2CONTENTS

CONTENTS

CORDLESS POWER TOOLS

12V & 20V MAX* Chargers . . . . . . . . . . . . . . . . . . . . . . . . . . 23

12V MAX* Combo Kits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

18V Combo Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

20V MAX* Combo Kits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

36V Combo Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Adhesive Dispensers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Band Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Batteries & Chargers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Bi-Metal Cordless Bandsaw Blades . . . . . . . . . . . . . . . . . . . . . . 16

Charger/Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Circular Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Concrete Vibrator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Cut-Off Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Cut-Out Tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Drill/Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Flashlights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Floodlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Hammerdrills . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Impact Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Impact Wrenches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Instruments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Jig Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Metal Cutting Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Nailers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Reciprocating Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Right Angle Drills . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Rotary Lasers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Screwdrivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

SDS Rotary Hammers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Shears . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Vacuums . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Work Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

CORDED POWER TOOLS

Angle Grinders - Small, Medium & Large . . . . . . . . . . . . . . . . . . . 39

Band Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Biscuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Chipping Hammers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Chop Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Circular Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Compressors - Air Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Compressors - Hand Carry - Electric. . . . . . . . . . . . . . . . . . . . . . 43

Compressors - Wheeled Portable - Electric. . . . . . . . . . . . . . . . . . . 44

Cut-Off Machines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Cut-Out Tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Demolition Hammers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Die Grinders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Drills - VSR, Electronic Clutch & Specialty . . . . . . . . . . . . . . . . . . . 32

Dust Extraction for Grinders . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Dust Extraction for Large Rotary Hammers & SDS Rotary Hammers . . . . . . 37

Dust Extractor Attachments & Connectors . . . . . . . . . . . . . . . . . . . 38

Dust Extractor Vacuums . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Flooring Tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Grinder Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Grinders - Bench & Straight . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Hammerdrills . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Hand Planers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Handheld Tile Saw. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Heat Guns. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Impact Wrenches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Jig Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Laminate Trimmers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Measurer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Miter Saw Stands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Miter Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Multi-Cutter® Saw. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Multi-Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Nailers - Finish/Brad, Framing and Rooﬁng. . . . . . . . . . . . . . . . . . . 42

Nibblers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Optical Instruments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Pavement Breaker. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Plate Joiner & Plate Joiner Blade . . . . . . . . . . . . . . . . . . . . . . . 45

Polishers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Random Orbital Sanders. . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Reciprocating Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Routers & Router Accessories . . . . . . . . . . . . . . . . . . . . . . . . . 46

Sanding Pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Screwdrivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Scroll Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

SDS MAX Rotary Hammers . . . . . . . . . . . . . . . . . . . . . . . . . . 35

SDS Rotary Hammers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Shears . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Spline Rotary Hammers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Staplers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Table Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Thickness Planers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Tile Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Track Saws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

HAND TOOLS

Clamps - Bar Clamps (Small, Medium & Large) . . . . . . . . . . . . . . . . 105

Clamps - Bar Clamps (Rapid Return). . . . . . . . . . . . . . . . . . . . . . 106

Cutting Tools - 5-in-1 Hacksaw & Blades . . . . . . . . . . . . . . . . . . . 104

Cutting Tools - Flush Cut Saw . . . . . . . . . . . . . . . . . . . . . . . . . 105

Cutting Tools - Jab Saws (Folding & Standard) . . . . . . . . . . . . . . . . . 105

Cutting Tools - Multi-Purpose Saw . . . . . . . . . . . . . . . . . . . . . . . 105

Cutting Tools - Panel Saws . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Cutting Tools - Retractable, Fixed, Snap Off Knives & Blades . . . . . . . . . . 104

Flashlights - Aluminum & Headlamp . . . . . . . . . . . . . . . . . . . . . . 101

Hammers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Hex Keys (Folding Locking) . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Hex Keys (Ratcheting T Handle) . . . . . . . . . . . . . . . . . . . . . . . . 110

Marking & Layout - Chalk, Chalk Reels / Kits . . . . . . . . . . . . . . . . . 101

Marking & Layout - Levels . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Measuring Tools - Short Tapes & Long Tapes. . . . . . . . . . . . . . . . . . 100

Nail Sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Pliers & Snips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Pry Bars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Screwdriver & Screwdriver Sets . . . . . . . . . . . . . . . . . . . . . . . . 102

Snips - Aviation Snips & Tin Snips . . . . . . . . . . . . . . . . . . . . . . . 110

Staplers & Staples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Wood Chisel & Side Strike Chisel . . . . . . . . . . . . . . . . . . . . . . . 106

Wrenches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110

ACCESSORIES

Adapter - Backing Flange & Spindle . . . . . . . . . . . . . . . . . . . . . . 72

Bandsaw Blades - Bi-Metal Portable . . . . . . . . . . . . . . . . . . . . . . 97

Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Cartridge Roll Mandrels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Cartridge Rolls - Aluminum Oxide (High Performance) . . . . . . . . . . . . . 65

Construction Saw Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Diamonds - Cup Grinding Wheels (Extended Performance) . . . . . . . . . . . 68

Diamonds - Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Drilling - Concrete & Masonry . . . . . . . . . . . . . . . . . . . . . . . . . 79

Drilling - Impact Ready®. . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Drilling - Industrial Metal. . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Drilling - Metal & Wood . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Drilling - Step Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Drilling - Wood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Fastening - Impact Ready® . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Fastening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Fiber Disc Backing Pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Fiber Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Flap Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Hand Pad Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Hole Saws - Bi-Metal, Mandrels & Sets . . . . . . . . . . . . . . . . . . . . 97

Hook & Loop Backing Pads - Disc . . . . . . . . . . . . . . . . . . . . . . . 72

Jig Saw Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Mandrels - Quick Change . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Metal Cutting Saw Blades - Ferrous Metals . . . . . . . . . . . . . . . . . . 76

Non-Woven Discs, Flap Discs & Hand Pads . . . . . . . . . . . . . . . . . . 67

Paper Discs - 5" & 6" Hook & Loop Random Orbit Discs . . . . . . . . . . . . 66

Power Strip Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Polishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Precision Saw Blades - PrecisionFramingTM & PrecisionTrimTM . . . . . . . . . 74

Quick Change - Drill Drive, Rapid Load® & Sets . . . . . . . . . . . . . . . . 94

Quick Change Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Reciprocating Saw Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Rolls - Paper Rolls Aluminum Oxide . . . . . . . . . . . . . . . . . . . . . . 66

Sheets - Waterproof Sheets Silicon Carbide . . . . . . . . . . . . . . . . . . 67

Shop Rolls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Steel Circular Saw Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Type 1 Bonded Abrasives - Cutting Wheels. . . . . . . . . . . . . . . . . . . 51

Type 1 Bonded Abrasives - High Speed Wheels . . . . . . . . . . . . . . . . 53

Type 11 Bonded Abrasives - Cup Wheels . . . . . . . . . . . . . . . . . . . 58

Type 27 Bonded Abrasives - Cutting Wheels . . . . . . . . . . . . . . . . . . 54

Type 27 Bonded Abrasives - Grinding Wheels . . . . . . . . . . . . . . . . . 58

Type 27 Bonded Abrasives - Masonry Cutting & Grinding Wheels. . . . . . . . 57

Type 27 Bonded Abrasives - Metal Cutting & Grinding . . . . . . . . . . . . . 56

Type 27 Bonded Abrasives - Stainless Cutting & Grinding Wheels . . . . . . . 57

Type 27 Flap Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Type 28 Bonded Abrasives - Grinding Wheels . . . . . . . . . . . . . . . . . 58

Type 29 Flap Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Wire Brushes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Woodworking Saw Blades . . . . . . . . . . . . . . . . . . . . . . . . . . 76

STORAGE

Adjustable Leg Saw Horse . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Mobile Work Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

One Touch Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Tote with Power Tool Case . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Tote with Removable Organizer . . . . . . . . . . . . . . . . . . . . . . . . 112

Tough System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

TSTACK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111

Water Seal Tool Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Factory Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

ServiceNet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

CORDLESS POWER TOOLS

* With respect to the 20V MAX*: Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage is 18.

†Speed and runtime claims are versus other leading 18 volt lithium ion tools. Weight claim is versus DC9096.

18V BATTERIES WORK WITH ALL YOUR 18V DEWALT TOOLS.

t Delivers fast speed of

application and long run-time

t DCF610S2 Screwdriver sinks

207 2-1/2" drywall screws on

a single charge

PERFORMANCE INNOVATIVE

FEATURES

t Contoured mid-handle design

t Ideal balance

t Battery location allows tool to

stand on ﬂat surfaces

t 3 LED Illumination

t One-handed loading

t Wireless, removable

camera screen

COMPACT,

LIGHTWEIGHT

RUNTIME

SPEED LIGHTWEIGHT

* With respect to the 12V MAX*: Maximum initial battery voltage (measured without a workload) is 12 volts. Nominal voltage is 10.8.

CORDLESS POWER TOOLS

4CORDLESS POWER TOOLS

HAMMER

DRILLS

SPECIFICATIONS DC901KL DCD985M2 DCD985B DCD970KL

Volts 36V 20V MAX* 20V MAX* 18V

Max Power 750 UWO 535 UWO 535 UWO 450 UWO

# of Speed Settings 3 3 3 3

No Load Speed – – – –

Max RPM 0-400 / 0-1,200 / 0-1,600 rpm 0-575 / 0-1,350 / 0-2,000 rpm 0-575 / 0-1,350 / 0-2,000 rpm 0-500 / 0-1,250 / 0-2,000 rpm

Max BPM

0-6,800 / 0-20,400 / 0-27,200 bpm 0-9,775 / 0-22,950 / 0-34,000 bpm 0-9,775 / 0-22,950 / 0-34,000 bpm 0-8,500 / 0-21,250 / 0-34,000 bpm

Chuck Size 1/2" 1/2" 1/2" 1/2"

Chuck Type Metal, self-tightening Metal, ratcheting Metal, ratcheting Metal, ratcheting

Weight 6.7 lbs 5.2 lbs 3.9 lbs (tool only) 5.2 lbs

Charger/Batteries 1-Hour Charger / (2) 36V Lithium Ion Fast Charger / (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

Sold Separately 1-Hour Nicd/NiMH/Li-Ion charger /

(2) 18V XRP™ Lithium Ion

Includes 360˚ side handle 360˚ side handle 360˚ side handle 360˚ side handle

20V MAX* Lithium Ion Premium

3-Speed

Hammerdrill Kit

20V MAX* XR Premium

3-Speed

Hammerdrill (Tool Only)

20V MAX* Lithium Ion Compact

Hammerdrill Kit

18V XRP™ Lithium Ion 1/2" (13 mm)

Hammerdrill/Drill/Driver Kit

36V

Lithium Ion

1/2" (13 mm)

Hammerdrill/Drill/Driver Kit

**Vehicle charger

SPECIFICATIONS DCD775KL DCD775B DC725KA DCD930KX/VX**

Volts 18V 18V 18V 14.4V

Max Power 350 UWO 350 UWO 410 UWO 325 UWO

# of Speed Settings 2 2 2 3

Max RPM 0-500 / 0-1,700 rpm 0-500 / 0-1,700 rpm 0-500 / 0-1,700 rpm 0-425 / 0-1,200 / 0-1,800 rpm

Max BPM

0-8,500 / 0-29,000 bpm 0-8,500 / 0-29,000 bpm 0-8,500 / 0-29,000 bpm 0-7,225 / 0-20,400 / 0-30,600 bpm

Chuck Size 1/2" 1/2" 1/2" 1/2"

Chuck Type Metal, ratcheting Metal, ratcheting Metal, ratcheting Metal, ratcheting

Weight 4.1 lbs (tool only) 3.1 lbs (tool only) 4.9 lbs 5.7 lbs

Charger/Batteries 30-Minute Charger / (2) 18V Compact

Lithium Ion

Sold Separately 1-Hour Charger / (2) 18V 1-Hour Charger / (2) 14.4V XRP™

Includes – – – 360˚ side handle

14.4V XRP™ 1/2" (13 mm)

Hammerdrill/Drill/Driver Kit

SPECIFICATIONS DCD785C2 DCD959KX/VX** DCD950KX/VX** DCD950B

Volts 20V MAX* 18V 18V 18V

Max Power 350 UWO 420 UWO 450 UWO 450 UWO

# of Speed Settings 2 3 3 3

Max RPM 0-600 / 2,000 rpm 0-450 / 0-1,450 / 0-2,000 rpm 0-500 / 0-1,250 / 0-2,000 rpm 0-500 / 0-1,250 / 0-2,000 rpm

Max BPM

0-10,200 / 0-34,000 bpm 0-7,650 / 0-24,650 / 0-34,000 bpm 0-8,500 / 0-21,250 / 0-34,000 bpm 0-8,500 / 0-21,250 / 0-34,000 bpm

Chuck Size 1/2" 1/2" 1/2" 1/2"

Chuck Type Ratcheting Metal, ratcheting Metal, ratcheting Metal, ratcheting

Weight 3.5 lbs 6.0 lbs 6.2 lbs 3.9 lbs (tool only)

Charger/Batteries Fast Charger / (2) 20V MAX*

Lithium Ion (1.5 Ah)

1-Hour Charger /

(2) 18V XRP™

1-Hour Charger /

(2) 18V XRP™

Sold Separately

Includes On-board bit tip holder & belt hook 360˚ side handle 360˚ side handle 360˚ side handle

18V XRP™ 1/2" (13 mm)

Hammerdrill/Drill/Driver Kit

18V XRP™ 1/2" (13 mm)

Hammerdrill/Drill/Driver Kit

18V XRP™ 1/2" (13 mm)

Hammerdrill/Drill/Driver (Tool Only)

20V MAX* XR Lithium Ion Brushless

Compact

Hammerdrill Kit

SPECIFICATIONS DCD795D2

Volts 20V MAX*

Max Power 360 UWO

# of Speed Settings 2

Max RPM 0-600 / 0-2,000 rpm

Max BPM

0-10,200 / 0-34,000 bpm

Chuck Size 1/2"

Chuck Type Metal, ratcheting

Weight 3.6 lbs

Charger/Batteries Fast Charger / (2) 20V MAX* XR Lithium Ion (2.0 Ah)

Includes On-board bit tip holder & belt hook

18V Compact 1/2" (13 mm)

Hammerdrill Kit

18V Compact Lithium Ion 1/2"

(13 mm) Hammerdrill Kit

18V Compact 1/2" (13 mm)

Hammerdrill (Tool Only)

CORDLESS POWER TOOLS

DRILL/

DRIVERS

SPECIFICATIONS DCD980M2 DCD940KX DCD960KL DCD790D2

Volts 20V MAX* 18V 18V 20V MAX*

Max Power 535 UWO 450 UWO 450 UWO 360 UWO

# of Speed Settings 3332

Max RPM 0-575 / 0-1,350 / 0-2,000 rpm 0-500 / 0-1,250 / 0-2,000 rpm 0-500 / 0-1,250 / 0-2,000 rpm 0-600 / 0-2,000 rpm

Chuck Size 1/2" 1/2" 1/2" 1/2"

Chuck Type Metal, ratcheting Metal, ratcheting Metal, ratcheting Metal, ratcheting

Weight 5.2 lbs 6.2 lbs 5.2 lbs 3.5 lbs

Charger/Batteries 1-Hour Charger / (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

1-Hour Charger / (2) 18V XRP™ 1-Hour NiCd/NiMH/Li-Ion Charger /

(2) 18V XRP™ Lithium Ion

1-Hour Charger / (2) 20V MAX*

XR Lithium Ion (2.0 Ah)

Includes 360˚ side handle 360° side handle 360° side handle On-board bit tip holder & belt hook

20V MAX* Lithium Ion Premium

3-Speed

Drill/Driver Kit

20V MAX* Compact

Drill/Driver (Tool Only)

SPECIFICATIONS DCD790B DCD780C2 DCD780B DCD760KL

Volts 20V MAX* 20V MAX* 20V MAX* 18V

Max Power 360 UWO 350 UWO 350 UWO 350 UWO

# of Speed Settings 2222

Max RPM 0-600 / 2,000 rpm 0-600 / 2,000 rpm 0-600 / 2,000 rpm 0-500 / 0-1,700 rpm

Chuck Size 1/2" 1/2" 1/2" 1/2"

Chuck Type Metal, ratcheting Ratcheting Ratcheting Plastic, ratcheting

Weight 2.6 lbs (tool Only) 3.4 lbs 2.7 lbs (tool only) 4.0 lbs

Charger/Batteries Sold Separately 30-Minute Fast Charger / (2) 20V MAX*

Lithium Ion (1.5 Ah)

Sold Separately 30-Minute Charger, (2) 18V Compact Lithium Ion

Includes On-board bit tip holder & belt hook On-board bit tip holder & belt hook On-board bit tip holder & belt hook –

20V MAX* Lithium Ion

Compact Drill/Driver Kit

18V XRP™ 1/2" (13 mm)

Drill/Driver Kit

18V XRP™

Lithium Ion

1/2"

(13 mm) Drill/Driver Kit

14.4V Compact 1/2" (13 mm)

Drill/Driver Kit

SPECIFICATIONS DCD710S2 DCD910KX DC742KA DC750KA

Volts 12V MAX* 12V 12V 9.6V

Max Power 189 UWO 285 UWO 200 UWO 130 UWO

Max RPM 0-400 / 0-1,500 rpm 0-425 / 0-1,200 / 0-1,800 rpm 0-400 / 0-1,450 rpm 0-300 / 0-1,100 rpm

Chuck Size 3/8" 1/2" 3/8" 3/8"

Chuck Type Plastic, ratcheting Metal, ratcheting Plastic, ratcheting Plastic, ratcheting

Weight 2.4 lbs 5.2 lbs 3.8 lbs 3.4 lbs

Charger/Batteries Fast Charger, (2) 12V MAX*

Lithium Ion

1-Hour Charger / (2) 12V XRP™Fast Charger / (2) 12V 1-Hour Charger / (2) 9.6V

Includes (1) belt hook – – –

12V MAX* Lithium Ion 3/8"

(10 mm) Drill/Driver Kit

12V XRP™ 1/2" (13 mm)

Drill/Driver Kit

12V Compact 3/8" (10 mm)

Drill/Driver Kit

9.6V Compact 3/8" (10 mm)

Drill/Driver Kit

18V Compact

Lithium Ion

1/2"

(13 mm) Drill/Driver Kit

SPECIFICATIONS DCD760B DC720KA DCD920KX DC730KA

Volts 18V 18V 14.4V 14.4V

Max Power 350 UWO 410 UWO 325 UWO 300 UWO

# of Speed Settings 2232

Max RPM 0-500 / 0-1,700 rpm 0-500 / 0-1,700 rpm 0-425 / 0-1,200 / 0-1,800 rpm 0-400 / 0-1,450 rpm

Chuck Size 1/2" 1/2" 1/2" 1/2"

Chuck Type Plastic, ratcheting Plastic, ratcheting Metal, ratcheting Plastic, ratcheting

Weight 3.0 lbs (tool only) 4.8 lbs 5.7 lbs 4.3 lbs

Charger/Batteries Sold Separately 1-Hour Charger / (2) 18V 1-Hour Charger / (2) 14.4V XRP™1-Hour Charger / (2) 14.4V

18V Compact 1/2" (13 mm)

Drill/Driver (Tool Only)

18V Compact 1/2" (13 mm)

Drill/Driver Kit

14.4V XRP™ 1/2" (13 mm)

Drill/Driver Kit

20V MAX* XR Brushless

Compact

Drill/Driver (Tool Only)

20V MAX* XR Lithium Ion Brushless

Compact

Drill/Driver Kit

WHY DEWALT IMPACT VS. DRILL?

t 4IPSU-FOHUI

Compact to fit into tight spaces

t /P3FBDUJPOBSZ5PSRVF

When fastening with impacts

t 'BTUFS.PUPS4QFFE

For quicker fastening

t /P#JUi$BNPVUw

For fewer stripped screw heads

1/8" to 3/8" Wood Screws Cabinetry

1/8" to 3/8" Self-Tapping Screws Electrical

1/8" to 3/8" Self-Tapping Screws Installation

1/8" to 3/8" Wood Screws Carpentry

1/2" to 1-1/4" Hex-Head Self-Tappers Metal Framing

1/2" to 1-1/4" Hex-Head Self-Tappers HVAC / Sheet Metal

Bolts; 1/2" to 2" Hex-Head Self Tappers Light-Medium Assembly

1/4" to 5/8" Nut & Bolt Combo < 6" couplings

1/4" x 1-1/2" to 1/2" x 3-1/2" Lags Deck Building

5/16" x 1-1/2" to 3" Lags Garage Doors

Lug Nuts Automotive

3/4" to 1-1/4" Nut & Bolt Combo > 6" Couplings

Cordless Impact Selection Chart

Best Solution Not Optimal

DC825KA DCF895D2DCF886D2 DW059K DC800KLDCF815S2 DCF885C2

CORDLESS POWER TOOLS

6CORDLESS POWER TOOLS

CORDLESS POWER TOOLS

IMPACT

DRIVERS

20V MAX* 1/4" (6.35 mm)

Impact Driver (Tool Only)

18V Compact Lithium Ion

1/4"

(6.35 mm)

Impact Driver Kit

18V XRP™ Lithium Ion

1/4"

(6.35 mm)

Impact Driver Kit

18V XRP™

1/4"

(6.35 mm)

Impact Driver Kit

SPECIFICATIONS DCF895M2 DCF895D2 DCF895B DCF886M2

Volts 20V MAX* 20V MAX* 20V MAX* 20V MAX*

Drive Size 1/4" Hex shank push-button release 1/4" Hex shank push-button release 1/4" Hex shank push-button release 1/4" Hex shank quick release

No Load Speed 0 - 2,850 / 1,900 / 950 rpm 0 - 2,850 / 1,900 / 950 rpm 0 - 2,850 / 1,900 / 950 rpm 0 - 2,800 rpm

Impacts/Min 0 - 3,300 / 2,400 / 1,300 ipm 0 - 3,300 / 2,400 / 1,300 ipm 0 - 3,300 / 2,400 / 1,300 ipm 0 - 3,200 ipm

Torque (in-lbs) 1,500 / 900 / 500 in-lbs 1,500 / 900 / 500 in-lbs 1,500 / 900 / 500 in-lbs 1,500 in-lbs

Torque (ft-lbs) 125 ft-lbs 125 ft-lbs 125 ft-lbs 125 ft-lbs

Tool Length 5-1/4" 5-1/4" 5-1/4" 5.5"

LEDs 3333

Weight 3.6 lbs 3.0 lbs 2.2 lbs (tool only) 3.4 lbs

Charger/Batteries Fast Charger / (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

Fast Charger / (2) 20V MAX*

XR Lithium Ion (2.0 Ah)

Sold Separately Fast Charger / (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

Includes Belt hook and accessory storage Belt hook and accessory storage Belt hook and accessory storage Belt hook

20V MAX* XR Brushless

1/4" (6.35 mm) 3-Speed

Impact Driver (Tool Only)

20V MAX* XR Lithium Ion

Brushless 1/4" (6.35 mm)

3-Speed Impact Driver

20V MAX* XR Lithium Ion

Brushless 1/4" (6.35 mm)

3-Speed Impact Driver

20V MAX* XR Lithium Ion

Brushless 1/4" (6.35 mm)

Impact Driver Kit

20V MAX* Lithium Ion 1/4"

(6.35 mm) Impact Driver Kit

20V MAX* Lithium Ion 1/4"

(6.35 mm) Impact Driver Kit

SPECIFICATIONS DCF886D2 DCF886B DCF885M2 DCF885C2

Volts 20V MAX* 20V MAX* 20V MAX* 20V MAX*

Drive Size 1/4" Hex shank quick release 1/4" Hex shank quick release 1/4" Hex shank quick release 1/4" Hex shank quick release

No Load Speed 0 - 2,800 rpm 0 - 2,800 rpm 2,800 rpm 2,800 rpm

Impacts/Min 0 - 3,200 ipm 0 - 3,200 ipm 3,200 ipm 3,200 ipm

Torque (in-lbs) 1,500 in-lbs 1,500 in-lbs 1,400 in-lbs 1,400 in-lbs

Torque (ft-lbs) 125 ft-lbs 125 ft-lbs 117 ft-lbs 117 ft-lbs

Tool Length 5.5" 5.5" 5.5" 5.5"

LEDs 3333

Weight 2.9 lbs 2.1 lbs (tool only) 3.4 lbs 2.8 lbs

Charger/Batteries Fast Charger / (2) 20V MAX*

XR Lithium Ion (2.0 Ah)

Sold Separately Fast Charger / (2) 20V MAX* XR

Lithium Ion (4.0 Ah)

Fast Charger / (2) 20V MAX*

Lithium Ion (1.5 Ah)

Includes Belt hook Belt hook Belt hook Belt hook

20V MAX* XR Lithium Ion

Brushless 1/4"

(6.35 mm) Impact Driver Kit

20V MAX* XR Brushless

1/4" (6.35 mm) Impact Driver Kit

(Tool Only)

SPECIFICATIONS DCF885B DC827KL DCF826KL DC825KA

Volts 20V MAX* 18V 18V 18V

Drive Size 1/4" Hex shank quick release 1/4" Hex shank quick release 1/4" Hex shank quick release 1/4" Hex shank quick release

No Load Speed 2,800 rpm 0-2,400 rpm 0-2,400 rpm 0-2,400 rpm

Impacts/Min 3,200 ipm 0-2,700 ipm 0-2,700 ipm 0-2,700 ipm

Torque (in-lbs) 1,400 in-lbs 1,330 in-lbs 1,330 in-lbs 1,330 in-lbs

Torque (ft-lbs) 117 ft-lbs 111 ft-lbs 111 ft-lbs 111 ft-lbs

Tool Length 5.5" 5-3/4" 5-3/4" 5-3/4"

LEDs 3111

Weight 2.0 lbs (tool only) 3.7 lbs 3.1 lbs 4.6 lbs

Charger/Batteries Sold Separately 1-Hour NiCd/NiMH/Li-Ion Charger /

(2) 18V XRP™ Lithium Ion

30-Minute Charger /

(2) 18V Compact Lithium Ion

1-Hour Charger / (2) 18V XRP™

Includes Belt hook – – –

CORDLESS POWER TOOLS

8CORDLESS POWER TOOLS

IMPACT

WRENCHES

IMPACT

DRIVERS

18V XRPTM Lithium Ion 1/2"

(13 mm) Impact Wrench Kit

SPECIFICATIONS DC800KL DCF889M2 DCF889B DCF889HM2

Volts 36V 20V MAX* 20V MAX* 20V MAX*

Drive Size 1/2" Square w/ detent pin anvil 1/2" Square w/ detent pin anvil 1/2" Square w/ detent pin anvil 1/2" Square w/ hog ring anvil

Max Torque (in-lbs) 3,900 in-lbs 3,600 in-lbs 3,600 in-lbs 3,600 in-lbs

Max Torque (ft-lbs) 325 ft-lbs 300 ft-lbs 300 ft-lbs 300 ft-lbs

No Load Speed 1,400 rpm 0-1,500 rpm 0-1,500 rpm 0-1,500 rpm

Impacts/Minute 2,500 ipm 0-2,300 ipm 0-2,300 ipm 0-2,300 ipm

Switch Rocker Variable Speed Variable Speed Variable Speed

Weight 7.5 lbs 6.7 lbs 5.3 lbs (tool only) 6.7 lbs

Tool Length 10-3/4" 10-3/4" 10-3/4" 10-3/4"

Charger/Batteries 1-Hour Charger / (2) 36V Lithium Ion Fast Charger / (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

Sold Separately Fast Charger / (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

SPECIFICATIONS DCF059KL DW059K-2 DW059B DW059HK-2

Volts 18V 18V 18V 18V

Drive Size

1/2" Square w/ detent pin anvil 1/2" Square w/ detent pin anvil 1/2" Square w/ detent pin anvil

1/2" Square w/ hog ring anvil

Max Torque (in-lbs) 3,600 in-lbs 3,600 in-lbs 3,600 in-lbs 3,600 in-lbs

Max Torque (ft-lbs) 300 ft-lbs 300 ft-lbs 300 ft-lbs 300 ft-lbs

No Load Speed 0-1,650 rpm 1,650 rpm 1,650 rpm 1,650 rpm

Impacts/Minute 0-2,600 ipm 2,600 ipm 2,600 ipm 2,600 ipm

Switch Rocker Rocker Rocker Rocker

Weight 6.6 lbs 7.5 lbs 5.3 lbs (tool only) 7.5 lbs

Tool Length 10-3/4" 10-3/4" 10-3/4" 10-3/4"

Charger/Batteries 1-Hour NiCd/NiMH/Li-Ion Charger /

(2) 18V XRP™ Lithium Ion

1-Hour Charger / (2) 18V XRP™Sold Separately 1-Hour Charger / (2) 18V XRP™

36V Lithium Ion 1/2" (13 mm)

Impact Wrench Kit

18V XRPTM 1/2" (13 mm) High

Torque Impact Wrench Kit

with Hog Ring Anvil

18V XRPTM 1/2" (13 mm) High

Torque Impact Wrench Kit

with Detent Pin Anvil

18V 1/2" (13 mm) High Torque

Impact Wrench with

Detent Pin Anvil (Tool Only)

SPECIFICATIONS DC825B DC835KA DCF815S2 DC845KA

Volts 18V 14.4V 12V MAX* 12V

Drive Size 1/4" Hex shank quick release 1/4" Hex shank quick release 1-Handed loading, 1/4" hex chuck 1/4" Hex shank quick release

No Load Speed 0-2,400 rpm 0-2,400 rpm 0-2,450 rpm 0-2,400 rpm

Impacts/Min 0-2,700 ipm 0-2,700 ipm 0-3,400 ipm 0-2,700 ipm

Torque (in-lbs) 1,330 in-lbs 1,240 in-lbs 950 in-lbs 1,150 in-lbs

Torque (ft-lbs) 111 ft-lbs 103 ft-lbs 79 ft-lbs 96 ft-lbs

Tool Length 5-3/4" 5-3/4" 6-1/4" 5-3/4"

LEDs 1131

Weight 2.2 lbs (tool only) 3.9 lbs 2.3 lbs 3.6 lbs

Charger/Batteries Sold Separately 1-Hour Charger / (2) 14.4V XRP™Fast Charger / (2) 12V MAX*

Lithium Ion

1-Hour Charger / (2) 12V XRP™

Includes – – (1) Belt hook –

12V XRPTM 1/4" (6.35 mm)

Impact Driver Kit

14.4V XRPTM 1/4" (6.35 mm)

Impact Driver Kit

12V MAX* Lithium Ion

1/4" (6.35 mm) Impact Driver Kit

18V 1/4" (6.35 mm)

Impact Driver (Tool Only)

20V MAX* Lithium Ion 1/2" (13 mm)

Impact Wrench Kit with Detent

Pin Anvil

20V MAX* 1/2" (13 mm) Impact

Wrench with Detent Pin Anvil

(Tool Only)

20V MAX* Lithium Ion 1/2" (13 mm)

Impact Wrench Kit with Hog Ring Anvil

CORDLESS POWER TOOLS

IMPACT

WRENCHES

18V 1/2" (13 mm) Impact Wrench

with Detent Pin Anvil (Tool Only)

SPECIFICATIONS DW059HB DC821KA DC821B DCF880M2

Volts 18V 18V 18V 20V MAX*

Drive Size 1/2" Square w/ hog ring anvil

1/2" Square w/ detent pin anvil 1/2" Square w/ detent pin anvil

1/2" Square w/ detent pin anvil

Max Torque (in-lbs) 3,600 in-lbs 1,920 in-lbs 1,920 in-lbs 1,800 in-lbs

Max Torque (ft-lbs) 300 ft-lbs 160 ft-lbs 160 ft-lbs 150 ft-lbs

No Load Speed 1,650 rpm 0-2,100 rpm 0-2,100 rpm 0-2,300 rpm

Impacts/Minute 2,600 ipm 0-3,000 ipm 0-3,000 ipm 0-2,700 ipm

LEDs – – – 3

Weight 5.3 lbs (tool only) 5.3 lbs 2.9 lbs (tool only) 3.4 lbs

Tool Length 10-3/4" 7-5/8" 7-5/8" 5.7"

Charger/Batteries Sold Separately 1-Hour Charger / (2) 18V XRP™ Sold Separately Fast Charger / (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

SPECIFICATIONS DCF880B DCF880HM2 DCF883M2 DCF883B

Volts 20V MAX* 20V MAX* 20V MAX* 20V MAX*

Drive Size

1/2" Square w/ detent pin anvil

1/2"

Square w/

hog ring anvil 3/8"

Square w/

hog ring anvil 3/8"

Square w/

hog ring anvil

Max Torque (in-lbs) 1,800 in-lbs 1,800 in-lbs 1,560 in-lbs 1,560 in-lbs

Max Torque (ft-lbs) 150 ft-lbs 150 ft-lbs 130 ft-lbs 130 ft-lbs

No Load Speed 0-2,300 rpm 0-2,300 rpm 0-2,300 rpm 0-2,300 rpm

Impacts/Minute 0-2,700 ipm 0-2,700 ipm 0-2,700 ipm 0-2,700 ipm

LEDs 3333

Weight 2.2 lbs (tool only) 3.4 lbs 3.4 lbs 2.2 lbs (tool only)

Tool Length 5.7" 5.7" 5.7" 5.7"

Charger/Batteries Sold Separately Fast Charger / (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

Fast Charger / (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

Sold Separately

18V XRPTM 1/2" (13 mm) Impact

Wrench Kit with Detent Pin Anvil

18V 1/2" (13 mm) High Torque

Impact Wrench with

Hog Ring Anvil (Tool Only)

20V MAX* Lithium Ion 1/2"

(13 mm) Impact Wrench Kit with

Detent Pin

20V MAX* 1/2" (13 mm)

Impact Wrench with

Detent Pin (Tool Only)

20V MAX* Lithium Ion 1/2"

(13 mm) Impact Wrench Kit with

Hog Ring Anvil

20V MAX* Lithium Ion 3/8"

(9.5 mm) Impact Wrench with Hog

Ring Kit

20V MAX* 3/8" (9.5 mm)

Impact Wrench with Hog Ring

(Tool Only)

CORDLESS POWER TOOLS

10 CORDLESS POWER TOOLS

IMPACT

WRENCHES

RIGHT ANGLE

DRILLS

SPECIFICATIONS DCD740C1 DCD740B

Volts 20V MAX* 20V MAX*

Max Power 360 UWO 360 UWO

Chuck Size 3/8" 3/8"

# of Speed Settings 2 2

RPM 0-650/0-2,000 rpm 0-650/0-2,000 rpm

Chuck Type Plastic, ratcheting Plastic, ratcheting

Weight 3.8 lbs 3.0 lbs (tool only)

Charger/Batteries Fast Charger / (1) 20V MAX*

Lithium Ion (1.5 Ah) Sold Separately

Includes Belt hook, 2" Phillips bit tip Belt hook, 2" Phillips bit tip

20V MAX* Lithium Ion 3/8"

(9.5 mm)

Right Angle Drill/Driver Kit

20V MAX* 3/8"

(9.5 mm)

Right

Angle Drill/Driver (Tool Only)

SCREWDRIVERS

SPECIFICATIONS DC668KA

Volts 18V

Drive Size 1/4"

No Load Speed 0-900 / 0-2,700 rpm

Max Torque (in-lbs) 180 in-lbs

Capacity (CRS) 12-28 gauge

Weight 5.4 lbs

Charger/Batteries 1-Hour Charger / (2) 18V XRP™

Includes #2 Phillips screwdriver bit, 5/16" nut driver

18V XRP™ Light Gauge

Steel Framing Screwdriver Kit

SPECIFICATIONS DC822KL DC820KA DC820B DC823KA

Volts 18V 18V 18V 18V

Drive Size 1/2" Square w/ detent pin anvil 1/2" Square w/ detent pin anvil 1/2" Square w/ detent pin anvil 3/8" Square w/ hog ring anvil

Max Torque (in-lbs) 1,740 in-lbs 1,740 in-lbs 1,740 in-lbs 1,500 in-lbs

Max Torque (ft-lbs) 145 ft-lbs 145 ft-lbs 145 ft-lbs 125 ft-lbs

No Load Speed 0 - 2,400 rpm 0 - 2,400 rpm 0 - 2,400 rpm 0 - 2,400 rpm

Impacts/Minute 0 - 2,700 ipm 0 - 2,700 ipm 0 - 2,700 ipm 0 - 2,700 ipm

LEDs 1111

Tool Length 5-3/4" 5-3/4" 5-3/4" 5-3/4"

Weight 3.7 lbs 4.6 lbs 2.2 lbs (tool only) 4.6 lbs

Charger/Batteries 1-Hour Charger

NiCd/NiMH/Li-Ion Charger /

(2) 18V XRP

™

Lithium Ion

1-Hour Charger / (2) 18V XRP™Sold Separately 1-Hour Charger / (2) 18V XRP™

SPECIFICATIONS DC823B DCF813S2

Volts 18V 12V MAX*

Drive Size 3/8" square w/ hog ring anvil 3/8" Anvil

Max Torque (in-lbs) 1,500 in-lbs 1,150 in-lbs

Max Torque (ft-lbs) 125 ft-lbs 96 ft-lbs

No Load Speed 0-2,400 rpm 0-2,450 rpm

Impacts/Minute 0-2,700 ipm 0-3,400 ipm

LEDs 1 3

Tool Length 5-3/4" 6-1/4"

Weight 2.2 lbs (tool only) 2.3 lbs

Charger/Batteries Sold Separately Fast Charger / (2) 12V MAX*

Lithium Ion

(continued on next page)

18V XRPTM Lithium Ion 1/2"

(13 mm) Impact Wrench

18V XRPTM 1/2" (13 mm)

Impact Wrench Kit

18V 1/2" (13 mm)

Impact Wrench (Tool Only)

18V XRPTM 3/8" (9.5 mm)

Impact Wrench Kit

18V 3/8" (9.5 mm)

Impact Wrench (Tool Only)

12V MAX* Lithium Ion

3/8" (9.5 mm) Impact Wrench Kit

CORDLESS POWER TOOLS

SCREWDRIVERS

SPECIFICATIONS DC520KA DCF610S2 DW920K-2

Volts 18V 12V MAX* 7.2V

Drive Size 1/4" 1/4" 1/4" Hex

No Load Speed 0 - 900 / 0 - 2,900 rpm 0 - 1,050 rpm 0 - 500 rpm

Chuck – 1-Handed Loading, 1/4" Hex Chuck 1/4" Hex chuck

Max Torque (in-lbs) 180 in-lbs – 80 in-lbs

Max Power – 160 UWO –

Capacity (CRS) 12 gauge – –

LEDs – 3 –

Length – 6-1/4" –

Weight 5.1 lbs 2.2 lbs 3.5 lbs

Charger/Batteries 1-Hour Charger / (2) 18V XRP™Fast Charger / (2) 12V MAX* Lithium Ion 1-Hour Charger / (2) 7.2V

Includes Bit tip / magnetic holder, drywall nosepiece,

& TEKS® nosepiece

(1) Belt hook –

18V XRP™ 1/4" (13 mm)

Drywall/Deck Screwdriver Kit

7.2V 1/4" (6.35 mm)

Two-Position Screwdriver Kit

12V MAX* Lithium Ion

1/4" (13 mm) Screwdriver Kit

CORDLESS POWER TOOLS

12 CORDLESS POWER TOOLS

SDS ROTARY

HAMMERS

SPECIFICATIONS DC233KLDH DC233KL DCH253M2 DCH253B

Volts 36V 36V 20V MAX* 20V MAX*

Chuck Type SDS Plus SDS Plus SDS Plus SDS Plus

No Load Speed 0 - 1,150 rpm 0 - 1,150 rpm 0 - 1,200 rpm 0 - 1,200 rpm

Blows/Min 0 - 4,400 bpm 0 - 4,400 bpm 0 - 4,500 bpm 0 - 4,500 bpm

Impact Energy 1.9 ft-lbs 1.9 ft-lbs 1.7 ft-lbs 1.7 ft-lbs

Vibration Measurement 8.5 m/s28.5 m/s26.9 m/s26.9 m/s2

Vibration Control Yes Yes - SHOCKS™Yes - SHOCKS™Yes - SHOCKS™

Chipping Yes Yes Yes Yes

Concrete Optimum 5/32" - 5/8" 5/32" - 5/8" 5/32 - 1/2" 5/32 - 1/2"

Weight 7.8 lbs 7.8 lbs 6.4 lbs 5.5 lbs (tool only)

Charger/Batteries 1-Hour Charger / (2) 36V Lithium Ion 1-Hour Charger / (2) 36V Lithium Ion Fast Charger / (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

Sold Separately

Includes D25302DH dust extraction system, and 360˚

side handle with depth rod

360˚ side handle with depth rod 360˚ side handle with depth rod 360˚ side handle with depth rod

SPECIFICATIONS DC212KL DC212KA DC212B

Volts 18V 18V 18V

Chuck Type SDS Plus SDS Plus SDS Plus

No Load Speed 0 - 1,100 rpm 0 - 1,100 rpm 0 - 1,100 rpm

Blows/Min 0 - 4,100 bpm 0 - 4,100 bpm 0 - 4,100 bpm

Impact Energy 1.7 ft-lbs 1.7 ft-lbs 1.7 ft-lbs

Vibration Measurement 8.0 m/s28.0 m/s28.0 m/s2

Vibration Control Yes - SHOCKS™Yes - SHOCKS™Yes - SHOCKS™

Chipping No No No

Concrete Optimum 5/32 - 1/2" 5/32 - 1/2" 5/32 - 1/2"

Weight 6.7 lbs 7.6 lbs 5.2 lbs (tool only)

Charger/Batteries 1-Hour Charger / (2) 18V XRP™ Lithium Ion 1-Hour Charger / (2) 18V XRP™Sold Separately

Includes 360˚ side handle with depth rod 360˚ side handle with depth rod 360˚ side handle with depth rod

18V XRP™ 7/8"

(22 mm) SDS Hammer Kit

SEE PAGES 34 - 35 FOR

ADDITIONAL AVAILABILITY

20V MAX* Lithium Ion SDS 3-Mode

Rotary Hammer Kit

20V MAX* SDS 3-Mode

Rotary Hammer (Tool Only)

36V Lithium Ion 1" (25 mm) SDS

Rotary Hammer Kit

36V Lithium Ion SDS Rotary Hammer

Kit and Dust Extraction System

CUT-OUT

TOOL

SPECIFICATIONS DC550KA DC550B

Volts 18V 18V

No Load Speed

26,000 rpm 26,000 rpm

Collet Diameter 1/4", 1/8" 1/4", 1/8"

Adjustable Guide Yes Yes

Weight 4.5 lbs 2.1 lbs (tool only)

Charger/Batteries 1-Hour Charger / (2) 18V XRP™Sold Separately

Includes

(1) General Purpose Bit,

(1) Drywall Cutting Bit, 1/4" & 1/8" Collets

(1) General Purpose Bit,

(1) Drywall Cutting Bit, 1/4" & 1/8" Collets

18V Cut-Off Tool

(Tool Only)

18V Cut-Off

Tool Kit

18V 7/8" (22 mm) SDS Hammer

(Tool Only)

18V XRP™ Lithium Ion 7/8"

(22 mm) SDS Rotary Hammer Kit

CORDLESS POWER TOOLS

JIG SAWS

CIRCULAR

SAWS

METAL

CUTTING

SAWS

SPECIFICATIONS DC300K DCS391M1 DCS391B

Volts 36V 20V MAX* 20V MAX*

No Load Speed 4,000 rpm 3,700 rpm 3,700 rpm

Blade Diameter 7-1/4" 6-1/2" 6-1/2"

Bevel Capacity 0° – 50° 0° – 50° 0° – 50°

Depth of Cut at 45˚ 1-5/8" 1-5/8" 1-5/8"

Depth of Cut at 90˚ 2-7/16" 2-1/4" 2-1/4"

Weight 9.9 lbs 8.3 lbs 7.0 lbs (tool only)

Charger/Batteries 1-Hour Charger / (1) 36V Lithium Ion Fast Charger, (1) 20V MAX*

XR Lithium Ion (4.0 Ah)

Sold Separately

Includes 7-1/4" Carbide tipped blade Carbide tipped circular saw blade Carbide tipped circular saw blade

SPECIFICATIONS DCS390L DC390K DC390B

Volts 18V 18V 18V

No Load Speed

3,700 rpm

3,700 rpm 3,700 rpm

Blade Diameter 6-1/2" 6-1/2" 6-1/2"

Bevel Capacity 0° – 50° 0° – 50° 0° – 50°

Depth of Cut at 45˚ 1 - 5/8" 1 - 5/8" 1 - 5/8"

Depth of Cut at 90˚ 2-1/4" 2-1/4" 2-1/4"

Weight 7.8 lbs 8.7 lbs 6.3 lbs (tool only)

Charger/Batteries 1-Hour Charger / (1) 18V XRP™ Lithium Ion 1-Hour Charger / (1) 18V XRP™Sold Separately

Includes 6-1/2" 16 tooth carbide tipped bade,

blade wrench

6-1/2" 16 tooth carbide tipped bade, blade wrench 6-1/2" 16 tooth carbide tipped blade,

blade wrench

SPECIFICATIONS DCS373M2 DCS373B DCS372KA DCS372B

Volts 20V MAX* 20V MAX* 18V 18V

No Load Speed

3,700 rpm 3,700 rpm

Blade DIameter 5-1/2" 5-1/2" 5-1/2" 5-1/2"

Depth of Cut at 90˚ 1-11/16" 1-11/16" 1-11/16" 1-11/16"

Weight 8.3 lbs 7.0 lbs (tool only) 9.2 lbs 6.8 lbs (tool only)

Charger/Batteries Fast Charger, (2) 20V MAX*

XR Lithium Ion (4.0 Ah)

Sold Separately 1-Hour Charger / (2) 18V XRP™Sold Separately

Includes 5-1/2" carbide tipped bade 5-1/2" carbide tipped bade 5-1/2" carbide saw blade 5-1/2" carbide saw blade

SPECIFICATIONS DCS330L DC330K DC330B DCS331M1 DCS331B

Volts 18V 18V 18V 20V MAX* 20V MAX*

Strokes/Min 0 - 3,000 spm 0 - 3,000 spm 0 - 3,000 spm 0 - 3,000 spm 0 - 3,000 spm

Stroke Length 1" 1" 1" 1" 1"

Keyless Blade Clamp Yes Yes Yes Yes Yes

Dust Blower Yes Yes Yes Yes Yes

Weight 6.6 lbs 7.5 lbs 5.1 lbs (tool only) 6.8 lbs 5.4 lbs (tool only)

Charger/Batteries 1-Hour Charger / (1) 18V XRP™

Lithium Ion

1-Hour Charger / (1) 18V XRP™Sold Separately Fast Charger, (1) 20V MAX*

XR Lithium Ion (4.0 Ah)

Sold Separately

Includes Jig saw blade Jig saw blade – Jig saw blade Jig saw blade

18V XRP™ Jig Saw Kit

w/ Keyless Blade Change

18V Jig Saw w/ Keyless Blade

Change (Tool Only)

20V MAX* Lithium Ion

Jig Saw Kit

20V MAX*

Jig Saw (Tool Only)

18V XRP™ Lithium

Ion Jig Saw Kit

18V XRP™ Lithium Ion 6-1/2"

(165 mm) Circular Saw Kit

20V MAX* Lithium Ion 5-1/2"

(127 mm) Metal Cutting

Circular Saw Kit

18V XRP™ 6-1/2" (165 mm)

Circular Saw Kit

20V MAX* 5-1/2"

(127 mm) Metal Cutting Circular

Saw (Tool Only)

18V 6-1/2" (165 mm)

Circular Saw (Tool Only)

18V Lithium Ion 5-1/2"

(127 mm) Metal Cutting

Circular Saw

18V 5-1/2" (127 mm) Metal

Cutting Circular Saw (Tool Only)

20V MAX* Lithium Ion 6-1/2"

(165 mm) Circular Saw Kit

20V MAX* 6-1/2" (165 mm)

Circular Saw (Tool Only)

36V Lithium Ion 7-1/4" (186 mm)

Circular Saw Kit

DCS380M1

CORDLESS POWER TOOLS

14 CORDLESS POWER TOOLS

RECIPROCATING

SAWS

SPECIFICATIONS DC305K DCS380M1 DCS380B DCS385L

Volts 36V 20V MAX* 20V MAX* 18V

Stroke/Min 0-3,000 spm 0-3,000 spm 0-3,000 spm 0-3,000 spm

Stroke Length 1-1/8" 1-1/8" 1-1/8" 1-1/8"

Keyless Blade Clamp Yes, 4-position Yes, 4-position Yes, 4-position Yes, 4-position

Adjustable Shoe Yes Yes Yes Yes

Electric Brake Yes Yes Yes Yes

Weight 8.4 lbs 7.3 lbs 6.0 lbs (tool only) 7.2 lbs

Charger/Batteries 1-Hour Charger / (1) 36V Lithium Ion Fast Charger / (1) 20V MAX* XR Lithium Ion (4.0 Ah) Sold Separately 1-Hour Charger / (1) 18V XRP™ Lithium Ion

SPECIFICATIONS DC385K DC385B DCS310S1

Volts 18V 18V 12V MAX*

Keyless Blade Clamp Yes, 4-position Yes, 4-position Yes

Stroke/Min 0-3,000 spm 0-3,000 spm 0-2,700 spm

Stroke Length 1-1/8" 1-1/8" 9/16"

Electric Brake Yes Yes Yes

Weight 8.2 lbs 5.8 lbs (tool only) 3.1 lbs

Charger/Batteries 1-Hour Charger / (1) 18V XRP™Sold Separately Fast Charger / (1) 12V MAX*

Lithium Ion

18V XRP™

Reciprocating Saw Kit

36V Lithium Ion

Reciprocating Saw Kit

20V MAX* Lithium Ion

Reciprocating Saw Kit

20V MAX* Reciprocating Saw

(Tool Only)

18V XRP™ Lithium Ion

Reciprocating Saw Kit

18V Reciprocating

Saw (Tool Only)

12V MAX* Lithium Ion Pivot

Reciprocating Saw Kit

CONCRETE

VIBRATOR

SPECIFICATIONS DC530KA DC530B

Volts 18V 18V

Vibrator Diameter 1-1/8"

1-1/8"

Shaft Length 4' 4'

Vibrations per Minute 14,000 vpm 14,000 vpm

Weight 9.3 lbs 7.0 lbs (tool only)

Charger/Batteries 1-Hour Charger / (2) 18V XRP™Sold Separately

18V XRP™ Pencil

Vibrator Kit

18V Pencil

Vibrator (Tool Only)

4-Position

Blade Clamp

Allows for flush

cutting and

increased positional

versatility with tool-

free blade changes

Variable Speed

Trigger with

0-3000 SPM

Provides increased

blade control and

faster cut speeds

1-1/8" (28.6 mm)

Stroke Length

Delivers a fast

cutting speed

Adjustable Shoe

Extends blade life

and allows depth of

cut control

CORDLESS POWER TOOLS

NAILERS

SPECIFICATIONS DCN690M1 DCN690B DC628K

Volts 20V MAX* 20V MAX* 18V

Operating Mode Bump & Sequential Bump & Sequential Bump & Sequential

Nailing Rate 2 nails/sec 2 nails/sec 4-5 nails/sec

Nail Diameter/Type .113 - .131 gauge .113 - .131 gauge 15 ga. DA type gauge

Mag. Angle/Capacity 33°/ 55 nails 33°/55 nails 34°/ 110 nails

Nail Length Capacity 2" - 3-1/2" 2" - 3-1/2" 1-1/4" - 2-1/2"

Magazine Loading Lock & Load Lock & Load Rear - load

Integrated Belt Hook Yes Yes Yes

Tool-Free Jam Cleaning No No Yes

Tool-Free Depth Adj. Yes Yes Yes

Weight 9.1 lbs 7.7 lbs (tool only) 8.9 lbs

Charger/Batteries Fast Charger / (1) 20V MAX* XR Lithium Ion (4.0 Ah) Sold Separately 1-Hour Charger / (1) 18V XRP™

Includes No-mar tip – No-mar tip, reversible belt hook, DEWALT safety glasses

SPECIFICATIONS DC618K DC616K DC608K DC608B

Volts 18V 18V 18V 18V

Operating Mode Bump & Sequential Bump & Sequential Bump & Sequential Bump & Sequential

Nailing Rate 4-5 nails/sec 4-5 nails/sec 4-5 nails/sec 4-5 nails/sec

Nail Diameter/Type 16 gauge 16 gauge 18 gauge 18 gauge

Mag. Angle/Capacity 20°/ 110 nails Straight/ 110 nails Straight/ 110 nails Straight/ 110 nails

Nail Length Capacity 1-1/4" - 2-1/2" 1-1/4" - 2-1/2" 5/8" - 2" 5/8" - 2"

Magazine Loading Rear - load Rear - load Side - load Side - load

Integrated Belt Hook Yes Yes Yes Yes

Tool-Free Jam Cleaning Yes Yes Yes Yes

Tool-Free Depth Adj. Yes Yes Yes Yes

Weight 8.5 lbs 8.5 lbs 7.4 lbs 7.4 lbs (tool only)

Charger/Batteries 1-Hour Charger / (1) 18V XRP™ 1-Hour Charger / (1) 18V XRP™ 1-Hour Charger / (1) 18V XRP™ Sold Separately

Includes No-mar tip, reversible belt hook, DEWALT safety glasses No-mar tip, reversible belt hook, DEWALT safety glasses Reversible belt hook, DEWALT safety glasses Reversible belt hook, DEWALT safety glasses

18V XRP™ 1-1⁄4" - 2-1⁄2"

(31.7 mm - 63.5 mm) 15 Gauge

34° Angled Finish Nailer Kit

18V

XRP™

1-1⁄4" - 2-1⁄2"

(31.7 mm - 63.5 mm)

16 Gauge 20°

Angled Finish Nailer Kit

20V MAX* XR

Lithium Ion

Brushless Framing Nailer Kit

20V MAX* XR

Brushless

Framing Nailer

(Tool Only)

18V

XRP™

1-1⁄4" - 2-1⁄2"

(31.7 mm - 63.5 mm)

16 Gauge Straight Finish Nailer Kit

18V XRP™ 5/8

- 2

(15.8 mm - 50.8 mm)

18 Gauge Straight Brad Nailer Kit

18V 5/8

- 2

(15.8 mm - 50.8 mm) 18 Gauge

Straight Brad Nailer (Tool Only)

SHEARS

CUT-OFF

TOOLS

SPECIFICATIONS DC495B DC490KA DC490B

Volts 18V 18V 18V

Stroke/Min 0-2,300 spm 0-2,300 spm 0-2,300 spm

Min. Cutting Radius 1" 5.5" 5.5"

Capacity in Steel 18 Gauge 18 Gauge 18 Gauge

Weight 3.7 lbs (tool only) 6.1 lbs 3.7 lbs (tool only)

Charger/Batteries Sold Separately 1-Hour Charger / (2) 18V XRP™ Sold Separately

Includes Blade wrench Blade wrench Blade wrench

SPECIFICATIONS DC415KL DCG412M2 DCG412B

Volts 36V 20V MAX* 20V MAX*

No Load Speed 6,500 rpm 6,500 rpm 6,500 rpm

Spindle Lock Yes Yes Yes

Spindle Thread 5/8" - 11 5/8" 5/8"

Weight 7.2 lbs 6.5 lbs 5.1 lbs (tool only)

Charger/Batteries 1-Hour Charger / (2) 36V Lithium Ion Fast Charger / (2) 20V MAX* XR Lithium Ion (4.0 Ah) –

Includes

Type 1 guards, Type 27 guard, Wrench, (2) matched flanges, 2-position side handle

and 4-1/2" cutting wheel

Type 1 guards, Wrench and 2-position side handle Type 1 guards, Wrench, and 2-position side handle

18V 18 Gauge

Off-Set Shear (Tool Only)

20V MAX* Lithium Ion

4-1/4" (114 mm) Cut-Off Tool Kit

18V 18 Gauge Swivel

Head and Shear

18V 18 Gauge Swivel

Head and Shear (

Tool Only

)

20V MAX* 4-1/4"

(114 mm) Cut-Off Tool (Tool Only)

36V Lithium Ion 4-1/2"

(114 mm) Cut-Off Tool Kit

(continued on next page)

CORDLESS POWER TOOLS

16 CORDLESS POWER TOOLS

ADHESIVE

DISPENSERS

SPECIFICATIONS DC547B DC546B DC545K DC545B

Volts 18V 18V 18V 18V

Lbs of Force 650 650 650 650

Auto Reverse Yes Yes Yes Yes

"Set & Forget" Speed Control Yes Yes Yes Yes

Capacity 300 ml & 600 ml sausage packs 29 oz, & quart size cartridges 10 oz, 1/10 gal, &

300 ml - 310 ml cartridges

10 oz, 1/10 gal, &

300 ml - 310 ml cartridges

Max. Speed 25 in/min 25 in/min 25 in/min 25 in/min

Weight 4.7 lbs (tool only) 5.5 lbs (tool only) 6.8 lbs 4.6 lbs (tool only)

Charger/Batteries Sold Separately Sold Separately 1-Hour Charger / (1) 18V Sold Separately

18V Adhesive

Dispenser - 10 oz

18V Adhesive

Dispenser - 300 ml (Tool Only)

18V Adhesive

Dispenser - 10 oz (Tool Only)

18V Adhesive

Dispenser - 29 oz (Tool Only)

CUT-OFF

TOOLS

SPECIFICATIONS DC411KA DC411B

Volts 18V 18V

No Load Speed

6,500 rpm 6,500 rpm

Spindle Lock Yes Yes

Spindle Thread 5/8" - 11 5/8" - 11

Weight 7.0 lbs 4.6 lbs (tool only)

Charger/Batteries 1-Hour Charger / (2) 18V XRP™ Sold Separately

Includes

Type 1 guards, Wrench, (2) matched flanges,

2-position side handle and 4-1/2" cutting wheel

Type 1 guards, wrench, (2) matched flanges and

2-position side handle

18V Cut-Off Tool

(Tool Only)

18V XRP™ Cut-Off Tool Kit

BAND

SAWS

SPECIFICATIONS DCS370L DCS370K DCS370B

Volts 18V 18V 18V

Ft/Min 570 fpm 570 fpm 570 fpm

Blade Length 32-7/8" 32-7/8" 32-7/8"

Max Capacity 2-1/2" 2-1/2" 2-1/2"

Tool Length 15" 15" 15"

Weight 9.2 lbs 10 lbs 7.7 lbs (tool only)

Charger/Batteries 1-Hour Charger / (1) 18V XRP™ Lithium Ion 1-Hour Charger / (1) 18V XRP™Sold Separately

Includes 14/18 blade, blade tracking wrench 14/18 blade, blade tracking wrench 14/18 blade, blade tracking wrench

18V XRP™ Lithium Ion

Band Saw

18V XRP™ Band Saw 18V Band Saw (Tool Only)

BI-METAL CORDLESS

BANDSAW BLADES

CAT # TPI THICKNESS LENGTH HEIGHT PACK

DW3982C 14 .020" 32-7/8" 1/2" 3

DW3983C 18 .020" 32-7/8" 1/2" 3

DW3984C 24 .020" 32-7/8" 1/2" 3

DW3986C 14/18 .020" 32-7/8" 1/2" 3

(continued)

WORKLIGHTS

CORDLESS POWER TOOLS

18V Flexible

Floodlight (Tool Only)

18V Fluorescent

Area Light (Tool Only)

14.4V Pivoting

Head Flashlight (Tool Only) LED Replacement Bulb

18V Pivoting

Head Flashlight (Tool Only)

SPECIFICATIONS DC020 DW906 DCL510 DCL0900

Volts / Power Source 12-18V NiCd/NiMH/Li-Ion Batteries

or AC/DC Power

14.4V 12V MAX* 9.6V - 36V

Bulb 38W fluorescent Xenon bulb LED LED

Brightness 2700 lumens – 130 lumens 110 lumens

Run-Time Up to 1 hr Up to 3 hrs 4 hrs Up to 4 hrs

Weight 6.0 lbs 0.5 lbs 0.5 lbs 0.2 lbs

Charger/Batteries Sold Separately Sold Separately Sold Separately Sold Separately

SPECIFICATIONS DCL040 DW919 DW908 DC527

Volts 20V MAX* 18V 18V 18V

Bulb LED Xenon bulb Xenon bulb 13 Watt fluorescent

Brightness 110 lumens – – –

Run-Time 11 hrs Up to 3 hrs 3 hrs Up to 3.5 hrs

Weight 1.0 lbs 0.5 lbs 0.5 lbs 1.2 lbs

Charger/Batteries Sold Separately Sold Separately Sold Separately Sold Separately

Cordless/Corded Worklight 12V MAX* Lithium Ion LED

Worklight (Tool Only)

20V MAX* LED Worklight

(Tool Only)

INSTRUMENTS

SPECIFICATIONS DCT410S1 DCT411S1 DCT412S1

Volts 12V MAX* 12V MAX* 12V MAX*

Camera Head Diameter 17 mm 9 mm 5.8 mm

Cable Length 3' waterproof 3' waterproof 3' waterproof

Screen Size 3.5" 3.5" 3.5"

Resolution 320x480 dpi 320x480 dpi 320x480 dpi

Zoom 3X 3X 3X

Charger/Batteries Fast Charger / (1) 12V MAX* Lithium Ion Fast Charger / (1) 12V MAX* Lithium Ion Fast Charger / (1) 12V MAX* Lithium Ion

Includes 17 mm - 3' camera cable, hook, & magnet 9 mm - 3' camera cable, hook, magnet, & mirror 5.8 mm - 3' camera cable

12V MAX* Lithium Ion (17 mm) Inspection

Camera with Wireless Screen Kit

12V MAX* Lithium Ion (9 mm) Inspection

Camera with Wireless Screen Kit

12V MAX* Lithium Ion (5.8 mm) Inspection

Camera with Wireless Screen Kit

12V MAX* Lithium Ion Imaging

Thermometer Kit

INSTRUMENTS

SPECIFICATIONS DCT418S1

Volts 12V MAX*

Display Type Color LCD

Objects Detected Wood, Ferrous Metal, Non-Ferrous

Metal, PVC and Live Electric

Screen Size 3.5"

Resolution 320x240 dpi

Languages English, Spanish, French

Charger/Batteries Fast Charger / (1) 12V MAX* Lithium Ion

12V MAX* Lithium Ion Hand

Held Radar Scanner Kit

SPECIFICATIONS DCT414S1 DCT416S1

Volts 12V MAX* 12V MAX*

Temperature Range -20º F to 932º F (-29º C to 500º C) 14º F to 480º F (-10º C to 250º C)

Field of View; Distance, Spot (D:S) 12:1 (IFOV) 1" @ 39.3" (25 mm @ 1m)

Accuracy +/-1.5% or +/- 1.5º C, whichever is greater,

assumes ambient

Below 200º F, +/-3.6º F, Above 200º F, +/-2%,

assumes ambient operating temperature

Charger/Batteries Fast Charger / (1) 12V MAX* Lithium Ion Fast Charger / (1) 12V MAX* Lithium Ion

Includes – Micro SD card, Report writing software

12V MAX* Lithium Ion Infrared

Thermometer Kit

CORDLESS POWER TOOLS

18 CORDLESS POWER TOOLS

ROTARY

LASERS

SPECIFICATIONS DW079KDT DW079KI DW079KD DW074KDT

Power Supply 9.6V-18V DEWALT batteries 9.6V-18V DEWALT batteries 9.6V-18V DEWALT batteries (2) D Alkaline batteries

Accuracy per 100 ft. 1/8" 1/8" 1/8" 1/4"

Rotation Speed 0, 60, 250, & 600 rpm 0, 60, 250, & 600 rpm 0, 60, 250, & 600 rpm 0, 60, & 600 rpm

Self-Leveling Range ±5° ±5° ±5° ±5°

Indoor Visibility Range 200' (dia) 200' (dia) 200' (dia) 100' (dia)

Range with Detector 2,000' (dia) 2,000' (dia) 2,000' (dia) 600' (dia)

Laser Class IIIa (<5 mW) at 635 nm IIIa (<5 mW) at 635 nm IIIa (<5 mW) at 635 nm IIIa (<5 mW) at 635 nm

Slope (Single Axis) Manual Slope ±5° Manual Slope ±5° Manual Slope ±5° –

Charger/Batteries 1-Hour Charger / (1) 18V 1-Hour Charger / (1) 18V 1-Hour Charger / (1) 18V –

Includes Wall mount, wireless (IR) remote control,

laser target card, laser enhancement glasses,

construction tripod - DW0736

Wall mount,

wireless (IR) remote control, laser

target card, laser enhancement glasses

Wall mount,

wireless (IR) remote control, laser

target card, laser enhancement glasses, digital

laser detector

DW0742 Detector and clamp, Target card,

DW0740 Wall mount, DW0737 tripod, DW0748

8' grade rod, (2) D Alkaline

batteries, & (1) 9V battery

SPECIFICATIONS DW074KD DW089K DW087K DW083K

Power Supply (2) D Alkaline batteries (4) AA batteries (3) AA batteries (4) AA batteries

Accuracy per 100 ft. 1/4" 1/8" at 30' 1/8" at 30' 1/4"

Rotation Speed 0, 60, & 600 rpm – – –

Self-Leveling Range ±5° ±5° ±5° ±4°

Indoor Visibility Range 100' (dia) 50' (dia) 50' (dia) 100' (dia)

Range with Detector 600' (dia) – – –

Laser Class IIIa (<5 mW) at 635 nm II II 2 (<1.5 mW) at 635 nm

Slope (Single Axis) – – – –

Charger/Batteries (2) D Alkaline batteries (4) AA batteries (3) AA batteries (4) AA batteries

Tool Weight 4.5 lbs 1.9 lbs 1.2 lbs 1.0 lbs

Includes DW0742 Digital laser detector, DW0740 Wall

mount, Target card, (2) D

Alkaline batteries

Ceiling mount, (4) AA batteries Ceiling mount, (3) AA batteries (4) AA batteries

Self-Leveling Int/Ext Rotary

Laser Package

Self Leveling Interior

Rotary Laser - Combo Kit

Self Leveling

3-Beam Line Laser

Self-Leveling Line Laser

(Horizontal and Vertical)

Self Leveling

3-Beam Line Laser

Self Leveling Rotary Laser -

Combo Kit w/ Detector (Int/Ext)

Self-Leveling Int/Ext Rotary

Laser Kit

Self-Leveling Int/Ext Rotary

Laser Kit

VACUUMS 18V 1/2 Gallon Wet/Dry

Portable Vac (Tool Only)

18/20V MAX* Wet-Dry

Vacuum

18/20V MAX* Cordless/

Corded Wet-Dry Vacuum

SPECIFICATIONS DC515K DC515B DCV580 DCV581H

Tank Size 1/2 gallon 1/2 gallon 2 gallon 2 gallon

Hose Diameter 1-1/4" 1-1/4" 1-1/4" 1-1/4"

Hose Length 2.5' 2.5' 5.0' 5.0'

Volts / Power Source 18V 18V 18V or 20V MAX* 18V or 20V MAX* or AC/DC Power

Blower No No Yes Yes

Weight 6.0 lbs 3.6 lbs (tool only) 10 lbs 10.5 lbs

Charger/Batteries 1-Hour Charger / (1) 18V XRP™Sold Separately Sold Separately Sold Separately

Filter Type High Efficiency Gore™ HEPA High Efficiency Gore™ HEPA High Efficiency HEPA Rated Filter

Includes – – Crevice Tool Attachment and

Wide Nozzle Tool Attachment

Crevice Tool Attachment and

Wide Nozzle Tool Attachment

18V XRP™ 1/2 Gallon

Wet/Dry Portable Vac

OPTICAL

INSTRUMENTS

PAGE 44

CORDLESS POWER TOOLS

36V COMBO

KITS

SPECIFICATIONS DCX6401

Volts 36V

Hammerdrill/Drill/Driver DC901

Circular Saw DC300

Reciprocating Saw DC305

Flexible Floodlight DC509

Charger/Batteries 1-Hour Charger / (2) 36V Lithium Ion

Includes 360° side handle, & 7-1/4" carbide

tipped blade

36V Lithium Ion 4-Tool

Combo Kit

WHY DEWALT COMBO KITS?

1. RIGHT MIX OF TOOLS FOR TRADES

AND APPLICATIONS:

DEWALT offers a full range of combination kits to accommodate

Professional Users and common applications being performed.

Depending on your needs – drilling wood or concrete, fastening,

cutting wood or metal, lighting, demolition – DEWALT has a

cordless solution.

2. VALUE PROPOSITION VERSUS

INDIVIDUAL TOOLS:

t(FUUIFDPSEMFTTUPPMTZPVOFFEJOPOFLJUGPSFBTZ

carry and storage

t"MMBSFQPXFSFECZUIFTBNFCBUUFSZQBDLBOEDIBSHFSXJUIJO

voltage family

t4BWFTNPOFZWFSTVTCVZJOHFBDIUPPMJOEJWJEVBMMZ

20V MAX*

COMBO KITS

SPECIFICATIONS DCK592L2 DCK590L2 DCK492L2 DCK491L2

Volts 20V MAX* 20V MAX* 20V MAX* 20V MAX*

Hammerdrill DCD985 DCD985 DCD985 DCD985

Circular Saw DCS391 DCS393 (6-1/2") DCS380 DCS393 (6-1/2")

Reciprocating Saw DCS380 DCS381 DCF885 DCS381

Impact Driver DCF885 DCF885 – –

LED Worklight

DCL040 DCL040 DCL040 DCL040

Charger/Batteries Fast Charger / (2) 20V MAX*

Lithium Ion (3.0 Ah)

Fast Charger / (2) 20V MAX*

Lithium Ion (3.0 Ah)

Fast Charger / (2) 20V MAX*

Lithium Ion (3.0 Ah)

Fast Charger / (2) 20V MAX*

Lithium Ion (3.0 Ah)

Includes 360° side handle, carbide tipped circular

saw blade, & belt hook

360° side handle, carbide tipped circular

saw blade, & belt hook

360° side handle & belt hook 360° side handle & carbide tipped

circular saw blade

20V MAX* Lithium Ion

5-Tool Combo Kit

20V MAX* Lithium Ion

5-Tool Combo Kit

20V MAX* Lithium Ion

4-Tool Combo Kit

(continued on next page)

20V MAX* Lithium Ion

4-Tool Combo Kit

CORDLESS POWER TOOLS

20 CORDLESS POWER TOOLS

18V COMBO

KITS

20V MAX*

COMBO KITS

SPECIFICATIONS DCK490L2 DCK298L2 DCK292L2 DCK290L2

Volts 20V MAX* 20V MAX* 20V MAX* 20V MAX*

Hammerdrill DCD985 – DCD985 DCD985

Reciprocating Saw DCS381 DCS380 DCS380 –

Impact Driver DCF885 DCF885 – DCF885

Screwdriver

––––

LED Worklight

DCL040 – – –

Charger/Batteries Fast Charger / (2) 20V MAX*

Lithium Ion (3.0 Ah)

Fast Charger / (2) 20V MAX*

Lithium Ion (3.0 Ah)

Fast Charger / (2) 20V MAX*

Lithium Ion (3.0 Ah)

Fast Charger / (2) 20V MAX*

Lithium Ion (3.0 Ah)

Includes 360° side handle & belt hook 360° side handle 360° side handle 360° side handle and belt hook

20V MAX* Lithium Ion

4-Tool Combo Kit

20V MAX* Lithium Ion

4-Tool Combo Kit

20V MAX* Lithium Ion

2-Tool Combo Kit

20V MAX* Lithium Ion

2-Tool Combo Kit

SPECIFICATIONS DCK675L DCK655X DCK555X DCK475L

Volts 18V 18V 18V 18V

Hammerdrill/Drill/Driver DCD970 DCD950 DCD950 DCD970

Circular Saw – DC390 (6-1/2") DC390 (6-1/2") –

Reciprocating Saw DC385 DC385 DC385 DC385

Cut-Off Tool

DC411 DC411 – –

Cut-Out Tool

––––

Jig Saw ––––

Impact Driver DC827 DC825 DC825 DC827

Impact Wrench DW059 – – –

Flexible Floodlight DW919 DW919 DW919 DW919

Charger/Batteries 1-Hour NiCd/NiMH/Li-Ion Charger /

(2) 18V XRP™ Lithium Ion

1-Hour Charger / (2) 18V XRP™1-Hour Charger / (2) 18V XRP™1-Hour NiCd/NiMH/Li-Ion Charger /

(2) 18V XRP™ Lithium Ion

Includes 360° side handle, type 1 guard, wrench, (2)

matched flanges, 2-position

side handle

360° side handle, carbide tipped circular saw

blade, type 1 guard, wrench,

(2) matched flanges, (1) type 1 wheel , &

2-position side handle

360° side handle & carbide tipped

circular saw blade

360˚ side handle

18V XRP™ 6-Tool Combo Kit18V XRP™ Lithium Ion 6-Tool Combo Kit 18V XRP™ 5-Tool Combo Kit 18V XRP™ Lithium Ion 4-Tool Combo Kit

SPECIFICATIONS DCK285C2 DCK280C2

Volts 20V MAX* 20V MAX*

Hammerdrill DCD785 –

Drill/Driver – DCD780

Impact Driver DCF885 DCF885

Charger/Batteries Fast Charger / (2) 20V MAX*

Lithium Ion (1.5 Ah)

Fast Charger / (2) 20V MAX*

Lithium Ion (1.5 Ah)

Includes (2) belt hooks and bit holder (2) belt hooks and bit holder

20V MAX* Lithium Ion

2-Tool Combo Kit

20V MAX* XR Lithium Ion

Brushless 2-Tool Combo Kit

20V MAX* XR Lithium Ion

Brushless 2-Tool Combo Kit

20V MAX* Lithium Ion

2-Tool Combo Kit

18V COMBO

KITS

SPECIFICATIONS DCK955X

Volts 18V

Hammerdrill/Drill/Driver DCD950

Circular Saw DC390 (6-1/2")

Reciprocating Saw DC385

Cut-Off Tool

DC411

Cut-Out Tool

DC550

Jig Saw DC330

Impact Driver DC825

Impact Wrench DW059

Flexible Floodlight DW919

Charger/Batteries 1-Hour Charger / (2) 18V XRP™

Includes 360° side handle, carbide tipped circular saw

blade, type 1 guard, wrench, (2) matched

flanges, 2 -position side handle

18V XRP™ 9-Tool Combo Kit

(continued)

SPECIFICATIONS DCK286D2 DCK281D2

Volts 20V MAX* 20V MAX*

Hammerdrill – –

Drill/Driver DCD795 DCD790

Impact Driver DCF886 DCF886

Charger/Batteries Fast Charger / (2) 20V MAX*

XR Lithium Ion (2.0 Ah)

Fast Charger / (2) 20V MAX*

XR Lithium Ion (2.0 Ah)

Includes (2) belt hooks and bit holder (2) belt hooks and bit holder

CORDLESS POWER TOOLS

18V COMBO

KITS

SPECIFICATIONS DCK251X DC4CKITA DCK425C DCK266L

Volts 18V 18V 18V 18V

Hammerdrill/Drill/Driver DCD950 – – DCD775

Drill/Driver – DC720 DC720 –

Circular Saw – DCS392 – –

Reciprocating Saw DC385 DW938 DW938 –

Impact Driver

– – DC825 DCF826

Pivot Head Flashlight – DW908 DW908 –

Charger/Batteries 1-Hour Charger / (2) 18V XRP™1-Hour Charger / (2) 18V 1-Hour Charger / (2) 18V 30-Minute Charger /

(2) 18V Compact Lithium Ion

Includes 360° side handle Carbide tipped circular saw blade – –

18V Compact Lithium Ion

2-Tool Combo Kit

SPECIFICATIONS DCK275L DCK274L DCK271L DCK255X

Volts 18V 18V 18V 18V

Hammerdrill/Drill/Driver DCD970 DCD775 DCD970 DCD950

Circular Saw ––––

Reciprocating Saw – – DC385 –

Impact Driver DC827 DC827 – DC825

Flexible Floodlight ––––

Charger/Batteries 1-Hour NiCd/NiMH/Li-Ion Charger /

(2) 18V XRP™ Lithium Ion

1-Hour NiCd/NiMH/Li-Ion Charger /

(2) 18V XRP™ Lithium Ion

1-Hour NiCd/NiMH/Li-Ion Charger,

(2) 18V XRP™ Lithium Ion

1-Hour Charger / (2) 18V XRP™

Includes 360° side handle – 360° side handle 360° side handle

18V XRP™ Lithium Ion

2-Tool Combo Kit

18V XRP™ Lithium Ion

2-Tool Combo Kit

18V XRP™ Lithium Ion

2-Tool Combo Kit 18V XRP™ 2-Tool Combo Kit

18V XRP™ Lithium Ion 4-Tool Combo Kit 18V XRP™ 4-Tool Combo Kit 18V XRP™ 4-Tool Combo Kit

SPECIFICATIONS DCK465L DCK455X DCK450X

Volts 18V 18V 18V

Hammerdrill/Drill/Driver DCD775 DCD950 DCD950

Circular Saw – – DC390 (6-1/2")

Reciprocating Saw DW938 DC385 DC385

Impact Driver DC827 DC825 –

Flexible Floodlight DW908 (Pivot Head Flashlight) DW919 DW919

Charger/Batteries 1-Hour NiCd/NiMH/Li-Ion

Charger / (2) 18V XRP™ Lithium Ion

1-Hour Charger / (2) 18V XRP™1-Hour Charger / (2) 18V XRP™

Includes – 360˚ side handle 360° side handle and

carbide tipped circular saw blade

18V XRP™ 2-Tool Combo Kit 18V Compact 4-Tool Combo Kit 18V Compact 4-Tool Combo Kit

(continued)

SPECIFICATIONS DCK265L

Volts 18V

Hammerdrill/Drill/Driver –

Drill/Driver DCD760

Circular Saw –

Reciprocating Saw –

Impact Driver

DCF826

Flexible Floodlight –

Charger/Batteries 30-Minute Charger /

(2) 18V Compact Lithium Ion

18V Compact

Lithium Ion 2-Tool Combo Kit

DEWALT’s XRP™ Lithium Ion Batteries Are Protected

By a DEWALT Designed Electronics Package That:

t.POJUPSTUIFDFMMTUPFOTVSFFBDIDFMMJTPQFSBUJOHBUJUT

fullest capacity

t$PNNVOJDBUFTUPUIFDIBSHFSUPMFUJULOPXXIFOUPTUPQ

charging

t1SPUFDUTUIFDFMMTGSPNBCVTJWF

conditions

The electronics are designed to

ensure the longest life and

maximum power output by

the pack during use.

No Memory & Virtually

No Self Discharge

For maximum productivity

& less downtime

Lightweight Design

1.5 lbs – same weight as a

DEWALT 12V NiCd battery

18V XRP™ Lithium Ion

Battery Works with

All Your 18V

DEWALT Tools.

XRP™ LITHIUM ION BATTERY ALSO AVAILABLE IN 14.4V

CORDLESS POWER TOOLS

22 CORDLESS POWER TOOLS

12V MAX*

COMBO KITS

SPECIFICATIONS DCK413S2 DCK212S2 DCK211S2 DCK210S2

Volts 12V MAX* 12V MAX* 12V MAX* 12V MAX*

Drill/Driver DCD710 DCD710 DCD710 -

Impact Driver DCF815 - DCF815 DCF815

Screwdriver - - - DCF610

Reciprocating Saw DCS310 DCS310 - -

Worklight DCL510 - - -

Charger/Batteries Fast Charger / (2) 12V MAX* Lithium Ion Fast Charger / (2) 12V MAX* Lithium Ion Fast Charger / (2) 12V MAX* Lithium Ion Fast Charger / (2) 12V MAX* Lithium Ion

Includes Bit tip, (2) belt hooks, (1) wood cutting recip blade, Belt hook, (1) wood cutting recip blade, 1 bit tip and (2) belt hooks 2 belt hooks and bit tips

(1) metal cutting recip blade (1) metal cutting recip blade

12V MAX* Lithium Ion Drill/Driver /

Impact Driver Combo Kit

12V MAX* Lithium Ion Screwdriver /

Impact Driver Combo Kit

12V MAX* Lithium Ion

2-Tool Combo Kit

12V MAX* Lithium Ion

4-Tool Combo Kit

CHARGER/RADIO

SPECIFICATIONS DC012 DCR015

Power Source 7.2V to 18V Battery 12V MAX* and 20V MAX* Battery

AM/FM Digital Tuner Yes Yes

Auxiliary Port Yes Yes

Charges batteries NiCd & Lithium Ion Lithium Ion

Weight 14.2 lbs 13.2 lbs

Does not work with 12V MAX*,

20V MAX* or Univolt®

Does not work with 18V batteries and

other stem packs batteries

Worksite Charger/Radio Charger/Radio

CORDLESS POWER TOOLS

DC9360

36V Lithium Ion

Battery

DW0242

24V XR+™ Pack Fan Cooled

Extended Run-Time Battery

DC9096

18V XRP™ Battery DC9180

18V XRP™ Lithium Ion

Battery

DC9181

18V Compact

Lithium Ion Battery

DC9091

14.4V XRP™ Battery DC9144

14.4V XRP™ Lithium Ion

Battery

DC9071

12V XRP™ Battery DW9061

9.6V Extended

Run-Time Battery

DW9057

7.2V Compact

Battery

12V MAX*

Fast Charger

12V MAX* – 20V MAX*

Lithium Ion Battery Charger

12V MAX* – 20V MAX* & 7.2V - 18V

Dual System, Dual Port Charger

12V MAX* – 20V MAX*

Lithium Ion Battery Charger

12V MAX* - 20V MAX*

Lithium Ion Charger/Radio

X=Not Compatible

12V MAX* &

20V MAX*

CHARGERS

SPECIFICATIONS DCB100 DCB101 DCR015 DCB119 DCB103

DC9180 18V - - - - 60

DCB120 12V MAX* 40 30 45 45 45

DCB200 20V MAX* X 60 90 90 90

DCB201 20V MAX* X 30 45 45 30

DCB203 20V MAX* X 35 60 60 35

DCB204 20V MAX* X 70 120 120 70

SPECIFICATIONS DW9117 DW0246 DW0249 DC9000 DC9310 DC9319 DC9320 DC012 DCB103

DC9360 36V X X X 60 XXXXX

DW0242 24V X 60 60 X XXXXX

DC9096 18V 20 X X X 60 60 60 60 60

DC9181 18V

X X X X 60 60 60 60 60

DC9180 18V

X X X X 60 60 60 60 60

DC9144 14.4V

X X X X 60 60 60 60 60

DC9091 14.4V

20XXX6060606060

DC9071 12V 20 X X X 60 60 60 60 60

DW9061 9.6V

15 X X X

45 45 45 45 45

DW9057 7.2V

12 X X X

30 30 30 30 30

DCB200

20V MAX* Lithium Ion

Battery

DCB201

20V MAX* Lithium Ion

Compact Battery

DCB204

20V MAX* Premium XR

Lithium Ion Battery

DCB203

20V MAX* XR Lithium Ion

Compact Battery

DCB120

12V MAX* Lithium Ion

Battery

1.5

AMP

HOURS

1.5

AMP

HOURS

2.0

AMP

HOURS

3.0

AMP

HOURS

4.0

AMP

HOURS

15-Minute

Charger 1-Hour Fan

Cooled Charger

1-Hour Fan Cooled

Vehicle Charger

1-Hour

Charger

NiCd/NiMH/Li-Ion

1-Hour Charger

1-Hour

Vehicle Charger

12V MAX* – 20V MAX*

& 7.2V - 18V Dual System,

Dual Port Charger

Dual Port

1-Hour Charger

Worksite

Charger/Radio

CORDLESS POWER TOOLS

24 CORDLESS POWER TOOLS

1. IS IT BETTER FOR DEWALT BATTERIES TO BE COMPLETELY DISCHARGED BEFORE CHARGING?

No. Just the opposite. You should stop using a battery as soon as you feel a substantial decrease in power from the tool. Completely running

down a battery may damage it. Do not tape the trigger to run down the battery.

2. WHAT IS MEMORY, AND DO DEWALT BATTERIES HAVE IT?

Memory is one of many conditions which causes a loss of run-time. Memory is created

from repetitive light use in the exact same application (i.e., Cordless Phones, Video Cameras, Electric

Shavers, etc.) Our products rarely see light use or the exact same loads, due to

variability from the user, the accessory size, as well as the material. The same variability which causes

different run-times prevents our cells from developing memory. Power tools

are considered high-drain applications. Memory typically develops in lower-drain rate

applications, such as cordless phones, laptops, etc…, because the rate at which the battery is draining

is continuously the same. Power tools draw higher currents and have sporadic drain rates minimizing

the opportunity for the battery to develop a memory.

3. DOES IT HURT DEWALT BATTERIES TO LEAVE THEM IN THE CHARGER?

No. The DEWALT chargers have a maintenance mode which allows batteries to remain in the charger,

maintaining a fully charged pack until the user is ready to work. If DEWALT NiCd batteries are stored

outside of the charger, they will discharge naturally, 15-20% the first 24 hours, 7-10% the next day, and

about 1% every day there after. NiCd batteries lose the bulk of the capacity when outside of the charger

in the first 3 days. In fact, it is better for the battery to leave it in the charger to be sure it goes through

Equalization and Maintenance Modes.

One of the benefits of DEWALT XRP

™

Lithium Ion batteries is that they have limited self discharge.

Storing

DEWALT Lithium Ion batteries outside of the charger will not result in loss of charge.

4. WHAT CAN I DO TO IMPROVE THE RUN-TIME OF MY BATTERY?

If no permanent damage has been done to your battery, you may be able to improve its run-time.

The correct procedure for charging your batteries is as follows:

1. Discharge the battery under normal use. Remove the battery, once you feel a loss of power from the

tool. Do not tape the trigger ON.

2. Let the battery sit out of the charger for a least 2 hours until the battery is at room temperature.

3. Place the battery in the charger overnight to allow for a full charge on each individual cell (A minimum

of 8 hours at room temperature).

If there is no difference in run-time, there is either permanent damage or the battery has reached the

end of its usable life. In either case, the battery should be replaced.

5. DOES THE OUTSIDE TEMPERATURE AFFECT BATTERIES? HOW?

Yes. If the batteries are too hot (105°F or higher) or too cold (below 40°F), the batteries will not take a full charge. Attempting to charge batteries

outside the 40°F-105°F range can result in a permanent loss of run-time. When batteries are being charged and discharged, a chemical reaction

is taking place, and if it is too hot or cold the chemical reaction is disturbed causing a loss of run-time.

6. CAN THE DEWALT CHARGER BE USED WITH A GENERATOR?

Yes. All DEWALT chargers, excluding the DW9106, have been designed to handle the variations in voltage and current delivered by generators.

7. SHOULD ANY SPECIAL PRECAUTIONS BE TAKEN WHEN TRANSPORTING OR

TRAVELING WITH BATTERIES?

Transporting batteries can possibly cause fires if the battery terminals inadvertently come in contact with conductive materials such as keys,

coins, hand tools and the like. The U.S. Department of Transportation Hazardous Material Regulations (HMR) actually prohibit transporting

batteries in commerce or on airplanes (i.e., packed in suitcases and carryon luggage) UNLESS they are properly protected from short circuits.

So anytime you transport individual batteries, make sure that the battery terminals are protected and well insulated from materials that could

contact them and cause a short circuit. For more information consult the U.S. DOT website at www.dot.gov.

8. WHAT SHOULD BE DONE WITH BATTERIES ONCE THEY HAVE GONE BAD?

RECYCLE THEM. DEWALT is an active participant with RBRC (Rechargeable Battery Recycling Corporation), the organization which is the

international leader in the collection, transportation and recycling of NiCd, NiMH and Lithium Ion cells. Old batteries should be disposed of at

DEWALT Service Centers.

For more information call 1-800-8-BATTERY or 1-800-8-228-8379.

XR DELIVERS EXTREME RUNTIME.

Brushless Motor

Electronically controls energy

transfer efficiently within the

tool. This allows the tool to run

longer between charges.

Brushed Motor

Mechanical carbon brush

system generates friction,

heat buildup and energy

loss resulting in less run

time.

1,737

Drive Up To

1-1/4” Screws Per Charge,

Into 2x Wood On Average.

DCD790D2

XR Brushless Drill with

2.0 AH Battery

Each DEWALT tool is engineered

and tested for toughness under real

world applications. Our tools are

dropped, frozen and heated with

major components cycling on/off

to ensure maximum performance

and life.

We also rigorously ﬁeld test with

professional core users to make sure

our tools meet the highest standard

of performance and durability.

Guaranteed Tough is built into every

tool and we stand behind that.

More Capacity.

More Runtime.

Same Size.

More Capa

city

BATTERY CAPACITY

RUNTIME CAPACITY

XR BATTERIES HAVE

33% MORE CAPACITY

Versus Standard 20V MAX* Batteries

BRUSHLESS

MOTOR +HIGH CAPACITY

BATTERIES

*Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage is 18.

Cooler Running.

More Efﬁcient.

Longer Runtime.

30.9˚C 40.6˚C

41.0˚C

21.7˚C

COOLER RUNNING

BRUSHLESS MOTOR

HOTTER RUNNING

BRUSHED MOTOR

30.

9˚

BRUSHLESS MOTORS

UP TO

57% MORE RUNTIME

Versus Standard Brushed Motors

CORDLESS POWER TOOLS

DUST, CONTROL, VIBRATION

THE DEWALT LINE OF PERFORM & PROTECT™ POWER TOOLS

IS DESIGNED WITH FEATURES THAT PROVIDE A HIGH LEVEL OF

CONTROL, DUST CONTAINMENT, OR LOW VIBRATION. LESSEN

WORKER DISCOMFORT WITHOUT SACRIFICING PERFORMANCE.

DEWALT’s Perform & ProtectTM line of Power Tools is designed to provide a high level of one or more of the following: control, dust containment, or low vibration,

without sacrificing performance.

CORDED POWER TOOLS

CORDED POWER TOOLS 27

CORDED POWER TOOLS

CORDED

POWER

TOOLS

JIG SAWS

RECIPROCATING

SAWS 13 Amp Reciprocating

Saw Kit

SPECIFICATIONS

Amps

Strokes/Min

Stroke Length

Keyless Blade Clamp

4-Position Blade Clamp

Adjustable Shoe

Variable-Speed Trigger

Variable-Speed Dial

Orbital Action

Anti-Slip Comfort Grip

DW311K

13 Amps

0 - 2,700 spm

1-1/8"

Twist

Yes

Powerful 10 Amp Motor

Designed for heavy-duty

applications

Keyless Blade Change

Allows for quick & easy

blade changing

4-Position Blade Clamp

Allows for ﬂush cutting

and increased versatility

2,800 spm & 1-1/8"

Stroke Length

For fast cutting

CIRCULAR

SAWS

SPECIFICATIONS

Amps

Max Watts Out

No Load Speed

Bevel Capacity

Bevel Stops

Rear Pivot

Electric Brake

Blade Diameter

Depth Of Cut At 90°

Depth Of Cut At 45°

Includes

DW384

15 Amps

2,075 W

5,800 rpm

50°

N/A

Yes

8-1/4"

2-15/16"

2-1/4"

Carbide tipped blade and

blade wrench

8-1/4" (210 mm) Circular

Saw with Rear Pivot

DWE575SB

15 Amps

1,950 W

5,200 rpm

57°

45° / 22.5°

N/A

7-1/4"

2.55"

1-7/8"

Carbide tipped 7-1/4"

blade and blade wrench

DWE575

15 Amps

1,950 W

5,200 rpm

57°

45° / 22.5°

N/A

7-1/4"

2.55"

1-7/8"

Carbide tipped 7-1/4"

blade and blade wrench

7-1/4" (184 mm)

Lightweight Circular Saw

7-1/4" (184 mm) Lightweight

Circular Saw w/ Electric Brake

DWS535 / DWS535T

15 Amps

2,100 W

4,800 rpm

53°

45° / 22.5°

7-1/4"

2-7/16"

1-7/8"

Carbide tipped 7-1/4" blade, blade

wrench / carbide tipped 7-1/4" blade,

blade wrench, pre-installed w/ twistlock plug

7-1/4" (184 mm) Worm

Drive Circular Saw

Variable Speed Top-Handle

Jig Saw Kit

Compact Jig Saw Kit

SCROLL SAW

SPECIFICATIONS

Amps

Strokes/Min

Stroke Length

Depth of Cut (inches)

Tool Weight

Includes

SCROLL SAW ATTACHMENTSDW788

1.3 Amps

400 - 1,750 spm

3/4"

56 lbs

Hex wrench and blades

DW7880 - Scroll Saw Stand

20" (50.8 mm) Variable-Speed

Scroll Saw

DW7881 - Scroll Saw Worklight

SPECIFICATIONS

Amps

Strokes/Min

Stroke Length

Keyless Blade Clamp

Dust Blower

Orbital Action

Tool Weight

DW331K

6.5 Amps

500 - 3,100 spm

Yes

4-position

6.4 lbs

DW317K

5.5 Amps

0 - 3,100 spm

Yes

N/A

4-position

6.2 lbs

DW364

15 Amps

2,075 W

5,800 rpm

50°

N/A

Yes

7-1/4"

2-7/16"

1-7/8"

Carbide tipped blade and

blade wrench

7-1/4" (184 mm) Circular

Saw with Rear Pivot

DW304PK

28 CORDED POWER TOOLS

CORDED POWER TOOLS

12 Amp Reciprocating

Saw Kit

DW310K

12 Amps

0 - 2,700 spm

1-1/8"

Twist

Yes

DW304PK

10 Amps

0 - 2,800 spm

1-1/8"

Lever

Yes

Fixed

Yes

10 Amp Reciprocating

Saw Kit

10 Amp Compact

Reciprocating Saw

DWE357

10 Amps

0 - 2,800 spm

1-1/8"

Lever

Yes

MULTI-TOOL

Oscillating Multi-Tool Kit

SPECIFICATIONS

Amps

Oscillations/Min

Variable Speed

Keyless Accessory Change

LED Light

Accessories Included

Tool Weight

Includes

DWE315K

3.0 Amps

0 - 22,000 opm

Yes

3.1 lbs

DEWALT Oscillating Tool Guide System, bi-metal plunge

cut blade, fast-cut wood blade, semi-circle ﬂush cut blade,

sanding pad, (25) sheets of sand paper, accessory storage

box and multi-brand accessory adaptor

TABLE SAWS

SPECIFICATIONS

Amps

No Load Speed

Blade Diameter

Arbor Size

Dust Port Diameter

Depth of Cut at 90°

Depth of Cut at 45°

Max Rip to Right of Blade

Max Rip to Left of Blade

Max Width of Dado

Includes

10" (254 mm) Compact Job Site

Table Saw w/ Rolling Stand

10" (254 mm) Jobsite Table Saw with

Guard Detect and w/ Rolling Stand

HANDHELD

TILE SAW

SPECIFICATIONS

Amps

Bevel Capacity

rpm

Arbor Size

Tool Weight

Includes

DWC860W

10.8 Amps

45°

13,000 rpm

20 mm

6.6 lbs

12' Water line and regulator,

4-3/8" DEWALT diamond blade

and 2 wrenches

4-3/8" (111.1 mm) Wet/Dry

Handheld Tile Saw

PORTABLE TABLE SAW ATTACHMENTS

DW7440‡ – Portable Table Saw Stand for DW744X

DW7441 – Out feed and Side Support

DW7442 – Thick Kerf Riving Knife for DW744X

DW7444 – Dado Throat Plate for DW744X

DW7450‡ – Table Saw Stand for DW745

DW7452 – Thick Kerf Riving Knife for DW745

DW7440RS – Rolling Table Saw Stand for DW744X

‡Available through service only

10" (254 mm) Job Site Table Saw with

Site-Pro™ Modular Guarding System

DWE7480

15 Amps

4,800 rpm

10"

5/8"

2-1/2"

3-1/8"

2-1/4"

24"

12"

N/A

Miter gauge, push stick, 10" 24T

carbide blade and blade guard

10" (254 mm) Compact Job

Site Table Saw with Site-Pro™

Modular Guarding System

TILE SAW 10" (254 mm)

Wet Tile Saw 10" (254 mm)

Wet Tile Saw w/ Stand

SPECIFICATIONS

Amps

Blade Diameter

Max Rip Capacity

Diagonal Cut Capacity

Plunge Feature

Max. Depth of Cut

Integrated 45° Miter

Integrated 22.5° Miter

Length

Tool Weight

D24000

15 Amps

10"

24" Tile

18" Tile

Yes

3-1/8"

Yes

34"

69 lbs

D24000S

15 Amps

10"

24" Tile

18" Tile

Yes

3-1/8"

Yes

34"

69 lbs

D24001 – Wet Tile Saw Stand

DWE7491RS

15 Amps

4,800 rpm

10"

5/8"

2-1/2"

3-1/8"

2-1/4"

32-1/2"

22"

13/16"

Miter gauge, push stick, 10" 24T

carbide blade, blade guard and rolling

table saw stand (DW7440RS)

DWE7499GD

15 Amps

4,800 rpm

10"

5/8"

2-1/2"

3-1/8"

2-1/4"

32-1/2"

22"

13/16"

Miter gauge, push stick, 10" 24T carbide

blade, blade guard and rolling table saw

stand (DW7440RS)

DWE7490X

15 Amps

4,800 rpm

10"

5/8"

2-1/2"

3-1/8"

2-1/4"

28"

16-1/2"

13/16"

Miter gauge, push stick, 10" 24T

carbide blade, blade guard and folding

table saw stand (DW7440)

CORDED POWER TOOLS 29

CORDED POWER TOOLS

TRACK SAWS

TRACKSAW ATTACHMENTS

DW5240 – Precision ground woodworking blade

for TrackSawTM System - 40T DWS5023 – 102" (259 cm) TrackSawTM Track DWS5030 – TrackSawTM Replacement

Glide Strip

DW5258 – Precision ground woodworking blade

for TrackSawTM System - 48T DWS5025 – TrackSawTM Track Bag DWS5031 – TrackSawTM Router Adapter

DWS5020 – 46" (116.8 cm) TrackSawTM Track DWS5026 – TrackSawTM Track Clamps DWS5032 – TrackSawTM Replacement

Friction Strip

DWS5022 – 59" (149.8 cm) TrackSawTM Track DWS5029 – TrackSawTM Replacement

Zero-clearance Anti Splinter Strip

SPECIFICATIONS

Power

No Load Speed

Blade Diameter

Bevel Capacity

Max. Cut at 90°

Max. Cut at 45°

Weight

Includes

DWS520CK

12 Amp, 1300 W

1,750 - 4,000 rpm

6-1/2"

47°

2-1/8"

1-5/8"

11.5 lbs

6-1/2" (20 mm arbor size) 48T ultra ﬁne

ﬁnishing blade, 59" track, 102" Track

and blade wrench

TILE SAW ATTACHMENTS

TrackSawTM Kit with

59" (149 cm) and 102" (259 cm) Tracks

DWS520LK

12 Amp, 1300 W

1,750 - 4,000 rpm

6-1/2"

47°

2-1/8"

1-5/8"

11.5 lbs

6-1/2" (20 mm arbor size) 48T ultra

ﬁne ﬁnishing blade, 102" Track and

blade wrench

TrackSawTM Kit with

102" (259 cm) Track

DWS520SK

12 Amp, 1300 W

1,750 - 4,000 rpm

6-1/2"

47°

2-1/8"

1-5/8"

11.5 lbs

6-1/2" (20 mm arbor size) 48T

ultra ﬁne ﬁnishing blade, 59" Track

and blade wrench

TrackSawTM Kit with

59" (149 cm) Track

DWS520K

12 Amp, 1300 W

1,750 - 4,000 rpm

6-1/2"

47°

2-1/8"

1-5/8"

11.5 lbs

6-1/2" (20 mm arbor size) 48T ultra

ﬁne ﬁnishing blade and blade wrench

6-1/2" (165 mm)

TrackSawTM Kit

MITER

SAWS

12" (305 mm) Double Bevel

Sliding Compound Miter Saw

12" (305 mm) Double Bevel

Sliding Compound Miter Saw

10" (254 mm) Double Bevel

Sliding Compound Miter Saw

SPECIFICATIONS

Amps

No Load Speed

Blade Diameter

Arbor Size

Vertical Capacity

Vertically Nested Capacity

Horizontal Capacity

Includes

DW716

15 Amps

3,800 rpm

12"

5/8" or 1"

6-1/2"

6-5/8"

8" (10" with back fence)

Carbide blade, dust bag and

blade wrench

12" (305 mm) Double Bevel

Compound Miter Saw

DW715

15 Amps

4,000 rpm

12"

5/8" or 1"

6-1/2"

5-1/4"

Carbide blade, dust bag and

blade wrench

12" (305 mm) Single Bevel

Compound Miter Saw

DW713

15 Amps

5,000 rpm

10"

5/8"

3-1/2"

4-1/2"

Carbide blade, dust bag and

blade wrench

10" (254 mm) Single

Bevel Miter Saw

DW718

15 Amps

3,600 rpm

12"

5/8" or 1"

6-1/2"

6-5/8"

16"

Carbide blade, blade wrench, dust

bag and vertical material clamp

DWS780

15 Amps

3,800 rpm

12"

5/8" or 1"

6-3/4"

7-1/2"

16"

XPS light, Carbide blade, blade wrench,

dust bag and vertical material clamp

DW717

15 Amps

4,000 rpm

10"

5/8"

6" Left - 3-1/2 Right"

6 1/4"

14"

Carbide blade, blade wrench, dust

bag and vertical material clamp

SPECIFICATIONS

Amps

No Load Speed

Blade Diameter

Arbor Size

Vertical Capacity

Vertically Nested Capacity

Horizontal Capacity (MAX with back fence)

Includes

MITER SAW

STANDS

‡Available through service only

DW7026 – Miter Saw Stand Carry Strap

DW7027 – Wide Roller Material Support

DW7028 – Miter Saw Stand Extension Support

DW7029 – Wide Miter Saw Stand Material

Support and Stop

DW7051 – Length Stop (for all DEWALT Miter Saws)

DW7053 – Dust Bag (for all DEWALT Miter Saws)

DW7055 – Miter Saw Replacement Kerf Plate

(for DW715 & DW716)

DW7080‡ – Extension Kit (for DW712, DW713,

DW715, DW716, DW717 & DW718)

DW7082 – Vertical Clamp (for DW712, DW713,

DW715, DW716, DW717 & DW718)

DW7084 – Crown Stops (for DW712, DW713,

DW715, DW716, DW717, DW718 &

DWS780)

DW7231 – Miter Saw Workstation Tool

Mounting Brackets (for DWX723,

DWX724 and DWX725 stands)

DW7232 – Miter Saw Workstation Work Piece

Support and Length Stop (for

DWX723 and DWX724 stands)

Compact Miter Saw StandMiter Saw Stand Work Stand

Work Stand with Miter Saw

Mounting Brackets Rolling Miter Saw Stand

SPECIFICATIONS

Support Width Up to 150" Up to 100" Up to 36" Up to 36" Up to 96"

Max. Capacity 500 lbs 500 lbs 1,000 lbs 1,000 lbs 300 lbs

Unit Weight 35 lbs 30 lbs 15.4 lbs 17.1 lbs 67 lbs

Includes (2) Convertible work

supports/stops and

(2) mounting brackets

(2) Convertible work

supports/stops and

(2) mounting brackets

–(2) Mounting brackets –

MITER SAW/STAND ATTACHMENTS

DWX724DWX723 DWX725 DWX725B DWX726

30 CORDED POWER TOOLS

CORDED POWER TOOLS

CORDED POWER TOOLS 31

CORDED POWER TOOLS

SCREWDRIVERS

SPECIFICATIONS DW255 DW252 DW272/W/WT DW257

Amps 6.0 Amps 6.0 Amps 6.3 Amps 6.2 Amps

No Load Speed 0 - 5,300 rpm 0 - 4,000 rpm 0 - 4,000 rpm 0 - 2,500 rpm

Clutch Standard Standard Standard Standard

Torque 60 in-lbs 60 in-lbs 81 in-lbs 132 in-lbs

Max Fastener Size #8 #8 #8 #12

Tool Weight 2.9 lbs 2.8 lbs 3.1 lbs 3.5 lbs

Includes ––

W = 50' cord

WT = 50' twist lock cord

–

SPECIFICATIONS DW276 DW266 DW260K DW267

Amps 6.5 Amps 6.5 Amps 6.2 Amps 6.5 Amps

No Load Speed 0 - 2,500 rpm 0 - 2,500 rpm 0 - 2,500 rpm 0 - 2,000 rpm

Clutch Standard Standard Standard VERSA-CLUTCH™ System

Torque 132 in-lbs 132 in-lbs 132 in-lbs 164 in-lbs

Max Fastener Size #14 #14 #12 #14

Tool Weight 3.6 lbs 3.5 lbs 3.2 lbs 3.7 lbs

Includes ––

1/4", 5/16", 3/8" Nut setters,

3 locators

–

SPECIFICATIONS DW268 DW269 DW281 DW284

Amps 6.5 Amps 6.5 Amps 6.5 Amps 6.5 Amps

No Load Speed 0 - 2,500 rpm 0 - 1,000 rpm 0 - 2,500 rpm 0 - 2,500 rpm

Clutch VERSA-CLUTCH™ System VERSA-CLUTCH™ System Positive Positive

Torque 132 in-lbs 344 in-lbs 132 in-lbs 132 in-lbs

Max Fastener Size #14 #14 #14 #14

Tool Weight 3.7 lbs 3.7 lbs 3.4 lbs 3.3 lbs

5,300 rpm

High Speed VSR

Drywall Scrugun

4,000 rpm

Lightweight VSR

Drywall Scrugun

4,000 rpm

VSR Drywall Scrugun

2,500 rpm

VSR All-Purpose

Scrugun

2,500 rpm

Heavy-Duty VSR

All-Purpose Scrugun

2,500 rpm

VSR Depth-Sensitive

TEKS® Scrugun

2,500 rpm

Lightweight VSR All-Purpose

Scrugun Kit

2,000 rpm

VSR VERSA-CLUTCH™

Scrugun

2,500 rpm

VSR VERSA-CLUTCH™

Scrugun

1,000 rpm

VSR VERSA-CLUTCH™

Scrugun

2,500 rpm

VSR Positive-Clutch Scrugun

with 1/4" Bit Holder

2,500 rpm

VSR Positive-Clutch Scrugun

with Threaded Clutch Housing

3/8" VSR

DRILLS

SPECIFICATIONS

Chuck Size

Keyless Chuck

Amps

No Load Speed

Max Watts Out

Capacity In Wood (Spade Bit)

Capacity In Wood (Hole Saw)

Capacity In Steel (Twist Bit)

Tool Weight

Includes

DWD115K

3/8"

Yes

8.0 Amps

0 - 2,500 rpm

650 W

1-1/8"

3/8"

4.1 lbs

–

3/8" (9.5 mm) VSR

Mid-Handle Drill

Kit with Keyless Chuck

DWD112

3/8"

Yes

8.0 Amps

0 - 2,500 rpm

650 W

1-1/8"

3/8"

4.1 lbs

–

3/8" (9.5 mm) VSR

Pistol Grip Drill with

Keyless Chuck

DWD110K

3/8"

Yes

8.0 Amps

0 - 2,500 rpm

650 W

1-1/8"

3/8"

4.1 lbs

–

3/8" (9.5 mm) VSR Pistol

Grip Drill Kit with Keyless

Chuck

DW223G

3/8"

7.0 Amps

0 - 1,200 rpm

560 W

1-1/4"

2-1/8"

3/8"

3.6 lbs

Chuck key with holder

3/8" (9.5 mm)

VSR Drill

DW222

3/8"

Yes

6.7 Amps

0 - 1,200 rpm

520 W

1-1/4"

2-1/8"

3/8"

3.3 lbs

–

3/8" (9.5 mm)

VSR Drill

with Keyless Chuck

DWE1014

3/8"

7.0 Amps

0 - 2,800 rpm

440 W

1-1/8"

3/8"

3.6 lbs

Chuck key

3/8" (9.5 mm)

VSR Drill

with Keyed Chuck

Racheting Keyless Chuck 8 Amps, 120V AC,

0 - 2500 rpm Motor

Anti-Slip

Comfort Grip

Balanced Mid-Handle

Design

VSR

DRILLS

SPECIFICATIONS

Chuck Size

Amps

No Load Speed

Max Watts Out

Keyless Chuck

Capacity In Wood (Spade Bit)

Capacity In Wood (Hole Saw)

Capacity In Steel (Twist Bit)

Tool Weight

Includes

DW217

1/4"

6.7 Amps

0 - 4,000 rpm

510 W

3/4"

N/A

1/4"

3.2 lbs

Chuck key with holder

1/4" (6.3 mm) VSR Drill

DW160V

3/8"

4.0 Amps

0 - 1,200 rpm

200 W

1-1/8"

3/8"

3.75 lbs

Chuck key with holder

3/8" (9.5 mm) VSR

Right Angle Drill

DWD115K

32 CORDED POWER TOOLS

CORDED POWER TOOLS

IMPACT

WRENCHES 1/2" (12.7 mm)

Impact Wrench

3/4" (19 mm)

Impact Wrench

3/4" (19 mm)

Impact Wrench

CUT-OUT TOOL

SPECIFICATIONS

Amps

No Load Speed

Collet Diameter

Adjustable Guide

Spindle Lock

Tool Length

Tool Weight

Includes

DW660

5.0 Amps

30,000 rpm

1/8", 1/4"

Yes

10"

3.2 lbs

(1) drywall cutting bit

and 1/4", 1/8" collets

Cut-Out Tool

SPECIFICATIONS

Amps

No Load Speed

Max. Torque

Impacts/Min

Anvil Type

Tool Length

Tool Weight

Includes

* (K) Includes Kitbag

DW292/K*

7.5 Amps

2,100 rpm

345 ft-lbs

2,700 ipm

Detent Pin

11-1/4"

7.0 lbs

–

DW294

7.5 Amps

2,100 rpm

345 ft-lbs

2,700 ipm

Detent Pin

11-1/4"

7.0 lbs

–

DW297

7.5 Amps

1,600 rpm

434 ft-lbs

1,800 ipm

Detent Pin

13"

11.0 lbs

360° side handle

DW293

7.5 Amps

2,100 rpm

345 ft-lbs

2,700 ipm

Hog Ring

11-1/4"

7.0 lbs

–

1/2" (12.7 mm)

Impact Wrench

ELECTRONIC

CLUTCH

DRILL

SPECIFICATIONS

Chuck Size

Amps

No Load Speed

Max Watts Out

Keyless Chuck

E-Clutch

Capacity In Wood (Spade Bit)

Capacity In Wood (Auger Bit)

Capacity In Steel (Twist Bit)

Capacity In Steel (Hole Saw)

Tool Weight

Includes

DWD220

1/2"

10.5 Amps

0 - 1,200 rpm

1100 W

Yes

1-1/2"

1/2"

4.9 lbs

360° side handle and

chuck key with holder

1/2" (12.7 mm) VSR

Pistol Grip Drill with

E-Clutch Anti-Lock Control

1/2" SPECIALTY

DRILLS

SPECIFICATIONS

Chuck Size

Amps

No Load Speed

Max Watts Out

Kit Box

Mechanical Clutch

Capacity In Wood (Auger Bit)

Capacity In Steel (Twist Bit)

Capacity In Steel (Hole Saw)

Tool Weight

Includes

DWD460/K*

1/2"

11 Amps

0-330 / 0-1,300 rpm

1015 W

No/Yes

Yes and Bind-Up Control®

1-1/2"

1/2"

11.7 lbs

2-position side handle, bail

handle and chuck key

with holder

1/2" (12.7 mm) VSR Stud &

Joist Drill w/ Clutch and

Bind-Up Control®

DW124/K*

1/2"

11.5 Amps

300 / 1,200 rpm

850 W

No/Yes

Yes

1-1/2"

1/2"

13.5 lbs

2-position side handle, bail

handle and chuck key

with holder

1/2" (12.7 mm) Stud &

Joist Drill

DW120K

1/2"

7.0 Amps

400 / 600 / 900 rpm

580 W

Yes

1-1/2"

1/2"

9.7 lbs

5-position side handle, allen

wrench and chuck key

with holder

1/2" (12.7 mm) Right

Angle Drill Kit

DW130V

1/2"

9.0 Amps

0 - 550 rpm

600 W

1-1/2"

1/2"

7.5 lbs

3-position side handle,

2-position rear spade handle

and chuck key with holder

1/2" (12.7 mm) Spade

Handle Drill

DW140

1/2"

7.0 Amps

600 rpm

580 W

1-1/2"

1/2"

1-1/2"

7.0 lbs

3-position side handle

and chuck key

1/2" (12.7 mm) End

Handle Drill

Improved Chuck Jaws

Protects flat shank

bits and holds them

more securely

Mechanical Clutch

In low speed for

increased

gear protection

Multi-Position

Adjustable Bail

Handle

Provides maximum

leverage and

control

Knuckle Guard

Provides increased

hand protection

0-330 / 0-1, 300 rpm

To match rpm / torque

requirements to a

variety of applications

Bind-Up Control®

Stall sensing technology

that provides increased

user control

Variable Speed Trigger

(JWFTVTFSJODSFBTFE

control when starting a hole

Anti-slip Comfort Grip on

Gear Casing & Handle

Provides additional comfort

Powerful 11 Amp Motor

For increased performance

in heavy-duty applications

DWD460

CORDED POWER TOOLS 33

CORDED POWER TOOLS

1/2" VSR DRILLS

SPECIFICATIONS

Chuck Size

Amps

No Load Speed

Max Watts Out

Keyless Chuck

Capacity In Wood (Spade Bit)

Capacity In Wood (Auger Bit)

Capacity In Steel (Twist Bit)

Capacity In Steel (Hole Saw)

Tool Weight

Includes

1/2" (12.7 mm) VSR

Mid-Handle Grip Drill with

Keyless Chuck

DWD215G

1/2"

10 Amps

0 - 1,200 rpm

980 W

Yes

1-1/2"

1/2"

5.2 lbs

360° locking side handle

1/2" (12.7 mm) VSR Drill

with Keyless Chuck

DW246

1/2"

7.8 Amps

0 - 600 rpm

600 W

Yes

1-1/2"

1/2"

2-3/4"

4.4 lbs

360° side handle

1/2" (12.7 mm)

VSR Drill

DW245

1/2"

7.8 Amps

0 - 600 rpm

600 W

1-1/2"

1/2"

2-3/4"

4.4 lbs

360° side handle and

chuck key with holder

1/2" (12.7 mm)

VSR Drill

DW235G

1/2"

7.8 Amps

0 - 850 rpm

600 W

1-1/2"

1-1/8"

1/2"

4.2 lbs

360° side handle and

chuck key with holder

DWD210G

1/2"

10 Amps

0 - 1,200 rpm

980 W

1-1/2"

1/2"

4.9 lbs

360° locking side handle

and chuck key with holder

1/2" (12.7 mm) VSR

Pistol Grip Drill

DWD216G

1/2"

10.5 Amps

0 - 1,200 rpm

1100 W

1-1/2"

1/2"

5.2 lbs

360° locking side handle

1/2" (12.7 mm) Keyed

VSR Mid Handle Drill

* (K) Includes Kitbox

34 CORDED POWER TOOLS

CORDED POWER TOOLS

SDS ROTARY

HAMMERS 7/8" (22 mm) D-Handle

SDS Rotary Hammerdrill

7/8" (22 mm) Pistol Grip

SDS Rotary Hammerdrill

1" (25.4 mm) Pistol Grip 3-Mode

SDS Rotary Hammerdrill

1" (25.4 mm) D-Handle

3-Mode SDS Hammerdrill

SPECIFICATIONS

Optimal Concrete Drilling

Amps

Impact Energy

Vibration Control

No Load Speed

Blows/Min

Vibration Measurement

Chipping

Clutch

Tool Length

Tool Weight

Warranty - Service Contract

Includes

D25023K

5/32"- 1/2"

6.9 Amps

1.8 ft-lbs

0 - 1,550 rpm

0 - 4,550 bpm

13.2 m/s2

Yes

16.2"

5.5 lbs

1 Yr.

360˚ side handle with

depth rod

D25012K

5/32"- 1/2"

6.0 Amps

1.8 ft-lbs

0 - 1,550 rpm

0 - 4,150 bpm

11 m/s2

Yes

13.2"

5.2 lbs

1 Yr.

360˚ side handle with

depth rod

D25123K

5/32"- 5/8"

8.0 Amps

2.5 ft-lbs

0 - 1,150 rpm

0 - 4,300 bpm

17.8 m/s2

Yes

14.2"

5.7 lbs

1 Yr.

360˚ side handle with

depth rod

D25213K

5/32"- 5/8"

8.0 Amps

2.5 ft-lbs

0 - 1,150 rpm

0 - 4,300 bpm

21 m/s2

Yes

16.6"

6.1 lbs

1 Yr.

360˚ side handle with

depth rod

D25223K

5/32"- 5/8"

8.0 Amps

2.5 ft-lbs

Yes - SHOCKS®

0 - 1,150 rpm

0 - 4,300 bpm

10 m/s2

Yes

17.7"

7.0 lbs

2 Yr.

360˚ side handle with

depth rod

1" (25.4 mm) D-Handle SDS

Rotary Hammerdrill

HAMMER

DRILLS 1/2" (12.7 mm) VSR Single

Speed Hammerdrill

1/2" (12.7 mm) VSR Dual

Range Hammerdrill

1/2" (12.7 mm) VSR

Pistol Grip Hammerdrill

1/2" (12.7 mm) VSR

Pistol Grip Hammerdrill Kit

SPECIFICATIONS

Amps

Max Watts Out

No Load Speed

Blows/Min

Capacity In Steel

Capacity In Wood

Concrete Optimum

Kit Box

Tool Length

Tool Weight

Includes

DW511

7.8 Amps

650 W

0-2,700 rpm

0-46,000 bpm

1/2"

1-1/4"

5/32" - 3/8"

11-1/2"

4.3 lbs

360° side handle, depth

rod and chuck key

DW505

7.8 Amps

650 W

0-1,100 / 0-2,700 rpm

0-19,000 / 0-46,000 bpm

1/2"

1-1/2"

5/32" - 3/8"

13"

4.8 lbs

360° side handle, depth

rod and chuck key

DWD520

10 Amps

980 W

0-1,200 / 0-3,500 rpm

0-56,000 bpm

1/2"

1-1/2"

5/32" - 7/16"

14"

6.0 lbs

360° side handle, steel

depth rod and chuck key

DWD520K

10 Amps

980 W

0-1,200 / 0-3,500 rpm

0-56,000 bpm

1/2"

1-1/2"

5/32" - 7/16"

Yes

14"

6.0 lbs

360° side handle, steel

depth rod and chuck key

DWD525K

10 Amps

980 W

0-1,200 / 0-3,500 rpm

0-56,000 bpm

1/2"

1-1/2"

5/32" - 7/16"

Yes

13"

6.0 lbs

360° side handle, steel depth

rod and chuck key with holder

1/2" (12.7 mm) VSR Mid-Handle

Grip Hammerdrill Kit

CORDLESS

SDS ROTARY

HAMMERS

SPECIFICATIONS DC212KA DCH253M2 DC233KL

Volts 18V 20V MAX* 36V

Chuck Type SDS Plus SDS Plus SDS Plus

No Load Speed 0 - 1,100 rpm 0 - 1,200 rpm 0 - 1,150 rpm

Blows/Min 0 - 4,100 bpm 0 - 4,500 bpm 0 - 4,400 bpm

Impact Energy 1.7 ft-lbs 1.7 ft-lbs 1.9 ft-lbs

Vibration Measurement 8.0 m/s26.9 m/s28.5 m/s2

Vibration Control Yes - SHOCKS®Yes - SHOCKS®Yes - SHOCKS®

Chipping No Yes Yes

Concrete Optimum 5/32" - 1/2" 5/32" - 1/2" 5/32" - 5/8"

Weight 7.6 lbs 6.4 lbs 7.8 lbs

Charger/Batteries 1-Hour Charger / (2) 18V XRP™ Fast Charger / (2) 20V MAX*

Lithium Ion (4.0 Ah)

1-Hour Charger / (2) 36V Lithium Ion

Includes 360˚ side handle with depth rod 360˚ side handle with depth rod 360˚ side handle with depth rod

Also available DC212KL (with 1-Hour Charger,

(2) 18V XRP™ Lithium Ion);

DC212B (Tool Only)

DCH253B (Tool Only) DC233KLDH (with 1-Hour Charger / (2) 36V

Lithium Ion, D25302DH dust extraction system)

36V Lithium Ion 1" (25 mm) SDS

Rotary Hammer Kit

20V MAX* Lithium Ion Cordless

3-Mode SDS Rotary Hammer Kit

18V XRP Cordless 7/8" (22 mm)

SDS Hammer Kit

* With respect to the 20V MAX*: Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage is 18.

SEE PAGE 12 FOR

ADDITIONAL AVAILABILITY

(continued on next page)

CORDED POWER TOOLS 35

CORDED POWER TOOLS

SDS ROTARY

HAMMERS 1" (25.4 mm) L-Shape

SDS Rotary Hammer Kit

1" (25.4 mm) L-Shape

SDS Rotary Hammer Kit

1" (25.4 mm) L-Shape

SDS Rotary Hammer Kit

with Quick Change Chuck

SPECIFICATIONS

Optimal Concrete Drilling

Amps

Impact Energy

Vibration Control

No Load Speed

Blows/Min

Vibration Measurement

Chipping

Clutch

Tool Length

Tool Weight

Warranty - Service Contract

Incudes

D25323K

5/32"- 5/8"

8.0 Amps

2.5 ft-lbs

Yes - SHOCKS®

0 - 1,150 rpm

0 - 4,300 bpm

10.5 m/s2

Yes

12.1"

7.5 lbs

2 Yr.

360˚ side handle with

depth rod

D25313K

5/32"- 5/8"

8.0 Amps

2.5 ft-lbs

0 - 1,150 rpm

0 - 4,300 bpm

18 m/s2

Yes

11.5"

6.5 lbs

1 Yr.

360˚ side handle with

depth rod

D25324K

5/32"- 5/8"

8.0 Amps

2.5 ft-lbs

Yes - SHOCKS®

0 - 1,150 rpm

0 - 4,300 bpm

10.5 m/s2

Yes

12.4"

7.8 lbs

2 Yr.

360˚ side handle with depth

rod and 3 Jaw Keyless chuck

D25404K

1-1/8"

8.3 Amps

3.3 ft-lbs

0 - 730 rpm

0 - 4,100 bpm

14.5 m/s2

Yes

15.25"

10.7 lbs

1 Yr.

360˚ side handle with

depth rod

1-1/8" (25.5 mm) SDS

Hammer Kit

SDS MAX

ROTARY

HAMMERS

SPECIFICATIONS

Optimal Concrete Drilling

Amps

Impact Energy

Vibration Control

No Load Speed

Blows/Min

Vibration Measurement

Clutch

Tool Length

Tool Weight

Warranty - Service Contract

Includes

1-9/16" (25.9 mm) SDS Max

Combination Hammer Kit

D25501K

3/8"- 1-1/4"

12 Amps

8 ft-lbs

490 rpm

3,300 bpm

18.3 m/s2

Yes

18.6"

13.5 lbs

1 Yr.

360˚ side handle

1-3/4" (26.1 mm) SDS Max

Combination Hammer Kit

with SHOCKS®

D25602K

1/2"- 1-3/8"

13.5 Amps

9.5 ft-lbs

Yes - SHOCKS®

210 - 415 rpm

1,430 - 2,840 bpm

9.1 m/s2

Yes

18.6"

15.1 lbs

2 Yr.

360˚ side handle

2" (50.8 mm) SDS Max

Rotary Hammer Kit

D25762K

1"- 1-3/4"

15 Amps

15 ft-lbs

Yes - SHOCKS®

125 - 250 rpm

1,150 - 2,304 bpm

9.3 m/s2

Yes - 2 Stage

23"

19.2 lbs

2 Yr.

360˚ side handle

D25712K

1"-1-5/8"

13 Amps

11.7 ft-lbs

Yes - SHOCKS®

137 - 275 rpm

1,260 - 2,520 bpm

7.8 m/s2

Yes - 2 Stage

20.5"

17.5 lbs

2 Yr.

360˚ side handle

1-7/8" (26.4 mm) SDS Max

Combination Hammer

DUST SOLUTIONS

PAGE 37 & 38

SPLINE ROTARY

HAMMERS 1-9/16" (25.9 mm) Spline

Combination Hammer Kit

D25553K

3/8"- 1-1/4"

11 Amps

8.0 ft-lbs

490 rpm

3,300 bpm

18.3 m/s2

Yes

18.6"

14 lbs

1 Yr.

360˚ side handle

SPECIFICATIONS

Optimal Concrete Drilling

Amps

Impact Energy

Vibration Control

No Load Speed

Blows/Min

Vibration Measurement

Clutch

Tool Length

Tool Weight

Warranty - Service Contract

Includes

D25651K

1/2"- 1-3/8"

13.5 Amps

9.5 ft-lbs

Yes - SHOCKS®

210 - 415 rpm

1,430 - 2,840 bpm

9.1 m/s2

Yes - 2 Stage

18.6"

15.5 lbs

2 Yr.

360˚ side handle

1-3/4" (26.1 mm) Spline

Combination Hammer Kit

(continued)

36 CORDED POWER TOOLS

CORDED POWER TOOLS

DEMOLITION

HAMMERS

SPECIFICATIONS

Amps

Impact Energy

Vibration Control

Vibration Measurement

Blows/Min

Variable Impact Control Dial

Chisel Rotation

Tool Length

Tool Weight

Warranty - Service Contract

Bit Type

Includes

D25899K

14 Amps

18.5 ft-lbs

11.5 m/s2

2,040 bpm

19 Settings

One-step, 12 Positions

25.8"

21.2 lbs

1 Yr.

SDS Max

360˚ side handle

SDS Max

Demolition Hammer

D25901K

14 Amps

3.7 - 18.5 ft-lbs

Yes - SHOCKS®

8.0 m/s2

1,020 - 2,040 bpm

Yes

One-step, 12 Positions

26.8"

23.4 lbs

2 Yr.

SDS Max

360˚ side handle

SDS Max Demolition

Hammer Kit

D25941K

15 Amps

22 ft-lbs

Yes - SHOCKS®

9.0 m/s2

1,620 bpm

One-step, 12 Positions

29.7"

27.2 lbs

2 Yr.

3/4" Hex

360˚ side handle

3/4" (19 mm) Hex Demolition

Hammer Kit

D25960K

15 Amps

30 ft-lbs

Yes - SHOCKS®

6.8 m/s2

1,460 bpm

30"

40.5 lbs

2 Yr.

1-1/8"

Bull point chisel and

wheeled kit box

40 lb. Demolition Hammer

CHIPPING

HAMMERS

SPECIFICATIONS

Amps

Impact Energy

Vibration Control

Vibration Measurement

Blows/Min

Variable Impact Control Dial

Chisel Rotation

Tool Length

Tool Weight

Warranty - Service Contract

Includes

D25330K

8.0 Amps

2.5 ft-lbs

17 m/s2

0 - 4,100 bpm

Yes

11.5"

6.5 lbs

1 Yr.

360˚ side handle

Compact SDS

Chipping Hammer

SDS Max Chipping

Hammer Kit

D25831K

13.5 Amps

9.5 ft-lbs

Yes - SHOCKS®

8.3 m/s2

1,430 - 2,840 bpm

7 Settings

Yes - Manual

18.6"

13.6 lbs

2 Yr.

360˚ side handle

Spline Chipping

Hammer Kit

D25851K

13.5 Amps

9.5 ft-lbs

Yes - SHOCKS®

8.3 m/s2

1,430 - 2,840 bpm

7 Settings

Yes - Manual

18.6"

14 lbs

2 Yr.

360˚ side handle

SDS Max Chipping

Hammer Kit

D25891K

15 Amps

15 ft-lbs

Yes - SHOCKS®

12.4 m/s2

1,152 - 2,304 bpm

8 Settings

Yes

23"

19 lbs

2 Yr.

360˚ side handle

PAVEMENT

BREAKER

SPECIFICATIONS

Amps

Impact Energy

Blows/Min

Vibration Control

Vibration Measurement

Tool Length

Tool Weight

Hand Truck

Warranty - Service Contract

Includes

D25980

15 Amps

61 ft-lbs

900 bpm

Yes - SHOCKS®

4.8 m/s2

30.7"

68.3 lbs

–

2 Yr.

–

Pavement Breaker

D25980K

15 Amps

61 ft-lbs

900 bpm

Yes - SHOCKS®

4.8 m/s2

30.7"

129.3 lbs

Multipurpose

2 Yr.

Hammer truck, ﬂat foot plate for

hammer truck, pegged foot plate for

hammer truck, (1) bull point chisel, (1)

1" cold chisel and (1) 3" wide chisel

68 lb. Pavement Breaker

with Wheel Cart

D259803

–

61 lbs

Multipurpose

3 Yr.

Flat foot plate for hammer truck,

pegged foot plate for hammer

truck, (1) bull point chisel, (1) 1"

cold chisel and (1) 3" wide chisel

Hammer Truck

and Steel

CORDED POWER TOOLS 37

CORDED POWER TOOLS

DUST

EXTRACTION

FOR SDS

ROTARY

HAMMERS

SPECIFICATIONS D25301D D25300DH D25302DH DC233KLDH

Built-In Motor N/A Yes Yes Yes

2-Second Shut-Off Delay N/A Yes Yes Yes

Separate Vac Required Yes No No No

Fits DEWALT SDS Hammers Corded & Cordless

except D25404

Corded L-Shape

except D25404

Cordless 36V 36V SDS Hammer

Includes Side handle – Side handle DC233 36V Lithium Ion 1" SDS rotary hammer,

D25302DH dust extraction system, 1-Hour

charger and (2) 36V Lithium Ion

Dust Extraction for

L-Shape SDS Hammer

36V Lithium Ion SDS Rotary

Hammer Kit and Dust

Extraction System

Dust Extraction System for

36V SDS Rotary Hammer

Dust Extractor Telescope

w/ Hose for SDS Rotary

Hammers

DUST

EXTRACTION

FOR GRINDERS

SPECIFICATIONS DWE46100 DWE46101 DWE46151

Max Wheel Diameter 5" / 6" 5" / 6" 5"

Hose Port Inner Diameter 35 mm 35 mm 35 mm

Hose Port Outer Diameter 42 mm 42 mm 42 mm

Tool Free Shroud Change Yes Yes Yes

Tool Free Accessory Change Yes Yes Yes

Includes – Universal connector, DWE46102 grinder

with guard, side handle, matched ﬂange

set, wrench and diamond blade

Universal Connector and

D28112 Grinder

SPECIFICATIONS DWE46150 DWE46170

Max Wheel Diameter 5" 7"

Hose Port Inner Diameter 35 mm 35 mm

Hose Port Outer Diameter 42 mm 42 mm

Tool Free Shroud Change Yes Yes

Tool Free Accessory Change Yes Yes

5" / 6" (125 mm / 150 mm)

Cutting/Tuck Pointing Shroud

5" / 6" (125 mm / 150 mm)

Cutting/Tuck Pointing Shroud Kit

5" (125 mm) Surfacing

Shroud Kit

5" (125 mm) Surfacing Shroud 7" (180 mm) Surface Grinding Dust

Shroud

DUST

EXTRACTION

FOR LARGE

ROTARY

HAMMERS

SPECIFICATIONS

Application

Used With

Hose Port Inner Diameter

Hose Port Outer Diameter

Compatible with

Universal Connector

Includes

DWH050K

Drilling (up to 2")

& Hole Cleaning (3/8" and up)

All rotary hammers

or hammerdrills

35 mm

42 mm

Yes

5/16" hole cleaning tube, 9/16" hole cleaning tube,

1-1/2" hole drilling head attachment, 2" hole

drilling head attachment and dust extractor body

DWH052K

Chipping

DEWALT Spline, SDS Max,

3/4" Hex Chipping Hammers

35 mm

42 mm

Yes

Dust extractor base, mounting

bracket and mounting

bracket strap

Large Hammer Dust

Extraction - Hole Cleaning

Large Hammer Dust

Extraction - Demolition

Large Hammer Dust

Extraction - Chiseling

DWH053K

Demolition

1-1/8" Demolition

Hammers

35 mm

42 mm

Yes

Dust extractor base, (3) chisel

nozzles and (3) tool adaptors

38 CORDED POWER TOOLS

CORDED POWER TOOLS

DUST

EXTRACTOR

VACUUM

SPECIFICATIONS

Tank Size

Amps

Max cfm

Water Lift

Size (L x H x W)

Weight

Decibel

Variable-Speed Dial

Power Cord

Hose Diameter

Hose Length

Warranty

Includes

10 Gallon Dust Extractor

with Automatic Filter Clean

DWV012

10 gal

15 Amps

140 cfm

81"

23.5 x 27.2 x 18.5

33.5 lbs

73 dBA

Yes

15'

1-1/4"

15'

1 Yr.

(2) HEPA ﬁlters and 15' kink resistant hose

DUST EXTRACTOR VACUUM ACCESSORIES

DWV9315 Replacement Hose for DWV012

Dust Extractor DWV9316 15' Anti Static Hose for DWV012

Dust Extractor DWV9320 Replacement HEPA Filter (2 Pack)

for DWV012 Dust Extractor

DWV9400 Disposable Plastic Liner (5 Pack)

for DWV012 Dust Extractor DWV9401 Paper Bag (5 Pack) for DWV012

Dust Extractor DWV9402 Fleece Bag (5 Pack) for DWV012

Dust Extractor

DUST

EXTRACTOR

VACUUM

ATTACHMENTS

D279059B D279059

Beater Bar

Floor Brush Kit

Dust Extractor 5-Piece

Accessory Kit

DUST

EXTRACTOR

CONNECTORS

SPECIFICATIONS

Outer Diameter

SPECIFICATIONS

Includes 11" Beater bar ﬂoor brush and

(2) extension wands (1.38" friction ﬁt)

Floor squeegee, ﬂoor

sweeper, crevice tool,

(2) extension wands

and curved wand

DWV9000 DWV9110 DWV9120 DWV9130 DWV9140 DWV9150

– 1.14" - 1.42"

(29 mm - 36 mm)

35 mm - 38 mm 31 mm 51 mm - 60 mm

52 mm (Inner Diameter)

35 mm

Universal Quick

Connector

Tapered Adapter

SPECIFICATIONS

Outer Diameter

Permanent Adapter for 1"

(25.5 mm) OD Port

Tool Adapter Large Hose Adapter Drywall Sander Dust

Extractor Attachment

1-1/4" (31.7 mm)

Hose Cord Clip

Angled Adapter

DWV9160 DWV9170 D279058CL DWV9190

25.5 mm 35 mm – Connects to 2-1/4" Hose O.D. similar

to RIDGID® Vac or Shop-Vac®.

Allows PORTER-CABLE® 7800

drywall sander to be con-

nected to DWV9000 universal

quick connector and DWV012

dust extractor

Tapered Large

Diameter Adapter

TOOLS USED WITH

DUST EXTRACTION

PAGE 45

PAGE

PORTER-CABLE is a registered trademark of PORTER-CABLE.

RIDGID is a registered trademark of RIDGID.

Shop-Vac is a registered trademark of Shop-Vac.

DWV9180

CORDED POWER TOOLS 39

CORDED POWER TOOLS

SMALL ANGLE

GRINDERS

HIGH

PERFORMANCE

SMALL ANGLE

BODY GRIP 6" (150 mm)

Cut-Off/Grinder

D28140

13 AC Amps

1,700 W / 2.3 HP

9,000 rpm

5/8"-11

Slide

Yes

13"

4.6 lbs

2-Position side handle, 6" type

27 keyless adjustable guard,

6" type 1 keyless adjustable

guard and wrench

6" (150 mm)

Cut-Off/Grinder

D28114

13 AC Amps

1,700 W / 2.3 HP

11,000 rpm

5/8"-11

Paddle w/ lock-on

Yes

13"

4.6 lbs

2-Position side handle, 5"

type 27 keyless adjustable

guard and wrench

4-1/2" / 5" (115 mm /

125 mm) Grinder

D28131

13 AC Amps

1,700 W / 2.3 HP

11,000 rpm

5/8"-11

Slide

Yes

13"

4.6 lbs

2-Position side handle, 5"

type 27 keyless adjustable

guard, and wrench

4-1/2" - 5" (115 mm /

125 mm) Grinder

6" (150 mm)

Cut-Off/Grinder

D28114N

13 AC Amps

1,700 W / 2.3 HP

11,000 rpm

5/8"-11

Paddle no lock-on

Yes

13"

4.6 lbs

2-Position side handle, 5"

type 27 keyless adjustable

guard and wrench

4-1/2" / 5" (115 mm /

125 mm) Grinder

DWE4011

7.0 AC/DC Amps

850 W / 1.14 HP

12,000 rpm

5/8"-11

Slide

Yes

10-5/8"

3.9 lbs

2-Position side handle, One-Touch™

guard type 27 and wrench

4-1/2" (115 mm)

Small Angle Grinder

4-1/2" (115 mm) Paddle

Switch Grinder (grounded)

SPECIFICATIONS

Amps

Max Watts Out / Horsepower

No Load Speed

Spindle Thread

Switch Type

Dust Ejection System™

Tool-Free Flange System

E-Clutch®/ Overload Protection

Tool Length

Tool Weight

Includes

HIGH

PERFORMANCE

SMALL ANGLE

TRIGGER GRIP

D28065

13 Amps AC/DC

1,700 W / 2.3 HP

9,000 rpm

5/8"-11

Trigger

Yes

15.25"

4.75 lbs

2-Position side handle,

5" type 27 keyless adjustable guard,

6" type 27 keyless adjustable guard

and wrench

5" / 6"

(125 mm / 150 mm)

Grinder w/ Trigger Grip

D28115

13 Amps AC/DC

1,700 W / 2.3 HP

9,000 rpm

5/8"-11

Trigger

Yes

15.25"

4.75 lbs

2-Position side handle,

5" type 27 keyless adjustable

guard and wrench

4-1/2" / 5"

(115 mm / 125 mm)

Grinder w/ Trigger Grip

D28065N

13 Amps AC/DC

1,700 W / 2.3 HP

9,000 rpm

5/8"-11

Trigger

Yes

15.25"

4.75 lbs

2-Position side handle,

5" type 27 keyless adjustable guard,

6" type 27 keyless adjustable guard

and wrench

5" / 6"

(125 mm / 150 mm) Grinder w/

No-Lock On Trigger Grip

D28115N

13 Amps AC/DC

1,700 W / 2.3 HP

9,000 rpm

5/8"-11

Trigger

Yes

15.25"

4.75 lbs

2-Position side handle,

5" type 27 keyless adjustable

guard and wrench

4-1/2" / 5"

(115 mm / 125 mm) Grinder w/

No-Lock On Trigger Grip

SPECIFICATIONS

Amps

Max Watts Out / Horsepower

No Load Speed

Spindle Thread

Switch Type

Dust Ejection System™

Tool-Free Flange System

E-Clutch®/ Overload Protection

Tool Length

Tool Weight

Includes

D28402N

10 AC/DC Amps

1,200 W / 1.6 HP

11,000 rpm

5/8"-11

Paddle no lock-on

Yes

11-1/4"

4.6 lbs

2-Position side handle, type 27

keyless adjustable guard and

wrench

4-1/2" (115 mm) Small Angle

Grinder w/ No Lock-On

D28402

10 AC/DC Amps

1,200 W / 1.6 HP

11,000 rpm

5/8"-11

Paddle w/ lock-on

Yes

11-1/4"

4.6 lbs

2-Position side handle, type 27

keyless adjustable guard and

wrench

4-1/2" (115 mm)

Small Angle Grinder

D28112

10 AC/DC Amps

1,200 W / 1.6 HP

11,000 rpm

5/8"-11

Slide

Yes

11-1/4"

4.6 lbs

2-Position side handle, type

27 keyless adjustable guard

and wrench

4-1/2" (115 mm)

Small Angle Grinder

SPECIFICATIONS

Amps

Max Watts Out / Horsepower

No Load Speed

Use Accessories rpm Above

Spindle Thread

Switch Type

Dust Ejection System™

Tool-Free Flange System

Tool Length

Tool Weight

Includes

MEDIUM ANGLE

GRINDERS

DW831

12 AC/DC Amps

1,837 W / 2.5 HP

10,000 rpm

Yes

5/8"-11

14.33"

7.4 lbs

Grinding wheel, wrench, backing ﬂange clamp nut,

5" type 27 keyless adjustable guard and 2-position side

handle

5" (125 mm) Medium Angle Grinder

DW840

13 AC/DC Amps

2,250 W / 3.0 HP

8,000 rpm

Yes

5/8"-11

16.1"

8.0 lbs

Grinding wheel, wrench, backing ﬂange clamp nut,

7" type 27 keyless adjustable guard and 2-position

side handle

7" (180 mm) Medium Angle Grinder

SPECIFICATIONS

Amps

Max Watts Out / Horsepower

No Load Speed

Use Accessories rpm Above

Spindle Lock

Spindle Thread

Tool Length

Tool Weight

Includes

DUST EXTRACTION

ACCESSORIES

PAGE 37

ACCESSORIES

PAGE

DW802G

9.0 AC/DC Amps

1,000 W / 1.3 HP

10,000 rpm

5/8"-11

Paddle w/ lock-on

Yes

11.5"

5.1 lbs

Side handle, type 27 keyless

guard, backing ﬂange, clamp

nut, wrench and grinding wheel

D28144

13 AC Amps

1,700 W / 2.3 HP

9,000 rpm

5/8"-11

Paddle w/ lock-on

Yes

13"

4.6 lbs

2-Position side handle, 6" type

27 keyless adjustable guard,

6" type 1 keyless adjustable

guard and wrench

D28144N

13 AC Amps

1,700 W / 2.3 HP

9,000 rpm

5/8"-11

Paddle no lock-on

Yes

13"

4.6 lbs

2-Position side handle, 6" type

27 keyless adjustable guard,

6" type 1 keyless adjustable

guard and wrench

40 CORDED POWER TOOLS

CORDED POWER TOOLS

STRAIGHT

GRINDERS BENCH

GRINDERS

6" (150 mm)

Straight Grinder

2-1/2" (65 mm)

Straight Grinder

8" (205 mm)

Bench Grinder

6" (152.4 mm)

Bench Grinder

LARGE

ANGLE

GRINDERS

GRINDER ACCESSORIES

Guards CAT # DESCRIPTION Flanges CAT # DESCRIPTION

D284931 7" (177.8 mm) Guard (Type 1 wheels) D284932 Type 1 Flange Set

D284937 7" (177.8 mm) Keyless Guard (Type 27 wheels) DWE4511 Matched Flange Set

D284938 9" (228.6 mm) Keyless Guard (Type 28 wheels) DWE4510 SAG Flange Wrench

D284939 9" (228.6 mm) Keyless Guard (Type 27 wheels) Flaring Cup Guards CAT # DESCRIPTION

D284991 4-1/2" (115 mm) Jumbo Flap Disc Grinder Guard D284933 Type 11 Flaring Cup Wheel Backing Flange

D284992 5" (127 mm) Jumbo Flap Disc Keyless Guard for Small Angle Grinder D284934 4" (101.6 mm) Adjustable Flaring Cup Wheel Guard (Type 11 wheels)

D284993 6" (152.4 mm) Jumbo Flap Disc Keyless Grinder Guard for Small Angle Grinder D284936 6" (152.4 mm) Adjustable Flaring Cup Wheel Guard (Type 11 wheels)

DW4705 Diamond Blade Guard

Service

Parts CAT # DESCRIPTION

N228080 Bail Handle

N228079 PipelineTM Grip

POLISHERS

DIE GRINDERS

7" / 9" (177.8 mm/

228.6 mm) Variable Speed

Polisher with Soft Start

7"/ 9" (177.8 mm/

228.6 mm) Variable Speed

Polisher

2" (50 mm)

Die Grinder

1-1/2" (40 mm)

Die Grinder

1-1/2" (40 mm)

Die Grinder

DWP849X

12 AC Amps

1,250 W

0-600 / 0-3,500 rpm

5/8"-11

Yes

17.3"

6.7 lbs

Hook & loop backing pad and

bale and straight side handle

DWP849

12 AC Amps

1,250 W

0-600 / 0-3,500 rpm

5/8"-11

Yes

17.3"

6.6 lbs

Rubber backing pad and

2-position side handle

SPECIFICATIONS

Amps

Max Watts Out

No Load Speed

Spindle Thread

Spindle Lock

Tool Length

Tool Weight

Includes

DW888

5.0 AC/DC Amps

485 W

19,000 rpm

N/A

1/4" collet & 1/8" sleeve

Trigger

19.2"

6.0 lbs

(2) Wrenches, 1/4" collet and

1/8" reducing sleeve

DW887

3.5 AC/DC Amps

350 W

25,000 rpm

N/A

1/4" collet

Paddle w/ Lock-On

13"

3.25 lbs

(2) Wrenches

and 1/4" collet

DW887N

3.5 AC/DC Amps

350 W

25,000 rpm

N/A

1/4" collet

Paddle / No Lock-On

13"

3.25 lbs

(2) Wrenches

and 1/4" collet

SPECIFICATIONS

Amps

Max Watts Out

No Load Speed

Use Accessories RPM Above

Spindle Lock

Spindle Thread

Switch Type

Tool Length

Tool Weight

Includes

DW882

13 AC/DC Amps

2,250 W

5,700 rpm

5/8"-11

24.4"

14.8 lbs

Wrench,

arbor nuts and ﬂanges

DW880

5.0 AC/DC Amps

485 W

19,000 rpm

3/8"-24

18.5"

6.8 lbs

(2) Wrenches,

arbor nuts and ﬂanges

SPECIFICATIONS

Amps

Max Watts Out

No Load Speed

Use Accessories rpm Above

Spindle Lock

Spindle Thread

Tool Length

Tool Weight

Includes

DW758

4.2 AC Amps

3/4 HP

3,600 rpm

5/8"

Yes

16"

39.5 lbs

36 Grit wheel, 60 grit wheel,

eye shields, spark deﬂectors,

tool rests and adjustment wrench

DW756

4.0 AC Amps

5/8 HP

3,450 rpm

1/2"

Yes

15"

28.5 lbs

36 Grit wheel, 60 grit wheel,

eye shields, spark deﬂectors,

tool rests and adjustment wrench

SPECIFICATIONS

Amps

Horsepower

No Load Speed

Wheel Diameter

Spindle Diameter

Adjustable Tool Resets

Tool Length

Tool Weight

Includes

NN

SQN)1

"OHMF(SJOEFS

NN

SQN)1

"OHMF(SJOEFS

NN

SQN)1

"OHMF(SJOEFS

NN

SQN)1

"OHMF(SJOEFS

NN

SQN)11JQFMJOF

(SJOEFS

NN

NN

)1-BSHF"OHMF

(SJOEFS

NNSQN

)1"OHMF(SJOEFS

NN

SQN)1"OHMF

(SJOEFS

NNSQN

)1"OHMF(SJOEFS

4QFDJGJDBUJPOT %8& %8& %8& %8&/ %8&$/ %9 %8& %8&/ %8&/

Amps 15 AC/DC Amps 15 AC/DC Amps 15 AC/DC Amps 15 AC/DC Amps 15 AC/DC Amps 15 AC/DC Amps 15 AC/DC Amps 15 AC/DC Amps 15 AC/DC Amps

Max Watts Out / Horsepower 3,000 W / 4 HP 3,000 W / 4 HP 3,450 W / 4.7 HP 3,450 W / 4.7 HP 3,450 W / 4.7 HP 3,950 W / 5.3 HP 3,650 W / 4.9 HP 3,650 W / 4.9 HP 3,650 W / 4.9 HP

No Load Speed 8,500 rpm 6,500 rpm 8,500 rpm 6,500 rpm 6,500 rpm 6,000 rpm 8,500 rpm 8,500 rpm 6,500 rpm

Use Accessories RPM Above 8,500 rpm 6,500 rpm 8,500 rpm 6,500 rpm 6,500 rpm 6,000 rpm 8,500 rpm 8,500 rpm 6,500 rpm

Lock-On Trigger Yes Yes Yes No No Yes Yes No No

Lock-Off Trigger Yes Yes Yes Yes Yes Yes Yes Yes Yes

Spindle Thread 5/8"-11 5/8"-11 5/8"-11 5/8"-11 5/8"-11 5/8"-11 5/8"-11 5/8"-11 5/8"-11

Motor Abrasion Protection Epoxy Epoxy DES* DES* DES* Epoxy DES* DES* DES*

Steel-Cut Gears Yes Yes Yes Yes Yes Yes Yes Yes Yes

Pipeline™ Grip No No No No Yes No No No No

Tool Length 19.3" 19.3" 20.8" 20.8" 20.9" 20.7" 21.4" 21.4" 21.4"

Tool Weight 12.1 lbs 12.1 lbs 11.6 lbs 12.1 lbs 12.4 lbs 14.5 lbs 12.3 lbs 12.3 lbs 12.8 lbs

E-Clutch No No No No No No Yes Yes Yes

Overload Protection No No No No No No Yes Yes Yes

Soft-Start No No No No No No Yes Yes Yes

Anti-Vibe Handle No No No No No No Yes Yes Yes

Includes 7" type 27 keyless

adjustable guard and

side handle

9" type 27 keyless

adjustable guard and

side handle

7" type 27 keyless

adjustable guard and

side handle

9" type 27 keyless

adjustable guard

and side handle

9" type 27 keyless ad-

justable guard, PipelineTM

Grip and side handle

7" type 27 keyless

adjustable guard and

side handle

7" type 27 keyless adjustable

guard and Anti-Vibration side

handle

7" type 27 keyless

adjustable guard and

Anti-Vibration side handle

9" type 27 keyless adjustable

guard and Anti-Vibration side

handle

*DES = Dust Ejection System

CORDED POWER TOOLS 41

CORDED POWER TOOLS

SHEARS

NIBBLERS

CUT-OFF

MACHINES

CHOP SAWS

SPECIFICATIONS

Amps

Max Watts Out

Strokes/Min

Capacity (Mild Steel)

Capacity (Stainless Steel)

Replacement Blade – Left/Right

Replacement Blade – Center

Tool Length

Tool Weight

Includes

DW890

5.0 AC/DC Amps

470 W

0-2,500 spm

18 ga.

20 ga.

DW8999 / DW8900

DW8901

9.1"

5.0 lbs

–

18 Gauge

Swivel Head Shear

DW891

5.0 AC/DC Amps

470 W

0-2,500 spm

14 ga.

16 ga.

DW8999 / DW8900

DW8902

9.1"

5.0 lbs

–

14 Gauge

Swivel Head Shear

DW892

3.0 AC/DC Amps

384 W

2,700 spm

14 ga.

16 ga.

–

DW8920

9.5"

5.5 lbs

Blade kit

14 Gauge

Shear

DW893

6.5 AC/DC Amps

225 W

1,950 spm

12 ga.

14 ga.

–

DW8930

10.5"

4.5 lbs

–

12 Gauge

Shear

D28605

6.5 AC/DC Amps

800 W

0-2,500 spm

N/A

–

9.1"

4.5 lbs

–

5/16" (7.9 mm) Variable

Speed Fiber Cement Siding Shear

14" (355 mm) Chop Saw

w/ Quick-Change Keyless

Blade Change System

14" (355 mm)

Chop Saw

14" (355 mm)

Cut-Off Machine

12" (304.8 mm) Cut-Off

Machine

DW896

3.0 AC/DC Amps

385 W

2,100 spm

16 ga.

18 ga.

9.7"

4.5 lbs

16 Gauge Nibbler

DW897

6.5 AC/DC Amps

225 W

1,950 spm

16 ga.

18 ga.

10.5"

4.5 lbs

16 Gauge Proﬁle Nibbler

DW898

6.5 AC/DC Amps

225 W

1,950 spm

14 ga.

16 ga.

5/8"

10.5"

4.5 lbs

14 Gauge Nibbler

SPECIFICATIONS

Amps

Max Watts Out

Strokes/Min

Capacity (Mild Steel)

Capacity (Stainless Steel)

Starting Hole

Tool Length

Tool Weight

BAND SAWS Deep Cut Variable Speed

Porta-Band® Saw

Deep Cut Band Saw

DW328/K*

6.0 AC/DC Amps

100 - 245 fpm

4-3/4"

4-1/2" x 4-3/4"

Pommel

Yes

21.5"

Hex wrench and standard

44-7/8" x 1/2" x .020" blade

DWM120/K*

10 AC Amps

100 - 350 fpm

5" X 4-3/4"

Multi Position Bale

Yes

Yes w/ serviceable shroud

21"

Hex wrench and standard

44-7/8" x 1/2" x. 020" blade

SPECIFICATIONS

Amps

Ft./Min.

Max Capacity (Rectangular)

Max Capacity (Round)

Front Handle Style

LED Light

AC/DC Capability

Rubber Bumpers

Tool Length

Includes

D28715

15 AC/DC Amps

4,000 rpm

5.5 HP

Yes

14"

4-1/2" x 6-1/2"

Quick Change

14" Abrasive wheel, fence wrench

and tool free ﬂange system

D28710

15 AC/DC Amps

3,800 rpm

4.0 HP

Yes

14"

4" x 7-5/8"

Wrench

14" Abrasive wheel

and wrench

SPECIFICATIONS

Amps

No Load Speed

Horsepower

Quick Lock Vise

Wheel Arbor

Wheel Diameter

Max Capacity (Round)

Max Capacity (Rectangular)

Blade Change

Includes

D28755

15 AC/DC Amps

4,300 rpm

5.5 HP

Yes

14"

clockwise / counter clockwise

Yes

21"

Masonry wheel, metal cutting

wheel and wrench

D28754

15 AC/DC Amps

5,000 rpm

4-1/2"

5.3 HP

12"

clockwise / counter clockwise

Yes

21"

Masonry wheel, metal cutting

wheel and wrench

SPECIFICATIONS

Amps

No Load Speed

Depth of Cut

Horsepower

Dust Collection

Wheel Diameter

Wheel Rotation

Motor Abrasion Protection

Tool Length

Includes

MULTI-CUTTER®

SAW 14" (355 mm)

Multi-Cutter® Saw

DW872

15 AC/DC Amps

1,300 rpm

Yes

14"

5-3/16"

6-1/2" x 4-1/2"

21"

14" carbide tipped blade,

wrench and vertical clamp

SPECIFICATIONS

Amps

No Load Speed

Spindle Lock

Quick Lock Vise

Wheel Arbor

Wheel Diameter

Max Capacity (Round)

Max Capacity (Rectangular)

Tool Length

Includes

* (K) Includes Kitbox

42 CORDED POWER TOOLS

CORDED POWER TOOLS

FRAMING

NAILERS

FINISH/BRAD

NAILERS 16 Gauge 1" - 2-1/2" (25.4 mm -

63.5 mm) Finish Nailer

SPECIFICATIONS

Nail Diameter

Nail Length Capacity

Magazine Angle

Magazine Capacity

Magazine Loading

Operating Pressure

Depth Setting

No Mar Pad

Integrated Belt Hook

Jam Clearing

Includes

D51276K

15 Gauge“Da” Style Nails Gauge

1" - 2-1/2"

34°

100 Nails

Rear Load, Load & Lock / Lock & Load

70 - 120 psi

Tool-Free Thumb Wheel

Low Proﬁle Rubber

Tool-Free Adjustable

Tool-Free Front Opening Sample ﬁnish

Sample ﬁnish nails "DA" style,

(2) wrenches and air ﬁtting

DWFP12231

18 Gauge

5/8" - 2"

Straight

100 Nails

Side Load

70 - 120 psi

Tool-Free Thumb Wheel

Low Proﬁle Rubber

Tool-Free Adjustable

Tool-Free Front Opening

500 brad nails of 1-1/4", 1/4" ﬁtting

15 Gauge 1" to 2-1/2"

(25.4 mm - 63.5 mm) Finish Nailer

18 Gauge 2" (63.5 mm)

Brad Nailer Kit

30° Clipped Head

Framing Nailer

SPECIFICATIONS

Nail Style

Magazine Angle

Nail Length Capacity

Nail Diameter Range

Magazine Capacity

Engine Valve Type

Jam Clearing

Dry Fire Lockout

Integrated Rafter Hook

Depth Setting

Includes

D51825

Clipped Head

30 - 34°

2"- 3-1/2"

.113" To .131"

80 Nails

Drop - Sleeve

Requires 5 mm or 3/16" Allen Key

Yes

Adjustable

Tool-Free Indexed

Safety glasses and bump ﬁre trigger

D51850

Full Round Head

20 - 22°

2"- 3-1/2"

.113" To .148"

65 Nails

Drop - Sleeve

Requires 5 mm or 3/16" Allen Key

Yes

Adjustable

Tool-Free Indexed

Safety glasses and bump ﬁre trigger

20° Full Round Head

Framing Nailer

STAPLERS

SPECIFICATIONS

Fastener Style

Crown Size

Fastener Length Capacity

Magazine Capacity

Magazine Angle

Magazine Loading

Operating Pressure

Speed

Depth Setting

Includes

1" - 2" x 1/2" (25.4 mm - 50.8 mm x 12.7 mm)

16 Gauge Medium Crown Stapler

D51431

16 Gauge Staple

1/2"

1" - 2"

160 Staples

Straight

Top Load

70 - 120 psi

20 Fasteners/Second @ 100 psi

Tool-Free Thumb Wheel

DEWALT safety glasses, (2) allen wrenches

and replacement sequential trigger

D51430

16 Gauge Staple

7/16"

1" - 2"

160 Staples

Straight

Top Load

70 - 120 psi

20 Fasteners/Second @ 100 psi

Tool-Free Thumb Wheel

DEWALT safety glasses, (2) allen wrenches

and replacement sequential trigger

1" - 2" x 7/16" (25.4 mm - 50.8 mm x 11.1 mm)

16 Gauge Medium Crown Stapler

DWFP12232

18 Gauge Staple

1/4"

1/2" - 1-1/2"

100 Staples

Straight

Bottom Load

70 - 120 psi

–

Tool-Free depth-of-drive adjustment with

detents for proper setting of staples

500 staples of 1" length and 1/4" air ﬁtting

1-1/2" (38.1 mm) 18 Gauge

Narrow Crown Stapler Kit

ROOFING

NAILER

FLOORING

TOOL

SPECIFICATIONS

Nail Style

Nail Diameter Range

Nail Length Capacity

Canister Capacity

Operating Pressure

Canister Loading

Nose Piece Carbide Inserts

Selectable Trigger

Jam Clearing

Includes

DWFP12658

Coil Rooﬁng

.120"

3/4" - 1-3/4"

120 Nails

70 - 120 psi

2-Door Side Load

Yes

Tool-Free Integrated In Nose Door

Nailer oil

SPECIFICATIONS

Nail Style

Nail Diameter Range

Nail Length Capacity

Canister Capacity

Operating Pressure

Canister Loading

Tool Base

Selectable Trigger

Jam Clearing

Includes

DWFP12569

Drives Staples and “L” Cleat Nails

15.5 ga Staples and 16 ga “L” Cleat Nails

1-1/2" - 2"

135 Cleats or 115 staples

70 - 100 psi

Top Loading

Non-marring, interchangeable base plates

Mallet Actuation

–

Mallet, Oil, Wrenches, 1/4" (6.4 mm) air

ﬁtting with dust cover

3/4" - 1-3/4" (19 mm - 44.4 mm)

Coil Rooﬁng Nailer

2-in-1 Flooring Tool

FINISH

NAILS

CAT # DESCRIPTION LENGTH BOX

QTY.

15 GAUGE “DA” Angled Finish Nails

DCA15150 “DA” Angle Finish Nails 1-1/2" (38.1 mm) 4,000

DCA15200 “DA” Angle Finish Nails 2" (50.8 mm) 4,000

DCA15250 “DA” Angle Finish Nails 2-1/2" (63.5 mm) 4,000

DCA15250G Angle Finish Nail Galv 2-1/2" (63.5 mm) 4,000

16 GAUGE 20˚ Angled Finish Nails

DCA16125 “FN” Angle Finish Nails 1-1/2" (38.1 mm) 2,500

DCA16150 “FN” Angle Finish Nails 2" (50.8 mm) 2,500

DCA16200 “FN” Angle Finish Nails 2-1/2" (63.5 mm) 2,500

DCA16250 “FN” Angle Finish Nails 2-1/2" (63.5 mm) 2,500

CAT # DESCRIPTION LENGTH BOX

QTY.

18 GAUGE Straight Brad Nails

DBN18063 Brad Nail 5/8" (15.8 mm) 5,000

DBN18125 Brad Nail 1-1/4" (31.7 mm) 5,000

DBN18150 Brad Nail 1-1/2" (38.1 mm) 5,000

DBN18200 Brad Nail 2" (508 mm) 5,000

16 GAUGE Straight Finish Nails

DCS16125 Straight Finish Nails 1-1/4" (31.7 mm) 2,500

DCS16150 Straight Finish Nails 1-1/2" (38.1 mm) 2,500

DCS16200 Straight Finish Nails 2" (15.8 mm) 2,500

DCS16250 Straight Finish Nails 2-1/2" (63.5 mm) 2,500

D51257K

16 Gauge

1" - 2-1/2"

Straight

100 Nails

Rear Load, Load & Lock / Lock & Load

70 - 120 psi

Tool-Free Thumb Wheel

Low Proﬁle Rubber

Tool-Free Adjustable

Tool-Free Front Opening

Sample ﬁnish nails "FN" style, safety

glasses, (2) allen wrenches and air ﬁtting

CORDED POWER TOOLS 43

CORDED POWER TOOLS

HAND CARRY-

ELECTRIC

COMPRESSORS

SPECIFICATIONS

Horsepower

Drive

Tank Size

Power Supply

cfm @100 PSI

Pump Speed

Tool Length

Tool Width

Tool Height

Includes

D55153

1.1 Continuous HP

Direct Drive

4 gal

120V AC, 15 Amps, 60 Hz,

2-Pole Induction Motor

3.8 cfm

3,400 rpm

18"

18.5"

16.7"

DEWALT compressor oil

1.1 HP Continuous 4

Gallon Compressor

SPECIFICATIONS

Horsepower

Drive

Tank Size

Power Supply

cfm @100 PSI

Pump Speed

Tool Length

Tool Width

Tool Height

D55154

1.1 Continuous HP

Direct

4 gal

120V AC, 15 Amps, 60 Hz,

2-Pole Induction Motor

3.8 cfm

3,400 rpm

22"

18.5"

23"

DEWALT compressor oil

1.1 HP Continuous 4 Gallon Wheeled

Dolly-Style Air Compressor with Panel

D55141

0.6 Continuous HP

Belt

2.0 gal

120V, 60Hz, 8 Amps,

Universal Motor

1.8 cfm

2,200 rpm

21.2"

19"

10.5"

2 Gallon, 150 PSI Max,

Trim Compressor

D55140

0.3 Continuous HP

Belt

1.0 gal

120V, 60Hz, 2.6 Amps,

Pmdc Motor

.6 cfm

2,200 rpm

19"

14.5"

1 Gallon, 135 PSI Max,

Trim Compressor

D55151

1.1 Continuous HP

Direct Drive

4 gal

120V AC 14 Amps, 60 Hz,

2-Pole Induction Motor

3.2 cfm

3,400 rpm

18.5"

15"

16.7"

DEWALT compressor oil

1.1 HP Continuous

4 Gallon Compressor

10" Pneumatic Wheels

and Collapsible Handle

For ease of mobility

High Flow Regulator

For high performance Oil Lubricated Pump

with Cast Iron Cylinder

For durability and life

Top Load Panel with

Tie Down Holes

Allows unit to transport

loads up to 100 lbs

Ball Drain Valve

Allows for quick and

thorough tank draining

Universal Quick Couplers

To easily support multiple tools

Convenient Cord Wrap

For easy storage

D55154

44 CORDED POWER TOOLS

CORDED POWER TOOLS

AIR HOSES

CAT # DIAMETER LENGTH MATERIAL THREADS WORKING PRESSURE

DAP14050 1/4" 50' Polyurethane 1/4” NPT Male Fittings 200 PSI

DAP14100 1/4" 100' Polyurethane 1/4" NPT Male Fittings 200 PSI

DAP38050 3/8" 50' Polyurethane 1/4" NPT Male Fittings 200 PSI

DAP38100 3/8" 100' Polyurethane 1/4" NPT Male Fittings 200 PSI

t 3FNBJOTnFYJCMFJOFYUSFNFDMJNBUFT¡UP¡'BMMPXJOHVTFSUPFBTJMZDPJMBOEVODPJMUIFIPTF

t 2VJDLmYTZTUFNGFBUVSFTBTUFQQSPDFTTUPFBTJMZSFQBJSBQVODUVSFEBJSIPTFBWPJEJOHUIFOFFEUPSFQMBDFBOFOUJSFIPTFEVFUPBTJOHMFQVODUVSF

t 4USFTTSFMJFWFSTGPSEVSBCJMJUZBOETXJWFMmUUJOHUPBWPJELJOLJOH

WHEELED

PORTABLE - ELECTRIC

COMPRESSORS

SPECIFICATIONS

Drive

Horsepower

Tank Size

Power Supply

cfm @100 PSI

Pump Speed

Tool Length

Tool Width

Tool Height

Tool Weight

200 PSI 15 Gallon 120 Volt

Workshop Compressor

D55167

Belt Drive

1.6 Continuous HP

15 gal

120 Volts

4.8 cfm

1,750 rpm

39.6"

16.5"

30"

83 lbs

200 PSI 4.5 Gallon

Compressor

D55146

Belt Drive

1.6 Continuous HP

4.5 gal

120 Volts

5.0 cfm

1,750 rpm

33.5"

23"

15"

83 lbs

D55168

Belt Drive

1.6 Continuous HP

15 gal

120 Volts

5.0 cfm

1,750 rpm

24.5"

22"

44.7"

92 lbs

200 PSI 15 Gallon 120 Volt

Workshop Compressor

OPTICAL

INSTRUMENTS

DW096PK

Auto

±1/32"

26x

300'

1:100

Continuous Drive

Aluminum tripod w/ quick adjust legs and

8' aluminum grade rod (feet-inches-eighths)

26x Auto Level Package

DW092PK

Manual

±1/4"

20x

200'

1:100

Continuous Drive

Aluminum tripod w/ quick adjust legs and

8' aluminum grade rod (feet-inches-eights)

20x Transit Level Package

DW090PK

Manual

±1/4"

20x

200'

1:100

Continuous Drive

Aluminum tripod w/ quick adjust legs and

8' aluminum grade rod (feet-inches-eighths)

20x Builders Level Package

SPECIFICATIONS

Leveling Type

Accuracy per 100'

Magniﬁcation

Range

Stadia Ratio

Horizontal Circle Type

Includes

CORDED POWER TOOLS 45

CORDED POWER TOOLS

* (K) Includes Kitbag

PLATE JOINER

Plate Joiner Kit

SPECIFICATIONS

Amps

No Load Speed

Depth Of Cut (mm)

Arbor Size

Fence Type

Biscuits Accepted

Tool Weight

Includes

DW682K

6.5 Amps

10,000 rpm

20 mm

7/8"

Dual Rack and Pinion

0, 10, 20

6.6 lbs

Carbide blade, dust bag vacuum adapter,

Torx® key and wrench

PLATE JOINER ACCESSORIES

DW6805 – Plate Joiner Blade

LAMINATE

TRIMMER Compact Router

SPECIFICATIONS

Amps

Collet Diameter

Spindle Lock

Tool Weight

Includes

D26670

5.6 Amps

1/4"

Yes

3.7 lbs

Standard base and

collet wrench

COMPACT ROUTER ACCESSORIES

D26671 – Standard Base (Service part)

D26672 – Tilt Base

D26673 – Offset Base

D26670K

5.6 Amps

1/4"

Yes

3.7 lbs

Standard trim base, tilt base,

offset base, collet wrench,

hex wrench and carry bag

Compact Router Kit

RANDOM

ORBITAL

SANDERS

SANDING

PADS

SPECIFICATIONS

Amps

Orbits/Min

Orbit Diameter

Dust Collection

Paper Size/Type

SFPM

Dust Sealed Switch

Pad Break

Tool Weight

Includes

D26453/K*

3.0 Amps

7,000 - 12,000 opm

3/32"

Yes

5", 8 Hole Hook & Loop

N/A

Yes

Yes - CFS

3.5 lbs

Dust bag with

vacuum adapter

5" (127 mm) VS

Random Orbit Sander

D26456

3.5 Amps

7,000 - 12,000 opm

3/32"

Yes

5", 8 Hole Hook & Loop

N/A

Yes

3.0 lbs

Dust bag with

vacuum adapter

5" (127 mm) Low Proﬁle

Random Orbit Sander

D26451/K*

3.0 Amps

12,000 opm

3/32"

Yes

5", 8 Hole Hook & Loop

N/A

Yes

Yes - CFS

3.4 lbs

Dust bag with

vacuum adapter

5" (127 mm) Random

Orbit Sander

DW443

4.3 Amps

4,000 - 6,800 opm

3/16"

Yes

6", 6 Hole Hook & Loop

N/A

Yes

5.7 lbs

Dust bag and

side handle

6" (152.4 mm) Right Angle

Random Orbit Sander w/

Electronic Variable Speed

D26441/K*

2.4 Amps

14,000 opm

1/16"

Yes

1/4 Sheet

N/A

Yes

N/A

3.0 lbs

Dust bag with vacuum

adapter and sandpaper punch

1/4 (6.3 mm) Sheet Palm

Grip Sander

DWE6401DS

6.0 Amps

0 - 3,700 opm

N/A

Yes

5", 8 Hole

N/A

4.0 lbs

5" 8 Hole hook & loop pad,

dust shroud and wrench

5" (127 mm) VS Disc

Sander with

Dust Shroud

SANDER PAD RELATED SANDER DESCRIPTION

DW4382 D26450, D26451, D26451K,

D26453K, D26456

5" (127 mm) PSA No-hole medium pad for

use with 5" (127 mm) DEWALT ROS without

dust collection

DW4385 DW421(D), DW422(D),

DW423(D)

5" (127 mm) PSA 8-hole medium pad for

use with 5" (127 mm) DEWALT ROS with

dust collection

DW4388 D26450, D26451, D26451K,

D26453K, D26456

5" (127 mm) Hook & loop 8-hole medium

pad for use with 5" (127 mm) DEWALT ROS

with dust collection

DW4390 DW443 Dust extraction adapter ﬁts 1-1/4" (32 mm),

1-3/8" (35 mm) & 1-1/2" (38 mm) standard

vacuum hoses (Sold at service ONLY)

DW4395 DW443 6" (152.4 mm) Hook & loop 6-hole hard pad

with dust collection

BISCUITS

DW6800 - Tube of 75 No. 0 size Biscuits

DW6804 - Tube of 150 No. 0 size Biscuits

DW6810 - Tube of 75 No. 10 size Biscuits

DW6815 - Tube of 125 No. 10 size Biscuits

DW6820 - Tube of 75 No. 20 size Biscuits

DW6825 - Tube of 150 No. 20 size Biscuits

46 CORDED POWER TOOLS

CORDED POWER TOOLS

ROUTER ACCESSORIES

DNP613 – Round Sub Base for Compact Routers DW6183 – D-Handle Base for DW616/618 DW6913 – Universal Edge Guide with Dust

Collection

DNP614 – D-Shaped Sub Base for Compact Routers DW6184 – Fixed Base for DW616/DW618 DW6966** – Fine Depth Adjuster

DNP615 – Compact Router Dust Collection Adapter

for Fixed Base Routers DW6188** – Template Guide Set D26671 – Standard Base**

DNP616 – Compact Router Dust Collection Adapter

for Plunge Base Routers

DW6902** – 1/4" (6.3 mm) Collet for

use with DW625 D26672 – Tilt Base

DNP617 – Centering Cone for Fixed Base Compact

Routers

DW6904** – 3/8" (9.5 mm) Collet for

use with DW625 D26673 – Offset Base

DNP618 – Edge Guide for Fixed Base Compact

Routers

DW6905** – 1/2" (12.7 mm) Collet for use with

DW625

DW6182 – Plunge Base for DW616/DW618

ROUTERS 1.25 HP Max Torque

Variable Speed Compact

Router with LED's

SPECIFICATIONS

Amps

Horsepower

No Load Speed

Collet Diameter

Plunge Stroke

Depth Stop

Base Dimension

Spindle Lock

Tool Weight

Includes

DW625

15 Amps

3 HP

8,000 - 22,000 rpm

1/2", 1/4"

2-7/16"

3 Stage Turret Stop

5-5/8 x 6-11/16"

Yes

11.2 lbs

1/4" and 1/2" collets, dust adapter,

guide adapter and wrench

3 HP (Max. Motor HP) EVS Plunge Router

DW621/K*

10 Amps

2 HP

8,000 - 24,000 rpm

1/2", 1/4"

2-1/8"

3 Stage Turret Stop

4-5/16 x 6-1/4"

Yes

9.0 lbs

1/4" and 1/2" collets, guide

adapter and wrench

2 HP (Max. Motor HP) EVS Plunge Router

SPECIFICATIONS

Amps

Horsepower

No Load Speed

Collet Diameter

Plunge Stroke

Depth Stop

Base Dimension

Spindle Lock

Tool Weight

Includes

DW618D

12 Amps

2-1/4 HP

8,000 - 24,000 rpm

1/2", 1/4"

N/A

Micro-ﬁne Ring

Yes

8.2 lbs

D-handle base, 1/4" and 1/2"

collets and wrench

2-1/4 HP (Max. Motor HP) EVS

D-Handle Router w/ Soft Start

DW618/K*

12 Amps

2-1/4 HP

8,000 - 24,000 rpm

1/2", 1/4"

N/A

Micro-ﬁne Ring

Yes

7.2 / 7.2

Fixed base, 1/4" and 1/2" collets,

large hole sub base and wrench

2-1/4 HP (Max. Motor HP) EVS

Fixed Base Router w/ Soft Start

1-3/4 HP (Max. Motor HP) Fixed

Base / Plunge Router Combo Kit

SPECIFICATIONS

Amps

Horsepower

No Load Speed

Collet Diameter

Plunge Stroke

Depth Stop

Base Dimension

Spindle Lock

Tool Weight

Includes

DWP611

7.0 Amps

1-1/4 HP

16,000 - 27,000 rpm

1/4"

N/A

Micro-ﬁne Ring

Yes - 12 position

5.5 lbs

Standard base and wrench

DW611PK

7.0 Amps

1-1/4 HP

16,000 - 27,000 rpm

1/4"

4" (standard),

4-3/8" x 5-3/4" (plunge)

Yes - 12 position

8.0 lbs

Extended sub-base,

standard base and wrench

DW616PK

11 Amps

1-3/4 HP

24,500 rpm

1/2", 1/4"

2-1/2"

Micro-ﬁne Ring

10 lbs

Plunge base, 1/4" and 1/2" collets, sub-base

concentricity gauge and (2) wrenches

DW616/K*

11 Amps

1-3/4 HP

24,500 rpm

1/2", 1/4"

N/A

Micro-ﬁne Ring

7.1 / 7.1

1/4" and 1/2" collets, sub-base concentricity

gauge, vacuum adapter and (2) wrenches

1-3/4 HP (Max. Motor HP)

Fixed Base Router

DW618B3

12 Amps

2-1/4 HP

8,000 - 24,000 rpm

1/2", 1/4"

2-1/2"

Micro-ﬁne Ring / 3 Stage

Turret Stop

Yes

10.1 lbs

Fixed base, plunge base, D-handle base, 1/4"

and 1/2" collets, concentricity gauge, large hole

sub base and wrench

2-1/4 HP (Max. Motor HP)

Three Base Router Kit

DW618PK

12 Amps

2-1/4 HP

8,000 - 24,000 rpm

1/2", 1/4"

2-1/2"

Micro-ﬁne Ring /

3 Stage Turret Stop

Yes

10.1 lbs

Fixed base, plunge base, 1/4" and 1/2"

collets, large hole sub base and wrench

2-1/4 HP (Max. Motor HP) EVS Fixed Base /

Plunge Router Combo Kit w/ Soft Start

* (K) Includes Kitbox or Kitbag

** Service part

1.25 HP Max Torque Variable

Speed Compact Router

Combo Kit with LED's

CORDED POWER TOOLS 47

CORDED POWER TOOLS

THICKNESS

PLANERS 13" (330.2 mm) Three Knife,

Two Speed Thickness Planer

13" (330.2 mm) Three Knife,

Two Speed Thickness Planer

12-1/2" (317.5 mm) Thickness

Planer w/ Three Knife Cutter-Head

SPECIFICATIONS

Amps

Max. Depth of Cut

Depth Capacity

Width Capacity

Speeds

Cuts Per Inch

Tool Weight

Includes

DW735X

15 Amps

1/8"

13"

96 and 179

92 lbs

Infeed and outfeed tables, dust hose

adapter and an extra set of knives

DW735

15 Amps

1/8"

13"

96 and 179

92 lbs

Dust hose adapter

DW734

15 Amps

1/8"

12-1/2"

80 lbs

Dust hood

THICKNESS PLANER ACCESSORIES (DW735/X)

DW7350 – Mobile Stand

DW7351 – 13" (330.2 mm) Folding Tables

DW7352 – 13" (330.2 mm) Disposable, Reversible Knives

DW7352-2 – 13" (330.2 mm) Vacuum Heat Treated Double Sided

Two Pack Replacement Planer Knives

(DW734)

DW7342 – 12-1/2" (317.5 mm)

Disposable, Reversible Knives

HAND PLANERS

SPECIFICATIONS

No Load Speed

Amps

Depth Of Cut (mm)

Depth Of Cut (inches)

Planing Width

Rabbeting Depth

Tool Weight

Includes

DW680K

15,000 rpm

7.0 Amps

2.5 mm

3/32"

3-1/4"

1/2"

6.2 lbs

(2) reversible carbide blades

and rabbeting fence

3-1/4" (82.5 mm) Planer Kit with

3/32" (2.5 mm) Depth of Cut

D26676

17,000 rpm

5.5 Amps

1.5 mm

1/16"

3-1/4"

23/64"

6.0 lbs

(2) resharpenable high-speed steel blades

(installed), rabbeting fence, blade depth setting gage,

blade resharpening tool and socket wrench

3-1/4" (82.5 mm) Portable

Hand Planer

D26677K

17,000 rpm

5.5 Amps

1.5 mm

1/16"

3-1/4"

23/64"

6.0 lbs

(2) Reversible carbide blades (installed),

rabbeting fence, blade depth setting

gage, dust adaptor and socket wrench

3-1/4" (82.5 mm) Portable

Hand Planer Kit

HAND PLANER ACCESSORIES

DW6654 – Pair of Reversible Carbide Blades

DW6655 – High Speed Steel Blades

HEAT GUNS

SPECIFICATIONS

Watts

Voltage

Amps

Temperature

Max. cfm

LCD

Power Cord

Weight

Includes

D26950

1550W

120V

13 Amps

120° to 1100° F

16 cfm

10'

2.1 lbs

Cone nozzle and ﬁshtail

surface nozzle

Heat Gun

D26960

1550W

120V

13 Amps

150° to 1100° F

17.7 cfm

Yes

10'

2.3 lbs

Cone nozzle and ﬁshtail

surface nozzle

LCD Heat Gun

D26960K

1550W

120V

13 Amps

150° to 1100° F

17.7 cfm

Yes

10'

2.3 lbs

Cone nozzle, ﬁshtail surface nozzle and

(10) other common accessories

Heat Gun Kit with

LCD Display

MEASURER Laser Distance

Measurer

DW030P

100'

1/8"

II (<1mW) @ 635nm

(2) AAA Alkaline

Batteries (Included)

Tool pouch and Lanyard

SPECIFICATIONS

Operating Range

Accuracy

Laser Class

Power Supply

Includes

CORDED POWER TOOLS

For information on these products and more go to

COMPRESSORS

PRESSURE WASHERS

GENERATORS

TOOL BELTS & BAGS

TRUCK TOOLBOXES & RACKS

TOOL SECURITY

REFERENCE BOOKS & GUIDES JOBSITE PROTECTION

ACCESSORIES

PERFORMANCE SO GOOD

IT RAISES YOURSTM

ACCESSORIES

50 ACCESSORIES

ACCESSORIES

%&."/%%EWALT

"#3"4*7&4

GOOD #&55&3 #&45

#POEFE %JBNPOET$PBUFE/PO8PWFO 8JSF8IFFMT

Ceramic

Zirconia COOL DISCTM

%&."/%

WALT

ACCESSORIES 51

ACCESSORIES

(continued on next page)

TYPE 1 BONDED ABRASIVES Type 1

A = Diameter B = Thickness C = Arbor

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DW8061 4" .045" 5/8" A60T Metal & Stainless Cutting 15,200 25

DW8062 4-1/2" .045" 7/8" A60T Metal & Stainless Cutting 13,300 25

DW8063 5" .045" 7/8" A60T Metal & Stainless Cutting 12,200 25

DW8725 6" .040" 7/8" A60T Metal & Stainless Cutting 10,100 25

DW8726 6" .045" 7/8" A60T Metal & Stainless Cutting 10,100 25

DW8065 7" .045" 7/8" A60T Metal & Stainless Cutting 8,700 25

DW8071 4" .045" 5/8" C60T Concrete & Masonry Cutting 15,200 25

DW8072 4-1/2" .045" 7/8" C60T Concrete & Masonry Cutting 13,300 25

Small Diameter Cutoff Wheels

DW8703 2-1/2" .035" 1/4" A36T Fast Metal & Stainless Cutting 30,500 50

DW8701 2-1/2" .035" 1/4" A60T Long Life Metal & Stainless Cutting 30,500 50

DW8702 2-1/2" .035" 3/8" A36T Fast Metal & Stainless Cutting 30,500 50

DW8700 2-1/2" .035" 3/8" A60T Long Life Metal & Stainless Cutting 30,500 50

DW8708 3" .035" 1/4" A36T Fast Metal & Stainless Cutting 24,400 50

DW8706 3" .035" 3/8" A36T Fast Metal & Stainless Cutting 24,400 50

DW8712 3" .035" 3/8" A60T Long Life Metal & Stainless Cutting 24,400 50

DW8704 3" 1/16" 1/4" A36T Fast Metal & Stainless Cutting 24,400 50

DW8705 3" 1/16" 3/8" A36T Fast Metal & Stainless Cutting 24,400 50

DW8711 3" 1/16" 3/8" A60T Long Life Metal & Stainless Cutting 24,400 50

DW8710 3" 1/8" 1/4" A24R Metal & Stainless Grinding 24,400 50

DW8709 3" 1/8" 3/8" A24R Metal & Stainless Grinding 24,400 50

DW8717 4" .035" 3/8" A36T Fast Metal & Stainless Cutting 19,000 25

DW8720 4" .035" 3/8" A60T Long Life Metal & Stainless Cutting 19,000 25

DW8724 4" .035" 5/8" A60T Long Life Metal & Stainless Cutting 19,000 25

DW8713 4" 1/16" 1/4" A36T Fast Metal & Stainless Cutting 19,000 25

DW8715 4" 1/16" 1/4" A60T Long Life Metal & Stainless Cutting 19,000 25

DW8716 4" 1/16" 3/8" A36T Fast Metal & Stainless Cutting 19,000 25

DW8719 4" 1/16" 3/8" A60T Long Life Metal & Stainless Cutting 19,000 25

DW8722 4" 1/16" 5/8" A36T Fast Metal & Stainless Cutting 19,000 25

.045" Masonry Cutting

SMALL DIAMETER

CUTTING WHEELS

Metal & Stainless Cutting & Grinding

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

.045"

DWA8951 4.5 .045" 7/8'' SG60T Metal & Stainless Cutting 13,300 25

DWA8952 5 .045" 7/8'' SG60T Metal & Stainless Cutting 12,200 10

DWA8953 6 .045" 7/8'' SG60T Metal & Stainless Cutting 10,100 10

Metal & Stainless Cutting

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

.045"

DW8850 4" .045" 5/8" Z60T Metal & Stainless Cutting 15,200 25

DW8851 4-1/2" .045" 7/8" Z60T Metal & Stainless Cutting 13,300 25

DW8852 5" .045" 7/8" Z60T Metal & Stainless Cutting 12,200 25

DW8853 6" .045" 7/8" Z60T Metal & Stainless Cutting 10,100 25

DW8854 7" .045" 7/8" Z60T Metal & Stainless Cutting 8,700 25

DW8056 7" 1/8" 5/8"- TA24T Metal Cutting 8,700 25

DW8057 12" 7/64" 1" TA24T Metal Stud Cutting 5,000 10

DW8059 14" 7/64" 1" TA24T Metal Stud Cutting 4,300 10

Metal & Stainless Cutting

Metal Abrasive Saw Blades

Metal Chop Saw Blades

.045" Metal & Stainless Cutting

52 ACCESSORIES

ACCESSORIES

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

Small Diameter Cutoff Wheels

DW8723 4" 1/16" 5/8" A60T Long Life Metal & Stainless Cutting 19,000 25

DW8718 4" 1/8" 3/8" A24R Metal & Stainless Grinding 19,000 25

DW8727 6" .045" 3/8" A60T Long Life Metal & Stainless Cutting 13,300 25

DW8424S 4-1/2" .045" 7/8" A60S Stainless Steel Cutting 13,300 25

DW8425S 5" .045" 7/8" A60S Stainless Steel Cutting 12,200 25

DW8426S 6" .045" 7/8" A60S Stainless Steel Cutting 10,100 25

DW8427S 7" .045" 7/8" A60S Stainless Steel Cutting 8,700 25

DW8080 4-1/2" 3/30" 7/8" A30S Stainless Steel Cutting 13,300 25

Stainless Steel Cutting Wheels CONTAMINANT-FREE

SMALL DIAMETER

CUTTING WHEELS

(continued)

Metal & Stainless Cutting & Grinding (continued)

TYPE 1 BONDED ABRASIVES (continued) Type 1

A = Diameter B = Thickness C = Arbor

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DWA8050 4" .045" 5/8" A60T Metal Cutting 15,200 25

DWA8051 4-1/2" .045" 7/8" A60T Metal Cutting 13,300 25

DWA8054 7" .045" 7/8" A60T Metal Cutting 8,700 25

DWA8050C 4" .045" 5/8" C60T Masonry Cutting 15,200 25

DWA8051C 4-1/2" .045" 7/8" C60T Masonry Cutting 13,300 25

SMALL DIAMETER

CUTTING WHEELS

.045" Masonry Cutting

.045" Metal Cutting

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DW8005 10" 7/64" 5/8" A24R General Purpose Metal Cutting 6,100 10

DW8004 12" 7/64" 1" A24R General Purpose Metal Cutting 5,000 10

DW8001 14" 7/64" 1" A24R General Purpose Metal Cutting 4,300 10

DW8002 14" 7/64" 1" A24S Fabrication Cutting 4,300 10

DW8003 14" 7/64" 1" A24T Stud Cutting 5,000 10

DW8010 16" 7/64" 1" A24R General Purpose Metal Cutting 3,800 10

DW8019 20" 3/16" 1" A24R General Purpose Metal Cutting 3,000 10

DW8009 10" 1/8" 5/8" C24R Masonry Cutting 6,100 10

DW8015 12" 7/64" 1" A30S Stainless Steel Cutting 5,000 10

DW8016 14" 7/64" 1" A30S Stainless Steel Cutting 4,300 10

DW3508 6-1/2" 1/8" 5/8"- A24R Metal Cutting 9,400 25

DW3511 7" 1/8" 5/8"- A24R Metal Cutting 8,700 25

DW3531 8" 1/8" 5/8"- A24R Metal Cutting 7,600 25

DW3509 6-1/2" 1/8" 5/8"- C24R Masonry Cutting 9,400 25

DW3521 7" 1/8" 5/8"- C24R Masonry Cutting 8,700 25

DW3532 8" 1/8" 5/8"- C24R Masonry Cutting 7,600 25

Metal Chop Saw Wheels

Masonry Stationary & Chop Saw Wheels

Metal Cutting Abrasive Saw Blades

Masonry Cutting Abrasive Saw Blades

Stainless Steel Stationary & Chop Saw Wheels CONTAMINANT-FREE

CUTTING

WHEELS

(continued on next page)

ACCESSORIES 53

ACCESSORIES

TYPE 1 BONDED ABRASIVES (continued) Type 1

A = Diameter B = Thickness C = Arbor

HIGH SPEED

WHEELS

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DWA8030 14" 1/8" 1" A24N High Speed Metal Cutting 5,500 10

DWA8031 14" 1/8" 20mm A24N High Speed Metal Cutting 5,500 10

DWA8032 12" 1/8" 1" A24N High Speed Metal Cutting 6,400 10

DWA8033 12" 1/8" 20mm A24N High Speed Metal Cutting 6,400 10

DWA8034 14" 1/8" 1" C24R High Speed Concrete Cutting 5,500 10

DWA8035 14" 1/8" 20mm C24R High Speed Concrete Cutting 5,500 10

DWA8036 12" 1/8" 1" C24R High Speed Concrete Cutting 6,400 10

DWA8037 12" 1/8" 20mm C24R High Speed Concrete Cutting 6,400 10

Masonry Cutting

Metal Cutting

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DWA8011 14" 7/65" 1" A24N Fast General Purpose Metal Cutting 4,300 10

DWA3501 7" 1/8" 5/8"- A24N Fast Metal Cutting 8,700 25

DWA3502 7" 1/8" 5/8"- C24R Fast Masonry Cutting 8,700 25

Metal Chop Saw Wheels

Metal Cutting Abrasive Saw Blades

Masonry Cutting Abrasive Saw Blades

CUTTING

WHEELS

HIGH SPEED

WHEELS

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DW8020 14" 1/8" 1" A24R High Speed Metal Cutting 5,500 10

DW8021 14" 1/8" 20mm A24R High Speed Metal Cutting 5,500 10

DW8022 12" 1/8" 1" A24R High Speed Metal Cutting 6,400 10

DW8023 12" 1/8" 20mm A24R High Speed Metal Cutting 6,400 10

DW8024 14" 1/8" 1" C24P High Speed Concrete Cutting 5,500 10

DW8025 14" 1/8" 20mm C24P High Speed Concrete Cutting 5,500 10

DW8026 12" 1/8" 1" C24P High Speed Concrete Cutting 6,400 10

DW8027 12" 1/8" 20mm C24P High Speed Concrete Cutting 6,400 10

DW8038 14" 3/16" 1" pinhole C24P Walk Behind Cured Concrete Cutting 4,300 10

DW8039 14" 3/16" 1" pinhole C24N Walk Behind Green Concrete & Asphalt Cutting 4,300 10

DW8030 14" 1/8" 1" A24/C24P High Speed Ductile Cutting 5,500 10

DW8031 14" 1/8" 20mm A24/C24P High Speed Ductile Cutting 5,500 10

DW8032 12" 1/8" 1" A24/C24P High Speed Ductile Cutting 6,400 10

DW8033 12" 1/8" 20mm A24/C24P High Speed Ductile Cutting 6,400 10

DW8034 14" 1/8" 1" C24N High Speed Asphalt Cutting 5,500 10

DW8035 14" 1/8" 20mm C24N High Speed Asphalt Cutting 5,500 10

DW8036 12" 1/8" 1" C24N High Speed Asphalt Cutting 6,400 10

DW8037 12" 1/8" 20mm C24N High Speed Asphalt Cutting 6,400 10

Metal Cutting

Masonry Cutting

Ductile Pipe Cutting

Asphalt Cutting

54 ACCESSORIES

ACCESSORIES

TYPE 27 BONDED ABRASIVES Type 27

A = Diameter B = Thickness C = Arbor

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

.045"

DW8856 4" .045" 5/8" Z60T Metal & Stainless Cutting 15,200 25

DW8857 4-1/2" .045" 7/8" Z60T Metal & Stainless Cutting 13,300 25

DW8857H 4-1/2" .045" 5/8"-11 Z60T Metal & Stainless Cutting 13,300 10

DW8858 5" .045" 7/8" Z60T Metal & Stainless Cutting 12,200 25

DW8858H 5" .045" 5/8"-11 Z60T Metal & Stainless Cutting 12,200 10

DW8859 6" .045" 7/8" Z60T Metal & Stainless Cutting 10,100 25

DW8859H 6" .045" 5/8"-11 Z60T Metal & Stainless Cutting 10,100 10

DW8860 7" .045" 7/8" Z60T Metal & Stainless Cutting 8,700 25

DW8860H 7" .045" 5/8"-11 Z60T Metal & Stainless Cutting 8,700 10

3/32"

DW8800 4" 3/32" 5/8" Z24R Metal & Stainless Cutting & Notching 15,200 25

DW8804 4-1/2" 3/32" 7/8" Z24R Metal & Stainless Cutting & Notching 15,200 25

DW8805 4-1/2" 3/32" 5/8"-11 Z24R Metal & Stainless Cutting & Notching 15,200 10

DW8810 5" 3/32" 7/8" Z24R Metal & Stainless Cutting & Notching 15,200 25

DW8811 5" 3/32" 5/8"-11 Z24R Metal & Stainless Cutting & Notching 15,200 10

DW8816 6" 3/32" 7/8" Z24R Metal & Stainless Cutting & Notching 10,100 10

Metal & Stainless Cutting

Metal & Stainless Cutting & Notching

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

.045"

DWA8957 4.5 .045" 7/8'' SG60T Metal & Stainless Cutting 13,300 25

DWA8958 5 .045" 7/8'' SG60T Metal & Stainless Cutting 12,200 10

DWA8959 6 .045" 7/8'' SG60T Metal & Stainless Cutting 10,100 10

DWA8904 4.5 3/32'' 7/8'' SG24N Metal & Stainless Cutting & Notching 13,300 25

DWA8905 4.5 3/32'' 5/8''-11 SG24N Metal & Stainless Cutting & Notching 13,300 10

DWA8910 5 3/32'' 7/8'' SG24N Metal & Stainless Cutting & Notching 12,200 25

DWA8911 5 3/32'' 5/8''-11 SG24N Metal & Stainless Cutting & Notching 12,200 10

DWA8916 6 3/32'' 7/8'' SG24N Metal & Stainless Cutting & Notching 10,100 10

DWA8917 6 3/32'' 5/8''-11 SG24N Metal & Stainless Cutting & Notching 10,100 10

DWA8922 7 3/32'' 7/8'' SG24N Metal & Stainless Cutting & Notching 8,700 10

DWA8923 7 3/32'' 5/8''-11 SG24N Metal & Stainless Cutting & Notching 8,700 10

DWA8928 9 3/32'' 7/8'' SG24N Metal & Stainless Cutting & Notching 6,600 10

DWA8929 9 3/32'' 5/8''-11 SG24N Metal & Stainless Cutting & Notching 6,600 10

DWA8906 4.5 1/8'' 7/8'' SG24N Metal & Stainless Cutting & Grinding 13,300 25

DWA8907 4.5 1/8'' 5/8''-11 SG24N Metal & Stainless Cutting & Grinding 13,300 10

DWA8912 5 1/8'' 7/8'' SG24N Metal & Stainless Cutting & Grinding 12,200 25

DWA8913 5 1/8'' 5/8''-11 SG24N Metal & Stainless Cutting & Grinding 12,200 10

DWA8918 6 1/8'' 7/8'' SG24N Metal & Stainless Cutting & Grinding 10,100 10

DWA8919 6 1/8'' 5/8''-11 SG24N Metal & Stainless Cutting & Grinding 10,100 10

DWA8924 7 1/8'' 7/8'' SG24N Metal & Stainless Cutting & Grinding 8,700 10

DWA8925 7 1/8'' 5/8''-11 SG24N Metal & Stainless Cutting & Grinding 8,700 10

DWA8930 9 1/8'' 7/8'' SG24N Metal & Stainless Cutting & Grinding 6,600 10

DWA8931 9 1/8'' 5/8''-11 SG24N Metal & Stainless Cutting & Grinding 6,600 10

DWA8908 4.5 1/4'' 7/8'' SG24N Metal & Stainless Grinding 13,300 25

DWA8909 4.5 1/4'' 5/8''-11 SG24N Metal & Stainless Grinding 13,300 10

DWA8914 5 1/4'' 7/8'' SG24N Metal & Stainless Grinding 12,200 25

DWA8915 5 1/4'' 5/8''-11 SG24N Metal & Stainless Grinding 12,200 10

DWA8920 6 1/4'' 7/8'' SG24N Metal & Stainless Grinding 10,100 10

DWA8921 6 1/4'' 5/8''-11 SG24N Metal & Stainless Grinding 10,100 10

DWA8926 7 1/4'' 7/8'' SG24N Metal & Stainless Grinding 8,700 10

DWA8927 7 1/4'' 5/8''-11 SG24N Metal & Stainless Grinding 8,700 10

DWA8932 9 1/4'' 7/8'' SG24N Metal & Stainless Grinding 6,600 10

DWA8933 9 1/4'' 5/8''-11 SG24N Metal & Stainless Grinding 6,600 10

Metal & Stainless Cutting

Metal & Stainless Cutting & Notching

Metal & Stainless Cutting & Grinding

Metal & Stainless Grinding

(continued on next page)

ACCESSORIES 55

ACCESSORIES

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

.045"

DW8420 4" .045" 5/8" A60T Metal & Stainless Cutting 15,200 25

DW8424 4-1/2" .045" 7/8" A60T Metal & Stainless Cutting 13,300 25

DW8424H 4-1/2" .045" 5/8"-11 A60T Metal & Stainless Cutting 13,300 10

DW8425 5" .045" 7/8" A60T Metal & Stainless Cutting 12,200 25

DW8425H 5" .045" 5/8"-11 A60T Metal & Stainless Cutting 12,200 25

DW8426 6" .040" 7/8" A60T Metal & Stainless Cutting 10,100 25

DW8426H 6" .040" 5/8"-11 A60T Metal & Stainless Cutting 10,100 25

DW8427 7" .045" 7/8" A60T Metal & Stainless Cutting 8,700 25

DW8427H 7" .045" 5/8"-11 A60T Metal & Stainless Cutting 8,700 25

DW8750 4-1/2" 3/32" 7/8" A24R Metal Cutting & Notching 13,300 25

DW8751 4-1/2" 3/32" 5/8"-11 A24R Metal Cutting & Notching 13,300 10

DW8752 5" 3/32" 7/8" A24R Metal Cutting & Notching 12,200 25

DW8753 5" 3/32" 5/8"-11 A24R Metal Cutting & Notching 12,200 10

DW8754 6" 3/32" 7/8" A24R Metal Cutting & Notching 10,100 10

DW8755 6" 3/32" 5/8"-11 A24R Metal Cutting & Notching 10,100 10

DW8756 7" 3/32" 7/8" A24R Metal Cutting & Notching 8,700 10

DW8757 7" 3/32" 5/8"-11 A24R Metal Cutting & Notching 8,700 10

DW8758 9" 3/32" 7/8" A24R Metal Cutting & Notching 6,600 10

DW8759 9" 3/32" 5/8"-11 A24R Metal Cutting & Notching 6,600 10

3/32" Metal Cutting & Notching

Metal & Stainless Cutting

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

3/32"

DW8817 6" 3/32" 5/8"-11 Z24R Metal & Stainless Cutting & Notching 10,100 10

DW8822 7" 3/32" 7/8" Z24R Metal & Stainless Cutting & Notching 8,700 10

DW8823 7" 3/32" 5/8"-11 Z24R Metal & Stainless Cutting & Notching 8,700 10

DW8828 9" 3/32" 7/8" Z24R Metal & Stainless Cutting & Notching 6,600 10

DW8829 9" 3/32" 5/8"-11 Z24R Metal & Stainless Cutting & Notching 6,600 10

1/8"

DW8801 4" 1/8" 3/8" Z24R Metal & Stainless Cutting & Grinding 15,200 25

DW8802 4" 1/8" 5/8" Z24R Metal & Stainless Cutting & Grinding 15,200 25

DW8806 4-1/2" 1/8" 7/8" Z24R Metal & Stainless Cutting & Grinding 13,300 25

DW8807 4-1/2" 1/8" 5/8"-11 Z24R Metal & Stainless Cutting & Grinding 13,300 10

DW8812 5" 1/8" 7/8" Z24R Metal & Stainless Cutting & Grinding 12,200 25

DW8813 5" 1/8" 5/8"-11 Z24R Metal & Stainless Cutting & Grinding 12,200 10

DW8818 6" 1/8" 7/8" Z24R Metal & Stainless Cutting & Grinding 10,000 10

DW8819 6" 1/8" 5/8"-11 Z24R Metal & Stainless Cutting & Grinding 10,000 10

DW8824 7" 1/8" 7/8" Z24R Metal & Stainless Cutting & Grinding 8,700 10

DW8825 7" 1/8" 5/8"-11 Z24R Metal & Stainless Cutting & Grinding 8,700 10

DW8830 9" 1/8" 7/8" Z24R Metal & Stainless Cutting & Grinding 6,600 10

DW8831 9" 1/8" 5/8"-11 Z24R Metal & Stainless Cutting & Grinding 6,600 10

1/4"

DW8803 4" 1/4" 5/8" Z24R Metal & Stainless Grinding 15,200 25

DW8808 4-1/2" 1/4" 7/8" Z24R Metal & Stainless Grinding 13,300 25

DW8809 4-1/2" 1/4" 5/8"-11 Z24R Metal & Stainless Grinding 13,300 10

DW8814 5" 1/4" 7/8" Z24R Metal & Stainless Grinding 12,200 25

DW8815 5" 1/4" 5/8"-11 Z24R Metal & Stainless Grinding 12,200 10

DW8820 6" 1/4" 7/8" Z24R Metal & Stainless Grinding 10,100 10

DW8821 6" 1/4" 5/8"-11 Z24R Metal & Stainless Grinding 10,100 10

DW8826 7" 1/4" 7/8" Z24R Metal & Stainless Grinding 8,700 10

DW8827 7" 1/4" 5/8"-11 Z24R Metal & Stainless Grinding 8,700 10

DW8832 9" 1/4" 7/8" Z24R Metal & Stainless Grinding 6,600 10

DW8833 9" 1/4" 5/8"-11 Z24R Metal & Stainless Grinding 6,600 10

Metal & Stainless Grinding

Metal & Stainless Cutting & Notching (continued)

(continued)

Pipeline Metal & Stainless Cutting & Grinding

TYPE 27 BONDED ABRASIVES (continued) Type 27

A = Diameter B = Thickness C = Arbor

(continued on next page)

56 ACCESSORIES

ACCESSORIES

(continued on next page)

TYPE 27 BONDED ABRASIVES (continued)

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

.045"

DWA4530 4" .045" 5/8" A60T Fast Cutting 15,200 25

DWA4531 4-1/2" .045" 7/8" A60T Fast Cutting 13,300 25

DWA4534 7" .045" 7/8" A60T Fast Cutting 8,700 25

1/8"

DWA4510 4" 1/8" 5/8" A24N Fast Cutting & Grinding 15,200 25

DWA4511 4-1/2" 1/8" 7/8" A24N Fast Cutting & Grinding 13,300 25

DWA4511H 4-1/2" 1/8" 5/8" -11 A24N Fast Cutting & Grinding 13,300 10

DWA4512 5" 1/8" 7/8" A24N Fast Cutting & Grinding 12,200 25

DWA4512H 5" 1/8" 5/8" -11 A24N Fast Cutting & Grinding 12,200 10

DWA4513 6" 1/8" 7/8" A24N Fast Cutting & Grinding 10,100 10

DWA4513H 6" 1/8" 5/8" -11 A24N Fast Cutting & Grinding 10,100 10

DWA4514 7" 1/8" 7/8" A24N Fast Cutting & Grinding 8,700 10

DWA4514H 7" 1/8" 5/8" -11 A24N Fast Cutting & Grinding 8,700 10

DWA4515 9" 1/8" 7/8" A24N Fast Cutting & Grinding 6,600 10

DWA4515H 9" 1/8" 5/8" -11 A24N Fast Cutting & Grinding 6,600 10

1/4"

DWA4500 4" 1/4" 5/8" A24N Fast Metal Grinding 15,200 25

DW4541 4-1/2" 1/4" 7/8" A24N Fast Metal Grinding 13,300 25

DW4542 4-1/2" 1/4" 5/8" -11 A24N Fast Metal Grinding 13,300 10

DW4543 5" 1/4" 7/8" A24N Fast Metal Grinding 12,200 25

DW4544 5" 1/4" 5/8" -11 A24N Fast Metal Grinding 12,200 10

DW4545 6" 1/4" 7/8" A24N Fast Metal Grinding 10,100 10

DW4546 6" 1/4" 5/8" -11 A24N Fast Metal Grinding 10,100 10

DW4547 7" 1/4" 7/8" A24N Fast Metal Grinding 8,700 10

DW4548 7" 1/4" 5/8" -11 A24N Fast Metal Grinding 8,700 10

DW4549 9" 1/4" 7/8" A24N Fast Metal Grinding 6,600 10

DW4550 9" 1/4" 5/8" -11 A24N Fast Metal Grinding 6,600 10

METAL CUTTING

& GRINDING

Metal & Stainless Cutting

Metal & Stainless Cutting & Grinding

Type 27

A = Diameter B = Thickness C = Arbor

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

1/8"

DW8434 4-1/2" 1/8" 7/8" A24R Metal & Stainless Cutting & Grinding 13,300 25

DW8435 4-1/2" 1/8" 5/8"-11 A24R Metal & Stainless Cutting & Grinding 13,300 10

DW8484 5" 1/8" 7/8" A24R Metal & Stainless Cutting & Grinding 12,200 25

DW8436 5" 1/8" 5/8"-11 A24R Metal & Stainless Cutting & Grinding 12,200 10

DW8485 6" 1/8" 7/8" A24R Metal & Stainless Cutting & Grinding 10,100 10

DW8438 6" 1/8" 5/8"-11 A24R Metal & Stainless Cutting & Grinding 10,100 10

DW8486 7" 1/8" 7/8" A24R Metal & Stainless Cutting & Grinding 8,700 10

DW8437 7" 1/8" 5/8"-11 A24R Metal & Stainless Cutting & Grinding 8,700 10

DW8487 9" 1/8" 7/8" A24R Metal & Stainless Cutting & Grinding 6,600 10

DW8439 9" 1/8" 5/8"-11 A24R Metal & Stainless Cutting & Grinding 6,600 10

DW4419 4" 1/4" 5/8" A24R Metal & Stainless Grinding 15,200 25

DW4514 4-1/2" 1/4" 7/8" A24R Metal & Stainless Grinding 13,300 25

DW4514B5 4-1/2" 1/4" 7/8" A24R Metal & Stainless Grinding 13,300 5

DW4523 4-1/2" 1/4" 5/8"-11 A24R Metal & Stainless Grinding 13,300 10

DW4619 5" 1/4" 7/8" A24R Metal & Stainless Grinding 12,200 25

DW4623 5" 1/4" 5/8"-11 A24R Metal & Stainless Grinding 12,200 10

DW4624 6" 1/4" 7/8" A24R Metal & Stainless Grinding 10,100 10

DW4626 6" 1/4" 5/8"-11 A24R Metal & Stainless Grinding 10,100 10

DW4719 7" 1/4" 7/8" A24R Metal & Stainless Grinding 8,700 10

DW4999 7" 1/4" 5/8"-11 A24R Metal & Stainless Grinding 8,700 10

DW4949 9" 1/4" 7/8" A24R Metal & Stainless Grinding 6,600 10

DW4954 9" 1/4" 5/8"-11 A24R Metal & Stainless Grinding 6,600 10

(continued)

Pipeline Metal & Stainless Cutting & Grinding

1/4" Metal & Stainless Grinding

ACCESSORIES 57

ACCESSORIES

MASONRY CUTTING &

GRINDING WHEELS

TYPE 27 BONDED ABRASIVES (continued) Type 27

A = Diameter B = Thickness C = Arbor

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DW4428 4" 1/8" 5/8" C24R Masonry Cutting 15,200 25

DW4528 4-1/2" 1/8" 7/8" C24R Masonry Cutting 13,300 25

DW4552 4-1/2" 1/8" 5/8"-11 C24R Masonry Cutting 13,300 10

DW4628 5" 1/8" 7/8" C24R Masonry Cutting 12,200 25

DW4658 5" 1/8" 5/8"-11 C24R Masonry Cutting 12,200 10

DW4728 7" 1/8" 7/8" C24R Masonry Cutting 8,700 10

DW4758 7" 1/8" 5/8"-11 C24R Masonry Cutting 8,700 10

DW4928 9" 1/8" 7/8" C24R Masonry Cutting 6,600 10

DW4929 9" 1/8" 5/8"-11 C24R Masonry Cutting 6,600 10

DW4429 4" 1/4" 5/8" C24R Masonry Grinding 15,200 25

DW4524 4-1/2" 1/4" 7/8" C24R Masonry Grinding 13,300 25

DW4551 4-1/2" 1/4" 5/8"-11 C24R Masonry Grinding 13,300 10

DW4629 5" 1/4" 7/8" C24R Masonry Grinding 12,200 25

DW4553 5" 1/4" 5/8"-11 C24R Masonry Grinding 12,200 10

DW4554 7" 1/4" 7/8" C24R Masonry Grinding 8,700 10

DW4759 7" 1/4" 5/8"-11 C24R Masonry Grinding 8,700 10

DW4557 9" 1/4" 7/8" C24R Masonry Grinding 6,600 10

DW4959 9" 1/4" 5/8"-11 C24R Masonry Grinding 6,600 10

1/8" Masonry Cutting

1/4" Masonry Grinding

MASONRY

GRINDING

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DWA4500C 4" 1/4" 5/8" C24R Fast Masonry Grinding 15,200 25

DWA4501C 4-1/2" 1/4" 7/8" C24R Fast Masonry Grinding 13,300 25

DWA4514CH 7" 1/4" 5/8" -11 C24R Fast Masonry Grinding 8,700 10

1/4" Masonry Grinding

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DW8452 4-1/2" 1/8" 7/8" A30S Stainless Cutting 13,300 25

DW8452H 4-1/2" 1/8" 5/8"-11 A30S Stainless Cutting 13,300 10

DW8454 5" 1/8" 7/8" A30S Stainless Cutting 12,200 25

DW8454H 5" 1/8" 5/8"-11 A30S Stainless Cutting 12,200 10

DW8457 6" 1/8" 7/8" A30S Stainless Cutting 10,100 10

DW8457H 6" 1/8" 5/8"-11 A30S Stainless Cutting 10,100 10

DW8456 7" 1/8" 7/8" A30S Stainless Cutting 8,700 10

DW8456H 7" 1/8" 5/8"-11 A30S Stainless Cutting 8,700 10

DW8458 9" 1/8" 7/8" A30S Stainless Cutting 6,600 10

DW8458H 9" 1/8" 5/8"-11 A30S Stainless Cutting 6,600 10

DW8410 4" 1/4" 5/8" A30S Stainless Grinding 15,200 25

DW8414 4-1/2" 1/4" 7/8" A30S Stainless Grinding 13,300 25

DW8415 4-1/2" 1/4" 5/8"-11 A30S Stainless Grinding 13,300 10

DW8464 5" 1/4" 7/8" A30S Stainless Grinding 12,200 25

DW8416 5" 1/4" 5/8"-11 A30S Stainless Grinding 12,200 10

DW8465 6" 1/4" 7/8" A30S Stainless Grinding 10,100 10

DW8465H 6" 1/4" 5/8"-11 A30S Stainless Grinding 10,100 10

DW8466 7" 1/4" 7/8" A30S Stainless Grinding 8,700 10

DW8417 7" 1/4" 5/8"-11 A30S Stainless Grinding 8,700 10

DW8468 9" 1/4" 7/8" A30S Stainless Grinding 6,600 10

DW8419 9" 1/4" 5/8"-11 A30S Stainless Grinding 6,600 10

1/8" Stainless Steel Cutting CONTAMINANT-FREE

1/4" Stainless Steel Grinding CONTAMINANT-FREE

STAINLESS CUTTING &

GRINDING WHEELS

(continued on next page)

58 ACCESSORIES

ACCESSORIES

A = Diameter B = Thickness C = Arbor

Type 28

TYPE 28 BONDED ABRASIVES

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DW8445 7" 1/4" 7/8" A24R Flat Metal Grinding 8,700 10

DW8446 7" 1/4" 5/8"-11 A24R Flat Metal Grinding 8,700 10

DW8447 9" 1/4" 7/8" A24R Flat Metal Grinding 6,600 10

DW8448 9" 1/4" 5/8"-11 A24R Flat Metal Grinding 6,600 10

1/4" Metal Grinding

GRINDING

WHEELS

Type 27

A = Diameter B = Thickness C = Arbor

CAT # DIA. ARBOR GRIT MAX RPM PACK

DW8210 4-1/2" 7/8" Z40 13,300 10

DW8211 4-1/2" 7/8" Z60 13,300 10

DW8212 4-1/2" 7/8" Z80 13,300 10

DW8213 4-1/2" 7/8" Z120 13,300 10

DW8210H 4-1/2" 5/8"-11 Z40 13,300 5

DW8211H 4-1/2" 5/8"-11 Z60 13,300 5

DW8212H 4-1/2" 5/8"-11 Z80 13,300 5

CAT # DIA. ARBOR GRIT MAX RPM PACK

DW8213H 4-1/2" 5/8"-11 Z120 13,300 5

DW8214 5" 7/8" Z40 12,200 10

DW8215 5" 7/8" Z60 12,200 10

DW8216 5" 7/8" Z80 12,200 10

DW8217 5" 7/8" Z120 12,200 10

DW8214H 5" 5/8"-11 Z40 12,200 5

DW8215H 5" 5/8"-11 Z60 12,200 5

TYPE 27 FLAP DISCS

WEARABLE

BACKING

FLAP DISCS

TYPE 27 BONDED ABRASIVES (continued)

Type 11

A = Diameter B = Thickness C = Arbor

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

Metal

DW4960 4" 2" 5/8"-11 A16R Metal Surface Grinding 9,000 10

DW4962 5" 2" 5/8"-11 A16R Metal Surface Grinding 7,000 10

DW4964 6" 2" 5/8"-11 A16R Metal Surface Grinding 6,000 10

DW4961 4" 2" 5/8"-11 C16R Masonry Surface Grinding 9,000 10

DW4963 5" 2" 5/8"-11 C16R Masonry Surface Grinding 7,000 10

DW4965 6" 2" 5/8"-11 C16R Masonry Surface Grinding 6,000 10

Metal Grinding

Masonry Grinding

TYPE 11 BONDED ABRASIVES

CUP

WHEELS

Type 27

A = Diameter B = Thickness C = Arbor

CAT # DIA. THICKNESS ARBOR GRIT APPLICATION MAX RPM PACK

DW8400 4" 1/4" 5/8" A30N Aluminum Grinding 15,200 25

DW8404 4-1/2" 1/4" 7/8" A30N Aluminum Grinding 13,300 25

DW8405 4-1/2" 1/4" 5/8"-11 A30N Aluminum Grinding 13,300 10

DW8474 5" 1/4" 7/8" A30N Aluminum Grinding 12,200 25

DW8406 5" 1/4" 5/8"-11 A30N Aluminum Grinding 12,200 10

DW8476 7" 1/4" 7/8" A30N Aluminum Grinding 8,700 10

DW8407 7" 1/4" 5/8"-11 A30N Aluminum Grinding 8,700 10

DW8409 9" 1/4" 5/8"-11 A30N Aluminum Grinding 6,600 10

GRINDING

WHEELS

1/4" Aluminum Grinding

(continued on next page)

ACCESSORIES 59

ACCESSORIES

CAT # DIA. ARBOR GRIT MAX RPM PACK

DW8250 4-1/2" 7/8" Z40 13,300 10

DW8251 4-1/2" 7/8" Z60 13,300 10

DW8252 4-1/2" 7/8" Z80 13,300 10

DW8253 4-1/2" 7/8" Z120 13,300 10

DW8254 4-1/2" 5/8"-11 Z40 13,300 5

DW8255 4-1/2" 5/8"-11 Z60 13,300 5

DW8256 4-1/2" 5/8"-11 Z80 13,300 5

DW8257 4-1/2" 5/8"-11 Z120 13,300 5

DW8258 5" 7/8" Z40 12,200 10

DW8259 5" 7/8" Z60 12,200 10

DW8260 5" 7/8" Z80 12,200 10

DW8261 5" 7/8" Z120 12,200 10

DW8262 5" 5/8"-11 Z40 12,200 5

DW8263 5" 5/8"-11 Z60 12,200 5

DW8264 5" 5/8"-11 Z80 12,200 5

DW8265 5" 5/8"-11 Z120 12,200 5

CAT # DIA. ARBOR GRIT MAX RPM PACK

DW8274 6" 7/8" Z40 10,100 10

DW8275 6" 7/8" Z60 10,100 10

DW8276 6" 7/8" Z80 10,100 10

DW8277 6" 7/8" Z120 10,100 10

DW8274H 6" 5/8"-11 Z40 10,100 5

DW8275H 6" 5/8"-11 Z60 10,100 5

DW8276H 6" 5/8"-11 Z80 10,100 5

DW8277H 6" 5/8"-11 Z120 10,100 5

DW8266 7" 7/8" Z40 8,700 10

DW8267 7" 7/8" Z60 8,700 10

DW8268 7" 7/8" Z80 8,700 10

DW8269 7" 7/8" Z120 8,700 10

DW8270 7" 5/8"-11 Z40 8,700 5

DW8271 7" 5/8"-11 Z60 8,700 5

DW8272 7" 5/8"-11 Z80 8,700 5

DW8273 7" 5/8"-11 Z120 8,700 5

CAT # DIA. ARBOR GRIT MAX RPM PACK

DW8216H 5" 5/8"-11 Z80 12,200 5

DW8217H 5" 5/8"-11 Z120 12,200 5

DW8222 6" 7/8" Z40 10,100 10

DW8223 6" 7/8" Z60 10,100 10

DW8224 6" 7/8" Z80 10,100 10

DW8225 6" 7/8" Z120 10,100 10

DW8222H 6" 5/8"-11 Z40 10,100 5

DW8223H 6" 5/8"-11 Z60 10,100 5

DW8224H 6" 5/8"-11 Z80 10,100 5

CAT # DIA. ARBOR GRIT MAX RPM PACK

DW8225H 6" 5/8"-11 Z120 10,100 5

DW8218 7" 7/8" Z40 8,700 10

DW8219 7" 7/8" Z60 8,700 10

DW8220 7" 7/8" Z80 8,700 10

DW8221 7" 7/8" Z120 8,700 10

DW8218H 7" 5/8"-11 Z40 8,700 5

DW8219H 7" 5/8"-11 Z60 8,700 5

DW8220H 7" 5/8"-11 Z80 8,700 5

DW8221H 7" 5/8"-11 Z120 8,700 5

TYPE 27 FLAP DISCS (continued)

WEARABLE BACKING

FLAP DISCS (continued)

Type 27

A = Diameter B = Thickness C = Arbor

CAT # DIA. ARBOR GRIT MAX RPM PACK

DW8300 4" 5/8" Z36 15,200 10

DW8302 4" 5/8" Z60 15,200 10

DW8303 4" 5/8" Z80 15,200 10

DW8304 4" 5/8" Z120 15,200 10

DW8350 4-1/2" 7/8" Z24 13,300 10

DW8351 4-1/2" 7/8" Z40 13,300 10

DW8352 4-1/2" 7/8" Z60 13,300 10

DW8353 4-1/2" 7/8" Z80 13,300 10

DW8354 4-1/2" 7/8" Z120 13,300 10

DW8355 4-1/2" 5/8"-11 Z24 13,300 5

DW8356 4-1/2" 5/8"-11 Z40 13,300 5

DW8357 4-1/2" 5/8"-11 Z60 13,300 5

DW8358 4-1/2" 5/8"-11 Z80 13,300 5

DW8359 4-1/2" 5/8"-11 Z120 13,300 5

DW8360 5" 7/8" Z24 12,200 10

DW8361 5" 7/8" Z40 12,200 10

DW8362 5" 7/8" Z60 12,200 10

CAT # DIA. ARBOR GRIT MAX RPM PACK

DW8363 5" 7/8" Z80 12,200 10

DW8364 5" 7/8" Z120 12,200 10

DW8365 5" 5/8"-11 Z24 12,200 5

DW8366 5" 5/8"-11 Z40 12,200 5

DW8367 5" 5/8"-11 Z60 12,200 5

DW8368 5" 5/8"-11 Z80 12,200 5

DW8369 5" 5/8"-11 Z120 12,200 5

DW8370 7" 7/8" Z24 8,700 10

DW8371 7" 7/8" Z40 8,700 10

DW8372 7" 7/8" Z60 8,700 10

DW8373 7" 7/8" Z80 8,700 10

DW8374 7" 7/8" Z120 8,700 10

DW8375 7" 5/8"-11 Z24 8,700 5

DW8376 7" 5/8"-11 Z40 8,700 5

DW8377 7" 5/8"-11 Z60 8,700 5

DW8378 7" 5/8"-11 Z80 8,700 5

DW8379 7" 5/8"-11 Z120 8,700 5

FLAP

DISCS

FLAP

DISCS

CONTAMINANT-FREE

60 ACCESSORIES

ACCESSORIES

FIBER DISCS

CAT # DIA. ARBOR GRIT MAX RPM PACK

DW8336 4-1/2" 7/8" Z24 13,300 10

DW8306 4-1/2" 7/8" Z36 13,300 10

DW8308 4-1/2" 7/8" Z60 13,300 10

DW8309 4-1/2" 7/8" Z80 13,300 10

DW8310 4-1/2" 7/8" Z120 13,300 10

DW8337 4-1/2" 5/8"-11 Z24 13,300 5

DW8311 4-1/2" 5/8"-11 Z36 13,300 5

DW8312 4-1/2" 5/8"-11 Z60 13,300 5

DW8313 4-1/2" 5/8"-11 Z80 13,300 5

DW8314 4-1/2" 5/8"-11 Z120 13,300 5

DW8338 5" 7/8" Z24 12,200 10

DW8315 5" 7/8" Z36 12,200 10

DW8317 5" 7/8" Z60 12,200 10

DW8318 5" 7/8" Z80 12,200 10

DW8319 5" 7/8" Z120 12,200 10

DW8339 5" 5/8"-11 Z24 12,200 5

DW8332 5" 5/8"-11 Z36 12,200 5

DW8333 5" 5/8"-11 Z60 12,200 5

DW8334 5" 5/8"-11 Z80 12,200 5

Type 29

A = Diameter C = Arbor

TYPE 29 FLAP DISCS

FLAP DISCS

CAT # DIA. ARBOR GRIT MAX RPM PACK

DWA8301H 4" 3/8"-24 36 15,200 5

DWA8305H 4" 3/8"-24 60 15,200 5

DWA8307H 4" 3/8"-24 80 15,200 5

DWA8201 4" 5/8" 40 15,200 10

DWA8202 4" 5/8" 60 15,200 10

DWA8203 4" 5/8" 80 15,200 10

DWA8206 4-1/2" 7/8" 40 13,300 10

DWA8206H 4-1/2" 5/8"-11 40 13,300 5

DWA8207 4-1/2" 7/8" 60 13,300 10

DWA8207H 4-1/2" 5/8"-11 60 13,300 5

DWA8208 4-1/2" 7/8" 80 13,300 10

DWA8208H 4-1/2" 5/8"-11 80 13,300 5

DWA8216H 7" 5/8"-11 40 8,700 5

DWA8217H 7" 5/8"-11 60 8,700 5

DWA8218H 7" 5/8"-11 80 8,700 5

CAT # DIA. ARBOR GRIT MAX RPM PACK

DW8335 5" 5/8"-11 Z120 12,200 5

DW8380 6" 7/8" Z40 10,100 10

DW8381 6" 7/8" Z60 10,100 10

DW8382 6" 7/8" Z80 10,100 10

DW8383 6" 7/8" Z120 10,100 10

DW8380H 6" 5/8"-11 Z40 10,100 5

DW8381H 6" 5/8"-11 Z60 10,100 5

DW8382H 6" 5/8"-11 Z80 10,100 5

DW8383H 6" 7/8" Z120 8,700 5

DW8340 7" 7/8" Z24 8,700 10

DW8321 7" 7/8" Z36 8,700 10

DW8323 7" 7/8" Z60 8,700 10

DW8324 7" 7/8" Z80 8,700 10

DW8325 7" 7/8" Z120 8,700 10

DW8341 7" 5/8"-11 Z24 8,700 5

DW8327 7" 5/8"-11 Z36 8,700 5

DW8329 7" 5/8"-11 Z60 8,700 5

DW8330 7" 5/8"-11 Z80 8,700 5

DW8331 7" 5/8"-11 Z120 8,700 5

CAT # DIA. ARBOR GRIT MAX RPM PACK

DARB5G0225 4-1/2" 7/8" 24 13,300 25

DARB5G0325 4-1/2" 7/8" 36 13,300 25

DARB5G0525 4-1/2" 7/8" 50 13,300 25

DARB5G0625 4-1/2" 7/8" 60 13,300 25

DARB5G0825 4-1/2" 7/8" 80 13,300 25

DARB5G1025 4-1/2" 7/8" 100 13,300 25

DARB5G1225 4-1/2" 7/8" 120 13,300 25

DARB5H0225 5" 7/8" 24 12,200 25

DARB5H0325 5" 7/8" 36 12,200 25

DARB5H0525 5" 7/8" 50 12,200 25

DARB5H0625 5" 7/8" 60 12,200 25

DARB5H0825 5" 7/8" 80 12,200 25

DARB5H1025 5" 7/8" 100 12,200 25

DARB5H1225 5" 7/8" 120 12,200 25

CAT # DIA. ARBOR GRIT MAX RPM PACK

DARB5K0225 7" 7/8" 24 8,700 25

DARB5K0325 7" 7/8" 36 8,700 25

DARB5K0525 7" 7/8" 50 8,700 25

DARB5K0625 7" 7/8" 60 8,700 25

DARB5K0825 7" 7/8" 80 8,700 25

DARB5K1025 7" 7/8" 100 8,700 25

DARB5K1225 7" 7/8" 120 8,700 25

ZIRCONIA

COOL DISCTM

CAT # DIA. ARBOR GRIT MAX RPM PACK

DARB6G0225 4-1/2" 7/8" 24 13,300 25

DARB6G0325 4-1/2" 7/8" 36 13,300 25

DARB6G0525 4-1/2" 7/8" 50 13,300 25

DARB6H0225 5" 7/8" 24 12,200 25

DARB6H0325 5" 7/8" 36 12,200 25

DARB6H0525 5" 7/8" 50 12,200 25

DARB6K0225 7" 7/8" 24 8,700 25

DARB6K0325 7" 7/8" 36 8,700 25

DARB6K0525 7" 7/8" 50 8,700 25

CAT # DIA. ARBOR GRIT MAX RPM PACK

DARC6G0215 4-1/2" Quick Lock 24 13,300 15

DARC6G0315 4-1/2" Quick Lock 36 13,300 15

DARC6G0515 4-1/2" Quick Lock 50 13,300 15

DARC6H0215 5" Quick Lock 24 12,200 15

DARC6H0315 5" Quick Lock 36 12,200 15

DARC6H0515 5" Quick Lock 50 12,200 15

DARC6K0215 7" Quick Lock 24 8,700 15

DARC6K0315 7" Quick Lock 36 8,700 15

DARC6K0515 7" Quick Lock 50 8,700 15

CERAMIC

CAT # DIA. ARBOR GRIT MAX RPM PACK

DARC5G0215 4-1/2" Quick Lock 24 13,300 15

DARC5G0315 4-1/2" Quick Lock 36 13,300 15

DARC5G0515 4-1/2" Quick Lock 50 13,300 15

DARC5G0615 4-1/2" Quick Lock 60 13,300 15

DARC5G0815 4-1/2" Quick Lock 80 13,300 15

DARC5H0215 5" Quick Lock 24 12,200 15

DARC5H0315 5" Quick Lock 36 12,200 15

DARC5H0515 5" Quick Lock 50 12,200 15

DARC5H0615 5" Quick Lock 60 12,200 15

DARC5H0815 5" Quick Lock 80 12,200 15

DARC5K0215 7" Quick Lock 24 8,700 15

DARC5K0315 7" Quick Lock 36 8,700 15

DARC5K0515 7" Quick Lock 50 8,700 15

DARC5KO615 7" Quick Lock 60 8,700 15

DARC5K0815 7" Quick Lock 80 8,700 15

CONTAMINANT-FREE

(continued on next page)

ACCESSORIES 61

ACCESSORIES

FIBER DISCS (continued)

CAT # DIA. ARBOR GRIT MAX RPM PACK

DARB4G0225 4-1/2" 7/8" 24 13,300 25

DARB4G0325 4-1/2" 7/8" 36 13,300 25

DARB4G0525 4-1/2" 7/8" 50 13,300 25

DARB4G0625 4-1/2" 7/8" 60 13,300 25

DARB4G0825 4-1/2" 7/8" 80 13,300 25

DARB4H0225 5" 7/8" 24 12,200 25

DARB4H0325 5" 7/8" 36 12,200 25

DARB4H0525 5" 7/8" 50 12,200 25

DARB4H0625 5" 7/8" 60 12,200 25

DARB4H0825 5" 7/8" 80 12,200 25

DARB4K0225 7" 7/8" 24 8,700 25

DARB4K0325 7" 7/8" 36 8,700 25

DARB4K0525 7" 7/8" 50 8,700 25

DARB4K0625 7" 7/8" 60 8,700 25

DARB4K0825 7" 7/8" 80 8,700 25

CAT # DIA. ARBOR GRIT MAX RPM PACK

DARC4G0215 4-1/2" Quick Lock 24 13,300 15

DARC4G0315 4-1/2" Quick Lock 36 13,300 15

DARC4G0515 4-1/2" Quick Lock 50 13,300 15

DARC4G0615 4-1/2" Quick Lock 60 13,300 15

DARC4G0815 4-1/2" Quick Lock 80 13,300 15

DARC4H0215 5" Quick Lock 24 12,200 15

DARC4H0315 5" Quick Lock 36 12,200 15

DARC4H0515 5" Quick Lock 50 12,200 15

DARC4H0615 5" Quick Lock 60 12,200 15

DARC4H0815 5" Quick Lock 80 12,200 15

DARC4K0215 7" Quick Lock 24 8,700 15

DARC4K0315 7" Quick Lock 36 8,700 15

DARC4K0515 7" Quick Lock 50 8,700 15

DARC4K0615 7" Quick Lock 60 8,700 15

DARC4K0815 7" Quick Lock 80 8,700 15

ZIRCONIA

CAT # DIA. ARBOR GRIT MAX RPM PACK

DARB1F0305 4" 5/8" 36 15,200 5

DARB1F0605 4" 5/8" 60 15,200 5

DARB1F0805 4" 5/8" 80 15,200 5

DARB1G0205 4-1/2" 7/8" 24 13,300 5

DARB1G0305 4-1/2" 7/8" 36 13,300 5

DARB1G0605 4-1/2" 7/8" 60 13,300 5

DARB1G0805 4-1/2" 7/8" 80 13,300 5

DARB1H0205 5" 7/8" 24 12,200 5

DARB1H0305 5" 7/8" 36 12,200 5

DARB1H0605 5" 7/8" 60 12,200 5

DARB1H0805 5" 7/8" 80 12,200 5

DARB1K0205 7" 7/8" 24 8,700 5

DARB1K0305 7" 7/8" 36 8,700 5

DARB1K0605 7" 7/8" 60 8,700 5

DARB1K0805 7" 7/8" 80 8,700 5

DARB1F0325 4" 5/8" 36 15,200 25

DARB1F0525 4" 5/8" 50 15,200 25

DARB1F0625 4" 5/8" 60 15,200 25

DARB1F0825 4" 5/8" 80 15,200 25

DARB1F1025 4" 5/8" 100 15,200 25

DARB1F1225 4" 5/8" 120 15,200 25

DARB1G0125 4-1/2" 7/8" 16 13,300 25

DARB1G0225 4-1/2" 7/8" 24 13,300 25

CAT # DIA. ARBOR GRIT MAX RPM PACK

DARB1G0325 4-1/2" 7/8" 36 13,300 25

DARB1G0525 4-1/2" 7/8" 50 13,300 25

DARB1G0625 4-1/2" 7/8" 60 13,300 25

DARB1G0825 4-1/2" 7/8" 80 13,300 25

DARB1G1025 4-1/2" 7/8" 100 13,300 25

DARB1G1225 4-1/2" 7/8" 120 13,300 25

DARB1H0125 5" 7/8" 16 15,200 25

DARB1H0225 5" 7/8" 24 15,200 25

DARB1H0325 5" 7/8" 36 13,300 25

DARB1H0525 5" 7/8" 50 13,300 25

DARB1H0625 5" 7/8" 60 13,300 25

DARB1H0825 5" 7/8" 80 12,200 25

DARB1H1025 5" 7/8" 100 12,200 25

DARB1H1225 5" 7/8" 120 12,200 25

DARB1K0125 7" 7/8" 16 8,700 25

DARB1K0225 7" 7/8" 24 8,700 25

DARB1K0325 7" 7/8" 36 8,700 25

DARB1K0525 7" 7/8" 50 8,700 25

DARB1K0625 7" 7/8" 60 8,700 25

DARB1K0825 7" 7/8" 80 8,700 25

DARB1K1025 7" 7/8" 100 8,700 25

DARB1K1225 7" 7/8" 120 8,700 25

CAT # DIA. ARBOR GRIT MAX RPM PACK

DARC1G0115 4-1/2" Quick Lock 16 13,300 15

DARC1G0215 4-1/2" Quick Lock 24 13,300 15

DARC1G0315 4-1/2" Quick Lock 36 13,300 15

DARC1G0515 4-1/2" Quick Lock 50 13,300 15

DARC1G0615 4-1/2" Quick Lock 60 13,300 15

DARC1G0815 4-1/2" Quick Lock 80 13,300 15

DARC1H0115 5" Quick Lock 16 12,200 15

DARC1H0215 5" Quick Lock 24 12,200 15

DARC1H0315 5" Quick Lock 36 12,200 15

DARC1H0515 5" Quick Lock 50 12,200 15

DARC1H0615 5" Quick Lock 60 12,200 15

DARC1H0815 5" Quick Lock 80 12,200 15

DARC1K0115 7" Quick Lock 16 8,700 15

DARC1K0215 7" Quick Lock 24 8,700 15

DARC1K0315 7" Quick Lock 36 8,700 15

DARC1K0515 7" Quick Lock 50 8,700 15

DARC1K0615 7" Quick Lock 60 8,700 15

DARC1K0815 7" Quick Lock 80 8,700 15

ALUMINUM

OXIDE

62 ACCESSORIES

ACCESSORIES

FLAP WHEELS

CAT # DIA. ARBOR GRIT MAX RPM PACK

DAGH1G0410 4-1/2" 5/8"-11 40 13,300 10

DAGH1G0610 4-1/2" 5/8"-11 60 13,300 10

CAT # DIA. ARBOR GRIT MAX RPM PACK

DAGH1G0810 4-1/2" 5/8"-11 80 13,300 10

DAGH1G1210 4-1/2" 5/8"-11 120 13,300 10

CAT # DIA. WIDTH SHAFT GRIT MAX RPM PACK

DAFE1P0410 3/4" 3/4" 1/4" 40 25,000 10

DAFE1P0610 3/4" 3/4" 1/4" 60 25,000 10

DAFE1P0810 3/4" 3/4" 1/4" 80 25,000 10

DAFE1P1210 3/4" 3/4" 1/4" 120 25,000 10

DAFE1A0410 1" 1/2" 1/4" 40 25,000 10

DAFE1A0610 1" 1/2" 1/4" 60 25,000 10

DAFE1A0810 1" 1/2" 1/4" 80 25,000 10

DAFE1A1210 1" 1/2" 1/4" 120 25,000 10

DAFE1A1810 1" 1/2" 1/4" 180 25,000 10

DAFE1A2410 1" 1/2" 1/4" 240 25,000 10

DAFE1B0410 1" 1" 1/4" 40 25,000 10

DAFE1B0610 1" 1" 1/4" 60 25,000 10

DAFE1B0810 1" 1" 1/4" 80 25,000 10

DAFE1B1210 1" 1" 1/4" 120 25,000 10

DAFE1B1810 1" 1" 1/4" 180 25,000 10

DAFE1B2410 1" 1" 1/4" 240 25,000 10

DAFE1D0410 1-1/2" 1" 1/4" 40 25,000 10

DAFE1D0610 1-1/2" 1" 1/4" 60 25,000 10

DAFE1D0810 1-1/2" 1" 1/4" 80 25,000 10

DAFE1D1210 1-1/2" 1" 1/4" 120 25,000 10

DAFE1D1810 1-1/2" 1" 1/4" 180 25,000 10

DAFE1D2410 1-1/2" 1" 1/4" 240 25,000 10

DAFE1E0410 2" 1/2" 1/4" 40 25,000 10

DAFE1E0610 2" 1/2" 1/4" 60 25,000 10

DAFE1E0810 2" 1/2" 1/4" 80 25,000 10

DAFE1E1210 2" 1/2" 1/4" 120 25,000 10

DAFE1E1810 2" 1/2" 1/4" 180 25,000 10

DAFE1E2410 2" 1/2" 1/4" 240 25,000 10

DAFE1R0410 2" 3/4" 1/4" 40 25,000 10

DAFE1R0610 2" 3/4" 1/4" 60 25,000 10

DAFE1R0810 2" 3/4" 1/4" 80 25,000 10

DAFE1R1210 2" 3/4" 1/4" 120 25,000 10

DAFE1R1810 2" 3/4" 1/4" 180 25,000 10

CAT # DIA. WIDTH SHAFT GRIT MAX RPM PACK

DAFE1R2410 2" 3/4" 1/4" 240 25,000 10

DAFE1F0410 2" 1" 1/4" 40 25,000 10

DAFE1F0610 2" 1" 1/4" 60 25,000 10

DAFE1F0810 2" 1" 1/4" 80 25,000 10

DAFE1F1210 2" 1" 1/4" 120 25,000 10

DAFE1F1810 2" 1" 1/4" 180 25,000 10

DAFE1F2410 2" 1" 1/4" 240 25,000 10

DAFE1Q0410 2-1/2" 1" 1/4" 40 25,000 10

DAFE1Q0610 2-1/2" 1" 1/4" 60 25,000 10

DAFE1Q0810 2-1/2" 1" 1/4" 80 25,000 10

DAFE1Q1210 2-1/2" 1" 1/4" 120 25,000 10

DAFE1Q1810 2-1/2" 1" 1/4" 180 25,000 10

DAFE1Q2410 2-1/2" 1" 1/4" 240 25,000 10

DAFE1G0410 3" 1/2" 1/4" 40 20,000 10

DAFE1G0610 3" 1/2" 1/4" 60 20,000 10

DAFE1G0810 3" 1/2" 1/4" 80 20,000 10

DAFE1G1210 3" 1/2" 1/4" 120 20,000 10

DAFE1G1810 3" 1/2" 1/4" 180 20,000 10

DAFE1G2410 3" 1/2" 1/4" 240 20,000 10

DAFE1H0410 3" 1" 1/4" 40 20,000 10

DAFE1H0610 3" 1" 1/4" 60 20,000 10

DAFE1H0810 3" 1" 1/4" 80 20,000 10

DAFE1H1210 3" 1" 1/4" 120 20,000 10

DAFE1H1810 3" 1" 1/4" 180 20,000 10

DAFE1H2410 3" 1" 1/4" 240 20,000 10

DAFK1M0510 6-1/2" 1" 1" 50 5,800 10

DAFK1M0610 6-1/2" 1" 1" 60 5,800 10

DAFK1M0810 6-1/2" 1" 1" 80 5,800 10

DAFK1M1210 6-1/2" 1" 1" 120 5,800 10

DAFK1N0510 6-1/2" 2" 1" 50 5,800 10

DAFK1N0610 6-1/2" 2" 1" 60 5,800 10

DAFK1N0810 6-1/2" 2" 1" 80 5,800 10

DAFK1N1210 6-1/2" 2" 1" 120 5,800 10

CAT # DIA. WIDTH SHAFT GRIT MAX RPM PACK

DAFE7F0610 2" 1" 1/4" 60 12,000 10

DAFE7F1010 2" 1" 1/4" 100 12,000 10

DAFE7F1510 2" 1" 1/4" 150 12,000 10

DAFE7K0610 3" 1-3/4" 1/4" 60 8,000 10

DAFE7K1010 3" 1-3/4" 1/4" 100 8,000 10

CAT # DIA. WIDTH SHAFT GRIT MAX RPM PACK

DAFE7K1510 3" 1-3/4" 1/4" 150 8,000 10

DAFE7L0610 4" 1-3/4" 1/4" 60 6,000 10

DAFE7L1010 4" 1-3/4" 1/4" 100 6,000 10

DAFE7L1510 4" 1-3/4" 1/4" 150 6,000 10

ANGLE GRINDER

FLAP WHEELS

FLAP

WHEELS

FINISHING

FLAP WHEELS

ACCESSORIES 63

ACCESSORIES

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALP5C031A 2" QMC 36 20,000 100

DALP5C051A 2" QMC 50 20,000 100

DALP5C061A 2" QMC 60 20,000 100

DALP5C081A 2" QMC 80 20,000 100

DALP5C121A 2" QMC 120 20,000 100

DALP5E0350 3" QMC 36 20,000 50

DALP5E0550 3" QMC 50 20,000 50

DALP5E0650 3" QMC 60 20,000 50

DALP5E0850 3" QMC 80 20,000 50

DALP5E1250 3" QMC 120 20,000 50

QUICK CHANGE DISCS

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALD5A031A 1" QDC 36 30,000 100

DALD5A051A 1" QDC 50 30,000 100

DALD5A061A 1" QDC 60 30,000 100

DALD5A081A 1" QDC 80 30,000 100

DALD5A121A 1" QDC 120 30,000 100

DALD5B031A 1-1/2" QDC 36 30,000 100

DALD5B051A 1-1/2" QDC 50 30,000 100

DALD5B061A 1-1/2" QDC 60 30,000 100

DALD5B081A 1-1/2" QDC 80 30,000 100

DALD5B121A 1-1/2" QDC 120 30,000 100

DALD5C031A 2" QDC 36 20,000 100

DALD5C051A 2" QDC 50 20,000 100

DALD5C061A 2" QDC 60 20,000 100

DALD5C081A 2" QDC 80 20,000 100

DALD5C121A 2" QDC 120 20,000 100

DALD5E0350 3" QDC 36 20,000 50

DALD5E0550 3" QDC 50 20,000 50

DALD5E0650 3" QDC 60 20,000 50

DALD5E0850 3" QDC 80 20,000 50

DALD5E1250 3" QDC 120 20,000 50

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALN5B031A 1-1/2" QRC 36 30,000 100

DALN5B051A 1-1/2" QRC 50 30,000 100

DALN5B061A 1-1/2" QRC 60 30,000 100

DALN5B081A 1-1/2" QRC 80 30,000 100

DALN5B121A 1-1/2" QRC 120 30,000 100

DALN5C031A 2" QRC 36 20,000 100

DALN5C051A 2" QRC 50 20,000 100

DALN5C061A 2" QRC 60 20,000 100

DALN5C081A 2" QRC 80 20,000 100

DALN5C121A 2" QRC 120 20,000 100

DALN5E0350 3" QRC 36 20,000 50

DALN5E0550 3" QRC 50 20,000 50

DALN5E0650 3" QRC 60 20,000 50

DALN5E0850 3" QRC 80 20,000 50

DALN5E1250 3" QRC 120 20,000 50

DALP5B031A 1-1/2" QMC 36 30,000 100

DALP5B051A 1-1/2" QMC 50 30,000 100

DALP5B061A 1-1/2" QMC 60 30,000 100

DALP5B081A 1-1/2" QMC 80 30,000 100

DALP5B121A 1-1/2" QMC 120 30,000 100

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALD6C031A 2" QDC 36 20,000 100

DALD6C051A 2" QDC 50 20,000 100

DALD6C061A 2" QDC 60 20,000 100

DALD6E0350 3" QDC 36 20,000 50

DALD6E0550 3" QDC 50 20,000 50

DALD6E0650 3" QDC 60 20,000 50

DALN6C031A 2" QRC 36 20,000 100

DALN6C051A 2" QRC 50 20,000 100

DALN6C061A 2" QRC 60 20,000 100

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALN6E0350 3" QRC 36 20,000 50

DALN6E0550 3" QRC 50 20,000 50

DALN6E0650 3" QRC 60 20,000 50

DALP6C031A 2" QMC 36 20,000 100

DALP6C051A 2" QMC 50 20,000 100

DALP6C061A 2" QMC 60 20,000 100

DALP6E0350 3" QMC 36 20,000 50

DALP6E0550 3" QMC 50 20,000 50

DALP6E0650 3" QMC 60 20,000 50

CERAMIC

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALD4A021A 1" QDC 24 30,000 100

DALD4A031A 1" QDC 36 30,000 100

DALD4A041A 1" QDC 40 30,000 100

DALD4A051A 1" QDC 50 30,000 100

DALD4A061A 1" QDC 60 30,000 100

DALD4A081A 1" QDC 80 30,000 100

DALD4A121A 1" QDC 120 30,000 100

DALD4B021A 1-1/2" QDC 24 30,000 100

DALD4B031A 1-1/2" QDC 36 30,000 100

DALD4B041A 1-1/2" QDC 40 30,000 100

DALD4B051A 1-1/2" QDC 50 30,000 100

DALD4B061A 1-1/2" QDC 60 30,000 100

DALD4B081A 1-1/2" QDC 80 30,000 100

DALD4B121A 1-1/2" QDC 120 30,000 100

DALD4C021A 2" QDC 24 20,000 100

DALD4C031A 2" QDC 36 20,000 100

DALD4C041A 2" QDC 40 20,000 100

DALD4C051A 2" QDC 50 20,000 100

DALD4C061A 2" QDC 60 20,000 100

DALD4C081A 2" QDC 80 20,000 100

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALD4C121A 2" QDC 120 20,000 100

DALD4E0250 3" QDC 24 20,000 50

DALD4E0350 3" QDC 36 20,000 50

DALD4E0450 3" QDC 40 20,000 50

DALD4E0550 3" QDC 50 20,000 50

DALD4E0650 3" QDC 60 20,000 50

DALD4E0850 3" QDC 80 20,000 50

DALD4E1250 3" QDC 120 20,000 50

DALN4B021A 1-1/2" QRC 24 30,000 100

DALN4B031A 1-1/2" QRC 36 30,000 100

DALN4B041A 1-1/2" QRC 40 30,000 100

DALN4B051A 1-1/2" QRC 50 30,000 100

DALN4B061A 1-1/2" QRC 60 30,000 100

DALN4B081A 1-1/2" QRC 80 30,000 100

DALN4B121A 1-1/2" QRC 120 30,000 100

DALN4C021A 2" QRC 24 20,000 100

DALN4C031A 2" QRC 36 20,000 100

DALN4C041A 2" QRC 40 20,000 100

DALN4C051A 2" QRC 50 20,000 100

DALN4C061A 2" QRC 60 20,000 100

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALN4C081A 2" QRC 80 20,000 100

DALN4C121A 2" QRC 120 20,000 100

DALN4E0250 3" QRC 24 20,000 50

DALN4E0350 3" QRC 36 20,000 50

DALN4E0450 3" QRC 40 20,000 50

DALN4E0550 3" QRC 50 20,000 50

DALN4E0650 3" QRC 60 20,000 50

DALN4E0850 3" QRC 80 20,000 50

DALN4E1250 3" QRC 120 20,000 50

DALP4B021A 1-1/2" QMC 24 30,000 100

DALP4B031A 1-1/2" QMC 36 30,000 100

DALP4B041A 1-1/2" QMC 40 30,000 100

ZIRCONIA

(continued

on next

page)

ZIRCONIA

COOL DISCTM

64 ACCESSORIES

ACCESSORIES

QUICK CHANGE DISCS (continued)

Arbor Types

QMCQRCQDC

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALD7ACR25 1" QDC Coarse 30,000 25

DALD7AMD25 1" QDC Medium 30,000 25

DALD7AFN25 1" QDC Fine 30,000 25

DALD7CCR25 2" QDC Coarse 20,000 25

DALD7CMD25 2" QDC Medium 20,000 25

DALD7CFN25 2" QDC Fine 20,000 25

DALD7ECR25 3" QDC Coarse 20,000 25

DALD7EMD25 3" QDC Medium 20,000 25

DALD7EFN25 3" QDC Fine 20,000 25

DALN7CCR25 2" QRC Coarse 20,000 25

DALN7CMD25 2" QRC Medium 20,000 25

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALN7CFN25 2" QRC Fine 20,000 25

DALN7ECR25 3" QRC Coarse 20,000 25

DALN7EMD25 3" QRC Medium 20,000 25

DALN7EFN25 3" QRC Fine 20,000 25

DALP7CCR25 2" QMC Coarse 20,000 25

DALP7CMD25 2" QMC Medium 20,000 25

DALP7CFN25 2" QMC Fine 20,000 25

DALP7ECR25 3" QMC Coarse 20,000 25

DALP7EMD25 3" QMC Medium 20,000 25

DALP7EFN25 3" QMC Fine 20,000 25

SURFACE

FINISHING,

NON-WOVEN

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALD1A021A 1" QDC 24 30,000 100

DALD1A031A 1" QDC 36 30,000 100

DALD1A041A 1" QDC 40 30,000 100

DALD1A051A 1" QDC 50 30,000 100

DALD1A061A 1" QDC 60 30,000 100

DALD1A081A 1" QDC 80 30,000 100

DALD1A121A 1" QDC 120 30,000 100

DALD1B021A 1-1/2" QDC 24 30,000 100

DALD1B031A 1-1/2" QDC 36 30,000 100

DALD1B041A 1-1/2" QDC 40 30,000 100

DALD1B051A 1-1/2" QDC 50 30,000 100

DALD1B061A 1-1/2" QDC 60 30,000 100

DALD1B081A 1-1/2" QDC 80 30,000 100

DALD1B121A 1-1/2" QDC 120 30,000 100

DALD1C021A 2" QDC 24 20,000 100

DALD1C031A 2" QDC 36 20,000 100

DALD1C041A 2" QDC 40 20,000 100

DALD1C051A 2" QDC 50 20,000 100

DALD1C061A 2" QDC 60 20,000 100

DALD1C081A 2" QDC 80 20,000 100

DALD1C121A 2" QDC 120 20,000 100

DALD1E0250 3" QDC 24 20,000 50

DALD1E0350 3" QDC 36 20,000 50

DALD1E0450 3" QDC 40 20,000 50

DALD1E0550 3" QDC 50 20,000 50

DALD1E0650 3" QDC 60 20,000 50

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALD1E0850 3" QDC 80 20,000 50

DALD1E1250 3" QDC 120 20,000 50

DALN1B021A 1-1/2" QRC 24 30,000 100

DALN1B031A 1-1/2" QRC 36 30,000 100

DALN1B041A 1-1/2" QRC 40 30,000 100

DALN1B051A 1-1/2" QRC 50 30,000 100

DALN1B061A 1-1/2" QRC 60 30,000 100

DALN1B081A 1-1/2" QRC 80 30,000 100

DALN1B121A 1-1/2" QRC 120 30,000 100

DALN1C021A 2" QRC 24 20,000 100

DALN1C031A 2" QRC 36 20,000 100

DALN1C041A 2" QRC 40 20,000 100

DALN1C051A 2" QRC 50 20,000 100

DALN1C061A 2" QRC 60 20,000 100

DALN1C081A 2" QRC 80 20,000 100

DALN1C121A 2" QRC 120 20,000 100

DALN1E0350 3" QRC 24 20,000 50

DALN1E0350 3" QRC 36 20,000 50

DALN1E0450 3" QRC 40 20,000 50

DALN1E0550 3" QRC 50 20,000 50

DALN1E0650 3" QRC 60 20,000 50

DALN1E0850 3" QRC 80 20,000 50

DALN1E1250 3" QRC 120 20,000 50

DALP1B021A 1-1/2" QMC 24 30,000 100

DALP1B031A 1-1/2" QMC 36 30,000 100

DALP1B041A 1-1/2" QMC 40 30,000 100

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALP1B051A 1-1/2" QMC 50 30,000 100

DALP1B061A 1-1/2" QMC 60 30,000 100

DALP1B081A 1-1/2" QMC 80 30,000 100

DALP1B121A 1-1/2" QMC 120 30,000 100

DALP1C021A 2" QMC 24 20,000 100

DALP1C031A 2" QMC 36 20,000 100

DALP1C041A 2" QMC 40 20,000 100

DALP1C051A 2" QMC 50 20,000 100

DALP1C061A 2" QMC 60 20,000 100

DALP1C081A 2" QMC 80 20,000 100

DALP1C121A 2" QMC 120 20,000 100

DALP1E0250 3" QMC 24 20,000 50

DALP1E0350 3" QMC 36 20,000 50

DALP1E0450 3" QMC 40 20,000 50

DALP1E0550 3" QMC 50 20,000 50

DALP1E0650 3" QMC 60 20,000 50

DALP1E0850 3" QMC 80 20,000 50

DALP1E1250 3" QMC 120 20,000 50

ALUMINUM

OXIDE

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALP4B051A 1-1/2" QMC 50 30,000 100

DALP4B061A 1-1/2" QMC 60 30,000 100

DALP4B081A 1-1/2" QMC 80 30,000 100

DALP4B121A 1-1/2" QMC 120 30,000 100

DALP4C021A 2" QMC 24 20,000 100

DALP4C031A 2" QMC 36 20,000 100

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALP4C041A 2" QMC 40 20,000 100

DALP4C051A 2" QMC 50 20,000 100

DALP4C061A 2" QMC 60 20,000 100

DALP4C081A 2" QMC 80 20,000 100

DALP4C121A 2" QMC 120 20,000 100

DALP4E0250 3" QMC 24 20,000 50

CAT # DIA. ARBOR GRIT MAX RPM PACK

DALP4E0350 3" QMC 36 20,000 50

DALP4E0450 3" QMC 40 20,000 50

DALP4E0550 3" QMC 50 20,000 50

DALP4E0650 3" QMC 60 20,000 50

DALP4E0850 3" QMC 80 20,000 50

DALP4E1250 3" QMC 120 20,000 50

ZIRCONIA

(continued)

ACCESSORIES 65

ACCESSORIES

BELTS

CAT # WIDTH LENGTH GRIT PACK

DABB1D0410 1/4" 18" 40 10

DABB1D0610 1/4" 18" 60 10

DABB1D0810 1/4" 18" 80 10

DABB1D1210 1/4" 18" 120 10

DABB1E0410 1/4" 24" 40 10

DABB1E0610 1/4" 24" 60 10

DABB1E0810 1/4" 24" 80 10

DABB1E1210 1/4" 24" 120 10

DABC1G0410 3/8" 13" 40 10

CAT # WIDTH LENGTH GRIT PACK

DABD1E0810 1/2" 24" 80 10

DABD1E1210 1/2" 24" 120 10

DABF1D0410 3/4" 18" 40 10

DABF1D0610 3/4" 18" 60 10

DABF1D0810 3/4" 18" 80 10

DABF1D1210 3/4" 18" 120 10

DABF1H0410 3/4" 20-1/2" 40 10

DABF1H0610 3/4" 20-1/2" 60 10

DABF1H0810 3/4" 20-1/2" 80 10

DABF1H1210 3/4" 20-1/2" 120 10

CAT # WIDTH LENGTH GRIT PACK

DABC1G0610 3/8" 13" 60 10

DABC1G0810 3/8" 13" 80 10

DABC1G1210 3/8" 13" 120 10

DABD1D0410 1/2" 18" 40 10

DABD1D0610 1/2" 18" 60 10

DABD1D0810 1/2" 18" 80 10

DABD1D1210 1/2" 18" 120 10

DABD1E0410 1/2" 24" 40 10

DABD1E0610 1/2" 24" 60 10

ALUMINUM

OXIDE

CAT # WIDTH LENGTH GRIT PACK

DABD7DCR10 1/2" 18" Coarse 10

DABD7DMD10 1/2" 18" Medium 10

CAT # WIDTH LENGTH GRIT PACK

DABD7ECR03 1/2" 24" Coarse 5

DABD7EMD05 1/2" 24" Medium 5

CAT # WIDTH LENGTH GRIT PACK

DABF7DCR05 3/4" 18" Coarse 5

DABF7DMD05 3/4" 18" Medium 5

SURFACE

FINISHING,

NON-WOVEN

CARTRIDGE ROLLS

CAT # DIA. LENGTH PILOT SHAPE GRIT MAX RPM PACK

DACG1B061A 3/8" 1-1/2" 1/8" Straight 60 25,000 100

DACG1B081A 3/8" 1-1/2" 1/8" Straight 80 25,000 100

DACG1B121A 3/8" 1-1/2" 1/8" Straight 120 25,000 100

DACG1B181A 3/8" 1-1/2" 1/8" Straight 180 25,000 100

DACG1C061A 1/2" 1" 1/8" Straight 60 25,000 100

DACG1C081A 1/2" 1" 1/8" Straight 80 25,000 100

DACG1C121A 1/2" 1" 1/8" Straight 120 25,000 100

DACG1D041A 1/2" 1-1/2" 1/8" Straight 40 25,000 100

DACG1D061A 1/2" 1-1/2" 1/8" Straight 60 25,000 100

DACG1D081A 1/2" 1-1/2" 1/8" Straight 80 25,000 100

DACG1D121A 1/2" 1-1/2" 1/8" Straight 120 25,000 100

DACG1D181A 1/2" 1-1/2" 1/8" Straight 180 25,000 100

DACG1D241A 1/2" 1-1/2" 1/8" Straight 240 25,000 100

DACG1E061A 1/2" 2" 1/8" Straight 60 25,000 50

DACG1E081A 1/2" 2" 1/8" Straight 80 25,000 50

DACG1E121A 1/2" 2" 1/8" Straight 120 25,000 50

DACG1F061A 3/4" 1-1/2" 1/8" Straight 60 25,000 100

CAT # DIA. LENGTH PILOT SHAPE GRIT MAX RPM PACK

DACG1F061A 3/4" 1-1/2" 1/8" Straight 80 25,000 100

DATG1A061A 3/8" 1" 1/8" Taper 60 25,000 50

DATG1A081A 3/8" 1" 1/8" Taper 80 25,000 50

DATG1A121A 3/8" 1" 1/8" Taper 120 25,000 50

DATG1A181A 3/8" 1" 1/8" Taper 180 25,000 100

DATG1B081A 3/8" 1-1/2" 1/8" Taper 80 25,000 100

DATG1B121A 3/8" 1-1/2" 1/8" Taper 120 25,000 100

DATG1C061A 1/2" 1" 1/8" Taper 60 25,000 100

DATG1C081A 1/2" 1" 1/8" Taper 80 25,000 100

DATG1D061A 1/2" 1-1/2" 1/8" Taper 60 25,000 100

DATG1D081A 1/2" 1-1/2" 1/8" Taper 80 25,000 100

DATG1D121A 1/2" 1-1/2" 1/8" Taper 120 25,000 100

DATG1D181A 1/2" 1-1/2" 1/8" Taper 180 25,000 100

DATG1E061A 1/2" 2" 1/8" Taper 60 25,000 100

DATG1E081A 1/2" 2" 1/8" Taper 80 25,000 100

DATG1E121A 1/2" 2" 1/8" Taper 120 25,000 100

ALUMINUM

OXIDE

CAT # WIDTH LENGTH GRIT PACK

DABB4D0310 1/4" 18" 36 10

DABB4D0410 1/4" 18" 40 10

DABB4D0610 1/4" 18" 60 10

DABB4D0810 1/4" 18" 80 10

DABB4D1210 1/4" 18" 120 10

DABB4E0310 1/4" 24" 36 10

DABB4E0410 1/4" 24" 40 10

DABB4E0610 1/4" 24" 60 10

DABB4E0810 1/4" 24" 80 10

DABB4E1210 1/4" 24" 120 10

CAT # WIDTH LENGTH GRIT PACK

DABC4G0410 3/8" 13" 40 10

DABC4G0610 3/8" 13" 60 10

DABC4G0810 3/8" 13" 80 10

DABC4G1210 3/8" 13" 120 10

DABD4D0410 1/2" 18" 40 10

DABD4D0610 1/2" 18" 60 10

DABD4D0810 1/2" 18" 80 10

DABD4D1210 1/2" 18" 120 10

DABD4E0410 1/2" 24" 40 10

DABD4E0610 1/2" 24" 60 10

CAT # WIDTH LENGTH GRIT PACK

DABD4E0810 1/2" 24" 80 10

DABD4E1210 1/2" 24" 120 10

DABF4D0410 3/4" 18" 40 10

DABF4D0610 3/4" 18" 60 10

DABF4D0810 3/4" 18" 80 10

DABF4D1210 3/4" 18" 120 10

DABF4H0410 3/4" 20-1/2" 40 10

DABF4H0610 3/4" 20-1/2" 60 10

DABF4H0810 3/4" 20-1/2" 80 10

DABF4H1210 3/4" 20-1/2" 120 10

ZIRCONIA

66 ACCESSORIES

ACCESSORIES

SHOP ROLLS

CAT # HOLES DIA. GRIT PACK

DW4301 8 5" 80 5

DW4303 8 5" 120 5

DW4304 8 5" 150 5

DW4306 8 5" 220 5

DW4307 8 5" Asst. 5

DW4309 8 5" 80 25

DW4310 8 5" 100 25

DW4311 8 5" 120 25

DW4312 8 5" 150 25

DW4313 8 5" 180 25

DW4314 8 5" 220 25

PAPER DISCS

CAT # HOLES DIA. GRIT PACK

DW4331 6 6" 80 5

DW4333 6 6" 120 5

DW4334 6 6" 150 5

DW4336 6 6" 220 5

CAT # TYPE WIDTH LENGTH GRIT

DAK2110801 PSA 2-3/4" 10 Meters 80

DAK2111001 PSA 2-3/4" 10 Meters 100

DAK2111201 PSA 2-3/4" 10 Meters 120

DAK2111501 PSA 2-3/4" 10 Meters 150

DAK2111801 PSA 2-3/4" 10 Meters 180

DAK2112201 PSA 2-3/4" 10 Meters 220

DAK2113201 PSA 2-3/4" 10 Meters 320

ROLLS

5” HOOK & LOOP

RANDOM ORBIT DISCS 6” HOOK & LOOP

RANDOM ORBIT DISCS PAPER ROLLS

ALUMINUM OXIDE

CAT # LGTH WIDTH GRIT

DANG120401 50 Yards 1" 40

DANG120601 50 Yards 1" 60

DANG120801 50 Yards 1" 80

DANG121001 50 Yards 1" 100

DANG121201 50 Yards 1" 120

DANG121501 50 Yards 1" 150

DANG121801 50 Yards 1" 180

DANG122201 50 Yards 1" 220

DANG122401 50 Yards 1" 240

DANG123201 50 Yards 1" 320

DANG124001 50 Yards 1" 400

DANK120401 50 Yards 1-1/2" 40

DANK120601 50 Yards 1-1/2" 60

DANK120801 50 Yards 1-1/2" 80

DANK121001 50 Yards 1-1/2" 100

DANK121201 50 Yards 1-1/2" 120

DANK121501 50 Yards 1-1/2" 150

DANK121801 50 Yards 1-1/2" 180

DANK122201 50 Yards 1-1/2" 220

DANK122401 50 Yards 1-1/2" 240

DANK123201 50 Yards 1-1/2" 320

DANK124001 50 Yards 1-1/2" 400

DANL120401 50 Yards 2" 40

DANL120601 50 Yards 2" 60

DANL120801 50 Yards 2" 80

CAT # LGTH WIDTH GRIT

DANL121001 50 Yards 2" 100

DANL121201 50 Yards 2" 120

DANL121501 50 Yards 2" 150

DANL121801 50 Yards 2" 180

DANL122201 50 Yards 2" 220

DANL122401 50 Yards 2" 240

DANL123201 50 Yards 2" 320

DANL124001 50 Yards 2" 400

DANM120401 50 Yards 2-1/2" 40

DANM120601 50 Yards 2-1/2" 60

DANM120801 50 Yards 2-1/2" 80

DANM121001 50 Yards 2-1/2" 100

DANM121201 50 Yards 2-1/2" 120

DANM121501 50 Yards 2-1/2" 150

DANM121801 50 Yards 2-1/2" 180

DANM122201 50 Yards 2-1/2" 220

DANM122401 50 Yards 2-1/2" 240

DANM123201 50 Yards 2-1/2" 320

DANM124001 50 Yards 2-1/2" 400

DANN120401 50 Yards 3" 40

DANN120601 50 Yards 3" 60

DANN120801 50 Yards 3" 80

DANN121001 50 Yards 3" 100

DANN121201 50 Yards 3" 120

DANN121501 50 Yards 3" 150

CAT # LGTH WIDTH GRIT

DANN121801 50 Yards 3" 180

DANN122201 50 Yards 3" 220

DANN122401 50 Yards 3" 240

DANN123201 50 Yards 3" 320

DANN124001 50 Yards 3" 400

DANP120401 50 Yards 3-1/2" 40

DANP120601 50 Yards 3-1/2" 60

DANP120801 50 Yards 3-1/2" 80

DANP121001 50 Yards 3-1/2" 100

DANP121201 50 Yards 3-1/2" 120

DANP121501 50 Yards 3-1/2" 150

DANP121801 50 Yards 3-1/2" 180

DANP122201 50 Yards 3-1/2" 220

DANP122401 50 Yards 3-1/2" 240

DANP123201 50 Yards 3-1/2" 320

DANP124001 50 Yards 3-1/2" 400

DANR120401 50 Yards 4" 40

DANR120601 50 Yards 4" 60

DANR120801 50 Yards 4" 80

DANR121001 50 Yards 4" 100

DANR121201 50 Yards 4" 120

DANR121501 50 Yards 4" 150

DANR121801 50 Yards 4" 180

DANR122201 50 Yards 4” 220

DANR122401 50 Yards 4" 240

CAT # LGTH WIDTH GRIT

DANR123201 50 Yards 4" 320

DANR124001 50 Yards 4" 400

DANS120401 50 Yards 4-1/2" 40

DANS120601 50 Yards 4-1/2" 60

DANS120801 50 Yards 4-1/2" 80

DANS121001 50 Yards 4-1/2" 100

DANS121201 50 Yards 4-1/2" 120

DANS121501 50 Yards 4-1/2" 150

DANS121801 50 Yards 4-1/2" 180

DANS122201 50 Yards 4-1/2" 220

DANS122401 50 Yards 4-1/2" 240

DANS123201 50 Yards 4-1/2" 320

DANS124001 50 Yards 4-1/2" 400

DANU120401 50 Yards 6" 40

DANU120601 50 Yards 6" 60

DANU120801 50 Yards 6" 80

DANU121001 50 Yards 6" 100

DANU121201 50 Yards 6" 120

DANU121501 50 Yards 6" 150

DANU121801 50 Yards 6" 180

DANU122201 50 Yards 6" 220

DANU122401 50 Yards 6" 240

DANU123201 50 Yards 6" 320

DANU124001 50 Yards 6" 400

ALUMINUM

OXIDE

CAT # LGTH WIDTH GRIT

DANG220401 50 Yards 1" 40

DANG220601 50 Yards 1" 60

DANG220801 50 Yards 1" 80

DANG221001 50 Yards 1" 100

DANG221201 50 Yards 1" 120

DANG221501 50 Yards 1" 150

DANG221801 50 Yards 1" 180

DANG222201 50 Yards 1" 220

DANG222401 50 Yards 1" 240

CAT # LGTH WIDTH GRIT

DANG223201 50 Yards 1" 320

DANG224001 50 Yards 1" 400

DANK220401 50 Yards 1-1/2" 40

DANK220601 50 Yards 1-1/2" 60

DANK220801 50 Yards 1-1/2" 80

DANK221001 50 Yards 1-1/2" 100

DANK221201 50 Yards 1-1/2" 120

DANK221501 50 Yards 1-1/2" 150

DANK221801 50 Yards 1-1/2" 180

CAT # LGTH WIDTH GRIT

DANK222201 50 Yards 1-1/2" 220

DANK222401 50 Yards 1-1/2" 240

DANK223201 50 Yards 1-1/2" 320

DANK224001 50 Yards 1-1/2" 400

DANL220401 50 Yards 2" 40

DANL220601 50 Yards 2" 60

DANL220801 50 Yards 2" 80

DANL221001 50 Yards 2" 100

DANL221201 50 Yards 2" 120

CAT # LGTH WIDTH GRIT

DANL221501 50 Yards 2" 150

DANL221801 50 Yards 2" 180

DANL222201 50 Yards 2" 220

DANL222401 50 Yards 2" 240

DANL223201 50 Yards 2" 320

DANL224001 50 Yards 2" 400

DANN220401 50 Yards 3" 40

DANN220601 50 Yards 3" 60

DANN220801 50 Yards 3" 80

ALUMINUM

OXIDE

(continued on next page)

ACCESSORIES 67

ACCESSORIES

NON-WOVEN DISCS**

NON-WOVEN

CAT # DIA. ARBOR GRIT PACK

DADA7NCR10 4" No Hole Coarse 10

DADA7NMD10 4" No Hole Medium 10

DADA7NFN10 4" No Hole Fine 10

DADB7NCR10 4" 5/8" Coarse 10

DADB7NMD10 4" 5/8" Medium 10

DADB7NFN10 4" 5/8" Fine 10

DADC7NCR10 4-1/2" No Hole Coarse 10

DADC7NMD10 4-1/2" No Hole Medium 10

CAT # DIA. ARBOR GRIT PACK

DADC7NFN10 4-1/2" No Hole Fine 10

DADD7NCR10 4-1/2" 7/8" Coarse 10

DADD7NMD10 4-1/2" 7/8" Medium 10

DADD7NFN10 4-1/2" 7/8" Fine 10

DADE7NCR10 5" No Hole Coarse 10

DADE7NMD10 5" No Hole Medium 10

DADE7NFN10 5" No Hole Fine 10

DADF7NCR10 5" 7/8" Coarse 10

CAT # LGTH WIDTH GRIT COLOR PACK

DAXU7ACR10 6" 9" Coarse Brown 10

DAXU7AGP10 6" 9" General Purpose Green 10

DAXU7AFN10 6" 9" Fine Maroon 10

DAXU7AVF10 6" 9" Very Fine Green 10

DAXU7AUF10 6" 9" Ultra Fine Gray 10

DAXU7ANA10 6" 9" No Abrasive White 10

CAT # DIA. ARBOR MAX RPM PACK

DAAB7GPW05 4-1/2" 7/8" 13,300 10

DAAH7GPW05 4-1/2" 5/8"-11 13,300 10

CAT # DIA. ARBOR GRIT MAX RPM PACK

DAAB7GCR05 4-1/2" 7/8" Coarse 13,300 5

DAAB7GMD05 4-1/2" 7/8" Medium 13,300 5

DAAB7GVF05 4-1/2" 7/8" Very Fine 13,300 5

DAAH7GCR05 4-1/2" 5/8"-11 Coarse 13,300 5

DAAH7GMD05 4-1/2" 5/8"-11 Medium 13,300 5

DAAH7GVF05 4-1/2" 5/8"-11 Very Fine 13,300 5

CAT # WIDTH LENGTH GRIT PACK

DASY3J0850 9" 11" 80 50

DASY3J1050 9" 11" 100 50

DASY3J1250 9" 11" 120 50

DASY3J1550 9" 11" 150 50

DASY3J1850 9" 11" 180 50

DASY3J2250 9" 11" 220 50

DASY3J2450 9" 11" 240 50

DASY3J2850 9" 11" 280 50

DASY3J3250 9" 11" 320 50

DASY3J3650 9" 11" 360 50

DASY3J4050 9" 11" 400 50

DASY3J5050 9" 11" 500 50

DASY3J6050 9" 11" 600 50

DASY3J8050 9" 11" 800 50

DASY3J1A50 9" 11" 1000 50

DASY3J1B50 9" 11" 1200 50

DASY3J1C50 9" 11" 1500 50

SHEETS

SHOP ROLLS (continued)

CAT # LGTH WIDTH GRIT

DANN221001 50 Yards 3" 100

DANN221201 50 Yards 3" 120

DANN221501 50 Yards 3" 150

DANN221801 50 Yards 3" 180

DANN222201 50 Yards 3" 220

DANN222401 50 Yards 3" 240

DANN223201 50 Yards 3" 320

DANN224001 50 Yards 3" 400

DANR220401 50 Yards 4" 40

DANR220601 50 Yards 4" 60

DANR220801 50 Yards 4" 80

DANR221001 50 Yards 4" 100

DANR221201 50 Yards 4" 120

DANR221501 50 Yards 4" 150

DANR221801 50 Yards 4" 180

DANR222201 50 Yards 4" 220

DANR223201 50 Yards 4" 320

DANR224001 50 Yards 4" 400

CAT # LGTH WIDTH GRIT

DANU220401 50 Yards 6" 40

DANU220601 50 Yards 6" 60

DANU220801 50 Yards 6" 80

DANU221001 50 Yards 6" 100

DANU221201 50 Yards 6" 120

DANU221501 50 Yards 6" 150

DANU221801 50 Yards 6" 180

DANU222201 50 Yards 6" 220

DANU222401 50 Yards 6" 240

DANU223201 50 Yards 6" 320

DANU224001 50 Yards 6" 400

CAT # DIA. ARBOR GRIT PACK

DADF7NMD10 5" 7/8" Medium 10

DADF7NFN10 5" 7/8" Fine 10

DADG7NCR10 7" No Hole Coarse 10

DADG7NMD10 7" No Hole Medium 10

DADG7NFN10 7" No Hole Fine 10

DADH7NCR10 7" 7/8" Coarse 10

DADH7NMD10 7" 7/8" Medium 10

DADH7NFN10 7" 7/8" Fine 10

**Use with long hook backing pads – found on page 70

WATERPROOF SHEETS

SILICON CARBIDE

NON-WOVEN HAND PADS NON-WOVEN FLAP DISCS

POWER STRIP DISCS

ALUMINUM

OXIDE (continued)

68 ACCESSORIES

ACCESSORIES

DIAMONDS

CUP

GRINDING

WHEELS

CAT # DIA. ARBOR NUMBER OF ROWS APPLICATION MAX RPM

DW4770 4" 5/8"-11 Single Row Heavy-Duty Masonry Grinding 15,200

DW4772 4" 5/8"-11 Double Row General Purpose Masonry Grinding 15,200

DW4772T 4" 5/8"-11 Turbo Smooth Finish Masonry Grinding 15,200

DW4774 4-1/2" 5/8"-11 Double Row General Purpose Masonry Grinding 13,300

DW4776 5" 5/8"-11 Single Row Heavy-Duty Masonry Grinding 12,200

DW4777 5" 5/8"-11 Double Row General Purpose Masonry Grinding 12,200

DW4777T 5" 5/8"-11 Turbo Smooth Finish Masonry Grinding 12,200

DW4771 7" 5/8"-11 Single Row Heavy-Duty Masonry Grinding 8,600

DW4773 7" 5/8"-11 Double Row General Purpose Masonry Grinding 8,600

DW4773T 7" 5/8"-11 Turbo Smooth Finish Masonry Grinding 8,600

CAT # DIA. EDGE

THICKNESS

SEGMENT

HEIGHT

ARBOR

SIZE APPLICATION MAX

RPM

DW4711 4" .080" 7mm 5/8", 7/8", 2Omm Masonry Cutting 15,200

DW4713 4-1/2" .080" 7mm 7/8" Masonry Cutting 13,300

DW4778 5" .080" 7mm 7/8" Masonry Cutting 12,200

DW4714 7" .095" 7mm 5/8", 7/8", Masonry Cutting 8,700

DW4716 12" .125" 7mm 1", 2Omm General Purpose Cutting 6,300

DW4747 12" .125" 7mm 1", 2Omm Fast Cutting 6,300

DW4743 12" .125" 7mm 1", 2Omm Cured Concrete Cutting 6,300

DW4745 12" .125" 7mm 1", 2Omm Asphalt or Green Concrete Cutting 6,300

DW4742 14" .125" 7mm 1", 2Omm General Purpose Cutting 5,400

DW4748 14" .125" 7mm 1", 2Omm Fast Cutting 5,400

DW4744 14" .125" 7mm 1", 2Omm Cured Concrete Cutting 5,400

DW4746 14" .125" 7mm 1", 2Omm Asphalt or Green Concrete Cutting 5,400

SEGMENTED

BLADES

CAT # DIA. EDGE

THICKNESS

SEGMENT

HEIGHT

ARBOR

SIZE APPLICATION MAX

RPM

DW4781 4" .080" 7mm 5/8", 7/8", 20mm Masonry Cutting 15,200

DW4782 4-1/2" .080" 7mm 7/8" Masonry Cutting 13,300

DW4783 5" .080" 7mm 7/8" Masonry Cutting 12,200

DW4784 7" .095" 7mm 5/8", 7/8", Masonry Cutting 8,700

SEGMENTED

BLADES

CAT # DIA. EDGE

THICKNESS

ARBOR

SIZE APPLICATION MAX

RPM

DW8500 14" 3/32" 1" Metal Cutting 4,300

METAL

CUTTING

100X LIFE**

**vs. Standard

DEWALT Chop

Saw Blades

SCAN FOR

MORE INFO

TUCK POINTING

BLADES

CAT # DIA. EDGE

THICKNESS

SEGMENT

HEIGHT

ARBOR

SIZE TYPE APPLICATION MAX

RPM

DW4710 4" .25" 8mm 5/8", 7/8", 20mm Standard Tuck Pointing 15,200

DW4710S 4" .25" 8mm 5/8", 7/8", 20mm Sandwich Tuck Pointing 15,200

DW4740 4-1/2" .25" 8mm 7/8" Standard Tuck Pointing 13,300

DW4740S 4-1/2" .25" 8mm 7/8" Sandwich Tuck Pointing 13,300

DW4741 5" .25" 8mm 7/8" Standard Tuck Pointing 12,200

DW4741S 5" .25" 8mm 7/8" Sandwich Tuck Pointing 12,200

DW4739 6" .25" 8mm 7/8" Standard Tuck Pointing 10,100

DW4739S 6" .25" 8mm 7/8" Sandwich Tuck Pointing 10,100

ACCESSORIES 69

ACCESSORIES

DIAMONDS

CAT # DIA. EDGE

THICKNESS

SEGMENT

HEIGHT

ARBOR

SIZE APPLICATION MAX

RPM

DW4729 4" .060" 5mm 5/8", 7/8", 2Omm Ceramic Tile - Wet or Dry 15,200

DW4760 7" .060" 6.5mm 5/8" Ceramic Tile - Wet 8,700

DW4767 8" .060" 6.0mm 5/8" Ceramic Tile - Wet 7,600

DW4761 10" .060" 6.5mm 5/8" Ceramic Tile - Wet 5,400

DW4762 10" .060" 8mm 5/8" Porcelain Tile - Wet 5,400

TILE BLADES

CAT # DIA. EDGE

THICKNESS

SEGMENT

HEIGHT

ARBOR

SIZE APPLICATION MAX

RPM

DW4790 4" .060" 5mm 5/8", 7/8", 20mm Tile - Wet 15,200

DW4791 7" .060" 5mm 5/8" Tile - Wet 8,700

DW4792 10" .060" 5mm 5/8" Tile - Wet 5,400

TILE BLADES

CAT # DIA. EDGE

THICKNESS

SEGMENT

HEIGHT

ARBOR

SIZE APPLICATION MAX

RPM

DW4735 4" .060" 5/8", 7/8", 20mm 8mm Porcelain Tile - Wet or Dry 15,200

DW4738 4-3/8" .060" 5/8", 7/8" 8mm Porcelain Tile - Wet or Dry 13,300

DW4765 4-1/2" .060" 8mm 5/8", 7/8", 2Omm Porcelain Tile - Wet or Dry 13,300

DW4766 7" .060" 8mm 5/8" Porcelain Tile - Wet 8,700

DW4764 10" .060" 8mm 5/8" Porcelain Tile - Wet 5,400

TILE BLADES

CAT # DIA. EDGE

THICKNESS

SEGMENT

HEIGHT

ARBOR

SIZE APPLICATION MAX

RPM PACK

DW4700 4" .080" 7.5mm 5/8", 7/8", 2Omm Masonry Cutting 15,200 1

DW4701 4-1/2" .080" 7.5mm 7/8" Masonry Cutting 13,300 1

DW4701B** 4-1/2" .080" 7.5mm 7/8" Masonry Cutting 13,300 10

DW4786 5" .080" 7.5mm 7/8" Masonry Cutting 12,200 1

DW4702 7" .090" 7.5mm 5/8", 7/8", Masonry Cutting 8,700 1

DW4702B** 7" .090" 7.5mm 5/8", 7/8", Masonry Cutting 8,700 10

DW4703 8" .090" 7.5mm 5/8", 7/8", Masonry Cutting 8,700 1

DW4704 12" .110" 7.5mm 1", 20mm Masonry Cutting 6,300 1

**Bulk

TURBO BLADES

**Bulk

CAT # DIA. EDGE

THICKNESS

SEGMENT

HEIGHT

ARBOR

SIZE APPLICATION MAX

RPM PACK

DW4724 4" .080" 7mm 5/8", 7/8", 2Omm Masonry Cutting 15,200 1

DW4724B** 4" .080" 7mm 5/8", 7/8", 2Omm Masonry Cutting 15,200 10

DW4725 4-1/2" .080" 7mm 7/8" Masonry Cutting 13,300 1

DW4725B** 4-1/2" .080" 7mm 7/8" Masonry Cutting 13,300 10

DW4727 5" .080" 7mm 7/8" Masonry Cutting 12,200 1

DW4712 7" .090" 7mm 5/8", 7/8", Masonry Cutting 8,700 1

DW4712B** 7" .090" 7mm 5/8", 7/8", Masonry Cutting 8,700 10

TURBO BLADES

70 ACCESSORIES

ACCESSORIES

CAT # DIA. WIRE

SIZE ARBOR WIRE

STYLE MATERIAL MAX

RPM PACK

DW4925 4" .020" 5/8"-11 Stringer Bead Carbon 20,000 1

DW49201 5" .020" 5/8"-11 Stringer Bead Carbon 12,000 1

DW49202 6" .020" 5/8"-11 Stringer Bead Carbon 12,000 1

DW49202B 6" .020" 5/8"-11 Stringer Bead Carbon 12,000 1

DW49204 4" .020" 5/8"-11 Stringer Bead Stainless

Steel 20,000 1

DW49504B 4" .020" 5/8"-11 Stringer Bead Stainless

Steel 20,000 6

CAT # DIA. WIRE

SIZE ARBOR WIRE

STYLE MATERIAL MAX

RPM PACK

DW49253 4" .020" 5/8-11" Cable Twist Carbon 20,000 6

DW4930 4" .020" 5/8"-11 Cable Twist Carbon 20,000 1

DW4935 4" .020" 10mm x

1-1/4" Cable Twist Carbon 20,000 1

DW49203 5" .020" 5/8"-11 Cable Twist Carbon 12,000 1

DW4937 6" .020" 5/8"-11 Cable Twist Carbon 6,000 1

WIRE WHEELS

CAT # DIA. WIRE SIZE FACE WIDTH TRIM LENGTH SHANK WIRE STYLE WHEEL TYPE MATERIAL MAX RPM PACK

DW4903 3" .014" 1/2" 3/4" 1/4" Crimped Circular Carbon 20,000 12

DW49007 2" .014" 1/2" 1/2" 1/4" Crimped Flared Carbon 20,000 12

DW49008 3" .014" 1/2" 15/16" 1/4" Crimped Flared Carbon 20,000 12

SMALL

WIRE WHEELS

CAT # DIA. WIRE SIZE WIRE STYLE MATERIAL ARBOR TRIM LENGTH MAX RPM PACK

DW49150 3" .014" Crimped Carbon 5/8"-11 13/16" 14,000 6

DW49151 4" .014" Crimped Carbon 5/8"-11 1-1/8" 9,000 6

DW49152 5" .014" Crimped Carbon 5/8"-11 1-3/8" 8,000 4

DW49153 6" .014" Crimped Carbon 5/8"-11 1-3/8" 6,600 4

DW49154 3" .014" Crimped Stainless 5/8"-11 13/16" 14,000 6

DW49155 4" .014" Crimped Stainless 5/8"-11 1-1/8" 9,000 6

DW49156 5" .014" Crimped Stainless 5/8"-11 1-3/8" 8,000 4

DW49157 3" .020" Knotted Carbon 5/8"-11 7/8" 14,000 6

DW49158 4" .020" Knotted Carbon 5/8"-11 1-1/8" 9,000 6

DW49159 6" .020" Knotted Carbon 5/8"-11 1-3/8" 6,600 4

DW49160 3" .020" Knotted Stainless 5/8"-11 7/8" 14,000 6

DW49161 4" .020" Knotted Stainless 5/8"-11 1-1/8" 9,000 6

DW49162 6" .020" Knotted Stainless 5/8"-11 1-3/8" 6,600 4

CUP BRUSHES

CAT # DIA. ARBOR MATERIAL PACK

DW4980 6" 5/8" Cotton 1

DW4988 7" – Wool 1

DW4989 7" – Cotton Blend 1

POLISHING

WIRE BRUSHES

CAT # DIA. WIRE

SIZE ARBOR WIRE

STYLE MATERIAL MAX

RPM PACK

DW4926 4" .020" 5/8"-11 Stringer Bead Carbon 20,000 6

DW49250 5" .020" 5/8"-11 Stringer Bead Carbon 12,000 6

DW4936 6" .020" 5/8"-11 Stringer Bead Carbon 12,000 6

DW4927 4" .020" 5/8"-11 Stringer Bead Stainless 20,000 6

DW49251 5" .020" 5/8"-11 Stringer Bead Stainless 12,000 6

DW49252 6" .020" 5/8"-11 Stringer Bead Stainless 12,000 6

CAT # DIA. WIRE

SIZE ARBOR WIRE

STYLE MATERIAL MAX

RPM PACK

DW49253 4" .020" 5/8"-11 Cable Twist Carbon 20,000 6

DW49254 5" .020" 5/8"-11 Cable Twist Carbon 12,000 6

DW4938 6" .020" 5/8"-11 Cable Twist Carbon 12,000 6

DW49255 4" .020" 5/8"-11 Cable Twist Stainless 20,000 6

DW49256 5" .020" 5/8"-11 Cable Twist Stainless 12,000 6

DW49257 6" .020" 5/8"-11 Cable Twist Stainless 12,000 6

POLISHING PADS

CAT # DIA. ARBOR MATERIAL PACK

DW4985 7" 5/8"-11 Rubber Backing Pad 1

DW4985CL 7" 5/8"-11 Cotton & Backing Pad 1

WIRE WHEELS

ACCESSORIES 71

ACCESSORIES

WIRE BRUSHES (continued)

CAT # DIA. WIRE SIZE WIRE STYLE MATERIAL ARBOR TRIM LENGTH MAX RPM PACK

DW4920 3" .014" Crimped Carbon 5/8"-11 13/16" 14,000 1

DW49101 4" .014" Crimped Carbon 5/8"-11 1-1/8" 9,000 1

DW4922 5" .014" Crimped Carbon 5/8"-11 1-3/8" 8,000 1

DW49102 6" .014" Crimped Carbon 5/8"-11 1-3/8" 6,600 1

DW4910 3" .020" Knotted Carbon 5/8"-11 7/8" 14,000 1

DW4915 3" .020" Knotted Carbon 10mm x 1.25" 7/8" 14,000 1

DW4916 4" .020" Knotted Carbon 5/8"-11 1-1/8" 9,000 1

DW4917 6" .020" Knotted Carbon 5/8"-11 1-3/8" 6,600 1

CUP BRUSHES

CAT # DIA. WIRE

SIZE

WIRE

STYLE MATERIAL TRIM

LENGTH

MAX

RPM PACK

DW49050 3/4" .020" Crimped Carbon 1" 22,000 12

DW49051 1" .020" Crimped Carbon 1" 22,000 12

DW49052 3/4" .020" Crimped Stainless 1" 22,000 12

DW49053 1" .020" Crimped Stainless 1" 22,000 12

CAT # DIA. WIRE

SIZE

WIRE

STYLE MATERIAL TRIM

LENGTH

MAX

RPM PACK

DW49054 3/4" .020" Knotted Carbon 1" 20,000 12

DW49055 1" .020" Knotted Carbon 1" 20,000 12

DW49056 3/4" .020" Knotted Stainless 1" 20,000 12

DW49057 1" .020" Knotted Stainless 1" 20,000 12

END BRUSHES

CAT # DIA. WIRE

SIZE

WIRE

STYLE MATERIAL TRIM

LENGTH

MAX

RPM PACK

DW49001 3/4" .014" Crimped Carbon 1" 20,000 12

DW4901 1" .014" Crimped Carbon 1-1/8" 20,000 1

DW4901B 1" .014" Crimped Carbon 1-3/8" 20,000 12

DW49002 3/4" .020" Crimped Carbon 1-3/8" 20,000 12

DW49003 1" .020" Crimped Carbon 1-1/8" 20,000 12

CAT # DIA. WIRE

SIZE

WIRE

STYLE MATERIAL TRIM

LENGTH

MAX

RPM PACK

DW49004 3/4" .014" Knotted Carbon 1-3/8" 20,000 12

DW49005 1" .014" Knotted Carbon 1-3/8" 20,000 12

DW49006 3/4" .020" Knotted Carbon 13/16" 20,000 12

DW4902 1" .020" Knotted Carbon 1" 20,000 1

DW4902B 1" .020" Knotted Carbon 1" 20,000 12

END BRUSHES

BENCH GRINDER

BRUSHES

CAT # DIA. WIRE SIZE WIRE STYLE MATERIAL ARBOR WIDTH LENGTH MAX RPM PACK

DW4904 6" .014" Crimped Carbon 5/8"-1/2" 3/4" 1-1/8" 6,000 1

DW4905 6" .014" Crimped Carbon 5/8"-1/2" 1" 1-1/8" 6,000 1

DW4906 8" .014" Crimped Carbon 5/8" 3/4" 1-9/16" 4,000 1

DW4907 8" .014" Crimped Carbon 5/8" 1" 1-9/16" 4,000 1

DW4908 10" .014" Crimped Carbon 3/4" 1-9/16" 2-1/2" 3,600 1

CAT # SIZE HANDLE STYLE WIRE SIZE MATERIAL PACK

DW49701 4 x 16 Shoe Handle .014" Carbon 12

DW49702 4 x 16 Shoe Handle .012" Stainless 12

DW49703 3 x 19 Curved Handle .014" Carbon 12

DW49704 3 x 19 Curved Handle .012" Stainless 12

CAT # SIZE HANDLE STYLE WIRE SIZE MATERIAL PACK

DW49705 3 x 7 Angled Back .014" Carbon 36

DW49706 3 x 7 Angled Back .012" Stainless 36

DW49707 3 x 7 Small Plastic .006" Brass 36

DW49708 3 x 7 Small Plastic .006" Stainless 36

SCRATCH BRUSHES

72 ACCESSORIES

ACCESSORIES

FIBER DISC

BACKING PADS

CAT # DIA. ARBOR MATERIAL MAX RPM

DW4939 4-1/2" 7/8" Paper 16,000

DW4940 4" 5/8"-11 &

M10 x 1.25" Medium Rubber 12,000

DW4942 4-1/2" 5/8"-11 Paper 16,000

DW4945 4-1/2" 5/8"-11 Rubber 12,000

DW4950 5" 7/8" Phenolic Disc 6,000

DW4955 7" 7/8" Phenolic Disc 6,000

CAT # DIA. ARBOR MATERIAL MAX RPM

DW4956 9" 7/8" Phenolic Disc 6,000

DAJHXGMD01 4-1/2" 5/8"-11 Medium Rubber Turbo 11,000

DAJHXHMD01 5" 5/8"-11 Medium Rubber Turbo 10,000

DAJHXKMD01 7" 5/8"-11 Medium Rubber Turbo 8,500

DAJHXKHD01 7" 5/8"-11 Firm Rubber Turbo 8,500

DAJHXMMD01 9" 5/8"-11 Medium Rubber Turbo 6,500

DAJHXMHD01 9" 5/8"-11 Firm Rubber Turbo 6,500

ABRASIVE ACCESSORIES

CAT # DESCRIPTION DIA. ARBOR SHANK MAX RPM

DAMR3FXX01 Firm 3" QRC 1/4" 20,000

DAMM1MXX01 Medium 1-1/2" QMC 1/4" 25,000

DAMM1FXX01 Firm 1-1/2" QMC 1/4" 30,000

DAMM2MXX01 Medium 2" QMC 1/4" 25,000

DAMM2FXX01 Firm 2" QMC 1/4" 30,000

DAMM3MXX01 Medium 3" QMC 1/4" 20,000

DAMM3FXX01 Firm 3" QMC 1/4" 20,000

CAT # DESCRIPTION DIA. ARBOR SHANK MAX RPM

DAMQ1XXX01 Small 1"–1-1/2" QDC 1/4" 30,000

DAMQ2XXX01 Large 2"– 4" QDC 1/4" 20,000

DAMR1MXX01 Medium 1"–1-1/2" QRC 1/4" 25,000

DAMR1FXX01 Firm 1"–1-1/2" QRC 1/4" 30,000

DAMR2MXX01 Medium 2" QRC 1/4" 25,000

DAMR2FXX01 Firm 2" QRC 1/4" 30,000

DAMR3MXX01 Medium 3" QRC 1/4" 20,000

QUICK CHANGE

MANDRELS

CARTRIDGE ROLL

MANDRELS

CAT # PILOT

SIZE

PILOT

LENGTH

ROLL

LENGTH

SHANK

SIZE

SHANK

LENGTH

OVERALL

LENGTH

MAX

RPM

DAMCX83401 1/8" 3/4" 1" 1/4" 1-1/4" 2-1/2" 25,000

DAMCX81001 1/8" 1" 1-1/2" 1/4" 1-1/4" 2-3/4" 25,000

DAMCX81501 1/8" 1-1/2" 2" 1/4" 1-1/4" 3-1/4" 25,000

HOOK & LOOP

BACKING PADS**

CAT # DESCRIPTION DIA. ARBOR MAX RPM

DAPHXGLH01 Long Hook 4-1/2" 5/8"-11 13,300

DAPHXHLH01 Long Hook 5" 5/8"-11 13,300

DAPHXKLH01 Long Hook 7" 5/8"-11 8,700

**For use with non-woven discs – found on page 67

QUICK LOCK FIBER

DISC BACKING PADS

CAT # DIA. ARBOR MATERIAL MAX RPM

DAJHXGQM01 4-1/2" 5/8"-11 Medium 13,300

DAJHXHQM01 5" 5/8"-11 Medium 12,200

DAJHXKQM01 7" 5/8"-11 Medium 8,700

DAJHXKQH01 7" 5/8"-11 Firm 8,700

HANDLE

CAT # DESCRIPTION SIZE

DAMHXXX01 Hand Pad Handle 6" x 4-1/2"

ADAPTERS

CAT # DESCRIPTION

DW4900 Spindle Adapter M10 x 1.25" to 5/8"-11

DW4706 Backing Flange for 5/8"-11 Shaft

Grinders to Mount Type 1 Cutoff Wheels

Arbor Types

QMCQRCQDC

ACCESSORIES 73

ACCESSORIES

QTrim

QHardwood Floor

QMaple

Trim Installation, Stair Installation,

Cabinet Installation

IDEAL FOR TRIM CARPENTERS:

QDimensional Lumber

QOSB

QPlywood

Framing, Deck Building

IDEAL FOR GENERAL CONTRACTORS:

A COMPLETE RANGE OF PRECISION BLADES

A COMPLETE RANGE OF CONSTRUCTION BLADES

A COMPLETE RANGE OF WOODWORKING BLADES

A BLADE FOR EVERY TRADE

QHardwoods

QCherry

QMaple

Cabinet Manufacturing, Production

Woodshops and Furniture Shops

IDEAL FOR WOODWORKERS:

QOak

QHickory

QMelamine

QOak

QMolding

74 ACCESSORIES

ACCESSORIES

PRECISION SAW BLADES

CAT # DESCRIPTION KERF TYPE DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

DW9199 Framing Blade Thin Kerf 6-1/2" 24 5/8" 18° .063" .039" ATB

DW9196 Cross Cutting Blade Thin Kerf 6-1/2" 40 5/8" 18° .063" .039" ATB

DW3199 Framing Blade Thin Kerf 7-1/4" 24 5/8"- 18° .063" .039" ATB

DW3599 Framing Blade Thin Kerf 7-1/4" 24 5/8"- 18° .063" .039" ATB

DW3599B10** Framing Blade Thin Kerf 7-1/4" 24 5/8"- 18° .063" .039" ATB

DW3194 Cross Cutting Blade Thin Kerf 7-1/4" 40 5/8"- 18° .063" .039" ATB

DW3594B10** Cross Cutting Blade Thin Kerf 7-1/4" 40 5/8"- 18° .063" .039" ATB

DW3196 Fine Cutting Blade Thin Kerf 7-1/4" 60 5/8"- 18° .063" .039" ATB

DW3596B10** Fine Cutting Blade Thin Kerf 7-1/4" 60 5/8"- 18° .063" .039" ATB

DW3185 Cross Cutting Blade Thin Kerf 8-1/4" 40 5/8"- 18° .071" .047" ATB

CAT # DESCRIPTION DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

MAX

RPM

DW7118PT Premium Finish 8-1/2" 60 5/8" -5° .094" .063" ATB 9,000

DW7124PT Fast Ripping 10" 24 5/8" 20° .098" .071" FT 6,000

DW7140PT General Purpose 10" 40 5/8" 20° .098" .071" ATB 6,000

DW7150PT Combination 10" 50 5/8" 15° .098" .071" ATB+R 6,000

DW3215PT Smooth Crosscutting 10" 60 5/8" 7° .098" .071" ATB 6,000

DW3218PT Ultra Fine Finish 10" 80 5/8" 7° .098" .071" ATB 6,000

DW3216PT Smooth Crosscutting 12" 60 1" 7° .106" .079" ATB 4,800

DW3232PT Ultra Fine Finish 12" 80 1" 7° .106" .079" ATB 4,800

DW72100PT Ultra Miter 12" 100 1" -5° .106" .079" ATB+R 4,800

Specialty

DW7119PT Non-Ferrous/Plastic/Fine Trim 8-1/2" 60 5/8" -5° .094" .063" TCG 9,000

DW3219PT Non-Ferrous/Plastic/Fine Trim 10" 80 5/8" -5° .098" .071" TCG 6,000

DW7296PT Non-Ferrous/Plastic/Fine Trim 12" 96 1" -5° .102" .079" TCG 4,800

SCAN FOR

MORE INFO

QExclusive Plate Technology

Improved cut performance and reduced vibration †

QFace Grind

For clean, precise cuts

QPremium Carbide

2X larger carbide than DEWALT construction series

Anti-stick coating

**Vs. DEWALT construction series ***Vs. Freud's DIABLO®* D0724R in 3/4" chip board † Vs. previous design

LARGER

CARBIDE**

2X LONGER

LIFE***

SAW BLADES

**Bulk

ACCESSORIES 75

ACCESSORIES

CONSTRUCTION SAW BLADES

LARGE DIAMETER

CAT # DESCRIPTION DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

DW3112** Fast Ripping Table Saw Blade 10" 24 5/8" 15° .095" .069" ATB

DW3103 General Purpose Saw Blade 10" 32 5/8" 7° .095" .069" ATB

DW3114** General Purpose Saw Blade 10" 40 5/8" 10° .095" .069" ATB

DW3106 Fine Finish Saw Blade 10" 60 5/8" 7° .095" .069" ATB

DW3123 General Purpose Saw Blade 12" 32 1" 7° .095" .069" ATB

DW3126 Fine Finish Saw Blade 12" 60 1" 7° .095" .069" ATB

DW3128 Fine Finish Saw Blade 12" 80 1" 7° .095" .069" ATB

Combo Packs

DW3106P5 Construction 10" Combo Pack

(DW3106 & DW3103) 10" 32, 60 5/8" 7° .095" .069" ATB

DW3128P5 Construction 12" Combo Pack

(DW3128 & DW3123) 12" 32, 80 1" 7° .095" .069" ATB

CORDLESS

PORTABLE

CAT # DESCRIPTION KERF

TYPE DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

Carbide Tipped

DW3161 Circular Saw Blade Thin Kerf 6-1/2" 18 5/8"- 25° .071" .045" ATB

DW3192 Circular Saw Blade Thin Kerf 7-1/4" 18 5/8"- 15° .071" .045" ATB

DW3592B10** Circular Saw Blade Thin Kerf 7-1/4" 18 5/8"- 15° .071" .045" ATB

DW3174 Pressure Treated/Wet Lumber Thin Kerf 7-1/4" 20 5/8"- 25° .071" .045" ATB

DW3178 Framing Blade Thin Kerf 7-1/4" 24 5/8"- 18° .071" .045" ATB

DW3578B10** Framing Blade Thin Kerf 7-1/4" 24 5/8"- 18° .071" .045" ATB

DW3176 Circular Saw Blade Thin Kerf 7-1/4" 36 5/8"- 15° .071" .045" ATB

DW3576B10** Circular Saw Blade Thin Kerf 7-1/4" 36 5/8"- 15° .071" .045" ATB

DW3182 Framing Blade Thin Kerf 8-1/4" 24 5/8"- 20° .076" .050" ATB

DW3582B10** Framing Blade Thin Kerf 8-1/4" 24 5/8"- 20° .076" .050" ATB

DW3184 Circular Saw Blade Thin Kerf 8-1/4" 40 5/8"- 15° .076" .050" ATB

Specialty Applications

DW3191 Nail Cutting Circular Saw Blade Thin Kerf 7-1/4" 18 5/8"- 15° .071" .045" ATB

DW3591B10** Nail Cutting Circular Saw Blade Thin Kerf 7-1/4" 18 5/8"- 15° .071" .045" ATB

DW3193 PCD Diamond Fiber Cement Blade

(HARDIEPLANK®* & HARDIEBACKER®*) - 7-1/4" 6 5/8" -5° .090" .060" FTG

*HARDIEPLANK® & HARDIEBACKER® is a registered trademark of JAMES HARDIE TECHNOLOGY LIMITED CORPORATION

**Bulk

CAT # DESCRIPTION DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

DW9055 Carbide - Fast Woodcutting 5-3/8" 16 10mm 20° .059" .039" ATB

DW9054 Carbide - Smooth Woodcutting 5-3/8" 24 10mm 20° .059" .039" ATB

DW9155 Carbide - Fast Cutting 6-1/2" 18 5/8" 20° .059" .039" ATB

DW9555** Carbide - Fast Cutting 6-1/2" 18 5/8" 20° .059" .039" ATB

DW9154 Carbide - Framing 6-1/2" 24 5/8" 20° .059" .039" ATB

Specialty

DW9052 Carbide - Aluminum/Non-Ferrous Metals 5-3/8" 30 10mm 3° .059" .039" FTG

DW9053 Steel - Vinyl/Paneling 5-3/8" 80 10mm -10°/-45° .059" .039" Alt. Set

DW9152 Carbide - Aluminum Cutting 6-1/2" 36 5/8" 3° .059" .039" FTG

DW9153 Steel - Vinyl/Paneling 6-1/2" 90 5/8" 18°/45°/20° .059" .039" FTG

Combo Packs

DW9058 Combo Pack (DW9052 & DW9055) 5-3/8" 16, 30 10mm 3°, 20° .059" .039" FTG/ATB

DW9059C5 Combo Pack (DW9052, DW9053 & DW9054) 5-3/8" 24, 30, 78 10mm 20° .059" .039" ATB

DW9158 Combo Pack (DW9155 & DW9154) 6-1/2" 18, 24 5/8" 20° .059" .039" ATB

**Bulk

**To be used on table saws only

76 ACCESSORIES

ACCESSORIES

WOODWORKING SAW BLADES

GENERAL PURPOSE

CAT # DESCRIPTION KERF TYPE DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

DW7657 General Purpose Thin Kerf 10" 40 5/8" 20° .110" .069" ATB

DW7658 General Purpose Thin Kerf 12" 48 1" 10° .110" .077" ATB

DW7659 General Purpose Thin Kerf 14" 48 1" 10° .110" .079" ATB

DW71040A General Purpose Full Kerf 10" 40 5/8" 10° .125" .087" ATB

DW71248A General Purpose Full Kerf 12" 48 1" 10° .125" .087" ATB

DW71448A General Purpose Full Kerf 14" 48 1" 10° .125" .087" ATB

RIPPING

CAT # DESCRIPTION KERF TYPE DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

DW7642 Fast Ripping Thin Kerf 10" 24 5/8" 20° .110" .069" FTG

DW7643 Fast Ripping Thin Kerf 12" 30 1" 20° .110" .077" FTG

DW7638 Glue Line Ripping Thin Kerf 10" 30 5/8" 20° .110" .069" FTG

DW7639 Glue Line Ripping Thin Kerf 12" 40 1" 20° .110" .077" FTG

DW7654 Finish Ripping Thin Kerf 10" 40 5/8" 10° .110" .069" TCG

DW7655 Finish Ripping Thin Kerf 12" 40 1" 10° .110" .079" TCG

DW71024F Fast Ripping Full Kerf 10" 24 5/8" 20° .125" .087" FTG

DW71230F Fast Ripping Full Kerf 12" 30 1" 20° .125" .087" FTG

DW71030F Glue Line Ripping Full Kerf 10" 30 5/8" 20° .125" .087" FTG

DW71240F Glue Line Ripping Full Kerf 12" 40 1" 20° .125" .087" FTG

DW71040T Finish Ripping Full Kerf 10" 40 5/8" 10° .125" .087" TCG

DW71250T Finish Ripping Full Kerf 12" 50 1" 10° .125" .087" TCG

METAL CUTTING SAW BLADES

FERROUS METALS

CAT # DESCRIPTION DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

MAX

RPM

Corded

DWA7770 Ferrous Metal Cutting 5-1/2" 30 20mm 0° .060" .045" M-ATB 3,700

DW7766 Ferrous Metal Cutting 7-1/4" 48 5/8"- 0° .079" .063" ATB 5,800

Cordless

DW7763 Ferrous Metal Cutting 6-3/4" 40 20mm 0° .069" .055" M-ATB 3,500

Stationary

DW7747 Heavy Gauge Ferrous Metal Cutting 14" 70 1" 0° .087" .071" M-ATB 1,800

DW7737 Heavy Gauge Ferrous Metal Cutting 12" 60 1" 0° .087" .071" M-ATB 1,800

DW7745 Light Gauge Ferrous Metal Cutting 14" 90 1" 0° .087" .071" M-ATB 1,800

DW7739 Stainless Steel Metal Cutting 12" 80 1" 0° .087" .071" M-ATB 1,800

DW7749 Stainless Steel Metal Cutting 14" 90 1" 0° .087" .071" M-ATB 1,800

ACCESSORIES 77

ACCESSORIES

WOODWORKING SAW BLADES (continued)

COMBINATION

CAT # DESCRIPTION KERF DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

DW7640 Combination Thin Kerf 10" 50 5/8" 15º .110" .069" 4ATB+R

DW7641 Combination Thin Kerf 12" 60 1" 15º .110" .079" 4ATB+R

DW71050R Combination Full Kerf 10" 50 5/8" 15º .125" .087" 4ATB+R

DW71260R Combination Full Kerf 12" 60 1" 15º .125" .087" 4ATB+R

DADO

CAT # DESCRIPTION DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

DW7670 Stacked Dado Set 8" 24 5/8" 0° .925" .125" ATB /FTG

FINE CROSSCUTS

CAT # DESCRIPTION KERF TYPE DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

DW7644 Fine Crosscuts Thin Kerf 8-1/2" 60 5/8" -5° .110" .069" ATB

DW7646** Fine Crosscuts Thin Kerf 10" 60 5/8" 10° .110" .069" ATB

DW7645 Fine Crosscuts Thin Kerf 10" 60 5/8" -5° .110" .069" ATB

DW7632 Fine Crosscuts Thin Kerf 10" 60 5/8" 7° .110" .069" ATB

DW7648 Fine Crosscuts Thin Kerf 12" 60 1" -5° .110" .077" ATB

DW7633 Fine Crosscuts Thin Kerf 12" 80 1" 7° .110" .077" ATB

DW7649 Fine Crosscuts Thin Kerf 12" 80 1" -5° .110" .077" ATB

DW722060T Fine Crosscuts Full Kerf 220mm 60 30mm 10° .125" .087" TCG

DW71060A** Fine Crosscuts Full Kerf 10" 60 5/8" 12° .125" .087" ATB

DW71060A5 Fine Crosscuts Full Kerf 10" 60 5/8" -5° .125" .087" ATB

DW71060T** Fine Crosscuts Full Kerf 10" 60 5/8" 12° .125" .087" TCG

DW71272T** Fine Crosscuts Full Kerf 12" 72 1" 12° .125" .087" TCG

DW71280A Fine Crosscuts Full Kerf 12" 80 1" 7° .125" .087" ATB

**To be used on table saws only

ULTRA-FINE CROSSCUTS

CAT # DESCRIPTION KERF DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

DW7647 Ultra-Fine Crosscuts Thin Kerf 10" 80 5/8" -5° .110" .069" ATB

DW7673 Ultra-Fine Crosscuts Thin Kerf 10" 80 5/8" 7° .110" .069" ATB

DW7650 Ultra-Fine Crosscuts Thin Kerf 12" 96 1" -5° .110" .079" ATB

DW7674 Ultra-Fine Crosscuts Thin Kerf 12" 100 1" -5° .110" .079" 4ATB+R

DW7651 Ultra-Fine Crosscuts Thin Kerf 14" 100 1" -5° .110" .079" ATB

DW71080A** Ultra-Fine Crosscuts Full Kerf 10" 80 5/8" 10° .125" .087" ATB

DW71080T** Ultra-Fine Crosscuts Full Kerf 10" 80 5/8" 10° .125" .087" TCG

DW712100RN5 Ultra-Fine Crosscuts Full Kerf 12" 100 1" -5° .125" .100" 4ATB+R

**To be used on table saws only

(continued on next page)

78 ACCESSORIES

ACCESSORIES

WOODWORKING SAW BLADES (continued)

SPECIALTY APPLICATIONS

CAT # DESCRIPTION KERF DIA. TEETH ARBOR HOOK

ANGLE KERF PLATE

THICKNESS

TOOTH

GRIND

Crosscutting Plywood

DW7671 Plywood Crosscutting Thin Kerf 10" 80 5/8" -5° .110" .069" HI-ATB

DW7672 Plywood Crosscutting Thin Kerf 12" 96 1" -5° .110" .079" HI-ATB

DW71080HN5 Plywood Crosscutting Full Kerf 10" 80 5/8" -5° .125" .100" HI-ATB

DW71296HN5 Plywood Crosscutting Full Kerf 12" 96 1" -5° .125" .100" HI-ATB

Melamines

DW7662 Melamines & Veneers Thin Kerf 10" 80 5/8" 0º .110" .069" H-ATB

DW7663 Melamines & Veneers Thin Kerf 12" 80 1" 0º .110" .079" H-ATB

DW722048HG Melamines & Veneers Full Kerf 220mm 48 30mm 10° .125" .087" HG

DW730072HG Melamines & Veneers Full Kerf 300mm 72 30mm 10° .125" .087" HG

DW71060HG Melamines & Veneers Full Kerf 10" 60 5/8" 10° .125" .087" HG

DW71272HG Melamines & Veneers Full Kerf 12" 72 1" 10° .125" .087" HG

Non-Ferrous Metal

DW7665 Non-Ferrous Metal Thin Kerf 10" 80 5/8" -5° .110" .069" TCG

DW7666 Non-Ferrous Metal Thin Kerf 12" 80 1" -5° .110" .079" TCG

DW71080T5 Non-Ferrous Metal Full Kerf 10" 80 5/8" -5° .125" .087" TCG

DW71280T5 Non-Ferrous Metal Full Kerf 12" 80 1" -5° .125" .087" TCG

Solid Surface & Plastics

DW7667 Solid Surface & Plastics Thin Kerf 10" 80 5/8" 0º .110" .069" M-TCG

DW7668 Solid Surface & Plastics Thin Kerf 12" 80 1" 0º .110" .079" M-TCG

DW71080MT Solid Surface & Plastics Full Kerf 10" 80 5/8" 0º .125" .087" M-TCG

DW71280MT Solid Surface & Plastics Full Kerf 12" 80 1" 0º .125" .087" M-TCG

Laminates

DW7660 Laminates Thin Kerf 10" 80 5/8" 0º .110" .069" TCG

DW7661 Laminates Thin Kerf 12" 80 1" 0º .110" .079" TCG

DW71080T0 Laminates Full Kerf 10" 80 5/8" 0º .125" .087" TCG

DW71280T0 Laminates Full Kerf 12" 80 1" 0º .125" .087" TCG

STEEL CIRCULAR SAW BLADES

STEEL SAW BLADES

CAT # DESCRIPTION DIA. TEETH ARBOR

DW3310 Fast Cut 6-1/2" 24 5/8"-

DW3323 Fast Cut 7-1/4" 26 5/8"-

DW3324 Crosscut 7-1/4" 100 5/8"-

DW3325 Combo 7-1/4" 40 5/8"-

DW3326 Hollow Ground Plywood 7-1/4" 140 5/8"-

DW3327 Hollow Ground Planer 7-1/4" 60 5/8"-

DW3329 Non-Ferrous 7-1/4" 68 5/8"-

DW3330 Iron/Steel 7-1/4" 16 Slots 5/8"-

DW3332 Master Combo 8-1/4" 60 5/8"-

CAT # DESCRIPTION DIA. TEETH ARBOR

DW3350 Combination 10" 40 5/8"-

DW3370 Fast Cut 10" 28 5/8"-

DW3372 Hollow Ground Planer 7-1/4" 80 5/8"-

DW3523 Combo Bulk 7-1/4" 26 5/8"-

DW3524 Crosscut 7-1/4" 100 5/8"-

DW3526 Hollow Ground Plywood Bulk 7-1/4" 140 5/8"-

DW3526L Hollow Ground Plywood Bulk

(Shrink Band on Teeth) 7-1/4" 140 5/8"-

ACCESSORIES 79

ACCESSORIES

(continued on next page)

CONCRETE & MASONRY DRILLING

PERCUSSION BITS

MULTI-MATERIAL

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

DW5221 1/8" 2" 3"

DW5209 5/32" 2" 3"

DW5227 5/32" 4" 6"

DW5222 3/16" 2" 3"

DW5223 3/16" 4" 6"

DW5211 7/32" 4" 6"

DW5224 1/4" 2" 4"

DW5225 1/4" 4" 6"

DW5226 1/4" 7" 12"

DW5228 5/16" 4" 6"

DW5229 5/16" 7" 12"

DW5230 3/8" 4" 6"

DW5231 3/8" 10" 12"

CAT # DIA. OVERALL

LENGTH

DWA56084 1/8" 4-1/2"

DWA56104 5/32" 4"

DWA56124 3/16" 4-1/2"

DWA56144 7/32" 4-1/2"

CAT # DIA. OVERALL

LENGTH

DWA56165 1/4" 4-3/4"

DWA56205 5/16" 5-1/4"

DWA56245 3/8" 5-1/4"

DWA56326 1/2" 6-1/4"

CAT # DIAMETER

5 Pc. Drill Bit Set

DWA56015 1/8", 3/16", 1/4", 5/16", 3/8"

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

DW5232 3/8" 16" 18"

DW5233 3/8" 22" 24"

DW5234 7/16" 4" 6"

DW5235 1/2" 4" 6"

DW5236 1/2" 10" 12"

DW5237 1/2" 16" 18"

DW5238 1/2" 22" 24"

DW5241 5/8" 4" 6"

DW5242 5/8" 7" 12"

DW5217 9/16" 4" 6"

DW5244 3/4" 4" 6"

DW5245 3/4" 7" 12"

DW5219 7/8" 7" 12"

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

DW5249 1" 7" 12"

Bulk Packs

DW5221B25 1/8" 2" 3"

DW5227B25 5/32" 4" 6"

DW5222B25 3/16" 2" 3"

DW5223B25 3/16" 4" 6"

DW5224B25 1/4" 2" 4"

DW5225B25 1/4" 4" 6"

DW5228B25 5/16" 4" 6"

DW5230B25 3/8" 4" 6"

DW5235B10 1/2" 4" 6"

PERCUSSION SETS

CAT # DESCRIPTION INCLUDES

DW5204 4 Pc. Premium Percussion

Masonry Drill Bit Set 3/16" x 3", 1/4" x 4", 5/16" x 6", 3/8" x 6"

DW5205 5 Pc. Premium Percussion

Masonry Drill Bit Set

5/32" x 6", 3/16" x 6", 1/4" x 6", 5/16" x 6", 3/8" x 6",

Medium TOUGH CASE® Container

DW5207 7 Pc. Premium Percussion

Masonry Drill Bit Set 3/16" x 3", (2)1/4" x 4", 1/4" x 6", 5/16" x 6", 3/8" x 6", 1/2" x 6"

'JUTBMMCSBOET&MFDUSJDBOE

$PSEMFTT)BNNFSESJMMTJODMVEJOH

DE8"-5#PTDI®BOE)JMUJ®*

DW5205

WALT'S MASONRY SOLUTIONS

*Bosch® is a registered trademark of Robert Bosch GmbH

and Hilti® is a registered trademark of Hilti Aktiengesellschaft

80 ACCESSORIES

ACCESSORIES

CONCRETE & MASONRY DRILLING (continued)

SDS

plus

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

SDS Plus Bulk Packs

DW5401B25 5/32" 4-1/2" 6-1/2"

DW5402B25** 3/16" 2" 4"

DW5403B25** 3/16" 4-1/2" 6-1/2"

DW5404B25 3/16" 6-1/2" 8-1/2"

DW5405B25 3/16" 8" 10"

DW5406B25 3/16" 10" 12"

DW5410B25 7/32" 4" 6"

DW5416B25** 1/4" 2" 4"

DW5417B25** 1/4" 4" 6"

DW5418B25 1/4" 6-1/2" 8-1/2"

DW5424B25 5/16" 4" 6"

DW5427B25*** 3/8" 4" 6"

DW5437B25*** 1/2" 4" 6"

DW5446B10*** 5/8" 6" 8"

SDS Plus Sets

DW5470

5 Pc. SDS

Plus Hammer

Bit Set

INCLUDES: 3/16" x

4-1/2" x 6-1/2",

1/4" x 2" x 4",

1/4" x 4" x 6",

3/8" x 4" x 6",

1/2" x 4" x 6"

**Compatible with Pin Anchor Drive

***Compatible with Depth Setter

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

Full Head Carbide SDS Plus

DW5502** 3/16" 2" 4-1/2"

DW5503** 3/16" 4" 6-1/2"

DW5504 3/16" 6" 8-1/2"

DW55050 3/16" 8" 10-1/2"

DW5506 3/16" 10" 12"

DW5507 3/16" 12" 14"

DW55100 7/32" 4" 6-1/2"

DW5512 7/32" 8" 10"

DW5516** 1/4" 2" 4-1/2"

DW5517** 1/4" 4" 6"

DW5518 1/4" 6" 8-1/2"

DW55200 1/4" 10" 12"

DW5521 1/4" 12" 14"

DW5524 5/16" 4" 6-1/2"

DW5526 5/16" 10" 12"

DW5527*** 3/8" 4" 6-1/2"

DW5529 3/8" 8" 10"

DW55300 3/8" 10" 12"

DW5531 3/8" 16" 18"

DW5532 3/8" 21" 23-1/2"

DW5537*** 1/2" 4" 6"

DW5538 1/2" 8" 10-1/2"

DW5539 1/2" 10" 12"

DW5540 1/2" 16" 18"

DW55410 1/2" 22" 24"

4 Cutter SDS Plus

DW5471 5/8" 8" 10"

DW5472 5/8" 16" 18"

DW5474 3/4" 8" 10"

DW5475 3/4" 16" 18"

DW5477 7/8" 8" 10"

DW5478 7/8" 16" 18"

DW5479 1" 8" 10"

DW5480 1" 16" 18"

DW5481 1-1/8" 8" 10"

DW5482 1-1/8" 16" 18"

SDS Plus Bulk Packs

DW5502B25** 3/16" 2" 4-1/2"

DW5503B25** 3/16" 4" 6-1/2"

DW5504B25 3/16" 6" 8-1/2"

DW55050B25 3/16" 8" 10-1/2"

DW5506B25 3/16" 10" 12"

DW55100B25 7/32" 4" 6-1/2"

DW5516B25** 1/4" 2" 4-1/2"

DW5517B25** 1/4" 4" 6"

DW5518B25 1/4" 6" 8-1/2"

DW5524B25 5/16" 4" 6-1/2"

DW5527B25*** 3/8" 4" 6-1/2"

DW5537B25*** 1/2" 4" 6"

SDS

plus

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

2 Cutter SDS Plus

DW5400 5/32" 2" 4"

DW5401 5/32" 4-1/2" 6-1/2"

DW5402 3/16" 2" 4"

DW5403** 3/16" 4-1/2" 6-1/2"

DW5404** 3/16" 6-1/2" 8-1/2"

DW5405 3/16" 8" 10"

DW5406 3/16" 10" 12"

DW5407 3/16" 12" 14"

DW5408 3/16" 14" 16"

DW5410 7/32" 4" 6"

DW5412 7/32" 8" 10"

DW5416** 1/4" 2" 4"

DW5417** 1/4" 4" 6"

DW5418 1/4" 6-1/2" 8-1/2"

DW5420 1/4" 10" 12"

DW5421 1/4" 12" 14"

DW5424 5/16" 4" 6"

DW5426 5/16" 10" 12"

DW5427*** 3/8" 4" 6"

DW5429 3/8" 8" 10"

DW5430 3/8" 10" 12"

DW5431 3/8" 16" 18"

DW5432 3/8" 22" 24"

DW5433 7/16" 4" 6"

DW5435 7/16" 10" 12"

DW5436 7/16" 16" 18"

DW5437*** 1/2" 4" 6"

DW5438 1/2" 8" 10"

DW5439 1/2" 10" 12"

DW5440 1/2" 16" 18"

DW5441 1/2" 22" 24"

DW5442 9/16" 4" 6"

DW5443 9/16" 10" 12"

DW5444 9/16" 16" 18"

DW5445 9/16" 22" 24"

DW5446*** 5/8" 6" 8"

DW5447 5/8" 10" 12"

DW5448 5/8" 16" 18"

DW5449 5/8" 22" 24"

DW5450 11/16" 6" 8"

DW5453 3/4" 6" 8"

DW5455 3/4" 10" 12"

DW5456 3/4" 16" 18"

DW5457 3/4" 22" 24"

DW5458 27/32" 6" 8"

DW5460 7/8" 6" 8"

DW5461 7/8" 10" 12"

DW5462 7/8" 16" 18"

DW5464 1" 8" 10"

DW5466 1" 16" 18"

DW5468 1-1/8" 8" 10"

DW5469 1-1/8" 16" 18"

SDS

plus

MASONRY

DRILLING

SDS

plus

'JUT"MM#SBOET

&MFDUSJDBOE$PSEMFTT

4%41MVT3PUBSZ

)BNNFSTJODMVEJOH

DE8"-5#PTDI®*

BOE)JMUJ®

*Bosch® is a registered

trademark of Robert

Bosch GmbH and

Hilti® is a registered

trademark of Hilti

Aktiengesellschaft

(continued on next page)

ACCESSORIES 81

ACCESSORIES

MASONRY

DRILLING

CONCRETE & MASONRY DRILLING (continued)

(continued on next page)

SDS

MASONRY

DRILLING

SPLINE

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

2 Cutter Spline

DW5700 3/8" 5" 10"

DW5701 3/8" 8" 13"

DW5702 7/16" 5" 10"

DW5703 1/2" 5" 10"

DW5704 1/2" 11" 16"

DW5705 1/2" 17" 22"

DW5706 1/2" 22" 27"

DW5707 1/2" 31" 36"

DW5708 9/16" 5" 10"

DW5735 9/16" 17" 22"

DW5709 5/8" 5" 10"

DW5710 5/8" 11" 16"

DW5711 5/8" 17" 22"

DW5712 5/8" 22" 27"

DW5713 11/16" 5" 10"

DW5714 3/4" 5" 10"

DW5715 3/4" 11" 16"

DW5716 3/4" 17" 22"

DW5717 3/4" 22" 27"

DW5719 7/8" 11" 16"

DW5720 7/8" 17" 22"

DW5721 1" 11" 16"

DW5722 1" 17" 22"

DW5723 1" 31" 36"

DW5724 1-1/8" 5" 10"

DW5725 1-1/8" 11" 16"

DW5726 1-1/8" 17" 22"

DW5727 1-1/4" 11" 16"

DW5728 1-1/4" 17" 22"

DW5729 1-3/8" 11" 16"

DW5730 1-3/8" 17" 22"

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

4 Cutter SDS Max

DW5806 5/8" 8" 13-1/2"

DW5809 5/8" 16" 21-1/2"

DW5807 5/8" 31" 36"

DW5808 11/16" 16" 21-1/2"

DW5810 3/4" 8" 13-1/2"

DW5812 3/4" 16" 21-1/2"

DW5813 3/4" 31" 36"

DW5814 13/16" 16" 21-1/2"

DW5815 7/8" 8" 13-1/2"

DW5816 7/8" 16" 21-1/2"

DW5851 7/8" 31" 36"

DW5817 27/32" 16" 21-1/2"

DW5818 1" 8" 13-1/2"

DW5819 1" 16" 21-1/2"

DW5852 1" 24" 29"

DW5820 1" 31" 36"

DW5821 1-1/8" 10" 15"

DW5822 1-1/8" 18" 22-1/2"

DW5853 1-1/8" 24" 29"

DW5854 1-1/8" 31" 36"

DW5824 1-1/4" 10" 15"

DW5825 1-1/4" 18" 22-1/2"

DW5855 1-1/4" 24" 29"

DW5826 1-1/4" 31" 36"

DW5860 1-5/16" 18" 22-1/2"

DW5827 1-3/8" 18" 22-1/2"

DW5856 1-3/8" 24" 29"

DW5857 1-3/8" 31" 36"

DW5828 1-1/2" 18" 22-1/2"

DW5858 1-1/2" 24" 29"

DW5859 1-1/2" 31" 36"

DW5830 1-3/4" 18" 22-1/2"

DW5831 2" 18" 22-1/2"

SDS

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

4 Cutter Spline

DW5740 5/8" 5" 10"

DW5741 5/8" 11" 16"

DW5742 5/8" 17" 22"

DW5743 5/8" 22" 27"

DW5744 5/8" 31" 36"

DW5746 3/4" 5" 10"

DW5747 3/4" 11" 16"

DW5748 3/4" 17" 22"

DW5749 3/4" 22" 27"

DW5750 3/4" 31" 36"

DW5751 27-32" 11" 16"

DW5752 7/8" 11" 16"

DW5753 7/8" 17" 22"

DW5755 1" 11" 16"

DW5756 1" 17" 22"

DW5757 1" 31" 36"

DW5758 1-1/8" 11" 16"

DW5759 1-1/8" 17" 22"

DW5760 1-1/4" 11" 16"

DW5761 1-1/4" 17" 22"

DW5762 1-1/4" 31" 36"

DW5763 1-3/8" 11" 16"

DW5765 1-3/8" 17" 22"

DW5764 1-1/2" 17" 22"

DW5768 1-3/4" 17" 22"

DW5769 2" 17" 22"

SPLINE

**Compatible with Pin Anchor Drive

***Compatible with Depth Setter

† Vs. previous design

SCAN FOR MORE INFO

LONGER

LIFE†

2X Less Bit Vibration †

Available

in SDS Max

and Spline

Aggressive Flute

Design Allows for

Fast Driving Speed

Increased

Surface Area

on Carbide Tip†

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

2 Cutter SDS Max

DW5803 1/2" 8" 13-1/2"

DW5804 1/2" 16" 21-1/2"

DW5801 9/16" 8" 13-1/2"

DW5802 9/16" 16" 21-1/2"

DW5870 5/8" 8" 13-1/2"

DW5871 5/8" 16" 21-1/2'

DW5872 3/4" 8" 13-1/2"

DW5873 3/4" 16" 21-1/2"

DW5874 7/8" 8" 13-1/2"

DW5875 7/8" 16" 21-1/2"

DW5876 1" 8" 13-1/2"

DW5877 1" 16" 21-1/2"

DW5878 1-1/8" 10" 15"

DW5879 1-1/8" 18" 22-1/2"

DW5880 1-1/4" 10" 15"

DW5881 1-1/4" 16" 22-1/2"

DW5882 1-3/8" 10" 15"

DW5883 1-3/8" 18" 22-1/2"

SDS

'JUT"MM#SBOETPG4%4

.BY3PUBSZ)BNNFST

JODMVEJOHDEWALT,

#PTDI®BOE)JMUJ®

SPLINE

'JUT"MM#SBOETPG

4%44QMJOF3PUBSZ

)BNNFST*ODMVEJOH

DE8"-5BOE#PTDI®*

*Bosch® is a registered

trademark of Robert

Bosch GmbH and

Hilti® is a registered

trademark of Hilti

Aktiengesellschaft

82 ACCESSORIES

ACCESSORIES

CONCRETE & MASONRY DRILLING (continued)

CAT # INCLUDES

DW5517PAD** Pin Anchor Drive Sleeve & 1/4" SDS Plus Bit

PIN ANCHOR

DRIVE SYSTEM

CAT # INCLUDES

DWA5537DS** Adjustable Depth Setter & 1/2" SDS Plus Bit

DWA500DC Dust Collector

DUST COLLECTOR

& DEPTH SETTER

QSet Pin

Anchors Fast

QNo Hammer

Needed

QIdeal for

Overhead

Applications

PIN ANCHOR

DRIVE SYSTEM

QProprietary

System

ONLY from

DEWALT

QControl Drilling

Depth

QAccurate

Depth Stop for

Setting Drop-in

Anchors

DEPTH

SETTER

QMinimizes Dust

while Drilling

Overhead

QFlexible for

Visibility

QWorks with

Depth Setter

DUST

COLLECTOR

SCAN FOR MORE INFO SCAN FOR MORE INFO

MASONRY

DRILLING

CAT # DIA. USABLE

LENGTH

OVERALL

LENGTH

SDS Plus Hex Bits

DW5359 5/32" 2" 5"

DW5360 5/32" 3" 6"

DW5361 5/32" 4" 7"

DW5362 3/16" 2" 5"

DW5363 3/16" 3" 6"

DW5364 3/16" 4" 7"

DW5365 Drive Sleeve for Hex

SDS Hammer Bit

SDS Plus Hex Bit Bulk Pack

DW5364B25 3/16" 4" 7"

SDS

plus

CAT # DESCRIP-

TION INCLUDES

SDS Plus Hex Bit Kit

DW5366

10 Pc.

Anchor Drive

Installation

Kit

5/32" x 4" x 7",

3/16" x 4" x 7",

Drive Sleeve,

Percussion Bit

Holder, Insert Bit

Adapter, #2 & #3

Insert Bits, 1/4" &

5/16" Nutsetter, Hex

Key, Medium TOUGH

CASE® Container

SDS

plus

SDS

plus

ONE PIECE CARBIDE

CORE BITS

CAT # DIA. LENGTH

SDS Max

DW5914 1-3/4" 12"

DW5915 1-3/4" 22"

DW5916 2" 12"

DW5917 2" 22"

DW5918 2-3/4" 12"

DW5919 2-3/4" 22"

DW5920 3-1/4" 12"

DW5921 3-1/4" 22"

DW5922 3-1/2" 12"

DW5923 3-1/2" 22"

CAT # DIA. LENGTH

SDS Max (continued)

DW5924 4" 12"

DW5925 4" 22"

DW5926 5" 22"

DW5927 6" 22"

Spline

DW5930 1-3/4" 12"

DW5931 1-3/4" 22"

DW5932 2" 12"

DW5933 2" 22"

DW5934 2-3/4" 12"

CAT # DIA. LENGTH

Spline (continued)

DW5935 2-3/4" 22"

DW5937 3-1/4" 22"

DW5938 3-1/2" 12"

DW5939 3-1/2" 22"

DW5940 4" 12"

DW5941 4" 22"

DW5942 5" 22"

DW5943 6" 22"

DW5945 Replacement Centering Bit

**Must use specified SDS Plus bits (on previous page)

SPLINE

SDS

(continued on next page)

ACCESSORIES 83

ACCESSORIES

CAT # DESCRIPTION

SDS Plus Steel

DW5348 10" Bull Point

DW5349 10" Scaling Chisel

DW5350 10" Cold Chisel

SDS Max

DW5832 12" Bull Point

DW5833 18" Bull Point

DW5834 1" x 12" Cold Chisel

DW5835 1" x 18" Cold Chisel

DW5837 2" x 12" Scaling Chisel

DW5838 3" x 12" Scaling Chisel

DW5848B 4" Clay Spade

DW5843 10" Bushing Tool

DW5847 3/4" Ground Rod Driver

DW5842 12" Slotting Tool

DW5846 Asphalt Cutter

DW5832B15** 12" Bull Point Bit

DW5833B15** 18" Bull Point Bit

DW5834B15** 12" Cold Chisel

DW5835B15** 18" Cold Chisel

DW5838B10** 3" Scaling Chisel

DW5843B10** Bushing Tool

CONCRETE & MASONRY DRILLING (continued)

TWO PIECE

CARBIDE

CORE BITS

CAT # DESCRIPTION DIA.

DW5900 1-1/2" x 4" Core Bit Body 1-1/2"

DW5901 2" x 4" Core Bit Body 2"

DW5902 2-1/2" x 4" Core Bit Body 2-1/2"

DW5903 3" x 4" Core Bit Body 3"

DW5904 3-1/2" x 4" Core Bit Body 3-1/2"

DW5905 4" x 4" Core Bit Body 4"

DW5906 5" x 4" Core Bit Body 5"

CAT # DESCRIPTION

DW5907 Centering Core Bit Body

DW5909 7" Spline Core Bit Shank

DW5910 16" Spline Core Bit Shank

DW5911 7" SDS Max Core Bit Shank

DW5912 16" SDS Max Core Bit Shank

DW5908 Thread Adapter

DIAMOND

DRILL BITS FOR TILE

CAT # DESCRIPTION

DW5570 3/16" Diamond Drill Bit

DW5572 1/4" Diamond Drill Bit

DW5574 5/16" Diamond Drill Bit

DW5576 3/8" Diamond Drill Bit

DW5578 1/2" Diamond Drill Bit

DW5580 5/8" Diamond Drill Bit

DW5582 3/4" Diamond Drill Bit

DW5584 1" Diamond Drill Bit

DW5586 1-3/8" Diamond Drill Bit

CHISELS &

DEMOLITION

STEEL

CAT # DESCRIPTION

Spline - 3/4" Hex x 21/32" Round Spline Shank

DW5770 12" Bull Point

DW5771 18" Bull Point

DW5779 1" x 12" Cold Chisel

DW5780 1" x 18" Cold Chisel

DW5773 1-1/2" x 12" Scaling Chisel

DW5774 2" x 12" Scaling Chisel

DW5775 3" x 12" Scaling Chisel

DW5786B 4-1/2" Clay Spade

DW5783 10" Bushing Tool

DW5785 3/4" Ground Rod Driver

DW5772 12" Slotting Tool

DW5770B15** 12" Bull Point

DW5771B15** 18" Bull Point

DW5775B10** 3" Scaling Chisel

DW5779B15** 12" Cold Chisel

DW5780B15** 18" Cold Chisel

DW5783B10** 10" Bushing Tool

CAT # DESCRIPTION

3/4" Hex

DW5950 12" Bull Point

DW5951 18" Bull Point

DW5953 1" x 12" Cold Chisel

DW5954 1" x 18" Cold Chisel

DW5952 3" x 12" Scaling Chisel

DW5959B 4-1/2" Clay Spade

DW5949 10" Bushing Tool

DW5958 3/4" Ground Rod Driver

DW5949B10 10" Bushing Tool

DW5950B15 12" Bull Point Chisel

DW5951B15 18" Bull Point

DW5952B10 3" Scaling Chisel

DW5953B15 1" x 12" Cold Chisel

DW5954B15 1" x 18" Cold Chisel

1-1/8" Hex

DW5960 20" Bull Point

DW5962 20" Cold Chisel

DW5961 3" x 20" Scaling Chisel

DW5965 5-1/2" Clay Spade

DW5964 1" Ground Rod Driver

DW5963 17" Asphalt Cutter

'JUT"MM#SBOET

PG4%41MVT

)BNNFST

'JUT"MM#SBOETPG

4%4.BY$IJQQJOH

BOE%FNPMJUJPO

)BNNFST

'JUT"MM#SBOETPG

4QMJOF$IJQQJOH

BOE%FNPMJUJPO

)BNNFST

'JUT"MM#SBOETPG

")FY$IJQQJOH

BOE%FNPMJUJPO

)BNNFST

'JUT"MM#SBOET

PG")FY

1BWFNFOU

#SFBLFST

Ring and notch

retentions allow for

use in electric and

pneumatic hammers.

SHANK

ADAPTERS

CAT # DESCRIPTION

DW5351 SDS Plus to 1/2" Chuck Adapter

DW5790 Spline to 1/2" Chuck Adapter

CAT # DESCRIPTION

DW5353 1/2" Chuck & Key

DW5791 Spline to SDS Plus Adapter

CAT # DESCRIPTION

DW5891 SDS Max to SDS Plus Adapter

SDS

plus

SDS SPLINE HEX HEX

CAT # DESCRIPTION

SDS Plus

DWA5320 12" Bull Point

DWA5321 1-1/2" x 12" Scaling Chisel

DWA5322 3/4" x 12" Cold Chisel

SDS Max

DWA5850 12" Bull Point

DWA5851 16" Bull Point Bit

DWA5852 1" x 12" Cold Chisel

DWA5853 1" x 16" Cold Chisel

DWA5854 2" x 16" Scaling Chisel

DWA5855 3" x 16" Scaling Chisel

SDS

plus

SDS

**Bulk

CAT # DESCRIPTION

3/4" Hex

DWA5970 16" Bull Point 3/4" Hex

DWA5973 1" x 16" Cold Chisel 3/4" Hex

HEX

***Vs. competitive products

SPLINE

SDS

LONGER LIFE***

CAT # DESCRIPTION INCLUDES

DW22838 3/8" 10 Pc. Socket

Set - IMPACT READY®

5/16", 3/8", 7/16", 1/2", 9/16", 5/8",

11/16", 3/4", 1/2" & (2) 1/4"-3/8" Adapters

DW22812 1/2" 10 Pc. Socket

Set - IMPACT READY®

7/16", 1/2", 9/16", 5/8", 11/16", 3/4",

13/16", 7/8" & (2) 1/4"-1/2" Adapters

SOCKET SETS

DW22838

SOCKET

ADAPTERS

CAT # DESCRIPTION

DW2541IR

1/4" Hex Shank to 1/4" Socket Adapter

DW2542IR

1/4" Hex Shank to 3/8" Socket Adapter

DW2547IR

1/4" Hex Shank to 1/2" Socket Adapter

DW2298 1/2

" Square

to 1/4

RAPID LOAD® Adapter

DW2299 1/2

to 3/8

Reducer

IMPACT READY® FASTENING

TIPS &

POWER BITS

CAT # DESCRIPTION LENGTH QTY.

Phillips

DW2001IR #1 Phillips - IMPACT READY®1" 2

DW2002IR #2 Phillips - IMPACT READY®1" 2

DW2002IR10 #2 Phillips Bit Tips - IMPACT READY®1" 10

DW2003IR #3 Phillips - IMPACT READY®1" 2

DW2004IR #2 Phillips (Reduced Dia.) - IMPACT READY®1" 2

DW2022IR #2 Phillips Power Bit - IMPACT READY®2" 2

DW2032IR #2 Phillips Power Bit - IMPACT READY®3-1/2" 2

DW2062IR #2 Phillips Power Bit - IMPACT READY® 6" 1

Square Recess Bit Tips

DW2201IR #1 Square Recess - IMPACT READY®1" 2

DW2202IR #2 Square Recess - IMPACT READY®1" 2

CAT # DESCRIPTION LENGTH QTY.

Square Recess Bit Tips (continued)

DW2202IR10 #2 Square Recess Bit Tips - IMPACT READY®1" 10

DW2212IR #2 Square Recess Power Bit - IMPACT READY®2" 2

Torx®* Bit Tips

DW2620IR T20 - IMPACT READY® 1" 2

DW2660IR T20 - IMPACT READY®2" 2

DW2625IR T25 - IMPACT READY®1" 2

DW2665IR T25 - IMPACT READY® 2" 2

DW2670IR T30 - IMPACT READY®2" 2

DW2680IR T40 - IMPACT READY®2" 2

DW2605IR 4 Pc. Torx®* Set - IMPACT READY®

INCLUDES: 1" T15/T20/T25/3" Holder -1

CAT # SOCKET

SIZE

DRIVE

SIZE

DW2281 1/4" 3/8"

DW2282 5/16" 3/8"

DW2283 11/32" 3/8"

DW2284 3/8" 3/8"

DW2285 7/16" 3/8"

DW2286 1/2" 3/8"

DW2287 9/16" 3/8"

DW2288 5/8" 3/8"

DW2289 11/16" 3/8"

DW2290 3/4" 3/8"

DW22842 3/8" 1/2"

DW22852 7/16" 1/2"

CAT # SOCKET

SIZE

DRIVE

SIZE

DW22862 1/2" 1/2"

DW22872 9/16" 1/2"

DW22882 5/8" 1/2"

DW22892 11/16" 1/2"

DW22902 3/4" 1/2"

DW22912 13/16" 1/2"

DW22922 7/8" 1/2"

DW22932 15/16" 1/2"

DW22942 1" 1/2"

DW22952 1-1/16" 1/2"

DW22962 1-1/8" 1/2"

DW22972 1-1/4" 1/2"

SOCKETS

*Torx® is a registered trademark of Textron

BIT TIPS SOCKETS

84 ACCESSORIES

ACCESSORIES

(continued on next page)

IMPACT READY® FASTENING (continued)

NUT

DRIVERS

CAT # DESCRIPTION

DW2218IR 1/4" x 1-7/8" Magnetic Nut Driver - IMPACT READY®

DW2219IR 5/16" x 1-7/8" Magnetic Nut Driver - IMPACT READY®

DW2220IR 3/8" x 1-7/8" Magnetic Nut Driver - IMPACT READY®

DW2227IR 7/16" x 1-7/8" Magnetic Nut Driver - IMPACT READY®

DW2230IR 1/2" x 1-7/8" Magnetic Nut Driver - IMPACT READY®

DW2221IR 1/4" x 2-9/16" Magnetic Nut Driver - IMPACT READY®

DW2222IR 5/16" x 2-9/16" Magnetic Nut Driver - IMPACT READY®

DW2223IR 3/8" x 2-9/16" Magnetic Nut Driver - IMPACT READY®

DW2228IR 7/16" x 2-9/16" Magnetic Nut Driver - IMPACT READY®

DW2234IR 1/2" x 2-9/16" Magnetic Nut Driver - IMPACT READY®

DW2235IR 5 Pc. Magnetic Nut Driver Set (1/4", 5/16", 3/8", 7/16",

1/2") - IMPACT READY®

PIVOTING

NUT DRIVERS

CAT # DESCRIPTION

DW2221IRP 1/4" Magnetic Pivoting Nut Driver - IMPACT READY®

DW2219IRP 5/16" Magnetic Pivoting Nut Driver - IMPACT READY®

DW2223IRP 3/8" Magnetic Pivoting Nut Driver - IMPACT READY®

DW2228IRP 7/16" Magnetic Pivoting Nut Driver - IMPACT READY®

DW2234IRP 1/2" Magnetic Pivoting Nut Driver - IMPACT READY®

DWPVTDRV3 3 Pc. Pivoting Netsetters (1/4", 5/16", 3/8") -

IMPACT READY®

DWPVTDRV 4 Pc. Pivoting Netsetters (1/4", 5/16", 3/8", 7/16") -

IMPACT READY®

DWPVTSET 10 Pc. Screwdriving Set - IMPACT READY®

CLEANABLE

NUT DRIVERS

CAT # DESCRIPTION

DWA2221IR

1/4" IMPACT READY

Cleanable Nut Driver

DWA2222IR

5/16" IMPACT READY

Cleanable Nut Driver

DWA2223IR

3/8" IMPACT READY

Cleanable Nut Driver

DWA2228IR

7/16" IMPACT READY

Cleanable Nut Driver

DWA2230IR

1/2" IMPACT READY

Cleanable Nut Driver

DWA2240IR

3 Pc. IMPACT READY

Cleanable Nut Driver

BIT TIP

HOLDERS

CAT # DESCRIPTION

DW2046 2" Magnetic

DWHJHLD

IMPACT CLUTCH

DWA2509

RAPID LOAD

Holder with SureSet

System

DWARA100

Right Angle Attachment with SureSet

System

Hog Ring**

DW2045 3" Magnetic with Hog Ring

DWPVTHLD Magnetic Pivot Holder with Hog Ring

**Hog ring helps secure bit, must use pliers to remove bit

NUT DRIVERS

INNOVATIVE

HOLDERS

ACCESSORIES

DW5060

DRILLING

SETS

CAT # DESCRIPTION INCLUDES

DD5055 5 Pc. Drilling Set -

IMPACT READY®(2) 1/8", 5/32", 3/16", 1/4"

DD5057 7 Pc. Drilling Set -

IMPACT READY®(2) 1/8", 5/32", 3/16", 7/32", 1/4", 5/16"

DD5060 10 Pc. Drilling Set -

IMPACT READY®

(2) 1/8", 9/64", 5/32", 11/64", 3/16", 7/32",

1/4", 5/16", 3/8", TOUGH CASE® Container

DW5057

CAT # QTY./

CARD BULK BULK

QTY.

DIA.

INCHES

DIA.

DECIMAL

OVERALL

LENGTH

DD5008 1 DD5008B6 6 1/8" .1250" 2.625"

DD5009 1 DD5009B6 6 9/64" .1406" 2.75"

DD5010 1 DD5010B6 6 5/32" .1562" 2.8125"

DD5011 1 DD5011B6 6 11/64" .1719" 2.9375"

DD5012 1 DD5012B6 6 3/16" .1875" 3"

DD5013 1 DD5013B6 6 13/64" .2031" 3.0625"

DD5014 1 DD5014B6 6 7/32" .2188" 3.125"

DD5015 1 DD5015B6 6 15/64" .2344" 3.15625"

CAT # QTY./

CARD BULK BULK

QTY.

DIA.

INCHES

DIA.

DECIMAL

OVERALL

LENGTH

DD5016 1 DD5016B6 6 1/4" .2500" 3.1875"

DD5018 1 DD5018B3 3 9/32" .2812" 3.5"

DD5020 1 DD5020B3 3 5/16" .3125" 4"

DD5022 1 DD5022B3 3 11/32" .3437" 4"

DD5024 1 DD5024B3 3 3/8" .3750" 4"

DD5028 1 DD5028B3 3 7/16" .4375" 4"

DD5032 1 DD5032B3 3 1/2" .5000" 4"

DRILLING

STEP DRILL

BITS

CAT # DESCRIPTION # OF

HOLES

STEP

INCREMENTS

SHANK

DIA.

MAX. MAT.

THICKNESS

Hex Shank - IMPACT READY®

DWA1783IR 1/8" – 1/2" Step Drill

Bit - IMPACT READY® 13 1/32" 1/4" 1/8"

DWA1784IR 3/16" – 1/2" Step Drill

Bit - IMPACT READY® 6 1/16” 1/4" 5/16"

DWA1786IR 3/16" – 7/8" Step Drill

Bit - IMPACT READY® 12 1/16" 1/4" 1/8"

DWA1789IR 7/8" – 1-1/8" Step Drill

Bit - IMPACT READY® 2 - 1/4" 1/8"

DWA1790IR 3 Pc. Step Drill Bit Set -

IMPACT READY®

Total

1/32"

1/16"

1/4"

1/8"

5/16"

1/8"

IMPACT READY® DRILLING

DW2153

CAT # DESCRIPTION

TOUGH CASE® Sets

DW2149 28 Pc. Accessory Set - IMPACT READY®

DW2153 34 Pc. Screwdriving Set - IMPACT READY®

DW2169 38 Pc. Fastening Set - IMPACT READY®

DW2180 35 Pc. Drilling/Fastening Set - IMPACT READY®

DW2183 26 Pc. Set - IMPACT READY®

DW2583 65 Pc. Accessory Mac Set - IMPACT READY®

Magnetic TOUGH CASE® Sets

DWMTCIR20 20 Pc. Magnetic TOUGH CASE® Set - IMPACT READY®

Compact TOUGH CASE® Sets

DWAX100IR 31pc. Screwdriving set with Compact TOUGH CASE®

SETS

DWMTCIR20 DWAX100IR

CAT # SIZE

Inches

SIZE

Metric

D180012IR 3/4" 19mm

D180014IR 7/8" 22mm

D180016IR 1" 25mm

D180018IR 1-1/8" 29mm

D180020IR 1-1/4" 32mm

HOLE

SAWS

CAT # SIZE

Inches

SIZE

Metric

D180022IR 1-3/8" 35mm

D180024IR 1-1/2" 38mm

D1800IR5

TOUGH CASE®

5 Pc. Set

3/4", 7/8",

(2) 1-1/8",

1-3/8"

19, 22, (2)

29, 35mm

DRILL BITS 5X

MORE DURABLE HOLE SAWS STEP BITS

2X LIFE

86 ACCESSORIES

ACCESSORIES

INDUSTRIAL METAL DRILLING Ideal for Drill

Press, CNC,

Corded &

Cordless Drills

INDUSTRIAL

COBALT

CAT # DIAMETER FLUTE

LENGTH

OVERALL

LENGTH

Fractional Jobber

DD4004B12 1/16" 7/8" 1-7/8"

DD4005B12 5/64" 1" 2"

DD4006B12 3/32" 1-1/4" 2-1/4"

DD4007B12 7/64" 1-1/2" 2-5/8"

DD4008B12 1/8" 1-1/8" 2-3/4"

DD4009B12 9/64" 1-1/4" 2-7/8"

DD4010B12 5/32" 1-1/2" 3-1/8"

DD4011B12 11/64" 1-5/8" 3-1/4"

DD4012B12 3/16" 1-3/4" 3-1/2"

DD4013B12 13/64" 1-7/8" 3-5/8"

DD4014B12 7/32" 2" 3-3/4"

DD4015B12 15/64" 2-1/8" 3-7/8"

DD4016B12 1/4" 2-1/4" 4"

DD4017B12 17/64" 2-3/8" 4-1/8"

DD4018B12 9/32" 2-1/2" 4-1/4"

DD4019B12 19/64" 2-5/8" 4-3/8"

DD4020B6 5/16" 2-3/4" 4-1/2"

DD4021B6 21/64" 2-7/8" 4-5/8"

DD4022B6 11/32" 3" 4-3/4"

DD4023B6 23/64" 3-1/8" 4-7/8"

DD4024B6 3/8" 3-1/4" 5"

DD4025B6 25/64" 3-5/16" 5-1/8"

DD4026B6 13/32" 3-3/8" 5-1/4"

DD4027B6 27/64" 3-1/2" 5-3/8"

DD4028B6 7/16" 3-5/8" 5-1/2"

DD4029B6 29/64" 3-3/4" 5-5/8"

DD4030B6 15/32" 3-7/8" 5-3/4"

DD4031B6 31/64" 4" 5-7/8"

DD4032B6 1/2" 4-1/8" 6"

Fractional Screw Machine

DD4104B12 1/16" 5/8" 1-5/8"

DD4105B12 5/64" 11/16" 1-11/16"

DD4106B12 3/32" 3/4" 1-3/4"

DD4107B12 7/64" 13/16" 1-13/16"

DD4108B12 1/8" 7/8" 1-7/8"

DD4109B12 9/64" 15/16" 1-15/16"

DD4110B12 5/32" 1" 2-1/6"

DD4111B12 11/64" 1-1/16" 2-1/8"

DD4112B12 3/16" 1-1/8" 2-3/16"

DD4113B12 13/64" 1-3/16" 2-1/4"

DD4114B12 7/32" 1-1/4" 2-3/8"

DD4115B12 15/64" 1-5/16" 2-7/16"

DD4116B12 1/4" 1-3/8" 2-1/2"

DD4117B12 17/64" 1-7/16" 2-5/8"

DD4118B12 9/32" 1-1/2" 2-11/16"

DD4119B12 19/64" 1-9/16" 2-3/4"

DD4120B6 5/16" 1-5/8" 2-13/16"

DD4121B6 21/64" 1-11/16" 2-15/16"

DD4122B6 11/32" 1-11/16" 3"

DD4123B6 23/64" 1-3/4" 3-1/16"

CAT # DIAMETER FLUTE

LENGTH

OVERALL

LENGTH

Fractional Screw Machine (continued)

DD4124B6 3/8" 1-13/16" 3-1/8"

DD4125B6 25/64" 1-7/8" 3-1/4"

DD4126B6 13/32" 1-15/16" 3-5/16"

DD4127B6 27/64" 2" 3-3/8"

DD4128B6 7/16" 2-1/16" 3-7/16"

DD4129B6 29/64" 2-1/8" 3-9/16"

DD4130B6 15/32" 2-1/8" 3-5/8"

DD4131B6 31/64" 2-3/16" 3-11/16"

DD4132B6 1/2" 2-1/4"

3-3/4"

Numbered Jobber

DD4201B12 #1 2-5/8" 3-7/8"

DD4202B12 #2 2-5/8" 3-7/8"

DD4203B12 #3 2-1/2" 3-3/4"

DD4204B12 #4 2-1/2" 3-3/4"

DD4205B12 #5 2-1/2" 3-3/4"

DD4206B12 #6 2-1/2" 3-3/4"

DD4207B12 #7 2-7/16" 3-5/8"

DD4208B12 #8 2-7/16" 3-5/8"

DD4209B12 #9 2-7/16" 3-5/8"

DD4210B12 #10 2-7/16" 3-5/8"

DD4211B12 #11 2-5/16" 3-1/2"

DD4212B12 #12 2-5/16" 3-1/2"

DD4213B12 #13 2-5/16" 3-1/2"

DD4214B12 #14 2-3/16" 3-3/8"

DD4215B12 #15 2-3/16" 3-3/8"

DD4216B12 #16 2-3/16" 3-3/8"

DD4217B12 #17 2-3/16" 3-3/8"

DD4219B12 #18 2-1/8" 3-1/4"

DD4219B12 #19 2-1/8" 3-1/4"

DD4220B12 #20 2-1/8" 3-1/4"

DD4221B12 #21 2-1/8" 3-1/4"

DD4222B12 #22 2" 3-1/8"

DD4223B12 #23 2" 3-1/8"

DD4224B12 #24 2" 3-1/8"

DD4225B12 #25 1-7/8" 3"

DD4226B12 #26 1-7/8" 3"

DD4227B12 #27 1-7/8" 3"

DD4228B12 #28 1-3/4" 2-7/8"

DD4229B12 #29 1-3/4" 2-7/8"

DD4230B12 #30 1-5/8" 2-3/4"

Numbered Screw Machine

DD4301B12 #1 1-5/16" 2-7/16"

DD4302B12 #2 1-5/16" 2-7/16"

DD4303B12 #3 1-1/4" 2-3/8"

DD4304B12 #4 1-1/4" 2-3/8"

DD4305B12 #5 1-1/4" 2-3/8"

DD4306B12 #6 1-1/4" 2-3/8"

DD4307B12 #7 1-3/16" 2-1/4"

DD4308B12 #8 1-3/16" 2-1/4"

DD4309B12 #9 1-3/16" 2-1/4"

CAT # DIAMETER FLUTE

LENGTH

OVERALL

LENGTH

Numbered Screw Machine (continued)

DD4310B12 #10 1-3/16" 2-1/4"

DD4311B12 #11 1-3/16" 2-1/4"

DD4312B12 #12 1-3/16" 2-1/4"

DD4313B12 #13 1-1/8" 2-3/16"

DD4314B12 #14 1-1/8" 2-3/16"

DD4315B12 #15 1-1/8" 2-3/16"

DD4316B12 #16 1-1/8" 2-3/16"

DD4317B12 #17 1-1/8" 2-3/16"

DD4318B12 #18 1-1/16" 2-1/8"

DD4319B12 #19 1-1/16" 2-1/8"

DD4320B12 #20 1-1/16" 2-1/8"

DD4321B12 #21 1-1/16" 2-1/8"

DD4322B12 #22 1-1/16" 2-1/8"

DD4323B12 #23 1" 2-1/16"

DD4324B12 #24 1" 2-1/16"

DD4325B12 #25 1" 2-1/16"

DD4326B12 #26 1" 2-1/16"

DD4327B12 #27 1" 2-1/16"

DD4328B12 #28 15/16" 1-15/16"

DD4329B12 #29 15/16" 1-15/16"

DD4330B12 #30 15/16" 1-15/16"

Lettered Jobber

DD4401B12 A 2-5/8" 3-7/8"

DD4402B12 B 2-3/4" 4"

DD4403B12 C 2-3/4" 4"

DD4404B12 D 2-3/4" 4"

DD4405B12 E 2-3/4" 4"

DD4406B12 F 2-7/8" 4-1/8"

DD4407B12 G 2-7/8" 4-1/8"

DD4408B12 H 2-7/8" 4-1/8"

DD4409B12 I 2-7/8" 4-1/8"

DD4410B12 J 2-7/8" 4-1/8"

DD4411B12 K 2-15/16" 4-1/4"

DD4412B12 L 2-15/16" 4-1/4"

DD4413B12 M 3-1/16" 4-3/8"

DD4414B12 N 3-1/16" 4-3/8"

DD4415B6 O 3-3/16" 4-1/2"

DD4416B6 P 3-5/16" 4-5/8"

DD4417B6 Q 3-7/16" 4-3/4"

DD4418B6 R 3-7/16" 4-3/4"

DD4419B6 S 3-1/2" 4-7/8"

DD4420B6 T 3-1/2" 4-7/8"

DD4421B6 U 3-5/8" 5"

DD4422B6 V 3-5/8" 5"

DD4423B6 W 3-3/4" 5-1/8"

DD4424B6 X 3-3/4" 5-1/8"

DD4425B6 Y 3-7/8" 5-1/4"

DD4426B6 Z 3-7/8" 5-1/4"

ACCESSORIES

METAL & WOOD DRILLING

COBALT

PILOT POINT®

CAT # QTY./

CARD

DIA.

INCHES

DIA.

DECIMAL

DRILLING

DEPTH

OVERALL

LENGTH

DW1204 1 1/16" .0625" .88" 1.88"

DW1205 1 5/64" .0781" 1.00" 2.00"

DW1206 1 3/32" .0938" 1.25" 2.25"

DW1207 1 7/64" .1094" 1.50" 2.62"

DW1208 1 1/8" .1250" 1.62" 2.75"

DW1209 1 9/64" .1406" 1.75" 2.88"

DW1210 1 5/32" .1562" 2.00" 3.12"

DW1211 1 11/64" .1719" 2.12" 3.25"

DW1212 1 3/16" .1875" 2.31" 3.50"

CAT # QTY./

CARD

DIA.

INCHES

DIA.

DECIMAL

DRILLING

DEPTH

OVERALL

LENGTH

DW1213 1 13/64" .2031" 2.44" 3.62"

DW1214 1 7/32" .2188" 2.50" 3.75"

DW1215 1 15/64" .2344" 2.62" 3.88"

DW1216 1 1/4" .2500" 2.75" 4.00"

DW1220 1 5/16" .3125" 3.19" 4.50"

DW1224 1 3/8" .3750" 3.62" 5.00"

DW1228** 1 7/16" .4375" 4.06" 5.59"

DW1232** 1 1/2" .5000" 4.5" 6.00"

**3/8" Reduced shank

COBALT SETS

CAT # DESCRIPTION INCLUDES

DW1263 14 Pc. Cobalt PILOT

POINT® Drill Bit Set

(2) 1/16", 5/64", 3/32", 7/64", (2) 1/8", 9/64", 5/32", 3/16", 7/32", 1/4", 5/16", 3/8",

TOUGH CASE® Container

DW1269 29 Pc. Cobalt PILOT

POINT® Drill Bit Set

1/16", 5/64", 3/32", 7/64", 1/8", 9/64", 5/32", 11/64", 3/16", 13/64", 7/32", 15/64",

1/4", 17/64", 9/32", 19/64", 5/16", 21/64", 11/32", 23/64", 3/8", 25/64", 13/32", 27/64",

7/16", 29/64", 15/32", 31/64", 1/2", TOUGH CASE® Container

DD4069 29 Pc. Cobalt Set

1/16", 5/64", 3/32", 7/64", 1/8", 9/64", 5/32", 11/64", 3/16", 13/64", 7/32",

15/64", 1/4", 17/64", 9/32", 19/64", 5/16", 21/64", 11/32", 23/64", 3/8", 25/64",

13/32", 27/64", 7/16", 29/64", 15/32", 31/64", 1/2", TOUGH CASE® Container DW1269 DW1263DD4069

TITANIUM

SPEED TIP

CAT # QTY./

CARD

DIA.

INCHES

DIA.

DECIMAL

DRILLING

DEPTH

OVERALL

LENGTH

DW1304 2 1/16" .0625" .88" 1.88"

DW1305 2 5/64" .0781" 1.00" 2.00"

DW1306 2 3/32" .0938" 1.25" 2.25"

DW1307 2 7/64" .1094" 1.50" 2.62"

DW1308 2 1/8" .1250" 1.62" 2.75"

DW1309 1 9/64" .1406" 1.75" 2.88"

DW1310 1 5/32" .1562" 2.00" 3.12"

DW1311 1 11/64" .1719" 2.12" 3.25"

DW1312 1 3/16" .1875" 2.31" 3.50"

CAT # QTY./

CARD

DIA.

INCHES

DIA.

DECIMAL

DRILLING

DEPTH

OVERALL

LENGTH

DW1313 1 13/64" .2031" 2.44" 3.62"

DW1314 1 7/32" .2188" 2.50" 3.75"

DW1315 1 15/64" .2344" 2.62" 3.88"

DW1316 1 1/4" .2500" 2.75" 4.00"

DW1320 1 5/16" .3125" 3.19" 4.50"

DW1324 1 3/8" .3750" 3.62" 5.00"

DW1328** 1 7/16" .4375" 4.06" 5.50"

DW1332** 1 1/2" .5000" 4.50" 6.00"

**3/8" Reduced shank

TITANIUM SETS

CAT # DESCRIPTION INCLUDES

DW1363 13 Pc. Titanium Drill Bit Set (2) 1/16", 5/64", (2) 3/32", 7/64", (2) 1/8", 9/64", 5/32", 3/16", 7/32", 1/4", TOUGH CASE® Container

DW1341 14 Pc. Titanium Speed Tip Drill

Bit Set

(2) 1/16", 5/64", 3/32", 7/64", (2) 1/8", 9/64", 3/16", 7/32", 1/4", 5/16", 3/8", 1/2", TOUGH CASE®

Container

DW1342 21 Pc. Titanium Speed Tip Drill

Bit Set

(2) 1/16", (2) 5/64", 3/32", 7/64", (2) 1/8", 9/64", 5/32", 11/64", (2) 3/16", (2) 13/64", 7/32", 15/64",

1/4", 5/16", 3/8", 1/2", TOUGH CASE® Container

DW1354 14 Pc. Titanium PILOT POINT®

Drill Bit Set

1/16", 5/64", 3/32", 7/64", (2) 1/8", 9/64", 5/32", 3/16", 7/32", 1/4", 5/16", 3/8", 1/2", TOUGH CASE®

Container

DW1361 21 Pc. Titanium PILOT POINT®

Drill Bit Set

(2) 1/16", (2) 5/64", 3/32", 7/64", (2) 1/8", 9/64", 5/32", 11/64", (2) 3/16", 13/64", 7/32", 15/64", (2)

1/4", 5/16", 3/8", 1/2", TOUGH CASE® Container

DW1369 29 Pc. Titanium PILOT POINT®

Drill Bit Set

1/16", 5/64", 3/32", 7/64", 1/8", 9/64", 5/32", 11/64", 3/16", 13/64", 7/32", 15/64", 1/4", 17/64",

9/32", 19/64", 5/16", 21/64", 11/32", 23/64", 3/8", 25/64", 13/32", 27/64", 7/16", 29/64", 15/32",

31/64", 1/2", TOUGH CASE® Container

DW1361

(continued on next page)

88 ACCESSORIES

ACCESSORIES

METAL & WOOD DRILLING (continued)

BLACK OXIDE

CAT # DIAMETER DRILLING

DEPTH

OVERALL

LENGTH QTY.

DW1104 1/16" .88" 1.88" 2

DW1105 5/64" 1" 2" 2

DW1106 3/32" 1.25" 2.25" 2

DW1107 7/64" 1.5" 2.62" 2

DW1108 1/8" 1.62" 2.75" 2

DW1109 9/64" 1.75" 2.88" 1

DW1110 5/32" 2" 3.12" 1

DW1111 11/64" 2.12" 3.25" 1

DW1112 3/16" 2.31" 3.5" 1

DW1113 13/64" 2.44" 3.62" 1

DW1114 7/32" 2.5" 3.75" 1

DW1115 15/64" 2.62" 3.88" 1

DW1116 1/4" 2.75" 4.00" 1

DW1117 17/64" 2.88" 4.12" 1

DW1118 9/32" 2.94" 4.25" 1

DW1119 19/64" 3.06" 4.38" 1

DW1120 5/16" 3.19" 4.5" 1

DW1121 21/64" 3.31" 4.62" 1

DW1122 11/32" 3.44" 4.75" 1

DW1123 23/64" 3.5" 4.88" 1

DW1124 3/8" 3.62" 5.00" 1

DW1125** 25/64" 3.75" 5.12" 1

DW1126** 13/32" 3.88" 5.25" 1

DW1127** 27/64" 3.94" 5.50" 1

DW1128** 7/16" 4.06" 5.59" 1

DW1129** 29/64" 4.19" 5.75" 1

CAT # DIAMETER DRILLING

DEPTH

OVERALL

LENGTH QTY.

DW1130** 15/32" 4.31" 5.87" 1

DW1131** 31/64" 4.38" 5.98" 1

DW1132** 1/2" 4.5" 6.00" 1

Reduced Shank

DW1620** 9/16" 3" 6" 1

DW1622** 5/8" 3" 6" 1

DW1623** 11/16" 3" 6" 1

DW1625** 3/4" 3" 6" 1

DW1627*** 7/8" 3" 6" 1

DW1629*** 1" 3" 6" 1

6" Extended Length Bit

DW1603 1/8" 1.65" 6" 1

DW1605 3/16" 2.36" 6" 1

DW1607 1/4" 2.83" 6" 1

DW1609 5/16" 3.27" 6" 1

DW1611 3/8" 3.74" 6" 1

DW1615 1/2" 4.65" 6" 1

12" Extended Length Bit

DW1602 1/8" 1.65" 12" 1

DW1604 3/16" 2.36" 12" 1

DW1606 1/4" 2.83" 12" 1

DW1608 5/16" 3.26" 12" 1

DW1610 3/8" 3.74" 12" 1

DW1612** 7/16" 4.17" 12" 1

DW1614** 1/2" 4.64" 12" 1

**3/8" Reduced shank ***1/2" Reduced shank

DW1116

GOLD FERROUS

PILOT POINT®

CAT # QTY./

CARD BULK BULK

QTY.

DIA.

INCHES

DIA.

DECIMAL

DRILLING

DEPTH

OVERALL

LENGTH

DW1904 2 DW1904B 12 1/16" .0625" .88" 1.88"

DW1905 2 DW1905B 12 5/64" .0781" 1.00" 2.00"

DW1906 2 DW1906B 12 3/32" .0938" 1.25" 2.25"

DW1907 2 DW1907B 12 7/64" .1094" 1.50" 2.62"

DW1908 2 DW1908B 12 1/8" .1250" 1.62" 2.75"

DW1909 1 DW1909B 12 9/64" .1406" 1.75" 2.88"

DW1910 1 DW1910B 12 5/32" .1562" 2.00" 3.12"

DW1911 1 DW1911B 12 11/64" .1719" 2.12" 3.25"

DW1912 1 DW1912B 12 3/16" .1875" 2.31" 3.50"

DW1913 1 DW1913B 12 13/64" .2031" 2.44" 3.62"

DW1914 1 DW1914B 12 7/32" .2188" 2.50" 3.75"

DW1915 1 DW1915B 12 15/64" .2344" 2.62" 3.88"

DW1916 1 DW1916B 12 1/4" .2500" 2.75" 4.00"

DW1917 1 DW1917B 12 17/64" .2656" 2.88" 4.12"

DW1918 1 DW1918B 12 9/32" .2812" 2.94" 4.25"

CAT # QTY./

CARD BULK BULK

QTY.

DIA.

INCHES

DIA.

DECIMAL

DRILLING

DEPTH

OVERALL

LENGTH

DW1919 1 DW1919B 12 19/64" .2969" 3.06" 4.38"

DW1920 1 DW1920B 6 5/16" .3125" 3.19" 4.50"

DW1921 1 DW1921B 6 21/64" .3281" 3.31" 4.62"

DW1922 1 DW1922B 6 11/32" .3438" 3.44" 4.75"

DW1923 1 DW1923B 6 23/64" .3594" 3.50" 4.88"

DW1924 1 DW1924B 6 3/8" .3750" 3.62" 5.00"

DW1925** 1 DW1925B** 6 25/64" .3906" 3.75" 5.12"

DW1926** 1 DW1926B** 6 13/32" .4062" 3.88" 5.25"

DW1927** 1 DW1927B** 6 27/64" .4219" 3.94" 5.50"

DW1928** 1 DW1928B** 6 7/16" .4375" 4.06" 5.59"

DW1929** 1 DW1929B** 6 29/64" .4531" 4.19" 5.75"

DW1930** 1 DW1930B** 6 15/32" .4688" 4.31" 5.87"

DW1931** 1 DW1931B** 6 31/64" .4844" 4.38" 5.98"

DW1932** 1 DW1932B** 6 1/2" .5000" 4.5" 6.00"

**3/8" Reduced shank

GOLD FERROUS

PILOT POINT® SETS

CAT # DESCRIPTION INCLUDES

DW1169 14 Pc. PILOT POINT® Drill Bit Set (2) 1/16", 5/64", 3/32", 7/64", (2) 1/8", 9/64", 5/32", 3/16", 7/32", 1/4", 5/16", 3/8",

TOUGH CASE® Container

DW1956 16 Pc. PILOT POINT® Drill Bit Set (2) 1/16", 5/64", 3/32", 7/64", 1/8", 9/64", 5/32", 11/64", 3/16",13/64", 7/32", 1/4",

5/16", 3/8", 1/2", TOUGH CASE® Container

DW1969 29 Pc. PILOT POINT® Drill Bit Set

1/16", 5/64", 3/32", 7/64", 1/8", 9/64", 5/32", 11/64", 3/16", 13/64", 7/32", 15/64",

1/4", 17/64", 9/32", 19/64", 5/16", 21/64", 11/32", 23/64", 3/8", 25/64", 13/32",

27/64", 7/16", 29/64", 15/32", 31/64", 1/2", Metal Index Container DW1956 DW1969

(continued on next page)

ACCESSORIES 89

ACCESSORIES

METAL & WOOD DRILLING (continued)

BLACK OXIDE SETS

CAT # DESCRIPTION INCLUDES

DW1163 13 Pc. Black Oxide Drill Bit Set (2) 1/16", 5/64", (2) 3/32", 7/64", (2) 1/8", 9/64", 5/32", 3/16", 7/32", 1/4", TOUGH CASE® Container

DW1167 17 Pc. Black Oxide Drill Bit Set (2) 1/16", 5/64", 3/32", 7/64", 1/8", 9/64", 5/32", 11/64", 3/16",13/64", 7/32", 15/64", 1/4",

5/16", 3/8", 1/2", TOUGH CASE® Container

DW1176 16 Pc. Black Oxide Drill Bit Set (2) 1/16", 5/64", 3/32", 7/64", 1/8", 9/64", (2) 5/32", 11/64", (2) 3/16", 7/32", 1/4", 5/16", 3/8",

TOUGH CASE® Container

DW1177 20 Pc. Black Oxide Drill Bit Set (3) 1/16", 5/64", (2) 3/32", 7/64", (2) 1/8", 9/64", 5/32", 11/64", 3/16", 13/64", 7/32", 15/64",

1/4", 5/16", 3/8", 1/2", TOUGH CASE® Container

DW1162 14 Pc. Black Oxide Drill Bit Set

(2) 1/16", 5/64", 3/32", 7/64", (2) 1/8", 9/64", 5/32", 3/16", 7/32", 1/4", 5/16", 3/8", TOUGH CASE

Container

DW1177

STEP BITS

See Page 86 for

IMPACT READY®

Step Drill Bit Lisitngs

See Page 86 for IMPACT READY®

Drilling Lisitngs

WOOD DRILLING

HEAVY-DUTY SELF

FEED BITS***

CAT # DESCRIPTION

DW1630 1"

DW1631 1-1/8"

DW1632 1-1/4"

DW1633 1-3/8"

DW1634 1-1/2"

DW1635 1-3/4"

DW1636 2"

DW1637 2-1/8"

DW1638 2-1/4"

CAT # DESCRIPTION

DW1639 2-9/16"

DW1640 3"

DW1641 3-5/8"

DW1642 4-5/8"

DW1646 5-1/2" Extension

DW1647 12" Extension

DW1650 Replacement Parts (DW1630-DW1639)

DW1651 Replacement Parts (DW1640-DW1642)

***7/16" Quick change shank

HEAVY-DUTY

SELF FEED BIT SETS

CAT # DESCRIPTION INCLUDES

DW1648 5 Pc. Self

Feed Bit Set

1-3/8", 1-1/2",

2-1/8", 2-9/16",

5-1/2" Extension

DW1649 8 Pc. Self

Feed Bit Set

1", 1-1/8", 1-1/4",

1-1/2", 1-3/4",

2-1/8", 2-9/16",

5-1/2" Extension DW1649

STEP DRILL

BITS

CAT # DESCRIPTION # OF

HOLES

STEP

INCREMENTS

SHANK

DIAMETER

MAX. MAT.

THICKNESS

Rotary

DW1787 3/4" – 1-3/8" Step Drill Bit 11 1/16" 3/8" 1/8"

Hex Shank - IMPACT READY®

DWA1783IR 1/8" – 1/2" Step Drill Bit - IMPACT READY®13 1/32" 1/4" 1/8"

DWA1784IR 3/16" – 1/2" Step Drill Bit - IMPACT READY®6 1/16" 1/4" 5/16"

DWA1786IR 3/16" – 7/8" Step Drill Bit - IMPACT READY®12 1/16" 1/4" 1/8"

DWA1789IR 7/8" – 1-1/8" Step Drill Bit - IMPACT READY®2 - 1/4" 1/8"

DWA1790IR 3 Pc. Step Drill Bit Set - IMPACT READY®19 Total

1/32"

1/16"

1/4"

1/8"

5/16"

1/8"

(continued on next page)

90 ACCESSORIES

ACCESSORIES

WOOD DRILLING (continued)

HEAVY-DUTY

SPADE BIT SET

CAT # DESCRIPTION INCLUDES

DW1587 6 Pc. Wood

Boring Bit Set

3/8", 1/2", 5/8",

3/4", 7/8", 1"

DW1587

BELL HANGER

BITS

CAT # DIA. LENGTH

DW1768 1/4" 12"

DW1769 5/16" 12"

DW1770 3/8" 12"

DW1771 7/16" 12"

DW1772 1/2" 12"

DW1773 1/4" 18"

DW1774 5/16" 18"

DW1775 3/8" 18"

CAT # DIA. LENGTH

DW1776 7/16" 18"

DW1777 1/2" 18"

DW1778 1/4" 24"

DW1779 5/16" 24"

DW1780 3/8" 24"

DW1781 7/16" 24"

DW1782 1/2" 24"

POWER SHIP

AUGER BITS***

CAT # DIA. FLUTE

LENGTH

OVERALL

LENGTH

Short

DW1665 5/8" 4" 6"

DW1666 11/16" 4" 6"

DW1667 3/4" 4" 6"

DW1668 13/16" 4" 6"

DW1669 7/8" 4" 6"

DW1670 15/16" 4" 6"

DW1671 1" 4" 6"

DW1672 1-1/16" 4" 6"

DW1673 1-1/8" 4" 6"

DW1674 1-1/4" 4" 6"

DW1675 1-3/8" 4" 6"

DW1676 1-1/2" 4" 6"

CAT # DIA. FLUTE

LENGTH

OVERALL

LENGTH

Long

DW1680 9/16" 12" 17"

DW1681 5/8" 12" 17"

DW1682 11/16" 12" 17"

DW1683 3/4" 12" 17"

DW1684 13/16" 12" 17"

DW1685 7/8" 12" 17"

DW1686 15/16" 12" 17"

DW1687 1" 12" 17"

DW1688 1-1/16" 12" 17"

DW1689 1-1/8" 12" 17"

DW1690 1-1/4" 12" 17"

DW1691 1-3/8" 12" 17"

DW1692 1-1/2" 12" 17"

***7/16" Quick change shank

HEAVY-DUTY

SPADE BITS

CAT # DESCRIPTION

DW1570 1/4" x 6"

DW1571 5/16" x 6"

DW1572 3/8" x 6"

DW1573 7/16" x 6"

DW1574 1/2" x 6"

DW1575** 9/16" x 6"

DW1576** 5/8" x 6"

DW1577 11/16" x 6"

DW1578** 3/4" x 6"

CAT # DESCRIPTION

DW1579 13/16" x 6"

DW1580** 7/8" x 6"

DW1581 15/16" x 6"

DW1582** 1" x 6"

DW1583** 1-1/8" x 6"

DW1584** 1-1/4" x 6"

DW1585 1-3/8" x 6"

DW1586 1-1/2" x 6"

CAT # DESCRIPTION

DW1590 3/8" x 16"

DW1591 1/2" x 16"

DW1592 5/8" x 16"

DW1593 3/4" x 16"

DW1594 7/8" x 16"

DW1595 1" x 16"

DW1588 6" Extension

DW1589 12" Extension

**Available in bulk 25 packs

BRAD POINT

CAT # DIA. INCHES DIA.

DECIMAL

FLUTE

LENGTH

OVERALL

LENGTH

QTY./

CARD

DW1702 1/8" .1250" 1.75" 2.75" 1

DW1704 3/16" .1875" 2.25" 3.38" 1

DW1706 1/4" .2500" 2.50" 4.00" 1

DW1708 5/16" .3125" 3.13" 4.75" 1

DW1710 3/8" .3750" 3.50" 5.25" 1

DW1714 1/2" .500" 4.00" 6.00" 1

BRAD POINT SETS

CAT # DESCRIPTION INCLUDES

DW1720 6 Pc. Brad Point

Bit Set

1/8", 3/16", 1/4", 5/16",

3/8", 1/2" DW1720

ACCESSORIES 91

ACCESSORIES

CAT # DESCRIPTION QTY.

DW2046 2" Magnetic 1

DW2050 Quick Change Magnetic 1

Hog Ring***

DW2045 3" Magnetic with Hog Ring 1

DW2045B** 3" Magnetic with Hog Ring 50

FASTENING ACCESSORIES

1” BIT TIPS

CAT # DESCRIPTION QTY.

1" Phillips Bit Tips

DW2001 #1 Phillips 2

DW2001BL** #1 Phillips 100

DW2002 #2 Phillips 2

DW2002B10 #2 Phillips 10

DW2002BL** #2 Phillips 100

DW2003 #3 Phillips 2

DW2003BL** #3 Phillips 100

DW2002X10 #2 Phillips - Bit Box 10

DW2002B30 #2 Phillips - Bit Box 30

1" Drywall Bit Tips

DW2125 #2 Drywall 25

DW2004BL** #2 Drywall 100

1" Deck Bit Tip

DW2025 Deck Bit Tip 3

CAT # DESCRIPTION QTY.

1" Slotted Bit Tips

DW2006 #6 Slotted 2

DW2008 #8 Slotted 2

DW2008BL** #8 Slotted 100

DW2010 #10 Slotted 2

DW2010BL** #10 Slotted 100

DW2012 #12 Slotted 2

1" Square Recess Bit Tips

DW2201 #1 Square Recess 2

DW2202 #2 Square Recess 2

DW2202B10 #2 Square Recess 10

DW2200 #2 Square Recess 25

DW2203 #3 Square Recess 2

DW2203BL** #3 Square Recess 100

CAT # DESCRIPTION QTY.

1" Torx®* Bit Tips

DW2615B** T15 Torx®* 50

DW2620B** T20 Torx®* 50

DW2625B** T25 Torx®* 50

DW2627B** T27 Torx®* 50

DW2630B** T30 Torx®* 50

**Bulk

CAT # DESCRIPTION LENGTH QTY.

Phillips Power Bits

DW2021 #1 Phillips 2" 1

DW2022 #2 Phillips 2" 1

DW2115 #2 Phillips - Multi-Pack 2" 5

DW2022B** #2 Phillips 2" 100

DW2023 #3 Phillips 2" 1

DW2023B** #3 Phillips 2" 100

DW2031 #1 Phillips 3-1/2" 1

DW2032 #2 Phillips 3-1/2" 1

DW2033 #3 Phillips 3-1/2" 1

DW2061 #1 Phillips 6" 1

DW2062 #2 Phillips 6" 1

DW2063 #3 Phillips 6" 1

DW2022B6 #1 Phillips 2" 6

Deck Power Bits

DW2021 Deck 2" 3

CAT # DESCRIPTION LENGTH QTY.

Slotted Power Bits

DW2015 #6 Slotted 2" 1

DW2016 #8 Slotted 2" 1

DW2017 #10 Slotted 2" 1

DW2036 #6 Slotted 3-1/2" 1

DW2038 #8 Slotted 3-1/2" 1

DW2040 #10 Slotted 3-1/2" 1

DW2065 #8 Slotted 6" 1

Square Recess Power Bits

DW2211 #1 Square Recess 2" 1

DW2212 #2 Square Recess 2" 1

DW2212B #2 Square Recess 2" 100

DW2213 #3 Square Recess 2" 1

DW2231 #1 Square Recess 3-1/2" 1

DW2232 #2 Square Recess 3-1/2" 1

DW2233 #3 Square Recess 3-1/2" 1

CAT # DESCRIPTION LENGTH QTY.

Square Recess Power Bit (continued)

DW2261 #1 Square Recess 6" 1

DW2262 #2 Square Recess 6" 1

DW2263 #3 Square Recess 6" 1

Torx®* Power Bit

DW2645B** T10 Torx®* 2" 50

DW2648B** T15 Torx®* 2" 50

DW2660B** T20 Torx®* 2" 50

DW2665B** T25 Torx®* 2" 50

DW2670B** T30 Torx®* 2" 50

DW2680B** T40 Torx®* 2" 50

DW2648 T15 Torx®*2"1

DW2660 T20 Torx®*2"1

DW2665 T25 Torx®*2"1

DW2670 T30 Torx®*2"1

POWER BITS

See Page 84 for

IMPACT READY®

Bit Tip Listings

& Power Bit Listings

BIT TIP

HOLDERS

**Bulk

DOUBLE

ENDED BITS

CAT # DESCRIPTION QTY.

DW2024 PH#2/SL#8 1

DW2024B** PH#2/SL#8 100

DW2028 PH#2/PH#2 1

DW2028B** PH#2/PH#2 100

CAT # DESCRIPTION QTY.

DW2029 PH#2/PH#2 5

DW2215 PH#2/SQ#2 3

DW2024B6 PH#2/SL#6 6

DW2028B6 PH#2/PH#2 6

**Bulk

See Page 85 for IMPACT READY®

Bit Tip Holder Listings

***Hog ring helps secure bit, must use pliers to remove bit

*Torx® is a registered trademark of Textron

**Bulk

*Torx® is a registered trademark of Textron

(continued on next page)

92 ACCESSORIES

ACCESSORIES

MAGNETIC NUT

DRIVERS

FASTENING ACCESSORIES (continued)

CAT # DESCRIPTION QTY.

DW2222 5/16" x 2-9/16" 1

DW2222B** 5/16" x 2-9/16" 50

DW2223 3/8" x 1-7/8" 1

DW2223B** 3/8" x 1-7/8" 50

DW2224 3 Pc. Nutdriver Set (1/4", 5/16", 3/8") 1

DW2225 Acoustical Eye Lag Driver 1

DW2225B** Acoustical Eye Lag Driver 50

DW2218B2 1/4" x 1-7/8" 2

CAT # DESCRIPTION QTY.

DW2219B2 5/16" x 1-7/8" 2

DW2219B3 5/16" x 1-7/8" 3

DW2218B3 1/4" x 2-9/16" 3

DW2227 7/8" x 1-7/8" 3

DW2227B** 7/8" x 1-7/8" 50

DW2224 3 Pc. Nut Driver Set (1/4", 5/16", 3/8") 1

DW2228 7/16" x 2-9/16" 1

DW2228B** 7/16" x 2-9/16" 50

CAT # DESCRIPTION QTY.

DW2218 1/4" x 1-7/8" 1

DW2218B** 1/4" x 1-7/8" 50

DW2219 5/16" x 1-7/8" 1

DW2219B** 5/16" x 1-7/8" 50

DW2220 3/8" x 1-7/8" 1

DW2220B** 3/8" x 1-7/8" 50

DW2221 1/4" x 2-9/16" 1

DW2221B** 1/4" x 2-9/16" 50

MAGNETIC DRIVE

GUIDES

CAT # DESCRIPTION QTY.

DW2054 Compact Magnetic Drive Guide 1

DW2055 6" Magnetic Drive Guide 1

DW2055B** 6" Magnetic Drive Guide 25

MAGNETIC DRIVE

GUIDE SETS

CAT # DESCRIPTION

DW2095 7 Pc. Magnetic Drive Guide Set

DW2052 10 Pc. Magnetic Drive Guide Set with #2 Square Recess Bit Tips

DW2053 16 Pc. Magnetic Drive Guide Set

DW2089CS 12 Pc. Magnetic Drive Guide Set - Clipstrip

DW2097CS 14 Pc. Magnetic Drive Guide Set - Clipstrip

DW2053CS 16 Pc. Magnetic Drive Guide Set - Clipstrip DW2095

**Bulk

DW2176

SCREW SETTERS

CAT # DESCRIPTION QTY.

DW2014 Drywall Screw Setter 1

DW2014B** Drywall Screw Setter 100

DW2043 Adjustable Screw Setter - Non Magnetic 1

SPECIALTY

BIT PACKS

DW2067

SCREWDRIVING

SETS DWMTC

CAT # DESCRIPTION INCLUDES

DW2067 7 Pc. Torx®* Bit Set T10, T15, T20, T25, T27, T30, T40

DW2067SCR 7 Pc. Security Torx®* Set T10, T15, T20, T25, T27, T30, T40

DW2068 9 Pc. 1" Hex Bit Set 5/64", 3/32", 7/64", 1/16", 1/8",

9/64", 5/32", 3/16", 1/4"

DW2069 3 Pc. POZIDRIV®* 1" Bit Set #1, #2, #3

**Bulk

See Page 84 - 85 for IMPACT READY®

Nut Driver and Socket Lisitngs

See Page 86 for IMPACT READY®

Sets Lisitngs

CAT # DESCRIPTION

TOUGH CASE® Sets

DW2160 13 Pc. Screwdriving Set with TOUGH CASE® Container

DW2161 21 Pc. Screwdriving Set with TOUGH CASE® Container

DW2162 29 Pc. Screwdriving Set with TOUGH CASE® Container

DW2163 37 Pc. Screwdriving Set with TOUGH CASE® Container

DW2166 45 Pc. Screwdriving Set with TOUGH CASE® Container

DW2167 25 Pc. Screwdriving Set with TOUGH CASE® Container

DW2174 18 Pc. Screwdriving Set with TOUGH CASE® Container

DW2176 37 Pc. Screwdriving Set with TOUGH CASE® Container

DW2587 80 Pc. Screwdriving Set with TOUGH CASE® Container

Magnetic TOUGH CASE® Sets

DWMTC15 15 Pc. Screwdriving Set with Magnetic TOUGH CASE® Container

Compact TOUGH CASE® Sets

DWAX100 31 Pc. Screwdriving Set with Compact TOUGH CASE® Container

DWAX200 31 Pc. Security Set with Compact TOUGH CASE® Container

Cases

DW2190 Medium TOUGH CASE® Container - Case Only

DWMTC Magnetic TOUGH CASE® Container - Case Only

*Torx® is a registered trademark of Textron and

POZIDRIV® is a registered trademark of the Philips Screw Company

ACCESSORIES 93

ACCESSORIES

QUICK CHANGE ACCESSORIES

DRILL DRIVE SETS

CAT # DESCRIPTION INCLUDES

DW2730 8 Pc. Drill Drive Set Drill Drive Holder, Drill Drive Connector, #6 & #8 Drill Bits with Countersinks, #8

Replacement Drill Bit, 3 Screwdriver Bit Tips, Heavy-Duty Container

DW2735P 12 Pc. Drill Drive Set Drill Drive Holder, Drill Drive Connector, #6, #8 & #10 Drill Bits with Countersinks, #6

(2), #8 & #10 Replacement Drill Bits, 3 Screwdriver Bit Tips, Heavy-Duty Container

Drill Drive

Replacement

Countersinks & Drill

Bits are Listed Below

RAPID LOAD® QUICK

CHANGE ACCESSORIES

CAT # DESCRIPTION

Countersinks

DW2537 #6 Countersink Replacement Drill Bit 9/64"

DW2538 #8 Countersink Replacement Drill Bit 11/64"

DW2539 #10 Countersink Replacement Drill Bit 3/16"

DW2540 #12 Countersink Replacement Drill Bit 7/32"

DW2567 #6 Countersink with 9/64" Drill Bit

DW2568 #8 Countersink with 11/64" Drill Bit

DW2569 #10 Countersink with 3/16" Drill Bit

DW2570 #12 Countersink with 7/32" Drill Bit

DW2535 3 Pc. Countersink Set #6, #8, #10

CAT # DESCRIPTION

Rotary Masonry Drill Bits

DW2572 5/32" Rotary Masonry Bit

DW2573 3/16" Rotary Masonry Bit

DW2574 1/4" Rotary Masonry Bit

DW2571 3 Pc. Countersink Set 5/32", 3/16", 1/4"

Socket Adapters

DW2541 1/4" Socket Adapter

DW2542 3/8" Socket Adapter

Power Bits - Page 92

Bit Tip Holders - Page 92

Magnetic Nut Drivers - Page 93

Magnetic Drive Guides - Page 93

These ACCESSORIES also ﬁt

the RAPID LOAD® Holder but

are found in separate listings

in this catalog.

RAPID LOAD®

HOLDER

CAT # DESCRIPTION

DW2505 RAPID LOAD® Hex Holder

DWA2500

RAPID LOAD

Holder with SureSet

System

t1SFTTVSFBDUJWBUFECBMMHSPPWFTZTUFNGPSSBQJEMPBEJOHBOE

strong retention

t*NQBDUSVTUSFTJTUBOUOJDLFMQMBUFEOPTFGPSFYUFOEFEVTF

t4UBJOMFTTTUFFMJOUFSJPSQBSUTGPSHSFBUFSEVSBCJMJUZBOENBHOFUJD

to hold fasteners

t5IF3"1*%-0"%® holder ﬁts all brands of 3/8" and 1/2"

cordless and corded drills, as well as 7 in 1 Screwdrivers

t"CMFUPIPMECJUUJQTEPVCMFFOEFECJUUJQTBOEBMM

1/4" hex shank accessories

DW2502

DW2507

RAPID LOAD®

SETS

CAT # DESCRIPTION

DW2502 17 Pc. RAPID LOAD® Set

DW2503 20 Pc. RAPID LOAD® Set

DW2504 27 Pc. RAPID LOAD® Set with Magnetic Compact

DW2507 6 Pc. RAPID LOAD® Set with Magnetic Compact

DW2513 15 Pc. RAPID LOAD® Set

DW2518 30 Pc. RAPID LOAD® Set

DW2521 28 Pc. RAPID LOAD® Set

DW2522 32 Pc. RAPID LOAD® Set

DW2530 35 Pc. RAPID LOAD® Set with Magnetic Compact

94 ACCESSORIES

ACCESSORIES

RECIPROCATING SAW BLADES

PREMIUM METAL

CUTTING

CAT # BLADE

LENGTH TPI BLADE

TYPE

5 Packs

DWA4186 6" 14/18 Straight

DWA4188 8" 14/18 Straight

DWA41812 12" 14/18 Straight

25 Packs

DWA4186B25 6" 14/18 Straight

DWA4188B25 8" 14/18 Straight

DWA41812B25 12" 14/18 Straight

100 Packs

DWA4186B 6" 14/18 Straight

DWA4188B 8" 14/18 Straight

DWA41812B 12" 14/18 Straight

METAL CUTTING

CAT # BLADE

LENGTH TPI BLADE

TYPE

2 Packs

DW4808-2 6" 14 Straight

DW4810-2 4" 18 Straight

DW4811-2 6" 18 Straight

DW4813-2 6" 24 Straight

5 Packs

DW4807 4" 14 Straight

DW4808 6" 14 Straight

DW4809 8" 14 Straight

DW4838 12" 14 Straight

DW4810 4" 18 Straight

DW4811 6" 18 Straight

DW4821 8" 18 Straight

DW4812 4" 24 Straight

DW4813 6" 24 Straight

DW4846L 9" 10/14 Straight

CAT # BLADE

LENGTH TPI BLADE

TYPE

25 Packs

DW4807B25 4" 14 Straight

DW4808B25 6" 14 Straight

DW4809B25 8" 14 Straight

DW4810B25 4" 18 Straight

DW4811B25 6" 18 Straight

DW4821B25 8" 18 Straight

DW4822B25 12" 18 Straight

DW4812B25 4" 24 Straight

DW4813B25 6" 24 Straight

100 Packs

DW4807B 4" 14 Straight

DW4808B 6" 14 Straight

DW4809B 8" 14 Straight

DW4811B 6" 18 Straight

DW4821B 8" 18 Straight

DW4813B 6" 24 Straight

**2X life vs. LENOX® 118R LAZER® series in 1018 steel

SCAN FOR

MORE INFO

QLonger Life**

Proprietary coating, steel

construction, tooth geometry

and blade thickness help to

reduce heat build-up

QOutstanding Durability

Thick and wide blade

QEfficient Cutting Performance

Variable pitch 14/18 TPI

ACCESSORIES 95

ACCESSORIES

RECIPROCATING SAW BLADES (continued)

DEMOLITION

CAT # BLADE

LENGTH TPI BLADE TYPE

5 Packs

DW4862 6" 6 Taper

DW4863 9" 6 Taper

DW4860 12" 6 Taper

DW4861 4" 10 Straight

DW4864 6" 10 Straight

DW4865 9" 10 Straight

DW4870 12" 10 Straight

DW4866 6" 14 Straight

DW4868 9" 14 Straight

DW4867 6" 18 Straight

DW4869 9" 18 Straight

DW4871 12" 18 Straight

25 Packs

DW4863B25 9" 6 Taper

DW4864B25 6" 10 Straight

DW4865B25 9" 10 Straight

DW4868B25 9" 14 Straight

100 Packs

DW4863B 9" 6 Taper

DW4864B 6" 10 Straight

DW4865B 9" 10 Straight

DW4866B 6" 14 Straight

DW4868B 9" 14 Straight

MULTI-MATERIAL

CAT # BLADE

LENGTH TPI BLADE TYPE

2 Packs

DW4806-2 6" 10 Straight

DW4845-2 6" 10/14 Straight

5 Packs

DW4845 6" 10/14 Straight

DW4846 8" 10/14 Straight

25 Packs

DW4806B25 6" 10 Straight

DW4845B25 6" 10/14 Straight

DW4846B25 8" 10/14 Straight

DW4839B25 12" 10/14 Straight

100 Packs

DW4806B 6" 10 Straight

DW4845B 6" 10/14 Straight

DW4846B 8" 10/14 Straight

DW4839B 12" 10/14 Straight

SPECIALTY

CAT # BLADE

LENGTH TPI BLADE TYPE

Scroll Cutting Blades

DW4814 3-1/2" 14 General Purpose

DW4815 3-1/2" 18 Metal

DW4816 6" 6 Wood

Drywall Cutting Blades

DW4851 6" 6 Taper

Carbide Grit Edge Blades

DW4844 6" Coarse Straight

DW4843 8" Coarse Straight

Cordless Bi-Metal Blades

DW4876 6" 5/8 Taper

DW4878 6" 18 Straight

SETS

CAT # DESCRIPTION INCLUDES

DW4853 3 Pc. Bi-Metal Saw Blade Set DW4802, DW4806, DW4811

DW4875 3 Pc. Cordless Bi-Metal Saw Blade Set DW4876, DW487, DW4878

DW4857 5 Pc. Bi-Metal Saw Blade Set (2) DW4802, DW4808, DW4811, DW4813

DW4856 6 Pc. Bi-Metal Saw Blade Set DW4802, DW4847, DW4806, DW4808,

DW4811, DW4813

DW4896 6 Pc. Bi-Metal Saw Blade Set with Telescoping Case (2) DW4809, (2) DW4803, (2) DW4865

DW4892 12 Pc. Bi-Metal Saw Blade Set with Telescoping Case (3) DW4802, (2) DW4811,

(2) DW4809, (2) DW4803, DW4865

DW4890 15 Pc. Bi-Metal Saw Blade Set with Medium TOUGH CASE®(5) DW4802, (5) DW4808, (5) DW4811

DW4897 15 Pc. Bi-Metal Saw Blade Set with Telescoping Case (4) DW4802, (4) DW4811, (3) DW4809,

(3) DW4803, DW4865

DW4898 10 Pc. Bi-Metal Reciprocating Saw Blade Set with Case (4) DW4802, (4) DW4811, (1) DW4809,

(1) DW4803

DW4899 16 Pc. Bi-Metal Reciprocating Saw Blade Set with Case (6) DW4802, (5) DW4811, (2) DW4809,

(2) DW4803, DW4865

DW4856 DW4892

WOOD CUTTING

CAT # BLADE

LENGTH TPI BLADE

TYPE

2 Packs

DW4802-2 6" 6 Taper

DW4804-2 12" 6 Taper

DW4847-2 6" 5/8 Taper

5 Packs

DW4801 6" 3 Taper

DW4802 6" 6 Taper

DW4803 9" 6 Taper

DW4804 12" 6 Taper

DW4847 6" 5/8 Taper

DW4848 9" 5/8 Taper

DW4849 12" 5/8 Taper

DW4850 6" 6 Straight

25 Packs

DW4802B25 6" 6 Taper

DW4803B25 9" 6 Taper

DW4804B25 12" 6 Taper

DW4847B25 6" 5/8 Taper

100 Packs

DW4802B 6" 6 Taper

DW4803B 9" 6 Taper

DW4804B 12" 6 Taper

96 ACCESSORIES

ACCESSORIES

HOLE SAWS

SETS

CAT # DESCRIPTION INCLUDES

D180001 9 Pc. Plumber’s

Hole Saw Set

3/4", 7/8", 1-1/8", 1-1/2", 1-3/4", 2-1/4", Small Quick Change Mandrel,

Large Quick Change Mandrel, Replacement Parts

D180002 9 Pc. Electrician’s

Hole Saw Set

7/8", 1-1/8", 1-3/8",1-3/4", 2", 2-1/2", Small Quick Change Mandrel, Large

Quick Change Mandrel, Replacement Parts

D180005 13 Pc. Master

Hole Saw Set

3/4", 7/8", 1", 1-1/8", 1-3/8",1-1/2", 1-3/4", 2", 2-1/8", 2-1/2",

Small Quick Change Mandrel, Large Quick Change Mandrel, Replacement Parts

D180004 Door Lock Installation Kit 1", 2-1/8" Holesaws, Mandrel, Adapter, Drill Guide D180004

D180001

BI-METAL

CAT # SIZE

Inches

SIZE

Metric

MAX

SPEED

D180009 9/16" 14mm 550

D180010 5/8" 16mm 530

D180011 11/16" 17mm 500

D180012 3/4" 19mm 460

D180098 - 20mm 425

D180013 13/16" 21mm 425

D180014 7/8" 22mm 390

D180015 15/16" 24mm 370

D180016 1" 25mm 350

D180017 1-1/16" 27mm 325

D180018 1-1/8" 29mm 300

D180019 1-3/16" 30mm 285

D180020 1-1/4" 32mm 275

CAT # SIZE

Inches

SIZE

Metric

MAX

SPEED

D180034 2-1/8" 54mm 160

D180036 2-1/4" 57mm 150

D180038 2-3/8" 60mm 140

D180040 2/1/2" 64mm 135

D180041 2-9/16" 65mm 130

D180042 2-5/8" 67mm 130

D180043 - 68mm 125

D180044 2-3/4" 70mm 125

D180046 2-7/8" 73mm 120

D180048 3" 76mm 115

D180050 3-1/8" 79mm 110

D180052 3-1/4" 83mm 105

D180054 3-3/8" 86mm 100

CAT # SIZE

Inches

SIZE

Metric

MAX

SPEED

D180021 1-5/16" 33mm 260

D180022 1-3/8" 35mm 250

D180023 1-7/16" 37mm 240

D180024 1-1/2" 38mm 230

D180025 1-9/16" 40mm 220

D180026 1-5/8" 41mm 210

D180027 1-11/16" 43mm 205

D180028 1-3/4" 44mm 195

D180029 1-13/16" 46mm 190

D180030 1-7/8" 48mm 180

D180032 2" 51mm 170

D180033 2-1/16" 52mm 165

CAT # SIZE

Inches

SIZE

Metric

MAX

SPEED

D180056 3-1/2" 89mm 95

D180058 3-5/8" 92mm 95

D180060 3-3/4" 94mm 90

D180062 3-7/8" 98mm 85

D180064 4" 102mm 85

D180066 4-1/8" 105mm 85

D180068 4-1/4" 108mm 80

D180072 4-1/2" 114mm 75

D180076 4-3/4" 121mm 70

D180080 5" 127mm 65

D180088 5-1/2" 140mm 60

D180096 6" 152mm 55

MANDRELS

CAT # TYPE SHANK

SIZE

CHUCK

SIZE

HOLE SAW

SIZE

DW1800 Standard 1/4" 1/4" 9/16" to 1-3/16"

DW1801 Standard 3/8" 3/8" 9/16" to 1-3/16"

DW1810 Quick Change 3/8" 3/8" 9/16" to 1-3/16"

DW1818 Standard 3/8" 3/8" 1-1/4" to 3"

DW1805 Quick Change 3/8" 3/8" 1-1/4" to 3"

CAT # TYPE SHANK

SIZE

CHUCK

SIZE

HOLE SAW

SIZE

DW1802 Standard 7/16" 1/2" 1-1/4" to 6"

DW1803 Quick Change 7/16" 1/2" 1-1/4" to 6"

DW1807 Short Replacement Pilot Bit - 3"

DW1808 Long Replacement Pilot Bit - 4"

BANDSAW BLADES

BI-METAL PORTABLE

BANDSAW BLADES

CAT # TPI THICK-

NESS LENGTH HEIGHT PACK

DW3981 10 .020" 44-7/8" 1/2" 3

DW3981B 10 .020" 44-7/8" 1/2" 100

DW3982 14 .020" 44-7/8" 1/2" 3

DW3982B 14 .020" 44-7/8" 1/2" 100

DW3983 18 .020" 44-7/8" 1/2" 3

DW3983B 18 .020" 44-7/8" 1/2" 100

CAT # TPI THICK-

NESS LENGTH HEIGHT PACK

DW3984 24 .020" 44-7/8" 1/2" 3

DW3984B 24 .020" 44-7/8" 1/2" 100

DW3985 10/14 .020" 44-7/8" 1/2" 3

DW3985B 10/14 .020" 44-7/8" 1/2" 100

DW3986 14/18 .020" 44-7/8" 1/2" 3

DW3986B 14/18 .020" 44-7/8" 1/2" 100

CAT # TPI THICK-

NESS LENGTH HEIGHT PACK

DW3987 10 .025" 44-7/8" 1/2" 3

DW3988 14 .025" 44-7/8" 1/2" 3

DW3989 18 .025" 44-7/8" 1/2" 3

DW3991 10/14 .025" 44-7/8" 1/2" 3

DW3992 14/18 .025" 44-7/8" 1/2" 3

Wider Shoulder Adds Tooth Strength Double Tooth

Design

Increases life

for greater

number of holes

Competition

DW1803DW1810

See Page 86 for

IMPACT READY®

Hole Saw Lisitngs

ACCESSORIES 97

ACCESSORIES

CAT # DESCRIPTION CUTTING

LENGTH TPI QTY.

High Performance WOOD Cutting (HCS)

DW3700H2 Fast Cutting 4" 6 2

DW3700H Fast Cutting 4" 6 5

DW3700H50 Fast Cutting 4" 6 50

DW3701H2 Fast Cutting 4" 6 2

DW3703H2 Clean Cutting 4" 6 2

DW3703H Clean Cutting 4" 6 5

DW3703H50 Clean Cutting 4" 6 50

DW3705H Aluminum/Fiberglass 4" 8 5

DW3710H2 Fine Cut Smooth Finish 4" 10 2

DW3710H Fine Cut Smooth Finish 4" 10 5

DW3710H50 Fine Cut Smooth Finish 4" 10 50

DW3712H2 Laminate Down Cutting 4" 10 2

DW3712H Laminate Down Cutting 4" 10 5

DW3715H2 Wood Scrolling 3" 12 2

DW3715H Wood Scrolling 3" 12 5

WOOD Cutting

DW3700-5 Fast Cutting 4" 6 5

DW3701-5 Wide Body 4" 6 5

DW3703-5 Clean Cutting 4" 6 5

DW3705-5 Aluminum/Fiberglass 4" 8 5

DW3710-5 Fine Cut Smooth Finish 4" 10 5

DW3712-5 Laminate Down Cutting 4" 10 5

DW3715-5 Scrolling 3" 12 5

CAT # DESCRIPTION CUTTING

LENGTH TPI QTY.

METAL Cutting

DW3720H2 Thick Metal Cutting 3" 14 2

DW3720-5 Metal Cutting 3" 14 5

DW3720B50 Metal Cutting 3" 14 50

DW3724H2 Medium Metal Cutting 3" 18 2

DW3724-5 Medium Metal Cutting 3" 18 5

DW3724B50 Medium Metal Cutting 3" 18 50

DW3726H2 Thin Metal Cutting 3" 24 2

DW3726-5 Thin Metal Cutting 3" 24 5

DW3726B50 Thin Metal Cutting 3" 24 50

DW3728H2 Sheet Metal Cutting 3" 32 2

DW3728-5 Sheet Metal Cutting 3" 32 5

DW3728B50 Sheet Metal Cutting 3" 32 50

MASONRY Cutting

DW3718-5 Carbide Grit Cobalt Steel 3" - 5

U-SHANK SETS

CAT # DESCRIPTION

DW3790 8 Pc. U-Shank Jig Saw

Blade Set

DW3792H 8 Pc. U-Shank Jig Saw

Blade Set

DW3798 15 Pc. U-Shank Jig

Saw Blade Set

DW3799 25 Pc. U-Shank Jig

Saw Blade Set

DW3744C

10 Pc. U-Shank Jig

Saw Blade Set with

Case

JIG SAW BLADES

T-SHANK

CAT # DESCRIPTION CUTTING

LENGTH TPI QTY.

High Performance WOOD Cutting (HCS) Adapters

DW3750H2 Fast Cutting 4" 6 2

DW3750H Fast Cutting 4" 6 5

DW3750H50 Fast Cutting 4" 6 50

DW3753H2 Clean Cutting 4" 6 2

DW3753H Clean Cutting 4" 6 5

DW3753H50 Clean Cutting 4" 6 50

DW3755H2 Aluminum/Fiberglass 4" 8 2

DW3755H Aluminum/Fiberglass 4" 8 5

DW3755H50 Aluminum/Fiberglass 4" 8 50

DW3760H2 Fine Cut Smooth Finish 4" 10 2

DW3760H Fine Cut Smooth Finish 4" 10 5

DW3760H50 Fine Cut Smooth Finish 4" 10 50

DW3762H2 Laminate Down Cutting 4" 10 2

DW3762H Laminate Down Cutting 4" 10 5

DW3762H50 Laminate Down Cutting 4" 10 50

DW3765H2 Trim Coping 3" 12 2

DW3765H Trim Coping 3" 12 5

CAT # DESCRIPTION CUTTING

LENGTH TPI QTY.

Cobalt Steel WOOD Cutting

DW3750-5 Fast Cutting 4" 6 5

DW3751-5 Wide Body 4" 6 5

DW3753-5 Clean Cutting 4" 6 5

DW3755-5 Aluminum/Fiberglass 4" 8 5

DW3760-5 Fine Cut Smooth Finish 4" 10 5

DW3762-5 Laminate Down Cutting 4" 10 5

DW3765-5 Scrolling 3" 12 5

METAL Cutting

DW3770-5 Metal Cutting 3" 14 5

DW3770B50 Metal Cutting 3" 14 50

DW3774-5 Metal Cutting 3" 18 5

DW3774B50 Metal Cutting 3" 18 50

DW3776-5 Metal Cutting 3" 24 5

DW3776B50 Metal Cutting 3" 24 50

DW3778-5 Metal Cutting 3" 32 5

DW3778B50 Metal Cutting 3" 32 50

MASONRY Cutting

DW3768-5 Carbide Grit Cobalt Steel 3" - 5

T-SHANK SETS

CAT # DESCRIPTION

DW3795H 5 Pc. T-Shank Jig Saw

Blade Set

DW3791 8 Pc. T-Shank Jig Saw

Blade Set

DW3741C 10 Pc. T-Shank Jig Saw

Blade Set with Case

DW3742C 14 Pc. T-Shank Jig Saw

Blade Set with Case

DW3795H DW3742C

U-SHANK

DW3799 DW3744C

98 ACCESSORIES

ACCESSORIES

HAND TOOLS

& STORAGE

HAND TOOLS & STORAGE

A WHOLE

NEW TOUGH

100 HAND TOOLS & STORAGE

HAND TOOLS & STORAGE

1-1/4" WIDE

SHORT TAPES

CAT # LENGTH WIDTH STANDOUT BLADE COATING SCALE BLADE LOCK BELT CLIP WEIGHT

DWHT33385L 25' 1-1/4" 13' Mylar® SAE Yes Yes 1.35 lbs

DWHT33386L 30' 1-1/4" 13' Mylar® SAE Yes Yes 1.50 lbs

DWHT33387L 35' 1-1/4" 13' Mylar® SAE Yes Yes 1.65 lbs

t hPGCMBEFTUBOEPVUGPSJODSFBTFEVTFSSFBDI

t &YUSBMBSHFFOEIPPLHSBCTDPOTUSVDUJPONBUFSJBMGSPNBMMTJEFT

t .® thermoplastic ﬁlm helps to protect blade from damage

MEASURING TOOLS

1-1/8" WIDE

SHORT TAPES

t hPGCMBEFTUBOEPVUGPSJODSFBTFEVTFSSFBDI

t NBSLJOHTUPTQFFEVQNFBTVSJOHKPCT

t %VPEVSPNFUFSCMBEFMPDLGPSEVSBCJMJUZBOEDPNGPSU

CLOSED CASE

LONG TAPE

t (FBSSBUJPGPSYGBTUFSCMBEFSFXJOE†

t #MBEFSFMFBTFCVUUPOGPSFBTZCMBEFQVMMPVU

t 4QSJOHMPBEFEDBSBCJOFSBUUBDINFOUGPSFBTZUSBOTQPSUBUJPO

t "VUPNBUJDCMBEFSFUSBDUJPOTBWFTUJNFCZFMJNJOBUJOHNBOVBMSFXJOE

t 3VTUSFTJTUBOUDPBUJOHQSPMPOHTCMBEFMJGF

t .FUBMDBTFGPSIFBWZEVUZVTF

OPEN REEL

LONG TAPE

t (FBSNFDIBOJTNGPSYGBTUFSCMBEFSFXJOE†

t 8JEFCMBEFGPSFBTZSFBEBCJMJUZ

t 'JCFSHMBTTTUSBOETQFSCMBEFGPSNBYJNVNEVSBCJMJUZBOESFEVDFETUSFUDI†

* Standout claim based on maximum performance

†Compared to standard competitor long tapes

Mylar is a registered trademark of Dupont Teijin

3M is a registered trademark of 3M company

AUTO REWIND

STEEL LONG TAPE

CAT # LENGTH WIDTH STANDOUT BLADE COATING SCALE BLADE LOCK BELT CLIP WEIGHT

DWHT33372L 16' 1-1/8" 10' Anti-Rust Polymer SAE Yes Yes 0.84 lbs

DWHT33373L 25' 1-1/8" 10' Anti-Rust Polymer SAE Yes Yes 1.10 lbs

DWHT33374L 30' 1-1/8" 10' Anti-Rust Polymer SAE Yes Yes 1.30 lbs

CAT # LENGTH WIDTH BLADE COATING SCALE GEAR RATIO BELT CLIP WEIGHT

DWHT34036L 100' 3/8" Lacquer SAE 5:1 Yes 1.11 lbs

CAT # LENGTH WIDTH BLADE COATING SCALE GEAR RATIO BELT CLIP WEIGHT

DWHT34201 100' 3/8" Lacquer SAE Auto Rewind Yes 1.70 lbs

CAT # LENGTH WIDTH SCALE GEAR RATIO BELT CLIP WEIGHT

DWHT34028 100' 3/4" SAE & Decimal Foot 3:1 No 2.14 lbs

HAND TOOLS & STORAGE 101

HAND TOOLS & STORAGE

MARKING & LAYOUT

FLASHLIGHTS

CHALK REELS/KITS

t 0QFOBDDFTTEPPSGPSRVJDLSFmMMTBOEBDDFTTUPJOUFSOBMDPNQPOFOUT

t hIFBWZEVUZMJOFSFTJTUTBCSBTJPOBOECSFBLBHF

t 4UBJOMFTTIPPLBOEDSBOLXJUITUBOEBCVTFBOESFTJTUDPSSPTJPO

CAT # DESCRIPTION CONTAINS WEIGHT

DWHT47142 Chalk Reel Chalk Reel 0.65 lbs

DWHT47144 Chalk Reel Kit Chalk Reel, 4 oz Red Chalk 0.83 lbs

DWHT47143 Chalk Reel Kit Chalk Reel, 4 oz Blue Chalk 0.83 lbs

t )JHIHSBEFDIBMLUPCFVTFEXJUIDIBMLMJOFSFFMT

t 0WBMTIBQFECPUUMFXJMMOPUSPMMPGGPGTVSGBDF

t 5FUIFSFEFBTZQPVSJOHQPQUPQTQPVUDBQ

CAT # SIZE COLOR PERMANENCE RANK WEIGHT

DWHT47029 8 oz White 1 0.50 lbs

DWHT47048 8 oz Red 3 0.50 lbs

DWHT47049 8 oz Blue 1 0.50 lbs

DWHT47056 8 oz Black 3 0.50 lbs

DWHT47069 8 oz Red Permanent 4 0.50 lbs

DWHT47076 8 oz Orange Hi Visibility 2 0.50 lbs

DWHT47079 8 oz Violet 0 0.50 lbs

DWHT47057 2.50 lbs Red 3 2.50 lbs

DWHT47058 2.50 lbs Blue 1 2.50 lbs

DWHT47059 5 lbs Red 3 5.00 lbs

DWHT47062 5 lbs Blue 1 5.00 lbs

t -BSHFDSPTTTFDUJPOBOEEJFDBTUBMVNJOVNDPNQPOFOUTGPSYTUSPOHFSMFWFM

t #MPDLWJBMTGPSEVSBCJMJUZBOEBDDVSBDZUP*O†

t .BHOJmFEDFOUFSWJBMNBYJNJ[FTWJBMSFBEBCJMJUZ

t 3PCVTUFOHJOFFSFEDSPTTTFDUJPO

t #MPDLWJBMTQSPWJEFEVSBCJMJUZBOEBDDVSBDZJO

t 7HSPPWFCBTFGPSBDDVSBUFBMJHONFOUPOSPVOEFETVSGBDFTBOEFEHFT

CAT # LENGTH # OF VIALS MAGNETIC WEIGHT

DWHT43224 24" 3 No 1.90 lbs

DWHT43025 24" 3 Yes 1.90 lbs

DWHT43248 48" 3 No 3.60 lbs

DWHT43049 48" 3 Yes 3.60 lbs

DWHT43172 72" 3 No 5.10 lbs

DWHT43079 78" 3 Yes 5.60 lbs

CAT # LENGTH # OF VIALS MAGNETIC WEIGHT

DWHT42151 24" 3 No 1.67 lbs

DWHT42163 24" 3 Yes 1.74 lbs

DWHT42166 48" 3 No 3.35 lbs

DWHT42167 48" 3 Yes 3.46 lbs

DWHT42169 72" 3 No 4.74 lbs

DWHT42170 72" 3 Yes 5.44 lbs

** Versus standard competitive levels

†Versus tubular vials

PERMANENCE SCALE

0 1 2 3

CHALK

LEVELS

I-BEAM

LEVELS

-08 )*()

HEAD

LAMP

t "OUJTMJQTJMJDPOFTUSBQ

t .FUFSJNQBDUSFTJTUBOU

t 8BUFSSFTJTUBOU

CAT # VOLTAGE RUN-TIME LUMENS BULB TYPE WEIGHT

DWHT70440 4.5V 29.48 hrs 104 LED 0.37 lbs

ALUMINUM

FLASHLIGHTS

t .FUFSJNQBDUSFTJTUBOU

t 4IBUUFSSFTJTUBOUMFOTGPSEVSBCJMJUZ

CAT # VOLTAGE RUN-TIME LUMENS BULB TYPE WEIGHT

DWHT70644 3V 4.0 hrs 80 LED 0.41 lbs

DWHT70645 4.5V 3.0 hrs 120 LED 0.49 lbs

DWHT70646 4.5V 73.50 hrs 136 LED 1.43 lbs

(continued on next page)

102 HAND TOOLS & STORAGE

HAND TOOLS & STORAGE

DEMO DRIVERS

VINYL GRIP

SCREWDRIVERS

CAT # # OF PIECES IN SET TIP STYLES TIP SIZE BAR LENGTH BOLSTER WEIGHT

DWHT66416 4 Standard 1/4" 4" Yes 1.01 lbs

Phillips 2 pt 4" No

Square 1 pt, 2 pt 4", 5" No

DWHT66409 8 Screwdrivers Standard 1/4", 1/4", 5/16" 1-1/2", 4", 6" Yes 2.83 lbs

1 Tool Roll Cabinet 3/16" 6" No

Phillips 1 pt, 2 pt, 2 pt, 3 pt 3", 1-1/2", 4", 6" No

DWHT66368 1 Standard Stubby 1/4" 1-1/2" No 0.14 lbs

DWHT66369 1 Phillips Stubby 2 pt 1-1/2" No 0.14 lbs

DWHT66382 1 Standard 3/16" 3" Yes 0.19 lbs

DWHT66383 1 Standard 1/4" 4" Yes 0.28 lbs

DWHT66384 1 Standard 5/16" 6" Yes 0.41 lbs

DWHT66387 1 Standard 3/8" 8" Yes 0.63 lbs

DWHT66389 1 Cabinet 3/16" 3" No 0.18 lbs

DWHT66391 1 Cabinet 3/16" 3" No 0.21 lbs

DWHT66393 1 Cabinet 3/16" 8" No 0.22 lbs

DWHT66396 1 Phillips 1 pt 3" No 0.19 lbs

DWHT66397 1 Phillips 2 pt 4" No 0.28 lbs

DWHT66399 1 Phillips 3 pt 6" No 0.40 lbs

DWHT66403 1 Square 1/4" 4" Yes (w/ Square Bar) 0.31 lbs

DWHT66406 1 Square 5/16" 6" Yes (w/ Square Bar) 0.45 lbs

DWHT66407 1 Square 3/8" 8" Yes (w/ Square Bar) 0.69 lbs

DWHT66419 1 Square 1 pt 4" No 0.20 lbs

DWHT66422 1 Square 2 pt 5" No 0.24 lbs

DWHT66423 1 Square 3 pt 5" No 0.24 lbs

t $PMPSDPEFEIBOEMFXJUIUJQ*%GPSFBTZTFMFDUJPO

t $PMEGPSNFECMBDLPYJEFUJQGPSQSFDJTFmUJOGBTUFOFSTBOEBDISPNFQMBUFECBSGPSDPSSPTJPOSFTJTUBODF

t $PNGPSUBCMFWJOZMHSJQIBOEMFT

SCREWDRIVER & SCREWDRIVER SETS

CAT # # OF PIECES IN SET TIP STYLES TIP SIZE BAR LENGTH WEIGHT

DWHT67530 2 Standard 5/16" 5-1/8" 0.92 lbs

Phillips 2 pt 5-1/8"

t 4UFFMDPSFUSBOTGFSTGPSDFEJSFDUMZGSPNTUSJLFDBQUPUJQ

t 4IBUUFSSFTJTUBOUDFMMVMPTFBDFUBUFIBOEMFUFTUFEVOEFSIFBWZMPBEBOEFYUSFNFUFNQFSBUVSF

t $PMPSDPEFEIBOEMFGPSFBTZTFMFDUJPOGSPNUPPMQPVDI

RATCHETING

SCREWDRIVER

CAT # # OF PIECES IN SET BIT STYLES INCLUDED WEIGHT

DWHT69233 12 Bits Standard - 3/16", 1/4", 5/16" 0.72 lbs

1 Driver Phillips - 1 pt, 2 pt, 3 pt

Square - 1 pt, 2 pt, 3 pt

Star - S10, S15, S25

t *OUFSOBMCJUTUPSBHFIPMETVQUPCJUT

t )FBWZEVUZSBUDIFUNFDIBOJTNGPSIJHIUPSRVFBQQMJDBUJPOT

t 3FNPWBCMFCBSDBOBMTPCFVTFEJOQPXFSESJMMT

HAND TOOLS & STORAGE 103

HAND TOOLS & STORAGE

CONTRACTOR

PACK STAPLES

HAMMER TACKER

STAPLE & BRAD

TACKER

VINYL GRIP

INSULATED

SCREWDRIVERS

SCREWDRIVER

SETS

CAT # # OF PIECES IN SET TIP STYLES TIP SIZE BAR LENGTH WEIGHT

DWHT62513 10 Standard 1/8", 1/4", 1/4", 3/16" 3", 1-3/4", 4", 4" 1.63 lbs

Cabinet 3/16" 6"

Phillips 0 pt, 2 pt, 1 pt, 2 pt, 2 pt 2-1/4", 1-3/4", 3", 4", 6"

DWHT62512 4 Standard 1/4" 4" 0.88 lbs

Cabinet 3/16" 4"

Phillips 1 pt, 2 pt 3", 4"

t .BHOFUJDUJQIPMETTDSFXTFDVSFMZ

t $PMPSDPEFEIBOEMFGPSFBTZTFMFDUJPO

t #JNBUFSJBMRVBEMPCFIBOEMFGPSUPSRVFBOEDPNGPSU

CAT # # OF PIECES IN SET TIP STYLE TIP SIZE WEIGHT

DWHT66417 8 Bars Standard 1/8", 3/16", 1/4" 1.01 lbs

1 Full Size Handle Phillips 0 pt, 1 pt, 2 pt

1 Precision Handle Square 1 pt, 2 pt

1 Tool Pouch

SCREWDRIVER & SCREWDRIVER SETS

STAPLERS & STAPLES

t &BTZTRVFF[FUFDIOPMPHZIFMQTSFEVDFBDUVBUJPOGPSDF

t 6TFT%EWALT heavy-duty staples series DWHTTA700 and 18 gauge headed brads

in sizes 1/2", 5/8" & 9/16"

CAT # HANDLE LENGTH MAXIMUM STAPLE LENGTH WEIGHT

DWHTTR350 4.25" 9/16" 2.00 lbs

t -JHIUXFJHIUEJFDBTUBMVNJOVNIPVTJOHEFTJHOGPSEVSBCJMJUZ

t 6TFT%EWALT heavy-duty staples series DWHTTA700

CAT # HANDLE LENGTH MAXIMUM STAPLE LENGTH WEIGHT

DWHTHT450 10.50" 1/2" 2.50 lbs

t $PNQBUJCMFXJUINPTUIFBWZEVUZUBDLFST

t %EWALT heavy-duty staples 5,000 pieces per reusable plastic case

t %VSBCMFQMBTUJDTUPSBHFCPYIFMQTQSFWFOUSVTUJOHBOETUJDLCSFBLBHF

CAT # LENGTH PACK SIZE

DWHTTA7055 5/16" (8 mm) 5,000 pcs

DWHTTA7065 3/8" (10 mm) 5,000 pcs

DWHTTA7085 1/2" (12 mm) 5,000 pcs

t 7SBUFE7UFTUFE

t 4QBDFTBWJOHNVMUJCMBEFEFTJHOXJUIRVJDLSFMFBTFNFDIBOJTNGPSTFDVSFBOEFBTZCMBEFDIBOHF

t 1PVDIJODMVEFEGPSFBTZPSHBOJ[BUJPO

104 HAND TOOLS & STORAGE

HAND TOOLS & STORAGE

BLADES

FOLDING

RETRACTABLE

KNIFE

RETRACTABLE

KNIFE

FIXED BLADE

KNIFE

t 3VHHFENFUBMCPEZGPSMPOHUPPMMJGF

t 3BQJEMPBECMBEFDIBOHJOHTZTUFNGPSRVJDLBOEFBTZCMBEFDIBOHFT

t #MBEFTUPSBHFGPSDPOWFOJFOUBDDFTTUPOFXCMBEFT

t &BTZPQFOGPSRVJDLCMBEFDIBOHF

t 4MJNOPTFGPSBDDVSBUFDVUT

t 3VHHFENFUBMCPEZGPSMPOHMJGF

5-IN-1

HACKSAW

t¡PS¡CMBEFBOHMFVTFEGPSTUBOEBSEBOEnVTIDVUT

t $POWFSUTUPMPXQSPmMFIBDLTBXGPSUJHIUTQBDFTBOEMPOHSFBDIIBDLTBXGPSIBSEUPSFBDIQMBDFT

t /PTFQJFDFBMTPDPOWFSUTUPQJTUPMHSJQKBCTBX

CAT # 5 FUNCTIONS BLADE TYPE BLADE STORAGE THROAT DEPTH HANDLE LENGTH WEIGHT

DWHT20547L 45° Hacksaw Blade - 12" Yes 4.75" 5" 1.29 lbs

90° Recip Saw Blade - 6"

Low Proﬁle Hacksaw

Long Reach Hacksaw

Pistol Grip Jab Saw

SNAP OFF

KNIVES

HACKSAW

BLADES

t "MMNFUBMCPEZJTIFBWZEVUZBOESVTUSFTJTUBOU

t /BSSPXCPEZGPSNBOFVWFSBCJMJUZBOETUPSBHF

t *OUFHSBUFECMBEFTOBQQFSGPSFBTZCMBEFTOBQQJOH

t #FTUJOJUJBMTIBSQOFTTJOUIFNBSLFUCFUUFSUIBO-FOPY/JDIPMTPOBOE#BIDP

t #JNFUBMDPOTUSVDUJPODPNCJOFTnFYJCJMJUZGSPNDBSCPOTUFFMBOEDVUUJOHQFSGPSNBODFGSPNIJHITQFFETUFFM

t $VUTNPTUNFUBMTJODMVEJOHVOIBSEFOFEUPPMTUFFMTUBJOMFTTTUFFM

CAT # SIZE BLADE LENGTH BLADE STORAGE LOCKABLE BLADE HANDLE LENGTH WEIGHT

DWHT10037 9 mm 3.25" No Yes 5.25" 0.08 lbs

DWHT10038 18 mm 4.25" No Yes 5" 0.32 lbs

DWHT10045 25 mm 5.25" No Yes 6" 0.46 lbs

CAT # BLADE COUNT BLADE LENGTH TEETH PER INCH

DWHT20548 2 pk 10" 18

DWHT20549 2 pk 10" 24

DWHT20550 2 pk 10" 32

DWHT20551 2 pk 12" 18

DWHT20552 2 pk 12" 24

DWHT20553 2 pk 12" 32

DWHT20555 3 pk 10" 18, 24 and 32

DWHT20558 3 pk 12" 18, 24 and 32

CUTTING TOOLS

t (SJOEJOHHFPNFUSZPGGFSTBOFEHFUIBUJTTIBSQFS1FSGPSNBODFBDDVSBUFDVUTGSPNUIFTUBSUPGXPSL**

t 4QFDJBMMZIFBUUSFBUFECMBEFTUIBUBSFTUSPOHFS%VSBCJMJUZMFTTCMBEFDIBOHFT**

t *OEVDUJPOIBSEFOFEDVUUJOHFEHFBMMPXTMPOHFSDVUUJOHGPSGFXFSCMBEFDIBOHFT**

CAT # BLADE COUNT BLADE LENGTH MATERIAL

DWHT11004L 75 pk 2.5" Steel

DWHT11004T 10 pk 2.5" Steel

**Compared to traditional single material blades

t 3FUSBDUBCMFCMBEFPGGFSTWBSJBCMFDVUEFQUI

t 3BQJEMPBECMBEFDIBOHJOHTZTUFNGPSRVJDLBOEFBTZCMBEFDIBOHFT

t 'PMEJOHGFBUVSFGPSRVJDLBOEFBTZPOFIBOEFEPQFOJOHDMPTJOH

CAT # BLADE LENGTH BLADE STORAGE LOCKABLE BLADE HANDLE LENGTH WEIGHT

DWHT10035L 2.5" Yes Yes 6.25" 0.34 lbs

CAT # BLADE LENGTH BLADE STORAGE LOCKABLE BLADE HANDLE LENGTH WEIGHT

DWHT10046 2.5" Yes Yes 6.75" 0.42 lbs

CAT # BLADE LENGTH BLADE STORAGE LOCKABLE BLADE HANDLE LENGTH WEIGHT

DWHT10246 2.5" Yes Yes 6" 0.35 lbs

(continued on next page)

HAND TOOLS & STORAGE 105

HAND TOOLS & STORAGE

MEDIUM

BAR CLAMPS

SMALL

BAR CLAMP

PANEL SAWS

CUTTING TOOLS

CLAMPS

t 0OFIBOEFEPQFSBUJPO

t $POWFSUTUPBTQSFBEFS

t 3FNPWBCMFKBXQBETQSPUFDUXPSLTVSGBDFT

CAT # # CLAMPS INCLUDED CLAMPING FORCE THROAT DEPTH WEIGHT

DWHT83138 1 35 lbs 1.50" 0.12 lbs

t 0OFIBOEFEPQFSBUJPO

t 5PVHISFJOGPSDFEOZMPOCPEZ

t 3FNPWBCMFKBXQBETQSPUFDUXPSLTVSGBDFT

CAT # # CLAMPS INCLUDED CLAMPING FORCE THROAT DEPTH WEIGHT

DWHT83139 (1) 6" Clamp 200 lbs 3" 0.80 lbs

DWHT83140 (1) 12" Clamp 200 lbs 3" 0.98 lbs

DWHT83149 (2) 6" Clamps 200 lbs 3" 1.10 lbs

DWHT83158 (2) 12" Clamps 200 lbs 3" 2.30 lbs

STANDARD

JAB SAW

t "HHSFTTJWFUPPUIEFTJHODVUTVQUPGBTUFSUIBOUSBEJUJPOBMUPPUIEFTJHOT

t .VMUJQMFNBUFSJBMVTBHFGPSVTFPOESZXBMMQMBTUJDBOEPUIFSCVJMEJOHNBUFSJBMT

CAT # BLADE LENGTH POINTS PER INCH TEETH PER INCH HANDLE LENGTH WEIGHT

DWHT20540 6" 9 8 5.50" 0.35 lbs

t 5ISFFTJEFEUPPUIDVUTVQUPGBTUFSUIBOUSBEJUJPOBMIBOETBXT

t *OEVDUJPOIBSEFOFEUFFUITUBZTIBSQGPSMPOHMJGF

t 5PVHI$PBU™ long-lasting, low-friction coating for less drag

CAT # BLADE LENGTH POINTS PER INCH TEETH PER INCH HANDLE LENGTH WEIGHT

DWHT20544L 15" 9 8 6.50" 1.30 lbs

DWHT20545L 20" 9 8 6.50" 1.50 lbs

FLUSH CUT SAW

t 'MFYJCMFCMBEFDSFBUFTQFSGFDUnVTIDVUT

t QPJOUUPPUIHFPNFUSZDVUTRVJDLMZBOEDMFBOMZPOUIFQVMMTUSPLF

t %PVCMFTJEFECMBEFGPSNBLJOHJOTJEFDVUTGSPNUIFMFGUPSSJHIU

CAT # BLADE LENGTH POINTS PER INCH TEETH PER INCH HANDLE LENGTH WEIGHT

DWHT20541 5" 24 23 6.50" 0.34 lbs

MULTI-PURPOSE

SAW

t 8PSLTXJUINPTUTUBOEBSESFDJQSPDBUJOHTBXBOEIBDLTBXCMBEFTGPSXPPENFUBMDVUUJOH

t 2VJDLCMBEFDIBOHFXJUIUFOTJPOOVU

t &SHPOPNJDCJNBUFSJBMIBOEMFGPSFYUSBDPNGPSU

CAT # BLADE TYPE BLADE LENGTH POINTS PER INCH TEETH PER INCH HANDLE LENGTH WEIGHT

DWHT20542 Hacksaw 10" 25 24 6.50" 0.32 lbs

Reciprocal 6" 8 7

FOLDING

JAB SAW

t JOEFTJHOGPSDPOWFOJFODFDVUESZXBMMBOEQMBOFFEHFTXJUIUPPM

t +BCTBXXJUIUSJQMFHSPVOEUFFUIGPSGBTUDVUUJOH

t 4UFFMSBTQGPSNBUFSJBMSFNPWBM

CAT # BLADE LENGTH POINTS PER INCH TEETH PER INCH HANDLE LENGTH WEIGHT

DWHT20123 Jab-5.25", Rasp-4" 9 8 6.50" 0.49 lbs

106 HAND TOOLS & STORAGE

HAND TOOLS & STORAGE

RAPID RETURN

BAR CLAMPS

LARGE

BAR CLAMPS

SIDE STRIKE

CHISELS

t $VUUJOHFEHFPOTJEFPGCMBEFGPSEFNPMJUJPOXPSLBMTPBMMPXTUIFDIJTFMUPEPVCMFBTBTDSBQFS

t 4UFFMTUSJLFDBQBOEMBSHFTJEFTUSJLFTVSGBDFGPSEVSBCJMJUZ

t 4FSSBUFEDVUUJOHFEHF

CAT # HANDLE MATERIAL HANDLE LENGTH CHISEL TIP STYLE BLADE WIDTH WEIGHT

DWHT16065 Bi-Material 5-1/4" Wood/Side Strike Yes 0.74 lbs

DWHT16148 Bi-Material 5-1/4" Wood/Side Strike 3/4", 1" & 1-1/4" 2.06 lbs

WOOD CHISELS

WOOD

CHISEL

SET

t )BSEFOFEUFNQFSFEDISPNFDBSCPOTUFFMCMBEFGPSFEHFSFUFOUJPO

t )BSEFOFETUSJLFDBQGPSEVSBCJMJUZ

t #MBEFMBDRVFSFEGPSDPSSPTJPOQSPUFDUJPO

CAT # HANDLE MATERIAL HANDLE LENGTH CHISEL TIP STYLE MALLET REQUIRED WEIGHT

DWHT16063 Bi-Material 5" Wood Chisel Yes 1.78 lbs

CLAMPS

HAMMERS

MIG WELD

HAMMERS

CAT # HANDLE MATERIAL HANDLE LENGTH FACE DIAMETER WEIGHT OF HEAD FACE STYLE HANDLE STYLE WEIGHT

DWHT51138 Steel 16" 2" 15 oz Checkered Straight 1.83 lbs

DWHT51145 Steel 16" 2" 15 oz Smooth Straight 1.83 lbs

DWHT51135 Steel 16" 2" 14 oz Smooth Straight 1.83 lbs

t .*(XFMEBMMTUFFMEFTJHOGPSEVSBCJMJUZBOEMPOHMJGF

t -JHIUXFJHIUGPSGBTUTXJOHBOESFEVDFEGBUJHVF**

t .BHOFUJDOBJMTUBSUFSGPSFBTZPOFIBOEFEOBJMQMBDFNFOU

** Versus one piece steel framing hammers

t 0OFIBOEFEPQFSBUJPO

t &BTJMZDPOWFSUTUPBTQSFBEFS

t 5PVHISFJOGPSDFEOZMPOCPEZ

CAT # # CLAMPS INCLUDED CLAMPING FORCE THROAT DEPTH WEIGHT

DWHT83144 (1) 24" Clamp 350 lbs 4.25" 8.0 lbs

DWHT83145 (1) 36" Clamp 350 lbs 4.25" 12.0 lbs

t 3BQJESFUVSONFDIBOJTNBMMPXTGPSRVJDLDMPTFBDUJPO

t &BTJMZDPOWFSUTUPBTQSFBEFS

t 5PVHISFJOGPSDFEOZMPOCPEZ

CAT # # CLAMPS INCLUDED CLAMPING FORCE THROAT DEPTH WEIGHT

DWHT83141 (1) 6" Clamp 350 lbs 4.25" 2.00 lbs

DWHT83143 (1) 12" Clamp 350 lbs 4.25" 2.30 lbs

t -JHIUXFJHIUGPSGBTUTXJOHBOESFEVDFEGBUJHVF**

t (FOVJOFIJDLPSZIBOEMFGPSEVSBCJMJUZBOEMPOHMJGF

t "WBJMBCMFXJUITNPPUIPSDIFDLFSFEGBDFBOEBYFPSTUSBJHIUIBOEMF

HICKORY HANDLE

FRAMING

HAMMERS

CAT # HANDLE MATERIAL HANDLE LENGTH FACE DIAMETER WEIGHT OF HEAD FACE STYLE HANDLE STYLE WEIGHT

DWHT51411 Hickory 16" 2" 17 oz Smooth Axe 1.88 lbs

DWHT51418 Hickory 16" 2" 17 oz Checkered Axe 1.88 lbs

DWHT51410 Hickory 16" 2" 17 oz Checkered Straight 1.88 lbs

HAND TOOLS & STORAGE 107

HAND TOOLS & STORAGE

NAIL SETS

PRY BARS

PLIERS & SNIPS

PUSHLOCK

PLIERS

t 4MJNIFBEEFTJHOmUTJOUPUJHIUQMBDFT

t 1VTIMPDLUFDIOPMPHZXJUIMPDLJOHQPTJUJPOTGPSGBTUKBXBEKVTUNFOU

t 7KBXEFTJHOGPSNVMUJQVSQPTFHSJQQJOH

CAT # GRIP MATERIAL HANDLE LENGTH JAW CAPACITY JAW TIP SIZE WEIGHT

DWHT70269 8" Bi-Material Cushion Handle 4.50" 3" 1" 0.44 lbs

DWHT70270 10" Bi-Material Cushion Handle 6" 3.75" 1.25" 0.84 lbs

DWHT70271 12" Bi-Material Cushion Handle 7" 4.50" 1.50" 1.43 lbs

Plier Set

DWHT70486 8" & 10" Bi-Material Cushion Handle 4.50", 6" 3", 3.75" 1", 1.25" 1.25 lbs

FENCING

PLIERS

t )BNNFSTUSJLFGBDF

t 4UBQMFTUBSUFSBOEQVMMFS

t 8JSFTUSFUDIFSBOETQMJDFS

CAT # GRIP MATERIAL HANDLE LENGTH JAW CAPACITY JAW TIP SIZE WEIGHT

DWHT70273 Bi-Material Cushion Handle 9.25" 1.50" 1" 1.64 lbs

SPRING STEEL

FLAT BARS

t 4QSJOHTUFFMGPSTUSFOHUIBOEEVSBCJMJUZ

t &YUSBXJEFQSZJOHFOEGPSMFWFSBHFBOEQSZTVSGBDF

t 1PJOUFECFWFMFEFOEGPSQFOFUSBUJPOBOEOBJMQVMMJOH

CAT # BAR LENGTH NUMBER OF NAIL SLOTS WEIGHT

DWHT55518 12" 3 1.24 lbs

DWHT55528 21" 3 2.17 lbs

CUSHION GRIP

NAIL SETS

t 1SFDJTJPO)BSEFOFE4UFFMGPSJODSFBTFEMJGF

t $VQQFEUJQGPSFBTZBMJHONFOU

t &BDIOBJMTFUJTDPMPSDPEFEGPSFBTZJEFOUJmDBUJPOPOUIFKPCTJUF

CAT # HANDLE MATERIAL TIP SIZE WEIGHT

DWHT58018 Bi Material 1/32", 2/32" & 3/32" 0.37 lbs

DWHT58019 Bi Material 1/32" 0.125 lbs

NAIL SET

t *OUFSDIBOHFBCMFUJQGPSDPOWFOJFODFJODMVEFTQU1IJMMJQTUJQT

t )FYBHPOBMIFBEQSFWFOUTSPMMJOHBOEDBOCFVTFEBTBTUBOEBSEESJMMDIVDLoOBJMTFUEPVCMFTBTESJMMFYUFOTJPO

t ,OVSMFEMPDLJOHDPMMBSGPSFBTZOBJMSFMFBTFBOESFWFSTBMBDDFQUTTUBOEBSETDSFXESJWFSCJUTGPSWFSTBUJMJUZ

CAT # HANDLE MATERIAL TIP SIZE WEIGHT

DWHT58503 Comfort Grip 1/32", 2/32", 3/32", & 2 pt Phillips 0.80 lbs

WRECKING

BARS

t 3PVOEFE¡QSZJOHFOEGPSMFWFSBHFBOEQSZJOH

t .VMUJQMFOBJMQVMMFSTGPSnFYJCJMJUZBOEOBJMSFNPWBM

t 1PJOUFECFWFMFEFOEGPSQFOFUSBUJPOBOEOBJMQVMMJOH

CAT # BAR LENGTH NUMBER OF NAIL SLOTS WEIGHT

DWHT55129 24" 3 4.20 lbs

DWHT55131 36" 2 6.50 lbs

DWHT55132 42" 2 7.20 lbs

10" CLAW

BAR

t /BJMEJHHFSFYQPTFTUIFIFBEPGBnVTIOBJM

t &YUSBXJEFTUSJLFTVSGBDFIFMQTVTFSBDDVSBUFMZTUSJLFUIFCBS

t *CFBNTIBGUQSPWJEFTTUSFOHUIXJUIPVUBEEJOHXFJHIU

CAT # BAR LENGTH NUMBER OF NAIL SLOTS WEIGHT

DWHT55524 10" 2 0.82 lbs

t &YUSBXJEFIFBEXJEFSUIBOTUBOEBSENPMEJOHCBST

t &YUSBXJEFTUSJLFTVSGBDFnBUQSZJOHFOEIFMQTVTFSBDDVSBUFMZTUSJLFUIFCBS

t *CFBNTIBGUQSPWJEFTTUSFOHUIXJUIPVUBEEJOHXFJHIU

10" MOLDING

BAR

CAT # BAR LENGTH NUMBER OF NAIL SLOTS WEIGHT

DWHT55529 10" 2 0.7 lbs

108 HAND TOOLS & STORAGE

HAND TOOLS & STORAGE

PLIERS & SNIPS

LINESMAN

PLIERS

tø'PSHFE$ISPNF7BOBEJVN4UFFMGPSTUSFOHUIBOEEVSBCJMJUZ

t(SJQ"SNPSIFMQTQSFWFOUHSJQTGSPNUFBSJOHBOEQSPWJEFTMPOHMJGF

tø*OEVDUJPOIBSEFOJOHIFMQTCMBEFTTUBZTIBSQ

CAT # GRIP MATERIAL HANDLE LENGTH JAW CAPACITY JAW TIP SIZE WEIGHT

DWHT70796 7" Polyvinyl Chloride 4.5" 1" 0.125" 0.65 lbs

DWHT70798 8" Polyvinyl Chloride 5.5" 1.75" 0.563" 1.19 lbs

DWHT70797 9" Polyvinyl Chloride 5.5" 1.75" 0.563" 1.19 lbs

END

NIPPERS

t'PSHFE$ISPNF7BOBEJVN4UFFMGPSTUSFOHUIBOEEVSBCJMJUZ

t(SJQ"SNPSIFMQTQSFWFOUHSJQTGSPNUFBSJOHBOEQSPWJEFTMPOHMJGF

t*OEVDUJPOIBSEFOJOHIFMQTCMBEFTTUBZTIBSQ

CAT # GRIP MATERIAL HANDLE LENGTH JAW CAPACITY JAW TIP SIZE WEIGHT

DWHT70801 6.5" Polyvinyl Chloride 5" 2" 0.063" 0.7 lbs

DWHT70802 8" Polyvinyl Chloride 5" 0.625" 1.125" 0.79 lbs

DWHT70803 10" Polyvinyl Chloride 5.5" 1" 1.25" 1.23 lbs

DIAGONAL

PLIERS

t'PSHFE$ISPNF7BOBEJVN4UFFMGPSTUSFOHUIBOEEVSBCJMJUZ

t(SJQ"SNPSIFMQTQSFWFOUHSJQTGSPNUFBSJOHBOEQSPWJEFTMPOHMJGF

t*OEVDUJPOIBSEFOJOHIFMQTCMBEFTTUBZTIBSQ

CAT # GRIP MATERIAL HANDLE LENGTH JAW CAPACITY JAW TIP SIZE WEIGHT

DWHT71011 6.5" Polyvinyl Chloride 3-1/2" 15/16" 1/8" 0.45 lbs

DWHT70815 6" Polyvinyl Chloride 4" 0.75" 0.063" 0.4 lbs

DWHT70793 7" Polyvinyl Chloride 4" 0.75" 0.063" 0.56 lbs

DWHT70794 8" Polyvinyl Chloride 4.5" 1" 0.125" 0.7 lbs

DWHT70795 10” Polyvinyl Chloride 6" 1.25" 0.125" 0.93 lbs

LENGTH

LONG NOSE

PLIERS

tø'PSHFE$ISPNF7BOBEJVN4UFFMGPSTUSFOHUIBOEEVSBCJMJUZ

t(SJQ"SNPSIFMQTQSFWFOUHSJQTGSPNUFBSJOHBOEQSPWJEFTMPOHMJGF

tø*OEVDUJPOIBSEFOJOHIFMQTCMBEFTTUBZTIBSQ

CAT # GRIP MATERIAL HANDLE LENGTH JAW CAPACITY JAW TIP SIZE WEIGHT

DWHT70799 6" Polyvinyl Chloride 3" 1.75" 0.063" 0.36 lbs

DWHT70800 8" Polyvinyl Chloride 5" 2" 0.063" 0.7 lbs

LENGTH

HAND TOOLS & STORAGE 109

HAND TOOLS & STORAGE

PLIERS & SNIPS

CRIMPING

PLIERS

t $SJNQTUP"8(UFSNJOBMTBOEDPOOFDUPST

t $ISPNF7BOBEJVN4UFFMGPSHFEQMJFSTGPSTUSFOHUIBOEEVSBCJMJUZ

t #JNBUFSJBMDVTIJPOIBOEMFGPSTUSPOHHSJQBOEDPNGPSU

CAT # GRIP MATERIAL HANDLE LENGTH JAW CAPACITY JAW TIP SIZE WEIGHT

DWHT70272 Bi-Material Cushion Handle 9.50" 1" 0.50" 0.71 lbs

COMPOUND

ACTION PLIERS

t .PSFDVUUJOHQPXFSPWFSTUBOEBSEDVUUJOHQMJFST

t #JNBUFSJBMIBOEMFTGPSTUSPOHHSJQBOEDPNGPSU

t "HHSFTTJWFDSPTTIBUDIUPPUIEFTJHOGPSHSJQQJOH

CAT # DESCRIPTION GRIP MATERIAL HANDLE LENGTH JAW CAPACITY JAW TIP SIZE WEIGHT

DWHT70275 Diagonal Pliers Bi-Material 4.25" 0.25" 0.75" 0.57 lbs

DWHT70276 Linesman Pliers Bi-Material 4.25" 0.38" 0.50" 0.73 lbs

DWHT70277 Long Nose Pliers Bi-Material 4.25" 0.75" 0.50" 0.66 lbs

REBAR

PLIERS

t 'PSHFE$ISPNF7BOBEJVNTUFFMGPSTUSFOHUIBOEEVSBCJMJUZ

t ¡CFOUIBOEMFGPSBEEJUJPOBMQVMMJOHMFWFSBHF

t 1SFDJTJPOJOEVDUJPOIBSEFOFEKBXTBOECMBEFT

CAT # DESCRIPTION GRIP MATERIAL HANDLE LENGTH JAW CAPACITY JAW TIP SIZE WEIGHT

DWHT84818 Light-Duty Polyvinyl Chloride (PVC) 6" 1" 0.25" 0.81 lbs

DWHT84720 Heavy-Duty Polyvinyl Chloride (PVC) 6" 0.94" 0.25" 1.20 lbs

SLIP JOINT

PLIERS

t(SJQ"SNPSIFMQTQSFWFOUHSJQTGSPNUFBSJOHBOEQSPWJEFTMPOHMJGF

t'PSHFE$ISPNF7BOBEJVN4UFFMGPSTUSFOHUIBOEEVSBCJMJUZ

t.FFUTPSFYDFFET"/4*TQFDJmDBUJPOT

CAT # GRIP MATERIAL HANDLE LENGTH JAW CAPACITY JAW TIP SIZE WEIGHT

DWHT71924 6" Polyvinyl Chloride 3.75" 2.25" 0.25" 0.437 lbs

DWHT71925 8" Polyvinyl Chloride 4.38" 3.38" 0.31" 0.5625 lbs

LENGTH

110 HAND TOOLS & STORAGE

HAND TOOLS & STORAGE

AVIATION

SNIPS

t 'MVTIIBSEXBSFBMMPXTTNPPUIBDDFTTGSPNQPVDI

t -BSHFSQJWPUCPMUUIBOMFBEJOHDPNQFUJUPSTGPSMPOHFSUPPMMJGF

t *OUFSOBMMPDLJOHNFDIBOJTNXJUIBVUPSFMFBTF

CAT # DESCRIPTION BLADE HANDLE GAUGE CUTTING CAPACITY BLADE MATERIAL WEIGHT

LENGTH LENGTH

DWHT70282 Bulldog 0.86" 6.50" 16 gauge cold rolled steel, Forged Chrome Molybdenum Alloy 0.97 lbs

18 gauge stainless steel

DWHT70283 Offset Left 1.30" 6.50" 18 gauge cold rolled steel, Forged Chrome Molybdenum Alloy 1.07 lbs

23 gauge stainless steel

DWHT70284 Offset Right 1.30" 6.50" 18 gauge cold rolled steel, Forged Chrome Molybdenum Alloy 1.08 lbs

23 gauge stainless steel

DWHT70279 Center 1.50" 6.50" 18 gauge cold rolled steel, Forged Chrome Molybdenum Alloy 0.88 lbs

23 gauge stainless steel

DWHT70280 Left 1.40" 6.50" 18 gauge cold rolled steel, Forged Chrome Molybdenum Alloy 0.87 lbs

23 gauge stainless steel

DWHT70281 Right 1.40" 6.50" 18 gauge cold rolled steel, Forged Chrome Molybdenum Alloy 0.85 lbs

23 gauge stainless steel

Aviation Snips Set

DWHT70278 3 pack (Includes: DWHT70279, DWHT70280, DWHT70281) 3.11 lbs

TIN SNIPS

t )FBWZEVUZGPSHFETUFFMCMBEFTDVUVQUPHBDPMESPMMFETUFFMBOEHBTUBJOMFTTTUFFM

t .FFUTPSFYDFFET"/4*TQFDJmDBUJPOTGPSDVUUJOHQFSGPSNBODF

t 4MJQSFTJTUBOUEPVCMFEJQQFEHSJQ

CAT # OVERALL BLADE BLADE GAUGE CUTTING CAPACITY HANDLE WEIGHT

LENGTH LENGTH MATERIAL LENGTH

DWHT70285 7" 2" Forged Steel 22 ga. Cold Rolled Steel & 26 ga. Stainless Steel 3.75" 0.66 lbs

DWHT70286 10" 2.50" Forged Steel 22 ga. Cold Rolled Steel & 26 ga. Stainless Steel 6" 1.15 lbs

DWHT70287 12" 3" Forged Steel 22 ga. Cold Rolled Steel & 26 ga. Stainless Steel 6.75" 1.49 lbs

WRENCHES

** Versus leading competitor

WRENCHES & HEX KEYS

RATCHETING

T HANDLE

SETS

t $PNQBDUBOEEVSBCMFDBTFGPSFBTZTUPSBHF

t -BSHFWBSJFUZPGCJUTGPSBMNPTUBOZKPCTUBS4PDLFUT/VU%SJWFST1IJMMJQTBOEnBU

t )FBWZEVUZSBUDIFUJOH5IBOEMFPGGFSTRVJDLDIBOHFLFZT

CAT # HEX KEY SHAPE METRIC/SAE/USS WEIGHT

DWHT70265 Flat, Star, Phillips Metric & SAE 2.90 lbs

DWHT70808 Sockets Metric & SAE 2.90 lbs

DWHT70838 Nut Drivers TORX 2.90 lbs

t 1VTICVUUPOMPDLJOHGFBUVSFMPDLTJOQPTJUJPOTBU¡¡BOE¡

t %VSBCMFTUFFMTJEFQMBUFGPSIJHIUPSRVFBQQMJDBUJPOT

t *ODMVEFTPGUIFNPTUDPNNPOMZVTFEIFYLFZTJ[FT

CAT # HEX KEY SHAPE METRIC/SAE/USS WEIGHT

DWHT70262M Flat End SAE 0.68 lbs

DWHT70263M Flat End Metric 0.68 lbs

DWHT70264 Star Metric & SAE 0.68 lbs

FOLDING

LOCKING

HEX KEYS

t *NQSPWFETUSFOHUIEVFUPJODSFBTFEFOHBHFNFOUPOUFFUIBOEXPSNHFBS**

t 5PVHI$PBU™ ﬁnish helps to prevent chipping

t +BXNPWFNFOUFOHJOFFSFEUPGBDJMJUBUFNJOJNBMKBXNPWFNFOUCFUXFFOKBXTGPSQSFDJTFBEKVTUNFOUT**

CAT # DESCRIPTION MAXIMUM OPENING LENGTH WEIGHT

DWHT70289 Black Phosphate Adjustable 6" 0.88" 6" 0.32 lbs

DWHT70290 Black Phosphate Adjustable 8" 1.25" 8" 0.25 lbs

DWHT70291 Black Phosphate Adjustable 10" 1.38" 10" 1.50 lbs

DWHT70292 Black Phosphate Adjustable 12" 1.63" 12" 1.38 lbs

DWHT70293 Black Phosphate Adjustable 15" 1.75" 15" 3.66 lbs

DWHT70295 16" Spud Wrench 1.62" 9.5" 10.25 lbs

Wrench Set

DWHT70294 Black Phosphate Adjustable 2 pack (Includes: DWHT70289, DWHT70291) 1.82 lbs

SNIPS

HAND TOOLS & STORAGE 111

HAND TOOLS & STORAGE

STORAGE

DS Carrier

TOUGH

SYSTEM

t %VSBCMFNNUIJDLTUSVDUVSBMGPBNCPYXBMMTHJWFSPCVTUTUSVDUVSFGPSUIFTUBOEBMPOFVOJUT

t *OUFHSBUFEXBUFSTFBMJOFBDIVOJUIFMQTQSPUFDUDPOUFOUT

t .FUBMDBSSJFSXJUIBEKVTUBCMFGPMEBCMFCSBDLFUTBMMPXTUBJMPSFEDPOmHVSBUJPO

CAT # DESCRIPTION LOAD CAPACITY WEIGHT

DWST08201 DS150 - Small Case Tough System 66 lbs 9.70 lbs

DWST08203 DS300 - Large Case Tough System 88 lbs 9.50 lbs

DWST08204 DS400 - XL Case Tough System 110 lbs 13.20 lbs

DWST08210 DS Carrier - Tough System 176 lbs total load on brackets 34.40 lbs

265**

lbs on toe plate

DWST08212 Brackets for Trolley 176 lbs 1.35 lbs

** 175 lbs if using on stairs

TSTACK

t'MFYJCMF1MBUGPSNBMMPXTEJGGFSFOUDPNCJOBUJPOT

tø4UBDLBCMF"MMVOJUTDBOTUBDLPOUPQPGUIFPUIFSDPOOFDUFEXJUIEVSBCMFTMJEFMBUDIFT

t3FNPWBCMF$PWFSFE$VQTGPSPSHBOJ[BUJPOPGTNBMMQBSUTBDDFTTPSJFT

CAT # DESCRIPTION LOAD CAPACITY WEIGHT

DWST17808 TSTAK I 66 lbs 5.57 lbs

DWST17807 TSTAK II 66 lbs 3.96 lbs

DWST17803 TSTAK III 16.5 lbs 8.40 lbs

DWST17804 TSTAK IV 16.5 lbs 9.35 lbs

DWST17889 TSTAK Cart 110 lbs 7.13 lbs

DS300 DS400DS150

MOBILE WORK

STATION

t 4JOHMFGSPOUQVMMVQMBUDIFBTJMZPQFOTVQUIFVOJU

t 8PSLMFWFMToUPQUPPMCPYBOEUSBZNJEPSHBOJ[FSTFDUJPOMBSHFCPUUPNCJOGPSQPXFSUPPMT

t *EFBMGPSPOTJUFTUPSBHFBOEUSBOTQPSUBUJPOPGFRVJQNFOU

CAT # LOAD CAPACITY WEIGHT

DWST20800 Bottom Bin - 44 lbs 21.42 lbs

Middle Organizer - 22 lbs

Top Tool Box - 22 lbs

112 HAND TOOLS & STORAGE

HAND TOOLS & STORAGE

ADJUSTABLE

LEG SAW HORSE

TOTE WITH

POWER TOOL

CASE

TOTE WITH

REMOVABLE

ORGANIZER

STORAGE

ONE TOUCH

BOX

t 0OFIBOEFEMBUDIPQFSBUJPOBMMPXTPQFOJOHXIFOPUIFSIBOEJTPDDVQJFE

t *OUFHSBUFEXBUFSTFBMUPIFMQQSPUFDUGSPNXBUFSBOEEVTU

t 4PGUHSJQIBOEMFGPSFBTZHSJQBOEDBSSZJOH

CAT # HANDLE HOLDING LATCH LOCKABLE MATERIAL WATER WEIGHT WHEELS WEIGHT

LENGTH CAPACITY TYPE RESISTANT CAPACITY

DWST24082 7" 3064 in3 Metal Yes Resin Yes 60 lbs No 5.32 lbs

WATER SEAL

TOOL BOX

t -BSHFDBQBDJUZEFTJHOFEGPSWPMVNFVUJMJUZ

t "MMSPVOEXBUFSTFBMUPIFMQQSPUFDUDPOUFOUT

t 1PSUBCMFUPUFUSBZGPSTUPSBHFPGMBSHFUPPMTBOEQPXFSUPPMT

CAT # HANDLE HOLDING LATCH LOCKABLE MATERIAL WATER WEIGHT WHEELS WEIGHT

LENGTH CAPACITY TYPE RESISTANT CAPACITY

DWST28001 7.10" 2125 in3 Metal Yes Resin Yes 100 lbs No 9.70 lbs

t 5PQDBTFGPSQPXFSUPPMTBOETNBMMQBSUTXJUIBOJOUFHSBUFEIBOEMF

t -POHNFUBMDBSSZIBOEMFGPSFBTZHSJQXIFODBSSZJOH

t )FBWZEVUZEFTJHOGPSEVSBCMFTUSVDUVSF

CAT # HANDLE HOLDING LATCH LOCKABLE MATERIAL WATER WEIGHT WHEELS WEIGHT

LENGTH CAPACITY TYPE RESISTANT CAPACITY

DWST24070 24.20" 3413 in3 Metal Yes Resin No 77 lbs No 7.41 lbs

t 5PQDBTFPSHBOJ[FSGPSTNBMMQBSUTXJUIJOUFHSBUFEIBOEMF

t -POHNFUBMDBSSZIBOEMFGPSFBTZHSJQXIFODBSSZJOH

t )FBWZEVUZEFTJHOGPSEVSBCMFTUSVDUVSF

CAT # HANDLE HOLDING LATCH LOCKABLE MATERIAL WATER WEIGHT WHEELS WEIGHT

LENGTH CAPACITY TYPE RESISTANT CAPACITY

DWST24075 24.20" 3190 in3 Metal on Yes Resin No 77 lbs No 7.40 lbs

Organizer

t 6OJRVFNFDIBOJTNXJUIFBTZTMJEFNPWFNFOUTBEKVTUTMFHTTFQBSBUFMZGPSXPSLPOVOFWFOTVSGBDFT

t )JHIRVBMJUZDPNCJOBUJPOPGNFUBMBOEQMBTUJDGPSMPBEDBQBDJUZPGVQUPMCTQFSQBJS

t 3VCCFSJOTFSUTPOMFHTBOEVQQFSSVMFSGPSTUBCJMJUZ

CAT # LENGTH MATERIAL TYPE WEIGHT CAPACITY WEIGHT

DWST11031 27.46" Metal / Plastic 2500 lbs per pair 10.64 lbs

Easy Ordering & Tracking

t6QMPBEZPVSDVSSFOUQBSUTPSEFSEJSFDUMZGSPNBO&YDFMPS8PSEEPDVNFOU

t5SBDLUIFTUBUVTPGZPVSPSEFSXIFUIFSJUIBTKVTUCFFOTVCNJUUFECFJOHQSPDFTTFETIJQQFEPSCBDLPSEFSFE

t$SFBUFBi4IPQQJOH-JTUwUPBMMPXGPSFBTZSFPSEFSPGZPVSUPQNPWJOHQBSUT

Extensive Library of Schematics & Manuals

t&BTZUPNBOFVWFSEJBHSBNT

t'VODUJPOBMJUZUPFNBJMEJBHSBNTPSNBOVBMTUP

yourself or anyone else

t0SEFSZPVSQBSUTEJSFDUMZGSPNUIFEJBHSBNJUTFMG

Parts Pricing & Availability

t"DDFTTUPZPVSQSJDJOHPOQBSUT

t%PXOMPBEMJTUQSJDFGJMFT

t7JTJCJMJUZUPQBSUBWBJMBCJMJUZCFGPSFZPVPSEFSJU

Factory & Authorized

Service Center Locator

t&BTJMZMPDBUFPOFPGPVS'BDUPSZ0XOFE

4FSWJDF$FOUFSTPS"VUIPSJ[FE4FSWJDF$FOUFST

24 / 7 / 365 Access

t"DDFTTUPBMMZPVSQBSUTTFSWJDFJOGPSNBUJPOIPVSTBEBZEBZTBXFFLEBZTBZFBS

___________________________________

Username

___________________________________

Password

To register, go to www.SERVICENET.DEWALT.com. Select

i3FHJTUFSwJOUIFUPQSJHIUDPSOFS$PNQMFUFUIFSFHJTUSBUJPO

form online. If you have an active account with a Factory Owned

Service Center, please allow 48 hours for your registration to be

approved. You will receive an email conﬁrmation once your

registration is approved. For any questions, please contact your

local Factory Owned Service Center.

113

tSafety Testing–Ensuring your tools are safe to operate

t We perform leakage current test, high pot test, and ground test

on all repaired products

t A safety features check confirms that all safety required

guarding, shields and handles are available

t04)"SFDPHOJ[FETBGFUZUBHQMBDFEPOBMMSFQBJST

t Performance Testing–Repaired product tested by

running through real-life applications prior to approvals

t Trained Technicians–Staff of over 250 professionally trained

technicians ensure your repair is right the first time

t1MVTPUIFSTQFDJBMUZUFTUTBTOFFEFE

t Multiple Call Centers:

Customer service agents

available for fast, friendly support

DEWALT: 1-800-433-9258

PORTER-CABLE : 1-800-223-7278

t Over 30 Field Service Coordinators

t1SPGFTTJPOBMUFDIOJDBMBTTJTUBODFUISPVHI

the Factory Service Centers and Call Centers

t0WFS"VUIPSJ[FE4FSWJDF1SPWJEFSTFODPNQBTTJOHUIFJOEVTUSZTMBSHFTUTFSWJDFOFUXPSL

SERVICE GUARANTEE

WE’VE GOT

YOUR BACK.

SERVICE CENTER

CALL CENTER

SERVICE VAN

HAND TOOLS & STORAGE

114

115

State/City/Zip Street Phone State/City/Zip Street Phone

Anchorage, 99503 4831 Old Seward Highway, Suite 103 907-561-7181

Birmingham, 35209 321 Valley Ave., Suite B 205-942-0538

Mobile, 36693 732 Lakeside Dr. 251-602-1000

North Little Rock, 72113 9600 Maumelle Blvd. 501-372-3040

Phoenix, 85040 4001 East Broadway, Suite B-11 602-437-1200

Hayward, 94545 2512 Tripaldi Way 510-783-3959

San Diego, 92111 7290 Clairemont Mesa Blvd. 858-279-2011

Anaheim, 92806 1119 North Kraemer Blvd. 714-414-0369

North Highlands, 95660 4986 Watt Ave., Suite B 916-344-3520

Ontario, 91761 1352 South Grove Ave., Suite B 909-930-1437

Denver, 80223 700 West Mississippi Ave., Unit B1 303-922-8325

Wethersﬁeld, 06109-3001 662 Silas Deane Hwy. 860-563-5800

Davie, 33314 4343 South State Rte 7, Unit 107 954-321-6635

Tampa, 33634 4909 West Waters Ave. 813-884-0434

Jacksonville, 32205-4898 920 Cassat Ave. 904-781-2253

Orlando, 32807 6100 Hanging Moss Rd., Suite 520 407-657-0474

West Palm Beach, 33415 4645 Gun Club Rd., Suite 27 561-689-3247

Norcross, 30071 6115-C Jimmy Carter Blvd. 770-246-1710

Honolulu, 96819 111 Sand Island Access Rd., Suite R-17 808-842-9925

Des Moines, 50310 3408 Merle Hay Rd., Suite A 515-270-1340

Tinley Park, 60477 8201 West 183rd St., Suite P 708-614-1596

Bensenville, 60106 800 Thorndale Ave. 630-521-1097

Indianapolis, 46224-3707 5999 Crawfordsville Rd. 317-243-8308

Overland Park, 66214 9201 Quivira Rd. 913-495-4330

Wichita, 67213 2333 S. West St. 316-943-1271

Louisville, 40213 2001 Fern Valley Rd. 502-380-3748

Metairie, 70001 1801 Airline Dr., Suite D 504-832-2187

Baton Rouge, 70816 10699 Airline Highway, Suite C 225-296-3191

Shreveport, 71108 7702 Jewella Rd. 318-688-1553

Westwood, 02090 377 University Ave. 781-329-3407

Baltimore, 21227 1646 Sulphur Spring Rd. 410-536-0722

Capitol Heights, 20743 7957-63 Central Ave. 301-333-0865

Grandville, 49418 2982 28th St., S.W. 616-261-0425

Madison Heights, 48071 30475 Stephenson Hwy. 248-597-5000

Eden Prairie, 55344 9709 Valley View Rd., Suite 9709 952-884-9191

St. Louis, 63146 11477 Page Service Dr. 314-997-9100

Charlotte, 28208 3557-B Wilkinson Blvd. 704-392-0245

Greensboro, 27407 3402 West Wendover Ave., Suite E 336-852-1300

Raleigh, 27604-3235 2930 Capital Blvd. 919-878-0357

Elmwood Park, 07407 213 Route 46 West, Suite #4 201-475-3524

Albuquerque, 87110-3233 5617 Menaul Blvd. N.E. 505-884-1002

Las Vegas, 89118 5565 S. Decatur Blvd., Suite 103 702-889-6025

Buffalo, 14209-1297 881 W. Delavan Ave. 716-884-6220

Woodside, 11377-4741 56-15 Queens Blvd. 718-335-1042

Rochester, 14623-2594 2969 W. Henrietta Rd. 585-424-1310

Hauppauge, 11788 180 Oser Ave., Suite 100 631-952-2008

Latham, 12110-2497 836 Troy-Schenectady Rd. 518-785-1867

Parma, 44130 12100 Snow Rd., Suite 2 440-842-9100

Cincinnati, 45241-1896 2310 E. Sharon Rd. 513-772-3111

Columbus, 43229 1948 Schrock Rd. 614-895-3112

Maumee, 43537 3661 Briarﬁeld Blvd. 419-867-8561

Oklahoma City, 73139 8507 South Western 405-634-8403

Tulsa, 74146 11414 East 51st St., Unit C 918-249-8641

Portland, 97230 14811 North East Airport Way, Suite 600 503-255-6556

Philadelphia, 19148 2715 South Front St. 215-271-5500

Pittsburgh, 15201 3234 Penn Ave. 412-642-0204

Whitehall, 18052-4522 2242 MacArthur Rd. 610-435-9544

York, 17402 2201 Industrial Highway 717-755-3441

North Charleston, 29405 4365 Dorchester Rd., Suite 104 843-745-9197

Greenville, 29605 1259 South Pleasantburg Dr., Unit C 864-299-8662

Memphis, 38133 2686 Kirby-Whitten Rd., Suite 102 901-384-8100

Nashville, 37210 746 Fesslers Lane 615-242-1633

Knoxville, 37917-2699 4118 North Broadway 865-688-0921

Carrollton, 75006 1300 Interstate 35 North, Suite 112 972-446-2996

Houston, 77040 10245 W. Little York, Suite 300 713-692-7111

San Antonio, 78216 1218 Arion Parkway, Suite 114 210-732-1221

Fort Worth, 76111-5944 721 North Beach St. 817-831-3828

El Paso, 79915-1007 6822 Gateway East 915-778-9769

McAllen, 78501 200 North McColl, Suite H 956-661-1122

Austin, 78758 2219 Braker Lane 512-382-3971

Salt Lake City, 84104 3060 West California Ave., Suite I 801-486-5828

Richmond, 23230 2256 Dabney Rd., Suite F 804-353-1197

Virginia Beach, 23455 5760 Northampton Blvd., Suite 110 757-363-0091

Seattle, 98134 2100 Airport Way S. 206-763-2010

Spokane, 99212 5308 East Sprague Ave. 509-535-9252

West Milwaukee, 53214 1650 Miller Parkway 414-645-4285

Charleston, 25312-2495 1638 Sixth Ave. 304-343-0289

3M® is a registered trademark of 3M Company.

LENOX® and LAZER® are registered trademarks of the Irwin

Industrial Tool Co.

Freud® and Diablo® are registered trademarks of Freud America, Inc.

Bosch® is a registered trademark of Robert Bosch GmbH

Hilti® is a registered trademark of Hilti Aktiengesellschaft

Milwaukee® is a registered trademark of Milwaukee Electric Tool Corp.

Walter™ is a trademark of J. Walter Co. Ltd.

Makita® is a registered trademark of Makita Corp.

Flexovit® is a registered trademark of Flexovit USA, Inc.

RIDGID® is a registered trademark of Ridge Tool Company.

SAIT® is a registered trademark of SAIT Abrasivi SPA

Norton® is a registered trademark of Saint-Gobain Abrasives, Inc.

Marathon® is a registered trademark of Irwin Industrial Tool Co.

Mylar® is a registered trademark of DuPont Teijin Films™ U.S.

Limited Partnership.

Arrow, T50, T-25 & JT-21 are trademarks of Arrow Fastener Co., Inc.

ShopVac® is a registered trademark of Shop Vac Corporation.

iPhone® is a registered trademark of Apple Inc

For the most up-to-date Authorized Service Center listings, please contact 1-800-433-9258 or visit www.DEWALT.com.

FOR EXCLUSIVE PRODUCT INFORMATION, PROMOTIONS AND GIVEAWAYS

/DEWALT @DEWALTtough /DEWALTtv @DEWALTtough

Copyright ©2013 DEWALT. The following are trademarks for one or more DEWALT Power Tools and Accessories: The yellow and black color scheme; the “D”-shaped air intake grill; the array of pyramids on the handgrip;

the kit box conﬁguration; and the array of lozenge-shaped humps on the surface of the tool.

*Standard text rates apply

PRODUCTS:

Compare, review and research every DEWALT

tool and accessory including our latest innovations.

RETAILERS:

Locate all DEWALT retail partners.

SERVICE:

Order service parts on-line or ﬁnd your

closest service center.

EVENTS:

Get the latest information on DEWALT sponsorships

and local events in your area.

SUPPORT:

Search our database for answers to your product

or service questions.

MOBILE WEB ONLINE

DWCAT13 7/13

DWCAT13.r02 0806 54219 Catalog

Navigation menu

Versions of this User Manual:

Views

Navigation
