Energy Efficient Product Catalog

indoor and outdoor line of energy efficient

lighting. Designed with conservation in

mind, these energy efficient collections

blend visionary ideals with practical action.

Through efficient bulbs that minimize

watt usage and innovative designs that

optimize utilization, Maxim Lighting

allows homeowners to go green without

sacrificing style.

Those committed to preserving

the world’s natural resources

appreciate Maxim Lighting’s

Light f orL ife

Morrow Bay EE Collection is featured on the front cover.

CounterMax MX-L Series and Rim EE are

featured on the inside cover.

TABLE OF CONTENTS

Installing new ENERGY STAR qualified light fixtures is a smart way to save energy and money. Maxim Lighting is proud to be a ENERGY STAR partner.

Look for this ENERGY STAR logo to find Maxim Lighting fixtures that use ¼ of the energy of traditional incandescent fixtures and last up

to 10 times longer. More information on ENERGY STAR can be found on the ENERGY STAR web site at energystar.gov.

All new homes, additions, alterations and most commercial buildings in California must meet minimum energy efficiency standards contained in Title 24,

Part 6 of the California Code of Regulations. When you see the California Title 24 symbol next to a Maxim Lighting fixtures, you can be assured that the

fixtures complies. More information on California Title 24 can be found on the California Energy Commission web site at energy.ca.gov/title24.

California Title 24

Energy Star Certified

Energy Efficient Indoor Collections

Aurora EE........................5

Basix EE..........................9

Essentials EE................17

Counter, Task & Accent Energy Efficient Lighting CounterMax...................30 StarStrand......................33

Outdoor Energy Efficient & Dark Sky Lighting

Arc EE............................62

Arc CF............................62

Balboa VX EE.................73

Beam EE........................65

Cambria EE....................81

Carriage House EE.........83

Cirrus EE.......................69

Coldwater EE.................79

Dover EE.......................86

Flush Mount EE............104

Knob Hill EE...................89

Lake Shore VX EE..........75

Luna EE.........................63

Madrona EE.................104

Morrow Bay EE..............91

Nantucket EE.................93

New Age LED.................59

Odessa EE.....................95

Optic LED......................61

Pacific Heights VX EE....77

Santa Barbara EE...........97

Scottsdale EE.................99

Side Door EE................100

Wakefield EE................101

Westlake EE.................103

Westport VX EE..............71

Whisper Dark Sky EE....105

Zenith EE.......................67

Finishes ...................... 108

Glass .......................... 108

Index ...........................106

Replacement Bulbs ..... 110

Warranty ..................... 110

Energy Efficient Flush Mounts

Low Profile EE................25

........26

Rim EE...........................21

Utility EE........................23

Wrap Around EE.............27

Low Profile Plus EE

Linda EE........................13

Malibu EE........................7

Blocks EE......................19

Classic EE.....................24

Cloud EE........................28

Flair EE..........................22

Energy Saving Flush Mounts...20

Maxim Lighting's newly designed Web Site is your resource for detailed product

information, including specification data, spec sheets, and high resolution images with

detailed zoom features. Visit www.maximlighting.com today!

Installs

Up or Down

Installs on

Slope Ceiling

Catalog Legend

Energy Star

Certified

California

Title 24

For over 40 years, Maxim Lighting has defined lifestyle lighting, offering a variety of high-quality, decorative fixtures for the home, including chande-

liers, sconces, pendants, ceiling mounts, and bath vanities. Design inspiration from around the world characterizes our collections from the traditional

to the unusual. Our exclusive products complement your distinct sense of style and add a touch of flair to every setting. Whether it's an elegant

chandelier to complete your dining room or a set of beautiful pendants to enhance your kitchen, you're certain to discover just the right product at

Maxim Lighting.

ADA Compliant

Includes

Photocell

maximlighting.com

Table of Contents alphabetically

Arc EE.................................................62

Arc CF.................................................62

Aurora EE.............................................5

Balboa VX EE......................................73

Basix EE...............................................9

Beam EE.............................................65

Blocks EE...........................................19

Cambria EE.........................................81

Carriage House EE..............................83

Cirrus EE.............................................69

Classic EE..........................................24

Cloud EE.............................................28

Coldwater EE......................................79

CounterMax........................................30

Dover EE.............................................86

Energy Saving Flush Mounts................20

Essentials EE......................................17

Flair EE..............................................22

Flush Mount EE.................................104

Knob Hill EE........................................89

Lake Shore VX EE...............................75

Linda EE..............................................13

Low Profile EE.....................................25

Low Profile Plus EE............................26

Luna EE..............................................63

Madrona EE......................................104

Malibu EE..............................................7

Morrow Bay EE....................................91

Nantucket EE......................................93

New Age LED......................................59

Odessa EE..........................................95

Optic LED............................................61

Pacific Heights VX EE..........................77

Rim EE................................................21

Santa Barbara EE................................97

Scottsdale EE......................................99

Side Door EE.....................................100

StarStrand.........................................33

Utility EE...........................................23

Wakefield EE.....................................101

Westlake EE......................................103

Westport VX EE...................................71

Whisper Dark Sky EE.........................105

Wrap Around EE..................................27

Zenith EE............................................67

Energy Efficient Indoor Collections

Those committed to ,

preserving the world s natural

resources appreciate Maxim s

contemporary line of energy

efficient lighting. Designed

with conservation in mind,

the Indoor Energy Efficient

Lighting collections blend

visionary ideals with practical

action. Through efficient bulbs

that minimize watt usage

and innovative designs that

optimize utilization, Maxim

allows homeowners to go

green without sacrificing style.

800.486.2946

maximlighting.com

83095FTSN 5-Light Chandelier

4500 Rated Lumens

Satin Nickel

26"W x 23.5"H

5 x 13w GU24 Bulbs (Included)

Aurora EE

Self-Ballasted GU24 Bulb

2700 K C olor T emperature

10,000 Rated Life Hours

maximlighting.com

Straight lines and curves make the energy efficient contemporary

Aurora EE collection a classic. Square metal tubing finished in

Satin Nickel support tapered square Frost glass shades.

Fixtures include energy efficient, long lasting and low

maintenance compact fluorescent bulbs.

Aurora EE Collection maximlighting.com

83102FTSN 1-Light Mini Pendant

900 Rated Lumens

Additional stems available:

6" order STR06206SN

12" order STR06212SN

One 6"stem and three 12"

stems included.

Satin Nickel

8"W

1 x 13w GU24 Bulbs (Included)

800.486.2946

83099FTSN 2-Light Wall Sconce

1800 Rated Lumens

Satin Nickel

13.5"W x 7"H x 8.5"Ext.

2 x 13w GU24 Bulbs (Included)

83098FTSN 1-Light Wall Sconce

900 Rated Lumens

Satin Nickel

5.5"W x 10"H x 7"Ext.

1 x 13w GU24 Bulbs (Included)

83100FTSN 3-Light Wall Sconce

2700 Rated Lumens

Satin Nickel

21.5"W x 7"H x 8.5"Ext.

3 x 13w GU24 Bulbs (Included)

800.486.2946

maximlighting.com

Malibu EE

Self-Ballasted GU24 Bulb

2700 K C olor T emperature

10,000 Rated Life Hours

maximlighting.com

82699MRSN 5-Light Chandelier

4500 Rated Lumens

Satin Nickel

25"W x 16"H

5 x 13w GU24 Bulbs (Included)

82697 MROI, MRSN

3-Light Chandelier

2700 Rated Lumens

20"W x 15"H

3 x 13w GU24 Bulbs (Included) 82698 MROI, MRSN

5-Light Chandelier

4500 Rated Lumens

Satin Nickel

24"W x 17"H

5 x 13w GU24 Bulbs (Included)

The energy saving Malibu EE collection is finished

in choice of Satin Nickel or Oil Rubbed Bronze completed

with Marble glass. Fixtures include energy efficient,

long lasting and low maintenance compact fluorescent bulbs,

with select fixtures being Energy Star certified.

Malibu EE Collection maximlighting.com

800.486.2946

82689MRSN 4-Light Bath Vanity

3600 Rated Lumens

Satin Nickel

29"W x 6"H x 8"Ext.

4 x 13w GU24 Bulbs (Included)

82686MRSN 1-Light Wall Sconce

900 Rated Lumens

Satin Nickel

6"W x 6.5"H x 9"Ext.

1 x 13w GU24 Bulb (Included)

82681MRSN

3-Light Flush Mount

2700 Rated Lumens

Satin Nickel

16"W x 4"H

3 x 13w GU24 Bulbs (Included)

82687MRSN 2-Light Bath Vanity

1800 Rated Lumens

Satin Nickel

13.25"W x 6"H x 8"Ext.

2 x 13w GU24 Bulbs (Included)

82688MRSN 3-Light Bath Vanity

2700 Rated Lumens

Satin Nickel

19.5"W x 6"H x 8"Ext.

3 x 13w GU24 Bulbs (Included)

800.486.2946

maximlighting.com

85128 ICSN, WSOI 9-Light Chandelier

8100 Rated Lumens

32"W x 31.5"H

9 x 13w GU24 Bulbs (Included)

Basix EE

Self-Ballasted GU24 Bulb

2700 K C olor T emperature

10,000 Rated Life Hours

maximlighting.com

The contemporary Basix EE collection features

sweeping arms and clean lines. Basix EE is offered

in choice of Ice glass with Satin Nickel finish or Wilshire

glass with Oil Rubbed Bronze finish. Fixtures include

energy efficient, long lasting and low maintenance compact

fluorescent bulbs, with select fixtures being Energy Star certified.

maximlighting.com

Basix EE Collection

85125 ICSN, WSOI 5-Light Chandelier

4500 Rated Lumens

26"W x 22.5"H

5 x 13w GU24 Bulbs (Included)

800.486.2946 10

85122 ICSN,WSOI 3-Light Chandelier

2700 Rated Lumens

19"W x 18.5"H

3 x 13w GU24 Bulbs (Included)

85123 ICSN, WSOI

3-Light Chandelier

2700 Rated Lumens

19"W x 18.5"H

3 x 13w GU24 Bulbs (Included)

maximlighting.com

85120 ICSN, WSOI 2-Light Semi-Flush

1800 Rated Lumens

14"W x 10"H

2 x 13w GU24 Bulbs (Included)

Basix EE Collection

85121 ICSN, WSOI 3-Light Pendant

2700 Rated Lumens

17"W x 22.5"H

3 x 13w GU24 Bulbs (Included)

85139 ICSN, WSOI

1-Light Mini Pendant

900 Rated Lumens

Additional stems available:

6" order STR06206SN

12" order STR06212SN

One 6" stem and

three 12" stems included.

6.5"W

1 x 13w GU24 Bulb (Included)

maximlighting.com

Basix EE Collection

85131 ICSN, WSOI 1-Light Wall Sconce

900 Rated Lumens

6"W x 8"H X 9" Ext.

1 x 13w GU24 Bulb (Included)

85133 ICSN, WSOI 3-Light Bath Vanity

2700 Rated Lumens

19"W x 8"H X 9" Ext.

3 x 13w GU24 Bulbs (Included)

85134 ICSN, WSOI 4-Light Bath Vanity

3600 Rated Lumens

27.5"W x 8"H X 9" Ext.

4 x 13w GU24 Bulbs (Included)

85132 ICSN, WSOI 2-Light Bath Vanity

1800 Rated Lumens

13.5"W x 8"H X 9" Ext.

2 x13w GU24 Bulbs (Included)

800.486.2946 12

800.486.2946

maximlighting.com

Linda EE

85806WSOI 9-Light Chandelier

8100 Rated Lumens

Oil Rubbed Bronze

32.5"W x 34"H

9 x 13w GU24 Bulbs (Included)

Self-Ballasted GU24 Bulb

2700 K C olor T emperature

10,000 Rated Life Hours

maximlighting.com

Linda EE is a beautiful transitional energy

saving collection with long flowing arms.

The warm Wilshire glass perfectly complements

the Oil Rubbed Bronze finish. Fixtures include

energy efficient, long lasting and low maintenance

compact fluorescent bulbs, with select fixtures

being Energy Star certified.

maximlighting.com

Linda EE Collection

85800WSOI 2-Light Flush Mount

1800 Rated Lumens

Oil Rubbed Bronze

13"W x 7"H

2 x 13w GU24 Bulbs (Included)

85801WSOI 3-Light Flush Mount

2700 Rated Lumens

Oil Rubbed Bronze

16"W x 9"H

3 x 13w GU24 Bulbs (Included)

85805WSOI 5-Light Chandelier

4500 Rated Lumens

Oil Rubbed Bronze

26"W x 27"H

5 x 13w GU24 Bulbs (Included)

800.486.2946 14

maximlighting.com Linda EE Collection

85804WSOI 3-Light Chandelier

2700 Rated Lumens

Oil Rubbed Bronze

19"W x 21.5"H

3 x 13w Gu24 Bulbs (Included)

85803WSOI 4-Light Pendant

3600 Rated Lumens

Oil Rubbed Bronze

25"W x 31"H

4 x 13w GU24 Bulbs (Included)

85802WSOI 3-Light Semi-Flush

2700 Rated Lumens

Oil Rubbed Bronze

19"W x 16.5"H

3 x 13w GU24 Bulbs (Included)

maximlighting.com

Linda EE Collection

85808WSOI 2-Light Bath Vanity

1800 Rated Lumens

Oil Rubbed Bronze

14.5"W x 8.5"H x 9"Ext.

2 x 13w GU24 Bulbs (Included)

85810WSOI 4-Light Bath Vanity

3600 Rated Lumens

Oil Rubbed Bronze

32"W x 9"H x 8"Ext.

4 x 13w GU24 Bulbs (Included)

85004WSOI

1-Light Mini Pendant

900 Rated Lumens

Additional stems available:

6" order STR06206 OI

12" order STR06212 OI

Oil Rubbed Bronze

6"W

1 x 13w GU24 Bulb (Included)

85807WSOI 1-Light Wall Sconce

900 Rated Lumens

Oil Rubbed Bronze

6"W x 9.5"H x 7.5"Ext.

1 x 13w GU24 Bulb (Included)

85809WSOI 3-Light Bath Vanity

2700 Rated Lumens

Oil Rubbed Bronze

24"W x 9"H x 8"Ext.

3 x 13w GU24 Bulbs (Included)

800.486.2946 16

800.486.2946

maximlighting.com

Essentials EE

85814 MROI,MRSN 4-Light Bath Vanity

3600 Rated Lumens

30"W x 7"H x 8"Ext.

4 x 13w GU24 Bulbs (Included)

Self-Ballasted GU24 Bulb

2700 K C olor T emperature

10,000 Rated Life Hours

85813 MROI,MRSN 3-Light Bath Vanity

2700 Rated Lumens

24"W x 7"H x 8"Ext.

3 x 13w Gu24 Bulbs (Included)

85812 MROI,MRSN 2-Light Bath Vanity

1800 Rated Lumens

18"W x 7"H x 8"Ext.

2 x 13w GU24 Bulbs (Included)

Energy Efficient Flush Mounts

800.486.2946

maximlighting.com

Blocks EE

3000 K C olor T emperature

10,000 Rated Life Hours

Electronic NPF Ballast

The Blocks EE collection features steel bases finished

in Satin Nickel. The extra thick clear glass coated White

on the inside provides excellent light diffusion.

Blocks ES fixtures are fitted with high quality commercial

grade ballasts and quad compact fluorescents.

53131WTSN 2-Light Flush Mount

1560 Rated Lumens

Satin Nickel

9"W x 3"H

2 x 13w G24q-1 Quad T4 CFL Bulbs (Included)

53132WTSN 2-Light Flush Mount

2500 Rated Lumens

Satin Nickel

11"W x 3"H

2 x 18w G24q-2 Quad T4 CFL Bulbs (Included)

53135WTSN 2-Light Flush Mount

1560 Rated Lumens

Satin Nickel

7.5"W x 3"H

2 x 13w G24q-1 Quad T4 CFL Bulbs (Included)

53136WTSN 2-Light Flush Mount

2500 Rated Lumens

Satin Nickel

9"W x 3"H

2 x 18w G24q-2 Quad T4 CFL Bulbs (Included)

Energy Saving

Flush Mounts

Self-Ballasted GU24 Bulb

2700 K C olor T emperature

10,000 Rated Life Hours

800.486.2946 20

800.486.2946 maximlighting.com

85832 FTTW, FTPB

3-Light Flush Mount

2700 Rated Lumens

15.5"W x 6"H

3 x 13w GU24 Bulbs (Included)

85842 MROI,MRSN,WSOI

3-Light Flush Mount

2700 Rated Lumens

15.5"W x 6"H

3 x 13w GU24 Bulbs (Included)

85831FTTW 2-Light Flush Mount

1800 Rated Lumens

Textured White

13.5"W x 6"H

2 x 13w GU24 Bulbs (Included)

85841 MROI,MRSN,WSOI

2-Light Flush Mount

1800 Rated Lumens

13.5"W x 6"H

2 x 13w GU24 Bulbs (Included)

85840 MROI,MRSN,WSOI

1-Light Flush Mount

900 Rated Lumens

11.5"W x 6"H

1 x 13w GU24 Bulb (Included)

85830FTTW 1-Light Flush Mount

900 Rated Lumens

Textured White

11.5"W x 6"H

1 x 13w GU24 Bulb (Included)

85885 MROI,MRSN

2-Light Flush Mount

1800 Rated Lumens

9"W x 5"H

2 x 13w GU24 Bulbs (Included)

85843 MROI, MRSN,WSOI

2-Light Semi-Flush

1800 Rated Lumens

17"W x 14"H

2 x 13w GU24 Bulbs (Included)

800.486.2946

maximlighting.com

Rim EE

3100 K C olor T emperature

10,000 Rated Life Hours

Acrylic Lens

87212 OI,SN,WT

2-Light Flush Mount

4750 Rated Lumens

Electronic NPF Ballast

21"W x 3"H

1 x 32w T 9 Circline Bulb (Included)

1 x 40w T 9 Circline Bulb (Included)

87210 OI,SN,WT

1-Light Flush Mount

1050 Rated Lumens

Electronic HPF Ballast

13"W x 3"H

1 x 22w T 9 Circline Bulb (Included)

87211 OI,SN,WT

2-Light Flush Mount

3000 Rated Lumens

Electronic HPF Ballast

17"W x 3"H

1 x 22w T 9 Circline Bulb (Included)

1 x 32w T 9 Circline Bulb (Included)

87011 OI,SN

2-Light Flush Mount

4700 Rated Lumens

Electronic HPF Ballast

17"W x 3"H

1 x 22w T 5 Circline Bulb (Included)

1 x 32w T 5 Circline Bulb (Included)

87012WT 2-Light Flush Mount

6100 Rated Lumens

Electronic NPF Ballast

White

21"W x 3"H

1 x 32w T 5 Circline Bulb (Included)

1 x 40w T 5 Circline Bulb (Included)

Rim Plus EE

T-5 High Lumen Technology

3000 K C olor T emperature

10,000 Rated Life Hours

Acrylic Lens

800.486.2946

Flair EE

Electronic NPF Ballast

2700 K C olor T emperature

10,000 Rated Life Hours

800.486.2946

maximlighting.com

87950 MROI, MRSN

1-Light Flush Mount

900 Rated Lumens

12"W x 4"H

1 x 13w GU24 Bulb (Included)

87951 MROI, MRSN

2-Light Flush Mount

1800 Rated Lumens

14"W x 5"H

2 x 13w GU24 Bulbs (Included)

87952 MROI, MRSN

3-Light Flush Mount

2700 Rated Lumens

17"W x 5"H

3 x 13w GU24 Bulbs (Included)

800.486.2946

maximlighting.com

85880WTWT

1-Light Flush Mount

900 Rated Lumens

White

7.5"W x 4.5"H

1 x 13w GU24 Bulb (Included)

85889WTWT

1-Light Flush Mount

900 Rated Lumens

White

6"W x 7"H

1 x 13w GU24 Bulb (Included)

85881WTWT

2-Light Flush Mount

1800 Rated Lumens

White

9"W x 5"H

2 x 13w GU24 Bulbs (Included)

85585 MRWT, WTWT

1-Light Wall Sconce

900 Rated Lumens

10.5"W x 5.5"H x 4"Ext.

1 x 13w GU24 Bulb (Included)

Utility EE

Self-Ballasted GU24 Bulb

2700 K C olor T emperature

10,000 Rated Life Hours

85066 MROI, MRSN

1-Light Mini Pendant

900 Rated Lumens

One 6" Stem STR06206SN (Included)

Three 12" Stems STR06212SN (Included)

7"W

1 x 13w GU24 Bulb (Included)

800.486.2946

maximlighting.com

Classic EE

T-5 High Lumen Technology

3000 K C olor T emperature

10,000 Rated Life Hours

Acrylic Lens

800.486.2946

87015 SN, WT

1-Light Flush Mount

1800 Rated Lumens

Electronic HPF ballast

14"W x 4"H

1 x 22w T 5 Circline Bulb (Included)

87016SN 2-Light Flush Mount

4700 Rated Lumens

Electronic HPF ballast

Satin Nickel

17"W x 4"H

1 x 22w T 5 Circline Bulb (Included)

1 x 32w T 5 Circline Bulb (Included)

87017WT 2-Light Flush Mount

6100 Rated Lumens

Electronic NPF ballast

White

22.5"W x 4"H

1 x 32w T 5 Circline Bulb (Included)

1 x 40w T 5 Circline Bulb (Included)

800.486.2946

maximlighting.com

87205WT 1-Light Wall Sconce

1050 Rated Lumens

Electronic HPF Ballast

White

12"W x 2.5"H

1 x 22w T 9 Circline Bulb (Included)

87206WT 2-Light Wall Sconce

3000 Rated Lumens

Electronic HPF Ballast

White

14.5"W x 2.5"H

1 x 22w T 9 Circline Bulb (Included)

1 x 32w T 9 Circline Bulb (Included)

87207WT 2-Light Wall Sconce

4750 Rated Lumens

Electronic NPF Ballast

White

19.5"W x 2.5"H

1 x 32w T 9 Circline Bulb (Included)

1 x 40w T 9 Circline Bulb (Included)

Low Profile EE

87200WT 1-Light Flush Mount

1050 Rated Lumens

Electronic HPF Ballast

For residential use only

White

11.5"W x 2.5"H

1 x 22w T 9 Circline Bulb (Included)

87201WT 2-Light Flush Mount

3000 Rated Lumens

Electronic HPF Ballast

For residential use only

White

14"W x 2.5"H

1 x 22w T 9 Circline Bulb (Included)

1 x 32w T 9 Circline Bulb (Included)

87202WT 2-Light Flush Mount

4750 Rated Lumens

Electronic HPF Ballast

For residential use only

White

19"W x 2.5"H

1 x 32w T 9 Circline Bulb (Included)

1 x 40w T 9 Circline Bulb (Included)

Slim 2.5 Profile

3100 K C olor T emperature

10,000 Rated Life Hours

UV Rated Acrylic Lens

Ceiling or Wall Mountable

maximlighting.com

800.486.2946 maximlighting.com

87005WT 1-Light Wall Sconce

1800 Rated Lumens

Electronic HPF Ballast

White

12"W x 2.5"H

1 x 22w T 5 Circline Bulb (Included)

87006WT 2-Light Wall Sconce

4700 Rated Lumens

Electronic HPF Ballast

White

14.5"W x 2.5"H

1 x 22w T 5 Circline Bulb (Included)

1 x 32w T 5 Circline Bulb (Included)

87007WT 2-Light Wall Sconce

6100 Rated Lumens

Electronic NPF Ballast

White

19.5"W x 2.5"H

1 x 32w T 5 Circline Bulb (Included)

1 x 40w T 5 Circline Bulb (Included)

800.486.2946

Low Profile

Plus EE

T-5 High Lumen Technology

Slim 2.5 Profile

3000 K C olor T emperature

10,000 Rated Life Hours

UV Rated Acrylic Lens

Ceiling or Wall Mountable

800.486.2946 26

800.486.2946

maximlighting.com

Electronic Ballast

24,000 Rated Life Hours

Acrylic Lens

Bulbs Not Included

87522WT 4-Light Flush Mount

11200 Rated Lumens

White

48"L x 13"W x 2.5"H

4 x 32w T8 Bulbs

87521WT 2-Light Flush Mount

5600 Rated Lumens

White

48"L x 9"W x 2.5"H

2 x 32w T8 Bulbs

87520WT 2-Light Flush Mount

1400 Rated Lumens

White

24"L x 9"W x 2.5"H

2 x 17w T8 Bulbs

Wrap Around EE

800.486.2946

maximlighting.com

Cloud EE

Electronic Ballast

24,000 Rated Life Hours

Acrylic Lens

Bulbs Not Included

87531WT 4-Light Flush Mount

11200 Rated Lumens

White

48"L x 16"W x 6"H

4 x 32w T8 Bulbs

87530WT 2-Light Flush Mount

5600 Rated Lumens

White

48"L x 11"W x 5"H

2 x 32w T8 Bulbs

Counter, Task & Accent

Energy Efficient Lighting

Maxim Lighting's full line of

under cabinet and task lighting

cast the perfect light through-

out the home. In kitchens,

granite countertops sparkle

under the direct beam and

food preparation becomes

safer and more enjoyable.

In bathrooms and studies,

they brighten the room with a

warm indirect glow. They even

eliminate unwanted shadows

in wet bars, curio cabinets, and

bookcases with sleek profiles

that conceal so discreetly you

will never see the source of the

gentle light.

maximlighting.com

800.486.2946 maximlighting.com

This state-of-the-art LED light bar raises under cabinet lighting to

a whole new level. The crisp white light illuminates without shadows,

and its direct wire plug in and easy clip installation make it

convenient as well as beautiful.

Features

•

Uses 80% less power than incandescent

•

50,000 life hours

•

Cool to touch

•

Linkable up to 30 LEDs

•

Warm white 3000 K light

MX-

nder Cabinet

ighting

COUNTER

™

87906MB

Shown in Bronze

87904WT

Shown in White

87902SA

Shown in Satin Aluminum

Bronze

Black Accessories

White

White Accessories

Satin Aluminum

Black Accessories

10" LED Light Kit

87902WT White

87902SA Satin Aluminum

87902MB Bronze

9.75"L x 2"W x 1"H

2 x 1w

160 Rated Lumens

20" LED Light Kit

87904WT White

87904SA Satin Aluminum

87904MB Bronze

19.125"L x 2"W x 1"H

4 x 1w

320 Rated Lumens

30" LED Light Kit

87906WT White

87906SA Satin Aluminum

87906MB Bronze

28.5"L x 2"W x 1"H

6 x 1w

480 Rated Lumens

Includes

•

MX-L LED Under Cabinet Light

•

One 18"MXInterLink2 Connector Cord

•

One MXInterLink2 Coupler

•

One MXInterLink2 Direct Wire Box

•

Installation Hardware

MXInterLink2 Power Cord

87817WT White

87817BK Black

72"L

MXInterLink2 Connector Cord

18" 87819WT White

18" 87819BK Black

9"87818WT White

9"87818BK Black

MXInterLink2 Direct Wire Box

87803WT White

87803BK Black

4"W x 1"H x 2"L

MXInterLink2 Coupler

87820WT White

87820BK Black

2"W x .375"H x .5"L

MXInterLink2 Cord Coupler

87823WT White

87823BK Black

2.125"W x .375"H x .625"L

O P T I O N A L C O M P O N E N T S

800.486.2946

Silver

White Accessories

800.486.2946

maximlighting.com

Black

Black Accessories

White

White Accessories

maximlighting.com

MX-

iscsCOUNTER

™

Maxim LED discs mount easily under any cabinet

and can link up to 30 discs without additional

hardware. The energy efficient LED disc uses

only 1.7 watts, requires no additional driver, and

stays cool to the touch making it safer than both

halogen and xenon. The warm white color lasts

long and compliments any room.

Features

•

Easy to install

•

3.125 diameter x .875 height

•

1.7 watts per disc

•

Cool to the touch olycarbonate

housing

•

3500 K color temperature

•

Requires no additional driver

•

Expand up to 30 discs

MXInterLink2 Power Cord

87817WT White

87817BK Black

72"L

MXInterLink2 Connector Cord

18" 87819WT White

18" 87819BK Black

9"87818WT White

9"87818BK Black

MXInterLink2 Direct Wire Box

87803WT White

87803BK Black

4"W x 1"H x 2"L

MXInterLink2 Coupler

87820WT White

87820BK Black

2"W x .375"H x .5"L

MXInterLink2 Cord Coupler

87823WT White

87823BK Black

2.125"W x .375"H x .625"L

O P T I O N A L C O M P O N E N T S

1-Light Disc Add-On

87881WT White

87881SV Silver

87881BK Black

3.125"W x .875"H

24 x .07w

130 Rated Lumens

Includes One 18" MXInterLink2 Cord

and Installation Hardware

3-Light Disc Kit

87883WT White

87883SV Silver

87883BK Black

5.1w Total

390 Rated Lumens

Kit Includes:

> Three MX-LD LED Discs

> On/Off Switch

> Installation Hardware

> One 72" MXInterLink2 Power Cord

> Two 18" MXInterLink2 Cords

800.486.2946 maximlighting.com

800.486.2946 32

5”

12”

12" 1-Light Fluorescent

87805WT White

12"L x 5"W x 1.25"H

1 F8 T5 (Included)

400 Lumens | 7,500 Hours

5”

21”

21" 1-Light Fluorescent

87806WT White

21"L x 5"W x 1.25"H

1 F13 T5 (Included)

870 Lumens | 7,500 Hours

5”

24”

24" 1-Light Fluorescent

87807WT White

24"L x 5"W x 1.25"H

1 F16 T5 (Included)

1360 Lumens | 7,500 Hours

5”

43”

43" 1-Light Fluorescent

87809WT White

43"L x 5"W x 1.25"H

1 F26 T5 (Included)

2700 Lumens | 7,500 Hours

MX-F

irect

ire Fluorescent

ndercabinet

ighting

This direct wire collection of fluorescent under cabinet lights boasts

T-5 high lumen technology in sizes from 12" to 43" in length.

Full size knock outs allow for easy installation in any application.

Features

T-5 high lumen technology

3100 K color temperature

Full size knock outs

Long life fluorescent lamps

•

COUNTER

™

MX-

120

nder Cabinet

ighting

Bronze White

With a sleek profile and direct wiring, this state-of-the-art direct wire

unit installs easily under the cabinet and emits a crisp white light which

illuminates without shadows. The hinged top gives easy access for

installation and wiring. Cabinets stay cool and safe with LED light output.

Features

Warm white 3000 K light

Cool to touch

CRI 70-75, 120 beam spread

50,000 life hours

Multiple, full size knock outs

4-Way dimming switch, Hi/Med/Night Light/Off

Linkable with or without cord using MXInterLink3

•

7" 2-Light LED Direct Wire

87912WT White

87912MB

7"L x 5"W x 1.25"H

2 x 1w

Bronze

160 Rated Lumens

13" 4-Light LED Direct Wire

87913WT White

87913MB

12.875"L x 5"W x 1.25"H

4 x 1w

Bronze

320 Rated Lumens

21" 6-Light LED Direct Wire

87914WT White

87914MB

21"L x 5"W x 1.25"H

6 x 1w

Bronze

480 Rated Lumens

30" 8-Light LED Direct Wire

87916WT White

87916MB

30"L x 5"W x 1.25"Hz

8 x 1w

Bronze

640 Rated Lumens

MXInterLink3 Direct Wire Box

87850WT White

87850BK Black

5"W x 1"H x 2.25"

MXInterLink3 Power Cord

87860WT White

87860BK Black

72"L

MXInterLink3 Connector Cord

9"87856WT White

9"87856BK Black

24"87858WT White

24"87858BK Black

18" 87857WT White

18" 87857BK Black

800.486.2946

maximlighting.com

ltima

tar 24

Item Length Diodes Wattage Lumens CRIColor Temp PC Board Beam CurrentVoltage

53450

53451

53455

53452

53453

53454

20"

12"

60"

120"

240"

180

360

120

1.44

4.32

7.2

21.6

43.2

86.4

241

402

1206

2413

4825

3500 K

70-75

White

24V

60mA

180mA

300mA

900mA

1.8A

3.6A

120

Model Number Wattage Maximum Run Maximum Run Using 2 Output Cords

Cuttable

every 4 inches

0.11”

CUT LINE CUT LINE

0.492”

0.65”

4”

3500K 120

Distance Foot Candles

12in

24in

36in

48in

51.47

14.47

6.65

3.85

Shown using 1 foot section of Ultima Star 24

Features

•

Highest StarStrand lumen light output

•

Long runs up to 100 feet

•

Plastic covered to reduce static failure

•

Multiple lengths with soldered connectors for

trouble free installation

•

UL approved for damp locations

•

Highly flexible material that is backed with

3M adhesive tape for easy installation

•

Field cuttable every 4 inches

Applications

•

Office task lighting

•

Under cabinet lighting

•

Closets

•

Work areas

•

Display counters

•

Steps and railings

13'

17'

22'

32'

......

70'

100'

53311,53313,53318

53320

53286

53314

53287

53288

53289

60 Watts

75 Watts

96 Watts

100 Watts

150 Watts

320 Watts

480 Watts

50'

maximlighting.com

800.486.2946

Ultima Star 24

ltima

tar 24

6-Pin 90° Connector

53464

1.25"L x 1.25"W x .25"H

•

For 90°corners

•

Reversible for left or right

•

Includes 3M adhesive for easy mounting

6-Pin Silicone End Cap

53469

.75"L x .5"W x .1"H

•

Placed on run termination

•

Protects against dust and damage

•

Package of 10

(See page 56-57 for detailed driver information)

53311

53313

53318

53320

53286

24V 60w Class II Dimmable Driver

24V 60w Plug-In Driver

24V 60w Class II Driver

24V 75w Plug-In Driver

24V 96w Class II Driver

Drivers

6-Pin Connecting Cords

53465 5"L x .75"W x .25"H

53467 13"L x .75"W x .25"H

53468 73"L x .75"W x .25"H

•

Extend distance between Ultima Star 24,

24V Driver or 24V Dimming Controller

6-Pin Mounting Clip

53273

.5"L x .5"W x .25"H

•

Use on irregular surfaces when

adhesive backing is not sufficient

•

Package of 20

Recommended interval is every 12

Aluminum Channel

53373

60"L x .75"W x .75"H

•

Can be recessed or surface mount

•

Aluminum screws included

45° Angle Mounting Channel

53374

48"L x 1"W x .75"H

•

Surface mount to angle tape for

accent lighting

•

Aluminum screws included

Plastic Wire Clip

53255

1"L x .5"W x .25"H

•

Backed with 3M adhesive

•

Package of 10

Secures to surface connecting cords

and input/output cords of drivers and

controllers

53350

1.5"L x 1.5"W x .25"H

•

Creates a power block for branching

between Ultima Star 24, 24V Driver

or 24V Dimming Controller

•

Allows for L, T and X installations

of Ultima Star 24

•

Includes two 6-Pin Male End Caps

and one 6-Pin Male/Male Adapter

6-Pin 4-Way Connector

6-Pin Rough-In Terminal Block

53258

4"L x .75"W x .5"H

•

Female connector on one end with two wire

quick connector on opposite end

•

Rough in for new installation construction

between Ultima Star 24, 24V Driver or

24V Dimming Controller

Includes one 6-Pin Male/Male Adapter

and installation screw

24V Dimming Controller

53393

5"L x 2.5"W x 1"H

•

Full range dimming and on/off

•

RF remote included

•

4" 6-Pin power input cord, 72" 6-Pin signal

output cord

•

Compatible with drivers 53313, 53318,

53320 & 53386

Installs between 24V Driver

and Ultima Star 24

53314

53287

53288

53289

24V 100w Class II Dimmable Driver

24V 150w Driver

24V 320w Driver

24V 480w Driver

6-Pin Male/Male Adapter

53342

.5"L x .5"W x .25"H

•

Changes female end to male

•

Package of 6

6-Pin Male End Cap

53344

.5"L x .5"W x .25"H

•

Placed on female end of run termination

•

Protects against dust and damage

•

Package of 6

Flexible Aluminum Channel

53254

36"L x .5"W x .6"H

•

Creates valance to conceal tape

•

Irregular surfaces installation

•

Includes screws for installation

Heat Shrink Wrap

53256

3"L x 1"W x .25"H

•

Secure connections when in walls

Waterproof for damp locations

Heat gun required for installation

Package of 10

800.486.2946

maximlighting.com

Color Flex

tar 24

Features

•

Adjustable color temperature from 2900K to 5000K

•

Plastic covered to reduce static failure

•

Multiples lengths with soldered connectors

for trouble free installation

•

Suitable for damp locations

•

Highly flexible material that is backed with

3M tape for easy installation

Applications

•

Cove and toe kick accent lighting

•

Outdoor covered porch and patio

•

Under cabinet lighting

•

Display case

•

Restaurants and lounges

•

Bathroom lighting

Wattage Maximum Run

Model Number

60W

20'

53313

53318

Beam CurrentVoltage

120 24V

24V

40mA

120mA

600mA

1.2A

2.4A

120

CRIColor Temp PC Board

Lumens

15-16.5

45-50

225-250

450-500

900-1000

2900-5000 K

70-75

White

Item Length Diodes Wattage

53550

53551

53552

53553

53554

240"

12"

60"

120"

180

360

0.96

2.88

14.4

28.8

57.6

(See page 56 for detailed driver information)

53313

53318

24V 60w Plug-In Driver

24V 60w Class II Driver

Drivers

maximlighting.com

800.486.2946

Color Flex Star 24

Color Flex

tar 24

6-Pin Connecting Cords

53465 5"L x .75"W x .25"H

53467 13"L x .75"W x .25"H

53468 73"L x .75"W x .25"H

•

Extend distance between 24V Driver and

24V Color Flex Controller or 24V Amplifier

4-Pin Mounting Clip

53272 .5"L x .5"W x .25"H

•

Use on irregular surfaces when

adhesive backing is not sufficient

•

Package of 20

Recommended interval is every 12

Aluminum Channel

53373 60"L x .75"W x .75"H

•

Can be recessed or surface mount

•

Aluminum screws included

45° Angle Mounting Channel

53374 48"L x 1"W x .75"H

•

Surface mount to angle tape for

accent lighting

•

Aluminum screws included

Plastic Wire Clip

53255 1"L x .5"W x .25"H

•

Backed with 3M adhesive

•

Package of 10

Secures to surface connecting cords

and input/output cords of drivers and

controllers

53350 1.5"L x 1.5"W x .25"H

•

Creates a power block for branching

between 24V Driver and 24V Color Flex

Controller or 24V Amplifier

•

Includes two 6-Pin Male End Caps

and one 6-Pin Male/Male Adapter

6-Pin 4-Way Connector

Flexible Aluminum Channel

53254 36"L x .5"W x .6"H

•

Creates valance to conceal tape

•

Irregular surfaces installation

•

Includes screws for installation

Heat Shrink Wrap

53256 3"L x 1"W x .25"H

•

Secure connections when in walls

Waterproof for damp locations

Heat gun required for installation

Package of 10

4-Pin 4-Way Connector

53263 1.5"L x 1.5"W x .25"H

•

Allows for L, T and X installations

between 24V Color Flex Controller or

24V Amplifier and Color Flex Star 24

Includes two 4-Pin Male End Caps and

one 4-Pin Male/Male Adapter

4-Pin Connecting Cords

53265 3"L x .5"W x .25"H 53266 7"L x .5"W x .25"H

53267 13"L x .5"W x .25"H 53268 73"L x .5"W x .25"H

•

Extend distance between 24V Color Flex

Controller or 24V Amplifier and

Color Flex Star 24

Connect sections of Color Flex Star 24

together

24V Amplifier

53386 4"L x 2.5"W x .8"H

•

" 6-Pin power input cord, 6" 4-pin signal

input cord, 6" 4-pin signal output cord

Synchronizes additional runs up to 20' of

Color Flex Star 24 to one 24V Color Flex

Controller

Requires an additional 24V Driver

24V Color Flex Controller

53398 4"L x 4"W x 2"H

•

" 6-Pin power input cord,

72" 4-pin signal output cord

Required to control up to 20' of

Color Flex Star 24

RF remote control and wall controller

are included

Adjusts color temperature from

2900 K to 5500 K

4-Pin Rough-In Terminal Block

53383 4"L x .75"W x .5"H

•

Rough in for new installation construction

between 24V Color Flex Controller or 24V

Amplifier and Color Flex Star 24

Female connector on one end with four

wire quick connector on opposite end

Includes one 4-Pin Male/Male Adapter

and installation screw

6-Pin Rough-In Terminal Block

53258 4"L x .75"W x .5"H

•

24V Driver and 24V Color Flex

Controller or 24V Amplifier

•

Female connector on one end with two wire

quick connector on opposite end

•

Rough in for new installation construction

between

Includes one 6-Pin Male/Male Adapter

and installation screw

53262

Package of 10

.5"L x .5"W x .25"H

•

Changes female end of Color Flex

Star 24 to male end

4-Pin Male/Male Adapter

4-Pin Silicone End Cap

53269 .75"L x .5"W x .1"H

•

Placed on run termination

•

Protects against dust and damage

•

Package of 10

4-Pin Male End Cap

53264 .5"L x .5"W x .25"H

•

Placed on female end of run termination

•

Protects against dust and damage

•

Package of 10

800.486.2946

maximlighting.com

Item Length Diodes Wattage Lumens CRIColor Temp PC Board Beam CurrentVoltage

53430

53431

53432

53433

53434

12"

60"

120"

240"

180

360

120

0.96

2.88

14.4

28.8

57.6

153

767

1534

3068

3500 K

70-75

Black

24V

40mA

120mA

600mA

1.2A

2.4A

120

Applications

Cove and toe kick accent lighting

Outdoor covered porch and patio

Under cabinet lighting

Step lighting

Restaurants and lounges

Boats and RV

•

Features

High lumen light output

Long runs up to 150 feet

Plastic covered to reduce static failure

Multiple lengths with soldered connectors for

trouble free installation

L approved for damp locations

Highly flexible material that is backed with

3M adhesive tape for easy installation

Field cuttable every 4 inches

•

Cuttable

every 4 inches

0.11”

CUT LINE CUT LINE

0.492”

0.65”

4”

Model Number Wattage Maximum Run Maximum Run Using 2 Output Cords O

3500K 120

Distance Foot Candles

12in

24in

36in

48in

23.78

6.77

3.12

1.83

Shown using 1 foot section of Elite Star 24

20'

26'

33'

50'

......

105'

150'

53311,53313,53318

53320

53286

53314

53287

53288

53289

60 Watts

75 Watts

96 Watts

100 Watts

150 Watts

320 Watts

480 Watts

75'

Elite

tar 24

maximlighting.com

800.486.2946

Elite Star 24

Elite

tar 24

800.486.2946 38

6-Pin 90° Connector

53464

1.25"L x 1.25"W x .25"H

•

For 90°corners

•

Reversible for left or right

•

Includes 3M adhesive for easy mounting

6-Pin Silicone End Cap

53469

.75"L x .5"W x .1"H

•

Placed on run termination

•

Protects against dust and damage

•

Package of 10

(See page 56-57 for detailed driver information)

53311

53313

53318

53320

53286

24V 60w Class II Dimmable Driver

24V 60w Plug-In Driver

24V 60w Class II Driver

24V 75w Plug-In Driver

24V 96w Class II Driver

Drivers

6-Pin Connecting Cords

53465 5"L x .75"W x .25"H

53467 13"L x .75"W x .25"H

53468 73"L x .75"W x .25"H

•

Extend distance between Elite Star 24,

24V Driver or 24V Dimming Controller

6-Pin Mounting Clip

53273

.5"L x .5"W x .25"H

•

Use on irregular surfaces when

adhesive backing is not sufficient

•

Package of 20

Recommended interval is every 12

Aluminum Channel

53373

60"L x .75"W x .75"H

•

Can be recessed or surface mount

•

Aluminum screws included

45° Angle Mounting Channel

53374

48"L x 1"W x .75"H

•

Surface mount to angle tape for

accent lighting

•

Aluminum screws included

Plastic Wire Clip

53255

1"L x .5"W x .25"H

•

Backed with 3M adhesive

•

Package of 10

Secures to surface connecting cords

and input/output cords of drivers and

controllers

53350

1.5"L x 1.5"W x .25"H

•

Creates a power block for branching

between Elite Star 24, 24V Driver

or 24V Dimming Controller

•

Allows for L, T and X installations

of Elite Star 24

•

Includes two 6-Pin Male End Caps

and one 6-Pin Male/Male Adapter

6-Pin 4-Way Connector

6-Pin Rough-In Terminal Block

53258

4"L x .75"W x .5"H

•

Female connector on one end with two wire

quick connector on opposite end

•

Rough in for new installation construction

between Elite Star 24, 24V Driver or

24V Dimming Controller

Includes one 6-Pin Male/Male Adapter

and installation screw

24V Dimming Controller

53393

5"L x 2.5"W x 1"H

•

Full range dimming and on/off

•

RF remote included

•

4" 6-Pin power input cord, 72" 6-Pin signal

output cord

•

Compatible with drivers 53313, 53318,

53320 & 53386

Installs between 24V Driver

and Elite Star 24

53314

53287

53288

53289

24V 100w Class II Dimmable Driver

24V 150w Driver

24V 320w Driver

24V 480w Driver

6-Pin Male/Male Adapter

53342

.5"L x .5"W x .25"H

•

Changes female end to male

•

Package of 6

6-Pin Male End Cap

53344

.5"L x .5"W x .25"H

•

Placed on female end of run termination

•

Protects against dust and damage

•

Package of 6

Flexible Aluminum Channel

53254

36"L x .5"W x .6"H

•

Creates valance to conceal tape

•

Irregular surfaces installation

•

Includes screws for installation

Heat Shrink Wrap

53256

3"L x 1"W x .25"H

•

Secure connections when in walls

Waterproof for damp locations

Heat gun required for installation

Package of 10

800.486.2946

maximlighting.com

Item Length Diodes Wattage Lumens CRIColor Temp PC Board Beam CurrentVoltage

300"

120

3500 K

70-75

Black

24V

120

Aqua

tar 24

53441

53442

53443

53445

24"

60"

120"

180

450

5.76

14.4

28.8

428

1070

2140

5351

240mA

600mA

1.2A

Cuttable

every 4 inches

Top View

Side View

Cut Line

.416 Wide"

.22 High"

.65 Between LEDs"

4" Between Cut Lines

3500K 120

Distance Foot Candles

12in

24in

36in

48in

29.54

8.42

3.86

2.2

Shown using 1 foot section of Aqua Star 24

Model Number Wattage Maximum Run

21'

30'

50'

53380

53316

53381

60 Watts

100 Watts

150 Watts

Features

•

Waterproof IP68 LED tape

•

Chemical and UV resistant plastic cover

•

Long runs up to 50

•

Installs into aluminum channel or

plastic mouting clips

•

High lumen double chip LED

•

Multiple lengths with watertight

IP68 connectors

•

Field cuttable every 4 inches

Applications

•

Swimming pools and fountains

•

Outdoor decks

•

Step and stairs

•

Landscape lighting

•

Outdoor building accent lighting

•

Driveway and sidewalk illumination

maximlighting.com

800.486.2946

Aqua

tar 24

Aqua Star 24

Silicone End Cap Kit

53368

.75"L x .5"W x .1"H

•

Placed on run termination

•

Protects against water and damage

Mounting Clip

53370

.5"L x .5"W x .25"H

•

Use to secure Aqua Star 24 to surface

•

Stainless steel screws included

•

Clear polycarbonate plastic

•

Package of 6

24V Outdoor Connecting Cords

53364 48"L x .75"W

53365 144"L x .75"W

•

Extend distance between 24V

Weatherproof Driver and Aqua Star 24

•

Extend distance between two sections

of Aqua Star 24

•

IP68 rated for underwater application

up to 10'

(See page 56 for detailed driver information)

53380

53316

53381

Drivers

24V 60w Weatherproof Class II Driver

24V 100w Weatherproof Class II Dimmable Driver

24V 150w Weatherproof Class II Driver

Aluminum Channel

53373

60"L x .75"W x .75”H

•

Can be recessed or surface mount

•

Aluminum screws included

45° Angle Mounting Channel

53374

48"L x 1"W x .75”H

•

Surface mount to angle tape for

accent lighting

•

Aluminum screws included

800.486.2946

maximlighting.com

Item Length Diodes Wattage Lumens PC Board Beam CurrentVoltage

53530

53531

53533

53534

12"

60"

120"

240"

180

360

120

1.44

4.32

21.6

43.2

86.4

White

24V

60mA

180mA

900mA

1.8A

3.6A

120

ainbow

tar 24

Cuttable

every 4 inches

CUT LINECUT LINE

0.394”

0.65”

0.11”

4”

53535

Features

Thousands of colors on one tape

Long runs up to 30 feet

DMX interface with optional controller

Plastic covered to reduce static failure

ETL approved for damp locations

Multiple lengths with soldered connectors for

trouble free installation

Field cuttable every 4 inches

•

Applications

Cove and toe kick accent lighting

Restaurants, bars and lounges

Store front displays

Back lighting of glass and acrylic panels

Game and theatre rooms

Discos and clubs

•

R:18 G:30 B:9

R:54 G:90 B:27

R:270 G:450 B:135

R:540 G:900 B:270

R:1080 G:1800 B:540

Model Number Wattage Maximum Run

53313,53318

53320

53286

53287

60 Watts

75 Watts

96 Watts

150 Watts

13'

17'

30'

22'

(See page 56 for detailed driver information)

Drivers

53313

53318

53320

53286

53287

24V 60w Plug-In Driver

24V 60w Class II Driver

24V 75w Plug-In Driver

24V 96w Class II Driver

24V 150w Driver

maximlighting.com

800.486.2946

ainbow

tar 24

Rainbow Star 24

6-Pin Connecting Cords

53465 5"L x .75"W x .25"H

53467 13"L x .75"W x .25"H

53468 73"L x .75"W x .25"H

•

Extend distance between 24V Driver and

24V RGB Controller or 24V Amplifier

4-Pin Mounting Clip

53272 .5"L x .5"W x .25"H

•

Use on irregular surfaces when

adhesive backing is not sufficient

•

Package of 20

Recommended interval is every 12

Aluminum Channel

53373 60"L x .75"W x .75"H

•

Can be recessed or surface mount

•

Aluminum screws included

45° Angle Mounting Channel

53374 48"L x 1"W x .75"H

•

Surface mount to angle tape for

accent lighting

•

Aluminum screws included

Plastic Wire Clip

53255 1"L x .5"W x .25"H

•

Backed with 3M adhesive

•

Package of 10

Secures to surface connecting cords

and input/output cords of drivers and

controllers

53350 1.5"L x 1.5"W x .25"H

•

Creates a power block for branching

between 24V Driver and 24V RGB

Controller or 24V Amplifier

•

Includes two 6-Pin Male End Caps

and one 6-Pin Male/Male Adapter

6-Pin 4-Way Connector

Flexible Aluminum Channel

53254 36"L x .5"W x .6"H

•

Creates valance to conceal tape

•

Irregular surfaces installation

•

Includes screws for installation

Heat Shrink Wrap

53256 3"L x 1"W x .25"H

•

Secure connections when in walls

Waterproof for damp locations

Heat gun required for installation

Package of 10

4-Pin 4-Way Connector

53263 1.5"L x 1.5"W x .25"H

•

Allows for L, T and X installations

between 24V RGB Controller or

24V Amplifier and Rainbow Star 24

Includes two 4-Pin Male End Caps and

one 4-Pin Male/Male Adapter

4-Pin Connecting Cords

53265 3"L x .5"W x .25"H 53266 7"L x .5"W x .25"H

53267 13"L x .5"W x .25"H 53268 73"L x .5"W x .25"H

•

Extend distance between 24V RGB

Controller or 24V Amplifier and

Rainbow Star 24

Connect sections of Rainbow Star 24

together

24V Amplifier

53386 4"L x 2.5"W x .8"H

•

" 6-Pin power input cord, 6" 4-pin signal

input cord, 6" 4-pin signal output cord

•

Synchronizes additional runs up to 30' of

Rainbow Star 24 to one 24V RGB Controller

Requires an additional 24V Driver

Maximum 27 amplifiers per conrtoller

4-Pin Rough-In Terminal Block

53383 4"L x .75"W x .5"H

•

Rough in for new installation construction

between 24V RGB Controller or 24V

Amplifier and Rainbow Star 24

Female connector on one end with four

wire quick connector on opposite end

Includes one 4-Pin Male/Male Adapter

and installation screw

6-Pin Rough-In Terminal Block

53258 4"L x .75"W x .5"H

•

24V Driver and 24V RGB

Controller or 24V Amplifier

•

Female connector on one end with two wire

quick connector on opposite end

•

Rough in for new installation construction

between

Includes one 6-Pin Male/Male Adapter

and installation screw

53262

Package of 10

.5"L x .5"W x .25"H

•

Changes female end of Rainbow

Star 24 to male end

4-Pin Male/Male Adapter

4-Pin Silicone End Cap

53269 .75"L x .5"W x .1"H

•

Placed on run termination

•

Protects against dust and damage

•

Package of 10

4-Pin Male End Cap

53264 .5"L x .5"W x .25"H

•

Placed on female end of run termination

•

Protects against dust and damage

•

Package of 10

24V RGB Controller

53385 6"L x 2.5"W x 1"H

•

Controls up to 30' of Rainbow

Star 24 using included RF remote control

•

4" 6-Pin power input cord,

72" 4-Pin signal output cord

24V DMX512 Interface/Decoder & Standalone RGB Controller

53387 7.5"L x 4.5"W x 1.5"H

•

Controls up to 30' of Rainbow

Star 24 using included RF remote control

•

Meets DMX512 protocol and can be used

as a DMX decoder

•

4" 6-Pin power input cord,

72" 4-Pin signal output cord

800.486.2946

maximlighting.com

ainbow Aqua

tar 24

Item Length Diodes Wattage Lumens PC Board Beam CurrentVoltage

53541

53542

53543

53545

120

White

24V

360mA

900mA

1.8A

4.5A

120

24"

60"

120"

300"

180

450

8.64

21.6

43.2

108

CUT LINE CUT LINE

Cuttable

every 4 inches

4”4”4”

0.65”

0.25”

0.5”

Features

•

Waterproof IP68 color changing LED tape

•

Nine modes of color and movement

•

Chemical and UV resistant plastic cover

•

Long runs up to 30 feet

•

Installs into aluminum channel or

plastic mouting clips

•

Multiple lengths with watertight IP68 connectors

•

Field cuttable every 4 inches

Applications

•

Swimming pools and fountains

•

Outdoor living areas

•

Landscape lighting

•

Outdoor architectural features

•

Signs

•

Outdoor walkwaysz

R:108 G:180 B:54

R:270 G:450 B:135

R:540 G:900 B:270

R:1350 G:2250 B:675

Model Number Wattage Maximum Run

13'

30'

53380

53381

60 Watts

150 Watts

maximlighting.com

800.486.2946

ainbow Aqua

tar 24

Rainbow Aqua Star 24

53390

•

Synchronizes additional runs up to

30' of Rainbow Aqua Star 24 to one

24V Weatherproof RGB Controller

•

IP65 rated (not submersible)

•

Requires an additional 24V Driver

4"L x 2.5"W x 1"H

•

Maximum 27 amplifiers per controller

•

6" power input cord,

6" signal input cord,

6" signal output cord

24V Weatherproof Amplifier

53389

•

Required to control up to 30' of

Rainbow Aqua Star 24

•

IP65 rated (not submersible)

•

RF remote control included

5"L x 2.5"W x 1"H

•

4" power input cord,

72" signal output cord

24V Weatherproof RGB Controller

(See page 56 for detailed driver information)

53380

53381

Drivers

24V 60w Weatherproof Class II Driver

24V 150w Weatherproof Class II Driver

Silicone End Cap Kit

53368

.75"L x .5"W x .1"H

•

Placed on run termination

•

Protects against water and damage

Mounting Clip

53370

.5"L x .5"W x .25"H

•

Use to secure Rainbow Aqua Star 24

to surface

•

Stainless steel screws included

•

Clear polycarbonate plastic

•

Package of 6

24V Outdoor Connecting Cords

53364 48"L x .75"W

53365 144"L x .75"W

•

Extend distance between 24V

Weatherproof Driver and

Rainbow Aqua Star 24

•

Extend distance between two sections

of Rainbow Aqua Star 24

•

IP68 rated for underwater application

up to 10'

Aluminum Channel

53373

60"L x .75"W x .75"H

•

Can be recessed or surface mount

•

Aluminum screws included

45° Angle Mounting Channel

53374

48"L x 1"W x .75"H

•

Surface mount to angle tape for

accent lighting

•

Aluminum screws included

800.486.2946

maximlighting.com

Channel

tar 24

Item Color Temp Beam CurrentVoltage

120

CRI

120

120mA

180mA

360mA

540mA

720mA

120mA

180mA

360mA

540mA

720mA

53700 AL, BRZ

53701 AL, BRZ

53702 AL, BRZ

53703 AL, BRZ

53704 AL, BRZ

53710 AL, BRZ

53712 AL, BRZ

53713 AL, BRZ

53714 AL, BRZ

Length Diodes Wattage Lumens

12"

24"

36"

48"

12"

24"

36"

48"

2.88

4.32

8.64

12.96

17.28

2.88

4.32

8.64

12.96

17.28

139

279

418

558

104

207

415

622

830

3500 K

5000 K

70 - 75

24V

53711 AL, BRZ

Features

•

High lumen output

•

Available in both Bronze and Aluminum finish

•

Clear lens for maximum light output

•

Rigid aluminum channel conceals light source

and provides excellent heat dissipation

•

Connect end to end or with the use of

connecting cables

•

Available in 3500 K or 5000 K

•

Includes easy to install mounting clips,

both downward and 45 angle

Applications

•

Under cabinets and bars

•

Office desk task lighting

•

Retail display cabinets and counters

•

Window displays

•

Closet lighting

5000K 120

3500K 120

Distance Foot CandlesDistance Foot Candles

12in12in

24in24in

36in36in

48in48in

63.5943.77

17.9612.01

8.275.16

4.673.16

Shown using 1 foot section of Channel Star 24Shown using 1 foot section of Channel Star 24

Wattage Maximum RunModel Number

13'

17'

22'

32'

53311,53313,53318

53320

53286

53314

53287

60 Watts

75 Watts

96 Watts

100 Watts

150 Watts

maximlighting.com

800.486.2946

Channel

tar 24

Channel Star 24

4 Pin to 6 Pin Adapter Cord

53352 6"L x 1"W x .5"H

•

6-Pin female to 4-Pin male

•

Included in every 24", 36" and 48" section

of Channel Star 24

4-Pin to 6-Pin Adapter Cord with On/Off Switch

53353 6"L x 1"W x .5"H

•

6-Pin female to 4-Pin male

•

Used to turn Channel Star 24 on and off

when not controlled by a 24V Dimming

Controller or by a wall switch

4-Pin Rough-In Terminal Block

53257 4"L x .75"W x .5"H

•

Female connector on one end with four wire

quick connector on opposite end

•

Rough in for new installation construction

between 24V Driver or 24V Dimming

Controller and Channel Star 24

Includes one 4-Pin Male/Male Adapter

and installation screw

Mounting Clips

53354 1"L x 1"W x .5"H

•

Additional clips for mounting

Channel Star 24 to surface

•

Package of 4

45° Angle Mounting Clips

53355 1"L x 1"W x .75"H

•

Additional clips for mounting

Channel Star 24 to surface at 45

•

Package of 4

° angle

(See page 56-57 for detailed driver information)

Drivers

53311

53313

53318

53320

24V 60w Class II Dimmable Driver

24V 60w Plug-In Driver

24V 60w Class II Driver

24V 75w Plug-In Driver

53286

53314

53287

24V 96w Class II Driver

24V 100w Class II Dimmable Driver

24V 150w Driver

Plastic Wire Clip

53255 1"L x .5"W x .25"H

•

Backed with 3M adhesive

•

Package of 10

Secures to surface connecting cords

and input/output cords of drivers,

controllers and amplifiers

53350 1.5"L x 1.5"W x .25"H

•

Creates a power block for branching

between 24V Driver and

24V Dimming Controller

•

Includes two 6-Pin Male End Caps

and one 6-Pin Male/Male Adapter

6-Pin 4-Way Connector

6-Pin Rough-In Terminal Block

53258 4"L x .75"W x .5"H

•

Female connector on one end with two wire

quick connector on opposite end

•

Rough in for new installation construction

between 24V Driver and

24V Dimming Controller

Includes one 6-Pin Male/Male Adapter

and installation screw

24V Dimming Controller

53393 4"L x 2.5"W x .8"H

•

Full range dimming and on/off

•

RF remote included

•

4" 6-Pin power input cord, 72" 6-Pin signal

output cord

•

Compatible with drivers 53313, 53318,

53320 & 53386

Installs between 24V Driver

and Channel Star 24

6-Pin Connecting Cords

53465 5"L x .75"W x .25"H

53467 13"L x .75"W x .25"H

53468 73"L x .75"W x .25"H

•

Extend distance between 24V Driver, 24V

Dimming Controller and Channel Star 24

4-Pin Connecting Cords

53265 3"L x .5"W x .25"H 53266 7"L x .5"W x .25"H

53267 13"L x .5"W x .25"H 53268 73"L x .5"W x .25"H

•

Connect sections of Channel Star 24

together

Heat Shrink Wrap

53256 3"L x 1"W x .25"H

•

Secure connections when in walls

Waterproof for damp locations

Heat gun required for installation

Package of 10

4-Pin 4-Way Connector

53263 1.5"L x 1.5"W x .25"H

•

Allows for L, T and X installations

between 24V Dimming Controller and

Channel Star 24 with connecting cords

Includes two 4-Pin Male End Caps and

one 4-Pin Male/Male Adapter

800.486.2946

maximlighting.com

ainbow Channel

tar 24

0.98"

0.9"

0.58"

Features

Available in Aluminum finish only

Clear lens for maximum light output

Rigid aluminum channel conceals light

source and provides excellent heat dissipation

Connect end to end or with the use

of connecting cables

Thousands of color combinations available

Includes easy to install mounting clips,

both downward and 45 angle

•

Applications

Under cabinets and bars

Alcove lighting

Retail display cabinets and counters

Window displays

Sign illumination

•

Model Number Wattage Maximum Run

53313,53318

53320

53286

53287

13'

17'

30'

60 Watts

75 Watts

96 Watts

150 Watts

22'

Lumens Beam Voltage

120 24V

24V

120

53720AL

53721AL

53722AL

53723AL

53724AL

12"

24"

36"

48"

Item Length

2.88

4.32

8.64

12.96

17.28

Diodes Wattage

80mA

180mA

360mA

540mA

720mA

Current

R:30 G:50 B:15

R:54 G:90 B:27

R:108 G:180 B:30

R:162 G:270 B:45

R:216 G:360 B:60

(See page 56-57 for detailed driver information)

Drivers

53313

53318

53320

24V 60w Plug-In Driver

24V 60w Class II Driver

24V 75w Plug-In Driver

53286

53287

24V 96w Class II Driver

24V 150w Driver

maximlighting.com

800.486.2946

ainbow Channel

tar 24

Rainbow Channel Star 24

Mounting Clips

53354

1"L x 1"W x .5"H

•

Additional clips for mounting Rainbow

Channel Star 24 to surface

•

Package of 4

45° Angle Mounting Clips

53355

1"L x 1"W x .75"H

•

Additional clips for mounting Rainbow

Channel Star 24 to surface at 45

•

Package of 4

° angle

53350

1.5"L x 1.5"W x .25"H

•

Creates a power block for branching

between 24V Driver and 24V RGB

Controller or 24V amplifier

•

Includes two 6-Pin Male End Caps

and one 6-Pin Male/Male Adapter

6-Pin 4-Way Connector

6-Pin Connecting Cords

53465 5"L x .75"W x .25"H

53467 13"L x .75"W x .25"H

53468 73"L x .75"W x .25"H

•

24V Driver and

24V RGB Controller or 24V amplifier

Extend distance between

Heat Shrink Wrap

53256

3"L x 1"W x .25"H

•

Secure connections when in walls

Waterproof for damp locations

Heat gun required for installation

Package of 10

4-Pin Connecting Cords

53265 3"L x .5"W x .25"H 53266 7"L x .5"W x .25"H

53267 13"L x .5"W x .25"H 53268 73"L x .5"W x .25"H

•

Extend distance between 24V RGB

controller or 24V amplifier and

Rainbow Channel Star 24

Connect sections of Rainbow

Channel Star 24 together

4-Pin 4-Way Connector

53263

1.5"L x 1.5"W x .25"H

•

Allows for L, T and X installations

between 24V RGB Controller or 24V

amplifier and Rainbow Channel Star

24 with connecting cords

Includes two 4-Pin Male End Caps and

one 4-Pin Male/Male Adapter

Plastic Wire Clip

53255

1"L x .5"W x .25"H

•

Backed with 3M adhesive

•

Package of 10

Secures to surface connecting cords

and input/output cords of drivers,

controllers and amplifiers

24V RGB Controller

53385

4"L x 2.5"W x .8"H

•

Controls up to 30' of Rainbow channel

Star 24 using included RF remote control

•

4" 6-Pin power input cord,

72" 4-Pin signal output cord

24V Amplifier

53386

4"L x 2.5"W x .8"H

•

" 6-Pin power input cord, 6" 4-pin signal

input cord, 6" 4-pin signal output cord

•

Synchronizes additional runs up to 30' of

Rainbow channel Star 24 to

one 24V RGB Controller

Requires an additional 24V Driver

Maximum 27 amplifiers per conrtoller

24V DMX512 Interface/Decoder & Standalone RGB Controller

53387

7.5"L x 4.5"W x 1.5"H

•

Controls up to 30' of Rainbow channel

Star 24 using included RF remote control

•

Meets DMX512 protocol and can be used

as a DMX decoder

•

4" 6-Pin power input cord,

72" 4-Pin signal output cord

6-Pin Rough-In Terminal Block

53258

4"L x .75"W x .5"H

•

24V Driver and 24V RGB

Controller or 24V amplifier

•

Female connector on one end with two wire

quick connector on opposite end

•

Rough in for new installation construction

between

Includes one 6-Pin Male/Male Adapter

and installation screw

4-Pin Rough-In Terminal Block

53383

4"L x .75"W x .5"H

•

Rough in for new installation construction

between 24V RGB Controller or 24V

Amplifier and Rainbow Channel Star 24

Female connector on one end with four

wire quick connector on opposite end

Includes one 4-Pin Male/Male Adapter

and installation screw

800.486.2946

maximlighting.com

Shown using 1 foot section of Basic Star

Basic

tar

Item Length Diodes Wattage Lumens CRIColor Temp PC Board Beam CurrentVoltage

53201 196" 300 120

24 2757 3500 K 70-75 Copper 12V 2A

Cuttable

every 2 inches

Cut Line

Top View

Side View

.38" Wide

.09" High

.65" Between LEDs

2" Between Cut Lines

Features

•

Low power consumption only

1.4 watts per foot

•

Warm 3500 K color

•

Highly flexible material that is backed with

3M adhesive tape for easy installation

•

No heat and no UV radiation

•

Supplied in 16' 4" continuous lengths and

can be field cut every 2", and reconnected as

necessary using specified accessories

•

Soldered connectors supplied on each end

•

Additional two power feeds

and one splicer supplied.

Applications

•

Cove and toe kick accent lighting

•

Cabinet lighting

•

Architectural features

•

Point of purchase displays

•

Backlighting of signs and displays

•

Wine cellars

•

Closets

Model Number Wattage Maximum Run

20'

33'

53302

53275,53304,53310

30 Watts

60 Watts

3500K 120

Distance Foot Candles

12in

24in

36in

48in

16.55

4.61

2.06

1.21

maximlighting.com

Basic

tar

Basic Star

(See page 55 for detailed driver information)

Drivers

53302

53275

53304

53310

12V 30w Class II Driver

12V 60w Class II Plug-In Driver

12V 60w Class II Driver

12V 60w Class II Dimmable Driver

Flexible Connector

53259

3"L x 1"W x .25"H

•

Use for corners and angles

•

Package of 6

Tape Splicer

53261

1"L x .5"W x .25"H

•

Joins two sections if tape is cut

•

One included with Basic Star

•

Package of 10

End Power Feed

53260

3"L x 1"W x .25"H

•

Required if tape is cut

•

Two included with Basic Star

•

Package of 6

800.486.2946

4-Pin Rough-In Terminal Block

53257

4"L x .75"W x .5"H

•

Female connector on one end with four wire

quick connector on opposite end

•

Rough in for new installation construction

between 12V Driver and Basic Star

Includes one 4-Pin Male/Male Adapter

and installation screw

Plastic Wire Clip

53255

1"L x .5"W x .25"H

•

Backed with 3M adhesive

•

Package of 10

Secures to surface connecting cords

and input/output cords of drivers,

controllers and amplifiers

Heat Shrink Wrap

53256

3"L x 1"W x .25"H

•

Secure connections when in walls

Waterproof for damp locations

Heat gun required for installation

Package of 10

4-Pin 4-Way Connector

53263

1.5"L x 1.5"W x .25"H

•

Allows for L, T and X installations

between 12V Driver and Basic Star

Creates a power block for branching

between 12V Drivers and Basic Star

Includes two 4-Pin Male End Caps and

one 4-Pin Male/Male Adapter

Aluminum Channel

53373

60"L x .75"W x .75"H

•

Can be recessed or surface mount

•

Aluminum screws included

45° Angle Mounting Channel

53374

48"L x 1"W x .75"H

•

Surface mount to angle tape for

accent lighting

•

Aluminum screws included

53262

Package of 10

.5"L x .5"W x .25"H

•

Changes female end of Basic

Star to male end

4-Pin Male/Male Adapter

4-Pin Silicone End Cap

53269

.75"L x .5"W x .1"H

•

Placed on run termination

•

Protects against dust and damage

•

Package of 10

4-Pin Connecting Cords

53265 3"L x .5"W x .25"H 53266 7"L x .5"W x .25"H

53267 13"L x .5"W x .25"H 53268 73"L x .5"W x .25"H

•

Extend distance between 12V Driver

and Basic Star

Connect sections of Basic Star together

Flexible Aluminum Channel

53254

36"L x .5"W x .6"H

•

Creates valance to conceal tape

•

Irregular surfaces installation

•

Includes screws for installation

800.486.2946

maximlighting.com

uper

tar

Cuttable

every 2 inches

Features

•

Laminated LED tape system

•

No exposed circuit board

•

Easy to install with multiple lengths to choose from

•

Warm color temperature enhances room interiors

•

Perfect for accent lighting in alcoves, toe-kick, and under counter

•

Flexible design that forms to contours

•

Safe and economical to operate

•

Long life LED average 50,000 hours life

•

Tested to UL standards for both US and Canada

maximlighting.com

Item Length Diodes Wattage Lumens CRIColor Temp PC Board Beam CurrentVoltage

53210

53211

53212

53213

53214

60"

12"

120"

240"

180

360

120

0.48

2.88

14.4

28.8

57.6

355

710

1420

3500 K

70-75

Black

12V

40mA

120mA

1.2A

2.4A

4.8A

120

3500K 120

Distance Foot Candles

12in

24in

36in

48in

40.41

12.16

6.33

3.84

Shown using 1 foot section of Super Star

Model Number Wattage Maximum Run

10'

21'

53302

53275, 53304, 53310

30 Watts

60 Watts

.38" Wide

.09" High

Top View

Side View

Cut Line

2" Between Cut Lines

.65" Between LEDs

With over twice the lumen output of the basic tape, and the aded benefit of it being covered in

a pliable clear plastic, StarStrand Super Star, with StarChip technology, excels in

performance and durability. The plastic cover keeps dust and dirt from landing directly on the

board and makes keeping it clean easy. Super Star is available in pre-manufactured lengths

with 4 pin connectors installed at each end for fast and sure installation. The minimum single

run for Super Star is 1', and the maximum run is 50'.

The black PC board is backed with 3M adhesive tape for easy installation.

TM TM

maximlighting.com

uper

tar

Super Star

(See page 55 for detailed driver information)

Drivers

53302

53275

53304

53310

12V 30w Class II Driver

12V 60w Class II Plug-In Driver

12V 60w Class II Driver

12V 60w Class II Dimmable Driver

800.486.2946

4-Pin Rough-In Terminal Block

53257

4"L x .75"W x .5"H

•

Female connector on one end with four wire

quick connector on opposite end

•

Rough in for new installation construction

between 12V Driver and Super Star

Includes one 4-Pin Male/Male Adapter

and installation screw

Plastic Wire Clip

Heat Shrink Wrap

53256

3"L x 1"W x .25"H

•

Secure connections when in walls

Waterproof for damp locations

Heat gun required for installation

Package of 10

4-Pin 4-Way Connector

53263

1.5"L x 1.5"W x .25"H

•

Allows for L, T and X installations

between 12V Driver and Super Star

Creates a power block for branching

between 12V Drivers and Super Star

Includes two 4-Pin Male End Caps and

one 4-Pin Male/Male Adapter

53262

Package of 10

.5"L x .5"W x .25"H

•

Changes female end of Super

Star to male end

4-Pin Male/Male Adapter

4-Pin Silicone End Cap

53269

.75"L x .5"W x .1"H

•

Placed on run termination

•

Protects against dust and damage

•

Package of 10

Flexible Aluminum Channel

53254

36"L x .5"W x .6"H

•

Creates valance to conceal tape

•

Irregular surfaces installation

•

Includes screws for installation

4-Pin Mounting Clip

53272

.5"L x .5"W x .25"H

•

Use on irregular surfaces when

adhesive backing is not sufficient

•

Package of 20

Recommended interval is every 12

4-Pin Male End Cap

53255

1"L x .5"W x .25"H

•

Backed with 3M adhesive

•

Package of 10

Secures to surface connecting cords

and input/output cords of drivers,

controllers and amplifiers

4-Pin Connecting Cords

53265 3"L x .5"W x .25"H 53266 7"L x .5"W x .25"H

53267 13"L x .5"W x .25"H 53268 73"L x .5"W x .25"H

•

Extend distance between 12V Driver

and Super Star

Connect sections of Super Star together

53264

.5"L x .5"W x .25"H

•

Placed on female end of run termination

•

Protects against dust and damage

•

Package of 10

Indoor Dimming Controller

53282

•

Full range dimming

•

On/Off control

•

RF remote control included

•

140w Max

800.486.2946

maximlighting.com

ltra

tar

Cuttable

every 2 inches

Features

•

High lumen laminated LED tape system

No exposed circuit board

Easy to install with multiple lengths to choose from

Warm color temperature enhances room interiors

Perfect for task applications in under counter,

and general room illumination

Flexible design that forms to contours

Safe and economical to operate

Long life LED average 50,000 hours life

Tested to UL standards for both US and Canada

maximlighting.com

Item Length Diodes Wattage Lumens CRIColor Temp PC Board Beam CurrentVoltage

53220

53221

53224

53222

53223

18"

12"

60"

120"

180

120

0.72

4.32

6.48

21.6

43.2

164

246

820

1640

3500 K

70-75

White

12V

60mA

360mA

540mA

1.8A

3.6A

120

3500K 120

Distance Foot Candles

12in

24in

36in

48in

73.86

10.74

6.58

Shown using 1 foot section of Ultra Star

Model Number Wattage Maximum Run

14'

53302

53275, 53304, 53310

30 Watts

60 Watts

StarStrand Ultra Star, with StarChip technology, is for applications requiring additional light

output. Ultra Star produces over 3 times the lumens of Basic Star and 50% more than Super Star.

This product is also covered with a pliable plastic and features an easy to install 3M tape

backed unique white PC board for ultimate light reflection . Ultra Star is available in

pre-manufactured lengths with 4 pin connectors installed at each end for fast and sure installation.

The minimum single run for Ultra Star is 1' and the maximum run is 32'.

TM TM

.38" Wide

.09" High

Top View

Side View

Cut Line Cut Line

.65" Between LEDs

Cut Line Cut Line

2" Between Cut Lines

maximlighting.com

ltra

tar

Ultra Star

(See page 55 for detailed driver information)

Drivers

53302

53275

53304

53310

12V 30w Class II Driver

12V 60w Class II Plug-In Driver

12V 60w Class II Driver

12V 60w Class II Dimmable Driver

800.486.2946

4-Pin Rough-In Terminal Block

53257

4"L x .75"W x .5"H

•

Female connector on one end with four wire

quick connector on opposite end

•

Rough in for new installation construction

between 12V Driver and Ultra Star

Includes one 4-Pin Male/Male Adapter

and installation screw

Plastic Wire Clip

Heat Shrink Wrap

53256

3"L x 1"W x .25"H

•

Secure connections when in walls

Waterproof for damp locations

Heat gun required for installation

Package of 10

4-Pin 4-Way Connector

53263

1.5"L x 1.5"W x .25"H

•

Allows for L, T and X installations

between 12V Driver and Ultra Star

Creates a power block for branching

between 12V Drivers and Ultra Star

Includes two 4-Pin Male End Caps and

one 4-Pin Male/Male Adapter

53262

Package of 10

.5"L x .5"W x .25"H

•

Changes female end of Ultra

Star to male end

4-Pin Male/Male Adapter

4-Pin Silicone End Cap

53269

.75"L x .5"W x .1"H

•

Placed on run termination

•

Protects against dust and damage

•

Package of 10

Flexible Aluminum Channel

53254

36"L x .5"W x .6"H

•

Creates valance to conceal tape

•

Irregular surfaces installation

•

Includes screws for installation

4-Pin Mounting Clip

53272

.5"L x .5"W x .25"H

•

Use on irregular surfaces when

adhesive backing is not sufficient

•

Package of 20

Recommended interval is every 12

4-Pin Male End Cap

53255

1"L x .5"W x .25"H

•

Backed with 3M adhesive

•

Package of 10

Secures to surface connecting cords

and input/output cords of drivers,

controllers and amplifiers

4-Pin Connecting Cords

53265 3"L x .5"W x .25"H 53266 7"L x .5"W x .25"H

53267 13"L x .5"W x .25"H 53268 73"L x .5"W x .25"H

•

Extend distance between 12V Driver

and Ultra Star

Connect sections of Ultra Star together

53264

.5"L x .5"W x .25"H

•

Placed on female end of run termination

•

Protects against dust and damage

•

Package of 10

Indoor Dimming Controller

53282

•

Full range dimming

•

On/Off control

•

RF remote control included

•

140w Max

12V Drivers

maximlighting.com

12V

immable

river

12V

rivers

12V 60w Class II Driver

53304

7.1"L x 2.4"W x 1.4"H

•

Electronic direct wire driver

•

120V-264V input

•

12V, 5A output

•

Short circuit protection, overload

protection, over voltage protection

•

Constant current

•

Operating temperature: -4°F to 140°F

•

IP64 rated

•

Includes 72'' 4-Pin output cord

•

Class II UL 1310, UL-RU certified

12V 60w Class II Plug-In Driver

53275

4.75"L x 2"W x 1.25"H

•

Electronic plug-in driver

•

120V-240V input

•

12V, 5A output

•

Short circuit protection, overload

protection, over voltage protection

•

Operating temperature: 32°F to 104°F

•

Includes 72'' 4-Pin output cord

•

Class II, UL certified

53302

5.7"L x 1.9"W x 1.2"H

•

Electronic direct wire driver

•

120V-264V input

•

12V, 2.5A output

•

Short circuit protection, overload

protection, over voltage protection

•

Constant current

•

Operating temperature: -4°F to 140°F

•

IP64 rated

•

Includes 72'' 4-Pin output cord

•

Class II UL1310, UL-RU certified

12V 30w Class II Driver

12V 60w Class II Dimmable Driver

53310

6"L x 2.5"W x 2.25"H

•

Magnetic direct wire driver

•

120V input

•

12V, 5A output

•

Short circuit protection, overload protection

•

Operating temperature: -22°F to 140°F

•

Includes 72" 4-Pin output cord

•

Class II UL 2108, ETL Certified

•

Requires magnetic low voltage dimmer (not included)

maximlighting.com

800.486.2946

24V

river

24V Drivers

24V 320w Driver

53288

8.5"L x 4.5"W x 2.25"H

•

Electronic direct wire driver

•

120V/240V input

•

24V, 12.5A output

•

Short circuit protection, overload

protection, over temperature, over

voltage protection

•

Operating temperature: 14°F to 140°F

•

Includes two 72'' 6-Pin output cords

•

UL 60950-1, UL-RU certified

53320

•

Electronic plug-in driver

•

120V-264V input

•

24V, 3A output

•

Short circuit protection, overload

protection, over voltage protection

•

Operating temperature: 32°F to 104°F

•

Includes 72'' 6-Pin output cord

24V 75w Plug-In Driver

24V 480w Driver

53289

11"L x 5"W x 1.7"H

•

Electronic direct wire driver

•

120V-264V input

•

24V, 20A output

•

Short circuit protection, overload

protection, over temperature, over

voltage protection

•

Power Factor Control, Constant current

•

Operating temperature: -4°F to 140°F

•

Includes two 72'' 6-Pin output cords

•

UL 60950-1, UL-RU certified

24V 150w Driver

53287

7.75"L x 3.75"W x 1.5"H

•

Electronic direct wire driver

•

120V/240V input

•

24V, 6.5A output

•

Short circuit protection, overload

protection, over voltage protection

•

Operating temperature: 14°F to 140°F

•

Includes 72'' 6-Pin output cord

•

UL 1012, UL-RU certified

24V 60w Class II Driver

53318

7.1"L x 2.4"W x 1.4"H

•

Electronic direct wire driver

•

120V-264V input

•

24V, 2.5A output

•

Short circuit protection, overload

protection, over voltage protection

•

Constant current

•

Operating temperature: -4°F to 140°F

•

IP64 rated

•

Includes 72'' 6-Pin output cord

•

Class II UL 1310, UL-RU certified

24V 96w Class II Driver

53286

8"L x 3.8"W x 1.5"H

•

Electronic direct wire driver

•

120V-264V input

•

24V, 4A output

•

Short circuit protection, overload

protection, over temperature, over

voltage protection

•

Power factor fontrol, constant current

•

Operating temperature: -22°F to 122°F

•

Includes 72'' 6-Pin output cord

•

Class II UL 1310, UL-RU certified

24V 60w Plug-In Driver

53313

•

Electronic plug-in driver

•

120V-240V input

•

24V, 2.5A output

•

Short circuit protection, overload

protection, over voltage protection

•

Operating temperature: 32°F to 104°F

•

Includes 72'' 6-Pin output cord

maximlighting.com

24V

eatherproof

rivers

53380

7.75"L x 2.5"W x 1.5"H

•

Electronic direct wire driver

•

120V-277V input

•

24V, 2.5A output

•

Short circuit protection, overload

protection, over temperature,

over voltage protection

•

Power factor control, constant current

•

Operating temperature: -22°F to 158°F

•

IP67 rated

•

Includes 72" weatherproof output cord

•

Class II UL 879, 8750, 1310,

UL-RU certified

53314

6"L x 2.5"W x 2.25"H

•

Magnetic direct wire driver

•

120V input

•

24V, 4A output

•

Short circuit protection,

overload protection

•

Operating temperature: -22°F to 140°F

•

Includes 72" 6-Pin output cord

•

Class II UL 2108, ETL Certified

•

Requires magnetic low voltage

dimmer (not included)

53316

6"L x 2.5"W x 2.25"H

•

Magnetic direct wire driver

•

120V input

•

24V, 4A output

•

Short circuit protection,

overload protection

•

Operating temperature: -22°F to 140°F

•

Includes 72" weatherproof output cord

•

Class II UL 2108, ETL Certified

•

Requires magnetic low voltage

dimmer (not included)

53381

8.75"L x 2.75"W x 1.5"H

•

Electronic direct wire driver

•

120V-277V input

•

24V, 6.3A output

•

Short circuit protection, overload

protection, over temperature,

over voltage protection

•

Power factor control, constant current

•

Operating temperature: -22°F to 158°F

•

IP67 rated

•

Includes 72" weatherproof output cord

•

Class II UL 1012, 60950-1,

UL-RU certified

53311

6"L x 2.5"W x 2.25"H

•

Magnetic direct wire driver

•

120V input

•

24V, 2.5A output

•

Short circuit protection,

overload protection

•

Operating temperature: -22°F to 140°F

•

Includes 72" 6-Pin output cord

•

Class II UL 2108, ETL Certified

•

Requires magnetic low voltage

dimmer (not included)

53316

6"L x 2.5"W x 2.25"H

•

Magnetic direct wire driver

•

120V input

•

24V, 4A output

•

Short circuit protection, overload protection

•

Operating temperature: -22°F to 140°F

•

Includes 72" weatherproof output cord

•

Class II UL 2108, ETL Certified

•

Requires magnetic low voltage

dimmer (not included)

24V

immable

rivers

24V Drivers

maximlighting.com

24V 100w Weatherproof Class II Dimmable Driver 24V 150w Weatherproof Class II Driver

24V 60w Weatherproof Class II Driver

24V 60w Class II Dimmable Driver 24V 100w Weatherproof Class II Dimmable Driver

24V 100w Class II Dimmable Driver

Maxim Lighting celebrates the

simple wonders of nature with

innovative outdoor lighting that

complements the character

of a home. As the sun sets,

our exterior collections create

a warm, inviting al-fresco

atmosphere. While illuminating

nature s beauty, Maxim

Lighting also preserves it.

These select wall mounts,

posts, and hanging lanterns in

a variety of designs, finishes,

and materials are energy

saving, come equipped with

ENERGY STAR certification,

and Dark Sky lighting to help

ensure that future generations

continue to enjoy the

magnificent outdoors.

Outdoor Energy Efficient &

Dark Sky Lighting

800.486.2946

maximlighting.com

New Age LED

88353CLTE 1-Light Wall Sconce

480 Rated Lumens

Textured Ebony

6.25"W x 19.75"H x 6.5"Ext.

7.5w LED (Included)

HCO 5" BP 5"W x 8”H

88354CLTE 1-Light Wall Sconce

480 Rated Lumens

Textured Ebony

8.25"W x 22.25"H x 8.5"Ext.

7.5w LED (Included)

HCO 6.5" BP 5.5"W x 11.5"H

3500 K Color Temperature

50,000 Rated Life Hours

The contemporary New Age LED outdoor collection

features an aluminum frame finished in Textured Ebony

supporting a Clear glass cylinder. A seeded acrylic post

floats down the center, illuminated by LED for the ultimate

in energy savings and low maintenance.

New Age LED Collection maximlighting.com

800.486.2946

88357CLTE 1-Light Pendant

480 Rated Lumens

Textured Ebony

8.25"W x 26"H x 44.25"OAH

7.5w LED (Included)

88352CLTE 1-Light Wall Sconce

480 Rated Lumens

Textured Ebony

6.25"W x 12.5"H x 6.5"Ext.

7.5w LED (Included)

HCO 5" BP 5"W x 8”H

88350CLTE 1-Light Post

480 Rated Lumens

Textured Ebony

8.25"W x 26"H

7.5w LED (Included)

800.486.2946

maximlighting.com

Optic LED

3500 K Color Temperature

30,000 Rated Life Hours

Aluminum Housing

88254 ABZ, PL 2-Light Wall Sconce

8"W x 18"H x 3.75"Ext.

HCO 8" BP 7"W x 12.5"H

1.3w and 3.7w GX5.3 MR16 LED (Included)

320 Rated Lumens

88252 ABZ, PL 2-Light Wall Sconce

6.5"W x 14"H x 3.75"Ext.

HCO 6" BP 5.5"W x 8.75"H

1.3w and 3.7w GX5.3 MR16 LED (Included)

320 Rated Lumens

88250 ABZ, PL 2-Light Wall Sconce

8"W x 11"H x 3.75"Ext.

HCO 4.5" BP 7"W x 6"H

2 x 1.3w GX5.3 MR16 LED (Included)

180 Rated Lumens

Two different light sources create the unique

effect of the Optic LED outdoor collection powered

by Nichia LEDs. The upper-light source concealed

in the top moves light forward while complying with

Dark Sky requirements. The lower concealed light

source spreads light directly on the ground below

where it is needed most. Most important, Optic LED

offers the ultimate in energy savings and long life.

800.486.2946 maximlighting.com

800.486.2946 62

Arc EE

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Stainless Steel

85006 FTOI, FTSST 2-Light Wall

1800 Rated Lumens

" BP 6.5"W x 12"H

2 x 13w GU24 Bulbs (Included)

6.5"W x 12"H x 4"Ext.

HCO 6

85005 FTOI, FTSST 1-Light Wall

900 Rated Lumens

" BP 6.5"W x 9"H

1 x 13w GU24 Bulb (Included)

6.5"W x 9"H x 4"Ext.

HCO 3.5

Arc CF

Electronic NPE Ballast

2700 K Color Temperature

10,000 Rated Life Hours

Stainless Steel

85002FTOI 1-Light Wall

1850 Rated Lumens

Oil Rubbed Beonze

6.5"W x 12"H x 4"Ext.

HCO 6" BP 6.5"W x 12"H

1 x 26w Quad PL Bulb

85000FTOI 1-Light Wall

900 Rated Lumens

Oil Rubbed Beonze

6.5"W x 9"H x 4"Ext.

HCO 3.5" BP 6.5"W x 9"H

1 x 13w Quad PL Bulb

800.486.2946

maximlighting.com

Luna EE

85215WTBM 1-Light Wall

900 Rated Lumens

Brushed Metal

9"W x 12"H x 4"Ext.

HCO 7" "W x 11"H

BP 8

1 x 13w GU24 Bulb (Included)

85216WTBM 2-Light Wall

1800 Rated Lumens

Brushed Metal

9"W x 21"H x 4"Ext.

HCO 10.5" BP 8"W x 20"H

2 x 13w GU24 Bulbs (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Aluminum

Indoor and Outdoor Application

85217WTBM 2-Light Flush Mount

1800 Rated Lumens

Brushed Metal

11"W x 5"H

2 x 13w GU24 Bulbs (Included)

maximlighting.com

85213WTBM 1-Light Pendant

1355 Rated Lumens

Brushed Metal

7.25"W x 15"H

1 x 18w GU24 Bulb (Included)

85214WTBM 1-Light Pendant

1760 Rated Lumens

Brushed Metal

9.5"W x 22.5"H

1 x 26w GU24 Bulb (Included)

85219WSOI 2-Light Wall

1800 Rated Lumens

Oil Rubbed Bronze

7"W x 21"H x 4"Ext.

HCO 10.5" "W x 19.75"H

BP 5.5

x 13w GU24 Bulbs (Included)

85218WSOI 1-Light Wall

900 Rated Lumens

Oil Rubbed Bronze

7"W x 12"H x 4"Ext.

HCO 6" "W x 10.5"H

BP 5.5

x 13w GU24 Bulb (Included)

Luna EE Collection

800.486.2946

maximlighting.com

Beam EE

54340 WTOI,WTSST

1-Light Wall Sconce

840 Rated Lumens

6"W x 12"H x 2.2 5"Ext.

"" "

1 x 13w 2GX7 Bulb (Included)

HCO 6 BP 5 W x 10.75 H

86300 WTOI,WTSST

1-Light Wall Sconce

840 Rated Lumens

6.75"W x 12"H x 2.2 5"Ext.

"" "

1 x 13w 2GX7 Bulb (Included)

HCO 8 BP 6.5 W x 11.75 H

86303 WTOI,WTSST

1-Light Wall Sconce

1250 Rated Lumens

6.75"W x 16"H x 2.2 5"Ext.

"" "

1 x 18w 2G11 Bulb (Included)

HCO 8 BP 6.5 W x 15.75 H

The Beam EE Collection features low-profile

wall lighting designed with versatility and

energy saving technology. Fixtures are

constructed of stainless steel to allow for

outdoor installation, and with the low-profile

design, the Beam EE Collection can also be

used interior for corridors and hallways

with ADA compliance. The fluorescent

light source saves energy and allows

for maintenance-free operation.

The White acrylic lens is durable and

strong. The metal is finished in either

Stainless Steel or Oil Rubbed Bronze.

2700 K C olor T emperature

10,000 Rated Life Hours

Indoor and Outdoor Application

maximlighting.com

800.486.2946

maximlighting.com

54341 WTOI,WTSST

1-Light Wall Sconce

1250 Rated Lumens

7.5"W x 16"H x 2.7 5"Ext.

"""

1 x 18w 2G11 Bulb (Included)

HCO 8 BP 6.25 W x 15 H

54345 WTOI,WTSST

1-Light Wall Sconce

840 Rated Lumens

6"W x 12"H x 2.2 5"Ext.

"""

1 x 13w 2GX7 Bulb (Included)

HCO 6 BP 4.25 W x 11.75 H

54346 WTOI,WTSST

1-Light Wall Sconce

1250 Rated Lumens

7"W x 16"H x 2.7 5"Ext.

"""

1 x 18w 2G11 Bulb (Included)

HCO 8 BP 4.25 W x 15.75 H

800.486.2946

Beam EE Collection maximlighting.com

Zenith EE

800.486.2946

maximlighting.com

86208 WTABZ,WTPL

1-Light Wall Sconce

1250 Rated Lumens

10.25"W x 10.25"H x 4"Ext.

"""

1 x 18w G24q-2 Bulb (Included)

HCO 5 BP 10.25 W x 10.25 H

86205 WTABZ,WTPL

2-Light Wall Sconce

2500 Rated Lumens

14.5"W x 14.5"H x 4.5 "Ext.

"""

2 x 18w 2G11 Bulbs (Included)

HCO 7.25 BP 14.5 W x 14.5 H

86207 WTABZ,WTPL

2-Light Wall Sconce

2500 Rated Lumens

14.5"W x 14.5"H x 4"Ext.

"""

2 x 18w 2G11 Bulbs (Included)

HCO 7.25 BP 14.5 W x 14.5 H

86206 WTABZ,WTPL

1-Light Wall Sconce

1250 Rated Lumens

10.25"W x 10.25"H x 3.7 5"Ext.

"""

1 x 18w G24q-2 Bulb (Included)

HCO 5 BP 10.25 W x 10.25 H

86204 WTABZ,WTPL

1-Light Wall Sconce

1250 Rated Lumens

10.25"W x 10.25"H x 4"Ext.

"""

1 x 18w G24q-2 Bulb (Included)

HCO 5 BP 10.25 W x 10.25 H

These contemporary, European-designed fluorescent

outdoor fixtures are a perfect combination of energy

efficiency and durability. The Zenith Collection features

die-cast metal frames painted with a polyurethane powder

coat, finished in Platinum or Architectural Bronze.

The durable white acrylic lens diffuses the light nicely.

The fluorescent light source gives the ultimate in energy

saving and long life.

2700 K C olor T emperature

10,000 Rated Life Hours

Indoor and Outdoor Application

maximlighting.com

Zenith EE Collection

86200 WTABZ,WTPL

2-Light Wall Sconce

1680 Rated Lumens

7.25"W x 12"H x 3.5 "Ext.

"""

2 x 13w 2GX7 Bulbs (Included)

HCO 6 BP 7.5 W x 12 H

86201 WTABZ,WTPL

2-Light Wall Sconce

1680 Rated Lumens

7.25"W x 12"H x 3.2 5"Ext.

"""

2 x 13w 2GX7 Bulbs (Included)

HCO 6 BP 7.5 W x 12 H

86202 WTABZ,WTPL

2-Light Wall Sconce

1680 Rated Lumens

7.25"W x 12"H x 3.5 "Ext.

"""

2 x 13w 2GX7 Bulbs (Included)

HCO 6 BP 7.5 W x 12 H

800.486.2946 68

maximlighting.com Zenith EE Collection

86195 WTABZ,WTPL

2-Light Wall Sconce

1680 Rated Lumens

8"W x 13.5"H x 4"Ext.

"""

2 x 13w 2GX7 Bulbs (Included)

HCO 6.75 BP 8 W x 9 H

86197 WTABZ,WTPL

1-Light Wall Sconce

1355 Rated Lumens

Light Output from Top and Bottom

10"W x 4.75"H x 5.2 5"Ext.

"""

1 x 18w GU24 Bulb (Included)

HCO 2.5 BP 3.75 W x 3.75 H

86222 WTABZ,WTPL

1-Light Wall Sconce

1355 Rated Lumens

7.25"W x 12"H x 3.5"Ext.

"" "

1 x 18w GU24 Bulb (Included)

HCO 6 BP 7 W x 9.75 H

88197 WTABZ,WTPL

Light Output from

Top and Bottom

maximlighting.com

Zenith EE Collection

86194 WTABZ,WTPL

1-Light Wall Sconce

1355 Rated Lumens

9"W x 12"H x 11"Ext.

"""

1 x 18w GU24 Bulb (Included)

HCO 9.75 BP 4.5 W x 4.5 H

86192 WTABZ,WTPL

1-Light Wall Sconce

1355 Rated Lumens

9.75"W x 9.5"H x 5.2 5"Ext.

"""

1 x 18w GU24 Bulb (Included)

HCO 4.75 BP 6.75 W x 9.25 H

86190 WTABZ,WTPL 1-Light Post

1355 Rated Lumens

9"W x 12.5"H

1 x 18w GU24 Bulb (Included)

800.486.2946 70

800.486.2946

maximlighting.com

85405MCAT 1-Light Wall

1760 Rated Lumens

Artesian Bronze

13"W x 25"H x 16"Ext.

HCO 10.5" BP 5.5"W x 11.5"H

1 x 26w GU24 Bulb (Included)

85404MCAT 1-Light Wall

1355 Rated Lumens

Artesian Bronze

10.5"W x 21 "H x 14 "Ext.

HCO 8.5" BP 5.5"W x 11.5"H

1 x 18w GU24 Bulb (Included)

85403MCAT 1-Light Wall

900 Rated Lumens

Artesian Bronze

9"W x 17.5"H x 11.5 "Ext.

HCO 7" BP 4.5"W x 7.5"H

1 x 13w GU24 Bulb (Included)

Westport EE

2700 K Color Temperature

10,000 Rated Life Hours

Self-Ballasted GU24 Bulb

maximlighting.com

Westport VX EE Collection

85409MCAT 2-Light Flush Mount

1800 Rated Lumens

Artesian Bronze

13"W x 6.5 "H

2 x 13w GU24 Bulbs (Included)

85407MCAT 1-Light Pendant

1355 Rated Lumens

Artesian Bronze

10.5"W x 21. 5"H

1 x 18w GU24 Bulb (Included)

85400MCAT 1-Light Post

1355 Rated Lumens

Artesian Bronze

10.5"W x 23 "H

1 x 18w GU24 Bulb (Included) 85402MCAT 1-Light Wall

900 Rated Lumens

Artesian Bronze

7"W x 12 "H x 9"Ext.

HCO 5.5" BP 4.5"W x 7.5"H

1 x 13w GU24 Bulb (Included)

800.486.2946 72

800.486.2946

maximlighting.com

85165GFCO 1-Light Wall

1760 Rated Lumens

Copper Oxide

12"W x 17.5"H x 14"Ext.

"" "

1 x 26w GU24 Bulb (Included)

HCO 6 BP 6 W x 11.5 H

85164GFCO 1-Light Wall

1355 Rated Lumens

Copper Oxide

10"W x 14 "H x 11.5 "Ext.

"""

1 x 18w GU24 Bulb (Included)

HCO 6 BP 5.25 W x 10 H

85163GFCO 1-Light Wall

900 Rated Lumens

Copper Oxide

7.5"W x 11.5"H x 9.5 "Ext.

"""

1 x 13w GU24 Bulb (Included)

HCO 4 BP 4.5 W x 7.5 H

Balboa EE

2700 K Color Temperature

10,000 Rated Life Hours

Self-Ballasted GU24 Bulb

maximlighting.com

85162GFCO 1-Light Wall

900 Rated Lumens

Copper Oxide

6.5"W x 9.5 "H x 8"Ext.

"""

1 x 13w GU24 Bulbs (Included)

HCO 4 BP 4.5 W x 7.5 H

85167GFCO 1-Light Pendant

1760 Rated Lumens

Copper Oxide

12"W x 18.5"H

1 x 26w GU24 Bulb (Included)

85160GFCO 1-Light Post

1355 Rated Lumens

Copper Oxide

10"W x 15. 5"H

1 x 18w GU24 Bulb (Included)

Balboa VX EE Collection

800.486.2946 74

800.486.2946

maximlighting.com

85484LTAP 1-Light Wall

1355 Rated Lumens

Antique Pecan

11"W x 21 "H x 12.5 "Ext.

"""

1 x 18w GU24 Bulb (Included)

HCO 9.5 BP 5.5 W x 17.5 H

85482LTAP 1-Light Wall

900 Rated Lumens

Antique Pecan

7"W x 9.5 "H x 7.5 "Ext.

1 x 13w GU24 Bulb (Included)

HCO 3 BP 5.25 W x 9.5"H

85483LTAP 1-Light Wall

900 Rated Lumens

Antique Pecan

8.5"W x 16.5"H x 10 "Ext.

"""

1 x 13w Gu24 Bulb (Included)

HCO 8.5 BP 5.5 W x 12.5 H

Lake Shore EE

2700 K Color Temperature

10,000 Rated Life Hours

Self-Ballasted GU24 Bulb

maximlighting.com

85487LTAP 1-Light Pendant

1355 Rated Lumens

Antique Pecan

11"W x 17 "H

1 x 18w GU24 Bulb (Included)

85485LTAP 1-Light Wall

1760 Rated Lumens

Antique Pecan

12"W x 25"H x 14.5"Ext.

"" "

1 x 26w GU24 Bulb (Included)

HCO 11.5 BP 7 W x 20.5 H

Lake Shore VX EE Collection

800.486.2946 76

800.486.2946

maximlighting.com

85493TLML 1-Light Wall

900 Rated Lumens

Mottled Leather

8.5"W x 17.5"H x 10.5"Ext.

"""

1 x 13w GU24 Bulb (Included)

HCO 8 BP 5.5 W x 12.5 H

85494TLML 1-Light Wall

1355 Rated Lumens

Mottled Leather

11"W x 23. 5"H x 12.5"Ext.

1 x 18w GU24 Bulb (Included)

HCO 12 BP 6.75"W x 15.5 H

85495TLML 1-Light Wall

1760 Rated Lumens

Mottled Leather

13.5"W x 27.5"H x 16"Ext.

1 x 26w GU24 Bulb (Included)

HCO 18 BP 6.5"W x 14.5 H

Pacific Heights EE

2700 K Color Temperature

10,000 Rated Life Hours

Self-Ballasted GU24 Bulb

maximlighting.com

85492TLML 1-Light Wall

900 Rated Lumens

Mottled Leather

6.5"W x 10 "H x 7"Ext.

1 x 13w Gu24 Bulb (Included)

HCO 3.5 BP 5 W x 9"H

85497TLML 1-Light Pendant

1355 Rated Lumens

Mottled Leather

11"W x 20.5"H

1 x 18w GU24 Bulb (Included)

85490TLML 1-Light Post

1355 Rated Lumens

Mottled Leather

11"W x 22"H

1 x 18w GU24 Bulb (Included)

Pacific Heights VX EE Collection

800.486.2946 78

800.486.2946

maximlighting.com

85050HOBU 1-Light Wall

1355 Rated Lumens

Burnished

6" W X 7.5"H X 6"Ext.

HCO 3.5" " "

BP 5 W x 7.25 H

1 x 18w GU24 Bulb (Included)

Coldwater EE

85054HOBU 1-Light Wall

1760 Rated Lumens

Burnished

9" W X 16"H X 10"Ext.

HCO 6" " "

BP 4.5 W x 9.5 H

1 x 26w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Aluminum

85051HOBU 2-Light Wall

1800 Rated Lumens

Burnished

9" W X 11"H X 6"Ext.

HCO 4" " "

BP 8W x 11H

2 x 13w GU24 Bulbs (Included)

maximlighting.com

Coldwater EE Collection

85059HOBU 2-Light Flush Mount

1800 Rated Lumens

Burnished

9"W X 5”H

2 x 13w GU24 Bulbs (Included)

85055HOBU 1-Light Post

1355 Rated Lumens

Burnished

6"W X 12"H

1 x 18w GU24 Bulb (Included)

85053HOBU 1-Light Wall

1355 Rated Lumens

Burnished

6" W X 12"H X 8.5"Ext.

HCO 2.5" " "

BP 4.5 W x 9.5 H

1 x 18w GU24 Bulb (Included)

800.486.2946 80

800.486.2946

maximlighting.com

Cambria EE

85194FCCH 1-Light Wall

1355 Rated Lumens

Chocolate

10" W x 17.5"H x 14"Ext.

HCO 11.5" BP 7"W x 13"H

1 x 18w GU24 Bulb (Included)

85193FCCH 1-Light Wall

900 Rated Lumens

Chocolate

7" W x 10.5"H x 8"Ext.

HCO 4" "

BP 5"W x 8 H

1 x 13w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours]

Die Cast Aluminum

85195FCCH 1-Light Wall

1760 Rated Lumens

Chocolate

13" W x 22.5"H x 16"Ext.

HCO 13" BP 9"W x 15"H

1 x 26w GU24 Bulb (Included)

maximlighting.com

Cambria EE Collection

85190FCCH 1-Light Post

1355 Rated Lumens

1 x 18w GU24 Bulb (Included)

Chocolate

10" W x 15"H

85199FCCH 1-Light Pendant

1760 Rated Lumens

1 x 26w GU24 Bulb (Included)

Chocolate

13"W x 21.5"H

85191FCCH 1-Light Post

1760 Rated Lumens

1 x 26w GU24 Bulb (Included)

Chocolate

13"W x 22"H

800.486.2946 82

800.486.2946

maximlighting.com

85523MOOB 1-Light Wall

900 Rated Lumens

Oriental Bronze

9"W x 20"H x 12.5"Ext.

HCO 11" BP 6"W x 13"H

1 x 13w GU24 Bulb (Included)

Carriage House EE

85524MOOB 1-Light Wall

1355 Rated Lumens

Oriental Bronze

12.5"W x 26.5"H x 15.5"Ext.

HCO 13.5" BP 6.5"W x 15.5"H

1 x 18w GU24 Bulb (Included)

85525MOOB 1-Light Wall

1760 Rated Lumens

Oriental Bronze

14"W x 31"H x 18.5"Ext.

HCO 15.5" BP 6.5"W x 15.5"H

1 x 26w GU24 Bulb (Included)

85596MOOB 1-Light Wall

900 Rated Lumens

Oriental Bronze

9"W x 20"H x 12.5"Ext.

HCO 8" BP 6"W x 13"H

1 x 13w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

maximlighting.com

Carriage House EE Collection

85595MOOB 1-Light Wall

900 Rated Lumens

Oriental Bronze

6"W x 12.5"H x 7.5"Ext.

HCO 7" BP 5"W x 9"H

1 x 13w GU24 Bulb (Included)

85522MOOB 1-Light Wall

900 Rated Lumens

Oriental Bronze

9"W x 16"H x 12"Ext.

HCO 11" BP 6"W x 13"H

1 x 13w GU24 Bulb (Included)

85529MOOB 2-Light Flush Mount

1800 Rated Lumens

Oriental Bronze

12.5"W x 9.5"H

2 x 13w GU24 Bulbs (Included)

85520MOOB 1-Light Post

1355 Rated Lumens

Oriental Bronze

12.5"W x 26.5"H

1 x 18w GU24 Bulb (Included)

85527MOOB 1-Light Pendant

1355 Rated Lumens

Oriental Bronze

12.5"W x 24.5"H

1 x 18w GU24 Bulb (Included)

800.486.2946 84

800.486.2946

maximlighting.com

Carriage House EE

86524MOOB 1-Light Wall

1355 Rated Lumens

Oriental Bronze

12.5"W x 26.5"H x 15.5"Ext.

HCO 13.5" BP 6.5"W x 15.5"H

1 x 18w GU24 Bulb (Included)

86525MOOB 1-Light Wall

1760 Rated Lumens

Oriental Bronze

14"W x 31"H x 18.5"Ext.

HCO 15.5" BP 6.5"W x 15.5"H

1 x 26w GU24 Bulb (Included)

No Photocell

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

86523MOOB 1-Light Wall

900 Rated Lumens

Oriental Bronze

9"W x 20"H x 12.5"Ext.

HCO 11" BP 6"W x 13"H

1 x 13w GU24 Bulb (Included)

86595MOOB 1-Light Wall

900 Rated Lumens

Oriental Bronze

6"W x 12.5"H x 7.5"Ext.

HCO 7" BP 5"W x 9"H

1 x 13w GU24 Bulb (Included)

86522MOOB 1-Light Wall

900 Rated Lumens

Oriental Bronze

9"W x 16"H x 12"Ext.

HCO 11" BP 6"W x 13"H

1 x 13w GU24 Bulb (Included)

maximlighting.com

800.486.2946 86

Dover EE

No Photocell

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

maximlighting.com

800.486.2946

86093FSBZ1-Light Wall

900 Rated Lumens

Bronze

8"W x 19.5" H x 9.5"Ext.

HCO 11.5" BP 5"W x 10.5"H

1 x 13w GU24 Bulb (Included)

86094FSBZ 1-Light Wall

1355 Rated Lumens

Bronze

10"W x 24.5" H x 13"Ext.

HCO 13.5" BP 7"W x 15.75"H

1 x 18w GU24 Bulb (Included)

86095FSBZ 1-Light Wall

1760 Rated Lumens

Bronze

12"W x 31.5" H x 15.5"Ext.

HCO 15.5" BP 7"W x 15.75"H

1 x 26w GU24 Bulb (Included)

86096FSBZ 1-Light Wall

900 Rated Lumens

Bronze

6.5"W x 9.5" H x 7.5"Ext.

HCO 5" BP 5"W x 6.5"H

1 x 13w GU24 Bulb (Included)

800.486.2946

maximlighting.com

85093FSBZ1-Light Wall

900 Rated Lumens

Bronze

8"W x 19.5" H x 9.5"Ext.

HCO 11.5" BP 5"W x 10.5"H

1 x 13w GU24 Bulb (Included)

Dover EE

85094FSBZ 1-Light Wall

1355 Rated Lumens

Bronze

10"W x 24.5" H x 13"Ext.

HCO 13.5" BP 7"W x 15.75"H

1 x 18w GU24 Bulb (Included)

85095FSBZ 1-Light Wall

1760 Rated Lumens

Bronze

12"W x 31.5" H x 15.5"Ext.

HCO 15.5" BP 7"W x 15.75"H

1 x 26w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

maximlighting.com

Dover EE Collection

85096FSBZ 1-Light Wall

900 Rated Lumens

Bronze

6.5"W x 9.5" H x 7.5"Ext.

HCO 5" BP 5"W x 6.5"H

1 x 13w GU24 Bulb (Included)

85099FSBZ 1-Light Pendant

1760 Rated Lumens

Bronze

12"W x 20" H

1 x 26w GU24 Bulb (Included)

85092FSBZ 1-Light Post

1760 Rated Lumens

Bronze

12"W x 25.5" H

1 x 26w GU24 Bulb (Included)

800.486.2946 88

800.486.2946

maximlighting.com

85466SFSE 1-Light Wall

1760 Rated Lumens

Sienna

13"W x 33"H x 18.5"Ext.

HCO 16" BP 7.5"W x 15"H

1 x 26w GU24 Bulb (Included)

Knob Hill EE

85465SFSE 1-Light Wall

1760 Rated Lumens

Sienna

10"W x 24.5"H x 14.5"Ext

HCO 11" BP 4.75"W x 9.5"H

1 x 26w GU24 Bulb (Included)

85464SFSE 1-Light Wall

900 Rated Lumens

Sienna

8"W x 19.5"H x 12"Ext.

HCO 9.75" BP 4.75"W x 9.5"H

1 x 13w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

maximlighting.com

Knob Hill EE Collection

85462SFSE 1-Light Wall

900 Rated Lumens

Sienna

6"W x 14"H x 7"Ext.

HCO 9" BP 4.75"W x 9.5"H

1 x 13w GU24 Bulb (Included)

85468SFSE 1-Light Pendant

1760 Rated Lumens

Sienna

13"W x 26.5"H

1 x 26w GU24 Bulb (Included)

85460SFSE 1-Light Post

1355 Rated Lumens

Sienna

10"W x 22.5"H

1 x 18w GU24 Bulb (Included)

85469SFSE 2-Light Flush Mount

1800 Rated Lumens

Sienna

13"W x 6"H

2 x 13w GU24 Bulbs (Included)

800.486.2946 90

800.486.2946

maximlighting.com

Morrow Bay EE

85184LTET 1-Light Wall

1355 Rated Lumens

Earth Tone

8.5"W x 20"H x 9.5"Ext.

HCO 9.5" BP 5.5"W x 12.5"H

1 x 18w GU24 Bulb (Included)

85189LTET 1-Light Wall

1760 Rated Lumens

Earth Tone

13.5"W x 32.5"H x 14.5"Ext.

HCO 15" BP 7"W x 21"H

1 x 26w GU24 Bulb (Included)

85188LTET 1-Light Wall

1760 Rated Lumens

Earth Tone

10.5"W x 27"H x 11"Ext.

HCO 12.5" BP 5.25"W x 17.25"H

1 x 26w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

maximlighting.com

Morrow Bay EE Collection

85183LTET 1-Light Wall

900 Rated Lumens

Earth Tone

7" W x 14"H x 7.5"Ext.

HCO 8" BP 5"W x 11"H

1 x 13w GU24 Bulb (Included)

85187LTET 1-Light Pendant

1760 Rated Lumens

Earth Tone

13.5" W x 26"H

1 x 26w GU24 Bulb (Included)

85181LTET 1-Light Post

1355 Rated Lumens

Earth Tone

10.5"W x 24"H

1 x 18w GU24 Bulb (Included)

800.486.2946 92

800.486.2946

maximlighting.com

85085FSCF 1-Light Wall

1760 Rated Lumens

Country Forge

11"W x 32"H x 15.5"Ext.

HCO 15.5" BP 4.5"W x 18"H

1 x 26w GU24 Bulb (Included)

Nantucket EE

85081FSCF 1-Light Wall

900 Rated Lumens

Country Forge

6.5"W x 10.5"H x 9.5"Ext.

HCO 4" BP 4.5"W x 8"H

1 x 13w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Forged Iron

maximlighting.com

Nantucket EE Collection

85080FSCF 1-Light Post

1355 Rated Lumens

Country Forge

8.5"W x 22.5"H

1 x 18w GU24 Bulb (Included)

85084FSCF 1-Light Wall

1355 Rated Lumens

Country Forge

8.5"W x 23"H x 11"Ext.

HCO 13.5" BP 4.75"W x 14"H

1 x 18w GU24 Bulb (Included)

800.486.2946 94

800.486.2946

maximlighting.com

85015LTES 1-Light Wall

1760 Rated Lumens

Espresso

11.5"W x 26.5" H x 15"Ext.

HCO 12" BP 5"W x 14.5"H

1 x 26w GU24 Bulb (Included)

Odessa EE

85014LTES 1-Light Wall

1355 Rated Lumens

Espresso

9"W x 21.5" H x 12.5"Ext.

HCO 10" BP 4.5"W x 12"H

1 x 18w GU24 Bulb (Included)

85013LTES 1-Light Wall

900 Rated Lumens

Espresso

7"W x 16" H x 8.5"Ext.

HCO 7.5" BP 4.5"W x 11.5"H

1 x 13w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

maximlighting.com

85011LTES 1-Light Post

1760 Rated Lumens

Espresso

11.5"W x 24.5" H

1 x 26w GU24 Bulb (Included)

85019LTES 1-Light Pendant

1760 Rated Lumens

Espresso

11.5"W x 23" H

1 x 26w Gu24 Bulb (Included)

85010LTES 1-Light Post

1355 Rated Lumens

Espresso

9"W x 20.5" H

1 x 18w GU24 Bulb (Included)

Odessa EE Collection

800.486.2946 96

800.486.2946

maximlighting.com

85031MOSE 1-Light Wall

900 Rated Lumens

Sienna

5.5"W x 10"H x 8"Ext.

HCO 6" BP 4"W x 7.5”H

1 x 13w GU24 Bulb (Included)

Santa Barbara EE

85035MOSE 1-Light Wall

1760 Rated Lumens

Sienna

11"W x 20"H x 13.5"Ext.

HCO 6" BP 7"W x 17"H

1 x 26w GU24 Bulb (Included)

85033MOSE 1-Light Wall

900 Rated Lumens

Sienna

7"W x 13"H x 8.5"Ext.

HCO 4" BP 5.5"W x 10"H

1 x 13w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

85034MOSE 1-Light Wall

1355 Rated Lumens

Sienna

9"W x 16"H x 11"Ext.

HCO 3.5" BP 6"W x 14"H

1 x 18w GU24 Bulb (Included)

maximlighting.com

Santa Barbara EE Collection

85030MOSE 1-Light Flush Mount

900 Rated Lumens

Sienna

9"W x 7"H

1 x 13w GU24 Bulb (Included)

85038MOSE 1-Light Pendant

1355 Rated Lumens

Sienna

9"W x 17.5"H

1 x 18w GU24 Bulb (Included)

85032MOSE 1-Light Deck Light

1355 Rated Lumens

Sienna

10.5"W x 12.5"H

1 x 18w GU24 Bulb (Included)

85037MOSE 1-Light Post

1760 Rated Lumens

Sienna

11"W x 18.5"H

1 x 26w GU24 Bulb (Included)

85036MOSE 1-Light Post

1355 Rated Lumens

Sienna

9"W x 16"H

1 x 18w GU24 Bulb (Included)

800.486.2946 98

800.486.2946

maximlighting.com

Scottsdale EE

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Forged Iron

85323FSCF 1-Light Wall

900 Rated Lumens

Country Forge

10.5"W x 21.5"H x 11.5"Ext.

HCO 8.5" BP 4.5"W x 7.5"H

1 x 13w GU24 Bulb (Included)

85325FSCF 1-Light Wall

1760 Rated Lumens

Country Forge

13.5"W x 28"H x 16"Ext.

HCO 12.5" BP 5"W x 10"H

1 x 26w GU24 Bulb (Included)

85324FSCF 1-Light Wall

1355 Rated Lumens

Country Forge

11.5"W x 23.5"H x 13"Ext.

HCO 10" BP 5”W x 8.5"H

1 x 18w GU24 Bulb (Included)

85322FSCF 1-Light Wall

900 Rated Lumens

Country Forge

6"W x 6.5"H x 8.5"Ext.

HCO 2.5" BP 4.5"W x 5"H

1 x 13w GU24 Bulb (Included)

maximlighting.com

800.486.2946 100

Side Door EE

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

85928 BK,RP,WT 1-Light Wall

900 Rated Lumens

Frost Glass

7.5"W x 12" H x 5.5"Ext.

"""

HCO 2.5 BP 7.5 W x 12 H

1 x 13w GU24 Bulb (Included)

85924 BK,EB,RP,WT

1-Light Wall

900 Rated Lumens

Frost Glass

5.5"W x 8.5" H x 6.5"Ext.

"""

HCO 2.5 BP 4.5 W x 4.5 H

1 x 13w GU24 Bulb (Included)

85926 BK,EB,RP,WT

1-Light Wall

900 Rated Lumens

Frost Glass

5.5"W x 10" H x 6"Ext.

"""

HCO 2.5 BP 4.5 W x 4.5 H

1 x 13w Gu24 Bulb (Included)

maximlighting.com

800.486.2946

maximlighting.com

Wakefield EE

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

85074MREB 1-Light Wall

1355 Rated Lumens

Empire Bronze

11.5"W x 26"H x 11.5"Ext.

HCO 17" BP 7"W x 13"H

1 x 18w GU24 Bulb (Included)

85072MREB 1-Light Wall

900 Rated Lumens

Empire Bronze

8"W x 20"H x 12"Ext.

HCO 9" BP 5"W x 8"H

1 x 13w GU24 Bulb (Included)

maximlighting.com

101

85078MREB 1-Light Pendant

1760 Rated Lumens

Empire Bronze

13"W x 27"H

1 x 26w GU24 Bulb (Included)

85073MREB 1-Light Wall

900 Rated Lumens

Empire Bronze

8"W x 20"H x 12"Ext.

HCO 9" BP 5"W x 8"H

1 x 13w GU24 Bulb (Included)

800.486.2946 102

maximlighting.com

Wakefield EE Collection

800.486.2946

maximlighting.com

103

85102 BK,RP 1-Light Wall

900 Rated Lumens

Frost Glass

8"W x 15"H x 8"Ext.

HCO 11" BP 4.5"W x 4.5"H

1 x 13w GU24 Bulb (Included)

Westlake EE

85100 BK,RP 1-Light Wall

900 Rated Lumens

Frost Glass

8"W x 15"H x 8"Ext.

HCO 2" BP 4.5"W x 4.5"H

1 x 13w Gu24 Bulb (Included)

85103 BK,RP 1-Light Wall

1355 Rated Lumens

Frost Glass

9.5"W x 24"H x 10"Ext.

HCO 19.5" BP 4.5"W x 10"H

1 x 18w GU24 Bulb (Included)

85104 BK,RP 1-Light Wall

1355 Rated Lumens

Frost Glass

9.5"W x 19"H x 10"Ext.

HCO 6" BP 4.5”W x 10"H

1 x 18w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

800.486.2946

maximlighting.com

104

Flush Mount EE

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

87920 BK,RP,WT

1-Light Flush Mount

900 Rated Lumens

11.5"W x 4.5"H

1 x 13w GU24 Bulb (Included)

Madrona EE

85041 BK,RP 1-Light Wall

900 Rated Lumens

Frost Glass

8"W x 16"H x 8.5"Ext.

HCO 5" BP 4.5"W x 4.5"H

1 x 13w GU24 Bulb (Included)

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

85044 BK,RP 1-Light Wall

1355 Rated Lumens

Frost Glass

9.5"W x 20.5"H x 10"Ext.

HCO 17" BP 4.5"W x 4.5"H

1 x 18w GU24 Bulb (Included)

800.486.2946

maximlighting.com

105

Whisper Dark

Sky EE

Self-Ballasted GU24 Bulb

2700 K Color Temperature

10,000 Rated Life Hours

Die Cast Aluminum

85393 BZ,SE 1-Light Wall

900 Rated Lumens

8"W x 19.5"H x 9.5"Ext.

HCO 9.5" BP 5"W x 9.5"H

1 x 13w GU24 Bulb (Included)

85394 BZ,SE 1-Light Wall

1355 Rated Lumens

10"W x 24.5"H x 13"Ext.

HCO 12.5" BP 5.5"W x 12.5"H

1 x 18w GU24 Bulb (Included)

800.486.2946

Index maximlighting.com

106

53131......................19

53132......................19

53135......................19

53136......................19

53201......................49

53210......................51

53211......................51

53212......................51

53213......................51

53214......................51

53220......................53

53221......................53

53222......................53

53223......................53

53224......................53

53254.....................34,

36,38,42,50,52,54

53255................34,36,

38,42,46,48,50,52,54

53256................34,36,

38,42,46,48,50,52,54

53257.......46,50,52,54

53258.....................34,

36,38,42,46,48

53259......................50

53260......................50

53261......................50

53262.....................36,

42,50,52,54

53263.....................36,

42,46,48,50,52,54

53264.......36,42,52,54

53265...................36,

42,46,48,50,52,54

53266...................36,

42,46,48,50,52,54

53267...................36,

42,46,48,50,52,54

53268...................36,

42,46,48,50,52,54

53269...................36,

42,50,52,54

53272.......36,42,52,54

53273.................34,38

53275......................55

53282................52,54

53286......................56

53287......................56

53288......................56

53289......................56

53302......................55

53304......................55

53310......................55

53311......................57

53364.. ,4

53365.. ,4

53368.. ,4

53370.. ,4

53373

53374

53380.. 5

53381.. 5

53383.. 4 ,4

53385.. 4 ,4

53386.. 4 ,4

53387.. 4 ,4

53389.. 4

53390.. 4

53393.. 3 ,3 ,4

53398.. 3

53430.. 3

53431.. 3

53432.. 3

53433.. 3

53434.. 3

53441.. 3

53442.. 3

53443.. 3

53445.. 3

53450.. 3

53451.. 3

53452.. 3

53453.. 3

53454.. 3

53455.. 3

53464.. 34,3

53465

53467

53468

53469.. 3 ,3

53313......................56

53314......................57

53316......................57

53318......................56

53320......................56

53342.................34,38

53344.................34,38

53350...................34,

36,38,42,46,48

53352......................46

53353......................46

53354.................46,48

53355.................46,48

...............40 4

...................34,

36,38,40,42,44,50

...................34,

36,38,40,42,44,50

.................... 7

.........36, 2 8

............... 2 8

.........36, 2 8

............... 2 8

.................... 4

.......... 4 8 6

.................... 6

.................... 7

.................... 9

.................... 3

............... 8

...................34,

36,38,42,46,48

...................34,

36,38,42,46,48

...................34,

36,38,42,46,48

............... 4 8

53530..

53531..

53533..

53534..

53535..

53541.. 43

53542.. 43

53543.. 43

53545.. 43

53550.. 35

53551.. 35

53552.. 35

53553.. 35

53554.. 35

53700.. 4

53701.. 4

53702.. 4

53703.. 4

53704.. 4

53710.. 4

53711.. 4

53712.. 4

53713.. 4

53714.. 4

53720.. 4

53721.. 4

53722.. 4

53723.. 4

53724.. 4

54340..

54341.. 6

54345.. 6

54346.. 6

82681.. 8

82686.. 8

82687.. 8

82688.. 8

82689.. 8

82697.. 7

82698.. 7

82699.. 7

83095.. 5

83098.. 6

83099.. 6

83100.. 6

83102.. 6

85004.. 16

85000..

85002..

85005..

85006..

85010.. 9

85011.. 9

85013.. 9

....................41

....................

.................... 5

.................... 7

....................65

.................... 6

......................

....................

....................62

.................... 6

.................... 5

85014.. 9

85015.. 9

85019.. 9

85030.. 9

85031.. 9

85032.. 9

85033.. 9

85034.. 9

85035.. 9

85036.. 9

85037.. 98

85038.. 98

85041.. 104

85044.. 10

85050.. 7

85051.. 7

85053..

85054.. 7

85055..

85059..

85066..

85072..

85073..

85074..

85078..

85080.. 9

85081..

85084.. 9

85085..

85092.. 8

85093.. 8

85094.. 8

85095.. 8

85096.. 8

85099.. 8

85100..

85102..

85103..

85104..

85120.. 11

85121.. 11

85122.. 10

85123.. 10

85125.. 10

85128.. 9

85131.. 12

85132.. 12

85133.. 12

85134.. 12

85139.. 11

85160.. 7

85162.. 7

85163..

85164..

.................... 5

.................... 6

.................... 8

.................... 7

.................... 8

.................... 7

.................... 8

....................

..................

.................. 4

.................... 9

....................80

.................... 9

....................80

....................23

..................101

..................102

..................101

..................102

.................... 4

....................93

.................... 4

....................93

.................... 8

.................... 7

.................... 8

..................103

....................

......................

....................

.................... 4

....................73

85165..

85167.. 7

85181..

85183..

85184..

85187..

85188..

85189..

85190..

85191..

85193..

85194..

85195..

85199..

85213..

85214..

85215..

85216..

85217..

85218..

85219..

85322.. 9

85323.. 9

85324.. 9

85325.. 9

85393.. 10

85394.. 10

85400..

85402..

85403..

85404..

85405..

85407..

85409..

85460..

85462..

85464.. 8

85465.. 8

85466.. 8

85468..

85469..

85482.. 7

85483.. 7

85484.. 7

85485.. 7

85487.. 7

85490.. 7

85492.. 7

85493.. 7

85494.. 77

85495.. 77

85497.. 7

85520.. 8

85522.. 8

....................73

.................... 4

....................92

....................91

....................92

....................91

....................82

....................81

....................82

....................64

....................63

....................64

.................... 9

.................. 5

....................72

....................71

....................72

....................90

.................... 9

....................90

.................... 5

.................... 6

.................... 8

.................... 7

....................

.................... 8

.................... 4

85523..

85524..

85525..

85527.. 8

85529.. 8

85585..

85595.. 8

85596..

85800.. 14

85801.. 14

85802.. 15

85803.. 15

85804.. 15

85805.. 14

85806.. 13

85807.. 16

85808.. 16

85809.. 16

85810.. 16

85812.. 17

85813.. 17

85814.. 17

85830.. 20

85831.. 20

85832.. 20

85840.. 20

85841.. 20

85842.. 20

85843.. 2

85880.. 2

85881.. 2

85885.. 2

85889.. 2

85924..

85926..

85928..

86093.. 8

86094.. 8

86095.. 8

86096.. 8

86190..

86192..

86194..

86195.. 6

86197.. 6

86200.. 68

86201.. 68

86202.. 6

86204.. 6

86205.. 6

86206.. 6

86207.. 6

86208.. 6

86222.. 6

....................83

.................... 4

....................23

.................... 4

....................83

....................

.................... 0

.................... 3

.................... 0

.................... 3

..................100

.................... 6

....................70

.................... 9

....................

.................... 8

.................... 7

.................... 9

86300..

86303..

86522.. 8

86523.. 8

86524.. 8

86525.. 8

86595.. 8

87005..

87006..

87007..

87011..

87012..

87015..

87016..

87017..

87200.. 2

87201.. 2

87202.. 2

87205.. 2

87206.. 2

87207.. 2

87210.. 21

87211.. 21

87212.. 21

87520.. 2

87521.. 2

87522.. 2

87530.. 2

87531.. 2

87803..

87805.. 3

87806.. 3

87807.. 3

87809.. 3

87817..

87818..

87819..

87820..

87823..

87850..

87856..

87857..

87858..

87860..

87881..

87883..

87902..

87904..

87906..

87912..

87913..

87914..

87916..

87920.. 10

....................65

.................... 5

....................26

....................21

....................24

.................... 5

....................

.................... 7

.................... 8

...............30,31

.................... 2

...............30,31

....................32

....................31

....................30

....................32

.................. 4

87950.. 2

87951.. 2

87952.. 2

88250..

88252..

88254..

88350..

88352..

88353.. 5

88354.. 5

88357..

.................... 2

....................61

....................60

.................... 9

....................60

maximlighting.com Index

maximlighting.com

107

Finishes maximlighting.com

800.486.2946 108

Finishes

ABZ

SST

Architectural Bronze

Antique Pecan

Artesian Bronze

Black

Brushed Metal

Burnished

Bronze

Country Forge

Chocolate

Copper Oxide

Empire Bronze

Espresso

Earth Tone

Bronze

Mottled Leather

Oriental Bronze

Oil Rubbed Bronze

Polished Brass

Platinum

Rust Patina

Satin Aluminum

Sienna

Satin Nickel

Satin Silver

Stainless Steel

Silver

Texture Ebony

Textured White

White

Glass Styles

Clear

Frost Crackle

Frost Lichen

Frosted Seedy

Frosted

Golden Frost

Honey

Ice

Latte

Mocha Cloud

Mocha

Marble

Snow Flake

Satin White

Tawny Linen

Wilshire

White

Installing new ENERGY STAR qualified light fixtures is a smart way to save energy and money. Maxim Lighting is proud to

be a ENERGY STAR partner. Look for this ENERGY STAR logo to find Maxim Lighting fixtures that use ¼ of the energy of

traditional incandescent fixtures and last up to 10 times longer. More information on ENERGY STAR can be found on the

ENERGY STAR web site at energystar.gov.

109 maximlighting.com

Energy Efficiency

All new homes, additions, alterations and most commercial buildings in California must meet minimum energy efficiency

standards contained in Title 24, Part 6 of the California Code of Regulations. When you see the California Title 24 symbol

next to a Maxim Lighting fixtures, you can be assured that the fixtures complies. More information on California Title 24

can be found on the California Energy Commission web site at energy.ca.gov/title24.

Energy Star

Certified

California

Title 24

Code Description Type

Lamping Guide

Code Description Type

LED

Fluorescent

MR16

2GX7

2G11

G24q-1

G24q-2

G24q-3

Gu24

Multifaceted Reflector

Bi-Pin GX5.3 Base

2” W

Twin Tube

4 Pin 2GX7 Base

6.2” MOL

Twin Tube

4 Pin 2G11 Base

16.313” MOL

Quad Tube

4 Pin G24q-1 Base

4.625” MOL

Quad Tube

4 Pin G24q-2 Base

5.75” MOL

Quad Tube

4 Pin G24q-3 Base

6.5” MOL

CFL

Bi-Pin GU24 Base

Tubular Circline

2GX13 Base

.625” W

Tubular Circline

4 Pin Base

1.125” W

Tubular

Mini Bipin Base

.625” W

Tubular

Medium Bipin Base

1” W

Fluorescent

Circline

800.486.2946 110

Replacement Bulbs

Item Type Code Note Watta

Warranty and Other Information

For specific and detailed warranty information, ask your Maxim Lighting sales representative or visit www.maximlighting.com/warranty.

Maxim Lighting reserves the right to change details of design, materials, colors and finishes. Color may vary from what is pictured due to limita-

tions inherent to the photographic process.

Always consult a qualified, licensed electrician before installation of any product weighing 35 pounds or more. We recommend that a qualified,

licensed electrician do installations. Always install to a mechanically sound structure.

Products in this supplement are UL, ETL and/or CSA certified. All electrical products are certified and listed to UL/CSA Standards for use in the

United States of America or Canada.

Bulbs are not included unless otherwise noted.

CounterMax, Maxim Lighting and StarStrand are registered trademarks of Maxim Lighting International, Inc. All designs, logos, products and images

BUFPL13036

BUFPL18037

BUFPL13038

BUFPL18039

BUFPL26044

BUFPL13026

BUFPL13004

BUFPL18005

BUFPL26006

BUFT522001

BUFT532002

BUFT540003

BUFT922018

BUFT932019

BUFT940020

BUFT508011

BUFT513012

BUFT516013

BUFT521014

BUFT526015

BULMR01040

BULMR03041

Fluorescent

LED

2GX7

2G11

G24q-1

G24q-2

G24q-3

GU24

Circline T5

Circline T9

MR16

2700 K

2700 K, Squat

2700 K

3000 K

3100 K

3100 K, 12” Long

3100 K, 21” Long

3100 K, 24” Long

3100 K, 36” Long

3100 K, 48” Long

3500 K

1.3

3.7

LMXCAT1102

$5.00

Maxim Lighting International

253 North Vineland Avenue

City of Industry, California

91746

USA

General Info:

Customer Service:

General Fax:

626.956.4200

800.486.2946

626.956.4235

Dallas Trade Mart:

Showroom:

Email:

Web:

214.748.8455

3901

info@maximlighting.com

www.maximlighting.com

3M Brand is a trademark and copyright of 3M. Nichia

is a trademark and copyright of Nichia Corporation.

CounterMax, Maxim Lighting and StarStrand are

registered trademarks of Maxim Lighting International,

Inc. All designs, logos, images and products 2011

Printed in China. LMXCAT1102 1107

Maxim Lighting Energy Efficient Product Catalog

Navigation menu

Versions of this User Manual:

Views

Navigation
