LINE LOAD CLASS J
(AJT, A4J, HSJ)
CLASS T
(A3T/A6T)
RK1
(A2D/A6D)
(A2K/A6K)
HSRK
RK5
(TR/TRS)
CLASS G
(AG)
CLASS CC
(ATDR, ATQR,
ATMR)
BDB162/0X 175 100kA (1) 2/0-#14 (6) #2-#14 200A 200A 200A 100A 60A 30A
BDB11500X 380 100kA (1) 500-#4 (1) 500-#4 400A 400A 400A 200A 60A 30A
BDB16500X 380 100kA (1) 500-#4 (6) 2/0-#14 400A 400A 400A 200A 60A 30A
BDB22500X 760 100kA (2) 500-#4 (2) 500-#4 600A 600A 600A 200A 60A 30A
BDB26500X 760 100kA (2) 500-#4 (6) 2/0-#14 600A 600A 600A 400A 60A 30A
BDB212500X 760 100kA (2) 500-#4 (12) #4-#14 600A 600A 600A 400A 60A 30A
BDB22350X 620 100kA (2) 350-#6 (2) 350-#6 600A 600A 600A 200A 60A 30A
BDB26350X 620 100kA (2) 350-#6 (6) 2/0-#14 600A 600A 400A 200A 60A 30A
BDB112350X 310 100kA (1) 350-#6 (12) #4-#14 400A 400A 400A 200A 60A 30A
BDB16350X 310 100kA (1) 350-#6 (6) 2/0-#14 400A 400A 400A 200A 60A 30A
BDB24500X 760 100kA (2) 500-#4 (4) 4/0-#6 600A 600A 600A 400A 60A 30A
BDB22600X 840 100kA (2) 600-#2 (2) 600-#2 600A 600A 600A 400A 60A 30A
WIRE RANGE MAX REQUIRED OVERCURRENT PROTECTION
SCCRAMPS
CATALOG
NUMBER
REV
SIZE
DRAWING NO
B50031053
SHEET 1 OF 1 A
CAT. NO:
ITEM NO:
VERSIPOLE FUSE RATINGS
--
DRAWN BY:
CHECKER:
DSN APRVL:
MFG APRVL:
QA APRVL:
MKT APRVL:
PROD FAM:
PROJECT #:
DOCUMENT TY PE:
REL LEVEL:
V KAMAL
T REYNOLDS
T REYNOLDS
--
08/28/13
08/29/13
SALES
Released
TO ORDER BURNDY® PRODUCTS CALL
UNITED STATES
1-800-346-4175 (LONDONDERRY, NH)
CANADA:
1-800-361-6975 (QUEBEC)
1-800-387-6487 (ALL OTHER PROVINCES)
FOR PRODUCT INFO: http://www.burndy.com
08/29/13
M BAILLY 08/29/13
--
C KOWALCZYK 09/04/13
--
(SEE TABLE)
REV DATE DESCRIPTION ECO BY C'H'K.
A08/28/2013 CREATE SALES DRAWING AS PER MARK-UP 33059 VK PB
NOTES:
1. UL RECOGNIZED FOR 100kA SCCR WHEN PROTECTED BY FUSES AS SHOWN.
2 REPLACE X WITH 1, 2 OR 3 TO DENOTE THE NUMBER OF POLES.
3. RATINGS ARE FOR COPPER CONDUCTOR ONLY.
2
