Effective August 6, 2012
Supersedes Form 0911D dated September 6, 2011
FORM 0812D
Phili
ps
Alk
co
Distributor Buying Guide
11500 Melrose Avenue
Franklin Park, Illinois 60131-8389
Phone: 847-451-0700
Fax: 847-451-7512
Toll Free: 866-50ALKCO (866-502-5526)
www.alkco.com
Night Lights
 •WGSeries............................................2
 •WGTSeries.........................................2
 •SONSeries..........................................3
 •103/104Series...................................4
 •103DF/104DFSeries......................5
Patient Room Solutions
 •ECSeries...............................................6
 •HZNLEDSeries..............................7
 •HZNFluorescentSeries..............8
 •ALBTSeries.........................................9
 •IBSeries.................................................10
 •2886Series..........................................11
 •9618Series..........................................12
 •ME640NSeries..................................13
 •ME540NSeries..................................14
 •ME340N/440NSeries....................15
 •ME340ARNSeries...........................16
 •ME240NSeries.................................16
 •DCEASeries.......................................17
 •DCESeries...........................................18
 •SL1Series..............................................19
SurgiCare Sealed Supplemental Troffers
 •SSTR24Series
  -T8Fluorescent................................20
  -T5Fluorescent................................21
  -T5HOFluorescent........................22
 •SSTR22Series
   -T8Fluorescent.............................23
   -T8UFluorescent..........................24
   -T5Fluorescent.............................25
   -40TTFluorescent.......................26
   -T5HOFluorescent.....................27
 •SSTR14Series
   -T8Fluorescent.............................28
   -T5Fluorescent.............................29
   -T5HOFluorescent.....................30
SurgiCare Supplemental Troffers
 •STR24Series
   -T8Fluorescent.............................31
   -T5Fluorescent.............................32
   -T5HOFluorescent................... 33
 •STR22Series
   -T8Fluorescent.............................34
   -T8UFluorescent.........................35
   -T5Fluorescent.............................36
   -40TTFluorescent.......................37
   -T5HOFluorescent....................38
 •STR14Series
   -T8Fluorescent.............................39
   -T5Fluorescent.............................40
   -T5HOFluorescent....................41
Sealed Surgical Troffers
 •STS8240Series..................................42
 •STS8220Series..................................43
 •STS8140Series..................................44
Surgical Troffer
 •ST8240Series......................................45
 •ST8220Series......................................46
 •ST8140Series......................................47
Recessed Halogen Exam Lights
 •9930Series..........................................48
 •9931Series..........................................48
Task & Examination Lighting
 •TE100Series........................................49
 •TE200Series........................................49
Minor Surgical & Procedure Lights
 •MNS10Series.....................................50
 •MNS50Series.....................................51
 •MNS100Series..................................52
 •MNS200Series..................................52
 •MNS300Series..................................53
Major Surgical & Procedure Lights
 •MJS200Series....................................54
X-Ray Illuminators
 •XSSeries...............................................55
 •XRSeries..............................................56
Darkroom Safelights
 •2058Series..........................................57
TABLE OF CONTENTS
HEALTHCARE LIGHTING
LINCS
 •LINCSLSeries.........................................58
 •LINCS100FSeries.................................59-60
 •LINCS100HN/XNSeries.................61
 •LINCS150Series...................................62
 •SFLINCS150Series..............................63
 •LINCSOSC-MODSeries..................64
Aris
 •ARISSeries............................................... 65
Little Inch2
 •L2FSeries..................................................66
Little Inch
 •HP100/200Series.................................67-68
 •HG/HXSeries........................................69
 •SFHP100/200Series............................70-71
 •TA2000Series.........................................72
Edge Glo Exits
 •RGLO/SGLO-FLSeries.....................89
 •RGLO/SGLO-LEDSeries.................90
 •WGLO-LEDSeries..............................91
 •RGLO-LEDWWSeries.....................92
Box Exit Signs
 •EASeries....................................................93-94
 •XCSeries...................................................95
SoftLook
 •SL1Series................................................82
Tableau
 •TABSeries................................................83
Lincandescents
 •LINSeries...................................................84
 •RLSeries.....................................................85
Super Inch
 •300Series..................................................73
 •SF300Series.............................................74
Inchline
 •ILFSeries....................................................75
Alkco-Lites
 •1000Series...............................................76
 •2000Series...............................................77
 •3000Series...............................................78
Quick Inch T5
•Q100/200Series.......................................79
Eco Inch
 •ECOSeries...............................................80
 •ECOHSeries...........................................81
 •ECOHLVSeries.....................................81
 •ECOXSeries...........................................81
Architectural Message Signs
•AMSSeries....................................................96
Red/Green Indicator Lights
 •207Series..................................................97
Neon, Incandescent & LED Signage
 •LDSeries....................................................98
Mini-Cove Strip
 •MCSSeries...............................................86
Mini-Troffers
 •MTSeries..................................................87
Recessed Trak
 •RTNSeries................................................88
TASK AND DISPLAY LIGHTING
EXITS & SIGNAGE
OTHER
RECESSED & SURFACE
Optional Special Ballasts, Replacement Components & Cost Adders for Special Finishes..................................99-101
Index............................................................................................................................................................................................................................102-105
Terms and Conditions......................................................................................................................................................................................106-107
WAYGLO
Night Light
LED
WG Series
Catalog Shpg Cont. Dist.
Number H W D Wt. Price Price
WG1V* 5-11/16" 4-3/8" 1-1/4"
WG2V* 5-11/16" 3" 15/16"
WG1H* 4-3/8" 5-11/16" 1-3/16"
WG2H* 3-15/16" 5-3/8" 15/16"
*Must add LED color and finish from list of available LEDs and finishes below
AVAILABLE LEDs (Must add as suffix)
/1 White LEDs
/2 Amber LEDs
VOLTAGE
/120 120 Volts
/277 277 Volts
AVAILABLE FINISHES1 (Must add as suffix)
/SWH Soft White
/BL Black
/AL Aluminum
/CC2Custom Color
OPTIONS
/PCC Photocell control
1The finish designation is for the faceplate only. The reflector comes standard as SWH - Soft White.
2Customer to provide RAL number or color chip to match.
WAYGLO
THRU-WALL NIGHT LIGHT
LED
WGT Series
Catalog Shpg Cont. Dist.
Number H W D Wt. Price Price
WGT3,4
Note: For Thru-Wall applications, you must specify two faceplates to go along with the
Thru-Wall Back Box. Use the pricing shown above for the WayGlo (WG) faceplates.
3The WGT is field convertible for either vertical or horizontal style faceplates. Both faceplates must
be of the same orientation.
4Faceplates must have the same voltage.
Oval shaped LED Night Light
(horizontal orientation)
Description
Oval shaped LED Night Light
(vertical orientation)
Rectangular shaped LED Night Light
(vertical orientation)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
Rectangular shaped LED Night Light
(horizontal orientation)
Description
Thru-Wall Back Box
(horizontal orientation)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
08/06/2012 2
SOFTGLO
Recessed Night Light
LED
SO2N/SO3N/SO4N SERIES
Catalog Shpg Cont. Dist.
Number H W D Wt. Price Price
COMPLETE LED NIGHT LIGHT
SO2N* 6 1/2" 8 1/4" 3"
SO3N* 6 1/2" 8 1/4" 3"
SO4N* 6 1/4" 8" 3"
*Must add LED color and finish from list of available LEDs and finishes below
120/277Volt Standard Lamps Included
AVAILABLE LEDs (Must add as suffix)
/1 White LEDs
/2 Amber LEDs
AVAILABLE FINISHES (Must add as suffix)
/MA Painted Matte Aluminum
/SS
Brushed Stainless Steel (only available with SO4N )
/SWH Soft White
OPTIONAL EQUIPMENT (Add as Suffix)
/SBF Slow Blow Fuse
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
LED Night Light with steel flat frame and
steel louver plate
LED Night Light with aluminum soft frame
and steel louver plate
Dimensions
Description
LED Night Light with aluminum deep
beveled front
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
308/06/2012
103/104
Micro-Louvered Night Light
Fluorescent/Incandescent
103/104 SERIES
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
HALF FACE
104
6 7/8" 5 1/2" 3 1/2" 3 1/2
277Volt Available Below Lamps Not Included
FULL FACE
103
6 7/8" 5 1/2" 3 1/2" 3 1/2
277Volt Available Below Lamps Not Included
OPTIONAL EQUIPMENT (Add as Suffix)
/277V 277 Volt Ballast (103 & 104 only)
/DUP Duplex Outlet for 104 only (120V only)
/HGWP Hospital Grade Duplex Outlet for 104 only (120V only)
/PL Ballast for PL 5 Watt lamp
/SLOBLO GMF Slow blow fuse and fuse holder (103 & 104 only)
/TP Tamper-Proof Oval-Head Screw
MOUNTING EQUIPMENT
PF104 Plaster Frame for 103 or 104
SD40 Screwdriver for Tamper-Proof Screw
REPLACEMENT EQUIPMENT
A103
A104
Dimensions
Description
Night Light for 1/F4T5
Fluorescent lamp
Night Light for 1/F4T5
Fluorescent lamp
LENS ASSEMBLY: (Full Face) Co-extruded acrylic light louver
featuring embedded opaque louvers for efficient light deflection
LENS ASSEMBLY: (Half Face) Co-extruded acrylic light louver
featuring embedded opaque louvers for efficient light deflection
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
08/06/2012 4
103DF/104DF
Double-Face, Micro-Louvered Night Light
Fluorescent/Incandescent
103DF/104DF SERIES
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
HALF FACE
104DF
6 7/8" 5 1/2" 3 1/2" 3 1/2
277Volt Available Below Lamps Not Included
FULL FACE
103DF 6 7/8" 5 1/2" 3 1/2" 3 1/2
277Volt Available Below Lamps Not Included
OPTIONAL LENS (Add as Suffix)
/3M Polarized directional lens for 103DF
/3M Polarized directional lens for 104DF
OPTIONAL EQUIPMENT (Add as Suffix)
/277V 277 Volt Ballast (103DF & 104DF only)
/DUP
Duplex Outlet for 104DF only (only one side--120V only)
/HGWP
Hospital Grade Duplex Outlet for 104 only (only one side--120V only)
/SLOBLO GMF Slow blow fuse and fuse holder (103DF & 104DF only)
/TP
Tamper-Proof Oval-Head Screw (only one side of unit is tamper proof)
MOUNTING EQUIPMENT
PF104 Plaster Frame for 103DF or 104DF
SD40 Screwdriver for Tamper-Proof Screw
REPLACEMENT EQUIPMENT
A103
A104
M103
Polarized directional lens (Full Face) for one face
M104
Polarized directional lens (Half Face) for one face
LENS ASSEMBLY: (Half Face) Co-extruded acrylic light louver, featuring
embedded opaque louvers for efficient light deflection, for one face
LENS ASSEMBLY: (Full Face) Co-extruded acrylic light louver, featuring
embedded opaque louvers for efficient light deflection, for one face
Dimensions
Night Light for (1) PL 5 Watt Fluorescent
lamp
Description
Night Light for (1) PL 5 Watt Fluorescent
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
508/06/2012
ERAcare
Multi-Function Patient Bed Light
T5HO/T5/T8 Fluorescent
EC Series
Shpg Cont. Dist.
L D H Wt. Price Price
120 Volt
ECT5HO-120 4 ft. T5HO Bed Light providing Exam, Reading and 48-15/16" 8-15/16" 5-1/2" 30
Ambient lighting functions, (4) F54 T5HO (Med. Bipin)
(1243.1mm)
(227.3mm) (139.7mm)
ECT5-120 4 ft. T5 Bed Light providing Exam, Reading and 48-15/16" 8-15/16" 5-1/2" 30
Ambient lighting functions, (4) F28 T5 (Med. Bipin)
(1243.1mm)
(227.3mm) (139.7mm)
ECT8-120 4 ft. T8 Bed Light providing Exam, Reading and 50-7/8" 8-15/16" 5-1/2" 35
Ambient lighting functions, (4) F32 T8 (Med. Bipin)
(1292.2mm)
(227.3mm) (139.7mm)
277 Volt
ECT5HO-277 4 ft. T5HO Bed Light providing Exam, Reading and 48-15/16" 8-15/16" 5-1/2" 30
Ambient lighting functions, (4) F54 T5HO (Med. Bipin)
(1243.1mm)
(227.3mm) (139.7mm)
ECT5-277 4 ft. T5 Bed Light providing Exam, Reading and 48-15/16" 8-15/16" 5-1/2" 30
Ambient lighting functions, (4) F28 T5 (Med. Bipin)
(1243.1mm)
(227.3mm) (139.7mm)
ECT8-277 4 ft. T8 Bed Light providing Exam, Reading and 50-7/8" 8-15/16" 5-1/2" 35
Ambient lighting functions, (4) F32 T8 (Med. Bipin)
(1292.2mm)
(227.3mm) (139.7mm)
347 Volt
ECT8-347 4 ft. T8 Bed Light providing Exam, Reading and 50-7/8" 8-15/16" 5-1/2" 35
Ambient lighting functions, (4) F32 T8 (Med. Bipin)
(1292.2mm)
(227.3mm) (139.7mm)
AVAILABLE FINISHES1 (must add as suffix: e.g. "-SWH" for Soft White)
SWH2Soft White
TPE Taupe
AL Aluminum
ALM Almond
CC3Custom Color
1 All standard finishes have an antimicrobial additive to inhibit the growth of microbes.
2 Soft White is the standard finish.
3 Customer needs to provide a color chip to match.
OPTIONAL SWITCHING (Add as suffix)
HDS 4-position pull cord switch for sequential control of ambient and
reading compartments (120v only)
LS Less switch (remote switching by others)
LVC4Low Voltage Controller for use with remotely located bed control system or
pillow switch (by others). Can be field wired for either separate or sequential
control of ambient and reading compartments.
4 Not available with EM1 option.
OPTIONAL EQUIPMENT (Add as suffix)
EM15Single lamp emergency ballast
NL5LED night/chart light w/ dual 3-position rocker switches (120v and 277v)
NL-W5LED night/chart light (remote switch by others), (120v and 277v)
SBF Slow blow fuse
BSS5Bed shut-off switch (120v and 277v)
PC Replacement 6' plastic pull cord (non-latex)
5 Not available for 347v applications.
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
30 3000K lamp substituted for standard 3500K lamp
41 4100K lamp substituted for standard 3500K lamp
Catalog
Number
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
Description
Dimensions
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
08/06/2012 6
Horizon
Patient Bed Light
LED
HZN SERIES
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
EXTRUDED ALUMINUM PATIENT BED LIGHT
(11, 01, 10 Lamp Configurations)
HZN4L351 4 foot LED bed light 50-5/16" 8-1/8" 5-1/4"
Available in either 120 or 277volts.
Pull switches not available with 277volt models.
347volt not available
3500K
AVAILABLE FINISHES
/SWH Soft White
/TP Taupe
/AL Aluminum
/ALM Almond
/CC1Custom Color
1 Customer needs to provide a color chip to match.
OPTIONAL (Add as suffix)
/HDS
and direct lamp compartments (120v only) (can not be used with LVC)
/LVC Low voltage controller (can not be used with HDS)
/NL LED night light
/SBF Slow blow fuse
/PC Replacement 6' plastic pull cord (non-Latex)
The LVC option is for use with remotely located bed control system or pillow switch (supplied by others).
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
NEW PRODUCT
4-position pull chain switch for sequential control of indirect
Dimensions
Description
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
7 08/06/2012
Horizon
Patient Bed Light
T8/T5/T5HO Fluorescent
HZN SERIES
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
EXTRUDED ALUMINUM PATIENT BED LIGHT
(11, 22, 12, 21 Lamp Configurations)
HZN2T8 2 foot F17 T8 lamped bed light 26-5/16" 8-1/8" 5-1/4" 13.5 lbs.
HZN2T5 2 foot F14 T5 lamped bed light 24-3/4" 8-1/8" 5-1/4"
HZN2T5HO 2 foot F24 T5HO lamped bed light 24-3/4" 8-1/8" 5-1/4"
HZN3T8 3 foot F25 T8 lamped bed light 38-5/16" 8-1/8" 5-1/4"
HZN3T5 3 foot F21 T5 lamped bed light 36-9/16" 8-1/8" 5-1/4"
HZN3T5HO 3 foot F39 T5HO lamped bed light 36-9/16" 8-1/8" 5-1/4"
HZN4T8 4 foot F32 T8 lamped bed light 50-5/16" 8-1/8" 5-1/4" 27 lbs.
HZN4T5 4 foot F28 T5 lamped bed light 48-3/8" 8-1/8" 5-1/4"
HZN4T5HO 4 foot F54 T5HO lamped bed light 48-3/8" 8-1/8" 5-1/4"
Available in either 120 or 277volts.
Pull switches not available with 277volt models.
347volt available on HZN2T8, HZN3T8, HZN4T8 and HZN4T5HO.
Lamps included.
EXTRUDED ALUMINUM PATIENT BED LIGHT
(01, 02, 10, 20 Lamp Configurations)
HZN2T8 2 foot F17 T8 lamped bed light 26-5/16" 8-1/8" 5-1/4"
HZN2T5 2 foot F14 T5 lamped bed light 24-3/4" 8-1/8" 5-1/4"
HZN2T5HO 2 foot F24 T5HO lamped bed light 24-3/4" 8-1/8" 5-1/4"
HZN3T8 3 foot F25 T8 lamped bed light 38-5/16" 8-1/8" 5-1/4"
HZN3T5 3 foot F21 T5 lamped bed light 36-9/16" 8-1/8" 5-1/4"
HZN3T5HO 3 foot F39 T5HO lamped bed light 36-9/16" 8-1/8" 5-1/4"
HZN4T8 4 foot F32 T8 lamped bed light 50-5/16" 8-1/8" 5-1/4"
HZN4T5 4 foot F28 T5 lamped bed light 48-3/8" 8-1/8" 5-1/4"
HZN4T5HO 4 foot F54 T5HO lamped bed light 48-3/8" 8-1/8" 5-1/4"
Available in either 120 or 277volts.
Pull switches not available with 277volt models.
347volt available on HZN2T8, HZN3T8, HZN4T8 and HZN4T5HO.
Lamps included.
AVAILABLE FINISHES
/SWH Soft White
/TP Taupe
/AL Aluminum
/ALM Almond
/CC3Custom Color
3 Customer needs to provide a color chip to match.
OPTIONAL (Add as suffix)
/HDS
and direct lamp compartments (120v only) (can not be used with LVC)
/LVC Low voltage controller (4' model only) (can not be used with HDS)
/EM1 Single lamp emergency ballast (4' model only)
/NL LED night light (lamp included)
/SBF Slow blow fuse
/BSS Bed shut off switch (3' and 4' models only)
/PC Replacement 6' plastic pull cord (non-Latex)
/DIM1 (1) Dimming Ballast (for 01, 02, 10 and 20 lamp configurations)
/DIM2 (2) Dimming Ballasts (for 11, 22, 12 and 21 lamp configurations)
/RSP1 (1) Radio Suppressor (for 01, 02, 10 and 20 lamp configurations)
/RSP2 (2) Radio Suppressors (for 11, 22, 12 and 21 lamp configurations)
/30 3000K lamp substituted for standard 3500K lamp
/41 4100K lamp substituted for standard 3500K lamp
Pull switch not provided with DIM1 or DIM2 option.
DIM1 and DIM2 are not available with LVC option.
The LVC option is for use with remotely located bed control system or pillow switch (supplied by others).
LVC option not availble for 2' or 3' models or with EM1, DIM1 or DIM2 options.
RSP1 and RSP2 option is not available for 2' models.
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
4-position pull chain switch for sequential control of indirect
Dimensions
3500K NAME BRAND LAMP INCLUDED
Description
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
08/06/2012 8
CareWell
Assisted Living Patient Bed Light
T8 Fluorescent
ALBT Series
Catalog Shpg Cont. Dist.
Number L H D Wt. Price Price
ALBT1 - T8 4 ft bed light (Style T1) 50-5/8" 4-3/4" 6-3/16"
ALBT2 - T8 4 ft bed light (Style T2) 50-5/8" 4-3/4" 6-3/16"
3500K Lamps included.
VOLTAGES
/120 120 Volt
/277 277 Volt
/347 347 Volt
AVAILABLE FINISHES
/SWH Soft White Painted
/CHT Chestnut Wood Stain
/WLT Walnut Wood Stain
/CC1Custom Color Painted
1 Customer needs to provide a color chip to match.
OPTIONAL (Add as suffix)
/HDS2
and direct lamp compartments (120v only)
/EM1 Single lamp emergency ballast (120v and 277v only)
/NL LED night light (lamp included)
/SBF Slow blow fuse
/LPL Acrylic linear prism lens (nom 0.125" thick)
/PC Replacement 6' plastic pull cord (non-Latex)
/30 3000K lamp substituted for standard 3500K lamp
/41 4100K lamp substituted for standard 3500K lamp
2 Pull chain is located in the middle of the fixture.
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
4-position pull chain switch for sequential control of indirect
3500K NAME BRAND LAMPS INCLUDED
NEW PRODUCT
Dimensions
Description
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
9 08/06/2012
IMPRESSIONS
Patient Bed Light
T8/T5/T5HO Fluorescent
IB SERIES
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
FOR T8 LAMPS
IB5217 28¾" 3¾" 9½" 24
IB5317 28¾" 3¾" 9½" 24
IB5517 28¾" 3¾" 9½" 24
IB5417 28¾" 3¾" 9½" 24
IB5225 40¾" 3¾" 9½" 48
IB5325 40¾" 3¾" 9½" 48
IB5525 40¾" 3¾" 9½" 48
IB5425 40¾" 3¾" 9½" 48
IB5232 52¾" 3¾" 9½" 54
IB5332 52¾" 3¾" 9½" 54
IB5532 52¾" 3¾" 9½" 54
IB5432 52¾" 3¾" 9½" 54
277Volt Available Below Lamps Included
FOR BI-AXIAL COMPACT FLUORESCENT LAMPS
IB6440 52¾" 3¾" 9½" 47
277Volt Available Below Lamps Included
AVAILABLE FINISHES1 (must add as suffix: e.g. "-SWH" for Soft White)
/WHG White Glossy
/SWH Soft White
/TPE Taupe
/AL Aluminum
/ALM Almond
CC3Custom Color
1 All standard finishes have an antimicrobial additive to inhibit the growth of microbes.
2 Customer needs to provide a color chip to match.
OPTIONAL SWITCHING (Add as suffix)
/HDS
/LESS SWITCH Less switch for use with Remotely Located Low Voltage
Controller (supplied by others)
/LVC
OPTIONAL EQUIPMENT (Add as suffix)
/277V 277 Volt Ballast (Pull Chain Switch not provided)
/CO-W White Grounded Convenience Outlet (120V only)
/NL LED night light
/NL4 F4T Fluorescent Night Light (120V only) (lamp not included)
/RSP (2) Radio Suppressors
/SLO-BLO (2) GMF slow-blow fuses and fuse holders
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp
/41 4100K lamp substituted for standard 3500K lamp
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
Low Voltage Controller installed in IB5232 or IB6440 for use with
Remotely Located Bed Control System (supplied by others, no
pull chain switch provided)
Bedlight for (4) FT40W/2G11/RS lamps
4-Position Pull Chain Switch for Sequential Control of Uplight and
Downlight (down on, up on, up & down on and off--120V only)
Bedlight for 1/F17T8 lamp up, 1 down
Bedlight for 2/F17T8 lamps up, 2 down
Bedlight for 1/F17T8 lamp up, 2 down
Bedlight for 2/F17T8 lamps up, 1 down
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
NEW LAMP CONFIGURATIONS NOW AVAILABLE
Bedlight for 1/F25T8 lamp up, 1 down
Bedlight for 1/F25T8 lamps up, 2 down
Bedlight for 2/F25T8 lamps up, 1 down
Bedlight for 2/F25T8 lamps up, 2 down
Bedlight for 1/F32T8 lamp up, 1 down
Bedlight for 1/F32T8 lamp up, 2 down
Bedlight for 2/F32T8 lamps up, 1 down
Bedlight for 2/F32T8 lamps up, 2 down
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
Dimensions
Description
08/06/2012 10
Patient Bed Light
T8 Fluorescent
2886 SERIES
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
EXTRUDED ALUMINUM
(11, 22, 12, 21 Lamp Configurations)
28863T5 3 foot T5 lamped bed light 36½" 7½" 7" 25.5
28863T8 3 foot T8 lamped bed light 36½" 7½" 7" 25.5
28864T5 4 foot T5 lamped bed light 48½" 7½" 7" 28
28864T8 4 foot T8 lamped bed light 48½" 7½" 7" 28
AVAILABLE FINISHES
/SWH Soft White
/BEIGE Beige
/CC1Custom Color
1 Customer needs to provide a color chip to match.
OPTIONAL EQUIPMENT (Add as suffix)
/LS Less switch for use with Remotely Located Low Voltage
Controller (supplied by others)
/PCL3Pull cord switch, left end (as facing fixture), (120V only)
/PCR3Pull cord switch, right end (as facing fixture), (120V only)
/HDSL 4-Position Pull Cord Switch for Sequential Control
of Direct and Indirect Lamp Compartments, left end
(as facing fixture), (120V only)
/HDSR 4-Position Pull Cord Switch for Sequential Control
of Direct and Indirect Lamp Compartments, right end
(as facing fixture), (120V only)
/LVC Low Voltage Controller (4' models only)
(supplied by others, no pull chain switch provided)
/277V (2) 277 Volt Ballasts (Pull Chain Switch not provided)
/347V 347 Volt Ballasts (not available for T5 models)
/CO-W White Grounded Convenience Outlet (120V only)
/NL5 5W T5 CFL Night Light (lamp not included)
/NL5SW45W T5 CFL Night Light with rocker switch control (lamp not included)
/NL5SW345W T5 CFL Night Light with 3-way rocker switch control
(for use with additional wall control - supplied by others)
(lamp not included)
/SBF Slow Blow Fuse
3 Controls the direct lamp compartment only.
/30 3000K lamp substituted for standard 3500K lamp
/41 4100K lamp substituted for standard 3500K lamp
REPLACEMENT EQUIPMENT
A863 3' Prismatic Acrylic Diffuser
A864 4' Prismatic Acrylic Diffuser
3500K NAME BRAND LAMP INCLUDED
2886
4 The rocker switch for the night light is positioned on the right end of the
luminaire (as facing luminaire) or the opposite end of the luminaire from the
location of the pull cord switch.
277 and 347 Volt Available Below Lamps Included
Dimensions
Description
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color
temperature is 3500K
11 08/06/2012
Renaissance
Patient Bed Light
T8 Fluorescent
9618 SERIES
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
BEDLIGHT
9618-411 48½" 7¾" 5½" 23
9618-412 48½" 7¾" 5½" 23
9618-421 48½" 7¾" 5½" 23
9618-422 48½" 7¾" 5½" 23
277Volt Available Below Lamps Included
OPTIONAL EQUIPMENT (Add as suffix)
/277V (2) 277 Volt Ballasts (Pull Chain Switch not provided)
/CO-W White Grounded Convenience Outlet (120V only)
/HDS 4 Position Pull Chain Switch (120V only)
/IV Bushing for I.V. arm
/LESS SWITCH Fixture shipped less switch
/NL4 F4T5 Fluorescent night light (120V only) (lamp not included)
/RSP (2) Radio Suppressors
/SLO-BLO (2) GMF slow-blow fuses and fuse holders
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp
/41 4100K lamp substituted for standard 3500K lamp
REPLACEMENT EQUIPMENT
O984
4' Opal Acrylic Diffuser
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
Note: Low Voltage controller not available on 9818 Series
Bed Light for 2/F32T8 lamps,
(1) Up and (1) Down
Bed Light for 3/F32T8 lamps,
(1) Up and (2) Down
Bed Light for 3/F32T8 lamps,
(2) Up and (1) Down
Bed Light for 4/F32T8 lamps,
(2) Up and (2) Down
Dimensions
Description
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
08/06/2012 12
Multi-Med
2x4 Recessed Multi-Function Patient Room Luminaire
LTT Fluorescent
ME640N Series
Catalog Cont. Dist.
Number L W D Price Price
ME640N w/PBL 47-13/16" 23-3/4" 5-9/16"
ME640N w/ACR 47-13/16" 23-3/4" 5-9/16"
ME640N w/PCL 47-13/16" 23-3/4" 5-9/16"
ME640NLG w/PBL 47-13/16" 23-3/4" 6-3/8"
ME640NLG w/PPBL 47-13/16" 23-3/4" 6-3/8"
ME640NLG w/PCL 47-13/16" 23-3/4" 6-3/8"
ALTERNATE VOLTAGES
120 120 volts
277 277 volts
347 347 volts
OPTIONS
4EX14 exam section lamps
SBF Slow blow fuse
LVC Low voltage controller for use with remotely located bed control
PSC Pillow switch control (control with cord and wall plate)
NL LED night light
NL13 Night light, 13W compact fluorescent (switched at wall) (lamp not included)
RFI2(3) radio frequency interference suppressors and RFI grid on lens
CACR3Clear acrylic lens (positioned below the exam section's louver/lens)
FK24A Flange kit
TIMER Timer wall switch for exam light (1-15 minutes, 120v only)
1The PBL and PPBL shielding options for a (4) lamp exam compartment have 24 cells.
2Available for ME640NLG model only.
3Not required for the ME640NLG model.
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
55 lbs.
50 lbs.
50 lbs.
50 lbs.
55 lbs.
55 lbs.
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
Description
Wt.
3500K NAME BRAND LAMP INCLUDED
ANTIMICROBIAL FINISH STANDARD
Dimensions
Shpg
Multi-function luminaire with full door and 18 cell
painted parabolic louver w/ transluscent acrylic
overlay for exam section shielding, (6) F40 twin-
tube T5 fluorescent lamps (2G11 base)
Multi-function luminaire with full door and
specular paracube louver (½" x ½" cells)
w/transluscent acrylic overlay for exam section
shielding, (6) F40 twin-tube T5 fluorescent lamps
(2G11 base)
Multi-function luminaire with 18 cell semi-
specular parabolic louver w/ transluscent acrylic
overlay for exam section shielding, (6) F40 twin-
tube T5 fluorescent lamps (2G11 base)
Multi-function luminaire with prismatic acrylic
lens (nom. 0.125" thick) for exam section
shielding, (6) F40 twin-tube T5 fluorescent lamps
(2G11 base)
Multi-function luminaire with specular paracube
louver (½" x ½" cells) w/ transluscent acrylic
overlay for exam section shielding, (6) F40 twin-
tube T5 fluorescent lamps (2G11 base)
Multi-function luminaire with full door and 18 cell
semi-specular parabolic louver w/ transluscent
acrylic overlay for exam section shielding, (6)
F40 twin-tube T5 fluorescent lamps (2G11 base)
13 08/06/2012
Multi-Med
2x4 Recessed Exam/Ambient Patient Luminaire
Twin-Tube T5 Fluorescent
ME540N Series
Catalog Cont. Dist.
Number L W D Price Price
ME540N w/PBL 47-13/16" 23-3/4" 5-9/16"
ME540N w/ACR 47-13/16" 23-3/4" 5-9/16"
ME540N w/PCL 47-13/16" 23-3/4" 5-9/16"
ME540NLG w/PBL 47-13/16" 23-3/4" 6-3/8"
ME540NLG w/PPBL 47-13/16" 23-3/4" 6-3/8"
ME540NLG w/ACR 47-13/16" 23-3/4" 6-3/8"
ME540NLG w/PCL 47-13/16" 23-3/4" 6-3/8"
ALTERNATE VOLTAGES
120 120 volts
277 277 volts
347 347 volts
OPTIONS
4EX14 exam section lamps
SBF Slow blow fuse
LVC Low voltage controller for use with remotely located bed control
NL LED night light
NL13 Night light, 13W compact fluorescent (switched at wall) (lamp not included)
RFI2(3) radio frequency interference suppressors and RFI grid on lens
CACR3Clear acrylic lens (positioned below the exam section's louver/lens)
FK24A Flange kit
TIMER Timer wall switch for exam light (1-15 minutes, 120v only)
1The PBL and PPBL shielding options for a (4) lamp exam compartment have 24 cells.
2Available for ME650NLG model only.
3Not required for the ME540NLG model.
55 lbs.
55 lbs.
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
55 lbs.
55 lbs.
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
Description
Wt.
with full door and 18 cell painted parabolic louver
w/ transluscent acrylic overlay for exam section
shielding, (5) F40 twin-tube T5 fluorescent lamps
(2G11 base)
Exam/Ambient luminaire with full door and
prismatic acrylic lens (nom. 0.125" thick) for
exam section shielding, (5) F40 twin-tube T5
fluorescent lamps (2G11 base)
Exam/Ambient luminaire with full door and
specular paracube louver (½" x ½" cells)
w/transluscent acrylic overlay for exam section
shielding, (5) F40 twin-tube T5 fluorescent lamps
(2G11 base)
Exam/Ambient luminaire with 18 cell semi-
specular parabolic louver w/ transluscent acrylic
overlay for exam section shielding, (5) F40 twin-
tube T5 fluorescent lamps (2G11 base)
Exam/Ambient luminaire with prismatic acrylic
lens (nom. 0.125" thick) for exam section
shielding, (5) F40 twin-tube T5 fluorescent lamps
(2G11 base)
Exam/Ambient luminaire with specular paracube
louver (½" x ½" cells) w/ transluscent acrylic
overlay for exam section shielding, (5) F40 twin-
tube T5 fluorescent lamps (2G11 base)
Exam/Ambient luminaire with full door and 18
cell semi-specular parabolic louver w/
transluscent acrylic overlay for exam section
shielding, (5) F40 twin-tube T5 fluorescent lamps
(2G11 base)
50 lbs.
50 lbs.
50 lbs.
3500K NAME BRAND LAMP INCLUDED
ANTIMICROBIAL FINISH STANDARD
Dimensions
Shpg
08/06/2012 14
Multi-Med
2x2 Recessed Patient Exam Luminaire
Twin-Tube T5 Fluorescent
ME340N/440N Series
Catalog Cont. Dist.
Number L W D Price Price
ME340NLG w/PBL 23-3/4" 23-3/4" 5-9/16"
ME340NLG w/ACR 23-3/4" 23-3/4" 5-9/16"
ME340NLG w/PCL 23-3/4" 23-3/4" 5-9/16"
ME440NLG w/PBL 23-3/4" 23-3/4" 6-3/8"
ME440NLG w/PPBL 23-3/4" 23-3/4" 6-3/8"
ME440NLG w/ACR 23-3/4" 23-3/4" 6-3/8"
ALTERNATE VOLTAGES
120 120 volts
277 277 volts
347 347 volts
SBF Slow blow fuse
NL LED night light
NL13 Night light, 13W compact fluorescent (switched at wall) (lamp not included)
RFI (3) radio frequency interference suppressors and RFI grid on lens
CACR1Clear acrylic lens (positioned below the exam section's louver/lens)
FK22A Flange kit
TIMER Timer wall switch for exam light (1-15 minutes, 120v only)
1If selecting the RFI option, the CACR option is included.
22.5 lbs.
22.5 lbs.
22.5 lbs.
24 lbs.
24 lbs.
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
Description
Wt.
3500K NAME BRAND LAMP INCLUDED
ANTIMICROBIAL FINISH STANDARD
Dimensions
Shpg
Exam luminaire with full door and 24 cell painted
parabolic louver w/ transluscent acrylic overlay,
(5) F40 twin-tube T5 fluorescent lamps (2G11
base)
Exam luminaire with full door and prismatic
acrylic lens (nom. 0.125" thick), (5) F40 twin-tube
T5 fluorescent lamps (2G11 base)
Exam luminaire with full door and 18 cell semi-
specular parabolic louver w/ transluscent acrylic
overlay, (5) F40 twin-tube T5 fluorescent lamps
(2G11 base)
Exam luminaire with full door and prismatic
acrylic lens (nom. 0.125" thick), (5) F40 twin-tube
T5 fluorescent lamps (2G11 base)
Exam luminaire with full door and specular
paracube louver (½" x ½" cells) w/ transluscent
acrylic overlay, (5) F40 twin-tube T5 fluorescent
lamps (2G11 base)
Exam luminaire with full door and 24 cell semi-
specular parabolic louver w/ transluscent acrylic
overlay, (5) F40 twin-tube T5 fluorescent lamps
(2G11 base)
24 lbs.
15 08/06/2012
Multi-Med
2x2 Recessed Ambient Patient Luminaire
Twin-Tube T5 Fluorescent
ME240N Series
Catalog Cont. Dist.
Number L W D Price Price
ME240N Ambient luminaire 23-3/4" 23-3/4" 5-9/16"
(2) F40 LTT T5 Fluorescent (2G11 base)
ME240NLG Ambient luminaire with full door 23-3/4" 23-3/4" 6-3/8"
(2) F40 LTT T5 Fluorescent (2G11 base)
ALTERNATE VOLTAGES
120 120 volts
277 277 volts
347 347 volts
OPTIONS
SBF Slow blow fuse
LVC Low voltage controller for use with remotely located bed control
NL LED night light
NL13 Night light, 13W compact fluorescent (lamp not included)
RFI1(3) radio frequency interference suppressors and RFI grid on lens
FK22A Flange kit
Multi-Med
2x2 Recessed Ambient/Reading Patient Luminaire
Twin-Tube T5 Fluorescent
ME340ARN Series
Catalog Cont. Dist.
Number L W D Price Price
ME340ARN Ambient and reading luminaire 47-13/16" 23-3/4" 5-9/16"
(3) F40 LTT T5 lamps (2G11 base)
ME340ARNLG Ambient and reading luminaire with full door 47-13/16" 23-3/4" 6-3/8"
(3) F50 LTT T5 lamps (2G11 base)
ALTERNATE VOLTAGES
120 120 volts
277 277 volts
347 347 volts
OPTIONS
SBF Slow blow fuse
LVC Low voltage controller for use with remotely located bed control
RFI1(3) radio frequency interference suppressors and RFI grid on lens
FK22A Flange kit
1Available for ME340ARNLG model only.
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
Description
Wt.
3500K NAME BRAND LAMP INCLUDED
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
Description
Wt.
23.5 lbs.
17.5 lbs.
ANTIMICROBIAL FINISH STANDARD
22.5 lbs.
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
3500K NAME BRAND LAMP INCLUDED
ANTIMICROBIAL FINISH STANDARD
Dimensions
Shpg
Dimensions
Shpg
27 lbs.
08/06/2012 16
DuoCare
Recessed Exam/Ambient Light
T5/T5HO Fluorescent ANTIMICROBIAL FINISH STANDARD
DCEA Series
"Individual, stand alone" fixtures (120 or 277V)
Catalog Shpg Cont. Dist.
Number Description L W D Wt. Price Price
DCEA-T5-SA
47 3/4"
(49 1/2")
7 5/8"
(9 3/8")
5 1/8"
(5 1/8")
16.5
DCEA-T5HO-SA 16.5
Notes:
 DuoCare is not available in 347V.
"Master" fixtures (120 or 277V)
Catalog Shpg Cont. Dist.
Number Description L W D Wt. Price Price
47 3/4"
(49 1/2")
7 5/8"
(9 3/8")
5 1/8"
(5 1/8")
16.5
16.5
DCEA-T5-M12 16.5
DCEA-T5-M15 16.5
DCEA-T5HO-M6 16.5
DCEA-T5HO-M9 16.5
DCEA-T5HO-M12 16.5
DCEA-T5HO-M15 16.5
"Satellite" fixtures (120 or 277V)
Catalog Shpg Cont. Dist.
Number Description L W D Wt. Price Price
DCEA-T5-S
47 3/4"
(49 1/2")
7 5/8"
(9 3/8")
4 7/8"
(4 7/8")
14.5
DCEA-T5HO-S 14.5
Notes:
 A prewired, interconnect cable is supplied with the "master" fixture.
 DuoCare is not available in 347V.
G Grid Mounting
F Flange Mounting
DOOR FRAME (Add as suffix)
FR1
FR2
FR3
OPTIONS (Add as suffix)
LVC Low voltage controller (not necessary for "satellite" fixtures)
EM1 Emergency ballast (not necessary for "satellite" fixtures)
TIMER
SBF Slow blow fuse
EQC Earthquake clips
Notes:
 The emergency ballast operates the ambient lighting compartment in the master fixture.
3500K LAMPS INCLUDED
Dimensions
Note: Dimensions shown in ( ) are
for flange version.
The "individual (stand alone)" version of the DuoCare fixture is suitable for applications where a single
fixture is required or for situations where a non-"master/satellite" solution is preferred.
Dimensions
Exam/Ambient "master" fixture with 9' interconnect whip
and (2) F28 T5 lamps (Med. Bi-pin)
Exam/Ambient "master" fixture with 12' interconnect
whip and (2) F28 T5 lamps (Med. Bi-pin)
Exam/Ambient "master" fixture with 15' interconnect
whip and (2) F28 T5 lamps (Med. Bi-pin)
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
Clear anodized extruded aluminum frame with full-length,
stainless steel hinge and stainless steel screws
Painted extruded aluminum frame with full-length, stainless steel
hinge and stainless steel screws
Exam/Ambient "master" fixture with 12' interconnect
whip and (2) F54 T5HO lamps (Med. Bi-pin)
Exam/Ambient "master" fixture with 15' interconnect
whip and (2) F54 T5HO lamps (Med. Bi-pin)
Exam/Ambient "satellite" fixture, (2) F28 T5 lamps
(Med. Bi-pin)
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
Timer wall switch for exam light (1-15 minutes, 120 volts only)
The LVC is wired to control the ambient compartment only. Consult factory if the exam compartment is
to be operated with LVC also.
Exam/Ambient "individual" fixture, (2) F28 T5 lamps
(Med. Bi-pin)
Dimensions
Exam/Ambient "individual" fixture, (2) F54 T5HO lamps
(Med. Bi-pin)
Note: Dimensions shown in ( ) are for
flange version.
DuoCare fixtures are to be used in pairs for patient bed applications. A "master" and "satellite" fixture
are required. The "master" fixture is wired with the ballasts with a supplied interconnect cable for
connecting the "satellite" fixture.
DCEA-T5-M6
Exam/Ambient "master" fixture with 6' interconnect whip
and (2) F28 T5 lamps (Med. Bi-pin)
Exam/Ambient "satellite" fixture, (2) F54 T5HO lamps
(Med. Bi-pin)
Note: Dimensions shown in ( ) are
for flange version.
Painted steel frame with full-length, stainless steel hinge and
stainless steel screws
Exam/Ambient "master" fixture with 6' interconnect whip
and (2) F54 T5HO lamps (Med. Bi-pin)
Exam/Ambient "master" fixture with 9' interconnect whip
and (2) F54 T5HO lamps (Med. Bi-pin)
DCEA-T5-M9
17 08/06/2012
DuoCare
Recessed Exam Light
T5/T5HO Fluorescent ANTIMICROBIAL FINISH STANDARD
DCE Series
"Individual, stand alone" fixtures (120 or 277V)
Catalog Shpg Cont. Dist.
Number Description L W D Wt. Price Price
DCE-T5-SA 12
DCE-T5HO-SA 12
Notes:

DuoCare is not available in 347V.
"Master" fixtures (120 or 277V)
Catalog Shpg Cont. Dist.
Number Description L W D Wt. Price Price
47¾"
(49½")
5 5/8"
(7 5/8")
4 7/8"
(4 7/8")
12
12
DCE-T5-M12 12
DCE-T5-M15 12
DCE-T5HO-M6 12
DCE-T5HO-M9 12
DCE-T5HO-M12 12
DCE-T5HO-M15 12
"Satellite" fixtures (120 or 277V)
Catalog Shpg Cont. Dist.
Number Description L W D Wt. Price Price
DCE-T5-S 10
DCE-T5HO-S 10
Notes:
 A prewired, interconnect cable is supplied with the "master" fixture.
 DuoCare™ is not available in 347V.
G Grid Mounting
F Flange Mounting
DOOR FRAME (Add as suffix)
FR1
FR2
FR3
OPTIONS (Add as suffix)
EM1 Emergency ballast (not necessary for "satellite" fixtures)
TIMER
SBF Slow blow fuse
EQC Earthquake clips
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
3500K LAMP INCLUDED
Dimensions
Dimensions
The "individual (stand alone)" version of the DuoCare fixture is suitable for applications where a single
fixture is required or for situations where a non-"master/satellite" solution is preferred.
Dimensions
Clear anodized extruded aluminum frame with full-length, stainless
steel hinge and stainless steel screws
7 5/8"
(9 3/8")
4 7/8"
(4 7/8")
Exam "satellite" fixture, (1) F54 T5HO lamp (Med. Bi-pin)
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
Exam "individual" fixture, (1) F28 T5 lamp (Med. Bi-pin)
47¾"
(49½")
7 5/8"
(9 3/8")
4 7/8"
(4 7/8")
Exam "individual" fixture, (1) F54 T5HO lamp (Med. Bi-pin)
Note: Dimensions shown in ( ) are
for flange version.
DuoCare fixtures are to be used in pairs for patient bed applications. A "master" and "satellite" fixture are
required. The "master" fixture is wired with the ballasts with a supplied interconnect cable for connecting
the "satellite" fixture.
DCE-T5-M6
Exam "master" fixture with 6' interconnect whip and (1) F28 T5
lamp (Med. Bi-pin)
Exam "master" fixture with 9' interconnect whip and (1) F54
T5HO lamp (Med. Bi-pin)
DCE-T5-M9
Exam "master" fixture with 9' interconnect whip and (1) F28 T5
lamp (Med. Bi-pin)
Note: Dimensions shown in ( ) are
for flange version.
Exam "master" fixture with 12' interconnect whip and (1) F28
T5 lamp (Med. Bi-pin)
Exam "satellite" fixture, (1) F28 T5 lamp (Med. Bi-pin)
47¾"
(49½")
Timer wall switch for exam light (1-15 minutes, 120 volts only)
Note: Dimensions shown in ( ) are
for flange version.
Painted steel frame with full-length, stainless steel hinge and
stainless steel screws
Painted extruded aluminum frame with full-length, stainless steel
hinge and stainless steel screws
Exam "master" fixture with 12' interconnect whip and (1) F54
T5HO lamp (Med. Bi-pin)
Exam "master" fixture with 15' interconnect whip and (1) F54
T5HO lamp (Med. Bi-pin)
Exam "master" fixture with 15' interconnect whip and (1) F28
T5 lamp (Med. Bi-pin)
Exam "master" fixture with 6' interconnect whip and (1) F54
T5HO lamp (Med. Bi-pin)
08/06/2012 18
SoftLook
Semi-Recessed Luminaire
LED
SL1Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
SoftLook
SL118 24 white LED's 18" 3 1/2" 3 3/8"
SL124 36 white LED's 24" 3 1/2" 3 3/8"
SL130 48 white LED's 30" 3 1/2" 3 3/8"
SL136 60 white LED's 36" 3 1/2" 3 3/8"
301 3000K
120
277
/SWH Soft White
/TPE Taupe
/AL Aluminum
/CC Custom Color
NEW PRODUCT
Dimensions
Description
LED Color Temperature
Voltage
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
AVAILABLE FINISHES (Must add as suffix--Consult factory for delivery on extra
cost finishes)
19 08/06/2012
SurgiCare
2x4 Sealed Supplemental Surgical Luminaire
T8 Fluorescent (F32 T8)
SSTR24 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
6-lamp
SSTRG24-6-T8-120-3 (3 circuits) 48 lbs.
SSTRG24-6-T8-120-2 (2 circuits)
SSTRG24-6-T8-120-1 (1 circuit)
4-lamp
SSTRG24-4-T8-120-2 (2 circuits) 48 lbs.
SSTRG24-4-T8-120-1 (1 circuit)
3-lamp
SSTRG24-3-T8-120-2 (2 circuits) 48 lbs.
SSTRG24-3-T8-120-1 (1 circuit)
ADDITIONAL T8 LAMP CONFIGURATIONS
Qty. Description
21 (3) F32 T8 (Med. Bi-pin), (2 white/1 green)
22 (4) F32 T8 (Med. Bi-pin), (2 white/2 green)
33 (6) F32 T8 (Med. Bi-pin), (3 white/3 green)
42 (6) F32 T8 (Med. Bi-pin), (4 white/2 green)
VOLTAGE
120 120 volts
277 277 volts
120D 120 volt dimming (0-10v control)
277D 277 volt dimming (0-10v control)
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP
Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (includes additional EMI suppressor)
EM212-lamp emergency ballast battery back-up (90 min.), (includes additional EMI suppressor)
GEN11,2,4 1-lamp, 5 min. interim ballast battery back-up (high lumen), (includes additional EMI suppressor)
GEN21,2,4 2-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (includes add'nl. EMI supp.)
GEN31,2,3,4
3-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (includes add'nl EMI supp.)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
2Available for non-dimming models.
3Available for 3- or 6-lamp models.
4Due to ratings for GEN emergency ballasts, ballast are mounted in separate enclosure on back of fixture.
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
IP65 RATED
MIL STD 461F
ANTIMICROBIALFINISH
08/06/2012 20
SurgiCare
2x4 Sealed Supplemental Surgical Luminaire
T5 Fluorescent (F28 T5)
SSTR24 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
6-lamp
SSTRG24-6-T5-120-3 (3 circuits) 48 lbs.
SSTRG24-6-T5-120-2 (2 circuits)
SSTRG24-6-T5-120-1 (1 circuit)
4-lamp
SSTRG24-4-T5-120-2 (2 circuits) 48 lbs.
SSTRG24-4-T5-120-1 (1 circuit)
3-lamp
SSTRG24-3-T5-120-2 (2 circuits) 48 lbs.
SSTRG24-3-T5-120-1 (1 circuit)
ADDITIONAL T5 LAMP CONFIGURATIONS
Qty. Description
21 (3) F28 T5 (Mini Bi-pin), (2 white/1 green)
22 (4) F28 T5 (Mini Bi-pin), (2 white/2 green)
42 (6) F28 T5 (Mini Bi-pin), (4 white/2 green)
VOLTAGE
120 120 volts
277 277 volts
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (includes additional EMI suppressor)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
IP65 RATED
MIL STD 461F
ANTIMICROBIAL FINISH
21 08/06/2012
SurgiCare
2x4 Sealed Supplemental Surgical Luminaire
T5HO Fluorescent (F54 T5HO)
SSTR24 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
4-lamp
SSTRG24-4-T5HO-120-2 (2 circuits) 48 lbs.
SSTRG24-4-T5HO-120-1 (1 circuit)
3-lamp
SSTRG24-3-T5HO-120-2 (2 circuits) 48 lbs.
SSTRG24-3-T5HO-120-1 (1 circuit)
ADDITIONAL T5HO LAMP CONFIGURATIONS
Qty. Description
21 (3) F54 T5HO (Mini Bi-pin), (2 white/1 green)
22 (4) F54 T5HO (Mini Bi-pin), (2 white/2 green)
VOLTAGE
120 120 volts
277 277 volts
120D 120 volt dimming (0-10v control)
277D 277 volt dimming (0-10v control)
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
IP65 RATED
MIL STD 461F
ANTIMICROBIAL FINISH
08/06/2012 22
SurgiCare
2x2 Sealed Supplemental Surgical Luminaire
T8 Fluorescent (F17 T8)
SSTR22 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
6-lamp
SSTRG22-6-T8-120-3 (3 circuits)
SSTRG22-6-T8-120-2 (2 circuits)
SSTRG22-6-T8-120-1 (1 circuit)
4-lamp
SSTRG22-4-T8-120-2 (2 circuits)
SSTRG22-4-T8-120-1 (1 circuit)
3-lamp
SSTRG22-3-T8-120-2 (2 circuits)
SSTRG22-3-T8-120-1 (1 circuit)
ADDITIONAL T8 LAMP CONFIGURATIONS
Qty. Description
21 (3) F17 T8 (Med. Bi-pin), (2 white/1 green)
22 (4) F17 T8 (Med. Bi-pin), (2 white/2 green)
33 (6) F17 T8 (Med. Bi-pin), (3 white/3 green)
42 (6) F17 T8 (Med. Bi-pin), (4 white/2 green)
VOLTAGE
120 120 volts
277 277 volts
120D1120 volt dimming (0-10v control)
277D1277 volt dimming (0-10v control)
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP
Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM12,3 1-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
GEN13,4,5 1-lamp, 5 min. interim ballast battery back-up (high lumen), (Includes additional EMI suppressor)
GEN23,4,5
2-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (Includes add'nl EMI supp.)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1Dimming not available for "42" lamp configuration.
2Available for 3-lamp (1 circuit) models only.
3A dedicated EMI suppressor provided for emergency ballasts.
4Available for non-dimming models only.
5Due to ratings for GEN emergency ballasts, ballast are mounted in separate enclosure on back of fixture.
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
IP65 RATED
MIL STD 461F
ANTIMICROBIAL FINISH
23 08/06/2012
SurgiCare
2x2 Sealed Supplemental Surgical Luminaire
T8U Fluorescent (FBO31 T8)
SSTR22 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
3-lamp
SSTRG22-3-T8U-120-2 (2 circuits)
SSTRG22-3-T8U-120-1 (1 circuit)
2-lamp
SSTRG22-2-T8U-120-1 (1 circuit)
VOLTAGE
120 120 volts
277 277 volts
120D 120 volt dimming (0-10v control)
277D 277 volt dimming (0-10v control)
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP
Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM11,2 1-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
GEN12,3,4 1-lamp, 5 min. interim ballast battery back-up (high lumen), (Includes additional EMI suppressor)
GEN22,3,4 2-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (Includes add'nl EMI supp.)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1Available for 2-lamp models.
2A dedicated EMI suppressor provided for emergency ballast.
3Available for non-dimming models.
4Due to ratings for GEN emergency ballasts, ballast are mounted in separate enclosure on back of fixture.
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
IP65 RATED
MIL STD 461F
ANTIMICROBIAL FINISH
08/06/2012 24
SurgiCare
2x2 Sealed Supplemental Surgical Luminaire
T5 Fluorescent (F14 T5)
SSTR22 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
6-lamp1SSTRG22-6-T5-120-2 (2 circuits)
SSTRG22-6-T5-120-1 (1 circuit)
4-lamp
SSTRG22-4-T5-120-2 (2 circuits)
SSTRG22-4-T5-120-1 (1 circuit)
3-lamp
SSTRG22-3-T5-120-1 (1 circuit)
VOLTAGE
120 120 volts
277 277 volts
120D2120 volt dimming (0-10v control)
277D2277 volt dimming (0-10v control)
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP
Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM
Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
SBF
Slow blow fuse (requires 1 per circuit)
TBC T-bar support clips
1Available with (2) 3-lamp ballasts.
2Available for 4-lamp models only.
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
IP65 RATED
MIL STD 461F
ANTIMICROBIAL FINISH
25 08/06/2012
SurgiCare
2x2 Sealed Supplemental Surgical Luminaire
40TT Fluorescent (F40 T5 LTT)
SSTR22 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
3-lamp
SSTRG22-3-40TT-120-2 (2 circuits)
SSTRG22-3-40TT-120-1 (1 circuit)
2-lamp
SSTRG22-2-40TT-120-2 (2 circuits)
SSTRG22-2-40TT-120-1 (1 circuit)
VOLTAGE
120 120 volts
277 277 volts
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP
Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM11,2 1-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
GEN12,3,4 1-lamp, 5 min. interim ballast battery back-up (high lumen), (Includes additional EMI suppressor)
GEN22,3,4 2-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (Includes add'nl EMI supp.)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1Available for 2-lamp models only.
2A dedicated EMI suppressor provided for emergency ballast.
3Available for non-dimming models only.
4Due to ratings for GEN emergency ballasts, ballast are mounted in separate enclosure on back of fixture.
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
IP65 RATED
MIL STD 461F
ANTIMICROBIAL FINISH
08/06/2012 26
SurgiCare
2x2 Sealed Supplemental Surgical Luminaire
T5HO Fluorescent (F24 T5HO)
SSTR22 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
4-lamp
SSTRG22-4-T5HO-120-2 (2 circuits)
SSTRG22-4-T5HO-120-1 (1 circuit)
3-lamp
SSTRG22-3-T5HO-120-2 (2 circuits)
SSTRG22-3-T5HO-120-1 (1 circuit)
ADDITIONAL T5HO LAMP CONFIGURATIONS
Qty. Description
21 (3) F24 T5HO (Mini. Bi-pin), (2 white/2 green)
22 (4) F24 T5HO (Mini. Bi-pin), (2 white/2 green)
VOLTAGE
120 120 volts
277 277 volts
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP
Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
SBF
Slow blow fuse (requires 1 per circuit)
TBC T-bar support clips
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
24"
(609.6mm)
23-3/4"
(603.3mm)
4-3/4"
(120.7mm)
IP65 RATED
MIL STD 461F
ANTIMICROBIAL FINISH
27 08/06/2012
SurgiCare
1x4 Sealed Supplemental Surgical Luminaire
T8 Fluorescent (F32 T8)
SSTR14 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
3-lamp
SSTRG14-3-T8-120-2 (2 circuits)
SSTRG14-3-T8-120-1 (1 circuit)
2-lamp
SSTRG14-2-T8-120-1 (1 circuit)
ADDITIONAL T8 LAMP CONFIGURATIONS
Qty. Description
21 (3) F32 T8 (Med. Bi-pin), (2 white/1 green)
VOLTAGE
120 120 volts
277 277 volts
120D 120 volt dimming (0-10v control)
277D 277 volt dimming (0-10v control)
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP
Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
EM212-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
GEN11,2,3 1-lamp, 5 min. interim ballast battery back-up (high lumen), (Includes additional EMI suppressor)
GEN21,2,3 2-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (Includes add'nl EMI supp.)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
2Available for non-dimming models.
3Due to ratings for GEN emergency ballasts, ballast are mounted in separate enclosure on back of fixture.
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
11-3/4"
(298.5mm)
6-5/16"
(160.3mm)
48"
(1219.2mm)
11-3/4"
(298.5mm)
6-5/16"
(160.3mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
IP65 RATED
MIL STD 461F
ANTIMICROBIAL FINISH
08/06/2012 28
SurgiCare
1x4 Sealed Supplemental Surgical Luminaire
T5 Fluorescent (F28 T5)
SSTR14 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
3-lamp
SSTRG14-3-T5-120-2 (2 circuits)
SSTRG14-3-T5-120-1 (1 circuit)
2-lamp
SSTRG14-2-T5-120-1 (1 circuits)
ADDITIONAL T5 LAMP CONFIGURATIONS
Qty. Description
21 (3) F28 T5 (Mini Bi-pin), (2 white/1 green)
VOLTAGE
120 120 volts
277 277 volts
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP
Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
11-3/4"
(298.5mm)
6-5/16"
(160.3mm)
48"
(1219.2mm)
11-3/4"
(298.5mm)
6-5/16"
(160.3mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
IP65 RATED
MIL STD 461F
ANTIMICROBIAL FINISH
29 08/06/2012
SurgiCare
1x4 Sealed Supplemental Surgical Luminaire
T5HO Fluorescent (F54 T5HO)
SSTR14 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
2-lamp
SSTRG14-2-T5HO-120-1 (1 circuit) 48 lbs.
VOLTAGE
120 120 volts
277 277 volts
120D 120 volt dimming (0-10v control)
277D 277 volt dimming (0-10v control)
DOOR FRAME MATERIALS
DST 18 ga. cold rolled steel
DAL Anodized extruded aluminum
DALP
Painted extruded aluminum
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
11-3/4"
(298.5mm)
6-5/16"
(160.3mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
IP65 RATED
MIL STD 461F
ANTIMICROBIAL FINISH
08/06/2012 30
SurgiCare
2x4 Supplemental Surgical Luminaire
T8 Fluorescent (F32 T8)
STR24 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
6-lamp
STRG24-6-T8-120-3 (3 circuits)
STRG24-6-T8-120-2 (2 circuits)
STRG24-6-T8-120-1 (1 circuit)
4-lamp
STRG24-4-T8-120-2 (2 circuits)
STRG24-4-T8-120-1 (1 circuit)
3-lamp
STRG24-3-T8-120-2 (2 circuits)
STRG24-3-T8-120-1 (1 circuit)
ADDITIONAL T8 LAMP CONFIGURATIONS
Qty. Description
21 (3) F32 T8 (Med. Bi-pin), (2 white/1 green)
22 (4) F32 T8 (Med. Bi-pin), (2 white/2 green)
33 (6) F32 T8 (Med. Bi-pin), (3 white/3 green)
42 (6) F32 T8 (Med. Bi-pin), (4 white/2 green)
VOLTAGE
120 120 volts
277 277 volts
120D 120 volt dimming (0-10v control)
277D 277 volt dimming (0-10v control)
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
EM212-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
GEN11,2 1-lamp, 5 min. interim ballast battery back-up (high lumen), (Includes additional EMI suppressor)
GEN21,2 2-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (Includes add'nl EMI supp.)
GEN31,2,3 3-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (Includes add'nl EMI supp.)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
2Available for non-dimming models.
3Available for 3- or 6-lamp models.
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
MIL STD 461F
ANTIMICROBIAL FINISH
31 08/06/2012
SurgiCare
2x4 Supplemental Surgical Luminaire
T5 Fluorescent (F28 T5)
STR24 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
6-lamp
STRG24-6-T5-120-3 (3 circuits)
STRG24-6-T5-120-2 (2 circuits)
STRG24-6-T5-120-1 (1 circuit)
4-lamp
STRG24-4-T5-120-2 (2 circuits)
STRG24-4-T5-120-1 (1 circuit)
3-lamp
STRG24-3-T5-120-2 (2 circuits)
STRG24-3-T5-120-1 (1 circuit)
ADDITIONAL T5 LAMP CONFIGURATIONS
Qty. Description
21 (3) F28 T5 (Mini Bi-pin), (2 white/1 green)
22 (4) F28 T5 (Mini Bi-pin), (2 white/2 green)
42 (6) F28 T5 (Mini Bi-pin), (4 white/2 green)
VOLTAGE
120 120 volts
277 277 volts
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
49-3/8"
(1254.1mm)
23-3/4"
(603.3mm)
MIL STD 461F
ANTIMICROBIAL FINISH
08/06/2012 32
SurgiCare
2x4 Supplemental Surgical Luminaire
T5HO Fluorescent (F54 T5HO)
STR24 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
4-lamp
STRG24-4-T5HO-120-2 (2 circuits)
STRG24-4-T5HO-120-1 (1 circuit)
3-lamp
STRG24-3-T5HO-120-2 (2 circuits)
STRG24-3-T5HO-120-1 (1 circuit)
ADDITIONAL T5HO LAMP CONFIGURATIONS
Qty. Description
21 (3) F54 T5HO (Mini Bi-pin), (2 white/1 green)
22 (4) F54 T5HO (Mini Bi-pin), (2 white/2 green)
VOLTAGE
120 120 volts
277 277 volts
120D 120 volt dimming (0-10v control)
277D 277 volt dimming (0-10v control)
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
48"
(1219.2mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
MIL STD 461F
ANTIMICROBIAL FINISH
33 08/06/2012
SurgiCare
2x2 Supplemental Surgical Luminaire
T8 Fluorescent (F17 T8)
STR22 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
6-lamp
STRG22-6-T8-120-3 (3 circuits)
STRG22-6-T8-120-2 (2 circuits)
STRG22-6-T8-120-1 (1 circuits)
4-lamp
STRG22-4-T8-120-2 (2 circuits)
STRG22-4-T8-120-1 (1 circuits)
3-lamp
STRG22-3-T8-120-2 (2 circuits)
STRG22-3-T8-120-1 (1 circuits)
ADDITIONAL T8 LAMP CONFIGURATIONS
Qty. Description
21 (3) F17 T8 (Med. Bi-pin), (2 white/1 green)
22 (4) F17 T8 (Med. Bi-pin), (2 white/2 green)
33 (6) F17 T8 (Med. Bi-pin), (3 white/3 green)
42 (6) F17 T8 (Med. Bi-pin), (4 white/2 green)
VOLTAGE
120 120 volts
277 277 volts
120D1120 volt dimming (0-10v control)
277D1277 volt dimming (0-10v control)
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM
Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM12,3 1-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
GEN13,4 1-lamp, 5 min. interim ballast battery back-up (high lumen), (Includes additional EMI suppressor)
GEN23,4 2-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (Includes add'nl EMI supp.)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1Dimming not available for "42" lamp configuration.
2Available for 3-lamp (1 circuit) models only.
3A dedicated EMI suppressor provided for emergency ballast.
4Available for 3- or 4-lamp (1 or 2 circuits), non-dimming models only.
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(1114.3mm)
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(1114.3mm)
MIL STD 461F
ANTIMICROBIAL FINISH
08/06/2012 34
SurgiCare
2x2 Supplemental Surgical Luminaire
T8U Fluorescent (FBO31 T8)
STR22 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
3-lamp
STRG22-3-T8U-120-2 (2 circuit)
STRG22-3-T8U-120-1 (1 circuit)
2-lamp
STRG22-2-T8U-120-1 (1 circuit)
`
VOLTAGE
120 120 volts
277 277 volts
120D 120 volt dimming (0-10v control)
277D 277 volt dimming (0-10v control)
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM11,2 1-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
GEN12,3 1-lamp, 5 min. interim ballast battery back-up (high lumen), (Includes additional EMI suppressor)
GEN22,3 2-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (Includes add'nl EMI supp.)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1Available for 2-lamp models and 3-lamp (1 circuit) models.
2A dedicated EMI suppressor provided for emergency ballast.
3Available for 2- or 3-lamp, non-dimming models.
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
MIL STD 461F
ANTIMICROBIAL FINISH
35 08/06/2012
SurgiCare
2x2 Supplemental Surgical Luminaire
T5 Fluorescent (F14 T5)
STR22 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
6-lamps1STRG22-6-T5-120-2 (2 circuits)
STRG22-6-T5-120-1 (1 circuit)
4-lamp
STRG22-4-T5-120-2 (2 circuits)
STRG22-4-T5-120-1 (1 circuit)
3-lamp
STRG22-3-T5-120-1 (1 circuit)
VOLTAGE
120 120 volts
277 277 volts
120D2120 volt dimming (0-10v control)
277D2277 volt dimming (0-10v control)
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM
Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
SBF
Slow blow fuse (requires 1 per circuit)
TBC T-bar support clips
1Available with (2) 3-lamp ballasts.
2Available for 4-lamp models only.
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES
REPRESENTATIVE FOR
PRICING
MIL STD 461F
ANTIMICROBIAL FINISH
08/06/2012 36
SurgiCare
2x2 Supplemental Surgical Luminaire
40TT Fluorescent (F40 T5 LTT)
STR22 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
3-lamp
STRG22-3-40TT-120-2 (2 circuits)
STRG22-3-40TT-120-1 (1 circuit)
2-lamp
STRG22-2-40TT-120-2 (2 circuits)
STRG22-2-40TT-120-1 (1 circuit)
VOLTAGE
120 120 volts
277 277 volts
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM11,2 1-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
GEN12,3 1-lamp, 5 min. interim ballast battery back-up (high lumen), (Includes additional EMI suppressor)
GEN22,3 2-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (Includes add'nl EMI supp.)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1Available for 2-lamp models only.
2A dedicated EMI suppressor provided for emergency ballast.
3Available for 2-lamp, non-dimming models.
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(1114.3mm)
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(1114.3mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
MIL STD 461F
ANTIMICROBIAL FINISH
37 08/06/2012
SurgiCare
2x2 Supplemental Surgical Luminaire
T5HO Fluorescent (F24 T5HO)
STR22 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
4-lamp
STRG22-4-T5HO-120-2 (2 circuits)
STRG22-4-T5HO-120-1 (1 circuit)
3-lamp
STRG22-3-T5HO-120-2 (2 circuits)
STRG22-3-T5HO-120-1 (1 circuit)
ADDITIONAL T5HO LAMP CONFIGURATIONS
Qty. Description
21 (3) F24 T5HO (Mini. Bi-pin), (2 white/1 green)
22 (4) F24 T5HO (Mini. Bi-pin), (2 white/2 green)
VOLTAGE
120 120 volts
277 277 volts
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
SBF
Slow blow fuse (requires 1 per circuit)
TBC T-bar support clips
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
24"
(609.6mm)
23-3/4"
(603.3mm)
4-1/2"
(114.3mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
MIL STD 461F
ANTIMICROBIAL FINISH
08/06/2012 38
SurgiCare
1x4 Supplemental Surgical Luminaire
T8 Fluorescent (F32 T8)
STR14 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
3-lamp
STRG14-3-T8-120-2 (2 circuits)
STRG14-3-T8-120-1 (1 circuit)
2-lamp
STRG14-2-T8-120-1 (1 circuit)
ADDITIONAL T8 LAMP CONFIGURATIONS
Qty. Description
21 (3) F32 T8 (Med. Bi-pin), (2 white/1 green)
VOLTAGE
120 120 volts
277 277 volts
120D 120 volt dimming (0-10v control)
277D 277 volt dimming (0-10v control)
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
EM212-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
GEN11,2 1-lamp, 5 min. interim ballast battery back-up (high lumen), (Includes additional EMI suppressor)
GEN21,2 2-lamp (GEN3), 4 min. interim ballast battery back-up (high lumen), (Includes add'nl EMI supp.)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
2Available for non-dimming models.
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
11-3/4"
(298.5mm)
6"
(152.4mm)
48"
(1219.2mm)
11-3/4"
(298.5mm)
6"
(152.4mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
MIL STD 461F
ANTIMICROBIAL FINISH
39 08/06/2012
SurgiCare
1x4 Supplemental Surgical Luminaire
T5 Fluorescent (F28 T5)
STR14 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
3-lamp
STRG14-3-T5-120-2 (2 circuits)
STRG14-3-T5-120-1 (1 circuit)
2-lamp
STRG14-2-T5-120-1 (1 circuit)
ADDITIONAL T5 LAMP CONFIGURATIONS
Qty. Description
21 (3) F28 T5 (Mini Bi-pin), (2 white/1 green)
VOLTAGE
120 120 volts
277 277 volts
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
11-3/4"
(298.5mm)
6 "
(152.4mm)
48"
(1219.2mm)
11-3/4"
(298.5mm)
6 "
(152.4mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
MIL STD 461F
ANTIMICROBIAL FINISH
08/06/2012 40
SurgiCare
1x4 Supplemental Surgical Luminaire
T5HO Fluorescent (F54 T5HO)
STR14 Series
No. of Catalog Shpg Cont. Dist.
Lamps Number L W D Wt. Price Price
2-lamp
STRG14-2-T5HO-120-1 (1 circuit)
VOLTAGE
120 120 volts
277 277 volts
120D 120 volt dimming (0-10v control)
277D 277 volt dimming (0-10v control)
DOOR MOUNTING
A1 Stainless steel hinge/screws
A2 Stainless steel screws/dual aircraft safety cables
A3 Stainless steel hinge/spring-loaded latches
LENS
ASM Asymmetric/symmetric lens
SYM Symmetric lens
OPTIONS
EM111-lamp emergency ballast battery back-up (90 min.), (Includes additional EMI suppressor)
SBF
Slow blow fuse (requires 1 per circuit + 1 for any emergency ballast)
TBC T-bar support clips
1A dedicated EMI suppressor provided for emergency ballast.
3500K NAME BRAND LAMP INCLUDED
Grid Model Dimensions
48"
(1219.2mm)
11-3/4"
(298.5mm)
6"
(152.4mm)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
MIL STD 461F
ANTIMICROBIAL FINISH
41 08/06/2012
STS8240
2x4 Sealed Surgical Troffer
T8 Fluorescent
STS8240 Series
Catalog Shpg Cont. Dist.
Number L* W D Wt. Price Price
SEALED SURGICAL TROFFER WITH SYMMETRIC/ASYMMETRIC CONTROL LENS
Sealed Surgical Troffer for 6/F32T8 lamps w/
1 Suppressor & 3 Electronic Ballasts
Sealed Surgical Troffer for 6/F32T8 lamps w/
2 Suppressors & 3 Electronic Ballasts
Sealed Surgical Troffer for 6/F32T8 lamps w/
3 Suppressors & 3 Electronic Ballasts
277Volt Available Below Lamps Included
*add 1 5/16" for flange on "/F" housings
SEALED SURGICAL TROFFER WITH PRIMATIC ACRYLIC LENS
Sealed Surgical Troffer for 6/F32T8 lamps w/
1 Suppressor & 3 Electronic Ballasts
Sealed Surgical Troffer for 6/F32T8 lamps w/
2 Suppressors & 3 Electronic Ballasts
Sealed Surgical Troffer for 6/F32T8 lamps w/
3 Suppressors & 3 Electronic Ballasts
277Volt Available Below Lamps Included
*add 1 5/16" for flange on "/F" housings
REQUIRED MOUNTING STYLE (Must add as Suffix)
/F Flanged Housing for Dry-Wall Ceilings
/G For Lay-In Grid Ceiling 1" to 1½" Tees
OPTIONAL EQUIPMENT (Add as suffix)
/277V (3) 277 Volt Ballasts
/EM1 Single Lamp Emergency Battery Back-Up
/EM2 Two Lamp Emergency Battery Back-Up
Single Lamp 5-Minute Interim Battery Back-Up (eliminates time
delay when switching to generator back-up circuit)
/SLO-BLO GMF Slow Blow Fuse & Fuse Holder (order one/circuit)
/T12 Ballasts for 6/F40T12 lamps substituted for T8
/WHS 20 gauge steel housing powder coated after fabrication
OPTIONAL MOUNTING EQUIPMENT
F8240
Plaster Frame for 2' x 4' ST8240/F series surgical troffers
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE
FOR PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE
FOR PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE
FOR PRICING
23¾"
4½"
37
47¾"
4½"
23¾"
37
47¾"
47¾"
23¾"
37
47¾"
23¾"
47¾"
23¾"
4½"
37
4½"
37
4½"
/GEN1
STS8240-1
STS8240-2
STS8240-3
STS8245-1
STS8245-2
STS8245-3
3500K NAME BRAND LAMP INCLUDED
Dimensions
Description
47¾"
4½"
37
ALKCO SURGICAL TROFFERS SUPPLIED WITH
ANTIMICROBIAL FINISHES
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE
FOR PRICING
23¾"
08/06/2012 42
STS8220
2x2 Sealed Surgical Troffer
T8 U-Shaped Fluroescent
STS8220 Series
Catalog Shpg Cont. Dist.
Number L* W D Wt. Price Price
SEALED SURGICAL TROFFER WITH SYMMETRIC/ASYMMETRIC CONTROL LENS
STS8220-1 Sealed Surgical Troffer for 2/FBO31T8
U-shaped lamps with
1 Suppressor & 1 Electronic Ballast
277Volt Available Below Lamps Included
SEALED SURGICAL TROFFER WITH PRIMATIC ACRYLIC LENS
STS8225-1 Sealed Surgical Troffer for 2/FBO31T8
U-shaped lamps with
1 Suppressor & 1 Electronic Ballast
277Volt Available Below Lamps Included
REQUIRED MOUNTING STYLE (Must add as Suffix)
/F Flanged Housing for Dry-Wall Ceilings
/G For Lay-In Grid Ceiling 1" to 1½" Tees
OPTIONAL EQUIPMENT (Add as suffix)
/277V 277 Volt Ballast
/EM1 Single Lamp Emergency Battery Back-Up
/EM2 Two Lamp Emergency Battery Back-Up
Single Lamp 5-Minute Interim Battery Back-Up (eliminates time
delay when switching to generator back-up circuit)
/SLO-BLO GMF Slow Blow Fuse & Fuse Holder (order one/circuit)
/T12 Ballast for T12 U-lamps substituted for T8
/WHS 20 gauge steel housing powder coated after fabrication
OPTIONAL MOUNTING EQUIPMENT
F8220
Plaster Frame for 2' x 2' ST8220/F series surgical troffers
ALKCO SURGICAL TROFFERS SUPPLIED WITH
ANTIMICROBIAL FINISHES
/GEN1
20
23¾"
23¾"
4½"
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
*add 1 5/16" for flange on
"/F" housings
*add 1 5/16" for flange on
"/F" housings
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE FOR
PRICING
3500K NAME BRAND LAMP INCLUDED
Description
20
Dimensions
23¾"
4½"
23¾"
43 08/06/2012
STS8140
1x4 Sealed Surgical Troffer
T8 Fluorescent
STS8140 Series
Catalog Shpg Cont. Dist.
Number L* W D Wt. Price Price
SEALED SURGICAL TROFFER WITH ASYMMETRIC CONTROL LENS
Sealed Surgical Troffer for 3/F32T8 lamps w/
1 Suppressor & 2 Electronic Ballasts
Sealed Surgical Troffer for 3/F32T8 lamps w/
2 Suppressors & 2 Electronic Ballasts
277Volt Available Below Lamps Included
SEALED SURGICAL TROFFER WITH PRIMATIC ACRYLIC LENS
Sealed Surgical Troffer for 3/F32T8 lamps w/
1 Suppressor & 2 Electronic Ballasts
Sealed Surgical Troffer for 3/F32T8 lamps w/
2 Suppressors & 2 Electronic Ballasts
277Volt Available Below Lamps Included
REQUIRED MOUNTING STYLE (Must add as Suffix)
/F Flanged Housing for Dry-Wall Ceilings
/G For Lay-In Grid Ceiling 1" to 1½" Tees
OPTIONAL EQUIPMENT (Add as suffix) 2 Suppressors & 2 Magnetic Ballasts
/277V (2) 277 Volt Ballasts
/EM1 Single Lamp Emergency Battery Back-Up
/EM2 Two Lamp Emergency Battery Back-Up
Single Lamp 5-Minute Interim Battery Back-Up (eliminates time
delay when switching to generator back-up circuit)
/SLO-BLO GMF Slow Blow Fuse & Fuse Holder (order one/circuit)
/T12 Ballasts for 3/F40T12 lamps substituted for T8
/WHS 20 gauge steel housing powder coated after fabrication
OPTIONAL MOUNTING EQUIPMENT
F8140 Plaster Frame for 1' x 4' ST8140/F series surgical troffers
3500K NAME BRAND LAMP INCLUDED
11¾"
4½"
20
Dimensions
11¾"
4½"
20
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE
FOR PRICING
20
11¾"
4½"
*add 1 5/16" for flange on "/F"
housings
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE
FOR PRICING
CONTACT YOUR
LOCAL SALES
REPRESENTATIVE
FOR PRICING
4½"
20
ALKCO SURGICAL TROFFERS SUPPLIED WITH
ANTIMICROBIAL FINISHES
Description
47¾"
11¾"
47¾"
47¾"
*add 1 5/16" for flange on "/F"
housings
/GEN1
STS8145-2
47¾"
STS8140-1
STS8145-1
STS8140-2
08/06/2012 44
ST8240
2x4 Surgical Troffer
T8 Fluorescent
ST8240 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
WITH SYMMETRIC/ASYMMETRIC CONTROL LENS
ST8240-1 Surgical Troffer for 6/F32T8 lamps w/
1 Suppressor & 3 Electronic Ballasts
47¾" 23¾" 4½" 37
ST8240-2 Surgical Troffer for 6/F32T8 lamps w/
2 Suppressors & 3 Electronic Ballasts
47¾" 23¾" 4½" 37
ST8240-3 Surgical Troffer for 6/F32T8 lamps w/
3 Suppressors & 3 Electronic Ballasts
47¾" 23¾" 4½" 37
277Volt Available Below Lamps Included
WITH PRISMATIC ACRYLIC LENS
ST8245-1 Surgical Troffer for 6/F32T8 lamps w/
1 Suppressor & 3 Electronic Ballasts
47¾" 23¾" 4½" 37
ST8245-2 Surgical Troffer for 6/F32T8 lamps w/
2 Suppressors & 3 Electronic Ballasts
47¾" 23¾" 4½" 37
ST8245-3 Surgical Troffer for 6/F32T8 lamps w/
3 Suppressors & 3 Electronic Ballasts
47¾" 23¾" 4½" 37
277Volt Available Below Lamps Included
REQUIRED MOUNTING STYLE (Must add as Suffix)
/F Flanged Housing for Dry-Wall Ceilings
/G For Lay-In Grid Ceiling 1" to 1½" Tees
OPTIONAL EQUIPMENT (Add as suffix)
/277V 277 Volt Ballast
/BIAX
/EM1 Single Lamp Emergency Battery Back-Up
/EM2 Two Lamp Emergency Battery Back-Up
/SLO-BLO GMF Slow Blow Fuse & Fuse Holder (order one/circuit)
/SS-ST Stainless Steel door frame
/T12 Ballasts for 6/F40T12 lamps substituted for T8
/WHS 20 gauge steel housing powder coated after fabrication
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp
/41 4100K lamp substituted for standard 3500K lamp
OPTIONAL MOUNTING EQUIPMENT
F8240 Plaster Frame for 2' x 4' ST8240/F series surgical troffers
REPLACEMENT EQUIPMENT
A8240 Asymmetric/Symmetric Lens only for ST8240
A8245 Prismatic Lens only for ST8245
STCK-1
Flange Kit to convert Grid Unit into a Flange Unit (specify for ST8240, 8220 or 8140)
3500K NAME BRAND LAMP INCLUDED
Dimensions
Description
Bi-Axial Lamps and Ballasts for 6/F40BX/RS substituted for T8
ALKCO SURGICAL TROFFERS SUPPLIED WITH
ANTIMICROBIAL FINISHES
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
45 08/06/2012
ST8220
2x2 Surgical Troffer
T8 U-Shaped Fluorescent
ST8220 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
WITH SYMMETRIC/ASYMMETRIC CONTROL LENS
ST8220-1 Surgical Troffer for 2/FBO31T8
U-shaped lamps with
1 Suppressor & 1 Electronic Ballast 23¾" 23¾" 4½" 20
277Volt Available Below Lamps Included
WITH PRISMATIC ACRYLIC LENS
ST8225-1 Surgical Troffer for 2/FBO31T8
U-shaped lamps with
1 Suppressor & 1 Electronic Ballast 23¾" 23¾" 4½" 20
277Volt Available Below Lamps Included
REQUIRED MOUNTING STYLE (Must add as Suffix)
/F Flanged Housing for Dry-Wall Ceilings
/G For Lay-In Grid Ceiling 1" to 1½" Tees
OPTIONAL EQUIPMENT (Add as suffix)
/277V 277 Volt Ballast
/BIAX Bi-Axial Lamps and Ballasts for 3/F40BX/RS substituted for T8
/EM1 Single Lamp Emergency Battery Back-Up
/EM2 Two Lamp Emergency Battery Back-Up
/SLO-BLO GMF Slow Blow Fuse & Fuse Holder
/SS-ST Stainless Steel door frame
/T12 Ballast for T12 U-lamps substituted for T8
/WHS 20 gauge steel housing powder coated after fabrication
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp
/41 4100K lamp substituted for standard 3500K lamp
OPTIONAL MOUNTING EQUIPMENT
F8220 Plaster Frame for 2' x 2' ST8220/F series surgical troffers
REPLACEMENT EQUIPMENT
A8220 Asymmetric/Symmetric Lens only for ST8220
A8225 Prismatic Lens only for ST8225
STCK-1
Flange Kit to convert Grid Unit into a Flange Unit (specify for ST8240, 8220 or 8140)
3500K NAME BRAND LAMP INCLUDED
Dimensions
Description
ALKCO SURGICAL TROFFERS SUPPLIED WITH
ANTIMICROBIAL FINISHES
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
08/06/2012 46
ST8140
1x4 Surgical Troffer
T8 Fluorescent
ST8140 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
WITH ASYMMETRIC CONTROL LENS
ST8140-1 Surgical Troffer for 3/F32T8 lamps w/
1 Suppressor & 2 Electronic Ballasts 47¾" 11¾" 4½" 20
ST8140-2 Surgical Troffer for 3/F32T8 lamps w/
2 Suppressors & 2 Electronic Ballasts
47¾" 11¾" 4½" 20
277Volt Available Below Lamps Included
WITH PRISMATIC ACRYLIC LENS
ST8145-1 Surgical Troffer for 3/F32T8 lamps w/
1 Suppressor & 2 Electronic Ballasts 47¾" 11¾" 4½" 20
ST8145-2 Surgical Troffer for 3/F32T8 lamps w/
2 Suppressors & 2 Electronic Ballasts
47¾" 11¾" 4½" 20
277Volt Available Below Lamps Included
REQUIRED MOUNTING STYLE (Must add as Suffix)
/F Flanged Housing for Dry-Wall Ceilings
/G For Lay-In Grid Ceiling 1" to 1½" Tees
OPTIONAL EQUIPMENT (Add as suffix)
/277V (2) 277 Volt Ballasts
/BIAX Bi-Axial Lamps and Ballasts for 4/F40BX/RS substituted for T8
/EM1 Single Lamp Emergency Battery Back-Up
/EM2 Two Lamp Emergency Battery Back-Up
/SLO-BLO GMF Slow Blow Fuse & Fuse Holder (order one/circuit)
/SS-ST Stainless Steel door frame
/T12 Ballasts for 3/F40T12 lamps substituted for T8
/WHS 20 gauge steel housing powder coated after fabrication
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp
/41 4100K lamp substituted for standard 3500K lamp
OPTIONAL MOUNTING EQUIPMENT
F8140 Plaster Frame for 1' x 4' ST8140/F series surgical troffers
REPLACEMENT EQUIPMENT
A8140 Asymmetric Lens only for ST8140
A8145 Prismatic Lens only for ST8145
STCK-1
Flange Kit to convert Grid Unit into a Flange Unit (specify for ST8240, 8220 or 8140)
Description
Dimensions
3500K NAME BRAND LAMP INCLUDED
ALKCO SURGICAL TROFFERS SUPPLIED WITH
ANTIMICROBIAL FINISHES
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
47 08/06/2012
Recessed Asymmetric Exam Light
Haloen Incandescent
9930 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
PATIENT EXAM LIGHT
9930 Examination Light for (1) 250W Quartz lamp 12" 12" 9½" 10
277Volt Not Available Lamps Not Included
ACCESSORY EQUIPMENT
TIMER 9930-Timer Wall-Mounted 1 to 15 Minute Timer
MOUNTING EQUIPMENT
PFH9930 Plaster Frame & Hangers
REPLACEMENT EQUIPMENT
G98 Corning Pyrex Lens
Recessed Exam Light
Haloen Incandescent
9931 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
PATIENT EXAM LIGHT
9931 Examination Light for (1) 250W Quartz lamp 12" 12" 10" 10
277Volt Not Available Lamps Not Included
ACCESSORY EQUIPMENT
TIMER 9931-Timer Wall-Mounted 1 to 15 Minute Timer
MOUNTING EQUIPMENT
PFH9931 Plaster Frame & Hangers
REPLACEMENT EQUIPMENT
G98 Corning Pyrex Lens
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
9930
9931
Dimensions
Description
Dimensions
Description
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
08/06/2012 48
TE100
Task and Examination Lighting
LED
TE100 Series
LED Examination Light is made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number Wt. Price Price
TE100-FL LED examination light with floorstand 12 & 38 lbs.
TE100-W LED examination light with wall mount 12 lbs.
TE100-T LED examination light with table mount 12 lbs.
TE100-SC LED examination light with single ceiling mount 5 & 10 lbs.
TE100-R LED examination light with Fairfield rail mount
TE100-R1 LED examination light with DIN 25mm rail mount
120 volt only.
TE200
Task and Examination Lighting
Halogen
TE200 Series
Halogen Examination Light is made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number Wt. Price Price
TE210-FL
Halogen examination light (10˚ beam) 10 & 21 lbs.
with floorstand
TE210-W
Halogen examination light (10˚ beam) 10 lbs.
wall mounted with extension arm and universal
mount
TE220-FL
Halogen examination light (35˚ beam) 10 & 21 lbs.
with floorstand
TE220-W
Halogen examination light (35˚ beam) 10 lbs.
wall mounted with extension arm and universal
mount
120 volt only. Lamps Included.
Replacement Parts
BPK10
Replacement bulbs, 10˚ beam (4/box) <1 lb.
BPK15
Replacement bulbs, 35˚ beam (4/box) <1 lb.
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
New Product
formerly "Halogen Spot"
(960 Series)
Description
Description
49 08/06/2012
MNS10
Minor Surgical/Exam Lighting
Halogen
MNS10 Series
Minor Surgical/Exam Lights are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number Wt. Price Price
MNS10-FL Halogen minor surgical spot light with floorstand 14, 32 & 8 lbs.
MNS10-W Halogen minor surgical spot light with wall mount 14 & 20 lbs.
MNS10-SC Halogen minor surgical spot light with single 14 & 37 lbs.
ceiling mount
MNS10-DC Halogen minor surgical spot lights with double 14, 14 & 47 lbs.
ceiling mount (includes (2) MNS10 fixtures)
MNS10-ST Halogen minor surgical spot light with Fastrac, 14, 58 & 34 lbs.
single head and single trolley
MNS10-DT Halogen minor surgical spot lights with Fastrac, 14, 14, 58 & 44 lbs.
double head and single trolley (includes (2)
MNS10 fixtures)
120 volt only. Lamps Included.
Options
MNS10-30T 30" Drop tube (for MNS10 or MNS300) 4 lbs.
MNS10-42T 42" Drop tube (for MNS10 or MNS300) 6 lbs.
MNS10-SLT 8 lbs.
Replacement Parts
BPK30 MNS10 replacement bulbs (4/box) <1 lb.
MNS10HR MNS10 handle replacement <1 lb.
LHC Disposable Light handle covers, sterile (25/box) 2 lbs.
Description
Special length drop tube (max. 58") (for MNS10 or
MNS300)
formerly "Halogen Spot"
(8400 Series)
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
08/06/2012 50
MNS50
Minor Surgical/Exam Lighting
Halogen
MNS50 Series
Minor Surgical/Exam Lights are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number Wt. Price Price
MNS50-FL Halogen minor surgical spot light with floorstand 16, 27 & 17 lbs.
MNS50-W Halogen minor surgical spot light with wall mount 16, 26 & 12 lbs.
MNS50-SC Halogen minor surgical spot light with single 16, 34 & 12 lbs.
ceiling mount
MNS50-DC Halogen minor surgical spot lights with double 16, 16, 44 & 12 lbs.
ceiling mount (includes (2) MNS50 fixtures)
120 volt only. Lamps Included.
Options
MNS50-20T 20" Drop tube 3 lbs.
MNS50-42T 42" Drop tube 7 lbs.
Replacement Parts
BPK35 MNS50 replacement bulbs (3/box) <1 lb.
MNS50HR <1 lb.
LHC Disposable Light handle covers, sterile (25/box) 2 lbs.
Description
MNS50/MNS100/MNS200/MJS200 handle
replacement
New Product
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
51 08/06/2012
MNS100
Minor Surgical/Exam Lighting
Halogen
MNS100 Series
Minor Surgical/Exam Lights are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number Wt. Price Price
MNS100-FL Halogen minor surgical spot light with floorstand 17, 32 & 17 lbs.
MNS100-W Halogen minor surgical spot light with wall mount 16, 26 & 12 lbs.
MNS100-SC Halogen minor surgical spot light with single 16, 34 & 12 lbs.
ceiling mount
MNS100-DC Halogen minor surgical spot lights with double 16, 16, 44 & 12 lbs.
ceiling mount (includes (2) MNS100 fixtures)
120 volt only. Lamps Included.
Options
MNS50-20T 20" Drop tube (for MNS50 or MNS100) 3 lbs.
MNS50-42T 42" Drop tube (for MNS50 or MNS100) 7 lbs.
MNS-DIM Dimmer for MNS100
Replacement Parts
BPK40 MNS100/MJS200 replacement bulbs (3/box) <1 lb.
MNS50HR
MNS50/MNS100/MNS200/MJS200 handle replacement
<1 lb.
LHC
Disposable Light handle covers, sterile (25/box)
2 lbs.
MNS200
Minor Surgical/Exam Lighting
LED
MNS200 Series
Minor Surgical/Exam Lights are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number Wt. Price Price
MNS200-FL 17, 40 & 17 lbs.
MNS200-W LED minor surgical spot light with wall mount 17, 29 & 12 lbs.
MNS200-SC
LED minor surgical spot light with single
17, 37 & 12 lbs.
ceiling mount
MNS200-DC LED minor surgical spot lights with double 17, 17, 48, 12 & 12 lbs.
ceiling mount (includes (2) MNS200 fixtures)
120 volt only. Lamps Included.
Replacement Parts
MNS50HR
MNS50/MNS100/MJS200/MNS200 handle replacement
<1 lb.
LHC
Disposable Light handle covers, sterile (25/box)
<1 lb.
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
New Product
New Product
MNS50/MNS100/MJS200 LED minor surgical spot light
with floorstand
Description
Description
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
08/06/2012 52
MNS300
Minor Surgical/Exam Lighting
Halogen
MNS300 Series
Minor Surgical/Exam Lights are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number Wt. Price Price
MNS300-FL Halogen minor surgical spot light with floorstand 18, 32 & 8 lbs.
MNS300-W Halogen minor surgical spot light with wall mount 18 & 20 lbs.
MNS300-SC Halogen minor surgical spot light with single 18 & 36 lbs.
ceiling mount
MNS300-DC Halogen minor surgical spot lights with double 18, 18 & 45 lbs.
ceiling mount (includes (2) MNS300 fixtures)
MNS300-ST Halogen minor surgical spot light with Fastrac, 18, 58 & 28 lbs.
single head and single trolley
MNS300-DT
Halogen minor surgical spot lights with Fastrac,
18, 18, 58 & 42 lbs.
double head and single trolley (includes (2)
MNS300 fixtures)
120 volt only. Lamps Included.
Options
MNS10-30T 30" Drop tube (for MNS10 or MNS300) 4 lbs.
MNS10-42T 42" Drop tube (for MNS10 or MNS300) 6 lbs.
MNS10-SLT 8 lbs.
Replacement Parts
BPK45 MNS300 replacement bulbs (3/box) <1 lb.
MNS300HR MNS300 handle replacement <1 lb.
LHC Disposable Light handle covers, sterile (25/box) 2 lbs.
Description
Special length drop tube (max. 58") (for MNS10 or
MNS300)
formerly "Outpatient
Light" (8060 Series)
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
53 08/06/2012
MJS200
Major Surgical/Exam Lighting
Halogen
MJS200 Series
Major Surgical/Exam Lights are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number Wt. Price Price
MJS200-FL Halogen major surgical light with floorstand 17, 32 & 17 lbs.
MJS200-W Halogen major surgical light with wall mount 17, 26 & 12 lbs.
MJS200-SC Halogen major surgical light with single 17, 30 & 12 lbs.
ceiling mount
MJS200-DC Halogen major surgical lights with double 17, 17, 39, 12 & 12 lbs.
ceiling mount (includes (2) MNS300
fixtures)
Replacement Parts
BPK40 MNS100/MJS100 replacement bulbs (3/box) 1 lb.
MJS100HR
MNS50/MNS100/MNS200/MJS200 handle replacement
2 lbs.
LHC Disposable light handle covers, sterile (25/box) 2 lbs.
120 volt only. Lamps Included.
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
Description
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
08/06/2012 54
XR/XS
X-Ray Illuminator
T8 (Preheat) Fluorescent
XR/XS Series
X-Ray Illuminators are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
SIDE BY SIDE, 2 LAMPS PER PANEL
XS2100 1 Panel for 2/F15T8D lamps 21" 14" 3" 17
XS2200 2 Panels for 4/F15T8D lamps 21" 28" 3" 33
XS2300 3 Panels for 6/F15T8D lamps 21" 42" 3" 50
XS2400 4 Panels for 8/F15T8D lamps 21" 56" 3" 67
XS2500 5 Panels for 10/F15T8D lamps 21" 70" 3" 84
XS2600 6 Panels for 12/F15T8D lamps 21" 84" 3" 101
SIDE BY SIDE, 3 LAMPS PER PANEL
XS3100 1 Panel for 3/F15T8D lamps 21" 14" 3" 19
XS3200 2 Panels for 6/F15T8D lamps 21" 28" 3" 37
XS3300 3 Panels for 9/F15T8D lamps 21" 42" 3" 56
XS3400 4 Panels for 12/F15T8D lamps 21" 56" 3" 75
XS3500 5 Panels for 15/F15T8D lamps 21" 70" 3" 94
XS3600 6 Panels for 18/F15T8D lamps 21" 84" 3" 113
SIDE BY SIDE, 4 LAMPS PER PANEL
XS4100 1 Panel for 4/F15T8D lamps 21" 14" 3" 23
XS4200 2 Panels for 8/F15T8D lamps 21" 28" 3" 44
XS4300 3 Panels for 12/F15T8D lamps 21" 42" 3" 66
XS4400 4 Panels for 16/F15T8D lamps 21" 56" 3" 88
XS4500 5 Panels for 20/F15T8D lamps 21" 70" 3" 110
XS4600 6 Panels for 24/F15T8D lamps 21" 84" 3" 132
STACKED, 2 LAMPS PER PANEL
XS2101 1 Panel over 1 Panel for 4/F15T8D lamps 42" 14" 3" 33
XS2202 2 Panels over 2 Panels for 8/F15T8D lamps 42" 28" 3" 67
XS2303 3 Panels over 3 Panels for 12/F15T8D lamps 42" 42" 3" 101
XS2404 4 Panels over 4 Panels for 16/F15T8D lamps 42" 56" 3" 134
XS2505 5 Panels over 5 Panels for 20/F15T8D lamps 42" 70" 3" 278
XS2606 6 Panels over 6 Panels for 24/F15T8D lamps 42" 84" 3" 322
STACKED, 3 LAMPS PER PANEL
XS3101 1 Panel over 1 Panel for 6/F15T8D lamps 42" 14" 3" 37
XS3202 2 Panels over 2 Panels for 12/F15T8D lamps 42" 28" 3" 75
XS3303 3 Panels over 3 Panels for 18/F15T8D lamps 42" 42" 3" 113
XS3404 4 Panels over 4 Panels for 24/F15T8D lamps 42" 56" 3" 150
XS3505 5 Panels over 5 Panels for 30/F15T8D lamps 42" 70" 3" 298
XS3606 6 Panels over 6 Panels for 36/F15T8D lamps 42" 84" 3" 346
STACKED, 4 LAMPS PER PANEL
XS4101 1 Panel over 1 Panel for 8/F15T8D lamps 42" 14" 3" 44
XS4202 2 Panels over 2 Panels for 16/F15T8D lamps 42" 28" 3" 88
XS4303 3 Panels over 3 Panels for 24/F15T8D lamps 42" 42" 3" 132
XS4404 4 Panels over 4 Panels for 32/F15T8D lamps 42" 56" 3" 176
XS4505 5 Panels over 5 Panels for 40/F15T8D lamps 42" 70" 3" 345
XS4606 6 Panels over 6 Panels for 48/F15T8D lamps 42" 84" 3" 389
277Volt Not Available Lamps Not Included
OPTIONAL EQUIPMENT (Add as suffix)
/DBFAS4000 Dual Brightness Switching w/ FAS for 4000 Series
/FAS Film Activated Ready Switch
/HGP Cordset with Hospital Grade Plug
/L 15W T8 Daylight Fluorescent Lamps installed in fixtures
/MS On/Off Master Switch
Description
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
Dimensions
55 08/06/2012
XR/XS
X-Ray Illuminator
T8 (Preheat) Fluorescent
XR/XS Series
X-Ray Illuminators are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
SIDE BY SIDE, 2 LAMPS PER PANEL
XR2100 1 Panel for 2/F15T8D lamps 21" 14" 3" 20
XR2200 2 Panels for 4/F15T8D lamps 21" 28" 3" 38
XR2300 3 Panels for 6/F15T8D lamps 21" 42" 3" 56
XR2400 4 Panels for 8/F15T8D lamps 21" 56" 3" 74
XR2500 5 Panels for 10/F15T8D lamps 21" 70" 3" 92
XR2600 6 Panels for 12/F15T8D lamps 21" 84" 3" 110
SIDE BY SIDE, 3 LAMPS PER PANEL
XR3100 1 Panel for 3/F15T8D lamps 21" 14" 3" 22
XR3200 2 Panels for 6/F15T8D lamps 21" 28" 3" 42
XR3300 3 Panels for 9/F15T8D lamps 21" 42" 3" 62
XR3400 4 Panels for 12/F15T8D lamps 21" 56" 3" 82
XR3500 5 Panels for 15/F15T8D lamps 21" 70" 3" 102
XR3600 6 Panels for 18/F15T8D lamps 21" 84" 3" 122
SIDE BY SIDE, 4 LAMPS PER PANEL
XR4100 1 Panel for 4/F15T8D lamps 21" 14" 3" 26
XR4200 2 Panels for 8/F15T8D lamps 21" 28" 3" 49
XR4300 3 Panels for 12/F15T8D lamps 21" 42" 3" 72
XR4400 4 Panels for 16/F15T8D lamps 21" 56" 3" 95
XR4500 5 Panels for 20/F15T8D lamps 21" 70" 3" 118
XR4600 6 Panels for 24/F15T8D lamps 21" 84" 3" 141
STACKED, 2 LAMPS PER PANEL
XR2101 1 Panel over 1 Panel for 4/F15T8D lamps 42" 14" 3" 38
XR2202 2 Panels over 2 Panels for 8/F15T8D lamps 42" 28" 3" 74
XR2303 3 Panels over 3 Panels for 12/F15T8D lamps 42" 42" 3" 110
XR2404 4 Panels over 4 Panels for 16/F15T8D lamps 42" 56" 3" 146
XR2505 5 Panels over 5 Panels for 20/F15T8D lamps 42" 70" 3" 294
XR2606 6 Panels over 6 Panels for 24/F15T8D lamps 42" 84" 3" 338
STACKED, 3 LAMPS PER PANEL
XR3101 1 Panel over 1 Panel for 6/F15T8D lamps 42" 14" 3" 42
XR3202 2 Panels over 2 Panels for 12/F15T8D lamps 42" 28" 3" 82
XR3303 3 Panels over 3 Panels for 18/F15T8D lamps 42" 42" 3" 113
XR3404 4 Panels over 4 Panels for 24/F15T8D lamps 42" 56" 3" 162
XR3505 5 Panels over 5 Panels for 30/F15T8D lamps 42" 70" 3" 314
XR3606 6 Panels over 6 Panels for 36/F15T8D lamps 42" 84" 3" 362
STACKED, 4 LAMPS PER PANEL
XR4101 1 Panel over 1 Panel for 8/F15T8D lamps 42" 14" 3" 49
XR4202 2 Panels over 2 Panels for 16/F15T8D lamps 42" 28" 3" 95
XR4303 3 Panels over 3 Panels for 24/F15T8D lamps 42" 42" 3" 141
XR4404 4 Panels over 4 Panels for 32/F15T8D lamps 42" 56" 3" 188
XR4505 5 Panels over 5 Panels for 40/F15T8D lamps 42" 70" 3" 360
XR4606 6 Panels over 6 Panels for 48/F15T8D lamps 42" 84" 3" 405
277Volt Not Available Lamps Not Included
OPTIONAL EQUIPMENT (Add as suffix)
/DBFAS4000 Dual Brightness Switching w/ FAS for 4000 Series
/FAS Film Activated Ready Switch
/L 15W T8 Daylight Fluorescent Lamps installed in fixtures
/MS On/Off Master Switch
Dimensions
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
CONTACT YOUR LOCAL SALES
REPRESENTATIVE FOR PRICING
Description
08/06/2012 56
Surface/Recessed Dark Room Safelight
Incandescent
2058 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
SINGLE COMPARTMENT
R2058-1 Recessed Mounting for 1/A15W lamp 12" 12" 6" 11
SM2058-1 Surface Mount for 1/A15W lamp 12" 12" 6" 11
DOUBLE COMPARTMENT
R2058-2 Recessed Mounting for 1/A15W & 1/A200W lamps 24" 12" 6" 22
SM2058-2 Surface Mount for 1/A15W & 1/A200W lamps 24" 12" 6" 22
TRIPLE COMPARTMENT
R2058-3 Recessed Mounting for 2/A15W & 1/A200W lamps 36" 12" 6" 33
SM2058-3 Surface Mount for 2/A15W & 1/A200W lamps 36" 12" 6" 33
277Volt Not Available Lamps Not Included
Specify Filter required per filter list below (included in price of fixture)
If no Filter is specified, a GBX-2 general use reddish/brown filter will be supplied
OPTIONAL EQUIPMENT (Add as suffix)
/TP Tamper Proof Oval-Head Screw
OPTIONAL MOUNTING EQUIPMENT
PF2058-1 Plaster Frame for R2058-1
PF2058-2 Plaster Frame for R2058-2
PF2058-3 Plaster Frame for R2058-3
OPTIONAL ACCESSORY EQUIPMENT
SD40 Screwdriver for Tamper Proof Screws
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
2058
GENERALLY, ONE (1) SAFELIGHT COMPARTMENT WILL PROVIDE
ADEQUATE SAFE LIGHTING FOR A 20 SQ. FT. AREA. 2058 SERIES
SAFELIGHT COMPARTMENTS ARE OFTEN SWITCHED ON IN
CONJUNCTION WITH "DARKROOM IN USE" SIGNS (see Page 96).
Description
Dimensions
57 08/06/2012
LINCS
GOLD PROGRAM PRODUCT
1" Modular Task Light
LED
LINCS100L Series
Catalog Shpg Cont. Dist.
Number Description L** W D Wt. Price Price
LINCS100-L10 3 LEDs 10-1/4" 4-3/16" 1-3/16" 137.90$ 103.70$
LINCS100-L19 6 LEDs 19-1/16" 4-3/16" 1-3/16" 204.20$ 153.50$
LINCS100-L28 9 LEDs 27-7/8" 4-3/16" 1-3/16" 268.80$ 202.10$
** Installation Notes: •
•Deduct 7/16" for each end cap removed for row mounting.
VOLTAGE
120 120 volt N/C N/C
277 277 volt N/C N/C
FINISH
WHG White Glossy N/C N/C
MB Matte Black 15.70$ 11.80$
SA Satin Aluminum N/C N/C
OPTIONS
CSJT-31,2,3 6' SJT cordset hard-wired into back of fixture (120 volt only) 12.00$ 9.00$
OSC446.60$ 35.00$
RSW Rocker switch (on/off) 4.70$ 3.50$
SBF Slow blow fuse 11.00$ 8.30$
SPECIFY NUMBER OF CONNECTORS NEEDED
LINCS100-15Wiring module 5-1/4" 4-3/16" 1-3/16" 121.30$ 16.00$
LINCS100-1/RSW5
Wiring module with rocker switch
5-1/4" 4-3/16" 1-3/16" 125.90$ 19.50$
LINCS100-2/CO57-1/4" 4-3/16" 1-3/16" 125.00$ 18.80$
LINCS100PC33,6 3' Straight power cord 16.90$ 12.70$
LINCS100PC63.6 6' Straight power cord 20.10$ 15.10$
LINCS100PC103,6 10' Straight power cord 25.00$ 18.80$
LINCS100PCF43,6 2'-4' Flexible coiled power cord 25.00$ 18.80$
LINCS100ICS36" Straight interconnect cord 10.50$ 7.90$
LINCS100ICF312"-36" Flexible coiled interconnect cord 14.50$ 10.90$
LINCS100MSBRK Mounting brackets for attachment to metal shelves 8.90$ 6.70$
1UL Listed for use in office systems furniture.
2LINCS fixtures with the CJST option can not be modularly connected.
3To designate the cord color add a "W" for white or a "B" for black to the model number. (Example: LINCS100ICSW)
4OSC not available for LINCS100-L10.
5Specify a voltage and finish for this option.
6Power cords may not be used with 277 volt applications.
Dimensions
When row mounting LINCS, allow one inch of additional space at end of run for connection
of last fixture. When using power supply cord, allow 3" for cord at start of run.
Dimming not currently available.
Wiring module w/ duplex
outlet
Integral occupancy sensor control (OSC is set at 30 minutes
when it leaves the factory. Contact factory for an alternative
setting.)
08/06/2012 58
LINCS ELECTRONIC BALLAST NOW STANDARD
1" Modular Task Light NAME BRAND LAMP INCLUDED
T5/T5HO Fluorescent
GOLD PROGRAM PRODUCT
LINCS100F Series
Catalog Shpg Cont. Dist.
Number Description L** W D Wt. Price Price
T5
LINCS100-FS23 (1) F14 T5 (Mini Bipin) 23-7/8" 4-3/16" 1-3/16" 4 180.50$ 135.70$
LINCS100-FS35 (1) F21 T5 (Mini Bipin) 35-11/16" 4-3/16" 1-3/16" 4.5 215.90$ 162.30$
LINCS100-FS46 (1) F28 T5 (Mini Bipin) 47-1/2" 4-3/16" 1-3/16" 5 244.60$ 183.90$
LINCS100-FS58 (1) F35 T5 (Mini Bipin) 59-5/16" 4-3/16" 1-3/16" 6 304.20$ 228.70$
T5HO
LINCS100-HO23 (1) F24 T5HO (Mini Bipin) 23-7/8" 4-3/16" 1-3/16" 4 196.30$ 147.60$
LINCS100-HO35 (1) F39 T5HO (Mini Bipin) 35-11/16" 4-3/16" 1-3/16" 4.5 232.90$ 175.10$
LINCS100-HO46 (1) F54 T5HO (Mini Bipin) 47-1/2" 4-3/16" 1-3/16" 5 265.50$ 199.60$
PREHEAT T5
LINCS100-F121(1) F8 T5 (Mini Bipin) 135/8" 4-3/16" 1-3/16" 2.5 63.20$ 47.50$
LINCS100-F211(1) F13 T5 (Mini Bipin) 22-5/8" 4-3/16" 1-3/16" 3 95.40$ 71.70$
LINCS100-F241(2) F8 T5 (Mini Bipin)
25-13/16"
4-3/16" 1-3/16" 4 103.60$ 77.90$
LINCS100-F331(1) F8 T5 (Mini Bipin) 34 13/16" 4-3/16" 1-3/16" 4.5 138.90$ 104.40$
& (1) F13 T5 (Mini Bipin)
LINCS100-F421(2) F13 T5 (Mini Bipin) 43 13/16" 4-3/16" 1-3/16" 5 164.80$ 123.90$
** Deduct 7/16" for each end-cover removed in row mount applications
1 Preheat T5 not available in 277 volt.
Select finish, voltage and mounting options below
Clear linear prismatic diffuser is standard. Opaque front and translucent white diffusers are optional.
OPTIONAL T5/T5HO LAMP COLOR TEMPERATURE (Add as suffix) default color termperature is 3000K
/35 3500K lamp substituted for standard 3000K lamp N/C N/C
/41 4100K lamp substituted for standard 3000K lamp N/C N/C
OPTIONAL PRE-HEAT T5 TRI-PHOSPHOR LAMPS IN PLACE OF STANDARD WARM WHITE LAMPS
F13-T5/30K F13T5 13 WATT 3000K T5 (price per lamp) 4.70$ 3.50$
VOLTAGE
/120 120 volt N/C N/C
/277 277 volt (not available with Preheat T5 lamps) N/C N/C
FINISH
/WHG White glossy N/C N/C
/MB Matte black 15.70$ 11.80$
/SA Satin aluminum (with black ends) N/C N/C
OPTIONAL EQUIPMENT (Add as suffix)
/CSJT-3-B * 2Black 6' cordset, direct wired out back of fixture * 12.00$ 9.00$
/CSJT-3-W * 2White 6' cordset, direct wired out back of fixture * 12.00$ 9.00$
/DIM13,4
/OF Opaque front task lens 6.70$ 5.00$
/WL White opal diffuser 5.30$ 4.00$
/OSC546.60$ 35.00$
/RSW6Rocker switch (controls an individual fixture) 4.70$ 3.50$
/SBF Slow blow fuse 11.00$ 8.30$
* UL listed for use in office systems furniture
2 LINCS fixtures with CSJT-3 option can not be modulary connected.
3 Dimming controls supplied by others.
4 Dimming available for models: LINCS100FS35, FS46, FS58 and LINCS100HO46.
5 OSC is not available for LINCS100F12.
6 Switch controls individual fixture
Integral occupancy sensor control (OSC is set at 30 minutes when it
leaves the factory. Contact factory for an alternative setting.)
Dimensions
Dimming ballast (use with analog 0-10 volt fluorescent
dimming control)
Consult Factory
59 08/06/2012
LINCS ELECTRONIC BALLAST NOW STANDARD
1" Modular Task Light NAME BRAND LAMP INCLUDED
T5/T5HO Fluorescent
GOLD PROGRAM PRODUCT
LINCS100F Series
Catalog Shpg Cont. Dist.
Number Description L** W D Wt. Price Price
CONNECTORS
LINCS100-17Wiring module 5-1/4" 4-3/16" 1-3/16" 1 21.30$ 16.00$
LINCS100-1/RSW7
Wiring module with rocker switch
5-1/4" 4-3/16" 1-3/16" 1 25.90$ 19.50$
LINCS100-2/CO77-1/4" 4-3/16" 1-3/16" 1 25.00$ 18.80$
LINCS100-PC3-W8White 3' Power Supply Cord 16.90$ 12.70$
LINCS100-PC3-B8Black 3' Power Supply Cord 16.90$ 12.70$
LINCS100-PC6-W8White 6' Power Supply Cord 20.10$ 15.10$
LINCS100-PC6-B8Black 6' Power Supply Cord 20.10$ 15.10$
LINCS100-PC10-W8White 10' Power Supply Cord 25.00$ 18.80$
LINCS100-PC10-B8Black 10' Power Supply Cord 25.00$ 18.80$
LINCS100-PCF4-W8White 2'-4' Coiled Power Cord 25.00$ 18.80$
LINCS100-PCF4-B8Black 2'-4' Coiled Power Cord 25.00$ 18.80$
LINCS100-ICS-W8White 6" Straight Interconnect Cord 10.50$ 7.90$
LINCS100-ICS-B8Black 6" Straight Interconnect Cord 10.50$ 7.90$
LINCS100-ICF-W8White 12"-36" Coiled Interconnect Cord 14.50$ 10.90$
LINCS100-ICF-B8Black 12"-36" Coiled Interconnect Cord 14.50$ 10.90$
LINCS100-MSBRK (2) Brackets for mounting to metal shelves 8.90$ 6.70$
7 Specify voltage and finish for these options
8 Power cords may not be used with 277 volt applications
Installation Notes:
When using power cord allow 3" at start of run
When row mounting LINCS, allow 1" at end of a run connection of last fixture
See page 99 for replacement diffuser Catalog Numbers and Pricing
Dimensions
Wiring module w/ duplex
outlet
08/06/2012 60
LINCS
GOLD PROGRAM PRODUCT
1" Modular Task Light
Low Voltage Halogen/Xenon
LINCS100HN/XN Series
Catalog Shpg Cont. Dist.
Number Description L** W D Wt. Price Price
LINCS100-HN9-SGD (1) 20W T3 Halogen G4 bi-pin base (12v) 9-7/8" 4-3/16" 1-3/16" 1.5 130.50$ 98.10$
LINCS100-XN9-SGD (1) 18W T5 Xenon-Wedge base (12v) 9-7/8" 4-3/16" 1-3/16" 1.5 130.50$ 98.10$
LINCS100-HN18-SGD (2) 20W T3 Halogen G4 bi-pin base (12v) 18-7/8" 4-3/16" 1-3/16" 2.5 141.80$ 106.60$
LINCS100-XN18-SGD (2) 18W T5 Xenon-Wedge base (12v) 18-7/8" 4-3/16" 1-3/16" 2.5 141.80$ 106.60$
LINCS100-HN27-SGD (3) 20W T3 Halogen G4 bi-pin base (12v) 27-7/8" 4-3/16" 1-3/16" 3.5 154.90$ 116.50$
LINCS100-XN27-SGD (3) 18W T5 Xenon-Wedge base (12v) 27-7/8" 4-3/16" 1-3/16" 3.5 154.90$ 116.50$
** Deduct 7/16" for each end cap removed for row mounting.
277Volt Not Available 20w Halogen and 18w Xenon lamps included
VOLTAGE
/120 120 volt N/C N/C
FINISH (Add as suffix)
/WHG White glossy N/C N/C
/MB Matte black 15.70$ 11.80$
/SA Satin aluminum (with black ends) N/C N/C
OPTIONAL EQUIPMENT (Add as suffix)
/10W 10 Watt Halogen Lamps N/C N/C
/CSJT-3-B*1Black 6' cordset, direct wired out back of fixture * 12.00$ 9.00$
/CSJT-3-W*1White 6' cordset, direct wired out back of fixture * 12.00$ 9.00$
/OSC246.60$ 35.00$
/HLRSW
3 Position Hi-Lo-Off Rocker Switch (switch controls individual fixture) 5.90$ 4.40$
/RSW Rocker switch (on/off) (switch controls individual fixture) 4.70$ 3.50$
/SBF Slow blow fuse 11.00$ 8.30$
* UL listed for use in office systems furniture
1 LINCS fixtures with CSJT-3 option can not be modularly connected
2 OSC is not available with LINCS100HN9-SGD or LINCS100XN9-SGD
SPECIFY NUMBER OF CONNECTORS NEEDED
LINCS100-13Wiring module 5-1/4" 4-3/16" 1-3/16" 1 21.30$ 16.00$
LINCS100-1/RSW3Wiring module with rocker switch 5-1/4" 4-3/16" 1-3/16" 1 25.90$ 19.50$
LINCS100-2/CO37-1/4" 4-3/16" 1-3/16" 1 25.00$ 18.80$
LINCS100-PC3W 3' Straight power cord, white 16.90$ 12.70$
LINCS100-PC3B 3' Straight power cord, black 16.90$ 12.70$
LINCS100-PC6W 6' Straight power cord, white 20.10$ 15.10$
LINCS100-PC6B 6' Straight power cord, black 20.10$ 15.10$
LINCS100-PC10W 10' Straight power cord, white 25.00$ 18.80$
LINCS100-PC10B 10' Straight power cord, black 23.90$ 18.00$
LINCS100-PCF4W 2'-4' Flexible coiled power cord, white 25.00$ 18.80$
LINCS100-PCF4B 2'-4' Flexible coiled power cord, black 25.00$ 18.80$
LINCS100-ICSW 6" Straight interconnect cord, white 10.50$ 7.90$
LINCS100-ICSB 6" Straight interconnect cord, black 10.50$ 7.90$
LINCS100-ICFW 12"-36" Flexible coiled interconnect cord, white 14.50$ 10.90$
LINCS100-ICFB 12"-36" Flexible coiled interconnect cord, black 14.50$ 10.90$
LINCS100-MSBRK (2) Brackets for mounting to metal shelves 8.90$ 6.70$
3 Specify voltage and finish for these options
REPLACEMENT LAMPS
Q10-T3 10 Watt Halogen Lamp 3.10$ 2.30$
Q20-T3 20 Watt Halogen Lamp 3.10$ 2.30$
REPLACEMENT GLASS DIFFUSERS
SGD-HN9 Sandblasted Diffuser for LINCSHN9 14.00$ 10.50$
SGD-HN18 Sandblasted Diffuser for LINCSHN18 14.00$ 10.50$
SGD-HN27 Sandblasted Diffuser for LINCSHN27 14.00$ 10.50$
Installation Notes:
Dimensions
For best dimming results, use a reverse phase dimmer designed for electronic transformers (such as Lutron
NPELV)
When row mounting LINCS, allow one inch of additional space at end of run for connection of last fixture. When using power supply cord,
allow 3" for cord at start of run.
Wiring module w/ duplex outlet
Integral occupancy sensor control (OSC is set at 30 minutes when it leaves the
factory. Contact factory for an alternative setting.)
61 08/06/2012
LINCS ELECTRONIC BALLAST STANDARD
1-1/2" Modular Task Light 3500K NAME BRAND LAMP INCLUDED
T8/LTT Fluorescent
GOLD PROGRAM PRODUCT
LINCS150 SERIES
Catalog Shpg Cont. Dist.
Number Description L** W D Wt. Price Price
LONG TWIN TUBE
LINCS150-B11 (1) F18 LTT (Med. Bipin) 12 1/2" 5 11/16" 1 13/16" 3 198.20$ 149.00$
LINCS150-B15 (1) F27 LTT (Med. Bipin) 16 3/8" 5 11/16" 1 13/16" 4 221.30$ 166.40$
LINCS150-B25 (1) F40 LTT (Med. Bipin) 25 7/8" 5 11/16" 1 13/16" 5 244.20$ 183.60$
T8
LINCS150-O24 (1) F17 T8 (Med. Bipin) 25 1/2" 5 11/16" 1 13/16" 5 152.00$ 114.30$
LINCS150-O36 (1) F25 T8 (Med. Bipin) 37 1/2" 5 11/16" 1 13/16" 7 183.50$ 138.00$
LINCS150-O48 (1) F32 T8 (Med. Bipin) 49 1/2" 5 11/16" 1 13/16" 8 217.60$ 163.60$
** Deduct 7/16" for each end cap removed for row mounting.
Clear linear prismatic diffuser is standard. Opaque front and translucent white diffusers are optional.
Lamps Included
VOLTAGE
/120 120 volt N/C N/C
/2771277 volt N/C N/C
/3471347 volt 2.40$ 1.80$
1 277 and 347 volt only available on LNICS150-O24, O36, O48 and B25.
OPTIONAL FINISH (Add as suffix) default finish is WHITE
/WHG White glossy N/C N/C
/MB Matte black 15.70$ 11.80$
/SA Satin aluminum (with black end caps) N/C N/C
OPTIONAL EQUIPMENT (Add as suffix)
/CSJT-3-B1.2 Black 6' cordset, direct wired out back of fixture * 12.00$ 9.00$
/CSJT-3-W1.2 White 6' cordset, direct wired out back of fixture * 12.00$ 9.00$
/DIM1
/DIM2
/OF Opaque front task lens 6.70$ 5.00$
/WL Translucent white diffuser 5.30$ 4.00$
/OSC346.60$ 35.00$
/RSW
Rocker switch (on/off)
4.70$ 3.50$
/SBF Slow blow fuse 11.00$ 8.30$
* UL LISTED FOR USE IN OFFICE SYSTEMS FURNITURE
1 LINCS fixtures with CSJT-3 option can not be modularly connected
2 CSJT-3 option only available with 120 volt
3 OSC is not available with LINCS150B11 or B15
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp N/C N/C
/41 4100K lamp substituted for standard 3500K lamp N/C N/C
SPECIFY NUMBER OF CONNECTORS NEEDED
LINCS150-1 Wiring Module 5-1/4" 5 11/16" 1 13/16" 21.30$ 16.00$
LINCS150-1/RSW
Wiring Module with rocker switch
5-1/4" 5 11/16" 1 13/16" 22.70$ 17.10$
LINCS150-2/CO
Wiring Module w/ duplex
receptacle
7 1/4" 5 11/16" 1 13/16" 1 26.50$ 19.90$
LINCS150-PC3-W4White 3' Power Supply Cord 16.90$ 12.70$
LINCS150-PC3-B4Black 3' Power Supply Cord 16.90$ 12.70$
LINCS150-PC6-W4White 6' Power Supply Cord 20.10$ 15.10$
LINCS150-PC10-W4White 10' Power Supply Cord 25.00$ 18.80$
LINCS150-PC10-B4Black 10' Power Supply Cord 25.00$ 18.80$
LINCS150-PCF4-W4White 2'-4' Coiled Power Supply Cord 25.00$ 18.80$
LINCS150-PCF4-B4Black 2'-4' Coiled Power Supply Cord 25.00$ 18.80$
LINCS150-ICS-W5White 6" Straight Interconnect Cord 10.50$ 7.90$
LINCS150-ICS-B5Black 6" Straight Interconnect Cord 10.50$ 7.90$
LINCS150-ICF-W5White 12"-36" Coiled Interconnect Cord 14.50$ 10.90$
LINCS150-ICF-B5Black 12"-36" Coiled Interconnect Cord 14.50$ 10.90$
LINCS150-MSBRK (2) Brackets for mounting to metal shelves 8.90$ 6.70$
4 Power cords are not available with 277 or 347 volt applications
5 Interconnect cords are not available with 347 volt applications
Installation Notes:
See page 99 for replacement diffuser Catalog Numbers and Pricing
Dimensions
Dimming ballast for use with analog 0-10 volt fluorescent
dimming control (120 and 277 volt only)
Dimming ballast for use with 2-wire line voltage fluorescent
dimming control (120 and 277 volt only)
Consult Factory
Consult Factory
When row mounting LINCS, allow one inch of additional space at end of run for connection
of last fixture. When using power supply cord, allow 3" for cord at start of run.
Integral occupancy sensor control (OSC is set at 30 minutes
when it leaves the factory. Contact factory for an alternative
setting.)
08/06/2012 62
Solid Front LINCS
1-1/2" Modular Task Light
T8/LTT Fluorescent
SFLINCS150 SERIES
Catalog Shpg Cont. Dist.
Number Description L** W D Wt. Price Price
T8
SFLINCS-150-O24 (1) F17 T8 (Med. Bipin) 25 1/2" 5 11/16" 1 13/16" 5 180.90$ 136.00$
SFLINCS-150-O36 (1) F25 T8 (Med. Bipin) 37 1/2" 5 11/16" 1 13/16" 7 214.50$ 161.30$
SFLINCS-150-O48 (1) F32 T8 (Med. Bipin) 49 1/2" 5 11/16" 1 13/16" 8 226.90$ 170.60$
** Deduct 7/16" for each end cap removed for row mounting.
VOLTAGE
/120 120 volt N/C N/C
/277 277 volt N/C N/C
/347 347 volt 2.40$ 1.80$
FINISH (Add as suffix)
/WHG White glossy N/C N/C
/MB Matte black 15.70$ 11.80$
/SA Satin aluminum (with black end caps) N/C N/C
OPTIONAL EQUIPMENT (Add as suffix)
/CSJT-3-B1.2 Black 6' cordset, direct wired out back of fixture * 12.00$ 9.00$
/CSJT-3-W1.2 White 6' cordset, direct wired out back of fixture * 12.00$ 9.00$
/DIM13
/DIM23
/BW Lateral prism batwing distribution lens 6.70$ 5.00$
/OSC 46.60$ 35.00$
/RSW4Rocker switch (on/off) (switch controls individual fixture) 4.70$ 3.50$
/SBF Slow blow fuse 11.00$ 8.30$
* UL LISTED FOR USE IN OFFICE SYSTEMS FURNITURE
1 LINCS fixtures with CSJT-3 option can not be modularly connected
2 CSJT-3 option only available with 120 volt
3 Dimming controls supplied by others
3 RSW only available with 120 and 277 volt
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp N/C N/C
/41 4100K lamp substituted for standard 3500K lamp N/C N/C
SPECIFY NUMBER OF CONNECTORS NEEDED
LINCS150-1 Wiring Module 5-1/4" 5 11/16" 1 13/16" 21.30$ 16.00$
LINCS150-1/RSW Wiring Module with rocker switch 5-1/4" 5 11/16" 1 13/16" 22.70$ 17.10$
LINCS150-2/CO
Wiring Module w/ duplex receptacle 7 1/4" 5 11/16" 1 13/16" 1 26.50$ 19.90$
LINCS150-PC3-W4White 3' Power Supply Cord 16.90$ 12.70$
LINCS150-PC3-B4Black 3' Power Supply Cord 16.90$ 12.70$
LINCS150-PC6-W4White 6' Power Supply Cord 20.10$ 15.10$
LINCS150-PC6-B4Black 6' Power Supply Cord 20.10$ 15.10$
LINCS150-PC10-W4White 10' Power Supply Cord 25.00$ 18.80$
LINCS150-PC10-B4Black 10' Power Supply Cord 25.00$ 18.80$
LINCS150-PCF4-W4White 2'-4' Coiled Power Supply Cord 25.00$ 18.80$
LINCS150-PCF4-B4Black 2'-4' Coiled Power Supply Cord 25.00$ 18.80$
LINCS150-ICS-W5White 6" Straight Interconnect Cord 10.50$ 7.90$
LINCS150-ICS-B5Black 6" Straight Interconnect Cord 10.50$ 7.90$
LINCS150-ICF-W5White 12"-36" Coiled Interconnect Cord 14.50$ 10.90$
LINCS150-ICF-B5Black 12"-36" Coiled Interconnect Cord 14.50$ 10.90$
LINCS150-MSBRK (2) Brackets for mounting to metal shelves 8.90$ 6.70$
4 Power cords are not available with 277 or 347 volt applications
5 Interconnect cords are not available with 347 volt applications
REPLACEMENT DIFFUSERS
P-O24 Prismatic Diffuser only for SFLINCS150-O24 6.90$ 5.20$
P-O36 Prismatic Diffuser only for SFLINCS150-O36 6.90$ 5.20$
P-O48 Prismatic Diffuser only for SFLINCS150-O48 6.90$ 5.20$
BW-O24 Batwing Lens only for SFLINCS150-O24 15.70$ 11.80$
BW-O36 Batwing Lens only for SFLINCS150-O36 15.70$ 11.80$
BW-O48 Batwing Lens only for SFLINCS150-O48 15.70$ 11.80$
Installation Notes:
ELECTRONIC BALLAST NOW STANDARD
GOLD PROGRAM PRODUCT
Dimensions
3500K NAME BRAND LAMP INCLUDED
When row mounting LINCS, allow one inch of additional space at end of run for connection of last fixture. When using power
supply cord, allow 3" for cord at start of run.
Dimming ballast for use with analog 0-10 volt fluorescent dimming
control (120 and 277 volt only)
Consult Factory
Dimming ballast for use with 2-wire line voltage fluorescent dimming
control (120 and 277 volt only)
Consult Factory
Integral occupancy sensor control (OSC is set at 30 minutes when it
leaves the factory. Contact factory for an alternative setting.)
63 08/06/2012
LINCS
GOLD PROGRAM PRODUCT
LINCSOSC-MOD Series
Catalog Shpg Cont. Dist.
Number L** W D Wt. Price Price
LINCS WIRING MODULE WITH INTEGRAL OCCUPANCY SENSOR
LINCS100-OSC 9-5/8" 4-3/16" 1-13/16" 167.80$ $51.00
LINCS150-OSC19-5/8" 5-11/16" 1-13/16" 167.80$ $51.00
** Deduct 7/16" for each end cap removed for row mounting.
VOLTAGE
/120 120 volt N/C N/C
/277 277 volt N/C N/C
FINISH
/WHG White glossy N/C N/C
/MB Matte black 15.70$ 11.80$
/SA Satin aluminum (with black ends) N/C N/C
OPTIONS
/RSW Rocker switch (on/off) N/C N/C
ACCESSORY CORDS FOR LINCS100
LINCS100-PC3-W White 3' Power Supply Cord 16.90$ 12.70$
LINCS100-PC3-B Black 3' Power Supply Cord 16.90$ 12.70$
LINCS100-PC6-W White 6' Power Supply Cord 20.10$ 15.10$
LINCS100-PC6-B Black 6' Power Supply Cord 20.10$ 15.10$
LINCS100-PC10-W White 10' Power Supply Cord 25.00$ 18.80$
LINCS100-PC10-B Black 10' Power Supply Cord 25.00$ 18.80$
LINCS100-PCF4-W White 2'-4' Coiled Power Cord 25.00$ 18.80$
LINCS100-PCF4-B Black 2'-4' Coiled Power Cord 25.00$ 18.80$
LINCS100-ICS-W White 6" Straight Interconnect Cord 10.50$ 7.90$
LINCS100-ICS-B Black 6" Straight Interconnect Cord 10.50$ 7.90$
LINCS100-ICF-W White 12"-36" Coiled Interconnect Cord 14.50$ 10.90$
LINCS100-ICF-B Black 12"-36" Coiled Interconnect Cord 14.50$ 10.90$
ACCESSORY CORDS FOR LINCS150
LINCS150-PC3-W 1White 3' Power Supply Cord 16.90$ 12.70$
LINCS150-PC3-B1Black 3' Power Supply Cord 16.90$ 12.70$
LINCS150-PC6-W1White 6' Power Supply Cord 20.10$ 15.10$
LINCS150-PC6-B1Black 6' Power Supply Cord 20.10$ 15.10$
LINCS150-PC10-W1White 10' Power Supply Cord 25.00$ 18.80$
LINCS150-PC10-B1Black 10' Power Supply Cord 25.00$ 18.80$
LINCS150-PCF4-W1White 2'-4' Coiled Power Cord 25.00$ 18.80$
LINCS150-PCF4-B1Black 2'-4' Coiled Power Cord 25.00$ 18.80$
LINCS150-ICS-W White 6" Straight Interconnect Cord 10.50$ 7.90$
LINCS150-ICS-B Black 6" Straight Interconnect Cord 10.50$ 7.90$
LINCS150-ICF-W White 12"-36" Coiled Interconnect Cord 14.50$ 10.90$
LINCS150-ICF-B Black 12"-36" Coiled Interconnect Cord 14.50$ 10.90$
1 Power cords may not be used with 277 volt applications.
NOTE: Power cords plug into left side of the fixtures.
Dimensions
1 Not available with 347v applications
1" and 1-1/2" Modular Undercabinet
Occupancy Sensor Control Modules
NOTE: Integral occupancy sensor control (OSC is set at 30 minutes when it leaves the factory. Contact
factory for an alternative setting.)
08/06/2012 64
ARIS
Low Profile Task Light
LED
ARIS Series
Catalog
Number Description L H D
Dist. Price*
ARIS-11-301 Nom. 11" LED fixture (3000K) 9.25" .88" 1.7" $53.00
ARIS-11-401 Nom. 11" LED fixture (4000K) 9.25" .88" 1.7" $53.00
ARIS-21-301 Nom. 21" LED fixture (3000K) 19.25" .88" 1.7" $89.00
ARIS-21-401 Nom. 21" LED fixture (4000K) 19.25" .88" 1.7" $89.00
ARIS-41-301 Nom. 41" LED fixture (3000K) 39.25" .88" 1.7" $144.00
ARIS-41-401 Nom. 41" LED fixture (4000K) 39.25" .88" 1.7" $144.00
120v Only
FINISH (Add as suffix)
/PRL Pearl N/C
ACCESSORIES (Add as suffix) Dist. Price
/DWC Direct wiring compartment 15.50$
/HWC1Wiring compartment 14.00$
/SLC Switched leader cable (10') 15.40$
/AFC Flush connector 0.80$
/AJC6 6" Jumper cable 8.40$
/AJC12 12" Jumper cable 9.80$
/AJC18 18" Jumper cable 11.20$
/AJC60 60" Jumper cable 24.00$
/AJCY "Y" Jumper cable 8.40$
/ATRM Termination plug 1.68$
/AMB11 9" Full length mounting bracket (for ARIS-11) 4.88$
/AMB21 19" Full length mounting bracket (for ARIS-21) 7.00$
/AMB41 39" Full length mounting bracket (for ARIS-41) 15.62$
NOTES
Aris fixtures can be dimmed with commercially available incandescent, line voltage dimmers designed for electronic
low voltage loads.
Max. Power Consumption
ARIS-11 (6W)
ARIS-21 (13W)
ARIS-41 (25W)
A Termination Plug (ATRM) is required to be plugged into the left side connector of the last fixture in the run before
energizing the system. One ATRM is supplied with each Wiring Compartment (HWC), Direct Wiring Compartment
(DWC), Switched Leader Cable (SLC) and "Y" Jumper Cable (AJCY).
1 The Wiring Compartment (HWC) requires a Jumper Cable (AJC6, AJC12, AJC18, AJC60 or AJCY) to connect to
the first fixture.
Up to 50 linear feet and <324 watts of Aris fixtures can be connected on a single run.
Dimensions
* For quantities over 1,000 please contact factory for pricing
65 08/06/2012
Little Inch2
Specification-Grade Task Light
T5/T5HO Fluorescent
L2F Series
Catalog Shpg Cont. Dist.
Number Lamping L H D
Wt. Price Price
FLUORESCENT
L2F1*
(1) F8 T5; No Rear Access Plate 12-3/4" 1-1/4" 4-1/2" 145.20$ 109.20$
L2F2 (1) F14 T5 23" 1-1/4" 4-1/2" 185.00$ 139.10$
L2F2HO (1) F24 T5HO 23" 1-1/4" 4-1/2" 201.40$ 151.40$
L2F3 (1) F21 T5 34-13/16" 1-1/4" 4-1/2" 216.40$ 162.70$
L2F3HO (1) F39 T5HO 34-13/16" 1-1/4" 4-1/2" 232.90$ 175.10$
L2F4 (1) F28 T5 46-5/8" 1-1/4" 4-1/2" 238.30$ 179.20$
L2F4HO (1) F54 T5HO 46-5/8" 1-1/4" 4-1/2" 253.50$ 190.60$
* This model utilizes a preheat T5 lamp. Available in 120Volt only.
347Volt Not Available
OPTIONAL DIMMING (Add as suffix)
/120DIM Dimming Option for 120 volt fixtures (10% dimming) 133.00$ $100
/277DIM Dimming Option for 277 volt fixtures (10% dimming) 133.00$ $100
OPTIONAL FINISH (Add as suffix) default finish is SOFT WHITE
/SWH Soft White N/C N/C
/AL Aluminum N/C N/C
/BLK Black N/C N/C
/BZ Bronze N/C N/C
OPTIONAL EQUIPMENT (Add as suffix)
/GL Stippled, tempered glass lens 10.60$ 8.00$
/SBF Slow blow fuse 11.00$ 8.30$
/SW Low profile switch 13.30$ 10.00$
LITTLE INCH2 FLUSH CONNECTOR & INTERCONNECT CORDS
FC6 In-line connector (6 conductor) for flush mounting 6.70$ 5.00$
CCW White 12"-36" Coiled Interconnect Cord 9.30$ 7.00$
CCB Black 12"-36" Coiled Interconnect Cord 9.30$ 7.00$
SCW White 6" Straight Interconnect Cord 7.70$ 5.80$
SCB Black 6" Straight Interconnect Cord 7.70$ 5.80$
CS3W 6' White 3-Wire Cordset 12.00$ 9.00$
CS3B 6' Black 3-Wire Cordset 12.00$ 9.00$
Order one connector or interconnect cord for each modular connection.
A 3-wire fluorescent dimmer from Lutron should be used.
Dimensions
3000K LAMP INCLUDED
GOLD PROGRAM PRODUCT
Switch is not available for 277v and dimmed applications.
Slow Blow Fuse not available for L2F1, L2F2HO and L2F2-DIM models.
Cannot use CCW, CCB, SCW, SCB, CS3W and CS3B with dimming option.
Dimming models are supplied without a switch.
Dimming is not available for L2F1.
08/06/2012 66
Little Inch NAME BRAND WARM WHITE LAMP INCLUDED
1" Task Light REAR ACCESS PLATE INCLUDED
T5/T5HO Fluorescent
GOLD PROGRAM PRODUCT
HP Series
Catalog Shpg Cont. Dist.
Number L W D
Wt. Price Price
WHITE BAKED ENAMEL FINISH
HP108 12" for 1/F8T5 No Rear Access Plate 12 1/4" 5" 1 1/8"
2.5 70.60$ 53.10$
HP113 21" 1/F13T5 21 1/4" 5" 1 1/8"
4104.50$ 78.60$
HP116 24" 2/F8T5 24 1/2" 5" 1 1/8"
4.5 111.50$ 83.80$
HP138
33" 1/F8T5 & 1/F13T5
33 1/2" 5" 1 1/8"
6.25 143.90$ 108.20$
HP213 42" 2/F13T5 42 1/2" 5" 1 1/8"
6.5 176.10$ 132.40$
277Volt Not Available Warm White Lamps Included
STAINLESS STEEL CONSTRUCTION
SSHP108 12" High Performance Little Inch for 1/F8T5 12 1/4" 5" 1 1/8"
2.5 131.40$ 98.80$
SSHP113 21" High Performance Little Inch for 1/F13T5 21 1/4" 5" 1 1/8"
4172.00$ 129.30$
SSHP116 24" High Performance Little Inch for 2/F8T5 24 1/2" 5" 1 1/8"
4.5 182.20$ 137.00$
SSHP138 33" High Performance Little Inch for 1/F8T5 & 33 1/2" 5" 1 1/8"
6.25 239.00$ 179.70$
1/F13T5
SSHP213 42" High Performance Little Inch for 2/F13T5 42 1/2" 5" 1 1/8"
6.5 295.90$ 222.50$
277Volt Not Available Warm White Lamps Included
OPTIONAL OPAQUE FRONT TASK LENS (Add as suffix)
/OF Opaque Front Task Lens 6.70$ 5.00$
OPTIONAL EQUIPMENT (Add as suffix)
/CO-W White Grounded Convenience Outlet 4.90$ 3.70$
/CS-3-W 6' White UL Labeled 3-Wire Cordset 12.00$ 9.00$
/RSW Rocker Switch (for replacement use HP-RSW) 4.70$ 3.50$
/SLO-BLO GMF Slow-Blow Fuse and Fuse Holder 11.00$ 8.30$
OPTIONAL FACTORY INSTALLED TRI-PHOSPHOR T5 LAMPS IN PLACE OF STANDARD WARM WHITE LAMPS
F13-T5/30K F13T5 13 WATT 3000K T5
PER LAMP
4.70$
3.50$
REPLACEMENT FOR STANDARD DIFFUSER
A8 12" Alkcorylic Diffuser only for HP108 8.00$ 6.00$
A13 21" Alkcorylic Diffuser only for HP113 8.00$ 6.00$
A16 24" Alkcorylic Diffuser only for HP116 8.00$ 6.00$
A38 33" Alkcorylic Diffuser only for HP138 8.00$ 6.00$
A23 42" Alkcorylic Diffuser only for HP213 8.00$ 6.00$
REPLACEMENT FOR OPAQUE FRONT TASK LENS
O8 12" Opaque Front Task Lens only for HP108 14.60$ 11.00$
O13 21" Opaque Front Task Lens only for HP113 14.60$ 11.00$
O16 24" Opaque Front Task Lens only for HP116 14.60$ 11.00$
O38 33" Opaque Front Task Lens only for HP138 14.60$ 11.00$
O23 42" Opaque Front Task Lens only for HP213 14.60$ 11.00$
Description
Dimensions
67 08/06/2012
Little Inch
1" Task Light
T5/T5HO Fluorescent
HP Series
Catalog Shpg Cont. Dist.
Number L W D
Wt. Price Price
PREMIUM T5 WHITE BAKED ENAMEL FINISH
HP114 24" Little Inch for 1/F14T5 premium T5 lamp 22-1/2" 5" 1-1/8" 172.80$ 129.90$
HP121 36" Little Inch for 1/F21T5 premium T5 lamp 34-3/8" 5" 1-1/8" 238.90$ 179.60$
HP128 48" Little Inch for 1/F28T5 premium T5 lamp 46-1/4" 5" 1-1/8" 270.30$ 203.20$
277Volt Available Lamps Included
T5 HIGH OUTPUT WHITE BAKED ENAMEL FINISH
HP124 24" Little Inch for 1/F24T5 high output T5 lamp 22-1/2" 5" 1-1/8" 190.20$ 143.00$
HP139 36" Little Inch for 1/F39T5 high output T5 lamp 34-3/8" 5" 1-1/8" 258.20$ 194.10$
HP154 48" Little Inch for 1/F54T5 high output T5 lamp 46-1/4" 5" 1-1/8" 293.10$ 220.40$
277Volt Available Lamps Included
PREMIUM T5 STAINLESS STEEL CONSTRUCTION
SSHP114 24" Little Inch for 1/F14T5 premium T5 lamp 22-1/2" 5" 1-1/8" 254.70$ 191.50$
SSHP121 36" Little Inch for 1/F21T5 premium T5 lamp 34-3/8" 5" 1-1/8" 351.80$ 264.50$
SSHP128 48" Little Inch for 1/F28T5 premium T5 lamp 46-1/4" 5" 1-1/8" 407.60$ 306.50$
277Volt Available Lamps Included
T5 HIGH OUTPUT STAINLESS STEEL CONSTRUCTION
SSHP124 24" Little Inch for 1/F24T5 high output T5 lamp 22-1/2" 5" 1-1/8" 275.30$ 207.00$
SSHP139 36" Little Inch for 1/F39T5 high output T5 lamp 34-3/8" 5" 1-1/8" 374.50$ 281.60$
SSHP154 48" Little Inch for 1/F54T5 high output T5 lamp 46-1/4" 5" 1-1/8" 434.50$ 326.70$
277Volt Available Lamps Included
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color termperature is 3000K
/35 3500K lamp substituted for standard 3000K lamp N/C N/C
/41 4100K lamp substituted for standard 3000K lamp N/C N/C
OPTIONAL OPAQUE FRONT TASK LENS (Add as suffix)
/OF Opaque Front Task Lens 6.70$ 5.00$
OPTIONAL EQUIPMENT (Add as suffix)
/CO-W White Grounded Convenience Outlet 4.90$ 3.70$
/CS-3-W 6' White UL Labeled 3-Wire Cordset 12.00$ 9.00$
/DIM
/RSW Rocker Switch (for replacement use HP-RSW) 4.70$ 3.50$
/SLO-BLO GMF Slow-Blow Fuse and Fuse Holder 11.00$ 8.30$
REPLACEMENT FOR STANDARD DIFFUSER
AP114 24" Alkcorylic Diffuser only for HP114/124 8.00$ 6.00$
AP121 36" Alkcorylic Diffuser only for HP121/139 8.00$ 6.00$
AP128 48" Alkcorylic Diffuser only for HP128/154 8.00$ 6.00$
REPLACEMENT FOR OPAQUE FRONT TASK LENS
OP114 24" Opaque Front Task Lens only for HP114/124 14.60$ 11.00$
OP121 36" Opaque Front Task Lens only for HP121/139 14.60$ 11.00$
OP128 48" Opaque Front Task Lens only for HP128/154 14.60$ 11.00$
Not available with HP124, HP139, SSHP124 & SSHP139
GOLD PROGRAM PRODUCT
Description
Dimensions
Contact Representative
Dimming ballast (use with analog 0-10 volt fluorescent dimming
control supplied by others)
NAME BRAND 3000K LAMP INCLUDED
REAR ACCESS PLATE INCLUDED
08/06/2012 68
Little Inch
1" Task Light
Low Voltage Halogen/ Xenon
HG/HX Series
Catalog Shpg Cont. Dist.
Number Description L W D
Wt. Price Price
HG8-SGD 1/Q20T3 No Rear Access Plate 8" 4 5/8"
1 5/16"
385.30$ 64.10$
HX8-SGD 1/18w T5 Capsule 8" 4 5/8"
1 5/16"
385.30$ 64.10$
No Rear Access Plate
HG17-SGD 2/Q20T3 17" 4 5/8"
1 5/16"
499.60$ 74.90$
HX17-SGD 2/18w T5 Capsule 17" 4 5/8"
1 5/16"
499.60$ 74.90$
HG23-SGD 3/Q20T3 23" 4 5/8"
1 5/16"
5113.70$ 85.50$
HX23-SGD 3/18w T5 Capsule 23" 4 5/8"
1 5/16"
5113.70$ 85.50$
HG47-SGD 6/Q20T3 47" 4 5/8"
1 5/16"
9201.00$ 151.10$
HX47-SGD 6/18w T5 Capsule 47" 4 5/8"
1 5/16"
9201.00$ 151.10$
277Volt Not Available 20w Halogen and 18w Xenon Lamps Included
OPTIONAL FINISH (Add as suffix) default finish is WHITE
/BLKG Black Glossy 15.70$ 11.80$
/AL Aluminum 15.70$ 11.80$
/BZ Bronze 15.70$ 11.80$
OPTIONAL EQUIPMENT (Add as suffix)
/CS-3-W 6' White UL labeled 3-wire cord set 12.00$ 9.00$
/HLRSW 3 Position HI-Lo-Off Rocker Switch 5.90$ 4.40$
REPLACEMENT LAMPS
Q10-T3 10 Watt Halogen Lamp 3.10$ 2.30$
Q20-T3 20 Watt Halogen Lamp 3.10$ 2.30$
REPLACEMENT FOR SANDBLASTED GLASS DIFFUSERS
SGD-HG8 Sandblasted Diffuser only for HG-8 14.00$ 10.50$
SGD-HG17 Sandblasted Diffuser only for HG-17 14.00$ 10.50$
SGD-HG23 Sandblasted Diffuser only for HG-23 14.00$ 10.50$
SGD-HG47 Sandblasted Diffuser only for HG-47 14.00$ 10.50$
SANDBLASTED GLASS LENS STANDARD
Dimensions
For best dimming results, use a reverse phase dimmer designed for electronic
transformers (such as Lutron NPELV)
REAR ACCESS PLATE INCLUDED
GOLD PROGRAM PRODUCT
69 08/06/2012
Solid Front Little Inch
1" Solid Front Task Light
T5/T5HO Fluorescent
SFHP Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
WHITE BAKED ENAMEL FINISH
SFHP108 12" 1/F8T5 No Rear Access Plate 12 1/4" 5" 1 1/8" 2.5 81.00$ 60.90$
SFHP113 21" 1/F13T5 21 1/4" 5" 1 1/8" 4 122.80$ 92.30$
SFHP116 24" 2/F8T5 24 1/2" 5" 1 1/8" 4.5 129.90$ 97.70$
SFHP138 33" 1/F8T5 & 1/F13T5 33 1/2" 5" 1 1/8" 6.25 180.60$ 135.80$
SFHP213 42" 2/F13T5 42 1/2" 5" 1 1/8" 6.5 211.70$ 159.20$
277Volt Not Available Warm White Lamps Included
STAINLESS STEEL CONSTRUCTION
SSSFHP108 12" High Performance Little Inch for 1/F8T5 12 1/4" 5" 1 1/8" 2.5 168.00$ 126.30$
SSSFHP113 21" High Performance Little Inch for 1/F13T5 21 1/4" 5" 1 1/8" 4 200.60$ 150.80$
SSSFHP116 24" High Performance Little Inch for 2/F8T5 24 1/2" 5" 1 1/8" 4.5 208.90$ 157.10$
SSSFHP138 33" High Performance Little Inch for 1/F8T5 & 33 1/2" 5" 1 1/8" 6.25 290.30$ 218.30$
SSSFHP213 42" High Performance Little Inch for 2/F13T5 42 1/2" 5" 1 1/8" 6.5 350.30$ 263.40$
277Volt Not Available Warm White Lamps Included
OPTIONAL EQUIPMENT (Add as suffix)
/CO-W White Grounded Convenience Outlet 4.90$ 3.70$
/CS-3-W 6' White UL Labeled 3-Wire Cordset 12.00$ 9.00$
/RSW
Rocker Switch (for replacement use HP-RSW)
4.70$ 3.50$
/SLO-BLO GMF Slow-Blow Fuse and Fuse Holder 11.00$ 8.30$
ADD OPTIONAL FACTORY INSTALLED TRI-PHOSPHOR T5 LAMPS IN PLACE OF STANDARD WARM WHITE LAMPS
F13-T5/30K F13T5 13 WATT 3000K T5 PER LAMP 4.70$ 3.50$
REORDER TRI-PHOSPHOR T5 LAMPS
F13-T5/30K F13T5 13 WATT 3000K T5 PER LAMP 7.20$ 7.20$
REPLACEMENT FOR STANDARD PRISMATIC DIFFUSER
SF8 12" Prismatic Diffuser only for SFHP108 6.90$ 5.20$
SF13 21" Prismatic Diffuser only for SFHP113 6.90$ 5.20$
SF16 24" Prismatic Diffuser only for SFHP116 6.90$ 5.20$
SF38 33" Prismatic Diffuser only for SFHP138 6.90$ 5.20$
SF23 42" Prismatic Diffuser only for SFHP213 6.90$ 5.20$
REPLACEMENT FOR BATWING LENS
ABW8 12" Batwing Lens only for SFHP108 15.70$ 11.80$
ABW13 21" Batwing Lens only for SFHP113 15.70$ 11.80$
ABW16 24" Batwing Lens only for SFHP116 15.70$ 11.80$
ABW38 33" Batwing Lens only for SFHP138 15.70$ 11.80$
ABW23 42" Batwing Lens only for SFHP213 15.70$ 11.80$
1/F13T5
NAME BRAND WARM WHITE LAMP INCLUDED
Dimensions
Description
REAR ACCESS PLATE INCLUDED
GOLD PROGRAM PRODUCT
08/06/2012 70
Solid Front Little Inch
1" Solid Front Task Light
T5/T5HO Fluorescent
SFHP Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
PREMIUM T5 WHITE BAKED ENAMEL FINISH
SFHP114 24" Little Inch for 1/F14T5 premium T5 lamp 22-1/2" 5" 1-1/8" 192.20$ 144.50$
SFHP121 36" Little Inch for 1/F21T5 premium T5 lamp 34-3/8" 5" 1-1/8" 227.70$ 171.20$
SFHP128 48" Little Inch for 1/F28T5 premium T5 lamp 46-1/4" 5" 1-1/8" 227.70$ 171.20$
277Volt Available Lamps Included
T5 HIGH OUTPUT WHITE BAKED ENAMEL FINISH
SFHP124 24" Little Inch for 1/F24T5 high output T5 lamp 22-1/2" 5" 1-1/8" 209.90$ 157.80$
SFHP139 36" Little Inch for 1/F39T5 high output T5 lamp 34-3/8" 5" 1-1/8" 247.40$ 186.00$
SFHP154 48" Little Inch for 1/F54T5 high output T5 lamp 46-1/4" 5" 1-1/8" 247.40$ 186.00$
277Volt Available Lamps Included
PREMIUM T5 STAINLESS STEEL CONSTRUCTION
SSSFHP114 24" Little Inch for 1/F14T5 premium T5 lamp 22-1/2" 5" 1-1/8" 282.60$ 212.50$
SSSFHP121 36" Little Inch for 1/F21T5 premium T5 lamp 34-3/8" 5" 1-1/8" 405.40$ 304.80$
SSSFHP128 48" Little Inch for 1/F28T5 premium T5 lamp 46-1/4" 5" 1-1/8" 405.40$ 304.80$
277Volt Available Lamps Included
T5 HIGH OUTPUT STAINLESS STEEL CONSTRUCTION
SSSFHP124 24" Little Inch for 1/F24T5 high output T5 lamp 22-1/2" 5" 1-1/8" 303.90$ 228.50$
SSSFHP139 36" Little Inch for 1/F39T5 high output T5 lamp 34-3/8" 5" 1-1/8" 428.50$ 322.20$
SSSFHP154 48" Little Inch for 1/F54T5 high output T5 lamp 46-1/4" 5" 1-1/8" 428.50$ 322.20$
277Volt Available Lamps Included
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color termperature is 3000K
/35 3500K lamp substituted for standard 3000K lamp N/C N/C
/41 4100K lamp substituted for standard 3000K lamp N/C N/C
OPTIONAL EQUIPMENT (Add as suffix)
/CO-W White Grounded Convenience Outlet 4.90$ 3.70$
/CS-3-W 6' White UL Labeled 3-Wire Cordset 12.00$ 9.00$
/DIM Dimming ballast (use with analog 0-10 volt fluorescent
/RSW Rocker Switch (for replacement use HP-RSW) 4.70$ 3.50$
/SLO-BLO GMF Slow-Blow Fuse and Fuse Holder 11.00$ 8.30$
REPLACEMENT FOR STANDARD PRISMATIC DIFFUSER
SF114 24" Prismatic Diffuser only for SFHP114/124 6.90$ 5.20$
SF121 36" Prismatic Diffuser only for SFHP121/139 6.90$ 5.20$
SF128 48" Prismatic Diffuser only for SFHP128/154 6.90$ 5.20$
REPLACEMENT FOR BATWING LENS
ABW114 24" Batwing Lens only for SFHP114/124 15.70$ 11.80$
ABW121 36" Batwing Lens only for SFHP121/139 15.70$ 11.80$
ABW128 48" Batwing Lens only for SFHP128/154 15.70$ 11.80$
Not available with SFHP124, SFHP139, SSSFHP124 & SSSFHP139
Description
NAME BRAND 3000K LAMP INCLUDED
REAR ACCESS PLATE INCLUDED
GOLD PROGRAM PRODUCT
Dimensions
Contact Representative
dimming control supplied by others)
71 08/06/2012
Task/Accent Little Inch
1" Multi-Function Task Light
T5 Fluorescent
TA Series
Catalog Shpg Cont. Dist.
Number L W D
Wt. Price Price
WHITE BAKED ENAMEL FINISH
TA2113 21" Task/Accent Little Inch for 2/F13T5 21 3/4" 5" 1 1/8"
5.5 222.00$ 166.90$
TA2116 24" Task/Accent Little Inch for 4/F8T5 25 1/4" 5" 1 1/8"
6.5 236.20$ 177.60$
TA2138 33" Task/Accent Little Inch for 2/F8T5 & 34 1/4" 5" 1 1/8"
8.25 313.70$ 235.90$
2/F13T5
TA2213 42" Task/Accent Little Inch for 4/F13T5 43 1/4" 5" 1 1/8"
9.5 368.80$ 277.30$
277Volt Not Available Warm White Lamps Included
OPTIONAL EQUIPMENT (Add as suffix)
/2-RSW (2) Fixture Mounted Rocker Switch (for replacement use HP-RSW) 9.30$ 7.00$
/CO-W White Grounded Convenience Outlet 4.90$ 3.70$
/CS-3-W
6' White UL Labeled 3-Wire Cordset
12.00$ 9.00$
/SLO-BLO GMF Slow-Blow Fuse and Fuse Holder 11.00$ 8.30$
OPTIONAL FACTORY INSTALLED TRI-PHOSPHOR T5 LAMPS IN PLACE OF STANDARD WARM WHITE LAMPS
F13-T5/30K F13T5 13 WATT 3000K T5 PER LAMP 4.70$ 3.50$
REORDER TRI-PHOSPHOR T5 LAMPS
F13-T5/30K
F13T5 13 WATT 3000K T5
PER LAMP 7.20$ 7.20$
REPLACEMENT FOR STANDARD DIFFUSER
TA13 21" Dual Distribution Lens only for TA2113 13.30$ 10.00$
TA16 25" Dual Distribution Lens only for TA2116 13.30$ 10.00$
TA38 34" Dual Distribution Lens only for TA2138 13.30$ 10.00$
TA23 43" Dual Distribution Lens only for TA2213 13.30$ 10.00$
NAME BRAND WARM WHITE LAMP INCLUDED
GOLD PROGRAM PRODUCT
Dimensions
Description
08/06/2012 72
Super Inch
1-1/2" Task Light
T8 Fluorescent
SI300 Series
Catalog Shpg Cont. Dist.
Number L W D
Wt. Price Price
WHITE BAKED ENAMEL FINISH
317 2' for 1/F17T8 Octron lamp 24 1/16" 5 7/16" 1 9/16" 7155.30$ 116.80$
325 3' for 1/F25T8 Octron lamp 36 1/16" 5 7/16" 1 9/16" 8.5 187.30$ 140.80$
332 4' for 1/F32T8 Octron lamp 48 1/16" 5 7/16" 1 9/16" 13 221.20$ 166.30$
277Volt Available Below Lamps Included
STAINLESS STEEL CONSTRUCTION
SS317 2' for 1/F17T8 Octron lamp 24 1/16" 5 7/16" 1 9/16" 7237.00$ 178.20$
SS325 3' for 1/F25T8 Octron lamp 36 1/16" 5 7/16" 1 9/16" 8.5 273.00$ 205.30$
SS332 4' for 1/F32T8 Octron lamp 48 1/16" 5 7/16" 1 9/16" 13 333.40$ 250.70$
277Volt Available Below Lamps Included
OPTIONAL OPAQUE FRONT TASK LENS (Add as suffix)
/OF Opaque Front Task Lens 6.70$ 5.00$
OPTIONAL EQUIPMENT (Add as suffix)
/277V 277V Ballast 2.40$ 1.80$
/CO-W White Grounded Convenience Outlet (120V only) 4.90$ 3.70$
/CS-3-W 6' White UL Labeled 3-Wire Cordset (120V only) 12.00$ 9.00$
/RSP Radio Suppressor 23.70$ 17.80$
/RSW Rocker Switch (120V only--for replacement use HP-RSW) 4.70$ 3.50$
/SLO-BLO GMF Slow-Blow Fuse and Fuse Holder 11.00$ 8.30$
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp N/C N/C
/41 4100K lamp substituted for standard 3500K lamp N/C N/C
REPLACEMENT FOR STANDARD DIFFUSER
A317 24" Alkcorylic Diffuser only for 317 8.00$ 6.00$
A325 36" Alkcorylic Diffuser only for 325 8.00$ 6.00$
A332 48" Alkcorylic Diffuser only for 332 8.00$ 6.00$
REPLACEMENT FOR OPAQUE FRONT TASK LENS
O317 24" Opaque Front Task Lens only for 317 14.60$ 11.00$
O325 36" Opaque Front Task Lens only for 325 14.60$ 11.00$
O332 48" Opaque Front Task Lens only for 332 14.60$ 11.00$
REAR ACCESS PLATE INCLUDED
GOLD PROGRAM PRODUCT
Description
Dimensions
3500K NAME BRAND LAMP INCLUDED
73 08/06/2012
Solid Front Super Inch
1-1/2" Solid Front Task Light
T8 Fluorescent
SF300 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
WHITE BAKED ENAMEL FINISH
SF317 2' for 1/F17T8 Octron lamp
24 1/16"
5 7/16" 1 9/16" 7184.50$ 138.70$
SF325 3' for 1/F25T8 Octron lamp
36 1/16"
5 7/16" 1 9/16" 8.5 218.10$ 164.00$
SF332 4' for 1/F32T8 Octron lamp
48 1/16"
5 7/16" 1 9/16" 13 237.00$ 178.20$
277Volt Available Below Lamp Included
OPTIONAL BATWING LENS (Add as suffix)
/BW Batwing Lens 6.70$ 5.00$
OPTIONAL EQUIPMENT (Add as suffix)
/277V 277V Ballast 2.40$ 1.80$
/CO-W White Grounded Convenience Outlet (120V only) 4.90$ 3.70$
/CS-3-W 6' White UL Labeled 3-Wire Cordset (120V only) 12.00$ 9.00$
/RSP Radio Suppressor 23.70$ 17.80$
/RSW Rocker Switch (120V only--for replacement use HP-RSW) 4.70$ 3.50$
/SLO-BLO GMF Slow-Blow Fuse and Fuse Holder 11.00$ 8.30$
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp N/C N/C
/41 4100K lamp substituted for standard 3500K lamp N/C N/C
REPLACEMENT FOR STANDARD LENS
P317 24" Prismatic Lens only for SF317 6.90$ 5.20$
P325 36" Prismatic Lens only for SF325 6.90$ 5.20$
P332 48" Prismatic Lens only for SF332 6.90$ 5.20$
REAR ACCESS PLATE INCLUDED
Description
Dimensions
GOLD PROGRAM PRODUCT
3500K NAME BRAND LAMP INCLUDED
08/06/2012 74
Inchline
1" Profile Undercabinet/Display Light
T5 Fluorescent
ILF Series
Catalog Shpg Cont. Dist.
Number L* W D Wt. Price Price
1 INCHLINE PREMIUM T5 LUMINAIRE WITH SINGLE LAMP REMOTE BALLAST ENCLOSURE
ILF114
Inchline Luminaire for 1/F14T5 premium lamp
25 15/16"
1 1/2" 1 1/8" 258.60$ 194.40$
ILF121
Inchline Luminaire for 1/F21T5 premium lamp
37 5/8" 1 1/2" 1 1/8" 285.80$ 214.90$
ILF128
Inchline Luminaire for 1/F28T5 premium lamp
49 7/16" 1 1/2" 1 1/8" 316.00$ 237.60$
ILF135
Inchline Luminaire for 1/F35T5 premium lamp
61 1/4" 1 1/2" 1 1/8" 349.00$ 262.40$
*Length dimension for rear-feed option. For universal end-feed, subtract 1 5/8".
Consult Factory for 277Volt Availability Lamps Included
2 INCHLINE LUMINAIRES WITH ONE, 2-LAMP REMOTE BALLAST ENCLOSURE
(separate conduit whips must be supplied to each luminaire.)
ILF114/2 Two Inchline Luminaires for 2/F14T5 lamps
25 15/16"
1 1/2" 1 1/8" 393.00$ 295.50$
ILF121/2 Two Inchline Luminaires for 2/F21T5 lamps 37 5/8" 1 1/2" 1 1/8" 453.80$ 341.20$
ILF128/2 Two Inchline Luminaires for 2/F28T5 lamps 49 7/16" 1 1/2" 1 1/8" 511.40$ 384.50$
ILF135/2 Two Inchline Luminaires for 2/F35T5 lamps 61 1/4" 1 1/2" 1 1/8" 569.00$ 427.80$
Please indicate feed locations for each luminaire. Example: ILF121/2/LR/RR
*Length dimension for rear-feed option. For universal end-feed, subtract 1 5/8".
Consult Factory for 277Volt Availability Lamps Included
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color termperature is 3000K
/35 3500K lamp substituted for standard 3000K lamp N/C N/C
/41 4100K lamp substituted for standard 3000K lamp N/C N/C
ELECTRICAL FEED LOCATION (
Must
specify as suffix--right or left locations as you face lamp)
/LR
Left Rear Feed N/C N/C
/LU Left Universal Feed *(subtract 1 5/8" from fixture length shown above) N/C N/C
/RR Right Rear Feed N/C N/C
/RU Right Universal Feed *(subtract 1 5/8" from fixture length shown above) N/C N/C
OPTIONAL DIFFUSERS
/DIF
Clear Linear Prism Diffuser
13.30$ 10.00$
REPLACEMENT FOR CLEAR LINEAR PRISM DIFFUSER
AILF114 (1) Clear Linear Prism Diffuser only for ILF114 13.30$ 10.00$
AILF121 (1) Clear Linear Prism Diffuser only for ILF121 13.30$ 10.00$
AILF128 (1) Clear Linear Prism Diffuser only for ILF128 13.30$ 10.00$
AILF135 (1) Clear Linear Prism Diffuser only for ILF135 13.30$ 10.00$
NAME BRAND 3000K LAMP INCLUDED
Please indicate feed locations for each luminaire. Example: ILF121/RR
Description
Dimensions
75 08/06/2012
Alkco-Lites
Wall/Shelf Mounted Luminaire
T8 Fluorescent
1000 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
WHITE BAKED ENAMEL FINISH
1126 1/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 235.10$ 176.80$
1136 1/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 12 282.60$ 212.50$
1146 1/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 15.5 292.70$ 220.10$
1226 2/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 266.00$ 200.00$
1236 2/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 12 301.80$ 226.90$
1246 2/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 15.5 312.80$ 235.20$
277Volt Available Below Lamps Included
STAINLESS STEEL CONSTRUCTION
1127 1/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 399.50$ 300.40$
1137 1/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 12 437.80$ 329.20$
1147 1/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 15.5 462.40$ 347.70$
1227 2/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 420.50$ 316.20$
1237 2/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 12 460.00$ 345.90$
1247 2/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 15.5 485.80$ 365.30$
277Volt Available Below Lamps Included
OPTIONAL EQUIPMENT (Add as suffix)
/277V 277 Volt 2.40$ 1.80$
/CO-W White Grounded Convenience Outlet (120V only) 4.90$ 3.70$
/CS-3-W 6' White UL Labeled 3-Wire Cordset (120V only) 12.00$ 9.00$
/RSP Radio Suppressor 23.70$ 17.80$
/RSW Rocker Switch (120V only) 4.70$ 3.50$
/SLO-BLO GMF Slow-Blow Fuse and Fuse Holder 11.00$ 8.30$
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp N/C N/C
/41 4100K lamp substituted for standard 3500K lamp N/C N/C
REPLACEMENT DIFFUSER
A26
24" Alkcorylic Diffuser only for 1126, 1226, 1127 or 1227
18.60$ 14.00$
A36
36" Alkcorylic Diffuser only for 1136, 1236, 1137 or 1237
18.60$ 14.00$
A46
48" Alkcorylic Diffuser only for 1146, 1246, 1147 or 1247
18.60$ 14.00$
Description
Dimensions
3500K NAME BRAND LAMP INCLUDED
ELECTRONIC BALLAST NOW STANDARD
08/06/2012 76
Alkco-Lites
Direct/Indirect Wall-Mounted Luminaire
T8 Fluorescent
2000 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
WHITE BAKED ENAMEL FINISH
2126 1/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 232.80$ 175.00$
2136 1/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 13 256.20$ 192.60$
2146 1/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 16 281.60$ 211.70$
2226 2/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 252.80$ 190.10$
2236 2/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 13 279.60$ 210.20$
2246 2/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 16 297.10$ 223.40$
277Volt Available Below Lamps Included
STAINLESS STEEL CONSTRUCTION
2127 1/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 402.10$ 302.30$
2137 1/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 13 433.40$ 325.90$
2147 1/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 16 460.00$ 345.90$
2227 2/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 422.90$ 318.00$
2237 2/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 13 455.50$ 342.50$
2247 2/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 16 485.80$ 365.30$
277Volt Available Below Lamps Included
OPTIONAL BATWING LENS (Add as suffix)
/BW Batwing Bottom Lens 6.70$ 5.00$
OPTIONAL EQUIPMENT (Add as suffix)
/277V 277 Volt 2.40$ 1.80$
/CO-W White Grounded Convenience Outlet (120V only) 4.90$ 3.70$
/CS-3-W 6' White UL Labeled 3-Wire Cordset (120V only) 12.00$ 9.00$
/RSP Radio Suppressor 23.70$ 17.80$
/RSW Rocker Switch (120V only) 4.70$ 3.50$
/SLO-BLO GMF Slow-Blow Fuse and Fuse Holder 11.00$ 8.30$
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp N/C N/C
/41 4100K lamp substituted for standard 3500K lamp N/C N/C
REPLACEMENT FOR STANDARD DIFFUSER
AC223 24" Acrylic Top Diffuser only for 2126, 2226, 2127 or 2227 7.60$ 5.75$
AC226 24" Acrylic Bottom Diffuser only for 2126, 2226, 2127 or 2227 10.30$ 7.75$
AC233 36" Acrylic Top Diffuser only for 2136, 2236, 2137 or 2237 7.60$ 5.75$
AC236 36" Acrylic Bottom Diffuser only for 2136, 2236, 2137 or 2237 10.30$ 7.75$
AC243 48" Acrylic Top Diffuser only for 2146, 2246, 2147 or 2247 7.60$ 5.75$
AC246 48" Acrylic Bottom Diffuser only for 2146, 2246, 2147 or 2247 10.30$ 7.75$
REPLACEMENT FOR BATWING LENS
ABW26 24" Batwing Bottom Lens only for 2126, 2226, 2127 or 2227 15.70$ 11.80$
ABW36 36" Batwing Bottom Lens only for 2136, 2236, 2137 or 2237 15.70$ 11.80$
ABW46 48" Batwing Bottom Lens only for 2146, 2246, 2147 or 2247 15.70$ 11.80$
Description
Dimensions
3500K NAME BRAND LAMP INCLUDED
77 08/06/2012
Alkco-Lites
Solid Front Wall/Shelf Mounted Luminaire
T8 Fluorescent
3000 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
WHITE BAKED ENAMEL FINISH
3116 1/F15T8 HPF Rapid Start 18 1/8" 6 3/4" 2 7/8" 9 187.00$ 140.60$
3126 1/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 196.30$ 147.60$
3136 1/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 13 227.30$ 170.90$
3146 1/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 15.5 241.10$ 181.30$
3226 2/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 230.80$ 173.50$
3236 2/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 13 249.80$ 187.80$
3246 2/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 15.5 273.30$ 205.50$
277Volt Available Below Lamps Included
STAINLESS STEEL CONSTRUCTION
3127 1/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 395.80$ 297.60$
3137 1/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 13 430.70$ 323.80$
3147 1/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 15.5 458.30$ 344.60$
3227 2/F17T8 HPF Rapid Start 24 1/8" 6 3/4" 2 7/8" 10 424.80$ 319.40$
3237 2/F25T8 HPF Rapid Start 36 1/8" 6 3/4" 2 7/8" 13 454.20$ 341.50$
3247 2/F32T8 HPF Rapid Start 48 1/8" 6 3/4" 2 7/8" 15.5 478.50$ 359.80$
277Volt Available Below Lamps Included
OPTIONAL BATWING LENS (Add as suffix)
/BW Batwing Lens for 3116 6.70$ 5.00$
OPTIONAL EQUIPMENT (Add as suffix)
/277V 277 Volt 2.40$ 1.80$
/CO-W White Grounded Convenience Outlet (120V only) 4.90$ 3.70$
/CS-3-W 6' White UL Labeled 3-Wire Cordset (120V only) 12.00$ 9.00$
/RSP Radio Suppressor 23.70$ 17.80$
/RSW Rocker Switch (120V only) 4.70$ 3.50$
/SLO-BLO GMF Slow-Blow Fuse and Fuse Holder 11.00$ 8.30$
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color temperature is 3500K
/30 3000K lamp substituted for standard 3500K lamp N/C N/C
/41 4100K lamp substituted for standard 3500K lamp N/C N/C
REPLACEMENT FOR STANDARD DIFFUSER
P16 18" Acrylic Diffuser only for 3116 10.30$ 7.75$
P26 24" Acrylic Diffuser only for 3126, 3226, 3127 or 3227 10.30$ 7.75$
P36 36" Acrylic Diffuser only for 3136, 3236, 3137 or 3237 10.30$ 7.75$
P46 48" Acrylic Diffuser only for 3146, 3246, 3147 or 3247 10.30$ 7.75$
REPLACEMENT FOR BATWING LENS
ABW31 18" Batwing Lens only for 3116 15.70$ 11.80$
ABW26 24" Batwing Lens only for 3126, 3226, 3127 or 3227 15.70$ 11.80$
ABW36 36" Batwing Lens only for 3136, 3236, 3137 or 3237 15.70$ 11.80$
ABW46 48" Batwing Lens only for 3146, 3246, 3147 or 3247 15.70$ 11.80$
3500K NAME BRAND LAMP INCLUDED
Description
Dimensions
08/06/2012 78
Quick Inch
Economy Task Light
T5 Fluorescent
Q100 Series
Shpg Cont. Dist.
L* W D Wt. Price Price
Q108-RSW-L-ECB 12" w/ switch & 1/F8T5 lamp 12 1/2"
4 5/8" 1 9/16" 2 41.60$ 31.30$
Q113-RSW-L-ECB 21" w/ switch & 1/F13T5 lamp 21 1/2"
4 5/8" 1 9/16" 3 66.20$ 49.80$
Q116-RSW-L-ECB 24" w/ switch & 2/F8T5 lamps 24 3/4"
4 5/8" 1 9/16" 3 68.50$ 51.50$
Q138-RSW-L-ECB 33" w/ switch and 1/F8T5 & 33 3/4"
4 5/8" 1 9/16" 4 90.60$ 68.10$
1/F13T5 lamps
Q213-RSW-L-ECB 42" w/ switch & 2/F13T5 lamps 42 3/4"
4 5/8" 1 9/16" 4 106.80$ 80.30$
277Volt Not Available Lamps Included
AQ-8 12" Alkcorylic Diffuser only for Q108 0.5 5.00$ 3.75$
AQ-13 21" Alkcorylic Diffuser only for Q113 1 5.00$ 3.75$
AQ-16 24" Alkcorylic Diffuser only for Q116 1 5.00$ 3.75$
AQ-38 33" Alkcorylic Diffuser only for Q138 1.5 5.00$ 3.75$
AQ-23 42" Alkcorylic Diffuser only for Q213 2 5.00$ 3.75$
ELECTRONIC BALLAST NOW STANDARD
GOLD PROGRAM PRODUCT
Number
REPLACEMENT DIFFUSERS
Description
QUICK INCH W/ ROCKER SWITCH AND WARM WHITE LAMPS
* add 3/8" for each exposed mounting ear in single and row mount
Dimensions
Catalog
79 08/06/2012
EcoInch
Economy Extruded Aluminum Task Light
T5 Fluorescent
ECO Series
Catalog Shpg Cont. Dist.
Number L W D
Wt. Price Price
FLUORESCENT WITH ROCKER SWITCH STANDARD
ECO108
12" for 1/F8T5 No Rear Access Plate 12 5/8" 5 3/8" 1 1/4" 241.90$ 31.50$
ECO113 21" for 1/F13T5 21 5/8" 5 3/8" 1 1/4"
366.20$ 49.80$
ECO116 24" for 2/F8T5 24 7/8" 5 3/8" 1 1/4"
3 1/2 68.50$ 51.50$
ECO138 33" for 1/F8T5 & 1/F13T5 33 7/8" 5 3/8" 1 1/4"
4 1/2 90.60$ 68.10$
ECO213 42" for 2/F13T5 42 7/8" 5 3/8" 1 1/4"
6106.70$ 80.20$
277Volt Not Available Warm White Lamps and Rocker Switch Included
/CS-3-W 6' White 3-wire cordset 12.00$ 9.00$
REPLACEMENT FOR STANDARD ALKCORYLIC DIFFUSER
AECO8 12" Alkcorylic Diffuser only for ECO108 8.00$ 6.00$
AECO13 21" Alkcorylic Diffuser only for ECO113 8.00$ 6.00$
AECO16 24" Alkcorylic Diffuser only for ECO116 8.00$ 6.00$
AECO38 33" Alkcorylic Diffuser only for ECO138 8.00$ 6.00$
AECO23 42" Alkcorylic Diffuser only for ECO213 8.00$ 6.00$
NAME BRAND WARM WHITE LAMP INCLUDED
REAR ACCESS PLATE INCLUDED
OPTIONAL EQUIPMENT (add as a suffix)
Description
Dimensions
GOLD PROGRAM PRODUCT
Only Available in Standard White Finish
08/06/2012 80
EcoInch FROSTED GLASS LENS STANDARD
Economy Extruded Aluminum Task Light
REAR ACCESS PLATE INCLUDED
Halogen (12v and 120v)
GOLD PROGRAM PRODUCT
ECOH/ECOHLV Series
Catalog Shpg Cont. Dist.
Number Description L W D
Wt. Price Price
120V LINE
VOLTAGE HALOGEN
ECOH8
8" for 1 lamp No Rear Access Plate
8" 5 3/8" 1 1/4" 2 32.20$ 24.20$
ECOH17 17" for 2 lamps 17" 5 3/8" 1 1/4" 3 44.00$ 33.10$
ECOH23 23" for 3 lamps 23" 5 3/8" 1 1/4" 4 57.60$ 43.30$
ECOH31 31" for 4 lamps 31" 5 3/8" 1 1/4" 5 74.50$ 56.00$
277Volt Not Available 20 Watt Halogen Lamps and Hi-Lo-Off Rocker Switch Included
12V LOW
VOLTAGE HALOGEN
ECOHLV8
8" for 1 lamp No Rear Access Plate
8" 5 3/8" 1 1/4" 43.90$ 33.00$
ECOHLV17 17" for 2 lamps 17" 5 3/8" 1 1/4" 51.90$ 39.00$
ECOHLV23 23" for 3 lamps 23" 5 3/8" 1 1/4" 61.20$ 46.00$
ECOHLV31 31" for 4 lamps 31" 5 3/8" 1 1/4" 73.50$ 55.30$
277V Not Available 18w Xenon Lamps and Hi-Lo-Off Rocker Switch Included
/CS-3-W 6' White 3-wire cordset 12.00$ 9.00$
REPLACEMENT FOR STANDARD FROSTED GLASS DIFFUSER
AEH8 8" Frosted Glass Diffuser only for ECOH8 or ECOHLV8 14.00$ 10.50$
AEH17 17" Frosted Glass Diffuser only for ECOH17 or ECOHLV17 14.00$ 10.50$
AEH23 23" Frosted Glass Diffuser only for ECOH23 or ECOHLV23 14.00$ 10.50$
AEH31 31" Frosted Glass Diffuser only for ECOH31 or ECOHLV31 14.00$ 10.50$
EcoInch FROSTED GLASS LENS STANDARD
Economy Extruded Aluminum Task Light
REAR ACCESS PLATE INCLUDED
Xenon (12v)
GOLD PROGRAM PRODUCT
ECOX Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
XENON
ECOX8
8" for 1 lamp, No Rear Access Plate 8" 5 3/8" 1 1/4" 2 45.10$ 33.90$
ECOX17 17" for 2 lamps 17" 5 3/8" 1 1/4" 3 53.30$ 40.10$
ECOX23 23" for 3 lamps 23" 5 3/8" 1 1/4" 4 63.00$ 47.40$
ECOX31 31" for 4 lamps 31" 5 3/8" 1 1/4" 5.5 75.90$ 57.10$
277V Not Available 18w Xenon Lamps and Hi-Lo-Off Rocker Switch Included
/CS-3-W 6' White 3-wire cordset 12.00$ 9.00$
REPLACEMENT FOR STANDARD FROSTED GLASS DIFFUSER
AEX8 8" Frosted Glass Diffuser for ECOX8 14.00$ 10.50$
AEX17 17" Frosted Glass Diffuser for ECOX17 14.00$ 10.50$
AEX23 23" Frosted Glass Diffuser for ECOX23 14.00$ 10.50$
AEX31 31" Frosted Glass Diffuser for ECOX31 14.00$ 10.50$
OPTIONAL EQUIPMENT (add as a suffix)
Dimensions
Description
Dimensions
OPTIONAL EQUIPMENT (add as a suffix)
Only Available in Standard White Finish
Only Available in Standard White Finish
Available in Standard White Finish
81 08/06/2012
SoftLook
Semi-Recessed Luminaire
LED
SL1 Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
SoftLook
SL118 24 white LED's 18" 3 1/2" 3 3/8"
SL124 36 white LED's 24" 3 1/2" 3 3/8"
SL130 48 white LED's 30" 3 1/2" 3 3/8"
SL136 60 white LED's 36" 3 1/2" 3 3/8"
301 3000K
120
277
AVAILABLE FINISHES (Must add as suffix--Consult factory for delivery on extra cost finishes)
/SWH Soft White
/TPE Taupe
/AL Aluminum
/CC Custom Color
NEW PRODUCT
Voltage
Dimensions
Description
LED Color Temperature
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
08/06/2012 82
Tableau
Adjustable Linear Luminaire
Fluorescent
TAB Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
TABLEAU
TAB126*
for 1/F26DTT lamp (not included)13 1/4" 3 3/8" 3 3/8"
TAB117 for 1/F17T8 lamp 29 5/8" 3 3/8" 3 3/8" 5
TAB125 for 1/F25T8 lamp 41 5/8" 3 3/8" 3 3/8" 7
TAB132 for 1/F32T8 lamp 53 11/16" 3 3/8" 3 3/8" 8
TAB114* for 1/F14T5 lamp 27 5/8" 3 3/8" 3 3/8" 5
TAB121* for 1/F21T5 lamp 39 7/16" 3 3/8" 3 3/8" 7
TAB128* for 1/F28T5 lamp 51 1/64" 3 3/8" 3 3/8" 8
TAB124* for 1/F24T5/HO lamp 27 5/8" 3 3/8" 3 3/8" 5
TAB139* for 1/F39T5/HO lamp 39 7/16" 3 3/8" 3 3/8" 7
TAB154* for 1/F54T5/HO lamp 51 1/64" 3 3/8" 3 3/8" 8
* Rocker Switch standard unless /LS is specified below.
277Volt Available Below Lamps Included
/ASY Asymmetric
/SYM Symmetric
AVAILABLE FINISHES (Must add as suffix--Consult factory for delivery on extra cost finishes)
/SWH Soft White
/AL Aluminum
/BA Brushed Aluminum
/PC Polished Chrome
/CC Custom Color
OPTIONAL DIFFUSER (Add as Suffix)
/CL Clear Lens
/LS Less Switch
OPTIONAL ELECTRICAL EQUIPMENT (Add as Suffix)
/277V 277 Volt (fixture supplied without RSW)
277 Volt not available for TAB126
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color termperature is 3000K
/35 3500K lamp substituted for standard 3000K lamp
/41 4100K lamp substituted for standard 3000K lamp
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
NAME BRAND 3000K LAMP INCLUDED
Description
Dimensions
STYLE (Must add as suffix)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
83 08/06/2012
Lincandescent
Surface-Mounted Linear Accent Luminaire
Incandescent
LIN Series
Catalog Shpg Cont. Dist.
Number Description L W D Wt. Price Price
60 WATT
LIN20ES-L Etched Silver
19 11/16"
1 3/4" 2 3/4" 3 228.40$ 171.70$
LIN20EG-L Etched Gold
19 11/16"
1 3/4" 2 3/4" 3 228.40$ 171.70$
LIN20EB-L Etched Black
19 11/16"
1 3/4" 2 3/4" 3 246.40$ 185.30$
LIN20PC-L Polished Chrome
19 11/16"
1 3/4" 2 3/4" 3 265.60$ 199.70$
LIN20PG-L Polished Gold
19 11/16"
1 3/4" 2 3/4" 3 265.60$ 199.70$
LIN20PB-L Polished Black
19 11/16"
1 3/4" 2 3/4" 3 260.30$ 195.70$
LIN20WBE-L White Baked Enamel
19 11/16"
1 3/4" 2 3/4" 3 228.40$ 171.70$
277Volt Not Available Lamps Included
150 WATT
LIN40ES-L Etched Silver 39 3/8" 1 3/4" 2 3/4" 4 320.50$ 241.00$
LIN40EG-L Etched Gold 39 3/8" 1 3/4" 2 3/4" 4 320.50$ 241.00$
LIN40EB-L Etched Black 39 3/8" 1 3/4" 2 3/4" 4 340.90$ 256.30$
LIN40PC-L Polished Chrome 39 3/8" 1 3/4" 2 3/4" 4 367.90$ 276.60$
LIN40PG-L Polished Gold 39 3/8" 1 3/4" 2 3/4" 4 367.90$ 276.60$
LIN40PB-L Polished Black 39 3/8" 1 3/4" 2 3/4" 4 352.50$ 265.00$
LIN40WBE-L White Baked Enamel 39 3/8" 1 3/4" 2 3/4" 4 320.50$ 241.00$
277Volt Not Available Lamps Included
OPTIONAL TRIANGULAR REFLECTOR (Price Per (1) Reflector)
TR20ES Etched Silver for use with LIN20 0.75 40.90$ 30.75$
TR20EG Etched Gold for use with LIN20 0.75 40.90$ 30.75$
TR20EB Etched Black for use with LIN20 0.75 48.70$ 36.65$
TR20PC Polished Chrome for use with LIN20 0.75 53.50$ 40.20$
TR20PG Polished Gold for use with LIN20 0.75 53.50$ 40.20$
TR20PB Polished Black for use with LIN20 0.75 62.40$ 46.95$
TR20WBE White Baked Enamel for use with LIN20 0.75 40.90$ 30.75$
TR40ES Etched Silver for use with LIN40 1.5 54.60$ 41.05$
TR40EG Etched Gold for use with LIN40 1.5 54.60$ 41.05$
TR40EB Etched Black for use with LIN40 1.5 62.40$ 46.95$
TR40PC Polished Chrome for use with LIN40 1.5 68.60$ 51.55$
TR40PG Polished Gold for use with LIN40 1.5 68.60$ 51.55$
TR40PB Polished Black for use with LIN40 1.5 77.90$ 58.60$
TR40WBE White Baked Enamel for use with LIN40 1.5 54.60$ 41.05$
REPLACEMENT LAMPS
L20 60 Watt Linear Incandescent Lamp 27.50$ 20.70$
L40 150 Watt Linear Incandescent Lamp 32.60$ 24.50$
OPTIONAL EQUIPMENT (Add as suffix)
/CS-3-B 6' Black UL labeled 3-Wire Cordset 12.00$ 9.00$
/LIN-CP* Outlet Box Cover Plate, Anodized Aluminum 8.80$ 6.60$
/LIN-CP-WBE Outlet Box Cover Plate, White Baked Enamel 6.00$ 4.50$
* Specify ES, EG, EB, PS, PG or PB for desired finish
Dimensions
LAMP INCLUDED
GOLD PROGRAM PRODUCT
NOTE: Use of (1) Reflector allows fixture to cover 2" Outlet Box, Use of (2) Reflectors allows fixture to cover 4" Outlet
Box
08/06/2012 84
Lincandescent
Recessed Linear Accent Luminaire
Incandescent
RL Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
60 WATT
RL20ES-L Etched Silver
19 11/16"
2" 2 7/8" 3 241.10$ 181.30$
RL20EG-L Etched Gold
19 11/16"
2" 2 7/8" 3 241.10$ 181.30$
RL20EB-L Etched Black
19 11/16"
2" 2 7/8" 3 263.30$ 198.00$
RL20PC-L Polished Chrome
19 11/16"
2" 2 7/8" 3 283.80$ 213.40$
RL20PG-L Polished Gold
19 11/16"
2" 2 7/8" 3 283.80$ 213.40$
RL20PB-L Polished Black
19 11/16"
2" 2 7/8" 3 274.20$ 206.20$
RL20WBE-L White Baked Enamel
19 11/16"
2" 2 7/8" 3 241.10$ 181.30$
277Volt Not Available Lamps Included
150 WATT
RL40ES-L Etched Silver 39 3/8" 2" 2 7/8" 4 342.30$ 257.40$
RL40EG-L Etched Gold 39 3/8" 2" 2 7/8" 4 342.30$ 257.40$
RL40EB-L Etched Black 39 3/8" 2" 2 7/8" 4 364.30$ 273.90$
RL40PC-L Polished Chrome 39 3/8" 2" 2 7/8" 4 392.90$ 295.40$
RL40PG-L Polished Gold 39 3/8" 2" 2 7/8" 4 392.90$ 295.40$
RL40PB-L Polished Black 39 3/8" 2" 2 7/8" 4 377.60$ 283.90$
RL40WBE-L White Baked Enamel 39 3/8" 2" 2 7/8" 4 342.30$ 257.40$
277Volt Not Available Lamps Included
OPTIONAL CUSTOM LENGTH (Add as suffix)
Custom Length Charge
97.50$ 73.30$
Specify in fractional inches as required. Up to maximum of 12" longer than lamp per end.
Factory tolerances: +0 - 1/8"
Custom length is provided for finish trim only--not lamp.
Lamp will be centered in extrusion unless otherwise indicated.
For field mitering order a minimum of 3" extra length at end of fixtures.
Ordering Example: RL40 fixture in polished silver finish, lengthened to 50" with the lamp positioned off-center
8" from one end--RL40PS/50", lamp 8" from one end.
REPLACEMENT LAMPS
L20 60 Watt Linear Incandescent Lamp 27.50$ 20.70$
L40
150 Watt Linear Incandescent Lamp
32.60$ 24.50$
Custom Length Recessed Lincandescents are made to order, non-cancellable and
non-returnable
LAMP INCLUDED
GOLD PROGRAM PRODUCT
Description
Dimensions
85 08/06/2012
Mini Cove Strip
Low Profile Luminaire
T5/T5HO Fluorescent
MCS Series
Catalog Shpg Cont. Dist.
Number L W D
Wt. Price Price
MINI COVE STRIP/SINGLE PREMIUM T5 LAMP
MCS114 2' Mini-Cove Strip for 1/F14T5 22 7/8" 1 7/16" 2"
2
MCS121 3' Mini-Cove Strip for 1/F21T5 34 11/16" 1 7/16" 2"
4
MCS128 4' Mini-Cove Strip for 1/F28T5 46 1/2" 1 7/16" 2"
6
MCS135 5' Mini-Cove Strip for 1/F35T5 58 5/16" 1 7/16" 2"
8
MCS128/2 (1) MCS128 fixture w/ a 2-lamp ballast and 93" 1 7/16" 2"
12
(1) MCS128 less ballast for 2/F28T5
Consult Factory for 277Volt Availability Lamps Included
MINI COVE STRIP/SINGLE T5 HIGH OUTPUT LAMP
MCS124 2' Mini-Cove Strip for 1/F24T5 22 7/8" 1 7/16" 2"
2
MCS139 3' Mini-Cove Strip for 1/F39T5 34 11/16" 1 7/16" 2"
4
MCS154 4' Mini-Cove Strip for 1/F54T5 46 1/2" 1 7/16" 2"
6
Consult Factory for 277Volt Availability Lamps Included
OPTIONAL EQUIPMENT (Add as suffix)
/AR1 Asymmetric Accessory Reflector for Single Row Units
/AR2 Symmetric Accessory Reflector for Double Row Units
/DIM Dimming ballast (use with analog 0-10 volt fluorescent
dimming control supplied by others)
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color termperature is 3000K
/35 3500K lamp substituted for standard 3000K lamp
/41 4100K lamp substituted for standard 3000K lamp
Description
Dimensions
Not available with MCS124, MCS135, MCS139 & MCS128/2
NAME BRAND 3000K LAMP INCLUDED
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
08/06/2012 86
MT
4" Mini Troffer
T5/T5HO Fluorescent
MT Series
Catalog D I M E N S I O N S Shpg Cont. Dist.
Number L W D Wt. Price Price
MINI TROFFER/SINGLE PREMIUM T5 LAMP
MT114 Mini Troffer for 1/F14T5
22 13/16"
3 1/2" 3 3/8" 8
MT121 Mini Troffer for 1/F21T5
34 13/16"
3 1/2" 3 3/8" 12
MT128 Mini Troffer for 1/F28T5
46 13/16"
3 1/2" 3 3/8" 16
MT135 Mini Troffer for 1/F35T5
58 13/16"
3 1/2" 3 3/8" 20
Consult Factory for 277Volt Availability Lamps Included
MINI TROFFER/SINGLE T5 HIGH OUTPUT LAMP
MT124 Mini Troffer for 1/F24T5/HO
22 13/16"
3 1/2" 3 3/8"
MT139 Mini Troffer for 1/F39T5/HO
34 13/16"
3 1/2" 3 3/8"
MT154 Mini Troffer for 1/F54T5/HO
46 13/16"
3 1/2" 3 3/8"
Consult Factory for 277Volt Availability Lamps Included
OPTIONAL LOUVER (Add as suffix)
/LOUV 1/2" White Acrylic Cube Cell louver for MT114/124
/LOUV 1/2" White Acrylic Cube Cell louver for MT121/139
/LOUV 1/2" White Acrylic Cube Cell louver for MT128/154
/LOUV 1/2" White Acrylic Cube Cell louver for MT135
OPTIONAL EQUIPMENT (Add as suffix)
/DIM Dimming ballast (use with analog 0-10 volt fluorescent
OPTIONAL LAMP COLOR TEMPERATURE (Add as suffix) default color termperature is 3000K
/35 3500K lamp substituted for standard 3000K lamp
/41 4100K lamp substituted for standard 3000K lamp
REPLACEMENT DIFFUSERS AND LOUVERS
PA-MT114 Clear Prismatic Diffuser for MT114/124
PA-MT121 Clear Prismatic Diffuser for MT121/139
PA-MT128 Clear Prismatic Diffuser for MT128/154
PA-MT135 Clear Prismatic Diffuser for MT135
CL-MT114 1/2" Cube Cell Louver for MT114/124
CL-MT121 1/2" Cube Cell Louver for MT121/139
CL-MT128 1/2" Cube Cell Louver for MT128/154
CL-MT135 1/2" Cube Cell Louver for MT135
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
Description
Not available with MT124 & MT139
NAME BRAND 3000K LAMP INCLUDED
dimming control supplied by others)
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
87 08/06/2012
Recessed-Trak
Concealed Track Lighting System
Low Voltage Incandescent
RTN Series
Catalog Shpg Cont. Dist.
Number L W H Wt. Price Price
HOUSING
RTN2024 24" Housing with track 24" 12" 9" 15
RTN2036 36" Housing with track 36" 12" 9" 17
RTN2048 48" Housing with track 48" 12" 9" 20

Important Notes:
<
<
<
<
<
<
TRIM & YOKE SETS
RTN4023** 23" Trim Set 23 3/4" 6 1/2" 2
RTN4024 24" Trim Set 24" 6 1/2" 2
RTN4036 36" Trim Set 36" 6 1/2" 3
RTN4047** 47" Trim Set 47 3/4" 6 1/2" 4
RTN4048 48" Trim Set 48" 6 1/2" 4
RTN4096 96" Trim Set 96" 6 1/2" 6
** For use in 2' x 2' and 2' x 4' suspended tile ceiling lay-in applications.
END TRIM
RTN4501 1 3/8" 6 1/2" 1
INTERSECTIONS
RTN5001 "L" Intersection 9 1/4" 9 1/4" 5/8" 1
RTN5002 "T" Intersection 12" 9 1/4" 5/8" 1
RTN5003 "X" Intersection 12" 12" 5/8" 1
LIGHTMODULE
RTN7000 1
(20W-50W MR16 lamp provided by others)
ACCESSORIES
RTN9001 Uniformity Lens
RTN9002 Diffusion Lens
RTN9512 U.V. Blocking (Clear)
The Housing has increased in depth by 3/4".
End Trim
Lightmodule
Dimensions
Description
Lamps are not included.
System not available for 277 volts.
RTN Series replaces the RTS Series. The RTN Series uses a
line voltage track system with each Lightmodule having it's
own electronic transformer. RTN components are not
interchangeable with the RTS system.
If replacement additional components are required for an RTS
Installation, contact Alkco's Inside Sales team.
Lightmodules must be ordered separately. See below.
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
CONTACT YOUR LOCAL
SALES REPRESENTATIVE
FOR PRICING
08/06/2012 88
Edge-Glo
Exit Sign
T5 Fluorescent
RGLO/SGLO-FL SERIES
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
RECESSED FLUORESCENT HOUSINGS (120V)
RGLOFL1 AC only for 1/F8T5 lamp 16¼" 3" 3½" 94.30$ 70.90$
RGLOFL2 AC only for 2/F8T5 lamps 16¼" 3" 3½" 7 lbs. 116.00$ 87.20$
RGLOFLX1 AC with Lead Acid Battery for 1/F8T5 16¼" 3" 5¼" 256.70$ 193.00$
RGLOFLX2 AC with Lead Acid Battery for 2/F8T5 16¼" 3" 5¼" 278.40$ 209.30$
277Volt Available Below Lamps Included
SURFACE FLUORESCENT HOUSINGS (120V)
SGLOFL1 AC only for 1/F8T5 lamp 17 1/8" 4" 3 3/4" 105.60$ 79.40$
SGLOFL2 AC only for 2/F8T5 lamps 17 1/8" 4" 3 3/4" 127.40$ 95.80$
SGLOFLX1 AC with Lead Acid Battery for 1/F8T5 17 1/8" 4" 5 1/2" 268.00$ 201.50$
SGLOFLX2 AC with Lead Acid Battery for 2/F8T5 17 1/8" 4" 5 1/2" 289.50$ 217.70$
277Volt Available Below Lamps Included
OPTIONAL HOUSING FINISHES (Add as Suffix to housing catalog number. White is standard)
/MB Matte Black N/C N/C
/PB Polished Brass
/SS Brushed Stainless Steel 12.90$ 9.70$
HOUSING OPTIONS (Add as Suffix to housing catalog number. Ex: RGLOFLX1/277V)
/277V 277V ballast for 1-lamp fluorescent signs 2.40$ 1.80$
/277V 277V ballast for 2-lamp fluorescent signs 4.80$ 3.60$
MOUNTING OPTIONS
BSC Black Stem and Canopy* 21.30$ 16.00$
WSC White Stem and Canopy* 22.20$ 16.70$
PANEL & FACE PLATE ASSEMBLY
PGLO1 Single Panel & Face Plate Assembly 39.20$ 29.50$
PGLO2 Double Panel & Face Plate Assembly 66.60$ 50.10$
LETTER COLOR/BACKGROUND COLOR
CHEVRONS
GC (Green letters on Clear. Mirrored separator provided R (Chevron Right)
on double-face signs)
L (Chevron Left)
GW (Green letters on Clear w/ white back plate/separator)
D (Double Chevron)
RC (Red letters on Clear. Mirrored separator provided LR (Universal Left & Right Chevrons for
on double-face signs)
double-sided signs)
RW (Red letters on Clear w/ white back-plate/separator)
WG (White letters on Green)
FOR CITY OF CHICAGO ONLY
RWS (Red letters on White)
OPTIONAL FACEPLATE FINISHES (Add as Suffix to housing catalog number. White is standard)
/MB Matte Black N/C N/C
/PB Polished Brass
/SS Brushed Stainless Steel 12.90$ 9.70$
PANEL OPTIONS (Add as suffix to panel/faceplate catalog number. Example: PGLO1/RW/R/8"
/8" Eight Inch Lettering (panel height increases to Nine Inches) 4.00$ 3.00$
/CUSTOM Custom Messages, specify message (Example: "IN USE")
/WALL
Bent Panel for Recessed Wall Mount Installations
7.80$ 5.90$
/STAIRS "STAIRS" in place of "EXIT" (only available with Chicago Code style arrows)
N/C
N/C N/C
Dimensions
CONSULT FACTORY
RWS is the only color combination approved by Chicago Department of Buildings.
Note: For Chicago Code style arrows, add
an "A" to chevron designation. Example:
AR for arrow right. Panel height increases
to 9" with Chicago Code style arrows.
Description
CONSULT FACTORY
CONSULT FACTORY
*Specify Stem Length as 6", 12", 24" or 36". Example: BSC-12
Must add letter/background color & chevron information as suffix. Example: PGLO1/RW/R
89 08/06/2012
Edge-Glo
Exit Sign
LED
RGLO/SGLO-LED SERIES
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
RECESSED HOUSINGS WITH RED LED'S (120/277V DUAL TAP)
RGLOLED1R AC only for Single Face Panel Assm. 16¼" 3" 3½" 131.40$ 98.80$
RGLOLED2R AC only for Double Face Panel Assm. 16¼" 3" 3½" 6 lbs. 186.10$ 139.90$
RGLOLEDX1R AC with Lead Acid Battery for Single Face Panel Assm. 16¼" 3" 5¼" 251.50$ 189.10$
RGLOLEDX2R
AC with Lead Acid Battery for Double Face Panel Assm.
16¼" 3" 5¼" 282.80$ 212.60$
Fixtures are 120/277V Dual Tap Lamps Included
SURFACE HOUSINGS WITH RED LED'S (120/277V DUAL TAP)
SGLOLED1R AC only for Single Face Panel Assm. 17 1/8" 4" 3 3/4" 143.00$ 107.50$
SGLOLED2R AC only for Double Face Panel Assm. 17 1/8" 4" 3 3/4" 197.80$ 148.70$
SGLOLEDX1R AC with Lead Acid Battery for Single Face Panel Assm. 17 1/8" 4" 5 1/2" 262.30$ 197.20$
SGLOLEDX2R
AC with Lead Acid Battery for Double Face Panel Assm.
17 1/8" 4" 5 1/2" 293.70$ 220.80$
Fixtures are 120/277V Dual Tap Lamps Included
WHITE LED'S SUBSTITUTED FOR RED (Change last R in catalog # to W. Ex: RGLOLED1/W)
/W White LED's for LED1 and LEDX1 housings for single face panel assm. 33.30$ 25.00$
/W White LED's for LED2 and LEDX2 housings for double face panel assm. 66.50$ 50.00$
GREEN LED'S SUBSTITUTED FOR RED (Change last R in catalog # to G. Ex: RGLOLED1/G)
/G Green LED's for LED1 and LEDX1 housings for single face panel assm. 62.60$ 47.10$
/G Green LED's for LED2 and LEDX2 housings for double face panel assm. 125.30$ 94.20$
OPTIONAL HOUSING FINISHES (Add as Suffix to housing catalog number. White is standard)
/MB Matte Black N/C N/C
/PB Polished Brass
/SS Brushed Stainless Steel 12.90$ 9.70$
HOUSING OPTIONS (Add as Suffix to housing catalog number. Ex: RGLOFLX1/NICAD)
/2C
2-Circuit Relay (MUST SPECIFY VOLTAGE) 25.00$ 18.80$
/NICAD Nickel Cadmium Battery substituted for Lead Acid 31.30$ 23.50$
MOUNTING OPTIONS
BSC Black Stem and Canopy* 20.20$ 15.20$
WSC White Stem and Canopy* 20.20$ 15.20$
PANEL & FACE PLATE ASSEMBLY
PGLO1 Single Panel & Face Plate Assm. (must use w/ LED1 or 1X housings) 39.20$ 29.50$
PGLO2
Double Panel & Face Plate Assm. (must use w/ LED2 or 2X housings)
66.60$ 50.10$
LETTER COLOR/BACKGROUND COLOR CHEVRONS
GC (Green letters on Clear. Mirrored separator provided R (Chevron Right)
on double-face signs)
L (Chevron Left)
GW (Green letters on Clear w/ white back plate/separator) D (Double Chevron)
for LED signs only LR (Universal Left & Right Chevrons for
RC (Red letters on Clear. Mirrored separator provided
double-sided signs)
on double-face signs)
RW (Red letters on Clear w/ white back-plate/separator) for LED signs only
OPTIONAL FACEPLATE FINISHES (Add as Suffix to housing catalog number. White is standard)
/MB Matte Black N/C N/C
/PB Polished Brass
/SS Brushed Stainless Steel 12.90$ 9.70$
PANEL OPTIONS (Add as suffix to panel/faceplate catalog number. Example: PGLO1/RW/R/8"
/8" Eight Inch Lettering (panel height increases to Nine Inches) 4.00$ 3.00$
/CUSTOM Custom Messages, specify message (Example: "IN USE")
/STAIRS "STAIRS" in place of "EXIT" (only available with Chicago Code style arrows) N/C N/C
Contact Chicago Sales Representative for LED EXITs approved by Chicago Department of Buildings
Description
CONSULT FACTORY
Dimensions
Must add letter/background color & chevron information as suffix. Example: PGLO1/RW/R
CONSULT FACTORY
*Specify Stem Length as 6", 12", 24" or 36". Example: BSC-12
CONSULT FACTORY
08/06/2012 90
Edge-Glo
Exit Sign
LED
WGLO-LED SERIES
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
WALL RECESSED HOUSING AND PANEL ASSEMBLY with Red LED's (120/277V DUAL TAP)
WGLOLEDRC AC only with RED letters on CLEAR panel 15 3/8" 3 1/2" 11 5/8" 194.20$ 146.00$
WGLOLEDRW AC only with RED letters on CLEAR
panel with WHITE separator 15 3/8" 3 1/2" 11 5/8" 194.20$ 146.00$
WGLOLEDXRC AC with Ni-Cad Battery--RED letters
on CLEAR panel 15 3/8" 3 1/2" 11 5/8" 314.30$ 236.30$
WGLOLEDXRW AC with Ni-Cad Battery-- RED letters on
CLEAR panel with WHITE separator 15 3/8" 3 1/2" 11 5/8" 314.30$ 236.30$
Fixtures are 120/277V Dual Tap Lamps Included
WALL RECESSED HOUSING AND PANEL ASSEMBLY with Green LED's (120/277V DUAL TAP)
WGLOLEDGC AC only with GREEN letters on CLEAR panel 15 3/8" 3 1/2" 11 5/8" 268.00$ 201.50$
WGLOLEDGW AC only with GREEN letters on CLEAR
panel with WHITE separator 15 3/8" 3 1/2" 11 5/8" 268.00$ 201.50$
WGLOLEDXGC
AC with Ni-Cad Battery--GREEN letters
on CLEAR panel 15 3/8" 3 1/2" 11 5/8" 388.10$ 291.80$
WGLOLEDXGW AC with Ni-Cad Battery-- GREEN letters on
CLEAR panel with WHITE separator 15 3/8" 3 1/2" 11 5/8" 388.10$ 291.80$
Fixtures are 120/277V Dual Tap Lamps Included
PANEL OPTIONS (Add as suffix. Example: WGLOLEDXRC/8"/L
/8"
Eight Inch Lettering (panel height increases to Nine Inches)
4.00$ 3.00$
/CUSTOM Custom Messages, specify message (Example: "IN USE")
/DH Double Chevrons N/C N/C
/L Left Chevron N/C N/C
/R Right Chevron N/C N/C
/STAIRS "STAIRS" in place of "EXIT" (only available with Chicago Code style arrows) N/C N/C
OPTIONAL HOUSING FINISHES (Add as Suffix. White is standard)
/MB Matte Black N/C N/C
/PB Polished Brass
/SS Brushed Stainless Steel 11.70$ 8.80$
ELECTRICAL OPTIONS (Add as Suffix. Ex: WGLOLEDRC/L/2C)
/2C
2-Circuit Relay (MUST SPECIFY VOLTAGE) 25.00$ 18.80$
/AA Intermittent Audible Alarm (LEDX battery signs only) 39.20$ 29.50$
/FA Fire Alarm Interface 39.20$ 29.50$
/VA Intermittent Visual Alarm (LEDX battery signs only) 27.40$ 20.60$
Description
CONSULT FACTORY
CONSULT FACTORY
Dimensions
91 08/06/2012
Edge-Glo
Exit Sign
LED
RGLO-LEDWW Series
Catalog Shpg Cont. Dist.
Number Description L W D Wt. Price Price
120 or 277 Volt, AC
RGLO-LEDWW LED Retrofit Kit for use with 76.90$ 57.80$
Alkco Edge-Glo Exits
(120 or 277 volt, AC models only)
•The Retrofit Kit is a direct replacement for the original wireway
and works with the original sign's housing and faceplates.
Dimensions
(replaces wireway in the
original exit sign)
08/06/2012 92
EA
Exit Sign
Fluorescent
EA Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
SINGLE FACE
EA12FL2 Fluorescent EXIT for 2/F8T5 lamps 13 5/8" 3 3/4" 9" 8½ 256.20$ 192.60$
EA12PL2 PL Fluorescent EXIT for 2/F7PL7 lamps 13 5/8" 3 3/4" 9" 8½ 238.50$ 179.30$
277Volt Available Below Lamps Not Included
DOUBLE FACE
EA22FL2 Fluorescent EXIT for 2/F8T5 lamps 13 5/8" 3 3/4" 9" 9½ 306.60$ 230.50$
EA22PL2 PL Fluorescent EXIT for 2/F7PL7 lamps 13 5/8" 3 3/4" 9" 9½ 288.60$ 217.00$
277Volt Available Below Lamps Not Included
RECESSED SINGLE FACE
ERA12FL2 Fluorescent EXIT for 2/F8T5 lamps 14" 3 1/2" 9 3/4" 9½ 311.20$ 234.00$
ERA12PL2 PL Fluorescent EXIT for 2/F7PL7 lamps 14" 3 1/2" 9 3/4" 9½ 293.40$ 220.60$
277Volt Available Below Lamps Not Included
FLUORESCENT EXITS WITH EMERGENCY BATTERY PACK
EAX12FL2 Fluorescent EXIT for 2/F8T5 lamps 13 5/8" 3 3/4" 13 3/4" 9½ 614.70$ 462.20$
EAX22FL2 Fluorescent EXIT for 2/F8T5 lamps 13 5/8" 3 3/4" 13 3/4" 9½ 692.90$ 521.00$
277Volt Available Below Lamps Not Included
OPTIONAL PANELS
/STAIRS "STAIRS" in place of "EXIT" 13 5/8" 3 3/4" 13 3/4" 9½ N/C N/C
OPTIONAL EQUIPMENT (Add as Suffix)
/277V 277 Volt ballast for F8T5 fluorescent and battery pack signs 2.40$ 1.80$
/277V PL 277 Volt ballast for PL fluorescent signs 8.10$ 6.10$
/6V DC 6 Volt DC socket for incandescent signs 20.00$ 15.00$
/M277V 277 to 120 Volt step down transformer for incandescent signs 19.60$ 14.70$
/TP Tamper Proof oval-head screws 22.20$ 16.70$
/SLO-BLO GMF slow-blow fuse and fuse holder 11.00$ 8.30$
/WH Painted White housing N/C N/C
For additional Options, Mounting Equipment & Replacement Panels, See Page 94.
Description
Dimensions
Inscription Panels:
Double strength glass
panels, ceramic fired
for permanency.
Chicago Code glass
panels are available at
extra cost.
for arrow left; "DH" for
double-headed arrow. On
double face signs if arrows
are to point in one
direction, add "LR" (panels
are inter- changeable); if
arrows are to point in 2
directions add "2DH"
(double-headed arrow on
both faces). Unless
specified other- wise, NEC
style arrow- heads at ends
of sign will be provided.
Chicago Code config-
Housing Finish:
Matte Black is
standard. White or
special colors may be
specified. Contact
factory for prices.
uration with arrows underneath
lettering may be specified by
adding a "CC" Suffix.
Special Lettering: Color
combinations and exact wording
must be specified. Ex: EA12
reading "OUT", BLACK letters
on WHITE. Panels are custom
made to order and are non-
cancelable and non-returnable.
(If color is not specified, BLACK
letters on WHITE will be
supplied for special messages)
Lettering & Color
Combinations: 6" RED
letters on WHITE are
standard for EXIT. The
following color combinations
can be supplied upon
request at no additional cost:
GREEN letters on WHITE or
BLACK letters on WHITE.
Arrows: On single face
signs add--"R" to catalog
number for arrow right; "L"
93 08/06/2012
EA
Exit Sign
Fluorescent
EA Series
Catalog Cont. Dist.
Number Price Price
MOUNTING EQUIPMENT
PF10 Plaster frame for ERA12 16.10$ 12.10$
BSC Black Stem and Canopy* 22.70$ 17.10$
WSC White Stem and Canopy* 22.70$ 17.10$
*Specify stem length as 6", 12", 24" or 36". Example: BSC-12
REPLACEMENT EQUIPMENT FOR EA SPECIFIER SERIES
G10E Glass panel EXIT 29.80$ 22.40$
G10O Glass down light 14.40$ 10.80$
OPTIONAL SPECIAL MESSAGES PER PANEL (BLACK lettering on WHITE standard)
/BEAM ON
/IN USE
/READY
/CAUTION X-RAY
/LASER IN USE
/ROOM IN USE
/DARKROOM IN USE
/LASER ON
/TELEPHONE
/DO NOT ENTER
/MEN
/TO EXIT
/ELEVATORS
/OCCUPIED
/WOMEN
/EMERGENCY EXIT
/OPEN
/X-RAY IN USE
/RADIATION ON
111.10$ 83.50$
Note: Disappearing Letters available by request--for fluorescent fixtures only--at no additional charge.
(letters seem to disappear when fixture is not powered)
Description
When ordering, add on to EA Series fixture price
(adder is per panel, double for double face signs)
08/06/2012 94
XC
Exit Sign
LED
XC Series
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
LED CAST ALUMINUM EXITS
XCLED1 Single face less canopy, AC only 14" 8.13" 2.38" 327.80$ 246.50$
XCLED2 Double face w/ canopy, AC only 14" 8.13" 2.38" 384.80$ 289.30$
XCLEDX1 Single face less canopy, AC w/ lead acid battery 14" 8.13" 2.38" 398.70$ 299.80$
XCLEDX2 Doube face w/ canopy, AC w/ lead acid battery 14" 8.13" 2.38" 464.80$ 349.50$
120/277Volt Dual Tap Standard Lamps Included
OPTIONAL FINISHES (Add as Suffix. Black w/ brushed aluminum stencil face is standard)
/B All Matte Black Finish 7.80$ 5.90$
/W All Matte White Finish 18.80$ 14.10$
OPTIONAL EQUIPMENT (Add as Suffix)
/AA Intermittent Audible Alarm (battery signs only) 39.20$ 29.50$
/CUSTOM Custom Messages, specify "STAIRS" for example
/FA Fire Alarm Interface (battery signs only) 39.20$ 29.50$
/TP Tamper Proof Closure Screws 22.20$ 16.70$
/VA Intermittent Visual Alarm (battery signs only) 27.40$ 20.60$
MOUNTING EQUIPMENT
BSC Black Stem and Canopy* 20.20$ 15.20$
WSC White Stem and Canopy* 20.20$ 15.20$
Dimensions
CONSULT FACTORY
*Specify Stem Length as 6", 12", 24" or 36". Example: BSC-12
Please indicate color of letters by adding "R" for RED, or "G" for GREEN as suffix to catalog number. Ex: XCLED1/R
Description
95 08/06/2012
Architectural Message Sign
Single-Face Illuminated Signage
LED
AMS SERIES
Fixtures are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number Description L H D Wt. Price Price
AMS Single-face LED Sign 11" 8" 3.25" 412.00$ 309.80$
Note: Sign has black finish.
VOLTAGES
120 120 volts
277 277 volts 10.00$ 7.50$
FACE PANEL Cont. Dist.
COLOR Price Price
BW Black letters on a white background
RW Red letters on a white background
GW Green letters on a white background
DS1Disappearing Sign, Red letters on a black background
1Message is only visible when sign is illuminated. The sign panel
appears black in Off condition.
Cont. Dist.
STANDARD PANEL MESSAGES Price Price
ALERT LASER ON
BEAM ON MEN
CAUTION X-RAY OCCUPIED
DANGER LASER IN USE RADIATION ON
DARKROOM IN USE
READY
DO NOT ENTER RECORDING
DRY ROOM IN USE RESTROOMS
ELEVATORS
ROOM IN USE
EXAM ROOM IN USE SYSTEM READY
FIRE DO NOT ENTER TELEPHONE
IN USE TO EXIT
LADIES WOMEN
LASER IN USE X-RAY IN USE
OPTIONS
RFR Recessed frame 59.90$ 45.00$
CMB Ceiling mount bracket 39.90$ 30.00$
SMB Side mount bracket 39.90$ 30.00$
PMB
Pendant mount bracket
126.40$ 95.00$
FLASH Message flashing (60 times/min.) 126.40$ 95.00$
Included in Price
Included in Price
Dimensions
Included in Price
Included in Price
Included in Price
All messages
included in price
08/06/2012 96
Signal Light
Incandescent
207 Series
Signal Lights are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number L W D Wt. Price Price
INCANDESCENT SIGNAL LIGHT
207H Surface mount, horizontal, signal light 14" 7" 9" 6 679.00$ 510.50$
207V Surface mount, vertical, signal light 7" 14" 9" 6 679.00$ 510.50$
277Volt Not Available Lamps Included
OPTIONAL EQUIPMENT
/LE-G (1) Green LED Light Engine 139.70$ 105.00$
/LE-R (1) Red LED Light Engine 139.70$ 105.00$
/FLS Flasher (Specify alternating or steady flash) 216.90$ 163.10$
OPTIONAL MOUNTING EQUIPMENT
AMIH Angle Mount Horizontal (Dual Angle 30° & 45°) 3 146.20$ 109.90$
AMIV Angle Mount Vertical (Dual Angle 30° & 45°) 3 146.20$ 109.90$
BRK207 Wall or ceiling mounting bracket 3 67.30$ 50.60$
FR207 Aluminum flange for semi-recessed mounting 3 93.60$ 70.40$
P207 7' 6" Mounting post 12.5 251.50$ 189.10$
OPTIONAL SWITCHING EQUIPMENT
1SW 3-Position lighted indicator switch 57.50$ 43.20$
2SW 2-Gang, 3-Position lighted indicator switch 93.60$ 70.40$
3SW 3-Gang, 3-Position lighted indicator switch 126.40$ 95.00$
4SW 4-Gang, 3-Position lighted indicator switch 165.90$ 124.70$
5SW 5-Gang, 3-Position lighted indicator switch 208.70$ 156.90$
207
For LED lamped Signal Light, add the appropriate LED light engines listed below
Ex: 207H/LE-G/LE-R at $454.35 + 105.00 + 105.00 = $664.35
Dimensions
Description
97 08/06/2012
Blank Out Sign
LED
LD Series
LED Signage Systems are made to order, non-cancelable and non-returnable
Catalog Shpg Cont. Dist.
Number L H D Wt. Price Price
LED BLANK OUT SIGNAGE SYSTEMS
LD77 7" x 7" Sign 7" 7" 2½" 881.50$ 662.80$
LD718 7" x 18" Sign 18" 7" 2½" 1,167.60$ 877.90$
LD734 7" x 34" Sign 34" 7" 2½" 1,400.80$ 1,053.20$
LD742 7" x 42" Sign 42" 7" 2½" 1,959.10$ 1,473.00$
LD1026 10" x 26" Sign 26" 10" 2½" 1,498.80$ 1,126.90$
LD1212 12" x 12" Sign 12" 12" 2½" 1,332.10$ 1,001.60$
LD1818 18" x 18" Sign 18" 18" 2½" 1,273.10$ 957.20$
LD1418 14" x 18" Sign 18" 14" 2½" 1,253.80$ 942.70$
LD1434 14" x 34" Sign 34" 14" 2½" 3,134.50$ 2,356.80$
LD1442 14" x 42" Sign 42" 14" 2½"
277Volt Not Available Lamps Included
OPTIONAL EQUIPMENT (Add as Suffix)
Flasher (Specify alternating or steady
flash on muliple message signs)
OPTIONAL MOUNTING EQUIPMENT
AMLD Angle Mount (Dual Angle 30° & 45°) 3 178.90$ 134.50$
MB Ceiling Mount 378.90$ 59.30$
P1 Single Post Mount (for use with LD718, 1418, 1212 & 1818) 12.5 246.70$ 185.50$
P2 Double Post Mount (for use with LD734, 742 & 1434) 25 459.50$ 345.50$
RF Recessed Frame 3104.80$ 78.80$
OPTIONAL SWITCHING EQUIPMENT
1SW 3-Position lighted indicator switch 56.30$ 42.30$
2SW 2-Gang, 3-Position lighted indicator switch 91.80$ 69.00$
3SW 3-Gang, 3-Position lighted indicator switch 124.00$ 93.20$
4SW 4-Gang, 3-Position lighted indicator switch 162.80$ 122.40$
5SW 5-Gang, 3-Position lighted indicator switch 204.70$ 153.90$
SPECIAL MESSAGE OPTIONS
Consult Factory for Pricing
Description
/FLS
212.80$
160.00$
Dimensions
Contact Factory
Along with catalog number, specify message and message LED color.
Ex: LD718, Open (Green) Closed (Red) Please contact your local sales
representative for pricing if WHITE LEDs are required
LD
08/06/2012 98
LINCS
Replacement Diffusers
Catalog Cont. Dist.
Number Price Price
Replacement Lenses for LINCS100L LED
AT-L10 Acrylic Textured Lens for LINCS100-L10 8.80$ 6.60$
AT-L19 Acrylic Textured Lens for LINCS100-L19 8.80$ 6.60$
AT-L28 Acrylic Textured Lens for LINCS100-L28 8.80$ 6.60$
Replacement Diffusers for LINCS100F T5 Fluorescents
CL-F12 Clear Diffuser For LINCS100F12 8.80$ 6.60$
CL-F21 Clear Diffuser For LINCS100F21 8.80$ 6.60$
CL-F24 Clear Diffuser For LINCS100F24 8.80$ 6.60$
CL-F33 Clear Diffuser For LINCS100F33 8.80$ 6.60$
CL-F42 Clear Diffuser For LINCS100F42 8.80$ 6.60$
OF-F12 Opaque Front Diffuser For LINCS100F12 15.40$ 11.60$
OF-F21 Opaque Front Diffuser For LINCS100F21 15.40$ 11.60$
OF-F24 Opaque Front Diffuser For LINCS100F24 15.40$ 11.60$
OF-F33 Opaque Front Diffuser For LINCS100F33 15.40$ 11.60$
OF-F42 Opaque Front Diffuser For LINCS100F42 15.40$ 11.60$
WL-F12 Translucent White Diffuser For LINCS100F12 14.00$ 10.50$
WL-F21 Translucent White Diffuser For LINCS100F21 14.00$ 10.50$
WL-F24 Translucent White Diffuser For LINCS100F24 14.00$ 10.50$
WL-F33 Translucent White Diffuser For LINCS100F33 14.00$ 10.50$
WL-F42 Translucent White Diffuser For LINCS100F42 14.00$ 10.50$
Replacement Diffusers for LINCS100FS T5 or T5 HO Fluorescents
CL-FS23 Clear Diffuser For LINCS100FS23 or HO23 8.80$ 6.60$
CL-FS35 Clear Diffuser For LINCS100FS35 or HO35 8.80$ 6.60$
CL-FS46 Clear Diffuser For LINCS100FS46 or HO46 8.80$ 6.60$
CL-FS58 Clear Diffuser For LINCS100FS58 8.80$ 6.60$
OF-FS23 Opaque Front Diffuser For LINCS100FS23 or HO23 15.40$ 11.60$
OF-FS35 Opaque Front Diffuser For LINCS100FS35 or HO35 15.40$ 11.60$
OF-FS46 Opaque Front Diffuser For LINCS100FS46 or HO46 15.40$ 11.60$
OF-FS58 Opaque Front Diffuser For LINCS100FS58 15.40$ 11.60$
WL-FS23 Translucent White Diffuser For LINCS100FS23 or HO23 14.00$ 10.50$
WL-FS35 Translucent White Diffuser For LINCS100FS35 or HO35 14.00$ 10.50$
WL-FS46 Translucent White Diffuser For LINCS100FS46 or HO46 14.00$ 10.50$
WL-FS58 Translucent White Diffuser For LINCS100FS58 14.00$ 10.50$
Replacement Diffusers for LINCS150 O T8 Fluorescents
CL-O24 Clear Diffuser For LINCS150 O24 8.80$ 6.60$
CL-O36 Clear Diffuser For LINCS150 O36 8.80$ 6.60$
CL-O48 Clear Diffuser For LINCS150 O48 8.80$ 6.60$
OF-O24 Opaque Front Diffuser For LINCS150 O24 15.40$ 11.60$
OF-O36 Opaque Front Diffuser For LINCS150 O36 15.40$ 11.60$
OF-O48 Opaque Front Diffuser For LINCS150 O48 15.40$ 11.60$
WL-O24 Translucent White Diffuser For LINCS150 O24 14.00$ 10.50$
WL-O36 Translucent White Diffuser For LINCS150 O36 14.00$ 10.50$
WL-O48 Translucent White Diffuser For LINCS150 O48 14.00$ 10.50$
Replacement Diffusers for LINCS150 B Bi-axial Fluorescents
CL-B11 Clear Diffuser For LINCS150 B11 8.80$ 6.60$
CL-B15 Clear Diffuser For LINCS150 B15 8.80$ 6.60$
CL-B25 Clear Diffuser For LINCS150 B25 8.80$ 6.60$
OF-B11 Opaque Front Diffuser For LINCS150 B11 15.40$ 11.60$
OF-B15 Opaque Front Diffuser For LINCS150 B15 15.40$ 11.60$
OF-B25 Opaque Front Diffuser For LINCS150 B25 15.40$ 11.60$
WL-B11 Translucent White Diffuser For LINCS150 B11 14.00$ 10.50$
WL-B15 Translucent White Diffuser For LINCS150 B15 14.00$ 10.50$
WL-B25 Translucent White Diffuser For LINCS150 B25 14.00$ 10.50$
Description
99 08/06/2012
OPTIONAL
SPECIAL BALLASTS
Power factor 1
Ballast factor 0.85
THD <20%
Sound rating A
REPLACEMENT COMPONENTS
NOT LISTED ON INDIVIDUAL
PRODUCT PAGES
Description Distributor Price
Single 8W T5 Electronic Ballast $13.00
Single 13W T5 Electronic Ballast $13.00
Single 8W and Single 13W T5 Electronic Ballast $27.90
Double 8W T5 Electronic Ballast $27.90
Double 13W T5 Electronic Ballast $27.90
Little Inch Lampholder $1.10
LINCS 100F Lampholder $1.10
Super Inch/LINCS 150O Lampholder $1.10
Little Inch BX/Romex Connector & Hardware $2.60
120 Volt
277 Volt
EG-12-FL-2 (Single Lamp Ballast) $5.00 $6.80
RGLO-F (Single Lamp Ballast) $5.00 $6.80
EA-12-FL-2 (Single Lamp Ballast) $5.00 $6.80
Philips Alkco reserves the right to provide electronic ballasts by
any major manufacturer as long as they meet the following
minimum standards:
REPLACEMENT ELECTRONIC BALLASTS FOR LINCS 100F AND HP, SFHP, HL, TA, TW & IS
LITTLE INCH PRODUCTS
MISCELLANEOUS LINCS/LITTLE INCH/SUPER INCH COMPONENTS
REPLACEMENT BALLASTS FOR EXIT SERIES
Of course we will continue to quote and provide specific ballasts
as requested by a specifier.
Dimming ballasts need to be compatible with the dimming
system being specified. Please consult the factory.
08/06/2012 100
COST ADDERS FOR SPECIAL FINISHES
Undercabinet Fixtures
Philips Alkco has the ability to paint most fixtures in custom finishes to match specific job
requirements. To ensure an acceptable color match, please provide a paint chip which is
large enough to be split into 3 pieces (one to keep in Customer Service, one to keep at
Philips Alkco Quality control and one to be sent to the Philips Alkco paint supplier).
Custom finishes are quoted on a job by job basis. Normally a $330 lot paint match & set-up
charge is applied to each order release.
When undercabinet fixtures are to be painted a special color which is of dark reflectance, the
inside usually will be painted white. This will normally entail a $330 lot charge for the custom
color plus a $11 per fixture mask and paint charge for the white. The lot charge will apply
per order release.
101 08/06/2012
103 4
103DF 5
104 4
104DF 5
207V 97
317 73
325 73
332 73
1126 76
1127 76
1136 76
1137 76
1146 76
1147 76
1226 76
1227 76
1236 76
1237 76
1246 76
1247 76
2126 77
2127 77
2136 77
2137 77
2146 77
2147 77
2226 77
2227 77
2236 77
2237 77
2246 77
2247 77
28863T5 11
28863T8 11
28864T5 11
28864T8 11
3116 78
3126 78
3127 78
3136 78
3137 78
3146 78
3147 78
3226 78
3227 78
3236 78
3237 78
3246 78
3247 78
9618-411 12
9618-412 12
9618-421 12
9618-422 12
9930 48
9931 48
ALBT1 9
ALBT2 9
AMS 96
ARIS-11 65
ARIS-21 65
ARIS-41 65
DCE-T5 18
DEC-T5HO 18
DCEA-T5 17
DCEA-T5HO 17
EA12FL2 93
EA12PL2 93
EA22FL2 93
EA22PL2 93
EAX12FL2 93
EAX22FL2 93
ECO108 80
ECO113 80
ECO116 80
ECO138 80
ECO213 80
ECOH17 81
ECOH23 81
ECOH31 81
ECOH8 81
ECOHLV17 81
ECOHLV23 81
ECOHLV31 81
ECOHLV8 81
ECOX17 81
ECOX23 81
ECOX31 81
ECOX8 81
ECT5 6
ECT5HO 6
ECT8 6
HG-17-SGD 69
HG-23-SGD 69
HG-47-SGD 69
HG-8-SGD 69
HP108 67
HP113 67
HP114 68
HP116 67
HP121 68
HP124 68
HP128 68
HP138 67
HP139 68
HP154 68
HP213 67
HZN2T5 8
HZN2T5HO 8
HZN2T8 8
HZN3T5 8
HZN3T5HO 8
HZN3T8 8
HZN4L351 7
HZN4T5 8
HZN4T5HO 8
HZN4T8 8
IB5217 10
IB5225 10
IB5232 10
IB5317 10
IB5325 10
IB5332 10
IB5417 10
IB5425 10
IB5432 10
IB5517 10
IB5525 10
IB5532 10
IB6440 10
ILF114 75
ILF114/2 75
ILF121 75
ILF121/2 75
ILF128 75
ILF128/2 75
ILF135 75
L2F1 66
L2F2 66
L2F2HO 66
L2F3 66
L2F3HO 66
L2F4 66
L2F4HO 66
LD1026 98
LD1212 98
LD1418 98
LD1434 98
LD1442 98
LD1818 98
Catalog # Page # Catalog # Page # Catalog # Page #
10208/06/2012
LD718 98
LD734 98
LD742 98
LD77 98
LIN2000-L 84
LIN20EB-L 84
LIN20EG-L 84
LIN20ES-L 84
LIN20PB-L 84
LIN20PG-L 84
LIN20PS-L 84
LIN20WBE-L 84
LIN4000-L 84
LIN40EB-L 84
LIN40EG-L 84
LIN40ES-L 84
LIN40PB-L 84
LIN40PG-L 84
LIN40PS-L 84
LIN40WBE-L 84
LINCS-100-1 58-61
LINCS-100-1-RSW 58-61
LINCS-100-2/CO 58-61
LINCS-100-F12 59
LINCS-100-F21 59
LINCS-100-F24 59
LINCS-100-F33 59
LINCS-100-F42 59
LINCS-100-FS23 59
LINCS-100-FS35 59
LINCS-100-FS46 59
LINCS-100-FS58 59
LINCS-100-HN18-SGD 61
LINCS-100-HN27-SGD 61
LINCS-100-HN9-SGD 61
LINCS-100-HO23 59
LINCS-100-HO35 59
LINCS-100-HO46 59
LINCS100-L10 58
LINCS100-L19 58
LINCS100-L28 58
LINCS100-OSC 64
LINCS-150-1 62-63
LINCS-150-2/CO 62-63
LINCS-150-B11 62
LINCS-150-B15 62
LINCS-150-B25 62
LINCS-150-O24 62
LINCS-150-O36 62
LINCS-150-O48 62
LINCS150-OSC 64
MCS114 86
MCS121 86
MCS124 86
MCS128 86
MCS128/2 86
MCS135 86
MCS139 86
MCS154 86
ME240N 16
ME340NLG 15
ME340ARN 16
ME440NLG 15
ME540N 14
ME540NLG 14
ME640N 13
ME640NLG 13
MJS200-DC 54
MJS200-FL 54
MJS200-SC 54
MJS200-W 54
MNS10-DC 50
MNS10-DT 50
MNS10-FL 50
MNS10-SC 50
MNS10-ST 50
MNS10-W 50
MNS100-DC 52
MNS100-FL 52
MNS100-SC 52
MNS100-W 52
MNS200-DC 52
MNS200-FL 52
MNS200-SC 52
MNS200-W 52
MNS300-DC 53
MNS300-DT 53
MNS300-FL 53
MNS300-SC 53
MNS300-ST 53
MNS300-W 53
MNS50-DC 51
MNS50-FL 51
MNS50-SC 51
MNS50-W 51
MT114 87
MT121 87
MT124 87
MT128 87
MT135 87
MT139 87
MT154 87
PGLO1 89-90
PGLO2 89-90
Q108-RSW-L-ECB 79
Q113-RSW-L-ECB 79
Q116-RSW-L-ECB 79
Q138-RSW-L-ECB 79
Q213-RSW-L-ECB 79
R2058-1 57
R2058-2 57
R2058-3 57
RGLOFL1 90
RGLOFL2 90
RGLOFLX1 90
RGLOFLX2 90
RGLOLED1R 90
RGLOLED2R 91
RGLO-LEDWW 93
RGLOLEDX1R 91
RGLOLEDX2R 91
RL20EB-L 85
RL20EG-L 85
RL20ES-L 85
RL20PB-L 85
RL20PG-L 85
RL20PS-L 85
RL20WBE-L 85
RL40EB-L 85
RL40EG-L 85
RL40ES-L 85
RL40PB-L 85
RL40PG-L 85
RL40PS-L 85
RL40WBE-L 85
RTN2024 88
RTN2036 88
RTN2048 88
RTN2524 88
RTN2548 88
RTN4023 88
RTN4024 88
RTN4036 88
RTN4047 88
RTN4048 88
RTN4096 88
RTN4501 88
RTN5001 88
RTN5002 88
RTN5003 88
RTN7000 88
RTN9001 88
RTN9002 88
Catalog # Page # Catalog # Page # Catalog # Page #
103 08/06/2012
SF317 74
SF325 74
SF332 74
SFHP108 70
SFHP113 70
SFHP114 71
SFHP116 70
SFHP121 71
SFHP124 71
SFHP128 71
SFHP138 70
SFHP139 71
SFHP154 71
SFHP213 70
SFLINCS-150-O24 63
SFLINCS-150-O36 63
SFLINCS-150-O48 63
SGLOFL1 89
SGLOFL2 89
SGLOFLX1 89
SGLOFLX2 89
SGLOLED1R 90
SGLOLED2R 90
SGLOLEDX1R 90
SGLOLEDX2R 90
SL118 19
SL124 19
SL130 19
SL136 19
SM2058-1 57
SM2058-2 57
SM2058-3 57
SO2N 3
SO3N 3
SO4N 3
SS317 73
SS325 73
SS332 73
SSHP108 67
SSHP113 67
SSHP114 68
SSHP116 67
SSHP121 68
SSHP124 68
SSHP128 68
SSHP138 67
SSHP139 68
SSHP154 68
SSHP213 67
SSSFHP108 70
SSSFHP113 70
SSSFHP114 71
SSSFHP116 70
SSSFHP121 71
SSSFHP124 71
SSSFHP128 71
SSSFHP138 70
SSSFHP139 71
SSSFHP154 71
SSSFHP213 70
SSTRF14-T5 29
SSTRF14-T5HO 30
SSTRF14-T8 28
SSTRG14-T5 29
SSTRG14-T5HO 30
SSTRG14-T8 28
SSTRF22-40TT 26
SSTRF22-T5 25
SSTRF22-T5HO 27
SSTRF22-T8 23
SSTRF22-T8U 24
SSTRG22-40TT 26
SSTRG22-T5 25
SSTRG22-T5HO 27
SSTRG22-T8 23
SSTRG22-T8U 24
SSTRF24-T5 21
SSTRF24-T5HO 22
SSTRF24-T8 20
SSTRG24-T5 21
SSTRG24-T5HO 22
SSTRG24-T8 20
STRF14-T5 40
STRF14-T5HO 41
STRF14-T8 39
STRG14-T5 40
STRG14-T5HO 41
STRG14-T8 39
STRF22-T8 34
STRF22-T8U 35
STRF22-T5 36
STRF22-40TT 37
STRF22-T5HO 38
STRG22-40TT 37
STRG22-T5 36
STRG22-T5HO 38
STRG22-T8 34
STRG22-T8U 35
STRF24-T5 32
STRF24-T5HO 33
STRF24-T8 31
STRG24-T8 31
STRG24-T5 32
STRG24-T5HO 33
ST8140-1 47
ST8140-2 47
ST8145-1 47
ST8145-2 47
ST8220-1 46
ST8225-1 46
ST8240-1 45
ST8240-2 45
ST8240-3 45
ST8245-1 45
ST8245-2 45
ST8245-3 45
STS8140-1 44
STS8140-2 44
STS8145-1 44
STS8145-2 44
STS8220-1 43
STS8225-1 43
STS8240-1 42
STS8240-2 42
STS8240-3 42
STS8245-1 42
STS8245-2 42
STS8245-3 42
TA2113 72
TA2116 72
TA2138 72
TA2213 72
TAB111 83
TAB113 83
TAB114 83
TAB117 83
TAB121 83
TAB124 83
TAB125 83
TAB126 83
TAB128 83
TAB132 83
TAB139 83
TAB154 83
TE100-FL 49
TE100-R 49
TE100-R1 49
TE100-SC 49
TE100-T 49
TE100-W 49
TE210-FL 49
TE210-W 49
TE220-FL 49
TE220-W 49
WGLOLEDGC 91
WGLOLEDGW 91
WGLOLEDRC 91
Catalog # Page # Catalog # Page # Catalog # Page #
10408/06/2012
WGLOLEDRW 91
WGLOLEDXGC 91
WGLOLEDXGW 91
WGLOLEDXRC 91
WGLOLEDXRW 91
WG1V 2
WG2V 2
WG1H 2
WG2H 2
WGT 2
XCLED1 95
XCLED2 95
XCLEDX1 95
XCLEDX2 95
XR2100 56
XR2101 56
XR2200 56
XR2202 56
XR2300 56
XR2303 56
XR2400 56
XR2404 56
XR2500 56
XR2505 56
XR2600 56
XR2606 56
XR3100 56
XR3101 56
XR3200 56
XR3202 56
XR3300 56
XR3303 56
XR3400 56
XR3404 56
XR3500 56
XR3505 56
XR3600 56
XR3606 56
XR4100 56
XR4101 56
XR4200 56
XR4202 56
XR4300 56
XR4303 56
XR4400 56
XR4404 56
XR4500 56
XR4505 56
XR4600 56
XR4606 56
XS2100 55
XS2101 55
XS2200 55
XS2202 55
XS2300 55
XS2303 55
XS2400 55
XS2404 55
XS2500 55
XS2505 55
XS2600 55
XS2606 55
XS3100 55
XS3101 55
XS3200 55
XS3202 55
XS3300 55
XS3303 55
XS3400 55
XS3404 55
XS3500 55
XS3505 55
XS3600 55
XS3606 55
XS4100 55
XS4101 55
XS4200 55
XS4202 55
XS4300 55
XS4303 55
XS4400 55
XS4404 55
XS4500 55
XS4505 55
XS4600 55
XS4606 55
Catalog # Page # Catalog # Page # Catalog # Page #
105 08/06/2012
PAYMENT TERMS:
A. 1% 10th PROX, NET 30 Days.
B. A service charge of 1½% per month will be applied to past due accounts.
PRICE AND QUOTATIONS:
A. The prices shown in Philips Alkco’s price list or in any order acknowledgment are prices prevail-
ing at the present time. Philips Alkco reserves the right to change such prices at any future
date. Unless otherwise provided in writing, orders will be billed at prices prevailing at time of
shipment.
B. Subject to “G” below, prices issued by a written standard quotation are firm for 30 days from
date of quotation. Purchase orders received and acknowledged within this 30-day period will
be price protected for shipment within 90 days from the date of the order.
C. Prices issued by a written non-standard quotation authorized by Philips Alkco’s Corporate
Offices in Illinois may offer price protection for a different period.
D. Releases for shipments beyond the price protected period (standard or non-standard) will be
increased in price at the rate of 1% per month.
E. Additions to orders already processed shall be considered separate orders and shall be priced
accordingly.
F. All prices are subject to additional federal, city and state taxes, if applicable, unless appropriate
exemption certificate is on file at Philips Alkco’s Headquarters .
G. Possession of a price list is not in itself an offer to sell; quotations to distributors placed on
credit hold or to others who are not on approved status shall not be binding on Philips Alkco
in any way and shall not be deemed offers to sell.
PURCHASE ORDERS:
A. To assure expeditious handling. Controls orders must be separately written on appropriate
order forms.
B. The acceptance of the Buyer’s purchase order is contingent upon written acknowledgment by
Philips Alkco at its Corporate Offices in Illinois, in the form of a letter or electronic or printed
acknowledgment.
C. The acceptance of Buyer’s order is expressly made conditional upon Buyer’s assent to the terms
and conditions stated herein and in Philips Alkco’s printed acknowledgment. Philips Alkco
agrees to furnish the merchandise covered by its price list only upon such terms and condi-
tions. In the absence of any written notification to the contrary, and by virtue of the issuance
of a purchase order, Buyer shall be deemed to have accepted terms and conditions as stated
herein and in Philips Alkco’s acknowledgment. If there is any inconsistency between the terms
and conditions stated herein and in Philips Alkco’s acknowledgment, the terms and conditions
contained in the acknowledgment shall control. Philips Alkco’s failure to object to provisions
contained in the Buyer’s forms shall not be deemed a waiver of the provisions in Philips Alkco’s
terms and conditions.
D. Requests to cancel or change made-to-order items must be submitted in writing by the
customer a minimum of 2 weeks prior to scheduled ship date. All requests are reviewed for
approval before processing and are subject to costs for work performed and/or materials pur-
chased.
E. All additions, deletions or other changes to or in an order are subject to all of the Terms and
Conditions herein.
SPECIFICATIONS; VARIATIONS; ERRORS:
A. Merchandise will be shipped in accordance with the standard styles and sizes as described in
Philips Alkco catalogs or, if special or made-to-order, in accordance with Philips Alkco drawings
and specifications sheets.
B. In the event of a conflict between a customer’s written order and a Philips Alkco drawing or
specification sheet marked “approved”, the Philips Alkco drawing or specification sheet shall
prevail.
C. Philips Alkco reserves the right to change details of design, materials and finish.
D. Every effort is made to avoid errors in catalogs, price sheets, specification sheets and other
data. Philips Alkco will not accept responsibility for labor charge-backs in connection with
errors of measurements, prices, descriptions, etc.
E. Philips Alkco will not be bound by general or blanket instructions not contained with Buyer’s
order. Each transaction must be accompanied by full instructions on the order itself.
F. Orders containing such phrases as “all material to be supplied as per project plans and specifi-
cations,” etc., are subject to separate written acceptance by Alkco .
PACKAGING:
A. Method of packaging is at Philips Alkco’s option.
B. Export packaging may be charged as an extra.
SPECIAL ITEMS:
A. Order for special items are not cancelable except on payment for work performed.
B. On special Philips Alkco fixtures not listed in our current catalogs, we reserve the right to quote
and sell only to the distributor who assisted Philips Alkco in the development of the business
for a specific customer.
DELIVERY AND TRANSPORTATION:
A. All merchandise is sold, and all shipments are made, F.O.B. the factory of Philips Alkco .
B. When a $3,000 net order is accepted for shipment at one time, domestic freight will be prepaid
by Philips Alkco with no charge to the customer in the Continental United States. In all other
cases domestic freight will be prepaid and charged. Foreign freight methods vary.
C. Philips Alkco will use its discretion in routing all shipments, and reserves the right to select
carrier and truck size. If any shipment made in accordance with Buyer’s instructions shall incur
additional labor or carrier costs, such costs shall be paid by Buyer as invoices are rendered.
D. The shipment date mentioned on our order acknowledgment, if any, is Philips Alkco’s best
approximation of the probable shipment date and is not a fixed or guaranteed shipment date.
Shipment of merchandise is subject to any and all delays due to any condition or happening
whatsoever beyond Philips Alkco’s control, including but not exclusive of strikes, fires, riots,
wars, acts of God, inability to obtain materials, government regulations or other conditions.
Philips Alkco shall not be responsible for any damage or loss resulting, whether directly or inci-
dentally, from delayed shipments or its inability to ship as above.
E. Philips Alkco reserves the right to make shipment installments unless otherwise expressly
stipulated in the order acknowledgment. All such installments shall be separately invoiced and
paid for when due, without regard to subsequent shipments. Delay in the shipment of any
installment will not relieve Buyer of its obligation to accept remaining shipments.
F. Philips Alkco reserves the right to refuse to make direct shipments to destinations outside
Buyer’s regular service area(s).
STORAGE:
A. If any shipment made in accordance with Buyer’s instructions is refused for whatever reason,
Buyer shall be responsible for payment of such merchandise, in accordance with the terms
hereof, as though such merchandise has been accepted at the time of original delivery. Buyer
shall also be responsible for reasonable storage, handling and delivery charges and shall pay
reasonable storage charges until such merchandise is delivered and accepted.
PAYMENT:
A. Buyer shall make payments as specified herein and Philips Alkco may suspend shipment or
delivery until such payments are made.
B. Philips Alkco reserves the right to charge a service charge of 1 1/2% per month, but not in
excess of any lawful rate, if Buyer is delinquent in payment of invoices.
C. If, in the opinion of Alkco , the financial condition of Buyer becomes impaired or unsatisfactory,
Philips Alkco may at any time limit or cancel the credit of Buyer and, before delivering addi-
tional goods to Buyer, require Buyer to pay in cash for such goods and to pay the goods there-
tofore delivered. Failure by Buyer to make any such payments within 10 days after demand in
writing shall constitute a breach of this agreement by Buyer. Approval of credit of one or more
deliveries shall not be deemed a waiver thereof.
D. Philips Alkco shall be entitled to reimbursement for all costs and expenses (including reason-
able attorney’s fees) incurred by it in connection with collection of any amounts for goods sold
in the event payment thereof shall not be made when due.
SECURITY INTERESTS:
A. Philips Alkco shall retain a security interest in all goods sold until the full amount of the pur-
chase price (including any service charges) has been paid by Buyer. In the event Buyer shall
default in payment of the purchase price, Philips Alkco shall have the right, in addition to and
not exclusive of any other rights it may have under the Uniform Commercial Code or other-
wise, to enter upon the premises where the goods are located and retake possession thereof,
without notice, free from any claims of Buyer. At the request of Alkco , Buyer will join Philips
Alkco and any assignee of Philips Alkco in preparing, executing and causing to be filed any and
all financing statements pursuant to the Uniform Commercial Code. Buyer hereby authorizes
Philips Alkco and any assignee of Philips Alkco to file a financing statement signed only by
Philips Alkco or such assignee in all places where necessary or appropriate to perfect any secu-
rity interest which Philips Alkco or such assignee might be deemed to have in all jurisdictions
where such authorization is permitted by law.
CLAIMS AND ADJUSTMENTS:
A. Claims due to any cause must be forwarded within five (5) days from receopt of shipment.
Deducations from remittances not to be allowed unless authorized by Philips Alkco in advance.
B. Claims for shipping errors or merchandise defects will be waived unless made in writing to
Alkco within 30 days after receipt of merchandise.
C. Philips Alkco’s sole responsibility and obligation in the event of defective merchandise shall
be limited to the repair or replacement of the merchandise, at Philips Alkco’s option, at its
own cost and expense, and Philips Alkco shall not be responsible for any other damage or loss
which may be sustained or claimed.
D. Claims for shortages, losses and apparent or concealed damages sustained in transit shall be
made by Buyer with the carrier.
E. “Upon request, Philips Alkco will provide evidence of goods turned over to a carrier, but
reserves the right to charge a reasonable fee for all proof of delivery requests.”
RETURNED GOODS:
A. Requests to return non-defective merchandise must be made within 180 days from the date of
shipment and is subject to a 50% re-stocking charge.
B. Only regular items in the current line are returnable. Special, made-to-order, or discontinued
merchandise is not subject to return.
C. Returns of orders drop-shipped to job site will be limited to 10% of the original order.
D. All returned goods must be accompanied by a “Return Goods Authorization (R.G.A)” issued by
Alkco .
E. Merchandise must be returned in the original factory-sealed cartons in saleable condition.
F. Returns must be made freight prepaid within 30 days of the date of Philips Alkco’s issuance of
the R.G.A.
G. All merchandise returned is subject to inspection. Unsaleable and damaged merchandise will
be credited at salvage value or less costs of repairs.
H. Philips Alkco reserves the right to issue credit at prices prevailing at time of shipment, or time
of return, whichever is lower, less the 25% restocking charge.
THREE YEAR LIMITED WARRANTY:
A. Philips Alkco warrants that its products (other than ballasts, lamps and emergency battery
packs) are free of defects in workmanship and materials. SUCH WARRANTY IS IN LIEU OF
ALL OTHER WARRANTIES INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Philips Alkco, at its sole option,
will repair or replace, F.O.B. our factory, freight prepaid, any Philips Alkco product (other than
ballasts, lamps and emergency battery packs) defective in workmanship or materials. Such
repair or replacement is the sole and exclusive remedy against Philips Alkco and is limited to
three years from date of original shipment by Philips Alkco . Philips Alkco reserves the right to
determine whether to repair or replace. No charge-back, or charge for labor or material, that
does not have Philips Alkco’s prior written approval from its Corporate Offices in Illinois will be
honored, accepted or paid by Philips Alkco . Philips Alkco will not be responsible for any conse-
quential or incidental damages in connection with any breach of its aforementioned warranty.
B. Ballasts, emergency battery packs and lamps may be covered by separate ballast manufactur-
ers’ warranties. Philips Alkco does not make any warranties whatsoever as to these items which
are sold by Philips Alkco “AS IS,” and Philips Alkco will accept no responsibility or liability what-
soever therefore.
C. Philips Alkco will not be responsible for any products subjected to inappropriate application or
installed or modified in any way that is not in accordance with Philips Alkco’s instructions.
D. No agent, employee or representative of Philips Alkco has any authority to bind Philips Alkco
to any other affirmation, representation or warranty concerning goods sold by Philips Alkco .
08-06-12
Philips Alkco
STANDARD TERMS AND CONDITIONS OF SALE
10608/06/2012
THREE YEAR LIMITED WARRANTY
A. Philips Alkco warrants that its products (other than ballasts) are free of defects in workmanship and materials.
SUCH WARRANTY IS IN LIEU OF OTHER WARRANTIES INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Philips Alkco , at its sole option, will repair or
replace, F.O.B. our factory, freight prepaid, any Philips Alkco product (other than ballasts) defective in workmanship
or materials. Such repair or replacement is the sole and exclusive remedy against Philips Alkco and is limited to
three years from date of shipment. Philips Alkco reserves the right to determine whether to repair or replace. No
charge-back, or charge for labor or material, that does not have Philips Alkco’s prior written approval from its
Corporate Offices in Illinois will be honored, accepted or paid by Philips Alkco. Philips Alkco will not be
responsible for any consequential or incidental damages in connection with any breach of its aforementioned
warranty.
B. Ballasts and emergency battery packs are covered by separate ballast manufacturers warranties. Philips Alkco does
not make any warranties whatsoever as to ballasts and will accept no responsibility or liability whatsoever therefore.
C. Philips Alkco will not be responsible for any products subjected to inappropriate application or installed or modified
in any way that is not in accordance with Philips Alkco’s instructions.
D. No agent, employee or representative of Philips Alkco has any authority to bind Philips Alkco to any affirmation,
representation or warranty concerning goods sold by Philips Alkco and unless an affirmation, representation or
warranty made by an agent, employee or representative is specifically included herein, or in Philips Alkco’s acknowl-
edgment or Buyer’s purchase order, or in standard printed materials provided by Philips Alkco , it does not form
a part of the basis of any bargain between Philips Alkco and Buyer and shall not in any way be enforceable by Buyer.
Philips Alkco
QUALITY ASSURANCE POLICY
Philips Alkco’s first priority is customer satisfaction. We take every step possible to ensure that our products are well
designed, of superior quality and are received by you in good working order. It is our intention that any problems result-
ing from defective materials or workmanship be promptly addressed.
FIELD PROBLEMS AND BACKCHARGES
Detailed below are the general procedures and guidelines we ask you to follow in the event a field problem arises due to
defective materials or workmanship. This policy statement is not intended to create a warranty, nor to become a part of,
nor extend the existing Philips Alkco limited customer warranty.
ACKNOWLEDGEMENT OF PROBLEM
In order to effectuate our policy, the Philips Alkco quality assurance department must by promptly notified by you of all
problems that you encounter with Philips Alkco products. Philips Alkco, once notified, will acknowledge your comments
and complaint in writing.
LIMITS OF RESPONSIBILITY
The correction of any problem resulting from abuse, neglect or misuse of the product after it leaves the factory is not the
responsibility of Philips Alkco. Philips Alkco also has the right to limit its financial responsibility for the back charges to
the purchased cost of the material involved in any such back charge.
AUTHORIZATION FOR BACK CHARGES
All back charges made by you must be authorized by Philips Alkco in writing prior to the performance of chargeable
work. Back charges due to delays in notification will not be allowed. Philips Alkco cannot be held responsible for
excessive preliminary problem investigation time.
Philips Alkco
STANDARD TERMS AND CONDITIONS OF SALE
107 08/06/2012

Navigation menu
