TABLE OF CONTENTS
This information is provided without warranty of any kind by any person,
including without limitation the owner and the publisher.
Specifications are subject to change without notice.
All products in this catalog may not be in stock at all times.
Please call for current availability.
Copyright © 2014
Power Line Supply
Catalog Produced By Shelley Hantz
shelley.hantz@gmail.com
AR Clothing & Dielectric Boots ................................... 1
Bags, Tool Boards & Buckets .................................... 6
Bolt & Cable Cutters................................................... 19
Compression Tools & Dies ........................................ 23
Conductor Grips & Swivels ....................................... 30
Digging & Pole Handling Tools ................................. 34
Fall Protection............................................................. 37
Flashlights...................................................................51
Hand Tools...................................................................63
Hoists .......................................................................... 90
Hot Sticks.....................................................................93
Meters & Testers....................................................... 100
Rubber Blankets & Line Hose..................................109
Traffic Control............................................................ 111
Wire Stripping Tools .................................................113
Work Gloves ..............................................................118
Gloves & Sleeves........................................................ 54 Index................................................................................i
Grounding....................................................................58
www.uco.com
420 Roth Street Reed City, MI 49677
Phone (231) 832-2297 Fax (231) 832-2490
“Contractors depend on their tools to perform when it counts”
Because we understand this, we have expanded.
Power Line Supply Company now offers complete sales and service for all of your
tooling and safety needs.
The included line card lists just some of the manufacturers we have partnered with in
order to offer you a complete solution for your tooling needs. As part of this expanded
service we are stocking all of the most popular tools, providing service and support.
Including factory authorized warranty repairs*.
Authorized Warranty Repairs
We have been factory trained and are authorized to repair many major brands. We are
also your local Warranty Service Center for Greenlee, Fairmont and Burndy. We are
also an authorized repair center for Huskie Tools. When you have a tool that needs to be
repaired just give us a call at (231-832-2297 Ext. 2104). We will arrange for UPS or our
own truck to pick it up for an evaluation. In our new upgrade with P21 we will be able to
track all tools by an assigned serial number that is given to each tool. The serial number
can be the manufacturer’s or a Power Line Supply number. When the tool arrives for the
repair and we enter the serial number into the system, it will tell us if there is any
warranty remaining on a certain tool.
Shipping and Receiving
We offer shipping on our own trucks that make deliveries once a week to certain
locations. This way there is no shipping cost. We can also return tools back to the
customer the same way. We can also use UPS and Freight trucks. When a tool reaches
the repair department it is assigned a serial number and can be tracked throughout the
repair cycle.
Worn Out Tools
Tools which the repairs have reached half of the cost of a new one we give the customer
the option to repair or replace. If the customer chooses to replace the worn out tool we
will either send it back to the customer or dispose of it for them.
Date
REPAIR WORK ORDER FORM
Customer Contact
Street Phone
City, State, Zip Date to Received
Account Manager
Make, Model No Serial No
Problem Reported
Work to be Performed Material Used
Qty Part No. Desciption
Repaired By Estimated Cost
Customer (print) Purchase Order No
Customer Signature Date
Power Line Supply*420 South Roth*Reed City, MI 49677
Office 231-832-2297 Fax 231-832-2490 Repair Shop 231-832-2297 Ext. 2104
TESTING DIVISION SERVICES
Dielectric testing of all personal protective equipment providing service up to 100
KV AC since 1986, an accredited member of NAIL (North American Independent
Laboratories). Our testing facility located in Reed City Michigan is accredited to
test the following product groups:
Insulating Gloves Insulating Sleeves
Insulating Blankets Insulating Line Hose
Insulating Covers Hot Sticks & LiveLine Tools
Insulating Plastic Guards Insulating Aerial Devices
Insulating ByPass Jumpers Rubber Insulating Matting
Portable Grounding Jumpers Dielectric Overshoe Footwear
Insulating Bucket Liners
We also offer mobile testing on site for Insulating Aerial Devices, Insulating Bucket
Liners, Hot Sticks & LiveLine Tools and Portable Grounding Jumpers.
Contact Power Line Supply today @ 18008322297 regarding available testing
programs.
Power Line Supply
420 Roth Street
Reed City MI 49677
Phone 18008322297 Fax 2318322490
TEST LABORATORY RETURN FORM
SHIP TO: BILL TO:
OTHER INSTRUCTIONS:
GLOVES, SLEEVES, OR BLANKETS NUMBERED:
Yes No
REJECTED MATERIAL REPLACED: Yes No
REJECTS TO BE RETURNED: Yes No
GLOVES POWDERED: Yes No
RETURN VIA:
CONTACT NAME:
PHONE:
DATE OF SHIPMENT:
NUMBER OF BOXES SHIPPED:
RETURN OF TESTED MATERIAL REQUIREMENT DATE:
PROTECTIVE EQUIPMENT
AR Clothing 
Dielectric Boots
1-800-832-2297 1
Unit# 1303466505
MESH VESTS
For workers exposed to arc flash potential in
roadway work zones. Complies with MUTCD,
fire retardant standard found in ASTM 1506-
02(a) and visibility standards found in ANSI
107-2004.
MESH VESTS
Modacrylic/Kevlar®  Hi-Vis
Features Modacrylic/Kevlar® Hi-Vis Mesh
construction with 2 segmented hi-vis striping.
Complies with ANSI/ISEA 107-2010 Class 2,
NFPA 70E-2012, ASTM 1506-02a and OSAH
29 CFR 1910.269.
Unit# 1303710719
ARC FLASH PROTECTION
JACKETS
Features hook and pile front closure, 32
length and Nomex® wristlets. Expansion back
for added comfort. FR hook & pile storm flap
coats are intended to be used with PRO--
HOODs. Meets current ASTM F1506 and
NFPA 70E standards. Available in S, M, L, XL,
2X or 3XL. CE 0120 certified.
Unit# 1303707372
ARC FLASH PROTECTION
OVERPANTS
Features full elastic waistband with FR hook
and pile front closure, 30 inseam and hook/
pile cuff adjustment. Loose design/flared legs
make it easy to put on and take off over exist-
ing work clothing. CE0120 certified. Available
in S, M, L, XL, 2XL or 3XL sizes.
KNIT HOODS
Ultrasoft®
Navy blue.
Unit# 1303796657
PROTECTION EQUIPMENT KITS
Includes arc flash coat, bib overalls, PRO-
HOOD®, hard hat, SKBAG and safety
glasses. Available in S,M,L,XL,2XL and 3XL.
No
Weight
Oz. Color Size
1613FR2 15 Lime
green M-4XL
No. Color cal/cm2
V00HA__2V Yellow 5.1
No. cal/cm2 Color
ACC1132BL 12 Navy Blue
No. cal/cm2 Color
ACP1130BL 12 Navy Blue
No. Description
cal/
cm2
HRC/
Level
H11RY Untra-Soft® Arc-
Rated Knit Hood 12 2
H11BA Modacrylic Knit
Hood 11.6 2
No.
ATPV
Rating HRC Color
SK40 40 4 Gray
AR Clothing 
Dielectric Boots
21-800-832-2297
Unit# 1303715637
REPLACEMENT FACE SHIELDS/WINDOWS
Used with the ASSLB, FBBRACKET, or BRACKET brackets and ASCP.
Features extra light tint and fog resistance. 7-1/2 x 20 viewing area.
Absorbs 99.9% of UV rays. .06 thickness.
No. AS1000FS. Replacement face shield for AS1000HAT, AS1000FB
and AS1000U.
No. AS1200FS. Replacement window for AS1200HAT.
Unit# 1303716490
REPLACEMENT CHIN CUPS
For use with AS1000 series shields.
Unit# 1303714657
CHIN GUARDS
Transparent
Increases users peripheral view.
Unit# 1303714960
INNER LENS
Anti-Fog
Natural convection air flow design helps minimize fogging. Meets
ASTM requirements.
Unit# 1303712404
ARC FLASH FACESHIELDS
Absorbs >99.9% of harmful UV radiation and resistant to fogging. 7-1/
2 x 20 viewing area, extra light tint, .06 thickness. Meets current
ANSI Z87.1, CSA, and tested to ASTM F2178 specifications
No. Desc.
AS1000FS Face shield
AS1200FS Window
No. Desc.
ASCP Chin cup
No. Desc.
AS12CLR Chin guard
AS1000FS AS1200FS
Visit our Web Site at
www.uscco.com
for our full line card.
No.
For use
with Desc.
AFLENS AS1200 Anti-fog inner lens
No.
Size
cal/cm2
AS1000HAT 10
AS1200HAT 12
AS2000HAT 20
AS1000HAT AS1200HAT
AS2000HAT
AR Clothing 
Dielectric Boots
1-800-832-2297 3
Unit# 1303716078
DIELECTRIC BRACKETS
Fits slotted front brim hard hats.
Unit# 1303714738
RESCUE HOOKS
Insulated
Used to withdraw injured worker from hazard-
ous areas, confined spaces, vaults or near
electrical cabinets and switch gear. Features
foam filled, fiberglass reinforced handle for
electrical insulation. Includes coated heat
treated body hook with 18 opening.
Unit# 1303716789
ARC FLASH HOODS
Creates 360° head and neck protection from
arc flash dangers. Features two layers of rib
knit material and elastic face opening that
maintains shape and size.
FACESHIELD BAGS
Used to protect faceshields.
GEAR BAGS
Sturdy construction with Velcro® on handle
straps. Side zipper pocket for holding acces-
sories such as glove bag, safety glasses etc.
Unit# 1303715284
STORAGE CLOTH BAGS
Cotton canvas storage bag with drawstring
closure and fleece interior.
Unit# 1303711976
LARGE STORAGE BAGS
For use with clothing, gloves, and accesso-
ries.
Unit# 1303714290
ATTACHABLE TASK LIGHTS
Flame Resistant
Features high intensity long lasting white LED
lamp with overall brightness of 7 lumens.
Accessories
No. For use with Desc.
ASSLB AS1000 Dielectric blanket
No.
Length
Ft.
Weight
Lbs.
24401 6 4-1/2
No. cal/cm2
AFHOOD10 10
No. DESC.
BCFSHIELD Faceshield Bag
No. Dim. In.
DFDLBAG30 25.5 x 14 x 16
DFDLBAG40 14x14x18
No. Desc.
ASBAG Storage bag
No.
Height
In.
Length
In.
Depth
In. Color
SKBAG 15 24 12 Orange
No. For use with
Diameter
In.
ASFL AS1200HAT 6-7
No. Desc.
FLCLIP Attachable task light clip
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
AR Clothing 
Dielectric Boots
41-800-832-2297
Unit# 1303473215
DEEP HEEL OVERSHOES
Provides safety when climbing ladders and poles where deep heel cav-
ity can lock onto rungs. Features ozone resistance and waterproof con-
struction. Hand-layered in full-cut patterns to fit over work boots. Sole
has anti-skid bar tread.
Unit# 1303474818
OVERSHOES
Ozone resistant yellow rubber construction. Features 100% waterproof,
fabric lined construction. Hand-layered in full-cut patterns to fit over
work boots. Sole has anti-skid bar tread. Outsoles have been tested to
20,000 volts to electrical hazard requirements of ASTM F2413-05.
Unit# 1303474818
DIELECTRIC INSULATING BOOTS
Provides added protection against electric shock and is capable of with-
standing over 35KV on the sole and 20KV on the complete boot. Fitted
with unique oil resistant vulcanised rubber sole that is slip, wear and cut
resistant. 200 Joule, epoxy coated steel toe cap. Meets ASTM F2413-
05, ASTM F1117-93, and CSA Z195-02 standards.
Unit# 1303474818
DIELECTRIC INSULATING OVERBOOTS
Insulating footwear made to easily slip on with rear entry design. Boot
slides easily into the overboot and is secured with rubber strap
attached, providing a snug and secure fit. Features slip resistant vul-
canised blue rubber sole. High voltage resistant Dielectric compound.
Resists 20KV on complete overboot. Waterproof.
No. Sizes Wt. Lbs. Type
51581 7-12 (whole & half sizes); 5, 6,
13-17 (whole sizes) 3.3 Storm rubber
51530 6-17 (whole sizes) 4.4 2-buckle
21402 7-17 (whole sizes) 5.8 17 overshoe
No. Desc.
Weight
Lbs.
31924 4-Buckle arctic 4.6
51824 Storm rubber 3.25
51581
51530
21402
31924
51824
No. Size Ht. In.
MIC/BTB00950-62 4-16 15
No. Sizes Ht. In.
MIC/BTB01170-71-72 Med (6-8), Large (9-11),
Extra-Large (12-14) 10
AR Clothing 
Dielectric Boots
1-800-832-2297 5
Power Line Supply is a proud distributor
of products for the following manufacturers:
ARC Rated Clothing
Protective Eyewear
Hearing & Head Protection
Footwear
Call for manufacturers catalogs.
Bags, Tool Boards
& Buckets
61-800-832-2297
Unit# 4320001
AERIAL APRONS
2-Pocket
Designed to fit flat against inside of bucket.
Heavy-duty canvas construction. Features inte-
gral non-conductive rod and brass grommet
hook holes. Each pocket measures 8 x 6 x 4.
AERIAL APRONS
2-Pocket
Designed to fit flat against inside of bucket.
Heavy-duty canvas construction. Features
integral non-conductive rod and brass grom-
met hook holes. Each pocket measures 8 x 6
x 4.
Unit# 4320002
AERIAL APRONS
8-Pocket
Designed to fit flat against inside of bucket.
Heavy-duty canvas construction. Features
large pocket, (7) tool pockets, (3) loops, inte-
gral non-conductive rod, and brass grommet
hook holes.
Unit# 4320003
AERIAL APRONS
9-Pocket
Designed to fit flat against inside of bucket.
Heavy-duty canvas construction. Features 8 x
4 pocket with plastic stiffener and support
hangers, (7) hand tool pockets, auger bit
pocket, quick release snap, integral non-con-
ductive rod, and brass grommet hook holes.
Unit# 4320004
AERIAL APRONS
Multi-Pocket
Designed to fit flat against inside of bucket.
Features (8) hand tool pockets, (3) socket
pockets, (2) utility pockets, (2) drill bit pockets
with PVC lining, hammer loop, leather knife/
screwdriver sheath, quick release snap, inte-
gral non-conductive rod, and brass grommet
hook holes. Yellow.
AERIAL APRONS
Magnetic Strip
Designed to fit flat against inside of bucket.
Features (8) hand tool pockets, (3) socket
pockets, (2) utility pockets, (2) drill bit pockets
with PVC lining, hammer loop, leather knife/
screwdriver sheath, quick release snap, and
magnetic strip.
AERIAL APRONS
Designed to fit flat against the liner to minimize
interference with line work and maximize abil-
ity to reach necessary tools. Includes multiple
hand tool pockets, (4) material pouches and
(2) drill bit holders. Non conductive rod in top
for support and (2) brass grommets.
No.
Overall
Dim. In.
43-100 18 x 10
No. Dim. In.
1825 18 x 10
No. Dim. In.
43-120 18 x 10-1/2
No. Dim. In.
43-130 19-1/2 x 18
No. Description Dim. In.
43-174 16 pockets, Vinyl 24 x 22-1/2
43-165 18 pockets, Vinyl 24 x 21-1/2
No. Description Dim. In.
43-162 18 pockets,
Yellow Vinyl 24 x 22-1/2
43-170 18 pockets,
Canvas 24 x 22-1/2
No.
Dim. In.
LxWxH
1829-A-2 28.5 x4x26.5
1829-BL-1
Bags, Tool Boards
& Buckets
1-800-832-2297 7
AERIAL APRONS
Designed to fit flat against inside of bucket.
Heavy-duty canvas construction. (1) pouch.
Unit# 4297003
TOOL APRONS
Aerial
Fits flat against liner inside aerial lift buckets.
Features non-conductive rod in top for sup-
port, brass grommet reinforced hanging holes,
Inosil corrosion shield, and internal stiffener.
TOOL POUCHES
Lineman's  5-Pocket
Leather construction. Features double backing
for extra support.
AERIAL BUCKETS
Made of heavy-duty canvas with black molded
polypropylene bottom.
No. 5144B. Does not include hooks.
Unit# 4320005
AERIAL TOOL BUCKETS
Oval  Blackwrap
Designed for attachment to aerial lift buckets.
Plastic lined. Features solid, non-conductive
plastic ring, molded rubber bottom and brass
grommet hook holes. Measures 14 x 17 x 9.
AERIAL TOOL BUCKETS
Oval with Cover
Yellow vinyl nylon laminate construction.
Includes (6) tool pockets. Fire retardant.
No. Description
Dim. In.
LxWxH
1826
Includes (8) hand tool
pockets and quick
release snap
18 x 4 x 19.5
1827
Includes (4) hand tool
pockets and (1)
hammer loop
20.5 x4x10.5
1828
Includes (7) hand tool
pockets, and (3)
hammer loops
18 x 4 x 10.5
No.
Dim. In.
LxWxH
1829-HB-7-MAG 23.9 x4x21.25
No. Description Dim. In.
1173
Includes pouches
for screwdriver, (2)
pliers, ruler and
wrench
10 x 10.5 x 2
1173-S
Includes pouches
for screwdriver, (2)
pliers, ruler, wrench
and knife snap
9x10x2
No. No. Pockets
Dim. In.
LxWxH
5144 15 14x7x10
5144B 15 14x7x10
No. Desc.
45-100 5 Pocket
45-113 5 Pocket, nut and bolt pocket
and support bar
45-120 14 Inside pockets, no handles
No. Dim. In.
1810-FR-C 15x7x9
45-113
Visit our Web Site at
www.uscco.com
for our full line card.
Bags, Tool Boards
& Buckets
81-800-832-2297
Unit# 4320006
AERIAL TOOL BUCKETS
Compression Tool  Blackwrap
Designed for attachment to aerial lift buckets.
Plastic lined. Features (5) compartments,
auger bit pocket with PVC lining, snap assem-
bly, non-conductive plastic ring, molded rubber
bottom, and brass grommet hook holes.
Unit# 4320007
AERIAL TOOL BUCKETS
Oval  Oversize  Blackwrap
Designed for attachment to aerial lift buckets.
Plastic lined. Features nylon webbing handles,
non-conductive plastic ring, molded rubber
bottom, and brass grommet hook holes.
Unit# 4320012
TOOL BUCKETS
Blackwrap
Heavy-duty canvas construction. Features
solid round non-conductive injected molded
top ring with polypropylene rope handle, and
brass grommet reinforced rope holes.
Note: Available with plastic, rubber or unitized
bottom. Specify when ordering.
TOOL BUCKETS
14-Pocket
Unit# 4320013
TOOL BUCKETS
Heavy-duty canvas construction. Features
rope handle with swivel snap.
No. 31-206. Includes one inside pocket.
Unit# 1728005
TOOL BUCKETS
Leather Bottom
Heavy-duty canvas construction. Polypropyl-
ene rope handle reinforced with leather for
water resistance and strength. Leather rein-
forcement extends 3 up sides. Inside pocket
measures 8 x 8.
No. Dim. In.
45-675 16x9x20
No. Dim. In.
Canvas with Blackwrap
65-700
15 inside
pockets, 13
outside pockets
14x7x9
45-217
17 inside pock-
ets,13 outside
pockets
16x9x12
Vinyl with Blackwrap
65-710
15 inside
pockets, 13
outside pockets
14x7x9
No. No. Pockets Dim. In.
30-010 55x6
31-206 Includes swivel snap
and 1 insdie pocket 8x8
31-295 Swivel snap, no
pockets 12 x 22
No. Description Size In.
35-575 Blackwrap with rope
and swivel snap 12 x 12
No. Dim. In.
31-205 12 x 15
31-206 12 x 15
31-295 12 x 22
No. Description
Dim. In.
Dia. x H
5019  12x15
5109S Includes swivel cap 12 x 15
5109PS
Includes swivel cap
and (1) 8 x 8 inside
pocket
12 x 15
5104S  12x17
Bags, Tool Boards
& Buckets
1-800-832-2297 9
Unit# 4297001
AERIAL TOOL BUCKETS
For attachment to aerial lift buckets. Con-
structed with PVC ring at top and PVC sup-
ports on sides to hold open in oval shape.
Features interior hand tool pockets, plastic
bottom with drainage holes, and brass grom-
met reinforced holes for attachment hooks
No. 1820HB. Hard body.
No. 1820HB-C. Includes cover.
No. 1820-H-C-MAG. Includes magnetic strip
and cover.
AERIAL BULB BAGS
Features collapsible design for easy storage.
Canvas construction.
No. 44-610. Includes hard bottom insert.
Unit# 4297002
TOOL BUCKETS
Splicers
Constructed of 1000 Denier nylon condura
material. Abrasion and cut resistant. Features
Inosil corrosion shield to protect tools from
rusting, PVC top ring to keep bag open, and
molded plastic bottom. Includes (15) inside
and (14) outside pockets, (2) handles and
shoulder strap.
No. 1815147H2G. Inosil corrosion shield &
hardbody
No. 1815147TVA. Inosil corrosion shield and
hardbody with handles and shoulder strap.
No.1815-14-HB. Heavy canvas construction,
hardbody, handles and molded bottom.
No. 181514HBHQ2. Oversize oval, black
nylon cordura body, handles, and hard body
liner.
NUT & BOLT BAGS
Canvas construction with quick release snaps.
Top hem is reinforced with stiffener to keep
bag open.
NUT & BOLT BAGS
Heavy green canvas
duck construction with
leather top and bottom
reinforcements and
quick release snaps.
Unit# 4297005
TOOL BUCKETS
Miniature
For use as promotional
item. Printed with Power
Line Supply logo.
Unit# 4297006
TOOL BUCKETS
Heavy-duty canvas construction with leather
bottom, rope holes, molded top ring, and poly-
propylene handle.
No.
No.
Pockets
Dim. In.
LxWxH
1800 6 15x7x9
1820 15 15x7x9
1820-HB 6 15x7x9
1820-HB-C 15 15x7x9
1820-H-C-MAG 15x7x9
No. Size In.
44-600 25x13x15
44-610 25x13x15
No.
Dim. In.
LxWxH
1815-14-7 15x7x9
1815147H2G 15x7x9
1815147TVA 15x7x9
1815-14-HB 15x7x9
181514HBHQ2 15x9x11
No. Dim. In.
1045 9x9x4
No. Dim. In.
1061-ESTEX 8.5x10x3
No.
Dim. In.
Dia. x H
2008 5x6
No. Description
Ht. In.
Dia. x H
2030-ESTEX Snap 8 x 12
2050-SOP Snap 12 x 12
2061-ESTEX No snap 12 x 15
2063 No snap 12 x 15
2069 Snap 12 x 15
2070 Snap 12 x 15
2061-SCL-S Snap 12 x 17
2061-ESTEX 2061-SCL-S
Bags, Tool Boards
& Buckets
10 1-800-832-2297
Unit# 4297004
AERIAL BUCKET HOOKS
For use with all aerial buckets. Injection molded polymer construction.
Weather resistant. 11/16 dia.
No. 1831. Fits high load lifts.
Unit# 4320009
AERIAL BUCKET HOOKS
Polymer construction.
TOOL BAGS
Canvas construction. Features tapered bottom and (2) pockets for
small parts. Includes snap for hanging.
Unit# 4329005
CHAINSAW SCABBARDS
Aerial Lift Bucket
For use with gasoline or hydraulic chainsaws. Mounts inside buckets
with or without liners. Fiberglass construction. Non-conductive. White
plastic finish cleans easily. Opening measures 3 x 5-3/4.
No. Desc.
1830 Aerial bucket hook
1831 Double aerial bucket hook; 3 W
No.
Fits Lip
Size In.
47-500 3
1830 1831
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
No.
Dim. In.
Dia. x H
5143 6-1/2 x 8
No.
Max. Blade
Lgth. In.
05-909-1 36
Bags, Tool Boards
& Buckets
1-800-832-2297 11
Unit# 4297014
AERIAL BUCKET COVERS
Vinyl coated nylon construction. Features rope
lanyard with snap for attachment to truck and
bungee in hem for tight fit.
Unit# 4320008
AERIAL TOOL HOLDERS
Designed for attachment to
aeriel lift buckets. Vinyl con-
struction with reinforced bot-
tom. Features (2) pockets
and grommet flap. Yellow.
AERIAL TOOL BUCKET
Hydraulic Tools
Blackwrap aerial tool bucket with grommet
flap.
Unit# 3871011
TOOL HOLSTERS
3-Pocket
Unit# 4329003
AERIAL TOOL HOLSTERS
Impact Wrench & Drill
Attaches to inside or outside of bucket with or
without liners. Includes Velcro hold down
strap.
No. 05-832. Slotted design for easy insertion
and removal of wrench when using drill bits
and hardware sockets.
No. 05-833. Allows storage of tools and (2)
drill bits.
nit# 1728043
KNIFE HOLDERS
Lineman's
For use with skinning knives.
Leather construction with riveted
seams. Features slotted belt
loop for belts up to 2 wide.
Unit# 4320010
GEAR BAGS
Industrial
Canvas construction. Features molded rubber
bottom and nylon frame.
No. 62-230. Features outside pocket.
No. 62-231. Features one inside pocket.
GEAR BAGS
Industrial
Measures 24 x 10 x 18.
No. Desc.
Fits Bucket
Size In.
2711-ESTEX Oneman 24x24to24x36
2712 Twoman 24x36to28x52
No. Dim. In.
12-802 10 x 19
No. Size In.
35-326 8x16
No. Dim. In.
4223 10-1/4 x 6
No. Desc.
05-832 Impact wrench & drill holster
05-833 Multi-purpose impact wrench &
drill holster w/ 4 bracket
No.
Overall
Dim. In.
5163 3-1/2 x 9-3/8
No. Dim. In.
62-105 15x8x13
62-225 24x10x14
62-230 24x10x14
62-231 24x10x14
No. Description
62-430 Canvas construction with one
outside pocket
62-630 Orange vinyl with roll up rainflap and
one outside pocket
Bags, Tool Boards
& Buckets
12 1-800-832-2297
GEAR BAGS
1000 Denier nylon Cordura construction with
zipper opening, two web handles and shoulder
strap.
TRANSFORMER SPILL BAGS
Pole Mount Style
For use on leaking pole or pad mount trans-
formers. Heavy puncture resistant vinyl con-
struction with double bottom. Fits transformer
while still on the pole.
Unit# 4320014
NUT & BOLT BAGS
Heavy-duty canvas construction. Features D-
ring and snap assembly on webbing straps,
and grommet reinforced drain hole.
Unit# 4320015
NUT & BOLT BAGS
Heavy-duty canvas construction. Features
inside pocket, reinforced bottom and top, D-
ring and snap assembly on webbing straps,
and drain hole.
Unit# 4320016
CARNEY BAGS
Canvas construction.
CARNEY BAGS
Canvas construction.
Unit# 4297008
TOOL BAGS
Constructed of heavyweight canvas duck.
Features steel frame top, leather straps, 2
nylon reinforced web handles, and hard bot-
tom with double tempered masonite board and
brass studs to protect against abrasion.
No. Dim. In.
2603-WC 26x12x14
No. Dim. In.
2747-1 42x72xFlat
No. Dim. In.
10-120 9x4x9
No. Dim. In.
10-160 8-1/2 x 10 x 3
No. Dim. In.
10-250-WARRENHEIM 6x8
No. Description
Dim. In.
Dia. x H
2015 Leather bottom, zeinth
cord handle 5.75 x 8
2008 Promotional use, zeinth
cord handle 5x6
2021
Molded top ring, leather
bottom and rope holes,
polypropylene handle
8x12
No. Description
Dim. In.
LxWxH
2113-12 #4 Canvas 12 x 7.5 x 12
2114-12 #8 Canvas 12 x 7-1/2 x 12
2114-14 #8 Canvas 14 x 7.5 x 12
Bags, Tool Boards
& Buckets
1-800-832-2297 13
TOOL BAGS
Steel frame mouth with hinge for rugged use. Canvas construction with
reinforced leather bottom.
TOOL BAGS
Wide bag constructed of heavy vinyl coated nylon with molded polymer
plastic bottom. Features 2 web handles, shoulder strap, and weather
flap. Measures 24 x 10 x 19.
TOOL BAGS
#4 Canvas construction with steel frame, web handle, hard bottom and
leather strap closure.
Unit# 4297013
TOOL BAGS
For use with compression tools and bolt cutters.
Vinyl coated nylon construction with reinforced
bottom. Features hanger strap and (2) grommets.
LINE HOSE BAGS
Heavy duty canvas construction, molded top
ring, and bottom leather rope holes. Polypropyl-
ene handle.
HOT LINE STORAGE BAGS
No. No. Pockets
Dim. In.
LxWxH
5003-20 1 Exterior, 15 Interior 20 x6x15
No. Description
2117-1LOSP 1 Outside pocket
2117-1HDL Wheels and 1 outside pocket
2117-2OSP 2 Outside pockets
2190-2OSPK 2 Large outside pockets
No. Dim. In.
2175-GP 24x10x18
No.
No.
Pockets
Dim. In.
LxWxH
2651 2 10x3x19
2651-2 3 10x3x19
No. Dim. In.
1920-31 8x31
No. Description Size In.
12-200 Yellow Vinyl 6 x 168
Bags, Tool Boards
& Buckets
14 1-800-832-2297
STORAGE FOR HOT STICKS
& CUTTERS
.
No. Description
01-4002 Case for 10-207
01-008 Case for 11-018 ratchet cutter
01-015 Case for 13412 & 13413 ratchet cutters
01-074 Bag for 4.5 line hoses. Measures 8 x 48
01-079 Linemans belt bag. Measures 9 x 4 x 9
01-4007 Storage bag fits both 15KV, 25KV, and 35KV ground sets
05-1001 Complete boom mounted hot stick holder 10 W x 7 H
05-800 5-Pocket Tuff-Wrap bag with inside pockets. Measures 14 x7x9
05-814 Compression tool aerial bucket with (5) compartments and (1) bit holder. Measures 16 x 9 x 20
05-805 Tool apron with (9) pockets and knife snap. Large pocket measures 4 x 8 and overall bag measure 19 x 10
05-826 Bucket storage bag with pair of 10-118 hooks
05-827 Bucket storage bag without hooks
05-825 Tool board without hooks
05-825-L Lighted tool board without hooks
C-208 Lightweight bucket storage canister for HV-208 Hot Stick
C-40 Case for standard hot sticks S-240 and ST-240
C-414 Hot stick carrying case for 4 hot stick. Single pocket
C-444 Hotstick carrying case for 4 hot stick. (4) pockets
C-426 Hotstick carrying case for 6 hot stick. (2) pockets
C-418 Hotstick carrying case for 8 hot stick. Single pocket
C-8110 Hotstick carrying case for 10 hot stick. Single pocket
C-8112 Hotstick carrying case for 12 hot stick. Single pocket
C-8104 Hotstick carrying case for 46 hot stick
C-8106 Hotstick carrying case for 66 hot stick
C-8108 Hotstick carrying case for 86 hot stick
C-8104 05-825 05-827
01-4002 01-008 01-074
05-1001 05-814
05-800
05-805
Bags, Tool Boards
& Buckets
1-800-832-2297 15
Unit# 2936013
TOOL BAGS
Electricians
Heavy-duty canvas construction with full-grain
leather bottom, sides and riveted buckle
straps. Features steel framed mouth with
hinge, nylon handles and (16) interior and
exterior pockets.
Unit# 2936014
TOOL BAGS
Multi-Pocket
Heavy-duty nylon construction. Features steel
framed mouth with hinge, padded nylon han-
dles, adjustable shoulder strap, and (31) inte-
rior and exterior pockets.
TOOL BAGS
Leather
Constructed of extra-heavy leather. Features
removable, padded shoulder strap and three-
ply bottom studs.
Unit# 1728004
TOOL BAGS
Nylon
Vinyl-coated nylon fabric construction. Features
reinforced bottom with metal protective studs,
nylon web handles, wide opening steel frame
mouth, and protective storm flap. Orange.
Unit# 1728045
TOOL BAGS
Tool Totes
Polyester construction. Features 2 wide poly-
propylene padded carry handles, leather
strap, molded bottom with drain holes, and
heavy-duty chain tape thong. Includes (10)
interior pockets, large interior compartment
and (7) exterior pockets.
Unit# 1728042
TOOL BAGS
Vinyl Bottom
Heavy-duty canvas construction. Features
steel frame hinged mouth, harness leather
handles with (2) retaining straps and buckles,
and non-scratch studs on base. Vinyl bottom
extends 8 on sides for moisture resistance.
Unit# 1728003
UTILITY BAGS
Heavy canvas construction. Edge reinforced
with 1/4 rope. Metal snaps on loops; attaches
to belts up to 3 wide. Ventilating eyelet in bot-
tom.
No.
Dim. In.
LxWxH
015811 20x12x10
No.
Dim. In.
LxWxH
015812 18x11x10
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
No.
Dim. In.
LxWxH
5108-24 24x7x8
No.
Dim. In.
LxWxD
5180 24x10x18
No.
Dim. In.
LxWxH
58890 15-1/2 x 7-1/2 x 10
No.
Dim. In.
LxWxH
5105-20 20x6x15
5102-24 24x6x15
Dim. In.
No. Opening Overall
5142 BAG 8x3 9x10
Bags, Tool Boards
& Buckets
16 1-800-832-2297
Unit# 1882012
TOOL ORGANIZERS
55-Pocket  Bucket
For use over 5-gallon buckets. 600 Denier
polyester with ripstop design. Features inter-
nal drill holster, speed square sleeve, and (53)
additional pockets inside and out. Water- and
tear-resistant.
Unit# 1882013
TOOL ORGANIZERS
50-Pocket  Bucketless
600 Denier polyester with ripstop design. Fea-
tures removable hard shell inner bottom, inter-
nal hammer loop, padded handles and (50)
additional pockets inside and out. Water- and
tear-resistant.
Unit# 2936015
TOOL CARRIERS
Open
Double layer lightweight Cordura® fabric con-
struction. Features box shaped design with
reinforced bottom and rubber feet, square
opening with snap handle, tape measure
holder, and (37) pockets and loops.
Unit# 4297009
TOOL CARRIERS
Soft-Side
Heavy-duty natural cotton duck construction.
Features (20) inside and (2) outside pockets
and shoulder strap.
Unit# 2936017
TOOL CADDIES
20-Pocket
Double layer lightweight Cordura® fabric con-
struction. Features padded handle and shoul-
der strap, tool snap, electrical tape strap, steel
hammer loop, tape measure holder and (20)
large capacity pockets.
Unit# 2936024
TOOL POUCHES
8-Pocket
Leather construction
with washer rivets. Fea-
tures tapered compart-
ments, (4) small
compartments, metal
tool clip, tape chain and
tape measure holder.
Fits belts up to 3 wide.
Unit# 2936030
TOOL BELTS
Leather
Features steel roller double-pronged buckle.
Can be cut to fit 29 to 52 waist.
No. Desc.
49-17-0170 55-Pocket tool organizer
No. Desc.
49-17-0180 50-Pocket tool organizer
Visit our Web Site at
www.u-s-c-co.com
for our full line card.
No.
Dim. In.
LxWxH
015813 11x9x10
No.
Dim. In.
LxWxH
2196 8-1/2 x 8-3/4 x 9
No.
Dim. In.
LxWxH
015815 10x7x10-1/2
No.
Dim. In.
LxWxH
025811 7 x 6 x 10-1/2
No.
Dim. In.
LxW
985811 57 x 2
Bags, Tool Boards
& Buckets
1-800-832-2297 17
Unit# 2936016
CANVAS BAGS
Zipper
For storing small items or tools. Heavy-duty canvas construction with
zipper closure.
Unit# 4329002
TOOL BOARDS
Aerial Lift Bucket
Fits buckets with or without liners. Features four-pocket leather tool
pouch, leather knife pouch, (4) nylon loops with condura backing, and
heavy-duty condura utility bag with riveted leather loop.
Unit# 4329004
AERIAL TOOL TRAYS
Outside
For storage of nuts, bolts and connectors. Fits lift buckets with or with-
out liner.
Unit# 4297010
TOTE BAGS
Heavy weight canvas construction. Features
(4) inside tool loops, inside vinyl pouch and 2
wide handles.
Unit# 4297017
BOOK COVERS
For use in protecting field manuals and speci-
fication books. Heavy vinyl construction. Fea-
tures 3-sided zipper closure and web handles.
Lays flat when open. Royal blue.
No.
Dim. In.
LxH
015814 12 x 7
No.
Dim. In.
WxL
05-829 18 x 19-1/4
Check our website for
special promotions.
www.u-s-c-co.com
No.
Dim. In.
LxWxD
05-951 14x6x7-1/2
No.
Dim. In.
LxWxH
2199-CP 13x5x12
No.
Dim. In.
LxWxThick.
2799-CP 14x8x12
Bags, Tool Boards
& Buckets
18 1-800-832-2297
Unit# 4297016
KNEELING PADS
Heavy-duty nitrile foam construction with
cushion top. Non-skid.
Unit# 4297011
RESCUE SYSTEM BAGS
Sky Genie
Vinyl coated nylon construction. Features spe-
cially designed lid with snap locks to protect
contents from water, and web loops on back
for attachment to boom. Accommodates res-
cue device with 75 to 150 rope.
Unit# 4297012
RESCUE BLOCK BAGS
Vinyl construction. Features glove bag design
with hook and loop closure, drainage grommet
in bottom and 1 wide web handle. Water
resistant. Red.
ROUND EYE SWIVEL SNAPS
Round eye swivel snap with quick release clo-
sure.
U
SUBSTATION CARD HOLDERS
Red vinyl coated nylon with clear front. Fea-
tures hook & loop closure and double magnets
to secure pouch to transformer.
PLACARDS
No. 1179-R42. Danger banner with reflective
tape on both sides.
No. 1632-GR. Florescent orange identification
marker for grounds.
POLE WRAP FOR HOLD CARDS
Wraps around pole an dis secured with hook &
loop. Warning is Worker On Line. Features
clear pouch to hold card and reflective striping
for night time visibility.
No.
Dim. In.
LxW
2735-11-18 10-1/2 x 18
No.
Dim. In.
LxWxH
2642-150 13x5x12
No.
Dim. In.
LxWxH
2647 8x4x16
No.
Eye
Open. In.
Snap
Open. In.
OAL
In.
2910 9/16 5/16 3-5/16
No. Dim. In.
5295-MAG 7x12
We are continually
adding new products.
Call us with your
inquiries.
No. Description Dim. In.
1179-R42 Danger 8 x 14
1632-GR Grounds 16 x 18
No. Dim. In.
1180-45 6x45
Bolt & Cable Cutters
1-800-832-2297 19
Unit# 1260002
CENTER CUT CUTTERS
H.K. Porter®
For use in plant mainte-
nance applications. Fea-
tures drop-forged alloy
steel jaws with lockplate;
toggle joints; screw-type
adjustment for edge
realignment, and steel
handles with rubber grips.
CENTER CUT CUTTERS
H.K. Porter®
Center cut blades and rubber hand grips.
CABLE CUTTERS
H.K. Porter®
Cuts soft and hard steel cable, wire rope, and
small ACSR cable. Features shear-cut blades
and tubular steel handle.
ANGULAR CUTTERS
H.K. Porter®
Ratchet-type jaws with notched shear-cut
blades. Cuts Aircraft cable, EHS guy strand,
wire rope and stainless steel cable.
STEEL STRAP CUTTERS
H.K. Porter®
Sheer-cut blades with cushion grip handles.
One-handed operation gives extra leverage
for continuous cuts.
Unit# 1260004Guy Strand Cutters
Ratchet  H.K. Porter®
For use on EHS guy strand, and mild steel
rods and bolts. Features notched shear-cut
blades and formed steel handle.
Unit# 4329012
GUY STRAND CUTTERS
Heavy-Duty
For cutting 1/2 EHS guy strand. Cutting jaw
retracts as handles are opened and closed.
Features release lever for opening jaw, and
fiberglass handles.
Unit# 1260005
HARD CABLE CUTTERS
Ratchet  H.K. Porter®
For use in cutting ACSR, ACAR, ZEBRA and
self-supporting telephone cable. Features
shear-cut blades, jaw keeper, ratchet and
chain for increased cutting pressure, and
formed steel handles.
Note: Not recommended for cutting insulated
copper or aluminum.
Unit# 1260006
WIRE ROPE CUTTERS
H.K. Porter®
For use in cutting aircraft cable, EHS guy
strand, wire rope and stainless steel cable.
Features ratchet-type jaws, notched shear-cut
blades, and formed steel handles.
No.
Lgth.
In.
1490MC 14
No. Description
Lgth.
In.
Fiberglass Handle
0090FC General purpose 18-1/4
0190FC General purpose 24-1/2
0190FCX General purpose 24
0290FC General purpose 30-1/2
0290FCS Shear type hand
operated cutter 25-1/2
0290FCX Heavy duty 30
Tubular Steel Handle
0190MC General purpose 24
0190MCX Heavy duty 24
0290MC Industrial grade 30
0390MCX Heavy duty 36
No. Description
Lgth.
In.
0290FHJ ACSR wire rope and cable
cutter 28
No. Description
Lgth.
In.
0390MA Angular-style jaws with
clipper-cut blades 36
No.
Lgth.
In.
1290G 12
No.
Jaw
Cap. In.
Lgth.
In.
8690CK 1/2 28
No. Desc.
10-260 Guy strand cutter
No.
Jaw Cap.
In.
Lgth.
In.
8690FH 1-3/16 29-1/4
No.
Jaw Cap.
In.
Lgth.
In.
8690TN 336
Bolt & Cable Cutters
20 1-800-832-2297
Unit# 2936029
CABLE CUTTERS
Ratchet
Compact design for use in confined spaces.
Features single speed ratchet mechanism,
heavy-duty blades and blade release.
No. 759. Cuts copper to 500 kcmil, aluminum
to 750 kcmil and communications cables to 1-
1/8 dia.
No. 45206. Cuts copper to 600 kcmil, alumi-
num to 600 kcmil and communications cables
to 1-3/8 dia.
Unit# 4329016
CABLE CUTTERS
Ratcheting
Cuts aluminum and copper
cables. Jaws surround conduc-
tor to eliminate blade distortion.
Features release lever and
plastic-dipped handles. Wire
capacity: 336 ACSR/500 MCM
aluminum; 350 MCM copper.
CABLE CUTTERS
Non-Insulated  Ratcheting
For cutting ACSR wire in
trenches, manholes and other
confined spaces. Features offset
cutting head, heat-treated jaws,
keeper on upper jaw, open/close
selection lever, and handle
plunger for fast advance or
retraction. Wire cap. 556 ACSR.
Warning: Not insulated. Do not
use on energized conductor.
RATCHET CABLE CUTTERS
Designed to cut up to 954 ACSR and 1000
kcmil copper and aluminum. Features rugged
steel blades and precision bi-directional
ratchet mechanism for positive blade control.
RATCHET CABLE CUTTERS
Designed to cut up to 954 ACSR and 1000
kcmil copper and aluminum. Features rugged
steel blades and precision bi-directional
ratchet mechanism for positive blade control.
RATCHET CABLE CUTTERS
Designed to cut up to 954 ACSR and 1000
kcmil copper and aluminum. Features rugged
steel blades and precision bi-directional
ratchet mechanism for positive blade control.
CABLE CUTTERS
Ratcheting
Allows straight cuts with minimum effort. Fea-
tures hold-open spring for quick cutting action,
quick-release lever and large finger-formed
handles..
Unit# 1728048
CABLE CUTTERS
Shear-Cutting
Features replaceable forged steel jaws with
black oxide finish, heavy-duty blade stop pins
in head, beveled tips for positive mating and
fiberglass handles with heavy vinyl grips.
Capacities: 1-3/4 dia. soft cable, 1000 MCM
copper, 1200 MCM aluminum.
Note: Not for steel/ACSR.
Unit# 1728012
CABLE CUTTERS
High-Leverage
Compact design for use in confined spaces.
Red plastic coated handles.
No. Lgth. In.
759 10-1/2
45206 10
No.
Max. Jaw
Open. In.
OAL
In.
11-014 1-1/4 10
No.
Max. Jaw
Open. In.
OAL
In.
10-205 219
No. Lgth. In.
RCC1000 20
No. Lgth. In.
RCC336 10.5
No. Lgth. In.
RCC750HD 10.5
No. Cutting Capacity
63607 336MCM ACSR, 400MCM copper,
600MCM aluminum
63800A
CSR
477MCM ACSR, 1-1/4 CU-AL
stranded, 1 CU Solid, 1/2 Guy
Strand
No.
OAL
In.
63045 32
No. Lgth. In.
63050 9-1/2
Visit our Web Site at
www.uscco.com
for our full line card.
Bolt & Cable Cutters
1-800-832-2297 21
Unit# 4310005
CABLE CUTTERS
Ratchet
For use in cutting solid, shrouded or multiple copper or aluminum con-
ductors. Features quick-release thumb lever and handle locking mech-
anism.
Note: Not for use on steel or ACSR cable.
Unit# 4329014
BOLT CUTTERS
Center Cut
For cutting steel bolts, wire, rods, chain links and case hardened
chains. Maximum hardness: Brinell 450; Rockwell C 48. Features short
cutting edge, cam hinge bolts for jaw alignment, and steel handles. 18
OAL.
Unit# 1307336328
BOLT CUTTERS
Used to cut hard material, high tensile steel, bolts, wire, rods, chain
links and case hardened chains. Features replaceable fiberglass han-
dles with unicellular foam core. and cam hinge bolts for use in jaw
alignment.
Unit# 2120001
BOLT CUTTERS
Center-cut design with hardened alloy steel jaws and single-step inter-
nal cam mechanism.
BOLT CUTTERS
H.K. Porter®
Drop-forged jaws with center cut blades.
No.
Lgth.
In.
Max. Cable
Dia. In.
34925 9.37 1.75
Cutting Cap. In.
Reinforce.
Steel
Bar
Steel
Steel
Wire
Music
Wire
10-450 5/16 1/4 1/4 7/32
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
No. Handle Length In.
Overall Length
In.
10-667 16 24
Metal
Cutting Cap. In. OAL
No. Soft Medium Hard In.
5228-98925 5/16 1/4 3/16 15
5228-98960 7/16 3/8 5/16 26
No. Description
Lgth.
In.
1490AC All purpose with aluminum alloy handle 14
Bolt & Cable Cutters
22 1-800-832-2297
BOLT CUTTERS
Heavy Duty
Designed for constant use in demanding appli-
cations. Features heavy duty side plates, steel
handles and precision ground forged alloy tool
steel jaws. 4000 lbs. jaw pressure with 50 lbs.
hand pressure..
Unit# 1728049
BOLT CUTTER HEADS
Forged alloy steel construction.
Unit# 1632009
CONDUCTOR CUTTERS
Hydraulic
For cutting conductors up to 954 MCM ACSR,
all-aluminum and 500 MCM copper. Features
knob-handle for pump operation, Epoxiglas®
pole, and adjustable jaws.
Unit# 1632011
CONDUCTOR CUTTERS
For cutting aluminum or copper conductors.
Heat treated steel construction. Features
shear-type blades and insulated Epoxiglas®
handles with black rubber cushion grips.
Unit# 1728009
DIAGONAL-CUTTING PLIERS
High leverage design with heavy-duty cutting
knives and blue plastic coated handles. Jaw
measures 1-3/16 W x 1 L. 8 OAL.
Unit# 1728024
DIAGONAL-CUTTING PLIERS
High Leverage
Features beveled cutting knives, and curved,
plastic dipped handles.
Unit# 1728011
DIAGONAL-CUTTING PLIERS
All-Purpose
Heavy steel construction with induction-hard-
ened cutting surfaces, tapered nose for work-
ing in confined areas, and red plastic coated
handles.
Unit# 1728013
SIDE-CUTTING PLIERS
2000 Series
For cutting ACSR, screws, nails and hardened
wire. High-leverage design with knurled jaws
and blue plastic dipped handles.
PLIERS KIT
Crescent®
Used for installing and removing retaining ring
clips. Cushion grip handles. Kit includes exter-
nal ring plier, internal ring plier, one pair each
of .035, .047 and .070 tips.
No.
Hard Cut.
Cap. In.
Soft Cut.
Cap. In.
OAL
In.
63542 1/2 11/16 42
No.
For Bolt
Cutter No.
63214 63314
No.
Pole
Dia. In.
Lgth.
Ft.
C4030732 1-1/4 8
Lgth. In.
No. Handle Overall
C4031422 28-1/2 35
No. Desc.
D2000-28 Straight
D2000-48 Angled head
No.
Jaw
Lgth. In.
OAL
In.
D228-8 13/16 8
No.
Jaw Dim. In.
WxL
OAL
In.
D252-6 3/4 x 13/16 6
No.
Jaw Dim. In.
WxL
OAL
In.
D2000-7 1-1/32 x 1-9/32 7-7/8
D2000-8 1-7/64 x 1-7/16 8-11/16
D2000-9NE 1-1/4 x 1-19/32 9-3/8
No. Description
Lgth.
In.
DR23H Retaining Ring Pliers Kit 6-1/4
Compression
Tools & Dies
1-800-832-2297 23
nit# 1632034
COMPRESSION TOOLS
Hydraulic  Versa-Crimp®
Features 360° rotating head and flip-top latch
for removal from large connectors. Includes
(2) 14.4V rechargeable batteries, AC charger,
shoulder strap, service manual and carry
case.
nit# 4333003
INSTALLATION TOOLS
Compression Connector  Burndy®
Hytool
For use in installation of line, pole and house
connections. Forged steel jaw construction.
Features spring-loaded positive lock die
retainer buttons, orange alignment grooves,
over center cam action, locking adjustment
screw, and anti-slip hickory handles. 9000-lb.
crimp force. 25-3/8 length.
Unit# 4333004
RATCHETING CRIMPERS
Burndy® Hytool
For installation of 5/8 Insu-
link and Linkit service
entrance connectors with sin-
gle crimp per end. Features
full cycle ratchet and cam
mechanism, forged steel
jaws, stainless steel indentor,
and spring loaded comfort
grip handles. 50-lbs. hand
force develops 6000-lbs.
crimp force.
RATCHET HAND TOOLS
Full Cycle  HYTOOL
For use on nylon insulated terminal and
splices. Incorporates a full cycle ratchet mech-
anism that provides a complete, positive crimp
each time. Features color coded dies, narrow
nose and comfort grips.
RATCHETING CRIMPERS
Hytool
Hand-held full cycle ratchet
tool for #8-22 AWG uninsu-
lated terminals and splices.
RATCHET HAND TOOLS
Full Cycle  HYTOOL
For use on copper connectors from #8 AWG to
240 kcmil. Aluminum connectors form #8
AWG to 4/0 AWG. Allows proper crimping of
sleeves and terminations in crimping under-
ground applications.
CRIMP TOOLS
HYTOOL
For use on #8 - 4/0 AWG copper terminals and
splices.
No.
Conductor
Range
VC6FTBP #10 Str. to 750 MCM Al/Cu
No.
Die
Grooves
MD68 O and D3
MD6 BG and D3
No.
Lgth.
In.
OH25 12-1/4
No. Wire Range Lgth. In.
MR18 #22-10 AWG 8.86
No. Lgth. In.
Y8MRB-1 9-1/2
No. Lgth. In.
OUR840 13
No. Lgth. In.
MRC840 26
We are continually
adding new products.
Call us with your
inquiries.
Compression
Tools & Dies
24 1-800-832-2297
Unit# 4333005
HYDRAULIC CRIMPERS
Cordless  Burndy® Hypress
For use in tap, terminate and splice compression applications. Features
ergonomic design, 360° rotating C-shaped head, trigger guard, audible
pop-off valve and safety lanyard connection. Measures 17.6 L x 3.7 W
x 13.9 H. Includes (2) 18V Ni-MH batteries, battery charger, lanyard
and carry case.
Unit# 4333006
HYDRAULIC CRIMPERS
Cordless  Burndy® Patriot®
For use on copper, aluminum, ACSR, steel, copperweld, alumoweld,
compressed, compact, stranded and solid splices, taps or terminations.
Features 180° rotating latch head design, permanent D3 crimping
groove, spring loaded die retaining pins, variable speed trigger, trigger
guard and mechanical ram release. Measures 14-1/2 L x 3-1/2 W x
13-3/4 H. Includes (2) 18V Ni-MH batteries, battery charger and carry
case.
Unit# 4333016
HYDRAULIC CRIMPERS
Cordless  Burndy® Patriot®
For use with U-style dies on copper, aluminum and ACSR. Features
360° rotating rubber covered head with large jaw opening, trigger
guard, and safety lanyard connection. Measures 15-3/4 L x 3-1/2 W x
13-1/2 W. Includes (2) 18V Ni-MH batteries, battery charger, lanyard
and carry case.
Unit# 4333017
HYDRAULIC CRIMPERS
Cordless  Burndy® 4-Point®
For use on copper, aluminum, compressed, compact, stranded, solid
and flex conductors. Features rotating head, locking latch pin, audible
pop-off valve, trigger guard and safety lanyard connection. Measures
17.6 L x 3.7 W x 13.9 H. Includes (2) 18V Ni-MH batteries, battery
charger, lanyard and carry case.
No.
Output
Force Tons
PAT4PC834-18V 6
No.
Output
Force Tons
PAT600-18V 6
We offer all 60 and 100 ton dies.
Call for information.
No.
Output
Force Tons
PAT750XT-18V 12
No.
Output
Force Tons
PAT81KFT18V 6
We offer all P, U and W dies.
Call for information.
Compression
Tools & Dies
1-800-832-2297 25
CRIMPING TOOLS
Powered in both the advance and retract
directions to prevent hang-ups. Relief valve
signals operator when crimp is complete and
heat rotates for easy tool positioning.
No. LPK1240K. Compatible with dies for
Kearney PH-2 and PH-3 tools.
No. LPK1240. Compatible with dies for
Burndy, Alcoa, Anderson and Tomas & Betts.
Unit# 4333008
HYDRAULIC CRIMPERS
Cordless  Burndy® Patriot®
In-line design for use with cop-
per, aluminum, ACSR, steel,
copperweld, alumoweld, com-
pressed and compact conduc-
tors. Features 350° rotating
head with interchangeable scis-
sor action jaws, spring loaded
die retainer buttons, activation
and release triggers, and large
hand grip. 6 ton output force.
Measures 20.91 L x 3.69 W x
5.48 H. Includes (2) 14.4V Ni-
MH batteries, battery charger
and carry case.
Hydraulic Crimpers
Accessories
CRIMP TOOLS
Cordless
Features one hand operation and wide crimp-
ing jaws to easily fit over connectors. Intelli-
gent Crimping System Technology includes a
pressure sensor that monitors the crimping
force of each crimp and provides operator a
visual and audible alert if the force is below
specifications. 18V Lithium-ion battery and
LED worklight.
CUTTING TOOLS
Battery Bolt & Lock
Designed to cut one-time disposable locks,
shipping container seals and small diameter
bolts. Features 18V lithium ion battery, LED,
one trigger control, 30 min. charge time, 350°
rotating cutting head, and overmolded tacky
grip.
Unit# 4333013
HYDRAULIC CRIMPERS
Manual  Burndy® Hypress
For use on tension sleeves, taps,
aerial cable, terminals and stops.
Features 355° rotating rubber
covered head, exposed die
release buttons, large jaw open-
ing, audible pop-off pressure
relief valve, and ergonomic han-
dle design with trigger drain and
comfort grips. Accepts U-type
dies. Measures 23.96 L x 8.71
W x 2.86 H. Includes carry case.
Unit# 4333014
HYDRAULIC CRIMPERS
Manual  Dieless  Burndy®
Hypress
For use in terminal and splice
compression applications. Fea-
tures 360° rotating flip-top head,
pivoting nest die, locking latch
pin, audible pop-off pressure
relief valve, and ergonomic han-
dle design with trigger drain and
comfort grips. Measures 25.6 L
x 2.5 W x 7.7 H. Includes carry
case.
Unit# 2936031
HYDRAULIC CRIMPERS
Cordless
For use with U-
style, 12 ton
dies. Features
two-speed
pump, repeating
retraction stop,
LED light, 360°
rotating head
and pistol grip.
24,000 lbs.
crimping force.
Measures 16-1/
2 L x 2-7/8 W x
14-1/2 D. Includes (2) 18V lithium ion batter-
ies and carry case.
No.
Operating
Pressure PSI
Crimping
Force
LPK1240K 1500 to 2500 12 Ton
LPK1240 1500 to 2500 12 Ton
No.
Die
Grooves
PATMD6-14V BG&D3
PATMD6814VDC O&D3
No. Desc.
W28K Cutter die
No.
Crimping
Force Tons
Lgth.
In.
EK425L 6 18-1/2
No. Description Lgth. In.
ETS12L11 120V Charger 13-5/8
No.
Jaw
Open. In.
Output
Force Tons
Y750HSXT 1.65 12
No.
Output
Force Tons
Y81KFT 6
No. Desc.
E12CCXL11 Includes 120V battery charger
E12CCXL12 Tool only
Compression
Tools & Dies
26 1-800-832-2297
Unit# 2936032
HYDRAULIC CRIMPERS
Cordless
For use with W-style, 6 ton dies. Features two-
speed pump, automatic retraction, repeating
retraction stop, LED light, and pistol grip.
12,000 lbs. crimping force. Includes (2) 18V
lithium ion batteries, 120V battery charger and
carry case.
Unit# 2936033
HYDRAULIC CRIMPERS
Cordless
12 ton. Features two speed pump, pressure
monitoring system, automatic retraction stop,
LED light, and pistol grip. 24,000 lbs. crimping
force. Includes (2) 18V lithium ion batteries,
battery charger and carry case. Measures 16-
1/4 L x 2-7/8 W x 12-1/2 D.
Unit# 2936034
HYDRAULIC CRIMPERS
Cordless  Dieless
For use on copper and aluminum lugs and
splice through 1000 kcmil. Indent style dieless
design. Features pressure monitoring system,
automatic retraction stop, LED light, and pistol
grip. 24,000 lbs. crimping force. Includes (2)
18V lithium ion batteries, 120V battery charger
and carry case.
Unit# 4333018
RECHARGEABLE BATTERIES
Ni-MH
For use with cordless hydraulic crimpers.
CUTTING TOOLS
Cordless
Designed specifically to cut ACSR, guy strand
and ground rods. Features 18V lithium ion bat-
tery, retraction stop, LED, Two-stage hydraulic
system, 350° rotating head, and one trigger to
control all tool functions.
Unit# 4333015
HYDRAULIC CUTTERS
Manual  Burndy®
For cutting bare or insulated copper and alu-
minum cable to 1.29 dia., ACSR, ground rod
and soft steel bolts to 5/8, rebar and standard
guy strand to 1/2, and EHS guy strand to 3/8.
Features 180° rotating latch style head, hard-
ened steel blade, rapid advance pump, and
ergonomic handle with trigger drain and com-
fort grips. Measures 22.4 L x 2.5 W x 6.6 H.
Includes carry case.
Unit# 4333007
HYDRAULIC CUTTERS
Cordless  Burndy® Patriot®
Features 180° rotating latch head design, pre-
cision cutting blades, mechanical ram release,
trigger guard and safety lanyard connection.
Includes (2) 18V Ni-MH batteries, battery
charger, tool retention lanyard and carry case.
No. PATCUT129ACSR-18V. For use on cop-
per and aluminum cable to 1.29, ACSR, soft
steel bolts and ground rod to 5/8, rebar to 1/
2, and EHS guy strand to 3/8.
No. PATCUT245CUAL-18V. For use on cop-
per or aluminum cable to 2.45 OD.
Note: Not for use on steel, ground rod, rebar
or guy wire.
No.
Dim. In.
LxWxD
ECCXL11 16-1/2 x 2-7/8 x 14-1/2
No. Desc.
Battery
Charger
Volts
EK1240L11 Quad-Point dieless
hydraulic crimper 120
EK1240L12 Hydraulic crimper
for U-style dies 12
No.
Dim. In.
LxWXD
EK12IDL11 16-1/2 x 2-7/8 x 14-1/2
No. Volts
26002820 18
No. Description
ESG45L11 Battery-powered ACSR cable
cutter with 120V charger
ESG45L120 Cable cutter with 120 VAC
adapter
ESG50L11 Battery-powered cable cutter
with 120V charger
ESG55L11 Battery-powered ACSR cable
cutter with 120V charger
No.
Output
Force Tons
YCUT129ACSR 7
No.
Dim. In.
LxWxH
PATCUT129ACSR-18V 14-1/2 x 3-1/2 x
13-1/2
PATCUT245CUAL-18V 18 x 3-3/4 x 14-3/4
PATCUT129ACSR-18V
PATCUT245CUAL-18V
Compression
Tools & Dies
1-800-832-2297 27
CRIMPING TOOLS
Cordless  Hydraulic
Features overmolded ergonomic handle, 18V
Li-Ion batteries, 30-minute smart charger and
C-Head crimp design with 355° head rotation.
Includes case.
CRIMPING TOOLS
Cordless  Hydraulic
Allows user to interchange different cutting
blades customized for the application. Fea-
tures C-head cutter and 355° swivel. For use
on ACSR, guy strand, ground rod, rebar, soft
steel bolts, copper and aluminum.
HYDRAULIC PUMPS
Electric
Provides high quality crimps with built-in fac-
tory set pressure release valve and audible
recycling of pump to signal completion of
crimp cycle. Easy to lift, carry and transport
around jobsite. 115V-AC electric powered
motor.
HYDRAULIC PUMPS
Gasoline Driven
Portable pump with sturdy steel roll cage. Fea-
tures durable heavy-duty (4) HP engine, man-
ual control valve for easy control of crimping or
cutting, and fast hose assembly with quick dis-
connect.
HYDRAULIC TOOLS
Single Acting HYPRESS
Features easy to carry design and easy to
remove splices. Fast die changing and secure
die positioning with positive die release lock-
ing pins.
HYDRAULIC BREAKERS
Light & Medium Duty
Powerful enough for most breaking applica-
tions. Features control trigger built into handle,
18 braided whip hoses and standard tool
attachment for use of all standard tool bits.
SIGN POST PULLERS
For use on most post sizes and shapes. Uses
serrated jaws or wraparound, high-strength
alloy chain. Includes chain.
No.
Output
Force Tons Lgth. In.
PAT46-LI 15 20.77
No. Lgth. In.
PATHCC10-18V 21.4
No.
Output Pressure
PSI
EPP10 10,000
No.
Output Pressure
PSI
GP10 10,000
No.
Force
Tons
Operating
Pressure PSI
Y60BHU 60 10,000
Check our website for
special promotions.
www.uscco.com
No.
Tool Steel
Cap. In.
Flow
GPM
HBR40 1 x 4-1/4 4-7
No.
Hydraulic Flow
Range GPM
Dim. In.
HxLxW
H4905A 4 to 6 26 x 10.5 x 10
Compression
Tools & Dies
28 1-800-832-2297
SIGN POST DRIVERS
Can drive a variety of post
sizes from small delineater
posts up to 3-1/2 round
posts including square, U
channel, breakaway stubs,
round, T fence and wood.
Features quick change front
head design with adapter for
different types of posts, and
integral trigger.
GROUND ROD DRIVERS
Can be used with Open- and Closed-Center
hydraulic systems. Dual guide rods provide
excellent control for driving rods straight, and
the remote on/off valve makes it easy to con-
trol the depth of the rod.
IMPACT WRENCHES
High Torque
Impact and temperature resistant replaceable
polymer grip designed to dissipate heat from
the cast handle. Features built-in hydraulic
check valve, large lifting eye for easy and
secure storage, and longer and wider trigger
for improved control with insulated gloves
7/16 hex, 1/2 drive size and 4-12 GPM flow
range.
TAMPER ASSEMBLIES
60 Pole
Makes quick work of setting poles, asphalt
patch, and general construction backfill com-
pacting. Features kidney-shaped foot and
reversible on/off valve for Open- and Closed-
Center hydraulic systems. 1000 - 2000 PSI.
Unit# 2936040
CABLE CUTTER BLADES
Unit# 4287001
COMPRESSION DIES
60 Ton
For compressing standard and HiTemp
compression accessories. Fits Alcoa 60ASC
and 60AFTGSC presses.
U
Unit# 4333009
DIE CASES
Burndy®
For storage and protection of dies (not
included). Steel construction.
No. PT29291. Measures 9-1/2 L x 6Wx1-1/
2 H.
Unit# 4333012
DIE HOLDERS
Burndy®
Tree shape design allows for easy insertion of
dies and secure storage.
No.
Blow
Energy
Ft-Lb
Blows Per
Min.
Lgth.
In.
HPD-T-U 81 1500 @ 8 GPM 32
No.
Blow Energy
Ft-Lb
Blows
Per Min.
Lgth.
In.
HRD-1 63 1740 @ 8
GPM 25-1/2
No. Description
HW1 Includes 49314 heavy-duty adapter
HW1V
Includes 49314 heavy-duty adapter
and torque adjustment with 3
positions
No. Lgth. In.
H4802 60
H4802-1 85
No. Desc.
UC26 For aluminum and copper to 1
UCACSR For ACSR and guy strand
No.
Die
Section
Wt.
Lbs.
6010SH 10SH 3.50
6014SH 14SH 3.10
6016SH 16SH 2.90
6020AH 20AH 4.60
No. Die Type Cap. Sets
PT29291 U15
PT4946 WorX 12
No.
Die
Type
WDIETREE W
PT29291
PT4946
Visit our Web Site at
www.uscco.com
for our full line card.
Compression
Tools & Dies
1-800-832-2297 29
Unit# 4333010
DIE SETS
U-Type  Burndy®
For aluminum crimping applications. Fits Y35,
Y39, Y750HS, PAT750, PAT750XT-18V,
PAT46-18V and Y46 tools.
Unit# 4333011
DIE SETS
Burndy®
For aluminum crimping applications. Fits MD6,
MD7, Y500CTHS, PAT600-18V and PATMD6
tools.
Unit# 2936036
DIE KITS
For #8 to 350 aluminum connectors. Includes
carry case.
DIE KITS
6Ton
Die Kit for 8 AWG-600 kcmil copper connec-
tors. Includes case.
Unit# 2936037
DIE KITS
U-Style  12-Ton
For use with copper lugs and splices. Pro-
duces hexagonal style crimp.
CUTTING DIES FOR ACSR
W-Style
Can be used with any crimping tool that
accepts W dies. Improved steel and heat
treatment for better durability.
Unit# 2936039
DIE ADAPTERS
For use with Kearney O, T&B 6-ton and
Blackburn OD dies.
NUT RUNNERS
With Adapter
Deep well accepts up to 6 excess bolt length.
Features slim profile for easy use and storage.
Includes 7/16 hex quick-change adapter.
No.
Wire Size
MCM
U31ART 350
U34ART 500
U39ART-2 750
No.
Wire
Size
W-Type
W161 #6
W162 #4
W239 #2
W163 #1
U-Type
U165
No. Desc.
KD06AL Die kit
No. Desc.
K09-2GL Die kit
No. Desc.
KD12CU 12-Ton U-style die kit
No. Capacity
KD6-27 4/0 ACSR
No. Desc.
UAK Die adapter
No.
Hex
Size In.
Dia.
IN.
Nut
Sizes In.
NR1 7/16 1-3/4 1, 13/16, 3/4, 5/8
Conductor Grips
& Swivels
30 1-800-832-2297
Unit# 4294002
PULLING GRIPS
Double Weave  Single Eye
For regular load applications. Double weave galvanized wire construc-
tion. Features flexible eye.
Unit# 4294003
PULLING GRIPS
Double Weave  Single Eye  Shoulders
Double weave galvanized wire construction. Features flexible eye and
shoulders for added protection of utility and leading wire strands.
Unit# 4294004
PULLING GRIPS
Double Weave  Rotary Head  Shoulders
For use in heavy-duty applications. Double weave galvanized wire con-
struction. Features flexible eye and shoulders for protection of leading
edge of cable or ducting.
Unit# 4292001
PULLING GRIPS
Rotating Eye
For pulling aluminum or copper bare conductors, ACSR, ground wire,
wire rope or insulated cables in overhead stringing applications where
moderate loading is anticipated. Approximate breaking strength 6800
lbs. Dark green.
* At nominal diameter.
Unit# 1632035
PULLING GRIPS
Overhead
For use with ACSR, aluminum or copper bare conductor; ground wires,
messenger strands, wire rope and insulated cables. Features rotating
eye with .25 to .49 cable dia. capacity. Dark green. CSA certified.
Unit# 1632036
PULLING GRIPS
Junior
Attaches to pulling line, snake or fish tape. Galvanized steel, single
weave mesh construction. CSA certified.
No.
Size
Range In.
Mesh
Lgth. In.
Approx.
Breaking
Strgth. Lbs.
00670-050 0.75 to 1.12 18 6600
00670-100 1.13 to 1.49 21 10,000
00670-125 1.5 to 1.99 23 13,800
00670-200 2.00 to 2.49 24 14,200
No.
Size
Range In.
Mesh
Lgth. In.
Approx.
Breaking
Strgth. Lbs.
00680-050 0.75 to 1.12 24 6700
00680-100 1.13 to 1.49 24 10,000
00680-125 1.50 to 1.99 24 16,400
00680-200 2.00 to 2.49 24 18,500
00680-250 2.50 to 2.99 36 24,500
No.
Size
Range In.
Mesh
Lgth. In.
Rotary Head
Dim. In.
Dia. x L
Approx.
Breaking
Strgth. Lbs.
00690-050 0.75 to 1.12 24 7/8 x 2-3/4 6700
00690-100 1.13 to 1.49 33 1-3/8 x 5-3/8 13,000
00690-200 2.00 to 2.49 36 1-5/8 x 6-1/8 21,000
00690-250 2.50 to 2.99 38 1-7/8 x 7-3/8 33,000
No.
Cable
Dia. In.
Eye
Dim. In.
LxOD
Mesh
Lgth. In.*
08641831 .25 to .49 5 x 7/8 26
No.
Breaking
Strgth. Lbs.
Eye
Dia. In.
Lgth.
In.
03302016 6800 7/8 31
No.
Low Tension Wire
Dia. In.
Breaking
Strgth. Lbs.
Lgth.
In.
03305003 .50 to .61 1300 13
03305004 .62 to .74 1950 15
03305005 .75 to .99 2800 15-3/4
03305006 1 to 1.24 3900 18
We offer all pulling swivels and grips.
Call for information.
Conductor Grips
& Swivels
1-800-832-2297 31
Unit# 1632037
PULLING GRIPS
Overhead  Dura-Pull
For use with bare or insulated conductors and
synthetic rope in overhead transmission line
stringing applications. Features .38 to .62
conductor range; .50 to .90 rope range.
POLY LINE
Green
Used for pulling rope through conduit. Use
with power fishing systems directly from the
container. Resists tangling when dispensing.
Rot and mildew resistant.
Unit# 4294001
DUCT PULLERS
For use in installation of SDR 9 to 17 and
Schedule 40 polyethylene ducting. Alloy steel
construction. Features permanent outer
sleeve to prevent fluids from entering duct or
puller. 5 nominal duct size.
LINE SWIVELS
Constructed with a thrust bearing for tensile
load and a radial bearing for bending load.
High safe working load combined with a com-
pact design. All sizes incorporate an oil seal
and are manufactured from high strength
stainless steel.
CLEVIS
The clevis style pulling eyes are better if
attaching to a pulling rope or wire with an eye
that can be slotted in to the clevis and simply
attached with the pin provided.
WIRE ROPE BRIDLE SLINGS
Allows multiple pulls at one time by attaching
2, 3, or 4 cables or ducts to the puller. Manu-
factured from aircraft quality wire rope with
thimble eyes for durability.
PUSHING EYES
Multiplex
Designed to pull triplex or quadplex cables. 4
holes are sized for the cable conductors and
each hole has three setscrews to clamp down
on the cable. Includes (3) spare set screws
and hex key.
DUCT ENTRY GUIDES
Designed with extra long tube section that
goes inside the duct for greater stability. Fea-
tures one half of a quick-disconnect coupling
attached to spray nozzle that will direct the
lubricant onto the cable as it is fed into the
ducting.
No.
Breaking
Strgth. Lbs.
Lgth.
In.
033271038 14,000 48
No.
Lgth.
Ft.
Tensile
Strength
Lbs. Thickness
430 6500 210 1 Ply
Visit our Web Site at
www.uscco.com
for our full line card.
Inside Duct
Dia. In.
Outside Duct
Dia. In.
No. Min. Max. Max.
00650-500 4-5/16 5-1/8 5-9/16
No.
Working
Safe Load Lbs.
OAL
In.
00505-020 5000 4-3/4
No.
Nominal
Duct Size In.
Min/Max
Inside Duct
Dia. In.
00605-125 1-1/4 1.26/1.44
No.
Wire
Dia. In.
No. of
Legs
Leg
Cap.
Lbs.
Sling
Cap.
Lbs.
23375-040 3/8 4 4800 19,200
No.
Max Cable
Size MCM
Max. Core
Size In.
Lgth.
In.
24300-500 500 0.875 6-1/8
No.
Duct
Dia. In.
3:1 Safe Working
Load Lbs.
32500-200 2 3000
Conductor Grips
& Swivels
32 1-800-832-2297
PARALLEL-JAW GRIPS
Round jaw. Large eyelet opening in handle to
accommodate wide variety of hooks on hoists,
winches and tackle blocks.
Nos. KT4500 and KT4801. Features hot latch
that closes automatically to guard against grip
accidentally disengaging from wire.
PULLING GRIPS
Havens Grip
Designed for use when light, compact grip is
desired and where conductor damage is not a
factor. Gripping pressure of the knurled jaw is
applied to 1/4 cable area.
PARALLEL-JAW GRIPS
Designed with a round inside-jaw contour for
maximum contact to minimize conductor dam-
age. Includes latch to prevent grip from falling
in case of jaw disengagement from cable.
CHICAGO GRIPS
Hot Line Latch for Bare Conductors
Grips maintain temporary tension until the wire
or cable can be permanently terminated.
Designed for use on aluminum, copper,
weatherproof coated wire, PVC covered con-
ductors and messenger and guy strand.
CHICAGO GRIPS
Bare ACSR, Aluminum &
Stranded-Copper Cables
Grips maintain temporary tension until the wire
or cable can be permanently terminated.
Designed for use on aluminum, copper,
weatherproof coated wire, PVC covered con-
ductors and messenger and guy strand.
CHICAGO GRIPS
Grips maintain temporary tension until the wire
or cable can be permanently terminated.
No.
Jaw
Lgth. In.
Min./Max
Cable In.
Max. Safe
Load Lbs.
KT-4500 4 .180 to .600 5000
KT4600 5 .300 to .800 10,000
KT4800 5-1/8 .700 to 1.25 12,000
KT4801 5-1/8 .700 to 1.25 12,000
No.
Maximum
Cable In.
Max. Safe
Load Lbs.
1604-10 2 B&S .25 2500
1604-20 Steel Strand .50 5000
1625-20 Wire rope .75 8000
162520-1 Wire rope 1 8000
No.
Jaw
Lgth. In.
Min./Max
Cable In.
Max. Safe
Load Lbs.
1685-20 2.50 .157 to .886 4500
1685-31 4.50 .625 to
1.250 7500
No.
Jaw
Lgth. In.
Maximum
Cable In.
Max. Safe
Load Lbs.
1656-20H 4-3/16 1/0 ACSR
.40 4500
1656-30H 4-7/8 .53 4500
1656-40H 5-1/2 335,40 CM
ACSR .74 8000
We are continually
adding new products.
Call us with your
inquiries.
No.
Jaw
Lgth. In.
Maximum
Cable In.
Max. Safe
Load Lbs.
1656-20 41/0 ACSR
.40 4500
1656-30 4-3/4 .53 4500
1656-50 5-1/2
477,000
CM ACSR
.86
8000
1656-60 5-/12
605,000
CM ACSR
.96
8000
No.
Jaw
Lgth. In.
Maximum
Cable In.
Max. Safe
Load Lbs.
For Bare Wire
1613-30 34B&S
solid .20 1500
For Aluminum Conductors
1678-50 5-11/16 1.20 5500
For PVC-Covered Conductors
1659-20 4-3/16 .42 4500
1659-50 5-11/16 1.01 8000
For Large Diameter Conductors
1628-30 10-3/4
1,033,500
CM ACSR
1.24
20,000
For Extra-High-Strength Cables,
Messenger, Guy Strand, and Conductors
1613-40 4-3/16 .37 4500
1684-5F 5 .55 8000
Conductor Grips
& Swivels
1-800-832-2297 33
TUF-LUGGER LITE
Features 4-stroke Honda GXH-50 cc engine
and lightweight design. Adding snatch blocks
can double, triple or quadruple your pulling
strength.
TRANSPORT CASE
Tuf-Lugger
Transport case with molded shapes for acces-
sories. Protects winch during transport.
CAPSTAN DRUMS
Capstan drum with rope guide.
WINCH SUPPORT PLATES
Used to attach winch to vehicle using square
tubing and a bent pin, or to a pole or tree using
the pole mount. Pivots up to 45°.
CABLE PULLER
ACCESSORIES
REEL RODS
Features sturdy, powder coated, steel tube
frame with a 16 diameter storage basket. Up
to 400 ft. of rod can be stored in basket. Light
adjustable brake prevents the rod from reeling
out of the basket under its own tension.
NOTES
No.
Max. Pulling
Force Lbs.
Rope
Sizes In.
Wt.
Lbs.
41000-200 2200 3/8 - 5/8 35
No.
Outside
Dim.
Inside
Dim.
Wt.
Lbs.
42130-030 20x20x19 19x19x15 15
No. Size In. Wt. Lbs.
42100-337 3-3/8 2
No. Wt. Lbs.
42200-010 9
No. Description
42200-010 2 Square tubing, 5 Lbs.
42200-030 Towing ball adapter, 1.5 Lbs.
42200-040 Pole mount with anchor strap,
18 Lbs.
42200-050 Vertical pull winch support, 18
Lbs.
No.
Rod
Lgth. Ft.
Wt.
Lbs.
52000-400 400 13
Digging & Pole
Handling Tools
34 1-800-832-2297
Unit# 4309001
POLE MARKERS
Letter & Number
Solid aluminum construction. Features
embossed profile to reflect light, and Roman
typeface. Resists UV radiation, temperature
extremes, creosote leaching and salt spray. 2
high.
nit# 4295001
Electromark
MARKER HOLDERS
Horizontal  Slide-In
Aluminum construction. Markers slide in from
end; channel can be crimped with pliers to
hold markers in place.
Unit# 4295002
MARKERS
Slide-In
Embossed aluminum construction. Features
protective overcoating for corrosion resis-
tance. Measures 2-1/2 x 1-1/2. Yellow char-
acter on black background.
Unit# 4314001
POLE PULLER KITS
Hydraulic
Features low center of gravity, and low chain
hook-upy. Includes cylinder, base plate,
swivel chain hook assembly and 1/2 x 6 alloy
chain.
Unit# 4314001
POLE PULLER PADS
For use in pole pulling applications where full
ground contact is available. Constructed of
UHMW plastic material. Features 28 cutout
for pole, and (4) retaining bushings.
Note: Do not use to bridge open holes.
Unit# 4308004
No. Desc.
Numbers
UAR02-0 0
UAR02-5 5
Letters
UAR02-B B
UAR02-C C
UAR02-F F
UAR02-G G
UAR02-H H
UAR02-L L
UAR02-M M
UAR02-N N
UAR02-P P
UAR02-Q Q
UAR02-S S
UAR02-T T
UAR02-V V
UAR02-W W
UAR02-Y Y
UAR02-Z Z
Special Characters
UAR02-DASH Dash
No.
No.
Positions
HOLD-AL2S-H4 4
No. Desc.
Numbers
SLIDE-YK-AR-2S-4 4
SLIDE-YK-AR-2S-6 6
Letters
SLIDE-YK-AR-2S-A A
SLIDE-YK-AR-2S-B B
SLIDE-YK-AR-2S-C C
SLIDE-YK-AR-2S-D D
SLIDE-YK-AR-2S-E E
SLIDE-YK-AR-2S-F F
SLIDE-YK-AR-2S-I I
SLIDE-YK-AR-2S-J J
SLIDE-YK-AR02S-K K
SLIDE-YK-AR-2S-L L
SLIDE-YK-AR-2S-M M
SLIDE-YK-AR-2S-N N
SLIDE-YK-AR-2S-O O
SLIDE-YK-AR-2S-P P
SLIDE-YK-AR-2S-Q Q
SLIDE-YK-2S-R R
SLIDE-YK-AR-2S-S S
SLIDE-YK-AR-2S-T T
SLIDE-YK-AR-2S-U U
SLIDE-YK-AR-2S-V V
SLIDE-YK-AR-2S-W W
SLIDE-YK-AR-2S-X X
SLIDE-YK-AR-2S-Y Y
SLIDE-YK-AR-2S-Z Z
No.
Lift
Lbs.
Input Press.
PSI
4001D 50,120 2800
No. Dim. In.
HA0039 24 x 32 x 1-1/2
Check our website for
special promotions.
www.uscco.com
Digging & Pole
Handling Tools
1-800-832-2297 35
Oshkosh Tool Company, Inc.
POST HOLE DIGGERS
Features welded alloy steel blades, channel-
shaped steel fulcrum members and split or
solid handle design. Produces 6 dia. hole
.
Post Hole Diggers
Accessories
PIKE POLES
For use with pole line tools. Used to pike or
support a pole when setting in the field. Mal-
leable iron ferrule with rivet running through
ferrule, handle and pike.
DIGGING BARS
No. 852. Features handle made of steel pipe
1 in diameter for easy gripping. Blade mea-
sures 3-1/2 W.
No. 1065. Features 2 chisel on one end and
pointed on the other end..
Unit# 4308001
CANT HOOKS
Constructed of high-carbon steel with hard
maple handle. Features hook stop to prevent
hook from falling back.
Unit# 43080052-1
SKIDDING TONGS
For pulling or skidding material along ground.
Constructed of 1 round high-carbon steel
stock. Features heavy up-set hammer-forged
points with flattened sides at pivot. Includes
ring.
Note: Not for use in overhead lifting.
U
Unit# 4308006
TAMPING BARS
Light
For flattening and smoothing dirt, stone and
asphalt.
Unit# 4308002
SPOON SHOVELS
Features high-carbon steel blade and ash
wood handle with footage marks to indicate
depth of hole. Scoop shape allows cleaning of
mud and water from holes.
Eastern Pattern design for use in light, sandy
soils.
Western Pattern design for use in harder,
clay like soils.
No.
Length
Ft.
Split Handle
2050 8
2050-10 10
2050-12 12
Solid Handle
2051 8
No. Description
2050-103 Split digger head
assembly
2050A-8 8 Split handle
2051A-8 8 Solid handle
No.
Pike
Size In.
Handle
Lgth. Ft.
806 212
No. Description
Wt.
Lbs.
852 Digging spud with tamper 25
1065 1-1/8 x 8 Crow and dig bar 27
No.
Hook
Size In.
Handle
Lgth. Ft.
Standard Hooks
199A 2-1/4 4
200 2-1/2 4-1/2
206-484 2-3/4 6
Duck Bill Hooks
480 9
Swivel Point Hooks
3994 2-1/2 4
Cant Hook Handles
572 2-1/4 4
573 2-1/4 4-1/2
576T 2-1/2 4-1/2
583 2-3/4 6
No.
Lgth.
In.
384 16
384A 24
384AL 16
No. Description
Lgth.
Ft.
Wt.
Lbs.
855 Light 8 8
856 Light 9 10
1057 Heavy 10 12
1058 Heavy 12 13
3698-9 Curved 9 12
No.
Lgth.
Ft.
Eastern Pattern
2024E 8
2026E 10
2027E 12
Western Pattern
2024 8
2025 9
2027 12
Eastern Pattern
Digging & Pole
Handling Tools
36 1-800-832-2297
Oshkosh Tool Company, Inc.
308003
STRAIGHT SHOVELS
Features heat-treated 10 carbon/boron steel
blade and ash wood handle with footage
marks to indicate depth of hole.
Shovels
Accessories
Unit# 2586001
DIGGING BARS
For use in post hole digging applications.
Sharp end is used to line up long posts once
they are inserted and being tamped into place.
1 hex steel construction.
Unit# 4331001
SHOVELS
Features 14-ga. steel blade with forward-
turned steps and open back, and fiberglass
handle.
Unit# 1632030
SHEAR PINS
For use in torque limiters.
Unit# 1632004
DRIVE-END WRENCHES
Hybrid
For installation of 8000-ft.-lb. large hub, 6000-
ft.-lb. PISA 6 and 7000-ft.-lb. PISA 7 anchors.
Features collar welded around drive end.
Unit# 1632003
KELLY BAR ADAPTERS
Hex
Features bent arm pin and 5-1/2 bolt circle. 8-
1/8 height.
Adapters
Accessories
Unit# 3871012
WIRE DISPENSERS
For use with cable coils. Features pivot swing
arm, bolt and wing nut.
Unit# 5669001
GROUND PROTECTION MATS
Features 1/2 thick recy-
cled polyethylene con-
struction and diamond
plate tread design. With-
stands vehicles weighing
up to 60 tons. Can be
locked together to form a
continuous roadway or
working platform. Black.
No.
Lgth.
Ft.
2033 8
2034 9
2035 10
2036 12
No. Description
1008 10 Shovel handle, Ash
1009 12 Shovel handle, Ash
SRS Shovel rivet set (4 rivets per set)
No.
Lgth.
In.
Wt.
Lbs.
11685-AMES 72 17
No.
Blade
Width In.
Handle
Lgth. In.
0204516 9-1/2 48
No.
Pkg.
Qty.
T3031420 510
No. Desc.
C3031064 Hybrid dive-end wrench
No.
Bar
Dia. In.
630011HD 2-1/2
630012HD 2-5/8
No. Desc.
C3030069HD Standard locking dog
assembly
C3031223 Bent arm pin & coil lock
No.
Dim. In.
Dia. x W
6150 6-1/2 x 30
No.
Dim.
Ft.
AM48 4x8
Fall Protection
1-800-832-2297 37
SELF RESCUE SYSTEMS
High Elevation
Provides all components required to self-res-
cue or rescue a fellow employee. Descender
will automatically stop the user until the user
compresses the handle allowing smooth con-
trolled descent. Also features additional built in
(anti-panic) safety features. Includes retrofit
rappelling straps that can be added to existing
harness for self-rescue.
SELF RESCUE SYSTEMS
Lightweight, compact design manufactured
from aircraft grade aluminum. Features anti
panic release brake to stop the descender if
user releases or compresses the descender
all the way. Includes weather resistant nylon
bag with mesh bottom, and two rappelling
straps.
ELITE RDD BASIC MODELS
Miller SafEscape
Includes hoisting wheel, ladder bracket,
anchor slings, adjustable rope anchor and res-
cue bag.
RESCUE STRAPS
Figure 8
Designed to be girth hitched on a structure to
aid in rescue of an injured victim. The strap is
made from 1 yellow webbing and the Figure 8
is made from aluminum. Ears prevent rope
from slipping down and knotting at the bottom
of the Figure 8.
RESCUE BUCK
Ideal for pole top rescue training, retrieval
training and fall protection testing. You can fill
rescue Buck with recycled tires to the desired
weight. Height: 56.
POLE TOP RESCUE TRAINER
BuckSqueeze
Provides fall protection on distribution poles
and can be adjusted with a flick of the wrist.
Modular design makes it easy to change out
worn or damaged components or straps in the
field. Rated to 310 lbs.
No.
Braided Rope
Dia. In. Length Ft.
101SR-50 1/2 50
101SR-75 1/2 75
No. Length Ft.
301SR-75 75
No. Length Ft.
SEHWLB/75FT 75
No. Length In.
5009E 36
No. Description
694 Rescue Buck
694F1 Buckmix rubber pellets, 55 lb. bag
No. Description
483M Features WebGrab on the inner
strap as well as brown strap
483A-150 Replacement practice straps with
150 webbing with punched holes
Fall Protection
38 1-800-832-2297
POLE TOP RESCUE TRAINER
Conventional
During practice the only part that is cut is the
12 6-ply neoprene piece that can be used 3
times. Simulates how difficult it is to cut the
pole strap in a a real emergency. Other com-
ponents may be reused.
MANHOLE RESCUE SYSTEMS
Non-Entry
Lifeline kit includes one 30 lifeline with
ascender, break away assembly, and rope
bag.
Unit# 3871008
CLIMBER STRAPS
One-piece nylon construction.
Unit# 3871002
BOOM STRAPS
For rescue operations when worker has fallen
to basket floor. Features D-ring for boom
attachment.
Unit# 1306295392
BUCKYARDS
For use with full body harness having steel
ring dorsal attachment. Features locking snap
hook on both ends. Interior material stretches
to reduce arresting force to less than 900 lbs.
nit# 3871001
Unit# 3871009
POSITIONING STRAPS
Neoprene impregnated nylon construction
with slide buckle.
POSITIONING STRAPS
Neoprene
6-Ply neoprene impregnated strap features
abrasion resistance, a contrasting center color
to alert user that replacement is needed, and
stiff material to start and slide on pole easily.
99E Lockers.
POSITIONING STRAPS
Nylon
99E Lockers.
No. 48129Y-7 and 48129Y-8. Woven nylon
positioning strap uses a friction buckle in con-
junction with a carabiner.
No. 498099E. Adjusts easily with a friction
buckle. Ideal for transmission towers, substa-
tions or ladders. Features contracting red
color to alert for wear.
Descent Control, Inc.
SELF-RESCUE SYSTEMS
Sky Genie®
Includes descent device, safety line, (2) oval
snaps for connecting to descent device and
line anchor point, and canvas carrying case.
No. Description
38A Two 12 six-ply neoprene strips
with 4 punched holes
38A-150
150 of six-ply neorprene with
buckle holes spaced every three
inches
No. Description
39SAM13Q-30 Lifeline Kit
No.
Dim. In.
WxL
2439 1x24
No. Desc.
3813D1 Boom strap
No.
Expanding Size
In. Length Ft.
8VV114.5 42 4-1/2
No.
Lgth.
Ft.
346099E 6
No. Description Length Ft.
388099E Tongue buckle 8
347099E Slide buckle 7
No. Description Length Ft.
48129Y-7 Friction buckle
and carabiner 7
48129Y-8 Friction buckle
and carabiner 8
498099E Firction buckle 8
No. Desc.
U4-45 Self-rescue system
Fall Protection
1-800-832-2297 39
POSITIONING STRAPS
Leather
Features a tongue buckle and woven nylon
center as wear indicator. 99E Lockers.
POSITIONING STRAPS
Neoprene SuperStrap
SuperStrap is made from 6 ply neoprene nylon
with red warning core. Features WebGrab for
easy adjustment, with no holes to find or run
out of like conventional straps.
Unit# 3871006
BODY BELTS
Features leather belt strap with nylon center,
5-1/2 foam cushioned pad with rawhide lace
reinforcement, and floating D-rings to allow 4
lateral movement.
No. 2000EM. Includes dee rings.
BODY BELTS
A light weight full float body belt with a 4 Dri-
lex® lined cushion pad designed to wick mois-
ture away from the user. Superior comfort is
provided by extra padding in the back support.
BODY BELTS
Lightweight Dri-lex® lined body belt features
four in-line dee rings for attaching another
strap when crossing an obstacle on the pole. 2
large full float double bar dee (front), 2 small
dee rings (back).
No. 2017M. Man Rated removable gut strap.
BODY BELTS
Bridge pieces and belt straps are crafted of
leather with a nylon center to provide strength
and longer life. Body belt features a 5-1/2
foam cushioned pad reinforced with rawhide
lace, 2 large full float double bar dee rings, 2
small upper dee rings and 9 back pad.
No. 2100M. Waist strap only; no upper gut
strap.
No. 2107M. Removable MAN RATED gut
strap.
BODY BELTS
Lightweight Dri-lex® lined body belt. Features
stacked dee rings, 2 large full float double bar
dee, 2 small upper dee rings and back sup-
port.
No. 2018M. Same as the 2019M but with
removable MAN RATED gut strap. (Must be
used with a Buckingham provided man rated
gut strap.)
BODY BELTS
Rest-A-Back
Features dual back adjustments, extended
back section, shifting D-rings, and double ply
leather upper tongue.
No. Length Ft.
366099E 6
No. Length Ft.
337099E 7
No. Size
2000M-19DBL 19
2000M-23DBL 23
2000M-26DBL 26
2000EM-D23 23
No.
Back Pad
Ht. In. Wt. Lbs.
2012M 56
No.
Back Pad
Ht. In. Wt. Lbs.
2014M 5 6.35
2015M 8 6.35
2017M 6.5
No. Ht. In. Wt. Lbs.
2100M 97.8
2107M 99.2
No. Ht. In. Wt. Lbs.
2019M 9 6.35
2018M 9 6.35
No.
D-Ring
Size
Back Section
Width In.
88B-D24 D24 5
Fall Protection
40 1-800-832-2297
Jelco
POSITIONING WAIST BELTS
2D
Features 5 back pad.
Jelco
POLE CHOKERS
Key component of Jelco Pole Choker Fall Pre-
vention Systems. The 1-3/4 wide yellow nylon
strap squeezes the pole, the rollers teeth dig
in to provide gripping force to prevent falling
down the pole.
Unit# 1303719872
CLIMBER GUARDS
Furnished un-slit to accommodate any length,
regular or adjustable climbers.
U
Unit# 3871010
WRAP PADS
Angled-style Velcro closure pad with metal
insert and 3/4 padding.
Unit# 3871003
SAFETY HARNESSES
H-Style  Economy
Type 13 nylon webbing construction. Features
orange upper and black lower section, rein-
forced web looper dorsal attachment for half-
hitching a shock absorbing lanyard, and step-
in leg straps. Meets ANSI requirements.
Note: Does not feature height or leg strap
adjustment.
Unit# 3871004
SAFETY HARNESSES
H-Style  Basic
Type 13 nylon webbing construction. Features
orange upper and black lower section, Vel-
cro® chest strap, interlocking leg strap buck-
les with leather chafes, web dorsal loop
attachment, and friction buckle for height
adjustment. Meets ANSI requirements.
FR HARNESSES
H-Style  BuckFit
Full body harness features foam padded
shoulder and leg pads, hook and loop chest
strap that meets ANSI requirements, Quick
Connect buckles, and web loop dorsal attach-
ment.
No. 637G8C700K1-L. Features Kevlar® mesh
shell that is designed to breath.
No. 637G8C700V9-L. Drilex® shell designed
to wick moisture away from user.
No. Size
03283 Large
No.
For Use with Fall
Prevention System Size Ft.
03725 Pole Choker 5 5.25
03726 Pole Choker 5 6.2
03734 Pole Choker 6 4.5
03737 Pole Choker 6 6.8
No.
Weight
Lbs.
21187 1/2
No.
Width
In.
3502 4
No. Size
6381700-L Large
Visit our Web Site at
www.uscco.com
for our full line card.
No. Size
6393700-M Medium
No. Desc. Size
637G8C700K1-L Kevlar Large
637G8C700V9-L Drilex® Large
637G8C700K1-L
Fall Protection
1-800-832-2297 41
HIGH END HARNESSES
H-Style
Full body harness features leg straps with
Quick Connect Buckles, hook and loop chest
strap that meets ANSI requirements, web dor-
sal loop attachment, and friction buckles
mounted on vertical shoulder strap for height
adjustment. Designed with minimal amount of
metal above the waist.
FR HARNESSES
H-Style  BuckFit
Full body harness with Kevlar® mesh shell
that is designed to breathe. Features foam
padded shoulder and leg pads, hook and loop
chest strap that meets ANSI requirements,
Quick Connect buckles, and 18 dorsal pigtail
with small dee ring to attach a 4-1/2 shock
absorbing lanyard.
BASIC HARNESSES
H-Style
Full body harness features interlocking chest
and leg strap buckles, web loop dorsal attach-
ment, and friction buckles mounted on vertical
shoulder strap for height adjustment.
BASIC HARNESSES
H-Style
Full body harness features interlocking steel
chest buckle, grommet & tongue buckle leg
straps, steel dee dorsal attachment, and fric-
tion buckles mounted on vertical shoulder
strap for height adjustment.
HARNESSES
H-Style  Buckfit
Full body harness features mesh shell
designed to breathe with FR foam padded
shoulder and leg pads. Quick connect buckles
with leather chafes and spring loaded friction
buckles for height adjustment.
HARNESSES
H-Style  Buckfit
Features Drilex® shell designed to wick mois-
ture away from user and padded Drilex®
shoulder and leg pads for added comfort.
Quick Connect Buckles with leather chafes on
chest and leg straps, and spring loaded friction
buckles for height adjustment.
FR HARNESSES
X-Style  BuckFit
Full body harness with Kevlar® mesh shell
that is designed to breathe. Features foam
padded shoulder and leg pads, patented
Quick Connect Buckles, web dorsal loop, and
reinforced web front loop that can be used for
rescue or with a rope/cable grab.
No. Size
6398C700-L Large
No. Size
637G8C500CK1-L Large
No. Size
6493700R3-L Large
No. Size
6494600-L Large
No. Description Size
68D7G8C600K1 Steel Dorsal Dee
68D7G8C700K1-M Web Dorsal Loop Med
No. Description Size
68D7G8C600V9 Steel Dorsal Dee Large
No. Description
603S8C700K1 X-Style FR Harness
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
Fall Protection
42 1-800-832-2297
BODY BELTS
A lightweight full float body belt with an extra
wide back support. The back pad is 8 of con-
tinuous firm cushion lined with durable
brushed leather. The 1-3/4 waist strap is 6-ply
neoprene impregnated nylon with 9 adjust-
ment holes.
HARNESSES
Universal
Universal sized full body harness features
hook and loop chest strap, shoulder strap
adjustment, interlocking leg buckles, and dor-
sal dee ring.
BODY BELTS
ErgoBelt
Features abdominal stabilizer system, dee
ring distributing pads, equalization strap, lum-
bar pocket and harness attachment buckles.
Designed with removable seat and removable
lumbar pad.
ULTRA HARNESSES
Miller Duraflex Python
Features comfort-touch back D-ring pad, belt
loops, front-D-ring option, side-D-rings, Quick-
Connect chest and leg strap buckles, sub pel-
vic strap, and removable waist belt.
HARNESSES
Miller Arc-Rated
Features Kevlar web loop back pad, 10,000 lb.
tensile strength webbing with permanent fire
retardant (FR) properties, and leather insula-
tors under all metal hardware. Universal (L/
XL). Rated to 400 lbs.
SAFETY HARNESSES
Made of durable nylon webbing that meets
ASTM F887 Arc Flash requirement for use
near energized lines. Designed with pass
through friction buckles.
No.
Back Pad
Ht. In. Wt. Lbs.
1993F-24D 86
No. Description
U6393600A Universal
No. Description
4200 17/35 Model 4200 - ErgoBelt
No. Size
P950QC U
No. Rescue Loops
RKNAR-QC-BDP/UBK No
RKNARRL-QC/UBK Yes
No. Description
683XA Nylon loop for lanyard attachment in
back
683XC
Back attachment with 2 extension
with small D-ring on end. Hook-n-
loop material keeps the extention
out of the way
683XD 3 D-ring for lanyard attachment
Fall Protection
1-800-832-2297 43
POLE LARIAT
Only WPFRD available that allows linemen to
climb a pole in the classic sense. Features red
wear indicator for easy inspection.
Note: 77BCSA should not be used on tool
belts with quick release buckles.
TREE CLIMBER STRAPS
Neoprene nylon construction with protective
buckle shield. Double riveted. Sold in pairs.
TREE CLIMBER ASSEMBLY
2-Piece bottom climber straps are direct
replacement for original lower straps on the tri-
angle ring of Bashlin climbers. Double riveted
and feature a protective buckle shield. Neo-
prene nylon construction.
MAN RATED GUT STRAPS
Can be used with any two dee body belt and is
completely adjustable for users comfort. Belt
features 5000 lb man rated connections,
leather lined strap, and standard tongue
buckle.
POLE CLIMBERS
Steel
Features contoured shank,
straight stirrup, and dowel
and screw replaceable
CCA gaff. Includes stan-
dard length sleeves,
adjusting from 16-1/4 to
18-3/4.
POLE CLIMBERS
Titanium
Features contoured shank, straight stirrup,
and dowel and screw replaceable CCA gaff.
Includes standard length sleeves, adjusting
from 16-1/4 to 18-3/4.
POLE CLIMBERS
Titanium  Offset
Features contoured shank, offset stirrup, and
dowel and screw replaceable CCA gaff.
POLE CLIMBERS
Titanium  Non-Contoured
Features non-contoured shank, offset stirrup,
and dowel and screw replaceable CCA gaff.
No. Description
77BCS D-Loop
77BCSA Uniloop
77BCS-LOOP SET Replacement
D Loop Set
77UL Replacment Uniloop
No. Dim. In.
85N 1-1/16 x 24
No. Dim. In.
87N 1-1/16 x 28
No. Size
6263M Medium
No. Desc.
SB90089A Steel pole
climbers
No. Description
TB92089A Titanium pole climbers
No. Description
TB91089A CCA
TB94059A
TB91059A CCA
No. Description
T94089A
T94059A
Fall Protection
44 1-800-832-2297
POLE CLIMBERS
Titanium  Permanent Gaff
Features contoured shank, offset stirrup, and
permanent gaff with 12° angle.
POLE GAFFS
Replaceable CCA  Pin Style
For use on climbers issued prior to October
2007. Designed to penetrate hard CCA poles
with ease.
POLE GAFFS
Replaceable CCA  Screw Style
Pin style replaceable CCA pole gaff. Use on
climbers issued after October 2007 and prior
to January 2011.
POLE GAFFS
Screw Style  Replaceable
For use with all titanium and steel replaceable
gaff tree climbers. Includes 4 screws. (Climb-
ers issued prior to Jan. 2011).
CLIMBER FOOTPLATES
Attaches easily to any steel or titanium
climber. Two plate construction fastened
together with two screws. Not for use with alu-
minum climbers.
POLE CLIMBERS
Pole climbers includes #2 gaff guard and #5
gaff gauge standard. Unpolished. Standard
15-18.
BD-14. Aluminum alloy climber features con-
tour shank with offset design and replaceable
gaff. 17° angle.
BD- 16B. Steel alloy adjustable climber fea-
tures a replaceable gaff, offset design, roomy
ankle area and triangular strap ring.
No. Description
TB98479 Offset
No. Description
9106 Pin style replaceable CCA pole gaff
No. Description
T9106A Screw style replaceable
CCA pole gaff
No. Size In.
TB9306 2-3/4
No. Description
35033 Climber footplate
No. Description
BD-14-2N Top-Bottom straps attached
BD-14-3N Top-Bottom straps attached,
110 D pads
BD-14-4N Top-Bottom straps attached,
130D pads
BD-14-5N Top-Bottom straps attached,
140DS pads
BD-16B-2N Top-Bottom straps attached
BD-16B-4N Top-Bottom straps attached,
130D pads
BD14 BD16B
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
Fall Protection
1-800-832-2297 45
CLIMBER FOOTPLATES
Features hook and loop wrap pad, increased
surface area to distribute pressure, and mois-
ture wicking Dri-lex lining, and rolled edge to
prevent chafing.
BUCK ARREST
For full body harness with steel ring dorsal
attachment. Features 16 shock pad covered
by water resistant nylon tube, and fixed length
woven nylon with 1706 locking snap hook on
both ends.
No. 6VV116+Z. Meets ANSI Z359.1-2009 for
a 3600 lb. gate.
BUCK ADJUSTER
Fully adjustable positioning lanyard. Features
length adjusting device specially designed
with a 90 degree twist in the eye of the CAM
for use with a line workers body belt. Also
designed with full red core wear indicator, dou-
ble locking rope snap and clear protective tube
for maximum rope life. May be used as pri-
mary work positioning device.
WOOD POLE FALL RESTRAINT
DEVICE
Provides fall protection during ascent and
descent. With use of secondary lanyard, also
protects the user while climbing over obsta-
cles. Designed to grip pole if user starts to fall.
WOOD POLE FALL
RESTRAINT DEVICE
SuperSqueeze
Provides fall protection on distribution poles
and can be adjusted with a flick of the wrist.
Modular design makes it easy to change out
worn or damaged components or straps in the
field. Rated to 310 lbs.
BUCKSKINNER
Ideal for stripping cable in any position and
has the ability to strip outer jackets on over-
head or underground cables up to 2 in diame-
ter. Features finger grips, dual handle design,
and convex edge that cuts the jacket not the
conductor.
SKINNING KNIVES
Cushioned Handle
Features durable blade and cushioned handle.
SKINNING KNIVES
Features durable blade and yellow handle.
No. Description
3202C Climber footplate
No. Length Ft.
6VV116 6
6BB116+Z 6
No. Dia. In. Length Ft.
9-8 1/2 8
No. Description
483D For distribution poles with circumfer-
ence from 16 (5 dia) to 50 (16 dia.)
484T For transmission poles with
circumference up to 90 (28.7 dia.)
Visit our Web Site at
www.uscco.com
for our full line card.
No. Description
488W2Q3 Features WebGrab on the inner
strap as well as brown strap
488W2 Available with Carabiners
488TW2 Available with Carabiners
488R Available with Carabiners
No.
For Cable
Dia. In.
7095 Up to 2
No. Description
70910 Without accessory
ring
70903 Notched blade
No.
Handle
Dia. In.
70863 1-1/4
Fall Protection
46 1-800-832-2297
KNIFE SHEATHS
High quality leather construction built to last.
HOLSTERS
Single Back
High quality leather construction built to last.
HOLSTERS
Double Back
Double back holsters stay rigid after years of
use to ensure easy tool removal from pockets.
Features pockets that are riveted to a thick
layer of leather with another leather layer
sewn over the rivet heads, with plastic stiffener
sandwiched in between.
HOLSTERS
Double Back
Double back holsters
stay rigid after years of
use to ensure easy tool
removal from pockets.
Features pockets that
are riveted to a thick
layer of leather with
another leather layer
sewn over the rivet
heads, with plastic stiff-
ener sandwiched in
between.
HOLSTERS
Double Back
Double back holsters stay rigid after years of
use to ensure easy tool removal from pockets.
Features pockets that are riveted to a thick
layer of leather with another leather layer
sewn over the rivet heads, with plastic stiffener
sandwiched in between.
HOLSTERS
Features 2 plies of rugged harness leather on
back with russett leather pockets. Includes
knife snap and attachment kit.
No. Dim. In.
4089 9-1/2 x 3
No. Description Dim. In.
4226 4 Pockets 11 x 6-1/4
We are continually
adding new products.
Call us with your
inquiries.
No. Description Dim. In.
4089 4 Pockets 11 x 6-1/4
No. Description Dim. In.
42666-BL
5 Pockets and 2-way
knife snap with knife
sheath attached
10-3/4 x 8
No. Description Dim. In.
42266S-BR 5 Pockets with
2-Way knife snap 8 x 9-1/4
No. Description
111HLS Linemens holster
Fall Protection
1-800-832-2297 47
DEPLOYMENTS BAGS
Throw Line
Features (3) outside mesh pockets with (4)
floating dee rings inside.
AERIAL TOOL APRONS
All pockets are sewn through two layers of
vinyl coated nylon plus one layer of heavy
canvas. Two large grommet holes are used to
suspend the apron from the bucket using
Buckingham PVC or polymer hooks.
TOOL APRONS
Heavy Canvas
Mounts onto door panel to hold miscellaneous
small parts. Features (8) pockets measuring
8 wide x 6-3/4 deep. 4 PVC rods maintain
rigidity.
NUT AND BOLT BAGS
#8 Cotton duck bag features reinforced bot-
tom, inside pocket and reinforced top that
stays open. Attaches to belt by 2 straps joined
by snaps and Ds.
UTILITY BAGS
Leather  Miller
Specialty tool bag features multiple compart-
ments and durable, oil-tanned leather con-
struction. Attaches directly to Miller Revolution
harness by snapping on or off.
STAPLE STICKS
Holds 12 staples. Slots are 1/8 W x 3/4 L and
the diameter of the hole to hang the stick is
1/2.
No.
Dim. In.
HxD
4467B1 8x12
No.
Dim. In.
HxWxL
4045 26x4x28
No.
Dim. In.
WxL
4048 17-1/2 x 28
No. Description
25A Nut and Bolt Bag
No. Description
RIA-T11/1 Utility bag
No. Dim. In.
574 7/8 x 3/4 x 14-1/4
Fall Protection
48 1-800-832-2297
GAFF GUARDS
GAFF MAINTENANCE
Pole Gaff Maintenance Kit to safely and prop-
erly shape gaffs. Includes smooth, single cut
file, pole gaff gauge, and finishing hone.
GAFF SHAPING KITS
Includes gaff gauge, 6 mill file with wooden
handle, sharpening stone and instructions.
Note: For use on Bashlin pole gaffs only.
CLIMBER STRAPS
Single Piece
Used to weave through stirrup loop or as top
straps. Sold in pairs. 1 Width.
Unit# 3871005
SHOCK ABSORBING LANYARDS
Buckyard
For use with full body harnesses with web loop
dorsal attachment. Features tubular nylon
exterior with 42 maximum expansion. Inner
material stretches to reduce arresting force to
less than 900 lbs.
Unit# 1306292518
WEB LANYARDS
Features locking snap hook on both ends.
LANYARDS
Miller Manyard®
Specially-woven shock-absorbing inner core
smoothly expands to reduce fall arrest forces.
After fall occurs, warning flag is released. Fea-
tures green webbing, one leg, and locking
snap hooks for harness and anchorage con-
nections.
No. Description
6909A
Snap on gaff guard fits all Bucking-
ham replaceable pole gaffs with a
16° angle (A style).
6909U
Coated wire universal pole gaff
guard that fits all pole climbers:
Buckingham, Bashlin, Klein and
Stringer Brooks.
6909 Only for Buckingham permanent
pole gaff climbers.
No. Description
6025 Gaff Maintenance Kit
6303 Pole gaff gauge only
6909A
No. Description
27-BASHLIN Gaff shaping kit
No.
Size
In. Description
2239 22 Nylon
2639 26 Nylon
2649 26 Nylon, with Buckle Pad
2644 26 Latigo Leather, with Buckle Pad
2839 28 Nylon
No.
Lgth.
Ft.
84V116S1 6
No. Width In. Length Ft.
7VV114 14
No. Length Ft.
216TWLS-Z7/6FTGN 6
Fall Protection
1-800-832-2297 49
LANYARDS
Stretchable  Miller Manyard® II
Contracts 6 ft to 4 ft to reduce tripping, snag-
ging or dragging. Specially-woven shock-
absorbing inner core smoothly expands to
reduce fall arrest forces. Flag released after
fall. Features locking snap hook harness and
locking rebar hook anchorage connection.
LANYARDS
Miller StretchStop® with SofStop®
SofStop shock absorber is designed with
woven inner core that smoothly expands to
reduce fall arrest frorces.When contracted, the
StretchStop minimizes the chances of tripping.
Heavy-duty back-up safety strap is incorpo-
rated for added safety protection. Locking
snap hook connections.
LANYARDS
Miller Arc-Rated
Meets ASTM F887-05 arc-flash standards.
Designed to protect workers form electric arc-
flash and arc-blast exposure. Features arc-
rated Kevlar webbing, lanyard with SofStop
shock absorber, choke-off loop and 1 leg. 6 Ft.
Length.
LANYARDS
Miller Manyard HP
Specially-woven shock-absorbing inner core
smoothly expands to reduce fall arrest forces.
Warning flag alerts fall. Heavy duty tubular
outer jacket serves as back-up lanyard.
Nos. 219TWRS/6FTGN and 233TWLS/
6FTGN. (1) leg.
No. 231TWRS/6FTGN. (2) Legs.
SAFETY STRAPS
Miller NF Series
100% nylon safety strap offers a friction buckle
to adjust length of strap quickly and easily.
Jelco
LANYARDS
Retractable
Auto-twist locking carabiner attached for easy
installation and auto-locking swivel snap on
other end.
Jelco
LANYARDS
Retractable
Designed for positioning. Mounted on swivel
plate with ultra light aluminum snap hook on
the end.Type1/Class C.
LANYARDS
Retractable
Retractable lanyard with 1-3/4 wide mounting
bracket and carabiner.
No. No. Legs Length Ft.
219M/6FTGN 16
No. No. Legs Length Ft.
913SS/6FTGN 16
No.
Anchorage
Conn.
933K/6FTBK Locking snap hook
933KR/6FTBK Locking rebar hook
No. Connections
219TWRS/6FTGN
Harness: Locking snap
hook, Anchorage:
locking rebar hook
231TWRS/6FTGN
Harness: Locking snap
hook, Anchorage: (2)
locking rebar hooks
233TWLS/6FTGN
Harness: Web choke-off
loop, Anchorage:
locking snap hook
No. Width In. Length Ft.
6NFLS/6FTYL 1-3/4 6
No. Description
21211 9 Retractable lanyard
No. Description
21211 7 Retractable lanyard
No. Length Ft.
5008-80F+N 8
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
Fall Protection
50 1-800-832-2297
PERSONAL FALL LIMITERS
Miller TurboLite
Compact, lightweight design attaches directly
to the harness back D-ring for mobility and
versatility. Features engineered webbing for
abrasion resistance, impact-resistant nylon
housing, and built-in swivel. Rated for up to
400 lb. user.
PERSONAL FALL LIMITERS
Titan
Offers 11-ft. of working capacity and requires
less fall clearance than shock-absorbing lan-
yards. Features quick-activating stainless
steel braking mechanism, swivel shackle and
carabiner.
CARABINERS
3600 Lb. Gate Triple Action
Auto lock steel carabiner with 3600 rated gate
keeper.
HARNESS BEAMS
Adjustable to fit over a 9.5 diameter pole.
Features center lifting eye and (8) bolts to
secure pole. Limits arresting force to under
900 lbs. 5,400 lb anchor point. 10 minutes to
install.
NOTES
No. Description
MFL-2-Z7/6FT Steel twist-lock carabiner
and locking rebar hook
No. Wt. Lbs.
TFL-3/11FT 2.9
No.
Breaking
Strength Lbs.
Opening
In.
Length
In.
50051 9,217 .94 4.88
No.
Rotation
Degree
Wt.
Lbs.
Arm
Length In.
5203 360 160 36
Flashlights
1-800-832-2297 51
Unit# 3169001
RECHARGEABLE LANTERNS
LiteBox®
Features 20W halogen spot bulb, safety orange thermoplastic ABS
housing with rubber bumper and cushion grip handle, 6V sealed lead-
acid battery, and red/green charge status LEDs. Includes shoulder
strap, AC/DC chargers and charging rack. 400 Lumens. Measures
11.5 L x 5.1 W x 7 H.
Flashlights
Accessories
Unit# 3169002
RECHARGEABLE LANTERNS
FireBox®
Features 8W halogen spot bulb, dual blue LEDs, thermoplastic ABS
housing with rubber bumper and cushion grip handle, reinforced D-
rings, 6V battery, and toggle switch. Includes shoulder strap and 12V
DC vehicle-mount charging rack.
RECHARGEABLE LANTERNS
E-Spot® FireBox®
Features high-impact ABS thermoplastic housing, rubberized impact
bumper, lens ring, and cushioned-grip handle. Toggle switch for use
with gloves. Includes (3) shockproof C4 LEDs with a 50,000 hour life-
time. 615 Lumens. Orange.
Flashlights
Accessories
RECHARGEABLE LANTERNS
E-Spot® LiteBox®
Constructed with high-impact ABS thermoplastic housing, rubberized
impact bumper, lens ring and cushioned-grip handle. Features (3)
shockproof C4 LEDS with 50,000 hour lifetime and jumper with high/
low setting. 540 Lumens.
No. Color Volts
45109 Yellow 120V (20WS)
45110 Orange 120V (20WS)
45117 Yellow 120V (8WS)
45116 Orange 120V (8WS)
No. Color Volts
45070 Orange Standard system mounting rack
45071 Orange Direct wire 12V DC mounting rack
No. Lumens
Dim. In.
LxWxH
45302 150 11.5 x 5.1 x 7
No. Description
45861 Standard system with AC/DC charge cords, shoulder strap
& mounting rack
45865 Vehicle mount system with DC charge cord
& mounting rack
45882 Without charger
No. Description
22051 DC1 Charge cord
22311 120V AC charge cord
45070 Standard system mounting rack, Orange
45071 Direct wire 12V DC mounting rack, Orange
45937 Sealed lead acid battery
45845 E-Spot upgrade kit
No. Description
45851 Standard system with 120V AC/DC, Orange
Flashlights
52 1-800-832-2297
RECHARGEABLE LANTERNS
HID LiteBox®
Constructed with high-impact ABS thermo-
plastic housing, rubberized impact bumper,
lens ring and cushioned-grip handle. Features
35W high intensity discharge xenon lamp with
2000 hr minimum lifetime. 3350 lumens.
RECHARGEABLE LANTERNS
E-Flood® LiteBox®
Constructed with high-impact ABS thermo-
plastic housing, rubberized impact bumper,
lens ring and cushioned-grip handle. Features
(6) C4 LEDs with 50,000 hour lifetime, (6)
wide pattern parabolic reflectors for smooth
flood pattern, and jumper with high/low setting.
Unit# 3169003
HEADLAMPS
LED  Trident® HP
Features thermoplastic body, 90° tilting head,
polycarbonate lens and white LEDs. Pushbut-
ton control with 3 lighting modes (1 LED, 3
LED and off). Water resistant. Yellow. Face-
cap measures 1.86 Dia. Includes rubber
hardhat strap and (3) AAA batteries.
HEADLAMPS
Enduro®
Features polycarbonate lens, on/off pushbut-
ton with low and high mode, High-Flux LED,
integral hatclip and rubber/elastic combo
headstrap. 50,000 hours rated LED life.
Includes batteries.
Unit# 3169004
RECHARGEABLE FLASHLIGHTS
LED  PolyStinger®
Features nylon polymer body with rubberized
grip, scratch-resistant polycarbonate lens,
deep-dish parabolic reflector, head-mounted
pushbutton switch, 3.6V Ni-Cd battery, and
C4® LED with 50,000-hour life. Yellow.
Includes compact snap-in charger. 185/95/50
Lumens. Measures 1.21 Dia. x 8.07 L.
FLASHLIGHTS
Features polycarbonate lens with scratch
resistant coating, (7) 100,000 hour life LEDs,
and wrist lanyard connection. 155 hour run
time.
Unit# 1728063
FLASHLIGHTS
LED  Recoil  Grip-It
Focuses 100% of light forward to produce col-
limated beam. Features ABS body, polycar-
bonate lens, O-ring seal, wrist lanyard and on/
off switch. 1W LED with 10,000 hour life. Sub-
mersible to 500 feet. Includes (4) AA alkaline
batteries.
No. Description
45601 120V AC/12V DC - Orange
No. Description
45821 Standard system 120V, Yellow
Check our website for
special promotions.
www.uscco.com
No.
Lighting
Modes
Lumens
3/1 LED
61080 1 LED, 3 LEDs and Off 30/11
61052 1 LED, 3 LEDs, 7 LEDs
or Off 50/25/9
No.
Facecap
Dia. In. Color
61400 1.3 Black
No. Description
76163 Steady Charge
76182 Steady Charge Piggy/Back
No. Description Color
68200
4AA LED with white
LEDs without alkaline
batteries
Yellow
No.
OAL
In.
X19 7
Flashlights
1-800-832-2297 53
LED/INCANDESCENT
FLASHLIGHTS
Twin-Task®-3C Combo
Constructed with anodized machined alumi-
num alloy and unbreakable polycarbonate
lens. Corrosion and water resistant. Features
3.6V, 0.9A high pressure Xenon with (6)
100,000 LEDs (white). (3) C size alkaline bat-
teries, not included.
FLASHLIGHTS
Key-Mate® LED
Constructed with machined aircraft-grade alu-
minum with anodized finish, white LEDs, and
polycarbonate lens. Features swivel snap
hook, spring steel pocket clip and neck/wrist
lanyard. 100,000 hour life high intensity LED.
96 Hour run time.
KEY CHAIN LIGHTS
Nano Light® LED
Constructed with machined aircraft-grade alu-
minum with anodized finish and white LEDs.
Features non-rotating snap hook and rotating
on/off head switch. 100,000 hour life LED. 10
Lumens.
FLASHLIGHTS
Survivor® LED
High impact nylon construction. Features O-
ring sealed for weather resistance, spring
loaded clip with built in wring, and polycarbon-
ate lens with anti-scratch coating. C4 LED with
50,000 life hours.
RECHARGEABLE WORKLIGHTS
Knucklehead®
High impact nylon construction. Features O-
ring sealed for weather resistance, circular
rare-earth magnet surrounded by durable
nickel plated steel housing, and polycarbonate
lens with anti-scratch coating. (2) C4 LEDs
with 50,000 life hours.
SPOTLIGHTS
Waypoint® Pistol Grip
Delivers long run times at low illumination lev-
els with strobing and dimming options. Fea-
tures LED with maximum output throughout
battery life, integrated stand for hands-free
scene lighting, battery or 12V DC power cord,
and removable lanyard.
Flashlights
Accessories
No. Lgth. In. Finish
51012 9.02 Titanium
No. Description Finish
72101 White LED Titanium
No. Description Color
73001 Nano Light Black
No. Description Color
90503 120V Orange
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
No. Description Color
90642 Alkaline Model Yellow
90607 Steady Charge with 120V
AC/DC charger holders Black
90627 Steady Charge with 120V
AC/DC charger holders Yellow
90657
Steady Charge with
120V AC/12V DC charger
holders and includes clip
Orange
No. Color
44900 Yellow
44902 Black
No. Description
22051 DC1 Charge cord
22311 120V AC charge cord
44007 Battery
Gloves  Sleeves
54 1-800-832-2297
ASTM Chart
Unit# 1303705408
INSULATING GLOVES
Rubber
Incorporates high dielectric and physical strength. Class 0 through
Class 4. Exceeds ASTM D120.
* Includes half sizes.
Unit# 1303455441
RUBBER GLOVES
Electrical Insulating
Class 00 and Class 0 gloves.
Unit# 1303461825
LINEMANS MITTENS
Keeps user warmer during harsh temperatures and allows for precise
hand movement. Rubber construction. Features bell cuff design. Avail-
able in full sizes 9-11.
Class
Color
Proof Test
Voltage
AC / DC
Max. Use
Voltage
AC / DC
00 Beige 2500 / 10,000 500 / 750
0 Red 5000 / 20,000 1000 / 1500
1 White 10,000 / 40,000 7500 / 11,250
2 Yellow 20,000 / 50,000 17,000 / 25,500
3 Green 30,000 / 60,000 26,500 / 39,750
4 Orange 40,000 / 70,000 36,000 / 54,000
No.
Size
In. Color Style Size*
PSC011Y 11 Yellow Straight cuff 8 to 12
PSC014Y 14 Yellow Straight cuff 8 to 11
PSC214YB 14 Yellow under black Straight cuff 8 to 11
PSC216YB 16 Yellow under black Straight cuff 8 to 11
PSC318YB 18 Yellow under black Straight cuff 9 to 11
PSC214BCYB 14 Yellow under black Bell cuff 8 to 12
PSC216BCYB 16 Yellow under black Bell cuff 8 to 12
PSC418BCYB 18 Yellow under black Bell cuff 9 to 11
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
No.
Length
In. Color Material
E0011BL 11 Blue Type 2 SALCOR®
E0011R 11 Red Type 1 natural rubber
E0011B 11 Black Type 1 natural rubber
E0011BLO 11 Blue/Orange Type 2 SALCOR®
E0014BL 14 Blue Type 2 SALCOR®
E0014R 14 Red Type 1 natural rubber
E0014BLO 14 Blue/Orange Type 2 SALCOR®
E011R 11 Red Type 1 natural rubber
E011Y 11 Yellow Type 1 natural rubber
E011BY 11 Black/Yellow Type 1 natural rubber
E011YB 11 Yellow/Black Type 1 natural rubber
E011B 11 Black Type 1 natural rubber
E011BL 11 Blue Type 2 SALCOR®
E014Y 14 Yellow Type 1 natural rubber
E014R 14 Red Type 1
natural rubber
No. Class Length In. Color
EM214BCYB 2 14 Yellow/Black
EM216BCYB 2 16 Yellow/Black
EM216BCRB 2 16 Red/Black
EM418BCYB 4 18 Yellow/Black
Gloves  Sleeves
1-800-832-2297 55
Unit# 1303460481
LINEMANS GLOVES
High Voltage
Features contrast inner and outer color for easy cut inspection. Class 1
through Class 4. Available in 14, 16 and 18 lengths.
Unit#1303474213
GOATSKIN PROTECTORS
High Voltage
Features free thumb design to reduce hand stress
and fatigue. Pearl-colored goatskin.
1200-5RBC-1F. Mitten style.
Unit#1303473153
LEATHER GLOVES
Insulating
Pearl-colored goatskin grain leather construction with
adjustable pull strap. Low-voltage Class O. Available
in sizes 7-12, including half sizes.
Unit# 1303471250
LEATHER PROTECTORS
Provides protection for rubber insulating glove. Avail-
able in dual sizes 8/8.5 through 11/11.5 and size 12.
Note: To specify goatskin, use ILPG.
Unit# 1303468476
DIPPED SLEEVES
Available in R, L or XL sizes.
No. Class
Lgth.
In. Color Style Sizes
E116YB 1 16 Yellow/Black Straight 9 to12
E214YB 2 14 Yellow/Black Straight 8 to12
E214BCYB 2 14 Yellow/Black Bell 8 to 12
E214BCRB 2 14 Red/Black Bell 8 to 12
E216YB 2 16 Yellow/Black Straight 8 to 12
E216RB 2 16 Red/Black Straight 8 to 12
E216BCYB 2 16 Yellow/Black Bell 8 to 12
E216BCRB 2 16 Red/Black Bell 8 to 12
E218YB 2 18 Yellow/Black Straight 8 to 12
E218CRB 2 18 Red/Black Contour 8 to 12
E318RB 3 18 Red/Black Straight 8 to 12
E318YB 3 18 Yellow/Black Straight
contour 9to12
E318CRB 3 18 Red/Black Straight 8 to 12
E418BCYB 4 18 Yellow/Black Bell 9 to 12
E418YB 4 18 Yellow/Black Straight 9 to 12
No.
Overall
Lgth. In.
1200-3RBC 12
1200-5RBC 14
1200-6RBC 15
1200-5RBC-1F 14
No.
Overall
Lgth. In.
999S 10
913S 13
No.
Overall
Lgth. In.
Weight
Lbs. Protector
ILPG10A 10 0.7 Low volt
ILPG5S 14 1.2 High volt
Voltage Class Color Style & Size
D0 Yellow (Y) Straight (ST)
D2 Black (B)/Yellow Black (YB) Straight (ST)
D2
Yellow (Y),Black (B),Red/
Yellow (RY), Yellow/Black
(YB)
Extra-curved cuff (EC)
D3 Red (R),Yellow/Black (YB) Extra-curved cuff (EC)
Gloves  Sleeves
56 1-800-832-2297
Unit# 1303468476
DIPPED SLEEVES
Available in R, L or XL sizes.
Unit# 1303467219
MOLDED SLEEVES
Provides electrical protection with added benefit of being resistant to
ozone and ultraviolet radiation. Features curved arm style. Available in
R, L and XL sizes. Voltage class 2.
Unit# 1303469794
SLEEVE STORAGE
& ACCESSORIES
Stores rubber sleeves in the right size bag and never forces more than
one pair into each bag. Features heavy-duty canvas duck, double
stitched and riveted at stress points. Includes D ring for hanging in
trucks or on work belts, and tapered gussets with wide opening tops.
Four buttons, two straps, and one harness required per pair of sleeves
for proper wear.
No. S1. 15 length.
Accessories
Unit# 3881001
HAND CLEANERS
Rub-Out
Removes grease, oil, ink, tar, creosote
and paint from hands. Non-petroleum
based formula contains skin conditioners.
Will not harm rubber or Salcor®. Fresh
citrus scent.
Unit# 1303711069
DETERGENTS
Super SALCO®
Removes oils, grease and dirt from natural rubber
and rubber equipment. Used for washing rubber
gloves, sleeves and other equipment by hand or
in commercial washing machines. Gallon jug.
Unit# 1303443347
SILICON SPRAYS
Salcon®
Reduces surface creepage on rubber gloves and
sleeves. Forms oxygen barrier that helps reduce corona
cutting and weather checking on rubber equipment. For
use on spark plugs and battery terminals in damp
weather to assist in starting.
Unit# 1303472607
GLOVE DUST
Ten-Four®
Prevents gloves from getting sticky; absorbs moisture
and perspiration during rubber glove wear. Includes 12
5-oz. squeeze bottles.
Voltage Class Color Style & Size
PSC2RRYEC Red Under Yellow (RY Extra-curved cuff (EC)
PSC2LRYEC Red Under Yellow (RY Extra-curved cuff (EC)
PSC2XLRYEC Red Under Yellow (RY Extra-curved cuff (EC)
PSC2RYBEC Yellow and Black (YB) Extra-curved cuff (EC)
PSC2LYBEC Yellow and Black (YB) Extra-curved cuff (EC)
PSC2XLYBEC Yellow and Black (YB) Extra-curved cuff (EC)
No. Color
2- R, L, or XL - B Black
No. Desc. Weight Lbs.
S1 Straps 0.1
No. Desc. Weight Lbs.
H1 Harness 1
B22 Buttons 0.8
No.
Size
Oz.
Pkg.
Qty.
1451 16 12
No.
Weight
Lbs. Pack Quantity
S4 54 4
No.
Weight
Oz.
S99 16
No.
Weight
Lbs.
10-4 5oz 5-1/2
Gloves  Sleeves
1-800-832-2297 57
Unit# 1303465070
Unit# 1303458878
SLEEVE BAGS
Combination
Heavy canvas construction. Features one flap over top of both pockets
secured with snap fasteners. Quick release snap on back for belt
attachment supported by leather on inside/outside of bag. Includes
grommeted bottom drainage holes and Power Line Supply logo.
No. 2449-REED. Also features web hang loop on inside with outer
glove pouch.
Unit# 1303455464
GLOVE BAGS
Features top flap with snap fasteners. Rivets capped to prevent
scratching of rubber gloves. Includes nickel plated quick release snap
for attachment to belt. Leather reinforced inside and outside and
includes bottom drainage grommets and Power Line Supply logo. Mea-
sures 12" x 8" x 2".
Unit# 4297020
GLOVE BAGS
Canvas construction. Includes snap hook and Power
Line Supply logo.
SLEEVE BAGS
Heavy canvas construction. Features capped rivets to
prevent scratching of rubber sleeves and flap over
opening secured with snap fasteners. Includes quick
release snap for belt attachment sewn to bag then riv-
eted with leather pieces on inside/outside of bag.
Unit# 3881041
GLOVE BAGS
Features heavy-duty canvas duck construction with double stitching at
stress points. Includes snap hook for belt hanging.
No.
Width
In.
Lgth.
In.
Ht.
In.
2300-REED 2 8-1/2 28-1/2
2449-REED 4 12 29-1/2
No. Desc.
2210-REED Without pockets
2210-REED-P With (2) pockets
2449-REED
2300-REED
2210-REED 2210-REED-P
No.
Dim.
In.
2233-REED 18 x 9
No.
Weight
Lbs.
Width
In.
Lgth.
In.
Ht.
In.
2426-REED 16818
No.
Length
In.
Dim.
In.
Weight
Lbs.
GB112 11 9x14 1
GB118 18 9 x 20 1-1/2
Grounding
1-800-832-2297 59
Unit# 4329015
GROUNDING CLAMPS
Duckbill
Aluminum construction with Acme-threaded
bronze eye screw and stainless steel cable
clamp for stress relief. Features smooth jaws.
Main line range .162 min./1.16 max. 4/0 max.
ground cable size. Fault circuit: 43KA @ 15
cycles; 30KA @ 30 cycles.
Unit# 4329013
GROUNDING CLAMPS
C-Head
Features 5/8-11 NC threaded terminals and
bronze alloy Acme threaded eye stems. Maxi-
mum 4/0 str. jumper cable w/ ferrule. 275 in-lb.
minimum installation torque. Max. fault current
rating: 43KA @ 15 cycles; 30KA @ 30 cycles.
Nos. 21070 & 21307. Features fixed serra-
tions cast into main body.
Unit# 4329021
GROUNDING CLAMPS
Tower & Flat Face
Bronze alloy
construction.
Features 5/8-
11 NC
threaded ter-
minals and
single ground
clamp. 1-1/2
jaw capacity.
Max. 4/0 str.
jumper cable.
Max. fault cur-
rent rating:
43KA @ 15
cycles; 30KA
@ 30 cycles.
Unit# 4329018
GROUNDING CLAMPS
Substation
Enables portable grounds to be used on large
bus. Features bronze Acme threaded eye
screw. Rated 54KA @ 15 cycles; 39KA @ 30
cycles.
No. 21056. Features cast bronze alloy body
and 13/16 OD stud.
No. 21057. Features aluminum body and 5/8
dia. solid copper alloy hanger stud.
Unit# 1632017
GROUNDING CLAMPS
Ball & Socket  Chance®
For use in industrial metalclad gear, substa-
tions and distribution applications where
space is limited. Bronze alloy construction with
tin-plated ball studs and silicone bronze lock-
washer and nut. Tapped for 5/8-11 UNC
threaded ferrule. Fault current ratings: 43KA
@ 15 cycles; 30KA at 30 cycles. Meets ASTM
Type I, Class A, Grade 5 specifications.
Unit# 1632018
GROUNDING CLAMPS
Tower & Flat-Face  Chance®
Features bronze body, serrated jaws, and
bronze eyescrew with Acme threads. Drilled
for 5/8-11 UNC threaded ferrule. Fault current
ratings: 43KA @ 15 cycles; 30KA at 30 cycles.
* With threaded stud
No.
Fault
Circuit
10476 43KA @ 15 cycles;
30KA @ 30 cycles
Main Line Dia.
No. Desc. Min. Max.
21070 Bronze alloy .16 2.88
21307 Bronze alloy .16 1.25
10375 Aluminum alloy .18 2
10375
No. Desc.
21571 w/ Eye screw
21608 w/ T-handle
Bus OD In.
No. Min. Max.
21056 1.25 5
21057 .398 6.625
21571 21608
21057
21056
No. Desc.
C6002101 Ball & socket grounding clamp
Main Line Range
In.
Jumper
Range*
No. Max. Min. Max. Min.
C6002232 1-1/2 Angles
and Flat 1/8 4/0 #2
Grounding
60 1-800-832-2297
Unit# 1632032
GROUNDING CLAMPS
C-Type  Chance®
Features aluminum body, serrated jaws, and
bronze eyescrew with Acme threads. Tapped
for 5/8-11 UNC threaded ferrule. Fault current
ratings: 43KA @ 15 cycles; 30KA at 30 cycles.
* With threaded stud.
Unit# 4305001
GROUNDING C-CLAMPS
For use on electrical facilities, apparatus,
tubes, conductors, trucks, pulling equipment
and jumper cables. Features insulated con-
ductor, round bus bar, 25mm grounding ball
stud, lubrication chamber, installation eye for
use with shotgun stick, and double internal
threads. Thermal shock indicator changes
color when clamp reaches 200°F. Receives 5/
8-11 UNC threaded stud ferrule. Aluminum
clamp and keeper. Capacity: 35kA @ 15
cycles; 39kA @ 30 cycles. 1-3/8 jaw capacity.
400A continuous current rating.
Unit# 3881007
GROUNDING C-CLAMPS
Main Line
For use on .83 to .12 dia. main lines. Bronze
construction. Features V-thread, eye, strain
relief sleeve, and curved, serrated lower jaw.
Unit# 3881009
GROUNDING C-CLAMPS
Substation Bus
For use on 3.5 to .16 dia. main lines. Alumi-
num construction. Features eye, strain relief
sleeve, long eye screw with Acme threads,
smooth top jaw and flat lower jaw.
Unit# 4329017
GROUNDING CABLE FERRULES
Compression
For use with 5/8-11 NC threaded
tin plated copper terminals.
Unit# 4329039
GROUNDING CLUSTER BARS
Provides protection for personnel in single
point grounding applications. Features adjust-
able chain tightener with 36 of chain. Alumi-
num alloy construction. Accepts C- and
duckbill grounding clamps. Tested for 43KA @
15 cycles.
Unit# 4329037
GROUNDING CABLE SETS
Three Phase
For use in under-
ground applica-
tions. Includes 6-
ft. 1/0 copper
grounding cables,
terminal block,
and flat jaw
grounding clamp.
Rated 10KA @ 10
cycles.
Main Line
Range In.
Jumper
Range*
No. Max. Min. Max. Min.
T6002708 1.25 0.128 4/0 #2
No.
Jumper Cable
AWG
Main Conductor
Size
01M037 2 to 4/0 #8 to 795
No.
Continuous
Current Amps
4260 400
No.
Continuous
Current Amps
4341 400
No.
Size
AWG
12998 #2
12999 1/0
13000 2/0
13001 4/0
No. Desc.
6767 Grounding cluster bar
No. Desc.
6717 Grounding cable set
Grounding
1-800-832-2297 61
Unit# 4329038
CABLE SPLICES
4-Way
For connecting ground cables together. Alumi-
num alloy construction. Features (4) terminal
positions tapped for use with 5/8-11 NC
threaded grounding ferrules, and stress relief
grounding cable pads. Tested for 43KA @ 15
cycles.
Unit# 4329028
GROUNDING RODS
Screw
Features 5/8 dia. copper-
weld rod and 12 bronze
handle.
Unit# 4329034
GROUNDING MATS
Anti-Skid  Portable
For use in underground padmount, transmis-
sion and distribution pole mount, and substa-
tion grounding grid applications. Hypalon
marine fabric construction with high ampacity
tinned-copper braid sewn into grid pattern.
Copper braid connect to 6 termination stud on
corner of mat. Weather resistant. Black.
Unit# 4329025
JUMPER HOLDER/EXTENDERS
Extends length of existing mechanical jump-
ers. Supports (2) jumpers while isolating con-
nection from other potentials. Can also be
used as parking stand or ground jumper
holder. Features non-conductive fiberglass
shaft and solid copper contact bar.
Unit# 4329041
JUMPERS
Medium Range
Features clear polycarbonate head. #2 size
with 15KV insulation. Conductor range: 6 Sol.
to 556.4 MCM.
Unit #4301001
GROUND ROD DRIVERS
Unit# 1632001
GROUNDING ELBOWS
Chance®
For use in underground distribution grounding
applications.
Unit# 1632015
GROUNDING ELBOW SETS
Includes orange jacketed elbow, 6-ft. of 1/0
copper grounding cable with yellow jacket,
and bronze ground clamp.
Unit# 1632016
CONVERSION TERMINALS
Eyebolt Style
Converts pressure-type grounding clamps to
accept 5/8-11 UNC threaded ferrules.
Includes shakeproof washer and nut.
No. Desc.
6724-1 4-Way cable splice
No.
OAL
In.
4370 72
No. Dim. In.
6610-NS 58 x 58
No.
Contact Bar
Dim. In.
Dia. x L
3484 .625 x 9
No.
Lgth.
Ft.
6884 8
6885 10
No.
Size
In.
312056 5/8
312057 3/4
No. Desc. kV
235GEHSG Large interface 35
No. kV
C6000729 15
No.
Clamp
Applications
C6001584 C-type, snap-on & flat-face
Grounding
62 1-800-832-2297
Unit# 1632020
STUD CONNECTORS
For connecting copper cable or tube to equipment stud. Bronze alloy
construction. 1-1/2-12 stud thread.
Unit# 1632033
SUBSTATION TEES
For connecting copper tubing to cable tap. Bronze alloy construction.
Features clamping bolts with hex stops and reversible cable caps.
Unit# 4311002
HOLD-DOWN BLOCKS
For use in heavy hold-down situations where hold-down line is con-
nected to shackle at bottom of frame. Can be used as a haul down for
making sleeves.
Note: Available with ductile iron or steel frame and with (2) 7 or 14
sheaves lined with urethane. Specify when ordering.
Unit# 2573004
HEAT SHRINK TUBING
Thin Wall
Single-wall flexible polyolefin construction. Non-corrosive. Dielectric
strength 900V. Clear. 50-ft. roll.
Unit# 4330001
GROUND ROD CAPS
For driving ground rods. Reduces hammer
deflection, protects rod against distortion and
finish damage. Steel construction with plated
finish.
Cable Tubing
No. Type Dia. In. IPS
DS1410012 #2 Sol. 1000 MCM .258 to 1.152 3/8 to 3/4
Cable Tubing
No. Type Dia. In. IPS
TTC8040253 #4 Sol. 250 MCM .204 to .575 1/2
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
No.
Max. Working
Load Lbs.
HD-72-D1-U 4000
No.
Dia.
In.
FP-301-1-CLEAR 1
FP-301-3/4-CLEAR 3/4
No.
Top
Dia. In.
H207 2
Hand Tools
1-800-832-2297 63
Unit# 4286001
PRUNING SAW SCABBARDS
Belted rubber construction with cleanout hole
at bottom. Saddle mount ring attaches to
accessory snap on climbing saddle.
Unit# 4286002
PRUNING SAWS
Curved
Features laminated hardwood handle and
replaceable blade with tri-cut tooth pattern.
Unit# 4286003
PRUNING SAWS
Curved  Utility
For clean branch removal. Features laminated
hardwood handle and heavy-gauge polished
steel blade.
Unit# 4329046
PRUNING SAWS
For use with universal saw handles. Features
Teflon coated, curved blade.
Unit# 1728052
HACKSAWS
Dual-Purpose
Features Golden Tri-Cut blade with (3) tooth
sizes, pivot lock for blade tension adjustment,
set screw for storage of extra blades, alumi-
num finger grip handle, and thumb guard for
two-handed sawing. Blade converts to 45° for
flush cut applications.
Unit# 4328001
ENGINE DRILLS
Features 25.4cc engine, electronic ignition, throt-
tle lockout, spark-arresting muffler, ergonomic
front handle, and 1/2 keyless chuck. Reversible.
17:1 to 1 gear reduction ratio. 10.7 lbs.
Drill
Accessories
Unit# 4319001
CHAINSAWS
Lightweight design. Features adjustable auto-
matic bar and chain oiler; IntelliCarb com-
pensating carburetor with preheat shutter;
decompression valve; side-access chain ten-
sioner, and toolless fuel and oil caps with
retainers. 460cc fuel capacity. 290cc chain oil
capacity. Compatible with 40 to 50cm guide
bars.
CHAIN SAWS
Professional
Features Pro-Fire electronic ignition, dia-
phragm carburetor with purge pump, forward/
reverse, and keyless chuck.
Unit# 3239001
CHAINSAWS
SmartStart® and fuel pump ensure easy
starts. X-Torq® engine provides reduced fuel
consumption and lower exhaust emission lev-
els. Features centrifugal air cleaning system,
quick-release air filter, low-vibration design
and inertia activated chain brake.
No.
For Saw
Lgth. In.
112-25 20 to 25
No.
Lgth.
In. PPI
HS1311 13 7
No.
Lgth.
In. PPI
HS137-24 24 5
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
No.
Lgth.
In.
A11000 16
No.
Blade
Lgth. In.
OAL
In.
701-S 12 16
No. RPM
Torque
Ft.-Lbs.
EDR-260 0to450 12
No. Description
89757005560 Engine drill chuck key
99944900321 Engine drill keyed chuck
No.
Engine
Cu. In. HP
MS-260 PRO 3.06 3.2
No. Size In.
MS-261 PRO 18
MS-261 PRO 16 16
No. HP Max. RPM
445 2.8 9600
Hand Tools
64 1-800-832-2297
CHAIN SAWS
Husqvarna
Mid-range chain-saw designed for all purpose
use but designed for applications where
increased power is needed. Rips through
wood quickly to save time. Features smooth
operation while cutting with very little vibration.
CHAIN SAW CHAIN
Oregon
Lightweight, fast-cutting chainsaw saw chain
with kickback reducing bumper drivelinks.
Features Oregon Vibe-Ban vibration reducing
cutters and tie straps for operator comfort and
safety, plus LubriLink tie straps for improved
lubrication.
CHAIN SAW BARS
Rollomatic E Laminated
All around bar suitable for occasional, mid-
range or professional users. High grade steel
construction. Features 3-part spot welded lam-
inated guide bar with star-shaped sprocket.
CHAIN SAW CHAIN LOOP
Oregon
Fast cutting chain designed for small and
medium sized professional Stihl chainsaws.
Round chisel cutters make quick work of both
softwoods and hardwoods.
CHAIN SAW CHAIN
Oilomatic Rapid Micro Chain
Features special cutter shape that reduces
cutting friction to a minimum, ensuring fast cut-
ting speed with good efficiency in any type of
wood. Lower vibration levels reduce operator
fatigue.
PROTECTIVE CHAPS
Chain Saw
Rugged, apron style chaps with deep cargo
pocket on front. Features Engtex® cut-retar-
dant material. Waist size fits from 30 to 42.
PROTECTIVE CHAPS
Pro Forest
600 Denier outer shell in orange with extra 4
coverage to the left of each leg. Adjustable
length with top snaps on waist. Machine wash-
able.
PRO FOREST HELMET
With Visor & Earmuffs
Helmet features visor, hearing protectors, sun
peak and neck guard. Polyethylene construc-
tion resists UV light and chemicals. Earmuffs
can be adjusted vertically and sideways and
nylon mesh visor can be raised or lowered.
Unit# 1260008
UTILITY KNIVES
Folding  Wiss®
Steel construction. Features quick-
change blade, blade lock, inter-
changeable thumb release for left or
right hand use, soft grip handle and
belt clip.
No. HP
460 RANCHER 3.7
No.
File
Size In. Gauge Pitch
21BPX-78E 3/16 .058 .325
No. Lgth. In.
3003 008 6817 18
No.
Size
In. Gauge Pitch
22LPX-67E 16 .063 .325
22LPX-74E 18 .063 .325
22LPX-81E 20 .063 .325
No.
Size
In. Gauge Pitch
26RM367 16 .063 .325
26RMC374 18 .063 .325
No.
Layers of
Engtex®
Lgth.
In.
0000 886 3202 636
0000 886 3203 640
No.
Layers of
Kevmalimot
Yellow Line
Lgth.
In.
5313095-66 6 36-38
No. Color
5777646-01 Orange
No.
Lgth.
In.
WKFQ4R 6
Hand Tools
1-800-832-2297 65
Unit# 3871014
SKINNING KNIVES
Linemans
Unit# 1728014
SKINNING KNIVES
Linemans
Heavy-duty serrated blade for sawing. Notch
on blade for scraping or removing wire insula-
tion. Textured red handle with finger grooves.
* Without ring.
Unit# 1728029
SKINNING KNIVES
Insulated  Linemans
For use in line work and cable scoring applica-
tions. Features tempered steel blade and dual
insulated handle with comfort grip and finger
guard. 1000V rating. Orange.
SKINNING KNIVES
Cushion Grip
Designed for lifting the front edge of cable
semi-con layer after it has been scored. Stain-
less steel blade with leather sheath.
LOCKBACK KNIVES
Lightweight
AUS8 stainless steel blade provides superior
edge holding. Features impact-resistant nylon
resin handle with rubber insert and thumb
stud.
LOCKBACK KNIVES
Sheepfoot Blade
AUS8 stainless steel blade provides superior
edge holding. Features impact-resistant nylon
resin handle with rubber insert and thumb
stud.
No. 44006. Anodized-aluminum handle for
corrosion resistance.
JAB SAWS
Cuts drywall, wallboard, plywood, and plastic.
Designed with triple ground teeth, hardened
carbon steel blade, beveled blade for scoring
and plunge cuts, and cushion grip with thumb
groove.
CABLE-SPLICERS KNIFE
Special-purpose short blade with comfortable,
full-sized heavy-duty handle. Hang hole for
easy storage.
Handle Lgth.
No. Dia. In. Desc. In.
With Accessory Ring
7089 1-1/8 Red 9-5/8
7090 Ergonomic 9-7/8
Without Accessory Ring
70861 1-1/4 Yellow 9
No.
Blade
Lgth. In.
OAL
In.*
1570-3 38
7089
7090
No.
Blade
Lgth. In.
OAL
In.
1570-3LR 2-1/4 7-3/4
No. Description
SC-11 Semi-Con edge wedge with
finger grip
No.
Blade
Length In.
Length
Closed In.
44002 2-3/8 3-1/2
44002 2-3/4 4-1/8
No.
Blade
Length In.
Length
Closed In.
44005 2-5/8 4-1/8
44006 2-5/8 3-1/2
No.
Blade
Length In.
OAL
In.
725 1/2 7/16
No.
Blade
Length In.
Length
Closed In.
44200 1-3/4 6-1/4
Hand Tools
66 1-800-832-2297
POCKET KNIVES
Compact and lightweight knife features stain-
less steel drop point blade and handle. Rose-
wood handle inserts on both sides.
POCKET KNIVES
No. 44037. Curved ebony wood handle with
big brass bolster. Stainless steel blade for long
life. Includes leather snap case with belt loop.
No. 44038. Standard pattern, multi-blade
knife. Nickel-silver bolster and staged plastic
handle with brass lining.
SHARPENING STEEL
Multi-Purpose
Leather-sheath handle folds out of the way for
use as a knife sharpener, and provides conve-
nient way to hold tool when used as a chisel
for hacking prying or cutting sheet metal.
Includes lanyard.
KNIFE & SCISSOR SHARPENER
High-grade, tungsten carbide inserts sharpen
both sides of blade at the same time. For use
on electricians scissors, pocket knives, utility
knives, razor blade knives and serrated
knives.
Unit# 1260003
MEASURING TAPES
Fiberglass  Lufkin®
Features fiberglass tape encapsulated in flexi-
ble plastic with non-conductive black and red
markings on yellow background. Blaze orange
ABS case.
Unit# 1728057
TAPE MEASURES
Fiberglass  Open Reel
Woven fiberglass construction with polyvinyl
chloride coating for resistance to moisture, oil
and chemicals. Features black numbers and
1/8 graduations, red foot markings, and per-
manently attached end hook. Orange reel with
handle for rewinding.
Unit# 1728006
TAPE MEASURES
Power-Return  Tape Stop
Features self-lock blade with oversized num-
bers, and 1/8 and 1/4 architectural scale on
back.
TAPE MEASURES
ProSeriesHi-Viz Lufkin®
Yellow clad fiberglass blade and Hi-Viz®
orange case makes this tape easy to find on
the jobsite. Features folding end hook for true-
zero measurements and feet/inches gradu-
ated to 8ths.
No.
Blade
Length In.
Length
Closed In.
44033 23
No. Desc.
Blade
Length In.
Length
Closed In.
44037 Single blade 3-3/8 4-7/8
44038 2-Blade 2, 1-1/4 2-7/8
No.
Size
In.
44150 5 x 7/8 x 1/4
No.
Size In.
LxWxD
48036 4 x 2-1/4 x 3/4
No.
Width
In.
Lgth.
Ft.
706L 1/2 100
No.
Tape
Width In.
Tape
Lgth. Ft.
946-150 1/2 150
No.
Blade
Width. In.
Blade
Lgth. Ft.
915-25 125
No.
Blade Size
LxW
FE300 300 x 1/2
Hand Tools
1-800-832-2297 67
TAPE MEASURES
Power-Return
Features double-sided steel rule with bold
black numbers and 16 and 19 red stud mark-
ings, and blue case with non-slip rubber grip.
Unit# 1728056
FOLDING RULES
Fiberglass
Nylon-reinforced fiberglass construction with
stainless steel spring hinges. Measurements
marked on both edges in black with red stud
center marking at 16 increments. Engraved
graduations on both sides. Yellow.
FOLDING RULES
Wood
Black markings on yellow, with red stud center
markings every 16 inches. Measurements are
marked on both sides and both edges, gradu-
ated to 1/16. Engraved graduations on both
sides. Riveted lock joints for long wear.
Unit# 1385003
PLUMB BOBS
Features brass body with hardened steel tip
and lacquered finish. Attaches to any string or
line.
nit# 1385001
BOX LEVELS
Magnetic
Features heavy-duty aluminum frame with
milled edges, oversized hand holes, solid
acrylic vials, and rubberized endcaps.
Unit# 1385002
TORPEDO LEVELS
Magnetic
Features aluminum frame with acrylic vials
(plumb, level and 45°) and magnetic edge.
Unit# 1728028
TORPEDO LEVELS
Magnetic
Features plumb, level and 45° mitre vials and
strip magnet. Aluminum construction.
TORPEDO LEVELS
Rare Earth Magnet
Strong, extruded aluminum frame features
built-in hang hole, top-read level window, V-
grooved edge for pipe and conduit work, and
highly visible plumb, level and 45° vials.
Unit# 1260007
LOCKING PLIERS
Curved Jaw  Crescent®
Features angled tooth design for improved
grip, compound action and long nose with wire
cutter. Nickel plated finish provides corrosion
resistance.
No.
Blade
Width In.
Blade
Lgth. Ft.
908-30 130
No. Reading
Lgth.
Ft.
910-6 Inside 6
911-6 Ouside 6
No. Reading
Lgth.
Ft.
900-6 Inside 6
901-6 Outside 6
No.
Wt.
Oz.
1116-908-BR 8
No.
Lgth.
In.
0268555 24
0268556 48
0268557 72
No.
Lgth.
In.
1116-581-9 9
No.
OAL
In.
930-9 9
No.
Length
In.
931-9RE 9
No.
Jaw Cap.
In.
Lgth.
In.
C10CV 1-7/8 10
Hand Tools
68 1-800-832-2297
Unit# 2936003
SIDE-CUTTING PLIERS
High Leverage
For cutting hardened wire, ACSR,
bolts, screws and nails. Chrome
vanadium steel construction with
induction-hardened blades. Fea-
tures diamond-serrated jaws, wide
grip design, handle ridge and slip-
proof ergonomic molded grips.
Note: Not insulated.
SIDE-CUTTING PLIERS
High Leverage  New England Nose
Features knurled jaws, plastic-dipped handles
and crimping die behind hinge for superior
leverage crimping non-insulated connectors,
lugs and terminals. 1-19/32 Jaw Length. 9-3/
8 OAL
2000 Series. Cuts ACSR, screws, nails and
most hardened wire.
No. D201-9NE. Not high leverage.
DIAGONAL-CUTTING PLIERS
High Leverage  Angled Head
Features short jaws and beveled cutting
edges for close cutting of wire. Plastic dipped
red handle.
D238-8. Semi-flush cuts Cherry Burrel rivets.
For use on non-ferrous wire only.
2000 Series. Cuts ACSR, screws, nails, and
most hardened wire.
CABLE CUTTERS
High Leverage
Cuts up to 4/0 aluminum AWG (no ACSR), 2/
0 AWG soft copper and 100-pair 24 AWG
communications cable.One-hand shearing
action.
CRIMPING/CUTTING TOOL
Designed to crimp insulated and non-insulated
10 to 22 AWG solderless terminals and con-
nectors.
FLUSH CUTTERS
Lightweight
Shears wire up to 18 AWG producing flat,
flush cut. Features cushioned grips and steel
return spring for increased comfort during
repetitive cutting. Red...
Unit# 2936025
LONG NOSE PLIERS
Side-Cutting
For cutting hardened wire, ACSR, bolts,
screws and nails. Chrome vanadium steel
construction. Features diamond-serrated jaws,
hardened cutting edges, wide grip design,
flared handles and molded grips.
Note: Not insulated.
No. Lgth. In.
015109MCP 9
0151-09D 9-3/8
No.
Jaw
Lgth. In.
OAL
In.
Connector Crimping
D2000-9NECR 1-19/32 9-3/8
D213-9NE-CR 1-19/32 9-3/8
Linemans Bolt Thread Holding
D2000-9NETH 1-19/32 9-3/8
D213-9NETH 1-19/32 9-3/8
Side-Cutting
D213-8NE 1-7/16 8-11/16
D213-9NE 1-19/32 9-3/8
D201-9NE 1-19/32 9-3/8
Journeyman Heavy Duty Side-Cutting
J2000-9NE 1-19/32 9-1/2
Heavy Duty Side-Cutting
HD2000-9NE 1-19/32 9-1/2
No.
Cutting
Knives
Jaw
Lgth. In.
OAL
In.
D238-8 Semi-flush 13/16 8-1/16
D248-9ST Standard 13/16 9-3/16
Journeyman
J2000-48 Standard 13/16 8-1/8
No. Color
OAL
In.
J63050 Red/Black 9-9/16
No. Color
OAL
In.
J1005 Red/Black 9-3/4
No.
Cutting
Knives
OAL
In.
D275-5 Flush 5
No.
Lgth.
In.
035106M 6
We are continually
adding new products.
Call us with your
inquiries.
Hand Tools
1-800-832-2297 69
Unit# 1728007
LONG NOSE PLIERS
Side-Cutting
Features knurled jaws, induction hardened
cutting surfaces, slim head for use in confined
spaces and curved plastic coated handles.
Yellow.
No. D203-8N. Heavy-Duty.
No. D304-6. Duck bill, rounded nose.
No. D305-6. Duck bill, flat nose.
No. D307-51/2C. Slim.
Unit# 1728025
PUMP PLIERS
Tongue & Groove
Unit# 2936027
PUMP PLIERS
Features riveted joint, right-angle teeth, wide
grip design, and slip-proof ergonomic molded
grips.
Note: Not insulated.
Unit# 1728058
PIPE-WRENCH PLIERS
Angled Head
Tongue and groove design with 90° angled
jaws for more leverage. Features seven jaw
positions, handle stop, and plastic dipped han-
dles. Yellow.
WRENCH SETS
Satin Chrome
12 Point box end provides easy socket
engagement and maximum versatility. Recess
corner in box end provide extra turning power.
Sets are packed in vinyl pouch.
WRENCH SETS
Combination
SUPERCOMBO® open end with specially
designed grooves that direct wrench force
away from fastener corners. SUPER-
TORQUE® box opening design allows appli-
cation of higher torque without rounding or
deforming hex fastener points. Many be sued
on all common hex (6 point) fasteners.
ADJUSTABLE WRENCHES
Standard Capacity Jaw
Drop forged, chrome plated alloy steel.
No. D500-18. Plastic-dipped handle.
Unit# 1728026
ADJUSTABLE WRENCHES
Extra-Capacity Jaw
Drop-forged, chrome plated alloy steel con-
struction.
Nos. HD507-10 and HD507-12. Feature
heavy-duty handle.
No.
Jaw
Lgth. In.
OAL
In.
D203-5 1-9/16 5-9/16
D203-6 1-15/16 6-5/8
D203-7 2-7/16 7-1/8
D203-8N 2-5/16 8-7/16
D304-6 2-5/16 7-1/16
D305-6 2-5/16 7-1/16
D307-51/2C 1-11/16 5-5/8
No.
Jaw
Cap. In.
OAL
In.
D502-6 1 6-1/2
D502-10 1-3/4 10
D502-12 2-1/8 12
D502-16 4-1/4 16-3/4
Journeyman
J502-10 1-3/4 10-1/4
Journeyman
No.
Lgth.
In.
Pkg.
Qty.
045110MCP 10 5
No.
Jaw
Cap. In.
OAL
In.
D503-10 2-1/8 10-1/4
D503-12 2-5/8 13-1/4
No. Sizes Description
11006 1/4 to 1-1/4 16-Piece wrench set
11014 6 to 24 mm 19-Piece wrench set
No. Description
WS-1172SCA 15-Piece wrench set
No.
Jaw
Cap. In.
OAL
In.
D500-18 2-1/16 18-3/8
500-18 2-1/16 18-1/4
No.
Jaw
Cap. In.
OAL
In.
Plastic-Dipped Handle
D507-6 1-5/16 6-3/8
D507-8 1-1/8 8-3/8
D507-10 1-5/16 10-3/8
D507-12 1-1/2 12-3/8
HD507-8 1-1/8 8-3/8
HD507-10 1-5/16 10-3/8
HD507-12 1-1/2 12-3/8
High Polish Chrome Finish Handle
507-10 1-5/16 10-1/4
507-12 1-1/2 12-1/4
Hand Tools
70 1-800-832-2297
Unit# 1728059
ADJUSTABLE WRENCHES
Standard Capacity Jaw
Forged, heat-treated alloy steel construction
with industrial black finish and plastic dipped
handles. Corrosion resistant.
Unit# 2936010
WRENCHES
Adjustable
Features composite handle, wide capacity jaw,
measuring scale on head, and compact
reversible switch for 15° offset of box end.
Corrosion-resistant finish.
RATCHETING WRENCH SETS
Combination
CAN WRENCHES
Features 3/8 socket with silver finish and 7/
16 socket with black finish. One end opens
telephone box fasteners, the other tightens
nuts on binding-post terminals. 1-1/4 deep
sockets.
Unit# 1728062
RATCHETING WRENCHES
Linemans
For use on lag bolts, C-clamps, suspension
bolts and other utility pole hardware. Bolt-
through design allows bolt to pass through
socket. Features bright yellow 3/4 and 1 x 1-
1/8 combination square socket.
LINEMANS WRENCH
5-in-1
Bolt-through design allows bolts to pass
through the socket. For use on most common
utility pole hardware, such as lag bolts, C
clamps and suspension bolts. 3/4 and 1 x 1-
1/8 square nut size.
No. KT155HD. Heavy-Duty.
Unit# 1632022
RATCHET WRENCHES
Linemans  Fargo
For tightening long machine bolts on utility
poles. Features bolt thru socket design and
reversible ratchet.
IMPACT SOCKET ADAPTER
LINEMAN'S WRENCHES
Forged from bar steel and heat-treated for
long life. Hole at large end for turning-in stan-
dard pole steps. Wrench for heavy three-bolt
guy clamps. 13 Length.
No.
Jaw Cap.
In.
OAL
In.
D508-10 1-1/8 10-3/8
D508-12 1-5/16 12-3/8
D508-15 1-11/16 15-1/8
No.
Lgth.
In.
015410C 10
No. Description
MSW-18A
18-Piece, high polished
chrome, black with
SUPERTORQUE®
MWS-12RC 12-Piece, high polished
MWS-4RC 4-Piece, high polished
WS-1164RC 4-Piece, high polished
WS-1168RC 8-Piece, high polished
No.
Handle
Dia. In.
Lgth.
In.
68005 17
No.
Lgth.
In.
KT151T 13
No.
Bolt
Size In.
Lgth.
In.
KT155T 1/2, 5/8, 3/4 9-1/2
KT155HD 1/2, 5/8, 3/4 9-1/2
No. Desc.
Fits Nut
Size In.
GP3458 2-in-1 combination
square socket 5/8 & 3/4
GP345812 3-in-1 combination
square socket
5/8, 3/4
& 1/2
No. Description
Hex
Size In.
NRHD Impact socekt adapter
for NRHD. 7/16
No. Description
Painted
Finish
3146 For 5/8 hardware Dark Blue
3146A For 3/4 hardware Dark Blue
3146B For NEMA hardware Silver
Hand Tools
1-800-832-2297 71
C CLAMP SETS
4-Piece
Drop forged C-Clamps with copper plated
screw. Yellow.
Unit# 3153002
RATCHETS
Snap-On®  Dual 80
Features 80-tooth gear design with 7 teeth in
contact for strength and durability, reduced
ratcheting arc, sealed head, and long handle.
Chrome finish.
Unit# 1632021
CONNECTOR WRENCHES
Ratchet  Fargo
For installation of mechanical connectors in
utility distribution applications. Polypropylene
handle separates both ends.
* Does not include polypropylene handle.
CONNECTOR WRENCHES
Ratchet
Designed for lineman use. Handle separates
both ends. Constructed for proper and fast
installation of mechanical connectors in utility
distribution applications. All have polypropyl-
ene handle except GP203.
Unit# 1728015
BOX WRENCHES
Ratcheting
For use in confined spaces and on long studs.
Laminated construction with chrome finish.
No. 68242. Both ends offset by 25°.
BOX WRENCHES
Ratcheting
Provides end to end isolation for maximum
safety. The RBW wrenches have an ergo-
nomic handle with center window displaying
the separation of the tool ends.
BOX WRENCHES
Ratcheting  Dogbone Style
Provides end to end isolation for maximum
safety. The RBW wrenches have an ergo-
nomic handle with center window displaying
the separation of the tool ends.
No. Description
20042 Sizes 2, 4, 6 and 8
No.
Drive
Size. In.
OAL
In.
FL80 3/8 10-5/16
SL80 1/2 15
Check our website for
special promotions.
www.uscco.com
No.
Ratchet
Sizes In.
GP2031* 1/2 & 9/16
GP2212 1/2 & 9/16
GP2214 3/8 & 1/2
GP223 9/16 & 3/4
GP2237 5/8 & 3/4
GP2238 3/4 & 13/16
No.
A End
Size In.
B End
Size In.
GP203 9/16 3/4
GP221 3/8 9/16
GP2213 5/16 3/8
GP2231 9/16 11/16
GP2233 9/16 5/8
GP2236 5/8 13/16
GP224 3/4 7/8
GP2245 7/8 15/16
No.
Size
In.
Lgth.
In.
68202 1/2 x 9/16 6-1/2
KT203 3/4 x 9/16 8-1/8
Offset
68242 3/4 x 7/8 9-1/8
No. Description
RBW-1 5/16 Hex shaft extended 1-1/2 on
one side
No. Size In.
RBW-51638 5/16 x 3/8
RBW-12916 1/2 x 9/16
RBW-1258 1/2 x 5/8
RBW-5834 5/8 x 3/4
RBW-11161516 11/16 x 15/16
RBW-3478 3/4 x 7/8
RBW-341516 3/4 x 15/16
RBW-13161516 13/16 x 15/16
Hand Tools
72 1-800-832-2297
Unit# 4312004
BOX WRENCHES
Ratcheting
Provides end to end isolation for safety. Fea-
tures spun fiberglass handle with 1-1/2 long
hex shafts on one end and Penta head on
other end.
Unit# 4312006
BOX WRENCHES
Ratcheting
Provides end to end isolation for safety. Fea-
tures 1-1/2 long hex shaft and ratcheting
Penta ends, and ergonomic handle with win-
dow displaying wrench end separation.
BOX WRENCH SETS
Ratcheting
Sizes 13/16 to 1 in storage tray.
PENTA SECURITY WRENCHES
For use on power transformers. Features
stainless steel Penta socket mounted on ergo-
nomically designed handle.
PENTA SECURITY WRENCHES
Reversible Sockets
Sockets include a Penta and 3/4 hex socket
combined into one socket with a common 3/8
center drive. The tool is reversible when used
with a socket extension.
PENTA/HEX WRENCHES
Features socket on one end and a 3/4 hex on
the other. Stainless steel construction with
captive folding cross-rod for leverage.
Unit# 1728016
CONSTRUCTION WRENCHES
Ratcheting
Accepts 1/2 square drive hex sockets.
Reversible. Drop forged alloy steel construc-
tion with black finish.
Unit# 1728017
CONSTRUCTION WRENCHES
Adjustable
Fits all nuts and bolts to 1-1/2. Drop forged
alloy steel construction with black finish.
Tapered handle.
Unit# 4312005
LINEMANS WRENCHES
Features padded handle with square sockets,
pass through bolt hole and extra-large revers-
ing lever on one end, and ratcheting box
wrench on other end.
Unit# 4312007
LINEMANS WRENCHES
For use in overhead hardware applications.
Features padded handle; 3/4, 1 and 1-1/8
square sockets; pass through bolt hole; large
reversing lever on one end, and 3/4 and 9/16
ratcheting box wrench on other end.
Unit# 4321001
WRENCHES
T-Style  Penta Head
For use on transformers, switchgear and
enclosures with penta head bolts. Heavy-duty
chrome plated construction.
No.
Hex Shaft
Size In.
RBW-3P 5/16 & 3/8
No.
Hex Shaft
Size In.
RBW-RP
RBW-516RP 5/16 Hex shaft
RBW-51638RP
5/16 Hex shaft on one
side, 3/8 hex shaft on
the other side
RBW-51638SRP
5/16 Hex shaft on one
side, 3/8 socket
(opposed) on other end
No. Description
BOER704 4-Piece Open End, Standard,
15° Offset
No. Description
PW-2 Penta/Hex combination socket
No. Description
PHS-1 Penta/Hex reversible sockets
No. Description
PHW-1 Penta/Hex wrench
No.
Lgth.
In.
3238 15
No.
Lgth.
In.
3239 15
No.
Square Socket
Size In.
Box
Wrench
Size In.
RBW-OHW34 3/4, 1 & 1-1/8 3/4
No.
Socket
Type
OHW Shallow
OHW-D Deep
No. Desc.
PH1 Penta head wrench
Hand Tools
1-800-832-2297 73
S&RSpecialty
FAT FINGERS
No. PLS3812. Accommodates 1/2 hex nut
and lock washer and 3/8 square nut and mat-
ing square lock nut on other end.
No. PLS5858. Accommodates 5/8 square nut
and mating square lock nut. Double load
design, same at both ends.
Unit# 1728051
COMBINATION WRENCH SETS
14-Piece
Includes wrenches with open and 12-point box
end in sizes: 3/8, 7/16, 1/2, 9/16, 5/8, 11/
16, 3/4, 13/16, 7/8, 15/16, 1, 1-1/16, 1-1/
8 and 1-1/4 in pouch with marked pockets.
U
Unit# 2936026
COMBINATION WRENCH SETS
Ratcheting  7-Piece
Five-degree ratcheting design allows use in
confined spaces. Corrosion-resistant polished
chrome finish. Includes 1/4, 5/16, 3/8, 7/16,
1/2, 9/16 and 5/8 sizes.
WRENCH SETS
DEEP SOCKET SETS
1/2 Drive
9-Piece set features SUPERTORQUE® lobu-
lar openings for greater turning power.
Designed for quick engagement on 6 point
fasteners.
No. 32926. Also for use on 12 point fasteners.
No. 37096. Heat treated for long life. Drive
end features pin retention hold and groove.
DEEP SOCKETS
1-1/2 Drive
SUPERTORQUE® lob-
ular openings for
greater turning power.
Designed for maximum
engagement on 6 point
fasteners.
SOCKET SETS
6 Point
SUPERTORQUE® lobular
openings for greater turning
power. Designed for maxi-
mum engagement on 6
point fasteners. Suitable for
use with any pneumatic
and electric impact
wrenches. Heat treated.
No. Size In.
PLS3812 1/2 and 3/8 Combo
PLS5858 5/8 and 5/8 Combo
PLS-MG1234 Hot finger
PLS-SP1234 Hot finger
No. Desc.
68406 14-Piece combination wrench set
No. Desc.
035401 Combination ratcheting wrench set
No. Description
65500
13-Piece  1/4 Drive Socket Wrench
Set includes (9) 6-point sockets,
spinner handle, two extensions 2
and 6 L, ratchet and hinged metal
box.
65506
13-Piece  3/8 Drive Metric Socket
Wrench Set includes (13) 6-point
sockets, and fliplock tray.
65508
20-Piece  3/8 Drive Socket Wrench
Set includes (4) 6-point sockets, (5)
12-point sockets, (8) 6-point deep
sockets, (2) extensions 1-3/4 and 3
L, ratchet and hinge metal box
65512
16-Piece  1/2 Drive Socket Wrench
Set includes (13) 12-point sockets,
5 long extension, 17 long flex
handle, ratchet and hinged metal
box.
No. Description
32926 For 6 and 12 Point fasteners
37096 For 6 Point fasteners
No. Description
HD-648 3/4 Drive Deep Socket,
No. Description
Deep Impact
14-620 Single , SAE, 1/2 Drive
MS-14-24RC 24-Piece, Metric, 1/2 Drive
MS-4-23RC 23-Piece, Metric, 1/2 Drive
MSH-20TB 20-Piece with Tool Box,
Metric, 3/4 Drive
MSS-33TB 33-Piece with Tool Box,
Metric, 1/2 Drive
Shallow Impact
WS-4-14 14-Piece, 1/2 Drive
WS-2-13 13-Piece, 3/8 Drive
Hand Tools
74 1-800-832-2297
Unit# 2936023
HEX KEY SETS
Folding  9-Piece
Single-piece powder coat handle case. Fea-
tures 5/64, 3/32, 7/64, 1/8, 9/64, 5/32 3/
16, 7/32 and 1/4 sizes. 4-3/8 OAL.
No. 025412. Features ball-end design use at
up to 30° angle.
HEX KEY SETS
Grip-It®
Features square-cut ends for secure full depth
fit and maximum contact with hex socket. Two
key positions (straight-out or right angle) for
extra leverage.Sizes: 3/16, 7/32, 1/5, 5/16 and
3/8..
nit# 1728027
HEX KEY SETS
Features square-cut ends for maximum con-
tact with socket.
HEX KEYS
Linemans L-Style
Heat-treated and tempered
for added strength. Alloy
steel construction.
HEX T-HANDLE
Journeyman
T-Handle design delivers more torque to fas-
teners. Features soft touch grip with molded-in
finger grooves...
Unit# 3881013
HEX WRENCH SETS
14-Piece  Type L
Features two-color insulation. Impact and
flame resistant. Rated for exposure to 1000V
AC; dielectrically tested at 10,000V AC. Meets
ASTM and IEC standards. Includes 1/16 to 1/
2 long arm wrenches and soft sided roll case.
Unit# 2936038
NUT RUNNERS
Slim profile design. Features deep well for use
with up to 6 excess bolt length. Includes 7/16
hex quick-change adapter. Measures 2-3/8
dia. x 8-5/8 L (without adapter).
Unit# 4291001
NUTDRIVERS
Extra long design with cushioned grip.
No. Desc.
025411 Folding hex key set
025412 Ball-end folding hex key set
No. Description Color
70570 Hex-Set Yelllow
70571 Ball Hex-Set Yellow
025411
025412
No. Key Sizes
70579 3/16, 7/32, 1/4, 5/16 & 3/8
70582 1.5mm, 2mm, 3mm, 4mm, 5mm and
6mm
70583 3/32, 7/64, 1/8, 9/64, 5/32, 3/16,
7/32 & 1/4
70591 5/64, 3/32, 7/64, 1/8, 9/64, 5/32,
3/16, 7/32 and 1/4
No. Description
BL10 Ball-End 5/32
Single Key
BLK12 Ball-End 12-Piece
Hex-Key Set
LMK10 9-Piece Hex-Key
Set
LLK12 12-Piece Hex-Key
Set
No.
Hex
Size In.
JTH9E14 5/16
No. Desc.
S2610214 14-Piece hex wrench set
No.
For Nut
Size In.
NR2 1-5/16, 1-1/8, & 1
No.
Socket
Size In.
Lgth.
In.
ND500-CGXL 3/8 6
Hand Tools
1-800-832-2297 75
Unit# 2936022
NUTDRIVER SETS
7-Piece
Features precision head for accurate fastener
fit, hollow shaft and cushioned grip. Handle
marked with size. Rust resistant satin chrome
plated finish. 3 shank. Includes 3/16, 1/4, 5/
16, 11/32, 3/8, 7/16 and 1/2 drivers.
Note: Not insulated.
NUT DRIVERS
Hollow Shank
Features cushion grip and color coded ends.
Fits over long bolts and studs.
NUT DRIVERS
Hollow Shank  Insulated
Provides protection against electric shock.
1000-Volt rating. Features cushion grip and
color coded ends.
NUT DRIVER SETS
Hollow Shank
Features color-coded handles with chrome-
plated shafts. Includes stand.
Unit# 1728040
SCREWDRIVER/NUTDRIVERS
11-in-1
Includes 3/8, 5/16, and 1/4 nutdriver sizes;
and #1 and #2 Phillips, 1/4 and 3/16 slotted
screwdriver bits; T10 and T15 Torx® bits, and
#1 and #2 square recess bits. End of handle is
marked for tool identification.
Unit# 1728039
SCREWDRIVER/NUTDRIVER
SETS
.
Unit# 1728020
SCREWDRIVERS
Keystone
Features heavy-duty square shank for
wrench-assisted turning, and cushioned grip.
Unit# 1728021
SCREWDRIVERS
Cabinet
For working in confined spaces. Features
cushioned grip. 3/16 narrow tip.
No. Desc.
025301C 7-Piece nutdriver set
No.
Hex
Size In.
Shank
In.
Lgth.
In.
630-1/2 1/2 3 7-5/16
630-9/16 9/16 4 9-3/8
630-1/4 1/4 3 6-3/4
630-3/8 3/8 3 6/3/4
630-5/8 5/8 4 9-3/8
Nut Driver Sets
631 7-Piece
647M 7-Piece Magnetic Tip
65160 7-Piece Metric
No.
Hex
Size In.
Shank
In.
Lgth.
In.
630-1/4-INS 1/4 3 7-3/4
630-1/2-INS 1/2 3 7-5/16
630-5/16-INS 5/16 3 6-3/4
630-5/8-INS 5/8 3 9-3/8
630-9/16-INS 9/16 4 9-3/8
646-1/2-INS 1/2 6 11-3/8
No. Description
70200 10-Piece Metric Nut-Dirver Set
with Stand
No. Desc.
32500 11-In-1 screwdriver/nutdriver
No. Desc.
32476
5-In-1 Set: Includes 5/16 nutdriver,
#1 and #2 Phillips, and 9/32 and 3/
16 slotted screwdriver bits. End of
handle is marked for tool identifica-
tion
32477
10-In-1 Set: Includes 5/16 and 1/4
nut drivers, #1 and #2 Phillips, 1/4
and 3/16 slotted, T10 and T15
TORX® and #1 and #2 square
recess
32557
Heavy-Duty Multi-Bit Set:. Includes
3/16 and 1/4 slotted, #1 and #2
Phillips, 1/4, 5/16, and 3/8 nut
drivers, #1 and #2 squire-recess, 3/
8 hex driver
No.
Tip
Width In.
Lgth.
In.
600-4 1/4 8-11/32
600-6 5/16 10-15/16
600-8 3/8 13-7/16
600-12 1/2 17-7/16
No.
Lgth.
In.
601-3 6-3/4
601-4 7-3/4
601-6 9-3/4
Hand Tools
76 1-800-832-2297
Unit# 1728022
SCREWDRIVERS
Keystone
Features heavy-duty round shank and cush-
ioned grip. 3/8 tip width.
Unit# 1728023
SCREWDRIVERS
Phillips
Features round shank, precision tip and cush-
ioned grip.
No. 603-1. Stubby.
No. 603B. Bends AWG gauges #12 and #14.
Unit# 1728047
SCREWDRIVERS
Coated  Cabinet
Plastic coated shank resists cutting, chipping
and cracking; thin coating permits use in con-
fined areas.
Nos. 620-4 & 620-6. Feature heavy-duty
shank.
Note: Not insulated.
Unit# 2936005
SCREWDRIVERS
Keystone
Features precision-machined black phos-
phated tip, square shank, and cushioned grip.
Handle marked with size, type and length.
Note: Not insulated.
Unit# 2936006
SCREWDRIVERS
Cabinet
Features precision-machined 3/16 black
phosphated tip and cushioned grip. Handle
marked with size, type and length.
Note: Not insulated.
Unit# 2936007
SCREWDRIVERS
Flat Blade  Stubby
Features precision-machined 3/16 black
phosphated tip, round shank and cushioned
grip. Handle marked with size, type and
length.
Note: Not insulated.
Unit# 2936008
SCREWDRIVERS
Phillips
Features precision-machined #2 black phos-
phated tip and cushioned grip. Handle marked
with size, type and length.
Note: Not insulated.
Unit# 2936009
SCREWDRIVERS
6-in-1
Features precision-machined hardened steel
bits and cushioned grip. Includes 3/16 and 1/
4 flat, #1 and #2 Phillips, and 5/16 and 1/4
hex bits. Rust-resistant chrome plated finish.
Note: Not insulated.
No.
Shank
Lgth. In.
OAL
In.
602-4 4 8-11/32
602-6 6 10-15/16
602-8 8 13-7/16
602-10 10 15-7/16
602-12 12 17-7/16
Insulated
602-6-INS 6 10-15/16
602-10-INS 10 15-7/16
33532-INS Set with 602-4-INS & 603-4-INS
No.
Tip
Size
Lgth.
In.
603-1 #2 3-7/16
603-3 #1 6-3/4
603B #1 6-3/4
603-4 #2 8-5/16
603-6 #3 11
603-7 #2 11-5/16
603-10 #2 14-5/16
Visit our Web Site at
www.uscco.com
for our full line card.
No.
Tip
Width In.
Shank
Lgth. In.
OAL
In.
620-4 1/4 4 4
620-3 3/16 3 6-3/4
621-6 3/16 6 9-3/4
620-6 5/16 6 10-15/16
621-8 3/16 8 11-3/4
621-10 3/16 10 13-3/4
No.
Tip
Size In.
Lgth.
In.
015312C 1/4 6
015314C 1/4 10
015315C 5/16 10-15/16
No.
Lgth.
In.
015322C 6
015324C 10
No.
Lgth.
In.
015328C 1-1/2
No.
Shank
Dia. In.
Lgth.
In.
015334C 1/4 6
No. Desc.
015342C 6-in-1 screwdriver
Hand Tools
1-800-832-2297 77
Unit# 2936004
SCREWDRIVER SETS
5-Piece
Features precision-machined black phos-
phated tips, and cushioned grip. Handle
marked with size, type and length. Rust resis-
tant chrome plated finish. Includes 3/16 x 6
and 1/4 x 6 cabinet, 1/4 x 4 and 5/16 x 6
keystone, and #2 x 4 Phillips drivers.
Note: Not insulated.
Unit# 2936012
SCREWDRIVER SETS
Insulated  6-Piece
Features precision machined tips with black
phosphated plating and ergonomic handle.
Includes flat blade sizes: 3/32 x 3, 5/32 x 4,
7/32 x 5, 1/4 x 6, flat; and Phillips sizes: #1
x 3-1/8 and #2 x 4. Rated to 1000V AC.
Meets IEC and ASTM standards.
Unit# 1728019
SCREWDRIVER SETS
Mini  4-Piece
Features precision tips, chrome plated shafts
and cushion grip handles. Includes #0 Phillips,
1/16 keystone and 3/32 and 1/8 cabinet
screwdrivers.
SCRATCH AWLS
Heavy-duty awl scribes metal, starts screw
holes, pierces and punches. Features cushion
grip handle.
SCREWDRIVERS
Screw-Holding
Blade separates to hold the fastener. Not
designed for torquing or tightening.
SCREW STARTERS
Flat Tip
No conductive path to user. No insulation to
puncture, tear or wear through. Individually
tested to protect up to 1,000 V AC and 1500 V
DC.
BALL-PEEN HAMMERS
Forged and hardened high-
carbon steel head with smooth
rounded peen. Straight-grain
hickory handle.
Unit# 1728053
STRAIGHT-CLAW HAMMERS
For easy nail pulling in tight quarters. Features
fiberglass shaft, plastic alloy jacketing and
neoprene grip.
Nos. 808-16 and 808-20. Heavy Duty.
Unit# 2936011
HAMMERS
Electricians
Elongated neck and narrow striking face for
use in boxes and other confined spaces. Fea-
tures long straight claws, fiberglass handle
with flared end, and cushioned grip.
Note: Not insulated.
No. Desc.
Pkg.
Qty.
015301CCP 5-Piece scredriver set 5
No. Desc.
0157011 Insulated screwdriver set
No. Desc.
85484 4-Piece mini screwdriver set
No.
Blade
Lgth. In.
OAL
In.
650 3-1/2 7-7/8
No. Description
OAL
In.
K16 Phillips-Tip 7
K19 Phillips-Tip 9
K36 1/4 Slotted 9-3/4
SK234 3-Piece slotted set includes
K23, K34, K46
No. Description
CSSC9 Flat Tip/Phillips®, non-conductive
composite, .032 x 9/32, #2, 9
K16
SK234
No.
Head Wt.
Oz.
OAL
In.
803-32 32 15
No.
Head
Wt. Oz.
OAL
In.
807-18 18 15
808-16 16 13
808-20 20 14
No.
Head
Wt. Oz.
015611 18
Hand Tools
78 1-800-832-2297
Unit# 1728054
DOUBLE-FACE HAMMERS
Linemans
For pole-line applications. Forged, tempered
steel head features identical faces with 1-3/4
round driving surfaces and beveled edges;
head measures 3-3/4 long.
No. 809-36MF. Milled-Face.
STRAIGHT-CLAW HAMMERS
Linemans
Heavy-duty, double-duty
hammer drives lags and
pulls big nails. Features
high-carbon steel head with
solid octagon-shaped driv-
ing end. Straight-grain lac-
quered hickory handle.
Unit# 3871013
STAPLE PULLERS
For removal of staples installed over ground
wire molding. Features welded bridge to strad-
dle molding without causing damage.
ELECTRICIANS CHISELS
One-piece forged handle and alloy steel
blade. Corrosion resistant black finish extends
to polished blade edge.
Unit #4301002
POINTED CHISELS
For use in concrete and masonry applications.
Features polygon design for reduced striking
and self-sharpening tip profile.
Unit #4301003
FLAT CHISELS
For use in concrete and masonry applications.
Narrow design.
Unit# 1260001
FLAT FILES
Bastard Cut  Nicholson®
For use in machine shops, on ships and in
engine repair for rapid removal of metal. Rect-
angular cross-section with slight taper toward
point. Double-cut on sides, single-cut on
edges. American pattern.
Unit# 2936018
TOOL KITS
28-Piece  Electricians
Includes multi-pocket bag, 8-pocket leather
pouch, leather tool belt, (4) pliers, wire strip-
per, cable ripper, stripping/crimping tool, cable
cutter, utility knife, hacksaw, (6) screwdrivers,
scratch awl, adjustable wrench, hex key set,
tape measure, torpedo level, hammer, gloves
and voltage tester.
Unit# 2936019
TOOL KITS
17-Piece  Journeymens
Includes 20-pocket caddy, voltage tester, tor-
pedo level, hammer, tape measure, (4) screw-
drivers, (4) pliers, wire stripper, cable ripper,
stripping/crimping tool and cable cutter.
No.
Head
Wt. Oz.
OAL
In.
809-36 36 14
809-36MF 36 14
No.
Head Wt.
Oz.
OAL
In.
832-32 32 15
No. Desc.
6400 Staple puller
No.
Blade
Width In.
OAL
In.
66100 2-3/4 8
No. Desc.
376493 Pointed chisel
No. Desc.
376496 Flat chisel
No.
Lgth.
In.
3665 10
3764 12
No. Desc.
015911 Electricians tool kit
No. Desc.
015912 Journeymens tool kit
We are continually
adding new products.
Call us with your
inquiries.
Hand Tools
1-800-832-2297 79
Unit# 2936020
TOOL KITS
12-Piece  Electricians
Includes leather tool belt, 8-pocket leather
pouch, tape measure, (4) screwdrivers, wire
stripper, and (4) pliers.
Unit# 2936021
TOOL KITS
5-Piece  Electricians
Includes 4-pocket leather pouch, Phillips, cab-
inet and flat blade screwdrivers, wire stripper
and side-cutting pliers.
TOOL KITS
Utility Insulated
1000-Volt rating. Two layers of insulation pro-
vide protection against electric shock. Includes
assortment of (13) professional insulated
tools.
Custom case includes (2) pallets with custom-
fitted pockets for each tool and combination
lock and (2) key-locked latches for security.
Unit# 1303712400
BASIC ELECTRICIAN ROLLS
Includes 7 needle nose pliers, 7-1/2 diagonal
cutting pliers, 9 linesmans pliers, combina-
tion stripper/crimper pliers, slotted screw-
drivers (3/16 x 4, 3/16 x 6,1/4 x 6) and
Phillips screwdrivers (1 X 3, 2 X 4) in insu-
lated roll.
Unit# 1882006
DRILL PRESSES
Adjustable Position
For drilling ferrous materi-
als 1/2 or thicker.
Grounded construction.
Features variable speed
base, 12-1/2 Amp motor,
solid state electronic
switching, feedback
speed control, line lockout
and 9-ft. cord. 120V AC.
Unit# 1882001
RECIPROCATING SAW KITS
Cordless  Sawzall®
Accepts 1/2 shank blades. Features high/low
speed selector, two-finger variable speed trig-
ger, gear protecting clutch, battery fuel gauge
and tool-free adjustable shoe. Blade clamp
allows for fast blade changes. 28V DC.
Includes (2) blades, (2) lithium-ion battery
packs, 1-hour charger and case.
SAW BLADES
Sawzall®
Features Matrix II bi-metal teeth with double
relief angle. 8/12 TPI.
No. Desc.
015913 Electricians tool kit
No. Desc.
015914 Electricians tool kit
Check our website for
special promotions.
www.uscco.com
No. Description
33525 Utility insulated tool kit with
custom case
33525SC Utility insulated too kit with fold
up case
No. Desc.
TK9 Electrician roll
No.
Min. No Load
RPM
Drill
Cap. In.
4206-1 350 3/4
4209-1 375 1-1/4
Max. No Load RPM Stroke
No. High Low Lgth. In.
0719-22 3000 2000 1-1/8
No.
Shank
In.
Dim In.
LxWxThick.
48-01-7091 1/2 6 x 3/4 x .05
Hand Tools
80 1-800-832-2297
Unit# 1882002
RIGHT ANGLE DRILLS
Cordless
For boring large holes between studs or joists
in confined spaces. Features 28V motor, 1/2
keyed chuck, 360° swivel head and forward/
reverse lever. 1/2 capacity in steel; 2-9/16
capacity in wood. Includes battery, side han-
dle, chuck key and case.
BANDSAW KITS
Cordless
Features 28V motor, high/low speed selector,
two-finger trigger speed control, non-slip soft
grip, LED light, and blade tightening lever. 4-3/
4 x 4-3/4 capacity. Includes blade, lithium-ion
battery pack, 1-hour charger and case.
IMPACT WRENCHES
Hex Quick Change
For use in heavy-duty driving and drilling appli-
cations. Features magnesium gearcase and
hanging bracket with solid steel ring, forward/
reverse switch, variable speed switch, non-slip
soft grip. 325 ft./lbs. maximum torque. 28V
DC. 7/16 hex drive.
Note: Requires 28V lithium-ion battery pack
(not included).
IMPACT WRENCHES
High Torque  Cordless
Includes tool, (2) Li-Ion batteries, charger,
choice of (6) impact sockets, and choice of
soft bag or impact-resistant plastic tool box.
Unit# 4333001
IMPACT WRENCHES
Hydraulic  Burndy®
For use in hole drilling and hardware installa-
tion applications. Features Gerotor type motor.
Operates on open or closed center circuits. 7/
16 chuck size. Includes eyelet kit.
Unit# 1882019
ROTARY HAMMERS
Compact design for use in concrete drilling,
overhead work and confined space applica-
tions. Features 7 Amp reversible motor, met
gear case, anti-vibration system, two-finger
trigger, rotating brush plate, 10-ft. cord and
soft grip D-handle. Three operating modes:
hammer drill; drill and chipping. 1 solid bit
capacity; 2-1/2 thin wall core bit capacity.
120V AC.
COMBINATION HAMMERS
Features four working modes: Drilling, Ham-
mer drilling, chisel setting and chiseling.
Includes tool with Active Torque Control, 13 fit
supply cord, bit, pointed chisel, side handle,
Hilti grease, cleaning cloth, operating instruc-
tions, and impact-resistant plastic tool box.
Max. No Load RPM Lgth.
No. High Low In.
0721-21 1000 900 18-1/2
Max. SFPM Lgth.
No. High Low In.
0729-21 350 225 22
No.
No Load
RPM
No Load
BPM
Lgth.
In.
0799-20 0 to 1450 0 to 2450 11-3/4
No. Description
Blows
Per
Min. Volts
03467650 SIW 18T 2500 18
No. Description
HIW716VTR1 Features adjustable torque
setting
No.
No Load
BPM
No Load
RPM
Lgth.
In.
5363-21 0 to 5980 0 to 1400 12-1/4
No. Mfg. No. Watts
Blows
Per Min.
03468367 TE-70-ATC 1600 2760
Hand Tools
1-800-832-2297 81
COMBINATION HAMMER TOOL
Includes tool with Active Torque Control and Active Vibration Reduc-
tion, 13 ft. supply cord, bit, pointed chisel, side handle, Hilti grease,
cleaning cloth, operating instructions and impact-resistant plastic tool
box...
HAMMER DRILL/DRIVER
Lithium ion cordless hammer drill/driver. Includes (2) Li-ion batteries,
battery charger, side handle and operating instructions and choice of
bag or impact resistant tool box...
Unit# 1882020
SANDERS
For use in removing paint or rust from metal, plastic or fiberglass sur-
faces. Features 15 Amp motor, angled rear handle and side handle,
two-finger trigger switch, spindle lock, spiral bevel gears, aluminum tool
rest and 9-ft. cord. 5/8-11 spindle. 120V AC/DC. Accommodates 7 or
9 backup pads.
No. HIW716ENF. Features adjustable torque selector spool; allows
user to feather up to desired torque.
Unit# 1882005
HAMMER DRILL KITS
Impact  Cordless
Features magnesium gear box with all
metal gears, variable speed trigger, LED
light, clutch bypass, bit holder, reversible
battery chamber, battery fuel gauge and
soft grip handle. Includes (2) 18V lithium-
ion batteries, battery charger and case.
HAMMER DRILL KITS
Includes TE 4-A18, WSR 18, SFH-18, soft bag, plus (1) each of the fol-
lowing TE-CX drill bits: 1/4 x 6, 3/8 x 6 and 1/2 x 6.
No. Description Watts
Blows
Per Min.
03444117 TE 60 ATC-AVR Kit 1200 2785
No. Mfg. No.
No.
Gears
Conn.
End.
Blows
Per Min.
03467877 SFH 18-A 3 Keyless
Chuck 39,000
Description Watts
Blows
Per Min.
TE 60 ATC-AVR Kit 1200 2785
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
No.
No Load
RPM
Max.
HP
Lgth.
In.
6081-20 6000 4 19-1/4
No. PSI
Flow
GPM
Torque
Ft./Lbs.
Quik Change
HIW-716 1000 to 2000 4 to 7 450@6GPM
HIW716VTR1 1000 to 2000 4 to 7 200 to 500 adjustable
Tri-Ball
HIW716ENF 750 to 2000 4 to 12 515 @ 8 GPM
No.
Torque
In.-Lbs.
0824-24 1400
No. Description
03472626 Combo package
Hand Tools
82 1-800-832-2297
Unit# 1882009
DRILL & DRIVE SETS
38-Piece  Quik-Lok
Includes premium
grade S2 tool steel
screwdriver bits,
titanium hex shank
drill bits, and mag-
netic nutdrivers for
use with sheet
metal and hexago-
nal type screws.
Unit# 1882014
DRILL BIT KITS
Contractors
7-Bit assortment for use in drilling large holes.
Includes 1, 1-1/8, 1-1/4, 1-1/2, 1-3/4: 2-1/8
and 2-9/16 dia. bits, 5-1/2 extension and
case.
Unit# 3153001
IMPACT SOCKET SETS
6-Point  Deep  Snap-On®
Contains sizes 5/16 to 1.
Unit# 3153003
IMPACT EXTENSIONS
Snap Ring Type  Snap-On®
Industrial finish.
Unit# 1882017
DRILL ATTACHMENTS
Right Angle
For use with cordless drills and screwdrivers.
Metal construction. Accepts standard 1/4 hex
drive accessories. Includes (5) bits.
DEEP IMPACT SOCKET SETS
9-Piece
Flank drive wrenching system grips the fas-
tener on the socket flanks to deliver 15% to
20% more turning power. 6 Point.
Unit# 1728050
DEEP SOCKET SETS
12-Point  1/2 Drive
8-Piece set includes: 1/2, 9/16, 5/8, 11/16,
3/4, 13/16, 7/8 and 15/16 sockets in hinged
metal box.
Unit# 1882016
ANNULAR CUTTER KITS
9-Piece
For use with magnetic drill presses. Features
dual alternating tooth design and Weldon
shank. Includes 1/2, 9/16, 5/8, 11/16, 3/4,
13/16, 7/8, 15/16, and 1-1/16 cutters, (2)
pilot bits and case.
U
No. Desc.
48-32-1500 38-Pc. drill and drive set
No. Desc.
49-22-0130 Contractors drill bit kit
No. Desc.
212SIMFYA 12-Pc. socket set
No.
Drive
Size. In.
Shank
Dia. In.
Nom.
Lgth. In.
IMX52 1/2 21/32 6
No.
Max Screw
Size
Width
In.
49-22-8510 #8x3L 2
No. Description
309SIMYA 1/2 to 1
No. Desc.
65514 8-Piece deep socket set
No.
Cutting
Depth In.
Shank
Dia. In.
49-22-8410 23/4
Visit our Web Site at
www.uscco.com
for our full line card.
Hand Tools
1-800-832-2297 83
Unit# 1882015
HOLE SAW KITS
5-Piece  Electricians
Carbide construction.
HOLE SAW ARBORS
With Pins
For electric drill sizes 1/2 to 6-7/8. Hardened mandrels for long thread
life. 118° split point pilot bit.
Unit# 2936028
KNOCKOUT PUNCH KITS
For use with 11 ton hydraulic driv-
ers in mild steel applications.
Includes standard round punches
and dies for 2-1/2 through 4 con-
duit and plastic case. Does not
include draw studs.
KNOCKOUT PUNCH KITS
Hydraulic Driver
For field use on construction sites and main-
tenance jobs. Can be used with most stan-
dard round Slug-Buster and Slug-Splitter SC
punches (not 1/2, 9/16 and 5/8). Will also
drive 751 cable cutter head. Can be used
with non-round punches.
KNOCKOUT PUNCH KITS
Hydraulic
1/2 through 2 conduit size slug-split-
ter SC knockout punch kit with
hydraulic ram and hand pump. Com-
pact design for use on construction
sites and maintenance jobs. Will also
drive 751 Cable cutter head.
KNOCKOUT PUNCHES
Slug-Buster.
Punches and splits slugs for easier slug
removal. Use with battery-powered,
hydraulic, ratchet or manual drivers.
Uses standard Greenlee dies and draw
studs. Includes punch, die and draw
stud.
Unit# 1728018
BULL PINS
Drop forged alloy steel construction. Features large striking surface and
even taper to reduce binding. Black rust-resistant finish. 13 length.
No. Desc.
49-22-8300 Electricians 5-pc. hole
saw kit
No.
Chuck
Size In. Shank Size In.
Thread
Size
31670 1/2 7/16 5/8-18
No.
Steel
Cap. Ga.
7304 10
No.
Hose
Size Ft.
7310SB 3
No.
Hose
Size Ft.
7506 3
No. Description
7211BB-1 Punches 0.492 to 2.520
No.
Point
Dia. In.
Head
Dia. In.
3255 5/16 1-1/4
Hand Tools
84 1-800-832-2297
Unit# 1728044
SHIP-AUGER BITS
Screw Point
Drills through nails, wood, vinyl, plastics and heavy timber. Heat-treated
steel construction with machine-ground flutes and polished edges. Fea-
tures feed-screw pilot, deep open-throat design, and 7/16 hex shank.
4 twist length.
Unit# 2936001
DRILL BITS
Nail Eater II®
Self-feeding screw point draws bit through wood. Heat-treated steel
construction; cuts through nails.
Unit# 4333002
HYDRAULIC TOOL
ACCESSORIES
Burndy®
No.
Size
In.
OAL
In.
53403 13/16 6
No.
Lgth.
In.
Hole
Dia. In.
66PT-1-1/8 18 1-1/8
No. Desc.
Adapters
LPHTADPMM71612 7/16 Quik chuck adapter; 1/2 square
Auger Bit
Insulated Hose
Couplers
Auger Bits  Dominator  7/16 QC
LPHTBIT111618D 11/16 dia. x 18 L
LPHTBIT111624D 11/16 dia. x 24 L
LPHTBIT131618D 13/16 dia. x 18 L
LPHTBIT131624D 13/16 dia. x 24 L
LPHTBIT151618D 15/16 dia. x 18 L
LPHTBIT151624D 15/16 dia. x 24 L
Insulated Hoses  8-ft. Length
LPHTHOSNCR66668 3/8 NPT ends
LPHTHOSNCR66668OP Direct connect
Insulated Hoses  10-ft. Length
LPHTHOSNCR666610 Whip set
PT29900-10 High pressure
Couplers
LPHTDRIPBODY66 Dripless body; 3/8 body x 3/8 NPT
LPHTDRIPBODY88 Dripless body; 1/2 body x 1/2 NPT
LPHTDRIPNOSE66 Dripless Nose; 3/8 body x 3/8 NPT
LPC38S Flush face set, body and nose;
3/8 body x 3/8 NPT
LPC12S 3/8, 1/2 NPT flush face coupler set - body
& nose
LPC38S
3/8, 3/8 NPT flush face coupler set - body
& nose
Sockets  1/2 Drive
LPHTSOC121/118 Dual socket; 1 x 1-1/8
Ground Rod Drivers
LPHTGRDVR11434 Ground rod driver,
1-1/4 hex, 3/4 rod
LPHTGRDVR11458 Ground rod driver,
1-1/4 hex, 5/8 rod
LPHTGRDVR11858 Ground rod driver,
1-1/8 hex, 5/8 rod
LPHTGRDVR134 Ground rod adapter, 1 Hex 3/4
LPHTGRDVR158 Ground rod adapter,
1 Hex 5/8
Batteries & Chargers
BAT14V Battery
BAT18V Battery
BCT/PATDCCHGR Charger for Patriot Tools
Miscellaneous Accessories
ALFLUIDGAL Hydrualic oil
L-250 Die for 60 Ton Press
No. Desc.
Hand Tools
1-800-832-2297 85
Unit# 1365001
SWIVEL ADAPTERS
Weatherhead®
Male straight thread to
female straight. Steel
construction.
ADAPTERS
Industrial finish. ASME/ANSI B107.10.
ADAPTERS
Compact size for access to tight quarters.
Chamfered drive end for easy drive engage-
ment. Replaceable square drive pin.
STUD ADAPTERS.
Unit# 1365002
90° STREET ELBOWS
Weatherhead®
For use with steel pipe in
high pressure applica-
tions. Brazed.
BATTERY PACKS
12VDC
For all Snap-on® CT and CDR Series 12VCD
tools and lights.
Unit# 1882010
BATTERY CHARGERS
NiCd
For use with Power Plus batteries. Plugs into
vehicle cigarette lighter. 1-hour charge time.
Unit# 1882011
CHUCK KEYS
For tightening 1/2 chucks.
Unit# 1882018
GRINDING WHEELS
A24R Type 27
1/4 thickness.
No.
Conn In.
NPSM x Thread
420528-131280 3/8 x 3/4
420531-131280 3/8 x 9/16
No. Description
GLA12B 1/2 Internal drive x 3/4 external
drive, 1-7/8 OAL.
No. Description
GLAS1E 3/4 Internal drive x 1/2 external
drive, 2-7/16 OAL.
No. Description
33967 3/4 Adpater F/Hydraulic
No.
Conn. In.
MPT x FPT
424291-131280 3/8 x 3/8
No. Description
CTB312 Battery pack
No. Volts
48-59-0186 12
No.
Pkg.
Qty.
48-66-3281 25
No.
Arbor
Size
Dia.
In.
49-94-4515 5/8-11 4-1/2
49-94-4585 5/8-11 4-1/2
49-94-7020 7/8 7
Hand Tools
86 1-800-832-2297
Unit# 4332001
EXTENSION CORDS
For indoor or outdoor applica-
tions. Features SJTW cord
with heavy-duty jacket and 3-
conductor ground. Yellow. UL
listed.
CONDUCTOR CLEANING
BRUSHES
V-Style
For use with shotgun sticks. Features stain-
less steel bristles, 3 dia. hand guard, thermo-
plastic contoured handle, raised ribs to
engage shotgun head slots, and molded eye.
Conductor Cleaning Brushes
Accessories
BRUSH SETS
Grip Cleaning
Set of four wire-bristle brushed designed for
cleaning Klein wire- and cable-pulling grips.
Brushes have stiff wire bristles. 12 and 14
lengths.
Unit# 4329007
FUSE CUPS
Universal
For changing 100A or 200A fuses. Fiberglass
construction. Features V-guide design and
aluminum disconnect prong. Safety yellow
color.
Unit# 3881011
TAGGING DEVICES
For tagging opened dis-
connect switches. Con-
structed of Salcor®
elastomer. Allows Hold
cards to be placed on cir-
cuit. Fits over heads of 1-1/
4 and 1-1/2 switch sticks.
Orange.
Unit# 1728064
BENT TRIMMERS
For cutting plastic, rubber, roofing compo-
nents, cording, vinyl, fiberglass and cloth
materials.
Replacement Blades
Unit# 1647001
WATER COOLERS
Industrial
Features foam insulation, FDA-grade liner,
recessed spigot, double-walled lid, and mount-
ing bracket for cup dispenser. OSHA-standard
Drinking Water imprint. Yellow and red.
Water Coolers
Accessories
No. Ga.
Lgth.
Ft.
0712322 12 50
No. Desc.
10-178 Dual purpose
10-180 Universal
No. Desc.
Pkg.
Qty.
10-179 Replacement brush 10
No. Description
25450 Includes (2) round and
(2) square brushes
No. Desc.
10-094 Fuse cup
No.
Slot
Lgth. In.
Cup
Dim. In.
Overall
Dim. In.
TD 7.25 2.13 x .63 2.5 x 1.75
No.
Cut Lgth.
In.
OAL
In.
23008 3-1/2 9
23010 4-1/2 10-1/2
No.
For
Shear No.
RS1B RS1
RS2B RS2
No.
Size
Gal.
5207431 3
No. Desc.
5207-9759
Cooler
rack w/
1/2 cinch
strap
Hand Tools
1-800-832-2297 87
Unit# 4325001
THREE STRAND ROPE
Polyxtra®
Features polyester strand cover wrapped
around polypropylene strand core. Resists
degradation from UV light. 600-ft. length.
Unit# 2483001
ROPE
Polyester/Polypropylene  Magnus
Three-strand design combines blended poly-
ester/polypropylene cover over polypropylene
core. Resists chemicals, abrasion and UV
exposure.
Unit# 1632031
HAND LINE BLOCKS
Chance®
Features high dielectric, fiber filled natural
nylon shell and sheave; silicon bronze shaft
and oil impregnated bronze sheave bearings.
Rated to 3500 lbs. Includes 150-ft. of 1/2 dia.
composite fiber braided rope.
Unit# 1260010
HAND LINE BLOCKS
Aluminum alloy construction. Features free
running sheave with 7/8 line capacity, bronze
Oilite® bearings, closed head swivel ring,
quick opening snatch with pull pin, and forged
steel safety sliphook.
Unit# 4329026
HAND LINE BLOCKS
High dielectric block and sheave construction
with nylon fiberglass reinforcement. Features
1/2 dia. axle and swivel bearings. Accommo-
dates rope to 5/8 dia. 1000 lbs. working load
capacity.
HAND LINE BLOCKS
Blocks without ropes and hooks. Light galva-
nized steel and aluminum alloy. Sheaves have
bronze bushings.
No. Dia.
Tracer
Color
Working
Load Limit
Lbs.
14050 3/8 Orange 356
14055 3/8 Black 356
14100 1/2 Orange 57.8
14105 1/2 Black 57.8
14149 5/8 Orange 801
14147 5/8 Black 801
14217 3/4 Black 1103
No.
Dia.
In.
Lgth.
Ft.
R8932S0600 1/2 600
We offer additional sizes
and styles.
Call for information.
No. Desc.
T4001258 Double & triple blocks
No.
Working Load
Limit Lbs.
404B2PJ 2500
No. Desc.
3550 Side opening block w/ swivel
hook and safety snap
3551-1 Closed block with swivel meat
hook
No. Description
267 Plain block
H267 Same as 267, but nose extends
over keeper
268 Same as 267 but with eye to splice
line to block and rope tie-off
3550 3551-1
H267
267
Hand Tools
88 1-800-832-2297
BLOCK & TACKLE
Blocks with standard snap hooks. Includes 25 of
3/8 rope, block with snap hook and a detach-
able forged anchor hook on one end, and block
with eye and rope tie-off on other end. Not occu-
pational protective hooks and not for human
support. Maximum safe load 750 Lbs.
ADJUSTABLE
POSITIONING LANYARDS
Secondary Device
UL Classified life safety rope with red center
indicator threads. Features self-closing and
self-locking snap hooks for ease of use with
gloved hands. Includes storage hook.
WIRE TOOLS
Howe
Constructed of tough nylon webbing strap and
forged steel hook with large opening. Max.
safe load 500 lbs.
Unit# 3871007
HAND LINE HOOKS
Nylon construction. Designed to straighten
with 14 to 18 lbs. of pressure freeing handline.
SNAP HOOKS
No. 443A. General-purpose forged snap hook
with eye at 90° to opening.
No. 455. Heavy-Duty. Snaps on with one
hand. Forged hook may be used on many
conventional steel blocks 4 or smaller.
RIPPING BARS
No. 66380. Heat-treated claws for extra
strength. Features double-claw design, baked
on black finish for rust resistance, and one V
nail puller.
No. 66384. Forged spring steel 1/4 thick and
1-1/2 wide. Features sandblasted finish, pry
edge and V nail puller on both ends, one end
curved, the other at 90° angle. Keyhole nail
puller in body.
HEX BARS
Provides extra leverage when positioning steel
members and aligning bolt holes. Forged fit-up
bar is pointed on one end. Chisel end at 15°
angle.
No. Description
1802-30 Blocks with standard snap
hooks.
1802-30SR Same as 1802-30 but with
rope spliced to block
1802-30S
Sames as 1802-30 except
suplied with adetachable
swivel anchor hook instead
of hook
1802-30SSR Same as 1802-30S but with
rope splieced to block
H1802-30S
Blocks w/guarded snap
hooks except supplied with
a detachable swivel anchor
hook instead of hook
H1802-30SSR
Blocks w/guarded snap
hooks but with rope spliced
to block
No.
Max.
Lgth. Ft.
SEC-5295 8
No.
Nylon Strap
Size
1702-20N 1 x 7
No. Desc.
2402 Handline hook
Check our website for
special promotions.
www.uscco.com
No.
Eye
I.D. In.
OAL
In.
Max. Safe
Load Lbs.
443A 1 5-1/2 1500
455 15/16 5 8000
No. Description
OAL
In.
66380 Carbon steel 18
66384 Spring steel, 14
No.
Hex
Dia. In.
Lgth.
In.
3242 3/4 30
3244 3/4 24
66380
Hand Tools
1-800-832-2297 89
TAPE THONG
Leather strap with fiber bar. Fits all standard electrical tape rolls.
PVC BLANKETS
Wrap blanket around PVC, secure with hook and loop strap. Built-in
stiffeners keep blanket tight to PVC surface. Heavy-duty cord and ther-
mostat for long life. Over 300° F. 120 VAC.
DATA CABLE CADDY
Ideal for large diameter spools of coax, data and communications
cable. Folds down for easy storage.
FISH LINE
Conduit-Bonded Nylon
Strong, lightweight nylon. Specially wound to payout fast from outside
without tangles. Use with might mouser blow gun. Mildew-resistant.
No. Belt Connection
Lgth.
In.
5130 Slotted 12
No. Watts Dim. In.
860-3 800 30 x 13-1/4
860-4 1300 38 x 16-1/4
No.
Maximum Total
Spool Wt. Lbs.
Dim. In.
LxWxH
9520 100 21 x 28-1/2 x 11-1/2
No.
Tensile
Strength
Lgth.
Ft.
595 85 Lb. breaking strength 2,150
Hoists
90 1-800-832-2297
Unit# 4329048
STRAP HOISTS
Linemens  Hook®
For two-way, dual capacity rigging in hot line applications. Features
cast aluminum housing, reversible fiberglass handle with overload
warning break, 360° swivel hooks with safety latches, stainless steel
springs, bronze bushings, aluminum winding wheel, and double inter-
locking pawl system. Includes hot stick rings on all hooks, and quick
disconnect shaft. Meets ANSI requirements.
Unit# 1632002
RATCHET HOISTS
Link-Chain Style  Chance®
Ratchets in full or half link increments.
Heat treated aluminum handle and
sheave housing with fully enclosed work-
ing parts. Features two-way handle, alloy
steel chain, 360° swiveling forged steel
load hooks with spring loaded latches,
shift key on top housing, and release key
in handle recess. 90 lbs. handle pull at
specified rating. 11 minimum hook-to-
hook. Meets ANSI specifications.
Unit# 1632029
RATCHET HOISTS
Nylon Strap  Chance®
Features plastisol cap on handle end and hot stick rings on hooks and
latches. 17 minimum hook-to-hook distance. 5 9 standard lift dis-
tance.
Note: Not an insulated live-line tool.
RATCHET HOISTS
RA Model  Coffing
Aluminum ratchet lever hoists utilize a ratchet and pawl design. The RA
is ideal for transmission and distribution utility applications where a disc
brake mechanism is not desirable. Features free chaining mechanism
for one-handed take-up and positing of slack chain, handle stops, and
multiple rigging options. Hoist can lift, pull or bind.
Single Line Double Line
No. Cap. Lbs. Lift Ft. Cap. Lbs. Lift Ft.
EH153-10 1500 10 3000 5
EH24-12 2000 15 4000 7.5
No.
Rating
Tons
3011S 1
4012 2
EH153-10 EH24-12
3011S 4012
No.
Rating
Tons
PSC3090323 1
No.
Rating
Tons
RA-15-10 3/4
RA-30-3 4-1/2
Hoists
1-800-832-2297 91
RATCHET HOISTS
Model LSB-B  Coffing
Lightweight, durable and
ideal for construction and
commercial applications.
Compact design is portable
and easy to rig. Features
impact resistant, stamped
steel housing, double reduc-
tion gearing, short cush-
ioned grip handle, free
wheeling mechanism and
latches on hooks for positive
load engagement. Metric
rated.
STRAP HOISTS
Linemans  Little Mule
Features standard hooks
with safety latches.
RATCHET HOISTS
G Series  Coffing
Malleable iron roller chain
ratchet lever hoists are effi-
cient and durable. Roller
chain can be spliced to cre-
ate longer lifts and can han-
dle higher capacities than
coil chain. G Series hoists
are ideal for utility transmis-
sion and distribution work.
Features free chaining, han-
dle stops and single or dou-
ble locking pawl design.
Unit# 2980001
WEB STRAP HOISTS
Features aluminum alloy frame, double inter-
locking pawl mechanism, breakable stress link
overload indicator, self-lubricating bearings,
steel latching hooks, and reversible 30 fiber-
glass handle. Open design allows visual
inspection. 1-ton capacity (double line).
CABLE HOISTS
Medium frame cable ratchet winch pulley
hoist. Features drum anchor for full extension
of cable, reversible handle, cable end with
hydraulically crimped copper sleeve and inter-
locking pawl system that will not slip. Self-stor-
ing aircraft cable with self lubricating bearings.
Unit# 4315001
TSE International, Inc.
PULLING EYES
For use with guy grips or strand vises. Fea-
tures large offset eye to accommodate 3-ton
chain hoist hooks. Fits 1-1/4 rods.
Unit# 4316001
Tulsa Power Products, Inc.
REEL LIFT TOOLS
Reel Thing®
For use in warehouse or field applications.
Load rating stamped on tool.
No. RT40. Features flipping mechanism for
safe flipping of reel from rolling to non-rolling
position.
F.D. Lake Company
CHAIN
For overhead lifting. Allows user to reduce
chain size and weight, and still lift comparable
loads. Heat treated alloy steel with standard
finish.
No. Lift
Rating
Tons
LSB-1500B-10 10 3/4
LSB-1500B-15 15 3/4
LSB-3000B-10 10 1-1/2
LSB-6000B-10 10 3
No.
Strap
Lgth. Ft.
Cap.
Lbs.
300A 14 1500
322B 15 1500
344B 12 2000
No.
Rating
Tons
ATG 1-1/2
ATGI 1-1/2
FTGI 3
ZG-6 6
No. Desc.
2A Latching hooks
2B Hot stick rings & latching hooks
No.
Lifting
Height Ft.
Cap.
Tons
4000-20 10 to 20 2
We offer all load rated
chains and lifting
straps.
Call for information.
No.
Working
Load Lbs.
E-96 6000
Arbor Size In.
Load
Rating.
No. Min. Max. Lbs.
RT40 3 6 4500
RT60 2-5/8 6 12,000
No. Description
Size
In.
30360 Grade 10 3/8
RT40 RT60
Hoists
92 1-800-832-2297
F.D. Lake Company
CHAIN SLINGS
Alloy
Grade 10 is the most durable of all sling types.
Grab hooks on both ends. Resists sharp
edges and abrasions and is suited to harsh
environments.
CHAIN SLINGS
Alloy
Grade 10 is the most durable of all sling types.
Oblong master links on both ends. Resists
sharp edges and abrasions and is suited to
harsh environments.
WIRE ROPE SLING
Ideal for heavy loads and rugged conditions.
Mechanically spliced eyes for greater strength.
NYLON WEB SLINGS
Heavy Duty
Flexible, lightweight, durable and adjusts to
load contours. Holds with secure grip and will
not damage most load surfaces.
AIRCRAFT CABLE
Galvanized
For use on aircraft controls, window and door
closures, and boat rigging. 7 Strand. Corro-
sion resistant.
SCREW PINS
Working load limit permanently shown on
shackle. Forged steel construction with alloy
pins.
CLEVIS GRAB HOOKS
High TestLever Length: 14-9/16.Grade 7 car-
bon steel construction. Used for load tie down,
towing, farm, and general purpose applica-
tions.
THIMBLES
Heavy Duty
Rugged thimble for heavy
duty service. Galvanized
steel construction.
SCREW EYE BOLTS
Shoulder style eye bolt.
Forged galvanized steel con-
struction.
RATCHET
BINDERS
One-man operation with-
out kickbacks. Continu-
ous take-up and infinite
adjustment to secure
loads as tightly as possi-
ble. Drop forged tem-
pered steel construction.
SNATCH BLOCKS
Forged alloy steel construction. Features inter-
changeable hook and shackle assemblies and
bolt retaining spring. Rope may be inserted
while block is suspended.
No. Description
Size
In.
37176 9/32 x 8 9/32
37196 3/8 x 8 3/8
37203 3/8 x 16 3/8
37212 1/2 x 4 1/2
37214 1/2 x 6 1/2
37218 1/2 x 10 1/2
No. Description
Size
In.
37593 3/8 x 5 3/8
37594 3/8 x 6 3/8
37595 3/8 x 7 3/8
37596 3/8x8 3/8
37614 1/2 x 6 1/2
37618 1/2 x 10 1/2
No. Description
Size
In.
20120-FD LAKE 1 MLL 3/8 x 6 3/8
No. Description Width In.
50671 IPE 12 2 x12 2
IPE21X2 IPE 21 1 x 2 1
No. Description
Size
In.
10860 3/8 7x19 GAC wire rope 3/8
No.
Working
Load Limit (tons)
Size
In.
40405 21/2
No.
Working
Load Limit (tons)
Nom. Chain
Size In.
40830 6,600 3/8
We offer all cable slings
and shackles.
Call for information.
No.
Rope
Dia. In.
40930 3/8
No. Size In.
42314 FD 1/2 x 3-1/4
No.
Min-Max
Chain Size In.
42365 FD 5/16 to 3/8
No.
Wire Rope
Size In.
Sheave
Dia. In.
42410 3/8 to 1/2 4-1/2
42430 5/16 to 3/8 3
Hot Sticks
1-800-832-2297 93
Unit# 4329050
TELESCOPIC HOT STICKS
Triangular  Tel-O-Pole II
Heavy-duty, no-twist triangular design. Alu-
minum alloy head construction with corona
discharge design and captive Belleville
washer for use with universal attachments.
Feature fluorescent tip section for visibility,
foam core, removable sections with lock but-
ton, and base end cap. Smooth glossy finish
for ease of cleaning and waxing. 1.15 section
dia. Meets OSHA and ASTM specifications.
Unit# 4329051
TELESCOPIC HOT STICKS
Round  Tel-O-Pole
For use in opening and closing disconnect
switches, replacing fuses, pruning tree limbs
and replacing lamps and street light circuits.
Reinforced electrical grade fiberglass con-
struction. Features corona discharge head,
retractable tip, sure lock joints, and disconnect
hook. Tip measures 1-3/32 retracted; 7/8 dia.
extended. Meets OSHA and ASTM specifica-
tions.
Unit# 4329049
TELESCOPIC STICKS
Measuring  Tel-O-Pole
Triangle design. For use in opening and clos-
ing switches, disconnects, line fuses, and cut-
outs and measuring elevated heights. Fea-
tures standard English graduations printed in
large, red numbers for easy viewing. Tip mea-
sures 1.15 dia. 68 minimum length. Meets
OSHA and ASTM specifications.
Unit# 1632008
HOT STICKS
Grip-All
For installing hot-line and ground lamps in
overhead and underground circuits. Epoxi-
glas® pole sections with Lexan® head and
metal hook and actuator. Features sliding
hand grip to open hook and thumb latch lock
release. 1-1/4 dia.
Unit# 1632012
SECTIONAL DISCONNECT
EXTENSIONS
For 1-1/4 dia. poles. Features female fitting at
top and male fitting at bottom.
Unit# 1632013
WIRE-HOLDING STICKS
For use on or around energized lines for form-
ing, bending and jumper wire applications.
Accommodates #6 solid copper through 1590
kcmil ACSR conductors. Epoxiglas® construc-
tion. Features gripper with eye, knurled nut at
control lever, and 3-position locking head.
Unit# 3881006
SWITCH STICKS
Double Ended  Universal
Foam-filled fiberglass reinforced plastic con-
struction. Meets ASTM specifications.
Unit# 4329029
SWITCH & DISCONNECT STICKS
Woven fiberglass construction with safety yel-
low epoxy finish. Features high tensile cast
bronze head. 1-1/4 pole dia. Meets OSHA
and ASTM specifications.
Unit# 4329022
DISCONNECT STICKS
Adjustable
For use in substation applications. Adjusts in
one foot increments. Features conventional 1-
1/4 dia. hot stick with fire retardant unicellular
core, 1-1/2 base section, and universal head.
Extended length is shown at each lock posi-
tion. Meets OSHA and ASTM specifications.
Lgth. Base
No. Min. In. Max. Ft. Dia. In.
HV-208 26 8 1.75
HV-216 60 16.75 1.61
HV-225 64 25.5 1.91
HV-235 68 35 2.22
HV-240 69 39.5 2.38
Lgth. Base
No. Min. In. Max. Ft. Dia. In.
ST-230 61-5/8 30 2-3/8
ST-235 63-3/8 35 2-11/16
ST-240 65-3/8 40 2-7/8
Lgth. Base
No. Max. Ft. Dia. In.
EV-30 30 2.07
EV-35 35 2.22
No.
Lgth.
Ft.
C4030292 6.66
C4030293 8.58
No.
Lgth.
Ft.
C4032063 6
No.
Dia.
In.
Lgth.
Ft.
C4033069 1-1/4 8.42
No.
Dia.
In.
Lgth.
Ft.
4231 1.25 8
No.
Lgth.
Ft.
Switch Head
460-4 4
460-6 6
Disconnect Head
461-4 4
461-6 6
Lgth. Ft.
Min. Max. Collapsed
3120 12 18 10.33
Switch Head Disconnect Head
Hot Sticks
94 1-800-832-2297
Unit# 4329024
INSULATED LINK STICKS
Spiral  Heavy-Duty
Provides insulation between energized con-
ductors and rope lines, hoists and rope blocks.
Fiberglass construction with unicellular foam
core. Features attached lifting eye and high
strength heat treated steel spiral hook. Maxi-
mum wire size 795 ACSR. Meets OSHA and
ASTM specifications. 2000 lb. maximum work-
ing load.
Unit# 4329023
INSULATED LINK STICKS
Isolated  Strap Hoist
Provides protection with using strap hoists on
primary voltages. Fiberglass construction with
solid foam core. Features standard swivel eye
and safety hook. 4000 lb. maximum working
load. Meets OSHA and ASTM specifications.
Unit# 4329043
SHOTGUN STICKS
Telescopic
Electrical grade fiberglass construction. Fea-
tures sure lock joints; extended length spear,
polycarbonate head with 5 deep throat and
molded hanger hook; dirt and moisture-resis-
tant rod guide; polycarbonate handle body;
plastic protective sleeve; full open side hook;
shielded hook release trigger; 13 TPI cast
slide for firm grip, and universal base end with
insulated rubber cap. 6-1/2 ft. retracted length.
Meets OSHA and ASTM specifications.
Unit# 4329042
SHOTGUN STICKS
Fixed Length
Electrical grade fiberglass construction. Fea-
tures extended length spear; polycarbonate
head with 5 deep throat and molded hanger
hook; dirt and moisture-resistant rod guide;
polycarbonate handle body; plastic protective
sleeve; full open side hook; shielded hook
release trigger, and 13 TPI cast slide for firm
grip.
Nos. 8106-U, 8108U & 8206U. Feature uni-
versal base end.
Unit# 4329044
SHOTGUN STICKS
Triangular  HV Series
Electrical grade fiberglass construction. Fea-
tures extended length spear; polycarbonate
head with 5 deep throat and molded hanger
hook; dirt and moisture-resistant rod guide;
polycarbonate handle body; plastic protective
sleeve; full open side hook; shielded hook
release trigger; 13 TPI cast slide for firm grip,
and internal operating rod.
Nos. 8306-U & 8308-U. Feature universal
base end.
Unit# 1632023
HOT STICK HANDLES
Chance®
Epoxiglas® and aluminum construction. Fea-
tures (2) heads and thumb screw on spline for
tool attachment. Spline allows up to 90°
angling.
No. H17908. Features pole hanger.
Handles
Accessories
Unit# 4329030
EXTENSION ARMS
Fiberglass
For use with distribution cross arms as tempo-
rary aid in reconductoring existing lines and
insulator replacements, or in moving out con-
ductors to obtain working clearance. Features
solid unicellular foam core, (2) conductor hold-
ers, and silicon bronze eye bolts and nuts.
Resists damage from UV light. Fits cross arm
up to 4-1/4Wx6-3/4 H. 150 lb. safe working
load per conductor holder. 6-ft. length.
No. 5007. Features insulator.
No.
Pole Dim. In.
Dia. x Lgth.
OAL
In.
3480 1x12 24
3481 1x24 36
No.
Lgth.
In.
3414 6
3414 12
No.
Operating
Lgth. Ft.
81611 6-1/2, 8, 9-1/2 & 11
81611-97 8, 9-1/2 & 11
No.
Lgth.
Ft.
External Operating Rod
8106-HASTINGS 6-1/2
8106-U 6-1/2
8108 8-1/2
8108U 8-1/2
Internal Operating Rod
8206 6-1/2
8206U 6-1/2
8208 8-1/2
No.
Lgth.
In.
8306 6-1/2
8306-U 6-1/2
8308 8-1/2
8308-U 8-1/2
External Operating Rod
Internal Operating Rod
No.
Dia.
In.
H17603 1-1/4
H17908 1-1/2
No. Desc.
H4455 Head only
No.
Wt.
Lbs.
5006 14-1/2
5007 15-1/2
5016-1 15-1/2
Hot Sticks
1-800-832-2297 95
Unit# 4329047
HOT STICK ACCESSORY HEADS
Universal
Adapts universal fit-on tools to existing sticks.
Unit# 4329006
FIBERGLASS FINISH WAX
High-grade carnuba formula for use on
booms, aerial lift buckets and hot sticks.
Weather resistant. 14 oz.
Unit# 4329010
HOT STICK WIPES
Removes dirt, oil, creosote and other contami-
nates from hot sticks. Leaves silicone mois-
ture barrier to promote water bead up in wet
conditions. Individually packaged in dispenser
box.
Unit# 1632006
HOT STICK WIPES
Moisture Eater II
For daily cleaning of insulated hot line tools,
line hose and rubber blankets. Pre-moistened,
lint-free towel in foil packet.
Unit# 1632007
HOT STICK WIPES
Silicone
Removes dust from hot line tools. Deposits
thin coat of silicone to protect against dust and
airborne contaminants. Lint-free 8 x 10 towel
in foil packet.
ALL PURPOSE CLEANER
For cleaning hot line tools, trucks, buckets,
booms, rubber goods, rigid cover up, painted
surfaces and aluminum metal, shop machin-
ery, hand cleaner and all plastic surfaces. Bio-
degradable, non-toxic, non-acid, non-
flammable.
FIBERGLASS CLEANING &
REFINISHING KIT
Used to clean and/or restore fiberglass hot
sticks, booms, and buckets. Includes All pur-
pose cleaner, ultra fine non-metallic abrasive
pads, clear epoxy refinishing kit, and silicone
treated wiping cloths.
No.
Fits Stick
Dia. In.
A10017-R 1-1/4
No.
Pkg.
Qty.
10-091 1
10-091-1 6
No.
Pkg.
Qty.
10-188 50
No.
Pkg.
Qty.
C4002538 50
M1904 1
No.
Pkg.
Qty.
C4002568 50
Visit our Web Site at
www.uscco.com
for our full line card.
No. Description
10-169 Premixed, 1 gallon
10-172 Premixed, 1 case (6 gallons)
10-168 Concentrate, 1 gallon
10-194 Concentrate, 1 case (6 gallons)
No. Description
10-171 Complete cleaning kit
10-170 Box of 20 ultra fine non metalic
pads
Hot Sticks
96 1-800-832-2297
ALL PURPOSE CLEANING KIT
6-Pack  Concentrate
Includes (6) 7 oz. ready to mix plastic containers of concentrated all
purpose cleaner, (14) ultra fine non-metallic pads, (6) large adhesive
backed identification labels to affix to gallon containers after mixing.
CONDUCTOR CLEANING BRUSHES
For tight clearances and easy storage. All brushes have stainless steel
bristles to allow the cleanest connection possible.
Unit# 1632025
HOT STICK PATCHING KITS
Epoxiglas® Bond  Chance®
For repairing small surface rup-
tures on hot sticks, installing new
ferrules on poles, or replacing
rungs on ladders. Includes hard-
ener, resin and mixing stick.
Orange.
Unit# 3881008
HOT STICK BAGS
For storage of 8-ft. long hot sticks. Heavy vinyl construc-
tion with double stitched seams and snap closure flap.
Orange.
Unit# 3881005
CLAMPSTICK REPAIR PARTS
External Rod
No. Description
10-197 Six-Pack cleaning kit
No. Description
Standard U Brush
10-175 8 SOL 500 MCM
10-183 8 SOL 954 ACSR
Compact U Brush
10-184 8 SOL 500 MCM
Universal U Brush
10-176 8 SOL 500 MCM
10-186 8 SOL 954 ACSR
10-175
10-184
10-176
No. Desc.
H1917 Hot stick patching kit
No.
Length
Ft.
4301 8.33
No.
Fig.
No. Desc.
20260-SALISBURY N/A Roll pin .125 dia. x .5 L
20262 8 Roll pin .125 dia. x .56 L
20251 9 Operating rod connector
20258-SALISBURY 10 Hex socket set screw .375-16
x 1.25
20253 12 Adjustment block
1959 24 End cap
Hot Sticks
1-800-832-2297 97
HOTSTICK ACCESSORIES
Universal
Unit# 3881005
No. Description
5454-2 Universal ball socket fork
5454-6 Universal 90° adapter
5454-5 Universal crescent skinning knife
5454-3 Universal ball peen hammer
5454-7 Universal hack saw
5455-8 Universal cotter key puller
5455-21 Universal cotter key installer-puller
5455-15 Universal locating pin
5455-29 Universal ball socket adjuster
5455-99 7 Universal vise grips
5455-98 10 Universal vise grips
5455-25 Universal paint brush
5455-28 Universal screw driver
5455-6 Universal ratchet wrench
5455-6
5455-2
5454-5 5455-25
5455-37 5455-35
5455-98
5455-3
5455-7
5455-8
5455-21
5455-98
5455-15
5455--29
5455-28
Hot Sticks
98 1-800-832-2297
Unit# 4329031
CONDUCTOR SUPPORTS
Pole-Mounted
Foam filled fiberglass construction treated to protect against electrical
and UV damage. Features (2) conductor holders, (2) insulators, 2 W x
44 L nylon strap and heavy-duty ratchet binder with extra wide handle.
150 lbs. safe working load per holder.
Unit# 4317001
DISCONNECT HOOKS
Universal  LitFinger
For use with hot sticks. Aluminum
construction. Features pointed head
for breaking ice or debris, notched
straight arm to secure fuse, curved
arm for hanging, LED light, high-low
switch, and sealed borosilicate win-
dow. Waterproof to 1 meter.
Requires (3) AAA alkaline or lithium
batteries.
Unit# 1632028
DISCONNECTS
Chance®
For opening and closing switches, and opening enclosed cutouts.
Unit# 1632010
DISCONNECT TOOLS
Telescoping
For disconnecting switches, replacing cutout tubes, removing pole cov-
ers and pruning trees from ground level. Epoxiglas® construction. Fea-
tures heavy-duty spring loaded plastic buttons, universal end fitting,
and insulated top section. 1-1/16 dia. tip. Meets OSHA requirements.
* Can be locked at each length.
Unit# 1632026
TREE TRIMMERS
Chance®
For use with hot sticks. Features forged steel stationary and
moving blades, and rope and pully mechanism. Cuts up to
1-1/2 dia. branches.
Unit# 4329027
TREE TRIMMING KITS
Includes pruner head assembly, (4) extension sections with base cap,
universal pruning saw, saw handle, universal adapter for extension sec-
tions, universal S-type wire handling hook, and heavy-duty vinyl tool
bag.
No.
Max.
Voltage kV
Lgth.
In.
Wt.
Lbs.
5040 15 48-1/2 15
5041 34.5 48-1/2 16
No.
Dim. In.
LxWxD
LITFINGER 5.7 x 4.9 x 0.9
No. Desc.
M44559 Aluminum
No.
Base
Dia. In.
Extended
Lgth. Ft.*
Retracted
Lgth. Ft.
C4031019 1-7/8 12-1/2; 16-1/2; 20 61
C4031020 2-1/16 16-1/2; 20-1/2; 25 63
C4031021 2-1/4 17-1/2; 21-1/2; 25-1/2; 30 65
No.
Length
In.
H21064 18
No.
Pole
Size
Section
Lgth. Ft.
4142 Round pole 1-1/4 Dia. 6
4143 Square pole 1-1/4 4
Hot Sticks
1-800-832-2297 99
Unit# 4329032
IMPACT ELBOW PULLERS
For installation and removal of elbow connec-
tors on transformers, and switch gear. Con-
structed with fiberglass operating rod and
metal components. Features spring-loaded
operating rod with positive latch feature, plasti-
sol coated slide handle, and positive grip. 6-ft.
length.
Impact Elbow Pullers
Elbow Grippers
Unit# 4329033
CROSS ARM GINS
Convertible
Aluminum alloy base assembly with reversible
plates for use with 3-1/2 W x 4-1/2 H or 4-3/4
W x 5-3/4 H cross arms. Aluminum plate sup-
port on base prevents cross arm damage.
TOOL ACCESSORIES
Universal
NOTES
No. Desc.
5327 Without gripper
5327-1 With torque handle
No. kV
5330 15
5331 25
5332 35
No.
Mast Dim. In.
ODxL
5571 3x58
5327-1
No. Description
M1942 47 Chain for two-pole strain
carrier
M44552 Pin holder
M445510 Chuck blank with 5/8 opening
M445512 Snapout cotter key remover
M445515 Locating pin
M445516 Folding rule
M445519 Cotter key pusher
M445522 Ball socket adjuster
M445523 Hack saw
M445525 Paint brush
M445528 Screw driver
M445536 Link stick head
M445538 Clear vision mirror
M445539 Shepherd hook
M445540 Fixed blade tie stick head
M445546 Flexible wrench head
M445550 Skinning knife
M445567 Adjustable insulator forks
M445569 Rotary prong tie stick head
M445570 Rotary blade tie stick head
M445577 Fuse puller, 1/2 to 1-1/2 fuse
M445578 Fuse puller, 1-1/2 to 2-1/2 fuse
M445579 Spiral disconnect
M445582 All-purpose cotter key tool
M445584 Universal adapter
M445585 Hammer
M445587 Ball socket adjuster
M445588 Bolt head wrench
M445596 Cotter key puller
Meters & Testers
100 1-800-832-2297
Unit# 2573007
FAULT LOCATORS
Cable/Pipe  Dynatel
For locating cable/pipe paths and conductor or
sheath faults, measuring cable/pipe depth,
and locating energized power and CATV
cable. Transmitter measures 6.75 H x 11.25
W x 7.75 D and requires (6) C-cell batteries;
receiver measures 10.25Hx10.5 W x 30 D
and requires (8) AA batteries.
CABLE DISTANCE METERS
Measures cable sag, cable height distance
and overhead clearance of conductors. Uti-
lizes ultrasonic signals to determine the height
of over cable up to 75 ft. Features 3-button
operation and low battery indicator.
CABLE DISTANCE METERS
3-Phase
Identifies correct phases on long lengths of
de-energized and discharged overhead and
underground cables. Includes sender and
receiver designed to be hand held with or with-
out gloves.
Unit# 4290002
PHASING VOLTMETERS
PD Series®
Multi-function design for use on primary or
secondary voltages or capacitive test points.
Features 3/4 backlit LCD meter, 5-position
selector switch, shielded housing and inter-
connect cable, and impact/wear resistant
probes. Accurate to ±1%.
Unit# 4290003
PHASING VOLTMETERS
Cordless
For use with 208V to 69kV distribution sys-
tems (direct contact) or 69kV to 800kV trans-
mission systems (non-contact; degree position
only). Features reference probe (transmitter)
and meter probe (receiver) with color-coded
LED indicators and 5-position selector switch.
Impact- and wear-resistant. Meter probe fea-
tures backlit digital display.
WIRELESS PHASERS
Tag®  Cordless
Designed to perform many of the existing
functions of conventional voltmeter/phaser
devices but is lighter weight and cordless.
Consists of 2 units, a transmitter and receiver.
Features built-in universal splines, clear in-
phase/out-of-phase indicators, overhead
probes, and carrying case.
Unit# 4290001
VOLTAGE DETECTORS
Non-Contact
For under-
ground and
overhead appli-
cations. Fea-
tures audible
(horn) and
visual (LED)
indicators, test
setting, over-
voltage protec-
tion, and grip
adapter.
No. Watts
2273MIDUU3WRT 3
No. Description
CDM-75 Cable Distance Meter
No. Description
3ID-100 Cable Tester/Identifier
No. Positions
PD25U Off-2kV-20kV-25kV-Test
PD50U Off-2kV-25kV-50kV-Test
No. Positions
PD800WU Off-Deg-URD-OH-Test
No. Description
TAG-5000 TAG® Wireless Phaser
No. Desc.
AV40U Voltage detector
Check our website for
special promotions.
www.uscco.com
Meters & Testers
1-800-832-2297 101
Unit# 4290004
VOLTAGE DETECTORS
Dual Application  Analog
For proximity or direct contact use on over-
head or underground systems. Detects 0 to
40kV line to ground; 0 to 69kV phase to
phase. Features analog scale, 5-position
selector switch, internal overload protection,
and backlight for use in low light. Water resis-
tant. Includes carrying case.
Unit# 4290005
VOLTAGE DETECTORS
Wide Range  Analog
For overhead or underground applications.
Detects 2.4kV to 450kV line to ground; 4kV to
765kV phase to phase. Requires no voltage
scale selectors or multipliers. Features linear/
logarithmic scale, backlight and hold function.
Water resistant. Includes carrying case.
VOLTAGE INDICATORS
Single point instruments designed to read the
voltage on a conductor up to 500kV line-to-
ground. Features large LED readout and built-
in universal spline for standard hotstick attach-
ment.
VOLTAGE INDICATORS
Features coil cord rated at 10kV and mea-
sures 3.6 retracted and 12 fully extended.
Accuracy 3% of full scale. Universal splines.
No. MARK-V. For phase-to-phase and phase-
to-ground measurements.
No. EM-1. For phase-to-ground measure-
ments only.
STRAY VOLTAGE DETECTORS
Used to detect stray voltage as low as 5 volts
on light poles, guide wires, meter cans, man-
hole covers and other metallic surfaces
around electrical utilities. 5 VAC to 600 VAC
with direct contact and above 600 VAC at a
distance. Features bright LED and tester built-
into the holster.
VOLTAGE PROXIMITY
DETECTORS
Detects voltages 10 or greater from source
and most elbow test points. Features
rechargeable battery with quick recharge, (9)
standard voltage ranges from 120 VAC up to
500 kVAC, and loud beeper and LED lights to
indicate voltage.
MULTIMETERS
Digital  Clamp-On
Features direct readings of ground resistance,
continuity and ground loop resistance and
ground leakage. Features auto-off and alarm
and memory functions.
No. Positions
VDA040PU P-URD-OH-x4-Test
No. Desc.
VDAH450U Wide range voltage
detector
No. Voltage
DVI-100 0.1kV to 99kV
DVI-500 0.1kV to 500kV
No. Description
MARK-V Dual Stick
EM-1 Single Stick
CM/100/V Case
No. Description
LV-S-5 Stray Voltage Detector
No. Description
PRX-500 Voltage Proximity Detector
No.
Ground
Resistance
Ohms
3731 0.01 to 1200
Meters & Testers
102 1-800-832-2297
Unit# 2851046
CLAMP MULTIMETERS
Small body and jaws fit into tight places. Controls positioned for one-hand operation. Accurate low current measurements. Auto shut-off and dis-
play hold. Includes batteries, automatic low battery indicator, test leads, instruction card, safety sheet and carrying case. Operating temperature: -
14°F to 122°F. Safety rating: IEC 1010-1-032, 600V CAT III.
CLAMPMETERS
True RMS
Features AC/DC voltage, frequency and resistance measuring capability, easy to ready backlit display, and peak and data hold
to capture measurement.
Unit# 2936002
MULTIMETERS
Clamp-On
Measures AC amperage, AC/DC voltage, and resistance. Features 3-1/2 digit LCD and auto power off. Cat III 600V rating.
Measurement Range Dim. In. Max. Wire
No. Volts Amps Ohms HxWxD Sz.MCM
0727814 0to400,0to600 0to40,40to400 0to400 7.5x2.5x1.4 500
0712551 0 to 600 0 to 999.9 0 to 600, 601 to 6000 9.875 x 3.125 x 1.625 750
No. AMP Measurement Jaw Opening In. Description
CM-1550 400, 1000 2 AC/DC RMS
CM-850 400, 600 1.34 AC RMS
No.
Resist.
Ohms
Jaw
Open. In.
CM-600 2000 1.38
Meters & Testers
1-800-832-2297 103
MULTIMETERS
Digital  Clamp-On
Features True-RMS, resistance and capaci-
tance measurements, and min, max, average
and inrush recordings.
ELECTRICAL TESTERS
Provides automatic measurement of amper-
age, voltage and resistance. Features low
impedance to eliminate stray or ghost voltage
readings, auto off, and data hold to capture
important readings. Includes battery, test
leads and carrying case.
CLAMP-ON ADAPTERS
Flexible design for easy fishing around a con-
ductor. 3000A AC current measuring acces-
sory. Ideal for multimeter that read AC
millivolts. Includes battery.
Unit # 1303468635
PERSONAL VOLTAGE
DETECTORS
V-Watch®
Detects presence
of AC voltage
electric fields sur-
rounding electri-
cal equipment.
Designed to be
worn on outside
of clothing or
other protective
gear. Features
audible/visual
alarms that
increase in fre-
quency as device approaches energized
equipment. Includes rugged protective hous-
ing, low battery indication, field replaceable 9V
alkaline battery and built-in self-test system.
Measures 3.5 x 2.88 x 1.25.
Unit# 3881002
VOLTAGE DETECTOR KITS
Self Testing
Verifies live or
de-energized
conductors.
Features splined
universal end fit-
ting for use with
insulating rub-
ber gloves or hot
sticks. Bright
LED light and
audible signal
indicate voltage. Includes shotgun adapter, (3)
C batteries and case.
Unit# 3881010
VOLTAGE DETECTOR KITS
Audio/Visual
Verifies live or de-energized conductors. Fea-
tures splined universal end fitting for use with
insulating rubber gloves or hot sticks. Bright
LED light and audible signal indicate0 voltage.
Includes shotgun adapter, (3) C batteries
and case.
MEGOHMMETER/INSULATION
TESTERS
Features (4) different test voltages: 100, 250,
500 and 1000 DCV for spot and step voltage
testing. Measures insulation resistance up to
2000 MW, and an ohm range to 5000 W.
Guard terminal to eliminate surface leakage
current.
No. AC/DCA AC/DCV
374 600 600
376 1000 1000
No.
Jaw
Opening In. Description
CMT-80 1.06 600V/400A
CMT-90 1.34 1000V/600A
CMT-80 CMT-90
No. Description
CMAF-3000 Current flex 24 300/3KA AC
No.
Weight
Oz.
Operating
Temp.
ºF
Sensing
Threshold
Hz
VW-20H 5.2 -20 to +120 50/60
No.
Detection
Range
4556 120V to 230kV
No.
Detection
Range
4356 240V to 230kV
No. Description
212159 1kV
Meters & Testers
104 1-800-832-2297
INSULATION/CONTINUITY
TESTERS
Provides indication of insulation resistance up
to 999 MOhms, 20mA continuity testing and a
fast-acting continuity buzzer.
INSULATION/CONTINUITY
TESTERS
Designed for unique test voltage require-
ments. Provides insulation testing up to 1000
V and 300 GOhm. Features TRMS & DC volt-
age measurement, pass/fail limit alarms and
timer function.
SYNCHROSCOPE METERS
Features easy to read meter up to 30 feet
away. Rugged, durable construction.
VOLTMETER/NULL DETECTORS
Fluke
Standard/Differential Voltmeter Null Detector.
VOLTAGE DETECTORS
Amprobe  Non-Contact
Utility tool for checking transmission lines,
power distribution equipment, down power
lines, fuses and load break connectors. Lower
voltage setting for checking voltage presence
in breaker panels, breakers, power outlets,
and wiring.
TRANSFORMER TURNS RATIO
TESTERS
Used to measure the turns ratio, excitation
current and polarity of windings in single-
phase and three-phase distribution and power
transformers, potential and current transform-
ers, and tapped transformers...
TRANSFORMER TESTERS
Manual Self-Test
Single push-button operation provides clear
indications of open circuits, short circuits and
confirmation that the test results are OK.Can
be used for quick screenings of incoming and
outgoing transformers for both primary and
secondary shorts or opens (including internal
fuses and breakers. Includes case and
instructions.
No.
Test
Voltages
MIT320-EN 250, 500, 1000
MIT300 250, 500
No.
Test
Voltages
MIT400 250, 500, 1000
No. Accuracy
120452ADAA +/- 1% of Full Scale
No.
mA
Output
DC Voltage
Output Accuracy
335A 0 to 50 0V to 1100V 0.002%
No. Voltage
TIC 300 PRO 30 VAC to 122,000 VAC
No. Description
TTR20 Handheld TTR Transformer
Turns Ratio Tester
No. Description
TL-MAN-N TILTII with Manual Self-Test
Meters & Testers
1-800-832-2297 105
SUPER BEAST
Combo Package
Indicates problems on secondary service and
verifies condition of secondary conductors and
associated connections Isolates and identifies
overhead or underground complaints on utility
side and detects open neutral quickly an accu-
rately. Meters register from 84-264 VRMS
Includes Digital meters, meter base adapter
and bag.
MEGA BEAST
Now in 20 AMP increments, you can apply an
80 Amp load to detect the most elusive prob-
lems on secondary service. Also provides
fused and circuit breaker safety.
RANGEFINDERS
TruPulse
Measures distances and heights and comes
standard with a serial port. Offers in-scope
data display with 7x power optics and runs on
2AA batteries. Measures HD, VD, SD, INC
and HT. Features 3-shot height routine and is
available in yellow or grey.
Trupulse 200B. Capable of wireless data con-
nection...
Unit# 4329035
PHASING METERS
High Voltage  Digital
For circuit potential and URD cable testing
applications. Attaches to (2) 1-1/4 dia. x 16 L
fiberglass sticks. Universal female splines on
one end, (2) 2 dia. conductor hooks on other
end. Features LCD display in nearest 100V,
automatic shutoff, low battery indicator, and
coiled, self-retracting cable. Includes 9V bat-
tery and plastic case.
High Voltage Meters
Accessories
Unit# 4329036
REGULATOR NEUTRAL
DETECTORS
Digital
For use in verifying neutral position on regula-
tors. Measures 0 to 2000 Volts in 1V incre-
ments. Features LCD display, lighted meter
switch, low battery indicator, female universal
spline for use with hot sticks, and removable
knurled contact electrodes to aid conductor
contact. Includes 9V battery, carry case and
instructions.
Unit# 2851001
ELECTRICAL TESTERS
T+PRO
Detects voltage by light, sound and vibration,
allowing use in noisy, dimly lit or confined
areas. Features backlit LCD display, rotary
field indicator, continuity beeper, hazardous
voltage warning light, GFCI trip capability, auto
power off, built-in LED flashlight, test lead
strap, and probe holder. UL listed, CSA and
CE certified.
No. Wt. Lbs.
HJA-469-DSCO 8
No. Wt. Lbs.
HJA-900-D 6.2
No.
Wireless Data
Connection
Trupulse 200 No
Trupulse 200B Yes
No. kV
6702 0to40
No. Desc.
6702-1 Loadbreak bushing adapter
6702-2 DC HiPot adapter
No. Desc.
6709-1 Regulator neutral detector
No.
Voltage Indication
Levels
Dim. In.
LxWxH
T+PRO 12, 24, 48, 120, 208,
240, 277, 480 & 600
7.6 x 2.15
x 1.3
Meters & Testers
106 1-800-832-2297
Unit# 4329040
TRANSFORMER & CAPACITOR TESTERS
For testing new or trouble-shooting in-service transformers and capaci-
tors. Verifies units are not shorted or open prior to energizing. Features
magnetized back for hands-free operation, push button test feature,
and (4) LED condition status lights. Includes 9V battery, storage case
and instructions.
Unit# 1632014
PROTECTIVE GROUND SET
TESTERS
For checking resistance in electric utility
applications. Applies direct current across
test specimen. Features ball-stud terminals,
(2) troubleshooting probes, and self-test
cable. Includes videotape demonstration,
instruction manual and self-contained carry
case.
Unit# 1632024
PHASING TESTER KITS
Chance®
For determining phase relationships
and approximate volts in line-to-line
or line-to-ground applications.
Includes tester, hook probes, (2) 6-ft.
L x 1-1/4 dia. Epoxiglas® handles
with storage bag, case and instruc-
tion manual.
Unit# 4304001
LASER RANGE FINDERS
TruPulse 360
Measures distance, inclination, height, azimuth and distance between
remote points. Features in-scope LCD screen, and standard, closest,
farthest, continuous and filter modes. Displays in feet, yards, meters
and degrees. Impact, water and dust resistant. Accuracy: ±1 ft. dis-
tance; ±.25° inclination; ±1° azimuth.
Unit # 4299001
CARRY CASE LANYARDS
V-Watch®
For use with V-Watch personal voltage detector. Features pocket with
reflective band, lanyard lock and breakaway device, belt clip, accessory
tab and large zipper pull. Electrically shielded.
Unit# 1403001
ALKALINE BATTERIES
Industrial
Zero-mercury-added formula-
tion allows better discharge
with lower impedance.
No. Desc.
6793 Transformer and capacitor tester
No. Desc.
C4033220 Protective ground set tester
No. kV
H1876 16
No.
Distance
Ft.
Inclination
Deg.
Azimuth
Deg.
7005525 0 to 3280 ±90 0 to 359.9
No. Desc.
VW-LAN V-Watch carry case lanyard
No. Size
60424 AAA
60422 AA
60420 C
60421 D
60423 9V
60433 6V  Lantern
Meters & Testers
1-800-832-2297 107
Unit# 4318001
CUTOUT BYPASS TOOLS
Jack Jumper
For use in fuse coordination tasks. Allows bypass on overhead cutout
without use of jumper cables and permits bypass of underground dips.
Features stainless steel external spring.
Unit# 4318002
LOAD BREAK TOOLS
Load-Ranger® XLT
Lightweight design. Features 8.2 EST metal-to-metal clearance during
stroke for reduced flashover potential. Includes hard carry case.
LOAD BREAK & PICK-UP TOOL
BREAK-SAFE®
Lightweight and compact and functions as a portable switch to provide
repair/maintenance convenience and flexibility. Features locking safety
pin, and yellow indicator band to insure tool is fully closed.
ELBOW-MULE
Standard, insulated shotgun stick attachment designed to remove stub-
born seized elbows without applying destructive and dangerous kinetic
impact force. Measures 24 x 7 x 1.5.
ARRESTER TESTER
For use on systems from 4kV to 25kV phase-to-phase and up to 69kV
with optional R-69 add-on. Designed to warn user that an arrester is
damaged or deteriorating and should not be energized. Features built-
in universal splines for attachment to hotsticks, and easy-to-read meter
face.
CAPACITOR TESTERS
Cap Check®
Designed to test substation rack of capacitors. Housed in case with
handles. Requires 120-volt external power. Allows testing from 50 to
480 volts AC.
No.
Max.
Lgth. In. kV
USJJ-002-H 14.5 27
No. Amps kV
USLR-XLT-1-NC-H 900 27
No. Description
USBS-15-1-PS 15kV - 300 AMPs with floating head
USBS-15-2-PS 15kV - 300 AMPs with duckbill head
No. Description
USEP-15-27 15kV Elbow-Mule with storage bag
No. Description
AT-100 Arrester/Leakage Tester
No. Description
CC-II/100 Cap Check® Capacitor Tester
Meters & Testers
108 1-800-832-2297
INSULATOR TESTERS
Hi-Test®
Detects non-visible insulator failures before they cause operations diffi-
culties or safety threats to line crews. Can be used as routine mainte-
nance tool and to test de-energized insulators prior to installation.
Universal spline and 8VDC rechargeable battery.
DC LEAKAGE DETECTORS
High Voltage
Portable, general purpose dual voltage leakage tester designed to test
primary distribution voltage or secondary voltage equipment for faults
or high leakage currents. Use only on cable or equipment verified to be
both de-energized and discharged. Can be set to either 500VDC or
5000VCD.
ROPE TESTERS
Hi-Test®
Designed to test hot line ropes, slings and straps for dielectric integrity
at the time and location they are being used. For use on ropes from 3/8
dia to 1-1/2 dia. Features green and red LED, 8VDC rechargeable bat-
tery, and buzzer sound to alert defective rope.
No. Description
IT-4 Insulator Tester
No. Description
PT-5000W DC Leakage Detector
No. Description
TR-200 Hi-Test® Rope Tester
MANUFACTURERS
CATALOGS
We shall be glad to send
manufacturers catalogs and
other available publications
and data on request.
Rubber Blankets
& Line Hose
1-800-832-2297 109
Unit# 4329001
RUBBER BLANKET ROLL-UPS
For storage of rubber blankets. Vinyl construc-
tion. Features fiberglass staves for mechnical
protection against punctures. Safety yellow
color.
Unit# 1303461832
ROLL BLANKETS
Features flame, oil, ozone, puncture and tear
resistance. Rolls measure 3 W x 30 L.
Unit# 1303458802
INSULATING BLANKETS
Slotted Style
For covering ridge pins, cross arms with insu-
lators or anyplace a wire, pin or projection
interferes with proper placement of other
cover-up devices. Includes 28 eyelets.
Unit# 1303459732
INSULATING BLANKETS
Low Voltage
Made of Type II
SALCOR® ozone
resistant yellow
rubber. Class 0,
maximum use of
1000VAC. Mea-
sures 36 x 36.
2.2lbs.
No. 123LV. Mea-
sures 12 x 36.
Maroon.
Unit# 1303456968
INSULATING BLANKETS
Eyelet Style
Features reinforced beaded edge, eyelets for
added strength and ozone/tear-resistance.
No. 900E. Orange
Nos. 300E, 12, and 901E. Black
Unit# 1303467615
SWITCHBOARD MATTING
Provides personal protection for workers.
Used when tending take-up and pay out reels
and when adding or replacing conductors.
Placed in front of switchgear, motor control
centers and other high voltage apparatus.
Class 2. 1/4 thickness.
Unit# 1303470490
BLANKET CLAMP PINS
Holds insulating blankets/rubber cover-up in
place and has molded rubber tips to increase
slip resistance. Made of fiberglass reinforced
nylon or sliver-free hardwoods.
Unit# 1303472088
BLANKET CANISTERS
Molded in bright orange, hi-impact polyethyl-
ene. Tight-fitting cap is secured with polypro-
pylene rope. Slots are provided within to allow
it to be secured in buckets or on trucks.
Unit# 1303468434
MAGNETIC BLANKET BUTTONS
For use in eyelets of insulating blankets when
covering energized portions in hard-to-cover
areas like pad mounts, cubicles, switchboards
and substations. Features four permanent
floating magnets mounted between nickel-
plated steel plates.
No.
Blanket
Size In.
01-071 36 x 36
No.
ASTM
Class.
Weight
Lbs. Color
RLB00 0 20 Brown
RLB0 0 26 Yellow
RLBPVC1 1 36 Clear
No.
ASTM
Class Size In.
Weight
Lbs. Color
14 2 22 x 22 2-1/2 Black
1100 2 36 x 36 7 Black
1300 4 36 x 36 7 Orange
Check our website for
special promotions.
www.uscco.com
No. Style
3636YLVNV No velcro
3636YLV Velcro
123LV Velcro
No. Eyelets
ASTM
Class.
Size
In.
Weight
Lbs.
900E 6436x368
300E 6236x368
12 28 2 22x22 3
901E 6436x368
No.
Width
In.
Weight
Lbs.
M24-2 24 9
M36-2 36 15
No.
Length
In.
Jaw Opening
In.
Weight
Lbs.
21 9-1/2 5 0.37
No.
Dim.
In. Capacity
Weight
Lbs.
P2 5 x 37 1-2 blankets 2
P4 7 x 37 1-4 blankets 3-1/2
P6 9 x 37 1-6 blankets 5
No.
Weight
Oz.
MB6 7
Rubber Blankets
& Line Hose
110 1-800-832-2297
Unit# 3881012
LINE HOSE CONNECTORS
SU System
Connects extended lip hose to PTHL and LRG insulator covers, dead
end protectors and line hose. Constructed of Salcor® Type II elastomer
with Rib-Grip® for secure connection. Orange. Meets ASTM specifica-
tions.
Unit# 1303711583
CONNECTOR END LINE HOSES
Salcor®
Remains flexible in cold weather and is not damaged by ozone or ultra-
violet rays.
Unit# 1303713420
INSULATOR COVERS
Provides complete insulation at the joint regardless of varying distance
between pins. Used with conventional line hose to cover pin-type insu-
lators. Features RIB-GRIP construction to lock underside of insulators.
NOTES
No.
Dim. In.
LxH
For Line
Hose ID
UC 10-1/2 x 6 1-1/2
No.
ASTM
Class
I.D.
In.
Weight
Lbs.
Length
In.
OR100-6C 2 1 6-1/2 6
OR125-6C 2 1-1/4 9 6
OR125-45C 2 1-1/4 6-1/2 4-1/2
OR150-6C 3 1-1/2 9 6
OR150-45C 3 1-1/2 8 4-1/2
No. Class
Insulator
Class
Line Hose
Size In.
Dim.
In.
Weight
Lbs.
OKRG 355-5
1-1/4 to
1-1/2 16 x 8 7
OJRG 2 55-4 1 16 x 6-1/2 6
Traffic Control
1-800-832-2297 111
Unit# 2676001
WARNING FLAGS
Mesh weave construction with dowel handle.
Orange.
Unit# 5671001
TRAFFIC CONES
PVC
Features polyvinyl chloride construction. Fluo-
rescent orange. 10/carton.
MDI Worldwide
TRAFFIC CONES
PVC
Standard Slimline Traffic Cone with premium
grade PVC construction. Fluorescent orange
with (2) gray reflective bands and black base.
Unit# 5672001
MDI Worldwide
FOLDABLE ROAD SIGNS
MDI Compact®  One Lane Road
Ahead
Permanently mounted to foldable crossbrac-
ing to allow sign to fold down. Crossbracing
has single trigger release system for easy
deployment and take-down. Features super-
reflective orange polymeric microprism sheet-
ing and aluminum rivets.
No. DF-05079. Rectangular.
Unit# 5672002
MDI Worldwide
FOLDABLE ROAD SIGNS
MDI Compact®  Right Lane Closed
Ahead
Permanently mounted to foldable crossbrac-
ing to allow sign to fold down. Crossbracing
has single trigger release system for easy
deployment and take-down. Features super-
reflective orange polymeric microprism sheet-
ing and aluminum rivets. Includes changeable
legend allowing message to be changed with
overlay patch (sold separately).
Unit# 5672003
FOLDABLE ROAD SIGNS
MDI Compact®  Be Prepared To
Stop
Permanently mounted to foldable crossbrac-
ing to allow sign to fold down. Crossbracing
has single trigger release system for easy
deployment and take-down. Features super-
reflective orange polymeric microprism sheet-
ing and aluminum rivets.
No.
Flag
Dim. In.
Handle
Lgth. In.
01-02-896 18 x 18 24
Wall Thickness
No.
Height
In.
Top
In.
Bottom
In.
Wt.
Lbs.
28 PVCS 28 .075 .130 7
No.
Height
In.
Cone
Base
Wt.
Lbs.
P-39738 28 13 Square 7
No. Description
Size
In.
DF-03650 One Lane Road Ahead 36 or 48
DF-04103 Merge Left 48
DF-04204 Utility Work Ahead 48
DF-04411 Right Shoulder Closed
Ahead
DF-05079 End Road Work 48 x 24
DF-09699 Road Closed 36
No.
Size
In.
Weight
Lbs.
DF-03658 36 or 48 6.85
No.
Size
In.
Weight
Lbs.
DF-03766 36 or 48 6.85
Traffic Control
112 1-800-832-2297
Unit# 5672004
MDI Worldwide
FOLDABLE ROAD SIGNS
MDI Compact®  Flagger Ahead
Permanently mounted to foldable crossbrac-
ing to allow sign to fold down. Crossbracing
has single trigger release system for easy
deployment and take-down. Features super-
reflective orange polymeric microprism sheet-
ing and aluminum rivets.
2-POCKET SIGNS
Lexan
Can be used with all WindMaster® sign
stands. Signs are permanently attached to the
vertical fiberglass cross-bracing with rivets.
Cross-bracing flexes and horizontal ends slide
into the Lexan pockets to hold sign firmly in
place.
REFLECTIVE PADDLES
Stop/Slow
Highly visible in daylight and headlights. Con-
structed of semi-rigid plastic with red and
white on one side, orange and black on the
other. Optional handle or staff screw into pre-
drilled holes.
Signs
Accessories
SIGN STANDS
Windmaster Economy
For use with roll up signs. Sign
attaches with a Camlock sign
bracket (included). Features sin-
gle-spring base design and
adjustable, telescoping legs with
kick-release buttons.
SIGN STANDS
Windmaster
For use with roll up signs. Features dual-
spring base for wind resistance, kick-release
legs for easy set-up and telescoping legs for
stability.
SIGN STANDS
Windmaster
For use with roll up, aluminum, plywood, plas-
tic and aluminum laminate signs. Features
dual-spring base for wind resistance, Break-
Away® system, and kick-release legs for easy
set-up. Includes flag holder bracket.
CROSSBRACES
Interchangeable
1-1/4 Wide fiberglass crossbracing for dia-
mond-shaped DuraLatch® roll-up signfaces.
CROSSBRACES
Rectangular Signs
1-1/4 Wide fiberglass crossbracing with 4
plastic end caps and powder-coated steel flag
bracket. Holds rectangular 48 x 24 Dura-
Latch® Roll-Up sign.
No.
Size
In.
Weight
Lbs.
DF-04095 36 or 48 6.85
No. Description Size In.
DCF-03642 Flagger 36
DCF-03650 One Lane Road
Ahead 36
DCF-03765 Be Prepared to
Stop (compact) 36
DCF-03989 Workers Ahead
(compact no stand) 36
DCF-04201 Shoulder Work
Ahead (compact) 36
DCF-04204 Utility Work Ahead 48
No. Dim. In.
24RFA 24 x 24
No. Description
SA-35394 Hardwood staff, natural finish,
5H x 1.25 Dia.
No. Material
Dep.
Height
40CAMKD Steel 65
No. Material
Deployed
Height
4814DLK Aluminum 6 10-1/2
No. Material
Deployed
Height
4860KC-1 Aluminum 11 2 and 13 2
No. Description Size In.
DLX-03626 2 Flags 36
DLX-03628 2 Flags 48
DLX-03631 No Flags 48
No. Size In.
DX2-48W24H 48 x 24
Wire Stripping Tools
1-800-832-2297 113
Unit# 1728008
WIRE STRIPPER/CUTTERS
Klein-Kurve
For cutting, stripping, looping and gauging
solid or stranded wire. Also shears 6-32 and 8-
32 screws. Features curved handles with dou-
ble-dipped comfort grips and coil spring for
fast opening. 7-1/8 OAL.
WIRE STRIPPERS
Automatic
For use with solid and stranded wire.
Strips up to 7/8 length. Strips PVC and
THHN insulation.
Note: Not insulat
