Product Detail Manual

Product Catalog

Volume XIII, Issue 1

www.engproducts.com

Welcome to

Engineered Products Company (EPCO)!

We are the premier brand supplier of specialty products to Electrical Distributors and Contractors.

Headquartered in Minnetonka (a suburb west of Minneapolis), EPCO has supported the electrical

industry since 1976 by supplying a broad range of standard and unique consumables for

commercial, industrial, residential, and agricultural buildings.

Our reliable, durable, and quality products are designed and engineered with innovative product

features specically intended to save installation time and cost. And EPCO’s unique display

packaging provides exceptional convenience for Contractors.

Thousands of Distributors and Contractors know just how easy it is to do business with EPCO

because we consistently ship and deliver on time, error-free, and risk-free.

When you select EPCO products, you join an exclusive group of Electrical Distributors and

Contractors who demand the very best in electrical specialty products. All of our standard

catalogued products are in stock in our 52,000 square foot warehouse and available for immediate

shipment. We are committed to providing our customers with the “complete” quality customer

service experience from technical support, easy ordering, shipping orders 100% complete in 24

hours or less, comprehensive post sale technical support, and “hassle-free” returns.

Our goal is to provide you with competitively priced, quality products with customer service and

delivery dates that meet your requirements. If you don’t see exactly what you need in our catalog,

call or fax your product request to us today.

Everyone at Engineered Products Company appreciates your business!

Respectfully,

Jack Schuster, President

Engineered Products Company

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

1

TABLE OF CONTENTS

LIGHTING PRODUCTS

RetroFit Lighting

T5 and T8 RetroFit Conversion Kits™ ........................ 3

Utility Lighting

GFF and GFFW Series™ Light Fixtures .......................7

GFF and GFFW Fixture Suspension System Kit...............9

GFF Surface Mount Bracket................................10

GFF and GFFW Ordering Information ......................13

ProSeries™ and ProSeries GU24 Utility Light Fixtures .......15

Ceiling Mount Light Fixtures ..............................17

Standard Non-Metallic Junction Boxes.....................18

SpiderBox™ Junction Boxes................................18

Compact Fluorescent Lamps ..............................18

Fixture Globes ............................................19

Non-Metallic UF Cable Connectors ........................19

Replacement Lamp Socket ................................19

Wire Guard ...............................................20

Wall Mount Light Fixtures .................................20

Lamp Holders (Porcelain and Plastic).......................21

GU24 Lamp Holders.......................................22

Fixture Whips

Fixture Whips with Die Cast Screw-In Connectors ..........24

Fixture Whips with Die Cast Snap-In Connectors ...........25

Fixture Whips with Polycarbonate Snap-In Connectors .....26

QuikWhip™ Fixture Whips .................................. 27

RetroFit Fixture Whips with Die-Cast Screw-In Connectors..28

Custom Fixture Whip Order Form ..........................29

Tube Guards

Standard Tube Guards.....................................31

UV Filtering Tube Guards ..................................34

Heat Sink Screens .........................................35

Temporary Lighting

TIGER 400 HID™ Light .....................................37

TIGERcub 175 HID™ Light .................................37

Deluxe and Contractor Grade CordLights™.................39

CordLight Kit .............................................39

Safety Cages .............................................40

Insulation Piercing Lamp Socket...........................40

Pigtail Lamp Socket .......................................40

Landscape Lighting

Landscape SplicePost™....................................42

Landscape LightPost™ ....................................43

GROUND BONDING PRODUCTS

Ground Bonding PigTails™

Insulated Solid Wire PigTails ...............................46

Insulated Stranded Wire PigTails ...........................47

Single and Dual-Gang PigTails .............................48

PowerTails® Device Wiring Conductors.....................49

Ground Bonding Application Examples ....................50

Ground Screws ...........................................51

Ground Clips..............................................52

SPLICE KITS/HEAT SHRINK TUBING PRODUCTS

Splice Kits

UF Cable Splice Kit ........................................54

Copper Butt Splice Kits ....................................54

Self Sealing UF Splice Kits .................................55

Dual Rated Butt Splice Kits ................................55

UF Stretcher Kit ...........................................55

Heat Shrink Tubing

Thick Wall Heat Shrink Tubing .............................57

Bulk Thick Wall Heat Shrink Tubing.........................57

Heat Shrink Torch .........................................58

PRODUCT ACCESSORIES

Residential Accessories

Air Conditioner Whips..................................... 62

Power/Appliance Cords ................................... 63

Flat and Round Cord Strain Relief Connectors .............. 63

Range Cords .............................................. 64

Dryer Cords............................................... 64

Wall Plate Insulation Gasket ............................... 64

Commercial Accessories

Duct Seal Compound ..................................... 66

Tie Wire................................................... 66

Side and Top Mount Fixture Hangers ...................... 66

Single and Double Loop Chain ............................ 67

S-Hooks .................................................. 67

SALES REPRESENTATIVES ............................... 68

GENERAL TERMS AND CONDITIONS

................69

LIGHTING PRODUCTS

2

n RETROFIT LIGHTING

CONVERSION

n UTILITY LIGHTING

n FIXTURE WHIPS

n TEMPORARY LIGHTING

n TUBE GUARDS

n LANDSCAPE LIGHTING

LIGHTING PRODUCTS

3

LIGHTING PRODUCTS

Our RetroFit Conversion Kits convert older 4-foot and 8-foot T8 or T12 strip-light fixtures into energy efficient T5

or T8 light fixtures. Each kit includes T5 or T8 Bi-Pin Lamp Sockets, RetroFit Bracket Socket Plates, and Self-Tapping

Screws.

n Complies with UL Standard 1598B and 1598C.

n Pre-wired conversion kit brackets; the installer only needs to complete the bracket installation and ballast lead

terminations.

n Pre-painted with smooth, glossy, highly reflective white paint.

n Includes pre-drilled holes for installing Ballast Cover or Reflectors.

BENEFITS FOR THE FACILITY OWNER

n Simple upgrade to an energy efficient T5 or T8 light fixture.

n The original light fixture housing is reused. This reduces the retrofit conversion time for a new T5 or T8 light

fixture to half the cost and half the time compared to the installation of a new fixture.

n Improved efficiency, lighting quality, and longer lamp life.

n Simplifies your lamp inventory to one lamp type and color temperature.

n Converting old light fixtures to energy efficient T5 or T8 light fixtures will provide energy savings up to 49%, and

the return on investment can be as short as 15 months.

DISTRIBUTOR BENEFITS

n The combination of our low cost RetroFit Conversion Kit, electronic ballasts, and T5 or T8 fluorescent lamps are

recognized as the most energy efficient lighting system today.

n Our RetroFit Conversion Kits are made in the USA, complies with the American Recovery and Reinvestment Act

(ARRA), and allows the Contractors to readily participate in Government sponsored lighting retrofit projects.

CONTRACTOR BENEFITS

n Viable retrofit opportunities in commercial, industrial, and institutional buildings that have not converted to the

energy efficient T5 or T8 lighting systems.

n Labor savings! The combination of high efficiency ballast, T5 or T8 lamps, and the low cost of our RetroFit

Conversion Kits is a fast and easy installation.

n Requires minimal rewiring.

n Minimal recycling on the job site.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

4LIGHTING PRODUCTS

RETROFIT LIGHTING

STRIP-LIGHT RETROFIT CONVERSION KITSTM

P/N 14085: 1/4

Turn Retainer

Clips

P/N 14080: Standard Ballast Cover

P/Ns 14092 and 14096: Specular ReflectorP/Ns 14091 and 14095: White Reflector

4-FT T8 RETROFIT KIT - P/N 14090

TYPICAL APPLICATIONS:

n

Commercial and industrial facilities

n

Factories

n

Warehouses and storage areas

n

Strip malls and shopping centers

n

Schools and recreation areas

n

Airport, train and bus terminals

n

Fast food restaurants

n

Other applications where

retrotting existing lighting

systems will provide improved

lumen output and energy savings.

BALLAST COVERS AND REFLECTORS

n Tool-less installation. Quickly and easily attaches to the RetroFit Conversion Kit

Bracket using 1/4 Turn Retainer Clips.

n Complies with the majority of utility rebate requirements.

n Optimizes light output and helps to reduce energy consumption.

n Standard Ballast Cover (Steel) - P/N 14080: White, Reectance 92%.

n Nominal Length: 4-Feet.

n Aluminum Reectors - Improves the usable light.

– P/Ns 14091 (6-inch) and 14095 (10-inch): White, Reectance 92%.

– P/Ns 14092 (6-inch) and 14096 (10-inch): Specular, Reectance 96%.

5.10"

2.25"

9.25"

2.5"

6-Inch Reector10-Inch Reector

4.58"

0.43"

5.40"

Part Numbers - 14060 and 14050: Converts an 8-foot, 2 Lamp T12 “strip-

type" Light Fixture into an 8-foot, 4 Lamp T5 or T8 Light Fixture

(Shown with optional P/Ns 14080, 14095 or 14096)

Part Numbers -14066 and 14090: Converts a 4-foot, 2 Lamp T12 “strip-

type" Light Fixture into a 4-foot, 2 Lamp T5 or T8 Light Fixture

(Shown with optional P/Ns 14095 or 14096)

Note: Does not include optional Ballast Cover or Reflectors.Note: Does not include optional Ballast Cover or Reflectors.

8-FT T8 RETROFIT KIT - P/N 14050

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

5LIGHTING PRODUCTS

RETROFIT LIGHTING

STRIP-LIGHT RETROFIT CONVERSION KITSTM(cont)

Key: Order Unit: The Unit to be ordered; Unit Quantity: Number of same pieces in each Unit; Units per Case: Unit Packages contained in the case; Tl Case = Total Case Quantity: The number of similar items in the Unit Package;

Unit Package: The type of Packaging; Min Order = Minimum Order Quantity: The smallest Unit to order; MM req = Multiple Minimum Order Required: Must order multiples of Unit the quantities; ship WT = Shipping Weight:

Total weight of the Unit Package; Order Unit / Packaging Types: BG = Bag; BRL = Barrel; BX = Box; BN = Bulk; LS = Loose; PKG = Package; RL = Roll; EA = Each; Package; LB = Pound; C = Hundred; M = Thousand

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

T5 RetroFit Conversion Kits

14060† 14060 T5 RetroFit Conversion Kit: for 8-FT Fixture, 4 Lamp EA 1 BG 10 10 10 Yes 14

14065† 14065 T5 RetroFit Conversion Kit: for 8-FT Fixture, 2 Lamp EA 1 BG 10 10 10 Yes 14

14066† 14066 T5 RetroFit Conversion Kit: for 4-FT Fixture, 2 Lamp EA 1 BG 10 10 10 Yes 14

14067† 14067 T5 RetroFit Conversion Kit: for 4-FT Fixture, 1 Lamp EA 1 BG 10 10 10 Yes 14

T8 RetroFit Conversion Kits*

14050 14050 T8 RetroFit Conversion Kit: for 8-FT Fixture, 4 Lamp EA 1 BG 10 10 10 Yes 14

14051 14051 T8 RetroFit Conversion Kit: for 8-FT Fixture, 4 Lamp, EA 1 BG 10 10 10 Yes 14

with Jumper and WAGO® Connector

14055 14055 T8 RetroFit Conversion Kit: for 8-FT Fixture, 2 Lamp EA 1 BG 10 10 10 Yes 14

14056 14056 T8 RetroFit Conversion Kit: for 8-FT Fixture, 2 Lamp, EA 1 BG 10 10 10 Yes 14

with Jumper and WAGO Connector

14057 14057 T8 RetroFit Conversion Kit: for 4-FT Fixture, 1 Lamp EA 1 BG 10 10 10 Yes 14

14070† 14070 T8 RetroFit Conversion Kit: for 8-FT Fixture, 4 Lamp, EA 1 BG 10 10 10 Yes 14

to be used with Programmed Start Ballast ONLY

14076† 14076 T8 RetroFit Conversion Kit: for 4-FT Fixture, 2 Lamp, EA 1 BG 10 10 10 Yes 14

to be used with Programmed Start Ballast ONLY

14090 14090 T8 RetroFit Conversion Kit: for 4-FT Fixture, 2 Lamp EA 1 BG 10 10 10 Yes 14

RetroFit Conversion Kit Accessories

14080 14080 Standard Ballast Cover: 4-FT - White, 1/4 Turn Retainer Clips EA 1 BX 20 20 20 Yes 27

for 4.25” Wide Fixture Housing ONLY

14085 14085 1/4 Turn Retainer Clips: for Ballast Cover and Reflectors EA 1 BG 40 40 40 Yes 1

14091 14091 White Reflector: 4-FT, 6-inch - Nominal Width 5.40”, with EA 1 BX 20 20 20 Yes 14

1/4 Turn Retainer Clips, for 4.58” Wide Fixture Housing ONLY

14092 14092 Specular Reflector: 4-FT, 6-inch - Nominal Width 5.40”, with EA 1 BX 20 20 20 Yes 14

1/4 Turn Retainer Clips, for 4.58” Wide Fixture Housing ONLY

14095 14095 White Reflector: 4-FT, 10-inch - Nominal Width 9.25”, with EA 1 BX 20 20 20 Yes 16

1/4 Turn Retainer Clips, for 5.10” Wide Fixture Housing ONLY

14096 14096 Specular Reflector: 4-FT, 10-inch - Nominal Width 9.25”, with EA 1 BX 20 20 20 Yes 16

1/4 Turn Retainer Clips, for 5.10” Wide Fixture Housing ONLY

Note: * 1. T8 RETROFIT KIT FOR USE WITH INSTANT START BALLAST ONLY EXCEPT P/NS 14070 AND 14076!

2. Accommodates xture housing widths between 4.25" to 5.0".

3. Energy consumption and savings will vary based on the operating hours per day, the number of operating days per year, the energy cost from

your local service provider, and lamp cost.

†4. Our RetroFit Conversion Kits may be suitable for use with Linear LED Retrot Lighting. These designated RetroFit Conversion Kit part numbers

tted with “non-shunted" lamp holders are suitable for use with linear LED engines (T5 and T8 shaped LED tubes) as long as the LED engine is

classied per UL 1598C.

LIGHTING PRODUCTS

6

Our energy efficient and cost-effective Utility Light Fixtures and Accessories meet a very broad variety of lighting

applications. We currently provide linear, multi-lamp fluorescent light fixtures as well as single-lamp utility light

fixtures. Both light fixture types are UL listed for use in “damp” or “wet” lighting applications.

GFF AND GFFW SERIES™

The GFF and GFFW Series multi-lamp light fixtures high-efficacy, energy-efficient, and highly desirable NEMA 4X

and IP 66/67 rating makes these light fixtures especially suitable for use in “wet” locations where high-pressure

wash down is required. Easily configurable for a range of lighting applications using either T5 or T8 lamps, the fast

installation saves time for the Contractor reducing the overall labor cost.

With capacity up to six T5 or T8 lamps, the GFF and GFFW Series is ideal for high-bay locations such as warehouses,

parking garages, food processing facilities, commercial kitchens, pedestrians walkways, road tunnels, as well as

other locations that require above-average lighting. In many of these installations, the use of GFF and GFFW Series

light fixtures can reduce the number of fixtures required to meet your lighting needs.

PROSERIES™ AND PROSERIES GU24

The newest addition to our single lamp Utility Light Fixtures is the UL listed ProSeries™ Utility Light that is rated

for use in “wet” locations. The ProSeries is available in two (2) “socket” base types, Edison-base and GU24! This UV

resistant, high impact and corrosion resistant construction features a “unique” 18 cubic-inch junction box that

provides capacity for running an additional power circuit that meets the National Electric Code junction box fill

requirements. Many agricultural buildings are beginning to transition to this type of light fixture because of the

lower maintenance cost and the opportunity to qualify for rebates from their local utility.

15000 SERIES

For agricultural and animal confinement applications, our single lamp Utility Light Fixtures have been a key

factor for many years to support worker safety, improved animal production, and providing overall farmstead

security. The core of our single-lamp light fixtures is the 15000 Series, UL listed and rated for use specifically in

“damp” locations. We have sold more of these light fixtures than any other manufacturer primarily because of our

outstanding quality and in-use longevity. Older barns and utility out-buildings that have substandard lighting

systems could be greatly improved with the installation of our 15000 Series light fixtures.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

7LIGHTING PRODUCTS

UTILITY LIGHTING

GFF AND GFFW SERIESTM LIGHT FIXTURES

Our domestically manufactured GFF and GFFW Series Light Fixtures accommodate both

T5 and T8 lamps, both rated for long life, energy eciency, and more uniform lumen

distribution. For high or low ceiling applications, the highly reective coated nish of

the GFF and GFFW light xtures’ gear tray surface translates into improved ecacy by

providing more usable lumens per watt.

FEATURES

n UL Listed. Suitable for use in wet locations. File Number: E319552.

n Fast installation saves time and reduces labor cost.

n Reliable, durable, maintenance free performance!

n Meets the requirements of the 2011 National Electrical Code: Articles 410.10(A),

410.104(A), 410.130(G)(1), 547.5(C)(1) and (2), and 547.8(A) and (B).

n

Long lasting fixtures will not deteriorate under most hostile environments when it is

installed according to factory procedures.

n Suitable for indoor or outdoor use.

n Multiple configurations available in 2-foot, 4-foot and 8-foot lengths.

Note: The GFFW Light Fixture is only available in 4-foot length!

n Ingress Protection – NEMA 4X and IP66/IP67 rated dust and moisture resistant luminaire;

suitable for use in wet locations where high-power pressure wash-down is required.

n Gear tray: tethered and hinged for the GFF and GFFW, respectively. Both light fixtures

provide quick access to the ballast wiring to simplify installation, power-to-ballast

termination, and allow for easy ballast replacement.

n Continuous “poured-in-place” closed cell polyurethane gasket completely seals the

fixture from dust and moisture.

n GFF Series Mounting Hardware allows the Contractor to pre-install the mounting

brackets to the mounting surface without drilling into the fixture housing.

n Luminaire Disconnect: Enables the Electrical Contractor to easily and safely disconnect

the incoming power to allow safe servicing of the GFF and GFFW Series Light Fixtures.

n

Impact resistant acrylic diffusers withstand breakage from high power pressure washers;

lowers replacement and maintenance costs.

n Solid reinforced fixture housings provide strong rigidity with no deflection. The

fixture housing is rated 5VA-F1 fiberglass.*

n “Captive” Acetal (Plastic) or Stainless Steel Latches.

n Domestic Ballast Manufacturer.

n 100% factory tested before shipping. No Contractor callbacks!

n Two (2) 1/2" trade size knockouts on each end of the light fixture accommodate

standard conduit fittings.

*Note: Quantied and tested by Underwriters Laboratories, reference UL 746C.

INGRESS PROTECTION

Continuous “poured-in-place” closed cell polyurethane

gasket seals the GFF and GFFW Series Fluorescent

Fixtures from dust and moisture and provides protection

from –40ºC/–40ºF to 80ºC/176ºF.

GFF/GFFW OCCUPANCY SENSOR  THE “R" OPTION

Our GFF and GFFW Series Occupancy Sensor (OS) is the energy and cost ecient

method to manage lighting systems in applications such as stairwells, warehouses, util-

ity and maintenance buildings, storage areas, tunnels and more.

Installing our occupancy sensor can reduce energy consumption by almost 45%. Its

installation lowers energy cost by operating similar to a light switch. The

sensor turns the lights on when it senses activity in a room or area, then turns the lights

o automatically after sensing no activity after a preset time.

TYPICAL APPLICATIONS:

n

Food processing facilities

n

Commercial kitchens

n

Laundries

n

Industrial facilities

n

Saunas

n

Car washes

n

Storage buildings

n

Pedestrian and Road Tunnels

n

Parking Garages

n

Elevator Shafts

n

Refrigerators and Freezers

n

Locker Rooms

n

And more...

GFF WIDE BODY (GFFW)

GFF NARROW BODY

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

8LIGHTING PRODUCTS

UTILITY LIGHTING

GFF AND GFFW SERIESTM LIGHT FIXTURES (cont)

FIXTURE LATCH OPTIONS

GFF Light Fixtures can be ordered with your

choice of Acetal (Plastic) or Stainless Steel Latches.

Note: GFFW Light Fixtures are only available with Stainless Steel Latches.

Both cam-type latch options accommodate a variety of application

environments.

Acetal (Plastic) Latches provide an exceptional combination of heat resistance,

durability and strength over a wide range of ambient temperatures with minimal

attachment of airborne particles.

Stainless Steel Latches are ideal for food processing facilities and related applications.

These latches can withstand extreme temperatures for refrigerator and freezer

applications as well as the chemicals present in car washes. They are also impervious

to acidic conditions making them suitable for use in livestock containment buildings.

Tamper Resistant Screws can help the building owner save thousands of dollars

in re-lamping cost by protecting the uorescent lamps installed in the GFF and

GFFW Light Fixtures from tampering, vandalism and theft.

Stainless Steel

Latch

Tamper

Resistant

Screws

SPECULAR REFLECTORS

n Specular reflectors can reduce lighting energy costs by as much as 30%.

n Provides additional light into the work space.

n Delivers the highest efficacy at the lowest watts per square foot that enables lamps

to perform to maximum efficiency.

n Two (2) reflector styles:

– The Basic Reector concentrates light to specic work areas and provides more uniform illumination.

– The Wide Reector provides a broader dispersion of light at higher and lower mounting levels in warehouses,

manufacturing areas, factories, commercial kitchens, parking garages, as well as outdoor lighting applications.

n Both reflectors provide 95% reflectivity to enhance energy efficiency for more effective lighting.

Note: Wide Reflector is available ONLY for 4-foot, two (2) lamp and 8-foot, four (4) lamp GFF Series Light Fixtures.

GFF - Basic Specular Reector GFF - Wide Specular Reector

GFFW - Specular Reector

Acetal (Plastic)

Latch

LAMP GUARD

Our Lamp Guards are constructed of cold-rolled steel wire and resistance welded

in a rectangular grid pattern. The Lamp Guard attaches to directly to the GFF and

GFFW Light Fixtures using the factory-mounted Acetal (Plastic) or Stainless Steel

latches.

Material Finish: Silver powder coated epoxy; moisture and weather resistant.

Typical applications include:

n Classrooms

n Offices

n Lavatories

n Commerical Kitchens

n Restaurants

n Shopping Centers

n Factories

Note: Custom colors are available on special order. Contact our Inside Sales Department

(800.336.1976 or sales@engproducts.com) for more information.

GFF Wire Spacing: Outside section: 2.75" x 3.0"

Center section: 3.0" x 3.0"

GFFW Wire Spacing:

Outside section: 2.75" x 3.0"

Center section: 3.0" x 3.5"

GFF

GFFW

n Workshops

n Warehouses

n Parking Garages

n Gymnasiums

n Other areas where the fluorescent

lamps may be exposed to forceful

contact or damage.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

9LIGHTING PRODUCTS

UTILITY LIGHTING

GFF AND GFFW SERIESTM LIGHT FIXTURES (cont)

GFF/GFFW FIXTURE SUSPENSION SYSTEM KIT

The GFF and GFFW Fixture Suspension Kit provides instant and “tool-less" infinite height

adjustment when installing our GFF and GFFW Series Light Fixtures.

n Accommodates two (2) GFF Light Fixtures or one (1) GFFW Light Fixture.

n Easily suspends light fixtures, signage, mechanical, HVAC systems, and other objects

that require suspension from beams, trusses, or joists.

n Eliminates the need for chain, S-Hooks, threaded rods and strut support nuts.

n Maintenance-free and requires no ongoing adjustments.

n Suspension Cable Length: 100-inches with two (2) 20-inch Y-cables and two (2)

swaged spring-loaded steel hooks with bright nickel plating on Y-cable ends with fuse cut cable to prevent fraying.

n Safe Working Load: 75 lbs. (34 kg.)

n Minimal breaking strength: 420 lbs. (190.5 kg.)

n Maximum load rating for one (1) cable: 62 lbs. (28.1 kg.); two (2) cables: 124 lbs. (56.2 kg.)

n Warranty - one (1) year.

n One (1) kit includes:

– Two (2) 1/16" (1.587 mm) x 10-foot galvanized steel cables with two (2) attached spring-loaded steel hooks ensure positive

attachment. Steel Hook Inside Diameter: 0.5 inches.

– Two (2) tool-less suspension cable adjustment blocks.

Bail Hanger: use for chain or cable

hanging installations.

Mounting Bracket: use for ceiling

hanging installations.

FIXTURE MOUNTING/HANGING HARDWARE

Fixture Mounting/Hanging Hardware is available for the GFF and

GFFW light xtures that eliminates drilling through the xture housing

to maintain the IP66/IP67 “wet" location ingress protection rating.

n GFF Light Fixture: For Ceiling Applications (P/N: GFF-MH) the

fixture mounting hardware includes two (2) “snap-on"

stainless steel fixture hanging brackets that attach to the

underside of the fixture housing.

n GFF Light Fixture: For Wall Mount Applications (P/N: GFF-WMH)

the fixture mounting hardware includes two (2) “snap-on”

mounting brackets that attach to the outside of the fixture

housing after the brackets have been mounted to desired wall

mount location.

n The GFFW uses two (2) V-Hooks that are primarily used for chain

or cable mounting applications to expedite fixture installation.

Installation Notice: We recommend the purchase and use of the Fixture

Mounting Hardware when installing a 2-foot, 4-foot or 8-foot GFF Series Light Fixture

and the V-Hooks when installing a 4-foot GFFW Series Light Fixture. Any GFF and

GFFW Series Light Fixture that has been incorrectly installed by drilling, puncturing,

piercing or any other means that will alter the integrity of the light fixture housing will

void the warranty!

V-Hooks (Option): attach to the GFFW

Fixture Hanger Bracket

GFFW V-Hooks (Option)

IMPACT RESISTANT UV STABILIZED DIFFUSERS

n 100% Impact Resistant Acrylic Diffusers.

n No tools or fasteners are required to attach the Diffuser to the fixture housing.

GFF Acrylic Ribbed Diuser is standard on all GFF Series Light Fixtures.

The Basic Specular Reector can be used with this Diuser.

GFF Acrylic Clear Diuser is intended for use with the Basic and Wide

Specular Reectors.

GFFW Acrylic Clear Diuser is standard on all GFFW Series Light Fixtures.

Note: Each end of the Acrylic Clear Diuser is frosted to minimize untargeted light dispersion. The

GFF Acrylic Clear Diffuser is available for 4-foot and 8-foot GFF Series Light Fixtures ONLY.

GFF Acrylic

Ribbed Diuser

GFF Acrylic

Clear Diuser

GFFW Acrylic

Clear Diuser

Fixture Hanging

Bracket

GFF-WMH:

Wall Mount

Fixture

Mounting

Hardware

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

10 LIGHTING PRODUCTS

UTILITY LIGHTING

GFF AND GFFW SERIESTM LIGHT FIXTURES (cont)

SURFACE MOUNT BRACKET “Y" OPTION

The Surface Mount Bracket (SMB) provides the Contractor with the ability to locate

and install a 2-foot, 4-foot or 8-foot GFF Series Light Fixture directly under or over a

junction box to surface mount the fixture to a ceiling or wall.

n The ability to wire the GFF Series fixture directly into the junction box.

n Eliminates the cost and installation of a fixture whip and junction box cover plate.

nReduces installation time and lowers labor cost.

n Providing a water and bug resistant seal that protects the critical area between the

junction box’s supply conductors and the light fixture. No adhesive sealant or

gasket material is required.

n The finished installation of the light fixture will be more pleasing to the

building owner without the fixture whip running across the ceiling.

n The SMB in combination with the GFF Light Fixture maintains its UL Listing for “wet"

location applications.

n Eight (8) slotted holes to simplify and expedite installation.

n Compliant with 2011 National Electrical Code: Article 410.24(B).

Note: The Surface Mount Bracket is a “factory installed" option and is not available for Sale as an Accessory

or for Field Retrofit.

We will pre-drill a hole in the GFF Series Light Fixture housing at the designated “number" location shown

in the following diagrams to facilitate pulling the supply conductors from the junction box and into the

fixture.

SURFACE MOUNT BRACKET: 4-FOOT GFF FIXTURE

SURFACE MOUNT BRACKET: 2-FOOT GFF FIXTURE

SURFACE MOUNT BRACKET: 8-FOOT GFF FIXTURE

Option - Y1

Large and Small Bracket

Option - Y

Large Bracket

Option - Y2

Large Bracket

Option - Y2

Large and Small Bracket

Option - Y3

Large and Small Brackets (2)

Option - Y1

Large and Small Bracket

Patent

Pending

Junction

Box

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

11LIGHTING PRODUCTS

UTILITY LIGHTING

GFF AND GFFW SERIESTM LIGHT FIXTURES (cont)

GFF AND GFFW SERIES SPECIFICATIONS

GFF and GFFW Series Fluorescent Light Fixtures provide a degree of protection against the ingress of solid foreign objects

(e.g., falling dirt), the ingress of water (e.g., hose directed water), protection against corrosion, and will be undamaged by the

external formation of ice on the enclosure.

n UL Listed and approved for use in wet locations.

n Meets the requirements of the 2011 National Electrical Code: Article 410.10(A).

n NEMA 4X and IP66/67 rated as a water resistant luminaire; protected against dust and strong jets of water.

n Meets the requirements of NSF ANSI Standard 2.*

n Operating Voltage: 120V - 277 VAC @ 60 Hz.

*National Sanitation Foundation (NSF International) is a leader in product certification and standards development. The NSF mark ( ) is your

assurance that all GFF and GFFW Series Light Fixtures have been tested and certified. This Standard establishes minimum food protection and sanitation

requirements for the materials, design, fabrication, construction, and performance of the GFF and GFFW Series Light Fixtures in the area of food handling

and food processing equipment.

SHIPPING WEIGHT APPROXIMATE:

n

2-Foot GFF Series Light Fixture: 8 Lbs. (3.62kg)

n

4-Foot GFF Series Light Fixture: 13 Lbs. (4.98kg)

n 8-Foot GFF Series Light Fixture: 21 Lbs. (8.61kg)

n 4-Foot GFFW Series Light Fixture: 26 Lbs. (11.79kg)

RECOMMENDED LAMP TYPES

n T5 Lamps

n T8 Lamps

Warning: T8 HO and T8 VHO Lamps must not be used under any circumstances! You will damage the light fixture and void the warranty!

MINIMUM STARTING TEMPERATURE:

n T5 - High/Standard Output: -20F / 29C.

n T8 - Standard Output Ballast: 0F / 18C.

n T8 - High Ballast Factor (HBF): -20F / 29C.

Note: High Ballast Factor is a system operating a standard output lamp to a higher wattage and lumen performance within standard lamp design. High

Output (HO) lamps operate with a higher current, thereby requiring ballasts to match the high output lamp designation and design.

GFF and GFFW Limited Warranty

Engineered Products Company (herein known as EPCO) warrants that it will repair, replace or refund, at EPCO‘s sole option, any GFF and/or GFFW Series

Light Fixture that is defective in materials or workmanship for a period of one (1) year from the date of original purchase. This warranty only applies to the

original purchaser and is not transferable.

This warranty does not apply to any of the following:

n Any GFF or GFFW Series Light Fixture that has been incorrectly installed by drilling holes, puncturing, piercing or any other means that will alter the

integrity of the xture housing.

n Product damage as determined by EPCO to be caused by a crash, impact, or obvious signs of abuse to the GFF or GFFW Series Light Fixture.

n Damage resulting from use of the GFF or GFFW Series Light Fixture in what EPCO, at its sole discretion, considers extreme applications.

n Damage caused by the use of parts, components, and/or other equipment(s) that is not compatible, suitable, and/or authorized by EPCO for use with the

GFF or GFFW Series Light Fixture.

n No charge-backs for any labor required to remove, re-install, or re-power the GFF or GFFW Series Light Fixture.

n Note: The Chemical Resistance of Plastics Chart (posted on EPCO’s web site) provides an overview of those chemical compounds where these light

xtures should not be installed.

The Ballast Warranty is ve (5) years and is limited to the original purchaser only. Contact the ballast manufacturer directly for more specic information on

their warranty policy and procedures.

EPCO GFF and GFFW Series Fluorescent Light Fixtures are Made in the USA. Complies with the American Recovery and Reinvestment Act - Buy American Provision.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

12 LIGHTING PRODUCTS

UTILITY LIGHTING

GFF AND GFFW SERIESTM LIGHT FIXTURES (cont)

A B C D E F G H I

4.25" (1) / 5.75" (2) 6.812" 2.44" 49.7" 51.7" 100" 98.0" 27.7" 25.7"

Note: Dimensions “E”, “F” and “H” reference the 1/2" trade size knockouts on each end of the light fixture.

D

I

E

H

G

F

A

B

C

A

B

C

(1)

Acrylic Ribbed Diffuser

(2)

Acrylic Clear Diffuser

Note: 1. Top down view of 2-foot, 4-foot and 8-foot GFF Series Gear Tray.

2. The GFF Series 8-foot Light Fixture will not accommodate 8-foot T8 lamps.

GFF SERIES LIGHT FIXTURES - LAMPS PER FIXTURE

4-Foot Fixture

2-Foot Fixture

Maximum of three (3) T5 or T8 Lamps

8-Foot Fixture

Maximum of six (6) T5 or T8 Lamps

GFF Series

Light Fixture

Note: Dimension “E” references the 1/2" trade size knockouts on each end of the light fixture.

A B C D E

6.125" 14.6" 3.0" 49.5" 51.5"

B

C

A

D

E

Note: Top down view of 4-foot GFFW Series Gear Tray.

Minimum of four (4) or Maximum of six (6) T5 or T8 Lamps

GFFW SERIES LIGHT FIXTURE - LAMPS PER FIXTURE

GFFW Series

Light Fixture

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

13LIGHTING PRODUCTS

UTILITY LIGHTING

GFF AND GFFW SERIESTM LIGHT FIXTURES (cont)

Fixture

[G]

Length

2 = 2-Feet

4 = 4-Feet

8 = 8-Feet

Ballast Type

T5 - High Output

T8 - Standard Output

T8HBF - High Ballast Factor

G 8 L 6 T8

B L S Y 3

GFF Fixture Options

A. 6-Foot Power Cord (PSS6)

B. Basic Specular Reflector (can be used with either the

Acrylic Ribbed of Clear Diffuser)

C. Acetal (Plastic) Latches (See Note 2)

E. Emergency Battery Back-up Ballast (See Note 3)

F. One (1) 1/2" Water Resistant Hub (See Note 8)

(required for Pendant Mounting a 2-foot or 4-foot fixture)

G. Two (2) 1/2" Water Resistant Hubs (See Note 8)

(required for Pendant Mounting an 8-foot fixture)

H. One (1) 3/4" Water Resistant Hub (See Note 8)

(required for Pendant Mounting a 2-foot or 4-foot fixture)

I. Two (2) 3/4" Water Resistant Hubs (See Note 8)

(required for Pendant Mounting an 8-foot fixture)

K. 3-Port Luminaire Disconnect

(required when a second ballast is installed)

L. 2-Port Luminaire Disconnect

(included on all GFF Series Fixtures)

M. Fixture Mounting Hardware for Hanging Applications

(two (2) per package)

O. Wire Lamp Guard (See Note 6)

P. Wall Mount Brackets (two (2) per package)

Q. Clear Diffuser (Note: The Acrylic Ribbed Diffuser is standard

with all GFF Series Fixtures unless otherwise specified. Not

available for the 2-foot GFF Light Fixture)

R. Occupancy Sensor

S. Stainless Steel Latches

T. Tamper Resistant Screws

W. Wide Specular Reflector (See Notes 4 and 5)

Y. Surface Mount Bracket (See Note 7)

Z. Bulk Packaging (25 or 50 per skid)

Number

of Lamps

L1 = 1 Lamp

L2 = 2 Lamps

L3 = 3 Lamps

L4 = 4 Lamps

L6 = 6 Lamps

The GFF Fixture can be built to your specifications by adding the respective item numbers.

Note:

1. When entering Bulk orders, do not include Mounting Hardware or Tamper Resistant

Screws in your part numbering scheme.

2. Acetal (Plastic) Latches ARE NOT recommended for the following applications:

- Swimming Pools because of the chlorine.

- Food Processing because of the cleaning chemicals.

- Car Washes because of the chemicals used.

- Agriculture because of the ammonia.

3. Two (2) lamps is the maximum lamp configuration when specifying a T5 2-foot light fixture

with an Emergency Battery Back-up Ballast.

4. The Wide Reflector for T5 and T8 lamps can only be used with two (2) lamp 4-foot GFF

Fixtures or four (4) lamp 8-foot GFF Fixtures.

5. The Wide Reflector can only be used in conjunction with the Acrylic Clear Diffuser (Option

Q). The Standard Acrylic Ribbed Diffuser will not fit! The Wide Reflector WILL NOT fit a

2-foot GFF Light Fixture.

6. When your part number includes the Wire Lamp Guard:

- The Acrylic Diffuser is not included with the light fixture.

- UL listing changes from a “wet" location to a “damp" location light fixture.

7. When adding the Surface Mounting Bracket (SMB - Y Option) to your part number, we will

pre-drill a hole in the fixture housing at the designated “number" location shown in the

diagrams, on page 10, to facilitate pulling the supply conductors from the junction box

and into the light fixture.

When specifying the Y Option for the 2-foot GFF Light Fixture,

there is no designated “number" location. Just include the Y Option as part of your

2-foot light fixture order configuration.

8. When adding the Water Resistant Hubs the UL listing changes from a "wet" location to a

"damp" location light fixture.

GFF SERIES - ORDERING INFORMATION EXAMPLE

GFF Series Light Fixture

Note: GFF Series Light Fixtures do not include T5 or T8 lamps!

Fixture

[W]

Length

4 = 4-Feet

Ballast Type

T5 - High Output

T8 - Standard Output

T8HBF - High Ballast Factor

W 4 L 6 T5

GFFW Fixture Options

A. 6-Foot Power Cord (PSS6)

E. Emergency Battery Back-up Ballast

G. Two (2) 1/2" Water Resistant Hubs (See Note 3)

(required for Pendant Mounting an 8-foot fixture)

I. Two (2) 3/4" Water Resistant Hubs (See Note 3)

(required for Pendant Mounting an 8-foot fixture)

L. Luminaire Disconnect

(included on all GFFW Series Fixtures)

N. Specular Reflector

O. Wire Lamp Guard (See Note 2)

R. Occupancy Sensor

T. Tamper Resistant Screws

V. V-Hooks for Chain (two (2) per Package)

X. Two (2) Circuit Fixture

Number

of Lamps

L4 = 4 Lamps

L6 = 6 Lamps

The GFFW Fixture can be built to your specifications by adding the respective item numbers.

Note:

1. Six (6) GFFW Fixtures is the minimum order quantity. We will not ship any GFFW Fixtures

that do not meet the minimum order quantity requirement!

2. When your part number includes the Wire Lamp Guard:

- The Acrylic Diffuser is not included with the light fixture.

- UL listing changes from a “wet" location to a “damp" location light fixture.

3. When adding the Water Resistant Hubs the UL listing changes from a "wet" location to a

"damp" location light fixture.

L N V

GFFW SERIES - ORDERING INFORMATION EXAMPLE

Note: GFFW Series Light Fixtures do not include T5 or T8 lamps!

GFFW Series Light Fixture

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

14 LIGHTING PRODUCTS

UTILITY LIGHTING

GFF AND GFFW SERIESTM LIGHT FIXTURES (cont)

Key: Order Unit: The Unit to be ordered; Unit Quantity: Number of same pieces in each Unit; Units per Case: Unit Packages contained in the case; Tl Case = Total Case Quantity: The number of similar items in the Unit Package;

Unit Package: The type of Packaging; Min Order = Minimum Order Quantity: The smallest Unit to order; MM req = Multiple Minimum Order Required: Must order multiples of Unit the quantities; ship WT = Shipping Weight:

Total weight of the Unit Package; Order Unit / Packaging Types: BG = Bag; BRL = Barrel; BX = Box; BN = Bulk; LS = Loose; PKG = Package; RL = Roll; EA = Each; Package; LB = Pound; C = Hundred; M = Thousand

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

GFF Series Light Fixture Accessories

GFF-DC4 14251 Replacement Clear Acrylic Diffuser: EA 1 BX 5 5 5 Yes 10

for 4-FT GFF Series Light Fixture

GFF-DC8 14252 Replacement Clear Acrylic Diffuser: EA 1 BX 5 5 5 Yes 21

for 8-FT GFF Series Light Fixture

GFF-DR2 14335 Replacement Ribbed Acrylic Diffuser: EA 1 BX 5 5 5 Yes 5

for 2-FT GFF Series Light Fixture

GFF-DR4 14253 Replacement Ribbed Acrylic Diffuser: EA 1 BX 5 5 5 Yes 10

for 4-FT GFF Series Light Fixture

GFF-DR8 14254 Replacement Ribbed Acrylic Diffuser: EA 1 BX 5 5 5 Yes 21

for 8-FT GFF Series Light Fixture

GFF-FSSK 14256 GFF/GFFW Fixture Suspension System Kit BG 2 BG 12 12 12 Yes 5

GFF-L2C 14336 Replacement Acetal (Plastic) Latches: BG 6 BG 0 0 6 Yes 1

for 2-FT GFF Series Light Fixture

GFF-L2SS 14337 Replacement Stainless Steel Latches: BG 6 BG 0 0 6 Yes 1

for 2-FT GFF Series Light Fixture

GFF-L4C 14240 Replacement Acetal (Plastic) Latches: BG 8 BG 0 0 8 Yes 1

for 4-FT GFF Series Light Fixture

GFF-L4SS 14239 Replacement Stainless Steel Latches: BG 8 BG 0 0 8 Yes 1

for 4-FT GFF Series Light Fixture

GFF-L8C 14250 Replacement Acetal (Plastic) Latches: BG 14 BG 0 0 14 Yes 1

for 8-FT GFF Series Light Fixture

GFF-L8SS 14249 Replacement Stainless Steel Latches: BG 14 BG 0 0 14 Yes 1

for 8-FT GFF Series Light Fixture

GFF-MH 14241 Fixture Mounting Hardware: BG 2 BG 0 0 2 Yes 1

for Ceiling Applications

GFF-SWLG4/8 14255 Steel Wire Lamp Guard: EA 1 BX 5 5 5 Yes 15

for 4-FT or 8-FT GFF Series Light Fixture

GFF-TPS-C 14248 Tamper Resistant Stainless Steel Screws: BG 100 BG 0 0 1 Yes 1

for Acetal (Plastic) Latches

GFF-TPS-S 14245 Tamper Resistant Stainless Steel Screws: BG 100 BG 0 0 1 Yes 1

for Stainless Steel Latches

GFF-WMH 14221 Fixture Mounting Hardware: EA 2 BG 0 0 2 Yes 1

for Wall Mount Applications

JC14B/100B 10205 14 AWG Jack Chain: 100-FT per Carton FT 100 BX 5 500 100 Yes 30

DL3B/100B 10211 14 AWG Bright Double Loop Chain: 100-FT per Carton FT 100 BX 5 500 100 Yes 30

GFFW Series Light Fixture Accessories

GFF-FSSK 14256 GFF/GFFW Fixture Suspension System Kit BG 2 BG 12 12 12 Yes 5

W-DC4 14238 Replacement Clear Acrylic Diffuser: EA 1 BX 5 5 5 Yes 27

for 4-FT GFFW Series Light Fixture

W-SWLG 50001 Wire Lamp Guard: EA 1 BX 5 5 5 Yes 19

for 4-FT GFFW Series Light Fixture

W-VHook 50002 Fixture Hanging Hardware: BG 2 BG 0 0 2 Yes 2

for 4-FT GFFW Series Light Fixture

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

15LIGHTING PRODUCTS

UTILITY LIGHTING

PROSERIESTM & PROSERIES GU24 UTILITY LIGHT FIXTURES

3.875"

*9.5"

10.5"

7.25"

5.5"

3.5"

4.1"

ENGINEERED PRODUCTS COMPANY

MINNETONKA, MN

SERIES 15800

SUITABLE FOR WET LOCATIONS

FOR USE WITH NON-METALLIC

WIRING SYSTEMS ONLY

18 CUBIC INCH

*Note: Measured without the Optional Safety Cage

PROSERIES AND PROSERIES GU24 UTILITY LIGHT FIXTURES

n

UL Listed. Suitable for use in wet locations. File Number: E182610.

n

Appropriate for use with all non-metallic wiring systems.

n

Provides the Contractor and Facility Manager with reliable, durable, maintenance free performance!

n

Labor savings! Fast installation saves time and reduces labor cost.

n

Versatile light fixture is suitable for numerous applications.

n

Rated for use with circuit conductors up to 150°C.

n

Can be used where high-pressure wash-down is required.

n

UV resistant, high impact, corrosion resistant construction.

n Integrated Octi-Junction Box™ Cover:

– Meets requirements of the 2011 National Electrical Code: Articles 314.15, 314.16(A)(2), 314.17(C),

410.10(A), 410.104(A), 547.5(C)(1) and (2) and 547.8(A) and (B).

– Provides extra junction box capacity for adding an additional power circuit.

– Easy to install; uses eight (8) mounting brackets that are “in-line" with 1/2" and 3/4" trade

size knockouts; eliminates a 2" x 4" stub-in by the installer.

Note: The Octi-Junction Box is not sold separately and will not t our Ceiling Mount Light Fixture

P/Ns: 15050, 15051, 15055, and 15056.

n Optional impact resistant quarter-turn safety cage attaches to the Octi-Junction Box without tools.

n T

he 18 Cubic Inch Octi-Junction Box and the “optional" Safety Cage are made from Polybutylene

Terephthalate (PBT) material.

Shown with optional

Safety Cage

18 Cubic Inch Octi-Junction Box uses eight (8) mounting brackets

that are “in-line" knockouts; eliminates a 2" x 4" stub-in.

Meets the box ll requirements as referenced in the 2011 National Electrical Code:

Articles 314.15, 314.16(A)(2), 314.17(C), 410.10(A), 410.104(A),

547.5(C)(1) and (2) and 547.8(A) and (B). The Octi-Junction Box

provides additional capacity for an extra power circuit.

Captive stainless steel set screw and posi-stop detent tab

on Octi-Junction Box Cover expedites xture installation.

Recessed Octi-Junction Box Cover with integral nickel-plated brass screw shell

accommodates high prole incandescent or compact uorescent lamps.

Captive stainless steel set screw secures the Octi-Junction

Box Cover to the Octi-Box – expedites xture installation.

Recessed Octi-Junction Box Cover with integral GU24 socket base accommodates

high prole Bi-Pin Compact Fluorescent Lamps.

1/2" and 3/4" trade size knockouts.

ProSeries GU24

Octi-Junction Box Cover

Octi-Junction Box with ProSeries

GU24 Octi-Junction Box Cover

Octi-Junction Box with

ProSeries (Edison Base)

Octi-Junction Box Cover

ProSeries (Edison Base)

Octi-Junction Box Cover

TYPICAL APPLICATIONS:

n

Food processing facilities

n

Commercial kitchens

n

Industrial facilities

n

Livestock containment buildings

n

Saunas

n

Laundries

n

Car washes

n

Elevator shafts

n

Storage buildings

n

Refrigerators and Freezers

n

Pedestrian and road tunnels

PROSERIES

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

16 LIGHTING PRODUCTS

UTILITY LIGHTING

PROSERIESTM & PROSERIES GU24 UTILITY LIGHT FIXTURES (cont)

Key: Order Unit: The Unit to be ordered; Unit Quantity: Number of same pieces in each Unit; Units per Case: Unit Packages contained in the case; Tl Case = Total Case Quantity: The number of similar items in the Unit Package; Unit

Package: The type of Packaging; Min Order = Minimum Order Quantity: The smallest Unit to order; MM req = Multiple Minimum Order Required: Must order multiples of Unit the quantities; ship WT = Shipping Weight: Total weight

of the Unit Package; Order Unit / Packaging Types: BG = Bag; BRL = Barrel; BX = Box; BN = Bulk; LS = Loose; PKG = Package; RL = Roll; EA = Each; Package; LB = Pound; C = Hundred; M = Thousand

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

ProSeries Utility Light Fixture (Edison Base)

15800 15800 ProSeries Utility Light: Standard Glass Globe; EA 1 BX 12 12 1 No 38

Rated for 150-watt Incandescent Lamp (maximum)

15801 15801 ProSeries Utility Light: Standard Glass Globe and Safety Cage; EA 1 BX 12 12 1 No 38

Rated for 150-watt Incandescent Lamp (maximum)

15805* 15805 ProSeries Utility Light: Acrylic Prismatic Globe; EA 1 BX 12 12 1 No 41

Rated for 60-watt Incandescent Lamp (maximum)

15806* 15806

ProSeries Utility Light: Polycarbonate Clear Globe;

EA 1 BX 12 12 1 No 38

Rated for 60-watt Incandescent Lamp (maximum)

15807* 15807

ProSeries Utility Light: Acrylic Prismatic Globe (Tall);

EA 1 BX 12 12 1 No 26

Rated for 60-watt Incandescent Lamp (maximum)

15810 15810 ProSeries Utility Light: Tempered Glass Globe; EA 1 BX 12 12 1 No 26

Rated for 150-watt Incandescent Lamp (maximum)

15811 15811 ProSeries Utility Light: Tempered Glass Globe and Safety Cage; EA 1 BX 12 12 1 No 26

Rated for 150-watt Incandescent Lamp (maximum)

15812 15812 Safety Cage: 1/4 Turn Attachment EA 1 BX 12 12 1 No 6

15815 15815 Octi-Junction Box Cover: with Porcelain Lamp Holder EA 1 BX 12 12 1 No 4

15680 15680 Compact Fluorescent Lamp: 23-watt, Self-Ballasted Lamp (5000K); EA 1 BX 50 50 1 No 8

Light output is equal to 90-watt incandescent lamp

ProSeries GU24 Utility Light Fixture

15865 15865

ProSeries GU24 Utility Light: Standard Glass Globe;

EA 1 BX 12 12 1 No 38

Rated for 23-watt GU24 Lamp (maximum)

15867 15867

ProSeries GU24 Utility Light: Standard Glass Globe and Safety Cage;

EA 1 BX 12 12 1 No 39

Rated for 23-watt GU24 Lamp (maximum)

15870* 15870

ProSeries GU24 Utility Light: Acrylic Prismatic Globe;

EA 1 BX 12 12 1 No 26

Rated for 23-watt GU24 Lamp (maximum)

15873* 15873 ProSeries GU24 Utility Light: Polycarbonate Clear Globe; EA 1 BX 12 12 1 No 39

Rated for 23-watt GU24 Lamp (maximum)

15875* 15875

ProSeries GU24 Utility Light: Acrylic Prismatic Globe (Tall);

EA 1 BX 12 12 1 No 26

Rated for 23-watt GU24 Lamp (maximum)

15880 15880

ProSeries GU24 Utility Light: Tempered Glass Globe;

EA 1 BX 12 12 1 No 38

Rated for 23-watt GU24 Lamp (maximum)

15885 15885

ProSeries GU24 Utility Light: Tempered Glass Globe and Safety Cage;

EA 1 BX 12 12 1 No 39

Rated for 23-watt GU24 Lamp (maximum)

15812 15812 Safety Cage: 1/4 Turn Attachment EA 1 BX 12 12 1 No 6

15890 15890 Octi-Junction Box Cover: with GU24 Lamp Socket EA 1 BX 12 12 1 No 4

15670 15670

Compact Fluorescent Lamp: 23-watt, GU24 Bi-Pin, Self-Ballasted Lamp (5000K);

EA 1 BX 50 50 1 No 8

Light output is equal to 90-watt incandescent lamp

*Note: Optional Safety Cage (Part Number 15812) will not fit ProSeries Part Numbers 15805, 15806, 15807, 15870, 15873 and 15875.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

17LIGHTING PRODUCTS

Key: Order Unit: The Unit to be ordered; Unit Quantity: Number of same pieces in each Unit; Units per Case: Unit Packages contained in the case; Tl Case = Total Case Quantity: The number of similar items in the Unit Package; Unit

Package: The type of Packaging; Min Order = Minimum Order Quantity: The smallest Unit to order; MM req = Multiple Minimum Order Required: Must order multiples of Unit the quantities; ship WT = Shipping Weight: Total weight

of the Unit Package; Order Unit / Packaging Types: BG = Bag; BRL = Barrel; BX = Box; BN = Bulk; LS = Loose; PKG = Package; RL = Roll; EA = Each; Package; LB = Pound; C = Hundred; M = Thousand

UTILITY LIGHTING

15000 SERIES

TYPICAL APPLICATIONS:

n

Walk-in Refrigerators

n

Elevator Shafts

n

Tunnels

n

Storage Buildings

n

Maintenance Areas

n

Hog and Poultry

Confinement Buildings

CEILING MOUNT LIGHT FIXTURES EDISON BASE

n

Medium-Base, UL Listed. File Number: E182610. Suitable for use

in damp locations.

n

Meets the requirements of the 2011 National Electrical Code:

Articles 314.16(A)(2), 314.17(C), 410.10(A) and 547.5(C)(1) and (2).

n

High impact, corrosion resistant, compression molded

phenolic junction box and fixture base.

n

Glass and Tempered Glass Globes rated for 150-watt/A21

incandescent lamp (maximum), medium-base compact

fluorescent or LED lamps.

n 

Polycarbonate and Acrylic Prismatic Globes rated for

60-watt/A19 incandescent lamp (maximum), medium-base

compact fluorescent or LED lamps.

n

All Ceiling Mount Fixtures are supplied with a cork mounting

gasket and corrosion protected screws with rubber washer.

Wired with 50°C (302°F) minimum supply wires (THHN).

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

With 12 Cubic Inch Junction Box (15045)

15000 15000 Utility Light: 1/2" & 3/4" Knockout Combo - Glass Globe EA 1 BX 12 12 12 Yes 24

15001 15001 Utility Light: 1/2" & 3/4" Knockout Combo - Tempered Glass Globe EA 1 BX 12 12 12 Yes 24

15002 15002 Utility Light: 3/4" Knockout - Glass Globe EA 1 BX 12 12 12 Yes 24

15005 15005 Utility Light: 1/2" & 3/4" Knockout Combo - Polycarbonate Globe EA 1 BX 12 12 1 No 18

15006 15006

Utility Light: 1/2" & 3/4" Knockout Combo - Acrylic Prismatic Globe (Tall)

EA 1 BX 12 12 1 No 19

15007 15007 Utility Light: 1/2" & 3/4" Knockout Combo - Acrylic Prismatic Globe EA 1 BX 12 12 1 No 19

Without Junction Box

15050 15050 Utility Light: Standard Glass Globe EA 1 BX 12 12 12 Yes 20

15051 15051 Utility Light: Tempered Glass Globe EA 1 BX 12 12 12 Yes 20

15055 15055 Utility Light: Polycarbonate Clear Globe EA 1 BX 12 12 1 No 14

15056 15056 Utility Light: Acrylic Prismatic Globe (Tall) EA 1 BX 12 12 1 No 15

15090 15090 Edison-Type Fixture Base: Globe not included EA 1 BX 12 12 1 No 7

Part Numbers

15050 15051

7.4375"

3.3"

6.7"

7.875" 6"

3.72"

3.28"

Part Numbers

15005 15055

9.4375"

11.625"

Part Numbers

15006 15056

3.7"

7.86"

3.3"

1.9375"

With Polycarbonate Clear Globe Glass and Tempered Glass Globes With Acrylic Prismatic Globe (Tall)

FIXTURE GLOBE AND JUNCTION BOX DIMENSIONAL REFERENCE

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

18 LIGHTING PRODUCTS

UTILITY LIGHTING

15000 SERIES

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

SPIDERBOX™ NONMETALLIC JUNCTION BOXES

n

UL Listed. File Number: E182992.

n

Suitable for use in “wet or damp" locations.

n

Corrosion resistant.

n

Easy to install using the eight (8) mounting

brackets that are in-line with knockouts.

n

Eliminates a 2" x 4" stub-in.

n

High impact compression molded phenolic

plastic rated to 150°C (302°F).

n

Meets the requirements of the 2011

National Electrical Code: Articles 314.15,

314.16(A)(2), 314.17(C), 547.5(C)(1) and (2).

COMPACT FLOURESCENT LAMPS

STANDARD NONMETALLIC JUNCTION BOXES

n

UL Listed. File Number: E182992.

n

High impact, compression molded

phenolic plastic rated to 150°C (302°F).

n

Meets the requirements of the 2011

National Electrical Code: Articles

314.15, 314.16(A)(2), 314.17(C),

and 547.5(C)(1) and (2).

n

Suitable for use in “wet or damp"

locations.

n

Corrosion resistant.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

15045 15045 12 Cubic Inch Junction Box: 1/2" and 3/4" Knockout Combo EA 1 BX 12 12 12 Yes 6

15046 15046 12 Cubic Inch Junction Box: 1/2" Knockouts EA 1 BX 12 12 12 Yes 6

15047 15047 12 Cubic Inch Junction Box: 3/4" Knockouts EA 1 BX 12 12 12 Yes 6

15049 15049 19 Cubic Inch Junction Box: 3/4" Knockouts EA 1 BX 12 12 12 Yes 6

15070 15070 16 Cubic Inch Single-Gang FS Type Junction Box: 1/2" Knockouts EA 1 BX 12 12 12 Yes 6

15071 15071 16 Cubic Inch Single-Gang FS Type Junction Box: 3/4" Knockouts EA 1 BX 12 12 12 Yes 6

15075 15075 Single-Gang Junction Box Cover and Gasket EA 1 BX 12 12 12 Yes 2

15690 15690 Universal Mounting Bracket EA 1 BG 0 0 1 No 6

15905 15905 Round Junction Box Cover and Gasket EA 1 BX 12 12 12 Yes 2

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

SPIDERBOX Non-Metallic Junction Boxes

15246 15246 12 Cubic Inch SPIDERBOX Junction Box: 1/2" Knockouts EA 1 BX 12 12 12 Yes 6

15247 15247 12 Cubic Inch SPIDERBOX Junction Box: 3/4" Knockouts EA 1 BX 12 12 12 Yes 6

15905 15905 Round Junction Box Cover and Gasket EA 1 BX 12 12 12 Yes 2

Compact Fluorescent Lamps

15670 15670 Compact Fluorescent Lamp: 23-watt, GU24 Bi-Pin, EA 1 BX 50 50 1 No 8

Self-Ballasted Lamp (5000K);

Light output is equal to a

90-watt Incandescent Lamp

15680 15680 Compact Fluorescent Lamp: 23-watt, Self-Ballasted Lamp (5000K); EA 1 BX 50 50 1 No 8

Light output is equal to a 90-watt Incandescent Lamp

12 Cubic Inch

16 Cubic Inch

19 Cubic Inch

Single-Gang

Junction

Box Cover

and

Gasket

Round

Junction Box

Cover and

Gasket

23-Watt

GU24 Bi-Pin

Compact

Fluorescent

Lamp

(P/N:

15670)

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

19LIGHTING PRODUCTS

UTILITY LIGHTING

15000 SERIES

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

FIXTURE GLOBES

GLASS AND TEMPERED GLASS GLOBES

n

Withstands extreme temperature changes.

n

Rated for use with a 150-watt/A21 incandescent

lamp (maximum), medium-base compact

fluorescent or LED lamp.

ACRYLIC PRISMATIC AND POLYCARBONATE GLOBES

n

UV stabilized material. The Acrylic Prismatic Globes resist discoloration four times longer than polycarbonate material.

n

3 Year guarantee against discoloration from UV exposure. For applications that require high-pressure washdown.

n

Acrylic Prismatic Globes feature internal ribbing and smooth exterior.

n

Rated for use with a 60-watt/A19 incandescent lamp (maximum), medium-base compact fluorescent or LED lamps.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

15015 15015 Glass Globe EA 1 BX 32 32 32 Yes 34

15016 15016 Tempered Glass Globe EA 1 BX 32 32 32 Yes 34

15020 15020 Polycarbonate Clear Globe EA 1 BX 12 12 12 No 5

15025 15025 Acrylic Prismatic Globe (Tall) EA 1 BX 12 12 12 No 5

15401 15401 Acrylic Prismatic Globe EA 1 BX 12 12 12 No 5

(a) Acrylic Prismatic Globe (Tall)

(b) Glass Globe

(c) Tempered Glass Globe

(d) Acrylic Prismatic Globe

(e) Polycarbonate Clear Globe

(a) (b) (c) (d) (e)

Note: Fixture Globes are sold ONLY in case quantities.

NONMETALLIC UF CABLE CONNECTORS

n

Compression type specifically designed for use with 14/2 or 12/2 AWG Romex® cable.

n

Low profile design fits the smaller UF Cables as well as standard sizes.

REPLACEMENT LAMP SOCKET

n

High temperature porcelain lamp socket with 6-inch 18 AWG stranded wire leads.

n

Includes corrosion resistant nickel-plated brass screw shell.

n

Can be used with 150-watt/A21 incandescent lamp (maximum), medium-base

compact fluorescent or LED lamps.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

15035 15035 Non-Metallic UF Cable Connector – 1/2": BG 12 BG 0 0 12 Yes 1

Accommodates 14/2 and 12/2 Romex Cable and our

SPT 16/3 Flat Power/Appliance Cords

15040 15040 Non-Metallic UF Cable Connector – 3/4": BG 12 BG 0 0 12 Yes 1

Accommodates 14/3 and 10/2 Romex Cable and our

SPT 16/3 Flat Power/Appliance Cords

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

15031 15031 Replacement Lamp Socket: Porcelain BG 12 BG 0 0 12 Yes 1

Note: Porcelain lamp sockets are not interchangable with light fixtures built with phenolic sockets.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

20 LIGHTING PRODUCTS

UTILITY LIGHTING

15000 SERIES

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

WALL MOUNT LIGHT FIXTURES EDISON BASE

n

UL Listed. Suitable for use in damp locations. File Number: E182610, Volume 2.

n

Meets the requirements of the 2011 National Electrical Code: Articles 314.16(A)(2), 314.17(C), 410.10(A) and 547.5(C)(1) and (2).

n

Can be used with incandescent lamps rated up to 150-watts/A21.*

n

Globe options: Glass, Tempered Glass or Acrylic Prismatic.

n

High impact, corrosion resistant construction.

n

Medium-Base – fits 3.25" or 4.0" Junction Box.**

n

Low cost alternative to Vapor Tight Light Fixtures.

n

Nickel-plated Brass Screw Shell.

n

UV resistant – will not fade or discolor.

WIRE GUARD

n

Fits Glass, Tempered Glass and Acrylic Prismatic (short) Globes only.

n

8 AWG steel, with a three-coat electrolytic plating.

n

Clamp-type attachment.

6.7"

3.4"

3.3"

3.7"

7.86"

3.3"

Black Fixture with

Tempered

Glass

Globe

White Fixture

with Acrylic

Prismatic

Globe

(Tall)

Glass and

Tempered

Glass

Globe

Acrylic

Prismatic

Globe

(Tall)

* When used with Glass or Tempered Glass Globes.

** Use the optional universal mounting bracket

(P/N: 15690) for residential junction box applications.

23-Watt Spiral

Fluorescent

Lamp

(P/N: 15680)

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

15063 15063 Wire Guard EA 1 BX 0 0 1 No 2

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Wall Mount Utility Light Fixtures

15600 15600 Utility Light: Tempered Glass Globe - Black EA 1 BX 12 12 1 No 22

15605 15605 Utility Light: Tempered Glass Globe; 12 Cubic Inch Junction EA 1 BX 12 12 1 No 28

Box with Combination 1/2" and 3/4" Knockouts - Black

15610 15610 Utility Light: Acrylic Prismatic Globe (Tall) - Black EA 1 BX 12 12 1 No 16

15615 15615 Utility Light: Acrylic Prismatic Globe (Tall); 12 Cubic Inch EA 1 BX 12 12 1 No 22

Junction Box Combination 1/2" and 3/4" Knockouts - Black

15620 15620 Utility Light: Tempered Glass Globe - White EA 1 BX 12 12 1 No 22

15625 15625 Utility Light: Tempered Glass Globe; 12 Cubic Inch Junction EA 1 BX 12 12 1 No 28

Box with Combination 1/2" and 3/4" Knockouts - White

15630 15630 Utility Light: Acrylic Prismatic Globe (Tall) - White EA 1 BX 12 12 1 No 16

15635 15635 Utility Light: Acrylic Prismatic Globe (Tall); 12 Cubic Inch EA 1 BX 12 12 1 No 22

Junction Box with Combination 1/2" and 3/4" Knockouts - White

Fluorescent Lamp

15680 15680

Compact Fluorescent Lamp:

23-watt, Self-Ballasted (5000K); EA 1 BX 50 50 1 No 8

Light output is equal to a 90-watt Incandescent Lamp

Universal Mounting Bracket

15690 15690 Universal Mounting Bracket EA 1 BG 0 0 1 No 6

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

21LIGHTING PRODUCTS

UTILITY LIGHTING

LAMP HOLDERS

* When used with Glass or Tempered Glass Globes.

** Use the optional universal mounting bracket

(P/N: 15690) for residential junction box applications.

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

16500 16500 Porcelain Lamp Holder: Keyless, 4-Terminal EA 1 BX 48 48 48 Yes 33

16502 16502 Porcelain Lamp Holder: Pull Chain EA 1 BX 48 48 48 Yes 35

16510 16510 Plastic Lamp Holder: Keyless, 4-Terminal EA 1 BX 48 48 48 Yes 11

16512 16512 Plastic Lamp Holder: Pull Chain EA 1 BX 48 48 48 Yes 13

16514 16514 Porcelain Lamp Holder: Pull Chain and 15 AMP Receptacle EA 1 BX 48 48 48 Yes 40

16520 16520 Porcelain Lamp Holder: Keyless, 4-Terminal with EA 1 BX 48 48 48 Yes 33

7" Black and White Conductors

16522 16522 Porcelain Lamp Holder: EA 1 BX 48 48 48 Yes 35

Pull Chain with 7" Black and White Conductors

16524 16524 Plastic Lamp Holder: Keyless, 4-Terminal with EA 1 BX 48 48 48 Yes 11

7" Black and White Conductors

16526 16526 Plastic Lamp Holder: EA 1 BX 48 48 48 Yes 13

Pull Chain with 7" Black and White Conductors

16100 16100 Safety Cage: Yellow EA 1 BX 10 10 10 Yes 1

16501 16501 Safety Cage: Metal EA 1 BX 12 12 12 Yes 6

Note: Lamp Holders are sold ONLY in case quantities of 48 per Carton.

PORCELAIN AND PLASTIC LAMP HOLDERS

n

UL Listed. File Number: E236781.

n

Nickel-plated Brass Screw Shell will not corrode.

n

For Commercial, Industrial, Residential and Agricultural Lighting Applications.

n

Medium-Base fits 3.25 inch or 4.0 inch Outlet Box.

n

UV resistant Lamp Holders will not fade or discolor.

n

Optional Plastic and Metal Safety Cages fit all Edison Base Lamp Holders.

n

Includes corrosion resistant mounting screws.

n

Meets the requirements of the

2011 National Electrical Code:

– Part Numbers: 16500, 16502, 16510, 16512 and 16514 - Articles 410.74(A)(B) and 410.122

– Part Numbers: 16520, 16522, 16524 and 16526 - Articles 410.52, 410.74(A)(B) and 410.122

Part Number:

16500

Part Number:

16514

Part Number:

16526

Part Number:

16502

Part Number:

16520

Part Number:

16100

Part Number:

16510

Part Number:

16522

Part Number:

16501

Part Number:

16512

Part Number:

16524

Lamp Holder

(P/N: 16512)

shown with

Metal Safety

Cage

(P/N: 16501)

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

22 LIGHTING PRODUCTS

UTILITY LIGHTING

GU24 LAMP HOLDERS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

3.10"

4.60"

3.75"

5.03"

Note: Lamp Holders are sold ONLY in case quantities of 24 per Carton.

n

UL Listed.

n

Includes 13-watt GU24 Bi-Pin compact fluorescent lamp (CFL) and polycarbonate lamp diffuser.

n

Can be used with a standard wall switch.

n

13-Watt GU24 Bi-Pin compact fluorescent lamp:

– Lamp Output = 900 lumens

– Lamp Color = 2700K

– Lamp Life (approximately 10,000 hours)

n

Lamp Holder Rating: 120W-250VAC, 60Hz

n Impact resistant construction.

n 7" Conductors simplify installation.

n Suitable for indoor use only.

n

Medium-Base fits 3.25 inch or 4.0 inch Outlet Box.

n Meets the requirements of the 2011 National Electrical Code: Articles 410.16(A)(2), 410.52, 410.74(A)(B), 410.722.

PULL CHAIN

KEYLESS

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

16530 16530 GU24 Lamp Holder: Keyless EA 1 BX 24 24 24 Yes 11

16535 16535 GU24 Lamp Holder: Pull Chain EA 1 BX 24 24 24 Yes 11

15675 15675 Compact Fluorescent Lamp: 13-watt, GU24 Bi-Pin, EA 1 BX 25 25 1 No 8

Self Ballasted Lamp (2700K)

GU24 LAMP HOLDERS

TYPICAL APPLICATIONS:

n

Closets

n Garages

n Attics

n Utility Rooms

n Basements

n Storage buildings

n Commercial, industrial, residential,

and agricultural lighting

n And more...

LIGHTING PRODUCTS

23

We are the leading American manufacturer of fixture whips for the electrical construction industry. Our pre-

wired armored cable fixture whips are factory fabricated wiring assemblies typically used for lighting and power

distribution in commercial buildings.

Our Fixture Whips consist of flexible metal conduit (FMC), .375mm (3/8”) and .5” (1/2”) trade sizes and meet all

requirements of the National Electrical Code (NEC), Article 348. These pre-assembled Fixture Whips provide an

excellent mechanical protection and a cost-effective, reliable installation. The connectors used are designed to

simplify the connection to metallic junction boxes and lighting fixtures. Typical applications include both new and

remodeled commercial buildings, industrial facilities, shopping centers, hotels, as well as health care, educational

and recreational facilities.

ADVANTAGES FOR THE CONTRACTOR

n A cost-effective and efficient alternative to traditional labor-intensive pipe and wire installation methods.

n Significantly reduces installation time to connect branch circuit power distribution and lighting systems.

n Fixture whip accessory products are available for the Contractor to expedite and facilitate installation.

n We can also build “custom” labor-saving Fixture Whips to the Contractor’s specifications. Please review page 29

for more specific information.

WHY CONTRACTORS USE UL LISTED EPCO FIXTURE WHIPS

n 100% of our Fixture Whips are assembled in our facility using UL Listed or UL Recognized components.

n Permitted for use by virtually all local building codes and approved by Electrical Inspectors in the majority of

municipalities across the U.S.

n A UL label attached to every Fixture Whip is an immediate identifier to the Electrical Inspector and

Contractor that our fixture whips have been inspected at the factory, listed by UL (File Number E87199) and

comply with the NEC.

n We provide product liability insurance as additional protection in the event of product defects that may cause a

liability to the Contractor.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

24 LIGHTING PRODUCTS

FIXTURE WHIPS

FIXTURE WHIPS WITH DIE CAST SCREW-IN CONNECTORS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Stranded Wire Fixture Whips - 3/8" (.375") Conduit

EPW1262 10311 2-12 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 175

EPW1263 10315 3-12 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 190

EPW1462 10303 2-14 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 160

EPW1463 10307 3-14 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 170

EPW1464 10308 4-14 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 180

EPW1662 10300 2-16 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1663 10301 3-16 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 165

EPW1664 10302 4-16 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 175

EPW1862 10297 2-18 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1863 10298 3-18 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 160

EPW1864 10299 4-18 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 170

Solid Wire Fixture Whips - 3/8" (.375") Conduit

EPW1262S 10336 2-12 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 175

EPW1263S 10337 3-12 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 190

EPW1462S 10333 2-14 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 160

EPW1463S 10334 3-14 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 170

EPW1464S 10335 4-14 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 180

EPW1662S 10330 2-16 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1663S 10331 3-16 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 165

EPW1664S 10332 4-16 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 175

EPW1862S 10327 2-18 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1863S 10328 3-18 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 160

EPW1864S 10329 4-18 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 170

Stranded Wire Fixture Whips - 1/2" (.5") Conduit

EPW1263-1/2 11600 3-12 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 186

EPW1264-1/2 10286 4-12 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 195

EPW1463-1/2 10309 3-14 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 175

EPW1464-1/2 10313 4-14 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 180

Solid Wire Fixture Whips - 1/2" (.5") Conduit

EPW1263S-1/2 10314 3-12 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 186

EPW1264S-1/2 10289 4-12 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 195

EPW1463S-1/2 10575 3-14 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 175

EPW1464S-1/2 10577 4-14 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 180

FIXTURE WHIPS WITH DIE CAST SCREWIN CONNECTORS

n

UL Listed. File Number: E87199.

n

Stranded and Solid THHN Conductors.

n

Includes Die Cast Screw-In Connectors on each end.

n

Packaging - 30 per Carton or 100 in an extra strong fiber drum.

n

Meets the requirements of the 2011 National Electrical Code: Articles 348.20(A)(2),

348.22, 410.177(C), and 410.137(C).

Note: Specify packaging requirements when placing your order. Add the “C” suffix to indicate 30 Fixture

Whips per Carton.

All stranded and solid wire conductors are stripped 5/8" (.625") from the end of the

conductor and securely tied to prevent damage to the conductors.

We manufacture Fixture Whips for 277 Volt applications. Contact our Inside Sales

Department (800.336.1976 or sales@engproducts.com) for more specific information.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

25LIGHTING PRODUCTS

FIXTURE WHIPS

FIXTURE WHIPS WITH DIE CAST SNAP-IN CONNECTORS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

FIXTURE WHIPS WITH DIE CAST SNAPIN CONNECTORS

n

UL Listed. File Number: E87199.

n

Significant Labor Savings!

n

3/8" Flexible Steel Conduit; 6-foot length – Standard.

n

Stranded and Solid THHN Conductors – Standard.

n

Manufactured using UL Listed or UL recognized components.

n

Packaging – 30 per Carton or 100 in an extra strong fiber drum.

n

Meets the requirements of the 2011 National Electrical Code: Articles 348.20(A)(2), 348.22, 410.117(C),

and 410.137(C).

Note: Specify packaging requirements when placing your order. Add the “C” suffix to indicate 30 Fixture Whips per Carton.

All stranded and solid wire conductors are stripped 5/8" (.625") from the end of the conductor and

securely tied to prevent damage to the conductors.

We manufacture Fixture Whips for 277 Volt applications. Contact our Inside Sales

Department (800.336.1976 or sales@engproducts.com) for more specific information.

Die Cast Snap-In Fixture Whips Part Number Reference Example: E P W 1 8 6 4 S A D

18 = Wire Gauge; 6 = Length (in feet); 4 = Wires; S = Solid Wire; AD = Die Cast Snap-In Connector

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Stranded Wire Fixture Whips

EPW1262AD 10554 2-12 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 175

EPW1263AD 10556 3-12 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 190

EPW1264AD 10558 4-12 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 170

EPW1462AD 10560 2-14 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 160

EPW1463AD 10369 3-14 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 170

EPW1464AD 10442 4-14 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 180

EPW1662AD 10566 2-16 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1663AD 10517 3-16 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 165

EPW1664AD 10568 4-16 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 175

EPW1862AD 10569 2-18 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1863AD 10281 3-18 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 160

EPW1864AD 10280 4-18 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 170

Solid Wire Fixture Whips

EPW1262SAD 10555 2-12 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 175

EPW1263SAD 10557 3-12 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 190

EPW1264SAD 10559 4-12 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 170

EPW1462SAD 10561 2-14 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 160

EPW1463SAD 10450 3-14 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 170

EPW1464SAD 10451 4-14 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 180

EPW1862SAD 10570 2-18 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1863SAD 10367 3-18 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 160

EPW1864SAD 10368 4-18 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 170

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

26 LIGHTING PRODUCTS

FIXTURE WHIPS

FIXTURE WHIPS WITH POLYCARBONATE SNAP-IN CONNECTORS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

FIXTURE WHIPS WITH POLYCARBONATE SNAPIN CONNECTORS

n

UL Listed. File Number: E87199

n

Significant Labor Savings!

n

Stranded and Solid THHN conductors – Standard.

n

Manufactured using UL Listed or UL recognized components.

n

Packaging – 30 per Carton or 100 in an extra strong fiber drum.

n

Meets the requirements of the 2011 National Electrical Code: Articles 348.20(A)(2), 348.22, 410.117(C),

and 410.137(C).

Note: Specify packaging requirements when placing your order. Add the “C" suffix to indicate 30 Fixture Whips per Carton.

All stranded and solid wire conductors are stripped 5/8" (.625") from the end of the conductor and

securely tied to prevent damage to the conductors.

We manufacture Fixture Whips for 277 Volt applications. Contact our Inside Sales

Department (800.336.1976 or sales@engproducts.com) for more specific information.

Polycarbonate Snap-In Fixture Whips Part Number Reference Example: E P W 1 8 6 4 S A

18 = Wire Gauge; 6 = Length (in feet); 4 = Wires; S = Solid Wire; A = Polycarbonate Snap-In Connector

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Stranded Wire Fixture Whips

EPW1262A 10318 2-12 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 175

EPW1263A 10319 3-12 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 190

EPW1462A 10316 2-14 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 160

EPW1463A 10317 3-14 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 170

EPW1464A 10326 4-14 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 180

EPW1662A 10323 2-16 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1663A 10324 3-16 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 165

EPW1664A 10325 4-16 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 175

EPW1862A 10320 2-18 AWG Stranded Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1863A 10321 3-18 AWG Stranded Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 160

EPW1864A 10322 4-18 AWG Stranded Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 170

Solid Wire Fixture Whips

EPW1262SA 10347 2-12 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 175

EPW1263SA 10348 3-12 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 190

EPW1462SA 10344 2-14 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 160

EPW1463SA 10345 3-14 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 170

EPW1464SA 10346 4-14 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 180

EPW1662SA 10341 2-16 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1663SA 10342 3-16 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 165

EPW1664SA 10343 4-16 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 175

EPW1862SA 10338 2-18 AWG Solid Wire: 6-FT - Black, White EA 1 BRL 100 100 10 Yes 155

EPW1863SA 10339 3-18 AWG Solid Wire: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 160

EPW1864SA 10340 4-18 AWG Solid Wire: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 170

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

27LIGHTING PRODUCTS

FIXTURE WHIPS

QUIKWHIP™ FIXTURE WHIPS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

QUIKWHIP FIXTURE WHIPS

n

UL Listed as a complete wire assembly that complies with the 2011 National

Electrical Code: Articles 348.20(A)(2), 348.22, 410.117(C), and 410.137(C). File #E87199.

n

Significant Contractor time and labor savings!

n

Pre-attached connectors add speed and dependability when finalizing fixture

whip terminations.

– Two (2) Die Cast “Snap-In” Connectors on each end of the

QuikWhip. Snaps directly into the fixture housing.

– WAGO® Pushwire 4-port connectors on each end of the QuikWhip.

n

No tools required to install the QuikWhip! A cost-effective solution that eliminates

lock nuts and wire nuts.

n

Easily insert the fixture’s conductors into the corresponding ports on the WAGO

connector and you’re finished. No wire nuts to twist or taping required.

n

Average Time Savings: 45% or up to three (3) minutes per fixture installation.

n

Approximate “installed” cost savings per fixture: $2.00 - $3.00.

n

Solid or Stranded THHN Conductors enclosed in 6-feet of 3/8" (.375") Flexible

Steel Conduit – Standard.

When you add-up your time and material cost, it makes economic sense to buy

“pre-fabricated,” ready-to-install QuikWhips from EPCO.

Note: The ground bonding conductor on each end of the QuikWhip includes a “green” WAGO grounding conductor.

Quikwhip Fixture Whips Part Number Reference Example: E P W 1 8 6 4 S A D P 2 - H N G

18 = Wire Gauge; 6 = Length (in feet); 4 = Wires; S = Solid Wire; AD = Die Cast Snap-In Connector; P = Pushwire Style Connector; 2 = Each End.

WAGO Connectors will be pre-attached to each end of the QuikWhip on the HOT, Neutral and Ground wires. HNG = Hot/Neutral/Ground.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Stranded Wire QuikWhips

EPW1463ADP1-HN

10546 3-14 AWG: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 171

EPW1463ADP1-HNG

10540 3-14 AWG: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 171

EPW1463ADP2-HNG

10531 3-14 AWG: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 171

EPW1464ADP2-HNG

10532 4-14 AWG: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 171

Solid Wire QuikWhips

EPW1263SADP1-HN

10548 3-12 AWG: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 191

EPW1263SADP1-HNG

10542 3-12 AWG: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 191

EPW1263SADP2-HNG

10535 3-12 AWG: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 191

EPW1863SADP1-HN

10544 3-18 AWG: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 161

EPW1863SADP1-HNG

10538 3-18 AWG: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 161

EPW1863SADP2-HNG

10533 3-18 AWG: 6-FT - Black, White, Green EA 1 BRL 100 100 10 Yes 161

EPW1864SADP1-HN

10545 4-18 AWG: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 171

EPW1864SADP1-HNG

10539 4-18 AWG: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 171

EPW1864SADP2-HNG

10534 4-18 AWG: 6-FT - Black, Red, White, Green EA 1 BRL 100 100 10 Yes 171

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

28 LIGHTING PRODUCTS

FIXTURE WHIPS

RETROFIT FIXTURE WHIPS WITH DIE CAST SCREW-IN CONNECTORS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Stranded Wire Retrofit Fixture Whips

EPW18103 10400 3-18 AWG Stranded Wire: 3/8" Conduit, 10-FT Length - EA 1 BRL 100 100 10 Yes 133

Black, White, Green

EPW18104 10402 4-18 AWG Stranded Wire: 3/8" Conduit, 10-FT Length - EA 1 BRL 100 100 10 Yes 142

Black, Red, White, Green

Solid Wire Retrofit Fixture Whips

EPW18103S 10401 3-18 AWG Solid Wire: 3/8" Conduit, 10-FT Length - EA 1 BRL 100 100 10 Yes 133

Black, White, Green

EPW18104S 10403 2-16 AWG Solid Wire: 3/8" Conduit, 10-FT Length - EA 1 BRL 100 100 10 Yes 142

Black, Red, White, Green

RETROFIT FIXTURE WHIPS WITH DIE CAST

SCREWIN CONNECTORS

n

UL Listed. File Number: E87199.

n

Labor saving Fixture Whips that expedite the installation process when

Contractors upgrade existing fluorescent fixtures with new energy saving ballast.

n

All stranded and solid wire conductors are stripped 5/8" (.625") from the end

of the conductor and securely tied to prevent damage to the conductors and

eliminate lost lock nuts.

n

Includes Die Cast Screw-In Connectors on each end.

Meets the requirements of the 2011 National Electrical Code: Article 410.137(C) as follows:

Wired luminaire (fixture) sections are paired, with a ballast(s) supplying a lamp or lamps in both. For

interconnection between paired units, it shall be permissible to use metric designator 12 (trade size 3/8")

flexible metal conduit in lengths not exceeding 7.5 m (25 ft) in conformance with Article 348. Luminaire

(fixture) wire operating at line voltage, supplying only the ballast(s) of one of the paired luminaires (fixtures),

shall be permitted in the same raceway as the lamp supply wires of the paired luminaires (fixtures).

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

29LIGHTING PRODUCTS

FIXTURE WHIPS

CUSTOM FIXTURE WHIP ORDER FORM

Wire (TFFN or THHN):



Solid



Stranded Wire Lead Length:



6-inch



12-inch



Other (specify) ___________

Wire Gauge:



12



14



16



18 Connector Type:



Left End



Right End (specify) ___________________

Wire Colors:



Black



White



Red Conduit Material:



3/8-inch



1/2-inch (Flexible Metal, Steel)



Green



Blue



Gray Insulated Throat:



Yes



No



Brown



Purple



Pink



Orange



Yellow



Other* (specify): ___________________

Conduit Length:



6-Foot



8-Foot



10-Foot



12-Foot



Other* ________________ * require longer lead times

Quantity Needed: __________________ Requested Shipping Date: __________________

Description: _____________________________________________________________________________________________________________________

_________________________________________________________________________________________________________________________________

Push-in Wire Connectors: Select wire color AND choose which end requires a Push-in Wire Connector:

CUSTOM FIXTURE WHIP ORDER FORM

We will build “Labor Saving” Fixture Whips to your specifications. Please use the information below to specify your non-Catalog

Custom Fixture Whip requirements. Complete this form and fax to:

Engineered Products Company, Attention: Inside Sales Department, FAX: 952.767.8786

If you need a quote on more than one Custom Fixture Whip, please complete a separate form for each variation.

Distributor: ________________________________________________ Contact: ______________________________________________________________

Address: __________________________________________________ City: _______________________________________ State/Zip: _______________

Sales Agency: ______________________________________________ Contact Name: ______________________________ Target Price ($):___________

(required)

Select a connector type (number) for each Fixture Whip

from the Connector Reference Guide shown below.

If your application requires a Connector other

than what is shown in the Reference Guide,

please indicate the following:

Connector Type: ______________________

Manufacturer: _______________________

Part Number: _______________________

Size: 3/8": P/N E00-041-002

Type: Set Screw, Squeeze

Material: Steel

Insulated: No

Size: 1/2": P/N E00-042-002

Type: Set Screw, Squeeze

Material: Steel

Insulated: Yes or No (circle one)

Size: 3/8": P/N E00-007-000

1/2": P/N E00-010-000

Type: Set Screw, 90º

Material: Die Cast

Insulated: Yes or No (circle one)

Size: 3/8": P/N E00-015-000

1/2": P/N E00-005-001

Type: Snap-in, 90º

Material: Die Cast

Insulated: No

Size: 3/8": P/N E00-003-003

1/2": P/N E00-004-003

Type: Speed Lock Style, Snap-in

Material: Steel

Insulated: Yes

CONNECTOR REFERENCE GUIDE

Size: 3/8": P/N E00-001-000

1/2": P/N E00-026-000

Type: Screw-in

Material: Die Cast

Insulated: Yes or No (circle one)

Size: 3/8": P/N E00-003-000

1/2": P/N E00-005-000

Type: Screw-in/Snap-in

Material: Die Cast

Insulated: Yes or No (circle one)

Size: 3/8": P/N E00-003-001

Type: Set Screw, Snap-in

Material: Die Cast

Insulated: No

Size: 3/8": P/N E00-041-000

1/2": P/N E00-042-000

Type: Set Screw, Squeeze

Material: Die Cast

Insulated: No

Size: 3/8": P/N E00-002-000

1/2": P/N E00-013-000

Type: Exterior, Snap-in

Material: Plastic w/Steel

Insulated: Yes



Left End



Right End



Black



Left End



Right End



White



Left End



Right End



Red



Left End



Right End



Green



Left End



Right End



Blue



Left End



Right End



Grey



Left End



Right End



Brown



Left End



Right End



Purple



Left End



Right End



Pink



Left End



Right End



Orange



Left End



Right End



Yellow

1

6

2

7

3

8

4

9

5

10

LIGHTING PRODUCTS

30

Make us your resource for Standard and UV filtering fluorescent tube guards! Their primary function is to provide

superior protection against broken glass and sparks that can result when fluorescent lamps shatter.

Our Tube Guards are “add-on” polycarbonate sleeves that are held in place around the linear fluorescent lamp

by two (2) plastic end caps. We always recommend using the end caps to maintain an air space between the

fluorescent lamp wall and the inside of the tube guard when placed around the lamp.

Note: It is extremely important to properly install our tube guards utilizing the supplied end caps. Improperly installed tube guards that come

into direct contact with the fluorescent lamp wall may cause premature lamp failure.

The average temperature to manufacturer polycarbonate tube guards is approximately 500°F. While some

manufacturers might use recycled polycarbonate material for tube guard production, we only use virgin

polycarbonate material for the best stability and long-term reliability. This means the melting point for our tube

guards is much higher and lowers the probability of them melting or deforming at the end of the fluorescent

lamp’s life. When the lamp and ballast system is wired correctly, the lamp and tube guard combination will function

satisfactorily during normal lamp life. However, toward the end of the lamp’s life, the ends of the lamp create

excessive heat that may cause the tube guard to heat up, distort and discolor. We always recommend using Heat

Sink Screens (P/N: 17893 - T5 HD, 17800 - T8, 17860 - T12) during the initial installation of new tube guards or when

retrofitting and reusing tube guards.

ADVANTAGES FOR THE CONTRACTOR

n Standard Tube Guards satisfy OSHA, FDA and USDA requirements for food processing, commercial businesses

and industrial plants.

n UV Filtering Tube Guards screen out harmful ultra-violet light emissions.

WHY CONTRACTORS USE EPCO TUBE GUARDS

n Our Standard Tube Guards are always “in-stock” and available for immediate shipping.

n End caps are included.

n Easy to install without the use of tools.

n Efficient, cost-effective and provides maximum protection against lamp breakage.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

31LIGHTING PRODUCTS

TUBE GUARDS

STANDARD TUBE GUARDS

The Standard Tube Guard is a light stabilized polycarbonate and has 0%

transmittance below 365 nanometers (Clear Tube Guards only). Available Colors:

Clear, Amber, Red, Green, Yellow and Blue. Available Sizes: T5, T8, and T12.

n An efficient economical solution where fluorescent lamp breakage would be

hazardous to personnel, product, equipment or animals.

n Slip over fluorescent lamps to retain shattered glass and control the release of

mercury vapor and phosphorescent material.

n Constructed of unbreakable lexan polycarbonate.

n “Cut-to-order” custom lengths are also available. Contact our Inside Sales

Department (800.336.1976 or sales@engproducts.com) for more information.

T5 HD SERIES TUBE GUARDS

Using T5 lamps is a cost-effective lighting systems solution for a variety of reasons.

Unfortunately the average T5 lamp will dissipate about 73% of its total lamp power

as heat. And when this lamp is used in combination with a tube guard, that heat

must be properly dissipated from the lamp.

Our T5 HD (Heat Dissipation) Series Tube Guard takes into consideration two major

factors; the temperature on the inside of the tube guard, and how close the T5 lamp

is actually located to the tube guard.

n Our T5 HD Series Tube Guard’s larger diameter and its “vented” End Caps allow a

layer of air to absorb heat from the lamp and cool it before making contact with

the inside wall of the tube guard. This results in a 25F temperature drop.*

n The larger diameter of the T5 HD Series Tube Guard allows it to accommodate

Heat Sink Screens to control and distribute heat, in addition to lowering the

temperatures over a larger area on the end of the tube guard.

Note: We strongly recommend using Heat Sink Screens with our T5 HD Series Tube Guards.

n The combination of the T5 HD Series Tube Guard, “vented” End Caps, and Heat

Sink Screens lower the inside temperature of the tube guard approximately 30F.**

n Together, these components provide a unique operational advantage over other

competitors T5 tube guards and still fits all T5 lamp applications.

TEMPERATURE TESTING

CONFIGURATION TEMPERATURE*

Original T5 Tube Guard 215F

T5 HD Series Tube Guard and “Vented” End Caps 190F*

T5 HD Series Tube Guard, “Vented” End Caps and

Heat Sink Screen

185F**

*Note: The temperature is measured on the inside surface of the Tube Guard. The ambient testing

temperature was 72ºF using a T5 F54 HO Lamp.

TYPICAL APPLICATIONS:

n

Food Processing Facilities

n

Commercial Kitchens

n

Grocery Stores

n

Laundries

n

Industrial Facilities

n

Saunas

n

Car Washes

n

Storage Buildings

n

Pedestrian and Road Tunnels

n

Parking Garages

n

Elevator Shafts

n

Refrigerators and Freezers

n

Locker Rooms

n

And more...

STANDARD TUBE GUARDS

T5 HD Series

“Vented” End Cap

T5 HD Series

Heat Sink

Screen

T5 HD Series

Tube Guard

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

32 LIGHTING PRODUCTS

TUBE GUARDS

STANDARD TUBE GUARDS (cont)

T5 HD SERIES TUBE GUARDS

DIM. “A” DIM. “B” NOMINAL

LENGTH

44.68 45.27 4'

“A” – Cut Tube Length

“B” – Overall Length

T12 TUBE GUARDS

DIM. “A” DIM. “B” NOMINAL

LENGTH

46.12 47.25 4'

68.56 69.67 6'

92.12 93.25 8'

T8 TUBE GUARDS

DIM. “A” DIM. “B” NOMINAL

LENGTH

46.38 47.10 4'

68.56 69.28 6'

92.38 93.10 8'

Note: End Caps for T5 HD Series, T8 and T12 Tube Guards fit inside the Tube Guard.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

17103 17103 End Caps: for T5 HD Series, “Vented" BG 48 BG 0 0 48 Yes 1

17100 17100 End Caps: for T8 BG 48 BG 0 0 48 Yes 1

17101 17101 End Caps: for T12 BG 48 BG 0 0 48 Yes 1

STANDARD TUBE GUARD END CAPS BLACK

STANDARD AND UV FILTERING TUBE GUARD DIMENSIONS

“A” – Cut Tube Length

“B” – Overall Length

“A” – Cut Tube Length

“B” – Overall Length

Note: Dimension “B” includes End Caps.

EPCO’s YELLOW TUBE GUARDS - How do they work?

Insects and humans have different visual perceptions. Light sources that radiate

ultraviolet energy and blue light are most attractive to insects. Light sources that

insects have a difficult time seeing are “yellow” hues in the color spectrum. Our

yellow tube guards will minimize the number of insects.

TYPICAL APPLICATIONS

n Commercial businesses that maintain night-time operations such as gas stations,

fast food restaurants, etc.

n Commercial food preparation and serving areas

n Parking lots loading areas

n Airport, Train and Bus Stations

n Building entrances

n

Decks and patios

YELLOW TUBE GUARDS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

33LIGHTING PRODUCTS

TUBE GUARDS

STANDARD TUBE GUARDS (cont)

T12 TUBE GUARDS

DIM. “A” DIM. “B” NOMINAL

LENGTH

46.12 47.25 4'

68.56 69.67 6'

92.12 93.25 8'

EPCO Standard Tube Guards are Made in the USA. Complies with the American Recovery and Reinvestment Act – Buy American Provision.

Note: *1. Standard Tube Guards are sold ONLY in case quantities of 24 per Carton. We will not

break case carton quantities! The exception is the T5 HD Series - Clear, which is available in

carton quantities of 48 and 120 Units (P/Ns: 17183 and 17184).

†2. Indicates long lead time. Contact our Inside Sales Department (800.336.1976 or sales@engproducts.com)

for more information.

3. Standard Tube Guards are not intended for use with HO or VHO Lamps! The exception is

the T5 HD Series Tube Guard that is rated for use with a T5 HO Lamp.

4. Tube Guards, other than sizes and colors listed, can be special ordered. Contact our

Inside Sales Department (800.336.1976 or sales@engproducts.com) for more information.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

T5 HD Series 4-Foot

17183* 17183 Clear Polycarbonate: with “Vented" Black End Caps EA 1 BX 48 48 48 Yes 6

17184* 17184 Clear Polycarbonate: with “Vented" Black End Caps EA 1 BX 120 120 120 Yes 16

17194† 17194 Amber Polycarbonate: with “Vented" Black End Caps EA 1 BX 24 24 24 Yes 4

17195† 17195 Red Polycarbonate: with “Vented" Black End Caps EA 1 BX 24 24 24 Yes 4

17196† 17196 Green Polycarbonate: with “Vented" Black End Caps EA 1 BX 24 24 24 Yes 4

17197† 17197 Blue Polycarbonate: with “Vented" Black End Caps EA 1 BX 24 24 24 Yes 4

17199† 17199 Yellow Polycarbonate: with “Vented" Black End Caps EA 1 BX 24 24 24 Yes 4

T8 4-Foot

17000 17000 Clear Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 6

17005 17005 Amber Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 6

17010 17010 Red Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 6

17015 17015 Green Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 6

17020 17020 Blue Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 6

17025 17025 Yellow Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 6

T8 6-Foot

17050 17050 Clear Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 8

T8 8-Foot

17030 17030 Clear Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 10

17031 17031 Amber Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 10

17032 17032 Red Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 10

17033 17033 Green Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 10

17034 17034 Blue Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 10

17035 17035 Yellow Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 10

T12 4-Foot

17060 17060 Clear Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 7

17065 17065 Red Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 7

17070 17070 Amber Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 7

17075 17075 Yellow Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 7

17080 17080 Blue Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 7

17085 17085 Green Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 7

T12 6-Foot

17040 17040 Clear Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 10

T12 8-Foot

17087 17087 Red Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 13

17088 17088 Green Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 13

17089 17089 Blue Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 13

17090 17090 Clear Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 13

17091 17091 Amber Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 13

17092 17092 Yellow Polycarbonate: with Black End Caps EA 1 BX 24 24 24 Yes 13

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

34 LIGHTING PRODUCTS

TUBE GUARDS

UV FILTERING TUBE GUARDS

n Our UV Filtering Tube Guards provide the basic reduction of harmful UV energy

by filtering 99% of harmful UV rays up to 390 nanometers.*

n Manufactured using thin-wall high tensile and impact resistant polycarbonate

material that is flexible to grasp the lamp to facilitate lamp changes; does not

easily crack.

n Special UV additive filters UV rays better than acrylic materials with comparable

wall thickness (0.016" wall thickness).

n Minimizes premature color shifting (fading) and deterioration that can be

detrimental to food products, paper, natural and synthetic textiles, paints,

coatings, wood and polymer materials, inc.

n Provides years of protection from dangerous UV light.

n Can readily be “field-cut” to length if desired.

n Manufactured to the highest quality standards.

n Sizes: T5, T8, and T12.

n Available in nominal 4-foot and 8-foot lengths.

*Note: Tested by two independent light testing laboratories.

TYPICAL APPLICATIONS:

n

Food Service

n

Commercial Kitchens

n

Photography Studios

n

Grocery Stores

n

Fabric Stores

n

Movie Theaters

n

Book Stores

n

Libraries

n

Furniture Stores

n

Warehouses

n

Special lighting applications where

UV protection is required

UV FILTERING TUBE GUARDS

Note: 1. UV Filtering Tube Guards are sold ONLY in case quantities of 24 per Carton. We will not break case carton quantities.

2.

UV Filtering Tube Guards are not to be used with HO or VHO fluorescent lamps! The exception is the UV Filtering T5 HD Series Tube

Guard that is rated for use with a T5 HO lamp.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

T5 HD Series 4-Foot

17206 17206 Clear UV Filtering: with “Vented” Green End Caps EA 1 BX 24 24 24 Yes 4

T8 4-Foot

17201 17201 Clear UV Filtering: with Green End Caps EA 1 BX 24 24 24 Yes 7

T8 8-Foot

17202 17202 Clear UV Filtering: with Green End Caps EA 1 BX 24 24 24 Yes 12

T12 4-Foot

17203 17203 Clear UV Filtering: with Green End Caps EA 1 BX 24 24 24 Yes 8

T12 8-Foot

17204 17204 Clear UV Filtering: with Green End Caps EA 1 BX 24 24 24 Yes 15

Note: End Caps for T5, T8 and T12 Tube Guards fit inside the Tube Guard.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

17303 17303 End Caps: for T5 HD Series, “Vented” BG 48 BG 0 0 48 Yes 1

17300 17300 End Caps: for T8 BG 48 BG 0 0 48 Yes 1

17301 17301 End Caps: for T12 BG 48 BG 0 0 48 Yes 1

UV FILTERING TUBE GUARD END CAPS GREEN

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

35LIGHTING PRODUCTS

Note: Heat Sink Screens are not to be used with HO or VHO lamps! The exception is the T5 HD Series Heat Sink Screen that is rated for use with a T5 HO lamp.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

17893 17893 Heat Sink Screen: for T5 HD Series Tube Guards BG 2 BG 0 0 2 Yes 1

17800 17800 Heat Sink Screen: for T8 Tube Guards BG 2 BG 0 0 2 Yes 1

17860 17860 Heat Sink Screen: for T12 Tube Guards BG 2 BG 0 0 2 Yes 1

HEAT SINK SCREENS

We recommend the use of Heat Sink Screens with all of our Tube Guards to aid in

controlling heat that is generated by the fluorescent lamp. The primary function

of our Heat Sink Screens is to distribute heat and lower the temperatures of the

fluorescent lamp over a larger area at each end of the Tube Guard.

The Heat Sink Screens are available in sizes for the T5 HD Series Tube Guard, as well

as T8 and T12 Tube Guards.

We recommend using Heat Sink Screens with all Tube Guards.

It is safe to use our Tube Guards preferably in conjunction with electronic high efficiency ballasts that are designed to prevent over-

heating of the lamp during use and at the lamps’s “end of life.”

We do not recommend using our Tube Guards under any condition where the surface temperature of the lamp can exceed 225°F

(107°C) or in any enclosed light fixture where normal venting is prohibited.

Heat Sink Screens T5 HD Series: Part Number 17893

Heat Sink Screens T8: Part Number 17800

Heat Sink Screens T12: Part Number 17860

Note: Our Tube Guards should not be used in any application where power surges or voltage spikes can cause arcing or over-burning

the lamps.

T5 HD SERIES HEAT SINK SCREEN

T8 HEAT SINK SCREEN T12 HEAT SINK SCREEN

T8 End Cap

T8 Heat Sink

Screen

T8 Tube Guard

WARNING

!

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

TUBE GUARDS

HEAT SINK SCREENS

New buildings under construction or retrofitting an existing building is an ever changing environment for

temporary lighting. Adequate temporary lighting is necessary for the safety and productivity of the workers, as well

as the quality of the completed work.

The General Contractor typically places the responsibility to provide temporary lighting on the Electrical

Contractor. And when it’s time to specify temporary lighting, 9 out of 10 times the Electrical Contractor chooses

Engineered Products Company, well-known for providing the best value for temporary lighting applications.

TYPEO PULSESTART LIGHTING TECHNOLOGY

n High-intensity light fixtures enhance productivity and provide increased security and safety.

n Energy efficient high lumen maintenance lowers operating expenses.

n Compact size and dependable high performance lighting source.

n Reliable operation and performance in a wide range of ambient temperatures.

CORDLIGHTS™

n Weather resistant lamp sockets feature rigid-mounted eyelets for hooks or wire to simplify hanging.

n Suitable for indoor and outdoor use.

n Unique open and secure closure clasp on the heavy duty lamp cage easily facilitates lamp changes.

n A patented detent “snap-off, snap-on” fitting on the lamp socket enables quick replacement if the Safety Cage

becomes damaged.

HID Temp Lights and CordLight products are always in stock!

36

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

36 LIGHTING PRODUCTS

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

37LIGHTING PRODUCTS

TEMPORARY LIGHTING

TIGER 400 AND TIGERCUB 175 HIDTM

During the construction phase, a skeletal framework is used which forms an interior subspace called a “bay,"

which in turn marks the space as either “high-bay" or “low-bay." We reference high-bay spaces as greater

than 30-feet off the floor and low-bay spaces as less than 25-feet off the floor.

TYPICAL HIGH-BAY APPLICATIONS FOR TIGER 400 HID:

n

Construction Sites

n

Industrial Facilities

n

Arena Lighting

n

High Rise Buildings

n

Manufacturing Facilities

n

Large Retail Centers

n

Big Box Stores

n

Discount Warehouses

TYPICAL LOW-BAY APPLICATIONS FOR TIGERCUB 175 HID:

n

Parking Garages

n

Grocery Stores

n

Retail Stores

n

Mezzanine Areas

n

Outdoor Areas

n

Schools and University Gymnasiums

METAL HALIDE LAMP SPECIFICATIONS

Color Lumen Average Rated Color Rendering

Temperature Output Life (In Hours) Index Voltage (AMPs)

TIGER 400 HID 4000K 38,000 15,000 60 120 3.25

TIGERcub 175 HID 4000K 16,600 12,000 60 120 1.5

*Note: These fixtures comply with the 2007 Energy Independence and Security Act (EISA) effective January 1, 2009. The intent of this

federal legislation focuses on improving the efficiency of certain consumer and electrical products – including metal halide fixtures – as

well as moving the United States toward reducing energy consumption and energy independence.

In compliance with EISA, EPCO’s TIGER 400-watt and TIGERcub 175-watt fixtures clearly display a capital letter “E" printed within a circle

( ) on the product carton and the ballast as specified by the Federal Trade Commission (FTC).

† The Illuminating Engineering Society of North America (IESNA), the authority in lighting, categorizes spaces as either high-bay (greater

than 30-feet) or low-bay (less than 25-feet).

TIGER 400 AND TIGERCUB 175 HID™ TEMPORARY LIGHT FIXTURES

n

Complies with the 2007 Energy Independence and Security Act (EISA).*

n

Meets the requirements of the 2011 National Electrical Code: Articles 410.62(C)(1) and (2),

410.104(A), 410.122, 410.130(F)(5) and 590.4(F).

n

Compact size, lightweight and balanced construction.

n

Easy to carry and install. UL Listed. Suitable for use in damp locations. TIGER 400 and TIGERcub

175 HID Light Fixtures and lamp combinations increase light levels up to 60% over traditional

probe-start fixtures while using the same number of fixture locations and wiring.

†

PULSE-START BALLAST

n

Reliable, durable, maintenance free performance!

n

A cost-effective solution to incandescent string

lighting.

n

Compact size, lightweight and balanced construction.

Easy to carry and install.

n

Faster warm-up time (2 min. vs. 4 min.)

n

Faster “hot" restrike (3-4 min. vs. 15-20 min.)

n

Improved cold weather starting performance.

n

Lower maintenance and operating cost –

ballast efficiency is 88%.

n

Pre-wired at the factory for 120V operation.

The multi-tap ballast can be re-configured for

208V, 240V or 277V applications.

n

Improved efficacy (up to 45% more lumens per watt).

FIXTURE LAMP WITH CERAMIC ARC TUBE

n

Improved lumen maintenance

(up to 25%).

n

Reduced color shift –

more consistent lamp-to-lamp color.

n

Longer lamp life – up to 30%

improvement over traditional

probe-start fixtures.

– 15,000+ hours for the TIGER 400 HID.

– 12,000+ hours for the TIGERcub 175 HID.

n

Higher initial lumen output.

n

Superior color rendering and

light stability.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

38 LIGHTING PRODUCTS

TEMPORARY LIGHTING

TIGER 400 AND TIGERCUB 175 HIDTM (cont)

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

Front View 9.875"

2.312"

8.0"

4.75"

Side View

20.5"

23.25"

12.875"

Rear View Two .75" Knockouts

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

TIGER 400 HID Temporary Lighting

15702 15702 TIGER 400 HID: 400-watt Type-O Metal Halide Lamp, EA 1 BX 1 1 1 No 22

Safety Cage and Lamp Guard

15752 15752 Type-O 400-Watt Metal Halide Lamp: Pulse-Start EA 1 BX 20 20 1 No 2

TIGERcub 175 HID Temporary Lighting

15711 15711 TIGERcub 175 HID: 175-watt Type-O Metal Halide Lamp, EA 1 BX 1 1 1 No 20

Safety Cage and Lamp Guard

15757 15757 Type-O 175-Watt Metal Halide Lamp: Pulse-Start EA 1 BX 20 20 1 No 2

HID Temporary Lighting Accessories

15760* 15760 Universal Replacement HID Safety Cage and Lamp EA 1 BX 5 5 1 No 9

Guard: Clamp Mount

* Note: Fits majority of manufacturer's HID Type-O and Type-S Temporary HID Lighting Fixtures.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

39LIGHTING PRODUCTS

TEMPORARY LIGHTING

CORDLIGHTS

TYPICAL APPLICATIONS:

n

Construction Sites

n

Parking Lots

n

Walkways

n

Festivals

n

Circus Tents

n

Christmas Tree Lots

n

Farmer’s Markets

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

TEMPORARY CORDLIGHTS

n

UL Listed. File Number: E190858. Meets all OSHA Standards.

n

Meets the requirements of the 2011 National Electrical Code: Article 590.4(B)(C).

n

Suitable for indoor and outdoor use.

n

Weather-resistant lamp sockets feature rigid-mounted eyelets for hooks or wire to

expedite and simplify hanging.

n

Unique open and secure closure clasp on the heavy-duty Safety Cage easily

facilitates bulb changes.

n

A patented detent “snap-off, snap-on" fitting on the lamp socket enables quick

replacement if the Safety Cage becomes damaged.

n

Rated only for use with Type A23 incandescent lamp - 150-watt rating (maximum),

compact fluorescent or LED lamps.

n

U.S. Patent Number: D.439,697.

DELUXE CORDLIGHTS

Deluxe CordLights are intended

for severe environments and are

impervious to dust, dirt, chemical

vapors, salt spray and other corrosive

elements. Constructed of heavy-duty

14/2, 14/3 or 12/3 SJTW round cord

with a 75°C (167°F) temperature

rating, Deluxe CordLights are UL

Listed and complies with UL Standard

1088 for Temporary Lighting Strings.

CONTRACTOR GRADE

CORDLIGHTS

Contractor Grade CordLight

is designed for medium-duty

applications and is ideal for

budget-minded Contractors who

need quality temporary lighting at

an affordable price. The Contractor

Grade CordLight is constructed

of heavy-duty 14/2 flat cord. Only

available in a 100-foot length.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Deluxe CordLights

16010 16010 Deluxe CordLights: 14/2 SJTW Round Cord, 100-FT Length, EA 1 BX 0 0 1 No 13

10-FT Centers (without Plug) - Yellow

16300 16300 Deluxe CordLights: 14/3 SJTW Round Cord, 100-FT Length, EA 1 BX 0 0 1 No 14

10-FT Centers (without Plug) - Yellow

16301 16301 Deluxe CordLights: 14/3 SJTW Round Cord, 100-FT Length, EA 1 BX 0 0 1 No 14

10-FT Centers (with Molded Plug) - Yellow

16350 16350 Deluxe CordLights: 12/3 SJTW Round Cord, 100-FT Length, EA 1 BX 0 0 1 No 19

10-FT Centers (without Plug) - Yellow

16353 16353 Deluxe CordLights: 12/3 SJTW Round Cord, 100-FT Length, EA 1 BX 0 0 1 No 19

10-FT Centers (with Molded Plug) - Yellow

16100 16100 Safety Cage: for Deluxe CordLight - Yellow EA 1 BX 10 10 10 Yes 1

Contractor Grade CordLights

16030* 16030 Contractor Grade CordLight: 14/2 Flat Cord, 100-FT Length, EA 1 BX 0 0 1 No 7

Ten (10) Lamp Sockets on 10-FT Centers - Yellow

16222 16222 Contractor Grade CordLight Kit: Includes Ten (10) Lamp EA 1 BX 0 0 1 No 3

Sockets and Ten (10) Safety Cages

16110 16110 Safety Cage: for Contractor Grade CordLight - Yellow EA 1 BX 10 10 10 Yes 1

*Note: The Contractor Grade CordLight is not UL Listed.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

40 LIGHTING PRODUCTS

TEMPORARY LIGHTING

CORDLIGHTS (cont)

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

SAFETY CAGES

n

Suitable for indoor and outdoor use.

n

Unique open and secure closure clasp on the heavy-duty Safety Cage easily

facilitates lamp changes.

INSULATION PIERCING LAMP SOCKET

n

Suitable for indoor and outdoor use.

n

Use to repair Contractor Grade CordLights, signage, appliances or other lighting fixtures.

n

Integrally designed terminals and contacts provide a superior electrical connection.

n

Use with 12 or 14 AWG THHN insulated stranded-wire.

n

No cutting, wire stripping, wire nuts or soldering required.

n

Rated only for use with Type A23 incandescent lamp - 150-watt rating (maximum),

compact fluorescent or LED lamps.

PIGTAIL LAMP SOCKET

n

A patented detent “snap-off, snap-on" fitting on the lamp socket

enables quick replacement if the Safety Cage becomes damaged.

Can be used with EPCO Safety Cage (P/N: 16100).

n

Suitable for indoor or outdoor use.

n

6-Inch leads, pre-stripped 5/8" (.625").

n

Rated only for use with Type A23 incandescent lamp - 150-watt rating

(maximum), compact fluorescent or LED lamps.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

16100 16100 Safety Cage: for Deluxe CordLight - Yellow EA 1 BX 10 10 10 Yes 1

16110 16110 Safety Cage: for Contractor Grade CordLight - Yellow EA 1 BX 10 10 10 Yes 1

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

16022 16022 Insulation Piercing Lamp Socket EA 5 BG 0 0 5 Yes 1

16110 16110 Safety Cage: for Contractor Grade CordLight - Yellow EA 1 BX 10 10 10 Yes 1

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

16023 16023 Pigtail Lamp Socket: with 6-Inch Leads EA 5 BG 0 0 5 Yes 1

16100 16100 Safety Cage: for Deluxe CordLight - Yellow EA 1 BX 10 10 10 Yes 1

LIGHTING PRODUCTS

41

LIGHTING PRODUCTS

41

The specific design of an outdoor lighting system is influenced by a variety of factors, including the site

characteristics, the scope of the landscape, its function, as well as the building owners requirements. But the

creation of an outdoor lighting system should always include our Landscape SplicePost or LightPost™. A few of the

value-added benefits include:

n

Suitable for use in wet locations.

n Ready to install. No assembly required.

n 3” Outside diameter PVC LightPost fixture fitting.

n Replaces EMT, conduit connectors and weatherproof boxes.

n 100% UV, corrosion and shatter-resistant.

n Accommodates a 1/2” trade size conduit nipple to mount a variety of light fixtures.

n The Uni-Stabilizer™ is made of durable polycarbonate material featuring four (4) uniquely shaped concaved

stabilizing blades. This design enables ground material to be easily packed around the Landscape LightPost

or SplicePost as well as provide solid in-ground support. The uni-stabilizer also helps resist against ground

movement typically caused by ground freezing and thawing.

n The 20° slanted top virtually eliminates water pooling or leakage into the interior of the Landscape LightPost and

SplicePost.

n 65° angled to bottom enables easy entry of UF Cable or conduit.

n Compact and attractive regardless of final height placement.

Compared to other designs, these landscape light fixture fittings are a cost-effective and simple solution for

permanent landscape, accent lighting or sign facade.

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

42 LIGHTING PRODUCTS

LANDSCAPE LIGHTING

LANDSCAPE SPLICEPOST®

Note: Cut-away shows wiring

connections inside the SplicePost Cap.

5.0"

15.25"

Buried

LANDSCAPE SLICEPOST™

Our Landscape SplicePost for outdoor lighting fixtures is different from any other “hollow pipe" style

landscape lightpost on the market. It features an internal wiring compartment/junction box, rated

for 19 cubic inches that easily accommodates two (2) 20 AMP circuits. The Landscape SplicePost

allows the installer to make a proper ground connection to safeguard people and property from

electrical shock hazards.

n

The Landscape SplicePost is UL Listed as a “Luminaire Fixture Fitting,"

suitable for use in wet locations.

n

Meets the requirements of the 2011 National Electrical Code:

Articles 314.3, 314.4, 314.15, 314.16(A)(2) and 314.17(B).

n

The Landscape SplicePost features a Separator Disk™ and SpliceCap™

that creates an integral “junction box" suitable for splicing.

n

The PVC SpliceCap is non-metallic and suitable for the majority of

outdoor lighting fixtures on the market.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Landscape SplicePost

LSPB 17200 Landscape SplicePost: PVC - Black EA 1 BX 9 9 9 Yes 21

17230 17230 Landscape SplicePost Cap: PVC, Separator Disk - Black EA 1 BX 0 0 1 Yes 1

Note: Landscape SplicePosts are ONLY sold in case quantities of 9 per Carton.

SpliceCap

compartment

fully encloses and

protects the circuit

conductors from

moisture, dirt

and abrasion.

Raised “Grips”

simplify installation

and removal of the

SpliceCap.

UF Connector

secures the

incoming supply

line cable to

the Separator Disk.

Incoming supply

line cable.

The SpliceCap’s 19 cubic inch box volume can house

two (2) 20 AMP circuit conductors.

Eight (8) internal “Stops” seat and rmly hold the

Separator Disk in place when the SpliceCap is

positioned on the PVC Pipe.

LANDSCAPE SPLICEPOST -

SPLICECAP CUT-AWAY EXAMPLE

Separator Disk with attached Ground

Wire. Use with non-grounded metallic

light xtures to make a safe ground

connection.

NEC Article 314.15 … boxes,

conduit bodies and ttings

installed in wet locations

shall be listed for use in wet

locations.

NEC Article 314.16(A)(2) –

Boxes 1650 cm

3

(100 in

3

)

or less, other than those

described in Table 314.16(A),

and non-metallic boxes shall

be durably and legibly marked

by the manufacturer with

their volume.

The Landscape SplicePost is

shatter resistant to denting

or cracking typically caused

by landscape maintenance

equipment. It is also

corrosion and UV resistant

and impervious to changing

environmental conditions.

When wiring multiple

lighting xtures in series, the

Landscape SplicePost’s angled

bottom allows UF Cable or

Conduit to easily enter at

dierent depths to eliminate

cable congestion.

SpliceCap accommodates a

1/2" trade size conduit nipple.

NEC Article 314.17 – Conductors

entering boxes, conduit bodies

or ttings shall be protected from

abrasion and shall comply with

314.17(A) through (D).

… Where raceway or cable is

installed with metal boxes or

conduit bodies, the raceway or

cable shall be secured to such

boxes and conduit bodies.

NEC Article 314.4 – All metal boxes

shall be grounded and bonded

in accordance with Parts I, IV,

V, VI, VII, and X of Article 250 as

applicable, except as permitted

in 250.112(I).

Replaces EMT, conduit connectors

and weatherproof boxes.

Uni-Stabilizer™ features unique

concave stabilizing blades that

allow ground material to be easily

packed around the Landscape

SplicePost for fast, easy and secure

installation.

The Uni-Stabilizer helps minimize

the Landscape SplicePost’s

movement typically caused by

ground freezing and thawing.

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

LIGHTING PRODUCTS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

43LIGHTING PRODUCTS

LANDSCAPE LIGHTING

LANDSCAPE LIGHTPOST®

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Landscape LightPost

LLPN25B 12701

Landscape LightPost: 17.5" - Black

EA 1 BX 9 9 9 Yes 21

E04-002-004 14025 Landscape LightPost Cap: Black EA 1 BX 0 0 1 No 1

LANDSCAPE LIGHTPOST™

The Landscape LightPost is UL Listed as a “Luminaire Fixture Fitting," suitable for use

in wet locations and complies with the 2011 National Electrical Code: Article 314.15.

It is designed for line voltage landscape light fixtures but can also be used for low

voltage fixtures.

*Note: The Landscape LightPost should always be used with a UL Listed Fixture and a grounding

means (i.e., ground bonded third wire) suitable for use in wet locations.

Note: Landscape LightPosts are ONLY sold in case quantities of nine (9) per Carton.

ASSEMBLY INSTRUCTIONS

1. Feed the light fixture’s black, white and ground wires through

the 1/2" nipple (not supplied) and Nesting Cap. Thread and

tighten the 1/2" nipple into the top of the Nesting Cap.

2. Using wire nuts or another appropriate connector, connect

the supply wires to the light fixture’s wires. Then push the

light fixture and Nesting Cap onto the top of the Landscape

LightPost.

3. Place the wired Landscape LightPost into the excavated trench

and position to the desired height.

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

44

GROUND BONDING

n GROUND BONDING

PIGTAILS™

n POWERTAILS® DEVICE

WIRING CONDUCTORS

n GROUND SCREWS

n GROUND CLIP

GROUND BONDING

45

GROUND BONDING

We introduced the Stranded Grounding PigTail over 37 years ago. Today, we have sold millions of Ground Bonding

PigTails. Our manufacturing expertise, quality, reliability, and expedited delivery time have always met customer

expectations.

Our Ground Bonding products provide a permanent and positive connection for the grounding system to ensure an

effective, low-impedance ground-fault current path to safeguard people and property from electrical hazards.

WHY CONTRACTORS USE EPCO GROUND BONDING PIGTAILS™ AND POWERTAILS®

No other company manufacturers more combinations of PigTails and PowerTails Device Wiring Conductors than we do.

Our solid and stranded wire single and dual-gang Ground Bonding PigTails are available in 6.5”, 8”, 10”, and 12” lengths

and include a grounding screw, a machine-formed and insulated crimped Ring or Flanged Spade Fork Terminal.

n The Ring Terminal used is a true grounding ring that actually “bites” into the screw head and receptacle box to ensure

an excellent “ground” connection.

n The factory made insulation crimp on the Ring Terminal and Flanged Fork Spade Terminal puts less stress on the

conductor’s strands to ensure an excellent ground and power connection because the strands will not break or

separate when these conductors are pushed into the junction box.

n The Flanged Fork Spade Terminal has “angled” flanges on the end of the “fork” that will stay in place to help the

installer connect the PigTail or PowerTail to the appropriate screw on the receptacle, switch or device.

ADVANTAGES FOR THE CONTRACTOR

n Installation speed and reliability!

n Cost-effective and efficient.

n Quickly connect receptacles, switches or other devices.

n The perfect products for pre-fabrication work in the shop or on the job site.

n A variety of configurations and lengths that meet a broad range of applications.

n Ground Bonding PigTails and PowerTail products are available in re-usable tubes.

n 12 AWG is the standard wire size. 14 AWG Ground Bonding PigTails are available.

n Solid Wire Ground Bonding PigTails: THHN Building Wire.

n Stranded Wire Ground Bonding PigTails: THHN Building Wire (19 or 65 strand).

n Ground Bonding PigTails in bulk quantities of 1,000 are available. Contact our Inside Sales Department

(800.336.1976 or sales@engproducts.com) for more information.

GROUND SCREW CHOICES

n Self-tapping GSC Ground Screw is used by Contractors when the metallic junction box’s ground screw hole is not

tapped or is not “cleanly” tapped.

n Tapered Point GSH Ground Screw is a labor savings screw used by Contractors. This ground screw is easy to start in

the pre-tapped hole.

TM

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

46 GROUND BONDING

GROUND BONDING

GROUND BONDING PIGTAILSTM

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

GROUND BONDING PIGTAILS 

INSULATED SOLID WIRE 12 AWG AND 14 AWG

n

UL Listed.

n

Our Solid Wire Ground Bonding PigTails are recommended for use

in metal box applications.

n

Features a captive GSH or GSC Green Ground Screw on one end, the other

end is pre-stripped 1".

Note: See Page 51 for detailed descriptions on the differences between the GSC and GSH Ground Screws.

n

Available in 6.5", 8", 10" and 12" lengths.

n

Typical applications:

– Ground bonding in a power distribution box, junction box or multi-gang

receptacle box.

– When a standard Stranded Wire PigTail is not required.

n

Meets the requirements of the 2011 National Electrical Code:

Articles 110.14(A) and (B) and 250.8.

*Contractor preferred

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

With GSC Ground Screw

20016 20016 6.5" PigTail: Captive GSC Ground Screw – Stripped 1" PKG 50 PKG 10 500 50 Yes 9

20086 20086 8" PigTail: Captive GSC Ground Screw – Stripped 1" PKG 50 PKG 10 500 50 Yes 11

20088 20088 10" PigTail: Captive GSC Ground Screw – Stripped 1" PKG 50 PKG 10 500 50 Yes 13

20090 20090 12" PigTail: Captive GSC Ground Screw – Stripped 1" PKG 50 PKG 10 500 50 Yes 1

With GSH Ground Screw

20009* 20009 6.5" PigTail: Captive GSH Ground Screw – Stripped 1" PKG 50 PKG 10 500 50 Yes 9

20010 20010 6.5" PigTail (14 AWG): Captive GSH Ground Screw – Stripped 1" PKG 50 PKG 10 500 50 Yes 7

20011* 20011 8" PigTail: Captive GSH Ground Screw – Stripped 1" PKG 50 PKG 10 500 50 Yes 11

20087 20087 10" PigTail: Captive GSH Ground Screw – Stripped 1" PKG 50 PKG 10 500 50 Yes 13

20089 20089 12" PigTail: Captive GSH Ground Screw – Stripped 1" PKG 50 PKG 10 500 50 Yes 15

20091 20091 8" PigTail (14 AWG): Captive GSH Ground Screw – Stripped 1" PKG 50 PKG 10 500 50 Yes 9

REFERENCE GUIDE – INSULATED SOLID WIRE PIGTAILS (12 AWG AND 14 AWG)

20009: 6.5-Inch* PigTail: With captive GSH Ground Screw - Stripped 1".

20011: 8-Inch*

20087: 10-Inch

20089: 12-Inch

20010: 6.5-Inch (14 AWG)

20091: 8-Inch (14 AWG)

PART NUMBERS

20016: 6.5-Inch PigTail: With captive GSC Ground Screw - Stripped 1".

20086: 8-Inch

20088: 10-Inch

20090: 12-Inch

GSC Ground Screw

EPCO Ground Bonding PigTails are Made in the USA. Complies with the American Recovery and Reinvestment Act – Buy American Provision.

Part Number: 20009

GSH Ground Screw

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

47GROUND BONDING

GROUND BONDING

GROUND BONDING PIGTAILSTM (cont)

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

GROUND BONDING PIGTAILS 

INSULATED STRANDED WIRE 12 AWG AND 14 AWG

n

UL Listed.

n

Labor and Time Savings!

n

Our Stranded Wire Ground Bonding PigTails can save the Contractor

up to 50 cents per installation.

n

Meets the requirements of the 2011 National Electrical Code:

Articles 110.14(A) and (B) and 250.8.

n

Factory-crimped Flanged Spade Terminal or Ring Terminal meets the

requirements of the 2011 National Electrical Code: Article 110.4 and

provides precise electrical terminations.

n

Typical applications: Ground bonding in a power distribution box,

junction box or multi-gang receptacle box.

Note: See Page 51 for detailed descriptions on the differences between the GSC and GSH Ground Screws.

Part Number: 20004

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

20007 20007 7" PigTail (14 AWG): One (1) Flanged Spade Terminal – Stripped 5/8" PKG 50 PKG 10 500 50 Yes 11

20008* 20008 8" PigTail: One (1) Flanged Spade Terminal – Stripped 5/8" PKG 50 PKG 10 500 50 Yes 13

20082 20082 10" PigTail: One (1) Flanged Spade Terminal – Stripped 5/8" PKG 50 PKG 10 500 50 Yes 13

20084 20084 12" PigTail: One (1) Flanged Spade Terminal – Stripped 5/8" PKG 50 PKG 10 500 50 Yes 15

With GSC Ground Screw

20020 20020 10" PigTail: Ring Terminal, captive GSC Ground Screw, PKG 50 PKG 10 500 50 Yes 15

One (1) Flanged Spade Terminal

20026 20026 12" PigTail: Ring Terminal, captive GSC Ground Screw, PKG 50 PKG 10 500 50 Yes 17

One (1) Flanged Spade Terminal

20035 20035 10" PigTail: Ring Terminal, captive GSC Ground Screw - Stripped 5/8" PKG 50 PKG 10 500 50 Yes 14

20036 20036 8" PigTail: Ring Terminal, captive GSC Ground Screw - Stripped 5/8" PKG 50 PKG 10 500 50 Yes 12

20040 20040 8" PigTail (14 AWG): Ring Terminal, captive GSC Ground Screw, PKG 50 PKG 10 500 50 Yes 11

One (1) Flanged Spade Terminal

20041 20041 8" PigTail: Ring Terminal, captive GSC Ground Screw, PKG 50 PKG 10 500 50 Yes 13

One (1) Flanged Spade Terminal

20044 20044 12" PigTail: Ring Terminal, captive GSC Ground Screw - Stripped 5/8" PKG 50 PKG 10 500 50 Yes 16

With GSH Ground Screw

20003 20003 8" PigTail (14 AWG): One (1) Flanged Spade Terminal, captive GSH Ground Screw PKG 50 PKG 10 500 50 Yes 16

20004* 20004 8" PigTail: One (1) Flanged Spade Terminal, captive GSH Ground Screw PKG 50 PKG 10 500 50 Yes 13

20019 20019 10" PigTail: One (1) Flanged Spade Terminal, captive GSH Ground Screw PKG 50 PKG 10 500 50 Yes 15

20025 20025 12" PigTail: One (1) Flanged Spade Terminal, captive GSH Ground Screw PKG 50 PKG 10 500 50 Yes 17

20029* 20029 8" PigTail: Ring Terminal, captive GSH Ground Screw - Stripped 5/8" PKG 50 PKG 10 500 50 Yes 12

20034 20034 10" PigTail: Ring Terminal, captive GSH Ground Screw - Stripped 5/8" PKG 50 PKG 10 500 50 Yes 14

20043 20043 12" PigTail: Ring Terminal, captive GSH Ground Screw - Stripped 5/8" PKG 50 PKG 10 500 50 Yes 16

*Contractor preferred

EPCO Ground Bonding PigTails are Made in the USA. Complies with the American Recovery and Reinvestment Act – Buy American Provision.

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

48 GROUND BONDING

GROUND BONDING

GROUND BONDING PIGTAILSTM (cont)

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

SINGLE AND DUALGANG GROUND BONDING PIGTAILS 12 AWG

n

Labor and Time Savings!

n

UL Listed.

n

Matched Flanged Spade and Ring Terminals

ensure a safe, reliable ground connection.

n

Meets the requirements of the 2011 National

Electrical Code: Articles 110.14(A) and (B) and 250.8.

Reprinted from the 2011 National Electrical Code: Article 250.148 –

Continuity and Attachment of Equipment Grounding Conductors

to Boxes: Where circuit conductors are spliced within a box, or

terminated on equipment within, or supported by a box, any

equipment grounding conductor(s) associated with those circuit

conductors shall be connected within the box or to the box with

devices suitable for the use in accordance with 250.148(A) through (E).

EPCO Ground Bonding PigTails are Made in the USA. Complies with the American Recovery and Reinvestment Act – Buy American Provision.

20040: 8-Inch (14 AWG) PigTail: One (1) Flanged Spade Terminal and a captive GSC Ground Screw.

20041: 8-Inch

20020: 10-Inch

20026: 12-Inch

PART NUMBERS

20007: 7-Inch (14 AWG) PigTail: One (1) Flanged Spade Terminal - Stripped 5/8".

20008: 8-Inch*

20082: 10-Inch

20084: 12-Inch

20036: 8-Inch PigTail: Ring Terminal and a captive GSC Ground Screw - Stripped 5/8".

20035: 10-Inch

20044: 12-Inch

REFERENCE GUIDE – INSULATED STRANDED WIRE PIGTAILS (12 AWG AND 14 AWG)

20003: 8-Inch (14 AWG) PigTail: One (1) Flanged Spade Terminal and a captive GSH Ground Screw.

20004: 8-Inch*

20019: 10-Inch

20025: 12-Inch

20029: 8-Inch* PigTail: Ring Terminal and a captive GSH Ground Screw - Stripped 5/8".

20034: 10-Inch

20043: 12-Inch

Part Number: 20074

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

20067 20067 Single-Gang PigTail: One (1) 8" Solid Wire Incoming Lead - PKG 20 PKG 10 200 20 Yes 9

Stripped 1", One (1) 8" Stranded Wire Conductor with One (1)

Flanged Spade Terminal, captive GSH Ground Screw

20068 20068 Single-Gang PigTail: One (1) 8" Stranded Wire Incoming Lead - PKG 20 PKG 10 200 20 Yes 9

Stripped 5/8", One (1) 8" Stranded Wire Conductor with One (1)

Flanged Spade Terminal, captive GSH Ground Screw

20070* 20070 Dual-Gang PigTail: Two (2) 8" Stranded Wire Conductors, each PKG 20 PKG 10 200 20 Yes 10

with One (1) Flanged Spade Terminal, captive GSH Ground Screw

20074* 20074 Dual-Gang PigTail: One (1) 8" Solid Wire Incoming Lead - PKG 20 PKG 10 200 20 Yes 11

Stripped 1",Two (2) 8" Stranded Wire Conductors, each with

One (1) Flanged Spade Terminal, captive GSH Ground Screw

20075 20075 Dual-Gang PigTail: One (1) 8" Stranded Wire Incoming Lead - PKG 20 PKG 10 200 20 Yes 13

Stripped 5/8", Two (2) 8" Stranded Wire Conductors, each with

One (1) Flanged Spade Terminal, captive GSH Ground Screw

PowerTails with One (1) Flanged

Terminal Part Numbers: 20065 (Black)

and 20062 (White)

Dual-Gang Grounding PigTails

Part Numbers: 20074 or 20075

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

49GROUND BONDING

GROUND BONDING

GROUND BONDING PIGTAILSTM (cont)

(THHN)

(UL 1015)

(THHN)

(UL 1015)

(THHN)

(UL 1015)

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

EPCO PowerTails are Made in the USA. Complies with the American Recovery and Reinvestment Act – Buy American Provision.

REFERENCE GUIDE – SINGLE AND DUAL-GANG GROUND BONDING PIGTAILS (12 AWG)

PART NUMBERS

20067: 8-Inch Single-Gang PigTail: One (1) 8" Solid Wire Incoming

Lead - Stripped 1", One (1) 8" Stranded Wire

Conductor with One (1) Flanged Spade Terminal

and a captive GSH Ground Screw.

20068: 8-Inch Single-Gang PigTail: One (1) 8" Solid Wire Incoming

Lead - Stripped 5/8", One (1) 8" Stranded Wire

Conductor with One (1) Flanged Spade Terminal and

a captive GSH Ground Screw.

20070: 8-Inch* Dual-Gang PigTail: Two (2) 8" Stranded Wire Conductors,

each with One (1) Flanged Spade Terminal and a

captive GSH Ground Screw.

20074: 8-Inch* Dual-Gang PigTail: One (1) 8" Solid Wire Incoming

Lead - Stripped 1", Two (2) 8" Stranded Wire

Conductors with Two (2) Flanged Spade Terminals

and a captive GSH Ground Screw.

20075: 8-Inch Dual-Gang PigTail: One (1) 8" Stranded Wire Incoming

Lead - Stripped 5/8", Two (2) 8" Stranded Wire

Conductors with Two (2) Flanged Spade Terminals

and a captive GSH Ground Screw.

REFERENCE GUIDE – POWERTAILS DEVICE WIRING CONDUCTORS (12 AWG)

20062: White PowerTail: Stranded Wire Conductor with One (1) Flanged Spade Terminal – Stripped 5/8".

20065: Black (THHN)

20063: White PowerTail: Stranded Wire Conductor with Two (2) Flanged Spade Terminals.

20064: Black (UL 1015)

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

20062 20062 8" PowerTail: White, Stranded Wire Conductor with PKG 50 PKG 10 500 50 Yes 8

One (1) Flanged Spade Terminal – Stripped 5/8"

20063 20063 8" PowerTail: White, Stranded Wire Conductor with PKG 50 PKG 10 500 50 Yes 9

Two (2) Flanged Spade Terminals

20064 20064 8" PowerTail: Black, Stranded Wire Conductor with PKG 50 PKG 10 500 50 Yes 8

Two (2) Flanged Spade Terminals

20065 20065 8" PowerTail: Black, Stranded Wire Conductor with PKG 50 PKG 10 500 50 Yes 9

One (1) Flanged Spade Terminal – Stripped 5/8"

POWERTAILS® DEVICE WIRING CONDUCTORS 12 AWG

n

UL Listed.

n

Labor Savings Tool! Used by Contractors that wire Commercial and Industrial buildings when using single and/or multi-gang

metal boxes.

n

Provides installation speed and a reliable connection when bringing power to multiple devices. Perfect for pre-wiring devices

in Contractor's shop or on the job site.

n

8" Length Black and White leads feature a factory crimped Flanged Spade Terminal that slips under the terminal screw on the device.

n

Manufactured using flexible 12 AWG stranded wire to easily push into the junction box.

n

Meets the requirements of the 2011 National Electrical Code: Articles 110.14(A) and (B).

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

50 GROUND BONDING

GROUND BONDING

GROUND BONDING PIGTAILSTM (cont)

SINGLEGANG SOLID WIRE: P/N 20067

SINGLEGANG STRANDED WIRE: P/N 20068

DUALGANG STRANDED WIRE: P/N 20070

DUALGANG SOLID WIRE: P/N 20074

DUALGANG STRANDED WIRE: P/N 20075

SINGLE AND DUALGANG GROUND BONDING PIGTAILS  APPLICATION EXAMPLES

The ground screw is screwed into and bonds the metal junction box. The two (2)

stranded wire grounding conductors with the anged spade terminals from this PigTail

grounds each receptacle. The solid wire conductor on the PigTail connects by wire nut to

the incoming ground conductor in the conduit and bonds back to the service panel.

The ground screw is screwed into and bonds the metal junction box. The single

stranded wire grounding conductor with the anged spade terminal from this same

PigTail grounds the receptacle. The solid wire grounding conductor on the PigTail

will ground the receptacle. The solid wire grounding conductor on the PigTail

connects to the MC Cable and bonds back to the service panel.

The ground screw is screwed into and “grounds" the metal junction box. The single

stranded wire grounding conductor with the anged spade terminal from this PigTail

grounds the receptacle. The stranded wire grounding conductor on the PigTail connects

(by wire nut) the incoming ground conductor in the MC Cable and bonds back to the

service panel.

The ground screw is screwed into the 10/32 tapped grounding hole opening in the

metal junction box, bonding the junction box to the conduit system and grounded

back to the service panel. The two (2) stranded wire ground PigTails with the anged

spade terminals would then connect to the grounding screw of the receptacles or

switches to be wired.

The ground screw is screwed into and “grounds" the metal junction box and is bonded

back to the service-grounded panel. Two (2) stranded wire grounding conductors with

anged spade terminals from this PigTail ground each receptacle. The stranded wire

grounding conductor on the PigTail connects by wire nut to the ground conductor

from the incoming cable.

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

51GROUND BONDING

GROUND BONDING

GROUND SCREWS AND GROUND CLIPS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

GSC 10053 GSC: Slotted, #2 Phillips, Hex Head with Cutting Point - Green PKG 100 PKG 10 1000 100 Yes 1

GSCT 30053 GSC: Slotted, #2 Phillips, Hex Head with Cutting Point - Green PKG 250 PKG 10 2500 250 Yes 2

20053 20053 GSC: Bulk C 1000 BN 0 0 1000 Yes 10

GSH 10051 GSH: Slotted, #2 Phillips, Hex Head, #2 Robertson with PKG 100 PKG 10 1000 100 Yes 1

Tapered Die Point - Green

GSHT 30051 GSH: Slotted, #2 Phillips, Hex Head, #2 Robertson with PKG 250 PKG 10 2500 250 Yes 2

Tapered Die Point - Green

20051 20051 GSH: Bulk C 1000 BN 0 0 1000 Yes 10

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

GC 10052 Ground Clip: for 14 AWG -12 AWG Solid Wire BG 100 BG 10 1000 100 Yes 1

GCT 30052 Ground Clip: for 14 AWG -12 AWG Solid Wire PKG 250 PKG 10 2500 250 Yes 2

20052 20052 GC: Bulk C 1000 BN 0 0 1000 Yes 10

GROUND SCREWS

Our Ground Screws and Ground Clip are manufactured in compliance with the

Restriction of Hazardous Substances (RoHS) European Directive. These Green Ground

Screws (#10-32 x .375") meet the requirements of the 2011 National Electrical Code:

Article 250.8.

GSC – Cutting Point Screw – Combination hex head, slotted, phillips and square

drive screw for use in metal boxes when holes have not been pre-tapped.

GSH – Hex Head Screw – Combination slotted, phillips and square drive tapered

point screw used to simplify wiring installations when pre-tapped holes exist in

metal boxes.

Note: Beginning July 1, 2006, Directive 2002/95/EC, of the European Union (EU), restricts the use of certain hazardous substances in

electrical and electronic equipment. Those substances are Lead, Mercury, Cadmium, Hexavalent Chromium, PBBs.

GROUND CLIPS

n

Excellent time and labor saving alternative to using Ground Screws.

n

Meets the requirements of the 2011 National Electrical Code: Article 250.8.

Our Ground Clips are specifically designed for termination of the grounding

conductor and should be used when a 10-32 hole is not pre-drilled or tapped into

a metallic junction box.

Since ground clips are forced onto the outside edge of the junction box, we

recommend using a “new" ground clip instead of re-using the old ground clip.

Ground clips should never be forced onto the round portion of a plaster ring or a

poor electrical connection will result.

INSTALLATION PROCEDURE

The correct way to install a ground clip is to feed the grounding conductor into the

ground clip with the shorter part of the ground clip placed inside the junction box.

Then use the flat blade of a screwdriver to force the ground clip onto the junction

box to ensure a good electrical connection. See illustration.

Note: Ground Screws listed above are used in our Ground Bonding PigTails.

EPCO

Ground

Clip

Grounding

Conductor

GSH Ground Screw-

Hex Head Screw

GSC Ground Screw-

Cutting Point Screw

52

SPLICE KITS/

HEAT SHRINK TUBING

n SPLICE KITS

n HEAT SHRINK TUBING

SPLICE KITS/

HEAT SHRINK TUBING

53

SPLICE KITS/

HEAT SHRINK TUBING

Our Splice Kits provide a permanent water resistant seal that eliminates expensive crimping tools when splicing

aluminum or copper conductors. These splice kits are specifically intended for direct burial applications and

designed to eliminate any cable deterioration and other problems that can lead to open circuits and cable failure.

Our Splice Kits are labor savings solutions that meet or exceed the Electrical Contractors requirements and can

easily encapsulate 18 AWG to 1/0 AWG multi-conductor wire splices as well as single service conductors up to

250 MCM. Heating the heat shrink tubing over the mechanical connector melts the adhesive to the cable, sealing

the splice from moisture and provide insulation and protection. Only a standard screwdriver is required to

terminate the wire into the mechanical connector.

Our kits are available in five (5) kit types and include the tubing, sealant and mechanical connectors to ensure

a safe and reliable splice.

SPLICE KIT COMMONALITIES

n UL Listed.

n Meets the requirements of the 2011 National Electrical Code: Article 110.14(B).

n Eliminates epoxies, tapes or separate mastics.

n Creates a waterproof splice.

n 600 Volt maximum, 105°C rating.

Note: Our Heat Shrink Torch is always recommended for use with all EPCO Splice Kits. A torch used for sweating copper tubing will not work

and could burn a hole in the shrink tubing!

SPLICE KITS AWG CHART

Dual Rated Butt

Splice Kits

Logical AWG

Number

AWG (and

“Aught" */0

Equivalent)

MCM

or

kcmil

DRBSK

8 8 17

7 7 21

6 6 26

5 5 33

4 4 42

DRBSK1

2 2 66

1 1 84

0 1/0 106

DRBSK3

-1 2/0 133

-2 3/0 168

-3 4/0 212

-3.7 4.7/0 250

Copper Butt

Splice Kits AWG

BSK1

BSK2

14

13

12

11

10

9

8 8

BS2

BSK3

BSK4

7

6

5

4

3

2

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

54 SPLICE KITS/HEAT SHRINK TUBING

SPLICE KITS/

HEAT SHRINK TUBING

SPLICE KITS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

UFC2B 10711 UF Cable Splice Kit – for Direct Burial: EA 1 BG 24 24 1 No 6

Accommodates Cable Sizes – 14/3 without

Ground (minimum),

8/3 without Ground (maximum)

COPPER BUTT SPLICE KITS

n UL Listed. File Number: E103228.

n Labor Savings! Designed to simplify splicing discreet copper conductors.

n Sizes: 14 AWG to 2 AWG.

n BSK series is rated for 600 Volts maximum, 105°C (221°F) temperature rating.

n Meets the requirements of the 2011 National Electrical Code: Articles 110.14(B),

300.5(E) and 300.50(D).

BSK Splice Kits include a mechanical butt splice connector and an 8-inch piece of

thick wall heat shrink tubing to create a fully insulated butt splice.

The BS Splice Kits use the same mechanical butt splice connector independent of

the heat shrink tubing in bulk quantities. These kits are approximately 1/3 the cost

of the equivalent Dual Rated Butt Splice Kits.

Before After

Heat Shrink Torch

After

Heat Shrink Tubing

Heat Shrink Torch

Heat Shrink Tubing Connector

Before

UF CABLE SPLICE KIT  FOR DIRECT BURIAL

n UL Listed for direct burial. File Number: E123896.

n Labor Savings! Obsoletes messy, two part Splice Kits.

n Accommodates UF Cables sizes: 14/3 without ground

minimum, 8/3 without ground maximum.

n 600 Volts maximum, 105°C (221°F) temperature rating.

n Meets the requirements of the 2011 National Electrical

Code: Articles 110.14(B), 300.5(E) and 300.50(D).

The UF Cable Splice Kit includes one (1) 4-position mechanical connector

and one piece of heat shrink tubing to splice and insulate 14 AWG to 8 AWG UF Cable.

By using Thick Wall Heat Shrink Tubing with sealant and the mechanical connector,

the repair of UF Cable is a quick, easy and reliable process.

No epoxies, tape or separate mastics are required.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

BS1 10713 Bulk Packaged Butt Splice Connectors: 8 AWG to 14 AWG BG 100 BG 0 0 1 No 8

BS2 10707 Bulk Packaged Butt Splice Connectors: 2 AWG to 8 AWG BG 100 BG 0 0 1 No 19

BSK1 10705 Butt Splice Kit: 14 AWG to 8 AWG Assembled EA 1 BG 24 24 1 No 2

BSK2 10706 Butt Splice Kit: 14 AWG to 8 AWG Assembled EA 1 BG 24 24 1 No 2

BSK3 10708 Butt Splice Kit: 8 AWG to 2 AWG Assembled EA 1 BG 24 24 1 No 2

BSK4 10709 Butt Splice Kit: 8 AWG to 2 AWG Assembled EA 1 BG 24 24 1 No 2

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

55SPLICE KITS/HEAT SHRINK TUBING

SPLICE KITS/

HEAT SHRINK TUBING

SPLICE KITS

SPLICE KITS (cont)

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

SELF SEALING UF SPLICE KIT  FOR DIRECT BURIAL

n UL Listed for direct burial. File Number: E123896.

n Labor Savings! Simplifies the assembly of a moisture resistant splice.

n Protects electrical connections and allows for re-entry if needed.

n Eliminates use of epoxies, tape or mastics.

n 600 Volts maximum, 105°C (221°F) temperature rating.

n Meets the requirements of the 2011 National Electrical Code:

Articles 110.14(B), 300.5(E) and 300.50(D).

The uniquely designed interference t cover enables direct burial of UF Cable to be a

quick and reliable process. The kit includes a mechanical connector, silicone lubricant

and the interference t covers. Accommodates 14 AWG to 8 AWG wire sizes.

Before

After

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

UFC3/4 10703 Self Sealing UF Splice Kit – for Direct Burial: EA 1 BG 24 24 1 No 10

Accommodates Cable Sizes – 14/3 without Ground (minimum),

8/3 with Ground (maximum)

DUAL RATED BUTT SPLICE KITS  FOR DIRECT BURIAL

n Eliminates expensive crimping tools when splicing aluminum

or copper conductors for direct burial.

n UL Listed components.

n 600 Volts maximum, 105°C (221°F) temperature rating.

n For use with aluminum and copper conductors.

n Meets the requirements of the 2011 National Electrical Code:

Articles 110.14(B), 300.5(E) and 300.50(D).

The kits include a pair of thick wall heat shrink tubing (2 pieces) and one (1) mechanical

connector. Popular splicing applications include repair and/or extending type USE Cable.

Before

After

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

DRBSK 11499

Dual Rated Butt Splice Kit: 8 AWG to 4 AWG Assembled

EA 1 BG 24 24 1 No 10

DRBSK1 11500

Dual Rated Butt Splice Kit: 2 AWG to 1/0 AWG Assembled

EA 1 BG 24 24 1 No 1

DRBSK3 11501

Dual Rated Butt Splice Kit: 2/0 AWG to 250 MCM Assembled

EA 1 BG 24 24 1 No 10

UF STRETCHER KIT  FOR DIRECT BURIAL

n UL Listed for direct burial. File Number: E123896.

n Labor Savings! Includes one 11.5" mechanical connector that eliminates the need to

use two (2) UF Cable Splice Kits (P/N: UFC2B) and a short piece of cable when repairing

a longer section of damaged UF Cable.

n 600 Volts maximum, 105°C (221°F) temperature rating.

n Meets the requirements of the 2011 National Electrical Code:

Articles 110.14(B), 300.5(E) and 300.50(D).

Simplify UF Cable repairs after a trencher or backhoe has damaged or destroyed a

7" to 10" section of UF Cable. Utilize our Thick Wall Heat Shrink Tubing with sealant to

make a quick and reliable repair. Eliminates epoxies, tapes or separate mastics and creates

a waterproof splice. The kit includes one (1) 4-position 11.5" connector and one (1) piece of heat

shrink tubing. Designed to splice and insulate 14 AWG to 8 AWG UF Cable.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

UFS2 10714

UF Stretcher Kit – for Direct Burial: Accommodates Cable Sizes –

EA 1 BG 12 12 1 No 12

14/3 without Ground (minimum), 8/3 without Ground (maximum)

56

SPLICE KITS/

HEAT SHRINK TUBING

Our Thick Wall Heat Shrink Tubing for direct burial applications is made from cross-linked polyolefin. This tough,

versatile tubing can be used for insulation, harnessing, strain relief, and identification purposes for residential,

commercial and industrial applications.

Heat Shrink Tubing is designed and tested to meet the most demanding requirements of IEEE, UL, CSA

and ANSI as well as many other international standards for performance and long-term reliability.

BENEFITS

n For direct burial applications; withstands severe mechanical requirements.

n Seals, protects and insulates electrical connections and terminations; provides excellent mechanical protection.

n Superior jacket tear resistance and elastomer characteristic allows better conformance over irregular contours

without splitting or cracking.

n Accommodates most applications Contractors will encounter.

n Excellent sealing efficiency ensuring no moisture ingress as the hot melt adhesive enables fill encapsulation

of cables and connectors.

n Provides maximum reliability protecting splices and terminations.

n High impact, abrasion, corrosion and chemical resistance.

n Provides a moisture and soil resistant seal.

n Rated for 600 Volts, 90°C continuous use.

n Standard Shrink Ratio: 3:1

n Shrink temperature: 120°C

TYPICAL APPLICATIONS

n Splice covers for repair of electrical cables and splice connections.

n Insulation cover or jacket repair on low voltage cables.

n Strain relief and environmental protection.

n HVAC systems for pipes and ducts.

Note: We recommend always using our Heat Shrink Torch for shrinking Thick Wall Heat Shrink Tubing. A torch used for sweating copper

tubing will not work and could burn a hole in the shrink tubing!

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

57SPLICE KITS/HEAT SHRINK TUBING

SPLICE KITS/

HEAT SHRINK TUBING

HEAT SHRINK TUBING (cont)

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

THICK WALL HEAT SHRINK TUBING  FOR DIRECT BURIAL

n UL Listed for direct burial. File Number: E123896.

n Meets the requirements of the 2011 National Electrical Code: Articles 110.14(B),

300.5(E) and 300.50(D).

n Installs and shrinks easily for labor savings. Most effective when insulating

over large transitions.

n 3:1 Shrink ratio enables wider cable range and fewer tubing sizes.

n Excellent abrasion, corrosion and environmental resistance properties.

n UV and fungi resistant.

Thick Wall Heat Shrink Tubing (HST) is used to dielectrically insulate and

encapsulate electrical connections. The HST internal coating has an adhesive

and sealant that melts when the tubing is heated to provide a moisture and

soil resistant seal. The standard color is black.

BULK THICK WALL HEAT SHRINK TUBING  FOR DIRECT BURIAL

Our Bulk Heat Shrink Tubing is used for direct burial and is the same quality

tubing as our popular packaged HST Thick Wall Tubing. Available in cut lengths

from 2" up to 48".

Please specify the length by adding the correct length in inches to the end of the

part number. Example: One (1) 13" piece of 14 AWG to 10 AWG tubing; E00-902-013.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

HST1410 10170 Heat Shrink Tubing: Conductor Size – 14 AWG to 10 AWG, BG 6 BG 12 72 6 Yes 5

Shrink Range – .36-Inch to .12-Inch; Includes Six (6) 8-Inch

Pieces per Package

HST84 10171 Heat Shrink Tubing: Conductor Size – 6 AWG to 2 AWG, BG 6 BG 12 72 6 Yes 7

Shrink Range – .75-Inch to .24-Inch; Includes Six (6) 8-Inch

Pieces per Package

HST23/0 10172 Heat Shrink Tubing: Conductor Size – 1/0 AWG to 3/0 AWG, BG 6 BG 12 72 6 Yes 9

Shrink Range – 1.10-Inch to .35-Inch; Includes Six (6) 8-Inch

Pieces per Package

HST2/0300 10173

Heat Shrink Tubing: Conductor Size – 2/0 AWG to 350 MCM

, BG 6 BG 12 72 6 Yes 10

Shrink Range – 1.50-Inch to .47-Inch; Includes Four (4) 8-Inch

Pieces per Package

HST300650 10174

Heat Shrink Tubing: Conductor Size – 250 MCM to 500 MCM,

BG 6 BG 12 72 6 Yes 13

Shrink Range – 2.0-Inch to .63-Inch; Includes Three (3) 12-Inch

Pieces per Package

HST14650 10175 Heat Shrink Tubing Multi–Pak: 14 AWG to 500 MCM, BG 6 BG 12 72 6 Yes 9

Includes Five (5) 8-Inch Pieces per Package of Part Numbers

HST1410, HST84, HST23/0, HST2/0300 and HST300650

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Conductor Size: 1 AWG / 3/0 AWG

E00-901-0__* n/a Thick Wall Tubing EA 1 BG 0 0 1 No 1

E00-901-005 13911 Thick Wall Tubing: One (1) 5-Inch Piece EA 1 BG 0 0 1 No 1

E00-901-006 13912 Thick Wall Tubing: One (1) 6-Inch Piece EA 1 BG 0 0 1 No 1

E00-901-008 13913 Thick Wall Tubing: One (1) 8-Inch Piece EA 1 BG 0 0 1 No 1

E00-901-009 13914 Thick Wall Tubing: One (1) 9-Inch Piece EA 1 BG 0 0 1 No 1

E00-901-010 13915 Thick Wall Tubing: One (1) 10-Inch Piece EA 1 BG 0 0 1 No 1

E00-901-012 13916 Thick Wall Tubing: One (1) 12-Inch Piece EA 1 BG 0 0 1 No 1

E00-901-024 13918 Thick Wall Tubing: One (1) 24-Inch Piece EA 1 BG 0 0 1 No 1

E00-901-036 13919 Thick Wall Tubing: One (1) 36-Inch Piece EA 1 BG 0 0 1 No 1

E00-901-048 13920 Thick Wall Tubing: One (1) 48-Inch Piece EA 1 BG 0 0 1 No 1

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

58 SPLICE KITS/HEAT SHRINK TUBING

SPLICE KITS/

HEAT SHRINK TUBING

HEAT SHRINK TUBING (cont)

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

HEAT SHRINK TORCH

Recommended for shrinking Thick Wall Heat Shrink Tubing and for use with all our

Splice Kits. The trigger-start ignition starts fast and easy. Features a fully adjustable

regulator valve and air inlet port for adjustable flame settings.

Connects directly to a standard 14.1 propane tank (not included).

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Conductor Size: 14 AWG / 10 AWG

E00-902-0__* n/a Thick Wall Tubing EA 1 BG 0 0 1 No 1

E00-902-006 13925 Thick Wall Tubing: One (1) 6-Inch Piece EA 1 BG 0 0 1 No 1

E00-902-008 13926 Thick Wall Tubing: One (1) 8-Inch Piece EA 1 BG 0 0 1 No 1

E00-902-009 13927 Thick Wall Tubing: One (1) 9-Inch Piece EA 1 BG 0 0 1 No 1

E00-902-012 13928 Thick Wall Tubing: One (1) 12-Inch Piece EA 1 BG 0 0 1 No 1

E00-902-024 13929 Thick Wall Tubing: One (1) 24-Inch Piece EA 1 BG 0 0 1 No 1

E00-902-048 13931 Thick Wall Tubing: One (1) 48-Inch Piece EA 1 BG 0 0 1 No 1

Conductor Size: 6 AWG / 2 AWG

E00-903-0__* n/a Thick Wall Tubing EA 1 BG 0 0 1 No 1

E00-903-006 13937 Thick Wall Tubing: One (1) 6-Inch Piece EA 1 BG 0 0 1 No 1

E00-903-008 13938 Thick Wall Tubing: One (1) 8-Inch Piece EA 1 BG 0 0 1 No 1

E00-903-009 13939 Thick Wall Tubing: One (1) 9-Inch Piece EA 1 BG 0 0 1 No 1

E00-903-010 13940 Thick Wall Tubing: One (1) 10-Inch Piece EA 1 BG 0 0 1 No 1

E00-903-012 13941 Thick Wall Tubing: One (1) 12-Inch Piece EA 1 BG 0 0 1 No 1

E00-903-024 13943 Thick Wall Tubing: One (1) 24-Inch Piece EA 1 BG 0 0 1 No 1

E00-903-048 13945 Thick Wall Tubing: One (1) 48-Inch Piece EA 1 BG 0 0 1 No 1

Conductor Size: 2/0 AWG / 350 MCM

E00-904-0__* n/a Thick Wall Tubing EA 1 BG 0 0 1 No 1

E00-904-006 13949 Thick Wall Tubing: One (1) 6-Inch Piece EA 1 BG 0 0 1 No 1

E00-904-008 13950 Thick Wall Tubing: One (1) 8-Inch Piece EA 1 BG 0 0 1 No 1

E00-904-009 13951 Thick Wall Tubing: One (1) 9-Inch Piece EA 1 BG 0 0 1 No 1

E00-904-012 13952 Thick Wall Tubing: One (1) 12-Inch Piece EA 1 BG 0 0 1 No 1

E00-904-024 13953 Thick Wall Tubing: One (1) 24-Inch Piece EA 1 BG 0 0 1 No 1

E00-904-030 13954 Thick Wall Tubing: One (1) 30-Inch Piece EA 1 BG 0 0 1 No 1

E00-904-048 13955 Thick Wall Tubing: One (1) 48-Inch Piece EA 1 BG 0 0 1 No 1

Conductor Size: 250 MCM / 500 MCM

E00-905-0__* n/a Thick Wall Tubing EA 1 BG 0 0 1 No 1

E00-905-006 13957 Thick Wall Tubing: One (1) 6-Inch Piece EA 1 BG 0 0 1 No 1

E00-905-008 13958 Thick Wall Tubing: One (1) 8-Inch Piece EA 1 BG 0 0 1 No 1

E00-905-009 13959 Thick Wall Tubing: One (1) 9-Inch Piece EA 1 BG 0 0 1 No 1

E00-905-012 13960 Thick Wall Tubing: One (1) 12-Inch Piece EA 1 BG 0 0 1 No 1

E00-905-024 13963 Thick Wall Tubing: One (1) 24-Inch PIece EA 1 BG 0 0 1 No 1

E00-905-048 13965 Thick Wall Tubing: One (1) 48-Inch Piece EA 1 BG 0 0 1 No 1

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

HST-T1 12200 Heat Shrink Torch EA 1 BX 20 20 1 No 22

BULK THICK WALL HEAT SHRINK TUBING CONTINUED

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

59SPLICE KITS/HEAT SHRINK TUBING

SPLICE KITS/

HEAT SHRINK TUBING

HEAT SHRINK TUBING (cont)

Fully recovered after heating

Expanded as supplied $

#

$

#

w

d

#

$

D

Property Typical Performance

Physical

Tensile Strength 2100 psi (14.5 MPa)

Specific Gravity 1.1

Heat Shock (4 hrs at 225ºC (437ºF)) No cracking or flowing

Low Temperature Flexibility No cracking

(4 hrs at -55ºC (-67ºF))

Electrical

Dielectric Strength 500 V/Mil (20kV/mm)

Dielectric Voltage Withstand No breakdown, 24kV-1 min,

(2500 V, 60 Hz, 1 min) 15kV-4 hrs

Volume Resistivity 1016 ohm-cm

Chemical

Fluid Resistance Good to Excellent

Copper Corrosion No corrosion

Water Absorption 0.1%

Fungus Resistance No growth

Adhesive

Adhesive softening point 92ºC (197ºC) +/- 5ºC (41ºF)

Adhesive Lap Shear 125 psi (0.875 MPa)

Adhesive Blocking (30ºC (86ºF)) No blocking

Water Penetration No penetration after 236 hrs (min)

of continuous immersion

Expanded Recovered 600 / 1000 V

Internal Diameter Internal Diameter Wall Thickness Application Range for Single Conductor

(min) D (max) d (nom) W General Use Size

Part Number Inches MM Inches MM Inches MM Inches MM AWG / MCM

HST1410 0.35 8.9 0.12 3.0 0.7 1.8 .15 - .3 3.5 - 8 #14 - #10

HST84 0.75 19.1 0.24 6.1 0.12 3.0 .25 - .65 6.5 - 16.5 #6 - #2

HST23/0 1.10 27.9 0.35 8.9 0.12 3.0 .4 - .95 10 / 24 #1 - 3/0

HST2/0300 1.50 38.1 0.47 11.9 0.14 3.6 .5 - 1.4 13 - 35 2/0 - 350

HST300650 2.0 50.8 0.63 16 0.14 3.6 .7 - 1.75 17.5 - 44 250 - 500

Refer to the table shown below to select the Heat Shrink Tubing

size which will shrink to t snugly over the component to be

covered. If recovery is restricted the resulting wall thickness

will be less than specied.

DIMENSIONS

SPECIFICATIONS

60

PRODUCT ACCESSORIES

n RESIDENTIAL

n COMMERCIAL

PRODUCT ACCESSORIES

61

PRODUCT ACCESSORIES

Whether it’s a large multi-family housing complex, town houses, or even a single family home, the benefits of using

our Residential Products Accessories increases the Electrical Contractor’s productivity, expedites the installation

time — and meets the Electrical Contractor’s budget and application needs.

We are an excellent source for the Contractor’s residential product accessory needs. We use only quality

components to ensure they operate as specified. All of our products in this section reduce the Electrical

Contractor’s time and labor costs when compared to other competitive offerings.

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

62 PRODUCT ACCESSORIES

PRODUCT ACCESSORIES

RESIDENTIAL ACCESSORIES

AIR CONDITIONER WHIPS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

EPCO AC Whips and AC Whip Connectors are Made in the USA. Complies with the American Recovery and Reinvestment Act – Buy American Provision.

2

13 4

Note: AC Connectors are available in bulk quantities. Contact our Inside Sales Department (800.336.1976 or sales@engproducts.com) for more

specic information.

Catalog UPC Order Unit Unit Units/ TL Case Min MM ShipWt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

ACWNM1043-1RA 11202 AC Whip: 4-FT, 1/2", One (1) Straight and One (1) Right Angle EA 1 BRL 20 20 1 No 47

Connector, Three (3) 10 AWG Stranded - Red, Black, Green

ACWNM1063-1RA 11204 AC Whip: 6-FT, 1/2", One (1) Straight and One (1) Right Angle EA 1 BRL 20 20 1 No 49

Connector, Three (3) 10 AWG Stranded - Red, Black, Green

ACWNM843-1RA 11205 AC Whip: 4-FT, 3/4", One (1) Straight and One (1) Right Angle EA 1 BRL 20 20 1 No 49

Connector, Two (2) 8 AWG Stranded - Red, Black; One (1) 10 AWG

Stranded - Green

ACWNM863-1RA 11208 AC Whip: 6-FT, 3/4", One (1) Straight and One (1) Right Angle EA 1 BRL 10 10 1 No 36

Connector, Two (2) 8 AWG Stranded - Red, Black; One (1) 10 AWG

Stranded - Green

ACWNM843-1RA-1/2 11214 AC Whip: 4-FT, 1/2", One (1) Straight and One (1) Right Angle EA 1 BRL 20 20 1 No 49

Connector, Two (2) 8 AWG Stranded - Red, Black; One (1) 10 AWG

Stranded - Green

ACWNM863-1RA-1/2 11213 AC Whip: 6-FT, 1/2", One (1) Straight and One (1) Right Angle EA 1 BRL 20 20 1 No 50

Connector, Two (2) 8 AWG Stranded - Red, Black; One (1) 10 AWG

Stranded - Green

AIR CONDITIONER WHIPS

n

Meets the requirements of the 2011 National Electrical Code: Articles 310.10(C)(H(2)

and (4), Table 310.15(B)(2)(A), 356.10, 356.20, 440.6 and 440.31.

n

Labor and Time Savings! Cost-effective Non-Metallic AC Whips save the Contractor

time and money.

n

Reducing washers included.

n

Convenient packaging of ten (10) or twenty (20) AC Whips per Carton.

n

UL Listed. File Number: E87199.

Designed to save the Contractor installation time and labor, our Air Conditioner

Whips are typically used to connect the Central Air Conditioner Compressor to the

AC disconnect box. Air Conditioner Whips include one (1) Straight and one (1) 90°

Connector. Three (3) Conductors are included in 1/2" or 3/4" Non-Metallic Liquid Tight

Conduit using either 8 or 10 AWG THHN Conductors.

We will also build “custom” Air Conditioner Whips to your specifications in any length

using UL Listed components. Contact our Inside Sales Department (800.336.1976 or

sales@engproducts.com) for more specific information.

AC WHIP CONNECTOR REFERENCE GUIDE

Type: Straight, Screw-in

Material: Liquid Tight PVC

Specify Size:

1/2": P/N E00-045-000

3/4": P/N E00-043-000

Type: 90°, Screw-in

Material: Liquid Tight PVC

Specify Size:

1/2": P/N E00-044-000

3/4": P/N E00-046-000

Type: Straight, Screw-in

Material: Die Cast

Specify Size:

1/2": P/N E00-011-000

3/4": P/N E00-021-000

Type: 90°, Screw-in

Material: Die Cast

Specify Size:

1/2": P/N E00-012-000

3/4": P/N E00-022-000

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

63PRODUCT ACCESSORIES

PRODUCT ACCESSORIES

RESIDENTIAL ACCESSORIES

POWER / APPLIANCE CORDS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Flat Cord Strain Relief Connectors

15035 15035 Flat Cord Strain Relief Connector - 1/2": Accommodates 14/2 BG 12 BG 0 0 12 Yes 1

and 12/2 Romex Cable and our SPT 16/3 Flat Power/Appliance Cords

15040 15040 Flat Cord Strain Relief Connector - 3/4": Accommodates 14/3 BG 12 BG 0 0 12 Yes 1

and 10/2 Romex Cable and our SPT 16/3 Flat Power/Appliance Cords

Round Cord Strain Relief Connectors

15042 15042 Round Cord Strain Relief Connector - 1/2": BG 12 BG 0 0 12 Yes 1

Accommodates our SPT 16/3 Round Power/Appliance Cords

15044 15044 Round Cord Strain Relief Connector - 3/4": BG 12 BG 0 0 12 Yes 1

Accommodates our SPT 16/3 Round Power/Appliance Cords

FLAT AND ROUND CORD STRAIN RELIEF CONNECTORS

n

Compression type specifically designed for use with 14/2 or 12/2 AWG

Romex® cable.

n

Low profile design fits the smaller UF Cables as well as standard sizes.

POWER/APPLIANCE CORDS

n

UL Listed.

n Meets the requirements of the 2011 National Electrical Code: Articles 422.16(B)(1) and (2).

SPT Flat and SJT Round Power/Applliance Cords are used for typical applications such as

installation of garbage disposals, dishwashers or similar appliances. These Power/Appliance

Cords can also be used for repairs of appliances, power tools or other electrical equipment.

The cords are 16 AWG or 14 AWG 3 wire heavy-duty vinyl conductors. One end is pre-stripped

at the factory, the other end has a straight or right angle grounded male plug.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

SPT 16/3 Flat Cord

PCR3 10178 3-FT: Right Angle Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 8

PCR4 10180 4-FT: Right Angle Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 8

PCR6 10181 6-FT: Right Angle Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 12

PCR8 10182 8-FT: Right Angle Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 13

PCS3 10179 3-FT: Straight Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 8

PCS4 10183 4-FT: Straight Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 8

PCS6 10184 6-FT: Straight Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 12

PCS8 10185 8-FT: Straight Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 13

PCS12 10169 12-FT: Straight Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 22

SJT 16/3 Round Cord

PSS3 10186 3-FT: Straight Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 8

PSS4 10168 4-FT: Straight Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 8

PSS6 10187 6-FT: Straight Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 12

PSS8 10188 8-FT: Straight Plug, 13 AMP - Black EA 1 BX 25 25 25 Yes 13

SPT 16/3 Round Cord

RSS3 10219 3-FT: Straight Plug with Receptacle, 15 AMP - Black EA 1 BX 25 25 25 Yes 12

SPT 14/3 Flat Cord

10950 10950 3-FT: Straight Plug, 15 AMP - Beige EA 1 BX 25 25 25 Yes 9

10953 10953 6-FT: Straight Plug, 15 AMP - Beige EA 1 BX 25 25 25 Yes 17

10956 10956 9-FT: Straight Plug, 15 AMP - Beige EA 1 BX 25 25 25 Yes 25

Flat Cord Strain Relief

Connectors

Round Cord Strain Relief

Connectors

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

64 PRODUCT ACCESSORIES

PRODUCT ACCESSORIES

RESIDENTIAL ACCESSORIES

RANGE AND DRYER CORDS

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

10938 10938 Wall Plate Insulation Gasket BG 100 BG 0 0 100 Yes 2

WALL PLATE INSULATION GASKET

Energy saving gasket prevents heat and cold loss through outlets

and switches that are located on outside walls.

n

Easy to install. Only a screwdriver is required.

n

Flame retardant closed cell polyethylene insulating foam.

n

One-piece design fits toggle, duplex receptacle or Decora style wall plates.

n

Fits duplex receptacles and multi-gang boxes.

Note: Each gasket is perforated.

DRYER CORDS

n

Meets Canadian Standards Association (CSA) Approval.

n

Meets the requirements of the 2011 National Electrical Code: Articles 420.5, 422.16(B)(3)(4)

and 422.33(A) and (B).

n

Heavy-duty terminals ensure an excellent power quality connection.

n

Right angle plug for fit-to-wall.

n

Strain Relief protects Dryer Cord from damage.

RANGE CORDS

n

Meets Canadian Standards Association (CSA) Approval.

n

Meets the requirements of the 2011 National Electrical Code: Articles 420.5, 422.16(B)(3)(4)

and 422.33(A) and (B).

n

Heavy-duty terminals ensure an excellent power quality connection.

n

Right angle plug for fit-to-wall.

n

Strain Relief protects Range Cord from damage.

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

40000 40000 Range Cord: 4-FT, SRDT 6/2 and 8/1, 3 Wire, 50 AMP - Gray EA 1 BX 16 16 1 No 27

40001 40001 Range Cord: 6-FT, SRDT 6/2 and 8/1, 3 Wire, 50 AMP - Gray EA 1 BX 16 16 1 No 35

40010 40010 Range Cord: 4-FT, SRDT 6/2 and 8/2, 4 Wire, 50 AMP - Black EA 1 BX 12 12 1 No 33

40011 40011 Range Cord: 6-FT, SRDT 6/2 and 8/2, 4 Wire, 50 AMP - Black EA 1 BX 12 12 1 No 38

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

40020 40020 Dryer Cord: 4-FT, SRDT 10/3, 3 Wire, 30 AMP - Gray EA 1 BX 32 32 1 No 35

40021 40021 Dryer Cord: 6-FT, SRDT 10/3, 3 Wire, 30 AMP - Gray EA 1 BX 32 32 1 No 51

40030 40030 Dryer Cord: 4-FT, SRDT 10/4, 4 Wire, 30 AMP - Black EA 1 BX 16 16 1 No 27

40031 40031 Dryer Cord: 6-FT, SRDT 10/4, 4 Wire, 30 AMP - Black EA 1 BX 16 16 1 No 35

65

PRODUCT ACCESSORIES

Whether from plan and specification, design/build or negotiated, our Commercial Product Accessories represent

the highest level of product quality and value that solves the Electrical Contractors problems quickly and easily.

This product quality and value is realized in the form of increased productivity and expedited installation times

at a price that meets the Electrical Contractor’s budgetary requirements and application needs.

Be it a small retrofit project or a new “ground up” construction project, you’ll want the most dependable and

reliable electrical product accessories working for you. All of our products are manufactured with unmatched

workmanship and shipped on-time.

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

66 PRODUCT ACCESSORIES

PRODUCT ACCESSORIES

COMMERCIAL ACCESSORIES

DUCT SEAL COMPOUND

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

EPD1 10101 Duct Seal: 1 Lb. Slug LB 1 BX 50 50 1 No 50

EPD5 10102 Duct Seal: Package of Five (5) 1 Lb. Slugs LB 5 BX 10 10 5 Yes 50

EPD5B 10105 Duct Seal: 5 Lb. Brick LB 5 BX 10 10 5 No 50

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

SMH 10726 11 AWG Plated Fixture Hangers: Side Mount BX 100 BX 0 0 100 Yes 5

TMH 10725 10 AWG Plated Fixture Hangers: Top Mount BX 100 BX 0 0 100 Yes 7

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

TY16 10150 16 AWG Black Tie Wire: 350’ per Roll EA 1 BX 20 20 20 Yes 70

TY16G 10152 16 AWG Galvanized Tie Wire: 350’ per Roll EA 1 BX 20 20 20 Yes 70

TY18G 10151 18 AWG Galvanized Tie Wire: 30" Length EA 1 BX 1750 1750 1750 Yes 25

TY18G-50B

12000 18 AWG Galvanized Tie Wire: 30" Length, 50 per Bundle EA 1 BX 35 35 1 No 25

Tie Wire: 18 AWG Galvanized Straight Wire

Carbon: C1008 Soft Annealed

Yield: LB/FT = .0104 (104 feet per pound)

Size: .047" Diameter (plus/minus .001")

Tensile/Breaking Strength: 75 lb. max. PSI;

105-135 lbs.

ASTM: Zinc Coating; Meets A641 that

requires no minimum ounces of zinc per

square foot of surface area.

Federal Specification: QQ-W-461

Tie Wire: 16 AWG Black

and Galvanized Coiled Wire

Carbon: C1008 Soft Annealed

Yield: LB/FT = .0104 (104 feet per pound)

Size: .0625" Diameter (plus/minus .001")

Tensile/Breaking Strength: 45-60,000 PSI

ASTM: Zinc Coating; Meets A641 that requires

no minimum ounces of zinc per square foot of

surface area.

Federal Specification: QQ-W-461

EPCO Fixture Hangers are Made in the USA. Complies with the American Recovery and Reinvestment Act – Buy American Provision.

EPCO Duct Seal Compound is Made in the USA. Complies with the American Recovery and Reinvestment Act – Buy American Provision.

TIE WIRE

Supports a variety of uses on the job site including bundling, supporting and

hanging cable conduit and suspended fixtures. Available in 16 AWG Black Annealed

or Galvanized rolls. Also available in 18 AWG Galvanized 30" pre-cut lengths.

DUCT SEAL COMPOUND

Our Duct Seal Compound is used to seal around junction boxes, flashings, service

mast and cable entries. Duct Seal Compound is available in individual 1 lb. bricks,

five (5) 1 lb. bricks in one (1) package, or a 5 lb. brick. Each Duct Seal package is

individually wrapped in release paper to simplify handling and repackaging.

n

Asbestos-free compound

n

Odorless, non-sticky.

n

Temperature tolerance: -40˚C (-40˚F)

n

Can be painted immediately.

to 82˚C (180˚F).

n

Excellent adhesive properties for use on wood, glass, aluminum and steel.

n

Meets the requirements of the 2011 National Electrical Code: Article 230.8.

FIXTURE HANGERS

These labor saving Fixture Hangers are available in Side Mount or Top Mount styles

and can be used with our Chain and S-Hook products. Top Mount Hangers are used

with mounting holes located on top of a troffer type lighting fixture. Side Mount

Hangers are used with mounting holes located on the side of a troffer type lighting

fixture. Both Fixture Hanger styles are plated for durability and precisely bent to

simplify installation and ensure a secure fit.

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

67PRODUCT ACCESSORIES

PRODUCT ACCESSORIES

COMMERCIAL ACCESSORIES

SINGLE AND DOUBLE LOOP CHAIN

UNITS OF MEASURE KEY Order Unit: The Unit to be ordered; Unit Qty: Number of pieces in each Unit; Unit Pkg: Unit Packages contained in the case - Packaging types - BG (Bag), BRL (Barrel), BX (Box), BN (Bulk),

PKG (Package), EA (Each), RL (Roll), LB (Pound), C (Hundred), M (Thousand); Units/Case: Unit packages contained in the Case; TL Case Qty: The total number of items in each Master Case; Min Order Qty: The smallest

Unit that can be ordered; MM Req: Must order multiples of the Unit in the stated quantities; Ship Wt (Lbs): Total weight of the units per Carton

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

Double Loop Chain

DL1B/100B 10207 12 AWG Bright Double Loop Chain: 100-FT per Carton FT 100 BX 5 500 100 Yes 50

DL2B/100B 10209 13 AWG Bright Double Loop Chain: 100-FT per Carton FT 100 BX 5 500 100 Yes 40

DL3B/100B 10211 14 AWG Bright Double Loop Chain: 100-FT per Carton FT 100 BX 5 500 100 Yes 30

Single Loop Jack Chain

JC10B/100B 10201 10 AWG

Bright Jack Chain: 100-FT per Carton

FT 100 BX 5 500 100 Yes 80

JC12B/100 11703 12 AWG Bright Jack Chain: 100-FT Spool FT 100 BX 5 500 100 Yes 45

JC12B/100B 10203 12 AWG

Bright Jack Chain: 100-FT per Carton FT 100 BX 5 500 100 Yes 45

JC14B/100B 10205 14 AWG

Bright Jack Chain: 100-FT per Carton FT 100 BX 5 500 100 Yes 30

Catalog UPC Order Unit Unit Units/ TL Case Min MM Ship Wt

Number Number Description Unit Qty Pkg Case Qty Order Qty Req (Lbs)

SH10 10251 10 AWG Plated S-Hooks: 1.25" Length BG 100 BG 10 1000 100 Yes 11

SH12 10252 12 AWG Plated S-Hooks: 1.125" Length BG 100 BG 10 1000 100 Yes 10

Trade Wire Wire Diameter Length Per 100 Weight Per 100 Working Load Break Test

Size Gauge Inches Link Inches Feet Pounds Limit Pounds Load Pounds

Double Loop Chain

3 14 .080 110 6 90 LBS/FT 360 LBS/FT

2 13 .091 133 8 115 LBS/FT 460 LBS/FT

1 12 .105 171 10 155 LBS/FT 620 LBS/FT

Single Loop Jack Chain

14 14 .080 63 5.0 16 LBS/FT 65 LBS/FT

12 13 .105 75 8.5 29 LBS/FT 115 LBS/FT

10 12 .135 95 14.7 43 LBS/FT 170 LBS/FT

Trade Wire Wire Diameter Working Load Minimum

Size Gauge Inches Length Limit Pounds Strength

SH10 10 .135 1.25" 48 LBS/FT 190 LBS/FT

SH12 12 .105 1.125" 32 LBS/FT 97 LBS/FT

SINGLE AND DOUBLE LOOP CHAIN

Double Loop Chain and Single Loop Jack

Chain is used to support suspended light

fixtures and is often required by code

in many cities. We package the chain in

convenient 50 and 100-foot boxes.

SHOOKS

S-Hooks are used with Jack Chain and Double Loop Chain

to support suspended light fixtures. All S-Hooks are plated

for lasting durability. Two (2) sizes are available ranging from

1.125" length 12 AWG wire to 1.25" length 10 AWG wire.

EPCO Loop Chain is Made in the USA. Complies with the American Recovery and Reinvestment Act – Buy American Provision.

EPCO S-Hooks are Made in the USA. Complies with the American Recovery and Reinvestment Act – Buy American Provision.

Single Loop Jack Chain Double Loop Jack Chain

S-HOOK LOAD LIMITS

CHAIN LOAD LIMITS

Engineered Products Co.

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

68

SALES REPRESENTATIVES

ALABAMA

Kam Sales, Inc.

1755 MacArthur Boulevard NW

Atlanta, GA 30318

P 404.351.0814 • F 404.351.7665

E charlie@kamsalesinc.com

ALASKA

Electrical Sales Associates, Inc.

1131 Andover Park West

Seattle, WA 98188

P 206.574.0092 • F 206.575.0674

E fred@repesa.com

ARIZONA

Abbott Associates

4101 West Van Buren Street, Suites 5 and 6

Phoenix, AZ 85009

P 602.484.7777 • F 602.484.0301

E david@abbottphx.com

ARKANSAS

Commodore Sales, Inc.

93 Aberdeen Drive

Little Rock, AR 72223

P 501.350.4348 • F 501.868.1249

E mmccarthy@commsalesinc.com

CALIFORNIA

ELR Sales

(Northern California)

2790 Tivoli Court

Livermore, CA 94550

P 925.292.0021 • F 925.264.0737

E erich@elrsales.com or jim@elrsales.com

Stellar Sales, Inc.

(Southern California)

14300 Alondra Boulevard

La Mirada, CA 90638

P 714.690.6400 • F 714.690.6410

E dan@stellarsalesinc.com

COLORADO

Professional Electrical Solutions

2750 South Shoshone Street, Suite 305

Englewood, CO 80110

P 303.650.5162 • F 303.650.5165

E rhunt@profelecsolutions.com

CONNECTICUT

C. C. Pierce Company, Inc.

104 Tremont Street, Suite 3

Duxbury, MA 02332

P 781.934.8300 • F 781.934.7755

E brooks@ccpiercecompany.com

DELAWARE

Engineered Products Company

5401 Smetana Drive

Minnetonka, MN 55343

P 800.336.1976 • F 800.336.2801

E sales@engproducts.com

DISTRICT of COLUMBIA

R. C. Colerick, Inc.

1244 Ritchie Highway, Suite 13

Arnold, MD 21012

P 410.421.9511 • F 410.421.9514

E craig@colerick.com

FLORIDA

Florida Electrical Sales

8100 Broadway Avenue, Suite E

Tampa, FL 33619

P 800.277.0318 • F 813.881.9624

E fesrbado@aol.com

Kam Sales, Inc.

(Florida Panhandle Only)

1755 MacArthur Boulevard NW

Atlanta, GA 30318

P 404.351.0814 • F 404.351.7665

E charlie@kamsalesinc.com

GEORGIA

Kam Sales, Inc.

1755 MacArthur Boulevard NW

Atlanta, GA 30318

P 404.351.0814 • F 404.351.7665

E charlie@kamsalesinc.com

HAWAII

Engineered Products Company

5401 Smetana Drive

Minnetonka, MN 55343

P 800.336.1976 • F 800.336.2801

E sales@engproducts.com

IDAHO

Electrical Sales Associates, Inc.

(Northern Idaho)

1131 Andover Park West

Seattle, WA 98188

P 206.574.0092 • F 206.575.0674

E fred@repesa.com

Interwest Electrical Sales

(Southern Idaho)

536 West 8360 South

Sandy, UT 84070

P 801.233.8800 • F 801.233.8801

E ies@interwestut.com

ILLINOIS

Becker Sales Company, Inc.

1850 Brummel Drive

Elk Grove Village, IL 60007

P 847.981.1776 • F 847.981.1977

E gary@beckersalesco.com

INDIANA

Wiltrout Sales, Inc.

(Central Indiana)

9296 Waldemar Road

Indianapolis, IN 46268

P 317.704.8800 • F 317.704.8810

E tmwiltrout@wiltroutsales.com

A. L. Pickens Company, Inc.

(Southern Indiana)

2500 Data Drive, Bluegrass Industrial Park

Louisville, KY 40299

P 502.491.4215 • F 502.491.3040

E sebooker@alpickens.com

IOWA

Perry & Associates

7559 Main Street, Suite 302

Omaha, NE 68127

P 402.596.1062 • F 402.596.1319

E don@pa.omhcoxmail.com

KANSAS

Schooler & Associates

PO Box 14012

Kansas City, MO 64101

P 816.842.0733 • F 816.842.0737

E schooler01@aol.com

KENTUCKY

Aero Sales

(Northern Kentucky)

29313 Clemens Road, #2-J

Westlake, OH 44145

P 440.250.9940 • F 440.250.9941

E jweissinger@aerosalesinc.com

A. L. Pickens Company, Inc.

(Southern Kentucky)

2500 Data Drive, Bluegrass Industrial Park

Louisville, KY 40299

P 502.491.4215 • F 502.491.3040

E sebooker@alpickens.com

LOUISIANA

SERG, Inc.

12522 Stanga Road

Covington, LA 70433

P 985.892.4343 • F 985.892.4951

E serginc@bellsouth.net

MAINE

C. C. Pierce Company, Inc.

104 Tremont Street, Suite 3

Duxbury, MA 02332

P 781.934.8300 • F 781.934.7755

E brooks@ccpiercecompany.com

MARYLAND

R. C. Colerick, Inc.

1244 Ritchie Highway, Suite 13

Arnold, MD 21012

P 410.421.9511 • F 410.421.9514

E craig@colerick.com

MASSACHUSETTS

C. C. Pierce Company, Inc.

104 Tremont Street, Suite 3

Duxbury, MA 02332

P 781.934.8300 • F 781.934.7755

E brooks@ccpiercecompany.com

MICHIGAN

Premier/Spectrum Sales, Inc.

720 Madison Street, Suite 1

Jackson, MI 49202

P 517.783.6020 • F 517.783.6040

E pssg@ameritech.net

Lakeshore Electrical Sales, Inc.

(Upper Peninsula Only)

6000 West Executive Drive, Suite A

Mequon, WI 53092

P 262.478.0680 • F 262.478.0595

E john.walter@lakeshoreelectrical.com

MINNESOTA

Lee Noonan Company

2230 County Road H2

Moundsview, MN 55112

P 763.560.1228 • F 763.560.3282

E bob@leenoonan.com

MISSISSIPPI

SERG, Inc.

322 2nd Street South

Columbus, MS 39701

P 662.574.3519 • F 662.327.8495

E jefflcaldwell@bellsouth.net

MISSOURI

Schooler & Associates

(Western Missouri)

PO Box 14012

Kansas City, MO 64101

P 816.842.0733 • F 816.842.0737

E schooler01@aol.com

Hendrix Company, Inc.

(Eastern Missouri)

11811 Westline Industrial Drive

St. Louis, MO 63146

P 314.994.0034 • F 314.994.1373

E ustrut@sbcglobal.net

MONTANA

Northern Rockies Agency, Inc.

246 Timberline Drive

Bozeman, MT 59718

P 406.587.0513 • F 406.587.3677

E nra@nrarep.com

NEBRASKA

Perry & Associates

7559 Main Street, Suite 302

Omaha, NE 68127

P 402.596.1062 • F 402.596.1319

E don@pa.omhcoxmail.com

NEVADA

Abbott Associates

4101 West Van Buren Street, Suites 5 and 6

Phoenix, AZ 85009

P 602.484.7777 • F 602.484.0301

E david@abbottphx.com

NEW HAMPSHIRE

C. C. Pierce Company, Inc.

104 Tremont Street, Suite 3

Duxbury, MA 02332

P 781.934.8300 • F 781.934.7755

E brooks@ccpiercecompany.com

NEW JERSEY

Tri-Tech Sales Associates, Inc.

(Northern New Jersey)

66 A Southern Boulevard

Nesconset, NY 11767

P 631.642.0087 • F 631.642.1544

E rtuniewicz@tri-techsales.com

Engineered Products Company

(Southern New Jersey)

5401 Smetana Drive

Minnetonka, MN 55343

P 800.336.1976 • F 800.336.2801

E sales@engproducts.com

NEW MEXICO

FP Sales, LLC

3636 Menaul NE, Suite 200

Albuquerque, NM 87110

P 505.884.8338 • F 505.884.5069

E john.fpsllc@comcast.net

NEW YORK

Tri-Tech Sales Associates, Inc.

(Metro New York; Five Burrows and Long Island)

66 A Southern Boulevard

Nesconset, NY 11767

P 631.642.0087 • F 631.642.1544

E rtuniewicz@tri-techsales.com

Robert H. Schaub & Associates, Inc.

(Upstate New York)

114 Kreischer Road, Stop 4

North Syracuse, NY 13212

P 315.452.0302 • F 315.452.0547

E mcgrew278@aol.com

NORTH CAROLINA

Emery Electrical Sales, Inc.

415 Minuet Lane, Suite C

Charlotte, NC 28217

P 704.525.9153 • F 704.525.3471

E rick@emeryelectrical.com

NORTH DAKOTA

Lee Noonan Company

2230 County Road H2

Moundsview, MN 55112

P 763.560.1228 • F 763.560.3282

E bob@leenoonan.com

OHIO

Aero Sales

29313 Clemens Road, #2-J

Westlake, OH 44145

P 440.250.9940 • F 440.250.9941

E jweissinger@aerosalesinc.com

OKLAHOMA

Triple C - Conrad Sales

1212 West Main

Oklahoma City, OK 73106

P 405.235.5456 • F 405.235.4180

E conrads@theshop.net

OREGON

Electrical Pacific Agencies, LLC

4307 NW St. Helens Road

Portland, OR 97210

P 503.248.0042 • F 503.248.0924

E bplasker@electri-pac.com

PENNSYLVANIA

Engineered Products Company

5401 Smetana Drive

Minnetonka, MN 55343

P 800.336.1976 • F 800.336.2801

E sales@engproducts.com

RHODE ISLAND

C. C. Pierce Company, Inc.

104 Tremont Street, Suite 3

Duxbury, MA 02332

P 781.934.8300 • F 781.934.7755

E brooks@ccpiercecompany.com

SOUTH CAROLINA

Emery Electrical Sales, Inc.

415 Minuet Lane, Suite C

Charlotte, NC 28217

P 704.525.9153 • F 704.525.3471

E rick@emeryelectrical.com

SOUTH DAKOTA

Lee Noonan Company

2230 County Road H2

Moundsview, MN 55112

P 763.560.1228 • F 763.560.3282

E bob@leenoonan.com

TENNESSEE

Commodore Sales, Inc.

(Western Tennessee)

93 Aberdeen Drive

Little Rock, AR 72223

P 501.350.4348 • F 501.868.1249

E mmccarthy@commsalesinc.com

Associated Products Company, Inc.

(Eastern Tennessee -

East of the Tennessee River )

147 Neil Street

Memphis, TN 38112

P 901.324.3725 • F 901.323.3919

E jrsteel@bellsouth.net

TEXAS

DSI Southwest

(Northern Texas)

6333 Denton Drive, Suite 900

Dallas, TX 75235

P 214.630.0200 • F 214.751.3649

E dtipton@dsisw.com

FP Sales, LLC

(Northwest Texas)

3636 Menaul NE, Suite 200

Albuquerque, NM 87110

P 505.884.8338 • F 505.884.5069

E john.fpsllc@comcast.net

Enhanced Electrical Sales, Inc.

(Southern Texas)

4650 South Pinemont, Suite 125

Houston, TX 77041

P 713.895.0300 • F 713.895.7204

E thardey@eestexas.com

UTAH

Interwest Electrical Sales

536 West 8360 South

Sandy, UT 84070

P 801.233.8800 • F 801.233.8801

E ies@interwestut.com

VERMONT

C. C. Pierce Company, Inc.

104 Tremont Street, Suite 3

Duxbury, MA 02332

P 781.934.8300 • F 781.934.7755

E brooks@ccpiercecompany.com

VIRGINIA

W. E. Sullivan

(Northern Virgina)

3751 B Westerre Parkway

Richmond, VA 23233

P 804.273.0905 • F 804.273.0907

E wesullivanco@netzero.com

R. C. Colerick, Inc.

(Southern Virgina)

1244 Ritchie Highway, Suite 13

Arnold, MD 21012

P 410.421.9511 • F 410.421.9514

E craig@colerick.com

WASHINGTON

Electrical Sales Associates, Inc.

1131 Andover Park West

Seattle, WA 98188

P 206.574.0092 • F 206.575.0674

E fred@repesa.com

WEST VIRGINIA

Engineered Products Company

5401 Smetana Drive

Minnetonka, MN 55343

P 800.336.1976 • F 800.336.2801

E sales@engproducts.com

WISCONSIN

Lakeshore Electrical Sales, Inc.

(Eastern Wisconsin)

6000 West Executive Drive, Suite A

Mequon, WI 53092

P 262.478.0680 • F 262.478.0595

E john.walter@lakeshoreelectrical.com

Lee Noonan Company

(Western Wisconsin)

2230 County Road H2

Moundsview, MN 55112

P 763.560.1228 • F 763.560.3282

E bob@leenoonan.com

WYOMING

Professional Electrical Solutions

(Southeast Wyoming)

2750 South Shoshone Street, Suite 305

Englewood, CO 80110

P 303.650.5162 • F 303.650.5165

E rhunt@profelecsolutions.com

Northern Rockies Agency, Inc.

(Northern Wyoming)

246 Timberline Drive

Bozeman, MT 59718

P 406.587.0513 • F 406.587.3677

E jim@nrarep.com

Interwest Electrical Sales

(Western Wyoming)

536 West 8360 South

Sandy, UT 84070

P 801.233.8800 • F 801.233.8801

E ies@interwestut.com

Engineered Products Company

| P

800.336.1976

| F

800.336.2801

| www.engproducts.com

Specications subject to change without prior notice.

GENERAL TERMS & CONDITIONS

CUSTOMER AND TECHNICAL SUPPORT

Business Hours: 8:00 AM to 5:00 PM Central Time,

Monday through Friday.

n Call toll free: 800-336-1976 or Fax: 800-336-2801

n E-mail: sales@engproducts.com

n Mail: 5401 Smetana Drive, Minnetonka, Minnesota 55343

n Website: engproducts.com

MINIMUM ORDER

The minimum merchandise order is $50.00 for existing

Customers, excluding any freight charges. Any merchandise

order for less than $50.00 will be billed at this minimum

amount, plus applicable freight charges.

Most orders placed before 12:00 PM Eastern Time for any of

our Standard Catalog Products ship the same business day.

Most orders placed after 12:00 PM Eastern Time will ship the

next business day.

NEW CUSTOMERS

Engineered Products Company (EPCO) requires an initial

purchase of $1,000.00. A “minimum” of 5 line items must

also be included on this sales order from any or all of the

following product categories:

n Lighting

n

Grounding Bonding

n Splicing Kits and Heat Shrink Tubing

n Residential Accessories

n Commercial Accessories

Note: To maintain open account with Engineered Products

Company, we require all customers must make annual

purchases of $1,500 or more.

FREIGHT TERMS

F.O.B. Shipping Point. Full freight is allowed and will be

prepaid by Engineered Products Company on any single

order valued at a minimum of $1,000.00. The freight

shipment will be via OUR ROUTING to the Distributor’s

Warehouse on sales orders for Standard Catalog Products

exceeding $1,000.00 net billing.

For Product shipments to Hawaii and Alaska, freight will be

prepaid and allowed based on the above qualifications only

to the United States West Coast point of embarkation. For

shipments to Puerto Rico and the Caribbean, freight will be

prepaid and allowed based on the above qualifications to

Miami, Florida.

For all freight shipments not directed to the Distributor’s

warehouse, EPCO will add a flat rate surcharge of $95.00

for delivery to the following locations:

n Construction sites, fairs and or carnivals, military bases,

mine sites, prisons, etc.

n Commercial establishments, churches, schools, or other

sites not open to the “walk in” public during normal

business hours

n Limited Access for Pickup or Delivery Service

The following surcharges are also applicable for

“arrival notification” services:

n $38.00 to Call For Appointment

n $38.00 to Call Consignee Before Delivery

n $88.00 for Inside Delivery or Pickup

n $86.00 for Lift Gate Service

n $91.00 for Residential Delivery or Pickup

The above surcharges are applicable to freight shipments

less than 500 lbs. Freight shipments over 500 lbs. will

cost more!

PRODUCT WARRANTY

EPCO warrants that the products described herein, will be

furnished free from defects in material and workmanship

for 1 year. Any exceptions will be indicated on the product

or packaging.

EPCO’s sole obligation for any breach of warranty under

the terms herein shall be, at our option, to repair or provide

replacement for the Product to which such warranty is

breached, or to return all payments made with respect

to such Product. Any Product(s) which are deemed to be

defective must be specified by the Purchaser in a written

notice to Engineered Products Company’s Warranty

Department within 1 year after receipt of such goods.

Under no circumstances will Engineered Products

Company be liable for loss of profits or incidental, indirect,

consequential or special damages of any kind beyond the

replacement cost of the defective merchandise.

Engineered Products Company shall not be liable for any

losses arising from governmental action, an act of God, or

the result of war, riot, strikes, civil commotion, sovereign

conduct, or the act or conduct of any person or persons not

party to or associated with Engineered Products Company.

GUARANTEED SALES POLICY

EPCO guarantees the sale of its Standard Catalog Products

from authorized distributors to their customers. If an

authorized distributor is not satisfied with their sales

movement of our Standard Catalog Product(s), the

distributor may request an Return Materials Authorization

(RMA) Form from either their Engineered Products

Company’s Sales Representative or by contacting our

Inside Sales Department.

If the Product(s) is in the “original” unopened package(s)

and is less than 12 months old, upon receipt, 100% credit

will be issued. Freight must be prepaid by the customer.

If the Product(s) is older than 1 year, but less than 2 years

old, 100% credit will be issued with a corresponding order

of equal or greater value. If the Product(s) being returned

is older than 2 years old, 100% credit will be issued with a

corresponding order of at least two times the value.

www.engproducts.com

5401

SMETANA DRIVE | MINNETONKA, MN

55343

P

800.336.1976

| F

800.336.2801

Distributed By:

Bracket, ProSeries, Octi-Juntion Box, Landscape LightPost and SplicePost, TIGER 400 HID, TIGERcub 175 HID, SPIDERBOX, and CordLights

are either trademarks or registered trademarks of Engineered Products Company in the United States and/or in other countries. All other

trademarks are the property of their respective holders.

E02-001-000 I1 (01/13 - AK)

Product Detail Manual

1751-Attachment 1751-Attachment 1751-Attachment 780321 Batch5 unilog cesco-content

Navigation menu

Versions of this User Manual:

Views

Navigation
