DOOR ENTRY SYSTEMS & KITS
KIT VIDEO VIP 1/4 OVERVIEW
8561V
QUADRA KIT AND MINI WI-FI/GW. VIP SYSTEM
The technical specifications are subject to variations without warning.
The kit consists of No. 1 Quadra external video entry unit for ViP kits art. 4899K, No. 1 power supply unit art.1441B, No. 1 network switch
art.1440 and No. 1 Mini handsfree Wi-Fi monitor art. 6742WK. The kit is pre-programmed and ready for use. The kit is expandable with
other VIP catalog products. Compatible with H.264 video format.
DOOR ENTRY SYSTEMS & KITS
KIT VIDEO VIP 2/4 KIT PRODUCT
8561V
QUADRA KIT AND MINI WI-FI/GW. VIP SYSTEM
The technical specifications are subject to variations without warning.
KIT PRODUCT
6742WK White HF Mini Monitor WI-FI/GW for ViP KIT
MAIN FEATURES - 6742WK
Audio system: No
Audio/video system: Yes
Flush-mounted: No
Wall-mounted: Yes
Desk base-mounted: Yes
Hands-free function: Yes
Induction loop function: Yes
Type of display: LCD
Display size (inches): 4,3'' 16:9
Touch screen display: Yes
Display resolution (H x V): 480x272
B/W or colour display: Color
Product colour: White
Sensitive Touch technology: Yes
Total buttons: 8
LED signaling (No.): 4
Wi-Fi Port: Yes
Comaptibility with Video Entry Comelit App : Yes
4899K QUADRA external unit for ViP KIT
MAIN FEATURES - 4899K
Type: Monoblock entrance panel
Type of finish: Alluminio pressofuso
Wall-mounted: Yes
Camera: Colors
DOOR ENTRY SYSTEMS & KITS
KIT VIDEO VIP 3/4 KIT PRODUCT
8561V
QUADRA KIT AND MINI WI-FI/GW. VIP SYSTEM
The technical specifications are subject to variations without warning.
MAIN FEATURES - 4899K
Power supply: PoE (Class 0) / VIP (37 ÷ 57 VDC)
Signaling LED: Call sent, lock-release activated, audio activated, system busy
Buttons to call: Yes
Total buttons: 1
Loudspeaker volume control: Yes
PoE Ethernet switch with 2 ports (10/100 Mb) and 4 ports (10 MB). Dimensions 66 x 85 x 35 mm
1440 NETWORK SWITCH 4 PORT
PoE Ethernet switch with 2 ports (10/100 Mb) and 4 ports (10 MB). Dimensions 66 x 85 x 35 mm
MAIN FEATURES - 1440
Product height (inches): 3.5
Product width (inches): 2.83
Product depth (inches): 2.44
Operating temperature (°F): 41 ÷ 104
RH max operating humidity (%): 25 ÷ 75
DIN rail mounted: Yes
DIN modules (no.): 4
Power supply unit with 110Vac/240Vac input and 48Vdc output. 30W power. DIN bar power supply unit (4
DIN modules). Dimensions: 72x93x56mm
1441B 30W VIP SYSTEM POWER SUPPLY UNIT
Power supply unit with 110Vac/240Vac input and 48Vdc output. 30W power. DIN bar power supply unit (4
DIN modules). Dimensions: 72x93x56mm
MAIN FEATURES - 1441B
Alternating input voltage (VAC): 110÷240
Number of DIN modules: 4
DOOR ENTRY SYSTEMS & KITS
KIT VIDEO VIP 4/4 ACCESSORIES
8561V
QUADRA KIT AND MINI WI-FI/GW. VIP SYSTEM
The technical specifications are subject to variations without warning.
ACCESSORIES
PoE Ethernet switch with 2 ports (10/100 Mb) and 4 ports (10 MB). Dimensions 66 x 85 x 35 mm
1440 NETWORK SWITCH 4 PORT
PoE Ethernet switch with 2 ports (10/100 Mb) and 4 ports (10 MB). Dimensions 66 x 85 x 35 mm
Power supply unit with 110Vac/240Vac input and 48Vdc output. 30W power. DIN bar power supply unit (4 DIN
modules). Dimensions: 72x93x56mm
1441B 30W VIP SYSTEM POWER SUPPLY UNIT
Power supply unit with 110Vac/240Vac input and 48Vdc output. 30W power. DIN bar power supply unit (4 DIN
modules). Dimensions: 72x93x56mm
4899K QUADRA external unit for ViP KIT
6742WK White HF Mini Monitor WI-FI/GW for ViP KIT
