TSQ8000_SparePartsGuide 1R120587 0004 TSQ Duo Spare Parts Guide

: Pdf 1R120587-0004 Tsq Duo Spare Parts Guide 1R120587-0004 TSQ Duo Spare Parts Guide TSQ Duo Manuals User ation

Open the PDF directly: View PDF .
Page Count: 116 [warning: Documents this large are best viewed by clicking the View PDF Link!]

TSQ Duo

Mass Spectrometer

Spare Parts Guide

1R120587-0004 Revision B December 2015

© 2015 Thermo Fisher Scientific Inc. All rights reserved.

TSQ, ISQ, TRACE, TriPlus, and TraceFinder are trademarks, and Chromeleon and Xcalibur are registered

trademarks of Thermo Fisher Scientific in the United States.

The following are registered trademarks in the United States and other countries: Microsoft, Windows, and

Excel are registered trademarks of Microsoft. Adobe and Acrobat are registered trademarks of Adobe Systems

Incorporated. Siltite is a registered trademark of SGE Analytical Science in the United States. Septum BTO is a

registered trademark of Chromatography Research Supplies, Inc. TORX is a registered trademark of Camcar

LLC of Acument Global Technologies. Vespel is a registered trademark of E.I. du Pont de Nemours and

Company in the United States and other countries.

Thermo Fisher Scientific Inc. provides this document to its customers with a product purchase to use in the

product operation. This document is copyright protected and any reproduction of the whole or any part of this

document is strictly prohibited, except with the written authorization of Thermo Fisher Scientific Inc.

The contents of this document are subject to change without notice. All technical information in this

document is for reference purposes only. System configurations and specifications in this document supersede

all previous information received by the purchaser.

Thermo Fisher Scientific Inc. makes no representations that this document is complete, accurate or error-

free and assumes no responsibility and will not be liable for any errors, omissions, damage or loss that might

result from any use of this document, even if the information in the document is followed properly.

This document is not part of any sales contract between Thermo Fisher Scientific Inc. and a purchaser. This

document shall in no way govern or modify any Terms and Conditions of Sale, which Terms and Conditions of

Sale shall govern all conflicting information between the two documents.

Release history: Revision A, September 2014; Revision B, December 2015

Software version: Thermo Foundation 3.1 SP1; Thermo Scientific™ Dionex™ Chromeleon™ 7 (release 7.2 SR3

MUa or later.

For Research Use Only. Not for use in diagnostic procedures.

Thermo Scientific TSQ Duo Spare Parts Guide iii

C

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

About Your System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x

Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi

Safety and Special Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi

Special Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi

Safety Symbols and Signal Words . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii

Hydrogen Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiii

Using Hydrogen with TSQ Duo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv

Hydrogen Connection Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv

Purchasing Hydrogen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Properly Storing Hydrogen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Hydrogen Safety Codes, Standards and References . . . . . . . . . . . . . . . . . . . .xix

Hazardous Substances Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xx

Biological Hazard Warning Note. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xx

Venting Toxic Gases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xxi

Contacting Us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xxi

Chapter 1 Ordering Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Identifying A Part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Calibration Gas Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Collision Gas Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Column Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Fan and Filter Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Ion Source Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Ion Source Cartridge Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Electron Multiplier Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Dual Filament Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Analyzer Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Board Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Power Module Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Manifold Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Cover Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

TSQ Duo Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Pump Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Contents

Contents

iv TSQ Duo Spare Parts Guide Thermo Scientific

Upgrade Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Declaration

Manufacturer: Thermo Fisher Scientific

Thermo Fisher Scientific is the manufacturer of the instrument described in this manual and, as such, is responsible for

the instrument safety, reliability and performance only if:

• installation,

•recalibration, and

•changes and repairs

have been carried out by authorized personnel and if:

• the local installation complies with local law regulations,

• the instrument is used according to the instructions provided, and

• if its operation is only entrusted to qualified trained personnel.

Thermo Fisher Scientific is not liable for any damages derived from the non-compliance with the aforementioned

recommendations.

Regulatory Compliance

Thermo Fisher Scientific performs complete testing and evaluation of its products to ensure full compliance with

applicable domestic and international regulations. When the system is delivered to you, it meets all pertinent

electromagnetic compatibility (EMC) and safety standards as described in the next section or sections by product name.

Changes that you make to your system may void compliance with one or more of these EMC and safety standards.

Changes to your system include replacing a part or adding components, options, or peripherals not specifically

authorized and qualified by Thermo Fisher Scientific. To ensure continued compliance with EMC and safety standards,

replacement parts and additional components, options, and peripherals must be ordered from Thermo Fisher Scientific

or one of its authorized representatives.

EMC and Safety Standards

• ITQ, and Ion Trap Series standards: EMC: EN 61326-1:2006. Safety: IEC 61010-1:2001, IEC 61010-2-081:2001

• Direct Probe Controller (DPC) standards: EMC: EN 61326-1:2013. Safety: IEC 61010-1:2001,

IEC 61010-2-081:2001

• ISQ Series standards: EMC: EN 61326-1:2013. Safety: IEC 61010-1:2010 (ed. 3); IEC 61010-2-081:2015 (ed.

2); IEC 61010-2-010:2014 (ed. 3); IECEE CB SCHEME CERT NO. DE 3-30000

• TSQ 8000 Evo and TSQ Duo standards: EMC: EN 61326-1:2013. Safety: IEC 61010-1:2010 (ed. 3); IEC

61010-2-081:2015 (ed. 2); IEC 61010-2-010:2014 (ed. 3); IECEE CB SCHEME CERT NO. DE 3-30034

Low Voltage Safety Compliance

This device complies with Low Voltage Directive 2011/95/EC.

FCC Compliance Statement

Notice on Lifting and Handling of

Thermo Scientific Instruments

For your safety, and in compliance with international regulations, the physical handling of this Thermo Fisher Scientific

instrument requires a team effort to lift and/or move the instrument. This instrument is too heavy and/or bulky for one

person alone to handle safely.

Notice on the Proper Use of

Thermo Scientific Instruments

In compliance with international regulations: Use of this instrument in a manner not specified by Thermo Fisher

Scientific could impair any protection provided by the instrument.

Notice on the Susceptibility

to Electromagnetic Transmissions

Your instrument is designed to work in a controlled electromagnetic environment. Do not use radio frequency

transmitters, such as mobile phones, in close proximity to the instrument.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO

THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL

INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,

INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

CAUTION Read and understand the various precautionary notes, signs, and symbols

contained inside this manual pertaining to the safe use and operation of this product before

using the device.

For manufacturing location, see the label on the instrument.

WEEE Compliance

This product is required to comply with the European Union’s Waste Electrical & Electronic Equipment (WEEE)

Directive 2002/96/EC. It is marked with the following symbol:

Thermo Fisher Scientific has contracted with one or more recycling or disposal companies in each European Union

(EU) Member State, and these companies should dispose of or recycle this product. See www.thermoscientific.com/

rohsweee for further information on Thermo Fisher Scientific’s compliance with these Directives and the recyclers in

your country.

WEEE Konformität

Dieses Produkt muss die EU Waste Electrical & Electronic Equipment (WEEE) Richtlinie 2002/96/EC erfüllen.

Das Produkt ist durch folgendes Symbol gekennzeichnet:

Thermo Fisher Scientific hat Vereinbarungen mit Verwertungs-/Entsorgungsfirmen in allen EU-Mitgliedsstaaten

getroffen, damit dieses Produkt durch diese Firmen wiederverwertet oder entsorgt werden kann. Mehr Information

über die Einhaltung dieser Anweisungen durch Thermo Fisher Scientific, über die Verwerter, und weitere Hinweise,

die nützlich sind, um die Produkte zu identifizieren, die unter diese RoHS Anweisung fallen, finden sie unter

www.thermoscientific.com/rohsweee.

Conformité DEEE

Ce produit doit être conforme à la directive européenne (2002/96/EC) des Déchets d'Equipements Electriques et

Electroniques (DEEE). Il est marqué par le symbole suivant:

Thermo Fisher Scientific s'est associé avec une ou plusieurs compagnies de recyclage dans chaque état membre de

l’union européenne et ce produit devrait être collecté ou recyclé par celles-ci. Davantage d'informations sur la

conformité de Thermo Fisher Scientific à ces directives, les recycleurs dans votre pays et les informations sur les

produits Thermo Fisher Scientific qui peuvent aider la détection des substances sujettes à la directive RoHS sont

disponibles sur www.thermoscientific.com/rohsweee.

Thermo Scientific TSQ Duo Spare Parts Guide ix

P

Preface

This guide contains information about ordering spare parts for your Thermo Scientific™ TSQ

Duo mass spectrometer.

Contents

•About Your System

•Related Documentation

•System Requirements

•Safety and Special Notices

•Hydrogen Safety Precautions

•Hazardous Substances Precautions

•Contacting Us

Preface

About Your System

xTSQ Duo Spare Parts Guide Thermo Scientific

About Your System

Thermo Scientific systems provide the highest caliber gas chromatography/mass spectrometry

(GC/MS) instrumentation available on today’s market.

GC/MS represents a combination of two powerful analytical techniques: GC, which acts as a

separation technique, and MS, which acts as a detection technique. Complex mixtures of

individual compounds can be injected into the GC, either manually or by an autosampler and

then separated for presentation to the MS. The MS will generate a mass spectrum of the GC

eluate and its components. The mass spectrum can then be used for qualitative identification

as well as accurate and precise quantification of the individual compounds present in the

sample.

A triple-quadrupole GC/MS/MS system provides the extra selectivity required for trace

analysis of compounds in complex matrices.

Related Documentation

The TSQ Duo system includes Help and these manuals as PDF files:

•TSQ Duo Preinstallation Guide, PN 1R120587-0001

•TSQ Duo User Guide, PN 1R120587-0002

•TSQ Duo Hardware Manual, PN 1R120587-0003

•TSQ Duo Spare Parts Guide, PN 1R120587-0004

•TSQ Duo AutoSRM User Guide, PN 1R120587-0005

To view product manuals

On the desktop go to Manuals > TSQ Duo.

To open Help

• From the TSQ Series instrument control software window, choose Help.

• If available for a specific window or dialog box, click Help or press the F1 key for

information about setting parameters.

For more information, visit www.thermoscientific.com.

WARNING Thermo Scientific systems operate safely and reliably under carefully

controlled environmental conditions. If the equipment is used in a manner not specified

by the manufacturer, the protections provided by the equipment might be impaired. If

you maintain a system outside the specifications listed in this guide, failures of many

types, including personal injury or death, might occur. The repair of instrument failures

caused by operation in a manner not specified by the manufacturer is specifically excluded

from the standard warranty and service contract coverage.

Preface

System Requirements

Thermo Scientific TSQ Duo Spare Parts Guide xi

System Requirements

Your data system must meet these minimum requirements.

Safety and Special Notices

Make sure you

follow the precautionary statements presented in this guide. The safety and other special

notices appear in boxes.

Special Notices

Special notices include the following:

System Requirements

Hardware • 4.6 GHz processor with 16GB RAM

•DVD/CD-ROM drive

• Video card and monitor capable of 1680 ×1050 resolution

• 1000 GB hard drive

• Quad core processor

Software • Microsoft™ Windows™ 7 SP1 Operating System (64-bit)

• Thermo Foundation1

• Thermo Scientific™ Dionex™ Chromeleon™ 7 (release 7.2 SR3 MUa

or later)2

1Check release notes for compatibility with TSQ Series instrument control software.

2Check release notes for compatibility with Thermo Foundation and TSQ Series instrument control software.

IMPORTANT Highlights information necessary to prevent damage to software, loss of

data, or invalid test results; or might contain information that is critical for optimal

performance of the system.

Note Highlights information of general interest.

Tip Highlights helpful information that can make a task easier.

Preface

Safety and Special Notices

xii TSQ Duo Spare Parts Guide Thermo Scientific

Safety Symbols and Signal Words

All safety symbols are followed by WARNING or CAUTION, which indicates the degree of risk

for personal injury, instrument damage, or both. Cautions and warnings are following by a

descriptor. A WARNING is intended to prevent improper actions that could cause personal

injury. A CAUTION is intended to prevent improper actions that might cause personal injury

or instrument damage. You can find the following safety symbols on your instrument or in

this guide.

Symbol Descriptor

BIOHAZARD: Indicates that a biohazard will, could, or might occur.

BURN HAZARD: Alerts you to the presence of a hot surface that could or

might cause burn injuries.

ELECTRICAL SHOCK HAZARD: Indicates that an electrical shock could or

might occur.

FIRE HAZARD: Indicates a risk of fire or flammability could or might occur.

FLAMMABLE GAS HAZARD: Alerts you to gases that are compressed,

liquefied or dissolved under pressure and can ignite on contact with an

ignition source. This symbol indicates this risk could or might cause physical

injury.

GLOVES REQUIRED: Indicates that you must wear gloves when performing

a task or physical injury could or might occur.

HAND AND CHEMICAL HAZARD: Indicates that chemical damage or

physical injury could or might occur.

INSTRUMENT DAMAGE: Indicates that damage to the instrument or

component might occur. This damage might not be covered under the

standard warranty.

LIFTING HAZARD: Indicates that a physical injury could or might occur if

two or more people do not lift an object.

Preface

Hydrogen Safety Precautions

Thermo Scientific TSQ Duo Spare Parts Guide xiii

Hydrogen Safety Precautions

Hydrogen is a colorless, odorless, highly flammable gas with the molecular formula H2 and an

atomic weight of 1.00794, making it the lightest element. Hydrogen gas presents a hazard as

it is combustible over a wide range of concentrations: at ambient temperature and pressure,

this ranges from about 4% to 74.2% by volume.

Hydrogen has a flash point of - 423 °F (- 253 °C) and an auto-ignition temperature of

1,040 °F (560 °C). It has a very low ignition energy and the highest burning velocity of any

gas. If hydrogen is allowed to expand rapidly from high pressure, it can self-ignite. Hydrogen

burns with a flame that can be invisible in bright light.

Before you begin using hydrogen, you should conduct a risk assessment based on the quantity

of hydrogen to be used and the conditions of your laboratory. You should ask yourself:

MATERIAL AND EYE HAZARD: Indicates that eye damage could or might

occur.

RADIOACTIVE: Indicates that exposure to radioactive material could or

might occur.

READ MANUAL: Alerts you to carefully read your instrument’s

documentation to ensure your safety and the instrument’s operational

ability. Failing to carefully read the documentation could or might put you at

risk for a physical injury.

TOXIC SUBSTANCES HAZARD: Indicates that exposure to a toxic substance

could occur and that exposure could or might cause personal injury or death.

For the prevention of personal injury, this general warning symbol precedes

the WARNING safety alert word and meets the ISO 3864-2 standard. In the

vocabulary of ANSI Z535 signs, this symbol indicates a possible personal

injury hazard exists if the instrument is improperly used or if unsafe actions

occur. This symbol and another appropriate safety symbol alerts you to an

imminent or potential hazard that could cause personal injury.

Symbol Descriptor

WARNING FIRE HAZARD: The use of hydrogen as a carrier gas is dangerous. Hydrogen

is potentially explosive and must be used with extreme care. Any use of hydrogen gas must

be reviewed by appropriate health and safety staff and all installations of hydrogen systems

must be performed to applicable codes and standards. Thermo Fisher Scientific assumes

no liability for the improper use of hydrogen as a carrier gas.

Preface

Hydrogen Safety Precautions

xiv TSQ Duo Spare Parts Guide Thermo Scientific

“What hydrogen hazards associated with this project are most likely to occur?”

“What hydrogen hazards associated with this project have the potential to result in the

worst consequences?”

• Try to reduce or eliminate the higher risks by using the proper ventilation to remove

hydrogen gas before an ignitable concentration can accumulate. You should also consider

purging the hydrogen to further reduce hazards and ensure anyone who will be working

with hydrogen has basic hydrogen safety training.

• As with laboratory safety in general, be sure to wear safety glasses, laboratory coats,

gloves, etc. Typically there are no specific requirements for gaseous hydrogen, other than

eye protection when working with a compressed gas. If working with liquid (cryogenic)

hydrogen, insulated gloves and protective shoes should be worn in addition to eye

protection.

• You should post “No Smoking” and “No Open Flames” signs to identify hydrogen

sources and cylinders. Maintain, inspect and leak-test all hydrogen sources regularly.

• All hydrogen shutoff valves should be clearly marked and permanent hydrogen piping

should be labeled as such at the supply or discharge point and at regular intervals along its

length. Where hydrogen gas piping passes through a wall, the piping should be labeled on

both sides of the wall.

• There should also be contingency plans in place should an incident occur.

• The site emergency response team, as well as the local fire department, should know the

location of all hydrogen storage tanks.

Preface

Hydrogen Safety Precautions

Thermo Scientific TSQ Duo Spare Parts Guide xv

Using Hydrogen with TSQ Duo

To use hydrogen with the TSQ Duo, you must always shut off the GC carrier gas before

venting or turning off the TSQ Duo. There are three hydrogen safety screws on the TSQ Duo

that must be in place. These are attached to your instrument at the factory.

Before powering on the TSQ Duo system, ensure that:

• All the covers and panels of the TSQ Duo system are firmly attached.

• The vent valve is tightly closed if you vented the system.

• All fittings, ferrules, and o-rings are sealed.

Hydrogen Connection Guidelines

Use the following guidelines to safely connect hydrogen to your system:

•Piping—Hydrogen must be delivered to equipment using appropriate piping and be

done in such a way as to pose essentially no hazard to end-users. Piping systems for the

delivery of hydrogen should be designed and installed by a person qualified by specific

training and experience with hydrogen piping systems.

Figure 1. Hydrogen Safety Screws on the TSQ Duo

Right Top Cover

Screw

Front Panel

Screw

Left Top

Cover Screw

Preface

Hydrogen Safety Precautions

xvi TSQ Duo Spare Parts Guide Thermo Scientific

Stainless steel is usually recommended because it is a safe, cost-effective material. Piping

of black iron or copper must not be used, as the pipe can become brittle with age.

Elastomeric/plastic tubing of various plastics and polymers should not be used, unless the

tubing is approved for use with hydrogen. If elastomeric/plastic tubing is used for

hydrogen gas delivery, the tubing should be tested for hydrogen permeability to minimize

leakage.

The hydrogen piping system must be flexible enough to endure routine thermal

expansion and contraction. The system should also include considerations for the most

severe condition of temperature and pressure expected during service. Piping and

supports must be able to withstand static loading introduced by such things as ice and

snow; and dynamic loading from high wind and earthquake.

Caution should be used if burying hydrogen piping. Proper controls should be used to

protect against damage and corrosion, and also to prevent Hydrogen from entering a

building if there is any leakage.

•Fittings—All fittings must be of the proper type approved or designed for use with

hydrogen gas. Use as few fittings as possible to minimize the potential for leaks. After

installation, ensure that leak testing is carried out prior to system use, and on a regular

basis.

There must be no PTFE tape or other things like plumber's putty used to enhance a seal, as

this actually is a detriment to a good seal. Ideally the best installation would use stainless

steel tubing with appropriate gas-tight fittings.

Welding is usually preferred for joints in hydrogen piping systems since welding provides

a better connection and reduces the potential for leaks compared to mechanical fittings.

Soft solder joints are not permitted for hydrogen systems (due to the low melting point of

soft solder and its potential for brittle failure at cryogenic temperatures). Brazed joints are

permitted, but such joints should be protected against the possibility of external fire.

Tubing connections should be clamped to barbed or press-fit type connections. Hose

clamps or jubilee clamps must not be used.

•Valves—All valves must be suitable for hydrogen service and for the specific operating

conditions. Valves, including regulators, must not be used for hydrogen, unless they are

designed and identified for such a use. Ball valves are often chosen because of their

superior leak tightness through the valve seat. Pneumatic operators are usually chosen for

remotely operated valves so that potential ignition sources (electricity) are remote from

the valve.

Manual shutoff valves should be provided near each point of use, within immediate reach.

If a hydrogen cylinder or hydrogen generation system is located within immediate reach,

a separate point-of-use shutoff valve is usually not necessary.

Line regulators that have their source away from the point of use should have a manual

shutoff valve near the point of use.

Preface

Hydrogen Safety Precautions

Thermo Scientific TSQ Duo Spare Parts Guide xvii

An emergency gas shutoff device in an accessible location outside the use area should be

provided in addition to the manual point-of-use valve in each educational and

instructional laboratory space that has a piped gas supply system.

If necessary, the piping system should have uninterruptible pressure relief. The pressure

relief system should be designed to provide a discharge rate sufficient to avoid further

pressure increase and should vent to a safe location outside or to a ventilation system

exhaust.

Purchasing Hydrogen

Use the following guidelines when purchasing hydrogen:

•Hydrogen Generator—Because it minimizes the amount of hydrogen present and

reduces the degree of hazard, a hydrogen generator (also called an electrolyzer) is the safest

way to purchase hydrogen in the quantity used in GC/MS.

However, to minimize the degree of hazard, the hydrogen generator must only be

operated in a non-explosive environment because hydrogen buildup can be ignitable.

This means that your ventilation system for the room or lab hood must maintain an air

exchange rate that is at least two orders of magnitude greater than the maximum

hydrogen production rate of the hydrogen generator. Be sure to follow the manufacturers'

directions about proper use and maintenance of the regulator.

To prevent the possibility of releasing hydrogen, the hydrogen generator should be set to

shut down if:

– There is a loss of flow to the ventilation system

– A hydrogen detector alarms at 25% of the lower flammable limit of hydrogen in air.

The oxygen exhausted by the electrolyzer should be vented to the outside as well.

•Hydrogen Cylinder—Hydrogen can be delivered in standard laboratory gas bottles or

cylinders. These cylinders have a limited amount of hydrogen in them and are a safe way

to transport and store hydrogen. However, compressed hydrogen gas cylinders, like all

compressed gas cylinders, must be secured in an upright position, ideally with a

non-combustible chain or cable. If the cylinder falls over, the valve can be knocked off

and the pressurized cylinder can take off like a rocket, which leads to the release of

hydrogen and possibly an explosion, severe injury, or death. Never crack a hydrogen

cylinder valve to remove dust or dirt from fittings prior to attaching a regulator, as there is

a risk of self-ignition.

Properly Storing Hydrogen

Storing and handling compressed hydrogen gas and cryogenic liquid hydrogen present

potential health and safety hazards. Using proper storage and handling techniques is essential

to maintaining a safe work environment.

Preface

Hydrogen Safety Precautions

xviii TSQ Duo Spare Parts Guide Thermo Scientific

Use the following guidelines when storing hydrogen:

• Store spare hydrogen gas cylinders outside and away from doors, windows, building air

intake vents, structures, and vehicle routes. This precaution applies when the hydrogen is

or is not in use. Indoor storage of spare hydrogen cylinders has special requirements,

which is beyond the scope of this document. Documentation for each vessel should

include a description of the vessel, a list of available drawings or other documents, the

most recent inspection results, and the responsible person's name.

• Prevent spare cylinders from toppling by wrapping them with chains. The chains should

also be protected against corrosion and excessive heat.

• Separate spare hydrogen cylinders from oxidizing gases (such as oxygen) with a 5 ft

(1.5 m) tall fire barrier with a half-hour fire rating or place the cylinders at least 20 ft

(6 m) apart.

• When moving hydrogen cylinders:

– Remove the regulator and replace the cylinder valve cap before moving.

– Move cylinders on cylinder carts or with other appropriate transport devices.

– Never roll or drop a cylinder and never lift a cylinder by its protective cap.

• Bulk hydrogen systems include either gaseous or liquid hydrogen in fixed installations; in

some gas systems a semi-permanent trailer (tube trailer) can be used. Storage vessels for

compressed hydrogen gas or liquid hydrogen should be designed, constructed, tested, and

maintained in accordance with applicable codes and standards. Bulk hydrogen systems

represent a level of complexity again which is beyond the scope of this document;

however some general guidelines are provided.

• The bulk hydrogen storage system should not be located beneath electric power lines,

close to other flammable gases/liquids, or close to public areas. It should be readily

accessible to authorized personnel and delivery equipment, but protected from physical

damage or tampering.

• As liquid hydrogen systems also have a cryogenic hazard, additional safety considerations

for the use of cryogenic liquids might be necessary.

Preface

Hydrogen Safety Precautions

Thermo Scientific TSQ Duo Spare Parts Guide xix

Hydrogen Safety Codes, Standards and References

The following list of safety codes, standards and references is in no way an exhaustive list. In

fact, there might be federal, state or local codes that apply to your specific location. Check

with all appropriate agencies with jurisdiction before installing or using a hydrogen system.

• Air Products Safetygram #4 Gaseous Hydrogen

• ANSI/AIAA standard for hydrogen safety guidelines is AIAA G-095-2004, Guide to

Safety of Hydrogen and Hydrogen Systems

• ASME B31.1, Power Piping Code

• ASME B31.3, Process Piping Code

• ASME B31.8, Gas Transmission and Distribution Systems

• BCGA Code Of Practice CP4 Industrial Gas Cylinder Manifolds and Gas Distribution

Pipework

• BCGA Code Of Practice CP33 The Bulk Storage of Gaseous Hydrogen at Users'

Premises

• CGA G-5, Hydrogen

• CGA G-5.4, Standard for Hydrogen Piping Systems at Consumer Locations

• CGA G-5.5, Hydrogen Vent Systems

• CGA G-5.6, Hydrogen Pipeline Systems

• CGA G-5.8, High Pressure Hydrogen Piping Systems at Consumer Locations.

• FM Global Property Loss Prevention Data Sheets 7-50: Compressed Gases in Cylinders

• FM Global Property Loss Prevention Data Sheets 7-91: Hydrogen

• IGC Doc 121/04/E, Hydrogen Transportation Pipelines System Design Features

• NASA

• NSS 1740.16 Safety Standard For Hydrogen And Hydrogen Systems Guidelines for

Hydrogen System Design, Materials Selection, Operations, Storage, and Transportation

• NFPA 52, Vehicular Fuel Systems Code

• NFPA 55, Standard for the Storage, Use, and Handling of Compressed Gases and

Cryogenic Fluids in Portable and Stationary Containers, Cylinders, and Tanks, 2005

Edition

• NFPA 68, Standard on Explosion Protection by Deflagration Venting

• NFPA 70, National Electrical Code

Preface

Hazardous Substances Precautions

xx TSQ Duo Spare Parts Guide Thermo Scientific

• NFPA 497, Recommended Practice for the Classification of Flammable Liquids, Gases,

or Vapors and of Hazardous (Classified) Locations for Electrical Installations in Chemical

Process Areas

• NFPA 13, Standard for the Installation of Sprinkler Systems

• NFPA 45, Standard on Fire Protection for Laboratories Using Chemicals

• NFPA 55, Standard for the Storage, Use, and Handling of Compressed Gases and

Cryogenic Fluids in Portable and Stationary Containers, Cylinders, and Tanks

• NFPA 68, 2007 Standard on Explosion Protection by Deflagration Venting

• NFPA 69, Standard on Explosion Prevention Systems

• NFPA 91, Standard for Exhaust Systems for Air Conveying of Vapors

• NFPA 255, Standard Method of Test of Surface Burning Characteristics of Building

Materials

• OSHA 29CFR1910.103 1910.103 Hydrogen

Hazardous Substances Precautions

Biological Hazard Warning Note

In laboratories where samples with potential biological hazards are handled, the user must

label any equipment or parts which might become contaminated with biohazardous material.

The appropriate warning labels are included with the shipment of the instrument. It is the

user’s responsibility to label the relevant parts of the equipment.

When working with biohazardous materials, you are responsible for fulfilling the following

mandatory requirements:

• Providing instructions on how to safely handle biohazardous material.

• Training operators to be aware of potential hazards.

WARNING Before using hazardous substances (toxic, harmful, and so on), please read the

hazard indications and information reported in the applicable Material Safety Data Sheet

(MSDS). Use personal protective equipment according to the safety requirements.

Preface

Contacting Us

Thermo Scientific TSQ Duo Spare Parts Guide xxi

• Providing personal protective equipment.

• Providing instructions for what to do if operators are exposed to aerosols or vapors during

normal operation (within the intended use of the equipment) or in case of single fault

situations such as a broken vial. The protective measures must consider potential contact

with the skin, mouth, nose (respiratory organs), and eyes.

• Providing instructions for decontamination and safe disposal of relevant parts.

Venting Toxic Gases

When analyzing toxic compounds, be aware that during the normal operation of the GC

some of the sample might be vented outside the instrument through the split and purge flow

vents; therefore, be sure to vent the exhaust gases to a fume hood. Consult local

environmental and safety regulations for instructions in exhausting fumes from your system.

Contacting Us

There are several ways to contact Thermo Fisher Scientific for the information you need.

To find out more about our products

Go to www.thermoscientific.com/en/products/mass-spectrometry.html for information

about our products.

To get local contact information for sales or service

Go to www.thermoscientific.com/en/support-landing/support.html.

To suggest changes to documentation or to Help

• Fill out a reader survey online at www.surveymonkey.com/s/PQM6P62.

• Send an e-mail message to the Technical Publications Editor at

techpubs-austin@thermofisher.com.

WARNING The user or operator is responsible for the safe handling of hazardous

chemicals or biological compounds including (but not limited to) bacterial or viral

samples and the associated waste, according to international and local regulations.

Thermo Scientific TSQ Duo Spare Parts Guide 1

Ordering Spare Parts

This chapter contains illustrations and part numbers for all of the replaceable components in

the TSQ Duo mass spectrometer. Refer to the TSQ Duo Hardware Manual for information

about installing these components in your instrument. Any component with a part number

can be ordered from us. Components without a part number are not available.

Contents

•Identifying A Part

•Calibration Gas Components

•Collision Gas Components

•Column Components

•Fan and Filter Components

•Ion Source Components

•Electron Multiplier Components

•Dual Filament Components

•Analyzer Components

•Board Components

•Power Module Components

•Manifold Components

•Manifold Components

•Cover Components

•TSQ Duo Tools

•Pump Components

•Upgrade Equipment

1 Ordering Spare Parts

Identifying A Part

2TSQ Duo Spare Parts Guide Thermo Scientific

Identifying A Part

To identify a part, you need to know where it was located on the TSQ Duo mass spectrometer

or the part’s relationship to a particular functionality of the instrument. Use the categories in

the table below to find a location or functionality that relates to the component you need. For

example, if you know the part is related to the calibration gas, look in the Calibration Gas

Components category. Then refer to the illustrations in that category to visually identify that

particular part.

CI

IMPORTANT Only components with a part number are available for purchase. The part

you are looking for may be shown in an illustration, but if it does not list a part number, it

is not available.

Table 1. Parts That Can Be Reordered (Sheet 1 of 10)

Component Thermo Scientific

Part Number Category

Single Flow Calibration Gas Module 1R119246-0004

Calibration Gas Components

Dual Flow Calibration Gas Module 1R119246-0003

Calibrant Reservoir Kit 1R120433-0001

Transfer Line 1R120402-0001

O-ring for Transfer Line 1R3814-223

Screws for Transfer Line 1R76913-0410

Gas Mixing Chamber Kit 1R120574-KIT

Gas Mixing Chamber (1) 1R120574-0054

Source Gas Tube (2 in Kit) 1R120574-0055 (PN orders 1)

M3 × 8 mm Screw (2 in Kit) 1R76913-0308

Calibration Gas Line 1R120438-0010

Delivery Tube 1R120404-1202

FC-43 Calibration Compound 50010-30059

Collision Gas Module 1R119246-0005

Collision Gas Components

Tube Fitting, Collision Gas Module to Manifold 1R76256-0045

Collision Gas Tube 1R120557-0030

Tee, 1/8 in. 1R76256-0126

1 Ordering Spare Parts

Identifying A Part

Thermo Scientific TSQ Duo Spare Parts Guide 3

Graphite Vespel™ Ferrule for 0.25 mm Columns

(pkg of 10)

29033496

Column Components

Graphite Vespel™ Ferrule for 0.18 mm Columns

(pkg of 10)

1R76458-2016

Graphite Vespel Ferrule for 0.32 mm Columns

(pkg of 10)

1R76458-2019

Graphite Vespel Ferrule for 0.53 mm Columns

(pkg of 10)

1R76458-2020

2-hole Graphite Vespel Ferrule for <0.32mm

Column (pkg of 10)

1R76458-2018

No-Hole Graphite Vespel Ferrule (pkg of 10) 1R76458-2009

SilTite™ Ferrule for 0.10-0.25mm ID Column

(pkg of 10)

1R76458-2000

SilTite Ferrule for 0.32mm Columns (pkg10) 1R76458-2024

SilTite Ferrule for 0.53mm Columns (pkg10) 1R76458-2026

Graphite Vespel Ferrule for 0.1–0.25 mm Columns

for use with Spring-loaded Transfer Line Nut

(pkg of 10)

290VA191

Spring Loaded Transferline Nut 1R120434-0100

Nut for SilTite Ferrules (pkg of 5) 1R76458-2001

Nickel-Coated Nut for Graphite Vespel Ferrule

(pkg of 5)

1R76256-0060

Air Deflector 1R120552-0010

Fan and Filter Components

Front Wire Mesh Filter 1R120554-0010

Left Rear Wire Mesh Filter 1R120554-0020

Fan Plenum 1R120553-0020

Fan Filter (Plastic) 1R76475-5005

Turbo Cooling Fan 1R120443-0003

Tra p O 2/H

2O, Hydrocarbon A0950-01600

Replacement Trap A0950-R1600

Chassis Cooling Fan 1R120443-0001

Nylon Rivet for Cooling Fan 1R3326-5000

Table 1. Parts That Can Be Reordered, continued (Sheet 2 of 10)

Component Thermo Scientific

Part Number Category

1 Ordering Spare Parts

Identifying A Part

4TSQ Duo Spare Parts Guide Thermo Scientific

Source Heater Block 1R120404-1311

Ion Source Components

Repeller Plate 1R120404-1312

Source-Repeller Thumbscrew 1R120564-0004

Thumbscrew-Repeller Spacer 1RTSLI053A

Lens/Source Heater 1R120404-1330

Lens Heater Block 1R120404-1323

Lock Washer for Lens Heater Block 1R76902-0004

Screw for Lens Heater Block 1R76913-0306

Lens Heater Block Grounding Strap 1R120404-2010

Lens Plate and Springs 1R120404-1750

Copper Washer for Lens Plate 1R76483-5003

Screw for Lens Plate 1R76913-0306

Source to Ion Guide Spacer 1R120404-1340

Insulating Spacer 1RTSLI050A

EI Ion Source Cartridge (Low Activity), which

includes:

1R120404-4100

• Ion Cartridge Sleeve 1R120404-1105

• EI Ion Volume (Low Activity) 1R120404-4111

• Ion Volume-Repeller Insulator 1R120404-1114

• Repeller (Low Activity) 1R120404-1161

• Ion Volume Locking Ring 1R120404-1118

• Repeller Spring (pkg of 5) 1R76485-1000K

• Repeller Nut 1R120404-1120

• Lens 3/RF Lens 1R120574-0103

• Lens 1 1R120574-0139

• Lens 2 1R120404-1140

Table 1. Parts That Can Be Reordered, continued (Sheet 3 of 10)

Component Thermo Scientific

Part Number Category

1 Ordering Spare Parts

Identifying A Part

Thermo Scientific TSQ Duo Spare Parts Guide 5

Electron Multiplier Plate 1R120405-1000

Electron Multiplier

Components

Electron Multiplier 1R76022-14633

Large Feedthrough 1R120610-0040

O-ring for Large Feedthrough 1R3814-113

Screw for Large Feedthrough 1R76913-0410

Anode Feedthrough 1R120610-0050

Anode Feedthrough Assembly Kit, includes: 1R120480-0012

Anode Feedthrough Assembly 1R120610-0050

O-ring for Anode Feedthrough 1R3814-110

Standoff for Anode Feedthrough 1R77005-3010

Screw for Anode Feedthrough (pkg of 4) 1R76913-0306

Detector Assembly (Dynode, Electron Multiplier,

and Lead Set)

1R120379-0001

Dual Filament 1R120404-1940

Dual Filament ComponentsFilament Retaining Spring Kit 1R120404-1405

Screw for Filament Retaining Spring 1R76913-0305

Table 1. Parts That Can Be Reordered, continued (Sheet 4 of 10)

Component Thermo Scientific

Part Number Category

1 Ordering Spare Parts

Identifying A Part

6TSQ Duo Spare Parts Guide Thermo Scientific

Ion Guide 1R120404-3100

Analyzer Components

Ion-Guide Clamp 1R120404-3214

Screws for Ion-Guide Clamp 1R76913-0316

Ion-Guide Wire Set 1R120480-0004

Analyzer Tray with Source Block and Ion Guide 1R120542-2535

Quad 1 Wire Set 1R120480-0005

Quad 3 Wire Set 1R120480-0006

Q1 Quad Assembly 1R120542-2560

Collision Cell Assembly 1R120574-0161

Q3 Quad Assembly 1R120542-2570

Q1 Exit Lens Wire 1R120542-2515

Q3 Entrance Lens Wire 1R120542-2514

Q3 Exit Lens Wire 1R120542-2513

Q3 Exit Lens Assembly 1R120542-2536

Wire Routing Clip 1R120542-2511

Q1 Entrance Lens Endcap 1R120404-3211

Q1 Entrance Lens Assembly 1R120404-3212

Table 1. Parts That Can Be Reordered, continued (Sheet 5 of 10)

Component Thermo Scientific

Part Number Category

1 Ordering Spare Parts

Identifying A Part

Thermo Scientific TSQ Duo Spare Parts Guide 7

Distribution Board 1R120485-0810

Board Components

Screw for Distribution Board 1R76913-0310

Rear RF Board/Rod Driver Kit 1R120501-1002

Front RF Board 1R120485-A060

Rear RF Board 1R120485-A065

Standoff for Rod Driver Board 1R76350-5003

Screw for Rod Driver Board 1R76913-0306

Front Rod Driver Board (50V) 1R120485-0415

Rear Rod Driver Board (75V) 1R120485-0420

Lens Driver Board 1R120485-A110

Controller Interface Board 1R120485-0020

Source Interface Board 1R120485-0210

Electrometer Board 1R120354-0500

Screw (6mm) for Electrometer Board 1R76913-0306

Screw (16mm) for Electrometer Board 1R76913-0316

Heat Shield for Source Interface Board 1R120404-2110

Screw for Heat Shield 1R76913-0410

Electrometer Shield 1R120368-0010

Screw for Electrometer Shield 1R76913-0306

20-pin Feedthrough 1R120610-0020

O-ring for 20-Pin Feedthrough 1R3814-123

Screw for 20-Pin Feedthrough 1R76913-0410

4-pin Feedthrough 1R120610-0030

O-ring for 4-Pin Feedthrough 1R3814-127

Screw for 4-Pin Feedthrough 1R76913-0410

Fan, 5 VDC 1R124170-5003

Fan, 60 mm 1R120443-0002

PC Communication Board 1R120354-0010

Table 1. Parts That Can Be Reordered, continued (Sheet 6 of 10)

Component Thermo Scientific

Part Number Category

1 Ordering Spare Parts

Identifying A Part

8TSQ Duo Spare Parts Guide Thermo Scientific

Power Module 1R120544-0002

Power Module Components

Dynode and Multiplier Power Supply and Cables

(EI only)

1R120361-0003

Manifold Door Hinge 1R120565-0001

Manifold Components

Front Manifold Plate 1R120403-0002

Large Top Glass Cover 1R120542-3000

Small Top Glass Cover 1R120401-3000

O-ring, Large for Back Glass 1R3814-376

Manifold O-ring 1R3815-360

Screw for Front Plate (M4 × 20 mm) 1R176913-0420

Vent Valve Knob 1R120403-0104

O-ring for Vent Valve Knob 1R3814-110

Source Insertion Guide 1R120564-0001

Front Door Alignment Pin 1R120564-0003

Back Tray Alignment Pin 1R120403-0103

Back Manifold Plate 1R120403-1001

Magnet Yoke 1R120564-0002

Source Magnet 1R70001-98195

Right Side Panel 1R120541-0200

Cover Components

Left Hand Front Panel 1R120541-0003

Left Hand Sub Panel 1R120541-0500

Top Cover Panel 1R120541-0001

TSQ Duo Front Cover 1R120548-0200

Front Door Hinge 1R3434-5000

Front Door Hinge Support 1R120445-0001

Front Door Latch 1R76483-3000

Rubber Spacers for Right Side Panel 1R3666-0207

Chassis Foot 1R3666-0208

Table 1. Parts That Can Be Reordered, continued (Sheet 7 of 10)

Component Thermo Scientific

Part Number Category

1 Ordering Spare Parts

Identifying A Part

Thermo Scientific TSQ Duo Spare Parts Guide 9

Bushing in the Source Exchange Tool 1R120406-2203

TSQ Duo Tools

Seal in the Source Exchange Tool 1R120406-2204

Clip in the Source Exchange Tool 1R76483-2102

Source Exchange Tool 1R120406-2000

MS Toolkit, which includes: 1R120467-0001

Source Removal Tool (Small) 1R120406-2250

Column Measurement Tool 1R120461-0010

T10 Torxhead Key 1R3812-5T10

T20 Torxhead Key 1R3812-5T20

T30 Torxhead Key 1R3812-5T30

Forceps, 8 in. 1R76360-0008

Wrench, Open-Ended, 1/4-in., 5/16-in. 1R76360-0109

Wrench, Open-Ended, 3/8 in., 7/16-in. 1R76360-0108

Turbomolecular Pump 1R119268-0002

Pump Components

Rough Pump (RV3) 1R76505-3007

Vacuum Hose (Order 10 ft) 1R76505-0625

Claw Clamp 1R76505-0017

Centering Ring 1R76505-2001

Convectron Gauge A0105-00501

Oil Mist Filter 1R76505-0036

Foreline Adapter 1R119244-0025

Vacuum Pump Oil A0301-15101

Hydrogen Ion Volume 1R120404-4115

Upgrade Equipment

Ion Gauge Upgrade Kit 1R120560-0020

Ion Gauge Mount 1R120416-0002

Ion Gauge Tube Shield 1R119605-0012

Ion Gauge O-ring 1R3814-116

Replacement Ion Gauge Tube A0105-06003

Dust Filter 1R120442-0005

Ion Gauge Board 1R120485-0120

Table 1. Parts That Can Be Reordered, continued (Sheet 8 of 10)

Component Thermo Scientific

Part Number Category

1 Ordering Spare Parts

Identifying A Part

10 TSQ Duo Spare Parts Guide Thermo Scientific

Crossover Cable 1R76396-0052

Cables

Ion Gauge Cable 1R119378-0063

Electrometer Cable 1R76396-0500

Transfer Line Cable 1R119378-0056

Single Flow Calibration Gas Module Cable 1R119378-0061

Roughing Pump Power Cable 1R76200-0250

Convectron Gauge Cable 1R119378-0067

CAT6 Connector 1R76322-0501

Collision Gas Cable 1R119378-0071

TSQ Duo Installation Kit 1R120459-0001

Other

TSQ Duo Specification Standards 1R120540-PERF

TSQ Series Instrument Control Software 1R120579-0031

Consumables Kit 1R120468-CONSUM

Aluminum Oxide 1R32000-60340

Cardinal Health CP100 Nitrile Cleanroom Gloves

(Recommended to avoid contaminating

instrument)

Fisher Scientific Catalog

Number

Gloves

Size X-Small (Case) 19-120-2947

Size Small (Case) 19-120-2947A

Size Medium (Case) 19-120-2947B

Size Large (Case) 19-120-2947C

Size X-Large (Case) 19-120-2947D

Table 1. Parts That Can Be Reordered, continued (Sheet 9 of 10)

Component Thermo Scientific

Part Number Category

1 Ordering Spare Parts

Identifying A Part

Thermo Scientific TSQ Duo Spare Parts Guide 11

TSQ Duo Screw Kit, which includes: 1R120480-0014

—

• M3 x 6 mm Screw (pkg of 10)

• M3 x 8 mm Screw (pkg of 10)

• M3 x 10 mm Screw (pkg of 5)

• M3 x 12 mm Screw (pkg of 5)

• M3 x 16 mm Screw (pkg of 5)

• M4 x 16 mm Screw (pkg of 5)

• M4 x 20 mm Screw (pkg of 10)

• M4 x 10 mm Screw (pkg of 10)

• M3 x 8 mm Screw for Hinges (pkg of 5)

• M4 x 8 mm Screw for Power Supply (pkg of 5)

• M3 Locking Nut for Front Door Latch (pkg of

2)

• M3 x 25mm Standoff for RF Board (pkg of 2)

* All of the screws in this table must be cleaned before you install them inside the vacuum manifold. See Cleaning Durable Components in

the TSQ Duo Hardware Manual for details.

Table 1. Parts That Can Be Reordered, continued (Sheet 10 of 10)

Component Thermo Scientific

Part Number Category

1 Ordering Spare Parts

Calibration Gas Components

12 TSQ Duo Spare Parts Guide Thermo Scientific

Calibration Gas Components

You can purchase the following calibration gas components for the TSQ Duo mass

spectrometer. Be sure to reference the component’s part number when placing an order with

your local Sales/Service Representative. See the TSQ Duo Hardware Manual for information

about installing these components or Ta b le 1 for a full list of available components.

The following calibration gas components can be replaced on your mass spectrometer.

•Tr a n s f e r L i n e

•Single Flow Calibration Gas Module

•Dual Flow Calibration Gas Module

•Calibrant Reservoir Kit

•Calibration Gas Line

•Gas Mixing Chamber

•FC-43 Calibration Compound

Figure 1. Replaceable Calibration Gas Components

Transfer Line

Gas Mixing

Chamber

Calibration

Gas Module

Calibrant

Reservoir Kit

Source Gas

Tubes

Calibration

Gas Line

1 Ordering Spare Parts

Calibration Gas Components

Thermo Scientific TSQ Duo Spare Parts Guide 13

Transfer Line Quantity: Each

Thermo Scientific Part Number 1R120402-0001

NOTE: To replace all the M4 x 10 mm screws on the transfer line, order two of PN 1R76913-0410. To replace the o-ring on the transfer line,

order PN 1R3814-223. PN 1R120402-0001 includes one o-ring initially.

O-Ring

1 Ordering Spare Parts

Calibration Gas Components

14 TSQ Duo Spare Parts Guide Thermo Scientific

Single Flow Calibration Gas Module Quantity: Each

Thermo Scientific Part Number 1R119246-0004

NOTE: To replace all the M4 x 10 mm screws on the calibration gas module, order two of PN 1R76913-0410.

Dual Flow Calibration Gas Module Quantity: Each

Thermo Scientific Part Number 1R119246-0003

NOTE: To replace all the M4 x 10 mm screws on the calibration controller, order two of PN 1R76913-0410.

1 Ordering Spare Parts

Calibration Gas Components

Thermo Scientific TSQ Duo Spare Parts Guide 15

Calibrant Reservoir Kit Quantity: Each

Thermo Scientific Part Number 1R120433-0001

Gas Mixing Chamber Quantity: Each

Thermo Scientific Part Number 1R120574-0054

NOTE: To replace all the M3 x 8 mm screws on the gas mixing chamber, order two of PN 1R76913-0308.

Note The Gas Mixing Chamber (PN 1R120574-0054), two Source Gas Tubes (PN 1R120574-0055), and two

M3 × 8 mm screws (PN 1R176913-0308) can be ordered as a kit. To purchase the Gas Mixing Chamber Kit, order

PN 1R120574-KIT.

Source Gas Tube Quantity: Each

Thermo Scientific Part Number 1R120574-0055

1 Ordering Spare Parts

Calibration Gas Components

16 TSQ Duo Spare Parts Guide Thermo Scientific

Calibration Gas Line Quantity: Each

Thermo Scientific Part Number 1R120438-0010

FC-43 Calibration Compound Quantity: Each

Thermo Scientific Part Number 50010-30059

1 Ordering Spare Parts

Collision Gas Components

Thermo Scientific TSQ Duo Spare Parts Guide 17

Collision Gas Components

You can purchase the following collision gas components for the TSQ Duo mass

spectrometer. Be sure to reference the component’s part number when placing an order with

your local Sales/Service Representative. See the TSQ Duo Hardware Manual for information

about installing these components or Ta b le 1 for a comprehensive list of available

components.

The following collision gas components can be replaced on your mass spectrometer.

•Collision Gas Module

•Tube Fitting, Collision Gas Module to Manifold

•Collision Gas Tube

•Tee , 1 / 8 i n .

Collision Gas Module Quantity: Each

Thermo Scientific Part Number 1R119246-0005

NOTE: This PN includes the module cable (PN 1R119378-0071), tubing (PN 1R120557-0030), and 1/8 in. tee (PN 1R76256-0126).

Tube Fitting, Collision Gas Module to Manifold Quantity: Each

Thermo Scientific Part Number 1R76256-0045

1 Ordering Spare Parts

Collision Gas Components

18 TSQ Duo Spare Parts Guide Thermo Scientific

Collision Gas Tube Quantity: Each

Thermo Scientific Part Number 1R120557-0030

Tee, 1/8 in. Quantity: Each

Thermo Scientific Part Number 1R76256-0126

1 Ordering Spare Parts

Column Components

Thermo Scientific TSQ Duo Spare Parts Guide 19

Column Components

You can purchase the following column components for the TSQ Duo mass spectrometer. Be

sure to reference the component’s part number when placing an order with your local

Sales/Service Representative. See the TSQ Duo Hardware Manual for information about

installing these components or Tab le 1 for a comprehensive list of available components.

The following column components can be replaced on your mass spectrometer.

•Graphite Vespel Ferrule for 0.25 mm Columns

•Graphite Vespel Ferrule for 0.18 mm Columns

•Graphite Vespel Ferrule for 0.32 mm Columns

•Graphite Vespel Ferrule for 0.53 mm Columns

•2-Hole Graphite Vespel Ferrule for <0.32mm Columns

•No-Hole Graphite Vespel Ferrule

•SilTite Ferrule for 0.25 mm Columns

•SilTite Ferrule for 0.32mm Columns

•SilTite Ferrule for 0.53mm Columns

•Graphite Ferrule for 0.1–0.25 mm Columns used with Spring-loaded

Tr a n s f e r L i n e Nu t

•Spring Loaded Transferline Nut

•Nickel-Coated Nut for Graphite Vespel Ferrules

•Nut for SilTite Ferrules

Note Visit www.thermo.com/columns for information about ordering a column.

Graphite Vespel Ferrule for 0.25 mm Columns Quantity: Pkg of 10

Thermo Scientific Part Number 29033496

1 Ordering Spare Parts

Column Components

20 TSQ Duo Spare Parts Guide Thermo Scientific

Graphite Vespel Ferrule for 0.18 mm Columns Quantity: Pkg of 10

Thermo Scientific Part Number 1R76458-2016

Graphite Vespel Ferrule for 0.32 mm Columns Quantity: Pkg of 10

Thermo Scientific Part Number 1R76458-2019

Graphite Vespel Ferrule for 0.53 mm Columns Quantity: Pkg of 10

Thermo Scientific Part Number 1R76458-2020

1 Ordering Spare Parts

Column Components

Thermo Scientific TSQ Duo Spare Parts Guide 21

2-Hole Graphite Vespel Ferrule for <0.32mm Columns Quantity: Pkg of 10

Thermo Scientific Part Number 1R76458-2018

No-Hole Graphite Vespel Ferrule Quantity: Pkg of 10

Thermo Scientific Part Number 1R76458-2009

SilTite Ferrule for 0.25 mm Columns Quantity: Pkg of 10

Thermo Scientific Part Number 1R76458-2000

1 Ordering Spare Parts

Column Components

22 TSQ Duo Spare Parts Guide Thermo Scientific

SilTite Ferrule for 0.32mm Columns Quantity: Pkg of 10

Thermo Scientific Part Number 1R76458-2024

SilTite Ferrule for 0.53mm Columns Quantity: Pkg of 10

Thermo Scientific Part Number 1R76458-2026

Spring Loaded Transferline Nut Quantity: Each

Thermo Scientific Part Number 1R120434-0100

1 Ordering Spare Parts

Column Components

Thermo Scientific TSQ Duo Spare Parts Guide 23

Nut for SilTite Ferrules Quantity: Pkg of 5

Thermo Scientific Part Number 1R76458-2001

Graphite Ferrule for 0.1–0.25 mm Columns used with Spring-loaded Transfer

Line Nut Quantity: Pkg of 10

Thermo Scientific Part Number 290VA191

Nickel-Coated Nut for Graphite Vespel Ferrules Quantity: Pkg of 5

Thermo Scientific Part Number 1R76256-0060

1 Ordering Spare Parts

Fan and Filter Components

24 TSQ Duo Spare Parts Guide Thermo Scientific

Fan and Filter Components

You can purchase the following fan and filter components for the TSQ Duo mass

spectrometer. Be sure to reference the component’s part number when placing an order with

your local Sales/Service Representative. See the TSQ Duo Hardware Manual for information

about installing these components or Ta b le 1 for a comprehensive list of available

components.

The following fan and filter components can be replaced on your mass spectrometer.

Figure 2. Fan and Filter Components

•Air Deflector

•Front Wire Mesh Filter

•Left Rear Wire Mesh Filter

•Fan Plenum

•Fan Filter (Plastic)

•Turbo Cooling Fan

•Chassis Cooling Fan

Plastic Fan

Front Wire Mesh

1 Ordering Spare Parts

Fan and Filter Components

Thermo Scientific TSQ Duo Spare Parts Guide 25

Air Deflector Quantity: Each

Thermo Scientific Part Number 1R120552-0010

Front Wire Mesh Filter Quantity: Each

Thermo Scientific Part Number 1R120554-0010

1 Ordering Spare Parts

Fan and Filter Components

26 TSQ Duo Spare Parts Guide Thermo Scientific

Left Rear Wire Mesh Filter Quantity: Each

Thermo Scientific Part Number 1R120554-0020

Fan Plenum Quantity: Each

Thermo Scientific Part Number 1R120553-0020

1 Ordering Spare Parts

Fan and Filter Components

Thermo Scientific TSQ Duo Spare Parts Guide 27

Fan Filter (Plastic) Quantity: Each

Thermo Scientific Part Number 1R76475-5005

Turbo Cooling Fan Quantity: Each

Thermo Scientific Part Number 1R120443-0003

1 Ordering Spare Parts

Fan and Filter Components

28 TSQ Duo Spare Parts Guide Thermo Scientific

Chassis Cooling Fan Quantity: Each

Thermo Scientific Part Number 1R120443-0001

NOTE: To replace all of the nylon rivets on the chassis cooling fan, order four of PN 1R3326-5000.

Nylon

Rivets

1 Ordering Spare Parts

Ion Source Components

Thermo Scientific TSQ Duo Spare Parts Guide 29

Ion Source Components

The following ion source components can be replaced on the TSQ Duo mass spectrometer.

Be sure to reference the component’s part number when placing your order. See the TSQ Duo

Hardware Manual for information about installing these components or Tabl e 1 for a

comprehensive list of available components.

•Source Heater Block

•Repeller Plate

•Source-Repeller Thumbscrew

•Thumbscrew-Repeller Spacer

•Insulating Spacer

•Lens/Source Heater

•Lens Heater Block

•Lens Heater Block Grounding Strap

•Lens Plate and Springs

•Source to Ion Guide Spacer

•Ion Source Cartridge (Low Activity)

•Ion Cartridge Sleeve

•EI Ion Volume (Low Activity)

•Ion Volume-Repeller Insulator

•Repeller (Low Activity)

•Ion Volume Locking Ring

•Repeller Spring

•Repeller Nut

•Lens 3/RF Lens

•Lens 1

•Lens 2

1 Ordering Spare Parts

Ion Source Components

30 TSQ Duo Spare Parts Guide Thermo Scientific

Figure 3. Replaceable Components of the Ion Source

Source-Repeller

Thumb Screws

Thumbscrew-Repeller

Spacers

Ion Volume

Locking Ring

Insulating

Spacers

Repeller

Plate

Repeller

Spring

Repeller

Repeller

Nut

Ion Volume-Repeller

Insulator

Ion

Volume

Lens 1

Lens 2

Lens 3/RF Lens

Ion

Cartridge

Sleeve

Lens/Source

Heaters

Source to

Ion Guide

Spacer

Source

Heater Block

Lens Plate

and Springs

Lens

Heater

Block

Lens Heater Block

Grounding Strap

Source Heater Block Quantity: Each

Thermo Scientific Part Number 1R120404-1311

1 Ordering Spare Parts

Ion Source Components

Thermo Scientific TSQ Duo Spare Parts Guide 31

Repeller Plate Quantity: Each

Thermo Scientific Part Number 1R120404-1312

Source-Repeller Thumbscrew Quantity: Each

Thermo Scientific Part Number 1R120564-0004

NOTE: There are two source-repeller thumbscrews on the ion source, so to replace them, order two of PN 1R120564-0004.

Thumbscrew-Repeller Spacer Quantity: Each

Thermo Scientific Part Number 1RTSLI053A

NOTE: There are two thumbscrew-repeller spacers on the ion source, so to replace them, order two of PN 1RTSLI053A.

Insulating Spacer Quantity: Each

Thermo Scientific Part Number 1RTSLI050A

NOTE: There are two insulating spacers on the ion source, so to replace them, order two of PN 1RTSLI050A.

1 Ordering Spare Parts

Ion Source Components

32 TSQ Duo Spare Parts Guide Thermo Scientific

Lens/Source Heater Quantity: Each

Thermo Scientific Part Number 1R120404-1330

NOTE: There are two lens/source heaters on the ion source, so to replace them, order two of PN 1R120404-1330. To replace the

M4 x 20 mm screws on each lens/source heater, order two of PN 1R76913-0420. To replace the lock washers, order PN 1R76902-0004.

Lens Heater Block Quantity: Each

Thermo Scientific Part Number 1R120404-1323

NOTE: To replace the M3 x 6 mm screw on the lens heater block, order PN 1R76913-0306. To replace the copper washer, order

PN 1R76483-5003.

Copper Washer

1 Ordering Spare Parts

Ion Source Components

Thermo Scientific TSQ Duo Spare Parts Guide 33

Lens Heater Block Grounding Strap Quantity: Each

Thermo Scientific Part Number 1R120404-2010

NOTE: To replace all the M3 x 6 mm screws on the grounding strap, order two of PN 1R76913-0306.

Lens Plate and Springs Quantity: Each

Thermo Scientific Part Number 1R120404-1750

NOTE: To replace the M3 x 6 mm screw on the lens plate and springs, order PN 1R76913-0306. To replace the copper washer, order

PN 1R76483-5003.

1 Ordering Spare Parts

Ion Source Components

34 TSQ Duo Spare Parts Guide Thermo Scientific

Source to Ion Guide Spacer Quantity: Each

Thermo Scientific Part Number 1R120404-1340

1 Ordering Spare Parts

Ion Source Components

Thermo Scientific TSQ Duo Spare Parts Guide 35

Ion Source Cartridge Components

The ion source cartridge consists of the following components. See the TSQ Duo Hardware

Manual for information about installing these components or Tabl e 1 for a comprehensive list

of available components.

•Ion Source Cartridge (Low Activity)

•Ion Cartridge Sleeve

•EI Ion Volume (Low Activity)

•Ion Volume-Repeller Insulator

•Repeller (Low Activity)

•Ion Volume Locking Ring

•Repeller Spring

•Repeller Nut

•Lens 1

•Lens 3/RF Lens

•Lens 2

Ion Source Cartridge (Low Activity) Quantity: Each

Thermo Scientific Part Number 1R120404-4100

1 Ordering Spare Parts

Ion Source Components

36 TSQ Duo Spare Parts Guide Thermo Scientific

Ion Cartridge Sleeve Quantity: Each

Thermo Scientific Part Number 1R120404-1105

EI Ion Volume (Low Activity) Quantity: Each

Thermo Scientific Part Number 1R120404-4111

Ion Volume-Repeller Insulator Quantity: Each

Thermo Scientific Part Number 1R120404-1114

Repeller (Low Activity) Quantity: Each

Thermo Scientific Part Number 1R120404-1161

1 Ordering Spare Parts

Ion Source Components

Thermo Scientific TSQ Duo Spare Parts Guide 37

Ion Volume Locking Ring Quantity: Each

Thermo Scientific Part Number 1R120404-1118

Repeller Spring Quantity: Pkg of 5

Thermo Scientific Part Number 1R76485-1000K

NOTE: Although the ion source only contains one repeller spring, you will receive a package of five when you order PN 1R76485-1000K.

Repeller Nut Quantity: Each

Thermo Scientific Part Number 1R120404-1120

Lens 1 Quantity: Each

Thermo Scientific Part Number 1R120574-0139

NOTE: This part replaces PN1R120404-1130.

1 Ordering Spare Parts

Ion Source Components

38 TSQ Duo Spare Parts Guide Thermo Scientific

Lens 3/RF Lens Quantity: Each

Thermo Scientific Part Number 1R120574-0103

NOTE: This part replaces PN1R120404-1150. If you are upgrading from the legacy Lens 3/RF, the ion guide frequency should be tuned and

saved. See the TSQ Duo User Guide for instructions.

Lens 2 Quantity: Each

Thermo Scientific Part Number 1R120404-1140

1 Ordering Spare Parts

Electron Multiplier Components

Thermo Scientific TSQ Duo Spare Parts Guide 39

Electron Multiplier Components

You can purchase the following electron multiplier components for the TSQ Duo mass

spectrometer. Be sure to reference the component’s part number when placing an order with

your local Sales/Service Representative. See the TSQ Duo Hardware Manual for information

about installing these components or Ta b le 1 for a comprehensive list of available

components.

The following electron multiplier components can be replaced on your mass spectrometer.

•Electron Multiplier

•Electron Multiplier Plate

•Large Feedthrough

•Anode Feedthrough

•Detector Assembly (Dynode, Electron Multiplier, and Lead Set)

Figure 4. Replaceable Components of the Electron Multiplier

Large Feedthroughs

Anode Feedthrough

Electron

Multiplier

Plate

Detector Assembly

(Dynode, Electron

Multiplier, and Lead

Set)

Large

Feedthrough

O-Rings

Anode O-Ring

1 Ordering Spare Parts

Electron Multiplier Components

40 TSQ Duo Spare Parts Guide Thermo Scientific

Electron Multiplier Quantity: Each

Thermo Scientific Part Number 1R76022-14633

Electron Multiplier Plate Quantity: Each

Thermo Scientific Part Number 1R120405-1000

NOTE: To replace the M4 x 10 mm screws, which secure the electron multiplier plate to the manifold, order four of PN 1R76913-0410.

1 Ordering Spare Parts

Electron Multiplier Components

Thermo Scientific TSQ Duo Spare Parts Guide 41

Large Feedthrough Quantity: Each

Thermo Scientific Part Number 1R120610-0040

NOTE: There are two large feedthroughs on the TSQ Duo, so to replace them, order two of PN 1R120610-0040. To replace all the M4 x 10

mm screws on each large feedthrough, order three of PN 1R76913-0410. To replace the o-ring, order PN 1R3814-113.

O-Ring

Large

Feedthrough

Anode Feedthrough Quantity: Each

Thermo Scientific Part Number 1R120610-0050

NOTE: To replace all the M3 x 6 mm screws on the anode feedthrough, order two of PN 1R76913-0306. To replace the o-ring, order

PN 1R3814-110. To replace the standoff, order PN 1R77005-3010.

Standoff

O-Ring

Anode

Feedthrough

1 Ordering Spare Parts

Electron Multiplier Components

42 TSQ Duo Spare Parts Guide Thermo Scientific

Detector Assembly (Dynode, Electron Multiplier, and Lead Set) Quantity: Assembly

Thermo Scientific Part Number 1R120379-0001

NOTE: To replace the screws, order PN 1R76913-0306. You must clean the screws prior to installing them.

1 Ordering Spare Parts

Dual Filament Components

Thermo Scientific TSQ Duo Spare Parts Guide 43

Dual Filament Components

You can purchase the following dual filament components for the TSQ Duo mass

spectrometer. Be sure to reference the component’s part number when placing an order with

your local Sales/Service Representative. See the TSQ Duo Hardware Manual for information

about installing these components or Ta b le 1 for a comprehensive list of available

components.

The following dual filament components can be replaced on your mass spectrometer.

•Dual Filament

•Filament Retaining Spring and Spacer

Figure 5. Replaceable Components of the Dual Filament

Filament Retaining Spring

Spacer

Dual Filament

1 Ordering Spare Parts

Dual Filament Components

44 TSQ Duo Spare Parts Guide Thermo Scientific

Dual Filament Quantity: Each

Thermo Scientific Part Number 1R120404-1940

Filament Retaining Spring and Spacer Quantity: Each

Thermo Scientific Part Number 1R120404-1405

NOTE: PN 1R120404-1405 contains the filament retaining spring, spacer, and screw. To replace only the M3 x 5 mm screw on the filament

retaining spring, order PN 1R76913-0305.

1 Ordering Spare Parts

Analyzer Components

Thermo Scientific TSQ Duo Spare Parts Guide 45

Analyzer Components

You can purchase the following analyzer components for the TSQ Duo mass spectrometer. Be

sure to reference the component’s part number when placing an order with your local

Sales/Service Representative. See the TSQ Duo Hardware Manual for information about

installing these components or Tab le 1 for a comprehensive list of available components.

The following analyzer components can be replaced on your mass spectrometer.

•Ion Guide

•Ion-Guide Clamp

•Ion Guide Wire Set

•Quad 1 Wire Set

•Quad 3 Wire Set

•Q1 Quad Assembly

•Collision Cell Assembly

•Q3 Quad Assembly

•Q3 Exit Lens Assembly

•Q1 Entrance Lens Endcap

•Q1 Entrance Lens Assembly

•Analyzer Tray with Source Block and Ion Guide

•Wire Routing Clip

•Q1 Exit Lens Wire

•Q3 Entrance Lens Wire

•Q3 Exit Lens Wire

1 Ordering Spare Parts

Analyzer Components

46 TSQ Duo Spare Parts Guide Thermo Scientific

Figure 6. Replaceable Components of the Analyzer

* See Ion Source Components for information about ordering the ion source.

Entrance Lens

Endcap

Collision Cell

Q3 Quad Assembly

Q1 Quad

Assembly

Q3 Exit Lens

Assembly

Ion Source Block

Assembly*

Ion Guide Analyzer Tray

Ion Guide

Wire Set

1 Ordering Spare Parts

Analyzer Components

Thermo Scientific TSQ Duo Spare Parts Guide 47

Ion Guide Quantity: Each

Thermo Scientific Part Number 1R120404-3100

Ion-Guide Clamp Quantity: Each

Thermo Scientific Part Number 1R120404-3214

NOTE: To replace all the M3 x 16 mm screws on the ion-guide clamp, order two of PN 1R76913-0316.

1 Ordering Spare Parts

Analyzer Components

48 TSQ Duo Spare Parts Guide Thermo Scientific

Ion Guide Wire Set Quantity: Pkg of 2

Thermo Scientific Part Number 1R120480-0004

NOTE: To replace the M3 nut on the ion guide wire set, order PN 1R76904-0003.

Quad 1 Wire Set Quantity: Pkg of 2

Thermo Scientific Part Number 1R120480-0005

NOTE: To replace all the M3 x 5 mm screws on the quad wire set, order four of PN 1R76913-0305. To replace all the copper washers, order

eight of PN 1R76483-5003.

1 Ordering Spare Parts

Analyzer Components

Thermo Scientific TSQ Duo Spare Parts Guide 49

Quad 3 Wire Set Quantity: Pkg of 2

Thermo Scientific Part Number 1R120480-0006

NOTE: To replace all the M3 x 5 mm screws on the quad wire set, order four of PN 1R76913-0305. To replace all the copper washers, order

eight of PN 1R76483-5003.

Q1 Quad Assembly Quantity: Each

Thermo Scientific Part Number 1R120542-2560

1 Ordering Spare Parts

Analyzer Components

50 TSQ Duo Spare Parts Guide Thermo Scientific

Collision Cell Assembly Quantity: Each

Thermo Scientific Part Number 1R120574-0161

NOTE: To replace all the M4 x 6 mm screws to mount the collision cell to the analyzer tray, order four of PN 1R76913-0306.

Q3 Quad Assembly Quantity: Each

Thermo Scientific Part Number 1R120542-2570

1 Ordering Spare Parts

Analyzer Components

Thermo Scientific TSQ Duo Spare Parts Guide 51

Q3 Exit Lens Assembly Quantity: Each

Thermo Scientific Part Number 1R120542-2536

NOTE: To replace all the M4 x 6 mm screws on the Q3 exit lens assembly to mount it to the tray, order two of PN 1R76913-0406.

Q1 Entrance Lens Endcap Quantity: Each

Thermo Scientific Part Number 1R120404-3211

NOTE: To replace all the M4 x 6 mm screws on the plastic quadrupole rod endcap, order four of PN 1R76913-0406.

1 Ordering Spare Parts

Analyzer Components

52 TSQ Duo Spare Parts Guide Thermo Scientific

Q1 Entrance Lens Assembly Quantity: Each

Thermo Scientific Part Number 1R120404-3212

NOTE: To replace all the M3 x 16 mm screws on the quad entrance lens, order two of PN 1R76913-0316.

Analyzer Tray with Source Block and Ion Guide Quantity: Each

Thermo Scientific Part Number 1R120542-2535

1 Ordering Spare Parts

Analyzer Components

Thermo Scientific TSQ Duo Spare Parts Guide 53

Wire Routing Clip Quantity: Each

Thermo Scientific Part Number 1R120542-2511

Q1 Exit Lens Wire Quantity: Each

Thermo Scientific Part Number 1R120542-2515

1 Ordering Spare Parts

Analyzer Components

54 TSQ Duo Spare Parts Guide Thermo Scientific

Q3 Entrance Lens Wire Quantity: Each

Thermo Scientific Part Number 1R120542-2514

Q3 Exit Lens Wire Quantity: Each

Thermo Scientific Part Number 1R120542-2513

1 Ordering Spare Parts

Board Components

Thermo Scientific TSQ Duo Spare Parts Guide 55

Board Components

You can purchase the following board components for the TSQ Duo mass spectrometer. Be

sure to reference the component’s part number when placing an order with your local

Sales/Service Representative. See the TSQ Duo Hardware Manual for information about

installing these components or Tab le 1 for a comprehensive list of available components.

The following board components can be replaced on your mass spectrometer.

•Front RF Board

•Rear RF Board

•Front Rod Driver Board (50 V)

•Rear Rod Driver Board (75V)

•Lens Driver Board

•Source Interface Board

•Heat Shield for the Source Interface Board

•Electrometer Board

•Electrometer Shield

•Controller Interface Board

•PC Communication Board

•Distribution Board

•20-Pin Feedthrough

•4-Pin Feedthrough

1 Ordering Spare Parts

Board Components

56 TSQ Duo Spare Parts Guide Thermo Scientific

Figure 7. Replaceable Board Components

WARNING ELECTRICAL SHOCK HAZARD: For safety reasons, the fuses on the lens driver

board can only be replaced by Field Service Engineers.

Controller Interface Board

PC Communication

Board

Front RF Board

and Front Rod

Driver Board Rear RF Board

and Rear Rod

Driver Board

Lens Driver

Board

Distribution

Board

1 Ordering Spare Parts

Board Components

Thermo Scientific TSQ Duo Spare Parts Guide 57

Front RF Board Quantity: Each

Thermo Scientific Part Number 1R120485-A060

NOTE: If you only need to replace the fan, order PN 1R120443-0002.

Rear RF Board Quantity: Each

Thermo Scientific Part Number 1R120485-A065

1 Ordering Spare Parts

Board Components

58 TSQ Duo Spare Parts Guide Thermo Scientific

Front Rod Driver Board (50 V) Quantity: Each

Thermo Scientific Part Number 1R120485-0415

NOTE: If you only need to replace the fan, order PN 1R24170-5003.

1 Ordering Spare Parts

Board Components

Thermo Scientific TSQ Duo Spare Parts Guide 59

Rear Rod Driver Board (75V) Quantity: Each

Thermo Scientific Part Number 1R120485-0420

Lens Driver Board Quantity: Each

Thermo Scientific Part Number 1R120485-A110

1 Ordering Spare Parts

Board Components

60 TSQ Duo Spare Parts Guide Thermo Scientific

Source Interface Board Quantity: Each

Thermo Scientific Part Number 1R120485-0210

1 Ordering Spare Parts

Board Components

Thermo Scientific TSQ Duo Spare Parts Guide 61

Heat Shield for the Source Interface Board Quantity: Each

Thermo Scientific Part Number 1R120404-2110

NOTE: To replace the M4 x 10 mm screw on the heat shield, order PN 1R76913-0410.

Electrometer Board Quantity: Each

Thermo Scientific Part Number 1R120354-0500

NOTE: To replace all the M3 x 6 mm screws on the electrometer board, order two of PN 1R76913-0306. To replace all the M3 x 16 mm

screws, order two of PN 1R76913-0316.

1 Ordering Spare Parts

Board Components

62 TSQ Duo Spare Parts Guide Thermo Scientific

Electrometer Shield Quantity: Each

Thermo Scientific Part Number 1R120368-0010

NOTE: To replace all the M3 x 6 mm screws on the electrometer shield, order two of PN 1R76913-0306.

Controller Interface Board Quantity: Each

Thermo Scientific Part Number 1R120485-0020

NOTE: To replace all the M3 x 6 mm screws that secure the controller interface board to the chassis, order seven of PN 1R76913-0306.

This part ships without the metal rack. Use the metal rack from the old board.

1 Ordering Spare Parts

Board Components

Thermo Scientific TSQ Duo Spare Parts Guide 63

PC Communication Board Quantity: Each

Thermo Scientific Part Number 1R120354-0010

Distribution Board Quantity: Each

Thermo Scientific Part Number 1R120485-0810

NOTE: To replace all the M3 x 10 mm screws on the distribution board, order 26 of PN 1R76913-0310.

1 Ordering Spare Parts

Board Components

64 TSQ Duo Spare Parts Guide Thermo Scientific

20-Pin Feedthrough Quantity: Each

Thermo Scientific Part Number 1R120610-0020

NOTE: To replace all the M4 x 10 mm screws on the 20-pin feedthrough, order three of PN 1R76913-0410. To replace the o-ring, order

PN 1R3814-123.

20-Pin

Feedthrough

O-Ring

4-Pin Feedthrough Quantity: Each

Thermo Scientific Part Number 1R120610-0030

NOTE: There are two 4-pin feedthroughs on the TSQ Duo system. To replace all the M4 x 10 mm screws on the 4-pin feedthrough, order

three of PN 1R76913-0410. To replace the interior o-ring, order PN 1R3814-127.

4-Pin

Feedthrough

O-Ring

1 Ordering Spare Parts

Power Module Components

Thermo Scientific TSQ Duo Spare Parts Guide 65

Power Module Components

You can purchase the following power supply components for the TSQ Duo mass

spectrometer. Be sure to reference the component’s part number when placing an order with

your local Sales/Service Representative. See the TSQ Duo Hardware Manual for information

about installing these components or Ta b le 1 for a comprehensive list of available

components.

The following power supply components can be replaced on your mass spectrometer.

•Power Module

•Dynode and Multiplier Power Supply and Cables (EI only)

Figure 8. Replaceable Power Supply Components

Power Supply

Dynode/Multi

plier Power

1 Ordering Spare Parts

Power Module Components

66 TSQ Duo Spare Parts Guide Thermo Scientific

Power Module Quantity: Each

Thermo Scientific Part Number 1R120544-0002

NOTE: To replace all the M4 x 10 mm flat-head screws on the power supply, order PN 1R76937-0410. To replace all the M4 x 10 mm

pan-head screws, order PN 1R76913-0410.

1 Ordering Spare Parts

Power Module Components

Thermo Scientific TSQ Duo Spare Parts Guide 67

Dynode and Multiplier Power Supply and Cables (EI only) Quantity: Each

Thermo Scientific Part Number 1R120361-0003

NOTE: To replace the M4 x 16 mm screw, order PN 1R76913-0416.

1 Ordering Spare Parts

Manifold Components

68 TSQ Duo Spare Parts Guide Thermo Scientific

Manifold Components

You can purchase the following manifold components for the TSQ Duo mass spectrometer.

Be sure to reference the component’s part number when placing an order with your local

Sales/Service Representative. See the TSQ Duo Hardware Manual for information about

installing these components or Tab le 1 for a comprehensive list of available components.

The following manifold components can be replaced on your mass spectrometer.

•Manifold Door Hinge

•Front Manifold Plate

•Large Top Glass Cover

•Small Top Glass Cover

•O-Ring, Large for Back Glass

•Manifold O-Ring

•Vent Valve Knob

•Front Door Alignment Pin

•Magnet Yoke

•Source Magnet

•Delivery Tube

•Source Insertion Guide

•Back Manifold Plate

1 Ordering Spare Parts

Manifold Components

Thermo Scientific TSQ Duo Spare Parts Guide 69

Figure 9. Replaceable Components of the Manifold

Manifold Door Hinge

Source

Magnets

Front Tray

Alignment Pins

Front Plate

Vent Valve Knob

and O-Ring

Bracket

Manifold O-ring

Back

Plate

Manifold O-ring

Back Tray

Alignment Pin

Manifold Door Hinge Quantity: Each

Thermo Scientific Part Number 1R120565-0001

NOTE: To replace all the M4 x 10 mm screws on the manifold door hinge, order three of PN 1R76913-0410.

1 Ordering Spare Parts

Manifold Components

70 TSQ Duo Spare Parts Guide Thermo Scientific

Front Manifold Plate Quantity: Each

Thermo Scientific Part Number 1R120403-0002

NOTE: To replace all the M4 x 20 mm screws on the front manifold plate, order four of PN 1R76913-0420.

Large Top Glass Cover Quantity: Each

Thermo Scientific Part Number 1R120542-3000

1 Ordering Spare Parts

Manifold Components

Thermo Scientific TSQ Duo Spare Parts Guide 71

Small Top Glass Cover Quantity: Each

Thermo Scientific Part Number 1R120401-3000

O-Ring, Large for Back Glass Quantity: Each

Thermo Scientific Part Number 1R3814-376

1 Ordering Spare Parts

Manifold Components

72 TSQ Duo Spare Parts Guide Thermo Scientific

Manifold O-Ring Quantity: Each

Thermo Scientific Part Number 1R3815-360

NOTE: There are four large manifold o-rings in the TSQ Duo: two on the top of the vacuum manifold, one at the front and one at the back.

To replace all of the manifold o-rings, order four of PN 1R3815-360.

Vent Valve Knob Quantity: Each

Thermo Scientific Part Number 1R120403-0104

NOTE: To replace the o-ring on the vent valve knob, order PN 1R3814-110.

Back Tray Alignment Pin Quantity: Each

Thermo Scientific Part Number 1R120403-0103

1 Ordering Spare Parts

Manifold Components

Thermo Scientific TSQ Duo Spare Parts Guide 73

Front Door Alignment Pin Quantity: Each

Thermo Scientific Part Number 1R120564-0003

NOTE: There are two front door alignment pins on the front of the instrument.

Magnet Yoke Quantity: Each

Thermo Scientific Part Number 1R120564-0002

Source Magnet Quantity: Each

Thermo Scientific Part Number 1R70001-98195

NOTE: There are two source magnets in the TSQ Duo, so to replace them, order two of PN 1R70001-98195.

1 Ordering Spare Parts

Manifold Components

74 TSQ Duo Spare Parts Guide Thermo Scientific

Delivery Tube Quantity: Each

Thermo Scientific Part Number 1R120404-1202

NOTE: If you are using CI, you need to order two of PN 1R120404-1202.

Source Insertion Guide Quantity: Each

Thermo Scientific Part Number 1R120564-0001

1 Ordering Spare Parts

Manifold Components

Thermo Scientific TSQ Duo Spare Parts Guide 75

Back Manifold Plate Quantity: Each

Thermo Scientific Part Number 1R120403-1001

NOTE: This PN includes the plate, alignment pin (1R120403-0103) and O-ring (1R3815-360). To replace all the M4 x 16 mm screws on the

back manifold plate, order four of PN 1R76913-0416.

1 Ordering Spare Parts

Cover Components

76 TSQ Duo Spare Parts Guide Thermo Scientific

Cover Components

You can purchase the following cover components for the TSQ Duo mass spectrometer. Be

sure to reference the component’s part number when placing an order with your local

Sales/Service Representative. See the TSQ Duo Hardware Manual for information about

installing these components or Tab le 1 for a comprehensive list of available components.

The following cover components can be replaced on your mass spectrometer.

•Right Side Panel

•Left Hand Front Panel

•Left Hand Sub Panel

•Top C ov er

•TSQ Duo Front Cover

•Front Door Hinge

•Front Door Hinge Support

•Front Door Latch

•Chassis Foot

1 Ordering Spare Parts

Cover Components

Thermo Scientific TSQ Duo Spare Parts Guide 77

Figure 10. Replaceable Covers

Top Cover Panel

Right Side

Left Side Panel

1 Ordering Spare Parts

Cover Components

78 TSQ Duo Spare Parts Guide Thermo Scientific

Right Side Panel Quantity: Each

Thermo Scientific Part Number 1R120541-0200

NOTE: To replace all the M4 x 10 mm screws on the right side panel, order four of PN 1R76913-0410. To replace the right side panel feet,

order PN 1R3666-0207.

Left Hand Front Panel Quantity: Each

Thermo Scientific Part Number 1R120541-0003

NOTE: To replace all the M4 x 10 mm screws on the right side panel, order four of PN 1R76913-0410.

1 Ordering Spare Parts

Cover Components

Thermo Scientific TSQ Duo Spare Parts Guide 79

Left Hand Sub Panel Quantity: Each

Thermo Scientific Part Number 1R120541-0500

Top Cover Quantity: Each

Thermo Scientific Part Number 1R120541-0001

NOTE: To replace all the M4 x 10 mm screws on the top cover panel, order two of PN 1R76913-0410.

1 Ordering Spare Parts

Cover Components

80 TSQ Duo Spare Parts Guide Thermo Scientific

TSQ Duo Front Cover Quantity: Each

Thermo Scientific Part Number 1R120548-0200

Front Door Hinge Quantity: Each

Thermo Scientific Part Number 1R3434-5000

NOTE: To replace all the M3 x 8 mm (flathead) screws on a front door hinge, order two of PN 1R76937-0308. There are two hinges on the

front door.

1 Ordering Spare Parts

Cover Components

Thermo Scientific TSQ Duo Spare Parts Guide 81

Front Door Hinge Support Quantity: Each

Thermo Scientific Part Number 1R120445-0001

NOTE: To replace the M4 x 10 mm screw on the front door hinge supports, order PN 1R76913-0410.

Front Door Latch Quantity: Each

Thermo Scientific Part Number 1R76483-3000

NOTE: To replace all the screws on the front door latch, order two of PN 1R120414-0010. To replace all the M3 locking nuts, order two of

PN 1R76944-0100.

Chassis Foot Quantity: Each

Thermo Scientific Part Number 1R3666-0208

NOTE: There are four feet on the bottom of the TSQ Duo, so to replace them, order six of PN 1R3666-0208. To replace the M4 x 12 mm

screw on each chassis foot, order 1R76913-0412.

1 Ordering Spare Parts

TSQ Duo Tools

82 TSQ Duo Spare Parts Guide Thermo Scientific

TSQ Duo Tools

The TSQ Duo mass spectrometer ships with a toolkit that contains all the tools you will need

to perform maintenance on the instrument. It does not contain any consumable items or

cleaning supplies. You can purchase any item in the toolkit individually or you can order a

complete kit. Contact your local Sales/Service Representative to place an order. See Table 1 for

a comprehensive list of available components.

The following toolkit components can be replaced.

•MS Toolkit

•Source Holder

•T10 Torxhead Key

•T20 Torxhead Key

•T30 Torxhead Key

•Forceps, 8 in.

•Wrench, open-ended, 1/4-in., 5/16-in.

•Wrench, open-ended, 3/8 in., 7/16-in.

MS Toolkit Quantity: Each

Thermo Scientific Part Number 1R120467-0001

1 Ordering Spare Parts

TSQ Duo Tools

Thermo Scientific TSQ Duo Spare Parts Guide 83

Small Source Removal Tool Quantity: Each

Thermo Scientific Part Number 1R120406-2250

Column Measuring Tool Quantity: Each

Thermo Scientific Part Number 1R120461-0010

Source Holder Quantity: Each

Thermo Scientific Part Number 1R120471-0001

1 Ordering Spare Parts

TSQ Duo Tools

84 TSQ Duo Spare Parts Guide Thermo Scientific

T10 Torxhead Key Quantity: Each

Thermo Scientific Part Number 1R3812-5T10

T20 Torxhead Key Quantity: Each

Thermo Scientific Part Number 1R3812-5T20

T30 Torxhead Key Quantity: Each

Thermo Scientific Part Number 1R3812-5T30

Forceps, 8 in. Quantity: Each

Thermo Scientific Part Number 1R76360-0008

1 Ordering Spare Parts

TSQ Duo Tools

Thermo Scientific TSQ Duo Spare Parts Guide 85

Wrench, open-ended, 1/4-in., 5/16-in. Quantity: Each

Thermo Scientific Part Number 1R76360-0109

Wrench, open-ended, 3/8 in., 7/16-in. Quantity: Each

Thermo Scientific Part Number 1R76360-0108

1 Ordering Spare Parts

Pump Components

86 TSQ Duo Spare Parts Guide Thermo Scientific

Pump Components

The following pump is available for the TSQ Duo. Contact your local Sales/Service

Representative to place an order. Once you receive the equipment, refer to the TSQ Duo

Hardware Manual for installation information or Tab le 1 for a comprehensive list of available

pumps and pump components.

•Turbomolecular Pump

•Rough Pump (RV3)

•Convectron Gauge

•Foreline Adapter

•Claw Clamp

•Centering Ring

•Oil Mist Filter

Turbomolecular Pump Quantity: Each

Thermo Scientific Part Number 1R119268-0002

1 Ordering Spare Parts

Pump Components

Thermo Scientific TSQ Duo Spare Parts Guide 87

Rough Pump (RV3) Quantity: Each

Thermo Scientific Part Number 1R76505-3007

Convectron Gauge Quantity: Each

Thermo Scientific Part Number A0105-00501

Foreline Adapter Quantity: Each

Thermo Scientific Part Number 1R119244-0025

1 Ordering Spare Parts

Pump Components

88 TSQ Duo Spare Parts Guide Thermo Scientific

Claw Clamp Quantity: Each

Thermo Scientific Part Number 1R76505-0017

Centering Ring Quantity: Each

Thermo Scientific Part Number 1R76505-2001

1 Ordering Spare Parts

Pump Components

Thermo Scientific TSQ Duo Spare Parts Guide 89

Oil Mist Filter Quantity: Each

Thermo Scientific Part Number 1R76505-0036

1 Ordering Spare Parts

Upgrade Equipment

90 TSQ Duo Spare Parts Guide Thermo Scientific

Upgrade Equipment

The following upgrade equipment is available for the TSQ Duo mass spectrometer. Contact

your local Sales/Service Representative to place an order. Once you receive the equipment,

refer to the TSQ Duo Hardware Manual for installation information or Table 1 for a

comprehensive list of available components.

•Hydrogen Ion Volume

•Ion Gauge Upgrade Kit

•Ion Gauge Mount

•Ion Gauge Tube Shield

•Replacement Ion Gauge Tube

•Ion Gauge Board

•Dust Filter

Hydrogen Ion Volume Quantity: Each

Thermo Scientific Part Number 1R120404-4115

1 Ordering Spare Parts

Upgrade Equipment

Thermo Scientific TSQ Duo Spare Parts Guide 91

Ion Gauge Upgrade Kit Quantity: Each

Thermo Scientific Part Number 1R120560-0020

NOTE: To replace the o-ring on the ion gauge, order PN 1R3814-116. To replace the ion gauge tube, order PN A0105-06003.

Ion Gauge Mount Quantity: Each

Thermo Scientific Part Number 1R120416-0002

1 Ordering Spare Parts

Upgrade Equipment

92 TSQ Duo Spare Parts Guide Thermo Scientific

Ion Gauge Tube Shield Quantity: Each

Thermo Scientific Part Number 1R119605-0012

Replacement Ion Gauge Tube Quantity: Each

Thermo Scientific Part Number A0105-06003

1 Ordering Spare Parts

Upgrade Equipment

Thermo Scientific TSQ Duo Spare Parts Guide 93

Ion Gauge Board Quantity: Each

Thermo Scientific Part Number 1R120485-0120

Dust Filter Quantity: Each

Thermo Scientific Part Number 1R120442-0005
