gloves & sleeves
E-2 Gloves and Sleeves. www.salisburybyhoneywell.com
GLOVES & SLEEVES
Rubber and SALCOR® Protective Equipment
Rubber insulating gloves are available in six ASTM dened voltage classes. Rubber insulating
sleeves are available in Class 00 through 4. The chart below identies the class, proof test voltage
and maximum allowable exposure voltage.
For an 8.5 x 11 reprint of this chart, contact your local Salisbury representative.
Proof Test Max. Use Rubber
Class Voltage Voltage* Molded Glove Label Rubber Dipped
Color AC / DC AC / DC Products Sleeve Label
Label
Protective Rubber Equipment Labeling Chart
for Salisbury Linemen’s Natural Rubber and SALCOR® Rubber Protective Equipment
Insulating Gloves and Sleeves must have a color coded label to meet appropriate ASTM Specifications.
* Max. Use Voltage when worn with leather protectors.
00 2,500 / 10,000 500 / 750
Beige
0 5,000 / 20,000 1,000 / 1,500
Red
1 10,000 / 40,000 7,500 / 11,250
White
2 20,000 / 50,000 17,000 / 25,500
Yellow
3 30,000 / 60,000 26,500 / 39,750
Green
4 40,000 / 70,000 36,000 / 54,000
Orange
E-3
101 E. Crossroads Pkwy., Ste. A Bolingbrook, IL 60440 toll free ph (USA):877.406.4501 toll free fax (USA):866.824.4922 ph:630.343.3800
Manufactured for
outstanding protection,
comfort and long-life
Rubber insulating gloves are among
the most important articles of personal
protection for electrical workers.
Incorporating high dielectric and physical
strength, exibility and durability, Salisbury
rubber insulating gloves have earned the
reputation for superior performance
-
meeting and exceeding the requirements
of current ASTM D120 specications and
IEC EN60903 Standards.
Salisbury rubber insulating gloves are
manufactured by dipping porcelain forms
into a tank of liqueed rubber. The thin
layer of rubber which results is allowed
to dry and the process is repeated until the
required thickness is reached. Depending
on the voltage class of the glove, this
dipping-drying-dipping cycle may need
to be repeated over 30 times. After the
desired thickness is achieved, the gloves
are allowed to dry. Once dry, they are cut to length, the reinforcing bead
is rolled, and the ASTM label and manufacturing information is applied
along with any additional permanent marking that may be requested.
The gloves are cured in an autoclave under steam pressure and heat.
After curing, the gloves are visually inspected. Gloves with visual
imperfections are rejected. The gloves are then given a halogenation
treatment (chlorination) to increase the comfort and wearability. The gloves
are electrically tested following ASTM D120/IEC 903 specications.
Following the electrical test, the gloves are given a nal visual inspection.
The gloves are then ready to be boxed and shipped.
SALISBURY LINEMEN’S GLOVES
Glove Congurator
Visit www.salisburybyhoneywell.com to use Salisbury’s
exclusive Glove Congurator™. This interactive web
tool allows you to easily determine which Salisbury
gloves you need to meet your requirements.
ARE YOU NOT SURE WHAT
GLOVES YOU NEED?
Salisbury has made it easy
with the Salisbury Glove ConfiguratorTM
E-4 Gloves and Sleeves. www.salisburybyhoneywell.com
MAKING A PROPER INSPECTION
Cat. No. Description
G99 Glove Inator Kit
G99B Replacement Bag
G99S Replacement Strap
G99V Replacement Check Valve
G100 Glove Inator Kit w/ Adapter
G100A Lo-Volt Glove Adapter
INF-1 Standard Bench Model Inator with Hand Pump
INF-2 Standard Bench Model Inator with AIr-Line Connection
INF-3 Standard Floor Model
INF-4 Bench Model Air-Bag Inator for High Voltage Gloves
INF-5 Bench Model Air-Bag Inator for High and Low Voltage Gloves
INF-6 Standard Sleeve Expander
INF-7 Replacement Glove Inator Boots for Air Bag Glove Inators
INF-8 Replacement Bladders for Sleeve Expander (with closed ends) - Set of three
INF-9 Single Replacement Bladders for Sleeve Expander (with closed ends) - Outside Bladder only
INF-10 Hand Held Glove Inator
G99
G100
G100A
G100 with inflated
lo-volt glove ready for
inspection.
OSHA 1910.137 states “Insulating equipment shall be inspected
before each day’s use and immediately following any incident that
can reasonably be suspected of having caused damage. Insulating
gloves shall be given an air test, along with the inspection.”
Salisbury’s New G100 (Patent Pending), with G100A adapter for
Class 00 and 0 and smaller size gloves, and the G99, without
additional adapter, are the perfect answer for inating your gloves
for inspection.
The G99 is a simple, easy to use, portable glove inator. The G99
provides a quality means of inspecting gloves in the eld. The glove
is secured to the inator using a nylon strap and fastened with a
hook and pile closure. Ination is accomplished by pumping the
bellows of the inator against any surface. NOTE: gloves should
be expanded no more than 1.5 times their normal size for Type
I, and 1.25 times normal for Type II SALCOR.
SALISBURY ADVANTAGE
The G100 is also a simple and easy to use, portable glove inator.
The G100 operates exactly like the G99, but includes an additional
G100A adapter to also inspect Class 00 and 0 and smaller gloves.
To use the adapter, the glove is secured to the G100A adapter
using a nylon strap with a hook and pile closure. The adapter,
with glove attached, is then placed on top of the inator to be
inated for inspection.
INF Series Glove Inators & Sleeve Expanders
Proper safety requires frequent inspection of gloves and sleeves.
These glove inators and sleeve expanders provide an efcient way
to conduct complete and thorough visual inspections before and after
use in the eld. Easy to install. Simple to operate. Accommodates
all sleeve and glove sizes. Minimum oor space. Compressed air
source required.
INF-1
INF-6
E-5
101 E. Crossroads Pkwy., Ste. A Bolingbrook, IL 60440 toll free ph (USA):877.406.4501 toll free fax (USA):866.824.4922 ph:630.343.3800
Cat. No. Breakdown for Class 00 Gloves
Class Length Color Size
SALISBURY LINEMEN’S GLOVES
LOW VOLTAGE - ASTM CLASS 00, 0
Measure the circumference
around the palm.
E 00 11 R, B, BL, or BLO 7, 8, 8H
9, 9H
E 00 14 R, B, BL, or BLO 10, 10H
R=red B=black Type I Natural Rubber 11, 12
BL=blue BLO=blue in, orange out :Type II SALCOR
Example: E0011BL/8 NOTE: Size 11H no longer available.
Cat. No. Breakdown for Class 0 Gloves
Class Length Color Size
E 0 11 Y, B, R, BL, BLO, or BY 7, 8, 8H
9,9H
E 0 14 Y, B, R, BL, BLO, or BY 10, 10H
R=red B=black Y=yellow:Type I Natural Rubber 11, 12
BY=black in, yellow out:Type I Natural Rubber
BL=blue BLO=blue in, orange out :Type II SALCOR
Example: E014R/9 NOTE: Size 11H no longer available.
E011Y Gloves being manufactured.
Selecting the right size, length and style
Salisbury linemen’s gloves are available in a full range
of sizes, from 7 through 12, including half sizes on 8, 9,
and 10. Proper t is important. To determine glove size,
measure the circumference around the palm. Allow for
additional room if fabric glove liners are to be worn,
especially with thermal liners.
SALISBURY ADVANTAGE
Type I and Type II gloves are extremely exible to make
working with small parts easy. The gloves meet or exceed
ASTM D120 and IEC EN60903 Standards.
Class 00 and 0 gloves are available in 11 and 14 inch
lengths. Class 00 Electrical Insulating Rubber Gloves
are made from red or black Type I natural rubber, blue
Type II SALCOR®, or in contrasting blue/orange Type
II SALCOR. The contrast between the outer orange color
against the inner blue color makes inspecting for cuts and
tears easier when the glove is inated or stretched.
Class 0 Electrical Insulating Rubber Gloves are
available in red, black, yellow, and contrasting black/
yellow colors in Type I Natural Rubber. The contrast
between the outer yellow color against the inner black
color makes inspecting for cuts and tears easier when
the glove is inated or stretched. These gloves are also
available in blue or contrasting blue/orange colors Type
II SALCOR rubber.
E0011BL/9
E0014BLO/9
E011R/9
E011Y/10
E-6 Gloves and Sleeves. www.salisburybyhoneywell.com
SALISBURY LINEMEN’S GLOVES
HIGH VOLTAGE - ASTM CLASS 1, 2, 3, 4
Straight Cuff
E316YB/10
Cat. No. Breakdown for Class 1,2,3,4 Gloves
Class Glove Length Cuff Style Color Size
in.
E 1 14, 16 or 18 BC***, C B, YB or RB 7, 8, 8H
E 2 14, 16 or 18 BC***, C B, YB or RB 9,9H
E 3* 14, 16 or 18 BC***, C B, YB or RB 10, 10H
E 4** 14, 16 or 18 BC***, C B, YB or RB 11, 12
BC***=bell cuff C=contour cuff (Contour cuff available for 18” only.)
*available in sizes 8 through 12 including half sizes only
**available in sizes 9 through 12 including half sizes only
***bell cuff gloves available in sizes 9 through 12 including half sizes
B=black YB=Y inside, B out RB=R inside, B out:Type I Natural Rubber
Example: E116BCYB/10
NOTE: Size 11H no longer available.
Class 1 through 4 gloves are available
in the industry standard color black, or
in contrasting two-color combinations.
The contrast between the thin outer
color against the inner color makes
inspecting for cuts and tears easier when
the glove is inated or stretched.
Class 1 through 4 gloves are available in
14, 16 and 18 inch lengths. A straight
cuff is standard on 14” (356 mm), 16”
(406 mm) & 18” (457 mm) gloves. The
straight cuff is the default style.
A contour cuff is angled to prevent
bunching or binding at the elbow when
the arm is bent. Available on all 18”
(457mm) gloves only.
The bell cuff accommodates heavier
winter clothing and allows for greater
air ow in warmer weather. These are
available for Class 1 through 4 gloves.
Bell cuff gloves are not available in sizes
7, 8 or 8H.
Contour Cuff
E218CYB/10
Bell Cuff
E214BCRB/10
E-7
101 E. Crossroads Pkwy., Ste. A Bolingbrook, IL 60440 toll free ph (USA):877.406.4501 toll free fax (USA):866.824.4922 ph:630.343.3800
SALISBURY LINEMEN’S MITTENS
HIGH VOLTAGE - ASTM CLASS 1, 2, 3, 4
Salisbury Lineman’s Mittens are made from the same
durable, lightweight rubber as the ve nger gloves yet keep
the user warmer during harsh temperatures. The three nger
mitten allows for precise hand movement as well.
Class 1 through 4 mittens are available in the industry
standard black or in contrasting two-color combinations.
The contrast between the thin outer color against the inner
color makes inspecting for cuts and tears easier when the
glove is inated or stretched.
Class 1 through Class 2 mittens are available in 14, 16 and
18 inch lengths. Class 3 through Class 4 mittens are available
in 16 and 18 inch lengths. A bell cuff design is standard on
all mittens. BC=Bell Cuff.
Mittens are available in sizes 9, through 11 full sizes only.
Cat. No. Breakdown for Class 1,2,3,4 Gloves
Class Glove Length Cuff Style Color Size
in.
EM 1 14, 16 or 18 BC B, YB or RB 9
EM 2 14, 16 or 18 BC B, YB or RB 10
EM 3 16 or 18 BC B, YB or RB 11
EM 4 16 or 18 BC B, YB or RB
Bell Cuff colors B=black YB=Yellow inside, Black out RB=Red inside, Black out
EM216BCRB/10
E-8 Gloves and Sleeves. www.salisburybyhoneywell.com
LEATHER PROTECTORS
CLEARANCE TABLE FOR LEATHER
PROTECTORS PER ASTM F496 - Table 4
Glove Min. Distance Between
Class Protectors and Rubber Gloves
in. mm
00, 0 1/2 13
1 1 25
2 2 51
3 3 76
4 4 102
Leather Protector Gloves should always be
worn over Rubber Insulating Gloves to provide
the needed mechanical protection against
cuts, abrasions and punctures. All Salisbury
protectors are steamed pressed on curved hand
forms to insure proper t over Rubber Gloves.
Manufactured from top grade leather, all are sewn
with heavy duty nylon thread in the “gunn cut”
inseam construction pattern. Each protector for
Class 1-4 gloves are equipped with a nonmetallic
buckle on the pull strap and an extra wide leather
reinforcement over the thumb seam. Protectors
for Class 00 and 0 gloves are available with non-
metallic buckle and pull strap or elastic wrist.
All Salisbury Leather Protectors meet ASTM
F696 standards.
It is the responsibility of the purchaser to specify
the overall length of the protector gloves. The
Clearance Table shows the minimum distance
which shall be allowed between the protector
glove cuff and the bead of the rubber glove per
ASTM F496 Specications.
WARNING: Do not use leather protectors
alone for protection against electric shock.
Serious injury or death will result. Always
use a properly rated insulating glove for the
voltage being worked.
Proper care of leather protectors is essential
to user safety. Inspect the leather protectors
when inspecting rubber gloves. Metal particles,
imbedded wire, abrasive materials or any
substance that could physically damage the
rubber gloves must be removed from the
protector before use.
1/2
1
2
3
4
Minimum Distance from Protector and Rubber Glove
Glove Class Leather Protector Cuff
--------- Cuff Line --------
00, 0 1/2” from cuff
1 1” from cuff
2 2” from cuff
3 3” from cuff
4 4” from cuff
2” from cuff
The minimum
distance from
the leather
protector cuff
to the bead
of the rubber
glove for this
Class 2 glove is
2 inches.
Adapted, with permission, from F496-08 Standard Specication for In-Service
Care of Insulating Gloves and Sleeves, copyright ASTM International, 100 Barr
Harbor Drive, West Conshohocken, PA 19428. A copy of the complete stan-
dard may be obtained from ASTM, www.astm.org.
E-9
101 E. Crossroads Pkwy., Ste. A Bolingbrook, IL 60440 toll free ph (USA):877.406.4501 toll free fax (USA):866.824.4922 ph:630.343.3800
156 Premium Series
Salisbury’s SALCOR® cuff provides maximum
protection.
These protectors are made from specially tanned
Grade A Red Boulevard buffed leather and an
orange colored SALCOR “Super Cuff” in the 4”
(102 mm) and 6” (152 mm) cuff lengths. The “Super
Cuff” has better characteristics than leather or vinyl
cuffs; it does not absorb water, has greater track
resistance, and creepage.
PREMIUM LEATHER PROTECTORS
Cat. No. Cuff Length OAL Length Weight ea.
in. ( mm ) in. ( mm ) lbs. ( kgs )
156-4 4 ( 102 ) Straight Cuff 12 ( 305 ) 1 ( .5 )
156-6 6 ( 152 ) Straight Cuff 14 ( 356 ) 1.2 ( .5 )
Available in dual sizes: 8/8.5, 9/9.5, 10/10.5, 11/11.5, 12
SALISBURY ADVANTAGE
156-4
156-6
E-10 Gloves and Sleeves. www.salisburybyhoneywell.com
LEATHER PROTECTORS
ILP Series
Manufactured from top grain cowhide, or goatskin, these protectors
provide excellent protection for rubber insulating gloves at a very
economical price. Cowhide cuffs are tough leather on palm side
and orange vinyl on the back, while the goatskin cuffs are green
leather on palm side and orange vinyl on back. Full complement
of styles from low-volt through 16” contour cuff. Comes in size
7, dual sizes 8/8.5 through 11/11.5 and size 12.
ILPM Series Mitten Protector
Manufactured from top grain cowhide, these protectors offer
excellent comfort and protection. The ILPM Series mitten
protectors feature adjustable straps with non-metallic buckles
and are stitched with polyester thread for strong seams. Cuffs are
tough leather on palm side and orange vinyl on the back of the
hand. Comes in sizes 9, 10 and 11.
LP Series
Manufactured from top grain cowhide or goatskin, these protectors
offer excellent comfort and protection. The LP Series protectors
feature adjustable straps with non-metallic buckles and are stitched
with polyester thread for strong seams. Cuffs are tough leather
on palm side and orange vinyl on the back of the hand. Comes in
sizes 7 to 12, including half sizes 8 1/2 to 11 1/2.
Cat. No. OAL Length Weight ea.
in. ( mm ) lbs. ( kgs )
ILP SERIES - COWHIDE
ILP3S* 12 ( 305 ) 1 ( .5 )
ILP4S* 13 ( 330 ) 1 ( .5 )
ILP5S* 14 ( 356 ) 1.2 ( .5 )
ILP6S* / ** 15 ( 381 ) 1.2 ( .5 )
ILP7C* / ** 16 ( 406 ) 1.5 ( .7 )
ILP10* 10 ( 254 ) .7 ( .32 )
ILP10A* w/ pull strap 10 ( 254 ) .7 ( .32 )
*To specify goatskin, use ILPG. Goatskin not available in size 7.
Available in dual sizes: 7, 8/8.5, 9/9.5, 10/10.5, 11/11.5, 12
** Not available in size 7.
ILPM SERIES - COWHIDE
ILPM3S 12 ( 305 ) 1 ( .5 )
ILPM4S 13 ( 330 ) 1 ( .5 )
ILPM5S 14 ( 356 ) 1.2 ( .5 )
Available in sizes: 9, 10, 11
LP SERIES
LP3S 12 ( 305 ) 1 ( .5 )
LP4S 13 ( 330 ) 1 ( .5 )
LP5S 14 ( 356 ) 1.2 ( .5 )
LP6S 15 ( 381 ) 1.2 ( .5 )
LP7C 16 ( 406 ) 1.5 ( .7 )
LP10 10 ( 254 ) .7 ( .32 )
LP10A w/ pull strap 10 ( 254 ) .7 ( .32 )
To specify goatskin, use LPG.
Available in single sizes: 8, 8.5, 9, 9.5, 10, 10.5, 11, 11.5, 12
ILPG10
LPG3S
ILPG10A
ILP7C
LP7C
ILPM5S
LPG5S
E-11
101 E. Crossroads Pkwy., Ste. A Bolingbrook, IL 60440 toll free ph (USA):877.406.4501 toll free fax (USA):866.824.4922 ph:630.343.3800
by Honeywell
SALISBURY ADVANTAGE
Glove Kits
Salisbury’s insulating rubber gloves are necessary
for every electrical worker’s complete safety. And
to insure your safety, Salisbury’s leather protectors
provide needed protection from cuts, abrasions,
and punctures. To keep these safety items in top
condition, proper storage is very important.
GLOVE STORAGE & GLOVES KITS
Product Numbering Chart for Glove Kits
Class Length Color Size
(inches) of Gloves
(choose one below)
GK 00 11 or 14 B, R, BL 7, 8, 9, 10, 11, 12
GK 0 11 or 14 R, BL, B, Y 7, 8, 9, 10, 11, 12
GK 2 14, 16, or 18 B, RB 7, 8, 9, 10, 11, 12
Example: GK011BL/9
Type I Natural Rubber available in: R=Red, Y=Yellow, B=Black,
RB=Red in, Black out
Type II SALCOR® Rubber available in: BL=Blue
Cat. No. For Glove Dimensions Weight ea.
length in. ( mm ) inches ( mm ) lbs. ( kgs )
26 oz. CANVAS GLOVE BAGS
GB112 11 ( 280 ) 9” x 14” ( 229 x 356 ) 1 ( .5 )
GB114 14 ( 356 ) 9” x 16” ( 229 x 406 ) 1 ( .5 )
GB116 16 ( 406 ) 9” x 18” ( 229 x 457 ) 1.2 ( .6 )
GB118 18 ( 457 ) 9” x 20” ( 229 x 508 ) 1.5 ( .7 )
26 oz. CANVAS GLOVE BAGS w/ goggle case
GB114GC 14 ( 356 ) 9” x 16” ( 229 x 406 ) 1 ( .5 )
GB116GC 16 ( 406 ) 9” x 18” ( 229 x 457 ) 1.2 ( .6 )
GB118GC 18 ( 457 ) 9” x 20” ( 229 x 508 ) 1.5 ( .7 )
14.75 oz. CANVAS GLOVE & PROTECTOR BAGS
GPB112 12 ( 305 ) 9” x 14” ( 229 x 356 ) 1 ( .5 )
GPB114 14 ( 356 ) 9” x 16” ( 229 x 406 ) 1 ( .5 )
GPB116 16 ( 406 ) 9” x 18” ( 229 x 457 ) 1.2 ( .6 )
GPB118 18 ( 457 ) 9” x 20” ( 229 x 508 ) 1.5 ( .7 )
GLOVE & PROTECTOR COMBO BAGS
2C16 14 ( 356 ) 16 ( 406 ) 9” x 18” ( 229 x 457 ) 1.2 ( .6 )
2C18 18 ( 457 ) 9” x 20” ( 229 x 508 ) 1.5 ( .7 )
Proper storage extends the service life of
linemen’s gloves and sleeves.
Folds and creases strain rubber and cause it to
crack from ozone prematurely. By storing rubber
gloves in the right size bag, and never forcing
more than one pair into each bag, equipment will
lie at and last longer.
Salisbury bags are constructed of heavy duty
canvas duck and are double stitched and riveted
at stress points for extra durability. Canvas bags
feature a D ring for hanging in trucks or on work
belts. Bags feature tapered gussets with wide
opening tops for easy insertion.
Glove and Protector Combo
Bags contain two layered
pockets in one bag. Now,
both a pair of gloves
and protectors can be
properly stored in
one convenient bag.
Never worry about
having to bring
more than one
bag from job site
t o job site.
GB116 GB116GC
GK011BL/9
Note: If you require test date stamping, please specify
when ordering.
E-12 Gloves and Sleeves. www.salisburybyhoneywell.com
LINEMEN’S SLEEVES
Rubber Insulating Sleeves extend coverage of
the arm from the cuff of rubber insulating gloves
to the shoulder
-
fully protecting these areas from
accidental contact with energized conductors and
equipment. Salisbury sleeves feature a reinforcing
fold at the cuff. This fold is preferred over a rolled
bead because it adds less bulk to the cuff and ts
into the glove easier without pushing. Two different
processes are used to manufacture insulating
sleeves; dipping and molding. Both meet the current
requirements of ASTM D1051 and offer the same
high level of quality and protection.
Sizing
Sleeves should be selected to t the arm comfortably,
covering from the top of the shoulder to inside the
top of the glove. Regular size sleeves are the shortest
and have the smallest arm and wrist openings. To
minimize the possibility of the sleeves pushing gloves
off the hand, size the sleeve to the shortest length
possible while maintaining complete coverage to
the shoulder.
Figure 1
Figure 2
Sizing Linemen’s Sleeves
STRAIGHT ARM SLEEVE- Figure 1
A B C D
in. ( mm ) in. ( mm ) in. ( mm ) in. ( mm )
Small
24.25 ( 616 ) 15.13 ( 384 ) 12.5 ( 317 ) 5.75 ( 146 )
Regular
26.25 ( 667 ) 15.5 ( 394 ) 11.25 ( 286 ) 5.5 ( 140 )
Large
28.5 ( 724 ) 17 ( 432 ) 12.87 ( 327 ) 6.87 ( 175 )
Extra Large
30 ( 762 ) 19 ( 483 ) 13.25 ( 337 ) 6.87 ( 175 )
EXTRA CURVED ARM SLEEVE- Figure 2
A B C D
in. ( mm ) in. ( mm ) in. ( mm ) in. ( mm )
Small
24.25 ( 616 ) 15.13 ( 384 ) 12.5 ( 317 ) 5.75 ( 146 )
Regular
26.5 ( 673 ) 15.5 ( 394 ) 12.25 ( 311 ) 5.25 ( 140 )
Large
27.75 ( 705 ) 16 ( 406 ) 12.87 ( 327 ) 6.87 ( 175 )
Extra Large
29.5 ( 749 ) 17.5 ( 445 ) 12.87 ( 327 ) 7 ( 178 )
E-13
101 E. Crossroads Pkwy., Ste. A Bolingbrook, IL 60440 toll free ph (USA):877.406.4501 toll free fax (USA):866.824.4922 ph:630.343.3800
Cat. No. Breakdown for Dipped Type I Sleeves
Voltage Size Color
Class
D0 S, R, L or XL Y=yellow
D1 S, R, L or XL
B=black
D2 S, R, L or XL
YB=Y inside, B out
D3 S, R, L or XL
RB=R inside, B out
D4
S, R, L or XL
YR=Y inside, R out
S=small, R=regular, L=large
XL=extra large
Example: D2LYB-ST
Extra-Curved Arm
D2LYR-EC
Add suffix “-ST” to order straight cuff or “-EC” to order extra-curved cuff
Straight Arm
D2RYB-ST
LINEMEN’S SLEEVES
DIPPED
SALISBURY ADVANTAGE
Dipped sleeves are manufactured in the
same way as Salisbury rubber insulating
gloves. Porcelain forms are dipped into
liqueed rubber, dried, trimmed, marked
and cured. Every sleeve receives the
same quality inspections and electrical
testing before shipping. Dipped sleeves
are available in the same colors as
dipped gloves, including two color
combinations.
Salisbury is the only manufacturer that
offers two popular styles of dipped
lineman’s sleeves: straight and extra-
curved. Both styles are available in every
color or color combination, size, and
voltage class. Most importantly, all are
made to the same rigid levels of quality
demanded by Salisbury.
Only Salisbury offers both dipped and
molded sleeves.
E-14 Gloves and Sleeves. www.salisburybyhoneywell.com
LINEMEN’S SLEEVES
MOLDED
Cat. No. Breakdown for Molded Type II Sleeves
Voltage Size Color
Class
1 R or L
BS or OS
2 R, L or XL
BS or OS
R=regular L=large XL=extra large BS=black SALCOR
Example: 2LOS OS=orange SALCOR
Cat. No. Breakdown for Molded Type I Sleeves
Voltage Size Color
Class
1 R or L
Y
2 R, L or XL
B, Y, M
3 R or L
Y, M
4
R or L
M
R=regular L=large XL=extra large B=black Y=yellow
Example: 2LB M=maroon
Molded sleeves are manufactured by either injection
or compression molding methods. The advantage
these methods offer is the ability to produce sleeves
of Type I or SALCOR® Type II synthetic rubber.
SALCOR sleeves provide the same high quality
and electrical protection as natural rubber, with
the added benet of being resistant to ozone and
ultraviolet radiation. Type I sleeves are available in
black, yellow or maroon. Type II SALCOR sleeves
are black or orange. Molded sleeves are available in
curved arm style only.
Black
Type I
2RB
Yellow
Type I
3LY
Orange
Type II
2ROS
E-15
101 E. Crossroads Pkwy., Ste. A Bolingbrook, IL 60440 toll free ph (USA):877.406.4501 toll free fax (USA):866.824.4922 ph:630.343.3800
T32
D Ring on back
SLEEVE STORAGE & ACCESSORIES
Proper storage extends the service life of linemen’s sleeves.
Folds and creases strain rubber and cause it to crack
from ozone prematurely. By storing rubber sleeves in
the right size bag, and never forcing more than one pair
into each bag, equipment will lie at and extend the life
of the product.
Salisbury bags are constructed of heavy duty canvas
duck and are double stitched and riveted at stress points
for extra durability. Canvas bags feature a D ring for
hanging in trucks or on work belts. Bags feature tapered
gussets with wide opening tops for easy insertion.
SALISBURY ADVANTAGE
The T32 bag contains a crush resistant lining to create
a more protective environment for your sleeves.
Sleeve buttons, straps, and harnesses are required to
wear rubber insulating sleeves properly. Four buttons
are required per pair of sleeves. Two straps are required
per pair of sleeves. One harness is required per pair of
sleeves.
Cat. No. For Sleeve Dimensions Weight ea.
length in. ( mm ) inches ( mm ) lbs. ( kgs )
CANVAS SLEEVE BAG
T31
-
30” x 9.5” ( 762 x 241mm) 1.5 ( . 7 )
T32
-
30” x 13” ( 762 x 330 mm) 3 ( 1.4 )
BUTTONS
B2
-
One Piece Sleeve Button .2 ( .01 )
B22
-
4 Screw Type Buttons .8 ( .04 )
STRAPS
S1
15”(381mm) Strap w/ 4 B2 Buttons .1 ( .005 )
HARNESS
H1
Harness w/ 4 B2 Buttons 1 ( .45 )
T31
S1
H1
B2
B22
Two-piece sleeve button
4 required per pair of sleeves
One piece sleeve button
4 required per pair of sleeves
E-16 Gloves and Sleeves. www.salisburybyhoneywell.com
SALISBURY LINEMEN’S GLOVE LINERS
L10JK L10J
L12J
Cat. No. Description Wrist Length Weight ea.
Style in. ( mm ) lbs. ( kgs )
L10JK Jersey Style, Light Weight, Seams Out Knit 10 ( 254 ) .14 (.06)
L10J Jersey Style, Light Weight, Seams Out Open 10 ( 254 ) .12 (.06)
L12J Jersey Style, Light Weight, Seams Out Open 12 ( 305 ) .14 (.07)
L10MKC Machine Knit, 100% Cotton Knit 10 ( 254 ) .12 (.05)
L12MKC Machine Knit, 100% Cotton Knit 12 ( 305 ) .12 (.05)
L10MKW Machine Knit, Wool Blend Knit 10 ( 254 ) .14 (.06)
L12MKW Machine Knit, Wool Blend Knit 12 ( 305 ) .14 (.07)
89/1402 White Machine Knit, 100% Cotton Knit 10 ( 254 ) .12 (.06)
89/4702 Rust Machine Knit, 100% Acrylic Knit 10 ( 254 ) .12 (.06)
One size ts all.
L12MKC
89/1402 89/4702
Liner Gloves enhance the comfort of
wearing Rubber Insulating Gloves in
every season. Liners provide warmth in
the cold season and absorb perspiration
in the warm months. Many styles and
fabrics are available with either an open
or knit wrist.
The knit wrist style grips the wrist rather
than allowing the cuff to roll down and
bunch at the palm. All Liner Gloves
are for year round use with Rubber
Insulating Gloves and Mittens. All liners
are made from stretch fabric that can t
any hand size.
The L Series has a tough outer cotton
fabric while the inner lining is soft and
comfortable. The LMKC Series is light,
airy and allows ease of movement. The
LMKW Series is made from a wool
blend fabric that moves easily yet gives
a substantial layer of lining.
The 89 Series is Salisbury’s classic
summer and winter glove liner. Liners
absorb perspiration from hands. The
summer liner is white in color and 100%
cotton. The winter blend is a rust color
and 100% acrylic.
L10MKW
E-17
101 E. Crossroads Pkwy., Ste. A Bolingbrook, IL 60440 toll free ph (USA):877.406.4501 toll free fax (USA):866.824.4922 ph:630.343.3800
SALPOL & WORK GLOVES
Salisbury’s SALPOL Gloves protect hands during cold
weather jobs. The black split cowhide leather has a 3M
Thinsulate* lining to keep hands warm. For extra warmth
a long knit wrist is sewn into the safety cuff to keep out
snow and ice. The glove also has a full leather index nger,
knuckle strap, leather ngertips, and pull patch.
*Thinsulate is a registered Trademark of the 3M Company.
Drivers Work Gloves set the standard for quality at
an affordable price. Combining comfort, durability and
economy, Salisbury leather Drivers Work Gloves meet
the tough challenges of today’s demanding workplace.
Available in lined or unlined styles. The bindings are
color coded to indicate size: red-small, green-medium,
brown-large, purple-extra large.
Linemen Work Gloves are designed specically for
use by linemen and offers many of the quality features
found in our leather protectors. Made from high quality
grain cowhide or goatskin, this glove is soft and exible,
while still being highly abrasion and cut resistant for
long wear.
Cat. No. Description Weight ea.
lbs. ( kgs )
I95/217/WHS* Unlined .3 ( .14 )
I95/317/WHS* Lined .3 ( .14 )
*Add “-S” for small, “-M” for medium, “-L” for large, “-XL” for extra-large.
LW2SPE** Cowhide leather, natural pigskin cuff .4 ( .18 )
LWG2SPE** Goatskin leather, natural pigskin cuff .4 ( .18 )
**Add “-M” for medium, “-L” for large, “-XL” for extra-large.
DRIVERS & LINEMEN WORK GLOVES
Cat. No. Description Length Weight ea.
in. ( mm ) lbs. ( kgs )
SALPOL GLOVES
SP-S Small Size Polar Glove n / a .5 ( .23 )
SP-L Large Size Polar Glove n / a .5 ( .23 )
SALPOL GLOVES
I95/217/WHS
SP-L
LW2SPE
E-18 Gloves and Sleeves. www.salisburybyhoneywell.com
RUB-OUT® is a non-petroleum-based hand cleaner
for workers who wear rubber gloves and sleeves.
Dissolves and removes grease, oil, ink, tar, pipe
dope, creosote, paint and more without harming
natural rubber or SALCOR® rubber. Cleans with
or without water. Contains natural skin conditioners
and leaves a fresh citrus scent.
Salisbury’s RUB-OUT® Towelettes are
premoistened heavy duty hand cleaner towels
that work fast to loosen, dissolve, and absorb dirt
and grease, and will not harm rubber gloves! Our
powerful yet safe cleaning agents work together with
an absorbent, nonscratching abrasive cleaning towel.
The citrus-based formula easily removes soil from
your hands and leaves them cleaned and conditioned
anywhere you’re working. And after cleaning your
hands there is enough absorbency to clean your tools
and other surfaces with the same towel. These shop
size (10.5” x 12.25”) durable towels quickly remove
tough-to-clean substances including lubricants, tar,
oils, wax, caulk and much more.
TEN-FOUR® GLOVE DUST is a cooling,
frictionless powder that absorbs moisture and
perspiration when wearing rubber gloves. Provides
extra comfort while preventing gloves from getting
sticky. The 5-oz. bottle easily ts in a pocket or glove
bag. The 4-quart bulk package is used in test labs as
a dusting powder when cleaning and testing.
SUPER SALCO® Cleaner is a concentrated
detergent with a special grease release formula that
removes oils, grease and dirt from natural rubber and
SALCOR rubber equipment. Suitable for washing
linemen’s rubber gloves, sleeves and other specialty
equipment, by hand or in commercial washing
machines. Also works well on berglass and other
materials. Just dilute with water, apply with a rag or
sponge and rinse thoroughly.
Cat. No. Description Weight ea.
lbs. ( kgs )
RUB-OUT® HAND CLEANER
1451 16 oz. ( .45kg ) can, 12/pack 16 ( 7.3 )
1452 4.5 lbs. ( 2kgs ) cans, 6/pack 28 ( 12.7 )
1453 Dispenser for 4.5lb. ( 2kg ) can 1 ( .5 )
RUB-OUT® TOWELETTES
1460 Bucket of 60, 6 buckets / Case 14 ( 6.4 )
1461 Single Packets, 100 Singles / Case 3 ( 1.4 )
TEN-FOUR® GLOVE DUST
10-4 12 @ 5 oz. ( 170g ) squeeze bottles 5.5( 2.2 )
10-4-4QT 4 quarts ( 3.8 ltrs. ) bulk, single 8 ( 3.6 )
SUPER SALCO® DETERGENT
S4 1 gal ( 3.8 ltr. ) jugs, 4 pack 54( 24.5 )
S5 5 gal ( 19 ltr. ) drum 49 ( 22.3 )
S55 55 gal ( 208 ltr. ) drum 540 ( 245 )
SALCON® SILICONE SPRAY
S99 Aerosol can 16 oz. ( .454 )
SUNSCREEN 30
SS30 100 towelettes 6 ( 2.72 )
S99
S5
SALCON® Silicone Spray is specially formulated
to reduce friction on SALCOR or natural rubber
products. Reduces surface creepage on rubber
gloves and sleeves. Forms an oxygen barrier which
helps reduce corona cutting and weather checking
on rubber equipment. May also be used to spray
spark plugs and battery terminals in damp weather
to assist in starting.
SUNSCREEN 30 is a non-oily sunscreen that
does the job for at least four hours. Safe for leather
and rubber gloves, leaves no residue
-
no slippery
hands. Large convenient towelettes.
CLEANERS, SUNSCREEN AND SUPPLIES
SS30
1460
1461
10-4 1451
