Fluke Networks Solutions Catalog

Products for the installation, testing, monitoring and

analysis of enterprise and telecommunication networks

2www.flukenetworks.com

Online Resources

Fluke Networks is committed to helping you get the most value out of our products and

find the solutions you need. We encourage you to visit www.flukenetworks.com where

you will find additional in-depth and up-to-date information for our complete product

offering – some of which isn’t represented in this catalog.

Also look to FlukeNetworks.com for value–added content pages that resonate

with your job function, technology interest, and content needs.

Community

Connect with other networking professionals through our online community.

• Forums

• Blogs

• Ratings & Reviews

• Follow us on Twitter, FaceBook, LinkedIn

From the Experts Blogs

Hear first-hand what our networking experts have to say about common challenges,

trends and happenings in an ever-changing industry.

• Wired to Wireless

Adventures in moving from Cat 5 to 5GHz

Follow a resident network expert as he shares his thoughts on the world of Wi-Fi.

• The Decoder

Solving the mysteries of monitoring, analysis and troubleshooting

This blog “decodes” what our team of experts learns on the road from meeting with

customers – best practices, how-to’s, cool tools, ins and outs of deploying new

technologies and how to tell management what’s going in terms they can understand.

• Packets in Paradise

Tips and tricks in protocol analysis

Learn from an industry packet analysis expert as he writes about tips and tricks,

protocol analysis, using Fluke Networks tools and case studies.

Products & Technology Forums

Have a question? Need more information? Want to see how other Fluke Networks customers

are using their solutions? Want to give us feedback about products, solutions or the website?

Participate in our growing online community where our forums are driven by users, for users.

Learn more about:

• Technology topics

• Product performance

• Customer best practices

Have a question or a problem that you don’t see listed in the forums? Start your own

discussion. Please visit www.flukenetworks.com/forums

3

email: info@flukenetworks.com

Online Resources .........................2

Fluke Networks Trusted Partner ................4

Datacom Cabling

Copper Cable Test Solutions

Copper Cable Test Solutions Product Comparison . .7

DTX CableAnalyzerTM Series ..................8

DTX Accessories and Gold Support ............9

DTX 10 Gig over Copper Test Solutions ........10

DTX CableAnalyzer Fiber Options ............10

CableIQTM Qualification Tester ...............11

CableIQ Kits ..........................12

MicroScanner2 Cable Verifier ................12

LinkWareTM Cable Test Management Software .....13

LinkwareTM Stats .......................13

IntelliToneTM Pro Toner and Probe ............14

Pro3000 Analog Toner and Probe ............14

TS®90 Cable Fault Finder .................15

TS®100 Cable Fault Finder ................15

Fiber Testing, Troubleshooting and Certification

Fiber Testing, Troubleshooting and Certification

Comparison ..........................17

Fiber Inspection and Cleaning

FiberInspectorTM Pro Video Microscope .........18

FiberInspectorTM Mini Video Microscope ........18

FiberViewerTM Fiber Microscope ..............18

VisiFaultTM Visual Fault Locator ..............18

Fiber Optic Cleaning Kits .................19

Inspection Adapters ....................19

Loss/Length (Tier 1) Fiber Certification

DTX Fiber Modules ......................20

DTX-CLT CertiFiber® Optical Loss Set ..........20

SimpliFiberTM Pro Optical Power Meter .........21

Fiber Test Kits ........................22

Test-Reference Cords, Adapters and Mandrels ....23

Fiber Plant Charecterization & Troubleshooting

(Tier 2 Certification)

OptiFiber® OTDR .......................24

OptiFiber Modules/Accessories .............25

Launch Fibers .........................25

DTX Compact OTDR .....................26

Fiber Testing Best Practices ...............27

Tools and Test Kits

JackRapidTM Termination Tool ...............29

Impact Tools .........................30

Blades. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Pro-Tool Kits .........................32

Electrical Contractor Telecom Kits ...........33

Modular Crimpers ......................34

Cable Splicing Knife ....................34

D-SnipsTM ............................34

Electrician’s Snips ......................34

Cable Strippers ........................35

Need-L-LockTM Crimping Pliers ..............35

Probe Pic ............................35

Can Wrench ..........................35

Basic Tools Article ......................36

IT Networking

Test and Troubleshoot

AirCheckTM Wi-Fi Tester ...................39

EtherScope™ Series II Network Assistant .......40

NetTool™ Series II Inline Network Tester .......41

LinkRunner™ Pro and Duo Network Multimeters . . 42

Monitoring, Analysis and Troubleshooting

OptiView® Management Appliance with Reporter . 44

OptiView® Portable Network Analyzer .........45

ClearSightTM Analyzer ....................46

Network Time MachineTM ..................47

Tap Solutions .........................48

AirMagnet Survey ......................49

AirMagnet Planner ......................49

AirMagnet WiFi Analyzer ..................49

AirMagnet Spectrum XT ..................50

AirMagnet VoFi Analyzer ..................50

AirMagnet Enterprise ....................50

Telecommunications Providers

Telephone Butt-In Test Sets

Telephone Test Set Comparison .............53

TS®52 PRO LCD Test Set ..................54

TS®40 Series Test Sets ...................55

TS®30 Test Set ........................55

TS®22 Series Test Sets ...................56

TS®25D Test Set .......................56

TS®19 Test Set ........................57

Modular Adapters ......................57

Line Cords and Clips ....................58

Access Network Test Equipment

Fiber OneShotTM Optical Test Set .............60

MetroScopeTM Service Provider Assistant ........61

LinkRunner Duo CE Pocket Carrier Ethernet

Test Set .............................62

CopperProTM Series II Broadband Loop Tester ....63

990DSL CopperProTM Loop Tester .............64

CopperPro TerminatorTM Far End

Terminating Device .....................64

635 QuickBERT-T1 Test Set ................65

Voltage Detector .......................65

Corporate

Communication Service Providers ............67

Fluke Networks Gold Support ...............68

Professional Services and Training ...........69

Latest News from Fluke Networks ............70

Contact .............................71

Table of Contents

4www.flukenetworks.com

Welcome to the Fluke Networks product

catalog, the definitive resource for information

on Fluke Networks industry-leading solutions for

installing, testing, monitoring and analyzing

enterprise and telecommunications networks.

You know that the right tool makes the job go

faster and easier. Each of our tools, from simple

cable strippers and knives to cable analyzers to

enterprise-level analysis tools, meet and exceed

industry standards, giving you confidence that

you and your team of professionals will achieve

your goals the first time and every time. Please

review our catalog for opportunities to enhance

your solution set and get ready to realize

the benefits of the latest advances from

Fluke Networks.

Fluke Networks is your trusted partner, striv-

ing to give you an unparalleled view into your

ongoing challenges of building and maintaining

mission-critical network and telecommunication

services. We offer easy-to-use tools that save

you precious time and money while improving

the productivity of your organization.

Fluke Networks is your trusted partner

Fluke Networks partners with you to help your organization solve today’s

problems and anticipate tomorrow’s challenges. Our award winning

solutions – portable network testers and analyzers, enterprise performance

management hardware and software, datacom installation tools or telecom-

munications instruments and systems – give you a unique look into your

enterprise or telecommunication network. It’s the instant visibility you need

to solve everyday network problems, and it offers the foresight required to

improve network performance in the future.

Fluke Networks Gold Support Programs

Fluke Networks Gold membership programs ensure a high return on your

investment by keeping your Fluke Networks products up-to-date and in top

condition. The programs are paid annual service contracts that offer 24/7

technical support, knowledge-base access, members-only discounts, access to

online training and up-to-the-minute information on your product – every-

thing you need to reduce your total cost of ownership. Turn to page 68 for a

complete overview of Gold Support.

Technical Assistance

Have a question? Need help troubleshooting a technical issue? Looking for

knowledgeable advice on which Fluke Networks solutions best fit your

network analysis needs? The certified support technicians at our Technical

Assistance Center are available to help you, call 1-800-283-5853.

5

Datacom Cabling

Copper Cable Test Solutions

Copper Cable Test Solutions Product Comparison ..........7

DTX CableAnalyzerTM Series ..........................8

DTX Accessories and Gold Support ....................9

DTX 10 Gig over Copper Test Solutions ................10

DTX CableAnalyzer Fiber Options ....................10

CableIQTM Qualification Tester .......................11

CableIQ Kits ..................................12

MicroScanner2 Cable Verifier ........................12

LinkWareTM Cable Test Management Software .............13

LinkwareTM Stats ...............................13

IntelliToneTM Pro Toner and Probe ....................14

Pro3000 Analog Toner and Probe ....................14

TS®90 Cable Fault Finder .........................15

TS®100 Cable Fault Finder ........................15

Fiber Testing, Troubleshooting and Certification

Fiber Testing, Troubleshooting and Certification Comparison . . 17

Fiber Inspection and Cleaning

FiberInspectorTM Pro Video Microscope .................18

FiberInspectorTM Mini Video Microscope ................18

FiberViewerTM Fiber Microscope ......................18

VisiFaultTM Visual Fault Locator ......................18

Fiber Optic Cleaning Kits .........................19

Inspection Adapters ............................19

Loss/Length (Tier 1) Fiber Certification

DTX Fiber Modules ..............................20

DTX-CLT CertiFiber® Optical Loss Set ..................20

SimpliFiberTM Pro Optical Power Meter .................21

Fiber Test Kits ................................22

Test-Reference Cords, Adapters and Mandrels ............23

Fiber Plant Charecterization & Troubleshooting

(Tier 2 Certification)

OptiFiber® OTDR ...............................24

OptiFiber Modules/Accessories .....................25

Launch Fibers .................................25

DTX Compact OTDR .............................26

Fiber Testing Best Practices .......................27

Tools and Test Kits

JackRapidTM Termination Tool .......................29

Impact Tools .................................30

Blades. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Pro-Tool Kits .................................32

Electrical Contractor Telecom Kits ...................33

Modular Crimpers ..............................34

Cable Splicing Knife ............................34

D-SnipsTM ....................................34

Electrician’s Snips ..............................34

Cable Strippers ................................35

Need-L-LockTM Crimping Pliers ......................35

Probe Pic ....................................35

Can Wrench ..................................35

Basic Tools Article ..............................36

Datacom Cabling

www.flukenetworks.com/datacom 5

6www.flukenetworks.com/copper

Fluke Networks copper verification, qualification and certification products are essential tools for installers, contractors and

network technicians in today’s environment. As networks grow and change, the performance of cabling is critical to delivering

services to users. New testing standards also emerge and with them come guidelines that cabling professionals must follow when

installing, testing, troubleshooting, and certifying copper. Whether it is coax, 10BASE-T, 100BASE-TX, 1000BASE-T or 10GBASE-T,

you need to be aware of the requirements and avoid the potential pitfalls in the copper infrastructure.

Fluke Networks copper testing products reduce network downtime caused by flaws in the cabling or installation process. They also

resolve problems in operating networks and make upgrades simpler. Intuitive user interfaces are easy to learn and understand.

With precise and repeatable accuracy that have become gold standard in network testing, network professionals save time and

money using Fluke Networks copper testing products.

Copper Cable Test Solutions

Complete solutions for the installation, testing, documentation and certification of copper

premises cabling

7

1-800-283-5853 (US and Canada) • www.flukenetworks.com/worldwide

Copper Cable Test Solutions Product Comparison

DTX

CableAnalyzer™

Series

CableIQ™

Qualification Tester

MicroScanner2

Cable Verifier

Supports structured cabling warranties 3

Meets TIA/ISO certification standards requirements Levels IIe, III, IIIe

and Level IV

Provides pass/fail results 9-second Cat 6

Documents test results 3 3

Qualifies cabling speed (10/100/VoIP/Gig) 3

Advanced troubleshooting: NEXT, AxTalk, ELFEXT, RL 3

Troubleshoots distance to connection fault 3 3

Basic troubleshooting: distance to break or short 333

Continuity and wiremap 333

8www.flukenetworks.com/dtx

Copper Cable Test Solutions

DTX CableAnalyzer™ Series

Fluke Networks DTX CableAnalyzer Series combines speed and unprecedented accuracy no other

certification tester can match. This revolutionary platform significantly reduces total time to certify:

saving time you can see on your bottom line – as much as 33% of certification costs per year.

Certify a Cat 6 link three times faster than other testers with 9-second Cat 6 autotest and level IV

accuracy. DTX also gives you 900 MHz of testing bandwidth, optional on-board fiber modules, easy-

to-understand diagnostics, 12-hour battery life, a bright color display, and nearly instant setup and

reporting. AC Wiremap verifies cabling through Midspan PoE controllers. DTX: It’s all about time!

• More than 1.2 billion copper links have been certified by the DTX CableAnalyzer

• Exceeds the field tester retirements for Level IIe (Cat 5e), Level III (Cat 6),

Level IIIe (Cat 6a) and Level IV (Cat 7 and Cat 7a)

• Three times faster with 9-second Cat 6 autotest

• Advanced time-saving diagnostics pinpoint fault and suggest corrective actions

• 900 MHz future-proofs your investment for future applications such as 10 Gigabit Ethernet,

Class FA and CATV

• Resident fiber modules let you switch between copper and fiber with the push of a button

• Fast, reliable, and rugged with extended 12-hour battery life and color display all enhance

user productivity

• DTX significantly reduces total certification costs by as much as 33% a year

Model Description

DTX-1800 Ultimate performance in a future-proof investment – test capabilities to 900 MHz, and

industry leading Autotest execution times – 9-seconds for a Cat 6 link

DTX-1200 Revolutionized performance and value for Cat 6/5e certification – test capabilities up to

350 MHz, and industry-leading Cat 6 Autotest in 9 seconds

DTX-LT Excellent performance in an entry-level model – test capabilities up to 350 MHz,

and impressive Cat 6 Autotest in 30 seconds*

DTX-1800-MSO

DTX 1800 Copper/Fiber/OTDR Kit includes DTX-1800 CableAnalyzer, sets of

Multimode DTX MFM2 and Singlemode DTX SFM2 Fiber (loss/length) Modules,

DTX Compact OTDR Module, launch fibers, accessories and carrying case(s)

DTX-1800-MO DTX-1800 with Multimode Fiber Modules and OTDR includes DTX-1800 CableAnalyzer,

set of Multimode DTX MFM2 Fiber Modules and a DTX Compact OTDR Module

DTX-1800-MS DTX-1800 with Multimode and Singlemode Fiber Module includes DTX-1800 CableAnalyzer

and set of DTX-MFM2 Multimode Fiber Modules and DTX-SFM2 Singlemode Fiber Modules

DTX-1800-M DTX-1800 with Multimode Fiber Modules – includes DTX-1800 CableAnalyzer and a set of

DTX-MFM2 Multimode Fiber Modules

DTX-AXKIT Alien Crosstalk Communication Modules (set of two) and AxTalk Analyzer™ Software

DTX-OTDR-QMOD DTX Compact OTDR Module – includes 850/1300/1310/1550 OTDR Module and carrying case

DTX-MFM2

DTX Multimode Fiber Modules – includes two modules (one for main and one for

Smart Remote), 850 nm and 1300 nm LED sources combined into single output port,

850/1300/1310/1550 nm power meter, and integrated VFL

DTX-SFM2

DTX Singlemode Fiber Modules – includes a set of two modules for main and Smart Remote,

1310 nm and 1550 nm laser sources combined into single output port,

850/1300/1310/1550 nm power meter and integrated VFL

DTX-NSM DTX Network Service Module – includes one module to verify connectivity, network service and PoE

DTX-1800SR DTX-1800 Smart Remote add-on

DTX-1200SR DTX-1200 Smart Remote add-on

DTX-LT/SR DTX-LT Smart Remote add-on*

See page 20 for the DTX CableAnalyzer fiber options.

* Not available in all geographies; contact your local Fluke Networks office for information.

9

email: info@flukenetworks.com

Copper Cable Test Solutions

DTX CableAnalyzer Gold Support

Model Description

DTX-COAX DTX Coax Cable Test Adapter (2 adapters included)

DTX-PCU6S DTX Series UTP Cat 6 Patch Cord Adapter Set – includes DTX Main adapter

(DTX-PCU6/MN) and DTX Smart Remote adapter (DTX-PCU6/SR)

DTX-PLA001S Permanent Link Adapters (2) with PM06 Personality Modules. Also interfaces with a number

of personality modules (DSP-PMxx) to test links with IDC termination

DTX-PLA001 Permanent Link Adapter for use with the DTX Series CableAnalyzer

DTX-PLA002 Permanent Link Adapter for Cat 6A and Alien Cross Talk testing

DTX-CHA002S Set of two (2) Cat 6A/Class Ea Channel Adapters optimized for Alien Crosstalk measurements

DTX-PLCAL Permanent Link Adapter Field Calibration module

DTX-PLA002PRP Plug replacement parts for the DTX-PLA002

DTX-TERA TERA Adapter Kit – includes TERA Channel Adapters (2) and TERA Permanent Link Adapters (2) to

test Siemon TERA class F systems

DTX-PLA011 TERA Permanent Link Adapter for Siemon TERA Class F Systems

DTX-CHA011 TERA Channel Adapter for Siemon TERA Class F Systems

DTX-CHA002 Cat 6A/Class Ea Channel Adapter optimized for Alien Crosstalk measurements.

DTX-ACUN AC charger, universal

DTX-ACNA AC charger, North America

DTX-CASE Standard carrying case – DTX Series

DTX-STRP DTX carrying strap

DTX-USB USB interface cable (mini-B)

DTX-SER Serial RS-232 cable (DB-9 to IEEE 1394)

DTX-LION Lithium-ion battery pack

DTX CableAnalyzer Accessories

Model Description

GLD-DTX 1-year of Gold Support – any DTX mainframe

GLD-DTX-2YR 2-years of Gold Support – any DTX mainframe

GLD-DTX-3YEAR 3-years of Gold Support – any DTX mainframe

GLD-DTX-MS 1-year of Gold Support – any DTX mainframe and Smart Remote, multimode and singlemode Fiber Module sets.

GLD-DTX-MO 1-year of Gold Support – any DTX mainframe and Smart Remote, multimode fiber set and OTDR modules.

GLD-DTX_MS-2YR 2-years of Gold Support – any DTX mainframe and Smart Remote, multimode fiber set and OTDR modules.

GLD-DTX-MO-2YR 2-years of Gold Support – any DTX mainframe and Smart Remote, singlemode fiber module sets and

OTDR module.

GLD-DTX-MSO 1-year of Gold Support – any DTX mainframe and Smart Remote, multimode and singlemode fiber module sets

and OTDR module.

GLD-DTX-MSO-2YR 2-years of Gold Support – any DTX mainframe and Smart Remote, multimode and singlemode fiber module sets

and OTDR module.

10 www.flukenetworks.com/dtx

DTX 10 Gig over Copper Test Solution

The DTX-1800 is the only cable tester that is capable of standards-compliant field testing to

guarantee that a cabling plant will support 10GBASE-T.

• Certifies the fastest growing enterprise cabling for new installations - Category 6A.

• Quickly and easily measures Alien Crosstalk (ANEXT and AFEXT) in full compliance

with industry standards

• Enables deep analysis and troubleshooting of AxTalk performance problems

Model Description

DTX-10GKIT

DTX-1800 Alien Crosstalk Analyzer Kit includes the DTX-AXTLK1 communication

modules and the Windows-based AxTalk Analyzer™ Software, DTX-PLA002S,

DTXCHA001AS and DTX-AXTERM terminator, quantity two

DTX-AXKIT Alien Crosstalk Communication Modules (set of two) and AxTalk Analyzer™ Software

DTX-PLA002S Cat 6A/Class EA Permanent Link Adapter – set of two

DTX-CHA001AS Cat 6/Class E Channel Adapters (AXTalk) – set of two

DTX-AXTERM Alien Crosstalk Link Terminators

GLD-DTX-10GKIT 1-year Gold Support – 10 Gigabit Alien Crosstalk kit

GLD-DTX-10GKIT-3YEAR 3-years Gold Support – 10 Gigabit Alien Crosstalk kit

Copper Cable Test Solutions

DTX CableAnalyzer Fiber Options

The DTX CableAnalyzer is a test platform that can function as an Optical Loss Test Set (OLTS)

and/or an Optical Time Domain Reflectometer (OTDR).

Loss/length (Tier 1) fiber certification can be performed by adding the DTX Fiber Modules.

This certification test compares absolute and length measurements to industry standards for the

application that will run over the cabling.

OTDR testing provides a graphical signature (trace) of the fiber’s attenuation along its length and

can be completed with the DTX Compact OTDR Module. OTDR testing can complement loss/length

testing with an extended or Tier 2 certification. Extended fiber certification characterizes individual

connectors and splices and ensures the workmanship and quality of the installation meet design and

warranty specifications. For more information about fiber options, see page 20.

Model Description

DTX-OTDR-QMOD DTX Compact OTDR Module – includes 850/1300/1310/1550 OTDR Module and

carrying case

DTX-MFM2

DTX Multimode Fiber Modules – includes two modules (one for main and one for

Smart Remote), 850 nm and 1300 nm LED sources combined into single output port,

850/1300/1310/1550 nm power meter, and integrated VFL

DTX-SFM2

DTX Singlemode Fiber Modules – includes a set of two modules for main and Smart

Remote, 1310 nm and 1550 nm laser sources combined into single output port,

850/1300/1310/1550 nm power meter and integrated VFL

GLD-DTX-FIBERMOD 1-year of Gold Support – DTX Fiber Module

GLD-DTXFMOD-3YEAR 3-years of Gold Support – DTX Fiber Module

11

email: info@flukenetworks.com

CableIQ™ Qualification Tester

CableIQ is the first qualification tool designed for network technicians who need to

troubleshoot connectivity problems and qualify cabling bandwidth. It gives network techs the

vision to see whether an existing cabling link is qualified to support 10/100, VoIP or Gigabit

Ethernet, quickly isolate cabling from network problems and discover what is at the far end

of any cable. It detects speed and duplex settings of attached switches and PCs. Intelligent

wiremap graphically shows distance to faults (e.g., pin 1 break at 37 ft). Lightweight, rugged,

reliable unit tests all copper cabling. Its ease and power can help you close trouble tickets

faster and ensure smooth upgrades to higher network speeds.

• Sees if your existing cabling can support voice, VoIP, 10/100/Gigabit Ethernet

• Troubleshoots why existing cabling plant can’t support the desired network bandwidth

• Discovers what’s at the end of any cable and displays device configuration

(speed/duplex/pairing)

• Frees-up switch ports and identifies unused links

• Graphically maps wiring configuration and shows distance to faults with Intelligent Wiremap

• Locates and traces cable with IntelliTone™ digital signaling technology

Model Description

CIQ-100 CableIQ Qualification Tester – includes CableIQ with remote adapter, soft carrying case

and four AA batteries

CIQ-CIT CableIQ IT hard carrying case

CIQ-COAX CableIQ Coax Adapter Kit – includes F-connector, BNC and RCA connectors

CIQ-IDK24 CableIQ Remote Identifier Kit – includes remote identifier numbers 2-4

CIQ-IDK57 CableIQ Remote Identifier Kit – includes remote identifier numbers 5-7

CIQ-RJA RJ-45/11 modular adapter

CIQ-SPKR CableIQ speaker wire adapter

CIQ-WM CableIQ main wiremap adapter (replacement part for lost or damaged unit)

CLIP-SET Clip Set – includes RJ-45-to-8-clip test lead

MT-8200-53A IntelliTone Pro 100 Probe – includes IntelliTone 100 Probe, lanyard, owners CD and

quick start guide, and 9-volt battery

MT-8200-63A IntelliTone Pro 200 Probe – includes IntelliTone 200 Probe, RJ-11 and RJ-45 patch

cables, lanyard, owners CD and quick start guide, and 9-volt battery

GLD-CIQ 1-year of Gold Support – CableIQ Qualification Tester

Copper Cable Test Solutions

12 www.flukenetworks.com/cableiq

CableIQ Kits

CableIQ Service Kit combines powerful cable and network testing in one package. Expedites problem

resolution and facilitates moves, adds, changes, and upgrades. Quickly qualifies cabling bandwidth

and confirms network connectivity.

CableIQ Gigabit Service Kit combines powerful Gigabit cable and network testing in one package.

Expedites problem resolution and facilitates moves, adds, changes, and upgrades. Documents cabling

bandwidth and network link speed.

MicroScanner2 Cable Verifier

Next generation MicroScanner streamlines voice/data/video cable and service testing. Revolu-

tionary user interface makes testing fast, easy, and crystal clear. Everything cable technicians

need to know, including available services (10/100/1000 Ethernet, POTS, PoE voltage), cable

length, wiremap, cable ID, and distance to fault all are displayed on one oversized backlit

screen. Replace multiple tools by testing all RJ-11, RJ-45, and coax (F) media with no adapters.

Built-in IntelliTone digital and analog toning precisely locates virtually any cable or wire pair –

even on active networks. Ergonomic design features sleek rubber over mold to enhance grip and

ruggedness. Includes carry case.

• Displays cable length, wiremap, cable ID, and distance to fault on one screen

• Detects today’s media services, including 10/100/1000 Ethernet, POTS, and PoE

• Locates virtually any cable or wire pair with IntelliTone digital and analog toning

Model Description

MS2-100 MicroScanner2 Cable Verifier

MS2-KIT

MicroScanner2 Professional Kit – includes MicroScanner2 Cable Verifier, Remote ID #s 2-7,

IntelliTone Pro 200 Probe, bare wire adapter, coax cable, two shielded RJ-45 cables, two RJ-11

cables and a deluxe carry case

MS2-TTK

MicroScanner2 Termination Test Kit – includes MicroScanner2 Cable Verifier, IS60 Pro Tool Kit,

IntelliTone Pro 200 Probe, RJ-11 and RJ-45 patch cables, lanyard, owners CD and quick start

guide, 9 volt battery and a deluxe carry case

MS2-IDK27 MicroScanner2 Remote ID Kit #s 2-7

CLIP-SET Clip Set - includes RJ-45 to 8-clip test lead

MT-8200-63A IntelliTone Pro 200 Probe

Copper Cable Test Solutions

CableIQ Advanced IT Kit

CableIQ Gigabit Service Kit

Model Description

CIQ-KIT CableIQ Advanced IT Kit – includes CableIQ with remote adapter, IntelliTone Pro 200 Probe,

six remote office IDs, rugged carrying case and four AA batteries

CIQ-SVC CableIQ Service Kit – includes CableIQ Qualification Tester with remote adapter, LinkRunner

Network Multimeter, IntelliTone Pro 200 Probe, six remote cable IDs and a rugged carrying case

CIQ-GSV

CableIQ Gigabit Service Kit – includes CableIQ Qualification Tester with remote adapter,

LinkRunner Pro Network Multimeter, IntelliTone Pro 200 Probe, six remote cable IDs and a

rugged carrying case

CIQ-KRQ

CableIQ Residential Qualifier Kit – includes CableIQ Qualification Tester, RJ-45 patch cord (2),

RJ-11 patch cord (2), bare wire adapter, speaker wire adapter, coax cable, coax BNC adapter,

coax RCA adapter, “Qualified” labels (50) and a soft carrying case

CIQ-VOIP

CableIQ VoIP Enterprise Service Kit – includes CableIQ with remote adapter, CableIQ Reporter

software CD, IntelliTone Pro 200 Probe, CableIQ Remote IDs #2-7, NetTool Series II Pro VoIP

tester with 10/100/1000Mbps inline, VoIP option, NetProve diagnostics, NetTool Connect PC

software, WireView Wiremapper #1, (2) RJ-45 – RJ-45 patch cord, (2) USB cables, coax “F” push-

on adapter, 75-ohm coax patch cord, RJ-45/11 universal coupler, RJ-11 – RJ-11 patch cord,

Ethernet cable, hard carry case for CableIQ, and soft carrying case for NetTool Series II Pro VoIP

GLD-CIQ 1-year of Gold Support – CableIQ Qualification Tester

13

email: info@flukenetworks.com

• Provides a complete, graphical view of cabling plant performance in ways you haven’t

seen before

• Transforms test data from your LinkWare database into statistics and graphics that

highlight the analytical information you need – at a glance

• Filters incoming data and highlights (in color) marginal or failed links to eliminate

the chance that an anomaly gets overlooked

• Quickly demonstrates that your installation meets warranty requirements

• Creates professional and easily-customized performance summary reports

Model Description

LinkWare-Stats LinkWare Stats Statistical Report Option

LinkWare™ Stats

LinkWare Stats is the first software to provide a quick, complete view of your entire cabling

plant’s performance. It generates statistics on the cabling links within your LinkWare data-

base, transforming performance results into summary graphics that highlight the analytical in-

formation you need – fast. Now it’s easy to verify margins and spot anomalies. Filter incoming

data to highlight exactly what you’re looking for. View graphs and tables showing margins by

test standard, operator, location and other attributes. Demonstrate that an installation meets

warranty requirements and win business with customized summary reports.

• Deliver professional reports in a common format

• Electronically save, maintain and archive test results

• Standards compliant with the ability to configure and print TIA 606-A documentation

• New drag and drop feature makes it easier to manage and organize multiple projects

• Simple user interface and time-saving features for increased productivity

• Included with DTX CableAnalyzer Series, OptiFiber OTDR, DTX-CLT CertiFiber and

SimpliFiber™ Pro Optical Power Meter and Fiber Test Kits

• LinkWare™ Stats option gives a comprehensive view of your entire cable plant’s performance

LinkWare™ Cable Test Management Software

LinkWare gives you the ability to manage test results data from multiple testers with one

PC software application. It makes project setup simpler by helping you quickly organize,

edit, view, print, save or archive test results by job site, customer, campus or building. You

can merge test results into an existing LinkWare database and then sort, search and orga-

nize the results by data fields or parameters. And you can count on your data integrity to

be secure. LinkWare ensures the data results you upload and store on your computer came

from the testers’ memory.

Model Description

LinkWare LinkWare Cable Test Management Software – free download at

www.flukenetworks.com/linkware

Copper Cable Test Solutions

14 www.flukenetworks.com/toneandprobe

Copper Cable Test Solutions

IntelliTone™ Pro Toner and Probe

Breakthrough digital and analog toning finds cables other toners/probes can’t. Advanced

sensing modes accurately find the correct cable bundle, and then rapidly isolate the exact

cable from within that bundle. Digital signal rejects noise and safely tones active networks.

SmartTone™ feature precisely locates individual wire pairs by changing tone when pair is

shorted. Verifies end-to-end cable continuity and basic miswires. Identifies and troubleshoots

services with datacom link, two line telecom, continuity and polarity. Powerful talk battery

capability tests telecom circuits.

• IntelliTone digital processing eliminates noise and false signals

• SmartTone™ analog toning precisely isolates individual wire pairs

• Locates cables safely and effectively on active networks

• Verifies twisted-pair installation with visual end-to-end continuity test

• Identifies, diagnoses, and troubleshoots datacom/telecom services

Pro3000™ Analog Toner and Probe

The Pro3000 Toner and Probe kit is the innovative analog toner and probe from Fluke Networks.

It’s your best choice for toning and tracing bare wire on non-active networks. Easily identify

individual pairs with its patented SmartTone™ technology (the five different tones for exact pair

identification). Angled-bed-of-nails clips allow easy access to individual wires, and the RJ-11

connector is ideal for use on telephone jacks. The large powerful speaker on the probe

allows you to hear through drywall, wood or other enclosures to find wires quickly and easily.

You can send tone up to 10 miles on most cables. Attach the nylon pouch to your belt, and

you will be equipped for any wire identification job.

• Select solid or alternating tone options, indicated with solid or flashing LEDs

• Exclusive SmartTone technology generates five separate analog tones when the pair is

shorted at the far end

• Works on de-energized AC wire, telephone/twisted pair wire, all voice and data category

rated cable, all coax cable, speaker wire and security wire

Model Description

MT-8200-60A

IntelliTone Pro 200 Kit – includes IntelliTone Pro 200 Toner and 200 Probe,

coax F connector adapter, two RJ-11 and two RJ-45 patch cables and test leads with

alligator clips

MT-8200-50A IntelliTone Pro 100 Kit – includes IntelliTone Pro 100 Toner and 100 Probe, coax F

connector adapter, RJ-11 and RJ-45 patch cables and test leads with alligator clips

MT-8200-61A IntelliTone Pro 200 Toner

MT-8200-51A IntelliTone Pro 100 Toner

MT-8200-63A IntelliTone Pro 200 Probe

MT-8200-53A IntelliTone Pro 100 Probe

Model Description

26000900 Pro3000 Analog Tone and Probe Kit

26100900 Pro3000 Probe

26200900 Pro3000 Toner

26100103 Pro3000 Analog Probe replacement tip

15

email: info@flukenetworks.com

Copper Cable Test Solutions

TS®90 Cable Fault Finder

The TS90 is our easy-to-use, three-tools-in-one tester – a fault locator, a cable inventory

manager and a toner with SmartTone™ technology (up to 2,500 feet). Easily find the distance

to opens or shorts on electrical wire, telephone wire, security wire and coax. Displays distance

reading rather than waveform.

• Works on any two or more conductor cable up to 2,500 feet

• Instantly measures distance to open or any fault from one end of any cable pair

• Patented SmartTone™ tone generator positively identifies pair

• Measures cable distance on spool

• Measures constantly while “on”

TS®100 Cable Fault Finder

Similar to the TS90, the TS100 is three tools in one tester – a fault locator, a cable inventory

manager and a toner with SmartTone™ technology (up to 3,000 feet). Easily find the distance

to opens or shorts on electrical wire, telephone wire, security wire and coax. Displays distance

reading rather than waveform.

• Works on any two or more conductor cable up to 3,000 feet (metric unit also available)

• Instantly measures distance to open or any fault from one end of any cable pair

• Patented SmartTone™ tone generator positively identifies pair

• Measures cable distance on spool

• Measures constantly while “on”

Model Description

26500090 TS90 cable fault finder with BNC to alligator clips

26501100 TS90 line cord, BNC to alligator clip

26501160 TS90 pouch with belt clip

26501200 TS90 line cord, BNC to F (male)

26501300 TS90 line cord, BNC to F (female)

26501600 TS90 line cord, banana

26501700 TS90 line cord, BNC to banana to ABN

Model Description

26500000 TS100 cable fault finder with BNC to alligator clips

26500500 TS100 with BNC to banana to ABN

26500610 TS100 metric cable fault finder with BNC to alligator clips

26501100 TS100 line cord, BNC to alligator clip

26501160 TS100 pouch with belt clip

26501200 TS100 line cord, BNC to F (male)

26501300 TS100 line cord, BNC to F (female)

26501600 TS100 line cord, banana

26501700 TS100 line cord, BNC to banana to ABN

16 www.flukenetworks.com/fiber

The Fluke Networks fiber test family is the industry’s broadest range of tools fiber inspection and cleaning, loss/length (Tier 1) fiber

certification, and fiber plant characterization and troubleshooting (Tier 2 certification). From OTDRs to cleaning supplies, Fluke Networks

fiber optic tools meet the complex needs of cabling contractors, installers and technicians. We set the standard for accuracy, ease of use,

and field toughness. So, whether you need simple continuity testing or advanced certification, Fluke Networks is the right fiber choice.

Fiber Testing, Troubleshooting and Certification

Complete solutions for the installation, testing, documentation and certification of fiber premises cabling

17

email: info@flukenetworks.com

Fiber Testing, Troubleshooting, and Certification Product Comparison

Inspection & Cleaning Loss Length (Tier 1) Certification Plant Characterization & Troubleshooting

(Tier 2 Certification)

FiberInspector

Pro/Mini Video

Microscopes

Fiber Optic

Cleaning Kits

SimpliFiber

Pro Power

Meter & Fiber

Test Kits

DTX-CLT

CertiFiber

Optical Loss

Test Set

DTX Series

with Fiber

Module

VisiFault

Visual Fault

Locator

FindFiber

Remote ID

DTX

Series with

Compact

OTDR Module

OptiFiber

OTDR

Check for fiber

end-face

contamination

or damage

3 3

Clean

contamination 3

Check

connectivity 3333333

Check

polarity 33333

Verify loss over

entire link to

ensure loss bud-

get not exceeded

333

Dual-fiber loss

testing 3 3

Basic

(Tier 1) 333

Locate faults 3 3 3

Extended

(Tier 2) 3 3

Pass/fail results 3 3 3 3

Document

test results 333 33

Fiber types

supported

Multimode

Singlemode

Multimode

Singlemode

Multimode

Singlemode

Multimode

Singlemode

Multimode

Singlemode

Multimode

Singlemode

Multimode

Singlemode

Multimode

Singlemode

Multimode

Singlemode

Source type LED, FP Laser LED, FP Laser LED, FP Laser,

and VCSEL

LED, FP Laser,

and VCSEL Laser LED, FP Laser LED, FP Laser

18 www.flukenetworks.com/fiberinspection

Fiber Inspection and Cleaning

• Easily inspects fiber connectors already installed on patch panels

• Quickly determines whether fiber connectors on a hardware device are

clean and in good condition – without disassembling the device

• Contains high-magnification optics that provides crisp, clear images of

microscopic debris and end-face damage

FiberInspector™ Pro Video Microscope

The FiberInspector Pro is a portable, dual magnification

video microscope which enables inspection of all types

of installed fiber terminations in hardware devices and

patch panels. The video microscope projects a crisp,

clear image of microscopic debris and end-face damage.

• Ensures clean, smooth terminations ready for optical transmission

• Special safety filter to protect your eyes from harmful infrared rays

• Handheld microscopes used to inspect the ends of fiber optic connections

• FT120 offers 200X magnification, FT140 offers 400X magnification

Model Description

FT120 FiberViewer, 200X

FT140 FiberViewer, 400X

NF350 1.25 mm universal microscope adapter

FiberViewer™ Fiber Microscope

The FiberViewer fiber microscope ensures a termination

is clean and ready for optical transmission. Inspect

multimode and singlemode fiber end-faces, and protect

your eyes with the built-in safety filter.

• Bright red visible laser light source, features continuous and flashing modes

• Accelerates end-to-end fiber continuity checks

• Speeds fiber tracing and identification

• Aids in location of fiber faults including tight bends, breaks and bad connectors

VisiFault™ Visual Fault Locator

The laser-powered VisiFault Visual Fault Locator (VFL)

traces fibers, verifies continuity and polarity, and helps

find breaks in cables, connectors and splices. Continuous

and flashing modes for easier identification. Compatible

with 2.5 mm and 1.25 mm connectors for easy connection.

Model Description

VisiFault VisiFault Visual Fault Locator with

2.5 mm universal adapter

NF380 1.25 mm Universal VisiFault Adpater

• The exceptionally convenient FiberInspector Mini uses a 200x magnification

probe sufficient for inspecting both multimode and singlemode fiber

• Quickly determines whether fiber connectors on a hardware device are clean

and in good condition without disassembling the device

• Contains high-magnification optics that provide crisp, clear images of micro-

scopic debris and end-face damage

FiberInspector™ Mini Video Microscope

The FiberInspector Mini video microscope enables

inspection of end-faces on all types of installed fiber.

The portable video microscope projects a crisp, clear

image of microscopic debris and end-face damage.

Model Description

FT500 FiberInspector Mini Video Microscope

FT525 FiberInspector Mini and Cleaning Kit

Model Description

FT600 FiberInspector Pro Video Microscope

OFTM-5352 FiberInspector Pro for OptiFiber

Certfying OTDR

OPV-FT600 FiberInspector Pro for OptiView

Integrated Network Analyzer

Fiber Testing, Troubleshooting and Certification

19

email: info@flukenetworks.com

Fiber Testing, Troubleshooting and Certification

Fiber Optic Cleaning Kits

Contaminated end-faces are the #1 cause of fiber link failure. Prevent this common problem

with Fluke Networks Fiber Optic Cleaning Kits and Components. These precision fiber optic

cleaning kits and components allow effective removal of all contaminants from end-faces on

both patch cords and inside ports.

• Prevent the #1 cause of fiber link failure: end-face contamination

• Everything needed for precision cleaning of end-faces on both patch cords and inside ports

• Specially formulated solvent dissolves contaminants, neutralizes static charge and

encapsulates particles for removal

• A range of wipers and swabs enable cleaning of all styles of fiber optic connections

• Use the convenient and rugged carrying case to store all of the cleaning components

Model Description

NFC-Kit-Case

Fiber Optic Cleaning Kit – includes cleaning cube with wipes, ten cards with

sealed cleaning zones, solvent pen, 2.5 mm port cleaning swabs and 1.25 mm

port cleaning swabs in a rugged carrying case.

NFC-Kit-Box Fiber Optic Cleaning Kit – includes cleaning cube with wipes, five cards with

sealed cleaning zones, solvent pen and 2.5 mm port cleaning swabs.

NFC-Cube Cleaning cube with wipes – cleans up to 500 end-faces

NFC-Cards-5pack 5 cards with 12 sealed cleaning zones each – perfect for troubleshooting

NFC-SolventPen Special solvent dispensed from pen (9 g)

NFC-Swabs-1.25mm LC and MU port cleaning swabs (25 count)

NFC-Swabs-2.5mm SC, ST, 2.5 mm port cleaning swabs (50 count)

NFC-Swabs-Multi Multi MTP/MPO port cleaning swabs (25 count)

NFC-Case Carrying case for cleaning accessories

FT525 FiberInspector Mini and Cleaning Kit

GLD-FTINSPECTOR 1-year of Gold Support

Inspection Adapters

Model Description

NFM110 Accessory tip set for FiberInspector Mini (LC, FC and 1.25 mm)

NF390 APC (Angled Physical Connector) video adapter probe for FiberInspector Mini

NFM120 Rechargeable battery for FiberInspector Mini (NIMH) for FiberInspector Mini

NF350 1.25 mm universal microscope adapter (FT-120/FT-140)

NF360 MT-RJ video probe adapter tip for FiberInspector Pro

NF362 LC video probe adapter tip for FiberInspector Pro

NF366 E2000 video probe adapter tip for FiberInspector Pro

NF368 1.25 mm universal video probe adapter tip for male ends for FiberInspector Pro

NF370 MTP/MPO video probe adapter tip for FiberInspector Pro

NF395 APC (Angled Physical Connector) video adapter probe for FiberInspector Pro

NF300SM ST/ST SM fiber optic adapter

NF310SM SC/SC SM fiber optic adapter

20 www.flukenetworks.com/dtxfiber

Loss/Length (Tier 1) Fiber Certification

Fiber Testing, Troubleshooting and Certification

Model Description

DTX-CERTIFIBER-M Multimode DTX-CLT CertiFiber – includes DTX-MFM2 and one set of 50 µm SC/SC test

reference cords

DTX-CERTIFIBER-S Singlemode DTX-CLT CertiFiber – includes DTX-SFM2 and one set of SM SC/SC test

reference cords

DTX-CERTIFIBER-MS Multimode and singlemode DTX-CLT CertiFiber – includes DTX-MFM2 and DTX-SFM2 and

one set each of 50 µm and SM SC/SC test reference cords

DTX-CERTIFIBER/MU Replacement mainframe for DTX-CLT CertiFiber

DTX-CERTIFIBER/RU Replacement remote for DTX-CLT CertiFiber

GLD-DTX-FIBERMOD 1-year of Gold Support

DTX-CLT CertiFiber® Optical Loss Test Set

The DTX-CLT CertiFiber® OLTS enables you to easily and accurately certify two fibers concurrently

over two wavelengths according to custom requirements or established industry specifications.

Quickly and efficiently conduct troubleshooting with a convenient integrated Visual Fault

Locator (VFL).

• 12 second Autotest – loss measurement of two fibers at two wavelengths, optical link budget

calculation, and a PASS/FAIL analysis

• Fast and professional test result documentation via the widely-used LinkWare reporting software

• Optimized for applications ranging up to 10 Gig

• Interchangeable multimode and singlemode modules

(which are also compatible with the popular DTX CableAnalyzer™ Series)

• Accurate fiber length measurement – eliminate haphazard guessing!

• Continuity and polarity verification

• Easy-to-use and widely-recognized DTX-based user interface

• On-board visual fault locator (VFL) to locate fibers and breaks

• Supports various small form factor (SFF) fiber connectors

DTX Fiber Modules

Add loss/length fiber certification capability to your DTX CableAnalyzer. Certify fiber

loss, length and polarity quickly and simply with the one-button Autotest. Featuring

automated testing of two fibers, each at two wavelengths, optical length measurement

and pass/fail analysis. The fastest test solution that yields the greatest time and cost

savings. Troubleshoot problems visually with the built-in VFL. Save, upload and report

results using LinkWare PC software. Available multimode and singlemode modules enable

certification of both fiber types.

Model Description

DTX-MFM2 Multimode 850 and 1300 nm

DTX-SFM2 Singlemode 1310 and 1550 nm

GLD-DTX-FIBERMOD 1-year of Gold Support – DTX Fiber Module

GLD-DTXFMOD-3YEAR 3-years of Gold Support – DTX Fiber Module

See page 8 for the DTX CableAnalyzer copper options.

21

email: info@flukenetworks.com

SimpliFiber Pro® Optical Power Meter

With new advanced functions that make fiber testing simple, SimpliFiber® Pro Optical Power

Meter and Fiber Test Kits are the single “go-to” kits for anyone involved in first-line optical

fiber cabling installation and verification. Designed for in-house fiber technicians as well as

contractors, our expertly configured kits are housed in a professional and durable case and

contain all the simple-to-use tools needed to quickly measure loss and power levels, locate

faults and polarity issues, and inspect and clean connector end-faces. Each SimpliFiber Pro

set includes the following industry-leading features:

• Dual-wavelength testing – complete testing in half the time

• Additional wavelengths to include 1490 and 1625 – calibrated to extend from

typical enterprise wavelengths for broader applications

• Min/Max – precision tracking of intermittent power fluctuations, a superior

alternative to the inaccurate “wiggle” test

• CheckActive™ – audible tone and display icon alerts you to a live wire

• Saves 1,000 results fully compatible with our popular LinkWare™ Cable Test

Management Software

• Quickly locate cable fault, polarity, and connector problems with VisiFault VFL

Fiber Testing, Troubleshooting and Certification

Model Description

SFPOWERMETER SimpliFiber Pro optical power meter; SC adapter included.

SFMULTIMODESOURCE

SimpliFiber Pro multimode 850/1300 light source. Fixed SC port

(with ST and LC testing capability available using hybrid test-reference

cord accessories purchased separately) – includes FindFiber™ source

capability.

SFSINGLEMODESOURCE

SimpliFiber Pro singlemode 1310/1550 laser light source. Fixed SC port

(with ST and LC testing capability available using hybrid test-reference

cord accessories purchased separately) – includes FindFiber™ source

capability.

To learn the truth about fiber optic inspection and cleaning – what to look for, when and

how to inspect ports and end faces, and how to keep them clean – please check out our

Best Practices in Fiber Optic Installation white paper at www.flukenetworks.com/whitepapers

22 www.flukenetworks.com//simplifiberpro

Fiber Test Kits

SimpliFiber Pro fiber test kits come in every configuration to meet your testing needs.

Each fiber test kit includes the following industry-leading features:

• Dual-wavelength testing – complete testing in half the time

• Additional wavelengths to include 1490 and 1625 – calibrated to extend from typical

enterprise wavelengths for broader applications

• Min/Max – precision tracking of intermittent power fluctuations. A superior alternative to the

inaccurate “wiggle” test

• CheckActive™ – audible tone and display icon alerts you to a live wire

• Saves 1,000 results fully compatible with our popular LinkWare™ Cable Test Management Software

• Quickly locate cable fault, polarity, and connector problems with VisiFault VFL

Complete Fiber Verification Kit (FTK1450)

The Complete Fiber Verification Kits are for network technicians and contractors who install and

maintain premise networks with both multimode and singlemode optical fiber. Use these kits to

verify optical loss and power levels at 850, 1300, 1310, 1490, 1550, and 1625 nm, inspect fiber

end-faces, locate cable faults, connector problems, and polarity issues.

Full-featured Inspection and Multimode Verification Kit (FTK1300 and FTK1350)

The Full-featured Inspection and Multimode Verification Kits are for network technicians and

contractors who install and maintain multimode premises network. Use these kits to verify optical

loss and power levels at 850 and 1300 nm, inspect fiber end-faces, locate cable faults, connector

problems, and polarity issues.

Basic Verification Kit (FTK1000 and FTK2000)

The Basic Verification Kit is a great starter kit for network technicians and contractors who install

and maintain fiber links. Available in single or multimode configurations, quickly verify optical loss

and power levels at 850 and 1300 nm or 1310 and 1550 nm. Add additional sources, microscopes,

and VFL options as needed.

Copper and Fiber Technician’s Kit (CIQ-FTKSFP)

Consisting of the CableIQ (CIQ-KIT) and the SimpliFiber Pro Basic Verification Kit (FTK1000), the

Copper and Fiber Technician’s Kit provides a robust combination of tools to help you expertly man-

age your network to it keep it running smoothly and inexpensively. Simple-to-use straight from the

box, you can do everything from quickly troubleshooting and qualifying cabling link bandwidth to

verifying optical fiber power and loss.

Fiber Testing, Troubleshooting and Certification

Model FTK1000 FTK1300 FTK1350 FTK1450 FTK2000

SimpliFiber Power Meter •••••

SimpliFiber Source 850/1300 MM source ••••

SimpliFiber Sources 1310/1550 SM source • •

FindFiber Remote ID source •••

FT120 200x FiberViewer •

FT500 FiberInspector • •

VisiFault Visual Fault Locator •••

NFC-Kit-Box (fiber optic cleaning kit) •

Professional durable carrying case •••••

23

email: info@flukenetworks.com

Test-Reference Cords, Adapters and Mandrels

Model Description

NFK1-EFLC-SC One 62.5 µm SC/SC Encircled Flux Launch Controller (two required for DTX)

NFK1-EFLC-LC One 62.5 µm SC/LC Encircled Flux Launch Controller (two required for DTX)

NFK2-EFLC-SC One 50 µm SC/LC Encircled Flux Launch Controller (two required for DTX)

NFK2-EFLC-LC One 50 µm SC/LC Encircled Flux Launch Controller (two required for DTX)

NF-MANDREL-50 Mandrel, 3 mm fiber cable, 50 µm (1)

NF-MANDREL-625 Mandrel, 3 mm fiber cable, 62.5 µm (1)

NF300SM Fiber Optic adapter, ST/ST, singlemode

NF310SM Fiber Optic adapter, SC/SC, singlemode

NFA-FC FC test adapters – set of two

NFA-LC LC test adapters – set of two

NFA-SC SC test adapters – set of two

NFA-ST ST test adapters – set of two

NFB1/2-LC/ST Kit of duplex MM 62.5 µm and 50 µm test cords with LC and ST adapters

NFK1-DPLX-FC Duplex MM 62.5 µm test reference cords for FC adapter – set of two

NFK1-DPLX-LC Duplex MM 62.5 µm test reference cords for LC adapter – set of two

NFK1-DPLX-SC Duplex MM 62.5 µm test reference cords for SC adapter – set of two

NFK1-DPLX-ST Duplex MM 62.5 µm test reference cords for ST adapter – set of two

NFK1-LC LC accessory kit includes (2) duplex MM 62.5 um patch cables for LC adapter,

dual LC-to-dual LC test jumper and adapter

NFK1-MANDREL-KIT Kit, mandrel, 3 mm fiber cable, 50 µm and 62.5 µm

NFK2-DPLX-FC Duplex MM 50 µm test reference cords for FC adapter – set of two

NFK2-DPLX-LC Duplex MM 50 µm test reference cords for LC adapter – set of two

NFK2-DPLX-SC Duplex MM 50 µm test reference cords for SC adapter – set of two

NFK2-DPLX-ST Duplex MM 50 µm test reference cords for ST adapter – set of two

NFK3-DPLX-FC Duplex SM test reference cords for FC adapter – set of two

NFK3-DPLX-LC Duplex SM test reference cords for LC adapter – set of two

NFK3-DPLX-SC Duplex SM test reference cords for SC adapter – set of two

NFK3-DPLX-ST Duplex SM test reference cords for ST adapter – set of two

NFK1-SMPLX-SC (2) Simplex MM 62.5 um test reference cords for SC adapter

NFK1-SMPLX-LC (2) Simplex MM 62.5 um test reference cords for LC adapter

NFK1-SMPLX-ST (2) Simplex MM 62.5 um test reference cords for ST adapter

NFK2-SMPLX-SC (2) Simplex MM 50 um test reference cords for SC adapter

NFK2-SMPLX-LC (2) Simplex MM 50 um test reference cords for LC adapter

NFK2-SMPLX-ST (2) Simplex MM 50 um test reference cords for ST adapter

NFK3-SMPLX-SC (2) Simplex SM test reference cords for SC adapter

NFK3-SMPLX-LC (2) Simplex SM test reference cords for LC adapter

NFK3-SMPLX-ST (2) Simplex SM test reference cords for ST adapter

Fiber Testing, Troubleshooting and Certification

24 www.flukenetworks.com/optifiber

Fiber Plant Characterization & Troubleshooting (Tier 2 Certification)

OptiFiber® OTDR

OptiFiber® OTDR is the fiber testing and troubleshooting solution to ensure the health of your

most critical network cabling.

OptiFiber integrates power/loss, fiber length measurement, OTDR analysis and fiber connector

end-face imaging to provide a higher tier of fiber certification and diagnostics. The companion

LinkWare PC software documents, reports and manages all test data. OptiFiber enables network

owners of all experience levels to certify fiber to customer specifications and industry standards,

troubleshoot connection-rich links, and thoroughly document results.

• Diagnose and solve fiber problems with integrated ChannelMap™, Auto OTDR and fiber

end-face inspection

• Boost productivity with an easy-to-use interface and small, lightweight design

• Certify fiber using integrated Auto OTDR analysis, automated loss and length

measurements and fiber end-face inspection

• Enhance visibility into premise, campus and metro networks with short event dead zones

• Document fiber with LinkWare™ Cable Test Management software

Model Description

OF-500-M OptiFiber multimode value bundle – includes mainframe, multimode module and standard accessories

OF-500-S OptiFiber singlemode value bundle – includes mainframe, singlemode module and standard accessories

OF-500-MS OptiFiber multimode/singlemode value bundle – includes mainframe, multimode and singlemode modules

and standard accessories

OF-500-M10 OptiFiber datacenter-ready certifying OTDR (MM) – includes mainframe, multimode OTDR/OPM/LL module, 62.5 µm and

50 µm launch fibers, 200x/400x inspection camera, and standard accessories

OF-500-MS35 OptiFiber enterprise-ready certifying OTDR (MM/SM) – includes mainframe, multimode OTDR/OPM/LL module, 62.5 µm,

50 µm, and singlemode launch fibers, 200x/400x inspection camera, and standard accessories

OF-500-MS45 OptiFiber premium enterprise-ready certifying OTDR (MM/SM) – includes contents and capabilities of OF-500-MS35,

plus SmartRemote unit components (DTX-1800/RU, DTX-MFM2/SU, DTX-SFM2/SU, and accessories)

OF-500-MSDTX

OptiFiber enterprise-ready certifying OTDR (MM/SM) + DTX CableAnalyzer – includes contents and capabilities of

OF-500-MS35, plus DTX-1800 INTL, DTX-MFM2/SU & DTX-SFM2/SU modules, 62.5µm, 50µm, and SM premium test

reference cords

GLD-OF 1-year of Gold Support – OptiFiber Mainframe and battery (no module). Models: OF-500

GLD-OF-500-M 1-year of Gold Support – OptiFiber Multimode Value Bundle. Models: OF-500-M, OF-500-01,

OF-500-01/50M, OF-500-02, OF-500-02/50M or OF-400-01.

GLD-OF-500-S 1-year of Gold Support – OptiFiber Singlemode Value Bundle. Models: OF-500-S, OF-400-02 or OF-500-03.

GLD-OF-500-MS 1-year of Gold Support – OptiFiber MM/SM Value Bundle. Models: OF-500-MS or OF-400-03.

GLD-OF-500-M10 1-year of Gold Support – OptiFiber Datacenter-Ready Certifying OTDR(MM).

Models: OF-500-M10, OF-500-10 or OF-500-10/50M.

GLD-OF-500-MS35 1-year of Gold Support – OptiFiber Enterprise-Ready Certifying OTDR(SM/MM) Bundle.

Models: OF-500-MS35, OF-500-35 or OF-500-35/50M.

GLD-OF-500-MS45 1-year of Gold Support – OptiFiber Premium Enterprise-Ready Certifying OTDR (MM/SM) Bundle.

Models: OF-500-MS45 or OF-500-45.

GLD-OF-500-MSDTX 1-year of Gold Support – OptiFiber Enterprise-Ready Certifying OTDR + DTX CableAnalyzer (MM/SM) Bundle.

Models: OF-500-MSDTX or OF-500-50.

GLD-OFTM-53XX 1-year of Gold Support – OptiFiber Probe Kit. Models: OFTM-5352

GLD-OFTM-56XX 1-year of Gold Support – OptiFiber Module. Models: OFTM-5611B or OFTM-5612B

GLD-OFTM-57XX 1-year of Gold Support – OptiFiber Module. Models: OFTM-5730,OFTM-5731 or OFTM-5732

GLD-OFSR-MM-REM 1-year of Gold Support – OptiFiber Smart Remote with Multimode Module Bundle. Model: OFSR-MMREM

GLD-OFSR-REMOTEMOD 1-year of Gold Support – OptiFiber Smart Remote Modules. Models: OFSR-SFM Singlemode or OFSR-MFM Multimode

Fiber Testing, Troubleshooting and Certification

25

email: info@flukenetworks.com

Fiber Testing, Troubleshooting and Certification

OptiFiber Modules/Accessories

Launch Fibers

Model Description

OFTM-5610B Multimode OTDR module

OFTM-5611B Multimode OTDR module with power meter

OFTM-5612B Multimode OTDR module with power meter / loss-length

OFTM-5730 Singlemode OTDR module with visual fault locator

OFTM-5731 Singlemode OTDR module with power meter / visual fault locator

OFTM-5732 Singlemode OTDR module with power meter / loss-length / visual fault locator

OFSR-MMREM OptiFiber Smart Remote with multimode module bundle

OFSR-SFM Singlemode module for OptiFiber Smart Remote

OFSR-MFM Multimode module for OptiFiber Smart Remote

OFTM-5352 FiberInspector Pro video probe (250x/400x). See page 19 for applicable Fiber Inspector Pro tips.

Model Description

NFK1-LAUNCH SC/SC launch fiber, 62.5 µm, 100 m

NFK2-LAUNCH SC/SC launch fiber, 50 µm, 100 m

NFK3-LAUNCH SC/SC launch fiber, singlemode, 130 µm

NFK1-LAUNCH-ST SC/ST launch fiber, 62.5 µm

NFK1-LAUNCH-LC SC/LC launch fiber, 62.5 µm

NFK1-LAUNCH-FC SC/FC launch fiber, 62.5 µm

NFK2-LAUNCH-ST SC/ST launch fiber, 50 µm

NFK2-LAUNCH-LC SC/LC launch fiber, 50 µm

NFK2-LAUNCH-FC SC/FC launch fiber, 50 µm

NFK2-LAUNCH-E2K SC/E2000 launch fiber, 50 µm

NFK3-LAUNCH-ST SC/ST launch fiber singlemode

NFK3-LAUNCH-LC SC/LC launch fiber singlemode

NFK3-LAUNCH-FC SC/FC launch fiber singlemode

NFK3-LAUNCH-E2K SC/E2000 launch fiber singlemode

Visit www.flukenetworks.com/OTDRdemo

to view the product demo.

26 www.flukenetworks.com/dtxcompactotdr

Complete DTX 1800 Copper/Fiber Certification Kit

(DTX-1800-MSO) Choose this option if you install and

maintain premise networks with both copper and fiber.

Includes a mainframe and Smart Remote along with the

complete package of testing and troubleshooting options.

Copper/Multimode Fiber Certification Kit (DTX-1800-MO)

Choose this option if you install or certify copper and fiber

in datacenters. Includes a DTX-1800 mainframe, a Smart

Remote, two multimode DTX MFM2 Fiber Modules, and one

DTX Compact OTDR Module.

DTX Compact OTDR Starter Kit (DTX-QUAD-OTDR)

Choose this option if you are looking for an OTDR for fiber

troubleshooting and extended certification. Copper and

Tier 1 fiber certification can be added later with addition

of a Smart Remote and other options and accessories.

DTX Compact OTDR Module (DTX-OTDR-QMOD)

Choose this option if you already own a DTX mainframe and

want to add OTDR capability and want to purchase launch

fibers separately.

DTX Compact OTDR Kit (DTX-OTDR-KIT)

Choose this option if you own a DTX CableAnalyzer with

loss/length fiber capability and want to add an OTDR option

and accessories.

DTX Fiber Certification Kit (DTX-OTDR/LL-KIT)

Choose this option if you own a DTX CableAnalyzer

without fiber capability. This kit will give you complete

fiber certification and troubleshooting capability.

DTX Compact OTDR

Fluke Networks Compact OTDR module is the latest enhancement to the DTX CableAnalyzer. In

addition to performing copper certification and diagnostics, your team can become fiber test

experts when you decide to grow your business and turn your cable tester into an OTDR. This full

featured, compact OTDR module snaps onto a DTX CableAnalyzer and provides unmatched ease of

use for premises fiber testing. Choose a kit that includes a DTX mainframe and smart remote,

options for copper certification, optical loss/length capability, or order a module and software

that can be installed on a your own DTX CableAnalyzer.

Model

DTX 1800-

MSO

DTX-

QUAD-OTDR

DTX-

OTDR-KIT

DTX-OTDR/

LL-KIT

DTX-OTDR-

QMOD

DTX-

1800-MO

850/1300/1310/1550 OTDR Module • • • • • •

DTX-1800 Mainframe • • •

DTX Smart Remote • •

Copper accessories • •

Fiber accessories • •

Launch fibers • • •

FiberInspector Mini •

Fiber Optic Cleaning Kit • • •

Standard protective carrying case for DTX

CableAnalyzer •

Protective carrying case for DTX

Compact OTDR and fiber accessories • • • • •

Set of Multimode Fiber Modules (MFM2) • • •

Set of Singlemode Fiber Modules (SFM2) • •

Gold Support GLD-DTX-MSO DTX-QUAD-OTDR

120 DTX-OTDR-KIT DTX-OTDR/

LL-KIT GLD-DTX-OTDR GLD-DTX-MO

• Turn your cable tester into an OTDR

• Test and troubleshoot fiber like an expert with easy-to-use DTX Compact OTDR

• Shoot OTDR traces on singlemode and multimode links at 850 nm, 1300 nm, 1310 nm, 1550 nm

• Perform extended Tier 2 certification with one powerful cable tester

Fiber Testing, Troubleshooting and Certification

27

email: info@flukenetworks.com

Fiber Testing Best Practices

With 40 G/100 G infrastructure deployments in the datacenter quickly becoming reality, the

shrinking loss budgets of optical fiber cabling due to increasing bandwidth demands mean that

reliable and efficient initial installations are now more important than ever. To minimize costly

installer/contractor callbacks, network technician troubleshooting time, and unnecessary

network downtimes, fiber-handling best practices should always be followed.

The easy-to-understand Fiber Best Practice Series was created by Fluke Networks to educate

about important optical fiber best practices, including:

• Fiber inspection and cleaning

• Loss-length fiber testing (Tier 1 certification)

• Fiber plant characterization and troubleshooting (Tier 2 certification)

Whether you want just the basics or prefer to dive into the technical details, Fluke Networks

provides a myriad of materials to help you understand each of these fiber best practices, when

and why you should follow them, and simple step-by-step procedures that any technician within

your organization can follow to ensure your fiber networks stay up and running.

Download valuable Fiber Testing Best Practices resources at www.flukenetworks.com/FiberBP

Fiber Testing, Troubleshooting and Certification

Fiber Testing Best Practices

Pocket Guide

Fiber Inspection and Cleaning Fiber Plant Characterization &

Troubleshooting (Tier 2 Certification)

Loss-Length Fiber Testing

(Tier 1 Certification)

28 www.flukenetworks.com

Fluke Networks offers the most reliable set of network installation tools on the market – each one designed to streamline the

network installation job. We have all the essential tools you need for installation and termination of high-performance voice, data

and video networks. The JackRapidTM Termination Tool saves time and increases accuracy by seating and terminating all wires at

once with a simple squeeze of the handle. The Pro-Tool Kits combine all professional tools you need to cut, strip, clean and connect

network phone and data lines to blocks and jacks. Our world-renowned punchdown tools, with a variety of interchangeable blades,

deliver high-quality, accurate terminations on the first punch. Industry standard Electrical Contractor Telecom Kits offer all the

telecommunications tools and test equipment technicians need in one durable case.

Tools and Test Kits

Fluke Networks offers a wide range of network installation tools – each one designed to streamline

the network installation job

29

email: info@flukenetworks.com

JackRapid™ Termination Tool

The JackRapid termination tool is the industry’s most innovative and time-saving

installation tool. JackRapid allows you to terminate jacks eight times faster than traditional

impact tools – with accuracy that’s unmatched. The patented jack termination tool seats and

terminates all wires simultaneously with one squeeze of an ergonomic handle. The built-in blade

cuts off the excess wire after it is seated in the connector, eliminating the need for a secondary

trim step. Simple, one-handed operation reduces hand fatigue. With JackRapid, you’ll never punch

into the palm of your hand or through drywall again.

• Cuts installation time – easy-to-use handle, seats and cuts all wires at once, saving you up to

two minutes installation time per jack

• High-quality, consistent terminations – no more compromised connections and wasted jacks

• Simple, one-handed operation with an ergonomically designed handle reduces hand fatigue

Model Description

JR-LEV-1 JackRapid termination tool (for Leviton 41106, 41108, 5G108)

JR-LEV-1-H JackRapid replacement blade head (for Leviton 41106, 41108, 5G108)

JR-SYS-UNI-1 JackRapid termination tool (for Systimax MPS100E, C5,M1BH and Uniprise UNJ600/500/300)

JR-SYS-UNI-1-H JackRapid replacement blade head (for Systimax MPS100E, C5, M1BH and Uniprise UNJ600/500/300)

JR-LEV-2 JackRapid termination tool (for Leviton 61110, 5G110, 6110G)

JR-LEV-2-H JackRapid replacement blade head (for Leviton 61110, 5G110, 6110G)

JR-SYS-2 JackRapid termination tool (for Systimax MGS400, MGS500, MFP420, MFP520)

JR-SYS-2-H JackRapid replacement blade head (for Systimax MGS400,MGS500, MFP420, MFP520)

JR-ORT-2 JackRapid termination tool (for Ortronics TJ5E00, TJ600, TJ610)

JR-ORT-2-H JackRapid replacement blade head (for Ortronics TJ5E00,TJ600, TJ610)

JR-ADC-2 JackRapid termination tool (for ADC KM8, Copper Ten®)

JR-ADC-2-H JackRapid replacement blade head (for ADC KM8, Copper Ten®)

JR-ERGOHANDLE JackRapid ergonomic handle

JR-PAN-2 JackRapid termination tool (for Panduit NK688M)

JR-PAN-2-H JackRapid replacement blade head (for Panduit NK688M)

Get accurate terminations and clean, consistent cuts every time with the JackRapid Termination Tool.

1. Strip cable jacket with a standard cable

stripper or the built-in cable stripper.

2. Determine wiring scheme.

Dress all four pairs (eight wires).

3. Insert jack in JackRapid front first with

IDC slots facing blades of JackRapid.

4. Ensure jack is completely and

securely inserted in jack holder bed

with IDC slots facing the blades.

5. Pull trigger completely and remove

excess wire prior to releasing trigger.

6. Wires will be seated and cut

for a solid termination.

Tools and Test Kits

30 www.flukenetworks.com/punchdowntools

• Industry standard with lifetime warranty

• Accepts standard industry blades

• Lightweight and easy-to-use

• Adjustable spring impact mechanism allows low impact for

24/26 gauge wire or high impact for 22-gauge wire

Model Description

10054000 D814 Impact Tool

10055000 D814 Impact Tool with EverSharp

66 blade

10055110 D814 Impact Tool with EverSharp

110 blade

10055200 D814 Impact Tool with EverSharp

110 and EverSharp 66 blade

10055501 D814 Impact Tool with EverSharp

110, EverSharp 66 blade and free

Wood Screw Starter Punch blade

10055503 D814 Impact Tool with BIX and

Eversharp 66/110 cut blade

D814™ Impact Tool

The D814 Impact Tool is a deluxe, all-in-one, telecom punch-

down tool and comes with the 66/110 blade. Impact wheel has

high and low settings. Automatic spring mechanism provides

the right impact to seat and/or terminate wires.

• Ensures clean, smooth terminations ready for

optical transmission

• Industry standard, internationally accepted with

lifetime warranty

• Hook and spudger tools are built into the handle

• Automatic spring handle – choose low impact for 24/26

gauge wire or high impact for 22-gauge wire

• Accept Phillips-head or flat screwdriver blade

Model Description

10051000 D914 Impact Tool

10051100 D914 Impact Tool with EverSharp

66 blade

10051110 D914 Impact Tool with EverSharp

110 blade

10051120 D914 Impact Tool with EverSharp

110 and EverSharp 66 blade

10051501 D914 Impact Tool with EverSharp

110, EverSharp 66 blade and

free screwdriver blade

D914™ Impact Tool

The D914 Impact Tool is the only punchdown tool to combine

torque and impact. It combines two versatile tools, the hook

and spudger, into the handle. 66/110 blades available.

• Industry standard, internationally accepted with

lifetime warranty

• Hook and spudger tools are built into the handle

• Automatic spring handle – choose low impact for 24/26

gauge wire or high impact for 22-gauge wire

• Accepts Phillips-head or flat screwdriver blade

D914™S Impact Tool

SoftTouch D914S Impact Tool offers a new ergonomic design

with a soft rubber handle for better grip and rounded edges to

absorb more of the impact recoil. Includes built-in probe pic/

spudger and torque, allowing you to choose from high-and

low-impact settings.

Model Description

10061000 D914S Impact Tool

10061100 D914S Impact Tool with EverSharp

66 blade

10061110 D914S Impact Tool with EverSharp

110 and EverSharp 66 blade

10061501 D914S Impact Tool with EverSharp

110, EverSharp 66 blade and free

screwdriver blade

10061503 D914S Impact Tool with BIX and

EverSharp 66/110 cut blade

10061810 D914S Impact Tool with EverSharp

66/110 cut blade

D-Impactor™ 5-Pair Impact Tool

The D-Impactor 5-pair impact tool easily cuts and terminates

five copper pairs on a 110 block. This rugged, easy-to-use tool

saves time and minimizes hand stress. The patented individual-

ly molded blades eliminate the chance of metallic shorts ensur-

ing optimal performance of your network. Lifetime warranty.

Model Description

10059000 D-Impactor

(five-pair 110 impact tool)

10059030 D-Impactor replacement blade

• Single reversible blade part

• Ease of use and reversing of cutting blade

• Fewer moving parts allow for smoother push down, less hand stress

Tools and Test Kits

31

email: info@flukenetworks.com

Tools and Test Kits

Blades

Fluke Networks increases the versatility and flexibility of its line of impact tools by offering a wide variety of inter-

changeable blades that permit each tool to perform multiple functions. From our high-performance EverSharp blades,

to our unique blade storage kit cases, Fluke Networks has the blades you need to terminate blocks and jacks quickly.

EverSharp™ Blades

Fluke Networks offers three EverSharp blade designs:

the EverSharp 66/110 cut blade, the EverSharp 110

blade and the EverSharp 66 blades. Through special

processing of the metal, these high performance

blades stay sharper longer than other competitive

blades. These blades fit the D914S, D914 and D814

punchdown tools.

Model Description

10056500 EverSharp 66 blade

10176500 EverSharp 110 blade

10178600 EverSharp 110/66 cut

blade

Blade Storage Kit

This unique blade storage case helps prevent loss,

misplacement and damage of impact blades by

keeping them all together in one convenient hard

case. They are sized to fit neatly into shirt or

pants pocket or clipped onto belt or tool pouch.

Model Description

10979003 66 blade kit

(2-66 blades, 1-630 blade,

1-Wood Screw Starter

blade)

10979004 110 blade kit

(2-110 blades, 1-66 blade,

1-Wood Screw Starter

blade)

10979002 Blade storage case only

10056000 10056003 10057000 10176000 10436001 10465001

66 blade 8762D-66

extra long

cutter blade

630 blade 110 blade Centerpunch blade 3M System D blade

10056225

66 blade, bulk

(must be ordered in

multiples of 100)

10176225

110 blade, bulk

(must be ordered in

multiples of 100)

10645001 10565000 10565110 10665000 10051200 10051300

Wood screw starter

punch

Cut blade,

compatible with

Krone/ADC

Cut blade,

compatible with

Krone/ADC, 110

BIX blade Screwdriver blade

(D914 or D914S only)

Torque Adapter

blade

32 www.flukenetworks.com/toolkits

Pro-Tool™ Kits

All the professional tools you need to cut, strip, clean and connect network phone and data lines

to blocks and jacks. Bundled together in our sleek form-fitting PVC Dur-A-GripTM tool pouch – holds

your tools securely inside, even upside down. Five tool kit combinations to choose from to meet a

multitude of applications.

• All kits include ergonomically designed Dur-a-Grip pouch for convenient tool storage on belt

• D914 and D814 industry standard punchdown tools make for solid terminations

• Easy-to-use cable stripper quickly rings and slits many types of cable

• Cut and strip wire cleaner and faster with the Electrician’s D-Snips

Model Description

11291000 IS40 Pro-Tool Kit

11291400 Pro-Tool Kit IS40 pouch only

11292000 IS50 Pro-Tool Kit

11292400 Pro-Tool Kit IS50 pouch only

11293000 IS60 Pro-Tool Kit

11293400 Pro-Tool Kit IS60 pouch only

IS60 Pro-Tool Kit

• D914S Impact tool

• Electrician’s D-Snips

• Cable stripper

• Mini Maglite®

• Dur-a-Grip pouch

• EverSharp 66/110 cut blade

IS50 Pro-Tool Kit

• D914S Impact tool

• Electrician’s D-Snips

• Cable stripper

• EverSharp 66/110 cut blade

• Dur-A-Grip pouch

Kit Descriptions

IS40 Pro-Tool Kit

• D814 Impact tool

• Electrician’s D-Snips

• Cable stripper

• EverSharp 66/110 cut blade

• Probe pic

• Dur-A-Grip pouch

Tools and Test Kits

33

email: info@flukenetworks.com

Tools and Test Kits

Electrical Contractor Telecom Kits

Fluke Networks Electrical Contractor Telecom Kits are comprised of industry standard

telecommunications tools and test equipment. Contents include D814™ Impact Tool, cable

stripper, probe pic, Electrican’s D-Snips, standard 4-wire modular adapter and EverSharp™

66/110 cut blade. Soft carrying case included for easy organization.

• Choose either Kit I with TS®30 Test Set or Kit II with Pro3000 Analog Tone and Probe

• D814 industry standard punchdown tool for reliable terminations

• EverSharp 66/110 cut blade provides flexibility for different block and jack terminations

• Cable stripper quickly rings and slits many types of cable

• Use the probe pic to check for loose or damaged connections

• Cut and strip wire cleaner and faster with the Electrician’s D-Snips

• Connect to jacks for testing with the standard 4-wire modular adapter

• A soft zippered pouch keeps your tools all in one convenient place

Model Description

11290000 Electrical Contractor Telecom Kit I (with TS®30 Test Set)

11289000 Electrical Contractor Telecom Kit II (with Pro3000™ Analog tone and probe kit)

11289400 Soft case, Electrical Contractor Telecom kit

Kit Descriptions

Electrical Contractor Telecom Kit I

• TS®30 Test Set with angled bed-of-nails cord

• D814 Impact Tool

• EverSharp 66/110 cut blade

• Electrician’s D-Snips

• Cable stripper

• Standard 4-wire modular adapter

• Probe pic

Electrical Contractor Telecom Kit II

• Pro3000 Analog tone and probe

• D814 Impact Tool

• EverSharp 66/110 cut blade

• Electrician’s D-Snips

• Cable stripper

• Standard 4-wire modular adapter

• Probe pic

34 www.flukenetworks.com/handtools

• Short blade (1.75 in) for strength

• Cutlery-steel blade for durability

• No slip, easy-to-grip handle

• Cuts various insulation types

• Ergonomic design provides 1½ times the cutting force with

half the effort

• High-quality forged steel construction for strength and durability

• File and scraper on both blades for cleaning wire

• Notched blade for stripping 19- and 23-gauge wire

• Cuts up to 16-gauge solid and 12-gauge stranded wire

• Embedded flat cable cutter and stripper

Model Description

44400000 Cable splicing knife

Model Description

44300000 D-Snips

Model Description

11212530 Modular crimper

D-Snips™

Fluke Networks Electrician’s D-Snips™ offer a unique

ergonomically-designed handle that leverages your power,

providing 1½ times the cutting force with half the effort.

Modular Crimper

Fluke Networks all-in-one crimping tool for WESS type

6- and 8-position modular telephone plugs. Crimps

8-position RJ-45 connectors and 4- and 6-position

RJ-11 and RJ-12 connectors.

Cable Splicing Knife

Fluke Networks cable splicing knife is the perfect tool for

splitting cable sheaths. Soft, easy-to-grip handle and cut-

lery-steel blade for durability and long-lasting blade edge.

Model Description

44500000 Electrician’s snips

• High-quality forged steel construction for strength and durability

• File and scraper on both blades for cleaning wire

• Notched blade for stripping 19- and 23-gauge wire

• Cuts up to 16-gauge solid and 12-gauge stranded wire

• Serrated blade for non-slip wire cutting

Electrician’s Snips

These versatile electrician’s snips feature a file and scraper

on both blades for easy wire cleaning. They also feature a

handy notched scissor blade for quickly stripping 19- and

23-gauge wire. Made to last with high-quality forged steel,

these snips are a must have for your tool bag.

Tools and test kits

35

email: info@flukenetworks.com

Tools and Test Kits

• Needle nose pliers

• UR/UY/UG connector crimper

• Wire stripper hole

• Built-in side cutter

• Rubber coated handles for non-slip grip

• Trace and pull wires with the pic end

• Check for loose or damaged connections

• Spread apart wires for direct access

• Compact size

• Full line of cable strippers offered

• Round cable stripper for a variety of flexible round cable

• Coax strippers with two or three levels

Model Description

44600000 Probe pic, 105 degree

Model Description

11230002 Cable stripper (round cable)

44210013 Double slotted stripper with cutter,

22/24 gauge

44200013 Double slotted stripper 22/24

gauge

11231257 Coax stripper, 2-level

11231255 Coax stripper, 2 and 3-level

Probe Pic

Fluke Networks handy, pocket-sized insulation probe is ideal

for checking for loose or damaged connections or to spread

apart wires for direct access. Its compact size also makes it

perfect for using the pic end for tracing or pulling wires from

a bunch.

Need-L-Lock™ Crimping Pliers

The Need-L-Lock pliers’ patented four-in-one tool combines

UR/UY/UG connector crimper with needle-nose pliers so you

can carry one less tool on your belt. Aligned crimping jaws

come down square ensuring a solid connection. Jaws are

grooved to provide a better grip on wires and feature a

built-in cutter and wire stripper.

Cable Strippers

Fluke Networks line of cable strippers includes a double

slotted cable stripper for 22/24 AWG wire installation and

a coax stripper to perform 2-level and 3-level stripping of

RG58/59 coaxial cables. We also offer a combo stripper

that cuts and rings Teflon®, smoothly slits fiber, copper

and coaxial cables, and rings 25-100 pair cable.

• Two hex head sockets (7/16 inch and 3/8 inch)

• Color-coded socket ends for quick size identification

• Wrench body constructed of tough, impact resistant and abrasion resistant material

• Socket ends guaranteed not to split or break up to a maximum torque of 45 pounds

• Two models available with wire stripper in handle (22 or 24 gauge)

Can Wrench

Fluke Networks can wrenches allow universal access to

telephone boxes and pedestals. Open telephone box

fasteners and tightens nuts on binding post terminals.

Model Description

44007000 Can wrench, hex head

44507003 Can wrench with stripper, 22 gauge

44507004 Can wrench with stripper, 24 gauge

10660001 Security key insert

Model Description

11294000 Need-L-Lock crimping pliers

36 www.flukenetworks.com/handtools

Basic tools to get the job done quickly and accurately

While it’s easy to get caught up in the technology of today’s cable testers, it’s important to remember that the

installation starts with some very basic tools. And having the right tool can make all the difference. To begin

cutting, stripping, and connecting cabling blocks and jacks, you need a punchdown tool with impact force, a

cable stripper, and a pair of scissors. You only have two hands, so a durable pouch to carry these tools will be

helpful for transport and ease-of-use once you are on the job.

Punchdown Tool

A punchdown tool properly terminates telecommunications cables. When any wire is punched down, force is

required to seat and terminate the wire. The basic impact tool has a spring-loaded head, which you compress

using the force of your hand. Once the spring reaches full compression, it’s automatically released and the

force is transferred to the head of the impact tool, which seats the wire.

Most impact tools accommodate a number of interchangeable blades, depending on the cabling system at your

job site. The tool helps you push each wire into the IDC tower to make a permanent connection. Some punch-

down tool blades have a cut side that removes the excess wire after the wire is pushed onto the connector;

others require you to cut off the wire snips. Also, some punchdown tools offer a soft, rubber handle. This gives

you a better grip and reduces wear and tear on your hand. Let the tool absorb some of the impact recoil and

give your hand a rest!

Cable Stripper

A cable stripper with an adjustable gauge guarantees fast, easy removal of outer insulation from all unshielded

twisted pair, shielded twisted pair and multicore cables. An adjustable depth gauge and a reference for check-

ing the length to be stripped ensures repeatable results and improves work quality. Using alternative methods

such as a pocket knife or scissors could result in stripping more cable sheath than necessary and damaging the

cable itself.

Snips

Professional snips are important for a fast, clean, and safe cut. You’ll need to cut

cable and trim excess wires on every job. Some specialty tools offer a unique,

ergonomically-designed handle that leverages your physical strength, providing

1½ times the cutting force with half the effort. The special “tail” on the

handle that provides the added leverage also minimizes hand fatigue.

Armed with a punchdown tool, a cable stripper and pair of

professional snips, you will be well on your way to a

successful installation. A professional, durable pouch that

holds these tools and clips to your belt will save you

time and give you more freedom.

Tools and test kits

IT Networking

Test and Troubleshoot

AirCheckTM Wi-Fi Tester ...........................39

EtherScope™ Series II Network Assistant ...............40

NetTool™ Series II Inline Network Tester ...............41

LinkRunner™ Pro and Duo Network Multimeters ..........42

Monitoring, Analysis and Troubleshooting

OptiView® Management Appliance with Reporter .........44

OptiView® Portable Network Analyzer .................45

ClearSightTM Analyzer ............................46

Network Time MachineTM ..........................47

Tap Solutions .................................48

AirMagnet Survey ..............................49

AirMagnet Planner ..............................49

AirMagnet WiFi Analyzer ..........................49

AirMagnet Spectrum XT ..........................50

AirMagnet VoFi Analyzer ..........................50

AirMagnet Enterprise ............................50

IT Networking

37

www.flukenetworks.com/ITnetworking

38 www.flukenetworks.com/aircheckresources

Today’s networks are typically very stable. The problem is they aren’t static. Management and users are constantly demanding

new technologies, new services, and better performance, which inevitably requires changing infrastructure, deploying new

applications, and dealing with security. The more your network changes, the more you need to improve network vision and

control to help you overcome the different types of challenges you encounter every day.

With Fluke Networks family of portable network testers, frontline technicians get a unique view into their LAN, WLAN, and VLAN

networks. These tools help network professionals clearly see all aspects of their network. Moves, adds, and changes as well as

complex troubleshooting tasks are sped up with the use of these testers. Take these tools anywhere, anytime, to isolate any

problem… fast.

Test and Troubleshoot

Complete line of portable network testers to give frontline technicians vision into their

LAN, WLAN, and VLAN networks

39

email: info@flukenetworks.com

Test and Troubleshoot

AirCheck™ Wi-Fi Tester

The AirCheck Wi-Fi Tester allows network professionals to quickly and easily troubleshoot

802.11 a/b/g/n networks.

Its intuitive design makes it simple for anyone to quickly master AirCheck. Instant power-up

and streamlined tests give answers in seconds so you can close trouble tickets faster –

making technicians and users alike more productive. Easily manage test results and quickly

create reports using AirCheck Manager software. From start to finish, AirCheck helps take the

guesswork out of everyday wireless troubleshooting.

• Dedicated, handheld 802.11 a/b/g/n wireless network tester with instant-on technology

• Rapidly perform a wireless discovery to fully assess your current wireless

security settings and network availability

• See wireless network utilization by channel and quickly determine

if it is 802.11 traffic or non-802.11 interference

• Robust and in-depth WLAN connection tests - from probing to

DHCP request to ping

• Quickly identify and locate wireless access points whether

authorized or rogue

• Fully document your troubleshooting session thus enabling fast

trouble ticket resolution or problem escalation

Model Description

AirCheck AirCheck Wi-Fi Tester – includes AirCheck tester, USB cable, soft case, Getting

Started Guide, and CD with AirCheck Manager software and User Manual

ACK-LRPRO

AirCheck Frontline Troubleshooting Kit with LinkRunner Pro – includes AirCheck

tester, external directional antenna, USB cable, carrying case, Getting Started

Guide, extra LION battery, and CD with AirCheck Manager software and User Manual,

LinkRunner Pro Standard Kit, and PoE Detector.

AIRCHECK-5PK* AirCheck 5 Pack – includes five (5) AirCheck testers and five (5) free external

directional antennas

AIRCHECK-10PK* AirCheck 10 pack – includes a bonus free AirCheck tester, so you receive

11 AirCheck testers, and 11 free directional antennas

ES2-PRO-SX/I-ACK EtherScope Series 2 LAN WLAN SX Fiber ITO + AirCheck – includes AirCheck Wi-Fi

Tester and EtherScope Series 2 LAN and WLAN with fiber and ITO options

ES2-PRO-SXI-LR-ACK

EtherScope S2 LAN WLAN SX Fiber ITO + LRPRO + AirCheck-Kit – includes AirCheck

Wi-Fi Tester with extra Lithium Ion battery, directional antenna and hardcase,

EtherScope E Series 2 LAN and WLAN with fiber and ITO options, and LinkRunner Pro

with Reflector, Lithium Ion battery, and software case

GLD-ACK 1-year of Gold Support – AirCheck

Accessories

EXTANT-RPSMA External Directional Antenna, RSMA connector

WBP-LION AirCheck Lithium Ion Replacement Battery

POE-Detector Power over Ethernet Detector

MS-Auto-Ch Auto Charger

DTX-ACUN AC Charger, Universal

* Please note that the AirCheck 5 and 10 packs listed above are only available in the US and Canada.

40 www.flukenetworks.com/techtools

EtherScope™ Series II Network Assistant

A handheld 10/100/Gigabit and 802.11 wireless LAN analyzer that assists frontline IT profession-

als with network installation, LAN validation and troubleshooting. Verify and edit infrastructure

configurations. Validate LAN services and measure end-to-end Ethernet performance at rates up

to 1 Gbps. Troubleshoot wired and wireless LAN problems fast.

• The essential toolkit for network first responders. The right combination of troubleshooting tools

in a handheld platform to help network professionals solve a wide range of problems fast

• Assists network installers with Ethernet performance measurement, installation

configuration and LAN validation

• Analyze 10/100/Gigabit twisted pair and 100/Gigabit fiber optic Ethernet LANs. Troubleshoot

switched networks. Discover devices, networks and VLANs. Monitor traffic statistics

• Analyze 802.11a/b/g wireless LANs. Troubleshoot performance and connectivity issues. Discover

access points, mobile clients and networks. Secure your WLAN. Identify and locate unauthorized

rogue devices, including 802.11n access points

• Measure end-to-end Ethernet performance of LAN and WAN links using IETF RFC 2544 and

advanced tests at rates up to 1 Gbps over copper or optical fiber cabling

Model Description

ES2-LAN-SX EtherScope Series II Network Assistant with 802.3 LAN analysis and fiber optic

interface

ES2-LAN-SX/I-KIT

Kit – includes an EtherScope Series II Network Assistant with 802.3 LAN analysis,

fiber optic interface, and ITO/RFC 2544 tests; plus a LinkRunner Pro with Reflector,

rechargeable battery and carrying case

ES2-PRO-SX/I-ACK

Kit – includes an EtherScope Series II Network Assistant with 802.3 LAN analysis,

802.11 WLAN analysis, fiber optic interface, and ITO/RFC 2544 tests; plus an

AirCheck Wi-Fi Tester

ES2-PRO-SXI-LR-ACK

Kit – includes an EtherScope Series II Network Assistant with 802.3 LAN analysis,

802.11 WLAN analysis, fiber optic interface, ITO/RFC 2544 tests, a comprehensive set

of accessories, and a larger carrying case; plus a LinkRunner Pro with Reflector,

rechargeable battery and carrying case; plus an AirCheck Wi-Fi Tester with extra

batter, directional antenna, and hard carrying case

GLD-ES 1-year of Gold Support

GLD-ES-2YR 2-years of Gold Support

GLD-ES-3YR 3-years of Gold Support

Options

ES-WLAN-OPT 802.11a/b/g WLAN analysis option, PCMCIA radio card, external directional antenna

ES-ITO-OPT ITO/RFC2544 option – includes Service Performance tool, traffic generator, RFC2544

and advanced performance tests

Accessories

MT-8200-63A IntelliTone Pro 200 Probe

LRPRO-REFLCT LinkRunner Pro with Reflector Option

ES-ACCY-KIT Accessories kit includes – LION battery, external battery charger, cable IDs, mini

keyboard, larger carrying case

Test and Troubleshoot

41

email: info@flukenetworks.com

Test and Troubleshoot

NetTool™ Series II Inline Network Tester

Isolate and document network device and application connectivity issues in seconds with

NetTool Series II from Fluke Networks. See connectivity to key network devices and services with

NetProve™ diagnostics – the fastest way to isolate the source of the problem – whether the cause

is the LAN, WAN, firewall, server or application. Get inline visibility into 10/100/Gig links to see

actual traffic between switches, PCs, IP phones and other devices. Quickly diagnose IP phone

problems and measure key call quality metrics. Verify the readiness of PoE systems and trouble-

shoot PoE device problems. Speed cable and fault location on active networks with IntelliTone™

digital technology. Create comprehensive reports of your network.

• NetProve diagnostics – isolate device and application connectivity issues in seconds

• Monitoring and authentication – identify spyware, malware, and viruses with port

monitoring; troubleshoot authentication issues with 802.1x log. Quickly resolve and document

network problems with powerful inline visibility into 10/100/Gig links between switches, PCs,

IP phones and other devices

• Connect inline for visibility into VoIP calls to quickly diagnose IP phone boot-up and call

control problems and to measure key call quality metrics

• Verify readiness of PoE systems and troubleshoot PoE device problems

• IntelliTone digital cable location and isolation technology speeds cable troubleshooting

Model Description

NTS2-NSKIT

NetTool Series II Network Service Kit – includes 10/100/1000 Mbps inline, VoIP option, monitoring and

authentication option, NetProve diagnostics, IntelliTone toning, IntelliTone Pro 200 Probe, NetTool

Connect PC software, WireView Wiremappers #1-6 and deluxe carrying case

NTS2-VOIP NetTool Series II Pro VoIP – includes 10/100/1000 Mbps inline, VoIP option, NetProve diagnostics,

IntelliTone toning, NetTool Connect PC software, WireView Wiremapper #1 and soft carrying case

NTS2-PRO NetTool Series II Pro – includes 10/100/1000 Mbps inline, NetProve diagnostics, IntelliTone toning,

NetTool Connect PC software, WireView Wiremapper #1 and soft carrying case

NT-VOIP NetTool 10/100 Pro VoIP – includes 10/100 Mbps inline, VoIP option, NetTool Blaster PC software,

NetTool Cable Identifier and soft carrying case

NT-PRO

NetTool 10/100 Pro – includes 10/100 Mbps inline, NetTool Blaster PC software, NetTool Cable Identifier,

set of four AA alkaline batteries, serial cable, Ethernet cable, Getting Started Guide, CD with multilanguage

user manuals, and soft carrying case

NT NetTool 10/100 – includes 10/100 Mbps single-ended testing, NetTool Blaster PC software, NetTool Cable

Identifier and soft carrying case

GLD-NT 1-year of Gold Support - NetTool

Options

NT-PRO-OPT Upgrade from NT to NT-PRO

NTS2-MONAUTH-OPT Add monitoring and authentication capabilities to NTS2-PRO or NTS2-VOIP

NT-VOIP-OPT Upgrade from NT-PRO to NT-VOIP

NTS2-VOIP-OPT Upgrade from NTS2-PRO to NTS2-VOIP

Accessories

NT-AC-ADAPT NetTool AC power adapter for NT 10/100

NT-Holster Holster for NT 10/100

NT-BATT-CHG NiMH battery charger for NT 10/100 and LinkRunner Network Multimeter

BATT-AA-NIMH Rechargable NiMH battery set (4) for all NT models and LinkRunner Network Multimeter

DTX-ACUN AC universal adapter for DTX, NTS2, ES, ES2

NTS2-POWERPACK AC adapter and NiMH battery set for NT Series II

42 www.flukenetworks.com/techtools

LinkRunner™ Pro and Duo Network Multimeters

LinkRunner Pro and Duo Network Multimeters empower technicians to resolve a broader range of

today’s connectivity problems. Unlike traditional 10/100 link testers, LinkRunner Pro and Duo

verify Gigabit links – increasingly import for today’s high-performance networks. They also ping

up to 10 key devices, detect Power over Ethernet (PoE), resolve 802.1X security conflicts, verifies

cable wiremap, and identifies the nearest switch port with Cisco, Extreme, and IEEE Link Layer

Discovery Protocols (CDP/EDP/LLDP). Built-in IntelliTone digital toning precisely locates cables

at patch panels and switches. Link status reports can be uploaded from USB port and routed with

trouble tickets to expedite problem resolution.

• Choose LinkRunner Pro for 10/100/Gig copper or LinkRunner Duo for 10/100/Gig copper and

just add an SFP for 100/Gig fiber

• Link at 10/100/Gig – identify device capabilities and confirm actual speed/duplex status

• Ping key devices – measure response of DHCP, router, DNS, and other devices or URLs

• Verify 802.1X settings – authenticate with EAP type, user name, certificates, and password

(LinkRunner Duo supports up to 2k certificates. LinkRunner Pro supports up to 1k certifi-

cates.)

• Detect PoE service – verify voltage level and pairs to IEEE 802.3af specifications

• Identify switch port – supports Cisco, Extreme, and IEEE Link Layer Discovery Protocols

• Test cable wiremap – measure length, detect miswires, shorts, split pairs or opens

• Locate and ID cable – use IntelliTone or optional IDs to locate cables at patch panels

• Document results – upload link status reports with USB port for faster problem resolution

Model Description

LRDUO LinkRunner Duo Network Multimeter – includes LinkRunner Duo, Wireview Cable ID #1, LinkRunner Connect Software

CD, USB cable, RJ-45 coupler, LinkRunner Duo getting started guide, four (4) AA alkaline batteries

LRPRO-1000

LinkRunner Pro Network Multimeter – includes LinkRunner Pro, WireView Cable ID #1, LinkRunner Connect software

CD, USB cable, LinkRunner Pro Getting Started Guide (English, Spanish, French, German, Japanese, Simplified

Chinese), four (4) AA alkaline batteries

LRPRO-REFLCT LinkRunner Pro with Reflector option

LINKRUNNER LinkRunner Network Multimeter 10/100 Mbps

GLD-LR 1-year of Gold Support – LinkRunner

Kits

CIQ-GSV CableIQ Gigabit Service Kit – includes CableIQ Qualification Tester, LinkRunner Pro Network Mulimeter, IntelliTone

Pro 200 Probe, CableIQ Remote Identifiers #1-7, WireView Cable ID #1 and CableIQ Reporter Software CD

LRPRO-KIT LinkRunner Pro Extended Test Kit – includes LinkRunner Pro, IntelliTone Pro 200 Probe, WireView Cable IDs #1-6,

clip-set RJ-45 to eight alligator clip bare wire adapter and LinkRunner Connect software CD

LRDUO-FTK LinkRunner Duo copper/fiber network troubleshooting kit – includes LinkRunner DUO and a Simplifiber Pro

multimode fiber verification kit

Options

LRPRO-Reflct-opt Reflector option for LinkRunner Pro

Accessories

MS-SX SX Gig Fiber DMM SFP transceiver (required for fiber testing)

MS-LX LX Gig Fiber DMM SFP transceiver (required for fiber testing)

ES2-ZX ZX Gig Fiber DMM SFP transceiver (required for fiber testing)

LRPRO-LION Lithium-Ion battery pack for LinkRunner Pro with AC adapter

Test and Troubleshoot

43

email: info@flukenetworks.com

Test and Troubleshoot

Managing today’s networks requires a range of visibility – from overall network health, to end-user experience, to in-depth

“on-the-wire” analysis. Performance needs to be monitored and root causes pinpointed for key devices, links and applications

anywhere on the network.

To do this with confidence, you need a complete picture of what’s happening on your network. Fluke Networks family of

analyzers delivers the breadth of visibility and depth of analysis you need for monitoring, analyzing and troubleshooting

networks and applications.

Monitoring, Analysis and Troubleshooting

Get the complete picture for monitoring, analyzing and troubleshooting networks and applications

44 www.flukenetworks.com/oms

Monitoring, Analysis and Troubleshooting

OptiView® Management Appliance with Reporter

Proactive monitoring and “on-the-wire” analysis from a dedicated appliance

OptiView Management Appliance is purpose-built to pro actively test and monitor

network and application performance. Test information is automatically imported into

OptiView Reporter for 24x7 monitoring, trending, and event notification, with easy access

via customizable web reports. When used together, this solution provides the tools needed

for daily management, and the detailed information and quick visibility that you need to

detect and resolve network and application problems smarter and faster. When problems

occur locally or at remote sites, the guesswork is eliminated; you know what’s out there,

what it’s doing, and how it all interconnects. With a simple click, you can immediately

access remote OptiView Appliances for real-time analysis and troubleshooting.

Proactive monitoring and “on the wire” analysis from a dedicated appliance provides:

• Daily proactive management – monitor key devices and applications for performance,

not just availability

• Easy identification and alarms/notifications on the top issues in the network

• Web-based reporting – provides daily reports to “prove it’s not the network” more easily

• “On-the-wire” visibility – integrates network management functions in a purpose-built

appliance with real-time traffic analysis and line-rate packet capture for detailed

application analysis that you can’t get from an NMS

Model Description

OPVS3-OMA/GIG/SP OptiView Management Appliance

Options

OPVS3-IPV6 OptiView IPv6 Analysis Option

OPV-RPTR/PRO OptiView Reporter Pro (40 Devices)

OPV-RPTR OptiView Reporter (1 Device)

Accessories

OPV-TCASE Hard shell transit case

OPV-RMK Rack Mount Kit for one or two management appliances

Model Description

GLD-OPV-FT 1-year of Gold Support – OPV FT

GLD-OPVS3 1-year of Gold Support – OptiView Series III

GLD-OPVS3/PSVS 1-year of Gold Support – OptiView Series III/PSVS

GLD-OPVS3-WGA 1-year of Gold Support – OPVS3-WGA

GLD-OPVS3-WGA/6 1-year of Gold Support – OPVS3-WGA/6

GLD-OPVS3-WGA/DSVS 1-year of Gold Support – OPVS3-WGA/DSVS

OptiView Gold Support

45

email: info@flukenetworks.com

Monitoring, Analysis and Troubleshooting

OptiView® Portable Network Analyzer

The OptiView Portable Analyzer provides wired or wireless analysis anywhere in the network,

allowing the user to monitor and capture the end-user experience “on-the-wire”. It is a

portable network management tool designed to help network professionals in their daily tasks.

The OptiView Network Analyzer is like having a “virtual network engineer” with its advanced

network analysis features, built-in expert advice and all-in-one capability for troubleshooting,

monitoring, trending and alerting – you can manage the core, remote sites or critical network

points with a single tool.

• Troubleshoot network and application performance problems

• Ensure network uptime and infrastructure availability

• Manage daily operations

• Ensure compliance with regulations and standards

• Provide management with accurate reporting and documentation

Model Description

OPVS3-GIG OptiView Series III Portable Network Analyzer Pro Gigabit. All OPVS3 mainframes

include: VLAN, ITO, and WAN options

OPVS3-GIG/W OptiView Series III Portable Network Analyzer Pro Gigabit – includes OPVS3-WFA

OptiView AirMagnet Wi-Fi analysis option 802.11 a/b/g/n

OPVS3-GIG/S

OptiView Series III Portable Network Analyzer Pro Gigabit with CSN/CSA-100

ClearSight Analyzer Software and OPVS3-WFA OptiView AirMagnet Wi-Fi analysis

option 802.11 a/b/g/n

OPVS3-GIG/RHD OptiView Series III Portable Network Analyzer Pro Gigabit with removable hard

drive and OPVS3-IPV6 analysis option

Options

OPVS3-IPV6 OptiView IPv6 Analysis Option

OPV-RPTR/PRO OptiView Reporter Pro (40 Devices)

OPV-RPTR OptiView Reporter (1 Device)

OPVS3-WSP OptiView AirMagnet Survey PRO & Planner Suite (Replaces InterpretAir)

OPVS3-WSPI OptiView Wireless Suite – includes AirMagnet Survey PRO, AirMagnet Planner

Module, and AnalyzeAir Wi-Fi Spectrum Analyzer (Replaces IA-AA)

OPVS3-WL

OptiView WLAN Suite – includes AirMagnet Survey PRO, AirMagnet Planner

Module, AnalyzeAir Wi-Fi Spectrum Analyzer, and OptiView 802.11 a/b/g/n

Wireless Network Analysis Option (Replaces OPVS3-WLESS)

46 www.flukenetworks.com/oms

Monitoring, Analysis and Troubleshooting

ClearSight™ Analyzer

Application-centric analysis software that gives quick answers to application performance

problems without looking at packets.

ClearSight Analyzer (CSA) is a powerful network monitoring and application analysis solution.

CSA provides deep network insight and visibility required for today’s complex and multi-

protocol networks. CSA’s intuitive and easy-to-use interface provides a comprehensive view of

the network plus the ability to drill down to lower layers of the network stack. Its real-time

protocol analysis capabilities make it a powerful monitoring and troubleshooting tool. With

support of third-party decode engines, such as Wireshark, CSA can decode about 1,000 proto-

cols. It operates with most NDIS-compatible Network Interface Cards (NICs) supporting line

speeds up to 1 Gbps.

• Application-centric summary view displays the health of the most commonly used

applications, giving you an instant view of performance

• Real-time monitoring provides 7-layer statistics and automatic problem/issue

identification

• Multi-segment analysis provides quick visibility on how applications progress through up

to 4 segments of the network without the need to look at decodes - speeding root cause

diagnosis of application problems

• Reconstruction and playback of application content such as audio/video, web pages

and email from real-time traffic or trace files

• Seamlessly integrate 3rd party decode engines, such as Wireshark for customized

decode views

Model Description

CSN/CSA-1000 ClearSight Analyzer Software

CSN/CSA-1000CD ClearSight Analyzer Software on CD

CSN/CSA-1045 CSA W/IP Multicast/History Rprt/Packet Gen

CSN/CSA-1045CD CSA W/IP Multicast/History Rprt/Packet Gen on CD

CSN/OPT-3045 IP Multicast Visualization, Hist Reporter, and Packet Gen for CSA

47

email: info@flukenetworks.com

Monitoring, Analysis and Troubleshooting

Network Time Machine™

High-performance critical link analysis, storage for data forensics and back-in-time

troubleshooting with application-centric analysis.

Network Time Machine’s multiple monitor ports interface with multiple critical 1/10G links for

traffic monitoring. Stream-to-disk technology records all packets for extended periods.

Built-in deep packet inspection and analysis provides the ability to monitor enterprise

network performance. The Atlas option can quickly analyze large amounts of captured traffic

through a special indexing mechanism. All analysis and packet decodes are done on board

without needing to pull data across the network – saving valuable bandwidth even when up to

4 remote users are analyzing data.

• Capture traffic through multiple ports on 10/100/1000 Mbps and 10 Gbps Ethernet

interfaces at up to full line rate

• High performance stream-to-disk hardware captures, stores, archives and recalls up to

60 TBs of live traffic

• Multiple hardware platforms – from portable to rack mounted – suit different

deployment needs

• Atlas Option facilitates the mining of application, network and data link data by

drilling down from areas of interest in order to view related trending charts, flow data,

and packet data

• Best-in-class real-time Video/VoIP metrics and troubleshooting for enterprise networks.

Integrated with ClearSight Analyzer for content playback, deep packet analysis

and decodes

Model Description

CSN/NTM-EX3 Network Time Machine Express, four 1GB SFP interfaces, 1 TB storage

CSN/NTM-ST3-4TB Network Time Machine Standard3, four 1GB SFP interfaces, 4 TB storage, SATA RAID 0

CSN/NTM-ST3-8TB Network Time Machine Standard3, four 1GB SFP interfaces, 8 TB storage, SATA RAID 0

CSN/NTM-ST3-8TB-FUG Network Time Machine Standard3, 8 TB SATA RAID 0 (field upgrade)

CSN/NTM-ST3-EA Network Time Machine Standard3, four 1GB SFP interfaces, 20 TB storage, SATA RAID 5

CSN/NTM-ST3-EA-UGD Additional Network Time Machine Standard external storage array, 20 TB SATA RAID 5 (factory installed)

CSN/NTM-ST3-EA-FUG Additional Network Time Machine Standard external storage array, 20 TB SATA RAID 5 (field upgrade)

CSN/NTM-PR3-S5 Network Time Machine Premium3, two 10GB XFP interfaces, 6.1 TB storage SAS RAID 5

CSN/NTM-PR3-S5-UGD Additional Network Time Machine Premium3 external storage array, 6.1 TB SAS RAID 5 (factory installed)

CSN/NTM-PR3-S5-FUG Additional Network Time Machine Premium3 external storage array, 6.1 TB SAS RAID 5 (field upgrade)

CSN/NTM-PO1-1G Network Time Machine Portable1, four 1GB SFP interfaces, 1.2 TB storage

CSN/NTM-PO2-1G Network Time Machine Portable2, four 1GB SFP interfaces, 1.7 TB storage

CSN/NTM-PO2-10G Network Time Machine Portable2, two 10GB XFP interfaces, 1.7 TB storage

Options

CSN/NTM-ATLAS Network Time Machine Atlas Software Module

CSN/NTM-REMSW-CD Network Time Machine Remote Viewer License for NTM Portable with CD

CSN/ACC-9022 10G Singlemode XFP, quantity 2

CSN/ACC-9032 10G Multimode XFP, quantity 2

CSN/ACC-9050 1G Singlemode SFP Transciever Kit,, quantity 2

CSN/ACC-9051 1G Multimode SFP Transceiver Kit., quantity 2

CSN/ACC-9055 1G Singlemode SFP Transciever Kit, quantity 2

FTAP-9-50 10/100/1000BASET SFP, copper, quantity 2

48 www.flukenetworks.com/oms

Tap Solutions

Taps provide reliable and secure access to network traffic without compromising network

performance. Featuring industry-leading innovation and unsurpassed quality, our Tap

solutions are suitable for numerous IT groups including network operations, network

engineering, information security, quality assurance, web analytics and application

analysis. Taps are available in numerous configurations to support all network access

strategies and objectives. These configurations include inline taps (copper and fiber),

inline aggregation taps (non-filter and filtering), span taps (non-filter, filtering and

switching), and combination inline/span taps (single and dual link)

• Copy traffic running through a network and sends that traffic to analyzers and probes

• Found in large data networks in virtually every industry vertical

• Provide permanent ports for network, application and security analysis solutions

• Improve the performance of network, application and security solutions

• Decrease the MTTR thru faster resolution of network, application and security issues

• Increase the ROI of traffic analyzers and probes

• Decrease the reliance on switch and router resources for network traffic visibility

• Are remarkably reliable

Models Description

TAP-100 Inline copper tap 10/100

TAP-10/100/1000 Inline copper tap 10/100/Gig

FTAP-50-50-10G Inline fiber tap, 50 multimode, 10 Gig

FTAP-9-50-10G Inline fiber tap, singlemode, 10 Gig

ATAP-100 Inline copper aggregating tap 10/100

AXTAP1204BT-BT Inline/SPAN copper aggregating tap with 2 any-to-any ports

(2 BT)

AXTAP1204BT-SFP Inline/SPAN copper aggregating tap with 2 any-to-any ports

(2 SFP)

AXTAP1210BT-BT/SFP Inline/SPAN copper aggregating tap and 8 any-to-any ports

(6 BT & 2 SFP)

AXTAP2206BT-BT Dual link inline/SPAN copper aggregating tap with

2 any-to-any ports (2 BT)

AXTAP2210BT-BT/SFP Dual link inline/SPAN copper aggregating tap with

6 any-to-any ports (4 BT & 2 SFP)

AXSTAP-4SFP SPAN aggregation tap with 4 any-to-any ports (4SFP)

AXSTAP-10SFP SPAN aggregation tap with 10 any-to-any ports (10SFP)

Other models available for different media, higher speeds, number of ports, and need for filtering.

Accessories

TAP-RMK-2 1U, 2Bay rack mount kit

TAP-RMK-3 1U, 3Bay rack mount kit

TAP-RMK-14 4U, 14Bay rack mount kit

MS-SX SX Gigabit fiber SFP transceiver

MS-LX LX Gigabit fiber SFP transceiver

SFP-RJ45 10/100/Gig copper SFP transceiver

Monitoring, Analysis and Troubleshooting

49

email: info@flukenetworks.com

Monitoring, Analysis and Troubleshooting

AirMagnet Survey

AirMagnet Survey is the most accurate mobile WLAN design and deployment solution for

802.11a/b/g/n indoor and outdoor wireless networks. It automatically gathers critical Wi-Fi

and RF spectrum information, using multiple data collection methods, and generates detailed

Wi-Fi performance maps of the results for easy network deployment, capacity planning and

optimization of wireless LANs.

• 802.11a/b/g/n and 4.9 GHz site surveying of indoor and outdoor networks

• Industry’s only active and Iperf surveying capability for real-world true

“uplink/downlink performance management”

• Determine ideal quantity, placement and configuration of APs for optimal security,

performance and compliance

AirMagnet Planner

AirMagnet Planner takes the guesswork out of WLAN design and installation, making it easy

for network professionals to accurately plan and deploy 802.11-based wireless networks in any

indoor environment. It accounts for building materials, obstructions, access point configura-

tions, antenna patterns, and a host of other variables to provide a reliable predictive map of

Wi-Fi signal and performance.

• Plan and design 802.11a/b/g/n indoor WLAN networks

• Predictive modeling to determine ideal quantity, placement and configuration of APs for

optimal security, performance and compliance

• Model building construction materials/obstructions and 802.11 APs

AirMagnet WiFi Analyzer

AirMagnet WiFi Analyzer is the most popular mobile field tool for troubleshooting enter-

prise Wi-Fi networks. AirMagnet WiFi Analyzer allows IT staff to quickly resolve performance

problems, while automatically detecting security threats and other network vulnerabilities. It

has many of the feature-rich qualities of a dedicated, policy-driven Wi-Fi network monitoring

system in a mobile tool.

• 802.11a/b/g/n and 4.9 GHz monitoring, management and troubleshooting

• Thorough inventory details for every detected Wi-Fi device

• Classify and physically locate unauthorized (rogue) devices or any policy violator

Model Version Description

A1150, A1173, B1170 8.7 Mobile software tool for wireless network security,

analysis and troubleshooting

GLD-AM-WFA 1-year of Gold Support – OptiView AirMagnet Wi-Fi

analyzer

Model Version Description

A4012 7.2 Mobile software tool for wireless network planning

GLD-AM-WSP 1-year of Gold Support – OptiView AirMagnet Survey

Pro and Planner Suite

Model Version Description

A4018, A4016, A4015, B4010 7.2 Mobile survey solution for designing and optimizing

wireless networks

GLD-AM-WSP 1-year of Gold Support – OptiView AirMagnet Survey Pro

and Planner Suite

50 www.flukenetworks.com/wsa

AirMagnet Spectrum XT

AirMagnet Spectrum XT is a professional spectrum analyzer solution that combines in-depth

RF analysis with real-time WLAN information for quicker and more accurate troubleshooting

of performance problems. This combined view of “impact analysis” of RF interference on the

network’s overall performance helps pinpoint the root-cause of those problems.

• Visualize impact of RF interference on WLAN performance

• Automatically detect and identify WLAN and non-WLAN interference sources

• Physically locate RF interference sources

AirMagnet VoFi Analyzer

AirMagnet VoFi Analyzer is the industry’s only solution built for troubleshooting VoWLAN

issues. It addresses all aspects of wireless voice and diagnoses problems rooted within the

end-user’s phone, QoS, RF, WLAN, and even wired network problems associated with voice

over Wi-Fi. AirMagnet VoFi Analyzer integrates with AirMagnet Survey software to additionally

validate and optimize phone call quality.

• Detect any 802.11a/b/g voice-over-WLAN call

• Full call quality analysis of encrypted wireless voice traffic

• Automatically diagnose and troubleshoot over 60 types of wireless voice call problems

AirMagnet Enterprise

AirMagnet Enterprise is a full-time wireless IDS/IPS and WLAN monitoring system that pro-

vides complete protection for all of a business’s wireless assets worldwide. The solution can

automatically detect hundreds of threats, block and prevent attacks, trace and locate prob-

lems, capture event forensics, troubleshoot performance problems remotely and document and

enforce compliance with internal and regulatory policies.

• Continuous monitoring of the entire wireless airspace

• Automatic detection and remediation of all wireless threats

• Trace, locate, map and capture forensics for any WLAN or RF event

Model Version Description

B4070 1.0.2 Professional spectrum analysis in USB form factor

B4720 1.0.1 AirMedic™ USB - entry-level spectrum analysis in USB form

factor

Model Version Description

A2200, A2210 4.0 Mobile software tool for voice-over-wreless analysis and

troubleshooting

Model Version Description

A5505, A5506, A5585,

A5586, A5588, A5590 8.5.5 24x7 wireless intrusion prevention, performance monitoring and

remote troubleshooting

Monitoring, Analysis and Troubleshooting

AirMedic™ USB

For entry-level users, AirMedic(tm) USB offers an affordable USB-based spectrum analysis tool for

RF interference analysis and Wi-Fi troubleshooting. AirMedic USB is a fast and simple, “just the

facts” approach to dealing with the periodic performance and reliability problems that all

wireless LANs experience.

Telecommunications Providers

Telephone Butt-In Test Sets

Telephone Test Set Comparison .....................53

TS®52 PRO LCD Test Set ..........................54

TS®40 Series Test Sets ...........................55

TS®30 Test Set ................................55

TS®22 Series Test Sets ...........................56

TS®25D Test Set ...............................56

TS®19 Test Set ................................57

Modular Adapters ..............................57

Line Cords and Clips ............................58

Access Network Test Equipment

Fiber OneShotTM Optical Test Set .....................60

MetroScopeTM Service Provider Assistant ................61

LinkRunner Duo CE Pocket Carrier Ethernet

Test Set .....................................62

CopperProTM Series II Broadband Loop Tester ............63

990DSL CopperProTM Loop Tester .....................64

CopperPro TerminatorTM Far End

Terminating Device .............................64

635 QuickBERT-T1 Test Set ........................65

Voltage Detector ...............................65

Telecommunications Providers

www.flukenetworks.com/telecom 51

52 www.flukenetworks.com/testsets

Fluke Networks offers the most comprehensive line of telephone test sets to meet the voice and data demands of telecommunica-

tions technicians. Our DropSafe™ reliability and RainSafe™ protection ensure maximum ruggedness, even in the most extreme

conditions. Our DataSafe™ technology is vital in preventing interruption of existing data traffic, and our DSL/POTS filtering

technology goes one step further to allow testing on the POTS side of a line even while data is present.

We continually improve our line of butt-in test sets to ensure technicians have the right features to match their application needs

– with the most flexible options for every budget.

Telephone Butt-In Test Sets

Complete line of analog butt-in telephone test sets provides the view you need to ensure

telecommunications services

53

email: info@flukenetworks.com

* TS120 for outside North America only. 67/33 break/make ratio.

Telephone Test Set Comparison

TS®52 PRO TS®44 PRO TS®42DLX TS®22A TS®22 TS®25D TS®30 /

TS®120*TS®19

Display – back lit LCD and

glow-in-the-the dark keypad 3LCD only

Extended range high-

impedance DataSafe

operation in monitor mode

333 3

High-impedance DataSafe

operation in monitor mode 3 3 3 3 3 3 3

Data lockout protection 3 3 3

Data lockout override 3 3 3

DSL/POTS filtering technology 3 3 3 3

Low/high voltage indication 3 3 3 3

Low current (mA) indication 3 3 3 3

Over voltage protection 3333333

Over current protection 3333333

Two-way speakerphone for

true hands-free conversations 3333

One-way amplified speaker for

hands-free monitoring 333333

Audible ringer for callbacks 3 3 3 3 3 3 3 3

Waterproof – exceeds

American Military Spec.

MIL-STD-810E

333

RainSafe – safe in severe

weather conditions 33333 3

DropSafe – passes 20 foot

(6 meter) drop test onto

concrete

33333 3

Meets Bellcore specifications 33333 3

Tone and pulse operation 3 3 3 3 3 3 3 3

Polarity indication in talk

mode 3 3 3 3 3 3 3 3

PBX pause button 333333

Stores nine 18-digit numbers

in repertory dialer

(speed dialing)

333333

Replaceable 9V battery for

powering speaker 333333

Telephone Test Equipment

54 www.flukenetworks.com/testsets

Telephone Test Equipment

TS®52 PRO LCD Test Set

Fluke Networks new TS®52 PRO Test Set features the latest in test set technology. Designed with

a superior, radiant liquid crystal display (LCD) user interface, it allows you to see what cannot be

heard in any outside plant environment. The back lit LCD and phosphorescent (glow-in-the-dark)

keypad brings light to even the darkest of work environments, providing perfect line diagnostic

clarity. The TS®52 PRO Test Set is also equipped with 2-way speakerphone and DataSafe™ Pro

data protection technology featuring superior high-impedance monitoring, data lockout and

lockout override, making you completely safe.

• Display – back lit LCD and glow-in-the-the dark keypad

• DataSafe™ Pro – superior high-impedance monitoring, lockout and override, making you

completely safe in any mode

• DropSafe™/RainSafe™ – passes 20-foot drop test and designed for use in rainy conditions

• DSL/POTS filtering technology – allows technicians to clip on a live DSL line to test POTS

service without downing or disrupting data service

• Two-way, hands-free speakerphone – for true hands-free conversation

• Test Functions:

– Data indication: warns when data is present.

– Voltage indication: troubleshooting feature to identify potential line problems

– Current (mA) indication: verifies sufficient line current

– Caller-ID: verifies service is functional

– DTMF digit grabbing: isolate faulty customer premise equipment

Model Description

52801001 TS52 PRO test set with piercing pin clips

52801004 TS52 PRO test set with 346A plug

52801009 TS52 PRO test set with ABN/PP clips

52801RJ9 TS52 PRO test set with ABN/PP and RJ-11 plug

Telephone/Data Room

or Central Office

Cross Box or

Serving Terminal

Inside or Outside the

Customer Premise

55

email: info@flukenetworks.com

Telephone Test Equipment

TS®40 Series Test Sets

Built for the demanding professional, the TS40 Series test sets combine an ergonomic water-

proof design, DropSafe™ durability and a standard 3-year warranty for unmatched reliability.

The TS40 Series test sets offer speakerphone capability for true hands-free conversations, a

rugged ergonomically designed waterproof case that exceeds American Military Specification

MIL-STD-810E and are DropSafe tested to 20 feet onto concrete. Designed with superior high-

impedance monitor to protect data lines, the TS40 Series offers the best DataSafe™ protection

in its class. Advanced testing functions for low/high voltage and low (mA) current detection

are displayed in easy-to-read LEDs. Always-on monitor mode simplifies operation and speeds

testing; just clip on to the pair and it is monitoring.

• DataSafe operation with superior high impedance monitor

• Advanced testing functions for low/high voltage and low (mA) current

• Always-on Monitor Mode

• Ergonomic DropSafe case

• High fidelity, 2-way speakerphone for true hands-free conversations.

• TS®44 PRO includes Data Lockout, Lockout Override and DSL/POTS filtering

Model Description

50801001 TS44 PRO test set with piercing pin clips

50801004 TS44 PRO test set with 346A plug

50801009 TS44 PRO test set with ABN/PP

50801RJ9 TS44 PRO test set with ABN/PP and RJ-11 plug

42801001 TS42 DLX test set with piercing pin clips

42801004 TS42 DLX test set with 346A plug

42801009 TS42 DLX test set with ABN

TS®30 Test Set

The TS30 test set features the latest in test set case design, at an affordable price. The

ergonomic non-slip grip handle provides improved handling of the set in all weather

conditions. Includes DataSafe™ operation so technicians can clip onto a line in monitor

mode, without disrupting existing data traffic.

• High impedance DataSafe operation in monitor mode

• DropSafe™ reliability passes 20-foot drop test

• RainSafe™ protection in severe weather conditions

• Mute switch

• Last number redial

Model Description

30800009 TS30 test set with ABN

30800001 TS30 test set with piercing pin clips

56 www.flukenetworks.com/testsets

TS®25D LCD Test Set

The TS25D test set features data lockout and lockout override, making you completely safe in talk or

monitor mode. The DSL/POTS filtering technology allows you to safely draw dial tone without downing

DSL. A built-in analog tone generator simplifies wire identification with a probe. An amplified speaker

makes monitoring the line hands-free, so you can keep working. The Talk Battery function provides

voltage to carry voice conversation on non-powered pairs. Also includes Caller-ID and Call-waiting

Caller-ID functions. All in a compact unit with an oversized, robust liquid crystal display (LCD) that

makes the intuitive, common-sense menus easy-to-read and use.

• Caller-ID and Call-waiting Caller-ID

• Amplified speakers for hands-free monitoring

• Data lockout and data lockout override

• Tone generator for wire identification

• Talk battery to power voice conversation on dry (non-powered) lines

Model Description

25501109 TS25D test set with ABN kit (includes pouch and earpiece)

25501009 TS25D test set with ABN

25501004 TS25D test set with 346A plug

25500400 TS25D pouch only

25500300 TS25D battery door with belt clip

Telephone Test Equipment

TS®22 Series Test Sets

The TS22 Series test sets’ unique built-in, one-way amplified speaker provides three audio levels

for hands-free listening and use with automated voice response systems. Multiple memories enable

storage of nine 18-digit telephone numbers in repertory dialer (speed dialing) for easy access to

test boards, the central office and other frequently called numbers. The last number redial feature

eliminates the need to re-key your last entry. The TS22 test set offers an unbeatable combination of

reliability, durability and expanded utility.

• TS22 test set has an amplified speaker for hands-free monitoring

• TS22A test set has a two-way speakerphone for true hands-free conversation

• DropSafe™ reliability passes 20-foot drop test

• RainSafe™ protection in severe weather conditions

• Stores nine 18-digit numbers in repertory dialer (speed dialing)

Model Description

22801009 TS22A test set with ABN

22801007 TS22A test set with ground start cord

22801004 TS22A test set with 346A plug

22801001 TS22A test set with piercing pin clips

22800009 TS22 test set with ABN

22800007 TS22 test set with ground start cord

22800004 TS22 test set with 346A plug

22800001 TS22 test set with piercing pin clips

57

email: info@flukenetworks.com

Model Description

10210100 4-wire in-line modular adapter

10210101 4-wire in-line modular adapter with K-plug

10220100 6-wire in-line modular adapter

10220101 6-wire in-line modular adapter with K-plug

10230100 8-wire in-line modular adapter

10230101 8-wire in-line modular adapter with K-plug

Model Description

10113000 4-wire modular adapter

Telephone Test Equipment

In-line Modular Adapter (4, 6, and 8-wire)

In-line banjo modular adapters permit testing on working lines without disrupting service.

Quickly determine whether the trouble is in the phone or in the line.

• Easily complete testing and obtain circuit access on working lines without disrupting service

• Clear circuit markings on the sides and bottom of the unit

• Test line status with the 4-wire modular adapter

Spare Modular Adapter Cords (standard and K-plugs)

In-line banjo modular adapters feature replaceable adapter cords which enable broken jack

clips to be replaced without discarding the entire unit. K-plug versions have rugged jack clips.

4-wire Standard Modular Adapter

Test line status with the 4-wire modular adapter. Provide a quick connect to modular telephone

jacks using any standard butt-in test set equipped with spring clips.

• Easily complete testing and obtain circuit access on working lines without disrupting service

• Clear circuit markings on the sides and bottom of the unit

• Test line status with the 4-wire modular adapter

Model Description

19800009 TS19 test set with ABN

19800003 TS19 test set with banana jacks to alligator clips

TS®19 Test Set

The TS19 test set combines all the essential test set features at an affordable price. This test

set was specifically designed for in-house telecom technicians. Its high impedance

monitor prevents accidental disruption of service from clipping onto a data line while in

Monitor Mode, thus ensuring the integrity of critical data lines. Features such as tone (DTMF)

or pulse operation, talk/monitor capabilities, polarity test button and last number redial

make this test set the perfect combination of features and price.

• High impedance DataSafe™ operation in monitor mode

• Tone (DTMF) and pulse operation

• Last number redial

• Polarity indication in talk mode

58 www.flukenetworks.com/testsets

P1980007 P1980009 P3218124 P3218RJ9 P3218442 P2280062

Line cord with

Ground Start cord

Compatible with

19 Series

Line cord with

Angled Bed-of-Nails

Clips

Compatible with

19 Series

Line cord 471 A Plug

with RJ-11 Plug

Compatible with all,

requires 346A Plug

cord

Line cord with

Angled Bed-of-Nails

Clips and RJ-11 plug

Compatible with the

TS20 Series

Line cord 471A Plug

with Angled Piercing

Pin Clips

Compatible with all,

requires 346A Plug

cord

Ground start cord

Component for

P1980007

Line cord boot only

P3218-418 Black Boots (Pkg. 10)

P3218-420 Red Boots (Pkg. 10)

P3218202 P4080248 P4080249 P3218249

Angled Bed-of-Nails,

Pkg. 1 each

Compatible with all

Standard locking

belt clip

Compatible with

52 & 40 series

Belt clip

Compatible with

52 & 40 series

Belt clip

Compatible with

19, 20, 30 series

P3218231 P3218232 P3218234 P3080009 P1980001 P1980003

Line cord with

Boots, no Clips

Compatible with

20 Series

Line cord with 346A

Plug (Central Office)

Compatible with

20 Series

Line cord with

Angled Bed-of-Nails

Clips

Compatible with

20 Series

Line cord with

Angled Bed-of-Nails

Clips

Compatible with

30 Series

Line cord with

Angled Piercing

Pin Clips

Compatible with

19 Series

Line cord with

Banana Jacks and

Alligator Clips

Compatible with

19 Series

P4480009 P4480001 P4480004 P4480RJ9 P3218024 P3218028

Line cord with

Angled Bed-of-Nails

Clips

Compatible with

52 & 40 Series

Line cord with

Angled Piercing

Pin Clips

Compatible with

52 & 40 Series

Line cord with 346A

plug (Central Office)

Compatible with

52 & 40 Series

Line cord with Bed-

of-Nails and RJ-11

plug

Compatible with

52 & 40 Series

Line cord with

Straight Bed-of-Nails

Clips

Compatible with

20 Series

Line cord with

Angled Piercing Pin

Clips

Compatible with

20 Series

Telephone Test Equipment

Line Cords and Clips

59

email: info@flukenetworks.com

Effective installation and maintenance solutions are essential to keep customers happy and technicians productive.

Award-winning field test products from Fluke Networks earned their reputation where it matters most: on the job.

We offer test and troubleshooting solutions that address a wide range of technologies and applications, from POTS to carrier

Ethernet, xDSL to IP, and more. Whether it’s validating service level agreements (SLAs) for carrier-class Ethernet services,

qualifying and deploying ADSL2/2+ or VDSL services, isolating cable faults, eliminating noise problems, or stress testing

circuits prior to service installation, Fluke Networks powerful tools help technicians get to the solution fast.

Access Network Test Equipment

Complete line of access network test sets for the successful installation and

troubleshooting of carrier Ethernet, xDSL and special services

60 www.flukenetworks.com/theone

Fiber OneShot™ Optical Test Set

Fiber OneShot is a pocket-sized optical test set designed to take the complexity out of single-

mode fiber testing. Fiber OneShot’s one-button-test capability will quickly and accurately verify

if a fiber is active and find the distance to a break or end, dirty end face or reflective event –

going from zero to 9,999 feet (0 - 6,000 meters displayed in metric mode). This portable FTTx

tester is designed to increase productivity and decrease training time. The Fiber OneShot allows

testing anywhere in the network – central office, node, hub, drop or optical network terminal

(ONT) – and is fast, affordable, lightweight and accurate.

The Fiber OneShot is built to last. The Fiber OneShot incorporates an energy-absorbing holster

over an impact-resistant case to withstand drops, impacts, and the tough outside plant envi-

ronment ensuring years of trouble-free operation. Together with a heavy-duty tethered end cap

to protect the fiber adapter the Fiber OneShot is the test set for demanding field applications.

Testing benefits increase your productivity:

• Measure the length of your fiber quickly and accurately

• New CheckActive™ feature alerts you if an optical signal is on the fiber

• Instant on – no boot/load time

• One-button testing – expedite your fiber testing with one button in just a few seconds

• Locate fiber faults at one meter

• Test results displayed numerically – no interpretation needed

Model Description

FIBR-1-KIT Fiber OneShot™ Optical Test Set, SC adapter, UPC-APC, UPC-UPC 1-meter launch

cords, holster, case, 22 language-QRC on CD, manual and batteries

FIBR-1-SHOT Fiber OneShot™ Optical Test Set, SC adapter, holster, 22 language-QRC on CD,

manual and batteries

FIBR-1-KIT-VF

Fiber OneShot™ Optical Test Set, SC adapter, UPC-APC, UPC-UPC 1-meter launch

cords, holster, case, 22-QRC on CD, manual, batteries + VisiFault™ Visual Fault

Locator with 2.5mm universal adapter

FIBR-1-KIT-PM

Fiber OneShot™ Optical Test Set, SC adapter, UPC-APC, UPC-UPC 1-meter launch

cords, holster, case, 22-QRC on CD, manual, batteries + SimpliFiber® Pro Optical

Power Meter; SC adapter included

FIBR-1-KIT-VFPM

Fiber OneShot™ Optical Test Set, SC adapter, UPC-APC, UPC-UPC 1-meter launch

cords, holster, case, 22-QRC on CD, manual, batteries + VisiFault™ Visual Fault

Locator with 2.5mm universal adapter + SimpliFiber® Pro Optical Power Meter; SC

adapter included

Accessories

Model Description

FIBR-AC-UAPC 1-meter UPC APC launch cord (Use with Fiber OneShot only, Not for OTDR use)

FIBR-AC-UUPC 1-meter UPC-UPC launch cord (Use with Fiber OneShot only, Not for OTDR use)

FIBR-AC-CH Holster case, Fiber OneShot

Access Network Test Equipment

61

email: info@flukenetworks.com

Access Network Test Equipment

MetroScope™ Service Provider Assistant

The new MetroScope Service Provider Assistant is the next generation in field test equipment

for installing and troubleshooting carrier Ethernet services (10/100/Gig) over copper or fiber.

The new ProVision™ test is the fastest, easiest, and most comprehensive way to test new

circuits. Generate performance reports using ProVision, RFC 2544 or BERT tests. The unique

Reflector accessory allows end-to-end testing without a second MetroScope, saving up to 40%.

Fluke Networks IP expertise puts unmatched troubleshooting for wired or wireless networks

behind a deceptively simple user interface. Full VGA color display with web remote control and

a built-in VoIP phone.

• Low-Cost Reflector tests links using a single MetroScope

• Easy to use with large VGA color touchscreen

• VoIP Phone and Metrics

• In-depth traffic monitoring and active network discovery

• Remote control via web browser

• Application Performance Testing

• 802.11a/b/g Wireless Testing

Model Description

MTSCOPE-KIT

MetroScope Kit – includes MetroScope mainframe with 10/100/1000BASE-T and

1000BASE-X SFP Port, rechargeable Li-Ion battery pack , AC adapter/battery charger, auto

lighter charger, remote wiremap adapter, 128MB compact-flash card, documentation CD,

carrying case and LinkReflector including 10/100/1000BASE-T port

MTSCOPE

MetroScope mainframe – includes 10/100/1000BASE-T and 1000BASE-X SFP Port,AC

adapter/battery charger, remote wiremap adapter, 128MB compact-flash card,

documentation CD, carrying case.

MTSCOPE-LT

MetroScope Mainframe without Advanced Network Analysis Features and without multi-

stream capability – includes 10/100/1000BASE-T and 1000BASE-X SFP Port, AC adapter/

battery charger, remote wiremap adapter, 128MB compact-flash card, Documentation CD,

carrying case

LRDUO-CE LinkRunner™ Duo CE for Carrier Ethernet

GLD-MTSCOPE 1-year of Gold Support

Options

MS-VOIP VoIP Phone and Analysis for MetroScope (all models)

MS-WLAN-OPT

Fluke Networks 802.11/a/b/g PCMCIA WLAN radio card, directional antenna, instructions

to activate MetroScope WLAN Option, printed English language Getting Started Guide and

CD containing multi-language user manuals and other useful files

MS-MULTI-LT Multistream option for MetroScope-LT

Accessories

DTX-ACUN AC charger, universal

OPVS-KB Mini USB keyboard

944806 Null modem cable (DB9)

ES-BATTERY Replacement battery

ES2-ZX 1000BASE-ZX Gig Fiber DDM SFP transceiver (1550nm DFP laser)

MS-SX SX Gig Fiber DDM SFP transceiver

MS-LX LX Gig Fiber DDM SFP transceiver

MS-100FX 100BASE-FX Fiber SFP transceiver (without DDM)

LRPRO-LION Lithium-Ion battery pack for LinkRunner Pro with AC adapter

MS-BAG Large carrying case for MetroScope and accessories

62 www.flukenetworks.com/Duo-CE

LinkRunner Duo CE Pocket Carrier Ethernet Test Set

If you’re installing carrier Ethernet, you’ve been forced to choose between thorough testing

with a dedicated performance test set or plugging it in and hoping for the best. Dedicated test

sets allow your team to thoroughly test the links but they can be costly. And “plug and pray”

can result in callbacks and extended troubleshooting sessions. Fluke Networks LinkRunner Duo

CE Pocket Carrier Ethernet Test Set reduces your costs and increases customer satisfaction. It’s

designed to help technicians quickly turn up and troubleshoot carrier Ethernet, and, it works

with your existing performance testers when you need more complete testing.

LinkRunner Duo CE Features:

• Link Verification of Fiber and Copper Circuits at 10/100/1000MBps – quickly determine

if the circuit is up or not

• Performance Testing with MetroScope and other Popular Test Sets – use as a remote

device for ProVision™, RFC 2544 and other performance tests with testers from

Fluke Networks, JDSU, Sunrise, Exfo and more

• Layer 1, 2, and 3 Loopback – configurable loop back to filter frame type and swap

MAC and/or IP addresses. Manual or DHCP IP configuration

• Fiber Power Measurements – make sure that the incoming signal meets requirements

• PING Testing – measure availability and response performance for key devices or URLs

• VLAN Verification – configurable VLAN and priority settings

• Designed for the Field – small (fits in a shirt pocket), lightweight (10oz), battery

operated and rugged. Operates for over three hours with a removable Li-ion battery pack,

four AA batteries, AC or optional car charger (optional)

• Document Results – save link and ping test results and upload to a PC through the

USB port

• CPE Testing – pinpoint problems on the customer side with port identification and

802.1x testing, cable and connectivity tests. Verify port settings and troubleshoot speed

and duplex mismatch issues

• Cable Testing – test cabling and patch cords, including support for toning

• Media Access – Copper: 10BASE-T, 100BASE-TX, 1000BASE-T (IEEE 802.3); Fiber (SFP):

100BASE-FX, 1000BASE-LX, SX, ZX, BX

• Easy Upgrades – the mini-USB port on the LinkRunner Duo CE allows software upgrades in

the field in jut minutes. And with our Gold support, you’ll automatically receive upgrades at

no additional charge. The LinkRunner Connect software also allows you to download reports

and capture screen graphics

Model Description

LR-DUO-CE LinkRunner Duo Carrier Ethernet Tester

GLD-LR 1-year of Gold Support – LinkRunner Duo

WIREVIEW 1 Wiremap Adapter

Wireview2-6 Wireview Cable IDs #2-6

MS-AUTO-CHG 12V Car Charger for LinkRunner Duo

ES2-ZX ZX DDM SFP

MS-SX SX DDM SFP

MS-LX LX DDM SFP

Access Network Test Equipment

63

email: info@flukenetworks.com

Access Network Test Equipment

CopperPro™ Series II Broadband Loop Tester

The CopperPro Series II is the complete test set for qualifying your local loop for ADSL,

ADSL2/2+, VDSL and special services. It packs all the test, analysis and troubleshooting

capabilities an OSP technician needs into one integrated, handheld tool. New features include

broadband noise identification for VDSL, advanced TDR capabilities for locating short bridge

taps and other VDSL-affecting impairments, and an optional ADSLx and VDSL modems for

verifying service connectivity and performance. Rugged construction and easy-to-use features

give your technicians the ability build, repair, install, and maintain OSP systems more

efficiently with fewer repeats.

• Quickly qualify the facilities for DSL services including ADSL, VDSL, HDSL, T1 and other

special services

• Easily identify and locate possible problems to ensure reliable performance

• Install new services efficiently with fewer call-backs

• Verify connectivity and network performance to ensure that next-generation services

perform up to your customers’ expectations

Expedite Installation and Maintenance

CopperPro Series II makes fast work of installing and maintaining service. The one-button POTS

Auto-Test quickly documents status before and after work is complete. The CopperPro also gives

you a clear view of all the basic tests you need to ensure top performance, including:

• AC and DC voltage

• Loop current

• Circuit noise

• Balance and leakage

• Caller-ID/ANI

Plus, you can quickly run loss and slope tests with its automated dial-up testing, and use the

built-in dial set with phone number storage. You can also verify xDSL connectivity, performance

and capacity up to VDSL rates with optional xDSL golden modems.

Streamline Trouble Calls

Step-by-step instructions make CopperPro Series II a breeze to set up. Use the unique

TDR Auto-Test to:

• Zero in on faults such as short bridge taps and shorted or open pairs

• Count and locate load coils

Model Description

990DSL2+ CopperPro Next Gen Copper Loop Analyzer w/TDR & wideband spectral analysis for ADSL2+

990VDSL CopperPro Next Gen Copper Loop Analyzer w/TDR & wideband spectral analysis for VDSL

990TL-SB/RF RF Test lead set for 990DSL2+ or 990VDSL with spike+bed-of-nails piercing clips

990LT 990LT CopperPro™ Test Set – Next-generation loop analyzer (basic)

990LT/TDR TDR option for the 990LT CopperPro™ Test Set

990LTD/DSL DSL option (2.2 MHz) for the 990LT CopperPro™ Test Set

990LT/VDSL VDSL option (17.7 MHz) for the 990LT CopperPro™ Test Set with DSL option installed

990-GM/2 ADSL/ADSL2/2+ Golden Modem Option for CopperPro Series II

990-GM/V-2 ADSL, ADSL2, ADSL2+, VDSL2 Golden Modem Option for CopperPro Series II

64 www.flukenetworks.com/accesstest

990DSL CopperPro™ Loop Tester

The CopperPro loop tester offers a broad range of Plain Old Telephone Services (POTS) trouble-

shooting, fault location and line qualification capabilities in an affordable package. Its Wideband/

TDR option adds high-frequency transmission testing and qualification functions for services like

ADSL, HDSL and HDSL2, ISDN, T1, E1 and DDS. And the TDR option adds precise fault location and

analysis. CopperPro is packed with test, analysis and troubleshooting capabilities integrated with

an easy-to-use toolbox interface that makes identifying and locating faults as simple as pushing

a button.

• Replaces up to 12 traditional test sets

• Troubleshoots and qualifies lines for POTS, ADSL and other special services

• Time Domain Reflectometer (TDR) feature allows precision fault locations

Model Description

990 DSL CopperPro Loop tester

990DSLWT Loop tester with wideband and TDR

990TL-SB Test lead set (Spike and bed-of-nails)

990-CASE Deluxe transport bag

GLD-990DSL 1-year of Gold Support

CopperPro Terminator™ Far End Terminating Device

The CopperPro family of loop testers from Fluke Networks packs a full complement of test and

troubleshooting capabilities into one rugged, integrated tool for OSP technicians. You can expand

those capabilities even further with Terminator – an accessory module to the 990DSL CopperPro

that lets you perform terminated transmission testing quickly, easily, single-handedly. Together,

the CopperPro and Terminator are a major advance in qualifying and troubleshooting copper access

network circuits, including HDSL2/4. Nothing else on the market offers a more complete and

effective solution for reducing failure frequency, repeats, and chronic problems with special

services circuits.

• Perform terminated transmission testing quickly, easily, single-handedly

• Optimize your workforce with “one tech out” terminated testing of out-of-service pairs

• High-speed acceptance/qualification tests, including loop attenuation – a must for HDSL2/4

• Robust error checking eliminates time-consuming false starts and assures reliable communica-

tion with the 990DSL CopperPro test set

• Sweep thousands of frequencies in seconds

Model Description

TN2100 Enhanced Terminator far end device

TN-LEADS-B Test lead set, bed-of-nail clip

Access Network Test Equipment

65

email: info@flukenetworks.com

Access Network Test Equipment

635 QuickBERT-T1 Test Set

Compact, handheld T1 test set for construction, installation and troubleshooting applica-

tions. Instantaneous detection and display of framing, line coding, errors, alarms, level,

frequency and more. In a single 4 lb (1.8 kg) package, the 635 includes all the basic T1

testing capabilities you would expect in a larger and more expensive tester. It performs

bit-error tests, detects framing type, line coding and bit pattern, and displays signal level,

frequency, clock slips, errors and alarms. The 635 transmits the most commonly used loop

codes, including HDSL. Full, unframed and fractional (56k and 64k) T1 are supported, along

with display of signaling and data bits and capture of DTMF digits. Plus, individual voice

channels may be monitored on the built-in speaker or over a headset.

• Instantaneous detection and display of framing, line coding, errors, alarms, level,

frequency and more

• Transmits and receives common Bit Error Rate Test (BERT) patterns and includes all

common loop codes

• Compact, rugged and easy-to-use

Model Description

635 QuickBERT-T1, carrying case, ToolPak™ hanging accessory, and necessary cables

and adapters

633/635-Kit 2 Bantam-to-310 cables, 2 Bantam-to-alligator clip cables, 1 Bantam-to-RJ-48

cable

635-1 635 QuickBERT-T1 and cable kit

Voltage Detector

In just a few seconds, a technician can determine if it’s safe to work around areas such as

transformer cases and circuit breaker housings, power ground wires or newly-driven ground

rods, mobile homes, metallic siding or metal framing, pedestals, cross boxes or conduit,

street light fixtures or electrical machinery. The Voltage Detector is a proven life-saver, with

more than 30 years of service in telecommunications outside plant and power utility

applications.

• Helps protect against accidental electrocution

• Is fast and easy-to-use. Handy as a flashlight

• Rated to 20,000 Vac and 2,000 Vdc

Model Description

C9970 Voltage Detector

C9973 Voltage Detector kit – includes Voltage Detector, probe cap, storage bag, temporary

bond, ground cord and handbook

C9974 Voltage Detector kit with test plug

Corporate

Communication Service Providers ....................67

Fluke Networks Gold Support .......................68

Professional Services and Training ....................69

Latest News from Fluke Networks ....................70

Contact .....................................71

Corporate

66 www.flukenetworks.com

67

email: info@flukenetworks.com

Communication Service Providers

CSP

Communication Service Providers

Fluke Networks helps many of the world’s leading communications service providers to

build, manage and maintain their networks for high efficiency and performance. Our

tools and systems are in service around the world, assisting with broadband network

conditioning, facility maintenance and repair, troubleshooting, and the installation and

maintenance for voice, video and data services.

Why are we different?

Only Fluke Networks brings together the deployment, maintenance, installation and operating support system

solutions that deliver the business-transforming results you need to address the challenges ahead. We work closely

with communication service providers to reduce operating expenses and maximize workforce productivity so they

take maximum advantage of their investment in new technologies and services.

Solutions

Conditioning for Broadband Deployment

Fluke Networks is the world leader in network conditioning. Our NetDSL systems play a pivotal role in accelerating

circuit qualification for ADSL and VDSL service deployment at the world’s leading telecommunications service

companies. And NetDSL ties that testing information back to central data systems, making it

easy to market and deliver these new services to customers.

Access Network Maintenance

Our CopperPro and NetTech products help field technicians to troubleshoot and locate

access network problems quickly and easily. Whether it’s isolating cable problems,

eliminating noise problems, or stress testing circuits prior to service installation,

Fluke Networks has powerful tools to help technicians get to the solution fast.

Service Installation

Look at the tool belt of any technician and you are sure to find Fluke Networks installation tools and test sets.

From market-leading dial sets to durable punchdown tools, Fluke Networks delivers professional quality to assure

technicians can get the job done right…the first time.

Operating Support Systems

Fluke Networks is unique in its ability to tie together and automate the far-flung elements of today’s access

network. Solutions include automated job planning, trouble handling, records verification and centralized testing.

• DaVaRandNetDSL

• CopperProLoopTesters/Analyzers

• CopperProSeriesIIVDSL/ADSL2

Golden Modems

• NetTechxDSLFieldVerication

• TelephoneTestSets

• PunchdownTools

• TDRs

• Toners/Probes

• AutomatedTroubleHandling

• MetroScopeCarrierEthernetAssistant

Product Offerings

68 www.flukenetworks.com/goldsupport

Gold Support

Fluke Networks Gold Support

Our Gold Support Program ensures a better return on your investment by lowering your

cost of ownership. You’ll minimize downtime with a loaner or exchange equipment and

unlimited 24x7 telephone technical assistance. You’ll get repairs and software/firmware

upgrades at no charge – now and for as long as your membership is valid.

Call 800-283-5853 to request a gold support quote or find your nearest Distributor.

Software and Firmware Upgrades

Your product will never be out of date. You’ll receive access to all software upgrades via “MyAccount” on

www.flukenetworks.com, giving you the latest functionality and improving technical efficiency and troubleshooting.

Upgrades also include Management Information Base (MIB) library updates for applicable products.

Unlimited 24x7 Technical Support

Extend the expertise of your staff. Gold support includes priority access to our world-class technical assistance center

(TAC) via members-only phone numbers. Our centers in Eindhoven (Netherlands), Beijing, Washington, DC and Seattle

employ a full staff of highly-trained technical experts that are on call, during weekends and through the night when

most network changes are implemented, to answer complex troubleshooting questions.

Annual Calibration/Performance Verification and Factory Refresh

Gold support includes one calibration (if applicable – see your owner’s manual for instructions) and factory refresh per

year at no charge. You unit will be precisely calibrated using the full battery of proprietary Fluke Networks test proce-

dures, adjusted/repaired as necessary with genuine repair parts, software and firmware updates applied, all accessories

tested and replaced if defective, then cleaned and performance verified.

Accessory Replacement

Some accessory parts are essential to your Fluke Networks unit. The normal warranty on accessories is 90 days, but

faulty or defective parts and accessories will be replaced free of charge during the term of your Gold Support contract

(some accessories are limited to 1 set per year – see website for further details).

Repairs and Loaner Equipment

As a Gold Support member, you will receive a loaner unit – delivered via next-day services and all shipping costs

covered – to keep you up an running. Out-of-warranty units will either undergo a fee-based inspection prior to

receiving Gold Support or the user must wait 30 days before taking advantage of any service or repair benefit.

Unlimited Access to our Knowledge Base

You’ll have an open door to valuable proprietary information we’ve gathered from helping customers over the years.

It also includes helpful technical articles written by our experts.

Members-Only Promotions

Your membership qualifies you for “Members Only” promotions and programs. This includes product discounts, access

to reconditioned equipment at special prices and other incredible values.

Training Opportunities

As a Gold Support member, you will have access to many online training materials, including on-demand webcasts via

MyAccount at www.flukenetworks.com/myaccount. OptiView Gold Support customers may attend our 2-Day OptiView

Network Troubleshooting course at no charge. See www.flukenetworks.com/training for more information and class

schedules.

69

email: info@flukenetworks.com

Professional Services and Training Opportunities

• Industry-leadingcourses

• Staycompetitive

• Enhanceteamskillset

• Affordablepricing

• Onsiteoroffsite

• BICSIcredits

• Certicateofcompletion

• Learnindustrystandards

• Understandinferiorcabling

• Speeddeploymenttimes

Professional Services and Training Benefits

Professional Services and Training Opportunities

No one understands the challenges and environments of networking professionals like Fluke Networks. That’s why

we’ve created a suite of training solutions from custom on-site training and instructor-led courses to self-guided

online training and webinars to match the varying needs, work models and experience levels of each user. Visit

www.flukenetworks.com/training for full details.

Maximize your Return On Investment

Fluke Networks professional services and training programs mean maximum flexibility while increasing your return on

investment in equipment and people. From our one-day on-site training and certification program to improve installer

skills in testing, certifying, and troubleshooting copper and fiber optic cabling systems to our on-site professional

services engagements to assist in design and installation of our tools, or troubleshooting existing stubborn network

issues, Fluke Networks professional services and training opportunities help your company get the most out of your

network tools.

Consider a training course if you currently own or plan to purchase any Fluke Networks tools. These classes are

scheduled around the world in key cities, or we can bring them to your location and customize them to meet your

product mix and specific educational needs. We can also create a custom on-site class or electronic training tool to

specifically cover the technology, features, and functionality your team needs to maintain your network.

Our classes are taught by specially qualified Fluke Networks experts, so your staff may earn continuing education

credits such as BICSI and a certificate of completion, enhancing their skill set and increasing their value to your

organization. Visit www.flukenetworks.com/training today to review specific course outlines and discover the

local contact in your area.

Fluke Networks On-Site Certification Course

Fluke Networks helps you realize the full value of your installation and troubleshooting teams with industry-leading

Certified Cabling Test Technician (CCTT) courses. This course help your department stay competitive in the installation

and certification of high-speed structured cabling systems. Fluke Networks training staff offers expert classroom

training and extensive hands-on experience with our latest products.

Latest News from Fluke Networks

Sign up for our monthly newsletter – Eye on Networks and receive the latest news from Fluke Networks via email.

We offer hundreds of live and on-demand webcasts throughout the year, visit www.flukenetworks.com/events.

Remember to register your product and receive world-class service and support from Fluke Networks.

www.flukenetworks.com/contact

70

Eye on Networks

Eye on Networks delivers networking news and information you can use on the job. You will

receive monthly updates with the latest in product and technology information, expert

technical resources and more. Sign up today at www.flukenetworks.com/eyeonnetworks

News, Events and Tradeshows

Fluke Networks is on the road throughout the year at most major industry events. We also

offer live and on-demand webcasts. To learn more about Fluke Networks news, events and

where we will be throughout the year, please visit www.flukenetworks.com/events

Benefits of Product Registration

Fluke Networks offers world-class service and support. Our Service Center Information page

will help you contact a Fluke Networks authorized service center and get more information.

You can also access our online knowledgebase for self-service. Our extensive knowledgebase

will help you quickly find the information you are looking for. For the most up-to-date sup-

port information, please remember to register your Fluke Networks product via our online

registration portal. For more information, please visit www.flukenetworks.com/support

Latest News from Fluke Networks

71

email: info@flukenetworks.com

Contact Us

Corporate

Street address

Fluke Networks

6920 Seaway Boulevard

Everett WA 98203, USA

Email: info@flukenetworks.com

Mailing address

PO Box 777

Everett WA 98206-0777, USA

Customer Service

United States and Canada:

1-800-283-5853 (Toll free inside U.S. and Canada)

1-425-446-4519 (worldwide)

Technical Support

United States and Canada:

1-800-283-5853

Email: support@flukenetworks.com

Training

United States and Canada:

1-800-283-5853

Email: training@flukenetworks.com

For general questions, information and feedback, please visit: www.flukenetworks.com/contact

For information on local sales offices, please visit: www.flukenetworks.com/worldwide

Contact Information

Fluke Networks

P.O. Box 777, Everett, WA USA 98206-0777

Fluke Networks operates in more than 50

countries worldwide. To find your local office

contact details, go to

www.flukenetworks.com/contact.

©2010 Fluke Corporation. All rights reserved.

Printed in U.S.A. 7/2010 3158212D C-EN

Your authorized Fluke Networks distributor

What’s new from Fluke Networks

AirCheck™ Wi-Fi Tester

• Dedicated, handheld 802.11 a/b/g/n tester with

instant-on technology

• Rapidly perform a Wi-Fi discovery to fully assess your

current wireless security settings and network availability

• Robust and in-depth WLAN connection tests

• Quickly identify and locate access points whether

authorized or rogue

• Fully documents your troubleshooting session

See page 39 for additional information.

DTX-CLT CertiFiber® Optical Loss Test Set

• 12 second Autotest – loss measurement of two fibers at

two wavelengths, optical link budget calculation, and a

PASS/FAIL analysis

• Interchangeable multimode and singlemode modules

(which are also compatible with the popular

DTX CableAnalyzer™ Series)

• Accurate fiber length measurement – eliminate

haphazard guessing!

• Continuity and polarity verification

See page 20 for additional information.

Fiber OneShot™ Optical Test Set

• Measure the length of your fiber quickly and accurately

• New CheckActive™ feature alerts you if an optical signal

is on the fiber

• Instant on – no boot/load time

• One-button testing—expedite your fiber testing with one

button in just a few seconds

• Locate fiber faults at one meter

Test results displayed numerically—no interpretation needed

See page 60 for additional information.
