CONDUIT
Flexible Conduit
Cantex . . . . . . .412
Carlon . . .412-413
AFC Cable Systems . . .414-415
Conduit Fittings
Elbows & Connectors . . .416-449
Couplings & Adapters . . .450-460
Locknuts & Bushings . . .461-464
Reducers . . .465-468
Nipples . . . . . . .469
Entrance Caps . . . . . . .470
Flashings . . . . . . .471
Seals . . .472-473
End Caps, Blanks & Plugs . . .474-475
Conduit Bodies & Boxes
Conduit Bodies . . .476-481
Outlet Boxes . . .482-485
Covers . . . . . . .486
Conduit Supports
Clamps . . .487-491
Straps . . .492-496
Hangers . . .497-500
Supports . . .501-502
Cement & Fiber Filler . . . . . . .503
411.qxp 9/5/07 10:22 AM Page 411
FLEXIBLE CONDUIT
412 hdsupply.com
Conduit
Cantex
Enviro-Flex Liquidtight Conduit
Enviro-Flex offers advantages compared to metal conduit: Enviro-Flex
costs less to install. It is easy to cut with no jagged edges, is less than
1/2 the weight of metal and can utilize all existing liquidtight fittings.
Enviro-Flex is more flexible and its smooth inner bore makes pulling
wires easier than ever. Enviro-Flex is waterproof, acid, oil, alkaline, and
corrosion resistant. It is non-conducive, self-extinguishing, extremely
resistant to crush, abrasion, and strain. UL listed for constant use at
maximum 60°C (140°F) and for sunlight resistance.
EZ Flex Coils and Reels
Carlon®
Flex-Plus®Blue™ENT Conduit
Standard Stock –Reels
Flex-Plus Blue ENT is a nonmetallic flexible raceway for use in walls,
floors, and non-plenum ceilings. It's light-weight, hand bendable, and
free from sharp edges, which reduces installation time and saves
money.
Standards: UL listed.
• Yellow color for communication circuits and signaling cable
• Red color for fire alarm circuits
• Blue color for power circuits
Model No. Hughes No.
Conduit
Size (In.)
Reel
Length (ft.) Unit List Price
V06ADA1 HBYX370 3/8 100 Reel Call
V06AEA1 HBYX601 1/2 100 Reel Call
V06AGA1 HBYX602 3/4 100 Reel Call
V06BAA1 HEJX260 1 100 Reel Call
V06BCN1 HBYX567 1-1/4 50 Reel Call
V06BEN1 HBYX568 1-1/2 50 Reel Call
V06CAN1 HBYX569 2 50 Reel Call
Model No. Conduit Size (In.) Length (ft.) Unit List Price
A51AEB1 1/2 200 Coil Call
A51AGA1 3/4 100 Coil Call
A51AEQ1 1/2 1500 Reel Call
A51AGJ1 3/4 1000 Reel Call
A51BAJ1 1 1000 Reel Call
Model No. Hughes No. Color Reel Length (ft.) Unit List Price
1/2", Inner Diameter: .56", Outer Diameter: .84", Minimum Bend Radius: 6"
12005AK-001 HDVT836 Blue 1500 EA Call
1205AKY-001 HECP150 Yellow 1500 EA Call
1205AKR-001 HECP149 Red 1500 EA Call
3/4", Inner Diameter: .76", Outer Diameter: 1.05", Minimum Bend Radius: 6"
12007AA-001 HECJ644 Blue 1000 EA Call
1207AAY-001 HEDP716 Yellow 1000 EA Call
1207AAR-001 HEDQ448 Red 1000 EA Call
1", Inner Diameter: 1.00", Outer Diameter: 1.315", Minimum Bend Radius: 6"
12008-750 HDUB041 Blue 750 EA Call
12008Y-750 HECP148 Yellow 750 EA Call
12008R-750 HEDQ447 Red 750 EA Call
1-1/4", Inner Diameter: 1.402", Outer Diameter: 1.66", Minimum Bend Radius: 7"
12009-750 HECO328 Blue 750 EA Call
1-1/2", Inner Diameter: 1.554", Outer Diameter: 1.90",
Minimum Bend Radius: 8-1/4"
12010-750 HECO330 Blue 750 EA Call
2", Inner Diameter: 2.030", Outer Diameter: 2.375", Minimum Bend Radius: 9-1/2"
12011-500 HECO329 Blue 500 EA Call
12011R-500 HEDP904 Red 500 EA Call
412-413.qxp 9/5/07 8:53 AM Page 412
FLEXIBLE CONDUIT
hdsupply.com 413
Conduit
Carlon®
Flex-Plus®Blue™ENT Conduit
Standard Stock –Coils
Flex-Plus Blue ENT is a nonmetallic flexible raceway for use in walls,
floors, and non-plenum ceilings. It's light-weight, hand bendable, and
free from sharp edges, which reduces installation time and saves money.
Standards: UL listed
• Yellow color for communication circuits and signaling cable
• Red color for fire alarm circuits
• Blue color for power circuits
Carlon®
Carflex®Liquidtight
Rigid Nonmetallic Conduit
Carflex Liquidtight Flexible Nonmetallic Conduit provides superior wire
protection in harsh, damp environments. Carflex Conduit is nonconductive,
noncorrosive, and resistant to oil acid, ozone, and alkaline. Carflex Conduit
is strong and lightweight, and because it weighs 50% less than metallic
systems, it's easy to handle, transport and install. Carflex is ideal for
industrial, air conditioning, heating and outdoor lighting applications.
• Sunlight resistant
• UL listed for outdoor use
• Nonconductive and noncorrosive
• Lightweight for easy handling, transportation, and installation
• Crush-, abrasion- and strain- resistant
• Provides superior wire protection
• Smooth interior ideal for pulling cable
• No jagged edges
• Maintains internal I.D. even in tight radius bends
• Type LFNC-B
Available in black and gray. Consult Hughes Supply representative for custom colors.
* Joint listed UL/CSA Approved product available
Model No. Hughes No. Color Coil Length (ft.) Unit List Price
1/2", Inner Diameter: .56", Outer Diameter: .84", Minimum Bend Radius: 6"
12005-200 HECP449 Blue 200 EA Call
12005Y-200 HECJ684 Yellow 200 EA Call
12005R-200 HECP016 Red 200 EA Call
3/4", Inner Diameter: .76", Outer Diameter: 1.05", Minimum Bend Radius: 6"
12007-100 HECP774 Blue 100 EA Call
12007Y-100 HEFT389 Yellow 100 EA Call
12007R-100 HECP147 Red 100 EA Call
1", Inner Diameter: 1.00", Outer Diameter: 1.315", Minimum Bend Radius: 6"
12008-100 HEFY159 Blue 100 EA Call
12008Y-100 HECN070 Yellow 100 EA Call
12008R-100 HECW364 Red 100 EA Call
Model No. Hughes No. Conduit Size (In.) Length (Ft.) Unit List Price
Coils
15005-100* HDYY706 1/2 100 EA Call
15007-100* HDZA115 3/4 100 EA Call
15008-100* HDXT374 1 100 EA Call
15009-100 HECN704 1-1/4" 100 EA Call
15010-100 HECN594 1-1/2" 100 EA Call
15011-050 HECJ485 2" 50 EA Call
Reels
15005-001 HDYZ278 1/2" 1000 EA Call
15007-001 HDZA483 3/4" 1000 EA Call
15008-500 HDZA927 1" 500 EA Call
15009-200 HECP151 1-1/4" 200 EA Call
15010-150 HECP152 1-1/2" 150 EA Call
15011-100 HECN741 2" 100 EA Call
Some products not available at all locations. Check with
your local HD Supply representative for product availability.
412-413.qxp 9/5/07 8:53 AM Page 413
FLEXIBLE CONDUIT
414 hdsupply.com
Conduit
AFC Cable Systems®
Liquid-tight Flexible Metal Conduit
UL Liquidtight Liquid-Tuff™Type LFMC
• UL bonded strip 3⁄8"–1-1⁄4"
• UL Liquidtight all sizes
• Sunlight resistant
• Flame retardant PVC jacket
• Hot dipped zinc galvanized low carbon steel core
• Blue PVC jacket
• Raised computer room floors per NEC®645.5(D)
• 600 volt and lower circuits
• Direct burial in earth
• Concrete embedment
• Suitable for grounding per NEC®250.118(7)
• Hazardous location per NEC®501
Model No. Hughes No.
Conduit
Size (In.)
Length
(Ft.)
Bend
Radius (in.) Unit List Price
6402-30-00 HGJB585 1/2 100' 3.25 Coil Call
6402-45-00 HGJB586 1/2 500' 3.25 Reel Call
6402-60-00 HGJB587 1/2 1000' 3.25 Reel Call
Flexible Metal Conduit
Reduced Wall Aluminum
• Premium aluminum alloy
• Interlocking design
• Flexible metal raceway for electrical power, control and
communication cables
• Motor leads
• Listed assemblies
• Listed wire fixtures
• Manufactured wiring systems
Model No. Hughes No.
Conduit
Size (In.)
Length
(Ft.)
Bend
Radius (in.) Unit List Price
5601-30-00 HGJB062 3/8 100' 2 coil Call
5602-22-00 HGJB066 1/2 25' 3 coil Call
5602-24-00 HGJB067 1/2 50' 3 coil Call
5602-30-00 HGJB068 1/2 100' 3 coil Call
5603-24-00 HGJB073 3/4 50' 4 coil Call
5603-30-00 HGJB074 3/4 100' 4 coil Call
5604-24-00 HGJB078 1 50' 5 coil Call
5605-24-00 HGJB080 1-1/4 50' 6.25 coil Call
5606-22-00 HGJB082 1-1/2 25' 7.50 coil Call
5607-22-00 HGJB083 2 25' 10 coil Call
5608-22-00 HGJB084 2-1/2 25' 12.50 coil Call
5609-22-00 HGJB085 3 25' 15 coil Call
Liquid-tight Flexible Metal Conduit
Non-UL Liquidtight, Liquid-Tuff™Type LFMC-VF
• General wiring applications
• Mechanical and moisture protection for conductors
• Sunlight resistant
• Flame retardant PVC jacket
• Hot dipped zinc galvanized low carbon steel core
• Very flexible
• 600 volt and lower circuits
• Industrial and machine tool applications
• Vibration and movement absorbing
Extra Flexible Conduit
• Non-UL
• High grade galvanized low carbon steel
• Interlocking design
• Corrosion resistant
• Flexible metal raceway for electrical power, control
and communication cables
• Motor leads
Model No. Hughes No.
Conduit
Size (In.)
Length
(Ft.)
Bend
Radius (in.) Unit List Price
6101-30-00 HGJB088 3/8 100' 2 coil Call
6102-30-00 HGJB091 1/2 100' 3.25 coil Call
6103-30-00 HGJB094 3/4 100' 4.25 coil Call
6104-30-00 HGJB097 1 100' 6.5 coil Call
6105-24-00 HGJB098 1-1/4 50' 8 coil Call
6106-24-00 HGJB100 1-1/2 50' 9 coil Call
6107-24-00 HGJB101 2 50' 11.12 coil Call
6108-22-00 HGJB102 2-1/2 25' 14.62 coil Call
6109-22-00 HGJB103 3 25' 17.5 coil Call
6120-22-00 HGJB567 3-1/2 25' 20 coil Call
6110-22-00 HGJB104 4 25' 24 coil Call
Model No. Hughes No.
Conduit
Size (In.)
Length
(Ft.)
Bend
Radius (in.) Unit List Price
5201-42-00 HGJB013 3/8 250' 2 coil Call
5201-45-00 HGJB014 3/8 500' 2 reel Call
5201-60-00 HGJB015 3/8 1000' 2 reel Call
414-415.qxp 9/5/07 8:53 AM Page 414
FLEXIBLE CONDUIT
hdsupply.com 415
Conduit
Note: All dimensions and weights are subject to normal manufacturing tolerances.
AFC Cable Systems®
Reduced Wall Flexible Steel Conduit
• High grade hot dipped zinc galvanized low carbon steel
• Interlocking design
• Corrosion resistant
• Flexible metal raceway for electrical power, control
and communication cables
• Motor leads
• Listed assemblies
• Listed wire fixtures
• Manufactured wiring systems
Model No. Hughes No.
Conduit
Size (In.)
Length
(Ft.)
Bend
Radius (in.) Unit List Price
5501-30-00 HGJB036 3/8 100' 2 Coil Call
5502-22-00 HGJB040 1/2 25' 3 Coil Call
5502-24-00 HGJB041 1/2 50' 3 Coil Call
5502-30-00 HGJB042 1/2 100' 3 Coil Call
5502-45-00 HGJB043 1/2 —3 Coil Call
5502-60-00 HGJB044 1/2 —3 Coil Call
5503-24-00 HGJB046 3/4 50' 4 Coil Call
5503-30-00 HGJB047 3/4 100' 4 Coil Call
5504-24-00 HGJB050 1 50' 5 Coil Call
5505-24-00 HGJB052 1-1/4 50' 6.25 Coil Call
5506-22-00 HGJB054 1-1/2 25' 7.50 Coil Call
5507-22-00 HGJB055 2 25' 10 Coil Call
5508-22-00 HGJB056 2-1/2 25' 12.50 Coil Call
5509-22-00 HGJB057 3 25' 15 Coil Call
5510-22-00 HGJB058 3-1/2 25' 17.50 Coil Call
5511-22-00 HGJB059 4 25' 20 Coil Call
Power and Appliance Whips
Metallic
• Conduit: Galvanized type RW steel flexible metal conduit
• Conductors: THHN 14AWG and larger 18 & 16AWG TFN/TFFN
• Maximum temperature rating: 90°C (dry)
• Grounding: NEC 250.118(5) many styles with green grounding
conductor
• Maximum voltage rating: 600V
• Connectors: Screw-in, die-cast connector is strandard
• Connectors are U.L. listed for grounding - 600V
• Units per package: 30
Model No. Hughes No. Description
Wire Size
(AWG) Unit List Price
4522-21 HGJB506 Solid conductor 18-3 EA Call
4502-21 HGJB494 Solid conductor 14-3 EA Call
4503-21 HGJB496 Solid conductor 14-4 EA Call
4622-21 HGJB529 Stranded conductor 18-3 EA Call
4602-21 HGJB518 Stranded conductor 14-3 EA Call
4679-21 HGJB535 Stranded conductor 3-Dec EA Call
4603-21 HGJB520 Stranded conductor 14-4 EA Call
414-415.qxp 9/5/07 8:53 AM Page 415
CONDUIT FITTINGS Elbows & Connectors
416 hdsupply.com
Conduit
Cantex
Enviro-Flex Straight Connectors
Enviro-Flex gives complete environmental protection for exposed cable
installations and is ideal for use with control and motor applications,
machinery tools, moving machinery, console wire, transformer
connections, outdoor lighting, air conditioning and heating.
Enviro-Flex is waterproof, acid, oil, alkaline, and corrosion resistant. It is
non-conducive, self-extinguishing, extremely resistant to crush,
abrasion, and strain. UL listed for constant use at maximum 60°C (140°F)
and for sunlight resistance.
90°Elbows - Plain End
Schedule 80
Larger radii and other degree bends available upon request.
Enviro-Flex 90-Degree Connectors
Enviro-Flex gives complete environmental protection for exposed cable
installations and is ideal for use with control and motor applications,
machinery tools, moving machinery, console wire, transformer
connections, outdoor lighting, air conditioning and heating.
Enviro-Flex is waterproof, acid, oil, alkaline, and corrosion resistant. It is
non-conducive, self-extinguishing, extremely resistant to crush,
abrasion, and strain. UL listed for constant use at maximum 60°C (140°F)
and for sunlight resistance.
Special Radius Elbows - Plain End
Schedule 80
Model No. Hughes No. Conduit Size (In.) Unit List Price
5121054 HEGQ427 3/4 Pack Call
5121055 HEGQ428 1 Pack Call
5121056 HEGQ429 1-1/4 Pack Call
5121057 HEGQ539 1-1/2 Pack Call
5121058 HEGQ540 2 Pack Call
5121059 HEGQ541 2-1/2 Pack Call
5121060 HEGQ542 3 Pack Call
5121061 HEGQ437 4 Pack Call
Model No. Hughes No. Conduit Size (In.) Radius (in.) Unit List Price
5121099 HEJV471 2 18 EA Call
5121079 HEJV395 3 18 EA Call
5121020 HEJV307 3 24 EA Call
5121081 HEGQ398 3 36 EA Call
5121023 HEGQ397 4 36 EA Call
5121024 HEJV329 4 48 EA Call
5121083 HEJV430 5 36 EA Call
5121026 HEJV340 6 48 EA Call
Model No. Hughes No. Conduit Size (In.) Package Qty. Unit List Price
5441000 HEJW504 3/8 50 Pack Call
5441001 HEGQ524 1/2 50 Pack Call
5441002 HEGQ525 3/4 50 Pack Call
5441003 HEGQ506 1 25 Pack Call
5441004 HEJV182 1-1/4 25 Pack Call
5441005 HEJV187 1-1/2 10 Pack Call
5441006 HEJV191 2 10 Pack Call
Model No. Hughes No.
Conduit
Size (In.) Package Qty. Unit List Price
6441000 HEJW510 3/8 100 Pack Call
6441001 HEGQ526 1/2 100 Pack Call
6441002 HEGQ527 3/4 50 Pack Call
6441003 HEGQ508 1 25 Pack Call
6441004 HEJV194 1-1/4 25 Pack Call
6441005 HEJV199 1-1/2 10 Pack Call
6441006 HEJV203 2 10 Pack Call
416-417.qxp 9/5/07 8:53 AM Page 416
hdsupply.com 417
Conduit
Elbows & Connectors CONDUIT FITTINGS
Cantex
Special Radius Elbows - Plain End
Schedule 40
Special Radius Elbows - Bell End
Schedule 40
Elbows for Type EB & DB Duct
TC6
Larger radii and other degree bends available upon request.
Special Radius Elbows for Type EB & DB Duct
TC8 - Belled End
Model No. Hughes No.
Conduit
Size (In.)
Angle
(Degrees)
Radius
(in.) Unit List Price
5133846 HEJV785 1 90 18 EA Call
5133859 HEGQ417 1 90 24 EA Call
5133866 HEJV858 1-1/2 90 36 EA Call
5133873 HEGQ418 1-1/2 90 24 EA Call
5133884 HEJV952 1-1/4 90 36 EA Call
5133778 HEGQ399 2 45 36 EA Call
5133815 HEJV709 2 45 24 EA Call
5133876 HEGQ419 2 90 48 EA Call
5133848 HEGQ414 2 90 36 EA Call
5133836 HEGQ408 2 90 24 EA Call
5134010 HDWF026 2-1/2 45 48 EA Call
5133935 HEJW093 2-1/2 45 24 EA Call
5133857 HEGQ416 2-1/2 90 36 EA Call
5133847 HEGQ413 2-1/2 90 24 EA Call
5133779 HEGQ400 3 45 36 EA Call
5133799 HFEF846 3 45 18 EA Call
5133817 HEGQ403 3 90 48 EA Call
5133820 HEGQ405 3 90 36 EA Call
5133837 HEGQ409 3 90 24 EA Call
5133845 HEJV778 3 22-1/2 18 EA Call
5133777 HEJV544 4 45 36 EA Call
5133854 HFEF416 4 90 60 EA Call
5133843 HEGQ412 4 90 48 EA Call
5133821 HEGQ406 4 90 36 EA Call
5133822 HEGQ407 4 90 24 EA Call
5133841 HEGQ410 5 90 36 EA Call
5133806 HEJV664 6 45 60 EA Call
5133813 HEJV697 6 45 48 EA Call
5133905 HEGQ423 6 22-1/2 36 EA Call
5133880 HEGQ421 6 45 36 EA Call
5133877 HEGQ420 6 90 36 EA Call
Model No. Hughes No.
Conduit
Size (In.)
Angle
(Degrees)
Radius
(in.) Unit List Price
5233848 HEJW246 2 90 36 EA Call
5233876 HEJW307 2 90 48 EA Call
5233935 HEJW197 2-1/2 45 24 EA Call
5233801 HEJW261 2-1/2 45 36 EA Call
5233847 HEJW189 2-1/2 90 24 EA Call
5233857 HEJW256 2-1/2 90 36 EA Call
5233837 HEJW201 3 90 24 EA Call
5233930 HEJW267 3 90 36 EA Call
5233812 HEJW243 4 45 24 EA Call
5233777 HEJW210 4 45 36 EA Call
5233822 HEJW235 4 90 24 EA Call
5233842 HEGQ424 4 90 36 EA Call
5233781 HEJW358 5-1/2 45 48 EA Call
5233841 HEJW216 5-1/2 90 36 EA Call
5233877 HEJW304 6 90 36 EA Call
5233816 HEJW365 6 90 48 EA Call
Model No. Hughes No.
Conduit
Size (In.)
Angle
(Degrees) Unit List Price
5123866 HBYW074 2 90 EA Call
5123867 HBYW075 2 90 EA Call
5123868 HBYX279 2 90 EA Call
5123870 HBYX281 3 90 EA Call
5123872 HBYX283 3 90 EA Call
5123772 HBYX261 3 45 EA Call
5123875 HBYX284 4 90 EA Call
5123876 HBYX285 4 90 EA Call
5123776 HBYX263 4 45 EA Call
5123880 HBYX302 5 90 EA Call
5123794 HBYX272 6 45 EA Call
5123733 HFEF367 6 11-1/4 EA Call
Model No. Hughes No.
Conduit
Size (In.)
Angle
(Degrees)
Radius
(in.) Unit List Price
5125881 HFEF404 2 90 24 EA Call
5125869 HFEF394 2 90 36 EA Call
5125740 HFEF375 2 90 48 EA Call
5125872 HFEF396 3 90 36 EA Call
5125876 HFEF399 4 90 36 EA Call
5125776 HFEF385 4 45 36 EA Call
5125884 HFEF405 6 90 36 EA Call
416-417.qxp 9/5/07 8:54 AM Page 417
CONDUIT FITTINGS Elbows & Connectors
418 hdsupply.com
Conduit
*Gray connectors provided with assembled o-ring and metal locknuts. Black connectors
provided with nylon locknuts only.
Carlon®
Carflex®Omni Connectors
Straight L/T Fitting
• Standards: cUL listed
• Available in sizes 3⁄8" through 1" conduit and tubing.
• All nylon construction resists salt water, weak acids, gasoline,
alcohol, oil, grease and common solvents.
• No disassembly required.
• No threading of the conduit or tubing required to install.
• Complete Conduit/connector system is reusable.
• Suitable for indoor/outdoor use.
Carflex®Omni Connectors
90 degree L/T Fitting
• Standards: cUL listed
• Available in sizes 3⁄8" through 1" conduit and tubing.
• Smooth internal surfaces for easier wire installation around
corner angles.
• All nylon construction resists salt water, weak acids, gasoline,
alcohol, oil, grease and common solvents.
• No disassembly required.
• No threading of the conduit or tubing required to install.
• Complete Conduit/connector system is reusable.
• Use of a sealing washer may be required for wet locations.
• Suitable for indoor/outdoor use.
Carflex®90°Fittings
One-Piece Liquidtight Nonmetallic Fittings
The simple, one piece body design of the Carflex One Piece Liquidtight
Nonmetallic Fitting requires no disassembly of components for
installation. The system is so strong that there is no need for a
compression nut.
PVC construction of the fitting and locknut provides unparalleled
protection from water, oil and dust. Totally nonmetallic, the system is
nonconductive and will not corrode or rust. Temperatures up to 140°F
(60°C)
Standards: cUL listed
Model No. Hughes No. Conduit Size (In.) Thread Size Unit List Price
LN20DA HDVU894 1/2 –14 NPT 1/2 –14 NPT EA Call
LN20EA HECO500 3/4 –14 NPT 3/4 –14 NPT EA Call
LN20FA HEHD854 1 –11-1/2 NPT 1 –11-1/2 NPT EA Call
Carflex®Straight Fittings
One-Piece Liquidtight Nonmetallic Fittings
The simple, one piece body design of the Carflex One Piece Liquidtight
Nonmetallic Fitting requires no disassembly of components for
installation. The system is so strong that there is no need for a
compression nut.
PVC construction of the fitting and locknut provides unparalleled
protection from water, oil and dust. Totally nonmetallic, the system is
nonconductive and will not corrode or rust. Temperatures up to 140°F
(60°C)
Standards: cUL listed
Model No. Hughes No. Conduit Size (In.) Unit List Price
LN43DA HECN421 1/2 –14 NPT EA Call
LN43EA HECO498 3/4 –14 NPT EA Call
LN43FA HEHD855 1 –11-1/2 NPT EA Call
Model No. Hughes No.
Conduit
Size (In.)
Clearance
Size (in.)
Thread
Length (In.) Unit List Price
Black
LT38 HCMG168 3/8" .875 (22.2) .625 (15.9) EA Call
LT50 HCMG170 1/2" .875 (22.2) .625 (15.9) EA Call
LT75 HCMG172 3/4" 1.109 (28.2) .625 (15.9) EA Call
LT100 HCMG323 1" 1.375 (34.9) .781 (19.8) EA Call
Gray*
LT38G HCMG169 3/8" .875 (22.2) .625 (15.9) EA Call
LT50G HCMG171 1/2" .875 (22.2) .625 (15.9) EA Call
LT75G HCMG173 3/4" 1.109 (28.2) .625 (15.9) EA Call
LT100G HCMG167 1" 1.375 (34.9) .781 (19.8) EA Call
Model No. Hughes No.
Conduit
Size (In.)
Clearance
Size (in.)
Thread
Length (In.) Unit List Price
Black
LT938 HCMG176 3/8" .875 (22.2) .52 (13.2) EA Call
LT950 HCMG178 1/2" .875 (22.2) .52 (13.2) EA Call
LT975 HCMG325 3/4" 1.109 (28.2) .52 (13.2) EA Call
LT9100 HCMG174 1" 1.375 (34.9) .78 (19.8) EA Call
Gray
LT938G HCMG177 3/8" .875 (22.2) .52 (13.2) EA Call
LT950G HCMG324 1/2" .875 (22.2) .52 (13.2) EA Call
LT975G HCMG326 3/4" 1.109 (28.2) .52 (13.2) EA Call
LT9100G HCMG175 1" 1.375 (34.9) .78 (19.8) EA Call
“List Price” refers to manufacturer’s suggested list price.
Prices subject to change without notice.
418-419.qxp 9/5/07 8:54 AM Page 418
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 419
Conduit
Carlon®
Liquidtight Nonmetallic Fittings
Carflex®90°Fittings
Standards: UL listed.
For use with Carflex®conduit and Carflex®X-Flex™conduit
• Nonconductive and Noncorrosive
• Resistant to oil, acid, ozone, and alkaline
• Easy to install
• Nitrile rubber "O" ring for a liquidtight termination
• Temperatures up to 225°F (107°C)
Model No. Hughes No. Conduit Size (In.) Unit List Price
LT20C-CAR HECN399 3/8 EA Call
LT20D-NEW HDZD186 1/2 EA Call
LT20E-NEW HDZD199 3/4 EA Call
LT20F HDZD211 1 EA Call
LT20G HECO178 1-1/4 EA Call
LT20H HECO179 1-1/2 EA Call
LT20J HECN256 2 EA Call
Liquidtight Nonmetallic Fittings
Carflex®Straight Fittings
Standards: cUL listed.
For use with Carflex®conduit and Carflex®X-Flex™conduit
• Nonconductive and Noncorrosive
• Resistant to oil, acid, ozone, and alkaline
• Easy to install
• Nitrile rubber "O" ring for a liquidtight termination
• Temperatures up to 225°F (107°C)
Model No. Hughes No. Conduit Size (In.) Unit List Price
LT43C-CAR HECN398 3/8 EA Call
LT43D-NEW HDZC939 1/2 EA Call
LT43E-NEW HDZC669 3/4 EA Call
LT43F HDZD170 1 EA Call
LT43G HDVT291 1-1/4 EA Call
LT43H HEHD059 1-1/2 EA Call
LT43J HECN121 2 EA Call
Rigid Nonmetallic Conduit
Schedule 80 90°Elbow, Standard
Radius Plain End
Standards: UL listed and ETL listed.
Rigid Nonmetallic Conduit
Schedule 80 90°Elbow, Special
Radius Plain End
Standards: UL listed and ETL listed.
Model No. Hughes No. Conduit Size (In.) Unit List Price
UB9AD-CAR HEDM623 1/2" EA Call
UB9AE-CAR HECM919 1/2" EA Call
UB9AF-CAR HEDQ574 1" EA Call
UB9AG HEVJ395 1-1/4" EA Call
UB9AH HEVJ396 1-1/2" EA Call
UB9AJ HEVJ397 2" EA Call
UB9AK-CAR HEDM625 2-1/2" EA Call
UB9AL-CAR HECN124 3" EA Call
UB9AN HECO643 4" EA Call
UB9AP HECD537 5" EA Call
UB9AR HEDP798 6" EA Call
Model No. Hughes No.
Nominal Diameter
(in.) Radius (in.) Unit List Price
UB9CF HEDQ268 1" 18" EA Call
UB9DF HEDQ271 1" 24" EA Call
UB9FF HECO800 1" 36" EA Call
UB9HF HEDQ273 1" 48" EA Call
UB9CG HEDQ269 1-1/4" 18" EA Call
UB9DG HECO906 1-1/4" 24" EA Call
UB9FG HECO907 1-1/4" 36" EA Call
UB9HG HEDQ274 1-1/4" 48" EA Call
UB9CH HECO899 1-1/2" 18" EA Call
UB9DH-UPC HECO900 1-1/2" 24" EA Call
UB9FH HECO901 1-1/2" 36" EA Call
UB9HH HEDQ275 1-1/2" 48" EA Call
UB9CJ HECO902 2" 18" EA Call
UB9DJ-UPC HECO903 2" 24" EA Call
UB9FJ HECO904 2" 36" EA Call
UB9HJ HECO905 2" 48" EA Call
UB9CK HEDQ270 2-1/2" 18" EA Call
UB9DK-UPC HECO798 2-1/2" 24" EA Call
UB9FK HECO799 2-1/2" 36" EA Call
UB9HK HECO908 2-1/2" 48" EA Call
UB9CL HECO909 3" 18" EA Call
UB9DL HECO910 3" 24" EA Call
UB9FL HECO911 3" 36" EA Call
UB9HL HECO912 3" 48" EA Call
UB9DN HECO913 4" 24" EA Call
UB9FN HECO914 4" 36" EA Call
UB9HN HECO915 4" 48" EA Call
UB9FP HECO916 5" 36" EA Call
UB9HP HECO917 5" 48" EA Call
UB9FR HEDQ272 6" 36" EA Call
UB9HR HECP146 6" 48" EA Call
418-419.qxp 9/5/07 8:54 AM Page 419
CONDUIT FITTINGS Elbows & Connectors
420 hdsupply.com
Conduit
Rigid Nonmetallic Conduit
Access Pull Elbows
Standards: UL listed.
Gasket Included.
Carlon®
Rigid Nonmetallic Conduit
Schedule 40 90°Elbows, Special Radius Plain End
Standards: UL listed.
Model No. Hughes No. Conduit Size (In.) Radius (in.) Unit List Price
UA9DF HECO689 1" 24" EA Call
UA9DG HECO724 1-1/4" 24" EA Call
UA9DH HECO675 1-1/2" 24" EA Call
UA9FH HECO725 1-1/2" 36" EA Call
UA9DJ HECP017 2" 24" EA Call
UA9FJ-UPC HECO678 2" 36" EA Call
UA9DK HECO898 2-1/2" 24" EA Call
UA9FK-UPC HECO680 2-1/2" 36" EA Call
UA9DL HECP142 3" 24" EA Call
UA9FL HECO682 3" 36" EA Call
UA9DM HEAZ527 3-1/2" 24" EA Call
UA9FM HECN747 3-1/2" 36" EA Call
UA9DN HECO685 4" 24" EA Call
UA9FN HECO687 4" 36" EA Call
UA9HN HECO688 4" 48" EA Call
UA9FP HECO691 5" 36" EA Call
UA9HP HECN863 5" 48" EA Call
UA9FR HECO692 6" 36" EA Call
UA9HR HECO693 6" 48" EA Call
Model No. Hughes No.
Size
(In.)
Standard Carton
Quantity Unit List Price
Dimensions (inches): .852 x .836 x 2.187 x .718
E990D HEVJ399 1/2 75 EA Call
E990DR-CAR HECJ582 1/2 25 EA Call
Dimensions (inches): 1.064 x 1.046 x 2.531 x .781
E990ER-CAR HEDM621 3/4 20 EA Call
420-421.qxp 9/5/07 8:54 AM Page 420
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 421
Conduit
Steel City®- T&B
Liquidtight Flexible Metal Conduit Connectors
Straight Connectors
Model No. Hughes No. Conduit Size (In.) Unit List Price
LT-100 HBJY540 3/8" EA $3.89
LT-101 HBJY652 1/2" EA 3.73
LT-102 HBJY653 3/4" EA 5.15
LT-103 HBJY654 1" EA 7.90
LT-104 HBJY655 1-1/4" EA 13.76
LT-105 HBJY711 1-1/2" EA 19.58
LT-106 HBJY712 2" EA 35.81
Liguidtight Flexible Metal Conduit Connectors
Straight Connectors
Die-Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
LT-200 HBJY784 3/8" EA $3.70
LT-201 HBAK345 1/2" EA 3.53
LT-202 HBJY785 3/4" EA 5.36
LT-203 HBJY786 1" EA 8.11
LT-205 HBJY788 1-1/2" EA 20.60
LT-206 HBJY789 2" EA 34.26
LT-207 HBJY819 2-1/2" EA 115.19
LT-208 HBJY820 3" EA 124.39
LT-209 HBJY821 3-1/2" EA 154.12
LT-210 HBJY822 4" EA 170.91
Liquidtight Flexible Metal Conduit Connectors
90°Connectors
Die-Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
LT-290 HBJY794 3/8" EA $5.84
LT-291 HBAJ355 1/2" EA 5.57
LT-292 HBJY795 3/4" EA 8.63
LT-293 HBJY796 1" EA 14.25
LT-294 HBJY797 1-1/4" EA 23.65
LT-295 HBJY798 1-1/2" EA 35.23
LT-296 HBJY799 2" EA 48.22
Liguidtight Flexible Metal Conduit Connectors
90°Connectors
Malleable Iron/Zinc Plated
Model No. Hughes No. Conduit Size (In.) Unit List Price
LT-490 HBJY830 3/8" EA $5.81
LT-491 HBJY831 1/2" EA 5.57
LT-492 HBJY833 3/4" EA 8.66
LT-493 HBJY834 1" EA 17.98
XC-220 and XC-221: U.L. File No. E-17909 3/8"
U.L. File No. E-1275 1/2"
Armored Cable/Flexible Metallic Conduit Fittings
Straight Set Screw Connectors
Die Cast Zinc –Noninsulated
Model No. Hughes No. Conduit Size (In.) Unit List Price
XC-220 HGZO803 3/8" (1/2" KO) EA Call
XC-221 HBJZ038 1/2" EA 0.92
Some products not available at all locations. Check with
your local HD Supply representative for product availability.
420-421.qxp 9/5/07 8:54 AM Page 421
CONDUIT FITTINGS Elbows & Connectors
422 hdsupply.com
Conduit
Steel City®- T&B
Armored Cable/Flexible Metallic Conduit Fittings
Straight Squeeze Type Connectors
Die Cast Zinc
Armored Cable/Flexible Metallic Conduit Fittings
Straight Squeeze Type Connectors
Malleable Iron or Stamped Steel / Zinc Plated
Model No. Hughes No. Conduit Size (In.) Unit List Price
XC-400 HBJZ073 3/8" (1/2" KO) EA $2.28
XC-401 HBJZ074 1/2" EA 2.22
XC-402 HBJZ075 3/4" EA 2.57
XC-403 HBJZ076 1" EA 5.53
XC-404 HBJZ077 1-1/4" EA 8.97
XC-405 HBJZ078 1-1/2" EA 12.44
XC-406 HBJZ079 2" EA 17.18
XC-407 HBJZ080 2-1/2" EA 32.99
XC-408 HBJZ081 3" EA 45.37
Armored Cable/Flexible Metallic Conduit Fittings
90°Angle Squeeze Type Connectors
Steel or Malleable Iron / Zinc Plated
Model No. Hughes No. Conduit Size (In.) Unit List Price
XC-490 HBJZ082 3/8" (1/2" KO) EA $2.47
XC-491 HBJZ083 1/2" EA 3.50
XC-492 HBJZ084 3/4" EA 6.04
XC-493 HBJZ085 1" EA 10.09
XC-494 HBJZ086 1-1/4" EA 18.73
XC-495 HBJZ087 1-1/2" EA 32.48
XC-496 HBJZ088 2" EA 39.28
XC-497 HBJZ089 2-1/2" EA 107.89
XC-498 HBJZ090 3" EA 141.82
Model No. Hughes No. Conduit Size (In.) Unit List Price
XC-280 HBJZ058 3/8" (1/2" KO) EA $0.82
XC-210 HBJZ036 3/8" (1/2" KO) EA 1.91
Armored Cable/Flexible Metallic Conduit Fittings
90°Clamp Type Connectors
Die Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
XC-290 HBJZ062 3/8" (1/2" KO) EA $1.48
XC-291 HBJZ063 1/2" EA 3.04
XC-292 HBJZ064 3/4" EA 4.71
XC-293 HBJZ015 1" EA 5.99
XC-294 HBKA064 1-1/4" EA 10.30
XC-295 HBKA065 1-1/2" EA 19.57
XC-296 HBKA066 2" EA 20.63
XC-297 HBKA067 2-1/2" EA 97.95
XC-298 HBKA068 3" EA 130.35
XC-299 HBKA069 3-1/2" EA 215.08
XC-2910 HBKA063 4" EA 347.54
Model No. Hughes No. Conduit Size (In.) Unit List Price
XC-269 HBJZ054 3/8" (1/2" KO) EA $1.53
XC-270 HBJZ055 1/2" EA 1.55
XC-272 HBJZ056 3/4" EA 2.02
XC-273 HBJZ057 1" EA 5.89
XC-274 HBJZ059 1-1/4" EA 5.87
XC-275 HBJZ060 1-1/2" EA 6.96
XC-276 HBJZ061 2" EA 8.57
XC-277 HBJZ780 2-1/2" EA 23.84
XC-278 HBKA061 3" EA 33.60
XC-278A HBKA062 3-1/2" EA 120.24
XC-2710 HBJZ779 4" EA 164.35 Armored Cable/Flexible Metallic Conduit Fittings
Die Cast Zinc
422-423.qxp 9/5/07 8:55 AM Page 422
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 423
Conduit
Rigid/Intermediate Grade Conduit Fittings
Threadless Compression Connectors
Suggested use –rigid conduit only.
Model No. Hughes No. Conduit Size (In.) Unit List Price
HC-401 HBJY646 1/2" EA $3.41
HC-402 HBJY248 3/4" EA 5.12
HC-403 HBJY249 1" EA 8.02
HC-404 HBJY647 1-1/4" EA 14.44
HC-405 HBJY648 1-1/2" EA 19.91
HC-406 HBJY662 2" EA 39.02
HC-407 HBJY663 2-1/2" EA 122.90
HC-408 HBJY664 3" EA 161.22
HC-409 HBJY665 3-1/2" EA 247.16
HC-410 HBJY666 4" EA 265.20
Rigid/Intermediate Grade Conduit Fittings
Set Screw Connectors
One Set Screw or Two
Two set screws starting at 2" Trade Size
Suggested use –rigid conduit only
Model No. Hughes No. Conduit Size (In.) Unit List Price
HC-101 HBJY636 1/2" EA $2.61
HC-102 HBJY637 3/4" EA 3.61
HC-103 HBJY638 1" EA 6.30
HC-104 HBJY639 1-1/4" EA 10.26
HC-105 HBJY640 1-1/2" EA 12.97
HC-106 HBJY641 2" EA 25.24
HC-107 HBJY642 2-1/2" EA 79.80
HC-108 HBJY643 3" EA 92.38
HC-109 HBJY644 3-1/2" EA 150.75
HC-110 HBJY645 4" EA 183.45
Model No. Hughes No. Conduit Size (In.) Unit List Price
HL-601 HBJY695 1/2" EA $5.05
HL-602 HBJY696 3/4" EA 7.80
HL-603 HBJY697 1" EA 14.08
HL-604 HBJZ878 1-1/4" EA 16.50
Thinwall Conduit Fittings (EMT)
EMT to EMT Set Screw Type
Die-Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
TL-201 HBJZ007 1/2" EA $3.17
TL-202-SC HCAD726 3/4" EA 4.41
TL-203 HBKA030 1" EA 13.57
TL-204 HBKA031 1-1/4" EA 18.57
Model No. Hughes No. Size Range (In.) Unit List Price
XC-730 HBYZ406 .450"/.610" EA $1.36
Steel City ®- T&B
Armored Cable/Flexible Metallic Conduit Fittings
Cable Lok
Simple, one-piece installation with no locknuts.
Screw designed for exceptional pullout resistance.
Captive screw ensures that the screw is intact for installation and
resists backing out after installation.
Corrosion-resistant, zinc-chromatic plating.
Rigid/Intermediate Grade Conduit Fittings
Pull Corner Elbows
Die Cast Zinc
See page 618 for Electric Conduit Benders
422-423.qxp 9/5/07 8:55 AM Page 423
CONDUIT FITTINGS Elbows & Connectors
424 hdsupply.com
Conduit
Steel City®- T&B
Thinwall Conduit Fittings (EMT)
Set Screw Connectors
Die Cast Zinc, Noninsulated
Model No. Hughes No. Conduit Size (In.) Unit List Price
TC-221-SC HBAG542 1/2" EA $0.53
TC-222-SC HBAG605 3/4" EA 0.89
TC-223-SC HBJY935 1" EA 1.42
TC-224-SC HBJY936 1-1/4" EA 2.47
TC-225-SC HBJY937 1-1/2" EA 3.73
TC-226-SC HBJY938 2" EA 4.95
TC-227-SC HBAG795 2-1/2" EA 17.48
TC-228-SC HBAG837 3" EA 19.28
TC-229-SC HBAG873 3-1/2" EA 30.28
TC-2210-SC HBAG916 4" EA 30.99
Thinwall Conduit Fittings (EMT)
Compression Connectors, Steel
Thinwall Conduit Fittings (EMT)
Compression Connectors
Die Cast Zinc, Noninsulated
Model No. Hughes No. Conduit Size (In.) Unit List Price
TC-211-SC HBAG027 1/2" EA $0.84
TC-212-SC HGZO791 3/4" EA Call
TC-213-SC HBJY931 1" EA 1.98
TC-214-SC HBJY932 1-1/4" EA 3.72
TC-215-SC HBJY933 1-1/2" EA 5.47
TC-216-SC HBJY934 2" EA 7.72
TC-217-SC HBAG324 2-1/2" EA 27.80
TC-218-SC HBAG385 3" EA 38.87
TC-219-SC HBAG438 3-1/2" EA 61.80
TC-2110-SC HGZO790 4" EA Call
Thinwall Conduit Fittings (EMT)
Set Screw Connectors, Steel
• Concrete Tight
• Zinc Plated
Model No. Hughes No. Conduit Size (In.) Unit List Price
Non-Insulated
TC111A HERL931 1/2" EA $2.55
TC112A HERL932 3/4" EA 3.70
TC113A HERL933 1" EA 6.33
TC114A HERL934 1-1/4" EA 12.60
TC115A HERL935 1-1/2" EA 18.40
TC116A HERL936 2" EA 26.06
TC117A HERL937 2-1/2" EA 82.17
TC118A HERL938 3" EA 113.06
TC119A HERL939 3-1/2" EA 170.75
TC1110A HERL940 4" EA 173.07
Insulated
TC711A HERL945 1/2" EA 3.28
TC712A HERL946 3/4" EA 4.48
TC713A HERL947 1" EA 7.86
TC714A HERL948 1-1/4" EA 16.29
TC715A HERL949 1-1/2" EA 24.66
TC716A HERL950 2" EA 34.13
TC717A HERL951 2-1/2" EA 130.83
TC718A HERL952 3" EA 178.36
TC719A HERL953 3-1/2" EA 273.78
TC7110A HERL954 4" EA 264.35
Model No. Hughes No. Conduit Size (In.) Unit List Price
Non-Insulated
TC121A HBCS271 1/2" EA $1.45
TC122A HBCS277 3/4" EA 2.33
TC123A HERL913 1" EA 4.32
TC124A HERL914 1-1/4" EA 8.04
TC125A HERL916 1-1/2" EA 13.00
TC126A HERL915 2" EA 17.60
TC127A HERL941 2-1/2" EA 52.91
TC128A HERL942 3" EA 63.04
TC129A HERL943 3-1/2" EA 83.43
TC1210A HERL944 4" EA 93.76
Insulated
TC721A HBCS284 1/2" EA 1.97
TC722A HBCS291 3/4" EA 3.13
TC723A HERL917 1" EA 5.69
TC724A HERL918 1-1/4" EA 10.51
TC725A HERL919 1-1/2" EA 17.08
TC726A HERL920 2" EA 21.83
TC727A HERL955 2-1/2" EA 86.06
TC728A HERL956 3" EA 113.13
TC729A HERL957 3-1/2" EA 154.73
TC7210A HERL958 4" EA 165.70
424-425.qxp 9/5/07 8:55 AM Page 424
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 425
Conduit
Steel City®- T&B
Nonmetallic Sheathed Cable Fittings
Hit Lock Connectors
Nonmetallic Sheathed Cable Fittings
NM Clamp Type Connector
Die Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
NC-201 HBJZ995 3/8" EA $1.01
NC-202 HBKA016 3/4" EA 1.23
NC-203 HBKA017 1" EA 2.05
NC-204 HBKA018 1-1/4" EA 3.49
NC-205 HBKA019 1-3/8" EA 4.11
NC-206 HBKA020 2" EA 5.37
Nonmetallic Sheathed Cable Fittings
Clamp Type Connector
Die Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
NC-301 HBJY872 3/8" (1/2" KO) EA $0.54
NC-302 HBJY873 3/4" EA 2.11
NC-303 HBJY874 1" EA 3.90
Nonmetallic Sheathed Cable Fittings
Tilt In Connector Metallic Steel –Electro-Galvanized
Model No. Hughes No. Conduit Size (In.) Unit List Price
NC-850 HBKA021 1/2" EA $0.51
NC-851 HBKA022 3/4"–1 EA 0.77
NC-852 HBKA023 1–1/4" EA 1.78
NC-853 HBKA024 1–1/2" EA 2.39
Model No. Hughes No. Description Unit List Price
NC501-SC HCHP230 1/2" Hit Lock Connector EA $0.14
NC501DBL-SC HCHP211 1/2" Double Hit Lock Connector EA 0.29
NC502-SC HCHP231 3/4" Hit Lock Connector EA 0.34
424-425.qxp 9/5/07 8:55 AM Page 425
IN BOX meets 2005 NEC, Section 406-8 Where a weatherproof-in-use cover
is required for 15 or 20 amp receptacles installed outdoors.
S
ave
Time
Arlington
Scranton, PA 18517
800.233.4717 •Fax 570.562.0646
www.aifittings.com
Patents pending ©2005 Arlington Industries, Inc.
You’’ll save time and money because
Arlington’s easy to install one-piece
IN BOX™ eliminates the need to install
an electrical box and a bubble cover
assembly (or a siding block on siding).
Homeowners get
a great-looking job
because IN BOX
installs in the wall –
so less of it shows
outside. It won’t
protrude like this!...
IN BOX, the non-
metallic electrical
box with a weatherproof-in-use clear or
white cover, comes in a variety of styles.
There’s an IN BOX for nearly any
vertical or horizontal installation –
retrofit, vinyl and rigid siding, stucco or
textured surfaces, foam wall systems,
brick, and concrete block and stucco.
R
R
IN BOX TM
with Arlington’s
Low Profile, Recessed
Look
Great!
forVinyl Siding
for Stucco
& Textured
Surfaces
for Brick
forRigid Siding
for Stucco &
Textured Surfaces
for Retrofit
/
/
426_EC05.qxd 10/22/05 2:39 PM Page 1
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 427
Conduit
*Provided with red tinted inside clip.
Arlington Industries
Connectors with Insulated Throat
Snap2It®All-Steel
For MC/HCF steel and aluminum cable
• AC/HCF steel and aluminum cable
• Flexible metal conduit steel and aluminum (regular and reduced
wall)
• MC cable continuous corrugated aluminum.
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
138AST HATJ666 01380 3/8 1/2 .405–.612 EA $0.76
140AST* HDWF064 00152 3/8 1/2 .485–.612 EA 0.64
*Provided with insulated throat.
Snap2It®Connectors
With Insulated Throat and Red Tinted Inside Clip
Zinc die-cast. For MC/HCF steel and aluminum cable
• AC/HCF steel and aluminum cable
• Flexible metal conduit steel and aluminum (regular and reduced
wall)
• MC cable continuous corrugated aluminum.
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
38AST* HEFR142 00070 3/8 1/2 .405–.612 EA $0.48
380AST* HATJ662 00382 3/8 1/2 .405–.612 EA 0.48
45AST* HATJ867 00045 1/2 1/2 .590–.840 EA 0.56
40AST HATJ749 00041 3/8 1/2 .485–.612 EA 0.48
400AST HATJ750 40347 3/8 1/2 .485–.612 EA 0.48
50AST HATJ856 72300 1/2 1/2 .860–.920 EA 0.56
*Provided with insulated throat.
†Provided with insulated throat and red tinted inside clip.
Duplex Connectors
Snap2It®
Zinc die-cast. For MC/HCF steel and aluminum cable
• AC/HCF steel and aluminum cable
• Flexible metal conduit steel and aluminum (regular and reduced
wall)
• MC cable continuous corrugated aluminum.
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
3838ST HATJ657 10935 3/8 1/2 (2).405–.612 EA $1.13
3838AST* HEFQ612 36230 3/8 1/2 (2).405–.612 EA 1.30
4040AST†HATJ751 40351 3/8 1/2 (2).485–.612 EA 1.30
426-427.qxp 9/5/07 8:55 AM Page 427
CONDUIT FITTINGS Elbows & Connectors
428 hdsupply.com
Conduit
Add suffix "BL"to Catalog # when ordering in black
*SNAP2IT Zero to 90™.
Arlington Industries
Connectors
Nonmetallic
For use with nonmetallic liquid-tight conduit, type B only and flexible
non-metallic tubing. Push on installation. Produced from UV rated plastic
for long out door life.
• Provides a super-secure, liquid-tight seal
• Removable and reusable!
Snap-Tite®Connectors
For steel and aluminum jacketed cables
With spring steel clip
Zinc die-cast
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
840ST HCAA850 80070 3/8 1/2 .225–.612 EA $0.46
8400ST HCAA852 80074 3/8 1/2 .225–.612 EA 0.58
Snap-Tite®Connector
For NM cable
With spring steel clip
Zinc die cast
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
841ST HCAA849 80068 3/8 1/2 .225–.612 EA $0.47
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Unit List Price
Snap2It®
NMLT5 HATJ716 54576 1/2 1/2 EA $2.28
NMLT7 HATJ717 54577 3/4 3/4 EA 3.28
NMLT10 HATJ861 54102 1 1 EA 4.69
NMLT12 HGZN762 21150 1-1/4 1-1/4 EA Call
NMLT15 HGZN764 21152 1-1/2 1-1/2 EA Call
NMLT20 HGZN766 21154 2 2 EA Call
90°Snap2It®
NMLT905 HATJ718 54578 1/2 1/2 EA 3.61
NMLT907 HATJ719 54579 3/4 3/4 EA 5.50
NMLT9010 HEQM055 54104 1 1 EA 10.83
NMLT1290* HGZN763 03906 1-1/4 1-1/4 EA Call
NMLT1590* HGZN765 03908 1-1/2 1-1/2 EA Call
NMLT2090* HGZN767 03910 2 2 EA Call
428-429.qxp 9/5/07 8:56 AM Page 428
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 429
Conduit
Add suffix "RH"for Robertson Head Screws.
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Unit List Price
800ST HCAA837 80025 1/2 1/2 EA $0.48
801ST HCAA838 80027 3/4 3/4 EA 0.87
*Provided with insulated throat.
Set-Screw Snap-Tite®Connectors
With spring steel clip
For steel only Flex - AC - MC cable. Zinc die-cast.
Not suitable for aluminum jacketed cables or aluminum flexible metal
conduit.
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
845AST* HCAA915 80122 3/8 1/2 .445–.630 EA Call
*Provided with insulated throat.
Connectors
For aluminum and steel Flex - AC - MC cable. Zinc die-cast
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
Saddlegrip®Snap-Tite®
SG38AST* HAHL890 80144 3/8 1/2 .405–.612 EA $0.47
SG50AST* HCAA046 17501 1/2 1/2 .710–.910 EA 1.35
SG75AST* HCAA050 17755 3/4 3/4 .840–1.110 EA 3.08
Duplex Saddlegrip®Snap-Tite®
SG3838AST* HALB286 36210 3/8 1/2 (2) .445–.612 EA 1.31
Arlington Industries
EMT Snap-Tite®Connectors
With spring steel clip
•Concrete tight
•Zinc die-cast
428-429.qxp 9/5/07 8:56 AM Page 429
CONDUIT FITTINGS Elbows & Connectors
430 hdsupply.com
Conduit
*Listed for use with steel and aluminum EMT, IMC and rigid conduit.
Arlington Industries
EMT Compression Connectors
Zinc die-cast
UL listed concrete tight
Add suffix "RH"for Robertson Head Screws.
*Concrete tight when taped.
†Listed for use with steel and aluminum EMT, IMC and rigid conduit.
EMT Set-Screw Connectors
Zinc die-cast
Concrete tight
Pull Elbows
Combination Threaded Rigid and Set-Screw EMT
90°pulling elbows with cover and gasket. Zinc die-cast.
Arlington's combination hubs are threaded for rigid and include
setscrews for EMT. The set-screws may be used for rigid, but are not
necessary. They are listed raintight with rigid and concrete-tight when
taped for EMT. These products can also be used for EMT to rigid.
Model No. Hughes No. UPC Code
Conduit
Size (In.) Unit List Price
HL5000 HAKR353 83105 1/2 EA $3.08
HL7500 HAKR385 83175 3/4 EA 3.49
HL100 HEGY172 50171 1 EA 9.44
HL125 HATJ630 50173 1-1/4 EA 12.46
Model No. Hughes No.
UPC
Code
Conduit
Size (In.)
Hole
Diameter (In.) Unit List Price
Uninsulated
820 HACY517 00820 1/2 1/2 EA $0.78
821 HACY520 00821 3/4 3/4 EA 0.86
822 HACY523 00822 1 1 EA 1.54
823 HACY526 00823 1-1/4 1-1/4 EA 3.19
824 HACY529 00824 1-1/2 1-1/2 EA 4.94
825 HACY530 00825 2 2 EA 7.11
826* HAKB890 00826 2-1/2 2-1/2 EA 22.47
827* HAKC112 00827 3 3 EA 29.66
828* HBCB506 00828 3-1/2 3-1/2 EA 42.17
829* HBCB557 00829 4 4 EA 46.02
With Insulated Throat
820A HAKB993 82010 1/2 1/2 EA 1.03
821A HAKC410 82110 3/4 3/4 EA 1.27
822A HAXI692 82210 1 1 EA 1.84
823A HBBF705 82310 1-1/4 1-1/4 EA 4.69
824A HAJF704 82410 1-1/2 1-1/2 EA 7.10
825A HBCA803 82510 2 2 EA 10.18
826A* HCAA542 82610 2-1/2 2-1/2 EA 44.52
827A* HAJE748 82710 3 3 EA 53.56
828A* HAJQ702 82810 3-1/2 3-1/2 EA 73.09
829A* HCAA543 82910 4 4 EA 81.65
Model No. Hughes No.
UPC
Code
Conduit
Size (In.)
Hole
Diameter (In.) Unit List Price
Uninsulated
800 HACY739 00800 1/2 1/2 EA $0.50
801 HACY743 00801 3/4 3/4 EA 0.80
802 HACY745 00802 1 1 EA 1.29
803 HACY750 00803 1-1/4 1-1/4 EA 2.25
804* HACY752 00804 1-1/2 1-1/2 EA 3.35
805* HACY754 00805 2 2 EA 4.58
806*†HBCB561 00806 2-1/2 2-1/2 EA 14.08
807*†HBCB563 00807 3 3 EA 18.68
8075*†HAYN994 08075 3-1/2 3-1/2 EA 24.27
808*†HBCB566 00808 4 4 EA 25.66
With Insulated Throat
800A HAHN737 80010 1/2 1/2 EA 0.77
801A HAGU643 80110 3/4 3/4 EA 1.18
802A HAGU554 80210 1 1 EA 1.87
803A HCAA943 80310 1-1/4 1-1/4 EA 4.27
804A* HCAA946 80410 1-1/2 1-1/2 EA 5.30
805A* HCAA954 80510 2 2 EA 7.70
806A*†HCAA956 80610 2-1/2 2-1/2 EA 27.88
807A*†HCAA957 80710 3 3 EA 36.35
8075A*†HCAA958 80711 3-1/2 3-1/2 EA 46.37
808A*†HAYS919 80810 4 4 EA 52.64
See page 599 for Milwaukee
Magnum®Drills
430-431.qxp 9/5/07 8:56 AM Page 430
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 431
Conduit
Arlington Industries
NM Cable Connector
For NM cable
Zinc die-cast
Model
No.
Hughes
No.
UPC
Code
Conduit
Size (In.)
Hole
Diameter
(In.)
Cable
Dimensions
(in.) Unit List Price
841 HACY609 00841 3/8 1/2 .225–.612 EA $0.45
Add suffix "BL"to Catalog # when ordering in black
Nonmetallic Connectors
For use with nonmetallic liquid-tight conduit, type B only and flexible
nonmetallic tubing. Produced from UV rated plastic for long outdoor life.
Add suffix "BL"to Catalog # when ordering in black.
Connectors
90°Nonmetallic
For use with nonmetallic liquid-tight conduit, type B only and flexible
non-metallic tubing. 90°connector provides a smooth, gradual radius
bend. Wiring is easily pulled or pushed through fitting and there are no
sharp edges to strip wire. Produced from UV rated plastic for long out-
door life.
Model No. Hughes No.
UPC
Code
Conduit
Size (In.)
Hole
Diameter (In.) Unit List Price
NMLT9050 HBDB873 54905 1/2 1/2 EA $3.61
NMLT9075 HBDB961 54907 3/4 3/4 EA 5.50
NMLT90100 HBDC035 54901 1 1 EA 10.83
NMLT90125 HBCA495 54912 1-1/4 1-1/4 EA 16.96
NMLT90150 HAIR200 54915 1-1/2 1-1/2 EA 20.75
NMLT90200 HBCB382 54920 2 2 EA 30.32
Plastic Push-In Connectors
For NM and flexible cord
Model No. Hughes No.
UPC
Code
Conduit
Size (In.)
Hole
Diameter (In.) Unit List Price
NM841 HACT433 54841 1/2 1/2 EA $0.48
NM842 HAHG326 54842 3/4 3/4 EA 0.70
NM843 HAHG338 54843 1 1 EA 0.89
NM844 HATJ631 50175 1-1/4 1-1/4 EA 1.38
Model No. Hughes No.
UPC
Code
Conduit
Size (In.)
Hole
Diameter (In.) Unit List Price
Screw-On Straight
NMSC50 HBZZ910 21000 1/2 1/2 EA $1.81
NMSC75 HCAA115 21010 3/4 3/4 EA 2.79
Screw-On 90°
NMSC9050 HCAA113 21007 1/2 1/2 EA 3.08
NMSC9075 HCAA114 21009 3/4 3/4 EA 4.79
Straight
NMLT50 HBDB690 54500 1/2 1/2 EA 2.28
NMLT75 HBDB766 54750 3/4 3/4 EA 3.28
NMLT100 HBDB800 54100 1 1 EA 4.69
NMLT125 HBCA493 04223 1-1/4 1-1/4 EA 8.66
NMLT150 HAIQ993 04222 1-1/2 1-1/2 EA 11.91
NMLT200 HAIR176 04221 2 2 EA 20.75
430-431.qxp 9/5/07 8:56 AM Page 431
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Unit List Price
NM94 HAHG242 05488 3/8 1/2 EA $0.11
NM95 HEFX348 10956 3/4 3/4 EA 0.24
NM96 HGOQ028 72158 1 1 EA 0.21
CONDUIT FITTINGS Elbows & Connectors
432 hdsupply.com
Conduit
Arlington Industries
Black Button™Plastic Push-In Connectors
For NM Cable
The Black Button is not only the lowest cost NM connector on the mar-
ket, but offers the fastest method of installing single or multiple cables.
Plus, the NM94 meets UL and CSA requirements for single or multiple
cables.
• Two cables may be inserted together or individually.
• A second cable may be added without removing the first.
Gland-Type Service Entrance Cable Connectors
Zinc die-cast
Model No. Hughes No. UPC Code Conduit Size (In.) Insulated Conductor Size (AWG) Uninsulated Conductor Size (AWG) Unit List Price
WC1008 HCAA620 53108 1 8-1 8 EA $4.26
WC1253 HAWS477 53123 1-1/4 2-7 3 EA 8.80
WC1502 HALF248 53152 1-1/2 2/0-19 2/0 EA 11.31
WC2002 HCAA220 53202 2 2/0-19 2/0 EA 24.40
WC2004 HAWS349 53204 2 4/0-19 4/0 EA 24.38
When ordering in black, add suffix "BL"to catalog #.
Connectors
Low-Profile Strain Relief Cord
Arlington's Low Profile Cord Connector has a unique grommet with grip-
ping fingers. These connectors have the largest cord range in the indus-
try —so there are fewer items to stock. A liquid-tight seal and superior
pullout resistance is accomplished by just tightening the nut. A sealing
ring is furnished to assure a liquid-tight seal when installing in non-
threaded openings.
Model No. Hughes No. UPC Code Conduit Size (In.) Cord Diameter Range (in.) Unit List Price
LPCG50 HAHN876 80086 1/2 .200/.472 EA $1.44
LPCG507 HAHN956 50354 1/2 .385/.750 EA 1.73
LPCG757 HCAA353 36100 3/4 .385/.750 EA 2.17
432-433.qxp 9/5/07 8:57 AM Page 432
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 433
Conduit
Arlington Industries
Connectors
Straight Zinc Die-Cast
For use with metallic and nonmetallic liquid-tight conduit, type B.
*Provided with insulated throat.
Connectors
90°Zinc Die-Cast
For use with metallic and nonmetallic liquid-tight conduit, type B.
Model No. Hughes No.
UPC
Code
Conduit
Size (In.)
Hole
Diameter
(In.) Unit List Price
LT9050 HAFQ641 32950 1/2 1/2 EA $4.39
LT9075 HAFQ733 32970 3/4 3/4 EA 5.68
LT90100 HAFQ248 32910 1 1 EA 14.10
LT90125 HAFQ845 32913 1-1/4 1-1/4 EA 24.29
LT90150 HAFQ948 32915 1-1/2 1-1/2 EA 28.21
LT90200 HAXR853 32920 2 2 EA 41.18
LT90250* HBCA797 32925 2-1/2 2-1/2 EA 146.64
LT90300* HBCA865 32930 3 3 EA 177.18
LT90350* HBCA866 32935 3-1/2 3-1/2 EA 210.70
LT90400* HBCA867 32940 4 4 EA 230.46
Cable Connectors
Zinc die-cast
Set-Screw Connectors
For steel only - Flex - AC -MC cable; zinc die-cast.
Not suitable for aluminum jacketed cables or aluminum flexible metal
conduit.
Model No. Hughes No.
UPC
Code
Conduit
Size (In.)
Hole
Diameter
(In.) Unit List Price
Uninsulated
LT50 HBBN273 32500 1/2 1/2 EA $2.27
LT75 HAFR427 32750 3/4 3/4 EA 3.89
LT100 HAFR528 32100 1 1 EA 7.20
LT125 HAFR743 32125 1-1/4 1-1/4 EA 11.74
LT150 HAFR137 32150 1-1/2 1-1/2 EA 16.83
LT200 HAXR821 32200 2 2 EA 25.26
With Insulated Throat
LT38A HCAA156 32381 3/8 1/2 EA 3.31
LT50A HCAA158 32501 1/2 1/2 EA 3.31
LT75A HCAA016 32751 3/4 3/4 EA 4.81
LT100A HCAA151 32101 1 1 EA 7.44
LT125A HCAA152 32121 1-1/4 1-1/4 EA 12.69
LT150A HCAA153 32151 1-1/2 1-1/2 EA 17.55
LT200A HCAA154 32201 2 2 EA 33.93
LT250 HBCA673 32250 2-1/2 2-1/2 EA 114.51
LT300 HAYK261 32300 3 3 EA 141.70
LT350 HBCA474 32350 3-1/2 3-1/2 EA 152.97
LT400 HBCA795 32400 4 4 EA 177.33
Model No. Hughes No. UPC Code
Cable
Dimensions (in.) Unit List Price
845 HAGV834 00845 .445–.630 EA $0.47
Model No. Hughes No.
UPC
Code
Conduit
Size (In.)
Hole
Diameter
(In.) Unit List Price
For NM • SEU cable
842 HACY639 00842 3/4 3/4 EA $1.34
843 HAGY777 00843 1 1 EA 2.03
844 HAGZ008 00844 1-1/4 1-1/4 EA 3.15
For NM • SEU cable
843S HACY665 84310 1 1 EA 2.03
844S HACY693 84410 1-1/4 1-1/4 EA 3.15
848S HACY575 84810 1-1/2 1-1/2 EA 4.90
849S HACY723 84910 2 2 EA 6.10
See page 415 for
Power and Appliance Whips
432-433.qxp 9/5/07 8:57 AM Page 433
CONDUIT FITTINGS Elbows & Connectors
434 hdsupply.com
Conduit
Arlington Industries
Squeeze Connectors
For Flex - AC - MC cable. Zinc die-cast.
*Provided with insulated throat.
†SG38 and SG38A are UL listed concrete tight when taped.
Connectors
For aluminum and steel Flex - AC - MC cable. Zinc die-cast.
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
SG38†HALB339 18065 3/8 1/2 .405–.612 EA $0.62
SG38A*†HCAA923 80138 3/8 1/2 .405–.612 EA 0.78
SG50 HALB341 07500 1/2 1/2 .710–.910 EA 0.80
SG75A* HCAA049 17751 3/4 3/4 .840–1.110 EA 2.40
SG3838A* HCAA355 36205 3/8 1/2 (2) .445–.612 EA 1.98
*Provided with insulated throat.
Connectors
Single Screw
For Flex - AC - MC - NM cable. Zinc die-cast.
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
Uninsulated
L42 HAIN391 34200 3/8 1/2 .530–.620 EA $0.86
L421 HAIN502 34210 1/2 1/2 .850–.910 EA 0.84
L422 HAIN671 34220 3/4 3/4 1.100–1.135 EA 1.36
L423 HAIN782 34230 1 1 1.255–1.375 EA 3.03
L424 HAIF212 34240 1-1/4 1-1/4 1.550–1.610 EA 6.55
L425 HAIF214 34250 1-1/2 1-1/2 1.810–1.895 EA 9.50
L426 HAIF251 34260 2 2 2.260–2.485 EA 13.46
L427 HAIF309 34270 2-1/2 2-1/2 2.770–2.950 EA 25.58
L428 HAIF311 34280 3 3 3.170–3.560 EA 35.68
L429 HBCB584 34290 3-1/2 3-1/2 3.630–4.155 EA 120.81
L4210 HBCB660 34211 4 4 4.030–4.635 EA 149.61
With Insulated Throat
L421A HBCB301 34212 1/2 1/2 .850–.910 EA 1.12
L422A HCAA310 34213 3/4 3/4 1.100–1.135 EA 1.55
L423A HCAA311 34214 1 1 1.255–1.375 EA 4.19
L424A HCAA312 34215 1-1/4 1-1/4 1.550–1.610 EA 8.65
L425A HCAA323 34216 1-1/2 1-1/2 1.810–1.895 EA 11.56
L426A HCAA324 34217 2 2 2.260–2.485 EA 15.78
L427A HCAA211 42700 2-1/2 2-1/2 2.770–2.950 EA 28.80
L428A HCAA212 42800 3 3 3.170–3.560 EA 39.12
L429A HCAA213 42900 3-1/2 3-1/2 3.630–4.155 EA 124.55
L4210A HCAA418 42100 4 4 4.030–4.635 EA 160.83
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
Duplex Connector
846 HACY462 00846 3/8 1/2 .150–.612 EA $1.25
Duplex Snap-Tite®
846AST* HCAA842 80052 3/8 1/2 .150–.612 EA 1.47
434-435.qxp 9/5/07 8:57 AM Page 434
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 435
Conduit
†Malleable.
Arlington Industries
90°Connectors
For aluminum and steel Flex - AC - MC cable. Zinc die-cast.
Model No. Hughes No. UPC Code Conduit Size (In.) Hole Diameter (In.) Cable Dimensions (in.) Unit List Price
Uninsulated
850 HAIN866 00850 3/8 1/2 .440–.750 EA $0.98
851 HAIN969 00851 1/2 1/2 .635–1.085 EA 1.59
852 HBCB163 00852 3/4 3/4 .830–1.380 EA 2.81
853 HAIF436 00853 1 1 1.330–1.570 EA 7.67
854 HAIF438 00854 1-1/4 1-1/4 1.625–1.940 EA 10.85
855 HAIF442 00855 1-1/2 1-1/2 1.400–2.400 EA 30.86
856 HAIF444 00856 2 2 1.400–2.400 EA 31.42
857†HAIF445 00857 2-1/2 2-1/2 2.600–3.100 EA 99.12
858†HBAS731 00858 3 3 3.100–3.640 EA 130.91
858†HAGO654 00859 3-1/2 3-1/2 3.380–4.220 EA 258.08
8510†HBAT185 08510 4 4 3.730–4.550 EA 400.21
With Insulated Throat
850A HBBX475 85010 3/8 1/2 .440–.750 EA 1.35
851A HCAB131 85110 1/2 1/2 .635–1.085 EA 1.85
852A HCAB136 85210 3/4 3/4 .830–1.380 EA 3.18
853A HCAB137 85310 1 1 1.330–1.570 EA 8.64
854A HCAB138 85410 1-1/4 1-1/4 1.625–1.940 EA 13.39
855A HCAB139 85510 1-1/2 1-1/2 1.400–2.400 EA 32.73
856A HCAB140 85610 2 2 1.400–2.400 EA 44.84
857A†HBZZ648 08571 2-1/2 2-1/2 2.600–3.100 EA 115.47
858A†HBZZ649 08581 3 3 3.100–3.640 EA 138.39
859A†HBZZ650 08591 3-1/2 3-1/2 3.380–4.220 EA 265.56
8510A†HCAB130 85101 4 4 3.730–4.550 EA 407.69
434-435.qxp 9/5/07 8:57 AM Page 435
A: One for every job. And counting.
LB’s, LR’s, T’s, C’s, malleable, gray iron, aluminum...name your conduit job. There’s a rugged, high-
performance Appleton conduit body to match. And you’ll find precision-machined threads, smooth hub bushings and
openings, and epoxy powder-coated corrosion-resistant construction in every one of them:
Form 35 Unilet®— Malleable iron construction resists impact and stress, temperature extremes, and
corrosive atmospheres. Freeze-resistant captive stainless steel cover screws. Rollers for easy-pulling in types LB and C
in sizes over 1".
FM7 Unilet®— Grayloy™ iron or aluminum. Interchangeable with Crouse-Hinds®Form 7.*
Most sizes in flat-back design for flat surface mounting and more wiring room.
FM8 Unilet®— Grayloy™ iron. Ideal for wet locations. Plenty of room for wire pulling and splicing.
Interchangeable with Crouse-Hinds Form 8.*
Form 85 Unilet®— Copper-free aluminum construction offers the highest corrosion resistance.
Mogul NEC 6x8x Unilets®— All types meet NEC 6x8x length and bending-space requirements for large, heavy
conductors. All include covers and gaskets. Rollers for easy-pulling in types C, LB and
UB in sizes over 1".
Get the complete story about Appleton’s complete line of conduit bodies. Call 800-621-1506 or visit Appleton
online at www.appletonelec.com. E-mail: literature@egseg.com
*Form 7 and Form 8 are products of Crouse-Hinds, a member company of Cooper Industries. Crouse-Hinds is a registered trademark of Cooper Industries.
Q: Just how many kinds of Appleton conduit body styles are out there?
436_EC05.qxd 10/26/05 4:59 PM Page 436
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 437
Conduit
Appleton®
Unions, Sealing Fittings, Flexible Couplings, Elbows,
Drain/Breather, Close-Up Plugs
Explosionproof
UNILETS®for Use with Threaded Metal Conduit
Features: All Fittings
• Explosionproof, dust-ignitionproof.
• Smooth, rounded integral bushing in each hub protects conductor
insulation.
• Accurately tapped, tapered threads for tight, rigid joints and
ground continuity.
Features: Non-Expansion Unions
• Concentric ring interlocked design of 1⁄2", 3⁄4" and 1" sizes makes
possible smaller diameter, allowing use in tighter spaces. 1-1⁄4" and
larger UNY sizes have removable male nipple.
• Choice of malleable iron or aluminum.
Features: Expansion Unions
• One-piece design eliminates need for disassembly during installa-
tion.
• Telescoping cylinder within cylinder design permits expansion or
contraction.
• Standard or long types available.
• Small external diameters—excellent in restricted areas in wiring
of pumps, motors, and other equipment.
• Internal phosphor bronze "bonding jumper"ring assures positive
ground between telescoping cylinders.
Standard Materials
• UNY and UNF (Non-Expansion) Unions, 1⁄2" thru 1": steel or alu-
minum. 1-1⁄4" thru 6": malleable iron or aluminum.
• UNY and UNF Expansion Unions: steel.
• UNL Unions: malleable iron and steel.
• EYSF/EYSM, EYF/EYM and EYDM Seals: malleable iron or Almag 35
aluminum.
• EYS, EYSEF/EYDEF, and ESUF/ESUM: malleable iron.
• EYD and EYS Seals: Grayloy™-iron.
• EXGJH and EXLK Couplings, 1⁄2" thru 2": outer bronze braid, inner
brass core with insulating liner; 2-1⁄2" thru 4": outer stainless steel
braid, inner stainless steel core with insulating liner. End Fittings:
1⁄2" thru 2"—brass; 2-1⁄2" thru 4"—stainless steel.
• PLG Close-Up Plugs: malleable iron, steel, or aluminum.
• BR Reducers: malleable iron or aluminum.
• EL and UNA Elbows: malleable or cast iron.
Compliances
• UL Standard 886
• Appleton malleable iron products conform to ASTM A47-77, Grade
32510. which has the following properties: tensile strength, 50,000
psi; yield, 32,000 psi; and elongation, 10%.
• Appleton aluminum products are produced from a high strength
copper-free (4⁄10 or 1% max.) alloy.
• Class I, Div. 1 & 2 and Class II, Div. 1 & 2, if installed as follows:
Unions, Elbows, Plugs, Flex. Couplings—NEC 501-4 (a)(b);
Seals—NEC 501-5 (a)(b)(c)(d)(e) and NEC 502-5;
Drains—NEC 501-5(f).
◊Indicates items which are U.L. Listed for Class I, Groups A, B, C & D; Class II, Groups E,F and G; and Class III.
††Indicated items which are U.L. Listed for Class I, Groups B, C and D; Class II, Groups E, F and G; and Class III
†Male end given first.
Unions: Explosionproof, Dust-Ignitionproof
UNL 90°Elbow Unions
For Connecting Conduit to Enclosure
• Class I, Div. 1 and 2
• Groups A◊, B††, C, D
• Class II, Div. 1 and 2
• Groups E, F, G
• Class III
• UNILETS®for Use with Threaded Metal Conduit
Model No. Hughes No. Size (In.) Dimension A (in.) Dimension B (in.) Type Unit List Price
UNL50N◊HEGI296 1/2–1/2 2.47 1.47 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNL50-75N◊HEGI295 1/2–3/4†2.47 1.75 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNL75-50N◊HEOL438 3/4–1/2†2.00 1.75 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNL75N◊HEGI297 3/4–3/4 2.00 1.47 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
436-437.qxp 9/5/07 8:57 AM Page 437
CONDUIT FITTINGS Elbows & Connectors
438 hdsupply.com
Conduit
◊Indicates items which are U.L. Listed for Class I, Groups A, B, C & D; Class II, Groups E, F and G; and Class III.
††Indicated items which are U.L. Listed for Class I, Groups B, C and D; Class II, Groups E, F and G; and Class III.
‡Size of right end is given first.
Appleton®
Unions: Explosionproof, Dust-Ignitionproof
UNF Female Unions
For Connecting Conduit To Conduit
• Class I, Div. 1 and 2
• Groups A◊, B††, C, D
• Class II, Div. 1 and 2
• Groups E, F, G
• Class III
• Unilets®for Use with Threaded Metal Conduit
Model No. Hughes No. Size (In.) Dimension A (in.) Dimension B (in.) Type Unit List Price
UNF50NR◊HEGB389 1/2 1.47 1.47 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF75-50NR◊HEGI300 3/4–1/2‡1.47 1.47 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF75NR◊HEGB394 3/4 1.47 1.75 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF100NR◊HEPQ938 1 1.72 2.00 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF125NR†† HEGI321 1-1/4 2.19 2.81 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF150NR†† HEGI322 1-1/2 2.19 3.06 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF200NR†† HEGI323 2 2.31 3.72 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF250R†† HEGJ097 2-1/2 3.38 4.88 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF300R†† HEGJ098 3 3.38 5.38 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF350R†† HEGJ099 3-1/2 3.38 5.88 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF400R†† HEOU970 4 3.50 6.44 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF500R HEOM710 5 3.88 8.38 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF600R HEOM525 6 4.00 9.63 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNF50NR-A◊HEGI293 1/2 1.47 1.47 Aluminum (1/2" to 4") EA Call
UNF75-50NR-A◊HEOL615 3/4–1/2‡1.47 1.47 Aluminum (1/2" to 4") EA Call
UNF75NR-A◊HEGC748 3/4 1.47 1.75 Aluminum (1/2" to 4") EA Call
UNF100NR-A◊HEGI294 1 1.72 2.00 Aluminum (1/2" to 4") EA Call
UNF125NR-A†† HEOL869 1-1/4 2.19 2.81 Aluminum (1/2" to 4") EA Call
UNF150NR-A†† HEOL877 1-1/2 2.19 3.06 Aluminum (1/2" to 4") EA Call
UNF200NR-A†† HEOL887 2 2.31 3.72 Aluminum (1/2" to 4") EA Call
UNF250R-A†† HEOU889 2-1/2 3.38 4.88 Aluminum (1/2" to 4") EA Call
UNF300R-A†† HEOU919 3 3.38 5.38 Aluminum (1/2" to 4") EA Call
UNF350R-A†† HEOU953 3-1/2 3.38 5.88 Aluminum (1/2" to 4") EA Call
UNF400R-A†† HEGJ100 4 3.50 6.44 Aluminum (1/2" to 4") EA Call
See page 654 for Kevlar®
High Strength Conduit
Mesuring Tape
438-439.qxp 9/5/07 8:58 AM Page 438
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 439
Conduit
◊Indicates items which are U.L. Listed for Class I, Groups A, B, C & D; Class II, Groups E, F and G; and Class III.
††Indicated items which are U.L. Listed for Class I, Groups B, C and D; Class II, Groups E, F and G; and Class III.
‡Size of right end is given first.
Appleton®
Unions: Explosionproof, Dust-Ignitionproof
UNY Unions
For Connecting Conduit To Enclosure
• Class I, Div. 1 and 2
• Groups A◊, B††, C, D
• Class II, Div. 1 and 2
• Groups E, F, G
• Class III
• Unilets®for Use with Threaded Metal Conduit
Model No. Hughes No. Size (In.) Dimension A (in.) Dimension B (in.) Type Unit List Price
UNY50NR◊HEGC501 1/2 1.94 1.47 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY75-50NR◊HEOL620 3/4–1/2‡1.94 1.47 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY75NR◊HEGC504 3/4 1.94 1.75 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY100NR◊HEPQ934 1 2.34 2.00 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY125NR†† HEGI324 1-1/4 3.13 2.81 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY150NR†† HEFP057 1-1/2 3.25 3.06 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY200NR†† HEGI327 2 3.63 3.72 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY250R†† HEGJ105 2-1/2 4.81 4.88 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY300R†† HEGJ107 3 4.81 5.38 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY350R†† HEOV152 3-1/2 4.94 5.88 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY400R†† HEGJ110 4 5.13 6.44 Steel (1/2" to 1") and Malleable Iron (1-1/4" to 6") EA Call
UNY50NR-A◊HEGX964 1/2 1.94 1.47 Aluminum (1/2" to 4") EA Call
UNY75-50NR-A◊HEGI301 3/4–1/2‡1.94 1.47 Aluminum (1/2" to 4") EA Call
UNY75NR-A◊HEGY044 3/4 1.94 1.75 Aluminum (1/2" to 4") EA Call
UNY100NR-A◊HEGI298 1 2.34 2.00 Aluminum (1/2" to 4") EA Call
UNY125NR-A†† HEGI325 1-1/4 3.13 2.81 Aluminum (1/2" to 4") EA Call
UNY150NR-A†† HEGI326 1-1/2 3.25 3.06 Aluminum (1/2" to 4") EA Call
UNY200NR-A†† HEGI328 2 3.63 3.72 Aluminum (1/2" to 4") EA Call
UNY250R-A†† HEGJ106 2-1/2 4.81 4.88 Aluminum (1/2" to 4") EA Call
UNY300R-A†† HEGJ108 3 4.81 5.38 Aluminum (1/2" to 4") EA Call
UNY350R-A†† HEGJ109 3-1/2 4.94 5.88 Aluminum (1/2" to 4") EA Call
UNY400R-A†† HEGJ111 4 5.13 6.44 Aluminum (1/2" to 4") EA Call
438-439.qxp 9/5/07 8:58 AM Page 439
CONDUIT FITTINGS Elbows & Connectors
440 hdsupply.com
Conduit
Appleton®
ELBD Pulling Elbow
Explosionproof, Dust-Ignitionproof
Unilets®for use with Threaded Metal Conduit
ELBY Capped Elbow
Explosionproof, Dust-Ignitionproof
Unilets®for use with Threaded Metal Conduit
*Remove sufficient outer covering of cord or cable to pass conductors through connector
body.
†Not UL Listed
††Not CSA Certified
Straight Liquidtight Strain
Relief Cord and Cable Connectors
Aluminum
Model No. Hughes No. Conduit Size (In.) Unit List Price
Malleable Iron
ELBD-50 HEGI353 1/2 EA Call
ELBD-75 HEGF106 3/4 EA Call
ELBD-100 HEGF110 1 EA Call
ELBD-125 HEGI354 1-1/4 EA Call
ELBD-150 HEGI355 1-1/2 EA Call
ELBD-200 HEOM367 2 EA Call
ELBD-250 HEOM369 2-1/2 EA Call
ELBD-300 HEOM458 3 EA Call
ELBD-350 HEOM463 3-1/2 EA Call
ELBD-400 HEOM468 4 EA Call
Aluminum
ELBD-50-A HENI832 1/2 EA Call
ELBD-75-A HENI835 3/4 EA Call
ELBD-100-A HENI840 1 EA Call
ELBD-125-A HENI845 1-1/4 EA Call
ELBD-150-A HEGS480 1-1/2 EA Call
ELBD-200-A HEOY002 2 EA Call
ELBD-250-A HENI853 2-1/2 EA Call
ELBD-300-A HENI857 3 EA Call
ELBD-350-A HENI862 3-1/2 EA Call
ELBD-400-A HEOY005 4 EA Call
Model No. Hughes No. Conduit Size (In.) Unit List Price
Malleable Iron
ELBY-50 HEIR560 1/2 EA Call
ELBY-75 HEIR592 3/4 EA Call
ELBY-100 HEGI356 1 EA Call
ELBY-125 HEGI357 1-1/4 EA Call
Aluminum
ELBY-50-A HEGI901 1/2 EA Call
ELBY-75-A HEGI902 3/4 EA Call
ELBY-100-A HEOT343 1 EA Call
ELBY-125-A HEOT347 1-1/4 EA Call
Model No. Hughes No. Cable Diameter Range (in) Unit List Price
1/4 Inch Hubs
CG-0625 HBLI337 .060—.156 EA Call
CG-1525 HBLI338 .156—.250 EA Call
3/8 Inch Hubs
CG-1238 HEOK778 .125—.187 EA Call
CG-1838 HEGI227 .187—.312 EA Call
CG-3138 HEFN887 .312—.437 EA Call
1/2 Inch Hubs
CG-1250 HEFQ112 .125—.187 EA Call
CG-1850 HEFQ114 .187—.312 EA Call
CG-3150 HEFQ122 .312—.437 EA Call
CG-3750 HEFQ124 .375—.500 EA Call
CG-5050 HEFQ376 .500—.625 EA Call
CG6250* HGZN713 .625—.750 EA Call
3/4 Inch Hubs
CG-1275 HEGI226 .125—.250 EA Call
CG-2575 HEFQ119 .250—.375 EA Call
CG-3775 HEFQ371 .375—.500 EA Call
CG-5075 HEFQ380 .500—.625 EA Call
CG-6275 HEFQ384 .625—.750 EA Call
CG-7575* HEGI228 .750—.875 EA Call
1 Inch Hubs
CG-37100 HEGI229 .375—.500 EA Call
CG-50100 HEGI230 .500—.625 EA Call
CG-62100 HEFQ387 .625—.750 EA Call
CG-75100 HEFQ392 .750—.875 EA Call
CG-87100 HEFQ395 .875—.1.000 EA Call
CG-100100* HEGI233 1.000—1.125 EA Call
1-1/4 Inch Hubs
CG-75125 HEGI231 .750—.875 EA Call
CG-87125 HEGI232 .875—1.000 EA Call
CG-100125 HEGY307 1.000—1.125 EA Call
CG-112125 HBLG240 1.125—1.250 EA Call
CG-125125* HBLG241 1.250—1.375 EA Call
CG-137125* HBLG242 1.375—1.500 EA Call
1-1/2 Inch Hubs
CG-115150 HBLH279 1.156—1.312 EA Call
CG-128150†† HAGW283 1.281—1.531 EA Call
2 Inch Hubs
CG-153200†HBAE179 1.531—1.780 EA Call
CG-165200†† HBLH280 1.650—2.000 EA Call
2-1/2 Inch Hubs
CG-200250†† HADF979 2.000—2.343 EA Call
CG-225250†† HBLH300 2.250—2.500 EA Call
3 Inch Hubs
CG-250300†† HAKY668 2.500—2.843 EA Call
CG-268300†† HBLH302 2.687—3.062 EA Call
3-1/2 Inch Hubs
CG-300350 HBLH303 3.000—3.390 EA Call
CG-328350 HBLH304 3.281—3.515 EA Call
4 Inch Hubs
CG-350400 HBLH305 3.500—3.843 EA Call
CG-375400 HBLH306 3.750—4.000 EA Call
440-441.qxp 9/5/07 8:58 AM Page 440
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 441
Conduit
*Remove sufficient outer covering of cord or cable to pass conductors through connector
body.
Appleton®
Straight Liquidtight Strain Relief Cord and Cable
Connectors
Steel Threadless Rigid Conduit Connectors and Couplings
Compression Connectors –Concrete Tight
Model No. Hughes No. Conduit Size (In.) Unit List Price
NTC-50 HEGI956 1/2 EA Call
NTC-75 HEGI957 3/4 EA Call
NTC-100 HEGI958 1 EA Call
NTC-125 HEGI959 1-1/4 EA Call
NTC-150 HEGI960 1-1/2 EA Call
NTC-200 HEGI961 2 EA Call
NTC-250 HEGI962 2-1/2 EA Call
NTC-300 HEGI963 3 EA Call
NTC-350 HEGI964 3-1/2 EA Call
NTC-400 HEGI965 4 EA Call
Threadless Rigid Conduit Connectors and Couplings
Compression Connectors–Insulated–Concrete Tight
Model No. Hughes No. Conduit Size (In.) Unit List Price
RNTC-50 HEOU002 1/2 EA Call
RNTC-75 HEOU004 3/4 EA Call
RNTC-100 HEOU008 1 EA Call
RNTC-125 HEOU012 1-1/4 EA Call
RNTC-150 HEOU013 1-1/2 EA Call
RNTC-200 HEOU017 2 EA Call
Model No. Hughes No.
Cable
Diameter Range (in) Unit List Price
1/4 Inch Hubs
CG-0625S HCDQ400 .060–.156 EA Call
CG-1525S HCDQ401 .156–.250 EA Call
3/8 Inch Hubs
CG-1238S HBLH436 .125–.187 EA Call
CG-1838S HBLH438 .187–.312 EA Call
CG-3138S HBLH439 .312–.437 EA Call
1/2 Inch Hubs
CG-1250S HAZT982 .125–.187 EA Call
CG-1850S HEGA960 .187–.312 EA Call
CG-3150S HEFN865 .312–.437 EA Call
CG-3750S HEGI728 .375–.500 EA Call
CG-5050S HEGI502 .500–.625 EA Call
CG-6250S* HEGI699 .625–.750 EA Call
3/4 Inch Hubs
CG-1275S HBLH437 .125–.250 EA Call
CG-2575S HEGI501 .250–.375 EA Call
CG-3775S HEFT883 .375–.500 EA Call
CG-5075S HEGI698 .500–.625 EA Call
CG-6275S HEGI700 .625–.750 EA Call
CG-7575S* HEGI701 .750–.875 EA Call
1 Inch Hubs
CG-37100S HBLH440 .375–.500 EA Call
CG-50100S HEGI702 .500–.625 EA Call
CG-62100S HBLH441 .625–.750 EA Call
CG-75100S HEGI703 .750–.875 EA Call
CG-87100S HEGI719 .875–1.000 EA Call
CG-100100S* HEGI720 1.000–1.125 EA Call
1-1/4 Inch Hubs
CG-75125S HBLH442 .750–.875 EA Call
CG-87125S HBLH443 .875–1.000 EA Call
CG-100125S HEGI721 1.000–1.125 EA Call
CG-112125S HEGI722 1.125–1.250 EA Call
CG-125125S* HBLH444 1.250–1.375 EA Call
CG-137125S* HBLH445 1.375–1.500 EA Call
1-1/2 Inch Hubs
CG-115150S HBLI059 1.156–1.312 EA Call
CG-128150S HBLI060 1.281–1.531 EA Call
2 Inch Hubs
CG-153200S HALB693 1.531–1.780 EA Call
440-441.qxp 9/5/07 8:58 AM Page 441
CONDUIT FITTINGS Elbows & Connectors
442 hdsupply.com442 hdsupply.com
Conduit
Image Missing
IG ID: 19339
Date: 09/28/2005
†UL Listing Not Applicable
Appleton®
Flexible Metal Conduit Connectors
Liquidtight "ST"®
For use with liquidtight flexible metal conduit where an external visible
equipment bonding jumper is desired and permitted by the 1999 National
Electrical Code Sections 250-96(b), 501-16(b) and 502-16(b) (where external
equipment bonding jumpers are permitted, they will be limited to lengths
not exceeding 6 feet and will be routed parallel to the conduit enclosure).
Bonded steel zinc electroplated lugs are adequately sized to provide
excellent grounding continuity and allow for visible ground path
inspection. The ground wire is easily installed using only an Allen head
wrench.
Liquidtight connectors with grounding lugs can also be provided with
Appleton's "STN", "STL"and "Female ST"Connectors (consult factory).
Model No. Hughes No. Conduit Size (In.) Unit List Price
Straight
ST-38 HEGJ036 3/8 flex, 1/2 hub EA Call
ST-50 HEGJ037 1/2 EA Call
ST-75 HEGJ039 3/4 EA Call
ST-100 HEGJ041 1 EA Call
ST-125 HEGJ042 1-1/4 EA Call
ST-150 HEGJ043 1-1/2 EA Call
ST-200 HEGJ044 2 EA Call
ST-250 HEGJ045 2-1/2 EA Call
ST-300 HEGJ046 3 EA Call
ST-350 HEGI339 3-1/2 EA Call
ST-400 HEGJ047 4 EA Call
ST-500†HEGJ048 5 EA Call
90°
ST-9038 HEGJ052 3/8 flex, 1/2 hub EA Call
ST-9050 HEGJ053 1/2 EA Call
ST-9075 HEGJ054 3/4 EA Call
ST-90100 HEGI718 1 EA Call
ST-90125 HEGJ058 1-1/4 EA Call
ST-90150 HEGJ059 1-1/2 EA Call
ST-90200 HEGJ060 2 EA Call
ST-90250 HEGJ061 2-1/2 EA Call
ST-90300 HEGJ062 3 EA Call
ST-90400 HEGJ063 4 EA Call
442-443.qxp 9/5/07 8:58 AM Page 442
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 443
Conduit
†Not CSA Certified
*Select Connectors by Physical Dimensions of cable as Dimensions May Vary Between Manufacturers.
Appleton®
Straight Armored Cable and Flexible
Metal Conduit Connectors
Insulated Malleable
Model No. Hughes No. Conduit Size (In.) Cable Size Hole Size (decimal inches) Weight per 100 (lbs.) Unit List Price
Armored Cable* and Flexible Metal Conduit†
7481VI HEGI586 1/2 .937 5/8 12.0 EA Call
7482VI HEGI587 3/4 1.125 13/16 17.5 EA Call
One Screw - Flexible Metal Conduit†
7483I HEGI588 1 1.380 1 32.0 EA Call
7484I HEGI589 1-1/4 1.630 1-3/8 43.0 EA Call
One Screw - Flexible Metal Conduit†
7485I HEGI590 1-1/2 1.950 1-19/32 67.0 EA Call
7486I HEGI591 2 2.450 2 138.0 EA Call
7487I HEOP098 2-1/2 3.062 2-7/16 169.0 EA Call
7488I HEGI592 3 3.563 3-1/16 230.0 EA Call
7489I HEOP105 3-1/2 4.125 3-1/2 300.0 EA Call
7490I HEGI593 4 4.665 4 400.0 EA Call
Straight Armored Cable and Flexible
Metal Conduit Connectors
Malleable
Model No. Hughes No. Conduit Size (In.) Cable Size Hole Size (decimal inches) Weight per 100 (lbs.) Unit List Price
Armored Cable* and Flexible Metal Conduit
7480V HEGJ192 3/8†.687 5/8 11.4 EA Call
7481V HEGJ193 1/2 .937 5/8 12.0 EA Call
7482V HEGJ194 3/4 1.125 13/16 17.5 EA Call
One Screw - Flexible Metal Conduit
7483 HEGJ195 1 1.380 1 32.0 EA Call
Two Screw - Flexible Metal conduit
7485 HEGJ119 1-1/2 1.950 1-19/32 67.0 EA Call
7486 HEGJ196 2 2.450 2 138.0 EA Call
7487 HEGJ197 2-1/2 3.062 2-7/16 169.0 EA Call
7488 HEGJ198 3 3.563 3-1/16 230.0 EA Call
7489 HEGI329 3-1/2 4.125 3-1/2 300.0 EA Call
7490 HEGI330 4 4.665 4 400.0 EA Call
†1/2" KO
*Select Connectors by Physical Dimensions of cable as Dimensions May Vary Between Manufacturers.
442-443.qxp 9/5/07 8:59 AM Page 443
CONDUIT FITTINGS Elbows & Connectors
444 hdsupply.com
Conduit
*Furnished with Removable Nipple
†Not CSA Certified.
Appleton®
Couplings and Connectors
Threaded Rigid Conduit and IMC
Model No. Hughes No. Conduit Size (In.) Weight per 100 (lbs.) Unit List Price
Three Piece Union– Concrete Tight
EC-50 HEGI306 1/2 16.5 EA Call
EC-75 HEGI307 3/4 24.0 EA Call
EC-100 HEGI308 1 58.0 EA Call
EC-125 HEGI309 1-1/4 98.0 EA Call
EC-150 HEGI310 1-1/2 134.0 EA Call
EC-200 HEGI311 2 198.0 EA Call
EC-250 HEGI312 2-1/2 255.0 EA Call
EC-300 HEGI313 3 394.0 EA Call
EC-350 HEGI314 3-1/2 380.0 EA Call
EC-400 HEGI315 4 700.0 EA Call
EC-500 HEGI316 5 788.0 EA Call
EC-600 HEOM611 6 825.0 EA Call
90° Female Gasketed Pulling Elbows– Watertight – Malleable Iron
FFL-50 HEGI479 1/2 31.0 EA Call
FFL-75 HEGI480 3/4 46.0 EA Call
FFL-100 HEGI481 1 76.0 EA Call
FFL-125 HEGX488 1-1/4 120.0 EA Call
FFL-150 HEGI482 1-1/2 160.0 EA Call
FFL-200 HEGI483 2 293.0 EA Call
90° Male to Female Gasketed Pulling Elbows – Watertight – Malleable Iron
MFL-50 HEGI947 1/2 36.0 EA Call
MFL-75 HEGI948 3/4 55.0 EA Call
MFL-100 HEGI949 1 90.0 EA Call
MFL-125* HEGI950 1-1/4 141.0 EA Call
MFL-150* HEOT609 1-1/2 192.0 EA Call
MFL-200* HEGI951 2 335.0 EA Call
90° Female Pulling Elbows†– Malleable Iron
PFFL-50 HEOT829 1/2 49.0 EA Call
PFFL-75 HEOT831 3/4 76.0 EA Call
PFFL-100 HEOT833 1 121.0 EA Call
90° Female Elbows†
LF90-50 HEOR673 1/2 39.0 EA Call
LF90-75 HEOR678 3/4 53.0 EA Call
90° Male to Female Long Bushed Elbows†– Malleable Iron
LMFL90-50 HEFQ507 1/2 32.5 EA Call
LMFL90-75 HEFQ125 3/4 50.0 EA Call
LMFL90-100 HEGI799 1 87.0 EA Call
LMFL90-125 HEOR796 1-1/4 126.0 EA Call
LMFL90-150 HEOR801 1-1/2 170.0 EA Call
LMFL90-200 HEOR808 2 410.0 EA Call
90° Male to Female Short Bushed Elbows†– Malleable Iron
LMF90-50 HEGI797 1/2 23.0 EA Call
LMF90-75 HEOR775 3/4 36.0 EA Call
LMF90-100 HEGI798 1 58.0 EA Call
90° Male to Female Short Box Connectors†– Malleable Iron
LMF90-50L HEOR770 1/2 26.0 EA Call
LMF90-75L HEOR776 3/4 34.0 EA Call
EC
FFL
PFFL
LF90 LMFL90
LMF90
MFL
444-445.qxp 9/5/07 8:59 AM Page 444
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 445
Conduit
Model No. Hughes No. Conduit Size (In.) Body Length (in.) Maximum Diameter (in.) Thread Length (In.) Unit List Price
Uninsulated
7050S HAKN952 1/2 1-1/8 1-1/16 3/8 EA Call
7075S HAKO004 3/4 1-1/32 1-1/4 7/16 EA Call
7100S HAKO045 1 1-1/4 1-9/16 7/16 EA Call
7125S HAKN926 1-1/4 1-13/16 2 9/16 EA Call
7150S HAKO111 1-1/2 2 2-3/16 9/16 EA Call
7200S HAKO154 2 2-1/4 2-11/16 11/16 EA Call
7250S HAKO209 2-1/2 2-3/8 3-11/32 7/8 EA Call
7300S HAKO284 3 2-7/8 4 7/8 EA Call
7350S HAKN927 3-1/2 3 4-1/2 1 EA Call
7400S HAKO400 4 3-3/16 5-1/16 1 EA Call
Insulated Throat
7050ST HAKO836 1/2 1-1/8 1-1/16 3/8 EA Call
7075ST HAKO878 3/4 1-1/32 1-1/4 7/16 EA Call
7100ST HAKO920 1 1-1/4 1-9/16 7/16 EA Call
7125ST HAKO972 1-1/4 1-13/16 2 9/16 EA Call
7150ST HAKP013 1-1/2 2 2-3/16 9/16 EA Call
7200ST HAKP098 2 2-1/4 2-11/16 11/16 EA Call
7250ST HAKP119 2-1/2 2-3/8 3-11/32 7/8 EA Call
7300ST HAKP172 3 2-7/8 4 7/8 EA Call
7350ST HAKP226 3-1/2 3 4-1/2 1 EA Call
7400ST HAKP291 4 3-3/16 5-1/16 1 EA Call
Appleton®
Gland Compression Connectors Type
7000 Series
• Male hub threads NPS
• Concretetight
• Steel Body and Nut
• Zinc Plated
• UL Listed E14815
• Listed Concretetight 1⁄2" through 4"
See page 619 for Hand Benders
444-445.qxp 9/5/07 8:59 AM Page 445
CONDUIT FITTINGS Elbows & Connectors
444466hhddssuuppppllyy..ccoomm
446 hdsupply.com
Conduit
Appleton®
Set Screw Connectors Type
4000 Series
• Heavy steel walls
• Concretetight when taped
• Pre-set/Pre-staked set screws
• Male hub threads NPS
• Available with insulated throat
• Three-way combination screws
Speedlock™Steel Box Connectors
Type AMC
For connecting MC, AC, and Flex Cable
• No locknut required
• Single-unit or duplex construction with captive clamp
• Connects various sizes of MC, AC and Flex RW cables with just
four fittings.
• Easy to install. Just tilt, insert and snap down.
• Integral red plastic insulated throat bushing provides maximum
protection for wire installation.
Model No. Hughes No. Conduit Size (In.) Length (In.) Height (In.) Unit List Price
AMC-50 HAGS596 1/2 Single 1-3/8 13/32 EA Call
AMC-75 HAZT586 3/4 Single 1-5/8 9/16 EA Call
AMC-5075 HAWX726 1/2 KO; 3/4 capacity 1-5/8 9/16 EA Call
AMC-52 HAIB558 1/2 Duplex 1-9/16 9/16 EA Call
Model No. Hughes No. Conduit Size (In.) Body Length (in.) Maximum Diameter (in.) Thread Length (In.) Unit List Price
Uninsulated
4050S HBMT104 1/2 1-1/32 27/32 7/16 EA Call
4075S HBMT105 3/4 1-3/32 1-5/64 7/16 EA Call
4100S HBMT106 1 1-3/16 1-5/16 7/16 EA Call
4125S HBMT107 1-1/4 1-3/4 1-11/16 9/16 EA Call
4150S HBMT108 1-1/2 1-15/16 1-15/16 9/16 EA Call
4200S HBMT109 2 2-3/16 2-3/8 5/8 EA Call
4250S HADE383 2-1/2 2-3/8 3-1/8 7/8 EA Call
4300S HADE519 3 2-7/8 3-3/4 7/8 EA Call
4350S HADE552 3-1/2 3 4-1/4 1 EA Call
4400S HADE617 4 3-3/16 4-3/4 1 EA Call
Insulated Throat
4050ST HADE659 1/2 1-1/32 27/32 7/16 EA Call
4075ST HADE453 3/4 1-3/32 1-5/64 7/16 EA Call
4100ST HADE197 1 1-3/16 1-5/16 7/16 EA Call
4125ST HADE719 1-1/4 1-3/4 1-11/16 9/16 EA Call
4150ST HADE781 1-1/2 1-15/16 1-15/16 9/16 EA Call
4200ST HADE822 2 2-3/16 2-3/8 5/8 EA Call
4250ST HAYL106 2-1/2 2-3/8 3-1/8 7/8 EA Call
4300ST HADR795 3 2-7/8 3-3/4 7/8 EA Call
4350ST HACY727 3-1/2 3 4-1/4 1 EA Call
4400ST HADR791 4 3-3/16 4-3/4 1 EA Call
446-447.qxp 9/5/07 8:59 AM Page 446
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 447
Conduit
•Not UL Listed
O-Z/Gedney
Gland Compression Connectors
Type 31
To connect threadless rigid conduit to boxes and enclosures.
• Malleable Iron/Zinc Electroplated
• Concretetight
• Male hub threads (NPS 1⁄2" through 2"; NPT above 2")
Model No. Hughes No. Conduit Size (In.) Overall Length (In.) Maximum Diameter (in.) Thread Length (In.) Unit List Price
Uninsulated
31-050 HALA560 1/2 3/4 1-3/8 7/16 EA Call
31-075 HALA374 3/4 7/8 1-9/16 7/16 EA Call
31-100 HALA663 1 1-3/16 1-15/16 9/16 EA Call
31-125 HALA705 1-1/4 1-3/8 2-5/16 5/8 EA Call
31-150 HALA737 1-1/2 1-3/8 2-5/8 5/8 EA Call
31-200 HALA780 2 1-1/2 3-5/16 11/16 EA Call
31-250 HALA834 2-1/2 2-1/8 4-1/32 1 EA Call
31-300 HALA864 3 2-7/16 4-13/16 1 EA Call
31-350 HALA906 3-1/2 2-5/8 5-1/2 1-3/16 EA Call
31-400 HALA607 4 2-9/16 6-1/8 1-1/4 EA Call
31-500 HBMS942 5 2-3/16 7-3/8 1-1/8 EA Call
31-600 HBMS943 6 2-3/8 8-9/16 1-3/8 EA Call
Insulated Throat
31-050T HAFY101 1/2 3/4 1-3/8 7/16 EA Call
31-075T HAFY102 3/4 7/8 1-9/16 7/16 EA Call
31-100T HAFY103 1 1-3/16 1-15/16 9/16 EA Call
31-125T HAFY104 1-1/4 1-3/8 2-5/16 5/8 EA Call
31-150T HAFY105 1-1/2 1-3/8 2-5/8 5/8 EA Call
31-200T HAFY106 2 1-1/2 3-5/16 11/16 EA Call
31-250T HAFY107 2-1/2 2-1/8 4-1/32 1 EA Call
31-300T HAFY108 3 2-7/16 4-13/16 1 EA Call
31-350T HAFY109 3-1/2 2-5/8 5-1/2 1-3/16 EA Call
31-400T HAFY110 4 2-9/16 6-1/8 1-1/4 EA Call
31-500T HAFY111 5 2-3/16 7-3/8 1-1/8 EA Call
31-600T HAFY162 6 2-3/8 8-9/16 1-3/8 EA Call
See page 647 for Slug-Splitter®
Hydraulic Driver Punch Kit
446-447.qxp 9/5/07 8:59 AM Page 447
CONDUIT FITTINGS Elbows & Connectors
448 hdsupply.com
Conduit
•UL Listing not applicable
*CSA Certification not applicable
O-Z/Gedney
Liquidtight Fittings
Type 4Q - Straight
To secure, ground and seal Liquidtight Flexible Metal conduit, Type
LFMC, to boxes and enclosures.
Malleable Iron Body and Nut, Zinc Electroplated, Steel Ferrule, Zinc
Electroplated.
• Tapered threaded male hub NPT
• Compact, slim diameter with small turning radius
• Furnished with locknut and sealing ring.
• Liquidtight/Raintight/Oiltight
• Suitable for grounding through 1-1⁄4" Trade Size per NEC Section
250.118(7)
• For Trade Sizes 1-1⁄2" and larger, an internal or external equipment
bonding conductor is required. See 4Q-L Series with external
ground lug in Catalog Section GB.
•UL Listing not applicable
Liquidtight Fittings
Type 4Q - 90°
To secure, ground and seal Liquidtight Flexible Metal conduit, Type
LFMC, to boxes and enclosures. Malleable Iron Body and Nut, Zinc
Electroplated. Steel Ferrule, Zinc Electroplated.
• Tapered threaded male hub NPT
• Furnished with locknut and sealing ring.
• Liquidtight/Raintight/Oiltight
• Suitable for grounding through 1-1⁄4" Trade Size per NEC Section
250.118(7)
• For Trade Sizes 1-1⁄2" and larger, an internal or external equipment
bonding conductor is required.
90°Raintight Corner Pulling Ells
Provides a compact wire-pulling point and a 90°change of direction in
a conduit run. Malleable Iron/Zinc Plated
• Threaded for rigid conduit and IMC (NPT)
• Furnished with Neoprene gasketed steel cover, zinc electroplated.
Model No. Hughes No. Conduit Size (In.) Unit List Price
FF-050 HAKW090 1/2 EA Call
FF-075 HAKW133 3/4 EA Call
FF-100 HAKW175 1 EA Call
FF-125 HAZO196 1-1/4 EA Call
FF-150 HBMP663 1-1/2 EA Call
FF-200 HBMP664 2 EA Call
FF-250 HBMP765 2-1/2 EA Call
FF-300 HBMP766 3 EA Call
Model No. Hughes No. Conduit Size (In.) Unit List Price
Uninsulated
4Q-38 HAHF269 3/8 (1/2 KO) EA Call
4Q-50 HAHF171 1/2 EA Call
4Q-75 HAHF697 3/4 EA Call
4Q-100 HAHF909 1 EA Call
4Q-125 HAHG288 1-1/4 EA Call
4Q-150 HAHG195 1-1/2 EA Call
4Q-200 HAHG578 2 EA Call
4Q-250 HAHG775 2-1/2 EA Call
4Q-300 HAHG506 3 EA Call
4Q-350 HAHH116 3-1/2 EA Call
4Q-400 HAXM545 4 EA Call
4Q-500• HBMS469 5 EA Call
4Q-600• * HBMS470 6 EA Call
Insulated Throat
4Q-38T HAHF382 3/8 (1/2 KO) EA Call
4Q-50T HAHF580 1/2 EA Call
4Q-75T HAHF796 3/4 EA Call
4Q-100T HAHG073 1 EA Call
4Q-125T HAHG391 1-1/4 EA Call
4Q-150T HAHR703 1-1/2 EA Call
4Q-200T HAHR879 2 EA Call
4Q-250T HAHS184 2-1/2 EA Call
4Q-300T HAHS375 3 EA Call
4Q-350T HAHS558 3-1/2 EA Call
4Q-400T HAHS661 4 EA Call
4Q-500T• HBMS468 5 EA Call
4Q-600T• * HBMS471 6 EA Call
Model No. Hughes No. Conduit Size (In.) Unit List Price
Uninsulated
4Q-938 HAHI072 3/8 (1/2 KO) EA Call
4Q-950 HAHG891 1/2 EA Call
4Q-975 HAHI304 3/4 EA Call
4Q-9100 HAHI698 1 EA Call
4Q-9125 HAHI895 1-1/4 EA Call
4Q-9150 HAHJ099 1-1/2 EA Call
4Q-9200 HAHJ258 2 EA Call
4Q-9250 HAHJ163 2-1/2 EA Call
4Q-9300 HAHJ482 3 EA Call
4Q-9400 HAZM420 4 EA Call
4Q-9500• HBMS476 5 EA Call
Insulated Throat
4Q-938T HAHI187 3/8 (1/2 KO) EA Call
4Q-950T HAHI400 1/2 EA Call
4Q-975T HAHI572 3/4 EA Call
4Q-9100T HAHI790 1 EA Call
4Q-9125T HAHR587 1-1/4 EA Call
4Q-9150T HAHR775 1-1/2 EA Call
4Q-9200T HAHS070 2 EA Call
4Q-9250T HAHS285 2-1/2 EA Call
4Q-9300T HAHS466 3 EA Call
4Q-9400T HBMS477 4 EA Call
4Q-9500T• HBMS478 5 EA Call
448-449.qxp 9/5/07 9:00 AM Page 448
Elbows & Connectors CONDUIT FITTINGS
hdsupply.com 449
Conduit
Shamrock™- T&B
Rigid Steel Conduit Elbows
Standard Radius Hot Dip Galvanized 45°and 90°
EZ Flex Terminal Adapters
EZ Flex Snap-In Terminal Adapters
Couplings
Schedule 40
PVC fittings for electrical applications conform to NEMA TC-3 and
UL514.
Cantex
EZ Flex Couplings
Some products not available at all locations. Check with
your local HD Supply representative for product availability.
Model
No. Hughes No.
Size
(In.)
Minimum
Radius
(in.)
Weight
(lbs. per
100)
Case
Quantity Unit List Price
7751 HFFQ100 4" 16" 2,067,
3,160
25 EA Call
Model No. Hughes No.
Conduit
Size (In.)
Package
Qty. Unit List Price
5163380 HEJX349 1/2 200 Pack Call
5163381 HEJX353 3/4 200 Pack Call
5163382 HEJW499 1 100 Pack Call
Model No. Hughes No.
Conduit
Size (In.)
Package
Qty. Unit List Price
5163415 HBYX176 1/2 200 Pack Call
5163416 HBYX177 3/4 200 Pack Call
5163417 HBYX178 1 100 Pack Call
Model No. Hughes No.
Conduit
Size (In.)
Carton
Quantity Unit List Price
6141623 HEGQ518 1/2 200 EA Call
6141624 HEGQ519 3/4 125 EA Call
6141625 HEGQ449 1 70 EA Call
6141626 HEGQ450 1-1/4 40 EA Call
6141627 HEGQ451 1-1/2 30 EA Call
6141628 HEGQ529 2 40 EA Call
6141629 HEGQ530 2-1/2 20 EA Call
6141630 HEGQ580 3 40 EA Call
6141631 HEGQ425 3-1/2 30 EA Call
6141632 HEGQ509 4 20 EA Call
6141633 HEGQ510 5 10 EA Call
6141634 HBYX565 6 8 EA Call
Model No. Hughes No.
Conduit
Size (In.)
Package
Qty. Unit List Price
5163405 HBYX584 1/2 200 Pack Call
5163406 HBYX585 3/4 200 Pack Call
5163407 HBYX368 1 100 Pack Call
448-449.qxp 9/5/07 9:00 AM Page 449
CONDUIT FITTINGS Couplings & Adapters
450 hdsupply.com
Conduit
Cantex
Terminal Adapters
Schedule 40
PVC fittings for electrical applications conform to NEMA TC-3
and UL514.
Female Adapters
Schedule 40
PVC fittings for electrical applications conform to NEMA TC-3
and UL514.
Carlon®
Quick Connect Adapters & Couplings
• Standards: UL Listed
• For use with Flex-Plus®Blue™ENT
• Carlon one piece ENT Quick Connect Couplings, Threaded
Adapters and Snap-In Terminator Adapters are suitable for damp
locations. Quick Connect Couplings and Threaded Adapters are
concrete-tight when used with Carlon ENT.
Model No. Hughes No. Conduit Size (In.) Unit List Price
Couplings
A240D HECO229 1/2" EA Call
A240E HECO230 3/4" EA Call
A240F HECO231 1" EA Call
Threaded Adapters
A243D HDVU038 1/2" EA Call
A243E HECN656 3/4" EA Call
A243F HECN658 1" EA Call
Snap-In Adapters
A253D HECO232 1/2" EA Call
A253E HECO233 3/4" EA Call
A253F HECO234 1" EA Call
Model No. Hughes No.
Conduit
Size (In.)
Carton
Quantity Unit List Price
5140103 HEGQ520 1/2 200 EA Call
5140104 HEGQ521 3/4 125 EA Call
5140105 HEGQ531 1 70 EA Call
5140106 HEGQ532 1-1/4 40 EA Call
5140107 HBYX587 1-1/2 30 EA Call
5140108 HBYX588 2 40 EA Call
5140109 HEGQ533 2-1/2 20 EA Call
5140110 HBYX375 3 40 EA Call
5140111 HEGQ489 3-1/2 30 EA Call
5140112 HBYX473 4 20 EA Call
5140013 HHBR746 5 10 EA Call
5140114 HBYX475 6 8 EA Call
Model No. Hughes No.
Conduit
Size (In.)
Carton
Quantity Unit List Price
5140043 HEGQ522 1/2 200 EA Call
5140044 HEGQ523 3/4 125 EA Call
5140045 HEGQ534 1 70 EA Call
5140046 HEGQ535 1-1/4 40 EA Call
5140047 HEGQ536 1-1/2 30 EA Call
5140048 HEGQ537 2 40 EA Call
5140049 HEGQ538 2-1/2 20 EA Call
5140050 HEGQ484 3 40 EA Call
5140051 HEGQ485 3-1/2 30 EA Call
5140052 HEGQ486 4 20 EA Call
5140053 HEGQ487 5 10 EA Call
5140054 HEGQ488 6 8 EA Call
450-451.qxp 9/5/07 9:00 AM Page 450
Couplings & Adapters CONDUIT FITTINGS
hdsupply.com 451
Conduit
Carlon®
Standard Couplings
Rigid Nonmetallic Conduit
Standards: UL listed.
Standard Expansion Fittings
Rigid Nonmetallic Conduit
Standards: UL listed.
• Molded two-piece design.
• For Use with Schedule 40 and Schedule 80
• Designed to compensate for length changes due to temperature
variations in exposed conduit runs.
Model No. Hughes No. Size (In.)
Standard
Carton Quantity
Dimension
A (in.)
Dimension
B (in.)
Inner
Diameter (In.)
Outer
Diameter (In.)
Dimension
C (in.)
Dimension
L (in.) Unit List Price
E940D HEHC879 1/2 150 .852 .836 .728 1-7/64 11/16 1-1/2 EA Call
E940E HEHD010 3/4 100 1.064 1.046 .840 1-5/16 3/4 1-5/8 EA Call
E940F HEHD060 1 50 1.330 1.310 1.210 1-5/8 15/16 2 EA Call
E940G HEHE317 1-1/4 30 1.677 1.655 1.535 1-63/64 1 2-1/8 EA Call
E940H HEGW402 1-1/2 25 1.918 1.894 1.755 2-15/64 1-1/8 2-3/8 EA Call
E940J HEHH921 2 30 2.393 2.369 2.190 2-47/64 1-3/15 2-1/2 EA Call
E940K HEHD747 2-1/2 20 2.890 2.868 2.688 3-5/16 1-33/64 3-3/16 EA Call
E940L HEHD748 3 25 3.515 3.492 3.375 3-31/32 1-3/4 3-13/32 EA Call
E940M HEHH930 3-1/2 20 4.015 3.992 3.780 4-9/16 1-3/4 3-5/8 EA Call
E940N HEHD749 4 15 4.515 4.491 4.265 5-3/32 1-25/32 3-3/4 EA Call
E940P HEAC511 5 8 5.593 5.553 5.097 6-1/4 1-5/16 4-1/16 EA Call
E940R HECN570 6 5 6.658 6.614 6.115 7-1/2 2-3/16 4-5/8 EA Call
Model No. Hughes No. Size (In.) Standard Carton Quantity Travel Length (In.) Unit List Price
Coupling Ends
E945D HDVA696 1/2 20 4 EA Call
E945E HECN762 3/4 15 4 EA Call
E945F HECJ663 1 10 4 EA Call
E945G HEAZ550 1-1/4 5 4 EA Call
E945H HECO610 1-1/2 5 4 EA Call
E945J HECN896 2 15 8 EA Call
E945K HDVT656 2-1/2 10 8 EA Call
E945L HDVT090 3 10 8 EA Call
E945M HEFM921 3-1/2 5 8 EA Call
E945N HECO611 4 5 8 EA Call
E945P HECP095 5 1 8 EA Call
E945R HECO612 6 1 8 EA Call
Male Terminal Adapter Ends
E945DX HHBS109 1/2 20 4 EA Call
E945EX HHBS110 3/4 15 4 EA Call
E945FX HHBS111 1 10 4 EA Call
E945GX HHBS112 1-1/4 5 4 EA Call
E945HX HHBS113 1-1/2 5 4 EA Call
E945JX HHBS114 2 15 8 EA Call
E945KX HEDQ284 2-1/2 10 8 EA Call
E945KXL* HECP094 2-1/2 10 12 EA Call
E945LX HEDQ285 3 10 8 EA Call
E945MX HHBS115 3-1/2 5 8 EA Call
E945NX HHBS116 4 5 8 EA Call
E945PX HFUT749 5 3 8 EA Call
E945RX HHBS117 6 2 8 EA Call
450-451.qxp 9/5/07 9:00 AM Page 451
Transition Adapter
Male ENT to Schedule 40
Transition Adapter
Reducers
90° Stub Down
Transition Adapter
Mud Box with
Ceiling Ring
Mounting Brackets
Outlet and Switch Boxes -
Eccentric Knockouts
Transition Adapter
ENT to EMT
Vertical Stub Down
Vertical
Stub Down
Transition Adapter
45° Stub Down
Mud Box Base with
Blank Cover
Mud Box with
One-Gang Ring
Mud Box with
Two-Gang Ring
Mud Box with 4
Square Ring
ENT Bridge
Eliminate off-site modifications by using Carlon “Out-of-
the-Box” ENT Accessories –
Transition Adapters, Stub Downs,
Mud Box Assemblies, and Switch and Outlet Boxes with
Eccentric Knockouts
. Each product is designed to provide Ready
to Use, Out-of-the-Box solutions for all ENT installations –
•
Four new stub downs
to fit any transition right out of the
box
•
Five new mud box assemblies
for literally any device from
fire alarms to data jacks
•
Transition Adapters
designed to make transitions from one
conduit type to another a snap. Ideal for when the specifica-
tion says PVC Schedule 40
• Reducers for jobsite flexibility in converting Carlon fittings
into another size
•
New ENT switch and outlet boxes
with the largest
capacity available in the market today and eccentric knockouts
to minimize the number SKU’s needed on the jobsite
No matter what the application, Carlon has the solution –
Carlon ENT Solutions: Ready to use Out-of-the-box.
ENT Solutions:
Ready to Use
“
Out-of-the-Box
”
NEW
For more information call
1-800-3-CARLON (1-800-322-7566)
or visit our website at
www.carlon.com
TDD/Hearing Impaired Access (216) 831-5918
25701 Science Park Drive
•
Cleveland, Ohio 44122
452_EC05.qxd 10/25/05 11:24 AM Page 2
Couplings & Adapters CONDUIT FITTINGS
hdsupply.com 453
Conduit
Carlon
Transition Adapters
For use with Flex-Plus Blue ENT
• Case Quantity: 100
• Standards: UL Listed
Special Long Line Couplings
Rigid Nonmetallic Conduit
• Standards: UL Listed, except E941RF
Special Long Line Sleeve Couplings
Rigid Nonmetallic Conduit
Box Adapters for Enclosures
Rigid Nonmetallic Conduit
Standards: UL Listed
Adapts nonmetallic conduit to all electrical enclosures by inserting
adapter through knockout and cementing into Carlon couplings.
Some products not available at all locations. Check with
your local HD Supply representative for product availability.
Model No. Hughes No. Description Size Unit List Price
A263D HFUT969 Male ENT to
Schedule 40, 80
1/2" ENT to 1/2"
Sch. 40 or 80
EA Call
A263E HFUT970 Male ENT to
Schedule 40, 80
3/4" ENT to 3/4"
Sch. 40 or 80
EA Call
A263F HFUT971 Male ENT to
Schedule 40, 80
1" ENT to 1"
Sch. 40 or 80
EA Call
A245D HFUT974 ENT to EMT 1/2" ENT to 1/2"
EMT
EA Call
A245E HFUT975 ENT to EMT 3/4" ENT to 3/4"
EMT
EA Call
A245F HFUU122 ENT to EMT 1" ENT to
1" EMT
EA Call
A273DF HGZO884 Reducers 3/4" to 1/2" EA Call
A273EF HGDY417 Reducers 1" to 3/4" EA Call
Model No. Hughes No.
Size
(In.)
Standard
Carton
Quantity
Standard
Carton
Weight (lbs.) Unit List Price
E948H HEIN607 1-1/2 25 6 EA Call
E948J HECO708 2 25 5 EA Call
E948K HEDQ045 2-1/2 25 16 EA Call
E948L HEDQ046 3 25 13 EA Call
E948N HEDQ047 4 10 8 EA Call
Model No. Hughes No.
Size
(In.)
Standard
Carton
Quantity
Outside
Diameter
(In.) Unit List Price
E996D HECO627 1/2 100 .840 EA Call
E996E HECO628 3/4 100 1.050 EA Call
E996F HDVV055 1 100 1.315 EA Call
E996G HEIN681 1-1/4 50 1.660 EA Call
E996H HEIN683 1-1/2 50 1.900 EA Call
E996J HEIN623 2 25 2.375 EA Call
E996K-CAR HECN382 2-1/2 10 2.875 EA Call
E996L-CAR HECN755 3 5 3.500 EA Call
E996N HDVT819 4 10 4.500 EA Call
Model No. Hughes No.
Size
(In.)
Standard
Carton
Quantity
Standard
Carton
Weight (lbs.) Unit List Price
E941H HEDQ283 1-1/2 40 9 EA Call
E941J HECO617 2 25 8 EA Call
E941K HEDP794 2-1/2 15 8 EA Call
E941L HEDP795 3 15 14 EA Call
E941N HECO618 4 10 15 EA Call
E941PF HCIZ698 5 4 12 EA Call
E941RF HEDN832 6 5 21 EA Call
452-453.qxp 9/5/07 9:00 AM Page 453
CONDUIT FITTINGS Couplings & Adapters
454 hdsupply.com
Conduit
Carlon®
Male Terminal Adapters
Rigid Nonmetallic Conduit
For adapting nonmetallic conduits to boxes, threaded fittings, metallic
systems. Male threads on one end, socket end on other.
UL listed.
Female Adapters
Rigid Nonmetallic Conduit
For adapting nonmetallic conduits to threaded fittings, metallic systems.
Female threads on one end, socket end on other.
UL listed.
Model No. Hughes No. Size (In.)
Standard
Carton Quantity
Dimension
A (in.)
Dimension
B (in.)
Dimension
C (in.)
Dimension
S (in.)
Dimension
L (in.) Unit List Price
E943D HEHH933 1/2 150 .852 .836 5/8 9/16 1-5/16 EA Call
E943E HEHH935 3/4 125 1.064 1.046 3/4 9/16 1-3/8 EA Call
E943F HEHH938 1 50 1.330 1.310 1 11/16 1-25/32 EA Call
E943G HEHP253 1-1/4 50 1.677 1.655 1 3/4 1-15/16 EA Call
E943H HEIN605 1-1/2 25 1.918 1.894 1-3/16 3/4 2-1/16 EA Call
E943J HEIN641 2 50 2.393 2.369 1-3/16 3/4 2-1/8 EA Call
E943K-CAR HEIN643 2-1/2 5 2.890 2.868 1-3/4 7/8 2-7/8 EA Call
E943L-CAR HEIN646 3 5 3.515 3.492 1-15/16 7/8 3-1/16 EA Call
E943M HEIN649 3-1/2 30 4.015 3.992 2-7/16 1-7/8 3-7/16 EA Call
E943N-CAR HEIN651 4 20 4.515 4.491 2-3/8 7/8 3-1/2 EA Call
E943P HFAP010 5 5 5.593 5.553 2-1/3 1 3-15/16 EA Call
E943R HECY049 6 10 6.658 6.614 2-3/8 1 3-3/8 EA Call
Model No. Hughes No. Size (In.)
Standard
Carton Quantity
Dimension
A (in.)
Dimension
B (in.)
Dimension
C (in.)
Dimension
T (in.)
Dimension
L (in.) Unit List Price
E942D HEIN656 1/2 150 .852 .836 11/16 3/4 1-9/16 EA Call
E942E HEIN657 3/4 100 1.064 1.046 13/16 3/4 1-5/8 EA Call
E942F HEIN665 1 50 1.330 1.310 15/16 7/8 1-15/16 EA Call
E942G HEIN668 1-1/4 30 1.677 1.655 1 7/8 2 EA Call
E942H HEIN671 1-1/2 25 1.918 1.894 1-1/8 7/8 2-7/32 EA Call
E942J HEIN672 2 30 2.393 2.369 1-3/16 1 2-5/16 EA Call
E942K-CAR HEIN674 2-1/2 4 2.890 2.868 1-5/8 1-1/8 2-15/16 EA Call
E942L-CAR HEIN675 3 3 3.515 3.492 1-3/4 1-1/8 3-1/16 EA Call
E942M HEIN677 3-1/2 20 4.015 3.992 1-7/8 1-1/8 3-1/4 EA Call
E942N-CAR HEIN680 4 7 4.515 4.491 2 1-1/8 3-13/64 EA Call
E942P HEFY227 5 8 5.593 5.553 1-15/16 1-1/16 3-3/16 EA Call
454-455.qxp 9/5/07 9:01 AM Page 454
Couplings & Adapters CONDUIT FITTINGS
hdsupply.com 455
Conduit
Steel City®- T&B
Rigid/Intermediate Grade Conduit Fittings
Set Screw Couplings
Two set screws starting at 2".
Model No. Hughes No. Conduit Size (In.) Unit List Price
HK-101 HBJY685 1/2" EA Call
HK-102 HBJY686 3/4" EA Call
HK-103 HBJY687 1" EA Call
HK-104 HBJY688 1-1/4" EA Call
HK-105 HBJY689 1-1/2" EA Call
HK-106 HBJY690 2" EA Call
HK-107 HBJY691 2-1/2" EA Call
HK-108 HBJY692 3" EA Call
HK-109 HBJY693 3-1/2" EA Call
HK-110 HBJY694 4" EA Call
Rigid/Intermediate Grade Conduit Fittings
Threadless Compression Couplings
Suggested use –rigid conduit only.
Model No. Hughes No. Conduit Size (In.) Unit List Price
HK-401 HBJY675 1/2" EA Call
HK-402 HBJY676 3/4" EA Call
HK-403 HBJY677 1" EA Call
HK-404 HBJY678 1-1/4" EA Call
HK-405 HBJY679 1-1/2" EA Call
HK-406 HBJY680 2" EA Call
HK-407 HBJY681 2-1/2" EA Call
HK-408 HBJY682 3" EA Call
HK-409 HBJY683 3-1/2" EA Call
HK-410 HBJY684 4" EA Call
Rigid/Intermediate Grade Conduit Fittings
Rigid Couplings –Three Piece Type
Die Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
EK-201 HBJZ961 1/2" EA Call
EK-202 HBJZ962 3/4" EA Call
Rigid/Intermediate Grade Conduit Fittings
Three Piece Couplings
Model No. Hughes No. Conduit Size (In.) Unit List Price
EK-401 HBJY595 1/2" EA Call
EK-402 HBJY596 3/4" EA Call
EK-403 HBJY246 1" EA Call
EK-404 HBJY247 1-1/4" EA Call
EK-405 HBJY597 1-1/2" EA Call
EK-406 HBJY598 2" EA Call
EK-407 HBJY537 2-1/2" EA Call
EK-408 HBJY538 3" EA Call
EK-409 HBJY599 3-1/2" EA Call
EK-410 HBJY600 4" EA Call
Thinwall Conduit Fittings (EMT)
Compression Couplings –Steel
Model No. Hughes No. Conduit Size (In.) Unit List Price
TK111A HERL959 1/2" EA Call
TK112A HERL960 3/4" EA Call
TK113A HERL961 1" EA Call
TK114A HERL962 1-1/4" EA Call
TK115A HERL963 1-1/2" EA Call
TK116A HERL964 2" EA Call
TK117A HERL965 2-1/2" EA Call
TK118A HERL966 3" EA Call
TK119A HERL967 3-1/2" EA Call
TK1110A HERL968 4" EA Call
Some products not available at all locations. Check with
your local HD Supply representative for product availability.
454-455.qxp 9/5/07 9:01 AM Page 455
CONDUIT FITTINGS Couplings & Adapters
456 hdsupply.com
Conduit
Steel City®- T&B
Thinwall Conduit Fittings (EMT)
Compression Couplings
Die Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
TK-211-SC HBAG980 1/2" EA Call
TK-212-SC HBAH033 3/4" EA Call
TK-213-SC HBJY999 1" EA Call
TK-214-SC HBJZ000 1-1/4" EA Call
TK-215-SC HBJZ001 1-1/2" EA Call
TK-216-SC HBJZ002 2" EA Call
TK-217-SC HBAH235 2-1/2" EA Call
TK-218-SC HBAH266 3" EA Call
TK-219-SC HBAH068 3-1/2" EA Call
TK-2110-SC HBAH371 4" EA Call
Thinwall Conduit Fittings (EMT)
Set Screw Couplings –Steel
• Concrete Tight, when taped
• Zinc Plated
Model No. Hughes No. Conduit Size (In.) Unit List Price
TK121A HERL896 1/2" EA Call
TK122A HERL897 3/4" EA Call
TK123A HERL921 1" EA Call
TK124A HERL922 1-1/4" EA Call
TK125A HERL923 1-1/2" EA Call
TK126A HERL924 2" EA Call
TK127A HERL969 2-1/2" EA Call
TK128A HERL970 3" EA Call
TK129A HERL971 3-1/2" EA Call
TK1210A HERL972 4" EA Call
Thinwall Conduit Fittings (EMT)
Set Screw Couplings
Die Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
TK-221 HGZO792 1/2" EA Call
TK-222 HGZO794 3/4" EA Call
TK-223 HGZO795 1" EA Call
TK-224 HGZO796 1-1/4" EA Call
TK-225 HGZO797 1-1/2" EA Call
TK-226 HGZO798 2" EA Call
TK-227 HGZO799 2-1/2" EA Call
TK-228 HGZO800 3" EA Call
TK-229 HGZO801 3-1/2" EA Call
TK-2210 HGZO793 4" EA Call
Thinwall Conduit Fittings (EMT)
Combination Couplings –EMT to Flex
Set Screw Type –Die Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
TX-210 HBKA033 1/2" –3/8" EA Call
TX-211 HBKA034 1/2" –1/2" EA Call
TX-212 HBKA035 3/4" –3/4" EA Call
Thinwall Conduit Fittings (EMT)
Combination Set Screw Couplings
Die-Cast Zinc Flexible Metal Conduit to EMT
Model No. Hughes No. Conduit Size (In.) Unit List Price
TX-220 HBJY847 3/8" flex to 1/2" EMT EA Call
TX-221 HBJZ024 1/2" flex to 1/2" EMT EA Call
TX-222 HBJZ025 3/4" flex to 3/4" EMT EA Call
TX-223 HBJZ026 1" flex to 1" EMT EA Call
“List Price” refers to manufacturer’s suggested list price.
Prices subject to change without notice.
456-457.qxp 9/5/07 9:01 AM Page 456
Couplings & Adapters CONDUIT FITTINGS
hdsupply.com 457
Conduit
*Listed for use with steel and aluminum EMT, IMC and rigid conduit.
Arlington Industries
EMT Compression Couplings
Zinc die-cast
UL listed concrete tight
Model No. Hughes No. UPC Code Conduit Size (In.) Unit List Price
830 HACY533 00830 1/2 EA Call
831 HACY559 00831 3/4 EA Call
832 HACY571 00832 1 EA Call
833 HACY573 00833 1-1/4 EA Call
834 HACY456 00834 1-1/2 EA Call
835 HACY458 00835 2 EA Call
836* HAKC215 00836 2-1/2 EA Call
837* HAKC308 00837 3 EA Call
838* HBCB559 00838 3-1/2 EA Call
839* HAJK204 00839 4 EA Call
Add suffix "RH"for Robertson Head Screws.
*Concrete tight when taped.
†Listed for use with steel and aluminum EMT, IMC and rigid conduit.
EMT Set-Screw Couplings
Concrete tight. Zinc die-cast
Model No. Hughes No. UPC Code Conduit Size (In.) Diameter (In.) Length (In.) Unit List Price
810 HACY757 00810 1/2 .950 1.560 EA Call
811 HACY762 00811 3/4 1.145 1.869 EA Call
812 HACY781 00812 1 1.435 2.000 EA Call
813 HACY806 00813 1-1/4 1.828 2.500 EA Call
814* HACY589 00814 1-1/2 2.075 2.890 EA Call
815* HACY869 00815 2 2.535 2.567 EA Call
816*†HBCB580 0816 2-1/2 3.280 4.000 EA Call
817*†HBCB581 00817 3 3.910 4.500 EA Call
8175*†HBCB273 08175 3-1/2 4.460 4.814 EA Call
818*†HAZJ361 00818 4 4.984 5.269 EA Call
Combination Coupling
Nonmetallic
For use with nonmetallic liquid-tight conduit, type B, to glue onto PVC
pipe. Produced from UV rated plastic for long outdoor life.
Model No.
Hughes
No.
UPC
Code
Conduit
Size (In.)
Hole
Diameter (In.) Unit List Price
NMLTFM38 HGZN768 54338 3/8 1/2 EA Call
NMLTFM50 HCAA634 54350 1/2 1/2 EA Call
NMLTFM75 HCAA637 54375 3/4 3/4 EA Call
456-457.qxp 9/5/07 9:01 AM Page 457
CONDUIT FITTINGS Couplings & Adapters
458 hdsupply.com
Conduit
*CSA Only.
Arlington Industries
Combination Coupling
EMT Set-Screw To Flex
Zinc die-cast
Model No. Hughes No. UPC Code EMT Size Flex Size Cable Dimensions (in.) Unit List Price
860* HEPP202 00860 1/2 3/8 .530–.620 EA Call
861 HAHJ435 00861 1/2 1/2 .850–.910 EA Call
862 HAZR953 00862 3/4 3/4 1.100–1.130 EA Call
8610 HAEB121 08610 1/2 1/2 .850–.910 EA Call
8620 HBCB180 08620 3/4 3/4 1.100–1.135 EA Call
8630 HAFZ044 08630 1 1 1.255–1.375 EA Call
Combination Coupling
EMT Compression To Flexible Metal Conduit
Zinc die-cast
Model No. Hughes No. UPC Code EMT Size Flex Size Unit List Price
GF860 HCAA824 76860 1/2 3/8 EA Call
GF861 HBAB431 76861 1/2 1/2 EA Call
GF862 HAGJ163 76862 3/4 3/4 EA Call
GF863 HAID843 80173 1 1 EA Call
458-459.qxp 9/5/07 9:02 AM Page 458
Couplings & Adapters CONDUIT FITTINGS
hdsupply.com 459
Conduit
†Indicates items in the shaded area which are UL Listed for Class I, Groups A, B, C and D;
Class II, Groups E, F and G; and Class III.
◊Indicates items in the shaded area which are UL Listed for Class I, Groups B, C and D;
Class II, Groups E, F and G; and Class III.
Appleton®
PLG Close-Up Plugs and BR Reducers:
Explosionproof, Dust-Ignitionproof
Threaded Bell Reducing Couplings
• Class I, Div. 1 and 2
• Groups A†, B◊, C, D
• Class II, Div. 1 and 2 Groups E, F, G
• Class III
• Unilets®for Use with Threaded Metal Conduit
Threadless Rigid Conduit Connectors and Couplings
Compression Couplings–Concrete Tight
Model No. Hughes No. Conduit Size (In.) Unit List Price
NTCC-50 HEGI966 1/2 EA Call
NTCC-75 HEGI967 3/4 EA Call
NTCC-100 HEGI968 1 EA Call
NTCC-125 HEGI969 1-1/4 EA Call
NTCC-150 HEGI970 1-1/2 EA Call
NTCC-200 HEGI971 2 EA Call
NTCC-250 HEGI972 2-1/2 EA Call
NTCC-300 HEGI973 3 EA Call
NTCC-350 HEGI974 3-1/2 EA Call
NTCC-400 HEGI975 4 EA Call
Gland Compression Couplings Type
6000 Series
• Concretetight.
• Steel Body and Nut
• Zinc Plated
• UL Listed E14815
• Listed Concretetight 1⁄2" through 4"
Model No. Hughes No.
Conduit
Size (In.)
Body
Length (in.)
Maximum
Diameter (in.) Unit List Price
6050S HAKO432 1/2 1-3/8 27/32 EA Call
6075S HAKO474 3/4 1-1/2 1-3/8 EA Call
6100S HAKO361 1 1-21/32 1-5/16 EA Call
6125S HAKO588 1-1/4 2-1/2 1-11/16 EA Call
6150S HAKO640 1-1/2 2-1/2 1-15/16 EA Call
6200S HAKO527 2 2-1/2 2-3/8 EA Call
6250S HAKO566 2-1/2 4-1/4 3-1/8 EA Call
6300S HAKO718 3 4-1/2 3-3/4 EA Call
6350S HAKO761 3-1/2 4-3/4 4-1/4 EA Call
6400S HAKO804 4 5 4-3/4 EA Call
Model No. Hughes No. Conduit Size (In.) Unit List Price
Malleable
BR75-50†HEGS105 3/4 EA Call
BR100-50†HEOM979 1 EA Call
BR100-75†HELM952 1 EA Call
BR125-100◊HELM960 1 EA Call
BR125-75◊HEGI402 1-1/4 EA Call
BR150-100◊HEGI403 1-1/2 EA Call
BR150-75◊HELM969 1-1/2 EA Call
BR150-125◊HEGS103 1-1/2 EA Call
BR200-75◊HELM980 2 EA Call
BR200-100◊HEGS420 2 EA Call
BR200-125◊HEON099 2 EA Call
BR200-150◊HEGS104 2 EA Call
BR250-150◊HEGI406 2-1/2 EA Call
BR300-200◊HEON124 3 EA Call
BR350-250◊HEOM984 3-1/2 EA Call
BR400-300◊HEON149 4 EA Call
BR500-400 HEND621 5 EA Call
Aluminum
BR75-50A†HEND594 3/4 EA Call
BR100-50A†HEOM983 1 EA Call
BR100-75A†HELM955 1 EA Call
BR125-100A HEND604 1 EA Call
BR125-75A HEON089 1-1/4 EA Call
BR150-100A HEON095 1-1/2 EA Call
BR150-75A HEND597 1-1/2 EA Call
BR150-125A HEND607 1-1/2 EA Call
BR200-75A HEGS419 2 EA Call
BR200-100A HEND613 2 EA Call
BR200-125A HEGI405 2 EA Call
BR200-150A HEND617 2 EA Call
BR250-150A HEON118 2-1/2 EA Call
BR300-200A HEON136 3 EA Call
BR350-250A HEON144 3-1/2 EA Call
BR400-300A HEON160 4 EA Call
BR500-400A HEND624 5 EA Call
Some products not available at all locations. Check with
your local HD Supply representative for product availability.
458-459.qxp 9/5/07 9:02 AM Page 459
CONDUIT FITTINGS Couplings & Adapters
460 hdsupply.com
Conduit
Appleton®
Set Screw Couplings Type
5000 Series
• Heavy steel walls
• Concretetight when taped
• Pre-set/Pre-staked set screws
• Three-way combination screws
Model No. Hughes No.
Conduit
Size (In.)
Body
Length (in.)
Maximum
Diameter (in.) Unit List Price
5050S HADE863 1/2 1-3/4 27/32 EA Call
5075S HADE931 3/4 2-1/8 1-5/64 EA Call
5100S HADE973 1 2-1/2 1-5/16 EA Call
5125S HADF081 1-1/4 3-1/4 1-11/16 EA Call
5150S HADF133 1-1/2 3-3/4 1-15/16 EA Call
5200S HADF184 2 4 2-3/8 EA Call
5250S HADF043 2-1/2 4-1/4 3-1/8 EA Call
5300S HADF225 3 4-1/2 3-3/4 EA Call
5350S HADF289 3-1/2 4-3/4 4-1/4 EA Call
5400S HADF320 4 5 4-3/4 EA Call
O-Z/Gedney
3-Piece Couplings
Type 4
• Malleable Iron/Zinc Electroplated
• Threaded (NPS) for rigid conduit and IMC
• Couples conduits when conduits can not be turned
• Concrete tight
Model No. Hughes No.
Conduit
Size (In.)
Overall
Length (In.)
Maximum
Diameter (in.) Unit List Price
4-50 HAKY922 1/2 1-3/8 1-7/16 EA Call
4-75 HAKY999 3/4 1-5/8 1-3/4 EA Call
4-100 HAKZ031 1 1-13/16 1-15/16 EA Call
4-125 HAKZ074 1-1/4 2-3/16 2-3/8 EA Call
4-150 HAKZ116 1-1/2 2-5/16 2-5/8 EA Call
4-200 HAKZ158 2 2-7/16 3-3/8 EA Call
4-250 HAKY931 2-1/2 3-3/16 4 EA Call
4-300 HAKZ221 3 3-5/16 4-3/16 EA Call
4-350 HAKZ254 3-1/2 3-1/2 5-1/8 EA Call
4-400 HAKZ291 4 3-3/4 5-1/2 EA Call
4-500 HBMS360 5 3-11/16 6-7/8 EA Call
4-600 HBMS361 6 4-5/16 8-1/4 EA Call
*Not UL Listed
Gland Compression Couplings
Type 30
To couple sections of threadless rigid conduit together.
Malleable Iron/Zinc Electroplated
• Concretetight
Model No. Hughes No.
Conduit
Size (In.)
Length
(In.)
Maximum
Diameter (in.) Unit List Price
30-050 HALA063 1/2 1-11/16 1-3/6 EA Call
30-075 HALA112 3/4 1-3/4 1-9/16 EA Call
30-100 HALA174 1 1-15/16 1-15/16 EA Call
30-125 HALA216 1-1/4 2-1/2 2-5/16 EA Call
30-150 HALA033 1-1/2 2-9/16 2-5/8 EA Call
30-200 HAKZ956 2 2-7/8 3-5/16 EA Call
30-250*HALA383 2-1/2 3-15/16 4-1/32 EA Call
30-300*HALA425 3 4-5/16 4-13/16 EA Call
30-350*HALA474 3-1/2 4-1/2 5-1/2 EA Call
30-400*HALA517 4 4-9/16 6-1/8 EA Call
30-500*HBMS940 5 3-7/8 7-3/8 EA Call
30-600*HBMS941 6 4-1/4 8-9/16 EA Call
460-461.qxp 9/5/07 9:02 AM Page 460
Locknuts & Bushings CONDUIT FITTINGS
hdsupply.com 461
Conduit
Arlington Industries
Die-Cast Locknuts
Cast thread, Zinc die-cast
Model No. Hughes No. UPC Code
Conduit
Size (In.) Unit List Price
DLN1 HAFS807 43510 1/2 EA Call
DLN2 HEHM051 43520 3/4 EA Call
DLN3 HCAA215 43530 1 EA Call
DLN4 HCAA216 43540 1-1/4 EA Call
DLN5 HCAA217 43550 1-1/2 EA Call
DLN6 HCAA218 43560 2 EA Call
DLN7 HCAA428 43570 2-1/2 EA Call
DLN8 HCAA429 43580 3 EA Call
DLN9 HCAA430 43590 3-1/2 EA Call
DLN10 HCAA214 43511 4 EA Call
Conduit Locknuts
Plated steel
Model No. Hughes No. UPC Code
Conduit
Size (In.) Unit List Price
401 HBBH214 00401 1/2 EA Call
402 HAKL765 00402 3/4 EA Call
403 HAKL804 00403 1 EA Call
404 HAKL826 00404 1-1/4 EA Call
405 HAKL906 00405 1-1/2 EA Call
406 HAKL988 00406 2 EA Call
407 HAKM041 00407 2-1/2 EA Call
408 HAKM071 00408 3 EA Call
409 HAKM123 00409 3-1/2 EA Call
410 HAKL945 00410 4 EA Call
411 HBBP174 00411 5 EA Call
412 HBZZ442 00412 6 EA Call
Snap-In Bushings
All plastic
Model No. Hughes No. UPC Code
Conduit
Size (In.) Unit List Price
4400 HAHU816 04400 1/2 EA Call
4401 HBBN374 04401 3/4 EA Call
4402 HACU801 04402 1 EA Call
4403 HALB962 04403 1-1/4 EA Call
4404 HAKS063 04404 1-1/2 EA Call
4405 HAHH997 04405 2 EA Call
4406 HATJ663 04409 2-1/2 EA Call
Plastic Insulating Bushings
105°C rated
Model No. Hughes No. UPC Code
Conduit
Size (In.) Unit List Price
440 HAXI701 00440 1/2 EA Call
441 HAXI703 00441 3/4 EA Call
442 HAXI706 00442 1 EA Call
443 HAXI710 00443 1-1/4 EA Call
444 HAXI713 00444 1-1/2 EA Call
445 HAXI715 00445 2 EA Call
446 HAXI718 00446 2-1/2 EA Call
447 HAXI719 00447 3 EA Call
448 HAXI723 00448 3-1/2 EA Call
449 HAXI725 00449 4 EA Call
4491 HADW374 04491 5 EA Call
4492 HBZZ725 04492 6 EA Call
460-461.qxp 9/5/07 9:02 AM Page 461
CONDUIT FITTINGS Locknuts & Bushings
462 hdsupply.com
Conduit
*Can also be used for rigid, IMC, and PVC rigid conduit.
Arlington Industries
Insulating Bushings
Press fit
Holds firmly in place while pulling cables.
Arlington's EMT Insulating Bushings protect cables from abrasion by
EMT. Examples: Power, Cable TV, computer datalines, telephone/modem,
audio/video cables, alarm systems, security systems. EMT is often used
to protect cables where damage could occur in a house or building.
Model No. Hughes No. UPC Code Conduit Size (In.) Width (In.) Diameter (In.) Unit List Price
EMT50 HAHM256 12200 1/2 .531 .840 EA Call
EMT75 HAHM270 12205 3/4 .531 1.056 EA Call
EMT100 HAJM419 12220 1 .625 1.280 EA Call
EMT125 HAJM512 12225 1-1/4 .625 1.660 EA Call
EMT150 HAJM611 12230 1-1/2 .625 1.915 EA Call
EMT200 HAYD432 12235 2 .625 2.377 EA Call
EMT250* HAZS445 12240 2-1/2 1.225 3.062 EA Call
EMT300* HAJM795 12245 3 1.225 3.690 EA Call
EMT350* HAJV226 12250 3-1/2 1.231 4.187 EA Call
EMT400* HACZ080 12255 4 1.233 4.815 EA Call
Anti-Short Bushings
Plastic
Model No. Hughes No. UPC Code Conduit Size (In.) Cable Size Depth (In.) Diameter (In.) Unit List Price
AS0 HAKA115 10500 5/16" 14/2, 14/3, 12/2 .590 .680 EA Call
AS1 HAKA391 10510 3/8" 14/4, 12/3, 6/1, 4/1 .630 .758 EA Call
AS2 HBZZ933 10520 7/16" 12/4, 10/2, 10/3, 2/1 .680 .920 EA Call
AS3 HAIN031 10530 1/2" 10/4, 8/2, 8/3, 1/1 .770 1.130 EA Call
AS4 HAWP099 10540 3/4" 8/4, 6/2, 6/3, 6/4, 4/2, 4/3 .880 1.340 EA Call
AS5 HBZZ744 06052 1" 3-1, 2-1, 2-1/10, 1-300MCM,
1-350MCM, 1-400MCM,
1-450MCM, 1-500MCM
1.038 1.460 EA Call
AS6 HAKW854 06054 1-1/4" 4-1, 4-1/10, 4-2/0, 3-1/0, 3-2/0,
3-3/0, 2-2/0, 2-3/0, 2-4/0, 1-600MCM,
1-650MCM, 1-700MCM, 1-750MCM,
1-800MCM, 1-900MCM
1.100 1.720 EA Call
AS7 HAHO176 06056 1-1/2" 4-3/0, 4-4/0, 3-4/0, 3-250MCM,
3-300MCM, 2-250MCM, 2-300MCM,
2-350MCM, 1-1000MCM
1.162 2.175 EA Call
AS8 HBZZ745 06058 2 to 2-1/2" 4-250MCM, 4-300MCM, 4-350MCM,
4-400MCM, 4-450MCM, 4-500MCM,
3-350MCM, 3-400MCM, 3-450MCM,
3-500MCM, 2-400MCM, 2-450MCM,
2-500MCM
1.330 2.625 EA Call
462-463.qxp 9/5/07 9:02 AM Page 462
Rigid/Intermediate
Grade Conduit Fittings
Thin Construction Locknuts
Steel/Zinc Plated
Rigid/Intermediate
Grade Conduit Fittings
Sealing Locknuts
Steel/Zinc Plated
Locknuts & Bushings CONDUIT FITTINGS
hdsupply.com 463
Conduit
Steel City®- T&B
Rigid/Intermediate Grade Conduit Fittings
Locknuts
Steel/Zinc Plated
Rigid/Intermediate
Grade Conduit Fittings
Locknuts
Die Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
LN-201 HBJY763 1/2" EA Call
LN-202 HBJY764 3/4" EA Call
LN-203 HBJY765 1" EA Call
LN-204 HBJY766 1-1/4" EA Call
LN-205 HBJY767 1-1/2" EA Call
LN-206 HBJY768 2" EA Call
LN-207 HBJY769 2-1/2" EA Call
LN-208 HBJY770 3" EA Call
LN-209 HBJY771 3-1/2" EA Call
LN-210 HBJY772 4" EA Call
Model No. Hughes No. Conduit Size (In.) Unit List Price
LS-101 HBJY757 1/2" EA Call
LS-102 HBJY758 3/4" EA Call
LS-103 HBJY759 1" EA Call
LS-104 HBJY760 1-1/4" EA Call
LS-105 HBJY761 1-1/2" EA Call
LS-106 HBJY762 2" EA Call
LS-107 HBJZ981 2-1/2" EA Call
LS-108 HBJZ982 3" EA Call
LS-109 HBJZ983 3-1/2" EA Call
LS-110 HBJZ984 4" EA Call
Rigid/Intermediate
Grade Conduit Fittings
Insulated Grounding Bushings
Malleable Iron/Zinc Plated
Model No. Hughes No. Conduit Size (In.) Unit List Price
BG-801 HBJY245 1/2" EA Call
BG-802 HBJY535 3/4" EA Call
BG-803 HBJY536 1" EA Call
BG-804 HBJY546 1-1/4" EA Call
BG-805 HBJY547 1-1/2" EA Call
BG-806 HBJY548 2" EA Call
BG-807 HBJY549 2-1/2" EA Call
BG-808 HBJY550 3" EA Call
BG-809 HBJY551 3-1/2" EA Call
BG-810 HBJY552 4" EA Call
Rigid/Intermediate
Grade Conduit Fittings
Grounding Bushings Die Cast Zinc
Insulated Metallic With Aluminum Lay in Type Lug
• 105°C Thermoplastic liners.
• Heavy reinforced ribs.
Model No. Hughes No. Conduit Size (In.) Unit List Price
BG-201 HBJZ913 1/2" EA Call
BG-202 HBJZ914 3/4" EA Call
BG-203 HBJZ915 1" EA Call
BG-204 HBJZ916 1-1/4" EA Call
BG-205 HBJZ918 1-1/2" EA Call
BG-206 HBJZ920 2" EA Call
BG-207 HBJZ922 2-1/2" EA Call
BG-208 HBJZ924 3" EA Call
BG-209 HBJZ926 3-1/2" EA Call
BG-210 HBJZ928 4" EA Call
Model No. Hughes No. Conduit Size (In.) Unit List Price
LN-101-SC HBJY774 1/2" EA Call
LN-102 HALB952 3/4" EA Call
LN-103 HBJY775 1" EA Call
LN-104 HBJY776 1-1/4" EA Call
LN-105 HBJY777 1-1/2" EA Call
LN-106 HBJY778 2" EA Call
LN-107 HBJY707 2-1/2" EA Call
LN-108 HEHX996 3" EA Call
LN-109 HBJY708 3-1/2" EA Call
LN-110 HBJY709 4" EA Call
Model No. Hughes No. Conduit Size (In.) Unit List Price
SPLN-107 HBJY289 2-1/2" EA Call
SPLN-108 HBJY292 3" EA Call
SPLN-109 HBJY294 3-1/2" EA Call
SPLN-110 HBJY290 4" EA Call
462-463.qxp 9/5/07 9:02 AM Page 463
CONDUIT FITTINGS Locknuts & Bushings
464 hdsupply.com
Conduit
Steel City®- T&B
Rigid/Intermediate Grade Conduit Fittings
Grounding Bushings, Die-Cast Zinc
Insulated metallic with aluminium lug
Model No. Hughes No. Conduit Size (In.) Unit List Price
BG-801A HBJZ930 1/2" EA Call
BG-802A HBJZ931 3/4" EA Call
BG-803A HBJZ932 1" EA Call
BG-804A HBJZ933 1-1/4" EA Call
BG-805A HBJZ934 1-1/2" EA Call
BG-806A HBJZ935 2" EA Call
BG-807A HBJZ936 2-1/2" EA Call
BG-808A HBJZ937 3" EA Call
BG-809A HBJZ938 3-1/2" EA Call
BG-810A HBJZ939 4" EA Call
Image Missing
IG ID: 19138
Date: 09/28/2005
Rigid/Intermediate Grade Conduit Fittings
Insulated Bushings
• Thermoplastic
• Rated 105°C
Model No. Hughes No. Conduit Size (In.) Unit List Price
BU-501 HAKM265 1/2" EA Call
BU-502 HAKM329 3/4" EA Call
BU-503 HAKM359 1" EA Call
BU-504 HAKM422 1-1/4" EA Call
BU-505 HAKM466 1-1/2" EA Call
BU-506 HAKM550 2" EA Call
BU-507 HAKM603 2-1/2" EA Call
BU-508 HAKM634 3" EA Call
BU-509 HAKM538 3-1/2" EA Call
BU-510 HAKM753 4" EA Call
BU-511 HBJY588 5" EA Call
BU-512 HAFZ360 6" EA Call
Appleton®
Grounding Bushings
Threaded Rigid Conduit and IMC
• Insulated
• 150°C Temperature Rating with Solderless Lugs
• Malleable Iron
• WIre Range: 14 sol - 2/0 str.
Model No. Hughes No. Conduit Size (In.) Unit List Price
GIB-50L-10 HEGI940 1/2" EA Call
GIB-75L-10 HEGI941 3/4" EA Call
GIB-100L-10 HEGI942 1" EA Call
GIB-125L-10 HEGI912 1-1/4" EA Call
GIB-150L-10 HEGI914 1-1/2" EA Call
GIB-200L-10 HEGI916 2" EA Call
GIB-250L-10 HEGI917 2-1/2" EA Call
GIB-300L-10 HEGI919 3" EA Call
GIB-350L-10 HEGI921 3-1/2" EA Call
GIB-400L-10 HEGI923 4" EA Call
GIB-500L-10 HEOT423 5" EA Call
GIB-600L-10 HEOT436 6" EA Call
See page 613 for Flex Splitter®
Flexible Metal Conduit Cutter
464-465.qxp 9/5/07 9:03 AM Page 464
Reducers CONDUIT FITTINGS
hdsupply.com 465
Conduit
Cantex
Reducers
Carlon®
Fabricated Reducers
Rigid Nonmetallic Conduit
Model No. Hughes No. Size (In.)
Standard
Carton
Quantity
Standard
Carton
Weight (lbs.) Unit List Price
E952KJ HDUY752 2-1/2" x 2" 48 28 EA Call
E952LJ HECO639 3" x 2" 36 21 EA Call
E952LK HECO640 3" x 2-1/2" 36 31 EA Call
E952NL HECO641 4" x 3" 15 23 EA Call
E952NM HFPE086 4" x 3-1/2" 15 25 EA Call
E952PN HECO642 5" x 4" 12 26 EA Call
E952RP HEDM892 6" x 5" 10 31 EA Call
Carlon®
Reducer Bushings
Rigid Nonmetallic Conduit
For connecting different sizes of conduit, Bell x Spigot.
UL Listed
*Not UL listed.
Model No. Hughes No. Size (In.) Standard Carton Quantity Dimension L (In.) Dimension A (In.) Dimension C (In.) Unit List Price
E950ED HECN678 3/4" x 1/2" 100 1-5/32 13/64 1-1/32 EA Call
E950FD-CAR HECO621 1" x 1/2" 25 1-11/32 3/16 57/64 EA Call
E950FE HECN749 1" x 3/4" 100 1-11/32 3/16 1-1/64 EA Call
E950GE-CAR HECO622 1-1/4" x 3/4" 10 1-15/32 3/16 1-1/64 EA Call
E950GF HECN751 1-1/4" x 1" 50 1-15/32 3/16 1-9/64 EA Call
E950HF-CAR HCIZ697 1-1/2" x 1" 10 1-19/32 3/16 1-9/64 EA Call
E950HG-CAR HECN752 1-1/2" x 1-1/4" 10 1-19/32 3/16 1-17/64 EA Call
E950JG-CAR HDUA974 2" x 1-1/4" 10 1-3/4 7/32 1-17/64 EA Call
E950JH-CAR HDVV087 2" x 1-1/2" 10 1-3/4 7/32 1-25/64 EA Call
E950KJ-CAR HECO624 2-1/2" x 2" 10 2-5/32 3/8 1-27/64 EA Call
E950LJ-CAR HDVU869 3" x 2" 10 2-1/8 1/4 1-7/8 EA Call
E950LK*HECJ467 3" x 2-1/2" 25 1-15/16 1/4 1-11/16 EA Call
E950NL HDVT649 4" x 3" 25 2-3/4 5/16 1-15/16 EA Call
Model No. Hughes No.
Conduit
Size (In.)
Package
Qty. Unit List Price
5142220 HBYX578 3/4" x 1/2" 100 Pack Call
5142221 HBYX579 1" x 3/4" 100 Pack Call
5142222 HBYX589 1-1/4" x 1" 50 Pack Call
5142223 HBYX590 1-1/2" x 1-1/4" 50 Pack Call
5142224 HBYX591 2" x 1-1/2" 25 Pack Call
5142225 HBYX592 2-1/2" x 2" 25 Pack Call
5142226 HBYX476 3" x 2-1/2" 25 Pack Call
5142227 HBYX288 4" x 3" 20 Pack Call
5142229 HBYX289 4" x 3-1/2" 20 Pack Call
464-465.qxp 9/5/07 9:03 AM Page 465
CONDUIT FITTINGS Reducers
466 hdsupply.com
Conduit
Carlon®
Reducer Plugs
Rigid Nonmetallic Conduit
Standards: cUL listed.
Model No. Hughes No. Size (In.)
Standard
Carton
Quantity
Standard
Carton
Weight (lbs.) Unit List Price
E971C HHBS340 3/4" x 1/2" 100 2 EA Call
E971D HECO626 1" x 3/4" 100 3 EA Call
Steel City®- T&B
Rigid/Intermediate Grade Conduit Fittings
Reducing Bushings
Model No. Hughes No. Conduit Size (In.) Unit List Price
RB-121 HBJY879 3/4"–1/2" EA Call
RB-131 HBJY880 1"–1/2" EA Call
RB-132 HBJY881 1"–3/4" EA Call
RB-141 HBJY882 1-1/4"–1/2" EA Call
RB-142 HBJY883 1-1/4"–3/4" EA Call
RB-143 HBJY884 1-1/4"–1" EA Call
RB-151 HBJY885 1-1/2"–1/2" EA Call
RB-152 HBJY886 1-1/2"–3/4" EA Call
RB-153 HBJY887 1-1/2"–1" EA Call
RB-154 HBJY888 1-1/2"–1-1/4" EA Call
RB-161 HBJY889 2"–1/2" EA Call
RB-162 HBJY890 2"–3/4" EA Call
RB-163 HBJY891 2"–1" EA Call
RB-164 HBJY892 2"–1-1/4" EA Call
RB-165 HBJY893 2"–1-1/2" EA Call
RB-175 HBJY894 2-1/2"–1-1/2" EA Call
RB-176 HBJY895 2-1/2"–2" EA Call
RB-186 HBJY896 3"–2" EA Call
RB-187 HBJY897 3"–2-1/2" EA Call
Rigid/Intermediate Grade Conduit Fittings
Reducing Washers
Steel/Zinc Plated
Model No. Hughes No. Conduit Size (In.) Unit List Price
WA-110 HBJY920 1/2"–3/8" EA Call
WA-121 HAKQ941 3/4"–1/2" EA Call
WA-131 HAKR123 1"–1/2" EA Call
WA-132 HAKR136 1"–3/4" EA Call
WA-141 HAKR241 1-1/4"–1/2" EA Call
WA-142 HAKR295 1-1/4"–3/4" EA Call
WA-143 HAKR320 1-1/4"–1" EA Call
WA-151 HAKR396 1-1/2"–1/2" EA Call
WA-152 HAIL462 1-1/2"–3/4" EA Call
WA-153 HAKR170 1-1/2"–1" EA Call
WA-154 HAKR519 1-1/2"–1-1/4" EA Call
WA-161 HAXN680 2"–1/2" EA Call
WA-162 HAWN700 2"–3/4" EA Call
WA-163 HAIL491 2"–1" EA Call
WA-164 HAKR620 2"–1-1/4" EA Call
WA-165 HAKR661 2"–1-1/2" EA Call
WA-171 HBJY921 2-1/2"–1/2" EA Call
WA-172 HEHM145 2-1/2"–3/4" EA Call
WA-173 HBJZ028 2-1/2"–1" EA Call
WA-174 HBJZ029 2-1/2"–1-1/4" EA Call
WA-175 HBJZ030 2-1/2"–1-1/2" EA Call
WA-176 HAKR988 2-1/2"–2" EA Call
WA-181 HBJZ031 3"–1/2" EA Call
WA-182 HBJZ032 3"–3/4" EA Call
WA-183 HBJZ033 3"–1" EA Call
WA-184 HBJZ034 3"–1-1/4" EA Call
WA-185 HBJZ035 3"–1-1/2" EA Call
WA-186 HAKS201 3"–2" EA Call
WA-187 HAXN913 3"–2-1/2" EA Call
466-467.qxp 9/5/07 9:03 AM Page 466
Reducers CONDUIT FITTINGS
hdsupply.com 467
Conduit
Arlington Industries
Reducing Washers
Plated steel
A bonding jumper is recommended when using reducing washers to
provide a reliable grounding/bonding path.
Model No. Hughes No. UPC Code Size (In.) Unit List Price
RW1 HAII321 95100 3/4 x 1/2 EA Call
RW2 HAII428 95200 1 x 1/2 EA Call
RW3 HAII621 95300 1 x 3/4 EA Call
RW4 HAII714 95400 1-1/4 x 1/2 EA Call
RW5 HAII554 95500 1-1/4 x 3/4 EA Call
RW6 HAII510 95600 1-1/4 x 1 EA Call
RW7 HAII512 95700 1-1/2 x 1/2 EA Call
RW8 HAII829 95800 1-1/2 x 3/4 EA Call
RW9 HAII924 95900 1-1/2 x 1 EA Call
RW10 HAIJ015 95101 1-1/2 x 1-1/4 EA Call
RW11 HAII613 95110 2 x 1/2 EA Call
RW12 HAIJ132 95120 2 x 3/4 EA Call
RW13 HAIJ235 95130 2 x 1 EA Call
RW14 HAIJ349 95140 2 x 1-1/4 EA Call
RW15 HAIJ453 95150 2 x 1-1/2 EA Call
RW16 HCAB331 95160 2-1/2 x 1/2 EA Call
RW17 HCAB332 95170 2-1/2 x 3/4 EA Call
RW18 HCAB333 95180 2-1/2 x 1 EA Call
RW19 HAKR902 95190 2-1/2 x 1-1/4 EA Call
RW20 HAKR945 95201 2-1/2 x 1-1/2 EA Call
RW21 HAIJ607 95210 2-1/2 x 2 EA Call
RW22 HCAB334 95220 3 x 1/2 EA Call
RW23 HCAB335 95230 3 x 3/4 EA Call
RW24 HCAB336 95240 3 x 1 EA Call
RW25 HAIJ720 95250 3 x 1-1/4 EA Call
RW26 HAIB672 95260 3 x 1-1/2 EA Call
RW27 HAIJ823 95270 3 x 2 EA Call
RW28 HAKS233 95280 3 x 2-1/2 EA Call
RW29 HCAB337 95290 3-1/2 x 1/2 EA Call
RW30 HCAB338 95301 3-1/2 x 3/4 EA Call
RW31 HCAB339 95310 3-1/2 x 1 EA Call
RW32 HCAB340 95320 3-1/2 x 1-1/4 EA Call
RW33 HCAB341 95330 3-1/2 x 1-1/2 EA Call
RW34 HCAB342 95340 3-1/2 x 2 EA Call
RW35 HCAB343 95350 3-1/2 x 2-1/2 EA Call
RW36 HAGG571 95360 3-1/2 x 3 EA Call
RW37 HCAB344 95370 4 x 1/2 EA Call
RW38 HCAB345 95380 4 x 3/4 EA Call
RW39 HCAB346 95390 4 x 1 EA Call
RW40 HCAB347 95401 4 x 1-1/4 EA Call
RW41 HCAB348 95410 4 x 1-1/2 EA Call
RW42 HAGH590 95420 4 x 2 EA Call
RW43 HAIO968 95430 4 x 2-1/2 EA Call
RW44 HAHL796 95440 4 x 3 EA Call
RW45 HCAB349 95450 4 x 3-1/2 EA Call
*UL Recognized.
◊Suitable for Class I, Group A in addition to Class I Groups B, C, D; Class II, Groups E, F, G; and
Class III.
†Class I, Groups C, D; Class II, Groups E, F, G; Class III.
Appleton®
Reducers
Threaded Rigid Conduit and IMC
Model No. Hughes No.
Conduit
Size (In.)
Weight per
100 (lbs.) Unit List Price
Steel
RB50-13*◊HEOL100 1/2 –1/8 1.5 EA Call
RB50-25*◊HEGS546 1/2 –1/4 2.0 EA Call
RB50-38*◊HEGI706 1/2 –3/8 2.7 EA Call
RB75-50◊HEIS766 3/4 –1/2 6.0 EA Call
RB100-50◊HEGI707 1 –1/2 13.8 EA Call
RB100-75◊HEFO190 1 –3/4 8.0 EA Call
RB125-50 HEGI708 1-1/4 –1/2 29.0 EA Call
RB125-75 HEGI709 1-1/4 –3/4 23.0 EA Call
RB125-100 HEFO188 1-1/4 –1 17.0 EA Call
RB150-50 HEGI711 1-1/2 –1/2 39.0 EA Call
RB150-75 HEFW972 1-1/2 –3/4 35.0 EA Call
RB150-100 HEGI712 1-1/2 –1 31.0 EA Call
RB150-125 HEGI713 1-1/2 –1-1/4 16.5 EA Call
RB200-50 HEGI997 2 –1/2 68.0 EA Call
RB200-75 HEGI998 2 –3/4 64.0 EA Call
RB200-100 HEGI999 2 –1 57.0 EA Call
RB200-125 HEGJ000 2 –1-1/4 45.0 EA Call
RB200-150 HEGJ001 2 –1-1/2 38.0 EA Call
Malleable Iron
RB250-100 HEGS113 2-1/2 –1 75.0 EA Call
RB250-125 HEGS114 2-1/2 –1-1/2 78.0 EA Call
RB250-150 HEGJ002 2-1/2 –1-1/2 82.0 EA Call
RB250-200 HEGJ003 2-1/2 –2 56.0 EA Call
RB300-100 HEGS115 3 –1 130.0 EA Call
RB300-125 HELN194 3 –1-1/2 135.0 EA Call
RB300-150 HEGJ004 3 –1-1/2 142.0 EA Call
RB300-200 HEGJ005 3 –2 126.0 EA Call
RB300-250 HEGJ006 3 –2-1/2 83.0 EA Call
RB350-200 HEGS548 3-1/2 –2 155.0 EA Call
RB350-250 HEGJ007 3-1/2 –2-1/2 164.0 EA Call
RB350-300 HEGJ008 3-1/2 –3 92.0 EA Call
RB400-200 HEGS550 4 –2 165.0 EA Call
RB400-250 HEGJ009 4 –2-1/2 245.0 EA Call
RB400-300 HEGZ420 4 –3 174.0 EA Call
RB400-350 HEGJ010 4 –3-1/2 106.0 EA Call
RB500-350†HEOL146 5 –3-1/2 180.0 EA Call
RB500-400†HEFX664 5 –4 190.0 EA Call
RB600-400†HEGS551 6 –4 192.0 EA Call
RB600-500†HEGS552 6 –5 195.0 EA Call
466-467.qxp 9/5/07 9:03 AM Page 467
CONDUIT FITTINGS Reducers
468 hdsupply.com
Conduit
*UL Recognized.
◊Suitable for Class I, Group A in addition to Class I Groups B, C, D; Class II, Groups E, F, G; and
Class III.
†Class I, Groups C,D; Class II, Groups E,F,G; Class III.
Appleton®
Reducers
Threaded Rigid Conduit and IMC
Class I, Groups A◊,B,C,D
Class II, Groups E,F,G
Class III
Model No. Hughes No. Conduit Size (In.) Unit List Price
RB50-13A*◊HEOL104 1/2 —1/8 EA Call
RB50-25A*◊HEOL114 1/2 —1/4 EA Call
RB75-50A◊HEFY996 3/4 —1/2 EA Call
RB100-50A◊HEGI409 1 —1/2 EA Call
RB100-75A◊HEFT094 1 —3/4 EA Call
RB125-50A HEGI410 1-1/4 —1/2 EA Call
RB125-75A HEGI411 1-1/4 —3/4 EA Call
RB125-100A HEGI710 1-1/4 —1 EA Call
RB150-50A HEGI412 1-1/2 —1/2 EA Call
RB150-75A HEGI413 1-1/2 —3/4 EA Call
RB150-100A HEFT080 1-1/2 —1 EA Call
RB150-125A HEGI996 1-1/2 —1-1/4 EA Call
RB200-50A HEGI427 2 —1/2 EA Call
RB200-75A HEGI428 2 —3/4 EA Call
RB200-100A HEFS918 2 —1 EA Call
RB200-125A HEGI429 2 —1/4 EA Call
RB200-150A HEFT086 2 —1-1/2 EA Call
RB250-100A HELN173 2-1/2 —1 EA Call
RB250-125A HEOL126 2-1/2 —1-1/4 EA Call
RB250-150A HEFT076 2-1/2 —1-1/2 EA Call
RB250-200A HEFT075 2-1/2 —2 EA Call
RB300-100A HEOY008 3 —1 EA Call
RB300-125A HEOK908 3 —1-1/4 EA Call
RB300-150A HEGS547 3 —1-1/2 EA Call
RB300-200A HEGI319 3 —2 EA Call
RB300-250A HEOL831 3 —2-1/2 EA Call
RB350-200A HEGS549 3 —2 EA Call
RB350-250A HEFT079 3-1/2 —2-1/2 EA Call
RB350-300A HEGI320 3-1/2 —3 EA Call
RB400-200A HEOY011 4 —2 EA Call
RB400-250A HEOL142 4 —2-1/2 EA Call
RB400-300A HEOL747 4 —3 EA Call
RB400-350A HEOL835 4 —3-1/2 EA Call
RB500-350A†HEOL150 5 —3-1/2 EA Call
RB500-400A†HEOL163 5 —4 EA Call
RB600-400A†HEOL174 6 —4 EA Call
RB600-500A†HEGS553 6 —5 EA Call
468-469.qxp 9/5/07 9:04 AM Page 468
Nipples CONDUIT FITTINGS
hdsupply.com 469
Conduit
Steel City®- T&B
Rigid/Intermediate Grade Conduit Fittings
Conduit Nipples
Die Cast Zinc –Noninsulated
Model No. Hughes No. Conduit Size (In.) Unit List Price
HA-201 HBJY606 1/2" EA Call
HA-202 HBJY607 3/4" EA Call
HA-203 HBJY608 1" EA Call
HA-204 HBJY609 1-1/4" EA Call
HA-205 HBJY610 1/2" EA Call
HA-206 HBJY611 2" EA Call
HA-207 HBJY284 2-1/2" EA Call
HA-208 HEHL669 3" EA Call
HA-209 HBJY615 3-1/2" EA Call
HA-210 HBJY616 4" EA Call
Arlington Industries
Conduit Nipples
Zinc die-cast
Model No. Hughes No. UPC Code
Conduit
Size (In.) Unit List Price
501 HAXI693 00501 1/2 EA Call
502 HAXI695 00502 3/4 EA Call
503 HAXI698 00503 1 EA Call
504 HAGY313 00504 1-1/4 EA Call
505 HAGY761 00505 1-1/2 EA Call
506 HAXI700 00506 2 EA Call
507 HAHA081 00507 2-1/2 EA Call
508 HAGZ678 00508 3 EA Call
509 HAHA182 00509 3-1/2 EA Call
510 HAWH004 00510 4 EA Call
Steel City®- T&B
Rigid/Intermediate Grade
Conduit Fittings
Offset Nipples
Die Cast Zinc
Model No. Hughes No. Conduit Size (In.) Unit List Price
HO-221 HBJY699 1/2" EA Call
HO-222 HBJY700 3/4" EA Call
HO-223 HBJY701 1" EA Call
HO-224 HBJY702 1-1/4" EA Call
HO-225 HBJY703 1-1/2" EA Call
HO-226 HBJY541 2" EA Call
*Not CSA Certified
O-Z/Gedney
Bushed Conduit Nipples
Type 7
Use through knockout to connect box to conduit coupling, with a lock-
nut to connect two boxes side by side or back to back or with a locknut
to connect fixture housings in continuous runs.
Malleable Iron/Zinc Electroplated
• With rigid conduit threads (NPS)
Model No. Hughes No.
Conduit
Size (In.)
Maximum
Diameter (in.)
Thread
Length (In.) Unit List Price
Uninsulated
7-38 HEPN493 3/8 7/8 1/2 EA Call
7-50 HEGW450 1/2 1-1/8 1/2 EA Call
7-75 HEGW452 3/4 1-1/4 5/8 EA Call
7-100 HEGW454 1 1-3/4 5/8 EA Call
7-125 HEGW459 1-1/4 2-1/8 7/8 EA Call
7-150 HEGW462 1-1/2 2-1/2 1 EA Call
7-200 HEGW465 2 3 1-1/8 EA Call
7-250 HEGW468 2-1/2 3-5/8 1-1/4 EA Call
7-300 HEGW471 3 4-1/2 1-1/4 EA Call
7-350 HEGW472 3-1/2 5-1/8 1-3/8 EA Call
7-400* HEGW473 4 5-1/4 1-1/4 EA Call
7-500* HEGY467 5 6-3/8 1-1/4 EA Call
Insulated Throat
7-50T HAFY091 1/2 1-1/8 1/2 EA Call
7-75T HAFY092 3/4 1-1/4 5/8 EA Call
7-100T HAFY093 1 1-3/4 5/8 EA Call
7-125T HAFY094 1-1/4 2-1/8 7/8 EA Call
7-150T HAFX805 1-1/2 2-1/2 1 EA Call
7-200T HAFX806 2 3 1-1/8 EA Call
7-250T HAFX807 2-1/2 3-5/8 1-1/4 EA Call
7-300T HAFY095 3 4-1/2 1-1/4 EA Call
7-350T HAFY096 3-1/2 5-1/8 1-3/8 EA Call
7-400T* HAFY097 4 5-1/4 1-1/4 EA Call
7-500T* HAFY098 5 6-3/8 1-1/4 EA Call
468-469.qxp 9/5/07 9:04 AM Page 469
CONDUIT FITTINGS Entrance Caps
470 hdsupply.com
Conduit
Carlon®
Service Entrance Caps
Rigid Nonmetallic Conduit
Standards: UL listed.
Arlington Industries
Service Entrance Cable Caps
Zinc die-cast
Model No. Hughes No.
UPC
Code
Wire
Size
Hole
Size (In.) Unit List Price
660 HAFW330 00660 3/8 to 3/1 (2).58 EA Call
662 HAFW439 00662 1/0 to 4/0 (2).80 EA Call
PVC Entrance Caps
With galvanized steel strap
Model No. Hughes No.
UPC
Code Wire Size
Hole
Size (In.) Unit List Price
PVC660 HAWR662 73660 (3) 3, 6, 4, 2 (2).53 EA Call
PVC662 HAHI809 73662 (3) 1/0
to (3) 4/0
(2).69 EA Call
Entrance Caps
PVC
• For rigid, IMC, PVC, EMT.
• EMT adapter sleeve included.
Model No. Hughes No. UPC Code Conduit Size (In.) Unit List Price
PVC102 HCAA752 73102 1 EA Call
PVC103 HCAA753 73103 1-1/4 EA Call
PVC104 HCAA754 73104 1-1/2 EA Call
PVC105 HAHN402 73105 2 EA Call
Entrance Caps
Clamp-On Type
For rigid, IMC, EMT
Model No. Hughes No.
UPC
Code
Conduit
Size (In.) Hole Size (In.) Unit List Price
142 HADE036 00142 1 (2).44 (3).50 EA Call
143 HADE132 00143 1-1/4 (2).42 (3).63 EA Call
144 HADE137 00144 1-1/2 (2).60 (3).75 EA Call
145 HADE204 00145 2 (2).75 (3)1.00
(1).53
EA Call
146 HADE245 00146 2-1/2 (3)1.31 (3).87
(1).99
EA Call
147 HADE288 00147 3 (3)1.31 (3).87
(1).99
EA Call
148 HADE341 00148 3-1/2 (3)1.73 (4)1.10 EA Call
“List Price” refers to manufacturer’s suggested list price.
Prices subject to change without notice.
Model No. Hughes No.
Size
(In.)
Standard
Carton Quantity Unit List Price
E998D HHBS119 1/2 5 EA Call
E998E HEHD816 3/4 20 EA Call
E998F-CAR HEIN730 1 5 EA Call
E998G-CAR HEIN740 1-1/4 5 EA Call
E998H-CAR HEIN744 1-1/2 5 EA Call
E998J HEIN745 2 5 EA Call
E998K-UPC HEIN696 2-1/2 2 EA Call
E998L HEIN752 3 2 EA Call
470-471.qxp 9/5/07 9:04 AM Page 470
Flashings CONDUIT FITTINGS
hdsupply.com 471
Conduit
Arlington Industries
Roof Flashing
Model No. Hughes No. UPC Code Copper and Aluminum Cable All Types (In.) Width (In.) Length (In.) Unit List Price
Galvanized steel with neoprene seal
625 HBZZ519 00625 2 10.750 14.500 EA Call
626 HBZZ520 00626 2-1/2 10.750 14.500 EA Call
All neoprene
635 HAFW743 00635 2 9.000 11.500 EA Call
636 HBZZ522 00636 2-1/2 9.000 11.500 EA Call
637 HAFX817 00637 3 10.000 13.500 EA Call
639 HBZZ523 00639 4 11.500 14.000 EA Call
Appleton®
Flashings
Type NC
No Caulk Galvanized
These are used to provide a watertight connection between the roof line
and ventilation pipes.
Model No. Hughes No. Conduit Size (In.) Width (In.) Length (In.) Unit List Price
NC-1069 HENC667 1-1/4 –1-1/2 8.75 12.50 EA Call
NC-1070 HENC675 2 8.88 12.50 EA Call
NC-1071 HENC679 2-1/2 –3-1/2 10.75 14.50 EA Call
See pages 346-347
for Armored Cable
470-471.qxp 9/5/07 9:04 AM Page 471
CONDUIT FITTINGS Seals
472 hdsupply.com
Conduit
*U.L. Listed for use with Appleton "Kwiko®A"and Crouse-Hinds "Chico®A"cement.
◊Indicated items in the shaded area which are suitable for Class I, Groups A, B, C, and D;
Class II, Groups E, F, G; and Class III.
†Turning radius with cover or plug removed.
Appleton®
EYS Vertical Conduit Seals
Malleable Iron*
Model No. Hughes No.
Conduit
Size (In.)
Turning
Radius (in)†Unit List Price
Female
EYSF-50◊HEGA999 1/2 1.81 EA Call
EYSF-75◊HEGB005 3/4 2.25 EA Call
EYSF-100◊HEGB010 1 2.38 EA Call
EYSF-125 HAHP244 1-1/4 2.94 EA Call
EYSF-150 HAHQ240 1-1/2 3.50 EA Call
EYSF-200 HGLI681 2 4.13 EA Call
EYSF-250 HBLG974 2-1/2 4.75 EA Call
EYSF-300 HBLG975 3 5.63 EA Call
EYSF-400 HBLG976 4 6.50 EA Call
Male/Female (Removable Male Nipple)
EYSM-50◊HEGI454 1/2 1.81 EA Call
EYSM-75◊HEGI455 3/4 2.25 EA Call
EYSM-100◊HEGI456 1 2.38 EA Call
*U.L. Listed for use with Appleton "Kwiko®A"and Crouse-Hinds "Chico®A"Cement.
†Turning radius with cover or plug removed.
EYS Vertical Conduit Seals
Almag 35* Aluminum
Model No. Hughes No.
Conduit
Size (In.)
Turning
Radius (in)†Unit List Price
Female
EYSF-50AL HGZN735 1/2 1.81 EA Call
EYSF-75AL HGZN736 3/4 2.25 EA Call
EYSF-100AL HGZN734 1 2.38 EA Call
Male/Female (Removable Male Nipple)
EYSM-50AL HGZN738 1/2 1.81 EA Call
EYSM-75AL HGZN739 3/4 2.25 EA Call
EYSM-100AL HGZN737 1 2.38 EA Call
*U.L. Listed for use with Appleton "Kwiko®A"and Crouse-Hinds "Chico®A"cement.
†Turning radius with cover or plug removed.
ESU Vertical and Horizontal Conduit Seals
Malleable Iron*
Model No. Hughes No.
Conduit
Size (In.)
Turning
Radius (in)†Unit List Price
Female
ESUF-50 HEGI386 1/2 1.25 EA Call
ESUF-75 HEFM272 3/4 1.25 EA Call
ESUF-100 HEGI387 1 1.38 EA Call
Male/Female (Removable Male Nipple)
ESUM-50 HEOM736 1/2 1.25 EA Call
ESUM-75 HEOM739 3/4 1.25 EA Call
ESUM-100 HEOM764 1 1.38 EA Call
1900 Piece Nut and Washer
Assortment, PV35549
• Contains 25 screws each of: 1/4-20 x 5/8", 1/4-20 x 1"
• Contains 50 screws each of: 10-32 x 1", 1/4-20 x 1/2",
1/4-20 x 1-1/2"
• Contains 100 screws each of: 6-32 x 5/8", 8-32 x 3/8",
x 5/8", x 1", x 1-1/2", x 2", 10-24 x 1-1/2", 10-32 x 3/8", x1/2"
• 100 each machine screw nuts: 6-32 square,
8-32 hex, 10-24 square, 10-32 square, 1/4-20 hex
• 100 each split washers: # 8, #10, 1/4"
472-473.qxp 9/5/07 9:04 AM Page 472
*U.L. Listed for use with Appleton "Kwiko®A"and Crouse-Hinds "Chico®A"cement.
◊Indicates items which are U.L.Listed for Class I, Groups A, B, C, and D; Class II Groups E, F
and G; and Class III.
†Turning radius with cover or plug removed.
‡Not U.L. Listed CSA Certified only.
Appleton®
EY Vertical and Horizontal Conduit Seals
for Close Turning Radius
Malleable Iron*
Model No. Hughes No.
Conduit
Size (In.)
Turning
Radius (in) Unit List Price
Female
EYF-50◊HEFQ304 1/2 1.06 EA Call
EYF-75◊HEFQ308 3/4 1.19 EA Call
EYF-100◊HEFQ311 1 1.38 EA Call
EYF-125 HEFQ314 1-1/4 1.75 EA Call
EYF-150 HEFQ317 1-1/2 2.06 EA Call
EYF-200 HEGE487 2 2.31 EA Call
EYF-250 HEGI106 2-1/2 2.69 EA Call
EYF-300 HEIP581 3 3.13 EA Call
EYF-350 HEOI578 3-1/2 3.44 EA Call
EYF-400 HEGI107 4 3.69 EA Call
EYF-500‡HENL042 5 4.69 EA Call
EYF-600‡HEGS499 6 5.38 EA Call
Male/Female (Removable Male Nipple)
EYM-50◊HEGI108 1/2 1.06 EA Call
EYM-75◊HEGI109 3/4 1.19 EA Call
EYM-100◊HEGI110 1 1.38 EA Call
EYM-125 HEGI111 1-1/4 1.75 EA Call
EYM-150 HEGI112 1-1/2 2.06 EA Call
EYM-200 HEGI113 2 2.31 EA Call
EYM-250 HEGI114 2-1/2 2.69 EA Call
EYM-300 HEGI115 3 3.13 EA Call
EYM-350 HEGI116 3-1/2 3.44 EA Call
EYM-400 HEGI117 4 3.69 EA Call
EYM-500‡HEGS500 5 4.69 EA Call
EYM-600‡HENL053 6 5.38 EA Call
Seals CONDUIT FITTINGS
hdsupply.com 473
Conduit
*U.L. Listed for use with Appleton "Kwiko®A"and Crouse-Hinds "Chico®A"cement.
◊Indicates items which are U.L. Listed for Class I, Groups A, B, C, and D; Class II, Groups E, F
and G; and Class III.
†Turning radius with cover or plug removed.
EY Vertical and Horizontal Conduit Seals
for Close Turning Radius
Almag 35 Aluminum*
Model No. Hughes No.
Conduit
Size (In.)
Turning
Radius (in)†Unit List Price
Female
EYF-50AL◊HGZN722 1/2 1.06 EA Call
EYF-75AL◊HGZN723 3/4 1.19 EA Call
EYF-100AL◊HGZN714 1 1.38 EA Call
EYF-125AL HGZN715 1-1/4 1.75 EA Call
EYF-150AL HGZN716 1-1/2 2.06 EA Call
EYF-200AL HGZN717 2 2.31 EA Call
EYF-250AL HGZN718 2-1/2 2.69 EA Call
EYF-300AL HGZN719 3 3.13 EA Call
EYF-350AL HGZN720 3-1/2 3.44 EA Call
EYF-400AL HGZN721 4 3.69 EA Call
Male/Female (Removable Male Nipple)
EYM-50AL◊HGZN732 1/2 1.06 EA Call
EYM-75AL◊HGZN733 3/4 1.19 EA Call
EYM-100AL◊HGZN724 1 1.38 EA Call
EYM-125AL HGZN725 1-1/4 1.75 EA Call
EYM-150AL HGZN726 1-1/2 2.06 EA Call
EYM-200AL HGZN727 2 2.31 EA Call
EYM-250AL HGZN728 2-1/2 2.69 EA Call
EYM-300AL HGZN729 3 3.13 EA Call
EYM-350AL HGZN730 3-1/2 3.44 EA Call
EYM-400AL HGZN731 4 3.69 EA Call
472-473.qxp 9/5/07 9:04 AM Page 473
CONDUIT FITTINGS End Caps, Blanks & Plugs
474 hdsupply.com
Conduit
Cantex
Caps
Rigid Nonmetallic Conduit
Meter Offset
Model No. Hughes No.
Size
(In.)
Standard
Carton
Quantity Offset
Dimension
A (in.) Unit List Price
E995J HDXT178 2 8 0.684 4.270 EA Call
End Bells
Rigid Nonmetallic Conduit
Carlon®
End Caps
Rigid Nonmetallic Conduit Plugs with Pull Tabs
Rigid Nonmetallic Conduit
Model No. Hughes No.
Size
(In.)
Standard
Carton
Quantity
Standard
Carton
Weight (lbs.) Unit List Price
P258JT HEIN758 2 60 3 EA Call
P258LT HECO619 3 30 3 EA Call
P258NT HDUB035 4 48 8 EA Call
P258PT HEIN690 5 30 6 EA Call
P258RT HECO620 6 30 9 EA Call
Model
No.
Hughes
No.
Size
(In.) Color
Standard
Carton
Quantity
Standard
Carton
Weight (lbs.) Unit List Price
E958D HECN079 1/2 Gray 100 3 EA Call
E958E HDXT203 3/4 Gray 100 4 EA Call
E958G HDVU082 1-1/4 Gray 40 4 EA Call
E958H HECO198 1-1/2 Gray 30 4 EA Call
E958J HECJ510 2 Gray 25 5 EA Call
E958N HECJ525 4 Gray 5 17 EA Call
Model No. Hughes No.
Size
(In.)
Standard
Carton
Quantity
Standard
Carton
Weight (lbs.) Unit List Price
E997F-CAR HECN590 1 15 1 EA Call
E997H HECN592 1-1/2 30 2.4 EA Call
E997J-CAR HECN162 2 10 1 EA Call
E997K-CAR HECO613 2-1/2 10 2 EA Call
E997L-CAR HEDM622 3 10 2 EA Call
E997M HEAY654 3-1/2 40 10 EA Call
E997N HECO614 4 30 11 EA Call
E997P HECO615 5 15 10 EA Call
E997R HECO616 6 10 7.4 EA Call
Model No. Hughes No. Conduit Size (In.) Unit List Price
5140031 HBYX461 1/2 Pack Call
5140032 HBYX462 3/4 Pack Call
5140033 HBYX463 1 Pack Call
5140034 HBYX464 1-1/4 Pack Call
5140035 HBYX465 1-1/2 Pack Call
5140037 HBYX467 2 Pack Call
5140038 HBYX468 2-1/2 Pack Call
5140039 HBYX469 3 Pack Call
5140036 HBYX466 3-1/2 Pack Call
5140040 HBYX470 4 Pack Call
5140041 HBYX471 5 Pack Call
5140042 HBYX472 6 Pack Call
474-475.qxp 9/5/07 9:05 AM Page 474
Steel (1/2" to 1") and Malleable (1-1/4" to 6")
List PriceUnitType
Conduit
Size (In.)Hughes No.Model No.
End Caps, Blanks & Plugs CONDUIT FITTINGS
hdsupply.com 475
Conduit
Steel City®- T&B
Rigid/Intermediate Grade Conduit Fittings
Snap in Blanks
Model No. Hughes No. Conduit Size (In.) Unit List Price
BL-111 HAXI607 1/2" EA Call
BL-112 HBJY563 3/4" EA Call
BL-113 HBJY564 1-1/4" EA Call
BL-114 HBJY565 1" EA Call
BL-115 HEHY025 1-1/2" EA Call
BL-116 HBJY566 2" EA Call
†Indicates items in the shaded area which are UL Listed for Class I, Groups A, B, C and D;
Class II, Groups E, F and G; and Class III.
◊Indicates items in the shaded area which are UL Listed for Class I, Groups B, C and D; Class
II, Groups E, F and G; and Class III.
Appleton®
PLG Close-Up Plugs and BR Reducers:
Explosionproof, Dust-Ignitionproof
Close-Up Plugs
• Class I, Div. 1 and 2
• Groups A†, B◊, C, D
• Class II, Div. 1 and 2
• Groups E, F, G
• Class III
• UNILETS®for Use with Threaded Metal Conduit.
Duct Sealing Compound
Type DC
This asbestos-free sealer is a gray, permanently soft, non-toxic, non-
volatile compound which will adhere to most clean, dry surfaces. It will
not adversely affect other plastic materials or corrode metals and has
no adverse effect on human skin.
• Asbestos Free
• FDA Approved as listed in CFR, Title 21 being composed of ingredi-
ents acceptable for packaging and transporting food.
• Chemically acceptable to the U.S.D.A. for use in meat and poultry
processing areas under Federal Inspection.
• Dielectric Strength: Approximate 100 volts per mil (ASTM D149-64).
Resistivity: 1.5.1 @ 100°C, 4.8 x 109 ohm-cm. 1.5.2 after 96 hours @
115°C, 4.8 x 1010 ohm-cm (ASME power test code of 1965, Section
40.5).
• No vehicle bleedout
• Non-Corrosive: , Non-Irritant, Non-Toxic
Model No. Hughes No. Description Unit List Price
DC-10 HEFV615 1 lb. bag EA Call
DC-50 HEFV617 5 lb. bag EA Call
Model No. Hughes No.
Conduit
Size (In.) Type Unit List Price
Steel (1/2" to 1") and Malleable (1-1/4" to 6")
PLG50R†HEPQ877 1/2 Recessed Head EA Call
PLG75R†HEGR891 3/4 Recessed Head EA Call
PLG100R†HEIR131 1 Recessed Head EA Call
PLG125◊HGZN748 1-1/4 Recessed Head EA Call
PLG150◊HGZN750 1-1/2 Recessed Head EA Call
PLG200◊HGZN752 2 Recessed Head EA Call
PLG250◊HGZN754 2-1/2 Recessed Head EA Call
PLG300◊HGZN756 3 Recessed Head EA Call
PLG400◊HEIQ029 4 Recessed Head EA Call
PLG50-S†HGZN760 1/2 Square Head EA Call
PLG75-S†HGZN761 3/4 Square Head EA Call
PLG100-S†HGZN747 1 Square Head EA Call
PLG125-S◊HGZN749 1-1/4 Square Head EA Call
PLG150-S◊HGZN751 1-1/2 Square Head EA Call
PLG200-S◊HGZN753 2 Square Head EA Call
PLG250-S◊HGZN755 2-1/2 Square Head EA Call
PLG300-S◊HGZN757 3 Square Head EA Call
PLG350-S◊HGZN758 3-1/2 Square Head EA Call
PLG400-S◊HGZN759 4 Square Head EA Call
PLG500-B HEGI426 5 Bar Head (Cast Iron) EA Call
PLG600-B HEIQ031 6 Bar Head (Cast Iron) EA Call
Aluminum (1/2" to 4")
PLG-50RA†HEGI725 1/2 Recessed Head EA Call
PLG-75RA†HEGI726 3/4 Recessed Head EA Call
PLG-100RA†HEGI727 1 Recessed Head EA Call
PLG-125A◊HEGI555 1-1/4 Recessed Head EA Call
PLG-150A◊HEGI556 1-1/2 Recessed Head EA Call
PLG-200A◊HEGI557 2 Recessed Head EA Call
PLG-250A◊HEOO809 2-1/2 Recessed Head EA Call
PLG-300A◊HEOO812 3 Recessed Head EA Call
PLG-400A◊HEIU221 4 Recessed Head EA Call
474-475.qxp 9/5/07 9:05 AM Page 475
CONDUIT BODIES & BOXES Conduit Bodies
476 hdsupply.com
Conduit
Cantex
Conduit Bodies
Type C
Model No. Hughes No. Conduit Size (In.) UPC Code Unit List Price
5133103 HBYX293 1 56760 4 EA Call
5133104 HEJX501 1-1/4 56761 1 EA Call
5133105 HBYX294 1-1/2 56762 8 EA Call
5133106 HBYX295 2 56763 5 EA Call
5133108 HBYX393 2-1/2 51713 5 EA Call
5133107 HBYX394 3 51712 8 EA Call
5133109 HBYX395 4 51714 2 EA Call
Conduit Bodies
Type LB
Model No. Hughes No. Conduit Size (In.) UPC Code Unit List Price
5133665 HEGQ546 1 56766 6 EA Call
5133666 HEGQ547 1-1/4 56767 3 EA Call
5133667 HEGQ517 1-1/2 56701 7 EA Call
5133668 HEGQ548 2 56768 0 EA Call
5133669 HEGQ432 2-1/2 06547 6 EA Call
5133670 HEGQ433 3 06548 3 EA Call
5133672 HEGQ435 4 06550 6 EA Call
Conduit Bodies
Type LL
Model No. Hughes No. Conduit Size (In.) UPC Code Unit List Price
5133662 HEGQ549 1 56771 0 EA Call
5133649 HEJW474 1-1/4 06564 3 EA Call
5133648 HEJW478 1-1/2 06565 0 EA Call
5133647 HEGQ550 2 56772 7 EA Call
5133644 HEJW679 2-1/2 51756 2 EA Call
5133646 HEJW525 3 51758 6 EA Call
5133645 HEJW683 4 51757 9 EA Call
Conduit Bodies
Type LR
Model No. Hughes No. Conduit Size (In.) UPC Code Unit List Price
5133652 HEGQ551 1 56775 8 EA Call
5133653 HEJW485 1-1/4 06584 1 EA Call
5133654 HEJW488 1-1/2 06585 8 EA Call
5133655 HEJX570 2 56776 5 EA Call
5133658 HEJW691 2-1/2 51761 6 EA Call
5133656 HEJW528 3 51759 3 EA Call
5133657 HEJW686 4 51760 9 EA Call
Conduit Bodies
Type T
Model No. Hughes No. Conduit Size (In.) UPC Code Unit List Price
5133565 HEGQ554 1 56785 7 EA Call
5133566 HEGQ555 1-1/4 56786 4 EA Call
5133567 HEGQ556 1-1/2 56787 1 EA Call
5133568 HEGQ557 2 56788 8 EA Call
5133569 HEGC642 2-1/2 06607 7 EA Call
5133570 HEJW646 3 51740 1 EA Call
5133571 HEJW650 4 51741 8 EA Call
Conduit Bodies
Type E
Model No. Hughes No. Conduit Size (In.) UPC Code Unit List Price
5133153 HBYW988 1 06523 0 EA Call
5133154 HBYW989 1-1/4 06524 7 EA Call
5133155 HBYX362 1-1/2 06525 4 EA Call
5133156 HBYX363 2 06526 1 EA Call
5133157 HBYX364 2-1/2 06527 8 EA Call
5133158 HBYX365 3 06528 5 EA Call
5133159 HBYX367 4 06530 8 EA Call
476-477.qxp 9/5/07 9:05 AM Page 476
Conduit Bodies CONDUIT BODIES & BOXES
hdsupply.com 477
Conduit
Supplied with 4 stainless steel cover screws. Diameter 4 1⁄8", Thickness 1⁄4".
Not designed for use with wiring devices or light fixtures.
Carlon®
Conduit Bodies
Type X with Cover
Four knock-out type socket openings, 90°spacing. Available with 1⁄2"or
3⁄4" socket outlets. Includes cover and gasket. Supplied with separate
mounting feet for easy mounting.
E970CE is UL listed.
Model No. Hughes No.
Size
(In.) Volume
Standard
Carton Quantity Unit List Price
E970CD HECO663 1/2 15.16 15 EA Call
E970CE HECO664 3/4 15.16 15 EA Call
Conduit Bodies
Type C
Standards: UL listed.
Model No. Hughes No. Conduit Size (In.) Capacity (cu. in.) Unit List Price
E987D-CAR HEDM890 1/2 4.0 EA Call
E987E-CAR HEDQ588 3/4 12.0 EA Call
E987F-CAR HDZO106 1 12.0 EA Call
E987G-CAR HEDM616 1-1/4 32.0 EA Call
E987H-CAR HDUA786 1-1/2 32.0 EA Call
E987J HECN123 2 63.0 EA Call
Conduit Bodies
Type LB
Standards: UL listed.
Model No. Hughes No. Conduit Size (In.) Capacity (cu. in.) Unit List Price
E986D-CAR HEIN624 1/2 4.0 EA Call
E986E-CAR HEIN688 3/4 12.0 EA Call
E986F-CAR HEIN691 1 12.0 EA Call
E986G-CAR HEIN699 1-1/4 32.0 EA Call
E986H-CAR HEIN700 1-1/2 32.0 EA Call
E986J HEIN702 2 63.0 EA Call
E986K*HEIN705 2-1/2 210. EA Call
E986L*HEIN714 3 210. EA Call
E986M*HEIN720 3-1/2 390. EA Call
E986N*HEIN721 4 390. EA Call
Conduit Bodies
Type LL
Standards: UL listed.
Model No. Hughes No. Conduit Size (In.) Capacity (cu. in.) Unit List Price
E984D-CAR HECN160 1/2 4.0 EA Call
E984E-CAR HECN091 3/4 12.0 EA Call
E984F-CAR HDXR310 1 12.0 EA Call
E984G-CAR HEDM888 1-1/4 32.0 EA Call
E984H-CAR HDXR915 1-1/2 32.0 EA Call
E984J HECJ654 2 63.0 EA Call
Conduit Bodies
Type LR
Standards: UL listed.
Model No. Hughes No. Conduit Size (In.) Capacity (cu. in.) Unit List Price
E985D-CAR HDVT941 1/2 4.0 EA Call
E985E-CAR HECN092 3/4 12.0 EA Call
E985F-CAR HDXS616 1 12.0 EA Call
E985G-CAR HEDM889 1-1/4 32.0 EA Call
E985H-CAR HDVT301 1-1/2 32.0 EA Call
E985J HDVV091 2 63.0 EA Call
Conduit Bodies
Type T
Standards: UL listed.
Model No. Hughes No. Conduit Size (In.) Capacity (cu. in.) Unit List Price
E983D-CAR HEIN723 1/2 4.0 EA Call
E983E-CAR HEIN724 3/4 12.0 EA Call
E983F HDXT057 1 12.0 EA Call
E983G HECN683 1-1/4 32.0 EA Call
E983H-CAR HECN684 1-1/2 32.0 EA Call
E983J HEAC926 2 63.0 EA Call
*Not UL listed
476-477.qxp 9/5/07 9:05 AM Page 477
List PriceUnitType
Body
Type
Hub
Size (in)Hughes No.Model No.
CONDUIT BODIES & BOXES Conduit Bodies
478 hdsupply.com
Conduit
Carlon®
Conduit Bodies
Type E
• Standards: UL Listed
Appleton®
Conduit Outlet Bodies
Form 85™Aluminum Unilet®
• Threaded Type for use with Rigid Metal Conduit and IMC.
• Setscrew Type for use with Electrical Metal Tubing (EMT).
Model No. Hughes No.
Conduit
Size (In.)
Capacity
(cu. in.) Unit List Price
E988D-CAR HEDM617 1/2 4.0 EA Call
E988E HECO487 3/4 12.0 EA Call
E988F-CAR HEDM618 1 12.0 EA Call
E988G-CAR HEDM619 1-1/4 32.0 EA Call
E988H-CAR HEDM620 1-1/2 32.0 EA Call
E988J HECO659 2 63.0 EA Call
Model No. Hughes No.
Hub
Size (in)
Body
Type Type Unit List Price
C50-A HEGA977 1/2 C Threaded Type EA Call
C75-A HEGA987 3/4 C Threaded Type EA Call
C100-A HEGF051 1 C Threaded Type EA Call
C125-A HEGW629 1-1/4 C Threaded Type EA Call
C150-A HEGF052 1-1/2 C Threaded Type EA Call
C200-A HEGW633 2 C Threaded Type EA Call
C250-A HEGI032 2-1/2 C Threaded Type EA Call
C300-A HEGI033 3 C Threaded Type EA Call
C350-A HEGI034 3-1/2 C Threaded Type EA Call
C400-A HEGI035 4 C Threaded Type EA Call
C50T-A HEOJ954 1/2 C Setscrew Type EA Call
C75T-A HEGI186 3/4 C Setscrew Type EA Call
C100T-A HEOK009 1 C Setscrew Type EA Call
C125T-A HEOK024 1-1/4 C Setscrew Type EA Call
C150T-A HEOJ876 1-1/2 C Setscrew Type EA Call
E50-A HEGI304 1/2 E Threaded Type EA Call
E75-A HEGI305 3/4 E Threaded Type EA Call
E100-A HEOL689 1 E Threaded Type EA Call
E50T-A HEOL675 1/2 E Setscrew Type EA Call
LB50-A HEGB245 1/2 LB Threaded Type EA Call
LB75-A HEGB253 3/4 LB Threaded Type EA Call
LB100-A HEGB087 1 LB Threaded Type EA Call
LB125-A HEGB091 1-1/4 LB Threaded Type EA Call
LB150-A HEGB093 1-1/2 LB Threaded Type EA Call
LB200-A HEGB256 2 LB Threaded Type EA Call
LB250-A HEGB258 2-1/2 LB Threaded Type EA Call
LB300-A HEGB261 3 LB Threaded Type EA Call
LB350-A HEGB263 3-1/2 LB Threaded Type EA Call
LB400-A HEGB269 4 LB Threaded Type EA Call
LB50T-A HEOR496 1/2 LB Setscrew Type EA Call
LB75T-A HEOR417 3/4 LB Setscrew Type EA Call
LB100T-A HEOR541 1 LB Setscrew Type EA Call
LB125T-A HEOR556 1-1/4 LB Setscrew Type EA Call
LB150T-A HEOR569 1-1/2 LB Setscrew Type EA Call
LB200T-A HEOR584 2 LB Setscrew Type EA Call
LL50-A HEGB282 1/2 LL Threaded Type EA Call
LL75-A HEGB288 3/4 LL Threaded Type EA Call
LL100-A HEGB292 1 LL Threaded Type EA Call
LL125-A HEGB295 1-1/4 LL Threaded Type EA Call
LL150-A HEGB297 1-1/2 LL Threaded Type EA Call
LL200-A HEGB301 2 LL Threaded Type EA Call
LL250-A HEGI055 2-1/2 LL Threaded Type EA Call
LL300-A HEGI056 3 LL Threaded Type EA Call
LL350-A HEOA000 3-1/2 LL Threaded Type EA Call
LL400-A HEGI057 4 LL Threaded Type EA Call
LL50T-A HEOR688 1/2 LL Setscrew Type EA Call
LL75T-A HEOR705 3/4 LL Setscrew Type EA Call
LL100T-A HEOR719 1 LL Setscrew Type EA Call
LL125T-A HEOR731 1-1/4 LL Setscrew Type EA Call
LL150T-A HEOR741 1-1/2 LL Setscrew Type EA Call
LL200T-A HEOR750 2 LL Setscrew Type EA Call
LR50-A HEGB317 1/2 LR Threaded Type EA Call
LR75-A HEGB321 3/4 LR Threaded Type EA Call
LR100-A HEGB324 1 LR Threaded Type EA Call
LR125-A HEGB326 1-1/4 LR Threaded Type EA Call
LR150-A HEGY114 1-1/2 LR Threaded Type EA Call
LR200-A HEGB100 2 LR Threaded Type EA Call
LR250-A HEOA010 2-1/2 LR Threaded Type EA Call
LR300-A HEGI058 3 LR Threaded Type EA Call
LR350-A HEOA026 3-1/2 LR Threaded Type EA Call
LR400-A HEOA030 4 LR Threaded Type EA Call
LR50T-A HEOR815 1/2 LR Setscrew Type EA Call
LR75T-A HEOR823 3/4 LR Setscrew Type EA Call
LR100T-A HEOR838 1 LR Setscrew Type EA Call
LR125T-A HEOR861 1-1/4 LR Setscrew Type EA Call
LR150T-A HEOR873 1-1/2 LR Setscrew Type EA Call
LR200T-A HEOR884 2 LR Setscrew Type EA Call
T50-A HEGB369 1/2 T Threaded Type EA Call
T75-A HEGB378 3/4 T Threaded Type EA Call
T100-A HEGB381 1 T Threaded Type EA Call
T125-A HEGB382 1-1/4 T Threaded Type EA Call
T150-A HEGB385 1-1/2 T Threaded Type EA Call
T200-A HEGB387 2 T Threaded Type EA Call
T250-A HAFX392 2-1/2 T Threaded Type EA Call
T300-A HAFX393 3 T Threaded Type EA Call
T350-A HAFW579 3-1/2 T Threaded Type EA Call
T400-A HAFW580 4 T Threaded Type EA Call
T50T-A HAFX387 1/2 T Setscrew Type EA Call
T75T-A HEGY572 3/4 T Setscrew Type EA Call
T100T-A HAFX391 1 T Setscrew Type EA Call
TB50-A HAFW768 1/2 TB Threaded Type EA Call
TB75-A HAFW769 3/4 TB Threaded Type EA Call
TB100-A HEFX809 1 TB Threaded Type EA Call
TB125-A HAFW770 1-1/4 TB Threaded Type EA Call
TB150-A HAFW771 1-1/2 TB Threaded Type EA Call
TB200-A HAFW772 2 TB Threaded Type EA Call
X50-A HEGJ151 1/2 X Threaded Type EA Call
X75-A HEFX810 3/4 X Threaded Type EA Call
X100-A HEOW078 1 X Threaded Type EA Call
Unilet Body Flat Back Round Back
C, LB, LL, LR, T 1/2" –2" 2-1/2" –4"
TB 1-1/4", 1-1/2" 1/2", 3/4", 1", 2"
E, X 1/2" –1"
478-479.qxp 9/5/07 9:06 AM Page 478
Conduit Bodies CONDUIT BODIES & BOXES
hdsupply.com 479
Conduit
List PriceUnitBody TypeHub Size (in)Hughes No.Model No.
Appleton®
Unilet®Conduit Outlet Bodies
Malleable Iron Form 35®Threaded Type Conduit Bodies
Threaded Type for use with Rigid Metal Conduit and IMC;
All TA Unilets are round back design.
Model No. Hughes No. Hub Size (in) Body Type Unit List Price
C50-M HEFX737 1/2 C EA Call
C75-M HEGV087 3/4 C EA Call
C100-M HEGI187 1 C EA Call
C125-M◊HEFQ364 1-1/4 C EA Call
C150-M◊HEGI188 1-1/2 C EA Call
C200-M◊HEGI189 2 C EA Call
C250-M◊HEGI190 2-1/2 C EA Call
C300-M◊HEGI191 3 C EA Call
C350-M◊HEOK093 3-1/2 C EA Call
C400-M◊HEIQ032 4 C EA Call
E50-M HEOL670 1/2 E EA Call
E75-M HEOL684 3/4 E EA Call
E100-M HEOL693 1 E EA Call
LB50-M HEFQ467 1/2 LB EA Call
LB75-M HENT705 3/4 LB EA Call
LB100-M HENU253 1 LB EA Call
LB125-M◊HEFQ471 1-1/4 LB EA Call
LB150-M◊HEFQ475 1-1/2 LB EA Call
LB200-M◊HEFQ477 2 LB EA Call
LB250-M◊HEFQ481 2-1/2 LB EA Call
LB300-M◊HEFQ485 3 LB EA Call
LB350-M◊HEFQ490 3-1/2 LB EA Call
LB400-M◊HENV654 4 LB EA Call
LB500-M HEGI783 5 LB EA Call
LB600-M HEOR635 6 LB EA Call
LL50-M HEGI788 1/2 LL EA Call
LL75-M HEGI789 3/4 LL EA Call
LL100-M HEGI790 1 LL EA Call
LL125-M HEGI791 1-1/4 LL EA Call
LL150-M HEGI792 1-1/2 LL EA Call
LL200-M HEGI793 2 LL EA Call
LL250-M HEGI794 2-1/2 LL EA Call
LL300-M HEFX653 3 LL EA Call
LL350-M HEGI795 3-1/2 LL EA Call
LL400-M HEGI796 4 LL EA Call
LR50-M HEGW996 1/2 LR EA Call
LR75-M HEFQ133 3/4 LR EA Call
LR100-M HEGI800 1 LR EA Call
LR125-M HEGI801 1-1/4 LR EA Call
LR150-M HEGI802 1-1/2 LR EA Call
LR200-M HEGI803 2 LR EA Call
LR250-M HEGI804 2-1/2 LR EA Call
LR300-M HEFV473 3 LR EA Call
LR350-M HEGI805 3-1/2 LR EA Call
LR400-M HEGI806 4 LR EA Call
LRL50-M HEOR904 1/2 LRL* EA Call
LRL75-M HEGI807 3/4 LRL* EA Call
LRL100-M HEGI808 1 LRL* EA Call
LRL125-M HEOR928 1-1/4 LRL* EA Call
LRL150-M HEGI809 1-1/2 LRL* EA Call
LRL200-M HEGI810 2 LRL* EA Call
T50-M HAFX385 1/2 T EA Call
T75-M HENV258 3/4 T EA Call
T100-M HEFQ666 1 T EA Call
T125-M HEFQ667 1-1/4 T EA Call
T150-M HEFQ671 1-1/2 T EA Call
T200-M HEFQ674 2 T EA Call
T250-M HEIN849 2-1/2 T EA Call
T300-M HAFX395 3 T EA Call
T350-M HAFX396 3-1/2 T EA Call
T400-M HAFX397 4 T EA Call
TA50-M HAFX398 1/2 TA EA Call
TA75-M HAFX399 3/4 TA EA Call
TA100-M HAFX400 1 TA EA Call
TB50-M HAFX401 1/2 TB EA Call
TB75-M HAFX402 3/4 TB EA Call
TB100-M HAFX403 1 TB EA Call
TB125-M HAFX404 1-1/4 TB EA Call
TB150-M HAFX405 1-1/2 TB EA Call
TB200-M HAFX406 2 TB EA Call
X50-M HEGJ152 1/2 X EA Call
X75-M HEGJ153 3/4 X EA Call
X100-M HEFS236 1 X EA Call
X125-M HEGJ154 1-1/4 X EA Call
X150-M HEGJ155 1-1/2 X EA Call
X200-M HEKX643 2 X EA Call
*LRL Unilets have double opening and are furnished with one steel cover, assembled.
◊Catalog numbers having patented roller feature, all others do not.
Back Style for Form 35 Unilet conduit body sizes (inches)
Unilet Body Flat Back Round Back
C, LB 1/2 - 2 2-1/2 and up
E 1/2 - 1
LL, LR, T 1/2 - 2 2-1/2 and up
TB 1-1/4, 1-1/2 1/2, 3/4, 1, 2
X 1/2 - 1 1-1/4 and up
EC LB LL
LR LRL TTA
TB X
Some products not available at all locations. Check with
your local Hughes representative for product availability.
478-479.qxp 9/5/07 9:06 AM Page 479
List PriceUnitType
Body
Type
Hub
Size (in)Hughes No.Model No.
CONDUIT BODIES & BOXES Conduit Bodies
480 hdsupply.com
Conduit
Appleton®
Unilet®Conduit Bodies
FM7 Conduit Bodies
• Approved for wet locations. FM7 and FM8 Grayloy-iron bodies
with the "FG"series cast covers and gasket are approved for use
in wet locations. (NEMA 3R)
• Maximum corrosion protection. Appleton FM7 and FM8
Grayloy-iron conduit bodies and cast covers have a triple-coat fin-
ish–(1) zinc electroplate, (2) dichromate, and (3) epoxy powder
coating. FM7 aluminum bodies and cast covers are coated with
epoxy powder coating. FM7 and FM8 blank steel covers have a
zinc electroplate finish. Superior FM7 and FM8 finish gives greater
corrosion protection in wet or harsh environments, assuring long,
trouble-free service.
• Grayloy-iron properties. Grayloy™is an Appleton proprietary cast
graphite flake gray iron alloy with superior physical and mechani-
cal properties offering strength, hardness, fracture toughness,
high vibration absorption and dimensional stability. Tensile
strength is similar to ASTM-A48 Class 30A (30,000 tensile), with
Brinell hardness of approximately 180BH.
• Aluminum properties. Aluminum products are produced from a
high strength copper-free (4⁄10 of 1% max.) alloy.
• More wiring space. Appleton's FM7 and FM8 flat-back design pro-
vides greater cubic content for easier wire pulling, and more room
for splicing. FM7 and FM8 flat back fits flush and snug against flat
surfaces for more stable installation.
• Form 7 and Form 8 are products of Crouse-Hinds, a member com-
pany of Cooper Industries.
• FM7™Grayloy™-Iron and Aluminum Unilet®Conduit Bodies with
Wedge-Lok™Clip Covers and Gaskets For use with Rigid Steel,
Rigid Aluminum and IMC Conduit.
• These Appleton FM7 conduit bodies, covers and gaskets have the
same applications and installation dimensions as Crouse-Hinds
Form 7 conduit bodies. Equivalent FM7 and Form 7 items are com-
pletely interchangeable.
Model No. Hughes No.
Hub
Size (in)
Body
Type Type Unit List Price
C17 HEGA820 1/2 C Grayloy-Iron EA Call
C27 HEGA968 3/4 C Grayloy-Iron EA Call
C37 HEGA969 1 C Grayloy-Iron EA Call
C47 HEGA971 1-1/4 C Grayloy-Iron EA Call
C57 HEGA975 1-1/2 C Grayloy-Iron EA Call
C67 HEGA983 2 C Grayloy-Iron EA Call
C77 HEIP444 2-1/2 C Grayloy-Iron EA Call
C87 HEOS548 3 C Grayloy-Iron EA Call
C17-SA HEGI869 1/2 C Aluminum EA Call
C27-SA HEGD244 3/4 C Aluminum EA Call
C37-SA HEGD246 1 C Aluminum EA Call
C47-SA HEGD247 1-1/4 C Aluminum EA Call
C57-SA HEGD249 1-1/2 C Aluminum EA Call
C67-SA HEGD254 2 C Aluminum EA Call
C77-SA HEND650 2-1/2 C Aluminum EA Call
C87-SA HEOS974 3 C Aluminum EA Call
LB17 HEGB232 1/2 LB Grayloy-Iron EA Call
LB27 HEGB236 3/4 LB Grayloy-Iron EA Call
LB37 HEGB239 1 LB Grayloy-Iron EA Call
LB47 HEGB242 1-1/4 LB Grayloy-Iron EA Call
LB57 HEGB248 1-1/2 LB Grayloy-Iron EA Call
LB67 HEGB250 2 LB Grayloy-Iron EA Call
LB77 HEGB255 2-1/2 LB Grayloy-Iron EA Call
LB87 HEGB082 3 LB Grayloy-Iron EA Call
LB97 HEGB084 3-1/2 LB Grayloy-Iron EA Call
LB107 HBLI316 4 LB Grayloy-Iron EA Call
LB17-SA HEGD199 1/2 LB Aluminum EA Call
LB27-SA HEGD206 3/4 LB Aluminum EA Call
LB37-SA HEGD208 1 LB Aluminum EA Call
LB47-SA HEGD209 1-1/4 LB Aluminum EA Call
LB57-SA HEGD213 1-1/2 LB Aluminum EA Call
LB67-SA HEGD215 2 LB Aluminum EA Call
LB77-SA HEOS986 2-1/2 LB Aluminum EA Call
LB87-SA HEOS990 3 LB Aluminum EA Call
LB97-SA HEGS526 3-1/2 LB Aluminum EA Call
LB107-SA HENO984 4 LB Aluminum EA Call
LL17 HEGB271 1/2 LL Grayloy-Iron EA Call
LL27 HEGB275 3/4 LL Grayloy-Iron EA Call
LL37 HEGB278 1 LL Grayloy-Iron EA Call
LL47 HEGB280 1-1/4 LL Grayloy-Iron EA Call
LL57 HEGB285 1-1/2 LL Grayloy-Iron EA Call
LL67 HEGB287 2 LL Grayloy-Iron EA Call
LL77 HEOS191 2-1/2 LL Grayloy-Iron EA Call
LL87 HEGI819 3 LL Grayloy-Iron EA Call
LL97 HEOS200 3-1/2 LL Grayloy-Iron EA Call
LL107 HEOS204 4 LL Grayloy-Iron EA Call
LL17-SA HEGD225 1/2 LL Aluminum EA Call
LL27-SA HEFT938 3/4 LL Aluminum EA Call
LL37-SA HEOO373 1 LL Aluminum EA Call
LL47-SA HEGI870 1-1/4 LL Aluminum EA Call
LL57-SA HEGI871 1-1/2 LL Aluminum EA Call
LL67-SA HEOT026 2 LL Aluminum EA Call
LL77-SA HENO991 2-1/2 LL Aluminum EA Call
LL87-SA HENO997 3 LL Aluminum EA Call
LL97-SA HENO999 3-1/2 LL Aluminum EA Call
LL107-SA HENP007 4 LL Aluminum EA Call
LR17 HEGB304 1/2 LR Grayloy-Iron EA Call
LR27 HEGB308 3/4 LR Grayloy-Iron EA Call
LR37 HEGB311 1 LR Grayloy-Iron EA Call
LR47 HEGB312 1-1/4 LR Grayloy-Iron EA Call
LR57 HEGB318 1-1/2 LR Grayloy-Iron EA Call
LR67 HEGB320 2 LR Grayloy-Iron EA Call
LR77 HEGI820 2-1/2 LR Grayloy-Iron EA Call
LR87 HEFV620 3 LR Grayloy-Iron EA Call
LR97 HEOS231 3-1/2 LR Grayloy-Iron EA Call
LR107 HEGI821 4 LR Grayloy-Iron EA Call
LR17-SA HEOT028 1/2 LR Aluminum EA Call
LR27-SA HEGD231 3/4 LR Aluminum EA Call
LR37-SA HEIP951 1 LR Aluminum EA Call
LR47-SA HEGI872 1-1/4 LR Aluminum EA Call
LR57-SA HEGI873 1-1/2 LR Aluminum EA Call
LR67-SA HEOT041 2 LR Aluminum EA Call
LR77-SA HENQ054 2-1/2 LR Aluminum EA Call
LR87-SA HENQ059 3 LR Aluminum EA Call
LR97-SA HENQ065 3-1/2 LR Aluminum EA Call
LR107-SA HENQ071 4 LR Aluminum EA Call
CLB LL LR
T E L TA
TB X
480-481.qxp 9/5/07 9:06 AM Page 480
List PriceUnitType
Body
Type
Hub
Size (in)Hughes No.Model No.
Conduit Bodies CONDUIT BODIES & BOXES
hdsupply.com 481
Conduit
T17 HEGB102 1/2 T Grayloy-Iron EA Call
T27 HEGB328 3/4 T Grayloy-Iron EA Call
T37 HEGB330 1 T Grayloy-Iron EA Call
T47 HEGB366 1-1/4 T Grayloy-Iron EA Call
T57 HEGB371 1-1/2 T Grayloy-Iron EA Call
T67 HEGB375 2 T Grayloy-Iron EA Call
T77 HAFX267 2-1/2 T Grayloy-Iron EA Call
T87 HEFW392 3 T Grayloy-Iron EA Call
T97 HAFX268 3-1/2 T Grayloy-Iron EA Call
T107 HAFX269 4 T Grayloy-Iron EA Call
T17-SA HEGD257 1/2 T Aluminum EA Call
T27-SA HEGD260 3/4 T Aluminum EA Call
T37-SA HEGD263 1 T Aluminum EA Call
T47-SA HEGD268 1-1/4 T Aluminum EA Call
T57-SA HEGD272 1-1/2 T Aluminum EA Call
T67-SA HEGD276 2 T Aluminum EA Call
T77-SA HEOL809 2-1/2 T Aluminum EA Call
T87-SA HEOL814 3 T Aluminum EA Call
T97-SA HEOL818 3-1/2 T Aluminum EA Call
T107-SA HEOL823 4 T Aluminum EA Call
E17 HEGI818 1/2 E Grayloy-Iron EA Call
E27 HEOS553 3/4 E Grayloy-Iron EA Call
E37 HEGI842 1 E Grayloy-Iron EA Call
E17-SA HENG766 1/2 E Aluminum EA Call
E27-SA HENG772 3/4 E Aluminum EA Call
E37-SA HENG529 1 E Aluminum EA Call
L17 HEOS561 1/2 L Grayloy-Iron EA Call
L27 HEOS566 3/4 L Grayloy-Iron EA Call
L37 HEOS574 1 L Grayloy-Iron EA Call
L47 HEOS125 1-1/4 L Grayloy-Iron EA Call
L57 HEOS486 1-1/2 L Grayloy-Iron EA Call
L67 HEOS130 2 L Grayloy-Iron EA Call
TA17 HAFX270 1/2 TA Grayloy-Iron EA Call
TA27 HEFW320 3/4 TA Grayloy-Iron EA Call
TA37 HAFX271 1 TA Grayloy-Iron EA Call
TA47 HAFX272 1-1/4 TA Grayloy-Iron EA Call
TA57 HAFX273 1-1/2 TA Grayloy-Iron EA Call
TA67 HAFX274 2 TA Grayloy-Iron EA Call
TB17 HAFX275 1/2 TB Grayloy-Iron EA Call
TB27 HEGR576 3/4 TB Grayloy-Iron EA Call
TB37 HAFX276 1 TB Grayloy-Iron EA Call
TB47 HAFX278 1-1/4 TB Grayloy-Iron EA Call
TB57 HAFX279 1-1/2 TB Grayloy-Iron EA Call
TB67 HAFX280 2 TB Grayloy-Iron EA Call
TB17-SA HAFW877 1/2 TB Aluminum EA Call
TB27-SA HEEY330 3/4 TB Aluminum EA Call
TB37-SA HEEY895 1 TB Aluminum EA Call
TB47-SA HAFW878 1-1/4 TB Aluminum EA Call
TB57-SA HAFW879 1-1/2 TB Aluminum EA Call
TB67-SA HAFX377 2 TB Aluminum EA Call
X17 HEGI822 1/2 X Grayloy-Iron EA Call
X27 HEGB404 3/4 X Grayloy-Iron EA Call
X37 HEFV529 1 X Grayloy-Iron EA Call
X47 HEGI823 1-1/4 X Grayloy-Iron EA Call
X57 HEGI824 1-1/2 X Grayloy-Iron EA Call
X67 HEGI825 2 X Grayloy-Iron EA Call
X17-SA HEOT066 1/2 X Aluminum EA Call
X27-SA HEGI874 3/4 X Aluminum EA Call
X37-SA HEGI875 1 X Aluminum EA Call
X47-SA HEOM848 1-1/4 X Aluminum EA Call
X57-SA HEOM852 1-1/2 X Aluminum EA Call
X67-SA HEOM857 2 X Aluminum EA Call
480-481.qxp 9/5/07 9:06 AM Page 481
GRLB
List PriceUnitCover Size (in.)Body Size (In.)Hughes No.Model No.
CONDUIT BODIES & BOXES Outlet Boxes
482 hdsupply.com
Conduit
Appleton®
GR Conduit Outlet Boxes
Aluminum
Unilets®for use with Threaded Metal Conduit.
Furnished with Internal Ground Screw and O-Ring.
• Malleable iron bodies and covers (except ELBY) triple-coat—
(1)zinc electroplate, (2) dichromate, and (3) epoxy powder coat.
• Aluminum bodies and covers: epoxy powder coat.
• ELBY malleable iron body and cover: zinc electroplate and clear
chromate.
Options
• PVC available—consult Hughes Supply representative.
Compliances
• UL Standard 886.
• Federal Spec. W-C-586B.
• Appleton malleable iron products conform to ASTM A47-77, Grade
32510, which has the following properties: tensile strength, 50,000
psi; yield, 32,000 psi; and elongation, 10%.
• Appleton aluminum products are produced from a high strength
copper-free (4/10 of 1% max.) alloy.
• Suitable for Class I, Div. 1 & 2, if installed in compliance with NEC
501-4(a)(b) and for Class II, Div. 1 & 2, if in compliance with NEC
502-4(a)(b).
Model No. Hughes No. Body Size (In.) Cover Size (in.) Unit List Price
GRE
GRE50-A HEOP216 1/2 3.38 EA $37.27
GRE75-A HEOP222 3/4 3.38 EA 37.07
GRE100-A HEOP231 1 3.38 EA 38.31
GRE125-A HENM301 1-1/4 3.94 EA 75.29
GRE150-A HEGS440 1-1/2 4.88 EA 166.35
GRC
GRC50-A HEGI597 1/2 3.38 EA 46.94
GRC75-A HEFV780 3/4 3.38 EA 46.04
GRC100-A HEOP193 1 3.38 EA 52.05
GRC125-A HEOP201 1-1/4 3.94 EA 87.70
GRC150-A HENZ902 1-1/2 4.88 EA 174.54
GRC200-A HENZ909 2 4.88 EA 150.89
GRL
GRL50-A HEGI652 1/2 3.38 EA 34.57
GRL75-A HEGI654 3/4 3.38 EA 46.04
GRL100-A HEGI656 1 3.38 EA 48.17
GRL125-A HEGI658 1-1/4 3.94 EA 87.70
GRL150-A HENZ915 1-1/2 4.88 EA 161.51
GRL200-A HEGI048 2 4.88 EA 178.83
GRLB
GRLB50-A HEGI662 1/2 3.38 EA 46.27
GRLB75-A HEGI663 3/4 3.38 EA 46.04
GRLB100-A HEGI664 1 3.38 EA 48.17
GRLB125-A HEGI666 1-1/4 3.94 EA 87.70
GRLB150-A HENZ928 1-1/2 4.88 EA 174.54
GRLB200-A HEGI051 2 4.88 EA 185.81
GRN
GRN50-A HENM359 1/2 3.38 EA 41.73
GRN75-A HENM364 3/4 3.38 EA 41.73
GRN100-A HENM369 1 3.38 EA 49.46
GRN125-A HENM373 1-1/4 3.94 EA 80.70
GRN150-A HENM378 1-1/2 4.88 EA 160.73
GRT
GRT50-A HEGI668 1/2 3.38 EA 46.04
GRT75-A HEGI669 3/4 3.38 EA 49.07
GRT100-A HEGI670 1 3.38 EA 50.76
GRT125-A HEGI671 1-1/4 3.94 EA 86.35
GRT150-A HEGI052 1-1/2 4.88 EA 176.66
GRT200-A HEGI054 2 4.88 EA 182.68
GRX
GRX50-A HEGI680 1/2 3.38 EA 52.05
GRX75-A HEGI682 3/4 3.38 EA 51.41
GRX100-A HEGI684 1 3.38 EA 56.46
GRX125-A HEOP806 1-1/4 3.94 EA 99.38
GRX150-A HENZ984 1-1/2 4.88 EA 197.45
GRX200-A HENZ989 2 4.88 EA 183.14
GRC
GRL
GRLB
GRN
GRT
GRX
482-483.qxp 9/5/07 9:07 AM Page 482
GRLB
List PriceUnit
Cover
Size (in.)
Body
Size (In.)Hughes No.Model No.
Outlet Boxes CONDUIT BODIES & BOXES
hdsupply.com 483
Conduit
Appleton®
GR Conduit Outlet Boxes
Unilets®for use with Threaded Metal Conduit. Furnished with Internal
Ground Screw and O-Ring.
• Malleable iron bodies and covers (except ELBY) triple-coat—
(1) zinc electroplate, (2) dichromat, and (3) epoxy powder coat.
• ELBY malleable iron body and cover
• PVC available—consult your Hughes Supply representative
Compliances
• UL Standard 88, Federal Spec. W-C-586, ASTM A47-77, Grade 32510
• Appleton aluminum products are produced from a high strength
copper-free (4/10 of 1% max.) alloy.
• Suitable for Class I, Div. 1 & 2, if installed in compliance with NEC
501- 4(a)(b) and for Class II, Div. 1 & 2, if in compliance with NEC
502-4(a)(b).
GRSS Conduit Outlet Boxes with Multiple Hubs.
Aluminum
Internally threaded aluminum bodies with externally threaded aluminum
form 1 covers.
Model No. Hughes No. Conduit Size (In.) Cover Size (in.) No. of Hubs No. of Plugs Unit List Price
GRSS Outlet Box with Cover
GRSS50 HEGI905 1/2 3.38 7 4 EA $60.86
GRSS75 HEGI906 3/4 3.38 7 4 EA 60.86
GRSS100 HEFO243 1 3.38 7 4 EA 62.41
GRSSA Outlet Box with Cover
GRSSA50 HEGR766 1/2 3.38 13 5 EA 65.74
GRSSA75 HEGI907 3/4 3.38 13 5 EA 70.55
Model No. Hughes No.
Body
Size (In.)
Cover
Size (in.) Unit List Price
GRE
GRE50 HEOP214 1/2 3.38 EA $36.29
GRE75 HEGI601 3/4 3.38 EA 37.15
GRE100 HEOP228 1 3.38 EA 42.75
GRE125 HEOP235 1-1/4 3.94 EA 75.29
GRE150 HEOP238 1-1/2 4.88 EA 161.65
GRC
GRC50 HEGC803 1/2 3.38 EA 34.57
GRC75 HEGA139 3/4 3.38 EA 36.70
GRC100 HEFP930 1 3.38 EA 48.17
GRC125 HEGI598 1-1/4 3.94 EA 86.89
GRC150 HEGI599 1-1/2 4.88 EA 161.51
GRC200 HEGI046 2 4.88 EA 171.86
GRL
GRL50 HEGI651 1/2 3.38 EA 34.57
GRL75 HEGI653 3/4 3.38 EA 36.70
GRL100 HEGI655 1 3.38 EA 48.17
GRL125 HEGI657 1-1/4 3.94 EA 81.13
GRL150 HEGI659 1-1/2 4.88 EA 161.51
GRL200 HEGI047 2 4.88 EA 165.48
GRLB
GRLB50 HEGC806 1/2 3.38 EA 34.11
GRLB75 HEFU990 3/4 3.38 EA 36.70
GRLB100 HEIS881 1 3.38 EA 48.17
GRLB125 HEGI665 1-1/4 3.94 EA 81.13
GRLB150 HEFW969 1-1/2 4.88 EA 161.51
GRLB200 HEGI049 2 4.88 EA 171.96
GRN
GRN50 HEOP686 1/2 3.38 EA 41.73
GRN75 HEGI667 3/4 3.38 EA 41.73
GRN100 HEOP694 1 3.38 EA 48.06
GRN125 HEOP698 1-1/4 3.94 EA 83.05
GRN150 HEOP704 1-1/2 4.88 EA 160.73
GRT
GRT50 HEFT390 1/2 3.38 EA 36.70
GRT75 HEEB116 3/4 3.38 EA 39.07
GRT100 HEIS878 1 3.38 EA 50.76
GRT125 HEIU421 1-1/4 3.94 EA 86.35
GRT150 HEGI672 1-1/2 4.88 EA 176.66
GRT200 HEGI053 2 4.88 EA 182.68
GRX
GRX50 HEGC573 1/2 3.38 EA 38.33
GRX75 HEGI681 3/4 3.38 EA 45.40
GRX100 HEGI683 1 3.38 EA 56.39
GRX125 HEGI685 1-1/4 3.94 EA 91.96
GRX150 HEGI686 1-1/2 4.88 EA 182.68
GRX200 HEGI687 2 4.88 EA 193.35
GRE
GRC
GRL
GRN
GRT
GRX
482-483.qxp 9/5/07 9:07 AM Page 483
A HomeWorks®lighting control system puts every light at your
client’s command. New Lutron patented wireless technology can be
installed at any stage of construction, in as little as one day - without
changes to walls or new wiring.
new Total lighting control for existing homes.
// g
484_EC05.qxd 10/25/05 10:45 AM Page 2
Cast Cover
List PriceUnitTypeBody Size (In.)Hughes No.Model No.
Outlet Boxes CONDUIT BODIES & BOXES
hdsupply.com 485
Conduit
Appleton®
Form 35®Covers and Gaskets
Unilet®Conduit Outlet Bodies
Unilet®Conduit Bodies
FM7 Blank Covers and Gaskets
• FM7™Grayloy™-Iron and Aluminum Unilet®Conduit Bodies with
Wedge-Lok™Clip Covers and Gaskets For use with Rigid Steel,
Rigid Aluminum and IMC Conduit.
Model No. Hughes No. Body Size (In.) Type Unit List Price
Cast Cover
170F HEGI826 1/2 Grayloy-Iron EA $3.56
270F HEGI827 3/4 Grayloy-Iron EA 4.32
370F HEGI828 1 Grayloy-Iron EA 6.83
470F HEGI829 1-1/4 Grayloy-Iron EA 9.11
570F HEGI830 1-1/2 Grayloy-Iron EA 9.11
670F HEGI831 2 Grayloy-Iron EA 13.43
870F HEGI832 2-1/2
3
Grayloy-Iron EA 15.71
970F HEGI833 3-1/2
4
Grayloy-Iron EA 21.31
170F-SA HEOT095 1/2 Aluminum EA 3.90
270F-SA HEGI877 3/4 Aluminum EA 5.33
370F-SA HEGI878 1 Aluminum EA 8.10
470F-SA HEOT105 1-1/4 Aluminum EA 9.69
570F-SA HEGI879 1-1/2 Aluminum EA 11.42
670F-SA HEGI880 2 Aluminum EA 13.75
870F-SA HEOM929 2-1/2
3
Aluminum EA 15.94
970F-SA HEOM936 3-1/2
4
Aluminum EA 33.27
170FG HEGI846 1/2 Grayloy-Iron EA 6.86
270FG HEGI847 3/4 Grayloy-Iron EA 7.86
370FG HEGI848 1 Grayloy-Iron EA 11.73
470FG HEGI849 1-1/4 Grayloy-Iron EA 15.38
570FG HEGI850 1-1/2 Grayloy-Iron EA 15.38
670FG HEGI851 2 Grayloy-Iron EA 21.41
870FG HEGI852 2-1/2
3
Grayloy-Iron EA 27.71
970FG HEGI853 3-1/2
4
Grayloy-Iron EA 39.52
170FG-SA HEOT118 1/2 Aluminum EA 7.86
270FG-SA HEGI881 3/4 Aluminum EA 9.06
370FG-SA HEOT129 1 Aluminum EA 13.27
470FG-SA HEGI882 1-1/4 Aluminum EA 17.23
570FG-SA HEOT135 1-1/2 Aluminum EA 18.13
670FG-SA HEGI883 2 Aluminum EA 23.58
870FG-SA HEOT144 2-1/2
3
Aluminum EA 32.73
970FG-SA HEOT146 3-1/3
4
Aluminum EA 46.01
170 HAZY947 1/2 Steel EA 2.60
270 HEGB415 3/4
1
Steel EA 3.18
470 HAZZ969 1-1/4 Steel EA 5.22
570 HBAA012 1-1/2 Steel EA 5.22
670 HBAA033 2 Steel EA 9.15
870 HBAA077 2-1/2
3
Steel EA 14.37
970 HEGB430 3-1/2
4
Steel EA 16.94
170-SA HEGD278 1/2 Aluminum EA 2.80
270-SA HEGD281 3/4
1
Aluminum EA 3.02
470-SA HEGD287 1-1/4 Aluminum EA 6.07
570-SA HEGD289 1-1/2 Aluminum EA 6.07
670-SA HEGD292 2 Aluminum EA 9.91
870-SA HEGD293 2-1/2
3
Aluminum EA 12.08
970-SA HEGI876 3-1/2
4
Aluminum EA 21.51
GASK571 HAZW877 1/2 - EA 2.28
GASK572 HAZW929 3/4 - EA 2.28
GASK573 HAZW982 1 - EA 3.02
GASK574 HAZX023 1-1/4 - EA 3.83
GASK575 HAZX143 1-1/2 - EA 3.83
GASK576 HAZX184 2 - EA 4.60
GASK578 HAZX207 2-1/2
3
- EA 7.61
GASK579 HAZX209 3-1/2
4
- EA 9.61
Model No. Hughes No. Conduit Size (In.) Unit List Price
Blank Stamped Steel Covers
K50-A HEFQ459 1/2 EA $2.10
K75-A HENW401 3/4 EA 2.96
K100-A HENW666 1 EA 3.79
K200-A HEFQ463 2 EA 7.63
Blank Cast Malleable Covers
K50-CA HEGI756 1/2 EA 3.80
K75-CA HEGI758 3/4 EA 4.77
K100-CA HEGI759 1 EA 7.62
K200-CA HEGI762 2 EA 14.72
Neoprene Gaskets
GK50-N HBAM829 1/2 EA 2.34
GK75-N HBAL887 3/4 EA 2.34
GK100-N HBAM874 1 EA 3.10
GK200-N HBAM958 2 EA 4.70
Composition Fiber Gaskets
GK50-V HHBS343 1/2 EA 2.53
GK75-V HHBS344 3/4 EA 2.52
GK100-V HHBS341 1 EA 2.85
GK200-V HHBS342 2 EA 5.12
484-485.qxp 9/5/07 9:07 AM Page 485
CONDUIT BODIES & BOXES Covers
486 hdsupply.com
Conduit
Aluminum Conduit Body Cover
and Gasket Assemblies
For Rigid Conduit and IMC
Conduit bodies provide access to conductors for pulling, splicing, and
maintenance.
• Hubs have tapered pipe threads.
• Bodies assembled with covers, gaskets and screws. Packaged
complete under one Catalog Number.
• Ready to use.
Appleton®
Form 85™Covers and Gaskets
For Form 85™Unilet®Conduit Outlet Bodies
Model No. Hughes No. Conduit Size (In.) Unit List Price
Blank Stamped Aluminum Covers
K50-A HEGB206 1/2 EA $2.10
K75-A HEGB209 3/4 EA 2.96
K100-A HEGB212 1 EA 3.79
K200-A HEGB219 2 EA 7.63
Blank Cast Aluminum Covers
K50-CA HEOR140 1/2 EA 3.80
K75-CA HEGI757 3/4 EA 4.77
K100-CA HEOR165 1 EA 7.62
K200-CA HEGI761 2 EA 14.72
Neoprene Gaskets
GK50-N HBAM829 1/2 EA 2.34
GK75-N HBAL887 3/4 EA 2.34
GK100-N HBAM874 1 EA 3.10
GK200-N HBAM958 2 EA 4.70
Composition Fiber Gaskets
GK50-V HHBS343 1/2 EA 2.53
GK75-V HHBS344 3/4 EA 2.52
GK100-V HHBS341 1 EA 2.85
GK200-V HHBS342 2 EA 5.12
Model No. Hughes No. Conduit Size (In.) Unit List Price
Type LB
LB-50ACGA HCHJ318 1/2 EA $10.37
LB-75ACGA HCHJ319 3/4 EA 13.85
LB-100ACGA HCHJ320 1 EA 20.07
LB-125ACGA HCHJ321 1-1/4 EA 28.03
LB-150ACGA HCHJ322 1-1/2 EA 33.72
LB-200ACGA HCHJ323 2 EA 53.70
Type LL
LL-50ACGA HCHJ150 1/2 EA 11.76
LL-75ACGA HCHJ151 3/4 EA 13.91
LL-100ACGA HCHJ152 1 EA 20.07
LL-125ACGA HCHJ153 1-1/4 EA 28.03
LL-150ACGA HCHJ154 1-1/2 EA 33.72
LL-200ACGA HCHJ155 2 EA 53.70
Type LR
LR-50ACGA HCHJ156 1/2 EA 11.76
LR-75ACGA HCHJ157 3/4 EA 13.91
LR-100ACGA HCHJ158 1 EA 20.07
LR-125ACGA HCHJ159 1-1/4 EA 28.03
LR-150ACGA HCHJ160 1-1/2 EA 33.72
LR-200ACGA HCHJ161 2 EA 53.70
Type T
T-50ACGA HCHJ324 1/2 EA 12.55
T-75ACGA HCHJ325 3/4 EA 16.14
T-100ACGA HCHJ326 1 EA 22.32
T-125ACGA HCHJ327 1-1/4 EA 32.07
T-150ACGA HCHJ328 1-1/2 EA 39.88
T-200ACGA HCHJ329 2 EA 61.19
Type C
C-50ACGA HCHJ162 1/2 EA 12.23
C-75ACGA HCHJ313 3/4 EA 13.91
C-100ACGA HCHJ314 1 EA 20.07
C-125ACGA HCHJ315 1-1/4 EA 28.03
C-150ACGA HCHJ316 1-1/2 EA 38.85
C-200ACGA HCHJ317 2 EA 53.70
486-487.qxp 9/5/07 9:07 AM Page 486
Clamps CONDUIT SUPPORTS
hdsupply.com 487
Conduit
*Note: Some clamp applications require 2 screws, 2 nuts and 2 washers.
Carlon®
Clamps
Rigid Nonmetallic
Nonmetallic clamps offer the same chemical resistance as Carlon non-
metallic conduits for a complete, corrosion resistant system.
Cantex
Conduit Clamps
Two holds in the feet of the clamp allow mounting with screws or nails.
Steel City®- T&B
Beam Clamps for Mounting Pipe or Conduit
RC Clamp-Malleable Iron
Beam Clamps for Mounting Pipe or Conduit
PC Clamp-Malleable Iron
Model No. Hughes No. Conduit Size (In.) Unit List Price
E977DC HDWD104 1/2" (16) EA Call
E977EC HDXS617 3/4" (21) EA Call
E977FC HECN066 1" (27) EA Call
E977GC HECM381 1-1/4" (35) EA Call
E977HC HECN159 1-1/2" (41) EA Call
E977JC HECO738 2" (53) EA Call
E977KC-CAR HEVJ445 2-1/2" (63) EA Call
E977LC-CAR HEVJ446 3" (78) EA Call
E977NC-CAR HEVJ447 4" (103) EA Call
Model No. Hughes No. Conduit Size (In.) Unit List Price
5133736 HEGQ558 1/2 EA Call
5133737 HEGQ559 3/4 EA Call
5133738 HEGQ560 1 EA Call
5133733 HEGQ561 1-1/4 EA Call
5133734 HEGQ562 1-1/2 EA Call
5133735 HEGQ563 2 EA Call
Model No. Hughes No. Conduit Size (In.) Unit List Price
RC-3/8 HBJZ133 3/8 EA $3.48
RC-1/2 HEHL686 1/2 EA 2.66
RC-3/4 HAFS173 3/4 EA 2.74
RC-1 HBJZ136 1 EA 3.07
RC-1-1/4 HBJZ138 1-1/4 EA 3.91
RC-1-1/2 HBJZ140 1-1/2 EA 3.87
RC-2-SC HAFS102 2 EA 5.64
RC-2-1/2 HBJZ143 2-1/2 EA 8.09
RC-3 HBFX909 3 EA 8.49
RC-3-1/2 HBJZ144 3-1/2 EA 13.48
RC-4-SC HAWZ279 4 EA 12.74
Model No. Hughes No. Conduit Size (In.) Unit List Price
PC-3/8 HBFX904 3/8 EA $4.46
PC-1/2 HBJZ127 1/2 EA 3.93
PC-3/4 HBJZ128 3/4 EA 4.37
PC-1 HBJZ129 1 EA 4.67
PC-1-1/4 HBJZ130 1-1/4 EA 7.59
PC-1-1/2 HBJZ131 1-1/2 EA 9.58
PC-2 HGZO788 2 EA Call
PC-2-1/2 HBFX905 2-1/2 EA 16.53
PC-3 HBFX906 3 EA 17.43
PC-3-1/2 HBFX907 3-1/2 EA 20.64
PC-4 HBFX908 4 EA 22.09
486-487.qxp 9/5/07 9:07 AM Page 487
CONDUIT SUPPORTS Clamps
488 hdsupply.com
Conduit
Steel City®- T&B
Beam Clamps for Mounting Pipe or Conduit
EC Clamp-Malleable Iron
Model No. Hughes No. Conduit Size (In.) Unit List Price
EC-1/2 HBFX900 1/2 EA Call
EC-3/4 HBJZ123 3/4 EA Call
EC-1 HBFX901 1 EA Call
EC-1-1/4 HBJZ124 1-1/4 EA Call
EC-1-1/2 HBFX902 1-1/2 EA Call
EC-2 HBJZ125 2 EA Call
EC-2-1/2 HBFX903 2-1/2 EA Call
Beam Clamps –Malleable Iron
Electroplated Finish
Model No. Hughes No.
Jaw
Opening
(in.)
Base &
Back Hole
Tapping
Load
Rating
(lbs.) Unit List Price
510 HBJZ172 5/8 1/4-20 400 EA Call
511-SC HBJZ173 5/8 10-24 400 EA Call
500-SC HBQX579 15/16 1/4-20 450 EA Call
509 HBJZ171 15/16 10-24 375 EA Call
501 HBJZ167 7/8 5/16-18 800 EA Call
502 HAWF572 1 3/8-16 1300 EA Call
503-SC HBJZ168 1 1/2-13 1300 EA Call
507 HBJZ169 1-3/8 1/2-13 1700 EA Call
508 HBJZ170 2-1/8 1/2-13 1700 EA Call
Superstrut®- T&B
Pipe Supports
Universal Clamp
Model No. Hughes No.
Diameter
Range (in.)
Gauge
of Steel
Max
Load (lbs) Unit List Price
703-1/2 HBJN215 .706 –.840 16 ga. 400 EA Call
703-3/4 HAIC433 .932 –1.050 14 ga. 550 EA Call
703-1 HAIC513 1.163 –1.315 14 ga. 550 EA Call
703-1-1/4 HBJN216 1.508 –1.660 14 ga. 800 EA Call
703-1-1/2 HBJN217 1.738 –1.900 14 ga. 800 EA Call
703-2 HBJN218 2.195 –2.375 14 ga. 800 EA Call
Arlington Industries
Beam Clamps
Model No. Hughes No. UPC Code Load Rating (lbs.) Conduit Size (In.) Threaded Rod Size (inches) Unit List Price
Plated Steel
BC25 HCAA125 23250 75 LBS. 1 1/4–20 EA Call
BC38 HCAA126 23380 200 LBS. 2 3/8–16 EA Call
Malleable Iron—Plated
MBC25 HCAA333 34810 125 LBS. 1 1/4–20 EA Call
MBC25A HCAA424 42321 125 LBS. 1 10–24 EA Call
MBC26 HCAA425 42326 300 LBS. 1-1/2 5/16–18 EA Call
MBC27 HCAA426 42327 300 LBS. 2 3/8–16 EA Call
MBC28 HCAA427 42328 600 LBS. 2-1/2 1/2–13 EA Call
"List Price" refers to manufacturer's suggested list price.
Prices subject to change without notice.
488-489.qxp 9/5/07 9:08 AM Page 488
Clamps CONDUIT SUPPORTS
hdsupply.com 489
Conduit
NOTE: 2-1⁄2" thru 4" sizes also suitable for EMT.
Appleton®
Clamps and Clamp Backs
For Rigid Metal Conduit, IMC and EMT
• Used to secure long runs of rigid metal conduit, IMC and EMT.
• Malleable iron clamps and clamp backs are exceptionally rugged
and strong.
• Steel clamps offer economy and have integrally formed gussets
for excellent strength.
Standard Finish
• Malleable iron clamps and clamp backs—hot dipped galvanized.
• Steel One-hole clamps—zinc electroplate.
Cooper B-Line®
Pipe Clamps
Multi-Grip for Thinwall (EMT), IMC, Rigid Conduit or Pipe
• Safety Factor of 5
• Add PA to suffix for pre-assembled pipe clamps
• Includes Slotted Hex Head Machine Screw and Square Nut
• Material: ASTM A570 Gr. 33
• Standard finish: ZN
Model No. Hughes No.
Conduit
Size (In.)
Bolt
Diameter (In.) Unit List Price
One-Hole Clamps—Malleable Iron
CL-50MN HFAH802 1/2 1/4 EA Call
CL-75MN HFAH803 3/4 1/4 EA Call
CL-100MN HFAH804 1 1/4 EA Call
CL-125MN HFAH805 1-1/4 3/8 EA Call
CL-150MN HFAH806 1-1/2 3/8 EA Call
CL-200MN HFAH807 2 1/2 EA Call
CL-250MN HFAH808 2-1/2 1/2 EA Call
CL-300MN HFAH809 3 1/2 EA Call
CL-350MN HFAH810 3-1/2 5/8 EA Call
CL-400MN HFAH811 4 5/8 EA Call
CL-500MN HFAH812 5 5/8 EA Call
CL-600MN HFAH813 6 1 EA Call
Clamp Backs—Malleable Iron
CLB-50MN HFAH814 1/2 –EA Call
CLB-75MN HFAH815 3/4 –EA Call
CLB-100MN HFAH816 1 –EA Call
CLB-125MN HFAH817 1-1/4 –EA Call
CLB-150MN HFAH818 1-1/2 –EA Call
CLB-200MN HFAH819 2 –EA Call
CLB-250MN HFAH820 2-1/2 –EA Call
CLB-300MN HFAH821 3 –EA Call
CLB-350MN HFAH822 3-1/2 –EA Call
CLB-400MN HFAH823 4 –EA Call
CLB-500MN HFAH824 5 –EA Call
CLB-600MN HFAH825 6 –EA Call
One-Hole Clamps—Steel
CL-25 HEGI234 1/4 1/4 EA Call
CL-38 HEGI235 3/8 9/32 EA Call
CL-50 HEGI236 1/2 9/32 EA Call
CL-75 HEGI237 3/4 9/32 EA Call
CL-100 HEGI238 1 11/32 EA Call
CL-125 HEGI240 1-1/4 13/32 EA Call
CL-150 HEGI242 1-1/2 13/32 EA Call
CL-200 HEGI244 2 15/32 EA Call
CL-250 HEGI246 2-1/2 9/16 EA Call
CL-300 HEGI247 3 9/16 EA Call
CL-350 HEGI248 3-1/2 11/16 EA Call
CL-400 HEGI249 4 11/16 EA Call
Model No. Hughes No.
Size
(In.) Thickness
Outer
Diameter (In.) Unit List Price
Design Load 1 - 400, Design Load 2 - 50
B2208 HGZN801 1/2" 16 Ga. .701–.875 EA Call
B2209 HGZN802 3/4" 14 Ga. .917–1.081 EA Call
B2210 HGZN803 1" 14 Ga. 1.125–1.375 EA Call
B2211 HGZN804 1-1/4" 14 Ga. 1.500–1.691 EA Call
Design Load 1 - 600, Design Load 2 - 75
B2212 HGZN805 1-1/2" 12 Ga. 1.735–1.931 EA Call
B2213 HGZN806 2" 12 Ga. 2.192–2.400 EA Call
1600 Piece Phillips Pan Head
Screw Assortment, PV35547
• 100 of each of the following: 4 x 1/2", 4 x 1", 6 x 5/8", 6 x 3/4",
6 x 1", 6 x 1-1/4", 8 x 1/2", 8 x 5/8", 8 x 3/4", 8 x 1", 8 x 1-1/4", 10
x 5/8", 10 x 3/4", 10 x 1", 10 x 1-1/4", 10 x 1-1/2"
488-489.qxp 9/5/07 9:08 AM Page 489
For a catalog, call
800-853-0878 or
visit www.erico.com
No Time to Burn
on Your Next
Installation?
No Time to Burn
on Your Next
Installation?
Use CADDY
®
SPEED LINK.
• Time Saving – Hook, wrap, lock and you’re done!
• Cost Effective – Just one product replaces threaded
rod and associated hardware.
• Fire Rated – Carries a DIN 4102-2 F30-A fire rating of
30 minutes for 2 mm wire rope and an F60-A of 60
minutes for 3 mm wire rope at maximum working load.
• Convenient – Single packs have everything necessary
for one installation: wire rope, lock and key.
• Versatile – Objects can be hung from a variety of
angles and adjusted after installation.
CADWELD®PLUS
The Standard by which all others are measured
Reliable – CADWELD®connections
consistently perform the best in
independent IEEE®837 tests.
Innovative – CADWELD PLUS
offers easy ignition and increases
flexibility in hard-to-reach areas.
Easy to Use – CADWELD PLUS
connections require fewer parts,
no starting material and no
cumbersome tools.
Most Experienced – ERICO®
, the
recognized leader in grounding
and bonding.
CADWELD PLUS
is the ultimate
exothermic welded
connection
Space-saving
packaging ships
and stores easily
IEEE is a registered trademark of The Institute of Electrical and Electronics Engineers, Incorporated
For more information
call 800-677-9089
or visit our website
at www.erico.com
490_EC05.qxd 10/23/05 7:45 PM Page 2
Clamps CONDUIT SUPPORTS
hdsupply.com 491
Conduit
VF for vertical flange only; AF for angle flange only.
Purlin Clips
• Supports wire or rod from bar joist, C Purlin (VF14) or
Z Purlin (AF14)
• Installs from floor with VAFT tool and conduit
• Static Load Limit: VF14 160 lbs., AF14 100 lbs.
Caddy®
Beam Clamps
• Easy installation to beam flanges up to 1⁄2inches
• Built-in Smart Nut snaps directly onto 3⁄8-16 threaded rod and is
adjustable and removable
• Nut eliminates extensive threading into place
Model No. Hughes No. Description Max Load (lbs) Case Quantity Unit List Price
BC HBCZ075 Beam clamp thru 1/2" flange 100 100 EA $0.67
BCISN375 HFFS418 Beam clamp thru 1/2" flange 3/8" smart nut 100 100 EA 0.88
BC812M HAXA542 1/2" to 3/4" conduit to beam thru 1/2" flange 100 100 EA 1.21
BC16M HAXA520 1" conduit to beam thru 1/2" flange 100 100 EA 1.32
BC20M HBMJ184 1-1/4" conduit to beam thru 1/2" flange 100 100 EA 1.49
BC24M HBMJ185 1-1/2" conduit to beam thru 1/2" flange 100 50 EA 1.52
BC32M HBMJ186 2" conduit to beam thru 1/2" flange 100 50 EA 1.57
BC812MSM HBMJ199 1/2" to 3/4" conduit to beam thru 1/2" flange 25 100 EA 1.21
BC16MSM HBMJ200 1" conduit to beam thru 1/2" flange 25 100 EA 1.32
BC20MSM HBMJ201 1-1/4" conduit to beam thru 1/2" flange 25 100 EA 1.49
BC24MSM HBMJ202 1-1/4" conduit to beam thru 1/2" flange 25 50 EA 1.52
BC32MSM HBMJ203 2" conduit to beam thru 1/2" flange 25 50 EA 1.57
BC8P HBMJ187 1/2" conduit to beam thru 1/2" flange 25 100 EA 1.19
BC16P HBMJ189 1" conduit to beam thru 1/2" flange 25 100 EA 1.27
BC12P HBMJ188 3/4" conduit to beam thru 1/2" flange 25 100 EA 1.22
BC8PSM HBMJ204 1/2" conduit to beam thru 1/2" flange 15 100 EA 1.19
BC12PSM HBMJ205 3/4" conduit to beam thru 1/2" flange 15 100 EA 1.22
BC16PSM HBMJ206 1" conduit to beam thru 1/2" flange 15 100 EA 1.27
Model No. Hughes No. Description Case Quantity Unit List Price
VF14 HBMJ342 1/16" to 1/4" vertical flange for wrap wire, S hooks, bolting straps, WMX6 100 EA $0.33
VF14708 HBMJ343 1/16" to 1/4" to #8 wire or 1/4" plain rod 100 EA 0.75
VF146A HBMJ344 1/16" to 1/4" to 3/8" plain rod 100 EA 0.75
VF144TI HBMJ345 1/16" to 1/4" to 1/4" threaded rod 100 EA 75.45
VF146TI HBMJ346 1/16" to 1/4" to 3/8" threaded rod 100 EA 75.45
VF146T HBMJ347 1/16" to 1/4" to 3/8" threaded rod (nuts required) 100 EA 0.73
AF14 HBMJ349 1/16" to 1/4" Z Purlin for wrap wire, S hooks, bolting straps, WMX6 100 EA 0.33
AF14708 HBMJ350 1/16" to 1/4" to #8 wire or 1/4" plain rod 100 EA 0.75
AF146A HBMJ351 1/16" to 1/4" to 3/8" plain rod 100 EA 0.75
AF144TI HBMJ352 1/16" to 1/4" to 1/4" threaded rod 100 EA 75.45
AF146TI HBMJ353 1/16" to 1/4" to 3/8" threaded rod 100 EA 75.45
AF146T HBMJ354 1/16" to 1/4" to 3/8" threaded rod (nuts required) 100 EA 0.73
AF146T HHBS337 Installation tool for VF & AF assemblies 1 EA Call
490-491.qxp 9/5/07 9:08 AM Page 491
CONDUIT SUPPORTS Straps
492 hdsupply.com
Conduit
Carlon
ENT Bridge
The Carlon ENT bridge is designed to support long ENT runs in concrete
pour applications. This makes pulling wire/cable a snap. Installation is
easy. Simply mount the ENT bridge, using nails or screws, to the wood
deck mounting and snap the ENT into place. The bridge is designed to
hold the conduit in place while minimizing dips in the conduit over long
runs. It is manufactured out of a highly engineered thermoplastic mate-
rial to provide extra strength and durability, and can accommodate ENT
sizes 1/2", 3/4" and 1".
Steel City®- T&B
Rigid/Intermediate Grade Conduit Fittings
One Hole Straps
Steel/Zinc Plated
Model No. Hughes No. Conduit Size (In.) Unit List Price
HS-101 HBJY543 1/2" EA $0.33
HS-102 HBJY544 3/4" EA 0.40
HS-103 HBJY545 1" EA 0.82
HS-104 HBJY704 1-1/4" EA 1.28
HS-105 HBJY705 1-1/2" EA 1.51
HS-106 HBJY706 2" EA 2.57
HS-107 HBJY721 2-1/2" EA 4.06
HS-108 HBJY722 3" EA 4.52
HS-109 HBJY723 3-1/2" EA 6.84
HS-110 HBJY724 4" EA 8.55
Rigid/Intermediate Grade Conduit Fittings
Two Hole Strap
Steel/Zinc Plated
Model No. Hughes No. Conduit Size (In.) Unit List Price
HS-901 HBJY734 1/2" EA $0.20
HS-902 HBJY735 3/4" EA 0.24
HS-903 HBJY736 1" EA 0.39
HS-904 HBJY737 1-1/4" EA 0.62
HS-905 HBJY738 1-1/2" EA 0.73
HS-906 HBJY739 2" EA 0.85
HS-907 HBJY740 2-1/2" EA 1.75
HS-908 HBJY741 3" EA 2.17
HS-909 HBJY742 3-1/2" EA 2.84
HS-910 HBJY743 4" EA 3.07
Thinwall Conduit Fittings (EMT)
One Hole Snap-Straps
Steel
Model No. Hughes No. Conduit Size (In.) Unit List Price
TS-101 HAZS475 1/2" EA $0.29
TS-102 HAZT915 3/4" EA 0.43
TS-103 HBAI691 1" EA 0.72
TS-104 HBJZ016 1-1/4" EA 0.96
TS-105 HBJZ017 1-1/2" EA 1.64
TS-106 HBJZ018 2" EA 2.57
HS-107 HBJY721 2-1/2" EA 4.06
HS-108 HBJY722 3" EA 4.52
HS-109 HBJY723 3-1/2" EA 6.84
HS-110 HBJY724 4" EA 8.55
“List Price” refers to manufacturer’s suggested list price.
Prices subject to change without notice.
Model No. Hughes No. Case Quantity Unit List Price
A293DEF HFUT991 50 EA Call
492-493.qxp 9/5/07 9:09 AM Page 492
Straps CONDUIT SUPPORTS
hdsupply.com 493
Conduit
Model No. Hughes No. Conduit Size (In.) Unit List Price
TS-901 HBJZ019 1/2" EA $0.16
TS-902 HBJZ020 3/4" EA 0.19
TS-903 HBJZ021 1" EA 0.31
TS-904 HBJZ022 1-1/4" EA 0.46
TS-905 HBJZ023 1-1/2" EA 0.58
TS-906 HBJY846 2" EA 0.69
Thinwall Conduit Fittings (EMT)
Nail Strap –Steel
Kindorf®- T&B
Pipe Supports
For Rigid Conduit, IMC and Pipe
Kindorf Pipe Straps are designed to be twist inserted anywhere along
the slot side of the channel. Pipes can be placed as closely as pipe cou-
plings permit.
Steel Straps –Galv-Krom Finish
Model No. Hughes No.
Conduit
Size (In.)
Outside
Diameter (In.)
Gauge
of Steel Unit List Price
C-105-3/8 HAFP311 3/8" 0.675 14 ga. EA $2.10
C-105-1/2 HAFO768 1/2" 0.840 14 ga. EA 1.55
C-105-3/4 HAFP278 3/4" 1.050 14 ga. EA 1.72
C-105-1 HAFO486 1" 1.315 14 ga. EA 1.88
C-105-1-1/4 HAFO608 1-1/4" 1.660 14 ga. EA 2.16
C-105-1-1/2 HAFO568 1-1/2" 1.900 12 ga. EA 2.39
C-105-2 HAFO885 2" 2.375 12 ga. EA 2.59
C-105-2-1/2 HAFO981 2-1/2" 2.875 12 ga. EA 3.16
C-105-3 HAFP094 3" 3.500 12 ga. EA 3.39
C-105-3-1/2 HAFO591 3-1/2" 4.000 11 ga. EA 4.28
C-105-4 HAFP467 4" 4.500 11 ga. EA 4.66
C-105-4-1/2 HCEN360 4-1/2" 5.000 11 ga. EA 6.95
C-105-5 HBJZ241 5" 5.563 11 ga. EA 8.35
C-105-6 HBCA277 6" 6.625 11 ga. EA 9.46
C-105-8 HAWM830 8" 8.625 11 ga. EA 13.53
C-105-10 HGZO772 10" 10.750 10 ga. EA Call
C-105-12 HGZO773 12 12.750 10 ga. EA Call
Pipe Supports
For EMT
Steel –Galv-Krom Finish
Model No. Hughes No.
Conduit
Size (In.)
Outside
Diameter (In.)
Gauge
of Steel Unit List Price
C-106-3/8 HBJZ242 3/8" 0.577 14 ga. EA $2.13
C-106-1/2 HAFP907 1/2" 0.706 14 ga. EA 1.55
C-106-3/4 HAFQ199 3/4" 0.922 14 ga. EA 1.72
C-106-1 HAFP606 1" 1.163 14 ga. EA 1.88
C-106-1-1/4 HAFP804 1-1/4" 1.510 14 ga. EA 2.16
C-106-1-1/2 HAFP698 1-1/2" 1.740 12 ga. EA 2.39
C-106-2 HAFQ065 2" 2.197 12 ga. EA 2.59
Steel City®- T&B
Thinwall Conduit Fittings (EMT)
Two Hole EMT Straps
Steel
Model No. Hughes No. Conduit Size (In.) Unit List Price
N-101-SC HBJY876 1/2" EA $0.26
N-102-SC HBJY877 3/4" EA 0.29
N-103-SC HBJY878 1" EA 0.57
492-493.qxp 9/5/07 9:09 AM Page 493
CONDUIT SUPPORTS Straps
494 hdsupply.com
Conduit
Kindorf®- T&B
Universal Pipe Straps
• Fits E.M.T., I.M.C., rigid conduit
• Size range 1⁄2" thru 2"
• Can be used on 11⁄2" or 15⁄8" channel
• Saves inventory dollars
• Corrosion resistant Galv-Krom finish
• One piece construction means no assembly required
Model No. Hughes No. Conduit Size (In.) Diameter Range (in.) Gauge of Steel Unit List Price
C-200-1/2 HAXI721 1/2" .706 –.804 14 ga. EA $1.55
C-200-3/4 HAXI724 3/4" .922 –1.060 14 ga. EA 1.72
C-200-1 HAXI726 1" 1.163 –1.315 14 ga. EA 1.88
C-200-1-1/4 HAXI727 1-1/4" 1.508 –1.660 14 ga. EA 2.16
C-200-1-1/2 HAWA194 1-1/2" 1.738 –1.900 12 ga. EA 2.39
C-200-2 HAXI728 2" 2.196 –2.375 12 ga. EA 2.59
Superstrut®- T&B
Pipe Straps
For Rigid Conduit, IMC and Pipe
Superstrut Pipe Straps are designed to be twist inserted anywhere
along the slot side of the channel. Pipes can be placed as closely as
pipe couplings permit.
• Bolt head is combination slot and hex head for flexibility of attach-
ment.
• Square nut is captivated on the shoulder for easy one-handed
tightening.
• Straps are interchangeable with 11⁄2" strut, for broader application.
• Straps are shipped assembled so counting and sorting are easier.
• Pipe or conduit sizes are sown on the strap for easy identification.
Model No. Hughes No. Conduit Size (In.) Gauge of Steel Max Load (lbs) Unit List Price
702-1/2 HADI918 1/2" 14 ga. 750 EA $1.99
702-3/4 HADI939 3/4" 14 ga. 750 EA 2.25
702-1 HADJ001 1" 14 ga. 750 EA 2.42
702-1-1/4 HADJ044 1-1/4" 14 ga. 800 EA 2.88
702-1-1/2 HADJ076 1-1/2" 12 ga. 800 EA 3.15
702-2-STR HADJ118 2" 12 ga. 800 EA 3.38
702-2-1/2 HADJ259 2-1/2" 12 ga. 1000 EA 3.64
702-3 HADJ301 3" 12 ga. 1650 EA 4.07
702-3-1/2 HADJ343 3-1/2" 11 ga. 1650 EA 4.74
702-4 HADJ385 4" 11 ga. 1650 EA 5.40
702-4-1/2 HGZO804 4-1/2" 11 ga. 1650 EA Call
Arlington Industries
1-Hole AC/MC Strap
Plated Steel
Model No. Hughes No. UPC Code Conduit Size (In.) Cable Size Width (In.) Unit List Price
310 HAFU200 00310 .503–.580 14/4, 14/3, 12/4, 12/3, 10/3, 10/2, 12/2 .750 EA $0.39
311 HCAA937 84174 .200–.320 #4 and #2 bare copper .500 EA 6.64
494-495.qxp 9/5/07 9:09 AM Page 494
Straps CONDUIT SUPPORTS
hdsupply.com 495
Conduit
Arlington Industries
1-Hole EMT Straps
Plated steel, Click-on
Snap-on type. Plated steel
2-Hole EMT Straps
Plated steel, Click-on
Model No. Hughes No. UPC Code Conduit Size (In.) Width (In.) Hole Size (In.) Unit List Price
360 HALB764 00360 1/2 .562 .187 EA $0.16
361 HALB768 00361 3/4 .625 .187 EA 0.23
362 HALB774 00362 1 .688 .187 EA 0.34
363 HALB796 00363 1-1/4 .750 .258 EA 0.50
364 HALB798 00364 1-1/2 .875 .258 EA 0.57
365 HALB800 00365 2 1.000 .375 EA 0.91
356 HAID634 00356 2-1/2 .985 .345 EA 1.29
357 HAID736 00357 3 .995 .345 EA 1.49
358 HAID827 00358 3-1/2 .990 .345 EA 1.81
359 HAID940 00359 4 .995 .345 EA 2.18
Model No. Hughes No. UPC Code Conduit Size (In.) Width (In.) Hole Size (In.) Unit List Price
Standard Duty
304 HBZZ440 00304 1/2 .745 .265 EA $9.17
305 HBZZ441 00305 3/4 .750 .265 EA 0.15
Heavy-Duty
370 HAIM133 00370 1/2 .562 .250 EA 0.27
371 HAIM236 00371 3/4 .625 .250 EA 0.36
372 HAIM345 00372 1 .750 .312 EA 0.58
373 HAIM439 00373 1-1/4 .875 .375 EA 0.75
374 HAIM542 00374 1-1/2 1.000 .375 EA 1.23
375 HAIM607 00375 2 1.125 .437 EA 1.95
346 HAIN236 00346 2-1/2 1.245 .550 EA 3.57
347 HAIM850 00347 3 1.250 .550 EA 3.87
348 HAIN616 00348 3-1/2 1.250 .575 EA 6.04
349 HAIN739 00349 4 1.240 .575 EA 7.64
1950 Piece Nut, Screw
and Washer Assortment, PV35550
• 100 each machine screw nuts: 6-32 square,
8-32 Hex, 1/4-20 Hex
• 100 each split washers: # 8, #10, 1/4"
• 100 each machine screw Phillips pan head:
6-32 x 3/8", x 1", 8-32 x 1-1/4", 1/4-20 x 3/4", 50
of 1/4-20 x 1-1/4"
• 100 each SMS- Phillips pan head: 6 x 3/4', 8
x 1/2", 8 x 3/4", 10 x 3/4"
• 100 each Phillips drywall screw: 6 x 1-1/4"
• 100 each slotted Hex washer head: 10 x 1/2",
10 x 1-1/4"
• 100 each SMS-Phillips flat head: 8 x 1"
• 100 each self- tapping SMS Hex washer
head: 10 x 3/4"
494-495.qxp 9/5/07 9:09 AM Page 495
CONDUIT SUPPORTS Straps
449966hhddssuuppppllyy..ccoomm
Conduit
496 hdsupply.com
Conduit
Arlington Industries
Rigid Straps
Plated Steel, Click-on
Snap-on type. Plated steel
EMT Nail Straps
Plated Steel, Click-on
Model No. Hughes No. UPC Code
Conduit
Size (In.) Unit List Price
NS1 HCAA550 51100 1/2 EA $0.22
NS2 HCAA554 51200 3/4 EA 0.29
NS3 HCAA556 51300 1 EA 0.42
Caddy®
Colorado Jim Cable Support
• New easy-to-use locking tab
• Cable locating ribs to maintain cable separation
• Flared edges for cable protection
Model No. Hughes No. UPC Code Conduit Size (In.) Width (In.) Hole Size (In.) Unit List Price
1-Hole
340 HAIM719 00340 1/2 .625 .250 EA $0.27
341 HAIM820 00341 3/4 .750 .250 EA 0.40
342 HAIN042 00342 1 .875 .312 EA 0.65
343 HAIN145 00343 1-1/4 .875 .375 EA 0.90
344 HAIN210 00344 1-1/2 1.000 .437 EA 1.08
345 HAIN413 00345 2 1.125 .562 EA 2.11
346 HAIN236 00346 2-1/2 1.245 .550 EA 3.57
347 HAIM850 00347 3 1.250 .550 EA 3.87
348 HAIN616 00348 3-1/2 1.250 .575 EA 6.04
349 HAIN739 00349 4 1.240 .575 EA 7.64
2-Hole
350 HAID141 00350 1/2 .620 .200 EA 0.17
351 HAID223 00351 3/4 .690 .200 EA 0.17
352 HAID315 00352 1 .750 .275 EA 0.27
353 HAID439 00353 1-1/4 .865 .275 EA 0.47
354 HAID123 00354 1-1/2 .940 .275 EA 0.51
355 HAID532 00355 2 .995 .325 EA 0.70
356 HAID634 00356 2-1/2 .985 .345 EA 1.29
357 HAID736 00357 3 .995 .345 EA 1.49
358 HAID827 00358 3-1/2 .990 .345 EA 1.81
359 HAID940 00359 4 .995 .345 EA 2.18
Model No. Hughes No. Unit List Price
CJ6 HADZ998 EA $0.44
496-497.qxp 9/5/07 9:09 AM Page 496
Hangers CONDUIT SUPPORTS
hdsupply.com 497
Conduit
Steel City®- T&B
Conduit and Pipe Hangers
6H Series –With Bolt
Model No. Hughes No. Conduit Size (In.) Unit List Price
6H0-B HAEB953 3/8–1/2 EA $0.50
6H0-TB HBJZ147 3/8–1/2 EA 0.63
6H1-B HAEC007 3/4 EA 0.51
6H1-TB HBJZ149 3/4 EA 0.71
6H2-B HAEC108 1 EA 0.84
6H2-1/2-B HAEC049 - EA 1.13
6H3-SC-B HGZO786 1-1/4 EA Call
6H4-B HAEC160 1-1/2 EA 1.47
6H5-B HAEC166 2 EA 1.58
6H6-B HAEC170 2-1/2 EA 2.06
6H7-B HAEC173 3 EA 2.42
6H8-B HAFN669 3-1/2 EA 3.56
6H9-B HAFN715 4 EA 8.13
Arlington Industries
Pipe Hangers
One Piece, Nonmetallic
• Saves 25 seconds per installation…about 15.5 cents at $22.50 per
hour labor rate
• Costs the same as a steel pipe hanger with bolt and nut
• Conduit snaps into place, locking automatically
• Accommodates thinwall, rigid conduit, PVC conduit, or copper
• Mounts horizontally or vertically
• UV rated for outdoor application
• Corrosion resistant
• Listed for use in environmental air handling spaces per 2005 NEC
code requirement 300-22(c)
• 2-1/2" to 4" hangers feature an additional opening for securing pur-
poses, such as a wire tie
Model No. Hughes No. UPC Code
Conduit
Size (In.) Unit List Price
NM2005 HATJ566 54525 1/2 EA $0.52
NM2015 HATJ567 54526 3/4 EA 0.57
NM2025 HATJ560 54518 1 EA 0.78
NM2040 HATJ561 54519 1-1/2 EA 0.92
NM2045 HATJ694 54544 1-1/2 EA 1.11
NM2050 HATJ562 54520 2 EA 1.31
NM2060 HGOQ021 54521 2-1/2 EA 4.39
NM2070 HGOQ022 54522 3 EA 5.37
NM2080 HGOQ023 54523 3-1/2 EA 6.83
NM2090 HGOQ024 54524 4 EA 7.61
Pipe Hangers
Plated Steel
Porcelain Wire Holder
With solid rivet through head. Porcelain and galvanized steel.
Model No. Hughes No. UPC Code Screw Size Unit List Price
612 HALC570 00612 2-1/4 Lag EA $12.89
613 HBZZ514 00613 3/8 x 1/2 Match Screw EA 9.63
616 HAYI607 00616 2-1/4 Lag EA 12.13
617 HBZZ516 00617 3/8 x 1/2 Match Screw EA 7.01
Model No. Hughes No. UPC Code
Conduit Size
(In.) Unit List Price
With bolt and nut
2000 HBZZ636 02000 3/8 x 1/2 EA $0.52
2010 HBZZ637 02010 3/4 EA 0.57
2020 HBZZ638 02020 1 EA 0.78
2040 HBZZ641 02040 1-1/2 EA 1.11
2050 HBZZ642 02050 2 EA 1.31
2060 HBZZ643 02060 2-1/2 EA 1.71
2070 HBZZ644 02070 3 EA 1.96
2080 HBZZ645 02080 3-1/2 EA 2.10
2090 HBZZ646 02090 4 EA 5.28
With formed thread in one end of the hanger
2200 HCAA118 22000 3/8 x 1/2 EA 0.41
2210 HCAA119 22100 3/4 EA 0.46
2220 HCAA120 22200 1 EA 0.60
2230 HCAA122 22300 1-1/4 EA 0.73
2240 HCAA123 22400 1-1/2 EA 0.99
2250 HCAA124 22500 2 EA 1.19
Some products not available at all locations. Check with
your local HD Supply representative for product availability.
496-497.qxp 9/5/07 9:09 AM Page 497
CONDUIT SUPPORTS Hangers
498 hdsupply.com
Conduit
Arlington Industries
Porcelain Wire Holder
With steel clip. Fits 1-1⁄4" to 3" pipe
S-Hooks
Plated Steel
Maximum load limit 25 lbs
Model No. Hughes No. UPC Code Size Unit List Price
SH1 HAGU441 18100 1-1/4-.106 EA $0.16
SH2 HBZZ844 18200 1-1/2-.135 EA 0.30
Jack Chain
Zinc-plated steel. 100 feet per steel reel. Maximum load limit 25 lbs.
Model No. Hughes No. UPC Code Size Unit List Price
JC12 HAFO657 13120 1/2 EA $0.46
Caddy®
Conduit Hangers
• Supports conduit (EMT, Rigid, ENT, MC/AC and Aluminum) to rods
or flanges
• Can also be sued for flexile metallic tubing, armored cable,
portable cables, control tubes, communications cables, etc.
• No installation tools required
Model No. Hughes No. Conduit Size (In.) Unit List Price
KX HEGZ294 No load rating - position-
ing only.
BX $0.29
K8 HEGZ292 1/2" EMT or rigid BX Call
K12 HEGZ290 1/2" or 3/4" EMT, 3/4" Rigid BX 0.28
K16 HBGB665 1/2" or 3/4" Rigid, 3/4" or 1"
EMT
BX 0.33
K20 HBGB666 3/4" or 1" Rigid, 1" or 1-1/4"
EMT
BX 0.49
Model No. Hughes No. UPC Code Conduit Size (In.) Unit List Price
610 HAHC045 00610 1-1/4 to 3 EA $20.32
498-499.qxp 9/5/07 9:10 AM Page 498
Hangers CONDUIT SUPPORTS
hdsupply.com 499
Conduit
Caddy
Caddy Mounting Plate Brackets (Nonmetallic)
Standards: UL and cUL listed
• No sharp metal edges with new plastic design
• No installation tools required to secure bracket in the drywall
opening
• Serrated interlocking system secures tightly
• Template points on brackets eliminate multiple measurement
markings during installation
• Eliminates the need for electrical boxes on low voltage Class 2
applications
Caddy Cablecat Wide Base
Cable Support
• Single protection
• Standards: UL listed
• Wire Size (AWG): 24
• Cable Type: UTP
• Number of Pairs: 4
• Diameter (mm): 5
• Load Rating (Kg): 22
• Cost-effective alternative to expensive cable tray
• Multiple tree configurations possible
• Galvanized finish on J-hook provides smoother cable pull and
greater corrosion resistance
• Provides proper support of high-speed copper or fiber optic cable
and innerduct
• Variety of sizes and designs available to attach to virtually any
structure or sub-structure
Model No. Loop Diameter (in.) Quantity Unit List Price
CAT12 3/4 50 EA $1.01
CAT21 1-5/16 33 EA Call
CAT21SS 1-5/16 80 Box 2.82
CAT32 2 50 EA 2.02
CAT32SS 2 60 Box 3.21
CAT64 4 25 Box 3.83
CAT64SS 4 25 Box 5.02
Cablecat Pulley Kits
• CAT32PLR accepts up to 20 4-pair cables; CAT64PLR accepts up to
40 4-pair cables
• Complies with the TIA standard requirement by minimizing the pull
force on the cable
• Maintains proper bend radius and protects cable during the instal-
lation
• Kits include spring-loaded J hook, pin, wheel and retainer, link
and beam clamp
• The pulley and pin assembly can be removed after the job is com-
pleted, leaving the J-hook as a cable support
CAT-CM Cable Support System
• Specially designed U-hooks and double
J-hooks have large diameter rounded support surfaces
• Compliant with NEC®and ANSI®/EIA/TIA®structured cabling sys-
tems standards
• Hooks are UL listed
Model No. Hughes No. Description
Case
Quantity Unit List Price
CAT100CM HFFS416 Double J-hook 20 EA $2.62
CAT200CM HFFS404 U-Hook 200mm/8"
with T-nut
10 EA 2.95
CAT200CMLN HFFS408 U-Hook 200mm/8"
less nut
10 EA 3.13
CAT300CM HFFS405 U-Hook 300mm/12"
T-nut
10 EA 3.57
CAT300CMLN HFFS409 U-Hook 300mm/12"
less nut
10 EA 3.40
CATRL200CM HFFS411 Roller 200mm /8"
(includes rod and
nuts)
10 EA 2.87
CATRL300CM HFFS412 Roller 300mm /12"
(includes rod and
nuts)
10 EA 3.19
CATRT200CM HFFS414 Wire retainer
200mm /8"
50 EA 0.59
CATRT300CM HFFS413 Wire retainer
300mm /12"
50 EA 0.64
CATTBCM HFFS415 Protection Tube 30 EA 1.13
CATWMCM HFFS478 Wall Bracket 10 EA 11.37
Model No. Hughes No. Description
Case
Quantity Unit List Price
CAT32PLR HCMY582 CAT32 2" spring-loaded
J-hook, pin, wheel and
retainer, link and beam
clamp
10 EA $33.38
CAT64PLR HCMX971 CAT 64 4" spring-loaded
J-hook, pin, wheel and
retainer, link and beam
clamp
2 EA 40.43
Model No.
Hughes
Part No. Description
Standard
Box
Quantity Unit List Price
MP1P HBFZ067 Single gang 100 EA $0.88
MPAL2 HBFZ066 Double gang 100 EA 2.57
MP34P HBFZ065 3 or 4 gang 20 EA 8.00
498-499.qxp 9/5/07 9:10 AM Page 499
CONDUIT SUPPORTS Hangers
500 hdsupply.com
Conduit
Bridle rings not recommended for high performance cables
Caddy
Caddy Bridle Ring
Bridle rings can be located on beam flanges up to 3/4-inch, drop-wire,
concrete, C-purlins, Z-purlins, acoustical T-grid.
Ultimate Static Load Limit (Pounds): 50.
Speed Link
• Quickly installs as a stand-alone hanging system without drilling
into the building structure - reducing installation time
• Works with a variety of Caddy®Fasteners
• Carries a DIN 4102-2 F30-A/F60-A fire rating of 30 minutes (2 mm
wire rope) or 60 minutes (3mm wire rope) at maximum rated load
• Reduces inventory, storage space and shipping costs
• Increases installation versatility
Speed Link LD
• Ideal in lighting and other installation projects
• Cost-effective alternative to jack chain, threaded rod and associ-
ated hardware
• Safe working load of 44 pounds
• 5:1 safety factor
• Sleek low-profile locking device reduces visual impact
Model
No. Hughes No.
Dimension
A (in.) Wire Size
Standard
Box
Quantity Unit List Price
2BR12 HBMJ803 3/4 #8 (.162) 100 EA Call
2BR20 HBMJ805 1-1/4 #8 (.162) 100 EA Call
2BR32 HBMJ809 2 #8 (.162) 100 EA Call
2BRT12 HBMJ804 3/4 10-24 threaded 100 EA Call
2BRT20 HBMJ806 1-1/4 10-24 threaded 100 EA Call
2BRT32 HBMJ810 2 10-24 threaded 100 EA Call
2BRT8 HAEA043 1/2 10-24 threaded 100 EA Call Model No. Hughes No. Length (Ft.) Materials Unit List Price
Galvanized Steel
SLD15L2 HHBS272 6.6 Galvanized Steel EA Call
SLD15L5 HHBS273 16.4 Galvanized Steel EA Call
SLD15L10 HHBS269 32.8 Galvanized Steel EA Call
Stainless Steel
SLD15L10 HHBS270 6.6 Stainless Steel EA Call
SLD15L5S HHBS274 16.4 Stainless Steel EA Call
SLD15L10S HHBS271 32.8 Stainless Steel EA Call
Model No. Hughes No.
Diameter
(In.)
Length
(Ft.)
Load
Rating
(lbs.)
Case
Quantity Unit List Price
SLD2L1 HFPD935 .079 3.3 100 100 EA Call
SLD2L2 HFPD936 .079 6.6 100 100 EA Call
SLD2L3 HFPD937 .079 9.9 100 100 EA Call
SLD2L5 HFPD938 .079 16.4 100 50 EA Call
SLD2L10 HFPD939 .079 32.8 100 25 EA Call
SLD3L1 HFPD940 .118 3.3 200 100 EA Call
SLD3L2 HFPD941 .118 6.6 200 100 EA Call
SLD3L3 HFPD942 .118 9.9 200 50 EA Call
SLD3L5 HFPD943 .118 16.4 200 50 EA Call
SLD3L10 HFPD944 .118 32.8 200 25 EA Call
SLD2L1BP HGPY994 .079 3.3 100 100 EA Call
SLD2L1BP HGPY995 .079 6.6 100 100 EA Call
SLD2L1BP HGPY996 .079 9.9 100 100 EA Call
SLD2L1BP HGPY997 .118 6.6 200 100 EA Call
SLD2L1BP HGPY999 .118 9.9 200 50 EA Call
Stainless Steel
SLD3L2SS HGPY998 .118 6.6 200 100 EA Call
SLD3L2SS HGPZ000 .118 9.9 200 50 EA Call
500-501.qxp 9/5/07 9:10 AM Page 500
CONDUIT SUPPORTS
hdsupply.com 501
Conduit
Arlington Industries
Safety Plate
Flat 16 gauge steel.
• Conduit Size(In.): 1-1/2 x 2-3/4
• Length(In.): 2.750
• Width(In.): 1.500
• Hole Size(In.): .155
Caddy
Pipe Pier™Supports
• Replaces time-consuming fabrication of rooftop pipe support sys-
tems
• Reduces rooftop wear and tear
• Supports steel pipe, copper pipe and electrical conduit to roof or
floor surfaces
• Reduces installation time by eliminating on-site cutting, drilling
and measuring
Cooper B-Line®
Concrete Inserts
Angle Fittings
Model No. Hughes No. Unit List Price
B104 HGZN800 EA Call
Available Finishes on Steel: Plain (Oil Coated), Dura-Green Epoxy, Pre-Galvanized, and Hot
Dip Galvanized are standard.
Cooper B-Line®
Support Channels
• Materials: Steel
• Thickness: 14 Ga.
Model No. Hughes No. UPC Code Unit List Price
SP100 HAKW332 17100 EA Call
Model No. Hughes No.
Dimensions Height
x Width (in.) Offset Unit List Price
B54 HGZN807 13/16”H x 1-5/8”W (SH) 1, 2, 3, 4;
(S) 1; (H17/8) 1,
2, 3, 4
EA Call
Model No. Hughes No. Description
Dimensions
(In.)
Case
Quantity Unit List Price
PP50H4 HCMX982 50 lb. load
capacity per
block, pre
galvanized
10-1/2" L x
4" W x 4" H
10 EA Call
PP50H6 HCMX983 50 lb. load
capacity per
block, pre
galvanized
10-1/2" L x
4" W x 6" H
10 EA Call
PP150H4 HEQV175 150 lb. load
capacity per
block, pre
galvanized
12" L x 12"
W x 4" H
3 EA Call
PP300H4 HEQV176 300 lb. load
capacity per
block, pre
galvanized
21-1/2" L x
12" W x 4" H
3 EA Call
PP50H2AH HEQV182 50 lb. load
capacity per
block, yellow
chromate
10-1/2" L x
4" W x 2" H
10 EA Call
500-501.qxp 9/5/07 9:10 AM Page 501
CONDUIT SUPPORTS
502 hdsupply.com
Conduit
For other channels, channel nuts, and fittings see B-Line Strut Systems Catalog.
Cooper B-Line®
Support Channels
Channel Nuts
Model No. Hughes No. For Use With Thread Size Thickness Unit List Price
N228 HGZN809 B22
B24
B32
3/8"–16 3/8" for all nuts EA Call
N225 HGZN808 B22
B24
B32
1/2"–13 1/2" for N725,N225,N225WO,TN225
3/8" for N525,N525WO,TN525
EA Call
N255 HGZN810 B22
B24
B32
5/8"–11 1/2" for N7555,N255,N255WO
3/8" for N555,N555WO
EA Call
502-503.qxp 9/5/07 9:10 AM Page 502
CEMENT & FIBER FILLER
hdsupply.com 503
Conduit
Carlon®
Carlon®Cement
All-Weather ENT Blue "Quick-Set" Solvent Cement
Recommended for use with Flex-Plus®Blue™ENT (Electrical
Nonmetallic Tubing), Riser-Gard®, P&C Flex®and Carlon PVC fittings.
Up through 4" diameter.
Cementing
All Weather Quick-Set Clear Cement
Model No. Hughes No. Container Size Unit List Price
VC9983 HEIN780 Pint Dauber Top EA Call
VC9982 HEIN782 Quart Dauber Top EA Call
Appleton®
Kwiko®A Sealing Cement
For use in Sealing Fittings
Mixing Ratio: 2 parts cement to 1 part water.
Model No. Hughes No. Net Weight (oz.) Shaft Seal Unit List Price
AC1-A HAGV119 16.00 23.00 EA $9.67
AC5-A HCCO147 80.00 115.00 EA 32.09
Kwiko®A TwinPak®
Sealing Cements
For use in Sealing Fittings
Each plastic pouch contains: Pre-measured Kwiko®A cement and
Pre-measured water (in an inner bag).
Kwiko®A TwinPak®also includes adequate amount of fiber filler packed
separately.
Product No. ACK6F-A includes 5–six-ounce cement pouches. Larger
quantities available, consult factory.
Product No. ACK12F-A includes 5–twelve-ounce cement pouches.
Larger quantities available, consult factory.
Model No. Hughes No. Net Weight (oz.) Volume (cu. ft.) Unit List Price
ACK6F-A HCCO149 30.00 (Cement)
5.00 (Fiber)
25.00 EA $35.23
ACK12F-A HCCO148 60.00 (Cement)
10.00 (Fiber)
50.00 EA 65.33
Kwiko®A Sealing Cement and Fiber Filler Kits
For use in Sealing Fittings
Model No. Hughes No. Net Weight (oz.) Volume (cu. ft.) Unit List Price
AC1F01-A HBDB009 16.00 (Cement)
1.00 (Fiber)
23.00 EA $16.93
Fiber Filler
For use in Sealing Fittings
Filler is used to make dams to prevent
cement from leaking while in fluid state.
Model No. Hughes No. Net Weight (oz.) Unit List Price
F038 HBLG989 0.38 EA $4.76
F075 HBLG990 0.75 EA 7.54
F01 HBLG984 1.00 EA 10.20
F02 HBLG985 2.00 EA 16.36
F04 HBLG986 4.00 EA 34.11
F08 HBLG987 8.00 EA 59.43
F1 HBLG983 16.00 EA 89.66
Model No. Hughes No. Container Size Unit List Price
VC9992 HECO480 Quart EA Call
502-503.qxp 9/5/07 9:10 AM Page 503
© 2005 Thomas & Betts Corporation.
Built on a century of trust,
and growing every day.
For more on the full line of Steel City products, contact your local
Hughes electrical branch, call 888-862-3289 or visit www.tnb.com.
NEW!
Steel City ®Ultra-shallow
Floor Box
NEW!
Steel City®Residential
Floor Box Kit
NEW!
Steel City®Snap-in
Fitting for MC Cable
NEW!
Steel City®Hands-Free
Swivel Hanger
Steel City
®
• Red
•
Dot
®
• Superstrut
®
• Kindorf
®
504_EC05.qxd 10/25/05 11:50 AM Page 2

Navigation menu
