Data Sheet
ADTRAN
621V
10 Gbps Single-Family Unit ONT
SDX Series
Features
Symmetric 10 Gbps service delivery
Integrated VoIP support
Integrated 4-channel NG-PON2 optics
10G Base-T user interface
Small 1RU half rack form factor
IPTV video support including
IGMP snooping feature set
Trafc management through
priority queuing, scheduling,
and trafc shaping
Overview
Upgrading FTTP networks to 10G
NG-PON2 provides network operators
the performance to extend the life of
their Optical Distribution Network (ODN)
while providing an architecture that
supports cost-eective business and
backhaul services delivery at greater
than Gigabit speeds.
Delivering Cost-Eective Converged
Residential and Business Services
e biggest challenge facing NG-PON2 is
developing a single system that meets the scale
and exibility needs of premium business and
backhaul services while also meeting the price
points needed for mass-market residential
applications. e ADTRAN® SDX 6310 uses a
exible optics approach that allows for a single
NG-PON2 OLT to utilize multiple types of op-
tical transceivers, enabling the service provider
to better align cost with the target application.
Flexible optics range from low-cost, xed
wavelength optics for residential, business and
small cell broadband applications, to Time and
Wavelength Division Multiplexing (TWDM)
optics for high-density, premium enterprise, data
center, fronthaul and backhaul services using
ONTs with tunable optics. Any mix of these
optics options can be used on a single NG-PON2
OLT, allowing for maximum exibility without
compromising future capabilities.
Benets
SDN-Ready Solution
e operational cost and complexity to connect
a FTTP subscriber can be further reduced to
accelerate the expansion of Gigabit broadband
services. e ADTRAN solution supports
provisioning through modern, open APIs,
facilitating its deployment in next-generation
SDN-based management systems. is, in
concert with accelerated mass-market electronics
and optics pricing, ensures that cost-sensitive
residential broadband will be viable using
NG-PON2 technology.
ADTRAN’s comprehensive portfolio of FTTP
devices is open, programmable and scalable.
ey support GPON, Active Ethernet, and
NG-PON2 access interfaces. ese devices are
part of ADTRAN’s SDN-optimized aggregation
architecture that aligns with the forward-looking
industry trend to build massively scalable and
open systems.
IPTV
Enabled
SDN
10
Gbps Open
Architecture
VoIP
ADTRAN 621V
Product Specications
Ethernet Interfaces
One User Interface:
RJ-45 for 100m/1/2.5/5/10G Base-T
10 Gbps Symmetric Throughput
Ethernet Port Auto Negotiation or Manual Conguration
MDI/MDIX Automatically Sense
Hardware Priority Queues on the Downstream Direction in
Support of CoS
Dimensions
6.4 in. x 9.75 in. x 1.5 in. (LxWxH)
Power Supply
+10 – 23V DC (Feed via External AC/DC Adapter)
3-PIN Molex Power Adaptor Input
Dying Gasp Support
Multi-pin Connector for Power and Alarm Input from UPS
Power Consumption:
Less than 30W
Network Interface
XFP WAN compliant with ITU-T G.989
NG-PON2 Standards
Class B+ Optics Support
DBA (Dynamic Bandwidth Allocation)
Mapping of xGEM Ports into a T-CONT with Priority
Queues Based Scheduling
POTS Interface
2 RJ-11 Interfaces
3-REN, 50V RMS
VoIP Voice
Both SIP and MGCP
TDM Voice
Both GR.303, GR-57, and TR-08
Full CLASS Feature Set
Both ANSI and ETSI POTS
T.38 Facsimile
Congurable Dial Plan
Congurable Country Specic Ring-back Tones
(Frequency and Cadence)
DHCP Client or Static IP Conguration
Optionally Metallic Loop Testing
OAM
Manageable through Mosaic Cloud
Support for Open OMCI
FCC/EMC
FCC Part 15 Class A
EN 300 386, with compliance to the EMC directive
89/336/EEC
EN 55022/CISPR22 Class A
Safety
UL/CUL 60950
EN 60950-1
IEC 60950
AS/NZS 60950
Regulatory
ETS 300 019-2-3 for Class 3.1E– Environmental condi-
tions and test for telecommunications equipment
EN 300 019-1-2 for ETS Class 2.3 –Transportation
EN 300 019-1-1 for ETS Class 1.2 – Storage
ETSI 300 132-2 – Power Supply interface at the input to
telecommunications equipment
LEDs
Status
Network
Management
Wavelength
Voice
Data
Single Family Unit ONT
Ordering Information
Equipment Part No.
ADTRAN 621V, 10 Gbps Single Family Unit ONT 1287821F1
