PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number: 1300970201
Status: Active
Overview: Strain-Relief Cord Grips
Description: Deluxe Cord Grips Strain Relief, 3/4" NPT, 45° Angle Male, Cable Diameter
6.35-9.53mm (.250-.375")
Documents:
Drawing (PDF) RoHS Certificate of Compliance (PDF)
Agency Certification
CSA LR32159
UL E76954
General
Product Family Cable Grips
Series 130097
Eye Type N/A
Hazardous Locations Class I, Div. 2, Class II, Div. 1 and 2, Class III, Div. 1
and 2
NEMA Rating NEMA 4
O-Ring N/A
Overview Strain-Relief Cord Grips
Product Name Deluxe Cord
Type Strain Relief Grip
UPC 78678836317
Use With 3/4" NPT MAX-LOC® Lock Nut 130099-0144 , 3/4" NPT
MAX-LOC® Gasket Sealing Ring 130099-0150 , 3/4"
NPT MAX-LOC® O-Ring 130180-0333
Woodhead Yes
Physical
Approximate Break Strength N/A
Bale Length N/A
Body Style 45° Angle
Cable Diameter 6.35-9.53mm (.250-.375")
Color - Grommet N/A
Gender Male
Material - Body Aluminum
Material - Grip Stainless Steel
Mesh Length N/A
Number of Holes N/A
Thread Size 3/4" NPT
Material Info
Old Part Number 36317
Reference - Drawing Numbers
Sales Drawing SD-130097-110
Series image - Reference only
EU ELV
Not Reviewed
EU RoHS China RoHS
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS Not Reviewed
ELV Not Reviewed
Search Parts in this Series
130097 Series
