Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

D

./Desks;Surveillance/17280

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR28633V2-209686.eps

Serious furniture for mission-critical installations.

FEATURES

•Modular design allows economical additions and limitless

configuration choices

•Consoles are optimized for flexible flat-screen arrangements and ergonomically

designed with the user in mind

•Fully welded bays provide a heavy-duty structure that can be assembled quickly

•Available with an 18-in. deep work surface or 34-in. desktop

•A large variety of standard finishes available

•Most configurations ship in three weeks or less

•Custom finishes and work surfaces available upon request

•UL Listed in the U.S. and Canada

•GREENGUARD IAQ certified

•LCD monitors can be mounted using optional monitor arms

•Ergonomically designed professional-use operator chair available

Video Monitor Wall;Surveillance/18034

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR34919V2-264048.eps

Robust video monitor support system application engineered for unparalleled

monitor support.

FEATURES

•Assembles quickly and easily

•Integral cable management channels

•Designed to meet the specific needs of each installation

•Accepts 10-in. to 80-in. monitors

•Walls can be designed up to 13 ft. 3 in. high, in any width

•Free-standing and desk-mount models available

•Power strips mount directly to the frame

•ETL Listed in the U.S. and Canada for strength and stability

Desks;Surveillance/4083

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21744V2-126482.eps

Versatile, configurable monitoring desk system provides more useable space in a

smaller footprint and is optimized for use with LCD screens. Satisfying the need for

optimized technical furniture, the highly modular LCD Monitoring Desk System is

equally suited for single-desk surveillance applications or larger-scale

command-and-control environments.

For additional LCD Monitoring Consoles or accessories, please contact your local

sales location.

ViewPoint Technical Furniture

Call your local sales representative. Middle Atlantic has

Free Designer layout software for console designs.

VisionFrame Video Monitor Wall

Also available as desk wall version that attaches directly to the

Middle Atlantic ViewPoint console and LCD desk line.

Call your local sales representative. Middle Atlantic has

Free Designer layout software for console designs.

LCD Monitoring Desk System

Anixter No. Vendor No. Description

275169 LD-L48 Light bridge for 48 in. desk

275170 LD-L64 Light bridge for 64 in. desk

275220 LD-M2X1 Monitor mount, 2 monitors, 2 across

275222 LD-M2X2 Monitor mount, 4 monitors, 2 across,

2 levels

275221 LD-M3X1 Monitor mount, 3 monitors, 3 across

275225 D-PT20 Pencil tray, 20 in. wide, mounts

under desk

369796 LD-4830 48 in. wide LCD desk, specify color*

369799 LD-6430 64 in. wide LCD desk, specify color*

369802 LD-SP30 Pair of half-height side panels for LCD

desks, specify color*

369807 LD-PSP30 Pair of full-height side panels for LCD

desks, specify color*

369901 LD-M3X2 Monitor mount, 6 monitors 3 across,

2 levels

*Add -DC for Dark Cherry, -HM for Honey Maple, -PS for Pepperstone or

-SL for Slate (available for side panels only) at the end

of the vendor number for color.

S04DatB.fm Page 2 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.3

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

Consoles;Surveillance/15219

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21742V2-126047.eps

The modular design of Quiet-Cool Series and Convective Series consoles allows for

limitless configurations. The combinations of base modules, top tiers, corner wedges

and writing surface option allow designs that can match any requirements, and

assemble in 1/3 the time of knock-down consoles. Whether the system requires

active cooling, or natural convective cooling, it is easy to select the configuration that

will meet the needs of each project.

Console configuration can be ordered quickly and easily with a single part number.

When passive cooling is need, select Convective Series configurations, or choose the

Quiet-Cool Series for systems requiring active cooling. Each configuration includes the

same features and benefits that are an integral part of Middle Atlantic's consoles.

FEATURES

•Welded design ships fully assembled to minimize installation time

•14-gauge construction provides a robust 1,500 lb. weight capacity

•Space saving 22 in. W, 27 in. D.

•Optional sliding rotating rack bay available

•Convective Series Consoles are Seismic Certified (UBC and CBC Zone 4 and IBC,

ASCE, and FPA Seismic use Group III) for protecting 375 lb. of equipment when

used with SC-Z4 brackets

•Granite gray color standard; black and light gray also available standard

•UL Listed in the U.S. and Canada

•Each configuration comes complete with:

- Locking solid front door on each bay

- 25 rack screws per bay

- Ganging hardware

- 15-amp power distribution

Racks;Wall-mount/3384

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21746V2-126039.eps

Wall-mount racks provide easy rear access.

FEATURES

•Unique design allows punching down while fully open

•Available in three depths: 6 in., 12 in. and 18 in.

•Abundant internal tie points for cable management

•Includes Velcro cable loops

Quiet-Cool Series Monitoring Consoles

Anixter No. Vendor No. Description

327166 SCQ-4 3-bay convective console configuration

package with wedges

369772 SC-2 2-bay straight convective console

configuration package

369774 SCQ-2 2-bay straight Quiet-Cool console

configuration package

369775 SC-3 3-bay straight convective console package

369776 SCQ-3 3-bay straight Quiet-Cool console

configuration package

369777 SC-4 4-bay straight convective console package

369781 SC-3W2 3-bay convective console configuration

package with wedges

369783 SCQ-3W2 3-bay Quiet-Cool console configuration

package with wedges

369785 SC-4W2 4-bay convective console configuration

package with wedges

369789 SCQ-4W2 4-bay Quiet-Cool console configuration

package with wedges

369791 SC-5W2-53T 5-bay convective console configuration

package with wedges and third tiers

369793 SCQ-5W2-53T 5-bay Quiet-Cool console configuration

package with wedges and third tiers

Pivoting Panel Mount

Anixter No. Vendor No. Description

240825 PPM-2 3 1/2 in. (2-rack space)

231155 PPM-4 7 in. (4-rack space)

231159 PPM-6 10 1/2 in. (6-rack space)

231167 PPM-6-12 10 1/2 in. (6-rack space), 12 in. deep

231168 PPM-8-12 14 in. (8-rack space), 12 in. deep

231169 PPM-8-18 14 in. (8-rack space), 18 in. deep

Anixter No. Vendor No. Description

S04DatB.fm Page 3 Tuesday, December 11, 2012 10:38 PM

4.4

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

D

Racks;Wall-mount/2802

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21748V2-126064.eps

The WRP/WRS Series low-profile wall cabinets allow mounting of equipment in a

vertical "knobs-up" fashion for space efficiency and aesthetics. With adjustable

rackrail providing 20 in. to 23 in. of useable racking depth, the innovative design

features a vented bottom, two bottom-located fan-mounting positions with grills

(fans not included), and the angled top cover (hinged plexiglass for the WRP and solid

steel for the WRS) allows convenient equipment access, and is keyed separately from

the body keylock to provide user access to front-equipment controls while limiting

access to connections in the rear of the equipment.

FEATURES

•Low-profile design

•Available in black or putty colors

•UL Listed in the U.S. and Canada

Racks;Wall-mount/17267

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR28623V2-209688.eps

Economical hinged wall mount provides easy rear access to rack-mount components.

FEATURES

•One side hinged at two points for easy rear access

•Simple, adjustable depth accommodates components from 9 in. to 15 in.

•Available in 4-, 6- or 8-rack space models

•Built-in cable management

•Includes four 10-32 rack screws

•Grounding stud built in

•Space indicators marked on rackrail

Racks;Wall-mount/17270

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR28624V2-209692.eps

Cost-effective, versatile solution to wall-mount racking.

FEATURES

•Can accommodate all depths of equipment

•Mounts horizontally or vertically allowing versatile component placement

•Heavy-duty threaded rackrail

•Available in 2-, 3- or 4-rack space models

WRS Series 19 in. Low-profile Wall-mount Rack

Anixter No. Vendor No. Description

275132 WRS-4 7 in. racking height (4 space), 23 in. deep,

black color, solid steel top cover

231269 WRS-6 10 1/2 in. racking height (6 space), 23 in.

deep, black color, solid steel top cover

231272 WRS-8 14 in. racking height (8 space), 23 in.

deep, black color, solid steel top cover

231265 WRP-6 10 1/2 in. racking height (6 space), 23 in.

deep, putty color, plexiglass top cover

268474 WRP-8 14 in. racking height (8 space), 23 in.

deep, putty color, plexiglass top cover

231266 WRP-4 7 in. racking height (4 space), 23 in. deep,

putty color plexiglass top cover

236158 WRP-4 7 in. racking height (4 space), 23 in. deep,

putty color plexiglass top cover

Adjustable-depth Hinged Panel-mount Rack

Anixter No. Vendor No. Description

421695 HPM-4-915 4-rack space, adjustable depth 9 in. to

15 in.

421696 HPM-6-915 6-rack space, adjustable depth 9 in. to

15 in.

421693 HPM-8-915 8-rack space, adjustable depth 9 in. to

15 in.

Vertical Panel Wall Mount

Anixter No. Vendor No. Description

421697 VPM-2 2-rack space, vertical panel mount

421698 VPM-3 3-rack space, vertical panel mount

421699 VPM-4 4-rack space, vertical panel mount

S04DatB.fm Page 4 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.5

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

Racks;Wall-mount/2789

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21749V2-126748.eps

Specify a DWR wall cabinet when floor space is an issue. This pivoting, sectional wall

cabinet is ideal for larger systems in both secure and non-secure areas. Equipped

with fully-adjustable 11-gauge, 10-32 threaded rackrail and advanced

cable-management systems, Middle Atlantic's DWR series welded sectional wall

racks feature 16-gauge steel construction and are offered in depths of 17 in., 22 in.,

26 in. and 32 in.

FEATURES

•Sectional wall rack

•Finished in durable black powder coat

•New Tool-Free Quick-Mount system for easy, one-person mounting of the center

section to the backpan on the job site

•Up to 300 lb. capacity depending on model

•Superior natural ventilation with additional cooling available with optional fans

•Abundant built-in cable lacing points in interior

•UL Listed in the U.S. and Canada

•Accepts the new Zero Clearance Latch which allows mounting side-by-side or in

a corner

•Available in granite gray

17 IN. DEPTH (15 IN. USEABLE)

22 IN. DEPTH (20 IN. USEABLE)

26 IN. DEPTH (24 IN. USEABLE)

32 IN. DEPTH (30 IN. USEABLE)

DWR Series Sectional Wall Racks

Anixter No. Vendor No. Description

240830 DWR-35-17 68 5/16 in. high, 35-rack space, 300 lb.

weight capacity

240827 DWR-24-17 49 1/16 in. high, 24-rack space, 300 lb.

weight capacity

275120 DWR-24-17PD 49 1/16 in. high, 24-rack space, 300 lb.

weight capacity, includes plexiglass door

240828 DWR-21-17 43 3/16 in. high, 21-rack space, 250 lb.

weight capacity

275121 DWR-21-17PD 43 13/16 in. high, 21-rack space, 250 lb.

weight capacity, includes plexiglass door

240829 DWR-18-17 38 9/16 in. high, 18-rack space, 250 lb.

weight capacity

240835 DWR-16-17 35 1/16 in. high, 16-rack space, 200 lb.

weight capacity

275122 DWR-16-17PD 35 1/16 in. high, 16-rack space, 200 lb.

weight capacity, includes plexiglass door

240836 DWR-12-17 28 1/16 in. high, 12-rack space, 200 lb.

weight capacity

231165 DWR-10-17 17 1/2 in. high, 10-rack space, 200 lb.

weight capacity

268467 DWR-10-17PD 24 9/16 in. high, 10-rack space, 200 lb.

weight capacity, includes plexiglass door

Anixter No. Vendor No. Description

240831 DWR-35-22 68 5/16 in. high, 35-rack space, 300 lb.

weight capacity

275123 DWR-35-22PD 68 5/16 in. high, 35-rack space, 300 lb.

weight capacity, includes plexiglass door

231177 DWR-24-22 49 1/16 in. high, 24-rack space, 300 lb.

weight capacity

247021 DWR-24-22PD 49 1/16 in., 24-rack space, 300 lb. weight

capacity, includes plexiglass door

240832 DWR-21-22 43 3/16 in. high, 21-rack space, 250 lb.

weight capacity

229932 DWR-21-22PD 43 13/16 in. high, 21-rack space, 250 lb.

weight capacity, includes plexiglass door

231173 DWR-18-22 38 9/16 in. high, 18-rack space, 200 lb.

weight capacity

240833 DWR-16-22 35 1/16 in. high, 16-rack space, 200 lb.

weight capacity

268471 DWR-16-22PD 22 in. deep, 16-rack space, DWR with

plexiglass front door, 200 lb.

weight capacity

240834 DWR-12-22 28 1/16 in. high, 12-rack space, 200 lb.

weight capacity

231170 DWR-10-22 17 1/2 in. high, 10-rack space, 200 lb.

weight capacity

264574 DWR-10-22-PD 24 9/16 in. high, 10-rack space, 200 lb.

weight capacity, includes plexiglass door

Anixter No. Vendor No. Description

275124 DWR-35-26 68 5/16 in. high, 35-rack space, 300 lb.

weight capacity

275125 DWR-35-26PD 68 5/16 in. high, 35-rack space, 300 lb.

weight capacity, includes plexiglass door

275126 DWR-24-26 49 1/16 in. high, 24-rack space, 300 lb.

weight capacity

275127 DWR-24-26PD 49 1/16 in., 24-rack space, 300 lb. weight

capacity, includes plexiglass door

275128 DWR-18-26 38 9/16 in. high, 18-rack space, 250 lb.

weight capacity

275129 DWR-18-26PD 38 9/16 in. high, 18-rack space, 250 lb.

weight capacity, includes plexiglass door

275130 DWR-12-26 28 1/16 in. high, 12-rack space, 200 lb.

weight capacity

275131 DWR-12-26PD 28 1/6 in. high, 26 in. deep, 12-rack

space, 200 lb. weight capacity, DWR with

plexiglass front door

Anixter No. Vendor No. Description

371051 DWR-12-32 28 1/16 in. high, 12-rack space, 200 lb.

weight capacity

371052 DWR-1832 38 9/16 in. high, 18-rack space, 250 lb.

weight capacity

371053 DWR-24-32 49 1/16 in. high, 24-rack space, 300 lb.

weight capacity

S04DatB.fm Page 5 Tuesday, December 11, 2012 10:38 PM

4.6

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

D

Racks;Wall-mount/17272

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR28625V2-209690.eps

Open wall-mount racks.

FEATURES

•Open-back design maximizes useable wall space

•90-degree opening with positive stop facilitates punching down of wires

•Ships ready-to-assemble to reduce space needed for storage and transport

•Unique, open-swing frame design utilizes pivot points instead of hinges and can

be inverted to allow opening from the left or the right

•Durable black powder coat finish

•50 rack screws included

•Abundant tie points and cable pass-throughs ease cable management

•Permanently lubricated bushings with a proprietary pivot prevent sag

Racks;Wall-mount/2799

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS pr4863V2-12606.eps

Available in 7- and 10-rack spaces high and 17 in. deep, the SBX series enclosures

offer an economical solution to those seeking a wall-mount rack for smaller systems.

The fully welded construction utilizes 18-gauge steel, incorporates a locking front

door which swings open a full 180 degrees on a virtually indestructible hinge, and

includes a removable backpan for easier wall mounting. Ventilation slots at the top of

each side provide superior cooling, while a deep rail-to-door clearance ratio provides

flexibility not found in flush-mount door designs. Additional features include

11-gauge threaded 10-32 rackrails, 1/2 in. and 3/4 in. electrical knockouts at top,

bottom and rear and a black textured powder coat finish.

Racks;Wall-mount/3383

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21752V2-126083.eps

Wall rack pivots on a floor base for easy equipment access.

FEATURES

•Fully welded construction, 16-gauge steel

•UL Listed in the U.S. and Canada

•500 lb. weight capacity

•Backpan features a large laser knock-out panel and accommodates 89-D

brackets and electrical boxes when used with optional subplate. Backpan

accepts up to four subplates

•Bottom cable-entry platform supports entire weight of rack on floor

•70 in. (40 space)

•One subplate mounting kit for 89-D type brackets and electrical boxes, includes

mounting hardware

Swing-frame Wall Rack

Anixter No. Vendor No. Description

259902 SFR-12-18 12-rack space, 18 in. deep

swing-frame rack

259904 SFR-20-18 20-rack space, 18 in. deep

swing-frame rack

375077 SFR-25-18 25-rack space, 18 in. deep

swing-frame rack

421701 SFR-12-24 12-rack space, 24 in. deep

swing-frame rack

421702 SFR-20-24 20-rack space, 24 in. deep

swing-frame rack

421703 SFR-25-24 25-rack space, 24 in. deep

swing-frame rack

SBX Series 19 in. Wall-mount Rack

Anixter No. Vendor No. Description

231289 SBX-7 12 1/4 in. high, 7-rack space, 14 in. deep,

75 lb. capacity

240784 SBX-10 17 1/2 in. high, 10-rack space, 14 in.

deep, 100 lb. capacity

SR 19 in. Pivoting Rack

Anixter No. Vendor No. Description

255593 SR-40-28 Swing-out cabinet, floor and

wall-supported, 40 RMU, 28 in. D

231228 SR-40-22 Swing-out cabinet, floor and

wall-supported, 40 RMU, 22 in. D

305194 SR-40-32 Swing-out cabinet, floor and

wall-supported, 40 RMU, 32 in. D

305454 SR-46-28 Swing-out cabinet, floor and

wall-supported, 46 RMU, 28 in. D

319793 SR-24-28 24 RMU, 28 in. D, SR pivoting rack

319794 SR-24-32 Swing-out cabinet, floor and

wall-supported, 24 RMU, 32 in. D

240824 SR-SUB Subplate mounting kit

255015 FD-40 Solid front door, 40 RMU

231151 PFD-40 Plexiglass front door, 40 RMU

231254 VFD-40 Vented front door, 40 RMU

275138 DWR-RR40 Additional rackrail, 40 RMU

231140 PFD-24 Plexiglass front door, 24 RMU

S04DatB.fm Page 6 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.7

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

Racks;Four-post/17273

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR28626V2-209689.eps

Engineered for high-density patching applications.

FEATURES

•Two mounting depths available: 16 7/16 in. (6 3/8 in. useable) and new 24 in.

(14 in. useable)

•Oversized cable ducts manage massive cable bundles

•Seismic certified to the UBC 1997 and 2001 CBC Seismic Zone 4 and the IBC

2000, IBC 2003, 2002 ASCE Standard 7 and 2003 NFPA 5000 Seismic Use Group

III for protecting 500 lb. of essential equipment in upper-floor installations with

an Ip value of 1.5

•Unique swiveling front D-Rings provide patch cable management

•Integral top cable tray, front and rear

•Modern design incorporates captive fasteners

•Hook-and-loop fasteners and front cable feed-through holes included

•100 rack screws included

Enclosures;Rack/3386

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21754V2-126057.eps

54-space enclosure provides more racking height.

FEATURES

•100 5/8 in. O.D. height, 54 useable spaces

•31 in. O.D. depth

•UL Listed in the U.S. and Canada

•Broadcast standard 22 in. width

•Fully welded construction

•Substantial 2,500 lb. weight capacity

•Two pairs threaded 10-32 "Z-RAIL" standard

•Seismic Certified (UBC and CBC Zone 4 and IBC, ASCE, and NFPA Seismic use

Group III) for protecting 600 lb. of equipment when used with MRK-Z4 bracket

231251 VFD-24 Vented front door, 24 RMU

255016 FD-24 Solid front door, 24 RMU

302340 DWR-RR24 Additional rackrail, 24 RMU

369836 DWR-RR46 Additional rackrail, 46 RMU

MK Cable-management Racks

Anixter No. Vendor No. Description

231191 MK-19-45 Rack cable management; overall height

84 1/4 in. and 16 7/16 in. depth

337232 MK-1945-24 Rack cable management; overall height

84 1/4 in. and 24 in. depth

Anixter No. Vendor No. Description

VMRK-54 19 in. 54-space Rack Enclosure

Anixter No. Vendor No. Description

240837 VMRK-54 54 RMU VMRK cabinet frame, 31 in. deep

with rear door

254081 MRK-Z4 Seismic bracket for MRK and

VMRK cabinets

S04DatB.fm Page 7 Tuesday, December 11, 2012 10:38 PM

4.8

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

D

Racks;Four-post/3380

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21755V2-126755.eps

These racks feature a narrow design for large-scale multibay jobs, and accept

optional removable side panels for easy equipment access.

FEATURES

•Fully welded construction, open sides

•UL Listed in the U.S. and Canada

•Substantial 2,500 lb. weight capacity

•Slim 22 in. O.D. width

•Available in three depths: 26 1/2 in., 31 1/2 in. and 36 in.

•Available with Proliant style cage-nut rackrail

•Seismic Certified (UBC and CBC Zone 4 and IBC, ASCE, and NFPA Seismic use

Group III) for protecting 1,000 lb. of equipment when used with

MRK-Z4 brackets

26 1/2 IN. OUTSIDE DEPTH

31 1/2 IN. OUTSIDE DEPTH

36 IN. OUTSIDE DEPTH

Cabinets;Free-standing, Network/15230

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21756V2-126968.eps

Gain unrestricted access to equipment and cabling without the need for tracks and

stands. Ideal for environments that require equipment bays to be placed up against

walls or back to back, the award-winning WR allows entire bays of equipment to roll

out and rotate for service and installation flexibility.

FEATURES

•Slides out and rotates 60 degrees, requiring no additional accessories

•UL Listed in the U.S. and Canada

•Host enclosure can be preinstalled on-site while detachable rack frame is

integrated with equipment off-site, simplifying installation

•26 in. useable depth, 32 7/8 in. deep host enclosure

•750 lb. weight capacity with proper weight distribution

•Available in 44- and 37-space rack frame heights

•Effective cable management system provided

•Knockouts provided for cable pass-through and ganging multiple racks

•Engineered ventilation locations optimize passive heat convection

•Configurable open top accepts a number of options for active thermal

management

•Standard front and rear 11-gauge, 10-32 threaded rackrail with marked

rack-space increments

MRK Series 19 in. Gangable Enclosures

Anixter No. Vendor No. Description

231193 MRK-4426 44 RMU MRK cabinet frame, 26 in. deep

with rear door

240798 MRK-4026 40 RMU MRK cabinet frame, 26 in. deep

with rear door

240799 MRK-3726 37 RMU MRK cabinet frame, 26 in. deep

with rear door

240796 MRK-2426 24 RMU MRK cabinet frame, 26 in. deep

with rear door

254081 MRK-Z4 Seismic bracket for MRK and

VMRK cabinets

Anixter No. Vendor No. Description

231198 MRK-4431 44 RMU MRK cabinet frame, 31 in. deep

with rear door

240800 MRK-4031 40 RMU MRK cabinet frame, 31 in. deep

with rear door

240801 MRK-3731 37 RMU MRK cabinet frame, 31 in. deep

with rear door

240802 MRK-2431 24 RMU MRK cabinet frame, 31 in. deep

with rear door

254081 MRK-Z4 Seismic bracket for MRK and

VMRK cabinets

Anixter No. Vendor No. Description

240806 MRK-4436 44 RMU MRK cabinet frame, 36 in. deep

with rear door

334389 MRK-4442 44 RMU MRK cabinet frame, 42 in. deep

with rear door

254081 MRK-Z4 Seismic bracket for MRK and

VMRK cabinets

WR Series Roll-out Rotating System

Anixter No. Vendor No. Description

303393 WR-37-32 37 SP/32D roll-out rotating rack

303394 WR-44-32 44 SP/32D roll-out rotating rack

303395 WRFD-37 37 SP solid front door for WR cabinet

303396 WRFD-44 44 SP solid front door for WR cabinet

S04DatB.fm Page 8 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.9

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

Cabinets;Wall-mount/16075

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR23397V2-164136.eps

26 in. width cabinet to allow much-needed space for patching. Comes standard with

wide-face rackrail on left and right of cabinet or an optional off-set face rail for

dressing to either side using included cable-management rings or optional

fiber spools.

Racks;Wall-mount/16076

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR23398V2-164156.eps

Ideal for small sound systems, paging and patching applications in schools, hotels,

offices or anywhere a secure, low-profile wall-mount solution is required.

CableSafe Data Wall Cabinet

Anixter No. Vendor No. Description

393132 CWR-12-17PD 12 RU tall, 17 in. deep with

plexiglass door

394305 CWR-18-17PD 18 RU tall, 17 in. deep with

plexiglass door

394307 CWR-26-17PD 26 RU tall, 17 in. deep with

plexiglass door

394310 CWR-12-22PD 12 RU tall, 22 in. deep with

plexiglass door

393134 CWR-18-22PD 18 RU tall, 22 in. deep with

plexiglass door

394313 CWR-26-22PD 26 RU tall, 22 in. deep with

plexiglass door

393133 CWR-12-26PD 12 RU tall, 26 in. deep with

plexiglass door

393135 CWR-18-26PD 18 RU tall, 26 in. deep with

plexiglass door

394315 CWR-26-26PD 26 RU tall, 26 in. deep with

plexiglass door

394320 CWR-12-32PD 12 RU tall, 32 in. deep with

plexiglass door

394323 CWR-18-32PD 18 RU tall, 32 in. deep with

plexiglass door

393137 CWR-26-32PD 26 RU tall, 32 in. deep with

plexiglass door

TOR Series Tilt-out Wall Rack

Anixter No. Vendor No. Description

303310 TOR-2-20SP Racking height 3 1/2 in. (2-rack space),

useable depth 20 in., outside height

30 1/4 in., outside width 24 1/2 in.,

outside depth 4 7/16 in.

303309 TOR-2-20RP Racking height 3 1/2 in. (2-rack space),

useable depth 20 in., outside height

30 1/4 in., outside width 24 1/2 in.,

outside depth 4 7/16 in.

303312 TOR-3-20SP Racking height 4 1/4 in. (3-rack space),

useable depth 20 in., outside height

30 1/4 in., outside width 24 1/2 in.,

outside depth 6 3/16 in.

303311 TOR-3-20RP Racking height 3 1/2 in. (2-rack space),

useable depth 20 in., outside height

30 1/4 in., outside width 24 1/2 in.,

outside depth 4 7/16 in.

303314 TOR-4-20SP Racking height 7 in. (4-rack space),

useable depth 20 in., outside height

30 1/4 in., outside width 24 1/2 in.,

outside depth 4 15/16 in.

303313 TOR-4-20RP Racking height 7 in. (4-rack space),

useable depth 20 in., outside height

30 1/4 in., outside width 24 1/2 in.,

outside depth 7 15/16 in.

S04DatB.fm Page 9 Tuesday, December 11, 2012 10:38 PM

4.10

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

D

Racks;Wall-mount/16077

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR23402V2-164131.eps

Upper bay mounts patch panels and pivots 100 degrees with positive stop for

punch-downs. Lower bay mounts switches, hubs and routers and pivots 15 degrees

for access to rear connections. Integral electrical box for power distribution. Vented,

locking front door for mounting in non-secure areas.

Multiple electrical knockouts to accommodate electrical conduit.

Cabinets;Racks/16081

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR23408V2-164150.eps

Racks;Ceiling-mount/15225

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21750V2-126091.eps

Rack-mount hubs, routers and other equipment overhead in warehouses, retail

outlets and other large, open area locations.

FEATURES

•Mounts overhead directly to uni-strut beams or from trusses using threaded

rods (not included)

•Dual exhaust fans extend equipment life

•Bottom plate can be machined in the field to mount wireless antennae, dome

cameras and more

•Multiple UHF/VHF antenna knockouts on the bottom of the enclosure

•Grounding/bonding stud in top of enclosure facilitates proper grounding and

bonding of electronic equipment, per NEBS and NEC standards

•Side knockouts for conduit pass-through to internal, standard electrical box

•Ships with included rack-mount power distribution unit, model #PD-915R

•Top includes four integral gland grommets for protecting cables and reducing

dust within the enclosure

•Durable textured black powder coat finish

•UL Listed in the U.S. and Canada

Horizontal Distribution Rack

Anixter No. Vendor No. Description

268472 HDR-4 3 1/2 in. + 3 1/2 in. (2-rack space +

2-rack space)

302499 HDR-FAN External 4 1/2 in. fan kit

Slim 5 Series 19 in. Equipment Racks

Anixter No. Vendor No. Description

231079 5-43 20 in. deep, 75 1/4 in. rack height

(43-rack space)

301963 5-43-26 26 in. deep, 75 1/4 height

(43-rack space)

231077 5-37 20 in. deep, 64 3/4 in. rack height

(37-rack space)

301952 5-37-26 26 in. deep, 64 3/4 in. rack height

(37-rack space)

243086 5-29 20 in. deep, 50 3/4 in. rack height

(29-rack space)

301937 46171 26 in. deep, 50 3/4 in. rack height

(29-rack space)

231075 5-21 20 in. deep, 36 3/4 in. rack height

(21-rack space)

301922 46163 26 in. deep, 36 3/4 in. rack height

(21-rack space)

243087 5-14 20 in. deep, 24 1/2 in. rack height

(14-rack space)

360580 5-14-26 26 in. deep, 24 1/2 in. rack height

(14-rack space)

243088 5-8 20 in. deep, 14 in. rack height

(8-rack space)

301964 5-8-26 26 in. deep, 14 in. rack height

(8-rack space)

Intermediate Distribution Rack

Anixter No. Vendor No. Description

354192 IDF-TM-1224BK 12 SP, truss mounted, 24 in. DP enclosure

Anixter No. Vendor No. Description

S04DatB.fm Page 10 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.11

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

Power Distribution;Rack Power Strips/4086

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS pr5950V2-12633.eps

FEATURES

•UL and CSA Listed

•Slim 1 5/8 in. width uses a minimum of rack space

•Outlets are spaced to accommodate plug-in power supplies

•Ships complete with a 10 ft. power cord terminated with a NEMA 5-15P plug,

and 15 amp circuit breaker

Power Distribution;Rack Power Strips/12519

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21766V2-126096.eps

15 AMP

20 AMP

High-density Slim 115 volt Vertical Power Strips

Anixter No. Vendor No. Description

258735 PD-2415SC-NS 24 outlet, 15 amp vertical power strip,

slim style, no surge protection

258736 PD-815SC-NS 8 outlet, 15 amp vertical power strip, slim

style, no surge protection

268475 PD-2415SC 24 outlet, 15 amp vertical power strip,

slim style

266386 PD-815SC 8 outlet, 15 amp vertical power strip,

slim style

PDT Series Power Strips

Anixter No. Vendor No. Description

449725 PDT-1015C-M-NS 10 outlet, single 15 amp circuit with

current meter, thin power strip with

9 in. cord

319811 PDT-1015C-NS 10 outlet, 15 amp vertical power strip,

thin series, cord, no surge protection

449726 PDT-1015C-NS20 10 outlet, single 15 amp circuit thin power

strip with 20 in. cord

449727 PDT-1015C-RN 10 outlet, single 15 amp circuit, 2-stage

surge/spike, remote notify, thin power

strip with 9 in. cord

449728 PDT-1615C-NS 16 outlet, single 15 amp circuit thin power

strip with 9 in. cord

449729 PDT-2015C-M-NS 20 outlet, single 15 amp circuit with

current meter, thin power strip with

9 in. cord

319812 PDT-2015C-NS 20 outlet, 15 amp vertical power strip,

thin series, cord, no surge protection

449730 PDT-2015C-RN 20 outlet, single 15 amp circuit, 2-stage

surge/spike, remote notify, thin power

strip with 9 in. cord

326274 PDT-2X1015 20 outlet, single/dual 15 amp circuit, thin

power strip with J-Box, ISO

ground configurable

319814 PDT-2X1015T 20 outlet, 72 3/4 in. with J-Box ground top

Anixter No. Vendor No. Description

240913 PD-620C-NS 6 outlet - 20 amp (1 circuit), cord with

NEMA 5-20P plug, circuit breaker

240920 PD-620J-IG 6 outlet - 20 amp ISO ground

(1 circuit), J-Box

240914 PD-1020C-NS 10 outlet - 20 amp (1 circuit), cord with

NEMA 5-20P plug, circuit breaker

240921 PD-1020J-IG 10 outlet - 20A ISO ground

(1 circuit), J-Box

231114 PD-1220C-NS 12 outlet - 20 amp (1 circuit), cord with

NEMA 5-20P plug, circuit breaker

240922 PD-1220J 12 outlet - 20 amp (1 circuit), J-Box

240919 PD-1220J-IG 12 outlet - 20 amp ISO ground

(1 circuit), J-Box

240918 PD-2X620J 12 outlet - 20 amp (2 circuit), J-Box

Anixter No. Vendor No. Description

S04DatB.fm Page 11 Tuesday, December 11, 2012 10:38 PM

4.12

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

D

Power Distribution;Rack Power Strips/17274

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR28627V2-209697.eps

Designed to optimize space and efficiency in power management, the new

single-circuit, 15 amp rack-mount power-distribution system provides 20 total

outlets within a shallow depth.

FEATURES

•Versatile design allows for the unit to be mounted either horizontally or

vertically in the rack

•Shallow 4 in. depth

•20 total outlets (10 on front of unit, 10 on rear of unit)

•9 in., 14 gauge Signal Safe power cord minimizes the effects of AC

magnetic fields

•Reversible, adjustable mounting ears provide more flexible installation options

with either 0-degree or 90-degree mounting

•Outlets are oriented in various directions to accommodate plugs of different

shapes, sizes and orientations. When installed with 90-degree orientation, the

unit supports heavy "wall wart" power supply plugs

Power Distribution;Rack Power Strips/3402

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21947V2-126971.eps

The PD-915R rack-mount 15 amp power-distribution unit is equipped with eight rear

outlets and one front outlet. Standard equipment includes surge and spike

protection, EMI filtering and a 9 ft. cord. An illuminated combination power switch/

circuit breaker is located on the front panel. Occupies one rack space. UL Listed in

the U.S. and Canada.

Power Strips;Rack-mount/3400

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21768V2-126476.eps

The PD-920R-NS rack-mount 20 amp power-distribution unit is equipped with eight

circuit breaker-protected rear outlets (NEMA 5-20R), and one 15 amp front outlet

(NEMA 5-15R). An illuminated power switch is located on the front panel and a

20 amp circuit breaker is located in the rear. Occupies one rack space. UL Listed in

the U.S. and Canada.

Power Strips;Vertical/15231

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21765V2-126493.eps

The PD Series dual-circuit 30 amp power-distribution strip supplies power on two

circuits to 15 amp equipment. With 12 duplexes (24 outlets) and a 9 1/2 ft. cord,

this new power strip allows connection to uninterruptible power supplies. Ideal for

high-density server cabinets. UL listed in the U.S. and Canada.

Multi-Mount Rack-mount Power Strips - 15 amp

Anixter No. Vendor No. Description

449770 PD-1815R-RN 18 outlet, single 15 amp circuit,

Multi-Mount power distribution with 9 in.

cord. 4 in. deep, 2-stage surge/spike,

remote notify, black powder coat finish

449771 PD-1820R-RN 18 outlet, single 15 amp circuit,

Multi-Mount power distribution with 9 in.

cord. 4 in. deep, 2-stage surge/spike,

remote notify, black powder coat finish

380261 PD-2015R-HH-NS One 15 amp with illuminated power switch

and a 9 in. length cord

380260 PD-2015R-NS One 15 amp, no power switch and the cord

length is 9 in.

449772 PD-2020R-NS 20 outlet, single 20 amp circuit,

Multi-Mount power distribution with 9 in.

cord. 4 in. deep, black powder coat finish

115 volt Rack-mount Power Strips - 15 amp

Anixter No. Vendor No. Description

231128 PD-915R 9 outlet, 15 amp rack-mount power strip

334452 PD-915RV-RN 9 outlet, 15 amp rack-mount power strip,

with 2-stage surge protection

115 volt Rack-mount Power Strips - 20 amp

Anixter No. Vendor No. Description

231131 PD-920R-NS 9 outlet, 20 amp rack-mount power strip,

no surge protection

115 volt Vertical Power Strips - 30 amp

Anixter No. Vendor No. Description

369864 PD-2X1215TL-30CB 24 outlet (12 per circuit) - 2x15 amp

circuits, cord with NEMA L5-30P plug,

circuit breakers

S04DatB.fm Page 12 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.13

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

Power Products;UPS/16080

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR23407V2-164141.eps

Pure Sine Wave technology provides optimum waveform for sensitive A/V components.

Line interactive with automatic voltage regulation. Compact rack-mount is only

19 in. deep.

Easily integrates with control systems using RS-232 and analog I/O. Total of eight

surge-protected outlets. Expansion battery pack option. Connect up to 10 to a single

UPS for extended half-load runtimes of up to 20 hours. Energy Saver circuitry reduces

power consumption by up to 75 percent when compared with traditional UPS designs.

Three-year warranty.

Rack Shelves;Clamping/3389

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21772V2-126082.eps

Clamping rack shelves captivate components.

FEATURES

•Available in 2- to 8-rack units

•15 1/2 in. depth

•UL Listed in the U.S. and Canada

Shelves;Rack Shelves/15232

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21770V2-126212.eps

Unlike standard adjustable shelves, the entire VSA shelf telescopes to reach rear rail,

providing a range of useable depths from 16 in. to 44 in. Providing the greatest

useable depth in its class, the heavy-duty VSA is ideal for even the deepest

components. Constructed of hemmed 16-gauge steel and finished in a durable black

powder coat, the VSA is fully vented for superior cooling and features many tie points

for enhanced cable management. 500 lb. weight capacity.

Shelves;Rack Shelves/16074

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR23396V2-164155.eps

Featuring fully ventilated bottom and sides for heat dissipation, these fully welded,

easy-to-install shelves fit all components up to 17 3/8 in. wide to quickly meet all of

your rack-mounting needs. Made from 16-gauge steel, each unit is individually boxed.

Includes three rear brackets to prevent components from sliding backwards. This

shelf helps to save valuable space by accepting the mounting of the PD-815SC-PBSH

8 outlet, 15 amp power strip on the rear of shelf. Also allows the attachment of

optional clamping bars to secure components.

Uninterruptible Power Supply

Anixter No. Vendor No. Description

394381 UPS-1000R 1,000 VA / 750 W UPS, 3.5 in. H x 17 in. W

x 19 in. D

394382 UPS-2200R 2,150 VA / 1,650 W UPS, 3.5 in. H

x 17 in. W x 19 in. D

394383 UPS-EBPR UPS expansion battery pack, 3.5 in. H

x 17 in. W x 19 in. D

394384 UPS-RBP UPS replacement battery pack

Clamping Rack Shelves

Anixter No. Vendor No. Description

231195 RC-2 2 RMU clamping rack shelf

231196 RC-3 3 RMU clamping rack shelf

231197 RC-4 4 RMU clamping rack shelf

240855 CAP5 8 3/4 in. (5 space),

knock-down construction

240856 CAP6 10 1/2 in. (6 space),

knock-down construction

240857 CAP7 12 1/4 in. (7 space),

knock-down construction

240858 CAP8 14 in. (8 space), knock-down construction

VSA Series Adjustable Telescoping Rack Shelf

Anixter No. Vendor No. Description

358800 VSA-1626 16 in. - 26 in. telescoping shelf

358801 VSA-2744 27 in. - 44 in. telescoping shelf

Vented Universal Rack Shelves

Continued on next page >>

S04DatB.fm Page 13 Tuesday, December 11, 2012 10:38 PM

4.14

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

D

(continued)

Vented Universal Rack Shelves

Monitors;Rack-mount LCD/17275

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR28629V2-209700.eps

FEATURES

•Generous front-to-back adjustment

•Versatile rack-mounting of LCD screen from 15 in. to 19 in., including some

20 in. monitors

•RM-LCD-MT can mount larger monitors, up to 32 in. depending on weight

Keyboards;Rack-mount/3405

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21776V2-126495.eps

FEATURES

•Includes high-quality keyboard

•Keyboard features built-in trackball and padded wrist-rests

•Hinged cable manager in rear

•Includes 12 ft. keyboard and trackball cable

•Occupies one space (1.75 in.)

Enclosures;Drawers/3398

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21775V2-126058.eps

Fully enclosed with inside dimensions measuring 15 7/8 in. wide by 14 1/2 in. deep,

the D and TD series drawers feature spring-loaded latches and rugged,

straightforward construction. Faceplates come with a textured black powder coat or

brushed and black anodized finish. Installed keylock option available.

BLACK BRUSHED AND ANODIZED FINISH

BLACK TEXTURED FINISH

Monitors;Rack-mount, LCD/16079

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR23405V2-164146.eps

Space-saving design occupies a single rack space. No-hassle one-year warranty.

Easy-to-read bright active matrix LCD display. LCD can be in open position for system

Anixter No. Vendor No. Description

394300 U2V 3 1/2 in. (2-rack space), 17.44 in. W x

15 in. D, 50 lb.

394302 U3V 5 1/4 in. (3-rack space), 17.44 in. W x

15 in. D, 70 lb.

394303 U4V 7 in. (4-rack space), 17.44 in. W x

15.50 in. D, 85 lb.

LCD Rack-mount

Anixter No. Vendor No. Description

412963 RM-LCD-MV 9 SP, rack-mount, LCD, VESA

412964 RM-LCD-MT 9 SP, rack-mount, LCD, articulating

412965 RM-LCD-MK 9 SP, rack-mount, LCD, tilt mechanism

Rack-mount Computer Keyboard

Anixter No. Vendor No. Description

231232 RM-KB Rack-mount computer keyboard, 1 RMU

Heavy-duty D and TD Series Drawers

Anixter No. Vendor No. Description

231158 D2 2 RMU anodized finish rack-mount drawer

231161 D3 3 RMU anodized finish rack-mount drawer

231162 D4 4 RMU anodized finish rack-mount drawer

240885 D5 5 RMU anodized finish rack-mount drawer

229265 TD2 2 RMU textured finish rack-mount drawer

229293 TD3 3 RMU textured finish rack-mount drawer

229297 TD4 4 RMU textured finish rack-mount drawer

240974 TD5 5 RMU textured finish rack-mount drawer

303305 TD8FLK 8 RMU textured finish rack-mount file

storage drawer with lock

Anixter No. Vendor No. Description

229265 TD2 2 RMU textured finish rack-mount drawer

229293 TD3 3 RMU textured finish rack-mount drawer

229297 TD4 4 RMU textured finish rack-mount drawer

240974 TD5 5 RMU textured finish rack-mount drawer

Rack-mount LCD Monitor With Keyboard and Touch Pad

S04DatB.fm Page 14 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.15

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

monitoring while keyboard is in the closed position. Standard 105-key keyboard with

touch pad. 17 in. monitor is capable of supporting 1,280x1,024 screen resolution.

Lockboxes;Rack-mount/3397

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21778V2-126037.eps

Safely secure gear in Middle Atlantic's rack-mount LBX Series lockboxes. 9 in. deep,

3- and 4-space models are offered with a durable black powder coat finish. UL Listed

in the U.S. and Canada.

Enclosures;Security and Commercial/16078

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR23403V2-164149.eps

Optimized to handle the active or passive thermal-management needs of digital video

recorders and other digital equipment. Mounts vertically or horizontally to the wall,

also can be used as a monitoring shelf. Configurable thermal-management system

includes fan and two filters, and can be set up to accommodate the needs of any

DVR. Optional proportional-speed thermostatic fan control ensures fan only runs

when needed, reducing maintenance requirements and noise.

Extensive cable management includes tie points, EKOs and cable pass-throughs.

Mechanically interlocking top provides added security yet removes easily for

equipment servicing. Standard keylocked solid hinging front door allows easy

equipment access.

Panels;Blank/3408

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21782V2-126206.eps

FEATURES

•Flanged steel

•Durable powder coat finish

Panels;Vented/3409

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21783V2-126203.eps

FEATURES

•Vent panels with high percentage of open area

•16-gauge perforated steel

•Flanged for strength

•Durable black powder coat finish

Anixter No. Vendor No. Description

319809 RM-KB-LCD17 Single space rack-mount 17 in. LCD

monitor with keyboard and touch pad

369897 RM-KB-LCD17X8KV Single space rack-mount 17 in. LCD

monitor with keyboard, touch pad and

8-port KVM switch

369899 RM-KB-LCD17X16K Single space rack-mount 17 in. LCD

monitor with keyboard, touch pad and

16-port KVM switch

394380 PS2/USB-4C PS/2 and USB cables, 4 pcs.

LBX Series Lockboxes

Anixter No. Vendor No. Description

231186 LBX-3 3 RMU lockbox, rack-mount

231188 LBX-4 4 RMU lockbox, rack-mount

DLBX Series DVR Lockboxes

Anixter No. Vendor No. Description

281779 DLBX DVR lockbox with fan

281781 DLBX-WM Pair of wall-mount brackets for DLBX

302259 DLBX-RR5 10-32 threaded rackrail kit for DLBX,

5-rack spaces with cutouts for

cable pass-through

352618 FC-2-215-1C Proportional-speed thermostatic fan

control with two 15 amp outlets

EB Series Blank Panels

Anixter No. Vendor No. Description

231178 EB1 1 RMU blank panel

231183 EB2 2 RMU blank panel

231187 EB3 3 RMU blank panel

231190 EB4 4 RMU blank panel

240849 EB5 5 RMU blank panel

240850 EB6 6 RMU blank panel

VT Series Vent Panels

Anixter No. Vendor No. Description

240851 VT1 1 3/4 in. (1 space)

240852 VT2 3 1/2 in. (2 space)

240853 VT3 5 1/4 in. (3 space)

240854 VT4 7 in. (4 space)

S04DatB.fm Page 15 Tuesday, December 11, 2012 10:38 PM

4.16

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

D

Covers;Security, Perforated/3393

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21784V2-126200.eps

Eliminate the prospect of any tampering with these tough security covers. Offered in

large- or fine-perforation styles (models S and SF respectively), each cover is

1 in. deep.

LARGE-PERFORATION STYLE

Allows unobstructed view of knob settings

FINE-PERFORATION STYLE

Allows sight of LEDs; most secure

Enclosures;Cable Management/17277

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR28631V2-209702.eps

The brush grommet panels provide a clean, organized cable-entry method when used

in conjunction with any work surface. Features a built-in cable-management tray.

Available in one- and two-space versions. Two-space brush grommet panel fits in

opening on all MW Series top options.

Enclosures;Cable Management Bars/3395

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21790V2-126191.eps

The economical and effective way to manage cable horizontally. Made from 1/4 in.

diameter flattened rod (model LBP-1R, LBP-1.5 and model LBP-1R4) or 3/16 in. thick

aluminum (model LBP-1S), each bar provides convenient cable tie points.

Cable Management;Horizontal/3396

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21796V2-126185.eps

FEATURES

•Available in a variety of styles to suit any application

•Welded steel construction

•Finished in durable black powder coat

Perforated Security Covers

Anixter No. Vendor No. Description

231271 S1 1 space (1 3/4 in.) regular

perforated pattern

231275 S2 2 space (3 1/2 in.) regular

perforated pattern

231277 S3 3 space (5 1/4 in.) regular

perforated pattern

231278 S4 4 space (7 in.) regular perforated pattern

Anixter No. Vendor No. Description

231290 SF1 1 RMU fine perforated vented

security panel

231292 SF2 2 RMU fine perforated vented

security panel

231293 SF3 3 RMU fine perforated vented

security panel

231294 SF4 4 RMU fine perforated vented

security panel

Brush Grommet Panels

Anixter No. Vendor No. Description

302118 BR1 1 RMU brush panel for cable pass-through

334554 BR2 2 RMU brush panel for cable pass-through

Cable Management Bars

Anixter No. Vendor No. Description

231182 LBP-1R Round horizontal lacing bars, 10-pack

231185 LBP-1S Square horizontal lacing bars, 10-pack

240884 LBP-1.5 1.5 in. offset round rod, 10 pcs.

231184 LBP-1R4 4 in. offset round rod, 10 pcs.

231181 LBP-1A L bar, 10 pcs.

290517 LBP-2A 2 in. offset L style lacing bars, 10-pack

290518 LBP-4A 4 in. offset L style lacing bars, 10-pack

290519 LBP-6A L bar, 6 in. offset, 10 pcs.

305193 LBP-LTF 2 RMU lacing panel, 10-pack

Cable Management

Anixter No. Vendor No. Description

231106 HCM-1 1 RMU horizontal cable manager

231117 HCM-1V 1 3/4 in. (1 space) micro-clip style,

end rings

S04DatB.fm Page 16 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.17

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

Enclosures;Cable Management/17276

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR28630V2-209691.eps

FEATURES

•Matches and integrates well with PCD Series Ducts

•Comes with removable hinged cover

•Available in single piece and four packs

Enclosures;Cable Management/17279

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR28632V2-209704.eps

Flexible application for vertical cable management on open frame racks. Plastic cable

ducts provide a cost-effective solution to protect, route and organize data cables,

patch cords and power cords.

FEATURES

•Available in 1 1/2 in., 2 in., 3 in. and 4 in. widths

•Available in 2 in., 3 in. and 4 in. depths; single channel and 6 in. and 8 in.

depths; dual channel

•38-, 45- and 51-split space heights available for all two-post and

four-post racks

•Slotted-finger design allows for horizontal cable access exactly where

it's needed

•Fingers can be easily removed for larger capacity

•Plastic covers provide organization while keeping cables hidden

231109 HCM-1D 1 RMU horizontal cable manager,

large D-Rings

231115 HCM-1DV 1 3/4 in. (1 space) D-Ring style, end rings

231119 HCM-2D 2 RMU horizontal cable manager,

large D-Rings

231123 HCM-2DV 3 1/2 in. (2 space) D-Ring style, end rings

231111 HCM-1DR 1 RMU horizontal cable manager, front and

rear D-Rings

231121 HCM-2DR 2 RMU horizontal cable manager, front and

rear D-Rings

231163 D-RING Wall-mount/rack-mount D-Ring

Plastic Horizontal Cable Managers

Anixter No. Vendor No. Description

421707 PHCM-1-2 One space and 2 in. depth

421708 PHCM-1-4 One space and 2 in. depth

421709 PHCM-2-3 Two space and 3 in. depth

421710 PHCM-1-2-P4 Four pack with one space and 2 in. depth

421711 PHCM-1-4-P4 Four pack with one space and 4 in. depth

421712 PHCM-2-3-P4 Four pack with two space and 3 in. depth

Anixter No. Vendor No. Description

PCD Series Plastic Cable Managers

Anixter No. Vendor No. Description

421713 PCD-1.5X2-4BK 1.5 in. W x 2 in. D x 41RU, single, 4 pieces

421719 PCD-1.5X4-4BK 1.5 IN. W x 4 in. D x 41RU, single, 4 pieces

421720 PCD-2-3-51SC 2 in. W x 3 in. D x 51RU, single

421722 PCD-2-3-45SC 2 in. W x 3 in. D x 45RU, single

421723 PCD-2-3-38SC 2 in. W x 3 in. D x 38RU, single

421724 PCD-2-3-30SC 2 in. W x 3 in. D x 30RU, single

421726 PCD-2-3-25SC 2 in. W x 3 in. D x 25RU, single

421728 PCD-2-3-20SC 2 in. W x 3 in. D x 20RU, single

421731 PCD-2-3-15SC 2 in. W x 3 in. D x 15RU, single

421733 PCD-2-3-12SC 2 in. W x 3 in. D x 12RU, single

421734 PCD-2-3-8SC 2 in. W x 3 in. D x 8RU, single

421735 PCD-3-3-51SC 3 in. W x 3 in. D x 51RU, single

421736 PCD-3-6-51DC 3 in. W x 6 in. D x 51RU, dual

421737 PCD-3-3-45SC 3 in. W x 3 in. D x 45RU, single

421738 PCD-3-6-45DC 3 in. W x 6 in. D x 51RU, dual

421739 PCD-3-3-38SC 3 in. W x 3 in. D x 38RU, single

421740 PCD-3-6-38DC 3 in. W x 6 in. D x 38RU, dual

421741 PCD-4-4-51SC 4 in. W x 4 in. D x 51RU, single

421742 PCD-4-8-51DC 4 in. W x 8 in. D x 51RU, dual

421743 PCD-4-4-45SC 4 in. W x 4 in. D x 45RU, single

421744 PCD-4-8-45DC 4 in. W x 8 in. D x 45RU, dual

421745 PCD-4-4-38SC 4 in. W x 4 in. D x 38RU, single

421746 PCD-4-8-38DC 4 in. W x 8 in. D x 38RU, dual

S04DatB.fm Page 17 Tuesday, December 11, 2012 10:38 PM

4.18

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Middle Atlantic

Security Racks, Consoles and Enclosures

D

Cable Management;Horizontal/16082

Index1.Netw orking Systems //Video Products//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR23409V2-164144.eps

FEATURES

•Dress cables between open frame racks and other enclosures

•Cable strain relief provides more reliable connections

•Multiple cable pass-throughs - top, rear, bottom and sides

•Solid face conceals cables from view

•Hinged panel allows easy entry for and access to cable bundles

Cabinets;Cooling Accessories/3394

Index1.N etworking Systems //Video Produc ts//Video Security Systems

MIDDLE ATLANTIC PRODUCTS PR21788V2-126184.eps

Available with one or two fans in a textured or anodized aluminum finish. Three

space, includes fans and grills. UQFP Series are two space panels with either two or

four fans. Available with or without the LED temperature display, fan-failure

notification and remote over-temp notification.

ANODIZED

TEXTURED

Hinged Horizontal Cable Managers

Anixter No. Vendor No. Description

336582 HHCM-1 1-rack space, hinged horizontal

cable manager

268463 HHCM-2 2-rack space, hinged horizontal

cable manager

QFP Series Quiet Fan Panel Assemblies

Anixter No. Vendor No. Description

231194 QFP-2 2 fan, 5 1/4 in. high (3 space), free air dB

rating < 33 dB

231171 QFP-1 1 fan, 5 1/4 in. high (3 space), free air dB

rating < 30 dB

Anixter No. Vendor No. Description

243125 QTFP-2 2 fan, 5 1/4 in. high (3 space), free air dB

rating < 33 dB

243126 QTFP-1 1 fan, 5 1/4 in. high (three space), free air

dB rating < 30 dB

326261 UQFP-2D 50 cfm fan panel with LED display, remote

failure notification, overtemp alarm

326262 UQFP-4D 100 cfm fan panel with LED display,

remote failure notification,

overtemp alarm

326260 UQFP-2 50 cfm fan panel, overtemp alarm

325467 UQFP-4 100 cfm fan panel, overtemp alarm

S04DatB.fm Page 18 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.19

Security Racks, Consoles and Enclosures

Hoffman

Security Racks, Consoles and Enclosures

./Enclosures;Security and Commercial/14989

Index1.Sup port and Supplies //Phy sical Support Struc ture//Cabine ts

HOFFMAN PR21425V2-119397.eps

Designed for use as a junction box and pull box in commercial and general

applications. Flush covers and door frames must be ordered separately for

flush installations.

FEATURES

•Industry standard: NEMA/EEMAC Type 1

•Flat, removable covers fastened with plated steel screws

•Provision for grounding

•Mounting holes on back of box

•Unique keyhole screw slots in the cover permit removal of the cover without

extracting the screws

•ANSI 61 gray polyester powder paint finish inside and out

Enclosures;NEMA/14990

Index1.Sup port and Su pplies//Physical Support St ructure//Cabinet s

HOFFMAN PR21426V2-119398.eps

Designed for use as a surface-mounted junction box, service box, switch box or

cutout box.

FEATURES

•Industry standard: NEMA/EEMAC Type 1

•14- or 16-gauge steel

•Butt hinges

•Mounting holes on back of box

•Provision for grounding

Screw Cover Type 1 Pull Box

Anixter No. Vendor No. Description

366304 ASE4X4X4 Pull box, 4 in. H x 4 in. W x 4 in. D

ASE6X6X4 ASE6X6X4 Pull box, 6 in. H x 6 in. W x 4 in. D

ASE8X8X4 ASE8X8X4 Pull box, 8 in. H x 8 in. W x 4 in. D

366307 ASE10X10X4 Pull box, 10 in. H x 10 in. W x 4 in. D

366308 ASE12X12X4 Pull box, 12 in. H x 12 in. W x 4 in. D

366309 ASE6X6X6 Pull box, 6 in. H x 6 in. W x 6 in. D

366310 ASE8X8X6 Pull box, 8 in. H x 8 in. W x 6 in. D

366311 ASE10X10X6 Pull box, 10 in. H x 10 in. W x 6 in. D

ASE12X12X6 ASE12X12X6 Pull box, 12 in. H x 12 in. W x 6 in. D

ASE18X18X6 ASE18X18X6 Pull box, 18 in. H x 18 in. W x 6 in. D

366314 ASE24X24X6 Pull box, 24 in. H x 24 in. W x 6 in. D

366315 ASE24X24X8 Pull box, 24 in. H x 24 in. W x 8 in. D

More sizes available and also without knockouts.

For more information contact your sales representative.

Hinged Cover Type 1 Cutout Box

Anixter No. Vendor No. Description

366316 AHE6X6X4 Hinged cover cutout box, 6 in. H x 6 in. W

x 4 in. D

366317 AHE8X6X4 Hinged cover cutout box, 8 in. H x 6 in. W

x 4 in. D

366318 AHE8X8X4 Hinged cover cutout box, 8 in. H x 8 in. W

x 4 in. D

366319 AHE10X8X4 Hinged cover cutout box, 10 in. H x 8 in. W

x 4 in. D

366320 AHE10X10X4 Hinged cover cutout box, 10 in. H x 10 in.

W x 4 in. D

366321 AHE12X10X4 Hinged cover cutout box, 12 in. H x 10 in.

W x 4 in. D

366322 AHE10X8X6 Hinged cover cutout box, 10 in. H x 8 in.

W x 6 in. D

366323 AHE10X10X6 Hinged cover cutout box, 10 in. H x 10 in.

W x 6 in. D

366324 AHE12X12X6 Hinged cover cutout box, 12 in. H x 12 in.

W x 6 in. D

366325 AHE16X16X6 Hinged cover cutout box, 16 in. H x 16 in.

W x 6 in. D

355062 AHE18X18X6 Hinged cover cutout box, 18 in. H x 18 in.

W x 6 in. D

366326 AHE24X18X6 Hinged cover cutout box, 24 in. H x 18 in.

W x 6 in. D

More sizes available. For more information

contact your sales representative.

S04DatB.fm Page 19 Tuesday, December 11, 2012 10:38 PM

4.20

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Hoffman

Security Racks, Consoles and Enclosures

D

Enclosures;Security and Commercial/14991

Index1.Sup port and Supplies //Phy sical Support Struc ture//Cabine ts

HOFFMAN PR21427V2-119396.eps

Designed for use in control and instrumentation applications in areas that do not

require oil-tight and dust-tight specifications. Available perforated back panel

reduces time required to mount components.

FEATURES

•Industry standard: NEMA/EEMAC Type 1

•Flush slotted latch operated with a screwdriver. Optional latches available

•Weldnuts provided for mounting optional panels

•16-gauge steel

•Butt hinges

•Mounting holes on back of enclosure

•ANSI 61 gray polyester powder paint finish inside and out

ENCLOSURES

ACCESSORIES

Type 1 Enclosure

Anixter No. Vendor No. Description

366327 A6N64 Type 1 small enclosure, 6 in. H x 6 in. W

x 4 in. D

366328 A8N64 Type 1 small enclosure, 8 in. H x 6 in. W

x 4 in. D

366329 A8N84 Type 1 small enclosure, 8 in. H x 8 in. W

x 4 in. D

366330 A12N104 Type 1 small enclosure, 12 in. H x 10 in. W

x 4 in. D

366331 A12N124 Type 1 small enclosure, 12 in. H x 12 in. W

x 4 in. D

366332 A8N86 Type 1 small enclosure, 8 in. H x 8 in. W

x 6 in. D

366333 A10N106 Type 1 small enclosure, 10 in. H x 10 in. W

x 6 in. D

366334 A12N126 Type 1 small enclosure, 12 in. H x 12 in. W

x 6 in. D

366335 A14N126 Type 1 small enclosure, 14 in. H x 12 in. W

x 6 in. D

366336 A16N126 Type 1 small enclosure, 16 in. H x 12 in. W

x 6 in. D

366337 A20N16ALP Type 1 medium enclosure, 20 in. H x 16 in.

W x 6.62 in. D

366338 A20N20ALP Type 1 medium enclosure, 20 in. H x 20 in.

W x 6.62 in. D

255674 A24N24ALP Type 1 medium enclosure, 24 in. H x 24 in.

W x 6.62 in. D

366339 A20N12BLP Type 1 medium enclosure, 20 in. H x 12 in.

W x 8.62 in. D

366340 A20N20BLP Type 1 medium enclosure, 20 in. H x 20 in.

W x 8.62 in. D

366341 A24N20BLP Type 1 medium enclosure, 24 in. H x 20 in.

W x 8.62 in. D

366342 A24N24BLP Type 1 medium enclosure, 24 in. H x 24 in.

W x 8.62 in. D

366343 A24N24DLP Type 1 medium enclosure, 24 in. H x 24 in.

W x 12.62 in. D

A42N3609 A42N3609 Type 1 large enclosure, 42 in. H x 36 in. W

x 9.25 in. D

Anixter No. Vendor No. Description

366344 A6N6PP Perforated back panel for 6 in. H x 6 in. W

small enclosure

366345 A8N6PP Perforated back panel for 8 in. H x 6 in. W

small enclosure

366346 A8N8PP Perforated back panel for 8 in. H x 8 in. W

small enclosure

335283 A10N10PP Perforated back panel for 10 in. H x 10 in.

W small enclosure

366347 A12N10PP Perforated back panel for 12 in. H x 10 in.

W small enclosure

366348 A12N12PP Perforated back panel for 12 in. H x 12 in.

W small enclosure

366349 A14N12PP Perforated back panel for 14 in. H x 12 in.

W small enclosure

366350 A16N12PP Perforated back panel for 16 in. H x 12 in.

W small enclosure

366351 A16N12MPP Perforated back panel for 16 in. H x 12 in.

W medium enclosure

366352 A20N12MPP Perforated back panel for 20 in. H x 12 in.

W medium enclosure

366353 A20N16MPP Perforated back panel for 20 in. H x 16 in.

W medium enclosure

366354 A20N20MPP Perforated back panel for 20 in. H x 20 in.

W medium enclosure

366355 A24N20MPP Perforated back panel for 24 in. H x 20 in.

W medium enclosure

331032 A24N24MPP Perforated back panel for 24 in. H x 24 in.

W medium enclosure

A42P36 A42P36 Solid back panel for 42 in. H x 36 in. W

large enclosure

AL12AR AL12AR Optional cylinder lock kit

More sizes available. For more information contact

your sales representative.

Anixter No. Vendor No. Description

S04DatB.fm Page 20 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.21

Security Racks, Consoles and Enclosures

Hoffman

Security Racks, Consoles and Enclosures

Enclosures;NEMA/14999

Index1.Sup port and Supplies //Phy sical Support Struc ture//Cabine ts

HOFFMAN PR21442V2-119600.eps

This convenient combination enclosure, with a perforated-panel assembly, provides a

ready solution for mounting electrical control gear. The enclosed panel is perforated

to reduce the time required to mount components. Use a #8 self-tapping screw to

attach components directly onto the panel, eliminating the need to measure, mark

and drill.

FEATURES

•Industry standard: NEMA/EEMAC Type 1

•Door has key lock quarter-turn latch; two keys included

•Includes removable 16-gauge gray perforated panel

•ANSI 61 gray polyester powder paint finish inside and out

Enclosures;Security and Commercial/15000

Index1.Sup port and Supplies //Phy sical Support Struc ture//Cabine ts

HOFFMAN

Designed for use as a wiring box and junction box. Enclosure provides protection

against rain, sleet and snow in outdoor installations or against dripping water in

indoor installations.

FEATURES

•Industry standard: NEMA/EEMAC Type 3R

•Drip-shield top and seam-free sides, front and back

•Slip-on removable cover fastened with plated steel screws along the

bottom edge

•Provision for padlocking

•No gasketing

•ANSI 61 gray polyester powder paint finish inside and out

SCREW COVER PR21447V2-119584.eps

Type 1 Control Box

Anixter No. Vendor No. Description

A12126T1PP A12126T1PP Type 1 enclosure with lock and panel,

12 in. H x 12 in. W x 6 in. D

A16126T1PP A16126T1PP Type 1 enclosure with lock and panel,

16 in. H x 12 in. W x 6 in. D

A2016AT1PP A2016AT1PP Type 1 enclosure with lock and panel,

20 in. H x 16 in. W x 6.62 in. D

A2420AT1PP A2420AT1PP Type 1 enclosure with lock and panel,

24 in. H x 20 in. W x 6.62 in. D

A3624AT1PP A3624AT1PP Type 1 enclosure with lock and panel,

36 in. H x 24 in. W x 6.62 in. D

A3630AT1PP A3630AT1PP Type 1 enclosure with lock and panel,

36 in. H x 30 in. W x 6.62 in. D

Type 3R Enclosures

Anixter No. Vendor No. Description

366672 A4R44 Type 3R screw cover enclosure, 4 in. H x

4 in. W x 4 in. D

366673 A6R64 Type 3R screw cover enclosure, 6 in. H x

6 in. W x 4 in. D

259511 A8R64 Type 3R screw cover enclosure, 8 in. H x

6 in. W x 4 in. D

259513 A8R84 Type 3R screw cover enclosure, 8 in. H x

8 in. W x 4 in. D

366674 A10R104 Type 3R screw cover enclosure, 10 in. H x

10 in. W x 4 in. D

316679 A12R124 Type 3R screw cover enclosure, 12 in. H x

12 in. W x 4 in. D

366675 A6R66 Type 3R screw cover enclosure, 6 in. H x

6 in. W x 6 in. D

366676 A8R86 Type 3R screw cover enclosure, 8 in. H x

8 in. W x 6 in. D

366677 A10R106 Type 3R screw cover enclosure, 10 in. H x

10 in. W x 6 in. D

366678 A12R126 Type 3R screw cover enclosure, 12 in. H x

12 in. W x 6 in. D

366679 A16R126 Type 3R screw cover enclosure, 16 in. H x

12 in. W x 6 in. D

366680 A18R186 Type 3R screw cover enclosure, 18 in. H x

18 in. W x 6 in. D

366681 A24R246 Type 3R screw cover enclosure, 24 in. H x

24 in. W x 6 in. D

366682 A12R128 Type 3R screw cover enclosure, 12 in. H x

12 in. W x 8 in. D

366683 A18R188 Type 3R screw cover enclosure, 18 in. H x

18 in. W x 8 in. D

366684 A24R248 Type 3R screw cover enclosure, 24 in. H x

24 in. W x 8 in. D

Continued on next page >>

S04DatB.fm Page 21 Tuesday, December 11, 2012 10:38 PM

4.22

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Hoffman

Security Racks, Consoles and Enclosures

D

(continued)

Type 3R Enclosures

HINGED COVER PR21448V2-119589.eps

Enclosures;NEMA/15001

Index1.Sup port and Supplies //Phy sical Support Struc ture//Cabine ts

HOFFMAN

Designed as a wall-mount telephone-termination cabinet that is suited for outdoor

and indoor use. These cabinets are also used for mounting and protecting

telecommunications circuit accessories, cross-connect terminal block assemblies,

maintenance-terminal modules, cable-splice enclosures, network-interface devices,

wireguide assemblies and telephone protectors.

FEATURES

•Industry standard: NEMA Type 3R

•Lift-off hinges

•Four-position grounding bar #14-2/0

•Tamper-resistant quarter-turn latch, 7 mm square drive; opens with

5/16 12-point socket

•Padlock hasp

•3/4 in.-thick plywood panel

•ANSI 61 gray polyester powder paint finish inside and out

SINGLE-DOOR PR21455V2-120877.eps

DOUBLE-DOOR PR21443V2-119599.eps

Enclosures;Security and Commercial/15003

Index1.Sup port and Su pplies//Physical Support St ructure//Cabinet s

HOFFMAN PR21444V2-119582.eps

Provides a secure enclosure for wireless equipment in both indoor and outdoor

locations. Ideal for locations such as tunnels, floor vaults, marinas, outside walls

and rooftops. Fiberglass construction allows Wi-Fi and WLAN signals to pass through

Anixter No. Vendor No. Description

366685 A6R44HCR Type 3R hinged cover enclosure, 6 in. H x

4 in. W x 4 in. D

317368 A6R64HCR Type 3R hinged cover enclosure, 6 in. H x

6 in. W x 4 in. D

366686 A8R64HCR Type 3R hinged cover enclosure, 8 in. H x

6 in. W x 4 in. D

366687 A8R86HCR Type 3R hinged cover enclosure, 8 in. H x

8 in. W x 6 in. D

366688 A10R86HCR Type 3R hinged cover enclosure, 10 in. H x

8 in. W x 6 in. D

366689 A12R106HCR Type 3R hinged cover enclosure, 12 in. H x

10 in. W x 6 in. D

366690 A12R126HCR Type 3R hinged cover enclosure, 12 in. H x

12 in. W x 6 in. D

366691 A12R1210HCR Type 3R hinged cover enclosure, 12 in. H x

12 in. W x 10 in. D

Type 3R Telephone Cabinet

Anixter No. Vendor No. Description

366692 ATC26R248 Type 3R telephone cabinet, single-door,

26 in. H x 24 in. W x 8 in. D

366693 ATC36R248 Type 3R telephone cabinet, single-door,

36 in. H x 24 in. W x 8 in. D

366694 ATC36R369 Type 3R telephone cabinet, single-door,

36 in. H x 36 in. W x 9 in. D

366697 ATC36R3612 Type 3R telephone cabinet, single-door,

36 in. H x 36 in. W x 12 in. D

366698 ALTC3R Locking T-handle accessory

Anixter No. Vendor No. Description

366695 ATC48R369 Type 3R telephone cabinet, double-door,

48 in. H x 36 in. W x 9 in. D

366696 ATC48R489 Type 3R telephone cabinet, double-door,

48 in. H x 48 in. W x 9 in. D

366698 ALTC3R Locking T-handle accessory

More sizes available. For more information contact

your sales representative.

Type 4x Fiberglass Hinged Cover Wi-Fi Cabinet

S04DatB.fm Page 22 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.23

Security Racks, Consoles and Enclosures

Hoffman

Security Racks, Consoles and Enclosures

the cabinet unimpeded. Lightweight for easy mounting. Available with solid and

window covers. Covers are secured with screws; optional quick-release latches

are available.

FEATURES

•Industry standard: NEMA/EEMAC Type 4, 4X, 12 and 13

•Enclosures and cover made of molded fiberglass polyester that resists

chemicals and temperature change

•Includes a 3/4 in. plywood panel for mounting equipment

•Seamless foam-in-place gasket assures watertight and dust-tight seal

•Screw cover enclosures are secured with two captivated Type 316 stainless steel

slotted cross point cover screws

Enclosures;Security and Commercial/16100

Index1.Sup port and Supplies //Phy sical Support Struc ture//Cabine ts

HOFFMAN PR23342V2-163392.eps

ACCESSPLUS II Cabinets provide security, equipment access, cooling and support for

network and other 19 in. rack-mount equipment. The cabinet has three components:

front door, center section and wall section. Double-hinged for easy equipment

access; center section provides 19 in. rack mounting per EIA universal spacing and is

accessed through the front door or swing the center section away from the wall

section for rear access.

FEATURES

•Industry standard: NEMA Type 1

•Front door has either a solid steel or hardened, tinted safety-glass window door

for superior scratch resistance

•Center section easily removed from rear section; tool-less one-person

installation possible

•Self-locking center-to-wall section latches in two locations

•Front access to all latches (no exposed side latches); cabinet can be installed

tightly in corners

•Vented sides provide cross-flow ventilation to improve heat dissipation

•RAL 9005 black light-textured, low-gloss polyester powder paint

Enclosures;Security and Commercial/15005

Index1.Sup port and Su pplies//Physical Support St ructure//Cabinet s

HOFFMAN

This Hoffman double-hinged wall-mounted cabinet is ideal for protecting 19 in.

network equipment from falling dirt, splashing water, dust and other contaminants.

This versatile cabinet mounts to a wall or can be pole-mounted with the optional

pole-mounting kit. Designed to hold multiple pieces of voice/data equipment

comfortably, it can be mounted to be left- or right-hinged and comes completely

assembled and ready to mount.

FEATURES

•Industry standard: NEMA/EEMAC Type 4 or 12

•Solid door provides complete physical and visual protection

•Window door, made with scratch-resistant safety glass, allows equipment

monitoring without opening the door

•Double-hinged for easy equipment access

•Foam-in-place seamless gasket around door seals against outdoor air

infiltration and is non-absorbing and chemical resistant

•Type 12 cabinets have solid or window doors and a locking wing knob with two

keys. They provide security and convenience in indoor applications

•Type 4 cabinets have solid doors and a padlock capable 1/4-turn latch. They

provide easy operation and locking options in indoor and outdoor applications

•One set of adjustable tapped 19 in. rack angles included

•RAL 7035 light gray textured, low-gloss polyester powder paint

Anixter No. Vendor No. Description

366699 D664CHSCFGP Type 4x, fiberglass, Wi-Fi enclosure, solid

cover, 6 in. H x 6 in. W x 4 in. D

317883 D16148CHSCFGP Type 4x, fiberglass, Wi-Fi enclosure, solid

cover, 16 in. H x 14 in. W x 8 in. D

366700 D181610CHSCFGP Type 4x, fiberglass, Wi-Fi enclosure, solid

cover, 18 in. H x 16 in. W x 10 in. D

Also available with window cover. For more information contact

your sales representative.

ACCESSPLUS II Type 1 Double-hinged Wall-mount Cabinets

Anixter No. Vendor No. Description

394585 EWMW242418 ACCESSPLUS II, window door, 24 in. H x

24 in. W x 18 in. D, 12RU

394586 EWMW362418 ACCESSPLUS II, window door, 36 in. H x

24 in. W x 18 in. D, 19RU

394587 EWMW482418 ACCESSPLUS II, window door, 48 in. H x

24 in. W x 18 in. D, 26RU

390048 EWMW242425 ACCESSPLUS II, window door, 24 in. H x

24 in. W x 25 in. D, 12RU

390051 EWMW362425 ACCESSPLUS II, window door, 36 in. H x

24 in. W x 25 in. D, 19RU

390053 EWMW482425 ACCESSPLUS II, window door, 48 in. H x

24 in. W x 25 in. D, 26RU

394588 EWMS242418 ACCESSPLUS II, solid door, 24 in. H x 24 in.

W x 18 in. D, 12RU

394589 EWMS362418 ACCESSPLUS II, solid door, 36 in. H x 24 in.

W x 18 in. D, 19RU

394590 EWMS482418 ACCESSPLUS II, solid door, 48 in. H x 24 in.

W x 18 in. D, 26RU

394591 EWMS242425 ACCESSPLUS II, solid door, 24 in. H x 24 in.

W x 25 in. D, 12RU

394592 EWMS362425 ACCESSPLUS II, solid door, 36 in. H x 24 in.

W x 25 in. D, 19RU

394593 EWMS482425 ACCESSPLUS II, solid door, 48 in. H x 24 in.

W x 25 in. D, 26RU

More sizes and configurations available. For more information contact

your sales representative.

PROTEK DH Type 4 and Type 12 Double-hinged Wall-mount Cabinet

Continued on next page >>

S04DatB.fm Page 23 Tuesday, December 11, 2012 10:38 PM

4.24

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Hoffman

Security Racks, Consoles and Enclosures

D

(continued)

PROTEK DH Type 4 and Type 12 Double-hinged

Wall-mount Cabinet

PROTEK DH WALL-MOUNT CABINETS PR21446V2-119588.eps

PROTEK DH A/C PACKAGE PR23344V2-163397.eps

PROTEK Air-Conditioner Packages provide cool air to internal equipment when high

ambient air temperatures exist (up to 130°F). A/C packages include an 800 Btu

indoor/outdoor air conditioner that operates on 115 V AC with 5-15P plug.

Enclosures;NEMA/16102

Index1.Sup port and Su pplies//Physical Support St ructure//Cabinet s

HOFFMAN PR23343V2-163395.eps

These cabinets provide physical protection and access control to DVR, 19 in.

equipment or other equipment. Mount the cabinet vertically or horizontally.

FEATURES

•Industry standard: NEMA Type 1

•Top cover has tool-less removal, is captivated by door and secured by keylock,

providing easy access and installation

•Solid front door has 180-degree opening continuous hinge

•Vented sides dissipate heat from equipment

•A fan-ready cutout is provided

•19 in. rack angles and hardware included

•Doors and body made of 18-gauge steel; top cover is 16-gauge steel

•RAL 9005 black, light-textured, low-gloss polyester powder paint

Anixter No. Vendor No. Description

366701 PTDHW162415G PROTEK, Type 12, window door, 16 in. H x

24 in. W x 15 in. D, 7RU

366702 PTDHW202415G PROTEK, Type 12, window door, 20 in. H x

24 in. W x 15 in. D, 10RU

366703 PTDHW242415G PROTEK, Type 12, window door, 24 in. H x

24 in. W x 15 in. D, 12RU

366704 PTDHW242424G PROTEK, Type 12, window door, 24 in. H x

24 in. W x 24 in. D, 12RU

366705 PTDHW362415G PROTEK, Type 12, window door, 36 in. H x

24 in. W x 15 in. D, 19RU

366706 PTDHW362424G PROTEK, Type 12, window door, 36 in. H x

24 in. W x 24 in. D, 19RU

366707 PTDHW482415G PROTEK, Type 12, window door, 48 in. H x

24 in. W x 15 in. D, 26RU

331734 PTDHW482424G PROTEK, Type 12, window door, 48 in. H x

24 in. W x 24 in. D, 26RU

366709 PTDHS242424G PROTEK, Type 12, solid door, 24 in. H x

24 in. W x 24 in. D, 12RU

366710 PTDHS362424G PROTEK, Type 12, solid door, 36 in. H x

24 in. W x 24 in. D, 19RU

366711 PTDHS482424G PROTEK, Type 12, solid door, 48 in. H x

24 in. W x 24 in. D, 26RU

366712 PTDHS242424G4 PROTEK, Type 4, solid door, 24 in. H x

24 in. W x 24 in. D, 12RU

366713 PTDHS362424G4 PROTEK, Type 4, solid door, 36 in. H x

24 in. W x 24 in. D, 19RU

366714 PTDHS482424G4 PROTEK, Type 4, solid door, 48 in. H x

24 in. W x 24 in. D, 26RU

Anixter No. Vendor No. Description

394618 PTDHW242429GA PROTEK AC package, Type 12, window door,

24 in. H x 24 in. W x 29 in. D, 12RU

394619 PTDHW362429GA PROTEK AC package, Type 12, window door,

36 in. H x 24 in. W x 29 in. D, 19RU

394620 PTDHW482429GA PROTEK AC package, Type 12, window door,

48 in. H x 24 in. W x 29 in. D, 26RU

394621 PTDHS242429GA4 PROTEK AC package, Type 4, solid door,

24 in. H x 24 in. W x 29 in. D, 12RU

394623 PTDHS362429GA4 PROTEK AC package, Type 4, solid door,

36 in. H x 24 in. W x 29 in. D, 19RU

394624 PTDHS482429GA4 PROTEK AC package, Type 4, solid door,

48 in. H x 24 in. W x 29 in. D, 26RU

More sizes and configurations available.

For more information contact your sales representative.

DVR and 19 in. Rack Equipment Cabinet

Anixter No. Vendor No. Description

394599 DVR4U 4RU cabinet, 9.5 in. H x 21.7 in. W x

18.4 in. D

394604 DVR6U 6RU cabinet, 13 in. H x 21.7 in. W x

18.4 in. D

394598 A4AXFNPGQ 4 in. fan, 115 V AC, with plug

S04DatB.fm Page 24 Tuesday, December 11, 2012 10:38 PM

Products. Technology. Services. Delivered Globally.

1.800.ANIXTER • anixter.com 4.25

Security Racks, Consoles and Enclosures

Winsted

Security Racks, Consoles and Enclosures

./Consoles;Surveillance/16117

Index1.Netw orking Systems //Video Products//Video Security Systems

WINSTED PR23367V2-163594.eps

Sight-Line consoles allow flexibility and expandability in console configurations to fit

any space requirement, user need or budget. In today's demanding control rooms,

monitor viewing angles and operator sight lines are critical to long-term success. To

address this issue, Sight-Line consoles feature Winsted's new integrated Versa-Trak

monitor-array system, which offers the ultimate in adjustability. The Versa-Trak

system permits users to optimize, and easily modify, sight lines and viewing angles

based on personal needs. Sight-Line is a beautiful console with a feature-set second

to none. The W5701 is just a sample of Sight-Line's flexibility. Let Winsted design the

perfect solution for you.

FEATURES

•Versa-Trak monitor-mounting system

•Integrated data/power provisions

•Easy-access cable management

•Doors with CPU shelf for convenient swing-out access

Consoles;Surveillance/17281

Index1.Netw orking Systems //Video Products//Video Security Systems

WINSTED PR28593V2-209524.eps

Winsted's compact console features a high-density profile designed for a

high-performance world. Insight's overall depth of 32 in. saves valuable space and

maximizes control room functionality. Our engineers reduced the depth of both the

chase and the work surface on the popular Sight-Line console to create a solution

with a more efficient footprint that meets ergonomic standards, and provides ample

desktop workspace. This configuration is just a sample of Insight's flexibility. Whether

you need a single workstation, or a complete control room, Insight is the perfect

solution. Let Winsted design a console just for you.

FEATURES

•Versa-Trak monitor-mounting system

•Integrated data/power provisions

•Easy-access cable management

•Doors with CPU shelf for convenient swing-out access

Consoles;Surveillance/17282

Index1.N etworking Systems //Video Produc ts//Video Security Systems

WINSTED PR28594V2-209522.eps

Winsted's sit/stand console offers three programmable height settings for ultimate

versatility and optimum comfort in any control room setting. This completely

redesigned sit/stand console includes electric-lift legs, which enable operators to

quickly and easily adjust the work-surface height from 29 in. to 44 in. with the push

of a button. Two-, three- and four-leg systems are available with load capacities of

300 lb., 450 lb. and 600 lb. respectively. This is just one example of an Ascend

sit/stand solution. Let Winsted design a console specifically for you, and take your

control room to new heights with Ascend.

FEATURES

•Electric-lift legs with three programmable height settings

•Versa-Trak monitor-mounting system

•Easy-access cable management

•Doors with CPU shelf for convenient swing-out access

Consoles;Surveillance/16113

Index1.N etworking Systems //Video Produc ts//Video Security Systems

WINSTED PR23363V2-163589.eps

This unique workstation fits every environment from multimedia, to video, to security

and office settings. Bring your work envelope closer to you. Encompass your

surroundings with this workstation for maximum work performance. Choose from

popular in-stock components, or create a customized look. Designed for efficient

workspace comfort. The E4858 is just one example of Winsted's Encompass II product

line. Choose from many other preconfigured models, or let Winsted design the perfect

solution for you.

FEATURES

•Upscale look with exceptional value

•Modular and easy to reconfigure

•Wide variety of accessories

•In stock and ready to ship

W5701 Sight-Line Console

Contact your local sales representative for ordering information.

Insight Console

Contact your local sales representative for ordering information.

Ascend Sit/Stand Console

Contact your local sales representative for ordering information.

E4858 Encompass II Workstation

Contact your local sales representative for ordering information.

S04DatB.fm Page 25 Tuesday, December 11, 2012 10:38 PM

4.26

Request the latest literature and guides from Anixter.

1.800.ANIXTER • anixter.com/literature

Security Racks, Consoles and Enclosures

Winsted

Security Racks, Consoles and Enclosures

D

Consoles;Surveillance/16114

Index1.Netw orking Systems //Video Products//Video Security Systems

WINSTED PR23364V2-163586.eps

The E4860 provides a compact, economical solution for supporting your electronics.

This ergonomic workstation enhances the workspace environment while maximizing

both operator performance and operator comfort. Customized workstations offer a

personal touch, with expanding possibilities in the future. The E4860 is just one

option. Winsted has many other workstations to choose from.

FEATURES

•Dual 14U rack-mount cabinets

•Two quad-monitor mounts

•Durable work surface with contour edge molding

•In stock and ready to ship

Monitor Walls;Surveillance/16115

Index1.Netw orking Systems //Video Products//Video Security Systems

WINSTED PR23365V2-163583.eps

Winsted's M-View is a custom-built, extruded-aluminum monitor wall that is flexible

and completely modular. Each M-View is designed and manufactured to support your

specific monitor configuration and fit in your unique space. The M-View is fabricated

from lightweight, high-strength extruded aluminum with a black anodized finish. The

monitor wall can support any size LCD and/or plasma screen and can be configured

as an in-line, concave or convex mounting solution. The M-View seamlessly integrates

technology and space to optimize viewing angles, improve operator comfort and

increase productivity. This configuration is just an example of M-View's flexibility.

FEATURES

•In-stock and custom monitor walls available

•Easy to reconfigure and expand with changing technology

•Constructed of black anodized extruded aluminum

•Integrated power strips and cable management

Consoles;Surveillance/16116

Index1.N etworking Systems //Video Produc ts//Video Security Systems

WINSTED PR23366V2-163593.eps

LCD/3 Consoles target the low-profile demands of today's command centers,

reception areas, surveillance areas and control rooms. Put your LCD application into

single-, double- or triple-tier modular consoles. LCD/3 Consoles are ergonomically

designed for the flat-panel market and expand easily with your growing needs. The

G5305 is just one example of Winsted's LCD/3 product line. Choose from several

other preconfigured models.

FEATURES

•Low-profile for unobstructed view over console

•Ergonomically correct viewing angle

•EIA 19 in. rack-mount openings

•Many user-friendly accessories to choose from

Consoles;Surveillance/18198

Index1.N etworking Systems //Video Produc ts//Video Security Systems

WINSTED PR35080V2-268584.eps

Winsted's Slat-Wall console is built on the same foundation as the award-winning

Sight-Line console. The same world-class feature set is incorporated with slat-wall to

provide added versatility and an element of privacy. The Slat-Wall is 15 in. tall and

constructed of high-quality extruded 6105-T5 aluminum. The black anodized finish is

attractive and smooth to the touch. A variety of monitor mounts and user-friendly

accessories are available to mount on the Slat-Wall. Slat-Wall consoles are modular,

reconfigurable and expandable. Let Winsted design the perfect solution for your

security control room.

FEATURES

•Slat-wall mounting system

•Integrated data/power provisions

•Easy-access cable management

•Doors with CPU shelf for convenient swing-out access

E4860 Surveillance Workstation

Contact your local sales representative for ordering information.

M-View Monitor Wall

Contact your local sales representative for ordering information.

G5305 LCD/3 Console

Contact your local sales representative for ordering information.

W5831 Slat-Wall Console

Contact your local sales representative for ordering information.

S04DatB.fm Page 26 Tuesday, December 11, 2012 10:38 PM
