Sun Winch

Grow Light Lift Kit

Congratulations on your purchase of a state of the

art wireless Sun Winch™ Grow Light Lift System!

To ensure that you get the most out of your Sun Winch™ lift kit, please

read these instructions completely and carefully BEFORE installing or

operating your system.

The Sun Winch™ lift system is designed to control a total lighting load of

not more than 50 pounds. Ensure that the light, ballast (if required) and any

hood vent hardware DOES NOT EXCEED 50 pounds.

SunWinch™ Kit Components

• 2SunWinchLiftMotors

 • 1Receiver

 • 1PowerSupply

 • 2LiftMotorCords

 • 3MountingRailSections

TooperateyourSunWinch™GrowLightLiftSystemyouwillneedto

purchaseaSunWinch™Remote.Eachremoteisdesignedtocontrol

8 Sun Winch™ lift kits. The SunWinch™ Remote is sold separately.

Scan here for

instructional video

TM

Product #710180

2

INSTALLATION

1.nInstallthe3mountingrailsectionsintoanexistingoverhead

support using the screws provided. It is the user responsibility to

ensure that the support used is adequate to bear the weight of the

lift system and grow light with associated hardware. The center

holesonthe2outsidemountsshouldbespacedtoaccommodate

the length of the grow light mounts.

2.nRemoveoneSunWinch™LiftMotorandmountitononeofthe

outsiderails.EnsurethepinintheLiftMotormountalignswiththe

center hole in the rail.

3.nRemovethesecondSunWinch™LiftMotorandmountitonthe

otheroutsiderail.EnsurethepinintheLiftMotormountalignswith

the center hole in the rail.

4.nRemovetheReceivermoduleandmountitonthecenterrailsection.

5.nAttachoneend ofaLift MotorcordtotheReceiver module.

AttachtheotherendtotheLiftMotor.

6.nAttachthesecondLiftMotorcordasdescribedabove.

7.nAttachoneendofthepowersupplytotheReceivermodule.Plug

theotherendofthepowersupplyintoanappropriate120Vsingle

phase electrical outlet.

The system is now ready to operate. Each Sun Winch™Liftreceiveris

pre-assignedtostation#1.EachSunWinch™LiftSystemRemote

is designed to independently control 8 different grow light setups.

WARNING: If you wish to control two grow light setups independently,

YOU MUST assign each receiver a separate station number.

Receiver shown.

Each receiver can be assigned

a single station number from 1 to 8.

3

OPERATION

To lift your grow light to the desired height, press the station button

once and then a direction button. HOLD DOWN the direction button

untilthedesiredheightisreached.Releasethedirectionbutton.

PROGRAM STATION NUMBER

YourSunWinch™Liftreceiverispre-programmedtoSTATION1.

To change the station number of a receiver, read the following instructions.

Remove the cover on the receiver by removing the four small

screws. Decide what number you wish to use and remove the jumpers

on the station ID DIP switches on the receiver board. See matrix

below for proper position of the jumpers.

Dip switches with jumpers

Uncovered dip switch

Station #8 configuration shown.

Dip switches identified by numbers on right.

Dip

Switch#

Station

#1

Station

#2

Station

#3

Station

#4

Station

#5

Station

#6

Station

#7

Station

#8

1••••

2• • • •

4• • • •

8•••••••

= Dip switch with jumper Blank = Uncovered dip switch

•

4
