Quick Selector

Quick Selector

5

Catalog numbers shown in red

indicate transformers normally in stock.

Type FB

• Encapsulated/Compound Filled

• 115° C Rise, 180° C Insulation System

• U.L.® Listed For Indoor & Outdoor Application

Type FH Energy Efcient

• Ventilated

• 150° C Rise, Optional 115° C & 80° C Rise

• 220° C Insulation System

• U. L.® Listed

• Floor Mounted

• NEMA TP-1 2002 Compliant

• NEMA Premium®

General Purpose Single Phase, 60 Hz

Type

Pri

Sec

KVA

120 x 240

120/240

No Taps

208

120/240

With Taps

240 x 480

120/240

No Taps

240 x 480

120/240

With Taps

277

120/240

With Taps

480

120/240

With Taps

600

120/240

With Taps

(Electrostatically

Shielded)

FB

.050 SE2N.050F

.075 SE2N.075F

.100 SE2N.100F

.150 SE2N.150F

.250 SE2N.250F

.500 SE2N.500F

.750 SE2N.750F

1 SE120N1F SE201D1F SE2N1F SE271D1F SE481D1F SE61D1FS

1.5 SE120N1.5F SE201D1.5F SE2N1.5F SE271D1.5F SE481D1.5F SE61D1.5FS

2 SE120N2F SE201D2F SE2N2F SE271D2F SE481D2F SE61D2FS

3 SE120N3F SE201D3F SE2N3FS SE2T3F SE271D3F SE481D3F SE61D3FS

5 SE120N5F SE201D5F SE2N5FS SE2T5F SE271D5F SE481D5F SE61D5FS

7.5 SE120N7.5F SE201D7.5F SE2N7.5F SE2T7.5F SE271D7.5F SE481D7.5F SE61D7.5FS

10 SE120N10F SE201D10F SE2N10F SE2T10F SE271D10F SE481D10F SE61D10FS

15 SE120N15F SE201D15F SE2N15F SE2T15F SE271D15F SE481D15F SE61G15FS

FH

15 S2T15E S61T15SE

25 S2T25E S61T25SE

37.5 S2T37E S61T37SE

50 S2T50E S61T50SE

75 S2T75E S61T75SE

100 S2T100E S61T100SE

167 S2T167E S61T167SE

Buck Boost Single Phase, 60 Hz

Type

Pri

Sec

KVA

120 x 240

12/24

120/240

16/32

240 x 480

24/48

FB

.050 SB12N.050F SB16N.050F SB24N.050F

.100 SB12N.100F SB16N.100F SB24N.100F

.150 SB12N.150F SB16N.150F SB24N.150F

.250 SB12N.250F SB16N.250F SB24N.250F

.500 SB12N.500F SB16N.500F SB24N.500F

.750 SB12N.750F SB16N.750F SB24N.750F

1SB12N1F SB16N1F SB24N1F

1.5 SB12N1.5F SB16N1.5F SB24N1.5F

2SB12N2F SB16N2F SB24N2F

3SB12N3F SB16N3F SB24N3F

5SB12N5F SB16N5F SB24N5F

Transformer

Quick Selector

Guide

Transformer

Quick Selector

Guide

Quick Selector

Quick Selector

6

General Purpose Three Phase, 60 Hz

Type

Pri

Sec

KVA

208 - 208Y/120

Electrostatically

Shielded

208

480Y/277

240

208Y/120

Electrostatically

Shielded

440

220Y/127

480

208Y/120

480 - 208Y/120

Electrostatically

Shielded

480 - 208Y/120

Electrostatically

Shielded Copper

480

240/120 LT

480 - 240/120 LT

Electrostatically

Shielded

480

480Y/277

600

208Y/120

Electrostatically

Shielded

FB

3 TE242D3FS TE4D3F TE4D3FS TE482D3F (No LT) TE482D3FS (No LT)

6 TE242D6FS TE4D6F TE4D6FS TE482D6F (No LT) TE482D6FS (No LT)

9 TE242D9FS TE4D9F TE4D9FS TE482D9F (No LT) TE482D9FS (No LT)

15 TE242D15FS TE4D15F TE4D15FS TE482D15F (No LT) TE482D15FS (No LT)

FH

15 T202H15SE T204H15E T242T15SE T422X15E T4T15E T4T15SE T4T15CSE T43T15E T43T15SE T484T15E T6T15SE

30 T202H30SE T204H30E T242T30SE T4T30E T4T30SE T4T30CSE T43T30E T43T30SE T484T30E T6T30SE

45 T202H45SE T204H45E T242T45SE T4T45E T4T45SE T4T45CSE T43T45E T43T45SE T484T45E T6T45SE

75 T202H75SE T204H75E T242T75SE T422X75E T4T75E T4T75SE T4T75CSE T43T75E T43T75SE T484T75E T6T75SE

112.5 T202H112SE T204H112E T242T112SE T4T112E T4T112SE T4T112CSE T43T112E T43T112SE T484T112E T6T112SE

150 T202H150SE T204H150E T242T150SE T4T150E T4T150SE T4T150CSE T43T150E T43T150SE T484T150E T6T150SE

225 T202J225SE T204J225E T242J225SE T4T225E T4T225SE T4T225CSE T43T225E T43T225SE T484T225E T6T225SE

300 T202L300SE T204L300E T242L300SE T4T300E T4T300SE T4T300CSE T43T300E T43T300SE T484T300E T6T300SE

500 T202E500SE T204E500E T242B500SE T4T500E T4T500SE T4T500CSE T43T500E T43T500SE T484T500E T6T500SE

750 T204E750E T4T750E T4T750SE T4T750CSE T43T750E T43T750SE T484T750E

1000 T4J1000E T4J1000SE T4J1000CSE

115° C Optional Temperature Rise

FH

15 T202H15FSE T204H15FE T242T15FSE T4T15FE T4T15FSE T4T15FCSE T43T15FE T43T15FSE T484T15FE T6T15FSE

30 T202H30FSE T204H30FE T242T30FSE T4T30FE T4T30FSE T4T30FCSE T43T30FE T43T30FSE T484T30FE T6T30FSE

45 T202H45FSE T204H45FE T242T45FSE T4T45FE T4T45FSE T4T45FCSE T43T45FE T43T45FSE T484T45FE T6T45FSE

75 T202H75FSE T204H75FE T242T75FSE T4T75FE T4T75FSE T4T75FCSE T43T75FE T43T75FSE T484T75FE T6T75FSE

112.5 T202H112FSE T204H112FE T242T112FSE T4T112FE T4T112FSE T4T112FCSE T43T112FE T43T112FSE T484T112FE T6T112FSE

150 T202J150FSE T204J150FE T242J150FSE T4T150FE T4T150FSE T4T150FCSE T43T150FE T43T150FSE T484T150FE T6T150FSE

225 T202L225FSE T204L225FE T242L225FSE T4T225FE T4T225FSE T4T225FCSE T43T225FE T43T225FSE T484T225FE T6T225FSE

300 T202B300FSE T204B300FE T242B300FSE T4T300FE T4T300FSE T4T300FCSE T43T300FE T43T300FSE T484T300FE T6T300FSE

500 T204E500FE T4T500FE T4T500FSE T4T500FCSE T43T500FE T43T500FSE T484T500FE

80° C Optional Temperature Rise

FH

15 T202H15BSE T204H15BE T242T15BSE T4T15BE T4T15BSE T4T15BCSE T43T15BE T43T15BSE T484T15BE T6T15BSE

30 T202H30BSE T204H30BE T242T30BSE T4T30BE T4T30BSE T4T30BCSE T43T30BE T43T30BSE T484T30BE T6T30BSE

45 T202H45BSE T204H45BE T242T45BSE T4T45BE T4T45BSE T4T45BCSE T43T45BE T43T45BSE T484T45BE T6T45BSE

75 T202H75BSE T204H75BE T242T75BSE T4T75BE T4T75BSE T4T75BCSE T43T75BE T43T75BSE T484T75BE T6T75BSE

112.5 T202J112BSE T204J112BE T242T112BSE T4T112BE T4T112BSE T4T112BCSE T43T112BE T43T112BSE T484T112BE T6T112BSE

150 T202J150BSE T204J150BE T242J150BSE T4T150BE T4T150BSE T4T150BCSE T43T150BE T43T150BSE T484T150BE T6T150BSE

225 T202B225BSE T204B225BE T242B225BSE T4T225BE T4T225BSE T4T225BCSE T43T225BE T43T225BSE T484T225BE T6T225BSE

300 T202B300BSE T204B300BE T242B300BSE T4T300BE T4T300BSE T4T300BCSE T43T300BE T43T300BSE T484T300BE T6T300BSE

500 T204E500BE T4T500BE T4T500BSE T4T500BCSE T43T500BE T43T500BSE T484T500BE

Quick Selector

Quick Selector

7

General Purpose Three Phase, 60 Hz

Type

Pri

Sec

KVA

208 - 208Y/120

Electrostatically

Shielded

208

480Y/277

240

208Y/120

Electrostatically

Shielded

440

220Y/127

480

208Y/120

480 - 208Y/120

Electrostatically

Shielded

480 - 208Y/120

Electrostatically

Shielded Copper

480

240/120 LT

480 - 240/120 LT

Electrostatically

Shielded

480

480Y/277

600

208Y/120

Electrostatically

Shielded

FB

3 TE242D3FS TE4D3F TE4D3FS TE482D3F (No LT) TE482D3FS (No LT)

6 TE242D6FS TE4D6F TE4D6FS TE482D6F (No LT) TE482D6FS (No LT)

9 TE242D9FS TE4D9F TE4D9FS TE482D9F (No LT) TE482D9FS (No LT)

15 TE242D15FS TE4D15F TE4D15FS TE482D15F (No LT) TE482D15FS (No LT)

FH

15 T202H15SE T204H15E T242T15SE T422X15E T4T15E T4T15SE T4T15CSE T43T15E T43T15SE T484T15E T6T15SE

30 T202H30SE T204H30E T242T30SE T4T30E T4T30SE T4T30CSE T43T30E T43T30SE T484T30E T6T30SE

45 T202H45SE T204H45E T242T45SE T4T45E T4T45SE T4T45CSE T43T45E T43T45SE T484T45E T6T45SE

75 T202H75SE T204H75E T242T75SE T422X75E T4T75E T4T75SE T4T75CSE T43T75E T43T75SE T484T75E T6T75SE

112.5 T202H112SE T204H112E T242T112SE T4T112E T4T112SE T4T112CSE T43T112E T43T112SE T484T112E T6T112SE

150 T202H150SE T204H150E T242T150SE T4T150E T4T150SE T4T150CSE T43T150E T43T150SE T484T150E T6T150SE

225 T202J225SE T204J225E T242J225SE T4T225E T4T225SE T4T225CSE T43T225E T43T225SE T484T225E T6T225SE

300 T202L300SE T204L300E T242L300SE T4T300E T4T300SE T4T300CSE T43T300E T43T300SE T484T300E T6T300SE

500 T202E500SE T204E500E T242B500SE T4T500E T4T500SE T4T500CSE T43T500E T43T500SE T484T500E T6T500SE

750 T204E750E T4T750E T4T750SE T4T750CSE T43T750E T43T750SE T484T750E

1000 T4J1000E T4J1000SE T4J1000CSE

115° C Optional Temperature Rise

FH

15 T202H15FSE T204H15FE T242T15FSE T4T15FE T4T15FSE T4T15FCSE T43T15FE T43T15FSE T484T15FE T6T15FSE

30 T202H30FSE T204H30FE T242T30FSE T4T30FE T4T30FSE T4T30FCSE T43T30FE T43T30FSE T484T30FE T6T30FSE

45 T202H45FSE T204H45FE T242T45FSE T4T45FE T4T45FSE T4T45FCSE T43T45FE T43T45FSE T484T45FE T6T45FSE

75 T202H75FSE T204H75FE T242T75FSE T4T75FE T4T75FSE T4T75FCSE T43T75FE T43T75FSE T484T75FE T6T75FSE

112.5 T202H112FSE T204H112FE T242T112FSE T4T112FE T4T112FSE T4T112FCSE T43T112FE T43T112FSE T484T112FE T6T112FSE

150 T202J150FSE T204J150FE T242J150FSE T4T150FE T4T150FSE T4T150FCSE T43T150FE T43T150FSE T484T150FE T6T150FSE

225 T202L225FSE T204L225FE T242L225FSE T4T225FE T4T225FSE T4T225FCSE T43T225FE T43T225FSE T484T225FE T6T225FSE

300 T202B300FSE T204B300FE T242B300FSE T4T300FE T4T300FSE T4T300FCSE T43T300FE T43T300FSE T484T300FE T6T300FSE

500 T204E500FE T4T500FE T4T500FSE T4T500FCSE T43T500FE T43T500FSE T484T500FE

80° C Optional Temperature Rise

FH

15 T202H15BSE T204H15BE T242T15BSE T4T15BE T4T15BSE T4T15BCSE T43T15BE T43T15BSE T484T15BE T6T15BSE

30 T202H30BSE T204H30BE T242T30BSE T4T30BE T4T30BSE T4T30BCSE T43T30BE T43T30BSE T484T30BE T6T30BSE

45 T202H45BSE T204H45BE T242T45BSE T4T45BE T4T45BSE T4T45BCSE T43T45BE T43T45BSE T484T45BE T6T45BSE

75 T202H75BSE T204H75BE T242T75BSE T4T75BE T4T75BSE T4T75BCSE T43T75BE T43T75BSE T484T75BE T6T75BSE

112.5 T202J112BSE T204J112BE T242T112BSE T4T112BE T4T112BSE T4T112BCSE T43T112BE T43T112BSE T484T112BE T6T112BSE

150 T202J150BSE T204J150BE T242J150BSE T4T150BE T4T150BSE T4T150BCSE T43T150BE T43T150BSE T484T150BE T6T150BSE

225 T202B225BSE T204B225BE T242B225BSE T4T225BE T4T225BSE T4T225BCSE T43T225BE T43T225BSE T484T225BE T6T225BSE

300 T202B300BSE T204B300BE T242B300BSE T4T300BE T4T300BSE T4T300BCSE T43T300BE T43T300BSE T484T300BE T6T300BSE

500 T204E500BE T4T500BE T4T500BSE T4T500BCSE T43T500BE T43T500BSE T484T500BE

Quick Selector

Quick Selector

8

Other K-Factor voltage combinations are also available from stock.

K-Factor Rated — 480-208Y/120, Three Phase, 60Hz

Type KVA Electrostatically Shielded Aluminum Electrostatically Shielded Copper

K4 K13 K20 K4 K13 K20

FH

15 T4T15SK4E T4T15SK13E T4T15SK20E T4T15CSK4E T4T15CSK13E T4T15CSK20E

30 T4T30SK4E T4T30SK13E T4T30SK20E T4T30CSK4E T4T30CSK13E T4T30CSK20E

45 T4T45SK4E T4T45SK13E T4T45SK20E T4T45CSK4E T4T45CSK13E T4T45CSK20E

75 T4T75SK4E T4T75SK13E T4T75SK20E T4T75CSK4E T4T75CSK13E T4T75CSK20E

112.5 T4T112SK4E T4T112SK13E T4T112SK20E T4T112CSK4E T4T112CSK13E T4T112CSK20E

150 T4T150SK4E T4T150SK13E T4T150SK20E T4T150CSK4E T4T150CSK13E T4T150CSK20E

225 T4T225SK4E T4T225SK13E T4T225SK20E T4T225CSK4E T4T225CSK13E T4T225CSK20E

300 T4T300SK4E T4T300SK13E T4T300SK20E T4T300CSK4E T4T300CSK13E T4T300CSK20E

500 T4T500SK4E T4T500SK13E T4T500SK20E T4T500CSK4E T4T500CSK13E T4T500CSK20E

115° C Optional Temperature Rise

FH

15 T4T15FSK4E T4T15FSK13E T4T15FSK20E T4T15FCSK4E T4T15FCSK13E T4T15FCSK20E

30 T4T30FSK4E T4T30FSK13E T4T30FSK20E T4T30FCSK4E T4T30FCSK13E T4T30FCSK20E

45 T4T45FSK4E T4T45FSK13E T4T45FSK20E T4T45FCSK4E T4T45FCSK13E T4T45FCSK20E

75 T4T75FSK4E T4T75FSK13E T4T75FSK20E T4T75FCSK4E T4T75FCSK13E T4T75FCSK20E

112.5 T4T112FSK4E T4T112FSK13E T4T112FSK20E T4T112FCSK4E T4T112FCSK13E T4T112FCSK20E

150 T4T150FSK4E T4T150FSK13E T4T150FSK20E T4T150FCSK4E T4T150FCSK13E T4T150FCSK20E

225 T4T225FSK4E T4T225FSK13E T4T225FSK20E T4T225FCSK4E T4T225FCSK13E T4T225FCSK20E

300 T4T300FSK4E T4T300FSK13E T4T300FSK20E T4T300FCSK4E T4T300FCSK13E T4T300FCSK20E

500 T4T500FSK4E T4T500FSK13E T4T500FSK20E T4T500FCSK4E T4T500FCSK13E T4T500FCSK20E

80° C Optional Temperature Rise

FH

15 T4T15BSK4E T4T15BSK13E T4T15BSK20E T4T15BCSK4E T4T15BCSK13E T4T15BCSK20E

30 T4T30BSK4E T4T30BSK13E T4T30BSK20E T4T30BCSK4E T4T30BCSK13E T4T30BCSK20E

45 T4T45BSK4E T4T45BSK13E T4T45BSK20E T4T45BCSK4E T4T45BCSK13E T4T45BCSK20E

75 T4T75BSK4E T4T75BSK13E T4T75BSK20E T4T75BCSK4E T4T75BCSK13E T4T75BCSK20E

112.5 T4T112BSK4E T4T112BSK13E T4T112BSK20E T4T112BCSK4E T4T112BCSK13E T4T112BCSK20E

150 T4T150BSK4E T4T150BSK13E T4T150BSK20E T4T150BCSK4E T4T150BCSK13E T4T150BCSK20E

225 T4T225BSK4E T4T225BSK13E T4T225BSK20E T4T225BCSK4E T4T225BCSK13E T4T225BCSK20E

300 T4T300BSK4E T4T300BSK13E T4T300BSK20E T4T300BCSK4E T4T300BCSK13E T4T300BCSK20E

500 T4T500BSK4E T4T500BSK13E T4T500BSK20E T4T500BCSK4E T4T500BCSK13E T4T500BCSK20E

Quick Selector

Quick Selector

9

Catalog numbers shown in red indicate transformers normally in stock

Motor Drive Isolation Transformers Three-Phase, 60 Hz, Type FH

KVA 230∆ - 230Y 230∆ - 460Y 460∆ - 230Y 460∆ - 460Y 230∆ - 575Y 460∆ - 575Y 575∆ - 230Y 575∆ - 460Y 575∆ - 575Y

7.5 FH7.5AEMD FH7.5AFMD FH7.5CEMD FH7.5CFMD FH7.5AHMD FH7.5CHMD FH7.5DEMD FH7.5DFMD FH7.5DHMD

11 FH11AEMD FH11AFMD FH11CEMD FH11CFMD FH11AHMD FH7.5CHMD FH11DEMD FH11DFMD FH11DHMD

15 FH15AEMD FH15AFMD FH15CEMD FH15CFMD FH15AHMD FH15CHMD FH15DEMD FH15DFMD FH15DHMD

20 FH20AEMD FH20AFMD FH20CEMD FH20CFMD FH20AHMD FH20CHMD FH20DEMD FH20DFMD FH20DHMD

27 FH27AEMD FH27AFMD FH27CEMD FH27CFMD FH27AHMD FH27CHMD FH27DEMD FH27DFMD FH27DHMD

34 FH34AEMD FH34AFMD FH34CEMD FH34CFMD FH34AHMD FH34CHMD FH34DEMD FH34DFMD FH34DHMD

40 FH40AEMD FH40AFMD FH40CEMD FH40CFMD FH40AHMD FH40CHMD FH40DEMD FH40DFMD FH40DHMD

51 FH51AEMD FH51AFMD FH51CEMD FH51CFMD FH51AHMD FH51CHMD FH51DEMD FH51DFMD FH51DHMD

63 FH63AEMD FH63AFMD FH63CEMD FH63CFMD FH63AHMD FH63CHMD FH63DEMD FH63DFMD FH63DHMD

75 FH75AEMD FH75AFMD FH75CEMD FH75CFMD FH75AHMD FH75CHMD FH75DEMD FH75DFMD FH75DHMD

93 FH93AEMD FH93AFMD FH93CEMD FH93CFMD FH93AHMD FH93CHMD FH93DEMD FH93DFMD FH93DHMD

118 FH118AEMD FH118AFMD FH118CEMD FH118CFMD FH118AHMD FH118CHMD FH118DEMD FH118DFMD FH118DHMD

145 FH145AEMD FH145AFMD FH145CEMD FH145CFMD FH145AHMD FH145CHMD FH145DEMD FH145DFMD FH145DHMD

175 FH175AEMD FH175AFMD FH175CEMD FH175CFMD FH175AHMD FH175CHMD FH175DEMD FH175DFMD FH175DHMD

220 FH220AEMD FH220AFMD FH220CEMD FH220CFMD FH220AHMD FH220CHMD FH220DEMD FH220DFMD FH220DHMD

275 FH275AEMD FH275AFMD FH275CEMD FH275CFMD FH275AHMD FH275CHMD FH275DEMD FH275DFMD FH275DHMD

330 FH330AEMD FH330AFMD FH330CEMD FH330CFMD FH330AHMD FH330CHMD FH330DEMD FH330DFMD FH330DHMD

440 FH440AEMD FH440AFMD FH440CEMD FH440CFMD FH440AHMD FH440CHMD FH440DEMD FH440DFMD FH440DHMD

550 FH550AEMD FH550AFMD FH550CEMD FH550CFMD FH550AHMD FH550CHMD FH550DEMD FH550DFMD FH550DHMD

660 FH660AEMD FH660AFMD FH660CEMD FH660CFMD FH660AHMD FH660CHMD FH660DEMD FH660DFMD FH660DHMD

750 FH750AEMD FH750AFMD FH750CEMD FH750CFMD FH750AHMD FH750CHMD FH750DEMD FH750DFMD FH750DHMD

Quick Selector

Quick Selector

10
