LPS Lighting Control Relay Panel

Make the most of your energySM

© 2012 Schneider Electric. All Rights Reserved.

1290HO1001R03/12

03/2012

DESCRIPTION

Schneider Electric LPS Lighting Control Relay Panels offer a practical design

for meeting energy codes requirements in smaller commercial spaces. Panels

are available pre-assembled with 4, 8, 16, 24, or 32 relays. They consist of

relays, time scheduler, panel controller, power supply, and NEMA 1 cabinet

and cover.

LPS reduces energy use by automatically shutting off lights in response to a

scheduled time event from its built-in time controller or in response to an

external control device, such as a keypad switch, occupancy sensor, or

photocell. These panels are ideal for use in smaller commercial applications,

such as small strip retail and office spaces, where a centralized building

management system is not practical.

The LPS time controller includes a full 365-day, 7-day repeating clock with full

24-hour scheduling functions. Daylight Saving Time (DST) is supported, as

well as astronomic control for exterior lighting. The LPS is fully compatible with

Schneider Electric occupancy sensors, photosensors, and SERPWS keypads.

FEATURES

- Stand-alone lighting control system meets

ASHRAE90.1 and CA Title 24

- Individual heavy duty, mechanically latching,

20A relays

- Built-in time controller supports 8 independent zones

- Time retained during power outages for up to 30

days; nonvolatile program memory

- Two universal switch inputs

- Individual relay overrides can directly control

each relay

- Easy to program interface

- 2-wire relay used for monitoring and control

- No derating for inductive lighting loads

- Manual operation lever with ON/OFF indicator built-in

for easy maintenance

- Screw terminals on load and control sides

- UL listed

- Full 365-day, 7-day repeating clock with event

priorities

ORDER INFORMATION

Relay Panel Description Relay Panel Catalog Number

4 HID relays, surface mount SERP4HS

8 HID relays, surface mount SERP8HS

16 HID relays, surface mount SERP16HS

24 HID relays, surface mount SERP24HS

32 HID relays, surface mount SERP32HS

Accessory Description Accessory Catalog Number

Flush Cover for SERP4HS or SERP8HS SERPFLCS8

Flush Cover (Hinged) for SERP4HS or SERP8HS SERPFLCS8H

Flush Cover for SERP16HS SERPFLC16

Flush Cover for SERP24HS or SERP32HS SERPFLC32

Key-type switch SERKWS

Rocker-type switch SERPRWS

Wall switch mounting bracket SERPWSMB

Wall switch with 1 gang, 1 button SERPWS1G1B

Wall switch with 1 gang, 2 button SERPWS1G2B

Wall switch with 1 gang, 3 button SERPWS1G3B

Wall switch with 2 gang, 4 button SERPWS2G4B

Wall switch with 2 gang, 6 button SERPWS2G6B

Wall switch with 3 gang, 9 button SERPWS3G9B

Wall switch with 3 gang, 12 button SERPWS3G12B

Wall switch with 5 gang, 15 button SERPWS5G15B

Wall switch with 6 gang, 18 button SERPWS6G18B

Wall switch filler plate SERPWSFP

LPS Lighting Control Relay Panel 1290HO1001R03/12

03/2012

2 © 2012 Schneider Electric. All Rights Reserved.

PANEL LAYOUT

NOTE: The relay lighting control panel is shown without the Class 2 voltage

covers for illustration purposes only.

WIRING DIAGRAM

1290HO1001R03/12 LPS Lighting Control Relay Panel

03/2012

© 2012 Schneider Electric. All Rights Reserved. 3

DIMENSIONS

Mounted Enclosure Dimensions (Without Doors)

Measurements — mm (in.)

Relays A B C D E F G H I J K L M N O P Q R

4 or 8* 42

(1.7) 149

(5.1) 149

(5.1) 46

(1.8) N/A N/A 330

(13) 381

(15) 345

(13.6) 381

(15) 90

(3.5) 101

(4) 101

(4) 90

(3.5) N/A N/A 46

(1.8) 101.6

(4)

4 or 8** 42

(1.7) 149

(5.1) 149

(5.1) 46

(1.8) N/A N/A

279.4

(11) 305

(12) 228.6

(9) 305

(12) 90

(3.5) 101

(4) 101

(4) 90

(3.5) N/A N/A 46

(1.8) 101.6

(4)

16 42

(1.7) 149

(5.1) 149

(5.1) 46

(1.8) N/A N/A 330

(13) 381

(15) 556

(21.9) 592

(23.3) 94

(3.7) 101

(4) 101

(4) 101

(4) 101

(4) 94

(3.7) 46

(1.8) 101.6

(4)

24 or 32 60

(2.4) 194

(7.6) 194

(7.6) 60

(2.4) 27.87

(1.10) 27.05

(1.08) 406.8

(16) 508

(20) N/A 850

(33.5) 55

(2.2) 190

(7.5) N/A N/A 190

(7.5) 55

(2.2) 55

(2.2) 101.6

(4)

* Without flush cover.

** With flush cover SERPFLCS8 or SERPFLCS8H.

Flush-Mounted Door Dimensions

Measurements — mm (in.)

Relays A B C D E F

4 or 8 229 (9) 356 (14) 229 (9) 356 (14) 356 (14) 356 (14)

16 349 (13.7) 493 (19.4) 582 (22.9) 704 (27.7) 493 (19.4) 704 (27.7)

24 or 32 478 (18.8) 620 (24.4) 838 (33) 962 (37.9) 620 (24.4) 962 (37.9)

LPS Lighting Control Relay Panel 1290HO1001R03/12

03/2012

SPECIFICATIONS

Relay Panel

Enclosures and steel doors Coated with ANSI/ASA 61 gray baked enamel

Panel construction 4, 8, and 16 relay - cold-rolled 16 gauge steel

24 and 32 relay - cold-rolled 14 gauge steel

Removable mounting plate Yellow zinc plated

Protection plates Yellow zinc plated

Standards UL, cUL, CSA

Power Supply

4 or 8 HID relay panels (surface or flush mounted) 120V, 208V, 244V, or 277V

16, 24, or 32 HID relay panels (surface or

flush mounted) 120V, 277V, or 347V

Heavy Duty HID Relay

Poles UL Rating CSA Rating Isolated Auxiliary

Contact

1 20A / 300VAC 20A / 347VAC N/A

2 20A / 480VAC 20A / 347VAC N/A

Characteristics

Electrical Life 60,000+ operations

Mechanical Life 120,000+ operations at 20 cpm

SCCR 14,000A / 277VAC single pole

5,000A / 277VAC double pole

Maximum Operating Speed 20 cpm at nominal load

Operate Time Approximately 20 msec.

Release Time Approximately 20 msec.

Initial Insulation Resistance More than 100M at 500VDC

Dielectric (between open contacts) 1,694V for one minute

Strength (between contacts and coils) 2,500V for one minute

Ambient Temperature -22° F to 122° F (-30° C to 50° C)

Temperature rise (at normal voltage) Maximum 149° F (65° C)

Contacts

Rating UL Rating CSA Rating

1 pole 20A 300V AC 20A 347V AC General Use

2 pole 20A 480V AC 20A 347V AC

1 pole 20A 300V AC 20A 347V AC Electric Discharge

2 pole 20A 300V AC 20A 347V AC

Tungsten 2,400W 120V AC 2,400W 120V AC

1/2 HP at 110-125V AC 1/2 HP at 110-125V AC Motor Load

1-1/2 HP at 220-227V AC 1-1/2 HP at 220-250V AC

Coil

Operating Voltage 18V to 30V pulsed DC, reversible polarity

18V to 30V half-wave rectified AC, reversible polarity

Minimum Input Duration 8M sec.

Nominal Operating Current 350mA*

* Simultaneous operation of multiple units: 350mA times the number of units operated simultaneously.

NOTE: Continuous input power supply to the relay coil prevents the operation lever from being

switched manually.

Mechanical Requirements

Main Contact Terminal AWG #12 to #14 Copper Wire Terminal Capacity

Input Terminal and auxiliary contact

terminal AWG #16 to #20 Copper Wire

Main contact terminal 6.9 to 10.4 inch-lbs Terminal Tightening

Torque Input terminal and auxiliary

contact terminal 4.3 to 6.9 inch-lbs.
