C-Taps

Burndy T&B Die

Part Number Cat. Number Part Number

YGHC2C2 CTP22 HBKC

YGHC26C2 CTP202 15501A

YGHC26C26 CTP2020 15501A

YGHC29C26 CTP25020 15G86R

YGHC29C29 CTP250250 15G86R

YGHC34C26 CTP50020 15G121R

YGHC34C29 CTP500250 15G121R

YGHC34C34 CTP500500 15G121R

Insulation Piercing Connectors

Burndy T&B

Part Number Cat. Number Main Tap

BIPC1/0-2 IPC1102 1/0–8 2–8

BIPC4/0-6 IPC4111 4/0–1/0 1/0–6

BIPC4/0-1/0 IPC4141 4/0–1/0 4/0–1/0

— IPC5041 500–350 4/0–4

BIPC350-350 IPC3535 350–4/0 350–4/0

BIPC500-4/0 IPC3541 350–4/0 4/0–10

Copper Split Bolts

Burndy T&B Inner

Part Cat. Equal Main Min Tap w/ Pack

Number Number & Tap 1 Main Max Qty

KS90 9H 10–12 14 sol 100

KS15 8H 8–10 14 sol 100

KS17 6H 6–8 14 sol 100

KS20 4H 4–8 14 sol 100

KS22 2H 2–6 14 sol 100

KS25 10H 1/0–4 14 sol 50

KS26 20H 2/0–2 14 sol 25

KS27 30H 4/0–2 6 sol 25

KS29 40H 250–1 8 25

KS31 350M 350–250 1/0 str 1

KS34 500M 500–400 2/0 str 1

KS39 750M 1000–800 4/0 str 1

Dual-Rated Split Bolts

Burndy T&B Inner Pack Std Pkg

Part Number Cat. Number Qty Qty

KSU17 6HPS 100 600

KSU20 4HPS 100 400

KSU22 2HPS 100 400

KSU23 1HPS 25 100

KSU25 10HPS 50 200

KSA1/0 APS11 25 250

U-Bolt and Water Pipe Clamps

Burndy Part Number T&B Cat. Number

GAR1429 GUV7825

GAR3903 3903

GAR3905 3905

GUV

3903

Figure 6 to 6 Compression

Ground Grid Connectors

Burndy T&B Die

Part Number Cat. Number Part Number

YGL2C2 54855L 15501A

YGL29C2 54856L 15G86R,15501A

YGLC29C29 54875L 15G86R

YGL34C2 54885L 15G126R,15501A

YGL34C29 54895L 15G126R,15G86R

YGL34C34 54900L 15G121R

Figure 6 Compression Ground

Tap Connector

Burndy T&B Die

Part Number Cat. Number Part Number

YGHPC29C2 54855 15G86R

YGHP29C26 54860 15G86R

YGHP29C29 54865CK 15G86R

YGHP34C26 54890 15G126R

YGHP34C29 54895 15G126R

YGHP34C34 54900 15G126R

Dual-Rated Splicer/Reducer

Burndy T&B

Part Number Cat. Number Max Min

AMS2 ASR0214 2 14

AMS0 ASR1114 1/0 14

AMS250 ASR2506 250 6

AMS350 ASR3506 350 6

AMS750 ASR7525 750 250

Ground Clamps

T&B Cat.

Burndy Part Number Number

GRC12 FOR 1⁄2" ROD G4

GRC58 FOR 5⁄8" ROD G5

GRC34 FOR 3⁄4" ROD G6

H Taps

T&B Cat.

Burndy Part Number Number

YHO1 2–6 MAIN WITH 2–6 TAP WR159

YHO2 2–1/0 MAIN WITH 6–2 TAP WR189

YHD3 1/0–2/0 MAIN WITH 6–2 TAP WR289

YHD4 1–2/0 MAIN WITH 1–2/0 TAP WR279

YHD5 3/0–4/0 MAIN WITH 6–2 TAP WR379

YHD6 3/0–4/0 MAIN WITH 1–2/0 TAP WR399

YHD7 3/0–4/0 MAIN WITH 3/0–4/0 TAP WR419

Lay-In Lug

T&B Cat.

Burndy Part Number Number

BGBL250 250KCMIL–6AWG LL2506

BGBL-4 4–14AWG LL414

One-Hole Long-Barrel Lugs

T&B Cat.

Burndy Part Number Number

YA6C 6AWG COP 1H LUG 54905BE

YA4C 4AWG COP 1H LUG 54906BE

YA3C 3AWG COP 1H LUG 54942BE

YA2C 2AWG COP 1H LUG 54942BE

YA1C 1AWG COP 1H LUG 54947BE

YA25 1/0AWG COP 1H LUG 54949BE

YA26 2/0AWG COP 1H LUG 54910BE

YA27 3/0AWG COP 1HLUG 54965BE

YA28 4/0AWG COP 1H LUG 54970BE

YA29 250MCM COP 1H LUG 54913BE

YA31 350MCM COP 1H LUG 54915BE

YA34 500MCM COP 1H LUG 54919BE

Standard-Barrel Splices

T&B Cat.

Burndy Part Number Number

YS8CLBOX 8AWG COP BUTT SPLICE 54504

YS6CLBOX 6AWG COP BUTT SPLICE 54505

YS4CLBOX 4AWG COP BUTT SPLICE 54506

YS2CLBOX 2AWG COP BUTT SPLICE 54507

YS1CLBOX 1AWG COP BUTT SPLICE 54508

YS25LBOX 1/0AWG COP BUTT SPLICE 54509

YS27 3/0AWG COP BUTT SPLICE 54511

YS29LBOX 250MCM BUTT SPLICE 54513

Long-Barrel Splices

T&B Cat.

Burndy Part Number Number

YS8C 8AWG COP BUTT SPLICE 54804

YS6C 6AWG COP BUTT SPLICE 54805

YS4C 4AWG COP BUTT SPLICE 54506

YS2C 2AWG COP BUTT SPLICE 54807

YS3C 3AWG COP BUTT SPLICE 54807

YS1C 1AWG COP BUTT SPLICE 54808

YS25 1/0 AWG COP BUTT SPLICE 54509

YS26 2/0AWG COP BUTT SPLICE 54810

YS28 4/0AWG COP BUTT SPLICE 54812

YS29 250MCM COP BUTT SPLICE 54813

YS31 350MCM COP BUTT SPLICE 54815

YS34 500MCM COP BUTT SPLICE 54816

YS36 600MCM COP BUTT SPLICE 54820

Aluminum Splices

T&B Cat.

Burndy Part Number Number

YS4CA1 4AWG ALCU BUTT SPLICE 60512

YS2CA1 2AWG ALCU BUTT SPLICE 60516

YS26A1 2/0 ALCU BUTT SPLICE 60536

YS28A1 4/0 ALCU BUTT SPLICE 60548

YS31A1 350MCM ALCU BUTT SPLICE

60565

Two-Hole Long-Barrel Lugs

T&B Cat.

Burndy Part Number Number

YA6C2N 6AWG COP 2H LUG 54105

YA4C2N 4AWG COP 2H LUG 256-30695-733

YA2C2N 2AWG COP 2H LUG 54811BE

YA1C2N 1AWG COP 2H LUG 54857BE

YA252N 1/0AWG COP 2H LUG 256-30695-593

YA262N 2/0AWG COP 2H LUG 54862BE

YA272N 3/0AWG COP 2H LUG 54864BE

YA282N 4/0AWG COP 2H LUG 54866BE

YA292N 250MCM COP 2H LUG 54868BE

YA302N 300MCM COP 2H LUG 54870BE

YA312N 350MCM COP 2H LUG 54872BE

YA342N 500MCM COP 2H LUG 54876BE

YA362N 600MCM COP 2H LUG 54878BE

YA392N 750MCM COP 2H LUG 54880BE

One-Hole Standard-Barrel Lugs

T&B Cat.

Burndy Part Number Number

YA8CLBOX 8AWG COP 1H LUG 54104

YA8CL1BOX 8AWG COP 1H LUG 54130

YA8CL2BOX 8AWG COP 1H LUG 54131

YA8CL3BOX 8AWG COP 1H LUG 54132

YA6CLBOX 6AWG COP 1H LUG 54105

YA6CL1BOX 6AWG COP 1H LUG 54134

YA6CL3BOX AWG COP 1H LUG 54135

YA6CL4BOX 4AWG COP 1H LUG 54136

YA4CL1BOX 4AWG COP 1H LUG 54138

YA4CL3BOX 4AWG COP 1H LUG 54139

YA4CL4BOX 4AWG COP 1H LUG 54140

YA3CL 3AWG COP 1H LUG 54142-TB

YA2CLBOX 2AWG COP 1H LUG 54142-TB

YA2CL2BOX 2AWG COP 1H LUG 54107

YA2CL4BOX 2AWG COP 1HLUG 54143TB

YA1CLBOX 1AWG COP 1H LUG 54147

YA1CL4BOX 1AWG COP 1H LUG 54148

YA1CL6BOX 1AWG COP 1H LUG 54150

YA25LBOX 1/0AWG COP 1H LUG 54153TB

YA25L4BOX 1/0 AWG COP 1H LUG 54109

YA25L6BOX 1/0AWG COP 1H LUG 54155TB

YA26LBOX 2/0AWG COP 1H LUG 54110

YA26L6BOX 2/0AWG COP 1H LUG 54160

YA27L4BOX 3/0AWG 1H LUG 54111

YA27LBOX 3/0AWG COP 1H LUG 54165-TB

YA28LBOX 4/0AWG COP 1H LUG 54170

YA28L4BOX 4/0AWG COP 1H LUG 54112

YA29LBOX 250MCM COP 1H LUG 54113

YA31LTC38FX HYLUG 1 H LUG 256-30695-112

Copper Mechanical Connectors

T&B Cat.

Burndy Part Number Number

KA8C 1 COND. 8STR.–14SOL., 1H L35

KA4C 1 COND. 4STR.–14SOL., 1H L70

KA25 1 COND. 1/0STR.–8SOL., 1H L125BB

KA28 1 COND. 250KCMIL–6STR., 1H L250

KA34 1 COND. 500KCMIL–4/0STR., 1H

L400BB

Dual-Rated Mechanical Connectors

— 1 Conductor

T&B Cat.

Burndy Part Number Number

KA6U 6STR.–14AWG, 1H ADR6

KA2U 2STR.–14AWG, 1H ADR2

KA25U 1/0STR.–14AWG, 1H ADR11

KA26U 2/0STR.–14AWG, 1H ADR21

KA29U 250KCMIL–6STR, 1H ADR25

KA31U 350KCMIL–6STR., 1H ADR35

KA34U 500KCMIL–4STR., 1H ADR50

Dual-Rated Mechanical Connectors

— 2 Conductor

T&B Cat.

Burndy Part Number Number

K2A25U 1/0STR.–14AWG, 1H ADR11-21

K2A26U 2/0STR.–14AWG, 1H ADR21-21

K2A29U 250KCMIL–6STR., 1H ADR25-21

K2A31U 350KCMIL–6STR., 1H ADR35-21

KA40U 800KCMIL–300KCMIL, 1H ADR80-21

Dual-Rated Mechanical Connectors

— 3 Conductor

T&B Cat.

Burndy Part Number Number

K3A2U-2 2STR.–14AWG, 2H ADR02-32

K3A36U-2N 600KCMIL–2STR., 2H ADR60-32D

JDLI

AJ

Ground Clamps

T&B Cat.

Burndy Part Number Number

C11K16D BRONZE, 1⁄2"–1" PIPE JDLI

GC15A ALUM., 1⁄2"–1" PIPE AJ

GC18A ALUM., 1-1⁄2"–2" PIPE AJ2

AMT Connectors

T&B Cat.

Burndy Part Number Number

2 Port Same Side

BIT4 4–14STR. AMTC4

BIT2/0 2/0–14STR. AMT20

BIT250 250KCMIL–10STR. AMT250

2 Port Offset Splice

BITO4 4–14STR. AMTTC4

BITO2/0 2/0–14STR. AMTT20

Multiport Same Side

BIBS4-4 4 PORT 4–14STR. AMTS4144

BIBS2/0-3 3 PORT 3/0–6STR. AMTS3063

BIBS250-3 3 PORT 250KCMIL–6STR. AMTS25063

BIBS-350-4 4 PORT 350KCMIL–6STR. AMTS35064

BIBS600-4 4 PORT 750–250KCMIL AMTS7502504

Multiport Both Sides

BIBD4-2 2 PORT 4–14STR. AMTD4142

BIBD2/0-3 3 PORT 3/0–6STR. AMTD3063

BIBD2/0-4 4 PORT 3/0–6STR. AMTD3064

Aluminum Splice

BISR1/0 1/0–14STR. AMTSR10

BISR250 250KCMIL–6STR. AMTSR250

BI

SR500 5

00KCMIL–4STR. AMTSR500

Ground Clamps

T&B Cat.

Burndy Part Number Number

GRC12 FOR 1⁄2" ROD G4

GRC58 FOR 5⁄8" ROD G5

GRC34 FOR 3⁄4" ROD G6

H Taps

T&B Cat.

Burndy Part Number Number

YHO1 2–6 MAIN WITH 2–6 TAP WR159

YHO2 2–1/0 MAIN WITH 6–2 TAP WR189

YHD3 1/0–2/0 MAIN WITH 6–2 TAP WR289

YHD4 1–2/0 MAIN WITH 1–2/0 TAP WR279

YHD5 3/0–4/0 MAIN WITH 6–2 TAP WR379

YHD6 3/0–4/0 MAIN WITH 1–2/0 TAP WR399

YHD7 3/0–4/0 MAIN WITH 3/0–4/0 TAP WR419

Lay-In Lug

T&B Cat.

Burndy Part Number Number

BGBL250 250KCMIL–6AWG LL2506

BGBL-4 4–14AWG LL414

One-Hole Long-Barrel Lugs

T&B Cat.

Burndy Part Number Number

YA6C 6AWG COP 1H LUG 54905BE

YA4C 4AWG COP 1H LUG 54906BE

YA3C 3AWG COP 1H LUG 54942BE

YA2C 2AWG COP 1H LUG 54942BE

YA1C 1AWG COP 1H LUG 54947BE

YA25 1/0AWG COP 1H LUG 54949BE

YA26 2/0AWG COP 1H LUG 54910BE

YA27 3/0AWG COP 1HLUG 54965BE

YA28 4/0AWG COP 1H LUG 54970BE

YA29 250MCM COP 1H LUG 54913BE

YA31 350MCM COP 1H LUG 54915BE

YA34 500MCM COP 1H LUG 54919BE

Standard-Barrel Splices

T&B Cat.

Burndy Part Number Number

YS8CLBOX 8AWG COP BUTT SPLICE 54504

YS6CLBOX 6AWG COP BUTT SPLICE 54505

YS4CLBOX 4AWG COP BUTT SPLICE 54506

YS2CLBOX 2AWG COP BUTT SPLICE 54507

YS1CLBOX 1AWG COP BUTT SPLICE 54508

YS25LBOX 1/0AWG COP BUTT SPLICE 54509

YS27 3/0AWG COP BUTT SPLICE 54511

YS29LBOX 250MCM BUTT SPLICE 54513

Long-Barrel Splices

T&B Cat.

Burndy Part Number Number

YS8C 8AWG COP BUTT SPLICE 54804

YS6C 6AWG COP BUTT SPLICE 54805

YS4C 4AWG COP BUTT SPLICE 54506

YS2C 2AWG COP BUTT SPLICE 54807

YS3C 3AWG COP BUTT SPLICE 54807

YS1C 1AWG COP BUTT SPLICE 54808

YS25 1/0 AWG COP BUTT SPLICE 54509

YS26 2/0AWG COP BUTT SPLICE 54810

YS28 4/0AWG COP BUTT SPLICE 54812

YS29 250MCM COP BUTT SPLICE 54813

YS31 350MCM COP BUTT SPLICE 54815

YS34 500MCM COP BUTT SPLICE 54816

YS36 600MCM COP BUTT SPLICE 54820

Aluminum Splices

T&B Cat.

Burndy Part Number Number

YS4CA1 4AWG ALCU BUTT SPLICE 60512

YS2CA1 2AWG ALCU BUTT SPLICE 60516

YS26A1 2/0 ALCU BUTT SPLICE 60536

YS28A1 4/0 ALCU BUTT SPLICE 60548

YS31A1 350MCM ALCU BUTT SPLICE

60565

Two-Hole Long-Barrel Lugs

T&B Cat.

Burndy Part Number Number

YA6C2N 6AWG COP 2H LUG 54105

YA4C2N 4AWG COP 2H LUG 256-30695-733

YA2C2N 2AWG COP 2H LUG 54811BE

YA1C2N 1AWG COP 2H LUG 54857BE

YA252N 1/0AWG COP 2H LUG 256-30695-593

YA262N 2/0AWG COP 2H LUG 54862BE

YA272N 3/0AWG COP 2H LUG 54864BE

YA282N 4/0AWG COP 2H LUG 54866BE

YA292N 250MCM COP 2H LUG 54868BE

YA302N 300MCM COP 2H LUG 54870BE

YA312N 350MCM COP 2H LUG 54872BE

YA342N 500MCM COP 2H LUG 54876BE

YA362N 600MCM COP 2H LUG 54878BE

YA392N 750MCM COP 2H LUG 54880BE

One-Hole Standard-Barrel Lugs

T&B Cat.

Burndy Part Number Number

YA8CLBOX 8AWG COP 1H LUG 54104

YA8CL1BOX 8AWG COP 1H LUG 54130

YA8CL2BOX 8AWG COP 1H LUG 54131

YA8CL3BOX 8AWG COP 1H LUG 54132

YA6CLBOX 6AWG COP 1H LUG 54105

YA6CL1BOX 6AWG COP 1H LUG 54134

YA6CL3BOX AWG COP 1H LUG 54135

YA6CL4BOX 4AWG COP 1H LUG 54136

YA4CL1BOX 4AWG COP 1H LUG 54138

YA4CL3BOX 4AWG COP 1H LUG 54139

YA4CL4BOX 4AWG COP 1H LUG 54140

YA3CL 3AWG COP 1H LUG 54142-TB

YA2CLBOX 2AWG COP 1H LUG 54142-TB

YA2CL2BOX 2AWG COP 1H LUG 54107

YA2CL4BOX 2AWG COP 1HLUG 54143TB

YA1CLBOX 1AWG COP 1H LUG 54147

YA1CL4BOX 1AWG COP 1H LUG 54148

YA1CL6BOX 1AWG COP 1H LUG 54150

YA25LBOX 1/0AWG COP 1H LUG 54153TB

YA25L4BOX 1/0 AWG COP 1H LUG 54109

YA25L6BOX 1/0AWG COP 1H LUG 54155TB

YA26LBOX 2/0AWG COP 1H LUG 54110

YA26L6BOX 2/0AWG COP 1H LUG 54160

YA27L4BOX 3/0AWG 1H LUG 54111

YA27LBOX 3/0AWG COP 1H LUG 54165-TB

YA28LBOX 4/0AWG COP 1H LUG 54170

YA28L4BOX 4/0AWG COP 1H LUG 54112

YA29LBOX 250MCM COP 1H LUG 54113

YA31LTC38FX HYLUG 1 H LUG 256-30695-112

Copper Mechanical Connectors

T&B Cat.

Burndy Part Number Number

KA8C 1 COND. 8STR.–14SOL., 1H L35

KA4C 1 COND. 4STR.–14SOL., 1H L70

KA25 1 COND. 1/0STR.–8SOL., 1H L125BB

KA28 1 COND. 250KCMIL–6STR., 1H L250

KA34 1 COND. 500KCMIL–4/0STR., 1H

L400BB

Dual-Rated Mechanical Connectors

— 1 Conductor

T&B Cat.

Burndy Part Number Number

KA6U 6STR.–14AWG, 1H ADR6

KA2U 2STR.–14AWG, 1H ADR2

KA25U 1/0STR.–14AWG, 1H ADR11

KA26U 2/0STR.–14AWG, 1H ADR21

KA29U 250KCMIL–6STR, 1H ADR25

KA31U 350KCMIL–6STR., 1H ADR35

KA34U 500KCMIL–4STR., 1H ADR50

Dual-Rated Mechanical Connectors

— 2 Conductor

T&B Cat.

Burndy Part Number Number

K2A25U 1/0STR.–14AWG, 1H ADR11-21

K2A26U 2/0STR.–14AWG, 1H ADR21-21

K2A29U 250KCMIL–6STR., 1H ADR25-21

K2A31U 350KCMIL–6STR., 1H ADR35-21

KA40U 800KCMIL–300KCMIL, 1H ADR80-21

Dual-Rated Mechanical Connectors

— 3 Conductor

T&B Cat.

Burndy Part Number Number

K3A2U-2 2STR.–14AWG, 2H ADR02-32

K3A36U-2N 600KCMIL–2STR., 2H ADR60-32D

JDLI

AJ

Ground Clamps

T&B Cat.

Burndy Part Number Number

C11K16D BRONZE, 1⁄2"–1" PIPE JDLI

GC15A ALUM., 1⁄2"–1" PIPE AJ

GC18A ALUM., 1-1⁄2"–2" PIPE AJ2

AMT Connectors

T&B Cat.

Burndy Part Number Number

2 Port Same Side

BIT4 4–14STR. AMTC4

BIT2/0 2/0–14STR. AMT20

BIT250 250KCMIL–10STR. AMT250

2 Port Offset Splice

BITO4 4–14STR. AMTTC4

BITO2/0 2/0–14STR. AMTT20

Multiport Same Side

BIBS4-4 4 PORT 4–14STR. AMTS4144

BIBS2/0-3 3 PORT 3/0–6STR. AMTS3063

BIBS250-3 3 PORT 250KCMIL–6STR. AMTS25063

BIBS-350-4 4 PORT 350KCMIL–6STR. AMTS35064

BIBS600-4 4 PORT 750–250KCMIL AMTS7502504

Multiport Both Sides

BIBD4-2 2 PORT 4–14STR. AMTD4142

BIBD2/0-3 3 PORT 3/0–6STR. AMTD3063

BIBD2/0-4 4 PORT 3/0–6STR. AMTD3064

Aluminum Splice

BISR1/0 1/0–14STR. AMTSR10

BISR250 250KCMIL–6STR. AMTSR250

BI

SR500 5

00KCMIL–4STR. AMTSR500

Please ask your Thomas & Betts sales representative for a complete catalog

of quality Thomas & Betts electrical products or visit us at www.tnb.com.

For customer service, call 1-800-816-7809. For technical questions, call 1-888-862-3289.

© 2009 Thomas & Betts Corporation. All rights reserved. Printed in the U.S.A. 10/09/5M GM-8248

Thomas & Betts Corporation

Electrical Division

8155 T&B Boulevard

Memphis, TN 38125

901-252-5000

www.tnb.com

C-Taps

Burndy T&B Die

Part Number Cat. Number Part Number

YGHC2C2 CTP22 HBKC

YGHC26C2 CTP202 15501A

YGHC26C26 CTP2020 15501A

YGHC29C26 CTP25020 15G86R

YGHC29C29 CTP250250 15G86R

YGHC34C26 CTP50020 15G121R

YGHC34C29 CTP500250 15G121R

YGHC34C34 CTP500500 15G121R

Insulation Piercing Connectors

Burndy T&B

Part Number Cat. Number Main Tap

BIPC1/0-2 IPC1102 1/0–8 2–8

BIPC4/0-6 IPC4111 4/0–1/0 1/0–6

BIPC4/0-1/0 IPC4141 4/0–1/0 4/0–1/0

— IPC5041 500–350 4/0–4

BIPC350-350 IPC3535 350–4/0 350–4/0

BIPC500-4/0 IPC3541 350–4/0 4/0–10

Copper Split Bolts

Burndy T&B Inner

Part Cat. Equal Main Min Tap w/ Pack

Number Number & Tap 1 Main Max Qty

KS90 9H 10–12 14 sol 100

KS15 8H 8–10 14 sol 100

KS17 6H 6–8 14 sol 100

KS20 4H 4–8 14 sol 100

KS22 2H 2–6 14 sol 100

KS25 10H 1/0–4 14 sol 50

KS26 20H 2/0–2 14 sol 25

KS27 30H 4/0–2 6 sol 25

KS29 40H 250–1 8 25

KS31 350M 350–250 1/0 str 1

KS34 500M 500–400 2/0 str 1

KS39 750M 1000–800 4/0 str 1

Dual-Rated Split Bolts

Burndy T&B Inner Pack Std Pkg

Part Number Cat. Number Qty Qty

KSU17 6HPS 100 600

KSU20 4HPS 100 400

KSU22 2HPS 100 400

KSU23 1HPS 25 100

KSU25 10HPS 50 200

KSA1/0 APS11 25 250

U-Bolt and Water Pipe Clamps

Burndy Part Number T&B Cat. Number

GAR1429 GUV7825

GAR3903 3903

GAR3905 3905

GUV

3903

Figure 6 to 6 Compression

Ground Grid Connectors

Burndy T&B Die

Part Number Cat. Number Part Number

YGL2C2 54855L 15501A

YGL29C2 54856L 15G86R,15501A

YGLC29C29 54875L 15G86R

YGL34C2 54885L 15G126R,15501A

YGL34C29 54895L 15G126R,15G86R

YGL34C34 54900L 15G121R

Figure 6 Compression Ground

Tap Connector

Burndy T&B Die

Part Number Cat. Number Part Number

YGHPC29C2 54855 15G86R

YGHP29C26 54860 15G86R

YGHP29C29 54865CK 15G86R

YGHP34C26 54890 15G126R

YGHP34C29 54895 15G126R

YGHP34C34 54900 15G126R

Dual-Rated Splicer/Reducer

Burndy T&B

Part Number Cat. Number Max Min

AMS2 ASR0214 2 14

AMS0 ASR1114 1/0 14

AMS250 ASR2506 250 6

AMS350 ASR3506 350 6

AMS750 ASR7525 750 250
