3459A NX Daylight Sensor Cutsheet
2017-10-09
: Pdf 3459A Nx Daylight Sensor Cutsheet 3459A_NX_Daylight_Sensor_Cutsheet spec products hba
Open the PDF directly: View PDF
.
Page Count: 2
3459A 081017
701 Millennium Blvd. | Greenville, SC 29607 | (864) 678-1000 | (866) 898-0131 - fax www.hubbellcontrolsolutions.com
Copyright © 2017 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. All rights reserved. All product and company names, logos and product
identiers are trademarks ™ or registered trademarks ® of Hubbell Lighting, Inc. or their respective owners. Use of them does not necessarily imply any
aliation with or endorsement by such respective owners.
Page 1
Project Name
Catalog No. Date
NXDS SERIES
Daylight Sensor
• Indoor and Outdoor models available
• Architecturally attractive design
• Open loop operation
• Foot-candle range: 3-6,000fc
• Mounts vertically or horizontally
• Color coded, plug-and-play integration with NX Room Controller
• UL and cUL listed
• Five-year limited warranty
Our NX Daylight Sensors provide the necessary daylight-level
information to the NX network. Using a photodiode element, the
daylight sensor continuously measures daylight levels and sends
the information to the network devices which then perform
daylight switching or dimming functionality based on the
amount of natural light in the area.
Dimensional Data
Product Features
TITLE
24
COMPLIANCE
Compliance and Certication
DAYLIGHT
HARVESTING
MODEL
NXDS NX Daylight Sensor
Ordering Information
NXDS
INDOOR/OUTDOOR
BLANK
O
Indoor
Outdoor
2.05”
.125” X .220”
slot
1.38”
3459A 081017
701 Millennium Blvd. | Greenville, SC 29607 | (864) 678-1000 | (866) 898-0131 - fax www.hubbellcontrolsolutions.com
Copyright © 2017 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. All rights reserved. All product and company names, logos and product
identiers are trademarks ™ or registered trademarks ® of Hubbell Lighting, Inc. or their respective owners. Use of them does not necessarily imply any
aliation with or endorsement by such respective owners.
Page 2
701 Millennium Blvd. | Greenville, SC 29607 | (864) 678-1000 | (866) 898-0131 - fax www.hubbellcontrolsolutions.com
Copyright © 2017 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. All rights reserved. All product and company names, logos and product
identiers are trademarks ™ or registered trademarks ® of Hubbell Lighting, Inc. or their respective owners. Use of them does not necessarily imply any
aliation with or endorsement by such respective owners.
Page 2
701 Millennium Blvd. | Greenville, SC 29607 | (864) 678-1000 | (866) 898-0131 - fax www.hubbellcontrolsolutions.com
Copyright © 2017 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. All rights reserved. All product and company names, logos and product
identiers are trademarks ™ or registered trademarks ® of Hubbell Lighting, Inc. or their respective owners. Use of them does not necessarily imply any
aliation with or endorsement by such respective owners.
Page 2
NXDS SERIES NX™ Daylight Sensor
Wiring Information
Electrical Four jumper-selectable foot candel ranges: 0.3-30fc; 3-300fc; 30-3,000fc; 60-6,000fc
Powered by NX Room Controller using plenum rated CAT5 cables (ordered separately)
Operating Environment NXDS: Indoor use only. Operating Temperature: 0° to +40°
NXDS-O: Outdoor Use - IP54. Operating Temperature: -40° to +50°
Construction Protective hard plastic cover and housing
Dimension Ø2”D x 1.2”H [Ø50.8 mm x 30.48 mm]
Certications UL and cUL listed
Warranty Five-year limited
General Specications
