SINGLE PHASE LOAD CENTERS 120V/240V
Stock Number DESCRIPTION
Main Breaker G-E TM2010CCU 100Amp Main Circuit Breaker 20 Circuit
G-E TM2020CCU 200Amp Main Circuit Breaker 20 Circuit
G-E TM3210CCU 100Amp Main Circuit Breaker 32 Circuit
G-E TM3215CCU 150Amp Main Circuit Breaker 32 Circuit
G-E TM3220CCU 200Amp Main Circuit Breaker 32 Circuit
G-E TM4020CCU 200Amp Main Circuit Breaker 40 Circuit
Main Lug G-E TLM2412CCU 125Amp Main Lug Only 24 Circuit
G-E TLM2020CCU 200Amp Main Lug Only 20 Circuit
G-E TLM3220CCU 200Amp Main Lug Only 32 Circuit
G-E TLM4020CCU 200Amp Main Lug Only 40 Circuit
THREE PHASE LOAD CENTERS 280Y/120V1
Stock Number DESCRIPTION
Main Breaker G-E TM18410C 100Amp Main Circuit Breaker 18 Circuit
G-E TM42420C 200Amp Main Circuit Breaker 42 Circuit
G-E TM42420R 200Amp Main Circuit Breaker 42 Circuit Raintight
Main Lug G-E TL12412C 125Amp Main Lug Only 12 Circuit
G-E TL18415C 150Amp Main Lug Only 18 Circuit
G-E TL24415C 150Amp Main Lug Only 24 Circuit
G-E TL30420C 200Amp Main Lug Only 30 Circuit
G-E TL30420R 200Amp Main Lug Only 30 Circuit Raintight
G-E TL42420C 200Amp Main Lug Only 42 Circuit
TL42422C 225Amp Main Lug Only 42 Circuit
LOAD CENTER GROUND KITS
Stock Number DESCRIPTION
G-E TGK12 12-Hole Ground Kit
G-E TGK24 24-Hole Ground Kit
G-E TGK42 42-Hole Ground Kit
G-E TGKIS Isolated Ground Bar Kit
LOAD CENTER CIRCUIT BREAKERS
Stock Number DESCRIPTION
Branch Breakers
(THQL Style)
G-E THQL1115 thru 1150 1-Pole 15A-50A 120/240V Plug In
G-E THQL2115 thru 21125 2-Pole 15A-125A 120/240V Plug In
G-E THQL32015 thru 32100 3-Pole 15A-100A 240V Plug In
1/2" Branch Breakers G-E THQP115 thru 130 1-Pole 15A-30A 120/240V 1/2"
(THQP Style) G-E THQP215 thru 250 2-Pole 15A-50A 120/240V 1/2"
Arc Fault Branch G-E THQL1115AF2 1-Pole 15Amp 120/240V Arc Fault
Breakers G-E THQL1120AF2 1-Pole 20Amp 120/240V Arc Fault
(AFCI) G-E THQL2115AF 2-Pole 15Amp 120/240V Arc Fault
G-E THQL2120AF 2-Pole 20Amp 120/240V Arc Faut
Ground Fault Branch G-E THQL1115GF 1-Pole 15Amp 120/240V GFI
Breakers G-E THQL1120GF 1-Pole 20Amp 120/240V GFI
(GFI) G-E THQL1130GF 1-Pole 30Amp 120/240V GFI
G-E THQL2115GF1 2-Pole 15Amp 120/240V GFI
G-E THQL2120GF1 2-Pole 20Amp 120/240V GFI
G-E THQL2130GF1 2-Pole 30Amp 120/240V GFI
G-E THQL2140GF1 2-Pole 40Amp 120/240V GFI
G-E THQL2150GF1 2-Pole 50Amp 120/240V GFI
Surge Protection G-E THQLSURGE Plug In Surge Arrestor
G-E THSASURGE60 Hard Wire Surge Arrestor
Generator Interlock2 G-E THQLLX1 Generator Interlock Kit
1 Also UL listed for 3P4W 240/120Vac Delta and 3P3W 240Vac
2Compatible with PowerMark Gold™ Mod 6 150-225A main breaker load centers
LOADCENTERS
SINGLEPHASE,THREEPHASE,GROUNDKITS,CIRCUITBREAKERS,SURGEPROTECTION
IndoorLoadCenters
Features:
• Greater breaker capacity
• Improved safety features
• Easier installation, simpler knockout
layout, adjustable depth mounting
holes, centered key holes
www.vikingelectric.com 3
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
LOADCENTERACCESSORIES
LOADCENTERACCESSORIES-GENERATORINTERLOCK/WHOLE-HOUSESURGEPROTECTION
Whole-HouseSurgeProtection
GE SurgePro™ AC surge protectors are designed for service entrance or
subpanel locations. Each provides small, easy to install surge protection
for the entire home or office. The protectors consist of multiple metal oxide
varistors with internal thermal and overcurrent protection. An LED indicates
the proper function of the protection elements.
The THQLSURGE conveniently connects inside the GE Powermark™
load center, directly onto the bus, like a circuit breaker, providing direct
protection for the entire panel and all attached loads.
The THSASURGE60 connects to a 2-pole 30 amp (or less) circuit breaker
and can be mounted on the outside of any manufacturer’s load center,
making the THSASURGE60 a great addition to a new or existing load center.
PowerMarkGold™
GeneratorInterlockKit
Features:
• Converts any PowerMark Gold load center
with a main breaker having a left-handle
orientation to be used as a generator panel
• Interlocks 4-pole main breaker with 2-pole
branch breakers in breaker positions 2-4
• Kit includes stainless steel interlock device,
auxiliary main breaker retainer, assembly
hardware, hole drill template, critical circuit
identification labels
• UL listed
• Suitable for use in accordance with Article
702 of the National Electrical Code, ANSI/
NFPA 70
With the PowerMark Gold Generator Interlock Kit, there’s no need for a separate
generator panel. The kit contains everything needed to make an existing load center a
generator panel. It’s quick and easy, it saves time and money!
Just install the kit in any new or existing 150-225A PowerMark Gold main breaker
load center, with a main breaker having a left-handle orientation, and with a
back-fed branch breaker mounted at top right. It’s safe because it ensures that the
main breaker is in the OFF position before the branch breaker is back-fed from the
generator or vice versa.
G-E THQLLX1 - Kit includes:
• Interlock plate
• Base Plate
• Rivets
• Interlock label
• Hole drilling template
• Aux. breaker retainer
• Mounting hardware
• Instruction sheet DEH-41103
THQLSURGE
THSASURGE60
Compatible with any
Mod 6 150-225A main
breaker PowerMark
Gold™ load center!
www.vikingelectric.com
4
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
LOADCENTERACCESSORIES
MAINBREAKERKITS&RETAINERS,GROUNDKITS,GROUNDBUSBARS,MAINLUGKITS,DOORLOCKS,CIRCUITDIRECTORY,FRONTFILLERPLATES
GROUNDED & ISOLATED GROUND BUS BAR
4-14 CU/10-12 Al Wire Stock Number
Ranges Per Hole, Solid or Stranded)
4-Hole Ground TGK4
12-Hole Ground G-E TGK12
16 Hole Ground/Neutral TGK8
24-Hole Ground G-E TGK24
32-Hole Ground G-E TGK32
42-Hole Ground G-E TGK42
Isolated Ground Bus Bar Kit
(Order with TGK Equipment Ground Kits)
G-E TGKIS
Isolated Ground Bar Feet
(Order with TGK8)
TGKIS2
DOOR LOCK
Stock Number Description
G-E TDL106 For all indoor load centers except TPL412
CIRCUIT DIRECTORY
Stock Number Description
G-E TD42 Card and holder with pressure-sensitive
backing mounts inside door
FRONT FILLER PLATES
To cover rectangular breaker knockouts
Stock Number Description
THFILLER Includes (2) 1/2" and (2) 1" filler plates
NEUTRAL AND NEUTRAL GROUND KITS
Description Wire Size Stock Number
Neutral 6-1 Cu/Al TNLK12
Neutral 6-2/0 Cu/Al TNLK20
Neutral 6-250 Cu/Al TNLK250
Neutral/Ground 6-2/0 Cu/Al G-E TLK20
Neutral/Ground 6-250 Cu/Al G-E TLK250
Neutral/Ground 6-300 Cu/Al TLK300
MAIN LUG KITS
Load Center Type Wire Size AWG/kcmil Cu/Al Ampere Rating Stock Number
Power Mark Gold 6-2/0 125 TMLK125
6-250 200 TMLK200
6-300 225 TMLK225
MAIN CIRCUIT BREAKER KITS
FOR USE WITH 150A - 225A LOAD CENTERS
22 KAIC RMS symmetrical. Includes mounting base.
Main Breaker Rating Stock Number
100A THQMV100D
125A THQMV125D
150A THQMV150D
175A THQMV175D
200A THQMV200D
225A THQMV225D
FOR USE WITH 125A LOAD CENTERS
22 KAIC RMS symmetrical. Includes mounting base. For bottom feed, purchase
TRL22 door handle
Stock Number DESCRIPTION
THQMH000 Order appropriate THQL* or THHQL
breakers separately
*10 kAIC
MAIN BREAKER RETAINERS
FOR MAIN LUG LOAD CENTERS UTILIZING A BACK FED BRANCH BREAKER AS A MAIN
Load Center Breaker Stock Number
Travel Trailer THQP THQPSBK
TL (225A max.) THQL G-E THQLRK
TQDL TQDLRK
PowerMark Gold THQL G-E THQLRK1
THQL THQLRK2CP*
TM/TLM1212CCU Mod 2 THQL THQLRK3CP
*For 6 or 8 circuit load centers
EQUIPMENT GROUND KITS
Number of Terminals
Small 14-8 Cu, 12-8 Al Large 14-4 Cu,
12-4 Al
Other AWG/kc-
mil Cu/Al
Stock Number
43G-E TGL1*
43G-E TGL3*
86G-E TGL2**
86G-E TGL4**
10 2 (1) 14-2 G-E TGL8**
(1) 6-2/0 G-E TGL20***
*TGL1 and TGL3 mount interchangeably. **TGL2, TGL4 and TGL8 mount interchangeably. ***Add-on equipment
ground lug (for use on any TGL Kit).
www.vikingelectric.com 5
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
LOADCENTERACCESSORIES
UNIVERSALHUBS,DOORHANDLES/LOCKS/TIES,INTERLOCKKITS,HARDWARE/KITS
UNIVERSAL RAINTIGHT HUBS (ALUMINUM)
Nominal Conduit
Diameter in Inches
Stock Number
3/4 G-E TC75
1G-E TC100
1 1/4 G-E TC125
1 1/2 G-E TC150
2G-E TC200
2 1/2 TC250
3 TC300
Closing Cap TCCP
4" BASE UNIVERSAL
HUBS
Nominal Conduit
Diameter in Inches
Stock Number
2G-E TCU27
2 1/2 TCU28
3 TCU30
3 1/2 TCU35
4* TCU40
4" Cover Plate TCUP
*For 40 and 42 circuit units in R8 boxes only
DOOR HANDLES / LOCKS / TIES
Stock Number Description Breaker
DOOR HANDLES / LOCKING HANDLES
TRL22 Universal 1PH and 3PH Door Handle
G-E TQPPL Handle Lock Padlocking,
On or Off, Snap-on, Padlock not included
THQP
G-E THP100 THQL
G-E TQPL Handle Lock - Non-Padlocking
On or Off, Snap-on
THQP
G-E THL103 THQL
HANDLE TIES
For Two Single-pole Brealers Pole*
THT1 Solid Snap-on Trip Indicating THQP
THT2 For 2 THQP's separated by 2 side-by-side THQPs THQP
G-E THT104 Solid Snap-on. (Can also be used to create a 2-pole
AFCI breaker by tying together two (2) 1-pole AFCIs )
THQL
TQHT1 Trip Indicating THQL
*all multi-pole breakers have internal common trip
LOAD CENTER HARDWARE & HARDWARE KITS
Stock Number Description
TBS One bond screw 100-200A
TBS22 Bond Screw 225A
THDWRKIT 20 Front mounting screws
THDWRKIT2 10 interior mounting screws
LOAD CENTER GENERATOR INTERLOCK KIT
Stock Number Description
G-E THQLLX1 For use with PowerMark Mod6 150-225A Main Breaker Load Centers
G-E THQLLX1
G-E TC75
G-E TQPPL
G-E THT104
www.vikingelectric.com
6
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
SINGLEPHASE&THREEPHASEREPLACEMENTFRONTS(60,125,150,200,225AMP)
LOADCENTERREPLACEMENTFRONTS
SINGLE PHASE REPLACEMENT FRONTS SINGLE PHASE REPLACEMENT FRONTS (CON’T)
Main Amp Rating Load Center Cat . No. Mod. No. Front Cat . No Main Amp Rating Load Center Cat . No. Mod. No. Front Cat . No
60 TM860FCUGEN M01 TMGPFC 200
(continued)
TLM2020CCUG M06 TLM20DCD
TM860SCUGEN M01 TMGPSC TLM2020CCUG M07 TLM2020
100 TM1210C24 M01 TLM12C24 TLM3220C42 M07 TLM32C42
TM1210C24G M01 TLM12C24 TLM3220CCU M01 TLM32AC
TM1210CCU M01 TM12FC TLM3220CCU M06 TLM32ACD
TM1210CCU M02 TLM12FD TLM3220CCU M07 TLM32C42
TM1210CCUG M01 TM12FC TLM3220CCUW M06 TLM32ACWD
TM1210CCUG M02 TLM12FD TLM4020CCU M01 TLM40AC
TM2010CCU M01 TM2010 TLM4020CCU M06 TLM4020
TM3210CCU M01 TM3210 TLM4220CCU M06 TLM4222
125 TLM1212C24 M01 TLM12C24 TM1620CCU M01 TM16GC
TLM1212C24G M01 TLM12C24 TM1620CCU M06 TM16GCD
TLM1212CCU M01 TLM12BC TM1620CCU M07 TLM1620
TLM1212CCU M02 TLM12BD TM1620CCUG M01 TM16GC
TLM1212CCUG M01 TLM12BC TM1620CCUG M06 TM16GCD
TLM1212CCUG M02 TLM12BD TM1620CCUG M07 TLM1620
TLM1612CCU M01 TLM1612 TM2020CCU M01 TM20EC
TLM2412CCU M01 TLM2412 TM2020CCU M06 TM20ECD
TLM612FCU M01 TLM6FC TM2020CCU M07 TLM2020
TLM612FCUD M01 TLM6FCD TM2020CCUB M01 TMB20BC
TLM612SCU M01 TLM6SC TM2020CCUG M01 TM20EC
TLM612SCUD M01 TLM6SCD TM2020CCUG M06 TM20ECD
TLM612SCUDG M01 TLM6SCD TM2020CCUG M07 TLM2020
TLM812FCU M01 TLM8FC TM2020CCUW M07 TM20FDWD
TLM812FCU M01 TLM8SC TM3220C42 M06 TM32GCD
TLM812FCUD M01 TLM8FCD TM3220C42 M07 TLM3220
TLM812FCUDG M01 TLM8FCD TM3220CCU M01 TM32FC
TLM812SCU M01 TLM8SC TM3220CCU M06 TM32FCD
TLM812SCUD M01 TLM8SCD TM3220CCU M07 TLM3220
TLM812SCUDG M01 TLM8SCD TM3220CCUB M01 TMB32C
TM1212C24 M01 TLM12C24 TM4020CCU M01 TM40BC
TM1212C24G M01 TLM12C24 TM4020CCU M06 TLM4020
TM1212CCU M01 TM12FC TM4020CCUB M01 TMB40AC
TM1212CCU M02 TLM12FD TM4220CCU M06 TLM4222
TM1212CCUG M01 TM12FC 225 TLM4222CCU M01 TLM42CM
TM1212CCUG M02 TLM12FD TLM4222CCU M06 TLM4222
TM1612CCU M01 TLM1612 TLM2020CCUW M06 TLM20ACWD
TM1612CCUG M01 TLM1612 TLM2020CCUW M07 TLM20W
TM2412CCU M01 TM24DC THREE PHASE REPLACEMENT FRONTS
150 TLM2015CCU M01 TLM20BC Main Amp Rating Load Center Cat . No. Mod. No. Front Cat . No
TLM2015CCU M06 TLM20BCD 100 TM12410C M02 TM12AC3
TLM2015CCU M07 TLM2015 TM18410C M02 TM18AC3
TLM2415CCU M01 TLM24DC 125 TL12412C M02 TL12AC3
TLM2415CCU M06 TLM2415 TM30412C M03 TM30EC3
TM1615CCU M01 TM16FC TM30412CB M03 TMB30BC3
TM1615CCU M06 TLM1620 150 TL18415C M02 TL18BC3
TM1615CCUG M01 TM16FC TL24415C M02 TL24AC3
TM1615CCUG M06 TLM1620 TM24415C M03 TM24DC3
TM2015CCU M01 TM20CX TM24415CB M03 TMB24BC3
TM2015CCU M06 TM20CXD TM30415C M03 TM30EC3
TM2015CCU M07 TLM2015 TM30415CB M03 TMB30EC3
TM2415CCU M01 TM24EC TM42415C M03 TM42DC3
TM2415CCU M06 TLM2415 TM42415CB M03 TMB42DC3
TM2415CCUB M01 TMB24BD 200 TL18420C M02 TL18DC3
TM3215C42 M06 TLM32C42 TL30420C M02 TL30BC3
TM3215CCU M01 TM32C TL42420C M02 TL42BC3
TM3215CCU M06 TLM3215 TM24420C M02 TM24DC3
200 TLM1620CCU M01 TLM16BC TM24420CB M02 TMB24DC3
TLM1620CCU M06 TLM16BCD TM30420C M03 TM30DC3
TLM1620CCU M07 TLM1620 TM30420CB M03 TMB30DC3
TLM1620CCUG M01 TLM16BC TM42420C M03 TM42EC3
TLM1620CCUG M06 TLM16BCD TM42420CB M03 TMB42EC3
TLM1620CCUG M07 TLM1620 225 TL30422C M01 TL30AC3
TLM2020CCU M01 TLM20DC TL42422C M01 TL42AC3
TLM2020CCU M06 TLM20DCD TM42422C M02 TM42BC3
TLM2020CCU M07 TLM2020 TM42422CB M02 TMB42BC3
TLM2020CCUG M01 TLM20DC Most of the items in the shaded rows are obsolete. In addition to ordering the replacement front with
the largest model number, order a new THQMV (KR main). The catalog number will be THQMVXXXD
where XXX is the main breaker amp rating. Example: THQMV200D for a 200A main breaker
www.vikingelectric.com 7
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
SAFETYSWITCHESATAGLANCE
NEMA TYPE
ENCLOSURE
TYPE 30 A 60 A 100 A 200 A 400 A 600 A 800 A 1200 A
1 General Duty 2 & 3 Pole (Fusible) 240Vac
3 Pole (Non-Fusible) 240Vac
Heavy Duty 2 & 3 Pole (Fusible) 240Vac
2 Pole (Fusible & Non-Fusible) 600Vdc
3 Pole (Fusible & Non-Fusible) 600Vac
Double
Throw
3 Pole (Non-Fusible) 240Vac & 600Vac
3 Pole (Fusible) 240Vac
3 Pole (Fusible) 600Vac
3R General Duty 2 Pole (Non-Fusible) 240Vac
Heavy Duty 2 & 3 Pole (Fusible) 240Vac
2 Pole (Fusible & Non-Fusible) 600Vdc
3 Pole (Fusible) 600Vac
3 Pole (Non-Fusible) 600Vac
Double
Throw
3 Pole (Fusible) 600Vac
2 Pole (Non-Fusible)
120/240Vac
3 Pole (Non-Fusible) 240Vac
3 Pole (Fusible) 240Vac
3 Pole (Non-Fusible) 600Vac
4/4X Heavy Duty 2 & 3 Pole (Fusible) 240Vac
2 Pole (Fusible & Non-Fusible) 600Vdc
3 Pole (Fusible & Non-Fusible) 600Vac
3 Pole (Non-Fusible) 600Vac
Mill Duty 2 & 3 Pole (Fusible) 240Vdc
2 Pole (Fusible & Non-Fusible) 600Vdc
3 Pole (Fusible & Non-Fusible) 600Vac
5/12 Heavy Duty 2 & 3 Pole (Fusible) 240Vac
2 Pole (Fusible & Non-Fusible) 600Vdc
3 Pole (Fusible & Non-Fusible) 600Vac (also available in 3R)
3 Pole (Non-Fusible) 600Vac
12 Mill Duty 2 & 3 Pole (Fusible) 240Vdc
2 Pole (Fusible & Non-Fusible) 600Vdc
3 Pole (Fusible & Non-Fusible) 600Vac
THN3361JDC
Switch Type Fusing Number of Wires Number of
Poles
Maximum
Voltage
Rating
Ampere
Rating
Enclosure Type Other Features
TG = General Duty
TH - Heavy Duty
N = Non-Fusible
(blank) = Fusible
2 = 2 wire system
3 = 3 wire system
4 = 4 wire system
2 = 2 Poles
3 = 3 Poles
6 = 6 Poles
2 = 240 Vac
6 = 600 Vac
1 = 30 amps
2 = 60 amps
3 = 100 amps
4 = 200 amps
5 = 400 amps
6 = 600 amps
(blank) = NEMA Type 1
J = NEMA 5/12
M = NEMA 12 MILL DUTY
R = NEMA Type 3R
SS = NEMA 4/4X (304SS)
SS316 = NEMA 4/4x (316SS)
B = Bottom Feed
CL = Copper Lugs
DC = 600 Vdc Rated
F = Vertically Hinged Door
W = Viewing Window
SafetySwitchNomenclature
SAFETYSWITCHESATAGLANCE
www.vikingelectric.com
8
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
SAFETYSWITCHES
GENERALDUTY/HEAVYDUTY(240V/480V/600V),EMERGENCYPOWERTRANSFERSWITCHES
GENERAL DUTY
240V Fusible
3P4W
Stock Number DESCRIPTION
G-E TG4321 30A
G-E TG4322 60A
G-E TG4323 100A
G-E TG4324 200A
G-E TG4325 400A
TG4326 600A
240V Non-Fusible
3P3W
G-E TGN3321 30A
G-E TGN3322 60A
G-E TGN3323 100A
G-E TGN3324 200A
TGN3325 400A
TGN3326 600A
*Add R to Stock Number for Nema 3R.
HEAVY DUTY
240V Fusible
3P4W
Stock Number DESCRIPTION
G-E TH4321 30A
G-E TH4322 60A
G-E TH4323 100A
G-E TH4324 200A
TH3325 400A
TH3326 600A
TC72367 800A
TC72368 1200A
600V Fusible
3P3W
G-E TH3361 30A
G-E TH3362 60A
G-E TH3363 100A
G-E TH3364 200A
G-E TH3365 400A
TH3366 600A
TC72367 800A
TC72368 1200A
480V and 600V
Non-Fusible
3P3W
G-E THN3361 30A
G-E THN3362 60A
G-E THN3363 100A
G-E THN3364 200A
G-E THN3365 400A
THN3366 600A
TC36367 800A
TC36368 1200A
*Add R to Stock Number for Nema 3R.
EMERGENCY POWER TRANSFER SWITCHES
120/240 Volt AC,
Non-Fusible
3 Wire SN
Stock Number DESCRIPTION
G-E TC10323R Nema 3R 100A
G-E TC10324R Nema 3R 200A
240V, Non-Fusible
4 Wire SN
TC10424R Nema 3R 200A
www.vikingelectric.com 9
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
GROUNDKITS,NEUTRALKITS,DOORGASKETKITS,RAINTIGHTHUBS,FUSINGKITS
SAFETYSWITCHACCESSORIES
EQUIPMENT GROUND KITS
Lug Wire Size (AWG/kcmil)
Switch Ampere Rating Stock Number Copper Aluminum
30-60 G-E TGL1 (4) 14-8 (4) 14-8
(3) 14-4 (3) 6-4
100-200 TNG3 (3) 10/1/0 (3) 10/1/0
400-600 TGL6 (3) 2-250 (3) 2-250
NEUTRAL KITS - INSULATED, GROUNDABLE AND BONDABLE
Lug Wire Size (AWG/kcmil)
Ampere Rating Stock Number Copper Aluminum
30 TNI21
60 G-E TNIA62 12-2 12-2
100 TNIA63 10-1/0 10-1/0
200 G-E TNIA64 2-250 2-250
400 G-E TNI65 (1) 2-600 or (2) 1/0-250 (1)2-600 or (2) 1/0-250
400 TNI65A (1)2-600 or (2) 1/0-250 (1)2-600 or (2) 1/0-250
600 TNI66 (2) 4-500 (2) 4-500
SEMI-DUST-TIGHT DOOR GASKET KITS
Switch Ampere Rating Stock Number
30-100 THG106
200 THG107
400-600 THG108
ALUMINUM UNIVERSAL RAINTIGHT HUBS
For outdoor enclosures with removable closing caps
Nominal Conduit Diameter
(in Inches)
Stock Number
3/4 G-E TC75
1G-E TC100
1 1/4 G-E TC125
1 1/2 G-E TC150
2G-E TC200
2 1/2 TC250
3 TC300
Closing Cap TCCP
CLASS R FUSING KIT
For rejecting fuses other than Class R on 2- and 3-pole TG Type 1 and 3R
safety switches. Filed Installble. UL Listed.
Switch Ampere Rating Stock Number
30 TGRK12
60 TGRK22
100 TGRK32
200 TGRK42
www.vikingelectric.com
10
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
SPEC-SETTER™DOUBLETHROWSAFETYSWITCHES-TYPETCANDTYPETDT
SAFETYSWITCHES
TypeTCNon-Fused(NEMA1)andOutdoor(NEMA3R)
Double-ThrowSwitches
• Designed for application where safety, high performance, and continuity of service are
required.
• UL Listed. Products in this section have been tested by UL and shown to meet the
construction and performance requirements of UL Standard Number 98, Enclosed and
Dead Front Switches. Suitable for use in accordance with Article 702 of the National
Electrical Code.
• Meet Federal Specification W-S-865C for enclosed switches; 30-200 amps, Type HD;
400-600 amps, Type LD.
• Meet or exceed NEMA Enclosed Switch Standard KS1 except paragraph 1-4.24
(withstand and short circuit) for Type HD 30-200 amps, Type GD 400-600 amps.
• 60°C and 75°C conductor ratings.
• Quick-make, quick-break mechanisms 30-200 amps; quick break mechanisms 400-
600 amps.
• UL Service Entrance rated (NEMA 1 and NEMA 3R).
TypeTCOutdoorEmergencyPowerTransferSwitches
• Designed for residential or light commercial applications where duty is not severe.
• UL Listed. Products in this section have been tested by UL and shown to meet the
construction and performance requirements of UL Standard Number 98, Enclosed and
Dead Front Switches.
• Meet or exceed NEMA Enclosed Switch Standard KS1 for Type GD.
• Suitable for use as service entrance equipment when installed in accordance with
National Electrical Code.
• 60°C and 75°C conductor ratings.
• Not quick-make, quick-break
TypeTDTFusibleDouble-ThrowSafetySwitches
• TDT safety switches are suitable for use as service entrance equipment when either
neutral kit DT200NK or ground lug kit DS200GK is installed. UL listed (no CSA or cUL).
www.vikingelectric.com 11
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
SPEC-SETTER™DOUBLETHROWSAFETYSWITCHES(TYPETC,TDT-240,480,600VAC)
SAFETYSWITCHES
3-POLE, 240V AC, 250V DC, NO FUSE
Ampere
Rating Enclosure
Type HP, 240
Vac, NEC
Std. 3-Ph
HP, 480
Vac, NEC
Std. 3-Ph
HP, 600
Vac, NEC
Std. 3-Ph
Lug Wire Size,
AWG/kcmil, Cu Only Stock
Number
30A NEMA
Type 1
2 - - 14-8 TC35321
60A 3 - - 14-4 TC35322
100A 7 1/2 - - 14-1/0 TC35323
200A 15 - - 6-250 TC35324
400A 30 - - (2)1/0-250 or #2-600 TC35325
600A 50 - - (2)3/0-350 or #2-600 TC353262
30A NEMA
Type 3R
2 - - 14-8 TC35321R
60A 3 - - 14-4 TC35322R
100A 7.5 - - 14-1/0 TC35323R
200A 15 - - 6-250 TC35324R
400A 30 - - (2)1/0-250 or #2-600 TC35325R
3-POLE, 600V AC, 250V DC, NO FUSE
Ampere
Rating
Enclosure
Type
HP, 240
Vac, NEC
Std. 3-Ph
HP, 480
Vac, NEC
Std. 3-Ph
HP, 600
Vac, NEC
Std. 3-Ph
Lug Wire Size,
AWG/kcmil, Cu Only
Stock
Number
30A NEMA
Type 1
10 10 10 14-4 Use 60A
60A 10 10 10 14-4 TC35362
100A 15 15 15 14-1/0 TC35363
200A 30 30 30 6-250 TC35364
400A - - - (2)1/0-250 or #2-600 TC353651,2
600A - - - (2)3/0-350 or #2-600 TC353661,2
30A NEMA
Type 3R
10 14-4 Use 60A
60A 10 14-4 TC35362R
100A 15 14-1/0 TC35363R
200A 30 6-250 TC35364R
240V, AC FUSIBLE
Ampere
Rating
Enclosure
Type
HP, 240 Vac,
Time Delay,
1-Ph
HP, 480 Vac,
Time Delay.
1-Ph
HP, 600 Vac,
Time Delay.
1-Ph
HP, 240 Vac,
Time Delay,
3-Ph
HP, 480 Vac,
Time Delay.
3-Ph
HP, 600 Vac,
Time Delay.
3-Ph
HP, DC @250V Stock Number
30A NEMA
Type 1
3 - - 7 1/2 - - 5 TDT3321
60A 10 - - 15 - - 10 TDT3322
100A 15 - - 30 - - 20 TDT3323
200A 15 - - 60 - - 40 TDT33243
400A - - - 125 - - 50 TDT3325
600A - - - 50 - - 50 TDT33264
30A NEMA Type
3R
3 7 1/2 10 7 1/2 15 20 5 TDT3321R
60A 10 20 25 15 30 50 10 TDT3322R
100A 15 30 40 30 60 75 20 TDT3323R
200A 15 50 50 60 125 150 40 TDT3324R3
600V, AC FUSIBLE
Ampere
Rating
Enclosure
Type
HP, 240 Vac,
Time Delay,
1-Ph
HP, 480 Vac,
Time Delay.
1-Ph
HP, 600 Vac,
Time Delay.
1-Ph
HP, 240 Vac,
Time Delay,
3-Ph
HP, 480 Vac,
Time Delay.
3-Ph
HP, 600 Vac,
Time Delay.
3-Ph
HP, DC @250V Stock Number
30A NEMA
Type 1
3 7 1/2 10 7 1/2 15 20 - TDT3361
60A 10 20 25 15 30 50 - TDT3362
100A 15 30 40 30 60 75 - TDT3363
200A 15 50 50 60 125 150 40 TDT33643
400A - - - 125 250 350 50 TDT3365
30A NEMA Type
3R
15 30 40 30 60 75 20 TDT3363R
60A 15 50 50 60 125 150 40 TDT3364R3
1 Not UL listed
2 Not suitable for use as service equipment per NEC Article 702
3 200 Amp switches move load base for Class J fuses
4 600 Amp switch available in Class T fuse only.
Type TC Indoor Double-throw Switch
www.vikingelectric.com
12
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
SPEC-SETTER™DOUBLETHROWSAFETYSWITCHES(TYPETCOUTDOOR-240,480,600VAC)
THREE-WIRE SN, 120/240 V AC, NO FUSE - EMERGENCY POWER TRANSFER SWITCH
Ampere Rating Enclosure Type Poles Lug Wire Size, AWG/kcmil,
Cu/Al
Stock Number
100A NEMA Type 3R 2 12-1 G-E TC10323R
200A 2 6-250 G-E TC10324R
FOUR-WIRE SN, 240 V AC, NO FUSE - EMERGENCY POWER TRANSFER SWITCH
Ampere Rating Enclosure Type Poles Lug Wire Size, AWG/kcmil,
Cu/Al
Stock Number
200A NEMA Type 3R 3 6-250 TC10424R
ACCESSORIES FOR TDT-STYLE FUSIBLE DOUBLE-THROW SAFETY SWITCHES*
Accessory Type Description Stock Number
Control Pole - DS16CP
Electrical Interlocks 30-800 A, 1N DS200EK1
Electrical Interlocks 30-800 A, 2N DS200EK2
Neutral Kit 30-100 A DT100NK
Neutral Kit 200 A DT200NK
Neutral Kit 400-600 A DT800NK
Class J Fuse Field Conversion Kit 400 A (600 V only) DT400JK
Equipment Ground Kits 30-101 A Kit DS100GK
Equipment Ground Kits 200 A Kit DS200GK
Equipment Ground Kits 400-800 A Kit DS468GK
Class R Fusing Kit - Field Installable for 3 Poles 30 A (240V) DS12FK
Class R Fusing Kit - Field Installable for 3 Poles 30 & 60 A DS16FK
Class R Fusing Kit - Field Installable for 2 Poles 60 A (600V) DS26FK
Class R Fusing Kit - Field Installable for 3 Poles 100 A (240V & 600V) DS36FK
Class R Fusing Kit - Field Installable for 3 Poles 200 A (240V & 600V) DS46FK
Class R Fusing Kit - Field Installable for 3 Poles 400 A (240V & 600V) DS56FK
Class R Fusing Kit - Field Installable for 3 Poles 600 A (240V & 600V) DS66FK
T Fuse Clip for 3 Pole 200A (240V) DS426TK
T Fuse Clip for 3 Pole 200A (600V) DS466TK
T Fuse Clip for 1 Pole 400A (240V) DS526TK1
T Fuse Clip for 1 Pole 400A (600V) DS566TK1
T Fuse Clip for 1 Pole 600A (240V) DS626TK1
T Fuse Clip for 1 Pole 600A (600V) DS666TK1
Conduit Hub - 3˝ for 200A Type 3R (240V & 600V) TC300
*Standard Delivery - 4 weeks
SAFETYSWITCHES
FOUR-WIRE SN, 240 V AC, NO FUSE - EMERGENCY POWER TRANSFER SWITCH
Accessory Type Switch Amp
Rating
Description Voltage Stock Number
Neutral Kits 30 (5) 1/0-14 with bond strap 240 TNK100
Neutral Kits 60 (5) 1/0-14 with bond strap 240 TNK100
Neutral Kits 100 (5) 1/0-14 with bond strap 240 TNK100
Neutral Kits 200 (5) 1/0-14 with bond screw 240 TNK200
Neutral Kits 400 (3) 2-600MCM with bond lug 240 TNK400
Neutral Kits 60 (5) 1/0-14 with bond strap 600 TNK100
Neutral Kits 100 (5) 1/0-14 with bond strap 600 TNK100
Neutral Kits 200 (5) 1/0-14 with bond screw 600 TNK200
Ground Kits 30 (4) 14-8 AWG CU or 12-8 AWG AL plus
(3) 14-4 AWG CU or 6-4 AWG AL G-E TGL1
Ground Kits 60 (4) 14-8 AWG CU or 12-8 AWG AL plus
(3) 14-4 AWG CU or 6-4 AWG AL G-E TGL1
Ground Kits 100 (3) #12-1/0 AWG CU/AL TNG3
Ground Kits 200 (3) #12-1/0 AWG CU/AL TNG3
Ground Kits 400 (3) #2-250MCM CU/AL TGL6
Ground Kits 600 (3) #2-250MCM CU/AL TGL6
Auxiliary Contact Kit
(Field Installed) 30-600 Auxiliary Contact Kit - Field installed for
NEMA 1 and NEMA 3R TC Switches THAUXDT
www.vikingelectric.com 13
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
TP1HIGHEFFICIENCYTRANSFORMERS
TRANSFORMERS
TP1-HIGH EFFICIENCY TRANSFORMERS
STOCK NUMBER DESCRIPTION
(3Ph, 480V to
208/120V, AL 150˚C)
G-E 9T83B3871 15 kVA
G-E 9T83B3872 30 kVA
G-E 9T83B3873 45 kVA
G-E 9T83B3874 75 kVA
G-E 9T83B3875 112.5 kVA
G-E 9T83B3876 150 kVA
GeneralPurposeTransformers
Advantages:
• Quiet performance - Unique core and coil design makes QL transformers among the quietest available
• No-weld design - Bolted coil terminations are more reliable than welded terminations, and they
eliminate weld failures and problems associated with welding and weld splatter.
• Comprehensive factory testing assures quality - 100% factory tested for shorts and coil integrity;
current and loss, voltage, impedance and noise.
• Easy, fast installation saves time - Single-piece front/back is easily removable for service. Acccessible
mounting flanges with front/back slotted mounting holes make installation easier
• Clear, comprehensive documentation and labeling enhance safety
Application QL General
Purpose
QL Ultra
Efficient
QL K - Factor
(K=4)
QL K - Factor
(K=13)
QL K - Factor
(K=20)
QL K - Factor
(K=30)
QL Low
Noise
QL Drive
Isolation
AC or DC variable speed drives ■
Computer installations ■ ■
Critical care facilities ■ ■ ■
Data processing equipment circuits ■ ■
HID lighting ■
Hospital operating rooms ■ ■
Incandescent lighting ■ ■
Induction heaters ■
Instrumentation ■ ■
LEED projects ■
Maximum energy efficiency ■
Motor generators (without solid state drives) ■ ■
Motors ■ ■
Multiple receptacle circuits in heath care facilities ■
Office buildings ■ ■ ■
PLC & solid state controls ■
Production or assembly line equipment ■
Programmable controllers ■ ■
Rectifier outputs ■
Resistance heating ■ ■
Schools & classroom facilities ■ ■ ■
SCR variable speed drives ■ ■
UPS with optional input filtering ■
UPS without optional input filtering ■
Welders ■
X-ray equipment ■ ■
LEED is a registered trademark of the U.S. Green Building Council.
QLTransformerSelectionGuide
www.vikingelectric.com
14
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
PANELBOARDSELECTIONGUIDE
PANELBOARDSELECTIONGUIDE
AEU1182RCXAXT1B4
Interior Type Phase Number of Circuits Maximum Amp Rating Feed-Thru/Non Feed-Thru Bus
AQU = 240Vac
AEU = 480V/277Vac
1 = 1 Phase
3 = 3 Phase
18 = 18 circuits
30 = 30 circuits
42 = 42 circuits
2 = 225A
4 = 400A
6 = 600A
T1 = Feed-thru
Blank = Non Feed-thru*
(requires copper bus (B4)
*For retrofit applications DEP-104
B4 = Copper
Blank = Aluminum
Pro-StockInteriorsCatalogNumberStructure
StartyourprojectfastwithPro-StockPanelboards
Pro-Stock panelboards use modular kits that form hundreds of different
panelboards, all available now from your distributor’s stock. A range of interiors,
boxes, fronts, kits and accessories give you everything you need to assemble
the right panelboard, right now.
And not just any panelboard, either, but one that delivers:
•Flexibility – kits for main or subfeed breakers, main or feed-thru lugs, 200%
neutrals and service entrance ratings
•Simplicity – one interior for top or bottom feed, main lug or main breaker
•Choice – either electronic trip or thermal magnetic breakers
Need to move fast?
Choose Pro-Stock panelboards and
other Pro-Stock Projects products
from Viking Electric Supply.
www.vikingelectric.com 15
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
PANELBOARDSELECTIONGUIDE
PANELBOARDSELECTIONGUIDE
1. SELECT INTERIOR
Select the interior by bus type, panel rating and number of circuits. Identify the box/front height for use in Steps 2 and 3.
Copper Bus
Voltage Amp
Rating
No. of
Circuits
Feed-thru Non Feed-thru TGL2 Ground
Bars2, 3
Stock Number1Box/Front Height Stock Number1Box/Front Height
240 Vac,
1 Phase
100-
225
18 AQU1182RCXAXT1B4 37.5” AQU1182RCXAXB4 31.5” 2
30 AQU1302RCXAXT1B4 43.5” AQU1302RCXAXB4 37.5” 3
42 AQU1422RCXAXT1B4 49.5” AQU1422RCXAXB4 43.5” 4
400 18 AQU1184RCXAXT1B4 64.5” – – 2
42 AQU1424RCXAXT1B4 76.5” AQU1424RCXAXB4 64.5” 4
600 18 AQU1186RCXAXT1B4 64.5” – – 2
42 AQU1426RCXAXT1B4 76.5” AQU1426RCXAXB4 64.5” 4
208/120
Vac,
3 Phase
100-
225
18 AQU3182RCXAXT1B4 37.5” AQU3182RCXAXB4 31.5” 2
30 G-E AQU3302RCXAXT1B4 43.5” AQU3302RCXAXB4 37.5” 3
42 G-EAQU3422RCXAXT1B4 49.5” AQU3422RCXAXB4 43.5” 4
400 18 AQU3184RCXAXT1B4 64.5” – – 2
42 G-E AQU3424RCXAXT1B4 76.5” AQU3424RCXAXB4 64.5” 4
600 18 AQU3186RCXAXT1B4 64.5” – – 2
42 AQU3426RCXAXT1B4 76.5” AQU3426RCXAXB4 64.5” 4
480/277
Vac,
3 Phase
100-
225
18 G-E AEU3182RCXAXT1B4 37.5” AEU3182RCXAXB4 31.5” 2
30 G-E AEU3302RCXAXT1B4 43.5” AEU3302RCXAXB4 37.5” 3
42 G-E AEU3422RCXAXT1B4 49.5” AEU3422RCXAXB4 43.5” 4
400 18 AEU3184RCXAXT1B4 64.5” – – 2
42 G-E AEU3424RCXAXT1B4 76.5” AEU3424RCXAXB4 64.5” 4
600 18 AEU3186RCXAXT1B4 64.5” – – 2
42 AEU3426RCXAXT1B4 76.5” AEU3426RCXAXB4 64.5” 4
Interior Type No. of TGL20s Required by Panel Rating
100-225A 400A 600A
Main Lug Only 1 1 2
Main Lug & Feed-thru 2 2 4
Main Breaker Only 1 1 1
Main Breaker & Sub-feed 1 1 1
Main Breaker & Feed-thru 2 2 3
1 For CSA label, add “M8” suffix to catalog number.
Not available for 600A AEU catalog numbers.
2 TGL20 Ground Lug Quantities.
3 For isolated ground, use EGS12. When using the EGS12, 3, 5 and 7 ground lugs (TGL20s)
are required for 18, 30 and 42 circuits respectively. For more information, see BuyLog (GEP-
1100), Section 9.
Aluminum Bus
Voltage Amp
Rating
No. of
Circuits
Feed-thru
Stock Number1
Box/Front
Height
TGL2 Ground
Bars2,3
240 Vac,
1 Phase
100-
225
18 AQU1182RCXAXT1 37.5” 2
30 G-E AQU1302RCXAXT1 43.5” 3
42 G-E AQU1422RCXAXT1 49.5” 4
208/120
Vac,
3 Phase
100-
225
18 G-E AQU3182RCXAXT1 37.5” 2
30 G-E AQU3302RCXAXT1 43.5” 3
42 G-E AQU3422RCXAXT1 49.5” 4
480/277
Vac,
3 Phase
100-
225
18 G-E AEU3182RCXAXT1 37.5” 2
30 G-E AEU3302RCXAXT1 43.5” 3
42 G-E AEU3422RCXAXT1 49.5” 4
2. SELECT BOX
Select a box of the correct height (see Step 1). Boxes come with blank endwalls. If end-
walls with knockouts are required, also order knockout endwall kit AKEW2
Box Height NEMA 1 NEMA 3R/12
20” Wide 30” Wide 20” Wide
Stock Number1Stock Number 1Stock Number 1
31.5” G-E AB31B AB31BW AB313
37.5” G-E AB37B AB37BW AB373
43.5” G-E AB43B AB43BW AB433
49.5” G-E AB49B AB49BW G-E AB493
64.5” G-E AB64B AB64BW AB643
76.5” G-E AB76B AB76BW AB763
1 For CSA label, add “A” suffix to catalog number.
NEMA 1
NEMA 3R/12
www.vikingelectric.com
16
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
PANELBOARDSELECTIONGUIDE
PANELBOARDSELECTIONGUIDE
3. SELECT FRONT
Select a front of the correct height (see Step 1). For additional front options, see Section 9 of the BuyLog® Catalog
(GEP-1100)
Front
Height
Standard (20” wide) Door Within Door (20” wide) Front Hinged To Box (20” wide) Standard (30” Wide)
Flush1Surface1Flush1Surface1Flush1Surface1Flush1Surface1
31.5” AF31F G-E AF31S AF31FP AF31SP AF31FD AF31SD AF31FW AF31SW
37.5” G-E AF37F G-E AF37S AF37FP AF37SP AF37FD AF37SD AF37FW AF37SW
43.5” G-E AF43F G-E AF43S AF43FP AF43SP G-E AF43FD AF43SD AF43FW AF43SW
49.5” G-E AF49F G-E AF49S AF49FP AF49SP G-E AF49FD G-E AF49SD AF49FW AF49SW
64.5” AF64F AF64S AF64FP AF64SP AF64FD AF64SD AF64FW AF64SW
76.5” G-E AF76F G-E AF76S AF76FP AF76SP AF76FD AF76SD AF76FW AF76SW
1 For CSA label, add “A” suffix to catalog number.
4. SELECT MAIN AND/OR SUB-FEED BREAKER KIT
Select a main breaker kit appropriate for your interior type (see Step 1), amp rating and kAIC rating. If a sub-feed breaker is
required, repeat this selection process. Circuit breakers are only included in kits ending in “WB”. “WB” kits include a breaker,
mounting kit and load-side lugs; rating plugs sold separately.
Interior
Type
Stock Num-
ber
Panel
Amps
No. of
Poles
Breaker Rating (kAIC)
10 14 22 25 65 100 200
AQU1:
240 VAC,
1 Phase
G-E MB612 100 2 THQB THHQB
MB614 100 4 (2) THQB (2) THHQB
G-E MB512 225 2 TQD THQD
MB335WB 400 2 SGDA+Kit
MB332 400 2 SGHA SGLA SGPA
MB332 600 2 SGHA SGLA SGPA
MB332WB 600 2 SGHA+Kit
AQU3:
208/120
VAC,
3 Phase
G-E MB613 100 3 THQB THHQB
MB616 100 65(2) THQB (2) THHQB
G-E MB513 225 3 TQD THQD
MB516 400 65(2) TQD (2) THQD
MB233 225 3 SFHA SFLA SFPA
MB233WB 225 3 SFHA+Kit
MB23324400 64,5 2nd SFHA
MB2332WB4400 64,5 2nd
SFHA+Kit
MB331WB 400 3 SGDA+Kit
MB333 400 3 SGHA SGLA SGPA
MB333 600 3 SGHA SGLA SGPA
MB333WB 600 3 SGHA+Kit
AEU3:
480/277
Vac,
3 Phase
G-E MB423 100 3 TEY
MB426 100 65(2) TEY
MB133 150 3 TED1THED
MB133 150 3 SEHA SELA SEPA
G-E MB133WB 150 3 SEHA+Kit
MB233 225 3 SFHA3SFLA SFPA
G-E MB233WB 225 3 SFHA+Kit3
MB23324400 64,5 2nd SFHA3
MB2332WB4400 64,5 2nd
SFHA+Kit3
MB334WB 400 3 SGHA+Kit
MB333 400 3 SGHA3SGLA SGPA
MB333 600 3 SGHA3SGLA SGPA
MB333WB 600 3 SGHA+Kit3
1 Actual breaker rating is 18kAIC
2 Actual breaker rating is 30kAIC.
3 Actual breaker rating is 35kAIC.
4 To achieve 6 poles of subfeed, the MB233WB or MB233 kit is also required.
5 6 poles of subfeed applies only to 400A and 600A interiors.
Door within Door
Standard
Front Hinged to Box
MB513 - Breaker Kit
MB516 - 6-pole Breaker Kit
MB233WB - “WB” Breaker Kit
www.vikingelectric.com 17
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
PANELBOARDSELECTIONGUIDE
PANELBOARDSELECTIONGUIDE
5. TYPICAL MAIN BREAKERS
•SkipStep5ifyouselectedamainbreakerkitendingin“WB”–nobreakerisrequired.
•TocorrelatebreakertypeswiththekAICrating,seethetableforStep4.Formoreratingdetails,seeA-SeriesLightingPanelsRatingSeriesLabels(DEH-40007).
•AllTQDandSpectramainbreakersrequireload-sidelugs.
•ForTEYandTHQBmainbreakers,seebranchbreakerstablesinStep7.
DIGITAL, SOLID STATE SPECTRA RMS™ BREAKERS (3-POLE)
For use with appropriate main breaker kit. See Step 4.
Breaker Rating Plug1Terminal Lugs for Front Connection2
Poles Current
Sensor
Stock Number Amp Rating Stock Number Stock Number Wire Range (Cu/Al)
3100 G-E SEDA36AT0100
SEHA36AT0100
SELA36AT0100
SEPA36AT0100
100 G-E SRPE100A100 G-E TCAL18 #12-3/0
150 SEDA36AT0150
SEHA36AT0150
SELA36AT0150
SEPA36AT0150
110
125
150
SRPE150A110
G-E SRPE150A125
G-E SRPE150A150
250 SFHA36AT0250
SFLA36AT0250
SFPA36AT0250
70
90
100
110
125
150
175
200
225
SRPF250A70
SRPF250A90
SRPF250A100
G-E SRPF250A110
SRPF250A125
G-E SRPF250A150
G-E SRPF250A175
G-E SRPF250A200
G-E SRPF250A225
G-E TCAL29 #8-350 MCM
3400 SGHA36AT0400
SGLA36AT0400
SGPA36AT0400
125
150
175
200
225
250
300
350
400
SRPG400A125
SRPG400A150
SRPG400A175
SRPG400A200
SRPG400A225
SRPG400A250
SRPG400A300
SRPG400A350
SRPG400A400
TCLK365 Al: (2) 2/0-500
MCM or (1)
#6-600 MCM Cu: (2) 2/0-400
MCM or (1)
#8-600 MCM
2400 SGHA26AT0400
SGLA26AT0400
SGPA26AT0400
TCLK265
3600 SGLA36AT0600
SGPA36AT0600
250
300
350
400
500
600
SRPG600A250
SRPG600A300
SRPG600A350
SRPG600A400
SRPG600A500
SRPG600A600
TCLK365
2600 SGLA26AT0600
SGPA26AT0600
TCLK265
1 Any rating plug within a given current sensor group may be paired with any breaker in that group.
2 Except for “WB” kits, lugs must be ordered separately for Spectra breakers. All Spectra breakers also require an appropriate rating plug.
MAIN OR SUBFEED BREAKERS For use with AQ panels (208/120Vac 3-phase
or 240Vac single phase). See Step 4.
Amp
Rating
2-pole 3-pole
10kAIC 22kAIC 10kAIC 22kAIC
Stock Number1Stock Number Stock Number1Stock Number
100 TQD22100X2 THQD22100X2 TQD32100X2 THQD32100X2
125 TQD22125X2 THQD22125X2 TQD32125X2 THQD32125X2
150 TQD22150X2 THQD22150X2 TQD32150X2 THQD32150X2
175 TQD22175X2 THQD22175X2 TQD32175X2 THQD32175X2
200 TQD22200X2 THQD22200X2 TQD32200X2 THQD32200X2
225 TQD22225X2 THQD22225X2 TQD32225X2 THQD32225X2
250 – TJD422250L2 – TJD432250L3
300 – TJD422300L2 – TJD432300L3
350 – TJD422350L2 – TJD432350L3
400 – TJD422400L2 – G-E TJD432400L3
1 Any load-side lugs on TQD breakers must be removed before assembly. TQD breakers with X2 catalog
number suffix feature line-side lugs only. Use TQD breakers for X2 for main; no suffix for subfeed
breaker.
MAIN OR SUBFEED BREAKERS For use with AE panels (480/277Vac
3-phase). See Step 4.
Amp
Rating
3-pole
18kAIC 25kAIC 30kAIC
Stock Number Stock Number Stock Number
110 TED134110WL THED134110WL G-E MB233WB
125 G-E TED134125WL THED134125WL G-E MB233WB
150 G-E TED134150WL THED134150WL G-E MB233WB
175 – – G-E MB233WB
200 – – G-E MB233WB
225 – – G-E MB233WB
250 – – TJJ436250L3
300 – – TJJ436300L3
350 – – TJJ436350L3
400 – – TJJ436400L3
www.vikingelectric.com
18
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
PNELBOARDSELECTIONGUIDE
PANELBOARDSELECTIONGUIDE
6. SELECT MAIN LUG KIT & ACCESSORIES
Select lug kit(s) for main lug and/or feed-thru applications, if required. Also select any
accessories required. For details and prices on other available accessories, see Section 9 of the BuyLog® Catalog (GEP-1100).
•Alllugsaresuitableforinteriorswitheithercopperoraluminumbus.
Lug Type Amp
Rating
Standard Oversized 200%
Neutral
Stock
Number
Wire Range Stock
Number
Wire Range Stock
Number
Pressure 225 G-E MLA1 6-350 MCM G-E MLA2 1-600 MCM or
(2) 1/0-250 MCM
G-E NKA
400 G-E MLA41 1-600 MCM or
(2) 1/0-250 MCM
MLA62 3/0-800 MCM NKA43
600 G-E MLA61 (2) 2/0-500 MCM MLA62 3/0-800 MCM –
Copper 225 G-E MLR1 4-350 MCM MLR2 1-600 MCM NKR
400 MLR41 1-600 MCM MLR61 (2) 2/0-500 MCM NKR4
600 MLR61 (2) 2/0-500 MCM – – –
Compression 225 MLT1 2/0-300 MCM MLT2 4/0-500 MCM NKT
400 MLT42 250-600 MCM MLT41 500-750 MCM1NKT4
Dual 225 G-E MLA2 1-600 MCM or
(2) 1/0-250 MCM
– – –
Main 400 G-E MLA61 (2) 2/0-500 MCM – – –
1 500 MCM Cu, 750 MCM Al
3 For 200% neutral feed-thru, order NKA4FT. Wire range (2) 2/0-600 MCM or (4) 4-250 MCM.
ProCare Kit2
Description Stock Number
ProCare Kit for Pro-Stock panel- board installation & maintenance PROCARE
3 ProCare Kit includes:
(5) filler plate hardware kits
(9) bus stud nuts
(5) MLA1 filler plates
(2) 225A phase barriers
(2) feed-thru barriers
(1) 400/600A phase barrier
(50) directory cards/rating books
(50) circuit number strips (1-84)
(50) circuit number strips (85-168)
(5) standard locks & keys
(50) deadfront screws
(10) AQ/AE front hardware kits
(10) AD front hardware kits
(50) service disconnect labels
(50) main labels
Accessories
Service Entrance1
Amp Rating Stock Number
225A G-E BNDKT
400A BNDKT6
600A BNDKT6
1 Service entrance kit includes a bonding strap with hardware and a
service entrance label.
www.vikingelectric.com 19
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
PANELBOARDSELECTIONGUIDE
PANELBOARDSELECTIONGUIDE
7. SELECT BOLT-ON BRANCH BREAKERS
Typical branch breakers are listed below. This list does not include all branch breakers that can be used
with Pro-Stock panelboards. For details on other branch breakers, see Section 9 of the BuyLog® Catalog
(GEP-1100).
Branch Circuit Breakers For use with AQ panels (208/120Vac 3-phase or 240Vac single phase).
Amp
Rat-
ing
10kAIC 22kAIC
1-pole 2-pole 3-pole 1-pole 2-pole 3-pole
Stock
Number
Stock Number Stock Number Stock
Number
Stock Number Stock
Number
15 G-E THQB1115 G-E THQB2115 G-E THQB32015 THHQB1115 THHQB2115 THHQB32015
20 G-E THQB1120 G-E THQB2120 G-E THQB32020 THHQB1120 THHQB2120 THHQB32020
25 G-E THQB1125 G-E THQB2125 G-E THQB32025 THHQB1125 THHQB2125 THHQB32025
30 THQB1130 G-E THQB2130 G-E THQB32030 THHQB1130 THHQB2130 THHQB32030
35 G-E THQB1135 THQB2135 THQB32035 THHQB1135 THHQB2135 THHQB32035
40 G-E THQB1140 G-E THQB2140 G-E THQB32040 THHQB1140 THHQB2140 THHQB32040
45 THQB1145 THQB2145 THQB32045 THHQB1145 THHQB2145 THHQB32045
50 THQB1150 G-E THQB2150 G-E THQB32050 THHQB1150 THHQB2150 THHQB32050
60 THQB1160 G-E THQB2160 G-E THQB32060 THHQB1160 THHQB2160 THHQB32060
70 THQB1170 G-E THQB2170 G-E THQB32070 THHQB1170 THHQB2170 THHQB32070
80 – THQB2180 G-E THQB32080 – THHQB2180 THHQB32080
90 – THQB2190 G-E THQB32090 – THHQB2190 THHQB32090
100 –G-E THQB21100 G-E THQB32100 –G-E THHQB21100 THHQB32100
8. SELECT INTEGRATED TRANQUELL ME TVSS
Select appropriate transient voltage surge suppressor – 65kA symmetrical fault withstand.
Maximum
Surge Current
Configuration Stock Number (Replace xxxx with
selected nominal voltage from table
below)
65kA per mode / 130kA per phase Lights, Alarm, Surge Counter, Form C Contacts TPMExxxx06PS
80kA per mode / 160kA per phase Lights, Alarm, Surge Counter, Form C Contacts TPMExxxx08PS
100kA per mode / 200kA per phase Lights, Alarm, Surge Counter, Form C Contacts TPMExxxx10PS
100kA per mode / 200kA per phase Lights, Alarm, Contacts, No Surge Counter, No Filter TPMExxxx10PSNC
100kA per mode / 200kA per phase Lights, Alarm, Surge Counter, Contacts, No Filter TPMExxxx10PSNF
Nominal Voltage
(Volts RMS)
Configuration MCOV% Suppressed Voltage Rating Stock Number Digits
(Replace xxxx in table
above)
Max. Continuing
Operating Voltage
UL 1449 2nd Edition
L-N / L-G / N-G
120/240 1 Phase, 3 Wire + Ground 125% 500 / 500 / 500 120S
120Y/208 3 Phase, 4 Wire + Ground 125% 500 / 500 / 500 120Y
240 Delta 3 Phase, 3 Wire + Ground 115% - / 800 / - 240D
120/240 Delta HL 3 Phase, 4 Wire + Ground 115% 500/700 / 500/700 / 500 240H
277Y/480 3 Phase, 4 Wire + Ground 115% 800 / 800 / 800 277Y
Branch Circuit Breakers For use with AE panels
(480/277Vac 3-phase).
Amp
Rating
14kAIC
1-pole 2-pole 3-pole
Stock
Number
Stock
Number
Stock
Number
15 G-E TEY115 G-E TEY215 G-E TEY315
20 G-E TEY120 G-E TEY220 G-E TEY320
30 G-E TEY130 G-E TEY230 G-E TEY330
40 TEY140 TEY240 G-E TEY340
50 TEY150 G-E TEY250 G-E TEY350
60 TEY160 TEY260 G-E TEY360
70 TEY170 TEY270 G-E TEY370
80 TEY180 TEY280 G-E TEY380
90 TEY190 TEY290 G-E TEY390
100 TEY1100 TEY2100 G-E TEY3100
www.vikingelectric.com
20
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
LIGHTINGCONTACTORQUICKSELECTOR
CR460 SERIES LIGHTING CONTACTORS ASSEMBLY
STEPS Stock Number Description
Step1 Combined with other appropriate components, basic contactors allow
configuration into any available electrically or mechanically held model.
Choose Basic
Contactor
G-E 463L20AJA* Base with 2NO Contacts
AC 60 Hz Coil Voltage 115-120V
AC 50 Hz Coil Voltage 110V
G-E 463L20ANA* Base with 2NO Contacts
* Includes one 2 NO open contact power pole.
Step 2 460 Series basic contactors accept up to 6 single- or double-pole
power poles
Select Power
Poles
G-E 460XP31* SINGLE POLE Maximum Amp Rating 30 Amp
G-E 460XP32* DOUBLE POLE Maximum Amp Rating 30 Amp
*12 NO poles when 6 double-poles are used in the NO positions (1-6) or *8 NC poles with 4 double poles in the NC
positions (1-4)
+ 4 NO poles with 2 double-poles in the 2 NO positions (5-6).
Step 3 Kits for converting electrically held contactors to a mechanically held
version. Kits include control module, latch, latch cover and auxiliary con-
tacts plus installation instructions. Conversion kits are suitable for coil
voltages 277V and below. Use CPT to reduce coil voltage if line voltage
is higher than 277V.
Select
Conversion Kit
(for Mechanically Held
Contactors Only)
G-E 460XMC* 24-277Vac Coil Volts, 2 wire control, 110-120Vac
Control Volts
460XMM* 24-277Vac Coil Volts, 3 wire control, 24Vac Control
Volts
G-E 460XMN* 24-277Vac Coil Volts, 3 wire control, 110-120Vac
Control Volts
* Kits are used to convert electrically held contactors to a mechanically version. Kits includes control module, latch, latch
cover and auxiliary contacts plus installation instructions.
Step 4 Each contactor may use one single or one double auxiliary contact block
on each side of the base. When installed on the left side the contacts
are NO, when installed on the right side the contacts are NC. This allows
a total of 2NO + 2NC contacts maximum.
Do You Need
Auxiliary Contacts?
460XB1 One Pole
460XB2 Double pole
* Each Contactor may use one single or one double auxiliary contact block on each side of the base. When installed on
the left side the contacts are NO, when installed on the right side the contacts are NC.
Step 5 Enclosure accessory kits contain accessory and complete installa-
tion wiring and hardware. Some kits contain multiple nameplates for
alternate markings.
Do You Need an
Enclosure?
G-E 460XE1B Nema 1 Enclosure with no provisions for CPT or
pilot device
Step 6
Order Spare Coils if
Required
G-E 460XCC Coil Voltages: AC, 60HZ 24V AC, 50 HZ 20V
G-E 460XCJ Coil Voltages: AC, 60HZ 115-120V AC, 50HZ 110V
460XCL Coil Voltages: AC, 60HZ 200-208V ONLY
G-E 460XCN Coil Voltages: AC, 60 HZ 277V AC, 50 HZ 240V
460XCS Coil Voltages: AC, 60HZ 230-240V AC, 50 HZ 220V
460Series
MechanicallyHeldLighting
Contactors
Features:
• Two- or three-wire control module
• Low input VA permits long wire runs
• Verifies contact status and has built-in
delays that minimize excessively frequent
signals from faulty controllers
• Come in a wide range of input voltages and
with coils from 24Vac to 277Vac an 12Vdc
to 24Vdc
• Clear labeling shows control module rating,
wire size and torque
• Field configurable from standard electrically
held contactor with simple, easy-to-install
kits of control modules, protected from latch
mechanisms and auxiliary contacts
LIGHTINGCONTACTORS
www.vikingelectric.com 21
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
DURASTATION,WATTSTATION,WALLWATTSTATION
ELECTRICVEHICLECHARGERS
GE’s Electric Vehicle Chargers are suitable for both commercial and residential applications and offer Level
II charging, which is capable of reducing charge time from 12-18 hours to 4-8 hours, with service needs of
208/240VAC at 40A, assuming a 24kWh battery and a full cycle charge.
Popular features and benefits include:
• Cord holder that keeps the cord organized and out of the way
• LEDs display status
• Pedestal mount (Durastation and WattStation) or wall mount (WattStation)
• Options for Radio Frequency Identification (RFID) reader and/or commerce and card reader capability
• LED lights and display
• Nuisance tripping avoidance and auto reclosure.
• Vehicle ground monitoring circuit.
DuraStation standards and approvals:
SAE J1772, NEC 625, UL 2231, 2251, 2594, cUL 2231, 2594, NEMA and NIST
WattStation standards compliance:
SAE J1772, NEC 625, cETL and ETL listed, UL 2594, cUL 2594, NEMA and NIST, ADA Compliance
WATTSTATION EV CHARGERS
Stock Number Description
EVWSWBH Wall Mount, black hardwired, NEMA 3R
EVWSWBC Wall Mount, black NEMA 6-50P plug, NEMA 3R
EVWPR3GEXXGB Pedestal Assembly - CAT5 (ethernet only)
EVWPR3GWXXGB Pedestal Assembly - WiFi + CAT5
EVWPR3GZXXGB Pedestal Assembly - Cellular CDMA for Verizon + CAT5
EVWPR3GFXXGB Pedestal Assembly - Cellular GSM for Vodafone + CAT5
EVWT3GREXXGB Head ASM - CAT5 (ethernet only)
EVWT3GRWXXGB Head ASM - WiFi + CAT5
EVWT3GRZXXGB Head ASM - Cellular CDMA for Verizon + CAT5
EVWT3GRFXXGB Head ASM - Cellular GSM for Vodafone + CAT5
EVWSDR01 Service access door
EVWSKEY01 Service door keys
EVWSCRR01 Cord reel
EVWSBRH01 Cord reel brushes
EVWSBLL01 Cord reel bellows
EVWSINL01 Inlet
EVWSFSB01 Fuse block
EVWSIPR01 IP Address reset harness
EVRCG50 Pack of 10 GE RFID Cards
EVWSETS01 4 Port Ethernet Switch
EVWSPWR01 24V Power Supply
EVWSMNT01 Mounting hardware
EVRP01 RFID enrollment reader CM5321CL USB – 13.45MHz
EVRP02 RFID enrollment reader CM5325CL USB – 125kHz
DURASTATION EV CHARGER
Stock Number Type Enclosure Connectors RFID
EVSN3 Single
Pedestal NEMA 3R 1 No
EVSRN3 Yes
EVDN3 Double
Pedestal NEMA 3R 2 No
EVDRN3 Yes
EVPN3 Pole NEMA 3R 1 No
EVPRN3 Yes
EVWN3 Wall NEMA 3R 1 No
EVWRN3 Yes
All units are 208/240V, 30A out, single phase integrated meter
ACCESSORIES
Stock Number Description
EVRP01 CM5321CL - 13.45MHz (comes with CD
and pack of GE RFID cards
EVRP02 CM5325CL USB reader - 125kHz (comes
with CD)
EVRP03 RP40 (comes with CD and pack of GE
cards)
EV100CD CD with RFID EV100 software
EVRCW10 Pack of 10 white RFID cards
EVRCG10 Pack of 10 GD-esigned RFID cards
Contact your Viking Electric Supply sales
representative for additional information.
DuraStation
Pedestal WattStation
Residential Wall Mount
WattStation
www.vikingelectric.com
22
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
EVERGOLD™SAFETYSWITCHESANDCOMBINERBOXES
EVERGOLD™SOLARSOLUTIONS
600VDC EVERGOLD™ SOLAR DUTY SAFETY SWITCHES
One-Pole, 600Vdc, Non-Fusible One-Pole, 600Vdc, Fusible
Amps Isc Rating -
Amps (NEC)
Type 1 Type 3R Type 1 Type 3R
30 19.2 TSN161 TSN161R TS161 TS161R
60 38.4 TSN162 TSN162R TS162 TS162R
100 64.0 TSN163 TSN163R TS163 TS163R
GE’s EverGold™ Solar Duty Safety Switches are designed for use in commercial and residential negative grounded
photovoltaic systems. UL listed for 600Vdc, they are designed for use as a disconnect for photovoltaic applications
per NEC 690.
• G-90 galvanized steel enclosrues for prolonged enclosure
life
• White powder coat finish for reduced internal operating
temperature and easy identification
• 3-point enclosure mounting helps reduce installation time
• Lockable over center cover latches (Type 3R) for waterproof
protection and security
• Easy access cover interlock defeat mechanism for security
and maintenance
• Vertically hinged “side-swing” cover for easy access to
electrical connections
• Ample gutter space (top, bottom, side) helps reduce wiring
time
• Highly visible bright yellow operating handle with fireman-
friendly grip
• Bright yellow PV disconnect arc shield helps guard against
accidental contact with live parts
• Bright red PV disconnect (NEC 690.17) warning label is
factory installed
• Factory installed Class R fuse clips on center pole for
isolation per NEC requirements
• Factory installed negative and equipment ground
connections
EVERGOLD™ SOLAR COMBINER BOX 12 & 24 CIRCUITS FUSED
Stock Number Number of
Inputs
Maximum
Fuse Size
Max
Rated
Current
Volts
Maximum
Number of
Outputs
Input
AWG
Output AWG Enclosure
Type
Dimensions
(in.)
H / L / W
Weight
(lb.)
TSCF126R 12 30 Amps 180 Amps 600VDC 1 #14-6 #6-350kcmil 3R 21.0x12.5x4.2 20
TSCF246R 24 30 Amps 360 Amps 600VDC 2 #14-6 #6-350kcmil 3R 21.0x12.5x4.2 20
TSCF126X 12 30 Amps 180 Amps 600VDC 1 #14-6 #6-350kcmil 4X 16.1x14.3x9.0 17
TSCF246X 24 30 Amps 360 Amps 600VDC 2 #14-6 #6-350kcmil 4X 18.0x16.0x9.0 19
GE’s EverGold™ Combiner Boxes offer a wide selection of circuit count and box styles to simplify solar system
installations. Choose from our standard NEMA 3R box or our innovative NEMA 4X fiberglass enclosure. Both box
options feature gasketed seals that offer increased protection from the elements and easy installation.
• NEMA 3R Steel & NEMA 4X Fiberglass Enclosures
• Touch Safe Fuse Holders
• 12 & 24 Input Terminals
• 30A maximum fuse capacity per terminal
• 60VDC rating
• 90C Output Termina
• UL-1741 Listed
www.vikingelectric.com 23
Items listed with a G-E prefix are stocked at Viking Electric Supply. Note however, not all items are stocked at all locations
THN3361JDC
Switch Type Fusing Number of Wires Number of
Poles
Maximum
Voltage
Rating
Ampere
Rating
Enclosure Type Other Features
TG = General Duty
TH - Heavy Duty
N = Non-Fusible
(blank) = Fusible
2 = 2 wire system
3 = 3 wire system
4 = 4 wire system
2 = 2 Poles
3 = 3 Poles
6 = 6 Poles
2 = 240 Vac
6 = 600 Vac
1 = 30 amps
2 = 60 amps
3 = 100 amps
4 = 200 amps
5 = 400 amps
6 = 600 amps
(blank) = NEMA Type 1
J = NEMA 5/12
M = NEMA 12 MILL DUTY
R = NEMA Type 3R
SS = NEMA 4/4X (304SS)
SS316 = NEMA 4/4x (316SS)
B = Bottom Feed
CL = Copper Lugs
DC = 600 Vdc Rated
F = Vertically Hinged Door
W = Viewing Window
SpecSetter™SafetySwitches
GEPARTNUMBERNOMENCLATURE
GEPARTNUMBERNOMENCLATURE
AEU1182RCXAXT1B4
Interior Type Phase Number of Circuits Maximum Amp Rating Feed-Thru/Non Feed-Thru Bus
AQU = 240Vac
AEU = 480V/277Vac
1 = 1 Phase
3 = 3 Phase
18 = 18 circuits
30 = 30 circuits
42 = 42 circuits
2 = 225A
4 = 400A
6 = 600A
T1 = Feed-thru
Blank = Non Feed-thru*
(requires copper bus (B4)
*For retrofit applications DEP-104
B4 = Copper
Blank = Aluminum
Pro-StockPanelboardInteriors
TM4220CCUB
GE Identification Type Maximum
Number of 1˝
Spaces
Bus Ampere
Rating
Enclosure Type Bus Type Insert for Specials
TM = Main Breaker
L = Main Lug
LM = Convertible
PL = Main Lug
Thermoplastic
Enclosure
4 - 42 10 = 100 amps
12 = 125 amps
15 = 150 amps
20 = 200 amps
22 = 225 amps
40 = 40 amps
60 = 60 amps
70 = 70 amps
C = Combination Flush and
Surface, Indoor
F = Flush
S = Surface
R = Outdoor
CU = Copper Bus G or T = Factory Installed
Ground Bar
B = Bottom Feed Main
Breaker
FL = Factory Installed
Feed-thru Lugs
D = Optional door for
6-8 circuit indoor panels.
(Doors are standard on all
other units)
LoadCenters
NOTES
451 Industrial Blvd. NE - Minneapolis, MN 55413
www.vikingelectric.com
BAXTER,MN56425
7650 Goedderz Road
PH 218-828-0151
FX 218-828-0399
BLAINE,MN55449
8844 West 35W Service Dr.
PH 763-572-0250
FX 763-572-0367
BURNSVILLE,MN55337
2601 West Hwy. 13
PH 952-890-8420
FX 952-882-0201
DULUTH,MN55807
4531 West 1st St.
PH 218-624-2200
FX 218-624-0209
GRANDRAPIDS,MN55744
807 Lily Lane
PH 218-326-5802
FX 218-326-5875
MINNEAPOLIS,MN55413
451 Industrial Blvd.
PH 612-627-1300
FX 612-627-1313
PLYMOUTH,MN55441
13870 Industrial Park Blvd.
PH 763-383-2929
FX 763-383-2930
ST.PAUL,MN55101
500 Broadway
PH 651-298-0666
FX 651-298-0665
05/2012
Viking Electric Supply is an EEO/AA Employer

Navigation menu
