CONTROL TRANSFORMERS

GENERAL SPECIFICATIONS:

STYLE: SERIES 2 IMPERVITRAN STYLE: IMPERVITRAN (NOT SERIES 2)

APPROVALS: UL/Cul FILE# E46323 APPROVALS: UL LISTED FILE# E46323/ CSA APPROVED FILE# LR27533

TEMP CLASS: 105°C/130°C TEMP CLASS: 105°C/130°C/180°C

VA SIZES: 50-1500 VA SIZES: 1000-5000 TERMINAL TORQUE:

SUFFIX DESCRIPTION: ALL IMPERVITRAN PRODUCT

"K" IN SUFFIX DENOTES INSTALLED SECONDARY FUSE CLIPS

"R" IN SUFFIX DENOTES INSTALLED CLASS "CC" PRIMARY FUSE BLOCK

≤30A: 20 INCH-POUNDS

TWO LETTER SUFFIX = TEMP CLASS 105C >30A: 30 INCH-POUNDS

THREE LETTER SUFFIX ENDING "F" = TEMP CLASS 130C

THREE LETTER SUFFIX ENDING "H" = TEMP CLASS 180C

CATALOG CATALOG CATALOG

NUMBER NUMBER NUMBER

GROUP "A" GROUP "C" GROUP "F"

VOLTAGE: VOLTAGE: VOLTAGE:

PRI: 220x440, 230x460, 240x480 PRI: 120x240 PRI: 208/277

SEC: 110/115/120 SEC: 24 SEC: 120

VA AMPS VA AMPS VA AMPS

B050BTZ13JK 50 0.43 B050LP7JK 50 2.08 B050MQ15XK 50 0.42

B050BTZ13RB B050LP7RB B050MQ15RK

B075BTZ13JK 75 0.65 B075LP7JK 75 3.13 B075MQ15XK 75 0.63

B075BTZ13RB B075LP7RB B075MQ15RK

B100BTZ13JK 100 0.87 B100LP7JK 100 4.17 B100MQ15XK 100 0.83

B100BTZ13RB B100LP7RB B100MQ15RK

B150BTZ13JKF 150 1.30 B150LP7JKF 150 6.25 B150MQ15XKF 150 1.25

B150BTZ13RBF B150LP7RBF B150MQ15RKF

B200BTZ13JKF 200 1.74 B200LP7JKF 200 8.33 B200MQ15XKF 200 1.67

B200BTZ13RBF B200LP7RBF B200MQ15RKF

B250BTZ13JKF 250 2.17 B250LP7JKF 250 10.42 B250MQ15XKF 250 2.08

B250BTZ13RBF B250LP7RBF B250MQ15RKF

B300BTZ13JKF 300 2.61 B300LP7JKF 300 12.50 B300MQ15XKF 300 2.50

B300BTZ13RBF B300LP7RBF B300MQ15RKF

B350BTZ13JKF 350 3.04 B350LP7JKF 350 14.58 B350MQ15XKF 350 2.92

B350BTZ13RBF B350LP7RBF B350MQ15RKF

B500BTZ13JKF 500 4.35 B500LP7JKF 500 20.83 B500MQ15XKF 500 4.17

B500BTZ13RBF B500LP7RBF B500MQ15RKF

B750BTZ13JKF 750 6.52 B750LP7JKF 750 31.25 B750MQ15XKF 750 6.25

B750BTZ13RBF B750LP7RBF B750MQ15RKF

B1K0BTZ13JKF 1000 8.70

B1K0BTZ13RBF GROUP "G"

B1K5BTZ13JKF 1500 13.04 VOLTAGE:

B1K5BTZ13RBF PRI: 208/230/460

B2K0BTZ13JKH 2000 17.39 SEC: 115

B2K0BTZ13RBH B050MBT13XK 50 0.43

B3K0BTZ13JXH 3000 26.09 B050MBT13RK

B5K0BTZ13JXH 5000 43.48 B075MBT13XK 75 0.65

B075MBT13RK

GROUP "B" GROUP "E" B100MBT13XK 100 0.87

VOLTAGE: VOLTAGE: B100MBT13RK

PRI: 240x480 PRI: 550/575/600 B150MBT13XKF 150 1.30

SEC: 24 SEC: 110/115/120 B150MBT13RKF

B050PU7JK 50 2.08 B050WZ13XK 50 0.43 B200MBT13XKF 200 1.74

B050PU7RB B050WZ13RK B200MBT13RKF

B075PU7JK 75 3.13 B075WZ13XK 75 0.65 B250MBT13XKF 250 2.17

B075PU7RB B075WZ13RK B250MBT13RKF

B100PU7JK 100 4.17 B100WZ13XK 100 0.87 B300MBT13XKF 300 2.61

B100PU7RB B100WZ13RK B300MBT13RKF

B150PU7JKF 150 6.25 B150WZ13XKF 150 1.30 B350MBT13XKF 350 3.04

B150PU7RBF B150WZ13RKF B350MBT13RKF

B200PU7JKF 200 8.33 B200WZ13XKF 200 1.74 B500MBT13XKF 500 4.35

B200PU7RBF B200WZ13RKF B500MBT13RKF

B250PU7JKF 250 10.42 B250WZ13XKF 250 2.17 B750MBT13XKF 750 6.52

B250PU7RBF B250WZ13RKF B750MBT13RKF

B300PU7JKF 300 12.50 B300WZ13XKF 300 2.61 B1K0MBT13XKF 1000 8.70

B300PU7RBF B300WZ13RKF B1K0MBT13RKF

B350PU7JKF 350 14.58 B350WZ13XKF 350 3.04 B1K5MBT13XKF 1500 13.04

B350PU7RBF B350WZ13RKF B1K5MBT13RKF

B500PU7JKF 500 20.83 B500WZ13XKF 500 4.35 B2K0MBT13XKH 2000 17.39

B500PU7RBF B500WZ13RKF B2K0MBT13RKH

B750PU7JKF 750 31.25 B750WZ13XKF 750 6.52 B3K0MBT13XXH 3000 26.09

B750PU7RBF B750WZ13RKF B5K0MBT13XXH 5000 43.48
