Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.1
Test Equipment
Cable Certification
Test Equipment
./-
Index1.Support and Supplies//Test Equipment//Hand-held Category 6A Testers
FLUKE NETWORKS PR10710V2-10857.tif
Fluke Networks' DTX CableAnalyzer Series combines powerful speed and
unprecedented accuracy that no other certification tester can match. Certify a
Cat 6 link faster with a 9-second Cat 6 Autotest and Level III accuracy. This
revolutionary platform combines unmatched copper certification with onboard fiber
OLTS and OTDR modules, easy-to-understand diagnostics, 12-hour battery life, a
bright color display and nearly instant setup and reporting. It reduces total time to
certify, savings you can see on your bottom line - as much as 33 percent of
certification costs per year. DTX - It's all about time!
FEATURES
•Exceeds standard requirements for Cat 5e/6/6A/Class E/EA/F/FA
certification testing
•Advanced time-saving diagnostics pinpoints faults invisible to other testers
•Third-party verified to meet ANSI/TIA-1152 and IEC 61935-1 for Level IIe, III, IIIe,
IV accuracy
•Onboard OTDR or OLTS modules for fiber certification to ANSI/TIA and
ISO standards
•Fast, reliable and rugged with extended 12-hour battery life and color display
enhance user productivity
•The choice of network owners, cabling manufacturers and contractors for
performance audits
DIGITAL CABLE ANALYZERS
GOLD SUPPORT
DTX and Gold bundles include a comprehensive maintenance and support program
for those that cannot afford downtime and are most committed to maintaining their
equipment to the highest standards Gold members are entitled to:
- a free annual calibration and factory refresh with paid shipping and loaner
- priority first-in-queue 24/7 technical assistance via members-only hotline
- free firmware/software upgrades with priority notification
- free accessory replacement
- first-on-bench priority repair with paid next-day shipping and loaner
- member-only training, promotions and resources
- Gold Support pays for itself and you get an even better deal when you purchase the
DTX and Gold together
DTX CableAnalyzer Series
Anixter No. Vendor No. Description
280602 DTX-1800 120 900 MHz with 9-second Cat 6 Autotest;
includes smart remote, permanent link
and channel adapters, MMC card, USB port
479732 DTX-1800120/GLD DTX-1800 CableAnalyzer with one year of
Gold Support
280630 DTX-1800-M 120 DTX-1800 CableAnalyzer with multimode
DTX fiber modules
280631 DTX-1800-MS 120 DTX-1800 CableAnalyzer with multimode
and single-mode DTX fiber modules
479733 DTX-1800-M120/GLD DTX-1800 with multimode fiber modules
and one year of Gold Support
348996 DTX-1800-MSO 120 Complete DTX-1800 copper/fiber/OTDR
certification kit
479734 DTX-1800-MS120/GLD DTX-1800 with multimode and
single-mode fiber modules and one year of
Gold Support
376839 DTX-1800-MO 120 Complete DTX-1800 copper/fiber
certification kit
485557 DTX-1800MSO120/GLD Complete DTX-1800 copper/fiber/OTDR
certification kit, plus one year of
Gold Support
280613 DTX-1800/SR DTX-1800 Smart Remote add-on
280615 DTX-LT/SR DTX-LT Smart Remote add-on
326847 DTX-MFM2 DTX multimode fiber modules - set of two
326853 DTX-GFM2 DTX gigabit multimode fiber modules - set
of two
326854 DTX-SFM2 DTX single-mode fiber modules - set of two
441698 DTX-PC5ES DTX patch cord test adapter set for Cat 5e
patch cord testing
441699 DTX-PC6S DTX patch cord test adapter set for
Cat 6 patch cord testing
441700 DTX-PC6AS DTX patch cord test adapter set for Cat 6A
patch cord testing
Anixter No. Vendor No. Description
280632 GLD-DTX DTX CableAnalyzer one year Gold Support
374470 GLD-DTX-3YEAR DTX CableAnalyzer and three years of
Gold Support
485586 GLD-DTX-M DTX-1800-M or DTX-1200-M with one year
of Gold Support
433239 GLD-DTX-MS-3YR DTX-1800-MS or DTX-1200-MS with three
years of Gold Support
280633 GLD-DTX-FIBERMOD One-year Gold Support for DTX fiber
module set
374473 GLD-DTXFMOD-3YEAR DTX fiber module with three years of
Gold Support
374475 GLD-DTX-MSO DTX-1800 MSO with one year of
Gold Support
490632 GLD-DTX-MSO-3YR DTX-1800 MSO three year of Gold Support
398917 GLD-DTX-MO DTX-1800 MO with one year of
Gold Support
433238 GLD-DTX-MO-3YR DTX-1800 MO with three years of
Gold Support
433237 GLD-DTX-KIT DTX-10GKIT or DTX-AXKIT with one year of
Gold Support
Anixter No. Vendor No. Description
14.2
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Cable Certification
Test Equipment
D
-
Index1.Support and Supplies//Test Equipment//Hand-held Category 6A Testers
FLUKE NETWORKS PR20666V2-82244.tif
Fluke Networks' compact OTDR module is the latest enhancement to the DTX
CableAnalyzer - a revolutionary test platform. In addition to performing copper
certification and diagnostics, your team can become fiber-test experts when you
decide to grow your business and turn your cable tester into an OTDR. This
full-featured, compact OTDR module snaps onto a DTX CableAnalyzer and provides
unmatched ease of use for premises fiber testing. Choose a kit that includes a DTX
mainframe and Smart Remote, options for copper certification, optical loss/length
capability, or order a module and software that can be installed on your own
DTX CableAnalyzer.
FEATURES
•Test and troubleshoot fiber like an expert with the easy-to-use DTX
compact OTDR
•Shoot OTDR traces on single-mode and multimode links at 850 nm, 1300 nm,
1310 nm and 1550 nm
•Perform basic loss/length certification and extended (OTDR trace) certification
with one powerful cable tester
•Diagnose hard-to-find fiber failures with DTX compact OTDR and resolve simple
cable faults and polarity problems with built-in VFL
•Produce professional certification test reports with LinkWare
results-management software
GOLD SUPPORT
-
Index1.Support and Supplies//Test Equipment//Hand-held Category 6A Testers
JDSU PR32267V2-237781.tif
JDSU Test and Measurement's NGC Cable Certifier has the highest-frequency sweep
on the market, sweeping up to 1,600 MHz to protect your investment. The
revolutionary Touch2 design, with intuitive touch screen at both ends, makes using
the Certifier40G the easiest ANSI/TIA cable certifier. Minimize time spent transferring
results off the tester with the capacity to store more than 2,000 full Cat 6A graph
results as well as transfer data via the USB flash drive. The full screen at both ends
allows users in the field to minimize their walking time by initiating, configuring and
storing tests from either side of a link or channel. The platform combines the ability
to certify copper as well as perform optical loss test with fiber modules.
FEATURES
•Surpasses ANSI/TIA-568 requirements for Cat 5/5e/6/6A and Class E/EA/FA/F
certification testing
•Exceeds ANSI/TIA-1152 Level IV accuracy over the full Class FAspectrum
•Revolutionary large touch screen with Touch2 two-ended control
•Fastest Cat 6A/Class FA test with 9-second Cat 6A test time and 15-second Class
FAtest
•Easy-to-use integrated planning software
•Tier 1 fiber-testing modules available for multimode or single-mode fiber testing
CERTIFIER40G
DTX CableAnalyzer OTDR Module
Anixter No. Vendor No. Description
348997 DTX-QUAD-OTDR DTX compact OTDR kit with mainframe
348998 DTX-OTDR-KIT DTX compact OTDR kit
348999 DTX-OTDR/LL-KIT Complete DTX fiber certification add-on kit
349000 DTX-OTDR-QMOD DTX compact OTDR
Anixter No. Vendor No. Description
395550 GLD-DTX-OTDR DTX-OTDR and DTX-OTDR-KIT with one year
of Gold Support
485594 GLD-DTX-OTDR-3YR DTX-OTDR-QMOD and DTX-OTDR-KIT with
three years of Gold Support
Next-generation Certifier
Anixter No. Vendor No. Description
434525 NGC-4500-FA-NA 1,600 MHz with 9-second Cat 6A and
15-second Class FA certification with more
than 500 MB flash memory and 1 GB USB
flash drive included for flexible test
record storage
441500 NGC-4500-MM-NA Certifier40G Class FA and MM kit: includes
all items in NGC-4500-FA-NA with
additional multimode fiber modules
441502 NGC-4500-MMSM-NA Certifier40G Class FA, MM and SM kit:
includes all items in NGC-4500-FA-NA with
additional multimode and single-mode
fiber modules
441709 NGC-4500-MM2 Certifier40G multimode adapter pair
441710 NGC-4500-SM2 Certifier40G single-mode adapter pair
434526 NGC-4500-6ACH2 Certifier40G Cat 6A channel adapter pair
441711 NGC-4500-6ALINT1 Cat 6A permanent link interface adapter.
When mated to Cat 6A permanent link test
cord, supports Cat 6A (and below)
permanent link certification testing
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.3
Test Equipment
Cable Certification
Test Equipment
MAXCARE
-
Index1.Support and Supplies//Test Equipment//Hand-held Category 6A Testers
IDEAL INDUSTRIES PR23118V2-160108.tif
The IDEAL LanTEK II series cable certifiers offer speed, performance and accuracy at a
great price. Eleven-second Cat 5e and 14 second Cat 6 tests with full performance
data, plus 10 gigabit alien crosstalk testing that's more than four times faster, make
LanTEK II the ultimate copper certification platform. The patented universal adapter
system lets you certify most cabling with off-the-shelf patch cords saving time and
money by eliminating the need for proprietary permanent link adapters.
The new optional FiberTEK FDX modules give extraordinary, fast fiber testing with the
first dual wavelength, bi-directional fiber certification capability. The new IDEAL
DataCENTER (IDC) software puts the power in the fingertips of the user. The main test
grid display can be customized and sorted by virtually any test parameter. IDC offers
many reporting options such as detailed, brief and single line report, plus export data
in XML, CSV or PDF format making it the most user-friendly and powerful cable
reporting software on the market today.
All testers include LanTEK II display and remote handset, two smart lithium-ion
batteries, two 110-240 V power adapters with U.S./EU/UK plugs, lockable semi-rigid
carrying case, Cat 6A/FTP patch cords, USB cable, DataCENTER data management and
reporting software, two headsets, hanging straps and ETL accuracy certificate.
FEATURES
•Three models are available at 350 MHz, 500 MHz and 1,000 MHz for the best
performance and price options, all with accuracy independently verified by ETL
•High-speed testing saves time and money
•The most internal memory available - store more than 1,700 Category 6/ISO E
tests with graphics
•Patented testing method which eliminates expensive permanent link adapters
and tests with patch cords for most installations
•Large, ultra-bright display - a 4.3 in. wide-screen display with white LED
backlighting provides easy viewing of high-frequency data plots
•350 MHz and 500 MHz models are fully upgradable to 1,000 MHz
•Smart lithium-ion battery technology - 18-hour battery life with self-calibrating
"fuel gauge" for accurate capacity readings
441712 NGC-4500-6ALCORD1 Cat 6A permanent link test cord. When
mated to Cat 6A permanent link interface
adapter NGC-4500-6ALINT1, supports
Cat 6A (and below) permanent link
certification testing
441713 NGC-4500-BAT1 Battery pack for Certifier40G
Anixter No. Vendor No. Description
441714 NGC-4500-FA-EW Extension of standard warranty for
one year
441715 NGC-4500-FA-MC1Y MaxCare first year: service package
includes annual calibration, accessory
replacement and loaner units during
first year
441716 NGC-4500-FA-MC MaxCare: service package includes
extended warranty, tech support, annual
calibration, accessory replacement and
loaner units
441717 NGC-4500-FA-MC3 MaxCare first three years: service package
includes extended warranty, tech support,
annual calibration, accessory replacement
and loaner units for first three years
LanTEK II Series Cable Certifiers
Anixter No. Vendor No. Description
Anixter No. Vendor No. Description
386921 33-991 LanTEK II-350, ANSI/TIA/ISO/IEC Cat 6,
Class E certifier with Cat 6 adapters
386923 33-992 LanTEK II-500, ANSI/TIA/ISO/IEC Cat 6A,
Class EA certifier with Cat 6A adapters
386924 33-993 LanTEK II-1000, ANSI/TIA/ISO/IEC Cat 7A,
Class F/FA certifier with Cat 6A adapters
442368 33-993-FA01 LanTEK II-1000 with MM LED FiberTEK
FDX kit
442369 33-993-FA02 LanTEK II-1000 with MM VSCEL/laser
FiberTEK FDX kit
442370 33-993-FA03 LanTEK II-1000 with SM laser FiberTEK
FDX kit
442371 33-993-FA04 LanTEK II-1000 with MM LED and SM laser
FiberTEK FDX kit
442372 33-993-FA05 LanTEK II-1000 with MM VSCEL and SM
laser FiberTEK FDX kit
442373 LT2-CP-3 Three-year care plan for LanTEK II.
Three-year warranty, annual calibration
and accessory replacement
14.4
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Cable Certification
Test Equipment
D
-
Index1.Support and Supplies//Test Equipment//Hand-held Category 6A Testers
IDEAL INDUSTRIES PR23117V2-160114.tif
Perform a standard 6-around-1 cable test with PS ANEXT and PS AACR-F results for
both ends of the cable in as little as 5 1/2 minutes compared to more than
20 minutes for some competitive units.
FEATURES
•Add alien-crosstalk testing capability to any LanTEK 6A, LanTEK 7G,
LanTEK II-500 or LanTEK II-1000 tester
•Perform PS alien NEXT and attenuation to alien-crosstalk ratio measurements
•Unique dual-port AXT adapter allows PS ANEXT testing with just one handset for
quick initial site testing
•Dual-handset mode allows complete AXT certification four times faster than
other AXT test systems
•No PC required in the field - all test results calculated on-the-fly for instant
pass/fail indication
•Kit includes two dual-port AXT adapters, 12 AXT terminators, shielded patch
cords, manual, firmware update and PC reporting software
-
Index1.Support and Supplies//Test Equipment//Hand-held Category 6A Testers
IDEAL INDUSTRIES PR28552V2-208955.tif
The FiberTEK FDX option allows users to add full Tier 1, standards-compliant
certification capability to IDEAL LanTEK II certifiers. Tier 1 certification utilizes a light
source and power meter to measure the power loss of optical cabling. The only
solution that completely eliminates the need to swap fiber or modules, allowing
complete one-step certification of horizontal and backbone cabling, twice as fast as
any other fiber certification testers.
Contents include two FiberTEK FDX modules, lockable semirigid carrying case, SC, FC
and ST adapters for modules (two each), SC-SC patch cords (multimode kits: 3 x
62.5 m, 3 x 50 m; single-mode kits: 3 x 9 m SMF)-compliant to the ISO/IEC
14763-3 standard, quick reference guide and electronic operation manual.
FEATURES
•Complies with ANSI/TIA/ISO/IEC certification standards
•Four attenuation measurements plus length in one press of the Autotest button
•Available with both LED and VCSEL/laser multimode sources for 10/100 Mbps or
1/10G certification
•Real-time power meter to aid in troubleshooting active equipment
•Field-changeable adapters (SC, ST and FC) eliminate the need to carry multiple
hybrid launch cords
PLANS
Three-year care plan for FiberTEK FDX. Three-year warranty, annual calibration
10 Gigabit Alien-crosstalk Testing Kit
Anixter No. Vendor No. Description
383357 LANTEK10GBKIT Alien-crosstalk testing kit
FiberTEK FDX Testing Kits
Anixter No. Vendor No. Description
386941 33-990-FA01 Multimode (850/1300 nm) kit with LED
light sources for standard multimode fiber,
850 nm LED and 1300 nm LED
386942 33-990-FA02 Multimode (850/1300 nm) kit with VCSEL/
laser light sources for laser-optimized
fiber, 850 nm VCSEL, 1300 nm FP laser
386943 33-990-FA03 Single-mode (1310/1550 nm) kit with
laser light sources for single-mode fiber,
1310 nm FP laser and 1550 FP laser
386944 33-990-FA04 Combination multimode/single-mode with
LED multimode sources and laser
single-mode sources (part numbers
386941 and 386943)
386946 33-990-FA05 Combination multimode/single-mode kit
with VCSEL/laser multimode sources and
laser single-mode sources (part numbers
386942 and 386943)
Anixter No. Vendor No. Description
442375 FDX-CP-3 For FA01, FA02 and FA03 kits
442376 FDX2-CP-3 For FA04 and FA05 kits
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.5
Test Equipment
SAN Testing
Test Equipment
./
Index1.Support and Supplies//Test Equipment//Data Applications
JDSU PR33636V2-248003.tif
The JDSU storage network test solutions are the premier tools available for supporting
deployment and diagnostic/troubleshooting requirements of storage area networks
within the data center. Solutions exist for support of native Fibre Channel SANs as
well as converged Ethernet environments that are using Fibre Channel over Ethernet
(FCoE). Solutions also exist for stand-alone storage analysis requirements for
everything from SD/SDIO/MMC to CompactFlash to USB technologies.
FEATURES
•Detailed protocol analysis and decode of all storage technologies
•Fibre Channel support for 1, 2, 4, 8 and 10G speeds
•Ethernet support for 1 and 10G speeds
•SAS/SATA support for 1.5, 3.0 and 6.0G speeds
•Analyzer, data generation and SAN fabric load testing up to
100 percent bandwidth
X-GIG SAS/SAN/SATA Tester
For more information, part-number configurations and adapters,
contact your local sales office.
14.6
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Network Analysis/Testing
Test Equipment
D
./-
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR33627V2-247674.tif
Network engineer's tablet with dedicated custom hardware for automated network
and application analysis in the deployment and troubleshooting of new technologies.
Unique features including proactive analysis, path analysis and application-centric
analysis get to root cause faster than ever before.
FEATURES
•Tablet form factor with powerful consolidated functionalities providing
automated analysis for 10/100 Mbps, 1/10 Gbps and 802.11a/b/g/n
wireless LANs
•Intuitive user interface with smart navigation and built-in intelligent guided
problem solving plus user customizable dashboards providing the flexibility to
view data as needed
•Application-centric analysis providing a high-level view of the health of the
applications on the network with the capability to analyze the performance of
the network infrastructure's underlying business-critical applications (path
analysis) to ensure a consistent end-user experience
•Guided troubleshooting with automated diagnostics and granular data to solve
problems before they escalate
•Detailed, fast network discovery for instant visibility of what's out there and
where it's connected in minutes
OPTIVIEW XG
GOLD SUPPORT
-
Index1.Support and Supplies//Test Equipment//Data Applications
JDSU PR33640V2-248027.tif
The Enterprise Services Application Module (ESAM) from JDSU addresses the
challenge of maintaining network availability. The ESAM is designed for JDSU's T-BERD
4000 platform, which recently won the "Best in Test" award from Test and
Measurement World in the Communications Network Test category.
The ESAM provides the industry's broadest range of enterprise-testing capabilities for
IT organizations that require a tool to quickly isolate and resolve network issues, which
reduces network downtime, lost productivity and associated costs.
FEATURES
•Verify that copper cables support Gigabit Ethernet
•Test network connectivity
•Discover network devices
•Analyze network utilization and traffic patterns
•Use Wireshark to analyze captured PCAP files at wirespeed
•Provides Layer 1-7 protocol capture and expert analysis
•Offers wirespeed deep packet statistics and analysis
OptiView XG Network Analysis Tablet
Anixter No. Vendor No. Description
441260 OPVXG OptiView XG - network analysis tablet (GIG)
444703 OPVXG/GLD OptiView XG - network analysis tablet (GIG)
with one year of Gold Support (also
available in three-year coverage: OPVXG/
GLD3)
441261 OPVXG-10G OptiView XG - network analysis tablet
(10 GIG)
444710 OPVXG-10G/GLD OptiView XG - network analysis tablet
(10 GIG) with one year of Gold Support
(also available in three-year
coverage: OPVXG-10G/GLD3)
441262 OPVXG-PRO OptiView XG - network analysis tablet (GIG)
with Wi-Fi analyzer and Spectrum XT
444724 OPVXG-PRO/GLD OptiView XG - network analysis tablet (GIG)
with Wi-Fi analyzer and Spectrum XT with
one year of Gold Support (also available in
three-year coverage: OPVXG-PRO/GLD3)
441263 OPVXG-EXPT OptiView XG - network analysis tablet
(10 GIG) with Wi-Fi analyzer and
Spectrum XT
444722 OPVXG-EXPT/GLD OptiView XG - network analysis tablet
(10 GIG) with Wi-Fi analyzer and Spectrum
XT with one year of Gold Support (also
available in three-year
coverage: OPVXG-EXPT/GLD3)
Anixter No. Vendor No. Description
443522 GLD-OPVXG OPVXG: One year of Gold Support
443529 GLD3-OPVXG OPVXG: Three years of Gold Support
443523 GLD-OPVXG-10G OPVXG-10G: One year of Gold Support
443530 GLD3-OPVXG-10G OPVXG-10G: Three years of Gold Support
443524 GLD-OPVXG-PRO OPVXG -PRO: One year of Gold Support
443531 GLD3-OPVXG-PRO OPVXG -PRO: Three years of Gold Support
443525 GLD-OPVXG-EXPT OPVXG- EXPT: One year of Gold Support
443532 GLD3-OPVXG-EXPT OPVXG- EXPT: Three years of Gold Support
Please contact your local sales representative for more information on the
OptiView XG Network Analysis Tablet. Your sales representative can help you
choose models, options, accessories and Gold Supervision support
programs to suit your needs.
Enterprise Services Application Module (ESAM) for the
T-BERD/MTS-4000 Platform
Anixter No. Vendor No. Description
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.7
Test Equipment
Network Analysis/Testing
Test Equipment
•A modular platform with many options:
- VoIP phone emulation
- Optical power meter/visual fault locator/OTDR module
- Fiber inspection probe with automated pass/fail
- Wi-Fi testing
ESAM WITH T-BERD 4000 BASE
ACCESSORIES
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR33718V2-248853.tif
A handheld Gigabit LAN and 802.11 wireless LAN analyzer that assists network
professionals with installation, validation and troubleshooting. Install and integrate
infrastructure easily by testing, verifying and fixing configuration issues during
deployment. Validate network performance and service delivery by measuring key
performance attributes and the availability and responsiveness of essential
resources. Diagnose LAN health with one click. Close trouble tickets fast with guided
drill-downs to the root cause. Audit the performance of the network on a regular,
periodic basis to identify and correct emerging issues. The EtherScope Network
Assistant makes testing so simple practically anyone can troubleshoot
problems instantly.
FEATURES
•Analyze Gigabit twisted-pair and fiber optic LANs, and 802.11 wireless LANs
•Troubleshoot problems fast with guided analysis and intelligent drill-downs
•Measure and assess Ethernet LAN/WAN link performance and SLA compliance
•Validate the availability and responsiveness of LAN services
Anixter No. Vendor No. Description
441728 TB4-DIS-LAN ESAM with T-BERD 4000 base
441730 TB4-DIS-LANVOIPWLAN With VoIP and Wi-Fi
441731 TB4000-GOVT-LAN With VoIP CISCO and UNISTIM call
manager software
441732 TB4-DIS-LANOPMVFL With OPM, VFL and scope
441733 TB4-DIS-LANPKG With VoIP, Wi-Fi, OPM, VFL and scope
Anixter No. Vendor No. Description
441738 FBP-SD01 Digital fiber inspection probe microscope
(USB 2.0), FiberChek2 software,
interchangeable FBPT inspection tips (4) in
hard case, SC and LC bulkhead tips,
1.25 mm patch cord tips and hard-sided
carrying case
For more information and part-number configurations,
contact your local sales office.
EtherScope Series II Network Assistant
Anixter No. Vendor No. Description
328391 ES2-LAN-SX LAN analyzer with fiber option: Series II
mainframe, 1000BASE-SX transceiver,
protective boot, carrying strap,
rechargeable Li-Ion battery pack, AC
adapter/battery charger, CompactFlash
card, remote wiremap adapter (ID #1),
patch cable, RJ45 adapter, Getting Started
Guide, resource CD and carrying case
415189 ES2-PRO-SX/I-ACK LAN and WLAN analyzer with fiber and
ProVision/RFC2544 options, plus an
AirCheck Wi-Fi tester: Series II mainframe,
1000BASE-SX transceiver, 802.11a/b/g
CardBus adapter, directional antenna,
protective boot, carrying strap,
rechargeable Li-Ion battery pack, AC
adapter/battery charger, CompactFlash
card, remote wiremap adapter (ID #1),
patch cable, RJ45 adapter, Getting Started
Guide, resource CD, carrying case,
additional ProVision/RFC2544-related
features, plus an AirCheck Wi-Fi tester
288287 GLD-ES One year of Gold Support; covers any
EtherScope mainframe
395549 GLD-ES-3YR Three years of Gold Support; covers any
EtherScope mainframe
427497 ES-SWUGD-V5 Version 5 software upgrade for all
EtherScope models
14.8
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Network Analysis/Testing
Test Equipment
D
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR67026V2-528622.tif
The OneTouch AT Network Assistant is an all-in-one field-ready Gigabit, fiber optic
and Wi-Fi network troubleshooter. Get a client view of network performance - from the
cable, through the wired and wireless infrastructure, to local and cloud-hosted
network services and applications - all in a single automated test. Create test scripts
tailored to your network, your services and your applications. Prove that your Wi-Fi
network is operating at peak performance with the exclusive Veri-Fi test. Identify and
resolve problems quickly with clear pass/fail indicators and dynamic Wi-Fi analysis.
Capture packets via the built-in copper/fiber inline filtering TAP. Control remotely via
Web-enabled devices.
FEATURES
•All-in-one, field-ready, handheld troubleshooter for Gigabit copper, fiber optic
and a/b/g/n Wi-Fi networks
•Troubleshoot network performance from the client connection through the cable,
the wired and Wi-Fi infrastructure, and to key network services hosted locally
and within private and public clouds
•Turn anyone into a troubleshooting expert with customized test scripts for your
network, your services and your applications
•Get answers in seconds with the one-touch AutoTest and intuitive user interface
•Prove that your Wi-Fi network is operating at peak performance with the
exclusive Veri-Fi test
•Solve complex network and application issues by capturing packets between the
client and network with the built-in copper/fiber filtering TAP
•Collaborate with colleagues and extend your troubleshooting reach by
controlling the OneTouch AT remotely via any Web-enabled device
ONETOUCH AT
ACCESSORIES
Index1.Support and Supplies//Test Equipment//Data Applications
IDEAL INDUSTRIES PR33679V2-248533.tif
The LanXPLORER PRO is an inline tester with active and passive troubleshooting
capabilities for Ethernet connectivity and cabling issues in multimedia environments,
including copper, fiber and Wi-Fi. It has a state-of-the-art touch screen and large,
clear color display. With full inline and endpoint test capabilities, the LanXPLORER
PRO tests not only copper cables but also active LAN connections over copper and
fiber links. In addition, it liberates the user from cables by allowing most tests to be
conducted through a wireless connection offering unparalleled flexibility. It is a
perfect tool to meet the needs of professional IT and network installers, facilities
maintenance, network cabling companies, IT consultants and systems administrators
in any enterprise, campus or industrial Ethernet environment.
FEATURES
•Troubleshoot passive cabling and active networks
•Touch-and-test user interface
•3 1/2 in. QVGA color display for crystal-clear graphical interpretation of results
like wiremap
•Copper, fiber and Wi-Fi testing
•Peak, instant, 30-second and continuous bandwidth monitoring
•PoE and PoE+ endpoint and inline testing with load simulation
•Device discovery and top-talker identification
•Advanced wiremapping capabilities - tests cables by pin and pair
•Does split-pair detection and length measurements
•Virtual keyboard allows easier and much faster data input
•Touch screen navigation allows tests to be completed within three steps
OneTouch AT Network Assistant
Anixter No. Vendor No. Description
479743 1T-1000 OneTouch AT LAN fiber
479744 1T-2000 OneTouch AT LAN fiber WLAN
479747 1T-3000 OneTouch AT LAN fiber WLAN inline capture
479755 1T-3000-FI OneTouch AT 3000 + fiber inspection kit
479758 1T-3000-CSA OneTouch AT 3000 + ClearSight analyzer
software on CD
479759 1T-3000-LRAT2KIT OneTouch AT 3000 + LinkRunner AT
2000 kit
479760 1T-3000-ACK-LRAT2 OneTouch AT 3000 +
AirCheck-LinkRunner AT 2000 kit
479761 1T-3000-ESLSI-LRAT OneTouch AT 3000 + EtherScope LAN SX I
+ LinkRunner AT 2000
Anixter No. Vendor No. Description
215827 1TS2-RPT OneTouch software to create network
inventory and monitor collisions
and errors
479762 1T-WLAN-OPT OneTouch AT WLAN option
479763 1T-IN-CAP-OPT OneTouch AT inline and capture
479764 1T-WLAN-IN-CAP-OPT OneTouch AT WLAN, inline and
capture option
479765 1T-2000-MOD OneTouch AT module LAN fiber WLAN
479766 1T-3000-MOD OneTouch AT module LAN fiber WLAN inline
and capture
479767 1T-ANT OneTouch AT external directional antenna
479768 1T-1000/GLD OneTouch AT 1000 and Gold Support
479769 1T-2000/GLD OneTouch AT 2000 and Gold Support
479770 1T-3000/GLD OneTouch AT 3000 and Gold Support
479771 GLD-1T One-year Gold Support, OneTouch AT
479772 GLD3-1T Three-year Gold Support, OneTouch AT
LanXPLORER PRO Inline Gigabit Network Tester
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.9
Test Equipment
Network Analysis/Testing
Test Equipment
•SM and MM SFP options, 1000BASE-SX, LX and ZX support
•Link LED blink for visual fiber tracing
•DHCP client, ping and traceroute tests with VLAN support
•Full bandwidth Layer 1, 2 and 3 loopback device
•Diagnostic statistics including top-10 talkers, protocols, error generation and
packet-size distribution
•Hub blink test with color-switching on supported devices
•Wi-Fi features
•Identification of active network devices with network discovery function
•Comparison of active network devices against historical data with network
verify function
•DHCP client, ping and traceroute tests with VLAN support
•802.11 b, g and n support
•Identification of access points, Service Set Identifiers (SSID), channels in use,
signal strength and security settings
•Detection of channel conflicts
LANXPLORER
LanXPLORER PRO package includes: test unit, active wiremap remote ID #1, NiMH
battery pack, Cat 5e STP patch cables, power supply, amplifier probe, RJ45 insert
extraction tool, 10 x Lifejack RJ45 inserts, external USB high-sensitivity Wi-Fi
antenna, user CD manual, carrying case and quick reference guide
ACCESSORIES
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR19972V2-61711.tif
Isolate and document network device and application connectivity issues in seconds.
See connectivity to key network devices and services with NetProve diagnostics - the
fastest way to isolate the source of the problem - whether the cause is the LAN, WAN,
firewall, server or application. Create comprehensive reports of your network.
FEATURES
•NetProve diagnostics: Isolate device and application connectivity issues
in seconds
•Quickly resolve and document network problems with powerful inline visibility
into 10/100/gig links between switches, PCs, IP phones and other devices
•Connect inline for visibility into VoIP calls to quickly diagnose IP phone boot-up
and call-control problems and to measure key call-quality metrics
•Verify readiness of PoE systems and troubleshoot PoE device problems
•IntelliTone digital cable location and isolation technology speeds
cable troubleshooting
NETTOOL TESTERS
OPTIONS AND ACCESSORIES
GOLD EXCHANGE SUPPORT SERVICES
Anixter No. Vendor No. Description
435655 33-942P LanXPLORER PRO
437722 33-941P LanXPLORER plus
438135 33-940B LanXPLORER basic tester
Anixter No. Vendor No. Description
435658 150054 Active remote #1
435662 150050 Active remote set #2 - #12
435663 150053 NiMH battery pack
435664 150052 Power supply with U.S./EU/UK plugs
435665 150058 RJ45 insertion/extraction tool, 10 x
Lifejack RJ45 inserts
435666 SFP-850-1 1000BASE-SX fiber kit includes 850 nm
SFP (Small Form Factor pluggable) SX
transceiver and LC/SC duplex
multimode cable
435667 SFP-1310-1 1000BASE-LX fiber kit includes 1310 nm
SFP (Small Form Factor pluggable) LX
transceiver and LC/SC duplex
multimode cable
435669 SFP-1550-1 Pair of 1550 nm SFP modules,
1000BASE-ZX, jumpers not included
435671 62-164 IDEAL amplifier probe
NetTool Series II Inline Network Tester
Anixter No. Vendor No. Description
334970 NTS2-VOIP 10/100/1000 inline testing, VoIP
application, NetProve, PoE, IntelliTone
toning, reporter
334961 NTS2-PRO 10/100/1000 inline testing, NetProve,
PoE, IntelliTone toning, reporter
355006 NTS2-NSKIT 10/100/1000 Mbps inline, VoIP option,
NetSecure option, NetProve diagnostics,
IntelliTone toning, IntelliTone Pro
200 probe, NetTool connect PC software,
WireView Wiremappers #1-6, set of 4 AA
alkaline batteries, NiMH battery/charger
kit, USB to mini-USB cable, Ethernet cable,
Getting Started Guide, CD with
multilanguage user manuals, TPAK meter
hanging kit and deluxe carrying case
Anixter No. Vendor No. Description
334971 NTS2-VOIP-OPT VoIP option to upgrade an NTS2-PRO to
NTS2-VOIP. Upgradeable by the customer
via a key code and the NetTool
connect software
381990 NTS2-MONAUTH-OPT Monitoring and authentication option
Anixter No. Vendor No. Description
256104 GLD-NT Gold Exchange Support; one year of
NetTool standard
14.10
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Network Analysis/Testing
Test Equipment
D
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR67000V2-528611.tif
The LinkRunner AT Network AutoTester is the fastest way to solve network connectivity
problems. This rugged, handheld network tester takes the guesswork out of
troubleshooting with its complete one-button AutoTest. AutoTest performs your
required set of connectivity tests in seconds, enabling you to accurately and quickly
identify and solve network problems. Key features include verifying signal and link
integrity at 10/100/1G over copper or fiber, unmatched TruePower over Ethernet (PoE)
testing and loading, 802.1x authentication, cable wiremapping, IPv4/IPv6 readiness,
streamlined UI and color display, full documentation of test results with storage for
50 reports, location and identification of cabling runs, and nearest
switch information.
FEATURES
•Fast answers: AutoTest accurately identifies network problems in seconds
•Verify connections at 10M/100M/1G on copper and fiber: Instantly verify link
status, connection type, signal strength and traffic
•Nearest switch and VLAN information: Displays the VLAN and nearest switch
model, slot and port
•TruePower PoE testing: Quickly validate PoE performance by drawing actual
power up to the 802.3 at standard 25.5 W
•Document results: Store up to 50 test results and download to your PC
•Instant-on: Boots in less than three seconds
•IPv4/IPv6 ready
LINKRUNNER
ACCESSORIES
-
Index1.Support and Supplies//Test Equipment//Data Applications
JDSU PR21945V2-127230.tif
Perform network-testing functions including port discovery, PoE test, ping, hub flash,
CDP and high-end cable testing including length measurement. Monitor and correct
network problems associated with the physical layer and link conditions of the
network. Results are displayed in a wiremap format with a pair by pair
status message.
FEATURES
•Cable-testing capability includes: single-ended (no remote required) testing of
cables for shorts, opens and split pairs
•Full-cable test finds all wiring faults including split pairs with a
remote connected
•Displays PASS for T568A/B passing cables
•Remote mapping capability - supports sets of 20 ID-only remotes
•Measures length
•Generates selectable tones on selected pins for use with tone tracers
•Auto-MDI/MDI-X Ethernet connectivity protocol supports connection to hub,
switch or NIC with any patch cable
•Support for six languages; English, French, German, Italian, Portuguese
and Spanish
•Large backlit LCD allows for clear display of setup information and test results
•Auto-off in any mode and low power consumption for long battery life
LinkRunner AT Network AutoTester
Anixter No. Vendor No. Description
461203 LRAT-2000 Deluxe Network Tester with IPv6, TruePower
PoE, reflection and 50 reports, Wireview
cable ID, carry case
461202 LRAT-1000 LinkRunner AT Network AutoTester with
carry case
461197 ACK-LRAT2000 Kit with: AirCheck, LRAT-2000, external
directional antenna, spare Li-Ion battery
and deluxe carry case
461207 LRAT-2000-KIT Kit with: LRAT-2000, IntelliTone Pro 200,
WireView Cable IDs #1-6, deluxe
carry case
461205 LRAT-2000-5PK Five LRAT-2000s with five auto chargers
and five holsters
461204 LRAT-2000-10PK 11 LRAT-2000s and 11 LinkRunner AT
mobility kits. With 11 auto chargers and
11 holsters
Anixter No. Vendor No. Description
485746 GLD-LRAT One-year Gold Support for LinkRunner AT
485747 GLD3-LRAT Three-year Gold Support for LinkRunner AT
415193 WBP-LION LinkRunner AT Li-Ion replacement battery
461209 LRAT-HOLSTER LinkRunner AT holster
346691 WIREVIEW 1 WireView cable IDs #1
328751 WIREVIEW 2-6 WireView cable IDs set #2-6
303639 CIQ-RJA RJ45/11 modular adapter
357012 MS-AUTO-CHG Auto charger
280626 DTX-ACUN AC charger, universal
LanScaperPRO Network Tester
Anixter No. Vendor No. Description
362605 NT800 With remote
362606 NT850 With eight remotes and TT100 probe
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.11
Test Equipment
Wireless
Test Equipment
./-
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR67001V2-528612.tif
Fluke Networks' AirMagnet Spectrum XT is the first and only professional
spectrum-analyzer solution that combines in-depth RF analysis with real-time WLAN
information for quicker and more accurate troubleshooting of performance problems.
This combined view of "impact analysis of RF interference" on the network's overall
performance helps pinpoint the root cause of those problems.
FEATURES
•Automatic identification and location of interference sources
•Integrated reporting
•High-resolution RF spectrum diagnostic views
•Visualize impact of RF interference on WLAN performance
•Zero-day response to any RF interferer
•Integration with AirMagnet Wi-Fi Analyzer and AirMagnet Survey
•Record and playback
AIRMAGNET SPECTRUM XT
GOLD SUPPORT
-
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR67002V2-528613.tif
The AirMagnet Survey PRO is the industry's most accurate solution for planning and
designing 802.11 a/b/g/n wireless LANs for optimal performance, security and
compliance. It calculates the ideal quantity, placement and configuration of APs for a
successful WLAN deployment. The AirMagnet Survey PRO goes beyond just verifying RF
coverage by plotting actual end-user network performance in terms of connection
speed, throughput and packet statistics. The end result is a complete Wi-Fi weather
map of all critical RF and end-user performance metrics. Advanced features allow
users to integrate with professional spectrum analyzers, model predeployment
scenarios, generate customized survey reports, perform outdoor surveys, conduct
voice surveys, verify end-user network requirements and do detailed end-user
capacity planning.
The AirMagnet Survey PRO is available in Express and PRO versions. The AirMagnet
Survey Express offers a lighter version of the solution that allows users to perform the
basics of Wi-Fi site surveying with ability to map out signal, noise and even user
performance. The AirMagnet Survey PRO extends those capabilities found in the
Express version and adds powerful, industry-defining features including 802.11n
deployments, multifloor deployments, outdoor surveys, network design verification,
voice-readiness verification and surveys, RF spectrum analysis and many more.
FEATURES
•"Real-world" survey data collection
•Multifloor deployments
•802.11n site surveys
•Unique RF spectrum and Voice over WLAN surveys
•Professional custom reports
•Visualize coverage differences over time
•Integration with AirMagnet planner
AIRMAGNET SURVEY PRO AND EXPRESSS (INCLUDING PLANNER MODULE)
GOLD SUPPORT
AirMagnet Spectrum XT
Anixter No. Vendor No. Description
456433 AM/B4070 AirMagnet Spectrum XT (USB-based)
485686 AM/A4040 AirMagnet directional antenna
485688 AM/A5225 Sensor with internal antenna, 802.11n,
dedicated spectrum-analysis radio
485690 AM/A5220 Sensor with external antenna, 802.11n,
dedicated spectrum-analysis radio
485691 AM/A5200 Sensor with external antenna,
802.11 a/b/g/n
485693 AM/A5205 Sensor with internal antenna,
802.11 a/b/g/n
485694 AM/A5031 Metal sensor-mounting bracket with
security lock option
485695 AM/A5231 Plastic sensor-mounting bracket
Anixter No. Vendor No. Description
485697 GLD-S4070G AirMagnet Spectrum XT Gold Support
AirMagnet Survey PRO (Including Planner Module)
Anixter No. Vendor No. Description
449812 AM/A4018G AirMagnet Survey PRO (including
planner module)
485698 AM/B4010 AirMagnet Survey Express
485699 AM/A4016-UGD AirMagnet Survey Express to Survey PRO
(upgrade model)
485700 AM/A4013-UGD AirMagnet Planner Module for existing
A4015 customers
456433 AM/B4070 AirMagnet Spectrum XT (USB-based)
485702 AM/C1095 AirMagnet multiadapter kit for survey
(U.S., world-mode and Japan
versions available)
Anixter No. Vendor No. Description
449815 GLD-S4018G AirMagnet Survey PRO Gold Support
14.12
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Wireless
Test Equipment
D
-
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR67003V2-528614.tif
The AirMagnet WLAN Design and Analysis Suite delivers the most powerful tools
available to solve every problem in the wireless network, from planning and
deployment to ongoing troubleshooting and security monitoring.
The suite includes AirMagnet Survey PRO (which includes AirMagnet Planner),
AirMagnet Wi-Fi Analyzer PRO and AirMagnet Spectrum XT. Not only are these products
effective when used individually, but are even more powerful when used as an
integrated suite. The multiadapter kit allows users to get more power out of AirMagnet
solutions. For instance, users can perform site surveys in half the time with AirMagnet
Survey PRO and users can perform client roaming analysis using AirMagnet Wi-Fi
Analyzer PRO with the multiadapter kit.
FEATURES
•Accurately plan and deploy 802.11-based wireless networks
•Simplify troubleshooting
•Instant and complete visibility into the performance and security of the
wireless environment
•In-depth RF analysis
AIRMAGNET WLAN DESIGN AND ANALYSIS SUITE (WI-FI AND SURVEY PRO, XT)
GOLD SUPPORT
-
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR67004V2-528615.tif
The AirMagnet Wi-Fi Analyzer is the industry standard tool for mobile auditing and
troubleshooting enterprise Wi-Fi networks. The AirMagnet Wi-Fi Analyzer helps IT staff
quickly solve end-user issues while automatically detecting security threats and
wireless-network vulnerabilities. The solution enables network managers to easily
test and diagnose dozens of common wireless performance issues including
throughput issues, connectivity issues, device conflicts and signal multipath
problems. The AirMagnet Wi-Fi Analyzer includes a full-compliance reporting engine,
which automatically maps collected network information to requirements for
compliance with policy and industry regulations.
AirMagnet Wi-Fi Analyzer is available in Express and PRO versions. The AirMagnet Wi-Fi
Analyzer Express provides the core building blocks of Wi-Fi troubleshooting and
auditing with the ability to see devices, automatically identify common problems and
physically locate specific devices. The AirMagnet Wi-Fi Analyzer PRO significantly
extends all the capabilities found in the Express version and adds many more to
provide a Wi-Fi tool to solve virtually any type of performance, security or reporting
challenge in the field.
FEATURES
•Wi-Fi dashboard on overall health of the WLAN
•Built-in wireless expertise
•Instant alerts to WLAN security and performance issues
•Real-time WLAN troubleshooting
•WLAN client roaming analysis
•Active troubleshooting tools
•Complete Wi-Fi interference detection and analysis
•Integrated reporting
AIRMAGNET WI-FI ANALYZER PRO
GOLD SUPPORT
AirMagnet WLAN Design and Analysis Suite (Wi-Fi and Survey PRO, XT)
Anixter No. Vendor No. Description
485707 AM/A1480 AirMagnet Survey PRO (including
planner module)
Anixter No. Vendor No. Description
485704 GLD-S1480 AirMagnet WLAN Design and Analysis Suite
Gold Support
AirMagnet Wi-Fi Analyzer PRO
Anixter No. Vendor No. Description
456434 AM/A1150 AirMagnet Wi-Fi Analyzer PRO
485722 AM/B1170 AirMagnet Wi-Fi Analyzer Express
485723 AM/A1173-UGD Upgrade module from Express to PRO
456433 AM/B4070 AirMagnet Spectrum XT (USB-based)
485724 AM/C1090 AirMagnet multiadapter kit for Wi-Fi
Analyzer (U.S., world-mode and Japan
versions available)
485688 AM/A5225 Sensor with internal antenna, 802.11n,
dedicated spectrum-analysis radio
485690 AM/A5220 Sensor with external antenna, 802.11n,
dedicated spectrum-analysis radio
485691 AM/A5200 Sensor with external antenna,
802.11 a/b/g/n
485693 AM/A5205 Sensor with internal antenna,
802.11 a/b/g/n
485694 AM/A5031 Metal sensor-mounting bracket with
security lock option
485695 AM/A5231 Plastic sensor-mounting bracket
Anixter No. Vendor No. Description
485705 GLD-S1150G AirMagnet Wi-Fi Analyzer Gold Support
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.13
Test Equipment
Wireless
Test Equipment
-
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR25095V2-195251.tif
The AirCheck Wi-Fi tester is a simple-to-use, handheld wireless tester that allows
users to quickly verify and troubleshoot 802.11 a/b/g/n network availability,
connectivity and security all in a dedicated, handheld tool. Its one-button AutoTest
quickly provides a pass/fail indication of the wireless environment and identifies
common problems such as interference, overloaded networks, rogue devices,
coverage and security issues. AirCheck helps you audit your wireless environment to
identify and locate rogue clients and APs. The tester fully documents your
troubleshooting session and creates professional-quality reports. Use these reports
to close your trouble ticket or to provide the required information to escalate the
ticket to the next level. AirCheck provides the information you need to quickly solve
your frontline Wi-Fi problems.
FEATURES
•Dedicated, handheld 802.11 a/b/g/n tester with instant-on technology
•Fully supports 2.4 and 5.0 GHz frequency bands
•One-button AutoTest quickly provides a pass/fail indication of the wireless
environment and identifies common problems - for any level of Wi-Fi expertise
•Identify and assess availability and security of access points and clients - even
locate them physically
•See what's using your Wi-Fi network by channel and quickly determine if it is
802.11 traffic or non-802.11 interference
•Rapidly perform a Wi-Fi discovery to fully assess your current wireless security
settings and network availability
•Robust and in-depth WLAN connection tests - from probing to DHCP request
to ping
SUPPORT
AirCheck Wi-Fi Tester
Anixter No. Vendor No. Description
415187 AIRCHECK AirCheck Wi-Fi tester includes: AirCheck
tester, USB cable, soft case, Getting
Started guide and CD with AirCheck
manager software and user manual
419411 AIRCHECK-5PK AirCheck 5 pack, includes five AirChecks
and five directional antennas
419412 AIRCHECK-10PK AirCheck 10 pack includes 11 AirChecks
and 11 directional antennas
415192 EXTANT-RPSMA External directional antenna,
RSMA connector
415194 POE-DETECTOR Power over Ethernet detector, 802.3at
Anixter No. Vendor No. Description
415195 GLD-ACK AirCheck Gold Support services, one year
437501 GLD-ACK-3YR Three years of Gold Support for AirCheck
14.14
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Video
Test Equipment
D
./-
Index1.Support and Supplies//Test Equipment//Video Applications
IDEAL INDUSTRIES PR21326V2-119027.tif
This tester combines seven essential CCTV tools into one cost-effective handheld
device. It incorporates a bright color LCD video display, analog PTZ controller, digital
multimeter, UTP wiremap, video pattern generator, PTZ protocol analyzer and
programming of camera presets and menus. The PTZ protocol analyzer and menu
programming decodes and identifies output from the PTZ console and allows access
to programming menus of the camera that support this feature. The SecuriTEST PRO is
multifeatured, affordable, great for new installs or troubleshooting and easy to use.
FEATURES
•IRE video level and sync tests
•Sound level test through integrated speaker and onscreen level indicator
•High-capacity lithium battery
•Support for additional PTZ protocols
•Carrying case included
•Lighter in weight with comfort-grip sides
•Includes batteries, AC adapter charger, 12 V auto charger, 4 ft. (1.2 m) BNC
video cable, DMM test leads, UTP cable terminator and neck strap
SecuriTEST PRO CCTV/Security Tester
Anixter No. Vendor No. Description
365881 33-892 SecuriTEST PRO CCTV/security tester
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.15
Test Equipment
Cable Qualification
Test Equipment
./--
Index1.Support and Supplies//Test Equipment//Data Applications
IDEAL INDUSTRIES PR67011V2-528752.tif
The SIGNALTEK II handheld cable and network qualifier is designed to confirm correct
installation of copper and fiber cabling capable of supporting voice, video, data and
CCTV applications over 10/100 Megabit or Gigabit Ethernet. Detect and run load
testing on PoE and PoE+. Qualify passive cabling to support Gigabit Ethernet and
perform active network testing diagnostics such as DHCP, ping and ARP (address
resolution protocol) tests. It tests the link's ability to support applications by
transmitting Ethernet packets on the cable and measuring the link performance to
the IEEE 802.3ab Gigabit Ethernet standard. By monitoring transmitted and received
data packets, it can report the BER (bit error rate) for the link. Incorporates IPv4 and
IPv6 compatibility to provide a future-proof investment. Wiremapping by pin as well
as pair.
FEATURES
•Gigabit Ethernet qualification tester for copper and fiber cable links
•Qualify to IEEE 802.3 standards
•BERT testing for 10/100/1000BASE-T
•Multimode and single-mode testing
•Small Form Factor Pluggable (SFP) modules are compact and field-changeable
•Store/print thousands of reports
•Supports USB "thumb-drives"
•2.8 in. color screen
•User-exchangeable RJ45 inserts
•Choice of power inputs
•Durable rubber molded housing
•Multifunction and cursor keys
ACCESSORIES
--
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR21306V2-118922.tif
The CableIQ quickly troubleshoots and qualifies existing twisted-pair cabling for
voice, 10/100BASE-T or Gigabit Ethernet. The CableIQ can detect speed and duplex
settings of attached switches and PCs and intelligent wiremap tests for length,
shorts, split pairs or opens, and graphically shows distance to specific pin faults
(e.g., pin #1 break at 37 ft.). With its intuitive, lightweight, rugged design, it tests
voice, data, video, security and audio cabling.
FEATURES
•Test existing cabling for support of voice or 10/100/Gigabit Ethernet
•Troubleshoot if existing cabling plant can support the desired network speed
•Discover what's at the end of any cable and switch configuration (speed/duplex/
pairing)
•Intelligent wiremap graphically maps wiring configuration and shows distance
to faults
•Test all copper cabling media: twisted-pair, coax and audio cabling
•Locate and trace cable with IntelliTone digital signaling technology
•Save and upload results to attached PC
CABLE IQ QUALIFICATION TESTER
GOLD EXCHANGE SUPPORT SERVICES
SIGNALTEK II - Cable and Network Qualification Tester
Anixter No. Vendor No. Description
486416 R156000 For copper networks
486417 R156001 For copper and fiber networks (fiber
modules sold separately)
Anixter No. Vendor No. Description
352089 SFP-850 Pair of 850 nm SFP modules,
1000BASE-SX, jumpers not included
352090 SFP-13X0 Pair of 1310 nm SFP modules,
1000BASE-LX, jumpers not included
435669 SFP-1550-1 Pair of 1550 nm SFP modules,
1000BASE-ZX, jumpers not included
435658 150054 Active remote #1
435662 150050 Active remote set #2 - #12
486418 151053 NiMH power module
CableIQ Qualification Tester
Anixter No. Vendor No. Description
376840 CIQ-VOIP CableIQ VoIP enterprise service kit
303632 CIQ-100 CableIQ qualification tester
303633 CIQ-KIT CableIQ advanced IT kit includes: main unit with
remote adapter, reporter software CD, IntelliTone
200 digital probe, remote IDs #2 to #7, two
RJ45 patch cords, USB cable, coax F push-on
adapter, 75 ohm coax patch cord, RJ45/11 patch
cord, four AA batteries
314671 CIQ-KRQ CableIQ residential qualifier kit
391277 CIQ-FTKSFP Copper and fiber technician's kit - includes the
CableIQ (CIQ-KIT) and SimpliFiber Pro (FTK1000)
fiber test kit
328388 CIQ-SVC CableIQ service kit includes CableIQ qualification
tester, six CableIQ remote identifiers, CableIQ
reporter software CD, two RJ45-RJ45 shielded patch
cords, USB cable, coax F push-on cable, RJ45/
RJ11 universal coupler, LinkRunner network
multimeter, LinkRunner main wiremap adapter,
IntelliTone 200 digital probe, test accessory soft
pouch, user CD and quick-start guide, packaged in a
rugged carrying case; one 9 V and six AA
batteries included
Anixter No. Vendor No. Description
366263 GLD-CIQ Gold support for CableIQ (any model), one year
14.16
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Cable Qualification
Test Equipment
D
-
Index1.Support and Supplies//Test Equipment//Data Applications
IDEAL INDUSTRIES PR70893V2-556775.tif
Advanced wiremapper and versatile troubleshooter for conducting active and passive
network testing across both copper and fiber networks. Powerful network and cable
verification tool for cabling installers and IT or facilities maintenance professionals
working in any enterprise, residential, campus or industrial Ethernet environment.
FEATURES
•Excellent wiremapping by pin, with distance to fault
•Bright, backlit color screen and intuitive intercase
•IPv6 compliant
•VLAN support
•Traceroute
•Create and store test results in standard compliant XML format
•Easy to view and export results for report printing
•Identify Ethernet and Power over Ethernet (PoE) issues in addition to verifying
Ethernet connectivity
•Supports both IPv4 and IPv6 Internet addresses
•802.1x compatibility to log onto networks securied by this protocol, avoiding
unnecessary security complications and lengthy project delays
--
Index1.Support and Supplies//Test Equipment//Data Applications
JDSU PR28507V2-208543.tif
The ValidatorPRO Ethernet speed certifier with integrated optical power meter and
accompanying Plan-Um cable-management software delivers the power to test both
copper and fiber cabling, determines if cables can support Gigabit Ethernet and
performs troubleshooting for cable installations.
FEATURES
•Measures optical power on single-mode and multimode fiber
•Conducts BER testing to speed-certify Ethernet data transmission speed up to
1000BASE-T (1 Gb/s)
•Measures SNR and skew to uncover impairments to electrical Ethernet
data transmission
•Tests for opens, shorts, split pairs, miswires and reversals and measures
distance to opens and shorts - supports all copper network, telco and
coax cables
•Measures PoE voltage and current (NT only)
•Performs port discovery to detect advertised Ethernet speed and displays
capabilities of network devices (NT only)
•Pings network devices to verify connectivity to active equipment (NT only)
•Discovers and displays essential information regarding functionality of
802.11 b/g/n wireless devices (NT only)
VALIDATORPRO
Each package includes: one smart remote, one set 1-8 wiremapping remotes (RJ11/
RJ45) (TP612), two lithium-ion rechargeable batteries (NT93), two universal AC
adapter/charger units, one 1.83 m 72 in. USB client-to-PC connection cable (series
A plug to series B plug), two 19 cm 7.5 in. RJ12-to-RJ12 cables for no-fault
connection to RJ11 or RJ45 jacks, two 30.48 cm 1 ft. patch cables with
RJ45 connectors, two 60.96 cm 2 ft. RJ45 to 8 alligator clips cord sets, two
sacrificial cables for RJ45 mod plug, one coupler F-jack to F-jack, USB drive
including Plan-Um cabling installation and planning software, user guide (product
manual) and quick-start guide, deluxe carrying case, printed quick-start guide,
100 "speed certified" cable labels and one 12 V vehicle charger
NaviTek Frontline Technician Tester
Anixter No. Vendor No. Description
487145 R151002 PRO - fully featured solution suitable for
copper and fiber networks
487146 R151001 PLUS premium kit - copper testing with
support for VLAN and storage for test
results, includes rechargeable power
module, RJ45 extraction tool,
10 RJ45 inserts and amplifier probe
487150 R151000 PLUS - tester only
487151 R153000 BASIC - entry model features LAN testing
over copper networks and includes
functionality for detecting Power over
Ethernet, no test storage
ValidatorPRO and ValidatorPRO-NT
Anixter No. Vendor No. Description
442340 NT1055 ValidatorPRO-NT CU. Copper-only Ethernet
network management tool including active
network tests
406656 NT1150 ValidatorPRO Ethernet speed certifier with
integrated optical power meter
406657 NT1155 ValidatorPRO-NT Ethernet speed certifier
with integrated optical power meter
including active network tests
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.17
Test Equipment
Cable Continuity
Test Equipment
./-
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR20668V2-82253.tif
The next-generation MicroScanner2 streamlines voice/data/video cable and service
testing. Revolutionary user interface displays available services (10/100/
1000 Ethernet, POTS, PoE), cable length (with true TDR technology for finding
distance to shorts and opens), wiremap, cable ID and distance to fault, all on one
screen. Test RJ11, RJ45 and coax with no adapters. Built-in IntelliTone digital and
analog toning precisely locates virtually any cable or pair.
FEATURES
•Displays cable length, wiremap, cable ID and distance to fault on one screen
•Detects today's media services, including 10/100/1000 Ethernet, POTS and PoE
•Locates virtually any cable or wire pair with IntelliTone digital and analog toning
•Tests all common media types, including RJ11, RJ45, coax, with no adapters
•Rubber overmold enhances grip and increases ruggedness
•"Oversized" backlit LCD makes results crystal clear in any work environment
-
Index1.Support and Supplies//Test Equipment//Data Applications
IDEAL INDUSTRIES PR28426V2-207843.tif
The VDV PRO cable tester is an easy-to-use cable-testing and verification device that
can quickly test all wiring requirements found throughout today's residential and
commercial environments. This tester checks for opens, shorts, split pairs, reversals
and miswires on UTP cables, and opens and shorts on coax. It supports RJ11/12,
RJ45, coax, F, BNC and RCA connectors. The IENet PRO version supports RJ45 and
MJ12 connections and tests to PROFINET industrial Ethernet cabling requirements.
FEATURES
•Both models measure cable length
•Displays wiring errors including open, short, miswire, split pair and length
•Multi-tone support for cable tracing and fault isolation
•Blink network link LED for visual cable tracing
•New integrated coax F-connection
•Larger backlit LCD screen for better test results readability
•Kits available with either one remote or eight remotes
•Remotes have coax, RJ11 and RJ45 jacks for increased testing capabilities
•IENet PRO features a unique, easy-to-use cable test for 2-pair and 4-pair
industrial Ethernet cabling
•IENet PRO remotes have shielded 2-pair, M12 and RJ45 ports and are
compatible with most IE cabling
•Test results are displayed in PROFINET industrial Ethernet required format
MicroScanner2 Cable Verifier
Anixter No. Vendor No. Description
348860 MS2-100 MicroScanner2includes: MicroScanner2,
main wiremap adapter, two AA alkaline
batteries, printed multilanguage getting
started guide, user CD with multilanguage
user manuals, packaged in a Fluke
Networks vinyl carry pouch
348861 MS2-KIT MicroScanner2professional kit includes:
MicroScanner2, main wiremap adapter,
remote identifiers #2-7 IntelliTone Pro
200 Probe, shielded twisted-pair
RJ45 patch cord, RJ11 patch cord, clip set
RJ45 to 8 alligator clip bare wire adapter,
F coax push-on patch cord, accessory soft
pouch, two AA alkaline batteries, 9 V
alkaline battery, MicroScanner2 Getting
Started Guide, user CD, IntelliTone Pro
getting-started guide, IntelliTone Pro user
CD, packaged in a deluxe Fluke Networks
carry case
363120 MS2-TTK MicroScanner2cable verifier, IS60 Pro-Tool
kit, IntelliTone 200 probe, RJ11 and
RJ45 patch cables, lanyard, owner's CD
and quick-start guide and 9 V battery,
packaged in a deluxe Fluke Networks
carry case
392768 MS2-FTK Copper and fiber basic technician's kit -
includes the MicroScanner (MS2-100) and
SimpliFiber Pro (FTK1000) fiber test kit
VDV PRO and IENet PRO Cable Testers
Anixter No. Vendor No. Description
412236 33-770 VDV PRO with one remote and terminator,
case and accessories
412217 33-771 VDV PRO with eight remotes and
terminators, case and accessories
420252 33-772 IENet PRO with single remote
420253 33-773 IENet PRO with eight remotes
412239 33-774 VDV PRO replacement eight remote kit
(ID 1-8)
420254 33-775 VDV PRO replacement eight coax
terminator kit
420255 33-776 IENet PRO replacement eight remote kit
(ID 1-8)
412238 33-780 VDV PRO tester with one remote and
amplifier probe
311427 LA-4173 BNC adapter accessory kit
14.18
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Cable Continuity
Test Equipment
D
-
Index1.Support and Supplies//Test Equipment//Data Applications
IDEAL INDUSTRIES PR67013V2-529320.tif
All-in-one testing solution for identifying wiring errors and locating cable in voice/
data/video installations. Designed for use in LAN, telephone, coaxial video, security,
A/V and other general coax and twisted-pair applications. This kit performs the
essential cable-testing functions required by installers and system technicians.
FEATURES
•Wiremap twisted-pair cable
•Trace copper cables
•Detect opens/shorts in coax
•Four selectable tones for tracing
•Includes patch cords and RCA and BNC adapters
•Carrying case and two 9 V batteries included
-
Index1.Support and Supplies//Test Equipment//Data Applications
IDEAL INDUSTRIES PR10778V2-12105.tif
Easy-to-use tester for installers working with voice, data and video applications.
Tests for opens, shorts, miswires, reversals and split pairs. Also indicates correct
wiremap. Has automatic shutoff to prolong battery life and low-battery indicator.
FEATURES
•VOICE - Supports 3-pair USOC and 6-position RJ11/12 jacks for telephone
cable testing
•DATA - Supports both shielded and unshielded cable testing for T568A/B (RJ45)
•VIDEO - Tests coax cable for opens and shorts with F-connector interface
•TONE GENERATOR - Supports four different tones, making fault identification
easier and allows selection of pairs or conductors to transmit tone
•One remote unit is stored inside the tester to keep all parts together with unique
design to accommodate coax, RJ11 and RJ45 type connectors
•Can support up to eight unique UTP/STP remotes that wiremap and test for voice
and data - must order separately
Test - Tone - Trace Kit
Anixter No. Vendor No. Description
486419 33-866 Test-Tone-Trace kit
VDV MultiMedia Tester
Anixter No. Vendor No. Description
306726 33-856 VDV tester
311427 LA-4173 BNC adapter accessory kit
412239 33-774 VDV PRO replacement eight remote kit
(ID 1-8)
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.19
Test Equipment
Cable Continuity
Test Equipment
-
Index1.Support and Supplies//Test Equipment//Data Applications
GREENLEE PR33665V2-248405.tif
The NETcat Pro 2 is a digital-wiring troubleshooter for voice, data and video cables,
wiring and service. Controlled by a touch screen display, it is designed to quickly
verify that patch cords and in-wall cables have been correctly wired or installed and
to determine if Ethernet LAN service is available. It also measures the length of
cables. Using connectors on the base unit and its onboard remote, the NC-500 works
with twisted-pair LAN, telephone and coaxial cable wiring.
FEATURES
•Touch screen display with contrast adjustment and backlight
•0to 2,000ft. cable length viaTDR
•Generates four distinct, precision tones for tracing low-loss cables like Cat 5
•Identifies active network devices (PC or hub) on 10/100BASE-T networks
•Detects shorts, opens, reversed, crossed and split pairs
•Office ID using remote ID units
•Patch cable and remote jack wiremap
•Power over Ethernet detection
-
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR20279V2-71133.tif
The TS90 Cable Fault Finder is three tools in one: 1) locate distance to opens or
shorts; 2) measure cable on a reel or in a box; 3) patented power-tone generator
provides five tones, allowing the user to short the far end and hear a change in tone
when the correct pair has been identified. Single-button operation and an
easy-to-read LCD display.
FEATURES
•Instantly measures distance to open or fault from one end of any cable pair up
to 3,000 ft.
•Patented power-tone generator positively identifies pair
•High-voltage detection
•Moistureproof
•Large LED screen and easy-to-use menu
NETcat Pro 2 NC-500
Anixter No. Vendor No. Description
352096 NC-500 NETcat Pro 2 digital VDV
wiring troubleshooter
352097 NC-510 NETcat Pro 2 accessory kit with carrying
case and seven digital remote units
TS90 Cable Fault Finder
Anixter No. Vendor No. Description
272098 26500090 TS90 with BNC alligator clips
14.20
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Tone Generators and Probes
Test Equipment
D
./
Index1.Support and Supplies//Test Equipment//Locators
GREENLEE PR28509V2-208556.tif
Used in conjunction with any tone generator, inductive amplifiers permit wire and
cable identification without having to make direct metallic contact with the
conductor. All models feature a powerful speaker for noisy environments, adjustable
volume control, recessed on/off button control and high gain for accurate wire
identification in congested cable bundles.
Index1.Support and Supplies//Test Equipment//Data Applications
GREENLEE PR28510V2-208568.tif
The filter probe blocks AC interference by filtering out power-related noise to stop
60 Hz power-line hum. The 200FP features adjustable sensitivity control/volume, a
momentary ON/OFF push-button and recessed terminals for connecting the unit to
telephone test sets or headphones. Works with most tone generators.
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR20667V2-82256.tif
Breakthrough IntelliTone digital signal technology finds cables other toners/probes
can't and speeds cable location with advanced sensing modes. The IntelliTone Pro
provides simplified signal interpretation with smart LED and audio indicators and
digital signal rejects noise and safely tones active networks. The IntelliTone Pro
200 Kit includes powerful troubleshooting capabilities with datacom link, two-line
telecom service ID and end-to-end cablemap.
FEATURES
•IntelliTone digital processing eliminates noise and false signals
•New SmartTone analog toning precisely isolates individual wire pairs
•Locates cables safely and effectively on active networks
•Identifies, diagnoses and troubleshoots datacom/telecom services
Index1.Support and Supplies//Test Equipment//Data Applications
GREENLEE PR28511V2-208559.tif
Designed for the network installation and maintenance professional, the LAN Toner
sends tone and blinks hub, switch port and PC activity lights for fast identification.
This kit can be used on any wiring system including datacom, telecom, security/
alarm, audio and CATV. Kit includes AT8L LAN toner, 200GX inductive amplifier probe
and carrying case.
Inductive Amplifier
Anixter No. Vendor No. Description
434496 200EP-G Inductive amplifier
240790 200GX Professional inductive amplifier
093664 200B-G Basic tone probe
Inductive Amplifier with Filter
Anixter No. Vendor No. Description
177079 200FP Filter probe
IntelliTone Pro Toner and Probe
Anixter No. Vendor No. Description
277448 MT-8200-60A IntelliTone Pro 200 toner and probe kit
277261 MT-8200-50A IntelliTone Pro 100 STD toner and probe kit
277449 MT-8200-61A IntelliTone Pro 200 toner
277452 MT-8200-63A IntelliTone Pro 200 probe
277270 MT-8200-53A IntelliTone Pro 100 probe
277453 MT-8202-05 IntelliTone Pro case
277454 MT-8203-20 Test leads with bed of nails
277455 MT-8203-22 Test leads with alligator clips
LAN Toner Kit
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.21
Test Equipment
Tone Generators and Probes
Test Equipment
FEATURES
•Universal 6- or 8-position modular plug
•Breakout adapter allows access to individual pairs
•Female RJ45 jack on bottom allows for patch-cord connection
Index1.Support and Supplies//Test Equipment//Power Applications
GREENLEE PR28588V2-209518.tif
The 701K-G is used to identify single conductors or cables within a bundle, at a
cross-connect point or at remote ends. The 701K-G packages the 77HP-G Tone
Generator and the 200EP-G Inductive Amplifier probe in a carrying case. The 200EP-G
tracing probe features an LED headlight for working safely in dark environments. It
also has three listening modes with adjustable volume controls. The 77HP-G tracing
tone generator has one- or two-line telephone service, voltage/polarity indication and
checks for short circuits/continuity with a light and audible beep.
Index1.Support and Supplies//Test Equipment//Data Applications
GREENLEE PR28512V2-208574.tif
The 801K is used to identify single conductors or cables within a bundle, at a
cross-connect point or at remote ends. The 60 Hz filter probe eliminates electrical
noise to make identifying cables in "noisy" environments possible. The 801K
packages the 77HP/6A Tone Generator and the 200FP Inductive Amplifier probe in a
carrying case.
Index1.Support and Supplies//Test Equipment//Video Applications
GREENLEE PR6774V2-20203.TIF
Designed specifically for the CATV industry, this kit allows you to tone through
splitters, directional couplers and taps.
FEATURES
•Kit includes: transmitter, receiver, male F-to-F-connector adapter cable, male
F-to-alligator clip adapter cable and carrying case
•Three methods of signal reception: electrostatic pickup for non-terminated
cables, electromagnetic pickup for terminated or shorted cables and direct
connection when identifying in the presence of passive devices
•Transmitter and receiver are equipped with female F-connectors
Anixter No. Vendor No. Description
244521 AT8L LAN toner
244522 AT8LK LAN toner kit
Classic Tone and Probe Kit
Anixter No. Vendor No. Description
151298 701K-G Classic tone and probe kit
148554 77HP-G Classic tone generator
434496 200EP-G Inductive amplifier
405398 601K-G Basic tone and probe kit
151297 700C Carrying case for 701K kit
Premium Tone and Probe Kit
Anixter No. Vendor No. Description
212374 801K Premium tone and probe kit
166855 77HP-G/6A Classic tone generator with
bed-of-nails clips
177079 200FP Filter probe
CATV Tone and Probe Kit
Anixter No. Vendor No. Description
218704 402K CATV cable tone test set
14.22
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Tone Generators and Probes
Test Equipment
D
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR10709V2-11240.tif
The Pro3000 Tone and Probe Kit is an innovative analog tone and probe from Fluke
Networks. Easily identify individual pairs with its patented SmartTone technology (the
five different tones for exact pair identification). The large powerful speaker on the
probe allows you to hear through drywall, wood or other enclosures to find wires
quickly and easily. Kit includes pouch.
FEATURES
•Select solid or alternating tone options, indicated with solid or flashing LEDs
•Exclusive SmartTone technology can generate five separate analog tones when
the pair is shorted at the far end
•Works on de-energized AC wire, telephone/twisted-pair wire, all voice and data
category-rated cable, all coax cable, speaker wire and security wire
•Send tone signal up to 10 miles on most cables
•Line cord features angled bed-of-nails clips and ruggedized RJ11 plug for direct
access to phone and data jacks without adapters
Index1.Support and Supplies//Test Equipment//Data Applications
GREENLEE PR28508V2-208557.tif
Permits technicians to identify the conductor within a bundle, at a cross-connect
point or at the remote end. Can be used on twisted-pair wiring (telecom, datacom,
etc.), single conductors, coaxial cables, de-energized AC wiring and most other wiring
with a handset or an inductive amplifier. The tone can reach 50,000 ft. through
low-resistance circuits. The unit has dual LEDs for checking polarity on lines one and
two. The tone and/or the continuity tests are controlled by the toggle switch. Battery
(9 V) not included.
FEATURES
•Selectable warble tone
•Continuity testing
•Polarity testing
•Talk battery supply
•Two-line modular test lead (RJ11)
•Three-color LED (identifies AC ring voltage)
•Weather-resistant design
Pro3000 Tone and Probe Kit
Anixter No. Vendor No. Description
290695 26000900 Pro3000 analog tone and probe kit
323956 26100900 Pro3000 probe
323957 26200900 Pro3000 tone generator
328803 26100103 Pro3000 analog probe replacement tip
77 Series Tone Generators
Anixter No. Vendor No. Description
148554 77HP-G Classic tone generator
166855 77HP-G/6A Classic tone generator with
bed-of-nails clips
447722 77M-G Basic tone generator
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.23
Test Equipment
Tone Generators and Probes
Test Equipment
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR33719V2-248856.tif
The Pocket Toner tools are pocket-size, durable test devices that allow users to
quickly and easily test wires and cables for continuity and short circuits. The Pocket
Toner comes in three models and several different kit configurations. No matter what
your job, you can safely install and test. All of the Pocket Toners have dual audible
indicators in the main body and detachable buzzer toner units, removable push-on
connectors, auto shut-off and easy-to-read indicators.
FEATURES
•Low-voltage circuit protection for both the PCB as well as the detachable toner
unit. An installer can test a (>6 V, up to 48 V) low-voltage cable without
causing lethal damage to the tool
•Dual audible indicators in main body and detachable buzzer toner unit
•Male and female adaptable toner section
•Removable push-on connector
•Lightweight, durable anodized aluminum body
ACCESSORIES
Pocket Toner
Anixter No. Vendor No. Description
441410 PTNX1 Pocket Toner NX1 - includes NX1 unit
and toner
441411 PTNX2 Pocket Toner NX2 - includes NX2 unit
and toner
441412 PTNX2-DLX Pocket Toner NX2 deluxe kit - includes
NX2 unit, toner, RJ11 and RJ45 adapters,
66 block adapter, Dial Tone Detective,
alligator clips, BNC adapters, RCA
adapters, F-81, F-71, Speed 81 adapter,
battery and canvas case
441413 PTNX2-CABLE Pocket Toner NX2 cable kit - includes
NX2 unit, toner, alligator clips adapter,
F-81, F-71 and Speed 81 adapters, male
push-on adapter, battery and canvas case
441414 PTNX8 Pocket Toner NX8 - includes NX8 unit
and toner
441415 PTNX8-CABLE Pocket Toner NX8 cable kit - includes
NX8 unit, toner, eight ID caps, alligator
clips, F-81, F-71 and Speed 81 adapters,
male push-on adapter, battery and deluxe
case with belt clip
441416 PTNX8-CT Pocket Toner NX8 cable and telephone kit -
includes NX8 unit, toner, eight ID caps,
66 block adapter, RJ11 adapter, Dial Tone
Detective alligator clips and RJ11 adapter,
F-81, F-71 and Speed 81 adapters, male
push-on adapter, battery and deluxe case
with belt clip
441417 PTNX8-DLX Pocket Toner NX8 deluxe kit - includes
NX8 unit, toner, eight ID caps, 66 block
adapter, RJ11 and RJ45 adapters, Dial
Tone Detective, alligator clips and
RJ45 adapter, BNC adapters, RCA
adapters, F-81, F-71, Speed 81 adapters,
male push-on adapter, battery and deluxe
case with belt clip
441419 PTNX8-VV-PRO Pocket Toner NX8 voice and video pro kit -
includes NX8 unit, toner, eight ID caps,
66 block adapter, RJ11 adapter,
RJ45 adapter, Dial Tone Detective, Alligator
clips and RJ11 adapter, F-81, F-71, Speed
81, male push-on adapter, battery and
deluxe case with belt clip
Anixter No. Vendor No. Description
441420 ADAP-PTNX-KIT Accessory kit - includes alligator clips and
RJ45 adapter, alligator clips and
RJ11 adapter, Dial Tone Detective,
RJ11 adapter, 66 block adapter,
RJ45 adapter, F-type connectors, RCA
connectors, BNC connector and bare
wire connector
441425 CASE-PTNX-SM Small case
441426 CASE-PTNX-LG Large case
441427 PTNX8-ID-1-8 Eight ID caps
441428 ADAP-PTNX-RJ11 RJ11 adapters
441429 ADAP-PTNX-RJ45 RJ45 adapters
Anixter No. Vendor No. Description
14.24
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Fiber Optic
Test Equipment
D
./
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
CORNING CABLE SYSTEMS PR29183V2-215904.tif
The Corning Cable Systems OV-Mini Optical Time Domain Reflectometer (OTDR)
provides a rugged, handheld and lightweight solution for testing and troubleshooting
fiber optic networks. This handheld OTDR gives the operator the flexibility of testing
single-mode 50 and 62.5 m multimode systems with the same unit. The OV-Mini
provides complete connectivity flexibility (with USB-stick compatibility and USB-cable
download) and top user-friendliness (offering one-touch testing). The OV-Mini has a
large internal memory that typically stores up to 500 traces and eliminates the need
for a hard drive, which can fail under extreme field conditions.
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
CORNING CABLE SYSTEMS PR12141V2-22090.tif
The Corning Cable Systems OV-1000 Optical Time Domain Reflectometer (OTDR)
provides testing flexibility by combining a rugged platform with field-interchangeable
multimode, single-mode and advanced testing modules. Designed for testing and
troubleshooting of LAN, Telco, CATV and FTTx networks, all OTDR modules can be used
as Continuous Wave (CW) light sources. Available as options on the mainframe are a
power meter and visual fault locator (VFL). The OV-1000 also has an internal 8 GB
flash memory that stores at least 1,500 traces and eliminates the need for a hard
drive, which can fail under extreme field conditions. For extra storage capacity, the
unit offers three USB ports for portable file transfer. The OV-1000 has the capacity to
hold up to two OTDR modules or one OTDR module and one advanced testing module
at the same time. Modules can be easily switched out in the field, without the use of
tools, in just a matter of seconds. The OV-1000has a 6.4in. color screen that is
resistant to shock, water and the most common chemicals in the field. The screen is
large enough to view both the trace and the event table simultaneously, eliminating
the need to toggle back and forth between the two. Along with offering three OTDR
test modes - Auto, Advanced and Template Trace - the OV-1000 is future-ready with
the ability to accept protocol-testing modules such as Gigabit Ethernet
characterization. You can even project the OV-1000 screen onto a projector via the
remote desktop. An optional handheld analog video probe is available and is the ideal
solution for inspecting the quality of a fiber optic connector end-face.
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
CORNING CABLE SYSTEMS PR29184V2-215907.tif
Corning Cable Systems offers two OTDR launch cable solutions created with
high-quality Corning fiber and cable assemblies. Used for connecting between the
OTDR and system-under-test, these launch cables can also be used on the far end of
the system-under-test as a receive fiber. The optical launch cables for OTDR are also
included.
Both options come with a wide variety of configurations depending on customer
application. The PTB is a small, portable test bag that offers a low-cost, compact
launch cable and can be placed inside most OTDR transit cases. The PTB also offers a
carabineer for attaching to an equipment rack, belt loop, bucket lift or messenger. The
second solution is a portable test fiber case (PTF), which offers a ruggedized,
easy-to-configure solution. The rugged construction allows for shipment of the launch
cable separate from the OTDR case.
Corning Cable Systems OTDR launch fiber is offered in several standard configurations
which are often stocked and offer shorter lead times. However, these items can be
custom built to meet your needs and specifications. Please contact your local sales
representative for help with custom part-number configurations.
OV-Mini Optical Time Domain Reflectometer (OTDR)
Anixter No. Vendor No. Description
406336 MINIDK OV-Mini OTDR deluxe kit, multimode/single-mode
OTDR with power meter and VFL
406335 MINIBK OV-Mini OTDR basic kit, multimode/
single-mode OTDR
406337 MINIXK OV-Mini OTDR deluxe kit with video inspection
probe (VIP)
443888 MINIXK-TK OV-Mini deluxe kit with video inspection probe and
separate handheld multimode/single-mode source
OV-1000 Optical Time Domain Reflectometer (OTDR)
Anixter No. Vendor No. Description
490596 1002DK-MDSD Deluxe kit includes Dual Multimode and Dual
Single-mode OTDR (module 400-MDSD)
mainframe with power meter and VFL, SC and
ST Compatible OTDR and meter port adapters,
OTS-Reporter2 processing software, cleaning
supplies and hard-shell transit case
414464 VIPROBE-DUAL 200x/400x video inspection probe includes:
video inspection probe (200x/400x
magnification), FC-SC tip for bulkheads, U25M
universal patch cord tip for 2.5 mm ferrules,
compartmented plastic case for tips
Basic kits and accessories are available. For more information,
contact your local sales representative.
Optical Time Domain Reflectometer (OTDR) Launch Fiber, Access
Jumper (PTBs and PTFs)
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.25
Test Equipment
Fiber Optic
Test Equipment
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
CORNING CABLE SYSTEMS PR29181V2-215422.tif
The Corning Cable Systems OTS-600 Series, consisting of optical sources, meters,
testers and kits with data-storage capabilities, is ideal for optical network
certification. The unit is designed for testing and troubleshooting of various
telecommunication networks, with ease of use achieved using a large, color LCD
screen, soft-key menus and a testing wizard.
The OTS-600 Series units have data storage for 10,000 results, USB data transfer
interface and a video inspection probe port. This unit comes standard with a 650 nm
visual fault locator (VFL) for convenient troubleshooting of optical networks.
FEATURES
•Intuitive step-by-step loss-testing wizard that walks user through calculating
pass/fail criteria, referencing and setting the file name
•Modular platform allows for future module upgrade
•Integrated video inspection probe (VIP) port for inspecting connector end-faces
•Provides source and meter in one unit for bi-directional testing functionality
•Auto wavelength switching and detection cuts typical testing time in half and
reduces potential for errors
•USB data ports provide convenient transfer of data to OTS-View Windows-based
PC software for storage, viewing and printing of test results
•Power meter has a range of +10 to -70 dBm
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
CORNING CABLE SYSTEMS PR20176V2-69279.tif
The Corning Cable Systems LTK-400 Series offers a complete, cost-effective solution
for link-loss testing of both multimode and single-mode systems for those users who
do not require data storage capabilities. The LTK offers unparalleled performance by
combining a source that has one of the highest-output powers in the industry with a
meter that has 10 calibrated wavelengths. The units can be powered by standard AA
alkaline batteries, or by the supplied AC power adapters.
The LTK-400 Series meter and sources are sold individually or packaged as test kits.
These test kits include everything needed to test "right out of the box."
The LTK-400 Series offers a rugged handheld design that can withstand the harshest
testing environments. Both the source and meter have field-interchangeable port
adapters. Automatic wavelength detection mode allows the power meter to detect/
switch to the wavelength being transmitted by the source. Optical sources are
available as single-mode only, multimode only, or as quad with both a single-mode
and multimode source in the same unit.
TEST KITS WITH SOURCE AND METER
Includes OM-410 Meter (no data storage), AA batteries for each units, two AC power
supplies, two wrist straps, plastic case of cleaning supplies and padded
carrying case.
ACCESSORIES FOR OTS-600 AND LTK-400 SERIES
Anixter No. Vendor No. Description
426741 PTF-300M-SP5861 SC-ST, OS2
270845 PTF-100M-6P3950 SC-ST, OM1
426742 PTF-100M-5P0339 SC-LC, OM3
Please contact your local sales representative for help with
custom part-number configurations.
OTS-600 Series
Anixter No. Vendor No. Description
370269 OTS-6MDSD Single-mode/multimode test kit with
OS-4RMDSD (850/1300 nm LED and 1310/
1550 nm laser) source; OM-610 power meter;
two Li-Ion rechargeable batteries and two AC
power adapters; USB cable for data transfer;
OTS-View software, one SC source port adapter,
one SC meter adapter, one ST compatible meter
adapter, one LC meter adapter, two wrist
straps, cleaning supplies, multimode testing
mandrels and hard transit case
LTK-400 Series
Anixter No. Vendor No. Description
309029 LTK-400MD Multimode Loss Test Kit including OS-403D
source (850/1300 nm LED), SC and ST
Compatible jumpers and adapters for MM, one
SC source port adapter and one ST compatible
meter port adapter
308987 LTK-4MDSD Quad Multimode and Single-mode Loss Test Kit
including OS-4MDSD (850/1300 nm LED) and
(1310/1550 nm laser) source, SC and ST
Compatible jumpers and adapters for both
multimode and single-mode, two SC source
ports adapter and one ST compatible source
port adapter
Anixter No. Vendor No. Description
314290 UI-SC Universal interface source connector
adapter, SC
314291 UI-ST Universal interface source connector adapter, ST
314292 UI-FC Universal interface source connector
adapter, FC
314286 OA-SC Power meter connector adapter, SC
314287 OA-ST Power meter connector adapter, ST compatible
Continued on next page >>
14.26
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Fiber Optic
Test Equipment
D
(continued)
LTK-400 Series
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
CORNING CABLE SYSTEMS PR9309V2-24361.tif
The VFL-350 Visual Fault Locator is a compact pen-design fault locator used to check
single-mode and multimode optical fiber cables and components for faults, check
system polarity or to locate individual fibers in a bundle. By transmitting a bright
beam of red light into a fiber, breaks or improper terminations can be seen as a
glowing red light with 635 nm wavelength. This device fits all 2.5 mm connector
ferrules but there is an optional 1.25 mm adapter for the LC connectors. The
VFL-350 operates on two AAA batteries and emits laser light of 635 nm (LASER Class
2 in accordance with IEC 825-2) with an output power less than 1mW. The robust and
compact metal housing makes the device suitable for daily on-site use.
-
Index1.Support and Supplies//Tools//Termination Equipment
CORNING CABLE SYSTEMS PR6504V2-29988.tif
Also ideal for troubleshooting contamination issues, their small size and rugged
construction make these microscopes excellent for field use. Each comes with a soft
carrying case and a universal 2.5 mm adapter for viewing most common connectors.
A 1.25 mm universal adapter can be purchased separately and an array of
connector-specific adapters are available for securely attaching the connector under
inspection to the microscope. The microscopes have a built-in laser safety filter that
provides a high level of attenuation at the most common laser wavelengths in case of
accidental viewing of an active fiber. Both the 200FM and 400FM microscopes
incorporate an LED designed to provide 100,000 hours of lamp life while using
minimal battery power.
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
JDSU PR23610V2-166686.tif
Testing metro, cable TV (CATV), access and fiber-to-the home (FTTH) networks with a
larger crew calls for using high-performance handheld test equipment, which is both
cost-effective and versatile. Whatever your needs, the T-BERD/MTS-4000 can provide
an optimized OTDR plug-in option. The OTDR plug-in modules, together with the
T-BERD/MTS-4000 family of products, provide a rugged, battery-operated handheld
test solution. The large display combined with a comprehensive user interface makes
it the ideal OTDR to respond to any test scenario.
The FiberComplete module offers the first solution of its kind that automatically
performs all the fundamental fiber qualification tests, such as bi-directional insertion
loss (IL) and optical return loss (ORL), distance and optical time domain reflectometry
(OTDR), with one module and from one optical port.
FEATURES
•Large 7 in. indoor/outdoor color display
•Intuitive graphical user interface with touch screen option
•Connection checker with VFL, power meter and video inspection scope options
•Optimized OTDR plug-ins for enterprise, FTTH, access, metro and
long-haul applications
•Highest OTDR performance with models with up to 42 dB dynamic range and
256,000 acquisition points
•Modules available for multimode, single-mode or both
•Instantaneous traffic detection when connecting live fiber
•Auto-test and automatic bend detection standard
•Integrated source and power meter under OTDR port
•Connect the JDSU FBP-P5000 scope to the unit via USB for automated pass/fail
on fiber inspection
Anixter No. Vendor No. Description
314288 OA-FC Power meter connector adapter, FC
314289 OA-LC Power meter connector adapter, LC
327816 OTS-COMBOMAN Set of mandrels for 50 m, 50 bend insensitive,
and 62.5/125 m multimode fiber
VFL-350 Visual Fault Locator
Anixter No. Vendor No. Description
251702 VFL-350 Visual fault locator, 635 nm penlight style
Handheld Field Inspection Microscope
Anixter No. Vendor No. Description
352625 200FM 200x microscope with universal
2.5 mm adapter
220360 400FM 400x microscope with universal
2.5 mm adapter
T-BERD 4000 OTDR and FiberComplete Tester
Anixter No. Vendor No. Description
441670 TB4-DIS-QUAD-S T-BERD 4000 Quad OTDR package basic,
which includes TB4000 mainframe, Quad
module, light source options and SC
adapters, fiber only
430670 TB4-DIS-QUAD-HPT T-BERD 4000 Quad OTDR package deluxe,
which includes TB4000 mainframe, Quad
module, power meter/light source options
and SC adapters - (can accept
ESAM module)
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.27
Test Equipment
Fiber Optic
Test Equipment
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
JDSU PR33747V2-249366.tif
Testing metro, cable TV (CATV), access and fiber-to-the home (FTTH) networks with a
larger crew calls for using high-performance handheld test equipment which is both
cost-effective and versatile. Whatever your needs, the T-BERD/MTS-2000 can provide
an optimized OTDR. The large display combined with a comprehensive user interface
makes it the ideal OTDR to respond to any test scenario. The TB2000 provides a
rugged, battery-operated handheld test solution.
FEATURES
•Large 5 in. indoor/outdoor color display
•Intuitive graphical user interface with touch screen option
•Connection checker with VFL, power meter and video inspection scope options
•Configurations available for multimode, single-mode or both
•Auto-test and automatic bend detection standard
•Connect the JDSU FBP-P5000 scope to the unit via USB for automated pass/fail
on fiber inspection
OPTIONS
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
JDSU PR28504V2-208538.tif
JDSU SmartPocket Optical Handhelds offer ergonomic and compact design with large
display, straightforward user interface and key features to provide the most suitable
test tool for technicians working with optical fiber.
The SmartPocket Optical Light Sources (OLS-3x) offer up to four wavelengths in one
product and provide an ideal economical solution for installing and maintaining
multimode datacom and local area networks LANs, as well as single-mode
telecommunications and multimedia networks.
The SmartPocket Optical Power Meters (OLP-3x) offer fast and accurate measurements
of optical power level and serve as ideal testing tools for installing single-mode and
multimode optical networks.
Together they constitute a perfectly suitable tool for verifying link-insertion loss,
measuring power level and checking continuity.
441671 TB4-DIS-MM-S T-BERD 4000 multimode OTDR package
441672 TB4T-FCOMP2-MA T-BERD 4000 package with 1310/1550 nm
FiberComplete and integrated
Metro-Access OTDR. Includes mainframe,
FiberComplete OTDR module, bi-directional
loss and length, light-source option, SC
interchangeable adapters, jumpers,
mating sleeves, nonreflecting terminations
for zero ORL testing and carrying case
441673 TB4T-FCOMP3-MP49 T-BERD 4000 package with 1310/1490/
1550 nm FiberComplete and integrated
Metro-PON OTDR. Includes mainframe,
FiberComplete OTDR module, bi-directional
loss and length, light-source option, SC
interchangeable adapters, jumpers,
mating sleeves, nonreflecting terminations
for zero ORL testing and carrying case
For more information and part-number configurations on the
JDSU T-BERD 4000, contact your local sales office.
T-BERD 2000 OTDR
Anixter No. Vendor No. Description
459882 TB2-DIS-2WLM Single-mode OTDR
459883 TB2-DIS-MM Multimode OTDR
449570 TB2-DIS-QUAD Quad OTDR
Anixter No. Vendor No. Description
459884 TB2-FCOMP2-FF FiberComplete with FaultFinder
(automated bi-directional loss, ORL
and FaultFinder)
459885 TB2-FCOMP2-MA FiberComplete with OTDR (automated
bi-directional loss, ORL and OTDR)
Anixter No. Vendor No. Description
459866 E20PMVFL Built-in broadband power meter option
with 2.5 mm ferrule universal
connector adapter
484552 E20WIFI Wi-Fi option for the T-BERD
2000 mainframe
459863 E20BLUE Bluetooth option for T-BERD 2000
450921 FBP-SD101 Inspection kit digital FBP-5000i,
FiberCheckPro software, FBPT tips SC, LC,
U25M, U12M and carrying case
For more information and part-number configurations on the
JDSU T-BERD 2000 OTDR, contact your local sales office.
OLP-34/35/38 and OLS-34/35/36 SmartPocket Optical Power Meters
and Light Sources
Anixter No. Vendor No. Description
Continued on next page >>
14.28
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Fiber Optic
Test Equipment
D
(continued)
OLP-34/35/38 and OLS-34/35/36 SmartPocket Optical
Power Meters and Light Sources
FEATURES
•Rugged and pocket-size design
•Large display combined with an easy-to-use interface
•Long battery lifetime
•Three years calibration
•Universal optical interface for both power meter and light source
•Auto-wavelength recognition and TwinTest features for saving test time and
error-free testing
•Permanent reference power level storage
•Fast download results using the micro USB port
•Report generation with OFS-355 software
SMARTPOCKET TEST KITS
Kits include AA alkaline batteries, AC power adapter, USB cable, one international
adapter per source, operating manual, neck strap, soft case MT-2P and a USB stick
including reporting software and all relevant documents.
SMARTPOCKET OPTICAL LIGHT SOURCES
Includes interchangeable adapter, AA alkaline batteries, operating manual, neck
strap and a belt bag.
SMARTPOCKET OPTICAL POWER METERS
Includes 2.5 mm UPP adapter, AA alkaline batteries, operating manual, neck strap, a
belt bag and USB download capability.
ADDITIONAL ACCESSORIES
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
JDSU PR33630V2-248018.tif
The new JDSU FI-Series Live Fiber Identifier (LFI) addresses the real-world needs of
fiber technicians with the ability to detect optical signals on a fiber cable without
disrupting network traffic. Designed with user workflow in mind, this small
form-factor device eliminates time-consuming and confusing problems encountered
in other LFI devices. Simply align the jacketed fiber into the open channel and click
the safe-latch trigger to identify activity or tones at 270 Hz, 330 Hz, 1 kHz and 2 kHz.
Compatible with multiple cable diameters from 250 m tight buffer to 3 mm
jacketed fibers, this LFI is ideal for installation, service, maintenance or
troubleshooting. This unique and compact tool is very easy to use.
FEATURES
•Slim form-factor design enables access to cables in densely populated areas
•Safe-latch trigger assures that the technician will not over-stress the fiber when
testing, providing a repeatable and controlled engagement with fiber
•Easy to understand controls with visible "traffic" indicator and audible tone
(solid or pulsed, depending on traffic type)
•Easily converts to an Optical Power Meter (OPM)
•Measures both absolute (dBm) and relative (dB) power measurements
•Store and recall up to 100 measurement readings directly on the device
•Download stored data to PC via USB connection
•User can define and customize list of selectable wavelengths
•Up to 2 kHz tone detection with user-adjustable power threshold
•Audible tone and visual indicator when power threshold is exceeded
Anixter No. Vendor No. Description
441818 2127/01 OMK-34P enterprise plus - MM SmartPocket test
kit with interchangeable adapters and USB option
430665 2127/04 OMK-36P enterprise plus - SM/MM SmartPocket
test kit with interchangeable adapters and
USB option
441838 2127/02 OMK-35P service provider plus - SM SmartPocket
test kit with interchangeable adapters and
USB option
441839 2127/03 OMK-38P service provider Hi-Power Plus- SM
SmartPocket test kit with interchangeable
adapters and USB option
Anixter No. Vendor No. Description
441840 2303/01 OLS-34 LED source, 850/1300 nm, MM
441847 2303/21 OLS-36 Quad Source, 850/1300/1310/1550 nm,
SM, MM
441844 2303/11 OLS-35 laser source, 1310/1550 nm, SM
Anixter No. Vendor No. Description
441883 2302/11 OLP-34 optical power meter, germanium and
+5 dBm with data storage
441884 2302/12 OLP-35 optical power meter, InGaAs and
+10 dBm with data storage
441885 2302/13 OLP-38 optical power meter, filtered InGaAs and
+26 dBm with data storage
Anixter No. Vendor No. Description
441873 FCR-CLN-01 Fiber cleaning consumables kit
441874 2237/90.02 NiMH rechargeable batteries, Mignon AA, 1.2 V
(two batteries)
441875 2302/90.01 SNT-505; universal AC power adapter, micro
USB connector
441876 2302/90.03 Neck strap for SmartPocket
441880 K 807 USB connection cable
441882 2127/90.01 MT-2P, soft case for two SmartPockets
and accessories
For more information and part-number configurations,
contact your local sales office.
FI-60
Anixter No. Vendor No. Description
440203 FI-60 Live Fiber Identifier with removable LFI
attachment, 2.5 mm and 1.25 mm OPM
connector interfaces, USB cable, software
and carrying case
Anixter No. Vendor No. Description
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.29
Test Equipment
Fiber Optic
Test Equipment
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
JDSU PR33639V2-248021.tif
The integrated features and contents of JDSU's fiber inspection and test kits are
specially designed to optimize workflow and provide ultimate portability. It features
the new FIT handheld inspection and test system that combines optical power
measurement and dedicated patch cord inspection into one device. The kit also
includes the industry-leading FBP Series probe for bulkhead inspection and a visual
fault locator that quickly and easily locates fiber damage. The utility boot organizes
these essential tools into one functional unit, making it ideal for field use.
FEATURES
•TFT LCD to view clear, crisp, detailed images of fiber end-faces with
optimal resolution
•Inspects both sides of fiber interconnect and accurately tests and measures
optical power with one device
•Integrated functions and features eliminate switching between multiple devices
•FBP series probe microscope and a dedicated patch cord microscope (PCM) let
users quickly and easily inspect both sides of the fiber interconnects
•Integrated patch cord monitor eliminates need for changing inspection tips,
prevents misrouting and protects patch cords
•Integrated power meter for all single-mode and multimode applications, such as
LAN, telecom, CATV and DWDM testing
•Included pocket-size visual fault locator to quickly locate bends, breaks and
damages in fiber
•Packaged in all-in-one portable organizer for essential fiber tools and includes
neck strap for hands-free operation
•Includes cleaning tools for both patch cord and bulkhead cleaning
•Modulation frequency detection lets users identify individual fibers at
specific tones
•Three-year calibration period
•Automatic wavelength detection (with JDSU optical light source)
FIBER ESSENTIALS TOOL KIT
Includes dual-mag FBP probe microscope and tips (SC and LC for UPC fiber),
FIT-HP2-60-P4 inspection and test system with 400X PCM, compact visual fault
locator, carrying case and batteries.
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
JDSU PR33634V2-248009.tif
FiberChek2 is an advanced application that determines the acceptability of optical
fiber end-faces through automated inspection and analysis. It identifies and
characterizes defects and contamination and determines their location relative to the
fiber core. It then provides a pass or fail result according to a preconfigured failure
criteria setting. The P5000 digital probe microscope connects directly to a PC or
laptop via a USB 2.0 connection, and the unique QuickCapture button lets users
capture, inspect and analyze a fiber end-face image in a single automated step.
Inspect before you connect.
FEATURES
•FiberChek2 software is preprogrammed to comply with International
Electrotechnical Commission (IEC) acceptance criteria standard (IEC
61300-3-35) for single-mode and multimode connectors
•Remove human subjectivity from fiber inspection and grading to ensure
consistent results
•Archive results and images as HTML or PDF files and generate integrated reports
•Plug it directly into PC/laptop via USB 2.0 connection
•Produces crisp, clear view of fiber end-face condition with high-resolution 5MP
camera and coaxial illumination
•Plug it directly into USB port on the TB4000 mainframe for automated pass/fail
of fiber cleanliness
Fiber Essentials Toolkit
Anixter No. Vendor No. Description
416164 FIT-S105-PRO Tool kit and inspection test system with
2in.screen
425443 FIT-S205-PRO Tool kit and inspection test system with
3.5 in. screen
For more information and part-number configurations such as additional
tips and adapters, contact your local sales office.
P5000 Digital Probe Microscope and FiberChek2
Anixter No. Vendor No. Description
441738 FBP-SD01 Digital fiber inspection probe microscope
(USB 2.0), FiberChek2 software,
interchangeable FBPT inspection tips (4) in
hard case, SC and LC bulkhead tips,
1.25 mm patch cord tips and hard-sided
carrying case
441803 FBP-P5000 Digital fiber inspection probe microscope
(USB 2.0), FiberChek2 software, FBPT
inspection tip, universal 2.5 mm patch
cord tip and hard-sided carrying case
14.30
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Fiber Optic
Test Equipment
D
Index1.Support and Supplies//Test Equipment//Accessories
JDSU PR33631V2-248015.tif
JDSU manufactures 300+ tips and adapters for any fiber optic type and connector
you need to inspect with probe microscopes for proper fiber care. JDSU supplies tips
for enterprise networks, carrier backbone networks, mobile backhaul networks, CATV,
FTTx, military/aerospace, ribbon fiber and backplane applications supporting the vast
majority of connector types in virtually any application. Tips and adapters are
available for both the patch cord (male) and bulkhead (female) portion of your fiber
connection. FBPT tips and FMAE adapters are for use with JDSU's FBP-P5 or
FBP-P5000 probe. Inspect before you connect.
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
JDSU PR33635V2-248006.tif
Whether installing or troubleshooting, the visual fault locator (VFL) is an essential
tool that quickly and easily locates problem areas in fiber cables. By pinpointing the
exact location of fiber damage, technicians can diagnose, troubleshoot and fix the
problem efficiently. JDSU offers two unique versions of the VFL that are economically
priced and ergonomically designed for comfortable handling and portability. The VFL
emits a bright red laser beam (Class II), making the light escaping from the damaged
fiber easily visible from a distance. The continuous/flash control button lets
operators choose between continuous or flashing illumination.
FEATURES
•Compact, ergonomic design for ultimate portability
•Visible wavelength is 650 nm
•High-powered laser (1 mW) for single-mode (> 7 km) and multimode
(> 5 km) connectors
•Continuous or flash illumination
•Universal connector interface for quick and easy connection
•2.5 mm connector input (1.25 mm adapter available)
•Includes soft-sided carrying case with belt loop
VISUAL FAULT LOCATOR
UNIVERSAL 1.25 MM ADAPTER
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
FLUKE NETWORKS PR67005V2-528616.tif
The OptiFiber Pro OTDR is the industry's first enterprise OTDR built from the ground up
to meet the challenges of enterprise fiber infrastructures. This fiber troubleshooting
and certification tool combines uncomplicated power with unparalleled efficiency
and the exact functions needed for troubleshooting or certifying campus, data center
and storage fiber networks. The OptiFiber Pro OTDR elevates fiber testing with the
industry's only smartphone user interface that turns any technician into a fiber
expert. The Fluke Networks DataCenter configuration eliminates uncertainty and
errors that occur when testing data center fiber. Its ultrashort dead zones enable
testing of fiber patch cords in virtualized data centers. These capabilities, plus the
fastest-in-the-industry trace times, make the OptiFiber Pro OTDR a must-have tool.
FEATURES
•Effectively test data center fiber with the least set up and trace time
•Troubleshoot data center fiber links where short patch cables and dense
connectors are common
Fiber Scope Tips and Adapters
Anixter No. Vendor No. Description
379493 FBPT-U12M Tip univ. 1.25 mm/UPC patch cord
441806 FBPT-FC Tip for FC/UPC bulkhead
441807 FBPT-FC-APC Tip for FC/APC bulkhead
441808 FBPT-LC Tip for LC/UPC bulkhead
441810 FBPT-SC Tip for SC/UPC bulkhead
441811 FBPT-SC-APC Tip for SC/APC bulkhead
441812 FBPT-ST Tip for ST/UPC bulkhead
441813 FBPT-MTP-L Tip MTP/UPC bulkhead long reach, X and Y
axis pan knob
441814 FBPT-MTPA-L Tip MTP/APC bulkhead long reach, X and Y
axis pan knob
441915 FBPT-U25M Tip univ. 2.50 mm/UPC patch cord
441917 FBPT-U25MA Tip univ. 12.50 mm/APC patch cord
For more information and additional part numbers,
contact your local sales office.
Visual Fault Locator
Anixter No. Vendor No. Description
416192 FFL-050 Pocket-size
441743 FFL-100 Ruggedized - with 1.25 mm adapter
Anixter No. Vendor No. Description
441744 FFL-U12 For FFL-100
441749 FFL-050-U12 For FFL-050
For more information and part-number configurations such as additional
tips and adapters, contact your local sales office.
OptiFiber Pro OTDR
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.31
Test Equipment
Fiber Optic
Test Equipment
•Maximize efficiency with a smartphone user interface that allows anyone to
perform expert fiber troubleshooting and certification
•Maximize return on investment by enabling customized user and project
folder capabilities
•Reduce network downtime by quickly and precisely identifying faults on
single-mode or multimode fiber
•Accelerate fiber certification with trace times as short as two seconds in Quick
Test mode
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
FLUKE NETWORKS PR28605V2-209675.tif
The DTX-CLT CertiFiber Optical Loss Test Set provides a complete Tier 1 fiber
certification (loss, length and polarity) solution for both multimode and single-mode
fiber. Leveraging the market-leading DTX CableAnalyzer interface, it performs easy
and quick validation of fiber link performance and installation quality, measurement
of optical loss at multiple wavelengths and polarity confirmation. It even measures
fiber length, eliminating the need for unreliable guesswork and estimation methods.
Cut testing time in half by testing two fibers in both directions at two wavelengths
without swapping main and remote units! Save, upload, manage and print
comprehensive certification reports using Fluke Networks' popular LinkWare
PC software.
FEATURES
•12-second Autotest - loss measurement of two fibers at two wavelengths,
optical link budget calculation and a PASS/FAIL analysis
•Optimized for applications ranging up to 10 Gig
•Interchangeable multimode and single-mode modules (which are also
compatible with the popular DTX CableAnalyzer)
•Accurate fiber length measurement - eliminate haphazard guessing
•Continuity and polarity verification
•Easy-to-use and widely recognized DTX-based interface
DTX-CLT CERTIFIBER OPTICAL LOSS TEST SET
SUPPORT
Anixter No. Vendor No. Description
463720 OFP-100-M OptiFiber Pro multimode OTDR for
troubleshooting and extended certification
463722 OFP-100-S OptiFiber Pro single-mode OTDR for
troubleshooting and extended certification
463718 OFP-100-Q OptiFiber Pro Quad OTDR for
troubleshooting and extended certification
463721 OFP-100-MI OptiFiber Pro multimode OTDR for
troubleshooting and extended
certification; includes fiber inspection kit
463723 OFP-100-SI OptiFiber Pro single-mode OTDR for
troubleshooting and extended
certification; includes fiber inspection kit
463719 OFP-100-QI OptiFiber Pro Quad OTDR for
troubleshooting and extended
certification; includes fiber inspection kit
DTX-CLT CertiFiber Optical Loss Test Set
Anixter No. Vendor No. Description
416002 DTX-CERTIFIBER-M Multimode DTX-CLT CertiFiber, includes
DTX-MFM2 and one set of 50 m SC/SC
test reference cords
416003 DTX-CERTIFIBER-S Single-mode DTX-CLT CertiFiber, includes
DTX-SFM2 and one of SM SC/SC test
reference cords
416004 DTX-CERTIFIBER-MS Multimode and single-mode DTX-CLT
CertiFiber, includes DTX-MFM2 and
DTX-SFM2 and one set each of 50 m and
SM SC/SC test reference cords
416005 DTX-CERTIFIBER/MU Replacement mainframe for
DTX-CLT CertiFiber
416006 DTX-CERTIFIBER/RU Replacement remote for DTX-CLT CertiFiber
Anixter No. Vendor No. Description
280633 GLD-DTX-FIBERMOD One-year Gold Support for DTX fiber
module set
485616 GLD-DTX-CRT One-year Gold Support for DTX-CLT
CertiFiber mainframe set
14.32
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Fiber Optic
Test Equipment
D
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
FLUKE NETWORKS PR33626V2-247671.tif
Whether you are troubleshooting FTTx, Hybrid Fiber Coax (HFC), fiber between Central
Offices or working on regional/rural access networks, Fiber OneShot PRO is your first
response to fiber trouble. The Fiber OneShot PRO analyzes fiber links and measures
faults up to 15 miles in less than five seconds. The one-button test feature means no
training and can cut the average job time by 30 percent. This new class of tester fills
the gap between a VFL and OTDR because it easily and quickly locates lossy
connections, high-loss faults and breaks in a single-mode fiber network.
FEATURES
•Measure up to 75,459 ft. (23,000 m) of fiber in seconds
•Locate severe bends, high-loss splices, breaks and dirty connectors in
single-mode fiber
•Save and store up to 99 test results for later review
•Confirm channel connectivity by analyzing the fiber link
•Locate sources of bit-error rates caused by end-face contamination or poor
connection leads
•Reports up to nine multiple events per fiber link
GOLD SUPPORT
Fiber OneShot PRO
Anixter No. Vendor No. Description
441397 FIBR-1-SHOTPRO Fiber OneShot PRO only - includes meter,
SC adapter, 22-language QRG on CD,
manual and batteries
441399 FIBR-1-KITPRO Fiber OneShot PRO-SC kit - includes meter,
SC adapter, UPC-UPC 2-meter patch cord,
holster, case, 22-language QRG on CD,
manual and batteries
441402 FIBR-1-KITPRO-VF Fiber OneShot PRO-SC kit with VisiFault -
includes meter, SC adapter, UPC-UPC 2 m
patch cord, holster, case, 22-language
QRG on CD, manual and batteries plus the
VisiFault visual fault locator with 2.5 mm
universal adapter
441404 FIBR-1-KITPRO-PM Fiber OneShot PRO-SC kit with SimpliFiber
Pro - includes meter, SC adapter, UPC-UPC
2 m patch cord, holster, case, 22-language
QRG on CD, manual and batteries plus
SimpliFiber Pro optical power meter and
SC adapter
441405 FIBR-1-KITPRO-VFPM Fiber OneShot PRO-SC kit with VisiFault
and SimpliFiber Pro - includes meter, SC
adapter, UPC-UPC 2 m patch cord, holster,
case, 22-language QRG on CD, manual and
batteries plus the VisiFault visual fault
locator with 2.5 mm universal adapter and
SimpliFiber Pro optical power meter and
SC adapter
411272 FIBR-1-SHOT Fiber OneShot optical test set, SC adapter,
holster, 22-language QRG on CD, manual
and batteries
411273 FIBR-1-KIT-VF Fiber OneShot optical test set, SC adapter,
UPC-APC, UPC-UPC 1 m launch cords,
holster, case, 22-language QRG on CD,
manual, batteries and VisiFault visual fault
locator with 2.5 mm universal adapter
411274 FIBR-1-KIT-PM Fiber OneShot optical test set, SC adapter,
UPC-APC, UPC-UPC 1 m launch cords,
holster, case, 22-language QRG on CD,
manual, batteries and SFPOWERMETER -
SimpliFiber Pro optical power meter, SC
adapter included
411276 FIBR-1-KIT-VFPM Fiber OneShot optical test set, SC adapter,
UPC-APC, UPC-UPC 1-meter launch cords,
holster, case, 22-language QRG on CD,
manual, batteries, VisiFault visual fault
locator with 2.5 mm universal adapter and
SFPOWERMETER - SimpliFiber Pro optical
power meter, SC adapter included
441930 FIBR-UPC-CORD-2M UPC-UPC patch cord, 2 meters
Anixter No. Vendor No. Description
447440 GLD-FOS-PRO One year of Gold Support for FIBR-1-KITPRO
or FIBR-1-KITPRO-VF
447441 GLD-FOS-MULTIKITS One year of Gold Support for
FIBR-1-KITPRO-PM or FIBR-1-KITPRO-VFPM
or LSPM
Anixter No. Vendor No. Description
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.33
Test Equipment
Fiber Optic
Test Equipment
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
FLUKE NETWORKS PR33643V2-248031.tif
The Fiber QuickMap is a new category of fiber troubleshooter for the enterprise,
quickly and efficiently locating connections and breaks in a multimode fiber network.
One button press and six seconds of test time lead to immediate visibility and
understanding of a multimode channel's links to identify any potential
problem areas.
FEATURES
•One-button troubleshooting - no lengthy setup necessary
•Six-second test time - no more blind troubleshooting that can last hours
•Locate multiple incidents - quickly see potentially problematic connections in
the channel
•Locate high-loss incidents or breaks - find the most common causes of
fiber failure
•Locate reflective incidents - discover causes of bit error rates, a primary source
of network degradation
GOLD SUPPORT
Fiber QuickMap Enterprise Fiber Troubleshooter
Anixter No. Vendor No. Description
441701 FQM-MAIN Fiber QuickMap mainframe with
carrying pouch
441702 FQM-KIT Fiber QuickMap kit with test reference
cords (50 and 62.5 m for both SC/SC
and SC/LC) and carrying pouch
441704 FTS900 Fiber QuickMap kit with test reference
cords (50 and 62.5 m for both SC/SC
and SC/LC), VisiFault visual fault locator
and carrying case
441705 FTS1000 Fiber QuickMap troubleshooter kit with
test reference cords (50 and 62.5 m for
both SC/SC and SC/LC), VisiFault visual
fault locator, SimpliFiber Pro power meter
and multimode source and carrying case
442403 FTS1100 Fiber QuickMap troubleshooter kit with
test reference cords (50 and 62.5 m for
both SC/SC and SC/LC), VisiFault visual
fault locator, SimpliFiber Pro power meter
and multimode source,
FT500 FiberInspector mini video
microscope and carrying case
Anixter No. Vendor No. Description
447443 GLD-FQM One year of Gold Support coverage for the
Fiber QuickMap kits: FQM-MAIN, FQM-KIT
or FTS900
447450 GLD-FQM-FTK One year of Gold Support coverage for the
Fiber QuickMap kits: FTS1000,
FTS1100 or FTS1100/E
14.34
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Fiber Optic
Test Equipment
D
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
FLUKE NETWORKS PR67006V2-528617.tif
MultiFiber Pro is the only fiber tester that tests MPO fiber trunks without the use of
fan-out cords, eliminates the complexity of polarity issues and makes cassette
testing in the field much easier.
Whether it is using 10 Gbps preterminated fiber trunks or planning for next-generation
40/100 Gbps performance, data centers are standardizing on an MPO connector
solution. Typical fiber installation means time-consuming, manual and imprecise MPO
validation. MultiFiber Pro is 90 percent faster than the single-fiber testing method
because it measures power loss and validates polarity on 12 fibers in a single
connector - reducing test time from weeks to days.
FEATURES
•Automatic scanning and testing of all fibers in MPO connectors
•Ensures correct end-to-end connectivity of MPO connectors with built-in
polarity verification
•On-board MPO connector so no fan-out cords are required when testing
fiber trunks
•Easy to interpret test result with a simple user interface that displays all
12 fibers
•Troubleshoots a single fiber by measuring loss of selective fiber within an
MPO trunk
•No dust caps to manage or lose with shuttered MPO connector
GOLD SUPPORT
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
FLUKE NETWORKS PR23101V2-157055.tif
With new, unique capabilities that simplify testing, the SimpliFiber Pro Optical Power
Meter and Fiber Test Kits are ideal for conducting first-line fiber cabling installation
or verification.
FEATURES
•Dual-wavelength testing - complete testing in half the time
•Additional wavelengths to include 1490 and 1625 - calibrated to extend from
typical enterprise wavelengths for broader applications
•Min./max. - precision tracking of intermittent power fluctuations, a superior
alternative to the inaccurate "wiggle" test
•CheckActive - audible tone and display icon alerts you to a live wire
•Saves 1,000 results - large internal memory enables continuous testing and
recording; fully compatible with the popular LinkWare cable
•Test management software
•Quickly locate cable fault, polarity and connector problems with VisiFault VFL*
•Inspect end-faces at 200x magnification with the FT120 FiberViewer or
FT500 FiberInspector Mini*
*Not available in all kit configurations
COMPLETE FIBER VERIFICATION KIT (FTK1450)
The complete fiber verification kit is for contractors and network technicians who
install and maintain premises networks with both multimode and single-mode
optical fiber. Use this kit to verify optical loss and power levels at 850, 1300, 1310,
1490, 1550 and 1625 nm, inspect fiber end-faces, locate cable faults, connector
problems and polarity issues. Kit combinations offer a variety of inspection options.
MultiFiber Power Meter and Fiber Test Kits
Anixter No. Vendor No. Description
480118 MFTK1200 MPO testing base kit includes MultiFiber
Pro power meter, 850 light source, test
cords, MPO adapters and carrying case
480119 MFTK1400 MPO testing and inspection kit includes
MFTK1200, FT600 FiberInspector Pro with
NF370 MPO tip
480120 MFPOWERMETER MultiFiber Pro optical power meter
480121 MFMULTIMODESOURCE MultiFiber Pro multimode 850 LED
light source
480129 TRC-MPO-PP-B 1 m test cord with MPO/MPO, pinned/
pinned, type B polarity
480130 TRC-MPO-UP-B 1 m test cord with MPO/MPO, unpinned/
pinned, type B polarity
480133 TRC-MPO-UU-B 0.3 m test cord with MPO/MPO, unpinned/
unpinned, type B polarity
480136 BKC-MPO-ULC 1 m breakout cord for MPO unpinned
LC connector
480137 BKC-MPO-USC 1 m breakout cord for MPO unpinned
SC connector
480138 ADP-MPO-B Type B polarity MPO adapter
Anixter No. Vendor No. Description
480140 GLD-MF One year of Gold Support
for MFPOWERMETER/MFMULTIMODESOURCE
480141 GLD-MFTK One year of Gold Support for
MFTK1200 or MFTK1400
SimpliFiber Pro Optical Power Meter and Fiber Test Kits
Anixter No. Vendor No. Description
381298 FTK1450 Includes SimpliFiber Pro power meter,
850/1300 and 1310/1500 sources (SC
port), two FindFiber remote ID sources,
FT500 FiberViewer video microscope,
VisiFault VFL, LC and ST adapters,
NFC-KIT-BOX cleaning equipment and
carrying case
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.35
Test Equipment
Fiber Optic
Test Equipment
FULL-FEATURED INSPECTION AND MULTIMODE VERIFICATION KITS
(FTK1300 AND FTK1350)
The full-featured inspection and multimode verification kits are for contractors and
network technicians who install and maintain multimode premises networks. Use
these kits to verify optical loss and power levels at 850 and 1300 nm, inspect fiber
end-faces, locate cable faults, connector problems and polarity issues. Kit
combinations offer a variety of inspection options.
BASIC VERIFICATION KITS (FTK1000-MM, FTK2000-SM AND FTK2100)
The basic verification kits are great starter kits for contractors and network
technicians who install and maintain fiber links. Available in single-mode or
multimode configurations, quickly verify optical loss and power levels at 850 and
1300 nm or 1310 and 1550 nm. Add additional sources, microscopes and VFL
options as needed.
FIBERINSPECTOR MINI AND CLEANING KIT (FT525)
Choose this option if you are installing and maintaining any fiber optics network.
Everyone using fiber optics needs to be inspecting and cleaning ports and end-faces
prior to mating for top network performance.
SIMPLIFIBER PRO
GOLD SUPPORT
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
FLUKE NETWORKS PR9793V2-22987.tif
The FiberInspector video microscope enables inspection of end-faces on all types of
installed fiber. In a survey commissioned by Fluke Networks, end-face contamination
was found to be the leading cause of fiber failures. By inspecting end-faces before
mating, this common problem can be prevented.
The portable video microscope projects a crisp, clear image of microscopic debris and
end-face damage on both patch cords and inside ports. Quickly determine whether
fiber connectors on a hardware device are clean and in good condition without
disassembling the device.
The FiberInspector Mini is exceptionally convenient while the full-featured Pro excels
with its larger screen, rugged boot and wide array of adapter tips.
FEATURES
•Inspect all types of installed fiber to prevent the #1 cause of fiber failure
•Quickly determines whether fiber connectors on a hardware device are clean
and in good condition without disassembling the device
•Contains high-magnification optics that provide crisp, clear images of
microscopic debris and end-face damage
•The exceptionally convenient FiberInspector Mini uses a 200x magnification
probe sufficient for inspecting both multimode and single-mode fiber
•The full-featured FiberInspector Pro excels with its dual-magnification (250x/
400x) probe, large 3.5 in. screen, rugged boot and wide array of adapter tips
Anixter No. Vendor No. Description
381296 FTK1300 Full-featured verification kit with
FiberViewer. Includes SimpliFiber Pro
power meter, 850/1300 source (SC port),
FindFiber remote ID source,
FT120 FiberViewer optical microscope,
VisiFault VFL, LC and ST adapters and
carrying case
381297 FTK1350 Full-featured verification kit with
FiberInspector Mini. Includes SimpliFiber
Pro power meter, 850/1300 source (SC
port), FindFiber remote ID source,
FT120 FiberViewer optical microscope,
VisiFault VFL, LC and ST adapters and
carrying case
Anixter No. Vendor No. Description
381295 FTK1000 Basic verification kit (multimode).
Includes SimpliFiber Pro power meter,
850/1300 multimode source (SC port) and
carrying case
381299 FTK2000 Basic verification kit (single-mode).
Includes SimpliFiber Pro power meter,
1310/1550 single-mode source (SC port)
and carrying case
433245 FTK2100 Basic verification kit (SFPOWERMETER,
SFSINGLEMODESOURCE,
SFSINGLEMODE2 with case)
Anixter No. Vendor No. Description
358648 FT525 FiberInspector Mini video microscope and
cleaning kit case
Anixter No. Vendor No. Description
381294 SFPOWERMETER SimpliFiber Pro power meter with SC
adapter, carrying pouch
381993 SFSINGLEMODESOURCE SimpliFiber Pro single-mode 1310/
1500 source with SC port, carrying pouch
433244 SFSINGLEMODE2 SimpliFiber Pro single-mode 1490/
1625 source
381994 FINDFIBER FindFiber remote ID source with SC port,
carrying pouch
381995 FINDFIBER-6 Set of six FindFiber remote ID sources,
carrying pouch
Anixter No. Vendor No. Description
447442 GLD-SFPRO One year of Gold Support for the
SimpliFiber Pro devices and test kits:
SFPOWERMETER, FTK1000 or FTK2000
368639 GLD-FTK One year of Gold Support for SimpliFiber
Pro Fiber Test Kits - Models: FTK1350,
FTK1450 or FTK2100
FiberInspector Pro
Anixter No. Vendor No. Description
Continued on next page >>
14.36
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Fiber Optic
Test Equipment
D
(continued)
FiberInspector Pro
ACCESSORIES
GOLD SUPERVISION SUPPORT
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
FLUKE NETWORKS PR9794V2-22990.tif
The laser-powered VisiFault visual fault locator (VFL) traces fibers, verifies continuity
and polarity, and helps find breaks in cables, connectors and splices. Ruggedly
constructed for demanding field-testing and includes a long battery life for hours
of use.
FEATURES
•Bright-red visible laser light source
•Accelerates end-to-end fiber continuity checks
•Speeds fiber tracing and identification
•Simplifies fiber-polarity verification
•Aids in location of fiber faults including tight bends, breaks and bad connectors
•Features continuous and flashing modes
•Rugged case survives drops, impacts and vibrations
•Connects to 2.5 mm standard and 1.25 mm SFF connectors
•Over 40-hour battery life with two AA batteries
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
FLUKE NETWORKS PR10770V2-10893.tif
To ensure your termination is smooth, clean and ready for optical transmission.
Rugged microscope with LED illumination available with either 200x or
400x magnification.
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
IDEAL INDUSTRIES PR23119V2-160773.tif
Designed with installers in mind, the 33-960 Micro OTDR offers excellent
performance and ease of use in a truly handheld, lightweight and rugged package. It
is ideally suited for the installation and troubleshooting of LAN, campus and WAN
fiber networks. It combines high measurement precision with the user-friendliness of
one-button operation resulting in accurate characterization of connectors and splices
in addition to fast and reliable fault location. With the Macro Bend detector (MB)
option, this OTDR provides a clear pass/fail indication for every link without the
cumbersome manual evaluation of traces. This benefits less-experienced users by
providing clear decision points on whether a line is good or bad.
33-960 SERIES MICRO OTDRS
Anixter No. Vendor No. Description
343307. FT500 FiberInspector Mini video microscope
283138. FT600 FiberInspector Pro video microscope
358648. FT525 FiberInspector Mini video microscope and
cleaning kit case
255469. OFTM-5352 FiberInspector Pro for OptiFiber
certifying OTDR
299602. OPV-FT600 OptiView fiber inspector
Anixter No. Vendor No. Description
239051 NF362 LC video probe adapter tip
261741 NF364 MU video probe adapter tip
283139 NF366 E2000 video probe adapter tip
335848 NF368 1.25 mm universal video probe adapter tip
for male ends
341449 NF370 MTP/MPO video probe adapter tip
356762 NF395 APC video probe adapter tip for use
with FT600
343308 NFM110 Accessory tip set for FiberInspector Mini
(LC, FC and 1.25 mm)
356763 NF390 APC adapter tip for use with FT500
Anixter No. Vendor No. Description
283140 GLD-FTINSPECTOR FiberInspector Pro Gold Support for
one year
VisiFault Visual Fault Locator (VFL)
Anixter No. Vendor No. Description
283141 VISIFAULT VisiFault visual fault locator with 2.5 mm
universal adapter
283142 NF380 Universal adapter for connectors with
1.25 mm ferrules
Fiber Viewers
Anixter No. Vendor No. Description
222056 FT120 FiberViewer 200x
222057 FT140 FiberViewer 400x
33-960 Series Micro OTDRs
Anixter No. Vendor No. Description
388800 33-960-30 Quad OTDR with 850/1300/1310/
1550 nm
388823 33-960-30MB OTDR kit with Tier 2 certification option
and Macro Bend detection, with 850/
1300/1310/1550 nm
393009 33-960-VP Video probe with 200x and
400x magnifications
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.37
Test Equipment
Fiber Optic
Test Equipment
ACCESSORIES
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
IDEAL INDUSTRIES PR10777V2-12102.tif
The economical, redesigned VFF5 visual fault finder is a light source used to locate
breaks and misconnections in fiber optic cables. A handheld battery-powered tool,
the VFF5 projects highly visible red light into a fiber optic cable. The VFF5 is equipped
with a high-power, extra-long-life laser which operates either in continuous (CW) or
modulated mode up to 3 km (2.3 miles) into multimode fiber and 4 km (2.5 miles)
into single-mode fiber.
FEATURES
•Finds breaks, faulty splices and crimps, poor components or connections
•Low-cost, basic fiber test tool
•Slim pocket-size tool (8.7 inch length)
•High-output, Class 2, 650 nm laser diode
•Includes carrying case, lens cap, batteries, lanyard and instruction book
•Rugged new metal body case design with protective Santoprene oversleeve
•Battery powered with improved battery life up to 80 hours in continuous mode
•Universal connector to support ST, SC and FC interface without
additional adapters
•Improved mechanical design: resists water, improves grip and prevents rolling
•Improved carrying options: nylon holster and integrated swivel belt-clip
-
Index1.Support and Supplies//Tools//Termination Equipment
COMMSCOPE SYSTIMAX SOLUTIONS
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
GREENLEE PR11998V2-21766.tif
These conveniently packaged test sets are used to test, troubleshoot and maintain
telco, CATV, LAN and other single-mode/multimode network applications.
FEATURES
•Insertion loss test set for multimode fiber
•850/1300 nm loss measurements
•Connector for FC, SC or ST
•Rugged package design
•Easy-to-use portable package
•Economically priced
Index1.Support and Supplies//Test Equipment//Fiber Optic Applications
GREENLEE PR11997V2-21769.tif
Designed for the technician to perform installation and maintenance measurements
on fiber optic cabling networks.
FEATURES
•Insertion loss test set for multimode fiber
•850/1300 nm loss measurements
•Connector for FC, SC or ST
•Rugged package design
•Easy-to-use portable package
•Economically priced
Anixter No. Vendor No. Description
393010 1912-00-1621 Cleaning kit
393011 33-960-BP Rechargeable battery
393012 33-960-KB Foldable USB keyboard
393014 33-961-10 Adapter for FC connectors
393016 33-961-20 Adapter for SC connectors
393017 33-961-30 Adapter for ST connectors
393019 33-961-40 Adapter for E2000 connectors
393020 33-961-50 Adapter for DIN 47256 connectors
393022 33-961-60 Adapter for HMS-10/AG connectors
VFF5 Visual Fault Finder
Anixter No. Vendor No. Description
198871 VFF5 Visual fault finder, 650nm redlaser
Microscope
Anixter No. Description Material ID
182430 Microscope - 100x, with LC adapter 700005887
266003 300B microscope 700008063
Multimode and Single-mode Fiber Optic Test Set
Anixter No. Vendor No. Description
329075 5890-FC With FC connector
329076 5890-SC With SC connector
329077 5890-ST With ST connector
Multimode Fiber Optic Test Set
Anixter No. Vendor No. Description
327977 5670-FC With FC connector
327978 5670-SC With SC connector
327979 5670-ST With ST connector
14.38
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Telecom
Test Equipment
D
./-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
GREENLEE pr5379V2-20179.tif
Performs the patented Stress Test which reads audible noise produced on a faulted
pair that is stressed by a 90 dBrnC excitation. This identifies DC resistive or
capacitive imbalances. The patented Leakage Test detects intermittent faults that do
not appear under normal VOM tests by using 135 V to "punch through" the oxide layer
and reveal a cable fault. The Sidekick Plus includes an RFL and TDR.
FEATURES
•Measures resistance, AC/DC and capacitive kick
•Provides tone for twisted-pair or crossed-conductor identification
•Single setup for testing Tip-Ring, Tip-Ground and Ring-Ground
•Tests loop current, circuit loss, metallic noise, power influence and load
coil detection
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
GREENLEE PR10740V2-11153.tif
The Sidekick 7B determines the stressed noise susceptibility of dry and
working pairs.
FEATURES
•Measures resistance, AC/DC and capacitive kick
•Provides tone for twisted-pair or crossed-conductor identification
•Single setup for testing Tip-Ring, Tip-Ground and Ring-Ground
•Minimal drying effect in all ranges
•Field replacement leads
•Soft case with adjustable strand hook
•Low-battery indicator light
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
GREENLEE PR6777V2-20212.TIF
The Model 88 Load Coil Detector is designed for use on telephone cable by
outside-plant or central-office personnel. Allows telephone personnel to quickly and
easily indicate the presence and number of load coils (up to four) on an active or
dead cable pair. The detector is lightweight and uses one 9 V battery.
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR67007V2-528618.tif
The innovative TS54 TDR (time domain reflectometer) is perfect for voice, data and
video technicians and communications service provider technicians who need a
best-in-class test set. There's nothing else like the TS54 TDR on the market today. No
longer will you need to carry a separate TDR, toner, pair identifier - everything you
need is in one newly redesigned and compact test set - that's a 62 percent weight
reduction and a 20 percent cost reduction over existing products.
The TS54 TDR delivers 20 percent more extreme weather protection with the latest
advancements to our patented RainSafe, DropSafe and DataSafe technology. This
means the TS54 TDR is weatherproof and rugged and able to butt in on live DSL lines
to test POTS quality without crashing data service.
FEATURES
•TDR - find cable length measurement and locate faults on virtually all types of
cable including twisted pair, coaxial and parallel conductors
•Toner - five separate tones for fast and easy differentiation between multiple
wire pairs
•SmartTone - short the correct pair and tone changes for exact pair identification
•Additional key testing functions include:
- Data indication - warns when data is present on the line
- Voltage indication/measurement - identifies potential line problems
- Current (mA) indication/measurement - verifies sufficient line current
- Caller ID with call waiting - verifies functional service
- DTMF digit grabbing - isolates faulty customer premise equipment
Sidekick T&N Telecom Tester
Anixter No. Vendor No. Description
228443 1137-5002 Sidekick T&N
331439 1155-5000 Sidekick Plus
Sidekick 7B Telecom Tester
Anixter No. Vendor No. Description
257835 1134-5029 Sidekick 7B
Load Coil Detector
Anixter No. Vendor No. Description
102679 88 Load coil detector
TS54 TDR
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.39
Test Equipment
Telecom
Test Equipment
- Detects dial tone, places and receives calls
-Polarity
•DropSafe PRO - passed 20-foot drop test onto concrete
•RainSafe PRO - protection for extreme weather conditions
•DataSafe PRO - prevents disruption of data transmission on the line
•High-visibility keypad with glow-in-the-dark keys for any outside
plant environment
•Extra-large, backlit LCD screen
•Familiar, cell phone-like menu and user interface
•Two-way, hands-free speakerphone
•Optional headset
ACCESSORIES
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR67008V2-528619.tif
The TS53 PRO is a professional network test set. It delivers voice, data and video
technicians and communications service provider technicians all the functionality
needed in one telephone test set. The advanced TS53 PRO performs seven essential
tests and contains all the latest advancements to our patented RainSafe, DropSafe
and DataSafe technology all in our newly designed, ruggedly built case.
FEATURES
•Data indication - warns when data is present
•Voltage indication/measurement - identifies potential line problems
•Current (mA) indication/measurement - verifies sufficient line current
•Caller ID with call waiting - verifies functional service
•DTMF digit grabbing - isolates faulty customer premise equipment
•Detects dial tone, places and receives calls
•Polarity
•DropSafe PRO - passed 20-foot drop test onto concrete
•RainSafe PRO - protection for extreme weather conditions
•DataSafe PRO - prevents disruption of data transmission on the line
•High-visibility keypad with glow-in-the dark keys for any outside
plant environment
•Extra-large, backlit LCD screen
•Familiar, cell phone-like menu and user interface
•Two-way, hands-free speakerphone
•Low battery and mute indication
•Optional headset
ACCESSORIES
Anixter No. Vendor No. Description
478776 TS54-A-09-TDR Test set + TDR, ABN with piercing pin
478785 TS54-BANA Test set + TDR, 4 mm banana, extra-large
alligator clips, test probe
Anixter No. Vendor No. Description
485665 BELTCLIP-TS Belt clip
485667 LEAD-PIRC-PIN Test leads with piercing pin clips
485668 LEAD-CO-346A Test leads with a 346A plug for the
central office
485669 LEAD-ABN-PPIN Test leads with angled bed-of-nails (ABN)
and piercing pin clips
485671 LEAD-ALIG-CLP Test leads with alligator clips
485672 LEAD-ABNPRJ11 Test leads with an RJ11 plug, angled
bed-of-nails (ABN) and piercing pin clips
485674 LEAD-BANA-CLP Test leads with a 4 mm banana plug,
alligator clips and test probe
485676 HEADSET-TS Headset
TS53 PRO
Anixter No. Vendor No. Description
478777 TS53-A-09 TS53, ABN with piercing pin
478778 TS53-P-01 TS53, piercing pin
478780 TS53-AR-09 TS53, ABN with piercing pinand RJ11
478781 TS53-C-04 TS53, Central Office (CO) 346A plug
478784 TS53-BANA TS53, 4 mm banana and extra-large
alligator clips and test probe
Anixter No. Vendor No. Description
485665 BELTCLIP-TS Belt clip
485667 LEAD-PIRC-PIN Test leads with piercing pin clips
485668 LEAD-CO-346A Test leads with a 346A plug for the
central office
485669 LEAD-ABN-PPIN Test leads with angled bed-of-nails (ABN)
and piercing pin clips
485671 LEAD-ALIG-CLP Test leads with alligator clips
485672 LEAD-ABNPRJ11 Test leads with an RJ11 plug, angled
bed-of-nails (ABN) and piercing pin clips
485674 LEAD-BANA-CLP Test leads with a 4 mm banana plug,
alligator clips and test probe
485676 HEADSET-TS Headset
14.40
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Telecom
Test Equipment
D
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR23527V2-165716.tif
Fluke Networks' new TS52 PRO Caller ID test set features the latest in test-set
technology. Designed with a superior, radiant liquid crystal display (LCD) user
interface, it allows you to see what cannot be heard in any outside-plant
environment. The backlit LCD and phosphorescent (glow-in-the-dark) keypad brings
light to even the darkest of work environments.
FEATURES
•DataSafe Pro - superior high-impedance monitoring, lockout and override,
making you completely safe in any mode
•Display - backlit LCD and glow-in-the-the dark keypad
•DropSafe - passes 20 foot drop test
•DSL/POTS filtering technology - allows technicians to clip on a live DSL line to
test POTS service without downing or disrupting data service
•RainSafe - designed for use in rain conditions
FUNCTION
Data indication - warns when data is present
Voltage indication - troubleshooting feature to identify potential line problems
Current (mA) indication - verifies sufficient line current
Caller-ID - verifies service is functional
DTMF digit grabbing - isolate faulty customer premise equipment
Two-way hands-free speakerphone - for true hands-free conversation
-
Index1.Support and Supplies//Test Equipment//Data Applications
FLUKE NETWORKS PR21918V2-127123.tif
The TS44 PRO Test Set is equipped with new DataSafe PRO Data Protection Technology,
high-impedance monitoring, data lockout and lockout override, making you safe in
Talk, Monitor or Override mode. Filtering technology allows the technician to draw dial
tone on a live DSL/POTS shared line to test the POTS service while protecting the DSL.
Features include a two-way hands-free amplified speakerphone; advanced testing
functions include low/high voltage and low (mA) current results displayed on an
easy-to-read LED.
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR21919V2-127119.tif
The TS42DLX test set includes a new ergonomic design, waterproof, DropSafe
durability and a three-year warranty. Features a two-way, hands-free amplified
speakerphone for true hands-free conversation. Advanced testing functions for low-/
high-voltage and low-current (mA) detection are displayed in easy-to-read LEDs.
TS52 PRO Test Set
Anixter No. Vendor No. Description
392770 52801009 TS52 PRO test set with angled
bed-of-nails, cord with piercing pin
392771 52801004 TS52 PRO test set, CO with 346A plug
392769 52801001 TS52 PRO test set with piercing pin cord
392772 52801RJ9 TS52 PRO test set with angled
bed-of-nails, cord with piercing pin and
RJ11 plug
TS44 PRO Test Set
Anixter No. Vendor No. Description
360158 50801001 TS44 PRO test set with piercing pin only
360159 50801009 TS44 PRO test set with ABN
360160 50801004 TS44 PRO test set with 346A plug
360161 50801RJ9 TS44 PRO test set with ABN and RJ11 plug
TS42 Deluxe Test Set
Anixter No. Vendor No. Description
249196 42801009 TS42DLX with ABN
311950 42801004 TS42DLX with 346A plug
305963 42801001 TS42DLX with piercing pin clips
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.41
Test Equipment
Telecom
Test Equipment
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR10716V2-11246.tif
The new test set includes multiple testing features including data lockout and lockout
override, making you completely safe in talk or monitor mode. The DSL/POTS filtering
technology allows you to safely draw dial tone without downing DSL. A built-in tone
generator simplifies wire identification with a probe. An amplified speaker makes
monitoring the line hands-free, so you can keep working. The Talk Battery function
provides voltage to carry voice conversation on nonpowered pairs. All in a compact
unit with an oversize robust liquid crystal display (LCD) that makes the intuitive,
common-sense menus easy to read and use.
FEATURES
•One-way speakerphone; kit includes earpiece, making the set hands-free
•Caller ID and call waiting Caller ID
•Data lockout detection
•Tone generator
•Continuity test for detecting shorts
•Phonebook
•DTMF digit grabbing to test other equipment for proper DTMF generation
•Row/column tones for single-tone dialing
•High- and low-voltage lockout
•Low-/high-voltage indication digital readout
•Low-current (mA) indication digital readout
•Overvoltage and overcurrent protection
•Selectable flash and pause duration
•Selectable timeouts to save batteries
•Speed dial (10 memories, 23 digits each)
•Battery-level indicator
•ADSL safe
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR10717V2-11249.tif
With its high-impedance monitor for DataSafe operation, technicians can clip onto a
line in monitor mode, without disrupting data.
FEATURES
•New ergonomic design
•DropSafe reliability - passes 20 foot drop test
•RainSafe protection and weatherproof in severe weather conditions
•Hook-flash button
•Mute switch
•Last-number redial
•Audible ringer for callbacks
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR67009V2-528620.tif
The TS23 PRO gives voice, data and video technicians and communications service
provider technicians all the functionality needed in a telephone test set while offering
unbeatable reliability, durability and expanded utility. The TS23 PRO performs four
essential tests and includes RainSafe, DropSafe and DataSafe technology all in a
newly designed, ruggedly built case.
Four testing functions include:
- Voltage indication - identifies potential line problems
- Current (mA) indication/measurement - verifies sufficient line current
- Detects dial tone, places and receives calls
- Polarity
- DropSafe PRO - passed 20-foot drop test onto concrete
- RainSafe PRO - protection for extreme weather conditions
- DataSafe PRO - prevents disruption of data transmission on the line
TS25D Test Set with LCD Kit
Anixter No. Vendor No. Description
262444 25501109 TS25D test set with ABN (includes pouch
and earpiece)
262443 25501009 TS25D test set with ABN
TS30 Analog Test Set
Anixter No. Vendor No. Description
210860 30800001 TS30 test set with piercing pin clips
196269 30800009 TS30 test set with ABN
TS23 PRO
Continued on next page >>
14.42
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Telecom
Test Equipment
D
(continued)
TS23 PRO
FEATURES
•Two-way, hands-free speakerphone
•Low battery and mute indication
•Optional headset
TS23 PRO TEST SET
ACCESSORIES
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR10718V2-11252.tif
The TS22 test set's unique built-in amplified speaker provides three audio levels for
hands-free listening and use with automated voice response systems. The TS22 unit
offers a combination of reliability, durability and expanded utility.
FEATURES
•Amplified speaker for hands-free monitoring
•DropSafe reliability - passes 20 foot drop test
•RainSafe protection in severe weather conditions
•PBX pause button and mute switch
•Stores nine 18-digit numbers in repertory dialer (speed dialing)
•Last-number redial
•Audible ringer for callbacks
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR20277V2-71127.tif
The TS19 test set combines all the basic test-set features. Its high-impedance
monitor prevents accidental disruption of service from clipping onto a data line while
in monitor mode, thus ensuring the integrity of critical data lines.
FEATURES
•Tone/pulse operation
•Last-number redial
•Spring-loaded field-replaceable belt clip
•Polarity indication in talk mode
•Two monitor modes
•High-impedance and ringing indication
•Additional line cords available, sold separately
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR67009V2-528620.tif
The new TS100 PRO cable fault finder with PowerBT bridge tap detect not only
provides open/short circuit detection - to 8,000 feet (2.4 kilometers) - but is also a
telecom technician's first line of defense against bridge taps. Because bridge taps
are a significant source of DSL network performance problems, they need to be
identified and fixed quickly before causing customer attrition. This five-in-one tool is
so affordable every technician can have one.
Anixter No. Vendor No. Description
478787 TS23-A-09 Includes ABN with piercing pin
478788 TS23-P-01 With piercing pin
478790 TS23-AR-09 Includes ABN with piercing pin and
RJ11 plug
478783 TS23-BANA With 4 mm banana and extra-large
alligator clips
Anixter No. Vendor No. Description
485665 BELTCLIP-TS Belt clip
485667 LEAD-PIRC-PIN Test leads with piercing pin clips
485668 LEAD-CO-346A Test leads with a 346A plug for the
central office
485669 LEAD-ABN-PPIN Test leads with angled bed-of-nails (ABN)
and piercing pin clips
485671 LEAD-ALIG-CLP Test leads with alligator clips
485672 LEAD-ABNPRJ11 Test leads with an RJ11 plug, angled
bed-of-nails (ABN) and piercing pin clips
485674 LEAD-BANA-CLP Test leads with a 4 mm banana plug,
alligator clips and test probe
485676 HEADSET-TS Headset
TS22 Series Analog Test Sets
Anixter No. Vendor No. Description
097795 22800001 TS22 with piercing pin clip
097790 22800009 TS22 with ABN
097792 22800007 TS22 with ground start cord, basic
analog set
TS19 Analog Test Set
Anixter No. Vendor No. Description
153534 19800009 TS19 with ABN
138370 19800003 TS19 with banana jacks and alligator clips
TS100 PRO
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.43
Test Equipment
Telecom
Test Equipment
FEATURES
•Bridge tap detection for xDSL pre-qualification
- Reports distance to bridge taps up to 3,200 feet (975 meters)
- Find multiple bridge taps and their length
- Sees past bridge taps to the end of the cable
•Long-distance tester - tests opens and shorts up to 8,000 feet (2.4 kilometers)
•Patented SmartTone tone generator with five different tones for exact
pair identification
•Built-in TDR (time domain reflectometer)
•AC/DC voltage detection
•One-button testing
•Built-in toner
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
GREENLEE pr5371V2-20167.tif
The PE900 Series telephone test sets are waterproof-tested to an IEC IP67 rating. The
PE961 features the DigAlert overvoltage alarm and lockout function to eliminate the
danger of damaging or knocking out digital service lines. The new PE961 provides full
ADSL compatibility.
FEATURES
•10-number speed-dial memory (32 digits each)
•Last-number redial
•Precise hook flash
•Microphone mute
•Audible and visual mode indicators
•Polarity test in any mode
•Unique quick-release belt clip
•Premium cordset with bed-of-nails and piercing pin clips
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
GREENLEE PR67200V2-529259.tif
The TM500 is an affordable solution for technicians needing to troubleshoot
communications circuits. The TM700 adds Caller ID, call waiting and multilanguage
display and displays line current and voltage.
FEATURES
•Headset included for hands-free operation
•Luminescent (glow-in-the-dark) keypad
•Can be used safely on a DSL-enabled line
•Overvoltage and overcurrent protection
•High-impedance monitor for monitoring line without disrupting existing traffic
•Adjustable volume control plus mute
•Polarity test with LED indicator
•10-number speed dial
•32-digit last number redial and pause
•Flash to generate a timed break call
•Line powered; no battery needed
•RJ11 socket
Anixter No. Vendor No. Description
453403 TS100-PRO-BT-TDR TS100 PRO cable fault finder TDR kit with
bridged tap detect
453756 LEAD-ABNP-100 Test lead with angled-bed-of-nails and
piercing pin. Compatible with the
TS100 and TS100 PRO
453757 CASE-TS100 TS100/TS100 PRO pouch with Fluke
Networks' logo
453758 LEAD-ALIG-100 Test lead with alligator clips. Compatible
with the TS100 and TS100 PRO
453759 LEAD-ABN-100 Test lead with angled-bed-of-nails.
Compatible with the TS100 and TS100 PRO
PE900 Series Test Sets
Anixter No. Vendor No. Description
247474 PE930 Adjustable ringer, red
238785 PE945 Two-way hands-free, green
244839 PE961 Two-way hands-free, DigAlert Lockout,
ADSL compatibility
Tele-Mate Test Set
Anixter No. Vendor No. Description
461179 TM500 Tele-Mate telephone test set with ABN
"bed-of-nails" croc clips
461180 TM700 Tele-Mate Pro test set with ABN angled
"bed-of-nails" croc clips
14.44
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Telecom
Test Equipment
D
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR20276V2-71124.tif
These modular adapters provide a quick connect to modular telephone jacks using
any standard butt-in test set.
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR20275V2-71121.tif
The In-line Modular Adapter permits testing on working lines without disrupting
service and helps determine whether the trouble is in the phone or in the line. This
unit works like the Fluke Networks standard modular adapter, but has the added
feature of replaceable test leads.
FEATURES
•Rugged design
•Slanted clips to prevent butt-set clips from disconnecting from the banjo
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
INDEPENDENT TECHNOLOGIES PR7104V2-141624.tif
A pencil-sized test device for testing analog telephone lines at the connecting block
or network interface. This device will check for open line, polarity, AC voltage and
dead line. On digital lines, it may or may not show voltage present.
Standard Modular Adapter
Anixter No. Vendor No. Description
041274 10113000 Standard modular adapter
In-line Modular Adapters
Anixter No. Vendor No. Description
136767 10210100 4-wire in-line modular adapter
249072 10210101 4-wire in-line modular adapter with K-plug
136768 10220100 6-wire in-line modular adapter
249073 10220101 6-wire in-line modular adapter with K-plug
136769 10230100 8-wire in-line modular adapter
249074 10230101 8-wire in-line modular adapter with K-plug
136745 10200000 Replacement modular cord (4 and 6)
136746 10300000 Replacement modular cord (8)
Telephone Line Tester
Anixter No. Vendor No. Description
102617 3003 Telephone line tester
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.45
Test Equipment
T1/WAN Analysis
Test Equipment
./-
Index1.Support and Supplies//Test Equipment//Data Applications
JDSU PR33633V2-248013.tif
The T-BERD/MTS-6000A with the Multiservices Application Module (MSAM) provides
the industry's most compact and modular multifunction, multilayer DS1 to 10-Gigabit
tester for designing, installing and maintaining carrier-grade networks. The MSAM
enables a highly portable test set with the versatility needed to support Ethernet
Layers 2-7, SONET/SDH, DSx/PDH, OTN, datacom and Fibre Channel in one platform.
With testing capabilities designed for Ethernet Backhaul, Metro Core telecom
networks, cable provider switch centers, government telecommunications centers
and providers labs, the MSAM is the latest innovation for the award-winning,
industry-leading T-BERD/ MTS family of test solutions.
FEATURES
•Layer 2 through Layer 4 comprehensive 10-stream Ethernet testing, enabling
service activation and application performance modeling for quality of
service verification
•Enhanced RFC2544 tests includes frame delay variation, asymmetric rates and
concurrent results to reduce overall testing time
•OTN testing supported from OTU1 to OTU2e, including SDH and Ethernet clients
•Fibre Channel support includes automated RFC-like scripting test,
buffer-to-buffer control verification, FC port and fabric login
•Modular form-factor enables field expandability of test capabilities by adding
modules and software test options
•Simultaneous Ethernet, Fibre Channel, and SONET/SDH/ PDH testing from
10 Mbps to 10 Gbps
•Options available for Datacom testing for EIA-530, EIA-530A, RS-449/V.36,
RS-232/V.24, X.21, V.35, MIL-188C and conditioned diphase serial interfaces
OPTIONS
-
Index1.Support and Supplies//Test Equipment//Digital Transmission
JDSU PR33741V2-249108.tif
The T-BERD/MTS-5800 handheld network tester is the industry's smallest 10G
handheld instrument and supports testing throughout the entire service network life
cycle, including installation, troubleshooting and maintenance. It is designed for field
technicians who must verify network configurations, including network transparency,
tunneling, and Ethernet OAM designs, as well as ensuring end-customer service level
agreements (SLAs). Integrated J-Complete functionality, such as capture/decode and
automated J-Mentor, helps field technicians perform guided troubleshooting without
having to carry a separate analyzer instrument.
The T-BERD/MTS-5800 is a cost-effective field instrument that not only covers your
test needs of today but also supports the cutting-edge technologies of tomorrow,
namely Synchronous Ethernet and 1588v2 PTP.
FEATURES
•Handheld instrument that supports 10G Ethernet, SONET/SDH and PDH testing
with fixed interfaces
•Dual-port operation enables performing two tests simultaneously
•Rapid boot-up from power on to start of test
•Wi-Fi for test set connectivity and remote control with VNC
•FiberScope connectivity
•Enhanced RFC 2544, including frame delay variation, asymmetric rates and
concurrent results to reduce overall test time
•Carrier Ethernet testing with link and service OAM (Y.1731), PBB/PBT, MPLS/
VPLS, MPLS-TP, VLAN, Q-in-Q and J-Proof Ethernet transparency
•Verify Ethernet synchronization using 1588v2 PTP or G.826x-based
Synchronous Ethernet
T-BERD/MTS-6000A with Multiservices Application Module MSAM
for Transport Testing
Anixter No. Vendor No. Description
441902 TB6000A-1G-10GE-DP TB6000A 10/100/1000M, GigE, 10GE
dual-port package
441903 TB6000A-DC TB6000A datacom package
441904 TB6000A-DS3-GIGE-DP TB6000A DS-STS1 and GigE
dual-port package
441905 TB6000A-GIGECU-DC TB6000A 10/100/1000M Ethernet and
datacom package
441906 TB6000A-OC12-GIGE-DP TB6000A DS1-OC12 and GigE
dual-port package
441907 FBP-MTS-001 TB6000/MTS probe kit with 200/400X
FBP P505 probe with USB adapter, seven
tips and case
Anixter No. Vendor No. Description
442386 CTLAYER4 10M-1GE Layer 4 line rate TCP/UDP with
automated TCP throughput
testing TrueSpeed
442387 CT10GLAYER4 10G Layer 4 TCP line rate with automated
TCP throughput testing TrueSpeed
442388 CTLSCAPTURE Packet capture at 1G and 10/100/1000M
with WireShark decode and J-Mentor
troubleshooting assistant
442389 CT10GCAPTURE Packet capture at 10G with WireShark
decode and J-Mentor
troubleshooting assistant
442390 CT1G2GFC 2G/1G Fibre Channel test option
442392 TB6000A-4GFC 4G Fibre Channel with 1310 nm and
850 nm 4G SFPs
442391 CT10GFC 10G Fibre Channel test option
This is a sampling of the kits and configurations. For more information,
complete package contents, options available or part-number
configurations, contact your local sales office.
T-BERD/MTS-5800 Handheld Network Tester
Continued on next page >>
14.46
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
T1/WAN Analysis
Test Equipment
D
(continued)
T-BERD/MTS-5800 Handheld Network Tester
•Line rate packet capture up to 10 Gbps
•Packet decodes with integrated WireShark
•J-Mentor provides expert troubleshooting post-capture analysis
TESTERS
OPTIONS
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
JDSU PR23607V2-166689.tif
The growth of converged services has changed the landscape of the
telecommunications industry, creating new opportunities and posing new challenges.
A need exists to deploy complex, new services to meet the demand for the triple play
of voice, video and data, coupled with the challenge to improve customer service and
reduce operating expenses. The right set of tools to do the job quickly and effectively
is needed to successfully navigate this dynamic new world. The modular platform
provides maximum flexibility through software options and field-swappable service
interface modules (SIMs) for copper- and fiber-based multiservice testing. As the role
of the technician moves beyond the physical layer to testing services and
applications, the lightweight, rugged and battery-operated HST-3000 smoothly
supports changing test needs. This handheld, modular platform for copper and
multiservice testing supports technologies such as Gigabit Ethernet, T1/T3 circuits,
serial datacom, DSL copper, POTs and more.
FEATURES
•Industry-leading access network tester with legacy-to-cutting-edge functionality
in one handheld platform
•Repeatable, customizable functionality enables technicians to ramp up quicker
and resolve more issues daily
•Supports triple-play, FTTN, FTTx, Ethernet, IPv4, IPv6 and TDM network tests
•Enables export of results to a PC or back-office system
•Provides ideal solution for circuit-switch to packet-switch migration
Anixter No. Vendor No. Description
442624 TB5801-GIGE TB5801 with 1GE optical and 10/100/
1000 Mbps electrical Ethernet, optics
and fiber patch cables
442626 TB5812-1G-10GE TB5812 with 1GE and 10GE optical and
10/100/1000 Mbps electrical Ethernet,
fiber inspection scope, optics and fiber
patch cables
442627 TB5802-GIGE-DP TB5802 dual port with 1GE optical and
10/100/1000 Mbps electrical Ethernet,
optics and fiber patch cables
442628 TB5812-1G-10GE-DP TB5812 dual port with 1GE and 10GE
optical and 10/100/1000 Mbps
electrical Ethernet, fiber inspection
scope, optics and fiber patch cables
442629 TB5802P-DS3-GIGE-DP TB5802P dual port with DS1/DS3/
STS1,1GE optical and 10/100/
1000 Mbps electrical Ethernet, optics,
bantam, BNC and fiber patch cables
442630 TB5802P-OC12-GIGE-DP TB5802P dual port with DS1/DS3/STS1,
OC3-12, 1GE optical and 10/100/
1000 Mbps electrical Ethernet, optics,
bantam, BNC and fiber patch cables
442631 TB5802P-OC48-GIGE-DP TB5802P dual port with DS1/DS3/STS1,
OC3-48, 1GE optical and 10/100/
1000 Mbps electrical Ethernet, fiber
inspection scope, optics, bantam, BNC
and fiber patch cables
442632 TB5812P-OC192-10GE-DP TB5812P dual port with DS1/DS3/STS1,
OC3-192, 1GE and 10GE optical and
10/100/1000 Mbps electrical Ethernet,
fiber inspection scope, optics, bantam,
BNC and fiber patch cables
Anixter No. Vendor No. Description
442633 C5LSCAPTURE 10/100/1000 Mbps and 1 GigE packet
capture test option
442634 C510GCAPTURE 10 GigE packet capture test option
442635 C5LSSYNCE 1 GigE optical Sync-E test option
442636 C510GESYNCE 10 GigE optical Sync-E test option
442637 C5LS1588 10/100/1000 Mbps and 1 GigE IEEE
1588 test option
442638 C5JPROOF J-Proof Layer 2 transparency test option
442639 C5MPLSVPLS Ethernet MPLS/VPLS test option
442640 C5MPLSTP Ethernet MPLS-TP and OAM test option
This is a sampling of the kits and configurations. For more information,
complete package contents, options available or part-number
configurations, contact your local sales office.
HST-3000 Handheld Services Tester
Anixter No. Vendor No. Description
362090 HST-PKG1 HST-PKG1 Basic ADSL2+
362091 HST-PKG2 HST-PKG2 copper/ADSL2+ loaded
362092 HST-PKG3 HST-PKG3 basic copper
362093 HST-PKG4 HST-PKG4 advanced copper upgrade
441760 HST-PKG5 HST-3000 package for T1
441761 HST-PKG6 HST-3000 package for T1 + ISDN PRI
441762 HST-PKG7 HST-3000 package for T1 and T3
441763 HST-PKG8 HST-3000 package for T1, T3 and ISDN PRI
441767 HST-PKG9 HST-3000 pkg. for copper, T1 and ISDN PRI
441768 HST3000-ETH-P3 Optical Ethernet gold package
441796 HST3000-ETH-P1 Electrical Ethernet nest value package
441802 HST3000S-VOIP Addition of VoIP software option
to HST3000
This is a sampling of the kits and configurations. For more information,
complete package contents, options available or part-number
configurations, contact your local sales office.
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.47
Test Equipment
T1/WAN Analysis
Test Equipment
-
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
JDSU PR23609V2-166700.tif
The SmartClass Ethernet product is an easy-to-use, cost-effective Ethernet-testing
solution for basic physical layer cable testing, Layer 2 and Layer 3 traffic generation
and full RFC 2544 testing. The rugged, battery-operated, application-specific test
tool enables field technicians to turn-up Ethernet and IP services by running an RFC
2544 test or following a set of methods and procedures. The product has been
designed for frontline technicians who do not have experience dealing with emerging
Metro Ethernet technologies and need a simple-to-use solution for Ethernet and IP
testing. The SmartClass product comes in two major configurations, one a
loopback-only device and the other featuring full traffic generation.
FEATURES
•Measures QoS parameters, including throughput, jitter, latency and error ratio
•Checks VLAN/Q-in-Q-based next-generation networks
•Supports 10/100/1000 Mbps testing
•Completely qualifies Ethernet and IP circuits
Index1.Support and Supplies//Test Equipment//Digital Transmission
FLUKE NETWORKS PR10772V2-10899.tif
The 635 QuickBERT is a quick and easy-to-use test set for those who provide and use
T1 services. After connecting the 635, service technicians can verify facility integrity,
configuration parameters and general performance. For quick and easy
troubleshooting, this tester automatically synchronizes and verifies DS1 bit error
performance, frequency and level.
ACCESSORIES
Index1.Support and Supplies//Test Equipment//Outside Plant Applications
FLUKE NETWORKS PR20670V2-82248.tif
Quickly clarify the facilities for ADSL, VDSL, HDSL, T1 and other special services with
the CopperPro Series II Broadband Loop Tester. Building on the popularity of the
original CopperPro, the CopperPro series II broadband loop tester is a complete
solution for locating faults (TDR and RFL), troubleshooting and qualifying OSP copper
cables and network services. Includes carry case, test leads, 12 V and 120 V
chargers, wire gauge and strapping cord.
SmartClass Ethernet
Anixter No. Vendor No. Description
396372 CSC-ETHLP-P1 Electrical-only loopback configuration
396373 CSC-ETHLP-P2 Optical and electrical
loopback configuration
396374 CSC-ETHLP-P3 Optical and electrical loopback
with accessories
362089 CSC-ETHTR-P1 Electrical traffic configuration
362088 CSC-ETHTR-P2 Optical and electrical traffic configuration
362087 CSC-ETHTR-P3 Optical and electrical traffic
with accessories
For more information and part-number configurations,
contact your local sales office.
635 QuickBERT-T1
Anixter No. Vendor No. Description
215850 635 QuickBERT-T1 tester
Anixter No. Vendor No. Description
221910 633/635-KIT Cable kit
CopperPro Series II Broadband Loop Tester
Anixter No. Vendor No. Description
346688 990DSL2+ CopperPro Next Gen copper loop analyzer
with TDR and wideband spectral analysis
for ADSL2+
346689 990VDSL CopperPro Next Gen copper loop analyzer
with TDR and wideband spectral analysis
for VDSL
243955 990DSL Series I POTS-only loop tester
250480 990DSLWT Series I loop tester with wideband and TDR
14.48
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Electrical
Test Equipment
D
./--
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR33682V2-248544.tif
The IDEAL 490 series are industrial-grade high-performance, data-logging
multimeters to measure AC/DC voltage, resistance, continuity, capacitance,
frequency, temperature and true RMS. These troubleshooting features, 20,000-count
resolution and accuracy help solve problems in electrical equipment, plant
automation, electronics and power distribution. Software and USB cable are included.
#61-498 has 0.015 percent DCV accuracy and #61-497 has 0.03 percent
DCV accuracy.
FEATURES
•True RMS
•Analog bar graph
•Auto/manual ranging
•20,000-count high-resolution mode
•Capacitance, frequency and temperature
•CAT III 600 V
•Low-battery indicator
•Carrying case included
•Two-year warranty
MULTIMETER, TRUE RMS, DATA LOGGING, SOFTWARE AND CABLE
ACCESSORIES
--
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR33683V2-248539.tif
The IDEAL #61-361 is a contractor-grade multimeter with true RMS, AC/DC voltage
and current, capacitance, temperature and frequency. These troubleshooting features
help solve problems in electrical equipment, plant automation, electronics and
power distribution.
FEATURES
•Manual ranging
•Phase rotation
•Peak min./max.
•Relative mode
•Audible continuity
•Rugged construction
•Auto power off and low-battery indicator
•Probe holder and rubber boot with tilt stand
•Overload protection on all ranges
•CAT III 1,000 V
•Two-year warranty
--
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR33742V2-249112.tif
The IDEAL 340 series are affordable multimeters with AC/DC voltage and current,
capacitance, temperature and frequency. The large numbers and symbols are easy to
read on the oversize display. These meters troubleshoot electrical circuits,
equipment, electronics and power distribution. The #61-342 adds true RMS.
FEATURES
•Auto/manual ranging
•Peak min./max.
•Relative mode
•Data hold
•Auto power off and low-battery indicator
•Probe holder and rubber boot with tilt stand
•Overload protection on all ranges
•CAT III 600 V
•Two-year warranty
490 Series Industrial-grade Multimeters
Anixter No. Vendor No. Description
442118 61-497 0.03 percent DCV accuracy
442122 61-498 0.015 percent DCV accuracy
Anixter No. Vendor No. Description
442120 61-906 ProVision II software
361 Contractor-grade Multimeter
Anixter No. Vendor No. Description
442125 61-361 361 multimeter with true RMS and
test leads
340 Series TestPro Multimeters
Anixter No. Vendor No. Description
395743 61-340 Multimeter, true RMS
388068 61-342 Multimeter, true RMS, backlight
data acquisition
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.49
Test Equipment
Electrical
Test Equipment
--
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR21793V2-125873.tif
FEATURES
•Super-bright display
•Measures voltage drop under load (12 A, 15 A, 20 A load tests)
•Estimates load on line (ELL) up to 15 A
•True RMS
•Line voltage
•Peak voltage
•Frequency
•Ground to neutral voltage
•Ground impedance
•Hot and neutral conductor impedances
•Identifies proper wiring in three-wire receptacles
•Identifies false (bootleg) grounds
•Tests GFCIs (6-9 mA) and EPDs (greater than 30 mA) for proper operation
•Conducts testing without disturbing sensitive loads
•Verifies isolated ground (with 61-176 adapter)
•Two-year warranty
•Includes carrying case and one-foot extension cord
OPTIONAL ACCESSORIES
--
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR23563V2-165850.tif
FEATURES
•Exclusive, super-bright rotating display
•Identifies breakers and fuses
•Pinpoints opens and shorts
•Traces wires
•0-99 display of signal strength
•Audible intensifies in tone/pitch
•Can be used on circuits 0-600 V AC/DC
•Works on energized or de-energized circuits
•Various modes of sensitivity - search high, search low, trace and breaker
•Peak bar graph
•Two-year warranty
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR23063V2-152478.tif
The IDEAL infrared (IR) thermometer is the noncontact way to make safe and quick
temperature checks on mechanical equipment, electrical circuits and building
systems while in operation. Regular monitoring of heat (infrared energy) emitted from
surfaces can prevent potential problems and failures.
FEATURES
•Measurement range of -76 to 932F (-60 to 500C)
•Holds and displays the maximum temperature measured
•Single-spot laser sighting
•Distance-to-spot ratio 12:1
•Maximum, minimum, difference and average temperature displays
•Programmable high-alarm and low-alarm settings with audible warning
•Supports K-type thermocouple (not included)
SureTest Circuit Analyzers
Anixter No. Vendor No. Description
370350 61-164 SureTest circuit analyzer
442130 61-165 SureTest circuit analyzer – tests AFCIs
wiring tests for shared neutrals
Anixter No. Vendor No. Description
370351 61-175 Ground continuity adapter
370352 61-176 Isolated ground adapter
370353 61-183 Alligator clip adapter
Open/Closed Circuit Tracers
Anixter No. Vendor No. Description
388825 61-956 With rotating OLED display, transmitter
and test lead set
388826 61-958 With ground clamp and battery pack
Infrared Thermometer
Continued on next page >>
14.50
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Electrical
Test Equipment
D
(continued)
Infrared Thermometer
•Adjustable emissivity
•Backlit display
•Two-year warranty
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR23565V2-165840.tif
The IDEAL 920 series ground resistance tester enables users to test grounding
systems without disconnecting the ground, saving both time and effort. By simply
clamping around the grounding rod or ground conductor, it provides direct
measurements of both ground resistance and ground leakage current.
FEATURES
•Simple clamp-on operation
•Ground resistance measurements up to 1,200 ohms
•Ground leakage current up to 30 A AC
•Noise check function
•Auto ranging
•Accommodates conductor size up to 1.25 in. (32 mm) 1,000 MCM cable
•Memory saves up to 99 readings
•Data hold
•Audible continuity buzzer
•Auto power off with alarm
•Backlight
•Audible resistance alarm
•Double reinforced insulation
•Includes protective case, calibration loop, user manual and four AA batteries
--
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR23566V2-165845.tif
The IDEAL #61-797 digital insulation meter is the tool needed to determine whether
the insulation is performing at an effective and safe level. It verifies the integrity of
insulation in cables, motors and other devices to keep current flowing safely through
the copper conductor. The meter identifies capacitive, absorption and leakage
current, helping to prevent problems before they result in injury or equipment failure.
This tester is rugged and built for industrial and commercial applications.
FEATURES
•Test voltages at 50/100/250/500/1,000 V
•Insulation resistance - up to 20G ohms
•Earth-bond resistance - 0.01 ohms to 40k ohms
•Automatic calculation of PI and DAR
•Auto-sensing AC/DC voltage to 600 V
•Low pass filter - filters out high-frequency noise
•Earth-bond resistance
•Test inhibition if > 30 V
•Digital reading with analog arc
•Compare pass/fail mode
•Remote test probe
•Store/recall memory
•Auto discharge and auto power off
•Backlit display - auto-sensing
•Low-battery indication
•Carrying case included
•CAT IV 600 V
•Two-year warranty
Anixter No. Vendor No. Description
386652 61-685 Infrared (IR) thermometer, carrying case
442116 61-461 K-type thermocouple accessory
Ground Resistance Clamp Meter
Anixter No. Vendor No. Description
388827 61-920 Ground resistance clamp meter
Insulation Meter
Anixter No. Vendor No. Description
386653 61-797 Digital insulation meter
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.51
Test Equipment
Power Quality
Test Equipment
./-
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR21889V2-126566.tif
The IDEAL #61-807 power-quality analyzer is a versatile and easy-to-use tool that
will record everything you need for energy, power and power-quality measurement.
The unit measures and analyzes power quality on all single- and 3-phase electrical
systems. Instantaneous readouts of current, voltage, power and harmonics including
tables, bar graphs and even individual waveforms make job-site data interpretation
easy. With a real-time clock and 1 MB data-logging memory, the power analyzer
stores data that can be downloaded to a personal computer for in-depth analysis
using PowerVision software.
PowerVision software provides automatic generation of useful tables and graphs. Files
are easily downloaded from the #61-807 unit. It provides multiple ways to view basic
and detailed information, allowing you to create custom graphs, charts and tables.
Compare up to 12 variables simultaneously. Easily scroll through, expand and collapse
data over time. Compare data from multiple files to show before-and-after studies.
Data can be exported into Excel or Word reports. Highly trained technical-support
people are always a phone call away.
FEATURES
•True RMS
•Single- or 3-phase measurements
•Data logging (1 MB memory)
•Up to one month of recording time
•Four channels for voltage measurements
•Four channels for current measurements
•Auto ranging
•Min./max./average
•Energy and harmonics program
•Lightweight, portable design
•User-selectable - FIFO or fill-and-stop memory
•Programmable trigger-points and start/stop time
•Intelligent battery-charging system
•Easy setup
•600 V CAT III-rated
•Two-year warranty
POWER ANALYZERS
Includes set of three 1,000 A AC clamps (61-811), voltage leads with alligator clips
(TL-806), power supply with RS-232 interface and cables, PowerVision analysis
software, demonstration CD and instructions, protective carrying case
ACCESSORIES
-
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR23637V2-167544.tif
The IDEAL #61-830 VPM identifies only those voltage conditions that can damage
equipment or cause equipment failure. Poor voltage quality costs money.
Undiscovered voltage problems increase facility expenses, warranty costs and
downtime, plus shortens the life of equipment.
FEATURES
•Monitor voltage near sensitive equipment
•Real-time true RMS voltage, frequency and harmonics monitoring
•Logs voltage sags, swells and impulses
•Measures percentage THD and logs periods over three percent (line to neutral)
•Selectable thresholds based on the most accepted international standards,
defaults to ITIC (Information Technology Industry Curve)
•Custom programmable event thresholds
•Invertible display, when it is necessary to plug in upside down
•Two-year warranty
•Includes set of four adapters and carrying case
APPLICATIONS
Installation and service technicians - monitor voltage at point of
equipment connection
Electricians - eliminate guesswork on service calls
Building-maintenance technicians - identify voltage-caused equipment failures
Equipment manufacturers - eliminate unnecessary warranty costs
Hospital/IT maintenance engineers - monitor voltage quality to critical
equipment
3-phase Power Analyzer
Anixter No. Vendor No. Description
370782 61-807 Has four current channels and backlit
display. Includes part no. 61-813 100 A AC
neutral clamp
Anixter No. Vendor No. Description
370821 61-813 One 100 A AC neutral clamp
442393 61-457 200/2,000/20,000 A AC flexible clamp
adapters (set of three)
Voltage Performance Monitor (VPM)
Anixter No. Vendor No. Description
370341 61-830 Voltage performance monitor
370343 61-2004 Kit with one SureTest 164, four voltage
performance monitors 61-830 and
softcase C-2004
14.52
Request the latest literature and guides from Anixter.
1.800.ANIXTER • anixter.com/literature
Test Equipment
Power Quality
Test Equipment
D
-
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR33717V2-248850.tif
This new, improved and complete line of industrial clamps designed by IDEAL elevates
the standard for safety and performance. It starts with the revolutionary TightSight
display. It allows the user to keep his head and face out of potentially dangerous
situations while viewing the instrument. The high-voltage indicator indicates the
presence of voltage through the test leads even with the dial set to the wrong
function. The units have a CAT IV safety rating, rugged construction and UL listing.
FEATURES
•TightSight bottom display
•Selectable audible and visual voltage alerts on AC/DC voltage functions
•Bright bold backlit display with large numbers and symbols
•Tapered jaws with hook tip
•Capacitance
•AC/DC voltage
•Measures AC current
•High frequency rejection
•Resistance
•Max./min. hold
•Peak hold
•Audible continuity
•Selectable auto power off
•Data hold
•Low-battery indicator
•Two-year warranty
660 AMP CLAMP METERS WITH TIGHTSIGHT BOTTOM DISPLAY
Includes true RMS.
1,000 AMP CLAMP METERS WITH TIGHTSIGHT BOTTOM DISPLAY
-
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR23568V2-165859.tif
FEATURES
•Measures up to 600 V AC
•Noncontact voltage indicator (70 V-600 V AC)
•Tapered jaws with hook-up
•Auto/manual ranging
•Data hold
•Auto power off
•Low-battery indicator
•Two-year warranty
TightSight 660 A/1,000 A Clamp Meters with Bottom Display
Anixter No. Vendor No. Description
386655 61-763 Capacitance frequency
386656 61-765 AC/DC current
Anixter No. Vendor No. Description
386910 61-773 True RMS
421435 61-775 True RMS, AC/DC current capacitance
ClampPro 600 amp Clamp Meter
Anixter No. Vendor No. Description
388824 61-744 ClampPro 600 amp Clamp Meter, compact
size with NCV
Products. Technology. Services. Delivered Globally.
1.800.ANIXTER • anixter.com 14.53
Test Equipment
Thermal Imaging
Test Equipment
./-
Index1.Support and Supplies//Test Equipment//Power Applications
IDEAL INDUSTRIES PR23064V2-152481.tif
Troubleshoot and identify potential problems before they happen with the IDEAL
HeatSeeker thermal imagers. Three cameras are now available to cover a wider range
of applications. Cursors instantly locate the hottest and coldest temperature on a live
screen. Cameras have the ability to overlay a thermal image on top of a digital image
for easy on-the-job decision making. The easy setup and operation of the HeatSeeker
make it a cost-effective tool for electrical service, industrial maintenance, building
inspection and data center applications.
FEATURES
•Blended thermal and digital image (0-100 percent and PIP)
•Hottest/coldest temperature displayed instantly on live screen
•1,849 temperature measurements live on camera screen
•Class II laser for view centering
•Built-in LED light for working in dark environments
•High- and low-temperature alarms
•Mark images with text and voice annotation
•Sequence image recording up to every hour
•Sequence image recording activated by alarm settings
•Measurement range of 14F to 662F (#61-844)
•Measurement range of 14F to 1,832F (#61-846)
•Measurement range of 14F to 482F (#61-848)
•Cursors - two movable on #61-844 and four movable (with independent
emissivity settings) on #61-846 and #61-848
•Field of view - 20 x 20 on #61-844, 10 x 15 on #61-846 and
21.4 x 16 on #61-848
•Focal plane array - (47 x 47) on #61-844, (160 x 120) on #61-846 and
(320 x 340) on #61-848
•Accuracy of +/- 2 percent or +/- 2 degrees C
•Six-hour battery life (4 hours on #61-848)
•Power - internal rechargeable Li-Ion battery on #61-844 and field-replaceable
rechargeable Li-Ion battery on #61-846
•Tripod mountable
•Carrying case and ThermalVision PC software included
•Two-year warranty
HEATSEEKER THERMAL IMAGERS
ACCESSORIES
HeatSeeker Thermal Imagers Anixter No. Vendor No. Description
386651 61-844 HeatSeeker thermal imager (47 x 47)
and removable handle
434500 61-846 HeatSeeker 160 thermal imager
(160 x 120)
486414 61-848 HeatSeeker 320 thermal imager
(320 x 240)
Anixter No. Vendor No. Description
386657 61-844CAR Car charger for #61-844
393000 61-844LS Light shade for #61-844 and #61-846
442115 61-846CAR Car charger for #61-846
442394 61-846BAT Removeable/rechargeable battery
442395 61-846DT Desktop charger
442396 61-846HC Hard transport case
Around the world, Anixter can provide you with opportunities
to learn about the latest data center, networking and security
technologies. All of these FREE tools, programs and seminars are
designed to help you make more informed purchasing decisions.
To request more information on all of our programs and resources,
contact your local Anixter representative or visit anixter.com/resources.
Customized to Fit Your
Educational Needs.
Anixter is Your One-Stop
Technical Resource.
are
ecisio
eso
Products. Technology. Services. Delivered Globally.
Anixter is a leading global supplier of communications and security products, electrical and electronic wire and cable, fasteners and other small components. We help our customers specify
solutions and make informed purchasing decisions around technology, applications and relevant standards. Throughout the world, we provide innovative supply chain management solutions
to reduce our customers’ total cost of production and implementation.
11A0004Z1 © 2013 Anixter Inc.
1.800.ANIXTER
anixter.com
ANIXTER UNIVERSITY
SM
Anixter University is a free educational curriculum
designed to educate and provide solutions for technical
issues based on customers’ specific needs. Colleges
include Data Center College,SM and Security Solutions
CollegeSM. Most courses are BICSI CEC certified.
STAY UP TO DATE ON THE STANDARDS
Anixter offers a variety of standards reference guides
to keep you current on the best practices and standards
endorsed by leading industry associations. Networking
standards for North America and Europe and a version
specific to industrial automation environments are available.
TECHNICAL RESOURCES AT YOUR FINGERTIPS
From brochures and white papers to TECHbriefs and
technical diagrams, Anixter creates a variety of technical
literature on topics from data centers to IP security to
industrial automation. The Installer’s Pocket Guide is
our most popular. Request your copies today.
IP SECURITY INFRASTRUCTURE
Learn about the latest trends, technologies and
best practices surrounding IP-based physical security
systems to build solid solutions today that will support
your customers’ needs in the future. Sign up for an event
near you or schedule your one-on-one presentation.
MAKE SURE YOUR INFRASTRUCTURE
IS ANIXTER IPASSURED
SM
Anixter ipAssured matches infrastructure solutions to your
data center and security applications based on technical
and life-cycle requirements. Make sure your applications
are efficient and future-ready with ipAssured.
ANIXTER INFRASTRUCTURE SOLUTIONS LAB
Anixter’s Infrastructure Solutions Lab demonstrates
and evaluates the most practical technologies from
best-in-class manufacturers in the areas of enterprise
cabling, security and industrial automation.
GET THE LATEST INDUSTRY NEWS
WITH ANIXTER’S E-NEWSLETTERS
Anixter is committed to delivering the latest news
and best practices around the most recent networking
and security products, standards and technologies.
Find out what electronic newsletters are available
in your local market.
