2010 V3.1 Prices in effect August 1st 2010 till Nov. 1st 2010.
IMAGE DESCRIPTION List
BOX CAMERAS (3 year warranty)
C550 $190.00
C6DN $290.00
C550DN $286.00
C6WD $360.00
INDOOR MINI DOME CAMERAS (3 year warranty)
D38B $78.00
D6B $132.00
INDOOR VARIFOCAL DOME CAMERAS (3 year warranty)
D6V $240.00
D6VDN $326.00
D55V49DN $326.00
D55V49IR $270.00
D6VWD $426.00
VANDAL / WEATHER PROOF DOME CAMERAS (3 year warranty)
VD6V $298.00
Luxon PART #
High Res Color Camera (550TVL)
1/3" SONY Super HAD CCD, 550TVL, DC/Video Iris,
0.3 Lux Color, AWB, AGC On/Off, BLC On/Off, Dual Voltage
Lens not included
High Res Color Camera (600TVL)
1/3" SONY Super HAD CCD, 600TVL, DC/Video Iris,
0.01 Lux Color, OSD, ICR, TDN, SBLC, Dual Voltage
Lens not included
Low Light Day/Night Camera (ICR) (550TVL)
(ICR, DSS, SDNR, D/N)
1/3" SONY Super HAD CCD, 550TVL
Color (0.3 Lux), B/W (0.001 Lux, DSS On)
B/W (0.0000 Lux, IR LED On)
(Digital Zoom, D/N, AWB, AGC, Flickerless with On/Off)
D&N(ICR), BLC On/Off, DSS, SDNR, DC/Video Iris, Dual Voltage
This camera can pick up an external IR light source !
Lens not included
Color Box Camera (560TVL, WDR, OSD, DSS)
1/3" SONY Double Scan CCD, 560TVL, WDR, C/CS Mount, , Back Focus Control Color/BW, AWB,
AGC (Auto), BLC(Zone Selectable), Flickerless On/Off, Motion Detection, DSS On/Off, 16x Digital
Zoom, D&N(ICR), 0.0003Lux, Dual Voltage
This camera can pick up an external IR light source !
Lens not included
Fixed Dome Camera (380 TVL)
1/3" SONY CCD, 380 TVL, 0.1 lx, 3.8 mm lens
Auto white balance, AGC On/off, BLC On/off, 85mm dome size, DC12V
Fixed Dome Camera (600TVL)
1/3" SONY CCD, 600 TVL, 0.1 lx, 3.8 mm lens
AGC, BLC, Flickerless On/off, 85mm dome size, DC12V
Vari-Focal Dome Camera with Day/Night (600/650 TVL)
1/3" SONY Super HAD CCD, (600TVL COLOR), (650TVL B/W), 2.8-10mm Lens
600 TVL Color (0.1Lux), 650 TVL B/W (0.03Lux)
(OSD, SBLC, SDNR, D/N, Privacy & Motion Zones), Service Video Out
Dome size: 100mm, Dual Voltage
Vari-Focal Dome Camera with Day/Night (600/650 TVL)
1/3" SONY Super HAD CCD, (600TVL COLOR), (650TVL B/W), 2.8-10mm Lens
600 TVL Color (0.1Lux), 650 TVL B/W (0.005Lux)
(OSD, SBLC, SDNR, D/N, Privacy & Motion Zones), Service Video Out
Dome size: 100mm, Dual Voltage
Day/Night Vari-Focal Dome with ICR (550TVL)
1/3" SONY Super HAD CCD, 2.9-10mm Vari-focal Lens
Color (0.3 Lux), B/W (0.001 Lux, DSS On)
B/W (0.0000 Lux, with IR LED On)
Digital Slow Shutter, SDNR, Day/Night
AGC, BLC, & Flickerless On/Off, AWB
Service Video Out, Dome size: 100mm, Dual Voltage
This camera can pick up an external IR light source !
IR Day/Night Vari-Focal Dome (530TVL)
1/3" SONY Super HAD CCD, 3.8-9.5mm Vari-focal Lens
Color (0.3 Lux), B/W (0.0000 Lux, IR LED On)
Digital Slow Shutter, Day/Night, AWB
Distance at 0.000 Lux: (75 FT w/IR LED's)
DSS, Digital Zoom, D/N, AGC, BLC, & Flickerless On/Off
Service Video Out, Dome size: 100mm, Dual Voltage
(Wide Dynamic Day/Night Dome (580TVL)
(WDR, OSD, DSS, SDNR, D/N, ICR)
1/3" SONY Double Scan CCD, 580 TVL,, 2.8-10.5mm Lens
Color (0.1 Lux), Color (0.001 Lux, DSS On), B/W (0.0002 Lux, DSS On)
Wide Dynamic, Digital Slow Shutter, SDNR, Day/Night ICR
WDR, AGC, BLC, & Flickerless On/Off, On Screen Display
RS485 Connection, Service Video Out, Dome size: 100mm, Dual Voltage
This camera can pick up an external IR light source !
Vari-Focal Vandal Dome Camera with Day/Night (600/650 TVL)
1/3" SONY Super HAD CCD, (600TVL COLOR), (650TVL B/W), 2.8-10mm Lens
600 TVL Color (0.1Lux), 650 TVL B/W (0.03Lux)
(OSD, SBLC, SDNR, D/N, Privacy & Motion Zones), Service Video Out
Weather Proof (IP66), Surface/Flush Mount, Dome size: 100mm, Dual Voltage
VD6VDN $380.00
VD55V49DN $380.00
VD55V49IR $344.00
VD6VWD $514.00
IR BULLET CAMERAS (3 year warranty on camera)
BIR380 $126.00
BIR550 $174.00
BIR55D $214.00
BIR55V49 $288.00
220X ZOOM CAMERAS (2 year warranty)
CDZ220DN $390.00
VDDZ220DN $470.00
COVERT CAMERAS (1 year warranty)
CVTSMOKE $130.00
CVTSMOKE1 $220.00
CVTPIR420 $190.00
CVTC540 $300.00
CVTFIRE420 $300.00
Vari-Focal Vandal Dome Camera with Day/Night (600/650 TVL)
1/3" SONY Super HAD CCD, (600TVL COLOR), (650TVL B/W), 2.8-10mm Lens
600 TVL Color (0.1Lux), 650 TVL B/W (0.005Lux)
(OSD, SBLC, SDNR, D/N, Privacy & Motion Zones), Service Video Out
Weather Proof (IP66), Surface/Flush Mount, Dome size: 100mm, Dual Voltage
Day/Night Vandal/Weather Dome with ICR (550TVL)
1/3" SONY Super HAD CCD, 2.9-10mm Vari-focal Lens
Color (0.3 Lux), B/W (0.008 Lux, DSS On)
B/W (0.0000 Lux, IR LED On)
Digital Slow Shutter, SDNR, Day/Night
AGC, BLC, & Flickerless On/Off, AWB
Service Video Out, Dome size: 100mm, Dual Voltage, Weather Proof (IP66)
This camera can pick up an external IR light source !
IR Day/Night Vari-Focal Dome (530TVL)
1/3" SONY Super HAD CCD, 3.8-9.5mm Vari-focal Lens
Color (0.3 Lux), B/W (0.0000 Lux, IR LED On)
Digital Slow Shutter, Day/Night, AWB
Distance at 0.000 Lux: (75 FT w/IR LED's)
DSS, Digital Zoom, D/N, AGC, BLC, & Flickerless On/Off, Weather Proof (IP66),
Service Video Out, Dome size: 100mm, Dual Voltage
Wide Dynamic Day/Night Dome (580TVL)
(WDR, OSD, DSS, SDNR, D/N, ICR)
1/3" SONY Double Scan CCD, 580 TVL,, 2.8-10.5mm Lens
Color (0.1 Lux), Color (0.001 Lux, DSS On), B/W (0.0003 Lux, DSS On)
Wide Dynamic, Digital Slow Shutter, SDNR, Day/Night ICR
WDR, AGC, BLC, & Flickerless On/Off, On Screen Display, Weather Proof (IP66)
RS485 Connection, Service Video Out, Dome size: 100mm, Dual Voltage
This camera can pick up an external IR light source !
Bullet IR Camera (fixed lens) (380 TVL)
1/3" SONY Super HAD CCD, 380 TVL, 4.3mm Fixed Lens
12 IR LED's, 1 CDS, Visibility Range: 45 FT
Weather Proof (IP65), Camera Diameter: 50mm, DC12V
Bullet IR Camera (fixed lens) (550 TVL)
1/3" SONY Super HAD CCD, 550 TVL, 4.3mm Fixed Lens
12 IR LED's, 1 CDS, Visibility Range: 49 FT
Camera Diameter: 50mm, Weather Proof (IP65), DC12V
Bullet IR Camera (fixed lens) (550 TVL)
1/3" SONY Super HAD CCD, 550 TVL, 6mm Fixed Lens
34 IR LED's, 1 CDS, Visibility Range: 15 Degree at 110 FT
Camera Diameter: 65mm, Weather Proof (IP65), DC12V
Varifocal Bullet IR Camera (550 TVL)
1/3" SONY Super HAD CCD, 550 TVL, 3.8-9.5mm Lens
18 IR LED's, 1 CDS, Visibility Range: 15 Degree at 60 FT
Camera Diameter: 65mm, Weather Proof (IP65), DC12V
220x Zoom Day/Night Camera (With Digital Slow Shutter)
1/4" SONY Super HAD CCD, 480 TVL
Day&Night (0.001 lux B/W with DSS on)
On Screen Display, Digital Slow Shutter
22x Optical Power Zoom (Digital 10x)
Video Transmission Distance Adjustable
RS-485 & PTZ Control Interface, Dual Voltage
220x Zoom Day/Night Vandal Dome (With DSS) (480 TVL)
1/4" SONY Super HAD CCD, 480 TVL, Vandal Proof
Day&Night (0.001 lux B/W with DSS on), OSD
22x Zoom (Digital 10x), Weather Proof (IP65)
RS-485 Interface, Service Video Out, 3-Axis Construction, Dual Voltage
Covert Camera (Smoke Detector Type, 380TVL)
1/3" SONY Super HAD CCD, 380TVL, 3.8mm Fixed Lens, AWB, AGC, 12VDC, 0.3Lux
Covert Camera (Smoke Detector Type, 530TVL)
1/3" SONY Super HAD CCD, 530TVL, 3.8mm Fixed Lens, AWB, AGC, 12VDC, 0.3Lux
Covert PIR Camera (420TVL)
1/3" SONY CCD, 420TVL, 3.7mm Fixed Pinhole Lens, 0.8Lux
12VDC 150mA
Covert Ceiling Camera (540TVL)
1/3" SONY High Res CCD, 540TVL, 2.5mm Fixed Lens, Slow Shutter 32x, SDNR,
12VDC 150mA, 0.001Lux
Covert Sprinkler Camera (420TVL)
1/3" SONY CCD, 420TVL, 3.7mm Fixed Pinhole Lens, 0.1Lux
12VDC 150mA
CVTCLOCK420 $398.00
VALUE LINE CAMERAS (1 year warranty)
VL2BIR420 $80.00
VL3BIR420 $114.00
VL5BIR420 $130.00
VL4BIR420 $184.00
VL1B420 $90.00
VL2VDTIR420 $80.00
VLVDTIR420V $134.00
550/680TVL VANDAL/WEATHER RESISTANT PTZ'S & ACCESSORIES (2 year warranty)
Z5532DNODW $1,660.00
Z5532DNODC $1,660.00
Z5544DNODW $2,300.00
Z5544DNODC $2,300.00
MPTZW $1,260.00
MPTZC $1,260.00
Covert Clock Camera (420TVL)
1/3" SONY CCD, 420TVL, 3.7mm Fixed Pinhole Lens, 0.1Lux
12VDC 150mA
Bullet IR Camera (fixed lens) (420 TVL)
1/4" SONY Super HAD CCD, 420 TVL, 4.3mm Fixed Lens
24 IR LED's, 1 CDS, Visibility Range: 45 FT
Weather Proof (IP66), DC12V
Bullet IR Camera (fixed lens) (420 TVL)
1/4" SONY Super HAD CCD, 420 TVL, 4.3mm Fixed Lens
24 IR LED's, 1 CDS, Visibility Range: 45 FT
Cable inside bracket, Weather Proof (IP66), DC12V
Varifocal IR Camera (4-9mm lens) (420 TVL)
1/4" SONY Super HAD CCD, 420 TVL, 4-9mm Lens
36 IR LED's, 1 CDS, Visibility Range: 90 FT
Cable inside bracket, Weather Proof (IP66), DC12V
Varifocal IR Camera (9-22mm lens) (420 TVL)
1/4" SONY Super HAD CCD, 420 TVL, 9-22mm Lens
36 Super IR LED's, 1 CDS, Visibility Range: 150 FT
Cable inside bracket, Weather Proof (IP66), DC12V
Bullet Camera (fixed lens) (420 TVL)
1/4" Sharp CCD, 420 TVL, 4.3mm Fixed Lens
Weather Proof (IP66), DC12V
Vandal IR Dome Camera (3.6mm fixed lens) (420 TVL)
1/3" SONY Super HAD CCD, 420 TVL, 3.6mm Fixed Lens
24 IR LED's, 1 CDS, Visibility Range: 45 FT
Weather Proof (IP66), DC12V
Vandal Varifocal IR Dome Camera (4-9mm lens) (420 TVL)
1/4" SONY Super HAD CCD, 420 TVL, 4-9mm Lens
36 IR LED's, 1 CDS, Visibility Range: 75 FT
Weather Proof (IP66), DC12V
Vandal In/Outdoor Day/Night PTZ Speed Dome with Wall Mount
1/4"Sony CCD, 550 TV Lines, 324x Zoom, OSD
Color (0.4 Lux), BW (0.02 Lux), Day/Night with IR cut filter (ICR)
27XOptical, 12X Digital Zoom with Digital Image Stabilization
Vandal-Proof Dome and Housing, IP67
128 Presets, 4 Patterns, 8 Swings, 8 Groups
Endless Pan Rotation, Auto Flip, 8 Privacy Zones
Vandal In/Outdoor Day/Night PTZ Speed Dome with Ceiling Mount
1/4"Sony CCD, 550 TV Lines, 324x Zoom, OSD
Color (0.4 Lux), BW (0.02 Lux), Day/Night with IR cut filter (ICR)
27XOptical, 12X Digital Zoom with Digital Image Stabilization
Vandal-Proof Dome and Housing, IP67
128 Presets, 4 Patterns, 8 Swings, 8 Groups
Endless Pan Rotation, Auto Flip, 8 Privacy Zones
Vandal In/Outdoor WDR, Day/Night PTZ Speed Dome with Wall Mount
1/4"Sony CCD, 550 TV Lines, 444x Zoom, OSD
Color (0.4 Lux), BW (0.02 Lux), Day/Night with IR cut filter (ICR)
37XOptical, 12X Digital Zoom with Digital Image Stabilization
Vandal-Proof Dome and Housing, IP67
128 Presets, 4 Patterns, 8 Swings, 8 Groups
Endless Pan Rotation, Auto Flip, 8 Privacy Zones
Vandal In/Outdoor WDR, Day/Night PTZ Speed Dome with Ceiling Mount
1/4"Sony CCD, 550 TV Lines, 444x Zoom, OSD
Color (0.4 Lux), BW (0.02 Lux), Day/Night with IR cut filter (ICR)
37XOptical, 12X Digital Zoom with Digital Image Stabilization
Vandal-Proof Dome and Housing, IP67
128 Presets, 4 Patterns, 8 Swings, 8 Groups
Endless Pan Rotation, Auto Flip, 8 Privacy Zones
Mini Vandal In/Outdoor Day/Night PTZ with Wall Mount
1/4" Interline Transfer CCD, 500 TV Lines, 100x Zoom
0.02 Lux B/W (Night), On Screen Display
10XOptical, 10X Digital Zoom
Day & Night with IR Cut filter
Built in Heater and Blower
Endless Pan Rotation, SNR (Super Noise Reduction)
Mini Vandal In/Outdoor Day/Night PTZ with Ceiling Mount
1/4" Interline Transfer CCD, 500 TV Lines, 100x Zoom
0.02 Lux B/W (Night), On Screen Display
10XOptical, 10X Digital Zoom
Day & Night with IR Cut filter
Built in Heater and Blower
Endless Pan Rotation, SNR (Super Noise Reduction)
ZCOM5539 $80.00
ZPM5539 $80.00
PARAPETW Parapet Wall Mount Bracket for Z5243DNOD Only $500.00
PARAPETR $500.00
PTZ CONTROLLER (1 year warranty)
ZCONTROL 3 Dimension controller $500.00
ST SERIES DVR (3 year warranty)
ST4500 Embedded, 4 Channel, 120 FPS, 500GB, H.264, Jump Drive, Networkable, Remote $700.00
ST41TB Embedded, 4 Channel, 120 FPS, 1TB, H.264, Jump Drive, Networkable, Remote $860.00
ST8500 Embedded, 8 Channel, 120 FPS, 500GB, H.264, Jump Drive, Networkable, Remote $900.00
ST81TB Embedded, 8 Channel, 120 FPS, 1TB, H.264, Jump Drive, Networkable, Remote $1,060.00
ST16500 Embedded, 16 Channel, 120 FPS, 500GB, H.264, Jump Drive, Networkable, Remote $1,100.00
ST161TB Embedded, 16 Channel, 120 FPS, 1TB, H.264, Jump Drive, Networkable, Remote $1,260.00
DVRL SERIES DVR (3 year warranty)
DVRL-4-120-500 H.264 Embedded 4CH, 120FPS, 500GB, Jump Drive $925.00
DVRL-4-120-1TB H.264 Embedded 4CH, 120FPS, 1TB, Jump Drive $1,139.00
DVRL-8-240-500 H.264 Embedded 8CH, 240FPS, 500GB, Jump Drive $1,373.00
DVRL-8-240-1TB H.264 Embedded 8CH, 240FPS, 1TB, Jump Drive $1,587.00
DVRL-16-240-500 H.264 Embedded 16CH, 240FPS, 500GB, Jump Drive $1,626.00
DVRL-16-240-1TB H.264 Embedded 16CH, 240FPS, 1TB, Jump Drive $1,840.00
DVRH SERIES DVR (3 year warranty)
DVRH-4-120-500 HYBRID 4CH, 120FPS, 500GB, DVDRW $1,248.00
DVRH-4-120-1TB HYBRID 4CH, 120FPS, 1TB, DVDRW $1,462.00
DVRH-4-120-2TB HYBRID 4CH, 120FPS, 2TB, DVDRW $1,728.00
DVRH-8-240-500 HYBRID 8CH, 240FPS, 500GB, DVDRW $1,750.00
DVRH-8-240-1TB HYBRID 8CH, 240FPS, 1TB, DVDRW $1,965.00
DVRH-8-240-2TB HYBRID 8CH, 240FPS, 2TB, DVDRW $2,230.00
DVRH-16-240-500 HYBRID 16CH, 240FPS, 500GB, DVDRW $2,019.00
DVRH-16-240-1TB HYBRID 16CH, 240FPS, 1TB, DVDRW $2,042.00
Corner Mount Bracket for all LUXON PTZ's on this pricelist
Pole Mount Bracket for all LUXON PTZ's on this pricelist
Parapet Rooptop Mount Bracket for Z5243DNOD Only
DVRH-16-240-2TB HYBRID 16CH, 240FPS, 2TB, DVDRW $2,499.00
HVR SERIES HYBRID IP/ANALOG DVR (3 year warranty)
HVR-8-240-500 HYBRID 8CH, 240FPS, 500GB, DVDRW $2,642.00
HVR-8-240-1TB HYBRID 8CH, 240FPS, 1TB, DVDRW $2,870.00
HVR-8-240-2TB HYBRID 8CH, 240FPS, 2TB, DVDRW $3,237.00
HVR-8-240-4TB HYBRID 8CH, 240FPS, 4TB, DVDRW $4,066.00
HVR-16-480S-500 HYBRID 16CH, 480FPS, 500GB, DVDRW $2,907.00
HVR-16-480S-1TB HYBRID 16CH, 480FPS, 1TB, DVDRW $3,135.00
HVR-16-480S-2TB HYBRID 16CH, 480FPS, 2TB, DVDRW $3,417.00
HVR-16-480S-4TB HYBRID 16CH, 480FPS, 4TB, DVDRW $4,247.00
HVR-16-480S-6TB HYBRID 16CH, 480FPS, 6TB, DVDRW $5,076.00
HVR-16-480-500 HYBRID 16CH, 480FPS, 500GB, DVDRW $4,199.00
HVR-16-480-1TB HYBRID 16CH, 480FPS, 1TB, DVDRW $4,427.00
HVR-16-480-2TB HYBRID 16CH, 480FPS, 2TB, DVDRW $4,709.00
HVR-16-480-4TB HYBRID 16CH, 480FPS, 4TB, DVDRW $5,539.00
HVR-16-480-6TB HYBRID 16CH, 480FPS, 6TB, DVDRW $6,368.00
16 HYBRID CHANNELS of IP, 480fps @ CIF
NVR-16 Network Video Recorder 16CH, NO Hard Drive, DVD-R $4,477.20
NVR-16-1TB Network Video Recorder 16CH, 1TB, DVD-R $4,858.00
NVR-16-2TB Network Video Recorder 16CH, 2TB, DVD-R $5,092.58
NVR-16-4TB Network Video Recorder 16CH, 4TB, DVD-R $5,707.97
NVR-16-6TB Network Video Recorder 16CH, 6TB, DVD-R $6,323.35
NVR-16-8TB Network Video Recorder 16CH, 8TB, DVD-R $6,938.72
16 HYBRID CHANNELS of IP, 480fps @ D1
NVR-16D1 Network Video Recorder 16CH, NO Hard Drive, Full fps @ D1, DVD-R $5,717.40
NVR-16D1-1TB Network Video Recorder 16CH, 1TB, Full fps @ D1, DVD-R $6,071.00
NVR-16D1-2TB Network Video Recorder 16CH, 2TB, Full fps @ D1, DVD-R $6,288.83
NVR-16D1-4TB Network Video Recorder 16CH, 4TB, Full fps @ D1, DVD-R $6,860.26
NVR-16D1-6TB Network Video Recorder 16CH, 6TB, Full fps @ D1, DVD-R $7,431.68
NVR-16D1-8TB Network Video Recorder 16CH, 8TB, Full fps @ D1, DVD-R $8,003.11
32 HYBRID CHANNELS of IP, 960fps @ VGA
NVR-32H 32 CH IP/Analog, NO Hard Drive, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $6,717.20
NVR-32H-2TB 32 CH IP/Analog, 2TB, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $7,332.61
NVR-32H-4TB 32 CH IP/Analog, 4TB, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $7,947.97
NVR-32H-6TB 32 CH IP/Analog, 6TB, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $8,563.35
NVR-32H-8TB 32 CH IP/Analog, 8TB, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $9,178.74
NVR-32H-10TB 32 CH IP/Analog, 10TB, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $9,794.12
LINUX PLATFORM HYBRID IP/ANALOG DVR (2 year warranty)
8 HYBRID CHANNELS of Analog with up to 8 as IP
LIN8-240 HYBRID 8CH, 240FPS, NO Hard Drive, DVDRW $1,947.40
LIN8500GB240 HYBRID 8CH, 240FPS, 500GB, DVDRW $2,126.80
LIN81TB240 HYBRID 8CH, 240FPS, 1TB, DVDRW $2,301.00
LIN82TB240 HYBRID 8CH, 240FPS, 2TB, DVDRW $2,518.83
LIN84TB240 HYBRID 8CH, 240FPS, 4TB, DVDRW $3,090.26
16 HYBRID CHANNELS of Analog with up to 16 as IP
LIN16-480 HYBRID 16CH, 480FPS, NO Hard Drive, DVDRW $2,597.40
LIN161TB480 HYBRID 16CH, 480FPS, 1TB, DVDRW $2,951.00
LIN162TB480 HYBRID 16CH, 480FPS, 2TB, DVDRW $3,168.83
LIN164TB480 HYBRID 16CH, 480FPS, 4TB, DVDRW $3,740.26
LIN166TB480 HYBRID 16CH, 480FPS, 6TB, DVDRW $4,311.68
ST SERIES DVR KITS WITH CAMERAS & ACCESSORIES
STBIR4500KIT Kit includes (1) ST4500, (4) VL2BIR420, (4) CABLE60, (1) 1TO4P, (1) DC2A $1,140.00
STVIR4500KIT $1,140.00
STBIR41TBKIT Kit includes (1) ST41TB, (4) VL2BIR420, (4) CABLE60, (1) 1TO4P, (1) DC2A $1,300.00
STVIR41TBKIT $1,300.00
STBIR8500KIT Kit includes (1) ST8500, (8) VL2BIR420, (8) CABLE60, (2) 1TO4P, (2) DC2A $1,792.00
STVIR8500KIT $1,792.00
STBIR81TBKIT Kit includes (1) ST81TB, (8) VL2BIR420, (8) CABLE60, (2) 1TO4P, (2) DC2A $1,952.00
STVIR81TBKIT $1,952.00
IMAGE DESCRIPTION List
IP Cameras (1 year warranty)
MIP1280 $390.00
MIPVD1280 $540.00
MIPC1280 $530.00
IPC540DN $390.00
IPVD54VIR $610.00
ENCODER1 MPEG4/JPEG 1ch video server, 720*480, SD card $380.00
MIPC1600 $615.00
MIPD1280V $450.00
MIPB1280V $540.00
MIPVD1600V $675.00
NVR's (Software Included) (2 year warranty)
4 CHANNELS of IP
NVR-4 Network Video Recorder 4CH, NO Hard Drive $1,033.20
NVR-4-500GB Network Video Recorder 4CH, 500GB $1,226.00
NVR-4-1TB Network Video Recorder 4CH, 1TB $1,414.00
NVR-4-2TB Network Video Recorder 4CH, 2TB $1,648.58
16 HYBRID CHANNELS of IP, 480fps @ CIF
NVR-16 Network Video Recorder 16CH, NO Hard Drive, DVD-R $4,477.20
NVR-16-1TB Network Video Recorder 16CH, 1TB, DVD-R $4,858.00
NVR-16-2TB Network Video Recorder 16CH, 2TB, DVD-R $5,092.58
NVR-16-4TB Network Video Recorder 16CH, 4TB, DVD-R $5,707.97
NVR-16-6TB Network Video Recorder 16CH, 6TB, DVD-R $6,323.35
NVR-16-8TB Network Video Recorder 16CH, 8TB, DVD-R $6,938.72
16 HYBRID CHANNELS of IP, 480fps @ D1
NVR-16D1 Network Video Recorder 16CH, NO Hard Drive, Full fps @ D1, DVD-R $5,717.40
NVR-16D1-1TB Network Video Recorder 16CH, 1TB, Full fps @ D1, DVD-R $6,071.00
NVR-16D1-2TB Network Video Recorder 16CH, 2TB, Full fps @ D1, DVD-R $6,288.83
NVR-16D1-4TB Network Video Recorder 16CH, 4TB, Full fps @ D1, DVD-R $6,860.26
NVR-16D1-6TB Network Video Recorder 16CH, 6TB, Full fps @ D1, DVD-R $7,431.68
Kit includes (1) ST4500, (4) VL2VDTIR420, (4) CABLE60, (1) 1TO4P, (1)
DC2A
Kit includes (1) ST41TB, (4) VL2VDTIR420, (4) CABLE60, (1) 1TO4P, (1)
DC2A
Kit includes (1) ST8500, (8) VL2VDTIR420, (8) CABLE60, (2) 1TO4P, (2)
DC2A
Kit includes (1) ST81TB, (8) VL2VDTIR420, (8) CABLE60, (2) 1TO4P, (2)
DC2A
Luxon PART #
1.3 Mega-Pixel IP Camera (1280x1024)
1/4" CMOS, 1280x1024, MPEG4 IP Camera
2 way audio, SD Card and Analog Output
Alarm Inputs and Outputs, 1 Lux Color
AWB, AGC, BLC, 5 VDC/700mA
1.3 Mega-Pixel IP Vandal/Weather Dome POE Camera (1280x1024)
1/4" CMOS, 1280x1024, MPEG4 IP Camera
2 way audio, SD Card , 3.7-12mm Vari-focal Lens
POE, AWB, AGC, BLC, 12VDC/600mA
1.3 Mega-Pixel IP Box Camera (1280x1024)
1/4" CMOS, 1280x1024, MPEG4 IP Camera
2 way audio, SD Card and Analog Output
Alarm Inputs and Outputs, 1 Lux Color
POE, AWB, AGC, BLC, 12VDC/600mA
Lens not included
Day/Night High Res IP Color Camera (720*480)
1/3" CCD, MPEG4/M-JPEG IP Camera
720*480, 2 way audio, SD Card and Analog Output
Alarm Inputs and Outputs, 0.003 Lux Color
Color (0.3 Lux), B/W (0.003 Lux)
AWB, AGC, BLC, 12VDC/500mA
Lens not included
IP IR Day/Night Vari-Focal Vandal/Weather Dome POE (720*480)
1/3" CCD, MPEG4/M-JPEG IP Camera
4-12mm Vari-focal Lens
720*480, 2 way audio, AWB, AGC, BLC
Alarm Inputs and Outputs, 12VDC/600mA
2 Mega-Pixel IP Box Camera (1600x1200)
1/3" CMOS, 1600x1200, H.264, MPEG4 & JPEG IP Camera
2 way audio, SD Card and Analog Output
Alarm Inputs and Outputs, 1 Lux Color
POE, AWB, AGC, BLC, 12VDC/450mA
Lens not included
1.3 Mega-Pixel IP Varifocal Dome Camera (1280x1024)
1/4" CMOS, 1280x1024, MPEG4 & M-JPEG IP Camera
SD Card , 3.7-12mm Vari-focal Lens
POE, 12VDC/320mA
1.3 Mega-Pixel IP Varifocal IR Bullet Camera (1280x1024)
1/4" CMOS, 1280x1024, MPEG4 & M-JPEG IP Camera
Day/Night, 2.8-10mm Vari-focal Lens, 60' IR Distance
POE, 12VDC/450mA
2 Mega-Pixel IP Vandal/Weather Dome POE Camera (1600x1200)
1/3" CMOS, 1600x1200, H.264,MPEG4,JPEG IP Camera
SD Card , 2.7-9mm Vari-focal Lens, 36' IR Distance
POE, 12VDC/600mA
NVR-16D1-8TB Network Video Recorder 16CH, 8TB, Full fps @ D1, DVD-R $8,003.11
32 HYBRID CHANNELS of IP, 960fps @ VGA
NVR-32H 32 CH IP/Analog, NO Hard Drive, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $6,717.20
NVR-32H-2TB 32 CH IP/Analog, 2TB, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $7,332.61
NVR-32H-4TB 32 CH IP/Analog, 4TB, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $7,947.97
NVR-32H-6TB 32 CH IP/Analog, 6TB, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $8,563.35
NVR-32H-8TB 32 CH IP/Analog, 8TB, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $9,178.74
NVR-32H-10TB 32 CH IP/Analog, 10TB, 960/960 FPS, DVDRW, POS, 16 CH AUDIO $9,794.12
32 CHANNELS of IP (IP only)
NVR-32 Network Video Recorder 32CH, NO Hard Drive, DVD-R $5,597.20
NVR-32-2TB Network Video Recorder 32CH, 2TB, DVD-R $6,212.61
NVR-32-4TB Network Video Recorder 32CH, 4TB, DVD-R $6,827.97
NVR-32-6TB Network Video Recorder 32CH, 6TB, DVD-R $7,443.35
NVR-32-8TB Network Video Recorder 32CH, 8TB, DVD-R $8,058.74
NVR-32-10TB Network Video Recorder 32CH, 10TB, DVD-R $8,674.12
LINUX PLATFORM HYBRID IP/ANALOG DVR (2 year warranty)
8 HYBRID CHANNELS of Analog with up to 8 as IP
LIN8-240 HYBRID 8CH, 240FPS, NO Hard Drive, DVDRW $2,097.20
LIN8500GB240 HYBRID 8CH, 240FPS, 500GB, DVDRW $2,290.40
LIN81TB240 HYBRID 8CH, 240FPS, 1TB, DVDRW $2,478.00
LIN82TB240 HYBRID 8CH, 240FPS, 2TB, DVDRW $2,712.58
LIN84TB240 HYBRID 8CH, 240FPS, 4TB, DVDRW $3,327.97
16 HYBRID CHANNELS of Analog with up to 16 as IP
LIN16-480 HYBRID 16CH, 480FPS, NO Hard Drive, DVDRW $2,797.20
LIN161TB480 HYBRID 16CH, 480FPS, 1TB, DVDRW $3,178.00
LIN162TB480 HYBRID 16CH, 480FPS, 2TB, DVDRW $3,412.58
LIN164TB480 HYBRID 16CH, 480FPS, 4TB, DVDRW $4,027.97
LIN166TB480 HYBRID 16CH, 480FPS, 6TB, DVDRW $4,643.35
IMAGE PART # DESCRIPTION List
MBALUN Mini Balun $10.00
MBALUNL Mini Balun w/lead $10.00
TP1VPBR $22.00
TP1VPBT $22.00
TP1VPDBT $34.00
TP1VPDBR $34.00
TP4VTR Separates 4 BNC channels of video from one CAT 5 cable. $58.00
TP4VDBR $70.00
TP44VPDRB $84.00
TA1AVDT $84.00
TA1AVDR $92.00
TA1VT $70.00
TA1VR $80.00
TP16VTB $550.00
TP16VRB $500.00
TP4VPRR $66.00
TP16PI $300.00
CA14VBB $66.00
TA8VTB $750.00
TA16VTB $1,246.00
PACDC $29.24
AUDIO1 $28.80
Size Key Features List
VGALCD19 19" 307.972
LCD17A 17" 1000:1, 300cd/m²Video I/O(BNCx2), VGA(RGB 15pin), S-Video, 2D Comb Filter, Noise Reduction, Tilt Function 680
LCD19A 19" 800:1, 300cd/m²Video I/O(BNCx2), VGA(RGB 15pin), S-Video, 2D Comb Filter, Noise Reduction, Tilt Function 790
SM4KIT 4" Portable 4" Color LCD Test Monitor with Cable Tester & Built-in Rechargeable Battery 390
LCD101 n/a Articulating LCD Mount (SILVER) 78
LCD301 n/a Tilting LCD Mount (Black) 48
UTP (Unshielded Twisted Pair) Products (3 year warranty)
BNC Male To RJ45 Female With Power
Video Tranceiver BNC Male To RJ45 Female With Power Cord
Use with TP4VP-RR to transmit video & power over one CAT 5 cable.
BNC Male To Terminal With Power
Video Tranceiver BNC Male To RJ45 Female With Power Cord
Use with TP4VP-RR to transmit video & power over one CAT 5 cable.
Video, Power, Data Tranceiver (Terminal Termination)
Sent over one CAT 5 cable.
Video, Power, Data Tranceiver (RJ45 Termination)
Sent over one CAT 5 cable.
4 BNC or 3 BNC/one data sent over one CAT 5 cable with
RJ45 termination
4 RJ45 or 3 RJ45/one data sent over one CAT 5 cable with
RJ45 termination. Use with TP1VP-BR and TP1VPD-BR.
Transmission of video audio & data up to 2400 meters.
Active Video & Audio & Data Twisted Pair Transmission - Transmitter
Receiver for TA1AVD-R
Active Video & Audio & Data Twisted Pair Transmission - Receiver
Transmission of video & data up to 1.5KM . (Use with TA1V-R )
Active Video Twisted Pair Transmission Transmitter
Adjustments for color gain and brightness.
Reciever for video and data.
Active Video Twisted Pair Transmission Receiver
(Use with TA1V-T for 1.5 KM or with Balun1 for 1KM transmission)
16 channels of video in through Terminal block into BNC
16 port Passive Video Transceiver Hub in 1U Rack Mounting Panel (Terminal Block to BNC)
16 channels of video in through RJ45 into BNC
16 port Passive Video Transceiver Hub in 1U Rack Mounting Panel
(RJ45 to BNC)
4 RJ45 Female to 1 RJ45 Female Cable Hub With Power
Transmit 4 channel of video over one CAT 5 use with TP1VP-BR
16 Port Cable Integrator (Video, Power, Data) In 1U Rack
16 channels of video or data in from TP1VP-BR or TP1VPD-BR.
Individual power inputs for different voltages
Built in surge protection on data
BNC Video Distributor
1 BNC Input to 4 BNC Outputs
8 port Active Receiver Hub in 1U Rack Mounting Panel
Per channel adjustments for color gain & brightness
Built in transient protection and ground looping.
Transmission range up to 3,300 ft.
16 port Active Receiver Hub in 1U Rack Mounting Panel
Per channel adjustments for color gain & brightness
Built in transient protection and ground looping.
Transmission range up to 3,300 ft.
AC to DC 12V Power Converter 500 mA (Regulated)
Audio Pickup Box
Add on to any camera that needs audio funtion.
Highly sensitive microphone (-65dB) and DC12V power regulator
box built in.
(see diagram on www.luxonvideo.com)
Luxon Part #
Most Popular!!! (IN STOCK!)
PC MONITOR LCD VGA Monitor Series - RTLD (MOST POPULAR!)
19" VGA Monitor (Brand may vary between Acer, Dell, HP, ect.)
ECONOMIC LCD CCTV Monitor Series - (19" MOST POPULAR!)
Wall & Rack Mounting Brackets (More mounts at bottom of page!)
NEW MONITORS and MOUNTS!!! (Allow 1 week for shipping!)
LCD17V 17" 850
LCD19V 19" 930
LCD22V 22" 1058.4
LED185E 18.5" 548.8
LED185P 18.5" 775.6
LED215E 21.5" 680.4
LED215S 21.5" 1181.6
LED215P 21.5" 946.4
LCD8C 8" 585.2
LCD10C 10.4" 400:1, 230cd/m², Video I/O(BNCx2), VGA(RGB 15pin), S-Video I/O, Trigger Input, PC stereo In 604.8
LCD15C 15" 865.2
LCD17C 17" 1055.6
LCD19C 19" 1153.6
LCD20H 20" 1383.2
LCD24C 24" 1814.4
LCD26C 26" 1853.6
LCD32C 32" 2080.4
LCD32C120 32" 2192.4
LCD42H 42" 3477.6
LCD42H120 42' 3592.4
LCD40L 40" 4536
LCD46L 46" 5860.4
LCD52L 52" 6920
LCD65L 65" 16537.5
LCD70L 70" 20587.5
LCD15RM 15" 600:1, 250cd/m², Video I/O(BNCx2), VGA RGB Input, S-Video I/O, PC Stereo Input, Built In Speakers & Tilt 865.2
LCD17RM 17" 1000:1, 300cd/m², Video I/O(BNCx2), VGA RGB Input, S-Video I/O, PC Stereo Input, Built In Speakers & Tilt 1055.6
LCD19RM 19" 800:1, 300cd/m², Video I/O(BNCx2), VGA RGB Input, S-Video I/O, PC Stereo Input, Built In Speakers & Tilt 1153.6
LCD22PV 22" 1720
LCD22PVW 22" 1758.4
LCD22PV/CR 22" 1892.8
LCD22PVW/CR 22" 1909.6
LCD26PV 26" 1946
LCD26PV/CR 26" 2307.2
LCD26PVW/CR 26" 2343.6
LCD32PV 32" 2690
LCD32PV/CR 32" 2836.4
LCD32PVW/CR 32" 2872.8
LCD15TC 15" 1470
LCD15TR 15" 1092
LCD17TC 17" 1716.4
LCD17TR 17" 1318.8
LCD19TC 19" 1870.4
LCD19TR 19" 1492.4
LCD26T 26" 3138.8
LCD32T 32" 3861
LCD42T 42" 6107.4
Wall & Rack Mounting Brackets
LCD101 n/a Articulating LCD Mount (SILVER) 78
LCD301 n/a Tilting LCD Mount (Black) 48
M105 n/a Flat Wall Mount (Low Profile: 0.5"), For Monitors 13" ~ 30", VESA: 75/100mm, Max 60lbs 70
M110 n/a Tilt / Rotate Wall Mount, Double Articulating Arm (20°/180°), VESA: 75/100mm, Max 40lbs. 70
M130 n/a Tilt / Rotate Wall Mount, Double Articulating Arm (20°/180°) , VESA: 75/100mm, Max: 30lbs 126
M131 n/a Tilt / Rotate Wall Mount, Double Articulating Arm, (20°/180°), VESA: 75 ~ 200mm, Max: 60lbs 168
M140 n/a 168
M150 n/a 196
M160 n/a 210
M170 n/a 238
MC105 n/a 182
MC107 n/a 196
MC110 n/a 308
MRM-108 n/a Rack Mounts 8" to 20" 168
VALUE LCD CCTV Monitor Series -
1000:1, 300cd/m², 600 TV LINE, VOV, Trigger & Auto switching, Video I/O(BNCx2), VGA(RGB 15pin), HDMI, S-
Video, LCD Protection Shield, Built in Speakers, Remote Controller
800:1, 300cd/m², 600 TV LINE, VOV, Trigger & Auto switching, Video I/O(BNCx2), VGA(RGB 15pin), HDMI, S-
Video, LCD Protection Shield, Built in Speakers, Remote Controller
1000:1, 300cd/m², 600 TV LINE, VOV, Trigger & Auto switching, Video I/O(BNCx2), VGA(RGB 15pin), HDMI, S-
Video, Built in Speakers, Remote Controller
PREMIUM LED CCTV Monitor Series -
600 TV Lines, 10bit Digital Conversion Rate, 1000:1, 250cd/m², <5ms, PC Stereo In/Out, RGB 15pin, HDMI,
PIP/PBP/VOV, Built in Speakers, Energy Efficient, Remote
600 TV Lines, 10bit Digital Conversion Rate, 1000:1, 250cd/m², <5ms, Video I/O(BNCx2/1), PC Stereo Input,
RGB 15pin, Trigger In, Audio In(RCA), DVI, HDMI, PIP/PBP/VOV, Built in Speakers, Energy Efficient, Remote
600 TV Lines, 10bit Digital Conversion Rate, 1000:1, 250cd/m², <5ms, PC Stereo In/Out, RGB 15pin, HDMI,
PIP/PBP/VOV, Built in Speakers, Energy Efficient, Remote
600 TV Lines, 10bit Digital Conversion Rate, 1000:1, 250cd/m², <5ms, SDI I/O, Video I/O(BNCx2/1), PC
Stereo Input, RGB 15pin, Trigger In, Audio In(RCA), HDMI, DVI PIP/PBP/VOV, Built in Speakers, Energy
Efficient, Remote
600 TV Lines, 10bit Digital Conversion Rate, 1000:1, 250cd/m², <5ms, Video I/O(BNCx2/1), PC Stereo Input,
RGB 15pin, Trigger In, Audio In(RCA), HDMI, DVI PIP/PBP/VOV, Built in Speakers, Energy Efficient, Remote
PREMIUM LCD CCTV Monitor Series -
500:1, 250cd/m², Supports 2 units in 1 tiltable rack (RMK-08), Video I/O(BNCx2), VGA(RGB 15pin), S-Video I/O,
Trigger Input, PC stereo In
700:1, 250cd/m², Video I/O(BNCx2), Audio In(x2), S-Video I/O, VGA Input, Built in Speakers, Remote Control,
Trigger Input, All metal cabinet, LCD Protection Glass
1000:1, 300cd/m², Video I/O(BNCx2), VGA Input, S-Video, DVI, HDMI, PIP, Built in Speakers, Trigger Input, All
metal cabinet, LCD Protection Glass
800:1, 300cd/m², Video I/O (BNCx2), VGA Input, S-Video, DVI, HDMI, PIP, Built in Speakers, Trigger Input, All
metal cabinet, LCD Protection Glass
800:1, 300cd/m², Video I/O(BNCx2), Audio I/O(x2) VGA Input, S-Video, DVI, HDMI, PIP, Built in Speakers,
Trigger Input, All metal cabinet, LCD Protection Glass
PREMIUM WIDE LCD CCTV Monitor Series -
Full HD Resolution, 16:9, 1000:1, 400cd/m², Video I/O(BNCx2), VGA Input, DVI-D, HDMI, Component, Audio
I/O(x2/1), S-Video I/O, PIP, LCD Protection Glass, Built in Speakers, Remote Control, trigger input
16:9, 1500:1, 450cd/m², Viedo I/O(BNCx2), VGA Input, DVI-D, HDMI, Component, Audio I/O(x2/1), S-Video
I/O, PIP, LCD Protection Glass, Remote Control, Trigger Input
16:9, 3000:1, 500cd/m², Video I/O(BNCx2), VGA Input, DVI-D, HDMI, Component, Audio I/O(x2), S-Video I/O,
PIP, LCD Protection Glass, Built in Speakers, Remote Control, Trigger Input
120Hz, 16:9, 3000:1, 500cd/m², Video I/O(BNCx2), VGA Input, DVI-D, HDMI, Component, Audio I/O(x2), S-
Video I/O, PIP/PBP, LCD Protection Glass, Built in Speakers, Remote Control, Trigger Input
Full HD Resolution, 16:9, 1300:1, 500cd/m², Video I/O(BNCx2), HDMI, VGA Input, DVI, Component, Audio
I/O(x2/1), S-Video I/O, PIP/PBP, Built in Speakers, Remote Control, Trigger Input
120Hz, Full HD Resolution, 16:9, 1300:1, 500cd/m², Video I/O(BNCx2), HDMI, VGA Input, DVI, Component,
Audio I/O(x2/1), S-Video I/O, PIP/PBP, Built in Speakers, Remote Control, Trigger Input
ULTRA NARROW BEZEL LCD CCTV Monitor Series - (Digital Signage)
16:9, 700cd/m², 2000:1, 3D Comb Filter, 8ms, PIP / PBP, DeInterlace, 3D Noise Reduction, 11mm narrow bezel,
RS-232C I/O, Video I/O(BNCx2), HDMI I/O, DVI-D I/O, S-Video I/O, Component In, Audio In(RCAx2/1), PC
Stereo In, Built in Speakers, IR Remote Control, optional Mounting Bracket
16:9, 700cd/m², 2000:1, 3D Comb Filter, 8ms, PIP / PBP, DeInterlace, 3D Noise Reduction, 11mm narrow bezel,
RS-232C I/O, Video I/O(BNCx2), HDMI I/O, DVI-D I/O, S-Video I/O, Component In, Audio In(RCAx2/1), PC
Stereo In, Built in Speakers, IR Remote Control, optional Mounting Bracket
16:9, 600cd/m², 1700:1, 3D Comb Filter, 8ms, PIP / PBP, DeInterlace, 3D Noise Reduction, 11mm narrow bezel,
RS-232C I/O, Video I/O(BNCx2), HDMI I/O, DVI-D I/O, S-Video I/O, Component In, Audio In(RCAx2/1), PC
Stereo In, Built in Speakers, IR Remote Control, optional Mounting Bracket
16:9, 700cd/m², 2500:1, 3D Comb Filter, 8ms, PIP / PBP, DeInterlace, 3D Noise Reduction, 11mm narrow bezel,
RS-232C I/O, Video I/O(BNCx2), HDMI I/O, DVI-D I/O, S-Video I/O, Component In, Audio In(RCAx2/1), PC
Stereo In, Built in Speakers, IR Remote Control, optional Mounting Bracket
16:9, 600cd/m², 1500:1, 3D Comb Filter, 8ms, PIP / PBP, DeInterlace, 3D Noise Reduction, 11mm narrow bezel,
RS-232C I/O, Video I/O(BNCx2), HDMI I/O, DVI-D I/O, S-Video I/O, Component In, Audio In(RCAx2/1), PC
Stereo In, Built in Speakers, IR Remote Control, optional Mounting Bracket
RACK MOUNTABLE LCD CCTV Monitor Series -
PUBLIC VIEW LCD CCTV Monitor Series -
Built in WDR Camera w/ Microwave Motion Sensor, 16:9, 1000:1, 300cd/m², Video I/O(BNC), Audio I/O(x2), S-
Video I/O, VGA Input, DVI, HDMI, 3D Comb Filter, Deinterlace, PIP/PBP/VOV, Built in Speakers, Remote Control,
(AC 110 & DC 24)
White Cabinet, Built in WDR Camera w/ Microwave Motion Sensor, 16:9, 1000:1, 300cd/m², Video I/O(BNC),
Audio I/O(x2), S-Video I/O, VGA Input, DVI, HDMI, 3D Comb Filter, Deinterlace, PIP/PBP/VOV, Built in Speakers,
Remote Control, (AC 110 & DC 24)
Built in WDR Camera w/ Microwave Motion Sensor + Card Reader, 16:9, 1000:1, 300cd/m², Video I/O(BNC),
Audio I/O(x2), S-Video I/O, VGA Input, DVI, HDMI, 3D Comb Filter, Deinterlace, PIP/PBP/VOV, Built in Speakers,
Remote Control, (AC 110 & DC 24)
White Cabinet, Built in WDR Camera w/ Microwave Motion Sensor + Card Reader, 16:9, 1000:1, 300cd/m²,
Video I/O(BNC), Audio I/O(x2), S-Video I/O, VGA Input, DVI, HDMI, 3D Comb Filter, Deinterlace, PIP/PBP/VOV,
Built in Speakers, Remote Control, (AC 110 & DC 24)
Built in WDR Camera w/ Microwave Motion Sensor,16:9, 2000:1, 450cd/m², Video I/O(BNC), Audio I/O(x2), S-
Video I/O, VGA Input, DVI, HDMI, 3D Comb Filter, Deinterlaced, PIP/PBP/VOV, LCD Protective Shield, Built in
Speakers, Remote Control, AC 110
Built in WDR Camera w/ Microwave Motion Sensor + Card Reader,16:9, 2000:1, 450cd/m², Video I/O(BNC),
Audio I/O(x2), S-Video I/O, VGA Input, DVI, HDMI, 3D Comb Filter, Deinterlaced, PIP/PBP/VOV, LCD Protective
Shield, Built in Speakers, Remote Control, AC 110
White Cabinet, Built in WDR Camera w/ Microwave Motion Sensor + Card Reader,16:9, 2000:1, 450cd/m²,
Video I/O(BNC), Audio I/O(x2), S-Video I/O, VGA Input, DVI, HDMI, 3D Comb Filter, Deinterlaced,
PIP/PBP/VOV, LCD Protective Shield, Built in Speakers, Remote Control, AC 110
Built in WDR Camera w/ Microwave Motion Sensor,16:9, 3000:1, 500cd/m², Video I/O(BNC), Audio I/O(x2), S-
Video I/O, VGA Input, DVI, HDMI, 3D Comb Filter, Deinterlaced, PIP/PBP/VOV, LCD Protective Shield, Built in
Speakers, Remote Control, AC 110
Built in WDR Camera w/ Microwave Motion Sensor + Card Reader,16:9, 3000:1, 500cd/m², Video I/O(BNC),
Audio I/O(x2), S-Video I/O, VGA Input, DVI, HDMI, 3D Comb Filter, Deinterlaced, PIP/PBP/VOV, LCD Protective
Shield, Built in Speakers, Remote Control, AC 110
White Cabinet, Built in WDR Camera w/ Microwave Motion Sensor + Card Reader,16:9, 3000:1, 500cd/m²,
Video I/O(BNC), Audio I/O(x2), S-Video I/O, VGA Input, DVI, HDMI, 3D Comb Filter, Deinterlaced,
PIP/PBP/VOV, LCD Protective Shield, Built in Speakers, Remote Control, AC 110
TOUCH SCREEN LCD CCTV Monitor Series -
5-Wire Analog Capacitive Touch Panel, 700:1, 250cd/m², All Metal Cabinet, Video I/O(BNC), Audio In(x2), S-
Video I/O, VGA Input, Trigger Input, LCD Protection Glass, Built in Speakers, Remote Control
5-Wire Analog Resistive Touch Panel, 700:1, 250cd/m², All Metal Cabinet, Video I/O(BNCx2), Audio In(x2), S-
Video I/O, VGA Input, Trigger Input, LCD Protection Glass, Built in Speakers, Remote Control
5-Wire Analog Capacitive Touch Panel, 1000:1, 300cd/m², All Metal Cabinet, Video I/O(BNCx2), S-Video I/O,
VGA Input, Trigger Input, DVI, HDMI, PIP, LCD Protection Glass, Built in Speakers, Remote Control
5-Wire Analog Resistive Touch Panel, 1000:1, 300cd/m², All Metal Cabinet, Video I/O(BNCx2), S-Video I/O, VGA
Input, Trigger Input, DVI, HDMI, PIP, LCD Protection Glass, Built in Speakers, Remote Control
5-Wire Analog Capacitive Touch Panel, 800:1, 300cd/m², All Metal Cabinet, Video I/O(BNCx2), S-Video I/O, VGA
Input, Trigger Input, DVI, HDMI, PIP, LCD Protection Glass, Built in Speakers, Remote Control
5-Wire Analog Resistive Touch Panel, 800:1, 300cd/m², All Metal Cabinet, Video I/O(BNCx2), S-Video I/O, VGA
Input, Trigger Input, DVI, HDMI, PIP, LCD Protection Glass, Built in Speakers, Remote Control
5-Wire Infared Touch Panel, 16:9, 1500:1, 450cd/m², All Metal Cabinet, Video I/O(BNCx2), S-Video I/O, VGA
Input, Trigger Input, Component Input, Audio I/O(x2), DVI, HDMI, PIP, LCD Protection Glass, Remote Control
5-Wire Infared Touch Panel, 16:9, 3000:1, 500cd/m², All Metal Cabinet, Video I/O(BNCx2), S-Video I/O, VGA
Input, Trigger Input, Component Input, Audio I/O(x2), DVI-D, HDMI, PIP, LCD Protection Glass, Built in
Speakers, Remote
5-Wire Infared Touch Panel, Full HD Resolution, 16:9, 1300:1, 500cd/m², All Metal Cabinet, Video I/O(BNCx2),
S-Video I/O, VGA Input, Trigger Input, Component Input, Audio I/O(x2), DVI-D, HDMI, PIP/PBP, LCD Protection
Glass, Built in Speakers, Remote Control
Flat Wall Mount (Low Profile: 1"), For Monitors 32" ~ 42", Built in Level Indicator, Lateral Adjustability, VESA
compatible, UL / GS Listed, Max: 132lbs
Low Profile Flat Wall Mount (1"), For Monitors 32" ~ 42", Built in Level Indicator, Lateral Adjustability, VESA
compatible and Non-VESA, UL / GS Listed, Max: 132lbs
Low Profile Flat Wall Mount (1"), For Monitors 42" ~ 65", Built in Level Indicator, Lateral Adjustability, VESA
compatible and Non-VESA, UL / GS Listed, Max: 132lbs
Tilt Wall Mount, For Monitors 42" ~ 65", Built in Level Indicator, Lateral Adjustability, VESA compatible and Non-
VESA, UL / GS Listed, Max: 132lbs
Adjustable Pendant Mount, Tilt: 20°, Rotation: 360°, Excellent Cable Management, Structural Ceiling Plate,
Monitor Interface Adapter, VESA: 50/75/100mm, Pole Adjusts: 25" ~ 48", Max: 55lbs
Adjustable Pendant Mount, Tilt: 15°, Rotation: 360°, Excellent Cable Management, Structural Ceiling Plate,
Monitor Interface Adapter, VESA: 75/100/200mm, Pole Adjusts: 25" ~ 31", Max 55lbs
Adjustable Pendant Mount, For Monitors 32" ~ 55" (max 165lbs), Tilt: 15°, Rotation: 360°, Excellent Cable
Management, Structural Ceiling Plate, Monitor Interface Adapter, VESA: 100/200mm, Pole Adjusts: 20" ~ 40",
Rugged Black Powercoat Finish, UL Safety Listed
Mounts, Power Supplies, Lens, & Accessories
IMAGE PART # DESCRIPTION List
WMOUNT Wall Mount Bracket for Vandal Proof Dome Camera $70.00
CMOUNT Ceiling Mount Bracket for Vandal Proof Dome Camera $70.00
IPODWMOUNT $50.00
IPIWMOUNT $34.00
OH $31.00
OHHF $46.00
OHHF1 $79.04
OHHF2 $92.80
CHIW $80.00
DOMEH1 7" Dome Ceiling Housing for Box Cameras $92.00
MOUNT1 Mount for Outdoor Housing (OH, OHHF, CHIR25) $12.00
MOUNT2 T-Bar, Ceiling, Pedestal Camera Mount $12.00
MOUNT4 Ceiling J-Mount for Outdoor Housings (OH, OHHF) $48.00
MOUNT5 Mount for Outdoor Housing (OHHF1, OHHF2) $18.24
PMOUNT1 $19.68
Power Supplies & Accessories
CABLE60 RG59 (with BNC) + DC cable (with connectors), Black, 60ft $24.00
CABLE125 RG59 (with BNC) + DC cable (with connectors), Black, 125ft $36.00
1TO4P $18.00
DC2A 12 Volt 2Amp Transformer $14.00
Outdoor Wall Mount Bracket for Vandal Proof IP Dome Camera
Wall Mount Bracket for Vandal Proof IP Dome Camera
Outdoor Housing
Use Mount Part# MOUNT1
Outdoor Housing with Heater and Blower (24VAC)
Use Mount Part# MOUNT1
Modern Style Outdoor Housing with Heater and Blower (24VAC)
Use Mount Part# MOUNT5
Heavy Duty Outdoor Housing with Heater and Blower (24VAC)
Use Mount Part# MOUNT5
Indoor Wedge Housing
Pole Mount Adapter for Outdoor Housing (OHHF, OH)
For Use with MOUNT1 only
Power Adapter DC Y Cable Pigtail 1 to 4, use DC2A to power
AC40VA 24 Volt 40 Amp Transformer $10.00
DC500MA 12 Volt 500 mA Transformer $8.00
$0.00
DC4UL 4 CAMERA, PTC 12VDC 4AMP POWER SUPPLY
$98.00
DC8UL 8 CAMERA, PTC 12VDC 4AMP POWER SUPPLY
$130.00
DC16UL 16 CAMERA, PTC 12VDC 8AMP POWER SUPPLY
$198.00
P-16DCUL 16 CAMERA, PTC 12VDC 12AMP POWER SUPPLY
$300.00
$0.00
AC4UL 4 CAMERA, PTC 24VAC 4AMP POWER SUPPLY
$90.00
AC8UL 8CAMERA, PTC 24VAC 4AMP POWER SUPPLY
$110.00
AC16UL 16 CAMERA, PTC 24VAC 8AMP POWER SUPPLY
$190.00
P-AC16UL 16 CAMERA, PTC 24VAC 15 AMP POWER SUPPLY
$290.00
PTZ-AC16UL 16ch, 17amps, fused@2amps, PTZ/OHHF
$386.00
OD-AC1 Outdoor NEMA-4 rated, 1 channel, 100AMP 24VAC $188.00
$0.00
RM-AC16 $320.00
RM-DC16 $340.00
Surge Protection
SP1VP12 Over Voltage and Over Current protection for video and power. (1 video & power input) 15V RMS $56.84
SP1VDP24 $130.00
FDCPG DC Female Pigtail Adapter $3.00
MDCPG DC Male Pigtail Adapter $3.00
Rackmount Power Supply 16 CH 8AMP 24VAC
Rackmount Power Supply 16 CH 8AMP 12VDC
Over Voltage and Over Current protection for video, data and power.
(1 video, data & power input) 28V RMS
Accessories
VL358AI $54.00
VL2812AI $86.00
VL660AI $114.00
VL5100IR $142.80
MVL358MI $92.00
MVL1230MI $96.00
IR170 $100.00
IR300 $190.00
Lens 3.5-8mm Vari-focal Auto Iris
Lens 2.8-12mm Vari-focal Auto Iris
Lens 6-60mm Vari-focal Auto Iris
Lens 5-100mm Vari-focal Auto Iris
Mega Pixel Camera Lens 3.5 -8mm Vari-focal Manual Iris for MIPC1280
Mega Pixel Camera Lens 12 -30mm Vari-focal Manual Iris for MIPC1280
170’ IR Illuminator, 12VDC, 45 ° Beam Spread, IP66
350’ IR Illuminator, 12VDC, 10 ° Beam Spread, IP66
