60STC

User Manual: Pdf 60STC

Open the PDF directly: View PDF .
Page Count: 5

28"

711

16"

407

57 13

16 "

1469

2"

51

32"

813

20 1

4"

515

4"

102

10"

254

19 1

4"

489

5"

127

8"

203

10 1

8"

258

62 1

8"

1578

Telescopic Leg Range

From bottom of glass: 10''-19''

FLARE See Through 60

Commercial

Rev 03

For 5 x 8 vent size create 10'' x 10''

vent termination opening

10"

254

12"

305

For 5 x 8 vent size create 10'' x 12''

vent termination opening

10"

254

10"

254

1" min.

25 min.

1" min.

25 min.

4" min.

102 min.

4" max.

102 max.

40" min.

1016 min.

1" min.

25 min.

Appliance Location

Horizontal Termination Vertical Termination

Chimney Installation

V

Flat Installation L Shape Installation

4.5” Max. Top

Of Recess

33"

838

64

1

8"

1629

271

4"

692

Metal stud

191

4"

489

64

1

8"

1629

33"

838

Metal stud

Step 1 - Basic Framing : Step 1 - Basic Framing :

Flat Vs. L Shape Installation

For FLARE ST Fireplace

1

2"

13

4.5" max.

115 max.

1"

25

1"

25

1" clearance from stud

1"

25

1"

25

1" clearance from stud

Finishing

Material Thickness

Step 2 -Positioning the Fireplace:

Flat Vs. L Shape Installation

For FLARE ST Fireplace

Last Step - Finishing The Fireplace Wall: Step 3 - Framing Front Studs For L Shape:

Step 2 -Positioning the Fireplace:

Fireplace frame finishing

holder space to match

wall finishing thickness

4.5'' gap to match the

length of the shelf.

Flat Installation L Shape Installation

Last Step - Finishing The Fireplace Wall:

Specifications for Appliance

Flare See Through 60 Commercial

L Shape Finishing Install

Flat Vs. L Shape Installation

For FLARE ST Fireplace

Factor NG LPG

Burner Type 35,55,35 35,55,35

Orifice 500,800,500 160,260,160

BTU Max. 50000 41000

BTU min. 28000 20000

Kw/h 14.6k 12k

Chimney DIA. 5X8 5X8

Manifold Pressure[w.c] 2.9 6.2

Efficiency rate 77 80

Glass Size Length\Width 1455 X 423 mm 57'' 1/4 X 16" 11/16'

Appliance Weigh 175Kg 385lb
