SERVICE BULLETIN
Head Office E17--00208 Issue 1, December 2000
Codan Pty Ltd
ACN 007 590 605
81 Graves Street
Newton, South Australia 5074
AUSTRALIA
Telephone +61 8 8305 0311
Facsimile +61 8 8305 0411
Email: radcom@codan.com.au
Codan (UK) Ltd
Gostrey House
Union Road
Farnham, Surrey GU9 7PT
UNITED KINGDOM
Telephone +44 1252 717 272
Facsimile +44 1252 717 337
Codan Pty Ltd
Suite 11A, 2 Hardy Street
South Perth, Western Australia 6151
AUSTRALIA
Telephone +61 8 9368 5282
Facsimile +61 8 9368 5283
Page1of3
Worldwide Web: www.codan.com.au
Codan Pty Ltd
10660 Wakeman Ct
Manassas, VA 20110
USA
Telephone +1 703 361 2721
Facsimile +1 703 361 3812
Introduction of new surface mount PCBs
in 9323/9360/9390/9680/9780
Transceivers
Introduction
This Service Bulletin affects users of the 9323/9360/9390/
9680/9780 Transceivers. The thru--hole printed circuit boards
(PCBs) of the Receiver Exciter and the Power Amplifier
assemblies have been replaced with surface mount PCBs (see
Table 1). The new PCBs increase the reliability of the
transceiver, and meet the changing availability of some
components.
Table 1: Comparison of new and old PCBs/assemblies
PCB/assembly Part number Circuit diagram2
New Receiver Exciter PCB 08--05798--001 04--03349
Old Receiver Exciter PCB 08--05322--001 04--03135
New 26.5 MHz Power
Amplifier Assembly
08--05749--001 04--03269
Interim 26.5 MHz Power
Amplifier Assembly1
08--05872--001 04--03372
Old 26.5 MHz Power
Amplifier Assembly
08--04963--001 04--02973
New 30 MHz Power Amplifier
Assembly
08--05749--002 04--03268
Interim 30 MHz Power
Amplifier Assembly1
08--05872--002 04--03373
Old 30 MHz Power Amplifier
Assembly
08--05237--001 04--03096
New 50 W Power Amplifier
Assembly
08--05749--003 04--03360
Old 50 W Power Amplifier
Assembly
08--04963--002 04--03177
1 The interim Power Amplifier assemblies were fitted to transceivers to
overcome component supply problems.
2 The circuit diagrams are available from Codan if required.
Introduction of new surface mount PCBs in 9323/9360/9390/9680/9780 Transceivers
17--00208 Issue 1, December 2000Page2of3
Details
The 9323/9360/9390/9680/9780 Transceivers that have been fitted with the new PCBs
have a serial number prefix of J or greater. The serial number prefixes of the transceivers
fitted with the old and new PCBs are listed in Table 2.
During the transition period from thru--hole to surface mount PCBs, some
transceivers may have been manufactured using both thru--hole and surface mount
PCBs.
Table 2: Serial number prefixes of the transceivers fitted with the old and new
versions of the PCBs
Type of transceiver Old serial number
prefix
Interim serial
number prefix
New serial
number prefix
9323 F K J
9323 H F K J
9323 low power Q K J
9360 C F K J
9360 low power Q K J
9360 MR (Arabic) B K J
9360 MR (Cyrillic
Russian)
B K J
9360 V B K J
9360--30 F K J
9390 F K J
9390 H C K J
9680 F K J
9780 C K J
9780 low power Q K J
Introduction of new surface mount PCBs in 9323/9360/9390/9680/9780 Transceivers
Page3of317--00208 Issue 1, December 2000
Software compatibility
Receiver Exciter PCB
Transceivers using software versions earlier than version 4.20
To fit the new Receiver Exciter PCB in transceivers using software versions earlier than
version 4.20, complete the following:
-Upgrade the software to at least version 4.20 (for details see Information Bulletin
IB--00001 and the Service Bulletin 9323/9360/9390 Series—Receiver Exciter (Codan
part number 17--00167)).
-Modify the PCB of the control panel, according to the Application Note 9323 software
upgrade (Codan part number 17--60056).
-Fit the new Receiver Exciter PCB.
Transceivers using software versions 4.20 or later
The new Receiver Exciter PCB can be used as a direct replacement in all transceivers using
software versions 4.20 or later.
Power Amplifier Assembly PCBs
The new Power Amplifier Assembly PCBs can be used as a direct replacement in all
transceivers.
Repair issues
The surface mount PCBs cannot be repaired in the field and should be considered for
module level repairs only.
