PRODUCT CATALOG
™
®
Liquid-Tight Conduit Fittings
Liquid-Tight Connectors – Zinc Die Cast
One-Piece.................................................................. 30
Multi-Piece ................................................................. 30
90° Liquid-Tight Connectors – Zinc Die Cast
One-Piece.................................................................. 30
Multi-Piece ................................................................. 31
Liquid-Tight Connectors – Steel and/or Malleable Iron
Straight – Steel/Malleable Iron .................................. 31
90° – Malleable Iron................................................... 32
45° – Malleable Iron................................................... 32
QUICK-SET® Liquid-Tight Connectors ............................ 33
Screw-In Couplings – PVC .............................................. 33
Compression Connectors–Steel ...................................... 34
Compression Connectors–Zinc ....................................... 34
Compression Couplings–Steel ........................................ 35
Compression Couplings–Zinc.......................................... 35
Set-Screw Connectors and Couplings............................. 36
Rigid-To-EMT Couplings .................................................. 37
Three-Piece Couplings – Malleable................................. 37
Rigid-To-Rigid Pull Elbows .............................................. 37
EMT/Rigid-To-EMT/Rigid Combo Elbows........................ 37
Rigid-To-Box Pull Elbows ................................................ 38
EMT/Rigid-To-Box Combo Elbows .................................. 38
One-Hole Straps – Steel or Malleable Iron ...................... 39
Two-Hole Straps – Steel .................................................. 39
Conduit Locknuts – Steel................................................. 39
Sealer Locknuts – Steel................................................... 40
Conduit Locknuts – Zinc Die Cast ................................... 40
Grounding Locknuts – Zinc Die Cast ............................... 40
Reducing Washers – Steel .............................................. 41
Reducing Bushings – Steel ............................................. 41
Conduit Nipples .......................................................... 42-43
Offset Nipples .................................................................. 44
Chase Nipples ................................................................. 44
Box Spacers .................................................................... 44
Clamp Backs ................................................................... 44
One-Hole Strap and Clamp ............................................. 44
Conduit Bushings – Zinc Die Cast ................................... 45
Plastic Insulating Bushings .............................................. 45
Insulated Metallic Grounding Bushings ........................... 45
Conduit Body Gaskets ..................................................... 46
Conduit Body Covers....................................................... 46
Service Entrance ELL ...................................................... 46
Threaded Conduit Bodies with Cover and Gasket .......... 47
Threaded Conduit Bodies ................................................ 48
Rigid/EMT Combo Conduit Bodies .................................. 48
Mogul Pulling Elbows ...................................................... 49
Water-Tight “Myers” Conduit Hubs .................................. 49
90° Short Radius Elbows ................................................. 49
90° Large Radius Adapter Elbows ................................... 49
Rigid Couplings ............................................................... 50
90° Rigid Elbows ............................................................. 50
45° Rigid Elbows ............................................................. 50
Service Entrance Fittings
Midget One-Hole Straps .................................................. 51
One-Hole Service-Cable Straps ...................................... 51
Two-Hole Service-Cable Straps ...................................... 51
Water-Tight Connectors ................................................... 51
Service Entrance Caps .................................................... 52
Thermoplastic Service Entrance Caps ............................ 52
Oval Service Cable Caps ................................................ 52
Non-Metallic Service Entrance Cable Hoods .................. 52
PVC Service Entrance Caps ........................................... 52
Slip-Fit Mast Heads ......................................................... 53
Service-Cable Sill Plates ................................................. 53
Conduit Sill Plates ........................................................... 53
Clamp Connectors ........................................................... 53
Offset Bottom Reducers .................................................. 54
Conduit Supports ............................................................. 54
Service Drop Brackets ..................................................... 54
Fork Bolts ........................................................................ 54
Roof Ties ......................................................................... 54
Adjustable Porcelain Wireholders.................................... 55
Porcelain Wireholders ..................................................... 55
Service Clevis .................................................................. 55
Service Entrance ELL ...................................................... 56
Wedge Clamp Connectors .............................................. 56
Roof Flashing .................................................................. 56
Duct Seals ....................................................................... 56
Electric Pane Washers .................................................... 56
Grounding and Bonding Fittings
Ground Clamps
For Bare Wire ............................................................. 57
For Armored Cable ..................................................... 57
With Threaded Hub .................................................... 58
With Strap and Hub .................................................... 58
Ground Rod Clamps ........................................................ 58
Ground Straps ................................................................. 58
Ground Screws ................................................................ 59
Solid Ground Wires ......................................................... 59
Stranded Ground Wires ................................................... 59
Ground Clips.................................................................... 59
KENNY CLAMP® Compression Connectors.................... 59
Accessories
Cable Staples .................................................................. 60
Plastic Insulating Staples................................................. 60
Strain Relief Cord Connectors ......................................... 60
Non-Metallic Strain Relief Cord Connectors .................... 61
90° Strain Relief Cord Connectors .................................. 61
Split Bolt Connectors ....................................................... 61
Split Bolt Connectors with Spacer Bar............................. 62
Solderless Terminal Lugs ................................................ 62
Strut Pipe Clamp ............................................................. 62
Knock Out Seals .............................................................. 63
Switch Box Supports ....................................................... 63
Snap-In Bushings ............................................................ 63
Universal Snap-In Bushings ............................................ 63
Nail Plates ....................................................................... 64
Jack Chains and “S” Hooks ............................................. 64
“Sky-Tie” Cable Clamps and Extension Springs ............. 64
Duct Seals ....................................................................... 65
Fixture Hangers and Conduit Hangers ............................ 65
Beam Clamps. ................................................................. 65
INDEX.................................................................... 66
CROSS REFERENCE ............................................. 69
INTRODUCTION
Catalog Parts Numbering System ..................................... 4
Online at www.halexco.com .............................................. 5
Electrical Metallic Tubing Fittings
Compression Connectors and Couplings – Zinc ............... 6
Compression Connectors and Couplings – Steel .............. 7
Raintight Compression Connectors
and Couplings – Steel ....................................................... 8
Set-Screw Connectors and Couplings – Zinc .................... 9
Set-Screw Connectors and Couplings – Steel ................ 10
EMT To Box Offset Connectors ........................................11
90° Elbows........................................................................11
45° Elbows........................................................................11
90° Compression Elbows ................................................ 12
90° Set-Screw Elbows ..................................................... 12
One-Hole Straps .............................................................. 13
Two-Hole Straps .............................................................. 13
Drive Straps ..................................................................... 13
EMT-To-EMT Pull Elbows ................................................ 14
EMT-To-Box Pull Elbows ................................................. 14
EMT/Rigid-To-EMT/Rigid Combo Elbows........................ 14
EMT/Rigid-To-Box Combo Elbows .................................. 14
EMT-To-EMT Inside-Corner Pull Elbows ......................... 14
EMT-To-Flex Combination Couplings .............................. 15
EMT-To-Non-Metallic Combination Couplings ................. 15
EMT Insulating Bushings ................................................. 15
EMT-To-Rigid Combination Couplings............................. 15
EMT/Rigid Combo Conduit Bodies ............................. 16-17
EMT/Conduit Bodies........................................................ 17
Screw-In Connectors and Couplings ............................... 18
90° Connectors ................................................................ 19
Anti-Short Bushings ......................................................... 20
Squeeze Connectors ....................................................... 20
FLEX-To-EMT Combination Couplings ............................ 21
AC (MC) One-Hole Straps ............................................... 21
Set-Screw Connectors..................................................... 21
Clamp-Combination Connectors ................................ 21-22
Duplex Connectors .......................................................... 22
Saddle Connectors ..................................................... 22-23
AC (BX) Connectors ........................................................ 23
MC “Snap-In” Connectors................................................ 23
MC “Snap-In” Duplex Connectors ................................... 23
SNAP-RITE® MC, AC, FLEX Connectors ........................ 24
SNAP-RITE® Duplex MC, AC, FLEX Connectors ............ 24
NON-METALLI
HIT LOCK® Non-Metallic Cable Connectors.................... 25
Duplex HIT LOCK® Non-Metallic Cable Connectors ....... 25
Plastic Non-Metallic Cable Connectors ........................... 25
Clamp Connectors ........................................................... 26
Clamp-Combination Connectors ..................................... 27
Duplex Connectors .......................................................... 27
Two-Piece Clamp Connectors ......................................... 28
Water-Tight UF Connectors ............................................. 28
Saddle Connectors .......................................................... 28
EMT-To-Non-Metallic Combination Couplings ................. 29
One-Hole Straps .............................................................. 29
3
© 2010, Halex/Scott Fetzer Company
TABLE OF CONTENTS
PRODUCT CATALOG
®
ACC
LIQUID
FLEX
NON-METALLIC
RIGID
SERVICE
GROUND
EMT
MC & AC Cable & Flexible
Metallic Conduit Fittings
Rigid & Intermediate
Metallic Conduit Fittings
Non-Metallic Sheathed
Cable Fittings
4
INTRODUCTION
INTRODUCTION: PARTS NUMBERING
TM
5
®
INTRODUCTION
ONLINE AT
www.halexco.com
For the latest product information and specications, visit us online at www.halexco.com.
ONLINE FEATURES INCLUDE:
• A dedicated area for Electrical Distributors and Sales Reps
• Product Category
View product photos and information according to category: EMT, FLEX, Non-Metallic,
Liquid-Tight, Rigid, Service Entrance, Ground and Accessories.
• Find A Part
• Halex Parts – Enter a Halex part number to instantly get the product name, size
and available link to additional details, from material, application and carton type,
to Master Carton information.
• Search for Other Manufacturer Parts – Enter a competitive part number to
receive details on parts made by nine different manufacturers.
• What’s New
Connect to application/usage information on some of our latest products or technologies.
• Rep Locator
Point and click selection by state provides immediate access to all our available rep
contact information.
• Links
Key industry Web site links are organized by industry inspection; professional
contractor and electrical distributor association; codes, regulatory and standards;
and other categories.
• Collateral Ordering
Order any of our available literature and materials online at any time and on any day.
To request a User ID and Password, go to www.halexco.com and click on the Contact
tab where you can submit your complete contact information and message.
VISIT US ONLINE TODAY.
Find A Part at www.halexco.com What's New at www.halexco.com
6
EMT
ELECTRICAL METALLIC TUBING FITTINGS
TM
6
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Compression Connectors Zinc Die Cast
1/2" 02105B 50/500 4.4/44.6 1.20 0.40 1.00
3/4" 02107B 25/250 3.3/33.5 1.27 0.40 1.19
1" 02110B 20/200 4.1/41.5 1.48 0.50 1.48
1 1/4" 02112B 25/100 8.2/34 1.75 0.59 1.84
1 1/2" 02115B 15/60 7.8/35 1.91 0.62 2.11
2" 02120B 10/40 7.6/30.5 2.11 0.76 2.56
2 1/2" 02125B 12 12.5 2.62 1.00 3.24
3" 02130B 12 16.4 2.75 1.06 3.87
3 1/2" 02135B 10 17 2.83 1.14 4.39
4" 02140B 6 12 2.84 1.14 4.88
WITH INSULATED THROAT
1/2" 82105B 50/500 5/50 1.25 0.45 1.00
3/4" 82107B 25/250 3.5/35 1.32 0.45 1.19
1" 82110B 20/200 4/40 1.53 0.55 1.48
1 1/4" 82112B 25/100 9.3/37 1.80 0.64 1.84
1 1/2" 82115B 15/60 8.3/33 1.96 0.67 2.11
2" 82120B 10/40 8.1/32.4 2.16 0.81 2.56
2 1/2" 82125B 12 12.8 2.67 1.05 3.24
3" 82130B 12 16.4 2.80 1.11 3.87
3 1/2" 82135B 10 17.6 2.88 1.19 4.39
4" 82140B 6 12.4 2.89 1.19 4.88
APPLICATION: INDOORS – Use to connect EMT conduit to steel outlet box, load center, or other
metal enclosure. MATERIAL: Zinc Die Cast. FEATURES: Concrete-Tight. CERTIFICATIONS: TO
UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Compression Couplings Zinc Die Cast
1/2" 02205B 50/500 5.9/59 1.59 1.00
3/4" 02207B 25/250 4.4/44.5 1.81 1.19
1" 02210B 20/200 5.4/54 1.82 1.48
1 1/4" 02212B 25/100 10.2/41.5 2.07 1.84
1 1/2" 02215B 15/60 10.2/41 2.47 2.11
2" 02220B 10/40 8.9/36 2.56 2.56
2 1/2" 02225B 12 15.5 3.29 3.24
3" 02230B 12 20.6 3.42 3.87
3 1/2" 02235B 10 20.5 3.51 4.39
4" 02240B 6 15 3.54 4.88
APPLICATION: INDOORS – Use to join two lengths of EMT conduit together. MATERIAL: Zinc Die
Cast. FEATURES: Concrete-Tight. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Compression Connectors Zinc Die Cast
1/2" 02005B 50 3.2
3/4" 02007B 25 2.3
APPLICATION: INDOORS – Use to connect EMT conduit to steel outlet box, load center, or other
metal enclosure. MATERIAL: Zinc Die Cast. FEATURES: Concrete-Tight. CERTIFICATIONS: TO
UL AND CSA REQUIREMENTS.
2 PIECE DESIGN
NEW
7
®
EMT
7
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Compression Connectors Steel
1/2" 62305B 25/250 2.8/28
3/4" 62307B 25/250 4.8/49.2
1" 62310B 10/100 2.8/28.5
1 1/4" 62312B 25 12.8
1 1/2" 62315B 20 11.3
2" 62320B 15 10.8
2 1/2" 62325B 12 21.4
3" 62330B 12 26.4
3 1/2" 62335B 6 15.4
4" 62340B 6 17.9
WITH INSULATED THROAT
1/2" 82305B 25/250 2.8/28
3/4" 82307B 25/250 4.8/49.2
1" 82310B 10/100 2.8/28.5
1 1/4" 82312B 25 12.8
1 1/2" 82315B 20 11.3
2" 82320B 15 10.8
2 1/2" 82325B 12 21.4
3" 82330B 12 26.4
3 1/2" 82335B 6 15.4
4" 82340B 6 17.9
APPLICATION: INDOORS – Use to connect EMT conduit to steel outlet box, load center, or
other metal enclosure. MATERIAL: Steel, Zinc Electro-Plate. FEATURES: Concrete-Tight.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Compression Couplings Steel
1/2" 62405B 25/250 3.1/31.5
3/4" 62407B 25/250 5.3/54.2
1" 62410B 10/100 2.9/29
1 1/4" 62412B 25 12.3
1 1/2" 62415B 20 11.3
2" 62420B 15 10.5
2 1/2" 62425B 12 26
3" 62430B 6 16.5
3 1/2" 62435B 6 19.2
4" 62440B 6 22.7
APPLICATION: INDOORS – Use to join two lengths of EMT conduit together. MATERIAL:Steel, Zinc
Electro-Plate. FEATURES: Concrete-Tight. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS
8
EMT
ELECTRICAL METALLIC TUBING FITTINGS
TM
a
c
b
across
corners
(
(
8
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Raintight Compression Connectors Steel
1/2˝ 62505B 50 5.9/29.5 1.650 0.460 1.125
3/4˝ 62507B 25 4.3/21.5 1.800 0.480 1.375
1˝ 62510B 15 3.5/17.5 1.870 0.500 1.690
11/4˝ 62512B 20 8.20 2.140 0.620 2.060
11/2˝ 62515B 10 5.00 2.270 0.650 2.250
2˝ 62520B 10 6.80 2.400 0.690 2.750
21/2˝ 62525B 6 10.7 2.440 0.750 3.625
3˝ 62530B 6 13.2 2.560 0.875 4.250
31/2˝ 62535B 6 15.4 2.750 0.938 4.688
4˝ 62540B 6 17.9 2.750 0.938 5.188
WITH INSULATED THROAT
1/2˝ 92505B 50 5.9/29.5 1.710 0.520 1.125
3/4˝ 92507B 25 4.3/21.5 1.860 0.540 1.375
1˝ 92510B 15 3.5/17.5 1.930 0.560 1.690
11/4˝ 92512B 20 8.20 2.190 0.680 2.066
11/2˝ 92515B 10 5.00 2.330 0.710 0.760
2˝ 92520B 10 6.80 2.460 0.750 2.750
21/2˝ 92525B 6 10.7 2.520 0.825 3.625
3˝ 92530B 6 13.2 2.620 0.938 4.250
31/2˝ 92535B 6 15.4 2.810 1.000 4.688
4˝ 92540B 6 17.9 2.810 1.000 5.188
APPLICATION: INDOORS OR OUTDOORS – Use to connect EMT conduit to steel outlet box,
load center, or other metal enclosure in a dry or wet location. MATERIAL: Steel, Zinc Electro-Plate.
FEATURES: Concrete-Tight and Raintight. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Raintight Compression Couplings Steel
1/2˝62605B 50 7.2/36 2.000 1.125
3/4˝62607B 25 5.5/27.5 2.200 1.375
1˝62610B 15 4.5/22.5 2.450 1.690
11/4˝62612B 20 10.8 2.600 2.060
11/2˝62615B 10 6.00 2.730 2.180
2˝62620B 10 8.00 2.920 2.750
21/2˝62625B 6 16.0 3.875 3.625
3˝62630B 6 19.8 4.00 4.250
31/2˝62635B 6 23.1 4.6875 4.688
4˝62640B 6 26.8 4.9375 5.188
APPLICATION: INDOORS OR OUTDOORS – Use to connect two lengths of EMT conduit together
in a dry or wet location. MATERIAL: Steel, Zinc Electro-Plate. FEATURES: Concrete-Tight and
Raintight. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
ab
UPC DIMENSIONS
TRADE HALEX PCS/ CTN/CASE CTN/CASE CODED (IN INCHES)
SIZE PART # UNIT QTY WT (LBS) SELL UNIT A B C
9
®
EMT
99
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE ( IN INCHES)
SIZE PART # QTY WT (LBS) A B
Set-Screw Connectors Zinc Die Cast
1/2˝ 12105B 50/500 2.9/29 1.16 0.41
3/4˝ 12107B 25/250 2.5/25 1.31 0.47
1˝ 12110B 20/200 3/30 1.56 0.56
11/4˝ 12112B 25/100 6.4/26.5 1.96 0.63
11/2˝ 12115B 15/60 6/24 2.19 0.72
2˝ 12120B 10/40 5.4/18.5 2.50 0.75
21/2˝ 12125B 12 10 3.03 1.00
3˝ 12130B 12 12.5 3.37 1.06
31/2˝ 12135B 10 12 3.58 1.09
4˝ 12140B 6 9 3.75 1.09
WITH INSULATED THROAT
1/2˝ 92105B 50/500 3.5/35 1.21 0.46
3/4˝ 92107B 25/250 2.5/25 1.36 0.52
1˝ 92110B 20/200 3/30 1.61 0.61
11/4˝ 92112B 25/100 7.3/29 2.01 0.68
11/2˝ 92115B 15/60 6/24 2.24 0.77
2˝ 92120B 10/40 5.4/21.6 2.55 0.80
21/2˝ 92125B 12 10 3.08 1.05
3˝ 92130B 12 12 3.42 1.11
31/2˝ 92135B 10 12.8 3.63 1.14
4˝ 92140B 6 9.4 3.80 1.14
APPLICATION: INDOORS ONLY – Use to connect EMT conduit to steel outlet box, load center, or
other metal enclosure. MATERIAL: Zinc Die Cast. FEATURES:Concrete-Tight1/2˝-3/4˝,Concrete-
TightWhenTaped1˝-4˝.CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
Set-Screw Couplings Zinc Die Cast
1/2˝ 12205B 50/500 3.5/32 1.53 0.94
3/4˝ 12207B 25/250 2.5/25.5 1.88 1.16
1˝ 12210B 20/200 2.8/28.5 2.00 1.43
11/4˝ 12212B 25/100 7.3/26 2.50 1.84
11/2˝ 12215B 15/60 5.9/21 2.88 2.07
2˝ 12220B 5/20 2.9/11.4 3.44 2.55
21/2˝ 12225B 12 9.9 3.99 3.30
3˝ 12230B 12 12.4 4.55 3.94
31/2˝ 12235B 10 12 4.92 4.45
4˝ 12240B 6 10 5.24 4.97
APPLICATION: INDOORS ONLY – Use to join two lengths of EMT conduit together. MATERIAL:
Zinc Die Cast. FEATURES:Concrete-Tight1/2˝-1˝,Concrete-TightWhenTaped11/4˝-4˝.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
10
EMT
ELECTRICAL METALLIC TUBING FITTINGS
TM
10
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Set-Screw Connectors Steel
1/2˝ 62705B 50/500 4.0/40.4
3/4˝ 62707B 25/250 4.0/35.9
1˝ 62710B 20/200 4.2/42.9
11/4˝ 62712B 25 8.5
11/2˝ 62715B 25 12
2˝ 62720B 20 12
21/2˝ 62725B 12 15
3˝ 62730B 12 21
31/2˝ 62735B 6 13
4˝ 62740B 6 15
WITH INSULATED THROAT
1/2˝ 82705B 50/500 4.0/40.4
3/4˝ 82707B 25/250 4.0/35.9
1˝ 82710B 20/200 4.2/42.9
11/4˝ 82712B 25 8.5
11/2˝ 82715B 25 12
2˝ 82720B 20 12
21/2˝ 82725B 12 15
3˝ 82730B 12 21
31/2˝ 82735B 6 13
4˝ 82740B 6 15
APPLICATION: INDOORS ONLY – Use to connect EMT conduit to steel outlet box, load center, or
other metal enclosure. MATERIAL: Steel, Zinc Electro-Plate. FEATURES: Concrete-Tight When
Taped. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Set-Screw Couplings Steel
1/2˝62805B 50/500 4.2/42.9
3/4˝62807B 25/250 3.2/32.9
1˝62810B 10/100 2.5/25
11/4˝62812B 25 10.5
11/2˝62815B 25 13.6
2˝62820B 20 13.2
21/2˝62825B 12 17.5
3˝62830B 12 25
31/2˝62835B 6 14
4˝62840B 6 17
APPLICATION: INDOORS ONLY – Use to join two lengths of EMT conduit together. MATERIAL:
Steel, Zinc Electro-Plate, Hardened Screws. FEATURES: Concrete-Tight When Taped.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
•Image shown is for
1/2" - 2". 2 1/2" - 4"
has two screws.
•Image shown is for
1/2" - 2". 2 1/2" - 4"
has four screws.
11
®
EMT
ARE MINIMUM
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A RADII
45° Elbows Steel
1/2˝64505 10 2.4 1.50 4.00
3/4˝64507 10 3.3 1.50 4.50
1˝64510 25 14.3 1.88 5.75
11/4˝64512 20 20 2.00 7.25
11/2˝64515 15 22.1 2.00 8.25
2˝64520 10 21 2.00 9.50
21/2˝64525 1 3.6 3.00 10.50
3˝64530 1 7 3.13 13.00
31/2˝64535 1 8.5 3.25 15.00
4˝64540 1 10 3.38 16.00
APPLICATION: INDOORS OR OUTDOORS – To connect EMT conduit together to allow
for 45° bends. MATERIAL: 16 ga. Galvanized Steel. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
11
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
EMT To Box Offset Connectors Zinc Die Cast
SET-SCREW TYPE
1/2˝ 03705B 10/100 1/10 2.09 0.94 0.38
3/4˝ 03707B 10/100 1.9/19 2.98 1.16 0.75
APPLICATION: INDOORS ONLY – Use to connect EMT conduit to a metal outlet box or
enclosure where an offset is desired. MATERIAL: Zinc Die Cast. FEATURES: Concrete-Tight.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
EMT To Box Offset Connectors Zinc Die Cast
COMPRESSION TYPE
1/2˝03905 20 2.3 2.13 1.00 0.38
3/4˝03907 10 2.1 2.90 1.19 0.75
APPLICATION: INDOORS OR OUTDOORS – Use to connect EMT conduit to a metal outlet box
or enclosure where an offset is desired. MATERIAL: Zinc Die Cast. FEATURES: Concrete-Tight.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
ARE MINIMUM
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A RADII
90° Elbows Steel
1/2˝64405B 50 13.5 1.500 4.00
3/4˝64407B 50 23.5 1.500 4.50
1˝64410B 25 21 1.880 5.75
11/4˝64412B 20 31.4 2.000 7.25
11/2˝64415B 15 32.3 2.000 8.25
2˝64420B 10 29.9 2.000 9.50
21/2˝64425 1 5 3.000 10.50
3˝64430 1 7.5 3.130 13.00
31/2˝64435 1 10.1 3.250 15.00
4˝64440 1 13 3.380 16.00
APPLICATION: INDOORS OR OUTDOORS – To connect EMT conduit together to allow
for 90° bends. MATERIAL: 16 ga. Galvanized Steel. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
DIMENSIONS
12
EMT
ELECTRICAL METALLIC TUBING FITTINGS
TM
12
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
90° Compression Elbows Zinc Die Cast
SHORT RADIUS
1/2˝ 02905B 25/250 4.7/47 1.75 0.83 0.52
3/4˝ 02907B 20/200 5.6/56 1.86 0.95 0.52
1˝02910 5 2.2 2.21 1.12 0.67
APPLICATION: INDOORS OR OUTDOORS – Use to connect EMT conduit to a steel outlet box or
enclosure where a close radius is desired. MATERIAL: Zinc Die Cast. FEATURES: Concrete-Tight.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
90° Compression Elbows Zinc Die Cast
LARGE RADIUS
1/2˝ 02805B 20/200 2.6/26 1.595 1.451 0.521
3/4˝ 02807B 10/100 2.0/20 1.882 1.675 0.521
APPLICATION: INDOORS OR OUTDOORS – Use to connect EMT conduit to a steel outlet box
or enclosure where a large radius 90° bend is desired. MATERIAL: Zinc Die Cast. FEATURES:
Concrete-Tight. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
90° Set-Screw Elbows Zinc Die Cast
LARGE RADIUS
1/2˝ 02705B 20/200 2.2/22 1.444 1.400 0.521
3/4˝ 02707B 10/100 1.7/17 1.900 1.642 0.518
APPLICATION: INDOOR USE ONLY – Use to connect EMT conduit to a steel outlet box or
enclosure where a large radius 90° bend is desired. MATERIAL: Zinc Die Cast. FEATURES:
Concrete-Tight. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
13
®
EMT
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Drive Straps Steel
1/2˝ 61405B 100/1000 1.4/14 2.00 1.10
3/4˝ 61407B 100/1000 1.6/16 2.12 1.20
1˝ 61410B 100/1000 2.4/24 2.25 1.50
APPLICATION: INDOORS OR OUTDOORS – To secure EMT to a wood or similar surface.
MATERIAL: Steel, Zinc Plate. TYPE: Flat Style. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
One-Hole Straps Steel
1/2˝ 61505B 100/1000 3/25 1.250 0.562
3/4˝ 61507B 100/1000 4/38 1.375 0.625
1˝ 61510B 50/500 3/31.5 1.562 0.750
11/4˝ 61512B 50/500 4/40 2.000 0.875
11/2˝ 61515B 25/250 3/36.5 2.125 1.000
2˝ 61520B 20/200 4.5/45 2.625 1.125
21/2˝61125 10 4.3 3.312 1.250
3˝61130 10 5 3.625 1.250
31/2˝ 61135B 25 17.5 4.000 1.250
4˝ 61140B 20 15.6 4.250 1.250
APPLICATION: INDOORS OR OUTDOORS – To support EMT conduit where greater load bearing
is required. MATERIAL: Steel, Zinc Electro-Plate. TYPE: Snap-On Style. CERTIFICATIONS: TO
UL AND CSA REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Two-Hole Straps Steel
1/2˝ 61605B 100/1000 2/18 2.250 1.625 0.562
3/4˝ 61607B 100/1000 2/25.5 2.750 2.125 0.625
1˝ 61610B 50/500 1.5/15.5 3.000 2.437 0.688
11/4˝ 61612B 25/250 1.5/14 3.750 2.937 0.750
11/2˝ 61615B 25/250 2/20 4.250 3.500 0.875
2˝ 61620B 50/200 7/28 4.812 4.000 1.000
21/2˝ 61225B 25 4.3 5.875 4.875 1.000
3˝ 61230 10 2.5 6.500 5.500 1.000
31/2˝ 61235B 25 6.5 7.375 6.375 1.000
4˝ 61240B 20 6.6 8.000 7.000 1.000
APPLICATION: INDOORS OR OUTDOORS – To support EMT conduit where greater load bearing
is required. MATERIAL: Steel, Zinc Electro-Plate. TYPE: Snap-On Style. CERTIFICATIONS: TO UL
AND CSA REQUIREMENTS.
13
a
b
DIMENSIONS
14
EMT
ELECTRICAL METALLIC TUBING FITTINGS
TM
14
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
EMT-To-EMT Pull Elbows Zinc Die Cast
WITHOUT GASKET
1/2˝14405 15 2.8 1.31 0.97
3/4˝14407 10 3.7 1.50 1.20
WITH NEOPRENE GASKET
1/2˝94405 10 2.4 1.31 0.97
3/4˝94407 5 1.9 1.50 1.20
1˝94410 5 3.4 1.85 1.52
APPLICATION: DRY LOCATIONS – Use to connect EMT conduit together at a 90° bend.
MATERIAL: Zinc Die Cast. TYPE: Set-Screw. FEATURES: Removable aluminum cover facilitates
wire pulling. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
b
a
b
a
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
EMT-To-Box Pull Elbows Zinc Die Cast
WITHOUT GASKET
1/2˝14305 10 2.2 1.31 0.97
3/4˝14307 5 1.8 1.50 1.20
APPLICATION: DRY LOCATIONS – Use to connect EMT conduit to a metal box or enclosure to
form a 90° bend. MATERIAL: Zinc Die Cast. TYPE: Set-Screw. FEATURES: Removable aluminum
cover facilitates wire pulling. Die cast locknut provided. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
EMT/Rigid-To-EMT/Rigid Combo Elbows Zinc
Die Cast
1/2˝94505 10 BAGS 2.0 1.31 0.97
3/4˝94507 10 BAGS 3.0 1.500 1.200
1˝94510 5 2.9 1.85 1.52
APPLICATION: INDOORS OR OUTDOORS. Use as a wire pulling elbow to facilitate wire pulling
through a sharp bend in a run of EMT or threaded Rigid or IMC conduit. Removable cover provides
easy access to facilitate wire pulling. Not listed for wet locations. MATERIAL: Zinc Die Cast.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
EMT/Rigid-To-Box Combo Elbows Zinc Die Cast
WITH NEOPRENE GASKET
1/2˝94705 10 BAGS 1.90 1.310 1.020
3/4˝94707 5 BAGS 1.50 1.500 1.270
APPLICATION: INDOORS OR OUTDOORS. Use to connect a run of EMT or threaded Rigid or IMC
conduit to an outlet box, or other metal enclosure. Removable cover provides easy access to facilitate
wire pulling. Not listed for wet locations. MATERIAL: Zinc Die Cast. CERTIFICATIONS: TO UL AND
CSA REQUIREMENTS.
WITH NEOPRENE GASKET
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
EMT-To-EMT Inside-Corner Pull Elbows Zinc
Die Cast
WITHOUT GASKET
1/2˝14605 15 2.7 1.81 1.00
3/4˝14607 8 1.9 2.00 1.25
APPLICATION: INDOORS ONLY – Use to connect EMT conduit together on a 90° inside corner.
MATERIAL: Zinc Die Cast. TYPE: Set-Screw. FEATURES: Removable cover facilitates wire
pulling. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
15
®
EMT
15
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
EMT-To-Flex Combination Couplings Zinc Die Cast
COMPRESSION TO SCREW-IN TYPE
1/2˝-1/2˝04905B 50/500 4/40 0.84 1.00
3/4˝-3/4˝04907B 25/250 2.8/27.5 0.95 1.19
1˝-1˝04910 10 1.7 1.11 1.48
APPLICATION:INDOORSONLY–UsetojoinEMTconduittoexiblemetallicconduit.MATE-
RIAL: Zinc Die Cast. TYPE: Compression To Screw-In. SUITABLE FOR:1/2˝steel,steelreduced
wall,andaluminumexiblemetalconduittoEMT,3/4˝-1˝exiblemetalconduittoEMT.CERTIFI-
CATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
EMT Insulating Bushings Polyethylene
1/2" 75005B 100/1000 0.4/4.0 0.725 0.181 0.570
3/4" 75007B 75/750 0.35/3.5 0.940 1.030 0.760
1" 75010B 50/500 0.35/3.5 0.945 1.300 0.635
1 1/4" 75012B 25/250 0.25/2.5 1.240 1.655 0.625
1 1/2" 75015B 25/250 0.3/3.0 1.44 1.918 0.625
2" 75020B 25/250 0.45/4.5 1.870 2.380 0.625
APPLICATION: INDOORS ONLY – Use to protect cables from abrasion from edge of EMT.
MATERIAL: Polyethylene. FEATURES:Holdsrmlyinplacewhilepullingvariouscables,i.e.
power, cable TV, telephone/modem, alarm/security systems. Meets 2008 NEC code requirements
for 300.16 (B) protection.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART# QTY WT (LBS) A B C
EMT-To-Flex Combination Couplings Zinc Die Cast
SET-SCREW TYPE
1/2˝-1/2˝15305B 25/250 2.5/25 0.75 0.95 1.65
3/4˝-3/4˝15307B 25/250 3.6/36 0.91 1.11 1.98
APPLICATION:INDOORSONLY–UsetojoinEMTconduittoexiblemetalconduit.MATERIAL:
Zinc Die Cast. TYPE: Set-Screw. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
EMT-To-Non-Metallic Zinc
Combination Couplings Die Cast
1/2˝-NM 15303B 50/500 4/40 0.17 0.63 1.35
APPLICATION: INDOORS ONLY – Use to join EMT conduit to non-metallic sheathed cable
(1) 14-2 to (1) 10-3, (2) 14-2 to (2) 12-3. MATERIAL: Zinc Die Cast. TYPE: Set-Screw.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
EMT-To-Rigid Combination Couplings Steel
SET-SCREW TYPE
1/2"-1/2” 15304B 25 3.5
3/4"-3/4” 15306B 25 6.1
APPLICATION: INDOORS ONLY – Use to join EMT conduit to Rigid metal conduit. MATERIAL:
Steel, Zinc Electro-Plate. TYPE: Set-Screw.
NEW
16
EMT
ELECTRICAL METALLIC TUBING FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
EMT/Rigid Combo Conduit Bodies Aluminum
WITH COVER AND GASKET ASSEMBLED TYPE LL
1/2˝ 56305 10 2.7 3.875 2.047 4.375 1.438
3/4˝ 56307 6 1.62 4.625 2.938 5.125 1.688
APPLICATION: INDOORS OR OUTDOORS – Use to gain access to the interior of a raceway for
wirepulling,splicing(withlimitationsasspeciedbytheNEC),andmaintenance.Threadportwithset-
screw for use with threaded or smooth pipe. Not listed for wet locations. MATERIAL: Copper-Free
Aluminum Die Cast. FEATURES: Use with EMT or Rigid conduit. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
EMT/Rigid Combo Conduit Bodies Aluminum
WITH COVER AND GASKET ASSEMBLED
TYPE C
1/2˝ 56405 10 2.5 3.875 1.438 4.906 1.063
3/4˝ 56407 6 2.5 4.125 1.688 5.500 1.344
APPLICATION: INDOORS OR OUTDOORS – Use to gain access to the interior of a raceway for wire
pulling,splicing(withlimitationsasspeciedbytheNEC),andmaintenance.Threadportwithset-screwfor
use with threaded or smooth pipe. Not listed for wet locations. MATERIAL: Copper-Free Aluminum Die
Cast. FEATURES: Use with EMT or Rigid conduit. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
EMT/Rigid Combo Conduit Bodies Aluminum
WITH COVER AND GASKET ASSEMBLED TYPE LB
1/2˝ 56605 10 2.7 3.875 2.125 4.375 1.063
3/4˝ 56607 10 3.8 4.625 2.438 5.125 1.344
APPLICATION: INDOORS OR OUTDOORS – Use to gain access to the interior of a raceway for wire
pulling,splicing(withlimitationsasspeciedbytheNEC),andmaintenance.Threadportwithset-screwfor
use with threaded or smooth pipe. Not listed for wet locations. MATERIAL: Copper-Free Aluminum Die
Cast. FEATURES: Use with EMT or Rigid conduit. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
EMT/Rigid Combo Conduit Bodies Aluminum
WITH COVER AND GASKET ASSEMBLED TYPE T
1/2˝ 56805 10 3.2 3.875 1.438 4.906 2.125
3/4˝ 56807 5 1.6 4.625 1.688 5.500 2.344
APPLICATION: INDOORS OR OUTDOORS – Use to gain access to the interior of a raceway for wire
pulling,splicing(withlimitationsasspeciedbytheNEC),andmaintenance.Threadportwithset-screwfor
use with threaded or smooth pipe. Not listed for wet locations. MATERIAL: Copper-Free Aluminum Die
Cast. FEATURES: Use with EMT or Rigid conduit. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
17
®
EMT
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
EMT/Rigid Combo Conduit Bodies Aluminum
WITH COVER AND GASKET ASSEMBLED TYPE LR
1/2˝ 56905 10 3 3.875 2.047 4.375 1.438
3/4˝ 56907 6 3 4.660 1.562 5.091 1.810
APPLICATION: INDOORS OR OUTDOORS – Use to gain access to the interior of a raceway for wire
pulling,splicing(withlimitationsasspeciedbytheNEC),andmaintenance.Threadportwithset-screwfor
use with threaded or smooth pipe. Not listed for wet locations. MATERIAL: Copper-Free Aluminum Die
Cast. FEATURES: Use with EMT or Rigid conduit. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
EMT/Conduit Bodies - Set-Screw Aluminum
WITH COVER AND GASKET ASSEMBLED TYPE LB
1/2˝ 58705 5 1.8 3.875 2.125 4.375 1.063
3/4˝ 58707 3 1.2 4.625 2.438 5.125 1.344
APPLICATION: INDOORS OR OUTDOORS – Use to gain access to the interior of a raceway for
wirepulling,splicing(withlimitationsasspeciedbytheNEC),andmaintenance.Set-screwforuse
with EMT smooth pipe. Not listed for wet locations. MATERIAL: Copper-Free Aluminum Die Cast.
FEATURES: Use with EMT. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
18
FLEX
MC & AC CABLE & FLEXIBLE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Screw-In Connectors Zinc Die Cast
3/8˝(1/2” ko) 04403B 50/500 3/30 1.31 0.92
1/2˝ 04405B 50/500 3/30 1.38 0.92
3/4˝ 04407B 25/250 2.5/25 1.62 1.12
1˝ 04410B 25/250 4/40 1.94 1.37
1 1/4˝ 04412B 10/100 2.8/28 2.12 1.75
1 1/2˝ 04415B 10/40 3.8/15.2 2.31 2.13
2˝ 04420B 10/40 6.3/25.2 2.58 2.67
WITH INSULATED THROAT
3/8˝(1/2” ko) 84403B 50/500 3/30 1.36 0.92
1/2˝ 84405B 50/500 3/30 1.43 0.92
3/4˝ 84407B 25/250 2.5/25 1.67 1.12
1˝ 84410 15 2.3 1.99 1.37
1 1/4˝ 84412 10 2.8 2.17 1.75
1 1/2˝ 84415 5 1.9 2.36 2.13
2˝ 84420 5 3.2 2.63 2.67
APPLICATION: INDOORS ONLY - Use to connect exible metallic conduit to steel outlet box, load
center or other metal enclosure. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout (ko).
SUITABLE FOR: 1/2˝ - steel, reduced wall steel, and aluminum exible metal conduit. 3/8˝, 3/4˝
to 1 1/4˝ and 2˝ exible metal conduit. 1 1/2˝ - steel and steel reduced wall exible metal conduit.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Screw-In Connectors Zinc Die Cast
SNAP-IN TYPE
3/8˝(1/2” ko) 04403NB 50/500 1.9/19 1.269 0.918
1/2˝ 04405NB 50/500 2/20 1.344 0.918
APPLICATION: INDOORS ONLY - Use to connect exible metallic conduit to steel outlet box,
load center or other metal enclosure. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝
knockout (ko). SUITABLE FOR: 3/8˝ exible metal conduit. 1/2˝ - steel and steel reduced wall
exible metal conduit. FEATURES: New Snap-In design allows for quick and easy installation.
No locknuts required. Meets UL ground fault requirements. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Screw-In Couplings Zinc Die Cast
1/2˝ 04505B 50/500 3/30 1.81 0.92
3/4˝ 04507B 25/250 2.3/22.5 2.09 1.12
1˝ 04510 15 3.8 2.41 1.37
1 1/4˝ 04512 10 2.5 2.75 1.81
1 1/2˝ 04515 5 2 3.05 2.12
2˝ 04520 4 2.4 3.28 2.67
APPLICATION: INDOORS ONLY - Use to join two pieces of exible metallic conduit. MATERIAL:
Zinc Die Cast. SUITABLE FOR: 1/2˝ - steel, steel reduced wall, and aluminum exible metal
conduit; 3/4˝ to 1 1/4˝ and 2˝ exible metal conduit; 1 1/2˝ - steel and steel reduced wall exible
metal conduit. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
19
®
FLEX
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B C
(MIN) (MAX)
90° Connectors Zinc Die Cast
3/8˝(1/2” ko) 11003B 50/500 4.5/45 0.40 0.63 1.81
1/2˝ 11005B 25/250 3.5/35 0.65 0.97 2.18
3/4˝ 11007B 10/100 2/20 0.77 1.12 2.38
1˝ 11010B 5/50 1.9/19 1.06 1.40 2.87
1 1/4˝ 11012B 10/40 5.1/20.4 1.34 1.65 3.93
1 1/2˝ 11015B 5 5.7 1.51 2.47 6.05
2˝ 11020B 5 6.2 1.51 2.47 6.05
2 1/2˝ 11025B 2 6.1 2.44 — 3.02 4.97
3˝ 11030B 1 4.2 2.97 — 3.48 5.50
3 1/2˝ 11035B 1 5.6 3.25 — 4.20 6.50
4˝ 11040B 1 7.5 3.66 — 4.75 7.25
WITH INSULATED THROAT A B C
3/8˝(1/2” ko) 91003B 25/250 2.3/23 0.40 0.63 1.81
1/2˝ 91005B 25/250 3.5/35 0.65 0.97 2.18
3/4˝ 91007B 10/100 2/20 0.77 1.12 2.38
1˝ 91010 5 1.9 1.06 1.40 2.87
1 1/4˝ 91012 5 2.6 1.34 1.65 3.93
1 1/2˝ 91015 4 4.6 1.51 2.47 6.05
2˝ 91020 2 2.5 1.51 2.47 6.05
APPLICATION: INDOORS ONLY - In a dry location, use to connect exible metal conduit,
aluminum and steel AC and MC cable to a steel outlet box or other metal enclosure. MATERIAL:
Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout. SUITABLE FOR: 11003B = Aluminum or steel
#14/2 AC; 3/8” exible metal conduit; .450-.550 ex cord; .465-558 steel MC; .455-.540 aluminum
MC. 11005B = Steel #14/2 AC; aluminum #10-4 AC; 1/2” exible metal conduit; .685-.825 ex cord;
.630-.880 steel and aluminum MC. 3/4”-4” exible metal conduit. CERTIFICATIONS: TO UL AND
CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
90° Connectors Zinc Die Cast
SNAP-IN TYPE
3/8˝(1/2” ko) 11003NB 50/500 3.7/37 0.40 0.63 1.756
1/2˝ 11005NB 25/250 2.7/27 0.65 0.97 2.125
APPLICATION: INDOORS ONLY - In a dry location, use to connect exible metal conduit,
aluminum and steel AC and MC cable to a steel outlet box or other metal enclosure. MATERIAL:
Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout. SUITABLE FOR: 3/8˝ - 1/2˝ steel and aluminum
armored cable, steel and aluminum interlocked metal clad cable, exible cord, and exible
metal conduit. FEATURES: New Snap-In design allows for quick and easy installation. No
locknuts required. Meets UL ground fault requirements. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
A
B
C
2 1/2˝ - 4˝
20
FLEX
MC & AC CABLE & FLEXIBLE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Anti-Short Bushings Polyethylene
FITS CABLE RANGE: 14/2, 14/3, 12/2
0 (5/16˝) 75400 10 BAGS/35 PCS 0.6 0.394 0.350
0 (5/16˝) 75400BP 1000 1.7 0.394 0.350
FITS CABLE RANGE: 14/4, 12/3, 6/1, 4/1
1 (3/8˝) 75401 10 BAGS/35 PCS 0.45 0.450 0.410
1 (3/8˝) 75401BP 1000 2.0 0.450 0.410
FITS CABLE RANGE: 12/4, 10/2, 10/3, 2/1
2 (7/16˝) 75402 5 BAGS/35 PCS 0.4 0.588 0.540
2 (7/16˝) 75402BP 500 1.2 0.588 0.540
3 (1/2˝) 75403 5 BAGS/20 PCS 0.3 0.780 0.730
3 (1/2˝) 75403BP 250 1.0 0.780 0.730
4 (3/4˝) 75404 4 BAGS/16 PCS 0.2 0.990 0.940
4 (3/4˝) 75404BP 250 1.0 0.990 0.940
B
A
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
Squeeze Connectors Zinc Die Cast
SNAP-IN TYPE
3/8˝(1/2” ko) 04203NB 50/500 2.3/23 0.58 0.62 0.938
1/2˝ 04205NB 25/250 1.8/18 0.74 0.997 1.305
APPLICATION: INDOORS ONLY - In a dry location, use to connect exible metallic conduit and steel
AC cable to a steel outlet box or other metal enclosure. The 3/8˝ can also be used with steel and
aluminum MC cable. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout (ko). SUITABLE
FOR: 3/8˝ steel exible conduit, #14/2 wire steel armored cable, .561” steel and .538-.599” aluminum
interlocked metal clad cable. 1/2˝ steel exible metal conduit and #4-2 wire steel armored cable.
FEATURES: New Snap-In design allows for quick and easy installation. No locknut required. Meets
UL ground fault requirements. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
Squeeze Connectors Zinc Die Cast
3/8˝(1/2” ko) 04203B 50/500 3.5/35 0.58 0.61 1.00
1/2˝ 04205B 25/250 2.5/25 0.74 0.95 1.47
3/4˝ 04207B 25/250 3.3/32.5 0.88 1.11 1.58
1˝ 04210B 10/100 2/20 1.14 1.38 1.75
1 1/4˝ 04212B 10/100 2.9/29 1.42 1.65 1.91
1 1/2˝ 04215B 5/50 2/19.5 1.68 1.94 2.09
2˝ 04220B 10/40 4.6/18.4 2.08 2.56 2.34
2 1/2˝ 04225B 10 9 2.88 3.25 2.75
3˝ 04230B 5 6.5 3.34 3.63 3.19
3 1/2˝ 04235B 2 3 3.75 4.13 3.56
4˝ 04240B 1 2 4.19 4.56 3.94
WITH INSULATED THROAT
1/2˝ 84205B 25/250 2.5/25 0.74 0.95 1.52
3/4˝ 84207B 25/250 3.3/32.5 0.88 1.11 1.63
1˝ 84210B 10/100 2/20 1.14 1.38 1.80
1 1/4˝ 84212B 10/100 2.9/29 1.42 1.65 1.96
1 1/2˝ 84215B 5/50 2/19.5 1.68 1.94 2.14
2˝ 84220B 10/40 4.6/18.4 2.08 2.56 2.39
APPLICATION: INDOORS ONLY - In a dry location, use to connect exible metallic conduit and
steel AC cable to a steel outlet box, load center or other metal enclosure. The 3/8˝ can also be used
with steel and aluminum MC cable. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout.
SUITABLE FOR: 3/8˝ steel exible conduit, #14/2 wire steel armored cable, .561 steel and .538-.599
aluminum interlocked metal clad cable. 1/2˝ steel exible metal conduit and #4-2 wire steel armored
cable. 3/4˝ steel exible metal conduit and #6-3 wire steel armored cable. 1˝ steel and reduced wall
steel exible metal conduit and #2-2 wire steel armored cable.1 1/4˝ - 4˝ steel exible metal conduit.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
APPLICATION: INDOORS ONLY - Use to protect wire within exible metallic conduit MC and AC
cable. Insert one bushing at each end of conduit or cable. MATERIAL: Polyethylene.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
21
®
FLEX
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
FLEX-To-EMT Zinc Die Cast
Combination Couplings
COMPRESSION TO SCREW-IN TYPE
1/2˝ 04905B 50/500 4/40 0.84 1.10
3/4˝ 04907B 25/250 2.8/27.5 0.95 1.30
1˝ 04910 10 1.7 1.11 1.62
APPLICATION: INDOORS ONLY - Use to join EMT conduit to exible metallic conduit
MATERIAL: Zinc Die Cast. TYPE: Compression to Screw-in. SUITABLE FOR: 1/2˝ steel, steel
reduced wall, and aluminum exible metal conduit to EMT, 3/4˝-1˝ exible metal conduit to EMT.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
FLEX-To-EMT Zinc Die Cast
Combination Couplings
SET-SCREW TYPE
1/2˝-1/2˝ 15305B 25/250 2.5/25 0.75 0.95 1.65
3/4˝-3/4˝ 15307B 25/250 3.6/36 — 1.11 1.98
APPLICATION: INDOORS ONLY - Use to join EMT conduit to exible metal conduit. MATERIAL:
Zinc Die Cast. TYPE: Set-Screw Type. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
AC (MC) One-Hole Straps Steel
3/8˝ 62181B 100/1000 1/10 0.96 0.50
APPLICATION: INDOORS ONLY - Use to secure AC/MC cable to a wood, masonry or similar
surface. MATERIAL: Steel, Zinc Electro-Plate.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Set-Screw Connectors Zinc Die Cast
1/2˝ 04805B 25/250 2.5/25 0.94 1.46
3/4˝ 04807B 25/250 3.8/38 1.15 1.56
WITH INSULATED THROAT
1/2˝ 84805B 25/250 2.5/25 0.94 1.51
3/4˝ 84807B 25/250 3.8/38 1.15 1.61
APPLICATION: INDOORS ONLY - In a dry location, use to connect steel or aluminum exible
metallic conduit to a steel outlet box or other metal enclosure. MATERIAL: Zinc Die Cast.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS) A A B C
(MIN) (MAX)
Clamp-Combination Connectors Zinc Die Cast
3/8˝(1/2” ko) 05703B 100/1000 6/60 0.18 0.64 1.18 0.34
APPLICATION: INDOORS - In a dry location, use to connect exible metallic conduit, AC, MC, or
NM cable to steel outlet box or other enclosure. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts
1/2˝ knockout. SUITABLE FOR: #14/2 thru 12/3 with ground NM sheathed cable, #14-2 wire steel
armored cable, 3/8˝ steel exible metal conduit, alum. cont. corrugated metal clad cable 0.365-
0.519˝ dia., alum. smooth sheath metal clad cable 0.345-0.525˝ dia., alum. interlocked metal
clad cable 0.455-0.575˝ dia., rect. alum. cont. corrugated metal clad cable 0.277˝ x 0.375˝, steel
interlocked metal clad cable 0.435-0.547˝ dia. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
(IN INCHES)
22
FLEX
MC & AC CABLE & FLEXIBLE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B C
(MIN) (MAX)
Clamp-Combination Connectors Zinc Die Cast
SNAP-IN TYPE
3/8˝(1/2” ko) 05703NB 100/1000 4.2/42 0.18 0.64 1.18 0.34
APPLICATION: INDOORS - In a dry location, use to connect exible metallic conduit, AC, MCxand
NM cable to steel outlet box or other enclosure. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts
1/2˝ knockout. SUITABLE FOR: #14/2 thru 12/3 with ground NM sheathed cable, #14-2 wire steel
armored cable, 3/8˝ steel exible metal conduit, alum. cont. corrugated metal clad cable 0.365-
0.519˝ dia., alum. smooth sheath metal clad cable 0.345-0.525˝ dia., alum. interlocked metal
clad cable 0.455-0.575˝ dia., rect. alum. cont. corrugated metal clad cable 0.277˝ x 0.375˝, steel
interlocked metal clad cable 0.435-0.547˝ dia. FEATURES: New Snap-In design allows for quick
and easy installation. Meets UL ground fault requirements. No locknut required. CERTIFICATIONS:
TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
Duplex Connectors Zinc Die Cast
3/8˝(1/2” ko) 15803B 25/250 3.3/32.5 0.13 0.65 1.496
APPLICATION: INDOORS ONLY - In a dry location, use to connect two pieces of exible metallic
conduit, AC, MC or NM sheathed cable, to a steel outlet box or other metal enclosure when using
only one knockout opening. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout.
SUITABLE FOR: #14-2 thru #12-3 wire with ground NM sheathed cable, #14-2 wire steel armored
cable, #14-2 wire with ground thru #10-4 with ground alum. armored cable, 3/8˝ FMC, alum.
smooth sheath metal clad cable 0.410-0.500˝ dia., alum. interlocked metal clad cable 0.460-0.538˝
dia., steel interlocked metal clad cable 0.438-0.560˝ dia. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
Duplex Connectors Zinc Die Cast
SNAP-IN TYPE
3/8˝(1/2” ko) 15803NB 25/250 2.5/25 0.13 0.65 1.496
APPLICATION: INDOORS ONLY - In a dry location, use to connect two pieces of exible metallic
conduit, AC, MC or NM sheathed cable, to a steel outlet box or other metal enclosure when using
only one knockout opening. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout.
SUITABLE FOR: #14-2 thru #12-3 wire with ground NM sheathed cable, #14-2 wire steel armored
cable, #14-2 wire with ground thru #10-4 with ground alum. armored cable, 3/8˝ FMC, alum.
smooth sheath metal clad cable 0.410-0.500˝ dia., alum. interlocked metal clad cable 0.460-
0.538˝ dia., steel interlocked metal clad cable 0.438-0.560˝ dia. FEATURES: New Snap-In design
allows for quick and easy installation. No locknut required. Meets UL ground fault requirements.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
Saddle Connectors Zinc Die Cast
3/8˝(1/2” ko) 06703B 50/500 4/40 0.12 0.63 0.939
INSULATED THROAT
3/8˝(1/2” ko) 86703B 50/500 4/40 0.134 0.681 1.017
APPLICATION: INDOORS ONLY - In a dry location, use to connect exible metallic conduit, AC,
MC and NM sheathed cable to a steel outlet box or other metal enclosure. MATERIAL: Zinc Die
Cast. MISC: 3/8˝ size ts 1/2˝ knockout. SUITABLE FOR: #14-2 to the largest size ttable NM
sheathed cable, #14-2 with ground steel and aluminum armored cable - .470˝ dia., 3/8˝ steel exible
metal conduit, alum. cont. corrugated metal clad cable 0.510-0.620˝ dia., alum. smooth sheath
metal clad cable 0.410-0.500˝ dia., alum. interlocked metal clad cable 0.462-0.548˝ dia.,
steel interlocked metal clad cable 0.442-0.552˝ dia. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
23
®
FLEX
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
Saddle Connectors Zinc Die Cast
SNAP-IN TYPE
3/8˝(1/2” ko) 06703NB 50/500 3/30 0.12 0.63 0.939
APPLICATION: INDOORS ONLY - In a dry location, use to connect exible metallic conduit, AC,
MC and NM sheathed cable to a steel outlet box or other metal enclosure. MATERIAL: Zinc Die
Cast. MISC: 3/8˝ size ts 1/2˝ knockout. SUITABLE FOR: #14-2 to the largest size ttable NM
sheathed cable, #14-2 with ground steel and aluminum armored cable - .470˝ dia., 3/8˝ steel exible
metal conduit, alum. cont. corrugated metal clad cable 0.510-0.620˝ dia., alum. smooth sheath
metal clad cable 0.410-0.500˝ dia., alum. interlocked metal clad cable 0.462-0.548˝ dia., steel
interlocked metal clad cable 0.442-0.552˝ dia. FEATURES: New Snap-In design allows for quick
and easy installation. No locknut required. Meets UL ground fault requirements. CERTIFICATIONS:
TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
AC (BX) Connectors Zinc Die Cast
3/8˝(1/2” ko) 05803B 100/1000 5/50 0.38 0.63 0.781
APPLICATION: INDOORS ONLY - In a dry location, use to connect AC (BX) cable to a steel
outlet box or other metal enclosure. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝
knockout. SUITABLE FOR: #14-2 steel armored cable. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
AC (BX) Connectors Zinc Die Cast
SNAP-IN TYPE
3/8˝(1/2” ko) 05803NB 100/1000 3.8/38 0.38 0.63 0.781
APPLICATION: INDOORS ONLY - In a dry location, use to connect AC (BX) cable to a steel outlet
box or other metal enclosure. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout (ko).
SUITABLE FOR: #14-2 steel armored cable. FEATURES: New Snap-In design allows for quick and
easy installation. No locknut required. Meets UL ground fault requirements. CERTIFICATIONS: TO
UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
MC “Snap-In” Connectors Steel
SNAP-IN TYPE
3/8˝(1/2” ko) 65705B 50/500 4.3/43 1.45 0.94
APPLICATION: INDOORS – In a dry location, use to connect aluminum or steel AC and MC
cables. MATERIAL: Steel, Zinc Electro-Plate. MISC: 3/8˝ size ts 1/2˝ knockout. SUITABLE FOR:
Aluminum and steel armored cable with #14-2-#10-3 wire; steel MC cable with #14-2-#10-3 wire;
aluminum MC cable with #10-3 wire. FEATURES: Snap-In installation, no locknut, insulating
bushing included. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
MC “Snap-In” Duplex Connectors Steel
SNAP-IN TYPE
3/8˝(1/2” ko) 65805B 25/250
APPLICATION: INDOORS – In a dry location, use to connect aluminum or steel AC and MC
cables. MATERIAL: Steel, Zinc Electro-Plate. MISC: 3/8˝ size ts 1/2˝ knockout. SUITABLE FOR:
Aluminum and steel armored cable with #14-2-#12-4 wire; steel MC cable with #14-2-#10-2 wire;
aluminum MC cable with #14-2-#12-4 wire. FEATURES: Snap-In installation, no locknut, insulating
bushing included. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
B
A
NEW
24
FLEX
MC & AC CABLE & FLEXIBLE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
SNAP-RITE® MC, AC, FLEX Connectors Zinc
Die Cast
3/8˝(1/2” ko) 85403NB 50/500 2.6/26 1.202 0.880
APPLICATION: INDOORS ONLY - In a dry location, use to connect MC and AC aluminum and
steel cable to metal outlet boxes, electrical enclosures and other metal enclosures. MATERIAL:
Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout. SUITABLE FOR: 85403N for one cable of these
characteristics: AC Cable: CULUS listed for aluminum and steel AC cable .405” to .615” diameter.
This is normally 14-2, 14-3, 14-4; 12-2, 12-3, 12-4; 10-2 and some 10-3. MC Cable: ULUS listed
for aluminum and steel MC cable .405” to .615” diameter. This is normally 14-2, 14-3, 14-4; 12-2,
12-3, 12-4; 10-2, 10-3 and some 10-4. MCI-A Cable: CULUS listed for aluminum MCI-A cable .400”
to .500” diameter. This is normally 14-2, 14-3, 14-4; 12-2, 12-3, 12-4; 10-2 and 10-3. For all of the
above sizes, Hospital Grade HCF (Health Care Facilities), Home Run, Super Neutral, Fire Alarm
and Isolated Ground cables are approved as well. FEATURES: Snap-In installation, no locknut,
insulating bushing included. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
SNAP-RITE® Duplex MC, AC, FLEX Zinc
Connectors Die Cast
3/8˝(1/2” ko) 95403NB 25/100 2.6/10.4 1.816 1.56
APPLICATION: INDOORS ONLY - In a dry location, use to connect MC and AC aluminum and
steel cable to metal outlet boxes, electrical enclosures and other metal enclosures. MATERIAL:
Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout. SUITABLE FOR: 95403N for one or two cables
of these characteristics: AC Cable: CULUS listed for aluminum and steel AC cable .405” to .615”
diameter. This is normally 14-2, 14-3, 14-4; 12-2, 12-3, 12-4; 10-2 and some 10-3. MC Cable: ULUS
listed for aluminum and steel MC cable .405” to .615” diameter. This is normally 14-2, 14-3, 14-4;
12-2, 12-3, 12-4; 10-2, 10-3 and some 10-4. MCI-A Cable: CULUS listed for aluminum MCI-A cable
.400” to .500” diameter. This is normally 14-2, 14-3, 14-4; 12-2, 12-3,12-4; 10-2 and 10-3. For all of
the above sizes, Hospital Grade HCF (Health Care Facilities), Home Run, Super Neutral, Fire Alarm
and Isolated Ground cables are approved as well. FEATURES: Snap-In installation, no locknut,
insulating bushing included. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
B
A
A
B
25
®
NON-METALLIC
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
HIT LOCK® Non-Metallic Nylon
Cable Connectors
FITS NM CABLE: #14/2, #14/3, #12/2, #12/3, #10/2, #10/3
3/8˝(1/2 ko) 75105B 100/1000 .5/5 0.98 0.49
FITS NM CABLE: #14/3, #12/3, #10/3, #8/3, #6/3
3/4˝ 75107B 50/500 0.4/4 1.25 0.58
APPLICATION: INDOORS ONLY - In a dry location, use to connect non-metallic sheathed cable to
a steel outlet box or other metal enclosure. MATERIAL: Nylon. TYPE: Snap-In Style - No screws
or locknuts required. MISC: 3/8˝ size ts 1/2˝ knockout. FEATURES: Design allows for quick and
easy two-step installation. Push into box and insert cable. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Duplex HIT LOCK® Non-Metallic Nylon
Cable Connectors
FITS NM CABLE: 2 CABLES #14/2 OR #12/2; 1 CABLE #14/2 AND 1 CABLE #12/2;
1 CABLE #14/2 AND 1 CABLE #10/2; 1 CABLE #12/2 AND 1 CABLE #10/2
3/8˝(1/2 ko) 75803B 25/250 0.4/4 1.23 1.06 0.99
APPLICATION: INDOORS ONLY - In a dry location, use to connect two non-metallic sheathed
cables to a steel outlet box or other metal enclosure. MATERIAL: Nylon. TYPE: Snap-In Style -
No screws or locknuts required. MISC: 3/8˝ size ts 1/2˝ knockout. FEATURES: Design allows for
quick and easy two-step installation. Push into box and insert cable. CERTIFICATIONS: TO UL
AND CSA REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Plastic Non-Metallic Polypropylene
Cable Connectors
FITS 1 NM CABLE: #14/2-#10-3; 2 NM CABLES: #14/2, #14/3, #12/2
1/2˝ 75101B 50/500 1.1/11 1.34 2.42 0.84
FITS 1 NM CABLE: #6/3-#8/3; 2 NM CABLES: #12/3-#8/2
3/4˝ 75102B 25/250 0.9/9 1.52 2.60 1.05
APPLICATION: INDOORS ONLY - In a dry location, use to connect non-metallic sheathed cable to
a steel outlet box or other metal enclosure. MATERIAL: Polypropylene. CERTIFICATIONS: TO UL
AND CSA REQUIREMENTS.
DIMENSIONS
26
NON-METALLIC
NON-METALLIC SHEATHED CABLE FITTINGS
TM
UPC DIMENSIONS
TRADE HALEX PCS/ CTN/CASE CTN/CASE CODED (IN INCHES)
SIZE PART # UNIT QTY WT (LBS) SELL UNIT A B C
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
Clamp Connectors Zinc Die Cast
FITS NM CABLE: #14/2, #12/2, #12/3, AWG OR 2 #14/2 AWG
OR FLEX CORD .300 TO .560 INCHES DIA.
3/8˝(1/2 ko) 05103B 100/1000 5/50 0.18 0.64 1.18
FITS NM CABLE: 12/3-8/3 AWG OR FLEX CORD .460 TO .720 INCHES DIA.
3/4˝ 05107B 50/500 5/50 0.30 0.83 1.60
FITS NM CABLE: #14/2 TO #6/3 AWG OR 3#10/3 AWG OR FLEX CORD .450 TO
.730 INCHES DIA.
1˝ 05110B 25/250 3.8/38 0.33 1.04 1.94
FITS NM CABLE: #6/3 TO #2/3 AWG OR FLEX CORD .800 TO 1.350 INCHES DIA.
OR SE CABLE 3 CONDUCTOR OR 3#1/0 MIN; 3 CONDUCTOR OR 3#2/0 MAX.
1 1/4˝ 05112B 10/100 2.4/24 0.36 1.06 2.20
FITS NM CABLE: FLEX CORDS, MULTI FLEX CORDS; FITTING RANGE .835-1.520
INCHES DIA.SE CABLES 2 CONDUCTOR 4/0
1 1/2˝ 05115B 5/50 1.7/17 0.63 1.60 2.95
FITS NM CABLE: FLEX CORDS, MULTI FLEX CORDS; FITTING RANGE 1.085-
1.520 INCHES DIA.
2˝ 05120B 10/40 4.5/18 0.86 2.06 2.95
APPLICATION: INDOORS ONLY - In a dry location, use to connect non-metallic sheathed cable
to a steel outlet box or other metal enclosure. MATERIAL: Zinc Die Cast. TYPE: Twin Screw.
MISC: 3/8˝ size ts 1/2˝ knockout. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
Clamp Connectors Zinc Die Cast
SNAP-IN TYPE
FITS NM CABLE: #14/2, #12/2, #12/3, AWG OR 2 #14/2 AWG
OR FLEX CORD .300 TO .560 INCHES DIA.
3/8˝(1/2 ko) 05103NB 100/1000 3.7/37 0.18 0.64 1.18
FITS NM CABLE: 12/3-8/3 AWG OR FLEX CORD .460 TO .720 INCHES DIA.
3/4˝ 05107NB 50/500 5/50 0.30 0.83 1.60
APPLICATION: INDOORS ONLY - In a dry location, use to connect non-metallic sheathed cable
to a steel outlet box or other metal enclosure. MATERIAL: Zinc Die Cast. TYPE: Twin Screw.
MISC: 3/8˝ size ts 1/2˝ knockout. FEATURES: New Snap-In design allows for quick and easy
installation. No locknut required. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX) (MIN)
Clamp Connectors Zinc Die Cast
1 1/4˝ 05312B 10/100 2.4/24 1.004 0.324 2.243
1 1/2˝ 05315B 5/50 1.7/17 1.094 0.384 2.847
2˝ 05320B 10/40 4.8/19.2 1.442 0.680 3.485
APPLICATION: INDOORS ONLY. In a dry location, use to connect oval service cable to steel outlet box or
other metal enclosure. MATERIAL: Zinc Die Cast. FEATURES: Twin Screws. CERTIFICATION: TO UL
AND CSA REQUIREMENTS.
A (MIN)
A (MAX)
B
27
®
NON-METALLIC
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B C
(MIN) (MAX)
Clamp-Combination Connectors Zinc Die Cast
3/8˝(1/2 ko) 05703B 100/1000 6/60 0.18 0.64 1.18 0.34
APPLICATION: INDOORS - In a dry location, use to connect exible metallic conduit, AC, MC
or NM cable to steel outlet box or other enclosure. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size
ts 1/2˝ knockout. SUITABLE FOR: #14/2 thru 12/3 with ground NM sheathed cable, #14-2 wire
steel armored cable, 3/8˝ steel exible metal conduit, alum. cont. corrugated metal clad cable
0.365-0.519˝ dia., alum. smooth sheath metal clad cable 0.345-0.525˝ dia., alum. interlocked
metal clad cable 0.455-0.575˝ dia., rect. alum. cont. corrugated metal clad cable 0.277˝ x 0.375˝,
steel interlocked metal clad cable 0.435-0.547˝ dia. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B C
(MIN) (MAX)
Clamp-Combination Connectors Zinc Die Cast
SNAP-IN TYPE
3/8˝(1/2 ko) 05703NB 100/1000 4.2/42 0.18 0.64 1.18 0.34
APPLICATION: INDOORS - In a dry location, use to connect exible metallic conduit, AC, MC
and NM cable to steel outlet box or other enclosure. MATERIAL: Zinc Die Cast Misc: 3/8˝ size
ts 1/2˝ knockout. SUITABLE FOR: #14/2 thru 12/3 with ground NM sheathed cable, #14-2 wire
steel armored cable, 3/8˝ steel exible metal conduit, alum. cont. corrugated metal clad cable
0.365-0.519˝ dia., alum. smooth sheath metal clad cable 0.345-0.525˝ dia., alum. interlocked metal
clad cable 0.455-0.575˝ dia., rect. alum. cont. corrugated metal clad cable 0.277˝ x 0.375˝, steel
interlocked metal clad cable 0.435-0.547˝ dia. FEATURES: New Snap-In design allows for quick
and easy installation. Meets UL ground fault requirements. No locknut required. CERTIFICATIONS:
TO UL AND CSA REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS) A A B C D
(MIN) (MAX)
Duplex Connectors Zinc Die Cast
3/8˝(1/2 ko) 15803B 25/250 3.3/32.5 0.13 0.65 1.496 0.42 1.50
APPLICATION: INDOORS ONLY - In a dry location, use to connect two pieces of exible metallic
conduit, AC, MC or NM sheathed cable, to a steel outlet box or other metal enclosure when
using only one knockout opening. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout.
SUITABLE FOR: #14-2 thru #12-3 wire with ground NM sheathed cable, #14-2 wire steel armored
cable, #14-2 wire with ground thru #10-4 with ground alum. armored cable, 3/8˝ FMC, alum.
smooth sheath metal clad cable 0.410-0.500˝ dia., alum. interlocked metal clad cable 0.460-0.538˝
dia., steel interlocked metal clad cable 0.438-0.560˝ dia. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B C
(MIN) (MAX)
Duplex Connectors Zinc Die Cast
SNAP-IN TYPE
3/8˝(1/2 ko) 15803NB 25/250 2.5/25 0.13 0.65 1.496 1.52
APPLICATION: INDOORS ONLY - In a dry location, use to connect two pieces of exible metallic
conduit, AC, MC or NM sheathed cable, to a steel outlet box or other metal enclosure when
using only one knockout opening. MATERIAL: Zinc Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout.
SUITABLE FOR: #14-2 thru #12-3 wire with ground NM sheathed cable, #14-2 wire steel armored
cable, #14-2 wire with ground thru #10-4 with ground alum. armored cable, 3/8˝ FMC, alum.
smooth sheath metal clad cable 0.410-0.500˝ dia., alum. interlocked metal clad cable 0.460-
0.538˝ dia., steel interlocked metal clad cable 0.438-0.560˝ dia. FEATURES: New Snap-In design
C
D
C
DIMENSIONS
DIMENSIONS
(IN INCHES)
28
NON-METALLIC
NON-METALLIC SHEATHED CABLE FITTINGS
TM
allows for quick and easy installation. No locknut required. Meets UL ground fault requirements.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
NM CABLE DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE WIRE (IN INCHES)
SIZE PART # QTY WT (LBS) RANGE A B
Two-Piece Clamp Connectors Steel
3/8˝(1/2 ko) 65103B 100/1000 5/50 0.160-0.560 0.95 1.31
3/4˝ - 1˝ 65110B 50/500 3.5/35 0.200-.0850 1.25 1.75
1 1/4˝ 65112B 25/250 3.3/33.9 0.250-1.000 1.62 2.13
1 1/2˝ 65115B 25/250 4/40.4 0.312-1.200 1.97 2.50
APPLICATION: INDOORS ONLY - In a dry location, use to secure #14 - #10 non-metallic sheathed
cable to a steel outlet box or other metal enclosure. No locknut is required. MATERIAL: Steel Zinc-
Plate. MISC: 3/8˝ size ts 1/2˝ knockout. TYPE: Buttery Style - does not require a locknut.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE ( IN INCHES)
SIZE PART # QTY WT (LBS) A A B B C
(MIN) (MAX) (MIN) (MAX)
Water-Tight UF Connectors Zinc Die Cast
FITS UF CABLE ONLY: #14/2, #12/2
1/2˝ 06605B 25/250 4.3/42.5 0.10 0.22 0.48 0.44 1.20
FITS UF CABLE ONLY: #14/3-#12/3
3/4˝ 06607B 25/250 6.5/65 0.18 0.22 0.80 0.66 1.27
APPLICATION: INDOORS OR OUTDOORS. Use to secure #14 - #12 UF cable to a waterproof
box with threaded hub. MATERIAL: Zinc Die Cast. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B C
(MIN) (MAX)
Saddle Connectors Zinc Die Cast
3/8˝(1/2 ko) 06703B 50/500 3/30 UPC ON CARTON 0.13 0.67 0.94 0.42
INSULATED THROAT
3/8˝(1/2 ko) 86703B 50/500 4/40 0.13 0.67 1.00 0.42
APPLICATION: INDOORS ONLY - In a dry location, use to connect exible metallic conduit,
AC, MC and NM sheathed cable to a steel outlet box or other metal enclosure. MATERIAL: Zinc
Die Cast. MISC: 3/8˝ size ts 1/2˝ knockout. SUITABLE FOR: #14-2 to the largest size ttable
NM sheathed cable, #14-2 with ground steel and aluminum armored cable - .470˝ dia., 3/8˝ steel
exible metal conduit, alum. cont. corrugated metal clad cable 0.510-0.620˝ dia., alum. smooth
sheath metal clad cable 0.410-0.500˝ dia., alum. interlocked metal clad cable 0.462-0.548˝
dia., steel interlocked metal clad cable 0.442-0.552˝ dia. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
Saddle Connectors Zinc Die Cast
SNAP-IN TYPE
3/8˝(1/2 ko) 06703NB 50/500 3/30 0.13 0.67 0.91
APPLICATION: INDOORS ONLY - In a dry location, use to connect exible metallic conduit, AC,
MC and NM sheathed cable to a steel outlet box or other metal enclosure. MATERIAL: Zinc Die
Cast. MISC: 3/8˝ size ts 1/2˝ knockout. SUITABLE FOR: #14-2 to the largest size ttable NM
sheathed cable, #14-2 with ground steel and aluminum armored cable -.470˝ dia., 3/8˝ steel exible
metal conduit, alum. cont. corrugated metal clad cable 0.510-0.620˝ dia., alum. smooth sheath
metal clad cable 0.410-0.500˝ dia. alum. interlocked metal clad cable 0.462-0.548˝ dia., steel
B
A
C
29
®
NON-METALLIC
interlocked metal clad cable 0.442-0.552˝ dia. FEATURES: New Snap-In design allows for quick
and easy installation. No locknut required. Meets UL ground fault requirements. CERTIFICATIONS:
TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
EMT-To-Non-Metallic Zinc Die Cast
Combination Couplings
1/2˝-NM 15303B 50/500 4/40 0.17 0.63 1.35
APPLICATION: INDOORS ONLY - Use to join EMT conduit to non-metallic sheathed cable. #14/2,
#12/3, or 2 #14/2. MATERIAL: Zinc Die Cast. TYPE: Set-Screw Type. CERTIFICATIONS: TO UL
AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
One-Hole Straps Steel
#12/2-#14/2 62171B 100/1000 1/10 0.585 0.300 1.322 0.500
APPLICATION: INDOORS ONLY - Use to secure non-metallic sheathed #12/2-#14/2 cable to a
wood, masonry or similar surface.
C
A
D
B
30
LIQUID-TIGHT CONDUIT FITTINGS
TM
LIQUID
UPC DIMENSIONS
TRADE HALEX PCS/ CTN/CASE CTN/CASE CODED (IN INCHES)
SIZE PART # UNIT QTY WT (LBS) SELL UNIT A B C
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Liquid-Tight Connectors Zinc Die Cast
ONE-PIECE
1/2˝ 06305B 25/100 3.5/14 1.661 0.521 1.543
3/4˝ 06307B 10/100 2.1/21 1.721 0.521 1.790
WITH INSULATED THROAT
1/2˝ 86305B 25/100 3.5/14 1.741 0.591 1.543
3/4˝ 86307B 10/100 2.1/21 1.801 0.600 1.790
APPLICATION: INDOORSOROUTDOORS.UsetoconnectexiblemetallicortypeBnon-metallic
liquid-tightconduittoasteeloutletboxorothermetalenclosureorhub.MATERIAL:ZincDieCast.
FEATURES: Newone-piecedesignallowsforquickandeasyinstallation.Pushinandtwistconduit
counter-clockwiseuntilseated.Tightenscrewto35in-lbs.andinstallintoenclosure.It’sthateasy!
CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Liquid-Tight Connectors Zinc Die Cast
MULTI-PIECE
3/8˝(1/2ko) 16203B 25/100 5/20 1.32 0.50 1.18
1/2˝ 16205B 25/100 4.3/17 1.40 0.50 1.29
3/4˝ 16207B 10/100 2.5/25 1.45 0.50 1.57
1˝ 16210B 10/100 4.4/44 2.06 0.58 1.81
11/4˝ 16212B 4/40 2.7/26.8 2.06 0.61 2.18
11/2˝ 16215B 2/20 1.8/18.4 2.09 0.63 2.51
2˝ 16220B 2/20 2.8/28 2.15 0.63 3.03
WITH INSULATED THROAT
3/8˝(1/2ko) 96203B 25/100 5/20 1.37 0.50 1.18
1/2˝ 96205B 25/100 4.3/17 1.45 0.50 1.29
3/4˝ 96207B 10/100 2.5/25 1.50 0.50 1.57
1˝ 96210B 10/100 4.4/44 2.11 0.63 1.81
11/4˝ 96212B 4/40 2.7/26.8 2.11 0.66 1.81
11/2˝ 96215B 2/20 1.8/18.4 2.11 0.68 2.18
2˝ 96220B 2/20 2.8/28 2.14 0.68 2.51
21/2˝ 96225B 1 2.7 2.20 0.68 3.03
3˝ 96230B 1 3.06 4.05 1.01 4.34
31/2˝ 96235B 1 3.80 4.30 1.05 4.78
4˝ 96240B 1 4.31 4.75 1.05 5.19
APPLICATION:INDOORSOROUTDOORS.UsetoconnectexiblemetallicortypeBnon-metallic
liquid-tightconduittoasteeloutletboxorothermetalenclosureorhub.MATERIAL:ZincDieCast.
MISC: 3/8˝sizets1/2˝knockout.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
90° Liquid-Tight Connectors Zinc Die Cast
ONE-PIECE
1/2˝ 06805B 25/100 4.6/18.4 2.47 1.520 0.521
3/4˝ 06807B 10/100 2.8/28 2.761 1.695 0.521
APPLICATION:INDOORSOROUTDOORS.UsetoconnectexiblemetallicortypeBnon-metallic
liquid-tightconduittoasteeloutletboxorothermetalenclosureorhub.MATERIAL:ZincDieCast.
FEATURES:Newone-piecedesignallowsforquickandeasyinstallation.Pushinandtwistconduit
counter-clockwiseuntilseated.Tightenscrewto35in-lbs.andinstallintoenclosure.It’sthateasy!
CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
DIMENSIONS
31
®
LIQUID
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
90° Liquid-Tight Connectors Zinc Die Cast
MULTI-PIECE
3/8˝(1/2˝ko) 16903B 25/100 7.5/30 1.45 0.50 1.66
1/2˝ 16905B 25/100 6.8/27 1.45 0.50 1.77
3/4˝ 16907B 10/100 3.9/39 1.60 0.50 1.95
1˝ 16910B 5/50 3.3/33 3.46 0.58 3.86
11/4˝ 16914B 4/40 4.2/42 3.37 0.67 3.99
11/2˝ 16915B 2/20 2.6/25.8 4.28 0.61 5.04
2˝ 16920B 2/20 3.9/39.2 4.21 0.71 5.06
WITH INSULATED THROAT
3/8˝(1/2˝ko) 96903B 25/100 7.5/30 1.50 0.55 1.66
1/2˝ 96905B 25/100 6.8/27 1.50 0.55 1.77
3/4˝ 96907B 10/100 3.9/39 1.65 0.55 1.95
1˝ 96910B 5/50 3.3/33 3.51 0.63 3.86
11/4˝ 96912B 4/40 4.2/42 3.47 0.72 3.99
11/2˝ 96915B 2/20 2.6/25.8 4.33 0.66 5.04
2˝ 96920B 2/20 3.9/39.2 4.26 0.76 5.06
21/2˝ 96925B 1 3.48 4.26 0.76 5.06
3˝ 96930B 1 5.25 4.05 1.00 3.86
31/2˝ 96935B 1 6.25 4.30 1.03 4.13
4˝ 96940B 1 8.08 4.75 1.05 4.52
APPLICATION:INDOORSOROUTDOORS.UsetoconnectexiblemetallicortypeBnon-metallic
liquid-tightconduittoasteeloutletboxorothermetalenclosureorhub.MATERIAL:ZincDieCast.
MISC: 3/8˝sizets1/2˝knockout.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Liquid-Tight Connectors Malleable Iron
STRAIGHT
3/8˝(1/2ko) 66203B 25/100 3.85/15.5 1.125 0.500 1.125
1/2˝ 66205B 25/100 4.4/17.7 1.250 0.500 1.250
3/4˝ 66206B 10/100 2.9/28.8 1.250 0.500 1.5625
1˝ 66210B 5/20 2.0/8.0 1.4375 0.625 1.822
11/4˝ 66212B 5/20 2.8/11.0 1.500 0.6875 2.250
11/2˝ 66215B 2/20 1.45/14.5 1.625 0.750 2.4375
2˝ 66220B 2/20 2.0/2.0 1.750 0.750 3.000
INSULATED THROAT
3/8˝(1/2ko) 86203B 25/100 3.9/15.7 1.125 0.56251.125
1/2˝ 86205B 25/100 4.5/18.0 1.250 0.5625 1.250
3/4˝ 86207B 10/100 2.9/29 1.250 0.56251.5625
1˝ 86210B 5/20 2.0/8.0 1.4375 0.6875 1.8215
11/4˝ 86212B 5/20 2.8/11.2 1.500 0.750 2.250
11/2˝ 86215B 2/20 1.45/14.5 1.625 0.8215 2.4375
2˝ 86220B 2/20 2.0/2.0 1.750 0.8215 3.000
21/2˝ 86225B 1 2.488
3˝ 86230B 1 3.780
31/2˝ 86235B 1 5.072
4˝ 86240B 1 6.364
APPLICATION:INDOORSOROUTDOORS.Usetoconnectexiblemetallicliquid-tightconduitto
asteeloutletboxorothermetalenclosureorhub.MATERIAL:MalleableIron.MISC:3/8˝sizets
1/2˝knockout.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
C
A
B
32
LIQUID-TIGHT CONDUIT FITTINGS
TM
LIQUID
B
C
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) B C
90° Liquid-Tight Connectors Malleable Iron
3/8˝(1/2ko) 66903B 10/100 2.6/26.0 0.500 1.125
1/2˝ 66905B 10/100 2.9/29.0 0.500 1.250
3/4˝ 66907B 10/40 4.5/18.0 0.500 1.5625
1˝ 66910B 5/20 3.8/15.2 0.625 1.8125
11/4˝ 66912B 5/20 4.8/19.2 0.6875 2.250
11/2˝ 66915B 2/20 2.5/25.0 0.750 2.4375
2˝ 66920B 2/20 3.6/36.0 0.750 2.4375
INSULATED THROAT
3/8˝(1/2ko) 86903B 10/100 2.6/26.0 0.56251.125
1/2˝ 86905B 10/100 2.9/29.0 0.5625 1.250
3/4˝ 86907B 10/40 4.5/18.0 0.56251.5625
1˝ 86910B 5/20 3.8/15.2 0.6875 1.8125
11/4˝ 86912B 5/20 4.9/19.4 0.750 2.250
11/2˝ 86915B 2/20 2.5/25.0 0.8215 2.4375
2˝ 86920B 2/20 3.6/36.0 0.8215 3.000
21/2˝ 86925B 1 5.848
3˝ 86930B 1 8.384
31/2˝ 86935B 1 9.824
4˝ 86940B 1 12.036
APPLICATION:INDOORSOROUTDOORS.Usetoconnectexiblemetallicliquid-tightconduitto
asteeloutletboxorothermetalenclosureorhub.MATERIAL:MalleableIron.MISC:3/8˝sizets
1/2˝knockout.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) B C
45° Liquid-Tight Connectors Malleable Iron
3/8˝(1/2”ko)66503B 10/100 2.7/27.0 0.500 1.125
1/2˝ 66505B 10/100 2.7/27.0 0.500 1.250
3/4˝ 66507B 10/40 4.0/16.0 0.500 1.5625
1˝ 66510B 5/20 3.2/12.8 0.625 1.8125
11/4˝ 66512B 5/20 4.4/17.6 0.6875 2.250
11/2˝ 66515B 2/20 2.2/22.0 0.750 2.4375
2˝ 66520B 2/20 3.6/36.0 0.750 3.000
INSULATED THROAT
3/8˝(1/2”ko)86503B 10/100 2.7/27.0 0.56251.125
1/2˝ 86505B 10/100 2.7/27.0 0.5625 1.250
3/4˝ 86507B 10/40 4.0/16.0 0.56251.5625
1˝ 86510B 5/20 3.2/12.8 0.6875 1.8125
11/4˝ 86512B 5/20 4.4/17.6 0.750 2.250
11/2˝ 86515B 2/20 2.2/22.0 0.8215 2.4375
2˝ 86520B 2/20 3.6/36.0 0.8215 3.000
21/2˝ 86525B 1 4.684
3˝ 86530B 1 6.988
31/2˝ 86535B 1 8.148
4˝ 86540B 1 9.962
APPLICATION:INDOORSOROUTDOORS.Usetoconnectexiblemetallicliquid-tightconduitto
asteeloutletboxorothermetalenclosureorhub.MATERIAL:MalleableIron.MISC:3/8˝sizets
1/2˝knockout.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
C
B
33
®
LIQUID
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
QUICK-SET® Liquid-Tight Connectors Nylon
3/8˝(1/2˝ko)76203B 25 1.5 1.18 0.55 1.42
1/2˝ 76205B 25/100 1.5/15 1.18 0.55 1.42
3/4˝ 76207B 10/100 0.7/7 1.20 0.64 1.69
1˝ 76210B 5/50 0.6/6 1.23 0.72 2.02
11/4˝ 76212B 5/25 1.082/5.41 2.44 0.76 2.40
11/2˝ 76215B 2/10 0.50/2.50 2.70 0.80 2.67
2˝ 76220B 2/10 0.86/4.33 2.99 0.85 3.28
APPLICATION:INDOORSOROUTDOORS.UsetoconnecttypeBnon-metallicliquid-tightconduit
toaweatherproofoutletbox,pool/spaequipmentmotor,centralairconditioningunitorvariousother
electricalenclosuresorhubs.MATERIAL:Nylon. FEATURES: Fittingwillnotrustorcorrode.No
disassembly required, just insert conduit, then hand-tighten nut. Reusable. MISC:3/8˝sizets
1/2˝knockout.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
QUICK-SET® 90° Liquid-Tight Connectors Nylon
3/8˝(1/2˝ko)76903B 10/100 0.8/7.2 2.84 0.50 2.03
1/2˝ 76905B 10/100 0.8/7.2 2.84 0.50 2.03
3/4˝ 76907B 10/100 1/10 3.25 0.50 2.33
1˝ 76910B 5/50 0.9/9 3.54 0.60 2.95
11/4˝ 76912B 5/25 0.9/9 4.75 0.76 5.20
11/2˝ 76915B 2/10 0.9/9 4.75 0.80 5.20
2˝ 76920B 2/10 0.9/9 5.42 0.86 5.80
APPLICATION:INDOORSOROUTDOORS.UsetoconnecttypeBnon-metallicliquid-tightconduit
toaweatherproofoutletbox,pool/spaequipmentmotor,centralairconditioningunitorvariousother
electricalenclosuresorhubs.MATERIAL:Nylon.FEATURES:Fittingwillnotrustorcorrode.No
disassembly required, just insert conduit, then hand-tighten nut.Reusable.MISC:3/8˝sizets
1/2˝knockout.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Screw-In Couplings PVC
1/2˝ 74505B 30 0.3
3/4˝ 74507B 25 0.4
APPLICATION:INDOORSOROUTDOORS.UsetoconnecttwolengthsoftypeBnon-metallic
liquid-tightconduit.MATERIAL:PVC.FEATURES:Screw-intype.CERTIFICATIONS:TOULAND
CSAREQUIREMENTS.
NEW
34
RIGID
RIGID & INTERMEDIATE METALLIC CONDUIT FITTINGS
TM
B
A
A
B
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Compression Connectors Steel
1/2˝ 63505B 25/100 3.2/13 1.43 1.17
3/4˝ 63507B 25/100 5/20 1.48 1.43
1˝63510B 5 1.4905 1.48 1.43
11/4˝63512B 5 2.338 1.96 2.16
11/2˝63515B 2 1.4 2.15 2.38
2˝63520B 2 2 2.24 2.88
21/2˝ 62325B 12 21.4
3˝ 62330B 12 26.4
31/2˝ 62335B 6 15.4
4˝ 62340B 6 17.9
INSULATED THROAT
21/2˝ 82325B 12 21.4
3˝ 82330B 12 26.4
31/2˝ 82335B 6 15.4
4˝ 82340B 6 17.9
APPLICATION: INDOORS.UsetojointhreadlessRigidorIMCconduittoasteeloutletboxor
othermetalenclosure.MATERIAL:MachinedSteel,Zincelectro-plate.FEATURES: Concrete-
Tight.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Compression Connectors Zinc Die Cast
21/2˝ 02125B 12 12.5 2.62 1.00
3˝ 02130B 12 16.4 2.75 1.06
31/2˝ 02135B 10 17 2.83 1.14
4˝ 02140B 6 12 2.84 1.14
WITH INSULATED THROAT
21/2˝ 82125B 12 12.5 2.67 1.00
3˝ 82130B 12 16.4 2.80 1.06
31/2˝ 82135B 10 17 2.88 1.14
4˝ 82140B 6 12 2.89 1.14
APPLICATION: INDOORS.UsetoconnectEMT,threadlessRigidorIMCconduittoasteel
outletboxorothermaterialenclosure. MATERIAL:ZincDieCast. FEATURES:Concrete-Tight.
CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
35
®
RIGID
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
.
A
B
A
B
Compression Couplings Steel
1/2˝63605B 10 1.3 1.76 1.17
3/4˝63607B 10 2.0 1.93 1.43
1˝63610B 5 1.8 2.19 1.77
11/4˝63612B 5 3.0 2.51 2.16
11/2˝63615B 2 2.0 2.77 2.38
2˝63620B 2 2.8 2.78 2.88
21/2˝ 62425B 12 26
3˝ 62430B 6 16.5
31/2˝ 62435B 6 19.2
4˝ 62440B 6 22.7
APPLICATION:INDOORS.UsetojointwolengthsofthreadlessRigidorIMCconduit.
MATERIAL:MachinedSteel,Zincelectro-plate.FEATURES: Concrete-Tight.CERTIFICATIONS:
TOULANDCSAREQUIREMENTS
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Compression Couplings Zinc Die Cast
21/2˝ 02225B 12 15.5 3.29 3.24
3˝ 02230B 12 20.6 3.42 3.87
31/2˝ 02235B 10 20.5 3.51 4.39
4˝ 02240B 6 15 3.54 4.88
APPLICATION:INDOORS.UsetojointwolengthsofEMT,threadlessRigidorIMCconduit
together.MATERIAL:ZincDieCast.FEATURES: Concrete-Tight.CERTIFICATIONS: TOUL
ANDCSAREQUIREMENTS.
36
RIGID
RIGID & INTERMEDIATE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Set-Screw Connectors Steel
21/2˝ 62725B 12 15 3.24
3˝ 62730B 12 21 3.74
31/2˝ 62735B 6 13 3.99
4˝ 62740B 6 15 4.24
WITH INSULATED THROAT
21/2˝ 82725B 12 15
3˝ 82730B 12 21
31/2˝ 82735B 6 13
4˝ 82740B 6 15
APPLICATION:INDOORS.UsetoconnectthreadlessRigidorIMCconduittoasteeloutletboxor
othermetalenclosure.MATERIAL:Steel-ZincElectro-Plate.MISC: 21/2˝-4˝canbeusedforEMT
conduitalso.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Set-Screw Connectors Zinc Die Cast
21/2˝ 12125B 12 9.96 3.03 1.00
3˝ 12130B 12 12 3.37 1.06
31/2˝ 12135B 10 12.8 3.58 1.09
4˝ 12140B 6 9.36 3.75 1.09
WITH INSULATED THROAT
21/2˝ 92125B 12 9.96 3.08 1.05
3˝ 92130B 12 12 3.42 1.11
31/2˝ 92135B 10 12.8 3.63 1.14
4˝ 92140B 6 9.36 3.80 1.14
APPLICATION:INDOORS.UsetoconnectthreadlessRigidorIMCconduittoasteeloutletbox
orothermetalenclosure.MATERIAL:ZincDieCast. MISC:21/2˝-4˝canbeusedforEMTconduit
also.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Set-Screw Couplings Zinc Die Cast
21/2˝ 12225B 12 9.12 3.99 3.30
3˝ 12230B 12 12.36 4.55 3.94
31/2˝ 12235B 10 14.76 4.92 4.45
4˝ 12240B 6 9.66 5.24 4.97
APPLICATION:INDOORS.UsetojointwolengthsofthreadlessRigidorIMCconduittogether.
MATERIAL:ZincDieCast.MISC:21/2˝-4˝canbeusedforEMTconduitalso.CERTIFICATIONS:
TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Set-Screw Couplings Steel
21/2˝ 62825B 12 17.5
3˝ 62830B 12 25
31/2˝ 62835B 6 14
4˝ 62840B 6 17
APPLICATION:INDOORS.UsetojointwolengthsofthreadlessRigidorIMCconduittogether.
MATERIAL:Steel-ZincElectro-Plate.MISC:21/2˝-4˝canbeusedforEMTconduitalso.
CERTIFICATIONS: TOULANDCSAREQUIREMENTS.
•Imageshownisfor
1/2"-2".21/2"-4"
hasfourscrews.
•Imageshownisfor
1/2"-2".21/2"-4"
hasfourscrews.
•Imageshownisfor
1/2"-2".21/2"-4"
hasfourscrews.
•Imageshownisfor
1/2"-2".21/2"-4"
hasfourscrews.
•Imageshownisfor
1/2"-2".21/2"-4"
hastwoscrews.
•Imageshownisfor
1/2"-2".21/2"-4"
hastwoscrews.
•Imageshownisfor
1/2"-2".21/2"-4"
hasfourscrews.
37
®
RIGID
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Rigid-To-EMT Couplings Steel
SET-SCREW TYPE
1/2˝ 15304B 25 3.5
3/4˝ 15306B 25 6.1
APPLICATION: INDOORSONLY.UsetojoinEMTconduittoRigidmetalconduit.MATERIAL:
Steel,ZincElectro-Plate.TYPE:Set-screw.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Rigid Three-Piece Couplings Malleable Iron
1/2˝ 65505B 25 6.9 1.188 0.984 1.406
3/4˝ 65507B 25 8.1 1.375 1.125 1.641
1˝ 65510B 10 6.3 1.688 0.750 2.016
11/4˝ 65512B 10 9.8 2.063 1.500 2.516
11/2˝ 65515B 10 13.5 2.344 1.672 2.828
2˝ 65520B 10 18.7 3.000 1.781 3.359
21/2˝ 65525B 10 33.5 3.500 1.938 4.031
3˝ 65530B 1 4 4.125 2.250 4.531
31/2˝ 65535B 1 5.8 4.688 2.594 5.297
4˝ 65540B 1 7.6 5.406 3.078 5.719
APPLICATION:INDOORSOROUTDOORS.Useasathreadedcouplingbetweenlengths
ofthreadedRigidorIMCconduit,whenneithercanberotated.MATERIAL:MalleableIron.
CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Rigid-To-Rigid Pull Elbows Zinc Die Cast
WITH NEOPRENE GASKET
1/2˝ 94105B 10/100 2.8/28 1.31 1.02
3/4˝ 94107B 5/50 1.7/17 1.50 1.27
1˝94110 5 3.1 1.85 1.54
APPLICATION: INDOORSOROUTDOORS.Useasawirepullingelbowtofacilitatewirepulling
throughasharpbendinarunofthreadedRigidorIMCconduit.Removablecoverprovides
easyaccesstofacilitatewirepulling.Not listed for wet locations.MATERIAL: ZincDieCast.
CERTIFICATIONS: TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
EMT/Rigid-To-EMT/ Zinc Die Cast
Rigid Combo Elbows
WITH GASKET
1˝ 94510 5 0.5692 1.85 1.52
1/2˝ 94505 10 0.1988 1.31 0.97
3/4˝ 94507 10 0.289 1.50 1.20
APPLICATION:INDOORSOROUTDOORS.Useasawirepullingelbowtofacilitatewirepulling
throughasharpbendinarunofthreadedRigidorIMCconduit.Removablecoverprovides
easyaccesstofacilitatewirepulling.Not listed for wet locations.MATERIAL: ZincDieCast.
CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
A
B
C
B
A
NEW
38
RIGID
RIGID & INTERMEDIATE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Rigid-To-Box Pull Elbows Zinc Die Cast
WITH GASKET
1/2˝ 94205B 10/100 3.1/31 1.31 1.02
3/4˝ 94207B 5/50 1.85/18.5 1.50 1.27
WITHOUT GASKET
1/2˝ 14205 10 3.1 1.31 1.02
3/4˝ 14207 5 1.85 1.50 1.27
APPLICATION: INDOORSOROUTDOORS.UsetoconnectarunofthreadedRigidorIMC
conduittoanoutletboxorothermetalenclosure.Removablecoverprovideseasyaccessto
facilitatewirepulling.Not listed for wet locations. MATERIAL:ZincDieCast.CERTIFICATIONS:
TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
EMT/Rigid-To-Box Combo Elbows Zinc Die Cast
WITH GASKET
1/2˝ 94705 10 0.1844 1.310 1.020
3/4˝ 94707 5 0.296 1.500 1.270
APPLICATION:INDOORSOROUTDOORS.UsetoconnectarunofthreadedRigidorIMC
conduittoanoutletboxorothermetalenclosure.Removablecoverprovideseasyaccessto
facilitatewirepulling.Not listed for wet locations. MATERIAL: ZincDieCast.CERTIFICATIONS:
TOULANDCSAREQUIREMENTS.
B
A
39
®
RIGID
A
B
C
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
One-Hole Straps Steel
1/2˝ 61105B 100/1000 3/30 1.375 0.625
3/4˝ 61107B 100/1000 5/50 1.562 0.750
1˝ 61110B 50/500 3.5/35 1.812 0.875
11/4˝ 61112B 50/500 5/50 2.000 0.875
11/2˝ 61115B 25/250 4.25/42.5 2.500 1.000
2˝61120 10 2.5 2.750 1.125
21/2˝61125 10 4.3 3.312 1.250
3˝61130 10 5 3.625 1.250
31/2˝ 61135B 25 17.8 4.000 1.250
4˝ 61140B 20 15.6 4.250 1.250
APPLICATION:INDOORSOROUTDOORS.UsetosecureRigidorIMCconduittowood,masonry
orsimilarsurfaceswheregreaterloadbearingisrequired.MATERIAL:Steel,ZincElectro-plate.
CERTIFICATIONS: TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
One-Hole Straps Malleable Iron
1/2˝ 31205B 50/500 2.5/25 2.016 0.625 0.969
3/4˝ 31207B 50/500 3/30 2.219 0.750 1.031
APPLICATION:INDOORSOROUTDOORS.UsetosecureRigidorIMCconduittowood,
masonryorsimilarsurfaceswheregreaterloadbearingisrequired.MATERIAL:MalleableIron.
CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Two-Hole Straps Steel
1/2˝ 61205B 100/1000 2/20 2.250 1.6250.562
3/4˝ 61207B 100/1000 3/30 2.875 2.2500.638
1˝ 61210B 50/500 2.5/25 3.375 2.6250.750
11/4˝ 61212B 25/250 1.75/17.5 4.188 3.4370.875
11/2˝ 61215B 25/250 3/30 4.625 3.8120.875
2˝ 61220B 50/200 7.5/30 5.125 4.2501.000
21/2˝ 61225B 25 4.3 5.875 4.8751.000
3˝ 61230 10 2.5 6.500 5.5001.000
31/2˝ 61235B 25 6.5 7.375 6.3751.000
4˝ 61240B 20 6.6 8.000 7.0001.000
APPLICATION:INDOORSOROUTDOORS.UsetosecureRigidorIMCconduittowood,masonry
orsimilarsurfaceswheregreaterloadbearingisrequired. MATERIAL: Steel,ZincElectro-plate.
CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE ( IN INCHES)
SIZE PART # QTY WT (LBS) A B
Conduit Locknuts Steel
1/2˝ 61905B 200/2000 2/20 1.125 0.09
3/4˝ 61907B 100/1000 1/10 1.380 0.10
1˝ 61910B 100/1000 4/40 1.697 0.13
11/4˝ 61912B 50/500 2.5/25 2.070 0.13
11/2˝ 61915B 50/500 3/30 2.385 0.13
2˝ 61920B 50/200 3.5/14 2.870 0.18
21/2˝ 61925B 25 3.25 3.455 0.18
3˝ 61930B 25 4.75 4.150 0.18
31/2˝ 61935B 10/40 2.3/9.2 4.703 0.18
4˝ 61940B 10/40 2.7/10.8 5.288 0.185
APPLICATION:INDOORSOROUTDOORS.UsetosecureRigid,IMCconduitorvariousthreaded
ttingstoasteeloutletboxorothermetalenclosure.MATERIAL:SteelwithZincplating.
40
RIGID
RIGID & INTERMEDIATE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B C D
(MIN) (MAX)
Sealer Locknuts Steel
1/2˝ 61805B 50/500 1/10 1.125 1.1350.09 0.97 0.78
3/4˝ 61807B 25/250 0.75/7.5 1.375 1.3850.101.21 1.10
1˝ 61810B 25/250 1/10 1.715 1.725 0.13 1.52 1.27
11/4˝ 61812B 10/100 0.8/8 2.060 2.0700.13 1.86 1.55
11/2˝ 61815B 10/100 0.8/8 2.375 2.3850.13 2.10 1.82
2˝ 61820B 10/100 1.2/12 2.885 2.8950.13 2.61 2.30
APPLICATION:INDOORSOROUTDOORS.UsetosecureRigid,IMCconduitorvariousthreaded
ttingstoasteeloutletboxorothermetalenclosures,whenmoistureproofprotectionisdesired.
MATERIAL:SteelwithZincplatingandmolded,integralPVCgasket. CERTIFICATIONS:TOUL
ANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Conduit Locknuts Zinc Die Cast
1/2˝01905B 200/2000 2/20 1.12 0.15
3/4˝01907B 100/1000 1/10 1.33 0.15
1˝01910B 100/1000 2.5/25 1.68 0.19
11/4˝01912B 50/500 2.5/25 2.15 0.19
11/2˝01915B 50/500 3/30 2.35 0.19
2˝01920B 50/200 3.5/14 2.89 0.19
21/2˝01925B 25 3.25 3.43 0.25
3˝01930B 25 4.75 4.12 0.25
31/2˝01935B 10/40 2.3/9.2 4.68 0.27
4˝01940B 10/40 2.7/10.8 5.25 0.27
APPLICATION: INDOORSOROUTDOORS.UsetosecureRigid,IMCconduitorvariousthreaded
ttingstoasteeloutletboxorothermetalenclosures.MATERIAL:ZincDieCast.FEATURES:
Reversible.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Grounding Locknuts Zinc Die Cast
2˝01820 25 3 2.940 0.255 2.280
APPLICATION: INDOORSOROUTDOORS.UsetosecureRigidorIMCthreadedconduittoan
unthreadedopeninginasteeloutletboxorothermetalenclosure.MATERIAL:ZincDieCast.
CERTIFICATIONS: TOULANDCSAREQUIREMENTS.
B
C
d
A
41
®
RIGID
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Reducing Washers Steel
3/4˝X1/2˝ 68205B 250/2500 3.75/37 1.43 1.00 0.87
1˝X1/2˝ 68305B 250/2500 5/50 1.75 1.34 0.87
1˝X3/4˝ 68307B 250/2500 50 1.75 1.34 1.11
11/4˝X1/2˝ 68405B 100 3 2.18 1.70 0.87
11/4˝X3/4˝ 68407B 100 3 2.18 1.70 1.11
11/4˝X1˝ 68410B 100 2 2.18 1.70 1.37
11/2˝X1/2˝ 68505B 100 4 2.44 1.94 0.87
11/2˝X3/4˝ 68507B 100 4 2.44 1.94 1.11
11/2˝X1˝68510 100 3.6 2.44 1.94 1.37
11/2˝X11/4˝68512B 100 3 2.44 1.94 1.73
2˝X1/2˝ 68605B 50 4 3.00 2.42 0.87
2˝X3/4˝ 68607B 50 4 3.00 2.42 1.11
2˝X1˝ 68610B 50 3.5 3.00 2.42 1.37
2˝X11/4˝ 68612B 50 3 3.00 2.42 1.73
2˝X11/2˝68615 50 3 3.00 2.42 1.98
21/2˝X2˝68720 50 3 3.50 2.90 2.46
APPLICATION:INDOORSOROUTDOORS.Usetoreducethesizeoftheknockoutinasteel
outletboxorothermetalenclosure.Mustuseoneinsidetheenclosureopeningandoneonthe
outside.MATERIAL:GalvanizedSteel. MISC:Consultfactoryforavailabilityoflargersizes.
CERTIFICATIONS: TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Reducing Bushings Steel
3/4˝X1/2˝ 13205B 50/500 1.9/19 0.810 0.760
1˝X1/2˝13305B 50/200 5/20 1.010 0.760
1˝X3/4˝13307B 50/200 3/12 1.010 0.760
11/4˝X1/2˝13405B 25/100 6.3/25 1.470 0.820
11/4˝X3/4˝13407B 25/100 5/20 1.470 0.820
11/4˝X1˝13410B 25/100 3.25/13 1.470 0.820
11/2˝X1/2˝13505B 25/100 9.5/38 1.700 0.850
11/2˝X3/4˝13507B 25/100 8/32 1.700 0.850
11/2˝X1˝13510 25 6.2 1.700 0.850
11/2˝X11/4˝13512 25 2.75 1.700 0.850
2˝X1/2˝13605B 10 8.5 2.230 0.970
2˝X3/4˝13607 10 6.8 2.230 0.970
2˝X1˝13610 10 4.4 2.230 0.970
2˝X11/4˝13612 10 4.4 2.230 0.970
2˝X11/2˝13615 10 3.1 2.230 0.970
21/2˝X11/2˝13715B 5 5.5 2.230 0.970
21/2˝X2˝13720 5 4 2.230 0.970
APPLICATION:DRYLOCATIONSONLY.Usetoreducetheentrysizeofarunofthreadedconduit.
MATERIAL:Steel. CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
42
RIGID
RIGID & INTERMEDIATE METALLIC CONDUIT FITTINGS
TM
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Conduit Nipples Steel
1/2˝XCLOSE 64305 20 1.2
1/2˝X11/2˝ 64311 25 2
1/2˝X2˝ 64325 15 2
1/2˝X3˝ 64331 25 4.2
1/2˝X4˝ 64341 15 4.2
1/2”X5” 64351B 25 8.25
1/2˝X6˝ 64361 10 3.9
1/2˝X8˝ 64381B 1 0.5
1/2˝X10˝ 64391B 1 0.7
1/2˝X12˝ 64301B 1 0.8
3/4˝XCLOSE 64307 20 1.9
3/4˝X2˝ 64327 15 2.4
3/4˝X3˝ 64332 20 6
3/4˝X4˝ 64342 15 9
3/4”X5” 64352B 25 10.75
3/4˝X6˝ 64362 10 5
3/4˝X8˝ 64382B 1 0.72
3/4˝X10˝ 64392B 1 0.9
3/4˝X12˝ 64302B 1 1.1
1˝XCLOSE 64310 15 4
1˝X2˝ 64313 10 2
1˝X21/2˝ 64323 15 4
1˝X3˝ 64333 25 9
1”X4” 64343B 25 12.25
1˝X5˝ 64353 10 6.4
1˝X6˝ 64363 6 4.8
1˝X8˝ 64383B 1 1.1
1˝X10˝ 64393B 1 1.3
1˝X12˝ 64303B 1 1.6
CONTINUATIONOFCHARTANDIMPORTANTAPPLICATION,MATERIALANDCERTIFICATION
NOTESPROVIDEDONNEXTPAGE
43
®
RIGID
11/4˝XCLOSE 64312 10 2.1
11/4˝X2˝ 64314 10 2.6
11/4˝X3˝ 64334 5 2.4
11/4”X4” 64344B 25 16.5
11/4˝X5˝ 64354 6 5
11/4˝X6˝ 64364 6 6
11/4˝X8˝ 64384B 1 1.4
11/4˝X10˝ 64394B 1 1.8
11/4˝X12˝ 64308B 1 2.2
11/2˝XCLOSE64315 5 1.48
11/2˝X2˝ 64615 5 1.7
11/2˝X3˝ 64335 10 5.6
11/2”X4” 64345B 25 20
11/2”X5” 64355B 25 25.75
11/2˝X6˝ 64365 4 5
11/2˝X8˝ 64385B 1 1.7
11/2˝X10˝ 64395B 1 2.2
11/2˝X12˝ 64605B 1 2.6
2˝XCLOSE 64320 4 1.9
2˝X3˝ 64336 6 5
2”X4” 64346B 25 25.75
2˝X5˝ 64356 6 8
2˝X6˝ 64366 5 3
2˝X7˝ 64676 3 8.5
2˝X8˝ 64386 4 9
2˝X10˝ 64396B 1 2.9
2˝X12˝ 64306B 1 3.5
21/2˝XCLOSE 64617B 1 0.45
21/2”X4” 64347B 1 1.5
21/2”X5” 64357B 1 2.0
21/2”X6” 64367B 1 2.4
21/2”X8” 64387B 1 3.3
21/2”X10” 64397B 1 4.25
21/2”X12” 64607B 1 5.1
3”XCLOSE 64618B 1 1.2
3”X3” 64338B 1 1.3
3”X4” 64348B 1 2.0
3”X5” 64358B 1 2.6
3”X6” 64368B 1 3.0
3”X8” 64388B 1 4.2
3”X10” 64398B 1 5.3
3”X12” 64608B 1 6.3
31/2”XCLOSE64619B 1 1.6
31/2”X4” 64349B 1 2.4
31/2”X5” 64359B 1 3.2
31/2”X6” 64369B 1 3.75
31/2”X8” 64389B 1 5.1
31/2”X10” 64399B 1 5.6
31/2”X12” 64309B 1 7.9
4”XCLOSE 64620B 1 1.8
4”X4” 64340B 1 2.9
4”X5” 64350B 1 3.8
4”X6” 64360B 1 4.4
4”X8” 64380B 1 6.0
4”X10” 64390B 1 7.75
4”X12” 64300B 1 9.25
APPLICATION:INDOORSOROUTDOORS.Usetoconnecttwosteeloutletboxesorothermetal
enclosures;usetoextendalengthofthreadedRigidorIMCconduit.MATERIAL:Steel,Zinc
Electro-Plate.MISC: Consultfactoryforavailabilityofothersizes.CERTIFICATIONS: TOULAND
CSAREQUIREMENTS.
44
RIGID
RIGID & INTERMEDIATE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Offset Nipples Zinc Die Cast
1/2˝ 04005B 10/100 1.2/12 2.44 0.93 0.75
3/4˝ 04007B 10/100 1.6/16 2.56 1.15 0.75
1˝ 04010B 10/100 2.2/22 2.75 1.42 0.75
11/4˝ 04012B 5/50 1.7/17 2.88 1.85 0.75
11/2˝ 04015B 5/50 2.3/23 3.06 2.07 0.75
2˝ 04020B 2/20 1.3/13 3.12 2.60 0.75
21/2˝ 04025B 2 2.6 4.02 3.23 0.75
3˝ 04030B 1 2.00 4.53 3.86 0.75
APPLICATION:INDOORSOROUTDOORS.Useasanoffsetconnectorbetweentwoenclosures.
Offsetstheaxisoftheracewayby3/4˝. MATERIAL:ZincDieCast. CERTIFICATIONS:TOULAND
CSAREQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
One-Hole Strap and Clamp Back Malleable Iron
11/4˝ 53212 10 3.5
2˝ 53220 10 9.0
APPLICATION:INDOORSOROUTDORS.UsetosecureRigidorIMCconduittomounting
surface,andtoprovidespacebetweenconduitandmountingsurface. MATERIAL:ZincElectro-
Plate.CERTIFICATIONS:TOCSAREQUIREMENTS.
NEW
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Clamp Backs Malleable Iron
1/2” 33205B 2.5/250 2.5/25 2.297 1.031
3/4" 33207B 2.75/250 2.75/27.5 2.438 1.172
APPLICATION:INDOORSOROUTDOORS.Usetospaceconduitfrommountingsurface,usewith
malleablestraps. MATERIAL:MalleableIron.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Box Spacers Zinc Die Cast
1/2˝ 16405B 50/500 4/40 1.12 0.40 0.31
3/4˝ 16407B 50/500 5.5/55 1.12 0.40 0.31
APPLICATION:INDOORS.Useasaracewaybetweentwosteeloutletboxesorothermetal
enclosures. MATERIAL:ZincDieCast.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Chase Nipples Zinc Die Cast
1/2˝ 07005B 100/1000 4/40 1.02 0.68
3/4˝ 07007B 50/500 3/30 1.29 0.75
1˝ 07010B 25/250 2.5/25 1.53 0.87
11/4˝ 07012B 25/250 3.5/35 1.89 0.94
11/2˝ 07015B 25/100 5/20 2.30 0.91
2˝ 07020B 10/40 2.3/9.2 2.88 1.07
21/2˝ 07025B 10/40 4.3/17.2 3.39 1.38
3˝ 07030B 10/40 5.5/22 4.06 1.44
31/2˝ 07035B 10/40 6.8/27.2 4.61 1.47
4˝ 07040B 5/20 3.5/14 5.15 1.47
WITH INSULATED THROAT
1/2˝ 87005B 100/1000 4/40 1.02 0.68
APPLICATION:INDOORSOROUTDOORS.Usewitharigidcouplingtoterminatethreaded
conduittoaknockoutboxorenclosure,wherespacewithintheboxislimited.Usedwitha
locknuttoprovideashortracewaybetweenboxesorenclosures. MATERIAL: ZincDieCast.
CERTIFICATIONS: TOULANDCSAREQUIREMENTS.
45
®
RIGID
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Conduit Bushings Zinc Die Cast
1/2˝ 05205B 100/1000 3/30 1.05 0.37
3/4˝ 05207B 100/1000 5/50 1.32 0.37
1˝ 05210B 50/500 3/30 1.58 0.37
11/4˝ 05212B 25/250 2.5/25 1.94 0.47
11/2˝ 05215B 25/250 3.75/37.5 2.20 0.50
2˝ 05220B 25/250 2.65/27.5 2.69 0.52
21/2˝ 05225B 10/100 3.6/36 3.23 0.52
3˝ 05230B 10/100 4.7/47 3.84 0.85
31/2˝ 05235B 5/50 3.05/30.5 4.35 0.85
4˝ 05240B 5/50 4/40 5.02 0.85
APPLICATION: INDOORSOROUTDOORS.UsewithlocknuttoterminatethreadedRigidorIMC
conduittoanoutletbox.Theroundedsurfaceofthebushingpreventsdamagetowireinsulation.
MATERIAL:ZincDieCast.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Plastic Insulating Bushings Thermoplastic
1/2˝ 75205B 100/1000 1/10 0.594 1.063 0.375
3/4˝ 75207B 100/1000 1/10 0.781 1.281 0.406
1˝ 75210B 50/500 1/10 1.000 1.563 0.563
11/4˝ 75212B 25/250 0.75/7.5 1.313 1.906 0.563
11/2˝ 75215B 25/250 0.75/7.5 1.531 2.219 0.563
2˝ 75220B 25/250 1.5/15 1.969 2.781 0.625
21/2˝ 75225B 10/100 1.1/11 2.406 3.375 0.750
3˝ 75230B 10/100 1.4/14 3.000 4.083 0.750
31/2˝ 75235B 5/50 1.1/11 3.328 4.469 0.688
4˝ 75240B 5/50 1.15/11.5 3.875 5.000 0.688
APPLICATION:INDOORSOROUTDOORS.UsewithlocknuttoterminatethreadedRigidor
IMCconduittobox.Roundedsurfaceofbushingpreventsdamagetowireinsulation.Required
bytheNEC.MATERIAL:HighImpactThermoplastic.FEATURES:Flame-Retardantto105°C.
CERTIFICATIONS: TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Insulated Metallic Zinc Die Cast
Grounding Bushings
(LAY-IN LUG)
1/2˝ 95205B 25/100 1.38/5.52 1.845 1.063 0.500
3/4˝ 95207B 25/100 1.75/7 2.047 1.281 0.500
1˝ 95210B 25/100 2.25/9 2.329 1.531 0.594
11/4˝ 95212B 20 2.6 2.688 1.875 0.625
11/2˝ 95215B 20 3.2 3.109 2.156 0.625
2˝ 95220B 10 2.1 3.594 2.625 0.625
21/2˝ 95225B 10/40 3.9/15.6 4.485 3.219 0.875
3˝ 95230B 10/40 5.8/23.2 5.063 3.813 0.875
31/2˝ 95235B 5/20 3.35/13.4 5.610 4.344 0.875
4˝ 95240B 5/20 4.5/18 6.095 4.813 0.875
APPLICATION:INDOORSOROUTDOORS.Usewithlocknuttoterminateserviceconduitto
acabinet.Lugprovidedforbondingjumpertoaneutralbusbar.Roundedsurfaceofbushing
preventsdamagetowireinsulation.MATERIAL: ZincDieCast.FEATURES: Thermoplasticliner
ratedat150°F.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
A
B
C
A
B
46
RIGID
RIGID & INTERMEDIATE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Conduit Body Gaskets Neoprene
1/2˝ 59105NB 25 0.4 1.375 3.906 3.500
3/4˝ 59107NB 25 0.55 1.563 4.688 4.125
1˝ 59110NB 25 0.7 1.781 5.375 4.813
11/4˝-11/2˝59115NB 20 1.1 2.500 7.250 6.500
2˝ 59120NB 20 1.75 3.125 9.500 8.563
21/2˝-3˝ 59130B 10 7.2 4.500 12.25011.250
31/2˝-4˝ 59140B 10 9.6 5.453 14.81313.750
APPLICATION:INDOORSOROUTDOORS.Useinconjunctionwithcovertoprovideadust-tight
sealtoalltypesofmetallicconduitbodies.MATERIAL:Neoprene.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Conduit Body Covers Aluminum
1/2˝ 59205B 50 3 1.375 3.906 3.500
3/4˝ 59207B 50 4 1.563 4.688 4.125
1˝ 59210B 50 4.5 1.781 5.375 4.813
11/4˝-11/2˝ 59215B 50 8.5 2.500 7.250 6.500
2˝ 59220B 25 7 3.125 9.500 8.563
21/2˝-3˝ 59230B 10 8 4.50012.25011.250
31/2˝-4˝ 59240B 5 7 5.45314.81313.375
APPLICATION:INDOORSOROUTDOORS.Usetocoverallstylesofmetallicbodies.MATERIAL:
Copper-FreeAluminumStamping.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Service Entrance ELL Aluminum
1/2˝ 59505 10 2.5 1.625 1.406 3.281
3/4˝ 59507 5 1.5 1.953 1.703 3.813
1˝ 59510 3 1.3 2.125 1.563 4.313
11/4˝ 59512 2 1.68 2.563 2.438 5.563
11/2˝ 59515 2 2.36 2.594 2.625 6.250
2˝ 59520 1 1.92 3.125 3.078 6.750
ALL SIZES INCLUDE COVER AND GASKET.
APPLICATION:INDOORSOROUTDOORS.Usetogainaccesstotheinteriorofaracewayor
wirepulling,inspections,andmaintenance.Mountsushagainststructure.UL listed for wet
locations. MATERIAL:Copper-FreeDieCastAluminum.CERTIFICATIONS: TOULANDCSA
REQUIREMENTS.
47
®
RIGID
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
Threaded Conduit Bodies Aluminum
WITH COVER AND GASKET
TYPE: LB
1/2˝58605 10 2.7 3.87 1.31 4.24 1.41
3/4˝58607 10 3.8 4.67 1.53 4.97 1.65
1˝58610 3 1.9 5.37 1.74 5.79 1.91
11/4˝58612 2 2.6 7.23 2.49 7.79 2.48
11/2˝58615 2 2.7 7.23 2.49 7.81 2.67
2˝58620 1 2.4 9.46 3.10 10.20 3.42
21/2˝58625 1 6 12.22 4.44 13.14 3.93
3˝ 58630B 1 5 12.22 4.44 13.14 4.52
31/2˝ 58635B 1 9.5 14.83 5.42 15.46 5.39
4˝ 58640B 1 8.5 14.83 5.42 15.46 5.39
TYPE: T
1/2˝58805 5 1.6 3.87 1.31 4.82 1.40
3/4˝58807 3 1.3 4.67 1.53 5.40 1.64
1˝58810 2 1.4 5.37 1.74 6.33 1.90
11/4˝58812 2 3.7 7.23 2.49 8.45 2.73
11/2˝58815 2 3.3 7.23 2.49 8.45 2.73
2˝58820 1 2.5 9.46 3.10 10.71 3.41
21/2˝ 58825B 1 6.222 11.208 4.50 13.75
3˝ 58830B 1 6.780 11.208 4.50 13.687
31/2˝ 58835B 1 12.526 14.937 4.50 16.904
4˝ 58840B 1 10.66 14.937 5.50 15.875
TYPE: LR
1/2˝58905 5 1.5 3.87 1.31 4.40 1.40
3/4˝58907 3 1.3 4.67 1.53 5.07 1.64
1˝58910 2 1.4 5.37 1.74 5.94 1.90
11/4˝58912 2 2.8 7.23 2.49 7.78 2.85
11/2˝58915 2 3.3 7.23 2.49 7.78 2.85
2˝58920 1 2.7 9.46 3.10 9.88 3.41
21/2˝ 58925B 1 6.000 12.22 4.50 13.14 4.00
3˝ 58930B 1 6.800 11.208 4.50 12.5
31/2˝ 58935B 1 11.55 14.937 5.50 15.062
4˝ 58940B 1 10.6375 14.937 5.50 15.187
TYPE: LL
1/2˝58305 5 1.5 3.87 1.31 4.40 1.40
3/4˝58307 3 1.3 4.67 1.53 5.07 1.64
1˝58310 2 1.4 5.37 1.74 5.94 1.90
11/4˝58312 2 2.8 7.23 2.49 7.87 2.85
11/2˝58315 2 3.1 7.23 2.49 7.87 2.85
2˝58320 1 2.7 9.46 3.10 10.20 3.41
21/2˝ 58325B 1 3 12.22 4.50 13.14 4.00
3˝ 58330B 1 6.592 11.208 4.50 12.5
31/2˝ 58335B 1 10.286 14.937 5.50 15.25
4˝ 58340B 1 9.8792
TYPE: C
1/2˝58405 5 1.4 3.87 1.31 4.82 1.40
3/4˝58407 3 1.3 4.67 1.53 5.50 1.64
1˝58410 2 1.2 5.37 1.74 6.44 1.90
11/4˝58412 2 3.3 7.23 2.49 8.45 2.73
11/2˝58415 2 3 7.23 2.49 8.45 2.73
2˝58420 1 2.6 9.46 3.10 10.71 3.41
21/2˝ 58425B 1 5.682 11.208 4.50 13.75
3˝ 58430B 1 6.314 11.208 5.50 13.687
31/2˝ 58435B 1 9.74 14.937 5.50 16.875
4˝ 58440B 1 10.226 14.937 5.50 16.875
APPLICATION:INDOORSOROUTDOORS.Usetogainaccesstotheinteriorofaracewayfor
wirepulling,splicing(withlimitationsasspeciedbytheNEC),andmaintenance.Not listed for
wet locations. MATERIAL:Copper-FreeDie-CastAluminum,AluminumStampedCoverand
NeopreneGasket.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
48
RIGID
RIGID & INTERMEDIATE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
Threaded Conduit Bodies Aluminum
COVER & GASKET SOLD SEPARATELY
TYPE: LB
1/2˝ 59605B 10/100 2.7/27 3.8752.1254.3751.063
3/4˝ 59607B 10/50 3.8/19 4.6252.4385.1251.344
1˝ 59610B 5/25 2.9/14.5 5.3752.8135.9381.656
11/4˝ 59612B 2/10 2.6/13 6.6253.7506.8752.250
11/2˝ 59615B 2/10 1.912/9.56 6.6253.7506.8752.250
2˝ 59620B 1 2.016 8.5004.1259.2192.938
TYPE: T
1/2˝ 59805B 10/100 3.2/32 3.8751.4384.9062.125
3/4˝ 59807B 10/50 4.8/24 4.6251.6885.5002.344
1˝ 59810B 5/25 3.5/17.5 5.3751.9386.4382.656
TYPE: C
1/2˝ 59405B 10/100 2.5/25 3.8751.4384.9061.063
APPLICATION:INDOORSOROUTDOORS.Usetogainaccesstotheinteriorofaracewayfor
wirepulling,splicing(withlimitationsasspeciedbytheNEC),andmaintenance.Not listed for
wet locations.MATERIAL: Copper-FreeDie-CastAluminum.CERTIFICATIONS: TOULANDCSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
RIGID/EMT Combo Conduit Bodies Aluminum
WITH COVER AND GASKET
TYPE: LR
1/2˝ 56905 10 3 3.875 2.0474.3751.438
3/4˝ 56907 6 1.8 4.625 2.3135.1251.688
TYPE: LL
1/2˝ 56305 10 2.7 3.875 2.0474.3751.438
3/4˝ 56307 6 1.62 4.625 2.9385.1251.688
TYPE: C
1/2˝ 56405 10 2.5 3.875 1.4384.9061.063
3/4˝ 56407 6 1.5 4.625 1.6885.5001.344
TYPE: LB
1/2˝ 56605 10 2.7 3.875 2.1254.3751.063
3/4˝ 56607 10 3.8 4.625 2.4385.1251.344
TYPE: T
1/2˝ 56805 10 3.2 3.875 1.4384.9062.125
3/4˝ 56807 5 1.6 4.625 1.6885.5002.344
APPLICATION:INDOORSOROUTDOORS.Usetogainaccesstotheinteriorofaracewayfor
wirepulling,splicing(withlimitationsasspeciedbytheNEC),andmaintenance.Not listed for
wet locations. MATERIAL:Copper-FreeDie-CastAluminum.MISC: CanbeusedwitheitherRigid,
IMCorEMTconduit.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
49
®
RIGID
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Mogul Pulling Elbows - Type LB Aluminum
11/4˝ 58212B 5 7 3.500 2.719 9.625
11/2˝ 58215B 2 7 5.500 4.12514.563
2˝ 58220B 2 7 5.500 4.12514.563
APPLICATION:INDOORSOROUTDOORS.Usetogainaccesstotheinteriorofaracewayfor
wirepulling,splicing(withlimitationsasspeciedbytheNEC),andmaintenance.Not listed for
wet locations. MATERIAL:Copper-FreeDie-CastAluminum.MISC: Allowslargeraccesstoinside
ofracewayforeasierwirepulling.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Water-Tight “Myers” Conduit Hubs Zinc Die Cast
WITH INSULATED THROAT
1/2˝91631 10 1.9 1.438 1.344
3/4˝91632 10 2.7 1.719 1.469
1˝16310 5 2.1 2.000 1.656
11/4˝16312 5 2.6 2.375 1.688
11/2˝16315 4 2.8 2.750 1.688
2˝16320 3 2.9 3.250 1.750
21/2˝16325B 2 3.12 3.750 2.219
3˝16330B 2 4.26 4.375 2.313
31/2˝16335B 1 2.6 5.000 2.375
4˝16340B 1 3.4 5.500 2.438
APPLICATION:INDOORSOROUTDOORS.UsetoconnectRigidorIMCconduittoaload
centerorothermetalenclosurewhereawater-tightjointisrequiredatknockoutsorslip-tholes.
MATERIAL: ZincDieCast.FEATURES:FlameRetardantInsulatedThroat.Rain,Oilanddusttight.
Oversizelocknutassuresvibration-proofinstallationandpositivegrounding.CERTIFICATIONS: TO
ULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
90° Short Radius Elbows Zinc Die Cast
1/2˝19005 20 2.1 0.98 0.96
3/4˝19007 10 1.7 1.17 1.04
APPLICATION: INDOORSOROUTDOORS.UsetoconnectRigidorIMCconduittoanoutletbox
whereacloseradiusisdesired.MATERIAL:ZincDieCast.CERTIFICATIONS: TOULANDCSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
90° Large Radius Adapter Elbows Zinc Die Cast
1/2˝ 19205B 25 2.9 1.294 1.4500.521
3/4˝ 19207B 10 1.6 1.526 1.6900.521
APPLICATION: INDOORSOROUTDOORS.UsetoconnectRigidorIMCconduittoanoutlet
boxwherealargeradiusisdesired.Usetoconvertanystandardstraightttingtoa90°tting.
MATERIAL:ZincDieCast.FEATURES:Exceptionalwirepullingability.CERTIFICATIONS: TOUL
ANDCSAREQUIREMENTS.
C
A
B
A
B
50
RIGID
RIGID & INTERMEDIATE METALLIC CONDUIT FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Rigid Couplings Steel
1/2˝64005B 100 12 1.010 1.625
3/4˝64007B 50 9 1.250 1.640
1˝64010 10 3.2 1.525 1.970
11/4˝64012 5 2.1 1.869 2.030
11/2˝64015 5 2.9 2.155 2.060
2˝64020 4 3.2 2.650 2.125
21/2˝64025 1 1.7 3.250 3.190
3˝64030 1 2.1 3.870 3.315
31/2˝64035 1 3.4 4.500 3.410
4˝64040 1 3 4.875 3.515
APPLICATION:INDOORSOROUTDOORS.UsetojointhreadedRigidorIMCconduittogether.
MATERIAL:GalvanizedSteel.CERTIFICATIONS:TOULANDCSAREQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A UL
RADIUS
90° Rigid Elbows Steel
1/2˝64105B 50 40 1.50 4.000
3/4˝64107B 50 54 1.50 4.500
1˝64110B 20 40 1.88 5.750
11/4˝64112B 20 60 2.00 7.250
11/2˝64115B 10 42 2.00 8.250
2˝64120B 10 68 2.00 9.500
21/2˝64125 1 12 3.00 10.500
3˝64130 1 19 3.13 13.000
31/2˝64135 1 28 3.25 15.000
4˝64140 1 31 3.38 16.000
APPLICATION:INDOORSOROUTDOORS.Usetoallowa90°changeofdirectioninarun
ofRigidorIMCconduit.MATERIAL:GalvanizedSteel.CERTIFICATIONS:TOULANDCSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A UL
RADIUS
45° Rigid Elbows Steel
1/2˝64205 10 5.2 1.50 4.000
3/4˝64207 10 8.2 1.50 4.500
1˝64210 25 30 1.88 5.750
11/4˝64212 20 40 2.00 7.250
11/2˝64215 15 45 2.00 8.250
2˝64220 10 50 2.00 9.500
21/2”64225 1 8.8 3.00 10.500
3”64230 1 14 3.13 13.000
31/2”64235 1 20 3.25 15.000
4”64240 1 24 3.38 16.000
APPLICATION:INDOORSOROUTDOORS.Usetoallowa45°changeofdirectioninarun
ofRigidorIMCconduit.MATERIAL:GalvanizedSteel.CERTIFICATIONS:TOULANDCSA
REQUIREMENTS.
A
B
51
®
SERVICE
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Midget One-Hole Straps Steel
26212
26214
APPLICATION:
MATERIAL:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
One-Hole Service-Cable Straps Steel
FITS NM CABLE
62171B
FITS SE AND SEU CABLE
62191B
62192B
62193B
62194B
APPLICATION:
MATERIAL:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C D
Two-Hole Service-Cable Straps Steel
FITS SE AND SEU CABLE
62291B
62292B
62293B
62294B
APPLICATION:
MATERIAL:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B B C
(MIN) (MAX) (MIN) (MAX)
Water-Tight Connectors Zinc Die Cast
COMPRESSION TYPE
(KO/CABLE SIZE)
07210
07310B
08112B
08212B
08312
09115B
09215
10220B
10420B
10520B
FITS UF CABLE ONLY: #14/2, #12/2
06605B
FITS UF CABLE: #14/3, #12/3
06607B
APPLICATION:
MATERIAL:
PURPOSE:
CERTIFICATIONS:
52
SERVICE
SERVICE ENTRANCE FITTINGS
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Service Entrance Caps Aluminum
CLAMP ON TYPE
58005
58007
58010
58012B
58015
58020B
58025
58030B
58035B
58040B
APPLICATION:
MATERIAL: FEATURES:CERTIFICATIONS:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Thermoplastic Service Entrance Caps PVC
77801
77802
77803
APPLICATION:
MATERIAL:TYPE:
CERTIFICATIONS:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Oval Service Cable Caps Aluminum
57499
57699
APPLICATION:
MATERIAL:Type: CERTIFICATIONS:
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Non-Metallic Service Entrance Cable Hoods
77602
77604
APPLICATION:
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
PVC Service Entrance Caps PVC
77907
77910
77912
77915
77920
APPLICATION:
MATERIAL:FEATURES:
CERTIFICATIONS:
NEW
53
®
SERVICE
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Slip-Fit Mast Heads Aluminum
FOR 200 AMP SERVICE
57925
APPLICATION:
MATERIAL:
CERTIFICATIONS:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CAS (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Service-Cable Sill Plates Aluminum
WITH 2 SCREWS
50599
WITH 4 SCREWS
50699
50799
APPLICATION:
MATERIAL:FEATURES:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CAS (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Conduit Sill Plates Aluminum
WITH 2 SCREWS
50507
50610
WITH 4 SCREWS
50612
50615
50720
APPLICATION:
MATERIAL:FEATURES:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX) (MIN)
Clamp Connectors Zinc Die Cast
05312B
05315B
05320B
APPLICATION:
MATERIAL: FEATURES:
CERTIFICATION:
54
SERVICE
SERVICE ENTRANCE FITTINGS
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Offset Bottom Reducers Aluminum
SLIPFITTER
50920
APPLICATION:
MATERIAL:MISC:CERTIFICATIONS:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Conduit Supports Malleable
LAG SCREW STYLE
51320
51325
APPLICATION:
MATERIAL:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Conduit Supports Malleable
10˝ BOLT, NUT & WASHER
33520
33525
APPLICATION:
MATERIAL:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Service Drop Brackets Steel
58050
APPLICATION:
MATERIAL: MISC.:
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Fork Bolts Steel
58060
APPLICATION: MATERIAL:
FEATURES:
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Roof Ties Steel
58070
APPLICATION: MATERIAL:
FEATURES:
NEW
NEW
NEW
55
®
SERVICE
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Adjustable Porcelain Wireholder
60525
APPLICATION:
MATERIAL:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Porcelain Wireholder
HEAVY DUTY
60222
APPLICATION:
MATERIAL:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Porcelain Wireholder
MEDIUM DUTY
60322
APPLICATION:
MATERIAL:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Porcelain Wireholder
LIGHT DUTY
60416
APPLICATION:
MATERIAL:
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Service Clevis Porcelain and Steel
60625
APPLICATION:
MATERIAL:FEATURES:
NEW
56
SERVICE
SERVICE ENTRANCE FITTINGS
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Service Entrance ELL Aluminum
59505
59507
59510
59512
59515
59520
APPLICATION:
MATERIAL:
CERTIFICATIONS:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Wedge Clamp Connectors Aluminum
51061
51062
51063
APPLICATION:
MATERIAL:
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Roof Flashing Steel
60812
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Duct Seals
79910B
79950B
APPLICATION:
FEATURES:
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Electric Pane Washers Steel
96312
APPLICATION: MATERIAL:FEATURES:
60820
60825
APPLICATION:
MATERIAL:
NEW
57
®
GROUND
A
A
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Ground Clamps for Bare Wire Bronze
With Lay-In Lug Design
FOR DIRECT BURIAL (STAINLESS STEEL SCREWS)
3/8˝ - 1˝ 36910B 100 27 2.36
APPLICATION: INDOORS OR OUTDOORS. Use to secure bare copper ground wire to
rebar, ground rod and pipe. UL listed for direct burial and concrete. WIRE SIZE: #10-#2 AWG.
MATERIAL: Bronze. FEATURES: This new JRD is extremely versatile - ts 3/8˝-1˝ Rebar, 1/2˝-1˝
pipe, 1/4˝-1˝ ground rods. Can be used for mechanically connecting 2 #8 solid wires. Use on water
pipes or for direct burial - no need to stock two clamps. Lay-In Lug feature is a tremendous
labor saver - no threading through holes - just lay-in ground wire and tighten screw.
CERTIFICATIONS: UL LISTED FOR DIRECT BURIAL AND CONCRETE.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Ground Clamps for Bare Wire Zinc Die Cast
1/2˝ - 1˝ 16010B 25/250 3.75/37.5 2.265
APPLICATION: INDOORS OR OUTDOORS. Use to secure the bare copper ground wire to a 1/2˝
through 1˝ pipe. 36010 and 36019 can be used with 4, 6, 8 rebar and ground rods. WIRE SIZE:
Fits #10 - #2 AWG. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Ground Clamps for Bare Wire Bronze
1/2˝ - 1˝ 36010B 25/250 5/48 2.281
FOR DIRECT BURIAL (BRONZE SCREWS)
1/2˝ - 1˝ 36019 15 3 2.281
APPLICATION: INDOORS OR OUTDOORS. Use to secure the bare copper ground wire to a 1/2˝
through 1˝ pipe. 36010 and 36019 can be used with 4, 6, 8 rebar and ground rods. WIRE SIZE: Fits
#10 - #2 AWG. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Ground Clamps for Bare Wire Bronze
1 1/4˝ - 2˝ 36020B 25 10 3.594
FOR DIRECT BURIAL (BRONZE SCREWS)
1 1/4˝ - 2˝ 36029 25 11 UPC ON PRODUCT 3.594
APPLICATION: INDOORS OR OUTDOORS. Use to secure the bare copper ground wire
to a 1 1/4˝-2˝ pipe. WIRE SIZE: Fits #10 - #2 AWG. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Ground Clamps for Armored Cable Bronze
1/2˝ - 1˝ 36110 15 BAGS 3.9 2.250
APPLICATION: INDOORS OR OUTDOORS. Use to secure the grounding wire to a 1/2˝ through
1˝ pipe. WIRE SIZE: Fits #8 - #4 AWG. FEATURES: Approved for direct burial. PURPOSE: For
Armored Covered Ground Wire. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Ground Clamps for Armored Cable Zinc Die Cast
1/2˝ - 1˝ 16110 15 BAGS 3 2.220
APPLICATION: INDOORS OR OUTDOORS. Use to secure Armored Covered Ground Wire to a
1/2˝ through 1˝ pipe. WIRE SIZE: Fits #8 - #6 AWG. PURPOSE: For Armored Covered Ground
Wire. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
A
58
GROUND
GROUNDING AND BONDING FITTINGS
TM
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Ground Clamp with Threaded Hub Bronze
1/2˝ HUB
1/2˝ - 1˝ 36210 10 2.8 2.230
APPLICATION: INDOORS OR OUTDOORS. Use to connect grounding conductor in rigid
threaded conduit to a 1/2˝-1˝ pipe. MATERIAL: Bronze. WIRE SIZE: #8-#4 AWG. FEATURES:
Hub accommodates 1/2˝ Rigid threaded conduit pipe. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
Ground Clamp with Strap and Hub Bronze
1/2˝-1˝
1/2” HUB 36310 10 4.0 2.281
3/4˝ HUB 36320 15 5.85 2.281
APPLICATION: INDOORS OR OUTDOORS. Use to connect grounding conductor in rigid threaded
conduit to a 1/2˝-1˝ pipe. WIRE SIZE: #8-#4 AWG. MATERIAL: Bronze with a 7˝ Copper strap and
Bronze hub. CERTIFICATIONS: TO UL REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Ground Rod Clamps Bronze
ONE SIZE FITS ALL
FOR DIRECT BURIAL (STAINLESS STEEL BOLT)
1/2˝-3/4˝ 35999B 100 14.5 1.55 0.75 0.860
APPLICATION: OUTDOORS. Use to connect bare copper ground wire to a driven ground rod.
MATERIAL: Bronze with Stainless Steel Bolt. FEATURES: This new SRC ground rod clamp ts all
size of ground rod - 1/2˝, 5/8˝ and 3/4˝ and accommodates wire size #10-1/0 AWG. Approved for
direct burial in ground or concrete. CERTIFICATIONS: TO UL REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Ground Rod Clamps Bronze
FOR DIRECT BURIAL (BRONZE BOLT)
1/2˝ 35905B 50/500 3/26 1.200 0.550 0.630
5/8˝ 35906B 50/500 4/36 1.320 0.660 0.670
3/4˝ 35907 35 6 1.500 0.800 0.800
APPLICATION: INDOORS or OUTDOORS. Use to connect bare copper ground wire to a driven
ground rod. Cannot use on Rebar. MATERIAL: Bronze with Bronze Bolt. FEATURES: Approved for
direct burial in ground and concrete. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Ground Straps
1/2˝ - 1˝ 32999 15 1.5 5.81 0.22
APPLICATION: INDOORS. Use to provide grounding termination points in load centers and other
electrical enclosures. MATERIAL: Solid copper with screw. A
B
A
DIMENSIONS
59
®
GROUND
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Ground Screws (Green) Steel
#10-32 63299 10 BOXES OF 100 PCS 5
APPLICATION: INDOORS OR OUTDOORS. Use to ground a wiring device to a steel outlet box.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Solid Ground Wires
#14 AWG 63188 100 1
APPLICATION: INDOORS OR OUTDOORS. Use to ground the branch wire to the wall of a metal
outlet box. FEATURES: Captive Screw. LENGTH: 6.5˝.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Stranded Ground Wires Copper
#12 AWG 46319 10 BAGS OF 2 PCS 0.5 0.50 6.50
APPLICATION: INDOORS OR OUTDOORS. Use to ground the branch wire to the wall of a metal
outlet box. FEATURES: Captive Screw and Clip. LENGTH: 8˝.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Ground Clips (Green) Steel
#14-#12 63099 10 BOXES OF 100 PCS 10
APPLICATION: INDOORS OR OUTDOORS. Use to connect the grounding wire to the side wall of
a steel outlet box. PURPOSE: For Non-Metallic Sheathed Cable.
TRADE HALEX CTN/CASE SERVICE ENTRANCE CONDUCTOR SIZES
SIZE PART # QTY COPPER CONDUCTORS ALUMINUM CONDUCTORS
KENNY CLAMP® Compression Connectors Brass
ALL SIZES FIT 1/2˝ KNOCKOUT
#8 STR 30208B 10 #2 OR SMALLER #1/0 OR SMALLER
#8 SOL 30218B 10 #2 OR SMALLER #1/0 OR SMALLER
#6 STR 30206B 10 #1 TO #1/0 #2/0 OR #3/0
#6 SOL 30216B 10 #1 TO #1/0 #2/0 OR #3/0
#4 STR 30204B 10 #2/0 OR #3/0 #4/0 OR 250 KCMIL
#4 SOL 30214B 10 #2/0 OR #3/0 #4/0 OR 250 KCMIL
#2 STR 30202B 10 OVER #3/0-350 KCMIL OVER 250 KCMIL-500 KCMIL
#1/0 STR 30210B 10 OVER 350 KCMIL-600 KCMIL OVER 500 KCMIL- 900 KCMIL
#2/0 STR 30220B 10 OVER 600 KCMIL-1100 KCMIL OVER 900 KCMIL-1750 KCMIL
#3/0 STR 30230B 10 OVER 600 KCMIL-1100 KCMIL OVER 1750 KCMIL
APPLICATION: Ensures code compliance for grounding electrode conductor installations,
and is the only UL listed connector for bonding and grounding of electrode conductors in panel
boards, pad mount, dry type transformers, metallic raceways and enclosures. MATERIAL: Brass.
CERTIFICATIONS: TO UL REQUIREMENTS.
A
B
60
ACCESSORIES
TM
ACC
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Cable Staples Steel
FOR NON-METALLIC CABLE
#14-2, #14-3, #12-2, #12-3
61050 20 BOXES OF 500 PCS 51 0.170 1.000 0.500
#14-2, #14-3, #12-2, #12-3
61010 100 BOXES OF 100 PCS 52 0.170 1.000 0.500
FOR ARMORED AND NON-METALLIC CABLE
#14-2, #14-3, #12-2, #12-3, #10-3, 2#14-2, 2#12-2
62550 20 BOXES OF 500 PCS 64 0.170 1.250 0.563
#14-2, #14-3, #12-2, #12-3, #10-3, 2#14-2, 2#12-2
62510 100 BOXES OF 100 PCS 66 0.170 1.250 0.563
APPLICATION: INDOORS ONLY. Use to secure non-metallic sheathed, armored or SEU cable to
wood surfaces. MATERIAL: Steel.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Plastic Insulating Staples Plastic
FITS NM CABLE: # 14 - #12 ;
FITS UF CABLE: #14/2 - #12/2
1/2˝ FLAT WIRE 27209 25 BAGS OF 50 PCS 7 0.93 0.43 1.25
FITS NM CABLE: # 10/2 - #8/2 ;
FITS UF CABLE: # 10/2 - #8/2 ; #14/3 - #12/3
3/4˝ FLAT WIRE 27309 25 BAGS OF 50 PCS 8 1.31 0.40 1.25
APPLICATION: INDOORS ONLY. Use to secure non-metallic sheathed or UF cable to wood
surfaces. MATERIAL: Plastic with Steel Nails.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A A B
(MIN) (MAX)
Strain Relief Cord Connectors Zinc Die Cast
FITS WIRE RANGE : .190 - .260
1/2˝ 16911B 25 2.5 0.190 0.260 1.20
FITS WIRE RANGE : .260 - .375
1/2˝ 16912B 25 2.5 0.260 0.375 1.20
FITS WIRE RANGE : .375 - .500
1/2˝ 16913B 25 2.5 0.375 0.500 1.20
FITS WIRE RANGE : .375 - .500
3/4˝ 16921B 25 3.5 0.375 0.500 1.27
FITS WIRE RANGE : .500 - .625
3/4˝ 16922B 25 3.5 0.500 0.625 1.27
FITS WIRE RANGE : .625 - .750
3/4˝ 16923B 25 3.5 0.625 0.750 1.27
FITS WIRE RANGE : .375 - .500
1˝ 16930B 10 3.4 0.375 0.500 1.48
FITS WIRE RANGE: .625 - .750
1˝ 16932 10 3.4 0.625 0.750 1.48
FITS WIRE RANGE : .750 - .880
1˝ 16933B 10 3.4 0.750 0.880 1.48
FITS WIRE RANGE .880 - .985
1˝ 16934B 10 3.4 0.880 0.985 1.48
APPLICATION: INDOORS ONLY. Use to connect S, SO, ST, SJ, SJO, and SJT cord to a
steel outlet box or other metal enclosure. MATERIAL: Zinc Die Cast. TYPE: Gland Style.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
C
A
B
B
A
C
61
®
ACC
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Non-Metallic Strain Relief Cord Connectors
FITS CORD RANGE: .200 - .472
1/2˝ 76913B 25 1 1.792 0.600 1.030
FITS CORD RANGE: .385 - .750
3/4˝ 76923B 10 0.6 2.250 0.600 1.270
APPLICATION: INDOORS ONLY. Use to connect cord to a steel outlet box or other metal
enclosure. MATERIAL: PVC. TYPE: Gland Style. FEATURES: Liquid-tight seal, oil-tight seal,
unique grommet with gripping ngers. A sealing ring and zinc locknut are provided to assure a
liquid-tight seal when installing in non-threaded openings. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
90° (Large Radius)
Zinc Die Cast
Strain Relief Cord Connectors
FITS WIRE RANGE : .190 - .260
1/2˝ 16811B 10 1.4 1.655 1.469 0.521
FITS WIRE RANGE : .260 - .375
1/2˝ 16812B 10 1.4 1.655 1.469 0.521
FITS WIRE RANGE : .375 - .500
1/2˝ 16813B 10 1.4 1.655 1.469 0.521
FITS WIRE RANGE : .440 - .500
3/4˝ 16821B 10 2.1 1.914 1.634 0.521
FITS WIRE RANGE : .500 - .625
3/4˝ 16822B 10 2.1 1.914 1.634 0.521
FITS WIRE RANGE : .625 - .725
3/4˝ 16823B 10 2.1 1.914 1.634 0.521
APPLICATION: INDOORS ONLY. Use to connect S, SO, ST, SJ, SJO, and SJT cord to a steel
outlet box or other metal enclosure. MATERIAL: Zinc Die Cast. TYPE: Gland Style. FEATURES:
Large Radius provides minimal wire stress and easy pulling. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Split Bolt Connectors Bronze
10-8 32408B 100 4 0.1475 0.4050 0.5475
8-6 SOL 32406B 100 5 0.1685 0.4055 0.6165
8-6 32404B 100 7 0.2100 0.4375 0.6780
6-2 32402B 100 11 0.3130 0.5980 0.8520
4-1/0 32310B 50 8 0.3770 0.7535 1.0085
2-2/0 32320B 25 8 0.4275 0.7915 1.0525
1-3/0 32330B 25 10 0.5375 0.9580 1.2565
1-250 MCM 32340B 25 13 0.5880 1.0410 1.3765
* RANGE: Equal run and tap. Each wire size is listed for both solid and stranded unless specied.
APPLICATION: INDOORS OR OUTDOORS. Use to connect ground wires together. For
direct burial stranded unless specied and concrete. PURPOSE: For Copper and Copperweld
Wires. MATERIAL: Silicon Bronze. TYPE: Flat Style. CERTIFICATIONS: TO UL AND CSA
REQUIREMENTS.
62
ACCESSORIES
TM
ACC
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Split Bolt Connectors with Spacer Bar Bronze
FOR COPPER TO COPPER; **CAN BE USED ON ALUMINUM CONDUCTOR,
BUT IS NOT UL LISTED FOR THAT APPLICATION
FOR COPPER TO COPPER, COPPER TO ALUMINUM, ALUMINUM TO ALUMINUM
6-2 32002B 100 13 0.3155 0.6080 0.8600
FOR COPPER TO COPPER; **CAN BE USED ON ALUMINUM CONDUCTOR,
BUT IS NOT UL LISTED FOR THAT APPLICATION
8-6 SOL 32006B 25 1.50 0.1670 0.3960 0.6155
8-6 32004B 25 2.00 0.2095 0.4375 0.6795
4-1/0 31910B 10 1.80 0.3785 0.7525 1.0430
2-2/0 31920B 25 8.00 0.4285 0.7955 1.0635
1-3/0 31930B 10 4.00 0.5825 1.0340 1.3725
1-250 MCM STR 31940B 25 13.30 0.05825 1.0340 1.3725
* RANGE: Each wire size is listed for both solid and stranded unless specied.APPLICATION:
INDOORS OR OUTDOORS. Use to connect wires together. Use oxide-inhibiting compound when
connecting aluminum or ACSR (aluminum conductor steel reinforced) or aluminum to copper wires.
MATERIAL: Silicon Bronze with Electro-Tin plated bolt, nut, spacer, and pressure bar. MISC: Call
factory for availability of other sizes. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Solderless Terminal Lugs Copper
#6-#14 32606B 250 7.5 NA 0.438 1.125 0.375
#8-#2 32602B 200 10 NA 0.500 1.438 0.500
#14-10 32609B 50 1.1 NA 0.281 0.938 0.313
#1/0-#8 32510B 100 11 NA 0.625 1.875 0.625
#4-#3/0 32530B 10 1.6 NA 0.750 2.250 0.750
#2-#4/0 32540B 10 2.4 NA 1.000 2.375 1.000
APPLICATION: INDOORS OR OUTDOORS. Use to connect a ground wire or wires to a
metal enclosure. MATERIAL: Electrolytic Copper. FEATURES: One Hole, Single Collar.
CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Strut Pipe Clamp Steel
1/2” & 3/4” 61399B 25 2.93 1.25 4.90
APPLICATION: INDOORS OR OUTDOORS. Use this strut pipe clamp for securing 1/2” and 3/4”
conduit and pipe from strut sizes 1-5/8” (41 mm) wide x minimum 13/16” (21mm) high. MATERIAL:
Steel, Zinc Electro-Plate. FEATURES: One clamp ts 1/2” and 3/4” trade sizes and provides a 2-1
SKU reduction. The slanted design makes installation easier and allows pipe and conduit to be
tightly spaced. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
A
B
NEW
63
®
ACC
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Knock Out Seals Steel
1/2˝ 60705B 250/1000 3.5/14 1.078 0.359
1/2˝ 60795B 100/1000 1.4/14 1.078 0.359
3/4˝ 60707B 250/1000 4/16 1.250 0.313
3/4˝ 60797B 100/1000 1.6/16 1.250 0.313
1˝ 60710B 50/500 1/10 1.500 0.344
1 1/4˝ 60712 25 0.8 1.818 0.313
1 1/2˝ 60715 25 1.2 2.219 0.359
2˝ 60720 15 0.9 2.688 0.375
APPLICATION: INDOORS. Use to cover exposed knock-out holes in steel outlet boxes and other
metal enclosures. MATERIAL: Steel; Zinc Electro-Plate.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Switch Box Supports Zinc Plated Steel
62700B 50 PAIR 3 2.20 5.35
APPLICATION: INDOORS. Use to support attachment of an outlet box in drywall, paneling, etc., in
the absence of a structure member. Installed in pairs.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Snap-In Bushings Plastic
1/2˝ 72505B 100 0.5 0.72 0.99 0.36
3/4˝ 72507B 100 0.6 0.95 1.22 0.36
1˝ 72510B 100 0.9 1.206 1.446 0.428
2˝ 72520B 25 1 2.20 2.65 0.75
2 1/2˝ 72525 10 0.05 2.50 2.95 0.71
APPLICATION: INDOORS ONLY. Use to protect non-metallic cable from damage when running
cable through metal studs into an enclosure or standard trade-size knockout. MATERIAL: Plastic.
FEATURES: Fits a round pre-punched metal stud opening.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Universal Snap-In Bushings Polypropylene
72599BP 250 12 1.20 2.27 0.56
72599B 25/250 1.2/12 1.20 2.27 0.56
BAGGED ITEMS
27259 6 BAGS OF 25 PCS 6.0 1.20 2.27 0.56
APPLICATION: INDOORS ONLY. Use to protect non-metallic cable from damage when running
cable through metal studs. MATERIAL: Polypropylene. FEATURES: Fits a variety of pre-punched
metal stud openings. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
C
A
B
64
ACCESSORIES
TM
ACC
A
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B
Nail Plates Zinc Plated Steel
1 1/2¨ X
2 1/2˝ 62899 50/500 3.3/33 1.50 2.50
1 1/2˝ X 5˝ 62850 100 PCS 12.6 1.50 5.00
1 1/2˝ X 5˝ 62851B 100 PCS 12.6 1.50 5.00
APPLICATION: INDOORS ONLY. Use to protect internal wire runs from nail punctures, as dened
in the NEC Article 300.4. MATERIAL: Zinc plated steel.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Jack Chains Zinc Plated Steel
12 GAUGE 60010 100' 6
10 GAUGE 60020 100' 9
FEATURES: Supports up to 29 lbs. MATERIAL: Zinc plated steel.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A
“S” Hooks Zinc Plated Steel
12 GAUGE 60199 100 1 1.219
APPLICATION: INDOORS. Use to suspend light xtures, etc. MATERIAL: Zinc plated steel.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
“Sky-Tie” Cable Clamps Steel
1/2˝-3/4˝ 66207B 10 3.5
3/4˝-1 1/8˝ 66211B 10 7
2” SPECIAL 25716B 5 10
FEATURES: Interchangeable Two-Piece Construction; Keyhole Slots - permits assembly on cable
without removal of bolts or threading of cable through tting. Supports and anchors bus-drop cable
at a 90° angle. MATERIAL: Stamped Steel.
TRADE HALEX CTN/CASE CTN/CASE
SIZE PART # QTY WT (LBS)
Extension Springs Steel
SUPPORTS 10 - 60 LBS.
10-60 LBS 66377B 10 2.8
SUPPORTS 15 - 70 LBS.
10-70 LBS 66388B 10 2.5
SUPPORTS 25-200 LBS.
25-200 LBS 66399B 5 5
APPLICATION: INDOORS. Use to suspend “Sky-Tie” cable to clamp. MATERIAL: Steel, Zinc
Electro-plate. FEATURES: Slips on to “Sky-Tie” at its outside bend and ties back to structural
member. Ensures tautness of cable, absorbs vibration.
65
®
ACC
A
C
B
B
AC
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Duct Seal
1 LB. SLUG 79910B 50 50 4.125 4.125 0.075
5 LB. SLUG 79950B 10 50 4.188 4.188 0.081
APPLICATION: INDOORS OR OUTDOORS. Use to seal around junction boxes, ashings, and
service entrance locations. FEATURES: Service Temperature Range: -30°F - 100°F; Compound is
pliable and noncorrosive to metals; Compound can be painted.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Fixture Hangers
FITS 3 1/4 OR 4˝ OCTAGONAL OUTLET BOXES
69588B 25 4.1 4.125 4.125 0.075
FITS 4˝ SQUARE OUTLET BOXES
69699B 25 5 4.188 4.188 0.081
APPLICATION: INDOORS OR OUTDOORS. Use to secure and suspend light xture. FEATURES:
Self-aligning covers provide exible suspension, assuring plumb alignment, regardless of ceiling
structure or angle. Equipped with ball joint, allows xture to swivel through an angle of 20° in any
direction. MATERIAL: Stamped steel.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B HW TW
RIGID EMT
Conduit Hangers Steel
WITH NUT AND BOLT ATTACHED
0 67800B 100 7 1.875 0.750 3/8˝-1/2˝ 1/2˝
1 67810B 100 9 2.125 0.750 3/4˝ 3/4˝
2 67820B 100 10 2.437 0.875 1˝ 1˝
2 1/2 67825 15 1.7 2.750 0.875 1 1/4˝
3 67830B 100 10 2.875 0.875 1 1/4˝ 1 1/2˝
4 67840B 100 16 3.125 1.000 1 1/2˝
5 67850B 50 10 3.875 1.000 2˝ 2˝
6 67860B 50 17 4.625 1.250 2 1/2˝ 2 1/2˝
7 67870B 50 19.5 5.500 1.250 3˝ 3˝
8 67880B 25 10.25 5.750 1.250 3 1/2˝ 3 1/2˝
9 67890B 10 5.5 6.250 1.250 4˝ 4˝
APPLICATION: INDOORS OR OUTDOORS. Use to secure and suspend conduit from overhead
supports. MATERIAL: Zinc plated steel. CERTIFICATIONS: TO UL AND CSA REQUIREMENTS.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Beam Clamps Steel
1/4-20 65600B 25/250 3.3/33 1.5 1.5 1.0
APPLICATION: INDOORS OR OUTDOORS. Use to secure conduit to a metal beam. Clamps on
beam, girder or similar structure to provide a mounting base for attachment of a conduit hanger,
either directly or by means of a threaded rod. Eliminates the need to drill a hole through the beam.
FEATURES: Maximum 100 lbs. load bearing.
DIMENSIONS
TRADE HALEX CTN/CASE CTN/CASE (IN INCHES)
SIZE PART # QTY WT (LBS) A B C
Beam Clamps Malleable Iron
1”- 1/4-20 35600B 25/250 5/50 2.10 1.73 0.85
2”- 3/8-16 35610B 10 7 1.9375 1.75 0.875
APPLICATION: INDOORS OR OUTDOORS. Use to secure conduit to a metal beam. Clamps on
beam, girder or similar structure to provide a mounting base for attachment of a conduit hanger,
either directly or by means of a threaded rod. Eliminates the need to drill a hole through the beam.
A
C
B
B
A
C
66
INDEX
INDEX
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
TM
01820 40
01905B 40
01907B 40
01910B 40
01912B 40
01915B 40
01920B 40
01925B 40
01930B 40
01935B 40
01940B 40
02005B 6
02007B 6
02105B 6
02107B 6
02110B 6
02112B 6
02115B 6
02120B 6
02125B 6, 34
02130B 6, 34
02135B 6, 34
02140B 6, 34
02205B 6
02207B 6
02210B 6
02212B 6
02215B 6
02220B 6
02225B 6, 35
02230B 6, 35
02235B 6, 35
02240B 6, 35
02705B 12
02707B 12
02805B 12
02807B 12
02905B 12
02907B 12
02910 12
03705B 11
03707B 11
03905 11
03907 11
04005B 44
04007B 44
04010B 44
04012B 44
04015B 44
04020B 44
04025B 44
04030B 44
04203B 20
04203NB 20
04205B 20
04205NB 20
04207B 20
04210B 20
04212B 20
04215B 20
04220B 20
04225B 20
04230B 20
04235B 20
04240B 20
04403B 18
04403NB 18
04405B 18
04405NB 18
04407B 18
04410B 18
04412B 18
04415B 18
04420B 18
04505B 18
04507B 18
04510 18
04512 18
04515 18
04520 18
04805B 21
04807B 21
04905B 15, 21
04907B 15, 21
04910 15, 21
05103B 26
05103NB 26
05107B 26
05107NB 26
05110B 26
05112B 26
05115B 26
05120B 26
05205B 45
05207B 45
05210B 45
05212B 45
05215B 45
05220B 45
05225B 45
05230B 45
05235B 45
05240B 45
05312B 26, 53
05315B 26, 53
05320B 26, 53
05703B 21, 27
05703NB 22, 27
05803B 23
05803NB 23
06305B 30
06307B 30
06605B 28, 51
06607B 28, 51
06703B 22, 28
06703NB 23, 28
06805B 30
06807B 30
07005B 44
07007B 44
07010B 44
07012B 44
07015B 44
07020B 44
07025B 44
07030B 44
07035B 44
07040B 44
07210 51
07310B 51
08112B 51
08212B 51
08312 51
09115B 51
09215 51
10220B 51
10420B 51
10520B 51
11003B 19
11003NB 19
11005B 19
11005NB 19
11007B 19
11010B 19
11012B 19
11015B 19
11020B 19
11025B 19
11030B 19
11035B 19
11040B 19
12105B 9
12107B 9
12110B 9
12112B 9
12115B 9
12120B 9
12125B 9, 36
12130B 9, 36
12135B 9, 36
12140B 9, 36
12205B 9
12207B 9
12210B 9
12212B 9
12215B 9
12220B 9
12225B 9, 36
12230B 9, 36
12235B 9, 36
12240B 9, 36
13205B 41
13305B 41
13307B 41
13405B 41
13407B 41
13410B 41
13505B 41
13507B 41
13510 41
13512 41
13605B 41
13607 41
13610 41
13612 41
13615 41
13715B 41
13720 41
14205 38
14207 38
14305 14
14307 14
14405 14
14407 14
14605 14
14607 14
15303B 15, 29
15304B 15, 37
15305B 15, 21
15306B 15, 37
15307B 15, 21
15803B 22, 27
15803NB 22, 27
16010B 57
16110 57
16203B 30
16205B 30
16207B 30
16210B 30
16212B 30
16215B 30
16220B 30
16310 49
16312 49
16315 49
16320 49
16325B 49
16330B 49
16335B 49
16340B 49
16405B 44
16407B 44
16811B 61
16812B 61
16813B 61
16821B 61
16822B 61
16823B 61
16903B 31
16905B 31
16907B 31
16910B 31
16911B 60
16912B 60
16913B 60
16914B 31
16915B 31
16920B 31
16921B 60
16922B 60
16923B 60
16930B 60
16932 60
16933B 60
16934B 60
19005 49
19007 49
19205B 49
19207B 49
25716B 64
26212 51
26214 51
27209 60
27259 63
27309 60
30202B 59
30204B 59
30206B 59
30208B 59
30210B 59
30214B 59
30216B 59
30218B 59
30220B 59
30230B 59
31205B 39
31207B 39
31910B 62
31920B 62
31930B 62
31940B 62
32002B 62
32004B 62
32006B 62
32310B 61
32320B 61
32330B 61
32340B 61
32402B 61
32404B 61
32406B 61
32408B 61
32510B 62
32530B 62
32540B 62
32602B 62
32606B 62
32609B 62
32930B 62
32940B 62
32999 58
33205B 44
33207B 44
33520 54
33525 54
35600B 65
35610B 65
35905B 58
35906B 58
35907 58
35999B 58
36010B 57
36019 57
36020B 57
36029 57
36110 57
36210 58
36310 58
36320 58
36910B 57
46319 59
50507 53
50599 53
50610 53
50612 53
50615 53
50699 53
50720 53
50799 53
50920 54
51061 56
51062 56
51063 56
51320 54
51325 54
53212 44
53220 44
56305 16, 48
56307 16, 48
56405 16, 48
56407 16, 48
56605 16, 48
56607 16, 48
56805 16, 48
56807 16, 48
56905 17, 48
56907 17, 48
57499 52
57699 52
57925 53
58005 52
58007 52
58010 52
58012B 52
58015 52
58020B 52
58025 52
58030B 52
67
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
®
INDEX
58035B 52
58040B 52
58050 54
58060 54
58070 54
58212B 49
58215B 49
58220B 49
58305 47
58307 47
58310 47
58312 47
58315 47
58320 47
58325B 47
58330B 47
58335B 47
58340B 47
58405 47
58407 47
58410 47
58412 47
58415 47
58420 47
58425B 47
58430B 47
58435B 47
58440B 47
58605 47
58607 47
58610 47
58612 47
58615 47
58620 47
58625 47
58630B 47
58635B 47
58640B 47
58705 17
58707 17
58805 47
58807 47
58810 47
58812 47
58815 47
58820 47
58825B 47
58830B 47
58835B 47
58840B 47
58905 47
58907 47
58910 47
58912 47
58915 47
58920 47
58925B 47
58930B 47
58935B 47
58940B 47
59105NB 46
59107NB 46
59110NB 46
59115NB 46
59120NB 46
59130B 46
59140B 46
59205B 46
59207B 46
59210B 46
59215B 46
59220B 46
59230B 46
59240B 46
59405B 48
59505 46, 56
59507 46, 56
59510 46, 56
59512 46, 56
59515 46, 56
59520 46, 56
59605B 48
59607B 48
59610B 48
59612B 48
59615B 48
59620B 48
59805B 48
59807B 48
59810B 48
60010 64
60020 64
60199 64
60222 55
60322 55
60416 55
60525 55
60625 55
60705B 63
60707B 63
60710B 63
60712 63
60715 63
60720 63
60795B 63
60797B 63
60812 56
60820 56
60825 56
61010 60
61050 60
61105B 39
61107B 39
61110B 39
61112B 39
61115B 39
61120 39
61125 13, 39
61130 13, 39
61135B 13, 39
61140B 13, 39
61205B 39
61207B 39
61210B 39
61212B 39
61215B 39
61220B 39
61225B 13, 39
61230 13, 39
61235B 13, 39
61240B 13, 39
61399B 62
61405B 13
61407B 13
61410B 13
61505B 13
61507B 13
61510B 13
61512B 13
61515B 13
61520B 13
61605B 13
61607B 13
61610B 13
61612B 13
61615B 13
61620B 13
61805B 40
61807B 40
61810B 40
61812B 40
61815B 40
61820B 40
61905B 39
61907B 39
61910B 39
61912B 39
61915B 39
61920B 39
61925B 39
61930B 39
61935B 39
61940B 39
62171B 29, 51
62181B 21
62191B 51
62192B 51
62193B 51
62194B 51
62291B 51
62292B 51
62293B 51
62294B 51
62305B 7
62307B 7
62310B 7
62312B 7
62315B 7
62320B 7
62325B 7, 34
62330B 7, 34
62335B 7, 34
62340B 7, 34
62405B 7
62407B 7
62410B 7
62412B 7
62415B 7
62420B 7
62425B 7, 35
62430B 7, 35
62435B 7, 35
62440B 7, 35
62505B 8
62507B 8
62510 60
62510B 8
62512B 8
62515B 8
62520B 8
62525B 8
62530B 8
62535B 8
62540B 8
62550 60
62605B 8
62607B 8
62610B 8
62612B 8
62615B 8
62620B 8
62625B 8
62630B 8
62635B 8
62640B 8
62700B 63
62705B 10
62707B 10
62710B 10
62712B 10
62715B 10
62720B 10
62725B 10, 36
62730B 10, 36
62735B 10, 36
62740B 10, 36
62805B 10
62807B 10
62810B 10
62812B 10
62815B 10
62820B 10
62825B 10, 36
62830B 10, 36
62835B 10, 36
62840B 10, 36
62850 64
62851B 64
62899 64
63099 59
63188 59
63299 59
63505B 35
63507B 35
63510B 34
63512B 34
63515B 34
63520B 34
63605B 35
63607B 35
63610B 35
63612B 35
63615B 35
63620B 35
64005B 50
64007B 50
64010 50
64012 50
64015 50
64020 50
64025 50
64030 50
64035 50
64040 50
64105B 50
64107B 50
64110B 50
64112B 50
64115B 50
64120B 50
64125 50
64130 50
64135 50
64140 50
64205 50
64207 50
64210 50
64212 50
64215 50
64220 50
64225 50
64230 50
64235 50
64240 50
64300B 43
64301B 42
64302B 42
64303B 42
64305 42
64306B 43
64307 42
64308B 43
64309B 43
64310 42
64311 42
64312 43
64313 42
64314 43
64315 43
64320 43
64323 42
64325 42
64327 42
64331 42
64332 42
64333 42
64334 43
64335 43
64336 43
64338B 43
64340B 43
64341 42
64342 42
64343B 42
64344B 43
64345B 43
64346B 43
64347B 43
64348B 43
64349B 43
64350B 43
64351B 42
64352B 42
64353 42
64354 43
64355B 43
64356 43
64357B 43
64358B 43
64359B 43
64360B 43
64361 42
64362 42
64363 42
64364 43
64365 43
64366 43
64367B 43
64368B 43
64369B 43
64380B 43
64381B 42
64382B 42
64383B 42
64384B 43
64385B 43
64386 43
64387B 43
68
INDEX
INDEX
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
Item Page
No. No.
TM
64388B 43
64389B 43
64390B 43
64391B 42
64392B 42
64393B 42
64394B 43
64395B 43
64396B 43
64397B 43
64398B 43
64399B 43
64405B 11
64407B 11
64410B 11
64412B 11
64415B 11
64420B 11
64425 11
64430 11
64435 11
64440 11
64505 11
64507 11
64510 11
64512 11
64515 11
64520 11
64525 11
64530 11
64535 11
64540 11
64605B 43
64607B 43
64608B 43
64615 43
64617B 43
64618B 43
64619B 43
64620B 43
64676 43
65103B 28
65110B 28
65112B 28
65115B 28
65505B 37
65507B 37
65510B 37
65512B 37
65515B 37
65520B 37
65525B 37
65530B 37
65535B 37
65540B 37
65600B 65
65705B 23
65805B 23
66203B 31
66205B 31
66206B 31
66207B 64
66210B 31
66211B 64
66212B 31
66215B 31
66220B 31
66377B 64
66388B 64
66399B 64
66503B 32
66505B 32
66507B 32
66510B 32
66512B 32
66515B 32
66520B 32
66903B 32
66905B 32
66907B 32
66910B 32
66912B 32
66915B 32
66920B 32
67800B 65
67810B 65
67820B 65
67825 65
67830B 65
67840B 65
67850B 65
67860B 65
67870B 65
67880B 65
67890B 65
68205B 41
68305B 41
68307B 41
68405B 41
68407B 41
68410B 41
68505B 41
68507B 41
68510 41
68512B 41
68605B 41
68607B 41
68610B 41
68612B 41
68615 41
68720 41
69588B 65
69699B 65
72505B 63
72507B 63
72510B 63
72520B 63
72525 63
72599B 63
72599BP 63
74505B 33
74507B 33
75005B 15
75007B 15
75010B 15
75012B 15
75015B 15
75020B 15
75101B 25
75102B 25
75105B 25
75107B 25
75205B 45
75207B 45
75210B 45
75212B 45
75215B 45
75220B 45
75225B 45
75230B 45
75235B 45
75240B 45
75400 20
75400BP 20
75401 20
75401BP 20
75402 20
75402BP 20
75403 20
75403BP 20
75404 20
75404BP 20
75803B 25
76203B 33
76205B 33
76207B 33
76210B 33
76212B 33
76215B 33
76220B 33
76903B 33
76905B 33
76907B 33
76910B 33
76912B 33
76913B 61
76915B 33
76920B 33
76923B 61
77602 52
77604 52
77801 52
77802 52
77803 52
77907 52
77910 52
77912 52
77915 52
77920 52
79910B 56, 65
79950B 56, 65
82105B 6
82107B 6
82110B 6
82112B 6
82115B 6
82120B 6
82125B 6, 34
82130B 6, 34
82135B 6, 34
82140B 6, 34
82305B 7
82307B 7
82310B 7
82312B 7
82315B 7
82320B 7
82325B 7, 34
82330B 7, 34
82335B 7, 34
82340B 7, 34
82705B 10
82707B 10
82710B 10
82712B 10
82715B 10
82720B 10
82725B 10, 36
82730B 10, 36
82735B 10, 36
82740B 10, 36
84205B 20
84207B 20
84210B 20
84212B 20
84215B 20
84220B 20
84403B 18
84405B 18
84407B 18
84410 18
84412 18
84415 18
84420 18
84805B 21
84807B 21
85403NB 24
86203B 31
86205B 31
86207B 31
86210B 31
86212B 31
86215B 31
86220B 31
86225B 31
86230B 31
86235B 31
86240B 31
86305B 30
86307B 30
86503B 32
86505B 32
86507B 32
86510B 32
86512B 32
86515B 32
86520B 32
86525B 32
86530B 32
86535B 32
86540B 32
86703B 22, 28
86903B 32
86905B 32
86907B 32
86910B 32
86912B 32
86915B 32
86920B 32
86925B 32
86930B 32
86935B 32
86940B 32
87005B 44
91003B 19
91005B 19
91007B 19
91010 19
91012 19
91015 19
91020 19
91631 49
91632 49
92105B 9
92107B 9
92110B 9
92112B 9
92115B 9
92120B 9
92125B 9, 36
92130B 9, 36
92135B 9, 36
92140B 9, 36
92505B 8
92507B 8
92510B 8
92512B 8
92515B 8
92520B 8
92525B 8
92530B 8
92535B 8
92540B 8
94105B 37
94107B 37
94110 37
94205B 38
94207B 38
94405 14
94407 14
94410 14
94505 14, 37
94507 14, 37
94510 14, 37
94705 14, 38
94707 14, 38
95205B 45
95207B 45
95210B 45
95212B 45
95215B 45
95220B 45
95225B 45
95230B 45
95235B 45
95240B 45
95403NB 24
96203B 30
96205B 30
96207B 30
96210B 30
96212B 30
96215B 30
96220B 30
96225B 30
96230B 30
96235B 30
96240B 30
96312 56
96903B 31
96905B 31
96907B 31
96910B 31
96912B 31
96915B 31
96920B 31
96925B 31
96930B 31
96935B 31
96940B 31
69
®
CROSS REFERENCE
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
01820 GL200 126-S LNS200G GL600D LG406 556 1248 GL-200
01905B DLN1 101DC LN50 L100D 501 LN201 241
01907B DLN2 102DC LN75 L200D 502 LN202 242
01910B DLN3 103DC LN100 L300D 503 LN203 243
01912B DLN4 104DC LN125 L400D 504 LG406 244
01915B DLN5 105DC LN150 L500D 505 LN205 245
01920B DLN6 106DC LN200 L600D 506 LN206 246
01925B DLN7 107DC LN250 L700D 507 LN207 247
01930B DLN8 108DC LN300 L800D 508 LN208 248
01935B DLN9 109DC LN350 L900D 509 LN209 249
01940B DLN10 110DC LN400 L1000D 510 LN210 250
02005B L20 225DC 92T050 2702
02007B 226DC 92T075 2703
02105B 820 250DC2 L21 TC601 601 TC211SC 651 2802 260 650DC
02107B 821 251DC2 L23 TC602 602 TC212SC 652 2803 261 651DC
02110B 822 252DC2 L25 TC603 603 TC213SC 653 2804 262 652DC
02112B 823 253DC2 L27 TC604 604 TC214SC 654 2805 263 653DC
02115B 824 254DC2 L29 TC605 605 TC215SC 655 2806 264 654DC
02120B 825 255DC2 L31 TC606 606 TC216SC 656 2808 265 655DC
02125B 826 256DC2 L33 TC607 607 TC217SC 657 2840 266 656DC
02130B 827 257DC2 L35 TC608 608 TC218SC 658 2842 267 657DC
02135B 828 258DC2 L37 TC609 609 TC219SC 659 2844 268 658DC
02140B 829 259DC2 L39 TC610 610 TK2110SC 660 2846 269 659DC
02205B 830 260DC L22 TC611 611 TK211SC 661 2822 320 660DC
02207B 831 261DC L24 TC612 612 TK212SC 662 2823 321 661DC
02210B 832 262DC L26 TC613 613 TK213SC 663 2824 322 662DC
02212B 833 263DC L28 TC614 614 TK214SC 664 2825 323 663DC
02215B 834 264DC L30 TC615 615 TK215SC 665 2826 324 664DC
02220B 835 265DC L32 TC616 616 TK216SC 666 2828 325 665DC
02225B 836 266DC L34 TC617 617 TK217SC 667 2870 326 666DC
02230B 837 267DC L36 TC618 618 TK218SC 668 2872 327 667DC
02235B 838 268DC L38 TC619 619 TK219SC 667 2874 328 668DC
02240B 839 269DC L40 TC620 620 TK2110SC 670 2876 329 669DC
02705B TC921 161 300-90
02707B 162 301-90
02805B 270-DC2
02807B
02905B 211 TWL50 TC911SC 431 260-90
02907B 213 TWL75 TC912SC 432 261-90
02910 433
03705B 890 1620DC2 L37-1 TN50 TO221 771 1762 300-0C 2400
03707B 891 1621DC2 L37-2 TN75 TO222 772 1763 301-0C 2401
03905 TO211SC 781 1952
03907 TO212 782 1953
04005B 6A2 1520DC L40-1 RN50 661 HO221 111 1452 830 300DC
04007B 6A3 1521DC L40-2 RN75 662 HO222 112 1453 831 301DC
04010B 6A4 1522DC L40-3 RN100 663 HO223 113 1454 832 302DC
04012B 6A5 1523DC L40-4 RN125 664 HO224 114 1455 833 303DC
04015B 6A6 1524DC L40-5 RN150 665 HO225 115 1456 834 304
04020B 6A7 1525DC L40-6 RN200 666 HO226 116 1458 835 305
04025B 6A8 117 836
04030B 6A9 118 837
04203B L42 403DC2 L42 SC38 730 XC269 150 2191 220 707DC
04203NB 403DCS
04205B L421 407DC2 L42-1 SC50 731 XC270 151 2192 222 708DC
04205NB
04207B L422 408DC2 L42-2 SC75 732 XC272 152 2193 223 709DC
04210B L423 410DC2 L42-3 SC100 733 XC273 153 2194 225 710DC
04212B L424 412DC2 L42-4 SC125 734 XC274 154 2195 226 711DC
04215B L425 414DC2 L42-5 SC150 735 XC275 155 2196 227 712DC
04220B L426 416DC2 L42-6 SC200 736 XC276 156 2198 228 713DC
04225B L427 417DC2 L42-7 SC250 737 XC227 157 229 714DC
70
CROSS REFERENCE
CROSS REFERENCE
TM
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
04230B L428 418DC2 L42-8 SC300 738 XC278 158 230 715DC
04235B L429 419DC2 L42-9 SC350 739 XC278A 159 231 721DC
04240B L4210 420DC2 L42-10 SC400 740 XC2710 160 232 722DC
04403B GF38 519DC2 L44 GC38 671 XC240 450 2281 939 770DC
04403NB GF38ST 519DCS
04405B GF50 520DC2 L44-1 GC50 672 XC241 451 2282 940 771DC
04405NB GF50ST 520DCS
04407B GF75 521DC2 L44-2 GC75 673 XC242 452 2283 941 772DC
04410B GF100 522DC2 L44-3 GC100 674 XC243 453 2284 942 773DC
04412B GF125 523DC2 L44-4 GC125 675 XC244 454 943 774DC
04415B GF150 524DC2 L44-5 GC150 681 XC245 455 944 775DC
04420B GF200 525DC2 L44-6 GC200 682 XC246 456 945 776DC
04505B GFC50 530DC L45-1 GX50 676 XK241 461 2272 940-CPL 791DC
04507B GFC75 531DC L45-2 GX75 677 XK242 462 2273 941-CPL 792DC
04510 GFC100 532DC L45-3 GX100 678 XK243 463 942-CPL 793DC
04512 GFC125 533DC L45-4 GX125 679 XK244 464 943-CPL 794DC
04515 GFC150 534DC L45-5 GX150 685 XK245 465 944-CPL 795DC
04520 GCF200 535DC L45-6 GX200 686 XK246 466 945-CPL 796DC
04805B L48 507DC2 L48-1 FC5501 654 XC221 121 2632 938
04807B L49 508DC2 L48-2 655 121A
04905B GF861 581DC L49-1 EGC50 1611 TX201 131 1482
04907B GF862 582DC L49-2 EGC75 1612 TX202 132 1483
04910 GF863 583DC L49-3 EGC100 1613 1484
05103B 841 650DC2 L51 C500 6623 NC301 120 2711 135 759DC
05103NB 841ST 650DCS
05107B 842 660DC2 L104 C750 6624 NC-302 952 2863, 2853 105R 2631
05107NB 842ST
05110B 843 662DC2 L106 C1001R 6625 NC-303 143R 2864, 2854 106R 2632
05112B 844 664DC2 L106 C1251R 6626 144R 2855 107R 2633
05115B 848 665DC2 L107 C1501R 6627 145R 2856 108R 2670
05120B 849 666DC2 L108 C2001R 6628 146R 2858 109R 2671
05205B 460 201DC CB50 ZB-100 631 BU201 301 351
05207B 461 202DC CB75 ZB-200 632 BU202 302 352
05210B 462 203DC CB100 ZB-300 633 BU203 303 353
05212B 463 204DC CB125 ZB-400 BU204 304 354
05215B 464 205DC CB150 ZB500 BU205 305 355
05220B 465 206DC CB200 ZB600 BU206 306 356
05225B 466 207DC CB250 ZB700 BU207 307 357
05230B 467 208DC CB300 ZB800 BU208 308 358
05235B 468 209DC CB350 ZB900 BU209 309 359
05240B 469 210DC CB400 ZB1000 BU210 310 360
05312B 674DC2 L-1106 C1250 6626 NC041 954 2855 2633
05315B 675DC2 L-1107 C1500 6627 NC051 955 2856 108 2670
05320B 676DC2 L-1108 C2000 6628 NC061 956 2858 109 2671
05703B 8400 565DC2 L57 C510 623 XC280 140 2661 135-C
05703NB 8400ST 565DCS
05803B 845 501DC2 L58 C550 653 XC220 130 2511 130
05803NB 845ST 845SP
06305B
06307B
06605B UF50 761UF LWC-05014 UF50 6601 UF201 871 2462 UF-50
06607B UF75 762UF LWC-07514 UF 75 6602 UF202 872 UF-75
06703B L16 560DC2 L67 TA38 8841 XC2200C 170 132
06703NB L16ST 560DCS
06805B
06807B
07005B 501 1102DC L701 CNN100 791 HA201 751 1662 332 50D
07007B 502 1103DC L702 CNN200 792 HA202 752 1663 333 51D
07010B 503 1104DC L703 CNN300 793 HA203 753 1664 334 52D
07012B 504 1105DC L704 CNN400 794 HA204 754 1665 335 53D
07015B 505 1106DC L705 CNN500 795 HA205 755 1666 54D
07020B 506 1107DC L706 CNN600 796 HA206 756 1668 55D
71
®
CROSS REFERENCE
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
07025B 507 1108DC L707 CNN700 797 HA207 757 1670 56D
07030B 508 1109DC L708 CNN800 798 HA208 758 1672 57D
07035B 509 1110DC L709 CNN900 799 HA209 759 1674 58D
07040B 510 1111DC L710 CNN1000 800 HA210 760 1676 59D
07210 WC1006 763-6 LWC1006 WC1006 6632 WT203B 873A 2474 17CH
07310B WC1004 763-4 LWC1004 WC1004 6633 WT203C 873B 17DH
08112B WC1253 764-3 LWC1253 WC1253 6643 WT204A 874 2485 18A
08212B WC1252 764-2 LWC1252 WC1252 6641 WT204B 874A 2475 18B
08312 WC1252N 764-2N LWC1252N WC1252N 6642 WT204C 874B
09115B WC1501 LWC1501 WC1501 6651 WT205A 875 152A
09215 WC1502 765-2 LWC1502 WC1502 6652 WT205B 875A 2486 152B
10220B WC2002 766-2 LWC2002 WC2002 6661 WT206A 876A 2448 153A
10420B WC2004 766-4 LWC2004 WC2004 6663 WT206D 876C 2468 153C
10520B WC2004N 766-4N LWC2004N WC2004N 6664 WT206E 876D 2478 153C-N
11003B 850 801DC2 L110 AC90 643 XC290 100 2691 40 724DC
11003NB 850ST 801DCS
11005B 851 804DC2 L110-1 AC95 644 XC291 101 2692 41 736DC
11005NB 851ST
11007B 852 806DC2 L110-2 AC96 645 XC292 102 2693 42 738DC
11010B 853 807DC2 L110-3 AC97 6463 XC293 103 2694 43 739DC
11012B 854 808DC2 L-110-4 AC98 6464 XC294 104 2695 44 740DC
11015B 855 809DC2 L110-5 AC985 6465 XC295 105 2696 45 741DC
11020B 856 810DC2 L110-6 AC99 6466 XC296 106 2698 46 742DC
11025B 857 811DC2 L110-7 AC250D 6467 XC297 107 744DC
11030B 858 812DC2 L110-8 AC300D 6468 XC298 108 745DC
11035B 859 L110-9 AC350D 6469 XC299 109 746DC
11040B 8510 L110-10 AC400D 6470 XC2910 110 747DC
12105B 800 230DC2 L121 TC501 701 TC221SC 631 2602 300 450DC
12107B 801 231DC2 L123 TC502 702 TC222SC 632 2603 301 451DC
12110B 802 232DC2 L125 TC503 703 TC223SC 633 2604 302 452DC
12112B 803 233DC2 L127 TC504 704 TC224SC 634 2605 303 453DC
12115B 804 234DC2 L129 TC505 705 TC225SC 635 2606 304 454DC
12120B 805 235DC2 L131 TC506 706 TC226SC 636 2608 305 455DC
12125B 806 236DC2 L133 TC507 707 TC227SC 637 2640 306 456DC
12130B 807 237DC2 L135 TC508 708 TC228SC 638 2642 307 457DC
12135B 8075 238DC2 L137 TC509 709 TC229SC 639 2644 308 458DC
12140B 808 239DC2 L139 TC510 710 TC2210SC 640 2646 309 459DC
12205B 810 240DC L122 TC511 711 TK221 641 2622 310 460DC
12207B 811 241DC L124 TC512 712 TK222 642 2623 311 461DC
12210B 812 242DC L126 TC513 713 TK223 643 2624 312 462DC
12212B 813 243DC L128 TC514 714 TK224 644 2625 313 463DC
12215B 814 244DC L130 TC515 715 TK225 645 2626 314 464DC
12220B 815 245DC L132 TC516 716 TK226 646 2628 315 465DC
12225B 816 246DC L134 TC517 717 TK227 647 2670 316 466DC
12230B 817 247DC L136 TC518 718 TK228 648 2672 317 467DC
12235B 8175 248DC L138 TC519 719 TK229 649 2674 318 468DC
12240B 818 249DC L140 TC520 720 TK2210 650 2676 319 469DC
13205B 522 1161 LRB2 RB2 8401 RB121 RB2 1142 RB75-50 251
13305B 523 1162 LRB3 RB3 8402 RB131 RB3 1143 RB100-50 252
13307B 524 1163 LRB4 RB4 8403 RB132 RB4 1144 RB100-75 260
13405B 525 1164 LRB5 RB5 8404 RB141 RB5 1145 RB125-50 253
13407B 526 1165 LRB6 RB6 8405 RB142 RB6 1146 RB125-75 261
13410B 527 1166 LRB7 RB7 8406 RB143 RB7 1147 RB125-100 268
13505B 528 1167 LRB8 RB8 8407 RB151 RB8 1148 RB150-50 254
13507B 529 1168 LRB9 RB9 8408 RB152 RB9 1149 RB150-75 262
13510 530 1169 LRB10 RB10 8409 RB153 RB10 1150 RB150-100 269
13512 531 1170 LRB11 RB11 8410 RB154 RB11 1151 RB150-125 275
13605B 532 1171 RB12 8411 RB161 RB12 1152 RB200-50 255
13607 533 1172 RB13 8412 RB162 RB13 1153 RB200-75 263
13610 534 1173 LRB14 RB14 8413 RB163 RB14 1154 RB200-100 270S
13612 535 1174 LRB15 RB15 8414 RB164 RB15 1155 RB200-125 276
13615 536 1175 LRB16 RB16 8415 RB165 RB16 1156 RB200-150 281
72
CROSS REFERENCE
CROSS REFERENCE
TM
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
13715B 1275 LRB21 RWN522 8139 RB175 RB19 RB250-150
13720 1276 1176 LRB22 RB17 8140 RB176 RB20 RB250-200 285
14205 71-DC2 L142-1
14207 72-DC2 L142-2
14305 51DC2 L143-1 9691 TL211 371 2762 650EMT 2410
14307 52DC2 L143-2 9692 TL212 372 2763 651EMT
14405 61DC L144-1 THL500 9711 TL201 381 2752 670EMT 2430
14407 62DC L144-2 THL750 9712 TL202SC 382 2753 671EMT 2431
14605 L244-1 CPL50 TL291 341 680EMT
14607 L244-2 CPL75 TL292 342 681EMT
15303B 8600 280DC L153 EFC50 520 TX210 180 685 780DC
15304B 290-S MERSS-50 391S 1432 420
15305B 861 281DC L153-1 EFC75 531 TX211 181 686 65
15306B 291-S MERSS-75 392S 1433 421
15307B 862 282DC L153-2 EFC100 532 TX212 182 687 66
15803B 846 601DC2 L158 DC5500 652 XC210 350 2611 6 2699
15803NB 846ST 601DCS
16010B 720Z 1309DC L160 GC5 8191 GC203 620Z 19Z
16110 740Z 1308DC L161 GA203 630Z 246DC
16203B LT38 429LT2 LQ1038 LMM01 5800 LT200 470 RT-38 LT38DC
16205B LT50 430LT2 LQ1050 LMM11 5801 LT201 471 3402 RT-50 LT50DC
16207B LT75 431LT2 LQA1075 LMM21 5802 LT202 472 RT-75 LT75DC
16210B LT100 432LT2 LQ1100 LMM31 5803 LT203 473 RT-100 LT100DC
16212B LT125 433LT2 LQ1125 LMM41 5804 LT204 474 RT-125 LT125DC
16215B LT150 434LT2 LQ1150 LMM51 5805 LT205 475 RT-150 LT150DC
16220B LT200 435LT2 LQ1200 LMM61 5806 LT206 476 RT-200 LT200DC
16310 WH3 153DC LWH-100 CHM100DT 403 H100SC 203 1704 WH-3 ST-3
16312 WH4 154DC LWH-125 CHM125DT 404 H125SC 204 1705 WH-4 ST-4
16315 WH5 155DC LWH-150 CHM150DT 405 H150SC 205 1706 WH-5 ST-5
16320 WH6 156DC LWH-200 CHM200DT 406 H200SC 206 1708 WH-6 ST-6
16325B WH7 157DC LWH-250 CHM250DT 407 H250SC 207 1710 WH-7 ST-7
16330B WH8 158DC LWH-300 CHM300DT 408 H300SC 208 1712 WH-8 ST-8
16335B WH9 159DC LWH-350 CHM350DT 409 H350SC 209 1714 WH-9 ST-9
16340B WH10 160DC LWH-400 CHM400DT 410 H400SC 210 1716 WH-10 ST-10
16405B 260 1191DC2 L64-1 781 BS201 141 BC-500 5050
16407B 1192DC2 141A
16811B 780-32
16812B 780-42
16813B 780-52
16821B 781-42
16822B 781-52
16823B 781-62
16903B LT9038 469LT2 LQ9038 LML01 5840 LT290 490 RT-90-38 LT3890DC
16905B LT9050 470LT2 LQ9050 LML11 5841 LT291 491 RT-90-50 LT5090DC
16907B LT9075 471LT2 LQ9075 LML21 5842 LT292 492 RT-90-75 LT7590DC
16910B LT90100 472LT2 LQ9100 LML31 5843 LT293 493 RT-90-100 LT-
10090DC
16911B 770-32 SRA350 881
16912B 770-42 SRA450 881A
16913B 770-52 SRA560 881B
16914B LT90125 473LT2 LQ9125 LML41 5844 LT294 494 RT-90-125 LT-
12590DC
16915B LT90150 474LT2 LQ9150 LML51 5845 LT295 495 RT-90-150 LT-
15090DC
16920B LT90200 475LT2 LQ9200 LML61 5846 LT296 496 RT-90-200 LT-
20090DC
16921B 771-42 SRB450 882
16922B 771-52 SRB560 882A
16923B 771-62 SRB650 882B
16930B 772-22
16932 772-32 883A
16933B CG100750 772-42 SRC750 883B
16934B CG100875 772-52 SRC850 883C
19005 2500 140-1 HL201SC 91 780-DC
73
®
CROSS REFERENCE
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
19007 2501 140-2 HL202SC 781-DC
19205B
19207B
25716B
26212 162 GWS-4
26214 311 164 MS4 GWS-8 566
27209 20W-1
27259 SB130 9882 ESGIBP SB1216SC
27309 30W-50
27938 CS20 BAG NMWH43 CG4
30202B
30204B
30206B
30208B
30210B
30214B
30216B
30218B
30220B
30230B
31205B 3100 901 801 TWCL-50MN HS401 561 1302 162 516
31207B 3101 902 802 TWCL-75MN HS402 562 1303 163 517
31910B A100SP ASB-1/0 SW7 796 SB-1/0-SP
31920B A200SP ASB-2/0 SW8 797 SB-2/0-SP
31930B A300SP ASB-3/0 SW9A 798 SB-3/0-SP
31940B A250SP ASB-4/0 SW10 799 SB-4/0-
250-SP
32002B A2SP ASB-2 SW6 795 SB-2-SP
32003B ASB-3 SW5 794 SB-3-SP
32004B A4SP ASB-4 SW4 793 SB-4-SP
32006B A6SP ASB-6 SW3 792 SB-6-SP
32008B A8SP ASB-8 SW2 791 SB-8-SP
32310B A100 SB-1/0 S1/0 696 SB-1/0
32320B A200 SB-2/0 S2/0 697 SB-2/0
32330B A300 SB-3/0 S3/0 698 SB-3/0
32340B A250 SB-4/0 S4/0-250 699 SB-4/0-250
32402B A2 SB-2 S2 695 SB-2
32403B A3 SB-3 S3 694 SB-3
32404B A4 SB-4 S4 693 SB-4
32406B A6 SB-6 S6 692 SB-6
32408B A8 SB-8 S8 691 SB-8
32510B SLU125 CLU125 SL-125 824 SLU-125
32530B SL-175 825 SLU-175
32540B SL-225 826 SLU-225
32602B SLU70 CLU70 SL-709 823 SLU-70
32606B CLU35 SL-35 821 SLU-35
32609B SLU35 SL-25 820 SLU-25
32999 GS1 8213 GS1 M-1
33205B CB1 941 1170 CB201 481 1342 282 CB1
33207B CB2 942 1171 CB202 482 1343 283 CB2
33520 2350 998
33525 2850 998
35600B MBC25 951 26 BC260 510 122 2524 902 529
35610B MBC27 953 27 502 123 2538 903L 533
35905B 780 GRC50 GRC1 RC500 8215 411 52B
35906B 781 GRC63 GRC2 RC625 8216 412 53B
35907 782 GRC75 GRC3 RC750 8217 413 54B
35999B
36010B 720B 1309B L160B GC1 8168 GC003 626A 2504 19B
36019 720DB DB1309 L160-DB GC1DB 8176 620DB B19B
36020B 721B 1313B L180-2B GC2 8169 626B 2505 59B
36029 8175 B59B
36110 740B 1308B 8172 630B 39B
74
CROSS REFERENCE
CROSS REFERENCE
TM
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
36210 730B 1325B L162-B 8178 621 2512 7C
36310 1325BH L160-1BH 8241
36320 1330BH L160-2BH 8242
36910B 717DB RB-16
39205B
39207B
39210B
39215B
39220B
39230B
39240B
39305B
39307B
39310B
39312B
39315B
39320B
39325B
39330B
39335B
39340B
39405B
39407B
39410B
39412B
39415B
39420B
39425B
39430B
39435B
39440B
39605B
39607B
39610B
39612B
39615B
39620B
39625B
39630B
39635B
39640B
39805B
39807B
39810B
39812B
39815B
39820B
39825B
39830B
39835B
39840B
39905B
39907B
39910B
39912B
39915B
39920B
39925B
39930B
39935B
39940B
46319 GSP
75
®
CROSS REFERENCE
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
50507 SP360 591
50599 PVC85 937-C 1900 1
50610 SP362 593
50612 SP363 594 192
50615 SP364
50699 663
50720 SP365 194
50799 664 ME14 596
50920 2200
51061 WGC-1 WC2-6 1005
51062 WGC-2 WC1/0-4 1006
51063 WGC-3 1007
51320 P26 1000
51325
53212
53220
56305 LL-41CGC LLLA-50CB LL15-MTC
56307 LL-42CGC LLLA-75CB LL25-MTC
56405 C-41CGC LCLA-50CB C15-MTC
56407 C-42CGC LCLA-75CB C25-MTC
56605 LB-41CGC LBLA-50CB LB15-MTC
56607 LB-42CGC LBLA-75CB LB25-MTC
56805 T-41CGC LTLA-50CB T15-MTC
56807 T-42CGC LTLA-75CB T25-MTC
56905 LR-41CGC LRLA-50CB LR15-MTC
56907 LR-42CGC LRLA-75CB LR25-MTC
57305B LL31 LLE-50 LL50SS 8721 BLL-1 ELL1 EBLL-1 LL-50AE LL15-MT
57307B LL32 LLE-75 LL75SS 8722 BLL-2 ELL2 EBLL-2 LL-75AE LL25-MT
57310B LL33 LLE-100 LL100SS 8723 BLL-3 ELL3 EBLL-3 LL-100AE LL35-MT
57312B LL34 LLE-125 LL125SS 8724 BLL-4 ELL4 EBLL-4 LL-125AE LL45-MT
57315B LL35 LLE-150 LL150SS 8725 BLL-5 ELL5 EBLL-5 LL-150AE LL55-MT
57320B LL36 LLE-200 LL200SS 8726 BLL-6 ELL6 EBLL-6 LL-200AE LL65-MT
57499 660 1200 90 SEC192 SC1000 707 2430 4L
57605B LB31 LBE-50 LB50SS 8701 BLB-1 ELB1 EBLB-1 LB-50AE LB15-MT
57607B LB32 LBE-75 LB75SS 8702 BLB-2 ELB2 EBLB-2 LB-75AE LB25-MT
57610B LB33 LBE-100 LB100SS 8703 BLB-3 ELB3 EBLB-3 LB-100AE LB35-MT
57612B LB34 LBE-125 LB125SS 8704 BLB-4 ELB4 EBLB-4 LB-125AE LB45-MT
57615B LB35 LBE-150 LB150SS 8705 BLB-5 ELB5 EBLB-5 LB-150AE LB55-MT
57620B LB36 LBE-200 LB200SS 8706 BLB-6 ELB6 EBLB-6 LB-200AE LB65-MT
57699 662 1221 92 SEC194 SC2001 708 2440 4XL-AL
57705B LR31 LRE-50 LR50SS 8711 BLR-1 ELR1 EBLR-1 LR-50AE LR15-MT
57707B LR32 LRE-75 LR75SS 8712 BLR-2 ELR2 EBLR-2 LR-75AE LR25-MT
57710B LR33 LRE-100 LR100SS 8713 BLR-3 ELR3 EBLR-3 LR-100AE LR35-MT
57712B LR34 LRE-125 LR125SS 8714 BLR-4 ELR4 EBLR-4 LR-125AE LR45-MT
57715B LR35 LRE-150 LR150SS 8715 BLR-5 ELR5 EBLR-5 LR-150AE LR55-MT
57720B LR36 LRE-200 LR200SS 8716 BLR-6 ELR6 EBLR-6 LR-200AE LR65-MT
57925 129 1257MT L809M 1053 706 717 EHMT4
58005 140 1251 L800CL ECO100 8661 SH101 731 2402 700 EHC-1
58007 141 1252 L801CL ECO101 8662 SH102 732 2403 701 EHC-2
58010 142 1253 L802CL ECO102 8663 SH103 733 2404 702 EHC-3
58012B 143 1254 L803CL ECO103 8664 SH104 734 2405 703 EHC-4
58015 144 1255 L804CL ECO104 8665 SH105 735 2406 704 EHC-5
58020B 145 1256 L805CL ECO105 8666 SH106 736 2408 705 EHC-6
58025 146 1257 L806CL ECO106 8667 SH107 737 2410 706 EHC-7
58030B 147 1258 L807CL ECO107 8668 SH108 738 2412 707 EHC-8
58035B 148 1259 L808CL ECO108 8669 SH109 739 2414 708 EHC-9
58040B 149 1260 L809CL ECO109 8670 SH110 740 2416 709 EHC-10
58050
58060
58070
58212B MLB-44 LBMO-125 LB6X-125A 8797 MALB-4 MLBCG4 MOLB-4
58215B MLB-45 LBMO-150 LB6X-150A 8798 MALB-5 MLBCG4 MOLB-5
76
CROSS REFERENCE
CROSS REFERENCE
TM
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
58220B MLB-46 LBMO-200 LB6X-200A 8799 MALB-6 MLBCG6 MOLB-6
58305 950LLCG LL-41CG LLLA50 LL50ACG 8821A DALL-1-CG LL1CG EALL-1CG LLC-50A LL15-CGN
58307 951LLCG LL-42CG LLLA75 LL75ACG 8822A DALL-2-CG LL2CG EALL-2CG LLC-75A LL25-CGN
58310 952LLCG LL-43CG LLLA100 LL100ACG 8823A DALL-3-CG LL3CG EALL-3CG LLC-100A LL35-CGN
58312 953LLCG LL-44CG LLLA125 LL125ACG 8824A DALL-4-CG LL4CG LLC-125A LL45-CGN
58315 954LCG LL-45CG LLLA150 LL150ACG 8825A DALL-5-CG LL5CG LLC-150A LL55-CGN
58320 955LLCG LL-46CG LLLA200 LL200ACG 8826A DALL-6-CG LL6CG LLC-200A LL65-CGN
58325B LL-47CG LLLA250 LL250ACG DALL-7-CG LL7CG LL75-CGN
58330B LL-48CG LLLA300 LL300ACG DALL-8-CG LL8CG LL85-CGN
58335B LL-49CG LLLA350 LL350ACG DALL-9-CG LL9CG LL95-CGN
58340B LL-50CG LLLA400 LL400ACG DALL-10-CG LL10CG LL105-CGN
58405 970CCG C-41CG LCLA50 C50ACG 8831A DAC-1-CG C1CG EAC-1CG CC-50A C15-CGN
58407 971CCG C-42CG LCLA75 C75ACG 8832A DAC-2-CG C2CG EAC-2CG CC-75A C25-CGN
58410 972CCG C-43CG LCLA100 C100ACG 8833A DAC-3-CG C3CG EAC-3CG CC-100A C35-CGN
58412 973CCG C-44CG LCLA125 C125ACG 8834A DAC-4-CG C4CG CC-125A C45-CGN
58415 974CCG C-45CG LCLA150 C150ACG 8835A DAC-5-CG C5CG CC-150A C55-CGN
58420 975CCG C-46CG LCLA200 C200ACG 8836A DAC-6-CG C6CG CC-200A C65-CGN
58425B C-47CG LCLA250 C250ACG DAC-7-CG C7CG C75-CGN
58430B C-48CG LCLA300 C300ACG DAC-8-CG C8CG C85-CGN
58435B C-49CG LCLA350 C350ACG DAC-9-CG C9CG C95-CGN
58440B C-50CG LCLA400 C400ACG DAC-10-CG C10CG C105-CGN
58525B
58530B
58605 930LBCG LB-41CG LBLA50 LB50ACG 8801A DALB-1-CG LB1CG EALB-1CG LBC-50A LB15-CGN
58607 931LBCG LB-42CG LBLA75 LB75ACG 8802A DALB-2-CG LB2CG EALB-2CG LBC-75A LB25-CGN
58610 932LBCG LB-43CG LBLA100 LB100ACG 8803A DALB-3-CG LB3CG EALB-3CG LBC-100A LB35-CGN
58612 933LBCG LB-44CG LBLA125 LB125ACG 8804A DALB-4-CG LB4CG EALB-4CG LBC-125A LB45-CGN
58615 934LBCG LB-45CG LBLA150 LB150ACG 8805A DALB-5-CG LB5CG EALB-5CG LBC-150A LB55-CGN
58620 935LBCG LB-46CG LBLA200 LB200ACG 8806A DALB-6-CG LB6CG EALB-6CG LBC-200A LB65-CGN
58625 936LBCG LB-47CG LBLA250 LB250ACG DALB-7-CG LB7CG LBC-250A LB75-CGN
58630B 937LBCG LB-48CG LBLA300 LB300ACG DALB-8-CG LB8CG LBC-300A LB85-CGN
58635B 938LBCG LB-49CG LBLA350 LB350ACG DALB-9-CG LB9CG LBC-350A LB95-CGN
58640B 939LBCG LB-50CG LBLA400 LB400ACG DALB-10-CG LB10CG LBC-400A LB105-CGN
58705 LB-31 LBELA-50 DBLB-1-C EBLB-1CG LB15-MTC
58707 LB-32 LBELA-75 DBLB-2-C EBLB-2CG LB25-MTC
58710B LB-33 LBELA-100 DBLB-3-C EBLB-3CG LB35-MTC
58725B LB-37 BLB-7 LB75-MTC
58805 T-41CG LTLA50 T50ACG 8841A DAT-1-CG T1CG EAT-1CG TC-50A T15-CGN
58807 T-42CG LTLA75 T75ACG 8842A DAT-2-CG T2CG EAT-2CG TC-75A 725-CGN
58810 942TCG T-43CG LTLA100 T100ACG 8843A DAT-3-CG T3CG EAT-3CG TC-100A T35-CGN
58812 943TCG T-44CG LTLA125 T125ACG 8844A DAT-4-CG T4CG EAT-4CG TC-125A T45-CGN
58815 944TCG T-45CG LTLA150 T150ACG 8845A DAT-5-CG T5CG EAT-5CG TC-150A T55-CGN
58820 945TCG T-46CG LTLA200 T200ACG 8846A DAT-6-CG T6CG EAT-6CG TC-200A T65-CGN
58825B T-47CG LTLA250 T250ACG DAT-7-CG T7CG T75-CGN
58830B T-48CG LTLA300 T300ACG DAT-8-CG T8CG T85-CGN
58835B T-49CG LTLA350 T350ACG DAT-9-CG 79CG T95-CGN
58840B T-50CG LTLA400 T400ACG DAT-10-CG T10CG T105-CGN
58905 960LRCG LR-41CG LRLA50 LR50ACG 8811A DALR-1-CG LR1CG EALR-1CG LRC-50A LR15-CGN
58907 961LRCG LR-42CG LRLA75 LR75ACG 8812A DALR-2-CG LR2CG EALR-2CG LRC-75A LR25-CGN
58910 962LRCG LR-43CG LRLA100 LR100ACG 8813A DALR-3-CG LR3CG EALR-3CG LRC-100A LR35-CGN
58912 963LRCG LR-44CG LRLA125 LR125ACG 8814A DALR-4-CG LR4CG LRC-125A LR45-CGN
58915 964LRCG LR-45CG LRLA150 LR150ACG 8815A DALR-5-CG LR5CG LRC-150A LR55-CGN
58920 965LRCG LR-46CG LRLA200 LR200ACG 8816A DALR-6-CG LR6CG LRC-200A LR65-CGN
58925B LR-47CG LRLA250 LR250ACG DALR-7-CG LR7CG LR75-CGN
58930B LR-48CG LRLA300 LR300ACG DALR-8-CG LR8CG LR85-CGN
58935B LR-49CG LRLA350 LR350ACG DALR-9-CG LR9CG LR-95-
CGN
58940B LR-50CG LRLA400 LR400ACG DALR-10-
CG LR10CG LR105-
CGN
59105B 990 SG61 LF50 FG50 8871 GKV1 581 EGKV-1 VG-50 GASK015
59105NB
59107B 991 SG62 LF75 FG75 8872 GKV2 582 EGKV-2 VG-75 GASK025
59107NB
77
®
CROSS REFERENCE
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
59110B 992 SG63 LF100 FG100 8873 GKV3 583 EGKV-3 VG-100 GASK035
59110NB
59115B 993 SG64 LF125 FG125 8874 GKV4 584 EGKV-4 VG125 GASK045
59115NB
59120B 994 SG66 LF200 FG200 8876 GKV5 585 EGKV-5 VG-200 GASK065
59120NB
59130B SG67 LF250 FG250 8857 GKN6 EGKN-6 VG-250 GASK085N
59140B SG69 LF350 FG400 8859 GKN7 EGKN-7 VG-350 GASK095N
59205B 980 SC41 LA50 BS50A 8861 SCV1 571 ESCV-1 AC-50 150
59207B 981 SC42 LA75 BS75A 8862 SCV2 572 ESCV-2 AC-75 250
59210B 982 SC43 LA100 BS100A 8863 SCV3 573 ESCV-3 AC-100 350
59215B 983 SC44 LA125 BS125A 8864 SCV4 574 ESCV-4 AC-125 450
59220B 984 SC46 LA200 BS200A 8866 SCV5 575 ESCV-5 AC-200 650
59230B SC47 LA250 BS250A 8867 SCV6 577 ESCV-6 AC-250 8500
59240B SC49 LA350 BS350A 8869 SCV7 579 ESCV-7 AC-350 9500
59405B C-41 LC50 C50A 8831 AC-1-RD C1 EAC-1 C-50A C15
59505 920SLB 1025 L900 SLB50 8771 ASLB1 211 EASLB-
1CG 730 SLB1
59507 921SLB 1026 L901 SLB75 8772 ASLB2 212 EASLB-
2CG 731 SLB2
59510 922SLB 1027 L902 SLB100 8773 ASLB3 213 EASLB-
3CG 732 SLB3
59512 923SLB 1028 L903 SLB125 8774 ASLB4 214 EASLB-
4CG 733 SLB4
59515 924SLB 1029 L904 SLB150 8775 ASLB5 215 EASLB-
5CG 734 SLB5
59520 925SLB 1030 L905 SLB200 8776 ASLB6 216 EASLB-
6CG 735 SLB6
59605B 930LB LB41 LB50 LB50 8801 ALB-1 LB1 EALB-1 LB-50A LB15
59607B 931LB LB42 LB75 LB75 8802 ALB-2 LB2 EALB-2 LB-75A LB25
59610B 932LB LB43 LB100 LB100 8803 ALB-3 LB3 EALB-3 LB-100A LB35
59612B 933LB LB44 LB125 LB125 8804 ALB-4 LB4 EALB-4 LB-125A LB45
59615B 934LB LB45 LB150 LB150 8805 ALB-5 LB5 EALB-5 LB-150A LB55
59620B 935LB LB46 LB200 LB200 8806 ALB-6 LB6 EALB-6 LB-200A LB65
59805B 940T T41 LT50 TC50 8841 AT-1 T1 EAT-1 T-50A T15
59807B 941T T42 LT75 TC75 8842 AT-2 T2 EAT-2 T-75A T25
59810B 942T T43 LT100 TC100 8843 AT-3 T3 EAT-3 T-100A T35
60010 JC12 701 W12 JC12S 298S JC-12
60020 W10 299B JC-10
60199 SH1 705 W11 SH100 300A SH-12
60222 616 RWH-1 P16 1402 1003 B3627
60322 612 P15 2700 1002
60416 P12 1001 B3625
60525 610 MWH-1 P18 1401 999 AWH-300
60625
60705B 900 1691 150 KO50 8971 BL111 KO50 1042 20 337
60707B 901 1692 151 KO75 8972 BL112 KO51 1043 21 338
60710B 902 1693 152 KO100 8973 BL113 K052 1044 22 337
60712 903 1694 153 KO125 8974 BL114 KO53 1045 23 338
60715 904 1695 154 KO150 8975 BL115 KO54 1046 24 339
60720 905 1696 155 KO200 8976 BL116 KO55 1048 25 340
60795B 900 1691 150 KO50 8971 BL111 K050 1042 20 335
60797B 901 1692 151 KO75 8972 BL112 K051 1043 21 336
60812 624 RF-125 P38 NC1069 984
60820 625 RF-200 P40 NC1070 986 RF2
60825 626 RF-250 P41 1071 987 RF25
61010 ST41 30-1 SN400 183 RS10-100
61050 ST415 30-5 SN405 184 RS10-500
61105B 340 901S 701 1801 8321 HS101 531 1332 162-S 410
61107B 341 902S 702 1802 8322 HS102 532 1333 163-S 411
61110B 342 903S 703 1803 8323 HS103 533 1334 164-S 412
61112B 343 904S 704 1804 8324 HS104 534 1335 165-S 413
61115B 344 905S 705 1805 8325 HS105 535 1336 166-S 414
61120 345 906S 706 1806 8326 HS106 536 1338 167-S 415
78
CROSS REFERENCE
CROSS REFERENCE
TM
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
61125 346 907S 1707 1807 8327 HS107 517 1337 168-S 206
61130 347 908S 1708 1808 8328 HS108 518 1339 169-S 207
61135B 348 909S 1709 1809 8329 HS109 519 1340 170-S 208
61140B 349 910S 1710 1810 8330 HS110 520 1341 171-S 209
61205B 350 1901 124 TH1801 8341 HS901 541 2232 TH-162S 496-3
61207B 351 1902 125 TH1802 8342 HS902 542 2233 TH-163S 496-4
61210B 352 1903 126 TH1803 8343 HS903 543 2234 TH-164S 496-5
61212B 353 1904 127 TH1804 8344 HS904 544 2235 TH-165S 496-6
61215B 354 1905 128 TH1805 8345 HS905 545 2236 TH-166S 496-7
61220B 355 1906 129 TH1806 8346 HS906 546 2238 TH-167S 496-8
61225B 356 1907 130 TH1807 8347 HS907 527 2239 TH-168S 496-9
61230 357 1908 131 TH1808 8348 HS908 528 2240 TH-169S 496-10
61235B 358 1909 132 TH1809 8349 HS909 529 2241 TH-170S 496-11
61240B 359 1910 133 TH1810 8350 HS910 530 2242 TH-171S 496-12
61399B
61405B NS1 920NS 1600 NS901 8291 N101SC DS1 2252 NSF-1
61407B NS2 921NS 1605 NS902 8292 N102SC DS2 2253 NSF-2
61410B NS3 922NS 1615 NS903 8293 N103SC DS3 2254 NSF-3
61505B 370 920S 1701 1901 8301 TS101 511 2082 180-S 200
61507B 371 921S 1702 1902 8302 TS102 512 2083 181-S 201
61510B 372 922S 1703 1903 8303 TS103 513 2084 182-S 202
61512B 373 923S 1704 1904 8304 TS104 514 2085 183-S 203
61515B 374 924S 1705 1905 8305 TS105 515 2086 184-S 204
61520B 375 925S 1706 1906 8306 TS106 516 2088 185-S 205
61605B 360 1920 1124 TH1901 8311 TS901 521 2092 TH-180S 497-1
61607B 361 1921 1125 TH1902 8312 TS902 522 2093 TH-181S 497-2
61610B 362 1922 1126 TH1903 8313 TS903 523 2094 TH-182S 497-3
61612B 363 1923 1127 TH1904 8314 TS904 524 2095 TH-183S 497-4
61615B 364 1924 1128 TH1905 8315 TS905 525 2096 TH-184S 497-5
61620B 365 1925 1129 TH1906 8316 TS906 526 2098 TH-185S 497-6
61805B SL50 141 LNS-50-I LS100 801-S LS101 711 1202 201SL SL1
61807B SL75 142 LNS-75-I LS200 802-S LS102 712 1203 202SL SL2
61810B SL100 143 LNS-100-I LS300 803-S LN103 713 1204 203SL SL3
61812B SL125 144 LNS-125-I LS400 804-S LS104 714 1205 204SL SL4
61815B SL150 145 LNS-150-I LS500 805-S LS105 715 1206 205SL SL5
61820B SL200 146 LNS-200-I LS600 806-S LS106 716 1208 206SL SL6
61905B 401 101 LNS-50 L100 801 LN101SC 281 1192 201 11X
61907B 402 102 LNS-75 L200 802 LN102 282 1193 202 12X
61910B 403 103 LNS-100 L300 803 LN103 283 1194 203 13X
61912B 404 104 LNS-125 L400 804 LN104 284 1195 204 14X
61915B 405 105 LNS-150 L500 805 LN105 285 1196 205 15X
61920B 406 106 LNS-200 L600 806 LN106 286 1198 206 16X
61925B 407 107 LNS-250 L700 807 LN107 287 1197 207 17X
61930B 408 108 LNS-300 L800 808 LN108 288 1199 208 18X
61935B 409 109 LNS-350 L900 809 LN109 289 1200 209 19X
61940B 410 110 LNS-400 L1000 810 LN110 290 1201 210 20X
62171B 370 134-1 510RX 188A
62181B 310 890-MC 699 BX50 8300 510BX BX-50
62191B 301 881-SE 261 1704 8273 SE100 501 2441 188C 3-8S,
3-6S,3-4S
62192B 303 882-SE 262 1702 8274 SE101 502 2442 188D 3-2S
62193B 313S 883-SE 263 1710 8275 SE102 503 2443 188E 3-10S,
3-20S
62194B 314S 884-SE 264 1740 8276 SE103 504 2444 188F 3-30S,
3-40S
62291B C STRAP 1881-SE 220 8283 SE900 506 TH-188C
62292B E STRAP 1882-SE 221 8284 SE901 507 TH-188D
62293B H STRAP 1883-SE 222 8285 SE902 508 TH-188E
62294B K STRAP 1884-SE 223 8286 SE903 509 TH-188F
62305B 250 MEC-750 7050S 7601 TC111A 651S 2902 260ST 650S
62307B 251 MEC-751 7075S 7602 TC112A 652S 2903 261ST 651S
62310B 252 MEC-752 7100S 7603 TC113A 653S 2904 262ST 652
79
®
CROSS REFERENCE
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
62312B 253 MEC-753 7125S 7604 TC114A 654S 2905 263ST 653
62315B 254 MEC-754 7150S 7605 TC115A 655S 2906 264ST 654
62320B 255 MEC-755 7200S 7606 TC116A 656S 2908 265ST 655
62325B 256 MEC-756 7250S 7607 TC117A 657S 2940 266ST 656
62330B 257 MEC-757 7300S 7608 TC118A 658S 2942 267ST 657
62335B 258 MEC-758 7350S 7609 TC119A 659S 2944 268ST 658
62340B 259 MEC-759 7400S 7610 TC1110A 660S 2946 269ST 659
62405B 260 MEC-760 6050S 7611 TK111A 661S 2922 320ST 660S
62407B 261 MEC-761 6075S 7612 TK112A 662S 2923 321ST 661S
62410B 262 MEC-762 6100S 7613 TK113A 663S 2924 322ST 662
62412B 263 MEC-763 6125S 7614 TK114A 664S 2925 323ST 663
62415B 264 MEC-764 6150S 7615 TK115A 665S 2926 324ST 664
62420B 265 MEC-765 6200S 7616 TK116A 666S 2928 325ST 665
62425B 266 MEC-766 6250S 7617 TK117A 667S 2950 326ST 666
62430B 267 MEC-767 6300S 7618 TK118A 668S 2952 327ST 667
62435B 268 MEC-768 6350S 7619 TK119A 669S 2954 328ST 668
62440B 269 MEC-769 6400S 7620 TK1110A 670S 2956 329ST 669
62505B 820RT 250SRT MECR-750 7050SR TC111A-RT 2902 650RT
62507B 821RT 251SRT MECR-751 7075SR TC112A-RT 2903 651RT
62510 ST45 31-1 SN1000 193 RS25-100
62510B 822RT 252SRT MECR-752 7100SR TC113A-RT 2904RT 652RT
62512B 823RT 253SRT MECR-753 7125SR TC114A-RT 2905RT 653RT
62515B 824RT 254SRT MECR-754 7150SR TC115A-RT 2906RT 654RT
62520B 825RT 255SRT MECR-755 7200SR TC116A-RT 2908RT 655RT
62525B 826RT 256SRT MECR-756 7250SR TC117A-RT 2940RT 656RT
62530B 827RT 257SRT MECR-757 7300SR TC118A-RT 2942RT 657RT
62535B 828RT 258SRT MECR-758 7350SR TC119A-RT 2944RT
62540B 829RT 259SRT MECR-759 7400SR TC1110A-
RT 2946RT
62550 ST455 31-5 SN1050 194 RS25-500
62605B 830RT 260SRT MECR-760 6050SR TK111A-RT 2922RT 660RT
62607B 831RT 261SRT MECR-761 6075SR TK112A-RT 2923RT 661RT
62610B 832RT 262SRT MECR-762 6100SR TK113A-RT 2924RT 662RT
62612B 833RT 263SRT MECR-763 6125SR TK114A-RT 2925RT 663RT
62615B 834RT 264SRT MECR-764 6150SR TK115A-RT 2926RT 664RT
62620B 835RT 265SRT MECR-765 6200SR TK116A-RT 2928RT 665RT
62625B 836RT 266SRT MECR-766 6250SR TK117A-RT 2950RT 666RT
62630B 837RT 267SRT MECR-767 6300SR TK118A-RT 2952RT 667RT
62635B 838RT 268SRT MECR-768 6350SR TK119A-RT 2954RT
62640B 839RT 269SRT MECR-769 6400SR TK1110A-
RT 2956RT
62700B SBS 722 102 HI102 199 150
62705B 230 MES-750 4050S 7701 TC121A 631S 2002 300ST 450S
62707B 231 MES-751 4075S 7702 TC122A 632S 2003 301ST 451
62710B 232 MES-752 4100S 7703 TC123A 633S 2004 302ST 452
62712B 233 MES-753 4125S 7704 TC124A 634S 2005 303ST 453
62715B 234 MES-754 4150S 7705 TC125A 635S 2006 304ST 454
62720B 235 MES-755 4200S 7706 TC126A 636S 2008 305ST 455
62725B 236 MES-756 4250S 7707 TC127A 637S 2140 306ST 456
62730B 237 MES-757 4300S 7708 TC128A 638S 2142 307ST 457
62735B 238 MES-758 4350S 7709 TC129A 639S 2144 308ST 458
62740B 239 MES-759 4400S 7710 TC1210A 640S 2146 309ST 459
62805B 240 MES-760 5050S 7711 TK121A 641S 2022 310ST 460
62807B 241 MES-761 5075S 7712 TK122A 642S 2023 311ST 461
62810B 242 MES-762 5100S 7713 TK123A 643S 2024 312ST 462
62812B 243 MES-763 5125S 7714 TK124A 644S 2025 313ST 463
62815B 244 MES-764 5150S 7715 TK125A 645S 2026 314ST 464
62820B 245 MES-765 5200S 7716 TK126A 646S 2028 315ST 465
62825B 246 MES-766 5250S 7717 TK127A 647S 2150 316ST 466
62830B 247 MES-767 5300S 7718 TK128A 648S 2152 317ST 467
62835B 248 MES-768 5350S 7719 TK129A 649S 2154 318ST 468
62840B 249 MES-769 5400S 7720 TK1210A 650S 2156 319ST 469
80
CROSS REFERENCE
CROSS REFERENCE
TM
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
62850 188
62899 SP100 732SP 43 SP100 8297 CP1 189 2710 KPA
63099 GC GC99 GC
63188 GSW GP
63299 48 GS
63505B 3000 MNT-2750 31-050 601 HC401 261 1802 960 CPR1
63507B 3001 MNT-2751 31-075 602 HC402 262 1803 961 CPR2
63510B 3002 MNT-2752 31-100 HC-403 263 1804 962 CPR3
63512B 3003 MNT-2753 31-125 HC-404 264 1805 963 CPR4
63515B 3004 MNT-2754 31-150 DC-405 265 1806 964 CPR5
63520B 3005 MNT-2755 31-200 HC-406 266 1808 965 CPR6
63610B 3102 MNT-2762 30-100 HK-403 253 1824 982 CPR23
63612B 3103 MNT-2763 30-125 HK-404 254 1825 983 CPR24
63615B 3104 MNT-2764 30-150 HK-405 255 1826 984 CPR25
63620B 3105 MNT-2765 30-200 HK-406 256 1828 985 CPR26
64005B RC-50 51 P105
64007B RC-75 52 P107
64010 RC-100 53 P110
64012 RC-125 54 P112
64015 RC-150 55 P115
64020 RC-200 56 P120
64025 RC-250 57 P125
64030 RC-300 58 P130
64035 RC-350 59 P135
64040 RC-400 60 P140
64105B ELR-5090 61 P1905
64107B ELR-7590 62 P1907
64110B ELR-10090 63 P1910
64112B ELR-12590 64 P1912
64115B ELR-15090 65 P1915
64120B ELR-20090 66 P1920
64125 ELR-25090 67 P1925
64130 ELR-30090 68 P1930
64135 ELR-35090 69 P1935
64140 ELR-40090 70 P1940
64205 ELR-5045 11 P1405
64207 ELR-7545 12 P1407
64210 ELR-10045 13 P1410
64212 ELR-12545 14 P1412
64215 ELR15045 15 P1415
64220 ELR20045 16 P1420
64225 ELR25045 17 P1425
64230 ELR30045 18 P1430
64235 ELR35045 19 P1435
64240 ELR40045 20 P1440
64300B N-4001200 641012 P14012
64301B N-501200 645112 P10512
64302B N-751200 645212 P10712
64303B N-1001200 645312 P11012
64305 N-50CL 6451 P10500 1500
64306B N-2001200 645612 P12012
64307 N-75CL 6452 P10700 1508
64308B N-1251200 645412 P11212
64309B N-3501200 645912 P13512
64310 N-100CL 6453 P11000 1515
64311 N-50150 6451112 P10515 1501
64312 N-125CL 6454 P11200 1522
64313 N-100200 64532 P11020 1516
64314 N-125200 64542 P11220
64315 N-150CL 6455 P11500 1529
64320 N-200CL 6456 P12000 1536
64323 N-100250 6453212 P11025
81
®
CROSS REFERENCE
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
64325 N-50200 64512 P10520 1502
64327 N-75200 64522 P10720 1509
64331 N-50300 64513 P10530 1503
64332 N-75300 64523 P10730 1510
64333 N-100300 64533 P11030 1517
64334 N-125300 64543 P11230 1524
64335 N-150300 64553 P11530 1531
64336 N-200300 64563 P12030 1538
64338B N-300300 64583 P13030 1550
64340B N-400400 64104 P14040
64341 N-50400 64514 P10540 1504
64342 N-75400 64524 P10740 1511
64343B N-100400 64534 P11040 1518
64344B N-125400 64544 P11240 1525
64345B N-150400 64554 P11540 1532
64346B N-200400 64564 P12040 1539
64347B N-250400 64574 P12540 1545
64348B N-300400 64584 P13040 1551
64349B N-350400 64594 P13540
64350B N-400500 64105 P14050
64351B N-50500 64515 P10550 1505
64352B N-75500 64525 P10750 1512
64353 N-100500 64535 P11050 1519
64354 N-125500 64545 P11250 1526
64355B N-150500 64555 P11550 1533
64356 N-200500 64565 P12050 1540
64357B N-250500 64575 P12550 1546
64358B N-300500 64585 P13050 1552
64359B N-350500 64595 P13550
64360B N-400600 64106 P14060
64361 N-50600 64516 P10560 1506
64362 N-75600 64526 P10760 1513
64363 N-100600 64536 P11060 1520
64364 N-125600 64546 P11260 1527
64365 N-150600 64556 P11560 1534
64366 N-200600 64566 P12060 1541
64367B N-250600 64576 P12560 1547
64368B N-300600 64586 P13060 1553
64369B N-350600 64596 P13560
64380B N-400800 64108 P14080
64381B N-50800 64518 P10580 1507
64382B N-75800 64528 P10780 1514
64383B N-100800 64538 P11080 1521
64384B N-125800 64548 P11280 1528
64385B N-150800 64558 P11580 1535
64386 N-200800 64568 P12080 1542
64387B N-250800 64578 P12580 1548
64388B N-300800 64588 P13080 1554
64389B N-350800 64598 P13580
64390B N-4001000 641010 P14010
64391B N-501000 645110 P10510
64392B N-751000 645210 P10710
64393B N-1001000 645310 P11010
64394B N-1251000 645410 P11210
64395B N-1501000 645510 P11510
64396B N-2001000 645610 P12010
64397B N-2501000 645710 P12510
64398B N-3001000 645810 P13010
64399B N-3501000 645910 P13510
64405B ELE-5090 81 P3905
64407B ELE-7590 82 P3907
64410B ELE-10090 83 P3910
82
CROSS REFERENCE
CROSS REFERENCE
TM
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
64412B ELE-12590 84 P3912
64415B ELE-15090 85 P3915
64420B ELE-20090 86 P3920
64425 ELE-25090 87 P3925
64430 ELE-30090 88 P3930
64435 ELE-35090 89 P3935
64440 ELE-40090 89A P3940
64505 ELE-5045 21 P3405
64507 ELE-7545 22 P3407
64510 ELE-10045 23 P3410
64512 ELE-12545 24 P3412
64515 ELE-15045 25 P3415
64520 ELE-20045 26 P3420
64525 ELE-25045 27 P3425
64530 ELE-30045 28 P3430
64535 ELE-35045 29 P3435
64540 ELE-40045 30 P3440
64605B N-1501200 645512 P11512
64607B N-2501200 645712 P12512
64608B N-3001200 645812 P13012
64615 N-150200 64552 P11520
64617B N-250CL 6457 P12500 1543
64618B N-300CL 6458 P13000 1549
64619B N-350CL 6459 P13500
64620B N-400CL 6410 P12070
64676 64565 P12070
65020
65103B BT50 642 L15 RX50 NC850 441 136
65110B BT75 643 L16 RX75 NC851 442 137
65112B BT125 644 L17 RX125 NC852 444 138
65115B BT150 645 L18 RX150 NC853 445 139
65505B 200 1121 L-500 TPC50 EK401 851 1502 370 190M
65507B 201 1122 L-501 TPC75 EK402 852 1503 371 191
65510B 202 1123 L-502 TPC100 EK403 853 1504 372 192
65512B 203 1124 L-503 TPC125 EK404 854 1505 373 193
65515B 204 1125 L-504 TPC150 EK405 855 1506 374 194
65520B 205 1126 L-505 TPC200 EK406 856 1508 375 195
65525B 206 1127 L-506 TPC250 EK407 857 1510 376 196
65530B 207 1128 L-507 TPC300 EK408 858 1512 377 197
65535B 208 1129 L-508 TPC350 EK409 859 1514 378 198
65540B 209 1130 L-509 TPC400 EK410 860 1516 379 199
65600B BC25 951S 25 BC250 BC1TB 122S 2500 902S 529-S
65705B AMC-50 MAFC-50 7750 XC731 AMC1 2800 MC-50 QLD50S
65805B AMC-52 MAFC-52 7652 AMC12 2715 MC-50D QLD50D
66203B 429-SLT MSTR-38 4QS38 LT100 3401 RT-38S LT-38
66205B 430-SLT MSTR-50 4QS50 LT101 3402 RT-50S LT-50
66206B 431-SLT MSTR-75 4QS75 LT102 3403 RT-75S LT-75
66207B
66210B 432-SLT MSTR-100 4QS100 LT103 3404 RT-100S LT-100
66211B
66212B 433-SLT MSTR-125 4QS125 LT104 3405 RT-125S LT-125
66215B 434-SLT MSTR-150 4QS150 LT105 3406 RT-150S LT-150
66220B 435-SLT MSTR-200 4QS200 LT106 3408 RT-200S LT-200
66377B
66388B
66399B
66503B 449-SLT MSTR-3845 4QS438 LT450 3441 RT-45-38S LT-3845
66505B 450-SLT MSTR-5045 4QS450 LT451 3442 RT-45-50S LT-5045
66507B 451-SLT MSTR-7545 4QS475 LT452 3443 RT-45-75S LT-7545
66510B 452-SLT MSTR-10045 4QS4100 LT453 3444 RT-45-100S LT-10045
66512B 453-SLT MSTR-12545 4QS4125 LT454 3445 RT-45-125S LT-12545
66515B 454-SLT MSTR-15045 4QS4150 LT455 3446 RT-45-150S LT-15045
83
®
CROSS REFERENCE
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
66520B 455-SLT MSTR-20045 4QS4200 LT456 3448 RT-45-200S LT-20045
66903B 469-SLT MSTR-3890 4QS938 LT490 3421 RT-90-38S LT-3890
66905B 470-SLT MSTR-5090 4QS950 LT491 3422 RT-90-50S LT-5090
66907B 471-SLT MSTR-7590 4QS975 LT492 3423 RT-90-75S LT-7590
66910B 472-SLT MSTR-10090 4QS9100 LT493 3424 RT-90-100S LT-10090
66912B 473-SLT MSTR-12590 4QS9125 LT494 3425 RT-90-125S LT-12590
66915B 474-SLT MSTR-15090 4QS9150 LT495 3426 RT-90-150S LT-15090
66920B 475-SLT MSTR-20090 4QS9200 LT496 3428 RT-90-200S LT-20090
67800B 2000 2100 0-WBA CH050B 8361H 6H0B 601 2052 H50WB 0-B
67810B 2010 2110 1-WBA CH100B 8362H 6H1B 602 2053 H75WB 1-B
67820B 2020 2120 2-WBA CH200B 8363H 6H2B 603 2054 H100WB 2-B
67825 2025 2125 2-1/2-WBA CH250B 8364H 6H2DB 604A 2041 H125AWB 2 1/2-B
67830B 2030 2130 3-WBA CH300B 8365H 6H3B 604 2055 H125WB 3-B
67840B 2040 2140 4-WBA CH400B 8366H 6H4B 605 2056 H150WB 4-B
67850B 2050 2150 5-WBA CH500B 8367H 6H5B 606 2058 H200WB 5-B
67860B 2060 2160 6-WBA CH600B 8368H 6H6B 607 2057 H250WB 6-B
67870B 2070 2170 7-WBA CH700B 8369H 6H7B 608 2059 H300WB 7-B
67880B 2080 2180 8-WBA CH800B 8370H 6H8B 609 2060 H350WB 8-B
67890B 2090 2190 9-WBA CH900B 792 6H9B 610 2061 H400WB 9-B
68205B RW1 1061 MR2 RW503 8120 WA121 900 1365 RW75-50 342
68305B RW2 1062 MR3 RW504 8121 WA131 901 1366 RW100-50 343
68307B RW3 1063 MR4 RW505 8122 WA132 902 1367 RW100-75 344
68405B RW4 1064 MR5 RW506 8123 WA141 903 1368 RW125-50 345
68407B RW5 1065 MR6 RW507 8124 WA142 904 1369 RW125-75 346
68410B RW6 1066 MR7 RW508 8125 WA143 905 1370 RW125-100 347
68505B RW7 1067 MR8 RW509 8126 WA151 906 1371 RW150-50 348
68507B RW8 1068 MR9 RW510 8127 WA152 907 1372 RW150-75 349
68510 RW9 1069 MR10 RW511 8128 WA153 908 1373 RW150-100 350S
68512B RW10 1070 MR11 RW512 8129 WA154 909 1374 RW150-125 351
68605B RW11 1071 MR12 RW513 8130 WA161 910 1375 RW200-50 352
68607B RW12 1072 MR13 RW514 8131 WA162 911 1376 RW200-75 353
68610B RW13 1073 MR14 RW515 8132 WA163 912 1377 RW200-100 354
68612B RW14 1074 MR15 RW516 8133 WA164 913 1378 RW200-125 355
68615 RW15 1075 MR16 RW517 8134 WA165 914 1379 RW200-150 356
68720 RW21 1081 MR22 523 8140 WA176 920 1383 RW250-200 365
69205RB
69207RB
69210RB
69215RB
69220RB
69230RB
69240RB
69588B SFR-75 MFHR50-75
69699B SFS-75 MFHS50-75
69900
72505B 4400 9791 170
72507B 4401 9792 171
72510B 4402 9793 172
72520B 4405 9796 175
72525 4406 9797
72599B SB130 9882 ESGI SB1216SC
72599BP SB130 9882 ESGIM SB1216SC
74505B
74507B
75005B EMT50 TWB-51
75007B EMT75 TWB-52
75010B EMT100 TWB53
75012B EMT125 TWB54
75015B EMT150 TWB55
75020B EMT200 TWB56
75101B NM841 620-NM ME-3201 NST50 9301 3300 460 4713 CCC50
75102B NM842 621-NM ME-3202 3202
84
CROSS REFERENCE
CROSS REFERENCE
TM
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
75105B NM940 619-NM 1200 NC501SC
75107B NM95 625-NM 1202 NC502SC
75205B 440 321 CPB-50 PB100 931 BU501 831 1402 501 931
75207B 441 322 CPB-75 PB200 932 BU502 832 1403 502 932
75210B 442 323 CPB-100 PB300 933 BU503 833 1404 503 933
75212B 443 324 CPB-125 PB400 934 BU504 834 1405 504 934
75215B 444 325 CPB-150 PB500 935 BU505 835 1406 505 935
75220B 445 326 CPB-200 PB600 936 BU506 836 1408 506 936
75225B 446 327 CPB-250 PB700 937 BU507 837 1410 507 937
75230B 447 328 CPB-300 PB800 938 BU508 838 1412 508 938
75235B 448 329 CPB-350 PB900 939 BU509 839 1414 509 939
75240B 449 330 CPB-400 PB1000 940 BU510 840 1416 510 940
75400 AS0 1000 3010 AS0 9310 IT100SC 0 383
75400BP AS0 1000 3010-B AS0 IT100SC 0B 383
75401 AS1 1001 3011 AS1 9311 IT101 1 384
75401BP AS1 1001 3011-B AS1 IT101 1B 384
75402 AS2 1002 3012 AS2 9312 IT102 2 385
75402BP AS2 1002 3012-B AS2 IT102 2B 385
75403 AS3 1003 3013 AS3 9313 IT103 3 386
75403BP AS3 1003 3013-B AS3 IT103 3B 386
75404 AS4 1004 3014 AS4 9314 IT104 4 387
75404BP AS4 1004 3014-B AS4 IT104 4B 387
75803B 623-NM 1201 NC501D-
BLSC
76203B 429-NMLT NMLQ-1038 NMM01 LT500 P470 NMLT-38
76205B 430-NMLT NMLQ-1050 NMM11 LT501 P471 NMLT-50
76207B 431-NMLT NMLQ-1075 NMM21 LT502 P472 NMLT-75
76210B 432-NMLT NMLQ-1100 NMM31 LT503 P473 NMLT-100
76212B 433-NMLT NMLQ-1125 P474 NMLT-125
76215B 434-NMLT NMLQ-1150 P475 NMLT-150
76220B 435-NMLT NMLQ-1200 P476 NMLT-200
76903B 469-NMLT NMLQ-9038 NML01 LT590 P490 NMLT-90-
38
76905B 470-NMLT NMLQ-9050 NML11 LT591 P491 NMLT-90-
50
76907B 471-NMLT NMLQ-9075 NML21 LT592 P492 NMLT-90-
75
76910B 472-NMLT NMLQ-9100 NML31 LT593 P493 NMLT-90-
100
76912B 473-NMLT NMLQ-9125 P494 NMLT-90-
125
76913B LPCG50 MNPT-50
76915B 474-NMLT NMLQ-9150 P495 NMLT-90-
150
76920B 475-NMLT NMLQ-9200 P496 NMLT-90-
200
76923B LPCG757 MNPT-75
77602 EH200 ME24 709
77604 EH201 ME256 710
77801 PVC660 1240-PVC 190 PVC8642 8673 727 4P
77802 PVC662 1241-PVC 191 PVC3040 8674 728 4X
77803 PVC662 1242-PVC 192 PVC3040 8675 729 4XL
77907 PMH-75
77910 PMH-100
77912 PMH-125 VMH-125
77915 PMH-150 VHM-150
77920 PMH-200 VMH-200
79910B DSC1 DS100 1901 DUX-1 961 DX-1
79950B DSC5 DS500 1905 DUX-5 965 DX-5
82105B 820A 250DCI2 IL21 TCI601 601S TC811SC 651i 2832 260-B 1650DC
82107B 821A 251DCI2 IL23 TCI602 602S TC812SC 652i 2833 261-B 1651DC
82110B 822A 252DCI2 IL25 TCI603 603S TC813SC 653i 2834 262-B 1652DC
82112B 823A 253DCI2 IL27 TCI604 604S TC814SC 654i 2835 263-B 1653DC
82115B 824A 254DCI2 IL29 TCI605 605S TC815SC 655i 2836 264-B 1654DC
82120B 825A 255DCI2 IL31 TCI606 606S TC816SC 656i 2838 265-B 1655DC
85
®
CROSS REFERENCE
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
82125B 826A 256DCI2 IL33 TCI607 607S TC817SC 657i 2890 266-B 1656DC
82130B 827A 257DCI2 IL35 TCI608 608S TC818SC 658i 2892 267-B 1657DC
82135B 828A 258DCI2 IL37 TCI609 609S TC819SC 659i 2894 268-B 1658DC
82140B 829A 259DCI2 IL39 TCI610 610S TC8110SC 660i 2896 269-B 1659DC
82305B 250-I MEC-750B 7050ST 7601-S TC711A 651Si 2912 260BST 1650
82307B 251-I MEC-751B 7075ST 7602-S TC712A 652Si 2913 261BST 1651
82310B 252-I MEC-752B 7100ST 7603-S TC713A 653Si 2914 262BST 1652
82312B 253-I MEC-753B 7125ST 7604-S TC714A 654Si 2915 263BST 1653
82315B 254-I MEC-754B 7150ST 7605-S TC715A 655Si 2916 264BST 1654
82320B 255-I MEC-755B 7200ST 7606-S TC716A 656Si 2918 265BST 1655
82325B 256-I MEC-756B 7250ST 7607-S TC717A 657Si 2960 266BST 1656
82330B 257-I MEC-757B 7300ST 7608-S TC718A 658Si 2962 267BST 1657
82335B 258-I MEC-758B 7350ST 7609-S TC719A 659Si 2964 268BST 1658
82340B 259-I MEC-759B 7400ST 7610-S TC7110A 660Si 2966 269BST 1659
82705B 230-I MES-750B 4050ST 7701-S TC721A 631Si 2122 300BST 1450
82707B 231-I MES-751B 4075ST 7702-S TC722A 632Si 2123 301BST 1451
82710B 232-I MES-752B 4100ST 7703-S TC723A 633Si 2124 302BST 1452
82712B 233-I MES-753B 4125ST 7704-S TC724A 634Si 2125 303BST 1453
82715B 234-I MES-754B 4150ST 7705-S TC725A 635Si 2126 304BST 1454
82720B 235-I MES-755B 4200ST 7706-S TC726A 636Si 2128 305BST 1455
82725B 236-I MES-756B 4250ST 7707-S TC727A 637Si 2160 306BST 1456
82730B 237-I MES-757B 4300ST 7708-S TC728A 638Si 2162 307BST 1457
82735B 238-I MES-758B 4350ST 7709-S TC729A 639Si 2164 308BST 1458
82740B 239-I MES-759B 4400ST 7710-S TC7210A 640Si 2166 309BST 1459
84205B L421A 407DCI2 IL42-1 SCI50 731-S XC870 151i 2392 1708DC
84207B L422A 408DCI2 IL42-2 SCI75 732-S XC872 152i 2393 1709DC
84210B L423A 410DCI2 IL42-3 733-S XC873 153i 1710DC
84212B L424A 412DCI2 IL42-4 734-S XC874 154i 1711DC
84215B L425A 414DCI2 IL42-5 735-S XC875 155i 1712DC
84220B L426A 416DCI2 IL42-6 736-S XC876 156i 1713DC
84403B GF38A 519DCI2 GCI38 671-S XC840 450i 939-B 3770DC
84405B GF50A 520DCI2 IL44-1 GCI50 672-S XC841 451i 2292 940-B 3771
84407B GF75A 521DCI2 IL44-2 GCI75 673-S XC842 452i 2293 941-B 3772
84410 GF100A 522DCI2 IL44-3 674-S XC843 453i 2294 942-B 3773DC
84412 GF125A 523DCI2 IL44-4 675-S XC844 454i 943-B 3774
84415 GF150A 524DCI2 IL44-5 681-S XC845 455i 944-B 3775
84420 GF200A 525DCI2 IL44-6 682-S XC846 456i 945-B 3776
84805B 507DCI2 XC821
84807B 508DCI2
85403NB 38AST/40AST 38ASP
86203B 429-SLTI MSTR-38-B 4QS38T LT700 470S 3511 RT-38AS LTB-38
86205B 430-SLTI MSTR-50-B 4QS50T LT701 471S 3512 RT-50AS LTB-50
86207B 431-SLTI MSTR-75-B 4QS75T LT702 472S 3513 RT-75AS LTB-75
86210B 432-SLTI MSTR-100-B 4QS100T LT703 473S 3514 RT-100AS LTB-100
86212B 433-SLTI MSTR-125-B 4QS125T LT704 474S 3515 RT-125AS LTB-125
86215B 434-SLTI MSTR-150-B 4QS150T LT705 475S 3516 RT-150AS LTB-150
86220B 435-SLTI MSTR-200-B 4QS200T LT706 476S 3518 RT-200AS LTB-200
86225B 436-SLTI MSTR-250-B 477S 3520 LTB-250
86230B 437-SLTI MSTR-300-B 478S 3522 LTB-300
86235B 438-SLTI MSTR-350-B 479S 3524 LTB-350
86240B 439-SLTI MSTR-400-B 480S 3526 LTB-400
86305B
86307B
86503B 449-SLTI MSTR-
3845-B 4QS438T LT950 230S 3561 RT-45-
38AS LTB-3845
86505B 450-SLTI MSTR-
5045-B 4QS450T LT951 231S 3562 RT-45-
50AS LTB-5045
86507B 451-SLTI MSTR-
7545-B 4QS475T LT952 232S 3563 RT-45-
75AS LTB-7545
86510B 452-SLTI MSTR-
10045-B 4QS4100T LT953 233S 3564 RT-45-
100AS LTB-10045
86
CROSS REFERENCE
CROSS REFERENCE
TM
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
86512B 453-SLTI MSTR-
12545-B 4QS4125T LT954 234S 3565 RT-45-
125AS LTB-12545
86515B 454-SLTI MSTR-
15045-B 4QS4150T LT955 235S 3566 RT-45-
150AS LTB-15045
86520B 455-SLTI MSTR-
20045-B 4QS4200T LT956 236S 3568 RT-45-
200AS LTB-20045
86525B 456-SLTI MSTR-
25045-B 237S LTB-25045
86530B 457-SLTI MSTR-
30045-B 238S LTB-30045
86535B 458-SLTI MSTR-
35045-B 239S LTB-35045
86540B 459-SLTI MSTR-
40045-B 240S LTB-40045
86703B L15A 560DCI2 6231
86903B 469-SLTI MSTR-
3890-B 4QS938T LT990 490S 3541 RT-90-
38AS LTB-3890
86905B 470-SLTI MSTR-
5090-B 4QS950T LT991 491S 3542 RT-90-
50AS LTB-5090
86907B 471-SLTI MSTR-
7590-B 4QS975T LT992 492S 3543 RT-90-
75AS LTB-7590
86910B 472-SLTI MSTR-
10090-B 4QS9100T LT993 493S 3544 RT-90-
100AS LTB-10090
86912B 473-SLTI MSTR-
12590-B 4QS9125T LT994 494S 3545 RT-90-
125AS LTB-12590
86915B 474-SLTI MSTR-
15090-B 4QS9150T LT995 495S 3546 RT-90-
150AS LTB-15090
86920B 475-SLTI MSTR-
20090-B 4QS9200T LT996 496S 3548 RT-90-
200AS LTB-20090
86925B 476-SLTI MSTR-
25090-B LT997 497S 3550 LTB-25090
86930B 477-SLTI MSTR-
30090-B LT998 498S 3552 LTB-30090
86935B 478-SLTI MSTR-
35090-B 499S 3554 LTB-35090
86940B 479-SLTI MSTR-
40090-B LT9910 500S 3556 LTB-40090
87005B 501A 1102DCI IL-701 CNI100 791S HA801 751i 3662 332-B
91003B 850A 801DCI2 IL110 ACI90 XC890 100i 2891 40-B 1724DC
91005B 851A 804DCI2 IL110-1 ACI95 XC891 101i 41-B 1736DC
91007B 852A 806DCI2 IL110-2 ACI96 XC892 102i 42-B 1738DC
91010 853A 807DCI2 IL110-3 XC893 103i 43-B 1739DC
91012 854A 808DCI2 IL110-4 XC894 104i 44-B 1740DC
91015 855A 809DCI2 IL110-5 XC895 105i 45-B 1741DC
91020 856A 810DCI2 IL110-6 XC896 106i 46-B 1742DC
91631 WH1 151-DC LWH-50 CHM50DT 401 H050SC 201 1702 WH-1 ST-1
91632 WH2 152-DC LWH-75 CHM75DT 402 H075SC 202 1703 WH-2 ST-2
92105B 800A 230DCI2 IL121 TCI501 701S TC821SC 631i 2634 300-B 1450DC
92107B 801A 231DCI2 IL123 TCI502 702S TC822SC 632i 2635 301-B 1451DC
92110B 802A 232DCI2 IL125 TCI503 703S TC823SC 633i 2636 302-B 1452DC
92112B 803A 233DCI2 IL127 TCI504 704S TC824SC 634i 2637 303-B 1453DC
92115B 804A 234DCI2 IL129 TCI505 705S TC825SC 635i 2638 304-B 1454DC
92120B 805A 235DCI2 IL131 TCI506 706S TC826SC 636i 2639 305-B 1455DC
92125B 806A 236DCI2 IL133 TCI507 707S TC827SC 637i 2648 306-B 1456DC
92130B 807A 237DCI2 IL135 TCI508 708S TC828SC 638i 2649 307-B 1457DC
92135B 8075A 238DCI2 IL137 TCI509 709S TC829SC 639i 2650 308-B 1458DC
92140B 808A 239DCI2 IL139 TCI510 710S TC8210SC 640i 2651 309-B 1459DC
92505B 820ART 250-SRTI MECR-750-B 7050SRT TC711A-RT 1650RT
92507B 821ART 251-SRTI MECR-751-B 7075SRT TC712A-RT 1651RT
92510B 822ART 252-SRTI MECR-752-B 7100SRT TC713A-RT 1652RT
92512B 823ART 253-SRTI MECR-753-B 7125SRT TC714A-RT 1653RT
92515B 824ART 254-SRTI MECR-754-B 7150SRT TC715A-RT 1654RT
92520B 825ART 255-SRTI MECR-755-B 7200SRT TC716A-RT 1655RT
92525B 826ART 256-SRTI MECR-756-B 7250SRT TC717A-RT 1656RT
92530B 827ART 257-SRTI MECR-757-B 7300SRT TC718A-RT 1657RT
92535B 828ART 258-SRTI MECR-758-B 7350SRT TC719A-RT
92540B 829AR 259-SRTI MECR-759-B 7400SRT TC7110A-
RT
87
®
CROSS REFERENCE
HALEX
ITEM ARLINGTON BP MADISON NEER REGAL T & B TOPAZ RACO PECO C-H
94105B HL500 81DC LG141-1 HL500 9661 HL601 351 2652 670 850RR DC
94107B HL750 82DC LG141-2 HL750 9662 HL602 352 2653 671 875RR DC
94110 HL1000 83DC LG141-3 HL1000 9663 HL603 353 2654 672 8100RR
DC
94205B 910 71DC2 LG142-1 9651 HL611 361 2662 650 850RB DC
94207B 911 72DC2 LG142-2 9652 HL612 362 2663 651 875RB DC
94405 61DC LG144-1 THL500G 9701 850EE DC
94407 62DC LG144-2 THL750G 9702 875EE DC
94410 63DC LG144-3 9703 TL203 383 2754 672EMT 8100EE DC
94505 HL5000 820DC
94507 HL7500 821DC
94510 HL1000 822DC
94705 9100 810DC
94707 9110 811DC
95205B 450 381DC CBGI-50 GBL100 8221 BG-201 331 MIGB-80 GLL1 DC
95207B 451 382DC CBGI-75 GBL200 8222 BG-202 332 MIGB-81 GLL2 DC
95210B 452 383DC CBGI-100 GBL300 8223 BG-203 333 MIGB-82 GLL3 DC
95212B 453 384DC CBGI-125 GBL400 8224 BG-204 334 MIGB-83 GLL4 DC
95215B 454 385DC CBGI-150 GBL500 8225 BG-205 335 MIGB-84 GLL5 DC
95220B 455 386DC CBGI-200 GBL600 8226 BG-206 336 MIGB-85 GLL6 DC
95225B 456 387DC CBGI-250 GBL700 8227 BG-207 337 MIGB-86 GLL7 DC
95230B 457 388DC CBGI-300 GBL800 8228 BG-208 338 MIGB-87 GLL8 DC
95235B 458 389DC CBGI-350 GBL900 8829 BG-209 339 MIGB-88 GLL9 DC
95240B 459 390DC CBGI-400 GBL1000 8230 BG-210 340 MIGB-89 GLL10 DC
96312 420
95403NB 3838AST/
4040AST 3838ASP
96203B LT38A 429LTI2 LQA1038-I LMM02 5800-S LT-800 470i RT-38A LTB38DC
96205B LT50A 430LTI2 LQA1050-I LMM12 5801-S LT-801 471i RT-50A LTB50DC
96207B LT75A 431LTI2 LQA1075-I LMM22 5802-S LT-802 472i RT-75A LTB75DC
96210B LT100A 432LTI2 LQA1100-I LMM32 5803-S LT-803 473i RT-100A LTB100DC
96212B LT125A 433LTI2 LQA1125-I LMM42 5804-S LT-804 474i RT-125A LTB125DC
96215B LT150A 434LTI2 LQA1150-I LMM52 5805-S LT-805 475i RT-150A LTB150DC
96220B LT200A 435LTI2 LQA1200-I LMM62 5806-S LT-806 476i RT-200A LTB200DC
96225B LT250A 436LTI2 LQA1250-I LMM72 5807-S LT-807 477 LTB250DC
96230B LT300A 437LTI2 LQA1300-I LMM82 5808-S LT-808 478 LTB300DC
96235B LT350A 438LTI2 LQA1350-I LMM86 5809-S LT-809 479 LTB350DC
96240B LT400A 439LTI2 LQA1400-I LMM92 5810-S LT-810 480 LTB400DC
96903B LT9038A 469-LTI2 LQA9038-I LML02 5840-S LT-890 490i RT-90-38A LTB-
3890DC
96905B LT9050A 470-LTI2 LQA9050-I LML12 5841-S LT-891 491i RT-90-50A LTB-
5090DC
96907B LT9075A 471-LTI2 LQA9075-I LML22 5842-S LT-892 492i RT-90-75A LTB-
7590DC
96910B LT90100A 472-LTI2 LQA9100-I LML32 5843-S LT-893 493i RT-90-100A LTB-
10090DC
96912B LT90125A 473-LTI2 LQA9125-I LML42 5844-S LT-894 4954i RT-90-125A LTB-
12590DC
96915B LT90150A 474-LTI2 LQA9150-I LML52 5845-S LT-895 495i RT-90-150A LTB-
15090DC
96920B LT90200A 475-LTI2 LQA9200-I LML62 5846-S LT-896 496i RT-90-200A LTB-
20090DC
96925B LT90250 476-LTI2 LQA9250-I LML72 5847-S LT-897 497 LTB-
25090DC
96930B LT90300 477-LTI2 LQA9300-I LML82 5848-S LT-898 498 LTB-
30090DC
96935B LT90350 478-LTI2 LQA9350-I LML86 5849-S LT-899 499 LTB-
35090DC
96940B LT90400 479-LTI2 LQA9400-I LML92 5850-S LT-8910 500 LTB-
40090DC
440-439-1616 . fax 440-439-1792 . 23901 Aurora Road . Cleveland, OH 44146
www.halexco.com
A SCOTT FETZER COMPANY
PRINTED IN THE USA
HALEX is a registered trademark of Halex/Scott Fetzer Company. Trade names and corporate references herein are for identification
purposes only and are not intended for promotion purposes. All product or specification information is subject to change without notice. L012-R080712
™
®
