ECONOMY RECESSED LIGHTING
A new view
on economy
lighting
Take a new view on economy lighting with VuLite from Juno Lighting Group. VuLite is an economic
alternative for recessed lighting offering a selection of 4”, 5” and 6” downlights for use in residential and
light commercial applications. The line includes a range of popular trim selections including baffles, cones,
adjustables and lensed, providing choices to meet the needs of various lighting applications. Economy does
not mean sacrificing the quality and standards you have come to expect from Juno Lighting Group. You can
buy and install VuLite products with total confidence knowing that all products are designed and tested to
meet UL requirements and are backed by the leader in residential recessed lighting.
4” Housings and Trims
V4ICW
V4ICLVW
V4TCW
V4TCLVW
Baffle Clear Cone Gimbal Ring Eyeball Flat Lens Shower
Viewing economy recessed
downlighting in a different light
Line Voltage Housings
V4TCRLVW
Low Voltage Housings
V4TCRW
4” Trims
VuLite Product Offering
2
Baffle
6” Housings and Trims
V6ICW and V6ICNW V6ICRW
Line Voltage Housings
V6TCW
6” Trims
V6TCRW
Clear Cone Full Cone
Eyeball Flat Lens Shower Drop Opal Open Frame
Full Baffle
Baffle
5” Housings and Trims
V5ICW V5ICRW
Line Voltage Housings
V5TCW
5” Trims
V5TCRW
Clear Cone White Cone
R/PAR20 Eyeball PAR30 Eyeball Flat Lens
3
V4TCW
4” TC New Construction
Requires 3” spacing from insulation.
Dimensions:
12-1/8”L x 13-3/8”W x 5-1/2”H
Ceiling Cutout: 4-1/2” Dia.
4” Line Voltage Housings and Trims
IC Housing TC Housings
V4ICW
4” IC New Construction
Energy efficient double wall
housing. May be covered
with insulation.
Dimensions:
12”L x 13-3/8”W x 6”H
Ceiling Cutout: 4-1/2” Dia.
Cone
V4017C-WH: Clear
Aperture: 3-7/8”
Outer Diameter: 5”
VuLite Housing: Lamp Wattage/Type
V4ICW, V4TCW, V4TCRW: 50W PAR20, 50W R20
Juno Compatible Housing: Lamp Wattage/Type
IC1, IC1P, TC1, TC1R: 50W PAR20, 50W R20
Baffle
V4034W-WH: White
V4034B-WH: Black
Aperture: 3-7/8”
Outer Diameter: 5”
VuLite Housing: Lamp Wattage/Type
V4ICW: 50W PAR20, 30W R20
V4TCW, V4TCRW: 50W PAR20, 50W R20
Juno Compatible Housing: Lamp Wattage/Type
IC1P, TC1, TC1R: 50W PAR20, 50W R20
IC1: 50W PAR20, 30W R20
Eyeball
V4018-WH: White
Outer Diameter: 5”
VuLite Housing: Lamp Wattage/Type
V4ICW, V4TCW, V4TCRW: 60W PAR16, 40W R16
Juno Compatible Housing: Lamp Wattage/Type
IC1, IC1P, TC1, TC1R: 60W PAR16, 40W R16
Gimbal Ring
V4010-WH: White
V4010-BN: Brushed Nickel
Outer Diameter: 5”
VuLite Housing: Lamp Wattage/Type
V4ICW, V4TCW, V4TCRW: 50W PAR20
Juno Compatible Housing: Lamp Wattage/Type
IC1P, TC1, TC1R: 50W PAR20
Stippled Opal Lens Shower
with Reflector
V4012-WH: White
Outer Diameter: 5”
VuLite Housing: Lamp Wattage/Type
V4ICW: 35W PAR20, 30W R20
V4TCW, V4TCRW: 50W PAR20, 50W R20
Juno Compatible Housing: Lamp Wattage/Type
(Remove reflector when using Juno IC1 housing)
IC1: 35W PAR20, 30W R20
IC1P: 50W PAR20, 30W R20
TC1, TC1R: 50W PAR20, 50W R20
V4TCRW
4” TC Remodel
Requires 3” spacing from insulation.
Dimensions:
12”L x 4-1/4”W x 5-1/2”H
Ceiling Cutout: 4-3/8” Dia.
4” Compatible Trims - Line Voltage
4
Accessories: VALG4 Airloc® gasket kit for V4IC housing when an Airloc® trim is not being used.
G2405 Set of (4) T-bar clips for installation in suspended ceilings.
VuLite IC housings meet IECC Energy Code requirements per STM E283.
Air-Loc® rated trims are pre-gasketed for minimum air leakage with IC housings.
Cone with Regressed Gimbal Ring
V4047C-WH: Clear
Aperture: 3-1/2”
Outer Diameter: 5”
VuLite Housing: Lamp Wattage/Type
V4ICLVW, V4TCLVW, V4TCRLVW: 50W MR16
Juno Compatible Housing: Lamp Wattage/Type
IC44N, TC44, TC44V, TC44R, TC47, TC47V: 50W MR16
V4TCLVW
4” TC Low Voltage New Construction
50W Housing includes 50VA,
12V thermally protected magnetic
transformer. Requires 3” spacing
from insulation.
Dimensions:
12-1/8”L x 13-3/8”W x 5-1/2”H
Ceiling Cutout: 4-1/2” Dia.
4” Low Voltage Housings and Trims
IC Housing TC Housings
V4ICLVW
4” IC Low Voltage New Construction
50W Energy efficient double wall
housing includes 50VA, 12V
thermally protected magnetic
transformer. May be covered
with insulation.
Dimensions:
18-1/2”L x 13-3/8”W x 7-5/8”H
Ceiling Cutout: 4-1/2” Dia.
Baffle with Regressed Gimbal Ring
V4044W-WH: White
V4044B-WH: Black
Aperture: 3-1/2”
Outer Diameter: 5”
VuLite Housing: Lamp Wattage/Type
V4ICLVW, V4TCLVW, V4TCRLVW: 50W MR16
Juno Compatible Housing: Lamp Wattage/Type
IC44N, TC44, TC44V, TC44R, TC47, TC47V: 50W
MR16
Eyeball with Baffle
V4048-WH: White
Outer Diameter: 5”
VuLite Housing: Lamp Wattage/Type
V4ICLVW, V4TCLVW, V4TCRLVW: 50W MR16
Juno Compatible Housing: Lamp Wattage/Type
IC44N, TC44, TC44V, TC44R, TC47, TC47V: 50W MR16
Gimbal Ring
V4040-WH: White
V4040-BN: Brushed Nickel
Outer Diameter: 5”
VuLite Housing: Lamp Wattage/Type
V4ICLVW, V4TCLVW, V4TCRLVW: 50W MR16
Juno Compatible Housing: Lamp Wattage/Type
IC44N, TC44, TC44V, TC44R, TC47, TC47V: 50W MR16
Stippled Opal Lens Shower
V4041-WH: White
Outer Diameter: 5”
VuLite Housing: Lamp Wattage/Type
V4ICLVW, V4TCLVW, V4TCRLVW: 50W MR16
Juno Compatible Housing/Lamp:
IC44N, TC44, TC44V, TC44R, TC47, TC47V: 50W MR16
4” Compatible Trims - Low Voltage
5
Accessory: G2405 Set of (4) T-bar clips for installation
in suspended ceilings.
VuLite IC housings meet IECC Energy Code requirements per STM E283.
Air-Loc® rated trims are pre-gasketed for minimum air leakage with IC housings.
V4TCRLVW
4” TC Low Voltage Remodel
50W Housing includes 50VA,
12V magnetic transformer.
Requires 3” spacing
from insulation.
Dimensions:
14-1/2”L x 4-1/4”W x 5-1/2”H
Ceiling Cutout: 4-3/8” Dia.
Baffle
V2015W-WH: White
V2015B-WH: Black
Aperture: 4-3/4”
Outer Diameter: 6-1/4”
VuLite Housing: Lamp Wattage/Type
V5ICW, V5ICRW: 65W BR30, 75W PAR30L,
75W PAR30 w/socket extender, 50W PAR30 (black only)
V5TCW, V5TCRW: 85W BR30, 75W PAR30L,
40W A19 (white only), 75W PAR30 (black only or use socket
extender with white)
Juno Compatible Housing: Lamp Wattage/Type
IC20, IC20R: 40W A19, 65W BR30, 75W PAR30L,
75W PAR30 w/socket extender
IC20N: 65W BR30
TC20, TC20R: 60W A19, 85W BR30, 75W PAR30L,
75W PAR30 w/socket extender
V5TCW
5” TC New Construction
Requires 3” spacing from insulation.
Dimensions:
11-7/8”L x 13-3/8”W x 7-1/2”H
Ceiling Cutout: 5-5/8” Dia.
V5TCRW
5” TC Remodel
Requires 3” spacing from insulation.
Dimensions:
12-1/2”L x 5-7/8”W x 7-1/2”H
Ceiling Cutout: 5-1/2” Dia.
IC Housings TC Housings
V5ICW
5” IC New Construction
Energy efficient housing.
May be covered with insulation.
Dimensions:
11-7/8”L x 13-3/8”W x 7-1/2”H
Ceiling Cutout: 5-5/8” Dia.
V5ICRW
5” IC Remodel
Energy efficient housing.
May be covered with insulation.
Dimensions:
14-3/8”L x 6-3/4”W x 7-1/2”H
Ceiling Cutout: 5-1/2” Dia.
Cone
V2016C-WH: Clear
V2016W-WH: White
Aperture: 4-3/4”
Outer Diameter: 6-1/4”
VuLite Housing: Lamp
Wattage/Type
V5ICW, V5ICRW: 65W BR30, 75W PAR30L,
75W PAR30 w/socket extender
V5TCW, V5TCRW: 85W BR30, 75W PAR30L,
75W PAR30 w/socket extender, 60W A19 (clear only),
40W A19 (white only)
Juno Compatible Housing: Lamp Wattage/Type
IC20, IC20R: 40W A19, 65W BR30, 75W PAR30L,
75W PAR30 w/socket extender
IC20N: 65W BR30
TC20, TC20R: 60W A19, 85W BR30, 75W PAR30L,
75W PAR30 w/socket extender
5” Compatible Trims
6
5” Line Voltage Housings and Trims
Accessories: VALG4 Airloc® gasket kit for V4IC housing when an Airloc® trim is not being used.
G2405 Set of (4) T-bar clips for installation in suspended ceilings.
VuLite IC housings meet IECC Energy Code requirements per STM E283.
Air-Loc® rated trims are pre-gasketed for minimum air leakage with IC housings.
VuLite IC housings meet IECC Energy Code requirements per STM E283.
Air-Loc® rated trims are pre-gasketed for minimum air leakage with IC housings.
5” Line Voltage Housings and Trims
5” Compatible Trims (continued)
R/PAR20 Eyeball
V2029-WH: White
Outer Diameter: 6-1/4”
VuLite Housing: Lamp Wattage/Type
V5ICW, V5ICRW: 50W R20, 50W PAR20
V5TCW, V5TCRW: 50W R20, 50W PAR20
Juno Compatible Housing: Lamp Wattage/Type
IC20, IC20N, IC20R, TC20, TC20R: 50W PAR20, 50W R20
PAR30 Eyeball
V2030-WH: White
Outer Diameter: 6-1/2”
VuLite Housing: Lamp Wattage/Type
V5ICW, V5ICRW: 75W PAR30
V5TCW, V5TCRW: 75W PAR30
Juno Compatible Housing: Lamp Wattage/Type
IC20, IC20N, IC20R, TC20, TC20R: 75W PAR30
Flat Lens Shower
with Reflector
V2010-WH: White
Outer Diameter: 6-1/2”
VuLite Housing: Lamp Wattage/Type
V5ICW, V5ICRW: 35W PAR30L
V5TCW, V5TCRW: 75W PAR30L, 90W A19
Juno Compatible Housing: Lamp Wattage/Type
IC20, IC20R: 35W PAR30L & 40W A19
IC20N: 35W PAR30L
TC20, TC20R: 75W PAR30L & 90W A19
VuLite IC housings meet IECC Energy Code requirements per STM E283.
Air-Loc® rated trims are pre-gasketed for minimum air leakage with IC housings.
7
Conical Baffle
V3024W-WH: White
V3024B-WH: Black
Aperture: 5-3/4”
Outer Diameter: 7-3/4”
VuLite Housing: Lamp Wattage/Type
V6ICW, V6ICRW: 50W PAR30, 75W PAR30L, 65W BR30
V6TCW, V6TCRW: 75W PAR30/PAR30L, 65W BR30,
120W BR40
Juno Compatible Housing: Lamp Wattage/Type
IC22, IC22R: 50W PAR30, 75W PAR30L, 65W BR30
IC2, TC2, TC2R: 75W PAR30 w/socket extender,
75W PAR30L, 65W BR30
V6TCW
6” TC New Construction
Requires 3” spacing from insulation.
Dimensions:
13-3/4”L x 13-3/8”W x 7-3/8”H
Ceiling Cutout: 6-1/2” Dia.
V6TCRW
6” TC Remodel
Requires 3” spacing from insulation.
Dimensions:
13-3/4”L x 6-3/4”W x 7-3/8”H
Ceiling Cutout: 6-1/4” Dia.
IC Housings TC Housings
V6ICW 6” IC New Construction
V6ICNW 6” IC New Construction
with Floating Socket
Energy efficient housing.
May be covered with insulation.
Dimensions:
13-3/4”L x 13-3/8”W x 7-3/8”H
Ceiling Cutout: 6-1/2” Dia.
V6ICRW
6” IC Remodel
Energy efficient housing.
May be covered with insulation.
Dimensions:
13-3/4”L x 6-3/4”W x 7-3/8”H
Ceiling Cutout: 6-1/4” Dia.
Clear Cone
V3027C-WH: Clear
Aperture: 5-3/4”
Outer Diameter: 7-3/4”
VuLite Housing: Lamp Wattage/Type
V6ICW, V6ICRW: 50W PAR30, 75W PAR30L, 65W BR30
V6TCW, V6TCRW: 75W PAR30/PAR30L, 65W BR30, 90W BR40
Juno Compatible Housing: Lamp Wattage/Type
IC2, IC22, IC22R: 50W PAR30, 75W PAR30L, 65W BR30
TC2, TC2R: 75W PAR30/PAR30L, 65W BR30
Straight Baffle
V3025W-WH: White
V3025B-WH: Black
Aperture: 5-3/4”
Outer Diameter: 7-3/4”
VuLite Housing: Lamp Wattage/Type
V6ICW, V6ICRW: 50W PAR30/PAR30L, 75W PAR38
V6TCW, V6TCRW: 75W PAR30/PAR30L, 65W BR30,
120W BR40,120W PAR38
Juno Compatible Housing: Lamp Wattage/Type
IC22, IC22R: 75W PAR30/PAR30L, 65W BR30, 75W PAR38
IC2: 75W PAR30 w/socket extender, 75W PAR30L, 65W BR30,
90W PAR38, 100W BR40
TC2, TC2R: 75W PAR30 w/socket extender, 75W PAR30L,
65W BR30, 150W PAR38, 120W BR40
Full Baffle
V3034W-WH: White
V3034B-WH: Black
V3034TW-WH: White w/Torsion Springs
V3034TB-WH: Black w/Torsion Springs
Aperture: 5-3/4”
Outer Diameter: 7-5/8”
VuLite Housing: Lamp Wattage/Type
V6ICW, V6ICNW, V6ICRW: 40W A19*, 75W PAR30/PAR30L,
65W BR30, 90W BR40, 90W PAR38*
V6TCW, V6TCRW: 60W A19*, 75W PAR30/PAR30L,
85W BR30, 120W BR40, 150W PAR38*
Juno Compatible Housing: Lamp Wattage/Type
IC22, IC22R, IC23: 40W A19, 75W PAR30/PAR30L, 65W BR30,
90W BR40, 90W PAR38
IC2: 60W A19, 75W PAR30/PAR30L, 85W BR30, 100W PAR38,
120W BR40
TC2, TC2R: 60W A19, 75W PAR30/PAR30L, 85W BR30,
150W PAR38, 120W BR40
ICPL6 Series: 32W max. CFL†
PL6 Series: 42W max CFL†
†Note: For best performance, 26W is recommended.
6” Compatible Trims
8
6” Line Voltage Housings and Trims
Accessories: VALG4 Airloc® gasket kit for V4IC housing when an Airloc® trim is not being used.
G2405 Set of (4) T-bar clips for installation in suspended ceilings.
Patent Pending
* No A19 listing and 75W PAR38 max. for the V3034B Series
VuLite IC housings meet IECC Energy Code requirements per STM E283.
Air-Loc® rated trims are pre-gasketed for minimum air leakage with IC housings.
VuLite IC housings meet IECC Energy Code requirements per STM E283.
Air-Loc® rated trims are pre-gasketed for minimum air leakage with IC housings.
Full Cone
V3037W-WH: White
V3037TW-WH: White w/ Torsion Springs
Aperture: 5-3/4”
Outer Diameter: 7-5/8”
VuLite Housing: Lamp Wattage/Type
V6ICW, V6ICNW, V6ICRW: 40W A19, 75W PAR30/PAR30L,
65W BR30, 75W BR40, 90W PAR38
V6TCW, V6TCRW: 60W A19, 75W PAR30/PAR30L, 85W BR30,
120W BR40, 150W PAR38
Juno Compatible Housing: Lamp Wattage/Type
IC22, IC22R, IC23: 40W A19, 75W PAR30/PAR30L, 65W BR30,
90W BR40, 90W PAR38
IC2: 60W A19, 75W PAR30/PAR30L, 85W BR30, 100W PAR38
TC2, TC2R: 60W A19, 75W PAR30/PAR30L, 85W BR30,
120W BR40, 150W PAR38
ICPL6 Series: 32W max. CFL†
PL6 Series: 42W max CFL†
†Note: For best performance, 26W is recommended.
6” Line Voltage Housings and Trims
6” Compatible Trims (continued)
Eyeball
V3029-WH: White
Outer Diameter: 7-3/4”
VuLite Housing: Lamp Wattage/Type
V6ICW, V6ICNW, V6ICRW: 65W BR30, 75W PAR30L
V6TCW, V6TCRW: 75W PAR30/PAR30L, 65W BR30
Juno Compatible Housing: Lamp Wattage/Type
IC22, IC22R, IC23, IC2, TC2, TC2R: 75W PAR30
w/socket extender, 75W PAR30L, 65W BR30
Stippled Opal Lens Shower
V3020-PW: Plastic White
Outer Diameter: 8”
VuLite Housing: Lamp Wattage/Type
V6TCW, V6TCRW: 40W A19, 75W PAR30/PAR30L, 65W BR30,
75W PAR38
(Not for use with V6IC/V6ICR)
Juno Compatible Housing: Lamp Wattage/Type
TC2, TC2R: 60W A19, 75W PAR30/PAR30L, 65W BR30,
75W PAR38
Stippled Opal Lens Shower
with Reflector
V3040N-PW: Plastic White
Outer Diameter: 8”
VuLite Housing: Lamp Wattage/Type
V6ICW, V6ICNW, V6ICRW: 34W A19, 35W PAR30
V6TCW, V6TCRW: 75W A19
Juno Compatible Housing: Lamp Wattage/Type
IC2, IC22, IC22R, IC23: 40W A19
TC2, TC2R: 75W A19
ICPL6/PL6 Series: 13W max. CFL
Drop Opal Lens Shower
with Reflector
V3041-PW: Plastic White
Outer Diameter: 8”
VuLite Housing: Lamp Wattage/Type
V6ICW, V6ICNW, V6ICRW: 40W A19
V6TCW, V6TCRW: 100W A19
Juno Compatible Housing: Lamp Wattage/Type
IC22, IC22R, IC23: 40W A19
IC2: 60W A19
TC2, TC2R: 100W A19
ICPL6/PL6 Series: 26W max. CFL
Open Frame
V3050-WH: White
Aperture: 3-7/8”
Outer Diameter: 8”
VuLite Housing: Lamp Wattage/Type
V6ICW, V6ICRW, V6TCW, V6TCRW: 65W BR30
Patent Pending
VuLite IC housings meet IECC Energy Code requirements per STM E283.
Air-Loc® rated trims are pre-gasketed for minimum air leakage with IC housings.
9
10
Cat. No. Description UPC Code Pkg. Wt.
V4ICW 4˝ Line Voltage IC New Construction Housing 66120927205 6 18
V4ICLVW 4˝ Low Voltage IC New Construction Housing 66120927206 4 36
V4TCW 4˝ Line Voltage TC New Construction Housing 66120927201 6 17
V4TCLVW 4˝ Low Voltage TC New Construction Housing 66120927203 6 30
V4TCRW 4˝ Line Voltage TC Remodel Housing 66120927202 6 10
V4TCRLVW 4˝ Low Voltage TC Remodel Housing 66120927204 6 20
V5ICW 5˝ Line Voltage IC New Construction Housing 66120927083 6 19
V5ICRW 5˝ Line Voltage IC Remodel Housing 66120927085 6 12
V5TCW 5˝ Line Voltage TC New Construction Housing 66120927084 6 24
V5TCRW 5˝ Line Voltage TC Remodel Housing 66120927086 6 17
V6ICW 6˝ Line Voltage IC New Construction Housing 66120925734 6 19
V6ICNW 6˝ Line Voltage IC New Construction Housing with Floating Socket 66120936353 6 19
V6ICRW 6˝ Line Voltage IC Remodel Housing 66120927198 6 12
V6TCW 6˝ Line Voltage TC New Construction Housing 66120927199 6 24
V6TCRW 6˝ Line Voltage TC Remodel Housing 66120927200 6 17
V2010-WH 5˝ Flat Lens Shower with Reflector 66120910749 12 8
V2015B-WH 5˝ Black Baffle 66120908085 12 4
V2015W-WH 5˝ White Baffle 66120908084 12 4
V2016C-WH 5˝ Clear Cone 66120908086 12 3
V2016W-WH 5˝ White Cone 66120908087 12 3
V2029-WH 5˝ R/PAR20 Eyeball 66120910754 12 12
V2030-WH 5˝ PAR30 Eyeball 66120927168 12 10
V3020-PW 6˝ Stippled Opal Lens Shower 66120910751 12 8
V3024B-WH 6˝ Conical Black Baffle 66120901731 48 18
V3024W-WH 6˝ Conical White Baffle 66120901730 48 18
V3025B-WH 6˝ Straight Black Baffle 66120907211 48 18
V3025W-WH 6˝ Straight White Baffle 66120907212 48 18
Ordering Information
11
V3027C-WH 6˝ Clear Cone 66120910752 12 7
Cat. No. Description UPC Code Pkg. Wt.
V3029-WH 6˝ Eyeball 66120903872 12 15
V3034B-WH 6˝ Full Black Baffle 66120904472 48 24
V3034TB-WH 6˝ Full Black Baffle with Torsion Springs 66120901575 24 12
V3034TW-WH 6˝ Full White Baffle with Torsion Springs 66120901835 24 12
V3034W-WH 6˝ Full White Baffle 66120904473 48 24
V3037TW-WH 6˝ Full White Cone with Torsion Springs 66120902068 24 12
V3037W-WH 6˝ Full White Cone 66120904474 48 24
V3040N-PW 6˝ Stippled Opal Lens Shower w/Reflector 66120931746 12 18
V3041-PW 6˝ Drop Opal Shower 66120903864 12 20
V3050-WH 6˝ Open Frame 66120921084 24 13
V4010-BN 4˝ Line Voltage Brushed Nickel Gimbal Ring 66120927273 12 7
V4010-WH 4˝ Line Voltage White Gimbal Ring 66120921075 12 7
V4012-WH 4˝ Line Voltage Stippled Opal Lens Shower w/Reflector 66120910741 12 6
V4017C-WH 4˝ Line Voltage Clear Cone 66120921072 12 5
V4018-WH 4˝ Line Voltage Eyeball 66120910744 12 10
V4034B-WH 4˝ Line Voltage Black Baffle 66120921074 24 9
V4034W-WH 4˝ Line Voltage White Baffle 66120921073 24 9
V4040-BN 4˝ Low Voltage Brushed Nickel Gimbal Ring 66120927274 12 7
V4040-WH 4˝ Low Voltage White Gimbal Ring 66120921079 12 7
V4041-WH 4˝ Low Voltage Stippled Opal Lens Shower 66120912020 12 8
V4044B-WH 4˝ Low Voltage Black Baffle w/Regressed Gimbal Ring 66120910745 12 6
V4044W-WH 4˝ Low Voltage White Baffle w/Regressed Gimbal Ring 66120910746 12 6
V4047C-WH 4˝ Low Voltage Clear Cone w/Regressed Gimbal Ring 66120921078 12 6
V4048-WH 4˝ Low Voltage Eyeball with Baffle 66120910747 12 8
Ordering Information
Products shown in this brochure are covered by U.S.
and international patents and patents pending.
Specifications subject to change without notice.
© 2011 JUNO LIGHTING, LLC.
Printed in the U.S.A. LIT-VULITE-BRO 3/13 Rev. 4
1300 South Wolf Road • Des Plaines, Illinois 60018
phone (847) 827-9880 • fax (847) 827-2925 • junolightinggroup.com
Regional Offices & Warehouses:
California, Georgia, Illinois, Indiana, Pennsylvania, Texas, Ontario CN
