U 883.00

Power Board

ATV58 ..D16M2 VX5A58D16M2U 1138.00

ATV58 ..D23M2 VX5A58D23M2U 1138.00

ATV58 ..D28M2 VX5A58D28M2U 1510.00

ATV58 ..D33M2 VX5A58D33M2U 1595.00

ATV58 ..D46M2 VX5A58D46M2U 1595.00

ATV58 ..D28N4 VX5A58D28N4U 1138.00

ATV58 ..D33N4 VX5A58D33N4U 1138.00

ATV58 ..D46N4 VX5A58D46N4U 1138.00

ATV58 ..D54N4 VX5A58D54N4U 1510.00

ATV58 ..D64N4 VX5A58D64N4U 1595.00

ATV58 ..D79N4 VX5A58D79N4U 1595.00

Output Transistor Kit

[Six (6) transistors included per kit]

ATV58 ..D28N4 VZ3IM6075M1258U 740.00

ATV58 ..D16M2 & D33N4 VZ3IM6100M1258U 905.00

ATV58 ..D23M2, D28M2 & D46N4, D54N4 VZ3IM6150M1258U 1036.00

ATV58 ..D33M2, D46M2 & D64N4, D79N4 VZ3IM2200M1258U 1308.00

Dynamic Braking Transistor

ATV58 ..D16M2, D23M2, & D28N4, D33N4, D46N4 VZ3IM1050M1258U 310.00

ATV58 ..D28M2 & D54N4 VZ3IM1100M1258U 340.00

ATV58 ..D33M2, D46M2 & D64N4, D79N4 VZ3IM1150M1258U 380.00

Input Diode/Thyristor Bridge Kit for all three (3) phases

ATV58 ..D16M2, & D28N4, D33N4 VZ3TD1055M1658U 410.00

ATV58 ..D23M2, D28M2 & D46N4, D54N4 VZ3TD1090M1658U 456.00

ATV58 ..D33M2, D46M2 & D64N4, D79N4 VZ3TD1130M1658U 520.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

REDUCED

AVAILABILTY

Pricing Guide Renewal Parts List

Altivar® 58 TRX AC Drives

Note: Note: We anticipate offering renewal parts for 5 years through 2012. The ATV61 and ATV71 AC drive should be used in new applications.

Description For Use on Drives Catalog Number $ Price

Replacement

Parts

(For ATV58

Type H 125 hp

to 500 hp VT)

Control Board ATV58H..C10N4–C33N4 VX4A381 680.00

Interface Board ATV58H.. C10N4–C33N4 VX4A382 300.00

Gate Drive Board ATV58H.. C10N4–C33N4 VX5A38C10N4 820.00

Gate Board ATV58H.. C10N4 VX5A38C11 180.00

Current Gait Board

ATV58H.. C10N4 VX5A38C12 400.00

ATV58H..C13N4–C15N4 and C25N4 VX5A38C13N4 400.00

ATV58H.. C19N4 VX5A38C14 400.00

ATV58H.. C23N4 and C28N4 VX5A38C15N4 400.00

ATV58H.. C31N4 VX5A38C16 400.00

ATV58H.. C33N4 VX5A38C17 400.00

Pre-Charge Contactor Kit

ATV58H.. C10N4 VY1A38101 360.00

ATV58H.. C13N4 VY1A38102 370.00

ATV58H.. C15N4–C19N4 VY1A38103 890.00

ATV58H.. C23N4–C33N4 VY1A38104 1565.00

Current Transformer

ATV58H.. C10N4 VY1A38111 100.00

ATV58H.. C13N4 VY1A38112 100.00

ATV58H.. C15N4–C19N4 VY1A38113 100.00

ATV58H.. C23N4–C25N4 VY1A38114 260.00

ATV58H.. C28N4–C33N4 VY1A38115 260.00

Power Supply Board ATV58H.. C10N4–C33N4 VY1A38120 820.00

Insulating Sheets

ATV58H.. C10N4 VY1A38210 120.00

ATV58H.. C13N4–C19N4 VY1A38211 240.00

ATV58H.. C23N4–C33N4 VY1A38212 320.00

Thermal Grease VY1A58856 80.00

Screw Kit

ATV58H.. C10N4 VY1ADV384 85.00

ATV58H.. C13N4 VY1ADV385 100.00

ATV58H.. C15N4 VY1ADV386 100.00

ATV58H.. C19N4 VY1ADV387 100.00

ATV58H.. C23N4–C25N4 VY1ADV388 150.00

ATV58H.. C28N4–C33N4 VY1ADV389 160.00

Capacitor Kit

ATV58H.. C10N4 VZ3C3810 2455.00

ATV58H.. C13N4–C19N4 VZ3C3811 3560.00

ATV58H.. C23N4–25 VZ3C3812 6230.00

ATV58H.. C28N4–C33N4 VZ3C3813 7350.00

Input Diode Bridge ATV58H.. C10N4–C33N4 VZ3D381 345.00

Input Filter ATV58H.. C10N4–C33N4 VZ3D382 145.00

Power Fuse

ATV58H.. C10N4 VZ3F3801 305.00

ATV58H.. C13N4–C19N4 VZ3F3802 320.00

ATV58H.. C23N4–25 VZ3F3803 565.00

ATV58H.. C28N4–C33N4 VZ3F3804 565.00

Thermal Sensor ATV58H.. C10N4–C33N4 VZ3G381 180.00

Output Transistor ATV58H.. C10N4 VZ3I381 1120.00

Output Transistor Kit

ATV58H.. C13N4–C19N4 VZ3I382 2225.00

ATV58H.. C23N4–C25N4 VZ3I383 4305.00

ATV58H.. C28N4–C33N4 VZ3I384 5340.00

Internal Cable Kit

ATV58H.. C10N4 VZ3N3808 455.00

ATV58H.. C13N4–C19N4 VZ3N3809 475.00

ATV58H.. C23N4–C33N4 VZ3N3810 1040.00

Pre-Charge Resistor

ATV58H.. C10N4 VZ3R3810 335.00

ATV58H.. C13N4–C19N4 VZ3R3811 195.00

ATV58H.. C23N4–C33N4 VZ3R3812 240.00

Control Transformer

ATV58H.. C10N4 VZ3TR381 180.00

ATV58H.. C13N4–C19N4 VZ3TR382 305.00

ATV58H.. C23N4–C33N4 VZ3TR383 350.00

Heatsink Fans

ATV58H.. C10N4 VZ3V3808 675.00

ATV58H.. C13N4–C19N4 VZ3V3809 970.00

ATV58H.. C23N4–C33N4 VZ3V3810 1780.00

Internal Fan Kit

ATV58H.. C10N4–C19N4 VZ3V3818 120.00

ATV58H.. C19N4 VZ3V3819 60.00

ATV58H.. C23N4–C33N4 VZ3V3820 225.00

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

REDUCED

AVAILABILTY

Pricing Guide Renewal Parts List

Altivar® 58 TRX AC Drives

aPL7 Software provides pre-defined configuration selections for 1⁄2 to 100 hp Type H products.

Note: Note: We anticipate offering renewal parts for 5 years through 2012. The ATV61 and ATV71 AC drive should be used in new applications.

Table 41: Options—Field Installed

Description For Use on Drives Catalog Number $ Price

Operator

Interface

Keypad ATV58 Type E, F, H, N and FVC VW3A58101U 115.00

Keypad Remote Mount Kit (IP65 rating) ATV58 Type H and FVC VW3A58103 125.00

Power Suite test & commissioning software for PC & PPC on CD ATV58 all types VW3A8104 150.00

PowerSuite upgrade CD from most recent to new version ATV58 all types VW3A8105 98.00

PC Cable connection kit to connect to PC to drive ATV58 all types VW3A8106 75.00

Pocket PC connection kit to connect HP Jornada to drive

Closing Plate Kit ATV58 Type N VW3A58836 25.00

Keypad Mount Kit ATV58 Type N VW3A58837 55.00

Operator, mounting collar, 2.5k ohm, 1⁄2 watt potentiometer All enclosed models, ATV58 Type H ATVPOT25K 69.00

I/O Extension

Cards

Analog I/O Option Card

Provides 2 Logic Inputs, 1 Logic Output, 1 Analog Output, and

1 Bi-polar Analog Input

ATV58 Type E, F, H, N and FVC VW3A58201U 200.00

Digital I/O Option Card

Provides 2 Logic Inputs, 1 Logic Output, 1 Analog Output, and

A,A-,B,B- Logic Inputs for

Encoder Speed Feedback.

ATV58 Type E, F, H, N and FVC VW3A58202U 200.00

General Purpose Option Card

Provides 1 Form C Relay Output and 3 Analog Outputs ATV58 Type E, F, H and N VW3A58253U 350.00

Application

Option Cards

Pump Switching Card

Sequences up to five pumps with one ATV58 ATV58 Type E, F, H and N VW3A58210U 550.00

115 Vac ATV58 Logic Input Module

Provides 115 Vac conversion for logic inputs LI1,LI2, LI3 & LI4 ATV58 Type H and N VW3A58275U 195.00

0–10 volt to 4–20 mA Adapter Card ATV58 all types 3115829750 175.00

Communication

FIPIO Communication Card ATV58 Type E, F, Ha and N VW3A58301U 550.00

Modbus® + Communication Card ATV58 Type E, F, H, N and FVC VW3A58302U 550.00

Modbus/Unitelway Communication Card ATV58 Type E, F, H, N and FVC VW3A58303U 300.00

Interbus S Communication Card ATV58 Type E, F, H, N and FVC VW3A58304EU 550.00

RS485 Cable w/ Modbus Mapping Guide ATV58 Type E, F, H, N and FVC VW3A58306U 50.00

Profibus DP Communication Card ATV58 Type E, F, H, N and FVC VW3A58307U 550.00

Device Net Communication Card ATV58 Type E, F, H, N and FVC VW3A58309U 550.00

Ethernet Modbus TCP/IP Communication Card ATV58 Type E, F, H, N and FVC VW3A58310U 550.00

FIPIO Communication Card ATV58 Type H 125–500 hp and FVC VW3A58311U 550.00

LonWorks to Modbus DIN Rail Mount Gateway ATV58 Type E, F, H and N VW3A58312PU 495.00

Johnson Controls N2 Communication Card ATV58 Type E, F, H and N VW3A58354U 300.00

Fan Kit

Ventilation Fan Kit

These kits mount directly to the top of the

ATV58 Type H and Type FVC products.

They are powered from the drive.

ATV58..U09M2, U18M2 VW3A58821 100.00

ATV58..U29M2, U41M2 and

ATV58..U18N4, U29N4, U41N4 VW3A58822 100.00

ATV58..U54M2, U72M2 and

ATV58..U54N4, U72N4, U90N4 VW3A58823 150.00

ATV58..U90M2, D12M2 and

ATV58..D12N4, D16N4, D23N4 VW3A58824 175.00

ATV58..D16M2, D23M2 and

ATV58..D28N4, D33N4, D46N4 VW3A58825 195.00

ATV58..D28M2, D33M2, D46M2 and

ATV58..D54N4, D64N4, D79N4 VW3A58826 225.00

Braking

Components

DB Transistor ATV58..U09M2, U18M2 VW3A58701 280.00

Protected DB Resistors in Type 1 Enclosure.

For use with ATV58 Type E, F, FVC, H and N.

ATV58..U09M2, U18M2: U18N4,

U29N4, U41N4, U54N4, U72N4 VW3A66711 422.00

ATV58..U29M2, U41M2: U90N4,

D12N4 VW3A66712 633.00

ATV58..U54M2, U72M2: D16N4,

D23N4 VW3A66713 950.00

ATV58..U90M2, D12M2 and

ATV58..D28N4, D33N4, D46N4 VW3A66714 1266.00

ATV58..D16M2, D23M2 and

AT V 5 8 . .D 5 4 N 4 VW3A66715 1846.00

ATV58..D28M2, D33M2, D46M2 and

ATV58..D64N4, D79N4 VW3A66716 2321.00

Hardware

Line Reactor for Single Phase Input

IP00 Rating for use with ATV58 Type E, F, H and N

ATV58..U09M2, U18M2, U29M2,

U41M2, U72M2 VW3A58501 350.0

ATV58..U90M2, D12M2 VW3A58502 380.0

EMC Wiring Plate

Assist in compliance with Level A EMC directive.

These plates are used to land the shield of shielded

motor cables. For use with ATV58 Type FVC and Type H.

ATV58..U09M2, U18M2 VW3A58831 25.00

ATV58..U29M2, U41M2 and

ATV58..U18N4, U29N4, U41N4 VW3A58832 25.00

ATV58..U54M2, U72M2 and

ATV58..U54N4, U72N4, U90N4 VW3A58833 25.00

ATV58..U90M2, D12M2 and

ATV58..D12N4, D16N4, D23N4 VW3A58834 25.00

Conduit Entrance Kit

These kits have various sized knockouts to land

conduit and provide wire bending space to wire line

and load cables. For use with ATV58 Type FVC and Type H.

ATV58..U09M2, U18M2 VW3A58842 45.00

ATV58..U29M2, U41M2 and

ATV58..U18N4, U29N4, U41N4 VW3A58843 45.00

ATV58..U54M2, U72M2 and

ATV58..U54N4, U72N4, U90N4 VW3A58844 45.00

ATV58..U90M2, D12M2 and

ATV58..D12N4, D16N4, D23N4 VW3A58845 45.00

ATV58..D16M2, D23M2 and

ATV58..D28N4, D33N4, D46N4 VW3A58846 65.00

ATV58..D28M2, D33M2, D46M2 and

ATV58..D54N4, D64N4, D79N4 VW3A58847 65.00

Operator Interface Options

I/O Extension Cards

Communication Options

Ventilation Fan Kits

Conduit Entrance Kits

CP4C Discount

Schedule

Prices subject to change without notice.

06/2009

Pricing Guide Renewal Parts List

Altistart® 48

Description For Soft Start: Catalog Number $ Price

Control Board All ATS48 soft starts VX4G481 2530.00

Power Board

ATS48D17Y VX5G48D17Y 625.00

ATS48D22Y VX5G48D22Y 635.00

ATS48D32Y VX5G48D32Y 650.00

ATS48D38Y VX5G48D38Y 675.00

ATS48D47Y VX5G48D47Y 715.00

ATS48D62Y VX5G48D62Y 840.00

ATS48D75Y VX5G48D75Y 900.00

ATS48D88Y VX5G48D88Y 1050.00

ATS48C11Y VX5G48C11Y 1110.00

ATS48C14Y VX5G48C14Y 1260.00

ATS48C17Y VX5G48C17Y 1315.00

ATS48C21Y VX5G48C21Y 1425.00

ATS48C25Y VX5G48C25Y 1515.00

ATS48C32Y VX5G48C32Y 1650.00

ATS48C41Y VX5G48C41Y 1795.00

ATS48C48Y VX5G48C48Y 1880.00

ATS48C59Y VX5G48C59Y 1975.00

ATS48C66Y VX5G48C66Y 2070.00

ATS48C79Y VX5G48C79Y 2180.00

ATS48M10Y VX5G48M10Y 2330.00

ATS48M12Y VX5G48M12Y 2650.00

Filter Board

ATS48D17, D22, D32, D38, D47Y VX4G48161Y 175.00

ATS48D62, D75, D88, C11Y VX4G48162Y 215.00

ATS48C14, C17Y VX4G48163Y 330.00

ATS48C21, C25, C32Y VX4G48164Y 435.00

Firing Board ATS48C41-C79, M10-M12Y VX4G48165Y 340.00

SCR Power Module

ATS48D17, D22, D32Y VZ3TM2056M18 243.00

ATS48D38, D47Y VZ3TM2091M18 277.00

ATS48D62, D75Y VZ3TM2132M18 372.00

ATS48D88, C11Y VZ3TM2162M18 478.00

ATS48C14, C17Y VZ3TM2250M18 658.00

ATS48C21, C25, C32Y VZ3TM2500M18 872.00

ATS48C41, C79Y VZ3TP2600M18 1125.00

ATSC48-C66Y, M10-M12Y VZ3TP2M12M18 1495.00

Temperature Sensor ATS48D17-D88Y, C11-C32Y VZ3G001 25.00

ATS48C41-C79Y, M10-M12Y VZ3G002 19.00

Fan

ATS48D32, D38Y VZ3V481 65.00

ATS48D47Y VZ3V4811 71.00

ATS48D62-D88, C11Y VZ3V482 105.00

ATS48C14, C17Y VZ3V483 165.00

ATS48C21, C25, C32Y VZ3V484 218.00

ATS48C41-C79Y, M10-M12Y VZ3V485 293.00

CP4C Discount

Schedule

www.schneider-electric.us

Replaces 8800PL9701R01/09

06/2009

Schneider Electric USA

3700 Sixth St. SW

Cedar Rapids, IA 52404

1-888-Square D

1-888-778-2733

www.schneider-electric.us

Pricing Guide Auxiliary Services

Drive Product Support Group

For support and assistance, contact the Drive Product Support Group.

The Drive Product Support Group is staffed from 8:00 am until 6:00 pm

Eastern time to assist with product selection, start-up, and diagnosis of

product or application problems.

EMERGENCY Technical phone support is available 24 hours a day,

365 days a year.

Toll Free 1-888-Square D (1-888-778-2733)

E-mail drive.products.support@us.schneider-electric.com

Fax 919-217-6508

Square D Service (On-Site)

The Square D Services division is committed to providing quality on-

site service that consistently meets customer expectations. Services

responds to your requests, seven days a week, 24 hours a day.

Phone: 888-778-2733 (Square D)

Square D Customer Training

Square D offers a variety of instructor-led skill enhancing and technical

product training programs for customers. For a complete list of

drives/soft start training with dates, locations and pricing please call:

Phone: 978-975-9306

Fax: 978-975-2821

Customer Information Center

(Assist with stock checks, assist with claims, and assist with order

management issues)

To provide additional support, Square D has rolled out new Technical

Service Representatives in local offices which have the strongest

needs.

Due to time zone changes and different time operation requirements,

business operation times vary.

Phone: 888-778-2733 (Square D)

Fax: 888-329-9773 (FAXXSQD)

Web Address: http://www.SquareD.com

Literature Fulfillment Center

To obtain support literature for your product or application needs,

contact the Square D Literature Fulfillment Center.

Phone: 800-888-2448

Fax: 920-766-6675

E-mail: SquareD@banta.com

Documentation, Start-up and Training

Standard Documentation

Each AC Drive or Soft Start shipped includes one set of instruction

bulletins. Additional instruction bulletins are available for $30.00 net

each. Each set of instruction bulletins includes installation, start-up,

trouble shooting and wiring diagram information. Separate Approval

and/or Record Drawings are not included.

Approval Drawings

Standard approval drawings are available for the enclosed drives and

soft starts. The price adder for custom approval drawings are listed in

the table below.

NOTE: Before manufacturing of the enclosed drive/soft start can

begin, the approving parties must stamp and sign the

transmittal forms that accompany the drawings. In the unlikely

event that approval drawings are not approved and must be

resubmitted, the approving parties must mark up, stamp and

sign the drawings before a second set of approval drawings

can be submitted.

Record Drawings

Record dr awings a re availabl e for the enclosed drives an d soft st arts.

The price adders for record drawings are listed in the table below.

aEnter drawing requirement as a separate line item on purchase order.

bPricing for Approval Drawings include pricing for Record Drawings

cOne set equals a maximum of 8 copies. Additional copies are available at $75.00 net

each.

dFloppy Disks are available in both double and high density formats for both 3.5" and

5.25" diskettes. The drawings are available in several formats. They are.DWG; .DXF;

.IGS; and Microcad.

Notes:

•Maximum of six drives or soft starts can be tested per day.

•When less than three days (72 hours) notice of start-up date is provided, the

premium rate will be charged.

Travel Time and Expenses

Travel time and expenses will be calculated based on actual “round

trip” mileage traveling from the Square D Sales Office to the job site

and return.

Travel and living expenses will be billed at cost plus an administrative

charge.

Travel and expense pricing will be based on actual number of trips with

travel charges applied to each separate trip Square D Service makes

to the job site.

Table 42: Pricing a

Drawing Size

Approval Drawings bRecord Drawings

One set per drive

$ Price

Floppy disks

$ Price

One set per drive

$ Price

Floppy disks

$ Price

A 8.5 x 11 250.00 net 350.00 net 175.00 net 270.00 net

B11 x 17 250.00 net 350.00 net 175.00 net 270.00 net

C 17 x 22 250.00 net 350.00 net 175.00 net 270.00 net

Table 43: Square D Services Drives Start-up Pricing

Square D Service offers standard pricing for start-up under conditions

as described below. The pricing is for Drives and Soft Starts located

within the U.S., excluding Alaska and Hawaii.

Call 1-888-Square D for scheduling.

Service

Standard Price

(Work Performed on weekdays

during normal business hours)

$ Price

Premium Price

(Work performed outside of

normal business hours, Saturday,

Sunday or Holidays)

$ Price

On Site Labor $165.00/Drive $300.00/Drive

Travel and Expense See Below See Below

8800PL9701R0609 Brochure

96448-Catalog 96448-Catalog 96448-Catalog B5 unilog cesco-content

Navigation menu

Versions of this User Manual:

Views

Navigation
