RACO® STEEL BOXES, COVERS AND ACCESSORIES

RACO bOxes, COveRs And ACCessORies

A2

General information

STEEL BOXES, COVERS and ACCESSORIES

stAndARds, 2014 nAtiOnAl eleCtRiCAl COdes®

Applications: Steel Boxes

RACO® high-quality steel boxes:

• Areusedinbranchcircuitwiring

• Accommodatewiringdevices,suchas

switchesandreceptacles

• Mostmayalsoserveasfixturesupports

• Provideexcellentprotectionforwiring

systemordevices

• Mustbeclosedwithacover,lightfixture

canopyorwallplate

• Permitaccesstoconductorsfor

maintenance

• Allowforbranchcircuitruns

• Providetwo-hourfireratingfor4x4or

smallerwallopening

Product Features: Outlet Boxes for

Fixture or Fan Support

These high-quality boxes:

• Arelistedtosupportlightingfixture

canopiesorfans

• Featureoversized#10screwstoprovide

strengthandrigidity

Product Features: TKO® Knockouts

• TKO®knockoutsoffergreaterflexibilitywith

RACO®combination1/2"and3/4"knockout

• Stockjustoneproductinsteadoftwoor

three

• Oneproductfortheinstallertocarry

TKO® Provides Reliable Grounding Path

• IndependenttestsconductedbyULprove

thattheTKOpassesthesamehigh-current

faulttestusedtotestgroundingbushings

andgroundlugs

• RACO®TKOknockoutisULListed,providing

bondingwithouttheuseofbondingjumpers

• Suitableforbondingwithoutanyadditional

bondingmeansaroundconcentric(or

eccentric,TKO)knockoutswhereusedin

circuitsaboveorbelow250V

• Thisknockoutdoesnotimpairtheelectrical

connectiontoground

Most Raco® Boxes Have At Least One

Tapped #10-32 Grounding Hole

• Theproductsthatdonothaveagrounding

screwholeare:plenumboxescatalog

numbers226and239

Product Features: Combination Screw

Heads

• Coverandclampscrewshavecombination

slotted/Phillipsheads

• Self-tappingscrewsprovidefor100%

threadengagement

Metallic Boxes: Fire Resistance Rating

Wall Penetrations*

Listedsingle-anddouble-gangmetallicoutlet

andswitchboxeswithmetallicornonmetallic

coverplates,also4x4andoctagonboxesmay

beusedinbearingandnon-bearingwoodstud

andsteelstudwallswithratingsnotexceeding

twohours.

Thesurfaceareaofindividualmetallicoutlet

orswitchboxesshallnotexceed16square

inchesthroughafireratedwall.Theaggregate

surfaceareaoftheboxesshallnotexceed

100squareinchesper100squarefeet.Boxes

locatedonoppositesidesofwallsorpartitions

shallbeseparatedbyahorizontaldistanceof

24inches.

Themetallicoutletorswitchboxesshall

besecurelyfastenedtothestuds,andthe

openinginthewallboardfacingshallbecut

sothattheclearancebetweentheboxandthe

wallboarddoesnotexceed1/8inch.

* Reference:ULFireResistanceDirectory

(OrangeBook)

Standard Material: Steel Covers, Outlet

And Switch Boxes

• Steelboxesandcoversaremadeof.0625

inchthickpre-galvanizedsheetsteel

• HandyBoxcoversaremadeof.030inch

thickgalvanizedsheetsteel

Compliances

RACO®steelboxesandcoversgenerally

carrythefollowingcomplianceratings.

Checkspecificcatalogpagesforindividual

compliances.

• ULListed–Standard514-A,fileE195978

(“QCIT”Category)

• Boxesandcoversarelistedfortheir

ElectricalApplications(electricalcodes),UL

ElectricalConstructionEquipmentOnline

Directory(electricalcodes).

• BoxesarelistedforFireResistance

Directory,includingtheTwo-HourFire

Rating,(buildingcodes)ULOrangeBook

• ULClassifiedStandard–UL263file

R16536,CEYY,QBWY

• CSACertified–C22.2#18,CSAFile

LR-1082

• ANSI/NEMAOS1

• FederalManufacturer’snumber28488

Forinstallationguidelinesandtolearnmore

about RACO®products,visittheNEMAwebsite

athttp://www.nema.org.

TheNationalElectricalManufacturers

Association(NEMA)websiteisavaluable

electricalresourceprovidingtheinformation

youneed-quickly.

RACO® UL Guide Cards

YoucandownloadandprintoutanyorallUL

GuideCardsissuedtoRACO®.Justgotothe

RACOwebsiteatwww.hubbell-raco.comand

clickontheULsymbol.EveryRACOULguide

cardislistedbyproductcategory.Clickonthe

livelink(righthandcolumninbluetype)and

theULGuideCardwillappear.Savetoyour

computerorprintitout.

UL Guide Information Pages

ULpublishesthemostfrequentlyasked

questionsconcerningproductratings,

configurations,installations,usesallowedor

notallowed,groundingandbonding,andmuch

more.EachULcategoryhasauniqueGuide

InformationPage.LivelinkstoeachULGuide

InformationPageappearsjustbelowtheRACO

ULguidecardforeachproductcategory.

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A3

GENERAL INfORmATION

STANDARDS, 2014 NATIONAL ELECTRICAL CODE®

Wiring Capacity: Steel Outlet and

Switch Boxes; Cubic Inches

Maximum Number of Conductors or

Minimum Size Box Required – National

Electrical Code Article 314.16 (A and

B) also table 314.16(A)

ThepurposeofNEC®Article314.16isto

determinethemaximumconductorcount

ortheminimumboxsizerequiredforan

application.Italsomaybeusedtodetermine

howmanyotherconductorsmaybeadded

withoutexceedingtheCode-prescribedlimit.

Mostapplicationshavedeterminedthenumber

ofconductors.Thequestionthatthenremains

isthesmallest(minimum)sizeboxthatis

permitted.TherulesofArticle314.16aretobe

usedtodeterminetheCode-recognizedlimit.

Selectionofanoutletorjunctionbox

foruseinanelectricalcircuitworkmusttake

intoconsiderationthemaximumnumberof

wirespermittedinthebox.Safeelectrical

practicedemandsthatwiresnotbejammed

intoboxesbecauseofthepossibilityofnicks,

abrasionsorotherdamagetotheinsulating

material,creatingthepotentialforground

faultsorshortcircuits.

Article 314 – Boxes and Fittings

NEC® 314.16 (A and B) also table

314.16(A). Number of Conductors in

Outlet, Device, and Junction Boxes, and

Conduit Bodies.

Boxesshallbeofsufficientsizetoprovidefree

spaceforallenclosedconductors.Innocase

shallthevolumeofthebox,ascalculatedin

(a)below,belessthanthefillcalculationas

calculatedin(b)below.Theminimumvolume

forconduitbodiesshallbeascalculatedin

(c)below.

Theprovisionsofthissectionshallnotapply

toterminalhousingssuppliedwithmotors.See

Section430.12.

Boxesandconduitbodiesenclosing

conductors,size#4orlarger,shallalsocomply

withtheprovisionsofSection314-28.

(a) Box Volume Calculations. Thevolumeofa

wiringenclosure(box)shallbethetotalvolume

oftheassembledsections,and,whereused,

thespaceprovidedbyplasterrings,domed

covers,extensionrings,etc.,thataremarked

withtheirvolumeincubicinchesoraremade

fromboxesthedimensionsofwhicharelisted

inTable314.16(A).

(1) Standard Boxes.Thevolumeofstandard

boxesthatarenotmarkedwithacubicinch

capacityshallbeasgivenin*Table314.16(A).

(2) Other Boxes.Boxes100cubicinches

(1,640cu.cm3.)orless,otherthanthose

describedintable,andnonmetallicboxes

shallbedurablyandlegiblymarkedbythe

manufacturerwiththeircubicinchcapacity.

Boxesdescribedintablethathavealarger

cubicinchcapacitythanisdesignatedinthe

tableshallbepermittedtohavetheircubic

inchcapacitymarkedasrequiredbythis

section.

(b) Box Fill Calculations.Thevolumes

inparagraphs(1)through(5)below,as

applicable,shallbeaddedtogether.No

allowanceshallberequiredforsmallfittings

suchaslocknutsandbushings.

(1) Conductor Fill.Eachconductorthat

originatesoutsidetheboxandterminates

orissplicedwithintheboxshallbecounted

once,andeachconductorthatpasses

throughtheboxwithoutspliceortermination

shallbecountedonce.Theconductorfill,in

cubicinches,shallbecomputedusingTable

314.16(B)(1).Aconductor,nopartofwhich

leavesthebox,shallnotbecounted.

Exception: Where an equipment grounding

conductor or not over four fixture wires smaller

than #14, or both, enter a box, from a domed

fixture or similar canopy and terminate within

that box, it shall be permitted to omit these

conductors from the calculations.

(2) Clamp Fill.Whereoneormoreinternal

cableclamps,whetherfactoryorfieldsupplied,

arepresentinthebox,asinglevolume

allowanceinaccordancewithNEC®314.16(B)

(2)shallbemadebasedonthelargest

conductorpresentinthebox.Noallowance

shallberequiredforacableconnectorwith

thisclampingmechanismoutsidethebox.

(3) Support Fittings Fill.Whereoneormore

fixturestudsorhickeysarepresentinthebox,

asinglevolumeallowanceinaccordancewith

NEC®314.16(B)(3)shallbemadeforeach

typeoffittingbasedonthelargestconductor

presentinthebox.

(4) Device or Equipment Fill.Foreachyoke

orstrapcontainingoneormoredevicesor

equipment,adoublevolumeallowancein

accordancewithNEC®314.16(B)(4)shall

bemadeforeachyokeorstrapbasedonthe

largestconductorconnectedtoadevice(s)or

equipmentsupportedbythatyokeorstrap.

(5) Equipment Grounding Conductor Fill.

Whereoneormoreequipmentgrounding

conductor(s)enter(s)abox,asinglevolume

allow-anceinaccordancewithTable314.16B

shallbemadebasedonthelargestequipment

groundingconductorpresentinthebox.Where

anadditionalsetofequipmentgrounding

conductors,aspermittedbyNEC®314.16(B)

(5)arepresentinthebox,anadditional

volumeallowanceshallbemadebasedonthe

largestequipmentgroundingconductorinthe

additionalset.

NationalElectricCode®andNEC®isaregisteredTrademarkoftheNationalFireProtectionAssociation.

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A4

GENERAL INfORmATION

STANDARDS, 2014 NATIONAL ELECTRICAL CODES®

250.97 Method of Bonding Service Equipment — Bonding

Jumpers.Bondingjumpersarenotrequiredforconcentricand

eccentricknockoutsiftheyarelistedforthepurpose.

314.27 (A) Boxes at Lighting Fixture Outlets.Boxestosupport

lightfixturesmustbelistedforfixturesupport.

314.27 (B) Floor Boxes.Boxeslistedspecificallyforthis

applicationshallbeusedforreceptacleslocatedinthefloor.

Exception:Boxeslocatedinelevatedfloorsofshowwindowsand

similarlocationswheretheauthorityhavingjurisdictionjudges

themfreefromphysicaldamage,moistureanddirt.

314.27 (C) Boxes at Fan Outlets.Boxesthatsupportceilingfans

mustbelistedforthatpurpose.

314.16 (A)(3) Space for Conductors.Canopiesandoutletboxes

takentogethershallprovideadequatespacesothatfixture

conductorsandtheirconnectingdevicescanbeproperlyinstalled.

314.27 (B) Maximum Luminaire Weight. Fixturesgreaterthan

50poundscannotbesupportedbyafixtureboxunlessadditional

independentsupportisprovided.

250.146 (A) Surface-Mounted Box. Wheretheboxismountedon

thesurface,directmetal-to-metalcontactbetweenthedevice

yokeandtheboxoracontactyokeordevicethatcomplieswith

250.146(B)shallbepermittedtogroundthereceptacletothebox.

Deviceboxesuse#6-32screwstosecuredevicessuchassnap-

switchesandreceptacles.Theyarenotsuitableforsupportofother

thanverylightweightlightingfixtures,suchassomewall-bracket

types.

OnlyboxesthatareULListedfortheapplicationmaybefastened

intothefloor.RACO®floorboxesareinSectionAofthiscatalog.

Foranyceilingoutletthatisintendedtohaveaceiling(paddle)fan

installed,aULListedoutletboxratedforceilingfansupportmust

beinstalled.RACO®offersacompletelineofproductsdesignedfor

variousapplicationsandmountingneeds.

Whencalculatingtheminimumcubicinchrequirementsforanoutlet

box,thecanopymaybeincludedinthecalculationatthediscretion

oftheAuthorityHavingJurisdiction.Ifthecanopyofthefixture/fan

ismarkedwiththecubicinchcapacity,thentheadditionalvolume

mustbeacceptedbytheAuthorityHavingJurisdiction.

Alloutletboxesthatareintendedtobeusedwithfixturesaretested

inaccordancewithULStandard514A.

Thisnewmethodprovidesbetterbondingforthecover.RACOflat

cornercoversandmudringscomply.

ThisSectionisusedtoensurethatthereisgroundcontinuitywhen

aconcentricoreccentricknockoutincorporatedinabox.Abonding

jumperisnotrequiredwhenusinganyoftheRACO®patentedTKO®

knockoutboxes,CatalogNumbers189,232,etc.

MOST OFTEN REQUESTED SECTIONS OF THE NATIONAL

ELECTRICAL CODE®

HOW RACO® PRODUCTS HELP COMPLETE THE

INSTALLATION

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A5

GENERAL INfORmATION

STANDARDS, 2014 NATIONAL ELECTRICAL CODES®

800.133 Exception (A)(1)(d) Installation of Communications

Wires, Cables and Equipment – Electric Light or Power Circuits.

Communicationsconductorsshallnotbeplacedinanyraceway,

compartment,outletbox,junctionbox,orsimilarfittingwith

conductorsorelectriclightorpowercircuitsorClass1circuits.

406.12, 406.13, 406.14 Tamper-resistant Receptacles in

Dwelling Units, Guest Rooms and Child Care Facilities.

Inallareasspecifiedin210.52,all125volt,15and20amp

receptaclesshallbelistedtamper-resistantreceptacles.

314.24 (B) Depth of Boxes. Minimumdepthofboxesforoutlets,

devices,andutilizationequipment.

Whenpowerandvoice/dataarebroughttooneenclosure,ameans

ofdividingthewiringisrequired.Voltagebarriersareavailableon

thefollowingboxtypes:4"and4-11/16"squareboxes,three-and

four-gangswitchboxes,masonryboxes,andgangboxes.

Thisistopreventshocksotsmallchildrenthatliketoinsertkeys,

paperclips,etc.intothereceptacleslots.

Boxesmustbeaminimumdepthdependingontheiruseand/or

arerequiredtohaveaminimumclearancebehindthedeviceor

equipmentofper314.24(B).

MOST OFTEN REQUESTED ARTICLES OF THE 2014

NATIONAL ELECTRICAL CODE®

HOW RACO® PRODUCTS HELP COMPLETE THE

INSTALLATION

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A6

NEC®314.16(A)and(B)describesthedetailed

wayofcountingwires,aswellasclamps,fittings

ordevices(i.e.,switches,receptacles,combination

devices)–byestablishinganequivalentconductor

valueforeach.Thosevaluesareaddedtogether

togetatotalnumberofconductors.Theminimum

sizeboxisthesmallestoneinTable314.16(A)that

canaccommodatethatnumberofconductors.

1.Nomatterhowmanygroundwirescomeintoa

box,theyonlycountasoneconductorwithinthe

box.

2.Anywirerunningunbrokenthroughthebox

countsasonewire.

3.Eachwirecomingintoasplicedevice(crimpor

twist-ontype)iscountedasonewire.

4.Eachwirecomingintotheboxandconnectingto

adevicecountsasonewireofthatsize.

BOX SELECTION

STEEL BOX SELECTION CHART

CALCULATE THE MINIMUM SIZE BOX

CUBICINCHES: 42.0 30.3 29.5 21.5 21.0 18.0

4-11/16" Sq. 4" Sq. 4-11/16" Sq. 4" Oct. 4" Sq. Switch

 2-1/8"Deep(inside) 2-1/8"(DepthInside) 1-1/2"(DepthInside) 2-1/8"(DepthInside) 1-1/2"(DepthInside) 3-1/2"(DepthInside)

CUBICINCHES: 30.3 21.5 21.0 18.0

4" Sq. 4" Oct. 4" Sq. Switch

 2-1/8"(DepthInside) 2-1/8"(DepthInside) 1-1/2"(DepthInside) 3-1/2"(DepthOutside)

5.Fixturestuds,cableclampsandhickeysareto

becountedasoneregardlessofhowmanythere

maybe.Ifaboxcontainstwocableclamps,the

totalisonlytobeincreasedbyone.

6.Wheredevicesaremountedinthebox,thetotal

conductorcountmustbeincreasedbytwofor

eachmountingstrap.

Example#1:–ConduitBoxes:Supplypowertoa

switchthatwillcontrolaremotelightwith#14

conductors.Metalconduitandfittingswillbe

usedasthewireway.Youmustprovidespacefor

fourconductorsandoneswitch,totaling6.Read

acrosstheline“Allowances”intheBox Fill table

tocolumn6,thenreaddowntotheminimumcubic

inchesrequiredfor#14conductor.Thisexample

requiresaminimumof12.0cubicinches.

Example#2:–CableBoxes:

Thisexamplewillillustratehowtheminimumsizeis

determinedforaboxwithcableclampsfedbytwo

#12-2nonmetallicsheathedcablesandsupplyinga

15Aduplexreceptacle.Aftersupplyingthereceptacle,

theconductorsareextendedtootheroutlets.

Circuitconductors.........................4

 Groundconductors...................1

 Cableclamps...........................1

 Device(receptacle)...................2

Total..............................................8

UsingtheBox Filltablefromthenextpage,read

acrosstheline“Allowances”tocolumn8,then

downtotheminimumcubicinchesrequiredfor

#12conductor.Thisexamplerequiresaminimum

of18.0cubicinches.

1"

CONDUIT

KO

TKO®

CONDUIT

KO ONE-SCREW EAR TWO-SCREW EAR

CABLE PRIOUTS

Alwaysinpairs.

FLAT-BOTTOMED

CABLE PRIOUTS

Eliminatechance

ofcablebeingcut.

“L” TYPE “X” TYPE “BN” TYPE “Q” TYPE“#9" or “AOL” TYPE

7/8"

1-3/32"

1/2"

CONDUIT

KO

3/4"

CONDUIT

KO

7/8"

1-3/32"

1-3/8"

Adjustableplasterearsareincludedonmanyswitch

boxesandoneoctagonbox.Theyaresetforward1/32".

KNOCKOUTS AND PRIOUTS PLASTER EARS

CONDUIT

STEEL

BOXES

MC/BX AND

NONMETALLIC CABLE

STEEL BOXES

CLAMP TYPES

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A7

BOX SELECTION

 16.5 15.5 14.0 13.0 12.5 6.0

Handy 4" Oct. Switch Handy Switch 4" Rnd. Pan

2-1/8"(DepthInside) 1-1/2"(DepthInside) 2-3/4"(DepthOutside) 1-7/8"(DepthOutside) 2-1/2"(DepthOutside) 1/2"(DepthInside)

 15.8 15.5 14.0 12.5 4.0

Switch 4" Oct. Switch Switch 3-1/2" Pan

2-9/64"(DepthOutside) 1-1/2"(DepthInside) 2-3/4"(DepthOutside) 2-1/2"(DepthOutside) 1/2" (DepthInside)

Conductor

Size (AWG) Volume Per Conductor

cm3 in.3

ALLOWANCES

6 7 8 9 10 11 12 13 14

#18 24.6 1.50 9.00 10.50 12.00 13.50 15.00 16.50 18.00 19.50 21.00

#16 28.7 1.75 10.50 12.25 14.00 15.75 17.50 19.25 21.00 22.75 24.50

#14 32.8 2.00 12.00 14.00 16.00 18.00 20.00 22.00 24.00 26.00 28.00

#12 36.9 2.25 13.50 15.75 18.00 20.25 22.50 24.75 27.00 29.25 31.50

#10 41.0 2.50 15.00 17.50 20.00 22.50 25.00 27.50 30.00 32.50 35.00

#8 49.2 3.00 18.00 21.00 24.00 27.00 30.00 33.00 36.00 39.00 42.00

#6 81.9 5.00 30.00 35.00 40.00 45.00 50.00 55.00 60.00 65.00 70.00

CLAMP

TYPE

RACEWAY TYPE

ARMORED CABLE (BX) METAL CLAD CABLE INTERLOCKING (MCI) NONMETALLIC

SHEATHED CABLE FLEXIBLE METAL

CONDUIT

STEEL ALUMINUM STEEL ALUMINUM

“L” TYPE — — – – #14-2to#10-3

w/ground –

“X” TYPE #14-2(.444inouter

diam.)tolargestsize

tofitinclamp

#14-2(.444inouter

diam.)tolargestsize

tofitinclamp

.425TO.600

outerdiam.

.400to.495

outerdiam. –3/8"tradesize

“#9" 0R “AOL”

TYPE — — — — #14-2w/ground —

“Q” TYPE — — — — #14-2to#10-3

w/ground —

“BN” TYPE — — — — #14-2w/groundor#12-2

w/ground —

CLAMP TECHNICAL DATA

BOX FILL

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A8

BOX SELECTION

BRACKET TECHNICAL DATA

BRACKET TYPE “A” “B” “D” “FH” “FM” “FS” “J” “LB” “MS” “TS” “W” “H”or“M”

LENGTH (In.) 6-7/16" 1-61/64" 6-1/4" 7-3/8" 6-7/8" 7" 2-3/8" 1-31/32" 4-1/2" 7" 6-25/32" 4-15/16"

WIDTH  5/8" 2" 21/32" 1-9/16" 1-9/16" 1-9/16" 2-23/32" 3-3/64" 1-1/2" 1-1/16" 1-1/16" 7/8"

OFFSET    3/8" 3/8" 3/8" 1/4"   17/64" 1-5/16" 3/8"

FOR METAL P  P  P P   P P P P

FOR WOOD P P P P P P P P  P P P

“A” Bracket

Positionshandy

boxagainstface

andsideofstud.

“FH” Bracket

Side-mount

bracketwith

hooksthatdrive

intofaceofstud.

BOX-LOC® “MS” Bracket

Positionsboxoneithersideofstud.BOX-LOC®(MS)BracketBoxisasnapto

install.Placethebracketontheopensideofthestudfirst.Slotsinthebracket

engagethelipofthestudandactuallycrimpitasyoupressthebracketonthe

stud.Barbedhooksdigintotheflatsideofthestud,quicklylockingitintoplace.

“UBS” Support

UniversalBackSidesupportto

providebracingonbackofboxfor

wallcavities2-1/2"-6"thick.

“B” Bracket

Facemountsonfrontedgeof

woodstud.Usewhenspace

betweenstudsislimited.

“FM” Bracket

Mountsonflat

sideofstud.

“FS” Bracket

Mountsonflatsideof

stud.Gaugingtabsand

recessednailingspurs.

“TS” Bracket

Side-mountbracketfor

octagon,square,switchand

handyboxes.Gaugingtabs

andrecessednailingspurs.

“D” Bracket

Mountsonflat

sideofstud.

“J” Bracket

Spurs,slottedholesfor

toe-nailing.Gauging

notchesat3/8"and1/2".

“W” Bracket

Positionsboxawayfromsideofstudto

clearthetrimmoldingofadoorframe.

“LB” Bracket

Facemountsonfrontedgeofwoodstud.

Usewhenspacebetweenstudsislimited.

5/8"offsettoclearnarrowdoormolding.

“H” Bracket

Narrowbracketallowsside-by-sidemountingonstud.

Positioningtabslocateboxperfectdistancefromstud.V

notchcentersbox.Dimplesprotectflushdrywallinstallation.

“M” Bracket

Bracketsonboth/

oppositesidesofbox

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A9

SEE END OF SECTION (PG A67) FOR DETAILED DRAWINGS »

SquARE BOXES & COVERS

4" SQUARE BOXES – DRAWN WITH CONDUIT KO'S

APPLICATIONS

• RACO® Boxesareinstalledinwallsor

ceilingsforlightingfixtures,switchesor

receptacles

• Squareboxesareusedwheremultiple

conductorrunsaresplitintotwoormore

directionstobringpowertoanumberof

electricaldevices

• Drawnboxesareidealforexposedwork

applications

PRODUCT FEATURES

• Combinationscrewheadsprovidefor

fasterinstallation

• Thru-the-wallboxisdesignedforshallow

wallapplicationsandallowsforattachment

ofwallplatetobothfacesofbox

COMPLIANCE

• FileE195978

• AllRACOsinglegang,twogang,4"

square,andsingleganggangableU.L.listed

steelboxesareacceptableforusein2-hour

fireratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteatwww.ul.com

190, 8190185 192, 8192

204

191, 8191

192SM

CAT. # DESCRIPTION CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG.

BAR

CODE

SIDES

CONDUIT BOTTOM

CONDUIT

4" Square Box, 1-1/4" Deep – Drawn with Conduit KO's

185 —18.0(295.0) (10)1/2" (5)1/2" 50 IIIIIIII

4" Square Box, 1-1/2" Deep – Drawn with Conduit KO's

190 RaisedGround 21.0(344.1) (12)1/2" (4)1/2" 50 —

8190 RaisedGround 21.0(344.1) (12)1/2" (4)1/2" 50 IIIIIIII

191 RaisedGround 21.0(344.1) (8)3/4" (1)1/2",(3)3/4" 50 —

8191 RaisedGround 21.0(344.1) (8)3/4" (1)1/2",(3)3/4" 25 IIIIIIII

192 RaisedGround 21.0(344.1) (8)1/2",(4)3/4" (2)1/2",(2)3/4" 50 —

8192 RaisedGround 21.0(344.1) (8)1/2",(4)3/4" (2)1/2",(2)3/4" 50 IIIIIIII

192SM RaisedGround,10"#12Stranded

CopperPigtail 21.0(344.1) (8)1/2"

(4)3/4"

(2)1/2"

(2)3/4" 50 IIIIIIII

4" Square Thru-the-Wall Box, 1-1/2" Deep – Drawn with Conduit KO's

204 — 22.5(368.7) (8)1/2",(4)3/4" —50 —

steel boxes, covers and accessories

RACO bOxes, COveRs And ACCessORies

A10

SEE End of SEction (PG A67) for dEtAilEd drAwinGS »

applications

• RACO® Boxes are installed in walls or

ceilings for lighting fixtrues, switches or

receptacles

• Square boxes are used where multiple

conductor runs are split into two or more

directions to bring power to a number of

electrical devices

product features

• Combination screw heads provide for faster

installation

• TKO® Knockouts allow for design and

installation flexibilit.

• Red boxes, covers and extensions for

dedicated life safety alarm circuits

compliance

• File E195978

• All RACO single gang, two gang, 4"

square, and single gang gangable U.L. listed

steel boxes are acceptable for use in 2-hour

fire rated walls. For additional information,

consult U.L. “Fire Resistance Directory” or

the U.L. website at www.ul.com

• Per U.L. 514-A, suitable for use without

a bonding jumper in circuits up to 600 volts

911-9189, 8189181 189RAC

189SM

4" squARe bOxes – Welded With COnduit KO's

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS Std.

PKG. bAr

codE

SidES

conduit bottom

conduit

4" Square Box, 1-1/2" Deep – Welded with Conduit KO's

181 — 21.0 (344.1) (8) 3/4" (1) 1/2", (4) 3/4" 50 —

189 , Raised Ground 21.0 (344.1) (8) 1/2", (4) TKO®(2) 1/2", (2) TKO®50 —

8189 , Raised Ground 21.0 (344.1) (8) 1/2", (4) TKO®(2) 1/2", (2) TKO®50 IIIIIIII

189rAc 21.0 (344.1) (8) 1/2", (4) TKO®(2) 1/2", (2) TKO®50 —

189Sm , Raised Ground, 10" #12

Stranded Copper Pigtail 21.0 (344.1) (8) 1/2"

(4) TKO®(2) 1/2"

(2) TKO®50 IIIIIIII

911-9 , Raised Ground, Painted

Red 21.0 (344.1) (8) 1/2"

(4) TKO®(2) 1/2"

(2) TKO®50 —

Square BoxeS & CoverS

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A11

SEE END OF SECTION (PG A67) FOR DETAILED DRAWINGS »

4" SQUARE BRACKETED BOXES – WELDED WITH CONDUIT KO'S

APPLICATIONS

• RACO® Boxesareinstalledinwallsor

ceilingsforlightingfixtrues,switchesor

receptacles

• Squareboxesareusedwheremultiple

conductorrunsaresplitintotwoormore

directionstobringpowertoanumberof

electricaldevices

PRODUCT FEATURES

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

• BOX-LOC®(MS)BracketBoxisasnapto

install.Placethebracketontheopenside

ofthestudfirst.Slotsinthebracketengage

thelipofthestudandactuallycrimpitas

youpressthebracketonthestud,quickly

lockingitinplace

• TKO®Knockoutsallowfordesignand

installationflexibility

• UBSSupport-Weldedtobox,presetbend

pointstoworkwithwallthickness2-1/2"

to6"

COMPLIANCE

• FileE195978

• AllRACOsinglegang,twogang,4"

square,andsingleganggangableU.L.listed

steelboxesareacceptableforusein2-hour

fireratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteatwww.ul.com

• PerU.L.514-A,suitableforusewithout

abondingjumperincircuitsupto600volts

189H, 189HS 189HWP

193, 8193

189M

8197196, 8196 208, 8208

199

227 BOX-LOC®

189F

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT BOTTOM

CONDUIT

4" Square Bracketed Boxes, 1-1/2" Deep – Welded with Conduit KO's

196 ,FS,Flush 21.0(344.1) (6)1/2"

(3)TKO®

(3)1/2"

(2)TKO®25 —

8196 ,FS,Flush 21.0(344.1) (6)1/2"

(3)TKO®

(3)1/2"

(2)TKO®25 IIIIIIII

8197 ,FH,Flush 21.0(344.1) (6)1/2"

(3)TKO®

(3)1/2"

(2)TKO®25 IIIIIIII

199 ,FS,Flush 21.0(344.1) (6)3/4" (1)1/2"

(4)3/4" 25 —

208 ,W,Flush 21.0(344.1) (6)1/2"

(3)TKO®

(3)1/2"

(2)TKO®25 —

8208 W,Flush 21.0(344.1) (6)1/2"

(3)TKO®

(3)1/2"

(2)TKO®25 IIIIIIII

193 ,B,Flush 21.0(344.1) (6)1/2"

(3)TKO®

(3)1/2"

(2)TKO®25 —

8193 ,B,Flush 21.0(344.1) (6)1/2"

(3)TKO®

(3)1/2"

(2)TKO®10 IIIIIIII

189F ,RaisedGround,8"#12

SolidCopperPigtail,UBSFarside

Support

21.0(344.1) (8)1/2"

(4)TKO®

(2)1/2"

(2)TKO®50 —

189H ,RaisedGround,8"#12

SolidCopperPigtail,UBS,HM 21.0(344.1) (6)1/2"

(3)TKO®

(2)1/2"

(2)TKO®20 —

189HS RaisedGround,10"#12

StrandedCopperPigtail,UBS,

HM

21.0(344.1) (6)1/2"

(3)TKO®

(2)1/2"

(2)TKO®20 —

189HWP ,RaisedGround,UBS,HM 21.0(344.1) (6)1/2"

(3)TKO®

(2)1/2"

(2)TKO®20 —

189M ,RaisedGround,8”#12

SolidCopperPigtail,UBS,HM 21.0(344.1) (4)1/2"

(2)TKO®

(2)1/2"

(2)TKO®20 —

227 ,MS,Flush,BOX-LOC®,

ProvidedwithFar-sidesupport

(part#978)

21.0(344.1) (6)1/2"

(3)TKO®

(3)1/2"

(2)TKO®25 IIIIIIII

SquARE BOXES & COVERS

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A12

4" SQUARE EXTENSION RINGS

APPLICATIONS

• RACO® Extensionringsprovideameansfor

addingcubiccapacityorasanoutletboxfor

surfaceconduit

PRODUCT FEATURES

• Combinationscrewheadsprovideforfaster

installation

• Redboxes,coversandextensionsfor

dedicatedlifesafetyalarmcircuits

• RACO® 187canbepositionedto

accommodateoneortwoswitchboxes

COMPLIANCE

• FileE195978

187

203, 8203202201, 8201

911-6 207

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT BOTTOM

CONDUIT

4" Square Extension Rings, 1-1/2" Deep – Drawn with Conduit KO's

201 — 22.5(368.7) (12)1/2" —50 —

8201 — 22.5(368.7) (12)1/2" —25 IIIIIIII

202 — 22.5(368.7) (8)3/4" —50 —

203 — 22.5(368.7) (8)1/2",(4)3/4" —50 —

8203 — 22.5(368.7) (8)1/2",(4)3/4" —25 IIIIIIII

911-6 PaintedRed 22.5(368.7) (8)1/2",(4)3/4" —50 —

187 AttachestoSwitchBoxes 22.5(368.7) (8)1/2",(4)3/4" —25 IIIIIIII

4" Square Extension Rings, 2-1/8" Deep – Welded with Conduit KO's

207 — 30.3(496.5) (6)1/2",(6)3/4" —25 —

SquARE BOXES & COVERS

steel boxes, covers and accessories

www.Hubbell-RTB.com A13

SEE End of SEction (PG A67) for dEtAilEd drAwinGS »

4" SQUARE BOXES – WELDED WITH CONDUIT KO’S

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS Std.

PKG. bAr

codE

SidES

conduit bottom

conduit

4" Square Box, 2-1/8" Deep – Welded with Conduit KO’s

232 , Raised Ground 30.3 (496.5) (8) 1/2", (4) TKO®(2) 1/2", (2) TKO®25 —

8232 , Raised Ground 30.3 (496.5) (8) 1/2", (4) TKO®(2) 1/2", (2) TKO®25 IIIIIIII

232rAc 30.3 (496.5) (8) 1/2", (4) TKO®(3) 1/2", (2) TKO®25 —

231 —30.3 (496.5) (8) 3/4" (1) 1/2", (4) 3/4" 25 —

8231 —30.3 (496.5) (8) 3/4" (1) 1/2", (4) 3/4" 25 IIIIIIII

233 —30.3 (496.5) (8) 1" (3) 1/2", (2) 3/4" 25 —

8233 —30.3 (496.5) (8) 1" (3) 1/2", (2) 3/4" 25 IIIIIIII

232Sm , Raised Ground, 10" #12

Stranded Copper Pigtail 30.3 (496.5) (8) 1/2", (4) TKO®(2) 1/2", (2) TKO®25 IIIIIIII

911-3 , Painted Red 30.3 (496.5) (8) 1/2", (4) TKO®(2) 1/2", (2) TKO®25 IIIIIII

232-ow

, Raised Ground, Old

Work, 4" Sq. Box Mounting

of One or Two Device

Applications

30.3 (496.5) (8) 1/2", (4) TKO®(2) 1/2", (2) TKO®25 IIIIIIII

applications

• RACO® Boxes are installed in walls or

ceilings for lighting fixtures, switches or

receptacles

• Square boxes are used where multiple

conductor runs are split into two or more

directions to bring power to a number of

electrical devices

product features

• Combination screw heads provide for

faster installation

• TKO® knockouts offer greater flexibility with

RACO patented combination 1/2" and 3/4"

knockout

• Red boxes, covers and extensions for

dedicated life safety alarm circuits

compliance

• File E195978

• All RACO single gang, two gang, 4"

square, and single gang gangable U.L. listed

steel boxes are acceptable for use in 2-hour

fire rated walls. For additional information,

consult U.L. “Fire Resistance Directory” or

the U.L. website at www.ul.com

• Per U.L. 514-A, suitable for use without

a bonding jumper in circuits up to 600 volts

U.S. Patent 7,300,025, B2 (232-OW)

232SM

232, 8232 231, 8231 233, 8233

911-3

232RAC

232-OW

Square BoxeS & CoverS

steel boxes, covers and accessories

RACO bOxes, COveRs And ACCessORies

A14

SEE End of SEction (PG A67) for dEtAilEd drAwinGS »

applications

• RACO® Boxes are installed in walls or

ceilings for lighting fixtures, switches or

receptacles

• Square boxes are used where multiple

conductor runs are split into two or more

directions to bring power to a number of

electrical devices

product features

• Reference the Box Selection section in the

front of this catalog for complete description

of bracket types and features

• BOX-LOC® (MS) Bracket Box is a snap to

install. Place the bracket on the open side

of the stud first. Slots in the bracket engage

the lip of the stud and actually crimp it as

you press the bracket on the stud, quickly

locking it in place

• Combination screw heads provide for

faster installation

• TKO® knockouts offer greater flexibility with

RACO® patented combination 1/2" and 3/4"

knockout

• UBS Support - Welded to box, preset bend

points to work with wall thickness 2-1/2"

to 6"

• Red boxes, covers and extensions for

dedicated life safety alarm circuits

235, 8235

232M

232HWP, 8232HWP

232H, 232HS

236

911-4

251

238 BOX-LOC®

237

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS Std.

PKG. bAr

codE

SidES

conduit bottom

conduit

4" Square Box, 2-1/8" Deep – Welded with Conduit KO’s

236 , FM, Flush 30.3 (496.5) (6) 3/4" (1) 1/2", (4) 3/4" 25 IIIIIIII

237 , FM, Flush 30.3 (496.5) (6) 1/2", (3) TKO®(3) 1/2", (2) TKO®25 IIIIIIII

235 , TS, Flush 30.3 (496.5) (6) 1/2", (3) TKO®(3) 1/2", (2) TKO®25 —

8235 TS, Flush, 30.3 (496.5) (6) 1/2", (3) TKO®(3) 1/2", (2) TKO®25 IIIIIIII

251 B Flush 30.3 (496.5) (6) 1/2", (3) TKO®(3) 1/2", (2) TKO®25 —

232h Raised Ground, 8" #12 Solid

Copper Pigtail, UBS, HM 30.3 (496.5) (8) 1/2"

(4) TKO®(2) 1/2"

(2) TKO®25 —

232hS Raised Ground, 10" #12

Stranded Copper Pigtail, UBS,

HM 30.3 (496.5) (8) 1/2"

(4) TKO®(2) 1/2"

(2) TKO®25 —

232hwP Raised Ground, UBS, HM 30.3 (496.5) (8) 1/2", (4) TKO®(2) 1/2", (2) TKO®25 —

8232hwP Raised Ground, UBS, HM 30.3 (496.5) (8) 1/2", (4) TKO®(2) 1/2", (2) TKO®25 IIIIIIII

232m , Raised Ground, 8" #12

Solid Copper Pigtail, UBS, HM 30.3 (496.5) (8) 1/2"

(4) TKO®(2) 1/2"

(2) TKO®25 —

232f , Raised Ground 8" #12

Solid Copper Pigtail, UBS 30.3 (496.5) (8) 1/2"

(4) TKO®(2) 1/2"

(2) TKO®25 —

238 BOX-LOC®, MS, Flush, Provided

with Far-side support (part #978) 30.3 (496.5) (6) 1/2"

(3) TKO®(3) 1/2"

(2) TKO®25 IIIIIIII

911-4 FM Bracket, Painted Red 30.3 (496.5) (6) 1/2", (3) TKO®(3) 1/2", (2) TKO®25 —

232F

compliance

• File E195978

• All RACO single gang, two gang, 4" square, and

single gang gangable U.L. listed steel boxes are

acceptable for use in 2-hour fire rated walls. For

additional information, consult U.L. “Fire Resistance

Directory” or the U.L. website at www.ul.com

• Per U.L. 514-A, suitable for use without a

bonding jumper in circuits up to 600 volts

4" squARe bOxes – Welded With COnduit KO’s

Square BoxeS & CoverS

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A15

SEE END OF SECTION (PG A67) FOR DETAILED DRAWINGS »

CAT.

#DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT BOTTOM

CONDUIT

4" Square Plenum Boxes and Cover – Drawn with Conduit KO’s

226 1-1/2"Depth 22.5(368.7) (8)1/2",(4)3/4" (3)1/2",(2)3/4" 50 IIIIIIII

239 2-1/8"Depth 30.3(496.5) (8)1/2",(4)3/4" (3)1/2",(2)3/4" 25 IIIIIIII

762 Gasketedcoverfor4"squareboxes — — — 50 IIIIIIII

239226 762

APPLICATIONS

• RACO® Plenumboxesareusedinabove-

ceilingapplicationswhereair-tight

enclosuresarerequired

PRODUCT FEATURES

• Tomaintainplenumseal,bothRACO226

and239donotprovidegroundscrewholes

• CovergasketisPVCfoammaterial

COMPLIANCE

• FileE195978

4" SQUARE PLENUM BOXES & COVER

SquARE BOXES & COVERS

steel boxes, covers and accessories

RACO bOxes, COveRs And ACCessORies

A16

SEE End of SEction (PG A67) for dEtAilEd drAwinGS »

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS Std.

PKG. bAr

codE

SidES

conduit bottom

conduit

3-3/4" Square Large Capacity Boxes, 3-1/2" Deep – Welded with Conduit KO’s

256 45.0 (737.4) (12) 1/2"-3/4"

Concentric (4) 1/2"-3/4"

Concentric 25 IIIIIIII

911-2 Painted Red 45.0 (737.4) (12) 1/2"-3/4"

Concentric (4) 1/2"-3/4"

Concentric 25 —

3-3/4" Square Large Capacity Bracketed Boxes, 3-1/2" Deep – Welded with Conduit KO’s

255 FM Bracket 45.0 (737.4) (10) 1/2"-3/4"

Concentric (4) 1/2"-3/4"

Concentric 10 IIIIIII

911-1 FM Bracket, Painted Red 45.0 (737.4) (10) 1/2"-3/4"

Concentric (4) 1/2"-3/4"

Concentric 10 —

3-3/4" squARe bOxes – Welded With COnduit KO’s

applications

• RACO® Red boxes and covers allow inspector

or building owner to immediately identify

alarm/fire or life safety systems

product features

• 3-3/4" opening in wall allows for margin of

error when using a 4" square cover

• Accepts all 4" square covers and mudrings

• Red boxes, covers and extensions for

dedicated life safety alarm circuits

compliance

• File E195978

911-2256 911-1255

Square BoxeS & CoverS

steel boxes, covers and accessories

www.Hubbell-RTB.com A17

SEE End of SEction (PG A67) for dEtAilEd drAwinGS »

4" SQUARE BOXES – WELDED WITH ARMORED CABLE / METAL CLAD / FLEX CLAMPS

applications

• RACO® Boxes are installed in walls or

ceilings for lighting fixtrues, switches or

receptacles

• Square boxes are used where multiple

conductor runs are split into two or more

directions to bring power to a number of

electrical devices

product features

• Reference the Box Selection section in the

front of this catalog for complete description

of bracket types and features

• BOX-LOC® (MS) Bracket Box is a snap to

install. Place the bracket on the open side

of the stud first. Slots in the bracket engage

the lip of the stud and actually crimp it as

you press the bracket on the stud, quickly

locking it in place

• UBS Support - Welded to box, preset bend

points to work with wall thickness 2-1/2"

to 6"

• Combination screw heads provide for faster

installation

• TKO® Knockouts offer greater flexibility with

RACO patented combination 1/2" and 3/4"

knockout

229 BOX-LOC®

218, 8218

213, 8213

224

213HWP

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS Std.

PKG. bAr

codE

cAblE

PrioutS SidES

conduit bottom

conduit

4" Square Box, 1-1/2" Deep – Welded with Armored Cable/Metal Clad/Flex Clamps

213 21.0 (344.1) 4(4) 1/2", (2) TKO®(1) 1/2" 50 —

8213 21.0 (344.1) 4(4) 1/2", (2) TKO®(1) 1/2" 50 IIIIIIII

4" Square Bracketed Box, 1-1/2" Deep – Welded with Armored Cable/Metal Clad/Flex Clamps

213hwP , HM, UBS 21.0 (344.1) 4(4) 1/2"

(2) TKO®(1) 1/2" 20 —

224 , B, Flush 21.0 (344.1) 4(2) 1/2"

(1) TKO®(1) 1/2" 25 —

218 , FS, Flush 21.0 (344.1) 4(2) 1/2"

(1) TKO®(1) 1/2" 25 —

8218 , FS, Flush 21.0 (344.1) 4(2) 1/2"

(1) TKO®(1) 1/2" 25 IIIIIIII

229 , BOX-LOC®, (MS)

Flush, Provided with Far-side

support (part #978) 21.0 (344.1) 4(2) 1/2" (1) 1/2" 25 IIIIIIII

compliance

• File E195978

• All RACO single gang, two gang, 4"

square, and single gang gangable U.L. listed

steel boxes are acceptable for use in 2-hour

fire rated walls. For additional information,

consult U.L. “Fire Resistance Directory” or

the U.L. website at www.ul.com

• Per U.L. 514-A, suitable for use without

a bonding jumper in circuits up to 600 volts

Square BoxeS & CoverS

steel boxes, covers and accessories

RACO BOXES, COVERS AND ACCESSORIES

A18

SEE End of SEction (PG A67) for dEtAilEd drAwinGS »

4" SQUARE BOXES – WELDED WITH ARMORED CABLE / METAL CLAD / FLEX CLAMPS

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS Std.

PKG. bAr

codE

cAblE

PrioutS SidES

conduit bottom

conduit

4" Square Box, 2-1/8" Deep – Welded with Armored Cable/Metal Clad/Flex Clamps

248 30.3 (496.5) 4(4) 1/2", (2) TKO®(1) 1/2" 25 IIIIIIII

4" Square Bracketed Box, 2-1/8" Deep – Welded with Armored Cable/Metal Clad/Flex Clamps

241 , TS, Flush 30.3 (496.5) 4(2) 1/2", (1) TKO®(1) 1/2" 25 —

8241 , TS, Flush 30.3 (496.5) 4(2) 1/2", (1) TKO®(1) 1/2" 25 IIIIIIII

249 , B, Flush 30.3 (496.5) 4(2) 1/2", (1) TKO®(1) 1/2" 25 —

248hwP , HM Bracket, UBS 30.3 (496.5) 4(2) 1/2", (1) TKO®(1) 1/2" 25 IIIIIIII

243 , BOX-LOC®, (MS)

Flush, Provided with Far-side

support (part #978) 30.3 (496.5) 4(2) 1/2", (1) TKO®(1) 1/2" 25 IIIIIIII

applications

• RACO® Boxes are installed in walls or

ceilings for lighting fixtrues, switches or

receptacles

• Square boxes are used where multiple

conductor runs are split into two or more

directions to bring power to a number of

electrical devices

product features

• Reference the Box Selection section in the

front of this catalog for complete description

of bracket types and features

• BOX-LOC® (MS) Bracket Box is a snap to

install. Place the bracket on the open side

of the stud first. Slots in the bracket engage

the lip of the stud and actually crimp it as

you press the bracket on the stud, quickly

locking it in place

• Combination screw heads provide for faster

installation

• TKO® knockouts offer greater flexibility with

RACO patented combination 1/2" and 3/4"

knockout

compliance

• File E195978

• All RACO single gang, two gang, 4"

square, and single gang gangable U.L. listed

steel boxes are acceptable for use in 2-hour

fire rated walls. For additional information,

consult U.L. “Fire Resistance Directory” or

the U.L. website at www.ul.com

• Per U.L. 514-A, suitable for use without

a bonding jumper in circuits up to 600 volts

243 BOX-LOC®

241, 8241248 248HWP249

Square BoxeS & CoverS

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A19

SEE END OF SECTION (PG A67) FOR DETAILED DRAWINGS »

APPLICATIONS

• RACO® Boxesareinstalledinwallsor

ceilingsforlightingfixtrues,switchesor

receptacles

• Squareboxesareusedwheremultiple

conductorrunsaresplitintotwoormore

directionstobringpowertoanumberof

electricaldevices

PRODUCT FEATURES

• ReferencetheBoxSelectionsectionin

thefrontofthiscatalogforcomplete

descriptionofbrackettypesandfeatures

• BOX-LOC® (MS)BracketBoxisasnapto

install.Placethebracketontheopenside

ofthestudfirst.Slotsinthebracketengage

thelipofthestudandactuallycrimpitas

youpressthebracketonthestud,quickly

lockingitinplace

• Combinationscrewheadsprovideforfaster

installation

• TKO®knockoutsoffergreaterflexibilitywith

RACOpatentedcombination1/2"and3/4"

knockout

228 BOX-LOC®

223211, 8211 225

240, 8240242

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

CABLE

PRIOUTS SIDES

CONDUIT BOTTOM

CONDUIT

4" Square Box, 1-1/2" Deep – Welded with Nonmetallic Sheathed Cable Clamps

211 21.0(344.1) 4(4)1/2",(2)TKO (1)1/2" 50 —

8211 21.0(344.1) 4(4)1/2",(2)TKO (1)1/2" 50 IIIIIIII

223 ,FS,Flush 21.0(344.1) 4(2)1/2",(1)TKO (1)1/2" 25 IIIIIIII

225 ,B,Flush 21.0(344.1) 4(2)1/2",(1)TKO (1)1/2" 25 —

228 ,BOX-LOC®,(MS)

Flush,ProvidedwithFar-side

support(part#978)

21.0(344.1) 4(2)1/2"

(1)TKO (1)1/2" 25 IIIIIIII

4" Square Box, 2-1/8" Deep – Welded with Nonmetallic Sheathed Cable Clamps

242 30.3(496.5) 4(4)1/2",(2)TKO (1)1/2" 25 —

240 ,TS,Flush 30.3(496.5) 4(2)1/2",(1)TKO (1)1/2" 25 —

8240 ,TS,Flush 30.3(496.5) 4(2)1/2",(1)TKO (1)1/2" 25 IIIIIIII

COMPLIANCE

• FileE195978

• AllRACOsinglegang,twogang,4"

square,andsingleganggangableU.L.listed

steelboxesareacceptableforusein2-hour

fireratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteatwww.ul.com

• PerU.L.514-A,suitableforusewithout

abondingjumperincircuitsupto600volts

4" SQUARE BOXES – WELDED WITH NONMETALLIC SHEATHED CABLE CLAMPS

SquARE BOXES & COVERS

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A20

SquARE BOXES & COVERS

4" SQUARE COVERS

774, 775, 8775

782

787 785, 786771, 8771, 772, 8772

773, 8773, 768, 8768

CATALOG # DESCRIPTION

CUBIC INCHES (CM3)

STD. PKG. BARCODE

4" Square Flat Covers

752 Flat,Blank —50 —

8752 Flat,Blank —50 IIIIIIII

8752-5* Flat,Blank —50 IIIIIIII

753 Flat,1/2"KOinCenter —50 —

8753 Flat,1/2"KOinCenter —50 IIIIIIII

8753-5* Flat,1/2"KOinCenter —50 IIIIIIII

911-8 Flat,Blank,PaintedRed —50 IIIIIIII

4" Square Single Device Covers

787 Flat —25 IIIIIIII

771 Raised1/4" 1.5(24.6) 100 —

8771 Raised1/4" 1.5(24.6) 25 IIIIIIII

782 Raised1/2"Tile 3.5(57.3) 25 IIIIIIII

772 Raised1/2"Drawn 3.5(57.3) 100 —

8772 Raised1/2"Drawn 3.5(57.3) 50 IIIIIIII

768 Raised5/8" 4.5(73.7) 50 —

8768 Raised5/8" 4.5(73.7) 25 IIIIIIII

773 Raised3/4" 5.5(90.1) 50 —

8773 Raised3/4" 5.5(90.1) 25 IIIIIIII

774 Raised1" 7.5(122.9) 25 IIIIIIII

775 Raised1-1/4" 9.5(115.6) 25 —

8775 Raised1-1/4" 9.5(115.6) 25 IIIIIIII

785 Raised1-1/2" 11.3(185.2) 25 —

786 Raised2" 14.5(237.6) 25 —

753, 8753,

8753-5 911-8

752, 8752,

8752-5

*5 Bundles of 10 – sold in carton quantities only

APPLICATIONS

• RACO® coversareusedtocloseanoutletbox

• Raiseddevicecoversareusedformounting

switchesorreceptacles

PRODUCT FEATURES

• Redboxes,coversandextensionsfor

dedicatedlifesafetyalarmcircuits

• Angledmountingslotscompensateupto

12°forboxmisalignment

COMPLIANCES

• FileE195978

• FileLR-1082

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A21

SquARE BOXES & COVERS

4" SQUARE COVERS

779, 8779

777, 8777-0 769, 8769778, 8778791

795, 796781, 8781780

CATALOG # DESCRIPTION

CUBIC INCHES (CM3)

STD. PKG. BARCODE

4" Square Two Device and Tile Covers

791 Flat —25 IIIIIIII

777 Raised,1/4",Drawn 3.0(49.2) 50 —

8777-0 Raised,1/4",Drawn 3.0(49.2) 10 IIIIIIII

778 Raised,1/2",Drawn 5.5(90.1) 50 —

8778 Raised,1/2",Drawn 5.5(90.1) 25 IIIIIIII

769 Raised,5/8",Drawn 7.3(119.6) 50 —

8769 Raised,5/8",Drawn 7.3(119.6) 25 IIIIIIII

779 Raised,3/4",Drawn 8.8(144.2) 50 —

8779 Raised,3/4",Drawn 8.8(144.2) 25 IIIIIIII

780 Raised,1",Drawn 12.0(196.6) 25 IIIIIIII

781 Raised,1-1/4",Drawn 15.0(245.8) 25 —

8781 Raised,1-1/4",Drawn 15.0(245.8) 25 IIIIIIII

795 Raised,1-1/2",Welded 15.5(253.9) 25 —

796 Raised,2",Welded 20.5(335.9) 25 —

APPLICATIONS

• Raiseddevicecoversareusedformounting

switchesorreceptacles

• Lowvoltagepartitionsmaybeaddedto

conduit-typeboxestodividepowerfrom

voice/data

PRODUCT FEATURES

• Angledmountingslotscompensateupto

12°forboxmisalignment

COMPLIANCE

• FileE195978

• FileLR-1082

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A22

SquARE BOXES & COVERS

4" SQUARE PARTITIONS

706RAC, 707RAC 708, 709

*Low voltage partitions are not UL Listed

Boxes, covers, and partitions must be ordered separately.

For 1-1/2" deep box with 5/8" cover, partition not available. For 2-1/8" deep box with 5/8" cover, use #708 partition.

Partitions are usable but not UL listed for 4-11/16" sq. box.

CAT. # DESCRIPTION STD. PKG. BARCODE

Low Voltage Partitions* for 1-1/2" Depth Boxes and 2-Device Covers

706RAC Fits1/4",1/2",3/4"or1"CoverDepth(#777, 778, 8778, 779, 8779, 780) 25 —

708 Fits1-1/4",1-1/2"or2"CoverDepth(#781, 8781, 795, 796) 25 —

Low Voltage Partitions* for 2-1/8" Depth Boxes and 2-Device Covers

707RAC Fits1/4",1/2",3/4"or1"CoverDepth(#777, 778, 8778, 779, 8779, 780) 25 —

709 Fits1-1/4",1-1/2"or2"CoverDepth(#781, 8781, 795, 796) 25 —

756-759, 767,

8756, 8767 896 897KH

NEw!

NEw

CAT. # DESCRIPTION CUBIC

INCHES

(CM3)

RECOMMENDED MAX. LOADS STD.

PKG. BAR

CODE

CEILING FAN

(DYNAMIC) LBS. FIXTURE

(STATIC) LBS.

4" Square Fixture Covers

767 Raised,1/2"Open,Ears2-3/4"O.C. 3.0(49.2) No 50 25 —

8767 Raised,1/2"Open,Ears2-3/4"O.C. 3.0(49.2) No 50 25 IIIIIIII

756 Raised,5/8"Open,Ears2-3/4"O.C. 4.0(65.5) No 50 100 —

8756 Raised,5/8"Open,Ears2-3/4"O.C. 4.0(65.5) No 50 25 IIIIIIII

759 Raised,3/4"Open,Ears2-3/4"O.C. 5.0(81.9) No 50 25 IIIIIIII

757 Raised,1"Open,Ears2-3/4"O.C. 6.8(111.4) No 50 25 IIIIIIII

758 Raised,1-1/4"Open,Ears2-3/4"O.C. 8.5(139.3) No 50 25 —

4" Square Swivel Fixture Covers

896 For4"Sq.Boxes,1/2"or3/4"Pipe —No 50 25 —

897KH KWIK-HANG® for4"Sq.Boxes,1/2"or

3/4"Pipe —No 50 25 —

APPLICATIONS

• Raisedfixturecoversareusedwhere

fixtureswillbeinstalled

PRODUCT FEATURES

• Angledmountingslotscompensateupto

12°forboxmisalignment

• Swivelcoversrestrictedto20°swingfrom

vertical

• KWIK-HANG®897KHallowseasyinstallation

ofhighbaylightingfixtures.Fixturerestsin

positionwhilewiringiscompleted

COMPLIANCES

• FileE195978

• FileLR-1082

PatentPending(897KH)

APPLICATIONS

• Lowvoltagepartitionsmaybeaddedto

conduit-typeboxestodividepowerfrom

voice/data

• Mustbeusedwithraisedcovers

PRODUCT FEATURES

• Partitiondivides4"squareboxesintotwo

compartments

• Usewithtwo-devicecoverswhichhavea

slotforthepartition

• Partitionisscoredsoitcanbebrokenatthe

properdepthofboxandcovercombination

• Helpfulhint:Assembletheboxwiththe

partitioninplacebeforebreakingoffat

thescoredtab.Thiswillpreventyoufrom

breakingoffmoretabthanneeded

COMPLIANCES

• FileE195978

• FileLR-1082

4" SQUARE FIXTURE COVERS

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A23

4" SQUARE EXPOSED WORK COVERS

APPLICATIONS

• RACO® surfacecoversareusedtosupport

switchesorreceptaclesinareaswherethebox

issurfacemountedorpositionedinexposed

workapplications

PRODUCT FEATURES

• RACO® exposedworkcoversincluderequired

hardwareformountingthereceptacle(s)

• RACO® Exposedworkcoversmeetthe

requirementsofthe2014NECArticle

250.146(A).Nobondingjumperisrequired

forcoverswith:

 (1)Crushedcorners

(2)Twoormoredeviceattachmentscrews

(3)Alockwasherorequivalent

• Hardwareandcoverarepackedinapoly-bag

withprintedcatalognumber,compliances

andinstallationinstructions

COMPLIANCES

• FileE195978

804C803C801C800C 805C

806C 807C 808C 810C809C 811C 812C

813C 814C

902C831C

817C815C

906C 907C 915C830C

816C

CATALOG # DESCRIPTION

CUBIC IN.

(CM3)

STD. PKG. BARCODE

4" Square, Crushed Corner Covers – Raised 1/2"

800C 1ToggleSwitch 6.5(106.5) 10 IIIIIIII

801C 1Receptacle1.406"Dia. 6.5(106.5) 10 IIIIIIII

803C 2ToggleSwitches 6.5(106.5) 10 IIIIIIII

804C Blank,NoHoles 6.5(106.5) 10 IIIIIIII

805C 1ToggleSwitchand1Receptacle1.406"Dia. 6.5(106.5) 10 IIIIIIII

806C 1Duplexand1Receptacle1.406"Dia. 6.5(106.5) 10 IIIIIIII

807C 2Receptacles1.406"Dia. 6.5(106.5) 10 IIIIIIII

808C 1GFCI 6.5(106.5) 10 IIIIIIII

809C 2GFCI 6.5(106.5) 10 IIIIIIII

810C 30-50AReceptacle2.141"Dia. 6.5(106.5) 10 IIIIIIII

811C 30ALocking1.719"Dia. 6.5(106.5) 10 IIIIIIII

812C 20AReceptacle1.620"Dia. 6.5(106.5) 10 IIIIIIII

813C 30-60AReceptacle2.625"Dia. 6.5(106.5) 10 IIIIIIII

814C 1GFCIand1ToggleSwitch 6.5(106.5) 10 IIIIIIII

815C 1Receptacle2.165"Dia.,Offset 6.5(106.5) 10 IIIIIIII

816C 1Receptacle2.480"Dia. 6.5(106.5) 10 IIIIIIII

817C 1Receptacle2.275"Dia.,Offset 6.5(106.5) 10 IIIIIIII

830C 1Receptacle2.255"Dia. 6.5(106.5) 10 IIIIIIII

831C 1Duplex,120ATwistLock®1.620"Dia. 6.5(106.5) 10 IIIIIIII

902C 1DuplexReceptacle 6.5(106.5) 10 IIIIIIII

906C 1DuplexReceptacleand1ToggleSwitch 6.5(106.5) 10 IIIIIIII

907C 2DuplexReceptacles 6.5(106.5) 10 IIIIIIII

915C 1GFCIand1DuplexReceptacle 6.5(106.5) 10 IIIIIIII

SquARE BOXES & COVERS

CRUSHED

CORNER

COVERS

CRUSHED

CORNER

COVERS

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A24

4" SQUARE EXPOSED WORK COVERS

SquARE BOXES & COVERS

APPLICATIONS

• RACO® surfacecoversareusedtosupport

switchesorreceptaclesinareaswherethe

boxissurfacemountedorpositionedin

exposedworkapplications

PRODUCT FEATURES

• RACO® exposedworkcoversincluderequired

hardwareformountingthereceptacle(s)

• RACO® Exposedworkcoversmeetthe

requirementsofthe2014NECArticle

250.146(A).Nobondingjumperisrequired

forcoverswith:

 (1)Crushedcorners

(2)Twoormoredeviceattachmentscrews

(3)Alockwasherorequivalent

• Hardwareandcoverarepackedinapoly-bag

withprintedcatalognumber,compliances

andinstallationinstructions

• Non-crushedcornercoversallowfor

additionalwiringcapacityforGFCI'sand

dimmers

COMPLIANCES

• FileE195978

PatentPending(808Uand809U)

809808 814 915

808U 809U

CATALOG # DESCRIPTION

CUBIC IN.

(CM3)

STD. PKG. BARCODE

4" Square Crushed Corner Covers – Raised 1/2"

808U Universalfor1Device:1GFCI,1Duplexor1Toggle

(InsertPlates) 6.5(106.5) 10 IIIIIIII

809U Universalfor2Device:2GFCI,2Duplexor2Toggle

(InsertPlates) 6.5(106.5) 10 IIIIIIII

4" Square Extra-Capacity Non-Crushed Corner Covers – Raised 1/2"

808 1GFCI 7.3(119.6) 10 IIIIIIII

809 2GFCI 7.3(119.6) 10 IIIIIIII

814 1GFCIand1ToggleSwitch 7.3(119.6) 10 IIIIIIII

915 1GFCIand1DuplexReceptacle 7.3(119.6) 10 IIIIIIII

NEw!

NEw!

NEw

NEw

CRUSHED

CORNER

COVERS

CRUSHED

CORNER

COVERS

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A25

SEE END OF SECTION (PG A68) FOR DETAILED DRAWINGS »

4-11/16" SQUARE BOXES AND EXTENSION RINGS – DRAWN WITH CONDUIT KO'S

APPLICATIONS

• RACO® 4-11/16"Boxesareusedforawide

varietyofindustrialapplicationswhere

largersizedconductorsorwiringdevicesare

neededandmorevolumeisrequired

• Drawnboxesareidealforexposedwork

applications(surfacemountedwiring)

• RACO® Extensionringsprovideameansfor

addingcubiccapacityorasanoutletboxfor

surfaceconduit

PRODUCT FEATURES

• Combinationscrewheadsprovidefor

fasterinstallation

COMPLIANCE

• FileE195978

245 247246

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT BOTTOM

CONDUIT

4-11/16" Square Boxes, 1-1/2" Deep – Drawn with Conduit KO's

245 —29.5(483.4) (12)1/2" (3)1/2",(2)3/4" 25 —

246 —29.5(483.4) (10)3/4" (3)1/2",(2)3/4" 25 —

247 —29.5(483.4) (8)1/2",(4)3/4" (3)1/2",(2)3/4" 25 —

4-11/16" Square Extension Rings – Drawn with Conduit KO's

250 1-1/2"Depth 29.5(483.4) (8)1/2",(4)3/4" —25 IIIIIIII

262 2-1/8"Depth 43.0(704.6) (8)1/2",(4)3/4" —25 IIIIIIII

262

250

SquARE BOXES & COVERS

steel boxes, covers and accessories

RACo BoxeS, CoveRS And ACCeSSoRieS

A26

SEE End of SEction (PG A68) for dEtAilEd drAwinGS »

4-11/16" SquARe BoxeS – Welded WiTH ConduiT Ko'S

* Not UL Rated

applications

• RACO® 4-11/16" Boxes are used for a wide

variety of industrial applications where

larger sized conductors or wiring devices are

needed and more volume is required

product features

• Reference the Box Selection section in the

front of this catalog for complete description

of bracket types and features

• BOX-LOC® (MS) Bracket Box is a snap to

install. Place the bracket on the open side

of the stud first. Slots in the bracket engage

the lip of the stud and actually crimp it as

you press the bracket on the stud, quickly

locking it in place

• Combination screw heads provide for faster

installation

• TKO® knockouts allow for design and

installation flexibility

• UBS Support - Welded to box, preset bend

points to work with wall thickness 2-1/2"

to 6"

• Red boxes, covers and extensions for

dedicated life safety alarm circuits

compliance

• File E195978

• Per U.L. 514-A, suitable for use without

a bonding jumper in circuits up to 600 volts

257SM

257, 8257,

8257SP

257F

258

257H, 257HS

265, 8265,

8265SP

266 BOX-LOC®

259

254

257M

257HWP

911-12 258SM

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS Std.

PKG. bAr

codE

SidES

conduit bottom conduit

4-11/16" Square Boxes, 2-1/8" Deep – Welded with Conduit KO's

257 , Raised Ground 42.0 (688.2) (12) TKO®(1) 1/2", (3) TKO®25 —

8257 , Raised Ground 42.0 (688.2) (12) TKO®(1) 1/2", (3) TKO®25 IIIIIIII

8257SP , Raised Ground 42.0 (688.2) (12) TKO®(1) 1/2", (3) TKO®20 IIIIIIII

258 , Raised Ground 42.0 (688.2) (8) 1" (1) 1/2", (3) TKO®25 —

259* , Raised Ground 42.0 (688.2) (6) 1-1/4" (1) 1/2", (3) TKO®25 —

265 , Raised Ground 42.0 (688.2) (4) 3/4", (4) 1" (1) 1/2", (3) TKO®25 —

8265 , Raised Ground 42.0 (688.2) (4) 3/4", (4) 1" (1) 1/2", (3) TKO®25 IIIIIIII

8265SP , Raised Ground 42.0 (688.2) (4) 3/4", (4) 1" (1) 1/2", (3) TKO®20 IIIIIIII

911-12 , Raised Ground, Painted

Red 42.0 (688.2) (12) TKO®(1) 1/2", (3) TKO®25 —

257Sm , Raised Ground, 10" #12

Stranded Copper Pigtail 42.0 (688.2) (12) TKO®(1) 1/2"

(3) TKO®25 IIIIIIII

258Sm , Raised Ground, 10" #12

Stranded Copper Pigtail 42.0 (688.2) (8) 1" (1) 1/2"

(3) TKO®25 IIIIIIII

257f , Raised Ground, 8" #12

Solid Copper Pigtail, UBS 42.0 (688.2) (12) TKO®(1) 1/2"

(3) TKO®20 —

4-11/16" Square Bracketed Boxes, 2-1/8" Deep – Welded with Conduit KO's

257h , Raised Ground, 8" #12

Solid Copper Pigtail, UBS, HM 42.0 (688.2) (12) TKO®(1) 1/2"

(3) TKO®20 —

257hS , Raised Ground, 10"

#12 Stranded Copper Pigtail,

UBS, HM 42.0 (688.2) (12) TKO®(1) 1/2"

(3) TKO®20 —

257hwP Raised Ground, UBS, HM 42.0 (688.2) (12) TKO®(1) 1/2", (3) TKO®20 —

257m , Raised Ground, 8" #12

Solid Copper Pigtail, UBS, HM 42.0 (688.2) (12) TKO®(1) 1/2"

(3) TKO®20 —

254 , Raised Ground, FM 42.0 (688.2) (9) TKO®(1) 1/2", (3) TKO®25 IIIIIIII

266

, Raised Ground,

BOX-LOC®, MS Flush, Provided

with Far-side support (part

#978)

42.0 (688.2) (9) TKO®(1) 1/2"

(3) TKO®25 IIIIIIII

Square BoxeS & CoverS

New!

New

New

New

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A27

4-11/16" SQUARE COVERS

SquARE BOXES & COVERS

APPLICATIONS

• Coversareusedtocloseanoutletbox

• Raiseddevicecoversareusedformounting

switchesorreceptacles

PRODUCT FEATURES

• Redboxes,coversandextensionsfor

dedicatedlifesafetyalarmcircuits

COMPLIANCE

• FileE195978

• FileLR-1082

832

837, 8837

833, 8833-5

898

911-11

899

843

842

838 839

*5 Bundles of 10 – sold in carton quantities only

CATALOG # DESCRIPTION STD. PKG. BARCODE

4-11/16" Square Flat Covers

832 Flat,Blank 50 IIIIIIII

833 Flat,1/2"KO,Centered 50 IIIIIIII

8833-5* Flat,1/2"KO,Centered 50 IIIIIIII

911-11 Flat,Blank,PaintedRed 50 —

CATALOG # DESCRIPTION

CUBIC IN.

(CM3)

STD. PKG. BARCODE

4-11/16" Square Single Device and Tile Covers

837 Raised1/2" 3.5(57.3) 25 —

8837 Raised1/2" 3.5(57.3) 25 IIIIIIII

843 Raised5/8" 4.5(73.7) 25 IIIIIIII

838 Raised3/4" 5.5(90.1) 25 —

839 Raised1" 7.5(122.9) 25 —

842 Raised1-1/4" 9.5(155.6) 25 —

898 Raised1-1/2" 11.0(180.2) 20 —

899 Raised2" 16.0(126.1) 20 —

steel boxes, covers and accessories

RACO bOxes, COveRs And ACCessORies

A28

4-11/16" squARe COveRs And PARtitiOns

Square BoxeS & CoverS

706RAC, 707RAC 708, 709

*Low voltage partitions are not UL Listed

Boxes, covers, and partitions must be ordered separately.

For 1-1/2" deep box with 5/8" cover, partition not available. For 2-1/8" deep box with 5/8" cover, use #708 partition.

Partitions are usable but not UL listed for 4-11/16" sq. box.

cAt. # dEScriPtion Std. PKG. bArcodE

Low Voltage Partitions* for 1-1/2" Depth Boxes and 2-Device Covers

706rAc Fits 1/4", 1/2", 3/4" or 1" Cover Depth (#777, 778, 8778, 779, 8779, 780) 25 —

708 Fits 1-1/4", 1-1/2" or 2" Cover Depth (#781, 8781, 795, 796) 25 —

Low Voltage Partitions* for 2-1/8" Depth Boxes and 2-Device Covers

707rAc Fits 1/4", 1/2", 3/4" or 1" Cover Depth (#777, 778, 8778, 779, 8779, 780) 25 —

709 Fits 1-1/4", 1-1/2" or 2" Cover Depth (#781, 8781, 795, 796) 25 —

829 835

applications

• RACO® 4-11/16" raised device covers are for

mounting switches or receptacles

• Raised fixture covers are used where

fixtures will be installed

• Low voltage partitions may be added to

conduit-type boxes to divide power from

voice/data

• Partitions must be used with raised

covers

product features

• Red boxes, covers and extensions for

dedicated life safety alarm circuits

• Partition divides 4" square boxes into

two compartments

• Use partitions with two-device covers which

have a slot for the partition

• Partition is scored so it can be broken at the

proper depth of box and cover combination

• Helpful hint: Assemble the box with the

partition in place before breaking off at

the scored tab. This will prevent you from

breaking off more tab than needed

compliance

• File E195978

• File LR-1082

818841 840 819 820

855, 859 911-16, 911-17

885

New! New!

cAt. # dEScriPtion cubic

inchES

(cm3)

rEcommEndEd mAx. loAdS Std.

PKG. bAr

codE

cEilinG fAn

(dynAmic) lbS. fixturE

(StAtic) lbS.

4-11/16" Square Fixture Covers

829 Raised 1/2", Open, Ears 2-3/4" O.C. 3.0 (49.6) No 50 25 IIIIIIII

835 Raised 5/8", Open, Ears 2-3/4" O.C. 4.0 (65.5) No 50 25 —

cAtAloG # dEScriPtion

cubic in.

(cm3)

Std. PKG. bArcodE

4-11/16" Square Two Device and Tile Covers

841 Raised 1/2" 5.5 (90.3) 25 IIIIIIII

818 Raised 5/8" 7.3 (119.6) 25 —

840 Raised 3/4" 8.8 (144.2) 25 —

819 Raised 1" 12.0 (196.6) 25 —

820 Raised 1-1/4" 15.0 (245.8) 25 —

885 Raised 1-1/2" 15.5 (254.0) 20 —

855 Raised 5/8", For Life Safety Appliances & Emergency

Exit Signs 8.3 (136.0) 25 —

859 Raised 1-1/4", For Life Safety Appliances & Emergency

Exit Signs 16.0 (262.0) 12 —

911-16 Raised 5/8", For Life Safety Appliances & Emergency

Exit Signs, Painted Red 8.3 (136.0) 25 —

911-17 Raised 1-1/4", For Life Safety Appliances & Emergency

Exit Signs, Painted Red 16.0 (262.0) 12 —

New

New

New

New

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A29

4-11/16" SQUARE EXPOSED WORK COVERS

SquARE BOXES & COVERS

878 887 888 959

972 979 881RAC 876

APPLICATIONS

• RACO® surfacecoversareusedtosupport

switchesorreceptaclesinareaswherethebox

issurfacemountedorpositionedinexposed

workapplications

PRODUCT FEATURES

• RACO® exposedworkcoversincluderequired

hardwareformountingthereceptacle(s)

• RACO® Exposedworkcoversmeetthe

requirementsofthe2014NECArticle

250.146(A).Nobondingjumperisrequired

forcoverswith:

 (1)Crushedcorners

(2)Twoormoredeviceattachmentscrews

(3)Alockwasherorequivalent

• Hardwareandcoverarepackedinapoly-bag

withprintedcatalognumber,compliances

andinstallationinstructions

COMPLIANCES

• FileE195978

CATALOG # DESCRIPTION

CUBIC IN.

(CM3)

STD. PKG. BARCODE

4-11/16" Exposed Work Covers

856 1DecoratordeviceorGFCI 10.3(168.7) 10 IIIIIIII

857 2DecoratordevicesorGFCI 10.3(168.7) 10 IIIIIIII

858 1ToggleSwitchand1GFCI 10.3(168.7) 10 IIIIIIII

870RAC 1ToggleSwitch 10.3(168.7) 10 IIIIIIII

878 30-50AReceptacle2.141"Dia. 10.3(168.7) 10 IIIIIIII

887 20AReceptacle1.594"Dia. 10.3(168.7) 10 IIIIIIII

888 30-60AReceptacle2.625"Dia. 10.3(168.7) 10 IIIIIIII

959 1Duplexand1GFCI 10.3(168.7) 10 IIIIIIII

972 1DuplexReceptacle 10.3(168.7) 10 IIIIIIII

979 2DuplexReceptacles 10.3(168.7) 10 IIIIIIII

881RAC 2ToggleSwitches 10.3(168.7) 10 IIIIIIII

876 1ToggleSwitchand1DuplexReceptacle 10.3(168.7) 10 IIIIIIII

857

856 858 870RAC

steel boxes, covers and accessories

RACO bOxes, COveRs And ACCessORies

A30

SEE End of SEction (PG A67 And A68) for dEtAilEd drAwinGS »

life sAfety suPPORt PROduCts - immediAte identifiCAtiOn

applications

• RACO® Red boxes and covers allow inspector

or building owner to immediately identify

alarm/fire or life safety systems

product features

• 911-2, 911-1 boxes have 3-3/4" opening in

wall that allows for a margin of error when

using a standard 4" square cover

• 911-15 accepts all 4-11/16" square covers

and mudrings

• Red boxes, covers and extensions for

dedicated life safety alarm circuits

compliances

• LISTED

LISTED - UL E195978

911-2 911-1

911-15

911-3

911-4

911-6911-9 911-12

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS Std.

PKG. bAr

codE

SidES

conduit bottom

conduit

Life Safety Steel Wall Boxes and Extension Rings – Painted Red

911-9 1-1/2" Depth, Welded,

4" Square 21.0 (344.1) (8) 1/2", (4) TKO®(2) 1/2", 2 TKO®50 —

911-6 1-1/2" Depth, 4" Square,

Drawn Extension Ring 22.5 (368.7) (8) 1/2", (4) 3/4" — 50 —

911-12 2-1/8" Depth, Welded,

4-11/16" Square 42.0 (688.2) (12) TKO®(1) 1/2",

(3) TKO®25 —

911-3 2-1/8" Depth, Welded,

4" Square 30.3 (496.5) (8) 1/2", (4) TKO®(3) 1/2", 2 TKO®25 —

911-4 2-1/8" Depth, Welded,

4" Square, FM Bracket 30.3 (496.5) (6) 1/2", (3) TKO®(3) 1/2", 2 TKO®25 —

911-15 3-1/4" Depth Back Box,

Welded, 4-11/16" Square 66.7 (1093.0)

(2) 1/2" - 3/4" TKO,

(2) 1" - 1-1/4"TKO,

(2) 1" - 2" Conc. KO

(2) 3/4"- 1" TKO,

(2) 1/2" KO 10 —

911-2 3-1/2" Depth, Welded,

3-3/4" Square 45.0 (737.4) (12) 1/2"-3/4"

Concentric (4) 1/2"-3/4"

Concentric 25 —

911-1 3-1/2" Depth, Welded,

3-3/4" Square, FM Bracket 45.0 (737.4) (10) 1/2"-3/4"

Concentric (4) 1/2"-3/4"

Concentric 10 —

New!

New

Square BoxeS & CoverS

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A31

LIFE SAFETY SUPPORT PRODUCTS - IMMEDIATE IDENTIFICATION

APPLICATIONS

• RACO® Redboxesandcoversallowinspector

orbuildingownertoimmediatelyidentify

alarm/fireorlifesafetysystems

PRODUCT FEATURES

• Redboxes,coversandextensionsfor

dedicatedlifesafetyalarmcircuits

COMPLIANCES

• LISTED

 LISTED-ULE195978

*Low voltage partitions are not UL Listed

Boxes, covers, and partitions must be ordered separately.

Partitions are usable but not UL listed for 4-11/16" sq. box.

SquARE BOXES & COVERS

911-16, 911-17

911-8

911-11

NEw!

NEw!

706RAC, 707RAC 206RAC, 8206RAC

205RAC

APPLICATIONS

• Lowvoltagepartitionsmaybeaddedto

conduit-typeboxestodividepowerfrom

voice/data

• Partitionsmustbeusedwithraisedcovers

• RACO® RETRO-RING® isusedtopositionany

depth,4"squaresteeljunctionboxinasheet

rockcoveredwallcavity

• Use205RACisusedinoldworklifesafety

applianceinstallations

• 206RACisusedinoldworkinstallations

whereoneortwodevicesarerequired

PRODUCT FEATURES

• RACO® RETRO-RING® worksin3/8"to1-1/2"

thickwallorceilingapplications

• Smallfootprintiscoveredbymostpopular

lifesafetydevices

• Steeloldworkwingsallowforsecure

mountingofboxanddevicestowall

• Includesonewalltemplatepercarton

• 206RACallowsforinstallationofsteellow

voltagepartitionforpower/dataapplications.

Oneortwodevicesmountdirectlyto206RAC

COMPLIANCE

• FileE195973

U.S.Patent7,300,025,B2(205RAC,206RAC,8206RAC)

855, 859

CATALOG # DESCRIPTION

CUBIC IN.

(CM3)

STD. PKG. BARCODE

Life Safety Steel Wall Boxes Covers

911-16 4-11/16"Sq.x4"Sq.Adapter,5/8"Raised,PaintedRed 8.3(136.0) 25 —

911-17 4-11/16"Sq.x4"Sq.Adapter,1-1/4"Raised,Painted

Red 16.0(262.0) 12 —

855 4-11/16"Sq.x4"Sq.Adapter,5/8"Raised 8.3(136.0) 25 —

859 4-11/16"Sq.x4"Sq.Adapter,1-1/4"Raised 16.0(262.0) 12 —

911-8 4"Sq.,FlatBlankCover,PaintedRed —50 —

911-11 4-11/16"Sq.,FlatBlankCover,PaintedRed —50 —

CATALOG # DESCRIPTION STD. PKG. BARCODE

Low Voltage Box Partition

706RAC BoxPartitionforRETRO-RING®and1-1/2"Depth,4"Sq.Box 25 —

707RAC BoxPartitionforRETRO-RING®and2-1/8"Depth,4"Sq.Box 25 —

Life Safety Steel Wall Box Mounting Brackets

205RAC OldWork,4"Sq.BoxMountingofLifeSafetySupport 20 —

206RAC OldWork,4"Sq.BoxMountingofOneorTwoDeviceApplications 20 —

8206RAC OldWork,4"Sq.BoxMountingofOneorTwoDeviceApplications 10 IIIIIIII

NEw

NEw

NEw

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A32

SEE END OF SECTION (PG A68) FOR DETAILED DRAWINGS »

BOXES FOR AUDIO, VIDEO, POWER AND DATA

263

260

APPLICATIONS

• RACO® Largecapacityboxesareusedfor

audio,video,dataandpowerapplications

providingamplespaceforCat6Aandfiber

opticcablebends

260 PRODUCT FEATURES

• Largecapacitydesignmeasures

4-11/16"Hx4-11/16"Wx3-1/4"D

• Acceptsstandard4-11/16"squaredevice

andflatcovers

• Groundscrewsprovided

263 PRODUCT FEATURES

• Largecapacitydesignmeasures

4-11/16"Hx7-3/4"Wx3-1/4"D

• Acceptsstandard4"squaredeviceand

flatcoversor792,793,7943-gangdevice

covers

• Built-intabsallowforspannerbars

• Includes1/2"thru2"knockouts

• Accepts981voltagepartition(ULListed)

• Groundscrewsprovided

255 AND 256 PRODUCT FEATURES

• Largecapacitydesignmeasures

3-3/4"Hx3-3/4"Wx3-1/2"D

• Acceptsstandard4"squaredeviceandflat

covers

COMPLIANCE

• LISTED,OutletBox,731A

PatentPending(263)

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT BOTTOM CONDUIT

4-11/16" Large Capacity Steel Wall Boxes, 3-1/4" Deep – Welded with Conduit KO’s

260 RaisedGround 66.7

(1093)

(2)1/2"-3/4"TKO,

(2)1"-1-1/4"TKO,

(2)1"-2"Conc.KO

(2)3/4"-1"TKO,

(2)1/2"KO 10 —

263 RaisedGround 113.3

(1856.6)

(6)1/2"-3/4"TKO,

(2)3/4"-1"TKO,

(2)1"-1-1/4"TKO,

(2)1"-2"Conc.KO

(2)1/2"-3/4"TKO,

(2)3/4"-1"TKO,

(2)1"-1-1/4"TKO

6—

3-3/4" Square Large Capacity Steel Wall Boxes, 3-1/2" Deep – Welded with Conduit KO’s

256 — 45.0

(737.4)

(12)1/2"-3/4"

Concentric

(4)1/2"-3/4"

Concentric 25 IIIIIIII

255 FMBracket 45.0

(737.4)

(10)1/2"-3/4"

Concentric

(4)1/2"-3/4"

Concentric 10 IIIIIIII

256 255

NEw! NEw!

NEw

NEw

LARGE CApACITy BOXES

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A33

LARGE CApACITy BOXES

COVERS AND PARTITIONS

APPLICATIONS

• RACO® Largecapacityboxesareusedfor

audio,video,dataandpowerapplications

providingamplespaceforCat6Aandfiber

opticcablebends

• 792,793and794coversaresolelyfor

RACO®263databox.The3-gangraised

coversare5/8",3/4"and1-1/4"raised

respectively

• 855isdesignedtoreduce4-11/16"square

boxto4"sq.boxopenings

PRODUCT FEATURES

• Usewithstandard4"squaresingleordouble

mudringsor3gangsspecialcovers(263)

• 855providesflushmountingoflighting

controllers,exitsignsandlifesafety

appliances

• AcceptsULListedVoltagePartition,Cat.No.

981

COMPLIANCE

• LISTED,OutletBox,731A

792 793 794

981855, 859

CAT. # DESCRIPTION

CUBIC IN.

(CM3)

FITS CAT. # STD. PKG. BARCODE

3-Gang Raised Device Covers – For 263 Box

792 5/8"Raised 10.3(168.8) 263 10 —

793 3/4"Raised 12.7(208.1) 263 10 —

794 1-1/4"Raised 24.2(396.6) 263 5—

2-Gang Raised Device Cover – For 4-11/16" Box

855 5/8"Raised,ForLifeSafetyAppliances&

EmergencyExitSigns 8.3(136.0) 260and

911-15 25 —

859 1-1/4"Raised,ForLifeSafetyAppliances&

EmergencyExitSigns 16.0(262.0) 260and

911-15 12 —

Voltage Partition

981 For5/8",3/4",1-1/4"coversfor260and263

boxes —260and263 25 —

NEw!

NEw! NEw! NEw!

NEw!

NEw

NEw

NEw

NEw

NEw

NEw

steel boxes, covers and accessories

RACO BOXES, COVERS AND ACCESSORIES

A34

SEE End of SEction (PG A68) for dEtAilEd drAwinGS »

CEILING BOXES AND COVERS

CEILING FAN AND FIXTURE SUPPORT PRODUCTS

NEW!

NEW!

296-1,

296

299

295-1, 295 291-1

294-1, 294

applications

• RACO® Ceiling Support Boxes are specifically designed

for ceiling fan and ceiling or wall light fixture support

product features

• 1/2" side knockouts (294, 294-1, 296, 296-1 and 299)

• No protruding ground screw or fan mounting screws

allows easy installation

• #10-32, 1" long ceiling fan screws provided and

provision for #8-32 fixture mounting screw (291-1,

294-1, 294, 296-1, 296 and 299)

• Setback tab allows for easy box installation of different

wall thickness (294-1, 294)

• Metal protection plate eliminates debris or damage to

wiring

• Easy to follow instructions and mounting hardware

included

• Graduated markings for 1/2" to 1-1/4" thick sheetrock

(Cat. No. 291-1)

Gorilla rinG® concrete rinG application

• Concrete rings are used with poured deck (floor) in

high-rise construction

• GORILLARINGfeaturesmountingscrewsthatallow

for safe and secure mounting of any chandeliers, or

lighting fixtures 70 lbs. or less

• DoublerowofKO’sallowgreaterinstallationflexibility

with a minimum of bends or offsets for working

around reinforcing rods

compliance

• File E195978

U.S. Patents 7,148,420, 7,211,744

* Packaged in a stackable, individual chipboard display cartons. Sold in master carton quantities only.

Hubbell® RACO® does not break carton quantities on these items.

4714, THE INSIDER® will secure nonmetallic sheathed cable in 1/2" KO (See pg. B75).

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS

rEcommEndEd mAx. loAdS

Std.

PKG. bAr

codE

cAblE

PrioutS SidES

conduit bottom

conduit

cEilinG fAn

(dynAmic) lbS. fixturE

(StAtic) lbS.

4" Round Ceiling Fan Pan – Drawn with Conduit KO's

295-1 1/2" Depth 6.0 (98.3) INSIDER —(5) 1/2" 70 150 10 —

295* 1/2" Depth 6.0 (98.3) INSIDER —(5) 1/2" 70 150 10 IIIIIIII

4" Round Ceiling Box – Drawn with Conduit KO's

291-1 1-1/2" Depth 15.8 (258.9) INSIDER —(3) 1/2" 70 150 20 —

294-1 2-1/8" Depth, Old and New Work 22.3 (365.4) INSIDER (2) 1/2" (1) 1/2" 70 70/150** 10 —

294* 2-1/8" Depth, Old and New Work 22.3 (365.4) INSIDER (2) 1/2" (1) 1/2" 70 70/150** 10 IIIIIIII

296-1 1-1/2" Depth 15.8 (258.9) INSIDER (2) 1/2" (3) 1/2" 70 150 20 —

296* 1-1/2" Depth 15.8 (258.9) INSIDER (2) 1/2" (3) 1/2" 70 150 8IIIIIIII

299* 2-1/8" Depth 22.4 (367.1) INSIDER (2) 1/2" (3) 1/2" 70 150 6IIIIIIII

GORILLA-RING® – Concrete Ring for Ceiling Fan Support

284 4" Deep, Double Row Side Knockouts 49.3 (807.9) —(4) 3/4"

(6) 1/2" —35 70 6 —

GORILLA-RING® 284

NEW

NEW

Bracket

Design

(Now for Old or New Work)

** New work applications

rated at 150 lbs. Old work

applications rated at 70 lbs.

steel boxes, covers and accessories

www.Hubbell-RTB.com A35

CEILING BOXES AND COVERS

CEILING FAN AND FIXTURE SUPPORT PRODUCTS

937

926, 926-1

applications

• RACO® RETRO-BRACE® is intended for

installations of heavy lighting fixtures or

ceiling paddle fans in old work or new work

applications

• RACO® KWIK-BRACE® is a heavy-duty ceiling

fan brace designed for new or existing

construction where joists are accessible

features

• KWIK-BRACE®

= Slides apart to accomodate joist spacing

from 16" to 24", screws provided

= #10-32 ceiling fan screws provided and

#8-32 ceiling fixture mounting provisions

= Metal protection plate included

= Nail spurs for easy brace positioning

= Easy installation, up front ground screws

= Easy to follow instructions and mounting

hardware included

• RETRO-BRACE®

= Adjustable for joist spacing from 16" to 24"

= Simple “tool free” expansion of brace

= Easy installation, up front gound screw

= #10-32 ceiling fan screws provided and

#8-32 ceiling fixture mounting provisions

= Easy to follow instructions and mounting

hardware included

compliance

• File E195978

U.S. Patents 7,148,420, 6,595,479, 7,191,994

* Packaged in a stackable, individual chipboard display cartons. Sold in master carton quantities only. Hubbell® RACO® does not break carton quantities on these items.

4714, THE INSIDER® will secure nonmetallic sheathed cable in 1/2" KO (See pg. B75).

936

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS

rEcommEndEd mAx. loAdS

Std.

PKG. bAr

codE

cAblE

PrioutS SidES

conduit bottom

conduit

cEilinG fAn (dynAmic) lbS. fixturE (StAtic) lbS.

16" JoiSt SPAn 24" JoiSt SPAn 16" JoiSt SPAn 24" JoiSt SPAn

KWIK-BRACE® with Box – New Construction Braces for Lighting Fixtures or Ceiling Fans

926-1 1-1/2" Depth 15.8 (258.9) INSIDER — (3) 1/2" 70 70 210 90 12 IIIIIIII

926* 1-1/2" Depth 15.8 (258.9) INSIDER —(3) 1/2" 70 70 210 90 6 IIIIIIII

RETRO-BRACE® with Box – Remodeling Kits for Lighting Fixtures or Ceiling Fans

936* 1-1/2" Depth 15.8 (258.9) INSIDER — (3) 1/2" 70 35 110 50 6 IIIIIIII

937* 2-1/8" Depth 22.4 (367.1) INSIDER — (3) 1/2" 70 35 110 50 4 IIIIIIII

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A36

SEE END OF SECTION (PG A68) FOR DETAILED DRAWINGS »

CEILING BOXES AND COVERS

CEILING FAN AND FIXTURE SUPPORT PRODUCTS

CEILING PANS

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS

RECOMMENDED MAX. LOADS

STD.

PKG. BAR

CODE

CABLE

PRIOUTS SIDES

CONDUIT BOTTOM

CONDUIT

CEILING FAN

(DYNAMIC) LBS. FIXTURE

(STATIC) LBS.

3-1/2" Round Ceiling Pan – Drawn with Nonmetallic Sheathed Cable Clamps

292 1/2"Depth 4.0(65.5) 4—(1)1/2" No 50 50 —

8292 1/2"Depth 4.0(65.5) 4—(1)1/2" No 50 25 IIIIIIII

287 3/4"Depth 5.0(81.9) 4—(1)1/2" No 50 50 —

4" Round Ceiling Pan – Drawn with Conduit KO's

293 1/2"Depth 6.0(98.3) ——(5)1/2" No 50 50 —

8293 1/2"Depth 6.0(98.3) ——(5)1/2" No 50 50 IIIIIIII

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS

RECOMMENDED MAX. LOADS

STD.

PKG. BAR

CODE

SIDES BOTTOM CONDUIT

CEILING FAN

(DYNAMIC) LBS. FIXTURE

(STATIC) LBS.

GRID-BRACE™ For Suspended Ceilings, 2-1/8" Deep

931 CeilingFanSupportforSuspendedCeilings 22.3(365.4) (2)1/2" (2)Conc.1/2"&3/4" 70 70 4 IIIIIIII

APPLICATION

• GRID-BRACE™ceilingsupportassembly

isspecificallydesignedforceilingfanor

fixturesupportforsuspendedceilings

PRODUCT FEATURES

• Heavy-dutyGRID-BRACE™for24"spans

• Turnbuckleand4’chainsectionprovided

• Yokeprovidedforthreadedrodinstallation

• Mountboxanywhereonslidingbracket

• Spacersprovidedfordecorativeceiling

tilesthatarebelowthedepthofmetal

gridforflushmountingofbox➔

• #10-32grade5,1"ceilingfanscrews

included

• Easytofollowinstructionsincluded

931

COMPLIANCE

• FileE195978

U.S.Patents7,148,420,U.S.PatentPending

APPLICATION

• RACO® CeilingPansareusedinthe

installationofceilingorwalllighting

fixtures

PRODUCT FEATURES

• Combinationscrewheadsprovidefor

fasterinstallation

COMPLIANCE

• FileE195978

U.S.Patent7,148,420,4,892,211

Canada1,324,360Mexico166,125

292, 8292 293, 8293

287

NEw!

NEw

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A37

SEE END OF SECTION (PG A69) FOR DETAILED DRAWINGS »

3-1/2" OCTAGON BOXES – DRAWN

119

112

111

110

APPLICATIONS

• RACO® OctagonBoxesareusedinthe

installationofceilingorwalllightingfixtures

• Extensionringsprovideameansforadding

additionalcubiccapacityorasanoutletbox

forsurfaceconduit

PRODUCT FEATURES

• Combinationscrewheadsprovideforfaster

installation

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

COMPLIANCE

• FileE195978

APPLICATIONS

• RACO® OctagonBoxesareusedinthe

installationofceilingorwalllightingfixtures

PRODUCT FEATURES

• Combinationscrewheadsprovideforfaster

installation

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

COMPLIANCE

• FileE195978

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS

RECOMMENDED MAX. LOADS

STD.

PKG. BAR

CODE

CABLE

PRIOUTS SIDES

CONDUIT BOTTOM

CONDUIT

CEILING FAN

(DYNAMIC) LBS. FIXTURE

(STATIC) LBS.

3-1/2" Octagon Box, 1-1/2" Deep – Drawn with Conduit KO's

110 —11.8(193.4) —(4)1/2" (1)1/2" No 50 25 IIIIIIII

3-1/2" Octagon Extension Ring, 1-1/2" Deep – Drawn with Conduit KO's

111 —11.8(193.4) —(4)1/2" —No —25 IIIIIIII

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS

RECOMMENDED MAX. LOADS

STD.

PKG. BAR

CODE

CABLE

PRIOUTS SIDES

CONDUIT BOTTOM

CONDUIT

CEILING FAN

(DYNAMIC) LBS. FIXTURE

(STATIC) LBS.

3-1/2" Octagon Box, 1-1/2" Deep – Drawn with Nonmetallic Sheathed Cable Clamps

112 —11.8(193.4) 4 (2)1/2" (1)1/2" No 50 25 IIIIIIII

119 TSBracket,1/2" 11.8(193.4) 4 (1)1/2" (1)1/2" No 50 25 IIIIIIII

CEILING BOXES AND COVERS

CEILING BOXES AND COVERS

steel boxes, covers and accessories

RACo BoxeS, CoveRS And ACCeSSoRieS

A38

SEE End of SEction (PG A69) for dEtAilEd drAwinGS »

4" oCTAgon BoxeS And exTenSion RingS – dRAWn WiTH ConduiT Ko'S

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS

rEcommEndEd mAx. loAdS

Std.

PKG. bAr

codE

SidES

conduit bottom

conduit

cEilinG fAn

(dynAmic) lbS. fixturE

(StAtic) lbS.

4" Octagon Box, 1-1/2" Deep – Drawn with Conduit KO's

125 — 15.5 (254.0) (4) 1/2" (5) 1/2" No 50 50 —

8125 Raised Ground 15.5 (254.0) (4) 1/2" (4) 1/2" No 50 50 IIIIIIII

126 Raised Ground 15.5 (254.0) (4) 3/4" (2) 1/2", (2) 3/4" No 50 50 IIIIIIII

127 Raised Ground 15.5 (254.0) (2) 1/2", (2) 3/4" (2) 1/2", (2) 3/4" No 50 25 IIIIIIII

127tS Raised Ground, TS Bracket, 1/2" Setback 15.5 (254.0) (1) 1/2", (2) 3/4" (2) 1/2", (2) 3/4" No 50 25 IIIIIIII

158 J Bracket, 3/8" or 1/2" Setback 15.5 (254.0) (4) 1/2" (5) 1/2" No 50 50 IIIIIIII

161 TS Bracket, 1/2" Setback 15.5 (254.0) (3) 1/2" (5) 1/2" No 50 25 IIIIIIII

161SP TS Bracket, 1/2" Setback 15.5 (254.0) (3) 1/2" (5) 1/2" No 50 12 IIIIIIII

324 Raised Ground, Box with 14-1/4" to 22-1/2" Bar

Hanger 15.5 (254.0) (4) 1/2" (3) 1/2" No 10* 25 IIIIIIII

4" Octagon Extension Rings, 1-1/2" Deep – Drawn with Conduit KO's

128 — 15.5 (254.0) (4) 1/2" — No 50 25 IIIIIIII

130 — 15.5 (254.0) (2) 1/2", (2) 3/4" — No 50 25 IIIIIIII

131rAc — 15.5 (254.0) (4) 3/4" — No 50 25 IIIIIIII

* 10 lbs max. load recommended. UL Rated for 50 lbs on 16" centers.

applications

• RACO® Octagon Boxes are used in the

installation of ceiling or wall lighting

fixtures

• Extension rings provide a means for adding

additional cubic capacity or as an outlet box

for surface conduit

product features

• Combination screw heads provide for

faster installation

• Reference the Box Selection section in the

front of this catalog for complete description

of bracket types and features

• Fixture bar hanger allows box to be located

anywhere along length of bar

compliance

• File E195978

• File LR-1082 (128, 130, 131RAC)

158

127

126

8125

125

324

131RAC

128

127TS

130

161, 161SP

CeiliNg BoxeS aNd CoverS

New

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A39

SEE END OF SECTION (PG A69) FOR DETAILED DRAWINGS »

4" OCTAGON DEEP BOXES – DRAWN WITH CONDUIT KO'S

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS

RECOMMENDED MAX. LOADS

STD.

PKG. BAR

CODE

SIDES

CONDUIT BOTTOM

CONDUIT

CEILING FAN

(DYNAMIC) LBS. FIXTURE

(STATIC) LBS.

4" Octagon Box, 2-1/8" Deep – Drawn with Conduit KO's

165 —21.5(352.3) (4)1/2" (5)1/2" No 50 50 IIIIIIII

166 —21.5(352.3) (4)3/4" (3)1/2",(2)3/4" No 50 50 —

167 —21.5(352.3) (2)1/2",(2)3/4" (3)1/2",(2)3/4" No 50 25 —

167TS TSBracket,1/2"Setback 21.5(352.3) (1)1/2",(2)3/4" (3)1/2",(2)3/4" No 50 25 —

165

APPLICATIONS

• RACO® OctagonBoxesareusedinthe

installationofceilingorwalllightingfixtures

• Combinationscrewheadsprovidefor

fasterinstallation

COMPLIANCE

• FileE195978

167

166

167TS

CEILING BOXES AND COVERS

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A40

SEE END OF SECTION (PG A69) FOR DETAILED DRAWINGS »

4" OCTAGON BOXES – DRAWN WITH ARMORED CABLE / METAL CLAD / FLEX CLAMPS

* 10 lbs max. load recommended. UL Rated for 50 lbs on 16" centers.

APPLICATIONS

• RACO® OctagonBoxesareusedinthe

installationofceilingorwalllighting

fixtures

PRODUCT FEATURES

• RACO® offersavarietyoflaborsaving

mountingbracketsthatallowforeasy

positioningofboxalongstudsorjoists

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

• Fixturebarhangerallowsboxtobelocated

anywherealonglengthofbar

COMPLIANCE

• FileE195978

325, 8325

157

155

153

CEILING BOXES AND COVERS

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS

RECOMMENDED MAX. LOADS

STD.

PKG. BAR

CODE

CABLE

PRIOUTS SIDES

CONDUIT BOTTOM

CONDUIT

CEILING FAN

(DYNAMIC) LBS. FIXTURE

(STATIC) LBS.

4" Octagon Box, 1-1/2" Deep – Drawn with Armored Cable/Metal Clad/Flex Clamps

153 —15.5(254.0) 4 (2)1/2" (1)1/2" No 50 25 IIIIIIII

155 TSBracket,1/2"Setback 15.5(254.0) 4 (1)1/2" (1)1/2" No 50 50 IIIIIIII

157 JBracket,3/8"or1/2"Setback 15.5(254.0) 4 (2)1/2" (1)1/2" No 50 50 IIIIIIII

325 Boxwith14-1/4"to22-1/2"barhanger 15.5(254.0) 4 (2)1/2" —No 10* 25 —

8325 Boxwith14-1/4"to22-1/2"barhanger 15.5(254.0) 4 (2)1/2" —No 10* 25 IIIIIIII

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A41

SEE END OF SECTION (PG A69) FOR DETAILED DRAWINGS »

4" OCTAGON BOXES – DRAWN WITH NONMETALLIC SHEATHED CABLE CLAMPS

APPLICATIONS

• RACO® OctagonBoxesareusedinthe

installationofceilingorwalllightingfixtures

PRODUCT FEATURES

• RACO® offersavarietyoflaborsaving

mountingbracketsthatallowforeasy

positioningofboxalongstudsorjoists

• ReferencetheBoxSelectionsectionin

thefrontofthiscatalogforcomplete

descriptionofbrackettypesandfeatures

• Fixturebarhangerallowsboxtobelocated

anywherealonglengthofbar

• Combinationscrewheadsprovidefor

fasterinstallation

COMPLIANCE

• FileE195978

146

160

164

326, 8326

145

150

CEILING BOXES AND COVERS

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS

RECOMMENDED MAX. LOADS

STD.

PKG. BAR

CODE

CABLE

PRIOUTS SIDES

CONDUIT BOTTOM

CONDUIT

CEILING FAN

(DYNAMIC) LBS. FIXTURE

(STATIC) LBS.

4" Octagon Box, 1-1/2" Deep – Drawn with Nonmetallic Sheathed Cable Clamps

146 —15.5(254.0) 4 (2)1/2" (1)1/2" No 50 25 IIIIIIII

145 Sideholes,1/8"and1/4" 15.5(254.0) 4 (2)1/2" (1)1/2" No 50 50 —

150 PlasterEars 15.5(254.0) 4 (2)1/2" (1)1/2" No 50 25 IIIIIIII

160 JBracket,3/8"or1/2"Setback 15.5(254.0) 4 (2)1/2" (1)1/2" No 50 25 IIIIIII

164 TSBracket,1/2"Setback 15.5(254.0) 4 (1)1/2" (1)1/2" No 50 25 IIIIIIII

326 Boxwith14-1/4"to22-1/2"barhanger 15.5(254.0) 4 (2)1/2" —No 10* 25 —

8326 Boxwith14-1/4"to22-1/2"barhanger 15.5(254.0) 4 (2)1/2" —No 10* 25 IIIIIIII

4" Octagon Box, 2-1/8" Deep – Drawn with Nonmetallic Sheathed Cable Clamps

175 —21.5(352.3) 4 (2)1/2" (1)1/2" No 50 25 IIIIIIII

176 JBracket,5/8"Setback 21.5(352.3) 4 (2)1/2" (1)1/2" No 50 25 IIIIIIII

177 TSBracket,1/2"Setback 21.5(352.3) 4 (1)1/2" (1)1/2" No 50 25 —

* 10 lbs max. load recommended. UL Rated for 50 lbs on 16" centers.

177

176

175

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A42

ROUND COVERS FOR 3-1/2" AND 4" OCTAGON BOXES

CEILING BOXES AND COVERS

APPLICATION

• Coversareusedtocloseanoutletbox

• Raisedcoversareusedformounting

lightingfixtures

PRODUCT FEATURES

• Combinationscrewheadsprovideforfaster

installation

• Swivelcoverrestrictedto20°swingfrom

vertical

• KWIK-HANG®allowseasyinstallationof

highbaylightingfixtures.Fixturerestsin

positionwhilewiringiscompleted

COMPLIANCE

• FileE195978

• FileLR-1082(722,729,731)

U.S.Patent7,148,420,7,211,744

PatentPending(894KH)

703, 8703-5

*5 Bundles of 10 – sold in carton quantities only

894KH

895

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

RECOMMENDED MAX. LOADS

STD.

PKG. BAR

CODE

CEILING FAN

(DYNAMIC) LBS. FIXTURE

(STATIC) LBS.

3-1/2" Round Cover

703 Flat,1/2"KOInCenter —No —25 IIIIIIII

8703-5* Flat,1/2"KOInCenter —No —50 IIIIIIII

3-1/2" or 4" Swivel Fixture, Support Covers

895 For3-1/2"or4"OctagonBoxes,1/2"

or3/4"Conduit —No 50 25 IIIIIIII

894KH Kwik-Hang®,For3-1/2"or4"

OctagonBoxes,1/2"or3/4"Conduit —No 50 25 IIIIIIII

4" Round Raised Cover

737 Raised1/2",Open,Ears2-3/4"O.C. 3.3(54.1) No 50 25 IIIIIIII

727 Raised5/8",Open,Ears2-3/4"O.C. 3.8(62.2) No 50 25 IIIIIIII

732 Raised1",Open,Ears2-3/4"O.C. 6.5(106.5) No 50 25 —

NEw!

NEw

727, 732, 737

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A43

SEE END OF BELL SECTION (PG D36) FOR 5653-1 DETAILED DRAWINGS »

OCTAGON AND ROUND COVERS

CEILING BOXES AND COVERS

APPLICATIONS

• Coversareusedtocloseanoutletbox

• Switchesorreceptaclesmaybeinstalled

intooctagonboxesbyusingcovers729or

731

PRODUCT FEATURES

• 5"roundcoversfeaturestate-of-the-art

powdercoatpaintfinishwhichprovidesa

lighttexturefinishandscratchresistance

COMPLIANCE

• FileE195978

• FileLR-1082(722,729,731)

722, 8722-5 729

724, 8724-5 731, 8731-5

5652-1 5654-1

5653-1

*5 Bundles of 10 – sold in carton quantities only

CATALOG # DESCRIPTION PKG. TYPE STD. PKG. BARCODE

4" Octagon and Round Covers

722 Flat,blank —50 IIIIIIII

8722-5* Flat,blank —50 IIIIIIII

724 Flat,1/2"KO —50 IIIIIIII

8724-5* Flat,1/2"KO —50 IIIIIIII

729 Flat,toggleswitch —50 IIIIIIII

731 Flat,duplexreceptacle —25 IIIIIIII

8731-5* Flat,duplexreceptacle —50 IIIIIIII

5" Round Steel Closure Plates

5652-1 Off-white,screwanduniversalmountstrap Shrink 10 —

5653-1 Off-white,(2)8-32screws,directmounttofixture

outlet box Shrink 10 —

5654-1 Off-white,fixturestudanduniversalmountstrap Shrink 10 —

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A44

SEE END OF SECTION (PG A70) FOR DETAILED DRAWINGS »

SINGLE DEVICE HANDY BOXES AND EXTENSION RINGS

663, 8663

APPLICATIONS

• RACO® Handyboxes,alsocalledutility

boxes,areusedforconvenienceoutlets,

switchboxesorsmalljunctionboxes

• Theyarepopularforexposedwork

applications(surfacemountedwiring)

• TheNECrequiresthatsurface-mounted

wiringbeenclosedwithaprotective

coveringsuchasEMTconduit

PRODUCT FEATURES

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

COMPLIANCES

• FileE195978

• FileLR-1082(611and650CSAonly)

• All RACO®HandyBox,U.L.listedsteel

boxesareacceptableforusein2-hourfire

ratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteatwww.ul.com

655

650, 8650,

650CSA

663SM

660, 8660

611 661, 661SP

662, 662SP

660SM

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT ENDS

CONDUIT BOTTOM

CONDUIT

4" x 2" Handy Boxes, 1-1/2" Deep – Welded with Conduit KO’s

650 —11.5(188.5) (6)1/2" (2)1/2" (3)1/2" 50 —

8650 —11.5(188.5) (6)1/2" (2)1/2" (3)1/2" 25 IIIIIIII

650CSA WithGroundScrewDriven 11.5(188.5) (6)1/2" (2)1/2" (3)1/2" 50 —

655 BBracket,1/4"Setback 11.5(188.5) (3)1/2" (2)1/2" (3)1/2" 50 —

4" x 2" Handy Box Extension Rings, 1-1/2" Deep – Welded with Conduit KO’s

653 —11.5(188.5) (6)1/2" (2)1/2" —25 IIIIIIII

4" x 2" Handy Boxes, 1-7/8" Deep – Drawn with Conduit KO’s

660 RaisedGround 13.0(213.0) (6)1/2" (2)1/2" (2)1/2" 50 —

8660 RaisedGround 13.0(213.0) (6)1/2" (2)1/2" (2)1/2" 50 IIIIIIII

611 RaisedGround,WithGroundScrew

Driven 13.0(213.0) (6)1/2" (2)1/2" (2)1/2" 50 —

660SM 10"#12StrandedCopperPigtail,

RaisedGround 13.0(213.0) (6)1/2" (2)1/2" (2)1/2" 50 IIIIIIII

661 RaisedGround,ABracket,5/8"

Setback 13.0(213.0) (3)1/2" (2)1/2" (3)1/2" 25 IIIIIIII

661SP RaisedGround,ABracket,5/8"

Setback 13.0(213.0) (3)1/2" (2)1/2" (3)1/2" 18 IIIIIIII

662 RaisedGround,TSBracket,1/2"

Setback 13.0(213.0) (3)1/2" (2)1/2" (3)1/2" 25 IIIIIIII

662SP RaisedGround,TSBracket,1/2"

Setback 13.0(213.0) (3)1/2" (2)1/2" (3)1/2" 18 IIIIIIII

663 RaisedGround 13.0(213.0) (4)3/4" (2)3/4" (1)3/4" 50 —

8663 RaisedGround,1-7/8"Depth

(inside), 13.0(213.0) (4)3/4" (2)3/4" (1)3/4" 25 IIIIIIII

663SM 10"#12StrandedCopperPigtail,

RaisedGround 13.0(213.0) (4)3/4" (2)3/4" (1)3/4" 50 IIIIIIII

666 RaisedGround 13.0(213.0) (6)1/2" (1)1/2"

(1)3/4" —50 —

4" x 2" Handy Box Extension Rings, 1-7/8" Deep – Drawn with Conduit KO’s

665 —13.0(213.0) (6)1/2" (2)1/2" —25 IIIIIIII

HANDy BOXES

653

665666

NEw

NEw

NEw

NEw!

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A45

SEE END OF SECTION (PG A70) FOR DETAILED DRAWINGS »

SINGLE DEVICE HANDY BOXES AND COVERS

APPLICATIONS

• RACO® Handyboxes,alsocalledutility

boxes,areusedforconvenienceoutlets,

switchboxesorsmalljunctionboxes

• Theyarepopularforexposedwork

applications(surfacemountedwiring)

• TheNECrequiresthatsurface-mounted

wiringbeenclosedwithaprotective

coveringsuchasEMTconduit

• RACO® HandyBoxcoversareusedtoclosea

HandyBox

• Coversalsomaybeusedassinglegangwall

plates

PRODUCT FATURES

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

• RACO®HandyBoxcoversaredesignedto

matchthecontoursofthebox

• Covercornersarerounded

• Allcovershavecaptivescrews

COMPLIANCE

• FileE195978

• FileLR-1082(Coversonly)

860 862

861 865 864 867863

640 880

670RAC, 8670 674 678 671

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT ENDS

CONDUIT BOTTOM

CONDUIT

4" x 2" Handy Boxes, 2-1/8" Deep – Welded with Conduit KO’s

670RAC — 16.5(270.4) (6)1/2" (2)1/2" (3)1/2" 50 —

8670 —16.5(270.4) (6)1/2" (2)1/2" (3)1/2" 25 IIIIIIII

674 —16.5(270.4) (4)3/4" (2)3/4" (2)3/4" 50 IIIIIIII

678 TSBracket,1/2"Setback 16.5(270.4) (3)1/2" (2)1/2" (3)1/2" 25 IIIIIIII

671 ABracket,5/8"Setback 16.5(270.4) (3)1/2" (2)1/2" (3)1/2" 50 IIIIIIII

3-3/4" x 1-9/16" Industrial Handy Box and Cover – Drawn with Conduit KO’s

640 1-1/2"Depth 7.3(119.6) (6)1/2" (2)1/2" (3)1/2" 50 —

880 BlankCoverwithCaptiveScrews — — — — 50 —

HANDy BOXES

CATALOG # DESCRIPTION STD. PKG. BARCODE

4" x 2" Handy Box Covers – 2-5/16" Wide x 4-3/16" Length

860 Blank 25 IIIIIIII

861 1/2"KO,Centered 25 IIIIIIII

862 GFCI 25 IIIIIIII

865 ToggleSwitch 25 IIIIIIII

864 DuplexReceptacle 25 IIIIIIII

863 SingleReceptacle,1.406"Dia. 25 IIIIIIII

867 20AReceptacle,1.594"Dia. 25 IIIIIIII

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A46

SEE END OF SECTION (PG A70) FOR DETAILED DRAWINGS »

TWO DEVICE HANDY / SWITCH BOXES AND COVERS

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT BOTTOM

CONDUIT

4" Square Two Device Switch Boxes, 2-1/8" Deep – Drawn with Conduit KO’s

680 —30.3(496.5) (12)1/2" (5)1/2" 25 IIIIIIII

683 —30.3(496.5) (8)1/2",(4)3/4" (3)1/2",(2)3/4" 25 IIIIIIII

683SP —30.3(496.5) (8)1/2",(4)3/4" (3)1/2",(2)3/4" 10 IIIIIIII

681 TSBracket,1/2"Setback 30.3(496.5) (9)1/2" (5)1/2" 25 IIIIIIII

681SP TSBracket,1/2"Setback 30.3(496.5) (9)1/2" (5)1/2" 8 IIIIIIII

685 TSBracket,1/2"Setback 30.3(496.5) (6)3/4" (3)1/2",(2)3/4" 25 IIIIIIII

685SP TSBracket,1/2"Setback 30.3(496.5) (6)3/4" (3)1/2",(2)3/4" 8 IIIIIIII

4" Square – Two Device Wall Plates

871 2ToggleSwitches,

1/4"RaisedfromSurface — — — 25 IIIIIIII

872 1Duplexand1ToggleSwitch,

1/4"RaisedfromSurface — — — 25 IIIIIIII

873 2DuplexReceptacles,

1/4"RaisedfromSurface — — — 25 IIIIIIII

APPLICATIONS

• Installerscansavetimeandcutinstallation

costswithtwogangswitchboxes

• Largercapacityboxesareidealfortodays

designswherethereisaneedtoinstalltwo

devicesatonelocation

• Drawnboxesareidealforexposedwork

applications(surfacemountedwiring)

PRODUCT FEATURES

• 681,685bracketedboxesaresetback1/2"

eliminatingtheneedforaplasterring

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbracketandclamptypesandfeatures

• 871,872and873coversareunpaintedand

manufacturedfrompre-galvanizedsteel

COMPLIANCES

• FileE195978

• All RACO®singlegang,twogang,4"

square,andsingleganggangableU.L.listed

steelboxesareacceptableforusein2-hour

fireratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteatwww.ul.com

683, 683SP

681, 681SP

680

685, 685SP

873

872

871

NEw

NEw

NEw

HANDy BOXES

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A47

SEE END OF SECTION (PG A70) FOR DETAILED DRAWINGS »

3" x 2" SWITCH BOXES – WITH CONDUIT KO'S

420400

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT ENDS

CABLE ENDS

CONDUIT BOTTOM

CONDUIT

1-1/2" Deep Switch Box – Gangable with Conduit KO’s

400 PlasterEars 7.5(122.9) — — (2)1/2" (1)1/2" 20 IIIIIIII

2" Deep Switch Box – Gangable with Conduit KO’s

420 PlasterEars 10.0(163.9) (4)1/2" — (2)1/2" (2)1/2" 25 IIIIIIII

2-1/2" Deep Switch Box – Gangable with Conduit KO’s

500 PlasterEars 12.5(204.8) (4)1/2" — (2)1/2" (2)1/2" 50 —

8500 PlasterEars 12.5(204.8) (4)1/2" — (2)1/2" (2)1/2" 25 IIIIIIII

501 NoPlasterEars 12.5(204.8) (4)1/2" — (2)1/2" (2)1/2" 50 —

503 PlasterEars 12.5(204.8) (4)1/2" — (2)3/4" (2)1/2" 50 —

502 BBracket,5/8"Setback 12.5(204.8) (4)1/2" — (2)1/2" (2)1/2" 10 IIIIIIII

504 TSBracket,1/2"Setback 12.5(204.8) (2)1/2" — (2)1/2" (2)1/2" 50 —

8504 TSBracket,1/2"Setback 12.5(204.8) (2)1/2" — (2)1/2" (2)1/2" 20 IIIIIIII

505 TSBracket,1/2"Setback 12.5(204.8) (2)1/2" — (2)3/4" (2)1/2" 50 —

506 OldWorkTIGERGRIP®,PlasterEars 12.5(204.8) — — (2)1/2" (2)1/2" 20 IIIIIIII

509 OldWork,PlasterEars 12.5(204.8) — — (2)1/2" (2)1/2" 20 IIIIIIII

508 OldWork,3/4"SheetRockMax.,PlasterEars 12.5(204.8) — — (2)1/2" — 20 IIIIIIII

SwITCH BOXES

502

501

500, 8500

503 504, 8504

505 506 508

509

APPLICATIONS

• RACO® Switchboxesareusedtohousewiring

devicessuchasswitchesoroutlets

PRODUCT FEATURES

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

• Gangableswitchboxesoffertheoptionof

constructingaboxtoholdtwoormoredevices

• Plasterearsallowboxtobeusedin“oldwork”

applications

COMPLIANCES

• FileE195978

• All RACO®singlegang,twogang,4"

square,andsingleganggangableU.L.listed

steelboxesareacceptableforusein2-hour

fireratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteatwww.ul.com

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A48

SEE END OF SECTION (PG A70) FOR DETAILED DRAWINGS »

3" x 2" SWITCH BOXES – WITH CONDUIT KO'S

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT ENDS

CABLE ENDS

CONDUIT BOTTOM

CONDUIT

2-3/4" Deep Switch Box – Gangable with Conduit KO’s

560 PlasterEars 14.0(229.4) (4)1/2" — (2)1/2" (2)1/2" 25 IIIIIIII

565 PlasterEars 14.0(229.4) (4)3/4" — (2)3/4" (2)1/2" 50 —

561 NoPlasterEars 14.0(229.4) (4)1/2" — (2)1/2" (2)1/2" 50 —

562 TSBracket,1/2"Setback 14.0(229.4) (2)1/2" — (2)1/2" (2)1/2" 50 —

3-1/2" Deep Switch Box – Gangable with Conduit KO’s

590 PlasterEars 18.0(295.0) (4)1/2" — (4)1/2" (1)1/2" 50 —

8590 PlasterEars 18.0(295.0) (4)1/2" — (4)1/2" (1)1/2" 25 IIIIIIII

591 PlasterEars 18.0(295.0) (4)3/4" — (4)3/4" (1)1/2" 50 IIIIIIII

592 NoPlasterEars 18.0(295.0) (4)1/2" — (4)1/2" (1)1/2" 50 —

APPLICATIONS

• RACO® Switchboxesareusedtohousewiring

devicessuchasswitchesoroutlets

PRODUCT FEATURES

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

• Gangableswitchboxesoffertheoptionof

constructingaboxtoholdtwoormoredevices

• Plasterearsallowboxtobeusedin“oldwork”

applications

COMPLIANCES

• FileE195978

• All RACO®singlegang,twogang,4"

square,andsingleganggangableU.L.listed

steelboxesareacceptableforusein2-hour

fireratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteatwww.ul.com

SwITCH BOXES

560 561

562

565

590, 8590 591 592

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A49

SEE END OF SECTION (PG A71) FOR DETAILED DRAWINGS »

3" x 2" SWITCH BOXES – WITH ARMORED CABLE / METAL CLAD / FLEX CLAMPS

APPLICATIONS

• RACO® Switchboxesareusedtohousewiring

devicessuchasswitchesoroutlets

PRODUCT FEATURES

• Gangableswitchboxesoffertheoptionof

constructingaboxtoholdtwoormoredevices

• Plasterearsallowboxtobeusedin“oldwork"

applications

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofclamptypesandfeatures

COMPLIANCES

• FileE195978

• All RACO®singlegang,twogang,4"

square,andsingleganggangableU.L.listed

steelboxesareacceptableforusein2-hour

fireratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteatwww.ul.com

440

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT ENDS

CABLE ENDS

CONDUIT BOTTOM

CONDUIT

2" Deep Switch Box – Gangable with Armored Cable/Metal Clad/Flex Clamps

440 PlasterEars 10.0(163.9) — 4—(1)1/2" 50 —

2-1/2" Deep Switch Box – Gangable with Armored Cable/Metal Clad/Flex Clamps

518 PlasterEars 12.5(204.8) — 4—(1)1/2" 25 IIIIIIII

524 TSBracket,1/2"Setback 12.5(204.8) — 4 (2)1/2" (1)1/2" 50 —

8524 TSBracket,1/2"Setback 12.5(204.8) — 4 (2)1/2" (1)1/2" 50 IIIIIIII

522 LBBracket,5/8"Setback 12.5(204.8) — 4 (2)1/2" (1)1/2" 25 IIIIIIII

523 PlasterEars,OldWork,GRIPTITE®12.5(204.8) — 4—(1)1/2" 25 IIIIIIII

526 PlasterEars,OldWork,3/4"SheetRockMax. 12.5(204.8) — 4— — 20 IIIIIIII

2-3/4" Deep Switch Box – Gangable with Armored Cable/Metal Clad/Flex Clamps

570RAC 2-3/4"Depth,PlasterEars 14.0(229.4) (4)1/2" 4 (2)1/2" (1)1/2" 50 —

574 2-3/4"Depth,TSBracket,1/2"Setback 14.0(229.4) (2)1/2" 4 (2)1/2" (1)1/2" 25 IIIIIIII

3-1/2" Deep Switch Box – Gangable with Armored Cable/Metal Clad/Flex Clamps

600 PlasterEars 18.0(295.0) (4)1/2" 4 (2)1/2" (1)1/2" 25 —

604 TSBracket,1/2"Setback 18.0(295.0) (4)1/2" 4 (2)1/2" (1)1/2" 25 IIIIIIII

SwITCH BOXES

523

522

518

524,

8524 526 570RAC

574 604

600

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A50

SEE END OF SECTION (PG A71) FOR DETAILED DRAWINGS »

3" X 2" SWITCH BOXES – WITH NONMETALLIC SHEATHED CABLE CLAMPS

596

545

528

519

517 512

531

540

529

410 445 471 473 487

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT ENDS

CABLE ENDS

CONDUIT BOTTOM

CONDUIT

1-1/2" Deep Switch Box – Gangable with Nonmetallic Sheathed Cable Clamps

410 PlasterEars 7.5(122.9) — 4— — 25 IIIIIIII

2" Deep Switch Box – Gangable with Nonmetallic Sheathed Cable Clamps

445 PlasterEars 10.0(163.9) — 4—(1)1/2" 50 —

2-1/4" Deep Switch Box – Gangable with Nonmetallic Sheathed Cable Clamps

471 OneScrew,PlasterEars 10.5(172.1) — 4—(1)1/2" 25 IIIIIIII

473 LevelBumps 10.5(172.1) — 4 (2)1/2" (1)1/2" 20 IIIIIIII

487 OldWork,TIGERGRIP®10.5(172.1) — 4— (1)1/2" 20 IIIIIIII

2-1/2" Deep Switch Box – Gangable with Nonmetallic Sheathed Cable Clamps

519 PlasterEars 12.5(204.8) — 4—(1)1/2" 25 IIIIIIII

528 LevelBumps 12.5(204.8) — 4 (2)1/2" (1)1/2" 25 IIIIIIII

529 LBBracket,5/8"Setback 12.5(204.8) — 4 (2)1/2" (1)1/2" 20 IIIIIIII

596 NoPlasterEars 12.5(204.8) — 4 (2)1/2" — 50 —

545 PlasterEars,OldWork,3/4"SheetRockMax. 12.5(204.8) — 4 (2)1/2" —20 IIIIIIII

531 TSBracket,1/2"Setback 12.5(204.8) — 4 (2)1/2" (1)1/2" 25 IIIIIIII

540 BBracket,1/4"Setback 12.5(204.8) — 4 (2)1/2" (1)1/2" 50 —

517 PlasterEars,OldWork,TIGERGRIP 12.5(204.8) — 4—(1)1/2" 20 IIIIIIII

512 PlasterEars,OldWork 12.5(204.8) — 4—(1)1/2" 20 IIIIIIII

APPLICATIONS

• RACO® Switchboxesareusedtohousewiring

devicessuchasswitchesoroutlets

PRODUCT FEATURES

• Beveledcornerboxesaredesignedto

preventtheclampscrewsfromprotruding

intobackwall

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

• Gangableswitchboxesoffertheoptionof

constructingaboxtoholdtwoormoredevices

• Plasterearsallowboxtobeusedin“oldwork”

applications

COMPLIANCES

• FileE195978

• All RACO®singlegang,twogang,4"

square,andsingleganggangableU.L.listed

steelboxesareacceptableforusein2-hour

fireratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteat

www.ul.com

SwITCH BOXES

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A51

SEE END OF SECTION (PG A71) FOR DETAILED DRAWINGS »

3" X 2" SWITCH BOXES – WITH NONMETALLIC SHEATHED CABLE CLAMPS

564 567

355, 8355

603

601, 8601

605

601G

APPLICATIONS

• RACO® Switchboxesareusedtohousewiring

devicessuchasswitchesoroutlets

PRODUCT FEATURES

• RACO®355and8355areextrawidefor

easeofGFCIinstallation

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

• Gangableswitchboxesoffertheoptionof

constructingaboxtoholdtwoormoredevices

• Plasterearsallowboxtobeusedin“oldwork”

applications

COMPLIANCES

• FileE195978

• FileLR-1082(601GCSAonly)

• All RACO®singlegang,twogang,4"

square,andsingleganggangableU.L.listed

steelboxesareacceptableforusein2-hour

fireratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteatwww.ul.com

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT ENDS

CABLE ENDS

CONDUIT BOTTOM

CONDUIT

2-3/4" Deep Switch Box – Gangable with Nonmetallic Sheathed Cable Clamps

567 PlasterEars 14.0(229.4) (4)1/2" 4 (2)1/2" (1)1/2" 25 IIIIIIII

564 TSBracket,1/2"Setback 14.0(229.4) (2)1/2" 4 (2)1/2" (1)1/2" 25 IIIIIIII

2-27/32" Deep Switch Box – Gangable with Nonmetallic Sheathed Cable Clamps

355 SBracket,Nails 15.8(258.9) — 4—(1)1/2" 50 —

8355 SBracket,Nails 15.8(258.9) — 4—(1)1/2" 20 IIIIIIII

3-1/2" Deep Switch Box – Gangable with Nonmetallic Sheathed Cable Clamps

601 PlasterEars 18.0(295.0) (4)1/2" 4 (2)1/2" (1)1/2" 25 —

8601 PlasterEars 18.0(295.0) (4)1/2" 4 (2)1/2" (1)1/2" 25 IIIIIIII

601G PlasterEars,WithGroundScrewDriven 18.0(295.0) (4)1/2" 4 (2)1/2" (1)1/2" 25 —

605 TSBracket,1/2"Setback 18.0(295.0) (4)1/2" 4 (2)1/2" (1)1/2" 25 IIIIIIII

603 BBracket,5/8"Setback 18.0(295.0) (4)1/2" 4 (2)1/2" (1)1/2" 25 —

SwITCH BOXES

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A52

SHALLOW SWITCH BOXES – WITH NONMETALLIC SHEATHED CABLE CLAMPS

APPLICATIONS

• RACO® Shallowswitchboxesaremadeforuse

withfurringstripsand1/4"paneling

• Switchboxesareusedtohousewiringdevices

suchasswitchesoroutlets

PRODUCT FEATURES

• RACO® “D”bracketispre-scoredandcanbe

brokienoffifneeded

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbrackettypesandfeatures

• 418willaccept4"squaremudringorflat

cover

COMPLIANCES

• FileE195978

(Cat.#404,#404SPand#405notULlisted)

• All RACO®singlegang,twogang,4"

square,andsingleganggangableU.L.listed

steelboxesareacceptableforusein2-hour

fireratedwalls.Foradditionalinformation,

consultU.L.“FireResistanceDirectory”or

theU.L.websiteatwww.ul.com

418

405

404, 404SP

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT ENDS

CABLE ENDS

CONDUIT BOTTOM

CONDUIT

3-3/4" x 2" Switch Boxes, 1" Deep – Nongangable with Nonmetallic Sheathed Cable Clamps

404 QClamp,1/4"Setback 6.5(106.5) —2 (1)1/2" —25 IIIIIIII

404SP QClamp,1/4"Setback 6.5(106.5) —2 (1)1/2" —6 IIIIIIII

405 QClamp,1/4"Setback 6.5(106.5) —4— — 25 IIIIIIII

4" x 4" Switch Box, 1" Deep – Nongangable with Nonmetallic Sheathed Cable Clamps

418 (2)QClamp,1/4"Setback 14.8(242.5) —4 (2)1/2" —25 IIIIIIII

SwITCH BOXES

NEw

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A53

SEE END OF SECTION (PG A71) FOR DETAILED DRAWINGS »

MULTI-DEVICE LARGE CAPACITY SWITCH BOXES & PARTITIONS

APPLICATIONS

• Installerscansavetimeandcutinstallation

costswithmulti-gangswitchboxes

• Largercapacityboxesareidealfortodays

designswherethereisaneedtoinstalltwo

devicesatonelocation

PRODUCT FEATURES

• ReferencetheBoxSelectionsectioninthe

frontofthiscatalogforcompletedescription

ofbracketandclamptypesandfeatures

COMPLIANCES

• FileE195978(Cat.#971notULListed)

687

971

686

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

SIDES

CONDUIT ENDS

CABLE ENDS

CONDUIT BOTTOM CONDUIT

Multi-Device Switch Boxes, 2-1/2" Deep – Welded with Conduit KO’s

686 3-Gang,1/2"Setback 47.8(783.3) (6)1/2",(6)3/4" — (2)1/2",(2)3/4" (3)1/2",(3)3/4" 10 IIIIIIII

687 4-Gang,1/2"Setback 63.5(1040.6) (8)1/2",(8)3/4" — (2)1/2",(2)3/4" (4)1/2",(4)3/4" 10 IIIIIIII

Low-Voltage Partition

971 For686and687Boxes — — — — — 25 —

SwITCH BOXES

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A54

SEE END OF SECTION (PG A71) FOR DETAILED DRAWINGS »

muLTI-GANG BOXES

APPLICATIONS

• RACO® Gangboxesareusedwhere

anumberofwiringdevicesaretobe

centrallylocated

PRODUCT FEATURES

• Gangboxessavetimeininstallation,no

needtogangboxestogether

• Have1/2"and3/4"concentricKO’s

forusewithawidevarietyofwiring

methods

• BottomKOpattern,3-1/2"and2-3/4"

ateitherendofbox

• Accepttwostylesofcovers,flatand

3/4"raiseddevicecover

• Uselowvoltagepartitions#947or

#949

COMPLIANCES

• Listed731A

941 through 945

951 through 958

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS STD.

PKG. BAR

CODE

TOP & BOTTOM SIDES BACK

Gang Boxes, 1-5/8" Deep – Welded with Conduit KO’s

951 2Gang 47.0(770.1) 8Conc.

1/2"&3/4"

4Conc.

1/2"&3/4"

(3)1/2"

(2)3/4" 5—

952 3Gang 60.0(983.2) 10Conc.

1/2"&3/4"

4Conc.

1/2"&3/4"

(6)1/2"

(4)3/4" 5IIIIIIII

953 4Gang 72.8(1192.9) 12Conc.

1/2"&3/4"

4Conc.

1/2"&3/4"

(6)1/2"

(4)3/4" 5IIIIIIII

954 5Gang 85.8(1406.0) 14Conc.

1/2"&3/4"

4Conc.

1/2"&3/4"

(6)1/2"

(4)3/4" 5—

955 6Gang 98.5(1614.1) 16Conc.

1/2"&3/4"

4Conc.

1/2"&3/4"

(6)1/2"

(4)3/4" 1—

956 7Gang 111.5(1827.1) 18Conc.

1/2"&3/4"

4Conc.

1/2"&3/4"

(6)1/2"

(4)3/4" 1—

957 8Gang 124.5(2040.1) 20Conc.

1/2"&3/4"

4Conc.

1/2"&3/4"

(6)1/2"

(4)3/4" 1—

958 9Gang 137.3(2249.9) 22Conc.

1/2"&3/4"

4Conc.

1/2"&3/4"

(6)1/2",

(2)3/4" 1—

Gang Boxes, 2-1/2" Deep – Welded with Conduit KO’s

941 2Gang 70.0(1147.0) (4)3/4"

4Conc.3/4"&1"

4Conc.

3/4"&1"

(3)1/2"

(2)3/4" 5IIIIIIII

942 3Gang 90.0(1474.8) (8)3/4"

2Conc.3/4"&1"

4Conc.

3/4"&1"

(6)1/2"

(4)3/4" 5IIIIIIII

943 4Gang 110.0(1802.5) (4)3/4"

4Conc.3/4"&1"

4Conc.

3/4"&1"

(6)1/2"

(4)3/4" 5IIIIIIII

944 5Gang 130.0(2130.3) (6)3/4"

4Conc.3/4"&1"

4Conc.

3/4"&1"

(6)1/2"

(4)3/4" 5IIIIIIII

945 6Gang 150.0(2458.0) (6)3/4"

6Conc.3/4"&1"

4Conc.

3/4"&1"

(6)1/2"

(4)3/4" 1IIIIIIII

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A55

muLTI-GANG BOXES

COVERS AND PARTITIONS

APPLICATIONS

• RACO® Gangboxcoverspermitthe

mountingofdevices

• Lowvoltagepartitionsmaybeaddedto

boxestodividepowerfromvoice/data

• RACO® 834and836coversareideal

fornursecallstations

PRODUCT FEATURES

• RACO® Devicecoversalsofitnext

smallerbox,i.e.threegangcoverfits

twoorthreegangbox

• Partitiondividesboxesinto

compartments

COMPLIANCE

• Listed731A(Cat.#974and#949

notULListed)

822

821

824

823

826

825

828

827

834, 836 974 949

DESCRIPTION UPC

BAR

CODE

STD.

PKG.

CAT. #

821 2Gang,7-1/16"Width 951or941 10.0(163.8) 5 —

822 3Gang,8-7/8"Width 952or942 15.3(250.7) 5 IIIIIIII

823 4Gang,10-11/16"Width 953or943 20.3(332.6) 5 IIIIIIII

824 5Gang,12-1/2"Width 954or944 25.5(417.8) 5 —

825 6Gang,14-5/16"Width 955or945 30.5(499.8) 1 —

826 7Gang,16-1/8"Width 956 35.5(581.7) 1 —

827 8Gang,17-15/16"Width 957 40.8(668.5) 1 —

828 9Gang,19-3/4"Width 958 45.8(750.5) 1 —

834 3Gang,8-7/8"Width,2"Raised 952or942 40.8(668.5) 15 —

836 3Gang,8-7/8"Width,1-1/2"Raised 952or942 30.6(501.4) 20 —

974 For1-5/8"Deep — — 25 —

949 For2-1/2"Deep — — 25 —

Low Voltage Partitions for Gang Boxes

CU. IN. CAP.

(CM3)

FOR GANG BOXES

Device Covers for Gang Boxes - Raised 3/4"

Device Covers for Gang Boxes

NEw

NEw!

STEEL BOXES, COVERS AND ACCESSORIES

RACO BOXES, COVERS AND ACCESSORIES

A56

BLANK COVERS

muLTI-GANG BOXES

DESCRIPTION UPC

BAR

CODE

STD.

PKG.

CAT. #

844 2Gang,7-1/16"Width 951or941 5 —

845 3Gang,8-7/8"Width 952or942 5 —

846 4Gang,10-11/16"Width 953or943 5 —

847 5Gang,12-1/2"Width 954or944 1 —

848 6Gang,14-5/16"Width 955or945 1 —

849 7Gang,16-1/8"Width 956 1 —

850 8Gang,17-15/16"Width 957 1 —

851 9Gang,19-3/4"Width 958 1 —

Flat, Blank Covers for Gang Boxes

845

844

847

846

849

848

851

850

APPLICATIONS

• Coversareusedtocloseamulti-

gangbox

FOR GANG BOXES

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A57

SEE END OF SECTION (PG A72) FOR DETAILED DRAWINGS »

CONCRETE RINGS, CEILING BOX AND COVER PLATES

CAT. # DESCRIPTION

CUBIC

INCHES

(CM3)

KNOCKOUTS

RECOMMENDED MAX. LOADS

STD.

PKG. BAR

CODE

CEILING FAN

(DYNAMIC) LBS. FIXTURE

(STATIC) LBS.

Concrete Rings

270RAC 2"Deep 24.5(401.4) SingleRowKO’s-

1/2"and3/4" No 50 25 —

271 2-1/2"Deep 30.8(504.7) SingleRowKO’s-

1/2"and3/4" No 50 25 IIIIIIII

272 3"Deep 37.0(606.3) SingleRowKO’s-

1/2"and3/4" No 50 25 —

277 3"Deep 37.0(606.3) SingleRowKO’s-

3/4"and1" No 50 25 —

273 3-1/2"Deep 43.0(704.6) DoubleRowKO’s-

1/2"and3/4" No 50 20 —

278 3-1/2"Deep 43.0(704.6) SingleRowKO’s-

3/4"and1" No 50 20 —

274 4"Deep 49.3(807.8) DoubleRowKO’s-

1/2"and3/4" No 50 20 —

279 4"Deep 49.3(807.8) DoubleRowKO’s-

3/4"and1" No 50 20 —

275 5"Deep 61.5(1007.8) DoubleRowKO’s-

1/2"and3/4" No 50 10 —

276 6"Deep 74.0(1212.6) DoubleRowKO’s-

1/2"and3/4" No 50 10 —

284 4"Deep 49.3(807.8) DoubleRowKO’s-

1/2"and3/4" 35 75 6 —

Hung Ceiling Box

280 3-1/2"Deep,

includesan

890cover

43.0(704.6) DoubleRowKO’s

(8)1/2"and(8)3/4" No —20 —

918 30"Long

BarsforHung

CeilingBox

— — No —40 —

APPLICATIONS

• RACO® Concreteringsareused

withpoureddeck(floor)inhigh-rise

construction

• Theseboxesareinstalledonwoodenor

steelconcreteforms.Aftertheforms

areremoved,theboxisflushwiththe

concrete

• RACO® CeilingFanConcreteRing284is

listedforsupportofceilingfans

PRODUCT FEATURES

• Flatsidesprovideexcellentcontactfor

locknuts

• Externalearsareusedtonailtheringto

thewoodform

• Topcoverisremovableforbefore-pour

work

• Earsoninsideofboxareforfixtures

• Waxedfixtureearspreventconcrete

frominterferingwiththethreads

• Avarietyofcoverplatesareavailable

• Coverplatemustbeorderedseparately

withallRACO®concreterings

COMPLIANCE

• FileE195978

276

275 284 GORILLA-RING®280

918

271

270RAC 272 277 273 278 274, 279

DESCRIPTION UPC

BAR

CODE

STD.

PKG.

CAT. #

890 (3)1/2"and(2)3/4"KO’s,O.D.Diam.4-1/2" 25 IIIIIIII

892 Flat,Blank,O.D.Diam.4-1/2" 25 —

893 O.D.Diam.4-1/2",JoinsOctagonExt.RingtoConcreteRing,TwoRetainedScrews 50 —

Concrete Ring - Back Plates/Covers and Adapter Ring

890 892 893

mASONRy BOXES

steel boxes, covers and accessories

RACO BOXES, COVERS AND ACCESSORIES

A58

SEE End of SEction (PG A72) for dEtAilEd drAwinGS »

Masonry Boxes

MASONRY BOXES AND PARTITIONS

applications

• RACO® Masonry boxes are designed to

accommodate the mounting of switches or

other devices in masonry walls

• Gangable masonry boxes offer the option of

constructing a box to hold two or more devices

• 2-1/2" deep boxes are used in 4" block

walls, 3-1/2" deep boxes are used in 6" or

8" block walls

nongangable product features

• Rugged welded design does not fall apart

during construction

• Available from one to six gang configurations

in both 2-1/2" and 3-1/2" depths

• Rectangular shape fits square cuts in block

• Large volume design allows for additional

work room inside the box

• Standard 1/2" and 3/4" concentric Knockouts

• Device ears inside the box prevent mortar

from getting in the device holes

• Steel low voltage partition #971 fits all

2-1/2" or 3-1/2" depths

• Standard wall plates can be used

coMpliance

• File E195978 (Cat. #971 not UL Listed)

690 through 694

695 through 699

960

965 971

cAt. # dEScriPtion

cubic

inchES

(cm3)

KnocKoutS Std.

PKG. bAr

codE

SidES

conduit EndS

conduit bottom

conduit

Masonry Boxes, 2-1/2" Deep – Nongangable with Conduit KO’s

690 1 Gang, 1-31/32" Wide 16.0 (262.1) 4 Conc. 2 Conc. 2 Conc. 25 —

691 2 Gang, 3-25/32" Wide 31.8 (521.1) 4 Conc. 4 Conc. 4 Conc. 25 —

692 3 Gang, 5-19/32" Wide 47.8 (783.3) 4 Conc. 6 Conc. 3 Conc. 10 —

693 4 Gang, 7-13/32" Wide 63.5 (1040.5) 4 Conc. 8 Conc. 4 Conc. 10 —

694 5 Gang, 9-7/32" Wide 79.5 (1302.7) 4 Conc. 10 Conc. 5 Conc. 10 —

960 6 Gang, 11-1/32" Wide 95.3 (1561.6) 4 Conc. 12 Conc. 6 Conc. 1 —

Masonry Boxes, 3-1/2" Deep – Nongangable with Conduit KO’s

695 1 Gang, 1-31/32" Wide 22.5 (368.7) 4 Conc. 4 Conc. 2 Conc. 25 —

8695 1 Gang, 1-31/32" Wide 22.5 (368.7) 4 Conc. 4 Conc. 2 Conc. 25 IIIIIIII

696 2 Gang, 3-25/32" Wide 45.0 (737.4) 4 Conc. 8 Conc. 4 Conc. 25 IIIIIIII

697 3 Gang, 5-19/32" Wide 67.3 (1102.8) 4 Conc. 12 Conc. 3 Conc. 10 IIIIIIII

698 4 Gang, 7-13/32" Wide 89.8 (1471.5) 4 Conc. 16 Conc. 4 Conc. 10 —

699 5 Gang, 9-7/32" Wide 112.3 (1840.2) 4 Conc. 20 Conc. 5 Conc. 10 —

965 6 Gang, 11-1/32" Wide 134.8 (2208.9) 4 Conc. 24 Conc. 6 Conc. 1 —

cAtAloG # dEScriPtion Std. PKG. bArcodE

Low Voltage Partitions for Masonry Boxes

971 For Nongangable, 2-1/2" or 3-1/2" Deep Boxes 25 —

steel boxes, covers and accessories

www.Hubbell-RTB.com A59

masonry boxes

MASONRY BOXES AND SUPPORT

675 676

688 689

CATAlog # DesCripTion sTD. pKg. BArCoDe

Low Voltage Partitions for Masonry Boxes

675 For Gangable, 2-1/2" Deep Boxes 20 IIIIIIII

676 For Gangable, 3-1/2" Deep Boxes 20 IIIIIIII

CAT. # DesCripTion

CuBiC

inChes

(Cm3)

KnoCKouTs sTD.

pKg. BAr

CoDe

siDes

ConDuiT enDs

ConDuiT BoTTom

ConDuiT

Masonry Boxes, 2-1/2" Deep – Gangable with Conduit KO’s

688 1 Gang, 1-15/16" Wide 15.5 (253.9) 4 TKO®2 TKO®2 TKO®20 IIIIIIII

Masonry Boxes, 3-1/2" Deep – Gangable with Conduit KO’s

689 1 Gang, 1-15/16" Wide 22.5 (368.7) 4 TKO®4 TKO®2 TKO®20 IIIIIIII

new!

BLOCK-LOC™

990

CATAlog # DesCripTion sTD. pKg. BArCoDe

BLOCK-LOC™ Masonry Box Support Bracket

990 For Gangable or Nongangable Boxes 5* IIIIIIII

new

*5 bags of 10 – sold in carton quantities only

applications

• RACO® Masonry boxes are designed to

accommodate the mounting of switches or

other devices in masonry walls

• Gangable masonry boxes offer the option of

constructing a box to hold two or more devices

• 2-1/2" deep boxes are used in 4" block

walls, 3-1/2" deep boxes are used in 6" or

8" block walls

gangable product features

• Rugged welded design does not fall apart

during construction

• Gangable design allows installer to build

unlimited number of gangs to hold multiple

devices

• Rectangular shape fits square cuts in block

• Standard 1/2" and 3/4" TKO® Knockouts

• Device ears inside the box prevent mortar

from getting in the device holes

• Steel low voltage partitions:

#675 fits 2-1/2" box

#676 fits 3-1/2" deep box

• Forward mounted grounding provision allows

for easy installation of grounding pigtail

• Standard wall plates can be used

blocK-loc™ applications

• Locksboxsecurelytoconcreteblockwallto

prevent movement during construction

blocK-loc™ features

• Securesboxtoconcreteblock,evenin

irregular cut openings

• Easy-bendtabslockboxfromtop,front,

sides and back

• Soldinbreakawaypairs

• Notoolsrequired

• Cost effective – reduces installation time

and eliminates costly rework

• Universal–Singleormulti-gangmasonry

boxes & tile covers

• Installationinstructionsincluded

• PatentPending

steel boxes, covers and accessories

RACO BOXES, COVERS AND ACCESSORIES

A60

Box support products

BRACES AND BRACKETS - BETWEEN STUDS

9004R, 9006R

9013R, 9015R

9001 9002

cAtAloG # dEScriPtion Std. PKG. bArcodE

Non-adjustable Box Mounting Brace – For 4" and 4-11/16" Square Box

9004r For 16" Stud Spacing, 1-1/2" or 2-1/8" Deep Box 50 —

9006r For 24" Stud Spacing, 1-1/2" or 2-1/8" Deep Box 50 —

Adjustable Box Mounting Brace – For 4" and 4-11/16" Square Box

9013r Adjusts from 10-3/8" to 18", 1-1/2" or 2-1/8" Deep Box 50 —

9015r Adjusts from 15" to 26", 1-1/2" or 2-1/8" Deep Box 50 —

Fixed Position Box Mounting Brackets – For 4" and 4-11/16" Square Box

9001 (3) Box, for 16" On Center Studs 50 —

9002 (4) Box, for 24" On Center Studs 50 —

Fixed Position Box Mounting Brackets w/Cable Support

3PrAc 9 Cable Supports 14 —

4PrAc 12 Cable Supports 10 —

applications

(9004r - 9006r, 9013r - 9015r)

• RACO® Braces and extenders are used for

metal or wood stud box positioning

product features

• Available for 1-1/2" or 2-1/8" deep boxes

• Locator dimples on face of bar allows for exact

positioning of single or multiple boxes

• Dimple feature provides quick start of screws,

and reinforcement to prevent box mounting

screws from stripping out when box is mounted

• Design of adjustable brace allows ground

screw to clear when box is mounted

• Boxes attach easily with self-tapping screws

coMpliances

• LISTED

LISTED - UL E195973

applications (9001, 9002)

• Positionselectricalboxes,plasterringsand

low voltage devices between studs

product features

• Fold-back stabilizer leg prevents bracket

from being pushed back in wall cavity during

drywall installation

• Designed for 2-1/2" or 3-1/2" studs.

• Mounts 4" or 4-11/16" sq. boxes

• Box can be mounted on ring without raised

cover to save time by providing maximum

work area inside box

• When mounted, raised cover is brought to

within 1/16" of drywall everytime and will not

bulge or break out drywall

coMpliances

• LISTED

USPatent7,902,457

applications (3prac, 4prac)

• Rough-In-Ready® 3PRACallowtwo4"and

one 4-11/16" (in center) square boxes

to be securely positioned between two

studs.4PRACbracketsallowmultiple4"

or 4-11/16" square boxes to be securely

positioned between two studs.

product features

• Face mount stud brackets allows bracket/

box to directly mount to any type of stud -

metal (open or closed sides) or wood

• 3PRAC=supportsupto3,squareboxesand

mudrings.4PRAC=supportsupto4,square

boxes and mud rings

• Integrated top cable support manages

cables entering assembly per current NEC

requirements

• Easy to use, integrated locking tabs hold

cable securely in place - simply snap cable

in, no additional hardware required to hold

cables in place

• 3PRAC=9built-incableholders,4PRAC=

12 built in cable locators

• Cable holders will accept cable ranges from

12-2MC to 10-4 MC

• Stud bracket features centering hole for easy

locating of bracket to correct height from

center of device to floor

• Unique box locking tab secures box to bracket

for transporting to job site. Tab design allows

mud ring to be removed from box without

disengaging from bracket assembly

• Built-in, flip-out far side supports will

accommodate either 2-1/2", 3-1/2", or 3-5/8"

steel or wood stud depths. For 5-1/2" or 6"

stud depths, simply break out included far

side extensions and add to flip-out support

with screw

• Heavy 20 gauge .038" gauge pre-galvanized

steel construction for secure and rigid

support of boxes in wall cavity

coMpliances

• LISTED

Covered by patents: US 7,053,300B2 & US 6,996,943B2

3PRAC 4PRAC

new! new!

new

STEEL BOXES, COVERS AND ACCESSORIES

www.Hubbell-RTB.com A61

box support products

BRACKETS AND BOX SUPPORTS - ON STUDS

APPLICATIONS (9018)

• Supports electrical box when mounted

to a stud

PRODUCT FEATURES

• Dual-point mounting, right or left of stud.

Perfectforprefabapplications

• Mounts 4" or 4-11/16" sq. box to 2-1/2",

3-1/2" or 6" studs

COMPLIANCES

• LISTED

•

9018

CATAlog # DesCripTion sTD. pKg. BArCoDe

Two-point Box Mounting Brackets

9018 LeftorRightSideStudMount 100 —

Single Box Mounting Bracket with Cable Support – For MC/BX Wiring Systems

sBrnrrAC Positionsa4"Sq.JunctionBoxbetweenTwoStuds 30 —

BOX-LOC Metal Stud Clip

980 Spring Steel Bracket 50 IIIIIIII

Plastic Far Side Support

978 1-7/8"Rigid,PlasticSupport 50 —

Between Stud Spanner Bars

sp1rAC Spans 16" Between Two Metal or Wood Studs 30 —

sp2rAC Spans 24" Between Two Metal or Wood Studs 30 —

SBRNRRAC BOX-LOC® 980

978

Installed

APPLICATIONS (SBRNRRAC)

• Rough-In-Ready® bracket supports electrical

box when mounted to a stud

PRODUCT FEATURES

• Patented,builtincablesupportacceptsup

to 3 MC cables (12-2 MC to 10-4 MC). No

additional cable support needed

• Mounts 4" sq. box left or right of stud

• Patentedflip-outsupportaccommodateswood

and metal stud depths: 2-1/2", 3-1/2", 3-5/8",

5-1/2", and 6"

COMPLIANCES

• LISTED

Coveredbypatents:US7,053,300B2&US6,996,943B2

APPLICATIONS

980 BOX-LOC® & 978 (sold separately)

• Allows any 4" or 4-11/16" square metal box

to be affixed to a metal stud quickly and

easily. 978 Far Side Support prevents box

from being pushed back in wall cavity

PRODUCT FEATURES

• 980Patentspring-steeldesigninstallsin

seconds without tools

• 978 simply snaps into hole in back of box and

is easily cut to fit wall cavity

APPLICATIONS (SP1RAC, SP2RAC)

• Rough-In-Ready® Spannerbars,SP1RAC

for16"andSP2RACfor24"spans,work

with both SBRNRRAC and S1CRAC bracket

systems to provide support between two

metal or wood studs

• Bars can be used in many mechanical

support applications

PRODUCT FEATURES

• 1" high profile, 1/8" mounting holes, on

1" centers

• Heavy 20 guage .038" guage pre-galvanized

steel construction for secure and rigid

support of boxes in wall cavity

COMPLIANCES

• ULListedaspartofthe

Rough-In-Ready system

978

Installed

SP1RAC SP2RAC

SBRNRRAC

with Spanner Bars

new!

new!

new!

new

new

steel boxes, covers and accessories

RACO BOXES, COVERS AND ACCESSORIES

A62

box support products

BOX AND CABLE SUPPORTS - BETWEEN STUDS AND FLOOR

9009

9010

CATAlog # DesCripTion sTD. pKg. BArCoDe

Floor Mounted Box Support

9009 12" Tall Bracket 25 —

9010 18" Tall Bracket 25 —

applications (9009, 9010)

• Supports electrical boxes from floor or

concrete forms

product features

• Fold back stabilizer prevents bracket from

being pushed back in wall cavity during

drywall installation

• Designed for mounting square boxes 12" or

18" above floor. Mounts to metal or wood

plate.

• Mounts 4" or 4-11/16" square boxes

• Box can be mounted on support without

drywall ring to save time by providing

maximum working area in box

• When mounted, raised cover is brought to

within 1/16" of drywall every time. Will not

bulge or break out drywall

compliances

• LISTED

 LISTED-ULE195973

USPatent4,602,789

MC/BX Cable Holder

Cs1rAC 16"-10CablePostions 36 —

Cs2rAC 24"-16CablePostions 40 —

KS1RAC

Floor Mount Kick Stand – Adjustable

Ks1rAC Spans 16" Between Two Metal or Wood Studs 20 —

applications (Ks1rac)

• Rough-In-Ready® KS1RAC is designed to be

used in conjunction with SBRNRRAC

• Adjusts the box assembly at various heights

from floor 7" to 18" at 1" increments

product features

• SBRNRRAC single box support brackets lock

into KS1RAC using built in locator tabs

• Wrap under lip design and securing lock tab

allows for KS1RAC to be positioned under

stud for hands free installation of bracket/

box assembly

• KS1RAC wall assembly can be easily located

behind closed wall with built in locator tab

that can be seen once drywall is in place

• Heavy 20 gauge .038" gauge pre-galvanized

steel construction for secure and rigid

support of boxes in wall cavity

compliance

• LISTED

applications (cs1rac and cs2rac)

• Rough-In-Ready® CS1RAC and CS2RAC are

used to organize runs of MC or BX cables

withspacingforNECrequirementsthat

eliminates the need for derating

• Flexibility allows for multiple mounting

applications

product features

• Cable holders can be mounted in multiple

configurations - wall/surface, hung by 1/4"

all threaded rod, top of wall mounted or

deck mounted

• Easytouse,integratedlockingtabshold

cable securely in place - snap cable in, no

additional hardware required to hold cables

in place

• Cable holders accept cable range ranges

from 12-2MC to 10-4MC

• Heavy 20 gauge .038" gauge pre-galvanized

steel construction for secure and rigid

support of boxes in wall cavity

compliance

• LISTED

USPatent6,996,943B2

CS1RAC

CS2RAC

SBRNRRAC, KS1RAC

w/Spanner Bar

new

new

new!

new!

new!

steel boxes, covers and accessories

www.Hubbell-RTB.com A63

accessories for steel boxes

application (920, 922)

• RACO® Adjustable bar hanger allows box

to be placed between ceiling joists or wall

studs quickly and easily

product features

• Both RACO® 920 and 922 bar fixture

hangers allow box to be located anywhere

along length of bar

• 920, 922 Clip installs in 1/2" knockout

located in bottom (back) of box

• RACO® box must be ordered separately

box installation

• Bar hangers attach to octagon or square

boxes through center 1/2" knockouts

• Remove knockout from box, also the screw

and fixture clip from bar hanger

• When box is located accurately between

joists, tighten the screw securely

920, 922

**UL rated at 16" span on center for 50 lbs.

CAT. # DesCripTion

reCommenDeD mAx. loADs

sTD.

pKg. BAr

CoDe

Ceiling FAn

(DynAmiC) lBs. FixTure

(sTATiC) lBs.

Adjustable Bar Hangers

920 Clip, Adjusts 14-1/4" to 22-1/2" No 10** 25 IIIIIIII

922 Clip, Adjusts 14-1/4" to 22-1/2" No 10** 50 —

KWiK-Hang™ applications

• Designedtosupport4"square,4-11/16"

square, round, or octagon boxes in hanging

applications

• Usesexistingholesinbottomofboxfor

quick installation

KWiK-Hang™ features

• Usewithcable,wire,chain,strut(not

included) to secure from building structure

• Quickinstallation

• Lockssecurelyintoposition

• Durablesteelconstruction

• Installationinstructionsincluded

CATAlog # DesCripTion sTD. pKg. BArCoDe

New Box Support Products

991 KWIK-HANG™ Box Support Hanger 50 —

new

new!

new!

DHRAC

CATAlog # DesCripTion sTD. pKg. BArCoDe

Universal Roof Deck Hanger

DhrAC Hanger 10 —

compliances

• cULusListedforstaticfixturesloadof50

lbs or less

• SatisfiesNEC300.11forboxsupport

• FileE195978

PatentPending

applications (dHrac)

• Rough-In-Ready® DHRAC provides means of

static load support from roof decking. The

DHRAC can be used to mount luminaries

that need to be suspended from roof decking

product features

• Easilyinstallstoroofdeckingwithuseof

4, #8 or larger sheet metal screws (not

included)

• Large1-3/8"holeopeningaccommodatesa

variety of chains, cables hooks, etc.

• Heavy 20 guage .038" guage pre-galvanized

steel construction for secure and rigid support

• Max. static support load for deck thickness

of 20 or 22 gauge using min. 4, #8 or larger

sheet metal screws - 100 lbs.

compliance

•

BOX SUPPORTS - CEILING

991

new

steel boxes, covers and accessories

RACO BOXES, COVERS AND ACCESSORIES

A64

accessories for steel Boxes

961 963 966

962 964

dEScriPtion Std.

PKG.

cAt. #

Switch Box Accessories, Replacement

for rAco® Switch boxES

969 Old Work Clips for Switch Boxes, 1/2" Sheetrock 50 pairs IIIIIIII

9008 New or Old Work Single Gang 100 —

9017 New or Old Work Single Gang 20 Bags** IIIIIIII

976 Adjustment Range 1/4" - 1", Two 1-1/8" Screws Included 25 Bags IIIIIIII

Old Work Switch Box Clips

Low Voltage Mounting Bracket

uPc

bAr

codE

961 PlasterEars-  410,420,440,445,500,503,506, 508, 526, 100 IIIIIIII

Open Style with Screws 545, 560, 565, 567, 570RAC, 590, 600, 601

962 PlasterEars-  150,400,591 100 IIIIIIII

Clipped Style with Screws

963 PlasterEars-  471,487,517,518,519,523 100 IIIIIIII

1 Screw Style with Screws

964 OldWorkGRIPTITE® Clip w/Screws 523 100 IIIIIIII

966 OldWorkTIGERGRIP® Clip w/Screws 487, 506, 517 100 IIIIIIII

“old WorK saddle” application

(970rac)

• The “Old Work Saddle” 907RAC is design-

ed to be used with 2-1/2" deep switch

boxes that have plaster ears

“old WorK saddle” product

feature

• 970RAC installs into the 1/2" bottom

conduit knockout

grip-loK® application

(977, 8977, 8977-5)

• TheGRIP-LOKsupportisdesignedtobe

used with any deep switch box that has

plates ears

grip-loK® product feature

• SimplyslipGRIP-LOKbetweenboxand

wall, then bend tabs into the box

applications (9008, 9017)

• Mounts standard low voltage wall plates,

old work (existing walls)

product features

• For use on low voltage Class 2 circuits only

where electrical boxes are not required

• Can be used to mount telephone jacks,

computer outlets, security/sound systems,

television antennas, etc.

• Fast, precise mounting of low voltage wall

plates to walls or studs

coMpliance

• File E195973

add-a-deptH applications (976)

• Add-A-Depth ring or “goof ring” is design-

ed to act as a barrier between combustible

wall surfaces and the wiring system

• For single and two-gang device boxes

• There is no UL standard for this product

• Subject to acceptance by an electric

inspector

969 976

9008, 9017

970RAC 977, 8977,

8977-5

GRIP-LOK® “Old Work” Switch Box Support

*4 Bundles of 25 – sold in carton quantities only **2 Brackets per polybag

dEScriPtion uPc

bAr

codE

Std.

PKG.

cAt. #

970rAc MountsSwitchBoxeswithPlasterEarsinHollowWallsorCeilings 10 IIIIIIII

977 Supplied as a pair. Use pair to mount switch box with 100 pairs —

plaster ears in hollow wall, 1-7/8" long legs

8977 Supplied as a pair. Use pair to mount switch box with 25 pairs IIIIIIII

plaster ears in hollow wall, 1-7/8" long legs

8977-5* Supplied as a pair. Use pair to mount switch box with 100 pairs IIIIIIII

plaster ears in hollow wall, 1-7/8" long legs

Switch Box Support “Old Work Saddle”

Add-A-Depth Ring Extends Switch Box Set Too Deep in Wall

nec code 314.20

• See page A(3) 2008 Standards

coMpliance

• File E195973, E195968

application (969)

• Old work box support clips convert standard

switch box to old work type

product feature

• Old work switch box clips for use with 1/2"

thick standard drywall

steel boxes, covers and accessories

www.Hubbell-RTB.com A65

protector plates

CABLE PROTECTOR PLATES

SEE END OF FITTINGS SECTION (PG B121) FOR PROTECTORS PLATES/PUZZLE-PLATES™ DETAILED DRAWINGS »

application (701r - 701fg)

• RACO® protector plates eliminate drywall

compound, debris, paint and drywall

router bit from entering box or damaging

device or conductors

product features

• Raisd - covers protect Decora, duplex and

switch devices

• Flat - covers close off mudring opening

to protect wiring from drywaller's router

bit tools

• Feature patented wire retrieval loop to

hold data wire in place

U.S.Patent7,102,079

puZZle-plate™ cable protectors

application (2712 – 2713r)

• Protectsnonmetallicsheathedcableor

raceway type wires running through wood

studs from accidental nail, screw, or drill

penetration. Also applies to plumbing to

protect nonmetallic piping

puZZle-plate™ product features

• Innovative,interlockingdesigndoesnot

allow nail or screw penetration through

gaps or holes

• Pre-galvanizedsteelconstructionfor

added corrosion protection

• Noadditionalhardwarerequired,just

position and hammer down spurs

• Uniqueinterlockingfeatureallows

installer to easily increase area that

requires protection

compliance

• LISTED

(not 2712, 2712-9, 2713)

701FD

702RD

701RD 702FD

DESCRIPTION STD.

PKG.

DEVICE

PROTECT

CAT. #

701R 3/4" Raised, for 1 Device Mudring GFI, Duplex, Switch 24

702R 3/4" Raised, for 2 Device Mudring GFI, Duplex, Switch 24

701F Flat, for 1 Device Mudring Opening and Wires 100

702F Flat, for 2 Device Mudring Opening and Wires 50

700F Flat, Round 2-3/4" O.C. Opening Mudring Opening and Wires 50

701RD Gangable for RACO 686, 687, and RACO Nongangable Masonry Boxes For Caddy®MP1S 24

702RD 3/4"Raised,LowVoltage ForCaddy®MP2S 24

701FD 3/4"Raised,LowVoltage For Caddy®MP1S 50

702FD 3/4"Raised,LowVoltage For Caddy®MP2S 50

701FG Flat, Gangable for 686, 687, RACO Gang Masonry Boxes Opening and Wires 100

Raised 3/4" and Flat for Device and Wire Protection

701F

702R

701R 702F

700F 701FG

2712 — PUZZLE-PLATE/Gangable 2-3/4" .0510" 100 IIIIIIII

2712-9R Yes PUZZLE-PLATE/Gangable 2-3/4" .0625" 50 —

2712-9 Yes PUZZLE-PLATE/Gangable 2-3/4" .0510" 50 —

2712R — PUZZLE-PLATE/Gangable 2-3/4" .0625" 100 IIIIIIII

2713 — PUZZLE-PLATE/Gangable 5" .0510" 50 IIIIIIII

2713R — PUZZLE-PLATE/Gangable 5" .0625" 50 IIIIIIII

2709 — Standard Type/NonGangable 2-9/16" .0625" 100 IIIIIIII

2709-9 Yes Standard Type/NonGangable 2-9/16" .0625" 100 —

2710 — Standard Type/NonGangable 2-9/16" .0625" 100 —

CONTRACTOR

PACK UPC

BAR

CODE

MATERIAL

THICKNESS

CAT. # STD.

PKG.

DESCRIPTION

2712 – 2713R

PUZZLE-PLATES®2709, 2710

Standard Type

Cable Protectors Plates – For Wood Studs

LENGTH

nailing spur applications (2709, 2710)

• Protectsnonmetallicsheathedcableorraceway

type wires running through wood members from

accidental nail, screw or drill penetration

• No nails required

product feature

• Old work

compliance

• LISTED(not970RAC)

PatentPending

steel boxes, covers and accessories

RACO BOXES, COVERS AND ACCESSORIES

A66

accessories for steel Boxes

BOX GROUNDING PRODUCTS

dEScriPtion uPc

bAr

codE

Std.

PKG.

cAt. #

982 994 #14 Solid insulated copper wire, captive 4-way combo head green dye finish 1000 —

ground screw one end (25 pc. bundles)

983 996 #12 Solid insulated copper wire, captive 4-way combo head green dye finish 1000 —

ground screw one end (25 pc. bundles)

8983-1 8996-1 #12 Solid insulated copper wire, captive 4-way combo head green dye finish 40 IIIIIIII

ground screw one end, poly bag (10 pc. per bag) Bags*

984 997 #14 Solid bare copper wire, captive 4-way combo head green dye finish 1000 —

ground screw one end (25 pc. bundles)

— 992 #14 Stranded insulated copper wire, captive 4-way combo head green dye finish 500 —

ground screw one end, spade terminal one end (100 pc. bundles)

— 993 #12 Stranded insulated copper wire, captive 4-way combo head green dye finish 500 —

ground screw one end, spade terminal one end (100 pc. bundles)

wirE lEnGth

Grounding Pigtails

992 #14 Wire

993 #12 Wire

984,

997 #14 Wire

982, 994 #14 Wire,

996, 8996-1, 8983-1,

983 #12 Wire

998,

8998-1 973,

8973-1 975,

8975-1

grounding applications

• RACO® Grounding accessories provide

a safe electrical path to ground to help

prevent shock

• RACO® Grounding screws thread into the

box and provide a means of fastening

the ground conductor

• Ground wires fasten to the box and

are then connected to wiring system or

wiring device

• RACO® 6" and 8" ground pigtails feature

4-way (slotted, phillips, hex-head)

combo 10-32 captive screw

• Ground clips provide a quick method

of fastening a ground conductor to the

edge of a steel outlet box

• Ground clips are designed for use with

solid No. 14, 12, and 10 guage copper

conductor or No. 12 and 10 guage

aluminum conductor

• Only one solid ground wire to be

installed per ground clip

coMpliance

• File E195975 (975, 8975-1)

6" 8"

dEScriPtion uPc

bAr

codE

Std.

PKG.

998 4-way combo head green dye finish 3/8" ground screw for 10-32 tapped hole, 1000 IIIIIIII

clam shell packaged (100 pc. per clam shell)

8998-1 4-way combo head green dye finish 3/8" ground screw for 10-32 tapped hole, 50 IIIIIIII

poly bag (10 pc. per bag) Bags*

973 Slotted head green dye finish 3/8" ground screw for 10-32 tapped hole, 1000 IIIIIIII

clam shell package (100 pc. per clam shell)

8973-1 Slotted head green dye finish 3/8" ground screw for 10-32 tapped hole, 50 IIIIIIII

poly bag (10 pc. per bag) Bags*

975 Green dye finish ground clip for #14-#10 AWG copper, 1000 IIIIIIII

clam shell package (100 pc. per clam shell)

8975-1 Green dye finish ground clip for #14-#10 AWG copper, 50 IIIIIIII

poly bag (10 pc. per bag) Bags*

Grounding Screws and Clips

cAt. #

*Order standard package bag quantifies only, not per piece

steel boxes, covers and accessories

www.Hubbell-RTB.com A67

detailed drawings

SQUARE BOXES

4" SqUARe CONDUIT BOXeS

CAT. # Dimensions

A (insiDe)

B C

223 1-1/2" 6-7/8" 4-3/8"

224 1-1/2" 1-31/32" 6"

225 1-1/2" 1-31/32" 6"

228 1-1/2" 4-5/8" 5-1/2"

229 1-1/2" 4-5/8" 5-1/2"

242 2-1/8" - -

243 2-1/8" 4-5/8" 5-1/2"

248 1-1/2" - -

249 2-1/8" 1-31/32" 6"

211, 8211 1-1/2" - -

213, 8213 1-1/2" - -

213hWp 1-1/2" 3-1/8" 4-15/16"

218, 8218 1-1/2" 6-7/8" 4-3/8"

240, 8240 2-1/8" 7" 4-5/16"

241, 8241 2-1/8" 7" 4-5/16"

248hWp 2-1/8" 3-1/8" 4-15/16"

CAT. # Dimensions

A (insiDe)

B C

181 1-1/2" - -

185 1-1/4" - -

187 1-1/2" - -

199 1-1/2" 6-7/8" 4-3/8"

202 1-1/2" - -

204 1-1/2" - -

207 2-1/8" - -

226 1-1/2" - -

227 1-1/2" 4-5/8" 5-1/2"

236 2-1/8" 7-5/8" 4-3/8"

237 2-1/8" 7-5/8" 4-3/8"

238 2-1/8" 4-5/8" 5-1/2"

239 2-1/8" - -

251 2-1/8" 1-31/32" 6"

8197 1-1/2" 7-3/8" 4-3/8"

189, 8189 1-1/2" - -

189F 1-1/2"

189h 1-1/2" 3-1/8" 4-15/16"

189hs 1-1/2" 3-1/8" 4-15/16"

189hWp 1-1/2" 3-1/8" 4-15/16"

189m 1-1/2" 3-1/8" 4-15/16"

189rAC 1-1/2" - -

189sm 1-1/2" - -

190, 8190 1-1/2" - -

191, 8191 1-1/2" - -

192, 8192 1-1/2" - -

192sm 1-1/2" - -

193, 8193 1-1/2" 1-31/32" 6"

196, 8196 1-1/2" 6-7/8" 4-3/8"

201, 8201 1-1/2" - -

203, 8203 1-1/2" - -

208, 8208 1-1/2" 6-13/16" 5-15/16"

231, 8231 2-1/8" - -

232, 8232 2-1/8" - -

232F 2-1/8" - -

232h 2-1/8" 3-1/8" 4-15/16"

232hs 2-1/8" 3-1/8" 4-15/16"

232hWp 2-1/8" 3-1/8" 4-15/16"

232m 2-1/8" 7" 4-15/16"

232-oW 2-1/8" - -

232rAC 2-1/8" - -

232sm 2-1/8" - -

233, 8233 2-1/8" - -

235, 8235 2-1/8" 7" 4-5/16"

911-3 2-1/8" - -

911-4 2-1/8" 7-5/8" 4-3/8"

911-6 1-1/2" - -

911-9 1-1/2" - -

CAT. # Dimensions

A (insiDe)

B C

255 3-1/2" 7-5/8" 3-3/4"

911-1 3-1/2" 7-5/8" 3-3/4"

256 3-1/2" - -

911-2 3-1/2" - -

3-3/4" SqUARe CONDUIT BOXeS

4" SqUARe CABLe BOXeS

steel boxes, covers and accessories

RACO BOXES, COVERS AND ACCESSORIES

A68

detailed drawings

SQUARE BOXES CEILING FAN SUPPORT PRODUCTS

CEILING PANS

4-11/16" SqUARE CONDUIT BOXES CEILING FAN SUPPORT BOXES

CEILING PANS – 3-1/2"

287, 292 AND 8292 CEILING PANS – 4"

293 and 8293

B

C

3 1/2"

A

D

E

C

3 1/2"

B

A

E

D

3 1/2"

B

A

B

3 1/2"

A

cAt. # dimEnSionS

A (inSidE)

b c

245 1-1/2" - -

246 1-1/2" - -

247 1-1/2" - -

250 1-1/2" - -

254 2-1/8" 7-5/8" 5-1/16"

258 2-1/8" - -

259 2-1/8" - -

260 3-1/4" - -

262 2-1/8" - -

266 2-1/8" 4-5/8" 6-3/16"

257, 8257 2-1/8" - -

257f 2-1/8" - -

257h 2-1/8" - -

257hS 2-1/8" - -

257m 2-1/8" - -

257Sm 2-1/8" - -

258Sm 2-1/8" - -

265, 8265 2-1/8" - -

911-12 2-1/8" - -

911-15 3-1/4" - -

cAt. # dimEnSionS

A (inSidE)

b

287

11/16" 3-3/8"

292 1/2" 3-3/8"

8292 1/2" 3-3/8"

293 1/2" 4"

8293 1/2" 4"

cAt. # dimEnSionS

A (inSidE)

b c d E

291-1 1-1/2" 4" 3-1/2" 1/2" 1-3/4"

294, 294-1 2-1/8" 4" 3-1/2" 1/2" 1-3/4"

295, 295-1 1/2" 4" ---

296, 296-1 1-1/2" 4" ---

299 2-1/8" 4" ---

291-1, 294, 294-1 (New Work)

295 and 295-1 296 – 299

294, 294-1 (Old Work)

steel boxes, covers and accessories

www.Hubbell-RTB.com A69

detailed drawings

OCTAGON BOXES

3-1/2" OCTAGON BOXES

4" OCTAGON CABLE BOXES

4" OCTAGON CONDUIT BOXES

cAt. # dimEnSionS

A (inSidE)

b c d E

110 1-1/2" 3-1/2" ---

111 1-1/2" 3-1/2" ---

112 1-1/2" 3-1/2" ---

119 1-1/2" 3-1/2" 7" -1-1/16"

cAt. # dimEnSionS

A (inSidE)

b c d E f

125, 8125 1-1/2" 4" ----

126 1-1/2" 4" ----

127 1-1/2" 4" ----

127tS 1-1/2" 4" 7" 1/2" 1-1/16" -

128 1-1/2" 4" ----

130 1-1/2" 4" ----

131rAc 1-1/2" 4" ----

158 1-1/2" 4" 2-3/8" - - 3-1/8"

165 2-1/8" 4" ----

166 2-1/8" 4" ----

161 1-1/2" 4" 7" 1/2" 1-1/16"

167 2-1/8" 4" ----

167tS 2-1/8" 4" 7" 1/2" 1-1/16" -

cAt. # dimEnSionS

A (inSidE)

b c d E f

145 1-1/2" 4" ----

146 1-1/2" 4" ----

150 1-1/2" 4" ----

153 1-1/2" 4" ----

155 1-1/2" 4" 7" 1/2" 1-1/16" -

157 1-1/2" 4" 2-3/8" - - 3-1/8"

160 1-1/2" 4" 2-3/8" - - 3-1/8"

164 1-1/2" 4" 7" 1/2" 1-1/16" -

175 2-1/8" 4" ----

176 2-1/8" 4" 2-3/8" 5/8" -3-3/4"

177 2-1/8" 4" 7" 1/2" 1-1/16" -

steel boxes, covers and accessories

RACO BOXES, COVERS AND ACCESSORIES

A70

detailed drawings

HANDY BOXES AND SWITCH BOXES

2-GANG HANDY BOXES / SWITCH BOXES

cAt. # dimEnSionS

A (inSidE)

b c

400 1-1/2" - -

420 2" - -

501 2-1/2" - -

502 2-1/2" 1-31/32" 4"

503 2-1/2" - -

505 2-1/2" 7" 2-13/64"

506 2-1/2" - -

508 2-1/2" - -

509 2-1/2" - -

560 2-3/4" - -

561 2-3/4" - -

562 2-3/4" 7" 2-13/64"

565 2-3/4" - -

591 3-1/2" - -

592 3-1/2" - -

500, 8500 2-1/2" - -

504, 8504 2-1/2" 7" 2-13/64"

590, 8590 3-1/2" - -

SINGLE GANG AND GANGABLE CONDUIT SWITCH BOXES

HANDY BOXES

cAt. # dimEnSionS

A (inSidE)

b c

661 1-7/8" 6-7/16" 2-7/32"

662 1-7/8" 7" 2-3/8"

655 1-1/2" 1-31/32" 4-1/8"

670rAc 2-1/8" - -

8670 2-1/8" - -

674 2-1/8" - -

678 2-1/8" 7" 2-3/8"

650, 8650 1-1/2" - -

650cSA 1-1/2" - -

653 1-1/2" - -

660, 8660 1-7/8" - -

611 1-7/8" - -

660Sm 1-7/8" - -

663, 8663 1-7/8" - -

663Sm 1-7/8" - -

665 1-7/8" - -

671 2-1/8" 6-7/16" 2-7/32"

cAt. # dimEnSionS

A (inSidE)

b c d E

680 2-1/8" 4" 4" - -

681 2-1/8" 4" 4" 7" 4-9/32"

683 2-1/8" 4" 4" - -

685 2-1/8" 4" 4" 7" 4-9/32"

steel boxes, covers and accessories

www.Hubbell-RTB.com A71

detailed drawings

SWITCH BOXES

SINGLE GANG AND GANGABLE CABLE SWITCH BOXES MULTI-DEVICE SWITCH BOXES

MULTI-GANG BOXES

cAt. # dimEnSionS

A (inSidE)

b c

410 1-1/2" - -

440 2" - -

445 2" - -

471 2-1/4" - -

473 2-1/4" - -

487 2-1/4" - -

512 2-1/2" - -

517 2-1/2" - -

518 2-1/2" - -

519 2-1/2" - -

522 2-1/2" 1-31/32" 5-3/64"

523 2-1/2" - -

526 2-1/2" 1-3/8" 3-13/32"

528 2-1/2" - -

529 2-1/2" 1-31/32" 5-3/64"

531 2-1/2" 7" 2-13/64"

540 2-1/2" 1-31/32" 4"

545 2-1/2" - -

564 2-3/4" 7" 2-13/64"

567 2-3/4" - -

574 2-3/4" 7" 2-13/64"

600 3-1/2" - -

603 3-1/2" 1-31/32" 4"

604 3-1/2" 7" 2-13/64"

605 3-1/2" 7" 2-13/64"

524, 8524 2-1/2" 7" 2-13/64"

570rAc 2-3/4" - -

601, 8601 3-1/2" - -

601G 3-1/2" - -

cAt. # dimEnSionS

A (inSidE)

b c

941 2-1/2" 6-3/8" 6-13/16"

942 2-1/2" 8-3/16" 8-5/8"

943 2-1/2" 10" 10-7/16"

944 2-1/2" 11-13/16" 12-1/4"

945 2-1/2" 13-5/8" 14-1/16"

951 1-5/8" 6-3/8" 6-13/16"

952 1-5/8" 8-3/16" 8-5/8"

953 1-5/8" 10" 10-7/16"

954 1-5/8" 11-13/16" 12-1/4"

955 1-5/8" 13-5/8" 14-1/16"

956 1-5/8" 15-7/16" 15-7/8"

957 1-5/8" 17-1/4" 17-11/16"

958 1-5/8" 19-1/16" 19-1/2"

cAt. # dimEnSionS

A (inSidE)

b c d E

686 2-1/2" 3-3/4" 5-9/16" 7-5/8" 5-31/32"

687 2-1/2" 3-3/4" 7-3/8" 7-5/8" 7-25/32"

steel boxes, covers and accessories

RACO BOXES, COVERS AND ACCESSORIES

A72

detailed drawings

CONCRETE RINGS AND MASONRY BOXES

STEEL CONCRETE RINGS

KnocKout

SiZE

dimEnSionS

A

b

1/2" & 3/4"

1/2" 3/4"

3/4" & 1" 3/4" 1"

STEEL MASONRY BOXES

cAt. # dimEnSionS

A (inSidE)

b

688 2-1/2" 1-15/16"

690 2-1/2" 1-31/32"

691 2-1/2" 3-25/32"

692 2-1/2" 5-19/32"

693 2-1/2" 7-13/32"

694 2-1/2" 9-7/32"

960 2-1/2" 11-1/32"

689 3-1/2" 5-19/32"

695 3-1/2" 1-31/32"

8695 3-1/2" 1-31/32"

696 3-1/2" 3-25/32"

697 3-1/2" 5-19/32"

698 3-1/2" 7-13/32"

699 3-1/2" 9-7/32"

965 3-1/2" 11-1/32"
